Sony MFC-240C User's Manual

Quick Setup Guide
MFC-240C
Before you can use the machine, you must set up the hardware and install the software.
Please read this Quick Setup Guide for the correct setup procedure and installation instructions.
STEP 1
Setting Up the Machine
STEP 2
Installing the Driver & Software
Setup is Complete!
Keep this Quick Setup Guide, the User’s Guide and the supplied CD-ROM in a convenient place for
quick and easy reference at all times.
Symbols used in this guide
Warning
Warnings tell you what to do to prevent
possible personal injury.
Caution
Improper Setup
Improper Setup icons alert you to
Cautions specify procedures you must
devices and operations that are not
follow or avoid to prevent possible
damage to the machine or other objects. compatible with the machine.
Note
User’s Guide or Software User’s Guide
Notes tell you how you should respond
to a situation that may arise or give tips
about how the current operation works
with other features.
Indicates reference to the User’s Guide
or Software User’s Guide we have
supplied.
Table of Contents
Getting Started
Carton components ...................................................................................................................................... 2
Control panel................................................................................................................................................ 3
STEP1 – Setting Up the Machine
Removing the protective parts ..................................................................................................................... 4
Loading paper .............................................................................................................................................. 4
Connecting the phone line ........................................................................................................................... 6
Connecting the power cord .......................................................................................................................... 6
Set Your Country (For Australia / New Zealand Customer Only)................................................................. 7
Installing the ink cartridges........................................................................................................................... 7
Print quality check ...................................................................................................................................... 10
Choosing your language ............................................................................................................................ 10
Setting the LCD contrast ............................................................................................................................ 11
Setting the date and time ........................................................................................................................... 11
Setting your station ID ................................................................................................................................ 12
Setting tone or pulse dialling mode (not available for New Zealand) ......................................................... 12
Choosing a Receive Mode ......................................................................................................................... 13
STEP2 – Installing the Driver & Software
Windows®
For USB Interface Users
(For Windows® 98/98SE/Me/2000 Professional/XP/XP Professional x64 Edition) ................................... 16
Macintosh®
For USB Interface Users
(For Mac OS® X 10.2.4 or greater) ........................................................................................................... 19
Uninstalling the ‘MFL-Pro Suite’
For instractions on how to uninstall the MFL Pro Suite software ............................................................... 22
Uninstalling for Windows............................................................................................................................ 22
Uninstalling for Macintosh .......................................................................................................................... 22
How to uninstall the Printer Driver: ....................................................................................................... 22
How to uninstall the Scanner Driver:..................................................................................................... 22
Consumables
Replacement consumables ........................................................................................................................ 23
Ink cartridge .......................................................................................................................................... 23
1
Getting Started
1
Carton components
Carton components may vary from one country to another.
Save all packing materials and the carton in case for any reason you must ship your machine.
Quick Setup Guide
CD-ROM
User’s Guide
Telephone Line Cord
Power Cord
Telephone Line Cord Adapter
(For Australia only)
Black (LC57BK)
Yellow (LC57Y)
Cyan (LC57C)
Magenta (LC57M)
Ink Cartridges
A USB interface cable is not a standard accessory.
Australia & New Zealand users:
Hong Kong, Malaysia & Singapore users:
The mains plug supplied with this machine is a grounded three pin plug. Make sure that the AC socket will accept this
grounded three pin plug. This machine must be grounded, If in doubt, call a qualified electrician.
Philippines & Thailand users:
The mains plug supplied with this machine is a side grounded two pin plug. Make sure that the AC socket
will accept this side grounded two pin plug. This machine must be grounded, If in doubt, call a qualified
electrician.
„ To ensure safe operation the supplied plug must be inserted only into a standard power outlet that is properly
grounded through the standard electrical wiring. Non grounded equipment may cause an electrical shock
hazard, and may cause excessive electrical noise radiation.
„ Please make sure you use a USB 2.0 cable that is no longer than 2 metres (6 feet) long.
„ Your machine has a USB interface that is compatible with the USB 2.0 specification.
„ DO NOT connect the interface cable at this time.
Connecting the interface cable is done during the software installation process.
2
Getting Started
Control panel
01/01 13:00
11
10
5
6
9
Fax
3
2
1
12
13
14
4
1
Fax and telephone keys
8
Start keys
2
Dial Pad
9
Stop/Exit key
3
Mode keys
10 Navigation keys
4
Fax Resolution key
11 Copy Options key
5
Ink Management key
12 Menu key
6
Clear/Back key
13 LCD (Liquid Crystal Display)
7
OK key
14 Power Save key
7
8
For the details of the control panel, see Control panel overview in Chapter 1 of the User’s Guide.
Note
Date
Time
Receive mode
01/01 13:00
Fax
When the machine is idle (not being used) it will return to the default display shown above. The default display
shows the date, time, and the current receive mode.
3
STEP1
Setting Up the Machine
1
1
1
2
Removing the protective
parts
2
Loading paper
You can load up to 100 sheets of 80 gsm
(20 lb) paper.
For details, see Acceptable paper and other
media in Chapter 2 of the User’s Guide.
Remove the protective tape and film covering
the scanner glass.
Remove the foam bag containing the ink
cartridges from on top of the paper tray.
1
Pull the paper tray completely out of the
machine and lift the output paper tray cover (1).
Improper Setup
DO NOT connect the USB cable. Connecting
the USB cable is done during the software
installation process.
1
2
Press and slide the paper side guides (1) and
paper length guide (2) to fit the paper size.
1
2
4
Setting Up the Machine
3
4
Fan the stack of paper well to avoid paper jams
and misfeeds.
6
Gently put the paper into the paper tray print
side down and top edge first.
Check that the paper is flat in the tray.
7
5
Close the output paper tray cover.
Gently adjust the paper side guides with both
hands to fit the paper.
Make sure that the paper guides touch the
edges of the paper.
8
Slowly push the paper tray completely into the
machine.
While holding the paper tray in place, pull out
the paper support ( ) until it clicks, and then
unfold the paper support flap ( ).
Note
Do not use the paper support flap for Legal size
paper.
Note
Be careful that you do not push the paper in too
far; it may lift at the back of the tray and cause
paper feed problems.
5
STEP1
3
Setting Up the Machine
Connecting the phone line
1
Note
If you are sharing one phone line with an external
telephone answering machine, connect it as
shown below.
Connect the telephone line cord. Connect one
end of the telephone line cord to the socket on
the machine marked LINE and the other end to
a modular wall socket.
Set the receive mode to ‘External TAD’ if you
have an external answering machine. For
details, see Connecting an external TAD
(telephone answering device) in Chapter 7 of
the User’s Guide.
Improper Setup
DO NOT connect the USB cable. Connecting
the USB cable is done during the software
installation process.
Warning
• The machine must be fitted with an earthed plug.
• Since the machine is grounded through the power
outlet, you can protect yourself from potentially
hazardous electrical conditions on the telephone
network by keeping the power cord connected to
your machine when you connect it to a telephone
line. Similarly, you can protect yourself when you
want to move your machine by disconnecting the
telephone line first and then the power cord.
Note
If you are sharing one phone line with an external
telephone, connect it as shown below.
1
2
6
1
Extension telephone
2
External telephone
4
1
Connecting the power cord
Connect the power cord.
Setting Up the Machine
5
Set Your Country
(For Australia / New Zealand
Customer Only)
You must set your country so that the machine works
correctly.
1
Check that the power is turned on by
connecting the power cord.
The LCD shows:
Set Country
6
Warning
If ink gets in your eyes, wash them out with water
at once, and if irritation occurs consult a doctor.
1
Make sure that the power is turned on.
The LCD shows:
No Cartridge
2
q
Installing the ink cartridges
Open the ink cartridge cover (1).
Press OK Key
2
Press OK.
The LCD shows:
Australia
e
q
1
Select ab & OK
3
4
5
Press a or b to select the country
(Australia or New Zealand).
3
Pull all the lock release levers down and
remove the yellow protective part (1).
Press OK when the LCD shows your country.
The LCD prompts you to make sure of the
country again.
Australia?
q
1.Yes 2.No
6
7
Press 1 to go to step 7.
---OR--Press 2 to go back to step 1 to select the
country again.
After the LCD shows Accepted for two
seconds, it shows; Please Wait.
1
Note
Do not throw away the yellow protective part. You
will need it if you transport the machine.
7
STEP1
Setting Up the Machine
4
Take out the ink cartridge.
5
Carefully remove the protective yellow cap (1).
6
Install each ink cartridge in the direction of the
arrow on the label.
Take care to match the colour of the lock
release lever (1) with the cartridge colour (2),
as shown in the diagram below.
2
1
1
Improper Setup
DO NOT touch the area shown in the
illustration below.
M
7
brother
XXXX
Lift each lock release lever and push it until it
clicks, and then close the ink cartridge cover.
Note
If the protective yellow cap comes off when you
open the bag, the cartridge will not be damaged.
Note
If the LCD shows Install Black,
Install Yellow, Install Cyan or
Install Magenta after you install the ink
cartridges, check that the ink cartridges are
installed properly.
8
Setting Up the Machine
The machine will clean the ink tube system for
use for the first time. The cleaning process will
last approximately four minutes.
The LCD shows:
Preparing System
q
Approx 4 Minutes
Cleaning
q
Please Wait
Caution
• DO NOT take out ink cartridges if you do not
need to replace them. If you do so, it may
reduce the ink quantity and the machine will
not know the quantity of ink left in the
cartridge.
• DO NOT shake the ink cartridges. If ink stains
your skin or clothing, wash with soap or
detergent at once.
• DO NOT repeatedly insert and remove the
cartridges. If you do so, ink may seep out of the
cartridge.
• If you mix the colours by installing an ink
cartridge in the wrong position, clean the print
head several times after correcting the
cartridge installation. (See Cleaning the print
head in Appendix B of the User’s Guide.)
• Once you open an ink cartridge, install it in the
machine and use it up within six months of
installation. Use unopened ink cartridges by
the expiration date written on the cartridge
package.
• DO NOT dismantle or tamper with the ink
cartridge, this can cause the ink to leak out of
the cartridge.
• Brother multifunction machines are designed
to work with ink of a particular specification
and will work to a level of optimum
performance when used with genuine Brother
branded ink cartridges.
Brother cannot guarantee this optimum
performance if ink or ink cartridges of other
specifications are used. Brother does not
therefore recommend the use of cartridges
other than genuine Brother branded cartridges
with this machine or the refilling of empty
cartridges with ink from other sources. If
damage is caused to the print head or other
parts of this machine as a result of using
incompatible products with this machine, any
repairs required as a result may not be covered
by the warranty.
9
STEP1
7
1
Setting Up the Machine
Print quality check
5
After the cleaning cycle is finished, the LCD
shows:
Do one of the following:
„ If all lines are clear and visible, press 1
(Yes) on the dial pad to finish the quality
check.
„ If you can see missing short lines, press 2
(No) on the dial pad and go to step 6.
OK
Set Paper and
Poor
q
Press Start
2
3
Make sure paper is loaded in the paper tray.
Press Colour Start.
The machine starts printing the Print Quality
Check Sheet (only during initial ink cartridge
installation).
6
The LCD asks you if the print quality is OK for
black and colour. Press 1 (Yes) or 2 (No) on the
dial pad.
Black OK?
q
Check the quality of the four colour blocks on
the sheet.
(black/yellow/cyan/magenta)
1.Yes 2.No
Color OK?
q
1.Yes 2.No
After pressing 1 (Yes) or 2 (No) for both black
and colour, the LCD shows:
Start Cleaning?
q
1.Yes 2.No
Improper Setup
Avoid touching the printed surface of the
paper immediately after printing, the surface
may not be completely dry and may stain your
fingers.
4
7
8
After cleaning is finished, press Colour Start.
The machine starts printing the Print Quality
Check Sheet again and goes back to step 3.
The LCD shows:
Is Quality OK?
q
1.Yes 2.No
8
Choosing your language
You can change the LCD language.
1
2
3
10
Press 1 (Yes), the machine will then start
cleaning the colours.
Press Menu, 0, 0.
Press a or b to choose your language
(English or Spanish).
Press OK.
Press Stop/Exit.
Setting Up the Machine
9
Setting the LCD contrast
You can adjust the LCD contrast for a sharper and
more vivid display. If you are having difficulty seeing
the LCD from your position, we recommend the
following contrast setting for improved viewing.
1
2
3
4
Press Menu, 1, 7.
Press a or b to choose Dark or Light.
Press OK.
Press Stop/Exit.
10 Setting the date and time
The machine displays the date and time, and if you
set up the station ID, the date and time displayed on
your machine will be printed on every fax you send.
1
2
3
4
Contrast:Light
Press Menu.
Press 0.
Press 2.
Enter the last two digits of the year on the dial
pad, and then press OK.
Year:2007
(e.g. Enter 0 7 for 2007.)
5
Enter the two digits for the month on the dial
pad, and then press OK.
Month:03
(e.g. Enter 0 3 for March.)
Contrast:Dark
6
Enter the two digits for the day on the dial pad,
and then press OK.
Day:01
(e.g. Enter 0 1 for the first of the month.)
7
Enter the time in 24-hour format on the dial
pad, and then press OK.
Time:15:25
(e.g. Enter 1 5, 2 5 for 3:25 P.M.)
8
Press Stop/Exit.
To confirm the current date and time, print
out the Users Settings Report. (See Printing
reports in Chapter 9 of the User's Guide.)
11
STEP1
Setting Up the Machine
11 Setting your station ID
You should store your name and fax number to be
printed on all fax pages that you send.
1
2
3
4
Your machine comes set for a Tone dialling service. If
you have a Pulse dialling service (rotary), you need to
change the dialling mode.
Press Menu.
Press 0.
Press 3.
Enter your fax number (up to 20 digits) on the
dial pad, and then press OK. To enter a “+” for
international codes, press l. For example, to
enter the UK dialling code “+44”, press l, 4, 4
and then the rest of your number.
Enter your name (up to 20 characters) using
the dial pad, and then press OK.
Name:_
Note
• See the following chart for entering your name.
• If you need to enter a character that is on the same
key as the last character, press
to move the
cursor to the right.
• If you entered a letter incorrectly and want to
change it, press
or
to move the cursor
under the incorrect character, press Clear/Back.
Press
key
One
time
Two
times
Three
times
Four
times
2
A
B
C
2
6
3
D
E
F
3
4
G
H
I
4
5
J
K
L
5
6
M
N
O
6
7
P
Q
R
S
8
T
U
V
8
9
W
X
Y
Z
Press Stop/Exit.
Note
If you make a mistake and want to start again,
press Stop/Exit and go back to step 1.
For details, see Entering Text in Appendix C
of the User's Guide.
12
1
2
3
4
5
Fax:+44XXXXXXXX
5
12 Setting tone or pulse dialling
mode (not available for New
Zealand)
Press Menu.
Press 0.
Press 4.
Press a or b to choose Pulse (or Tone).
Press OK.
Press Stop/Exit.
Setting Up the Machine
13 Choosing a Receive Mode
There are four possible receive modes: Fax Only,
Fax/Tel, Manual and External TAD.
Now go to
Go to Supplied CD-ROM ‘MFL-Pro Suite’ on
the next page to install the drivers.
Are you connecting an external telephone or external
telephone answering device to the machine?
Yes
No
Are you using the voice message function
of an external telephone answering
device?
No
Do you want the machine to answer
fax and telephone calls
automatically?
Yes
Do you want to use the
machine for Fax only?
Yes
No
No
Yes
Fax Only
Your machine
automatically answers
every call as a fax.
Fax/Tel
Your machine controls
the line and
automatically answers
every call. If the call is
not a fax, the phone will
ring for you to pick up
the call.
Manual
You control the phone
line and must answer
every call yourself.
External TAD
Your external telephone
answering device (TAD)
automatically answers
every call. Voice
messages are stored on
the external TAD. Fax
messages are printed.
1
2
3
4
5
6
Press Menu.
Press 0.
Press 1.
Press a or b to choose the mode.
Press OK.
Press Stop/Exit.
For details, see Receive mode Settings in
Chapter 6 of the User's Guide.
13
Supplied CD-ROM ‘MFL-Pro Suite’
1
Supplied CD-ROM ‘MFL-Pro Suite’
Windows®
Install MFL-Pro Suite
You can install the MFL-Pro Suite software and
multifunction drivers.
Install Other Drivers or Utilities
You can install additional MFL-Pro Suite software
utilities, install without PaperPort® SE, or install the
printer driver only.
User’s Guide
View the Software User’s Guide in HTML format.
The Software User's Guide includes instructions for
features available when connected to a computer.
(eg. Printing and scanning details)
On-Line Registration
You will be pointed to the Brother Product
Registration Web page for quick registration of your
machine.
Brother Solutions Center
You can access the Brother Solutions Center which is
a Web site offering information about your Brother
product including FAQs, User’s Guides, driver
updates and tips for using your machine.
Repair MFL-Pro Suite
If an error occurred during the installation of the
MFL-Pro Suite, use this selection to automatically
repair and re-install the MFL-Pro Suite.
Note
MFL-Pro Suite includes the Printer Driver,
Scanner Driver, Brother ControlCenter3,
ScanSoft® PaperPort® SE with OCR and
True Type® fonts.
PaperPort® SE with OCR is a document
management application for scanning and viewing
documents.
14
Macintosh®
Start Here OSX
You can install the MFL-Pro Suite that includes the
printer driver, scanner driver and the Brother
ControlCenter2 for Mac OS® 10.2.4 or greater.
Presto! PageManager
You can also install Presto!® PageManager ® to add
OCR capability to the Brother ControlCenter2 and
easily scan, share and organize photos and
documents.
Documentation
View the Software User’s Guide in HTML format.
The Software User's Guide includes instructions for
features available when connected to a computer.
(eg. Printing and scanning details)
Brother Solutions Center
You can access the Brother Solutions Center which is
a Web site offering information about your Brother
product including FAQs, User’s Guides, driver
updates and tips for using your machine.
On-Line Registration
You will be pointed to the Brother Product
Registration Web Page for quick registration of your
machine.
STEP2
Installing the Driver & Software
Follow the instructions on this page for your operating system and interface.
For the latest drivers and documentations and to find the best solution for your problem or question, access the Brother Solutions Center
directly from the driver or visit http://solutions.brother.com.
Windows®
For USB Interface Users
(For Windows® 98/98SE/Me/2000 Professional/XP/XP Professional x64 Edition) .... 16
Macintosh®
For USB Interface Users
(For Mac OS® X 10.2.4 or greater) ................................................................................. 19
The screens for Windows® in this Quick Setup Guide are based on Windows® XP.
The screens for Mac OS® X in this Quick Setup Guide are based on Mac OS® X 10.4.
15
STEP2
Installing the Driver & Software
Windows®
1
Windows®
USB
For USB Interface Users
(For Windows® 98/98SE/Me/2000 Professional/XP/XP Professional
x64 Edition)
Important
4
The CD-ROM main menu will appear. Click
Install MFL-Pro Suite.
Make sure that you have finished the
instructions from Step 1 Setting Up the
Machine on pages 4 through 13.
Note
• Uninstall any other version of MFC software, any
scanning and faxing software and any GDI printer
drivers as they might cause conflicts with new
software.
• Please close any applications running before
installing MFL-Pro Suite.
• Make sure there are no memory cards in the
media drive of the machine.
1
2
3
16
Disconnect the machine from the power socket
and from your computer, if you already
connected an interface cable.
Turn on your PC.
(For Windows® 2000 Professional/XP/
XP Professional x64 Edition, you must be
logged on with Administrator rights.)
Put the supplied CD-ROM into your CD-ROM
drive. If the model name screen appears,
choose your machine. If the language screen
appears, choose your language.
Note
• If this window does not appear, use Windows®
Explorer to run the setup.exe program from the
root folder of the Brother CD-ROM.
• If you are using Windows® 2000 Professional
and have not installed service pack 3 (SP3) or
greater:
To access the PhotoCapture Center™ features
from your computer you may have to install a
Windows® 2000 update first.
The Windows® 2000 update is included with the
MFL-Pro Suite installer.
To install the update, follow the steps below:
1 Click OK to start installation of the Windows®
updates.
2 When instructed, click OK to restart your
computer.
3 After the computer restarts, the installation of
MFL-Pro Suite will automatically continue.
If the installation does not continue automatically,
open the main menu again by ejecting and then
reinserting the CD-ROM disc or double-click the
setup.exe program from the root folder, and
continue from Step 4 to install MFL-Pro Suite.
Installing the Driver & Software
After reading and accepting the ScanSoft®
PaperPort® SE License Agreement, click Yes.
10 Using both hands, use the plastic tabs on both
sides of the machine to lift the scanner cover
until it locks securely into the open position.
Windows®
USB
5
Windows®
6
7
8
The installation of PaperPort ® SE will
automatically start and is followed by the
installation of MFL-Pro Suite.
When the Brother MFL-Pro Suite Software
License Agreement window appears, click Yes
if you agree to the Software License
Agreement.
11 Connect the USB cable to the USB socket
marked with a
symbol. You will find the
USB socket inside the machine as shown
below.
Choose Standard, and then click Next. The
installation continues.
12 Carefully guide the USB cable into the trench
as shown below, following the trench around
and toward the back of the machine and
connect it to your computer.
9
When this screen appears, go to the next step.
Improper Setup
• DO NOT connect the machine to a USB port on
a keyboard or a non-powered USB hub.
Brother recommends that you connect the
machine directly to your computer.
• Make sure that the cable does not restrict the
cover from closing, or an error may occur.
• Please make sure you use a USB 2.0 cable that
is no longer than 2 metres long (6 feet).
17
STEP2
Installing the Driver & Software
13 Lift the scanner cover to release the lock (
Windows®
USB
).
Gently push the scanner cover support down
( ) and close the scanner cover ( ).
14 Turn on the machine by connecting the power
cord.
Windows®
16 Click Finish to restart your computer.
(After restarting the computer, for Windows®
2000 Professional/XP/XP Professional x64
Edition, you must be logged on with
Administrator rights.)
Note
After restarting the computer, the Installation
Diagnostics will run automatically. If the
installation is unsuccessful, the installation results
window will be shown. If the Diagnostics shows a
failure, please follow the on-screen instructions or
read the on-line help and FAQs in
Start/All Programs (Programs)/Brother/
MFC-XXXX.
The MFL-Pro Suite has been installed and
the installation is now complete.
The installation of the Brother drivers will
automatically start. The installation screens
appear one after another. Please wait, it will
take a few seconds for all the screens to
appear.
Improper Setup
DO NOT try to cancel any of the screens during
this installation.
15 When the On-Line Registration screen is
displayed, make your selection and follow the
on-screen instructions.
18
Note
MFL-Pro Suite includes the Printer Driver,
Scanner Driver, Brother ControlCenter3,
ScanSoft® PaperPort® SE with OCR and
True Type® fonts.
PaperPort® SE with OCR is a document
management application for scanning and viewing
documents.
Installing the Driver & Software
Macintosh®
For USB Interface Users
(For Mac OS® X 10.2.4 or greater)
Important
3
Macintosh®
USB
Make sure that you have finished the
instructions from Step 1 Setting Up the
Machine on pages 4 through 13.
Carefully guide the USB cable into the trench
as shown below, following the trench around
and toward the back of the machine and
connect it to your computer.
Note
For Mac OS® X 10.2.0 to 10.2.3 users, upgrade to
Mac OS ® X 10.2.4 or greater. (For the latest
information for Mac OS® X, visit
http://solutions.brother.com)
1
Using both hands, use the plastic tabs on both
sides of the machine to lift the scanner cover
until it locks securely into the open position.
Improper Setup
• DO NOT connect the machine to a USB port on
a keyboard or a non-powered USB hub.
Brother recommends that you connect the
machine directly to your computer.
• Make sure that the cable does not restrict the
cover from closing, or an error may occur.
• Please make sure you use a USB 2.0 cable that
is no longer than 2 metres long (6 feet).
4
2
Lift the scanner cover to release the lock ( ).
Gently push the scanner cover support down
( ) and close the scanner cover ( ).
Connect the USB cable to the USB socket
marked with a
symbol. You will find the
USB socket inside the machine as shown
below.
Note
Make sure that the machine is turned on by
connecting the power cord.
19
STEP2
5
6
7
Installing the Driver & Software
Turn on your Macintosh ®.
Put the supplied CD-ROM into your CD-ROM
drive.
Macintosh®
10 For Mac OS® X 10.2.4 to 10.2.8 users:
Click Add.
Double-click the Start Here OSX icon to install.
Follow the on-screen instructions.
Macintosh®
USB
11 Choose USB.
Note
Please wait, it will take a few seconds for the
software to install. After the installation, click
Restart to finish installing the software.
8
9
12 Choose MFC-XXXX (where XXXX is your
model name), and then click Add.
The Brother software will search for the Brother
device. During this time the following screen
will appear.
When this screen appears, click OK.
13 Click Print Center, then Quit Print Center.
For Mac OS® X 10.3.x or greater users:
The MFL-Pro Suite, Brother printer driver,
scanner driver and Brother
ControlCenter2 have been installed and
the installation is now complete.
Go to step 14.
The MFL-Pro Suite, Brother printer driver,
scanner driver and Brother
ControlCenter2 have been installed and
the installation is now complete.
20
Installing the Driver & Software
Macintosh®
14 To install Presto!® PageManager®, click the
Note
When Presto!® PageManager® is installed OCR
capability is added to the Brother ControlCenter2.
You can easily scan, share and organize photos
Macintosh®
USB
Presto! PageManager icon and follow the
on-screen instructions.
and documents using Presto!® PageManager®.
Presto!® PageManager® has been
installed and the installation is now
complete.
21
Uninstalling the ‘MFL-Pro Suite’
For instractions on how to uninstall the MFL Pro Suite software
Uninstalling for Windows
Improper Setup
Uninstalling for Macintosh
How to uninstall the Printer Driver:
DO NOT remove the USB cable
during the uninstallation process.
1
Start/All Programs (Programs)/Brother/
MFC-XXXX/UnInstall
2
3
4
1
2
Click UnInstall.
Click OK.
5
3
4
Remove the USB cable.
Click Finish.
6
7
Disconnect the USB cable between the
Macintosh and your Brother device.
Reboot the Mac.
Log on as an ”Administrator”.
Run the ”Print Center” or ”Printer Setup
Utility”
(from the Macintosh HD/Applications/
Utilities/Print Center or Printer Setup Utility
folder), then choose the printer you went to
remove and remove it by clicking the ”Delete”
button.
Click on the model name of your Brother
product in the printer list. From the Finder
menu, delete the Printer.
Drag the ”Brother” folder (Macintosh HD/
Library/Printers/Brother) into the Trash bin
and then empty the trash bin.
Reboot the Mac.
How to uninstall the Scanner
Driver:
1
The MFL-Pro Suite has been uninstalled
and the uninstallation is now
complete.
2
3
4
Disconnect the USB cable between the
Macintosh and your Brother device.
Reboot the Mac.
Log on as an ”Administrator”.
Delete the ”Brother TWAIN.ds” folder
(Macintosh HD/Library/Image
Capture/TWAIN Data Sources/Brother
TWAIN.ds)
The MFL-Pro Suite, Brother printer driver,
scanner driver and Brother
ControlCenter2 has been uninstalled and
the uninstallation is now complete.
22
Consumables
1
Replacement consumables
When the time comes to replace ink cartridges, an error message will be indicated on the LCD. For more
information about the ink cartridges for your machine, visit http://solutions.brother.com or contact your local
Brother re-seller.
Ink cartridge
Black
Yellow
Cyan
Magenta
LC57BK
LC57Y
LC57C
LC57M
23
Trademarks
The Brother logo is a registered trademark of Brother Industries, Ltd.
Brother is a registered trademark of Brother Industries, Ltd.
Multi-Function Link is a registered trademark of Brother International Corporation.
Windows and Microsoft are registered trademarks of Microsoft in the U.S. and other countries.
Macintosh and True Type are registered trademarks of Apple Computer, Inc.
PaperPort is a registered trademark of ScanSoft, Inc.
Presto! PageManager is a registered trademark of NewSoft Technology Corporation.
PictBridge is a trademark.
Each company whose software title is mentioned in this manual has a Software License Agreement specific to its proprietary
programs.
All other brand and product names mentioned in this manual are trademarks or registered trademarks of their
respective companies.
Compilation and Publication
Under the supervision of Brother Industries Ltd., this manual has been compiled and published, covering the latest product
descriptions and specifications.
The contents of this manual and the specifications of this product are subject to change without notice.
Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be
responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited
to typographical and other errors relating to the publication.
This product is designed for use in a Professional Environment.
Copyright and License
©2006 Brother Industries, Ltd.
LP3415040
ARL/ASA/NZ
Printed in China
