Samsung DVD-HD948 Instruction manual

KDC-X995
KDC-BT948HD
CD-RECEIVER
INSTRUCTION MANUAL
Before reading this manual, click the button below to check the latest edition and the
modified pages.
Check the latest edition
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from
your new CD-receiver.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the
space provided below. Refer to the model and serial numbers whenever you call upon your Kenwood dealer for
information or service on the product.
Model KDC-X995/ KDC-BT948HD Serial number
US Residents Only
Register Online
Register your Kenwood product at www.Kenwoodusa.com
© 2010 Kenwood Corporation All Rights Reserved.
11FLIP_IM330_Ref_K_en_00
Contents
Before use
4
Component names and functions
6
General operation
7
Before Using
Common Operation
Menu List Operation
iPod/iPhone Operation
8
Basic Operation
Selecting a song by browsing iPod
Play Mode
iPod Setting
Selecting the Search mode
Direct Search
Related Search
Alphabet Search
Skip Search
My Playlist
PANDORA® Operation
14
Basic Operation
Station Search
Bookmark Registration
Search and New Station Registration
Deletion of Station
USB device Operation
16
Basic Operation
Music Search
Play Mode
Basic Operation of Disc Changer (Optional)
Direct Music Search
Direct Disc Search
2 |
KDC-X995/ KDC-BT948HD
Operation of hands-free phoning
26
Getting Started
Receiving a Call
During a Call
Call Waiting
Other Functions
Making a Call
Speed Dialing (Preset Dial)
Calling a Number in the Phone Book
Calling a Number in the Call log
Dial a Number
Make a Voice Dialing Call
Registering to the Preset Dial Number List
Display of Phone Number type (category)
30
Basic Operation
Display Setting
Customization of 5-line Display Mode & 3-line
Display Mode & iPod-like Display Mode
Customization of Spectrum Analyzer Display Mode
Customization of Clock Display Mode
Illumination Color Selection
Auxiliary Input Display Setting
Clock and Other Functions
19
22
Basic Operation
Station Preset Memory
Auto Memory Entry
Preset Tuning
HD Radio™ Setting
Direct Access Tuning
iTunes Tagging
Display Settings
Basic Operation
File Search
Play Mode
USB Setting
Skip Search
Direct Music Search
Music CD/ Audio file Operation
HD Radio™ Tuner Operation
Clock & Date display type setting
Clock Adjustment
Date Adjustment
Dual clock city setting
Initial Settings
Demonstration mode Setting
Theft Deterrent Faceplate
36
Audio Adjustments
40
Audio Control
Preset Equalizer curve Select
Manual Equalizer Control
Listening Position Selection
Listening Position Fine Adjustments
Dual Zone System
DSP Setup
44
Car Type Selection
Speaker Setting
Car Type Fine Adjustments
X’Over Setting
Audio Preset Memory
Audio Preset Recall
Bluetooth Setup
48
Easy pairing function
Bluetooth Setting
Registering Bluetooth device
Registering PIN Code
Selecting the Bluetooth device You Wish to
Connect
Deleting a Registered Bluetooth device
Downloading the Phone Book
Adding a Voice Dialing Command
Setting a Voice Command for Category
SMS (Short Message Service)
Basic Operations of remote control
58
Appendix 60
About Audio file
iPod/iPhone that can be connected to this unit
About PANDORA® internet radio
About USB device
About “KENWOOD Music Editor”
About the Cell-Phone
About Satellite Radio tuner (Optional)
Menu List
City list
Accessories/ Installation Procedure
67
Connecting Wires to Terminals
68
Installation/Removing the Unit
69
Troubleshooting Guide
71
Specifications
74
54
Downloading the SMS
SMS (Short Message Service)
Satellite Radio Tuner Control (Optional) 56
Basic Operation
Satellite Radio Setting
Category and Channel Search
Preset Memory
Preset Tuning
Channel Scan
Direct Access Tuning
English |
3
Before use
2WARNING
To prevent injury or fire, take the following
precautions:
To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools) inside
the unit.
Do not use this unit before canceling
Demonstration mode!
This unit is initially set on the Demonstration mode.
When using this unit for the first time, cancel the
Demonstration mode. Refer to <Before Using> (page
7).
How to reset your unit
If this unit or the connected unit (auto disc changer,
etc.) fails to operate properly, press the Reset button.
The unit returns to factory settings when the Reset
button is pressed.
Reset button
Cleaning the Unit
If the faceplate of this unit is stained, wipe it with a
dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe the stain off with
a cloth moistened with neutral cleaner, then wipe it
again with a clean soft dry cloth.
¤
• Applying spray cleaner directly to the unit may affect its
mechanical parts. Wiping the faceplate with a hard cloth or
using a volatile liquid such as thinner or alcohol may scratch
the surface or erases characters.
Unit and Faceplate Terminals
• To prevent deterioration, do not touch the terminals
of the unit and faceplate with your fingers.
• If the terminals on the unit or faceplate get dirty,
wipe them with a clean soft dry cloth.
4 |
KDC-X995/ KDC-BT948HD
Lens Fogging
When you turn on the car heater in cold weather,
dew or condensation may form on the lens in the
CD player of the unit. Called lens fogging, this
condensation on the lens may not allow CDs to play.
In such a situation, remove the disc and wait for the
condensation to evaporate. If the unit still does not
operate normally after a while, consult your Kenwood
dealer.
Notes
• If you experience problems during installation,
consult your Kenwood dealer.
• When you purchase optional accessories, check with
your Kenwood dealer to make sure that they work
with your model and in your area.
• Characters that conform to ISO 8859-1 can be
displayed.
• The Radio Data System feature won’t work where
the service is not supported by any broadcasting
station.
• In this document, the description indicator will
light means a status is displayed. Refer to <Basic
Operation> (page 30) for the details of the status
display.
• The illustrations of the display and the panel
appearing in this manual are examples used to
explain more clearly how the controls are used.
Therefore, what appears on the display in the
illustrations may differ from what appears on the
display on the actual equipment, and some of the
illustrations on the display may be inapplicable.
Handling CDs
• Do not touch the recording surface of the CD.
• Do not stick tape etc. on the CD, or use a CD with
tape stuck on it.
• Do not use disc type accessories.
• Clean from the center of the disc and move
outward.
• When removing CDs from this unit, pull them out
horizontally.
• If the CD center hole or outside rim has burrs,
use the CD only after removing the burrs with a
ballpoint pen etc.
CDs that cannot be used
• CDs that are not round cannot be used.
• CDs with coloring on the recording surface or CDs
that are dirty cannot be used.
• This unit can only play the CDs with
.
This unit may not correctly play discs which do not
have the mark.
• You cannot play a CD-R or CD-RW that has not
been finalized. (For the finalization process refer to
your CD-R/CD-RW writing software, and your CD-R/
CD-RW recorder instruction manual.)
• 3 inch CD cannot be used. Attempt to insert using
an adapter can cause malfunction.
English |
5
Component names and functions
1
2
3
10
11
5
4
6
AUX
7
8
9
1 Release button
To drop the faceplate down to open and CD can be
inserted or ejected (press the button).
2 [MENU] button
To select a song or set functions. See <Menu List
Operation> (page 7).
3 [DISP] button
To change display item (press the button).
4 [VOL] knob
To adjust volume (turn the knob).
To select menu list item (turn and press the knob). See
<Menu List Operation> (page 7) for details.
Enters Play mode Menu (press the button at least 1
second).
5 [SEARCH MODE] button
To enter Search mode (iPod), move between folders
(Audio file), etc. For more details, see operations of
each source described in page 8 or later.
6 Microphone
The microphone for the hands free phone is supplied.
When your voice cannot be recognized due to the
low microphone volume or noises in the vehicle,
adjust the microphone settings by <Bluetooth
Setting> (page 48).
7 Auxiliary Input Terminal
Portable audio device can be connected with the
mini-plug (3.5 mm (1/8”) ø).
• Use the mini-plug cable which is stereo type and does not
have any resistance.
6 |
KDC-X995/ KDC-BT948HD
12
13
14
8 [SRC] button
To turn on this unit and select the Source (press the
button).
To turn off this unit (press the button at least 1
second).
9 [4] / [¢] buttons
To select station, song and setting items. (press the
button).
10 [38] button
To start or interrupt playback for CD, audio file, and
iPod (press the button).
11 [SCRL] button
The displayed text scrolls (press the button).
To enter “Clock & Date” settings when Clock Display
mode is selected in the Display Setting mode (press
the button).
12 Display window
13 [ ] button
To enter Bluetooth mode (press the button).
To enter Bluetooth easy pairing mode (press the
button at least 1 second). See <Easy pairing function>
(page 48).
14 USB Terminal
A USB device or an iPod can be connected.
General operation
mode when the messages “To cancel Demo
press the volume knob” are displayed (approx. 15
seconds).
2 Turn the [VOL] knob to select “YES” and press the
[VOL] knob.
⁄
• Demonstration mode can also be cancelled in “DEMO
Mode” of Menu List mode. Refer to <Demonstration mode
Setting> (page 38).
Common Operation
Power and source select
Turns the power ON by pressing the [SRC]
button.
When the power is ON, select a source.
• SRC Select mode 1: Pressing the [SRC] button
each time switches between sources.
HD Radio (“HD RADIO”) ➜ USB (“USB”) or iPod
(“iPod”) ➜ Pandora (“Pandora”) ➜ CD (“CD”) ➜
Auxiliary input (“AUX”) ➜ Standby (“STANDBY”)
➜ HD Radio...
• SRC Select mode 2: Press the [SRC] button and
then turn the [VOL] knob. To determine the
selected source, press the [VOL] knob.
Keeping pressing the [SRC] button for at least 1
second turns the power OFF.
⁄
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Function items vary from source to source. For a list
of the function items. Refer to <Menu List> (page 62).
2 Enter Menu List mode
Press the [MENU] button.
3 Select the setting item
Turn the [VOL] knob and press it when the
desired item is displayed.
Repeat the operation until your desired setup item
is selected.
✍✍Press the [MENU] button to return to the
previous item.
Operation example:
Music
1
2
4
3
2
1 [VOL]
2 [VOL]
3 [MENU]
4 [MENU]
3
PlayLists
My Best 25
1
…
1 Press the [VOL] knob to quit the demonstration
The basic operating procedure for using this
function is described below. The individual function
items are covered in the operating procedures.
Artists
Albums
…
Exit of the Demonstration Mode
Turn off the demonstration mode when you use it
for the first time after installation.
Menu List Operation
1 sec.
Play Mode
…
Before Using
In this manual, the above selection is indicated as
Select “Music” > “Playlists” > “My Best 25”.
4 Make a setting
• W
hen the “ PUSH ” icon is displayed (at the
right edge of the display)
Turn the [VOL] knob to select a setting value,
and then press the [VOL] knob.
• When the “ PUSH ” icon is not displayed
Press the [4] or [¢] button to select a
setting value.
• The SRC Select mode can be set in “SRC Select” of <Initial
Settings> (page 38).
• Auxiliary input source is initially set to “OFF”. Set “Built in
AUX” described in <Initial Settings> (page 38) to “ON”.
• When an optional accessory is connected, the source name
for each device appears.
• When connection of the iPod is recognized, the source
display changes from “USB” to “iPod”.
5 Exit Menu List mode
Volume
Turning the [VOL] knob adjusts the sound
volume.
⁄
Press the [MENU] button for at least 1 second to
return to the first hierarchy. Press the [MENU]
button in the first hierarchy to exit the Menu
List mode.
• You cannot set the item with the “ ” icon displayed.
English |
7
iPod/iPhone Operation
SRC MENU VOL
4 38 ¢
DISP
SEARCH MODE
Playing iPod
• Connect an iPod
When connected, the source is switched
automatically and a song starts playing.
• Select iPod source
Press the [SRC] button.
Select the “iPod” display.
Song Select
Press the [4] or [¢] button.
Fast Forwards or Fast Backwards
Hold down the [4] or [¢] button.
Pause and Play
Press the [38] button to pause or resume
playback.
Remove iPod
Select a source other than iPod and Pandora, and
the iPod can be removed safely.
Selecting a song by browsing iPod
Items
Playlists
Artists
Albums
Songs
Podcasts
Genres
Composers
1 Select iPod source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music”.
8 |
not use the KCA⁄ Do
iP102 with an extension
SCRL
Basic Operation
Display
“Music”
“Playlists”
“Artists”
“Albums”
“Songs”
“Podcasts”
“Genres”
“Composers”
KCA-iP102 (optional
accessory) is required to
connect an iPod.
KDC-X995/ KDC-BT948HD
cord.
4 Select a song
Operation type
Move between items
Select an item
High Speed Search
Return to previous item
Return to Top menu
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [DISP] or [SCRL] button to scroll
up or down by a page.
Press the [DISP] or [SCRL] button for at
least 1 second to continuously scroll up or
down at high speed. Press the button again
to stop scrolling.
Press the [MENU] button.
Press the [MENU] button for at least 1
second.
✍✍For example: Searching by Artist name.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music” > “Artists” > Artist name > Album
name > Song title
Cancelling Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• The unit memorizes the position where you have
found a song in the Search mode. When you enter the
Menu List mode after searching a song, the memorized
position is displayed. Press the [MENU] button for at least
1 second to move to the first hierarchy, select a Menu
item, and set it’s parameters.
• Characters which cannot be displayed are left blank. If
non of the characters can be displayed, the browse item
name and digits are displayed.
Items
Playlists
Artists
Albums
Songs
Display
“PLIST***”
“ART***”
“ALB***”
“PRGM***”
Items
Podcasts
Genres
Composers
Display
“PDCT***”
“GEN***”
“COM***”
Play Mode
iPod Setting
You can select a Play Mode, such as Random play
and Repeat play.
You can select following iPod Setting items.
1 Select iPod source
2 Enter Play Mode Menu
Press the [VOL] knob for at least 1 second.
✍✍You can also select from “Play Mode” in Menu
List mode.
3 Select the Play Mode
Turn the [VOL] knob.
Display
“iPod by Hand”
“Folder Random”
“All Random”
“File Repeat”
Overview
When set to “ON”, allows you to operate iPod
with the control on the iPod.
“ON”/ “OFF”
When set to “ON”, plays the music in the folder
randomly.
“ON”/ “OFF”
When set to “ON”, plays all songs in iPod
randomly.
“ON”/ “OFF”
When set to “ON”, plays the music repeatedly.
“ON”/ “OFF”
4 Make a setting
Press the [4] or [¢] button.
5 Exit Play Mode Menu
Press the [MENU] button.
Remarks
• All Random
• The time required to turn on the all random function
may become longer depending on the number of songs
in iPod.
• Turning on the all random function changes the iPod
browse item to “Songs”. This browse item will not be
changed even if the all random function is turned off.
• If the browse item is changed to search for music while
the all random function is on, the all random function is
turned off and the songs in the browse item are played
at random.
• iPod by Hand (iPod Control by Hand Mode)
Allows you to operate iPod with the control on the iPod.
1 Select iPod source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings”.
4 Select the setting item
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Settings”
“Skip Search”
“Delete My
Playlist”
Overview
Sets the ratio of skip performed with <Skip
Search> (page 12).
“0.5%”/ “1%”/ “5%”/ “10%”
Deletes the registered My Playlist.
Refer to <Deleting a Song from the Playlist>
(page 12) for the operation.
“One”/ “All” ➜ “Yes”/ “No”
(
: Factory setting)
5 Make a setting
• W
hen the “ PUSH ” icon is displayed (at the
right edge of the display)
Turn the [VOL] knob to select a setting value,
and then press the [VOL] knob.
• When the “ PUSH ” icon is not displayed
Press the [4] or [¢] button to select a
setting value.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• The setting of “Skip Search” in <iPod Setting> (page 9)
and that in <USB Setting> (page 17) are always the same.
Changing the setting of one reflects the other.
⁄
• In the iPod Control by Hand Mode, iPod cannot be
operated using this unit.
• This mode is not compatible with music information
display. The display will show “iPod by Hand Mode”.
• iPod can be operated when it conforms to the iPod
control function.
English |
9
iPod/iPhone Operation
Selecting the Search mode
Direct Search
You can select the most suited search method for
the desired song from 4 types of the Search mode.
You can quickly search the desired song by
specifying its Search item (artist, album, etc.) and
character.
Normal playing
Display
“Direct Search”
“Related Search”
“Recall My Playlist”
“Delete My Playlist”
“Register My P-list”
Overview
You can quickly search the desired song by
specifying its Search item (artist, album, etc.)
and character.
Refer to <Direct Search> (page 10).
Searches for music of the same artist or genre
as the one being played.
Refer to <Related Search> (page 11).
Registers a song to My Playlist and play it.
Refer to <My Playlist> (page 12).
Browsing
Display
“Direct Search”
“Alphabet Search”
“Skip Search”
“Register My P-list”
Overview
You can quickly search the desired song by
specifying its Search item (artist, album, etc.)
and character.
Refer to <Direct Search> (page 10).
You can select an alphabetic character from
the list in the Search item (artist, album, etc.)
selected now.
Refer to <Alphabet Search> (page 11).
The number of songs to be skipped is
determined by the ratio of the total number of
songs in the list which is selected now.
Refer to <Skip Search> (page 12).
Registers a song to My Playlist.
Refer to <My Playlist> (page 12).
1 Select iPod source
Pressing the [SRC] button repeatedly switches
source.
Select the “iPod” display.
2 Enter Search mode
Press the [SEARCH MODE] button.
3 Select the Search mode
Turn the [VOL] knob.
4 Start the search mode
Press the [VOL] knob.
Cancelling Search mode
Press the [SEARCH MODE ] button.
10 |
KDC-X995/ KDC-BT948HD
1 Select iPod source
2 Press the [SEARCH MODE] button.
3 Enter Direct Search mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Direct Search”.
4 Select the Search item
Turn the [VOL] knob and press it when the
desired Search item is selected.
Display
Items
Display
Items
“PLAYLISTS”
Playlists
“PODCASTS”
Podcasts
“ARTISTS”
Artists
“GENRES”
Genres
“ALBUMS”
Albums
“COMPOSERS” Composers
“SONGS”
Songs
5 Select the character to be searched for
Operation type
Move between items
Select an item
Move to the next column
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [4] or [¢] button.
Up to 3 characters can be entered.
6 Determine the selected character
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “DONE”.
Start search. When search is completed, the music
search mode is selected again at the selected
character position.
After this step, you need to browse. See step 4 of
<Selecting a song by browsing iPod> (page 8) to
select a song.
Cancelling the Direct Search
Press the [SEARCH MODE] button.
⁄
• Characters that can be entered are alphabetical
characters (A to Z), numerical characters(0 to 9), and “ * ”.
• “ * ” indicates characters other than alphabetical and
numerical characters. You cannot enter any more
characters when entering “ * ” in the first character
position.
• If the first character string begins with an article “a”, “an”,
or “the” in the Direct Search mode, it is searched for in
defiance of the article.
Related Search
Alphabet Search
Searches for music of the same artist or genre as the
one being played.
You can select a song by alphabet. This function
searches songs whose name contain the specified
character(s) in the list of the selected Search item
(artist, album, etc).
1 Play the music in iPod
2 Press the [SEARCH MODE] button.
3 Enter Related Search mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Related Search”.
4 Select the Search item
Turn the [VOL] knob and press it when the
desired Search item is selected.
Display
“Search Artist”
“Search Album”
Searches music
Displays the album of the same artist.
Displays music in the album in which the one
being played is included.
“Search Genre”
Displays the artist of the same genre.
“Search Composer” Displays the album including music created by the
same Composer.
After this step, you need to browse. See step 4 of
<Selecting a song by browsing iPod> (page 8) to
select a song.
Cancelling the Related Search
Press the [SEARCH MODE] button.
⁄
• Related search cannot be performed while playing the
Podcast.
• When the music being played has no information on
browsing items or no music was found, “Not Found” is
displayed.
1 Select iPod source
2 Enter browsing mode
Press the [MENU] button.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music” > item.
3 Enter Alphabet Search mode
Turn the [VOL] knob fast. Or, press the [SEARCH
MODE] button and turn the [VOL] knob to
select “Alphabet Search”.
4 Search for item
Operation type
Select the character
Select an item
Return to previous item
Operation
Press the [DISP] or [SCRL] button./
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [MENU] button.
After this step, you need to browse. See step 4 of
<Selecting a song by browsing iPod> (page 8) to
select a song.
Cancelling the Alphabet Search
Press the [MENU] button.
⁄
• The time of search by alphabet may become long
depending on the number of songs or items in iPod.
• If the first character string begins with an article “a”, “an”,
or “the” in the Alphabet Search mode, it is searched for in
defiance of the article.
English |
11
iPod/iPhone Operation
Skip Search
My Playlist
You can scroll up or down according to the number
of the selected Search items so that you can quickly
switch the display position.
Allows you to register your favorite songs in the
Playlist of this unit. You can register up to 10 songs
in the Playlist.
1 Select iPod source
2 Enter browsing mode
Registering Songs in the Playlist
Press the [MENU] button.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music” > item.
3 Press the [SEARCH MODE] button.
4 Enter Skip Search mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Skip Search”.
5 Search for item
Operation type
Move between items
Select an item
Skip Search
Sets the ratio of skip
performed
Return to previous item
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [DISP] or [SCRL] button.
Keep pressing the button for 3 seconds or
longer skips songs at 10% irrespective of
the setting.
Press the [4] or [¢] button.
Press the [MENU] button.
After this step, you need to browse. See step 4 of
<Selecting a song by browsing iPod> (page 8) to
select a song.
Cancelling the Skip Search
Press the [SEARCH MODE] button.
⁄
• Set the ratio with “Skip Search” in <iPod Setting> (page
9).
1 Play the song you want to register
2 Press the [SEARCH MODE] button.
3 Register the song
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Register My Playlist”.
“## Stored (Registration number)” is displayed.
⁄
• Make a Playlist from the songs stored in one iPod. If you
attempt to register a song stored in a different iPod,
”No Information” appears and then ”Delete My Playlist”
appears. Select “Yes” to delete the Playlist when you want
to remake it.
• The song displayed in the Music Search mode can be
registered in the same manner. For how to use the music
search function, refer to <Selecting a song by browsing
iPod> (page 8).
• If you attempt to register the eleventh song, ”Memory
Full” appears and you cannot register it accordingly. To
register the song, delete an unnecessary song.
• Do not register Podcasts. Songs you do not want to
register may be registered, or playback may not be
carried out correctly.
Playing the Song in the Playlist
1 Press the [SEARCH MODE] button.
2 Enter My Playlist mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Recall My Playlist”.
3 Play the song in the Playlist
Turn the [VOL] knob and press it when the
desired item is displayed.
Select the song you want to play.
⁄
• Turning ACC OFF or the power OFF cancels the My
Playlist mode.
• The ending of a song may be cut unless the song has a
silence of 1 second or longer at the end.
• Random play cannot be performed during playback of a
song in the Playlist.
Deleting a Song from the Playlist
1 Press the [SEARCH MODE] button.
12 |
KDC-X995/ KDC-BT948HD
2 Enter Delete Playlist mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Delete My Playlist”.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select ”Delete One” or ”Delete All”.
Selecting “Delete All” moves to step 5 and all songs
are deleted.
4 Turn the [VOL] knob and press it when the
desired item is displayed.
Select the song you want to delete.
5 Turn the [VOL] knob and press it when the
desired item is displayed.
Select ”Yes”.
“Completed” is displayed.
⁄
• You can also delete all songs from the Playlist by
selecting “Delete My Playlist” described in <iPod Setting>
(page 9).
• If you connect the different iPod from one registered to
My Playlist, “Delete One” and “Delete All” will not appear
and all songs be deleted.
English |
13
PANDORA® Operation
SRC MENU VOL
4 38 ¢
DISP
KCA-iP102 (optional
accessory) is required to
connect an iPhone.
not use the KCA⁄ Do
iP102 with an extension
SCRL
cord.
Basic Operation
Station Search
Listening to PANDORA®
You can select the station you want to listen to from
your station list.
• Connect an iPhone
Connecting the iPod with the Pandora
application running will switch the source
automatically to start broadcasting from the
registered station.
• Select Pandora source
Press the [SRC] button.
Select the “Pandora” display.
✍✍If the Pandora application is not running, “Check
Device” is displayed.
⁄
• To use the Pandora source, set “Pandora Source” in
<Initial Settings> (page 38) to “ON”.
• If no station has been selected, broadcasting does not
start.
Pause and Play
Press the [38] button to pause or resume
playback.
Thumbs up
Press the [DISP] button for at least 1 second.
“ ” is displayed.
1 Select Pandora source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Stations”.
A station list is displayed.
4 Switch between the station list display mode.
Press the [4] or [¢] button.
Display
“Alphabet Sort”
“Date Sort”
Overview
Stations are displayed in alphabetical order..
Stations are displayed in date order.
5 Select a station
Turn the [VOL] knob and press it when the
desired item is displayed.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Thumbs down
Press the [SCRL] button for at least 1 second.
“ ” is displayed.
Bookmark Registration
Song skip
Press the [¢] button.
✍✍If the skip count limit specified by Pandora is
exceeded, “No skips remaining” is displayed.
1 Select Pandora source
2 Enter Menu List mode
Remove iPhone
Select a source other than Pandora and iPod, and
the iPod can be removed safely.
14 |
KDC-X995/ KDC-BT948HD
You can register the current song information or
artist information in Bookmark.
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Bookmarks” > “Bookmark Song” (to
register song information) or “Bookmark Artist”
(to register artist information).
4 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• This unit allows you to bookmark songs and/or artists in
your personalized PANDORA® account. The bookmarks
will not be available for review on the unit but will be
available in your PANDORA® account.
Search and New Station Registration
You can search for the desired station by specifying
its character. You can register the displayed station
as a new station.
1 Select Pandora source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “New Stations”.
4 Select the character to be searched for
Operation type
Move between items
Select an item
Move to the next column
Return to previous item
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [4] or [¢] button.
Press the [MENU] button.
Deletion of Station
You can delete registered station information.
1 Select Pandora source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Station Delete”.
4 Switch between the station list display mode.
Press the [4] or [¢] button.
Display
“Alphabet Sort”
“Date Sort”
Overview
Stations are displayed in alphabetical order.
Stations are displayed in date order.
5 Turn the [VOL] knob and press it when the
desired item is displayed.
Select the station you want to delete.
6 Turn the [VOL] knob and press it when the
desired item is displayed.
Select ”YES”.
“Completed” is displayed.
Cancelling the Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Up to 3 characters can be entered.
5 Determine the selected character
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “DONE”.
Start search.
After this step, you need to Search. See step 4 of
<Station Search> (page 14) to select a station.
Cancelling Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• Characters that can be entered are alphabetical
characters (A to Z), numerical characters(0 to 9), and
other symbols (“ & ”, “ . ”, “ ‘ ”, “ - ”, “ # ” ,“ + ”, “ ! ”, “ $ ”, “ “ ”).
English |
15
USB device Operation
SRC MENU VOL
DISP
4 38 ¢
SCRL
SEARCH MODE
When connecting the
USB device, usage of the
CA-U1EX (MAX : 500 mA)
(option) is recommended.
Basic Operation
File Search
Playing USB device
Selecting the file you want to listen to from the
device being played now.
• Connect a USB device
When connected, the source is switched
automatically and a song starts playing.
• Select USB source
Press the [SRC] button.
Select the “USB” display.
Moving to the next folder
Press the [SEARCH MODE] button.
Song Select
Press the [4] or [¢] button.
Fast Forwards or Fast Backwards
Hold down the [4] or [¢] button.
⁄
• No sound is output while playing audio file.
USB device
Display
“Music”
Items
Folder or file name list.
Music Editor media
Display
“Music”
“Playlists”
“Artists”
“Albums”
“Songs”
“Genres”
Items
Playlists
Artists
Albums
Songs
Genres
1 Select USB source
2 Enter Menu List mode
Press the [MENU] button.
Pause and Play
Press the [38] button to pause or resume
playback.
3 Turn the [VOL] knob and press it when the
Remove USB device
Select a source other than the USB, and the USB
device can be removed safely.
4 Select a file
desired item is displayed.
Select “Music”.
Operation type
Move between items
Select an item
High Speed Search
Return to previous item
Return to Top menu
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [DISP] or [SCRL] button to scroll
up or down by a page.
Press the [DISP] or [SCRL] button for at
least 1 second to continuously scroll up or
down at high speed. Press the button again
to stop scrolling.
Press the [MENU] button.
Press the [MENU] button for at least 1
second.
✍✍For example: Searching for ¡".
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music” > 1 > 2 > ¡"
16 |
KDC-X995/ KDC-BT948HD
1
¡!
USB Setting
2
You can select following USB Setting items.
¡"
¡#
Cancelling Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• When you search a song in the File Search mode, the
unit memorizes the position of the song being played
after the search. To set a different Menu item after
searching a song, press the [MENU] button for at least 1
second to move to the first hierarchy.
1 Select USB source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings”.
4 Select the setting item
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Settings”
“Skip Search”
Play Mode
You can select a Play Mode, such as Random play
and Repeat play.
1 Select USB source
2 Enter Play Mode
3 Select the Play Mode
“All Random”
“File Repeat”
“Folder Repeat”
(
: Factory setting)
Press the [4] or [¢] button.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
Turn the [VOL] knob.
“Folder Random”
Sets the ratio of skip performed with <Skip
Search> (page 18).
“0.5%”/ “1%”/ “5%”/ “10%”
5 Make a setting
Press the [VOL] knob for at least 1 second.
✍✍You can also select from “Play Mode” in Menu
List mode.
Display
“File Scan”
Overview
Overview
When set to “ON”, plays the intro of the music in
the folder successively.
“ON”/ “OFF”
When set to “ON”, plays the music in the folder
randomly.
“ON”/ “OFF”
When set to “ON”, plays all songs in the USB
device randomly.
“ON”/ “OFF”
When set to “ON”, plays the music repeatedly.
“ON”/ “OFF”
When set to “ON”, plays the music in the folder
repeatedly.
“ON”/ “OFF”
(
• The setting of “Skip Search” in <iPod Setting> (page 9)
and that in <USB Setting> (page 17) are always the same.
Changing the setting of one reflects the other.
• This operation is effective only for the files registered in
the database created with KENWOOD Music Editor.
: Factory setting)
4 Make a setting
Press the [4] or [¢] button.
5 Exit Play Mode
Press the [MENU] button.
English |
17
USB device Operation
Skip Search
Function of remote control
You can scroll up or down according to the number
of the selected Search items so that you can quickly
switch the display position.
Searching the music by entering the file number.
1 Select USB source
2 Enter File Search mode
Press the [MENU] button.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music” > item.
3 Enter Skip Search mode
Press the [SEARCH MODE] button.
4 Search for music
Operation type
Move between items
Select an item
Skip Search
Sets the ratio of skip
performed
Return to previous item
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [DISP] or [SCRL] button.
Keep pressing the button for 3 seconds or
longer skips songs at 10% irrespective of
the setting.
Press the [4] or [¢] button.
Press the [MENU] button.
After this step, see step 4 of <File Search> (page 16)
to select a song.
Cancelling the Skip Search
Press the [SEARCH MODE] button.
⁄
• This operation is effective only for the files registered in
the database created with KENWOOD Music Editor.
• Set the ratio with “Skip Search” in <USB Setting> (page 17).
18 |
KDC-X995/ KDC-BT948HD
Direct Music Search
1 Enter Direct Music Search mode
Press the [DIRECT] button on the remote
control.
2 Enter the music number
Press the number buttons on the remote
control.
3 Search the music
Press the [4] or [¢] button.
Cancelling Direct Music Search
Press the [DIRECT] button.
⁄
• Direct Music Search cannot be performed during playing
of “Music Editor” media, Random play, or scan play.
Music CD/ Audio file Operation
Release
MENU VOL
DISP
SEARCH MODE
Fast Forwards or Fast Backwards
Hold down the [4] or [¢] button.
⁄
• No sound is output while playing audio file.
SRC 4 38 ¢
SCRL
Pause and Play
Press the [38] button to pause or resume
playback.
Basic Operation
Function of Internal CD source
Drop open the faceplate
Press the Release button.
Selecting the music you want to listen to from the
disc being played now.
⁄
• Push the faceplate on the left side, and return it to its
former position.
Disc play
• A disc inserted.
When inserted, the source is switched
automatically and a song is starts playing.
When a CD is inserted, the “CD-IN” indicator
is ON.
Music Search
Display
“Music”
Overview
Track list (Music CD) / Folder or file name list
(Audio file)
1 Select CD source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Music”.
4 Search for music
Operation type
Move between items
Select an item
High Speed Search
• Select CD source
Press the [SRC] button.
Select the “CD” display.
Disc ejection
Press the [0] button.
Moving to the next folder
Press the [SEARCH MODE] button.
⁄
• This operation can be performed only for the Audio file.
Return to previous item
Return to Top menu
Operation
Turn the [VOL] knob.
Press the [VOL] knob.
Press the [DISP] or [SCRL] button to scroll
up or down by a page.
Press the [DISP] or [SCRL] button for at
least 1 second to continuously scroll up or
down at high speed. Press the button again
to stop scrolling.
Press the [MENU] button.
Press the [MENU] button for at least 1
second.
Cancelling Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Song Select
Press the [4] or [¢] button.
English |
19
Music CD/ Audio file Operation
Play Mode
“Track Repeat”
You can select a Play Mode, such as Random play
and Repeat play.
“Disc Repeat”
1 Select CD source
2 Enter Play Mode
When set to “ON”, plays the music repeatedly.
“ON”/ “OFF”
When set to “ON”, plays the music on the disc
repeatedly.
“ON”/ “OFF”
(
Press the [VOL] knob for at least 1 second.
✍✍You can also select from “Play Mode” in Menu
List mode.
: Factory setting)
4 Make a setting
Press the [4] or [¢] button.
5 Exit Play Mode
Press the [MENU] button.
3 Select the Play Mode
Turn the [VOL] knob.
Music CD source
Display
“Track Scan”
“Disc Random”
“Track Repeat”
Overview
When set to “ON”, plays the intro of the music on
the disc successively.
“ON”/ “OFF”
When set to “ON”, plays the music on the disc
randomly.
“ON”/ “OFF”
When set to “ON”, plays the music repeatedly.
“ON”/ “OFF”
(
: Factory setting)
Audio file source
Display
“File Scan”
“Folder Random”
“All Random”
“File Repeat”
“Folder Repeat”
Overview
When set to “ON”, plays the intro of the music on
the folder successively.
“ON”/ “OFF”
When set to “ON”, plays the music on the disc
randomly.
“ON”/ “OFF”
When set to “ON”, plays all songs in the disc
randomly.
“ON”/ “OFF”
When set to “ON”, plays the music repeatedly.
“ON”/ “OFF”
When set to “ON”, plays the music on the folder
repeatedly.
“ON”/ “OFF”
(
: Factory setting)
Disc changer source (Optional)
Display
“Track Scan”
Overview
When set to “ON”, plays the intro of the music on
the disc successively.
“ON”/ “OFF”
“Disc Random”
When set to “ON”, plays the music on the disc
randomly.
“ON”/ “OFF”
“Magazine Random” When set to “ON”, plays the music in the disc
changer randomly.
“ON”/ “OFF”
20 |
KDC-X995/ KDC-BT948HD
Basic Operation of Disc Changer
(Optional)
Select CD changer source
Press the [SRC] button.
Select the “CD CHANGER” display.
Moving to the next disc
Press the [SEARCH MODE] button.
Song Select
Press the [4] or [¢] button.
Fast Forwards or Fast Backwards
Hold down the [4] or [¢] button.
Pause and Play
Press the [38] button to pause or resume
playback.
Function of remote control
Direct Music Search
Searching the music by entering the track number.
1 Enter Direct Music Search mode
Press the [DIRECT] button on the remote
control.
2 Enter the music number
Press the number buttons on the remote
control.
3 Search the music
Press the [4] or [¢] button.
Cancelling Direct Music Search
Press the [DIRECT] button.
⁄
• Direct Music Search cannot be performed during playing
of Random play or scan play.
Function of disc changer with remote control
Direct Disc Search
Searching the disc by entering the disc number.
1 Enter Direct Disc Search mode
Press the [DIRECT] button on the remote
control.
2 Enter the disc number
Press the number buttons on the remote
control.
3 Search the disc
Press the [FM] or [AM] button.
Cancelling Direct Disc Search
Press the [DIRECT] button.
⁄
• Direct Disc Search cannot be performed during Random
play or scan play.
• Input “0” to select disc 10.
English |
21
HD Radio™ Tuner Operation
SRC MENU VOL
SEARCH MODE
3 Enter Preset Memory mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “List & Memory”.
4 Select the number to put in the memory
4
¢
Display
“List & Memory”
“-1”
“-2”
Overview
Preset number 1. (FM/ AM/ Mixed)
Preset number 2. (FM/ AM/ Mixed)
…
This HD Radio receiver enables:
Turn the [VOL] knob and press [VOL] knob for
at least 2 seconds when the desired item is
displayed.
Select a preset number.
Preset number 6. (FM/ AM/ Mixed)
…
“-6”
“-18”
Preset number 18. (FM)
⁄
Basic Operation
Selecting HD Radio source
Press the [SRC] button.
Select the “HD RADIO” display.
Selecting the Receiving Band
1.Enter Menu List mode
Press the [MENU] button.
2.Turn the [VOL] knob and press it when the
desired item is displayed.
Select “FM” or “AM”.
Selecting the Receiving station or channel
Press the [4] or [¢] button.
During reception of stereo stations the “ST”
indicator is light up.
✍✍Details of the station selecting in operation are
set in the “Seek Mode” of <HD Radio™ Setting>
(page 23).
Station Preset Memory
Putting a station in the memory.
1 Select the radio band and tune in a desired
radio station you wish to store in the preset
memory
2 Enter Menu List mode
Press the [MENU] button.
22 |
KDC-X995/ KDC-BT948HD
• You can register up to 18 FM stations and 6 AM stations.
Selecting “Mixed” for “Tuner Preset Type” allows you to
register up to six stations including FM, AM, and another
Satellite Radio Tuner regardless of the selected source.
See “Tuner Preset Type” of <Initial Settings> (page 38).
Cancelling the Preset Memory mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Auto Memory Entry
Putting stations with good reception in the memory
automatically.
1 Select the radio band you wish to store in the
preset memory
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Auto Memory Entry mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “Auto Memory”.
4 Open Auto Memory Entry
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “YES”.
When 18 stations (FM) or 6 stations (AM) that can
be received are put in the memory, auto memory
entry closes.
⁄
5 Make a setting
• This setting can be made when “Type Normal” is selected
for the “Tuner Preset Type” of <Initial Settings> (page 38).
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Preset Tuning
Recalling the stations in the memory.
Function of remote control
1 Select the radio band
2 Enter Menu List mode
Direct Access Tuning
Press the [MENU] button.
3 Select a desired station in the memory
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “List & Memory” > Preset number.
You can select following HD Radio Setting items.
1 Select the HD Radio source
2 Enter Menu List mode
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings”.
Turn the [VOL] knob and press it when the
desired item is displayed.
“Receive Mode”
“TAG Memory”
“Tagging”
1 Select the radio band
2 Enter Direct Access Tuning mode
Press the [DIRECT] button.
“– – – –” is displayed.
Press the [DIRECT] button.
Pressing the [DIRECT] button each time switches
the following tuning items as follows.
Items
Frequency
Channel
Cancelling Direct Access Tuning
Display
“– – – –”
“HD –”
­—
4 Enter the frequency or Channel
4 Select the setting item to adjust
“Auto Memory”
Tuning in a desired radio station by entering the
frequency.
3 Select Tuning item
HD Radio™ Setting
Display
“Settings”
“Seek Mode”
Press the [4] or [¢] button.
Overview
Selects the tuning mode of the radio.
“Auto1”: Automatic search for a station.
“Auto2”: Search in order of the stations in the
Preset memory.
“Manual”: Normal manual tuning control.
Memorizes 18 stations (FM) or 6 stations (AM)
with good reception automatically.
Refer to <Auto Memory Entry> (page 22)
Sets the receive mode of the HD Radio receiver.
“Auto”: Automatically tunes to analog broadcast
when there is no digital broadcast.
“Digital”: Digital broadcasts only.
“Analog”: Analog broadcasts only.
Displays the tag memory usage of HD Radio
receiver. Up to 50 tags can be registered to
this unit.
“0”/“50”
Turns ON / OFF the tag memory function of
HD Radio receiver.
“OFF”/“ON”
(
Press the number buttons.
Example of frequency input:
Desired frequency
92.1 MHz (FM)
810 kHz (AM)
Press button
[9], [2], [1]
[8], [1], [0]
5 Tune in to the entered frequency or Channel
Press the [4] or [¢] button.
Cancelling Direct Access Tuning
Press the [DIRECT] button on the remote
control.
: Factory setting)
English |
23
HD Radio™ Tuner Operation
iTunes Tagging
Using an iTunes Tagging enabled HD Radio receiver
you can tag your music. When you hear a song you
enjoy on your local HD Radio station, you only have
to press the [SEARCH MODE] button. The song’s
information will then be saved on this unit. The
saved songs will then show up in a playlist called
“Tagged” in iTunes the every next time you sync
your iPod to your computer. So then you just need
to click and then easily buy and download the song
you were tagging directly from the Apple iTunes
Music Store.
1 Saves song’s information
Press the [SEARCH MODE] button.
“ TAG ” will be indicated on the display when song
information can be registered.
⁄
• Turn “ON” the “Tagging” of <HD Radio™ Setting> (page 23)
when using this function.
• Up to 50 TAGs (song’s information) can be registered to
this unit. When iPod is connected, the TAG information
registered to this unit is transferred to the connected
iPod.
• The memory usage can be checked by selecting “TAG
Memory” of <HD Radio™ Setting> (page 23).
24 |
KDC-X995/ KDC-BT948HD
English |
25
Operation of hands-free phoning
SRC MENU VOL
DISP
SEARCH MODE
Receiving a Call
Answering a Phone Call
Press the [VOL] knob.
⁄
4 38 ¢
Getting Started
Before use the cell-phone, you need to connect cellphone to this unit.
⁄
• For details on the Bluetooth cell-phone with the handsfree function, see <About the Cell-Phone> (page 61).
1 Enter easy pairing mode
Press the [
] button for at least 1 second.
2 “Searching” is displayed.
Search for the Bluetooth device.
When search is completed, “Finished” is displayed.
3 Select a cell-phone name
Turn the [VOL] knob and press it when the
desired item is displayed.
4 Input the PIN code
1.Turn the [VOL] knob and press it when the
desired item is displayed.
Select the digit.
2.Turn the [VOL] knob to select the numbers,
and then press the [VOL] knob.
5 Transmit the PIN code
If “Pairing Success” is displayed, registration is
completed.
When “Confirm Phone” is displayed, confirm
connection with a cell-phone operation.
6 The receiver is connected to a cell-phone, with
“HF Connect” displayed, and exits the easy
pairing mode.
⁄
• For more details, see <Easy pairing function> (page 48).
• The following operations disconnect the line:
- Insert a CD.
- Connect a USB device.
• The name of the calling party is displayed if it has already
been registered in the Phone Book.
Rejecting an Incoming Call
Press the [ ] or [SRC] button.
During a Call
Disconnecting a Call
Press the [ ] or [SRC] button.
Switching to the Private Mode
Press the [38] knob.
Switches between Private talk (“PRIVATE”) and
Hands-free talk each time this button is pressed.
⁄
• Depending on the type of your cell-phone, switching
to the private talk mode may select the source that was
used before commencing the hands-free connection.
If this happens, the source cannot be switched back to
the hands-free talk mode by operating this unit. Operate
your cell-phone to return to the hands-free talk mode.
Adjusting the Voice Volume during a Call
Turn the [VOL] knob.
Call Waiting
Answering Another Incoming Call with the
Current Call Suspended
1 Press the [VOL] knob.
2 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “ANSWER”.
Answering another Incoming Call after
Terminating the Current Call
Press the [ ] or [SRC] button.
Continuing the Current Call
1 Press the [VOL] knob.
2 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “REJECT”.
26 |
KDC-X995/ KDC-BT948HD
Answering the Waiting Call after Terminating
the Current Call
Press the [ ] or [SRC] button.
Switching between the Current Call and Waiting
Call
Press the [VOL] knob.
Each pressing of this knob switches the calling
party.
Speed Dialing (Preset Dial)
1 Enter Bluetooth mode
Press the [
] button.
2 Select the preset dial mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Preset call”.
3 Select the number you want to recall from the
Other Functions
Clearing the Disconnection Message
Press the [ ] button.
“HF Disconnect” disappears.
memory
Turn the [VOL] knob and press it when the
desired item is displayed.
Select preset number.
Phone number is displayed.
4 Exit the preset dial mode
Making a Call
1 Enter Bluetooth mode
Press the [
] button.
2 Select a dialing method
Turn the [VOL] knob and press it when the
desired item is displayed.
Press the [MENU] button.
5 Make a call
Press the [VOL] knob.
⁄
• You need to register the preset dial number. Refer to
<Registering to the Preset Dial Number List> (page 29).
Display
“Preset Call”
“Phonebook”
Overview
Calling a number in the preset.
Selecting the character to be searched for the
phone book.
“Outgoing Calls” Calling a number in the outgoing call list.
“Incoming Calls” Calling a number in the incoming call list.
“Missed Calls”
Calling a number in the missed calls list.
“Number Dial” Making a call by entering phone number.
“Voice Recognize” Make a Voice Dialing Call.
Operation method of each mode is described
below.
3 Exit the dialing method mode
Press the [
] button.
English |
27
Operation of hands-free phoning
Calling a Number in the Phone Book
1 Enter Bluetooth mode
Press the [
] button.
2 Select the Phone Book mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Phonebook”.
3 Select the character to be searched for
Operation type
Move to the next character.
Move to the next row.
Determine the selected
character.
Operation
Turn the [VOL] knob.
Press the [4] or [¢] button.
Press the [VOL] knob.
4 Select the name
Operation type
Operation
Move to the next phone
Turn the [VOL] knob.
number.
Determine the selected phone Press the [VOL] knob.
number.
✍✍Switching between Display Modes
Press the [DISP] button.
Pressing this button each time switches between
name and telephone number.
5 Make a call
Press the [VOL] knob.
⁄
• During search, a non-accent character such as “u” is
searched for instead of an accent character such as “ü”.
Calling a Number in the Call log
1 Enter Bluetooth mode
Press the [
] button.
2 Select the call log mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Outgoing Calls”, “Incoming Calls”, or
“Missed Calls”.
3 Select a name or phone number
Turn the [VOL] knob and press it when the
desired item is displayed.
✍✍Switching between Display Modes
Press the [DISP] button.
Pressing this button each time switches between
name and telephone number.
28 |
KDC-X995/ KDC-BT948HD
4 Make a call
Press the [VOL] knob.
⁄
• The outgoing call list and the incoming call list, and the
missed call list are the lists of calls originated from and
received at this unit. They are not the ones stored in the
cell-phone memory.
Dial a Number
1 Enter Bluetooth mode
Press the [
] button.
2 Select the number dial mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Number Dial”.
3 Enter a phone number
Operation type
Select the numbers.
Move to the next digit.
Delete the last digit.
Operation
Turn the [VOL] knob.
Press the [¢] button.
Press the [4] button.
• Press the number ([1] – [0]), #([FM]), *([AM]), or
+([¢]) button on the remote controller.
✍✍To erase the entered phone number digit
by digit:
Press the [4] button on the remote
controller.
4 Make a call
• Press the [VOL] knob.
• Press the [DIRECT] button on the remote
controller.
⁄
• You can input max 25 digits.
Make a Voice Dialing Call
1 Enter Bluetooth mode
Press the [
] button.
2 Select voice recognition mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Voice Recognize”.
3 “PB Name?” is displayed.
When a beep is heard, say the name within 2
seconds.
4 “PN Type” is displayed.
When a beep is heard, say the category name
within 2 seconds.
5 Make a call
Press the [VOL] knob.
✍✍This step is the same as step 4 of the procedure
in <Calling a Number in the Phone Book> (page
28). You can make a call or select a category.
⁄
• If your voice cannot be recognized, a message is
displayed. Pressing the [VOL] knob allows you to retry
voice input. Refer to <Troubleshooting Guide> (page 72).
• Both the name and category require registration of
a voice tag. Refer to <Setting a Voice Command for
Category> (page 53).
• Audio sound is not output during voice recognition.
Registering to the Preset Dial Number
List
1 Select the phone number you wish to register
Select the phone number with reference to the
following:
- Calling a Number in the Phone Book (page 28)
- Calling a Number in the Call log (page 28)
- Dial a Number (page 28)
2 Enter Preset Memory mode
Press the [VOL] button for at least 1 second.
3 Select the Preset number to put in the
memory
Turn the [VOL] knob and press it for at least 1
second when the desired item is displayed.
Select preset number.
4 Determine the Preset number to put in the
memory
Turn the [VOL] knob and press it when the
desired item is displayed.
Exit the Preset Memory mode
Press the [MENU] button.
Display of Phone Number type
(category)
The category items in the Phone Book are displayed
as follows:
Display
“GENERAL” / “
”
Information
General
“HOME” / “
”
Home
“OFFICE” / “
”
Office
“MOBILE” / “
”
Mobile
“OTHER” / “
”
Other
English |
29
Display Settings
SRC MENU VOL
DISP
Display Setting
You can select following Display Setting items.
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
4
¢
SCRL
Basic Operation
Switching display
Press the [DISP] button.
Mode
5-line display mode
3-line display mode
iPod-like display
mode
Spectrum analyzer
display mode
Clock display mode
Display off mode
Display Type
Displays 4 to 5 lines of text.
Displays 2 to 3 lines of text.
Displays like iPod. (iPod source only)
Displays a line of text and the spectrum analyzer.
Displays the clock.
Turns off the display and illumination..
⁄
• When the 5-line display mode is selected, the status (ON/
OFF indicator of each function) can be displayed on the
first line, and the icon of the currently selected source and
the text information title can be displayed on the left side
by the following <Customization of 5-line Display Mode
& 3-line Display Mode & iPod-like Display Mode> (page 32)
operation.
Status display: Select “Settings” > “DISP & ILLUMI” > “Display
Select” > “Status”
Side display: Select “Settings” > “DISP & ILLUMI” > “Display
Select” > “Side Select”
• When “Display off mode” is selected, you can select only
“Type Select” for “Display Select”.
Text scroll
Press the [SCRL] button.
The displayed text scrolls.
30 |
KDC-X995/ KDC-BT948HD
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Display Setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “DISP & ILLUMI”.
4 Select the setting item to adjust
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Settings”
“DISP & ILLUMI”
“Display Select”
“Color Select”
Overview
Making Display and Illumination settings.
Selecting and customizing the Display type.
Selecting the Illumination Color of the panel.
Refer to <Illumination Color Selection>
(page 34)
“DISP & ILLUMI If this unit is not operated at least 5 seconds
OFF”
with “DISP” selected, the display turns off.
During a setup mode, the display will not turn
off even if 5 seconds lapse.
Selecting “DISP & ILLUMI” turns off the
illumination and display together.
“DISP”/ “DISP & ILLUMI”
“Display
Reduces the display Illumination brightness.
Dimmer”
“Auto”: Dims the illumination in conjunction
with the Light switch of the vehicle.
“Manual1”: Dims the illumination constantly.
“Manual2”: Dims the illumination darker than
Manual1.
“OFF”: Does not dim the illumination.
“Contrast”
Adjusting the display contrast.
“1” - “5” - “12”
“DISP N/P”
Switches the panel display between positive
or negative.
“POSI1”/ “POSI2”/ “NEGA1”/ “NEGA2”
“TEXT Scroll” Specifies whether the text is scrolled
automatically.
“Auto”/ “Once”/ “OFF”
“ILLUMI
Reduces the key Illumination brightness.
Dimmer”
“Auto”: Dims the illumination in conjunction
with the Light switch of the vehicle.
“Manual1”: Dims the illumination constantly.
“Manual2”: Dims the illumination darker than
Manual1.
“OFF”: Does not dim the illumination.
“ILLUMI Effect” Sets whether the key illumination brightness is
changed in conjunction with the key operation.
“OFF”/ “ON”
“ILLUMI MSC Sets whether the key illumination color is
SYNC”
changed in conjunction with the sound volume.
“OFF”/ “ON”
(
: Factory setting)
5 Make a setting
• W
hen the “ PUSH ” icon is displayed (at the
right edge of the display)
Turn the [VOL] knob to select a setting value,
and then press the [VOL] knob.
• When the “ PUSH ” icon is not displayed
Press the [4] or [¢] button to select a
setting value.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
English |
31
Display Settings
Customization of 5-line Display Mode
& 3-line Display Mode & iPod-like
Display Mode
You can customize the display of the 5-line display
mode, 3-line display mode, and iPod-like display
mode.
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Display Setting mode and Select the
5-line display mode, 3-line display mode or
iPod-like display mode.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “DISP & ILLUMI” > “Display
Select” > “Type Select” > 5-line display mode
or 3-line display mode or iPod-like display
mode.
4 Select the setting item to adjust
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Display Select”
“Type Select”
“Side Select”
“Text Select”
“Status”
Setting
Selects from 5-line display mode, 3-line display
mode, or iPod-like display mode.
Sets the source display.
Text/ Icon/ Disappear
Sets the text display.
1. Turn the [VOL] knob to select the text
display part
The selected text display part blinks.
2. Press the [4] or [¢] button to
select the text
Sets the Status display of the 5-line display mode.
Appear/ Disappear
(
: Factory setting)
5 Make a setting
Press the [4] or [¢] button.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
32 |
KDC-X995/ KDC-BT948HD
Text Display Selection
In HD Radio source
5-line display mode
Frequency (“Frequency”)
Station name (“Station Name”)
Song Title (“Song Title”)
Album name (“Album Name”)
Artist name (“Artist Name”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
3-line display mode
Frequency (“Frequency”)
Station name (“Station Name”)
Artist name & Song Title (“Artist
name/Title”)
Artist name & Album name
(“Artist/Album”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
In USB/ iPod/ Audio file source
5-line display mode
Song title (“Song Title”)
Album name (“Album Name”)
Artist name (“Artist name”)
Folder name (“Folder name”)
File name (“File name”)
Play time (“P-Time”)
Play time bar (“Time Bar”) : iPod
only
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
3-line display mode
Ttitle & Artist (“Ttitle/ Artist”)
Album & Artist (“Album/ Artist”)
Folder name (“Folder name”)
File name (“File name”)
Play time (“P-Time”)
Play time bar (“Time Bar”) : iPod
only
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
iPod-like display mode
Song title (“Song Title”)
Album name (“Album Name”)
Artist name (“Artist name”)
Blank (“Blank”)
In Pandora source
5-line display mode
Song title (“Song Title”)
Album name (“Album Name”)
Artist name (“Artist name”)
Play time (“P-Time”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
3-line display mode
Ttitle & Artist (“Ttitle/ Artist”)
Album & Artist (“Album/ Artist”)
Play time (“P-Time”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
In Music CD source
Disc title (“Disc title”)
Track title (“Track title”)
Play time (“P-Time”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
In Auxiliary input source
Source name (“Source Name”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
In Standby
Source name (“Source Name”)
Date (“Date”)
Clock (“Clock”)
Blank (“Blank”)
In Disc changer source (Optional)
Disc title (“Disc title”)
Track title (“Track title”)
Play time (“P-Time”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
In SIRIUS/ XM source (Optional)
5-line display mode
Channel Name (“Channel Name” /
“CHANNEL NAME”)
Song Title (“Song Title” / “SONG
TITLE”)
Artist name (“Artist name” /
“ARTIST NAME”)
Composer name (“Composer
name”) : SIRIUS only
Category Name (“Category Name”
/ “CATEGORY”)
Channel Number (“Channel
Number” / “CHANNEL NUMBER”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
3-line display mode
Channel Name (“Channel Name” /
“CHANNEL NAME”)
Artist name & Song Title (“Artist/
Song” / “NAME/TITLE”)
Category Name (“Category Name”
/ “CATEGORY”)
Channel Number (“Channel
Number” / “CH NUMBER”)
Spectrum analyzer & Clock
(“Speana/Clock”)
Date (“Date”)
Blank (“Blank”)
⁄
• If the selected display item does not have any information,
alternative information is displayed.
• Some items cannot be selected depending on the display
type and row.
• When selecting “Folder name” while playing with iPod,
names will be displayed depending on currently selected
browsing items.
• If the iPod Control by Hand Mode is set to on while playing
the iPod, “iPod by Hand Mode” is displayed.
• If all characters cannot be displayed while playing with iPod,
the file number in the list is displayed.
Information
Music title
Folder name
File name
Display
“TITLE***”
“FLD***”
“FILE***”
Customization of Spectrum Analyzer
Display Mode
You can customize the display of the Spectrum
analyzer display mode.
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
2 Enter Menu List mode
Press the [MENU] button.
3 Enter the Display Setting mode and select the
Spectrum analyzer display mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “DISP & ILLUMI” > “Display
Select” > “Type Select” > Spectrum analyzer
display mode.
4 Select the setting item to adjust
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Display Select”
“Type Select”
“Graphic
Select”
“Text Select”
Setting
Selects the Spectrum analyzer display mode.
Changes the display of the Spectrum analyzer
display mode.
Sets the text display.
5 Make a setting
Press the [4] or [¢] button.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
English |
33
Display Settings
Customization of Clock Display Mode
Illumination Color Selection
You can customize the display of the Clock Display
mode.
Selecting the Illumination Color of the panel.
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Display Setting mode and Select the
Clock Display
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “DISP & ILLUMI” > “Display
Select” > “Type Select” > Clock Display mode.
4 Select the setting item to adjust
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Display Select”
“Type Select”
“Graphic
Select”
Setting
Selects the Clock Display mode.
Switches between single and dual clock.
5 Make a setting
Turn the [VOL] knob to select a setting value,
and then press the [VOL] knob.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
1 Enter Menu List mode
Press the [MENU] button.
2 Enter Illumination color selection mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “DISP & ILLUMI” > “Color
Select”.
3 Select the place where you want to set the
Illumination Color
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“All”
“Display”
“Key”
Place
Display and key
Display
Key
4 Select the Illumination Color
Turn the [VOL] knob and press it when the
desired item is displayed.
Select the color from “Variable Scan”/ “Color1” —
“Color 24”/ “User”.
Creating “User” color
You can create your original color during the
selection from “Color1” — “Color24.”
The color you created can be called when you
select “User”.
1.Press the [VOL] knob for at least 1 second.
Enter the detail color adjustment mode.
2.Set the color.
Operation type
Operation
To select the color to adjust. Press the [4] or [¢] button.
(red, green, or blue)
To adjust color.
Turn the [VOL] knob.
(Range: 0 – 9)
3.Press the [VOL] knob.
Exit the detail color adjustment mode.
5 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
34 |
KDC-X995/ KDC-BT948HD
Auxiliary Input Display Setting
Selecting the display when changing to Auxiliary
input source.
1 Select the AUX source
Pressing the [SRC] button repeatedly switches
source.
Select the “AUX” display.
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Auxiliary input display setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “AUX Name Set”.
4 Select the Auxiliary input display
Turn the [VOL] knob.
Select “AUX”, “DVD”, “PORTABLE”, “GAME”, “VIDEO”, or
“TV”
5 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• The Auxiliary input display can be set only when the
built-in auxiliary input or the auxiliary input of optional
KCA-S220A is used. On the KCA-S220A, “AUX EXT” is
displayed by default.
• AUX source is initially set to “OFF”. Before display setting,
set “Built in AUX” described in <Initial Settings> (page 38)
to “ON”.
English |
35
Clock and Other Functions
Release
4 Set the Clock & Date setting items
MENU VOL
Turn the [VOL] knob and press it when the
desired item is displayed.
5 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
SRC 4
¢
Clock Adjustment
Clock & Date display type setting
You can adjust the clock.
Sets the display type of the clock and calendar.
1 Enter Menu List mode
1 Enter Menu List mode
Press the [MENU] button.
✍✍When “Clock display mode” is selected in the
Display Setting mode, pressing the [SCRL] button
allows you to select “Clock & Date” directly.
2 Enter the Clock & Date setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “Clock & Date”.
3 Select the desired Clock & Date setting item
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Settings”
“Clock & Date”
“Clock Adjust”
Overview
Sets the clock.
Refer to <Clock Adjustment> (page 36)
“City Select”
Sets the two cities to be displayed when
dual clock mode is selected for “Graphic
Select”. Refer to <Customization of Clock
Display Mode> (page 34), <Dual clock city
setting> (page 37).
“Time Synchronized” Synchronizing the Radio Data System
station time data and this unit’s clock.
“OFF”/ “ON”
“Summer Time”
Advances the clock one hour when set
to ON.
“OFF”/ “ON”
“Sub Clock Adjust” Adjusts the time difference caused by
summer time.
“-1h”/ “0h”/ “+1h”
“Date Adjust”
Sets the date.
Refer to <Date Adjustment> (page 37)
“Date Mode Select” Sets the date display mode.
7 types
(
36 |
KDC-X995/ KDC-BT948HD
: Factory setting)
Press the [MENU] button.
2 Enter Clock adjustment mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “Clock & Date” > “Clock
Adjust”.
3 Adjusting Clock
1.Turn the [VOL] knob to set the hours.
2.Press the [¢] button.
3.Turn the [VOL] knob to set the minutes.
4.Press the [VOL] knob.
4 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Date Adjustment
Dual clock city setting
You can adjust the date.
You can select cities for two clocks.
1 Enter Menu List mode
1 Enter Menu List mode
2 Enter Clock adjustment mode
2 Enter City Select mode
3 Adjusting Date
3 Select the city (Home or Sub) display part
Press the [MENU] button.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “Clock & Date” > “Date
Adjust”.
1.Turn the [VOL] knob to adjust the month.
2.Press the [¢] button.
3.Turn the [VOL] knob to adjust the day.
4.Press the [¢] button.
5.Turn the [VOL] knob to adjust the year.
6.Press the [VOL] knob.
4 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Press the [MENU] button.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings” > “Clock & Date” > “City
Select”.
Turn the [VOL] knob.
4 Set cities for Home/ Sub
Press the [4] or [¢] button.
5 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• To display the clocks of two cities, select dual clock
mode for “Graphic Select” described in <Customization
of Clock Display Mode> (page 34).
• For adjustment of Home time, refer to <Clock
Adjustment> (page 36).
• Time of Sub City is automatically derived from Home
time.
When summer time systems are different between
Home and Sub cities, adjustment can be done by
referring to “Sub Clock Adjust” of <Clock & Date display
type setting> (page 36).
Remarks
• City Select
Set a time zone for your area as “Home”. When you set a
time zone for different area to the “Sub”, clocks for two
time zones can be displayed on the clock display. See
<Customization of Clock Display Mode> (page 34).
For time zone list, see <City list> (page 64).
English |
37
Clock and Other Functions
Initial Settings
“Built in AMP”
You can select following Initial Setting items.
1 Select the Standby
Pressing the [SRC] button repeatedly switches
source.
Select the “STANDBY” display.
2 Enter Menu List mode
“DSI”
“F/W Update”
Press the [MENU] button.
3 Enter Initial Setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Initial Settings”.
4 Select the setting item to adjust
Turn the [VOL] knob.
Display
Overview
“Initial Settings”
“Tuner Preset Type” You can select a preset type.
“Type Normal”: Memorizes one station for each
preset button in each band (FM/ AM/ SR1 –
SR4/ XM1 – XM4).
“Type Mixed”: Memorizes one station for each
preset button regardless of the selected band
(FM/ AM) and another Satellite Radio Tuner.
“SRC Select”
Sets the source selection method.
“Settings 1”/ “2”
“Beep”
Setting the operation check sound (beep sound)
ON/OFF.
“OFF”/ “ON”
“Menu Language” You can select the display language for the
Menu list item.
“English”/ “Français”/ “Español”
“Pandora Source” When this is set to ON, Pandora source can be
selected.
“ON”: Allows you to select the Pandora source
by connecting a Pandora-compliant iPhone.
“OFF”: Disable Pandora source selection.
“Built in AUX”
When this is set to ON, AUX source can be
selected.
“ON”: Allows AUX source to be selected. Use
this setting when the built-in AUX terminal
is connected to the external equipment all
the time.
“OFF”: Disable AUX source selection. Use this
setting when the built-in AUX terminal is
not used.
“Forced CD-DA” Sets the method for reading CD.
“Settings 1”: Automatically distinguishes
between audio file disc and music CD when
playing disc.
“Settings 2”: Forces playing as music CD.
38 |
KDC-X995/ KDC-BT948HD
Selecting “OFF” turns off the built-in amplifier.
Turning off the built-in amplifier improves the
quality of the sound from Preout.
“OFF”/ “ON”
DSI (Disabled System Indicator) of the unit blinks
when the faceplate is removed.
“OFF”/ “ON”
Updates the firmware. The update information
will be posted on the following URL as
necessary.
www.kenwood.com/cs/ce/
(
: Factory setting)
5 Make a setting
• W
hen the “ PUSH ” icon is displayed (at the
right edge of the display)
Turn the [VOL] knob to select a setting value,
and then press the [VOL] knob.
• When the “ PUSH ” icon is not displayed
Press the [4] or [¢] button to select a
setting value.
6 Exit Menu List mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Demonstration mode Setting
Turning the demonstration mode ON/OFF.
1 Enter Menu List mode
Press the [MENU] button.
2 Enter Demonstration mode setting
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “DEMO Mode”.
3 Set the Demonstration mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “ON” or “OFF”.
4 Exit Menu List mode
Press the [MENU] button.
Theft Deterrent Faceplate
The faceplate of the unit can be detached and
taken with you, helping to deter theft.
Removing the Faceplate
1 Press the Release button.
Drop open the faceplate.
2 Drawing the faceplate to left side pull it to
forward and remove it.
¤
• The faceplate is a precision piece of equipment and can
be damaged by shocks or jolts.
• Keep the faceplate in its faceplate case while detached.
• Do not expose the faceplate (and the faceplate case) to
direct sunlight or excessive heat or humidity. Also avoid
places with too much dust or the possibility of water
splashing.
Reattaching the Faceplate
3 Align the shaft on the unit with the depression
on the faceplate.
4 Push the faceplate in until it clicks.
The faceplate is locked in place, allowing you to
use the unit.
English |
39
Audio Adjustments
SRC MENU VOL
“2Zone”
“2Zone Select”
“Preset”
Sets the Dual Zone System.
- Dual Zone System (page 42).
Sets the audio preset.
- Audio Preset Memory (page 46).
- Audio Preset Recall (page 47).
(
4
¢
Audio Control
You can adjust following Audio Setting items.
Display
“SubWoofer Level”
“DSP Set”
“Equalizer”
“Bass Boost”
“HIGHWAY-SOUND”
“Supreme+”
“Position”
“Balance”
“Fader”
“2Zone Rear Volume”
“SubWoofer”
“Detailed Setup”
“Car Type”
“Speaker”
“Car Type Adjust”
“X'Over”
“Volume offset”
40 |
Overview
You can set subwoofer level.
“–15” — “0” — “+15”
“Bypass”: Disables the DSP function.
“Through”: Enables the DSP function.
Sets the sound quality.
- Preset Equalizer curve Select (page 41).
- Manual Equalizer Control (page 41).
Sets the Bass Boost level in two steps.
“OFF”/ “Step1”/ “2”
Compensates the low volume or bass sound
being lost by road noises to make vocal sound
clearer.
“OFF”/ “Step1”/ “2”/ “3”
Turns ON/OFF the Supreme plus function.
Can be set while Music CD source, Audio file
source of USB and iPod source.
“ON”/ “OFF”
Compensates the sound environment in
accordance with the listening position.
- Listening Position Selection (page 42).
- Listening Position Fine Adjustments (page
42).
Adjusts left/right speaker balance.
(Left) “L15” — “0” — “R15” (Right)
Adjusts front/rear speaker balance.
(Rear) “R15” — “0” — “F15” (Front)
Refer to <Dual Zone System> (page 42).
Turns on/off the subwoofer output.
“ON”/ “OFF”
To get clear sound, set the sound environment
according to the location and size of physically
installed speakers with reference to the
followings:
- Car Type Selection (page 44).
- Speaker Setting (page 44).
- Car Type Fine Adjustments (page 45).
- X’Over Setting (page 46).
Sets each source’s volume as a difference from
the basic volume.
“–8” — “0” (AUX: “–8”— “+8”)
KDC-X995/ KDC-BT948HD
: Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Select the setting item to adjust
Turn the [VOL] knob and press it when the
desired item is displayed.
4 Make a setting
Press the [4] or [¢] button to select a
setting value, and then press the [VOL] knob.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
Remarks
• DSP Set
When “DSP Set” is set to “Bypass”, the DSP function is
disabled , and the colored items can not be set.
• HIGHWAY-SOUND
Increases the volume of faintest sound being lost by road
noises to make the sound more audible. Additionally, it
accentuates bass sound being lost by road noises to make
the bass sound more dynamic.
This function is not effective for the Tuner source.
• Supreme+ (Supreme Plus)
Technology to extrapolate and supplement with
proprietary algorithm, the high-frequency range that is cut
off when encoding. The bass and vocal sound that are cut
off by encoding are supplemented for the reproduction
of natural sound quality. Supplementing is optimized by
compression format (AAC, MP3 or WMA) and processed
according to bit rate. The effect is negligible with music
that is encoded at high bit rate, variable bit rate or has
minimal high frequency range.
The bass and vocal sound of Music CD/ iPod is also
supplemented.
• Dual Zone System
Main source and sub source (Auxiliary input) output Front
channel and Rear channel separately.
Preset Equalizer curve Select
Manual Equalizer Control
You can select following Equalizer curve.
You can adjust following Equalizer Control items.
Display
“Natural”
“User”
“Rock”
“Pops”
“Easy”
“Top 40”
“Jazz”
“Game”
“iPod”
Equalizer curve
Natural
User*
Rock
Pops
Easy
Top 40
Jazz
Game
iPod (During iPod source only)
* The Equalizer curve set in the section <Manual Equalizer
Control> is recalled.
( : Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Preset Equalizer mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Equalizer” > “Preset Equalizer”.
4 Select the Equalizer curve
Press the [4] or [¢] button.
✍✍Select the iPod Equalizer curve
You can select from 22 Equalizer curve types for
iPod when “iPod” is selected.
1.Enter iPod Equalizer mode
Press the [VOL] knob.
2.Select the iPod Equalizer curve
Press the [4] or [¢] button and press it
when the desired item is displayed.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
⁄
• You can select for each source.
KDC-X995
Band
“BAND1” (62.5 Hz)
“BAND2” (250 Hz)
“BAND3” (1 kHz)
“BAND4” (4 kHz)
“BAND5” (16 kHz)
Item
“GAIN” Band level
“EFCT” Bass Effect
“GAIN” Band level
“GAIN” Band level
“GAIN” Band level
“GAIN” Band level
Range
-9 ­–+9 dB
“ON”/ “OFF”
-9 ­–+9 dB
-9 ­–+9 dB
-9 ­–+9 dB
-9 ­–+9 dB
(
KDC-BT948HD
Band
Item
“BAND1” (60/ 100/ “GAIN” Band level
160/ 250/ 400 Hz) “Q” Quality
“BAND2” (630/ 1k/
1.6k/ 2.5k Hz)
“GAIN” Band level
“Q” Quality
“BAND3” (4k/ 6.3k/
10k/ 16k kHz)
“GAIN” Band level
“Q” Quality
: Factory setting)
Range
-9 ­–+9 dB
0.25/ 0.5/ 1.0/
2.0
-9 ­–+9 dB
0.25/ 0.5/ 1.0/
2.0
-9 ­–+9 dB
0.25/ 0.5/ 1.0/
2.0
(
: Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Manual Equalizer Control mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Equalizer” > “Manual Equalizer”.
4 Select the item you want to set
Operation type
Selects the item.
Adjust each item.
Set the value
Operation
Turn the [VOL] knob.
Press the [4] or [¢] button.
Press the [VOL] button.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
⁄
• When “iPod” is selected in the section <Preset Equalizer
curve Select> (page 41), Manual Equalizer Control is
disabled.
• You can select for each source.
English |
41
Audio Adjustments
Listening Position Selection
The sound environment can be compensated in
accordance with the selected position. According to
the listening position, select the position from the
following settings.
Display
“ALL”
“Front-Left”
“Front-Right”
“Front”
Compensation seat
Not compensating.
Front-Left seat
Front-Right seat
Front seat
Item
“FRONT” / “L”
“FRONT” / “R”
“REAR” / “L”
“REAR” / “R”
“SUBWOOFER” / “L”
“SUBWOOFER” / “R”
“INITIAL”
Setting overview
Front Left speaker
Front Right speaker
Rear Left speaker
Rear Right speaker
Subwoofer Left
Subwoofer Right
Initialize the setting values.
5 Set the value
(
: Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Preset position setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Position” > “Preset Position”.
4 Select the seat you want to compensate
Press the [4] or [¢] button.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
Function of KDC-X995
Listening Position Fine Adjustments
Making fine adjustment of the value specified at
Preset position selection per speaker.
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Manual position setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Position” > “DTA”.
4 Select the speaker you want to set
Turn the [VOL] knob and press it when the
desired value is displayed.
Press the [4] or [¢] button.
Adjust between 0 and 5.58 feet.
Press the [VOL] knob for at least 1 second if you
want to execute the “INITIAL”.
6 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
Dual Zone System
Main source and sub source (Auxiliary input) output
Front channel and Rear channel separately.
Display
Overview
“2Zone Rear Volume”*1 Adjust the volume of Rear channel.
“0” — “35”
“Detailed Setup”
“2Zone”
Sets the Dual Zone System.
“OFF”/ “ON”
1
“2Zone Select”*
Specifies the destination of sub source sound
when the Dual Zone function is turned on.
“Rear”/ “Front”
*1The Dual Zone System is set to “ON”.
(
: Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup”.
4 Select the item you want to set
Turn the [VOL] knob and press it when the
desired item is displayed.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
⁄
• Select Main source by [SRC] button.
• Adjust the volume of Front channel by [VOL] knob.
42 |
KDC-X995/ KDC-BT948HD
• The Audio Control has no effect on sub source.
• There are following limitations when Dual Zone System
is enabled.
- There is no output from the subwoofer.
- “Fader”, “Subwoofer Level” of <Audio Control> (page 40)
and DSP function are not available.
English |
43
DSP Setup
Speaker Setting
SRC MENU VOL
The speaker X’Over is automatically set when the
position and size of each speaker are selected from
the following items.
Speaker
“FRONT”
4
¢
Car Type Selection
You can compensate the delay of the sound arrival
time by selecting your environment from the
following car types.
Display
“OFF”
“Compact”
“Full size car”
“Wagon”
“Minivan”
“SUV”
“Minivan (Long)”
Overview
Not compensating.
Compact car
Full size car
Station wagon
Minivan
Sport-utility vehicle
Long Minivan
“REAR”
(
: Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Cabin select mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup” > “Car Type”.
4 Select the car type
Press the [4] or [¢] button.
5 Set the value
Press the [VOL] button.
6 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
⁄
• You can compensate the distances in more details by
using <Car Type Fine Adjustments> (page 45) function.
“SUB W”
Item
“SIZE”
Range
Speaker Size Front
KDC-X995:
“O.E.M.”, “4inch”, “5inch”, “6 1/2inch”,
“6 3/4inch”, “7inch”, “4x6”, “5x7”, “6x8”,
“6x9”, “7x10”
KDC-BT948HD:
“Small”, “Medium”, “Large”
“LOCATION” Speaker Location Front
“Door”, “On Dash”, “Under Dash”
“TWEETER” Speaker Size Tweeter
“None”, “Use”
“SIZE”
Speaker Size Rear
KDC-X995:
“None”, “O.E.M.”, “4inch”, “5inch”,
“6 1/2inch”, “6 3/4inch”, “7inch”, “4x6”,
“5x7”, “6x8”, “6x9”, “7x10”
KDC-BT948HD:
“None”, “Small”, “Medium”, “Large”
“LOCATION” Speaker Location Rear
• “Door”, “Rear Deck”
• “2nd Row”, “3rd Row” (Car Type:
“Minivan”, “Minivan (Long)”)
“SIZE”
Speaker Size Subwoofer
KDC-X995:
“None”, “6 1/2inch”, “8inch”, “10inch”,
“12inch”, “15inch Over”
KDC-BT948HD:
“None”, “Small”, “Large”
(
: Factory setting)
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Speaker setting mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup” > “Speaker”.
4 Select the item you want to set
Operation type
Selects the item.
Adjust each item.
Set the value.
Operation
Turn the [VOL] knob.
Press the [4] or [¢] button.
Press the [VOL] button.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
44 |
KDC-X995/ KDC-BT948HD
Car Type Fine Adjustments
Reference point
Adjusting fine tuning of the speaker position
compensation value specified at <Car Type
Selection> (page 44).
Display
“Front”
“Rear”
“SW”
Item
Front speaker
Rear speaker
Subwoofer
Range
0 – 14.44 feet
0 – 14.44 feet
0 – 14.44 feet
(
: Factory setting)
1 Select the source
+3.2 feet
FRONT
1.7 feet
2.6 feet
REAR
REAR
4.9 feet
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Enter Car Type Adjustment mode
FRONT
+2.3 feet
+0 feet
SUB-W
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup” > “Car Type Adjust”.
4 Select the item you want to set
Operation type
Selects the item.
Adjust each item.
Set the value.
Operation
Turn the [VOL] knob.
Press the [4] or [¢] button.
Press the [VOL] button.
The settings of the delay time are automatically
identified and compensated by specifying the
distances of each speaker from the center of the
vehicle interior.
1 Set the front and rear positions and the height
of the reference point to the position of the ears
of the person sitting in the front seat, and set
the right and left positions to the center of the
vehicle interior.
2 Measure the distances from the reference point
to the speakers.
3 Calculate the distance difference in accordance
with the farthest speaker.
English |
45
DSP Setup
X’Over Setting
7 Exit Audio Control mode
Fine adjusting the following setting values
corresponding to the X’Over values set in the
section <Speaker Setting> (page 44).
Audio Preset Memory
Display
“X’Over”
“Front”
“Rear”
Registering the value setup by Sound Control.
Item
Range
“FC”
Front High Pass Filter
Through, 30*, 40, 50*, 60, 70, 80,
90*, 100, 120, 150, 180, 220, 250*
(Hz)
Front High Pass Slope
-6, -12, -18, -24 dB/Oct
Rear High Pass Filter
Through, 30*, 40, 50*, 60, 70, 80,
90*, 100, 120, 150, 180, 220, 250*
(Hz)
Rear High Pass Slope
-6, -12, -18, -24 dB/Oct
Subwoofer Low Pass Filter
30*, 40, 50*, 60, 70, 80, 90*, 100,
120, 150, 180, 220, 250*, Through
(Hz)
Subwoofer Slope
-6, -12, -18, -24 dB/Oct
Subwoofer Phase
Reverse (180°)/ Normal (0°)
“SLOPE”*
“FC”
“SLOPE”*
“SubWoofer” “FC”
“SLOPE”*
“PHASE”
Press the [MENU] button for at least 1 second.
(
: Factory setting)
* Function of KDC-X995
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
1 Setup Sound Control
Refer to the following operations to setup the
Sound Control.
- Car Type Selection (page 44)
- Speaker Setting (page 44)
- Car Type Fine Adjustments (page 45)
- X’Over Setting (page 46)
- Manual Equalizer Control (page 41)
- Listening Position Selection (page 42)
- Listening Position Fine Adjustments (page 42)
2 Enter Audio preset memory mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup” > “Preset” > “Memory”.
3 Select the number to put in the memory
Turn the [VOL] knob and press it when the
desired item is displayed.
Select a preset number.
4 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “YES”.
“Memory Completed” is displayed.
5 Exit Audio Control mode
2 Enter Audio Control mode
Press the [MENU] button for at least 1 second.
3 Enter X’Over setting mode
• Register 2 patterns of Audio Preset Memory.
• Preset number “1”:
When you press the Reset, all the sources will be the
setting value which is registered.
• Preset number “1” and “2”:
The memory cannot be erased by the Reset button.
• This function cannot be registered when the iPod
Equalizer set in <Preset Equalizer curve Select> (page 41).
Press the [VOL] knob.
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup” > “X’Over”.
4 Select the speaker you want to set
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Front”, “Rear”, or “SubWoofer”.
5 Select the item you want to set
Operation type
Selects the item.
Adjust each item.
Set the value
Operation
Turn the [VOL] knob.
Press the [4] or [¢] button.
Press the [VOL] button.
6 Repeat steps 3 to 4 to complete the X’Over
settings.
46 |
KDC-X995/ KDC-BT948HD
⁄
Audio Preset Recall
Recalling the sound setup registered by <Audio
Preset Memory> (page 46).
1 Select the source
Pressing the [SRC] button repeatedly switches
source.
Select a source other than “STANDBY”.
2 Enter Audio preset recall mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Detailed Setup” > “Preset” > “Recall”.
3 Select the number to recall in the memory
Turn the [VOL] knob and press it when the
desired item is displayed.
Select preset number.
4 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “YES”.
“Recall Completed” is displayed.
5 Exit Audio Control mode
Press the [MENU] button for at least 1 second.
⁄
• The “User” of <Preset Equalizer curve Select> (page 41) is
changed to the value which was recalled.
• The Equalizer curve is changed to the value which was
recalled by the selected source.
English |
47
Bluetooth Setup
When a cell-phone has already been registered,
or maximum of five cell-phones have already
been registered/ selecting a cell-phone
MENU VOL
2 “(cell-phone name)” or “Device Full” is
displayed.
3 Select a cell-phone name
4
¢
Easy pairing function
1 Enter easy pairing mode
Press the [ ] button for at least 1 second.
Any of the following is displayed depending on
cell-phone registration condition:
–“Searching”: When registering a cell-phone for the
first time.
–“(cell-phone name)”: When a cell-phone has
already been registered.
–“Device Full”: When maximum of five cell-phones
have already been registered.
When registering a cell-phone for the first time,
registering a cell-phone
2 “Searching” is displayed.
Search for the Bluetooth device.
When search is completed, “Finished” is displayed.
3 Select a cell-phone name
Turn the [VOL] knob and press it when the
desired item is displayed.
4 Input the PIN code
Operation type
Select the numbers.
Move to the next digit.
Delete the last digit.
Operation
Turn the [VOL] knob.
Press the [¢] button.
Press the [4] button.
5 Transmit the PIN code
Press the [VOL] knob.
If “Pairing Success” is displayed, registration is
completed.
When “Confirm Phone” is displayed, confirm
connection with a cell-phone operation.
6 The receiver is connected to a cell-phone, with
“HF Connect” displayed, and exits the easy
pairing mode.
Turn the [VOL] knob.
✍✍To register a new cell-phone, select “Device
Search”, then go to “When registering a cellphone for the first time.”
4 Set up the cell-phone name
Press the [VOL] knob.
“✱(name)” or “-(name)” is displayed.
“✱”: The selected Bluetooth device is busy.
“-”: The selected Bluetooth device is on standby.
“ “ (blank): The Bluetooth device is deselected.
✍✍If a Bluetooth device is already selected, deselect
it, and then select a different one.
5 Exit easy pairing mode
Press the [MENU] button for at least 1 second.
Deleting the registered cell-phone
2 “(cell-phone name)” or “Device Full” is
displayed.
3 Select a cell-phone name
Turn the [VOL] knob.
4 Delete the selected cell-phone
Press the [VOL] knob for at least 2 seconds.
5 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “YES”.
Bluetooth Setting
You can select following Bluetooth Setting items.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings”.
3 Select the Menu item
Turn the [VOL] knob and press it when the
desired item is displayed.
48 |
KDC-X995/ KDC-BT948HD
Display
“SMS Inbox”
“Mic Gain”
Adjust the sensitivity of the microphone for a
telephone call. Adjust the voice of caller. Setting
to “+” increases the voice volume.
“–3” – “0” – “+3”
“NR Level”
Reduce the noises generated by surrounding
environment without changing the microphone
volume. Adjust the voice of caller when it is
not clear. Setting to “+” increases the noise
reduction.
“–3” – “0” – “+3”
“Echo Cancel LV“ Adjust the level of echo cancellation. Setting to
“+” increases the echo cancel reduction.
“–2” – “0” – “+2”
Overview
Display the received short message.
Refer to <SMS (Short Message Service)>
(page 54).
“BT Settings”
“Pairing”
“Device Regist.” Register a Bluetooth device (pairing).
Refer to <Registering Bluetooth device>
(page 50).
“Phone
Select a cell-phone connection.
Selection”
Refer to <Selecting the Bluetooth device You
Wish to Connect> (page 51).
“SPCL DVC
Register a Bluetooth device (pairing).
Select”
Refer to <Registering Bluetooth device>
(page 50).
“Device Delete” Cancel registration of the Bluetooth device.
Refer to <Deleting a Registered Bluetooth
device> (page 52).
“SMS Download” Download a short message.
Refer to <Downloading the SMS> (page 54).
“Voice Tag”
Registers voice for voice recognition and voice
to select the Phone number category in Phone
book.
- Adding a Voice Dialing Command (page 52)
- Setting a Voice Command for Category (page
53)
“Detailed Setup” Move to detailed item.
“PIN Code Edit” Specify the PIN code required when registering
this unit using the Bluetooth device.
Refer to <Registering PIN Code> (page 51).
“Auto Answer” Answer a call automatically after lapse of the
preset time interval for automatic answer.
“OFF”/ “0s” – “8s” – “99s”
“Auto
Automatically reconnects the selected
Reconnect”*2 Bluetooth device when radio wave becomes
strong enough, even after it is disconnected.
“ON”/ “OFF”
✍✍ When this function is enabled, the
Bluetooth device is reconnected
even if “Phone Selection” is selected
to select a cell-phone connection.
To cancel the Bluetooth connection,
select OFF to disable this function.
“Bluetooth HF” You can specify output speakers for hands-free
voice communication.
“FRONT”: Outputs voice from the front
speakers.
“ALL”: Outputs voice from the front and rear
speakers.
“Call Beep”
You can output a beep from the speaker when
a call comes in.
“ON”: Beep is heard.
“OFF”: Beep is canceled.
“BT F/W Update” Display the version of the firmware of this unit.
(
: Factory setting)
4 Make a setting
• W
hen the “ PUSH ” icon is displayed (at the
right edge of the display)
Turn the [VOL] knob to select a setting value,
and then press the [VOL] knob.
• When the “ PUSH ” icon is not displayed
Press the [4] or [¢] button to select a
setting value.
5 Exit BT Settings mode
Press the [
] button.
Remarks
• “Auto Answer” (Setting the Time Interval for Automatic
Answer)
This function automatically answers (responds to) a call
after lapse of the preset time interval for automatic answer.
“OFF” : Does not answer the phone call automatically.
“0” : Automatically answers the phone call at once.
“1s” – “99s” : Automatically answers the phone call after
lapse of 1 – 99 seconds.
⁄
• If the time set in the cell-phone is shorter than that set in
the unit, the former will be used.
• This function does not work for call waiting.
• “Bluetooth HF” (Setting up the Voice Output Speakers)
Select the speaker which is further from the microphone in
order to prevent howling or echoes.
• “BT F/W Update” (Displaying the Firmware Version)
Display the version of the firmware of this unit.
For how to update the firmware, access our web site.
http://www.kenwood.com/cs/ce/bt/
English |
49
Bluetooth Setup
Registering Bluetooth device
To make your Bluetooth device (cell-phone) usable
with this unit, you need to register it (pairing). You
can register up to 5 Bluetooth devices to this unit.
Registering from this unit
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Enter Bluetooth device registration mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Pairing” > “Device
Regist.”.
Search for the Bluetooth device.
When search is completed, “Finished” is displayed.
3 Select a Bluetooth device
Turn the [VOL] knob and press it when the
desired item is displayed.
4 Input the PIN code
Operation type
Select the numbers.
Move to the next digit.
Delete the last digit.
Operation
Turn the [VOL] knob.
Press the [¢] button.
Press the [4] button.
5 Transmit the PIN code
Press the [VOL] knob.
If “Pairing Success” is displayed, registration is
completed.
✍✍If the error message appears even though the
PIN code is correct, try <Registering Special
Bluetooth device>.
6 Return to the device list
Press the [MENU] button.
7 Exit BT Settings mode
Press the [
] button.
⁄
• This unit allows up to eight digits to be input for a PIN
code. If a PIN code cannot be input from this unit, it can
be input from the Bluetooth device.
• If there are 5 or more Bluetooth devices registered, you
cannot register a new Bluetooth device.
50 |
KDC-X995/ KDC-BT948HD
Registering Special Bluetooth device
Allow registration of a special device that cannot be
registered normally (pairing).
1.Select Special device registration mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Pairing” > “SPCL DVC
Select”.
2.Enter Special device registration mode
Press the [VOL] knob.
A list is displayed.
3.Select a device name
Turn the [VOL] knob and push the center when
the desired device name is displayed.
If “Completed” is displayed, registration is
completed.
4.Go through the procedure step 3 of
<Registering from this unit> and complete
the registration (pairing).
Cancelling Special device registration mode
Press the [MENU] button for at least 1 second.
⁄
• If the device name is not in the list, select “Other Phones”.
Registering PIN Code
By operating the Bluetooth device, specify the PIN
code necessary for registering this unit.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Enter PIN code edit mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Detailed Setup” > “PIN
Code Edit”.
The current setting of PIN code is displayed.
3 Input the PIN code
Operation type
Select the numbers.
Move to the next digit.
Delete the last digit.
Operation
Turn the [VOL] knob.
Press the [¢] button.
Press the [4] button.
4 Register a PIN code
Press the [VOL] knob.
If “Completed” is displayed, registration is
completed.
5 Exit BT Settings mode
Press the [
] button.
⁄
• By default, “0000” is specified.
• A PIN code can be specified with up to eight digits.
Selecting the Bluetooth device You
Wish to Connect
When two or more Bluetooth devices have already
been registered, you need to select the Bluetooth
device you wish to use.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Select Bluetooth device selection mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Pairing” > “Phone
Selection”.
3 Enter Bluetooth device selection mode
Press the [VOL] knob.
“(name)” is displayed.
4 Select the Bluetooth device
Turn the [VOL] knob.
5 Set up the Bluetooth device
Press the [VOL] knob.
“✱(name)” or “-(name)” is displayed.
“✱”: The selected Bluetooth device is busy.
“-”: The selected Bluetooth device is on standby.
“ “ (blank): The Bluetooth device is deselected.
6 Exit BT Settings mode
Press the [
] button.
⁄
• If a Bluetooth device is already selected, deselect it, and
then select a different one.
English |
51
Bluetooth Setup
Deleting a Registered Bluetooth
device
You can delete a registered Bluetooth device.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Enter Bluetooth device deletion mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Pairing” > “Device
Delete”.
“(name)” is displayed.
3 Select the Bluetooth device
Turn the [VOL] knob.
4 Delete the selected Bluetooth device
Press the [VOL] knob.
5 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “YES”.
“Delete” is displayed.
6 Exit BT Settings mode
Press the [
] button.
⁄
• When a registered cell-phone is deleted, its Phone Book,
log, SMS, and voice tag are also deleted.
Downloading the Phone Book
Download the phone book data from the cellphone to this unit so that you can use the Phone
Book of this unit.
To download automatically
If the cell-phone supports a phone book
synchronization function, the phone book is
downloaded automatically after Bluetooth
connection.
⁄
• Setting on the cell-phone may be required.
• If no phone book data is found in the unit even after
the compete display, your cell-phone may not support
automatic download of phone book data. In this case, try
downloading manually.
To download from the cell-phone manually
1 By operating the cell-phone, end the hands-free
connection.
52 |
KDC-X995/ KDC-BT948HD
2 By operating the cell-phone, send the phone
book data to this unit
By operating the cell-phone, download the phone
book data to this unit.
• During downloading:
“Downloading” is displayed.
• After completion of downloading:
“Completed” is displayed.
3 By operating the cell-phone, start the handsfree connection.
To clear the downloading completion message
Press any button.
⁄
• Up to 500 phone numbers can be registered for each
registered cell-phone.
• Up to 25 digits can be registered for each phone number
along with up to 50* characters representing a name.
(* 50: Number of alphabetic alphabetical characters.
Fewer characters can be input depending on the type
of characters.)
• To cancel downloading of the phone book data, operate
the cell-phone.
Adding a Voice Dialing Command
Add a voice tag to the phone book for voice dialing.
You can register up to 30 voice tags.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Enter Phone book name edit mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Voice Tag” > “PB Name
Edit”.
3 Search for the name to register
Select the name to register with reference to 4 in
<Calling a Number in the Phone Book> (page 28).
If a voice tag has already been registered for a
name, “*” is displayed before the name.
4 Select a mode
Turn the [VOL] knob.
Display
“PB Name Regist”
“PB Name Check”*
“PB Name Delete”*
Operation
Register a voice tag.
Play a voice tag.
Delete a voice tag.
* Displayed only when a name for which a voice tag has
been registered is selected.
Select “PB Name Regist” (Regist)
5 Press the [VOL] knob.
6 Register a voice tag (first)
“Enter Voice 1” is displayed.
When a beep is heard, say a voice tag within 2
seconds.
7 Confirm the voice tag (second)
“Enter Voice 2” is displayed.
When a beep is heard, say the same voice tag as
that you said in step 6 within 2 seconds.
“Completed” is displayed.
8 End registration
Press the [VOL] knob.
Return to step 3. You can register another voice tag
continuously.
⁄
• If your voice cannot be recognized, a message is
displayed. Pressing the [VOL] knob allows you to retry
voice input. Refer to <Troubleshooting Guide> (page 72).
Select “PB Name Check” (Play)
3 Select the category (type) you wish to set
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “General”, “Home”, “Office”, “Mobile”, or
“Other”
4 Select a mode
Turn the [VOL] knob.
Display
“PN Type Regist”
Operation
Register a voice tag.
* Displayed only when a name for which a voice tag has
been registered is selected.
5 Register the category (type) by performing
steps 5 to 8 in <Adding a Voice Dialing
Command> (page 52).
6 Exit BT Settings mode
Press the [
] button.
⁄
• Set the voice tag for all the 5 categories. If the voice tag
is not registered for all the categories, the Phone book
may not be recalled by voice command.
5 Press the [VOL] knob.
Play the registered voice and return to step 3.
Select “PB Name Delete” (Delete)
5 Delete a voice tag
Press the [VOL] knob.
6 Turn the [VOL] knob to select “YES”, and then
press the [VOL] knob.
Exit BT Settings mode
Press the [ ] button.
⁄
• Audio sound is not output during voice tag registration.
Setting a Voice Command for
Category
Add a voice tag to the phone number category
(type) for voice calling.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Enter Phone Number type edit mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “Voice Tag” > “PN Type
Edit”.
English |
53
SMS (Short Message Service)
MENU VOL
SMS (Short Message Service)
DISP
The SMS arrived at the cell-phone is displayed on
the receiver.
A newly arrived message is displayed.
¤
TEL
Downloading the SMS
Download the short message (SMS) arrived at the
cell-phone so that it can be read on this unit.
1 Enter Bluetooth mode
Press the [ ] button.
✍✍You can also select from “Settings” in Menu List
mode.
2 Enter SMS download mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “BT Settings” > “SMS Download”.
3 Start downloading
Press the [VOL] knob.
“Downloading” is displayed.
When the downloading finishes, “Completed” is
displayed.
4 Exit BT Settings mode
Press the [
] button.
⁄
• The cell-phone must be able to transmit the SMS using
Bluetooth. Setting on the cell-phone may be required.
If the cell-phone does not support SMS function, the
SMS download item in Function Control mode is not
displayed.
• When the SMS is downloaded from the cell-phone, the
unopened messages in the cell-phone are opened.
• The already-read and unread short messages can be
respectively downloaded up to 75.
• Up to 200 characters can be received per SMS.
54 |
KDC-X995/ KDC-BT948HD
• To prevent car accidents, the driver should not read the
SMS while driving.
When a new message arrives
“SMS Received” is displayed.
The display disappears with any operations.
Displaying the SMS
1 Enter Bluetooth mode
Press the [
] button.
2 Enter SMS Inbox mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “SMS Inbox”.
A message list appears.
3 Select a message
Turn the [VOL] knob.
Each pressing of the [DISP] button switches
between telephone number or name and message
reception date.
4 Display the text
Press the [VOL] knob.
Turning the [VOL] knob scrolls the message.
Pressing the [VOL] knob again returns to the
message list screen.
5 Exit SMS Inbox mode
Press the [MENU] button.
6 Exit BT Settings mode
Press the [
] button.
⁄
• The unopened message is displayed at the beginning
of the list. Other messages are displayed in the order of
reception.
• The SMS that has arrived when the cell-phone is not
linked with Bluetooth cannot be displayed. Download
the SMS.
• The short message cannot be displayed during
downloading the SMS.
English |
55
Satellite Radio Tuner Control (Optional)
SRC MENU VOL
Satellite Radio Setting
You can select following Satellite Radio Setting
items.
1 Select Satellite Radio source
2 Enter Menu List mode
4
¢
Basic Operation
Selecting Satellite Radio source
Pressing the [SRC] button repeatedly switches
source.
Select the “SIRIUS”, or “XM” display.
⁄
• You need to register to the service provider to receive
the service by Satellite Radio. Consult the service
provider if “CALL … TO SUBSCRIBE” appears.
• The radio may take a little time to start receiving after
you select the Satellite Radio source.
• If the signal reception fails, “Acquiring Signal”/ “No Signal”
appears.
Press the [MENU] button.
3 Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Settings”.
4 Select the setting item to adjust
Turn the [VOL] knob and press it when the
desired item is displayed.
Display
“Settings”
“Seek Mode”
“ESN”
Selectable setting/item
Selects the tuning mode of the radio.
“Channel”: Normal manual seeking control.
“Preset”: Search in order of the channels in the
Preset memory
Displays the Electronic Serial Number of satellite
radio.
“ESN=”
(
Selecting the channel
Press the [4] or [¢] button.
5 Make a setting
Selecting the Preset Band
1.Enter Menu List mode
Press the [MENU] button.
2.Turn the [VOL] knob and press it when the
desired item is displayed.
Select “SR1”, “SR2”, “SR3” or “SR4”. (SIRIUS)
Select “XM1”, “XM2”, “XM3” or “XM4”. (XM)
6 Exit Menu List mode
: Factory setting)
Press the [4] or [¢] button.
Press the [MENU] button for at least 1 second,
and then press it again briefly.
Category and Channel Search
Selecting the channel and category you want to
receive.
1 Select Satellite Radio source
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Category and Channel Search mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Channel Search”.
4 Select the Category
Turn the [VOL] knob to select Category, and
then press the [VOL] knob.
5 Select the Channel
Turn the [VOL] knob to select Channel, and
then press the [VOL] knob.
56 |
KDC-X995/ KDC-BT948HD
Cancelling Category and Channel Search mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• You cannot Channel search until the category
information is acquired.
Preset Memory
Putting the channel in the memory.
1 Select the channel you wish to store in the
preset memory
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Preset Memory mode
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “List & Memory”.
4 Select the number to put in the memory
Turn the [VOL] knob and press [VOL] knob for
at least 2 seconds when the desired item is
displayed.
Select preset number.
Cancelling the Preset Memory mode
Press the [MENU] button for at least 1 second,
and then press it again briefly.
⁄
• Only the channel number is stored. Category information
is not stored.
• Up to six channels can be registered for each preset
band. Selecting “Mixed” for “Tuner Preset Type” allows
you to register up to six stations including FM, AM, and
another Satellite Radio Tuner regardless of the selected
source. See “Tuner Preset Type” of <Initial Settings> (page
38).
Preset Tuning
Recalling the channels in the memory.
1 Select Satellite Radio source
2 Enter Menu List mode
Channel Scan
Every receivable Channel is checked for 10 seconds.
1 Select Satellite Radio source
2 Enter Menu List mode
Press the [MENU] button.
3 Enter Channel Scan
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “Channel Scan”.
4 Start Channel Scan
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “YES”.
5 Release it when the channel you want to listen
to is received
Press the [VOL] knob.
Function of remote control
Direct Access Tuning
Entering the channel and tuning.
1 Select Satellite Radio source
2 Enter Direct Access Tuning mode
Press the [DIRECT] button on the remote
control.
“– – – –” is displayed.
3 Enter the channel
Press the number buttons.
4 Tune in to the entered channel
Press the [4] or [¢] button.
Cancelling Direct Access Tuning
Press the [DIRECT] button on the remote
control.
⁄
• If you make no button operation for 10 seconds, the
Direct Access Tuning mode is automatically canceled.
• If you cannot receive any signal in the input Channel due
to bad conditions on radio wave or other such problems,
“Acquiring Signal”/ “No Signal” appears.
Press the [MENU] button.
3 Select a desired station in the memory
Turn the [VOL] knob and press it when the
desired item is displayed.
Select “List & Memory” > Preset number.
English |
57
Basic Operations of remote control
In HD Radio source
VOL
SRC
ATT
ENT
5/∞
EXIT
AUD
AM
FM
0—9
• Band select: [FM]/[AM]
• Station select: [4]/[¢]
• Recall preset stations: [1] — [0] and [ENT]
Example:
Desired preset number
1
6
10
18
Press button
[1], [ENT]
[6], [ENT]
[1], [0], [ENT]
[1], [8], [ENT]
In USB/Music CD/Audio file source
DIRECT
(page 18, 21, 23, 28, 57)
General control
• Volume control: [VOL]
• Source select: [SRC]
• Volume reduce: [ATT]
When the button is pressed again, the volume
returns to the previous level.
• Return to previous item: [ ]
• Exit from mode: [EXIT]
• Selection of item: [5]/[∞]
• Determination: [ENT]
• Enter Audio Control mode: [AUD]
• Music select: [4]/[¢]
• Fast Forwards or Fast Backwards: [4]/[¢]
(Hold down the button)
• Folder select: [FM]/[AM]
• Pause/Play: [ENT]
• Enter Menu List mode: [5]/[∞]
• Return to previous folder: [ ]
In iPod source
• Enter Menu List mode: [5]/[∞]
• Movement between items during Music search
mode: [5]/[∞]
• Return to previous item: [ ]
• Music select: [4]/[¢]
• Fast Forwards or Fast Backwards: [4]/[¢]
(Hold down the button)
• Pause/Play: [ENT]
In Pandora source
• Music select: [¢]
• Pause/Play: [ENT]
In Satellite Radio tuner source
• Preset band select: [FM]
• Channel select: [4]/[¢]
• Recall preset channels: [1] — [6]
58 |
KDC-X995/ KDC-BT948HD
Hands-free phone control
Preparing the remote control unit
Making a call
• Enter Bluetooth mode: [ ]
• Select a dialing method: [5]/[∞] ➜ [ENT]
• Number dial input:
Input a digit: [0] – [9]
Input “+”: [¢]
Input “#”: [FM]
Input “*”: [AM]
Clear the entered phone number: [4]
• Make a call: [DIRECT]
Pull the battery sheet out from the remote control
unit to the direction of the arrow.
Receiving a call
• Answer the call: [ ]
• Switch between the private talk mode and the
hands-free talk mode: [ENT]
Call waiting
• Answer Another Incoming Call with the Current
Call Suspended: [ ]
• Answer another Incoming Call after Terminating
the Current Call: [SRC]
• Continue the Current Call: [1]
Changing the battery of the remote control
unit
Keep on slide
Pull out
CR2025
(+side)
Use a commercially available button battery (CR2025).
Insert the battery with the + and – poles aligned
properly, following the illustration inside the case.
During a call
• End the call: [SRC]
¤ CAUTION
• Do not set the remote control in hot places such
as on the dashboard.
• Lithium battery.
Danger of explosion if the battery is incorrectly
replaced.
Replace only with the same or equivalent type.
• The battery pack or batteries shall not be exposed
to excessive heat such sunshine, fire or the like.
• Keep battery out of reach of children and in
original package until ready to use. Dispose of
used batteries promptly. If swallowed contact
physician immediately.
English |
59
Appendix
About Audio file
• Playable Audio file
AAC-LC (.m4a), MP3 (.mp3), WMA (.wma)
• Playable disc media
CD-R/RW/ROM
• Playable disc file format
ISO 9660 Level 1/2, Joliet, Romeo, Long file name.
• Playable USB device
USB mass storage class
• Playable USB device file system
FAT16, FAT32
Although the audio files are complied with the
standards listed above, the play maybe impossible
depending on the types or conditions of media or
device.
• Playing order of the Audio file
In the example of folder/file tree shown below, the
files are played in the order from ① to ⑩.
^ :Folder
Folder
CD (1)
¡ :Audio
Audiofile
file
¡!
2
4
3
¡$
5
¡"
¡#
Made for
• iPod touch (4th generation)
• iPod touch (2nd generation)
• iPod classic
• iPod nano (6th generation)
• iPod nano (4th generation)
• iPod nano (2nd generation)
• iPhone 4
• iPhone 3G
• iPod touch (3rd generation)
• iPod touch (1st generation)
• iPod with video
• iPod nano (5th generation)
• iPod nano (3rd generation)
• iPod nano (1st generation)
• iPhone 3GS
• iPhone
(As of January 2011)
• Latest compatible list of iPod/iPhone.
For details, see:
www.kenwood.com/cs/ce/ipod/
• Type of control available varies depending
on the type of connected iPod. See
www.kenwood.com/cs/ce/ipod/ for further details.
• The word “iPod” appearing in this manual indicates
the iPod or the iPhone connected with the iPod
connection cable* (optional accessory).
* Not supported model KCA-iP500.
Refer to the web site for connectable iPod and iPod
connection cable.
http://www.kenwood.com/cs/ce/ipod/
⁄
¡%
¡P
An online manual about audio files is put on the site,
www.kenwood.com/cs/ce/audiofile/. On this online
manual, detailed information and notes which are not
written in this manual are provided. Make sure to read
through the online manual as well.
⁄
• In this manual, the word “USB device” is used for flash
memories and digital audio players which have USB
terminals.
60 |
iPod/iPhone that can be connected to this
unit
KDC-X995/ KDC-BT948HD
• If you start playback after connecting the iPod, the
music that has been played by the iPod is played
first.
In this case, “RESUMING” is displayed without
displaying a folder name, etc. Changing the browse
item will display a correct title, etc.
• You cannot operate iPod if “KENWOOD” or “✓”
displayed on iPod.
About PANDORA® internet radio
The requirements for listening to PANDORA® internet
radio are as follows:
• Use an Apple iPhone or iPod touch running under
iOS3 or later.
• Install the latest version of the PANDORA®
application on your iPhone. (Search for “PANDORA”
in the Apple iTunes App Store to find and install the
most current version.)
• Create an account with PANDORA®. (If you are
not already a registered user, an account can be
established at www.pandora.com.)
• Internet connection by 3G, EDGE, or WiFi.
• iPhone connected to this unit with a KCA-IP102.
⁄
• The Pandora service is available only in the U.S.
• Because PANDORA® internet radio is a third-party service,
the specifications are subject to change wihtout prior
notice. Accordingly, compatibility may be impaired or some
or all of the services may become unavailable.
• Some PANDORA® functionality cannot be operated from
this unit.
• For issues using the PANDORA® application, please contact
Pandora at pandora-support@pandora.com
About USB device
• When the USB device is connected to this unit,
it can be charged up provided that this unit is
powered.
• Install the USB device in the place where it will not
prevent you from driving your vehicle properly.
• You cannot connect a USB device via a USB hub and
Multi Card Reader.
• Take backups of the audio files used with this unit.
The files can be erased depending on the operating
conditions of the USB device.
We shall have no compensation for any damage
arising out of erasure of the stored data.
• No USB device comes with this unit. You need to
purchase a commercially available USB device.
• When connecting the USB device, usage of the
CA-U1EX (option) is recommended. (However,
maximum supply current of CA-UIEX is 500mA.)
• Normal playback is not guaranteed when a cable
other than the USB compatible cable is used.
Connecting a cable whose total length is longer
than 4 m can result in abnormal playback.
About “KENWOOD Music Editor”
• This unit supports the PC application “KENWOOD
Music Editor Light ver1.1” or later.
• When you use the audio file with database
information added by the “KENWOOD Music Editor
Light ver1.1”, you can search a file by title, album or
artist name using the <File Search> (page 16).
• In the Instruction manual, the term “Music Editor
media” is used to mean the device that contains
audio files with database information added with
KENWOOD Music Editor.
• “KENWOOD Music Editor Light ver1.1” is available
from the following web site:
www.kenwood.com/cs/ce/
• For further information on “KENWOOD Music
Editor Light ver1.1”, refer to the site above or the
application help.
About the Cell-Phone
This unit conforms to the following Bluetooth
specifications:
Version
Bluetooth Standard Ver. 2.0
Profile
HFP (Hands Free Profile)
OPP (Object Push Profile)
PBAP (Phone Book Access Profile)
SYNC (Synchronization Profile)
For the cell-phones verified for compatibility, access
the following URL:
http://www.kenwood.com/cs/ce/bt/
⁄
• The units supporting the Bluetooth function have been
certified for conformity with the Bluetooth Standard
following the procedure prescribed by Bluetooth
SIG. However, it may be impossible for such units to
communicate with your cell-phone depending on its type.
• HFP is a profile used to make a hands-free call.
• OPP is a profile used to transfer data such as a phone book
between units.
About Satellite Radio tuner (Optional)
This unit supports Satellite Radio tuners which are
released by SIRIUS and XM.
Refer to the instruction manual of Satellite radio tuner.
English |
61
Appendix
Menu List
Common function items
Display
“Settings”
“Clock & Date”
“Clock Adjust”
“City Select”
“Time Syncronized”
“Summer Time”
“Sub Clock Adjust”
“Date Adjust”
“Date Mode Select”
“DISP & ILLUMI”
“Display Select”
“Type Select”
“Side Select”
“Graphic Select”
“Text Select”
“Status”
“Color Select”
“DISP & ILLUMI OFF”
“Display Dimmer”
“Contrast”
“DISP N/P”
“TEXT Scroll”
“ILLUMI Dimmer”
“ILLUMI Effect”
“ILLUMI MSC SYNC”
“DEMO Mode”
Page
–
36
–
–
32, 33
32
33
32
34
30
38
Function items appearing during standby
Display
Page
“Settings”
–
“Clock & Date”
–
“DISP & ILLUMI”
–
“Initial Settings”
–
“Tuner Preset Type”
38
“SRC Select”
“Beep”
“Menu Language”
“Pandora source”
“Built in AUX”
“Forced CD-DA”
“Built in AMP”
“DSI”
“F/W Update”
62 |
KDC-X995/ KDC-BT948HD
Function items appearing when the iPod source
is selected
Display
Page
“Music”
8
“Playlists”
“Artists”
“Albums”
“Songs”
“Podcasts”
“Genres”
“Composers”
“Play Mode”
9
“iPod by Hand”
“Folder Random”
“All Random”
“File Repeat”
“Settings”
–
“Skip Search”
9
“Delete My Playlist”
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when the Pandora
source is selected
Display
Page
“Stations”
14
“New Stations”
15
“Bookmarks”
14
“Bookmark Song”
“Bookmark Artist”
“Station Delete”
15
“Settings”
–
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when the USB source
is selected
Display
Page
“Music”
16
“Play Mode”
17
“File Scan”
“Folder Random”
“All Random”
“File Repeat”
“Folder Repeat”
“Settings”
–
“Skip Search”
17
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when the Music CD/
Audio file source is selected
Display
Page
“Music”
19
“Play Mode”
20
“File Scan”
“Track Scan”
“Folder Random”
“Disc Random”
“Magazine Random”
“All Random”
“File Repeat”
“Folder Repeat”
“Track Repeat”
“Disc Repeat”
“Settings”
–
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when the HD Radio™
tuner source is selected
Display
Page
“List & Memory”
22, 23
“FM”
22
“AM”
“Settings”
–
“Seek Mode”
23
“Auto Memory”
22
“Receive Mode”
23
“TAG Memory”
“Tagging”
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when an AUX source
is selected
Display
Page
“Settings”
–
“AUX Name Set”
35
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when the Hands-Free
source is selected
Display
Page
“SMS Inbox”
54
“BT Settings”
–
“Pairing”
–
“Device Regist.”
50
“Phone Selection”
51
“SPCL DVC Select”
50
“Device Delete”
52
“SMS Download”
54
“Voice Tag”
52
“Detailed Setup”
–
“PIN Code Edit”
51
“Auto Answer”
48
“Auto Reconnect”
“Bluetooth HF”
“Call Beep”
“BT F/W Update”
“Mic Gain”
“NR Level”
“Echo Cancel LV“
“Clock & Date”
–
“DISP & ILLUMI”
–
Function items appearing when the Satellite
Radio tuner source is selected
Display
Page
“List & Memory”
57, 57
“SR1”/ “XM1”
56
“SR2”/ “XM2”
“SR3”/ “XM3”
“SR4”/ “XM4”
“Channel Search”
56
“Channel Scan”
57
“Settings”
–
“Seek Mode”
56
“ESN”
“Clock & Date”
–
“DISP & ILLUMI”
–
English |
63
Appendix
City list
Continent
Area
City
64 |
Continent
City
Hawaii
Alaska
Pacific Time
Arizona
Mountain Time
Central Time
Eastern time
Indiana
Atlantic Time
Mid-Atlantic
W.Central Africa
Abu Dhabi
Adelaide
Amman
Amsterdam
Anchorage
Ankara
Athens
Atlanta
Auckland
Baghdad
Baku
Bangkok
Beijing
Beirut
Berlin
Bogotá
Brasilia
Brussels
Bucharest
Budapest
Buenos Aires
Cairo
Cape Verde Is.
Caracas
Chicago
Copenhagen
Denver
Detroit
Dhaka
Ekaterinburg
Harare
Helsinki
Hong Kong
Islamabad
Istanbul
Jakarta
Jerusalem
Johannesburg
Kabul
KDC-X995/ KDC-BT948HD
Time Difference
–10:00
–9:00
–8:00
–7:00
–7:00
–6:00
–5:00
–5:00
–4:00
–2:00
+1:00
+4:00
+9:30
+2:00
+1:00
–9:00
+2:00
+2:00
–5:00
+12:00
+3:00
+4:00
+7:00
+8:00
+2:00
+1:00
–5:00
–3:00
+1:00
+2:00
+1:00
–3:00
+2:00
–1:00
–4:30
–6:00
+1:00
–7:00
–5:00
+6:00
+5:00
+2:00
+2:00
+8:00
+5:00
+2:00
+7:00
+2:00
+2:00
+4:30
City
Kansas City
Kathmandu
Kingston
Krasnoyarsk
Kuala Lumpur
Kuwait
Kyiv
Las Vegas
Lima
London
Los Angeles
Madrid
Magadan
Manila
Mexico City
Midway Is.
Minsk
Moscow
Nairobi
New Caledonia
New Delhi
New Orleans
New York
Newfoundland
Novosibirsk
Nuku’alofa
Oslo
Ottawa
Panama
Paris
Prague
Rome
San Francisco
Santiago
Sarajevo
Seattle
Singapore
St. Petersburg
Stockholm
Sydney
Taipei
Tehran
Tokyo
Toronto
Tunis
Vancouver
Vienna
Warsaw
Yangon
Zagreb
Zurich
Time Difference
–6:00
+5:45
–5:00
+7:00
+8:00
+3:00
+2:00
–8:00
–5:00
+0:00
–8:00
+1:00
+11:00
+8:00
–6:00
–11:00
+2:00
+3:00
+3:00
+11:00
+5:30
–6:00
–5:00
–3:30
+6:00
+13:00
+1:00
–5:00
–5:00
+1:00
+1:00
+1:00
–8:00
–4:00
+1:00
–8:00
+8:00
+3:00
+1:00
+10:00
+8:00
+3:30
+9:00
–5:00
+1:00
–8:00
+1:00
+1:00
+6:30
+1:00
+1:00
(GMT)
English |
65
Appendix
2CAUTION
IC (Industry Canada) Notice
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
In compliance with Federal Regulations, following
are reproductions of labels on, or inside the product
relating to laser product safety.
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation
of the device.
The term “IC: ” before the certification/registration
number only signifies that the Industry Canada
technical specification were met.
Kenwood Corporation
2967-3, ISHIKAWA-MACHI,
HACHIOJI-SHI
TOKYO, JAPAN
KENWOOD CORP. CERTIFIES THIS EQUIPMENT
CONFORMS TO DHHS REGULATIONS N0.21 CFR
1040. 10, CHAPTER 1, SUBCHAPTER J.
Location : Top Panel
CALIFORNIA, USA
This product contains a CR Coin Cell Lithium Battery
which contains Perchlorate Material – special handling
may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
FCC WARNING
This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless
the modifications are expressly approved in the
instruction manual. The user could lose the authority
to operate this equipment if an unauthorized change
or modification is made.
FCC NOTE
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment may cause harmful interference to radio
communications, if it is not installed and used in
accordance with the instructions. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
•
•
Contains Transmitter Module
FCC ID : RKXCK5000NVIA
Contains Transmitter Module
IC : 5119A-CK5000NVIA
66 |
KDC-X995/ KDC-BT948HD
• PANDORA, the PANDORA logo, and the Pandora trade
dress are trademarks or registered trademarks of
Pandora Media, Inc., used with permission.
• HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. HD Radio™ and the HD, HD Radio, and “Arc”
logos are proprietary trademarks of iBiquity Digital
Corp.
• “Adobe Reader” is a trademark of Adobe Systems
Incorporated.
• The “AAC” logo is a trademark of Dolby Laboratories.
• The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks
by Kenwood Corporation is under license. Other
trademarks and trade names are those of their
respective owners.
• iTunes is a trademark of Apple Inc.
• “Made for iPod” and “Made for iPhone” mean that an
electronic accessory has been designed to connect
specifically to iPod or iPhone, respectively, and has
been certified by the developer to meet Apple
performance standards. Apple is not responsible for
the operation of this device or its compliance with
safety and regulatory standards. Please note that the
use of this accessory with iPod or iPhone may affect
wireless performance.
• iPhone, iPod, iPod classic, iPod nano, and iPod touch
are trademarks of Apple Inc., registered in the U.S. and
other countries.
Accessories/ Installation Procedure
Accessories
2
1
..........2
..........1
3
4
..........4
..........4
5
3 m (9.5 ft) ..........1
Installation Procedure
1 To prevent a short circuit, remove the key from the
ignition and disconnect the - battery.
2 Make the proper input and output wire
connections for each unit.
3 Connect the speaker wires of the wiring harness.
4 Connect the wiring harness wires in the following
• If your car’s ignition does not have an ACC position, connect
the ignition wires to a power source that can be turned on
and off with the ignition key. If you connect the ignition
wire to a power source with a constant voltage supply, as
with battery wires, the battery may die.
• If the console has a lid, make sure to install the unit so that
the faceplate will not hit the lid when closing and opening.
• If the fuse blows, first make sure the wires aren’t touching
to cause a short circuit, then replace the old fuse with one
with the same rating.
• Insulate unconnected wires with vinyl tape or other similar
material. To prevent a short circuit, do not remove the caps
on the ends of the unconnected wires or the terminals.
• Connect the speaker wires correctly to the terminals to
which they correspond. The unit may be damaged or fail to
work if you share the - wires or ground them to any metal
part in the car.
• When only two speakers are being connected to the
system, connect the connectors either to both the front
output terminals or to both the rear output terminals (do
not mix front and rear). For example, if you connect the +
connector of the left speaker to a front output terminal, do
not connect the - connector to a rear output terminal.
• After the unit is installed, check whether the brake lamps,
blinkers, wipers, etc. on the car are working properly.
• Mount the unit so that the mounting angle is 30° or less.
• Reception may drop if there are metal objects near the
Bluetooth antenna.
order: ground, battery, ignition.
5 Connect the wiring harness connector to the unit.
6 Install the unit in your car.
7 Reconnect the - battery.
8 Press the reset button.
2WARNING
If you connect the ignition wire (red) and the battery wire
(yellow) to the car chassis (ground), you may cause a short
circuit, that in turn may start a fire. Always connect those
wires to the power source running through the fuse box.
¤
• Mounting and wiring this product requires skills and
experience. For safety’s sake, leave the mounting and wiring
work to professionals.
• Make sure to ground the unit to a negative 12V DC power
supply.
• Do not install the unit in a spot exposed to direct sunlight
or excessive heat or humidity. Also avoid places with too
much dust or the possibility of water splashing.
• Do not use your own screws. Use only the screws provided.
If you use the wrong screws, you could damage the unit.
• If the power is not turned ON (“Protect” is displayed), the
speaker wire may have a short-circuit or touched the
chassis of the vehicle and the protection function may
have been activated. Therefore, the speaker wire should be
checked.
Bluetooth antenna unit
For Good Reception
To assure good reception, note the following:
• Communicate with the cell-phone within the lineof-sight distance of 10 m (30 ft). The communication
range becomes shorter depending on the
surrounding environment. The communication
range also becomes shorter when there is an
obstacle between this unit and the cell-phone. The
above maximum communication range (10 m) is
not always assured.
• A broadcast station or walkie-talkie located nearby
can interfere with communication due to too strong
signal.
English |
67
Connecting Wires to Terminals
not remove the cap
⁄Do
when you do not use the
To USB device
USB connector
(0.8 m (2.7 ft))
R
USB cable. The connector
will cause the unit to
malfunction if it gets in
touch with any metallic
part of the vehicle.
Microphone input
L
Rear output
Front output
Sub Woofer output
Antenna Cord
Microphone
(Accessory5)
FM/AM antenna input
L
R
AUX input (Stereo)
Use the mini-plug which is stereo type
and does not have any resistance.
(3.5 mm (1/8”) ø)
Fuse (10A)
Wiring harness
(Accessory1)
To Kenwood disc changer/ External optional accessory
connect these leads, refer to the relevant
⁄ To
instruction manuals.
White
White/Black
Gray
Gray/Black
To front left speaker
To front right speaker
Green
Green/Black
Purple
To rear left speaker
Purple/Black
To rear right speaker
If no connections are made, do not let the wire come out from the tab.
Blue/White (Power control wire)
P.CONT
When using the optional power amplifier, connect to its power control
terminal.
ANT.
CONT
Depending on what antenna you are using, connect either to the control
terminal of the motor antenna, or to the power terminal for the booster
amplifier of the film-type or short pole type antenna.
MUTE
To connect the Kenwood navigation system, consult your navigation
manual.
Blue (Antenna control wire)
Brown (Mute control wire)
Orange / White (Dimmer control wire)
ILLUMI
Light Blue/Yellow (Steering remote control)
REMOTE
CONT
To car light control switch
To use the steering wheel remote control feature, you need to an
exclusive remote adapter (not supplied) matches your car is required.
STEERING
WHEEL
REMOTE
INPUT
Car fuse
box
Red (Ignition wire)
ACC
Ignition key
switch
Car fuse box
(Main fuse)
Yellow (Battery wire)
Black (Ground wire) · (To car chassis)
–
68 |
KDC-X995/ KDC-BT948HD
+ Battery
Installation/Removing the Unit
non-Japanese cars
Removing the hard rubber frame
1 Engage the catch pins on the removal tool and
remove the two locks on the upper level.
Upper the frame and pull it forward as shown in
the figure.
Lock
Bend the tabs of the mounting
sleeve with a screwdriver or similar
utensil and attach it in place.
Accessory2
Removal tool
⁄
• Make sure that the unit is installed securely in place. If the
unit is unstable, it may malfunction (for example, the sound
may skip).
Catch
2 When the upper level is removed, remove the
lower two locations.
⁄
Japanese cars
1 Refer to the section <Removing the hard rubber
frame> and then remove the hard rubber frame.
2 Align the holes in the unit (two locations on each
side) with the vehicle mounting bracket and secure
the unit with the accessory screws.
T
N
N
T/N
T
T: Toyota cars
N: Nissan cars
8 mm
MAX.
Removing the Unit
1 Refer to the section <Removing the hard rubber
frame> and then remove the hard rubber frame.
2 Detach the faceplate.
3 Insert the two removal tools deeply into the slots
on each side, as shown.
4 Lower the removal tool toward the bottom, and
pull out the unit halfway while pressing towards
the inside.
Accessory2
8mm
MAX.
3
ø5mm
• The frame can be removed from the bottom side in the
same manner.
4
ø5mm
Accessory3...for Nissan car
Accessory4...for Toyota car
¤
¤ CAUTION
Install this unit in the console of your vehicle.
Do not touch the metal part of this unit during and
shortly after the use of the unit. Metal part such as
the heat sink and enclosure become hot.
• Be careful to avoid injury from the catch pins on the
removal tool.
5 Pull the unit all the way out with your hands, being
careful not to drop it.
English |
69
Installation/Removing the Unit
Installation the Microphone Unit
1 Check the installation position of the microphone
(accessory 5).
2 Remove oil and other dirt from the installation
surface.
3 Install the microphone.
4 Wire the cable up to the unit with it secured at
several positions using tape or the like.
Accessory 5
Fix a cable with a commercial
item of tape.
Peel the release coated paper of double-face adhesive tape to
fix on the place shown above.
Adjust the direction of the microphone to the driver.
⁄
• Install the microphone as far as possible from the cellphone.
70 |
KDC-X995/ KDC-BT948HD
Troubleshooting Guide
Some functions of this unit may be disabled by
some settings made on this unit.
! • Cannot set up the subwoofer.
• No output from the subwoofer.
• Cannot set up the subwoofer position of Manual
position setting.
▲ • The Dual zone function is enabled.  <Dual Zone
System> (page 42)
• In the speaker select option, None is selected for
the subwoofer.  <Speaker Setting> (page 44)
! • Cannot set up the equalizer.
• Cannot set up the Bass Boost.
• Cannot set up the Highway sound.
• Cannot set up the Supreme.
• Cannot set up the Position control.
▲ • The Dual zone function is enabled.  <Dual Zone
System> (page 42)
• The DSP function is disabled.  “DSP Set” of <Audio
Control> (page 40)
• In the speaker select option, None is selected for
the rear speakers.  <Speaker Setting> (page 44)
! • Cannot select the output destination of the
subsource in the Dual zone.
• Cannot adjust the volume of the rear speakers.
▲ The Dual zone function is disabled.  <Dual Zone
System> (page 42)
! Cannot set up Display.
▲ <Demonstration mode Setting> (page 38) is not
turned off.
! The number of songs contained in “SONGS”
category of this unit is different from that
contained in “SONGS” category of iPod.
▲ Podcast files are not counted in this unit as this unit
does not support the playback of podcast files.
What might seem to be a malfunction in your unit
may just be the result of slight misoperation or
miswiring. Before calling service, first check the
following table for possible problems.
General
? The operation check sound (beep sound) does not
sound.
 The preout jack is being used.
 The Touch Sensor Tone cannot be output from
the preout jack.
? The illumination flashes when the knob or button
is operated.
 This is the key illumination effect.
 You set this effect in “ILLUMI Effect” of <Display
Setting> (page 30).
? The key illumination effect brought about in
conjunction with the sound volume is small.
 The key illumination effect may be insufficient
depending on the sound volume and sound quality.
Tuner source
? Radio reception is poor.
 The car antenna is not extended.
 Pull the antenna out all the way.
 Antenna Control wire is not connected.
 Connect the ANT.CONT wire.
Disc source
? The specified disc does not play, but another one
plays instead.
 The specified CD is quite dirty.
 Clean the CD, referring to the CD cleaning of the
section on <Handling CDs> (page 5).
 The disc is loaded in a different slot from that
specified.
 Eject the disc magazine and check the number
for the specified disc.
 The disc is severely scratched.
 Try another disc instead.
Audio file source
? The sound skips when an Audio file is being
played.
 The media is scratched or dirty.
 Clean the media, referring to the CD cleaning of
the section on <Handling CDs> (page 5).
 The recording condition is bad.
 Record the media again or use another media.
English |
71
Troubleshooting Guide
Hands-free
? The hands-free talk volume is low.
 The hands-free talk volume is set at a low level.
 The hands-free talk volume can be adjusted
independently. Adjust it during hands-free talk.
“Mic Gain” and “NR Level” <Bluetooth Setting>
(page 48).
? No sound is heard from the rear speakers.
CD-IN (Blink): The CD player section is not operating
properly.
 Reinsert the CD. If the CD cannot be
ejected or the display continues to flash
even when the CD has been properly
reinserted, please switch off the power
and consult your nearest service center.
Protect (Blink):
The speaker wire has a short-circuit or
touches the chassis of the vehicle, and then
the protection function is activated.
 Wire or insulate the speaker cable properly
and press the reset button. If the “Protect”
code does not disappear, consult your
nearest service center.
 You are talking in the hand-free talk mode.
 No sound is heard from the rear speakers in the
hands-free talk mode.
? No beep is heard at reception of an incoming call.
 No beep is heard depending on the type of your
cell-phone.
 The “Call Beep” of <Bluetooth Setting> (page 48) is
set ON.
? Voice is not recognized.
 The vehicle window is open.
 If the surrounding noise is large, voice cannot be
recognized properly. Close the vehicle windows
to reduce noise.
 Small voice.
 If voice is too small, it cannot be recognized
properly. Speak into the microphone a little more
loudly and naturally.
 The person uttering the voice tag is not the one who
registered the it.
 Only the voice of the person who registered the
voice tag can be recognized.
The messages shown below display your
systems condition.
TOC Error: ERROR 05: 72 |
Copy Protection:
A copy-protected file is played.
Read Error: The file system of the connected USB device
is broken.
 Copy the files and folders for the USB
device again. If the error message is still
displayed, initialize the USB device or use
other USB devices.
No Device:
The USB device is selected as a source
although no USB device is connected.
 Change the source to any source other
than USB. Connect an USB device, and
change the source to USB again.
No Disc:
Insert a playable disc into the loading slot.
N/A Device:
• An unsupported USB device is connected.
• Connection to the iPod has failed.
 Check that the connected iPod is an iPod
that is supported. See <iPod/iPhone that
can be connected to this unit> (page 60) for
information on supported iPods.
 Disconnect the USB device or the iPod,
and reconnect it.
• No disc has been loaded in the disc
magazine.
• The CD is quite dirty. The CD is upsidedown. The CD is scratched a lot.
The disc is unreadable.
ERROR 77/Mecha Error:
The unit is malfunctioning for some reason.
 Press the reset button on the unit. If the
“ERROR 77”/“Mecha Error” code does not
disappear, consult your nearest service
center.
ERROR 99: Unsupported File:
An Audio file is played with a format that this
unit can’t support.
Something is wrong with the disc magazine.
Or the unit is malfunctioning for some reason.
 Check the disc magazine. And then press
the reset button on the unit. If the “ERROR
99” code does not disappear, consult your
nearest service center.
KDC-X995/ KDC-BT948HD
No Music Data/Error 15:
• The connected USB device contains no
playable audio file.
• Media was played that does not have data
recorded that the unit can play.
USB ERROR:
Some trouble may have occurred to the
connected USB device.
 Remove the USB device, then cycle the
power switch to ON. If the same display is
repeated, use another USB device.
iPod Error:
Connection to the iPod has failed.
 Remove the USB device and then
reconnect it.
 Reset the iPod/iPhone.
No Access: The procedure preset with mixed preset
memory function cannot be available.
The preset content may not be recalled
depending on the selected band or source.
SIRIUS/ XM/ HD Radio Reception
Memory Full: The TAG Memory of HD Radio receiver is full.
iPod Memory: The iPod Memory is full.
No Tag Function:
iPod which does not support the tag Memory
is connected.
Tag Error: The unit is unable to complete transferring
the tagged information to the iPod.
N/A Channels: No receivable channel and category.
Bluetooth
No Number: • The calling party does not notify a caller ID.
• There is no phone number data.
No Data:
• There is no outgoing call list.
• There is no incoming call list.
• There is no missed call list.
• There is no phone book list.
No Entry: The cell-phone has not been registered
(pairing).
HF Disconnect: The unit cannot communicate with the cellphone.
HF Error 07: HF Error 68: The memory cannot be accessed.
 Turn off the power and on again. If this
message still appears, press the reset
button on the control unit.
The unit cannot communicate with the cellphone.
 Turn off the power and on again. If this
message still appears, press the reset
button on the control unit.
Un Known: The Bluetooth device cannot be detected.
Device Full: 5 Bluetooth device have already been
registered. No more Bluetooth device cannot
be registered.
Too Long: The word or utterance is too long to be
recognized.
No Phonebook:Data is not contained in the phone book.
No Message: No short message in In Box.
No Record: The voice tag is not registered in the phone
book.
Memory Full: The number of voice tags reaches the
maximum number to be registered in the
phone book.
No Voice: No call.
Pandora
Pandora Error 01:
Registration in Bookmark has failed..
Pandora Error 02:
Deletion of the station has failed.
Pandora Error 03:
Registration of the station has failed.
Pandora Error 04:
The number of registerable stations has been
exceeded.
Pandora Error 05:
Thumb up/down operation has failed.
Pandora Error 06:
Search has failed.
No Station:
No station is found.
Not available: The station does not have an available song.
No skips remaining:
The skip count limit has been exceeded.
Check Device:
Check the Pandora application of the iPhone.
PIN Code NG: The PIN code is wrong.
Connect NG: The unit cannot be connected to the device.
Pairing Failed: Pairing error.
Err No Matching:
The voice tag is wrong. Voice cannot be
recognized because of an unregistered voice
tag, etc.
Too Soft: Voice is too small and cannot be recognized.
Too Loud: Voice is too large to be recognized.
English |
73
Specifications
FM tuner section
Frequency range (200 kHz space)
: 87.9 MHz – 107.9 MHz
Usable sensitivity (S/N = 30dB)
: 9.3dBf (0.8 μV/75 Ω)
Quieting Sensitivity (S/N = 50dB)
: 15.2dBf (1.6 μV/75 Ω)
Frequency response (±3 dB)
: 30 Hz – 15 kHz
Signal to Noise ratio (MONO)
: 70 dB
Selectivity (±400 kHz)
: ≥ 80 dB
Stereo separation (1 kHz)
: 40 dB
Digital FM tuner section
Frequency range (200 kHz space)
: 87.9 MHz – 107.9 MHz
Frequency response (±3 dB)
: 20 Hz – 120 kHz
Signal to Noise ratio (STEREO)
: 70 dB
AM tuner section
Frequency range (10 kHz space)
: 530 kHz – 1700 kHz
Usable sensitivity (S/N = 20dB)
: 28 dBµ (25 µV)
Digital AM tuner section
Frequency range (10 kHz space)
: 530 kHz – 1700 kHz
Frequency response (±3 dB)
: 40 Hz – 15 kHz
Signal to Noise ratio (STEREO)
: 70 dB
Bluetooth section
Version
: Bluetooth Ver.2.0 Certified
Frequency range
: 2.402 – 2.480 GHz
Output Power
: +4dBm (MAX), 0dBm (AVE) Power Class 2
Maximum Communication range
: Line of sight approx.10m (32.8 ft)
Profiles
: HFP (Hands Free Profile)
: HSP (Headset Profile)
: SPP (Serial Port Profile)
: PBAP (Phone Book Access Profile)
: OPP (Object Push Profile)
: SYNC (Synchronization Profile)
74 |
KDC-X995/ KDC-BT948HD
USB Interface
USB Standard
: USB1.1/ 2.0 (Full speed)
Maximum Supply current
: DC 5 V
1A
File System
: FAT16/ 32
MP3 decode
: Compliant with MPEG-1/2 Audio Layer-3
WMA decode
: Compliant with Windows Media Audio
AAC decode
: AAC-LC ”.m4a” files
CD player section
Laser diode
: GaAlAs
Digital filter (D/A)
: 8 Times Over Sampling
D/A Converter
: 24 Bit
Spindle speed
: 500 – 200 rpm (CLV)
Wow & Flutter
: Below Measurable Limit
Frequency response (±1 dB)
: 10 Hz – 20 kHz
Total harmonic distortion (1 kHz)
: 0.008 %
Signal to Noise ratio (1 kHz)
KDC-X995: 110 dB
KDC-BT948HD: 105 dB
Dynamic range
: 93 dB
MP3 decode
: Compliant with MPEG-1/2 Audio Layer-3
WMA decode
: Compliant with Windows Media Audio
AAC decode
: AAC-LC “.m4a” files
Audio section
Maximum output power
: 50 W x 4
Full Bandwidth Power (at less than 1% THD)
: 22 W x 4
Speaker Impedance
: 4 – 8 Ω
Tone action (KDC-X995)
BAND1 (62.5 Hz): ±9 dB
BAND2 (250 Hz): ±9 dB
BAND3 (1 kHz): ±9 dB
BAND4 (4 kHz): ±9 dB
BAND5 (16 kHz): ±9 dB
Tone action (KDC-BT948HD)
BAND1 : 60 Hz - 400 Hz ±9 dB
BAND2 : 630 Hz - 2.5 kHz ±9 dB
BAND3 : 4.0 kHz - 16 kHz ±9 dB
Preout level / Load (CD)
: 4000 mV/10 kΩ
Preout impedance
: ≤ 600 Ω
Auxiliary input
Frequency response (±1 dB)
: 20 Hz – 20 kHz
Input Maximum Voltage
: 1200 mV
Input Impedance
: 10 kΩ
General
Operating voltage (10.5 – 16V allowable)
: 14.4 V
Maximum Current consumption
: 10 A
Installation Size (W x H x D)
: 182 x 53 x 158 mm
7-3/16 x 2-1/16 x 6-1/4 inch
Weight
: 2.9 lbs (1.30 kg)
• Specifications subject to change without notice.
English |
75
This symbol mark indicates that
Kenwood manufactured this product
so as to decrease harmful influence on
the environment.
