M5A97
EVO R2.0
ii
E7429
First Edition
June 2012
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data, you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from http://support.asus.com/download or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan product for which you wish to obtain the corresponding source code and your contact details so that we can coordinate the terms and cost of shipment with you.
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
Software licenses. If however you encounter any problems in obtaining the full corresponding source code we would be much obliged if you give us a notification to the email address [email protected], stating the product and describing the problem (please DO NOT send large attachments such as source code archives, etc. to this email address).
Contents
Chapter 1:
Product introduction 1-1
Product highlights........................................................................1-1
Dual Intelligent Processors 3 with New DIGI+ Power Control ....1-2
ASUS Exclusive Features ...........................................................1-3
ASUS Quiet Thermal Solution .....................................................1-4
ASUS EZ DIY ..............................................................................1-4
Other special features .................................................................1-5
Before you proceed .....................................................................1-6
Motherboard layout .....................................................................1-7
Central Processing Unit (CPU) ...................................................1-9
System memory ........................................................................1-10
Expansion slots .........................................................................1-24
Onboard buttons and switches..................................................1-26
Jumper ......................................................................................1-30
Onboard LEDs ..........................................................................1-31
Internal connectors....................................................................1-34
Chapter 2:
Basic Installation 2-1
2.1.1 Motherboard installation ..............................................................2-1
CPU installation...........................................................................2-4
CPU heatsink and fan assembly installation ...............................2-5
DIMM installation.........................................................................2-7
ATX Power connection ................................................................2-8
SATA device connection ..............................................................2-9
Front I/O Connector ..................................................................2-10
Expansion Card installation....................................................... 2-11
Motherboard rear and audio connections .............................................2-13
2.3.1 Rear I/O connection ..................................................................2-13
2.3.2 Audio I/O connections ...............................................................2-15
iii
iv
Chapter 3:
BIOS setup 3-1
3.2.2 Advanced Mode ..........................................................................3-4
3.5.1 CPU Configuration ....................................................................3-17
3.5.2 North Bridge Configuration........................................................3-18
South Bridge Configuration .......................................................3-20
SATA Configuration ...................................................................3-20
USB Configuration ....................................................................3-22
CPU Core On/Off Function .......................................................3-23
Onboard Devices Configuration ................................................3-24
APM ..........................................................................................3-26
Network Stack ...........................................................................3-27
ASUS EZ Flash 2 Utility ............................................................3-33
ASUS SPD Information .............................................................3-33
ASUS O.C. Profile .....................................................................3-34
3.10.1 ASUS Update ............................................................................3-36
3.10.2 ASUS EZ Flash 2 ......................................................................3-39
3.10.3 ASUS BIOS Updater .................................................................3-41
Chapter 4:
Software support 4-1
Installing an operating system .................................................................4-1
4.2.1 Running the support DVD ...........................................................4-1
4.2.2 Obtaining the software manuals..................................................4-2
4.3.2 DIGI+ Power Control ...................................................................4-4
TurboV EVO ................................................................................4-8
EPU ...........................................................................................4-12
Remote GO! ..............................................................................4-13
USB 3.0 Boost...........................................................................4-24
Network iControl........................................................................4-25
USB BIOS Flashback Wizard....................................................4-29
FAN Xpert..................................................................................4-31
4.3.12 Sensor Recorder .......................................................................4-34
4.3.13 ASUS Update ............................................................................4-36
4.3.15 Audio configurations..................................................................4-39
Chapter 5:
RAID support 5-1
RAID definitions ..........................................................................5-1
Installing Serial ATA hard disks ...................................................5-2
Setting the RAID item in BIOS ....................................................5-2
Option ROM utility ............................................................5-3
5.2.1 Creating a RAID driver disk without entering the OS ..................5-6
Creating a RAID driver disk in Windows
....................................5-6
Installing the RAID driver during Windows
Using a USB floppy disk drive .....................................................5-8
Chapter 6:
Multiple GPU support 6-1
CrossFireX™ technology ...............................................................6-1
6.1.1 Requirements ..............................................................................6-1
Before you begin .........................................................................6-1
Installing two CrossFireX™ graphics cards ................................6-2
Installing the device drivers .........................................................6-3
CrossFireX™ technology .............................6-3
Appendices A-1
v
vi
Safety information
•
•
•
•
•
•
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt the grounding circuit.
Ensure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
•
•
•
•
•
•
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the package.
Before using the product, ensure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet.
Place the product on a stable surface.
If you encounter technical problems with the product, contact a qualified service technician or your retailer.
About this guide
This user guide contains the information you need when installing and configuring the motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it supports. It includes description of the switches, jumpers, and connectors on the motherboard.
•
•
•
Chapter 2: Basic installation
This chapter lists the hardware setup procedures that you have to perform when installing system components.
Chapter 3: BIOS setup
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
Chapter 4: Software support
•
•
This chapter describes the contents of the support DVD that comes with the motherboard package and the software.
Chapter 5: RAID support
This chapter describes the RAID configurations.
Chapter 6: Multiple GPU technology support
This chapter describes how to install and configure multiple AMD
® graphics cards.
CrossFireX™
Where to find more information
Refer to the following sources for additional information and for product and software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. These documents are not part of the standard package.
vii
viii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task.
CAUTION: Information to prevent damage to the components when trying to complete a task
IMPORTANT: Instructions that you MUST follow to complete a task. .
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text
Italics
<Key>
Indicates a menu or an item to select.
Used to emphasize a word or a phrase.
Keys enclosed in the less-than and greater-than sign means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key names are linked with a plus sign (+).
M5A97 EVO R2.0 specifications summary
CPU
Chipset
System Bus
Memory
Expansion slots
Multi-GPU support
AMD
®
Socket AM3+ for AMD
®
FX Series CPU up to 8-core
Compatible with AMD
®
Socket AM3 for AMD
®
II/Sempron™ 100 Series Processors
Phenom™II/Athlon™
AMD 140W CPU Support
AMD Cool ‘n’ Quiet™ Technology
Supports AM3+ 32nm CPU
AMD
®
970/SB950
Up to 4800 MT/s; HyperTransport™ 3.0
4 x DIMM, Max. 32GB, DDR3 2133(O.C)/1866/1600/1333/1066
MHz, ECC, Non-ECC, un-buffered Memory
Dual channel memory architecture
* Due to CPU spec., AMD 100 Series CPUs support up to DDR3 1066MHz.
With ASUS design, this motherboard can support up to DDR3 1333MHz.
** Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
*** Refer to www.asus.com or user manual for the Memory QVL(Qualified
Vendors Lists) of AM3+/AM3 CPU.
2 x PCIe 2.0 x16 slots (Blue@x16 speed; Black@x4 speed)
2 x PCIe 2.0 x1 slots
2 x PCI slots
Supports AMD
®
Quad-GPU CrossFireX™ Technology
Storage
LAN
Audio
AMD
®
SB950 Chipset:
- 6 x SATA 6Gb/s ports with RAID 0,1,5 and 10 support (gray)
1 x ASMedia
®
PCIe SATA controller:
- 2 x eSATA 6Gb/s ports (red)
Realtek
®
8111F Gigabit LAN controller
Realtek
®
ALC 892 8-channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-Streaming, and Front Panel
Jack-Retasking
- Supports 192khz/ 24bit True BD Lossless Sound
- Blu-ray audio layer Content Protection
- DTS UltraPC II
- DTS Connect
- Optical S/PDIF Out port at back I/O
- ASUS Noise Filter
(continued on the next page) ix
x
M5A97 EVO R2.0 specifications summary
USB
IEEE 1394
ASUS Unique Features
2 x ASMedia USB 3.0 controllers
- 2 x USB 3.0/2.0 ports at mid-board for front panel support
- 2 x USB 3.0/2.0 ports at back panel (blue)
AMD® SB950 chipset
- 14 x USB 2.0/1.1 ports (6 ports at mid-board, 8 ports at back panel)
VIA ® 6308P controller supports 2 x IEEE 1394a ports (1 at midboard, 1 at back panel)
ASUS Dual Intelligent Processors 3 with New DIGI Power Control:
CPU Power
- Industry leading Digital 6+2 Phase Power Design
- ASUS CPU Power Utility
DRAM Power
- Industry leading Digital 2 Phase Power Design
- ASUS DRAM Power Utility
SMART DIGI Key
ASUS EPU
- EPU, EPU switch
ASUS TPU
- Auto Tuning, TurboV, TPU switch
ASUS Exclusive Features
- ASUS UEFI BIOS EZ Mode
- Remote GO!
- Front Panel USB 3.0 Support
- Network iControl
- USB 3.0 Boost
- MemOK!
- AI Suite II
- Ai Charger+
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Heat-sink solution
- ASUS Fan Xpert
ASUS Q-Design
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Connector
ASUS EZ DIY
- ASUS O.C. Profile
- DirectKey
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Precision Tweaker 2
- Multi-language BIOS
(continued on the next page)
M5A97 EVO R2.0 specifications summary
ASUS overclocking features
Back Panel I/O Ports
Internal I/O Ports
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.00625V increment
- vDDNB: Adjustable CPU/NB voltage at 0.00625V increment
- vNB: Adjustable NB voltage at 0.00625V increment
- vNB HT bus: Adjustable HT voltage at 0.00625V increment
- vDRAM Bus: Adjustable DRAM voltage at 0.005V increment
- vSB: Adjustable SB voltage at 0.005V increment
SFS (Stepless Frequency Selection)
- Internal Base Clock tuning from 100MHz up to 600MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz up to 150MHz at
1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
1 x PS/2 keyboard/mouse combo port
1 x Optical S/PDIF Out port
1 x IEEE 1394a port
1 x LAN (RJ45) port
2 x eSATA 6Gb/s ports (red)
2 x USB 3.0/2.0 ports (blue)
8 x USB 2.0/1.1 ports (One can be used for USB BIOS Flashback)
6 x 8-channel audio jacks
1 x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
(19-pin)
6 x SATA 6Gb/s connectors
1 x CPU Fan connector (4-pin)
3 x Chassis Fan connectors (4-pin)
1 x IEEE 1394a connector
1 x COM connector
1 x TPM header
1 x DRCT header
1 x Front panel audio connector
1 x S/PDIF Out header
1 x Clear CMOS jumper
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x System Panel (Q-Connector)
1 x MemOK! button
1 x USB BIOS Flashback button
1 x DirectKey button
1 x EPU switch
1 x TPU switch
(continued on the next page) xi
xii
M5A97 EVO R2.0 specifications summary
BIOS features
Manageability
Accessories
Support DVD contents
Form factor
64 Mb Flash ROM, UEFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS
2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, F12
PrintScreen, F3 Shortcut Function and ASUS DRAM SPD (Serial
Presence Detect) memory information
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
3 x Serial ATA 6Gb/s cables
2 in 1 Q-connector
I/O Shield
User’s manual
Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
ATX form factor: 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Specifications are subject to change without notice.
Package contents
Check your motherboard package for the following items.
User Manual
User guide Support DVD
3 x Serial ATA 6.0 Gb/s cables 1 x 2-in-1 ASUS Q-Connector kit 1 x ASUS I/O Shield
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specifications may vary with different models.
xiii
xiv
Installation tools and components
1 bag of screws
PC chassis
AMD AM3+ CPU
DDR3 DIMM
Philips (cross) screwdriver
Power supply unit
AMD AM3+ compatible CPU Fan
SATA hard disk drive
SATA optical disc drive (optional) Graphics card (optional)
The tools and components in the table above are not included in the motherboard package.
Product introduction
1.1 Special features
1
1.1.1 Product highlights
AMD
®
FX™-Series/Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors
(socket AM3+/AM3)
This motherboard supports AMD native CPU cores, and AMD
®
® better overclocking capabilities with less power consumption. It features AMD Turbo CORE
Technology 2.0 to accelerate data transfer rate up to 4800MT/s rate via HyperTransport™ 3.0 based system bus.
Socket AM3+ multi-core processors with up to 8-core
CPUs in the new 32nm manufacturing process. It provides
AMD
®
970 Chipset
The AMD
®
Chipset is designed to support up to 4800 MT/s HyperTransport™ 3.0 (HT 3.0) interface speed and PCI Express™ 2.0x16 graphics. It is optimized with AMD
®
’s latest AM3+ and multi-core CPUs to provide excellent system performance and overclocking capabilities.
AMD
®
SB950 Chipset
The AMD
®
SB950 Southbridge natively supports the next generation SATA 6.0 Gb/s data transfer rate and PCI Express 2.0 interface.
PCI Express
®
2.0
This motherboard supports the latest PCIe 2.0 devices for double speed and bandwidth that enhances system performance.
AMD
®
Quad-GPU CrossFireX™ Support
AMD
®
’s CrossFireX™ boosts image quality along with rendering speed, eliminating the need to scale down screen resolution to get high quality images. CrossFireX™ allows higher antialiasing, anisotropic filtering, shading and texture settings. Adjust your display configurations, experiment with the 3D settings, and check the effects with a real-time 3D-rendered previews within AMD Catalyst™ Control Center.
Dual-Channel DDR3 2133 (O.C.)/ 1866/ 1600/ 1333 /1066 MHz Support
The motherboard supports the dual-channel DDR3 memory that features data transfer rates of DDR3 2133 (O.C.)/ 1866/ 1600/ 1333/ 1066 MHz to boost the system’s performance, and to meet the higher bandwidth requirements of 3D graphics, multimedia, and Internet applications.
Complete USB 3.0 Solution
This motherboard offers you the strategic USB 3.0 accessibility for both the front and rear panels, allowing you to experience the convenience of the latest plug and play connectivity solution at speed up to ten times faster than USB 3.0.
ASUS M5A97 EVO R2.0
1-1
1-2
Native SATA 6.0 Gb/s support
With AMD
®
SB950 Southbridge supporting the Serial ATA (SATA) storage interface, this motherboard can deliver up to 6.0 Gb/s data transfer rates. It also provides enhanced scalability, faster data retrieval, and double the bandwidth of current bus systems.
IEEE 1394a
The IEEE 1394a interface provides high-speed digital interface for audio/video devices such as digital television, digital video camcorders, storage peripherals, and other portable PC devices.
1.1.2 Dual Intelligent Processors 3 with New DIGI+ Power
Control
A first on the AMD platform, the evolutionary, innovative, and industry-leading ASUS thirdgeneration Dual Intelligent Processors with its New DIGI+ Power Control provides total
CPU, memory, and SMART DIGI+ Key profile tuning and digital power solutions. Bundled with the ASUS AI Suite II utility, the New DIGI+ Power Control has been upgraded and optimized for a one-click extreme performance. It includes two digital voltage controllers that allows ultra-precise DRAM tuning and CPU voltage control for better efficiency, stability, and performance.
New DIGI+ Power Control
With its two digital voltage controllers, the New DIGI+ Power Control offers an enhanced overall power delivery solution on AMD AM3+ motherboards, and allows ultra-precise DRAM tuning anad ultra-precise CPU control. This evolutionary, innovative, and industry-leading
ASUS technology provides the best control mechanism for better efficiency, stability, and performance.
TPU with the All-New SMART DIGI+ Key
Propelling you into the forefront of power management design, ASUS gives you the complete
CPU, memory, and new SMART DIGI+ technology with its profile tuning and digital power solutions. Enable the new SMART DIGI+ Key profile with just one click and manually adjusts the CPU ratios in the TPU interface for a blazing 100% increase in CPU frequency and performance.
Increased CPU and DRAM overclocking range
Adjusts the CPU and DRAM voltages and VRM switching frequencies for various overclocking scenarios with the onboard programmable digital controllers. Explore for new
DRAM tuning possibilities to make the most of the DDR3 memory modules for better CPU/NB loadline calibration performance and 30% more DRAM current capacity. With several power options coupled with an extensive and intuitive UEFI BIOS, overclocking very large memory setups has become extremely easy.
Chapter 1: Product introduction
TPU
TPU (TurboV Processing Unit) offers precise voltage control and advanced monitoring mechanisms through the Auto Tuning and TurboV functions.
Auto Tuning provides a user-friendly solution to automatically optimize the system for fast, yet stable clock speeds, while TurboV enables unlimited freedom to adjust CPU frequencies and ratios for optimized performance in diverse situations.
EPU
EPU (Energy Processing Unit), the world’s first real-time system power-saving chip, automatically detects the current system load and intelligently moderates power usage.
It offers a total system-wide energy optimization, reduces fan noise, and extends the component’s lifespan.
1.1.3 ASUS Exclusive Features
•
Remote GO!
Remote GO! links PCs, tablets, smartphones, and TVs wirelessly together through an existing LAN cable and route setup. It provides a seamless environment for a futuristic connected lifestyle with three useful functions:
DLNA Media Hub: Enjoy HD video, music and photos stored in your PC, streaming to your DLNA devices via Wi-Fi. You can even use your tablet to control your PC to play multimedia contents.
•
Remote Desktop: Operate and control your PC in real time from a smartphone or tablet for complete comfort and convenience.
•
File Transfer: Send and share files between your PC and smart devices* with only a right click on the mouse.
* iPad/iPhone can send files, but cannot receive file transfers from PC.
MemOK!
MemOK!, the remarkably memory rescue tool, allows you to simply press a button to patch memory issues, ensure memory boot compatibility, determine fail-safe settings, and dramatically improve the system’s bootup.
AI Suite II
With its user-friendly interface, ASUS AI Suite II integrates several ASUS utilities and allows you to launch and operates these utilities simultaneously. It allows you to configure the overclocking settings, adjust the frequencies and related voltages, remotely control the system via a mobile device, and other easy-to-use helpful utilities.
USB 3.0 Boost
ASUS USB 3.0 Boost technology, which supports UASP (USB Attached SCSI Protocol), automatically accelerates the data transfer speed of a USB 3.0 device up to 170% faster than the standard USB 3.0 transfer speed.
Network iControl
Network iControl is an intuitive one-step network control center that makes it easier for you to manage your bandwidth and allows you to set, monitor, and schedule the bandwidth priorities for your network programs. It allows you to automatically connect to a PPPoE network for a more convenient online experience.
ASUS M5A97 EVO R2.0
1-3
1-4
1.1.4 ASUS Quiet Thermal Solution
ASUS Fanless Design—Heat-sink solution
The stylish heatsink features 0-dB thermal solution for a noiseless PC environment. The heatsink design also lowers the chipset’s temperature and power phase area through efficient heat-exchange. Combining usability with aesthetics, the ASUS heatsink gives you a smartlydesigned fanless cooling solution.
ASUS Fan Xpert
ASUS Fan Xpert intelligently allows you to adjust both the CPU and chassis fan speeds based on different ambient temperatures, resulting to a quiet and cool computing environment.
•
•
•
1.1.5 ASUS EZ DIY
ASUS UEFI BIOS (EZ Mode)
ASUS UEFI BIOS, a UEFI compliant architecture, offers the first mouse-controlled intuitive graphical BIOS interface that goes beyond the traditional keyboard-only BIOS controls, providing you with more flexibility, convenience, and easy to navigate EFI BIOS than the traditional BIOS versions. It offers you with dual selectable modes and native support for hard drives larger than 2.2 TB.
ASUS UEFI BIOS includes the following new features:
F12 BIOS snapshot hotkey
F3 Shortcut for most accessed information
ASUS DRAM SPD (Serial Presence Detect) information detecting faulty DIMMs, and helping with difficult POST situations.
ASUS Direct Key
This feature allows your system to go to the BIOS Setup program with the press of a button.
With DirectKey, you can enter the BIOS anytime without having to press <Del> key during
POST. It also allows you to turn on and turn off your system and conveniently enter the BIOS during bootup.
USB BIOS Flashback
USB BIOS Flashback offers a hassle-free updating solution for your ultimate convenience.
Install a USB storage device containing the BIOS file, press the BIOS Flashback button for about three seconds, and the UEFI BIOS is automatically updated even without entering the existing BIOS or operating system. It also allows you to regularly check for UEFI BIOS updates, and download the latest BIOS automatically.
Chapter 1: Product introduction
ASUS Q-Design
ASUS Q-Design enhances your DIY experience. All of Q-LED, Q-Slot, and Q-DIMM design speed up and simplify the DIY process!
ASUS Q-Connector
ASUS Q-Connector allows you to easily connect or disconnect the chassis front panel cables to the motherboard. This unique module eliminates the trouble of connecting the system panel cables one at a time and avoiding wrong cable connections.
ASUS EZ-Flash 2
ASUS EZ Flash 2 is a user-friendly utility that allows you to update the BIOS without using a bootable floppy disk or an OS-based utility.
1.1.6 Other special features
External SATA
The external SATA port located at the back I/O provides smart setup and hot-plug functions.
Easily back up photos, videos and other entertainment contents on external devices.
DTS Connect
To get the most out of your audio entertainment across all formats and quality levels, DTS
Connect combines two enabling technologies, DTS Neo:PC™ upmixes stereo sources (CDs,
MP3s, WMAs, internet radio) into as many as 7.1 channels of incredible surround sound.
Consumers can connect their PC to a home theater system. DTS Interactive is capable of performing mult-channel encoding of DTS bitstreams on personal computers, and sending encoded bitstreams out of a digital audio connection (such as S/PDIF or HDMI) designed to deliver audio to an external decoder.
DTS UltraPC II
DTS UltraPC II delivers an exceptional 7.1 surround experience through the most popular PC audio setups—your existing stereo speakers or headphones. In addition to virtual surround, it upgrades the original sound to new levels with Audio Restoration, recreating dynamic range of audio files. Symmetry mode improves the balance of perceived loudness across different input sources, and enhances boost audio quality through high hand low frequency equalization. With these technologies, users experience better home theater audio with ease.
ErP Ready
The motherboard is European Union’s Energy-related Products (ErP) ready, and ErP requires products to meet certain energy efficiency requirement in regards to energy consumptions.
This is in line with ASUS vision of creating environment-friendly and energy-efficient products through product design and innovation to reduce carbon footprint of the product and thus mitigate environmental impacts.
ASUS M5A97 EVO R2.0
1-5
1.2 Motherboard overview
1.2.1 Before you proceed
Take note of the following precautions before you install motherboard components or change any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.
1-6 Chapter 1: Product introduction
1.2.2 Motherboard layout
Refer to 1.2.9 Internal connectors and 2.3.1 Rear I/O connection for more information about rear panel connectors and internal connectors.
ASUS M5A97 EVO R2.0
1-7
1-8
Layout contents
Connectors/Jumpers/Slots
1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
2. AM3+/AM3 CPU Socket
3. CPU and chassis fan connectors (4-pin CPU_FAN; CHA_FAN1/2/3)
4. DDR3 DIMM slots
5. EPU LED (O2LED3)
6. EPU Switch
7. MemOK! button
8. POST State LEDs
9. DirectKey button
10. USB 3.0 connector (20-1 pin USB3_34)
11. AMD
®
Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6 [gray])
12. TPU Switch
13 TPU LED (O2LED2)
14. Clear RTC RAM (3-pin CLRTC)
15. Direct connector (2-pin DRCT)
16 System panel connector (20-8 pin PANEL)
17. Serial port connector (10-1 pin COM1)
18. USB 2.0 connectors (10-1 pin USB910, USB1112, USB1314)
19. Standby Power LED
20. TPM connector (20-1 pin TPM)
21. BIOS Flashback LED (FLBK_LED)
22. USB BIOS Flashback button
23. IEEE 1394a port connector (10-1 pin IE1394_2)
24. Front panel audio connector (10-1 pin AAFP)
25. Digital audio connector (4-1 pin SPDIF_OUT)
26. POST State LEDs
1-35
1-34
1-29
1-32
1-30
1-42
1-41
1-39
Page
1-40
1-9
1-38
1-10
1-33
1-28
1-27
1-31
1-26
1-36
1-31
1-42
1-32
1-28
1-37
1-39
1-37
1-31
Chapter 1: Product introduction
1.2.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount AM3+ socket designed for the AMD
®
Series/Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors.
FX™-
Ensure that all power cables are unplugged before installing the CPU.
The AM3+ socket has a different pinout from the 940-pin socket designed for the AMD
Opteron processor. Ensure that you use a CPU designed for the AM3+ socket. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU!
ASUS M5A97 EVO R2.0
1-9
1.2.4 System memory
The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory Modules
(DIMM) slots.
A DDR3 module is notched differently from a DDR or DDR2 module. DO NOT install a DDR or DDR2 memory module to the DDR3 slot.
Recommended memory configurations
1-10 Chapter 1: Product introduction
Memory configurations
You may install 1GB, 2GB, 4GB, 8GB, and 16GB unbuffered ECC and non-ECC DDR3 DIMMs into the DIMM sockets.
• You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation.
• Always install DIMMs with the same CAS latency. For optimal compatibility, we recommend that you install memory modules of the same version or date code (D/C) from the same vendor. Check with the retailer to get the correct memory modules.
• Memory module with memory frequency higher than 2133MHz and its corresponding timing or the loaded DRAM OC profile is not the JEDEC memory standard. The stability and compatibility of the memory modules depend on the CPU’s capabilities and other installed devices.
• Due to the CPU spec., AMD AM3 100 series CPUs support up to DDR3 1066MHz.
With ASUS design, this motherboard can support up to DDR3 1333MHz.
• When overclocking, some AMD CPU models may not support DDR3 1600 or higher frequency DIMMs.
• Due to the memory address limitation on 32-bit Windows OS, when you install 4GB or more memory on the motherboard, the actual usable memory for the OS can be about 3GB or less. For effective use of memory, we recommend that you do any of the following:
Install a 64-bit Windows OS when you want to install 4GB or more on the motherboard.
c) For more details, refer to the Microsoft
® com/kb/929605/en-us.
support site at http://support.microsoft.
• This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less
(Memory chip capacity counts in Megabit, 8 Megabit/Mb = 1 Megabyte/MB).
• The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. To operate at the vendor-marked or at a higher frequency, refer to section 3.4 Ai Tweaker menu for manual memory frequency adjustment.
• For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs) or overclocking condition.
ASUS M5A97 EVO R2.0
1-11
1-12
M5A97 EVO R2.0 Motherboard Qualified Vendors Lists (QVL)
DDR3 2400 MHz capability
Vendors Part No.
Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
A-DATA
G.SKILL
G.SKILL
G.SKILL
G.SKILL
GEIL
Kingston
Patriot
AX3U2400GC4G 10(XMP)
F3-19200CL10Q-32GBZHD(XMP)
F3-19200CL11Q-16GBZHD(XMP)
F3-19200CL9D-4GBPIS(XMP)
F3-19200CL9Q-16GBZMD(XMP)
GOC316GB2400C11QC(XMP)
KHX2400C11D3K4/ 8GX(XMP)
PXD38G2400C11K(XMP)
Patriot PXD38G2400C11K(XMP)
Transcend TX2400KLU-4GK (374243)(XMP)
4GB DS
DS
16GB
(4x4GB)
4GB
(2x2GB)
DS
DS
DS
DS
8GB
(4x2GB)
8GB
(2x4GB)
SS
DS
DS
2GB DS -
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
10-11-11-30 1.65
10-12-12-31 1.65
11-11-11-31 1.65
9-11-9-28 1.65
9-11-11-31 1.65
11-11-11-30 1.65
11-13-11-30 1.65
11-11-11-30 1.65
-
11-11-11-30 1.65
1.65
Apacer
CORSAIR
CORSAIR
G.SKILL
G.SKILL
G.SKILL
KINGSTON
KINGSTON
Patriot
Patriot
Team
DDR3 2133 MHz capability
Vendors Part No.
Size
78.BAGE4.AFD0C(XMP)
CMT4GX3M2A2133C9(XMP)
CMT4GX3M2B2133C9(Ver7.1)(XMP)
F3-17000CL9Q-16GBZH(XMP)
4GB
(2x2GB)
16GB
(4x4GB)
F3-17066CL9D-8GBPID(XMP))
F3-17066CL9Q-16GBTDD(XMP)
KHX2133C11D3K4/16GX(XMP)
KHX2133C11D3T1K2/16GX(XMP)
16GB
(4x4GB)
16GB
(2x8GB)
PVV34G2133C9K(XMP)
PXD38G2133C11K(XMP)
TXD34096M2133HC9N-L(XMP) 4GB
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
SS/
DS
Chip
Brand
Chip
NO.
-
-
-
-
-
-
-
-
9-9-9-
24
9-11-
10-28
-
-
-
-
-
-
-
-
11-12-
11-30
9-9-9-
24
-
-
-
SAMSUNG K4B2G
0846D
9-9-9-
24
Timing
-
Voltage
•
2
DIMM socket support
(Optional)
4
1.65
1.5
1.65
1.65
1.65
1.65
1.6
1.66
1.65
1.65
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DIMM socket support
(Optional)
2 4
•
•
•
•
•
Chapter 1: Product introduction
DDR3 2000 MHz capability
Vendors Part No.
Size
A-DATA
A-DATA
AEXEA
AEXEA
AXA3ES2G2000LG
28V(XMP)
AXA3ES4GK2000L
G28V(XMP)
78.AAGD5.9KD(XMP)
2GB
4GB
2GB DS
4GB
(2x2GB)
DS
DS
4GB DS
DS
DS
Apacer
Asint
GEIL
Gingle
Patriot
Patriot
CORSAIR
CORSAIR
CMT6GX3M3A2000
C8(XMP)
CMZ4GX3M2A2000C
10(Ver 5.12)(XMP)
G.SKILL
Patriot
6GB
(3x2GB)
4GB
(2x2GB)
DS
SS
DS
GU34GB2000C9DC
(XMP)
FA3URSS673A801A
PV736G2000ELK(XMP)
PVT36G2000LLK(XMP)
4GB
(2x2GB)
2GB
6GB
(3x2GB)
6GB
(3x2GB)
X7312G2000ELK(XMP)
DS
DS
DS
DS
DS
Team
Team
TXD32048
M2000C9(XMP)
TXD32048M2000C9-
L(XMP)
2GB
2GB
2GB
DS
DS
DS
Team
Transcend
2GB
4GB
DS
DS
-
-
-
Hynix
-
-
-
-
-
-
-
-
-
-
-
Team
Team
-
Team
-
-
-
-
-
Chip NO.
-
-
-
-
-
-
-
-
-
T3D1288RT-20
T3D1288LT-20
-
T3D1288RT-20
-
9-11-9-27
9-9-9-24
9-9-9-24
-
9-9-9-24
Timing
-
-
9-11-9-27
9-11-9-27
9-9-9-27
9-9-9-27 -
-
8-9-8-24 1.65
10-10-10-27 1.5
9-9-9-24
9-9-9-28
9-9-9-24
7-7-7-20
8-8-8-24
1.65
1.65
-
1.65
1.65
Voltage
1.55~1.75
•
2 support
(Optional)
4
1.55~1.75
• •
1.65
1.65
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
1.6
1.6
1.5
1.5
-
1.65
•
•
•
•
•
•
ASUS M5A97 EVO R2.0
1-13
DDR3 1866 MHz capability
Vendors Part No.
A-DATA
CORSAIR
CORSAIR
G.SKILL
AX3U1866GC4G9B(XMP)
CMZ16GX3M4X1866C9R
(Ver8.16)(XMP)
CMZ32GX3M4X1866C10
(Ver3.23)(XMP)
F3-14900CL10Q2-64GBZLD(XMP)
Kingston
Patriot
Patriot
KHX1866C9D3K2/8GX(XMP)
PXD38G1866ELK(XMP)
PXD38G1866ELK(XMP)
Team TXD34096M1866HC9K-L(XMP)
Size
4GB
16GB
(4x4GB)
32GB
(4x8GB)
DS
DS
DS
DS
DS
8GB
(2x4GB)
8GB
(2x4GB)
4GB
DS
DS
DS
-
-
-
-
-
-
-
Hynix
SS/
DS
Chip
Brand
-
-
-
-
-
-
-
Chip NO.
Timing
9-11-9-27
9-10-9-27
10-11-
10-27
1.5
-
9-11-9-27
9-11-9-27
1.5
1.65
1.65
1.65
Voltage
1.55~1.75
1.5
•
•
2
DIMM socket support
(Optional)
•
•
4
•
•
•
•
• •
•
•
83BFRH
9A
9-11-9-27 1.65
•
1-14
A-DATA
A-DATA
A-DATA
AMD
Apacer
Apacer
Asint
Asint
Asint
Asint
DDR3 1600 MHz capability
Vendors Part No.
Size SS/
DS
Chip Brand Chip NO.
Timing
AM2U16BC2P1
AX3U1600G
C4G9(XMP)
2GB
4GB
SS
DS -
A-DATA
-
3CCD-1509A
-
-
78.B1GE3.9L10C
AHU04GFA60
C9Q1D(XMP)
4GB
4GB
4GB
DS
DS
DS
DS -
-
-
Apacer
-
-
-
AM5D5908
DEQSCK
8-8-8-24
9-9-9-28
-
9-9-9-27
4GB
4GB
DS
DS
Asint
Asint
9-9-9-27
302G08-GJ1C 9-9-9-27
SLA302G08- EGN1C
SLB304G08- EGN1B
4GB
8GB
DS
DS
ASint
ASint
302G08-
GN1C
304G08-GN1B
(continued on the next page)
-
-
-
-
-
1.65
1.65
1.65
-
Voltage
1.55~
1.75
•
•
•
•
•
•
•
•
•
2
DIMM socket support
(Optional)
•
•
4
•
•
•
•
•
•
•
Chapter 1: Product introduction
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
DDR3 1600 MHz capability
Vendors
Asint
Asint
ATP
CORSAIR
CORSAIR
Part No.
Size Chip Brand Chip NO.
Timing
SLZ302G08- EGN1C 2GB
SLZ3128M8-
EGJ1D(XMP)
AQ12M64B8 BKK0S
CMG4GX3M2A
1600C6
CML16GX3M4X
2.12)(XMP)
CMP6GX3M3A
1600C8 (XMP)
CMP6GX3M3A1600
C8(XMP)
2GB
4GB
4GB
(2x2GB)
16GB
(4x4GB)
DS
DS
DS
6GB
(3x2GB)
6GB
(3x2GB)
DS
DS
DS
SS
DS
DS
CMZ32GX3M4X1600
C10(Ver2.2)(XMP)
32GB
(4x8GB)
DS
DS
DS
CMZ8GX3M4X1600
C9(Ver2.12)(XMP)
HX3X12G1600C9
(XMP)
8GB
(4x2GB)
12GB
(6x2GB)
SS
DS
-
-
-
-
-
-
-
-
-
ASint
Asint
-
-
SAMSUNG
-
-
-
-
-
-
-
(continued on the next page)
-
-
-
-
3128M8-GJ1D -
K4B2G08460
-
-
6-6-6-18
Heat-Sink
Package
-
-
NO
1.65
1.5
8-8-8-24
8-8-8-24
1.65
1.65
7-8-7-20
9-9-9-24
10-10-
10-27
8-8-8-24
9-9-9-24
9-9-9-24
9-9-9-24
1.65
1.5
1.5
1.5
1.6
1.5
1.5
Voltage
•
•
•
•
•
2 socket
(Optional)
•
4
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
ASUS M5A97 EVO R2.0
1-15
1-16
DDR3 1600 MHz capability
Vendors Part No.
Size SS/
DS
Chip
Brand
Crucial
Crucial
EK Memory
BL12864BN16 08.8FF(XMP)
BLT4G3D1608D
T1TX0.16FM(XMP)
EKM324L28BP8- I16(XMP)
Elixir
4GB
4GB( 2x
2GB )
2GB
SS
DS
DS
SS Elixir
-
-
-
Elixir
Elixir
G.SKILL
G.SKILL
F3-12800CL7D-
8GBRH(XMP)
F3-12800CL7Q-
16GBXH(XMP)
G.SKILL
G.SKILL
G.Skill
F3-12800CL9Q-
16GBZL(XMP)
GEIL
GoodRam
KINGMAX
KINGMAX
KINGSTON
GR1600D364 L9/2G
FLGE85F-C8K L9A(XMP)
FLGF65F-C8K L9A(XMP)
KINGSTON
KINGSTON
KINGSTON
KHX1600C9D3
K3/12GX(XMP)
KHX1600C9D3
K3/6GX(XMP)
KINGSTON
4GB
8GB
8GB
(2x4GB)
16GB
(4x4GB)
16GB
(4x4GB)
2GB
2GB
4GB
12GB
(3x4GB)
6GB
(3x2GB)
DS
DS
DS
DS
-
-
Elixir
Elixir
DS
DS
DS
-
-
-
DS
DS
DS
DS
DS
SS
DS
DS
DS -
-
-
-
-
GoodRam
-
-
KINGMAX
KINGMAX
-
N/A
N/A
-
-
-
-
-
-
-
-
-
-
-
-
Chip NO.
Timing
1.65
1.65
1.65
-
1.6
-
-
1.65
1.65
1.5
1.5
1.5
1.6
1.6
-
1.5
-
-
1.5
Voltage
1.65
•
2
DIMM socket
(Optional)
•
4
•
•
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
8-8-8-24
8-8-8-24
9
9-9-9-28
-
9
9
-
9-9-9-28
-
9-9-9-28
9-9-9-28
9
9-9-9-28
9-9-9-28
7-8-7-24
7-8-7-24
9-9-9-24
9-9-9-24
9-9-9-24
(continued on the next page)
Chapter 1: Product introduction
DDR3 1600 MHz capability
Vendors
Kingston
KINGSTON
Kingston
KINGSTON
Kingston
Patriot
Patriot
Patriot
Patriot
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGTIGER
MICRON
MICRON
Mushkin
Mushkin
Patriot
Patriot
Patriot
SanMax
SanMax
Silicon
Power
Silicon
Power
Part No.
Size SS/
DS
Chip
Brand
Chip NO.
Timing
9-9-9-24
Voltage
1.65
•
DIMM socket support
(Optional)
2 4
• KHX1600C9D3
K4/16GX(XMP)
16GB
(4x4GB)
DS -
KHX1600C9D3L
K2/4GX(XMP)
KHX1600C9D3L
K2/8GX(XMP)
4GB
(2x2GB)
8GB
(2x4GB)
DS
DS
DS
DS
-
-
-
-
-
-
-
9 1.65
9-9-9-27 1.65
1.35
9-9-9-24 1.35
KHX1600C9D3T1
K3/6GX(XMP)
KHX1600C9D3X2
K2/4GX(XMP)
KTG2G1600P G3(XMP)
6GB
(3x2GB)
4GB
(2x2GB)
2GB
4GB
2GB
996805(XMP)
998805(XMP)
AE32G1609U1-U
AE34G1609U2-U
PGD316G1600
ELK(XMP)
PGD38G1600
ELK(XMP)
PGS34G1600 LLKA
PVV38G1600LLK(XMP)
PX7312G1600
LLK(XMP)
SMD-4G68 HP-16KZ
SMD-4G68 NG-16KK
SP002GBLTU160
V02(XMP)
SP004GBLTU160
V02(XMP)
4GB
(2x2GB)
6GB
(3x2GB)
2GB
4GB
16GB
(2x8GB)
8GB
(2x4GB)
8GB
(2x4GB)
12GB
(3x4GB)
4GB
4GB
2GB
4GB
DS
DS
DS
DS
DS
DS
DS
DS
DS
SS
DS
DS
DS
DS
SS
DS
SS
DS
DS
DS
-
-
-
-
-
-
-
-
-
AMD
AMD
-
-
MICRON
-
MICRON
-
-
-
-
-
D9PFJ
-
D9PFJ
-
-
-
-
-
-
23EY4587MB6H
23EY4587MB6H
9
9
9
9
-
-
-
1.5
1.65
1.65
1.65
-
-
-
6-8-6-24 1.65
6-8-6-24 1.65
-
-
-
1.5
1.5
1.65
9-9-9-24 1.65
7-7-7-20 1.7
8-9-8-24 1.65
8-9-8-24 1.65
Hynix
ELPIDA
S-POWER
H5TQ2G83BFRPBC
J2108BDBG-GN-F
20YT5NG
S-POWER 20YT5NG
-
-
9-11-
11-28
9-9-9-24
-
1.5
1.5
1.5
(continued on the next page)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
ASUS M5A97 EVO R2.0
1-17
1-18
DDR3 1600 MHz capability
Vendors Part No.
Size
Team
Team
Team
Team
TED34096M1600HC11 4GB
1GB
TXD32048M1600
HC8-D(XMP)
Team
Transcend
Transcend
Transcend
Transcend
JM1600 KLN-8GK
TS256ML K64V6N
TS512ML K64V6N
TS512ML K64V6N
2GB
2GB
4GB
2GB
4GB
4GB
DS
DS
SS
DS
DS
Chip Brand
DS
SS
Team
Team
DS Team
DS Team
Hynix
Transcend
Transcend
MICRON
Transcend
Chip NO.
T3D2568ET-16
T3D1288RT-16
T3D1288LT-16
T3D1288RT-16
Timing
-
8-8-8-24
-
Voltage
1.65
•
•
2 socket
(Optional)
4
•
7-7-7-24
8-8-8-24
1.65
1.65
•
•
•
• H5TC2G83BFRH9A
TK483PCW3
K4B2G0846C
D9PFJ
K4B2G0846C
-
-
-
-
9-9-9-24 1.5
-
-
-
•
•
•
•
• •
•
DDR3 1333 MHz capability
Vendors Part No.
ACTICA
A-DATA
A-DATA
A-DATA
A-DATA
A-DATA
ACTICA
ACTICA
ACTICA
ACTICA
ACTICA
ACTICA
ACTICA
A-DATA
ACT1GHU64B8F1333S
ACT1GHU72C8G1333S
ACT2GHU64B8G1333M
ACT2GHU64B8G1333S
ACT2GHU72D8G1333M
ACT2GHU72D8G1333S
ACT4GHU64B8H1333H
ACT4GHU72D8H1333H
AD63I1B0823EV
AD63I1C1624EV
AM2U139C2P1
AM2U139C4P2
AXDU1333GC2G9(XMP)
2GB
4GB
2GB
4GB
2GB
4GB
1GB
1GB
2GB
2GB
2GB
2GB
4GB
SS
DS
SS
DS
SS
DS
SS
SS
DS
DS
DS
DS
DS
SU3U1333W8G9(XMP) 8GB DS
Size SS/
DS
Chip Brand Chip NO.
Hynix
A-DATA
A-DATA
-
A-DATA
A-DATA
SAMSUNG
SAMSUNG
Micron
SAMSUNG
Micron
SAMSUNG
Hynix
ELPIDA
K4B1G0846F
K4B1G0846F(ECC)
D9KPT
K4B1G0846F
D9KPT(ECC)
K4B1G0846F(ECC)
H5TQ2G83AFR
H5TQ2G83AFR(ECC)
3CCA-1509A
3CCA-1509A
-
3CCD-1509A
3CCD-1509A
J4208BASE-DJ-F -
-
-
-
-
-
-
-
-
-
-
-
-
Timing Voltage
-
-
-
-
-
-
1.25~1.35
-
-
-
-
-
-
-
•
•
•
•
•
•
•
•
•
•
•
•
•
DIMM socket support
(Optional)
2 4
•
•
•
•
•
•
•
•
•
•
•
•
•
(continued on the next page)
Chapter 1: Product introduction
DDR3 1333 MHz capability
Vendors
AMD
AMD
Apacer
Apacer
Asint
Part No.
AE32G1339U1-U
AE34G1339U2-U
78.A1GC6.9L1
78.B1GDE.9L10C
Size
2GB
4GB
2GB
4GB
2GB
SS/
DS
SS
DS
DS
DS
SS
Asint
ATP
BUFFALO
BUFFALO
BUFFALO
CORSAIR
CORSAIR
EK
Memory
Elixir
SLZ302G08-
EDJ1C
AQ12M72E8BKH9S
D3U1333-1G
D3U1333-2G
D3U1333-4G
CMX8GX3M2
A1333C9(XMP)
TW3X4G1333 C9A
EKM324L28B
P8-I13
4GB
4GB
1GB
2GB
4GB
8GB (2x4GB)
4GB (2x2GB)
4GB (2x2GB)
2GB
DS
DS
SS
DS
DS
DS
DS
DS
SS
Elixir
Elixir
M2F2G64CB88
G7N-CG
M2F4G64CB8H
D5N-CG
2GB
4GB
SS
DS
ELPIDA
G.SKILL
4GB DS
4GB (2x2GB) DS
G.SKILL
G.SKILL
F3-10666C L7D-
8GBRH(XMP)
F3-10666C L8D-
4GBHK(XMP)
8GB (2x4GB) DS
4GB (2x2GB) DS
G.SKILL
G.SKILL
G.SKILL
F3-10666C L9D-
8GBXL
8GB (2x4GB) DS
8GB (2x4GB) DS
8GB (2x4GB) DS
Chip
Brand
AMD
AMD
Apacer
Apacer
ASint
Chip NO.
23EY4587MB3H
23EY4587MB3H
AM5D5808FEQSBG
AM5D5908CEHSBG
302G08-DJ1C
-
-
9
-
9
-
-
-
Elixir
Elxir
Elixir
-
-
ELPIDA
G.SKILL
-
-
ASint 302G08-DJ1C
SAMSUNG
Elpida
Elpida
-
NANYA
K4B2G0846C(ECC)
J1108BFBG-DJ-F
J1108BFBG-DJ-F
-
NT5CB256M8BN-CG
-
-
-
-
-
9-9-9-24
-
-
-
-
1.5
9-9-9-24
9 -
1.5
-
-
-
-
-
M2CB2G80DN-CG
N2CB2G80GN-CG
M2CB2G80DN-CG
J2108BCSE-DJ-F
D3 128M8CE9 2GB
-
-
-
-
9-9-9-24 1.5
7-7-7-21 1.5
8-8-8-21 1.5
-
-
-
9-9-9-24 1.5
9-9-9-24 1.5
9-9-9-24 1.5
Timing
-
-
1.5
-
1.5
Voltage
•
•
•
2
•
•
DIMM socket support
(Optional)
•
4
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
(continued on the next page)
ASUS M5A97 EVO R2.0
1-19
1-20
DDR3 1333 MHz capability
Vendors Part No.
Size
GEIL
GEIL
GEIL
GEIL
GEIL
GB34GB1333C7DC
GET316GB1333C9QC
GG34GB1333C9DC
16GB
(4x4GB )
4GB
(2x2GB )
GG34GB1333C9DC
GVP34GB1333C9DC
GEIL
GEIL
GVP38GB1333C7QC
GVP38GB1333C9DC
Hynix
Hynix
INNODISK
HMT125U6TFR8A-H9
HMT325U6BFR8C-H9
M3UN-2GHJBC09
8GB
(4x2GB )
8GB
(2x4GB )
2GB
2GB
2GB
INNODISK M3UN-4GHJAC09
KINGMAX
KINGMAX
KINGMAX
FLFD45F-B8KL9
FLFE85F-B8KL9
FLFE85F-C8KL9
4GB
1GB
2GB
2GB
KINGMAX
KINGMAX
KINGMAX
KINGMAX
FLFE85F-C8KL9
FLFE85F-C8KM9
FLFF65F-C8KL9
FLFF65F-C8KL9
KINGMAX FLFF65F-C8KM9
2GB
2GB
4GB
4GB
4GB
SS/
DS
Chip
Brand
Chip NO.
DS GEIL
DS
DS
-
GEIL
-
GL1L128M88BA
115FW
9-9-9-
24
9-9-9-
24
DS GEIL
DS
DS
DS
DS
SS
SS
-
-
-
Hynix
Hynix
Hynix
-
-
-
H5TC1G83TFR
H5TQ2G83BFR
H5TQ2G83CFR
H9C
DS Hynix
DS
SS
SS
SS
SS KINGMAX
KINGMAX
KINGMAX
KINGMAX
KFB8FNLXL-BNF
-15A
KFC8FNLBF-GXX
-12A
-
-
-
Kingmax
-
-
7-7-7-
24
9-9-9-
24
-
-
9-9-9-
24
DS
DS
DS
KINGMAX
KINGMAX
Kingmax
KFC8FNLBF-GXX
-12A
KFC8FNLXF-DXX
-15A
-
-
-
Timing
1.5
1.3
Voltage
1.5
•
2
DIMM socket
(Optional)
•
4
•
• •
•
-
-
-
-
-
-
-
-
-
-
-
-
1.5
1.5
1.3
1.5
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
(continued on the next page)
Chapter 1: Product introduction
DDR3 1333 MHz capability
Vendors Part No.
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KVR1333D3E9S/4G
KVR1333D3N9/2G
KVR1333D3N9/2G
KVR1333D3N9H/8G
KINGSTON KVR1333D3N9K2/4G
Size
4GB
2GB
2GB
8GB
4GB
(2x2GB )
2GB
2GB
DS
SS
DS
DS
DS
DS
DS
Chip Brand Chip NO.
Elpida
Kingston
Elpida
ELPIDA
KINGSTON
J2108ECSE-DJ-F
D1288JPNDPLD9U
J1108BDBG-DJ-F
J4208EASE-DJ-F
D1288JEMFPGD9U
Timing
9
-
9
-
9-9-9-
24
KINGSTON
KINGTIGER
KVR1333D3S8N9/2G
F10DA2T1680
KINGTIGER
Mach
Xtreme
KTG2G1333PG3
MXD3U133316GQ
MXD3V13332GS
MICRON
MICRON
OCZ
OCZ
Patriot
Patriot
Patriot
Patriot
RiDATA
RiDATA
SAMSUNG
SAMSUNG
MT16JTF1G64AZ-
1G4D1
MT8JTF25664AZ-1G4M1
OCZ3G1333LV8GK
8GB
OCZ3RPR1333C9LV8GK
PG38G1333EL(XMP)
PGD316G1333ELK(XMP)
2GB
8GB
(2x4GB)
8GB
(2x4GB)
8GB
16GB
(2x8GB)
PGS34G1333LLKA
PSD32G13332
C304627CB1AG22Fe
E304459CB1AG32Cf
M378B1G73AH0-CH9
M378B5273CH0-CH9
2GB
16GB
(4x4GB )
2GB
DS
DS
SS
DS
SS
DS
DS
DS
DS
DS
SAMSUNG
SAMSUNG
SAMSUNG
M378B5273DH0-CH9
M378B5673FH0-CH9
M378B5773DH0-CH9
-
-
-
-
-
Micron
KINGTIGER
-
-
IFD77 D9LGK
KTG1333PS120
8NST-C9
-
MICRON
-
MICRON
-
-
-
C2S46D30-D313
D9PCP
-
-
D9PFJ
-
-
-
-
-
-
-
9-9-9
9-9-9
-
9-9-9-
24
2GB
2GB
4GB
8GB
4GB
4GB
2GB
2GB
DS
DS
DS
DS
DS
DS
DS
SS
Prtriot
RiDATA
RiDATA
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
PM128M8D3BU-15
C304627CB1AG22Fe
E304459CB1AG32Cf
K4B4G0846A-HCH9
K4B2G0846C
K4B2G08460
K4B1G0846F
K4B2G08460
(continued on the next page)
9
9
-
-
-
9
-
K4B2G
0846C
-
-
-
-
-
-
-
-
-
-
-
-
-
1.5
-
1.65
1.65
1.5
1.5
1.7
1.5
1.5
1.5
1.5
Voltage
•
•
•
•
2 socket
(Optional)
•
4
•
•
•
1.5
• •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
ASUS M5A97 EVO R2.0
1-21
1-22
DDR3 1333 MHz capability
Vendors Part No.
Silicon Power SP001GBLTE
133S01
Silicon Power
Silicon Power
Silicon Power
Team
SP004GBLTU
133V02
TED34096M
1333HC9
Team
Team
Team
Transcend
Transcend
Transcend
Transcend
Transcend
Transcend
TXD32048M
1333C7-D(XMP)
JM1333KLN -2G
JM1333KLN
-2G(582670)
JM1333KLN -4G
JM1333KLN
-4G(583782 )
TS1GLK64V3H
TS256MLK64V3N
(585541 )
Transcend
Transcend
Transcend
Transcend
TS256MLK64
V3NL
TS512MLK64V3N
(585538 )
Transcend
Transcend TS512MLK64
V3NL
Size
1GB
1GB SS
2GB DS
4GB
4GB
1GB SS
1GB SS
2GB DS
2GB
2GB
SS
SS
Team
Team
T3D1288LT-13
T3D1288LT-13
Team T3D1288LT-13
Transcend
Micron
TK483PCW3
ICD77 C9LGK
4GB
4GB
8GB
2GB
2GB
2GB
2GB
4GB
4GB
4GB
SS/
DS
SS
DS
DS
DS
DS
DS
SS
SS
SS
SS
DS
DS
DS
Chip
Brand
NANYA
NANYA
S-
POWER
Team
Transcend
Transcend
MICRON
Micron
Hynix
Micron
Hynix
Micron
Micron
Hynix
Chip NO.
NT5CB128
M8AN-CG
10YT3E5
20YT3NG
T3D2568LT-13
TK483PCW3
TK483PCW3
D9PBC
ICD77 D9LGK
H5TQ2G83BFR 9
D9LGK
H5TQ2G83C
FRH9C
IED27 D9LGK
-
9
9
D9LGK
H5TQ2G83C
FRH9C
-
9
-
9
-
9
-
Timing
-
Voltage DIMM socket support
(Optional)
•
2
•
4
-
9
-
9-9-9-
24
-
-
-
-
•
•
•
• •
•
•
-
-
7-7-7-
21
-
-
-
-
-
-
-
-
-
-
-
-
1.75
1.75
1.5-1.6
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Chapter 1: Product introduction
Side(s): SS - Single-sided DS - Double-sided DIMM support:
(1) Supports one (1) module inserted into any slot as Single-channel memory configuration. We suggest that you install the module into A2 slot.
(2) Supports two (2) modules inserted into either the blue slots or the black slots as one pair of Dual-channel memory configuration. We suggest that you install the modules into slots A2 and B2 for better compatibility.
(4) Supports four (4) modules inserted into both the blue and black slots as two pairs of
Dual-channel memory configuration.
• When overclocking, some AMD CPU models may not support DDR3 1600 or higher frequency DIMMS.
• Visit the ASUS website for the latest QVL.
ASUS M5A97 EVO R2.0
1-23
1.2.5 Expansion slots
Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.
1-24
3
4
5
6
Slot No. Slot Description
1 PCIe 2.0 x16_1 slot (at x16 mode)
2
PCIe 2.0 x1_1 slot
PCIe 2.0 x1_2 slot
PCIe 2.0 x16_2 slot (at x4 mode)
PCI slot 1
PCI slot 2
VGA configuration
Single VGA/PCIe card
Dual VGA/PCIe card
PCI Express operating mode
PCIe 2.0 x16_1 PCIe 2.0 x16_2
x16 (Recommend for single VGA) x16 x4 x4
Chapter 1: Product introduction
• In single VGA card mode, use the PCIe 2.0 x16_1 slot (navy blue) for a PCI Express x16 graphics card to get better performance.
• In CrossFireX™ mode, use the PCIe 2.0 x16_1 and PCIe 2.0 x16_2 slots for PCI
Express x16 graphics cards to get better performance.
• We recommend that you provide sufficient power when running CrossFireX™ mode.
• Connect a chassis fan to the motherboard connector labeled CHA_FAN1/2/3 when using multiple graphics cards for better thermal environment.
IRQ assignments for this motherboard
Gigabit LAN eSATA6G Controller 0 eSATA6G Controller 1
USB 3.0 (Front)
USB 3.0 (Rear)
Onchip SATA Controller –
–
–
–
–
A
–
–
–
Onchip USB1
Onchip USB2
HD Audio
PCIe_x16_1
PCIe_x16_2
PCIe_x1_1
PCIe_x1_2
PCI Slot1 shared shared
–
– shared
–
PCI Slot2 –
–
–
–
–
–
–
–
–
–
B
–
–
–
– – –
– shared –
–
–
–
–
C
–
D E F
– shared –
– shared –
– shared –
– shared –
–
–
–
–
–
–
–
–
–
–
– shared
–
– –
–
–
– shared
–
–
–
G
–
–
–
–
–
H
–
– shared –
–
–
–
– shared –
–
–
–
–
–
–
–
– shared
–
–
–
–
–
–
–
–
–
–
–
– shared
–
–
–
–
– – – – shared – –
ASUS M5A97 EVO R2.0
1-25
1.2.6 Onboard buttons and switches
Onboard switches and buttons allow you to fine-tune performance when working on a bare or open-case system. This is ideal for overclockers and gamers who continually change settings to enhance system performance.
1. DirectKey button (DirectKey)
This feature allows your system to go to the BIOS Setup program with the press of a button. With DirectKey, you can enter the BIOS anytime without having to press the <Del> key during POST. It also allows you to turn on or turn off your system and conveniently enter the BIOS during boot-up.
1-26
Ensure to save your data before using the DirectKey button.
• When the system is on and you press the DirectKey button, your system will shut down. Press the DirectKey button again or the Power-on button to reboot and enter the BIOS directly.
• Turn off your system using the power-on button to allow your system to go through
POST (without entering the BIOS) when you reboot your system.
• Refer to section 3.7 Boot Menu for details about setting the DirectKey default function.
Chapter 1: Product introduction
2. MemOK! button
Installing DIMMs that are not compatible with the motherboard may cause system boot failure, and the DRAM_LED near the MemOK! switch lights continuously. Press and hold the MemOK! button until the DRAM_LED starts blinking to begin automatic memory compatibility tuning for successful boot.
• Refer to section
• The DRAM_LED also lights up when the DIMM is not properly installed. Turn off the system and reinstall the DIMM before using the MemOK! function.
• The MemOK! switch does not function under Windows™ OS environment.
• During the tuning process, the system loads and tests failsafe memory settings. It takes about 30 seconds for the system to test one set of failsafe settings. If the test fails, the system reboots and test the next set of failsafe settings. The blinking speed of the DRAM_LED increases, indicating different test processes.
• Due to memory tuning requirement, the system automatically reboots when each timing set is tested. If the installed DIMMs still fail to boot after the whole tuning process, the DRAM_LED lights continuously. Replace the DIMMs with ones recommended in the Memory QVL (Qualified Vendors Lists) in this user manual or on the ASUS website at www.asus.com.
• If you turn off the computer and replace DIMMs during the tuning process, the system continues memory tuning after turning on the computer. To stop memory tuning, turn off the computer and unplug the power cord for about 5–10 seconds.
• If your system fails to boot up due to BIOS overclocking, press the MemOK! switch to boot and load the BIOS default settings. A message will appear during POST reminding you that the BIOS has been restored to its default settings.
• We recommend that you download and update to the latest BIOS version from the
ASUS website at www.asus.com after using the MemOK! function.
ASUS M5A97 EVO R2.0
1-27
3. USB BIOS Flashback button
USB BIOS Flashback button allows you to easily update the BIOS without entering the
BIOS or operating system. Just connect the USB storage USB device containing the
BIOS file to the USB port, press the BIOS Flashback button, and the BIOS is updated automatically.
For more details about the USB BIOS Flashback button, refer to section 2.2.1 USB BIOS
Flashback.
4. EPU switch
This switch allows you to enable or disable the EPU function.
1-28
• The EPU LED (O2LED3) near the EPU switch lights when the switch setting is enabled. Refer to section 1.2.8 Onboard LEDs for the exact location of the EPU LED.
• If you change the switch setting to Enable under the OS environment, the EPU function will be activated after the next system bootup.
• You may change the EPU settings in the software application or BIOS setup program, and enable the EPU function at the same time. However, the system will use the last setting you have made.
Chapter 1: Product introduction
5. TPU switch
This switch allows you to enable or disable the TPU function.
• The TPU LED (O2LED2) near the TPU switch lights when the switch setting is enabled. Refer to section 1.2.8 Onboard LEDs for the exact location of the TPU LED.
• If you change the switch setting to Enable under the OS environment, the TPU function will be activated after the next system bootup.
• You may use the TurboV and Auto Tuning feature in the TurboV EVO application, adjust the BIOS setup program, or enable the TPU switch at the same time. However, the system will use the last setting you have made.
ASUS M5A97 EVO R2.0
1-29
1.2.7 Jumper
1. Clear RTC RAM (3-pin CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as system passwords.
1-30
To erase the RTC RAM
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5–10 seconds, then move the cap back to pins 1-2.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup to reenter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure!
• If the steps above DO NOT help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery.
• You DO NOT need to clear the RTC when the system hangs due to overclocking. For system failure due to overclocking, use the C.P.R. (CPU Parameter Recall) feature.
Shut down and reboot the system so the BIOS can automatically reset parameter settings to default values.
• Due to the chipset behavior, AC power off is required to enable C.P.R. function. You must turn off and on the power supply or unplug and plug the power cord before rebooting the system.
Chapter 1: Product introduction
1.2.8 Onboard LEDs
1. Standby Power LED
The motherboard comes with a standby power LED. The green LED lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED.
2. POST State LEDs
The POST State LEDs provide the status of these key components during POST
(Power-On-Self Test): CPU, memory modules, VGA card, and hard disk drive.s If an error is found, the critical component’s LED stays lit up until the problem is solved.
ASUS M5A97 EVO R2.0
1-31
3. BIOS Flashback LED (FLBK_LED)
The FLBK LED lights when the USB Flashback button is pressed for three seconds.
4. TPU LED (O2LED2)
The TPU LED lights when the TPU switch is switched to Enable.
1-32 Chapter 1: Product introduction
5. EPU LED (O2LED3)
The EPU LED lights when the EPU switch is switched to Enable.
ASUS M5A97 EVO R2.0
1-33
1.2.9 Internal connectors
1. AMD
®
Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6 [gray])
These connectors are for the Serial ATA 6.0 Gb/s signal cables for Serial ATA hard disk drives and optical disc drives.
If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 5, or RAID 10 configuration through the onboard AMD
®
SB950 controller.
1-34
• These connectors are set to [AHCI Mode] by default. If you intend to create a Serial
ATA RAID set using these connectors, set the SATA Mode item in the BIOS to [RAID
Mode]. Refer to section 3.5.4 SATA Configuration for details.
• Before creating a RAID set, refer to section 5.1 RAID configurations or the manual bundled in the motherboard support DVD.
• When creating a RAID set, set the SATA_5-6 connectors to [IDE Mode] to ensure that the system recognizes your ODD device.
• When using NCQ, set the SATA Mode in the BIOS to [AHCI Mode]. Refer to section
3.5.4 SATA Configuration for details.
• You must install Windows
ATA hard disk drives. The Serial ATA RAID feature is available only if you are using
Windows
®
®
XP Service Pack 3 or later versions before using Serial
XP SP3 or later versions.
Chapter 1: Product introduction
2. USB 3.0 connector (20-1 pin USB3_34)
This connector is for the additional USB 3.0 ports, and complies with the USB 3.0 specificaton that supports up to 5.0 Gbps connection speed. If the USB 3.0 front panel cable is available from your system chassis, with this USB 3.0 connector, you can have a front panel USB 3.0 solution.
• You can connect the ASUS front panel USB 3.0 box to this connector to obtain the front panel USB 3.0 solution.
• The USB 3.0 module is purchased separately.
ASUS M5A97 EVO R2.0
1-35
1-36
3. USB 2.0 connectors (10-1 pin USB910; USB1112; USB1314)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that supports up to
480 Mbps connection speed.
Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
You can connect the front panel USB cable to the ASUS Q-Connector (USB, blue) first, and then install the Q-Connector (USB) to the USB connector onboard if your chassis supports front panel USB ports.
The USB 2.0 module is purchased separately.
Chapter 1: Product introduction
4. IEEE 1394a port connector (10-1 pin IE1394_2)
This connector is for an IEEE 1394a port. Connect the IEEE 1394a module cable to this connector, then install the module to a slot opening at the back of the system chassis.
Never connect a USB cable to the IEEE 1394a connector. Doing so will damage the motherboard!
The IEEE 1394 bracket is purchased separately.
5. Digital audio connector (4-1 pin SPDIF_OUT)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this connector, then install the module to a slot opening at the back of the system chassis.
The S/PDIF module is purchased separately.
ASUS M5A97 EVO R2.0
1-37
6. CPU and chassis fan connectors (4-pin CPU_FAN; CHA_FAN1/2/3)
Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector.
1-38
DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! DO NOT place jumper caps on the fan connectors!
• The CPU_FAN connector supports the CPU fan of maximum 1A (12 W) fan power.
• Only the CPU_FAN, CHA_FAN1, CHA_FAN2 and CHA_FAN3 connectors support the
ASUS FAN Xpert feature.
• If you install two VGA cards, we recommend that you plug the rear chassis fan cable to the motherboard connector labeled CHA_FAN1, CHA_FAN2 or CHA_FAN3 for better thermal environment.
Chapter 1: Product introduction
7. Front panel audio connector (10-1 pin AAFP)
This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC`97 audio standard. Connect one end of the front panel audio I/O module cable to this connector.
• We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability.
• If you want to connect a high-definition front panel audio module to this connector, set the Azalia Front Panel item in the BIOS setup to [HD]; if you want to connect an
AC'97 front panel audio module to this connector, set the item to [AC97]. By default, this connector is set to [HD].
8. Serial port connector (10-1 pin COM1)
This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis.
The COM module is purchased separately.
ASUS M5A97 EVO R2.0
1-39
1-40
9. ATX power connectors (24-pin EATXPWR; 8-pin EATX12V)
These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit.
• For a fully configured system, we recommend that you use a power supply unit
(PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 450 W.
• DO NOT forget to connect the 8-pin EATX12 V power plug; otherwise, the system will not boot.
• We recommend that you use a PSU with higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate.
• If you are uncertain about the minimum power supply requirement for your system, refer to the Recommended Power Supply Wattage Calculator at http://support.asus.
com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details.
• If you want to use two high-end PCI Express x16 cards, use a PSU with 1000W power or above to ensure the system stability.
Chapter 1: Product introduction
10. System panel connector (20-8 pin PANEL)
This connector supports several chassis-mounted functions.
•
•
•
•
•
System power LED (2-pin PLED)
This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
Hard disk drive activity LED (2-pin IDE_LED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The IDE LED lights up or flashes when data is read from or written to the HDD.
System warning speaker (4-pin SPEAKER)
This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.
ATX power button/soft-off button (2-pin PWRSW)
This connector is for the system power button. Pressing the power button turns the system on or puts the system in sleep or soft-off mode depending on the BIOS settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF.
Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power.
ASUS M5A97 EVO R2.0
1-41
11. TPM connector (20-1 pin TPM)
This connector supports a Trusted Platform Module (TPM) system, which securely store keys, digital certificates, passwords and data. A TPM system also helps enhance network security, protect digital identities, and ensures platform integrity.
TPM module is purchased separately.
12. Direct connector (2-pin DRCT)
This connector is for the chassis-mounted button that supports the DirectKey function.
Connect the button cable that supports DirectKey, from the chassis to this connector on the motherboard.
1-42
Ensure that your chassis comes with the button cable that supports the DirectKey feature.
Refer to the technical documentation that came with the chassis for details.
Chapter 1: Product introduction
Basic Installation
2.1 Building your PC system
2
2.1.1 Motherboard installation
The diagrams in this section are for reference only. The motherboard layout may vary with models, but the installation steps are the same for all models.
1. Install the ASUS I/O Shield to the chassis rear I/O panel.
ASUS M5A97 EVO R2.0
2-1
2. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’ rear I/O panel.
2-2
Chapter 2: Basic installation
3. Place nine screws into the holes indicated by circles to secure the motherboard to the chassis.
DO NOT overtighten the screws! Doing so can damage the motherboard.
ASUS M5A97 EVO R2.0
2-3
2.1.2 CPU installation
The AMD AM3+ socket is compatible with AMD AM3+ and AM3 processors. Ensure you use a CPU designed for the AM3+ socket. The CPU fits in only one correct orientation. DO
NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU!
1 2
3
2-4
Chapter 2: Basic installation
2.1.3 CPU heatsink and fan assembly installation
Apply the Thermal Interface Material to the
CPU heatsink and CPU before you install the heatsink and fan if necessary.
To install the CPU heatsink and fan assembly
1
ASUS M5A97 EVO R2.0
2-5
2-6
2
3
4
5
Chapter 2: Basic installation
2.1.4 DIMM installation
1
2
3
To remove a DIMM
B
A
ASUS M5A97 EVO R2.0
2-7
2.1.5 ATX Power connection
1
2
OR OR
2-8
Chapter 2: Basic installation
2.1.6 SATA device connection
1
OR
2
OR
ASUS M5A97 EVO R2.0
2-9
2.1.7 Front I/O Connector
To install ASUS Q-Connector
1
2
IDE_LED+
IDE_LED-
IDE_LED
PWR
Ground
Reset
Ground
POWER SW
RESET SW
To install USB 2.0 connector To install front panel audio connector
AAFP
2-10
USB 2.0
To install USB 3.0 connector
USB 3.0
Chapter 2: Basic installation
2.1.8 Expansion Card installation
To install PCIe x16 cards
To install PCIe x1 cards To install PCI cards
ASUS M5A97 EVO R2.0
2-11
2.2 BIOS update utility
2.2.1 USB BIOS Flashback
USB BIOS Flashback allows you to easily update the BIOS without entering the existing
BIOS or operating system. Simply insert a USB storage device to the USB port, press the
USB BIOS Flashback button for three seconds, and the BIOS is updated automatically.
To use USB BIOS Flashback:
1. Place the bundled support DVD to the optical drive and install the USB BIOS
Flashback Wizard. Follow the onscreen instructions to complete the installation.
You can also download the BIOS from the ASUS official website (www.asus.com). Rename the file as M5A97E20.CAP, save it to a USB portable device, and place it in the root directory.
2. Insert the USB storage device to the USB BIOS Flashback port.
3. Launch the USB BIOS Flashback Wizard to automatically download the latest BIOS version.
4. Press the USB BIOS Flashback button for three seconds until a flashing light appears, which indicates that the BIOS Flashback function is enabled.
5. Wait until the light goes out, indicating that the BIOS updating process is completed.
2-12
USB BIOS Flashback port
For more BIOS update utilities in BIOS setup, refer to the section 3.10 Updating BIOS.
• Do not unplug portable disk, power system, or press the CLR_CMOS button while
BIOS update is ongoing, otherwise update will be interrupted. In case of interruption, please follow the steps again.
• If the light flashes for five seconds and turns into a solid light, this means that the
BIOS Flashback is not operating properly. This may be caused by improper installation of the USB storage device and filename/file format error. If this scenario happens, please restart the system to turn off the light.
• Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service
Center.
Chapter 2: Basic installation
2.3 Motherboard rear and audio connections
2.3.1 Rear I/O connection
Rear panel connectors
1. PS/2 keyboard/mouse combo port
2. IEEE 1394a port
3. USB 2.0 ports 3 and 4
4. USB 2.0 ports 5 and 6
5. LAN (RJ-45) port
6. USB 2.0 ports 1 and 2
7. Optical S/PDIF Out port
8. USB 3.0 ports 1 and 2
9. External SATA 6Gb/s port 1
10. External SATA 6Gb/s port 2
11. USB 2.0 ports 7 and 8
12. Audio I/O ports*
*: Refer to the tables on the next page for LAN port LEDs, and audio port definitions.
ASUS M5A97 EVO R2.0
2-13
2-14
• Press the Clear CMOS switch to clear BIOS setup information only when the system hangs due to overclocking.
• DO NOT insert a different connector to the external SATA port.
• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under
Windows
®
OS environment and after the USB 3.0 driver installation.
• USB 3.0 devices can only be used as data storage only.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster and better performance for your USB 3.0 devices.
* LAN ports LED indications
Activity Link LED
Status Description
OFF
ORANGE
BLINKING
No link
Linked
Data activity
Speed LED
Status
OFF
Description
10 Mbps connection
ORANGE 100 Mbps connection
GREEN 1 Gbps connection
LAN port
** Audio 2, 4, 6, or 8-channel configuration
Port Headset
2-channel
Light Blue Line In
Lime Line Out
Pink
Orange
Black
Gray
Mic In
–
–
–
4-channel 6-channel 8-channel
Line In Line In Line In
Front Speaker Out Front Speaker Out Front Speaker Out
Mic In
–
Mic In
Center/Subwoofer
Mic In
Center/Subwoofer
Rear Speaker Out Rear Speaker Out Rear Speaker Out
– – Side Speaker Out
Chapter 2: Basic installation
2.3.2 Audio I/O connections
Audio I/O ports
Connect to Headphone and Mic
Connect to Stereo Speakers
ASUS M5A97 EVO R2.0
2-15
2-16
Connect to 2.1 channel Speakers
Connect to 4.1 channel Speakers
Connect to 5.1 channel Speakers
Chapter 2: Basic installation
Connect to 7.1 channel Speakers
When the DTS UltraPC II and DTS Connect functions are enabled, ensure to connect the rear speaker to the gray port.
ASUS M5A97 EVO R2.0
2-17
2-18
2.4 Starting up for the first time
1. After making all the connections, replace the system case cover.
2. Ensure that all switches are off.
3. Connect the power cord to the power connector at the back of the system chassis.
4. Connect the power cord to a power outlet that is equipped with a surge protector.
5. Turn on the devices in the following order: a. Monitor b. External SCSI devices (starting with the last device on the chain) c. System power
6. After applying power, the system power LED on the system front panel case lights up.
For systems with ATX power supplies, the system LED lights up when you press the
ATX power button. If your monitor complies with the “green” standards or if it has a
“power standby” feature, the monitor LED may light up or change from orange to green after the system LED turns on.
The system then runs the power-on self tests (POST). While the tests are running, the
BIOS beeps (refer to the BIOS beep codes table) or additional messages appear on the screen. If you DO NOT see anything within 30 seconds from the time you turned on the power, the system may have failed a power-on test. Check the jumper settings and connections or call your retailer for assistance.
BIOS Beep
One short beep
Description
VGA detected
Quick boot set to disabled
No keyboard detected
No memory detected One continuous beep followed by two short beeps then a pause (repeated)
One continuous beep followed by three short beeps
One continuous beep followed by four short beeps
No VGA detected
Hardware component failure
7. At power on, hold down the <Delete> key to enter the BIOS Setup. Follow the instructions in Chapter 3.
2.5 Turning off the computer
While the system is ON, press the power button for less than four seconds to put the system on sleep mode or soft-off mode, depending on the BIOS setting. Press the power switch for more than four seconds to let the system enter the soft-off mode regardless of the BIOS setting.
Chapter 2: Basic installation
BIOS setup
3.1 Knowing BIOS
3
The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboardonly BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system. The term “BIOS” in this user manual refers to “UEFI BIOS” unless otherwise specified.
•
•
BIOS (Basic Input and Output System) stores system hardware settings such as storage device configuration, overclocking settings, advanced power management, and boot device configuration that are needed for system startup in the motherboard CMOS. In normal circumstances, the default BIOS settings apply to most conditions to ensure optimal performance. DO NOT change the default BIOS settings except in the following circumstances:
An error message appears on the screen during the system bootup and requests you to run the BIOS Setup.
You have installed a new system component that requires further BIOS settings or update.
Inappropriate BIOS settings may result to instability or boot failure. We strongly
recommend that you change the BIOS settings only with the help of a trained service personnel.
When downloading or updating the BIOS file, rename it as M5A97E20.CAP for this motherboard.
ASUS M5A97 EVO R2.0
3-1
3-2
3.2 BIOS setup program
Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screen include navigation keys and brief onscreen help to guide you in using the BIOS Setup program.
Entering BIOS at startup
To enter BIOS Setup at startup:
• Press <Delete> during the Power-On Self Test (POST). If you DO NOT press
<Delete>, POST continues with its routines.
•
•
Entering BIOS Setup after POST
To enter BIOS Setup after POST:
• Press <Ctrl>+<Alt>+<Delete> simultaneously.
Press the reset button on the system chassis.
Press the power button to turn the system off then back on. Do this option only if you failed to enter BIOS Setup using the first two options.
• The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen.
• Ensure that a USB mouse is connected to your motherboard if you want to use the mouse to control the BIOS setup program.
• If the system becomes unstable after changing any BIOS setting, load the default settings to ensure system compatibility and stability. Select the Load Optimized
Defaults item under the Exit menu or press hotkey <F5>. See section 3.9 Exit Menu for details.
• If the system fails to boot after changing any BIOS setting, try to clear the CMOS and reset the motherboard to the default value. See section 1.2.7 Jumper for information on how to erase the RTC RAM via the Clear CMOS button.
• The BIOS setup program does not support the bluetooth devices.
BIOS menu screen
The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.
You can change modes from the Exit menu or from the Exit/Advanced Mode screen.
Chapter 3: BIOS setup
3.2.1 EZ Mode
By default, the EZ Mode screen appears when you enter the BIOS setup program. The EZ
Mode provides you an overview of the basic system information, and allows you to select the display language, system performance mode and boot device priority. To access the
Advanced Mode, click Exit/Advanced Mode, then select Advanced Mode or press <F7> hot key for the advanced BIOS settings.
The default screen for entering the BIOS setup program can be changed. Refer to the
Setup Mode item in section 3.7 Boot menu for details.
UEFI BIOS Utility - EZ Mode
Monday [06/23/2012]
M5A97 EVO R2.0
BIOS Version : 0206
CPU Type : AMD Eng Sample, 2D338251W8K54_39/33/22_2/8
Total Memory : 1048 MB (DDR3 1333MHz)
Temperature
CPU +113.0ºF/+45.0ºC CPU
Voltage
MB +75.2ºF/+40.0ºC
1.344V 5V
3.3V
3.344V 12V
Exit/Advanced Mode
English
Speed : 3300 MHz
5.160V
12.248V
Fan Speed
CPU_FAN 2481RPM CHA_FAN1 N/A
CHA_FAN2 N/A CHA_FAN3 N/A
System Performance
Quiet
Performance
Boot Priority
Energy Saving
Normal
Use the mouse to drag or keyboard to navigate to decide the boot priority.
Shortcut (F3)
Advanced Mode (F7)
Selects the boot device priority
Boot Menu(F8) Default(F5)
Power Saving mode
Normal mode
ASUS Optimal mode
Selects the boot device priority
• The boot device options vary depending on the devices you installed to the system.
• The system.
ASUS M5A97 EVO R2.0
3-3
3-4
3.2.2 Advanced Mode
The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations.
To access the Advanced Mode, click Exit, then select Advanced Mode or press F7 hotkey.
Back button Menu items Menu bar
UEFI BIOS Utility - Advanced Mode
Configuration fields General help
Exit
Main
Back
Ai Tweaker Advanced Monitor Boot Tool
AMD Turbo CORE technology
Disabled/Enabled
Current CPU Speed : 3300MHz
Target CPU Speed : 330MHz
Current Memory Frequency : 1333MHz
Current NB Frequency : 220MHz
Current HT Link Speed : 2400MHz
Ai Overclock Tuner
CPU Ratio
AMD Turbo Core Technology
Memory Frequency
CPU/NB Frequency
HT Link Speed
AMD Turbo CORE technology
Auto
Auto
Disabled
Enabled
Auto
Auto
Auto
Auto
Auto
CPU Spread Spectrum
PCIe Spread Spectrum
EPU Power Saving Mode
> OC Tuner
Auto
Auto
Disabled
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
Submenu item
Pop-up window Scroll bar
Menu bar
The menu bar on top of the screen has the following main items:
Navigation keys
Main
For changing the basic system configuration
Ai Tweaker
For changing the overclocking settings
Advanced
For changing the advanced system settings
Monitor
For displaying the system temperature, power status, and changing the fan settings.
Boot
Tool
Exit
For changing the system boot configuration
For configuring options for special functions
For selecting the exit options and loading default settings
Chapter 3: BIOS setup
Menu items
The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items.
The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items.
Back button
This button appears when entering a submenu. Press <Esc> or use the USB mouse to click this button to return to the previous menu screen.
Submenu items
A greater than sign (>) before each item on any menu screen means that the item has a submenu. To display the submenu, select the item and press <Enter>.
Pop-up window
Select a menu item and press <Enter> to display a pop-up window with the configuration options for that item.
Scroll bar
A scroll bar appears on the right side of a menu screen when there are items that DO NOT fit on the screen. Press the Up/Down arrow keys or <Page Up> / <Page Down> keys to display the other items on the screen.
Navigation keys
At the bottom right corner of the menu screen are the navigation keys for the BIOS setup program. Use the navigation keys to select items in the menu and change the settings. Use
<F12> key to capture the BIOS screen and save it to the removable storage device. Press
<F3> key for BIOS Option shortcut.
General help
At the top right corner of the menu screen is a brief description of the selected item.
Configuration fields
These fields show the values for the menu items. If an item is user-configurable, you can change the value of the field opposite the item. You cannot select an item that is not userconfigurable.
A configurable field is highlighted when selected. To change the value of a field, select it and press <Enter> to display a list of options.
ASUS M5A97 EVO R2.0
3-5
3-6
3.3 Main menu
The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup program. The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings.
UEFI BIOS Utility - Advanced Mode
Exit
Main Ai Tweaker Advanced Monitor
BIOS Information
BIOS Version
Build Date
CPU Information
AMD Eng Sample, 2D338251W8K54_39/33/22_2/8
Memory Information
Total Memory
EC Version
System Language
System Date
System Time
Access Level
> Security
0206 x64
06/18/2012
1088 MB (DDR3 1333MHz)
MBECI-0006
English
[Saturday 06/23/2012]
[16:46:15]
Administrator
Boot Tool
Choose the system default language
Security
The Security menu items allow you to change the system security settings.
UEFI BIOS Utility - Advanced Mode
Main
Back
Ai Tweaker
Main\ Security >
Password Description
If ONLY the Administrator's password is set, then this only limits access to Setup and is only asked for when entering Setup
If ONLY the User's password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights
The password must be 3 to 20 characters long.
Administrator Password
User Password
Administrator Password
User Password
Advanced Monitor
Not Installed
Not Installed
Exit
Boot Tool
To clear the administrator password, key in the current password in the
Enter Current Password box, and then press <Enter> when prompted to create/confirm the password.
• If you have forgotten your BIOS password, erase the CMOS Real Time Clock (RTC)
RAM to clear the BIOS password. See section 1.2.7 Jumper for information on how to erase the RTC RAM via the Clear CMOS button.
• The Administrator or User Password items on top of the screen show the default [Not
Installed]. After you set a password, these items show [Installed].
Chapter 3: BIOS setup
Administrator Password
If you have set an administrator password, we recommend that you enter the administrator password for accessing the system. Otherwise, you might be able to see or change only selected fields in the BIOS setup program.
To set an administrator password:
1. Select the Administrator Password item and press <Enter>.
2. From the Create New Password box, key in a password, then press <Enter>.
3. Confirm the password when prompted.
To change an administrator password:
1. Select the Administrator Password item and press <Enter>.
2. From the Enter Current Password box, key in the current password, then press
<Enter>.
3. From the Create New Password box, key in a new password, then press <Enter>.
4. Confirm the password when prompted.
To clear the administrator password, follow the same steps as in changing an administrator password, but press <Enter> when prompted to create/confirm the password. After you clear the password, the Administrator Password item on top of the screen shows Not Installed.
User Password
If you have set a user password, you must enter the user password for accessing the system.
The User Password item on top of the screen shows the default Not Installed. After you set a password, this item shows Installed.
To set a user password:
1. Select the User Password item and press <Enter>.
2. From the Create New Password box, key in a password, then press <Enter>.
3. Confirm the password when prompted.
To change a user password:
1. Select the User Password item and press <Enter>.
2. From the Enter Current Password box, key in the current password, then press
<Enter>.
3. From the Create New Password box, key in a new password, then press <Enter>.
ASUS M5A97 EVO R2.0
3-7
3-8
4. Confirm the password when prompted.
To clear the user password, follow the same steps as in changing a user password, but press
<Enter> when prompted to create/confirm the password. After you clear the password, the
User Password item on top of the screen shows Not Installed.
3.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field values can cause the system to malfunction.
The configuration options for this section vary depending on the CPU and DIMM model you installed on the motherboard.
Scroll down to display other BIOS items.
UEFI BIOS Utility - Advanced Mode
Exit
Main
Back
Ai Tweaker Advanced Monitor Boot
AMD Turbo CORE Technology
Disabled/Enabled
Tool
Current Memory Frequency : 1333MHz
Current NB Frequency : 220MHz
Current HT Link Speed : 2600MHz
Ai Overclock Tuner
CPU Ratio
AMD Turbo Core Technology
Memory Frequency
CPU/NB Frequency
HT Link Speed
CPU Spread Spectrum
PCIe Spread Spectrum
EPU Power Saving Mode
> OC Tuner
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Disabled
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
Chapter 3: BIOS setup
Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal frequency. Select any of these preset overclocking configuration options:
[Auto]
[Manual]
[D.O.C.P.]
Loads the optimal settings for the system.
Allows you to individually set overclocking parameters.
CPU Bus, CPU ratio and memory parameters will be auto optimized.
CPU Ratio [Auto]
Allows you can manually adjust the maximum non-CPB mode CPU ratio. The value will be limit to CPU base or factory setting. Use the <+> and <-> keys to adjust the ratio. The valid value ranges vary according to your CPU model.
AMD Turbo CORE technology [Auto]
Allows you to enable or disable the AMD Turbo CORE technology.
Configuration options: [Auto] [Enabled] [Disabled]
Turbo CORE Ratio [Auto]
This item appears only when you set AMD Turbo CORE technology to [Enabled]. This allows you to increase or decrease the target turbo core speed. Use the <+> and <->
Memory Frequency [Auto]
Allows you to set the memory operating frequency.
Configuration options: [Auto] [DDR3-800MHz] [DDR3-1066MHz] [DDR3-1333MHz] [DDR3-
1600MHz] [DDR3-1866MHz] [DDR3-2133MHz] [DDR3-2400MHz]
Selecting a very high memory frequency may cause the system to become unstable! If this happens, revert to the default setting.
CPU/NB Frequency [Auto]
Allows you to select the CPU/NB frequency.
Configuration options: [Auto] [1400MHz] [1600MHz] [1800MHz] [2000MHz] [2200MHz]
[2400MHz] [2600MHz] [2800MHz] [3000MHz] [3200MHz]
HT Link Speed [Auto]
Allows you to select the HyperTransport link speed.
Configuration options: [Auto] [800MHz] [1000MHz] [1200MHz] [1400MHz] [1600MHz]
[1800MHz] [2000MHz] [2200MHz] [2400MHz]
CPU Spread Spectrum [Auto]
[Auto]
[Disabled]
Automatic configuration.
Enhances CPU bus frequency overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
ASUS M5A97 EVO R2.0
3-9
3-10
PCIe Spread Spectrum [Auto]
[Auto] Automatic configuration.
[Disabled]
[Enabled]
Enhances the PCIe overclocking ability.
Sets to [Enabled] for EMI control.
EPU Power Saving Mode [Disabled]
Allows you to enable or disable the EPU power saving function.
Configuration options: [Disabled] [Enabled]
OC Tuner [CANCEL]
OC Tuner automatically overclocks the frequency and voltage of CPU and DRAM for enhancing the system performance.
Configuration options: [OK] [Cancel]
EPU Setting [Auto]
This item appears only when you set the EPU Power Saving Mode item to [Enabled] and allows you to select the EPU power saving mode.
Configuration options: [AUTO] [Light Power Saving Mode] [Medium Power Saving Mode]
[Max Power Saving Mode]
DRAM Timing Control
Primart Timings
DRAM CAS# Latency [Auto]
Configuration options: [Auto] [5 CLK] – [19 CLK]
DRAM RAS# to CAS# Delay [Auto]
Configuration options: [Auto] [2 CLK] – [19 CLK]
DRAM RAS# PRE Time [Auto]
Configuration options: [Auto] [2 CLK] – [19 CLK]
DRAM RAS# ACT Time [Auto]
Configuration options: [Auto] [8 CLK] – [40 CLK]
DRAM READ to PRE Time [Auto]
Configuration options: [Auto] [4 CLK] – [10 CLK]
DRAM RAS# to RAS# Delay [Auto]
Configuration options: [Auto] [1 CLK] – [9 CLK]
DRAM WRITE to READ Delay [Auto]
Configuration options: [Auto] [4 CLK] – [9 CLK]
DRAM CAS# write Latency [Auto]
Configuration options: [Auto] [5 CLK] – [12 CLK]
DRAM WRITE Recovery Time [Auto]
Configuration options: [Auto] [5 CLK] [6 CLK] [7 CLK] [8 CLK] [10 CLK] [12 CLK] [14
CLK] [16 CLK]
Chapter 3: BIOS setup
DRAM REF Cycle Time [Auto]
Configuration options: [Auto] [90ns] [110ns] [160ns] [300ns] [350ns]
DRAM Row Cycle Time [Auto]
Configuration options: [Auto] [10 CLK] – [56 CLK]
DRAM READ to WRITE Delay [Auto]
Configuration options: [Auto] [2 CLK] – [22 CLK]
DRAM WRITE to READ Delay(DD) [Auto]
Configuration options: [Auto] [1 CLK] – [11 CLK]
DRAM WRITE to WRITE Timing [Auto]
Configuration options: [Auto] [2 CLK] – [11 CLK]
DRAM READ to READ Timing [Auto]
Configuration options: [Auto] [2 CLK] – [11 CLK]
DRAM Refresh Rate [Auto]
Configuration options: [Auto] [Every 7.8ms] [Every 3.9ms]
DRAM Command Rate [Auto]
Configuration options: [Auto] [1T] [2T]
DRAM Driving Control
DCT0 Information
CKE drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
CS/ODT drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
ADDR/CMD drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
MEMCLK drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
Data drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
DQS drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
Processor ODT [Auto]
Configuration options: [Auto] [240 ohms +/- 20%] [120 ohms +/- 20%] [80 ohms +/-
20%] [60 ohms +/- 20%]
DCT1 Information:
CKE drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
CS/ODT drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
ASUS M5A97 EVO R2.0
3-11
3-12
ADDR/CMD drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
MEMCLK drive strength [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
Data drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
DQS drive strength [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
Processor ODT [Auto]
Configuration options: [Auto] [240 ohms +/- 20%] [120 ohms +/- 20%] [80 ohms +/-
20%] [60 ohms +/- 20%]
DIGI+ Power Control
CPU Load-Line Calibration [Auto]
Load-line is defined by AMD VRM spec and affects CPU voltage. The CPU working voltage will decrease proportionally to CPU loading. Higher load-line calibration would get higher voltage and better overclocking performance, but increase the CPU and VRM thermal. This item allows you to adjust the voltage range from the following percentages to boost the system performance: 0% (Regular), 25% (Medium), 50% (High), 75% (Ultra High) and 100%
(Extreme).
Configuration options: [Auto] [Regular] [Medium] [High] [Ultra High] [Extreme]
The actual performance boost may vary depending on your CPU specifiation.
CPU/NB Load-Line Calibration [Auto]
Allows you to select the CPU/NB Load-Line mode.
Configuration options: [Auto] [Regular] [High] [Extreme]
CPU Currrent Capability [Auto]
This item provides wider total power range for overclocking. A higher value brings a wider total power range and extends the overclocking frequency range simultaneously.
Configuration options: [Auto] [100%] [110%] [120%] [130%] [140%]
DO NOT remove the thermal module while changing the DIGI+ Power Control related parrameters . The thermal conditions should be monitored.
Some of the following items are adjusted by typing the desired values using the numeric keypad and press the <Enter> key. You can also use the <+> and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard and press the <Enter> key.
Chapter 3: BIOS setup
CPU/NB Currrent Capability [Auto]
This item provides wider total DRAM controller power range for overclocking. A higher value brings a wider total power range and extends the overclocking frequency range simultaneously.
Configuration options: [Auto] [100%] [110%] [120%] [130%]
CPU Power Phase Control [Standard]
Phase number is the number of woorking VRM phase. Increasing phase number under heavy system loading to get more transient and better thermal performance. Reducing phase number under light system loading to increase VRM efficiency
[Standard]
[Optimized]
[Extreme]
[Manual Adjustment]
Proceeds phase control depending on the CPU loading.
Loads the ASUS optimized phase tuning profile.
Proceeds the full phase mode.
Allows manual adjustment.
CPU Voltage Frequency [Auto]
Switching frequency will affects the VRM transient response and component thermal. Higher frequency gets quicker transient response.
Configuration options: [Auto] [Manual]
VRM Fixed Frequency Mode
This item appears only when you set the CPU Voltage Frequency to [Manual]. It allows you to set a fixed frequency range for the VRM. The values range from 200KHz to 400KHz with a 10KHz interval.
VRM Spread Spectrum [Disabled]
This item appears only when you set the CPU Voltage Frequency to [Auto]. It allows you to enable the spread spectrum to enhance system stability.
Configuration options: [Disabled] [Enabled]
CPU Power Duty Control [T.Probe]
This item adjusts the current and thermal of every VRM phase component.
[T.Probe] Maintains the VRM thermal balance.
[Extreme] Maintains the VRM current balance.
CPU Power Response Control [Auto]
Allows you to control the CPU Power Response.
Configuration options: [Auto] [Regular] [Medium] [Fast] [Ultra Fast]
CPU/NB Power Response Control [Auto]
Allows you to control the CPU/NB Power Response.
Configuration options: [Auto] [Regular] [Medium] [Fast] [Ultra Fast]
CPU Power Thermal Control [130]
Allows you to control the CPU Power thermal value.
Configuration options: [130] ~ [151]
ASUS M5A97 EVO R2.0
3-13
3-14
DRAM Current Capability [100%]
Allows you to set the DRAM current capability.
Configuration options: [100%] [110%] [120%] [130%]
DRAM Voltage Frequency [300KHZ]
Allows you to set the DRAM voltage frequency.
Configuration options: [300KHZ] [350KHZ] [400KHZ] [450KHZ] [500KHZ]
DRAM Power Phase Control [Optimized]
Allows you to set the DRAM power phase control.
Configuration options: [Optimized] [Extreme]
CPU & NB Voltage [Offset Mode]
[Manual Mode] Allows you to set a fixed CPU & NB voltage.
[Offset Mode] Allows you to set the Offset voltage.
Offset Mode Sign [+]
This item appears only when you set the CPU & NB Voltage item to [Offset Mode].
[–] To offset the voltage by a negative value.
[+] To offset the voltage by a positive value.
CPU Offset Voltage [Auto]
This item appears only when you set the CPU & NB Voltage item to [Offset Mode] and allows you to set the Offset voltage. The values range from 0.00625V to 0.70000V with a 0.00625V interval.
CPU/NB Offset Mode Sign [+]
[+]
[–]
To offset the voltage by a positive value.
To offset the voltage by a negative value.
CPU/NB Offset Voltage [Auto]
This item appears only when you set the CPU & NB Voltage item to [Offset Mode] and allows you to set the CPU/NB Offset voltage. The values range from 0.00625V to
0.70000V with a 0.00625V interval.
CPU Manual Voltage [Auto]
This item appears only when you set the CPU & NB Voltage item to [Manual Mode] and allows you to set a fixed CPU voltage. The values range from 0.675V to 2.075V with a 0.00625V interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage may damage the CPU permanently, and setting a low voltage may make the system unstable.
CPU/NB Manual Voltage [Auto]
This item appears only when you set the CPU & NB Voltage item to [Manual Mode] and allows you to set a fixed CPU/NB voltage. The values range from 0.5V to 1.9V with a 0.00625V interval.
Chapter 3: BIOS setup
CPU VDDA Voltage [Auto]
Allows you to set the CPU VDDA voltage. The values range from 2.20000V to 2.80000V with a 0.00625V interval.
DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 0.86V to 2.135V with a 0.005V interval.
NB Voltage [Auto]
Allows you to set the Northbridge voltage. The values range from 1.10000V to 1.25V with a
0.00625V interval.
NB HT Voltage [Auto]
Allows you to set the HyperTransport voltage. The values range from 1.2V to 1.4V with a
0.00625V interval.
NB 1.8V Voltage [Auto]
The values range from 1.80V to 2.80V with a 0.005V interval.
SB Voltage [Auto]
Allows you to set the Southbridge voltage. The values range from 1.10V to 1.80V with a
0.005V interval.
ASUS M5A97 EVO R2.0
3-15
3-16
3.5 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system devices.
Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction.
UEFI BIOS Utility - Advanced Mode
Exit
Main Ai Tweaker Advanced Monitor Boot
CPU Configuration Parameters
Tool
> CPU Configuration
> North Bridge
> South Bridge
> SATA Configuration
> USB Configuration
> CPU Core On/Off Function
> Onboard Devices Configuration
> APM
> Network Stack
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
Chapter 3: BIOS setup
3.5.1 CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically detects.
The items shown in this screen may be different due to the CPU you installed.
UEFI BIOS Utility - Advanced Mode
Exit
Main
Back
Ai Tweaker
Advanced\ CPU Configuration >
Advanced
CPU Configuration
Socket 942: AMD Eng Sample, ZD338251W8K54_39/33/22_2/8
8 Cores Running @3300 MHz 1375 mV
Max Speed: 3300 MHz Intended Speed: 3300 MHz
Not loaded
- - - - - - - Cache per Core - - - - - - -
L1 Instruction Cache: 64 KB/2-way
L1 Data Cache: 16 KB/4-way
L2 Cache: 2048 KB/16-way
Total L3 Cache per Socket: 8 MB/64-way
Cool 'n' Quiet
C1E
SVM
Core C6 State
HPC Mode
Apm Master Mode
Monitor
Enabled
Enabled
Enabled
Enabled
Enabled
Auto
Boot Tool
Enabled/Disabled the generation of ACPI
_PPC, _PSS, and _PCT objects.
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
Cool‘n’Quiet [Enable]
Allows you to enable or disable AMD Cool’n’Quiet function.
Configuration options: [Enabled] [Disabled]
C1E [Enabled]
Enable this feature will let your system utilize the AMD specific ACPI states to save power consumption. Configuration options: [Enabled] [Disabled]
SVM [Enabled]
Enable AMD virtualization in CPU. This secure virtual mode will let you run multiple OS
(guest) on the same physical hardware by decoupling OS and physical hardware with the hypervisor layer.
Configuration options: [Enabled] [Disabled]
Core C6 State [Enabled]
Allows you to reduce the CPU’s power consumption.
Configuration options: [Enabled] [Disabled]
ASUS M5A97 EVO R2.0
3-17
3-18
HPC Mode [Disabled]
Allows you to enable or disable High Performance Computing (HPC) function.
Configuration options: [Enabled] [Disabled]
APM Master Mode [Auto]
Allows you to enable or disable Application Power Management (APM) function.
Configuration options: [Auto] [Enabled] [Disabled]
3.5.2 North Bridge Configuration
UEFI BIOS Utility - Advanced Mode
Monitor Main
Back
Ai Tweaker
Advanced\
North Bridge Configuration
North Bridge >
IOMMU
> Memory Configuration
Initiate Graphic Adapter
Advanced
Disabled
PEG/PCI
Exit
Boot
Enabled/Disabled IOMMU
Tool
Dimm0: Not Present
Dimm1: size=1024 MB, speed=1333 MHz
Dimm2: Not Present
Dimm3: Not Present
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
IOMMU [Disabled]
Set IOMMU to Enabled to show IOMMU Mode.
Configuration options: [Disabled] [Enabled]
IOMMU Mode [Disabled]
This item appears only when you set IOMMU item to [Enabled]. IOMMU is supported on LINUX based systems to convert 32bit I/O to 64bit MMIO.
Configuration options: [Disabled] [64MB]
Chapter 3: BIOS setup
Memory Configuration
Bank Interleaving [Auto]
Configuration options: [Auto] [Disabled]
Channel Interleaving [Auto]
Configuration options: [Auto] [Disabled]
ECC Mode [Enabled]
Enables or disables the DRAM ECC mode that allows the hardware to report and correct memory errors.
[Disabled] Disables the DRAM ECC mode.
[Enabled] Set to [Enable] to adjust ECC mode automatically.
Power Down Enable [Disabled]
Enables or disables the DDR power down mode.
Configuration options: [Disabled] [Enabled]
Memory Hole Remapping [Enabled]
Configuration options: [Disabled] [Enabled]
DCT Unganged Mode [Enabled]
Configuration options: [Disabled] [Enabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to select which graphics controller to use as the primary boot device.
Configuration options: [PCI/PEG] [PEG/PCI]
ASUS M5A97 EVO R2.0
3-19
3-20
3.5.3 South Bridge Configuration
UEFI BIOS Utility - Advanced Mode
Main
Back
HPET
Ai Tweaker
Advanced\ South Bridge >
Advanced Monitor
Disabled
Boot
HPET Timer
Exit
Tool
HPET [Enabled]
Allows you to set the HPET timer.
Configuration options: [Disabled] [Enabled]
3.5.4 SATA Configuration
While entering Setup, the BIOS automatically detects the presence of SATA devices. The SATA
Port items show Not Present if no SATA device is installed to the corresponding SATA port.
UEFI BIOS Utility - Advanced Mode
Exit
Main
Back
Ai Tweaker
Advanced\ SATA Configuration >
Advanced
SATA Configuration
SATA6G_1
SATA6G_2
SATA6G_3
SATA6G_4
SATA6G_5
SATA6G_6
> SB SATA Configuration
Monitor
Not Present
Not Present
Not Present
Not Present
Not Present
Not Present
Boot
Options for SATA Configuration.
Tool
SB SATA Configuration
Options for SATA Configuration.
OnChip SATA Channel [Enabled]
[Enabled]
[Disabled]
Enables the onboard channel SATA port.
Disables the onboard channel SATA port.
The following items appear only when you set the OnChip SATA Channel item to
[Enabled].
Chapter 3: BIOS setup
SATA Port1–Port4 [AHCI]
Allows you to set the SATA configuration.
[IDE] Set to [IDE] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
[RAID] Set to [RAID] when you want to create a RAID configuration from the
SATA hard disk drives.
[AHCI] Set to [AHCI] when you want the SATA hard disk drives to use the
AHCI (Advanced Host Controller Interface). The AHCI allows the onboard storage driver to enable advanced Serial ATA features that increases storage performance on random workloads by allowing the drive to internally optimize the order of commands.
Setting this item to [IDE] instead of [RAID] or [AHCI] allows the system to recognize the optical drives connected to the SATA connector 5 or 6 when installing Windows OS.
• When the SATA Port1–Port 4 and the SATA Port5–Port6 items are set to [AHCI], the information of the SATA connectors 1–6 can be seen only under the OS environment or during POST.
• For Windows
®
XP OS, you have to install the AHCI driver, so that you could use the
SATA connectors 1–6 in AHCI mode under the OS environment.
If you use a SATA optical drive to run the
[IDE] mode.
Windows
OS installation disk, we strongly recommend that you install the optical drive to the SATA connector 5/6 and set them to
S.M.A.R.T Status Check [Enabled]
[Enabled] Enables the S.M.A.R.T feature.
[Disabled] Disables the S.M.A.R.T feature.
SATA ESP on PORT1 [Disabled]
Configuration options: [Enabled] [Disabled]
SATA ESP on PORT2 [Disabled]
Configuration options: [Enabled] [Disabled]
SATA ESP on PORT3 [Disabled]
Configuration options: [Enabled] [Disabled]
SATA ESP on PORT4 [Disabled]
Configuration options: [Enabled] [Disabled]
SATA ESP on PORT5 [Disabled]
Configuration options: [Enabled] [Disabled]
SATA ESP on PORT6 [Disabled]
Configuration options: [Enabled] [Disabled]
ASUS M5A97 EVO R2.0
3-21
3-22
3.5.5 USB Configuration
The items in this menu allow you to change the USB-related features.
UEFI BIOS Utility - Advanced Mode
Main
Back
Ai Tweaker
Advanced\ USB Configuration >
Advanced
USB Configuration
USB Devices:
1 Keyboard, 1 Mouse
Legacy USB Support
Legacy USB3.0 Support
EHCI Hand-off
Monitor
Enabled
Enabled
Disabled
Exit
Boot Tool
Enabled Legacy USB support. AUTO option disables legacy support if no
USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.
> SB USB Configuration
The USB Devices item shows the auto-detected values. If no USB device is detected, the item shows None.
Legacy USB Support [Enabled]
[Enabled]
[Disabled]
Enables the support for USB devices on legacy operating systems (OS).
The USB devices can be used only for the BIOS setup program.
[Auto] Allows the system to detect the presence of USB devices at startup. If detected, the USB controller legacy mode is enabled. If no USB device is detected, the legacy USB support is disabled.
Legacy USB3.0 Support [Enabled]
[Enabled] Enables the support for USB 3.0 devices on legacy operating systems
(OS).
[Disabled] Disables the function.
EHCI Hand-off [Disabled]
[Enabled] Enables the support for operating systems without an EHCI hand-off feature.
[Disabled] Disables the function.
Chapter 3: BIOS setup
SB USB Configuration
USB PORT 1-14 [Enabled]
This item allows you to enable or disable individual USB ports.
Configuration options: [Enabled] [Disabled]
3.5.6 CPU Core On/Off Function
UEFI BIOS Utility - Advanced Mode
Main
Back
Ai Tweaker
Advanced
Advanced\ CPU Core On/Off Function >
CPU Core Activation Auto
Monitor
Exit
Boot Tool
Let User turn off core except core 1, user can turn off 2nd, 3rd, 4th, 5th, etc. core manually.
CPU Core Activation [Auto]
This item allows you to turn off the CPU cores manually.
Configuration options: [Auto] [Manual]
The number of cores vary with CPU models.
ASUS M5A97 EVO R2.0
3-23
3.5.7 Onboard Devices Configuration
UEFI BIOS Utility - Advanced Mode
Exit
Main
Back
Ai Tweaker Advanced
Advanced\ Onboard Devices Configuration >
VIA 1394 Controller
ASM1061 Storage Controller
ASM1061 Storage OPROM
Monitor
Enabled
Enabled
Enabled
Asmedia USB 3.0 Controller (Rear)
Asmedia USB 3.0 Controller (Front)
Asmedia USB 3.0 Battery Charging Support
Realtek LAN Controller
Realtek PXE OPROM
Enabled
Enabled
Disabled
Enabled
Disabled
Disabled S3 Video Repost
> Serial Port Configuration
> SB HD Azalia Configuration
Boot
Enabled/Disabled VIA 1394
Tool
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
3-24
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
VIA 1394 Controller [Enabled]
[Enabled]
[Disabled]
Enables the controller.
Disables the controller.
ASM1061 Storage Controller [Enabled]
[Enabled] Enables the controller.
[Disabled] Disables the controller.
ASM1061 Storage OPROM [Enabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable or disable the ASM1061 Storage OptionRom.
Configuration options: [Enabled] [Disabled]
Asmedia USB 3.0 Controller (Rear) [Enabled]
[Enabled] Enables the USB 3.0 controller.
[Disabled] Disables the controller.
Asmedia USB 3.0 Controller (Front) [Enabled]
[Enabled] Enables the USB 3.0 controller.
[Disabled] Disables the controller.
Asmedia USB 3.0 Battery Charging Support [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable or disable the Asmedia USB 3.0 Battery Charging Support.
Configuration options: [Enabled] [Disabled]
Chapter 3: BIOS setup
Realtek LAN Controller [Enabled]
[Enabled] Enables the Realtek LAN controller.
[Disabled] Disables the controller.
Realtek PXE OPROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable or disable the PXE OptionRom of the Realtek LAN controller.
Configuration options: [Enabled] [Disabled]
S3 Video Repost [Disabled]
Allows you to set the S3 Video Repost.
Configuration options: [Disabled] [Enabled]
Serial Port Configuration
The sub-items in this menu allow you to set the serial port configuration.
This item functions only if there is a serial port (COM1) connector on the motherboard.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Configuration options: [Enabled] [Disabled]
Change Settings [IO=3F8h; IRQ=4]
Allows you to select the Serial Port base address.
Configuration options: [IO=3F8h; IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4]
[IO=2E8h; IRQ=3]
SB HD Azalia Configuration
Options for SB HD Azalia.
HD Audio Azalia Device [Enabled]
Allows you to enable or disable the HD Audio controller.
Configuration options: [Disabled] [Enabled]
Azalia Front Panel [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-definition audio depending on the audio standard that the front panel audio module supports.
[AC 97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
[HD] Sets the front panel audio connector (AAFP) mode to high definition audio.
SPDIF Out Type [SPDIF]
[SPDIF]
[HDMI]
Sets to [SPDIF] for SPDIF audio output.
Sets to [HDMI] for HDMI audio output.
ASUS M5A97 EVO R2.0
3-25
3-26
3.5.8 APM
UEFI BIOS Utility - Advanced Mode
Advanced Main
Back
Ai Tweaker
Advanced\ APM >
ERP Ready
Restore AC Power Loss
Power On By PS/2 Device
Power On By PME Device
Power On By Ring
Power On By RTC
Monitor
Disabled
Power Off
Disabled
Disabled
Disabled
Disabled
Exit
Boot Tool
Allow BIOS to switch off some power at S5 to get the system ready for ErP requirement. When set to Enabled, all other PME options will be switched off.
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
ErP Ready [Disabled]
[Disabled]
[Enabled]
Disables the Energy Related Products (ErP) Ready function.
Allows BIOS to switch off some power at S5 state to get system ready for the ErP requirement. When set to [Enabled], power for WOL, WO_USB, audio and onboard LEDs will be switched off at S5 state.
Restore AC Power Loss [Power Off]
When set to [Power Off], the system goes into off state after an AC power loss. When set to [Power On], the system will reboot after an AC power loss. When set to [Last State], the system goes into either off or on state, whatever the system state was before the AC power loss.
Configuration options: [Power Off] [Power On] [Last State]
Power On By PS/2 Device [Disabled]
[Disabled] Disables the PS/2 devices from generating a wake event.
[Enabled] Enables the PS/2 devices to generate a wake event.
Power On By PME Device [Disabled]
[Disabled] Disables the PME devices from generating a wake event.
[Enabled] Enables the PME devices to generate a wake event.
Chapter 3: BIOS setup
Power On By Ring [Disabled]
[Disabled] Disables the Ring devices from generating a wake event.
[Enabled] Enables the Ring devices to generate a wake event.
Power On By RTC [Disabled]
[Disabled] Disables RTC from generating a wake event.
[Enabled] When set to [Enabled], the items RTC Alarm Date (Days) and Hour/
Minute/Second will become user-configurable with set values.
3.5.9 Network Stack
UEFI BIOS Utility - Advanced Mode
Exit
Main
Back
Network Stack
Ai Tweaker
Advanced\ Network Stack >
Advanced Monitor
Disabled
Boot Tool
Enable/Disable UEFI network stack
Network stack [Disabled]
This item allows you to enable/disable UEFI network stack function.
Configuration options: [Disabled] [Enabled]
The following item appears only when you set the Network Stack to [Enabled].
Ipv4/Ipv6 PXE Support [Enabled]
Allows you to enable or disable the Ipv4/Ipv6 PXE boot option.
Configuration options: [Disabled] [Enabled]
ASUS M5A97 EVO R2.0
3-27
3-28
3.6 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change the fan settings.
Scroll down to display the other BIOS items.
UEFI BIOS Utility - Advanced Mode
Exit
Main Ai Tweaker Advanced Monitor Boot Tool
CPU Temperature
MB Temperature
VCORE Voltage
3.3V Voltage
5V Voltage
12V Voltage
VDDA2.5V Voltage
CPU Fan Speed
Chassis Fan 1 Speed
Chassis Fan 2 Speed
Chassis Fan 3 Speed
CPU Q-Fan Control
CPU Fan Speed Low Limit
+31ºC / +87ºF
+1.452 V
+3.312 V
+5.080 V
+12.192 V
+2.520 V
4192 RPM
N/A
N/A
N/A
Enabled
600 RPM
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
CPU Temperature / MB Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and motherboard temperatures.
VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage, VDDA2.5V Voltage
The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators.
CPU Fan Speed [xxxx RPM] / [N/A], Chassis Fan 1/2/3 Speed [xxxx RPM] /
[N/A]
The onboard hardware monitor automatically detects and displays the CPU and chassis fan speed in rotations per minute (RPM). If the fan is not connected to the motherboard, the field shows N/A.
Chapter 3: BIOS setup
CPU Q-Fan Control [Enabled]
[Disabled] Disables the CPU Q-Fan control feature.
[Enabled] Enables the CPU Q-Fan control feature.
CPU Fan Speed Low Limit [600 RPM]
This item appears only when you enable the CPU Q-Fan Control feature and allows you to disable or set the CPU fan warning speed.
Configuration options: [Ignore] [100 RPM] [200 RPM] [300 RPM] [400 RPM] [500 RPM]
[600 RPM]
CPU Fan Profile [Standard]
This item appears only when you enable the CPU Q-Fan Control feature and allows you to set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on the CPU temperature.
[Silent]
[Turbo]
[Manual]
Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
Sets to [Turbo] to achieve maximum CPU fan speed.
Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set CPU Fan Profile to [Manual].
CPU Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The values range from 20ºC to 75ºC.
CPU Lower Temperature [20]
Use the <+> and <-> keys to adjust the lower limit of the CPU temperature. The values range from 20ºC to 75ºC.
CPU Fan Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum CPU fan duty cycle. The values range from 20% to 100%. When the CPU temperature reaches the upper limit, the
CPU fan will operate at the maximum duty cycle.
CPU Fan Min. Duty Cycle(%) [30]
Set the minimum CPU fan duty cycle when CPU temperature is lower the CPU Lower
Temperature setting.
Chassis Q-Fan Control [Disabled]
[Disabled] Disables the Chassis Q-Fan control feature.
[Enabled] Enables the Chassis Q-Fan control feature.
Chassis Fan Speed Low Limit [600 RPM]
This item appears only when you enable the Chassis Q-Fan Control feature and allows you to disable or set the chassis fan warning speed.
Configuration options: [Ignore] [100 RPM] [200 RPM] [300 RPM] [400 RPM] [500 RPM]
[600 RPM]
ASUS M5A97 EVO R2.0
3-29
3-30
Chassis Fan Profile [Standard]
This item appears only when you enable the Chassis Q-Fan Control feature and allows you to set the appropriate performance level of the chassis fan.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust depending on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan operation.
[Turbo]
[Manual]
Sets to [Turbo] to achieve maximum chassis fan speed.
Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set Chassis Fan Profile to [Manual].
Chassis Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature.
The values range from 40ºC to 90ºC.
Chassis Lower Temperature [40]
Displays the lower limit of the chassis temperature.
Chassis Fan Max. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the maximum chassis fan duty cycle.
The values range from 20% to 100%. When the chassis temperature reaches the upper limit, the chassis fan will operate at the maximum duty cycle.
Chassis Fan Min. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the minimum chassis fan duty cycle.
The values range from 0% to 100%. When the chassis temperature is under 40ºC, the chassis fan will operate at the minimum duty cycle.
Chapter 3: BIOS setup
3.7 Boot menu
The Boot menu items allow you to change the system boot options.
UEFI BIOS Utility - Advanced Mode
Main
Boot Configuration
Boot NumLock State
Full Screen Logo
Wait for ‘F1’ If Error
Direct Key Enabled
Option ROM Messages
INT19 Trap Response
Setup Mode
Ai Tweaker
Advanced Monitor Boot Tool
Select the keyboard NumLoxk state
On
Enabled
Enabled
Go to BIOS...
Force BIOS
Immediate
EZ Mode
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.00.1208. Copyright (C) 2012 American Megatrends, Inc.
Bootup NumLock State [On]
[On]
[Off]
Sets the power-on state of the NumLock to [On].
Sets the power-on state of the NumLock to [Off].
Full Screen Logo [Enabled]
[Enabled] Enables the full screen logo display feature.
[Disabled] Disables the full screen logo display feature.
Exit
Set this item to [Enabled] to use the ASUS MyLogo 2™ feature.
Wait For ‘F1’ If Error [Enabled]
[Disabled]
[Enabled]
Disables this function.
The system waits for the <F1> key to be pressed when error occurs.
ASUS M5A97 EVO R2.0
3-31
3-32
DirectKey Enabled [Go to BIOS...]
[Disabled] Disables the DirectKey function. The system will only power on or off when you press the DirectKey button.
[Go to BIOS Setup] Allows the system to power on and go to BIOS Setup directly when you press the DirectKey button.
Option ROM Messages [Force BIOS]
[Force BIOS] The third-party ROM messages will be forced to display during the boot sequence.
[Keep Current] The third-party ROM messages will be displayed only if the third-party manufacturer had set the add-on device to do so.
INT19 Trap Response [Immediate]
[Immediate] Executes the trap right away.
[Postponed] Executes the trap during legacy boot.
Setup Mode [EZ Mode]
[Advanced Mode] Sets Advanced Mode as the default screen for entering the BIOS setup program.
[EZ Mode] Sets EZ Mode as the default screen for entering the BIOS setup program.
Boot Option Priorities
These items specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system.
• To access Windows OS in Safe Mode, do any of the following:
• Press <F8> after POST.
• To select the boot device during system startup, press <F8> when ASUS Logo appears.
Boot Override
These items display the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system. Click an item to start booting from the selected device.
Chapter 3: BIOS setup
3.8 Tools menu
The Tools menu items allow you to configure options for special functions. Select an item then press <Enter> to display the submenu.
UEFI BIOS Utility - Advanced Mode
Exit
Main Ai Tweaker Advanced Monitor Boot Tool
Be used to update BIOS
> ASUS EZ Flash 2 Utility
> ASUS SPD Information
> ASUS O.C. Profile
3.8.1 ASUS EZ Flash 2 Utility
Allows you to run ASUS EZ Flash 2. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice.
For more details, refer to section 3.10.2 ASUS EZ Flash 2 utility.
3.8.2 ASUS SPD Information
This item allows you to get DRAM SPD information.
UEFI BIOS Utility - Advanced Mode
Exit
Main
Back
Ai Tweaker
Tool\ ASUS SPD Information >
Advanced Monitor
DIMM Slot # Slot 2
Manufacturer
Module Size
Corsair
1024 MBytes
Maximum Bandwidth 1333 MHz
Part Number CM3X1024-1600C7DHN
Serial Number
Product Week/Year
SPD Ext.
XMP Rev.
22/2012
XMP
1.0
JEDEC ID JEDEC XMP #1 XMP#2
Frequency (Mhz) 1333
Voltage (V) 1.500
CAS# Latency (tCL) 9
RAS# to CAS# (tRCD) 9
RAS# Precharge (tRP) 9 tRAS 24 tRC 33 tWR 10 tRRD tRFC tWTR tRTP tFAW
4
60
5
5
20 tCWL
Command Rate
Boot
DIMM Slot number
→←
: Select Screen
↑↓
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Tool
ASUS M5A97 EVO R2.0
3-33
3-34
3.8.3 ASUS O.C. Profile
This item allows you to store or load multiple BIOS settings.
UEFI BIOS Utility - Advanced Mode
Main
Back
Ai Tweaker
Tool\ ASUS O.C. Profile >
O.C. Profile Configuration
Setup Profile 1 Status :
Setup Profile 2 Status :
Setup Profile 3 Status :
Setup Profile 4 Status :
Setup Profile 5 Status :
Setup Profile 6 Status :
Setup Profile 7 Status :
Setup Profile 8 Status :
Add Your CMOS Profile
Label
Save to Profile
Add Your CMOS Profile
Load from Profile
Advanced
1
1
Monitor
Not Installed
Not Installed
Not Installed
Not Installed
Not Installed
Not Installed
Not Installed
Not Installed
Boot
Input the label of setup profile
Tool
Exit
The Setup Profile Status items show Not Installed if no profile is created.
Label
Allows you to input the label of your setup profile.
Save to Profile
Allows you to save the current BIOS settings to the BIOS Flash, and create a profile. Key in a profile number from one to eight, press <Enter>, and then select Yes.
Load from Profile
Allows you to load the previous BIOS settings saved in the BIOS Flash. Key in the profile number that saved your BIOS settings, press <Enter>, and then select Yes.
• DO NOT shut down or reset the system while updating the BIOS to prevent the system boot failure!
• We recommend that you update the BIOS file only coming from the same memory/
CPU configuration and BIOS version.
Chapter 3: BIOS setup
3.9 Exit menu
The Exit menu items allow you to load the optimal default values for the BIOS items, and save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit menu.
Exit
Load Optimized Defaults
Save Changes & Reset
Discard Changes & Exit
ASUS EZ Mode
Launch EFI Shell from filesystem device
Load Optimized Defaults
This option allows you to load the default values for each of the parameters on the Setup menus. When you select this option or if you press <F5>, a confirmation window appears.
Select Yes to load the default values.
Save Changes & Reset
Once you are finished making your selections, choose this option from the Exit menu to ensure the values you selected are saved. When you select this option or if you press <F10>, a confirmation window appears. Select Yes to save changes and exit.
Discard Changes & Exit
This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit.
ASUS EZ Mode
This option allows you to enter the EZ Mode screen.
Launch EFI Shell from filesystem device
This option allows you to attempt to launch the UEFI Shell application (shellx64.efi) from one of the available filesystem devices.
ASUS M5A97 EVO R2.0
3-35
3-36
3.10 Updating BIOS
The ASUS website publishes the latest BIOS versions to provide enhancements on system stability, compatibility, or performance. However, BIOS updating is potentially risky. If there is no problem using the current version of BIOS, DO NOT manually update the BIOS.
Inappropriate BIOS updating may result in the system’s failure to boot. Carefully follow the instructions of this chapter to update your BIOS if necessary.
Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard.
The following utilities allow you to manage and update the motherboard BIOS setup program.
1. ASUS Update: Updates the BIOS in Windows
®
environment.
2. ASUS EZ Flash 2: Updates the BIOS using a USB flash drive.
3. ASUS BIOS Updater: Updates and back ups the BIOS in DOS environment using the motherboard support DVD and a USB flash disk drive.
Save a copy of the original motherboard BIOS file to a USB flash disk in case you need to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update or BIOS Updater utilities.
3.10.1 ASUS Update
The ASUS Update is a utility that allows you to manage, save, and update the motherboard
BIOS in Windows
®
environment.
• ASUS Update requires an Internet connection either through a network or an Internet
Service Provider (ISP).
• This utility is available in the support DVD that comes with the motherboard package.
Chapter 3: BIOS setup
Launching ASUS Update
To launch ASUS Update, click Update > ASUS Update on the AI Suite II main menu bar.
Quit all Windows® applications before you update the BIOS using this utility.
Updating the BIOS through the Internet
To update the BIOS through the Internet:
1. From the ASUS Update screen, select
Update BIOS from Internet, and then click Next.
2. Select the ASUS FTP site nearest you to avoid network traffic.
If you want to enable the BIOS downgrade and auto backup functions, tick Enable BIOS downgrade and click Next.
3. Select the BIOS version that you want to download. Click Next.
ASUS M5A97 EVO R2.0
3-37
Updating the BIOS through a BIOS file
To update the BIOS through a BIOS file:
1. From the ASUS Update screen, select
Update BIOS from file, and then click
Next.
2. Locate the BIOS file and click Next.
3. You can decide whether to change the BIOS boot logo. Click Yes if you want to change the boot logo or No to continue.
4. Follow the onscreen instructions to complete the update process.
3-38
• The screenshots in this section are for reference only. The actual BIOS information vary by models.
• Refer to the software manual in the support DVD or visit the ASUS website at www.asus.com for detailed software configuration.
Chapter 3: BIOS setup
3.10.2 ASUS EZ Flash 2
ASUS EZ Flash 2 allows you to update the BIOS without having to use a bootable floppy disk or an OS-based utility.
Before you start using this utility, download the latest BIOS from the ASUS website at www.asus.com.
To update the BIOS using EZ Flash 2:
1. Insert the USB flash disk that contains the latest BIOS file to the USB port.
2. Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select
ASUS EZ Flash Utility and press <Enter> to enable it.
Exit
ASUSTek EZ Flash BIOS ROM Utility V01.04
Flash Info
MODEL: M5A97 EVO R2.0
File Path:
Drive Info
fs0:\
fs1:\
Folder Info
VER: 0206
06/14/12 11:13p 8390656 M5A97E20.CAP
DATE: 06/18/2012
File Infor
MODEL:
Help Info
VER: DATE:
[Enter] Select or Load [Tab] Switch [Up/Down/PageUp/PageDown/Home/End] Move [Esc] Exit
3. Press <Tab> to switch to the Drive field.
4. Press the Up/Down arrow keys to find the USB flash disk that contains the latest BIOS, and then press <Enter>.
5. Press <Tab> to switch to the Folder Info field.
6. Press the Up/Down arrow keys to find the BIOS file, and then press <Enter> to perform the BIOS update process. Reboot the system when the update process is done.
ASUS M5A97 EVO R2.0
3-39
• This function can support devices such as a USB flash disk with FAT 32/16 format and single partition only.
• DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure!
Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu. See section 3.9 Exit Menu for details.
3-40
Chapter 3: BIOS setup
3.10.3 ASUS BIOS Updater
The ASUS BIOS Updater allows you to update the BIOS in DOS environment. This utility also allows you to copy the current BIOS file that you can use as a backup when the BIOS fails or gets corrupted during the updating process.
The succeeding utility screens are for reference only. The actual utility screen displays may not be same as shown.
Before updating BIOS
1. Prepare the motherboard support DVD and a USB flash drive in FAT32/16 format and single partition.
2. Download the latest BIOS file and BIOS Updater from the ASUS website at http://support.asus.com and save them on the USB flash drive.
• NTFS is not supported under DOS environment. DO NOT save the BIOS file and
BIOS Updater to a hard disk drive or USB flash drive in NTFS format.
• DO NOT save the BIOS file to a floppy disk due to low disk capacity.
3. Turn off the computer and disconnect all SATA hard disk drives (optional).
Booting the system in DOS environment
1. Insert the USB flash drive with the latest BIOS file and BIOS Updater to the USB port.
2. Boot your computer. When the ASUS Logo appears, press <F8> to show the BIOS
Boot Device Select Menu. Insert the support DVD into the optical drive and select the optical drive as the boot device.
Please select boot device:
SATA: XXXXXXXXXXXXXXXX
USB XXXXXXXXXXXXXXXXX
UEFI: XXXXXXXXXXXXXXXX
Enter Setup
↑
and ↓ to move selection
ENTER to select boot device
ESC to boot using defaults
ASUS M5A97 EVO R2.0
3-41
3-42
3. When the Make Disk menu appears, select the FreeDOS command prompt item by pressing the item number.
4. At the FreeDOS prompt, type d: and press <Enter> to switch the disk from Drive C
(optical drive) to Drive D (USB flash drive).
Welcome to FreeDOS (http://www.freedos.org)!
C:\>d:
D:\>
Backing up the current BIOS
To backup the current BIOS file using the BIOS Updater
Ensure that the USB flash drive is not write-protected and has enough free space to save the file.
1. At the FreeDOS prompt, type bupdater /o[filename] and press <Enter>.
D:\>bupdater /oOLDBIOS1.rom
Filename Extension
The [filename] is any user-assigned filename with no more than eight alphanumeric characters for the filename and three alphanumeric characters for the extension.
2. The BIOS Updater backup screen appears indicating the BIOS backup process. When
BIOS backup is done, press any key to return to the DOS prompt.
Current ROM
BOARD: M5A97 EVO R2.0
PATH:
ASUSTek BIOS Updater for DOS V1.30 [2012/12/22]
A:\
Update ROM
BOARD: Unknown
BIOS backup is done! Press any key to continue.
Note
Saving BIOS:
Chapter 3: BIOS setup
Updating the BIOS file
To update the BIOS file using BIOS Updater:
1. At the FreeDOS prompt, type bupdater /pc /g and press <Enter>.
D:\>bupdater /pc /g
2. The BIOS Updater screen appears as below.
ASUSTek BIOS Updater for DOS V1.30 [2012/12/22]
FLASH TYPE:
MX1C 25L1065A
VER:
Current ROM
BOARD: M5A97 EVO R2.0
PATH:
A:\
A:
M5A97E20.CAP 2097152 2012-01-06 17:30:48
[Up/Down/Home/End] Move [B] Backup [Esc] Exit
3. Press <Tab> to switch between screen fields and use the <Up/Down/Home/End> keys to select the BIOS file and press <Enter>. BIOS Updater checks the selected BIOS file and prompts you to confirm BIOS update.
Are you sure to update BIOS?
Yes No
4. Select Yes and press <Enter>. When BIOS update is done, press <ESC> to exit BIOS
Updater. Restart your computer.
DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure!
• For BIOS Updater version 1.04 or later, the utility automatically exits to the DOS prompt after updating BIOS.
• Ensure to load the BIOS default settings to ensure system compatibility and stability.
Select the Load Optimized Defaults item under the Exit BIOS menu. See Chaper 3 of your motherboard user manual for details.
• Ensure to connect all SATA hard disk drives after updating the BIOS file if you have disconnected them.
ASUS M5A97 EVO R2.0
3-43
3-44
Chapter 3: BIOS setup
Software support
4.1 Installing an operating system
4
This motherboard supports Windows
®
XP/ 64-bit XP/ Vista / 64-bit Vista / 7 / 64-bit 7 operating systems (OS). Always install the latest OS version and corresponding updates to maximize the features of your hardware.
• Motherboard settings and hardware options vary. Use the setup procedures presented in this chapter for reference only. Refer to your OS documentation for detailed information.
• Ensure that you install the Windows
®
XP Service Pack 3 or later versions before installing the drivers for better compatibility and system stability.
4.2 Support DVD information
The contents of the support DVD are subject to change at any time without notice. Visit the
ASUS website at www.asus.com for updates.
4.2.1 Running the support DVD
Place the support DVD into the optical drive. The DVD automatically displays the Drivers menu if Autorun is enabled in your computer. Click each menu tab and select the items you want to install.
If Autorun is NOT enabled in your computer, browse the contents of the support DVD to locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the DVD.
ASUS M5A97 EVO R2.0
4-1
4.2.2 Obtaining the software manuals
The software manuals are included in the support DVD. Follow the instructions below to get the necessary software manuals.
The software manual files are in Portable Document Format (PDF). Install the Adobe®
Acrobat® Reader from the Utilities menu before opening the files.
1. Click the Manual tab. Click ASUS
Motherboard Utility Guide from the manual list on the left.
2. The Manual folder of the support
DVD appears. Double-click the folder of your selected software.
3. Some software manuals are provided in different languages.
Double-click the language to show the software manual.
4-2
The screenshots in this section are for reference only. The actual software manuals containing in the support DVD vary by models.
Chapter 4: Software support
4.3 Software information
Most of the applications in the support DVD have wizards that will conveniently guide you through the installation. View the online help or readme file that came with the software application for more information.
4.3.1 AI Suite II
AI Suite II is an all-in-one interface that integrates several ASUS utilities and allows users to launch and operate these utilities simultaneously.
Installing AI Suite II
To install AI Suite II on your computer:
1. Place the support DVD to the optical drive. The Drivers installation tab appears if your computer has enabled the Autorun feature.
2. Click Utilities tab > AI Suite II.
3. Follow the onscreen instructions to complete the installation.
Using AI Suite II
AI Suite II automatically starts when you enter the Windows® operating system (OS). The AI
Suite II icon appears in the Windows® notification area. Click the icon to open the AI Suite II main menu bar.
Click each button to select and launch a utility, to monitor the system, to update the motherboard BIOS, to display the system information, and to customize the settings of AI
Suite II.
Click to update the motherboard BIOS
Click to select a utility
• The
• The applications in the Tool menu vary with motherboard models and CPUs installed.
• The screeshots of AI Suite II in this user manual are for reference only. The actual screenshots vary with models.
• Refer to the software manual in the support DVD or visit the ASUS website at www.asus.com for detailed software configuration.
ASUS M5A97 EVO R2.0
4-3
4-4
4.3.2 DIGI+ Power Control
ASUS DIGI+ Power Control allows you to adjust VRM voltage and frequency modulation to enhance reliability and stability. It also provides the highest power efficiency, generating less heat to prolong the component lifespan and minimize power loss.
To launch DIGI+ Power Control, click Tool > Power Control on the AI Suite II main menu bar.
Smart DIGI+ Key
1
3
2
1
2
3
Smart DIGI+ Key
Quickly delivers an optimized VRM frequency, voltage, and current for superior
CPU/DRAM overclocking performance with one click.
OC Now!
Adjusts the ratio settings in TurboV.
Default
Sets your CPU/DRAM power to default settings.
Chapter 4: Software support
CPU Power
CPU Power offers precise digital power control for CPU and CPU/NB to enhance efficiency, stability, and performance for overclocking scenarios.
4 5
1
2
Application help
3
6
Undoes all the changes
8
9
7
Application help
1
2
3
Undoes all the changes
CPU Load-line Calibration
It allows you to adjust the voltage settings and control the system temperature. Higher load-line calibration could get higher voltage and good overclocking performance but increases the CPU and VRM thermal.
CPU Current Capability
CPU Current Capability provides wider total power range for overclocking. A higher value setting gets higher VRM power consumption delivery.
CPU Voltage Frequency
Switching frequency will affect the VRM transient response and component thermal. Higher frequency gets quicker transient response.
ASUS M5A97 EVO R2.0
4-5
7
8
9
4
5
6
CPU/NB Load-line Calibration
Set to a higher value for system performance, or to a lower value for better thermal solution.
Current Capability
Setting CPU/NB Current Capability to a higher value increases the overclocking frequency range of the DRAM Controller.
CPU Power Phase Control
Increase phase number under heavy system loading to get more transient and better thermal performance. Reduce phase number under light system loading to increase VRM efficiency.
CPU Power Response Control
The VRM controller provides a faster and precise power response rate for CPU.
Apply a higher value for an extreme overclocking.
CPU Power Thermal Control
A higher temperature brings a wider CPU power thermal range, and extends the overclocking tolerance to enlarge overclocking potential.
CPU Power Duty Control
CPU Power Duty Control adjusts the current of every VRM phase and the thermal of every phase component.
4-6
Chapter 4: Software support
DRAM Power
DRAM Power offers precise digital power control for DRAM to enhance efficiency, stability, and performance for overclocking scenarios.
1
2
3
Application help
1
2
3
Undoes all the changes
DRAM Current Capability
A higher value brings a wider total power range and extends the overclocking frequency range simultaneously.
DRAM Voltage Frequency
Allows you to adjust the DRAM switching frequency for system stability or to increase OC Range.
DRAM Power Phase Control
Select Extreme for full phase mode to increase system performance or select
Optimized for ASUS optimized phase tuning profile to increase DRAM power efficiency.
• The actual performance boost may vary depending on your CPU/DRAM specification.
• Do not remove the thermal module. The thermal conditions must be monitored.
ASUS M5A97 EVO R2.0
4-7
4-8
4.3.3 TurboV EVO
ASUS TurboV EVO includes TurboV that allows you to manually adjust the CPU frequency and related voltages such as Auto Tuning that offers automatic and easy overclocking and system level up.
To launch AI Suite II, click Tool > TurboV EVO on the AI Suite II main menu bar.
Refer to the software manual in the support DVD or visit the ASUS website at www.asus.com for detailed software configuration.
TurboV
TurboV allows you to overclock the CPU Bus/PEG frequency, CPU voltage, CPU/NB voltage and DRAM voltage in Windows rebooting the OS.
® environment and takes effect in real-time without exiting and
Refer to the CPU documentation before adjusting CPU voltage settings. Setting a high voltage may damage the CPU permanently, and setting a low voltage may lead to an unstable system.
For system stability, all changes made in TurboV will not be saved to BIOS settings and will not be kept on the next system boot. Use the Save Profile function to save your customized overclocking settings and manually load the profile after Windows starts.
Load profile
Target values
Current values
Undoes all the changes
Chapter 4: Software support
Using Advanced Mode
Click on the Advanced Mode tab to adjust the advanced voltage settings.
Advanced mode
Target values
Current values
CPU Ratio
Allows you to manually adjust the CPU ratio.
1. Click on the CPU Ratio tab.
2. Drag the adjustment bar upwards or downwards to the desired value.
3. Click Apply to save the changes made.
Undoes all the changes
CPU Ratio
Adjustment bar
Undoes all the changes
• Set the CPU Ratio Setting item in BIOS to [Auto] before using the CPU Ratio function in TurboV. Refer to the BIOS chapter of your motherboard user manual for details.
• The CPU Ratio bars show the status of the CPU cores, which vary with your CPU model.
ASUS M5A97 EVO R2.0
4-9
Auto Tuning
ASUS TurboV EVO provides you with these two auto-tuning modes for the most flexible autotuning options.
• The overclocking result varies with the CPU model and the system configuration.
• We recommend that you set up a better thermal environment to prevent overheating from damaging the motherboard.
•
•
Fast Tuning: fast overclocking for the system
Extreme Tuning: extreme overclocking for the system
Using Fast Tuning
1. Click Auto Tuning tab > Fast.
2. Read the warning messages and click
Start to start the auto-overclocking process.
TurboV automatically overclocks the
CPU, saves the BIOS settings, and restarts the system.
3. After the system restarts, a message appears indicating that auto-tuning is successful. Click OK to exit.
4-10
Chapter 4: Software support
Using Extreme Tuning
1. Click Auto Tuning tab > Extreme.
2. Read the warning messages and click
Start to start the auto-overclocking process.
TurboV automatically overclocks the
CPU and memory, and restarts the system.
3. After the system has restarted, a message appears indicating the current overclocking result. To keep the result, click Stop.
4. If you did not click Stop in the previous step, TurboV automatically starts further system overclocking and stability test.
Click Stop if you want to cancel the overclocking process.
TurboV automatically adjusts and saves the BIOS settings and restarts the system.
5. After the system has restarted, a message appears indicating that the auto-tuning process is successful. Click
OK to exit.
ASUS M5A97 EVO R2.0
4-11
4.3.4 EPU
EPU is an energy-processing utility that provides several power-saving modes. When set to the Auto Mode, the system automatically changes its power-saving mode based on the current system condition.
You can also configure the system settings such as CPU frequency, GPU frequency, vCore
Voltage, and Fan Control to customize a power-saving mode.
Launching EPU
To launch EPU, click Tool > EPU on the AI Suite II main menu bar.
4-12
Advanced settings for each mode
Displays the system properties of each mode
• *Select From EPU Installation to show the CO2 that has been reduced since you installed EPU.
• *Select From the Last Reset to show the total CO2 that has been reduced since you click the Clear button .
• Refer to the software manual in the support DVD or visit the ASUS website at www.
asus.com for detailed software configuration.
Chapter 4: Software support
4.3.5 Remote GO!
Connect your computer to a wireless network and use Remote GO! to wirelessly stream media files to DLNA devices. It allows you to remotely control and access your computer using your mobile device, and easily transfer files between your computer and mobile device.
• Remote GO! is supported only on Windows
®
7.
• All devices using the Remote GO! functions must be in the same network.
Using Remote GO!
To launch Remote GO!, click Tool > Remote GO! on the AI Suite II menu bar.
Remote GO! functions
•
DLNA Media Hub: Provides support to the latest DLNA standard, and allows you to stream media files to a DLNA-supported device.
•
Remote Desktop: Allows you to view your computer’s desktop and remotely operate your computer in real-time from your mobile device.
•
File Transfer: Allows you to transfer files between your computer and mobile device.
Launch Wi-Fi GO! Remote on your mobile device to use Wi-Fi GO! Remote control functions. For more details, refer to next section Wi-Fi GO! Remote.
ASUS M5A97 EVO R2.0
4-13
Wi-Fi GO! Remote
Install the Wi-Fi GO! Remote application on your mobile device to use Remote GO!’s remote control functions.
• Wi-Fi GO! Remote supports iOS 4.0/Android 2.3 mobile devices or later versions.
• For iOS devices, download the Wi-Fi GO! Remote from iTunes store. For Android devices, download the Wi-Fi GO! Remote from Google Play Store or from ASUS support DVD.
Launching Wi-Fi GO! Remote
1. Turn on your mobile device’s wireless connection. Ensure that your mobile device is within the same network as your computer.
2. On your mobile device, tap and tap Enter on the Wi-Fi GO! Remote page.
3. Tap the computer you want to connect to your mobile device.
4. Tap the computer you want to connect to your mobile device.
4-14
Chapter 4: Software support
Wi-Fi GO! Remote menu
The Wi-Fi GO! Remote’s user interface shown above is for reference only and may vary with the mobile device’s operating system.
Below are the supported screen resolution of your mobile devices:
Screen type Low Density
(120, ldpi)
Medium Density
(160, mdpi)
High Density
(240, hdpi)
Extra high density
(320, xhdpi)
Small creen
Normal screen
QVGA
(240 x 320)
WQVGA400
(240 x 400)
WQVGA432
(240 x 432)
HVGA
(320 x 480)
480 x 640
WVGA800
(480 x 800)
WVGA854
(480 x 854)
600 x 1024
640 x 960
Large screen
Extra large screen
WVGA800
(480 x 800)
WVGA854
(480 x 854)
1024 x 600
WVGA800
(480 x 800)
WVGA854
(480 x 854)
600 x 1024
WXGA
(1280 x 800)
1024 x 768
1280 x 768
1536 x 1152
1920 x 1152
1920 x 1200
2048 x 1536
2560 x 1536
2560 x 1600
ASUS M5A97 EVO R2.0
4-15
DLNA Media Hub
DLNA Media Hub allows you to stream your multimedia files to your DLNA-supported device and remotely control playback using your mobile device or your computer.
Media files pane
Click to edit the playlist
Using the DLNA Media Hub
1. From the main screen, click DLNA Media Hub.
2. Click to select a device as your receiver.
Click to select receiver
• When using your DLNA display (such as DLNA TV) as the receiver, ensure that
DLNA function is enabled.
• When using another computer as the receiver, launch Windows Media Player, click Stream > Allow remote control of my Player to remotely control media playback.
• When using the computer as sender and receiver, launch Windows Media Player, click Stream > Allow remote control of my Player and Automatically allow
devices to play my media.
4-16
• Only computers under Windows
®
7 support the DLNA Media Hub function.
• Keep the Windows Media Player open. Ensure that your media file formats supported on Windows Media Player and DLNA playback devices.
3. Click any of the tabs to select your preferred media file type.
Chapter 4: Software support
To play music:
1. Click Music tab.
2. Tick Library to view or play files.
Tick Playlist and select an existing playlist from the dropdown list.
3. Click a music file, and click .
To edit the library:
1. Tick Library.
2. Click to add or delete music files.
3. Click Add and locate the file from the directory. To delete, tick the selected file and click Delete.
4. Click OK.
To edit the music playlist:
1. Tick Playlist.
2. Click .
3. Tick to select or deselect the music file and click Save Profile.
4. Select the profile name and click
Save. To add as a new playlist, key in your profile name and click
Save.
5. To delete playlist, select the profile and click .
ASUS M5A97 EVO R2.0
4-17
4-18
To play a video file:
1. Click Video tab.
2. Tick Library to view the video files from your local computer. Tick
Playlist to view the video files saved in your profile.
3. Click the video file you want to watch, and click .
Change the resolution from the
Quality dropdown list.
To edit the video library:
1. Tick Library.
2. Click to add or delete video files.
3. Click Add and locate the file from the directory. To delete, tick the selected file and click Delete.
4. Click OK.
To edit the video playlist:
1. Tick Playlist.
2. Click .
3. Tick to select or deselect the video file and click Save Profile.
4. Select the profile name and click
Save. To add as a new playlist, key in your profile name and click
Save.
5. To delete playlist, select the profile and click .
Chapter 4: Software support
To view images:
1. Click Photo tab.
2. Tick Library to view the image files from your local computer. Tick
Playlist to view the image files saved in your profile.
An image slideshow plays when pressing .
To edit the image library:
1. Tick Library.
2. Click to add or delete image files.
3. Click Add and locate the file from the directory. To delete, tick the selected file and click Delete.
4. Click OK.
To edit the image playlist:
1. Tick Playlist.
2. Click .
3. Tick to select or deselect the image file and click Save Profile.
4. Select the profile name and click
Save. To add as a new playlist, key in your profile name and click
Save.
5. To delete playlist, select the profile and click .
ASUS M5A97 EVO R2.0
4-19
Using the DLNA Media Hub via Wi-Fi GO! Remote
You can access the DLNA Media Hub on your mobile device via Wi-Fi GO! Remote.
1. Tap DLNA Media Hub.
2. Select and tap the receiver name.
3. The mobile device shows the information of the DLNA Media Hub function. Tap Enter to proceed to the Remote GO! function.
4. Tap Music, Video or Photo, to play.
Your mobile device’s WI-FI GO! Remote interface may vary with the mobile device’s operating system.
Remote Desktop
Remote Desktop allows you to view your computer’s desktop and remotely operate your computer in real-time from your mobile device.
Using the Remote Desktop
1. From the main screen, click Remote Desktop.
2. Click Setting.
4-20
Chapter 4: Software support
3. Select a suitable codec Auto, Speed optimization, or Image optimization for your mobile device.
4. Click Apply.
Application help
Using the Remote Desktop via Wi-Fi GO! Remote
When the Remote Desktop is enabled, the mobile device shows the contents of your desktop.
The Wi-Fi GO! Remote’s user interface shown above is for reference only and may vary with the mobile device’s operating system.
ASUS M5A97 EVO R2.0
4-21
4-22
File Transfer
Allows you to transfer files wirelessly between your computer and mobile device.
Before using File Transfer, ensure that your computer is connected to your mobile device.
For more details, refer to the section Wi-Fi GO! Remote.
Application help
• Android mobile devices can send and receive files.
• iOS mobile devices can only send files.
Using File Transfer
1. Right-click the file and click Send to > [Device name].
2. After the transfer is complete, click OK.
Using File Transfer via Wi-Fi GO! Remote
1. On your mobile device, tap File Transfer.
2. Tap Enable to receive files from PC.
3. Tap Enter to send files to PC.
Chapter 4: Software support
The Wi-Fi GO! Remote’s user interface shown above is for reference only and may vary with the mobile device’s operating system.
Securing your computer for Wi-Fi GO! Remote functions
Remote GO! Settings allows you to create a password for your computer.
To create a password:
1. Click in the main menu.
2. Tick Use Password and key in your password.
3. Click Apply.
• When you launch the Wi-Fi GO! Remote, the application prompts you to key in the computer’s password.
• Your password must contain 6-12 letters or numbers.
ASUS M5A97 EVO R2.0
4-23
4.3.6 USB 3.0 Boost
ASUS USB 3.0 Boost technology supports UASP (USB Attached SCSI Protocol) and automatically increases a USB 3.0 device’s transfer speed up to 170%.
Launching USB 3.0 Boost
To launch USB 3.0 Boost, click Tool > USB 3.0 Boost on the AI Suite II main menu bar.
Configuring USB 3.0 Boost
1. Connect a USB 3.0 device to the USB 3.0 port.
USB 3.0 Boost automatically detects the property of the USB 3.0 device and switches to Turbo mode or UASP mode (if UASP is supported by the USB 3.0 device).
2. You can manually switch the USB 3.0 mode back to Normal mode at any time.
4-24
• Refer to the software manual in the support DVD or visit the ASUS website at www.
asus.com for detailed software configuration.
• Use the USB 3.0 devices for high performance. The data transfer speed varies with
USB devices.
Chapter 4: Software support
4.3.7 Network iControl
ASUS Network iControl is an intuitive one-stop network control center that makes it easier for you to manage your network bandwidth and allows you to set, monitor, and schedule the bandwidth priorities for your network programs. It also allows you to automatically connect to a PPPoE for a more convenient online experience.
To launch Network iControl, click Tool > Network iControl from AI Suite II main menu bar.
• Ensure to install the LAN drivers before using this function.
• Network iControl is only supported under Windows
® onboard LAN.
7 and can only support the
Using EZ Start
EZ Start allows you to quickly activate Network iControl, and set the highest bandwidth priority for your top currently running program.
To use EZ Start:
1. Click the EZ Start tab.
2. Click ON/OFF to enable/disable Network iControl.
• By default, Network iControl is set to ON.
• When switched off, the Quick Connection, EZ Profile, and Info are disabled.
• You may monitor the bandwidth priority from your desktop’s taskbar.
3. Select a profile and click Apply.
Tick Set current network program as the highest priority to set the top network program as the highest priority.
ASUS M5A97 EVO R2.0
Click to select a profile
4-25
Using Quick Connection
Configuring the PPPoE connection settings
Before enabling the Network iControl’s Quick Connection functions, you must configure the
PPPoE connection settings
To configure the PPPoE settings:
1. Right-click in the taskbar, and select Open Network and Sharing Center.
2. Right-click the PPPoE Connection, and select Properties.
3. Click the Options tab, and deselect Prompt for name and password, certificate,
etc. Click OK to complete the auto PPPoE connection settings.
4-26
• You only need to configure the PPPoE connection settings once.
• Obtain the necessary information about your PPPoE connection from your network provider.
Chapter 4: Software support
Configuring the Quick Connection
To configure the auto-PPPoE connection:
1. Click the Quick Connection tab.
2. Tick Automatically connect online anytime option, then select the connection name in the Connection Name dropdown box.
3. Click Apply to enable the PPPoE automatic network connection.
You can also enable the No Delay TCP function to help improve the network performance.
ASUS M5A97 EVO R2.0
4-27
Using EZ Profile
To use the EZ Profile:
EZ Profile allows you to load, edit, and save your own network program priority profile.
1. Click the EZ Profile tab. The programs are shown in the network program column.
2. Select the network program, and click to create your profile.
3. Click to save the changes and/or rename your profile.
4. Click , , or to set the program priority as High, Normal, or Low.
network profile
4-28
Chapter 4: Software support
4.3.8 USB BIOS Flashback Wizard
USB BIOS Flashback allows you to easily update the BIOS without entering the BIOS or operating system. Just connect the USB storage device containing the BIOS file to the USB port, press the BIOS Flashback button, and the BIOS is updated automatically.
Cancels all the changes
Applies all the changes
Scheduling the latest BIOS download
1. In the Download Setting field, tick Schedule (days) and select the number of days for your download schedule.
2. Click Apply to save the BIOS download schedule. Click Cancel to cancel the changes made.
Downloading the updated BIOS
Before you start downloading, ensure that you have installed the USB storage device to your computer’s USB port.
1. Click Check for New BIOS Update to check for the latest BIOS version.
Wait for the system to check the latest
BIOS firmware.
ASUS M5A97 EVO R2.0
4-29
2. From the Save to dropdown list, select the USB storage device that you want to save the BIOS file to, then click
Download.
3. When the download process is completed, click OK to exit.
4-30
Chapter 4: Software support
4.3.9 FAN Xpert
Fan Xpert intelligently allows you to adjust both the CPU and chassis fan speeds according to different ambient temperatures caused by different climate conditions in different geographic regions and your PC’s system loading. The built-in variety of useful profiles offer flexible controls of fan speed to achieve a quiet and cool environment.
Launching FAN Xpert
After installing AI Suite II from the motherboard support DVD, launch FAN Xpert by clicking
Tool > Fan Xpert on the AI Suite II main menu bar.
Using FAN Xpert
Click Fan Name to select a fan and then click Setting to select a preset mode for your selected fan.
Click to select a fan type
Click to select a fan profile
Click to apply the settings
Click to discard the settings
Fan setting
• Disable: disables the Fan Xpert function.
• Standard: adjusts fan speed in a moderate pattern.
• Silent: minimizes fan speed for quiet fan operation.
• Turbo: maximizes the fan speed for the best cooling effect.
• User: Allows you to configure the CPU fan profile under certain limitations.
ASUS M5A97 EVO R2.0
4-31
4.3.10 Ai Charger+
This utility allows you to fast-charge your portable BC 1.1* mobile devices on your computer’s
USB port three times faster than the standard USB devices**.
• * Check your manufacturer if your USB device is a Battery Charging Specification 1.1
(BC 1.1) compliant or compatible device.
• ** Actual charging speeds may vary depending on the charging rate and specifications of your USB device.
• To ensure normal charging function, disconnect and reconnect your USB device every time you enable or disable Ai Charger+.
4-32
Chapter 4: Software support
4.3.11 Probe II
Probe II is a utility that monitors the computer’s vital components, and detects and alerts you of any problem with these components. Probe II senses fan rotations, CPU temperature, and system voltages, among others. With this utility, you are assured that your computer is always at a healthy operating condition.
Launching Probe II
To launch Probe II, click Tool > Probe II on the AI Suite II main menu bar.
Configuring Probe II
Click the Voltage/Temperature/Fan Speed tabs to activate the sensors or to adjust the sensor threshold values. The Preference tab allows you to customize the time interval of sensor alerts, or change the temperature unit.
• Click Monitor > Sensor on the AI Suite II main menu bar and the system status will appear on the right panel.
• Refer to the software manual in the support DVD or visit the ASUS website at www.
asus.com for detailed software configuration.
ASUS M5A97 EVO R2.0
4-33
4.3.12 Sensor Recorder
Sensor Recorder monitors the changes in the system voltage, temperature, and fan speed on a timeline. The History Record function allows you to designate specific time spans on record to keep track of the three system statuses for certain purposes.
Launching Sensor Recorder
To launch Sensor Recorder, click Tool > Sensor Recorder on the AI Suite II main menu bar.
Using Sensor Recorder
Click on Voltage/ Temperature/ Fan Speed tabs for the status you want to monitor. Colored lines will automatically appear on the diagram to indicate the immediate changes in the system status.
4-34
Chapter 4: Software support
Using History Record
1. Click the History Record tab and adjust the settings on the left for Record Interval and Record Duration according to need.
2. Click Start Recording to start measuring and recording each sensor.
3. To stop recording, click Recording again.
4. To track the recorded contents, set Type/ Date/ Select display items to display the history details.
Click Monitor > Sensor on the AI Suite II main menu bar and the system status will appear on the right panel.
ASUS M5A97 EVO R2.0
4-35
4.3.13 ASUS Update
ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows
®
environment.
Launching ASUS Update
To launch ASUS Update, click Update > ASUS Update on the AI Suite II main menu bar.
Using ASUS Update
4-36
•
•
•
Select any of these options to update the BIOS:
•
Update BIOS from Internet
Allows you to download the latest BIOS version from the ASUS website at www.asus.com and follow the onscreen instructions to update the BIOS.
Download BIOS from Internet
Download the latest BIOS version from the ASUS website at www.asus.com and save it for later use.
Update BIOS from file
Use the BIOS file that you had downloaded and saved to update the system BIOS.
Save BIOS to file
Save the BIOS file to another file or a USB storage device for later use.
Updating the BIOS poses some risks such as system instability or failure to boot. Before updating the BIOS, ensure that you back up the original BIOS file.
Chapter 4: Software support
4.3.14 MyLogo2
MyLogo2 allows you to customize the boot logo, which is the image that appears on the screen during the Power On Self Tests (POST).
Launching MyLogo2
To launch MyLogo2, click Update > MyLogo on the AI Suite II main menu bar.
Using MyLogo
Select the option that you want to use to update your boot logo, click Next and follow the instructions below.
Change the boot logo of a downloaded BIOS file and update (or do not update) this
BIOS to the motherboard
1. From the BIOS file field, click Browse to locate the BIOS file.
2. From the Picture File field, click Browse the image for your boot logo, then click
Next.
ASUS M5A97 EVO R2.0
4-37
3. Do any of the following:
• Click Auto Tune to adjust the image size or the image resolution.
• Click Booting Preview to preview the boot image.
4. Click Next.
5. Click Flash to update the boot logo.
6. When prompted, click Yes to reboot the system. You will see the new boot logo the next time you start up the system.
Ensure to enable the Full Screen Logo in BIOS to use this feature.
4-38
Chapter 4: Software support
4.3.15 Audio configurations
The Realtek
®
audio CODEC provides 8-channel audio capability to deliver the ultimate audio experience on your computer. The software provides Jack-Sensing function, S/PDIF Out support, and interrupt capability. The CODEC also includes the Realtek
®
proprietary UAJ
®
(Universal Audio Jack) technology for all audio ports, eliminating cable connection errors and giving users plug and play convenience.
Follow the installation wizard to install the Realtek
® came with the motherboard package.
Audio Driver from the support DVD that
If the Realtek audio software is correctly installed, you will find the Realtek HD Audio
Manager icon on the taskbar. Double-click on the icon to display the Realtek HD Audio
Manager.
A. Realtek HD Audio Manager with DTS UltraPC II for Windows
®
7™ / Vista™
Configuration option tabs (vary with the audio devices connected)
Information button
Exit button
Minimize button
Control settings
Set default device buttons
Connector settings
Analog and digital connector status
ASUS M5A97 EVO R2.0
4-39
B. Realtek HD Audio Manager for Windows XP
Configuration options
Control settings window
Exit button
Minimize button
Information button
• DTS UltraPC II and DTS Connect only support Windows 7/Vista operating systems.
• Refer to the software manual in the support DVD or visit the ASUS website at www.asus.com for detailed software configuration.
4-40
Chapter 4: Software support
RAID support
5.1 RAID configurations
The motherboard comes with the AMD
®
SB950 chipset that allows you to configure
Serial ATA hard disk drives as RAID sets. The motherboard supports the following RAID configurations: RAID 0, RAID 1, RAID 5 and RAID 10.
5
• You must install Windows
Windows
®
®
XP Service Pack 3 or later versions before using Serial
ATA hard disk drives. The Serial ATA RAID feature is available only if you are using
XP SP3 or later versions.
• Due to Windows
®
XP limitation, a RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only.
• If you want to install a Windows
®
operating system to a hard disk drive included in a
RAID set, you have to create a RAID driver disk and load the RAID driver during OS installation. Refer to section 5.2 Creating a RAID driver disk for details.
5.1.1 RAID definitions
RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks. Two hard disks perform the same work as a single drive but at a sustained data transfer rate, double that of a single disk alone, thus improving data access and storage. Use of two new identical hard disk drives is required for this setup.
RAID 1 (Data mirroring) copies and maintains an identical image of data from one drive to a second drive. If one drive fails, the disk array management software directs all applications to the surviving drive as it contains a complete copy of the data in the other drive. This RAID configuration provides data protection and increases fault tolerance to the entire system. Use two new drives or use an existing drive and a new drive for this setup. The new drive must be of the same size or larger than the existing drive.
RAID 5 stripes both data and parity information across three or more hard disk drives. Among the advantages of RAID 5 configuration include better HDD performance, fault tolerance, and higher storage capacity. The RAID 5 configuration is best suited for transaction processing, relational database applications, enterprise resource planning, and other business systems.
Use a minimum of three identical hard disk drives for this setup.
RAID 10 is data striping and data mirroring combined without parity (redundancy data) having to be calculated and written. With the RAID 10 configuration you get all the benefits of both
RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive and three new drives for this setup.
ASUS M5A97 EVO R2.0
5-1
5-2
5.1.2 Installing Serial ATA hard disks
The motherboard supports Serial ATA hard disk drives. For optimal performance, install identical drives of the same model and capacity when creating a disk array.
To install the SATA hard disks for a RAID configuration:
1. Install the SATA hard disks into the drive bays.
2. Connect the SATA signal cables.
3. Connect a SATA power cable to the power connector on each drive.
5.1.3 Setting the RAID item in BIOS
You must enable the RAID function in the BIOS Setup before creating RAID sets using SATA
HDDs. To do this:
1. Enter the BIOS Setup during POST.
2. Go to Advanced Mode and go to the Advanced menu > SATA Configuration > SB
SATA Configuration, and press <Enter>.
3. Set the SATA Mode item to [RAID Mode].
4. Save your changes, and then exit the BIOS Setup.
Refer to Chapter 3 for details on entering and navigating through the BIOS Setup
• Due to chipset limitation, when SATA ports are 1-4 are set to RAID mode, SATA ports
1-4 run at RAID mode at the same time.
• When creating a RAID volume using more than four HDDs, ensure that SATA ports
5-6 are set to [RAID] mode.
• When creating a RAID set, set the SATA_5-6 connectors to [IDE] mode to ensure that the system recognizes your ODD device.
Chapter 5: RAID support
5.1.4 AMD
®
Option ROM utility
To enter the AMD
®
Option ROM utility:
1. Turn on the system.
2. During POST, press <Ctrl> + <F> to display the utility main menu.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ Main Menu ]
View Drive Assignments .......
[ 1 ]
LD View / LD Define Menu ......
[ 2 ]
Delete LD Menu ...............
[ 3 ]
Controller Configuration ......
[ 4 ]
Press 1..4 to Select Option
[ Keys Available ]
[ESC] Exit
•
•
The Main Menu allows you to select an operation to perform. The Main Menu options include:
View Drive Assignments: shows the status of the hard disk drives.
LD View / LD Define Menu: displays the existing RAID set information / creates a RAID
0, RAID 1, RAID 5 or RAID 10 configuration.
•
•
Delete LD Menu: deletes a selected RAID set and partition.
Controller Configuration: shows the system resources configuration.
Press <1>, <2>, <3>, or <4> to enter the option you need; press <ESC> to exit the utility.
The RAID BIOS setup screens shown in this section are for reference only and may not exactly match the items on your screen.
To create a RAID volume using more than four hard disk drives, ensure that the SATA connectors 5-6 are set to [RAID] mode.
ASUS M5A97 EVO R2.0
5-3
5-4
Creating a RAID volume
To create a RAID volume:
1. In the Main Menu, press <2> to enter the LD View / LD Define Menu function.
2. Press <Ctrl> + <C>, and the following screen appears.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ LD Define Menu ]
LD No LD Name RAID Mode Drv
LD 1 Logical Drive 1 RAID 0 2
Strip Block 64 KB
Gigabyte Boundary ON
Fast Init ON
Cache Mode WriteThru
[ Drives Assignments ]
Port:ID Drive Model Capabilities Capacity(GB) Assignment
01:00 xxxxxxxxx
02:00 xxxxxxxxx
03:00 xxxxxxxxx
04:00 xxxxxxxxx
xxxxxxx
xxxxxxx
xxxxxxx
xxxxxxx
xxxxxx
xxxxxx
xxxxxx
xxxxxx
Y
Y
N
N
[ Keys Available ]
[↑] Up [↓] Down [PaUp/PaDn] Switch page [Space] Change Option
[Ctrl-Y] Save [ESC] Exit
3. Move to the RAID Mode item and press <Space> to select a RAID mode to create.
4. Move to the Assignment item by using the down arrow key and set Y to select the hard disk drives you want to include in the RAID set.
5. Press <Ctrl> + <Y> to save the setting.
6. The utility prompts the following message. Press <Ctrl> + <Y> to input the LD name.
Please press Ctrl-Y key to input the LD Name or press any key to exit.
If you do not input any LD name, the default LD name will be used.
7. Eenter an LD name, and then press any key to continue.
Enter the LD name here:
8. Press <Ctrl> + <Y> to erase the MBR, or you may press any key to abort the settings.
Fast Initialization Option has been selected
It will erase the MBR data of the disks.
<Press Ctrl-Y Key if you are sure to erase it>
<Press any other key to ignore this option>
9. Press <Ctrl> + <Y> to enter the screen to modify the array capacity, or press any key to use the maximum capacity.
Chapter 5: RAID support
Deleting a RAID configuration
Take caution when deleting a RAID volume. You will lose all data on the hard disk drives when you delete a RAID volume.
To delete a RAID volume:
1. In the Main Menu, press <3> to enter the Delete LD function.
2. Select the RAID item you want to delete and press <Del> or <Alt> + <D>.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ Delete LD Menu ]
LD No RAID Mode Drv Capacity(GB) Status
LD 1 RAID 0 2 xxxxxx Functional
[ Keys Available ]
[↑] Up [↓] Down [PaUp/PaDn] Switch page [Del/Alt+D] Delete LD
3. The utility prompts the following messages:
Press Ctrl-Y to delte the data in the disk! or press any other key to abort...
Press <Ctrl> + <Y> to delete the RAID volume.
Displaying a RAID set information
To display a RAID set information:
1. In the Main Menu, press <2> to enter the LD View / LD Define Menu function.
2. Select a RAID item and press <Enter> to display its information.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
[ View LD Defination Menu ]
LD No LD Name RAID Mode Drv Capacity(GB)
LD 1 xxxxx RAID 0 2 157.99
Strip Block 64 KB Cache Mode WriteThru
[ Drives Assignments ]
Port:ID Drive Model Capabilities Capacity(GB)
01:00 xxxxxxxxx
02:00 xxxxxxxxx
xxxxxxx
xxxxxxx
xxxxxx
xxxxxx
Any Key To Continue.......
ASUS M5A97 EVO R2.0
5-5
5-6
5.2 Creating a RAID driver disk
A floppy disk with the RAID driver is required when installing a Windows
®
operating system on a hard disk drive that is included in a RAID set.
• The motherboard does not provide a floppy drive connector. You have to use a USB floppy disk drive when creating a SATA RAID driver disk.
• Windows
®
XP may not recognize the USB floppy disk drive due to Windows
®
XP limitation. To work around this OS limitation, refer to section 5.2.4 Using a USB
floppy disk drive.
5.2.1 Creating a RAID driver disk without entering the OS
To create a RAID driver disk without entering the OS:
1. Boot your computer.
2. Press <Del> during POST to enter the BIOS setup utility.
3. Set the optical drive as the primary boot device.
4. Insert the support DVD into the optical drive.
5. Save changes and exit BIOS.
6. When the Make Disk menu appears, press <1> to create a RAID driver disk.
7. Insert a formatted floppy disk into the USB floppy disk drive, then press <Enter>.
8. Follow the succeeding screen instructions to complete the process.
5.2.2 Creating a RAID driver disk in Windows
®
To create a RAID driver disk in Windows
®
:
1. Start Windows
®
.
2. Plug the USB floppy disk drive and insert a floppy disk.
3. Place the motherboard support DVD into the optical drive.
Go to the Make Disk menu, and then click AMD AHCI/RAID 32/64bit xxxx Driver to create a RAID driver disk.
5. Select USB floppy disk drive as the destination disk.
6. Follow the succeeding screen instructions to complete the process.
Write-protect the floppy disk to avoid a computer virus infection.
Chapter 5: RAID support
5.2.3 Installing the RAID driver during Windows
®
OS installation
If you use a SATA optical drive to run the Windows OS installation disk, we strongly recommend that you connect the optical drive to the SATA connectors 5/6 and set them to
[IDE] mode.
To install the RAID driver in Windows
®
XP:
1. During the OS installation, the system prompts you to press the <F6> key to install third-party SCSI or RAID driver.
2. Press <F6>, and then insert the floppy disk with RAID driver into the USB floppy disk drive.
3. When prompted to select the SCSI adapter to install, select the RAID driver for the corresponding OS version.
4. Follow the succeeding screen instructions to complete the installation.
To install the RAID driver for Windows
®
Vista or later OS:
1. During the OS installation, click Load Driver to allow you to select the installation media containing the RAID driver.
2. Insert the USB flash drive with RAID driver into the USB port or the support DVD into the optical drive, and then click Browse.
3. Click the name of the device you’ve inserted, go to Drivers > RAID, and then select the RAID driver for the corresponding OS version. Click OK.
4. Follow the succeeding screen instructions to complete the installation.
Before loading the RAID driver from a USB flash drive, you have to use another computer to copy the RAID driver from the support DVD to the USB flash drive.
ASUS M5A97 EVO R2.0
5-7
5-8
5.2.4 Using a USB floppy disk drive
Due to OS limitation, Windows
®
XP may not recognize the USB floppy disk drive when you install the RAID driver from a floppy disk during the OS installation.
To solve this issue, add the USB floppy disk drive’s Vendor ID (VID) and Product ID (PID) to the floppy disk containing the RAID driver. Refer to the steps below:
1. Using another computer, plug the USB floppy disk drive, and insert the floppy disk containing the RAID driver.
2. Right-click My Computer on the
Windows
®
desktop or start menu, and then select Manage from the pop-up window.
or
3. Select Device Manager. From the
Universal Serial Bus controllers, right-click xxxxxx USB Floppy, and then select Properties from the pop-up window.
The name of the USB floppy disk drive varies with different vendors.
4. Click Details tab. The Vendor ID (VID) and Product ID (PID) are displayed.
5. Browse the contents of the RAID driver disk to locate the file txtsetup.oem.
6. Double-click the file. A window appears, allowing you to select the program for opening the oem file.
Chapter 5: RAID support
7. Use Notepad to open the file.
8. Find the [HardwareIds.SCSI.Napa_i386_ahci8086] and [HardwareIds.SCSI.
Napa_amd64_ahci] sections in the txtsetup.oem file.
9. Type the following line to the bottom of the two sections:
id = “USB\VID_xxxx&PID_xxxx”, “usbstor”
[HardwareIds.SCSI.Napa_i386_ahci8086] id= “PCI\VEN_1002&DEV_4392&CC_0104”,”ahcix86” id= “PCI\VEN_1002&DEV_4391&CC_0106”,”ahcix86” id= “PCI\VEN_1002&DEV_4393&CC_0104”,”ahcix86” id= “USB\VID_03EE&PID_6901”, “usbstor”
[HardwareIds.SCSI.Napa_amd64_ahci] id= “PCI\VEN_1002&DEV_4392&CC_0104”,”ahcix64” id= “PCI\VEN_1002&DEV_4391&CC_0106”,”ahcix64” id= “PCI\VEN_1002&DEV_4393&CC_0104”,”ahcix64” id= “USB\VID_03EE&PID_6901”, “usbstor”
Add the same line to both sections.
The VID and PID vary with different vendors.
10. Save and exit the file.
ASUS M5A97 EVO R2.0
5-9
5-10
Chapter 5: RAID support
Multiple GPU support
6
6.1 AMD
®
CrossFireX™ technology
The motherboard supports the AMD this section.
®
CrossFireX™ technology that allows you to install multi-graphics processing units (GPU) graphics cards. Follow the installation procedures in
•
•
•
6.1.1 Requirements
In Dual CrossFireX mode, you should have two identical CrossFireX-ready graphics cards or one CrossFireX-ready dual-GPU graphics card that are AMD® certified.
Ensure that your graphics card driver supports the AMD CrossFireX technology.
Download the latest driver from the AMD website (www.amd.com).
Ensure that your power supply unit (PSU) can provide at least the minimum power required by your system. See Chapter 1 for details.
• We recommend that you install additional chassis fans for better thermal environment.
• Visit the AMD Game website (http://game.amd.com) for the latest certified graphics card and the supported 3D application list.
6.1.2 Before you begin
For AMD CrossFireX to work properly, you have to uninstall all existing graphics card drivers before installing AMD CrossFireX graphics cards to your system.
To uninstall existing graphics card drivers:
1. Close all current applications.
2. For Windows XP, go to Control Panel > Add/Remove Programs.
For Windows 7/Vista, go to Control Panel > Programs and Features.
3. Select your current graphics card driver/s.
4. For Windows XP, select Add/Remove.
For Windows 7/Vista, select Uninstall.
5. Turn off your computer.
ASUS M5A97 EVO R2.0
6-1
6-2
6.1.3 Installing two CrossFireX™ graphics cards
The following pictures are for reference only. The graphics cards and the motherboard layout may vary with models, but the installation steps remain the same.
1. Prepare two CrossFireX-ready graphics cards.
2. Insert the two graphics card into the
PCIEX16 slots. If your motherboard has more than two PCIEX16 slots, refer to Chapter 1 in this user manual for the locations of the PCIEX16 slots recommended for multi-graphics card installation.
3. Ensure that the cards are properly seated on the slots.
4. Align and firmly insert the CrossFireX bridge connector to the goldfingers on each graphics card. Ensure that the connector is firmly in place.
Goldfingers
Chapter 6: Multiple GPU support
5. Connect two independent auxiliary power sources from the power supply to the two graphics cards separately.
6. Connect a VGA or a DVI cable to the graphics card.
6.1.4 Installing the device drivers
Refer to the documentation that came with your graphics card package to install the device drivers.
Ensure that your PCI Express graphics card driver supports the AMD® CrossFireX™ technology. Download the latest driver from the AMD website (www.amd.com).
6.1.5 Enabling the AMD
®
CrossFireX™ technology
After installing your graphics cards and the device drivers, enable the CrossFireX™ feature through the AMD VISION Engine Control Center in Windows environment.
Launching the AMD VISION Engine Control Center
To launch the AMD VISION Engine Control Center:
1. Right-click on the Windows
®
desktop and select AMD
VISION Engine Control Center.
ASUS M5A97 EVO R2.0
6-3
6-4
Enabling Dual CrossFireX technology
1. In the AMD VISION Engine Control Center window, click Performance > AMD
CrossFireX
TM
.
2. Select Enable CrossFireX
TM
.
3. Select a GPU combination from the drop-down list.
4. Click Apply to save and activate the GPU settings made.
2
1
3
4
Chapter 6: Multiple GPU support
Appendices
Notices
Federal Communications Commission Statement
•
•
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received including interference that may cause undesired operation.
•
•
•
•
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
ASUS M5A97 EVO R2.0
A-1
A-2
IC: Canadian Compliance Statement
Complies with the Canadian ICES-003 Class B specifications. This device complies with RSS
210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations.
This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Cut appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Cet appareil est conforme aux normes CNR exemptes de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes :
(1) cet appareil ne doit pas provoquer d’interférences et
(2) cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité de l’appareil.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
VCCI: Japan Compliance Statement
VCCI Class B Statement
KC: Korea Warning Statement
Appendices
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.
DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in different regions.
ASUS M5A97 EVO R2.0
A-3
A-4
ASUS contact information
ASUSTeK COMPUTER INC.
Address
Telephone
Fax
Web site
15 Li-Te Road, Peitou, Taipei, Taiwan 11259
+886-2-2894-3447
+886-2-2890-7798 [email protected]
www.asus.com.tw
Technical Support
Telephone
Online support
+86-21-38429911 support.asus.com
ASUS COMPUTER INTERNATIONAL (America)
Address
Telephone
Fax
Web site
800 Corporate Way, Fremont, CA 94539, USA
+1-812-282-3777
+1-510-608-4555 usa.asus.com
Technical Support
Telephone
Support fax
Online support
+1-812-282-2787
+1-812-284-0883 support.asus.com
ASUS COMPUTER GmbH (Germany and Austria)
Address
Fax
Web site
Online contact
Harkort Str. 21-23, D-40880 Ratingen, Germany
+49-2102-959911 www.asus.de
www.asus.de/sales
Technical Support
Telephone
Support Fax
Online support
+49-1805-010923*
+49-2102-9599-11 support.asus.com
* EUR 0.14/minute from a German fixed landline; EUR 0.42/minute from a mobile phone.
Appendices
ASUS M5A97 EVO R2.0
A-5
A-6
Appendices
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Key Features
- AMD Socket AM3+ AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
- PC ATX AMD 970 Realtek ALC887 7.1 channels
- DDR3-SDRAM 4 DIMM ECC Non-ECC Maximum internal memory: 32 GB
- SATA III
- Quad-GPU CrossFireX
- BIOS type: UEFI 64 Mbit ACPI version: 2.0a Clear CMOS jumper
- Gigabit Ethernet
