Operating and assembly instructions BIA, BIU Induction

EN
Operating and assembly instructions BIA, BIU
Induction-glass ceramic cooktop with
integrated cooktop extractor
BIASUMEN--002
www.bora.com
M8800361
Operating and installation instructions:
 Original
 Translation
Manufacturer
BORA Vertriebs GmbH & Co KG
Prof.-Dr.-Anton-Kathrein-Straße 3
6342 Niederndorf
Austria
Contact
T +43 (0) 5373/62250-0
mail@bora.com
www.bora.com
The distribution and duplication of this document, as well as the use and disclosure of its contents are prohibited
unless expressly authorised.
© BORA Vertriebs GmbH & Co KG
All rights reserved.
EN

Table of Contents
1General
4
2Safety
6
2.1
2.2
2.3
2.4
2.5
2.6
General safety precautions.................................. 6
Safety instructions, operation.............................. 7
Safety instructions, assembly............................... 9
Safety instructions, disassembly and disposal.....10
Safety instructions, spare parts......................... 11
Use as intended................................................. 11
3
Technical data
12
4
Energy label
13
5
Device description
14
5.1Structure............................................................ 14
5.2
Operating panel and operating principle............15
5.3
How the cooking zone works ............................ 15
5.3.1 Power levels....................................................... 16
5.3.2 power setting..................................................... 16
5.3.3 Timer functions.................................................. 16
5.3.4 Pan size recognition........................................... 16
5.3.5 Suitable cookware.............................................. 16
5.4
How the cooktop extractor works......................17
5.4.1 power setting..................................................... 17
5.4.2 Automatic after-run............................................ 17
5.4.3 Filter service display........................................... 17
5.5
Safety devices.................................................... 17
5.5.1 Residual heat display......................................... 17
5.5.2 Safety shut-down............................................... 17
5.5.3 Cooking zone overheating protection.................17
5.5.4 Automatic switch-off if the button is
pressed and held................................................ 17
5.5.5 Child safety lock................................................. 17
6Assembly
6.1
6.2
6.3
6.3.1
6.4
6.5
6.6
6.6.1
6.7
6.8
7Operation
7.1
7.1.1
7.1.2
7.1.3
7.1.4
7.1.5
7.1.6
7.1.7
7.1.8
7.1.9
7.2
7.2.1
7.2.2
18
Checking the scope of delivery.......................... 18
Tool and aids...................................................... 18
Assembly instructions........................................ 18
Safety distances................................................. 18
Dimensions of cut-out for cooktop.....................19
Installing the air recirculation version (BIU).......20
Installing exhaust air duct variant (BIA)...............23
Using the cooktop extractor with a fireplace
which does not depend on room air...................23
Establishing the power connection....................27
Handover to user................................................ 28
7.2.3
7.2.4
7.3
7.4
Switching on the delayed automatic after-run......31
Switching off the cooktop extractor...................31
Pay attention to the filter service display...........31
Saving energy..................................................... 31
8
Cleaning and m
­ aintenance
8.1
8.2
8.3
8.4
8.4.1
8.4.2
8.4.3
8.5
8.5.1
8.5.2
8.6
32
Cleaning agents.................................................. 32
Maintaining the cooktop.................................... 32
Cleaning the cooktop......................................... 32
Cleaning the cooktop extractor.......................... 33
Removing the air inlet nozzle and
stainless steel grease filter................................ 33
Cleaning the air inlet nozzle and
stainless steel grease filter................................ 33
Installing stainless steel grease filter
and air inlet nozzle............................................. 33
Cleaning the air guiding housing........................ 33
Opening the air guiding housing......................... 33
Closing the air guiding housing.......................... 34
Replacing the activated charcoal filter...............34
9Troubleshooting
36
10Decommissioning,
disassembly and
disposal37
10.1Decommissioning............................................... 37
10.2Disassembly....................................................... 37
10.3 Disposing of the product in an
environmentally friendly way.............................. 37
11
Warranty, service and spare parts
38
11.1Warranty............................................................. 38
11.2Service............................................................... 38
11.3 Spare parts......................................................... 38
12Notes
39
29
Switching cooktop on/off.................................. 29
Switching on the cooking zone.......................... 29
Adjusting the power level................................... 29
Changing the power level................................... 29
Switching on the power setting.......................... 29
Switching the power setting off early.................29
Switching off the cooking zone.......................... 29
Pay attention to the residual heat display..........29
Using the timer function..................................... 29
Activating/deactivating the child safety lock.....30
Operating the cooktop extractor........................ 30
Switching on the cooktop extractor...................31
Setting the fan level........................................... 31
www.bora.com
3
General
EN
1 General
Target group
These operating and assembly instructions are intended
for the following target groups:
Target group
Requirements
Users
The Device may be used by children
from the age of 8 as well as by people
with limited physical, sensory or mental
capabilities or a lack of experience and/or
knowledge, provided they are supervised,
have been instructed in the safe use of the
device and have understood the dangers
involved. Children must be supervised. All
safety and warning information and handling
instructions in the operating manual must
be followed.
Ambitious Diyers
Ambitious Diyers may carry out all the
necessary carpentry and assembly work
themselves providing that they have the
­necessary skills and knowledge. They must
not connect the current and gas themselves.
Assembly
expert
The assembly expert must carry out all the
necessary carpentry and assembly work
taking existing regulations into account.
The current and gas connections must be
approved for the system in use by a certified
electrician or gas engineer before use.
Electrical
expert
The electrical connection must only be
executed by a certified electrician. He/she
also assumes responsibility for the proper
electrical installation and commissioning.
Expert
gas connection
The gas connection must only be implemented by a certified gas engineer. He/she also
assumes responsibility for the proper gas
installation and commissioning.
Tab. 1.1
Target groups
INFO
BORA Holding GmbH, BORA Vertriebs
GmbH & Co KG, BORA APAC Pty Ltd and BORA
Lüftungstechnik GmbH - hereinafter referred
to as BORA - shall not assume any liability for
damage caused by non-compliance with these
documents nor by improper assembly!
The electricity and gas connections must be
implemented by a certified engineer.
Assembly must only take place in compliance
with the applicable norms, regulations and
laws. All safety and warning information and
handling instructions in the operating and
assembly instructions must be followed.
4
Validity of the operating and assembly
instructions
This manual is valid for several versions of the device.
For this reason, it is possible that individual features are
described in the manual that do not apply to your device.
Other applicable documents
Additional documents are valid as well as these o
­ perating
and assembly instructions, and likewise need to be
­observed.
Please observe all documents included in the scope of
delivery.
INFO
BORA cannot assume any liability for d
­ amage
caused by non-compliance with these
­documents!
Guidelines
These devices meet the following EC guidelines:
2014/30/EC EMC Directive
2014/35/EC Low-Voltage Directive
2009/125/EC Ecological Design Directive
2010/30/EC Energy label Directive
2011/65/EC RoHS Directive
2012/19/EC WEEE Directive
Depiction of information
We used standard formatting, numbering, symbols, safety
instructions, terms and abbreviations so that you can
work quickly and safely when using this manual.
Instructions are marked with an arrow.
XX
Always perform all instructions in the prescribed order.
Enumerations are indicated with a square bullet point at
the start of the line.
QQ Enumeration 1
QQ Enumeration 2
INFO
Information notes point to special features that
must be taken into account.
Safety and warning instructions
The safety and warning instructions in this manual are
emphasised with symbols and signal words.
Safety and warning instructions are structured as follows:
WARNING SYMBOL AND
SIGNAL WORD!
Type and source of the danger
Results of non-compliance
XX
Measures
to minimise risk
www.bora.com
General
EN
Please note:
QQ The warning symbol draws your attention to the risk.
QQ The signal word indicates the severity of that risk.
Warning
symbol
—
Tab. 1.2
Signal word
Risk
Danger
Indicates an immediate,
hazardous situation which
­causes death or serious injury if
not respected.
Warning
Indicates a potentially
hazardous situation which can
cause death or serious injury if
not respected.
Caution
Indicates a possible
hazardous situation which
can cause minor injury if not
respected.
Caution
Indicates a situation which
can cause minor injury if not
respected.
Meaning of the warning symbols and signal words
www.bora.com
5
Safety
EN
2 Safety
INFO
2.1
XX
Make
INFO
General safety precautions
The product complies with the
mandatory safety provisions.
The user is responsible for cleaning,
care and safe use of the device.
Any improper use may lead to
personal injury and property damage.
This operating and installation instructions
contain important information concerning
assembly and operation. It protects you
from injury and prevents damage to the
product. You can find contact data to get
further information and answers to questions
about the use of the product on the last
page of this operating and installation
­instructions.
QQ The term “device” is used to refer to cooktop, cooktop extractor or cooktop with
­integrated cooktop extractor.
XX
Read this operating and installation
­instructions in full before you assemble the
device and start to use it.
XX
Always keep these operating and installation
instructions to hand so it is available when
needed.
XX
After selling the device, pass on the
­operating and installation manual to the
new owner.
XX
Carry out all work with great care and
­attention.
XX
Check the device for visible damage after
unpacking.
XX
Do not install a damaged device.
XX
Do not use the device until installation is
complete. Only in this way a safe operation
can be guaranteed.
XX
Make sure contact with hot cooking surfaces
is not possible.
XX
Avoid over-cooking.
XX
Pay attention to the residual heat indicator.
XX
Turn the device off after use.
XX
Do not rely on the pan size recognition.
XX
Keep pets away from the device.
QQ
Recirculated air mode
INFO
Every time the device is used for
cooking, supplementary moisture is
released into the room air.
In the recirculated air mode, only
a small amount of moisture is
removed from the cooking vapours.
sure that the room is sufficiently ventilated to the outside air in the recirculated
air mode, e.g. through an open window.
XX
Ensure a normal and comfortable indoor
climate (45-60% humidity), e.g. through
natural ventilation openings or domestic
ventilation systems.
XX
Set the cooktop extractor to a low setting
for about 15 minutes or activate the
­automatic after-run after every use in the
recirculated air mode.
Effects on pacemakers, hearing aids and
metal implants
INFO
Induction cooktops generate a highfrequency electromagnetic field
in the area of the cooking ­zones.
The cooking zones may affect
­pacemakers, hearing aids or metal
implants negatively or disturb their
function when in close proximity. A
reduced function of the pacemaker is
unlikely.
XX
If
in doubt, contact the manufacturer of
your medical device or your doctor.
When there are children and people with
special needs in the house
QQ This device may be used by children from
the age of 8 as well as by persons with
­limited physical, sensory or mental
­capabilities or a lack of experience and/or
knowledge, provided they are supervised,
have been instructed in the safe use of the
device and have understood the dangers
­involved.
QQ Do not leave children unattended when
they are near the device.
QQ Children must not play with the device.
QQ Use the child safety lock in order to
prevent children from switching on the
cooktop or changing the settings when they
are unattended.
XX
Do not store any objects that could be of
interest to children in storage spaces above
or behind the device. Otherwise, the children
will be tempted to climb onto the device.
XX
Keep children and other persons away from
the cooking surfaces.
Unauthorised modifications
Due to unauthorised modifications
6
www.bora.com
Safety
The device can constitute a hazard.
XX
Do not make any changes to the device.
2.2
Cleaning and Maintenance
The device must be cleaned at regular
intervals. Dirt can lead to damage or odour
nuisance.
Remove dirt immediately.
QQ Any work involving cleaning and user
­maintenance must not be carried out by
children unless they are supervised at all
times while doing so.
XX
Do not use a steam cleaner for cleaning.
Steam can cause a short circuit on live
parts and thus lead to property damage
(see the Cleaning chapter).
XX
Do not place any hot cookware in the area
of the control panel so as not to damage
the underlying electronics.
XX
When cleaning the device, water must not
penetrate the interior of the device. Use
only a slightly damp cloth. Never spray the
device with water. Water penetration can
cause damage!
XX
Whenever possible, clean the cooktop after
every use.
XX
Clean the cooktop only after it has cooled
down.
XX
When cleaning, only use non-abrasive
cleaning agents to prevent scratching and
abrasion on the surface.
XX
Make sure that the base of the cookware
as well as the cooking zone are clean and
dry.
XX
Always lift (do not drag!) the cookware to
prevent scratching and abrasion on the
­surface.
XX
Do not place any hot cookware onto the air
inlet nozzle of the cooktop extractor.
XX
Make sure that hot cookware does not
touch the edge of the air inlet nozzle.
Cooktop
EN
Safety instructions, operation
DANGER!
Danger of fire caused by leaving
the cooktop unattended!
Oil or fat in the pot can quickly heat
up and ignite.
XX
Never
leave oil or fat to heat up
unattended.
XX
Never extinguish oil and fat fires
with water.
XX
Suffocate the fire, for example by
using a lid.
DANGER!
Danger of explosion caused by
flammable liquids!
Flammable liquids in the vicinity of
the cooktop can explode and cause
serious injury.
XX
Do
not place any flammable liquids
in the vicinity of the
cooktop.
DANGER!
Danger of electric shock!
Cracks, fissures or fractures in the
glass ceramic panel can damage
the underlying electronics. This can
cause an electrical shock.
XX
If there
are any cracks, fissures or
fractures in the glass ceramic,
switch the device off immediately.
XX
Safely disconnect the device from
the mains using miniature or
­automatic circuit breakers, fuses
or contactors.
WARNING!
Risk of burns caused by a hot
­cooktop!
The cooktop and its touchable parts
become hot during operation. After
turning off the cooking zone, allow it
to cool down to less than 60°C first.
Touching hot surfaces can lead to
­serious burns.
XX
Do not touch the hot cooktop.
XX
Keep children away from the hot
cooktop unless they are under
constant supervision.
www.bora.com
7
Safety
EN
WARNING!
Danger of fire caused by objects on
the cooktop!
The cooktop and its touchable parts
become hot when the cooking zone
is switched on and while it is cooling
down. Objects on the cooktop can
heat up and ignite.
XX
Do not leave any objects on the
cooktop.
XX
Do
WARNING!
Risk of burns caused by hot
objects!
The cooktop and its touchable parts
become hot when the cooking zone
is switched on and while it is cooling
down. Objects (pot lid, cooktop
­extractor cover) on the cooktop
become hot very quickly and can
lead to serious burns.
XX
Do not leave any objects on the
cooktop.
XX
Use suitable aids
(pot cloths, thermal glove).
WARNING!
Risk of burns caused by hot
cookware!
Handles protruding over the
worktops can induce children to grab
them.
XX
Do
not turn the handles on the
pots or pans to one side over the
worktop.
XX
Prevent children from pulling down
hot pots and pans.
XX
A special stove guard for children
(available in specialist shops)
­reduces the danger.
WARNING!
Risk of burns!
Liquids between the cooking zone
and base of the pot can scald the
skin when steaming up.
XX
Make
sure that the cooking zone
and the base of the pot are always
dry.
8
CAUTION!
Damage caused by hard and
pointed objects!
Hard and pointed objects may cause
damage to the glass ceramic plate of
the cooktop.
not use the cooktop surface as
a kitchen worktop.
XX
Do not use any hard and pointed
objects when working on the cooktop.
CAUTION!
Damage caused by substances
containing sugar and salt!
Substances containing sugar and salt
and juices can damage the cooking
zone when they are spilled on its hot
surface.
XX
Make
sure that no food or drinks
containing sugar or salt and
juices are spilled onto the hot
­cooking zones.
XX
Immediately remove food or drinks
containing sugar or salt and juices
from the hot cooking zone.
CAUTION!
Escaping hot liquids!
Unattended pans can boil over
­allowing hot liquids to escape.
XX
Always
keep an eye on pans while
cooking.
XX
Short cooking sessions must be
constantly monitored.
Cooktop extractor
DANGER!
Danger to life caused by
smoke poisoning!
Combustion gases arise when
running a fireplace that depends on
the air in the room.
If you operate the cooktop extractor
with a fireplace that depends on the
air in the room at the same time,
poisonous combustion gases
(carbon monoxide) may be drawn
from the chimney or extraction duct
into the living room.
XX
Make sure that there is always
enough air supply.
www.bora.com
Safety
DANGER!
Risk of fire through flambéing!
While in operation, the cooktop
extractor draws off cooking fat. When
flambéing food, the cooking fat can
catch fire.
the cooktop extractor at
r­ egular intervals.
XX
Do not carry out any work
involving an open flame when the
cooktop extractor is switched on.
XX
Clean
DANGER!
Danger of fire due to grease
deposits!
By failing to clean the stainless steel
grease filter at regular
intervals, increased amounts of
­grease may accumulate in it.
This increases the risk of fire.
XX
Clean or replace the filters at
­regular intervals.
CAUTION!
Touchable parts may become hot!
The cooktop extractor and its
­touchable parts are hot when the
cooking zone is switched on and
­during the cooling phase.
XX
Do
not place any items on the
cooktop.
XX
Please use suitable tools
(pot holders, oven gloves).
WARNING!
Danger of injury when opening the
bottom housing cover!
There is a risk of injury while the fan
is turning.
EN
CAUTION!
Damage caused by objects or
paper being sucked in!
Small and light objects such as
cleaning wipes made of fabrics or
­paper can be sucked into the
cooktop extractor. As a result,
the fan can be damaged or the
fan output can be impaired.
XX
Do not store any objects or paper
on the cooktop extractor.
CAUTION!
Damage caused by fat or dirt
­deposits!
Fat or dirt deposits can impair the
functioning of the cooktop extractor.
XX
Never
use the cooktop extractor
without a stainless steel grease
­filter.
2.3
Safety instructions, assembly
Installation and assembly of the device may
only be carried out by trained personnel who
are familiar with and comply with common
­national regulations and supplementary
­regulations of the local utility companies.
Work on electrical parts must only be carried
out by trained electrical personnel.
The electrical safety of the device is only
­guaranteed if it is connected to a properly
­installed protective conductor system. Make
sure that these basic safety precautions have
been taken.
XX
Switch
off the cooktop extractor
and the cooktop.
XX
Turn off the fuse.
www.bora.com
9
Safety
EN
Cooktop
Cooktop extractor
DANGER!
Danger of electric shock!
Connecting the device incorrectly
to the mains poses a risk of electric
shock.
DANGER!
Risk of poisoning caused by
combustion gases!
When the cooktop extractor is used
for exhaust operation, it draws in air
from the room it is installed in and
from neighbouring rooms. Without
sufficient air, negative pressure will
occur. Toxic gases could be drawn
out of the chimney or extraction
­ducting on a fireplace that depends
on the room air and back into the
room.
XX
Make sure there is always enough
air supply.
XX
Use technical safety measures
(e.g. window contact switch, low
pressure warning device) and have
them approved by a qualified
­expert (certified chimney-sweep).
XX
Make sure that the device has a fixed
connection to the mains voltage.
sure that the device is
connected to a properly installed
protective conductor system.
XX
Make sure that technical
equipment is provided to allow for
all of the device’s poles to be
­disconnected from the mains with
a contact opening width of at least
3 mm (miniature and automatic
circuit breakers, fuses, contactors).
XX
Make
DANGER!
Danger of electric shock!
The connection cable can be
damaged if it comes into contact
with hot cooking zones. A damaged
connection cable can cause a (fatal)
electrical shock.
XX
Make sure that the connection
cable does not come into contact
with hot cooking surfaces.
XX
Make sure that the connection
cable is not caught or damaged.
CAUTION!
Back injury caused by heavy loads!
When removing and inserting the
device, incorrect handling may cause
injuries to the limbs and the trunk.
XX
Always
lift the device out of the
packaging with two persons.
XX
Always place the device onto
the worktop cut-out with two
persons.
XX
Use suitable aids to prevent
­damage to the limbs and the trunk.
DANGER!
Risk of electric shock!
Incorrect stripping of the connection
cable to external switching devices
results in a risk of electric shock.
Ensure that the stated stripping
lengths are adhered to.
XX
Check
the device for visible damages
b­ efore installing it.
XX
Do not install a damaged device.
QQ A damaged device may put your safety at
risk!
Repair and maintenance work may only be
carried out by specialists authorised by the
manufacturer.
2.4
Safety instructions, disassembly
and disposal
Disassembly of the device may only be carried
out by trained personnel who are familiar with
and comply with common national regulations
and supplementary regulations of the local
­utility companies.
Work on electrical parts may only be carried
out by trained electrical personnel.
10
www.bora.com
Safety
DANGER!
Danger of electric shock!
Disconnecting the device ­incorrectly
from the mains poses a risk of
­electric shock.
XX
Safely
disconnect the device from
the mains using miniature or automatic circuit breakers, fuses or
contactors.
XX
Use a suitable measuring device
to ensure that the device is
­de-energised.
DANGER!
Risk of suffocation!
Parts of the packaging (e.g. films,
­polystyrene) can be fatal to children.
XX
Store
packaging materials away
from the reach of children.
XX
Dispose of packaging correctly
and promptly.
2.5
EN
Not using the device as described in this
­operating and assembly manual is considered
not using the device as intended, as is using it
beyond the purpose described here.
BORA shall not assume any liability for
­damages caused by improper use or incorrect
operation.
All misuse is prohibited!
INFO
BORA Holding GmbH,
BORA Vertriebs GmbH & Co KG,
BORA APAC Pty Ltd and
BORA Lüftungstechnik GmbH shall
not assume any liability for damage
arising from non-adherence to the
­safety and warning instructions.
Safety instructions, spare parts
WARNING!
Risk of injury and damage to
property!
Incorrect parts can lead to injury
to persons or damage to device!
­Modifications, attachment parts or
conversions to device can impair
­safety.
XX
Only use original spare parts when
carrying out repairs.
2.6
Use as intended
The device is solely intended for preparing
food in private households.
This device is not designed for:
QQ use outdoors
QQ installation in vehicles
QQ heating the room
QQ use in non-fixed installation sites
(e.g. on ships)
QQ use with an external timer or separate
­remote control system.
www.bora.com
11
Technical data
EN
3 Technical data
Parameter
Value
Supply voltage
380-415 V 3N
Frequency
50/60 Hz
Power consumption
7.6 kW
Fuse protection, minimum
1 x 32 A / 2 x 16 A
Total output
7.6 KW
Line-to-line voltage
AC 220 – 240 V / 50 Hz
Main dimensions (width x depth x height) 760 x 515 x 196 mm
(excl. duct connections)
Weight (incl. accessories/packaging)
Approx. 25 kg
Cooktop
Front single-ring induction cooking zones 210 mm
2300 W
power setting
3000 W
Back single-ring induction cooking zones 175 mm
1400 W
Power levels
1 – 9, power setting
Cooktop energy consumption
Cooking zone 1 (210 mm)
194,5 (Wh/kg)
Cooking zone 2 (175 mm)
181,1 (Wh/kg)
Cooking zone 3 (210 mm)
193,8 (Wh/kg)
Cooking zone 4 (175 mm)
184,1 (Wh/kg)
Total
188,4 (Wh/kg)
Extraction system (BIA)
Maximum flow volume
647 m3/h
Maximum static pressure
339 Pa
Power control
1 – 2, power setting
Exhaust air connection (BIA)
222 x 40 x 89 mm
Recirculation system (BIU)
Maximum flow volume
624 m3/h
Maximum static pressure
341 Pa
Power control
1 – 2, power setting
Recirculation connection (BIU)
650 x 90 mm
Recirculation filter
Filter area
2 x 0.4m2
Filter capacity
150 operating hours
Service life
1 year
Tab. 3.1
12
Technical data
www.bora.com
Energy label
EN
4 Energy label
Product description
Glass ceramic cooktop with 4 cooking zones and an
integrated cooktop extractor
BIA
BIU
Operating mode
Exhaust air
Recirculation
Energy consumption
Value
Value
EN standard
Annual energy consumption (AEChood)
87,5 kWh/a
94,2 kWh/a
61591
Energy efficiency class
C
*
61591
Fluid dynamic efficiency (FDEhood)
15,7
13,1
61591
Fluid dynamic efficiency class
D
*
61591
Lighting efficiency (LEhood)
* lx/Watt
* lx/Watt
*
Lighting efficiency class
*
*
*
Level 2 maximum (GFEhood)
88,5 %
88,5 %
61591
Class level 2 normal
B
*
61591
Level P maximum (GFEhood)
93 %
93 %
61591
Class level P maximum
B
*
61591
Air flow level 1 minimum
342 m³/h
*
m³/h
61591
Air flow level 2 normal
497 m³/h
*
m³/h
61591
Air flow level P maximum (Qmax)
647 m³/h
624 m³/h
61591
Level 1 minimum
55 dB(A)
* dB(A)
60704-2-13
Level 2 normal
64 dB(A)
65 dB(A)
60704-2-13
Level P maximum
69 dB(A)
70 dB(A)
60704-2-13
Level 1 minimum
43 dB(A)
* dB(A)
**
Level 2 normal
51 dB(A)
53 dB(A)
**
Level P maximum
57 dB(A)
57 dB(A)
**
< 0,5 W
< 0,5 W
61591
Flow volume
Lighting
Grease filtering
Grease filtering (additional details)
Flow volume
Sound power level
Sound pressure level (additional details)
Details according to 66/2014
Power consumption in off mode (PO)
Time increase factor
1,4
1,5
61591
Energy efficiency index (EEIhood)
79,9
85,6
61591
Air flow rate at the best efficiency point (QBEP)
370,8 m³/h
320,8 m³/h
61591
Pressure at the best efficiency point (PBEP)
261 Pa
253 Pa
61591
Electric power input at the best efficiency point (WBEP)
171,2 W
172,1
61591
Tab. 4.1
Energy label details
(The recirculation information is optional and not subject to mandatory inclusion on the label)
* This specification is not applicable for this product.
** The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording) on the
basis of the sound power levels established in EN 60704-2-13.
www.bora.com
13
Device description
EN
5 Device description
Observe all safety and warning information during
operation (see the Safety chapter).
The cooktop with cooktop extractor has the following
features:
Cooktop:
QQ power setting
QQ Timer functions
QQ Residual heat display
QQ Pan size recognition
QQ Child safety lock
QQ Safety shut-down
INFO
When using recirculated air, always ensure
sufficient ventilation and aeration to expel any
humidity.
The filter in the activated charcoal filter is made from
special activated charcoal, which is ideal for trapping
cooking odours.
5.1
Structure
1
2
Cooktop extractor:
QQ Touch-operated power control
QQ Automatic after-run (20 minutes)
QQ Safety shut-down
QQ Filter service display
3
4
5
Depending on your purchase decision, the cooktop
extractor is operated as an exhaust air or a recirculating
version.
Exhaust operation
The air suctioned away by the cooktop is purified by the
stainless steel grease filter and expelled into the open air
via a duct system.
The exhaust air must not be expelled into:
QQ a smoke or exhaust gas flue that is in operation
QQ a shaft used to aerate areas in which fireplaces are
installed
Abb. 5.1
[1]
[2]
[3]
[4]
[5]
Cooktop
Inlet nozzle
Stainless steel grease filter
Cooktop
Suction opening
Operating panel
If the exhaust air is fed into a smoke or exhaust air flue
that is not in operation, the installation must be checked
and approved by a qualified heating engineer.
1
Recirculated air mode
2
5
3
4
The air suctioned away by the cooktop is purified by the
stainless steel grease filter and an activated charcoal
filter and fed back into the room in which the appliance is
installed.
To prevent odours in the recirculated air, an activated
charcoal filter must be used. For hygiene and health
reasons, the activated charcoal filter must be replaced
at the recommended intervals (see the Cleaning and
maintenance section).
14
Abb. 5.2
[1]
[2]
[3]
[4]
[5]
Cooktop extractor recirculation (BIU)
Flexible duct
Activated charcoal filter housing
Activated charcoal filter housing cover
Activated charcoal filter
Air guiding housing with housing base
www.bora.com
Device description
EN
Display fields:
1
2
[7]
[8]
[9]
[10]
Fan level indicator/filter service display
Cooking zone indicator light
Cooking zone indicator
Timer
Display panel
Display
Meaning
Fan level indicator
0
Fan off
1 or 2
Setting
P
power setting
n
Automatic after-run
1 ... 9
Power level
P
power setting
H
Residual heat display:
­Cooking zone is
switched off but still hot
(temperature > 60°C)
L
Child safety lock active
On
Automatic cut-off (timer)
activated
Flashes
Timer on (00); no time set
Off
Timer off
0 1 ... 99
Set minutes for short time
(egg timer) or automatic
cut-off
00
Timer on; no time set
Cooking zone
indicator
3
Abb. 5.3
Cooktop extractor exhaust air (BIA)
[1] Exhaust air arc with duct connection for BORA Ecotube
[2] Horizontal exhaust air extension
[3] Air guiding housing with housing base
5.2
Operating panel and operating
principle
7
1


6
9
Abb. 5.4
Operating panel
Sensor keys:
[1]
[2]
[3]
[3]
[4]
[5]
[5]
[6]
Reduce fan power level
Increase fan power level
increase power level
Increase timer value
switch cooktop on/off
reduce power level
Decrease timer value
Select cooking zone
www.bora.com
Touch control

5
4
Meaning of displays
(1*) Timer display
The timer display uses the cooking zone indicators for
the two back cooking zones (e.g. 30 for 30 minutes).
The cooking zone indicators for the two front cooking
zones are disabled while the timer is displayed.


Timer display (1*)
Tab. 5.1
2
10
Cooking zone
indicator light
3
8
The operating panel is fitted with electronic sensor
buttons and display panels. The sensor buttons respond
to finger contact.
You operate the device by touching the corresponding
sensor key with your finger. Keep the finger pressed on
the sensor key until you either hear an acoustic signal or
the display changes accordingly.
5.3
How the cooking zone works
An induction coil is located underneath an induction
cooktop. If the cooking zone is switched on, this coil
creates a magnetic field that acts directly on the base
of the pot thus heating it up. The cooking zone is only
indirectly heated up by the heat emitted by the pot.
Cooking zones with induction only work if the cookware
has a magnetisable base.
15
Device description
EN
The induction automatically takes into account the size of
the used cookware which means that only the area in the
cooking zone covered by the base of the pot is heated up.
XX
Observe the minimum pot base diameter.
The cooking zone does not work
QQ If it is switched on without cookware or with unsuitable
cookware.
QQ If the base diameter of the cookware is too small.
QQ If the cookware is removed from a cooking zone that is
switched on.
In the case of cookware that is unsuitable or too small,
v appears in the cooking zone display.
5.3.1 Power levels
The high power output of induction cooktops results in
the very quick heating up of cookware. A slight adjustment is needed in comparison to conventional cooking
systems when selecting the power level in order to avoid
burning food.
Activity
1-3
Cooking potatoes, pasta, soups, ragouts, steaming
fruit, vegetables and fish, defrosting food
2-6
Frying in coated pans, moderate frying
(without overheating the fat) of pork cutlets, fish
6-7
Heating up fat, browning fish, cooking thickened
sources and soups, making omelettes
7-8
Cooking large quantities of liquid, browning steaks
9
Heating up water
P
Recommendations for power levels
The specifications provided in the table are standard
values.
Depending on the cookware and filling quantity, it is
recommended to either decrease or increase the power
level.
5.3.2 power setting
The two front cooking zones have a power-enhancing
power setting.
The power setting can be used in order to quickly heat up
large quantities of water. If the power level is activated,
the cooking zones will run at extra high power. After
5 minutes, the power level is automatically switched to
level 9.
16
5.3.4 Pan size recognition
The cooking zone does not work
QQ v appears in the display.
QQ If it is switched on without cookware or with unsuitable
cookware.
QQ If the base diameter of the cookware is too small.
QQ If the cookware is removed from a cooking zone that is
switched on.
5.3.5 Suitable cookware
INFO
1
Keeping sauces and soups warm, soaking rice
INFO
You can use 2 timer functions:
QQ Short-time timer (egg timer), no automatic switching
off of a cooking zone.
QQ Automatic cut-off for automatically switching off a
cooking zone.
The heating and heat through time for the base
of the cookware as well as the cooking results
are significantly influenced by the structure and
material of the cookware.
Power level
Melting of butter and chocolate, breaking up gelatine
Tab. 5.2
5.3.3 Timer functions
Never heat up oil, fat and the like at this power
setting. The bottom of the pan can overheat
due to the high power output.
Cookware with this symbol is suitable for
induction cooktops.
The cookware used for the induction cooktop
must be made of metal, feature magnetic
properties and possess a sufficient bottom
surface.
Suitable cookware is made of:
QQ stainless steel with a magnetisable base
QQ enamelled steel
QQ cast iron
Cooking zone
Minimum diameter
Front
120 mm
Back
90 mm
Tab. 5.3
Minimum cookware diameter
XX
Perform a magnet test, if necessary. If a magnet sticks
to the base of the utensils, they are normally induction
compatible.
XX
Pay attention to the cookware bottom. The base of
the cookware should not show any sign of curvature.
Due to incorrect temperature monitoring of the hob
caused by the air gap between the cookware and the
temperature sensor underneath the hob, overheating
may occur. The bottom of the cookware must not have
any sharp grooves or sharp edges to avoid scratching
the cooktop.
XX
Place the cookware (without a mat or similar) directly
onto the glass ceramic.
www.bora.com
Device description
Noises
The following noises may occur in the cookware when
using induction cooking zones, depending on the material
and the finish of the base:
QQ Humming may occur when using a high power level. It
decreases or disappears if the power level is decreased.
QQ Crackling or whistling may occur due to the bases of
cookware made of different materials (e.g. sandwich
base).
QQ Clicking sounds may occur during electronic
switching procedures especially at low power levels.
QQ Whirring may occur when the cooling fan is s
­ witched
on. In order to increase the service life of the
­electronic system, the cooktop is equipped with a
cooling fan. The cooling fan switches on ­automatically
if the cooktop is used intensively. You will hear a
­whirring sound. The cooling fan may continue running
after the device has been switched off.
5.4
How the cooktop extractor works
5.4.1 power setting
The cooktop extractor has a power-enhancing power
setting.
This power setting makes it possible to suction away high
levels of cooking vapours more quickly. After 10 minutes,
the power setting is automatically switched to power level 2.
5.4.2 Automatic after-run
The cooktop extractor fans continue to run at level 1 and
switch off automatically after 20 minutes.
5.4.3 Filter service display
The filter service display is activated once the cooktop
extractor has been operated for 150 hours. The activated
charcoal filters are exhausted (with recirculation only) and
the stainless steel grease filter needs to be thoroughly
cleaned.
QQ F appears (flashing) in the filter service display.
5.5
Safety devices
5.5.1 Residual heat display
INFOWhile H is displayed in the cooking zone
indicator (residual heat display), do not touch
the cooking zone or place any heat-sensitive
objects on top of it. Risk of burns and fire!
After switching it off, the cooking zone remains hot.
H is displayed in the cooking zone indicator (residual heat
indicator). The cooking zone indicator will go out after
sufficient cooling time (temperature < 60°C).
www.bora.com
EN
5.5.2 Safety shut-down
Cooking zone
Each cooking zone is switched off automatically when the
cooking zone in the power level exceeds the maximum
operating duration. H (residual heat display) is then
displayed in the cooking zone indicator (see the Device
description section).
Power level
1
2
3
4
5
Switch off after
x hours
8
6
5
5
4
Tab. 5.4
6
7
8
9
1.5 1.5 1.5 1.5
Overview of the safety shut-down
XX
Switch the cooking zone back on (see Operating
control) if you want to put the cooking zone back into
operation.
Cooktop extractor
INFO
The cooktop extractor switches off
automatically if no buttons are pressed
for 120 minutes.
5.5.3 Cooking zone overheating protection
The induction coils and cooling elements of the electronic
system are equipped with an overheat protection. Before
the induction coils and/or cooling elements overheat,
the overheat protection will initiate one of the following
measures:
QQ The power level P is automatically switched to power
level 9 after 5 minutes. The cooking zone indicator P
switches to 9.
QQ The set power level is reduced.
QQ The cooking zones switch off automatically. H (residual
heat display) is displayed in the cooking zone indicator
if the cooking zone is still hot.
5.5.4 Automatic switch-off if the button is
pressed and held
The cooktop will be switched off automatically when
one or more sensor buttons are touched for longer than
10 seconds (finger contact, objects, soiling).
QQ After a few seconds, the cooktop will switch off.
XX
Remove the finger or object from the cooktop.
XX
Clean the cooktop as required.
XX
Where necessary, switch the cooktop back on.
5.5.5 Child safety lock
The child safety lock prevents the cooktop from being
switched on automatically. The child safety lock can only
be activated when the cooktop is switched on and all
cooking zones have been switched off (see the Operation
chapter).
17
Assembly
EN
6 Assembly
XX
Dispose of transport packaging in the proper manner
(see Decommissioning, Disassembly and Disposal
chapter)
XX
Observe all safety instructions and warnings
(see Safety chapter).
XX
Follow the enclosed manufacturer’s information.
6.2
INFO
The mains connection cord must be provided
by the customer.
INFO
The device may not be installed above cooling
devices, dishwashing machines, stoves, baking
ovens as well as washing and drying machines.
INFO
The contact surface of the worktops and
the wall sealing strip must be made of a
­heat-resistant material (up to approx. 100 °C).
INFO
Worktop cut-outs must be moisture-sealed
using suitable means and, where necessary,
fitted with a thermal insulator.
INFO
The integrated cooktop extractor must not
be used with other cooktops.
6.1
Checking the scope of delivery
Name
The following tools are required for the correct installation
of the cooktop:
QQ Pencil
QQ Drill or cordless drill with a 5 mm wood bit (for the
back wall)
QQ Compass saw or handsaw
QQ Drilling template for cut-out on back wall (included)
QQ Phillips screwdriver Z2
QQ Silicone sealing compound for sealing cutting surfaces
6.3
Assembly instructions
6.3.1 Safety distances
XX
Maintain the following safety distances:
Quantity
Induction glass ceramic cooktop with ­integrated
cooktop extractor
1
Stainless steel grease filter
1
BAKF activated charcoal filter
2
Flexible duct (only BIU)
1
EURO screws (only BIU)
6
Duct extension for extracted air, horizontal BLAVH
(only BIA)
1
Mounting brackets
5
Sealing tape
1
Glass ceramic scraper
1
Cable routing clips
3
Operating and assembly manual
1
Lenshead screws
5
Drilling template
1
Height compensation plate set
1
Tab. 6.1
Tool and aids
3
2
1
Abb. 6.1
[1]
[2]
[3]
Recommended minimum clearances
Minimum distance of 50 mm at the back between worktop
cut-out and the rear edge of the worktop.
Minimum distance of 300 mm from the left and right of the
worktop cut-out to the adjacent cabinet or wall.
Minimum distance of 600 mm between the worktop and the
wall unit. A minimum clearance of 1000 m is recommended
for ergonomic reasons.
Scope of delivery
XX
Check the scope of delivery for damage and make sure
it is complete.
XX
If there are any missing or damaged parts, please
notify BORA Customer Services immediately.
XX
Do not under any circumstances install parts which are
damaged.
18
www.bora.com
Assembly
Dimensions of cut-out for
cooktop
Surface installation
600
5
Flush installation
50
QQ Cross
Abb. 6.4
Dimensions of cut-out for surface installation
12,5
10 ... 50
bars on the unit in the area of the worktop
c­ ut-out may need to be removed.
QQ A false floor underneath the cooktop with integrated
cooktop extractor is not needed.
QQ Make sure that the area below the device is sufficiently
ventilated.
QQ There must be an opening cross-section > 50 cm2 at
the front side and in the false floor for ventilation of
the induction system of the cooktop.
QQ The drawers and/or shelves in the floor unit must be
removable.
QQ A return flow aperture > 500 cm2 is required in the
kitchen units for recirculation appliances (e.g. by
shortening the plinth boards or using suitable slatted
plinths).
QQ The power socket is underneath the device on the
front.
735
<R
Preparing the worktop
XX
Create the worktop cut-out taking the specified cut-out
dimensions into account.
XX
Make sure that the cutting surfaces of the worktops
are properly sealed.
XX
Observe the instructions provided by the worktop
manufacturer.
490
6.4
EN
Abb. 6.5
Dimension of support for surface installation
Attaching the sealing tape
764
735
5
<R
R5
1
2
Sealing tape, surface installation
600
519
490
Abb. 6.6
1
50
2
Abb. 6.2
Dimensions of cut-out for flush installation
6,5
14,5
Sealing tape, flush installation
[1] Black heat-resistant silicone sealing compound
[2] Sealing tape
XX
With surface installation, attach the included sealing
tape [2] on the underside of the cooktop before
­installing it. Do not leave any gaps.
10 ... 50
Abb. 6.3
Abb. 6.7
Dimensions of groove for flush installation
www.bora.com
19
Assembly
< R15
117
90
6x Ø5mm
133
XX
With flush installation, attach the sealing tape [2] to
the horizontal cutting edge in the worktop cut-out,
even if you seal the cooktop with a silicone sealing
compound [1] or similar.
XX
Align the cooktop precisely.
119
EN
650
675
1
>600
490
2
Abb. 6.8
90
Height adjustment plates
>50
[1] Cooktop
[2] Height adjustment plates
650
735
510 - 570
XX
If necessary insert height adjustment plates [2].
XX
Note down the type designation and build number of
the cooktop (FD number) on the back of this manual.
Both designations can be found on the nameplate on
the underside of this cooktop.
119
>25
>800
INFO INFO Installing the air recirculation
version (BIU)
There must be a minimum clearance of 25 mm
for the vertical return flow aperture.
Abb. 6.10 Dimensions of furniture, recirculated air
> 600
There must be a return flow aperture of at least
500 cm2.
119
6.5
When the cooktop extractor is exclusively used in
­recirculated air mode, it is possible to operate it with an
open furnace without any additional safety measures
being required.
Installation dimensions
515
510 - 570
760
196
Abb. 6.9
20
> 25
Device dimensions, recirculated air
483
510 - 570
Abb. 6.11 Installation dimensions for recirculated air, worktop
depth 600 mm
QQ The
floor unit must have a continuous rear wall so that
the returned recirculated air is not directed into the
front furniture body compartment.
QQ There must be a cut-out in the rear wall.
www.bora.com
Assembly
QQ A
minimum clearance of 25 mm between the rear wall of
the furniture body and an adjacent piece of furniture or
room wall must be observed for the return flow aperture.
XX
Using a screwdriver (not a cordless drill) screw the
flexible duct into the rear wall of the furniture until
hand-tight.
Preparing the rear wall of the furniture
XX
Adjust the rear wall according to the required installation dimensions.
XX
You may need to move the rear wall.
XX
Where necessary, extend the height of the rear wall so
that the furniture body is closed to the front.
Inserting the cooktop
1
2
3
4
EN
5
6 x ø5
Abb. 6.14 Insert the cooktop at an angle
Abb. 6.12 Cut-out and connection bores
XX
Using the included drilling template, draw the return
flow aperture and the connection bores in the middle
of the cooktop based on the installation dimensions.
XX
Saw out the return flow aperture.
XX
Rough-drill the connection bores.
XX
Decrease the height of the skirting boards or create
corresponding apertures in the base.
Screwing on the flexible duct
[1]
[2]
[3]
[4]
[5]
Cooktop
Suction opening
Air inlet nozzle
Stainless steel grease filter
Worktop cut-out
XX
Before inserting the device, remove the air inlet nozzle
[3] and the stainless steel grease filter [4].
XX
Use the suction opening as something to grab hold of
during insertion.
XX
Insert the cooktop at an angle into the worktop cut-out
[5]. The glass ceramic panel must be supported along
the entire rear width (e.g. using a strip of wood) in the
process.
1
Abb. 6.15 Opening the housing cover
[1] Housing cover of the activated charcoal filter
XX
Open the cover to the housing of the activated
­charcoal filter [1] from below.
Abb. 6.13 Flexible duct with 6 EURO screws 6.3x10 mm
www.bora.com
21
Assembly
EN
click
2
1
1
2
3
4
5
3
4
1
Abb. 6.16 Hooking in the frame of the flexible duct
5
[1] Retaining groove of the housing of the activated charcoal
filter
[2] Position shackles
[3] Flexible duct frame
[4] Lower lock
XX
Insert the frame of the flexible duct into the retaining
groove of the housing of the activated charcoal filter [1].
XX
Make sure that both lateral position shackles [2] are in
the guide.
XX
Move the frame upwards [3] until the lower [4] and
upper lock engage in the middle.
XX
Make sure that the frame is inserted into the groove of
the housing [1] on all sides.
1
2
Abb. 6.17 Inserting the activated charcoal filter
[1] Housing cover of the activated charcoal filter
[2] Activated charcoal filter
6
Abb. 6.18 Securing the cooktop in the middle
[1]
[2]
[3]
[4]
[5]
[6]
Cooktop
Suction opening
Air inlet nozzle
Stainless steel grease filter
Worktop cut-out
Mounting bracket
For surface installation
XX
Make sure that the sealing tape of the cooktop is
­resting on the worktop.
For flush installation
XX
Make sure that the sealing tape of the cooktop is
sealed well all the way round.
XX
You may need to place some height adjustment panels
underneath.
XX
Fasten the cooktop using the mounting brackets [6] at
the worktop.
XX
Afterwards, insert the stainless steel grease filter [4]
and air inlet nozzle [3].
XX
Seal the surrounding gap with a black heat-resistant
silicone sealing compound.
XX
Remove the packaging from the activated charcoal
filters.
XX
Insert the two activated charcoal filters [2] from below.
XX
Note the flow direction of the filter. This is indicated by
an arrow.
XX
Close the cover to the housing [1].
22
www.bora.com
Assembly
Installing exhaust air duct variant
(BIA)
INFO
National and regional laws and regulations
must be followed when executing the exhaust
air duct. Sufficient intake air must be provided.
Installation dimensions
196
290
6.6.1 Using the cooktop extractor with a
fireplace which does not depend on
room air
Fireplaces depending on room air (e.g. gas, oil, wood
or coal-fired heaters, continuous-flow water heaters,
­instantaneous water heaters) draw in air from the room in
which they are installed and discharge the exhaust fumes
to the outside via an exhaust system (e.g. chimney).
When the cooktop extractor is used for exhaust air
­operation, it draws in air from the room it is installed in
and from neighbouring rooms. If there is insufficient air, an
underpressure will occur. Toxic gases could be drawn out
of the chimney or extraction duct and back into the room.
515
760
a
b
535
635
40
6.6
EN
222
89
a
b
100
170
270
170
Abb. 6.21 Device dimensions, exhaust air
[a] Device dimensions without a channel extension.
[b] Device dimensions with a channel extension.
Abb. 6.19 Incorrect exhaust air system installation
735
>50
a
b
Abb. 6.20 Correct exhaust air system installation
XX
When running the cooktop extractor in the room in
which a fireplace is installed, make sure that
QQ the maximum underpressure is 4 Pa (4 x 10-5 bar),
QQ a safety-related device (e.g. window contact switch,
minimum pressure controller) ensuring that a
­sufficient supply of fresh air is guaranteed must
always be used,
QQ the exhaust air may not be ducted into a chimney
that is used for exhaust gases of devices operated
with gas or other combustibles,
QQ the installation has been inspected and signed off
by a qualified professional (e.g. chimneysweep).
www.bora.com
320
490
600
700
110
>800
Abb. 6.22 Furniture dimensions, exhaust air
[a] Worktop depth from 600 mm
[b] Worktop depth from 700 mm
23
Assembly
EN
QQ The
maximum exhaust air duct length is 6 m.
information for the installation of the
­exhaust air ducts are provided in the BORA ventilation
­instructions.
> 600
40
290
QQ Planning
< 430
105
480
Preparing the rear wall of the furniture
XX
Before carrying out the installation at the floor unit,
check the required installation dimensions for the
device and the planned duct system.
XX
Adjust the position of the rear wall according to the
required installation dimensions as necessary.
Extending the exhaust air duct
535
INFO
Abb. 6.23 Installation dimensions for exhaust air, worktop depth
600 mm
XX
Remove the air inlet nozzle and stainless steel grease
filter.
XX
With the glass ceramic panel facing downwards, place
the cooktop onto a clean and protective surface (e.g.
cardboard, packaging material) to prevent damage to
the glass ceramic panel.
290
> 700
The exhaust air duct can optionally be
­extended by 100 mm to the rear using the
supplied horizontal extension BLAVH.
1
2
40
100
< 530
105
580
635
3
Abb. 6.25 Removing the housing base
Abb. 6.24 Installation dimensions for exhaust air, worktop depth
700 mm
Installation conditions
QQ The rear wall of the floor unit must be adjusted for the
exhaust air duct.
QQ A minimum clearance of 110 mm between the rear
wall of the furniture body and an adjacent piece of
furniture or wall must be observed for the duct.
QQ The exhaust air must be directed to the outside in
appropriate exhaust air ducts.
QQ The minimum cross-section of the exhaust air ducts
must be 176 cm2. This equates to a cylindrical tube
with a diameter of 150 mm.
24
[1] Housing base
[2] Locks
[3] Air guiding housing
XX
Open the 4 locks [2].
XX
Remove the housing base [1] from the air guiding
housing [3].
www.bora.com
Assembly
EN
1
2
1
1
1
Abb. 6.28 Removing the air guiding housing
[1] Exhaust air arc
[2] Air guiding housing
Abb. 6.26 Releasing the position lock
[1] Shackles for position lock
XX
Using a screwdriver, press the shackles [1] downwards
left and right to release the position lock.
XX
Remove the air guiding housing [2] with exhaust air arc
[1] upwards.
1
1
2
2
Abb. 6.29 Removing the exhaust air arc
[1] Exhaust air arc
[2] Air guiding housing
3
XX
Move the exhaust air arc [1] from the air guiding
housing [2] upwards.
Abb. 6.27 Moving the air guiding housing
[1] Exhaust air arc
[2] Air guiding housing
[3] Support opening
1
2
XX
Move the air guiding housing [2] together with the
exhaust air arc [1] as far as the left-hand edge of the
support opening [3].
3
Abb. 6.30 Inserting the extension for exhaust air duct
[1] Exhaust air arc
[2] Extension for exhaust air duct
[3] Air guiding housing
www.bora.com
25
Assembly
EN
XX
Insert the extension for the exhaust air duct [2] into
the groove of the air guiding housing [3].
XX
Insert the exhaust air arc [1] into the groove of the
extension for the exhaust air duct [2].
1
1
1
1
2
Abb. 6.33 Position lock
2
[1] Shackles for transport and position lock
Abb. 6.31 Inserting the airflow assembly on the cooktop base
[1] Airflow assembly
[2] Openings
XX
Press the two shackles [1] for the position lock ­upwards.
XX
Lift the cooktop with integrated cooktop extractor.
XX
Turn the glass ceramic panel upwards.
1
2
3
4
5
XX
Position the airflow assembly [1] at the cooktop base
in such a way that all retaining hooks are in the
openings [2].
1
2
2
Abb. 6.32 Engaging the airflow assembly
[1] Airflow assembly
[2] Openings
XX
Now move the airflow assembly [1] to the right until it
engages fully into the slot of the opening [2].
26
Abb. 6.34 Inserting the cooktop
[1]
[2]
[3]
[4]
[5]
Cooktop
Suction opening
Air inlet nozzle
Stainless steel grease filter
Worktop cut-out
XX
Use the suction opening [2] as a handle during
­insertion.
XX
Reach into the suction opening [2].
XX
Insert the cooktop centrally into the provided worktop
cut-out [5].
www.bora.com
Assembly
For surface installation
XX
Make sure that the sealing tape is resting on the
worktop.
For flush installation
XX
Make sure that the sealing tape of the cooktop is
sealed well all the way round.
XX
You may need to place some height adjustment panels
underneath.
1
2
3
4
EN
INFO
The power connection must only be
­implemented by a certified engineer. He/she
also assumes responsibility for the proper
­installation and commissioning.
INFO
Connection via plug-in contacts, e.g. plugs with
earthing contacts, are not allowed.
INFO
The device complies with IEC 61000-3-12
XX
Switch off the main switch/automatic circuit breaker
before connecting the cooktop.
XX
Protect the main switch/automatic circuit breaker
from being switched on without permission.
XX
Make sure the device is not energised.
XX
Only connect the cooktop using a permanent
­connection to a type H 05 VV-F power supply line
with appropriate minimum cross section (s. Tab. Fuse
protection and minimum cross section).
5
7
8
1
Connection
Fuse protection
Minimum
cross-section
Three-phase-connection
3 x 16 A
2.5 mm2
Two-phase-connection
2 x 16 A
2.5 mm2
One-phase-connection
1 x 32 A
4 mm2
Tab. 6.2
Fuse protection and minimum cross section
5
6
Abb. 6.35 Connecting the exhaust air duct
1
2
L1
3
L2
[1] Mounting bracket
[1] Exhaust air arc
[2] Exhaust air duct
XX
Connect the exhaust air duct [8] installed on-site to the
exhaust air arc [7].
XX
Seal the duct connection so that it is airtight using
adhesive sealing tape UDB1.
XX
Fasten the cooktop using the mounting brackets [6] at
the worktop.
XX
Afterwards, insert the stainless steel grease filter [4]
and air inlet nozzle [3].
XX
Seal the surrounding gap with a black heat-resistant
silicone sealing compound.
4
L3
N
PE
220 - 240 V~
220 - 240 V~
220 - 240 V~
Abb. 6.36 Connection diagram 3-phase connection
1
2
L1
3
4
L2
N
PE
220 - 240 V~
220 - 240 V~
Abb. 6.37 Connection diagram 2-phase connection
6.7
Establishing the power
connection
XX
Observe all safety and warning information (see Safety
chapter).
XX
Observe all national and regional laws and regulations
as well as the supplementary regulations of the local
utility companies.
www.bora.com
1
2
3
L1
4
N
PE
220 - 240 V~
Abb. 6.38 Connection diagram 1-phase connection
27
Assembly
EN
1
2
3
3
1
Abb. 6.39 Electrical connections of the cooktop
[1] Bore holes
[2] Power supply
[3] Cable mounting clip
XX
By pressing the
or
button, set the reduced
total power consumption to 4.4.
XX
To save your settings, press all 4 cooking zone selection buttons at the same time for 3 seconds until an
acoustic signal sounds.
QQ The acoustic signal indicates that the setting is saved
and the cooktop switches itself off.
If the cooktop is switched on again, it is ready for use.
6.8
Handover to user
Once installation is done:
XX
Explain the important functions to the user.
XX
Explain all safety-relevant aspects of operation and
handling to the user.
XX
Provide the user with the accessories and operating
and installation instructions to be kept in a safe place.
XX
Based on the relevant connection diagram (see
Figs. Connection diagram), connect the power supply
line to the power connection [2] on the cooktop with
integrated cooktop extractor.
XX
For one- or two-phase-connections install the relevant
contacts with the BKAS connector clip (included in the
scope of delivery).
XX
Fasten the cable mounting clips [3] in the designated
bore holes (1) either on the left or right hand side for
the cable routing to the rear.
XX
Make sure that the cable is not clamped or damaged
and cannot touch any hot parts of the cooktop.
XX
Verify that the installation was done correctly.
XX
Switch on the main switch/automatic circuit breaker.
XX
Put the cooktop extractor into operation (see the
­Operation chapter).
XX
Check all the functions are working correctly.
Device power management
(total power reduction)
The total power of the device can be reduced to 4.4
KW for initial commissioning, if the required electrical
power cannot be provided at the site of installation.
The ­connection must always be equipped with a fuse
­protection of at least 20 A.
Programming the device power management
For the programming process, the device must not be
switched on and the childproofing feature must not be
active. Program the cooktop within 2 minutes after the
cooktop is supplied with power.
XX
For programming, press all 4 cooking zone selection
buttons
at the same time for 3 seconds.
QQ The display will show 7.4 (factory setting).
28
www.bora.com
Operation
7 Operation
XX
Observe all safety and warning information during
operation (see Safety chapter).
INFO
The integrated cooktop extractor must not be
used with other cooktops.
INFO
The cooktop should only be operated when the
stainless steel grease filter and air inlet nozzle
are installed.
7.1
Switching cooktop on/off
Switching on
XX
Press
to switch on the cooktop.
The power level 0 is displayed in the cooking zone
indicators.
Switching off
INFO
Use the operating panel to switch off the
­cooking zone after use. Do not rely on the pan
size recognition.
XX
Press
to switch off the cooktop.
XX
Pay attention to the residual heat display
(see Device Description chapter).
7.1.1 Switching on the cooking zone
XX
Press the cooking zone button (e.g. ) of the desired
cooking zone.
The 0 in the cooking zone indicator lights up more
brightly. The cooking zone indicator light lights up.
7.1.2 Adjusting the power level
XX
Press
or
press
to set power level 5
to set power level 9.
7.1.3 Changing the power level
XX
Press the cooking zone button (e.g. ) of the desired
cooking zone.
The cooking zone indicator lights up more brightly.
XX
Press
or
until the required power level is shown
in the cooking zone indicator.
7.1.4 Switching on the power setting
INFO
Only the two front cooking zones are equipped
with a power-enhancing power setting.
XX
Press the cooking zone button (e.g.
cooking zone.
www.bora.com
) of the desired
EN
XX
Continue pressing
until power level P is displayed in
the cooking zone indicator.
After 5 minutes, the cooking zone is automatically
switched to power level 9.
7.1.5 Switching the power setting off early
XX
Press the cooking zone button (e.g. ) of the desired
cooking zone. The indicator will appear brighter.
XX
Continue pressing
until the lower power level that
you want is displayed.
7.1.6 Switching off the cooking zone
XX
Press the cooking zone button (e.g. ) of the desired
cooking zone.
XX
Continue pressing
or
until the cooking zone
indicator displays power level 0.
The display will show a 0 for a few seconds.
7.1.7 Pay attention to the residual heat
display
After switching it off, the cooking zone remains hot. H
is displayed in the cooking zone indicator (residual heat
indicator). The cooking zone indicator will go out after
sufficient time is left to cool down (temperature < 60 °C).
INFO
While a H is displayed in the cooking zone
indicator (residual heat display), do not touch
the cooking zone or place any heat-sensitive
objects on top of it. Risk of burns and fire!
XX
Pay attention to the residual heat indicator.
XX
Make sure the hot hobs are not touched and no
­objects are placed on it.
7.1.8 Using the timer function
Prerequisite
QQ The cooktop must be switched on.
You can use 2 timer functions:
QQ Short time (egg timer)
(the cooking zone is not ­automatically switched off)
QQ Automatic cut-off (for automatic cutting off of a
­cooking zone)
You can set a time range of between 1 and 99 minutes for
both timer functions.
INFO
After the pre-set time has passed in the timer
display, 00 will be shown for a few seconds.
A signal tone will sound for a few seconds.
INFO
If you first press
start time.
If you first press
the start time.
, 1 minute is pre-set as the
, 30 minutes are pre-set as
Switching off the timer signal tone
XX
Press any sensor button on the operating panel to end
the signal tone prematurely.
29
Operation
EN
Setting the short time (egg timer)
XX
Press
and
simultaneously.
In the timer display 00 will appear for a few seconds on
both rear cooking zone indicators.
XX
Press
or
to set the required time.
Setting the automatic cut-off (timer)
You can set an automatic cut-off for every cooking zone.
INFO
INFO
The cooking zone control light indicates
whether the automatic cut-off is activated. The
cooking zone indicator light lights up until the
cooking zone is switched off after the pre-set
time has passed.
If several cooking zones are activated with an
automatic cut-off, the cooking zone indicator
light with the lowest timer value will light up
provided that a cooking zone was not selected.
Prerequisite
QQ A cooking zone has been selected.
QQ A power level was set.
7.1.9 Activating/deactivating the child
safety lock
INFO
If a cooking zone indicator alternately shows L
and H, this means the cooking zone is still hot.
Activating the child safety lock
Prerequisites:
QQ The cooktop is switched on.
QQ All cooking zones are switched off.
XX
Within 10 seconds of switching it on, press sensor
­buttons
and
simultaneously before pressing
sensor button
one more time.
L is displayed in all cooking zone indicators. The child
safety lock is activated.
Deactivating the child safety lock for a
­cooking session
INFO
If a cooking zone indicator alternately shows 0
and H, this means the cooking zone is still hot.
XX
Press
and
simultaneously.
In the time display 00 will appear for a few seconds on
both rear cooking zone indicators.
XX
Press
or
to set the required time.
After the last input, the set time will be displayed in the
timer display for a few seconds.
Press sensor buttons
and
simultaneously. The
power level 0 is displayed in all cooking zone indicators
and the cooking zone indicator lights flash.
The power level you require can now be set for each
cooking zone.
After the cooktop has been switched off, the child safety
lock is activated again.
Changing the timer settings
Deactivating the child safety lock
XX
Press the cooking zone button for the cooking zone,
for which you wish to change the automatic cut-off.
XX
Press
and
simultaneously.
In the timer display, the set time is displayed and the
cooking zone indicator light flashes.
XX
Press
or
to set the required time.
If several timers are active
XX
Continue pressing
and
simultaneously until
the indicator light for the desired cooking zone starts
flashing.
The cooking zone control lights are controlled in a
clockwise order for which a timer was activated,
­beginning with the short time (egg timer).
XX
Press
or
to change the set time.
Switching the timer off early
XX
Press the cooking zone button of the cooking zone for
which you wish to switch off the timer.
XX
Press
and
simultaneously.
In the timer display, the set time is displayed and the
cooking zone indicator light flashes.
XX
Press
until the timer display shows 00.
30
INFO
If a cooking zone indicator alternately shows 0
and H, this means the cooking zone is still hot.
Prerequisites:
QQ The cooktop is switched on.
XX
Press sensor buttons
and
simultaneously and
then
one more time.
All cooking zone indicators display power level 0. The
child safety lock is deactivated.
7.2
Operating the cooktop extractor
Prerequisite:
QQ The cooktop with integrated cooktop extractor is
switched on.
Recommendations for an efficient vapour extraction:
XX
Make sure to always use a lid for pots that are
­particularly high. This ensures effective vapour
­extraction. It also reduces power consumption.
XX
Only operate the cooktop extractor at the minimum
power level required for an effective vapour extraction.
This way, you can improve the performance of the
odour filters during air circulation operation.
www.bora.com
Operation
XX
Only operate the hob at the minimum power level
required for cooking. This reduces the cooking vapours
and power consumption.
XX
Avoid strong drafts.
7.2.1 Switching on the cooktop extractor
XX
Press
or
to switch on the cooktop extractor.
0 is shown in the fan level indicator. If no further
input is made, the cooktop extractor will switch off
­automatically a few seconds afterwards.
7.2.2 Setting the fan level
XX
Press
to increase the fan level.
The following fan level sequence is run through:




Abb. 7.1
When the fan level indicator displays 0, the cooktop
­extractor is switched off automatically after a few ­seconds.
7.3
XX
Press
to reduce the fan level. The following fan level
sequence is run through:



If the fan level indicator displays F (F = filter service
indicator), this means the activated charcoal filter is used
up (for recirculated air only) and the stainless steel grease
filter needs an overhaul.
If you do not wish to do the filter change yet, e.g. if you
only cook occasionally:
XX
Press
or
to go into the normal operating mode.
0 is shown in the fan level indicator.
The filter service indicator remains active and is shown
again each time the cooktop with integrated cooktop
extractor is switched back on again.
Carrying out a filter change
XX
Switch off the cooktop with integrated cooktop extractor.
XX
Replace the activated charcoal filter (only for
­recirculated air BIU) (see Cleaning chapter ).
XX
Clean the stainless steel grease filter
(see the Cleaning chapter).
If the activated charcoal filter was replaced (only for recirculated air) and the stainless steel grease filter was cleaned, it
will be necessary to reset the filter service display.
XX
Switch on the cooktop with integrated cooktop extractor.
The fan level indicator displays F.
XX
Press
and
simultaneously for at least three
­seconds until a 0 flashes in the fan level indicator.
After a few seconds, 0 will be displayed permanently.
The filter service display has been reset.
7.4
Abb. 7.2

Fan level sequence
7.2.3 Switching on the delayed automatic
after-run
XX
Continue pressing
until power level n is displayed
for automatic after-run.
The fan runs in level 1 and switches off automatically
after 10 minutes.
7.2.4 Switching off the cooktop extractor
XX
Press
and
simultaneously until the fan level
indicator 0 is displayed.
or
XX
Press
or
several times until the fan level
­indicator 0 is displayed.
www.bora.com
Pay attention to the filter service
display
Resetting the filter service display
Fan level sequence

EN
Saving energy
XX
Follow all of the energy-saving tips to use the cooktop
with integrated cooktop extractor in an energy-efficient
manner.
XX
When purchasing cookware, pay attention to the
­diameter of the base. Usually the upper diameter of the
pot is given. The diameter of the base is often smaller.
XX
Use pressure cookers. Due to the closed cooking
chamber and the overpressure, pressure cookers save
the most time and energy. The short cooking time
helps preserve vitamins.
XX
Make sure there is sufficient liquid in the pressure
cooker. An empty pot which is still being heated can
lead to overheating. The cooking zone and the pot may
be damaged by overheating.
XX
If possible, always close cookware using a suitable lid.
XX
Choose a suitable size of cookware commensurate
with the amount of food you are cooking. A big pot that
is barely filled requires a lot of energy.
31
Cleaning and ­maintenance
EN
8 Cleaning and
­maintenance
XX
Observe all safety and warning information
(see Safety chapter).
XX
Follow the enclosed manufacturer’s information.
XX
Make sure that the cooktop and cooktop extractor
have been switched off completely and have cooled
down prior to the planned cleaning and maintenance
work to prevent injury (see the Operation chapter).
QQ Regular cleaning ensures the longevity of the product
and optimal functioning.
XX
Adhere to the following cleaning and maintenance
cycles:
Component
Cleaning cycle
Operating panel
Immediately after every soiling
Cooktop
Immediately after every soiling every week
thoroughly with standard commercially
available glass ceramic cleaners
Cooktop extractor
Weekly
Air inlet nozzle and
stainless steel grease
filter
After every time you prepare very greasy
foods; at least weekly, when the fan
level indicator = F by hand or in the
­dishwashing machine (at a max. 65 °C);
Only clean the stainless steel surfaces in
the polishing direction!
Air guiding housing
Clean every 6 months or when replacing
the activated charcoal filter
Activated charcoal
filter (only for
recirculated air)
Replace after the build-up of odour, when
the extraction power has diminished or
the fan level indicator shows F
Tab. 8.1
8.1
INFO
Cleaning cycles
Cleaning agents
Due to the use of aggressive cleaning agents
and abrasion caused by the pot bases the
­surface will become damaged and dark stains
will occur.
You need a special glass ceramic panel scraper and
­suitable cleaning agents to clean the cooktop.
XX
Never use steam cleaners, abrasive sponges, scouring
pads, or chemically aggressive cleaning agents (e.g.
baking oven spray).
XX
Make sure that the cleaning agent does not contain
any sand, soda, acids or chloride.
8.2
Maintaining the cooktop
XX
Do not use the cooktop as a worktop or shelf.
XX
Do not push or pull cookware across the cooktop.
XX
Always lift pots and pans.
XX
Keep the cooktop clean.
XX
Remove any kind of soiling immediately.
XX
Only use cookware which is suitable for glass ceramic
panels (see the Device description chapter)
8.3
INFO
Cleaning the cooktop
When the cooktop extractor is switched on,
the air inlet nozzle is installed to ensure that no
small and light objects, such as cleaning wipes
made of fabrics or paper are sucked in.
XX
Make sure that the cooktop is switched off (see
­Operating chapter).
XX
Wait until all cooking zones are cold.
XX
Remove all coarse soiling and food residues from the
cooktop with a glass ceramic scraper.
XX
Apply the cleaning agent onto the cold cooktop.
XX
Rub the cleaning agent with a paper towel or a clean cloth.
XX
Wipe off the cooktop while wet.
XX
Rub the cooktop dry with a clean cloth.
When the cooktop is hot:
XX
Immediately remove molten residues of plastic,
­aluminium film, sugar or foods containing sugar with
a glass ceramic scraper from the hot cooking zone to
prevent burning them in.
Special soiling
XX
Heavy soiling and stains (limescale stains, pearly
­shimmering stains) are best to be removed if the
­cooktop is still warm.
XX
Soften dried dirt residues using a damp cloth.
XX
Remove dirt residues with the glass ceramic scraper.
XX
Always remove grains, crumbs or the like which fall
onto the cooktop during general cooking work right
away to prevent the surface from being scratched.
Coloured changes and shiny surfaces are not cooktop
­damage. They do not impact on the function of the
­cooktop and the stability of the glass ceramic.
Discolourations to the cooktop arise from residues which
are not removed and have been burnt in.
Glossy spots are caused by the abrasion of the pot base,
especially when using cooking utensils with aluminium
bases, or by unsuitable cleaning agents. They are very
hard to remove.
For air inlet nozzle and grease filter
XX
Do not use any aggressive, acidic or alkaline cleaning
agents.
32
www.bora.com
Cleaning and ­maintenance
8.4
Cleaning the cooktop extractor
The air inlet nozzle and the stainless steel grease filter
absorb the greasy components of the kitchen vapour.
XX
Make sure that the cooktop and cooktop extractor are
switched off (see Operating chapter).
XX
Wait until the fan display is 0.
XX
Clean the cooktop extractor in accordance with the
cleaning cycles (see Tab. 7.1).
XX
Clean the surfaces of the exhaust air system using a
soft damp cloth, detergent or a mild window cleaning
agent.
XX
Soften dried-on dirt residues using a damp cloth
(do not scratch!).
8.4.1 Removing the air inlet nozzle and
stainless steel grease filter
1
2
Abb. 8.1
EN
8.4.2 Cleaning the air inlet nozzle and
stainless steel grease filter
INFO
Clean the stainless steel surfaces in the
­polishing direction only.
INFO
If the stainless steel grease filter can no
longer be cleaned completely, this means the
­stainless steel grease filter will need to be
replaced.
Manual cleaning
XX
Use a degreasing cleaning agent.
XX
Rinse the inlet nozzle and stainless steel grease filter
with hot water.
XX
Use a soft brush to clean the inlet nozzle and stainless
steel grease filter.
XX
After cleaning, rinse the inlet nozzle and stainless steel
grease filter well.
Cleaning in the dishwasher
XX
Rinse the air inlet nozzle and the stainless steel grease
filter with a rinsing program at a maximum of 55 °C.
8.4.3 Installing stainless steel grease filter
and air inlet nozzle
Removing the air inlet nozzle
[1] Air inlet nozzle
[2] Access opening
Prerequisite: The fan level indicator indicates 0.
XX
Reach into the access opening [2] with your hand.
XX
Remove the air inlet nozzle [1] out upwards.
XX
Grab the stainless steel grease filter using the handle [2]
(Fig. 7.2)
XX
Insert the stainless steel grease filter [1] into the
­suction opening.
XX
Make sure that the stainless steel grease filter rests
against the bottom housing base. A lock is not needed
and is not provided.
XX
Reach into the access opening [2] of the inlet nozzle
with your hand (Fig. 7.1).
XX
Insert the air inlet nozzle (Fig. 7.1; [1]) centrally into
the suction opening.
XX
Press the air inlet nozzle upwards until it engages.
1
2
3
Abb. 8.2
Removing the stainless steel grease filter
[1] Stainless steel grease filter
[2] Handle
[3] Suction opening
XX
Grab the stainless steel grease filter using the
handle [2].
XX
Pull the stainless steel grease filter [1] out of the
­suction opening [3] upwards.
www.bora.com
8.5
Cleaning the air guiding housing
Greasy deposits and limescale residues from the cooking
vapour can accumulate on the surface of the air guiding
housing. Regular, thorough cleaning (see Table 7.1) is
thus necessary.
The air guiding housing is on the underside of the cooktop
in the floor unit.
8.5.1 Opening the air guiding housing
XX
Make sure that the cooktop and cooktop extractor are
switched off (see Operating chapter).
XX
Wait until the fan display is 0.
33
Cleaning and ­maintenance
EN
XX
Using both hands, position the housing base [5] so that
the position of the locking straps [4] on the housing base
match the position of the hooks [3] on the housing.
XX
Insert the housing base at the sealing groove [2] of the
air guiding housing [1].
XX
Press the housing base [5] upwards until the 4 locks
(2 front, 2 rear) engage into the hooks [3].
XX
Check that all 4 locking straps [4] have correctly engaged.
8.6
4
Abb. 8.3
[1]
[2]
[3]
[4]
1
4
3
2
1
Opening the air guiding housing
Front locks
Air guiding housing
Housing base
Rear locks
8.5.2 Closing the air guiding housing
1
2
34
The activated charcoal filters must be replaced
when the fan level indicator indicates F (filter
service display).
BAKF activated charcoal filters can be
­pur­chased from your specialist.
You can also contact BORA on its homepage
http://www.bora.com.
XX
Make sure that the cooktop and cooktop extractor are
switched off (see Chapter 6.1).
XX
Wait until the fan display is 0.
1
3
2
1
3
Abb. 8.5
4
[1] Outer locks
[2] Activated carbon filter housing cover
[3] Middle lock
5
[1]
[2]
[3]
[4]
[5]
Two activated charcoal filters are used only when the
cooktop extractor is being operated in recirculated
air mode. The activated charcoal filter binds odorous
­materials which arise during cooking.
INFO
XX
Hold the housing base with one hand [3].
XX
Open both locks on the rear [4].
XX
Open both front locks [1].
XX
Remove the housing base [3].
XX
Clean the air guiding housing [2] and the housing base
[3] with a mild cleaning agent.
Abb. 8.4
Replacing the activated charcoal
filter
Releasing the activated carbon filter housing lid
Closing the air guiding housing
Air guiding housing
Sealing groove
Hooks
Locking strop
Housing base
www.bora.com
Cleaning and ­maintenance
Removing the activated carbon filter
EN
XX
Remove the activated charcoal filter by moving it
downwards.
XX
Dispose of used activated charcoal filters with
household waste.
1
Inserting the activated charcoal filter
Abb. 8.6
Opening middle lock
[1] Lock, middle
XX
Open the lock [1] in the middle.
2
Abb. 8.9
1
Abb. 8.7
Opening outer locks
[1] Outer lock
XX
Open both outer locks [1].
XX
Fold the lid (Fig. 7.5; [2]) down until it engages.
1
Inserting the activated charcoal filter
[1] Filter bracket
[2] Activated charcoal filter
XX
Position the new activated charcoal filter [2] in such a
way that the directional arrow is pointing to the rear
and is visible from below.
XX
Move the activated charcoal filter into the housing.
XX
Press the activated charcoal filter upwards until the
filter retainer [1] engages.
click
click
click
2
1
1
1
2
1
Abb. 8.10 Closing the activated charcoal filter housing lid
Abb. 8.8
Removing the activated carbon filter
[1] Activated charcoal filter
[2] Filter bracket
XX
Hold the activated charcoal filter with one hand [1].
XX
Push the filter retainer [2] to the back.
www.bora.com
[1] Locks
[2] Activated carbon filter housing cover
XX
Fold the activated charcoal filter housing lid [2] by
moving up upwards.
XX
Press on the activated charcoal filter housing lid until
the locks [1] engage.
35
Troubleshooting
EN
9 Troubleshooting
Observe all safety and warning information (see Safety chapter).
Operating situation
Cause
Remedy
The cooktop or the fan cannot be
switched on.
The fuse or the automatic circuit breaker
of the electrical installation of the
­apartment and/or house is defective.
Replace the fuse.
The fuse or the automatic circuit breaker
trips several times.
Call the BORA Service Team.
The power supply is disconnected.
Have a specialist electrician inspect the power
supply.
Odours and vapours arise when the new
cooktop is put into operation.
This is normal on brand-new
appliances.
Wait a few operating hours.
Contact the Service Team if the odour persists.
v is displayed in the cooking zone
indicator.
No or unsuitable cooking utensils have
been placed on the cooking zone.
Only use suitable cookware.
Select the cookware size depending on the
­cooking zone (see Device Description chapter).
L is displayed in the cooking zone
The child safety lock is activated.
Switch off the child safety lock
(see Operating chapter).
A cooking zone or the entire cooktop
­switches off automatically.
The operating time of a cooking zone has
been exceeded.
Put the cooking zone back into
operation (see Operating chapter).
The overheat protection has tripped.
(see Device Description chapter)
The power setting is automatically
shut off prematurely.
The overheat protection has tripped.
(see Device Description chapter)
E is displayed in the fan level indicator.
ER03 is shown across all 4 cooking zone
One or more sensor buttons are covered,
e.g. due to finger contact or by objects
placed on them.
Clean the control panel or remove ­objects
(see Device description chapter).
The cooling fan continues running after
the cooktop has been switched off.
The fan will continue to run until the
cooktop has cooled down and will then
switch off automatically.
Wait until the fan switches off automatically.
E is displayed in the cooking zone
An error has occurred in the
electronic system.
Interrupt the power supply of the cooktop for
approx. 1 minute.
If the problem continues to persist after the
power supply has been restored, write down
the error number and contact BORA Customer
Services.
F is displayed in the fan level indicator.
The period of use of the filters has been
exceeded.
Replace the activated charcoal filter (only
with recirculated air) and ­thoroughly clean the
­stainless steel grease filter. In case of heavy
­soiling, replacing the stainless steel grease
filter is also ­recommended (see Cleaning/­
Maintenance chapter).
The extraction rate of the
cooktop extractor has decreased.
The stainless steel grease filter is heavily
soiled.
Clean or replace the stainless steel grease filter.
The activated carbon filter is heavily
soiled (only BIU).
Replace the activated charcoal filter.
There is an object in the air guiding
housing (e.g. cleaning cloth).
Remove the trapped object.
The fan is defective or a duct connection
has loosened.
Call the BORA Service Team.
indicator.
indicators, and the cooktop switches off
during operation.
indicator.
Tab. 9.1
Switch the safety cut-out back on.
Resolving a fault
XX
In all other instances, call the BORA Service Team (see the Warranty, service and spare parts chapter).
36
www.bora.com
Decommissioning, disassembly and disposal
10 Decommissioning,
disassembly and
disposal
XX
Observe all safety and warning information
(see Safety chapter).
XX
Follow the enclosed manufacturer’s information.
10.1 Decommissioning
Decommissioning is considered the final decommissioning
and disassembly. After decommissioning, the device can
either be built into another piece of furniture, sold on
privately, or disposed of.
INFO
Disconnecting and connecting the electricity
and gas connection may only be carried out by
certified experts.
XX
Switch off the device before decommissioning
(see Operating chapter)
XX
Disconnect the device from the voltage supply.
10.2 Disassembly
The removal requires that the device is accessible
for ­disassembly and was separated from the voltage
­supply. On gas-powered devices, make sure that the gas
­connection is complete.
XX
Undo the mounting brackets.
XX
Remove the silicone joints.
XX
Disconnect the duct from the cooktop extractor.
XX
Remove the device from the worktop upwards.
XX
Remove further accessory parts.
XX
Remove the old appliance and dirty accessory as
­described under “Disposing of the product in an
­environmentally friendly way”.
www.bora.com
EN
10.3 Disposing of the product in an
environmentally friendly way
Disposal of transport packaging
INFO
The packaging protects the device against
transport damages. The packaging is made of
materials that are environmentally friendly and
easy to dispose of and can therefore be recycled.
Returning the packaging material into the material cycle
saves resources and reduces the waste production. Your
specialist supplier will take the packaging back.
XX
Hand the packaging to your specialist supplier
or
XX
Dispose of the packaging properly taking into account
the regional regulations.
Disposing of the old appliance
Electrical devices marked with this
symbol should not be disposed of as
household waste at the end of its life.
They must be taken to a collection
centre for recycling electrical or
electronic non-heating appliances.
For information, please contact your
city or local authorities.
Waste electric and electronic equipment often still
contains valuable materials. They do, however, also
contain harmful substances that were required for their
correct functioning and safety. When disposed of in the
residual waste or if not handled correctly, they may cause
harm to the health of people and the environment.
XX
Therefore do not dispose of your old appliance as
household waste.
XX
Take the old appliance to a regional collection centre
for return and recycling of electronic and electrical
parts and other materials.
37
Warranty, service and spare parts
EN
11 Warranty, service and
spare parts
XX
Observe all safety and warning information
(see Safety chapter).
11.1 Warranty
The warranty period shall be 2 years.
11.2 Service
BORA Service:
see reverse side of operating and assembly instructions
+800 7890 0987
XX
In the case of faults you cannot fix yourself,
contact your BORA specialist supplier or the
BORA Service Team.
The After Sales Service will require the type designation
and the serial number of your device (FD number). This
information is provided on the nameplate or on the back
of the manual as well as on the device.
11.3 Spare parts
XX
Only use original spare parts when making repairs.
INFO
38
Spare parts can be obtained from your BORA
dealer, the BORA online service website at
www.bora.com/service or by calling the
service number provided.
www.bora.com
Notes:
EN
12 Notes:
www.bora.com
39
Nameplate:
Germany::
Australia – New Zealand:
BORA Lüftungstechnik GmbH
Rosenheimer Str. 33
83064 Raubling
Germany
T +49 (0) 8035 / 907-240
F +49 (0) 8035 / 907-249
info@bora.com
www.bora.com
BORA APAC Pty Ltd
A/ 91-95 Victoria Road
Drummoyne NSW 2047
Australia
T +61 2 7900 5580
F +61 2 8076 3514
info@boraapac.com.au
www.boraapac.com.au
Austria:
BORA Vertriebs GmbH & Co KG
Prof.-Dr.-Anton-Kathrein-Straße 3
6342 Niederndorf
Österreich
T +43 (0) 5373 / 62250-0
F +43 (0) 5373 / 62250-90
mail@bora.com
www.bora.com
Europe:
BORA Holding GmbH
Prof.-Dr.-Anton-Kathrein-Straße 3
6342 Niederndorf
Austria
T +43 (0) 5373 / 62250-0
F +43 (0) 5373 / 62250-90
mail@bora.com
www.bora.com
+800 7890 0987
Download PDF
Similar pages
