U
Front Surround System
ATS-1010
OWNER’S MANUAL
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF
ELECTRIC
SHOCK DO NOT
OPEN
1
2
3
4
5
6
7
8
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
9
• Explanation of Graphical Symbols
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert you to the presence of
uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
10
11
12
13
14
IMPORTANT
Please record the serial number of this unit in the space
below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.
i En
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
Only use attachments/accessories specified by the
manufacturer.
Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been
dropped.
FOR CANADIAN CUSTOMERS
To prevent electric shock, match wide blade of plug to
wide slot and fully insert.
This Class B digital apparatus complies with Canadian
ICES-003.
FCC INFORMATION (for US customers)
1
2
3
IMPORTANT NOTICE: DO NOT MODIFY THIS
UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC,
to use the product.
IMPORTANT: When connecting this product to
accessories and/or another product use only high
quality shielded cables. Cable/s supplied with this
product MUST be used. Follow all installation
instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
NOTE: This product has been tested and found to
comply with the requirements listed in FCC
Regulations, Part 15 for Class “B” digital devices.
Compliance with these requirements provides a
reasonable level of assurance that your use of this
product in a residential environment will not result in
harmful interference with other electronic devices.
This equipment generates/uses radio frequencies and,
if not installed and used according to the instructions
found in the users manual, may cause interference
harmful to the operation of other electronic devices.
4
5
6
7
8
9
Compliance with FCC regulations does not guarantee
that interference will not occur in all installations. If
this product is found to be the source of interference,
which can be determined by turning the unit “OFF”
and “ON”, please try to eliminate the problem by using
one of the following measures:
Relocate either this product or the device that is being
affected by the interference.
Utilize power outlets that are on different branch
(circuit breaker or fuse) circuits or install AC line
filter/s.
In the case of radio or TV interference, relocate/
reorient the antenna. If the antenna lead-in is 300 ohm
ribbon lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce
satisfactory results, please contact the local retailer
authorized to distribute this type of product. If you can
not locate the appropriate retailer, please contact
Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe
Ave., Buena Park, CA 90620.
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.
We Want You Listening For A Lifetime
Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the
most out of your equipment by playing it at a safe level. One that lets the sound come through loud
and clear without annoying blaring or distortion – and, most importantly, without affecting your
sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late,
Yamaha and the Electronic Industries Association’s Consumer Electronics Group recommend you to
avoid prolonged exposure from excessive volume levels.
ii En
Caution: Read this before operating your unit.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
Install this unit in a well ventilated, cool, dry, clean place
- away from direct sunlight, heat sources, vibration, dust,
moisture, and/or cold. For proper ventilation, allow the
following minimum clearances.
Top: 5 cm (2 in)
Rear: 5 cm (2 in)
Sides: 1 cm (3/8 in)
Locate this unit away from other electrical appliances,
motors, or transformers to avoid humming sounds.
Do not expose this unit to sudden temperature changes
from cold to hot, and do not locate this unit in an
environment with high humidity (i.e. a room with a
humidifier) to prevent condensation inside this unit,
which may cause an electrical shock, fire, damage to this
unit, and/or personal injury.
Avoid installing this unit where foreign objects may fall
onto this unit and/or this unit may be exposed to liquid
dripping or splashing. On the top of this unit, do not
place:
– Other components, as they may cause damage and/or
discoloration on the surface of this unit.
– Burning objects (i.e. candles), as they may cause fire,
damage to this unit, and/or personal injury.
– Containers with liquid in them, as they may fall and
liquid may cause electrical shock to the user and/or
damage to this unit.
Do not cover this unit with a newspaper, tablecloth,
curtain, etc. in order not to obstruct heat radiation. If the
temperature inside this unit rises, it may cause fire,
damage to this unit, and/or personal injury.
Do not plug in this unit to a wall outlet until all
connections are complete.
Do not operate this unit upside-down. It may overheat,
possibly causing damage.
Do not use force on switches, knobs and/or cords.
When disconnecting the power cable from the wall
outlet, grasp the plug; do not pull the cable.
Do not clean this unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
Only voltage specified on this unit must be used. Using
this unit with a higher voltage than specified is dangerous
and may cause fire, damage to this unit, and/or personal
injury. Yamaha will not be held responsible for any
damage resulting from use of this unit with a voltage
other than specified.
To prevent damage by lightning, keep the power cable
and outdoor antennas disconnected from a wall outlet or
the unit during a lightning storm.
Do not attempt to modify or fix this unit. Contact
qualified Yamaha service personnel when any service is
needed. The cabinet should never be opened for any
reasons.
When not planning to use this unit for long periods of
time (i.e. vacation), disconnect the AC power plug from
the wall outlet.
Be sure to read the “Troubleshooting” section on
common operating errors before concluding that this unit
is faulty.
Before moving this unit, press
to set this unit in
standby mode, and disconnect the power supply cable
from the wall outlet.
iii En
18 Condensation will form when the surrounding
temperature changes suddenly. Disconnect the power
supply cable from the outlet, then leave the unit alone.
19 Install this unit near the wall outlet and where the AC
power plug can be reached easily.
20 The batteries shall not be exposed to excessive heat such
as sunshine, fire or like.
21 Secure placement or installation is the owner’s
responsibility. Yamaha shall not be liable for any accident
caused by improper placement or installation of speakers.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
As long as this unit is connected to the AC wall outlet,
it is not disconnected from the AC power source even
if you turn off this unit by . In this state, this unit is
designed to consume a very small quantity of power.
(Power key)
Turns on the power of this unit or sets it to the standby
mode.
English
Contents
Enjoying sound with your preference ......... 7
Additional Information ................................ 8
Operation indicators of the unit ................ 11
Troubleshooting ....................................... 12
Specification............................................. 14
Deutsch
What you can do with this unit
Français
Supplied items ............................................2
Front panel .................................................2
Placing........................................................3
Connection .................................................4
Operation....................................................6
Svenska
• Enjoy high quality surround sound (AIR SURROUND XTREME)............................ 7
• Enjoy clear dialogue and narration (Clear voice) ......................................................... 7
• Maintain a consistent volume level between different channels, programs,
commercials. (UniVolume) .......................................................................................... 7
• Operate the unit by the TV’s remote control (TV remote control learning)................. 9
About this manual
Italiano
• In this manual, operations that can be performed using either the front panel buttons or the remote control are
explained using the remote control.
• y indicates a tip for your operation. Notes contain important information about safety and operating instructions.
• This manual is produced prior to production. Design and specifications are subject to change in part as a result of
improvements, etc. In case of differences between the manual and the product, the product has priority.
Notes on the remote control and batteries
Nederlands
Русский
1 En
Español
• Do not spill water or other liquids on the remote control.
• Do not drop the remote control.
• Do not leave or store the remote control in the following places:
- places of high humidity, such as near a bath
- places of high temperatures, such as near a heater or a stove
- places of extremely low temperatures
- dusty places
• Do not expose the remote control sensor of this unit to direct sunlight or lighting such as inverted fluorescent lamps.
• If the batteries grow old, the effective operation range of the remote control decreases considerably. If this happens,
replace the batteries with two new ones as soon as possible.
• Do not use old batteries together with new ones.
• Do not use different types of batteries (such as alkaline and manganese batteries) together. Read the packaging
carefully as these different types of batteries may have the same shape and color.
• Exhausted batteries may leak. If the batteries have leaked, dispose of them immediately. Avoid touching the leaked material
or letting it come into contact with clothing, etc. Clean the battery compartment thoroughly before installing new batteries.
• Do not throw away batteries with general house waste. Dispose of them correctly in accordance with your local regulations.
• Keep batteries away from children. If a battery is accidentally swallowed, contact your doctor immediately.
• When not planning to use the remote control for long periods of time, remove the batteries from the remote control.
• Do not charge or disassemble the supplied batteries.
Supplied items
Before assembly and connecting, make sure you have received all of the following items.
Main unit × 1
Optical cable × 1
(1.5 m (4.9 ft))
Battery × 2
(AAA, R03, UM4)
Remote control × 1
Mounting template × 1
Spacer × 2
(for attaching to a wall)
Front panel
4
1
5
6
2 3
1 Indicators
3 TV remote control sensor
Light up to show the system condition.(☞ P. 11)
y
The indicators automatically become darker if the unit is
left turned on for 5 seconds without any operation being
performed. (Auto dimmer function)
Receives infrared signals from the TV remote
control.
4 INPUT
Selects an input source you want to listen to. (☞ P. 6)
5 VOLUME –/+
2 Remote control sensor
Receives infrared signals from the remote control of
this unit.
2 En
Controls the volume of the unit. (☞ P. 8)
6
(Power)
Turns on the unit, or sets it to standby mode.
English
Placing
1
Installation: illustrated examples
Example 1
Example 2
Example 3
Attach the supplied mounting template
on a wall and mark the holes of the
mounting template.
Tapes or
thumbtacks
Mark
Example 1: Unit beneath TV
Example 2: Unit without stand beneath TV (☞ P. 9)
Example 3: Wall mounting
2
Notes
• Do not place the unit on/under any other components such
as BD player in a pile. The vibration of the unit may cause
system failure, etc. in other components.
• Depending on your installation environment, connections
to external components such as TV or BD player can be
done before installing the unit. We recommend that you
temporarily place and arrange all components in order to
decide which procedure is best done first.
• When you clean the unit, use a clean, dry and soft cloth
(such as cloth for glasses).
• Do not touch the grille on the front and bottom of the unit.
• Place the unit away from your TV more than 50 mm (2”)
so as not to damage your TV with rear panel of the unit.
The brackets on the rear of the unit are removable.
Remove the mounting template and then
install the commercially available screws
and the supplied spacers at the marks.
Spacer (5 mm (1/4”))
7 to 9 mm
(1/4” to 3/8”)
4 mm (#8)
Minimum
2 to 4 mm
20 mm (3/4”)
(1/16” to 3/16”)
3
Hang the unit on the screws using the
brackets on the rear of the unit.
Notes
Attaching the unit to a wall
You can attach the unit to a wall using the brackets on the
rear of the unit.
When installing the unit on a wall, all
installation work must be performed by a
qualified contractor or dealer. The customer
must never attempt to perform this installation
work. Improper or inadequate installation
could cause the unit to fall, resulting in
personal injury.
• Do not attach the unit to a wall that is made of weak
materials such as plaster or veneered woods. Doing so may
cause the unit to fall.
• Use commercially available screws that can support the
weight of the installation.
• Make sure you use specified screws to attach the unit. Using
clamps other than specified screws, such as short screws,
nails, or two-sided tape, may cause the unit to fall.
• When connecting the unit, fix the cables in place where they
will not become loose. If your foot or hand accidentally gets
caught on a loose cable, the unit may fall.
• After attaching the unit, check that the unit is fixed
securely. Yamaha will bear no responsibility for any
accidents caused by improper installations.
3 En
Connection
• Do not connect the power cable until all connections are completed.
• Do not use excessive force when inserting the cable plug. Doing so may damage the cable plug
and/or terminal.
Connecting a TV
The unit plays the audio output from your TV.
Connect input components such as a BD player, etc., to your TV first and check the components play properly before
connecting to the unit. See the manuals of your TV and BD player, etc., for details.
After that, connect the unit to your TV as the illustration below.
BD player
STB
OPTICAL
OUTPUT
1. Remove the cap
Optical cable
(supplied)
TV
SUBWOOFER OUT
2. Check the direction of
the plug
SYSTEM
CONNECTOR
SUBWOOFER OUT
SYSTEM
CONNECTOR
To AC wall outlet
Setting your TV
As connections are completed, set your TV as below before operation.
• Set the volume of the TV to minimum.
• If applicable, set the audio output of your TV’s built-in speakers to off.
4 En
Connection
English
yAlternative connections
Connect the input components (BD player, STB, etc) to the unit directly in the following cases.
• When the unit does not play the sound output from the components connected to your TV (☞ P. 4).
• When your TV does not have any audio input jacks to connect input components, such as a BD player, etc.
Refer to “Using an external subwoofer” (☞ P. 8) for details on the use of an external subwoofer and appropriate settings
of the unit.
SUBWOOFER OUT
SYSTEM
CONNECTOR
System connector cable
(commercially available)*
SUBWOOFER OUT
SYSTEM
CONNECTOR
External
subwoofer
MONAURAL
INPUT
Subwoofer cable
(sold separately)
SYSTEM
CONNECTOR
BD player
Optical cable
(sold separately)
OPTICAL
OUTPUT
STB
Audio digital pin cable
(sold separately)
COAXIAL
OUTPUT
* If connecting an external Yamaha subwoofer, use the cable supplied with the subwoofer to enable synchronous on/
off switching of the unit and subwoofer.
5 En
Operation
Once you have finished all cable connections and remote control operation, follow the procedure below to start basic
playback operation.
Remote control
Installing the batteries
1
3
4
2
5
Before installing batteries or using the remote control,
make sure that you read precautions on the remote control
and batteries in “Notes on the remote control and
batteries” (☞ P. 1).
1
6
3
2
7
8
9
Operation range
Use the remote control within 6 m (20 ft) of the main unit
and point it toward the remote control sensor.
1
(Power): Turns on the unit, or sets it to
standby mode.
2 Input buttons: Select the input source you want
to listen to.
3 UNIVOLUME: Turns UniVolume mode on and
off. (☞ P. 7)
4 CLEAR VOICE: Turns Clear voice mode on and
off. (☞ P. 7)
5 AUDIO DELAY: Turns the audio delay adjusting
mode on and off. (☞ P. 8)
6 SURROUND/STEREO: Switch surround/stereo
mode. (☞ P. 7)
7 SUBWOOFER +/–: Adjust the subwoofer
volume. (☞ P. 8)
8 VOLUME +/–: Adjust the volume. (☞ P. 8)
9 MUTE: Switches mute mode on and off. (☞ P. 8)
6 En
Within 6 m
(20 ft)
Enjoying sound with your preference
1
2
a BD player connected to the audio input
jack of the unit.
Turn your TV on.
Press the TV button to switch the input of
the unit to “TV.”
The unit plays the TV sound.
The INPUT indicator lights up in green.
(☞ P. 11)
3
Switch the input of your TV if you use
components such as a BD player.
1
Switch the video input of your TV to the
video source such as a BD player.
2
Press the BD/DVD or STB button to
switch the input of the unit.
The color of INPUT indicator depends on the selected
input. (☞ P. 11)
3
Start playback.
y
For information on the external component, refer to the
instruction manual for the product.
Enjoying sound with your preference
Switching stereo/surround sound
Playback in surround sound: You can enjoy a
realistic sound effect using Yamaha’s exclusive AIR
SURROUND XTREME.
Playback in stereo sound: An extended sound is
achieved for a 2 channel source.
Surround
Green
Stereo
Automatic volume level adjustment
(UniVolume)
While watching the TV, compensate the excessive
volume differences to make it easier to hear during the
following cases.
• When switching the channel
• When a TV program changed to commercial
• When one program is finished and another program
started
No light
On/Off
Green
Hear narration or dialogue from your
TV more clearly (Clear voice)
This function makes dialogue in movies, TV dramas or
play-by-play broadcasting clear to listen to.
On/Off
Green
7 En
English
yWhen you play back components such as
Basic playback operation
Additional Information
Adjust the volume level
Audio delay control
Press VOLUME +/– to adjust the volume
level.
You can use this function to delay sound to synchronize
with a lagging video image.
1
Press and hold AUDIO DELAY
more than 3 seconds to enter
adjustment mode.
Up
Down
The color of qD DTS indicator changes depending on
the adjustable range. Green indicates a lower volume
level, orange a moderate level, and red a higher level.
Flashes in green (☞ P. 11)
2
Note
Press SUBWOOFER +/– to adjust the
delay time. (+ increases the delay time)
Note that when the qD DTS indicator is red, the volume is
set to a higher level. Excessive sound may damage your
hearing or bother others.
Make the delay time longer
y
To turn off the volume temporarily, press
MUTE.
To resume the volume, press MUTE again or
press VOLUME +/–.
Adjust the subwoofer level
Press SUBWOOFER +/– to adjust the bass
level.
The color of qD DTS indicator changes depending on
the bass level. Green indicates a minus level, orange a
standard level (default value is 0), and red a plus level.
Make the delay time shorter
The color of qD DTS indicator changes depending on
the adjustable range. Green indicates a shorter delay time,
orange a medium delay, and red a longer delay.
3
Press AUDIO DELAY to exit the
adjustment mode.
y
The adjustment mode is canceled if the unit is left for 20
seconds without any operation being performed.
Additional Information
Using an external subwoofer
Although the unit has a subwoofer built-in, you can use
commercially available powered subwoofer of your
choice. Refer to “Alternative connections” (☞ P. 5).
1
2
This unit is turned on when switching between the
built-in subwoofer and external subwoofer.
The SURROUND indicator lights up as the following
illustration. Check if the setting is correct. (☞ P. 11)
8 En
External
subwoofer
Green
No light
The SURROUND
indicator (for 2
seconds after the
unit is turned on)
Set the unit to standby mode.
Press both the VOLUME – button and
button of the main unit, release the
button first, then release the VOLUME –
button.
Built-in
subwoofer
• The default setting is playback of the built-in
subwoofer.
• You can verify the current setting by turning the
unit on again from standby mode.
Note
You cannot use the built-in subwoofer and the external
subwoofer simultaneously.
Additional Information
2
TV remote control operation may be difficult if the unit
hides the sensor of your TV when beneath or under the
TV. Try the two solutions below and see whether this
solves the problem.
Press both the VOLUME + button and
button of the main unit, release the
button first, then release the VOLUME +
button.
The unit is turned on when switching the TV remote
control relay function on/off.
The CLEAR VOICE indicator lights up as the
following illustration. Check if the setting is correct.
(☞ P. 11)
1 Move the unit in all directions.
2 Remove the stands to lower the height of
the unit.
The CLEAR
VOICE indicator
(for 2 seconds
after the unit is
turned on)
Use a + driver to
remove the screws.
The unit will be
19 mm lower without
the stands.
On
Off
No light
Green
• The default setting is off.
• You can verify the current setting by turning the
unit on again from standby mode.
Notes
Note
Keep the stands and screws in a safe place for future use.
Using TV remote control relay
function
If you cannot solve the problem by the suggestions above,
follow the procedure below and use the TV remote
control relay function, which relays the TV remote
control signal received at the front of the unit to the
remote control sensor of your TV through the TV remote
control signal transmitter at the rear of the unit.
• Move the unit in all directions again if TV remote control
remains difficult.
• The TV remote control relay function is enabled even if
the unit is in standby mode.
Operate the unit by TV remote control
(TV remote control learning function)
You can use the TV remote control solely to operate by
having the unit learn the TV remote control operations.
You can operate the following functions by TV remote
control.
• Volume down
• Volume up
• Power on/standby mode
y
The remote
control sensor of
your TV
TV remote control signal transmitter
1
Set the unit to standby mode.
Some TV remote controls may not control these functions.
Use the remote control supplied with the unit in this case.
1
2
Set the unit and TV to standby mode.
Press both the INPUT button and
button of the main unit, release the
button first, then release the INPUT
button.
The unit enters the remote control
learning mode.
Flashes in
red
Continued to the next page. \
9 En
English
Operation by the TV remote control is
difficult (with unit beneath/under TV)
Additional Information
3
Press the button below of the main unit to
select the operation you want the unit to
learn.
Operation you
want the unit to
learn
The button
The Indicator
of the unit flashes in green
Volume down
VOLUME –
Volume up
VOLUME +
Removing all learned TV remote
control operations
Power on/standby
mode
4
Point your TV remote control at the
remote control sensor and press the
respective button twice or three times
until the indicator changes from flashing
green to lit green.
Press
(1 sec)
Notes
• The unit will automatically set to standby mode if the unit
in the remote control learning mode is left turned on for 5
minutes without any operation being performed.
• If learning fails, try again with your TV turned off. Note
that screen glare may disturb TV remote control learning.
Approx.
30 cm
(1 ft)
Indicator
1
2
4
Release the INPUT button of the main unit
when qD DTS indicator flashes.
Press the
button of the main unit for more than 3
seconds to finish the remote control learning mode, or
to have the unit learn operations of another TV
remote control.
Flashes
e.g.
Volume up
Success in learning
Fault in learning
The UNIVOLUME, CLEAR VOICE and
SURROUND indicators flash in green
simultaneously for about 3 seconds.
5
Repeat steps 3 and 4 to make the unit
learn the other operations.
6
Press the
button of the main unit for
more than 3 seconds to finish the remote
control learning mode.
Release the
button of the main unit when all the
indicators light up in green. The unit enters standby
mode.
10 En
Flashes in
red
Press the INPUT button of the main unit
again for more than 3 seconds.
Flashes
rapidly
Flashes
rapidly
Press both the INPUT
button and
button of the
main unit, release the
button first, then release the
INPUT button.
3
Release
(1 sec)
Press
(1 sec)
Set the unit to standby mode.
Resetting the unit
Should the unit freeze for any reason, this may be
remedied by initiating the factory settings.
1
2
Set the unit to standby mode.
Press and hold the
button of the main
unit for more than 3 seconds.
All the indicator flashes in green.
3
Release the
button of the main unit.
English
Operation indicators of the unit
The six indicators are placed in the above order, and their color and appearance are symbolically represented as below.
: Lights up in green
: Lights up in red
: Lights up in orange
: No light
: Flashes in green
: Flashes in red
Indication immediately after turning on the unit
Immediately after turning on the unit, the indicators show the state of the unit as below.
Playback of the
subwoofer (☞ P. 8)
TV remote control relay
function (☞ P. 9)
Built-in subwoofer
Off
External subwoofer
Off
Built-in subwoofer
On
External subwoofer
On
Indicators
Indication of the setting mode
The indicators show the setting mode as below.
Setting mode
Indicators
Audio delay control (☞ P. 8)
*
TV remote control learning (☞ P. 9)
*
* These indicators light up according to the state.
Normal indication
INPUT
: TV
SURROUND
CLEAR VOICE
UNIVOLUME
: Surround
playback
: Clear voice
on
: UniVolume
on
: Stereo
playback
: Clear voice
off
: UniVolume
off
qD DTS
: Dolby
Digital
: BD/DVD
: PCM
: STB
: DTS Digital
Surround
: Stand-by
: Mute
qPL II
:
Surround
playback of 2ch
stereo signal
input
:
• Stereo
playback
• Surround
playback of
surround signal
input
11 En
Troubleshooting
Refer to the chart below should the unit not function properly. If the problem you are experiencing is not listed below,
or if the instruction below does not help, set the unit to the standby mode, disconnect the AC power supply cable, and
contact the nearest authorized Yamaha dealer or service center. Check the below first.
1 The AC power supply cable of the unit, TV and external components (such as BD player) are firmly connected to
the AC wall outlet.
2 The power supply of the unit, TV and the external components (such as BD player) are turned on.
3 All cables are firmly connected to their respective jacks on each component.
Problem
Power turns on but
immediately shuts off.
Cause
Solution
The power cable may be connected improperly. Make sure the power cable is plugged into the
outlet firmly.
4
The unit may have received a strong electrical
shock, such as from a lightening bolt or
excessive static electricity.
—
Set the unit to standby mode, and then
disconnect the power cable. Wait for about 30
seconds, connect the power cable, and then turn
the unit on again.
The unit has an auto-sleep function, which will
automatically set to standby mode if the unit is
left turned on for 12 hours without any
operation being performed.
The speakers make no
sound.
Surround effect is not
achieved.
See
page
—
The volume may be set to minimum.
Adjust the volume level.
8
The mute function may be activated.
Press MUTE on the remote control to cancel the
mute function and adjust the volume.
8
The input source or input setting may be
incorrect.
Select the correct input source or input setting.
7
A surround mode is not selected.
Press SURROUND on the remote control to
play back the source in surround effect.
7
Adjust the volume level of the subwoofer.
8
No bass / The external
The volume of the subwoofer channel may be
subwoofer makes no sound. set to minimum level.
Opposite setting of subwoofer is selected.
Select collect setting of subwoofer.
The source does not contain low frequency
signals.
The cable between the unit and the subwoofer
not connected when selecting playback of the
external subwoofer.
8
—
Connect the unit and the external subwoofer by
using a subwoofer pin cable.
5
The volume level decreases The unit controls its volume within a certain
Reset the volume.
without any operation.
level to prevent the next playback from sudden
output at excessive volume.
8
This unit does not operate
properly.
—
The unit may receive a strong electrical shock, Set the unit to standby mode, and then
such as from a lightening bolt or excessive static disconnect the power cable. Wait for about 30
electricity, or drop in power supply.
seconds, connect the power cable, and then turn
on the unit again.
A digital or high-frequency The unit may be placed close to digital
equipment produces noises. equipment or high-frequency equipment.
Place the unit away from such equipment.
—
The remote control does not The unit may be outside the remote control
operate the unit.
operation range.
The operation range for the remote control of
the unit is within 6 m (20 ft).
6
The remote control sensor of the unit may be
exposed to direct sunlight or other lighting.
Change the lighting or reposition the unit.
—
The batteries may be worn out.
Replace the batteries.
6
The volume of the unit and TV Your TV itself received the signal from TV
Set the volume of your TV to minimum, or set
increases simultaneously.
remote control, having learned the operation of the audio output of your TV built-in speaker to
the unit.
off.
—
Adjust the volume by using the remote control
of the unit.
8
12 En
Troubleshooting
Cause
Solution
The volume, subwoofer and The adjustment has reached the maximum or
audio delay time is not
minimum.
adjustable.
The unit does not learn the
operation of TV remote
control.
See
page
8
The remote control sensor of the unit may be
exposed to direct sunlight or lighting.
Reposition the unit.
—
The screen glare of TV disturbs the remote
control signal.
Disconnect the power cable and perform the
remote control learning operation again.
—
The batteries of TV remote control may be worn Replace the batteries.
out.
—
The button of the unit was not pressed long
enough for the remote control learning
operation.
Press the button of TV remote control in the
order “press 1 second” → “release 1 second” →
“press 1 second”
9
The TV remote control is not available for
remote control learning.
Use the remote control of the unit.
9
The TV remote control is outside of the
operation range.
Point your TV remote control towards the
remote control sensor of the unit keeping a
distance of 30 cm (1 ft) between them.
9
The unit does not enter the remote control
learning mode.
Operate after checking that the INPUT
indicator is flashing in red.
9
The power state of the unit and of your TV is
opposite from the beginning.
Press the power button of TV remote control to
set your TV and the unit to standby mode after
pressing the power button of your TV itself and
of the unit to set both your TV and the unit to on.
9
Try to use the TV remote control relay function
again after repositioning the TV remote control
signal transmitter of the unit and the remote
control sensor of your TV.
9
Try to use the TV remote control relay function
again after adjusting the height of the unit by
removing or attaching its stands.
9
Something is between the unit and your TV.
Remove the obstruction.
—
The TV remote control relay function is not
activated.
Restart the unit and check the indicator status.
9
The TV remote control is not compatible with
the TV remote control relay function.
Place the unit (without the stands, for example)
so as not to hide the remote control sensor of
your TV.
9
You cannot use 3D glasses. The unit obstructs the 3D glasses transmitter of Check the position of 3D glasses transmitter of
your TV.
your TV by referring to the manual of your TV,
and move the unit to the position where there is
no obstruction.
—
The picture on your TV
screen becomes blurred or
distorted.
—
The power state of the unit
and of your TV is opposite.
(For example, though your
TV is on, the unit is in
standby mode.)
The TV remote control is out The unit and TV are too close/far from one
of work even if you use TV
another.
remote control relay
function.
The unit is too close to your CRT TV.
Move the unit away from your TV.
Contact your nearest authorized Yamaha dealer or service center if the following problem occurs.
Problem
Cause
The power of the unit
The protection circuit is activated.
immediately shuts off, and
the INPUT indicator flashes.
Solution
See
page
—
13 En
English
Problem
Specification
Amplifier section
Input Jacks
• Minimum RMS Output Power
Front Left and Right (1 kHz, 1% THD, 6 Ω)
....................................................................... 24 W + 24 W
Subwoofer (100 Hz, 1% THD, 3 Ω)........................... 48 W
• Maximum Power
Front Left and Right (1 kHz, 10% THD, 6 Ω)
....................................................................... 30 W + 30 W
Subwoofer (100 Hz, 10% THD, 3 Ω).........................60 W
• Optical ...................................................... 2 (TV,BD/DVD)
• Coaxial ................................................................... 1 (STB)
Speaker section
• Type
Front speaker ........................... Accoustic suspension type/
Non-magnetic shielding type
Subwoofer.................................................Bass reflex type/
Non-magnetic shielding type
• Driver
Front speaker .............................6.5 cm (2-1/2 in) cone × 2
Subwoofer........................................ 7.5 cm (3 in) cone × 2
• Impedance
Front speaker .................................................................6 Ω
Subwoofer......................................................................3 Ω
• Frequency Response (-10 dB, Stereo mode)
Front speaker .......................................... 150 Hz to 20 kHz
Subwoofer................................................. 50 Hz to 150 Hz
This system employs new technologies and algorithms that
make it possible to achieve 7-channel surround sound with
only front speakers, and without using wall reflections.
Manufactured under license from Dolby Laboratories. Dolby,
Pro Logic and the double-D symbol are trademarks of Dolby
Laboratories.
14 En
Output Jacks
• Subwoofer ......................................................................... 1
• System Connector (for subwoofer power interlock)......... 1
General
•
•
•
•
Power Supply .......................................... AC 120 V, 60 Hz
Power Consumption ....................................................22 W
Standby Power Consumption.................... Less than 0.5 W
Dimensions (W × H × D)
With stands.......................................890 × 107 ×120.5 mm
(35-1/8 × 4-1/4 × 4-3/4 in)
• Weight ........................................................ 4.2 kg (9.3 lbs.)
* Specifications are subject to change without notice.
“DTS” and “DTS Digital Surround” are registered
trademarks of DTS, Inc.
“UniVolume” is a trademark of Yamaha Corporation.
© 2011 Yamaha Corporation
Printed in Malaysia ZA81330
