The Kodak i780 Scanner is designed to handle mission
critical, production applications. It’s loaded with features
that are optimized for production forms processing and
data extraction environments. This scanner offers
exceptional speed, price and performance.
The i780 Scanner runs at 130 pages per minute whether
you are scanning at 200 or 300 dpi and it delivers
incredible image quality with super-fast image processing
technologies. Yet, the auto feeder is sensitive enough to
handle fragile and lightweight paper without damage.
The Kodak i780 Scanner raises the bar and operates at
the same rated speed, even with advanced image
processing features enabled, including our new content-based auto orientation/auto rotation.
Simply put, there’s nothing but performance and precision under the hood of the i780 Scanner.
Features at a Glance
•
TWAIN Datasource — features an easy-to-use TWAIN Datasource GUI that allows users to
save and select from several pre-configured scanner settings (called Setting Shortcuts). The
programmatic interface remains the same as our earlier TWAIN Datasource so support of
third party scanning applications will continue to be robust.
•
Lockable paper-feeding guides — for better control of the printing location.
•
Enhanced Printer — includes a factory-installed, pre-configured front printer. The printer
operates at full scanner speed and can add a date, time, document sequential counter, and
custom messages.
•
Five Output options — meet essentially every application need. Choose, color, black and
white, grayscale, simultaneous black and white and grayscale, or simultaneous black and
white and color.
•
Outstanding Document Feeding — Kodak’s renowned feeder technology is designed into
the scanner.
Exclusive SurePath Paper Handling — the i780 Scanner is virtually jam-free and damagefree because it’s designed for smooth paper transport from input to output.
Resolutions — black and white: 200/240/300/400; color: 100/150/200/240/300;
grayscale: 100/150/200/240/300.
Independent settings for ultrasonic multifeed sensors — the three ultrasonic document
sensors can be independently enabled/disabled to further customize and increase
productivity.
Kodak Manual Feeder — the Kodak Manual Feeder provides a flat work surface to aid in
manual feeding.
Multiple automatic document feeder elevator settings — the elevator can now be set to
four settings — 500-, 250-, 100-sheets and manual — for added versatility and productivity.
•
•
•
•
•
January 2008
1
•
•
•
•
•
•
•
•
•
•
•
34 in. maximum document length — the maximum document length that can be fed has
been increased to 34 inches for all resolutions and with all cropping methods in black and
white and color/grayscale.
Dual xenon lamps — two long-lasting, mercury-free Xenon lamps per side give you
maximum illumination to help eliminate shadows from wrinkled documents.
Auto Color Detection ⎯ allows your scanner to automatically scan in color or grayscale
when it senses that the color content of specific documents within a batch is above a set
threshold. Based on the threshold you set, your scanner determines when to scan in color or
grayscale.
Perfect Page scanning with iThresholding — Perfect Page scanning with iThresholding is
essential when you are scanning mixed batches of documents of varied contrast in
background and/or text.
Orthogonal rotation — allows you to feed documents in landscape orientation (faster
throughput), but display the scanned images in portrait orientation (convenient viewing).
Auto Orientation/Auto Rotation — this feature automatically analyzes each document to
determine how it was fed into the scanner and will rotate the image to the proper orientation.
Toggle patch — enable color or grayscale on-the-fly processing with the Toggle patch.
Attractive, compact design, quiet — big scanning volume, small size. The desktop design
means it fits just about anywhere.
Section 508-compliant — offers easy access to all controls, user replaceable parts and the
entire transport.
Advanced image processing — offers incredibly clear scans in color, black and white, and
grayscale.
Tricolor Plus CCD Sensor — exceptional image quality and readability are automatic.
January 2008
2
P
N
ON
TIIO
PT
RIIP
CR
ESSC
DE
TD
CT
UC
DU
OD
RO
PR
What’s in the box?
•
•
•
•
•
•
•
•
•
•
•
Kodak i780 Scanner
Output tray
Short document tray
Ink cartridge and blotter strips
Tires and Pre-separation pads
Cleaning supplies
FireWire (IEEE-1394) package (card and cable)
Calibration targets
Exit deflector
Power cord bundle
Warranty/Registration box
Paper Path cleaner
User’s Guide (printed English version)
Installation and application CDs
Registration card
Brightness and Contrast Control CD
Brightness and Contrast Control Reference Guide
Quick Tips Guide (printed 14-language pack)
Installation Setup Guide (printed 14-language pack)
Read Me Now sheet (14-language)
System requirements
•
•
•
•
Intel Pentium IV, 2.5 GHz processor, 512 MB RAM
PCI slot
Windows 2000 (Service Pack 4), Windows XP (Service Pack 2) and Windows Vista (32-bit)
Monitor and mouse
January 2008
3
Physical dimensions
Height: 40.6 cm / 16 in.
Width: 60.9 cm / 24 in.
H
Length: 76.2 cm / 30 in.
L
Weight: 38.6 kg / 85 lbs
W
Environmental conditions
Operating Temperature:
10°C to 35°C (50° to 95°F)
Humidity:
10 to 85%
Environmental Factors:
Energy Star qualified scanners
Heat Load:
2500 BTU/hr. max
Acoustic Noise:
Operating: 61 dB(A)
Standby: 42 dB(A)
Speeds
Scanning speeds will vary depending on a number of conditions, including software application,
size of paper scanned, selected resolution, and PC speed. The table below shows typical speeds
in pages per minute (ppm) for A4 or letter-sized paper scanned.
Resolution
Color/Gray
Black and
White
100
150
200
200
240
240
300
300
400
Landscape
ppm
Portrait
ppm
130
130
130
130
130
<130
105
105
105
105
105
<105
NOTE: Throughput speeds may vary depending on driver, application software, operating system
and PC.
January 2008
4
Scanner components
Front view
10
5
8
4
7
3
6
12
2
9
1
11
1
Elevator tray extender — open the elevator tray extender to accommodate long documents.
2
Feed module — provides smooth document feeding of various sizes, thicknesses and
textures.
3
Elevator tray side guides — slide the guides in or out to accommodate the document size
you want to scan. Side guides can be left-, center- and right-adjusted to accommodate
documents of various widths. Side guides also lock in place to hold the print location.
4
Gap Release lever — allows you to manually adjust the space between the feed module and
separation roller for documents that require special handling.
5
Output tray and End stop — collects the scanned documents. The output tray width and end
stop length can be adjusted.
Short Document tray (not shown in illustration) — for best stacking performance, the short
document tray can be used when scanning documents from 6.4 x 6.4 in. (164 mm x 164 mm)
to 2.5 x 2.5 (64 mm x 64 mm)
6
POD release latch — push up the POD release latch when you need to access the inside of
the scanner.
7
Stop/Pause and Start/Resume buttons:
•
Stop/Pause button: (white with red triangle) press to temporarily stop scanning.
•
Start/Resume button: (green) press to start scanning.
January 2008
5
8
LEDs — illuminates or flashes from top to bottom as follows:
Illuminates when the power is turned on and the scanner is idle.
This indicator will flash if the scanner is in “sleep” or lamp saver
mode.
Illuminates when the scanner is enabled and/or scanning, and
flashes when the scanner is powering up.
Flashes when a document has jammed in the transport or when a
multi-feed has been detected. Illuminates when a user-correctable
error has been detected.
Illuminates when you need to call Service.
9
Power switch — press the power switch on (I) or off (O) as required.
10 Exit deflector (optional) — aids in document stacking.
11 Paper Present Sensor — detects the presence of documents in the elevator tray.
12 Height Adjustment Wire — located underneath the output tray (not shown in photo), this wire
can be pulled out to raise the front of the output tray.
January 2008
6
Inside view
6
3
2
1
5
6
1
Separation roller — provides smooth document feeding of various sizes and textures one
document at a time.
2
Ink blotter strips — collects residue from the Enhanced Printer.
3
Imaging guides — the scanner has an upper and lower imaging guide. It is important to keep
the imaging guides clean to obtain optimum image quality.
4
Rollers — drive rollers and NFR rollers transport the documents through the paper path.
5
Pre-separation pad — provides smooth document feeding of various sizes and textures one
document at a time.
6
Sensors — the scanner has 3 (ultrasonic) multi-feed detection sensors, 1 (optical) paper path
sensor and 1 (optical) paper present sensor. These sensors detect the presence of
documents in the elevator tray and documents in the paper path during feeding and imaging.
January 2008
7
Back view
Power cord connection
Retainer clip
FireWire (IEEE 1394)
connection
Power Cord Connection — provides power to the scanner. The scanner is packed with six
power cords. Choose the power cord appropriate for your location and connect it accordingly.
Connect the power cord first to the scanner, then to the wall outlet.
FireWire (IEEE-1394) Connection — before connecting the FireWire cable, be sure that power
to the scanner is off.
Retainer clip — after connection, place the cable in the retainer clip located above the connector.
January 2008
8
P
ESS
RE
UR
TU
AT
EA
FE
TF
CT
UC
DU
OD
RO
PR
While the i780 Scanner looks similar to the i600 Series
Scanners, it incorporate the latest innovative design,
technology, features as well as exceptional
price/performance that customers demand.
Under the hood, a new architecture allows customers
to scan their documents with advanced image
processing features enabled in color, black and white,
and grayscale and all at the same speed. Kodak’s firstin-class feeding technology allows easy capture of
mixed batches of business documents, photos,
graphics, and tear sheets for processing, archiving and
sharing. The i780 Scanner has a recommended daily
volume up to 130,000 pages per day.
SCANNER FEATURES
Locking side guides
It’s as easy to moving a switch to lock the side guides for better control of the printing location.
Easy to use, meets ergonomic design standards
We’ve made the i780 Scanner easy to operate and tough to beat:
•
500-sheet elevator tray for easy paper feeding which can be pre-set to accommodate different
batch sizes.
•
Easy-to-reach input and output trays making it easy to load and unload documents.
•
Easy access to the complete paper path allows you to clear the paper path quickly and
perform efficient scanner maintenance.
•
Easy-open design allows you to open the cover with a touch of the release lever.
•
Easy-to-change rollers and feed module.
Kodak SurePath Paper Handling
Kodak SurePath Paper Handling means you have the confidence that documents will “fly” through
the scanner under control. Kodak’s Document Imaging scientists and engineers analyzed years of
production scanner feedback from the Kodak service organization’s tracking system and took the
best paper transport system in the industry and made it better. This includes new feeder
geometry, redesigned feeding mechanisms, an improved drive train and a host of other
enhancements that maximize throughput and reduce noise.
January 2008
9
Paper Handling and Feeding
The input tray and automatic document feeder of the i780 Scanner is designed to stack and feed
up to 500 sheets of 75 g/m2 (20 lb.) bond paper reliably across the specified range of document
sizes.
The feeder accepts a wide variety of paper weight, with no operator intervention necessary after
the initial loading. While the automatic document feeder works best with similar size documents, it
also handles the feeding of mixed document sets (batches) consisting of varying paper weight
and sizes in a reliable manner.
The feeder includes a gap release for the operator to easily bypass the separation feature when
feeding documents such as folders or envelopes.
Auto Orientation/Auto Rotation
For documents that contain mostly text, the scanner will analyze each document to determine
how it was fed and will rotate the image to the proper orientation at rated speed.
Ultrasonic Multifeed Detection
A reliable ultrasonic multi-feed detection system has been integrated into the i780 Scanner. Three
detection zones allow for greater feeding flexibility and can be independently enabled/disabled to
further customize and increase productivity of a scanning application. (left-, center-, and rightedge) while still benefiting from multi-feed detection.
Sensors may be enabled or disabled, depending on your application. For example, if you know
that the right side of the document has a Post ItTM on it, you can disable the right sensor.
Multi-feed detection is enabled through the host software. Sensitivity levels (high, medium and
low) can be set to control how aggressively the scanner will work to determine if more than one
document is fed into the transport. Multi-feeds are triggered by detecting air gaps between
documents. This allows multi-feed detection to be used with applications containing documents
with mixed thicknesses.
•
High sensitivity is the most aggressive setting and good to use if all documents are similar in
thickness of no greater than 75 g/m2 (20 lb.) bond paper.
•
Medium sensitivity is the default and good to use if your application has varying document
thicknesses or labels attached to the documents.
•
Low sensitivity is the least aggressive setting and is less likely to detect labels, poor quality
or wrinkled documents as multi-fed documents.
The operator can select either option when the system determines that multiple documents have
been fed through the scanner.
•
Beep and Continue: beeps when a multifeed has been detected and will continue scanning.
•
Beep and Stop: beeps when a multifeed has been detected and stops scanning. When this
occurs, the scanner will need to be re-enabled to resume scanning.
•
Beep and Pause: beeps when a multifeed has been detected and pauses scanning. When
this occurs, the operator can quickly resume scanning by pressing the start button on the
scanner.
January 2008
10
Diagnostic Software (for use by Kodak Service Personnel)
Robust diagnostic software for the i780 Scanner provides maximum uptime and optimum
performance for the customer. Comprehensive hardware analysis and problem determination in
the software allows a high success rate in resolving the root cause of problems via remote
analysis. When on-site service is required, the diagnostic analysis allows the Field Engineer to
better understand the nature of the problem and be prepared with the appropriate service parts
before going on site.
Features of diagnostics include the ability to provide error logs that can be e-mailed or faxed to
the Response Center at Kodak for further analysis.
Optics
The design heritage of the M-type Kodak lens used in the i780 Scanner comes from a highresolution production scanner developed for complex character scanning. The lens also
incorporates an infrared filter with its lead-free multiple elements. This reduces light loss
and eliminates alignment of the infrared filter to the lens. The infrared filter reduces warm-up time
by providing a more “color stable” light output to the CCD when the lamps have just been turned
on, as well as during operation.
Unlike competitive scanners, which use off-the-shelf lenses, the additional glass elements in the
i780 Scanner’s lens provide a greater depth of focus to keep thin-to-thick and light-to-heavy
documents in focus. In addition, the scanner’s lens keeps outer edges in focus so they have
virtually the same clarity as the center of the document.
Tri-Color Plus Array
The Tri-Color Plus Array is built on a rich foundation of Kodak CCD technology. Produced by the
Kodak Image Sensor Solution division (ISS) via specifications created by Kodak’s Document
Imaging Scanner Engineering and Advanced Development teams, the Tri-Color Plus Array is the
fastest, most accurate and advanced chip available today. This CCD is exclusive to Document
Imaging.
One array contains the red, green, blue and luminance (grayscale) sensors. This provides cleaner
image transmission (focusing the lens on one array), and since the grayscale image is created in
conjunction with the color image, you have the ability to use grayscale image elements in the
color image processing chain for a sharper image and to maximize image purity in dark regions of
the image.
January 2008
11
Enhanced Printer
The Enhanced Printer provides a vertical print capability and supports alphanumeric characters,
date, time, document count and custom messages. The Enhanced Printer is unique in that the
document print string can be configured to include both static information (i.e., information that
stays the same for each document, such as scan station or operator) and dynamic information
(i.e., information that may change for each page scanned, such as time or sequential document
number). All printer controls and functions are accessible via the ISIS and TWAIN Drivers.
The Enhanced Printer cartridge is a standard HP print head and affords the
customer an inexpensive and effective way to apply information to the scanned
document.
See the User’s Guide for details on the printing functionality.
Printer specifications
Maximum lines: 1
Print locations (horizontal): 8 front manually set
Print locations (vertical): set by the scanning application
Print orientation: 0, 90, 180 and 270
Feed Direction
0
90
180
270
Font size: 2 selectable, Normal and Bold.
Number of characters in print string: 40
Ink cartridge: HP-C6602A Black (CAT No. 818 3386); HP-C6602R, Red (CAT No. 159 6832) or
compatible. Other print cartridges are also available from your office supply vendor:
HP-C6602G (Green) and HP-C6602B (Blue). For more information regarding supplies and
consumables, refer to the Supplies and Consumables catalog, A-61403.
Print side: front (pre-scan).
Minimum printing distance from document edge: 0.89 cm (0.35 in.).
Static fields available: user-specified messages via the scanning application.
Dynamic fields available: up to 9-digit sequential document number, date, 4-digit time.
Languages supported: Any phonetic language (for example, Danish, Dutch, English, Finnish,
French, German, Italian, Norwegian, Portuguese, Spanish, Swedish, Half-width Katakana)
January 2008
12
Kodak Capture Software and bundled ISIS Driver and TWAIN Datasource
The ISIS Driver and TWAIN Datasource are shipped with the scanner and can be installed from
the CD. The scanner host system is the primary means of controlling the scanner. The TWAIN
Datasource and ISIS Driver-compliant enabling software from Pixel Translations supports
Microsoft Windows 2000 Professional, Windows Me, Windows 98SE, Windows XP
(Professional/Home).
The newly designed TWAIN Datasource graphical user interface allows users to save and select
from several pre-configured scanner settings (called Setting Shortcuts). The programmatic
interface remains the same as our earlier TWAIN Datasource so support of third party scanning
applications will continue to be robust.
500-sheet Elevator Tray
End user feedback in the mid-volume segment indicated a strong desire for a higher volume, yet
reliable feeder. The i780 Scanner offers elevator-feed or continuous-feed, when the elevator is in
the up-position. In addition, the elevator can now be set to four settings for added versatility and
productivity: 500-, 250-, 100-sheets and manual. The Start/Resume button on the control panel is
also active; therefore, it can reverse direction if it is pressed while the elevator is descending,
saving valuable time between batches.
Flexible Feeder and Output Tray
Mid-volume operations typically include multiple applications with variable feeding requirements.
Traditional center-line-only feeders do not meet the needs of these operations. Voice of the
Customer feedback strongly indicated a desire for left-edge feeding. The side guides allow for leftedge feeding, right-edge feeding, center-line feeding or an infinite number of variable feeder
widths not constrained to a center line (the side guides may be moved together or independently
and may be reset to auto center-line by simply pushing the side guides to the center). In addition,
use the short document tray when you are feeding small documents.
Customer Maintenance
The i780 Scanner was designed with minimal operator maintenance in mind. The scanners use
long-lasting transport rollers and lamps. The only required scanner consumables are the feed
module, imaging guides, ink cartridges and the separation roller, which are easily replaced by the
operator.
The Kodak Feeder Consumables Kit has an estimated life of 1,750,000 pages of non-abrasive, A4
or letter-sized, 75 g/m2or 20 lb. bond paper. For more information regarding consumables and
supplies, refer to the Supplies and Consumables catalog, A-61403.
January 2008
13
Integration
For the most up-to-date listing of completed integrations, go to the Kodak web site at
www.kodak.com/go/ScannerISVs.
IEEE-1394 (FireWire) Interface
Reduce setup and installation time with plug-and-play simplicity. The IEEE-1394 (FireWire) card
and cable are shipped with the scanner.
Accessories
Kodak Feeder Kit for Ultra-Lightweight Paper — CAT No. 896 5279
The Kodak Feeder Kit for Ultra-Lightweight Paper allows you to feed
lightweight paper from a paper weight range of 25 g/m2 to 75 g/m2
(7 to 20 lb.). This accessory includes a feed module and separation
roller that are specially designed to feed lightweight paper through
the scanner transport.
Kodak White Background Accessory — CAT No. 894 9000
If you are scanning translucent documents, this accessory will reduce
black background bleed-through while scanning thus producing
whiter images. The White Background Accessory comes with two
white background strips that easily replace the two black background
strips in the scanner.
Kodak Manual Feeder — CAT No. 163 4948
The Kodak Manual Feeder is available for manual feeding of documents.
This feeder provides a flat surface for easy feeding.
January 2008
14
IMAGE PROCESSING FEATURES
Advanced image processing capabilities have long been the hallmark of document image
scanners. The i780 Scanner advances image processing to a new level, taking all the best and
adding more. Full-speed image processing in color, grayscale and black and white arenas in a
scanner of this capability offers an unparalleled opportunity for today’s demanding document
management systems. The table below outlines the image processing features available for
color/grayscale and black and white images. Remember that the i780 Scanner processes images
at full rated speed.
Feature
Color
Adaptive Threshold Processing
Black and
White
Grayscale
X
Auto Color Detection
X
X
Brightness and Contrast Control
X
Four cropping options
X
X
X
Deskew
X
X
X
Electronic Color Dropout
X
Fixed Thresholding
X
Halftone Removal
X
Polarity
X
Noise Filter
X
Orthogonal Rotation
X
X
X
Auto Orientation/Auto Rotation
X
X
X
Perfect Page with iThresholding
X
Adaptive Threshold Processing
After skew correction and auto-cropping algorithms have been applied to the scanned image, the
grayscale image is processed using Adaptive Threshold Processor (ATP) which is built into the
scanner software. ATP turns a grayscale image into a black and white image. The ATP algorithms
utilize a two-dimensional symmetrical array of surrounding pixels in order to accurately determine
the value of each pixel. Other approaches use only a few surrounding pixels to make the
determination.
January 2008
15
Auto Color Detection
Based on the color content of a document, this new feature will make it easier for customers to
capture color/grayscale only when they require it, reducing document prep time, storage
requirements and eliminating the need for patch sheets.
If you choose to use this option, the scanner will be automatically triggered to change from the
current image stream (black and white) to the alternative image stream (color/grayscale) based on
the values set in Color Content, Color Amount and Color Threshold. This is done on a documentby-document basis by scanning each document and determining the color content.
NOTES:
•
Toggle Patch will still be supported.
•
Not compatible with all document capture software products; consult with your software
provider.
Brightness and Contrast Control
Brightness and Contrast Control provides customers with the ability to create their own custom
color tables to meet any unique scanning need. Once a color table has been created, it can be
downloaded to the scanner and used in production. The color tables to be used for front and back
images are set independently. When scanning, only one color table can be applied to each image
(front or back). The same color table can be used for both the front and the back, or use one color
table for the front and one color table for the back. These tables can be easily managed by
capture applications.
Simultaneous Output of Color/Grayscale and Black and White Images
The i780 Scanner can output color, grayscale, or black and white images; grayscale and black
and white images; or color and black and white images without further processing required by the
host (some color scanners create this type of output by having the color image converted at the
host). The output from the scanner can be in five different formats and at the same rated speed.
Tri-Color Plus Scanning Array
Kodak’s exclusive scanning array the Tri-Color Plus Array, provides, in one pass, true color,
grayscale, and original black and white images.
The Tri-Color Plus Array was designed to be the fastest, most accurate, highest quality and
efficient production image capture device in the world. It enables black and white applications to
take advantage of the scanner’s unparalleled productivity and evolve to true color production
scanning when ready.
January 2008
16
Toggle Patch
The Toggle Patch triggers the scanner to switch from the current scanning mode to the alternative
mode (i.e., black and white to color/grayscale or color/grayscale to black and white).
When you scan using a Toggle Patch (shown at right), color onthe-fly processing is enabled. With color on-the-fly, scanning
automatically switches between scanning modes (e.g., black and
white to color/grayscale, then back to black and white) whenever
a Toggle patch is read by the scanner.
NOTE: An information packet (A-61599) is available for Kodak
Innovation Series Scanners. This describes the use of
patch codes and patch sheets in a document scanning
work flow.
Orthogonal 90° Rotation
This feature allows the customer to feed documents in landscape orientation, thus obtaining the
best throughput speed, but display the images in portrait orientation, which provides a more
convenient viewing result.
ABC
ABC
Viewing result
Landscape
Feed Orientation
Cropping — including zone processing
Cropping allows you to capture a portion of the document being scanned. Cropping parameters
may be separately defined for the front and rear sides and for the color and black and white
images and are operator-selectable via the host.
Automatic: (used for batches of mixed-size documents) — dynamically adjusts the cropping
window for different document sizes. Based on the edges of the image detected, the i780 Scanner
dynamically detects the boundaries of the document and only delivers the actual document to the
operator. Auto-cropping for a page accurately occurs anywhere within the imaging window of the
transport.
Fixed: (used for batches of same-size documents) — allows you to define the area or zone to be
imaged.
Aggressive: (used for batches of mixed-size documents) — this cropping method eliminates any
residual black border on any image edge.
January 2008
17
Relative to Document or zone processing (used for batches of same-size documents) — some
applications have a requirement to store part of an image in color and the rest of the image in
black and white format (this saves storage space by not storing the entire image in color). Zone
processing is a fixed crop window (the zone) that allows the operator to select via the host
application an area on the document to be delivered in either color or black and white format (a
separate window for both black and white and color may be defined). Different parameters may
be selected for both the front and rear of the image.
Zone processing can also be applied to text or black and white areas on a document. For
example, a certain area might contain a bar code that needs to be read as a high-resolution black
and white image. The i780 Scanner can pick up the area with the bar code as a black and white
image and deliver the rest of the image in full color (high or low resolution depending upon the
needs of the application). This reduces storage space requirements, network traffic and still
delivers the functionality required for an effective image processing system.
Original
Black and White Cropping
Relative Cropping
Deskew — Multi-bit (Color/Grayscale/Black and White)
The skew detection and correction subsystem performs accurate deskew on the 8-bit image in
each channel (RGB and grayscale) in the i780 Scanner. The front, rear, and simultaneous outputs
are deskewed independently providing maximum accurate deskew, all done at full machine
speed. It is important to note that deskew is based on the document edges not the content within
the document. This provides an assurance that document information will not be lost.
The new algorithm is also less sensitive to background noise and provides for deskew at an angle
up to 45 degrees with an accuracy of ± 0.3 degrees. (Since it takes longer to deskew a document
with a higher degree of skew, the feeder is designed to throttle while the image is deskewed.)
Electronic Color Dropout
Electronic color dropout is used to eliminate a form’s color background so that a document
management system may automatically (through OCR or ICR technology) read pertinent data
without interference from the lines and boxes of the form. The i780 Scanner can drop out either
red, green or blue. The dropout color selection (R, G, B) is changeable at the host. The scanner
does more than just drop out the color. The selected dropout color is fine-tuned for optimal image
quality through a simple operator setup procedure.
The i780 Scanner uses electronic color dropout, meaning there is no lamp change or filter change
required to change the dropout color.
The i780 Scanner can be configured to output black and white images with the selected color
dropped out, but also output the full-color image.
January 2008
18
Fixed Thresholding
Fixed thresholding is used for black and white and other high-contrast documents. A single level
is set to determine the black and white transition. This threshold is programmable over the entire
density range. When Contrast is set to zero, Threshold is fixed. When Contrast is set to 100,
Threshold is fully dynamic. Usually a setting in between these numbers produces the best results.
Fixed thresholding is used where the desired output is consistent vs. variable as with ATP.
Testing should be performed to find the best fixed threshold level in these types of applications.
Fixed thresholding may not be used when adaptive thresholding or dithering is selected.
Perfect Page scanning — for Black and White, Grayscale and Color Images
Perfect Page scanning means that within the scanner, images are correctly deskewed and
straightened. Black borders have been accurately reduced, without clipping corners. Photographs
look like photographs. Exposure and contrast have been optimized to bring out details. Lines and
fonts appear with smooth edges. All this, in color or black and white, without operator intervention
or post-processing. Only the combination of Kodak optics and image processing bring you Perfect
Page scanning.
Perfect Page scanning with iThresholding
Perfect Page scanning with iThresholding delivers high-quality black and white images from a
large range of both poor- and high-contrast documents and reduces the need to pre-sort, rescan,
and perform post-image processing. You get better image and text legibility, smoother lines,
minimal to no artifacts, and fewer shaded areas with minimal or no user intervention.
Scan mixed batches of documents of varied contrast in background and/or text with the
iThresholding features and the scanner dynamically evaluates each document in the batch to
determine the optimal threshold value to produce the highest quality image. Brightness is
automatically adjusted for each individual document for highlighting, low contrast, and lightweight
paper.
Perfect Page is a combination of built-in powerful imaging technologies. Every scan is optimized
as it is captured. Perfect Page scanning also shifts gears automatically to handle a wide range of
documents.
Polarity
Used to reverse the pixel values of a black and white image (i.e., make the white pixels black and
black pixels white). Polarity may be used when a reverse document is scanned (common in old
government records systems) or documents that do not appear readable in Normal mode may
become legible using polarity.
Image Output
The scanner outputs either compressed or uncompressed raw data to your application. The
bundled drivers output JPEG and TIFF image formats. Use your application to select an image
format in which to save the image data.
January 2008
19
A
NSS
ON
TIIO
AT
CA
PLLIIC
PP
AP
The Kodak i780 Scanner is targeted at departments or organizations that need to automatically
extract data from a wide variety of structured and unstructured forms.
Structured Forms:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
New customer applications
Customer orders and billings
Customer update or responses forms
Licensing
Vital records
HR / new employee records
Customer service
Surveys
Academic or professional testing
Lab tests / results
Mortgage and loans
Credit applications
Patient records
Medicare, Medicaid
Tax
Census
Unstructured Forms:
• Supplier invoices
• Accounting records
• Contracts
• Customer correspondence
• Legal documents
• Insurance documents
• EOB’s
• Transportation documents
• Purchase orders
• Incoming mail
January 2008
20
V
N
ON
TIIO
OSSIIT
PO
OP
RO
PR
EP
UE
ALLU
VA
End User
The Kodak i780 Scanner is a high-speed, production level scanner optimized for the needs of
mission-critical forms processing operations. It is the only scanner in it’s price / performance
class that operates at full rated speeds with advanced image processing features that enable data
extraction:
•
50% to 80% faster than competitive models (BB&H Spectrum XF and Fujitsu 5900C) running
at 300dpi with auto-crop and deskew enabled.
•
Only scanner in class that performs content-based, automatic image orientation at rated
speed.
Reseller
Kodak continues to lead the worldwide high-speed, production scanner class with proven
technology and service options that you can confidently deliver to your highest value clients, while
maintaining your hardware, service and services margins.
January 2008
21
P
G
NG
NIIN
ON
TIIO
OSSIIT
PO
TP
CT
UC
DU
OD
RO
PR
For:
Organizations that need to do forms processing in a mission-critical,
production environment.
Who need:
Fast, accurate, reliable image and data capture.
Our product is a:
High-speed, high-volume document scanner.
That provides:
Fastest capture technology optimized for OCR and ICR based data
extraction.
Unlike:
BB&H Spectrum Series and Fujitsu 5900C.
Our product:
Maintains rated speeds when using image processing features
required for data extraction (deskew, auto-crop, image clean-up and
auto orientation/auto rotation) at resolutions required for forms
processing (300 dpi).
Proof points:
Speed and Throughput — fast 130 pages per minute capture in
color, grayscale or black and white at 200 and 300 dots per inch of
resolution. Throughput is maintained even when advanced image
processing and data extraction oriented features such as auto-page
orientation, auto-crop and deskew are enabled.
Perfect Page scanning with iThresholding — Perfect Page
scanning with iThresholding is essential when you are scanning
mixed batches of documents of varied contrast in background
and/or text.
Auto Orientation/Auto Rotation — this feature automatically
analyzes each document to determine how it was fed into the
scanner and will rotate the image to the proper orientation.
Auto Cropping — dynamically adjusts the cropping window for
different document sizes. Based on the edges of the image
detected, the i780 Scanner dynamically detects the boundaries of
the document and only delivers the actual document to the
operator. Auto-cropping for a page accurately occurs anywhere
within the imaging window of the transport.
Deskew — front, rear, and simultaneous outputs are deskewed
independently providing maximum accurate deskew, all done at full
machine speed
Electronic Color Dropout — eliminates a form’s color background
so that a document management system may automatically
(through OCR or ICR technology) read pertinent data without
interference from the lines and boxes of the form. The i780 Scanner
can drop out either red, green or blue. The dropout color selection
(R, G, B) is changeable at the host.
January 2008
22
From the industry leader in digital innovation and the world leader in imaging, the i780 Scanner
truly re-defines the “mid-volume production” document scanner category. Competitive offerings
are hard pressed to beat Kodak’s winning combination of price, features, and performance offered
with the i780 Scanner.
These scanners are ideal for capturing business documents, graphics, photos, tear sheets, and
even long (up to 34 in. standard) or irregularly shaped documents — that may have been
considered impossible to capture previously — into a digital workflow for sharing and archiving.
The new i780 Scanner will change the way you think about desktop production document
scanning.
•
Convert file space to working space and meet new peak processing periods imposed by
tighter regulatory compliance and other legal mandates, at speeds up to 130 pages per
minute.
•
Improve customer response time with best-in-class throughput, often versus scanners that
claim to have higher rated speed.
•
Handle ever-increasing paper volumes within shorter timeframes without 500-sheet feeder,
featuring continuous, non-stop document feeding.
•
Take on more volume with equivalent or few production staff with the most productive scanner
family in the business.
The i780 Scanner offers new, innovative, and highly productive features that distinguish it from
other offerings in the market.
•
Scanning in color or grayscale is as fast as black and white scanning up to 130 ppm at 300
dpi.
•
Auto orientation/auto rotation increases actual throughput by allowing you to scan at the faster
landscape orientation, but have the images automatically oriented for proper viewing, without
incurring any penalty for additional post-scan processing.
•
Simultaneous output of multiple image formats, up to 520 images per minute.
•
Perfect Page with iThresholding delivers built-in advanced image processing functions as
“standard”, such as a best-in-class auto crop and deskew, relative cropping, automatic color
detection, and brightness and contrast control. These features ensure readable business
documents by office workers and automated data extraction technology (OCR, ICR, OMR and
bar codes) alike.
•
World renowned SurePath paper handling that effectively captures practically any document
in almost any condition. You can trust your valuable business documents to Kodak.
•
Fast, plug-and-play IEEE-1394 (FireWire) interface and Capture Software, which enables
100% of all scanner features, to speed your images on their way.
The i780 Scanner continues to deliver upon our industry reputation as providing reliable, easy to
set-up and use scanners that require minimal operation intervention and maintenance whether in
the mailroom or scanning department.
January 2008
23
C
N
ON
TIIO
TIIT
ET
PE
MP
OM
CO
This section compares the Kodak i780 Scanner with the major competition in the mid-volume
production scanner segment. We hope you find the comparisons useful.
The information that follows was gathered through sell sheet materials supplied (physically or via
the Internet) by the manufacturer. Other data has been provided by Kodak Engineering Staff,
Value-Added Distributors, and outside consultants. Several categories of information require
special explanation for a full understanding of the following competitive profiles.
NOTE: Every effort has been made to verify the features, performance, and pricing information
shown on the following pages. As conditions change, however, Kodak cannot accept
responsibility for the validity of competitive data.
Scanner Speed
All manufacturers have provided the stated speed(s) of their paper transports (typically using the
landscape mode on A4 or letter-sized paper). Be extremely cautious using these figures, as very
few, if any, scanners can actually function at these speeds due to constraints in paper handling,
jams, or restrictions at the computer (SCSI/Video/USB/IEEE-1394) interface.
Kodak scanners perform all functions at rated speed, with no performance penalty for color
imaging, Perfect Page processing and our new auto orientation/auto rotation feature. Not all (if
any) of the competitive scanners can make this claim.
Capture Resolution/Output Resolution
The basic laws of physics suggest that higher output resolution for a given machine means
proportionally slower speed. Additionally, the differences between capture and output resolutions
allow the imaging algorithms within the scanner to clean up the image and remove spurious data.
Therefore, capture resolution plays an integral part in establishing the overall quality of the image.
Capture resolution is the actual dpi of the image as the scanner captures it. Some scanners can
interpolate up to a higher output resolution than the optical or actual capture resolution (i.e., a 300
dpi image can be interpolated up to look like a 600 dpi image). Final image quality is dependent
on multiple variables, such as the quality of the lens, light, CCD, and image processing routines.
January 2008
24
Paper Thickness
Like transport speed, minimum and maximum paper thickness are normally interesting
hypothetical measures. Although necessary parameters to evaluate a scanner’s performance,
they tell little about the equipment’s treatment of a thin or fragile document or what happens to
documents when a double-feed is detected, or a paper-clip is accidentally fed into the paper path.
In addition, various manufacturers specify their scanner’s paper handling capacities differently —
some by thickness, some by weight — thus making it difficult to make an apples-to-apples
comparison.
Changes in paper thickness from one document to the next and the scanners’ ability to handle
these changes cannot be measured using these parameters. The paper thickness comparison
should be used only as an estimate of the general capabilities of a scanner. The operator is
always the best possible evaluator of tolerance to thickness and thickness changes by running
standard batches of their documents through the machine. Kodak has a program named
SurePath Paper Handling that goes back to the transport engineering philosophy that all pages
within the scanner specification will go through the scanner.
Kodak scanners have been tested with a range of documents that represent the broad spectrum
of document types found in the most common business applications. Optimal scanner
performance is achieved when scanning documents within the recommended document
specifications listed below. Scanning documents outside of these specifications may lead to
undesirable results in terms of scanner reliability, image quality, and/or consumable life.
Materials:
•
•
Virgin and recycled papers
Clear protective sleeves meeting the size and thickness requirements in this section
Paper Types: Bond, Laser, Inkjet, Offset
Paper Weights: The elevator tray handles a broad range of paper weights from 45 to 200 g/m2
(12 to 110 lb.). The Kodak Feeder Kit for Ultra Lightweight Paper can handle paper weights from
25 to 75 g/m2 (7 to 20 lb.).
Minimum Document Size: 6.4 x 6.4 cm (2.5 x 2.5 in.). Documents as small as 5 cm (2 in.)
(i.e. business cards) can be center-fed, in portrait orientation one at a time.
January 2008
25
Key Selling Points Against Competition
Kodak i780 Scanner -vs.- BB&H Spectrum Scanners
•
The list price of the Kodak i780 Scanner is 15% less than that of BB&H’s top Spectrum model.
•
The Kodak i780 Scanner offers superb image processing utilizing Kodak’s proprietary Perfect
Page image quality algorithm, providing an array of image quality capabilities including:
•
− Deskew
− Cropping
− Color dropout
− Dynamic thresholding (iThresholding)
− Contrast control
− Blank page detection
− Auto Orientation / Auto Rotation (AO/AR)
The Kodak i780 Scanner technology for multifeed detection (with ultrasonic technology) can
handle mixed batch documents, and will run at rated speed at 200 and 300 dpi. In contrast,
the BB&H Spectrum Scanner speed decreases by 25% with black and white, two-sided
documents and 74% with color two-sided documents with deskew, auto crop, and AO/AR
features turned on at 200 and 300 dpi.
•
The Kodak i780 Scanner produces dual stream output at rated speed. With a capture software
application that supports multiple streams, dual stream is an advantage as it allows a color
image to be leveraged in the validation stage of a typical work flow, then deleted, while the
black and white image, a smaller file, can be archived – without an additional document scan
required. The BB&H Spectrum Scanners do not support dual stream output.
•
Kodak Scanners are backed by factory-trained employees providing world-class service and
support for all hardware and software.
•
The Kodak i780 Scanner can capture longer documents (up to 34 inches / 864 mm) at rated
speed. In contrast, the BB&H Spectrum Scanners cannot handle longer documents,
supporting only documents up to 17 inches / 432 mm.
Kodak i780 Scanner -vs.- Canon imageFORMULA DR 9080C
•
The Kodak i780 Scanner is a robust scanner with CCD technology, able to handle a
production level duty cycle, and performing 36% faster than the Canon imageFORMULA DR
9080C Scanner. The Canon scanner is limited by its CIS technology, which results in poor
image quality and large file sizes.
•
The Kodak i780 Scanner offers superb image processing, utilizing Kodak’s Perfect Page
image quality algorithm. In contrast, Canon’s imageFORMULA DR 9080C image processing
has some limitations, including inadequate border removal, and ineffective image rotation with
color documents. Kodak’s Perfect Page feature provides an array of capabilities including:
−
−
−
−
−
−
−
Deskew
Cropping
Color dropout
Dynamic thresholding (iThresholding)
Contrast control
Blank page detection
Auto Orientation / Auto Rotation (AO/AR)
January 2008
26
•
Canon’s 600 dpi resolution scanning capability is available in limited scenarios. For example,
the product cannot scan large documents (more than 17 inches), color documents, or twosided documents at 600 dpi.
•
Kodak i780 Scanner technology for multifeed detection (with ultrasonic technology) can
handle mixed batch documents, and runs at rated speed at 200 and 300 dpi. Whereas, the
Canon Scanner speed slows down with several critical features. Specifically, the Canon
Scanner will not run at rated speed with auto orientation / auto rotation turned on in color
mode, and it has difficulty running mixed document sets.
•
The Kodak i780 Scanner produces dual stream output at rated speed. With a capture software
application that supports multiple streams, dual stream is an advantage as it allows a color
image to be leveraged in the validation stage of a typical work flow, then deleted, while the
black and white image, a smaller file, can be archived – without an additional document scan
required. The Canon Scanner does not offer dual stream scanning.
•
Kodak Scanners are backed by factory-trained employees providing world-class service and
support for all hardware and software.
Kodak i780 Scanner vs. Fujitsu 5900C
•
The Kodak i780 Scanner is a robust, ergonomically designed scanner, able to handle a
production level duty cycle, and performing 8% faster (running at 200 and 300 dpi) than the
Fujitsu fi-5900C Scanner. The Fujitsu fi-5900C Scanner design, specifically it’s height, makes
it difficult to effectively run the machine for periods of 8 hours or more.
•
The Kodak i780 Scanner offers superb image processing, utilizing Kodak’s Perfect Page
image quality algorithm. In contrast, the Fujitsu fi-5900C images are dark, noisy and grainy,
and the product struggles when handling documents with binder holes. Kodak’s Perfect Page
technology provides an array of image quality capabilities to effectively manage production
level scanning needs, including:
•
− Deskew
− Cropping
− Color dropout
− Dynamic thresholding (iThresholding)
− Contrast control
− Blank page detection
− Auto Orientation / Auto Rotation (AO/AR)
Kodak i780 Scanner technology for multifeed detection (with ultrasonic technology) can
handle mixed batch documents reliably, and runs at rated speed at 200 and 300 dpi. In
contrast, the Fujitsu 5900C Scanner speed is limited to 100 ppm with VRS enabled. Specific
image quality features contribute to the Fujitsu scanners throughput decline of 31% one-sided
mode and 72% two-sided mode @ 200 dpi, and a reduction of 51% in one-sided mode, and
85% two-sided mode @ 300 dpi, including: blank page detection, deskew, auto cropping, and
auto orientation /auto rotation having the greatest impact to Fujitsu’s throughput decline.
Additionally, the Fujitsu scanner has difficulty managing small documents; specifically, small
documents can disappear in the transport.
•
The Kodak i780 Scanner can scan longer documents (up to 34 inches / 864 mm) at rated
speed. The Fujitsu scanner cannot handle longer documents, supporting only documents up
to 17 inches / 432 mm.
•
Kodak Scanners are backed by factory-trained employees providing world-class service and
support for all hardware and software.
January 2008
27
Kodak i780 Scanner vs. InoTec ScanMAX 422 DC
•
Kodak i780 Scanner is robust and is ergonomically designed to be able to handle a production
level duty cycle. Its list price is 30% less than the InoTec ScanMAX 422 DC Scanner.
•
Kodak Scanners are backed by factory-trained employees providing world-class service and
support for all hardware and software
•
Limited additional detailed insight is available regarding this competitive product at this time.
Updates will be published through CI network as information becomes available.
Kodak i780 Scanner vs. Microform MFS 455
•
Kodak i780 Scanner is robust and is ergonomically designed to be able to handle a production
level duty cycle. Its list price is 39% less than that of the Microform MFS 455 scanner.
•
Kodak Scanners are backed by factory-trained employees providing world-class service and
support for all hardware and software
•
Limited additional detailed insight is available regarding this competitive product at this time.
Updates will be published through CI network as information becomes available.
Kodak i780 Scanner vs. Panasonic KV-S3105C
•
Kodak i780 Scanner is robust and is ergonomically designed to be able to handle a production
level duty cycle.
•
The Kodak i780 Scanner offers superb image processing, utilizing Kodak’s Perfect Page
image quality algorithm. The Panasonic offering does not provide a similar capability. Kodak’s
Perfect Page feature provides an array of image quality capabilities including:
•
− Deskew
− Cropping
− Color dropout
− Dynamic thresholding (iThresholding)
− Contrast control
− Blank page detection
− Auto Orientation / Auto Rotation
Kodak i780 Scanner technology for multifeed detection (with ultrasonic technology) can
handle mixed batch documents, and will run at rated speed at 200 and 300 dpi. In contrast,
the Panasonic KV-S3105C Scanner speed @ 200 dpi demonstrates a 32% reduction in speed
for B&W duplex, 44% reduction in speed for duplex color; and @ 300 dpi: B&W: demonstrates
a 45% reduction in speed with simplex and a 58% reduction in speed with duplex; and in
Color: demonstrates a 55% reduction in speed for simplex, and a 66% reduction in speed for
duplex.
•
The Kodak i780 Scanner can scan longer documents (up to 34 inches / 864 mm) at rated
speed. The Panasonic scanner does not offer this capability.
•
Kodak Scanners are backed by factory-trained employees providing world-class service and
support for all hardware and software.
January 2008
28
Key Knockouts
Productivity: The most productive forms processing scanner available on the market, the Kodak
i780 Scanner meets more of your scanning needs, with speed and reliability.
•
The speed of the Kodak i780 Scanner will not slow down when key features are enabled. For
example, the product provides auto orientation/auto rotation and dual stream output at rated
speed, a broad array of critical image quality capabilities including deskew and color dropout,
and even manages mixed batch documents, all at rated speed.
•
The Kodak i780 Scanner can also handle longer documents, up to 34 inches, when many
competitors handle only up to 17 inches.
Image Quality: Offering Kodak’s renowned Perfect Page image quality technology.
•
Provides scans that are as good as, or better than, the original.
•
The Kodak i780 Scanner offers the broadest set of image quality capabilities, delivered
through the Kodak’s Perfect Page technology included with our production level scanner
products, providing an array of superb image quality features, including:
−
−
−
−
−
−
−
Deskew
Cropping
Color dropout
Dynamic thresholding (iThresholding)
Contrast control
Blank page detection
Auto Orientation / Auto Rotation (AO/AR)
Plug and Play: Production ready, out of the box!
•
Minimal Setup - everything you need is included in the box – no need for additional third party
applications or components.
•
Reliable Paper Handling - SurePath Paper Handling ensures reliable document scanning with
a wider range of documents than offered by competitors’ products.
•
Included software fully leverages the broad array of features and capabilities of the Kodak
i780 Scanner.
January 2008
29
C
RSS
ER
BE
MB
UM
NU
GN
OG
ALLO
TA
AT
CA
Scanners
CAT No.
Kodak i780 Scanner
120 0013
Consumables
Kodak Feed Consumables Kit for i600/i700/i1800 Series Scanners
108 4755
Kodak Feeder Kit for Ultra-Lightweight Paper for i600/i700/i1800 Series Scanners
896 5279
Kodak Extra-Large Feeder Consumables Kit for i600/i700/i1800 Series Scanners
842 6157
Kodak Extra-Extra-Large Feeder Consumables Kit for i600/i700/i1800 Series Scanners
134 3680
Kodak Imaging Guide Set for i600/i700/i1800 Series Scanners
197 6703
Kodak Printer Ink Blotters, Front Side for i600/i700 Series Scanners
840 5425
Kodak Enhanced Printer Ink Cartridge Carrier
113 3842
Enhanced Printer Black Ink Cartridge (qty 3)
818 3386
Enhanced Printer Red Ink Cartridge (qty 3)
159 6832
Kodak Digital Science Transport Cleaning Sheets (50)
169 0783
Kodak Digital Science Roller Cleaning Pads (24)
853 5981
Staticide Wipes for Kodak Scanners (144)
896 5519
Kodak Calibration Targets (5)
127 1436
Service Care Kits
CAT #
Kodak i780 Equipment Maintenance Agreement - 1year
Check Local
Kodak Care Kit i780 – 1year Post Warranty
Check Local
Kodak Care Kit i780 – 1 year Extended Warranty
Check Local
Kodak Care Kit i780 – 2 year Extended Warranty
Check Local
Kodak Care Kit i780 – 2 year Extended Warranty
Check Local
January 2008
32
F
NSS
ON
TIIO
ESST
UE
QU
DQ
ED
KE
ASSK
YA
TLLY
NT
EN
UE
QU
EQ
RE
FR
What customer-installable options are available?
The following accessories can be installed:
•
The Kodak Feeder Kit for Ultra-Lightweight Paper allows you to feed lightweight paper
from a paper weight range of 25 g/m2 to 75 g/m2 kg (7 to 20 lbs). This accessory includes a
feed module and separation roller that are specially designed to feed lightweight paper
through the scanner transport.
•
The Kodak White Background Accessory. If you are scanning translucent documents, this
accessory will reduce black background bleed-through while scanning which produces whiter
images. The White Background Accessory comes with two white background strips that easily
replace the two black background strips in the scanner.
•
The Kodak Manual Feeder. The Kodak Manual Feeder is available for manual feeding of
documents. This feeder provides a flat surface for easy feeding.
Will the i780 Scanner work with VRS?
No. Kofax applications can be supported through AIPE using the ISIS driver.
Does the i780 Scanner support JPEG 2000?
No, not at this time.
How many hours will the lamps last?
The long-life xenon lamps were designed to last the life of the scanner. If the lamps need to be
replaced, a Kodak Field Engineer will replace them at no extra cost (per the Kodak Service
Agreement).
What is the warm-up time for the i780 Scanner when they are in standby with lamps off?
Warm up times are as follows:
•
60 seconds for the lamps to stabilize after the scanner is turned on (from Energy-Star standby
mode).
•
5 seconds when recovering from a document jam or multi-feed error where the pod has been
opened.
•
90 seconds for calibration.
Scanning is not allowed during these warm-up times.
January 2008
33
What are the customer-replaceable consumables, expected life of consumables, and
recommended cleaning supplies?
See the “Catalog Numbers” section or refer to the User’s Guide or Supplies and Consumables for
Kodak Scanners (A-61403) for information about consumables for the i780 Scanner:
•
Feeder Consumables Kits (feed modules, separator modules, pre-separation pads,
replacement tires)
NOTE: The nominal tire life is 500,000 documents. The separator module requires two tires
and the feed module requires four tires. The Feeder Consumables Kit (CAT. No.108
4755) contains enough tires to scan up to 1,750,000 documents. The Feed Module
and Separation Roller are quickly and easily replaceable.
•
•
•
•
•
•
•
Printer ink cartridges
Printer ink blotters
Transport cleaning sheets
Staticide Wipes
Roller cleaning pads
Calibration targets
Imaging guides
Can I add Kodak PerformancePlus to the i700 Scanner?
Service for the i780 Scanner is covered by the Kodak PerformancePlus program. It will allow
customers to upgrade their cover at highly competitive prices. PerformancePlus is available in
selected markets only. Contact your local Kodak sales team for more information.
Does the scanner support zone processing in black and white, color, and grayscale?
Yes.
Why does the output tray have five positions?
Different output tray positions work best for different jobs. Choose the best position to suit your
application. For example, long documents (e.g., A3-size) work best with the tray in the full down
position. The highest position works best with shorter documents.
When should I use the gap release lever?
Use the gap release any time thick or fragile documents will be fed one at a time through the
scanner. Refer to the User’s Guide for more information.
January 2008
34
What is the IEEE-1394 (FireWire) Connection Standard?
FireWire is a high-speed serial input/output (I/O) technology for connecting peripherals, such as
scanners, to a computer. FireWire was originally developed by Apple Computer, Inc., and is now
an industry standard (IEEE-1394).
FireWire is one of the fastest peripheral standards developed. It has primarily been used with
multimedia peripherals such as digital video camcorders, professional digital cameras, printers,
and other high-speed devices.
FireWire is over 30 times faster than USB 1.1 standard. While USB 2.0 tops out at 480 Mbps, the
IEEE-1394 (FireWire) standard allows for programmed increases in bandwidth over time. The
standard is currently moving from 400 Mbps to 800 Mbps, however, products at this speed are not
yet available.
Why does Kodak use FireWire in the i780 Scanner?
Kodak has placed FireWire in the i780 Scanner because it is a plug-and-play PC interface
standard and because it is one of the fastest peripheral standards ever developed, and to allow
for maximum speed and efficiency for the transfer of data-intensive materials.
What operating systems does IEEE-1394 work with?
The IEEE-1394 standard works with Windows 98 (Second Edition), Windows ME, Windows 2000,
Windows XP, and all Macintosh systems.
What operating systems do not support IEEE-1394?
IEEE-1394 is not compatible with Windows 3.1, Windows 95, Windows NT, and Windows 98
(First Edition).
What does an IEEE-1394 connection cost?
The IEEE-1394 (FireWire) card and cable are bundled with the Kodak i780 Scanner; therefore,
there is no additional cost to the customer.
What host adapter does Kodak ship with the scanner?
Koutech 1582T.
Do I need to purchase a FireWire card and cable?
No. Kodak supplies both a FireWire card and cable in the box with the scanner (see the “What’s in
the Box” section).
Why would someone buy FireWire?
It is a proven, reliable standard for data-intensive, high-speed transmission and it is one of the
fastest peripheral standards ever developed, at a price that’s affordable to consumers. Other highspeed serial I/O technologies have yet to become readily available.
January 2008
35
How does IEEE-1394 compare with other serial I/O interfaces such as USB and
SCSI?
IEEE-1394
(FireWire)
SCSI-I
SCSI-II
SCSI-III
USB 1.1
USB 2.0
Speed
400 Mbps
(50 Mbps)
(Practical: 25)
5 Mbps
(Practical: 2.5)
10 Mbps
(Practical: 5)
80 Mbps
(Practical: 20)
12 Mbps
(1.5 Mbps)
480 Mbps
(60 Mbps)
(Practical:
unknown)
Kodak Scanner
Compatibility
i200/i700
Scanners
Kodak
Professional
Digital
Cameras
Standard on
most PCs.
$50 USD
adapter board
also available
Yes
55XX/75XX/95XX
i50/i60
1500/2500
35XX/4500
7520/9520
i800 Series
Scanners
$200 USD for
adapter board
$200 USD for
adapter board
$300 USD for
adapter board
Standard on
most PCs.
$70 USD adapter
card
Yes
Yes
Yes
Yes
Yes
Standard on
many PCs;
many board
markers
Only available on
PCs as an added
board; limited
board makers
Standard on
most PCs
6 meters
Only available
on PCs as an
added board;
limited board
makers
12 meters
Standard on
most PCs
5 meters
(connect more
by adding
hubs/repeaters)
$8 USD
Only available
on PCs as an
added board;
limited board
makers
3 meters
5 meters
(connect more by
adding hubs)
$40 USD
$40 USD
$40 USD
5 meters
(connect more
by adding
hubs)
$8 USD
Approximate Cost
Standard
Ubiquity
Cable Length
Approximate Cable
Cost
Hot-Pluggable
Operating System
Support
Plug and Play
January 2008
$18 USD
Yes
No
No
No
Yes
Yes
Windows 98SE
Windows ME
Windows 2000
Windows XP
Vista
All
All
All
All
Yes
No
No
No
Yes
Windows 2000
Windows XP
Does not support
Windows 98 or
Windows ME,
Vista
Yes
36
Product Comparison – Kodak i780 Scanner with the Competition
Kodak i780 Scanner
Kodak i660 Scanner
Kodak i1840 Scanner
Features
Böwe Bell & Howell
Spectrum XF: 8120DC
XF 8140DCI
Canon
imageFORMULA
DR 9080C
Fujitsu
fi-5900C
InoTec
ScaMax 422 CD
(M06)
Microform
MF S 455
Panasonic
KV-S3105C
$9,995
$24,995
$57,000
$65,000
$26,995
Yes
Yes
Yes
Yes
Yes
245
Image processing
Yes – Perfect Page features
include: deskew, cropping, color
dropout, dynamic thresholding
(iThresholding), contrast control,
blank page detection
Yes – Perfect Page features
include: deskew, cropping,
color dropout, dynamic
thresholding (iThresholding),
contrast control, blank page
detection, automatic
orientation, image addressing
Yes
3D Ultrasonic
3D Ultrasonic
3D Ultrasonic
Ultrasonic
Ultrasonic
Ultrasonic
Ultrasonic
Ultrasonic
Ultrasonic
Maximum scan
size
12 x 34 in.
305 x 864 mm
12 x 34 in.
305 x 864 mm
12 x 34 in.
305 x 864 mm
11.7 x 40 in.
297 x 10163 mm
12 x 39.4 in.
305 x 1000 mm
12 x 17 in.
305 x 432 mm
11.7 x 163 in.
297 x 4128 mm
12.5 x 157 in.
315 x 4000 mm
11.7 x 17 in.
297 x 432 cm
Minimum scan
size
2.5 x 2.5 in.
64 x 64 mm
2.5 x 2.5 in.
64 x 64 mm
2.5 x 2.5 in.
64 x 64 mm
2.6 x 2.6 in.
66 x 66 mm
2.2 x 2.8 in.
56 x 71 mm
2.1 x 2.9in.
53 x 74 mm
1.1 x 2.4 in.
28 x 60 mm
1.9 x 2.75 in.
50 x 70 mm
1.9 x 2.75 in.
50 x 70 mm
Dual-stream: Color and
B/W or
Gray and B/W images
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Auto Color Detection
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes – optional
Yes
B&W:
Simplex/Duplex
@ 200 dpi A4*
130 ppm/260 ipm
120 ppm/240 ipm
160 ppm/320 ipm
XF 8120: 120 ppm/240
ipm+
XF 8140: 140 ppm/280
ipm+
120 ppm/240 ipm+
VRS is: 100 ppm /200 ipm
150 ppm/300 ipm
120 ppm/240 ipm
132 ppm/230
ipm+
B&W
Simplex/Duplex
@ 300 dpi A4*
130 ppm/260 ipm
80 ppm/160 ipm
107 ppm/214 ipm
N/A
N/A
120 ppm/240 ipm+
VRS is: 100 ppm /200 ipm
N/A
N/A
N/A
Color
Simplex/Duplex
@ 200 dpi A4*
130 ppm/260 ipm
120 ppm/240 ipm
160 ppm/320 ipm
8120: 90 ppm/180 ipm+
8140: 140 ppm/230 ipm+
54 ppm/92 ipm**+
120 ppm/240 ipm+
VRS is: 100 ppm /200 ipm
150 ppm/300 ipm
120 ppm/240 ipm
132 ppm/180
ipm+
Color
Simplex/Duplex
@ 300 dpi A4*
130 ppm/260 ipm
80 ppm/160 ipm
107 ppm/214 ipm
N/A
N/A
120 ppm/240 ipm+
VRS is: 100 ppm /200 ipm
N/A
N/A
N/A
500 sheets
500 sheets
500 sheets
500 sheets
500 sheets
500 sheets
500 sheets
500 sheets
1000 sheets
130,000 sheets
120,000 sheets
Unlimited
60,000 sheets
10,000 sheets
100,000 sheets
Unlimited
30,000 sheets
Unlimited
Optical resolution
300 dpi
300 dpi
300 dpi
600 dpi
600 0dpi
600 dpi
400 dpi
400 dpi
600 dpi
Software Support
Kodak Capture Software
Kodak Capture Software,
Kofax VRS
Kodak Capture Software
Kofax VRS 4.1
Capture Perfect 3.0
ScandAll 21
Kofax VRS 4.1
MDIT
MDIT
J&K DpuScan
RTIV/PIE
IEEE-1394 (FireWire)
IEEE-1394 (FireWire)
IEEE-1394 (FireWire)
SCSI-3
SCSI-3, USB 2.0
SCSI -3, USB 2.0
Ethernet
SCSI-3
SCSI-3, USB 2.0
TWAIN and ISIS (included)
TWAIN and ISIS (included)
TWAIN and ISIS (included)
TWAIN and ISIS
TWAIN and ISIS
TWAIN and ISIS
TWAIN and ISIS
TWAIN and ISIS
TWAIN and ISIS
3 months on-site
3 months on-site
3 months on-site
1 year on-site
3 months on-site –
next business day
3 months on-site – next
business day
1 year RTB (Australia)
N/A
6 months on-site,
next business
day
Scanning Speed
Paper
Size
Multi-Feed Detection
Yes – Perfect Page features
include: deskew, cropping, color
dropout, dynamic thresholding
(iThresholding), contrast control,
blank page detection, automatic
orientation
Feeder capacity
Recommended daily
volume
Interface
Drivers
Warranty
* Landscape Speed
** Portrait Speed
+Letter
90 ppm/180 ipm**+
Kodak’s Graphic Communications Group:
Guangzhou
+86-20-8666-9888 ext. 6403
Beijing
+86-10-6561-6561 ext. 8908
Shanghai
+86-21-5884-1818
Shenzhen
+86-755-8835-2068 ext. 362
Hong Kong
+852-2564-9357
Taiwan
+886-2-8751-8187
Australia Toll Free
1800-895-747
New Zealand Toll Free
0800-256-325 (0800 2 KODAK)
Singapore & South East Asia
+65-6371-3388
India
+91-22-6641-6380
Japan
+81-3-5577-1300
South Korea
+82-2-3143-0981
