just add your TV
YHT-500
QUICK-CONNECT GUIDE
YHT-500 Q U I C K -C O N N E C T GU I D E
I NTRODUCTION
Yamaha developed the YHT-500 A/V Home Theater
package to turn your home into a theater. In addition to
enhancing the sound of a video source, like your TV,
DVD, or VCR, the YHT-500 also superbly reproduces
audio sources, such as a CD player or a cassette deck.
For the video portion, you will need a television or monitor.
Refer to the Yamaha HTR-5540 Ownerís Manual , as well as
those that came with your other components, for complete instructions and cautions. Be sure to turn off all
power while making connections.
This Quick-Connect Guide will help you get started.
Study the speaker system plan (below), and then use
the interconnect diagrams (on the following pages) to
connect the receiver and speakers to your system.
Save this Quick-Connect Guide for future reference.
NOTE: Label the end of each speaker wire (i.e., left rear, right
front, etc.) before connecting them to the A/V receiver. For wire
runs over 30 feet, use larger 18- or 16-gauge speaker wire.
T OOLS A ND P ARTS
∑ Wire strippers (optional)
The YHT-500 Home Theater package consists of
(1) HTR-5540 A/V receiver with (1) remote control,
DV-S5450 DVD Player with (1) remote control, (4) 2way NS-A329 front/rear speakers, (1) NS-AC329
2-way center-channel speaker (includes factory
installed rubber feet), (1) 100' of bulk speaker
speaker wire, (1) 0.5m optical cable,(1) 10' RCA
audio cable, (1) YST-SW005 Powered Subwoofer,
and related owner's manuals. You will also need:
∑ Brackets, toggle bolts, molly anchor screws, or sheet
metal screws (for securing NS-A329 speakers to
walls)
NOTE: If you are unsure of how to securely and safely fasten
speakers to a wall, please contact a reliable source about the best
type of hardware for your particular wall's construction.
Secure installation is the purchaser's responsibility.
S PEAKER S YSTEM P LAN
YST-SW005 Subwoofer (on floor)
C
NS-A329
(left side, same height as TV)
L
NS-AC329
(on top or below TV)
NS-A329
Sub
(right side, same height as TV)
R
6'~ 8' apart
L = Left Channel
R = Right Channel
C = Center Channel
S = Surround Channel
Couch
Listening Area
NS-A329
(on stand or wall, at least
ear level or preferably higher)
2
S
8'~10' apart
S
NS-A329
(on stand or wall, at least
ear level or preferably higher)
YHT-500 Q U I C K -C O N N E C T GU I D E
C ONNECTING AUDIO C OMPONENTS
Yamaha HTR-5540 Receiver (Rear Panel)
SPEAKERS
DIGITAL
INPUT
AUDIO
VIDEO
VIDEO
V-AUX
R
L
R
REAR
L
(SURROUND)
CENTER
TUNER
-
AM
ANT
CENTER
SUB
WOOFER
MAIN
-
SURROUND
+
L
R
CD
+
COAXIAL
6CH INPUT
MAIN
IN
OPTICAL
GND
VCR
DVD
AC OUTLETS
OUT
CD
75
D-TV
/CBL
IN
(PLAY)
MD
/CD-R
OUT
(REC)
UNBAL.
SWITCHED
120V 60Hz
0.8A MAX. TOTAL
100W MAX. TOTAL
IMPEDANCE SELECTOR
SET BEFORE POWER ON
FM
ANT
MAIN
CENTER
REAR
: 4 MIN. /SPEAKER
: 6 MIN. /SPEAKER
: 6 MIN. /SPEAKER
MAIN
CENTER
REAR
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
DVD
L
R
SUB
WOOFER
MONITOR
OUT
VIDEO
AUDIO
OUTPUT
NOTE: For your convenience, the Yamaha HTR-5540 receiver is equipped with
two switched AC outlets (100 W max.). If desired, use them to power on connected
components (e.g.,CD player) each time the receiver is turned on. However, do not
use them for components equipped with clocks (e.g.,VCR).
Cassette Deck,
CD or MD Recorder
* Use Playback Or Line Out
** Use Line In
CD Player (Changer)
R Out*
L Out
R Out
R
L
R
L
L Out*
R In** L In**
DVD
CD
IN
(PLAY)
MD
/CD-R
OUT
(REC)
Use RCA Audio Cables For Audio Interconnections
AUDIO
RCA Cable Color Codes
White = Left Audio
Red = Right Audio
3
YHT-500 Q U I C K -C O N N E C T GU I D E
C ONNECTING T HE YHT-500 S PEAKERS
NS-A329
(Front Right Ch.)
NS-A329
(Front Left Ch. )
NS-AC329
(Center Channel)
RED = positive (+)
use clear wire
_+
BLK = negative (-)
use clear with
white stripe wire
_
Strip 1/4" off ends of
speaker wires.
Stripe
Wire
Loosen terminals.
+
Insert speaker wires;
tighten terminals.
_
Stripe
Wire
_
+
Stripe
Wire
Speaker
Wiring
+
SPEAKERS
DIGITAL
INPUT
6CH INPUT
AUDIO
VIDEO
MAIN
VIDEO
R
-
AM
ANT
CENTER
SUB
WOOFER
L
REAR
L
(SURROUND)
CENTER
TUNER
+
Yamaha HTR-5540
A/V Receiver
(Rear Panel)
V-AUX
SURROUND
MAIN
R
CD
-
L
R
+
COAXIAL
IN
OPTICAL
GND
VCR
DVD
AC OUTLETS
OUT
CD
75
D-TV
/CBL
IN
(PLAY)
MD
/CD-R
OUT
(REC)
UNBAL.
IMPEDANCE SELECTOR
SET BEFORE POWER ON
FM
ANT
MAIN
CENTER
REAR
: 4 MIN. /SPEAKER
: 6 MIN. /SPEAKER
: 6 MIN. /SPEAKER
MAIN
CENTER
REAR
SWITCHED
120V 60Hz
0.8A MAX. TOTAL
100W MAX. TOTAL
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
DVD
L
R
SUB
WOOFER
MONITOR
OUT
VIDEO
AUDIO
OUTPUT
Set IMPEDANCE Selector
to right position.
YST-SW005
(Subwoofer)
Stripe
Wire
_
VOLUME
0
+
AUTO
STANDBY
10
HIGH
HIGHCUT
LOW
HIGH
LOW
OFF
INPUT2
INPUT2
/MONO
/MONO
Stripe
Wire
_
+
INPUT1
FROMAMPLIFIER
OUTPUT
TOSPEAKERS
POWER
ON
OFF
To AC outlet
NS-A329
(Surround Right)
4
NS-A329
(Surround Left)
YHT-500 Q U I C K -C O N N E C T GU I D E
C ONNECTING V IDEO C ABLES FOR V IDEO C OMPONENTS
Yamaha HTR-5540 Receiver (Rear Panel)
SPEAKERS
DIGITAL
INPUT
AUDIO
VIDEO
VIDEO
V-AUX
L
R
-
AM
ANT
CENTER
SUB
WOOFER
MAIN
R
REAR
L
(SURROUND)
CENTER
TUNER
-
SURROUND
+
L
R
CD
+
COAXIAL
6CH INPUT
MAIN
IN
OPTICAL
GND
VCR
DVD
AC OUTLETS
OUT
CD
75
D-TV
/CBL
IN
(PLAY)
MD
/CD-R
OUT
(REC)
UNBAL.
SWITCHED
120V 60Hz
0.8A MAX. TOTAL
100W MAX. TOTAL
IMPEDANCE SELECTOR
SET BEFORE POWER ON
FM
ANT
MAIN
CENTER
REAR
: 4 MIN. /SPEAKER
: 6 MIN. /SPEAKER
: 6 MIN. /SPEAKER
MAIN
CENTER
REAR
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
DVD
L
R
SUB
WOOFER
MONITOR
OUT
VIDEO
AUDIO
OUTPUT
NOTE: When using a hi-fi stereo VCR, set the Tuner/Line switch
(on the VCR) to Line position to record from another source
connected to the Yamaha HTR-5540 receiver.
Satellite Receiver
(or Cable Box)
AUDIO
Video Out
R
VIDEO
L
VIDEO
V-AUX
Video Out
Hi-Fi Stereo VCR
IN
DVD Player
(or Video Game)
VCR
ANT Out
(RF Out)
OUT
Video In
D-TV
/CBL
DVD
Video Out
MONITOR
OUT
VIDEO
Monitor/TV
Use RCA Video Cables And Jacks For Video Interconnections
Video In
Optional 75-ohm
Coaxial Cable
ANT In
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
5
YHT-500 Q U I C K -C O N N E C T GU I D E
C ONNECTING T HE Y AMAHA DV-S5450 DVD P LAYER
Yamaha HTR-5540 Receiver (Rear Panel)
SPEAKERS
DIGITAL
INPUT
AUDIO
VIDEO
MAIN
VIDEO
V-AUX
R
L
REAR
L
(SURROUND)
R
-
AM
ANT
CENTER
SUB
WOOFER
MAIN
CENTER
TUNER
-
SURROUND
+
L
R
CD
+
COAXIAL
6CH INPUT
IN
OPTICAL
GND
VCR
DVD
AC OUTLETS
OUT
CD
75
D-TV
/CBL
IN
(PLAY)
MD
/CD-R
OUT
(REC)
UNBAL.
SWITCHED
120V 60Hz
0.8A MAX. TOTAL
100W MAX. TOTAL
IMPEDANCE SELECTOR
SET BEFORE POWER ON
FM
ANT
MAIN
CENTER
REAR
: 4 MIN. /SPEAKER
: 6 MIN. /SPEAKER
: 6 MIN. /SPEAKER
MAIN
CENTER
REAR
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
DVD
L
R
SUB
WOOFER
MONITOR
OUT
VIDEO
AUDIO
OUTPUT
R
RCA Cable Color Codes
DIGITAL
INPUT
COAXIAL
CD
Yellow = Video
White = Left Audio
Red = Right Audio
AUDIO
R
L
VIDEO
L
Use an RCA Video Cable And Jacks
For Video Interconnections
V
VIDEO
V-AUX
IN
VCR
OPTICAL
OUT
DVD
POWER
D-TV
/CBL
Optical Cable
(Included)
1
2
4
5
7
8
RETURN/RESUME
DVD
3
6
9
BIT RATE
MENU
ON SCREEN
ENTER
OK
MONITOR
OUT
STOP
PLAY
PAUSE
VIDEO
SUBTITLE ANGLE ZOOM AUDIO
REPEAT Ñ A B
SHUFFLE SCAN
Note: You will need the DVD
remote to fully operate this
system. Please refer to the
DV-S5450 owner's manual
for complete remote and
DVD player instructions.
DVD
Yamaha DV-S5450 DVD Player (Rear Panel)
AUDIO OUT
PCM
DIGITAL
DTS MPEG
NOTE: Use the optical connection to enjoy 5.1 - channel surround sound
found on DVDs recorded in the Dolby Digital or DTS Digital Surround format.
COAXIAL
OPTICAL
SUBWOOFER
1
1
2
2
R
L
VIDEO
VIDEO OUT
PR
PB
Y
COMPONENT VIDEO
S VIDEO
Connecting Optical Cable
*Analog Audio Out connections are required for playback of CD-Rs and
recording from DVD to VCR.
Dolby Digital is a trademark of Dolby Laboratories Licensing Corporation.
DTS is a trademark of DTS Technology LLC.
Remove dust cap.
NOTES:
Align plug with terminal
and insert cable.
∑ On both ends of the optical cable, align and firmly insert
each plug into its mating terminal.
6
∑ During connection, do not bend the optical cable.
∑ Keep dust caps and reattach them if terminals are not used.
YHT-500 Q U I C K -C O N N E C T GU I D E
C ONNECTING AUDIO C ABLES F OR V IDEO C OMPONENTS
Yamaha HTR-5540 Receiver (Rear Panel)
SPEAKERS
DIGITAL
INPUT
AUDIO
VIDEO
MAIN
VIDEO
V-AUX
L
R
-
AM
ANT
CENTER
SUB
WOOFER
MAIN
R
REAR
L
(SURROUND)
CENTER
TUNER
-
SURROUND
+
L
R
CD
+
COAXIAL
6CH INPUT
IN
OPTICAL
GND
VCR
DVD
AC OUTLETS
OUT
CD
75
D-TV
/CBL
IN
(PLAY)
MD
/CD-R
OUT
(REC)
UNBAL.
SWITCHED
120V 60Hz
0.8A MAX. TOTAL
100W MAX. TOTAL
IMPEDANCE SELECTOR
SET BEFORE POWER ON
FM
ANT
MAIN
CENTER
REAR
: 4 MIN. /SPEAKER
: 6 MIN. /SPEAKER
: 6 MIN. /SPEAKER
MAIN
CENTER
REAR
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
DVD
L
R
SUB
WOOFER
MONITOR
OUT
VIDEO
AUDIO
OUTPUT
NOTE: When using a hi-fi stereo VCR, set the Tuner/Line switch (on the VCR) to Line
position to record from another source connected to the Yamaha HTR-5540 receiver.
Video Player
(or Video Game Console)
Audio L Out
Audio R Out
Satellite
Receiver
(or Cable Box)
Hi-Fi Stereo VCR
R
R
AUDIO
L
VIDEO
L
V
VIDEO
V-AUX
Audio
L Out
Audio
R Out
Audio
L In
Audio
R In
IN
VCR
Audio L Out
Audio R Out
OUT
D-TV
/CBL
DVD
MONITOR
OUT
VIDEO
RCA Cable Color Codes
Use RCA Audio Cables And Jacks For Audio Interconnections
Yellow = Video
White = Left Audio
Red = Right Audio
7
YHT-500 Q U I C K -C O N N E C T GU I D E
C ABLE H OOK -U P (B ASIC A ND P REMIUM C HANNELS )
Yamaha HTR-5540 Receiver (Rear Panel)
SPEAKERS
DIGITAL
INPUT
AUDIO
VIDEO
VIDEO
V-AUX
R
L
REAR
L
(SURROUND)
R
-
AM
ANT
CENTER
SUB
WOOFER
MAIN
CENTER
TUNER
-
SURROUND
+
L
R
CD
+
COAXIAL
6CH INPUT
MAIN
IN
OPTICAL
GND
VCR
DVD
AC OUTLETS
OUT
CD
75
D-TV
/CBL
IN
(PLAY)
MD
/CD-R
OUT
(REC)
UNBAL.
SWITCHED
120V 60Hz
0.8A MAX. TOTAL
100W MAX. TOTAL
IMPEDANCE SELECTOR
SET BEFORE POWER ON
FM
ANT
MAIN
CENTER
REAR
: 4 MIN. /SPEAKER
: 6 MIN. /SPEAKER
: 6 MIN. /SPEAKER
MAIN
CENTER
REAR
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
: 8 MIN. /SPEAKER
DVD
L
R
SUB
WOOFER
MONITOR
OUT
VIDEO
AUDIO
OUTPUT
NOTE: When using a hi-fi stereo VCR, set the Tuner/Line
switch (on the VCR) to Line position to record from another
source connected to the Yamaha HTR-5540 receiver.
Hi-Fi Stereo VCR
ANT In
Basic Cable
(From Wall Jack)
Video In
Video Out
R
AUDIO
Audio
L In
OR
Audio
R In
Audio
R Out
VIDEO
L
L
R
Audio L Out
V
VIDEO
V-AUX
IN
RCA Audio Cables
VCR
OUT
RCA Audio Cables
RCA Video
Cables
D-TV
/CBL
DVD
MONITOR
OUT
Premium Cable
(From Wall Jack)
VIDEO
Hi-Fi Stereo VCR
Cable
Box
(Channel 3 or 4
Output)
ANT In
(Tuner set to Channel 3 or 4)
Video In
Video Out
R
R
Audio
L In
Audio
R In
Audio
R Out
Audio L Out
AUDIO
VIDEO
L
L
V
VIDEO
V-AUX
RCA Audio Cables
IN
VCR
OUT
RCA Audio Cables
RCA Video
Cables
D-TV
/CBL
DVD
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
8
MONITOR
OUT
VIDEO
YHT-500 Q U I C K -C O N N E C T GU I D E
I NITIAL A DJUSTMENT OF T HE YST-SW005 S UBWOOFER
To achieve the optimum volume balance between the
4. Play an audio source and adjust the HTR-5540's
YST-SW005 Subwoofer and the NS-A329 Main Speakers,
VOLUME control to a desired listening level.
perform the following procedure:
5. Increase the YST-SW005 volume control gradually to
1. Insert the YST-SW005 power plug into a nearby AC outlet. adjust the balance and volume between the YST-SW005
Subwoofer and the NS-A329 Main Speakers.
2. Set the YST-SW005 VOLUME control to 0 (minimum
setting), the AUTO STANDBY switch to HIGH, and
NOTE: Once the volume is balanced between the
the HIGH CUT switch to LOW.
subwoofer and the main speakers, you can adjust the
volume of your whole sound system by using the
3. Press the YST-SW005 POWER button to ON and
HTR-5540's VOLUME control.
power on all other components.
YST-SW005 Subwoofer
(Rear Panel)
2
VOLUME
VOLUME
0
AUTO
STANDBY
POWER
ON
3
OFF
5
10
HIGH
HIGH CUT
LOW
HIGH
LOW
OFF
AUTO
STANDBY
INPUT2
/MONO
HIGH
LOW
OFF
0
HIGH
LOW
10
HIGH CUT
INPUT1
FROM AMPLIFIER
OUTPUT
TO SPEAKERS
POWER
ON
OFF
1
To AC Outlet
9
YHT-500 Q U I C K -C O N N E C T GU I D E
THE R EMOTE C ONTROL
The YHT-500 Home Theater package includes a
remote control. It comes pre-programmed to
control your HTR-5440 receiver.
I NSTALLING B ATTERIES I N THE R EMOTE C ONTROL
Insert the batteries in the correct direction by aligning the
+ and - marks on the batteries with the polarity markings
(+ and -) inside the battery compartment.
POWER
SLEEP
DVD
D-TV/CBL
VCR
V-AUX
CD
TUNER
PRESET
2
1
6CH INPUT
+
MD/CD-R
Input
Selector
Buttons
A/B/C/D/E
PROGRAM
3
HALL
JAZZ
CLUB
ROCK
CONCERT
ENTERTAINMENT
TV
SPORTS
MONO
MOVIE
1
1
Press the
part and slide off the battery
compartment cover.
2
Insert the 2 supplied batteries (AA) according
to the polarity markings on the inside of the
battery compartment.
3
Slide the cover back on so that it snaps into
place .
MOVIE
- THEATER - 2
/ DTS
SUR.
MATRIX
6.1
SELECT
LEVEL
SET MENU
-
+
DSP
TEST
STEREO
EFFECT
MUTE
P OWER O N /Off
1. Aim the remote control at the receiver, press POWER.
2. The receiver should turn on.
3. Press the POWER button again to turn the receiver off.
10
Turns On
Receiver's
Power
VOLUME
Surround Sound
Program Selection
Used to Adjust
Receiver Settings
©2002 YAMAHA ELECTRONICS CORPORATION, USA
6660 Orangethorpe Avenue, Buena Park, CA 90620
PH: (714) 522-9105; FAX: (888) 435-7922
http://www.yamaha.com
