WMA MP3 CD Player/HD-Radio Receiver with Full Dot Matrix Motorized Display
CQ-CB8901U
®
Operating Instructions
CQ-CB8901U
SRC
CQ-C8401U
TEXT
Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America
One Panasonic Way, Secaucus, New Jersey 07094
http://www.panasonic.com
YEFM285625A
ND1204-1015
Printed in China
¡Please read these instructions (including “Limited Warranty” and “Customer Services Directory”) carefully before using this product
and keep this manual for future reference.
Safety Information
ponents of your car audio system carefully before using the
system. They contain instructions about how to use the system in a safe and effective manner. Panasonic assumes no
responsibility for any problems resulting from failure to
observe the instructions given in this manual.
Warning
This pictograph intends to alert you to the presence of important operating instructions and
installation instructions. Failure to heed the
instructions may result in severe injury or death.
Warning
Observe the following warnings when using
this unit.
❑ The driver should neither watch the display nor
operate the system while driving.
Watching the display or operating the system will distract
the driver from looking ahead of the vehicle and can cause
accidents. Always stop the vehicle in a safe location and use
the parking brake before watching the display or operating
the system.
❑ Use the proper power supply.
This product is designed for operation with a negative
grounded 12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery
system.
❑ Keep batteries and insulation film out of reach of
infants.
Batteries and insulation film can be ingested, so keep them
out of the reach of infants. If an infant ingests a battery or
insulation film, please seek immediate medical attention.
❑ Protect the Deck Mechanism.
Do not insert any foreign objects into the slot of this unit.
❑ Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the
product yourself. If the product needs to be repaired, consult your dealer or an authorized Panasonic Servicenter.
❑ Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an
abnormal state (has foreign objects in it, is exposed to
water, is smoking, or smells), turn it off immediately and
consult your dealer.
❑ The remote control unit should not lie about in the
car.
If the remote control unit lies about, it could fall on the floor
while driving, get wedged under the brake pedal, and lead to
a traffic accident.
❑ Refer fuse replacement to qualified service personnel.
When the fuse blows out, eliminate the cause and have it
replaced with the fuse prescribed for this unit by a qualified
service engineer. Incorrect replacement of the fuse may lead
to smoke, fire, and damage to the product.
■ This manual uses pictographs to show you how to use the
product safely and to alert you to potential dangers resulting
from improper connections and operations. The meanings of
the pictographs are explained below. It is important that you
fully understand the meanings of the pictographs in order to
use this manual and the system properly.
Caution
This pictograph intends to alert you to the presence of important operating instructions and
installation instructions. Failure to heed the
instructions may result in injury or material damage.
Observe the following warnings when
installing.
❑ Disconnect the lead from the negative (–) battery
terminal before installation.
Wiring and installation with the negative (–) battery terminal
connected may cause electrical shock and injury due to a
short circuit.
Some cars equipped with the electrical safety system have
specific procedures of battery terminal disconnection.
FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY
SYSTEM RESULTING IN DAMAGE TO THE VEHICLE AND
PERSONAL INJURY OR DEATH.
❑ Never use safety-related components for installation, grounding, and other such functions.
Do not use safety-related vehicle components (fuel tank,
brake, suspension, steering wheel, pedals, airbag, etc.) for
wiring or fixing the product or its accessories.
❑ Installing the product on the air bag cover or in a
location where it interferes with airbag operation is
prohibited.
❑ Check for piping, gasoline tank, electric wiring, and
other items before installing the product.
If you need to open a hole in the vehicle chassis to attach or
wire the product, first check where the wire harness, gasoline tank, and electric wiring are located. Then open the hole
from outside if possible.
❑ Never install the product in a location where it interferes with your field of vision.
❑ Never have the power cord branched to supply other
equipment with power.
❑ After installation and wiring, you should check the
normal operation of other electrical equipment.
The continuation of their using in abnormal conditions may
cause fire, electrical shock or a traffic accident.
❑ In the case of installation to an airbag-equipping
car, confirm warnings and cautions of the vehicle
manufacturer before installation.
❑ Make sure the leads do not interfere with driving or
getting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
Caution
Observe the following cautions when using this
unit.
❑ Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road and
traffic conditions while driving.
❑ Do not insert or allow your hand or fingers to be
caught in the unit.
To prevent injury, do not get your hand or fingers caught in
moving parts or in the disc slot. Especially watch out for
infants.
❑ This unit is designed for use exclusively in automobiles.
❑ Do not operate the unit for a prolonged period with
the engine turned off.
Operating the audio system for a long period of time with the
engine turned off will drain the battery.
❑ Do not expose the unit to direct sunlight or excessive heat.
Otherwise these will raise the interior temperature of the
unit, and it may lead to smoke, fire, or other damage to the
unit.
❑ Do not use the product where it is exposed to water,
moisture, or dust.
Exposure of the unit to water, moisture, or dust may lead to
smoke, fire, or other damage to the unit. Make especially
sure that the unit does not get wet in car washes or on rainy
days.
❑ Do not install the product where it is exposed to
strong vibrations or is unstable.
Avoid slanted or strongly curved surfaces for installation. If
the installation is not stable, the unit may fall down while
driving and this can lead to an accident or injury.
❑ Installation Angle
The product should be installed in a horizontal position with
the front end up at a convenient angle, but not more than
30˚.
The user should bear in mind that in some areas there may
be restrictions on how and where this unit must be installed.
Consult your dealer for further details.
❑ Wear gloves for safety. Make sure that wiring is
completed before installation.
❑ To prevent damage to the unit, do not connect the
power connector until the whole wiring is completed.
❑ Do not connect more than one speaker to one set of
speaker leads. (except for connecting to a tweeter)
Observe the following cautions when handling
the battery for the remote control unit.
● Use only specified battery (CR2025).
● Match the polarity of the battery with the (+) and (–) marks
in the battery case.
● Replace dead battery as soon as possible.
● Remove the battery from the remote control unit when not
using it for an extended period of time.
● Insulate the battery (by placing them in a plastic bag or covering them with vinyl tape) before disposal or storage.
Observe the following cautions when
installing.
● Dispose of the battery according to the local regulations.
● Do not disassemble, recharge, heat or short the battery. Do
❑ Refer wiring and installation to qualified service
personnel.
In case of battery leakage
● Thoroughly wipe the battery liquid off the battery case and
Installation of this unit requires special skills and experience.
For maximum safety, have it installed by your dealer.
Panasonic is not liable for any problems resulting from your
own installation of the unit.
❑ Follow the instructions to install and wire the product.
Safety Information
■ Read the operating instructions for the unit and all other com-
not throw a battery into a fire or water.
insert new battery.
● If any part of your body or clothing comes into contact with
battery liquid, wash it with plenty of water.
● If battery liquid comes into contact with your eyes, wash
them with plenty of water and get immediate medical attention.
Not following the instructions to properly install and wire the
product could cause an accident or fire.
❑ Take care not to damage the leads.
When wiring, take care not to damage the leads. Prevent
them from getting caught in the vehicle chassis, screws, and
moving parts such as seat rails. Do not scratch, pull, bend or
twist the leads. Do not run them near heat sources or place
heavy objects on them. If leads must be run over sharp
metal edges, protect the leads by winding them with vinyl
tape or similar protection.
❑ Use the designated parts and tools for installation.
Use the supplied or designated parts and appropriate tools
to install the product. The use of parts other than those supplied or designated may result in internal damage to the unit.
Faulty installation may lead to an accident, a malfunction or
fire.
❑ Do not block the air vent or the cooling plate of the
unit.
Blocking these parts will cause the interior of the unit to
overheat and will result in fire or other damage.
2
CQ-CB8901U
CQ-CB8901U
3
Service and Warranty
U.S.A.
The following applies only in the U.S.A.
Caution
THIS PRODUCT IS A CLASS I LASER PRODUCT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR BY YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Part 15 of the FCC Rules
PANASONIC CONSUMER ELECTRONICS COMPANY,
DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA
One Panasonic Way, Secaucus, New Jersey 07094
FCC Warning:
Any unauthorized changes or modifications to this
equipment would void the user's authority to operate
this device.
PANASONIC SALES COMPANY,
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
Ave. 65 de infanteria, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985
LIMITED WARRANTY COVERAGE
If your product does not work properly because of defects in materials and workmanship.
Panasonic Consumer Electronics Company or Panasonic Sales
Company (collectively referred to as “the warrantor”) will, for the
length of the period indicated in the chart below, which starts with
the date of original purchase (“warranty period”), at its option either
(a) repair your product with new or refurbished parts, or (b) replace
it with a new or refurbished product. The decision to repair or
replace will be made by the warrantor.
During the “Labor” warranty period, there will be no charge for
labor. During the “Parts” warranty period, there will be no charge for
Obtain Product Information and Operating Assistance;
locate your nearest Dealer or Servicenter; purchase
Parts and Accessories; or make Customer Service and
Literature requests by visiting our Web Site at:
http://www.panasonic.com/support
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262),
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7
pm, EST.
For hearing or speech impaired TTY users, TTY : 1-877833-8855
Accessory Purchases:
Purchase Parts, Accessories and Instruction Books
online for all Panasonic Products by visiting our Web
Site at:
http://www.pasc.panasonic.com
or, send your request by E-mail to:
npcparts@panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday-Friday 9 am to 8 pm, EST.)
Panasonic Services Company
20421 84th Avenue South, Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American
Express, and Personal Checks)
For hearing or speech impaired TTY users, TTY : 1-866605-1277
Service in Puerto Rico
Matsushita Electric of Puerto Rico, Inc.
Panasonic Sales Company
Factory Servicenter:
Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial
Park,
Carolina, Puerto Rico 00985
Phone (787) 750-4300, Fax (787) 768-2910
Categories
Limited Warranty
Customer Services Directory
U.S.A.
Parts
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have
other rights which vary from state to state. If a problem with this
product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not handled to your
satisfaction, then write to warrantor’s Consumer Affairs Department
at the addresses of the warrantor.
PANASONIC AUTO PRODUCTS
LIMITED WARRANTY
Service and Warranty
IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.
Labor
Audio Components (except items listed
below)
MXE Series Audio Components (except
items listed below)
Speakers
One (1) Year
One (1) Year
Two (2) Years
Two (2) Years
One (1) Year
Not Applicable
Accessories (in exchange for defective
items)
Ninety (90) Days Not Applicable
PARTS AND SERVICE WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY ARE YOUR RESPONSIBILITY.
Safety Information, Service and Warranty
Safety Information (continued)
Customer’s Record
Model
No.
Serial
No.
Dealer’s
No.
Code
No.
Dealer’s
Address
Date of
Purchase
parts. You must carry in or mail in your product during the warranty
period. If non-rechargeable batteries are included, they are not warranted. This warranty only applies to products purchased and serviced in the United States or Puerto Rico. This warranty is extended
only to the original purchaser of a new product which was not sold
“as is”. A purchase receipt or other proof of the original purchase
date is required for warranty service.
CARRY-IN OR MAIL-IN SERVICE
For Carry-In or Mail-In Service in the United States, call 1-800-211PANA (7262) or visit
Panasonic Web Site: http://www.panasonic.com
For assistance in Puerto Rico, call Panasonic Sales Company (787)750-4300 or fax (787)-768-2910.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials and
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages
which occurred during shipment, failures which are caused by products not supplied by the warrantor, failures which result from accident, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustment, maladjustment of consumer control, improper maintenance, improper antenna, inadequate
signal reception or pickup, power line surge, improper voltage supply, lightning, modification, commercial use (such as use in hotels,
offices, restaurants, or other business uses) or rental use of the
product, or service by anyone other than the technician from Factory
Servicenter or other authorized service centers, or damage that is
attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED
UNDER “LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS
NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install
an installed unit if applicable, travel to and from the servicer, and
loss of media, data or other memory contents. The items listed are
not exclusive, but are for illustration only.) ALL EXPRESS AND
4
CQ-CB8901U
CQ-CB8901U
5
Before Reading These Instructions
Features
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully
selected components, and assembled by people who are proud of the reputation their work has built for our company. We
know this product will bring you many hours of enjoyment, and after you discover the quality, value and reliability we have
built into it, you too will be proud to be a member of our family.
POWER
SOURCE MENU
XXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
SEL
SRC
OO-OOOOO
VOL
SET
BAND
MUTE
1
2
3
RANDOM
SCAN
REPEAT
4
5
7
8
9
0
DISP
6
TUNE
TUNE
#
NUMBER
CAR AUDIO
Operating
Instructions
Owners
Information Card
Removable Face
Plate Case
Remote Control Unit
(including a battery)
(CR2025)
(YEFA131646)
(EUR7641010)
(YEFM285625)
Instruction kit
Qty: 1
Qty: 1
Q'ty: 1 set
You can hear the digital broadcasting easily due to the
incorporation of the IBOC system. “IBOC” stands for In Band On
Channel. This system adds to the existing analog radio signals
by using broadcast carrier.
As a result, Sound quality of AM/FM broadcasting is greatly
improved (An AM is to an FM quality, an FM is to a CD quality).
The station names, call sign, artists and song titles can be
received and displayed on your unit.
*A special antenna is not necessary to tune into a HD Radio
broadcast station.
Accessories
Full lineup of optional parts
Power Connector
Mounting Collar
Trim Plate
Rear Support Strap
(YEAJ02871)
(YEFX0217222)
(YEFC05654)
(YEFG04019)
Qty: 1
Qty: 1
Qty: 1
Qty: 1
An optional XM tuner allows you to receive the XM radio
service. A DVD changer instead of an XM tuner is also
connectable.
¡ Toll free number
XM Tuner P/N: XMD1000
Call 1-800-XM-RADIO(96-72346)
Extension cord P/N: XMDPAN100
Call 1-800-942-TERK(8375)
The XM name and related logos are trademarks of XM Satellite
Radio Inc.
Notes:
¡A changer and an XM receiver are not connectable at the
same time.
¡ To connect the XM receiver (XMD1000), it is required to use
an optional extension cord (XMDPAN100) that is produced by
XM exclusively for Panasonic products.
Other function
● Electric-controlled retractable face plate equipped
(Tilt a page 15)
● Adjustable 7-band preset equalizer (SQ a page 18)
● Initially stored moving images and still images are editable to
taste. IMAGE STUDIO* allows you to process images from a
digital camera or other devices without difficulty. ( a page
37)
* This software is downloadable from Panasonic Web site
(http://panasonic.co.jp/pas/en/software/customize/index.html).
Delightful sound space thanks to system buildup
XM Receiver
XMD1000: manufactured by XM Satellite
Radio (Option)
Hex. Nut
(5 mmø)
Tapping Screw
(5 mmø X 16 mm)
Mounting Bolt
Headrest Monitor: CY-V7100U (Option)
Lock Cancel Plate
Before Reading These Instructions, Features
HD Radio tuner for the AM/FM built in
(YEP0FZ5701)
Qty: 1 set
Notes:
¡ The number in parenthesis underneath each accessory part name is the part number for maintenance and service.
¡ Accessories and their parts numbers are subject to modification without prior notice due to improvements.
¡ Mounting Collar and Trim Plate are mounted on the main unit at shipment.
CQ-CB8901U
Head unit
DVD Changer:
CX-DH801U
(Option)
Stereo/Mono
Power Amplifier (Option)
6
CQ-CB8901U
Sub-Woofer
(Option)
*You can connect only one of a changer, an XM receiver
and other commercially available portable audio
equipment.
CQ-CB8901U
7
Contents
Features
What is HD Radio™?
While HD Radio™ will bring you pristine audio quality, it will
also provide data services*. Both AM and FM HD Radio™
stations will transmit song and artist title, traffic updates,
weather alerts, news reports and much more. For more
information, visit www.hd-radio.com. Stay tuned!
HD Radio is a trademark of iBiquity Digital Corporation.
HD Radio broadcasts can be enjoyed only in those areas in the United States where the broadcasts can be
received. This means that the HD Radio feature cannot be used outside the U.S. or in areas inside the U.S.
where these broadcasts cannot be receive. ( as of December 2003)
8
CQ-CB8901U
Common
Using these new receivers, you can pick up the new HD Radio™
digital signals at the same place on the dial (106.7 KROQ will be
digital 106.7 KROQ broadcasting in HD Radio™, 710 WOR will
be digital 710 WOR broadcasting in HD Radio™). Your favorite
HD Radio™ digital station will be right where you left it.
Additionally, new HD Radio™ receivers will still pick up stations
broadcasting in analog, so you don't need two radios. The
benefits of digital far outweigh old analog technology. HD
Radio™ makes radio “fun” again. FM digital will sound like a CD
throughout the coverage area, and AM digital will sound like
today's FM throughout the coverage area, both without the
static, hiss pops or fades that you've had to put up with for
almost a century.
¡Safety Information
¡Service and Warranty
¡Before Reading These Instructions
¡Features
¡Controls Layout
¡Preparation
¡General
2
4
6
7
10
12
14
Each Source
*This unit supports text displays for the following items; station
name, call sign, artist, song title.
¡Radio
¡CD Player
¡MP3/WMA Player
¡XM Tuner
¡Disc Changer
20
22
24
28
30
As Needed
Today's AM and FM radio is broadcast in analog, which has
lower audio quality and is filled with static, hiss, pops and fades.
Radio stations have begun a transformation to the world of
digital using a new technology called HD Radio™. Today's
analog signals and new HD Radio™ digital signals will be
transmitted at the same time from AM and FM stations. The
radios you use today will continue to function for years,
however, new receivers are needed to hear the HD Radio digital
signals broadcast from the stations.
¡Audio Setting
¡Function Setting
¡Display Setting
¡Customize the Display
¡Troubleshooting
¡Error Display Messages
¡Notes on Discs
¡Maintenance
¡Installation
¡Specifications
34
35
36
37
39
42
44
44
45
55
CQ-CB8901U
9
Controls Layout
Note: This instruction manual explains operations for use with the buttons on the main unit. (Different operations excluded)
Number Buttons
0
#
TILT
OPEN (eject)
BAND
SRC
SQ Sound Quality
MENU
DIM Dimmer
SRC Source
PWR Power
y / 5 Pause/Play
BAND
SET
APM Auto Preset
Main Unit
Memory
SRC
CQ-CB8901U
Number
POWER
SRC (SOURCE)
POWER
SOURCE
SRC
VOL
MENU
SEL
SEL Select
MENU
VOL Volume
}:Up
{:Down
RANDOM
4
RANDOM
POWER
SOURCE MENU
SEL
SRC
SCAN
5
REPEAT
6
7
SCAN
REPEAT
9
VOL
SET
SET
BAND
BAND
MUTE
1
2
3
RANDOM
SCAN
REPEAT
4
5
6
7
8
9
0
DISP
y / 5 Pause/Play
BAND
SET
APM Auto Preset
Memory
TUNE
TRACK (FILE)
MUTE
TUNE
MUTE
SBC·SW Super Bass
Control·Subwoofer
TUNE
#
NUMBER
DISP
DISP Display
8
CAR AUDIO
0
P·SET (Preset)
DISC (FOLDER)
TUNE
TRACK (FILE)
DISP Display
Release
When Face Plate
Opens
Disc slot
CQ-CB8901U
One-touch operation is available for selecting a track
playing style by use of [4] (RANDOM), [5] (SCAN), or
[6] (REPEAT). (For a Folder/Disc playing style, hold
down the same button for 2 sec. or more.)
D/A (Digital/Analog)
Functions Only by Remote Control Unit
MUTE
SBC·SW Super Bass
Control·Subwoofer
10
9
Controls Layout
P·SET Preset
DISC (FOLDER)
VOLUME
PUSH SEL Select
Remote Control Unit
NUMBER
~
Direct Access
A channel (XM mode), a track (CD mode), a disc (Disc
changer), a file and a folder (MP3/WMA mode) can be
directly selected.
Example: Track number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [BAND] (SET).
CQ-CB8901U
11
Preparation
SRC
CQ-CB8901U
Security Function
Setting
1 Set your car's ignition switch to the ACC
or On position.
(DEMONSTRATION)
First Time Power On
The demonstration screen appears.
2 Press [DISP] (Display).
The demonstration screen is cancelled, and no more
appears.
3 Press [SRC] (PWR: Power).
Note: If you would like to turn on the power and make
the demonstration message appear, hold down [SRC]
(PWR: Power) for 4 sec. or more after turning off the
power in other than the XM mode.
The following functions are activated when the Security
Function is ON. (a page 35)
¡ The security indicator lights up when removing the
face plate.
Security Indicator
You may need to set the following depending on the
devices to be connected.
Warning
Pull the insulation film out
from the backside of
remote control gently.
¡Keep batteries and insulation film out of reach of
infants. If an infant ingests a battery, please seek
immediate medical attention.
Battery Replacement
¡Remove and dispose of an old battery immediately.
¡Do not disassemble, heat or short a battery. Do not
throw a battery into a fire or water.
¡Follow local regulations when disposing of a battery.
¡Improper use of a battery may cause overheating, an
explosion or ignition, resulting in injury or a fire.
Other Settings
Using Subwoofer
Preparation Before Initial Use
w Put a battery in the case
with (+) side facing up.
e Put the case back.
2
3
12
CQ-CB8901U
Note: Battery Information:
Battery Type: Panasonic lithium battery (CR2025)
(Included in the remote control)
Battery Life : Approximately 6 months under normal use
(at room temperature)
Connecting XM tuner
¡ Connect the optional XM receiver (XMD1000).
¡ To connect the XM receiver (XMD1000), it is required
to use an optional extension cord (XMDPAN100) that is
produced by XM exclusively for Panasonic products.
Getting Started
Note:
¡ Adjust the clock when “ADJUST” appears on the
display.
Clock adjustment
Remote Control Preparation
Tough pointed object
q Remove the battery holder
with the remote control unit
placed on a flat surface.
q Stick your thumbnail into
the groove, and push the
holder in the direction of
the arrow, and at the
same time.
w
w Pull it out in the direction
q
of the arrow using a
tough pointed object.
Back side
¡ Subwoofer level adjustment (a page 34)
¡ Subwoofer low pass filter (a page 34)
¡ High Pass Filter (a page 34)
Check of XM Satellite Radio ID
1
¡ Write down the ID indicated on the lower right of your
XM receiver (XMD1000).
¡ Radio ID also can be found by turning your XM Radio
to channel 0. (Refer to “Channel Selection” on page
28.)
2 Activate the XM Satellite Radio
Select either of the below to sign up.
¡ Web site: http://www.xmradio.com/activation
¡ Phone number: 1-800-852-9696
Note: Refer to the operating instructions for the XM
receiver for details.
It is required to sign up to become an XM Satellite
Radio subscriber. After checking your XM Satellite
Radio ID, sign up on the XM’s website or by calling
them.
Cautions
Insulation film
¡ The alarm sounds and the message appears on the
screen to warn you to remove the face plate at ACC
off.
Preparation
The demonstration message appears for first use.
5 Adjust the setting value.
1 Press [MENU] to display the menu
display.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
2 Press []] or [[] to display the
DISPLAY menu.
3 Press [{] to select “CLOCK ADJ”.
4 Press [BAND] (SET) to confirm the
display.
[[]: Adjusting minutes
[]]: Adjusting hours
[}]: Forward
[{]: Backward
6 Press [BAND] (SET) to confirm the
adjustment.
7 Press [MENU].
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
CQ-CB8901U
13
General
This chapter explains how to turn on or off the power, how to adjust the volume, etc.
Open/Eject
Hold down [SRC] (PWR) until you hear a
beep, then release it.
Note: The ending screen appears. You can change the
ending screen (moving image). (a page 37)
2 Put the face
] (OPEN).
When a disc is already loaded, the disc will automatically
be ejected.
(OPEN/CLOSE, TILT)
Power off
You can remove the face
plate to prevent it from
being stolen.
Press [
CQ-CB8901U
Face Plate Motion (Open/Close, Tilt)
SRC
Note: The opening screen appears. You can overwrite
opening screen (moving image) with new one. (a page
37)
(PWR: Power)
Power On/off
Press [SRC] (PWR: Power).
plate in the case.
CQ-CB8901U
SRC
Tilt
Cautions:
¡ To avoid damaging the face plate, do not push it
down or place objects on it while it is open.
¡ Do not pinch your finger or hand in the face plate.
¡ Do not insert foreign objects into the disc slots.
¡ For the following cases, the face plate automatically closes. Use caution not to catch your finger.
¡ After a lapse of 20 seconds
¡ When a disc is inserted
¡ When the face plate is removed (a page 14)
Note: The last selected
angle is memorized even
after turning off the power.
Close
Press [
The display angle changes among 4 levels as follows
every time you hold down [
] (TILT) for 1 sec. or
more and release.
General
Power on
TILT 1
TILT 2
TILT 3
OPEN
] (OPEN).
14
(The face plate disengages with a click
when it is removed.)
1 Slide the left side of the face plate in
place.
CQ-CB8901U
The face plate automatically closes after
a lapse of 5 seconds
while it is open.
2 Press the right end of the face plate
until “click” is heard.
The power is automatically turned off while the unit
is active.
Cautions:
¡ It is recommended to remove or mount the face
plate when the plate is at the closed position.
Do not remove or mount the face plate when the
plate is in motion.
¡ This face plate is not waterproof. Do not expose it to
water or excessive moisture.
¡ Do not remove the face plate while driving your car.
CQ-CB8901U
¡ Do not place the face plate on the dashboard or
nearby areas where the temperature rises to high
levels.
¡ Do not touch the contacts on the face plate or on the
main unit, since this may result in poor electrical
contacts.
¡ If dirt or other foreign substances get on the contacts, wipe them off with clean and dry cloth.
¡ To avoid damaging the face plate, do not push it
down or place objects on it while it is open.
Setting Range: 0 to 40
Default: 18
Notes:
¡ The volume level can be set independently for each
source. (For radio, one volume setting for AM, one
volume setting for all FMs)
¡ The volume is not adjustable (except XM mode) while
an error display is on the monitor. (a page 42)
Volume off (down)
Press [
MUTE (ATT: Attenuation)
] (Release).
q Up
w Down
(VOLUME)
Mounting
Temporary Volume Off (Down)
1 Press [
(Anti-Theft System)
Face Plate Removing/Mounting
Removing
Volume Adjustment
TILT OFF
] (MUTE).
SRC
CQ-CB8901U
Cancel
Press [
] (MUTE) again.
Note: Volume-down range can be specified. (a page
35)
CQ-CB8901U
15
General
Radio
The display changes as follows every time [DISP] is
pressed.
Note: The graphic pattern and still image are selectable.
(a page 36)
CQ-CB8901U
SRC
At power-on:
Auxiliary (AUX 2)
FM1, FM2, FM3, AM (a page 20)
CQ-CB8901U
SRC
Mode
When connecting CD Changer, DVD Changer
(a page 30, 32)
Display OFF
All displays disappear in 5 seconds.
Folder hierarchy (MP3/WMA only)
When connecting a device that is not
controlled by with this unit.
(DISP: Display)
When loading CD (a page 22)
Display Change
When connecting XM Tuner (a page 28)
Player
(SOURCE)
Source Selection
Ordinary display + clock
Ordinary display + graphic pattern
Only graphic pattern
When loading MP3/WMA disc (a page 24)
Auxiliary (AUX 1)
When connecting a device that is not controlled by this
unit
Note: Please connect a CD changer or a DVD changer
to CH/AUX 2. (a Page 50)
Note: The graphic equalizer of 19 bands is
selectable when selecting a graphic pattern.
General
The source changes as follows every time [SRC]
(Source) is pressed.
Only still image
Ordinary display + still image
At power-off:
16
Off
The rear speaker can be used as a substitutional
subwoofer when a subwoofer is not connected.
The dimmer level changes as follows every time you hold
down [MENU] (DIM) for 2 sec. or more.
SRC
CQ-CB8901U
Off (default)
On
Note: If ON is selected, the settings of subwoofer level
adjustment and subwoofer low pass filter are activated.
(a page 34)
CQ-CB8901U
lights when activated.
Brighter (Default)
(DIM: Dimmer)
Holding down [ ] (SBC·SW) for 2 sec. or
more toggles SBC-SW on and off.
Dimmer Control
(SBC-SW: Super Bass Control·Subwoofer)
Substitutional Subwoofer
Clock display (default)
SRC
CQ-CB8901U
Medium
Darker
Note: This setting is not adjustable with the remote
control.
CQ-CB8901U
17
General
The sound type each of which is adjusted with 7 bands
changes every time you press [SQ].
SRC
You can make fine adjustments to the currently selected
SQ presetting in ROCK, POP, VOCAL, JAZZ, or CLUB in
accordance with your car type or taste.
CQ-CB8901U
SRC
CQ-CB8901U
1 Hold down [SQ] (Sound Quality) for 2
sec. or more.
1. FLAT
(default)
4 Hold down [}] or [{] for 2 sec. or
6. CLUB
more to confirm your adjustment.
2 Adjust each frequency.
5. JAZZ
Note: If you press [DISP], the presetting is canceled. The presetting is active until another SQ preset is called up.
3. POP
18
Notes:
¡ Setting of SQ, bass/treble and volume are influenced
one another. If the influence mentioned above causes
distortion to the audio signal, readjust bass/treble or
volume.
¡ Each SQ (except FLAT) level is changeable. (a page
19)
CQ-CB8901U
[[]: Higher frequency
[]]: Lower frequency
q : Level Up
w : Level Down
Lights when activated.
Change of SQ Presetting
(SQ: Sound Quality)
SQ Selection Based on Genre
4. VOCAL
3 Hold down [}] or [{] for 2 sec. or
more to confirm your adjustment.
The existing adjustment is overwritten with new
adjustment.
Notes:
¡ FLAT is not changeable.
¡ If no operation takes place for more than 10 seconds, the display returns to the regular mode.
¡ This adjustment is executable in the AUDIO menu
as well. (a page 34)
¡ If you hold down [BAND] for 2 sec. or more on
the SQ call-up screen, the presetting that is called
up can be turned into the default.
General
The targeted SQ preset appears.
2. ROCK
Note: You can select a SQ preset to be targeted
with [}] and [{] (and [2]-[6] on the remote control).
CQ-CB8901U
19
Radio
This chapter explains how to listen to the radio.
SRC
Up to 6 stations can be preset in AM, FM1, FM2, and FM3
respectively.
Preset stations can be simply called up by pressing [}]
(P·SET) or [{] (P·SET).
Notes:
¡ Direct selection can be executed with [1] to [6] buttons on remote control.
¡ Preset stations are changeable.
CQ-CB8901U
radio mode.
2 Press [BAND] to select a band.
[]] (TUNE): Lower
[[] (TUNE): Higher
Note: Hold down for 0.5 sec. or more and release
for station search. Seeking will starts.
Preset station selection
[{] (P·SET: Preset): Lower preset number
[}] (P·SET: Preset): Higher preset number
Radio Mode Display
Note: Direct selection can be executed with [1] to
[6] buttons on remote control.
Station Preset
Frequency adjustment
(APM: Auto Preset Memory, P·SET: Preset)
Operation Flow
3 Select a station.
Frequency
Preset Number
1
2 Hold down
Select a band.
CQ-CB8901U
[BAND] (APM) for
2 sec. or more.
[AUTO mode (Auto seeking)]
The stations that broadcast digital signals are stored
in the memory in sequence with the station featuring
the best reception first and starting with the highest
preset number whereas the stations that broadcast
only analog signals are stored in the memory in
sequence starting with the lower preset number.
The stations that broadcast digital signals are saved
in sequence with the one featuring the best reception
first. (this may take some time.)
lights when When digital broadcast
is received in AUTO mode.
AUTO: Analog or Digital reception (Default)
ANALOG: Analog reception only
Seeking Mode
When the reception mode is “AUTO”:
Hold down [D/A] for 2 sec. or more to select the
Auto seeking or Digital seeking.
AUTO Seeking: Seeks analog or digital broadcast stations. (Default)
Digital Seeking: Seeks digital broadcast stations.
Notes:
¡ The sound may not switch over to digital if the program concerned is being broadcast in real time.
¡ Analog sound will be output if the reception is poor.
¡ In the AUTO mode, analog sound is output immediately after the frequency has been turned in. When
listening to analog sound to analog, the sound quality
will be better in the ANALOG mode.
¡ To display text information, select the AUTO mode.
(TEXT Display Setting)
Press [D/A] to select the AUTO mode or ANALOG
mode.
CQ-CB8901U
Notes:
¡ New stations overwrite existing saved stations.
¡ In step 2, a station can be stored by holding down the
one of the preset buttons [1] to [6] for 2 sec. or more.
CQ-CB8901U
TEXT DISPLAY
For using the remote
control, hold down
[MENU] for 2 sec. or more.
2 Press [}] or [{] to select a mode to be
: Station name (Default)
: Artist name/Song title
: off
adjusted.
3 Press [BAND]
(SET) to adjust.
CQ-CB8901U
4 Press [MENU] to
confirm the
adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
20
the station by holding down [}]
4 Preset
or [{] for 2 sec. or more.
1 Press [MENU] to
Radio Menu Display
CQ-CB8901U
1 Tune in to a station.
2 Hold down [}] or [{] for 2 sec. or more.
3 Select a preset number by pressing [}]
While receiving a digital broadcast station, you can set up
its text contents to be displayed.
lights when digital seeking
is selected.
display the menu
display.
SRC
Manual station preset
¡ To stop presetting stations, press [DISP] (Display).
Indicates the intensity of
the radio wave.
lights when reception
mode is “AUTO”.
The preset stations under best receiving conditions are
received for 5 sec. each after presetting the stations
(SCAN). To stop scanning, press [}] or [{].
Note: New stations overwrite existing saved stations.
or [{].
[AUTO mode (Digital seeking)]
Reception Mode
Mode Setting
Stations with good receiving conditions automatically preset.
The 6 stations with good reception will be automatically
saved in the memory under preset number [1] to [6].
Frequency/preset number blinks once.
HD indicator lights when
the broadcast station now
being received is an HD
Radio station.
Band
Auto Preset Memory (APM)
[ANALOG mode]
Radio
1 Press [SRC] (Source) to select the
Notes:
¡To have an another circle scroll when the text is display,
Hold down [DISP] (Display) for 2 sec. or more.
¡ If any of the following screens are displayed, the display will not be switched even when the above operations is performed.
¡Mode and Moving picture display/SA display
¡Moving picture display/SA display
¡Mode and clock display
¡Display and light off
¡ There is a case that text is not always displayed while
a digital station is received.
CQ-CB8901U
21
CD Player
] (OPEN) to open the face
plate.
CQ-CB8901U
up.
The face plate closes automatically, and the unit recognizes the disc and starts playing automatically,
too.
Printed side
3 Select a desired portion.
Random and Repeat play can be set.
Track selection
[7] (TRACK): Next track
[6] (TRACK): Preceding track (press twice)
When a disc is already loaded, press [SRC]
(Source) to select the CD mode.
Note: Hold down for fast forward/reverse.
Pause
Press [BAND] (h / 5).
Press again to cancel.
Track number
Time
CD Mode Display
TRC (Track)
22
CD-TEXT display
Notes:
¡ For scrolling text, hold down [DISP] for 2 sec. or
more.
¡ “NO TEXT” is displayed when there is no information
on the disc.
CQ-CB8901U
Play Mode indicators
lights when each mode is
activated.
1 Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
CQ-CB8901U
RANDOM
: Off
: Random playback
(RANDOM, REPEAT)
Operation Flow
2 Load a disc with the printed-side facing
¡ Refer to the section on “Notes on CD, CD Media (CD-ROM,
CD-R, CD-RW)” (a page 44).
¡ A disc which has both CD-DA data and MP3/WMA data on it
may not be reproduced normally.
2 Press [}] or [{] to select a mode to be
adjusted.
: Off
3 Press [BAND]
(SET) to adjust.
REPEAT
: Playing the current track repeatedly
CQ-CB8901U
TEXT (CD TEXT)
: Enabled (Default)
: Disabled
4 Press [MENU] to confirm the adjust-
CD Player
SRC
Random, Repeat Play (CD Menu Display)
When a disc is already loaded, the disc will automatically be ejected.
Cautions:
¡ This unit does not support 8 cm (3”) discs.
¡ Do not use irregularly shaped discs. (a page 44)
¡ Do not use discs that have a seal or label attached.
¡ To avoid damaging the face plate, do not push it down or
place objects on it while it is open.
¡ Do not pinch your finger or hand in the face plate when the
face plate is in motion.
¡ Do not insert foreign matter into the disc slots.
ment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
lights when the disc is
loaded.
Play Mode Selection
Functions Only by
Remote Control Unit
1 Press [
One-touch operation is available for selecting a track
playing style by use of [RANDOM] or [REPEAT].
RANDOM
Press [RANDOM].
Press again to cancel.
REPEAT
Press [REPEAT].
Press again to cancel.
SCAN play
You can find your favorite track by playing first 10-sec. of
each track.
Press [SCAN].
Press again to cancel.
Direct Access
A track can be directly selected.
Example: track number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Note: To suspend direct
selection, press [DISP] (Display).
CQ-CB8901U
23
MP3/WMA Player
plate.
When a disc is already loaded, the disc will automatically be ejected.
Operation Flow
up
The face plate closes automatically, and the unit recognizes the disc and starts playing automatically,
too. (It may take several minutes to start for a disc
that has a lot of files.)
Printed side
3 Select a desired portion.
[}] (FOLDER): Next folder
[{] (FOLDER): Preceding folder
File selection
[7] (TRACK): Next file
[6] (TRACK): Preceding file (press twice)
When a disc is already loaded, press [SRC]
(Source) to select the MP3/WMA mode.
Note: Hold down for fast forward/reverse.
Pause
Press [BAND] (h / 5).
Press again to cancel.
File number
Time
Folder number
MP3/WMA Mode Display
File type indicator
Information Display
Notes:
¡ For scrolling text, hold down [DISP] for 2 sec. or
more.
¡ “NO TEXT” is displayed when there is no information
on the disc.
¡ ID3/WMA tag information is displayed for the album
name and title/artist name.
Random and Repeat play can be set.
1 Press [MENU] to display the menu dis-
Folder selection
play.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
RANDOM
: Off
: Random playback (disc)
CQ-CB8901U
FOLDER RANDOM
: Off
(RANDOM, REPEAT)
2 Load a disc with the Printed-side facing
Notes:
¡ Refer to the section on “Notes on MP3/WMA” (a page 26)
¡ A disc which has both CD-DA data and MP3/WMA data on it may not be reproduced normally. (For example, it may be reproduced without sound.)
2 Press [}] or [{] to select a mode to be
adjusted.
3
Press [BAND]
(SET) to adjust.
: Random playback (folder)
REPEAT
: Off
CQ-CB8901U
: Playing the current file repeatedly
FOLDER REPEAT
4 Press [MENU] to
confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
: Off
: Playing the current folder repeatedly.
TEXT
: Folder name/File name
: Album/Title (tag information)
Play Mode indicators
lights when each mode is
activated.
(Folder Repeat)
(Folder Scan)
: No display
lights when the disc is
loaded.
(Folder Random)
MP3/WMA Player
CQ-CB8901U
SRC
Random, Repeat Play (MP3/WMA Menu Display)
] (OPEN) to open the face
Play Mode Selection
Functions Only by
Remote Control Unit
1 Press [
One-touch operation is available for selecting a track
playing style by use of [RANDOM] or [REPEAT].
RANDOM, REPEAT
Press the button. Press again to cancel.
FOLDER RANDOM, FOLDER REPEAT
Hold down the button for 2 sec. or more. Hold
down again to cancel.
SCAN play
You can find your favorite file by playing first 10-sec. of
each file.
Hold down [SCAN] for 2 sec. or more. Hold down
again to cancel.
Direct Access
A file in the current folder can be directly selected.
Example: file number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Notes:
¡ For folder selection, enter a number after pressing [#]
(NUMBER) twice.
¡ To suspend direct selection, press [DISP] (Display).
SCAN (All files)
Press [SCAN]. Press again to cancel.
FOLDER SCAN (1st file in each folder)
24
CQ-CB8901U
CQ-CB8901U
25
MP3/WMA Player
Notes:
¡ MP3/WMA encoding and CD writing software is not
supplied with this unit.
Points to remember when making MP3/WMA files
Notes on MP3/WMA
Common
¡ High bit rate and high sampling frequency are recommended for high quality sounds.
¡ Selecting VBR (Variable Bit Rate) is not recommended
because playing time is not displayed properly and
sound may be skipped.
¡ The playback sound quality differs depending on the
encoding circumstances. For details, refer to the user
manual of your own encoding software and writing
software.
Recording MP3/WMA files on a CD-media
¡ CD-TEXT
Disc title
Track title
¡ MP3 (ID3 tag)
Album name
¡ MP3/WMA
Folder name
File name
¡ WMA (WMA tag)
Album name
Title and artist name
Title and artist name
Displayable characters
¡ Displayable length of file name/folder name: within 64
characters
¡ Name files and folders in accordance with the standard of each file system. Refer to the instructions of
writing software for details.
¡ ASCII character set and special characters in each language can be displayed.
ASCII character set
A to Z, a to z, digits 0 to 9, and the following symbols:
(space) ! ” # $ % & ’ ( ) * + , - . / : ; < = > ? @ [ \ ] ˆ
_`{|}~
MP3
¡ It is recommended to set the bit rate to “128 kbps or
more” and “fixed”.
WMA
¡ It is recommended to set the bit rate to “64 kbps or
more” and “fixed”.
¡ Do not set the copy protect attribute on the WMA file
to enable this unit to play back.
Caution: Never assign the “.mp3”, or
“.wma” file name extension to a file that is
not in the MP3/WMA format. This may not
only produce noise from the speaker damage, but also damage your hearing.
¡ You are recommended to minimize the chances of
making a disc that contains both CD-DA files and
MP3/WMA files.
¡ If CD-DA files are on the same disc as MP3 or WMA
files, the songs may not play in the intended order,
or some songs may not play at all.
¡ When storing MP3 data and WMA data on the same
disc, use different folders for each data.
¡ Do not record files other than MP3/WMA files and
unnecessary folder on a disc.
¡ The name of an MP3/WMA file should be added by
rules as shown in the following descriptions and also
comply with the rules of each file system.
¡ The file extension “.mp3” or “.wma” should be
assigned to each file depending on the file format.
Displayed items
Notes:
¡ With some software in which MP3/WMA format files
have been encoded, the character information may not
be displayed properly.
¡ Undisplayable characters and symbols will be converted into an asterisk ( ).
*
Windows Media, and
the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation
in the United States
and/or other countries.
¡ You may encounter trouble in playing MP3/WMA files
or displaying the information of MP3/WMA files
recorded with certain writing software or CD
recorders.
¡ This unit does not have a play list function.
¡ Although Multi-session recording is supported, the
use of Disc-at-Once is recommended.
Supported file systems
ISO 9660 Level 1/Level 2, Apple Extension to ISO 9660,
Joliet, Romeo
Note:
¡ Apple HFS, UDF 1.50, Mix CD and CD Extra are not
supported.
Compression formats
(Recommendation: “Points to remember when making MP3/WMA files” on the previous page)
Compression method
Bit rate
VBR
Sampling frequency
MPEG 1 audio layer 3 (MP3)
32k-320 kbps
Yes
32, 44.1, 48 kHz
MPEG 2 audio layer 3 (MP3)
8k-160 kbps
Yes
16, 22.05, 24 kHz
Windows Media Audio Ver. 2, 8
64k-192 kbps
No
32, 44.1, 48 kHz
Folder selection order/file playback order
Maximum number of files/folders
¡ Maximum number of files: 999
¡ Maximum number of files in one folder: 255
¡ Maximum depth of trees: 8
¡ Maximum number of folders: 255 (Root folder is
included.)
Root Folder
(Root Directory)
1
2
q
Folder Selection
4
e
w
Notes:
¡ This unit counts the number of folders irrespective of
the presence or absence of an MP3/WMA file.
¡ If the selected folder does not contain any MP3/WMA
files, the nearest MP3/WMA files in the order of playback will be played.
¡ Playback order may be different from other MP3/WMA
players even if the same disc is used.
¡ “ROOT” appears when displaying the root folder
name.
In the order
1
–
8
3
MP3/WMA Player
MP3 (MPEG Audio Layer-3) and WMA (Windows MediaTM
Audio) are the compression formats of digital audio. The
former is developed by MPEG (Motion Picture Experts
Group), and the latter is developed by Microsoft
Corporation. Using these compression formats, you can
record the contents of about 10 music CDs on a single
CD media (This figures refer to data recorded on a 650
MB CD-R or CD-RW at a fixed bit rate of 128 kbps and a
sampling frequency of 44.1 kHz).
Display Information
Notes on MP3/WMA (continued)
What is MP3/WMA?
File Selection
In the order
–
y
q
5
6
r
8
7
Tree 1
Tree 2
Tree 3
t
y
Tree 4
Tree 8
(Max.)
Copyright
It is prohibited by copyright laws to copy, distribute and
deliver copyrighted materials such as music without the
approval of copyright holder except enjoying yourself
personally.
No warranty
Above description complies with our investigations as of
December 2004. It has no warranty for reproducibility
and displayability of MP3/WMA.
26
CQ-CB8901U
CQ-CB8901U
27
XM Tuner
The optional XM receiver allows you to receive the XM radio service.
You can toggle the category on and off every time you
hold down [BAND] for 2 sec. or more. If the category is
set to on, the unit operates as follows for each button:
Note: “LOADING” is displayed when it takes for 2
sec. or more to receive the XM satellite radio.
2 Press [BAND] to select a band.
required to use an optional extension cord
(XMDPAN100) that is produced by XM exclusively for Panasonic products.
Notes:
¡“RADIO ID” is displayed with channel 0.
¡“UPDATING” is displayed during the update of the
identification code.
¡“LOADING” is displayed during the acquisition of
audio data or information.
(P·SET: Preset)
Channel Preset
XM Tuner Mode
Display
Preset Number
1 Tune into a channel.
2 Hold down [}] or [{] for 2 sec. or more.
3 Select a preset number by pressing
[}] or [{].
Preset channel selection
[{] (P·SET: Preset):
[}] (P·SET: Preset):
Lower preset channel
Higher preset channel
Note: Direct selection can be executed with [1] to
[6] buttons on remote control.
Channel number/name
Indicates the intensity of
the radio wave.
CQ-CB8901U
1 Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
TEXT
: Enabled (Default)
: Disabled
CQ-CB8901U
2 Press [BAND] (SET) to adjust.
CQ-CB8901U
3 Press [MENU] to confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
4 Preset the channel by holding down [}]
or [{] for 2 sec. or more.
Preset number/channel number blinks once.
Notes:
¡ New channels overwrite existing saved channels.
¡ In step 2, a channel can be stored by holding down
one of the preset buttons [1] to [6] for 2 sec. or more.
¡ To stop presetting channels, press [DISP] (Display).
28
[{] (P·SET: Preset): Preceding category
[}] (P·SET: Preset): Next category
lights when activated.
indicates the satellite tuner
is ready.
Up to 6 channels can be preset in XM1 to XM3
respectively.
Preset channels can be simply called up by pressing [}]
(P·SET) or [{] (P·SET).
Note: Direct selection can be executed with [1] to [6]
buttons on remote control.
Category selection
[]] : Preceding channel
[[] : Next channel
Band
Artist name/Song title
[]] (TUNE): Preceding channel in current category
[[] (TUNE): Next channel in current category
XM Tuner
¡ Connect the optional XM receiver (XMD1000).
¡ To connect the XM receiver (XMD1000), it is
Channel selection
TEXT Setting (XM Tuner Menu Display)
Operation Flow
3 Select a channel.
CQ-CB8901U
SRC
Channel selection
(P·SET: Preset)
CQ-CB8901U
SRC
Functions Only by
Remote Control Unit
Satellite Radio mode.
Selection by Category
1 Press [SRC] (Source) to select the XM
Direct Access
A channel can be directly selected.
Example: channel number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Note: To suspend direct selection, press [DISP]
(Display).
CQ-CB8901U
29
Disc Changer (When CDs or MP3 discs are loaded)
Connected an optional CD changer or an optional DVD changer can be controlled by this unit.
CQ-CB8901U
SRC
2 Select a desired portion.
Disc selection
[}]: Next disc
[{]: Preceding disc
Track selection
[7]: Next track/file
[6]: Preceding track/file (press twice)
Note: Hold down for fast forward/reverse.
Pause
Press [BAND] (y / 5).
Press again to cancel.
Track number
Time
Disc number
Changer indicator
CD Changer Mode Display
(CD changer)
(DVD changer)
¡ Trouble may occur while playing CD-Rs. Refer to the section
on “Notes on CD/CD Media (CD-ROM, CD-R, CD-RW)”. (a
page 44)
¡ This unit does not support the following through the CD
changer.
¡MP3 playback.
Random and Repeat play can be set.
1 Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
RANDOM (Only for CD-DA)
: Off
: Random playback (from whole magazine: CD-CH)
CQ-CB8901U
(from selected disc: DVD-CH)
RANDOM (Only for MP3 disc)
: Off
2 Press [}] or [{] to select a mode to be
(RANDOM, REPEAT)
Note: The changer is automatically turn on when
the magazine is inserted.
adjusted.
DISC RANDOM (Only for CD changer)
: Off
3 Press [BAND]
(SET) to adjust.
: Random playback (from selected folder)
CQ-CB8901U
: Random playback (from selected disc)
REPEAT
: Off
4 Press [MENU] to
confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
: Playing the current track/file repeatedly
DISC REPEAT
: Off
: Playing the current disc repeatedly
FOLDER REPEAT (Only for MP3 disc)
: Off
: Playing the current folder repeatedly
Play Mode indicators
lights when the changer is
connected.
lights when each mode is
activated.
(Only for CD changer)
(Disc Random)
(Disc Repeat)
(Disc Scan)
Play Mode Selection
Functions Only by
Remote Control Unit
Operation Flow
The unit recognizes the magazine and starts playing
automatically.
Random, Repeat Play (Disc Changer Menu Display)
When a magazine is already loaded, press [SRC]
(Source) to select the CD mode.
Notes:
¡ Please connect a CD changer or a DVD changer to AUX 2.
¡ “AUX 2” is display when connecting a changer that is not
compatible with this unit.
¡ When CX-DP880 or CX-DH801U is connected, a CD-RW
disc is playable.
One-touch operation is available for selecting a track
playing style by use of [RANDOM] or [REPEAT].
RANDOM, REPEAT
Press the button. Press again to cancel.
DISC RANDOM, DISC REPEAT
Hold down the button for 2 sec. or more. Hold
down again to cancel.
SCAN play (Only for CD-DA)
You can find your favorite track by playing first 10-sec. of
each track.
SCAN (CD changer: All tracks, DVD changer:
from selected disc)
DISC SCAN (1st track in each disc, only for CD
changer)
Hold down [SCAN] for 2 sec. or more. Hold down
again to cancel.
Direct Access
A disc can be directly selected.
Example: disc number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Disc Changer (When CDs or MP3 discs are loaded)
1 Load a magazine (discs).
Note: To suspend direct selection, press [DISP]
(Display).
Press [SCAN]. Press again to cancel.
30
CQ-CB8901U
CQ-CB8901U
31
Disc Changer (when DVDs or VCDs are loaded)
Connected an optional DVD changer (CX-DH801U) can be controlled by this unit.
1 Load a magazine (discs).
When a magazine is already loaded, press [SRC]
(Source) to select the DVD changer mode.
CQ-CB8901U
SRC
Notes:
¡ Please connect a CD changer or a DVD changer to AUX 2.
¡ “AUX 2” is display when connecting a changer that is not compatible with this unit.
2 Select a desired portion.
[7]: Next chapter/Next track
[6]: Preceding chapter/Preceding track
(press twice)
Press [BAND] (y / 5).
Press again to cancel.
Chapter number
Time
Disc number
Changer indicator
CQ-CB8901U
¡For a DVD insertion
CHAPTER REPEAT
: Off
: Playing the current chapter repeatedly.
TITLE REPEAT
: Off
2 Press [}] or [{] to select a mode to be
: Playing the current title repeatedly.
Note: The unit may not operate for some DVDs.
3 Press [BAND]
¡For a VCD insertion
adjusted.
(SET) to adjust.
CQ-CB8901U
REPEAT
: Off
: Playing the current track repeatedly
4 Press [MENU] to confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
DISC REPEAT
: Off
: Playing the current disc repeatedly
Notes:
¡ The unit may not operate for some VCDs.
¡ The unit may not operate for a disc with the play back
function activated.
Disc type
Play Mode indicators
Lights when each mode is
activated.
Lights when the changer is
connected.
(Disc Repeat)
(Chapter Repeat)
(Title Repeat)
CQ-CB8901U
Play Mode Selection
One-touch operation is available for selecting a chapter
playing style by use of [REPEAT].
CHAPTER REPEAT(DVD), REPEAT (VCD)
Press the button. Press again to cancel.
TITLE REPEAT(DVD), DISC REPEAT (VCD)
Hold down the button for 2 sec. or more. Hold
down again to cancel.
Direct Access
A disc can be directly selected.
Example: disc number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Disc Changer (when DVDs or VCDs are loaded)
Chapter/Track selection
Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
(RANDOM, REPEAT)
[}]: Next disc
[{]: Preceding disc
Pause
DVD Changer Mode Display
1
Disc selection
Note: Hold down for fast forward/reverse.
32
Random and Repeat play can be set.
Random, Repeat Play (Disc Changer Menu Display)
Note: The power is turned on automatically when
inserting a magazine.
Functions Only by
Remote Control Unit
Operation Flow
The unit recognizes the magazine and starts playing
automatically.
Note: To suspend direct
selection, press [DISP] (Display).
CQ-CB8901U
33
Audio Setting
Function Setting
(SEL: Select) to
display the
AUDIO menu
display.
2 Press [VOLUME] (SEL: Select) to select
a mode to be
adjusted.
3 Turn [VOLUME]
clockwise or
counterclockwise
to adjust.
AUDIO Menu Display
Note: If no operation takes place for more than 10 seconds in the audio menu (2 sec. in Main volume adjustment), the display returns to the regular mode.
SQ preset change
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
CQ-CB8901U
MUTE KEY
Setting [MUTE] buttons’ functions
: Volume off (Default)
2 Press []] or [[] to display the FUNCTION menu.
Balance adjustment
(Setting range: L15 to R15 and Center, Default: Center)
q : Right enhanced
w : Left enhanced
be adjusted.
Fader adjustment
(Setting range: R15 to F15 and Center, Default: Center)
q : Front enhanced
w : Rear enhanced
Subwoofer level adjustment
(Setting range : mute (-∞),-6 dB to +6 dB, 2 dB Step,
Default: 0 dB)
q : Up
w : Down
:
Volume down by 10 steps
:
Volume down by 5 steps
SECURITY
3 Press [}] or [{] to select a function to
Bass adjustment
(Setting range: -12 dB to +12 dB, 2 dB Step, Default:
Bass 0 dB)
q : Up
w : Down
play.
q : Up
w : Down
[[]: Higher frequency
[]]: Lower frequency
Main volume adjustment
(Setting range: 0 to 40, Default: 18)
q : Up
w : Down
1 Press [MENU] to display the menu dis-
(Adjustable frequency: 60, 160, 400, 1 k, 3 k, 6 k, 16 k (Hz),
Setting range: –12 dB to +12 dB, 2 dB Step) (a page 19)
FUNCTION Menu Display
1 Press [VOLUME]
Adjustment to display on the FUNCTION menu
Setting the security function (a page 13)
: ON (Default)
: OFF
Audio Setting, Function Setting
Adjustment to each speaker and an optional subwoofer
4 Press [BAND]
(SET) to adjust.
CQ-CB8901U
5 Press [MENU] to confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
Subwoofer Low Pass Filter
(Setting range: 80 Hz, 120 Hz, 160 Hz, Default: 80 Hz)
q : Up
w : Down
Treble adjustment
(Setting range: -12 dB to +12 dB, 2 dB Step, Default:
Treble 0 dB)
q : Up
w : Down
Note: Do not activate SQ and Bass/Treble at same time
to avoid causing sound distortion.
34
CQ-CB8901U
Subwoofer output range
Other speakers output ranges
High Pass Filter
(Setting range: Filter OFF, 90 Hz, 135 Hz, 180 Hz, 225 Hz,
Default: Filter OFF)
q : Up
w : Down
CQ-CB8901U
35
Display Setting
Customize the Display (Customize Function)
Adjustment to display on the DISPLAY menu
play.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
CQ-CB8901U
Still image setting
(Setting range: 11types, Default: All)
Switching by []] or [[]
Preparation:
Put the CD-R/RW that contains data to
be customized in hand.
Sequential display
from pattern 1 to
10
No.1-10
ALL:
1 If there is a disc inside, take out the
disc.
2 Press []] or [[] to display the DIS-
[}][{][]][[]:Select
[BAND] (SET): Confirm
2 Press [SRC] to
PLAY menu.
3
select the CD
mode.
Press [}] or [{] to select a function to
be adjusted.
SRC
4 Press [BAND]
(SET) to confirm
the display.
3 Hold down [SEL] for 4 sec. or more to
CQ-CB8901U
display the menu screen.
(Setting range: 1 to 5, Default: Contrast 3)
[[]: Tilting up view angle
[]]: Tilting down view angle
ment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
Graphic pattern setting
Clock adjustment
Note: Adjust the clock when “ADJUST” appears on the
display.
[[]: Adjusting minutes
[]]: Adjusting hours
[}]: Forward
[{]: Backward
4 Load a CD-R/RW that contains data.
Note:
¡ It may take time for the unit to identify the CDR/RW.
¡ Discs recorded by the packet writing software are
not supported.
5 Select an item to be customized.
Moving image (graphic pattern) data (a page 36)
Notes:
¡ The graphic pattern and still image are changeable.
(a page 37)
¡ If corrupted data is selected, “DISPLAY FILE INCOMPLETE” appears. (a page 38)
Still image data (a page 36)
OPENING MESSAGE
Moving image at power on (a page 14)
CLOSING MESSAGE
Moving image at power off (a page 14)
CQ-CB8901U
Notes:
¡ New data overwrites existing data.
¡ If “BACK” is selected, the screen of step 6
appears.
[]][[]:
Select
[BAND] (SET): Confirm
GRAPHIC PATTERN
STILL IMAGE
36
[]][[]:
Select
[BAND] (SET): Confirm
[}][{]:
Select
[BAND] (SET): Confirm
Note: To exit the customize menu, hold down
[SEL] 4 sec. or more.
ALL:
Sequential display from pattern A to D.
Pattern A-D
S.A.:
19-band display (Spectrum analyzer)
7 For a moving image file or still image
8 Confirm the changed item.
(Setting range: 6 types, Default: All)
Switching by []] or [[]
Notes:
¡ Files are automatically identified by their extensions, and target files are displayed.
¡ If “BACK” is selected, the screen of step 5
appears.
file, select where to save the file.
CUSTOMIZE Menu Display
DISPLAY Menu Display
Contrast adjustment
5 Adjust the setting value.
6 Press [BAND] (SET).
7 Press [MENU] to confirm the adjust-
6 Select a file.
Display Setting, Customize the Display (Customize Function)
1 Press [MENU] to display the menu dis-
You can edit the moving images and still images that are initially stored in the unit. You also can use the data that is downloaded from
the Panasonic Web site and the data that is stored with a digital camera or other devices and processed with exclusive software,
IMAGE STUDIO. See “Notes on Customize function” (a page 38) as well.
Note: Visit Panasonic Web site (http://panasonic.co.jp/pas/en/software/customize/index.html) for details.
Customization is performed. Do not turn off the
power in mid-operation. (It takes approx. 8 minutes
to complete this operation for a 751 kB moving
image.) After completion of this operation, the
screen of step 5 appears.
Note: If “NO” is selected, the screen of step 5
appears.
9 Hold down [SEL] 4 sec. or more.
The CD mode comes back. Press the [OPEN] button to eject the disc.
CQ-CB8901U
37
Note on Download Service
At Customizing
The download service may be suspended or stopped
without advance notice. The download service is not
available in some areas. Please visit the site below for
further information.
Panasonic Web site:
(http://www.panasonic.co.jp/global/)
Notes on IMAGE STUDIO
Download site:
¡ This download service is not available in some areas.
For details, please access the Panasonic website.
¡ IMAGE STUDIO is available only by downloading from
the address below. It is not bundled with this unit.
¡ Refer to the downloaded operating manual for how to
use IMAGE STUDIO.
http://panasonic.co.jp/pas/en/software/
customize/index.html
If You Suspect Something Wrong
Check and take steps as described below.
If the described suggestions do not solve the problem, it is
recommended to take the unit to your nearest authorized Panasonic
Servicenter. The product should be serviced only by qualified personnel.
Please refer the checking and the repair to professionals. Panasonic
shall not be liable for any accidents arising out of neglect of checking the
unit or your own repair after your checking.
Problem
¡ The customize-specific file is downloadable from the
URL below. You can create exclusive files stored with
a digital camera or other devices by using exclusive
software, IMAGE STUDIO that can be accessed from
the same URL.
¡ Do not change the extension. Otherwise, the data cannot be recognized.
NO FILES DETECTED
No power to the
unit
Customize failed
a Check to see whether or not the extension is correct and file contents are appropriate.
Sound is not
generated.
Type
Extension
Max. number
GRAPHIC PATTERN
.pfm
10
STILL IMAGE
.pfs
15
OPENING MESSAGE
.pfo
5
CLOSING MESSAGE
.pfe
5
Intended moving image or still image is damaged.
a Customize it again and overwrite the file with
new one.
Common
¡ Save only customize-specific data.
¡ Save all data in the root directory. Files contained in a
folder cannot be recognized.
¡ Follow the table below with regard to the number of
files that are saved to a disc. Files beyond the specified capacity are not readable.
¡ Discs recorded by the packet writing software are not
supported.
Possible cause a Possible solution
The power cord (battery, power and ground) is connected in the wrong way.
a Check the wiring.
Fuse blows out.
a Eliminate the cause of fuse blowout and replace the fuse with new one.
Consult your dealer.
CUSTOMIZING FAILED
DISPLAY FILE INCOMPLETE
At Disc Making
Cautions:
¡ Do not use the unit in an irregular condition, for
example, without sound, or with smoke or a foul
smell, which can cause ignition or electric shock.
Immediately stop using the unit and consult your
dealer.
¡ Never try to repair the unit by yourself because it is
dangerous to do so.
Error Display Messages
No customize-specific data on the disc
a Load a disc that contains customize-specific
data.
Notes on File
Notes on Customize Function
¡ If customizing is interrupted on account of turning off
the power, stopping the engine, removing the face
plate or other reasons, you may lose the data. In such
a case, try customizing again.
¡ The default image exists on the Panasonic Web site. If
you would like to restore it, download the image from
the site.
Troubleshooting
The demonstration
screen displayed
and no operable
Noise
MUTE is set to ON.
a Set MUTE to OFF.
The wiring of speaker lines are not correct, or a break or poor contact arises.
a Check the wiring in accordance with the wiring diagram. (a page 50)
You cannot operate the unit while the demonstration screen appears.
a Press [DISP] to end the demonstration screen.
If the demonstration screen appears frequently, there is a possibility that poor
contact or wrong wiring arises between the battery lead of the unit and the battery
cable of the car. (The battery lead should be always powered.)
a Check the battery wiring in accordance with the wiring diagram.
Customize the Display (Customize Function), Troubleshooting
Customize the Display (Customize Function)
There is an electromagnetic-wave generator such as a cellular phone near the unit or
its electrical lines.
a Keep an electromagnetic-wave generator such as a cellular phone away from
the unit and the wiring of the unit. In case that noise cannot be eliminated
due to the wiring harness of the car, consult your dealer.
The contact of the ground lead is poor.
a Make sure that the ground lead is connected to an unpainted part of the chassis securely.
Noise is made in
step with engine
revolutions.
38
CQ-CB8901U
Alternator noise comes from the car.
a Change the wiring position of the ground lead.
a Mount a noise filter on the power supply.
CQ-CB8901U
39
Troubleshooting
The sound field is
not clear in the
stereo mode.
Central sound does
not settled.
The power fails
unintentionally.
Poor reception or
noise
There is a break, a short circuit, poor contact or wrong wiring regarding the speaker
wiring.
a Check the speaker wiring.
The number of auto
preset stations is
less than 6.
Radio
Seeking takes too
long.
40
CQ-CB8901U
The number of receivable stations is less than 6.
a Move to an area where receivable stations number is maximum, and try presetting.
Preset stations
cannot be stored.
The contact of the battery lead is poor, or the battery lead is not always powered.
a Make sure that the battery lead is connected securely, and preset stations
again.
Channel
unselectable
No contract with XM Satellite Radio Inc.
a Refer to page 13 of this book and the XM's website to sign up for XM Radio
service.
The speaker wiring is confused between right and left.
a Perform the speaker wiring in accordance with the wiring diagram.
The plus and minus terminals at right and left channels of speakers are connected
reversely.
a Perform the speaker wiring in accordance with the wiring diagram.
The safety device works.
a Call the store where you purchased the unit, or your nearest Panasonic
Servicenter.
No playback or
disc ejected
Sound skipping or
noise
Antenna installation or wiring of antenna cable is faulty.
a Check whether the antenna mounting position and its wiring are correct. In
addition, check to see whether the antenna ground is securely connected to
the chassis.
No power is supplied to the antenna amplifier (when using a film antenna, etc.).
a Check the wiring of the antenna battery lead.
Sound skipping
due to vibration
Unsatisfactory broadcast conditions.
a Receive and listen to signals from the station concerned in the analog mode.
No digital sound is
output.
Possible cause a Possible solution
There are no HD radio broadcast stations.
a Move to an area where HD radio can be received.
Analog mode is selected.
a Select AUTO mode.
Digital seeking may take some time.
a Change to auto seeking, and proceed with seeking again.
Disc unejectable
The disc is inserted upside down.
a Insert a disc correctly.
There is a flaw or foreign material on the disc.
a Remove the foreign material, or use a flawless disc.
There is a flaw or foreign material on the disc.
a Remove the foreign material, or use a flawless disc.
Troubleshooting
The speaker
channels are
reversed between
right and left.
BALANCE/FADER setting is not appropriate.
a Readjust BALANCE/FADER.
Radio (continued)
Common (continued)
No sound from
speaker (s)
Some operations are not executable in particular modes such as menu mode.
a Read the operating instructions carefully and cancel the mode. In case the
unit is still out of order, consult the dealer.
XM Tuner
Some operations
are not executable.
Problem
Possible cause a Possible solution
CD
Problem
The unit is not sufficiently secured.
a Secure the unit to the console box with the rear support strap, etc.
The unit is tilted at over 30˚ in the front-to-end direction.
a Make the angle 30˚ or less.
Something such as a peeled label obstructs the disc coming out.
a Hold down the [OPEN] button for 2 sec. or more when the face plate is open
(disc forced ejection). In case that the disc forced ejection does not work,
consult the dealer
The microcontroller in the unit operates abnormally due to noise or other factors.
a Unplug the power cord and plug it again. In case the unit is still out of order,
consult the dealer.
CQ-CB8901U
41
MP3/WMA
No playback or
disc ejected
Problem
Possible cause a Possible solution
Possible cause a Possible solution
The disc has unplayable formatted data.
a Refer to the description about MP3/WMA for playable sound data except CDDA (i.e. music CD).
Disc is dirty, or is upside down.
The unit plays back the ROM track of a MIX mode CD.
a Skip the ROM track.
Disc has scratches.
The CD-R/RWs that
are playable on
other devices are
not playable on
this unit.
The playability of some CD-R/RWs may depend on the combination of media,
recording software and recorder to be used even if these CD-R/RWs are playable on
other devices such as a PC.
a Make CD-R/RWs in different combination of media, recording software and
recorder after referring to the description about MP3/WMA.
Sound skipping or
noise
There is a flaw or foreign material on the disc.
a Remove the foreign material, or use a flawless disc. For MP3/WMA, refer to
the description about MP3/WMA.
No operation by some cause.
a When normal operation is not performed even after ejection, forced ejection
or turning on/off, Call the store where you purchased the unit, or your nearest
Panasonic Servicenter.
CD/MP3/WMA
Problem
Error Display Messages
The file is not readable.
a Insert a different disc.
(After 5 seconds)
To next file automatically
A WMA file can be copyrighted.
a The file protected by copyright is not playable.
No disc.
Error Display Messages
Problem
XM Tuner
XM antenna unconnected.
a Connect the XM antenna.
XM broadcasts unreceivable because of poor receiving conditions.
a Move to an area where XM broadcasts can be received well.
Channel not in service
a This channel is not currently in service. Tune to another channel.
CQ-CB8901U
(After 5 seconds)
To next disc automatically
DISC Changer
Radio
Digital broadcasts cannot be received because something is wrong. (However,
analog broadcasts can still be received.)
a Call the store where you purchased the unit or the nearest Panasonic
Servicenter to ask for repairs.
Cannot receive XM satellite radio.
a Verify the wiring.
42
Display
Possible cause a Possible solution
Possible
Disc is dirty, or is upside
down. cause a Possible solution
Disc has scratches.
a Eject the magazine.
¡Check the disc.
¡Load the disc again.
Troubleshooting, Error Display Messages
Troubleshooting
No operation by some cause.
a Eject the magazine. If failure persists, press the reset switch on the DISC
changer. If normal operation is not restored, call the store where you purchased the unit or the nearest Panasonic Servicenter to ask for repairs.
An error arises in the DVD changer.
a Check the DVD changer. (“REGION ERROR” etc.)
No disc is in the CD Changer (magazine).
a Insert discs into the changer (magazine).
The changer has become disconnected from the unit in the changer mode.
a Verify the wiring.
Note: Messages in the action and display sections of the error chart vary with changers. Refer to the operating
instructions for the Disc changer for details.
CQ-CB8901U
43
Installation
If you use commercial CDs, they must have
either of these labels shown at right.
Some copy-protected music CDs are not
playable.
WARNING
TEXT
❐ This installation information is designed for professional installers with
¡ Do not touch the underside of the disc.
¡ Do not scratch on the disc.
¡ Do not bend the disc.
¡ When not in use, keep disc in the case.
Printed side
Do not use irregularly shaped discs.
Do not leave discs in the following places:
¡ In direct sunlight
¡ Near car heaters
¡ Dirty, dusty and damp areas
¡ On seats and dashboards
Use a dry, soft cloth to wipe from the center outward.
Do not attach any seals or labels to your discs.
Do not write on the disc label with a ballpoint
pen or other hard-point pens.
<Correct>
<Wrong>
¡ You may have trouble playing back some CD-R/RW discs recorded on CD recorders (CD-R/RW drives), either due
to their recording characteristics or dirt, fingerprints, scratches, etc. on the disc surface.
¡ CD-R/RW discs are less resistant to high temperatures and high humidity than ordinary music CDs. Leaving them
inside a car for extended periods may damage and make playback impossible.
¡ Some CD-R/RWs can not be played back successfully thanks to incompatibility among writing software, a CD
recorder (CD-R/RW drive) and the discs.
¡ This player cannot play the CD-R/RW discs if the session is not closed.
¡ This player cannot play the CD-R/RW discs which contains other than CD-DA or MP3/WMA data (Video CD, etc.).
¡ Be sure to observe the instructions of CD-R/RW disc for handling it.
Cleaning the
Unit
Your product is designed and manufactured to ensure the minimum of maintenance. Use a soft cloth for
routine exterior cleaning. Never use benzine, thinner, or other solvents.
If the fuse blows out, consult your dealer, or your nearest authorized Panasonic Servicenter.
Fuse
dures may be required for connection and disconnection of the battery to install
this product.
Before attempting installation of this electronic component against the manufacturer's recommendation, you must contact your car dealer or manufacturer to determine the required procedure and strictly follow their instructions.
Disc cleaning
Maintenance
44
❐ If your car is equipped with air bag and/or anti-theft systems, specific proce-
Do not use irregularly shaped discs.
FAILURE TO FOLLOW THE PROCEDURE MAY RESULT IN THE UNINTENDED
DEPLOYMENT OF AIR BAGS OR ACTIVATION OF THE ANTI-THEFT SYSTEM
RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL INJURY OR
DEATH.
This product should be installed by a professional.
However, should you decide to install the product
against the manufacturer's recommendation, this
operating Instructions does not contain electrical
installation instructions. You must contact your car
dealer or manufacturer for electrical connection
instructions to avoid possible damage to your electrical safety systems and resulting injury or death.
(Please refer to the “WARNING” statement above).
Your next step is to decide where to install the unit
The instructions in these pages will guide you
through the remaining steps:
¡Identify and label the car wires.
¡Connect the car wires to the wires of the power
connector.
¡Install the unit.
¡Check the operation of the unit.
Caution: This unit operates with a 12 V DC
negative ground auto battery system only. Do
not attempt to use it in any other system. Doing
so could cause serious damage.
Notes on discs, Maintenance, Installation
knowledge of automobile electrical safety systems and is not intended for nontechnical, do-it-yourself individuals. It does not contain instructions on the
electrical installation and avoidance of potential harm to air bag, anti-theft and
ABS braking or other systems necessary to install this product.
Any attempt to install this product in a motor vehicle by anyone other than a
professional installer could cause damage to the electrical safety system
and could result in serious personal injury or death.
How to hold the disc
Overview
Notes on
CD-Rs/RWs
Notes on CD/CD Media (CD-ROM, CD-R, CD-RW)
Notes on Discs
Before you begin installation, look for the following
items which are packed with your unit.
¡Installation Hardware … Needed for installation.
If you encounter problems, please consult your nearest professional installer.
Warning
¡Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the
unit directly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your
nearest authorized Panasonic Servicenter.
CQ-CB8901U
CQ-CB8901U
45
Installation
¡Never use bolts or nuts from the car's safety
devices for installation. If bolts or nuts from the
steering wheel, brakes or other safety devices are
used for installation of the monitor, it may cause
an accident.
Before Installation
¡Attach the wires correctly. If the wiring is not correctly performed, it may cause a fire, failure of
electrical equipment and-or an accident. In particular, be sure to run and secure the lead wire so
that it does not get tangled with a screw or the
moving portion of a seat rail.
¡Use with 12 V DC negative ground car. This unit
is only for use with a 12 V DC negative ground
car. It cannot be used in large trucks or diesel
cars which are 24 V DC cars. If it is used in the
wrong type of car, it may cause a fire or an accident.
Cautions:
¡Use the specified fuse. Be sure to always
use the specified fuse. If a fuse other than
the specified fuse is used, it may cause a
fire or an accident.
¡Do not damage the cord by pinching or
pulling it. Do not pull or damage the cord. If
the cord is not treated properly, it will short
out or be severed and may cause a fire or
an accident.
❏ Required Tools
You’ll need a screwdriver and the following:
12 V DC
Test Bulb
Electrical
Tape
Side-Cut
Pliers
❏ Dashboard Specifications
THICKNESS
MIN. 4.75 mm {3/16”}
MAX. 5.56 mm {7/32”}
53 mm {2 3/32”}
CQ-CB8901U
If your car is not wired for an audio unit:
Go to the fuse block and find the fuse port for the
battery, usually marked BAT.
182 mm {7 5/32”}
❏ Identify All Leads
The first step in installation is to identify all the car
wires you’ll use when hooking up your LCD monitor.
As you identify each wire, we suggest that you label
it using masking tape and a permanent marker. This
will help avoid confusion when making connections
later.
Note: Do not connect the power connector to the
display unit until you have made all connections. If
there are no plastic caps on the hooking wires, insulate all exposed leads with electrical tape until you
are ready to use them. Identify the leads in the following order.
Power Lead
If your car has a radio or is pre-wired for one:
Cut the connector wires one at a time from the plug
(leaving the leads as long as possible) so that you
can work with individual leads. Turn the ignition on
to the accessory position, and ground one lead of
the test bulb to the chassis.
Touch the other lead of the test bulb to each of the
exposed wires from the cut radio connector plug.
Touch one wire at a time until you find the outlet that
causes the test bulb to light.
Now turn the ignition off and then on. If the bulb
also turns off and on, that outlet is the car power
lead.
If your car is not wired for an audio unit:
Go to the fuse block and find the fuse port for radio
(RADIO) accessory (ACC) or ignition (IGN).
Battery Lead
If your stereo unit has a yellow lead, you will need to
locate the car's battery lead. Otherwise you may
ignore this procedure. (The yellow battery lead provides continuous power to maintain a clock or other
functions.)
46
If your car has a radio or is pre-wired for one:
With the ignition and headlights off, identify the car
battery lead by grounding one lead of the test bulb
to the chassis and checking the remaining exposed
wires from the cut radio connector plug.
Before Installation (Continue)
Warning
¡DO NOT INSTALL THE MONITOR IN A LOCATION
WHICH OBSTRUCTS DRIVING, VISIBILITY OR
WHICH IS PROHIBITED BY APPLICABLE LAWS
AND REGULATIONS. If the monitor is installed
in a location which obstructs forward visibility
or operation of the air bag or other safety equipment or which interferes with operation of the
car, it may cause an accident.
Speakers (not supplied speaker)
Identify the car speaker leads. There are two leads
for each speaker, usually color coded.
A handy way to identify the speaker leads and the
speaker they are connected with is to test the leads
using a 1.5 V AA battery as follows.
Hold one lead against one pole of the battery and
stroke the other lead across the other pole. You will
hear a scraping sound in a speaker if you are holding a speaker lead.
If not, keep testing different lead combinations until
you have located all the speaker leads. When you
label them, include the speaker location for each.
❏ Connect All Leads
Now that you have identified all the wires in the car,
you're ready to begin connecting them to the LCD
monitor wires. The Electrical Connections (a page
50-51) shows the proper connections and color
coding of the leads.
We strongly recommend that you test the unit
before making a final installation.
You can set the unit on the floor and make temporary connections to test the unit. Use electrical tape
to cover all exposed wires.
Important: Connect the red power lead last, after
you have made and insulated all other connections.
Ground
Connect the black ground lead of the power connector to the metal car chassis.
Speakers
Connect the speaker wires. See the wiring diagram
for the proper hookups. Follow the diagram carefully
to avoid damaging the speakers and the stereo unit.
The speakers used must be able to handle more than
50 W of audio power. If using an optional audio
power, the speakers should be able to handle the
maximum amplifier output power. Speakers with low
input ratings can be damaged.
Speaker impedance should measure 4–8 Ω, which
is typically marked on most speakers. Lower or
higher impedance speakers will affect output and
can cause both speaker and stereo unit damage.
Caution: Never ground the speaker
cords. For example, do not use a chassis
ground system or a three-wire speaker common system. Each speaker must be connected
separately using parallel insulated wires. If in
doubt about how your car’s speakers are wired,
please consult with your nearest professional
installer.
Battery
Connect the yellow battery lead to the correct radio
wire or to the battery fuse port on the fuse block.
Equipment
Connect any optional equipment according to the
instructions furnished with the equipment. Read the
operating and installation instructions of any equipment you will connect to this unit.
Power
Connect the red power lead to the correct car radio
wire or to the appropriate fuse port on the fuse
block.
If the LCD monitor functions properly with all these
connections made, disconnect the wires and proceed to the final installation.
❏ Final Installation
Lead Connections
Connect all wires, making sure that each connection
is insulated and secure. Bundle all loose wires and
fasten them with tape so they will not fall down
later. Now insert the LCD monitor into the mounting
collar.
Installation
Installation
Congratulations! After making a few final checks,
you’re ready to enjoy your new LCD monitor.
❏ Final Checks
1. Make sure that all wires are properly connected and insulated.
2. Make sure that the LCD monitor is securely
held in the mounting collar.
3. Turn on the ignition to check the unit for
proper operation.
If you have difficulties, consult your nearest authorized professional installer for assistance.
CQ-CB8901U
47
Installation
Installation
Item
Diagram
Cautions:
¡We strongly recommend that you wear gloves for installation work to protect yourself from injuries.
¡When bending the mounting tab of the mounting collar with a screwdriver, be careful not to injure your
hands and fingers.
Q’ty
q
Mounting Collar
1
w
Mounting Bolt (5 mmø)
1
e
Power Connector
1
First complete the electrical connections, and then check them for correctness. (a Page 50-51)
r
Trim Plate
1
t
Lock Cancel Plate
2
y
Rear Support Strap
1
u
Tapping Screw
(5 mmø x 16 mm)
1
i
Hex. Nut (5 mmø)
1
The included Mounting Collar q is designed specially for this unit. Do not use it to attach any other
model.
Caution:
When this unit is installed in dashboard,
ensure that there is sufficient air flow
around the unit to prevent damage from
overheating, do not block any ventilation
holes on the unit.
Installation Opening
The unit can be installed in any dashboard having an
opening as shown at right. The dashboard should be
4.5 mm - 6 mm thick in order to be able to support
the unit.
Installation Precautions
This product should be installed by a professional
installer, if possible.
In case of difficulty, please consult the shop where
you purchased the product.
1. This system is to be used only in a 12-volt, DC
battery system (car) with negative ground.
2. Follow the electrical connections carefully (a
Page 50-51). Failure to do so may result in damage to the unit.
3. Connect the power lead (red) after all other connections are made.
4. Be sure to connect the battery lead (yellow) to the
positive terminal (+) of the battery or fuse block
(BAT) terminal.
5. Insulate all exposed wires to prevent short circuiting.
6. Secure all loose wires after installing the unit.
7. Please carefully read the operating and installation
instructions of the respective equipment before
connecting it to this unit.
CQ-CB8901U
(a) Using the Rear Support Strap
3 mm
Tapping screw u
Rear support strap y
2
w Mounting Bolt
Establish the rear of
the unit.
After fixing Mounting Bolt w
and Power Connector e, fix
the rear of the unit to the car
body by either method (a) or
(b) shown on the previous
page.
e Power Connector
Mounting bolt w
Clank!
Hexl nut i
1
Insert Mounting Collar q into the dashboard, and bend the mounting tabs out
with a screwdriver.
3
Insert Trim Plate r.
4
After installation reconnect the negative (–) battery terminal.
Installation
Methods for Fixing the Rear of the Unit.
Dashboard Installation
No.
30° or less
Caution: Do not disconnect the battery terminals of a car with trip or navigational computer
since all user settings stored in memory will be
lost. Instead take extra care with installing the
unit to prevent shorts.
48
Supplied Hardware
Dashboard Installation (continued)
Preparation
¡Before installation, check the radio operation with
antenna and speakers.
¡Disconnect the cable from the negative (–) battery
terminal (see caution below).
¡Unit should be installed in a horizontal position
with the front end up at a convenient angle, but
not more than 30°.
¡Remove Mounting Collar q and Trim Plate r
from the main unit temporarily, which are already
mounted at shipment.
To the unit
(b) Using the Rubber Bushing (option)
Snapping point
Rubber bushing (Option)
Mounting bolt w
Rear support bracket
(supplied with car)
To the unit
CQ-CB8901U
49
Installation
Cautions
¡This unit is designed for use in a car having a 12 V negative ground battery system.
¡To prevent damage to the unit, be sure to follow the connection diagram below.
¡Strip about 5 mm of the lead ends for connection.
¡Do not insert the power connector into the unit until the wiring is completed.
¡Be sure to insulate any exposed wires to prevent short circuiting with the car chassis. Bundle all
cables, and prevent cable terminals from touching any metal parts.
¡Remember, if your car has drive computer or a navigation computer, the data of its memory may be
erased when the battery terminals are disconnected.
Antenna
Fuse (15 A) Refer fuse replacement to your nearest authorized Panasonic
Servicenter. Do not try fuse replacement by yourself.
1
3
2
Electrical Connections
(R) (Red)
AUX1-IN
ACC
AUX Input Connector
(Red)
Power Lead (ACC or IGN) To ACC power, +12 V DC.
(L) (White)
(R) (Red)
(L) (White)
CD Changer/AUX/XM receiver Input Connector
The RCA cord of a CD changer/AUX/XM receiver
should be connected.
(Black)
Ground Lead To a clean, bare metallic part of the car chassis.
BATTERY 15A
(Yellow)
Battery Lead To the car battery, continuous +12 V DC.
(Blue w/white stripe)
(Red)
S・W-OUT
Installation
CH/AUX2-IN
External Amplifier Control Power Lead To an external amplifier.
(Max. 100 mA)
Subwoofer Output Connector
The RCA cord of a external power amplifer should be connected.
(White)
Not used (Brown w/white stripe)
(Blue)
Motor Antenna Relay Control Lead To Motor Antenna. (Max. 100 mA)
(This lead is not intended for use with a switch actuated power antenna)
(R) (Red)
PRE-OUT REAR
Speaker lead
Front Left + (White)
Front Left – (White w/black stripe)
Pre-out Cord (Rear)
(L) (White)
FRONT SP
(R) (Red)
PRE-OUT FRONT
(L) (White)
50
CQ-CB8901U
Front Right + (Gray)
Front Right – (Gray w/black stripe)
Rear Left + (Green)
Rear Left – (Green w/black stripe)
Pre-out Cord (Front)
REAR SP
Rear Right + (Violet)
Rear Right – (Violet w/black stripe)
CQ-CB8901U
51
Installation
Installation
¡For connection to a CD changer (CX-DP880) or DVD changer (CX-DH801U), refer to the operating
instructions of corresponding device.
¡For details, consult the shop where you purchased this product.
Caution: Please follow the instructions given below. Failure to do so will cause damage to the unit
and speakers.
¡Use ungrounded speaker only.
¡The maximum speaker input should be 50 W or more. (If used with
the optional power amplifier, the speaker input should be higher than
the maximum amplifier output.)
¡The speaker impedance should be 4 - 8 Ω.
¡This unit uses the BTCL circuit, so each speaker should be connected
separately using parallel vinyl insulated cords.
¡The speaker cords and the power amplifier unit should be kept away
(about 30 cm apart) from the antenna and antenna extension cord.
● A CD changer, an XM receiver cannot be connected at the same time.
System Upgrade Example: Connecting with a CD changer
CX-DP880
Ground Lead
Extension Cord
(DIN/BATT/RCA/GND)
(Supplied for an optional CD Changer)
Battery Lead
CH/AUX2-IN
RCA Cord
DIN Cord
(R) (Red)
CQ-CB8901U
¡Do not connect more than one
speaker to one set of speaker
leads. (except for connecting to a
tweeter)
Installation
(L) (White)
Speaker Connections
Connection with a CD Changer/XM Receiver
(Option)
System Upgrade Example: Connecting with an XM Receiver
XMD1000
(Option)
*Please understand that Panasonic
is not liable for modification of
specifications, shape, name, and
the like of the optional XM
receiver and digital adapter
without prior notice because they
are not manufactured by
Panasonic.
(R) (Red)
(L) (White)
RCA Cord (Option)
DIN Connector
(L) (White)
Ground Lead
XMDPAN100*
CH/AUX2-IN
(Option)
(R) (Red)
Battery Lead
DIN Cord
Power Lead
CQ-CB8901U
52
CQ-CB8901U
CQ-CB8901U
53
Power Supply
Tone Controls (Bass/Treble)
Equalizer Center Frequency
Variable Range of Equalizer
Current Consumption
Maximum Power Output
Speaker Impedance
Pre-amp output voltage
Subwoofer-output voltage
Pre-amp output impedance
Subwoofer-output impedance
Dimensions (Main Unit)
Weight (Main Unit)
DC 12 V (11 V - 16 V), Test Voltage 14.4 V, Negative Ground
Bass; ±12 dB at 62 Hz, Treble; ±12 dB at 16 kHz
60, 160, 400, 1 k, 3 k, 6 k, 16 k (Hz)
-12 dB to 12 dB (2 dB step)
Less than 2.2 A (CD mode, 0.5 W 4-Speaker)
50 W x 4 (at 1 kHz)
4-8Ω
5V
5V
60 Ω
60 Ω
178(W) x 50(H) x 155(D) mm {7” x 1 15/16 ”x 6 1/8”}
1.7 kg {3 lbs. 12 oz}
Sampling Frequency
DA Converter
Pick-Up Type
Light Source
Wavelength
Frequency Response
Signal to Noise Ratio
Total Harmonic Distortion
Wow and Flutter
Channel Separation
8 times oversampling
4 DAC System
Astigma 3-beam
Semiconductor laser
790 nm
20 Hz - 20 kHz (±1 dB)
96 dB
0.01 % (1 kHz)
Below measurable limits
86 dB
q
w
e
w Remove the trim plate.
w
e Lock release
q Insert the lock cancel plate until you hear a
click.
w Pull the main unit.
Insert the tab
end in the
outer groove.
q
w
FM
Radio
To Remove the Unit
q
Frequency Range
Usable Sensitivity
50 dB quieting Sensitivity
Frequency Response
Alternate channel selectivity
Stereo Separation
Image response ratio
IF response ratio
Signal to noise ratio
FM (HD Radio)
87.9 MHz - 107.9 MHz
12.2 dBf. (1.12 µV, 75Ω)
15.2 dBf. (1.59 µV, 75Ω)
30 Hz - 15 kHz (±3 dB)
75 dB
40 dB (at 1 kHz)
75 dB
100 dB
62 dB
AM
Frequency Range
Usable Sensitivity
Frequency Range
Usable Sensitivity
Signal to noise ratio
Stereo Separation
Total harmonic distortion
87.9 MHz - 107.9 MHz
– 88 dBm (BER<1.0X10 -5)
79 dB
76 dB
0.08 % (1 kHz)
Installation, Specifications
General
q Remove the face plate.
CD Player
Specifications
Installation
AM (HD Radio)
530 kHz - 1 710 kHz
25 dB/µV (S/N 20 dB)
“Click”
Frequency Range
Usable Sensitivity
Signal to noise ratio
Stereo Separation
Total harmonic distortion
530 kHz - 1 710 kHz
21 dB/µV (BER<1.0X10 -5)
77 dB
74 dB
0.08 % (1 kHz)
r Pull out the unit with both hands.
Above Specifications comply with EIA standards.
Power Output:
18 W RMS x 4 Channels at 4 Ω and ≤ 1%
THD+N
Signal to Noise Ratio:
78 dBA (reference: 1 W into 4 Ω)
Cautions:
¡Do not touch the contacts on the face plate or on the main unit, since this may result in poor electrical
contacts.
¡If dirt or other foreign substances get on the contacts, wipe them off with clean and dry cloth.
54
CQ-CB8901U
Notes:
¡Specifications and design are subject to modification without notice due to improvements.
¡Some figures and illustrations in this manual may be different from your product.
CQ-CB8901U
55
Download PDF
Similar pages
