4IPNET OWL500 Quick Installation Manual

OWL500/510

V1 . 00

Quick Installation Guide

O W L 5 0 0 / 5 1 0 L o n g R a n g e O u t d o o r C P E / A P / B r i d g e

ENGLISH

Copyright N otic e

This document is protected by U S A copyrig ht l a w s a nd other l a w s a nd is the property of

4 I P N E T, I N C . Y ou ma y not copy, reproduce, distribute, publ ish, displ a y, perf orm, or modif y a ny pa rt of this publ ica tion in a ny f orm or by a ny mea ns w ithout prior w ritten permission f rom 4 I P N E T, I N C . Y ou ma y not a l ter or remov e a ny copyrig ht or other notice f rom copies of the content. Al l other bra nd a nd product na mes a re cl a imed or reg istered ma rk s of their respectiv e compa nies or org a niz a tions.

Al l rig hts reserv ed. i

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299



ENGLISH

N o t e

The respective FCC ID for This document serves only as a sample manual and QIG for this sample unit. The respective FCC ID for O W L 5 00/ O W L 5 1 0 w ill b e V Z 9090003 , application in prog ress in J uly 2 009. ii




ENGLISH

Preface

The 802.11 b/g compliant OWL500/510 is a Long

Range Outdoor CPE/AP/Bridge device that can be used for dual purposes. First, it can be deployed as a traditional fixed wireless Access Point (AP).

Secondly, it can be used as a Customer Premises

Equipment (CPE) that connects to the outdoor wireless network of Wireless Internet Service

Provider (WISP).

Pack ag e C o n t en t s

1. OWL500/510 x 1

2. Quick Installation Guide (QIG) x 1

3. CD-ROM (with User’s Manual and QIG) x 1

4. Power Sourcing Equipment (PSE) with

AC cable x 1

5. Mounting Kit x 1

The metal sealed OWL500/510 is compact in size and weatherproof. Coming with a mounting kit, it can be mounted on a pole or wall. It is suitable for both indoor and outdoor usage with its 500mW output power, which is higher than a typical indoor

AP (100mW).

It is recommended to keep the original packing material for possible future shipment when repair or maintenance is required. Any returned product should be packed in its original packaging to prevent damage during delivery.

This Quick Installation Guide (including FAQ

Instruction Guide) provides instructions for getting started with OWL500/510.

- 1 -




ENGLISH

System Overview

OWL500

1 WLAN Green LED ON indicates system ready

2 Wireless Signal Strength For showing the signal strength situation

3 Ethernet Green LED ON indicates connection, OFF indicates no connection, and BLINKING indicates transmitting data.

4 PoE Connector

5 N-type Connector

6 Power

For connecting to the Power Sourcing Equipment (PSE)

For connecting to an antenna

Red LED ON indicates power on, and OFF indicates power off

7, 8 Wireless Signal Strength For showing the signal strength situation (7: Yellow; 8: Green)

OWL510

1 WLAN Green LED ON indicates system ready

2 Wireless Signal Strength For showing the signal strength situation

3 Ethernet Green LED ON indicates connection, OFF indicates no connection, and BLINKING indicates transmitting data.

4 PoE Connector

5 Built-in patch antenna

6 Power

For connecting to the Power Sourcing Equipment (PSE)

10 dBi (Horizontal: 110 degree; Vertical: 60 degree)

Red LED ON indicates power on, and OFF indicates power off

7, 8 Wireless Signal Strength For showing the signal strength situation (7: Yellow; 8: Green)

- 2 -


H a rd wa re I n sta l l a tio n



ENGLISH

OWL500/510

The following diagram is a basic network topology which can be used for testing and configuring the

OWL500/510.

Installation Steps:

Step 1. Connect an N-type antenna to the N-type connector (applicable for OWL500/510 only).

Step 2. Connect the PSE (POWER & DATA OUT) to the PSE 1 connector on the lower panel.

Step 3. Connect one end of an Ethernet cable to the PSE 2 connector on the lower panel and the other end to a computer.

Step 4. Connect the power cord to the PSE.

Step 5. Power on the PSE in order to supply power to the OWL500/510.

- 3 -




ENGLISH

G ettin g Sta rted

4ipnet OWL500/510 supports web-based configuration. OWL500/510 is a dual-mode system, AP Mode as the default mode for the first time entering the system, which also can be configured as either an access point (AP

Mode) or a gateway (CPE Mode) based on your needs. It is required to follow the respective installation procedures provided to properly set up the desired mode for this system.

• Default IP Address of Web Management Interface:

The default IP address and Subnet Mask for the AP mode and CPE mode are as follows:

Mode AP Mode CPE Mode

IP Address

1 9 2 . 1 6 8 . 1 . 1 1 9 2 . 1 6 8 . 1 . 1

Subnet Mask

2 5 5 . 2 5 5 . 2 5 5 . 0 2 5 5 . 2 5 5 . 2 5 5 . 0

• Default User Name and Password:

There is only one management account for AP mode, root. In addition, there are two system management accounts for CPE mode to maintain the system, root and admin, and each has different levels of management capabilities. The root account is empowered with full privileges while the admin account is with partial ones.

The default user name and password for both the root and admin account are as follows:

Mode

Management

Account

User Name

Password

AP Mode

Root

Account root a dmin

CPE Mode

Root

Account root a dmin

Admin

Account a dmin a dmin

- 4 -




ENGLISH

<AP Mode—Default Mode>

Step 1: IP Segment Setup for Administrator PC

Set a static IP address on the same subnet mask as OWL500/510 in TCP/IP of the administrator PC, such as the following example. Do not duplicate the IP address used here with the IP address of OWL500/510 or any other devices within the same network.

>> Example of IP Segment:

The valid range of IP address is 1 ~ 254. However, 1 must be avoided as it is already used by OWL500/510.

Below depicts an example of using 100 (the underlined value can be changed as desired).

IP Address: 192.168.1.100

Subnet Mask: 255.255.255.0

Step 2: Launch Web Browser

Launch a web browser to access the web management interface of AP mode by entering the default IP address, http://192.168.1.1/, in the URL field, and then press Enter.

Using an incorrect default IP address will result in no Login page shown in the web browser. Please make sure a correct IP address is used for the desired mode.

Step 3: System Login

The system manager Login Page will then appear.

Enter “root” in the User name field and “admin” in the Password field, and then click OK to log in.

- 5 -




ENGLISH

Step 4: Login Success

After a successful login to OWL500/510, a System Overview page of web management interface will appear,

To logout, simply click on the Logout button at the upper right hand corner of the interface.

Note:

By default, AP mode is enabled. Therefore, the administrator must access the system via the AP mode login page for the first time. The administrator is then able to switch between modes afterwards.

- 6 -




ENGLISH

<CPE Mode>

Step 1: Launch Web Browser

Launch a web browser to access the web management interface of CPE mode by entering the default IP address, http://192.168.1.1/, in the URL field, and then press Enter.

Step 2: System Login

The system manager Login Page will then appear.

Enter “root” in the User name field and “admin” in the Password field, and then click OK to log in. Below depicts an example of using the root manager account.

- 7 -




ENGLISH

Step 3: Login Success

After a successful login to OWL500/510, a System Overview page of web management interface will appear.

To logout, simply click on the Logout button at the upper right hand corner of the interface.

- 8 -


C o mmo n Settin g s

<AP Mode – Default Mode>

Step 1: Mode Confirmation



ENGLISH

Ensure the Operating Mode is currently in AP mode.

Click on the Status button and then select the System Overview tab. The Operating Mode is at the

System section on the System Overview page.

- 9 -


Step 2: Change Password



ENGLISH

Click on the Utilities button and then select the Password tab.

Enter a new password in the New Password field and retype it in the Re-enter New Password field.

Click Save to save the changes.

- 1 0 -


Step 3: Network Settings



ENGLISH

Settings here are for example only

Click on the System button and then select the Network tab.

Enable Static, and then enter the related information in the fields marked with red asterisks.

Click Save to save the settings.

- 1 1 -


Step 4: SSID Settings



ENGLISH

Click on the Wireless button and then select the General tab.

Band: Select an appropriate band from the drop-down list box.

Click on the Wireless button and then select the General tab.

Band: Select an appropriate band from the drop-down list box.

SSID: Enter a SSID for the system in the SSID field or use the default. SSID (Service Set Identifier) is a unique identifier used for networking devices to get associated with OWL500/510.

- 1 2 -




ENGLISH

Note: Band and SSID are required; other fields are optional.


Step 5: Security Settings

Click on the Wireless button and then select the Security tab.

Select the desired VAP Profile and Security Type from the drop-down list boxes. The above figure depicts an example of selecting VAP-1 and WEP.

Enter the information required in the blank fields.

You must use the same information provided here to configure the network devices that are to be associated with OWL500/510.

Click Apply to activate all settings configured so far.

Congratulations!

The AP mode is now successfully configured.

- 1 3 -


<CPE Mode>

Step 1: Mode Confirmation



ENGLISH

Ensure the Operating Mode is currently in CPE mode.

Click on the Status button and then select the System Overview tab. The Operating Mode is at the

System section on the System Overview page.

- 1 4 -


Step 2: Change Password



ENGLISH

Click on the Utilities button and then select the Password tab.

Change Root Account Password

• Enter the old password in the Old Password field; default password is “admin”.

• Enter a new password in the New Password field and retype it in the Re-enter New Password field.

Change Admin Account Password

• Enter a new password in the New Password field and retype it in the Re-enter New Password field.

Click Save to save the changes.

- 1 5 -


Step 3: Site Survey



ENGLISH

The scan result displayed here is an example only.

Click on the Wireless button and then select the Site Survey tab.

The system will automatically scan and display all APs in its coverage area.

Click Scan Again if the APs to be associated with are not listed on the Scan Result list.

Step 4: Select AP to be Associated

Select an AP to be associated with from the Scan Result list provided in Step 3.

- 1 6 -


Step 5: Security Settings



ENGLISH

The above figure depicts an example of selecting AP2 (encrypted via WEP security type).

Click Setup of AP2, and then a related encryption configuration box will appear.

Enter the information required in the configuration box. Information to be entered must be exactly the same as configured in this AP2.


- 1 7 -


Step 6: Network Interface Configuration



ENGLISH

Settings here are for example only

Click on the System button and then select Network tab.

Enable Static, and then enter the related information in the fields marked with red asterisks.


Step 7: LAN Configuration

Click on the System button and then select the Network tab.

The LAN Configuration section is on the same page as the WAN Configuration section.

Enter the IP Address and Netmask of the LAN port.

Click Apply to activate all settings configured so far.

Congratulations!

The CPE mode is now successfully configured.

- 1 8 -




ENGLISH

After OWL500/510's network configuration completes, please remember to change the IP Address of your PC Connection Properties back to its original settings in order to ensure that your PC functions properly in its real network environments.

It is strongly recommended to make a backup copy of configuration settings.

For further configuration and backup information, please refer to the User’s Manual.

P / N : V 1 002 009092 0

- 1 9 -
