Version 7.0
English
Leica RX1200
User Manual
Introduction
Introduction
Purchase
RX1200
2
Congratulations on the purchase of an RX1200.
This manual contains important safety directions as well as instructions for setting
up the product and operating it. Refer to "7 Safety Directions" for further information.
Read carefully through the User Manual before you switch on the product.
Product identification
The type and serial number of your product are indicated on the type plate.
Enter the type and serial number in your manual and always refer to this information when you need to contact your agency or Leica Geosystems authorized service workshop.
Type:
Serial No.:
_______________
_______________
Symbols
Trademarks
Introduction
The symbols used in this manual have the following meanings:
Type Description
Danger
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Warning
Indicates a potentially hazardous situation or an unintended use which, if not avoided, could result in death or serious injury.
Caution
Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor or moderate injury and/or appreciable material, financial and environmental damage.
)
Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner.
• Windows and Windows CE are a registered trademark of Microsoft Corporation
• CompactFlash and CF are trademarks of SanDisk Corporation
• Bluetooth is a registered trademark of Bluetooth SIG, Inc
All other trademarks are the property of their respective owners.
RX1200
3
Introduction
Validity of this manual
Available documentation
RX1200
This manual applies to all RX controllers. Differences between the various models are marked and described.
4
Name Description/Format of RX1200 manuals
User Manual All instructions required in order to operate the product to a basic level are contained in the User Manual.
Provides an overview of the product together with technical data and safety directions.
9
Name
System Field
Manual
Applications
Field Manual
Technical
Reference
Manual
Description/Format of
GPS1200+/TPS1200+/TPS1200 manuals
Describes the general working of the product in standard use. Intended as a quick reference field guide.
Describes specific onboard application programs in standard use. Intended as a quick reference field guide.
Overall comprehensive guide to the product and program functions. Included are detailed descriptions of special software/hardware settings and software/hardware functions intended for technical specialists.
9
9
9
9
9
Refer to the following resources for all System1200 documentation/software:
• the SmartWorx DVD
• http://www.leica-geosystems.com/downloads
Introduction
RX1200
5
Table of Contents
Table of Contents
In this manual
RX1200
Chapter
Data Storage and Data Conversion Concept
Fixing the RX to a Holder and Pole
6
Page
Table of Contents
Fixing the RX to a GNSS Receiver
Setting up for Remote Control (with the RadioHandle)
Setting up for Remote Control (with the TCPS27)
Setting up a Real-Time Reference
3.3 Working with the CompactFlash Card
3.4 LED Indicators on SmartAntenna
3.6 Working with the Clip-On-Housings for Devices on GHT56
3.7 Guidelines for Correct Results with GNSS Surveys
4 Getting Started with SmartWorx
4.2 Turning on the RX, setting the Instrument Mode and Interface
4.3 Understanding the Main Menu
4.4 Switching Between GPS and TPS
RX1200
7
Table of Contents
RX1200
4.6 Connecting to a Digital Cellular Phone
4.8 Connecting to a Personal Computer
4.9 Connecting to a Radio (for Remote Control Surveys)
Working in Semi-Transparent Mode
4.10 Connecting to the SmartAntenna
5.1 Accessing the Main Configuration Menu
5.2 Overview of the Main Configuration Menu
8
Table of Contents
7.5 End User Licence Agreement EULA
7.7 Electromagnetic Compatibility EMC
7.8 FCC Statement, Applicable in U.S.
9.2 SmartAntenna Technical Data
9.4 Conformity to National Regulations
RX1200
9
Table of Contents
RX1200
10
GFU19 (US), GFU25 (CAN), GFU26 (US) CDMA MultiTech
10 International Limited Warranty, Software Licence Agreement
Appendix A Directory Structure of the Memory Device
Table of Contents
RX1200
11
Description of the System
1
1.1
RX1200
Description of the System
Terminology
Abbreviations
12
The following abbreviations may be found in this manual:
Term
GNSS
LGO
RCS
TPS
Description
Global Navigation Satellite System (generic term for satellite based navigation systems like GPS, GLONASS, Galileo, Compass, SBAS)
LEICA Geo Office (office software consisting of a suite of standard and extended programs for the viewing, exchange and management of data)
Remote Control Surveying
Total Station Positioning System
RX general description
Type
RX or
RX1200
Description
This is a collective term describing the various models of the multipurpose controller which is used with GPS and TPS instruments.
RX available models
RX1210
RX1210T
RX1250T
RX1250Tc
9
9 9
9 9
9
GPS1200+ GX Receiver
GPS1200+ GX Receiver
9 9 9 9 9 TPS1200+/TPS1200 instruments
9 9 9 9 9 9 TPS1200+/TPS1200 instruments
RX1250X
RX1250Xc
9 9
9 9
9 9 9 9 GPS1200+ SmartRover
9 9 9 9 GPS1200+ SmartRover
)
Use the supplied stylus on the screens of the touch screen models.
Description of the System
RX1200
13
Description of the System
RX available radios
RX1200
Radios for remote control (RCS) are found in the following devices:
Radio
Modem
GFU23
Description
Clip-on-Housing with an integrated radio modem and attached radio antenna.
14
RadioHandle Instrument carry handle with an integrated radio modem and attached radio antenna.
RX1250T
RX1250Tc
Controller with an integrated radio modem and attached radio antenna. This controller has a monochrome display.
Controller with an integrated radio modem and attached radio antenna. This controller has a colour display.
TCPS27
TCPS27B
TCPS27R
External radio modem with attached radio antenna.
TCPS27 set to operate as a base radio.
TCPS27 set to operate as a remote radio.
)
All devices contain the same spread spectrum transceiver radio modem.
1.2
1.2.1
System Concept
Software Concept
Software for
RX1210/RX1210T
Software for all
RX1250 models
Software type
RX firmware
(RX1200.fw)
Software type
RX firmware
(RX1250_xx.fw)
Description of the System
Description
These RX models are used as terminals and only one software is required to be installed. All other necessary software is loaded onto the GPS/TPS.
This software includes all the local display, sound and communication settings. These settings can only be changed by putting the RX into local mode.
Description
These RX models can be used as data loggers or terminals.
The same amount of software is required to be installed as for the GPS/TPS. This software includes:
- The local display, sound and communication settings.
- The language specific version of Windows CE.
- The basic functionality of the RX.
RX1200
15
Description of the System
RX1200
16
Software type Description
- The programs Survey and Wake-Up (for GPS) and Survey and Setup (for TPS), which cannot be deleted.
- The English language, which cannot be deleted.
Numerous languages are available for the RX. Language software is also referred to as system language.
Language software
(SYS_LANG.sxx)
Application programs
(RX_program.axx)
The system software enables a maximum of three languages which can be stored at any one time - the English language and two other languages. The English language is the default language and cannot be deleted. One language is chosen as the active language.
A suite of optional survey-specific application programs are available for the instrument.
Some of these programs are freely available and can be loaded and are immediately activated. The other programs must be purchased and are only activated with a licence key.
Software for the
SmartAntenna
Software upload
Software type
Customised application programs
Description
Custom software specific to user requirements can be developed using the GeoC++ development kit.
Information on the GeoC++ development environment is available on request from a Leica Geosystems representative.
Software type
SmartAntenna software
Description
This is the software for the ATX1230+ GNSS. It covers the firmware for the measurement engine.
Software for
RX1210/RX1210T
Description
This firmware can be uploaded to RX via LGO,
TPS1200+/TPS1200 or GPS1200+.
If TPS1200+ is being used, refer to the TPS1200+ Technical Reference Manual.
If TPS1200 is being used, refer to the TPS1200 Technical
Reference Manual.
Description of the System
RX1200
17
Description of the System
RX1200
18
Software for Description
If GPS1200+ is being used, refer to the GPS1200+ Technical Reference Manual.
If LGO is being used, refer to the online help in LGO.
All RX1250 models
All software is stored in the System RAM of the RX. The software can be uploaded onto a CompactFlash card in the
RX.
After uploading, the software must then be transferred from the CompactFlash card to the RX System RAM. Refer to
GPS1200+/TPS1200+/TPS1200 Technical Reference
Manuals for further details.
SmartAntenna
Microsoft ActiveSync is the synchronization software for
Windows mobile-based pocket PC’s. Microsoft ActiveSync enables a PC and a Windows mobile-based pocket PC to communicate.
SmartAntenna must always be connected to an RX1250 model when uploading the firmware. Connect Smart-
Antenna and an RX1250 model via cable. Uploading the firmware takes some time.
1.2.2
Description
Data Storage and Data Conversion Concept
Memory device
Data is stored within a job in a database on a memory device.
The memory device can be a CompactFlash card or internal memory.
CompactFlash card: A CompactFlash card slot is standard. A CompactFlash card can be inserted and removed. Available capacity:
256 MB.
)
Whilst other CompactFlash cards may be used,
Leica recommends to only use Leica Compact-
Flash cards and is not responsible for data loss or any other error that may occur whilst using a non-Leica card.
)
Unplugging connecting cables or removing the CompactFlash card during the measurement may cause loss of data. Always return to the Main Menu screen before removing the CompactFlash card and switch off the instrument before removing cables.
Description of the System
RX1200
19
Description of the System
Data conversion Export
RX1200
20
Data can be exported from a job in a wide range of ASCII formats. The export format is defined in Format Manager which is a PC tool in LEICA Geo Office. Refer to the online help of LGO for information on creating format files.
Data can also be exported from a job in DXF or LandXML format.
Import
Data can be imported from ASCII, DXF, GSI8 or GSI16 format.
Data can be transferred in various ways. Refer to "ActiveSync" and LGO online help.
Transfer data
)
CompactFlash cards can directly be used in an OMNI drive as supplied by Leica
Geosystems. Other PC card drives may require an adaptor.
1.2.3
General
Power Concept
Use the Leica Geosystems batteries, chargers and accessories or accessories recommended by Leica Geosystems to ensure the correct functionality of the instrument.
Power options
Model Power supply
RX1210/RX1210T Via cable, or
Via clip-on connector of the GPS receiver, or
Externally via cable all RX1250 models Internally via GEB211 battery, or
Externally via cable
If an external power supply is connected and one internal battery is inserted, then the external power is used.
SmartAntenna Internally via GEB211 battery, or
Externally via cable
If an external power supply is connected and one internal battery is inserted, then the external power is used.
Description of the System
RX1200
21
Description of the System
1.3
Container Contents
Container for
System 1200 components part 1 of 2
a b c d
RX1200 e f
SYS12_001 g h i j k l m n o a) GAD33 Arm 15cm b) ATX SmartAntenna c) Cables d) GHT52 Clamp e) GAD31 Adapter f) Radio antennas g) GAD104 SmartAntenna
Adapter h) GFU Radio modem i) Mini Prism spike j) GEB221 Battery k) GRZ101 Mini prism and
GAD103 Adapter l) GMP101 Mini prism m) RH1200 RadioHandle n) Instrument carry handle o) GAT15 Antenna
22
Container for
System 1200 components part 2 of 2
a b c d e f g
SYS12_002 h i j k l a) Manuals b) GHT57 Bracket c) CompactFlash card d) GRZ4 / GRZ122 Prism e) Spare stylus f) Software DVD g) GEB211 Batteries h) GHT56 Holder i) TNC L-adapter j) GEB221 Battery k) RX Controller l) GHT39 Holding plate
Description of the System
RX1200
23
Description of the System
Container for
SmartRover components part 1 of 2
a b c d e f g
RX12_042a
RX1200
Leica G
PS900
Leica G
PS900 j i h k l m n o a) GEB211 Batteries b) GEB221 Battery c) Cables d) ATX SmartAntenna e) GEB171 Battery f) TNC L-adapter g) GHT56 Holder h) Spare stylus i) GHT52 Clamp j) Radio antennas k) Software DVD l) Radio housing m) GAD31 Adapter n) CompactFlash card o) GHT57 Bracket
24
Container for
SmartRover components part 2 of 2
a b c d e
RX12_042
Description of the System
RX1200 f g j i h a) GHT39 Holding plate b) Grip for pole c) Carrier d) Manuals e) RX Controller f) GAD33 Arm 15cm g) Height hook h) GEB221 Battery i) Tribrach j) Allen key
25
Description of the System
1.4
RX Components
Upperside of RX
RX12_017
RX1200
26
a b c d e a) For RX1250T/RX1250Tc: Radio antenna b) Screen c) Keyboard d) Hand strap bottom clips e) LEMO port: for RX1250 including USB port
Underside of RX
a b c d e
RX12_002 f g h
Description of the System
RX1200 a) Bottom spring clip for pole holder b) Top clips for pole holder c) Hand strap top clips d) Stylus e) Hand strap bottom clips f) LEMO port
For RX1250 including USB port g) Battery compartment
For RX1250 with CompactFlash card compartment h) Clip-on-contacts
For RX1250, a Bluetooth port is included inside to facilitate connectivity to the
SmartAntenna, digital cellular phone or
Leica Disto
TM
.
27
User Interface
2
2.1
User Interface
Keyboard
Keyboard display
RX1200
26
ESC
OFF
PROG
ON
Q
W
F1 F3 F5
P
E R T Y U I O
A S D F G H J K L
CAPS
Z X C V B N M
SPACE
F7 F8
SHIFT
PgUp
7 8 9
4 5 6
PgDn
1 2 3
0 .
CE ESC
USER PROG
OFF ON
RX12_001 a b c d e f g h i j a) Function keys F1-F6 b) Alpha keys c) CAPS d) Hot keys F7-F12 e) SPACE, SHIFT f) ENTER g) Arrow keys h) CE, ESC, USER, PROG i) Numeric keys j) For all RX1250 models:
Windows key symbol. It is the Microsoft flag logo located between PROG and ESC.
)
Keys
User Interface
For the purpose of the illustration, a RX1250 model has been selected which is representative for all models. Differences to other RX models are outlined.
Key
Function keys
F1-F6
Hot keys
F7-F12
Alpha keys
Numeric keys
CAPS
CE
ESC
Function
Correspond to six softkeys that appear on the bottom of the screen when the screen is activated.
User definable keys to execute chosen commands or access chosen screens.
To type letters.
To type numbers.
Switches between upper case and lower case letters.
Clears all entry at the beginning of user input.
Clears the last character during user input.
Leaves the current screen without storing any changes.
In SmartWorx mode and in the Main Menu:
Turns RX off when held for 2 s.
In Terminal mode:
Turns RX off when held for 2 s
RX1200
27
User Interface
Key
PROG (ON)
SHIFT
SPACE
USER
Arrow keys
ENTER
RX1200
28
Function
If RX is already off: Turns RX on.
If RX is already on: Accesses the Programs menu.
Switches between the first and second level of function keys.
Enters a blank.
In SmartWorx mode:
Calls the user defined menu.
In Terminal mode:
Hold down for 2 s to open the Main Configuration Menu.
Move the focus on the screen.
Selects the highlighted line and leads to the next logical menu / dialog.
Starts the edit mode for edit fields.
Opens a choicelist.
Key combinations
Key Function
PROG plus USER In SmartWorx mode and in the Main Menu:
Turns RX off when pressed simultaneously.
In Terminal mode:
Turns RX off when pressed simultaneously.
SHIFT PROG ( ) For all RX1250 models:
Displays the Windows desktop, task bar and start menu.
USER STAT (F3) Opens the Status Menu.
User Interface
RX1200
29
User Interface
2.2
Screen
Screen
a b c d
Elements
e
S_RX12_001
Type
Time
Caption
Title
RX1200 k f h i j g a) Time b) Caption c) Title d) Screen area e) Message line f) Icons g) ESC h) CAPS i) SHIFT icon j) Quick coding icon k) Softkeys
Description
The current local time is shown.
Shows location either in Main Menu, under PROG key or
USER key.
Name of the screen is shown.
30
User Interface
Type
Screen area
Message line
Icons
Description
The working area of the screen.
Messages are shown for 10 s.
ESC
CAPS
SHIFT icon
Shows current status information of the instrument. Can be used with touch screen to access the subsequent screen.
Can be used with touch screen. Same functionality as the ESC fixed key. The last operation will be undone.
The caps mode for upper case letters is active.The caps mode is activated and deactivated by pressing UPPER (F5) or
LOWER (F5) in some screens.
Shows the status of the SHIFT key; either first or second level of softkeys is selected. Can be used with touch screen and has the same functionality as the fixed key SHIFT.
Quick coding icon Shows the quick coding configuration. Can be used with touch screen to turn quick coding on and off.
Softkeys Commands can be executed using F1 - F6 keys. The commands assigned to the softkeys are screen dependent.
Can be used directly with touch screen.
RX1200
31
User Interface
2.3
Operating Principles
Keyboard and touch screen
RX1200
32
The user interface is operated either by the keyboard or by the touch screen with supplied stylus. The workflow is the same for keyboard and touch screen entry, the only difference lies in the way information is selected and entered.
Operation by keyboard
Information is selected and entered using the keys. Refer to "2.1 Keyboard" for a
detailed description of the keys on the keyboard and their function.
Operation by touch screen
Information is selected and entered on the screen using the supplied stylus.
Operation
To select an item
To start the edit mode in input fields
To highlight an item or parts of it for editing
Description
Tap on the item.
Tap on the input field.
Drag the supplied stylus from the left to the right.
To accept data entered into an input field and exit the edit mode
Tap on the screen outside of the input field.
2.4
Description
Icons
Battery icons
For a complete listing of icons
• for GPS1200+ refer to GPS1200+ System Field Manual.
• for TPS1200+ refer to TPS1200+ System Field Manual.
• for TPS1200 refer to TPS1200 System Field Manual.
The power status (indicated by six levels) and source of the battery is displayed.
Tapping the icon leads to STATUS Battery & Memory, Battery.
Icon Description
Internal battery is in use
External battery attached and in use
For TPS1200+/TPS1200 instruments: Internal TPS and RX battery are in use
User Interface
RX1200
33
User Interface
Icon
RX1200
34
Description
For TPS1200+/TPS1200 instruments: External TPS and RX battery are in use
Bluetooth icons
The status of each Bluetooth port and any Bluetooth connection is displayed.
Tapping the icon leads to STATUS Bluetooth.
Icon Description
All RX1250 models are integrated with Bluetooth
A Bluetooth connection is established and active
Bluetooth connection not established. Bluetooth port 1,2,3 are down
Bluetooth connection established. Bluetooth port 1,2,3 are active
Full Switch icon in
GPS instrument mode
The following icon appears only in the Main Menu.
Icon Description
Tapping the icon leads to Instrument Mode Selection, which allows a full switch from GPS instrument mode to TPS instrument mode.
Refer to "4.4 Switching Between GPS and TPS" for further details.
Full Switch icon in
TPS instrument mode
The following icon appears only in the Main Menu.
Icon Description
Tapping the icon leads to Instrument Mode Selection, which allows a full switch from TPS instrument mode to GPS instrument mode.
Refer to "4.4 Switching Between GPS and TPS" for further details.
Quick Switch icons in TPS instrument mode
The following icons appear only in the Survey program.
Refer to "4.4 Switching Between GPS and TPS" for further details.
Icon Description
Tapping the icon leads to GPS Survey. The icon displays the current status of the
GPS position and is represented by the following:
User Interface
RX1200
35
User Interface
Icon
RX1200
Description
No connection to the SmartAntenna
Active connection to the SmartAntenna - navigated solution
Active connection to the SmartAntenna - code solution
36
Active connection to the SmartAntenna - fixed solution
Tapping the icon leads to TPS Survey. The icon displays the current status of the instrument connection and is represented by the following:
No connection to the instrument
Active connection to the instrument
Active connection to the instrument - Searching for prism
Icon Description
Active connection to the instrument - Locked onto prism
Interface icons in
TPS instrument mode
Tapping the icon leads to Configure Interfaces. The icon displays the current status of the radio connection to the instrument and is represented by the following:
Icon Description
No radio connection to the instrument
Active radio connection to the instrument
User Interface
RX1200
37
Setting up the Equipment
3
3.1
3.1.1
RX1200
Setting up the Equipment
Equipment Setup
Fixing the RX to a Holder and Pole
38
Components of the
GHT39 holder
The GHT39 holder consists of a number of components, as shown in the diagram.
d a b c e f a) Plastic sleeve b) Pole clamp c) Clamp bolt d) Tightening screw e) Mounting plate f) Mounting arm
RX12_005
Components of the
GHT56 holder
The GHT56 holder consists of a number of components, as shown in the diagram.
a b c
RX12_016 k j i d e f g h
GHT52 clamp
a) Plastic sleeve b) Pole clamp c) Clamp bolt
GHT56 holder
d) Tightening screw e) Mounting arm f) Clip-on-contacts for connecting RX1250 g) LED h) Mounting plate i) Battery compartment j) Locking mechanism for battery k) Space for clip-on-housing with LEMO port
Fixing the RX and
GHT39 holder to a pole step-by-step
Description
1. Remove holder from the travel container.
2. A plastic sleeve may be required to be fitted to the pole clamp.
Setting up the Equipment
RX1200
39
Setting up the Equipment
RX1200
Description
3. Insert pole into the clamp hole.
4. Adjust the angle of the mounting plate and the height of the holder on the pole to comfort.
5. Tighten the clamp with the tightening screw.
)
Once tightened, the button on the tightening screw can be
) depressed to change the position of the handle for more comfort.
A locking mechanism is incorporated in the mounting plate of the holder.
6. Before RX is placed onto the mounting plate ensure that the locking pin is put into the unlocked position. To unlock the locking pin, push down the red button situated on top of the mounting plate.
40
RX12_015
7. Hold RXabove the holder and lower the end into the holder.
Description
8. Apply slight pressure in a downward direction and then lower the top part of RX until the unit is clicked into the holder. The guides of the holder aid in this action.
RX12_006
9. After RX is placed onto the mounting plate ensure that the locking pin is put into the locked position. To lock the locking pin, push up the red button from below.
Setting up the Equipment
RX12_014
RX1200
41
Setting up the Equipment
Detaching the RX from a pole stepby-step
RX1200
42
Description
1. Unlock the locking pin by pushing down the red button situated on top of the mounting plate.
2. Place the palm over the top of RX until the fingers grip the bar of the holder under the top of RX.
3. Compress the top of RX toward the bar of the holder.
4. While in this position, raise the top of RX where the palm is gripping the unit up from the holder.
1
2
RX12_007
3.1.2
Fixing the RX to a Handstrap
Fixing the RX to a
Handstrap step-bystep
Description
1. Hold the main hook rotated to approximately the 11 o'clock position in relation to RX.
2. Lower the main hook onto the pivot knob in the middle of RX.
3. Rotate the main hook to the 12 o'clock position. A click should be felt when the clip is secure.
4. Take the other end of the handstrap and clip it to the base of RX.
3
RX12_003
2
1
Setting up the Equipment
RX1200
43
Setting up the Equipment
3.1.3
RX1200
Fixing the RX to a GNSS Receiver
Fixing the RX to
GNSS receiver step-by-step
Description
1. Hold RX above the recess in the housing of the GNSS receiver intended for the unit.
2. Lower the bottom part of RX into the recess in the housing of the GNSS receiver.
3. Apply slight pressure in a downward direction and then lower the top part of RX until the unit is clicked into the GNSS receiver.
The recess in the housing of the GNSS receiver helps to guide RX.
RX12_008
1
2
44
Detaching the RX from GNSS receiver step-bystep
Description
1. Place the palm over the top of RX.
2. Compress RX downward toward the ports of the GNSS receiver.
3. While in this position, raise the top of RX from the GNSS receiver.
RX12_009
Setting up the Equipment
RX1200
45
Setting up the Equipment
3.1.4
RX1200
Setting up for Remote Control (with the RadioHandle)
TPS1200+/TPS1200
/RX1200 setup for
RCS with Radio-
Handle
a e f g b c d
RX12_041 h
46
a) 360° prism b) Prism pole c) RX1250T/RX1250Tc d) RX holder and pole clamp e) RH1200 RadioHandle f) Communication side cover g) TPS1200+/TPS1200 instrument h) Tripod
Refer to TPS1200+/TPS1200 User
Manual for further details on the
RadioHandle.
3.1.5
Setting up for Remote Control (with the TCPS27)
TPS1200+/TPS1200
/RX1200 setup for
RCS with TCPS27
a e b c d
RX12_011 i h f g a) 360° prism b) Prism pole c) RX1250T/RX1250Tc d) RX holder and pole clamp e) TPS1200+/TPS1200 instrument f) Tripod g) TCPS27B h) External battery i) Y-cable
Setting up the Equipment
RX1200
47
Setting up the Equipment
Mount base radio to tripod step-by-step
RX1200
Description
1. The GHT43 tripod adapter is used to mount TCPS27B to all Leica standard tripods, in order to optimise the radio transmission performance.
Attach TCPS27B to the adapter and then attach to the tripod leg.
2. Adjust the angle of TCPS27B until it is approximately vertical.
4.
3. Adjust the location of the adapter on the tripod leg so that there are no metallic objects in the horizontal plane around the antenna.
)
Metallic objects near the antenna disturb radio transmissions.
To achieve the best performance from
TCPS27B, it should be mounted in a vertical position on the tripod leg approximately 30 cm from the top of the tripod.
)
If the adapter is no longer able to retain it’s angle position, the adjustment bolt at the hinge can be slightly tightened.
~ 30 cm
RX12_010
48
3.1.6
Setting up SmartPole
SmartPole setup
a b c g i h j f d e
RX12_035
Setting up the Equipment
RX1200 a) SmartAntenna b) Battery for SmartAntenna c) GRZ122 360° prism d) GLS12 (cm)/GLS12F (ft) pole with snap-lock positions e) RX1250T/RX1250Tc f) RX holder and pole clamp g) RH1200 RadioHandle h) Communication side cover i) TPS1200+/TPS1200 instrument j) Tripod
49
Setting up the Equipment
Understanding the reflector/antenna heights with the
GLS12/GLS12F pole
RX1200
50
The GLS12 (cm)/GLS12F (ft) telescopic pole has fixed equally spaced snap-lock positions. The scale readings along the pole relate to the height of the reflector
(prism centre). Two additional positions, clearly marked with diagrams on the pole, relate to the SmartAntenna. The snap-lock must always click into position.
Snap-lock positions Diagram on pole
1. Use only these snap-lock positions for measurements with:
GRZ4 360° prism or GRZ122 360° prism or circular prism
Reflector Height (prism centre) = height reading on pole
2. Use only this snap-lock position for measurements with:
SmartAntenna and the GRZ122 360° prism
Antenna Height (MRP) = 2.0 m/6.562 ft
Reflector Height (prism centre) = 1.941 m/6.368 ft
The height difference between:
SmartAntenna(MRP) - Reflector(prism centre) = 5.90 cm/0.194 ft
3. Use only this snap-lock position for measurements with:
SmartAntenna and the GAD31 screw to stub adapter
Antenna Height (MRP) = 2.0 m/6.562 ft
3.1.7
Description
Setting up a Real-Time Reference
Two setups for RX1250 are given as example. Refer to GPS1200+ Technical Reference Manual for information on additional setups.
SmartAntenna/
RX1250X setup for real-time reference
f g i h a b c d e
RX12 28 j l k m n o a) SmartAntenna b) Battery for SmartAntenna c) Height hook d) Carrier e) Tribrach f) Tripod g) GHT57 h) GHT56 i) Radio housing j) Transport container k) RX1250X l) Radio antenna m) Battery for RX1250X n) CompactFlash card o) Battery for GHT56
Setting up the Equipment
RX1200
51
Setting up the Equipment
3.1.8
Setting up SmartRover
SmartRover setup with external radio
a b c
RX1200 d e f g
RX12 31
52
l j i h k a) SmartAntenna b) Battery for SmartAntenna c) Upper half aluminium pole with screw or stub d) Grip for pole e) GHT56 f) Radio in housing g) Lower half aluminium pole h) Radio antenna i) Battery for RX1250X j) CompactFlash card k) RX1250X l) Battery for GHT56
Increase radio coverage on Smart-
Rover
Description
Some applications require the maximum radio coverage. In those cases the radio antenna is mounted on an antenna arm which is fixed to the pole just below the
SmartAntenna. Connection is made between the radio housing and the radio antenna.
Connect radio antenna and radio housing using cable step-by-step
Description
1. Clip the antenna arm to the SmartAntenna.
2. Screw the radio antenna onto the antenna arm.
3. Attach the radio in its housing to GHT56.
4. Place the battery into the battery compartment of the GHT56.
5. Attach GHT56 to the pole and tighten the screw.
6. Connect the radio antenna to the radio housing using the 1.2 m antenna cable.
Setting up the Equipment
RX1200
53
Setting up the Equipment
3.2
3.2.1
Batteries
Operating Principles
)
)
RX1200
This chapter is valid for all RX1250 models and GHT56.
54
Primary use/charging
• The battery must be charged prior to using it for the first time because it is delivered with an energy content as low as possible.
• For new batteries or batteries that have been stored for a long time (> three months), it is effectual to make only one charge/discharge cycle.
• For Li-Ion batteries, a single discharging and charging cycle is sufficient. We recommend carrying out the process when the battery capacity indicated on the charger or on a Leica Geosystems product deviates significantly from the actual battery capacity available.
• The permissible temperature range for charging is between 0°C to +40°C/ +32°F to +104°F. For optimal charging we recommend charging the batteries at a low ambient temperature of +10°C to +20°C/+50°F to +68°F if possible.
• It is normal for the battery to become warm during charging. Using the chargers recommended by Leica Geosystems, it is not possible to charge the battery if the temperature is too high.
Operation/Discharging
• The batteries can be operated from -20°C to +55°C/-4°F to +131°F.
• Low operating temperatures reduce the capacity that can be drawn; very high operating temperatures reduce the service life of the battery.
Setting up the Equipment
RX1200
55
Setting up the Equipment
3.2.2
RX1200
Battery for all RX1250 models
Change battery step-by-step
2
56
5
4
6
3 f
RX12_018
Description
1. Turn RX over to gain access to the battery compartment.
2. Push the slide fastener in the direction of the arrow with the open-lock symbol.
3. Open the battery compartment.
Description
4. Pull the battery from the battery compartment.
5. A pictogram of the battery is displayed inside the battery compartment. This is a visual aid to assist in placing the battery correctly.
6. Place the battery into the battery compartment with the Leica logo facing to the left.
7. Close the battery compartment by pushing the slide fastener in the direction of the arrow with the close-lock symbol.
Setting up the Equipment
RX1200
57
Setting up the Equipment
3.2.3
Battery for SmartAntenna
RX1200
Change battery step-by-step
1
2
3
4
TPS12_193
1.
Description
)
Turn SmartAntenna over to gain access to the battery compartment.
Open the battery compartment by pushing the slide fastener in the direction of the arrow with the open-lock symbol.
2. Pull out the battery housing. The battery is attached to the housing.
3. Hold the battery housing and pull the battery from the battery housing.
58
Description
4. A polarity of the battery is displayed inside the battery housing. This is a visual aid to assist in placing the battery correctly.
5. Place the battery onto the battery housing, ensuring that the contacts are facing outward. Click the battery into position.
6. Close the battery compartment by pushing the slide fastener in the direction of the arrow with the close-lock symbol.
Setting up the Equipment
RX1200
59
Setting up the Equipment
3.2.4
Battery for GHT56
Change battery step-by-step
RX1200
3
2
5
6
6
2 f
RX12_022
Description
1. Turn GHT56 over to gain access to the battery compartment.
2. Press simultaneously on the right side of the locking mechanism and the left side of the battery.
)
This unlocks the battery from its locked position.
3. Pull the battery from the battery compartment.
4. Place the battery into the battery compartment.
)
Ensure that the battery is placed adjacent to the locking mechanisam with the contacts facing down.
60
Description
5. Press simultaneously on the right side of the locking mechanism and the right side of the battery.
)
This locks the battery into position.
)
GEB211 and GEB221 can both be used with GHT56. The battery powers a device in a clip-on-housing attached to the GHT56.
Setting up the Equipment
RX1200
61
Setting up the Equipment
3.3
RX1200
Working with the CompactFlash Card
)
)
This chapter is only valid for all RX1250 models.
• Keep the card dry.
• Use it only within the specified temperature range.
• Do not bend the card.
• Protect the card from direct impacts.
)
Failure to follow these instructions could result in data loss and/or permanent damage to the card.
62
Insert and remove a CompactFlash card step-by-step
2
4
3
11
10
RX12_019
Description
1. The CompactFlash card is inserted into a slot inside the battery compartment.
Turn RX over to gain access to the battery compartment.
2. Push the slide fastener in the direction of the arrow with the open-lock symbol.
3. Open the battery compartment.
Setting up the Equipment
RX1200
63
Setting up the Equipment
RX1200
Description
4. Pull the battery from the battery compartment.
5.
)
The card should be held with the label for the care instructions upwards and the contacts facing the slot.
Slide the card firmly into the slot until it clicks into position.
6. Place the battery into the battery compartment.
7. Close the compartment cover.
8. To remove the card, open the cover of the battery compartment.
9. Pull the battery from the battery compartment.
10. Press the eject button on the right side of the card slot twice.
11. Pull out the CompactFlash card.
12. Close the compartment cover.
64
Format a Compact-
Flash card step-bystep
Formatting the CompactFlash card before logging data is started is required if a completely new CompactFlash card is used or if all existing data needs to be deleted.
Setting up the Equipment
Description
1. Select Main Menu: Tools...\Format Memory Device.
2. TOOLS Format Memory Device
<Memory Device: CF Card>
<Format Method: Format Quick>
Select the memory device to be formatted.
)
By activating the format command all data will be lost. Make sure that all important data on the CompactFlash card has been backed up before formatting the card. Before formatting the internal memory
) make sure that all important data is first transferred to the PC.
To exit the screen without formatting the memory device, press
ESC. This returns to the previous screen.
3. CONT (F1)
4. YES (F4) to continue with the formatting of the selected device.
)
NO (F6) to not continue with the formatting of the selected device and to return to TOOLS Format Memory Device.
RX1200
65
Setting up the Equipment
3.4
RX1200
LED Indicators on SmartAntenna
LED indicators
66
Description
SmartAntenna has Light Emitting Diode indicators. They indicate the basic antenna status.
Diagram
TRK
BT
PWR
TRK BT PWR
ON
OFF
GPS12_153
TRK
BT
Tracking LED
Bluetooth LED
PWR Power LED
Description of the LED’s
IF the
TRK
BT
PWR
is
off flashing green less than four satellites are tracked, a position is not yet available.
green red
THEN
no satellites are tracked.
enough satellites are tracked to compute a position.
SmartAntenna is initialising.
green purple blue flashing blue
Bluetooth is in data mode and ready for connecting.
Bluetooth is connecting.
Bluetooth has connected.
data is being transferred off green power is off.
power is okay.
flashing green power is low. The remaining time for which enough power is available depends on the type of survey, the temperature and the age of the battery.
red power is very low. The battery should be changed.
Setting up the Equipment
RX1200
67
Setting up the Equipment
3.5
LED Indicators on GHT56
RX1200
LED indicator
68
Description
GHT56 has one Light Emitting Diode indicator. It indicates the basic power status.
Diagram
a
RX12_021 a) Power LED
Description of the LED
IF the
PWR
is
off green flashing green red
THEN
power is off.
power is okay.
power is low. The remaining time for which enough power is available depends on the type of survey, the temperature and the age of the battery.
power is very low. The battery should be changed.
Setting up the Equipment
RX1200
69
Setting up the Equipment
3.6
RX1200
Working with the Clip-On-Housings for Devices on GHT56
Devices fitting into a clip-on-housing
Digital cellular phones for GPS RTK fitting into a clip-on-housing
Digital cellular phone
Siemens MC75
CDMA MultiTech MTMMC-C (US)
CDMA MultiTech MTMMC-C (CAN)
Clip-on-housing
GFU24
GFU19, GFU26
GFU25
Radios for GPS RTK fitting into a clip-on-housing
Radio
Pacific Crest PDL, receive
Satelline 3AS, transceive
Clip-on-housing
GFU15
GFU14
Radios for Remote Control fitting into a clip-on-housing
Radio
spread spectrum transceiver
Clip-on-housing
GFU23
70
Attach a clip-onhousing step-bystep
The clip-on-housing for devices fits to the underside of the GHT56.
RX12_020
1.
Description
)
A circular screw is located at one end of the clip-on-housing. Ensure that the circular screw is in the unlocked position. Turn it anticlockwise, as shown by the lock and arrow symbols on the screw.
Setting up the Equipment
RX1200
71
Setting up the Equipment
RX1200
Description
Turn GHT56 over to gain access to the space for the clip-on-housing.
2. Place the clip-on-housing into position such that
• the guide rails on the GHT56 are aligned with the guide rails on the clipon-housing.
AND
• the LEMO port on the GHT56 is aligned with the connector on the clip-onhousing.
3. Slide the clip-on-housing into position such that the connector is completely plugged into the LEMO port. It clicks.
)
Do not turn the screw on the topside of the clip-on-housing. The clipon-housing is automatically fixed when completely plugged into position.
72
Detach a clip-onhousing step-bystep
Description
1. Press the small press clip next to the guide rail on the GHT56 to unlock the clip-on-housing from the GHT56.
2. Slide the clip-on-housing away from the press clip until the connector is completely unplugged from the LEMO port.
Description
3. Pull the clip-on-housing from the GHT56.
Insert a SIM card step-by-step
For those digital cellular phones that require SIM cards.
Description
1. Take the SIM card, a coin and a pen.
2. Locate the SIM card screw, that covers the SIM card slot, on the bottom of the clip-on-housing.
3. Insert the coin into the groove of the SIM card screw.
4. Turn the coin anticlockwise to loosen the SIM card screw.
5. Remove the SIM card screw from the housing.
6. Using the pen, press the small button of the SIM card slot to eject the SIM card holder.
7. Take the SIM card holder out off the housing.
8. Put the SIM card into the SIM card holder, the chip facing up.
9. Insert the SIM card holder into the SIM card slot, the chip facing the connectors inside the slot.
Setting up the Equipment
RX1200
73
Setting up the Equipment
RX1200
Description
10. Place the SIM card screw back on the housing.
11. Insert the coin into the groove of the SIM card screw.
12. Turn the coin clockwise to tighten the SIM card screw.
74
Remove a SIM card step-by-step
For those digital cellular phones that require SIM cards.
7
6
5
4
GPS12_088
Description
1. Take a coin and a pen.
2. Locate the SIM card screw, that covers the SIM card slot, on the bottom of the clip-on-housing.
3. Insert the coin into the groove of the SIM card screw.
Setting up the Equipment
RX1200
75
Setting up the Equipment
RX1200
76
Description
4. Turn the coin anticlockwise to loosen the SIM card screw.
5. Remove the SIM card screw from the housing.
6. Using the pen, press the small button of the SIM card slot to eject the SIM card holder.
7. Take the SIM card holder out off the SIM card slot.
8. Take the SIM card out of the SIM card holder.
9. Put the SIM card holder back into the SIM card slot, the even side not facing the contacts inside the slot.
10. Place the SIM card screw back on the housing.
11. Turn the coin clockwise to tighten the SIM card screw.
LED indicators Description
Each clip-on-housing for a radio, digital cellular phones or Bluetooth communication has Light Emitting Diode indicators on the bottom side. They indicate the basic device status.
Diagram
Setting up the Equipment
GPS12_089 c d a b a) Configuration LED b) Data Transfer LED c) Signal Strength LED d) Power LED
RX1200
77
Setting up the Equipment
RX1200
78
Description of the LED’s
IF the
Config
LED
Data transfer
LED
Signal strength
LED
on
GFU14 with
Satelline 3AS,
GFU23 any device
is
red off green or flashing green
GFU19 (US),
GFU25 (CAN),
GFU26 (US) with CDMA
MultiTech
MTMMC-C red flashing red off
GFU23 off red
THEN
the device is in the configuration mode controlled from the PC via cable.
data is not being transferred.
data is being transferred.
device is on, not registered on the network.
device is on, registered on the network.
download mode or device is off.
no radio link to remote controller.
radio link to remote controller.
IF the on is THEN
GFU24 with
Siemens MC75 red red: long flash, long break call is in progress.
no SIM card inserted, no PIN entered or network search, user authentication or network login in progress.
GFU15 with
Pacific Crest
PDL red: short flash, long break red: flashing red, long break red: long flash, short break off logged onto network, no call in progress.
GPRS PDP context activated.
Packet switched data transfer is in progress.
device is off.
red or flashing red the communication link, Data
Carrier Detection, is okay on the roving receiver.
off the DCD is not okay.
Setting up the Equipment
RX1200
79
Setting up the Equipment
IF the
Power
LED
on
GFU14 with
Satelline 3AS any device
RX1200
is
80
red or flashing red the communication link, Data
Carrier Detection, is okay on the off off green
THEN
roving receiver.
the DCD is not okay.
power is off.
power is okay.
3.7
Guidelines for Correct Results with GNSS Surveys
Undisturbed satellite signal reception
Successful GNSS surveys require undisturbed satellite signal reception, especially at the receiver which serves as a reference. Set up the receivers in locations which are free of obstructions such as trees, buildings or mountains.
Steady antenna for static surveys
For static surveys, the antenna must be kept perfectly steady throughout the whole occupation of a point. Put the antenna on a tripod or pillar.
Centred and levelled antenna
Centre and level the antenna precisely over the marker.
Setting up the Equipment
RX1200
81
Getting Started with SmartWorx
4
4.1
RX1200
Getting Started with SmartWorx
Overview
82
Choosing the correct program on the Windows CE
Desktop
Data Storage
Store data on CF Card in GPS/TPS instrument
Store data on CF Card in RX controller
TPS1200+/
TPS1200
9 9
Instrument
GPS1200+
GX Receiver
GPS1200+
SmartRover
TPS1200+/
TPS1200
9 9
Program
To use the RX as a terminal
To use the RX as a data logger
4.2
Turning on the RX, setting the Instrument Mode and Interface
Turning the RX on step-by-step
Description
1. Ensure that the RX has a power supply.
Press PROG (ON) on the keyboard.
For RX1210/RX1210T, the RX will automatically turn on if it is connected via cable or via clip-on connector to GPS/TPS which is already on.
2. For all RX1250 models, the Windows desktop is the default display after starting up.
To use the RX as a terminal:
Double click on the Terminal icon.
To use the RX as a data logger:
Double click on the SmartWorx icon.
Getting Started with SmartWorx
RX1200
83
Getting Started with SmartWorx
RX1200
Description
3. For SmartWorx, the Instrument Mode
Selection screen is displayed by default.
To connect the RX to GPS, select Choose
Sensor=GPS.
To show this screen the next time the RX is turned on, select Show at Startup=Yes.
For SmartWorx, the Instrument Mode
Selection screen is displayed by default.
To connect the RX to TPS, select Choose
Sensor=TPS.
To show this screen the next time the RX is turned on, select Show at Startup=Yes.
4. Configuring the interface.
For GPS, press CONF (F2) to go to the
Configure SmartAntenna Interface screen.
For TPS, press CONF (F2) to go to the
Configure Instrument Interface screen.
84
Description
Setting the SmartAntenna Interface.
Turn on the SmartAntenna.
Set Use Device=Yes.
Select a free Bluetooth port.
Press DEVCE (F5) to open a list of devices.
Select the SmartAntenna.
Press SRCH (F4) to search and establish a data connection to the SmartAntenna.
Setting the Instrument Interface.
For RX1250T/RX1250Tc:
Set the instrument interface to:
Port=Internal Radio, Device=Int. Radio.
For TPS with RadioHandle:
Set the GeoCom interface to:
Port=Port 2(Handle), Device=RH1200.
5. Press CONT (F1) to go to the Main Menu.
Getting Started with SmartWorx
RX1200
85
Getting Started with SmartWorx
)
RX1200
86
Setting the interface between the RX and the connecting device can always be set later. From the Main Menu select Config/ Interfaces.
Turning the RX off
Option
Turning the RX off
Description
The RX can only be turned off in the Main Menu screen or in the Windows CE desktop.
Press USER and PROG simultaneously, or
Press and hold ESC for 2 s.
Unplugging the RX or unclipping the RX from the GPS/TPS
Disconnecting either the LEMO cable or the clip-on connector of the RX without an internal battery automatically switches it off.
Auto power down Option to set shutdown and sleep events after user defined duration of instrument inactivity when working with TPS.
4.3
Understanding the Main Menu
The Main Menu
Description
1. By default, the Main Menu is the first screen shown after starting up from the Windows desktop.
To set another screen for the start up:
Select Config from the Main Menu,
Select General Settings,
Select Start Up,
Select the Start Up page,
2. Select a start screen from the choicelist,
Press CONT (F1) to go to the Main Menu.
Main Menu icons
Refer to "2.4 Icons" for a list and description of all available icons in the Main Menu.
Getting Started with SmartWorx
RX1200
87
Getting Started with SmartWorx
Main Menu keys
RX1200
88
Description
To select the highlighted menu function and continue
CONT (F1)
To select another sensor - switching between GPS and TPS SHIFT MODE (F2)
To put the RX into sleep mode. In sleep mode, the RX shuts down and reduces power. The sleep mode is designed to preserve energy. Rebooting the RX from sleep mode is quicker than a cold start after turning off.
SHIFT SLEEP (F3)
To minimise SmartWorx and to display the Windows desktop SHIFT MINIM (F5)
To quit and close SmartWorx
SHIFT EXIT (F6)
For all RX1250 models:
To display the Windows desktop, task bar and start menu.
SHIFT PROG
4.4
Switching Between GPS and TPS
Full switching step-by-step
To switch from GPS instrument mode to TPS instrument mode:
1. Option 1: Click on the TPS icon , or
Option 2: Press SHIFT MODE (F2).
2. Select Choose Sensor=TPS. Press CONT
(F1) to go to the TPS1200+/TPS1200 Main
Menu.
To switch from TPS instrument mode to GPS instrument mode:
1. Option 1: Click on the GPS icon , or
Option 2: Press SHIFT MODE (F2).
2. Select Choose Sensor=GPS. Press CONT
(F1) to go to the GPS1200+ Main Menu.
Full switching is available only in the Main Menu screen.
Full switching does not require a licence.
Getting Started with SmartWorx
RX1200
89
Getting Started with SmartWorx
Switching in survey step-bystep
RX1200
To switch between TPS Survey and GPS Survey during Survey:
1. From TPS Survey:
Option 1: Click on the GPS icon, or
90
Option 2: Configure and assign a hot key:
Select Config from the Main Menu,
Select General Settings,
Select Hot Keys & User Menu
2. From GPS Survey:
Option 1: Click on the TPS icon, or
Option 2: Press the configured hot key.
The display masks are user configured:
Select Config from the Main Menu,
Select Survey Settings,
Select Display Settings.
Switching in Survey is available only in TPS mode.
Switching in setup step-by-step
To switch to GPS Survey during Setup:
1. Select the setup method.
2. Press GPS (F4) to access GPS Survey.
3. The measured GPS point is stored to the
Fixpoint Job. This point can be used as a control point in TPS Setup. The display masks are user configured.
Switching in Setup (for SmartPole) is available only in TPS mode.
Getting Started with SmartWorx
RX1200
91
Getting Started with SmartWorx
4.5
RX1200
Working with Licence Keys
92
Remote Licensing
It is possible to temporarily transfer a program licence from TPS1200+/TPS1200 onto any of the RX1250 models. This procedure would only make sense when the
RX is to be used as a data logger.
Available programs
RX1210/RX1210T
For these models, only the RX firmware file is loaded. All programs are loaded onto
the GPS/TPS. Refer to "1.2.1 Software Concept" for further details.
Available programs all RX1250 models
For these models, a one program/one licence concept has been established. That is, it is only necessary to load one file for each program and to activate one licence.
The program can be loaded in either GPS mode or TPS mode. Once loaded, the program is available to both GPS and TPS (except TPS specific programs). A program can also be removed from either GPS or TPS mode.
Licence Key Available programs
Alignment Tool Kit
Cogo
Determine Coordinate System
DXF Export
LandXML Export
9
9
9
Available programs
DXF Import
Hidden Point (for TPS only)
RoadRunner
Reference Line
Reference Plane
Stakeout
Volume Calculations
Sets of Angles (for TPS only)
Survey Cross Section
Traverse (for TPS only)
Protected options
Protected option
licence - SmartPole licence - GPS Survey Functionality option - Cogo (Area Division) option - Extended OWI messages
Getting Started with SmartWorx
RX1200
Licence Key
9
9
9
9
9
9
9
9
Licence Key
9
9
9
9
93
Getting Started with SmartWorx
RX1200
Protected option
option - GLONASS permanent option option - GPS L5 option option - Galileo option
Activating a licence
Description
1. To enter a licence key or upload a licence key file:
Select Tools from the Main Menu,
Select Licence Keys from the Tools Menu.
Licence Key
9
9
9
94
Description
2. Upload Key File:
Upload the key file from the CompactFlash card. The key file must be stored in the
\SYSTEM directory on the CompactFlash card. Licence key files use the naming convention L_123456.key, where 123456 is the instrument serial number.
3. Manual Entry of Key:
Type the key in manually.
4. An optional step is to delete all licence keys. Press SHIFT DEL (F4).
5. Press CONT (F1) to go to the Main Menu.
Getting Started with SmartWorx
RX1200
95
Getting Started with SmartWorx
4.6
RX1200
Connecting to a Digital Cellular Phone
Connecting step-by-step
Description
1. Select Main Menu: Config...\Interfaces... in the Leica SmartWorx software.
2. Highlight Real-Time.
3. EDIT (F3)
4. CONFIGURE Real-Time Mode
<R-Time Mode: Rover>
Select a free Bluetooth port.
5. DEVCE (F5)
6. CONFIGURE Devices, Modems/GSM page
Highlight a Bluetooth capable digital cellular phone.
7. CONT (F1)
8. SRCH (F4) to search for the digital cellular phone.
)
The digital cellular phone must be turned on and Bluetooth must be activated.
9. CONFIGURE Search Bluetooth Device
96
Description
All available Bluetooth devices are displayed.
10. Highlight the digital cellular phone to be used.
11. CONT (F1)
)
If the digital cellular phone selected is connected for the first time, the Windows CE dialog for pairing comes up. Type in 0000 as identification number for Leica’s Bluetooth and click OK.
)
Some digital cellular phones also ask for the identification number
) for Leica’s Bluetooth. The number is 0000.
Some digital cellular phones also ask for an acknowledgement before connecting to another Bluetooth device.
Getting Started with SmartWorx
RX1200
97
Getting Started with SmartWorx
4.7
Connecting to the Disto
RX1200
Connecting step-by-step
Description
1. Turn on the Disto. Press the Bluetooth key to activate Bluetooth. The Bluetooth icon will display on the Disto screen and will continue to blink until there is a successful data connection to the RX. Bluetooth will switch off on the Disto if the connection is not established within 240 sec.
2. Ensure that the RX is in GPS mode. Go to the Survey program and to the Survey
Begin screen. Enter the appropriate information and press CONT (F1) to continue to the Survey screen. Ensure that the Survey page is active. Press H PNT (F5) to continue to the Hidden Point Measurement screen.
98
Description
3. Press SHIFT CONF (F2) to enter the
Configuration screen.
4. Set <Use Device: Yes>. Select a free
Bluetooth port. Press DEVCE (F5) to open a list, displaying Bluetooth capable devices. From the list, highlight and select the Disto and return to the configuration screen. Press SRCH (F4) to search for
Bluetooth devices. Select the Disto device from the list of Bluetooth devices found and return to the configuration screen. Press
CONT (F1) to establish the data connection.
Getting Started with SmartWorx
RX1200
99
Getting Started with SmartWorx
RX1200
Description
5. Measure the required distance with the
Disto. For Disto A4/A5, press and activate the 2nd key. Then press the Bluetooth key to send the measurement to the RX. For
Disto A6 it is sufficient to press the Blue-
tooth key. The distance will be sent and displayed on the RX screen.
100
4.8
Connecting to a Personal Computer
ActiveSync
Microsoft ActiveSync is the synchronization software for Windows mobile-based pocket PC’s. ActiveSync enables a PC and a Windows mobile-based pocket PC, like the RX1250, to communicate.
ActiveSync is freeware. It can be downloaded from the Microsoft website.
Connect USB cable to PC for the first time step-by-step
Description
1. Start the PC.
2. Have the SmartWorx DVD version 5.0 or higher ready.
3. Plug the GEV161 cable into RX1250.
4. Turn the RX1250 on.
5. Wait until the Windows CE desktop is visible.
6. Plug the GEV161 cable into the USB port of the PC.
)
The new hardware wizard starts up automatically.
7. Tick No, not at this time.
8. Next>.
9. Tick Install from a list or specific location (Advanced).
Getting Started with SmartWorx
RX1200
101
Getting Started with SmartWorx
RX1200
102
Description
10. Next>.
11. Insert the SmartWorx DVD version 5.0 or higher.
12. Tick Search removable media (floppy, CD-ROM...).
13. Next>.
14. Confirm Hardware Installation window with Continue Anyway.
15. Finish.
16. Run the ActiveSync installation program if not already installed.
17. Allow USB connections inside the Connection Settings window of Active-
Sync.
18. Is LGO used?
If yes, continue with step 6. in paragraph "Connect to LGO via USB cable step-by-step".
Is no, continue with step 6. in paragraph "Connect to PC via USB cable stepby-step".
Connect to LGO via
USB cable step-by-step
Description
1. Start the PC.
2. Plug the GEV161 cable into RX1250.
3. Turn the RX1250 on.
4. Plug the GEV161 cable into the USB port of the PC.
)
ActiveSync starts up automatically.
If does not start automatically, start ActiveSync.
If not already installed, run the ActiveSync installation program.
5. Allow USB connections inside the Connection Settings window of Active-
Sync.
6. Start LGO or install it if not available.
7. Start the Leica SmartRover software on the RX1250.
8. Goto Data Exchange Manager in LGO.
9. Click Refresh on the ActiveSync folder.
10. Establish the communication to RX1250.
)
The folders CF-Card, System1200 and Sensor System are displayed in the Data Exchange Manager.
Getting Started with SmartWorx
RX1200
103
Getting Started with SmartWorx
Connect to PC via
USB cable step-by-step
Description
1. Start the PC.
RX1200
2. Plug the GEV161 cable into RX1250.
3. Turn the RX1250 on.
4. Plug the GEV161 cable into the USB port of the PC.
)
ActiveSync starts up automatically.
If does not start automatically, start ActiveSync.
If not already installed, run the ActiveSync installation program.
5. Allow USB connections inside the Connection Settings window of Active-
Sync.
6. Click on Explore in ActiveySync.
)
The folders on the RX1250 are displayed under Mobile Devices.
The folders of the CompactFlash can be found in StorageCard.
104
Via Bluetooth step-by-step
Description
1. Activate Bluetooth on the PC.
The steps required depend on the Bluetooth driver and other PC specific configurations. On the PC, always ensure that
• the correct COM port is defined.
• the COM port is configured as incoming, which allows Bluetooth devices to detect the PC.
2. Turn the RX1250 on.
3. Go to Start/Settings/Control Panel/Bluetooth Device.
4. Click Scan Device.
5. Highlight the service required in the Untrusted box.
6. Click - -> to move the service to the Trusted box.
7. Highlight the service required in the Trusted box.
8. Right mouse click to access the context menu.
9. Tick Active.
)
Go to Start/Settings/Control/System/Device Name to give the
RX1250 a specific name.
Getting Started with SmartWorx
RX1200
105
Getting Started with SmartWorx
RX1200
106
Description
10. Go to Start/Settings/Control Panel/PC Connection.
11. Select Bluetooth from the combo box.
12. Go to Start/Programs/Communication/ActiveSync to initialise the communication.
)
As soon as the communication is initialised on the RX1250, Active-
Sync establishes the link between the PC and RX1250.
13. Start LGO or install it if not available.
14. Goto Data Exchange Manager in LGO.
15. Click Refresh on the ActiveSync folder.
16. Establish the communication to RX1250.
)
The folders CF-Card, System1200 and Sensor System are displayed in the Data Exchange Manager.
4.9
4.9.1
Connections
Connecting to a Radio (for Remote Control Surveys)
Available Radios
Radio modem
Internal radio of RX1250T/RX1250Tc
Port
Internal Radio
GFU23 attached to any RX1250 model via GHT56 Clip-on
TCPS27 attached to any RX1250 model via cable Port 1
RadioHandle attached on top of TPS
GFU23 attached to TPS via cable
TCPS27 attached to TPS via cable
Port 2 (Handle)
Port 1
Port 1
Getting Started with SmartWorx
RX1200
107
Getting Started with SmartWorx
4.9.2
Working in Remote Mode
RX1200
Description
108
In the remote mode TPS is controlled from RX. To work in this mode TPS must be set to RCS mode. Refer to TPS1200+/TPS1200 Technical Reference Manual for more information. While in RCS mode TPS can still be controlled with the keys on the instrument.
Access step-by-step
1.
Description
)
Proceed to the local menu of RX.
Select Main Configuration Menu: Radio/Comms Settings, Modes page.
2. Set <ComMode: RCS Mode>.
)
<ComMode: RCS Mode> is set automatically when turning on RX.
4.9.3
Description
Working in Transparent Mode
<ComMode: Transparent> enables the remote control of TPS with GeoCOM commands. RX becomes a transparent radio modem, like the RadioHandle or
TCPS27B. GeoCOM commands can be sent from a computer to RX which are then sent to TPS via RadioHandle or TCPS27B. These commands will be executed on
TPS and results can be sent back.
Access step-by-step
1.
Description
)
From CONFIGURE Interfaces on TPS ensure that GeoCOM Mode is turned on and RCS Mode is turned off.
)
Proceed to the local menu of RX.
Select Main Configuration Menu: Radio/Comms Settings, Modes page.
2. Set <ComMode: Transparent>.
Getting Started with SmartWorx
RX1200
109
Getting Started with SmartWorx
4.9.4
RX1200
Working in Semi-Transparent Mode
Description
)
Access step-by-step
110
<ComMode: Semi-Transparent> enables the total remote control of TPS in RCS mode but the data being captured by TPS will be sent via radio link to the LEMO port of RX. A computer connected to this port will receive the data captured on TPS in real-time.
Data being sent over the radio link in this mode is not protected by a Leica protocol.
There exists a chance of data loss without notification.
Description
)
From CONFIGURE Interfaces on TPS ensure that GSI Output and
RCS Mode are turned on.
)
Proceed to the local menu of RX.
1. Select Main Configuration Menu: Radio/Comms Settings, Modes page.
2. Set <ComMode: Semi-Transparent>.
4.10
Connecting to the SmartAntenna
Connecting step-by-step
Description
1. Select Main Menu: Config...\Interfaces... in the Leica software.
2. Highlight SmartAntenna.
3. EDIT (F3)
4. CONFIGURE SmartAntenna Interface
<Use Device: Yes>
Select a free Bluetooth port.
5. DEVCE (F5)
6. CONFIGURE Devices
Highlight ATX1230.
7. CONT (F1)
8. SRCH (F4) to search for Bluetooth devices.
)
SmartAntenna must be turned on.
9. CONFIGURE Search Bluetooth Device
Getting Started with SmartWorx
RX1200
111
Getting Started with SmartWorx
RX1200
112
Description
All available Bluetooth devices are displayed.
10. Highlight the SmartAntenna to be used.
11. CONT (F1)
)
If the SmartAntenna selected is connected for the first time, a
Windows CE authentication request comes up. Type in 0000 as
) identification number for Leica’s Bluetooth and click OK.
Once the Bluetooth connection is established, the Bluetooth LED on the SmartAntenna starts flashing in blue.
Getting Started with SmartWorx
RX1200
113
Local Mode
5
5.1
)
Access
RX1200
Local Mode
Accessing the Main Configuration Menu
114
This menu is always available to RX1210/RX1210T.
This menu is only available to the RX1250 models when in terminal mode.
Press USER for 2 s or automatically after 10 s when no sensor can be detected.
A message is displayed for a period of 10 s.
Next step
IF the RX is to be
configured connected automatically connected to TPS connected to GPS
THEN
CONF (F2) leads directly to Main Configuration Menu.
AUTO (F3) initiates the auto detect function. RX tries to connect to any available instrument or receiver.
TPS (F4) tries to connect to any available TPS instrument.
GPS (F5) tries to connect to any available GPS receiver.
5.2
Overview of the Main Configuration Menu
Main
Configuration
Menu
Description of main menu functions
Main menu function Description
Choose Sensor
Local Settings
Select the sensor to be working with RX.
Change or adjust the display and sound settings of RX.
Radio/Comms Settings Change or adjust the communication settings of RX.
Work with Sensor
Leave the Local Mode and work with the selected sensor.
Refer to chapter
Local Mode
RX1200
115
Local Mode
5.3
Choosing a Sensor
Access step-by-step
RX1200
Description
1. Refer to "5.1 Accessing the Main Configuration Menu" to access the menu
2. Main Configuration Menu
Highlight Choose Sensor.
3. CONT (F1).
116
Choose Sensor Description of fields
Field Option
Sensor TPS1200+/
TPS1200
GPS1200+
Auto Detect
Description
Sets RX to work with TPS1200+/TPS1200. Choose this option if working only TPS1200+/TPS1200.
Sets RX to work with GPS1200+. Choose this option if working only GPS1200+.
Sets RX to try and connect with any connected instrument when starting up. This is the default setting.
5.4
Description
Local Settings
The settings on this screen allow the screen appearance to be configured, turn the notification beeps on and off and define the behaviour of the keys. The settings are stored on RX itself.
Access step-by-step
Description
1. Refer to "5.1 Accessing the Main Configuration Menu" to access the menu
2. Main Configuration Menu
Highlight Local Settings.
3. CONT (F1).
Local Settings,
Display page
Description of fields
Field Option
<Touch Screen:> On or Off
Description
Turns touch screen on and off.
<Screen Beep:>
Off, Soft or Loud Controls the beep upon touching the touch screen.
Local Mode
RX1200
117
Local Mode
Field
<Screen Illum:>
<Key Illum:>
<Contrast:>
<Heating:>
<Brightness:>
RX1200
118
Option
Off, Always On,
On for 30 s,
On for 1 min,
On for 2 min or
On for 5 min
Description
Controls the screen illumination to be on, off or on for the specified time after the last key was pressed or touch screen event.
Off, Always On, or
Same as Screen
Controls the keyboard illumination.
From
0% to 100%
For RX1210/RX1210T only.
Adjust the contrast level for the display using the arrow keys or using the stylus on the slider.
Off
Automatic
For RX1210/RX1210T only.
The screen heating never comes on.
The screen heating comes on automatically at 5°C and below and shuts off again at 7°C.
Settings from 1-5 For all RX1250 models only.
To set the screen brightness.
Local Settings,
Beeps page
Next step
IF THEN
the local settings are to be exited CONT (F1) accepts changes and returns to the screen from where this screen was accessed.
the touch screen is to be calibrated CALIB (F5) calibrates the touch screen.
the next page is to be accessed PAGE (F6) changes to another page.
Description of fields
Field
<Key Beeps:>
Option
<Warning Beeps:>
Off, Soft or
Loud
Off, Soft or
Loud
Description
Controls the beep for acoustic warning signals.
Controls the beep upon key presses on
RX.
Local Mode
RX1200
119
Local Mode
Local Settings,
More page
Description of fields
Field Option
<Language:> Choicelist
RX1200
<Action:> None
RX Off
RX+TPS Off
<After time:> From 1 to 99 minutes
120
Description
Allows the local mode functions to be displayed in different languages. The language setting does not affect the language displayed when working with a sensor. When working with a sensor, the language selected in the sensor is shown on RX.
RX does not switch off automatically.
After the preset time of RX inactivity, RX switches off.
After the preset time of RX inactivity, both RX and TPS1200+/TPS1200 switch off.
Time of RX inactivity before the set action is executed.
5.5
5.5.1
Description
Access step-by-step
Radio Settings
Radio Communication Settings
Allows changes to the communication parameters of RX.
Description
1. Refer to "5.1 Accessing the Main Configuration Menu" to access the menu
2. Main Configuration Menu
Highlight Radio/Comms Settings.
3. CONT (F1).
Radio/Comms
Settings,
Modes page
Description of fields
Field Option
<ComMode:> RCS Mode
Description
RX operates as a secondary control unit for
TPS1200+/TPS1200.This is the default setting of RX.
Local Mode
RX1200
121
Local Mode
Field
<Modem:>
RX1200
Option
Transparent
Semi-
Transparent
Output
<Baud Rate:> From 19200 to 115200
122
Description
Deactivates the software functionality of RX, converting it into a radio modem which can be used with GFU23, RadioHandle or TCPS27B to communicate remotely with
TPS1200+/TPS1200. Refer to "4.9.3 Working in
Transparent Mode" for more information.
Enables measurement data to be sent from
TPS1200+/TPS1200, via the radio link, to the
LEMO port of RX in real-time. RX continues to control TPS1200+/TPS1200 in the normal RCS
way. Refer to "4.9.4 Working in Semi-Transparent Mode" for more information.
Communication internally via the radio modem or externally via the LEMO port.
This field is only available when:
<ComMode: Transparent> or
<ComMode: Semi-Transparent>.
Radio/Comms
Settings,
Param page
Local Mode
Next step
IF
the local settings are to be exited the next page is to be accessed
THEN
CONT (F1) accepts changes and returns to the screen from where this screen was accessed.
PAGE (F6) changes to another page on this screen
Description of fields
Field Option
<Link Number:>
From 0 to
15
<Baud Rate:>
<Parity:>
Output
Output
Description
Assigned channel number enabling multiple pairs of radios to work simultaneously in the same area without interfering with each other.The link number for a pair of radios must be the same.
Frequency of data transfer from instrument to device.
Error checksum at the end of a block of digital data.
RX1200
123
Local Mode
Field
<Terminator:>
<Data Bits:>
<Stop Bits:>
<Set as:>
RX1200
Option
Output
Output
Output
Remote
Base
124
Description
The terminator of a data packet.
Number of bits in a block of digital data.
Number of bits to end a block of digital data.
Sets the internal radio into a remote mode. The radio modules inside GFU23, RadioHandle or
TCPS27 and RX must be set to opposite settings. It is recommended to set RX to remote and the GFU23, RadioHandle or TCPS27 to base.
Sets the internal radio into a base mode
Next step
IF
the local settings are to be exited default values are to be restored
THEN
CONT (F1) accepts changes and returns to the screen from where this screen was accessed.
DEFLT (F3) restores Leica default values to the internal modem of RX.
Local Mode
IF THEN
radio settings are to be edited
EXT R (F4) displays and allows editing of TCPS27 external radio settings when connected to the LEMO port.
radio settings are to be synchronised
SYNC (F5) synchronises the settings between the internal radio of RX and external radio GFU23, TCPS27B when connected to each other via cable.
)
Open Radio/Comms Settings, Param page to change the parameters for the communication between the radios.
the next page is to be accessed
PAGE (F6) changes to another page on this screen
RX1200
125
Local Mode
5.5.2
Configuring the Radios
View/edit internal/external radio settings step-by-step
RX1200
Description
1. Open Radio/Comms Settings, Param page.
126
2. • For RX1250T/RX1250Tc the internal radio settings are displayed.
• For other models the external radio settings are displayed, when a radio is connected.
)
DEFLT (F3) to reset to Leica default values
3. Edit settings.
)
EXT R (F4) to view the external radio settings when a radio is connected to RX.
4. CONT (F1) to exit and accept changes.
5. ESC to exit and disregard changes.
Synchronising radio settings for the RX step-by-step
Description
1. Connect the radio to RX with a Y-cable and external battery.
2. Open Radio/Comms Settings, Param page.
Description
3. SYNC (F5).
4. Open Radio/Comms Settings, Param page.
5. The settings of the internal radio of RX are displayed.
6. Edit settings.
Local Mode
RX1200
127
Local Mode
5.6
Working with a Sensor
RX1200
Description
128
This function allows to leave the Main Configuration Menu and returns to working with the sensor.
Exit Configuring step-by-step
Description
1. ESC until Main Configuration Menu is displayed.
2. Main Configuration Menu
Highlight Work with Sensor.
3. CONT (F1).
Local Mode
RX1200
129
Care and Transport
6
6.1
Care and Transport
Transport
RX1200
130
Transport in a road vehicle
Never carry the product loose in a road vehicle, as it can be affected by shock and vibration. Always carry the product in its transport container and secure it.
Shipping
When transporting the product by rail, air or sea, always use the complete original
Leica Geosystems packaging, transport container and cardboard box, or its equivalent, to protect against shock and vibration.
Shipping, transport of batteries
When transporting or shipping batteries, the person in charge of the product must ensure that the applicable national and international rules and regulations are observed. Before transportation or shipping, contact your local passenger or freight transport company.
6.2
Product
Storage
Li-Ion batteries
Respect the temperature limits when storing the equipment, particularly in summer
if the equipment is inside a vehicle. Refer to "9 Technical Data" for information about
temperature limits.
•
Refer to "9 Technical Data" for information about storage temperature range.
• A storage temperature range of -20 to +30°C/-4 to 86°F in a dry environment is recommended to minimise self-discharging of the battery.
• At the recommended storage temperature range, batteries containing a 10% to
50% charge can be stored for up to one year. After this storage period the batteries must be recharged.
• Remove batteries from the product and the charger before storing.
• After storage recharge batteries before using.
• Protect batteries from damp and wetness. Wet or damp batteries must be dried before storing or use.
Care and Transport
RX1200
131
Care and Transport
6.3
Cleaning and Drying
RX1200
132
Product and accessories
Use only a clean, soft, lint-free cloth for cleaning. If necessary, moisten the cloth with water or pure alcohol. Do not use other liquids; these may attack the polymer components.
Damp products
Dry the product, the transport container, the foam inserts and the accessories at a temperature not greater than 40°C / 104°F and clean them. Do not repack until everything is completely dry. Always close the transport container when using in the field.
Cables and plugs
Keep plugs clean and dry. Blow away any dirt lodged in the plugs of the connecting cables.
Care and Transport
RX1200
133
Safety Directions
7
7.1
Safety Directions
General Introduction
Description
RX1200
134
The following directions should enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid operational hazards.
The person responsible for the product must ensure that all users understand these directions and adhere to them.
7.2
Intended Use
Permitted use
Adverse use
• Remote control of product.
• Data communication with external appliances.
• Use of the product without instruction.
• Use outside of the intended limits.
• Disabling safety systems.
• Removal of hazard notices.
• Opening the product using tools, for example screwdriver, unless this is specifically permitted for certain functions.
• Modification or conversion of the product.
• Use after misappropriation.
• Use of products with obviously recognizable damages or defects.
• Use with accessories from other manufacturers without the prior explicit approval of Leica Geosystems.
• Inadequate safeguards at the surveying site, for example when measuring on roads.
• Controlling of machines, moving objects or similar monitoring application without additional control- and safety installations.
Safety Directions
RX1200
135
Safety Directions
Warning
RX1200
136
Adverse use can lead to injury, malfunction and damage.
It is the task of the person responsible for the equipment to inform the user about hazards and how to counteract them. The product is not to be operated until the user has been instructed on how to work with it.
7.3
Limits of Use
Environment
Danger
Suitable for use in an atmosphere appropriate for permanent human habitation: not suitable for use in aggressive or explosive environments.
Local safety authorities and safety experts must be contacted before working in hazardous areas, or in close proximity to electrical installations or similar situations by the person in charge of the product.
Safety Directions
RX1200
137
Safety Directions
7.4
Responsibilities
RX1200
138
Manufacturer of the product
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the user manual and original accessories, in a completely safe condition.
Manufacturers of non
Leica Geosystems accessories
The manufacturers of non Leica Geosystems accessories for the product are responsible for developing, implementing and communicating safety concepts for their products, and are also responsible for the effectiveness of those safety concepts in combination with the Leica Geosystems product.
Person in charge of the product
The person in charge of the product has the following duties:
• To understand the safety instructions on the product and the instructions in the user manual.
• To be familiar with local regulations relating to safety and accident prevention.
• To inform Leica Geosystems immediately if the product and the application becomes unsafe.
• To ensure that the national laws, regulations and conditions for the operation of radio transmitters are respected. Not applicable for RX1210.
Warning
The person responsible for the product must ensure that it is used in accordance with the instructions. This person is also accountable for the training and the deployment of personnel who use the product and for the safety of the equipment in use.
Safety Directions
RX1200
139
Safety Directions
7.5
RX1200
End User Licence Agreement EULA
EULA terms
140
• You have acquired a device RX1250 that includes software licenced by Leica
Geosystems from an affiliate of Microsoft Corporation ("MS"). Those installed software products of MS origin, as well as associated media, printed materials, and "online" or electronic documentation ("SOFTWARE") are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved.
• IF YOU DO NOT AGREE TO THIS END USER LICENCE AGREEMENT
("EULA"), DO NOT USE THE DEVICE OR COPY THE SOFTWARE, INSTEAD,
PROMPTLY CONTACT Leica Geosystems FOR INSTRUCTIONS ON
RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE OF THE
SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE,
WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICA-
TION OF ANY PREVIOUS CONSENT).
• GRANT OF SOFTWARE LICENCE. This EULA grants you the following licence:
• You may use the SOFTWARE only on the DEVICE.
• NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT.
Leica Geosystems HAS INDEPENDENTLY DETERMINED HOW TO USE
THE SOFTWARE IN THE DEVICE, AND MS HAS RELIED UPON Leica
Safety Directions
Geosystems TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT
THE SOFTWARE IS SUITABLE FOR SUCH USE.
• NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is provided
"AS IS" and with all faults. THE ENTIRE RISK AS TO SATISFACTORY
QUALITY, PERFORMNCE, ACCURACY, AND EFFORT (INCLUDING LACK
OF NEGLIGENCE) IS WITH YOU. ALSO, THERE IS NO WARRANTY
AGAINST INTERFERENCE WITH YOUR ENJOYMENT OF THE SOFT-
WARE OF AGAINST INFRINGEMENT. IF YOU HAVE RECEIVED ANY
WARRANTIES REGARDING THE DEVICE OR THE SOFTWARE, THOSE
WARRANTIES DO NOT ORIGINATE FROM, AND ARE NOT BINDING ON,
MS.
• No Liability for Certain Damages. EXCEPT AS PROHIBITED BY LAW, MS
SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSE-
QUENTIAL OR INCIDENTAL DAMAGES ARISING FROM OR IN CONNEC-
TION WITH THE USE OR PERFORMANCE OF THE SOFTWARE. THIS
LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS FOF ITS
ESSENTIAL PURPOSE. IN NO EVENT SHALL MS BE LIABLE FOR ANY
AMOUNT IN EXCESS OF U.S. TWO HUNDRED FIFTY DOLLARS
(U.S.$250.00).
• Limitations on Reverse Engineering, Decompilation, and Disassembly.
You may not reverse engineer, decompile, or disassemble the SOFTWARE,
RX1200
141
Safety Directions
RX1200
142
except and only to the extent that such activity is expressly permitted by applicable law notwithstanding these limitation.
• SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS. You may permanently transfer rights under this EULA only as part of a permanent sale or transfer of the Device, and only if the recipient agrees to this EULA. If the
SOFTWARE is an upgrade, any transfer must also include all prior versions of the SOFTWARE.
• EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is subject to
U.S. and European Union export jurisdiction. You agree to comply with all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as end-user, end-use and destination restrictions issued by U.S. and other governments.
For additional information see http://www.microsoft.com/exporting/.
7.6
Danger
Hazards of Use
Warning
The absence of instruction, or the inadequate imparting of instruction, can lead to incorrect or adverse use, and can give rise to accidents with far-reaching human, material, financial and environmental consequences.
Precautions:
All users must follow the safety directions given by the manufacturer and the directions of the person responsible for the product.
Because of the risk of electrocution, it is very dangerous to use poles and extensions in the vicinity of electrical installations such as power cables or electrical railways.
Precautions:
Keep at a safe distance from electrical installations. If it is essential to work in this environment, first contact the safety authorities responsible for the electrical installations and follow their instructions.
Safety Directions
RX1200
143
Safety Directions
Warning
Warning
Warning
Caution
RX1200
144
If the product is used with accessories, for example masts, staffs, poles, you may increase the risk of being struck by lightning.
Precautions:
Do not use the product in a thunderstorm.
During dynamic applications, for example stakeout procedures there is a danger of accidents occurring if the user does not pay attention to the environmental conditions around, for example obstacles, excavations or traffic.
Precautions:
The person responsible for the product must make all users fully aware of the existing dangers.
Inadequate securing of the working site can lead to dangerous situations, for example in traffic, on building sites, and at industrial installations.
Precautions:
Always ensure that the working site is adequately secured. Adhere to the regulations governing safety and accident prevention and road traffic.
With the remote control on surveying products, it is possible that extraneous targets will be picked out and measured.
Precautions:
When measuring in remote control mode, always check your results for plausibility.
Warning
Warning
Caution
Only Leica Geosystems authorized service workshops are entitled to repair these products.
If computers intended for use indoors are used in the field there is a danger of electric shock.
Precautions:
Adhere to the instructions given by the computer manufacturer with regard to field use in conjunction with Leica Geosystems products.
If the accessories used with the product are not properly secured and the product is subjected to mechanical shock, for example blows or falling, the product may be damaged or people may sustain injury.
Precautions:
When setting-up the product, make sure that the accessories are correctly adapted, fitted, secured, and locked in position.
Avoid subjecting the product to mechanical stress.
Safety Directions
RX1200
145
Safety Directions
Caution
Warning
Warning
RX1200
146
During the transport, shipping or disposal of batteries it is possible for inappropriate mechanical influences to constitute a fire hazard.
Precautions:
Before shipping the product or disposing of it, discharge the batteries by running the product until they are flat.
When transporting or shipping batteries, the person in charge of the product must ensure that the applicable national and international rules and regulations are observed. Before transportation or shipping contact your local passenger or freight transport company.
Using a battery charger not recommended by Leica Geosystems can destroy the batteries. This can cause fire or explosions.
Precautions:
Only use chargers recommended by Leica Geosystems to charge the batteries.
High mechanical stress, high ambient temperatures or immersion into fluids can cause leackage, fire or explosions of the batteries.
Precautions:
Protect the batteries from mechanical influences and high ambient temperatures. Do not drop or immerse batteries into fluids.
Warning
Warning
Safety Directions
Short circuited battery terminals can overheat and cause injury or fire, for example by storing or transporting in pockets if battery terminals come in contact with jewellery, keys, metallized paper or other metals.
Precautions:
Make sure that the battery terminals do not come into contact with metallic objects.
If the product is improperly disposed of, the following can happen:
• If polymer parts are burnt, poisonous gases are produced which may impair health.
• If batteries are damaged or are heated strongly, they can explode and cause poisoning, burning, corrosion or environmental contamination.
• By disposing of the product irresponsibly you may enable unauthorized persons to use it in contravention of the regulations, exposing themselves and third parties to the risk of severe injury and rendering the environment liable to contamination.
Precautions:
The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with the national regulations in force in your country.
Always prevent access to the product by unauthorized personnel.
RX1200
147
Safety Directions
RX1200
148
Product specific treatment and waste management information can be downloaded from the Leica Geosystems home page at http://www.leica-geosystems.com/treatment or received from your Leica Geosystems dealer.
7.7
Description
Electromagnetic Compatibility EMC
Warning
Caution
The term Electromagnetic Compatability is taken to mean the capability of the product to function smoothly in an environment where electromagnetic radiation and electrostatic discharges are present, and without causing electromagnetic disturbances to other equipment.
Electromagnetic radiation can cause disturbances in other equipment.
Although the product meets the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that other equipment may be disturbed.
There is a risk that disturbances may be caused in other equipment if the product is used in conjunction with accessories from other manufacturers, for example field computers, personal computers, two-way radios, non-standard cables or external batteries.
Precautions:
Use only the equipment and accessories recommended by Leica Geosystems.
When combined with the product, they meet the strict requirements stipulated by the guidelines and standards. When using computers and two-way radio, pay attention to the information about electromagnetic compatibility provided by the manufacturer.
Safety Directions
RX1200
149
Safety Directions
Caution
Warning
RX1200
150
Disturbances caused by electromagnetic radiation can result in erroneous measurements.
Although the product meets the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that the product may be disturbed by very intense electromagnetic radiation, for example, near radio transmitters, two-way radios or diesel generators.
Precautions:
Check the plausibility of results obtained under these conditions.
If the product is operated with connecting cables attached at only one of their two ends, for example external supply cables, interface cables, the permitted level of electromagnetic radiation may be exceeded and the correct functioning of other products may be impaired.
Precautions:
While the product is in use, connecting cables, for example product to external battery, product to computer, must be connected at both ends.
Radios or digital cellular phones
Warning
Use of product with radio or digital cellular phone:
Electromagnetic radiation can cause disturbances in other equipment, in installations, in medical devices, for example pacemakers or hearing aids and in aircraft. It can also affect humans and animals.
Precautions:
Although the product meets in combination with radio or digital cellular phone devices recommended by Leica Geosystems the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that other equipment may be disturbed or that humans or animals may be affected.
• Do not operate the product with radio or digital cellular phone devices in the vicinity of filling stations or chemical installations, or in other areas where an explosion hazard exists.
• Do not operate the product with radio or digital cellular phone devices near medical equipment.
• Do not operate the product with radio or digital cellular phone devices in aircraft.
• Do not operate the product with radio or digital cellular phone devices for long periods immediately next to your body.
Safety Directions
RX1200
151
Safety Directions
7.8
RX1200
FCC Statement, Applicable in U.S.
Applicablility
Warning
152
The grayed paragraph below is only applicable for RX1210 products without radio.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning
Labelling
RX1210/RX1210T
Changes or modifications not expressly approved by Leica Geosystems for compliance could void the user's authority to operate the equipment.
Type: RX1210 .......
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including i nterference that may cause undesired operation.
RX12_023
Safety Directions
RX1200
153
Safety Directions
Labelling all RX1250 models
RX1200
Type: RX1250
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
This device complies with part
15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
RX12_025
Labelling
SmartAntenna
154
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may not cause harm- ful interference, and (2) this device must accept any interference received, including inter- ference that may cause undesired operation.
Type: AT.... Art.No.: ......
Equip.No.: XXXXXX S.No.: ......
Power: 12V---, nominal 1/0.5A max.
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured: 2004
Made in Switzerland S.No.: ......
TPS12_208
Labelling
GHT56
RX12_026
Safety Directions
RX1200
Type: GHT 56 .......
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . .
. . . . . . . . .
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
155
Safety Directions
Labelling
GFU23, GFU24
RX1200
Type: GFUXX . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
GPS12_103
156
Labelling
GFU19, GFU25,
GFU26
Type: GFUXX . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
TPS12_218
Safety Directions
RX1200
157
Safety Directions
Labelling internal battery
GEB211, GEB221
.............................................
................................
....
..........
......................
RX1200
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
158
TPS12_082
Labelling
USB cable GEV161
RX12_027
Type: GEV161
Power: 3,3V / 0,005mA
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured: 08.2005
Made in Switzerland
Art.No.: 733281
S.No.: 0055
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Safety Directions
RX1200
159
Trouble Shooting
8 Trouble Shooting
Turning on and communicating with the instruments
RX1200
160
Problem
RX does not turn on
RX does not connect to
TPS1200+/
TPS1200
Details
all
RX1250 models with a battery
To be checked
• Battery fully charged.
RX1210/RX1210T • Clip-on connection to GPS1200+.
• Cable connection to GPS1200+ RX port.
• Connection to a fully charged battery.
Via the radio link • <Sensor: TPS1200+> or <Sensor: Auto
Detect> is selected in Main Configuration
Menu: Choose Sensor on RX. Refer to
• <ComMode: RCS Mode> is selected in
Main Configuration Menu: Radio/Comms
Settings on the Modes page. Refer to
Trouble Shooting
Problem Details
RX1200
To be checked
• TPS1200+/TPS1200 is set to work in
RCS mode. Refer to
TPS1200+/TPS1200 Technical Reference Manual.
• The base radio is connected to the instrument and a fully charged external battery.
• RX and the base radio are within radio range.
• The radio settings in RX and the base
radio are correct. Refer to "5.5 Radio
Radio settings should be synchronised to
Leica default values. Refer to paragraph
"Synchronising radio settings for the RX step-by-step" in "5.5.2 Configuring the
161
Trouble Shooting
Problem
RX does not connect to
GPS1200+
RX1200
Details
Via cable
Via clip-on-contacts
162
To be checked
• <Sensor: TPS1200+> or <Sensor: Auto
Detect> is selected in Main Configuration
Menu: Choose Sensor on the controller.
Refer to "5.3 Choosing a Sensor".
• <ComMode: RCS Mode> is selected in
Main Configuration Menu: Radio/Comms
Settings on the Modes page. Refer to
• Proper physical connection of cable to
TPS1200+/TPS1200 and the controller.
• RX1210/RX1210T is connected to the instrument and a fully charged external battery.
• RX is properly connected to GPS1200+.
Trouble Shooting
Problem Details
Via cable
RX1250 does not connect to
SmartAntenna
Via Bluetooth
Via cable
To be checked
• <Sensor: GPS1200+> or <Sensor: Auto
Detect> is selected in Main Configuration
Menu: Choose Sensor on RX. Refer to
• RX is properly connected to GPS1200+.
• <Sensor: GPS1200+> or <Sensor: Auto
Detect> is selected in Main Configuration
Menu: Choose Sensor on RX. Refer to
• SmartAntenna battery is charged.
• SmartAntenna is switched on.
• Correct configuration in CONFIGURE
SmartAntenna Interface.
• Correct cable being used GEV173, 8 pin
Lemo connectors with green shielding.
RX1200
163
Trouble Shooting
Radio performance
Problem
Radio range not optimal
Details
RX1200
164
To be checked
• TCPS27B is mounted onto the tripod
using the adapter. Refer to "3.1.4 Setting up for Remote Control (with the Radio-
• Change the link number if it is suspected to have other 2.4 GHz radios operating in the area, this measure may reduce interference and improve radio performance.
Refer to "5.5 Radio Settings".
• RX faces the instrument without obstruction between the antennas.
RX1250 communicating with radio/digital cellular phone
Problem
RX1250 does not connect to digital cellular phone
Details
Via Bluetooth
To be checked
• Bluetooth on digital cellular phone turned on.
• Digital cellular phone ready for external connectivity.
RX1250 recognising Compact-
Flash card
Trouble Shooting
Problem
RX1250 does not recognise radio
Details
Via GHT56
To be checked
• Battery of digital cellular phone fully charged.
• RX1250 is properly connected to GHT56 via clip-on-contacts.
• Battery of radio fully charged. The radio is powered by the battery attached to
GHT56. If the LED indicator on GHT56 is green, then power is okay.
Problem
RX1250 does not recognise
CompactFlash card
Details
CompactFlash card is inserted into a slot inside the battery compartment on the underside of the RX1250.
To be checked
• CompactFlash card is inserted.
• CompactFlash card is pushed in completely.
RX1200
165
Trouble Shooting
RX1250
Windows CE
RX1200
166
Problem
Icons not on
Windows CE desktop
Details
Icon to display
Leica software
Function keys are hidden by
Windows CE task bar
-
To be checked
• Tap the Start button in the bottom left corner of Windows CE desktop. Then select Programs\Leica Geosystems.
• Access the Windows directory from the
Windows CE Explorer. Copy the Leica software icon and paste it to the Windows
CE desktop. The Leica software icon may be a hidden file.
• Tap the Start button in the bottom left corner of Windows CE desktop. Then select Settings\Taskbar and Start Menu.
Under the General tab tick the Auto hide option.
RX1250 Bluetooth connection to PC
Problem
RX1250 does not connect to
PC
Details
Via Bluetooth
To be checked
• Use another USB port to connect the
Bluetooth device to the PC.
Trouble Shooting
Problem Details To be checked
• Is the device properly detected and the driver loaded?
• Go to My Computer/Manage/Device
Management. Check the settings of the
Bluetooth device.
• Check the Bluetooth device settings, for example the Options and COM ports pages.
• Is ActiveSync running? Is the correct
COM port defined in the Connection
Settings dialog?
• Re-boot the PC or/and RX1250.
RX1200
167
Technical Data
9
9.1
Technical Data
RX Technical Data
Design
Control unit
RX1200
168
Glass reinforced polymer housing with optional integrated battery and radio modem.
Display: 1/4 VGA (320 x 240 pixels), graphics capable LCD, illumination, optional touch screen, monochrome display (RX1210, RX1250T, RX1250X)
Keyboard:
Angle Display:
Distance Display: colour display (RX1250Tc, RX1250Xc)
62 keys including 12 function keys, illumination
360°’", 360° decimal, 400 gon, 6400 mil, V % m, ft int, ft us, ft int inch, ft us inch
Touch screen if fitted: Toughened film on glass
Dimensions
Type
RX1210/RX1210T
Length [m]
0.218
all RX1250 models 0.218
Width [m]
0.123
0.123
Thickness [m]
0.037
0.047
Weight
Type
RX1210/RX1210T
RX1250T/RX1250Tc, with GEB211, with Internal Radio
RX1250X/RX1250Xc, with GEB211
Weight [kg]/[lbs]
0.480/1.058
0.795/1.753
0.741/1.634
Technical Data
RX1200
169
Technical Data
Recording
RX1200
170
For all RX1250 models, data can be recorded on the CompactFlash card.
Type
CompactFlash card
Capacity [MB] Data capacity
• 256 256 MB is typically sufficient for about
GPS only (12 satellites)
• 2000 h L1 + L2 + L5 data logging at 15 s rate
• 8000 h L1 + L2 + L5 data logging at 60 s rate
• 360000 real-time points with codes
GPS + GLONASS (12/8 satellites)
• 1700 h data logging at 15 s rate
• 6800 h data logging at 60 s rate
• 360000 real-time points with codes
GPS + GLONASS + Galileo (12/8/10 satellites)
• 800 h data logging at 15 s rate
• 3200 h data logging at 60 s rate
• 360000 real-time points with codes
Power
Type
RX1210/RX1210T
Consumption [W]
1
RX1250T/
RX1250Tc
RX1250X/
RX1250Xc
1.6/
1.8
Bluetooth to
SmartAntenna, digital cellular phone powered from GHT56
1.1/
1.4
Bluetooth to
SmartAntenna, digital cellular phone powered from GHT56
External supply voltage
Nominal voltage 12 V DC
( )
Voltage range 11.5 V-28 V
Nominal voltage 12 V DC
( )
Voltage range 11.5 V-28 V
Nominal voltage 12 V DC
( )
Voltage range 11.5 V-28 V
Technical Data
RX1200
171
Technical Data
Internal battery
Type
RX1250T/
RX1250Tc
RX1250X/
RX1250Xc
RX1200
172
Battery
Li-Ion
Voltage
7.4 V
Capacity Operating time, typical
GEB211: 2.2 Ah 10 h/
9 h
Radio link to instrument
Li-Ion 7.4 V GEB211: 2.2 Ah 12 h/
11 h
Bluetooth link to SmartAntenna
Environmental specifications
Temperature
Type
all models
Internal battery
Operating temperature [°C] Storage temperature [°C]
-30 to +65
Bluetooth: -25 to +65
Colour display: -30 to +50
-40 to +80
-20 to +55 -40 to +70
Interfaces
Technical Data
Protection against water, dust and sand
Type
all models
Protection
IP67 (IEC60529)
Dusttight
Waterproof to 1 m temporary immersion
Humidity
Type
all models
Protection
Up to 100 %
The effects of condensation are to be effectively counteracted by periodically drying out RX.
Type
RX1210/RX1210T
RS232
No handshake
LEMO port
Clip-on-contacts all RX1250 models LEMO port
RS232
Handshake
-
Clip-oncontacts
USB
-
Bluetooth
-
LEMO port Class 2
RX1200
173
Technical Data
Data format for
RS232
Ports
RX1200
The default values are:
Baud rate:
Parity:
Terminator:
Data bits:
Stop bits:
115200
None
CR/LF
8
1
Type 8 pin LEMO-1 Special clip-on interface
all models For power and/or communication For communication to GHT56 and GPS1200+
174
9.2
9.2.1
SmartAntenna Technical Data
Tracking Characteristics
Receiver technology
SmartTrack+ (ATX1230+ GNSS)
Satellite reception
Triple frequency
Receiver channels
ATX1230+ GNSS: Up to 16 channels continuous tracking on L1, L2 and L5 (GPS); up to 14 channels continuous tracking on L1 and L2
(GLONASS); up to 14 channels continuous tracking on E1,
E5a, E5b and Alt-BOC (Galileo); four channels tracking SBAS.
)
Depending on the satellite systems and signals configured in CONFIGURE Satellite
Settings a maximum number of 120 channels is allocated.
Technical Data
RX1200
175
Technical Data
Supported codes and phases
RX1200
176
GPS
Type
ATX1230+ GNSS
L1
Carrier phase,
C/A code
L2 L5
Carrier phase, C code (L2C) and
P2 code
Carrier phase, code
GLONASS
Type L1
ATX1230+ GNSS Carrier phase, C/A code
Galileo
Type
ATX1230+ GNSS
L2
Carrier phase, P2 code
E1
Carrier phase, code
E5a
Carrier phase, code
E5b
Carrier phase, code
Alt-BOC
Carrier phase, code
)
Carrier phase and code measurements on L1, L2 and L5 (GPS) are fully independent with AS on or off.
Satellites tracked
ATX1230+ GNSS: Up to 16 simultaneously on L1, L2 and L5 (GPS) + up to 14 simultaneously on L1 and L2 (GLONASS) + up to 14 simultaneously on E1, E5a, E5b and Alt-BOC (Galileo) + up to four
SBAS
Technical Data
RX1200
177
Technical Data
9.2.2
Accuracy
)
RX1200
178
Accuracy is dependent upon various factors including the number of satellites tracked, constellation geometry, observation time, ephemeris accuracy, ionospheric disturbance, multipath and resolved ambiguities.
The following accuracies, given as root mean square, are based on measurements processed using LGO and on real-time measurements.
Differential code
The use of multiple GNSS systems can increase accuracy by up to 30% relative to
GPS only.
The baseline precision of a differential code solution for static and kinematic surveys is 25 cm.
Differential phase in post-processing
Static
Horizontal
5 mm + 0.5 ppm
Vertical
Kinematic
Horizontal
10 mm + 0.5 ppm 10 mm + 1 ppm
Vertical
20 mm + 1 ppm
Differential phase in real-time
Static
Horizontal
5 mm + 0.5 ppm
Vertical
Kinematic
Horizontal
10 mm + 0.5 ppm 10 mm + 1 ppm
Vertical
20 mm + 1 ppm
Technical Data
RX1200
179
Technical Data
9.2.3
Technical Data
Description and use
Dimensions
RX1200
180
The SmartAntenna is selected for use based upon the application. The table gives a description and the intended use of the SmartAntenna.
Type Description Use
ATX1230+ GNSS GPS, GLONASS, Galileo,
Compass SmartTrack+ antenna with built in groundplane.
With RX1250 or
TPS1200+/TPS1200.
Height:
Diameter:
0.089 m
0.186 m
Connector
Mounting
Weight
Power
8 pin LEMO-1
5/8" Whitworth
1.1 kg including internal battery GEB211
Power consumption: 1.8 W typically, 150 mA
External supply voltage: Nominal 12 V DC ( ), voltage range 5-28 V DC
Battery internal
Electrical data
Technical Data
Type:
Voltage:
Capacity:
Typical operating time:
Li-Ion
7.4 V
GEB211: 2.2 Ah
5.7 h
Type
Voltage
Current
Frequency
ATX1230+ GNSS
-
-
GPS L1 1575.42 MHz
GPS L2 1227.60 MHz
GPS L5 1176.45 MHz
GLONASS L1 1602.5625-1611.5 MHz
GLONASS L2 1246.4375-1254.3 MHz
Galileo E1 1575.42 MHz
Galileo E5a 1176.45 MHz
Galileo E5b 1207.14 MHz
Galileo Alt-BOC 1191.795 MHz
RX1200
181
Technical Data
)
Environmental specifications
RX1200
Type
Gain
Noise Figure
ATX1230+ GNSS
Typically 27 dBi
Typically < 2 dBi
Galileo Alt-BOC covers bandwith of Galileo E5a and E5b.
Temperature
Operating temperature [°C]
-40 to +65
Bluetooth: -30 to +65
Storage temperature [°C]
-40 to +80
Protection against water, dust and sand
Protection
IP67 (IEC 60529)
Dusttight
Protected against water jets
Waterproof to 1 m temporary immersion
182
Humidity
Protection
Up to 100 %
The effects of condensation are to be effectively counteracted by periodically drying out the antenna.
Technical Data
RX1200
183
Technical Data
9.3
GHT56 Technical Data
Dimensions
Length:
Width:
Thickness:
RX1200
0.169 m
0.123 m
0.130 m
Connector
Weight
Power
Battery
• 8 pin LEMO-1
• 7 pin clip-on-contacts
0.460 kg including internal battery GEB211
Power consumption: Nominal voltage 7.4 V DC ( ) / 2.0 A max
Type:
Voltage:
Capacity:
Typical operating time:
Li-Ion
7.4 V
GEB211: 2.2 Ah, GEB221: 4.4 Ah
The given operating times are valid for
• one fully charged GEB221 battery.
• 25°C. Operating times will be shorter when working in cold weather.
• good data link.
184
Environmental specifications
GFU14, receive only mode: 16.8 h
GFU24: 7.1 h
Pacific Crest radio, receive only mode: 15.4 h
Temperature
Operating temperature [°C] Storage temperature [°C]
-20°C to +65 -40 to +80
Protection against water, dust and sand
Protection
IP67 (IEC 60529)
Dusttight
Protected against water jets
Waterproof to 1 m temporary immersion
Technical Data
RX1200
185
Technical Data
RX1200
Humidity
Protection
Up to 100 %
The effects of condensation are to be effectively counteracted by periodically drying out the antenna.
186
9.4
9.4.1
Conformity to National Regulations
RX1210
Conformity to national regulations
Hereby, Leica Geosystems AG, declares that the product RX1210 is in compliance with the essential requirements and other relevant provisions of the applicable European Directives The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce.
Technical Data
RX1200
187
Technical Data
9.4.2
RX1250, GFU23
Conformity to national regulations
RX1200
188
• FCC Part 15 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the RX1250 and GFU23 is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC. The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC
(R&TTE) can be placed on the market and be put into service without restrictions in any EU Member state.
• The conformity for countries with other national regulations not covered by the
FCC part 15 or European directive 1999/5/EC has to be approved prior to use and operation.
Frequency band
Type
all RX1250 models (Bluetooth)
Frequency band [MHz]
2402 - 2480
RX1250T/RX1250Tc (Spread Spectrum Transceiver) Limited to 2409 - 2435
GFU23 (Spread Spectrum Transceiver)
Output power
Antenna
Type
all RX1250 models (Bluetooth)
Output power [mW]
2.5
RX1250T/RX1250Tc (Spread Spectrum Transceiver) < 100
GFU23 (Spread Spectrum Transceiver)
A
B
C
Type A:
Type B:
Type C: all RX1250 models (Bluetooth)
RX1250T/RX1250Tc (Spread Spectrum Transceiver)
GFU23 (Spread Spectrum Transceiver)
Type Antenna Gain [dBi] Connector
Integrated antenna
Detachable λ/4 antenna
Detachable λ/2 antenna
-
2
1
-
SMA
TNC
Frequency band [MHz]
-
2409 - 2435
2409 - 2435
Technical Data
RX1200
189
Technical Data
9.4.3
GFU24, Siemens MC75
Conformity to national regulations
RX1200
190
• FCC Part 15, 22 and 24 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the GFU24 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC
(R&TTE) can be placed on the market and be put into service without restrictions in any EU Member state.
• The conformity for countries with other national regulations not covered by the
FCC part 15, 22 and 24 or European directive 1999/5/EC has to be approved prior to use and operation.
Frequency band
Output power
Quad-Band EGSM850 / EGSM900 / GSM1800 / GSM1900 MHz
EGSM850:
EGSM900:
GSM1800:
GSM1900:
2 W
2 W
1 W
1 W
Antennas
Specific Absorption Rate (SAR)
Type
Frequency band
Type
Gain
Connector
GAT 3
900 or 1800 MHz
Detachable λ/2 antenna
0 dBi
TNC
GAT 5
850 or 1900 MHz
Detachable λ/2 antenna
0 dBi
TNC
The product meets the limits for the maximum permissible exposure of the guidelines and standards which are force in this respect. The product must be used with the recommended antenna. A separation distance of at least 20 centimeters should be kept between the antenna and the body of the user or nearby person within the intended application.
Technical Data
RX1200
191
Technical Data
9.4.4
RX1200
GFU19 (US), GFU25 (CAN), GFU26 (US) CDMA MultiTech MTMMC-C
192
Conformity to national regulations
Frequency band
Output power
• FCC Part 15, 22 and 24 (applicable in US)
• The conformity for countries with other national regulations not covered by the
FCC part 15, 22 and 24 has to be approved prior to use and operation.
Dual-Band CDMA850/CDMA1900 MHz
CDMA850:
CDMA1900:
2 W
0.4 W
Antenna
Type
Frequency band
Type
Gain
Connector
GAT 5
850 or 1900 MHz
Detachable λ/2 antenna
0 dBi
TNC
Specific Absorption Rate (SAR)
The product meets the limits for the maximum permissible exposure of the guidelines and standards which are force in this respect. The product must be used with the recommended antenna. A separation distance of at least 20 centimeters should be kept between the antenna and the body of the user or nearby person within the intended application.
Technical Data
RX1200
193
Technical Data
9.4.5
RX1200
SmartAntenna with Bluetooth
Conformity to national regulations
194
• FCC Part 15 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the SmartAntenna with Bluetooth is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC. The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC
(R&TTE) can be placed on the market and be put into service without restrictions in any EU Member state.
• The conformity for countries with other national regulations not covered by the
FCC part 15 or European directive 1999/5/EC has to be approved prior to use and operation.
Frequency band
Type
ATX1230+ GNSS
Output power
Antenna
Technical Data
Bluetooth
Type
GNSS
Bluetooth
GNSS
Bluetooth
RX1200
Frequency band [MHz]
1176.45
1191.795
1207.14
1227.60
1246.4375 - 1254.3
1575.42
1602.4375 - 1611.5
2402 - 2480
Output power [mW]
Receive only
5
Internal GNSS antenna element (receive only)
Type: Internal Microstrip antenna
Gain: 1.5 dBi
195
International Limited Warranty, Software Licence Agreement
10
RX1200
International Limited Warranty, Software Licence
Agreement
196
International
Limited Warranty
Software Licence
Agreement
This product is subject to the terms and conditions set out in the International Limited
Warranty which you can download from the Leica Geosystems home page at http://www.leica-geosystems.com/internationalwarranty or collect from your Leica
Geosystems distributor. The foregoing warranty is exclusive and is in lieu of all other warranties, terms or conditions, express or implied, either in fact or by operation of law, statutory or otherwise, including warranties, terms or conditions of merchantability, fitness for a particular purpose, satisfactory quality and non-infringement, all of which are expressly disclaimed.
This product contains software that is preinstalled on the product, or that is supplied to you on a data carrier medium, or that can be downloaded by you online pursuant to prior authorization from Leica Geosystems. Such software is protected by copyright and other laws and its use is defined and regulated by the Leica Geosystems
Software Licence Agreement, which covers aspects such as, but not limited to,
Scope of the Licence, Warranty, Intellectual Property Rights, Limitation of Liability,
Exclusion of other Assurances, Governing Law and Place of Jurisdiction. Please make sure, that at any time you fully comply with the terms and conditions of the
Leica Geosystems Software Licence Agreement.
Such agreement is provided together with all products and can also be referred to and downloaded at the Leica Geosystems home page at http://www.leica-geosystems.com/swlicense or collected from your Leica Geosystems distributor.
You must not install or use the software unless you have read and accepted the terms and conditions of the Leica Geosystems Software Licence Agreement. Installation or use of the software or any part thereof, is deemed to be an acceptance of all the terms and conditions of such licence agreement. If you do not agree to all or some of the terms of such licence agreement, you may not download, install or use the software and you must return the unused software together with its accompanying documentation and the purchase receipt to the dealer from whom you purchased the product within ten (10) days of purchase to obtain a full refund of the purchase price.
International Limited Warranty, Software
Licence Agreement
RX1200
197
Directory Structure of the Memory
Device
RX1200
Appendix A Directory Structure of the Memory Device
198
Description
On the memory device, files are stored in certain directories. The following diagram of the directory structure refers to both CompactFlash card and internal memory if fitted. Backwards compatible with Leica GPS System 500 are geoid field files, CSCS field files and GSI files.
• Codelists, various files
Directory structure
|
|
|—— CODE
|
|
|—— CONFIG
|
|
|
|
|
|
|
|
|—— CONVERT
|
|
|
|
|
|
|—— DATA
|
|
|
|
|
|—— GPS
|
|
|
|—— CSCS
•
• TPS configuration files (*.xfg)
• Format files (*.frt)
•
•
•
GPS configuration files (*.xfg)
ASCII, DXF, LandXML, GSI8, GSI16 files for import/export to/from job (*.*)
• Logfiles created from application programs
Almanac file (Almanac.sys)
CSCS field files (*.csc)
|
|
|
|
|
|
|
|
|
|
|
|
|
|—— DBX
|
|
|
|
|—— GPS
|
|
|
|—— GSI
|—— SYSTEM
|
|
|—— GEOID
|
|—— RINGBUF
• Geoid field files (*.gem)
• Ring buffer files
• Job files, various files
• DTM jobs, various files
• System 1200 coordinate system file
(Trfset.dat)
• Antenna file (List.ant)
• GSM/Modem station list
(Stations1200.fil)
• GSI files (*.gsi)
• ASCII files for export from job (*.*)
• Application program files (*.a*)
• Firmware files (*.fw)
• Language files (*.s*)
• Licence file (*.key)
• System files (System.ram)
Directory Structure of the Memory Device
RX1200
199
Cables
Appendix B Cables
RX1200
200
Description
Some applications require the connection of instruments, devices or accessories to the RX. In this chapter, the required cables and their use are listed.
Cables connecting instruments, devices or accessories
The table shows in alphabetical order which instruments, devices or accessories can
be connected using cables. Refer to paragraph "Cables and product names" for a
full description of these cables.
From To Cables
External - GEB171 or GEV208 all RX1250 models • GEV215
•
PC cable, RS232 9 pin
SmartAntenna • GEV215 all RX1250 models • GEV162
PC cable, USB on PC
RX1210/RX1210T
SmartAntenna
GPS1200+
• GEV162 all RX1250 models • GEV161
•
• GEV163
• GEV164
From To
GRX1200+/
GRX1200+ GNSS
RX1250 (all RX1250 models) SmartAntenna
Cables
• GEV163
• GEV164
• GEV173
• GEV215
• GEV217
TCPS27
TPS1200+/
TPS1200
TPS1200+/
TPS1200
• GEV186
Cables and product names
The product names of the cables in the above table are explained in detail below in ascending order.
Name Description
GEV71 Cable 4.0 m, LEMO to 12 V DC power supply
It allows a connection to a 12 V DC power supply for example a car battery. Cables used to connect to a GEB171 battery can be connected to adapter cable number 7.
GEV97 Cable 1.8 m, GX power cable
Cables
RX1200
201
Cables
RX1200
Name Description
GEV160 Cable 2.8 m, data transfer GX COM to RS232
GEV161 Cable 2.8 m, data transfer GX RX1250 to USB
GEV162 Cable 2.8 m, data transfer GX RX to RS232
GEV163 Cable 1.8 m, RX to GX
GEV164 Cable 1.0 m, RX to GX, all-on-pole setup
GEV171 Y-cable 1.8 m, programming cable, GFU14 to RS232 with power
GEV173 Cable 1.2 m, SmartAntenna to all RX1250 models
GEV186 Y-cable 1.8 m, TCPS27 to TPS1200+/TPS1200 with power
GEV208 Power supply unit, 12 V DC
GEV215 Y-cable, SmartAntenna and all RX1250 models to GEB171
GEV217 Cable 1.8 m, TPS1200+/TPS1200 to all RX1250 models
202
Cables
RX1200
203
Index
RX1200
204
Index
A
Abbreviations ....................................................... 12
ActiveSync ................................................... 18, 101
Antenna file, directory ........................................ 199
Application program file, directory ..................... 199
Attach, clip-on-housing ........................................ 71
B
Battery
Change in GHT56 .......................................... 60
Change in RX1250 ......................................... 56
Change in SmartAntenna ............................... 58
Icons ............................................................... 33
Operating temperature ................................. 172
Storage temperature ............................ 131, 172
Bluetooth
Icon ................................................................ 34
LED on SmartAntenna ................................... 66
C
Cables ............................................................... 200
Cleaning and Drying ......................................... 132
Clip-on-housing
Attach ............................................................. 71
Detach ........................................................... 72
Codelist, directory ............................................. 198
CompactFlash card
Format ........................................................... 64
Insert .............................................................. 63
Memory device .............................................. 19
Remove ......................................................... 63
Safety instructions ......................................... 62
Configuration file, directory ............................... 198
Connector
GHT56 ......................................................... 184
SmartAntenna .............................................. 180
Conversion of data .............................................. 20
Coordinate system file, directory ....................... 199
CSCS field file, directory ................................... 198
D
Data conversion .................................................. 20
Data transfer ........................................................ 20
Detach, clip-on-housing ....................................... 72
Device
Clip-on-housing .............................................. 70
Status ............................................................. 77
Dimensions
GHT56 .......................................................... 184
SmartAntenna .............................................. 180
Directory structure of memory device ................ 198
Documentation ...................................................... 4
Drive
PC card, on office computer ........................... 20
DTM job, directory ............................................. 199
E
Electrical data, SmartAntenna ........................... 181
End User Licence Agreement ........................... 140
Environmental specifications
GHT56 ......................................................... 185
SmartAntenna .............................................. 182
EULA ................................................................. 140
F
Firmware file, directory ...................................... 199
Flashing LED on clip-on-housing ........................ 79
Format CompactFlash card ................................ 64
Format files, directory ....................................... 198
Frequency band
GFU19, MultiTech MTMMC-C ..................... 192
GFU24, Siemens MC75 ............................... 190
SmartAntenna .............................................. 195
G
Galileo ................................................................. 94
GAT 3, antenna ................................................. 191
GeoC++ .............................................................. 17
Geoid field file, directory ................................... 199
GFU19 .............................................................. 192
GFU23 .............................................................. 188
Index
RX1200
205
I
Index
RX1200
GFU24 ............................................................... 190
GFU25 ............................................................... 192
GFU26 ............................................................... 192
GPS
L5 option ........................................................ 94
GSI file, directory ............................................... 199
H
Handstrap ............................................................ 43
Housing for devices ............................................. 70
Icons .................................................................... 33
Indicators, LED
Clip-on-housing .............................................. 77
GHT56 ............................................................ 68
SmartAntenna ................................................ 66
Insert
CompactFlash card ........................................ 63
SIM card ......................................................... 73
J
Job file, directory ............................................... 199
K
206
Key Combinations ............................................... 29
Keyboard
Graphical overview ........................................ 26
Operating principles ....................................... 32
Keys
Alpha keys ..................................................... 27
Arrow keys ..................................................... 28
CAPS key ...................................................... 27
CE key ........................................................... 27
Combinations ................................................. 29
Description of ................................................. 27
ENTER key .................................................... 28
ESC key ......................................................... 27
Function keys ................................................. 27
Hot keys ......................................................... 27
Numeric keys ................................................. 27
PROG key ...................................................... 28
SHIFT key ...................................................... 28
SPACE key .................................................... 28
USER key ....................................................... 28
L
Labelling
GHT56 .......................................................... 155
RX1210 ........................................................ 153
RX1250 ........................................................ 154
USB cable GEV161 ...................................... 159
Language file, directory ..................................... 199
LED
Clip-on-housing, description ........................... 78
GHT56, description ........................................ 69
Housing, description ....................................... 77
SmartAntenna, description ............................. 67
Licence file, directory ......................................... 199
Light Emitting Diode
Clip-on-housing .............................................. 77
GHT56 ............................................................ 68
SmartAntenna ................................................ 66
Li-Ion battery ............................................. 181, 184
Local Settings ................................................... 117
Logfile, directory ................................................ 198
M
Main Configuration Menu
Accessing .................................................... 114
Choosing a sensor ....................................... 116
Description of ............................................... 115
Local settings ............................................... 117
Memory device
Available ........................................................ 19
Directory structure ....................................... 198
Microsoft ActiveSync ................................... 18, 101
Mode
Remote ........................................................ 108
Semi-transparent ......................................... 110
Transparent ................................................. 109
Mount, SmartAntenna ....................................... 180
MultiTech MTMMC-C
GFU19, technical data ................................. 192
Index
RX1200
207
Index
RX1200
O
Operating Temperature
For internal battery GEB211 ........................ 172
For RX .......................................................... 172
GHT56 .......................................................... 185
SmartAntenna .............................................. 182
Output power
GFU19, MultiTech MTMMC-C ..................... 192
GFU24, Siemens MC75 ............................... 190
SmartAntenna .............................................. 195
P
PC card drive on office computer ........................ 20
Power
GHT56 .......................................................... 184
SmartAntenna .............................................. 180
Power LED
GHT56 ............................................................ 68
SmartAntenna ................................................ 66
Power on GHT56, status ..................................... 68
Power supply ....................................................... 21
208
R
Radio Modem
Available radios ............................................. 14
Communication settings .............................. 121
Configuring .................................................. 126
Description of RadioHandle ........................... 14
Description of TCPS27 .................................. 14
Mount TCPS27 to tripod ................................ 48
RCS setup with RadioHandle ........................ 46
RCS setup with TCPS27 ............................... 47
RadioHandle, description of ................................ 14
RCS
Setup with RadioHandle ................................ 46
Setup with TCPS27 ....................................... 47
Recording .......................................................... 170
Remove
CompactFlash card ........................................ 63
SIM card ........................................................ 75
Ring buffer file, directory ................................... 199
RX
Available models ............................................ 13
Components ................................................... 24
Description of ................................................. 12
Detach from GPS receiver ............................. 45
Detach from pole ............................................ 42
Firmware for all RX1250 models .................... 15
Firmware for RX1210/RX1210T ..................... 15
Operating principles ....................................... 32
Operating temperature ................................. 172
Storage temperature .................................... 172
S
Screen
Description of elements .................................. 30
Graphical overview ......................................... 30
Icons ............................................................... 33
Setup for RCS
With RadioHandle .......................................... 46
With TCPS27 ................................................. 47
Siemens MC75
GFU24, technical data ................................. 190
SIM card
Insert .............................................................. 73
Remove ......................................................... 75
Sleep mode ......................................................... 88
SmartAntenna
Accuracy ...................................................... 178
Battery ........................................................... 21
Status ............................................................. 66
Technical data ............................................. 175
Software
Application programs ..................................... 16
ATX1230+ GNSS ........................................... 17
Customised application programs ................. 17
Language ....................................................... 16
Type ............................................................... 15
Upload ........................................................... 17
Specifications, environmental
GHT56 ......................................................... 185
SmartAntenna .............................................. 182
Status, device ..................................................... 77
Status, power on GHT56 .................................... 68
Status, SmartAntenna ......................................... 66
Index
RX1200
209
Index
RX1200
Storage of Equipment ........................................ 131
Storage Temperature
For internal battery GEB211 ................ 131, 172
For RX .......................................................... 172
GHT56 .......................................................... 185
SmartAntenna .............................................. 182
System file, directory ......................................... 199
210
Tracking LED, SmartAntenna ............................. 66
Transfer data ....................................................... 20
Transparent Mode ............................................. 109
Transport of Equipment .................................... 130
Trouble Shooting ............................................... 160
Turning the RX off ......................................... 29, 86
Turning the RX on ......................................... 28, 83
T
TCPS27, description of ....................................... 14
Technical Data
Dimensions .................................................. 168
Display and keyboard ................................... 168
Environmental specifications ........................ 172
Interface ....................................................... 173
Internal battery GEB211 ............................... 172
Ports ............................................................. 174
Power supply ................................................ 171
Weight .......................................................... 169
Temperature, charging internal battery ............... 54
Touch Screen, operating principles ..................... 32
U
Upload software .................................................. 17
User Interface ..................................................... 26
User Manual
W
Validity of ......................................................... 4
Weight
GHT56 ......................................................... 184
SmartAntenna .............................................. 180
Windows key symbol .................................... 26, 29
Index
RX1200
211
Total Quality Management: Our commitment to total customer satisfaction.
Leica Geosystems AG, Heerbrugg, Switzerland, has been certified as being equipped with a quality system which meets the International Standards of Quality Management and Quality Systems (ISO standard 9001) and Environmental
Management Systems (ISO standard 14001).
Ask your local Leica Geosystems dealer for more information about our TQM program.
Leica Geosystems AG
Heinrich-Wild-Strasse
CH-9435 Heerbrugg
Switzerland
Phone +41 71 727 31 31
www.leica-geosystems.com
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Related manuals
advertisement
