Multiroom Link
User Manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
• Supported devices : The function is available for all 2014 models that support Multiroom Link.
• Sound quality may be affected by the condition of the wireless network.
• The network connection can be negatively affected and even lost if the network environment
deteriorates over time.
AA Connecting to Your Network
1 All the devices need to connect to the same router.
2 The Multiroom App can only be used with Wireless Audio Multirooms or a Soundbar which has the Multiroom
Link function.
❚❚ Connecting to a network if you do not have a HUB.
Internet
TV
Home Entertainment
System
Soundbar
Wireless Router
Wireless Audio Multiroom
Blu-ray Disc Player
Link Mate
Smart Devices
(Android or iOS)
• If you have a HUB, you can connect more easily.
If you want to connect to a HUB, refer to the manual for each device.
44
2
❚❚ Connecting to a network if you have a HUB.
Internet
TV
Soundbar
Home Entertainment
System
Wireless Router
HUB
Blu-ray Disc Player
Wireless Audio Multiroom
Link Mate
Smart Devices
(Android or iOS)
• If you have a HUB, you can connect more easily.
If you want to connect to a HUB, refer to the manual for each device.
• HUBs may not be available in all countries and regions.
If you want to purchase a HUB, please contact or visit the dealer you purchased your Wireless
Audio Multiroom from or contact the Samsung Customer Care Center.
44
3
AA Grouping
❚❚ Grouping Devices So You Can Listen to the Same Audio from Each Device
• With grouping, you can listen to the same music or audio from several devices.
Home Entertainment
System
Same Sound
Soundbar
Wireless Audio
- Multiroom
`` Setting Up Grouping with the Multiroom App
Group
Multiroom Audio 1
Multiroom Audio 1
MultiroomAudio
Audio11++ [Samsung]
[Samsung]
Multiroom
To create a new group.
Choose some speakers.
choose some speakers.
No Music
No Music
Select
All
No Music
Multiroom Audio 1
No Music
Source
Surround
Group
[Samsung] Soundbar 1
No Music
Source
Surround
Source
Surround
Group
[Samsung] Soundbar 1
[Samsung] Soundbar 2
[Samsung] Soundbar 1
Soundbar 1
[Samsung] Soundbar 1
Cancel
No Music
Group
Multiroom Audio 1
Source
Surround
Done
Group
Soundbar 2
Source
Edit
Ungroup
AA Multiroom Mode vs Surround Mode
Multiroom Mode
Specified Use
Restrictions
Surround Mode
Place a number of Multiroom speakers
You can listen to the same audio from
in the same space and listen to surround
several speakers in each separate space.
sound.
The audio from each device may lag
Cannot be used with multiple units in
behind the video and audio of the device
different rooms or spaces.
which is playing the source content.
44
4
Remark
AA Listening to Audio or Music in Multiroom Mode
❚❚ Listening to TV Audio from Devices in Multiple Rooms
• You can listen to the sound from your TV through a Home Theater, Soundbar, or Wireless Audio Multiroom.
• The sound from each device may lag behind the video and audio on the TV.
• You can set up Multiroom TV audio using the Multiroom App or the menu on your TV. See the instructions below.
Home Entertainment System
Soundbar
Wireless Router
TV
Wireless Audio Multiroom
`` Setting Up Multiroom TV Audio Using the Multiroom App
[Samsung] M* 1
Source
[Samsung] M* 1
No Music
Multiroom
Audio 1
Wi-Fi
Listen to stored music from other
devices and online streams.
No Music
No Music
[HTS]Model Name 1
[TV] Samsung Model Name 1
Source
Surround
Group
Source
[Samsung] Soundbar 1
Group
Source
Group
Source
AUX
No Music
Cancel
Surround
Group
Source
OK
Surround
`` Setting Up Multiroom TV Audio Using Your TV's Menu
• Settings ; Sound ; Speaker Settings ; Multiroom Link ; Multiroom
Settings
Multiroom Link
[HTS]Model [HTS]Model [Samsung]
Name 1
Name 2
Soundbar 1
[Samsung]
M* 2
Settings
Multiroom Link
Multiroom
[Samsung]
Soundbar 2
[Samsung]
M* 1
[HTS]Model [HTS]Model
Name 1
Name 2
[Samsung]
M* 3
Settings
Multiroom Link
[Samsung]
M* 2
[Samsung]
M* 3
Speaker Settings
Multiroom
Multiroom
[Samsung]
M* 1
Use
Don't Use
Multiroom Link
w
~ SettingsSurround
q
TV Sound Output
XX XXXXXXXXXXX
~ XX XXXXXXXXXXX
XX XXXXXXXXXXX
[HTS]Model [HTS]Model [Samsung]
Name 1
Name 2
Soundbar 1
[Samsung]
M* 2
[Samsung]
Soundbar 2
~ XX XXXXXXXXXXX
~ XX XXXXXXXXXXX
[Samsung]
M* 1
Multiroom Link
[Samsung]
M* 3
OK
44
5
Group
[Samsung] Soundbar 1
No Music
Surround
Surround
TV soundbar
Bluetooth
[Samsung] Soundbar 2
No Music
Source
Surround
Group
❚❚ Listening to Home Theater Audio from Devices in Multiple Rooms
• You can listen to audio from your Home Theater through another Home Theater, a Soundbar, or a Wireless Audio
Multiroom.
• You can set up Multiroom Home Theater audio using the Multiroom App or the menu on your Home Theater. See
the instructions below.
Home Entertainment System
Soundbar
Wireless Router
Home Entertainment
System
Wireless Audio Multiroom
`` Setting Up Multiroom Home Theater Audio Using the Multiroom App
[Samsung] M* 1
Source
[Samsung] M* 1
No Music
Multiroom
Audio 1
Wi-Fi
Listen to stored music from other
devices and online streams.
No Music
No Music
[HTS]Model Name 1
[HTS]Model Name 2
Source
Surround
Group
Source
[Samsung] Soundbar 1
Group
Source
Group
Source
AUX
No Music
Cancel
Surround
Group
Source
Surround
`` Setting Up Multiroom Home Theater Audio Using Your Home Theater's Menu
• Settings ; Sound ; Speaker Settings ; Multiroom Link
Multiroom Link
Multiroom
Select a speaker to use.
Multiroom Link
[Samsung] Soundbar 1
Don't Use
[Samsung] Soundbar 2
Don't Use
[Samsung] [Samsung]
Soundbar 1 Soundbar 2
Select a speaker to use.
Edit Name
Close
Multiroom Link
[Samsung] Soundbar 1
Use
[HTS]Model Name 2
Don't Use
Multiroom Link
Edit Name
[Samsung] [Samsung]
Soundbar 1 Soundbar 2
Close
44
6
Group
[Samsung] Soundbar 1
No Music
Surround
Surround
TV soundbar
Bluetooth
[Samsung] Soundbar 2
No Music
Source
Surround
Multiroom
OK
Group
❚❚ Listening to Blu-ray Player Audio from Devices in Multiple Rooms
• You can listen to audio from your Blu-ray through a Home Theater, Soundbar, or Wireless Audio Multiroom.
• You can set up Multiroom Blu-ray audio using the Multiroom App or the menu on your Blu-ray player. See the
instructions below.
Home Entertainment System
Soundbar
Wireless Router
Blu-ray Disc Player
Wireless Audio Multiroom
`` Setting Up Multiroom Blu-ray Audio Using the Multiroom App
[Samsung] M* 1
Source
[Samsung] M* 1
No Music
Multiroom
Audio 1
Wi-Fi
Listen to stored music from other
devices and online streams.
No Music
No Music
[BD]Model Name 1
[BD]Model Name 2
Source
Surround
Group
Source
[Samsung] Soundbar 1
Surround
Group
Source
Source
Surround
AUX
No Music
Cancel
Group
Group
[Samsung] Soundbar 1
No Music
Group
Surround
TV soundbar
Bluetooth
[Samsung] Soundbar 2
No Music
Source
Surround
Source
Surround
OK
Group
`` Setting Up Multiroom Blu-ray Audio Using Your Blu-ray Player's Menu
• Settings ; Sound ; Speaker Settings ; Multiroom Link
Multiroom Link
[Samsung] [Samsung]
Soundbar 1 Soundbar 2
Multiroom
Multiroom Link
[Samsung]
Soundbar 1
Multiroom
Use
Multiroom Link
[Samsung] [Samsung]
Soundbar 1 Soundbar 2
Don't Use
44
7
Multiroom
AA Listening to Audio or Music in Surround Sound Mode
• The Surround Sound mode will be updated soon.
• If the audio source is in 2-channel format, sound will be produced only through the speakers that correspond to
Front Left and Front Right.
• If the network connection is not stable, Surround Sound Mode may be cancelled automatically.
• When setting Surround Sound Mode, setting speakers of equal output power as both Front Left and Front Right
is recommended.
❚❚ Listening to Surround Sound Using Several Audio Devices
• You can set up Surround Sound mode using the Multiroom App or the menu on your TV. See the instructions
below.
`` Setting Up TV Surround Sound Using the Multiroom App
Source
[Samsung] M* 1
[TV] Samsung Model Name 1
No Music
Source
[TV] Samsung Model Name 1
Noyour
Music
Connect
speakers and
[TV] Samsung Model Name 1 via Wi-Fi to
enjoy surround sound.
Surround
Group
Source
TV soundConnect
Surround
Source
Group
Bluetooth
[Samsung] M*2
Cancel
Surround
Surround
Group
[Samsung] M*2
[Samsung]
Soundbar 1
AUX
No Music
Source
[Samsung] M* 1
Wi-Fi
Multiroom
Audio 1
No Music
OK
Group
Source
Surround
Group
Stereo & Surround : Setup
Stereo & Surround : Setup
Stereo & Surround : Setup
1. Select the number of channels you
would like to set up.
1. Select the number of channels you
would like to set up.
1. Select the number of channels you
would like to set up.
Multiroom
Audio 1
2CH
[Samsung] M* 1
Front L
Multiroom
Audio 1
2CH
[Samsung] M* 1
Front L
Front R
2CH
[Samsung] M* 1
Front L
Front R
Multiroom Audio 1
Multiroom Audio 1
[Samsung] Soundbar 1
[Samsung] Soundbar 1
[Samsung] M* 2
Front R
2. Drag speakers to the positions that
best match your desired layout.
2. Drag speakers to the positions that
best match your desired layout.
2. Drag speakers to the positions that
best match your desired layout.
[Samsung] M* 2 [Samsung] M* 3 [Samsung] M* 4
[Samsung] M* 2 [Samsung] M* 3 [Samsung] M* 4
[Samsung] M* 3 [Samsung] M* 4 [Samsung] M* 5
Source
Cancel
Source
Cancel
Surround
Group
Next
Surround
Group
Next
Cancel
Next
`` Setting Up TV Surround Sound Using Your TV's Menu
• Settings ; Sound ; Speaker Settings ; Multiroom Link ; Surround
Settings
Multiroom Link
2CH
Front Left
Settings
Multiroom Link
Surround
Front Right
Front Left
2CH
[Samsung] M* 1
Surround
Front Right
[Samsung] M* 2
[Samsung] Soundbar 1
[Samsung] Soundbar 2
Settings
Multiroom Link
Front Left
2CH
Speaker Settings
Surround
Multiroom Link
w
~ SettingsSurround
q
TV Sound Output
XX XXXXXXXXXXX
~ XX XXXXXXXXXXX
Front Right
XX XXXXXXXXXXX
~ XX XXXXXXXXXXX
~ XX XXXXXXXXXXX
[Samsung] M* 1
Multiroom Link
OK
44
8
❚❚ Listening to Surround Sound Using a Soundbar and Multiroom Audio Devices
• You can set up Surround+Soundbar mode using the Multiroom App or the menu on your TV. See the instructions below.
• If the audio source transferred to the Soundbar is encoded in DTS format, sound will be produced
only through the speakers that correspond to Front Left and Front Right.
`` Setting Up Surround+Soundbar Mode Using the Multiroom App
Source
[Samsung] Soundbar 1
[TV] Samsung Model Name 1
No Music
Source
[TV] Samsung Model Name 1
Noyour
Music
Connect
speakers and
[TV] Samsung Model Name 1 via Wi-Fi to
enjoy surround sound.
Surround
Group
Source
TV soundConnect
Surround
Cancel
Group
Source
Front L+R
[Samsung] Soundbar
[Samsung] Soundbar
Surround L
[Samsung] M* 1
Surround R
Group
Surround R
Move the speaker by dragging it to the
desired location.
Move the speaker by dragging it to the
desired location.
[Samsung] M* 1 [Samsung] M* 2 [Samsung] M* 3 [Samsung]...
[Samsung] M* 2 [Samsung] M* 3 [Samsung] M* 4
Cancel
Surround
Stereo & Surround : Setup
Front L+R
Surround L
Group
No Music
OK
Stereo & Surround : Setup
Surround
[Samsung] Soundbar 2
[Samsung]
Soundbar 1
AUX
No Music
Surround
Source
Group
Bluetooth
[Samsung] Soundbar 2
Source
[Samsung] Soundbar 1
Wi-Fi
Multiroom
Audio 1
Next
Cancel
Next
`` Setting Up TV Surround +Soundbar Mode Using Your TV's Menu.
• Settings ; Speaker Settings ; Multiroom Link ; Soundbar+Surround
Speaker Settings
Settings
Multiroom Link
TV Sound Output
Soundbar+Surround
Multiroom Link
w
Surround
q
XXXXXXXX
~ XXXXXXXX
XXXXXXXX
Surround Left
~ XXXXXXXX
~ XXXXXXXX
Surround Right
Multiroom Link
~ Settings
OK
Volume Level
OK
Speaker Test
44
9
