Leica Zeno 20
Android
User Manual
Version 1.1
English
Introduction
Purchase
Product Identification
Trademarks and
Licenses
Congratulations on the purchase of a Leica Zeno 20.
This manual contains important safety directions as well as instructions for setting up
the product and operating it. Refer to "1 Safety Directions" for further information.
Read carefully through the User Manual before you switch on the product.
The type and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or Leica
Geosystems authorised service workshop.
• The operating system is using the Android Open Source Project (AOSP). The license associated with it is available at https://source.android.com/source/licenses.html#android-open-source-projectlicense.
• CompactFlash and CF are trademarks of SanDisk Corporation
• Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc.
• SD Logo is a trademark of SD-3C, LLC.
All other trademarks are the property of their respective owners.
This manual applies to the Android version of the Leica Zeno 20 device.
Validity of this manual
Available documentation
Name
Leica Zeno 20
Quick Guide
Leica Zeno 20
User Manual
Description/Format
Provides an overview of the product together with technical data and safety directions. Intended as a quick reference guide.
All instructions required in order to operate the product to a basic level are contained in the User Manual.
Provides an overview of the product together with technical data and safety directions.
-
Name Description/Format
Zeno GIS
Getting Started
Guide
Describes the general working of the product in standard use. Intended as a quick reference field guide.
-
Zeno Connect
Getting Started
Guide
Describes the general working of the product in standard use. Intended as a quick reference field guide.
-
Zeno Mobile
Quick Guide
Zeno GIS Help
*
Describes the general working of the product in standard use. Intended as a quick reference field guide.
-
Overall comprehensive help to the product and application functions. Included are detailed descriptions of special software/hardware settings and software/hardware functions.
-
-
* only available as Online Help
Refer to the following resources for all Zeno 20 documentation/software:
• the Leica USB documentation card
• https://myworld.leica-geosystems.com
Zeno 20 Android, Introduction 2
myWorld@Leica Geosystems ( https://myworld.leica-geosystems.com
) offers a wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services whenever it is convenient for you, 24 hours a day, 7 days per week. This increases your efficiency and keeps you and your equipment instantly updated with the latest information from
Leica Geosystems.
Service myProducts myService mySupport
Description
Add all Leica Geosystems products that you and your company own. View detailed information on your products, buy additional options or Customer Care Packages (CCPs), update your products with the latest software and keep up-to-date with the latest documentation.
View the service history of your products in Leica Geosystems
Service Centres and detailed information on the services performed on your products. For your products that are currently in Leica Geosystems Service Centres view the current service status and the expected end date of service.
Create new support requests for your products that will be answered by your local Leica Geosystems Support Team. View the complete history of your Support and view detailed information on each request in case you want to refer to previous support requests.
myTraining Enhance your product knowledge with the Leica Geosystems
Campus - Information, Knowledge, Training. Study the latest online training material or download training material on your products. Keep up-to-date with the latest News on your products and register for Seminars or Courses in your country.
myTrustedServices Offers increased productivity while at the same time providing maximum security.
• myExchange
With myExchange you can exchange any files/objects from your computer to any of your Leica Exchange Contacts.
• mySecurity
If your instrument is ever stolen, a locking mechanism is available to ensure that the instrument is disabled and can no longer be used.
Zeno 20 Android, Introduction 3
Table of Contents
In this manual Chapter
Safety Directions
General Introduction
Definition of Use
Limits of Use
Responsibilities
Hazards of Use
Electromagnetic Compatibility EMC
FCC Statement, Applicable in U.S.
ICES-003 Statement, Applicable in Canada
Description of the System
Overview
System Concept
Software Concept
Power Concept
Data Storage Concept
System Components
Zeno 20 Components
User Interface
Keyboard
Operating Principles
LED Indicators on Zeno 20
Operation
Equipment Setup
Fixing the Display Foil to the Zeno 20
Inserting and Removing a SIM Card and SD Card
Attaching the AS10/AS05 Antenna to the Zeno 20
Batteries
Operating Principles
Changing the Battery
Charging the Battery
Power Functions
Connecting the Zeno 20 to a PC with the Micro-USB Cable
Optimising the Zeno 20 for GNSS Tracking
Setting up the Zeno 20 with a Disto S910
Software
Overview: Home Screen, Navigation, Apps and Widgets
Settings
Changing the Operating System Language
Resetting the Zeno 20 Device
Useful Applications
Hot Keys
Screenshots
File Manager
System Information
Using the Digital Camera
Boot Logo Changer
Page
Zeno 20 Android, Table of Contents 4
Care and Transport
Transport
Storage
Cleaning and Drying
Technical Data
Zeno 20 Technical Data
Conformity to National Regulations
Dangerous Goods Regulations
Software Licence Agreement
Zeno 20 Android, Table of Contents 5
1
1.1
Description
About Warning
Messages
Safety Directions
General Introduction
The following directions enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid operational hazards.
The person responsible for the product must ensure that all users understand these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instrument. They appear wherever hazards or hazardous situations can occur.
Warning messages...
• make the user alert about direct and indirect hazards concerning the use of the product.
• contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be strictly observed and followed! Therefore, the manual must always be available to all persons performing any tasks described herein.
DANGER , WARNING , CAUTION and NOTICE are standardized signal words for identifying levels of hazards and risks related to personal injury and property damage. For your safety it is important to read and fully understand the table below with the different signal words and their definitions! Supplementary safety information symbols may be placed within a warning message as well as supplementary text.
Type Description
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation or an unintended use which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in appreciable material, financial and environmental damage.
Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner.
Zeno 20 Android, Safety Directions 6
1.2
Definition of Use
Intended use • Remote control of product.
• Data communication with external appliances.
Reasonably forseeable misuse
• Use of the product without instruction.
• Use outside of the intended use and limits.
• Disabling safety systems.
• Removal of hazard notices.
• Opening the product using tools, for example screwdriver, unless this is permitted for certain functions.
• Modification or conversion of the product.
• Use after misappropriation.
• Use of products with obvious damages or defects.
• Use with accessories from other manufacturers without the prior explicit approval of Leica Geosystems.
• Inadequate safeguards at the working site.
Controlling of machines, moving objects or similar monitoring application without additional control and safety installations.
Additional Advice • The Zeno 20 is essentially an enhanced PDA (personal digital assistant) used in geospatial applications. This device is to be used for data logging and data communication for industrial applications only and not for domestic consumer applications.
• This device does not have held-to-ear voice operations.
• This device does not have body-worn accessories.
• This device is designed to be used only in the hand or in fixed installations by mounting it on a pole or a vehicle. When the device is not mounted on a pole or a vehicle, you may use it in handheld mode only and should keep it away from your
body (as described in "4.5 Optimising the Zeno 20 for GNSS Tracking"). Do not
place the device on your lap or any part of the body.
1.3
Limits of Use
Environment Suitable for use in an atmosphere appropriate for permanent human habitation: not suitable for use in aggressive or explosive environments.
DANGER
Local safety authorities and safety experts must be contacted before working in hazardous areas, or close to electrical installations or similar situations by the person in charge of the product.
Environment
The following advice is only valid for battery charger, power adapter and car adapter.
Suitable for use in dry environments only and not under adverse conditions.
Zeno 20 Android, Safety Directions 7
1.4
Responsibilities
Manufacturer of the product
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica Geosystems, is responsible for supplying the product, including the user manual and original accessories, in a safe condition.
Person responsible for the product
The person responsible for the product has the following duties:
• To understand the safety instructions on the product and the instructions in the user manual.
• To ensure that it is used in accordance with the instructions.
• To be familiar with local regulations relating to safety and accident prevention.
• To inform Leica Geosystems immediately if the product and the application becomes unsafe.
• To ensure that the national laws, regulations and conditions for the operation of e.g. radio transmitters or lasers are respected.
1.5
Hazards of Use
DANGER
Because of the risk of electrocution, it is dangerous to use poles, levelling staffs and extensions in the vicinity of electrical installations such as power cables or electrical railways.
Precautions:
Keep at a safe distance from electrical installations. If it is essential to work in this environment, first contact the safety authorities responsible for the electrical installations and follow their instructions.
WARNING
During dynamic applications, for example stakeout procedures there is a danger of accidents occurring if the user does not pay attention to the environmental conditions around, for example obstacles, excavations or traffic.
Precautions:
The person responsible for the product must make all users fully aware of the existing dangers.
WARNING
Inadequate securing of the working site can lead to dangerous situations, for example in traffic, on building sites, and at industrial installations.
Precautions:
Always ensure that the working site is adequately secured. Adhere to the regulations governing safety and accident prevention and road traffic.
CAUTION
If the accessories used with the product are not properly secured and the product is subjected to mechanical shock, for example blows or falling, the product may be damaged or people can sustain injury.
Precautions:
When setting-up the product, make sure that the accessories are correctly adapted, fitted, secured, and locked in position.
Avoid subjecting the product to mechanical stress.
8 Zeno 20 Android, Safety Directions
WARNING
If the product is used with accessories, for example masts, staffs, poles, you may increase the risk of being struck by lightning.
Precautions:
Do not use the product in a thunderstorm.
WARNING
During the transport, shipping or disposal of batteries it is possible for inappropriate mechanical influences to constitute a fire hazard.
Precautions:
Before shipping the product or disposing of it, discharge the batteries by running the product until they are flat.
When transporting or shipping batteries, the person in charge of the product must ensure that the applicable national and international rules and regulations are observed. Before transportation or shipping contact your local passenger or freight transport company.
WARNING
High mechanical stress, high ambient temperatures or immersion into fluids can cause leakage, fire or explosions of the batteries.
Precautions:
Protect the batteries from mechanical influences and high ambient temperatures. Do not drop or immerse batteries into fluids.
WARNING
If battery terminals are short circuited e.g. by coming in contact with jewellery, keys, metalized paper or other metals, the battery can overheat and cause injury or fire, for example by storing or transporting in pockets.
Precautions:
Make sure that the battery terminals do not come into contact with metallic objects.
WARNING
Only Leica Geosystems authorised service workshops are entitled to repair these products.
WARNING
The following advice is only valid for battery charger, power adapter and car adapter.
If you open the product, either of the following actions may cause you to receive an electric shock.
• Touching live components
• Using the product after incorrect attempts were made to carry out repairs
Precautions:
Do not open the product. Only Leica Geosystems authorised service workshops are entitled to repair these products.
The following advice is only valid for batteries, power adapter or docking station.
Zeno 20 Android, Safety Directions 9
WARNING
If the product is improperly disposed of, the following can happen:
• If polymer parts are burnt, poisonous gases are produced which may impair health.
• If batteries are damaged or are heated strongly, they can explode and cause poisoning, burning, corrosion or environmental contamination.
• By disposing of the product irresponsibly you may enable unauthorised persons to use it in contravention of the regulations, exposing themselves and third parties to the risk of severe injury and rendering the environment liable to contamination.
Precautions:
The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with the national regulations in force in your country.
Always prevent access to the product by unauthorised personnel.
Product-specific treatment and waste management information can be downloaded from the Leica Geosystems home page at http://www.leicageosystems.com/treatment or received from your Leica Geosystems dealer.
1.6
Electromagnetic Compatibility EMC
Description The term Electromagnetic Compatibility is taken to mean the capability of the product to function smoothly in an environment where electromagnetic radiation and electrostatic discharges are present, and without causing electromagnetic disturbances to other equipment.
WARNING
Electromagnetic radiation can cause disturbances in other equipment.
Although the product meets the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that other equipment may be disturbed.
The product is a class A product when operated with the internal batteries. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
CAUTION
There is a risk that disturbances may be caused in other equipment if the product is used with accessories from other manufacturers, for example field computers, personal computers or other electronic equipment, non-standard cables or external batteries.
Precautions:
Use only the equipment and accessories recommended by Leica Geosystems. When combined with the product, they meet the strict requirements stipulated by the guidelines and standards. When using computers or other electronic equipment, pay attention to the information about electromagnetic compatibility provided by the manufacturer.
CAUTION
Disturbances caused by electromagnetic radiation can result in erroneous measurements.
Although the product meets the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that the product may be disturbed by intense electromagnetic radiation, for example, near radio transmitters, two-way radios or diesel generators.
Precautions:
Check the plausibility of results obtained under these conditions.
10 Zeno 20 Android, Safety Directions
CAUTION
If the product is operated with connecting cables attached at only one of their two ends, for example external supply cables, interface cables, the permitted level of electromagnetic radiation may be exceeded and the correct functioning of other products may be impaired.
Precautions:
While the product is in use, connecting cables, for example product to external battery, product to computer, must be connected at both ends.
Radios or Digital Use of product with radio or digital cellular phone devices:
Cellular Phones
WARNING
Electromagnetic fields can cause disturbances in other equipment, in installations, in medical devices, for example pacemakers or hearing aids and in aircraft. It can also affect humans and animals.
Precautions:
Although the product meets the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that other equipment can be disturbed or that humans or animals can be affected.
• Do not operate the product with radio or digital cellular phone devices in the vicinity of filling stations or chemical installations, or in other areas where an explosion hazard exists.
• Do not operate the product with radio or digital cellular phone devices near to medical equipment.
• Do not operate the product with radio or digital cellular phone devices in aircraft.
Zeno 20 Android, Safety Directions 11
1.7
WARNING
FCC Statement, Applicable in U.S.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications not expressly approved by Leica Geosystems for compliance could void the user's authority to operate the equipment.
Labelling Zeno 20
Typ e: Ze
Eq no 2 uip.
No.
Po wer
: 12
: 5V
/
1.8
Art
.No
.: 8
XXX
XX
Leic a Geo
CH
Ma sys
35 H nuf
A tem eer s A
S.N
o.: 1
2345
6 brug ac tured
G g
X
FCC-
ID:
IC-
RF
ID:
D.No
D-
. : X
ZE
NO
-ZEN
20G
O2
XX
XXX
0G
XX
XX
Type: Zeno 20 UMTS
Equip. No.: 1234567
Power: 5V / 1.8A
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured: 20XX
Art.No.: 8XXXXX
S.No.: 123456
FCC-ID: RFD-ZENO20G
IC-ID: 3177A-ZENO20G
D.No. : XXXXXXXXXX
Type: Zeno 20 CDMA
Equip. No.: 1234567
Power: 5V / 1.8A
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured: 20XX
Art.No.: 8XXXXX
S.No.: 123456
FCC-ID: RFD-ZENO20C
IC-ID: 3177A-ZENO20C
D.No. : XXXXXXXXXX
in
Ch ina
Made in China
009333_002
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause undesired operation.
Zeno 20 Android, Safety Directions 12
1.8
ICES-003 Statement, Applicable in Canada
WARNING
This Class (B) digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe (B) est conforme à la norme NMB-003 du Canada.
Exposure to radio frequency (RF) signals
The wireless device is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limit for exposure to radio frequency (RF) energy set by the OET Bulletin 65 Supplement C / Ministry of Health (Canada), Safety Code 6. These limits are part of comprehensive guidelines and established permitted levels of RF energy for the general population. These guidelines are based on the safety standards previously set by international standard bodies. These standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
This device has been shown to be capable of compliance for localised specific absorption rate (SAR) for uncontrolled environment / general public exposure limits specific in ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE Std. 1528-2003.
IC Canadian Compliance
This radio transmitter has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p) is not more than that necessary for successful communication.This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:(1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.Le présent appareil est conforme aux
CNR d'Industrie Canada applicables aux appareils radio exempts de licence.L'exploitation est autorisée aux deux conditions suivantes :(1) Ll'appareil ne doit pas produire de brouillage.
(2) L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
13 Zeno 20 Android, Safety Directions
2
2.1
Zeno 20 General
Description
Description of the System
Overview
The Zeno 20 is a compact, high performance, low weight device with an integrated high accuracy GNSS, designed for outdoor & fieldwork usage. The Zeno 20 can withstand severe environmental conditions including vibration, shock, moisture and temperature variations. The Zeno 20 is suitable for use in harsh environments such as construction sites, warehouses, military, manufacturing and field service.
009343_001
Zeno 20 Available
Models
Model Zeno 20 3.75G
Android
Touch screen
Colour display
Zeno 20 3.75G
WEH
Zeno 20 CDMA
Android
Zeno 20 CDMA
WEH
Internal modem W/WWAN-GSM W/WWAN-GSM W/WWAN-
CDMA
Internal batteries
*1
MicroSD Card
Bluetooth
Wireless LAN
802.11b/g/n
Wi-Fi
Operating
System
L1/L2 GNSS board
Android 4.2.2
Windows
Embedded
Handheld 6.5
Professional
W/WWAN-
CDMA
Android 4.2.2
Windows
Embedded
Handheld 6.5
Professional
FCC etc. (reports)
Model Name
FCC ID
Zeno 20 Zeno 20 Zeno 20 Zeno 20
RFD-ZENO20G RFD-ZENO20G RFD-ZENO20C RFD-ZENO20C
CE and IC
Model Name
IC Number
ZENO20G
3177A-
ZENO20G
ZENO20G
3177A-
ZENO20G
ZENO20C
3177A-
ZENO20C
ZENO20C
3177A-
ZENO20C
*1
One removable battery and one backup battery
Zeno 20 Android, Description of the System 14
2.2
2.2.1
Software Options for Zeno 20
System Concept
Software Concept
NOTICE
2.2.2
General
Software type
Windows Embedded Handheld
6.5 Professional (WEH)
Description
This software includes:
• The English version of WEH.
• The basic WEH functionality.
• If ordered, the Zeno Field or Zeno Connect for
Zeno 20.
Android 4.2.2
This software includes:
• The language-specific version of Android.
• The basic Android functionality.
• If ordered, the Zeno Mobile or Zeno Connect for
Zeno 20.
This User Manual only describes the Android version of the Zeno 20. For more information about the other version refer to the respective User Manual.
The Zeno 20 is delivered with the operating system and software that you ordered. The software is already licensed. For information on how to switch to
a different language version, refer to "5.2.1 Changing the Operating System
Language" or to the according software documentation.
The installation includes the latest released Zeno updates, the latest released
GNSS board firmware and the purchased Auth Code. Refer to the according software documentation for more information. Be aware, that the Zeno 20 is only working correctly with the Android versions released from Leica Zeno.
“Google Play Store” will not be available on the Zeno Android. Instead, you can use different app stores such as the “Amazon Appstore” or “1MobileMarket”.
Rooting your Android device will void your right for any warranty services and support by Leica!
Power Concept
Use the batteries, chargers and accessories recommended by Leica Geosystems to ensure the correct functionality of the instrument.
Power Options
Model
Zeno 20
Power supply
Internally by AZ206
*1
battery, OR
Externally by AZ209
*2
AC/DC adapter, OR
Externally by AZ208 car adapter.
If an external power supply is connected and the internal batteries are inserted, then the external power is used. If the power consumption of the Zeno 20 is less than the charging capacity, the internal batteries are charged.
*1
manufacturer: ETI CA Battery Inc.
*2
manufacturer: Ktec
15 Zeno 20 Android, Description of the System
2.2.3
Description
Memory Device
2.3
Zeno 20 Package
Data Storage Concept
Data is stored on a memory device. The memory device can be a USB stick or internal memory.
USB stick:
Internal memory:
MicroSDHC card:
The device has a USB port fitted as standard.
The device has an internal memory fitted as standard.
Available capacity: 4 GB.
The device has an MicroSDHC card slot.
Maximum card size: 32 GB
The delivered Leica Geosystems USB flash drive contains system software and is not certified for permanent data transfer i.e. as data storage for measurement data. Use only certified industrial grade USB flash drives such as the Leica
MS1 (order number 765199).
System Components
The Zeno 20 package includes the following components: a Zeno 20 d AZ203 g e AZ211 b AZ206 h f AZ209 c AZ201
009342_001 a) Zeno 20 Android
OR
Zeno 20 Windows Embedded Handheld b) Rechargeable Battery c) Capacitive Stylus d) Hand Strap e) Data Transfer Cable f) AC Adapter g) Quick Guide h) USB documentation card with software and documents
Zeno 20 Android, Description of the System 16
Optional Accessories
2.4
Front Side of the
Zeno 20
• 16 GB MicroSD card (823058)
• Car Charger (823056)
• Desktop Charger (823055)
• Additional Battery (823054)
• Zeno 20 Pole Plate (823052)
• Zeno 20 Pole Plate and Disto S910 Pole Plate (823053)
• Additional Stylus (823049)
• Disto FTA360 Adapter for Zeno 20 (827546)
• Screen Protection Foil for Zeno 20 (823050)
• AS10 Antenna Cable (667200)
• AS10 (827546)
Zeno 20 Components
a e b c d
009316_001 f a) Internal GNSS Antenna and Board b) External GNSS Antenna Connector c) Screen d) Keypad e) LED Indicators f) Microphone
Back Side of the
Zeno 20 a b c d
009317_001 e f a) Holder for Handstrap b) Camera and Flash c) Speaker d) Compartment with Slots for
Battery, SIM Card and SD Card e) Release Lever for Battery Compartment f) Handstrap Fixation
Bottom Panel of the
Zeno 20 a b
009318_001 a) USB A Host Port b) Micro USB Host Port, works also as
Power Socket
Battery Compartment a b c d a) Battery Cosnnectors b) SIM Card Slot c) MicroSDHC Card Slot d) Latch for Battery Pack
009319_001
Zeno 20 Android, Description of the System 17
3
3.1
Keypad
Functions of the
Keys a b c d e f
User Interface
Keyboard
009320_001 g h l j i k a) Home key b) Left softkey c) Direction Pad UP d) F1 key e) Camera key f) Power key g) Right softkey h) F2 key i) OK key j) Satellite/GNSS key k) F3 key l) Direction Pad DOWN
Key
Power key
Function (WEH) Function (Android)
Power, Suspend & Resume Power, Suspend & Resume
Left Back
Left softkey
Home key
Home
(Returns to main screen)
Right
Home
(Returns to main screen)
Menu
Right softkey
OK key
OK
OK OK
Measure in Zeno Field Measure in Zeno Mobile
Satellite/GNSS key
Up Up
Direction Pad UP
Down Down
Direction Pad DOWN
Press to open camera app.
If camera app is opened:
Press to take a picture.
Press to open camera app.
If camera app is opened:
Press to take a picture.
Camera Key
F1
Programmable hot keys.
Programmable hot keys.
F2
F3
For detailed information on the programmable hot keys, refer to "5.3.1 Hot
Keys".
18 Zeno 20 Android, User Interface
How to Use the
Power Key
3.2
Touch Screen
If the handheld is turned off:
To turn on the handheld, press the Power key for 5 s.
If the handheld is turned on:
• To put the handheld into stand-by mode, press the Power key for maximally 4 s. If you press the Power key again, the handheld returns to normal operation.
• To open the Shut-Down menu, press the Power key for at least 4 s.
Within the menu, you can choose between the options Power Off , Reboot or
Airplane Mode . The Airplane Mode suspends many of the signal transmitting functions of the device.
You can also choose between silent mode, vibration mode or normal mode.
To close the Shut-Down menu, tap on the screen outside the menu or press the left softkey.
Operating Principles
The user interface is operated through the capacitive touch screen. You can either use the supplied stylus or touch the screen with the finger. Multi-touch and gestures are supported.
Operation
To select an item
To start the edit mode in editable fields Tap on the editable field.
To navigate in menus or maps Swipe with the supplied stylus or via touch from one side to the other or up and down.
To accept data entered into an editable field and exit the edit mode
Description
Tap on the item.
To open a context-sensitive menu
To zoom in maps/pictures/apps
To close the virtual keyboard
Tap on the screen outside of the editable field.
Tap on the item and hold for 2 s.
Pinch with your fingers.
Press the left softkey on the keypad or the softkey “Back” on the screen.
Gestures for Touch-Screen
Tap: Tap and hold:
Swipe:
009105_001
Zoom in:
009107_001
009108_001
Zoom out:
009106_001
Rotate:
009111_001
009110_001
Zeno 20 Android, User Interface 19
3.3
LED Indicators
LED Indicators on Zeno 20
Status of the LED
Indicators a b
009326_001 a) Battery LED b) GPS LED
The Zeno 20 device has L ight E mitting D iode indicators. They indicate the basic status of the device.
LED Status of LED Description
Battery LED off Batteries are in use (discharging).
green Batteries are fully charged.
Device is ready for operation.
GPS LED red flashing red
Batteries are charging.
Batteries are low and should be charged.
flashing amber Error off No connection.
green red
GPS FIX is good.
GPS FIX is not good.
Zeno 20 Android, User Interface 20
4
4.1
4.1.1
Fixing the Display
Foil to the Zeno 20
Handheld Step-by-
Step
Operation
Equipment Setup
Fixing the Display Foil to the Zeno 20
a b
009802_001
Step Description
Ensure that the display of the Zeno 20 is free of dust and grease.
The non-reflecting display foil (b) has a carrier foil (a) with the name of the foil printed on it.
1.
2.
3.
Peel away the carrier foil from the display foil.
Do not peel the carrier foil more than 2 cm - 3 cm away.
Fix the laid open adhesive underside of the display foil at the display border.
While peeling away the carrier foil bit by bit, slowly smooth out the display foil onto the display.
4.
Use a microfibre cloth to smooth out potential air bubbles between display and display foil.
Do not use sharp objects!
If you want to reattach the display foil, you can easily remove and fix it again.
4.1.2
Inserting and Removing a SIM Card and SD Card
• Keep the card dry.
• Use it only within the specified temperature range.
• Do not bend the card.
• Protect the card from direct impacts.
Failure to follow these instructions could result in data loss and/or permanent damage to the card.
CAUTION
Always ground yourself to remove any static charge before touching the CPU card. The electronic devices are sensitive to static electricity.
Precautions:
1) Only experienced personnel should open the mechanical housing of the device.
2) Use a grounding wrist strap all the time.
3) Place all the electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis.
21 Zeno 20 Android, Operation
Insert and Remove a SIM Card or an
SD Card Step-bystep
Apply general practice for working with static-sensitive devices when you open the device, insert the SIM or SD card and closing the device:
• Discharge any static charge before opening the device and working with the SIM or
SD card.
• The device must not be subject to high electrostatic potentials when it is open.
• Minimise contact with internal components of the device.
• Avoid any discharges of static electricity near the device when inserting the SIM or
SD card.
2b
1
5s = OFF
3
6
4b
009346_001
Step Description
The slots for the SIM card and the SD card are inside the battery compartment of the Zeno 20.
1.
2.
3.
4.
Turn off the Zeno 20.
Push the release lever on the back side of the Zeno 20 to the position
“unlocked” and remove the cover of the battery compartment.
Remove the battery.
a) Slide the SIM card firmly into the right slot.
b) Slide the SD card firmly into the left slot.
Do not force the card into the slot. The card should be held with the contacts facing the slot.
5.
6.
Insert the battery back into the battery compartment.
Reattach the compartment cover by inserting it bottom first. Close the battery compartment until it clicks into place. The release lever jumps back to the position “locked”.
Zeno 20 Android, Operation 22
4.1.3
Attach External
Antenna Step-by-
Step
Attaching the AS10/AS05 Antenna to the Zeno 20
1
3 2
009334_001
Step Description
1.
Connect the antenna cable to the AS10/AS05 antenna.
2.
Open the protector cap of the external antenna connector on the left side of the Zeno 20 device.
3.
Plug the antenna cable into the external antenna connector.
If you use Zeno Field, Zeno Connect or Zeno Mobile, attaching the antenna cable automatically sets the external antenna as the currently used antenna. If you detach the antenna cable, the internal antenna is used again automatically.
4.2
Battery Power
System
4.2.1
First-time Use /
Charging Batteries
Operation /
Discharging
Batteries
The Zeno 20 device is designed to work with one removable battery placed inside the battery compartment. An internal backup battery is also included, which allows to hotswap the removable battery while the device is running. The fully charged battery provides several hours of battery life.
Operating Principles
• The battery must be charged prior to using it for the first time.
• The permissible temperature range for charging is between 0°C to +40°C/ +32°F to
+104°F. For optimal charging, we recommend charging the batteries at a low ambient temperature of +10°C to +20°C/+50°F to +68°F if possible.
• It is normal for the battery to become warm during charging. Using the chargers recommended by Leica Geosystems, it is not possible to charge the battery if the temperature is too high.
• For Li-Ion batteries, a single refreshing cycle is sufficient. We recommend carrying out a refreshing cycle when the battery capacity indicated on the charger or on a
Leica Geosystems product deviates significantly from the actual battery capacity available.
• The batteries can be operated from -30°C to +60°C/-22°F to +140°F.
• Low operating temperatures reduce the capacity that can be drawn; high operating temperatures reduce the service life of the battery.
23 Zeno 20 Android, Operation
4.2.2
Replacing an Empty
Battery
Changing the Battery
The batteries are hot-swappable. You can remove an empty battery and replace it with a charged one without turning off the device completely. Before removing an empty battery, put the device into sleep-mode. After replacing the battery you can resume normal operation.
Remove the
Battery: Step-bystep
2b
009327_001
Step Description
Ensure that the handheld is put into stand-by mode.
1.
Place the Zeno 20 on a stable surface, with the back side facing up.
2.
3.
4.
While pushing the release lever to the position “unlocked”, open and remove the cover of the battery compartment.
To release the battery from the compartment, press down the latch.
While pressing down the latch, lift the battery with your thumb and remove it from the compartment.
Insert the Battery:
Step-by-step 1a
1b
2a
009329_001
Step Description
To open the battery compartment, follow the instructions of the previous paragraph.
1.
Insert the battery into the compartment with the contacts facing the top, until the battery clicks into place.
2.
Reattach the compartment cover by inserting it bottom first. Close the battery compartment until it clicks into place. The release lever jumps back to the position “locked”.
The IP67 protection is only ensured if the battery compartment is attached correctly!
24 Zeno 20 Android, Operation
4.2.3
Charging the Battery
WARNING
If unit is not connected to ground, death or serious injury can occur.
Precautions:
To avoid electric shock power cable and power outlet must be grounded.
WARNING
The following advice is only valid for battery charger, power adapter and car adapter.
If you open the product, either of the following actions may cause you to receive an electric shock.
• Touching live components
• Using the product after incorrect attempts were made to carry out repairs
Precautions:
Do not open the product. Only Leica Geosystems authorised service workshops are entitled to repair these products.
WARNING
The following advice is only valid for batteries, power adapter or docking station.
The product is not designed for use under wet and severe conditions. If unit becomes wet it may cause you to receive an electric shock.
Precautions:
Use the product only in dry environments, for example in buildings or vehicles. Protect the product against humidity. If the product becomes humid, it must not be used!
Charge Battery
Step-by-Step
100-240 V 12/24 V USB
AZ208
AZ211
AZ209
1
009336_001
Step Description
Only use the charger delivered with the Zeno 20.
Similar to a smartphone, the Zeno 20 switches on automatically when you attach it to a power adapter. While charging, the device cannot be switched off. To reduce the charging time, turn off GPS.
25 Zeno 20 Android, Operation
Step Description
1.
Connect the AZ209 power adapter to the Zeno 20 and to an A/C plug.
Alternatives :
• Connect the AZ208 car charger to the Zeno 20 and to a cigarette lighter of a car (12V/24V DC).
• Connect the Zeno 20 to a computer using the AZ211 data transfer cable.
Note: The data transfer cable has a lower charging capability than the
AC power adapter!
• Remove the battery from the Zeno 20 and charge it with the Desktop
Charger (823055). This charger allows you to charge up to two batteries simultaneously.
2.
The batteries start charging. The Battery LED switches on to indicate the status of the battery.
Refer to "3.3 LED Indicators on Zeno 20" for information about the
4.3
Power Functions
Turning the Zeno 20
On: Step-by-step
Step Description
1.
Place the Zeno 20 on a flat and stable surface or hold the device in your hand.
2.
Ensure that either the device is connected with the AC power adapter or the batteries are charged up.
3.
Press and hold Power key ( ) for 5 s.
While the operating system boots up, the booting screen is displayed. When the main screen is displayed, the Zeno 20 is ready to use.
Turning the Handheld Device Off:
Step-by-step
Step Description
Note: While charging, the Power Off function is disabled and the device cannot be switched off.
1.
Press the Power key for at least 4 seconds to open the Shut-Down menu.
2.
Within the menu, select on of the following options:
• Power Off: The operating system shuts down and the handheld is turned off.
• Reboot: The handheld device reboots.
• Airplane Mode: Suspends many of the signal transmitting functions.
Select this mode in order to save battery power when not using the device.
Within the menu, you can also choose between vibration or silent mode.
In order to close the Shut-Down menu, press somewhere outside of the dialog.
After turning off the handheld device, wait for at least 5 seconds before turning it on again.
26 Zeno 20 Android, Operation
4.4
Connect Handheld
Device to PC:
Step by-Step
Connecting the Zeno 20 to a PC with the Micro-USB Cable
1
ON
2a
2b
AZ211
009339_001
1.
2.
Turn on the Zeno 20.
With the data transfer cable, connect the handheld device to the PC.
3.
On the Zeno 20, you need to select which kind of connection you want to establish to the PC:
Select Media sync (MTP) .
The AutoPlay menu opens up automatically and you can browse the files stored on theZeno 20.
If an SD card is inserted into the Zeno 20 and the handheld device is connected to a PC, you can also access the data that is stored on the SD card.
Optimising the Zeno 20 for GNSS Tracking 4.5
Recommendations To optimise the GNSS tracking of the Zeno 20, adhere to the following recommendations:
• Do not hold the device too close to your body to ensure good visibility of satellites.
• Hold the device always pointed towards the direction where the most satellites are probable to be seen. Due to the satellite constellation, this is the southern direction on the northern hemisphere, and the northern direction on the southern hemisphere. This ensures, that you do not impair the visibility of most of the satellites by shielding the device with your body.
• To ensure the best tracking behaviour of the integrated antenna, hold the device in a way that the antenna is aligned horizontally as best as possible.
009332_001
Zeno 20 Android, Operation 27
4.6
GAMtec-Setup
Setting up the Zeno 20 with a Disto S910
You can combine the Zeno 20 with a Disto S910 to get a TPS-similar setup.
Position the setup close to the asset where the GNSS conditions are good and measure your target with the Disto S910. This method allows you to measure inaccessible or unreachable points from a safe distance and to collect data in areas where the
GNSS reception is bad. To increase your productivity, it is also possible to measure multiple assets within sight of one setup point.
Tripod Solution: Zeno 20 and Disto S910 are mounted on a tripod using the Disto FTA360 adapter. This solution allows for a stable setup for more accurate measurements with the
Disto S910. For this setup, you can use the internal antenna of the Zeno 20.
009345_001
For more information on how to use the Zeno 20 with a Disto S910, refer to the respective software documentations.
Accuracy of Measured Points
When using the combination of Zeno 20 and Disto S910, the accuracies of the points measured with the Disto S910 depend on different variables. To ensure high point accuracies, keep in mind the following principles:
1) The farther away the reference point that you measure for your orientation, the better the resulting point accuracies. Make sure that the reference point is at least
25 m away from your current position.
2) When measuring new points with the Disto S910 that are far from your current position, the point accuracy decreases.
3) The better the accuracy of the reference point and of the current position, the better the resulting point accuracies. When measuring points with GNSS, make sure that you measure with highest possible accuracy, for example with open sky conditions and averaging of at least 10 seconds.
Zeno 20 Android, Operation 28
5
5.1
Home Screen
Software
Overview: Home Screen, Navigation, Apps and Widgets
The home screen is the starting place for accessing all functionalities of the instrument. The screen is displayed after switching on the instrument.
a b c d e a) Status bar with icons b) Notification area c) Widget installed on the home screen d) Background image (user definable) e) Apps added to the home screen f) Access to all apps, settings and widgets g) Navigation bar with softkeys
008977_001 f g
You can customize the home screen by adding different
apps and widgets to the home screen pages (refer to "
Apps and Widgets"). To access the additional pages of the
home screen, swipe to the left or to the right.
Status Icons
008978_001
The icons within the status bar indicate the current status of the main system functions. If an icon is not displayed, the respective system function is switched off.
a b c d e f g
009081_001 a) Bluetooth status (on/off) b) Current volume setting/vibration mode c) Wifi status (on/off) and reception d) Modem status (on/off) and reception e) Battery status: remaining power and charging/discharging mode f) Current time g) Airplane mode
Zeno 20 Android, Software 29
Softkeys Use the softkeys within the navigation bar to navigate through Android. The same function of the softkeys can be executed by pressing the according hard key on the
Zeno 20 keyboard (refer to " Functions of the Keys").
Back: Returns to the last page. This function also applies to pages within an app.
009085_001
Home: Returns to the Home screen.
009086_001
Menu: Opens an overview over all currently running apps. Within this menu, you can close apps to save battery power.
009087_001
To close an app, drag it to the left or right until it disappears.
You can hide the navigation bar or show it again. Press the button to open the APPS page. Select Tools
NoNaviBar . Tap OK to show or hide the navigation bar.
Notifications and
Access to Important
Settings
Android is able to push information to you using notifications. In this case, an icon appears within the notification area.
To display details on all recently received notifications, slide down the notification area to open the notification drawer.
009082_001 a b
Within the notification drawer, the notifications details are displayed.
To display the main settings of the Zeno 20, press the button in the upper right-hand corner.
a) Button to display the main settings of the
Zeno 20.
b) Received notifications.
009083_001
Zeno 20 Android, Software 30
009084_001 a b a) Button to display the notification details within the notification drawer.
b) Buttons to access the main settings of the
Zeno 20.
Press one of the buttons to change a setting or enable/disable a function, such as Wi-Fi,
Modem, Bluetooth.
For some of these functions, further settings are necessary, for example, when enabling Wi-Fi, you have to select a respective Wi-Fi connection.
Tip: In order to save battery power when not working, disable the functions that you do not need currently.
This decreases the power consumption of the Zeno 20 and thus increases the lifetime of the battery.
In order to display the main settings of the
Zeno 20 directly from any menu, slide down the notification drawer with two fingers.
Apps and Widgets
009112_001
The home screen can have multiple pages which you can access by swiping to the left or to the right. You can use apps and widgets to customise the different pages of the home screen by adding an app or a widget to a page.
To access all available apps and widgets, press the displayed.
button. The APPS page is
APPS page:
• To display further apps, swipe to the left.
• To display the WIDGETS page, swipe to the left or tap on the tab WIDGETS.
• To get faster access to a specific app, drag the app and drop it on a page of the home screen at the desired position.
• To remove an app from a page of the home screen, tap and hold the app, until the text “Remove” appears at the top of the screen, then drag and drop the app on top of the text “Remove”.
009090_001
Zeno 20 Android, Software 31
5.2
Settings page
WIDGETS page:
• To display further widgets, swipe to the left.
• To display the APPS page, swipe to the right or tap on the tab APPS.
• To add a specific widget to your home screen, drag the widget and drop it on a page of the home screen at the desired position.
• To remove a widget from a page of the home screen, tap and hold the widget until the text “Remove” appears at the top of the screen, then drag and drop the widget on top of the text “Remove”.
009091_001
Settings
To access the settings page, press the button and tap on the Settings icon.
To scroll up or down the list of available settings, swipe across the screen.
009093_001
On the settings page, you can manage a variety of information and settings:
• WIRELESS & NETWORKS
– Enable or disable Wi-Fi and Bluetooth.
– Display information on data usage.
– Press More... to display further options.
• DEVICE
– Define the settings for sound and display.
– Display information on storage use.
– Display information on power consumption of different apps.
– Display information on installed apps.
• PERSONAL
– Define the settings for location access and security.
– Define the system language and the input method.
– Execute factory resets.
• ACCOUNTS
– Add an account.
• SYSTEM
– Change the settings for date and time.
– Define the settings for accessibility.
– Display basic phone information and execute system updates.
Zeno 20 Android, Software 32
5.2.1
Language & input page
Changing the Operating System Language
To access the Language & input page, open the settings menu and tap on the button
Language & input within the section PERSONAL.
To change the Operating System Language, tap on the button Language and select the desired language.
As default, the keyboard language is equivalent to the system language. If you want to change the keyboard language, tap on the button Default within the section
KEYBOARD & INPUT METHODS.
Once the device is connected to a mobile data connection using the SIM card, the language is automatically changed according to your location.
5.2.2
Performing a
Factory Reset
009095_001
Resetting the Zeno 20 Device
009097_001
Resetting the Zeno 20 device back to factory default is helpful if some components of the device are not working correctly anymore. During a factory reset, Android (including all drivers) is reinstalled completely. A factory reset helps to determine if a problem is hardware or software related.
To prevent data loss, backup all important data to an SD card or an external memory device before performing a factory reset. After a factory reset, you need to install licences and software files again manually.
1) Open the Settings menu. Within the section PERSONAL, tap on the button Factory data reset.
2) To start the data reset, tap on the button Reset phone.
3) Confirm by pressing the button Erase everything.
The device is automatically reset to the last installed version of the operating system. This process may take a few minutes.
Zeno 20 Android, Software 33
5.3
5.3.1
Define a Hot Key
Step-by-step
Useful Applications
Hot Keys
The keys F1 , F2 and F3 on the keypad are programmable hot keys. To assign a function or an application to these keys, carry out the following instructions.
Step Description
1.
Tap on the button to open the page APPS. Select
Tools
Program Buttons to open the Program Buttons window.
Within the tab PROPERTIES , a list of the programmable keys and their currently assigned functions is displayed.
2.
3.
4.
009103_001
Tap on the key for which you want to define a specific function.
A window with the available key functions is displayed.
Tap on a function or an application to assign it to the key.
To save your changes and exit the window, tap OK .
To reassign the default key function, tap Default .
To exit the window without saving any changes, tab Cancel .
Alternative:
You can also apply a key definition file with already defined key functions.
Step Description
1.
2.
3.
Within the Program Buttons page, tap on the DEFINE tab.
To select a key definition file, tap the ... button and choose a file from the directory.
To apply the selected key definition file, tap Apply .
To reset the key definition file to default, tap Default key definition file .
4.
To exit the window, tap OK in the command bar or press the OK key on the keypad.
Note: The functions that you assign to the hotkeys do not apply when working within Zeno Mobile. There are predefined functions for Zeno Mobile. For information on these key functions refer to the according software documentation.
Zeno 20 Android, Software 34
5.3.2
Screenshots
Create a Screenshot The system allows you to capture the current screen displayed on the Zeno 20.
To create a screenshot, press the Home key and Power key simultaneously for about
2 seconds.
The captured screenshot is shortly displayed and then stored in the following directory: /storage/sdcard0/Pictures/Screenshots/ .
5.3.3
File Manager
Browse for a File with the
OI File Manager
5.3.4
Save System Information to a File
The OI File Manger allows you to browse for files that are stored on the Zeno 20, on a USB stick plugged into the Zeno 20 or on an SD card inserted in the Zeno 20.
To access the file manager, tap on the
Tools
OI File Manager .
button and select
System Information
Within the System Information page, you can save the current system information in a file. If there is a problem with the device and the support needs information about the version numbers of the device, you can use this file.
To access the System Information page, tap on the
Tools
System Information .
button and select
Using the Digital Camera 5.3.5
Camera App The Zeno 20 is equipped with a digital camera that allows you to capture images.
To open the Camera app, press the Camera key or tab on the Camera icon within the
APPS page.
To capture an image, press the Camera key or press the respective button within the camera app.
The image is stored in the following directory: /storage/sdcard0/Pictures .
Zeno 20 Android, Software 35
5.3.6
Customise the
Start-Up Screen
Boot Logo Changer
You can customise the start-up screen of the Zeno 20 device by using the app “Boot Logo Changer”. This app is installed per default on your Android device.
1)To change the start-up screen, place the desired image file in the root directory of the device: /storage/sdcard0 or
/storage/sdcard1 .
The image file must meet the following restrictions:
–Width: 480 pixel
–Height: 854 pixel
–File size: max. 410998 byte
–Bit count: 8
–Format: BMP
2)To open the app, tap on the button and select Boot
009176_001
Logo Changer .
3)Within the app, tap on the image file that you want to install as start-up screen.
A message is displayed to inform you about the status of the start-up screen.
To switch back to the default Leica start-up screen, select Default .
Zeno 20 Android, Software 36
6
6.1
Care and Transport
Transport
Transport in a road vehicle
Never carry the product loose in a road vehicle, as it can be affected by shock and vibration. Always carry the product in its transport container, original packaging or equivalent and secure it.
Shipping When transporting the product by rail, air or sea, always use the complete original
Leica Geosystems packaging, transport container and cardboard box, or its equivalent, to protect against shock and vibration.
Shipping, transport of batteries
When transporting or shipping batteries, the person responsible for the product must ensure that the applicable national and international rules and regulations are observed. Before transportation or shipping, contact your local passenger or freight transport company.
6.2
Product
Li-Ion batteries
Storage
Respect the temperature limits when storing the equipment, particularly in summer if
the equipment is inside a vehicle. Refer to "7 Technical Data" for information about
temperature limits.
• Refer to "Technical Data" for information about storage temperature range.
• Remove batteries from the product and the charger before storing.
• After storage recharge batteries before using.
• Protect batteries from damp and wetness. Wet or damp batteries must be dried before storing or use.
• A storage temperature range of 0°C to +30°C / +32°F to +86°F in a dry environment is recommended to minimize self-discharging of the battery.
• At the recommended storage temperature range, batteries containing a 30% to
50% charge can be stored for up to one year. After this storage period the batteries must be recharged.
Zeno 20 Android, Care and Transport 37
6.3
Cleaning and Drying
Product and accessories
Damp products
• Use only a clean, soft, lint-free cloth for cleaning. If necessary, moisten the cloth with water or pure alcohol. Do not use other liquids; these may attack the polymer components.
Dry the product, the transport container, the foam inserts and the accessories at a temperature not greater than 40°C/104°F and clean them. Remove the battery cover and dry the battery compartment. Do not repack until everything is dry. Always close the transport container when using in the field.
Cables and plugs
Connectors with dust caps
Keep plugs clean and dry. Blow away any dirt lodged in the plugs of the connecting cables.
Wet connectors must be dry before attaching the dust cap.
Zeno 20 Android, Care and Transport 38
7
7.1
Control unit
System
Dimensions
Weight
Recording
Power
Internal battery
Environmental specifications
Technical Data
Zeno 20 Technical Data
Touch Screen:
Keyboard:
Audio:
Digital camera:
4.7’’ FWVGA (854 x 480 pixels); IPS; 600 nits, capacitive multi-touch Asahi Dragontrail chemically strengthened glass
12 keys, including three programmable function keys and software-specific keys
Built-in receiver, loud-speaker and microphone
8-megapixel camera with autofocus and LED flash
Processor:
Operating System:
System Memory:
I/O slot:
Storage:
Texas Instrument 4470 dual-core 1.5 GHz
Windows Embedded Handheld 6.5 Professional OR
Android 4.2.2
1 GB RAM / 4 GB iNAND Flash
SIM (user accessible), MicroSD/MicroSDHC slot
4 GB built-in storage
Length [m]
0.27
Width [m]
0.099
Thickness [m]
0.050
Type
Zeno 20 with battery
Zeno 20 without battery
Weight [kg]/[lbs]
0.87/1.92
0.72/1.59
Data can be recorded on the USB memory stick, on an SD card or in the internal memory.
Type
Zeno 20
External supply voltage
Nominal voltage 5 V DC ( )
Type
Zeno 20
Battery
Li-Ion
Voltage
3.7
V
Capacity
7800 mAh
Operating time, typical
*
7 h
*
Operating time depends on use of wireless communication devices.
Temperature
Operating temperature: -30°C to +60°C
Storage temperature: -40°C to +70°C
Protection against water, dust and sand
IP67 (IEC60529)
Dust tight
Waterproof to 1 m temporary immersion
Humidity
Protection: Up to 90 %
The effects of condensation are to be effectively counteracted by periodically drying out the device.
Zeno 20 Android, Technical Data 39
Interfaces
Vibration
Protection: Withstands strong vibration during operation, compliance with
MIL STD-810G - 514.6 I/II - Cat.5
Drops
Protection: Withstands 1.22 m drop, compliance with MIL-STD-810G - 516.6 IV
MicroUSB:
USB host:
Bluetooth:
WLAN:
Micro A/B Connector
USB A
Class 2
802.11 b/g/n
Audio: Micro-In, Audio-Out
External antenna connector: SMB connector
L1/L2 GNSS
Type
Channels:
Values
120 channels
Satellite signals tracking: Basic configuration: GPS L1 only
Upgrade options: GPS: L2, L2C
GLONASS: L1, L2
BeiDou: B1
Galileo: E1
Integrated real-time:
Output data protocols:
Real-time protocols:
Update rate:
Time to first fix*
SBAS (WAAS, EGNOS, GAGAN)
NMEA-0183 (GGA, VTG, GLL, GSA, ZDA, GSV, RMC, GST,
GRS) via Zeno Connect only
RTCM 2.x, RTCM 3.0, RTCM 3.1, Leica, CMR, CMR+
1 Hz (1 s)
Optional:
Typically <45 s
5 Hz (0.2
s)
* May vary due to used antenna, atmospheric conditions, multipath, obstructions, signal geometry and number of tracked satellites.
7.2
Conformity to National Regulations
Conformity to national regulations
• FCC Part 15, 22 and 24 (applicable in US).
• Hereby, Leica Geosystems AG, declares that the Zeno 20 and the Zeno 20 are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC and other applicable European Directives. The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC (R&TTE) can be placed on the market and be put into service without restrictions in any EEA Member state.
• The conformity for countries with other national regulations not covered by the FCC part 15, 22 and 24 or European directive 1999/5/EC has to be approved prior to use and operation.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance.
– This device is granted pursuant to the Japanese Radio Law and the Japanese
Telecommunications Business Law.
– This device should not be modified (otherwise the granted designation number will become invalid).
Zeno 20 Android, Technical Data 40
Frequency Band
Type
Zeno 20, Bluetooth
Zeno 20, WWAN
Zeno 20, WLAN
Frequency band [MHz]
2402 ~ 2480
WCDMA: HSDPA/UMTS - 800/850/900/1900/2100
GSM: Quad-Band EDGE/GPRS/GSM - 850/900/1800/1900
CDMA: Dual-Band EV-DO Rev. A-800/1900
CE: 2412 ~ 2472
FCC: 2412 ~ 2462
7.3
Dangerous Goods
Regulations
Dangerous Goods Regulations
The products of Leica Geosystems are powered by Lithium batteries.
Lithium batteries can be dangerous under certain conditions and can pose a safety hazard. In certain conditions, Lithium batteries can overheat and ignite.
When carrying or shipping your Leica product with Lithium batteries onboard a commercial aircraft, you must do so in accordance with the
IATA Dangerous Goods Regulations .
Leica Geosystems has developed Guidelines on “How to carry Leica products” and “How to ship Leica products” with Lithium batteries. Before any transportation of a Leica product, we ask you to consult these guidelines on our web page (http://www.leica-geosystems.com/dgr) to ensure that you are in accordance with the IATA Dangerous Goods Regulations and that the Leica products can be transported correctly.
Damaged or defective batteries are prohibited from being carried or transported onboard any aircraft. Therefore, ensure that the condition of any battery is safe for transportation.
Zeno 20 Android, Technical Data 41
8
Software Licence
Agreement
Software Licence Agreement
This product contains software that is preinstalled on the product, or that is supplied to you on a data carrier medium, or that can be downloaded by you online according to prior authorisation from Leica Geosystems. Such software is protected by copyright and other laws and its use is defined and regulated by the Leica Geosystems Software
Licence Agreement, which covers aspects such as, but not limited to, Scope of the
Licence, Warranty, Intellectual Property Rights, Limitation of Liability, Exclusion of other Assurances, Governing Law and Place of Jurisdiction. Please make sure, that at any time you fully comply with the terms and conditions of the Leica Geosystems Software Licence Agreement.
Such agreement is provided together with all products and can also be referred to and downloaded at the Leica Geosystems home page at http://www.leicageosystems.com/swlicense or collected from your Leica Geosystems distributor.
You must not install or use the software unless you have read and accepted the terms and conditions of the Leica Geosystems Software Licence Agreement. Installation or use of the software or any part thereof, is deemed to be an acceptance of all the terms and conditions of such Licence Agreement. If you do not agree to all or some of the terms of such Licence Agreement, you must not download, install or use the software and you must return the unused software together with its accompanying documentation and the purchase receipt to the distributor from whom you purchased the product within ten (10) days of purchase to obtain a full refund of the purchase price.
Zeno 20 Android, Software Licence Agreement 42
Leica Geosystems AG
Heinrich-Wild-Strasse
CH-9435 Heerbrugg
Switzerland
Phone +41 71 727 31 31 www.leica-geosystems.com
837160-1.1.0en
Original text
Printed in Switzerland
© 2015 Leica Geosystems AG, Heerbrugg, Switzerland
advertisement
Related manuals
advertisement
