Motorola FLIPOUT features a unique swivel touchscreen that reveals a full QWERTY keypad for easy typing. It seamlessly syncs all your contacts, email, messages, and status updates from various accounts into one place with MOTOBLUR, accessible from your phone or computer. Stay connected with friends and family through social networking integration and enjoy thousands of apps from Android Market™. Capture life's moments with the 3MP camera and video recorder, and expand your storage with a microSD card (sold separately).
advertisement
SOMETHING TO FLIP OVER.
MOTOBLUR
Congratulations
MOTOROLA FLIPOUT with MOTOBLUR
Introducing the MOTOROLA FLIPOUT with
MOTOBLUR - an innovative phone that's as unique as you are. Most intriguing is how its touch screen rotates on a hinge to expose a QWERTY keypad with a separate number row for easy.
MOTOBLUR is the only service that can sync all your friends, emails, messages, Facebook™, MySpace,
Twitter and happenings with continuous updates and back-ups, along with the ability to remotely locate and wipe your phone if its lost or stolen.
More information
• Answers: Touch Home > Help Center .
• Updates: Phone updates, PC software, online help and more at www.motorola.com/myflipout.
• MOTOBLUR: After you create a MOTOBLUR account, open it at www.motorola.com/mymotoblur.
• Accessories: Find accessories for your phone at www.motorola.ca.
Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your phone.
Congratulations 1
Your phone
the important keys & connectors
Volume Keys
Tou s c c hreen
Menu Key
Open m enu options.
3.5mm
He a dset J ac k
M ic ro USB Conne c tor
Charge or connect to PC.
Power Key
Press to put the display to sleep or hold to turn off.
B ac k Key
Home Key
Return to ho m e screen.
W hen you open or turn your phone, the screen adjusts for you.
Sh i ft
S c roll & Sele c t
Altern a te
S pac e
Note: Your phone might look a little different.
Delete
Enter
OK
Se a r c h
Sym b ols
2 Congratulations
Contents
Your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 6
Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Google Maps™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 29
Wi-Fi™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
USB & memory card (optional) . . . . . . . . . . . . . . . . 43
Synchronize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 51
Let’s go
let’s get you up and running
Assemble & charge
1 Cover off 2 SIM in
3 MicroSD in (may already be inserted)
4 Battery in
5 Cover on 6 Charge up
3H
Caution: Please read “Battery Charging” on page 52.
Let’s go 3
Set up & go
Create or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on page 10.
Registration is secure, and should only take a few minutes.
Note: Before you use MOTOBLUR, read the terms and conditions during registration and if you agree, touch
Agree
.
1 Turn on.
2 Select a language.
3 Register or log in.
Tip: Open your phone to type.
Login to your MOTOBLUR account
MOTOBLUR ID: Your email address
Password: ********
Forgot Password?
Back
Logging into MOTOBLUR
Next
If you have not created a MOTOBLUR account, you’ll need to register: Enter your name, your current email address (where
MOTOBLUR can send account information), and a new
MOTOBLUR account password.
Tip: You can also skip
MOTOBLUR setup by tapping Setup account later
.
4 Let’s go
4 Add your accounts to
MOTOBLUR.
Set up existing accounts
If you use any of the services below, tap the icon to set it up or long press the icon for more detials.
MOTOBLUR Accounts
MySpace Facebook Last FM Twitter Email
Finished adding accounts
5 Import your SIM contacts.
To add an account, touch it. Then, enter the user name or email and password that you set up on that account.
Tip: For more, or to add accounts anytime, go to “Add account” on page 11.
After you sign in, your phone will automatically start to import your SIM contacts.
Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details.
Turn it on & off
To turn on your phone, press and hold Power the right side of the phone).
To turn off your phone, press and hold Power touch Power off .
(on
, then
Wi-Fi™ connect
If you want to use a Wi-Fi computer network for even faster Internet access, touch Menu > Settings
>
Wireless & networks
>
Wi-Fi settings
.
Cool content & more
Browse and download thousands of the coolest apps on the planet from Android Market™ (see “Apps for all” on page 29).
Note: Some features are not available in some areas or with some service providers.
Your phone comes with a microSD memory card installed—you can load it up with photos, videos, and music from your computer using “USB drag & drop” on page 43.
Security
Your contacts are backed-up on MOTOBLUR, so don’t worry. Even if you lose your phone, MOTOBLUR can help you find it or wipe it. And when you get your next
MOTOBLUR product, your stored info makes it a snap to set up with just a username and password.
Of course it doesn't stop there. There are plenty of ways to protect your phone and your information, in “Security” on page 48.
Let’s go 5
Touchscreen & keys
a few essentials
Touch tips
Here are some tips on how to navigate around your phone.
Touch
To choose an icon or option, touch it.
298 minutes away from cake.
8:52
Touch & hold
To open special options, touch and hold an icon or other item. Try it: In the home screen, touch
Contacts , then touch and hold a contact to open options.
Trevor Gilley
Black turtleneck and a beret, and
OTTAWA
Jones Lara just found a black...
26 minutes ago
Messaging
Browser
Benji Mans
Jennie Jenkins
Leo Heaton
Drag
To scroll through a list or move slowly, drag across
Alex Pico the touchscreen. Try it: In the home screen, touch
Contacts , then drag your Contacts list up or down.
Benji Mans
Jennie Jenkins
Leo Heaton
Tip: When you drag or flick a list, a scroll bar appears on the right. Drag the scroll bar to move the list to a letter A - Z.
Flick
To scroll through a list or move quickly, flick across the touchscreen (drag quickly and release).
Tip: When you flick a long list, touch the screen to stop it from scrolling.
Pinch-to-zoom
Get a closer look at maps, web pages, or photos. To zoom in, touch the screen with two fingers and then slide them apart. To zoom out, drag your fingers together.
6 Touchscreen & keys
Key tips
Menu, home, & back
Touch Home to close any menu or app and return to the home screen.
In the home screen, touch and hold Home to show the last few apps you used, then touch an app to open it.
Press Search for text search.
Touch Menu
Back
to open menu options, or touch
to go back.
Sleep & wake up
To save your battery, prevent accidental touches, or when you want to wipe smudges off your touchscreen, put the touchscreen to sleep by pressing
Power
Power
. To wake up the touchscreen, just press
again, or open the phone.
To change how long your phone waits before the screen goes to sleep automatically, touch Menu
>
Settings
>
Sound & display
>
Screen timeout
.
Tip: To make the screen lock when it goes to sleep, use “Screen lock” on page 48.
Power key menu
Press and hold Power to open the power key menu, where you can turn off the phone ( Power off ), or turn
Airplane mode
or
Silent mode
on or off.
Adjust volume
Press the volume keys to change the ring volume (in the home screen), or the earpiece volume (during a call).
Tip: To silence the ringtone with a double tap, or to switch to vibrate mode by placing your phone face down, touch Menu > Settings > Sounds & display
>
Double-Tap to Silence
or
Smart Profile:
Face Down to Vibrate .
Spin the screen
The touchscreen can rotate 90 degrees in some apps, such as messaging and contacts, to stay right-side up when you rotate your phone:
Find it: Menu > Settings > Sound & display
> Orientation
Touchscreen & keys 7
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information in one place. It’s what you see when you turn on the phone or touch Home from a menu. It’s basically like this:
OTTAWA
298 minutes away from cake.
Trevor Gilley
Black turtleneck and a beret, and
Jones Lara just found a black...
26 minutes ago
Messaging Browser
11:46
Not i f ica t i ons
Flick this bar down to see details.
St a tus Ind ica tors
Your Onl i ne St a tus
Touch to change your status.
Open the m ain m enu.
W i d g ets
Touch to open, or touch & hold to m ove or delete.
Flick left or right to open m ore panels of widgets.
Short c uts
Touch to open.
Note: Your home screen might look a little different.
Use & change your home screen
On your home screen, shortcuts are icons that you open your favorite apps, Web bookmarks, contacts,
8 Home screen mail labels, or music playlists. Widgets show you news, weather, messages, and other updates.
Flick the home screen left or right to open other panels of shortcuts and widgets.
• To open something, touch it. Touch Home to return to the home screen.
• To change a widget’s settings, open it and then touch Menu >
Settings
.
You can find details about the settings for
Happenings
(“Add account” on page 11),
Messages (“Set up messaging” on page 20), Music
(“Music” on page 39), Social Status (“Update your status” on page 10), or News or Weather
(“Widgets” on page 35).
• To add something or change your wallpaper , touch and hold an empty spot until you see the
Add to
Home screen menu.
You can add a folder to organize your shortcuts.
• To move or delete something, touch and hold it until you feel a vibration, then drag it to another spot, another panel, or the trash on the lower right of the screen.
Running multiple apps
No need to close an app before opening another one.
Your phone runs multiple apps, all at once.
You can open a new app while already running another.
Touch Home to return to the home screen. Open the Applications tab and touch the app you want. To switch from one running app to another, touch and hold Home to see what apps are already open, then touch the one you want. You can view up to the last six apps that you ran.
Search
To search, touch Search on the front of the phone, or press Search on the QWERTY keypad.
Phone status & notifications
At the top of the screen, icons on the left notify you about new messages or events (flick the bar down for details). Icons on the right tell you about phone status:
3G
Bluetooth™ active
GPS active
Wi-Fi™ active
11:35 network (full signal) network (roaming) downloading mute call signal (roaming) speakerphone active
GPRS (fast data) battery (charging) battery (full charge) alarm set
EDGE (faster data)
Tip: To see today’s date, touch and hold the status bar at the top of the screen.
Main menu
Quick start: Main menu
The main menu shows you all of your applications. To open it from the home screen, touch . To close it, touch Home .
Note: Your main menu will vary.
Tip: To find an app in the main menu, open your phone
(or touch and hold Menu to open a display keypad), then type the app name.
Home screen 9
Recent apps
Touch and hold Home to see the last few apps you used, then touch the app you want. Touch Home to return to the home screen.
Social networking
my life, your life
Your MOTOBLUR account
The first time you turned on your phone, you registered for a MOTOBLUR account that manages your messages, contacts, and more (“Set up & go” on page 4). You can log into this account from a computer to upload contacts, reset your password, get help, or even locate your phone: www.motorola.com/mymotoblur
What is MOTOBLUR?
MOTOROLA FLIPOUT with MOTOBLUR is a phone with social skills.
MOTOBLUR is the only service that can sync all your friends, emails, messages, Facebook™, MySpace,
Twitter and happenings with continuous updates and back-ups, along with the ability to remotely locate and wipe your phone if its lost or stolen.
Update your status
After you add a social networking account, you can update and see your current status in a Social Status widget on your home screen.
To update your status, just touch your Social Status widget and enter text. If you have more than one
10 Social networking
account, you can use the pull-down menu to limit which accounts are updated. If you don’t see a
Social
Status widget, flick your home screen left or right to check all panels.
To add a Social Status widget:
1 Touch and hold an empty spot on your home screen to open the Add to Home screen menu.
2 Touch
Motorola widgets
>
Social Status
. The widget appears in the empty spot, and will show your status the next time your phone updates from the network.
Add account
If you skipped setting up a MOTOBLUR account when you first turned on your phone, you’ll need to set up a
MOTOBLUR account before you can add other accounts. In your home screen, touch Set up Your
Blur account and follow the steps in “Set up & go” on page 4.
Note: You can add your Facebook, MySpace, Twitter, or other accounts to your phone. If you don’t have accounts, you can visit their Web sites to set them up.
Find it: Menu >
Settings
>
Accounts
>
Add account
To sign into your account, use the user name or email and password that you set up on that account (the same as on your computer).
When you sign into social networking accounts, you’ll see your friends and contacts in your Contacts list, and your status and updates can appear in Social
Status and Happenings widgets.
Note: Twitter and MySpace messages will always appear as “read” on your phone, but your phone notifies you when you receive a new message.
MySpace marks your messages as “read” online.
For email accounts, see “Set up messaging” on page 20.
Tip: To download updates faster, use “Wi-Fi™” on page 31.
View account updates & features
After you add a social networking account, you can see and respond to friends’ updates with the Happenings widget on your home screen. If you don’t see one, set one up in “Widgets” on page 35.
When you touch the Happenings widget to open an update, you can touch to open its Web site.
Note: Your network or other factors might affect the speed of widget updates.
Social networking 11
Edit & delete accounts
Find it: Menu > Settings > Accounts
Touch and hold an account, then touch
Open account to edit it, or touch Remove account to remove it
(along with its contacts and messages).
Calls
it’s good to talk
Quick start: Calls
Dialing options
Find it:
Dialer
Delete
Delete a digit.
11:46
Call
1
4
GHI
7
PQRS
*
2
ABC
5
JKL
8
TUV
0
+
3
DEF
6
MNO
9
WXY
#
More O p t i ons
Touch for voice m ail, speed dial, and frequent calls.
Se a r c h Cont ac ts or Add Cont ac t
Re c ent C a lls
C a ll
Enter a phone nu m ber and touch here to call it.
12 Calls
In-call options
Active call ( 00:12 )
Alex Pico
Mobile (555) 555-2505
C a ll T i mer
D ia l P a d
Open to enter nu m bers during a call.
End C a ll
Hang up.
End call Mute
Mute or un m ute the call.
Bluetooth Mute Speaker
S p e a ker p hone
Turn speakerphone on or off.
Bluetooth
Turn Bluetooth on or off.
During a call, touch Menu to choose Hold , New call
,
Use Bluetooth
, or
Voice Quality
. Your touchscreen goes dark to avoid accidental touches. To wake it up, press Power .
Tip: You can touch Home or Back active call display. To reopen it, touch
to hide the
Dialer .
Make & answer calls
Note: Unless you have a headset connected, you need to open the phone to make and answer calls.
To make a call, open the phone, touch enter a number, then touch Call .
Dialer
,
To answer a call, open the phone or drag
Answer
to the right
(when your phone is unlocked,
Answer is just a touch button).
Press Power/Lock button to ignore.
Ignore Answer End Call + Answer
Tip: Flip your phone face down to switch to vibrate or double-touch to silence the ring. For these quick options, touch Menu > Settings > Sound & display
>
Double-Tap to Silence
or
Smart Profile:
Face Down to Vibrate .
End calls
Touch
End call
.
End call
Voicemail
Find it: Dialer , and then touch 1 .
Speed dial
Find it:
Dialer
> Menu >
Speed Dial
• To call a number, touch it.
• To add, edit, or clear entries, touch Menu .
Frequent calls
Find it:
Dialer
> Menu >
Frequent
• To call a number, touch it.
Calls 13
• To send a text message, view a contact, add the call to speed dial, or other options, touch and hold an entry.
Handsfree
Note: Using a mobile device or accessory while driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
During a call:
• To use the speakerphone, touch
Speaker
.
• To use a Bluetooth™ device, touch Bluetooth .
Voice commands
Find it:
Voice commands
, and then say a command.
Mute & hold
During a call:
• To mute the current call, touch Mute .
• To put a call on hold, touch Menu >
Hold
.
Enter numbers during a call
To enter numbers during a call, touch and then touch the dial pad.
14 Calls
Conference calls
To start a conference call, call the first number. After they answer, touch Menu > New call and call the next number. When the next number answers, touch Menu > Join .
Your phone number
Find it: Menu >
Settings
>
About phone
>
Status
>
My phone number
Your caller ID
To hide your number from the people you call, touch Menu >
Settings
>
Call settings
>
Additional settings
>
Caller ID
.
Emergency calls
Note: Your service provider programs one or more emergency phone numbers (such as 911 or 112) that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country.
Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.
1 Open the phone, then touch Dialer (if your phone is locked, touch Emergency Call or touch Menu >
Emergency call
).
2 Enter the emergency number.
3 Touch Call to call the emergency number.
Note: Your mobile device can use AGPS satellite signals to help emergency services find you (see “GPS
& AGPS” on page 53).
Call forwarding & waiting
You can forward calls all the time or only when your phone is busy, unanswered, or unreachable (not on the network):
Find it: Menu > Settings > Call settings > Call forwarding
When you’re on a call and a second call comes in, Call waiting
lets you answer it by touching
Answer
. You can turn off Call waiting to send second calls straight to your voicemail:
Find it: Menu > Settings > Call settings >
Additional settings > Call waiting
Restrict outgoing calls
To restrict your phone so that it can only dial a few numbers:
Find it: Menu dialing number
> Settings > Call settings >
• To turn fixed dialing on, touch FDN disabled .
Fixed
• To add or delete the allowed numbers, touch Manage FDN list .
Calls 15
Contacts
contacts like you’ve never had before
Quick start: Contacts
Find it:
Contacts
Contacts A-Z
Contacts: All contacts
Alex Pico
8:52
Grou p
Touch Menu to choose which group to show (like
All, Favorites, or Facebook).
Touch to add a contact.
Dan Smith
Cont ac ts L i st
Touch to view contact infor m ation. Touch & hold to send e m ail, delete, and m ore
Kate Shunney
Tip: To search the list, touch and hold Menu >
Search , then type a name. When you flick or drag this list, a scroll bar appears on the right. Drag the scroll bar to move the list faster.
Import contacts from your SIM
Note: You might have already done this during “Set up
& go” on page 4.
16 Contacts
If you need to import the contacts from your SIM card, touch
Contacts
, then touch Menu >
Settings
> Manage SIM card .
Call, text, or email contacts
Find it:
Contacts
For View contact , Send email , Delete contact , touch and hold the contact.
View & use contacts
With a MOTOROLA FLIPOUT with MOTOBLUR, you’ll know what everybody’s up to and when. Every time you pick up a call, check a message, or look up a friend’s contact info, sure, you’ll see their name and number, but you’ll see their social network status and smiling face, too.
Find it: Contacts
• To filter the contacts by group (
All
,
, and so on) touch Menu > Display group .
Tip: To change which account provides the pictures for your Contacts , from the home screen touch Menu > Settings > Accounts >
Menu >
Picture source
.
• To find a contact, just type the name.
Touch a contact to open their details. To start a call or message, just touch their phone number or other info.
• To change the list view to History (recently used),
A-Z
(list without status), or
Status
(list with status), flick the screen to the left or right.
Edit or delete contacts
Find it:
Contacts
Touch the contact, then touch Menu > Edit or
Delete
. You can set a ringer, address, and other details that will be saved on your phone and your MOTOBLUR account.
Where are contacts edited or deleted?
Your phone edits the contacts in its memory, and also updates your MOTOBLUR account. Your changes won’t affect your SIM card.
Link contacts
You might have two Contacts for the same person, maybe a Facebook friend who is also stored on your
SIM card, or one friend with two email addresses. To combine these two contacts:
Find it:
Contacts
Touch a contact to open it, then touch Menu >
Link contact
and touch the second entry. Your
MOTOBLUR account remembers this connection.
Create contacts
Find it:
Contacts
> Menu >
Add contact
Open your phone to type the name and details.
Add contact
First name
Last name
Phone
Emails
Save Cancel
+ adds another entry.
To see m ore details, flick up.
When you’re finished, touch Save .
Where are contacts saved?
Your phone saves new contacts in its memory, your MOTOBLUR account, and other accounts you select: In Contacts , touch Menu >
Settings
to choose which accounts get updated. New contacts won’t be on your SIM card, but they will download to any new MOTOBLUR phone when you log into your MOTOBLUR account.
Contacts 17
Synchronize contacts
Note: You might not have this feature. For details, ask your service provider. To synchronize contacts in your service provider account, ask your service provider.
When you change one of your Contacts , your phone automatically updates your MOTOBLUR account online. Also, your phone updates your Contacts and
MOTOBLUR account whenever you change a friend in your social networking accounts.
So, you don’t have to do anything to synchronize your
Contacts with your other accounts! MOTOBLUR takes care of it for you.
My details
Find it: Contacts > Menu > My info
To edit details, touch them.
Groups
You can put your Contacts into groups that you create
(like “friends,” “family,” or “work”). Then, you can find contacts faster by showing one group at a time.
To create a group in your Contacts , touch Menu >
Display group
>
Create new group
. Enter a group name, then touch Add to add members. When you’re finished, touch Done .
To show only one group in your Contacts , touch
Contacts at the top of your screen and choose the group name.
18 Contacts
Messaging
sometimes it’s best to text, or IM, or email . . .
Quick start: Messaging
Find it: Home > >
Messaging
>
Universal
Inbox
Universal Inbox (4)
Check for m essages now.
Touch to add a contact.
Alex Pico
8:34 PM
Some guys have all the luck - me...
Right now, you’re busy flexing...
Keith Zang
Job
Sep 25
It’s only a freelance gig, but it pays...
Mess ag e L i st
Touch to open a m essage.
Touch & hold to m ove, delete, and m ore.
Touch to select m ultiple m essages to m ove, delete, and m ore.
Or, touch Menu > Sele c t a ll or Desele c t a ll .
Tip: To see more messages, flick or drag up.
Read & reply to messages
Every text, email, friend-feed, wall post, and bulletin is automatically delivered to you, ready for your immediate reply with the flip-open keypad. The best part is you don’t have to dig through any apps, screens or menus—every message streams right to the phone, viewable exactly the way you want.
Find it: Home > > Messaging > Universal
Inbox
Note: Universal Inbox shows all of your messages together—text, email, and social networking messages. To show only one type of message, touch a message account type instead of Universal Inbox .
• To open a message and all of its replies, touch it.
• To respond to a message, just open it and enter your response in the text box at the bottom.
• To open options, touch and hold a message.
Tip: Add the Messages widget to your homescreen, see “Widgets” on page 35.
Create messages
Find it: Home > > Messaging > >
Compose
Choose a message type. Then, enter the recipient and message. In text messages and emails, touch Menu to add files or choose other options.
Send & receive attachments
To send a file in a message, open a new message, touch Menu , and choose the file.
Messaging 19
When you receive a message with an attachment, open the message and touch the file name to download it. Then, touch the name again to open it.
Some file formats can be converted to HTML for faster viewing, and your phone will show a button that says
Get HTML version
.
Tip: To send and receive large attachments faster, use a Wi-Fi connection, in “Wi-Fi™” on page 31.
Set up messaging
To add email accounts, in the home screen touch Menu >
Settings
>
Accounts
>
Add account .
•
Corporate Sync
is for Exchange server work email accounts. Enter details from your IT administrator.
Tip: You might need to enter your domain name with your user name (like domain/username )
Note: Some work accounts might require you to add a password lock to your phone, for security. To stop an account from showing the contacts you create on your phone, touch
Contacts
, touch Menu > Settings , then uncheck the account under New contacts .
• Email is for most personal email accounts. For account details, contact the account provider.
20 Messaging
To change your settings, touch Home > >
Messaging
> Menu , then touch:
• Manage accounts to change your user name or password (or server settings, for email).
• Edit Universal Inbox to choose which accounts show messages in the
Universal Inbox
.
• Messaging Settings to set the notification for each account type (along with other preferences, for email).
To get G mail™ in your Messages widget and
Universal Inbox , you’ll need to add it as an Email account: Touch Home > > Messaging >
Menu , then touch Manage accounts > Add account
>
and enter your Gmail™ details. If you added your Google account too, turn off its email sync to avoid duplicate email notices: Touch >
Accounts
, touch your Google™ account, and touch the checkmark to turn off Gmail .
Tip: For social network accounts, see “Add account” on page 11.
Instant messages
Note: You might not have this feature. For details, ask your service provider.
To send and receive instant messages, you can use the
IM
app, Google Talk™, another instant messaging app, or your browser.
Find it: >
Talk
• To download and use an instant messaging app, touch Home > >
Market
>
Apps
>
Communication , then choose an app for your provider. Once you download the app, you’ll see it in
“Main menu” on page 9.
• If you don’t see an app for your IM provider, you can use your Web browser. Touch Home > >
Browser
. Touch the Web address field, then enter your provider’s Web site, and touch Go . Once you’re there, follow the link to sign in.
Note: Your IM options will depend on your IM provider.
To browse instant messaging apps from your computer, go to www.android.com/market.
Voicemail
When you have a new voicemail, shows at the top of your screen. To hear the voicemail, touch Dialer , then touch and hold .
If you need to change your voicemail number, in the home screen touch Menu > Settings > Call settings > Voicemail settings .
Text entry
think keyboard, now think smaller
Typing tips
To use the full keypad, just open your phone:
To...
Enter symbols chosen from a list
Press Symbols
Press Alternate Enter alternate characters at the top of the keys
Enter several alternate characters, until you press
Alternate again
Enter one capital letter
Press Alternate twice
Press Shift
Press Shift twice Enter only capital letters, until you press Shift again
Select text
Cut , Copy , or you selected
Paste text
Hold Shift press Scroll
+
Touch and hold the text box to open the editing menu
Text entry 21
To...
Select
Cut ,
text
Copy , or you selected
Paste text
Hold Shift press Scroll
+
Touch and hold the text box to open the editing menu
Delete a character (hold to delete more)
Delete the current line
Press Delete
Jump to the beginning/end of a line
Press Alternate +
Delete
Press Alternate +
Scroll
Press Enter Start a new line (email or social networking) or send the message (text messages)
To change your text entry settings and see the dictionary of terms you’ve used, from the home screen, in the home screen touch Menu >
Settings > Language & keyboard .
22 Text entry
Touchscreen keypad
When your phone is closed, you can open a display keypad by touching a text field, or touching and holding Menu . To close the keypad, touch Back .
Done
Text Entry
Touch to open the touchscreen keypad.
Delete
:-) Emot ic on
Sh i ft S pac e
Sym b ols/Num b ers
Touch to open a keypad for sy m bols and nu m bers.
Touch Alt for m ore sy m bols.
To change your settings for this keypad, from the home screen, touch Menu > Settings > Language & keyboard > Android keyboard .
Text entry settings
When you use the touchscreen keypad, your phone suggests words from your dictionary and chosen
language. Your phone also automatically enters apostrophes in some words, like “dont.”
Find it: In the home screen touch Menu >
Settings
>
Language & keyboard
• To edit your dictionary, touch User dictionary .
• To change the language and the style for your touchscreen keypad, touch Select locale .
• To change the sounds, corrections, and other settings for your touchscreen keypad, touch
Android keyboard
.
• To change the automatic correction settings for your full keypad, touch
Device keyboard
.
Web
you don’t need a computer, surf the web with your phone
Quick start: Browser
Find it: > Browser
8:52 www.google.com: Google
Web Images Local News more
New Window
Refresh
Google Search
My Location: Off - Turn On
Sign in Preferences Help
View Google in: Mobile
©2009 Google
Classic
Bookmarks
Forward
Windows
More
Note: If you can’t connect, contact your service provider.
Connect
Your phone uses the mobile phone network (over the air) to automatically connect to the Web.
Note: Your service provider may charge to surf the
Web or download data.
To use a wireless network, in the home screen touch Menu >
Settings
>
Wireless & networks
.
Touch Wi-Fi to turn it on, then touch Wi-Fi settings to
Web 23
search for nearby wireless networks. Touch a network to connect. There’s more in “Wi-Fi™” on page 31.
Web touch tips
Zoom & magnify
In Web pages, when you scroll (drag or flick), zoom icons appear at the bottom of your screen.
www.google.com: Google
Zoom In/Out
M ag n i fy
Open a m agnifying window that you can drag.
Android | Official Website
Official site for the development of the open source project. Provides a directory of applications and links to download the source ..
www.android.com/ - Options
More from www.android.com »
Android Market
Tip: Use pinch-to-zoom to zoom in/out, see
“Pinch-to-zoom” on page 6.
Select links
When you touch a link, your source/android.com/ - Options phone outlines it. If you
Android Community - Tracking the Android
Platform touch and hold the link, your phone shows options, like Cache or Mobile format .
24 Web
Browser options
Touch Menu to see browser options: options
New window
Bookmarks
Windows
Refresh
Forward
More
Add a new browser window to your list.
Shows a list of your bookmarks.
Touch Add bookmark...
to add the current page to your list.
View the browser windows that are currently open.
Reloads the current page.
Navigate to a previously viewed page.
Shows browser options, like
Find on page , Select text , Page info ,
Share page , Downloads , and
Settings
.
Download apps
Warning: Apps downloaded from the Web can be from unknown sources. To protect your phone and
personal data, only download apps from sources you trust, like “Apps for all” on page 29.
Note: All apps downloaded are stored in your phone memory.
To download apps:
1 If you want to download apps from any Web page, touch Menu > Settings > Applications >
Unknown sources
.
2 To launch the browser, touch > Browser .
3 Find the app you want to download and touch the download link.
Manage your downloads
To view files or applications you have downloaded, touch >
Browser
> >
More
>
Downloads
.
To clear your download history, touch Menu >
Clear list
. To cancel, touch Menu >
Cancel all downloads
.
Google Maps™
where you are, where you’re going
Note: This feature is not available in all areas. Check with your service provider.
Quick start: Google Maps
Where am I? Where do I want to go? Don’t worry—let
Google Maps™ find out for you.
Find it: Home > >
Maps
8:52
My Location
Accurate to 1800 meters
M ap V i ew
Drag or flick to scroll.
Tap to show zoo m .
Search
My Location
Directions
Join Latitude
Layers
More
Touch to show options.
Google Maps™ opens by default in “Map mode”. To learn more about the different map modes, go to
“Select map mode” on page 26.
Tip: Use pinch-to-zoom to zoom in/out, see
“Pinch-to-zoom” on page 6.
Note: Some features are not available in some areas or with some service providers.
Google Maps™ 25
Set your location sources
Set your phone to determine your location using GPS satellite signals (highly accurate, but uses battery power) or using the mobile network (less accurate, but conserves battery power).
To set your location, touch Menu >
Settings
> Location & security > Use GPS satellites and/or
Use wireless networks .
Find your location
Note: Don’t forget to set your location sources.
From the main Map screen, touch Menu >
My
Location . Your location is shown on the map as .
The bigger the circle, the less accurate the location.
Find any location
1 Touch Menu >
Search
.
2 Enter text in the search box, like an address, business, or city, then touch .
Tip: If it’s an address you have visited before, select from the list shown.
3 Touch the search box to view all the results, then touch the one you want. Select
Show on map
,
Get directions , Search nearby , or Add as a contact .
26 Google Maps™
Get directions
1 Touch Menu > Directions .
2 Enter a starting point address or touch and select
My location , Contacts , or Points on map .
3 Enter an end point address or touch and select
Contacts or Points on map .
4 Select your mode of transport (car, public transport or walk), then touch Go . Your directions are shown as a list. To view your directions on a map, touch
Show on map
.
5 When you have finished, touch Menu > More
>
Clear Map
.
Select map mode
Touch Menu > Layers to select from Traffic ,
Satellite
,
Latitude
or recent searches, viewed positions or directions.
Touch Menu >
Layers
>
More layers
to select from My Maps , Wikipedia , or Transit Lines .
Touch
Clear Map
to clear your selections.
Map view
Shows a map, complete with names of streets, rivers, lakes, mountains, and borders. This is the default view.
Satellite view
Shows map on top of aerial photo.
Traffic view
If available in your area, real-time traffic conditions are shown on the roads as color-coded lines.
YouTube™
go and create your own classic
Quick start: YouTube
Post that great video you’ve taken and see how many hits you get.
Find it: Home > >
YouTube
8:52
You Tube
TM
Most viewed
Lady Gaga On Saturda...
Lady Gaga appeared together...
1 day ago gol de cabeza de paler...
C a te g or i es
Tap to play.
Search Upload My account Categories Settings
Touch to show options.
YouTube user-generated content web site lets you share videos with YouTube users everywhere. You don’t need a YouTube account to browse and view videos.
Note: If you don’t have a YouTube account, visit http://www.youtube.com to find out more. To create an account or sign in, go to “Your account” on page 28.
YouTube™ 27
Watch videos
See popular video categories, like Most viewed, Most discussed and Most recent. Touch a category, then touch the video to start playing it. To see more video categories, touch Menu > Categories .
Search for videos
Find it: Menu >
Search
Enter text, then touch Search.
Share videos
Send someone a link to a video that you are watching.
1 Touch Menu > Share .
2 Address and complete your email, then touch Send .
Your account
Log in or create account
Find it: Menu > My account
1 To create your YouTube account, touch the “Don’t have a YouTube account? Touch here to create one” link.
If you already have a YouTube account, enter your user name and password, and touch Sign in .
2 For a new account, enter a user name, and complete the fields, then touch I accept .
28 YouTube™
Upload videos
Find it: Menu > Upload
1 Touch the video you want to upload. You can change the video title, description, set the access, and add tags.
2 Touch Upload .
Apps for all
get the app you want
Android Market™
Note: You’ll need to set up a Gmail account (see “Set up messaging” on page 20) in order to buy and download apps from the Android Market.
Find it: Home > > Market
Get all the fun games and cool apps you want!
Market provides you with access to software developers everywhere, so you can find the app you want. If you need help or have questions about Android Market, touch Menu >
Help
.
Browse & install apps
Scroll to and touch the app you want to install. Then, touch Install (if app is free) or Buy .
Warning: If an app you are downloading requires access to your data or control of functions on your phone, you’ll be asked to give your permission. After selecting
Install
, the app will download. After selecting Buy , you may be asked to sign in to an additional Google account. Sign in and select
Purchase now to proceed. Follow the on-screen instructions. To see the download progress, open the notifications window.
After you download an app, the icon for that app appears on your Applications tab.
Manage & restore apps
To manage your apps, in the home screen touch
Menu >
Settings
>
Applications
>
Manage applications .
Touch the app to open the details screen—from here you can review, uninstall, and more.
To reinstall any downloaded items, touch Home
> Market > Downloads . All previously installed apps are listed and available for download.
Apps for all 29
Bluetooth™ wireless
lose the wires and go wireless
Quick start: Bluetooth wireless
Find it: Home >Menu >
Settings
>
Wireless
& networks > Bluetooth settings
Bluetooth settings
Bluetooth
Device name
Smithy
Discoverable
Make device discoverable
Turn on & scan.
Turn Bluetooth power on or off
Find it: Home > Menu > Settings > Wireless
& networks
>
Bluetooth
Note: To extend battery life, turn Bluetooth power off when not in use.
Connect new devices
Note: This feature requires an optional accessory.
To connect with a new device, you need to pair with it.
You only need to do this once for each device—to connect again, just turn on the device.
30 Bluetooth™ wireless
1 Make sure the device you are pairing with is in discoverable mode.
Note: Refer to the guide that came with the device for details.
2 In the home screen touch Menu >
Settings
>
Wireless & networks > Bluetooth settings .
3 Touch
Bluetooth
to turn on and scan. If Bluetooth power is already on, touch Scan for devices .
4 Touch a device to connect.
5 If necessary, touch OK , or enter the device passkey
(like 0000) to connect to the device. When the device is connected, the Bluetooth indicator appears in the status bar.
Note: Using a mobile device or accessory while driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
Reconnect devices
To automatically reconnect your phone with a paired device, simply turn on the device.
To manually reconnect your phone with a paired device, touch the device name in the
Bluetooth devices list.
Disconnect devices
To automatically disconnect your phone from a paired device, simply turn off the device.
To manually disconnect your phone from a paired device, touch the device name in the devices list, then touch Menu >
Disconnect
.
Edit properties
In the home screen touch Menu > Settings >
Wireless & networks
>
Bluetooth settings
>
Device name . Enter a name and touch OK .
Wi-Fi™
home, office, or hotspot
Quick start: Wi-Fi
Find it: Home > Menu >
Settings
>
Wireless
& networks > Wi-Fi settings
Note: Your phone's Wi-Fi features and power levels are not allowed for outdoor operation in France. To avoid unlawful interference with radio signals, do not use the Wi-Fi features in France unless you are indoors.
Use a wireless network for fast Internet access and to download data.
Wi-Fi settings
Turn on & scan.
Wi-Fi
Connected to Smithy’s network
Network notification
Notify me when an open network is available
Wi-Fi networks
Smithy’s network
Connected
Connect.
Turn Wi-Fi on or off
Find it: In the home screen touch Menu >
Settings
>
Wireless & networks
>
Wi-Fi
Wi-Fi™ 31
Note: To extend battery life, turn off Wi-Fi power when not in use.
Wi-Fi search & connect
To find networks in your range:
1 In the home screen touch Menu > Settings >
Wireless & networks > Wi-Fi settings .
2 Touch Wi-Fi to turn on and scan. If Wi-Fi is already on, touch Menu > Scan . Your phone lists the networks it finds within range.
Tip: To see your phone’s MAC address or other
Wi-Fi details, touch Menu >
Advanced
.
3 Touch a network to connect.
4 If necessary, enter Network SSID , Security , and
Wireless password , and touch Connect . When your phone is connected to the network, the wireless indicator appears in the status bar.
Tip: When you are in range and Wi-Fi is on, you will automatically reconnect to available networks you’ve connected to before.
Tips & tricks
a few handy hints
Shortcuts
To...
Return to the home screen
See recently dialed numbers
Sleep/wake your phone
Set lock screen
Google™ search
Show last few apps used
Turn airplane mode on/off
Touch Home .
Touch Dialer > .
To sleep, press Power wake, touch Power
. To
again.
In the home screen touch Menu > Settings >
Location & security
>
Screen lock .
Press Search on the keypad.
In the home screen touch and hold Home .
Press and hold Power
Airplane mode
.
>
32 Tips & tricks
To...
View and control
Bluetooth™ , Wi-Fi
™ and G PS status
Touch and hold an empty spot on your home screen, then touch Motorola widgets >
Bluetooth toggle
,
Wi-Fi toggle
, or
GPS toggle
.
Touch > link .
Zoom in to select a link on a web page
Go to the top of a list
Go to the bottom of a list
Scroll list up one screen
Scroll list down one screen
Sync media to your desktop / laptop
Press Alternate
Scroll down.
up.
Press Shift visit www.motorola.com/ mymedialink
>
Press Alternate > Scroll down.
Press Shift > Scroll
> Scroll
up.
To...
Sync contacts from your desktop
/ laptop to your phone
Show email or updates from a group of friends
Use the MOTOBLUR portal: www.motorola.com/ mymotoblur.
Touch
Contacts
>
Menu > Display group >
Create new group . Create a group, then open the group
(touch
Contacts
at the top of your Contacts list). Flick left or right to see this group’s messages or updates.
Open the Universal Inbox then touch Menu >
Edit
Universal Inbox to choose your accounts.
Change which messages appear in the Universal
Inbox
Add a shortcut on your home screen for an app or contact
Touch and hold an open area on your home screen to open the Add to Home screen menu, then choose
Shortcuts
. Then, you can choose from the
Applications , Bookmark , or
Contacts lists.
Tips & tricks 33
To...
Move a widget shortcut
or Touch and hold the widget or shortcut until you feel a vibration, then drag it to where you want.
Delete a widget or shortcut
Touch and hold a widget or shortcut until you feel a vibration, then drag it to the trash can at the bottom of your screen.
Battery tips
Your phone is like a small computer, giving you a lot of information and apps, at 3G speed, with a touch display! Depending on what you use, that can take a lot of power. So, if you want to save battery life between charges, you could reduce:
• recording or watching videos, listening to music, or taking pictures.
• widgets that stream information to your home screen, like news or weather (“Use & change your home screen” on page 8).
• unused online accounts that you registered with
MOTOBLUR (“Edit & delete accounts” on page 12).
34 Tips & tricks
• GPS, Wi-Fi™, and Bluetooth™ use: Touch and hold an empty spot on your home screen, then touch
Motorola widgets > Bluetooth toggle , Wi-Fi toggle , or GPS toggle to view and control.
• email updates: Touch Messaging > Menu >
Messaging Settings > Email > Email delivery >
Fetch schedule > Every 15 minutes , Every 30 minutes
,
Every hour
,
Every 4 hours
, or
Manually
.
• network speed: in the home screen touch Menu >
Settings
>
Wireless & networks > Mobile networks > Select network >
2G Only saves battery .
• network searching: if you are out of coverage, to keep your phone from looking for networks, press and hold Power to open the Power key menu, then touch Airplane mode .
• display brightness: in the home screen touch Menu > Settings > Sound & display >
Brightness > (dimmer setting) .
• display timeout delay: in the home screen touch Menu > Settings > Sound & display >
Screen timeout > (shorter setting) .
Personalize
add your personal touch
Widgets
To create a new widget:
1 Find an empty spot on your home screen where you want to add a widget, then touch and hold.
Tip: You can flick left or right to open other panels on your home screen.
2 Touch Motorola widgets or Downloaded widgets .
3 Touch the type of widget. If necessary, enter the widget settings.
You can personalize widgets with content that you choose.
Set up widgets
You can customize some widgets. Touch a widget to open it, then press Menu :
• Happenings : Update your status, choose which accounts appear in this widget, or manage your accounts (the same as “Add account” on page 11).
• Messages : Change the widget name or choose how long it shows new messages. To add email accounts, “Set up messaging” on page 20.
• Music : Set this widget to an artist, album, song, playlist, or just press
Shuffle All Songs
. There’s more about “Music” on page 39.
•
News
: Change the widget name, choose how long it shows new stories, or choose a news source. To choose a source, touch , then choose preset
Bundles or Channels , or choose Custom to enter a
URL for a
Webpage
or an
RSS feed
.
• Weather : Change temperature units or add locations. To add locations, touch , enter a city, and touch Search . When you open the weather widget, flick left to see other locations you added.
Note: Some apps have custom widget types that you can add and set up after you install the app.
Ringtones
To personalize your ringtones:
Find it: In the home screen touch Menu
> Settings > Sound & display > Phone ringtone or
Notification ringtone
To set your vibrate options:
Find it: In the home screen touch Menu
> Settings > Sound & display > Phone vibrate
Personalize 35
Wallpaper
To apply a new wallpaper:
1 Find an empty spot on your home screen, then touch and hold.
2 Touch
Wallpapers
.
3 Touch Media gallery to select a photo as your wallpaper, or touch
Wallpaper gallery
to choose a wallpaper that comes with your phone.
Sounds
• To set volume for media and videos, in the home screen touch Menu > Settings > Sound & display > Media volume .
• To play tones when using dial pad, in the home screen touch Menu > Settings > Sound & display
>
Audible touch tones
.
• To play sound on a screen selection, in the home screen touch Menu >
Settings
>
Sound & display > Audible selection .
Display settings
• To set display brightness, in the home screen touch
Menu >
Settings
>
Sound & display
> Brightness .
36 Personalize
• To set orientation, in the home screen touch
Menu >
Settings
>
Sound & display
> Orientation .
• To set animation, in the home screen touch
Menu > Settings > Sound & display
> Animation .
Quick launch shortcuts
To set keyboard shortcuts to launch your favorite app, in the home screen touch Menu > Settings
> Applications > Quick launch > Assign application
.
To use a quick launch shortcut, press Search and the assigned key, like Search and B to launch the browser.
Date & time
Set date, time, time zone, and formats:
Find it: In the home screen touch Menu
> Settings > Date & time
Language & region
Set your menu language and region:
Find it: In the home screen touch Menu
>
Settings
>
Language & keyboard
>
Select locale
Photos & videos
see it, capture it, share it!
Photos
Take & share photos
Take that family photo, and post it online for everyone to see.
Find it: Home > >
Camera
3MP 245
New York, New York 10006
United States Zoom In
Capture
Tap to zoo m or take the photo.
Zoom Out
Auto lo ca t i on tag. Touch for custo m tags.
Note: Photos are stored on your optional microSD memory card. Picture Resolution is 3MP, unless you change it.
To take the photo, touch Capture .
The photo you’ve just taken is shown on the screen.
Touch the photo, then:
• To set the photo as a wallpaper or contact photo, touch
Set As
.
• To enhance the color and contrast of the photo, touch
Kodak Perfect Touch
.
• To send the photo in a message or post it online, touch
Share
. For more info on sharing your photos, see “Share your photo gallery” on page 38.
• To delete the photo, touch
Delete
.
• For more options, touch .
Photo options
In the viewfinder, touch Menu > Settings to open the camera menu: options
Resolution
Set the resolution of your photo.
Quick upload album
Set the default web site to upload your photos to.
Review Time Set the time period to review your photo after you’ve taken it.
View your photos
Find it: Home > > Gallery > Camera roll
Photos & videos 37
Tip: Use pinch-to-zoom to zoom in/out, see
“Pinch-to-zoom” on page 6.
Play a slideshow
Touch Home > > Gallery > Camera roll , touch a picture, then touch to start a slideshow. To stop the slideshow, touch the display. To return to the gallery, touch Back .
Share your photo gallery
Find it: Home > >
Gallery
>
Camera roll
To send your photo in a message or post it online:
1 Touch and hold a photo, then touch Share .
2 Choose how you want to share—like Bluetooth ,
Email , or Messaging .
Manage your photos
Find it: Home > > Gallery > Camera roll
Touch and hold a photo, then:
• To delete the photo, touch
Delete
.
• To set the photo as a contact picture or wallpaper, touch
Set as
.
Tip: To copy photos to/from a computer, go to “USB drag & drop” on page 43.
Videos
Record & share videos
Find it: Home > > Camcorder
CIF 00:30:10
New York, New York 10006
United States
Record
CIF
Resolut i on (touch
to change)
T ag (location or custo m tags)
M i nutes Left
(depends on video resolution and m e m ory card)
Record.
Tip: To send your video in a message, set the video resolution to Small (QCIF) by touching Menu
> Settings > Video Resolution .
To record the video, touch . Touch to stop the video. Or, press on the keypad.
38 Photos & videos
The video you’ve just recorded is shown on the screen. Touch the video, then:
• To send the video in a message or post it online, touch
Share
. For more info on sharing your photos, see “Share your photo gallery” on page 38.
• To play the video, touch .
• To delete the video, touch Delete .
Play your videos
Find it: Home > >
> video
Gallery > All videos
Note: To see the controls while the video is playing, touch the display.
Music
when music is what you need...
Your music community
Listen to the radio, watch videos, read music news, and more.
Find it: Home > >
Music
11:46
Connected Music Player
My Music
Radio
Music Videos
Community
Song Identification
My Music.
Listen to your tunes.
Radio.
Surf the airwaves for fresh music. There’s something for everyone. You need a headset for FM
Radio. Check out SHOUTcast™ Radio for music from all generations and types.
Music Videos.
Watch videos from YouTube™, prerecorded TV shows, and your own videos.
Community.
Find songs, see what people are listening to all around the world, and see what’s hot on the music charts.
Music 39
Song Identification.
Get information about a song that is playing. Select
Tell me what is playing
and hold your phone close to the source of the music.
Note: Recognition will not take place if the music is from a live concert or a musical performance which digital recording is not even.
Configuration data.
Some features in Connected
Music Player, such as Music Videos and News,
Community, Song Identification and Song lyrics, require data traffic. Set the data mode: Tap
Menu > Settings > Data Usage .
Quick start: Music
Touch, touch, play—instant music. Just open your music library, then select what you want to play.
Find it: Home > >
Music
>
My Music
Your music is stored by artists, albums, songs, and playlists. Touch a category, then touch the song or playlist you want to play.
Music Artist....Song Title....
1:14 3:45
Pro g ress B a r
Tot a l Son g T i me
Mus ic Controls
Tip: When a song is playing, you can add it to a playlist by touching Menu > More > Add to playlist .
Set up music
What music transfer tools do I need?
To put music on your computer and then load it on your phone, you need:
• Microsoft™ Windows™ PC or
Apple™ Macintosh™.
• USB data cable.
• memory card. Your music is stored on your optional memory card. Your phone supports removable optional microSD memory cards up to 32 GB
40 Music
capacity. To make sure your memory card is installed, go to “Assemble & charge” on page 3.
Tip: To see the available memory on your optional memory card, in the home screen touch Menu
> Settings > SD card & phone storage .
What music file formats can I play?
Your phone can play many types of files: MP3, M4A,
AAC, ACC+, MIDI, WAV, and OGG Vorbis.
What headphones can I use?
Your phone has a 3.5mm headset jack for wired stereo listening. You can go wireless with Bluetooth™ stereo headphones or speakers (see “Bluetooth™ wireless” on page 30).
Get music
Rip a CD
Not literally. If you’re new to digital music transfer, this means transferring music from a music CD to your computer.
To rip a music CD on your computer, you can use
Microsoft™ Windows™ Media Player. You can download Windows Media Player from www.microsoft.com.
1 On your computer, open Windows Media Player.
2 Insert a music CD into the computer’s CD
ROM drive.
Note: Make sure you change the format to MP3 in
“Rip > Format > Rip Settings.”
3 In the Windows Media Player window, click on the
“Rip” tab.
4 Highlight the songs you want to import, and click
“Start Rip“.
The songs are imported to the Windows Media Player
Library.
Transfer using Windows Media Player
Transfer music files from a computer to your memory card.
Note: Copyright—do you have the right? Always follow the rules in your phone’s safety, regulatory, and legal information, packaged with your phone.
1 With a memory card inserted, and your phone showing the home screen, connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.
Note: Your phone supports Microsoft™ Windows™
XP, Windows Vista™, and Apple™ Macintosh™.
Other operating systems may not be compatible.
Music 41
2 Your phone shows a USB connection dialog. Touch
USB drive
. You can’t use the files on your optional memory card while it is connected.
3 On your computer, open Windows Media Player.
4 On the “Sync” tab, select “More Options.” Under
“Device,” select your phone.
5 Select “Properties,” check the “Create folder hierarchy on device” box, and click “OK.”
6 Drag your music files over to the “Sync List” and press “Start Sync.”
Transfer using USB
To use an optional USB cable, see “Transfer using
USB” on page 42.
Music player controls
controls play/pause previous/next volume display lyrics
Touch / .
Touch / .
Press the side volume keys.
Touch Menu > More >
Settings > Display lyrics .
42 Music controls send blip add to playlist use as ringtone delete
Love this song, or hate it?
Let your friends know.
Touch Menu > Send
Blip
.
Touch Menu >
More >
Add to playlist .
Touch Menu >
More >
Set as ringtone .
Touch Menu > More >
Delete .
Hide, wake, turn off
Touch Home to use another app. Your music continues to play.
When you see in the status bar a song is playing, flick down to see details. Touch the song to return to the music controls.
To turn off your music touch .
Playlists
To add a song from the music library to a playlist, touch and hold the song then touch Add to playlist . Choose an existing playlist, or touch
New playlist
to create a new playlist.
To add a song to the playlist you're playing, touch Menu > More > Add to playlist in the music player.
To edit, delete and rename playlists, touch and hold the playlist in the music library.
FM Radio
Plug in a 3.5mm headset and surf the airwaves for fresh music.
Find it: Home > > Music > Radio
USB & memory card (optional)
connect your phone and computer, then drag & drop
USB drag & drop
You can transfer your pictures, videos, music, ringtones, and more, from your computer to your phone’s optional memory card.
1 With a memory card inserted, and your phone showing the home screen, connect a
Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.
Note: You may need to remove the USB data cable from the charger power head.
Note: Make sure to connect the phone to a high power USB port. Typically, these are located directly on your computer.
2 Your phone shows a USB connection dialog at the top of the screen. Flick down, touch Memory Card
Management
, then touch
OK
. You can’t use the files on your optional memory card while it is connected.
USB & memory card (optional) 43
3 Touch Mount (if asked) to connect your optional memory card.
4 On your computer, use the “My Computer” window to find “Removable Disk”.
5 Click on the “Removable Disk” icon to access the memory card.
6 Drag and drop your pictures, videos, music, ringtones, and more, to your phone folder. To help manage your files, you can create more folders in your phone folder.
7 When you’re done, use the “Safely Remove
Hardware” feature to finish.
Motorola Phone Portal
1 Connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer (see “USB drag & drop”).
2 Your phone shows a USB connection dialog, at the top of the screen. Flick down, touch Moto Phone
Portal
, then touch
OK
.
Windows™ Media Sync
Synchronize media content with your computer using
Windows Media Player or other similar applications.
1 Connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer (see “USB drag & drop” on page 43).
2 Your phone shows a USB connection dialog, at the top of the screen. Flick down, touch Windows
Media Sync
, then touch
OK
.
Memory card
Note: You need the optional memory card installed for some features on your phone, like
Camera
.
Remove or format your memory card
Before you remove or format your optional memory card you need to unmount it. Touch Menu
> Settings > SD card & phone storage > Unmount
SD card .
To format your memory card, touch Format SD card .
Warning: All data on your memory card will be deleted.
44 USB & memory card (optional)
Synchronize
keep up-to-date
Google™ data synchronization
Find it: In the home screen touch Menu >
Settings > Accounts > Google account > Sync
Gmail
The Google apps on your phone give you access to the same personal information (emails, events, and contacts) that you have on a computer using
Gmail
™,
Google Calendar
™, and
Contacts
, It’s easy to synchronize the Google apps information you want to keep up-to-date.
Select apps to synchronize
1 Touch Background data and Auto-sync .
Tip: To save battery power do not touch
Background data .
2 Touch the apps you want to synchronize, like Gmail ,
Calendar , or Contacts .
Synchronize with Microsoft™ Office
Outlook
If you use Microsoft Office Outlook on your work computer, your phone can synchronize emails, events, and contacts with your Microsoft Exchange server.
Find it: In the home screen touch Menu >
Settings > Accounts > Add account > Corporate
Sync
1 Enter your username ([email protected]), password, email address, and server details (server address is the same URL you use to access your company’s email using the Web on your computer).
Note: Contact your business IT department for server details.
2 Touch
Next
.
Synchronize 45
Tools
stay on top of things
Alarm clock
Find it: Home > >
Alarm & Timer
To turn on an alarm, touch the check box.
When an alarm sounds, drag
Dismiss
to turn it off or touch the screen to snooze.
Alarm
7:00am
Wake Up
8:30am Tuesday
9:00am Tue, Fri
To add an alarm, touch Menu > Add alarm , then enter alarm details.
Calendar
Find it: Home > > Calendar
Your calendar events can be viewed in different ways:
Touch Menu > Agenda , Day , or Week . When you highlight an event in the day and week views, more details appear.
Add calendar events
From any calendar view, touch Menu > New event
. Enter event details and touch
Save
.
46 Tools
Manage calendar events
To edit an event, touch and hold it, then touch Edit event . When you’re done, touch Save .
To delete an event, touch and hold it, then touch Delete event .
To go to today, touch Menu > Today .
To view your calendar events for the week, touch Menu > Week .
Calculator
Find it: Home > >
Calculator
Your calculator has two views: basic and advanced. To change your views, touch Menu >
Advanced panel or Basic panel . To clear history, touch Menu > Clear history .
Quickoffice
Use Quickoffice to view recent documents and files on your optional memory card.
Find it: Home > >
Quickoffice
Touch a file or folder to open, or touch and hold a file for options.
To manage your folders and transfer files, see
“Memory card” on page 44.
Management
stay in control
Wireless manager
Find it: Home > Menu >
Settings
>
Wireless
& networks
Manage all your wireless connections: Wi-Fi,
Bluetooth™, airplane mode, & mobile networks
(“Network” on page 47).
Airplane mode
Use airplane mode to turn all your wireless connections off—useful when flying. Press Power
>
Airplane mode
.
Update my phone
To keep your phone current, software updates may be available. In the home screen touch Menu >
Settings
>
About phone
>
System updates
to see if your phone is up to date. If it isn’t, touch Update .
Network
You should not need to change any network settings.
Contact your service provider for help.
In the home screen touch Menu > Settings >
Wireless & networks > Mobile networks to show options for roaming networks, network selection, operator selection, and access point names.
Management 47
Security
help keep your phone safe
Quick start: Security
Find it: Home > Menu >
Settings
>
Location
& security
You have lots of ways to keep your phone safe.
Security
Screen lock
Display a screen preventing accidental touches
Turn on.
Security lock Set lock type, code, and ti m er.
SIM card lock
Set up SIM card lock
Set SIM card lock and change SIM PIN.
d
If you lose your phone, you can log into your
MOTOBLUR account from a computer to locate your phone or clear the data on it: www.motorola.com/mymotoblur.
Screen lock
Some work accounts might require you to add a password lock to your phone, for security.
• Pattern lock : draw a pattern to unlock.
•
Passcode lock
: enter a code to unlock.
48 Security
Note: You can make emergency calls on a locked phone (“Emergency calls” on page 14). A locked phone still rings, but you need to unlock it to answer .
Pattern lock
To set the lock pattern, in the home screen touch Menu >
Settings
>
Location & security
> Security lock > Security lock type > Pattern lock
Follow the instructions to draw your lock pattern.
When prompted, draw the pattern to unlock the phone.
Passcode lock
To set the passcode, in the home screen touch Menu > Settings > Location & security >
Set password
.
Enter a password, then confirm it.
When prompted, enter the password to unlock the phone.
Personalize your lock screen
To change your timeout, in the home screen touch Menu >
Settings
>
Sound & display
>
Screen timeout . If you don't touch the screen or press any keys for this amount of time, the screen locks automatically. To unlock, see “Lock & unlock” on page 49.
Lock & unlock
To lock the screen/phone:
• Press Power .
• Let the screen time out (don’t press anything).
• Switch the power off.
To unlock the screen/phone:
• Press Power —if you've set a lock pattern or passcode, you'll be asked to enter it.
Lock your SIM
Enable SIM PIN
To lock your SIM (the next time you power up the phone you will need to enter your SIM PIN), in the home screen touch Menu > Settings > Location
& security
>
Set up SIM card lock
. Enter your SIM
PIN code.
Caution: If you enter an incorrect PIN code three times, your phone locks your SIM card and asks for your PIN unlock code, contact your service provider.
Change SIM PIN
To change your SIM PIN , in the home screen touch Menu > Settings > Location & security >
Set up SIM card lock
>
Change SIM PIN
.
PUK code
To unlock your SIM PIN, you need to enter your PIN unlock code (PUK code) when prompted.
Note: Your PUK code is provided by your service provider.
Lost, stolen, broken, cleared
Don't you just hate it when your life is on your phone and it all goes wrong. Lose it, break it, reset it, or even worse—stolen! Relax, MOTOBLUR can help find your phone, clear it (if you need to) and best of all, restore all your stuff.
Track your phone
To locate your phone:
1 Log into your MOTOBLUR account: www.motorola.com/mymotoblur.
2 On the phone profile page, follow the link to locate your phone.
Security 49
MOTOBLUR locates your phone using GPS and
AGPS (see the important legal and safety information packaged with your phone).
Remote clear
To wipe your phone data:
1 Log into your MOTOBLUR account: www.motorola.com/mymotoblur.
2 On the phone profile page, follow the link to delete data.
Warning: All downloaded apps and user data on your phone will be deleted. Data on your memory card will not be deleted.
Restore your phone
If you lose your phone don’t worry, your contacts are backed-up on MOTOBLUR.
If you get your next MOTOBLUR product, just log into your existing MOTOBLUR account on your phone to recover all your stuff automatically.
To recover your Android Market apps, see “Manage & restore apps” on page 29.
Troubleshooting
we’re here to help
Crash recovery
In the unlikely event that your phone stops responding to touches and key presses, try a quick reset. Remove the back cover and battery (“Assemble & charge” on page 3), then replace and turn on your phone as usual.
Service & repairs
If you have questions or need assistance, go to www.motorola.com/support, where you can select from a number of customer care options. You can also contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456
(TTY/TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
50 Troubleshooting
Safety, Regulatory & Legal
Battery Use & Safety
Battery Use & Safety Important: Handle and store batteries properly to avoid injury or damage.
Most battery issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the form of your battery.
• Don’t let the phone or battery come in contact with water.
Water can get into the phone’s circuits, leading to corrosion. If the phone and/or battery get wet, have them checked by your service provider or contact Motorola, even if they appear to be working properly.*
• Don’t allow the battery to touch metal objects.
If metal objects, such as jewelry, stay in prolonged contact with the battery contact points, the battery could become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the phone or the battery. High temperatures can cause the battery to swell, leak, or malfunction. Therefore:
• Do not dry a wet or damp battery with an appliance or heat source, such as a hair dryer or microwave oven.
• Avoid leaving your phone in your car in high temperatures.*
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on a hard surface, can potentially cause damage.*
• Do contact your service provider or Motorola if your phone or battery has been damaged from dropping or high temperatures.
* Note: If the product guide expressly states that your phone is designed to resist damage from exposure to certain rugged conditions, such as water immersion, rain, dust, high and low temperatures, shock, or other conditions, do not exceed the stated limits, and ensure the stated precautions are taken. Always make sure that the battery compartment is closed and secure to avoid direct exposure of the battery to any of these conditions.
Important: Use Motorola Original products for quality assurance and safeguards.
To aid consumers in identifying authentic Motorola batteries from non-original or counterfeit batteries (that may not have adequate safety protection),
Motorola provides holograms on its batteries. Consumers should confirm that any battery they purchase has a “Motorola Original” hologram.
Motorola recommends you always use Motorola-branded batteries and chargers.
Motorola mobile devices are designed to work with Motorola batteries.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge , take the following steps:
• Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;
• If there is no hologram, the battery is not a Motorola battery;
• If there is a hologram, replace the battery and retry charging it;
• If the message remains, contact a Motorola authorized service center.
Important: Motorola’s warranty does not cover damage to the phone caused by non-Motorola batteries and/or chargers.
Warning: Use of a non-Motorola battery or charger may present a risk of fire, explosion, leakage, or other hazard.
Proper and safe battery disposal and recycling: Proper battery disposal is not only important for safety, it benefits the environment. Consumers may recycle their used batteries in many retail or service provider locations. Additional information on proper disposal and recycling may be found on the Web:
• www.motorola.com/recycling
• www.rbrc.org/call2recycle/ (in English only)
Disposal: Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center or national recycling organizations for more information on how to dispose of batteries.
032375o
Warning: Never dispose of batteries in a fire because they may explode.
51
Battery Charging
Battery Charging Notes for charging your phone’s battery:
• When charging your battery, keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging.
• New batteries are not fully charged.
• New batteries or batteries stored for a long time may take more time to charge.
• Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.
Specific Absorption Rate (IEEE)
SAR (IEEE)
Your model wireless phone meets the governmental requirements for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed and manufactured to not exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the
Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed for the safety of all persons, regardless of age or health, and to account for any variations in measurements.
The exposure standard for mobile devices employs a unit of measurement known as the Specific Absorption Rate (SAR). The IEEE SAR limit set by the FCC and by the
Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over one gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC and by Industry Canada with the mobile device transmitting at its highest certified power level in all tested frequencies. Although the SAR is determined at the highest certified power level, the actual SAR level of the mobile device while operating can be below the maximum value. This is because the mobile device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output.
52
Before a mobile device is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) submitted to the
FCC and available for review by Industry Canada. The highest SAR value for this mobile device when tested for use at the ear is 1.16 W/kg, and when worn on the body, as described in this guide, is 1.09 W/kg. The SAR value for this mobile device in its data transmission mode (body-worn use) is 0.54 W/kg. Body-worn measurements can differ, depending upon available accessories and regulatory requirements. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.
While there may be differences between the SAR levels of various mobile devices and at various positions, they meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.
Additional information on SAR can be found on the Cellular Telecommunications
& Internet Association (CTIA) Web site: http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web site: http://www.cwta.ca
European Union Directives Conformance
Statement
EU Conformance
[Only Indoor Use
Allowed In France]
Hereby, Motorola declares that this product is in compliance with:
• The essential requirements and other relevant provisions of Directive 1999/5/EC
• All other relevant EU Directives
0168
Product
Approval
Nu
m
ber
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC
(to R&TTE Directive) at www.motorola.com/rtte. To find your DoC, enter the
Product Approval Number from your product’s label in the “Search” bar on the Web site.
Software Copyright Notice
Software Copyright Notice Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.
Content Copyright
Content Copyright The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.
Open Source Software Information
OSS Information For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number.
MOTOROLA MOBILITY, INC.
OSS Management
600 North US Hwy 45
Libertyville, IL 60048
USA
The Motorola website opensource.motorola.com also contains information regarding Motorola's use of open source.
Motorola has created the opensource.motorola.com website to serve as a portal for interaction with the software community-at-large.
To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please press Menu Key > Settings > About Phone > Legal information
>
Open source licenses
. In addition, this Motorola device may include self-contained applications that present supplemental notices for open source packages used in those applications.
GPS & AGPS
GPS & AGPS Your mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of
Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device.
Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges,
53
and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details.
Your Location
Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network transmit location-based information. Devices enabled with GPS or
AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.
Emergency Calls
When you make an emergency call, the cellular network may activate the AGPS technology in your mobile device to tell the emergency responders your approximate location.
AGPS has limitations and might not work in your area . Therefore:
• Always tell the emergency responder your location to the best of your ability; and
• Remain on the phone for as long as the emergency responder instructs you.
Performance Tips
• Go outside and away from underground locations, covered vehicles, structures with metal or concrete roofs, tall buildings, and foliage. Indoor performance might improve if you move closer to windows, but some window sun shielding films can block satellite signals.
• Move away from radios, entertainment equipment, and other electronic devices.
Navigation
Navigation Motorola strives to provide complete and accurate mapping information, directions, and other navigational data, using a combination of governmental and private location information sources. These sources may contain inaccurate or incomplete data. In some countries, complete information may not be available. Therefore, you should visually confirm that the navigational instructions are consistent with what
54 you see. All drivers should pay attention to road conditions, closures, traffic, and all other factors that may impact driving. Always obey posted road signs.
Safety & General Information
Safety Information This section contains important information on the safe and efficient operation of your mobile device. Read this information before using your mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits.
Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like you would a landline phone.
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola, keep the mobile device and its antenna at least 2.5 centimeters (1 inch) from your body when transmitting.
Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our Web site at: www.motorola.com.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy
compatibility. In some circumstances, your mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator, consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
• ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable medical device when the mobile device is turned ON.
• DO NOT carry the mobile device in the breast pocket.
• Use the ear opposite the implantable medical device to minimize the potential for interference.
• Turn OFF the mobile device immediately if you have any reason to suspect that interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your mobile device with your implantable medical device, consult your healthcare provider.
Driving Precautions
Using a mobile device while driving may cause distraction. End a call if you can’t concentrate on driving. Input information about your destination and route prior to your drive. Do not input data or engage in text messaging while driving. Keep your eyes on the road while driving. Listen to the audible turn-by-turn directions, if available.
Also, using a mobile device or accessory may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.
Responsible driving practices can be found at www.motorola.com/callsmart
(in English only).
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted and can include fueling areas, such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Symbol
032374o
Definition
Important safety information follows.
032376o
Do not dispose of your battery or mobile device in a fire.
032375o
Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.
Do not throw your battery or mobile device in the trash.
Do not let your battery, charger, or mobile device get wet.
55
Symbol Definition
Listening at full volume to music or voice through a headset may damage your hearing.
Batteries & Chargers
Caution: Improper treatment or use of batteries may present a danger of fire, explosion, leakage, or other hazard. For more information, see “Battery Use &
Safety.”
Keep Your Mobile Device & Its Accessories Away
From Small Children
These products are not toys and may be hazardous to small children. For example:
• A choking hazard may exist for small, detachable parts.
• Improper use could result in loud sounds, possibly causing hearing injury.
• Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes,
56 leave the lights on in the room, take a 15-minute break every hour, and stop use if you are tired.
Caution About High Volume Usage
Warning: Exposure to loud noise from any source for extended periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected.
To protect your hearing:
• Limit the amount of time you use headsets or headphones at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears, or muffled speech, you should stop listening to the device through your headset or headphones and have your hearing checked.
For more information about hearing, see our Web site at direct.motorola.com/hellomoto/nss/AcousticSafety.asp (in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.
[Nov0109]
Industry Canada Notice to Users
Industry Canada Notice Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See RSS-GEN 7.1.5.
FCC Notice to Users
FCC Notice The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID:xxxxxx on the product label.
Motorola has not approved any changes or modifications to this device by the user.
Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use & Care
Use & Care To care for your Motorola phone, please keep it away from: liquids of any kind
Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture. If it does get wet, don’t try to accelerate drying with the use of an oven or dryer, as this may damage the phone.
extreme heat or cold
Avoid temperatures below 0°C/32°F or above 45°C/113°F.
microwaves
Don’t try to dry your phone in a microwave oven.
dust and dirt
Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.
cleaning solutions
To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.
shock and vibration
Don’t drop your phone.
Motorola Limited Warranty for the
United States and Canada
Warranty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Mobility, Inc. warrants its mobile telephones (“Products”), Motorola-branded or certified accessories sold for use with these Products (“Accessories”), and Motorola software contained on
CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories, and
Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:
57
Products and Accessories
Products Covered
Products and Accessories as defined above, unless otherwise provided for below.
Decorative Accessories and
Cases. Decorative covers, bezels, PhoneWrap™ covers and cases.
Monaural Headsets. Ear buds and boom headsets that transmit mono sound through a wired connection.
Products and Accessories that are Repaired or
Replaced.
Length of Coverage
One (1) year from the date of purchase by the first consumer purchaser of the product unless otherwise provided for below.
Limited lifetime warranty for the lifetime of ownership by the first consumer purchaser of the product.
Limited lifetime warranty for the lifetime of ownership by the first consumer purchaser of the product.
The balance of the original warranty or for ninety (90) days from the date returned to the consumer, whichever is longer.
Exclusions (Products and Accessories)
Normal Wear and Tear. Periodic maintenance, repair and replacement of parts due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from coverage.
58
Use of Non-Motorola Products and Accessories. Defects or damage that result from the use of non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of Products,
Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.
Software
Products Covered
Software. Applies only to physical defects in the media that embodies the copy of the software (e.g.
CD-ROM, or floppy disk).
Length of Coverage
Ninety (90) days from the date of purchase.
Exclusions (Software)
Software Embodied in Physical Media. No warranty is made that the software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media. Software that is not embodied in physical media (e.g. software that is downloaded from the Internet), is provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new
Products, Accessories or parts. No data, software or applications added to your
Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software, and applications, please create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
USA
Canada
TTY
All Products, Accessories, and Software: 1-800-331-6456
All Products: 1-800-461-4575
1-888-390-6456
You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase;
(b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.
What Other Limitations are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE
THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS
PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO
EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR
PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR
APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION
WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR
SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.
Hearing Aid Compatibility with Mobile
Phones
Hearing Aids Some Motorola phones are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies.
When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.
The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in finding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box. To maintain the published Hearing
Aid Compatibility (HAC) rating for this mobile phone, use only the original equipment battery model.
The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the
59
phone with your hearing device is the best way to evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of interference.
Your hearing device manufacturer or hearing health professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.
Information from the World Health
Organization
WHO Information Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using handsfree devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193
Further information: http://www.who.int/peh-emf
Product Registration
Registration Online Product Registration: www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions.
Registration is not required for warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status.
60
Thank you for choosing a Motorola product.
Export Law Assurances
Export Law This product is controlled under the export regulations of the United States of
America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations.
For further information contact the U.S. Department of Commerce or the Canadian
Department of Foreign Affairs and International Trade.
Caring for the Environment by
Recycling
Recycling Information This symbol on a Motorola product means the product should not be disposed of with household waste.
Disposal of your Mobile Device &
Accessories
Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste. Do not dispose of your battery or mobile device in a fire. These items should be disposed of in accordance with the national collection and recycling
032376o schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved
Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling
Disposal of your Mobile Device Packaging &
Product Guide
Product packaging and product guides should only be disposed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.
California Perchlorate Label
Perchlorate Label Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases,
California law requires the following label:
Perchlorate Material – special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate
There is no special handling required by consumers.
Privacy & Data Security
Privacy & Data Security Motorola understands that privacy and data security are important to everyone.
Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:
• Monitor access —Keep your mobile device with you and do not leave it where others may have unmonitored access. Lock your device’s keypad where this feature is available.
• Keep software up to date —If Motorola or a software/application vendor releases a patch or software fix for your mobile device that updates the device’s security, install it as soon as possible.
• Secure personal information —Your mobile device can store personal information in various locations including your SIM card, memory card, and phone memory. Be sure to remove or clear all personal information before you recycle, return, or give away your device. You can also backup your personal data to transfer to a new device.
Note: For information on how to backup or wipe data from your mobile device, go to www.motorola.com/support
• Online accounts —Some mobile devices provide a Motorola online account
(such as MOTOBLUR). Go to your account for information on how to manage the account, and how to use security features such as remote wipe and device location (where available).
• Location-based information —Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.
• Other information your device may transmit —Your device may also transmit testing and other diagnostic (including location-based) information, and other non-personal information to Motorola or other third-party servers. This information is used to help improve products and services offered by Motorola.
If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at [email protected], or contact your service provider.
Smart Practices While Driving
Driving Safety
Drive Safe, Call Smart
Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas—for example, handsfree use only. Go to www.motorola.com/callsmart
(in English only) for more information.
Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your mobile device while driving, remember the following tips:
• Get to know your Motorola mobile device and its features such as speed dial and redial. If available, these features help you to place your call without taking your attention off the road.
• When available, use a handsfree device. If possible, add an additional layer of convenience to your mobile device with one of the many Motorola Original handsfree accessories available today.
• Position your mobile device within easy reach. Be able to access your mobile device without removing your eyes from the road. If you
61
receive an incoming call at an inconvenient time, if possible, let your voicemail answer it for you.
• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions. Rain, sleet, snow, ice, and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while driving. Jotting down a
“to do” list or going through your address book takes attention away from your primary responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place calls when your car is not moving or before pulling into traffic. If you must make a call while moving, dial only a few numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that may be distracting. Make people you are talking with aware you are driving and suspend conversations that can divert your attention away from the road.
• Use your mobile device to call for help. Dial 911 or other local emergency number in the case of fire, traffic accident, or medical emergencies (wherever wireless phone service is available).
• Use your mobile device to help others in emergencies. If you see an auto accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number (wherever wireless phone service is available), as you would want others to do for you.
• Call roadside assistance or a special non-emergency wireless assistance number when necessary. If you see a broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number (wherever wireless phone service is available).
62
Motorola Mobility, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048 www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing.
Motorola reserves the right to change or modify any information or specifications without notice or obligation.
MOTOROLA, the Stylized M Logo, MOTOBLUR and the MOTOBLUR logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. The
Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. is a Certification Mark of the Wireless Fidelity Alliance, Inc.
Java and all other Java-based marks are trademarks or registered trademarks of
Sun Microsystems, Inc. in the U.S. and other countries. Google, Google Maps,
Google Calendar, YouTube, Picasa, Android, AndroidMarket,Gmail, and the Google logo are trademarks of Google, Inc.. Facebook is a trademark of Facebook, Inc. All other product or service names are the property of their respective owners.
© 2010 Motorola Mobility, Inc. All rights reserved.
Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment.
MOTOROLA FLIPOUT with MOTOBLUR (MB511)
Manual Number: 68000202953-B
63
64
advertisement
Key Features
- 7.11 cm (2.8") 320 x 240 pixels TFT
- 0.6 GHz
- Single SIM
- Bluetooth 2.1+EDR
- Single camera
- Lithium-Ion (Li-Ion) 1170 mAh
Related manuals
advertisement
Table of contents
- 4 Your phone
- 5 Let’s go
- 8 Touchscreen & keys
- 10 Home screen
- 12 Social networking
- 14 Calls
- 17 Contacts
- 20 Messaging
- 23 Text entry
- 27 Google Maps
- 29 YouTube
- 30 Apps for all
- 31 Bluetooth™ wireless
- 33 Wi-Fi
- 34 Tips & tricks
- 36 Personalize
- 38 Photos & videos
- 41 Music
- 45 USB & memory card (optional)
- 46 Synchronize
- 47 Tools
- 48 Management
- 49 Security
- 52 Troubleshooting
- 53 Safety, Regulatory & Legal
