User's Guide
IMPORTANT:
Read this manual carefully before using your printer.
Save this manual for future reference.
ENG
LBP3000
Laser Printer
User's Guide
Manuals for the Printer
The instruction manuals for this product are arranged as follows. Read the sections that are
appropriate for your goals, to let you fully utilize this product.
CD-ROM
Guides marked with this symbol are PDF manuals included on the accompanying CD-ROM.
• Installation
• Connecting to a Computer
• Printing Methods
Getting Started Guide
CD-ROM
User's Guide
(This Manual)
CD-ROM
• Basic Operations
• Troubleshooting
• To view the manual in PDF format, Adobe Reader/Adobe Acrobat Reader is required. If Adobe Reader/Adobe Acrobat Reader is not installed on your
system, please download it from the Adobe Systems Incorporated website.
• The printer illustration on the cover of this manual may differ slightly from your printer.
How This Manual Is Organized
Chapter 1
Before You Start Using This Printer
Chapter 2
Loading and Delivering Paper
Chapter 3
Setting Up the Printing Environment
Chapter 4
Printing a Document
Chapter 5
Routine Maintenance
Chapter 6
Troubleshooting
Chapter 7
Appendix
Make sure you read this
Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, as we are constantly improving our
products, if you need an exact specification, please contact Canon.
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
How To Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Notation for Keys and Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Displays Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Abbreviations Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Model Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
FCC (Federal Communications Commission) . . . . . . . . . . . . . . . . . . . . . . . . . . ix
EMC Directive (220 - 240 V model) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Laser Safety (110 - 127/220 - 240 V models). . . . . . . . . . . . . . . . . . . . . . . . . . . x
International Energy Star-Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
WEEE Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Disclaimers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Legal Limitations on the Usage of Your Product and the Use of Images . . . . . xiii
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Maintenance and Inspections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii
Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix
Other . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix
Chapter 1
Before You Start Using This Printer
Printer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Component Names and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Indicators and the Paper Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4
1-5
1-6
1-7
1-8
Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Turning the Printer On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Turning the Printer On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Turning the Printer Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
ii
Chapter 2
Loading and Delivering Paper
Paper Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Usable Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Paper Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Paper Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Abbreviations of Paper Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Printable Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Paper You Cannot Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Storing Blank Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Storing Printed Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
Paper Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Paper Source Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Paper Source Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Paper Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Output Tray Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Output Tray Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies . . .2-14
Loading the Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
Loading Paper into the Multi-Purpose Tray . . . . . . . . . . . . . . . . . . . . . . .2-15
Loading Paper into the Manual Feed Tray . . . . . . . . . . . . . . . . . . . . . . . .2-20
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . .2-23
Printing on Index Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
Loading Index Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
Loading Index Card into the Manual Feed Tray. . . . . . . . . . . . . . . . . . . .2-27
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . .2-30
Printing on Envelopes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-34
Loading Envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-34
Loading Envelopes into the Multi-Purpose Tray. . . . . . . . . . . . . . . . . . . .2-35
Loading Envelopes into the Manual Feed Tray . . . . . . . . . . . . . . . . . . . .2-38
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . .2-41
Printing on Custom Paper Sizes (Non-Standard Sizes). . . . . . . . . . . . . . . . .2-45
Loading Custom Paper Sizes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-45
Loading Custom Paper into the Multi-Purpose Tray . . . . . . . . . . . . . . . .2-45
Loading Custom Paper into the Manual Feed Tray . . . . . . . . . . . . . . . . .2-51
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . .2-54
Chapter 3
Setting Up the Printing Environment
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
After Installing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Each Time You Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Installing the CAPT Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Installing from CD-ROM Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
iii
Installing with Plug and Play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Windows 98/Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Windows XP/Server 2003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-12
3-12
3-21
3-28
3-33
After Completing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40
Printing a Test Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
Printing from a Network Computer using a Shared Printer . . . . . . . . . . . . .
Configuring the Print Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Windows 98/Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For Windows 2000/XP/Server 2003/Vista . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing from CD-ROM Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing from the [Printers and Faxes] Folder or the [Printers] Folder . . . .
Installing using [Windows Explorer] . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-47
3-48
3-48
3-53
3-61
3-62
3-69
3-73
Uninstalling the CAPT software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-75
Chapter 4
Printing a Document
Printing from an Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Specifying Printing Preferences. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
For Windows 98/Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Opening the [Document Properties] Dialog Box from an Application . . . 4-7
Opening the [Printer Properties] Dialog Box from the [Printers] Folder . . 4-9
For Windows 2000/XP/Server 2003/Vista . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Opening the [Document Properties] Dialog Box from an Application . . 4-11
Opening the [Document Properties] Dialog Box from the
[Printers and Faxes] or [Printers] Folder . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Opening the [Printer Properties] Dialog Box from the
[Printers and Faxes] or [Printers] Folder . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Canceling, Pausing and Resuming Printing . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Using the Printing Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tab Sheets in the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[Page Setup] Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[Finishing] Sheet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[Paper Source] Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[Quality] Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[General] Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[Details] Sheet (Windows 98/Me only) . . . . . . . . . . . . . . . . . . . . . . . . . .
[Sharing] Sheet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
[Ports] Sheet (Windows 2000/XP/Server 2003/Vista only) . . . . . . . . . . .
[Advanced] Sheet (Windows 2000/XP/Server 2003/Vista only) . . . . . . .
[Color Management] Sheet (Windows 2000/XP/Server 2003/Vista only)
[Security] Sheet (Windows 2000/XP/Server 2003/Vista only) . . . . . . . . .
[Configuration]/[Device Settings] Sheet . . . . . . . . . . . . . . . . . . . . . . . .
[Profile] Sheet (Windows 2000/XP/Server 2003/Vista only) . . . . . . . . . .
iv
4-19
4-19
4-20
4-23
4-24
4-25
4-27
4-27
4-28
4-28
4-29
4-29
4-30
4-30
4-31
Preview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-33
Printing Multiple Pages on One Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-34
Scaling Printer Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-36
Scaling a Document Automatically . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-36
Scaling a Document Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-37
Poster Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-38
Specifying a Custom Paper Size (Non-Standard Paper) . . . . . . . . . . . . . . . .4-39
Specifying the Finishing Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-41
Specifying the Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-44
Grayscale Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-46
Working with Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-47
Adding a Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-48
Editing/Deleting a Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-50
Editing Print Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-52
Viewing Printer Settings/Restoring the Default Settings . . . . . . . . . . . . . . . .4-54
Viewing Printer Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-54
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-55
Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-56
Installing the Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-56
Uninstalling the Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-59
Printer Status Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-60
Using the Printer Status Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-61
Displaying the Printer Status Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-63
The Options Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-64
Setting Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-64
[Cleaning] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-66
[Refresh]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-66
[Resolve Error] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-66
Displaying Printer Status When Using a Print Server . . . . . . . . . . . . . . . . . .4-67
Chapter 5
Routine Maintenance
Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Before Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-14
Precautions for Handling the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . .5-16
Storing Toner Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-18
Clean the outside of the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-19
Moving the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-21
Moving the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-22
Handling the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-27
Precautions for Handling the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-27
Precautions for Storing the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-28
v
Chapter 6
Troubleshooting
Troubleshooting Map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Service Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
When a Fixing Unit Error Appears . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
When a Scanner Error or Service Error Appears. . . . . . . . . . . . . . . . . . . . . 6-20
Print Quality Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Paper Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25
When Nothing Prints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Installation Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If Uninstallation Fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uninstalling the USB Class Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Problems During Local Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Problems Installing a Shared Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-27
6-28
6-30
6-34
6-34
Miscellaneous Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36
Chapter 7
Appendix
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Hardware Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Printer Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Network Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
NetSpot Device Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Windows Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Configuring Windows Firewall to unblock communication with client computers . . . . 7-9
Configuring Windows Firewall to block communication with client computers . . 7-11
Configuring Windows Firewall to unblock communication with the server . . 7-12
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
Locating the Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
vi
Introduction
Thank you for purchasing the Canon LBP3000. In order to fully understand the features of
this product and thus be able to use it more effectively, please be sure to fully read this
instruction manual before using the product. Store this manual in a safe place after reading
it.
How To Use This Manual
Conventions
The following symbols are used in this manual to explain procedures, restrictions,
handling precautions, and instructions that should be observed for safety.
WARNING
Indicates warnings that, if followed incorrectly, may lead to death or
serious personal injury. To use the product safely, be sure to adhere to
these warnings.
CAUTION
Indicates cautions that, if followed incorrectly, may lead to personal
injuries or damage to property. To use the product safely, be sure to
adhere to these cautions.
IMPORTANT Indicates important points and limitations that need to be observed. Be
sure to read these carefully to avoid running into problems operating the
printer.
NOTE
Indicates additional information related to the operation of the printer. It
is recommended that you read these points.
Notation for Keys and Buttons
In this manual, the following notation is used for key and button names.
• Control
panel keys: <Key icon> + (Key Name)
Examples:
(Paper Key)
• Button appearing on the computer screen: [Button Name]
Examples: [OK]
[Details]
vii
Displays Used in This Manual
Displays used in this manual may differ from those on your computer depending on
the system environment.
The buttons which you should press are marked with a
as shown below.
When multiple buttons can be pressed on the screen shot of computer operation
screen, all buttons are marked. Select the button which suits your needs.
10 Click [Next].
Click this button for operation.
Abbreviations Used in This Manual
In this manual, product names and model names are abbreviated as follows:
viii
Microsoft® Windows® 95 operating system:
Windows 95
Microsoft® Windows® 98 operating system:
Windows 98
Microsoft® Windows® Millennium Edition operating system:
Windows Me
Microsoft® Windows® 2000 operating system:
Windows 2000
Microsoft® Windows® XP operating system:
Windows XP
Microsoft® Windows ServerTM 2003 operating system:
Windows Server 2003
Microsoft® Windows VistaTM operating system:
Windows Vista
Microsoft® Windows® operating system:
Windows
Legal Notices
Model Name
The following names may be provided for the safety regulations in each sales
region of this Laser Beam Printer.
110 - 127 V model: L11121A
220 - 240 V model: L11121E
FCC (Federal Communications Commission)
Laser Beam Printer, Model L11121A
■ 110 -127 V model
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of
FCC Rules.
ix
Do not make any changes or modifications to the equipment unless otherwise specified in
the manual. If such changes or modifications should be made, you could be required to
stop operation of the equipment.
Canon U.S.A. Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516) 328-5600
EMC Directive (220 - 240 V model)
"This equipment has been tested in a typical system to comply with the technical
requirements of EMC Directive."
• Use
of shielded cable is necessary to comply with the technical requirements of
EMC Directive.
The product is in conformity with the EMC directive at nominal mains input 230 V,
50 Hz although the rated input of the product is 220 - 240 V, 50/60 Hz.
C-tick marking
on the rating label means that we declare the product is in
conformity with the relevant requirements at nominal mains input 230 V, 50 Hz
although the rated input of the product is 220 - 240 V, 50/60 Hz.
Laser Safety (110 - 127/220 - 240 V models)
Laser radiation could be hazardous to the human body. For this reason, laser
radiation emitted inside this printer is hermetically sealed within the protective
housing and external cover. No radiation can leak from the printer in the normal
operation of the product by the user.
This printer is classified as a Class 1 laser product under IEC60825-1:1993,
EN60825-1:1994, and as for the U.S.A., it is classified as Class 1 under the Code of
Federal Regulations, 1040.10 of Title 21.
x
This printer has been classified under IEC60825-1:1993, EN60825-1:1994 and
conforms to the following classes:
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL A RAYONNEMENT LASER DE CLASSE 1
APPARECCHIO LASER DI CLASSE 1
PRODUCTO LASER DE CLASE 1
APARELHO A LASER DE CLASSE 1
(220 - 240 V model only)
CAUTION
Performance of procedures other than those specified in this manual may result
in hazardous radiation exposure.
International Energy Star-Program
As an ENERGY STAR Partner, Canon Inc. has determined that
this product meets the ENERGY STAR Program for energy
efficiency.
The International ENERGY STAR Office Equipment Program is
an international program that promotes energy saving through
the use of computers and other office equipment.
The program backs the development and dissemination of
products with functions that effectively reduce energy
consumption. It is an open system in which business proprietors
can participate voluntarily.
The targeted products are office equipment, such as
computers, displays, printers, facsimiles, and copiers. The
standards and logos are uniform among participating nations.
xi
WEEE Directive
European Union (and EEA) only.
This symbol indicates that this product is not to be disposed of
with your household waste, according to the WEEE Directive
(2002/96/EC) and your national law. This product should be
handed over to a designated collection point, e.g., on an
authorized one-for-one basis when you buy a new similar
product or to an authorized collection site for recycling waste
electrical and electronic equipment (EEE). Improper handling of
this type of waste could have a possible negative impact on the
environment and human health due to potentially hazardous
substances that are generally associated with EEE. At the
same time, your cooperation in the correct disposal of this
product will contribute to the effective usage of natural
resources. For more information about where you can drop off
your waste equipment for recycling, please contact your local
city office, waste authority, approved WEEE scheme or your
household waste disposal service. For more information
regarding return and recycling of WEEE products, please visit
www.canon-europe.com/environment.
(EEA: Norway, Iceland and Liechtenstein)
Trademarks
Canon, the Canon Logo, and LBP are trademarks of Canon Inc.
Adobe® Acrobat is a trademark of Adobe Systems Incorporated.
Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and
other countries.
Windows Server and Windows Vista are trademarks of Microsoft Corporation.
Other product and company names herein may be the trademarks of their
respective owners.
Copyright
Copyright 2005 by Canon Inc. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording, or by any
information storage or retrieval system without the prior written permission of
Canon Inc.
xii
Disclaimers
The information in this manual is subject to change without notice.
CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS PROVIDED HEREIN,
INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO
MARKETABILITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OF USE OR AGAINST INFRINGEMENT OF ANY PATENT. CANON
INC. SHALL NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES
RESULTING FROM THE USE OF THIS MATERIAL.
Legal Limitations on the Usage of Your Product and the
Use of Images
Using your product to scan, print or otherwise reproduce certain documents, and
the use of such images as scanned, printed or otherwise reproduced by your
product, may be prohibited by law and may result in criminal and/or civil liability. A
non-exhaustive list of these documents is set forth below. This list is intended to be
a guide only. If you are uncertain about the legality of using your product to scan,
print or otherwise reproduce any particular document, and/or of the use of the
images scanned, printed or otherwise reproduced, you should consult in advance
with your legal advisor for guidance.
•
Paper Money
•
Travelers Checks
•
Money Orders
•
Food Stamps
•
Certificates of Deposit
•
Passports
•
Postage Stamps (canceled or
uncanceled)
•
Immigration Papers
•
Identifying Badges or Insignias
•
Internal Revenue Stamps (canceled
or uncanceled)
•
Selective Service or Draft Papers
•
Bonds or Other Certificates of
Indebtedness
•
Checks or Drafts Issued by
Governmental Agencies
•
Stock Certificates
•
Motor Vehicle Licenses and
Certificates of Title
•
Copyrighted Works/Works of Art
without Permission of Copyright
Owner
xiii
Important Safety Instructions
Before using this product, make sure you read this section (Important Safety
Instructions) thoroughly, and that you use the product correctly. The purpose of the
warnings and cautions contained in this section is to prevent injuries to the user and
other people, and to prevent damage to property. Make sure you adhere to these
warnings and cautions. Do not perform any actions that are not explicitly written in
this manual.
Installation
WARNING
• Do not install the printer in a location near alcohol, thinners, or other flammable
substances. If an inflammable substance comes into contact with the electrical unit
inside the printer it may ignite or cause an electrical shock.
• Do not put any of the following types of objects on top of this printer. If any of these
items come into contact with the electrical unit inside the printer it may ignite or
cause an electrical shock.
If any of these objects fall into the printer, turn the printer and computer off
immediately a, and disconnect the USB cable if it is connected b. After this, pull out
the power plug c, and contact the store where you purchased the printer.
- Necklaces and other metal objects
- Cups, vases, flowerpots, and other containers filled with water or liquids
b
a
c
a
xiv
CAUTION
• Do not install the printer on an unsteady platform, an uneven surface, or any other
unstable location, or any location subject to vibrations. If the printer falls down or the
platform tips over, someone may be injured.
• Do not install this printer in a location where a wall or other object will block the
ventilation slots in the printer. Do not install the printer on a bed, sofa, thick carpet,
etc. If the ventilations slots are blocked, the internal printer components will
overheat, and this may cause a fire.
• Do not install the printer in any of the following locations. Doing so may cause fire or
electrical shock.
- A damp or dusty location
- A location exposed to smoke and steam, such as next to a stove or humidifier.
- A location exposed to rain or snow
- A location near water faucets or water
- A location exposed to direct sunlight
- A location subject to high temperatures
- A location near open flames
• When you are installing the printer, work slowly and carefully to avoid pinching your
hands between the printer and the floor, or between the printer and another product.
You may be injured if your hands, etc. are pinched by the printer.
• When connecting the USB cable, connect the cable correctly by following the
directions in this manual. Failure to properly connect cables can damage the printer
or cause electrical shocks.
• When you are carrying the printer, hold the printer correctly by following the
directions in this manual. Dropping the printer may lead to personal injuries. (See
"Moving the Printer," on p. 5-21.)
Power Supply
WARNING
• Do not scratch, break or modify the power cord. Do not place heavy items on the
cord, pull on the cord, or bend the cord excessively. Electrical current may flow out
from damaged parts of the cord, causing fire or electrical shock.
• Do not place the cord near any heating appliance. This can melt the cord insulation,
causing fires or electrical shock.
• Do not plug in or unplug the electrical cord if your hands are wet. Doing so may
cause an electrical shock.
• Do not connect an excessive number of appliances to a single outlet. Doing so may
cause fire or electrical shock.
• Do not coil or tie knots in the electrical cord. Doing so may cause fire or electrical
shock.
• Make sure the plug is fully inserted into the power outlet. If the plug is not fully
inserted, fire and electrical shock may result.
xv
• Do not use any electrical cables other than the supplied cord. Doing so may cause
fire or electrical shock.
• In principle, you should not connect the printer using an extension cord or connect
too many appliances to a single power outlet. However, if there is no choice but to
use an extension cord or connect multiple appliances to a single power outlet, it is
the responsibility of the user to take care of the following cautions. If these points are
not followed correctly, a fire or electrical shock may result.
- Do not connect one extension cord to another.
- Make sure that the voltage of the power plug matches the voltage on the rating label
(attached to the back of the printer) when you use the printer.
- Use an extension cord that can carry an electrical current greater than the value
indicated on the rating label (attached to the back of the printer).
- When you use an extension cord, untie the cord binding, and insert the power plug
completely into the extension cord outlet to ensure a firm connection between the
power cord and the extension cord.
- Periodically check that the extension cord is not overheated.
CAUTION
• Do not use a power source with a voltage other than that indicated. Doing so may
cause fire or electrical shock.
• When you unplug the power cord, make sure you hold the cord by the plug. If you pull
on the cord itself, the cord may experience damage such as exposure of the core
wires or an open circuit, and electrical current flowing out of the damaged section
can cause fires or electrical shock.
• Whenever you pull out the power plug, make sure there are no objects around the
power plug. Do not pull out the power plug in an emergency.
Handling
WARNING
• Do not disassemble or modify this product. This product contains high voltage and
high temperature internal parts, which could cause a fire or electrical shock if
tampered with.
• Electrical components can produce unexpected hazards if not handled correctly.
Make sure that the power cord, cables, and internal gears and electrical components
are kept out of reach of children.
• If this product emits strange noises, smoke, excess heat, or unusual smells, turn the
power off immediately, and disconnect the USB cable if it is connected. Next, pull out
the power plug, and contact the store where you purchased this printer. Continuing
to use a faulty printer may cause fire or electrical shock.
• Do not use flammable sprays near this product. If the gas from a spray comes into
contact with the electrical unit inside the printer it may ignite or cause an electrical
shock.
xvi
• When you are moving the printer, always turn the printer and computer off, unplug
the power plug, and remove the interface cable. If you move the printer without
unplugging the cables, the electrical cord and interface cable may be damaged,
causing a fire or electrical shock.
• Do not drop paper clips, staples, or any other metallic objects into the printer. Do not
spill water, liquids, or flammable substances (alcohol, benzene, thinners, etc.) onto
the printer. If any of these items come into contact with the electrical unit inside the
printer they may ignite or cause an electrical shock. If any of these objects fall into
the printer, turn the printer and computer off immediately, and disconnect the USB
cable if it is connected. After this, pull out the power plug, and contact the store
where you purchased the printer.
• If you are connecting or disconnecting the USB cable while the printer power plug is
connected to a power outlet, make sure that you do not touch the metal parts of the
connector. Doing so may cause an electrical shock.
CAUTION
• Do not put any heavy objects on top of this product. If a heavy object topples over or
falls it can cause personal injuries.
• If you are not going to use the printer for a long period of time, such as overnight,
turn the printer off for safety reasons. Furthermore, if you are not going to use the
printer for a longer period of time, such as a weekend, turn the printer off and
disconnect the power plug for safety.
• Keep your hands or clothing away from the roller in the output area. Even if the
printer is not printing, sudden rotation of the roller may catch your hands or clothing,
resulting in personal injury.
• Laser light can be harmful to the human body. The laser scanning unit in this product
is sealed behind a cover, and there is virtually no risk of being exposed to the laser
light if the product is operated normally. Be sure to observe the following safety
precautions.
- Do not open any of the printer covers unless directed to by this manual.
- Do not remove the caution label attached to the cover of the laser scanner unit.
- If the laser beam escapes from the printer, exposure may cause serious damage to
your eyes.
xvii
Maintenance and Inspections
WARNING
• Turn the printer and computer off, disconnect the USB cable and remove the power
plug from the wall when you are cleaning the printer. Failure to do so may cause fire
or electrical shock.
• When cleaning the printing, always use a cloth dipped in plain water or water
containing a mild soap solution and firmly wring the excess moisture out of the cloth
before use. Do not use alcohol, benzene, thinners or any other inflammable
substance. If an inflammable substance comes into contact with the electrical unit
inside the printer it may ignite or cause an electrical shock.
• There is a high-voltage unit inside this product. When you are clearing paper jams or
inspecting the interior of the printer, make sure that no necklaces, bracelets, or other
metallic objects come into contact with the inside of the printer. If this does happen, it
may cause burns or an electrical shock.
• Do not put spent toner cartridges into a fire. Any toner remaining in the toner
cartridge may ignite, causing burns or fire.
• Unplug the power plug periodically and wipe away any dust or dirt that has built up
around the power outlet. If the power plug is left connected for a long period of time
in a dusty, humid, or smoky environment, dust that gathers around the power outlet
will absorb moisture and reduce the effectiveness of the insulation, leading to fires.
CAUTION
• Never attempt to service this printer yourself, except as explained in this manual.
There are no user serviceable parts inside the printer. Adjust only those controls that
are covered in the operating instructions. Improper adjustment could result in
personal injury and/or damage requiring extensive repair that may not be covered
under your Limited Warranty.
• The area around the fixing unit inside the printer becomes hot during use. If you are
inspecting the inside of the printer while you are clearing a paper jam, etc., take care
not to touch the area around the fixing unit. Doing so can cause burns.
• Be careful to avoid staining your clothes or hands with toner while you are clearing a
paper jam or replacing the toner cartridge. If you do get any toner on your clothes or
hands, wash it off immediately with cold water. If you rinse using hot water the toner
may become fixed, creating a stain that cannot be removed.
xviii
• When you are clearing jammed paper from inside the printer, remove the paper gently
so that toner that is on the jammed paper does not spray out of the printer. This could
lead to toner getting in your eyes or mouth. If toner gets into your eyes or mouth,
wash it out immediately with cold water and consult a doctor.
• When loading paper or removing jammed paper, take care not to cut your hands with
the edges of the paper.
• When removing a used toner cartridge from the toner cartridge slot, remove the
cartridge carefully to prevent the toner from scattering and entering your eyes or
mouth. If the toner enters your eyes or mouth, wash them immediately with cold
water and immediately consult a physician.
Consumables
WARNING
• Do not put spent toner cartridges into a fire. The toner may ignite cause burns and
fires.
• Do not store toner cartridges or paper in a location where there are open flames.
Toner and paper could ignite, causing burns and fires.
CAUTION
Store toner cartridges and other consumables out of reach of infants. If toner from a
toner cartridge is swallowed, seek medical attention immediately.
Other
WARNING
The toner cartridge produces a weak magnetic field. If someone who is using a
pacemaker feels any unusual sensations, they should stay clear of the toner
cartridge and seek medical attention immediately.
xix
xx
Before You Start Using This Printer
1
CHAPTER
This chapter describes the major features and basic functions of this printer.
Printer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Component Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Inside the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
Indicators and the Paper Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Turning the Printer On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Turning the Printer On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-15
Turning the Printer Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-16
1-1
Printer Features
■ High Performance Printing System "CAPT"
1
Before You Start Using This Printer
The LBP3000 is equipped with the latest CAPT (Canon Advanced Printing Technology)
software that supports Windows OS. This system allows the data processing that is
conventionally handled by the printer during printing to be batch processed by the
computer, delivering high-speed printing that utilizes the full power of the computer. On
top of this, the time taken until the computer is released has also been reduced, and
printer information, such as paper out during printing, is displayed on the computer
screen.
■ USB 2.0 High Speed Installed as Standard
The LBP3000 is capable of high transmission speeds of up to 480 Mbps through an
interface that features support for USB 2.0 High Speed.
■ High Speed Printing and Super High Quality Printing
Delivers a high printing speed of 14 pages per minute. Relieves the stress of waiting for a
print job to finish. This printer is fitted with a 600dpi laser printer engine. A stunningly high
resolution of 2400 effective dpi x 600 dpi is made possible through the Automatic Image
Refinement which is unique to Canon. Furthermore, because the grayscale makes use of
a dithering pattern, photographs and graphics can be printed with beautifully subtle
reproduction.
■ Support for a Wide Variety of Networks
When used as a network printer, the printer status can be displayed on both the client and
server computers. Job control can also be performed from either computer.
■ Support for Various Types of Media
The LBP3000 supports plain paper, Index Card, envelopes (Envelope C5, Envelope
COM10, Envelope DL, Envelope Monarch), label paper, transparencies and a variety of
other paper. In addition, even though this is an A4 printer, A3 and B4 size documents can
be printed reduced onto A4 paper using reduction mode.
You can also print onto non-standard custom paper sizes.
■ Low Power Consumption and Quick Startup
The revolutionary On-Demand Fixing Technology, which is exclusive to Canon, delivers
both energy savings and quick startup. This technology means that the fixing heater is
only heated up momentarily during printing, and so no time is needed to warm the printer
up. As a result, you can always start printing directly from standby mode without any
delay. Furthermore, the energy saving design delivers an average energy consumption in
standby mode of a mere 2W.
1-2
Printer Features
■ Compact and Silent Design
The compact design of the main printer body means that it can be used in the tiny spaces
in the home or office.
The noise-reducing design delivers quiet operation even during printing. Because the
printer is silent in standby mode, you can use it even in the middle of the night, without
having to be concerned about those around you.
■ Simple Maintenance and Printer Status Window
The Printer Status Window that is displayed during printing makes it easy to tell exactly
what the printer is doing through the use of graphical and audio cues, improving the
overall usability of the printer.
Printer Features
1-3
Before You Start Using This Printer
1
The toner cartridges made for this printer (Canon genuine part) are designed as a single
part containing both toner and the light sensitive drum, so that they can be easily
replaced.
Component Names and Functions
This section describes the names and functions of each component of the printer
so that you can use the printer properly and make full use of all of the printer's
features.
Before You Start Using This Printer
1
CAUTION
Do not install this printer in a location where a wall or other object will block the
ventilation slots in the printer. If the ventilations slots are blocked, the internal
printer components will overheat, and this may cause a fire.
NOTE
Consult the store where you purchased this product in the event that any of the parts are
broken.
1-4
Component Names and Functions
Front View
a
b
c
d
e
c
h
g
a Top Cover
This cover needs to be opened to replace the toner
cartridge or to clear paper jams. (See p. 5-3, p. 6-6)
b Output Tray
Assists in the collection of printed paper.
c Paper Guides
These can be adjusted to match the width of the
paper, allowing the paper to feed straight.
d Small Paper Guide
When you are loading small sized custom paper
sizes, this should be attached to the rear paper
guide.
f
e Rear Paper Guide
Adjust this to suit the loaded paper to keep the rear
edge of the paper aligned.
f Multi-Purpose Tray
This tray can hold up to a maximum of 150 sheets of
plain paper (64 g/m2). (See p. 2-9)
g Manual Feed Tray
This paper source is for use when you are printing
on paper fed manually one sheet at a time.
(See p. 2-9)
h Tray Cover
Open this cover when you are loading paper in the
multi-purpose tray. The tray cover both protects the
paper loaded in the multi-purpose tray from dust and
acts as the tray when you are loading paper in the
manual feed tray.
Component Names and Functions
1-5
Before You Start Using This Printer
1
Rear View
a
b
Before You Start Using This Printer
1
f
c
d
e
a Ventilation Slots
These are ventilation slots for cooling the internal
parts of the printer. Do not block or obstruct the
ventilation slots.
b Power Switch
This switch turns the printer on and off.
(See p. 1-15)
c Power Socket
Connect the supplied power cord to this socket.
(See p. 1-9)
1-6
Component Names and Functions
d Rating Label
This also shows the electrical current rating and
average electrical current consumption.
e USB Connector
The USB cable plugs into this connector. This is
used to connect the printer to the USB port on a
computer, etc.
(See p. 1-13)
f USB Cover
Open this cover when you are connecting or
disconnecting the USB cable.
Inside the Printer
a
Before You Start Using This Printer
1
b
a Toner Cartridge Guide
When you install the toner cartridge, make sure that
the protrusions on the edges of the cartridge align
with this guide while you push the cartridge in.
(See p. 5-6)
b Transfer Roller
This is a very important part of the printer that
transfers toner onto the paper during printing.
Component Names and Functions
1-7
Indicators and the Paper Key
a
Before You Start Using This Printer
1
b
a Power Indicator
This light turns on when the power is on.
1-8
Component Names and Functions
b Paper Indicator / Paper Key
This flashes when the printer runs out of paper or
when the paper does not feed properly. After refilling
a paper tray, press this key to restart printing.
Connecting the Power Cord
This section explains how to connect the power cord to the printer. Refer to
"Important Safety Instructions," on p. xiv before connecting the printer.
Connecting the Power Cord
WARNING
• Do not scratch, break or modify the power cord. Do not place heavy items on
the cord, pull on the cord, or bend the cord excessively. Electrical current may
flow out from damaged parts of the cord, causing fire or electrical shock.
• Do not place the cord near any heating appliance. This can melt the cord
insulation, causing fires or electrical shock.
• Do not plug in or unplug the electrical cord if your hands are wet. Doing so may
cause an electrical shock.
• Do not connect an excessive number of appliances to a single outlet. Doing so
may cause fire or electrical shock.
• Do not coil or tie knots in the electrical cord. Doing so may cause fire or
electrical shock.
• Make sure the plug is fully inserted into the power outlet. If the plug is not fully
inserted, fire and electrical shock may result.
• Do not use any electrical cables other than the supplied cord. Doing so may
cause fire or electrical shock.
• In principle, you should not connect the printer using an extension cord or
connect too many appliances to a single power outlet. However, if there is no
choice but to use an extension cord or connect multiple appliances to a single
power outlet, it is the responsibility of the user to take care of the following
cautions. If these cautions are not followed correctly, a fire or electrical shock
may result.
- Do not connect one extension cord to another.
- Make sure that the voltage of the power plug matches the voltage on the rating
label (attached to the back of the printer) when you use the printer.
- Use an extension cord that can carry an electrical current greater than the
value indicated on the rating label (attached to the back of the printer).
- When you use an extension cord, untie the cord binding, and insert the power
plug completely into the extension cord outlet to ensure a firm connection
between the power cord and the extension cord.
- Periodically check that the extension cord is not overheated.
Connecting the Power Cord
1-9
Before You Start Using This Printer
1
CAUTION
• Do not use a power source with a voltage other than that indicated. Doing so
may cause fire or electrical shock.
• When you unplug the power cord, make sure you hold the cord by the plug. If
you pull on the cord itself, the cord may experience damage such as exposure
of the core wires or an open circuit, and electrical current flowing out of the
damaged section can cause fires or electrical shock.
• Whenever you pull out the power plug, make sure there are no objects around
the power plug. Do not pull out the power plug in an emergency.
Before You Start Using This Printer
1
IMPORTANT
• Do not plug the power cord into the auxiliary outlet on a computer.
• One AC power outlet should be used exclusively for the printer.
• Do not connect this printer to an uninterruptible power supply. The printer may
malfunction when a power outage occurs, and there is a risk of damaging the printer.
1
Make sure that the power switch of the printer is turned off.
The printer is off when the "
2
1-10
" side of the power switch is pressed in.
Plug the supplied power cord securely into the power socket.
Connecting the Power Cord
Plug the power plug into the AC power outlet.
1
Before You Start Using This Printer
3
Connecting the Power Cord
1-11
Connecting to a Computer
This section describes how to connect the printer to a computer.
This printer is fitted with a USB connector as standard, and can be connected to a
computer using a USB cable.
Connect the printer to a computer equipped with a USB port using a USB cable.
Before You Start Using This Printer
1
WARNING
• If you are connecting or disconnecting the USB cable while the printer power
plug is connected to a power outlet, make sure that you do not touch the metal
parts of the connector. Doing so may cause an electrical shock.
• Do not pull out the USB cable while the computer or printer are turned on. Doing
so may damage the printer.
IMPORTANT
This printer uses bidirectional communication. Operation of the printer when connected
via unidirectional communication equipment has not been tested. As a result, Canon
cannot guarantee printer operation when the printer is connected using unidirectional
print servers, USB hubs and switching devices.
NOTE
• The USB interface of the printer depends on the OS of the computer it is connected to as
follows. For further details, please inquire at the store where you purchased the printer.
- Windows 98/Me: USB Full-Speed (USB1.1 equivalent)
- Windows 2000/XP/Server 2003/Vista: USB 2.0 Hi-Speed/USB Full-Speed (USB1.1
equivalent)
• When you connect this printer to a computer via a USB cable, use a computer where the
USB port has been guaranteed to operate correctly by the manufacturer.
• A USB cable is only supplied with 220 - 240 V model for countries and regions of Asia. In
other countries and regions, prepare according to the specifications of your computer.
1
1-12
Make sure that the computer and printer are turned off at the
power.
Connecting to a Computer
2
Open the USB cover.
3
Connect the B-type (square) end of the USB cable to the USB
connector on the rear side of the printer, and close the USB
cover.
Connecting to a Computer
1-13
Before You Start Using This Printer
1
4
Connect the A-type (flat) end of the USB cable to the USB port
on the computer.
Before You Start Using This Printer
1
NOTE
If you are not sure about the USB cable that is supported by your computer, contact the
store where you purchased the computer.
1-14
Connecting to a Computer
Turning the Printer On and Off
Turning the Printer On
To begin using the printer, press the " " side of the power switch to turn the printer
on. After performing a self-diagnostic check, the printer is ready to print.
IMPORTANT
• Do not turn the printer on again immediately after turning the printer off. If you want to
turn the printer on again after turning it off, wait at least 10 seconds after turning the
printer off before turning it on again.
• Refer to "Troubleshooting," on p. 6-1 if the printer does not operate properly, or an error
message appears in the Printer Status Window.
• When you turn the printer on for the first time after installing it, a single sheet of white
paper may be ejected from the printer. This is not a malfunction.
1
Press the " " side of the power switch to turn the printer on.
Turning the Printer On and Off
1-15
1
Before You Start Using This Printer
The printer can be turned on and off using the power switch on the left side of the
printer body. To avoid running into unexpected problems, be sure to correctly
memorize this procedure.
The printer Power Indicator turns on and the printer runs a self-diagnostic test. If
there are no errors in the self-diagnostic test, the printer is ready to print.
Light On
Before You Start Using This Printer
1
Turning the Printer Off
Use the following procedure to turn the printer off.
IMPORTANT
• If the printer is used on a network, make sure that it is not printing data from another
computer before turning the power off.
• When the printer is turned off, any remaining print data in the printer's memory is erased.
If you need the print data, wait for the printer to finish printing before turning the power
off.
• Do not turn the printer off under any of the following circumstances:
- While printing
- While running a self-diagnostic test immediately after turning the printer on
1
Press the "
" side of the power switch to turn the printer off.
IMPORTANT
When the " " side of the power switch is pressed in, the power consumption of the
printer is 0 W.
1-16
Turning the Printer On and Off
Loading and Delivering Paper
2
CHAPTER
This chapter describes the types of paper that can be used with this printer, and how the paper
is loaded and delivered.
Paper Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Usable Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Printable Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Paper You Cannot Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Storing Blank Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Storing Printed Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
Paper Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Paper Source Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Paper Source Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Paper Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Output Tray Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Output Tray Capacities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies. . . . . . . . . . . . 2-14
Loading the Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23
Printing on Index Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
Loading Index Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-30
Printing on Envelopes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Loading Envelopes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-34
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-41
Printing on Custom Paper Sizes (Non-Standard Sizes) . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
Loading Custom Paper Sizes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-45
Selecting Printer Driver Settings and Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-54
2-1
Paper Requirements
Usable Paper
To get the most out of the features of this printer, you should use the right kind of
paper. If you use poor quality paper, the printing quality will deteriorate and the
paper will jam easily.
Loading and Delivering Paper
2
IMPORTANT
• A safety feature that prevents printer damage due to overheating, etc. may be activated
in the following circumstances, causing the printing speed to drop.
- When printing continuously on B5, A5 or Executive size paper, the printing speed may
drop to 3.9 ppm.
• Use the paper capacity for each type of paper as a guide to the number of sheets of
paper that can be printed continuously.
Paper Sizes
You can use the following paper sizes with this printer. The symbol
indicates
paper that can be loaded, and
indicates paper that cannot be loaded.
Paper Size
A4
B5
A5
Legal
Letter
Executive
Custom Paper Size
Width: 76.2 mm to 215.9 mm
Length: 127.0 mm to 355.6 mm
Envelope DL 110.0 mm x 220.0 mm
Envelope COM10 105.0 mm x 241.0 mm
Envelope C5 162.0 mm x 229.0 mm
Envelope Monarch 98.4 mm x 190.5 mm
Index Card 76.2 mm x 127.0 mm
2-2
Paper Requirements
Paper Source
Multi-Purpose Tray
Manual Feed Tray
Paper Types
You can use the following types of paper with this printer. The symbol
indicates
paper that can be loaded, and
indicates paper that cannot be loaded.
Printer Driver
Setting
Plain Paper
(64 to 90 g/m2)
[Plain Paper],
[Plain Paper L]*1
Heavy Paper
(91 to 163 g/m2)
[Heavy Paper],
[Heavy Paper H]*2
Transparencies
[Transparency]
Label Paper
[Plain Paper]*3
Index Card
*4
Envelopes
*4
Paper Source
Multi-Purpose
Tray
Manual Feed
Tray
2
*1 If the paper curls excessively when printed using the [Plain Paper] setting, select [Plain Paper L].
*2 If you want to get improved fixing properties over the results of printing using the [Heavy Paper] setting, select
[Heavy Paper H].
*3 When you are printing on label paper, set the paper type setting to [Plain Paper].
*4 When printing Index Card or envelopes, the printer automatically selects the appropriate printing mode when you
select the paper size. You can change the paper size using the [Output Size] setting on the [Page Setup] sheet.
■ Plain Paper
This printer can print on plain paper with width in the range of 76.2 to 215.9 mm, length in
the range of 127.0 to 355.6 mm, and weight in the range of 64 to 90 g/m2 including the
standard paper sizes: A4, B5, A5, Legal, Letter, and Executive.
■ Heavy Paper
This printer can print on heavy paper with width in the range of 76.2 to 215.9 mm, length
in the range of 127.0 to 355.6 mm, and weight in the range of 91 to 163 g/m2 including the
standard paper sizes: A4, B5, A5, Legal, Letter, and Executive.
■ Transparencies
This printer can print on A4 and Letter size transparencies.
IMPORTANT
Thoroughly fan through each sheet before loading transparencies as they easily stick to
each other.
■ Label Paper
This printer can print on A4 and Letter size label paper.
Paper Requirements
2-3
Loading and Delivering Paper
Paper Type
IMPORTANT
Do not use the following types of label paper with this printer. Using label paper that
meets any of these conditions may result in paper jams that are difficult to clear or may
cause damage to the printer.
- Peeling labels or partly used labels
- Labels that peel off from the backing sheet too easily
- Labels where the adhesive is exposed
■ Index Card
You can use index card in this printer.
2
Loading and Delivering Paper
IMPORTANT
Index card can only be loaded in the manual feed tray.
■ Envelopes
The envelopes that can be used with this printer are as follows:
Envelope DL
Envelope Monarch
110.0 mm x 220.0 mm
(4.33 inch x 8.66 inch)
98.4 mm x 190.5 mm
(3.88 inch x 7.50 inch)
Envelope COM10
Envelope C5
104.9 mm x 241.3 mm
(4.13 inch x 9.50 inch)
162.0 mm x 229.0 mm
(6.38 inch x 9.02 inch)
* Envelopes with a flap on the short edge cannot be used.
IMPORTANT
• The following envelopes cannot be used with this printer. Using any of these envelopes
may result in paper jams that are difficult to clear or may cause damage to the printer.
- Envelopes with fasteners or snaps
- Envelopes with address windows
- Envelopes with adhesive on the surface
- Wrinkled or creased envelopes
- Poorly manufactured envelopes in which the glued parts are uneven
- Irregularly-shaped envelopes
• Before loading the envelopes, push down on the stack of envelopes to release any
remaining air, and press down firmly along the folded edges of the envelopes.
• Do not print on the reverse side (glued side) of envelopes.
• Printing speed drops when printing on envelopes.
2-4
Paper Requirements
NOTE
When printing envelopes, the envelopes may become creased.
Abbreviations of Paper Sizes
The following abbreviations are used for the sizes displayed on the multi-purpose tray and
manual feed tray.
Paper Guide
Legal
LGL
Letter
LTR
Executive
2
Loading and Delivering Paper
Paper Size
EXEC
.
Printable Area
The printable area of this printer is as follows:
■ Plain Paper / Heavy Paper / Transparency / Label Paper
You can print within the following area.
5 mm
4 mm
6 mm
5 mm
Paper Requirements
2-5
■ Envelopes / Index Card
Printable up to 10 mm from the edges of an envelope.
You may need to adjust the printing position depending the application you are using.
(Sample : Envelope COM10)
241.3 mm
10 mm
(9.50 inch)
10 mm
10 mm
104.9 mm
(4.13 inch)
2
Loading and Delivering Paper
10 mm
Paper You Cannot Use
To avoid problems such as paper jams and other malfunctions, you should not use
the following types of paper:
IMPORTANT
• Paper that jams easily
- Paper that is too thick or too thin
- Irregularly-shaped paper
- Wet or moist paper
- Torn or damaged paper
- Rough, extremely smooth, or glossy paper
- Paper with binding holes or perforations
- Curled or creased paper
- Specially coated paper (coated paper for ink jet printers, etc.)
- Labels that peel off from the backing sheet too easily
- Paper that has already been printed on using a copy machine or other laser printer.
(The reverse side of the paper is also unusable.)
- Paper with jagged edges
- Wrinkled paper
- Paper with the corners folded
• Paper where the properties change at high temperatures
- Paper that contains ink that melts, burns, evaporates or emits harmful gases at the high
temperatures (approx. 150°C or 302°F) present in the fixing unit.
- Heat-sensitive paper
- Treated color paper
- Specially coated paper (coated paper for ink jet printers, etc.)
- Paper with adhesive on the surface
2-6
Paper Requirements
• Paper that causes printer malfunctions or damages the printer
- Carbon paper
- Paper with staples, clips, ribbons or tapes
- Paper that has already been printed on using a copy machine or other laser printer.
(The reverse side of the paper is also unusable.)
• Paper that is difficult for the toner to fix onto
- Paper with rough surfaces
- Specially coated paper (coated paper for ink jet printers, etc.)
- Paper containing thick fibers
Even standard paper may deteriorate if not stored correctly. Degraded paper can
cause paper feed problems and paper jams, and may reduce printing quality.
Observe the following guidelines when storing and handling paper:
IMPORTANT
• Store paper away from moisture since paper quality deteriorates in a moist environment.
• The paper wrapper around new paper acts to prevent dampness and drying. Leave the
wrapper intact until you are ready to use the paper. You should also re-wrap the wrapper
around paper that you do not use.
• Store paper on a flat surface.
• Do not store paper on the floor where water and moisture can accumulate.
• Do not store paper in a place where it will curl or be creased.
• Do not store paper vertically or store too many stacks of paper in one pile.
• Avoid direct sunlight and humid or dry places when storing paper.
• If there are extreme differences in temperature between the storage area and the place
where the paper is used, leave the paper in the wrapper in the usage area for about a
day to allow the paper to adjust before using it. Rapid changes in temperature and
humidity can cause paper to curl or wrinkle.
● If damp paper is printed
If damp paper is printed, steam may come out of the surroundings of the output area
of the printer.
This is because water contained in the paper is evaporating by heat radiated when
the toner is fixing. Therefore, this is not abnormal (Particularly, this is apt to occur at
low temperature.).
WARNING
If you experience a burnt odor, immediately turn OFF the printer, unplug
the power plug from the AC power outlet, and then contact your local
authorized Canon dealer. Otherwise, this may result in a fire or electrical
shock.
Paper Requirements
2-7
Loading and Delivering Paper
2
Storing Blank Paper
Storing Printed Paper
When handling or storing documents printed using this printer, be careful of the
following points:
IMPORTANT
• Do not store in clear folders or with other PVC materials. This can dissolve the toner,
causing the paper to stick to the PVC material.
• When gluing paper, be sure to use insoluble adhesive. The use of soluble adhesives can
cause the toner to dissolve. When you first use an adhesive, test it on an unneeded
printout before use.
Whenever you stack printouts, check that the documents are completely dry. If the
printouts are stacked when they are not completely dry, the toner may dissolve.
• Store paper on a flat surface. If the paper becomes folded or wrinkled, the toner may
peel.
• Do not store in a high temperature place. This can cause the toner to melt, making the
colors bleed.
• If you are storing printouts for a long period of time (2 years or more), store them in a
binder, etc. (Long-term storage can make printouts appear discolored due to
discolorations in the paper.)
Loading and Delivering Paper
2
2-8
Paper Requirements
Paper Sources
Paper Source Types
This printer has the following paper sources:
■ Paper Source / Capacity
Manual Feed Tray:
1 sheet
Multi-Purpose Tray: Approx. 150 sheets (Plain paper: 64 g/m2)
Manual Feed Tray
Multi-Purpose Tray
IMPORTANT
When you are printing from the multi-purpose tray, make sure that there is no paper in
the manual feed tray. If there is any paper in the manual feed tray, paper will feed from the
manual feed tray because manual feed tray has priority over the multi-purpose tray.
Paper Sources
2-9
Loading and Delivering Paper
2
Paper Source Capacities
Paper Type
Multi-Purpose Tray
Manual Feed Tray
Approx. 150 sheets
1 sheet
Approx. 60 sheets
1 sheet
Transparency
Approx. 100 sheets
1 sheet
Label Paper
Approx. 50 sheets
1 sheet
Index Card
-
1 sheet
1 sheet
1 sheet
Plain Paper (64
g/m2)
Heavy Paper (128
Loading and Delivering Paper
2
Envelope
2-10
Paper Source
Paper Sources
g/m2)
Paper Output
Output Tray Types
2
Loading and Delivering Paper
Pages are output to the output tray on the top of the printer with the printed side
facing down. Open the output tray when you are printing to the output tray.
Close the output tray when you are not using the printer.
CAUTION
Keep your hands or clothing away from the roller in the output area. Even if the
printer is not printing, sudden rotation of the roller may catch your hands or
clothing, resulting in personal injury.
Paper Output
2-11
IMPORTANT
The area around the output tray becomes very hot during printing and directly after
printing. When you are collecting paper from the output tray or clearing a paper jam, be
careful not to touch the area around the output tray.
Loading and Delivering Paper
2
● If damp paper is printed
If damp paper is printed, steam may come out of the surroundings of the output area
of the printer.
This is because water contained in the paper is evaporating by heat radiated when
the toner is fixing. Therefore, this is not abnormal (Particularly, this is apt to occur at
low temperature.).
For details on storing paper, see "Storing Blank Paper," on p. 2-7.
WARNING
If you experience a burnt odor, immediately turn OFF the printer, and
then unplug the power plug from the AC power outlet and contact your
local authorized Canon dealer. Otherwise, this may result in a fire or
electrical shock.
NOTE
The output tray can hold up to approximately 100 sheets of plain paper (64 g/m2). The
paper capacity varies depending on the paper type and paper size. Refer to "Output Tray
Capacities," on p. 2-13 for more details.
2-12
Paper Output
Output Tray Capacities
Plain Paper (64 g/m2)
Heavy Paper (128
g/m2)
Output Tray*
Approx. 100 sheets
Approx. 30 sheets
Transparency
Approx. 10 sheets
Label Paper
Approx. 10 sheets
Index Card
Approx. 10 sheets
Envelope
Approx. 10 sheets
2
* Actual paper capacities vary depending on the environment where the printer is installed and the type and size of the
paper you are using.
Paper Output
2-13
Loading and Delivering Paper
Paper Type
Printing on Plain Paper, Heavy Paper, Label Paper, and
Transparencies
This section described how to print on plain paper, heavy paper, label paper and
transparencies.
Refer to "Printing on Custom Paper Sizes (Non-Standard Sizes)," on p. 2-45 for
details about printing on custom paper sizes.
Loading and Delivering Paper
2
Loading the Paper
Paper can be loaded into either the multi-purpose tray or the manual feed tray. If
you are printing continuously, load paper in the multi-purpose tray.
If you are printing a single sheet with a size and type different to the paper already
loaded in the multi-purpose tray, load the paper in the manual feed tray.
IMPORTANT
• When you are printing from the multi-purpose tray, make sure that there is no paper in
the manual feed tray. If there is any paper in the manual feed tray, paper will feed from the
manual feed tray because manual feed tray has priority over the multi-purpose tray.
• Do not load paper into the manual feed tray while the printer is printing from the
multi-purpose tray. The paper loaded in the manual feed tray will feed into the printer,
causing overlapping paper feeds and paper jams.
• Do not load paper that has jagged edges, wrinkles, or that is extremely curly. Doing so
can cause paper jams and printer faults.
• Refer to "Usable Paper," on p. 2-2 for more details on the paper that can be used.
• Do not use the following types of label paper with this printer. Using label paper that
meets any of these conditions may result in paper jams that are difficult to clear or may
cause damage to the printer.
- Peeling labels or partly used labels
- Labels that peel off from the backing sheet too easily
- Labels where the adhesive is exposed
2-14
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
Loading Paper into the Multi-Purpose Tray
Use the following procedure to load paper into the multi-purpose tray.
Always load paper lengthways into the multi-purpose tray.
IMPORTANT
• Do not touch or pull paper out of the multi-purpose tray during printing. Doing so may
cause the printer to malfunction.
• If you are refilling the multi-purpose tray when there is still paper in the tray, take out the
remaining paper and align it properly with the new paper before loading it into the tray.
• Use the paper capacity for each type of paper as a guide to the number of sheets of
paper that can be printed continuously.
1
Open the tray cover up to the position where it stops a, and
then pull out the rear paper guide b.
a
b
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
2-15
Loading and Delivering Paper
2
2
Push the side paper guides out a little wider than the actual
width of the paper.
Loading and Delivering Paper
2
3
Before loading transparencies or labels, fan them in small
batches and align the edges.
Thoroughly fan in small batches.
Stand the paper on a flat
surface and gently tap it a few
times to align the edges.
CAUTION
Be careful not to cut your hands with the edges of transparencies or label
paper.
IMPORTANT
• Make sure you thoroughly fan through transparencies and label paper before
loading them. If you do not sufficiently fan the sheets, multiple sheets will feed at
once causing paper jams.
• When fanning or aligning the transparencies, try to hold the edges to avoid
touching the printing surface.
• Take care not to mark or stain the printing surface of the transparencies with
fingerprints, dust, or oil. Doing so may reduce the printing quality.
2-16
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
Gently load the paper with the printing side facing up until it
touches the back of the tray.
Make sure that the paper passes under the paper limit guides.
Paper Limit Guide
2
CAUTION
When loading paper, take care not to cut your hands with the edges of the
paper.
IMPORTANT
• The number of sheets of paper that can be loaded in the multi-purpose tray is as
follows. Check that there is sufficient clear space between the paper limit guides
and the paper. If there is no free space, slightly reduce the amount of paper.
- Plain Paper :Approx. 150 sheets (64 g/m2)
- Heavy Paper :Approx. 60 sheets (128 g/m2)
- Transparency :Approx. 100 sheets
- Label Paper :Approx. 50 sheets
• If you use paper that has been poorly cut, the paper may have a tendency to
double-feed. In this case, thoroughly line up the edges of the paper on a flat
surface before loading it.
Thoroughly fan in small batches.
Stand the paper on a flat
surface and gently tap it a few
times to align the edges.
• Load the paper so that it is straight.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
2-17
Loading and Delivering Paper
4
• If the rear edge of the paper stack is not properly aligned, it may result in misfeeds
or paper jams.
• If the paper is curled or folded at the corners, flatten it out before loading.
NOTE
To print on letterhead paper or paper with a logo already printed on it, load the
paper so that the printed side is facing up and the top of the paper is at the far end.
Loading and Delivering Paper
2
5
2-18
Slide the paper guides to fit both sides of the stack.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
IMPORTANT
Always make sure the paper guides match the width of the paper. If the paper
guides are too loose or too tight, the paper will not feed properly and this will cause
paper jams.
6
Adjust the rear paper guide to match the paper a, and close
the tray cover b.
b
a
IMPORTANT
If you run out of paper and then refill the paper tray, the Paper Indicator will flash.
Press the
(Paper Key) to resume printing.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
2-19
Loading and Delivering Paper
2
Loading Paper into the Manual Feed Tray
Use the following procedure to load paper into the manual feed tray.
Always load paper lengthways into the manual feed tray.
Loading and Delivering Paper
2
IMPORTANT
• You can only load a single sheet of paper in the manual feed tray.
• You cannot print from the manual feed tray if the printer settings are set to multiple copies
or multiple pages. If you start a print job set for multiple copies or multiple pages, the
second and subsequent sheets will feed from the multi-purpose tray regardless of the
paper size and paper type.
• Do not touch or pull paper out of the manual feed tray during printing. Doing so may
cause the printer to malfunction.
1
2-20
Push the side paper guides out a little wider than the actual
width of the paper.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
Gently load the paper with the printing side facing up until it
touches the back of the tray.
Make sure that the paper passes under the paper limit guides.
Paper Limit Guide
2
CAUTION
When loading paper, take care not to cut your hands with the edges of the
paper.
IMPORTANT
• Load the paper so that it is straight.
• If the paper is curled or folded at the corners, flatten it out before loading.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
2-21
Loading and Delivering Paper
2
NOTE
To print on letterhead paper or paper with a logo already printed on it, load the
paper so that the printed side is facing up and the top of the paper is at the far end.
Loading and Delivering Paper
2
3
2-22
Slide the paper guides to fit both sides of the stack.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
IMPORTANT
• If you run out of paper and then refill the paper tray, the Paper Indicator will flash.
Press the
(Paper Key) to resume printing.
• Always make sure the paper guides match the width of the paper. If the paper
guides are too loose or too tight, the paper will not feed properly and this will cause
paper jams.
Selecting Printer Driver Settings and Printing
This section describes how to change the printer driver settings.
1
Select [Print] from the [File] menu in the application. Select
the name of your printer from the [Name] or [Printer Name]
field and click [Properties].
The [Properties] dialog box for the printer is displayed.
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
2-23
Loading and Delivering Paper
2
2
Display the [Page Setup] sheet, then set the [Page Size]
setting to the size of the document that you created in the
application.
Loading and Delivering Paper
2
3
Set the [Output Size] setting to the size of the paper loaded in
the printer as needed.
Select [A4] or [Letter] if you are printing transparencies or labels.
Leave the setting set to [Match Page Size] when the page size and the size of
the paper loaded in the multi-purpose tray are the same, since there is no need
to change the setting.
2-24
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
IMPORTANT
If the [Page Size] and [Output Size] settings are different, the printer produces an
enlarged or reduced print automatically.
Display the [Paper Source] sheet, and set the [Paper Type] to
the type of paper loaded in the printer.
Set this to [Plain Paper] for regular paper and labels, [Heavy Paper] for thick
paper, and [Transparency] for transparencies.
2
Loading and Delivering Paper
4
NOTE
• If the paper curls excessively when you are printing on plain paper (64 to 90g/m2)
with the [Paper Type] setting set to [Plain Paper], try setting the [Paper Type] setting
to [Plain Paper L].
• If you want to get improved fixing properties over the results of printing using the
[Heavy Paper] setting, select [Heavy Paper H].
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
2-25
5
Click [OK] to close the Properties dialog box.
6
Click [OK] to start printing.
Loading and Delivering Paper
2
2-26
Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies
Printing on Index Card
This section describes how to print on index cards.
Loading Index Cards
Loading Index Card into the Manual Feed Tray
Use the following procedure to load an index card into the manual feed tray.
Always load index cards lengthways into the manual feed tray.
IMPORTANT
• You can only load a single sheet of index card in the manual feed tray.
• You cannot print from the manual feed tray if the printer settings are set to multiple copies
or multiple pages. If you start a print job set for multiple copies or multiple pages, the
second and subsequent sheets will feed from the multi-purpose tray regardless of the
paper size and paper type.
• Do not touch or pull the index card out of the manual feed tray during printing. Doing so
may cause the printer to malfunction.
1
Push the side paper guides out a little wider than the actual
width of the paper.
Printing on Index Card
2-27
Loading and Delivering Paper
2
You can only load index cards in the manual feed tray.
2
Gently load the index card with the printing side facing up
until it touches the back of the tray.
Make sure that the index card passes beneath the paper limit guides.
Paper Limit Guide
Loading and Delivering Paper
2
CAUTION
When loading index card, take care not to cut your hands with the edges of
the paper.
IMPORTANT
• If the index card is warped, make sure you fix the warp before loading the card.
• Load the index card so that it is straight.
• If the rear edge of the index card is not properly aligned, it may result in misfeeds or
paper jams.
• If the leading edge of the index card is curled or folded at the corners, flatten it out
before loading.
2-28
Printing on Index Card
NOTE
To print on index card with a logo already printed on it, load the index card so that
the printed side is facing up and the top of the index card is at the far end.
ABC
ABC
Loading and Delivering Paper
2
3
Slide the paper guides to fit both sides of the index card.
Printing on Index Card
2-29
IMPORTANT
• If you run out of index card and then refill the paper tray, the Paper Indicator will
flash. Press the
(Paper Key) to resume printing.
• Always make sure the paper guides match the width of the index card. If the paper
guides are too loose or too tight, the index card will not feed properly and this will
cause paper jams.
Loading and Delivering Paper
2
Selecting Printer Driver Settings and Printing
This section describes how to set the printer driver settings.
1
Select [Print] from the [File] menu in the application. Select
the name of your printer from the [Name] or [Printer Name]
field and click [Properties].
The [Properties] dialog box for the printer is displayed.
2-30
Printing on Index Card
Display the [Page Setup] sheet, then set the [Page Size]
setting to the size of the document that you created in the
application.
2
NOTE
When you set the page size to [Index Card], the following message is displayed
and the paper type is automatically changed.
Printing on Index Card
2-31
Loading and Delivering Paper
2
3
Set the [Output Size] setting to [Index Card] as necessary.
Leave the setting set to [Match Page Size] when the page size and the size of
the paper loaded in the multi-purpose tray are the same, since there is no need
to change the setting.
Loading and Delivering Paper
2
IMPORTANT
If the [Page Size] and [Output Size] settings are different, the printer produces an
enlarged or reduced print automatically.
4
2-32
Click [OK] to close the Properties dialog box.
Printing on Index Card
Click [OK] to start printing.
2
Loading and Delivering Paper
5
Printing on Index Card
2-33
Printing on Envelopes
This section describes how to print to envelopes.
Loading Envelopes
Envelopes can be loaded into either the multi-purpose tray or the manual feed tray.
You can only load one envelope at a time, regardless of whether you use the
multi-purpose tray or the manual feed tray.
Loading and Delivering Paper
2
If you are printing a single sheet of paper that is different from the paper already
loaded in the multi-purpose tray, load the paper in the manual feed tray.
IMPORTANT
• When you are printing from the multi-purpose tray, make sure that there is no paper in
the manual feed tray. If there is any paper in the manual feed tray, paper will feed from the
manual feed tray because manual feed tray has priority over the multi-purpose tray.
• Do not load paper into the manual feed tray while the printer is printing from the
multi-purpose tray. The paper loaded in the manual feed tray will feed into the printer,
causing overlapping paper feeds and paper jams.
• Printing speed drops when printing on envelopes.
• The envelopes that can be used with this printer are as follows:
Envelope DL
Envelope Monarch
110.0 mm x 220.0 mm
(4.33 inch x 8.66 inch)
98.4 mm x 190.5 mm
(3.88 inch x 7.50 inch)
Envelope COM10
Envelope C5
104.9 mm x 241.3 mm
(4.13 inch x 9.50 inch)
162.0 mm x 229.0 mm
(6.38 inch x 9.02 inch)
* Envelopes with a flap on the short edge cannot be used.
2-34
Printing on Envelopes
• The following envelopes cannot be used with this printer. Using any of these envelopes
NOTE
When printing envelopes, the envelopes may become creased.
Loading Envelopes into the Multi-Purpose Tray
Use the following procedure to load envelopes into the multi-purpose tray.
Always load envelopes lengthways into the multi-purpose tray.
IMPORTANT
• You can only load a single envelope in the manual feed tray.
• Do not touch or pull envelopes out of the multi-purpose tray during printing. Doing so may
cause the printer to malfunction.
1
Open the tray cover up to the position where it stops a, and
then pull out the rear paper guide b.
a
b
Printing on Envelopes
2-35
2
Loading and Delivering Paper
may result in paper jams that are difficult to clear or may cause damage to the printer.
- Envelopes with fasteners or snaps
- Envelopes with address windows
- Envelopes with adhesive on the surface
- Wrinkled or creased envelopes
- Poorly manufactured envelopes in which the glued parts are uneven
- Irregularly-shaped envelopes
• Before loading the envelopes, push down on the stack of envelopes to release any
remaining air, and press down firmly along the folded edges of the envelopes.
• Do not print on the reverse side (glued side) of envelopes.
2
Push the side paper guides out a little wider than the actual
width of the paper.
Loading and Delivering Paper
2
3
Load the envelopes with the printing surface facing up and
the flaps closed and on the left side, then gently insert them
all the way to the back of the tray.
Make sure that the envelopes passes under the paper limit guides.
Paper Limit Guide
CAUTION
When loading envelopes, be careful not to cut your hands with the edges
of the envelopes.
IMPORTANT
• You cannot print on the reverse side (glued side) of envelopes.
• Load the stack of envelopes straight.
• If the leading edges of the envelopes are curled or folded at the corners, flatten
them out before loading.
2-36
Printing on Envelopes
NOTE
When you are printing on envelopes, load the envelopes with the paper surface
(the side you want to print on) facing up, and the envelope flap on the left side.
4
Slide the paper guides to meet both sides of the envelopes.
IMPORTANT
Always make sure the paper guides match the width of the paper. If the paper
guides are too loose or too tight, the paper will not feed properly and this will cause
paper jams.
Printing on Envelopes
2-37
Loading and Delivering Paper
2
5
Adjust the rear paper guide to match the paper a, and close
the tray cover b.
b
Loading and Delivering Paper
2
a
IMPORTANT
If you run out of envelopes and then refill the paper tray, the Paper Indicator will
flash. Press the
(Paper Key) to resume printing.
Loading Envelopes into the Manual Feed Tray
Use the following procedure to load envelopes into the manual feed tray.
Always load envelopes lengthways into the manual feed tray.
IMPORTANT
• You can only load a single envelope in the manual feed tray.
• You cannot print from the manual feed tray if the printer settings are set to multiple copies
or multiple pages. If you start a print job set for multiple copies or multiple pages, the
second and subsequent sheets will feed from the multi-purpose tray regardless of the
paper size and paper type.
• Do not touch or pull envelopes out of the manual feed tray during printing. Doing so may
cause the printer to malfunction.
2-38
Printing on Envelopes
1
Push the side paper guides out a little wider than the actual
width of the paper.
2
Load the envelope with the printing surface facing up and the
flaps closed and on the left side, then gently insert them all
the way to the back of the tray.
Be sure that the envelope passes beneath the paper limit guides.
Paper Limit Guide
CAUTION
When loading envelope, be careful not to cut your hands with the edges of
the envelope.
IMPORTANT
• You cannot print on the reverse side (glued side) of envelope.
• Load the envelope straight.
• If the leading edge of the envelope is curled or folded at the corners, flatten it out
before loading.
Printing on Envelopes
2-39
Loading and Delivering Paper
2
NOTE
When you are printing on envelopes, load the envelopes with the paper surface
(the side you want to print on) facing up, and the envelope flap on the left side.
Loading and Delivering Paper
2
3
Slide the paper guides to meet both sides of the envelope.
IMPORTANT
• If you run out of envelopes and then refill the paper tray, the Paper Indicator will
flash. Press the
(Paper Key) to resume printing.
• Always make sure the paper guides match the width of the envelope. If the paper
guides are too loose or too tight, the envelope will not feed properly and this will
cause paper jams.
2-40
Printing on Envelopes
Selecting Printer Driver Settings and Printing
This section describes how to set the printer driver settings.
Select [Print] from the [File] menu in the application. Select
the name of your printer from the [Name] or [Printer Name]
field and click [Properties].
2
Loading and Delivering Paper
1
The [Properties] dialog box for the printer is displayed.
Printing on Envelopes
2-41
2
Display the [Page Setup] sheet, then set the [Page Size]
setting to the size of the document that you created in the
application.
Loading and Delivering Paper
2
NOTE
If you set the page size to any of [Envelope DL], [Envelope COM10], [Envelope
C5], or [Envelope Monarch], the following message appears and the appropriate
paper type is automatically selected.
2-42
Printing on Envelopes
3
Set the [Output Size] setting to the size of the paper loaded in
the printer as needed.
Leave the setting set to [Match Page Size] when the page size and the size of
the paper loaded in the multi-purpose tray are the same, since there is no need
to change the setting.
Loading and Delivering Paper
2
IMPORTANT
If the [Page Size] and [Output Size] settings are different, the printer produces an
enlarged or reduced print automatically.
4
Click [OK] to close the Properties dialog box.
Printing on Envelopes
2-43
5
Click [OK] to start printing.
Loading and Delivering Paper
2
2-44
Printing on Envelopes
Printing on Custom Paper Sizes (Non-Standard Sizes)
This section describes how to print to custom paper sizes.
Loading Custom Paper Sizes
If you are printing a single sheet of paper that is different from the paper already
loaded in the multi-purpose tray, load the paper in the manual feed tray.
You can load custom paper sizes of width 76.2 mm to 215.9 mm and length
127.0 mm to 355.6 mm.
IMPORTANT
• When you are printing from the multi-purpose tray, make sure that there is no paper in
the manual feed tray. If there is any paper in the manual feed tray, paper will feed from the
manual feed tray because manual feed tray has priority over the multi-purpose tray.
• Do not load paper into the manual feed tray while the printer is printing from the
multi-purpose tray. The paper loaded in the manual feed tray will feed into the printer,
causing overlapping paper feeds and paper jams.
• Do not load paper that has jagged edges, wrinkles, or that is extremely curly. Doing so
can cause paper jams and printer faults.
• Refer to "Usable Paper," on p. 2-2 for more details on the paper that can be used.
Loading Custom Paper into the Multi-Purpose Tray
Use the following procedure to load custom paper into the multi-purpose tray.
Always load paper lengthways into the multi-purpose tray.
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-45
Loading and Delivering Paper
2
Custom paper sizes can be loaded into either the multi-purpose tray or the manual
feed tray. If you are printing continuously, load paper in the multi-purpose tray.
IMPORTANT
• Do not touch or pull paper out of the multi-purpose tray during printing. Doing so may
cause the printer to malfunction.
• If you are refilling the multi-purpose tray when there is still paper in the tray, take out the
remaining paper and align it properly with the new paper before loading it into the tray.
• Use the paper capacity for each type of paper as a guide to the number of sheets of
paper that can be printed continuously.
1
Loading and Delivering Paper
2
Open the tray cover up to the position where it stops a, and
then pull out the rear paper guide b.
a
b
IMPORTANT
Make sure you pull out the auxiliary tray when you load paper in the multi-purpose
tray.
2
2-46
Push the side paper guides out a little wider than the actual
width of the paper.
Printing on Custom Paper Sizes (Non-Standard Sizes)
Gently load the paper with the printing side facing up until it
touches the back of the tray.
Make sure that the paper passes under the paper limit guides.
Paper Limit Guide
2
CAUTION
When loading paper, take care not to cut your hands with the edges of the
paper.
IMPORTANT
• The number of sheets that can be loaded in the multi-purpose tray is as follows.
Check that there is sufficient clear space between the paper limit guides and the
paper. If there is no free space, slightly reduce the number of envelopes.
- Plain Paper :Approx. 150 sheets (64 g/m2)
- Heavy Paper :Approx. 60 sheets (128 g/m2)
• If you use paper that has been poorly cut, the paper may have a tendency to
double-feed. In this case, thoroughly line up the edges of the paper on a flat
surface before loading it.
Thoroughly fan in small batches.
Stand the paper on a flat
surface and gently tap it a few
times to align the edges.
• Load the paper so that it is straight.
• If the rear edge of the paper stack is not properly aligned, it may result in misfeeds
or paper jams.
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-47
Loading and Delivering Paper
3
• If the paper is curled or folded at the corners, flatten it out before loading.
NOTE
To print on letterhead paper or paper with a logo already printed on it, load the
paper so that the printed side is facing up and the top of the paper is at the far end.
Loading and Delivering Paper
2
4
2-48
Slide the paper guides to fit both sides of the stack.
Printing on Custom Paper Sizes (Non-Standard Sizes)
IMPORTANT
Always make sure the paper guides match the width of the paper. If the paper
guides are too loose or too tight, the paper will not feed properly and this will cause
paper jams.
5
Adjust the rear paper guide to match the paper a, and close
the tray cover b.
● If the custom paper that you are using is over 190 mm in length:
❑ Slide the rear paper guide a to align the small paper guide with the paper, and
close the tray cover b.
b
a
IMPORTANT
If you run out of paper and then refill the paper tray, the Paper Indicator will flash.
Press the
(Paper Key) to resume printing.
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-49
Loading and Delivering Paper
2
● If the custom paper that you are using is less than 190 mm in length:
❑ Move the rear paper guide to the position shown in the diagram.
Loading and Delivering Paper
2
❑ Remove the small paper guide from the multi-purpose tray.
❑ Insert the small paper guide from directly above, as shown in the diagram, then
fold it towards the back.
2-50
Printing on Custom Paper Sizes (Non-Standard Sizes)
❑ Slide the rear paper guide a to align the small paper guide with the paper, and
close the tray cover b.
b
a
IMPORTANT
If you run out of paper and then refill the paper tray, the Paper Indicator will flash.
Press the
(Paper Key) to resume printing.
Loading Custom Paper into the Manual Feed Tray
Use the following procedure to load custom paper into the manual feed tray.
Always load custom paper lengthways into the manual feed tray.
IMPORTANT
• You can only load a single sheet of paper in the manual feed tray.
• You cannot print from the manual feed tray if the printer settings are set to multiple copies
or multiple pages. If you start a print job set for multiple copies or multiple pages, the
second and subsequent sheets will feed from the multi-purpose tray regardless of the
paper size and paper type.
• Do not touch or pull paper out of the manual feed tray during printing. Doing so may
cause the printer to malfunction.
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-51
Loading and Delivering Paper
2
1
Push the side paper guides out a little wider than the actual
width of the paper.
Loading and Delivering Paper
2
2
Gently load the paper with the printing side facing up until it
touches the back of the tray.
Make sure that the paper passes under the paper limit guides.
Paper Limit Guide
CAUTION
When loading paper, take care not to cut your hands with the edges of the
paper.
IMPORTANT
• Load the paper so that it is straight.
• If the paper is curled or folded at the corners, flatten it out before loading.
2-52
Printing on Custom Paper Sizes (Non-Standard Sizes)
NOTE
To print on letterhead paper or paper with a logo already printed on it, load the
paper so that the printed side is facing up and the top of the paper is at the far end.
Loading and Delivering Paper
2
3
Slide the paper guides to fit both sides of the paper.
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-53
IMPORTANT
• If you run out of paper and then refill the paper tray, the Paper Indicator will flash.
Press the
(Paper Key) to resume printing.
• Always make sure the paper guides match the width of the paper. If the paper
guides are too loose or too tight, the paper will not feed properly and this will cause
paper jams.
Loading and Delivering Paper
2
Selecting Printer Driver Settings and Printing
This section describes how to set the printer driver settings.
1
Select [Print] from the [File] menu in the application. Select
the name of your printer from the [Name] or [Printer Name]
field and click [Properties].
The [Properties] dialog box for the printer is displayed.
2-54
Printing on Custom Paper Sizes (Non-Standard Sizes)
Display the [Page Setup] sheet, then set the [Page Size]
setting to the size of the document that you created in the
application.
2
NOTE
• When you are using a custom paper size, you need to register the size of the
custom paper in advance. Refer to "Specifying a Custom Paper Size
(Non-Standard Paper)," on p. 4-39 for information on how to register a custom
paper size.
• When you set the page size to [Index Card], the following message is displayed
and the paper type is automatically changed.
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-55
Loading and Delivering Paper
2
3
Set the [Output Size] setting to the name (paper size) of the
custom paper loaded in the printer as needed.
Leave the setting set to [Match Page Size] when the page size and the size of
the paper loaded in the multi-purpose tray (the name of the custom paper size)
are the same, since there is no need to change the setting.
Loading and Delivering Paper
2
IMPORTANT
If the [Page Size] and [Output Size] settings are different, the printer produces an
enlarged or reduced print automatically.
4
2-56
Click [OK] to close the Properties dialog box.
Printing on Custom Paper Sizes (Non-Standard Sizes)
Click [OK] to start printing.
2
Loading and Delivering Paper
5
Printing on Custom Paper Sizes (Non-Standard Sizes)
2-57
Loading and Delivering Paper
2
2-58
Printing on Custom Paper Sizes (Non-Standard Sizes)
Setting Up the Printing Environment
3
CHAPTER
This chapter describes the procedure for installing the printer driver on a computer and
specifying the settings for printing from a network computer by sharing the printer on the
network.
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
After Installing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Each Time You Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Installing the CAPT Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Installing from CD-ROM Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
Installing with Plug and Play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
After Completing Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40
Printing a Test Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
Printing from a Network Computer using a Shared Printer . . . . . . . . . . . . . . . . . . . . . . 3-47
Configuring the Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-48
Installing the Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-61
Uninstalling the CAPT software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-75
3-1
Introduction
After Installing the Printer
The following shows the tasks that should be performed after installing the printer:
■ Installing the Printer Driver (See p. 3-4)
The printer driver is a piece of software that is needed when you are printing from
application software. Settings related to printing can be configured using the printer driver.
Setting Up the Printing Environment
3
■ Using a computer to share the printer on a network (See p. 3-47)
If you share this printer on a network and use it from a computer on the network, you must
specify the settings for the computer and install the printer driver on the client computers.
Each Time You Print
The following shows the tasks that should be performed each time you print:
■ Specifying print settings
The printer paper size, page size, number of copies, etc. are configured using the printer
driver. If these settings are not configured correctly, you will not be able to achieve the
expected results.
■ Printing
Select the printing option from the menu of the application software you are using. As the
method for printing varies depending on the application, refer to the individual users
manuals of each application.
System Requirements
In order to use the printer driver, your computer system needs to meet the following
requirements:
■ Operating system software
• Microsoft Windows 98
• Microsoft Windows Me
• Microsoft Windows 2000 Server/Professional
• Microsoft Windows XP Professional/Home Edition*
• Microsoft Windows Server 2003*
3-2
Introduction
• Microsoft Windows Vista*
*
32-bit processor version only
- System Requirements (minimum required)
Windows 98/Me
CPU
Pentium II
300 MHz or more
Memory (RAM)*1 64 MB or more
Hard Disk*2
120 MB or more
Windows 2000/XP/
Server 2003
Pentium II
300 MHz or more
Windows Vista
128 MB or more
Conforms to the
minimum system
requirements for
Windows Vista
120 MB or more
120 MB or more
(PC/AT Compatibles)
3
Setting Up the Printing Environment
*1 As the amount of available memory varies depending on the system configuration of the computer or
application you are using, the above environment does not guarantee printing in all cases.
*2 This indicates free hard disk space required for installing the printer driver and manuals using Easy
Installation. Required free hard disk space varies depending on the system environment or installation
method.
- System Requirements (recommended)
Windows 98/Me
Windows 2000/XP/
Server 2003
CPU
Pentium III
600 MHz or more
Pentium III
600 MHz or more
Memory (RAM)
128 MB or more
256 MB or more
Windows Vista
Conforms to the
recommended
system
requirements for
Windows Vista
■ Interface
• USB: USB 2.0 High-Speed (Windows 2000/XP/Server 2003/Vista only), USB
Full-Speed (USB 1.1 equivalent)
NOTE
• If you want to use the sounds from the printer driver, a PC synthesizer (and the PCM
synthesizer driver) needs to be installed in your computer. Do not use the PC speaker
driver (speaker.drv).
• This printer uses bidirectional communication. Operation of the printer when connected
via unidirectional communication equipment has not been tested. As a result, Canon
cannot guarantee printer operation when the printer is connected using unidirectional
print servers, USB hubs and switching devices.
Introduction
3-3
Installing the CAPT Software
This section describes the procedure for installing the CAPT software on a
computer that is connected directly to the printer using a USB cable.
There are the following methods for installing the printer driver:
Installation method
Setting Up the Printing Environment
3
Contents
Reference page
Easy Installation
Installs the manuals when
installing the printer driver from
p. 3-5
the CD-ROM supplied with the
printer (CD-ROM Setup).
Custom Installation
You can choose to install only
the printer driver or only the
manuals from the CD-ROM
supplied with the printer
(CD-ROM Setup).*
Installing with Plug and
Play
Searches for the printer
automatically, selects the file
required for the installation
from the CD-ROM supplied
with the printer, and then
installs the printer driver.
p. 3-5
Windows 98/Me: p. 3-12
Windows 2000: p. 3-21
Windows XP/Server 2003:
p. 3-28
Windows Vista: p. 3-33
* If you want to install the manuals only, see "Installing the Manuals," on p. 4-56.
IMPORTANT
• The CAPT software is required for printing using this printer. Make sure that you install it.
• If there is not enough free space remaining on the hard disk, the message appears
during the installation. Abort the installation and create more space on the disk before
beginning the installation again.
NOTE
• For details on the procedure for installing this software when the printer is shared on the
network from one computer and you are printing from another computer over the
network, see "Printing from a Network Computer using a Shared Printer," on p. 3-47.
• A USB cable is only supplied with 220 - 240 V model for countries and regions of Asia. In
other countries and regions, prepare according to the specifications of your computer.
3-4
Installing the CAPT Software
Installing from CD-ROM Setup
The screen shots used in this section are from Windows XP.
IMPORTANT
If you are using Windows 2000/XP/Server 2003/Vista, be sure to log on as a member of
Administrators when starting up.
1
Make sure that the printer and computer are OFF.
2
Open the USB cover.
Setting Up the Printing Environment
3
Installing the CAPT Software
3-5
3
Connect the B-type (square) end of the USB cable to the USB
connector on the rear side of the printer, then close the USB
cover.
Setting Up the Printing Environment
3
4
3-6
Connect the A-type (flat) end of the USB cable to the USB port
on the computer.
Installing the CAPT Software
5
Turn the computer on and start up Windows.
IMPORTANT
If a Wizard or dialog box appears by the Plug and Play automatic setup, click
[Cancel], and then install the CAPT software using this procedure.
6
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If the CD-ROM is already in the drive, eject the disk and re-insert it into the drive.
NOTE
If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Allow].
7
Click [Easy Installation] or [Custom Installation].
[Easy Installation] allows you to install the printer driver and the instruction
manuals simultaneously. If you do not install the manuals, select [Custom
Installation].
Installing the CAPT Software
3-7
3
Setting Up the Printing Environment
IMPORTANT
• If you are using Windows Vista and the [AutoPlay] dialog box appears, click [Run
AUTORUN.EXE].
• If CD-ROM Setup does not appear, display it using the following procedures. (The
CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name
may differ depending on the computer you are using.)
- If you are using an operating system other than Windows Vista, select [Run] from
the [Start] menu, enter "D:\English\MInst.exe", and then click [OK].
- If you are using Windows Vista, enter "D:\English\MInst.exe" in [Start Search]
under the [Start] menu, and then press the [ENTER] key on your keyboard.
8
Click [Install].
Setting Up the Printing Environment
3
If you selected [Custom Installation] in Step 7, clear the [Online Manuals] check
box, and then click [Install].
9
3-8
Confirm the contents, then click [Yes].
Installing the CAPT Software
10 Click [Next].
Setting Up the Printing Environment
3
11 Select [Install with USB Connection], then click [Next].
Depending on the system environment, a message that prompts you to restart the
computer may appear. In this case, restart the computer and continue the
installation.
If you are using Windows XP Service Pack 2 or another operating system
equipped with Windows Firewall, the following screen is displayed. Specify
whether to configure Windows Firewall to unblock communication with the client
computers when sharing the printer on a network.
Click [Yes] when you share the printer on a network. After completing the
installation, see "Printing from a Network Computer using a Shared Printer" (p.
3-47) and specify the settings for sharing the printer on the network.
Click [No] when you do not share the printer on a network.
Installing the CAPT Software
3-9
NOTE
Even after the installation, you can change the Firewall settings using "CAPT
Windows Firewall Utility" in the supplied CD-ROM. For more details, see "Windows
Firewall," on p. 7-8.
12 The message <Installation cannot be stopped once it starts.
Do you want to continue?> appears. Click [Yes].
3
Setting Up the Printing Environment
NOTE
• If you are using Windows 2000 and the [Digital Signature Not Found] dialog box
appears, click [Yes].
• If you are using Windows XP/Server 2003 and the [Hardware Installation] dialog
box appears, click [Continue Anyway].
• If you are using Windows Vista and the [Windows Security] dialog box appears,
click [Install this driver software anyway].
13 When the following screen is displayed, turn the printer ON.
Press " " of the power switch to turn the printer ON.
Installation of the USB class driver and the printer driver starts automatically.
3-10
Installing the CAPT Software
NOTE
• If the printer is not recognized automatically even after the USB cable is connected,
see "Installation Problems," on p. 6-27.
• If you are using Windows XP/Server 2003 and the [Hardware Installation] dialog
box appears, click [Continue Anyway].
• If you are using Windows Vista and the [Windows Security] dialog box appears,
click [Install this driver software anyway].
14 If [Easy Installation] is selected in Step 7, the manuals are
installed.
Setting Up the Printing Environment
3
15 Confirm the installation results, then click [Next].
NOTE
If the printer driver is not installed properly, see "Installation Problems," on p. 6-27.
Installing the CAPT Software
3-11
16 Select the [Restart Computer Now (Recommended)] check
box, then click [Restart].
Setting Up the Printing Environment
3
Windows restarts.
The installation of the USB class driver and the printer driver is completed.
Installing with Plug and Play
For Windows 98/Me
The screen shots used in this section are from Windows Me.
1
2
3-12
Make sure that the computer and printer are turned off at the
power.
Open the USB cover.
Installing the CAPT Software
3
Connect the B-type (square) end of the USB cable to the USB
connector on the rear side of the printer, and close the USB
cover.
Setting Up the Printing Environment
3
4
Connect the A-type (flat) end of the USB cable to the USB port
on the computer.
Installing the CAPT Software
3-13
Setting Up the Printing Environment
3
5
Press the " " side of the power switch to turn the printer on.
6
Turn the computer on and start up Windows 98/Me.
The [Add New Hardware Wizard] dialog box appears.
● For Windows Me
If the following dialog box appears, proceed to Step 7.
If the following dialog box appears, proceed to Step 14.
3-14
Installing the CAPT Software
● For Windows 98
If the following dialog box appears, click [Next], then proceed to Step 7.
3
7
Setting Up the Printing Environment
If the following dialog box appears, click [Next], then proceed to Step 14.
Select [Specify the location of the driver (Advanced)], then
click [Next].
For Windows 98: Select [Search for the best driver for your device.
(Recommended)], then click [Next].
A dialog box is displayed that allows you to specify the search location.
Installing the CAPT Software
3-15
8
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If CD-ROM Setup appears, click [Exit].
9
Select [Search for the best driver for your device.
(Recommended).], remove the checkmark from [Removable
Media (Floppy, CD-ROM...)], place a checkmark next to
[Specify a location].
For Windows 98: Remove the checkmarks from [Floppy disk drives] and
[CD-ROM drive], place a checkmark next to [Specify a location].
Setting Up the Printing Environment
3
10 Click [Browse], and then select a folder.
For Windows 98: Select [D:\English\USBPORT\Win98], and then click [OK].
In this case the CD-ROM drive is assumed to be assigned to "D:". The actual
CD-ROM drive letter may be different depending on the computer you are using.
3-16
Installing the CAPT Software
11 Make sure that the correct path is displayed in the [Specify a
location] field, and then click [Next].
Setting Up the Printing Environment
3
12 Click [Next].
Installation of the USB class driver starts.
13 Click [Finish].
The computer automatically detects the printer. Please wait a moment.
Installing the CAPT Software
3-17
The [Add New Hardware Wizard] dialog box appears.
For Windows 98, click [Next].
3
Setting Up the Printing Environment
14 Select [Specify the location of the driver (Advanced)], then
click [Next].
For Windows 98: Select [Search for the best driver for your device.
(Recommended)], then click [Next].
A dialog box is displayed that allows you to specify the search location.
15 If the supplied "LBP3000 User Software" CD-ROM is not in the
CD-ROM drive, insert the "LBP3000 User Software" CD-ROM
into the drive.
If CD-ROM Setup appears, click [Exit].
3-18
Installing the CAPT Software
16 Select [Search for the best driver for your device.
(Recommended).], remove the checkmark from [Removable
Media (Floppy, CD-ROM...)], place a checkmark next to
[Specify a location].
For Windows 98: Remove the checkmarks from [Floppy disk drives] and
[CD-ROM drive], place a checkmark next to [Specify a location].
17 Click [Browse], and then select a folder.
Select [D:\English\Win98_Me], and then click [OK].
In this case the CD-ROM drive is assumed to be assigned to "D:". The actual
CD-ROM drive letter may be different depending on the computer you are using.
Installing the CAPT Software
3-19
Setting Up the Printing Environment
3
18 Make sure that the correct path is displayed in the [Specify a
location] field, and then click [Next].
Setting Up the Printing Environment
3
19 Click [Next].
20 Enter a new name in the [Printer name] field if you want to
change the name of the printer.
If another printer driver has been already installed in the computer, the message
[Do you want your Windows-based programs to use this printer as the default
printer?] appears. In this case, select [Yes] or [No].
3-20
Installing the CAPT Software
21 Click [Finish].
Windows will begin copying files.
22 Once the installation complete dialog is displayed, click [OK].
23 Click [Finish].
Setting Up the Printing Environment
3
This completes the installation of the USB class driver and printer driver.
For Windows 2000
1
Make sure that the computer and printer are turned off at the
power.
Installing the CAPT Software
3-21
2
3
Setting Up the Printing Environment
3
3-22
Open the USB cover.
Connect the B-type (square) end of the USB cable to the USB
connector on the rear side of the printer, and close the USB
cover.
Installing the CAPT Software
4
Connect the A-type (flat) end of the USB cable to the USB port
on the computer.
5
Press the " " side of the power switch to turn the printer on.
6
Turn the computer on and start up Windows 2000.
7
Log on as a user who is a member of the Administrators
group.
The [Found New Hardware Wizard] dialog box appears.
NOTE
Full Control Permissions are required for the installation of the printer driver.
Installing the CAPT Software
3-23
Setting Up the Printing Environment
3
8
Click [Next].
Setting Up the Printing Environment
3
9
Select [Search for a suitable driver for my device
(recommended)], then click [Next].
NOTE
[Unknown] may be displayed as the name of the device.
3-24
Installing the CAPT Software
10 Remove the checkmarks from [Floppy disk drives] and
[CD-ROM drives], place a checkmark next to [Specify a
location], and then click [Next].
Setting Up the Printing Environment
3
11 Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive, then click [Browse].
If CD-ROM Setup appears, click [Exit].
Installing the CAPT Software
3-25
12 Select [D:\English\Win2K_Vista]. Select [CNAB3STK.INF] and
click [Open].
In this case the CD-ROM drive is assumed to be assigned to "D:". The actual
CD-ROM drive letter may be different depending on the computer you are using.
Setting Up the Printing Environment
3
13 Make sure that the correct path is displayed in the [Copy
manufacturer's files from] field, then click [OK].
A dialog box is displayed when the computer finishes searching for the driver files.
3-26
Installing the CAPT Software
14 Click [Next].
Windows will begin copying files.
When it has finished, the [Completing the Found New Hardware Wizard] dialog is
displayed.
NOTE
If the [Digital Signature Not Found] dialog box appears, click [Yes].
15 Click [Finish].
Installation of the USB class driver (supplied with OS) and the printer driver starts
automatically.
Installing the CAPT Software
3-27
Setting Up the Printing Environment
3
For Windows XP/Server 2003
The screen shots used in this section are from Windows XP.
1
2
Make sure that the computer and printer are turned off at the
power.
Open the USB cover.
Setting Up the Printing Environment
3
3-28
Installing the CAPT Software
3
Connect the B-type (square) end of the USB cable to the USB
connector on the rear side of the printer, and close the USB
cover.
Setting Up the Printing Environment
3
4
Connect the A-type (flat) end of the USB cable to the USB port
on the computer.
Installing the CAPT Software
3-29
Setting Up the Printing Environment
3
5
Press the " " side of the power switch to turn the printer on.
6
Turn the computer on and start up Windows XP/Server 2003.
7
Log on as a user who is a member of the Administrators
group.
The [Found New Hardware Wizard] dialog box appears.
NOTE
Full Control Permissions are required for the installation of the printer driver.
8
Insert the "LBP3000 User Software" CD-ROM into the CD-ROM
drive. Select [Install from a list or specific location
(Advanced)], then click [Next].
If CD-ROM Setup appears, click [Exit].
3-30
Installing the CAPT Software
9
Select [Search for the best driver in these locations.], remove
the checkmark from [Search removable media (floppy,
CD-ROM...)], place a checkmark next to [Include this location
in the search].
10 Click [Browse], and then select a folder.
Select [D:\English\Win2K_Vista], and then click [OK].
In this case the CD-ROM drive is assumed to be assigned to "D:". The actual
CD-ROM drive letter may be different depending on the computer you are using.
Installing the CAPT Software
3-31
Setting Up the Printing Environment
3
11 Make sure that the correct path is displayed in the [Include
this location in the search] field, then click [Next].
Setting Up the Printing Environment
3
The installation progress is displayed.
After this, the [Completing the Found New Hardware Wizard] dialog is displayed.
NOTE
If the [Hardware Installation] dialog box appears, click [Continue Anyway].
12 Click [Finish].
IMPORTANT
If you are using Windows XP Service Pack 2 or another operating system equipped
with Windows Firewall as a print server, configure Windows Firewall to unblock
communication with the client computers. (See p. 7-8)
This completes the installation of the USB class driver (supplied with OS) and printer
driver.
3-32
Installing the CAPT Software
For Windows Vista
1
Make sure that the printer and computer are OFF.
2
Open the USB cover.
3
Connect the B-type (square) end of the USB cable to the USB
connector on the rear side of the printer, and close the USB
cover.
Installing the CAPT Software
3-33
Setting Up the Printing Environment
3
4
Connect the A-type (flat) end of the USB cable to the USB port
on the computer.
Setting Up the Printing Environment
3
5
Press the " " side of the power switch to turn the printer on.
6
Turn the computer on and start up Windows Vista.
7
Log on as a member of Administrators.
The [Found New Hardware] dialog box appears.
NOTE
Full Control Permission is required for the installation of the printer driver.
3-34
Installing the CAPT Software
8
Click [Locate and install driver software (recommended)].
3
9
Setting Up the Printing Environment
NOTE
If the [User Account Control] dialog box appears, click [Continue].
If the following screen appears, click [Don't search online].
Installing the CAPT Software
3-35
10 Click [I don't have the disc. Show me other options.].
Setting Up the Printing Environment
3
11 Click [Browse my computer for driver software (advanced)].
3-36
Installing the CAPT Software
12 Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive, and then click [Browse].
If CD-ROM Setup appears, click [Exit].
13 Select [D:\English\Win2K_Vista], then click [OK].
The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive
name may differ depending on the computer you are using.
Installing the CAPT Software
3-37
Setting Up the Printing Environment
3
14 Make sure that the folder to be browsed is displayed in
[Search for driver software in this location], and then click
[Next].
Setting Up the Printing Environment
3
Copying files is started.
NOTE
If the [Windows Security] dialog box appears, click [Install this driver software
anyway].
15 Click [Close].
IMPORTANT
If you want to use the computer in which the printer driver was installed as the print
server, configure Windows Firewall to unblock communication with the client
computers. (See p. 7-9)
3-38
Installing the CAPT Software
The installation of the USB class driver (supplied with an operating system) and the
printer driver is completed.
Setting Up the Printing Environment
3
Installing the CAPT Software
3-39
After Completing Installation
When the installation of the CAPT software is complete, an icon and folder will be
created for the printer.
■ For Windows 98/Me/2000
• The icon for the printer is displayed in the [Printers] folder.
Setting Up the Printing Environment
3
• [Canon Printer Uninstaller] is added to [Programs] under the [Start] menu.
3-40
After Completing Installation
• If the manuals are installed, [LBP3000 Online Manuals] is created on the desktop, and
[LBP3000 Online Manuals] under [Canon LBP3000] is added to [Programs] under the
[Start] menu.
Setting Up the Printing Environment
3
After Completing Installation
3-41
■ For Windows XP/Server 2003
• The icon for the printer is displayed in the [Printers and Faxes] folder.
Setting Up the Printing Environment
3
• [Canon Printer Uninstaller] is added to [All Programs] under the [Start] menu.
• If the manuals are installed, [LBP3000 Online Manuals] is created on the desktop, and
[LBP3000 Online Manuals] under [Canon LBP3000] is added to [All Programs] under the
[Start] menu.
3-42
After Completing Installation
■ For Windows Vista
• The icon for the printer is displayed in the [Printers] folder.
• [Canon Printer Uninstaller] is added to [All Programs] under the [Start] menu.
• If the manuals are installed, [LBP3000 Online Manuals] is created on the desktop, and
[LBP3000 Online Manuals] under [Canon LBP3000] is added to [All Programs] under the
[Start] menu.
After Completing Installation
3-43
Setting Up the Printing Environment
3
Printing a Test Page
Before using the printer for the first time, be sure to print a test page using the
following procedure.
NOTE
The screen shots shown here are taken from Windows XP Home Edition.
3
Setting Up the Printing Environment
1
Open the [Printers and Faxes] or [Printers] folder.
For Windows 98/Me/2000: Select [Settings] ➞ [Printers] from the [Start] menu.
For Windows XP Professional/Server 2003: Select [Printers and Faxes] from the
[Start] menu.
For Windows XP Home Edition: Select [Control Panel] from the [Start] menu, then
click [Printers and Other Hardware] ➞ [Printers and Faxes].
For Windows Vista: Select [Control Panel] from the [Start] menu, then click
[Printer].
The [Printers and Faxes] or [Printers] folder is displayed.
3-44
Printing a Test Page
2
Right-click the icon for this printer, then select [Properties]
from the pop-up menu.
Setting Up the Printing Environment
3
The [Properties] dialog box for the printer is displayed.
3
Click [Print Test Page] on the [General] sheet.
The printer will begin printing a test page.
Printing a Test Page
3-45
4
If the page is printed correctly, click [OK], [Yes], or [Close].
NOTE
If test page does not print correctly, refer to Chapter 6 "Troubleshooting".
Setting Up the Printing Environment
3
3-46
Printing a Test Page
Printing from a Network Computer using a Shared
Printer
If you set the printer up as a shared network printer, you will be able to print directly
to the printer from any computer on the network.
Network Environment
Print Server
Windows 98/Me
LBP3000
Local
Installation
Print
Download
and Install
Client
Windows 98/Me
Client
Windows 2000/
XP/Server 2003/Vista
Download
and Install
Network Environment
Print Server
Windows 2000/XP/
Server 2003/Vista
LBP3000
Local
Installation
*
Print
Download
and Install
Client
Windows 2000/
XP/Server 2003/Vista
Client
Windows 98/Me
Download and Install
* If the print server is running Windows Vista, you cannot download and install the driver on Windows 98/
Me.
Printing from a Network Computer using a Shared Printer
3
Setting Up the Printing Environment
If you want to use the printer as a shared printer, perform the following
configuration. In this section, the computer that is directly connected to the printer is
called the print server, and other computers that access the printer over the
network are called client computers.
3-47
If you want to use a print server, perform the following steps.
Item to Configure
Refer to
1
p. 3-4
Installing the Printer Driver on the Print Server
Configure the Print Server
2
3
p. 3-48
• For Windows 2000/XP/Server 2003/Vista
p. 3-53
Install the Clients
p. 3-61
NOTE
Using this printer on your network requires that both the print server and clients should
be using Windows 98/Me or Windows 2000/XP/Server 2003/Vista.
3
Setting Up the Printing Environment
• For Windows 98/Me
Configuring the Print Server
For Windows 98/Me
The screen shots used in this section are from Windows Me.
■ Preparing the Print Sharing Settings
1
Double-click [My Computer] ➞ [Control Panel] ➞ the
[Network] icon.
The [Network] dialog box is displayed.
2
3-48
Display the [Configuration] sheet, then click [Add].
Printing from a Network Computer using a Shared Printer
The [Select Network Component Type] dialog box is displayed.
4
Click the [Service] icon, then click [Add].
Select [File and printer sharing for Microsoft Networks], then
click [OK].
The [Select Network Component Type] dialog box appears first, then the
[Network] dialog box reappears.
5
Click [File and Print Sharing].
Printing from a Network Computer using a Shared Printer
3
Setting Up the Printing Environment
3
3-49
6
7
3
Make sure that [I want to be able to allow others to print to my
printer(s).] is selected, then click [OK].
Go to the [Access Control] sheet and select either
[Share-level access control] or [User-level access control].
Setting Up the Printing Environment
If you want to specify the users that can print, select [User-level access control].
8
Click [OK], then restart Windows.
■ Printer Sharing Settings
1
From the [Start] menu, select [Settings] ➞ [Printers].
The [Printers] folder is displayed.
3-50
Printing from a Network Computer using a Shared Printer
2
Right-click the icon for your printer, then select [Sharing] from
the pop-up menu.
3
Setting Up the Printing Environment
3
Select [Shared As]. Change the [Share Name] and enter a
[Comment] and [Password] as needed.
NOTE
• If you selected [User-level access control] in Step 7 of the "Network Settings"
procedure (See p. 3-50), click [Add] and select the users that can use the printer.
• Do not enter blank or special characters in [Shared As].
• If you enter a password, it is possible that the client computer will not be able to
create the printer port.
Printing from a Network Computer using a Shared Printer
3-51
4
Click [OK].
The printer icon changes to the shared printer icon.
Setting Up the Printing Environment
3
3-52
Printing from a Network Computer using a Shared Printer
For Windows 2000/XP/Server 2003/Vista
The screen shots shown in this section are taken from Windows XP Home Edition.
■ Preparing the Print Sharing Settings
Select [Control Panel] from the [Start] menu, then click
[Network and Internet Connections] ➞ [Network
Connections].
For Windows 2000: Select [Settings] ➞ [Network and Dial-up Connections] from
the [Start] menu.
For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞
[Network Connections] ➞ [Local Area Connection] ➞ [Properties], and then
proceed to Step 3.
For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[View network status and tasks] ➞ [Manage network connections].
For Windows 2000: The [Network and Dial-up Connections] folder is displayed.
For Windows XP/Vista: The [Network Connections] folder is displayed.
2
Right-click the [Local Area Connection] icon, then select
[Properties] from the pop-up menu.
The [Local Area Connection Properties] dialog box appears.
Printing from a Network Computer using a Shared Printer
3-53
3
Setting Up the Printing Environment
1
NOTE
If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Continue].
3
Check that [File and Printers Sharing for Microsoft Networks]
is selected, then click [OK].
Setting Up the Printing Environment
3
■ Printer Sharing Settings
NOTE
For Windows XP, the printer cannot be shared over a network using the default settings
(the settings immediately after installation).
To use the printer sharing settings, you need to run [Network Setup Wizard] and enable
printer sharing.
For more details, see the Windows online help.
1
Open the [Printers and Faxes] or [Printers] folder.
For Windows 2000: Select [Settings] ➞ [Printers] from the [Start] menu.
For Windows XP Professional/Server 2003: Select [Printers and Faxes] from the
[Start] menu.
For Windows XP Home Edition: Select [Control Panel] from the [Start] menu, then
click [Printers and Other Hardware] ➞ [Printers and Faxes].
For Windows Vista: Select [Control Panel] from the [Start] menu, then click
[Printer].
The [Printers and Faxes] or [Printers] folder is displayed.
3-54
Printing from a Network Computer using a Shared Printer
Right-click the icon for your printer, then select [Sharing] from
the pop-up menu.
3
Setting Up the Printing Environment
2
NOTE
If you are using Windows Vista and [Change sharing options] appears, click
[Change sharing options].
If the [User Account Control] dialog box appears, click [Continue].
Printing from a Network Computer using a Shared Printer
3-55
3
Select [Share this printer]. Update the share name as
required.
For Windows 2000: Select [Shared as].
For Windows Vista: Select the [Share this printer] check box.
Setting Up the Printing Environment
3
NOTE
• You can also specify the sharing settings during the local installation.
• Do not enter blank or special characters in [Shared name].
3-56
Printing from a Network Computer using a Shared Printer
If the print server is running an operating system other than
Windows Vista and any client is using Windows 98/Me, click
[Additional Drivers].
If the print server is running Windows Vista or no client is using Windows 98/Me,
click [OK]. The printer icon changes to the shared printer icon, and the printer
sharing settings are completed.
3
Setting Up the Printing Environment
4
The [Additional Drivers] dialog box is displayed.
Printing from a Network Computer using a Shared Printer
3-57
5
Place a checkmark next to [Windows 95, 98 and Me], then
click [OK].
For Windows 2000: Place a checkmark next to [Windows 95 or 98], and then
click [OK].
For Windows Server 2003: Place a checkmark next to [Windows 95, Windows 98,
and Windows Millennium Edition], and then click [OK].
Setting Up the Printing Environment
3
6
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If the [Insert Disk] dialog box appears, click [OK].
7
Click [Browse]. If your CD-ROM drive is drive [D:], select
[D:\English\Win98_Me], and then click [OK].
Windows will begin copying files.
3-58
Printing from a Network Computer using a Shared Printer
8
Click [Close].
The printer icon changes to the shared printer icon.
IMPORTANT
To clear the printer sharing settings, use the following procedures.
- For an operating system other than Windows Vista: Select [Do not share this
printer] ([Not shared] for Windows 2000) in the [Sharing] sheet.
- For Windows Vista: Clear the [Share this printer] check box in the [Sharing] sheet.
(If [Change sharing options] appears, click [Change sharing options] to display
the [User Account Control] dialog box, and then click [Continue].)
If you cleared the printer sharing settings with Windows XP Service Pack 2 or
another operating system equipped with Windows Firewall, you need to delete the
settings registered in Windows Firewall using the utility software. (See p. 7-11)
■ Configuring Windows Firewall Settings
If you are using Windows XP Service Pack 2 or another operating system equipped with
Windows Firewall as a print server, you need to configure Windows Firewall to unblock
communication with the client computers.
Use the following procedure to check whether you configure Windows Firewall to unblock
this communication.
Printing from a Network Computer using a Shared Printer
3-59
Setting Up the Printing Environment
3
• When you installed the CAPT software from CD-ROM Setup, a [Warning] dialog box was
displayed.
3
1. Display the [Windows Firewall] ([Windows Firewall Settings] for Windows Vista)
dialog box.
Setting Up the Printing Environment
- If you clicked [Yes], Windows Firewall was reconfigured to unblock communication with
the client computers.
- If you clicked [No], however, Windows Firewall was configured to block communication
with the client computers, and you will need to use the following method to clear that
block.
- For Windows XP: From the [Start] menu, select [Control Panel], and then click
[Network and Internet Connections] ➞ [Windows Firewall].
- For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞
[Windows Firewall].
- For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[Allow a program through Windows Firewall]. (If the [User Account Control] dialog
box appears, click [Continue].)
2. On the [Exceptions] sheet in the [Windows Firewall] ([Windows Firewall Settings] for
Windows Vista) dialog box, place a checkmark next to [Canon LBP3000 RPC
Server Process], and click the [OK] button.
• If you installed the CAPT software by any method other than CD-ROM Setup, you need
to use the CAPT Windows Firewall Utility software to configure Windows Firewall to
unblock communication with the client computers. (See p. 7-8)
3-60
Printing from a Network Computer using a Shared Printer
Installing the Client
This section describes the procedure for installing the printer driver on the client
computers.
There are two ways to install the printer driver: local installation and download
installation.
■ Local Installation (See p. 3-62)
Installing the printer driver using the supplied CD-ROM.
■ Download and Install
• Installing from the [Printers and Faxes] Folder or the [Printers] Folder (See p. 3-69)
• Installing using [Windows Explorer] (See p. 3-73)
IMPORTANT
• If you are using Windows 2000/XP/Server 2003/Vista, be sure to log on as a user who is
a member of the Administrators group when starting up.
• If the client computer is using Windows XP Service Pack 2 or another operating system
equipped with Windows Firewall, configure the following settings. If you do not make
these settings on the client computer, status information will not display correctly in the
Printer Status Window, and some of the printer functions may not operate correctly.
1. Display the [Windows Firewall] ([Windows Firewall Settings] for Windows Vista)
dialog box.
- For Windows XP: From the [Start] menu, select [Control Panel], and then click
[Network and Internet Connections] ➞ [Windows Firewall].
- For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞
[Windows Firewall].
- For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[Allow a program through Windows Firewall]. (If the [User Account Control] dialog
box appears, click [Continue].)
Printing from a Network Computer using a Shared Printer
3-61
3
Setting Up the Printing Environment
This installs the printer driver by downloading it from the print server, without needing to
use the supplied CD-ROM. There are two ways to download and install the driver:
2. On the [Exceptions] sheet in the [Windows Firewall] ([Windows Firewall Settings]
for Windows Vista) dialog box, place a checkmark next to [File and Printer Sharing]
then click [OK].
Setting Up the Printing Environment
3
NOTE
• Clients can use either Windows 98/Me or Windows 2000/XP/Server 2003/Vista.
• If your print server is Windows 98/Me, you cannot download and install on Windows
2000/XP/Server 2003/Vista.
• If the print server is running Windows Vista, you cannot download and install the driver on
Windows 98/Me.
• The screen shots shown in this section are taken from Windows XP Home Edition.
Installing from CD-ROM Setup
1
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If the CD-ROM is already in the drive, eject the CD-ROM and reinsert it into the
drive again.
The CD-ROM Setup appears automatically.
IMPORTANT
• If you are using Windows Vista and the [AutoPlay] dialog box appears, click [Run
AUTORUN.EXE].
• If CD-ROM Setup does not appear, display it using the following procedures. (The
CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name
may differ depending on the computer you are using.)
- If you are using an operating system other than Windows Vista, select [Run] from
the [Start] menu, enter "D:\English\MInst.exe", and then click [OK].
3-62
Printing from a Network Computer using a Shared Printer
- If you are using Windows Vista, enter "D:\English\MInst.exe" in [Start Search]
under the [Start] menu, and then press the [ENTER] key on your keyboard.
NOTE
If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Allow].
2
Click [Easy Installation] or [Custom Installation].
[Easy Installation] allows you to install the printer driver and the instruction
manuals simultaneously. If you do not install the manuals, select [Custom
Installation].
3
Setting Up the Printing Environment
3
Click [Install].
Printing from a Network Computer using a Shared Printer
3-63
If you selected [Custom Installation] in Step 2, clear the [Online Manuals] check
box, and then click [Install].
Setting Up the Printing Environment
3
3-64
4
Confirm the contents, then click [Yes].
5
Click [Next].
Printing from a Network Computer using a Shared Printer
6
Select [Manually Set Port to Install], then click [Next].
7
Click [Add Port].
8
Select [Network], then click [OK].
Printing from a Network Computer using a Shared Printer
Setting Up the Printing Environment
3
3-65
9
Select the icon for the shared printer in the print server, then
click [OK].
Setting Up the Printing Environment
3
10 Select whether or not to use this printer as the default printer,
then click [Next].
11 Click [Start].
3-66
Printing from a Network Computer using a Shared Printer
If you are using Windows XP Service Pack 2 or another operating system
equipped with Windows Firewall, the following screen is displayed. Click [No].
Select [Yes] only when the computer on which you are currently installing the
printer driver is to be used as a print server.
12 The message <Installation cannot be stopped once it starts.
Do you want to continue?> appears. Click [Yes].
Installation of the printer driver starts.
For Windows Vista: The [Printers] dialog box appears. Click [Install driver]. (If the
[User Account Control] dialog box appears, click [Continue].)
13 If [Easy Installation] is selected in Step 2, the manuals are
installed.
Printing from a Network Computer using a Shared Printer
3-67
Setting Up the Printing Environment
3
14 Confirm the installation results, then click [Next].
Setting Up the Printing Environment
3
NOTE
If the printer driver is not installed properly, see "Installation Problems," on p. 6-27.
15 Select the [Restart Computer Now (Recommended)] check
box, then click [Restart].
Windows restarts.
If you are using Windows XP Service Pack 2 or another operating system equipped
with Windows Firewall on the client computers, configure Windows Firewall to
unblock communication with the print server. If you do not clear the block, the printer
status may not be displayed properly in the Printer Status Window, and some of the
printer functions may not operate properly. (See p. 7-8)
3-68
Printing from a Network Computer using a Shared Printer
Installing from the [Printers and Faxes] Folder or the [Printers]
Folder
1
Open the [Printers and Faxes] or [Printers] folder.
For Windows 98/Me/2000: Select [Settings] ➞ [Printers] from the [Start] menu.
For Windows XP Professional/Server 2003: Select [Printers and Faxes] from the
[Start] menu.
For Windows XP Home Edition: Select [Control Panel] from the [Start] menu, then
click [Printers and Other Hardware] ➞ [Printers and Faxes].
For Windows Vista: Select [Control Panel] from the [Start] menu, then click
[Printer].
2
Display the [Add Printer Wizard] or [Add Printer] dialog box.
For Windows 98/Me/2000: Double-click [Add Printer].
For Windows XP Professional/Home Edition: Click [Add a printer].
For Windows Server 2003: Double-click [Add Printer].
For Windows Vista: Proceed to Step 4 by clicking [Add a printer].
3
Click [Next].
Printing from a Network Computer using a Shared Printer
3-69
Setting Up the Printing Environment
3
The [Printers and Faxes] or [Printers] folder is displayed.
4
Select [A network printer, or a printer attached to another
computer], then click [Next].
For Windows 98/Me/2000: Select [Network Printer] then click [Next].
For Windows Vista: Click [Add a network, wireless or Bluetooth printer].
Setting Up the Printing Environment
3
If you are using Windows Vista, searching the printer on a network starts
automatically. Click [The printer that I want isn't listed].
5
Select [Browse for a printer], then click [Next].
For Windows 98/Me: click [Browse].
For Windows Vista, select [Select a shared printer by name], and then click
[Next].
3-70
Printing from a Network Computer using a Shared Printer
6
Select the printer on the print server, then click [Next].
For Windows Vista, select the printer on the print server, and then click [Select].
For Windows 98/Me: Proceed to Step 8.
For Windows Vista: The [Printers] dialog box appears. Click [Install driver]. (If the
[User Account Control] dialog box appears, click [Continue].)
7
Select whether or not to use this printer as the default printer,
then click [Next].
For Windows Vista, enter a new name in [Printer name] if you want to change the
printer name. When specifying the printer as the default printer, select the [Set as
the default printer] check box, and then click [Next].
For Windows Vista, click [Print a test page] when printing a test page. A dialog box
appears after printing. Click [Close] to close the dialog box.
Printing from a Network Computer using a Shared Printer
3-71
Setting Up the Printing Environment
3
8
Click [Finish].
Setting Up the Printing Environment
3
IMPORTANT
If you are using an operating system equipped with Windows Firewall, such as
Windows XP Service Pack 2, on the client computer, you need to configure
Windows Firewall to unblock communication with the print server. If you do not
configure Windows Firewall to unblock communication with the server, the printer
status may not be displayed correctly in the Printer Status Window and some
functions may not operate properly. (See p. 7-8)
NOTE
If the [Digital Signature Not Found] dialog box appears, click [Yes].
3-72
Printing from a Network Computer using a Shared Printer
Installing using [Windows Explorer]
1
From the [Start] menu, select [All Programs] ➞ [Accessories]
➞ [Windows Explorer].
For Windows Me/2000: From the [Start] menu, select [Programs] ➞
[Accessories] ➞ [Windows Explorer].
For Windows 98: From the [Start] menu, select [Programs] ➞ [Windows
Explorer].
The [Windows Explorer] window is displayed.
Select the print server from [My Network Places] (from
[Network Neighborhood] for Windows 98; from [Network] for
Windows Vista), then double-click the icon for this printer.
Alternatively, you can drag and drop the icon for the printer into the [Printers and
Faxes] or [Printers] folder.
Printing from a Network Computer using a Shared Printer
3-73
3
Setting Up the Printing Environment
2
3
Follow the instructions that appear on the screen.
IMPORTANT
If you are using an operating system equipped with Windows Firewall, such as
Windows XP Service Pack 2, on the client computer, you need to configure
Windows Firewall to unblock communication with the print server. If you do not
configure Windows Firewall to unblock communication with the server, the printer
status may not be displayed correctly in the Printer Status Window and some
functions may not operate properly. (See p. 7-8)
Setting Up the Printing Environment
3
3-74
Printing from a Network Computer using a Shared Printer
Uninstalling the CAPT software
The process of removing software to restore the computer to the same state as
before the software was installed is referred to as uninstalling. Use the following
procedure to uninstall the CAPT software.
1
Make sure to close all the files and programs listed below:
• Help files
• Printer Status Window
• Control Panel
• Other applications
2
From the [Start] menu, select [All Programs] ➞ [Canon Printer
Uninstaller] ➞ [Canon LBP3000 Uninstaller].
For Windows 98/Me/2000: From the [Start] menu, select [Programs] ➞ [Canon
Printer Uninstaller] ➞ [Canon LBP3000 Uninstaller].
The [Delete Printer] dialog box is displayed.
Uninstalling the CAPT software
3-75
3
Setting Up the Printing Environment
IMPORTANT
• If the software was installed with administrative permissions on Windows 2000/XP/
Server 2003/Vista, then it cannot be uninstalled by anyone that does not have
administrative permissions. Make sure you log on as a member of the Administrators
group before uninstalling.
• If the manuals are installed, the installed manuals also can be uninstalled by uninstalling
the CAPT software using the Uninstaller.
• If you are using Windows XP Service Pack 2 or another operating system equipped with
Windows Firewall, this printer is registered in the [Exceptions] sheet in the [Windows
Firewall] ([Windows Firewall Settings] for Windows Vista) dialog box. When you uninstall
the CAPT software using the uninstaller, the settings for this printer are also deleted from
the [Exceptions] sheet in the [Windows Firewall] ([Windows Firewall Settings] for
Windows Vista) dialog box.
NOTE
If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Allow].
3
Select the name of your printer, and then click [Delete].
Setting Up the Printing Environment
3
A confirmation message is displayed.
NOTE
Even if [Canon LBP3000] is not in the list in the [Delete Printer] dialog box, you can
delete all of the files and data related to this printer by clicking the [Delete] button.
4
Click [Yes].
The uninstallation process begins. Please wait a moment.
3-76
Uninstalling the CAPT software
Click [Exit].
3
The [Delete Printer] dialog box closes.
NOTE
If you are unable to uninstall the CAPT software, refer to "If Uninstallation Fails," on
p. 6-28.
Uninstalling the CAPT software
3-77
Setting Up the Printing Environment
5
Setting Up the Printing Environment
3
3-78
Uninstalling the CAPT software
Printing a Document
4
CHAPTER
This chapter describes the printing procedures and the functions of this printer.
Printing from an Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Specifying Printing Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
For Windows 98/Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
For Windows 2000/XP/Server 2003/Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10
Canceling, Pausing and Resuming Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Using the Printing Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Tab Sheets in the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-19
Preview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-33
Printing Multiple Pages on One Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-34
Scaling Printer Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-36
Poster Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-38
Specifying a Custom Paper Size (Non-Standard Paper) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-39
Specifying the Finishing Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-41
Specifying the Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-44
Grayscale Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-46
Working with Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-47
Editing Print Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-52
Viewing Printer Settings/Restoring the Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-54
Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-56
Installing the Manuals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-56
Uninstalling the Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-59
Printer Status Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-60
Using the Printer Status Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-61
Displaying the Printer Status Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-63
The Options Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-64
[Resolve Error] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-66
Displaying Printer Status When Using a Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-67
4-1
Printing from an Application
After installing the CAPT software, you can now print jobs on the printer.
This section describes the procedure for printing from an application, taking Adobe
Reader 6.0 as an example.
1
Load paper in the multi-purpose tray or manual feed tray.
NOTE
If you are printing on plain paper, heavy paper, label paper, or transparencies, refer
to "Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies," on p.
2-14; if you are printing on index card, refer to "Printing on Index Card," on p. 2-27;
if you are printing on envelopes, refer to "Printing on Envelopes," on p. 2-34; and if
you are printing on custom paper, refer to "Printing on Custom Paper Sizes
(Non-Standard Sizes)," on p. 2-45.
Printing a Document
4
2
4-2
Open the PDF file to print with Adobe Reader, and then select
[Print Setup] from the [File] menu.
Printing from an Application
4
Specify the paper size of the document and the printing
orientation, then click [OK].
Select [Print] from the [File] menu.
4
Printing a Document
3
The [Print] dialog box is displayed.
Printing from an Application
4-3
5
Select this printer from the [Name] or [Printer Name] list and
select your printing preferences.
Printing a Document
4
NOTE
The printer name displayed in this dialog box can be changed from the [Printers
and Faxes] folder (the [Printers] folder for Windows 98/Me/2000/Vista).
6
If you want to specify more detailed printing preferences, click
[Properties].
The [Canon LBP3000 Properties] dialog box is displayed.
4-4
Printing from an Application
NOTE
The procedure for displaying the [Document Properties] dialog box may differ
depending on the application you are using.
7
Specify the printing preferences in the [Page Setup],
[Finishing], [Paper Source], and [Quality] sheets.
NOTE
• The settings that are specified here only apply to the currently opened file. Check
the contents of the [Document Properties] dialog box each time you print. In
particular, it is recommended that you verify the information in the [Page Setup]
sheet and the [Paper Source] sheet.
• The default settings for all files can be configured using the following dialog box.
- For Windows 98/Me: Open the [Printer Properties] dialog box from the [Printers]
folder. (See "Opening the [Printer Properties] Dialog Box from the [Printers]
Folder," on p. 4-9.)
- For Windows 2000/XP/Server 2003/Vista: Open the [Document Properties] dialog
box from the [Printers and Faxes] or [Printers] folder. (See "Opening the
[Document Properties] Dialog Box from the [Printers and Faxes] or [Printers]
Folder," on p. 4-13.)
8
Click [OK].
The [Print] dialog box reappears.
9
Click [OK].
The printer starts printing.
Printing from an Application
4-5
Printing a Document
4
NOTE
• If the document does not print properly, refer to Chapter 6 "Troubleshooting".
• Refer to "Using the Printing Functions," on p. 4-19 for an explanation on using the
features of the printer and printer driver. To ensure that a document prints the way
you want it to, adjust the printer and printer driver settings.
Printing a Document
4
4-6
Printing from an Application
Specifying Printing Preferences
The CAPT software allows you to configure various printing preferences for the
LBP3000.
You can configure various printer functions on each of the pages of the [Printer
Properties] dialog box and [Document Properties] dialog box. Depending on your
OS, use the following procedures to open these property dialog boxes.
For Windows 98/Me
If you open the [Printer Properties] dialog box from the [Printers] folder, you can
configure the default printer settings for all print jobs.
Opening the [Document Properties] Dialog Box from an Application
This section describes the procedure for opening the [Document Properties] dialog
box, taking Adobe Reader 6.0 as an example.
1
Select [Print] from the [File] menu in the application.
The [Print] dialog box is displayed.
Specifying Printing Preferences
4-7
Printing a Document
4
If you open the [Document Properties] dialog box from within an application, the
settings are only applicable to that particular print job.
NOTE
The print command is different depending on the application you are using. Refer
to the users manual supplied with your application for further details.
2
Confirm the printer name, then click [Properties].
Printing a Document
4
The [Document Properties] dialog box is displayed.
4-8
Specifying Printing Preferences
Opening the [Printer Properties] Dialog Box from the [Printers]
Folder
1
From the [Start] menu, select [Settings] ➞ [Printers].
4
2
Printing a Document
The [Printers] folder is displayed.
Right-click the icon for this printer, then select [Properties]
from the pop-up menu.
Specifying Printing Preferences
4-9
The [Printer Properties] dialog box is displayed.
Printing a Document
4
NOTE
The [Printer Properties] dialog box can also be displayed by selecting the icon for
this printer and selecting [Properties] from the [File] menu.
For Windows 2000/XP/Server 2003/Vista
If you open the [Document Properties] dialog box from within an application, the
settings are only applicable to that particular print job.
If you open the [Document Properties] dialog box from the [Printers and Faxes] or
[Printers] folder, you can specify the default settings used by all print jobs.
If you open the [Printer Properties] dialog box from the [Printers and Faxes] or
[Printers] folder, you can configure printer options and create "Profiles" of frequently
used options.
NOTE
To change settings in the [Printers and Faxes] or [Printers] folders you need to have Full
Access Permissions. If you are unable to open the [Document Properties] dialog box
from within the [Printers and Faxes] or [Printers] folder, open it from within the
application.
4-10
Specifying Printing Preferences
Opening the [Document Properties] Dialog Box from an Application
This section describes the procedure for opening the [Document Properties] dialog
box, taking Adobe Reader 6.0 as an example.
Select [Print] from the [File] menu in the application.
4
The [Print] dialog box is displayed.
NOTE
The print command is different depending on the application you are using. Refer
to the users manual supplied with your application for further details.
Specifying Printing Preferences
4-11
Printing a Document
1
2
Confirm the printer name, then click [Properties].
Printing a Document
4
The [Document Properties] dialog box is displayed.
4-12
Specifying Printing Preferences
Opening the [Document Properties] Dialog Box from the [Printers and
Faxes] or [Printers] Folder
Open the [Printers and Faxes] or [Printers] folder.
For Windows 2000: Select [Settings] ➞ [Printers] from the [Start] menu.
For Windows XP Professional/Server 2003: Select [Printers and Faxes] from the
[Start] menu.
For Windows XP Home Edition: Select [Control Panel] from the [Start] menu, then
click [Printers and Other Hardware] ➞ [Printers and Faxes].
For Windows Vista: Select [Control Panel] from the [Start] menu, then click
[Printer].
4
Printing a Document
1
The [Printers and Faxes] or [Printers] folder is displayed.
Specifying Printing Preferences
4-13
2
4
Right-click the icon for this printer, then select [Printing
Preferences] from the pop-up menu.
Printing a Document
The [Document Properties] dialog box is displayed.
NOTE
For Windows 2000/XP/Server 2003, the [Document Properties] dialog box can also
be displayed by selecting the icon for this printer and selecting [Printing
Preferences] from the [File] menu.
4-14
Specifying Printing Preferences
Opening the [Printer Properties] Dialog Box from the [Printers and
Faxes] or [Printers] Folder
Open the [Printers and Faxes] or [Printers] folder.
For Windows 2000: Select [Settings] ➞ [Printers] from the [Start] menu.
For Windows XP Professional/Server 2003: Select [Printers and Faxes] from the
[Start] menu.
For Windows XP Home Edition: Select [Control Panel] from the [Start] menu, then
click [Printers and Other Hardware] ➞ [Printers and Faxes].
For Windows Vista: Select [Control Panel] from the [Start] menu, then click
[Printer].
4
Printing a Document
1
The [Printers and Faxes] or [Printers] folder is displayed.
Specifying Printing Preferences
4-15
2
4
Right-click the icon for this printer, then select [Properties]
from the pop-up menu.
Printing a Document
The [Printer Properties] dialog box is displayed.
NOTE
For Windows 2000/XP/Server 2003, the [Printer Properties] dialog box can also be
displayed by selecting the icon for this printer and selecting [Properties] from the
[File] menu.
4-16
Specifying Printing Preferences
Canceling, Pausing and Resuming Printing
You can use the Printer Status Window to cancel, pause, or resume print jobs.
1
Start printing.
The Printer Status Window appears.
2
To delete or pause a print job, click the [
] (Pause Job)
button in the [Current Print Job] tab or [My Job Operation]
tab.
When you click the [
] (Pause Job) button in the [Current Print Job] tab, the
following message is displayed and the screen switches to the [My Job
Operation] tab.
Canceling, Pausing and Resuming Printing
4-17
4
Printing a Document
NOTE
The Printer Status Window may not appear depending on the [Display Printer
Status Window] setting in the [Preferences] menu. (See "Setting Preferences," on
p. 4-64)
3
Click the button corresponding to the operation you would
like to perform from among the [Job Operation] buttons.
Printing a Document
4
● Deleting the job
❑ Click [
] (Delete Job).
● Pausing the job
❑ Click [
] (Pause Job).
● Resuming the job
❑ Click [
4-18
] (Resume Job).
Canceling, Pausing and Resuming Printing
Using the Printing Functions
Tab Sheets in the Printer Driver
The [Printer Properties] and [Document Properties] dialog boxes contain the
following sheets, which can be used to configure a variety of printer functions. Click
on the tab corresponding to a sheet to switch the display to that sheet.
This section describes the types of printing preferences that can be specified in
each sheet.
4
Printing a Document
■ For Windows 98/Me
• [Document Properties] Dialog Box
- [Page Setup] Sheet
- [Finishing] Sheet
- [Paper Source] Sheet
- [Quality] Sheet
• [Printer Properties] Dialog Box
- [General] Sheet
- [Details] Sheet
- [Sharing] Sheet
- [Page Setup] Sheet
- [Finishing] Sheet
- [Paper Source] Sheet
- [Quality] Sheet
- [Configuration] Sheet
■ For Windows 2000/XP/Server 2003/Vista
• [Document Properties] Dialog Box
- [Page Setup] Sheet
- [Finishing] Sheet
- [Paper Source] Sheet
- [Quality] Sheet
Using the Printing Functions
4-19
• [Printer Properties] Dialog Box
- [General] Sheet
- [Sharing] Sheet
- [Ports] Sheet
- [Advanced] Sheet
- [Color Management] Sheet
- [Security] Sheet
- [Device Settings] Sheet
- [Profile] Sheet
NOTE
For more details on using these sheets, refer to the online help.
You can access the online help using the following procedure. To close any online help
that is currently displayed, click somewhere inside the online help window.
- Press the [Tab] key on your keyboard to select the item that you want help with, then
press the [F1] key.
- Right-click the item that you want help with, then click [What's This?] from the pop-up
menu.
- Click [
] (Help) on the title bar, then move the mouse pointer with attached [?] over
the item you want help with and click on it. (This method cannot display Help on
Windows Vista.)
Printing a Document
4
For Windows Vista, the Windows help application (WinHlp32.exe) is required to display
its Online Help. If the Windows help application (WinHlp32.exe) is not installed on your
system, download it from the Microsoft Corporation website.
For details on the download methods, click [Help] in the printer driver or Printer Status
Window, and then see the [Windows Help and Support] dialog box.
[Page Setup] Sheet
The [Page Setup] sheet allows you to specify the following printing preferences:
4-20
Using the Printing Functions
■ [Page Size]
Open the [Page Size] drop-down list, then select the desired page size by clicking it.
The page sizes that can be selected are as follows:
• Standard paper sizes (sizes from A3 to A5 and from Legal to Executive)
• Index Card
• Envelopes (Envelope C5, Envelope COM10, Envelope DL, Envelope Monarch)
• Custom Paper Size (See p. 4-39)
NOTE
If the paper size specified in [Page Size] is larger than the size that can be loaded in the
printer and [Output Size] is set to [Match Page Size], A3 and B4 size pages will be
reduced and printed on A4 size paper.
■ [Output Size]
Open the [Output Size] drop-down list, then select the desired paper size.
• Match Page Size
• Standard paper sizes (sizes from A4 to A5 and from Legal to Executive)
• Index Card
• Envelopes (Envelope C5, Envelope COM10, Envelope DL, Envelope Monarch)
• Custom Paper Size (See p. 4-39)
NOTE
• When printing on paper that is the same size as [Page Size], select [Match Page Size].
• If you select a paper size that differs from [Page Size], the print will be automatically
reduced or enlarged to fit on the paper.
• When printing data in which multiple paper sizes are specified in the application, set the
[Output Size] setting in the printer driver to a specific size to print all of the pages at a
uniform size.
• If you can specify the page size, print copies, and orientation in your application, you do
not have to specify the settings in the [Page Setup] sheet.
■ [Copies]
Allows you to specify the number of copies to print.
You can click on the up and down arrows to change the [Copies] setting or type a value
directly into the box. The number of copies can be set to between 1 and 999.
■ [Orientation]
Allows you to select either portrait orientation or landscape orientation.
Click on either [Portrait] or [Landscape] to change the [Orientation].
Using the Printing Functions
4-21
Printing a Document
4
The paper sizes that can be selected are as follows:
■ [Page Layout] (See p. 4-34)
• N Pages per Sheet
Multiple pages can be printed on one sheet of paper.
The number of pages that can be selected is 1, 2, 4, 6, 8, 9, or 16 (Pages per Sheet).
If you select 2, 4, 6, 8, 9, or 16 (Pages per Sheet), the [Page Order] drop-down list
appears, allowing you to specify the page order.
• Poster
Magnifies a single page image and prints it out over several sheets of paper.
The number of pages that can be selected is 2 x 2, 3 x 3, or 4 x 4.
■ [Manual Scaling] / [Page Order] (See p. 4-36)
The [Manual Scaling] setting is displayed if the [Page Layout] is set to 1 page per sheet.
The [Page Order] setting is displayed if the number of pages per sheet is 2, 4, 6, 8, 9 or
16.
• Manual Scaling: The scale factor is automatically adjusted if the [Page Size] and [Output
Size] are different. If you want to change the scale factor manually, select [Manual
Scaling] and enter the numerical scale factor in the adjacent box. The scale factor can
be set to between 25 and 200%.
• Page Order: You can select the page order when printing multiple pages on one sheet of
paper.
Printing a Document
4
■ [Custom Paper Size] (See p. 4-39)
Click [Custom Paper Size] to open the dialog box shown below.
This dialog box allows you to enter the paper length and width when you are printing on
custom paper that does not match any of the standard paper sizes.
In Windows 98/Me, up to 30 custom paper sizes can be added. In Windows 2000/XP/
Server 2003/Vista, the number depends on your system environment.
4-22
Using the Printing Functions
[Finishing] Sheet
The [Finishing] sheet allows you to specify the following printing preferences:
■ [Finishing]
You can select the method of finishing the document from the following options:
• Off: Each page is printed repeatedly to give the desired number of copies.
• Collate: The entire document is printed repeatedly to produce the desired number of
copies.
■ [Finishing Details] (See p. 4-41)
Click [Finishing Details] to display the following dialog box.
This dialog box allows you to specify the various options for job processing.
■ [Advanced Settings] (See p. 4-42)
Click [Advanced Settings] in the [Finishing Details] dialog box to open the following dialog
box.
Using the Printing Functions
4-23
Printing a Document
4
This dialog box allows you to specify detailed finishing settings.
[Paper Source] Sheet
You can specify the following printing preferences in the [Paper Source] sheet.
Printing a Document
4
■ [Paper Type]
Specifies the type of paper used in the printer.
Configure this setting as follows:
Printer Driver
Setting
Paper Type
[Plain Paper]
Plain Paper (64 to 90 g/m2), Label Paper
[Plain Paper L]
If the paper curls excessively when you are printing on plain paper (64
to 90 g/m2) with the [Paper Type] setting set to [Plain Paper], try
setting the [Paper Type] setting to [Plain Paper L].
[Heavy Paper]
Heavy Paper (91 to 163 g/m2)
[Heavy Paper H]
Select this if you want to get improved fixing properties over the
results of printing using the [Heavy Paper] setting.
[Transparency]
Transparencies
* When printing envelopes, index card or custom paper, the printer automatically changes the printing mode to suit
the paper type when you change the [Output Size] setting in the [Page Setup] sheet.
* You can only select [Transparency] if the [Output Size] in the [Page Setup] sheet is set to either A4 or Letter size.
4-24
Using the Printing Functions
[Quality] Sheet
The [Quality] sheet allows you to specify the following printing preferences:
■ [Objective] (See p. 4-44)
Selecting the appropriate objective for the contents of the job allows you to perform
optimum printing.
• Standard: This mode is best suited to printing documents containing a mixture of text,
photographs, and graphics. It produces printouts that match what you see on the screen.
• Text/Lines: This mode is best suited to printing color text and fine color lines. Color text
and fine color lines are printed in solid black.
• Web Pages: This mode is best suited to printing the images, etc. of a web page.
Low-resolution images that would normally print out coarsely or jagged in regular
printing modes are printed clearly.
■ [Details] (See p. 4-45)
Click [Details] to open the dialog box shown below.
This dialog box allows you to change the printing settings according to your preferences.
Using the Printing Functions
4-25
Printing a Document
4
IMPORTANT
Using the toner save mode may decrease print density making printed text look patchy.
■ [Manual Grayscale Settings] (See p. 4-46)
Check this box if you want to customize the grayscale settings. To configure the grayscale
settings in detail, click the [Grayscale Settings] button to open the [Grayscale Settings]
dialog box.
■ [Grayscale Settings] (See p. 4-46)
Click [Grayscale Settings] to open the dialog box shown below.
This dialog box allows you to specify brightness and contrast used for printing.
Printing a Document
4
4-26
Using the Printing Functions
[General] Sheet
This sheet displays the printer name and allows you to print a test page.
[Details] Sheet (Windows 98/Me only)
This sheet allows you to configure printer port settings, add drivers, modify spooling
settings, etc.
Using the Printing Functions
4-27
Printing a Document
4
[Sharing] Sheet
This sheet allows you to specify whether or not to share the printer.
NOTE
• For Windows 98/Me, the [Sharing] sheet does not appear if [File and printer sharing for
Microsoft Networks] has not been added in the network settings. (See p. 3-48)
• For Windows 2000/XP/Server 2003/Vista, the [Sharing] sheet does not appear if the
network has not been configured. (See p. 3-53)
Printing a Document
4
[Ports] Sheet (Windows 2000/XP/Server 2003/Vista only)
This sheet allows you to add, delete, and configure the printer port.
4-28
Using the Printing Functions
[Advanced] Sheet (Windows 2000/XP/Server 2003/Vista only)
This sheet allows you to specify detailed settings, such as the times when the
printer is available and the spooling settings.
Printing a Document
4
[Color Management] Sheet (Windows 2000/XP/Server 2003/Vista
only)
The [Color Management] sheet is not used by this printer.
Using the Printing Functions
4-29
[Security] Sheet (Windows 2000/XP/Server 2003/Vista only)
This sheet allows you to confirm the access permissions for each user.
NOTE
• On Windows XP Professional, the [Security] sheet is not displayed if the [Use simple file
sharing (Recommended)] checkbox is checked in the [View] sheet of the Windows
[Folder Options] settings.
• On Windows XP Home Edition, the [Security] sheet is not displayed.
Printing a Document
4
[Configuration]/[Device Settings] Sheet
The [Configuration]/[Device Settings] sheet allows you to configure when the
Printer Status Windows is displayed, and other settings.
4-30
Using the Printing Functions
■ [Spooling at Host] (Windows 2000/XP/Server 2003/Vista only)
You can specify whether spooling is performed at the Host.
■ [Show Icon in the Taskbar] (See p. 4-63)
When this option is checked, an icon for displaying the Printer Status Window appears in
the Windows Taskbar.
[Profile] Sheet (Windows 2000/XP/Server 2003/Vista only)
This sheet allows you to create and add new Profiles and to edit existing Profiles.
Printing a Document
4
■ [Profile List]
Lists the available Profiles.
■ [Name]
Displays the name of the Profile selected in the [Profile List].
■ [Comment]
Displays a comment about the Profile selected in [Profile List].
■ [Add] (See p. 4-48)
Click [Add] to open the dialog box shown below.
Using the Printing Functions
4-31
This dialog box allows you to enter the [Name], [Icon], [Comment], and printing
preferences for a newly added Profile or a Profile that you are editing.
Printing a Document
4
■ [Edit] (See p. 4-50)
Click [Edit] to open the dialog box shown below.
This dialog box allows you to enter the [Name], [Icon], [Comment], and printing
preferences for a newly added Profile or a Profile that you are editing.
■ [Delete] (See p. 4-50)
Allows you to delete an added Profile.
■ [Import] (See p. 4-50)
Allows you to import a Profile saved as a file and add it to the printer driver.
■ [Export] (See p. 4-51)
Allows you to save an added or edited Profile as a file.
4-32
Using the Printing Functions
■ [Allow Profile Selection]
Allows you to select a Profile from within the [Document Properties] dialog box.
■ [Allow Setting Edition]
Allows you to add new Profiles that are different from the Profiles previously registered in
the [Document Properties] dialog box.
Preview
The preview panel on the [Page Setup], [Paper Source], and [Finishing] sheets
shows the current printer settings. You can change [Page Layout] and [Finishing]
settings by right-clicking on the Preview panel.
Printing a Document
4
The Preview panel functions differently depending on which icon is selected (
) at the upper left of the Preview panel.
■ When
or
is selected
You can adjust the [Page Layout] setting.
The [Page Layout] setting changes cyclically between [1 Page per Sheet], [2 Pages per
Sheet], and [4 Pages per Sheet] each time you left-click within the document image.
If you right-click within the Preview panel, you can choose between [1 Page per Sheet], [2
Pages per Sheet], and [4 Pages per Sheet].
■ When
is selected
You can adjust the [Finishing] settings.
If you right-click within the Preview panel, you can choose between [Off] and [Collate].
Using the Printing Functions
4-33
Printing Multiple Pages on One Sheet
Multiple pages can be printed on one sheet of paper.
1
For Windows 2000/XP/Server 2003/Vista, display the [Device
Settings] sheet and select [Auto] from [Spooling at Host].
Printing a Document
4
4-34
Using the Printing Functions
2
Display the [Page Setup] sheet, then set the [Page Layout]
setting to the number of pages to print on each sheet of paper.
The number of pages that can be selected is 1, 2, 4, 6, 8, 9, or 16 (Pages per
Sheet).
Printing a Document
4
3
The [Page Order] setting is displayed if the number of pages
per sheet is 2, 4, 6, 8, 9 or 16. Use this to select the order that
pages are printed.
Using the Printing Functions
4-35
NOTE
The options in the [Page Order] drop-down list differ depending on the paper
orientation and the number of pages to be printed on each sheet.
4
Confirm the settings, then click [OK].
Scaling Printer Output
You can choose to scale your document if [Page Layout] is set to [1 Page per
Sheet].
4
However, the scale factor can also be specified manually.
Printing a Document
The scale factor is automatically adjusted if the [Page Size] and [Output Size]
settings are different.
You can specify a scaling factor of between 25 and 200%.
Scaling a Document Automatically
1
4-36
Display the [Page Setup] sheet, and set the [Page Size]
setting.
Using the Printing Functions
2
Specify the paper size in [Output Size].
3
Confirm the settings, then click [OK].
The scale factor will be set automatically depending on the sizes specified in
[Page Size] and [Output Size].
Scaling a Document Manually
2
3
4
Display the [Page Setup] sheet, and set the [Page Size]
setting.
4
Specify the paper size in [Output Size].
Printing a Document
1
Place a checkmark next to [Manual Scaling], then enter the
scaling factor in the spin box.
Confirm the settings, then click [OK].
Using the Printing Functions
4-37
Poster Printing
You can magnify a single page image and print it out over several sheets of paper.
You can then create a large poster-sized printout by taping the multiple sheets of
paper together.
1
For Windows 2000/XP/Server 2003/Vista, display the [Device
Settings] sheet and select [Auto] from [Spooling at Host].
Printing a Document
4
4-38
Using the Printing Functions
2
Display the [Page Setup] sheet and select [Poster (N x N)] (N =
2, 3, 4) from [Page Layout].
Printing a Document
4
A layout image of the printout appears in the Preview panel.
3
Confirm the settings, then click [OK].
IMPORTANT
• The printing order of each sheet (after being divided into multiple pages) becomes
"Upper Left to Right".
• When you perform poster printing, the [Page Order] setting is disabled.
Specifying a Custom Paper Size (Non-Standard Paper)
It is possible to configure custom paper sizes.
NOTE
To specify a custom paper size, you need to open the dialog box shown below.
- For Windows 2000/XP/Server 2003/Vista
Open the [Document Properties] dialog box from the [Printers and Faxes] folder (the
[Printers] folder for Windows 2000/Vista).
- For Windows 98/Me
Open the [Printer Properties] dialog box from the [Printers] folder.
Using the Printing Functions
4-39
1
Display the [Page Setup] sheet, then click [Custom Paper
Size].
Printing a Document
4
The [Custom Paper Size Settings] dialog box is displayed.
2
Configure the following items as needed:
[Paper List]:
Displays the names and dimensions of the standard paper sizes
and existing custom paper sizes.
[Name of Custom Paper Enter a name to use for the new custom paper size. You can enter
Size]:
up to 31 characters.
4-40
[Unit]:
Specify the unit (Millimeter or Inch) to use when entering the
dimensions of the custom paper size.
[Paper Size]:
Specifies the length and width of the custom paper size (length
greater than or equal to width). Paper sizes should be specified in
portrait orientation (length greater than or equal to width) and
within the user-definable limits.
Using the Printing Functions
3
Click [Register].
NOTE
In Windows 98/Me, up to 30 custom paper sizes can be added. In Windows 2000/
XP/Server 2003/Vista, the number depends on your system environment.
4
Confirm the settings, then click [OK].
Specifying the Finishing Method
You can specify a variety of options for print processing.
Display the [Finishing] sheet, then click [Finishing Details].
4
Printing a Document
1
The [Finishing Details] dialog box is displayed.
Using the Printing Functions
4-41
2
Configure the following settings as needed:
[Detect Paper Size in Multi-purpose When this box is checked, a message is displayed and
Tray]:
the print job is paused if the [Output Size] setting in the
[Page Setup] sheet of the current print job is different
from the previous print job.
To print on the paper currently loaded in the printer,
click [
] (Resolve Error) in the Printer Status
Window.
To print on different paper than the paper currently
loaded in the printer, reload the new paper then click
[
] (Resolve Error) in the Printer Status Window.
However, the first job that you print straight after
turning the printer off and on will print onto the
currently loaded paper without displaying a message,
regardless of the [Output Size] setting.
When this box is unchecked, the job prints on the
paper currently loaded in the printer regardless of the
[Output Size] setting.
Printing a Document
4
3
[Rotate Print Data 180 Degrees]:
Rotates the print data by 180 degrees while printing.
This function can be used to print on envelopes, index
card and other material that can only be fed to the
printer in one specific direction.
[Use Skip Blank Pages Mode]:
When this option is checked, blank pages are not
output if the job includes blank pages.
Click [Advanced Settings] in the [Finishing Details] dialog
box.
The [Advanced Settings] dialog box is displayed.
4-42
Using the Printing Functions
4
Configure the following settings as needed:
[Image Refinement]:
This setting specifies whether or not to apply
Image Refinement. When Image Refinement is
applied, jagged lines in text and graphics are
printed smoothly.
[EMF Spooling]
Specifies whether to spool print data in EMF
(Windows 2000/XP/Server 2003 only): (metafile) format. If this option is selected, print
data is spooled in EMF format.
Confirm the settings, then click [OK].
The [Finishing Details] dialog box reappears.
4
Printing a Document
5
Using the Printing Functions
4-43
Specifying the Print Quality
You can perform optimum printing by simply selecting the appropriate choice from
the [Objective] list.
1
Display the [Quality] sheet, then select the [Objective] setting.
Printing a Document
4
[Standard]:
This mode is best suited to printing documents
containing a mixture of text, photographs, and
graphics. This lets you produce printouts that are
relatively close to what you see on the screen.
[Text/Lines]:
This mode is best suited to printing color text and fine
color lines. Color text and fine color lines are printed in
solid black.
[Web Pages]:
This mode is best suited to printing the images, etc. of
a web page. Low-resolution images that would
normally print out coarsely or jagged in regular printing
modes are printed clearly.
For more detailed settings, click the [Details] button.
4-44
Using the Printing Functions
The [Detailed Settings] dialog box is displayed.
Configure the following settings as needed:
[B & W Halftones]:
3
Select the method for reproducing subtle gradations
(halftones) in black-and-white data.
[Pattern 1]: Prints using gradation that makes gray and
color text appear sharp, while keeping photographic
images and diagrams smooth. This mode produces
relatively stable printing results.
[Pattern 2]: Choose this setting if text, diagrams,
tables, graphs, etc. appear exceedingly light or
disappear when using [Pattern 1]. In some cases,
however, diagrams, tables and graphs may appear
even lighter or less smooth than [Pattern 1] using this
setting.
[None [Solid]]: Prints all colors in black, except for
white.
[Print Colored Text and Lines in
Black]:
Check this box when the color text or thin lines in CAD
data etc. drop out or appear broken when printed. You
should be able to print thin lines clearly.
[Enable Image Correction]:
When image data such as photographic images are
enlarged by an application when printed, the printed
images can appear rough or jagged. Select this setting
to smooth the images when printing this kind of
low-resolution data.
[Toner Density]:
Adjusts the density of printed toner. Adjust the density
by dragging the [Toner Density] slider left or right.
[Use Toner Save]:
By using this function, you can reduce the toner
consumption of the printer by thinning out the data that
is printed.
Confirm the settings, then click [OK].
Using the Printing Functions
4-45
4
Printing a Document
2
Grayscale Settings
You can customize the grayscale settings.
1
Display the [Quality] sheet, place a checkmark next to [Manual
Grayscale Settings], and then click [Grayscale Settings].
Printing a Document
4
The [Grayscale Settings] dialog box is displayed.
4-46
Using the Printing Functions
2
3
Configure the following settings as needed:
[Brightness]:
Adjusts the brightness level used for printing. Drag the
[Brightness] slider left or right to adjust the brightness.
[Contrast]:
Adjusts the contrast level used for printing. Drag the
[Contrast] slider left or right to adjust the contrast.
Confirm the settings, then click [OK].
The [Quality] sheet reappears.
Working with Profiles
Use the following procedure to save the printing preferences as a [Profile].
Make sure that any one of the [Page Setup], [Finishing], [Paper Source] and
[Quality] sheets is displayed, then perform the following procedure.
NOTE
• If you are using Windows 98/Me, up to 50 profiles can be created. However, if [Users can
customize their preferences and desktop settings. Windows switches to your personal
settings when you log on.] is selected in the [User Profiles] sheet of the Windows
password settings (double-click [My Computer] ➞ [Control Panel] ➞ [Passwords]), then
you can create up to 50 profiles for each user.
• For Windows 2000/XP/Server 2003/Vista, up to 50 Profiles can be added for each user
account.
• If you change the name of the printer, any saved profiles will become unreadable. If you
restore the printer name to the original value, you will be able to read the profiles again.
• Profile data will not be erased even if you uninstall the printer. You will be able to use the
profiles again after you reinstall the printer driver.
• The Profile information files saved on Windows 98/Me cannot be used on Windows 2000/
XP/Server 2003/Vista and vice versa.
• Selecting a Profile does not change the [Page Size] setting.
Using the Printing Functions
4-47
4
Printing a Document
Profiles make it possible to save or import all the printing preferences specified in
the [Page Setup], [Finishing], [Paper Source], and [Quality] sheets at once. It is also
possible to add, edit and choose between profiles.
Adding a Profile
1
2
Configure the printer settings that you want to register using
each of the [Page Setup], [Finishing], [Paper Source], and
[Quality] sheets.
Click [
] (Add Profile).
Printing a Document
4
The [Add Profile] dialog box is displayed.
3
Enter the name of the Profile in the [Name] field.
You can select an icon for the profile using the [Icon] setting. If you have any
notes you want to make about the profile, enter them in the [Comment] field.
NOTE
You can enter up to 31 characters in the [Name] field and 255 characters in the
[Comment] field.
4-48
Using the Printing Functions
● Confirming the Printer Settings
❑ Click [View Settings].
❑ Click [OK] to return to the [Add Profile] dialog box.
Printing a Document
4
4
Click [OK].
The Properties dialog box reappears.
Check that the name of the Profile has been added to the [Profile] list.
Using the Printing Functions
4-49
Editing/Deleting a Profile
You can change or save Profile information or delete it from the [Profile List].
1
Click [
] (Edit Profile).
Printing a Document
4
The [Edit Profile] dialog box is displayed.
2
4-50
Edit the Profile information.
Using the Printing Functions
● Editing a Profile
❑ You can change the [Name], [Icon], and [Comment] settings.
❑ You can change the order of the selected profile by clicking [
] and [
].
❑ When [Import] is clicked, the Profile information is imported from the previously
saved file.
❑ Click [Export] to save the data from the currently selected profile to a file. If you
save a profile to disk, you will be able to use it again even after you delete it
from the list of profiles.
❑ If the [Apply Settings from Application] checkbox is ticked, the [Page Size],
[Orientation] and [Copies] selected in the application will be used for printing.
Even if you change these settings in the profile, the values from the application
will still be used.
● Deleting a Profile
IMPORTANT
You can only delete custom profiles. The pre-installed default profiles cannot be
deleted. You are also unable to delete a profile if it is currently selected on any of
the property sheets.
Using the Printing Functions
4-51
Printing a Document
4
❑ Click [Delete] to delete a profile from the list.
Editing Print Jobs
PageComposer allows you to combine 2 or more print jobs into a single job for
printing, or modify the printer settings of combined jobs for printing. You can also
edit jobs from different applications and preview print jobs.
Make sure that any one of the [Page Setup], [Finishing], [Paper Source], or [Quality]
sheet is displayed in the [Document Properties] dialog box, then perform the
following procedure:
1
Set the [Output Method] to [Edit and Preview].
Printing a Document
4
2
4-52
The message that the output method is going to be switched
to the [Edit and Preview] mode is displayed. Click [OK].
Using the Printing Functions
3
Specify the printing preferences in each sheet, then click
[OK].
The [Print] dialog box reappears.
4
Click [OK].
Click on the [Print] button depending on the application software that you are
using.
The [Canon PageComposer] dialog box is displayed and the job is displayed on
a list.
5
6
Repeat Step 1 to 4 for each of the jobs that you want to edit.
In the [Canon PageComposer] dialog box, you can edit the
jobs in the list.
NOTE
• For details on adjusting settings in the [Canon PageComposer] dialog box,
refer to the Canon PageComposer online help.
• If you select [Edit and Preview] mode in the [Printer Properties] dialog box and
select [ ] (Lock), the [Canon PageComposer] dialog box will appear every time
you print.
Using the Printing Functions
4-53
Printing a Document
4
Viewing Printer Settings/Restoring the Default Settings
You can view a summary of the printing preferences specified in the [Page Setup],
[Finishing], [Paper Source], [Quality], and [Configuration]/[Device Settings] sheets,
or restore the settings to their default values.
Make sure that any one of the [Page Setup], [Finishing], [Paper Source] and
[Quality] sheets is displayed, then perform the following procedure.
NOTE
A preview is displayed on each sheet. You can use the preview to verify the printed
image.
Viewing Printer Settings
4
Printing a Document
1
Click [View Settings].
The [View Settings] dialog box is displayed.
4-54
Using the Printing Functions
You can click on the [Page Setup], [Finishing], [Paper Source], [Quality], or
[Configuration]/[Device Settings] tabs to view a list of printing preferences for
each sheet.
2
Click [OK].
The previous sheet reappears.
Restoring the Default Settings
Click [Restore Defaults] to restore the printer settings to their default values.
The [Restore Defaults] button only restores to default the settings that are displayed
on the same sheet or dialog box as the button.
The settings in the [Page Setup], [Finishing], [Paper Source], [Quality] and
[Configuration]/[Device Settings] sheets cannot be restored all at once to the
default settings.
Using the Printing Functions
4-55
Printing a Document
4
Manuals
This section describes the procedures for installing or uninstalling the manuals
included on the CD-ROM supplied with the printer on the computer you are using.
Installing the Manuals
Install the manuals in the CD-ROM supplied with the printer on the computer using
the following procedure.
4
Printing a Document
1
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If the CD-ROM is already in the drive, eject the disk and re-insert it into the drive.
IMPORTANT
• If you are using Windows Vista and the [AutoPlay] dialog box appears, click [Run
AUTORUN.EXE].
• If CD-ROM Setup does not appear, display it using the following procedures. (The
CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name
may differ depending on the computer you are using.)
- If you are using an operating system other than Windows Vista, select [Run] from
the [Start] menu, enter "D:\English\MInst.exe", and then click [OK].
- If you are using Windows Vista, enter "D:\English\MInst.exe" in [Start Search]
under the [Start] menu, and then press the [ENTER] key on your keyboard.
NOTE
If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Allow].
4-56
Manuals
Click [Custom Installation].
3
Clear the [Printer Driver] check box, then click [Install].
4
Confirm the contents, then click [Yes].
4
Printing a Document
2
Installation of the instruction manuals starts.
Manuals
4-57
5
When screen for completing the installation appears, click
[Next].
4
Printing a Document
6
Click [Exit].
The installation of the manuals is completed.
To see the manuals, double-click [LBP3000 Online Manuals] created on the
desktop to display respective manuals or select [Canon LBP3000] - [LBP3000
Online Manuals] added to [All Programs] ([Programs] for Windows 98/Me/2000)
under the [Start] menu.
4-58
Manuals
Uninstalling the Manuals
The installed manuals can also be uninstalled by uninstalling the CAPT software
using the Uninstaller. For details on uninstalling the CAPT software, see
"Uninstalling the CAPT software," on p. 3-75.
When uninstalling only the manuals without uninstalling the CAPT software, delete
the following.
• "\Program
IMPORTANT
If the manuals are installed on Windows 2000/XP/Server 2003/Vista logged on by a user
who is a member of Administrators, they cannot be uninstalled from the computer logged
on by anyone other than users who are members of Administrators. Be sure to log on as
a member of Administrators before the uninstallation.
NOTE
If you are using Windows Vista and the [Destination Folder Access Denied] dialog box
appears, click [Continue]. (If the [User Account Control] dialog box appears, click
[Continue].)
Manuals
4-59
4
Printing a Document
Files\Canon\LBP3000"
- "Manuals" folder
• Right-click [Canon LBP3000] in [All Programs] ([Programs] for Windows 98/Me/
2000) under the [Start] menu, then select [Delete] from the pop-up menu.
• Desktop
- [LBP3000 Online Manuals] (Shortcut for [Index.pdf])
Printer Status Window
The Printer Status Window shows status information about the LBP3000 (such as
operating status and job information) using messages, animations, sounds, and
icons.
NOTE
In order to use the sounds, your computer must be equipped with a PCM synthesizer,
and have the driver for the PCM synthesizer installed.
Printing a Document
4
4-60
Printer Status Window
Using the Printer Status Window
The functionality of the Printer Status Window is the same on both Windows 98/Me
and Windows 2000/XP/Server 2003/Vista.
Refer to the online help for more details on using the Printer Status Window.
Menu Bar
Refresh Button
Icon
Message Area
Message Area (Auxiliary)
Animation Area
Resolve Error Button
Printing a Document
4
Status Bar
■ [Current Print Job] Tab
Job Information Area
■ [My Job Operation] Tab
[Pause Job] Button
Job Information Area
Progress Bar
Job Operation Buttons
Job Status Message Area
■ Menu Bar
[Job] Menu
Used to pause, resume and cancel print jobs. If a job is paused for
some reason, you can resume the job by selecting [Resolve Error].
The buttons appears grayed out if you do not have access
permissions to the current print job.
[Options] Menu
Allows you to change the preferences for the Printer Status Window,
and clean the fixing rollers on the printer.
[Help] Menu
Displays the online help.
Printer Status Window
4-61
■ Other Functions
Icon
Displays an icon representing the current printer status.
Message Area
Displays the current printer status using a short message.
Message Area (Auxiliary)
Displays additional information when an error occurs, etc.
Animation Area
Displays a graphical representation of the current printer status. The
background color is normally blue, but changes to orange when the
printer requires some kind of attention, and to red during a warning.
Refresh Button
Obtains the current printer status and refreshes the Printer Status
Window display.
Resolve Error Button
Allows you to resume a job when the job is paused for some reason.
[Current Print Job] Tab
Progress Bar:
Indicates the progress of the current job by showing the number of
pages printed and changing the background color.
[Pause Job] Button:
Pauses the job temporarily.
4
Printing a Document
Job Information Area:
Displays the document name, user name, and computer name for the
job.
[My Job Operation] Tab
Job Status Message Area:
Displays a message about the status of the job.
Job Operation Buttons:
Used to pause, resume and cancel print jobs. The buttons appears
grayed out if you do not have access permissions to the current print
job.
Job Information Area:
Displays the [Document Name], [User Name], [Computer Name], and
status of the job.
Status Bar
4-62
Printer Status Window
Indicates how the printer is connected (Local or Network).
Descriptions of each of the menu items are displayed here as you
navigate through the menus.
Displaying the Printer Status Window
The Printer Status Window can be opened in the following two ways.
• Click
[
] (Display Printer Status Window) in locations such as the [Page
Setup] sheet in the [Printer Properties] dialog box.
• Check
the [Show Icon in the Taskbar] box in the [Configuration]/[Device Settings]
sheet in the [Printer Properties] dialog box. A Printer Status Window icon is then
shown in the Windows Taskbar, and you can click on this icon, then click [Canon
LBP3000] to open the window.
Printer Status Window
4-63
Printing a Document
4
The Printer Status Window is automatically displayed during printing and if an error
occurs. If [Display Printer Status Window] is not set to [When Starting Printing] in
the [Preferences] of the [Options] menu in the Printer Status Window, the Printer
Status Window will not be displayed during printing. (See "Setting Preferences," on
p. 4-64.)
The Options Menu
This menu allows you to change the preferences for the Printer Status Window and
clean the fixing rollers on the printer.
Setting Preferences
The Preferences menu item allows you to display the Printer Status Window
automatically, specify the sound settings, and make the Printer Status Window
monitor the printer status.
Printing a Document
4
■ [Display Printer Status Window] Group
• When Starting Printing (Default Value)
The Printer Status Window appears automatically each time printing starts.
• Only when Errors Occur
The Printer Status Window appears automatically only when an error occurs during
printing.
• Not Display Automatically
The Printer Status Window will not automatically appear, even if printing starts or an
error occurs.
• Always Display on Top
The Printer Status Window is always on top of all the other windows on the desktop.
■ [Monitor Printer Status] Group
• Only while Displaying Printer Status Window (Default Value)
The Printer Status Window monitors the printer status only while it is displayed.
• Only while Printing
The Printer Status Window only monitors the printer status during printing.
• Always
The Printer Status Window always monitors the printer status.
■ [Tone Settings] Group
• Enabled All (Default Value)
A sound is played whenever a message is displayed.
• Enable only when Error Occurs
A sound is played only when an error occurs.
• Disabled
No sounds are played.
4-64
Printer Status Window
1
Select [Preferences] from the [Options] menu.
Printing a Document
4
The [Preferences] dialog box is displayed.
2
Confirm the settings, then click [OK].
NOTE
For detailed information on using the Printer Status Window, refer to the online
help.
Printer Status Window
4-65
[Cleaning]
You should clean the printer whenever you replace the toner cartridge or when you
see black spots appearing on the front or back of the paper. Refer to "Cleaning," on
p. 5-14 for more details.
[Refresh]
Selecting [Refresh] from the [Options] menu obtains the latest printer status and
refreshes the Printer Status Window display.
You can also refresh the display by clicking [
Window.
] (Refresh) in the Printer Status
[Resolve Error]
4
Printing a Document
If a job is paused for some reason, you can resume the job by selecting [Resolve
Error] from the [Job] menu. However, resuming a job by selecting [Resolve Error]
may cause unexpected print results. You cannot use [Resolve Error] in any of the
following circumstances:
• When
the job is paused due to printer errors such as paper jams or paper-out
• When another user's job is paused ([Resolve Error] is available in the print server
if the printer is shared on a network)
You can perform the same action by clicking [
] (Resolve Error) in the Printer
Status Window.
IMPORTANT
If a message that says "Insufficient Disk Space" is displayed, delete any unnecessary
files, then select [Resolve Error].
4-66
Printer Status Window
Displaying Printer Status When Using a Print Server
The status of a network printer can be displayed on the client's Printer Status
Window as well as on the print server's.
If the print server is not started yet, the Printer Status Window is not displayed on
the client computer.
• Printer
Status at the Print Server
- Printer Status Window Display and Job Operation
[My Job Operation] Tab
Job
Information
Area
Job
Information
Area
Displays the
first job
[Pause
Job]
Button
Enabled*1
Displays the
first job*2
Job
Operation
Buttons
Enabled
Job Operation
4
Pause Job:
Pauses all the jobs
Resume Job:
Resumes all the jobs
Delete Job:
Deletes the first job
*1: The [My Job Operation] tab is displayed when you click the [Pause Job] button.
*2: If a job has been printed from the print server, that job is displayed.
- Plays sounds.
- If the print server is running on Windows 2000/XP/Server 2003/Vista, the status
is not displayed when no one is logged on. (You still can print now.)
• Printer Status at the Client
- Printer Status Window Display and Job Operation
[Current Print Job] Tab
Job
Information
Area
Displays the
first job in the
print server
[Pause Job] Button
When your job is
displayed in Job
Information Area:
Enabled*
When another
user's job is
displayed in Job
Information Area:
Disabled
[My Job Operation] Tab
Job
Information
Area
Displays your
first job
Job
Operation
Buttons
Enabled
Job Operation
Pause Job:
Pauses all your
jobs
Resume Job:
Resumes all your
jobs
Delete Job:
Deletes your first
job
*: The [My Job Operation] tab is displayed when you click the [Pause Job] button.
Printer Status Window
4-67
Printing a Document
[Current Print Job] Tab
- You cannot use the [
] (Resolve Error) button when another user's job is
paused.
- While another user's job is being printed, the progress bar is displayed in gray.
- Sounds are only played on the clients that match the user name.
NOTE
To display the printer status when printing a job over the network, a network environment
that uses one of the following protocols is required.
- TCP/IP
- NetBEUI
The printer status cannot be displayed only if you are using the IPX/SPX protocol.
Printing a Document
4
4-68
Printer Status Window
Routine Maintenance
5
CHAPTER
This chapter describes the procedures for maintaining the printer such as replacing the toner
cartridge and taking care of the printer.
Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Before Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-14
Precautions for Handling the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-16
Storing Toner Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-18
Clean the outside of the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Moving the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
Moving the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-22
Handling the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
Precautions for Handling the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-27
Precautions for Storing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-28
5-1
Replacing the Toner Cartridge
This section describes how to replace and handle the toner cartridge and
precautions on storing it.
Contact the store where you purchased the printer to obtain replacement toner
cartridges.
IMPORTANT
Even when the toner cartridge is nearing the end of its life, there are no messages
displayed on the computer. If white stripes appear lengthways along the paper, or if the
printed text becomes faint or patchy, you may need to replace the toner cartridge. When
replacing toner cartridges, only use toner cartridges that are specifically designed for this
printer.
5
Routine Maintenance
NOTE
The lifetime of the toner cartridges for this printer (Canon Genuine Parts) is
approximately 2000 sheets of A4 prints. This page count is for standard printing (page
coverage: approx. 5%, print density: factory default setting). The level of toner
consumption varies depending on the type and content of documents printed. Because
documents that contain few areas of white space, such as figures, tables and graphs,
consume larger amounts of toner, toner cartridge life will be reduced if you print large
amounts of this kind of document.
Before Replacing the Toner Cartridge
Toner cartridges are consumable parts. If there is not enough toner in the toner
cartridge, white stripes will appear lengthways on the paper and printed text will
appear faint or patchy. If you experience any of these symptoms, try the following
actions before replacing the toner cartridge. This may allow you to print for a while
longer until the toner is completely spent.
CAUTION
Be careful to avoid staining your clothes or hands with toner. If you do get any
toner on your clothes or hands, wash it off immediately with cold water. If you
rinse using hot water the toner may become fixed, creating a stain that cannot
be removed.
5-2
Replacing the Toner Cartridge
IMPORTANT
Never touch any of the high voltage parts inside the top cover. Doing so may damage the
printer.
High Voltage Electrical
Contacts
1
Routine Maintenance
5
Open the top cover.
Grasp the groove on the right side of the top cover and open the cover until it
stops.
Replacing the Toner Cartridge
5-3
2
Lift the toner cartridge in the direction of the arrows a, then
pull it out b.
a
Routine Maintenance
5
b
IMPORTANT
• If you touch the inner drum with your hand or scratch it, the printing quality will be
degraded. Do not touch or open the protective shutter of the drum under any
circumstances. Be careful not to hold or touch any parts other than as directed.
Doing so may damage the toner cartridge.
Drum Protective Shutter
5-4
Replacing the Toner Cartridge
• Do not expose the toner cartridge to direct sunlight or strong light.
Hold the toner cartridge as shown in the figure, and roll it
gently from side to side 5 or 6 times to evenly distribute the
toner inside.
Be careful not to spill the toner.
5
IMPORTANT
• If toner is not distributed evenly, the printing quality may be reduced. Make sure
you perform this step.
• Rotate the toner cartridge gently. If you do not rotate the cartridge gently, toner may
spill out.
• Be careful not to hold or touch sensitive areas such as the sensor or electrical
contacts. Doing so may damage the toner cartridge.
Electrical
Contacts
Electrical
Contacts
Replacing the Toner Cartridge
5-5
Routine Maintenance
3
4
Align the protrusions on the left and right ends of the toner
cartridge with the toner cartridge guides in the main printer,
and push the cartridge all the way to the back a, then pull it
down towards you b.
a
Routine Maintenance
5
b
5-6
Replacing the Toner Cartridge
Close the top cover.
IMPORTANT
• If you cannot close the top cover, check that the toner cartridge is installed properly
in the printer. If you close the top cover forcefully, the printer may be damaged.
• Do not leave the top cover open for a long time after installing the toner cartridge.
If the printing remains patchy even after following these steps, you should replace the
toner cartridge with a new cartridge.
Replacing the Toner Cartridge
Use the following procedure to replace the toner cartridge with a new cartridge.
You should clean the printer after you replace the toner cartridge. Refer to
"Cleaning," on p. 5-14 for details on cleaning the printer.
WARNING
Do not put spent toner cartridges into a fire. Any toner remaining in the toner
cartridge may ignite, causing burns or fire.
CAUTION
Be careful to avoid staining your clothes or hands with toner. If you do get any
toner on your clothes or hands, wash it off immediately with cold water. If you
rinse using hot water the toner may become fixed, creating a stain that cannot
be removed.
IMPORTANT
• Only use the toner cartridge designed for this printer.
Replacing the Toner Cartridge
5-7
5
Routine Maintenance
5
• Never touch any of the high voltage parts inside the top cover. Doing so may damage the
printer.
High Voltage Electrical
Contacts
5
Routine Maintenance
1
Open the top cover.
Grasp the groove on the right side of the top cover and open the cover until it
stops.
5-8
Replacing the Toner Cartridge
2
Lift the toner cartridge in the direction of the arrows a, then
pull it out b.
a
Routine Maintenance
5
b
3
Take the new toner cartridge out of the protective bag.
As there is a notch cut into the protective bag near the arrow, you can tear open
the bag by hand. However, if you are unable to tear open the bag by hand, you
should use scissors to cut the bag open to avoid damaging the toner cartridge.
Replacing the Toner Cartridge
5-9
IMPORTANT
• Do not throw away the toner cartridge protective bag. You will need this cover when
you remove the toner cartridge for printer maintenance, etc.
• If you touch the inner drum with your hand or scratch it, the printing quality will be
degraded. Do not touch or open the protective shutter of the drum under any
circumstances. Be careful not to hold or touch any parts other than as directed.
Doing so may damage the toner cartridge.
Drum Protective Shutter
• Do not expose the toner cartridge to direct sunlight or strong light.
Routine Maintenance
5
4
Hold the toner cartridge as shown in the figure, and roll it
gently from side to side 5 or 6 times to evenly distribute the
toner inside.
IMPORTANT
• If the toner is not distributed evenly, you may get poor printing quality. Make sure
you perform this step.
• Rotate the toner cartridge gently. If you do not rotate the cartridge gently, toner may
spill out.
5-10
Replacing the Toner Cartridge
• Be careful not to hold or touch sensitive areas such as the sensor or electrical
contacts. Doing so may damage the toner cartridge.
Electrical
Contacts
Electrical
Contacts
Place the toner cartridge on a flat surface, then slowly pull out
the sealing tape (approx. 50 cm in length) while supporting
the toner cartridge.
Pull the sealing tape out directly in the direction of the arrow.
5
Routine Maintenance
5
CAUTION
If you pull on the sealing tape with excessive force or stop pulling midway,
toner may spray from the tape. If toner gets into your eyes or mouth, wash
it out immediately with cold water and consult a doctor.
IMPORTANT
• Do not bend the tape or pull it up or down. If you do, the sealing tape may break in
the middle, and you won't be able to fully remove it.
• Keep pulling on the tape until it is fully removed from the cartridge. If any sealing
tape is left inside the toner cartridge, you may experience printing problems.
Replacing the Toner Cartridge
5-11
• When pulling out the sealing tape, be careful not to hold the drum protective shutter
with your hands.
Drum Protective Shutter
• After removing the packing materials, install the toner cartridge in the printer as
soon as possible.
• Dispose of the sealing tape according to local regulations.
Routine Maintenance
5
5-12
Replacing the Toner Cartridge
Align the protrusions on the left and right ends of the toner
cartridge with the toner cartridge guides in the main printer,
and push the cartridge all the way to the back a, then pull it
down towards you b.
a
5
Routine Maintenance
6
b
Replacing the Toner Cartridge
5-13
7
IMPORTANT
• If you cannot close the top cover, check that the toner cartridge is installed properly
in the printer. If you close the top cover forcefully, the printer may be damaged.
• Do not leave the top cover open for a long time after installing the toner cartridge.
5
Routine Maintenance
Close the top cover.
You should now clean the printer. (See "Cleaning," on p. 5-14)
Cleaning
You should clean the printer after you replace the toner cartridge.
1
Load a sheet of A4 (or Letter) size white paper into the
multi-purpose tray or manual feed tray.
To load A4 (or Letter) size paper, refer to "Printing on Plain Paper, Heavy Paper,
Label Paper, and Transparencies," on p. 2-14.
5-14
Replacing the Toner Cartridge
2
Open the Printer Status Window.
Refer to "Displaying the Printer Status Window," on p. 4-63 for details on opening
the Printer Status Window.
3
Routine Maintenance
5
Select [Cleaning] from the [Options] menu.
Replacing the Toner Cartridge
5-15
4
Click [OK].
The message "Cleaning" appears in the Printer Status Window, and cleaning
begins.
Cleaning is finished when the paper ejects from the printer and the message
disappears.
NOTE
• Cleaning takes approximately 3 minutes.
• Cleaning cannot be interrupted. Wait until the cleaning is finished.
Precautions for Handling the Toner Cartridge
5
Routine Maintenance
The toner cartridge is constructed from precision mechanical parts. Handling the
cartridge roughly can damage it or cause deterioration of printing quality. Whenever
you are installing or removing toner cartridges, take care of the following handling
precautions.
WARNING
Do not put spent toner cartridges into a fire. Any toner remaining in the toner
cartridge may ignite, causing burns or fire.
CAUTION
Be careful to avoid staining your clothes or hands with toner. If you do get any
toner on your clothes or hands, wash it off immediately with cold water. If you
rinse using hot water the toner may become fixed, creating a stain that cannot
be removed.
5-16
Replacing the Toner Cartridge
IMPORTANT
• If you touch the inner drum with your hand or scratch it, the printing quality will be
degraded. Do not touch or open the protective shutter of the drum under any
circumstances. Be careful not to hold or touch any parts other than as directed. Doing so
may damage the toner cartridge.
Drum Protective Shutter
• Do not expose the toner cartridge to direct sunlight or strong light.
• Be careful not to hold or touch sensitive areas such as the sensor or electrical contacts.
Doing so may damage the toner cartridge.
Electrical
Contacts
Electrical
Contacts
• Whenever you are handling the toner cartridge, hold it as shown in the diagram, and
keep the surface marked with the arrow facing up. Do not stand it on its end, or turn it
upside down.
Replacing the Toner Cartridge
5-17
Routine Maintenance
5
• Do not attempt to disassemble or modify the toner cartridge.
• If you expose a toner cartridge to rapid changes in temperature, droplets of water
(condensation) may form on the interior and exterior of the cartridge. If a new toner
cartridge that has been stored in a cool location is going to be installed in a warm area,
leave the cartridge for at least one hour without opening the protective bag to allow the
cartridge to adjust to the surrounding temperature before opening the bag.
• Be sure to use new toner cartridges within the expiration date indicated on the package.
• Keep toner cartridges away from products that generate magnetic waves, such as the
computer or monitor.
• Toner cartridges are magnetic parts. Do not bring toner cartridges near floppy disks, disk
drives, or other magnetic-sensitive devices. Doing so may cause data corruption.
Storing Toner Cartridges
Be careful of the following points when storing a new toner cartridge or handling a
toner cartridge that has been taken out of the printer for maintenance or moving the
printer.
5
Routine Maintenance
IMPORTANT
• Do not take a new toner cartridge out of the protective bag until it is ready to be used.
• If you take the toner cartridge out of the printer to remove a paper jam or service the
printer, place the toner cartridge into the original protective bag, or wrap it in a thick cloth
immediately.
• Do not stand it on its end, or turn it upside down. Store the cartridge in the same direction
as when it is installed in the printer.
• Do not store the toner cartridge in a place exposed to direct sunlight.
• Do not store the toner cartridge in a hot or humid place, or a place where the
temperature and humidity can change significantly.
- Storage Temperature Range: 0 to 35°C (32 to 95°F)
- Storage Humidity Range: 35 to 85%RH (non-condensing)
• Do not store the toner cartridge in a place where corrosive gases, such as ammonia, are
generated, or where a considerable amount of salt is contained in the air, or where there
is a lot of dust.
• Keep toner cartridges out of the reach of small children.
• Do not store toner cartridges near floppy disks, disk drives, or other magnetic-sensitive
devices.
■ Condensation
Even when the humidity is within the storage range, water droplets may form on the inside
or outside of the toner cartridge due to temperature differences with the surrounding air.
This condensation will have a bad effect on the performance of the toner cartridge.
5-18
Replacing the Toner Cartridge
Clean the outside of the printer
If dirt and dust builds up on the outside of the main unit after you use the printer for
a long period of time, you should clean the printer. To avoid damage to the printer
and electrical shocks while cleaning, observe the following precautions when
cleaning.
WARNING
• Turn the printer off and remove the plug from the wall when you are cleaning the
printer. Failure to do so may cause fire or electrical shock.
• Do not use alcohol, benzene, thinners or any other inflammable substance. If an
inflammable substance comes into contact with the electrical unit inside the
printer it may ignite or cause an electrical shock.
1
Turn the printer and computer off a, remove the USB cable b,
and disconnect the power plug from the power outlet c.
b
a
c
a
Clean the outside of the printer
5-19
5
Routine Maintenance
IMPORTANT
• Be careful not to use a cleaning agent other than water or a mild detergent mixed with
water as it may deform or crack the plastic materials in the printer.
• When using a mild detergent, be sure to dilute it with water.
• This printer does not need to be lubricated. Do not lubricate the printer.
2
Firmly wring a soft cloth dampened with water or a mild
detergent diluted with water, and wipe off the dirt.
If you use a mild detergent for cleaning, be sure to wipe away the detergent with
a soft cloth dampened with water.
3
Routine Maintenance
5
4
5-20
After wiping off the dirt, wipe the printer with a dry cloth.
Once the printer is completely dry, plug the power plug into
the power outlet and reconnect the USB cable.
Clean the outside of the printer
Moving the Printer
When changing the location of the printer or moving the printer for maintenance, be
sure to use the following procedure.
WARNING
When you are moving the printer, always turn the printer off, unplug the power
plug, and remove the USB cable. If you move the printer without unplugging the
cables, the electrical cord and USB cable may be damaged, causing a fire or
electrical shock.
CAUTION
• The printer weighs approximately 6.3 kg when the tray cover is not installed.
Take care to carry the printer without hurting your back.
5
Routine Maintenance
• Never hold the printer by the front panel, ventilation slots, rear panel, or
anywhere else other than the specified locations. Doing so may cause the
printer to fall, resulting in personal injury.
Moving the Printer
5-21
Moving the Printer
Use the following procedure to move the printer.
1
Turn the printer and computer off a, remove the USB cable b,
and disconnect the power plug from the power outlet c.
b
a
c
5
Routine Maintenance
a
5-22
2
Remove the power cord.
3
Remove the tray cover.
Moving the Printer
Clear out any paper that is loaded in the printer, and push the
rear paper guide in to the position shown in the diagram.
IMPORTANT
If you try to close the multi-purpose tray while the rear paper guide is sticking out of
the tray, you may damage the printer. Always check to make sure that rear paper
guide is pushed all the way back into the multi-purpose tray before you close the
multi-purpose tray.
5
Close the multi-purpose tray.
Moving the Printer
5-23
5
Routine Maintenance
4
6
7
Grasp the left and right side of the printer with your hands, as
shown in the diagram, and firmly hold onto the printer when
you carry it.
Routine Maintenance
5
If the paper output tray is open, close it.
8
Put the printer down carefully at the installation site.
CAUTION
Put the printer down slowly and carefully. You may be injured if your
hands, etc. are pinched by the printer.
5-24
Moving the Printer
9
Open the output tray.
10 Open the multi-purpose tray.
Routine Maintenance
5
11 Load the Paper
Refer to "Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies,"
on p. 2-14 for information on loading plain paper, heavy paper, label paper and
transparencies.
Refer to "Printing on Index Card," on p. 2-27 for information on loading index
card.
Refer to "Printing on Envelopes," on p. 2-34 for information on loading envelopes.
Refer to "Printing on Custom Paper Sizes (Non-Standard Sizes)," on p. 2-45 for
information on loading custom paper sizes.
Moving the Printer
5-25
12 Attach the tray cover.
Attach the tray cover so that the protrusions on the left and right sides of the
cover fit into the grooves in the main body.
Protrusion
Groove
Tray cover
Routine Maintenance
5
13 Connect the power cord.
14 Plug the power plug into the AC power outlet.
15 Connect the USB cable.
● Transporting the Printer
When transporting the printer for reasons such as relocating, remove the toner
cartridge and store the printer and parts in the packages that they came in with
the protective materials attached in order to prevent them from being damaged
while being transported.
If the original package and packing materials are not available, find an
appropriate box and packing materials and pack the printer and the parts
appropriately.
5-26
Moving the Printer
Handling the Printer
This printer uses a variety of electronic components and delicate optical
components. Read the following section carefully, and take care when handling the
printer.
IMPORTANT
Information on handling the printer is also described in "Important Safety Instructions,"
on p. xiv.
Precautions for Handling the Printer
Observe the following precautions to allow your printer to consistently produce
high-quality printing.
IMPORTANT
• Do not place any heavy objects on top of the printer, output tray, tray cover, or other part
of the printer. Doing so may damage the printer.
• If you try to close the multi-purpose tray while the rear paper guide is sticking out of the
tray, you may damage the printer. Always check to make sure that rear paper guide is
pushed all the way back into the multi-purpose tray before you close the multi-purpose
tray.
• Do not leave the top cover open for any longer than you need to. Exposure to direct
sunlight or strong light can degrade the printer performance.
Handling the Printer
5-27
Routine Maintenance
5
• Do not shake the printer while it is printing. Doing so may cause the print quality to
deteriorate.
• Do not open the top cover of the printing while it is printing. Doing so may damage the
printer.
• Open and close the output tray, multi-purpose tray, and the top cover of the printer gently.
The printer may be damaged if you are rough.
• If you want to spread a blanket on the printer to prevent dust from entering the printer,
turn the power off and allow the printer to cool down sufficiently before covering the
printer.
• If you do not plan to use the printer for a long period of time, unplug the power cord from
the AC power outlet.
• Do not use or store the printer in a room where chemicals are used.
• The area around the output tray becomes very hot during printing and directly after
printing. When you are collecting paper from the output tray or clearing a paper jam, be
careful not to touch the area around the output tray.
Routine Maintenance
5
Precautions for Storing the Printer
If you do not plan to use the printer for a long period of time, store it in the following
environment:
• Storage Temperature
• Storage
5-28
Range: 0 to 35°C (32 to 95°F)
Humidity Range: 10 to 80%RH (non-condensing).
Handling the Printer
Troubleshooting
6
CHAPTER
This chapter describes the remedies for problems such as paper jams or poor print quality.
Troubleshooting Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Paper Jams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Service Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
When a Fixing Unit Error Appears . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-19
When a Scanner Error or Service Error Appears . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-20
Print Quality Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Paper Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25
When Nothing Prints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Installation Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27
If Uninstallation Fails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-28
Uninstalling the USB Class Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-30
Problems During Local Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-34
Problems Installing a Shared Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-34
Miscellaneous Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36
6-1
Troubleshooting Map
If you have any problems while you are using the printer, use the flow chart shown
below to determine the cause of the problem.
The printer driver is not properly
installed
Yes
The printer
driver cannot be
used
➞Chapter 6: Installation Problems (p. 6-27)
No
The power cord is not connected
The power switch is off
Yes
Cannot Print
Troubleshooting
6
➞Chapter 1: Turning the Printer On and Off
(p. 1-15)
No
No
An error is
displayed in the Printer
Status Window
Yes
Follow the directions displayed in
the Printer Status Window to
resolve the problem
➞Chapter 4: Printer Status Window
(p. 4-60)
Yes
The toner density is set too
light
➞Chapter 4: Specifying the Print
Quality (p. 4-44)
No
The toner is running out
➞Chapter 5: Replacing the Toner
Cartridge (p. 5-2)
No
No
The installation environment is
bad
➞Getting Started Guide
No
Miscellaneous Problems
Paper Problems
➞Chapter 6: Paper Problems (p. 6-25)
6-2
➞Chapter 1: Connecting to a Computer
(p. 1-12)
No
No
The printing
quality is poor
The printer is not connected to the
computer
Troubleshooting Map
➞Chapter 6: Print Quality Problems
(p. 6-22)
The printer driver is not properly
installed
➞Chapter 6: Installation Problems (p. 6-27)
Paper Jams
The following message is displayed in the Printer Status Window when a paper jam
occurs during printing.
Troubleshooting
6
WARNING
There is a high-voltage unit inside this product. When you are clearing paper
jams or inspecting the interior of the printer, make sure that no necklaces,
bracelets, or other metallic objects come into contact with the inside of the
printer. If this does happen, it may cause burns or an electrical shock.
CAUTION
• Be careful to avoid staining your clothes or hands with toner while you are
clearing a paper jam. If you get any toner on your hands or clothes, wash it off
immediately with cold water. Do not rinse with hot water, as this can fix the
toner, creating a stain that cannot be removed.
• When you are clearing jammed paper from inside the printer, remove the paper
gently so that toner that is on the jammed paper does not spray out of the
printer. This could lead to toner getting in your eyes or mouth. If toner gets into
your eyes or mouth, wash it out immediately with cold water and consult a
doctor.
• When removing jammed paper, take care not to cut your hands with the edges
of the paper.
Paper Jams
6-3
• The area around the fixing unit inside the printer becomes hot during use. If you
are inspecting the inside of the printer while you are clearing a paper jam, etc.,
take care not to touch the area around the fixing unit. Doing so can cause burns.
• Keep your hands or clothing away from the roller in the output area after
removing jammed paper completely. Even if the printer is not printing, sudden
rotation of the roller may catch your hands or clothing, resulting in personal
injury.
IMPORTANT
• Never touch any of the high voltage parts inside the top cover. Doing so may damage the
printer.
High Voltage Electrical
Contacts
Troubleshooting
6
• If you tug too hard on jammed paper, the paper can tear and the internal components
may be damaged. When you pull out jammed paper, pull it out in the correct direction
depending on the location of the jam.
• If paper is torn, be sure to find and remove any remaining pieces of paper.
• If you clear the jammed paper without opening the top cover, the error message may not
clear. In this case, open and close the top cover once.
6-4
Paper Jams
• Do not touch the transfer roller under any circumstances. Doing so may cause the print
quality to deteriorate.
Transfer Roller
• Do not touch the paper feed roller under any circumstances. Doing so may cause the
paper feed mechanism to malfunction.
Paper Feed Roller
6
printing. When you are collecting paper from the output tray or clearing a paper jam, be
careful not to touch the area around the output tray.
Paper Jams
6-5
Troubleshooting
• The area around the output tray becomes very hot during printing and directly after
1
Open the top cover.
Grasp the groove on the right side of the top cover and open the cover until it
stops.
6
Troubleshooting
IMPORTANT
Even if you can see the jammed paper from the output tray, do not pull on the
paper. Make sure you open the top cover and remove the toner cartridge before
attempting to clear the jam.
6-6
Paper Jams
Lift the toner cartridge in the direction of the arrows a, then
pull it out b.
a
6
b
IMPORTANT
• If you touch the inner drum with your hand or scratch it, the printing quality will be
degraded. Do not touch or open the protective shutter of the drum under any
circumstances. Be careful not to hold or touch any parts other than as directed.
Doing so may damage the toner cartridge.
Drum Protective Shutter
Paper Jams
6-7
Troubleshooting
2
• Do not expose the toner cartridge to direct sunlight or strong light.
• Be careful not to hold or touch sensitive areas such as the sensor or electrical
contacts. Doing so may damage the printer.
Electrical
Contacts
Electrical
Contacts
6
Troubleshooting
3
6-8
Paper Jams
Place the toner cartridge into the protective bag.
Remove any paper from the multi-purpose tray.
Open the tray cover up to the position where it stops a, pull out the rear paper
guide b, and then remove the paper c.
a
b
6
c
Troubleshooting
4
IMPORTANT
Even if the paper is jammed in the multi-purpose tray, do not clear the jam, but
continue with the following steps.
Paper Jams
6-9
5
Removing the jammed paper.
● If you can see the leading edge of the paper inside the printer
❑ Gently pull the paper up to clear the jam.
❑ If the jam is difficult to clear, pull the paper out from the multi-purpose tray or
manual feed tray.
Troubleshooting
6
6-10
Paper Jams
IMPORTANT
If you are pulling jammed paper out from the multi-purpose tray or manual feed tray,
excess toner may stain the next sheet of paper that you print on.
● If you can see the tail edge of the paper inside the printer
❑ Hold the paper by both edges and slowly feed it downwards to clear the paper
out.
Troubleshooting
6
Paper Jams
6-11
❑ If the paper is difficult to pull out, pull on the leading edge of the paper as
shown in the diagram a, then remove the paper from the output tray side b.
a
b
Troubleshooting
6
IMPORTANT
If you are pulling jammed paper out from the output tray side, excess toner may
stain the next sheet of paper that you print on.
6-12
Paper Jams
● If you cannot see the leading edge or the tail edge of the paper
❑ Pull out the back end of the paper as shown in the diagram a, then hold the
paper by both edges and feed it slowly down to clear the paper out of the
printer b.
a
Troubleshooting
6
b
Paper Jams
6-13
❑ If the paper is difficult to pull out, pull on the leading edge of the paper as
shown in the diagram a, then remove the paper from the output tray side b.
a
b
Troubleshooting
6
IMPORTANT
If you are pulling jammed paper out from the output tray side, excess toner may
stain the next sheet of paper that you print on.
6-14
Paper Jams
6
Load the paper so that the paper meets the rear paper guide
a, then close the tray cover b.
b
a
If the paper jam occurred while feeding from the manual feed tray, load paper into
the manual feed tray.
Take the toner cartridge out of the protective bag.
6
Troubleshooting
7
Paper Jams
6-15
8
Align the protrusions on the left and right ends of the toner
cartridge with the toner cartridge guides in the main printer,
and push the cartridge all the way to the back a, then pull it
down towards you b.
a
Troubleshooting
6
b
6-16
Paper Jams
Close the top cover.
IMPORTANT
• If you cannot close the top cover, check that the toner cartridge is installed properly
in the printer. If you close the top cover forcefully, the printer may be damaged.
• Do not leave the top cover open for a long time after installing the toner cartridge.
6
Troubleshooting
9
Paper Jams
6-17
Service Call
If the printer has some kind of error such that it can no longer function properly, a
service call is displayed as follows.
Service Call
Cause
Resolution
The fixing unit is
malfunctioning.
Follow the procedure (see "When
a Fixing Unit Error Appears," on
p. 6-19) and contact the store
where you purchased the printer.
The scanner is
malfunctioning.
Follow the procedure (see "When
a Scanner Error or Service Error
Appears," on p. 6-20), then turn
the power off and on.
Troubleshooting
6
6-18
Service Call
Service Call
Cause
Resolution
Follow the procedure (see "When
a Scanner Error or Service Error
Appears," on p. 6-20), then turn
the power off and on.
The printer is
malfunctioning.
When a Fixing Unit Error Appears
If a fixing unit error is displayed, follow the procedure below then contact the store
where you purchased the printer.
6
Turn the printer and computer off a, remove the USB cable b,
and disconnect the power plug from the power outlet c.
b
a
c
a
IMPORTANT
If a fixing unit error appears, do not turn the printer on again after you have turned
it off.
2
Contact your local authorized Canon dealer.
Describe the problems you are experiencing when you contact the dealer.
Service Call
6-19
Troubleshooting
1
When a Scanner Error or Service Error Appears
If a scanner error or service error appears, cycle the power of the printer using the
following procedure. This may clear the message.
1
Turn the power off, wait for at least 10 seconds, then turn the
printer on again.
OFF
ON
6
Troubleshooting
If the message does not reappear, continue using the printer as normal. If the
message reappears, proceed to the next step.
2
6-20
Service Call
Note down the error code displayed in the Printer Status
Window.
3
Turn the printer and computer off a, remove the USB cable b,
and disconnect the power plug from the power outlet c.
b
a
c
a
Contact your local authorized Canon dealer.
When you contact your Canon dealer, please describe the problems that
occurred and the error code that you noted down.
6
Troubleshooting
4
Service Call
6-21
Print Quality Problems
If any problem occurs while you are using the printer, take the following measures
depending on the symptoms.
IMPORTANT
• If a message appears in the Printer Status Window, follow the directions given in the
message.
• In the case of a paper jam, refer to "Paper Jams," on p. 6-3.
• If a problem occurs that is not described in this section, none of the remedies solve the
problem, or you cannot determine the cause of the problem, contact your local
authorized Canon dealer.
White Stripes Appear. (Printed Text is Faint or Patchy)
Troubleshooting
6
Cause
The toner cartridge is running out of toner.
Remedy
Remove the toner cartridge and gentle rock it from side to side 5 or 6 times,
then reinsert the cartridge. If the same problem persists, replace the toner
cartridge with a new cartridge. (See "Replacing the Toner Cartridge," on p. 5-2.)
The overall printing is faint.
Cause 1
The [Toner Density] setting is not appropriate.
Remedy
Drag the [Toner Density] slider in the printer driver toward [Dark].
In order to change the [Toner Density] setting, click the [Details] button in the
[Quality] sheet to open the [Detailed Settings] dialog box.
Cause 2
[Use Toner Save] is selected.
Remedy
Remove the checkmark from [Use Toner Save] in the printer driver.
In order to change the [Use Toner Save] setting, click the [Details] button in the
[Quality] sheet to open the [Detailed Settings] dialog box.
The overall printing is dark.
6-22
Cause 1
The [Toner Density] setting is not appropriate.
Remedy
Drag the [Toner Density] slider in the printer driver toward [Light].
In order to change the [Toner Density] setting, click the [Details] button in the
[Quality] sheet to open the [Detailed Settings] dialog box.
Print Quality Problems
Cause 2
The printer is exposed to direct sunlight or strong light.
Remedy
Move the printer to a location that is not exposed to direct sunlight or strong
light. Alternatively, separate the printer from the source of the strong light.
One portion of a page does not print.
Cause 1
The scale factor is incorrect.
Remedy 1 Clear the checkmark from [Manual Scaling] in the printer driver. When this
checkbox is cleared, the scaling factor is automatically determined based on the
[Page Size] and [Output Size] settings.
In order to update the [Manual Scaling] setting, open the [Page Setup] sheet.
Remedy 2 Place a checkmark next to [Manual Scaling] in the printer driver and specify an
appropriate scale factor according to the paper size you are using.
In order to update the [Manual Scaling] setting, open the [Page Setup] sheet.
The paper is loaded in the wrong position.
Remedy
Load the paper properly. (See "Printing on Plain Paper, Heavy Paper, Label
Paper, and Transparencies," on p. 2-14, "Printing on Index Card," on p. 2-27,
"Printing on Envelopes," on p. 2-34, "Printing on Custom Paper Sizes
(Non-Standard Sizes)," on p. 2-45)
Cause 3
Data was printed from an application with the margin settings set outside the
printable area of the printer.
Remedy
The printable area of the printer is bounded by margins of 4 mm at the top,
6 mm at the bottom, and 5 mm on the left and right (for index card and
envelopes, the top, bottom, left and right margins are all 10 mm). Make sure you
have made sufficiently large margins in your data.
The front or back of printouts is stained with black dots.
Cause
The fixing unit is dirty
Remedy
Perform cleaning. (See "Cleaning," on p. 5-14.)
The printing position is misaligned.
Cause
The [Top Margin] and [Paper Position] settings in the application are configured
incorrectly.
Remedy
Update the [Top Margin] and [Paper Position] settings in the application. (See
Instruction manual for the application.)
Print Quality Problems
6-23
6
Troubleshooting
Cause 2
The next page is printed from halfway through the previous page.
Cause
The [Line Spacing] or [Lines/Page] settings in the application are not configured
correctly.
Remedy
Update the [Line Spacing] and [Lines/Page] in the application so that data fits
onto one page and print again. (See Instruction manual for the application.)
Nothing is printed on the paper.
Cause 1
The toner cartridge was installed with the sealing tape still attached.
Remedy
Remove the toner cartridge, pull away the sealing tape, and reinstall the
cartridge. (See "Replacing the Toner Cartridge," on p. 5-2)
Cause 2
Multiple sheets of paper are feeding at the same time.
Remedy
Thoroughly align the stack of paper and load it again. (See "Printing on Plain
Paper, Heavy Paper, Label Paper, and Transparencies," on p. 2-14, "Printing on
Index Card," on p. 2-27, "Printing on Envelopes," on p. 2-34, "Printing on
Custom Paper Sizes (Non-Standard Sizes)," on p. 2-45)
6
Troubleshooting
The paper comes out completely black.
Cause
The drum in the toner cartridge has deteriorated.
Remedy
Replace the toner cartridge with a new one. (See "Replacing the Toner
Cartridge," on p. 5-2.)
Printed pages have white specks.
6-24
Cause 1
The paper is inappropriate.
Remedy
Replace the paper with one of the usable paper types and print again. (See
"Paper Requirements," on p. 2-2.)
Cause 2
The paper is damp because it was stored in poor conditions.
Remedy
Replace the paper with new paper and print again.
Cause 3
The drum in the toner cartridge has deteriorated.
Remedy
Replace the toner cartridge with a new one. (See "Replacing the Toner
Cartridge," on p. 5-2.)
Print Quality Problems
Paper Problems
Paper comes out wrinkled.
Cause 1
Paper is loaded in the multi-purpose tray or manual feed tray at an angle.
Remedy
Load the paper in the multi-purpose tray or manual feed tray straight. (See
"Printing on Plain Paper, Heavy Paper, Label Paper, and Transparencies," on p.
2-14, "Printing on Index Card," on p. 2-27, "Printing on Envelopes," on p. 2-34,
"Printing on Custom Paper Sizes (Non-Standard Sizes)," on p. 2-45.)
Cause 2
The paper is damp.
Remedy
Replace the paper with paper from a new ream.
The paper curls.
The paper is inappropriate.
Remedy
Replace the paper with paper that can be used with this printer. (See "Paper
Requirements," on p. 2-2.)
Cause 2
The [Paper Type] setting does not match the loaded paper.
Remedy
Set the [Paper Type] in the printer driver to [Plain Paper L].
In order to change the [Paper Type] setting, open the [Paper Source] sheet.
White dust is attached to the printed transparencies.
Cause
You printed the transparencies just after continuously printing on another type
of paper.
Remedy
If you print transparencies after printing continuously on normal paper, paper
dust may adhere to the transparencies when they are output. If this is the case,
use a soft cloth to wipe off the paper dust.
Paper Problems
6-25
Troubleshooting
6
Cause 1
When Nothing Prints
Check the following items if nothing prints when you print from an application:
1
Check if any error messages are displayed in the Printer
Status Window.
If there is an error message displayed in the Printer Status Window, follow the
directions given in the message. If there are no error messages, proceed to the
next step.
2
Print a test page.
Click [Print Test Page] in the [General] sheet in the [Printer Properties] dialog box.
6
Troubleshooting
■ If the test page prints correctly
You can print from the CAPT software. To check the application software, check that all of
the printer settings are configured appropriately.
■ If the test page does not print
Uninstall the CAPT software, then reinstall it and print another test page. (See
"Uninstalling the CAPT software," on p. 3-75.)
6-26
When Nothing Prints
Installation Problems
If you cannot install the "USB Class Driver" and "LBP3000 Printer Driver" properly,
use the following procedure to check for problems.
[Canon Printer Uninstaller] is
1
displayed in [All Programs]*
under the [Start] menu.
No
➞Chapter 6: Uninstalling the USB
Class Driver (p. 6-30)
No
If you could
not uninstall
Yes
Reinstall the software
Delete [Canon LBP3000] in [Add
or Remove Programs]*2.
Uninstall using the uninstaller
➞Chapter 3: Uninstalling the CAPT
Software (p. 3-75)
➞Chapter 3: Installing the CAPT
Software (p. 3-4)
➞Chapter 6: If Uninstallation Fails
(p. 6-28)
6
Reinstall the software
Reinstall the software
➞Chapter 3: Installing the CAPT
Software (p. 3-4)
➞Chapter 3: Installing the CAPT
Software (p. 3-4)
If you could not
install the software
Troubleshooting
Yes
Uninstall the USB Class Driver
[Canon LBP3000] is displayed in
2
[Add or Remove Programs]* .
If you could not
install the software
Uninstall using the uninstaller
➞Chapter 3: Uninstalling the CAPT
Software (p. 3-75)
[Canon Printer Uninstaller] is
displayed in [All Programs]*1
under the [Start] menu.
No
[Canon LBP3000] is displayed in [Add
or Remove Programs]*2.
Yes
Yes
Uninstall using the uninstaller
➞Chapter 3: Uninstalling the CAPT
Software (p. 3-75)
If you
could not
uninstall
No
Delete [Canon LBP3000] in [Add
or Remove Programs]*2.
➞Chapter 6: If Uninstallation Fails
(p. 6-28)
Uninstall the USB Class Driver
➞Chapter 6: Uninstalling the USB
Class Driver (p. 6-30)
Reinstall the software
➞Chapter 3: Installing the CAPT
Software (p. 3-4)
*1 [Programs] for Windows 98/Me/2000
*2 [Add/Remove Programs Properties] for Windows 98/Me; [Add/Remove Programs] for Windows 2000; [Uninstall a
program] for Windows Vista
Installation Problems
6-27
If Uninstallation Fails
If you cannot uninstall the CAPT software using the uninstaller that was created
during installation, use the following procedure to uninstall the CAPT software.
1
From the [Start] menu, select [Control Panel], and then click
[Add or Remove Programs].
For Windows 98/Me/2000: From the [Start] menu, select [Settings] ➞ [Control
Panel], and then click [Add/Remove Programs].
For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[Uninstall a program].
2
Select [Canon LBP3000] in the [Add or Remove Programs]
dialog box, then click [Change/Remove].
For Windows 98/Me: Select [Canon LBP3000] in the [Add/Remove Programs]
dialog box, then click [Add/Remove].
For Windows 2000: Select [Canon LBP3000] in the [Add/Remove Programs]
dialog box, then click [Change/Remove].
For Windows Vista: Select [Canon LBP3000] in the [Programs and Features]
dialog box, then click [Uninstall/Change].
Troubleshooting
6
NOTE
• If [Canon LBP3000] is not displayed in the dialog box, perform "Uninstalling the
USB Class Driver" (See p. 6-30), and then install the CAPT software again.
• If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Continue].
6-28
Installation Problems
3
Select the name of your printer, then click [Delete].
4
Click [Yes].
6
5
Troubleshooting
The uninstallation process begins. Please wait a moment.
Click [Exit].
The [Delete Printer] dialog box closes.
6
Restart Windows.
Installation Problems
6-29
Uninstalling the USB Class Driver
Uninstalling the USB class driver is required when you cannot install the CAPT
software properly after uninstalling it once or when you cannot uninstall the CAPT
software.
1
2
Make sure that the computer is connected to the printer with
the USB cable and that the printer is turned on.
From the [Start] menu, select [Control Panel], and then click
[Add or Remove Programs].
For Windows 98/Me/2000: From the [Start] menu, select [Settings] ➞ [Control
Panel], and then click [Add/Remove Programs].
For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[Uninstall a program].
3
Troubleshooting
6
Make sure that [Canon LBP3000] does not appear in the [Add
or Remove Programs] dialog box, and then click [ ].
For Windows 98/Me/2000: Make sure that [Canon LBP3000] does not appear in
the [Add/Remove Programs] dialog box, and then click [ ].
For Windows Vista: Make sure that [Canon LBP3000] is not displayed in the
[Programs and Features] dialog box, and then click [
].
6-30
Installation Problems
NOTE
If [Canon LBP3000] is displayed in the dialog box, see "If Uninstallation Fails" (p.
6-28) and delete [Canon LBP3000] in the dialog box.
From the [Start] menu, select [Control Panel], and then click
[Performance and Maintenance] ➞ [System].
For Windows 98/Me/2000: From the [Start] menu, select [Settings] ➞ [Control
Panel], and then double-click the [System] icon.
For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞
[System].
For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[Hardware and Sound] ➞ [View hardware and devices].
6
Troubleshooting
4
NOTE
If you are using Windows Vista and the [User Account Control] dialog box appears,
click [Continue].
Installation Problems
6-31
5
Click [Hardware] ➞ [Device Manager], and then double-click
[Universal Serial Bus controllers].
For Windows 98/Me: Display the [System Properties] dialog box, click the
[Device Manager] tab, and then double-click [Universal Serial Bus controllers].
For Windows Vista: Double-click [Universal Serial Bus controllers].
6
Troubleshooting
6
Select [USB Printing Support], then select [Uninstall] in the
[Action] menu.
On Windows 98 select [Canon LBP3000]; and on Windows Me select [Canon
CAPT USB Device]; and then click [Remove].
6-32
Installation Problems
IMPORTANT
• You cannot install the printer driver properly if the USB class driver is listed under
[Other Devices]. Depending on your OS, select [Canon LBP3000], [Canon CAPT
USB Device] or [Unknown Device] and delete it.
• Do not delete any other devices or device drivers. If you delete the wrong thing by
mistake, Windows may not be able to startup properly.
• If the USB Class Driver is not installed properly, [USB Printing Support]
(on Windows 2000/XP/Server 2003/Vista), [Canon CAPT USB Device] (on
Windows Me), or [Canon LBP3000] (on Windows 98) will not be displayed.
7
When the [Confirm Device Removal] ([Confirm Device
Uninstall] for Windows Vista) dialog box appears, click [OK].
8
Click [
Troubleshooting
6
].
[Device Manager] closes.
9
Disconnect the USB cable from the computer, then restart
Windows.
After Windows restarts, reinstall the CAPT software. (See "Installing the CAPT
Software," on p. 3-4.)
Installation Problems
6-33
Problems During Local Installation
When you install the printer driver from CD-ROM, the printer is not automatically detected
even when it is turned on.
Troubleshooting
6
Cause 1
The USB cable has already been connected and the printer is turned on before
installing the printer driver.
Remedy
Turn the printer off then turn it back on again.
Cause 2
The printer is turned off.
Remedy
Turn the printer on.
Cause 3
The USB cable is not connected properly.
Remedy
Make sure that the printer and computer are connected properly with the USB
cable.
Cause 4
An inappropriate USB cable is being used.
Remedy
Use a USB cable that matches the USB interface on the printer. The USB
interface on this printer is USB 2.0 High-Speed (Windows 2000/XP/Server
2003/Vista only), USB Full-Speed (USB 1.1 equivalent).
Cause 5
You cannot install from CD-ROM Setup.
Remedy
Install using Plug and Play. (See "For Windows 98/Me," on p. 3-12, p. 3-21 or p.
3-28)
Problems Installing a Shared Printer
You cannot find the print server to connect to.
6-34
Cause 1
The print server has not been started up.
Remedy
Start up the print server.
Cause 2
The printer is not configured as a shared printer.
Remedy
Configure the printer as a shared printer using the [Printer Properties] dialog
box on the print server.
Cause 3
You do not have permissions to access the print server or printer.
Remedy
Ask your network administrator to change the user permissions.
Installation Problems
Cause 4
If you are using Windows Vista, [Network discovery] is not set to [On].
Remedy
Set [Network discovery] to [On].
To specify the setting for [Network discovery], select [Control Panel] from the
[Start] menu, click [View network status and tasks], and then display [Network
and Sharing Center].
Troubleshooting
6
Installation Problems
6-35
Miscellaneous Problems
The LBP3000 does not function properly.
Cause 1
The LBP3000 is not configured as the default printer.
Remedy
Set it to the default printer.
Cause 2
The CAPT software may not be installed properly.
Remedy
To check whether the CAPT software is installed correctly or not, try printing
from an application. If the printing does not work properly, uninstall the CAPT
software and then reinstall it (see "Uninstalling the CAPT software," on p. 3-75,
"Installing the CAPT Software," on p. 3-4).
Steam comes out of the surroundings of the output area of the printer.
Troubleshooting
6
Cause
Water contained in the paper evaporated by heat radiated when the toner is
fixing. (Particularly, this is apt to occur at low temperature.)
Remedy
Although the above phenomenon is not abnormal, you can prevent steam
radiation by replacing with new paper whose package is unopened.
Also, store paper so that it is not damp. (See "Storing Blank Paper," on p. 2-7)
WARNING
If you experience a burnt odor, immediately turn OFF the printer, unplug the
power plug from the AC power outlet, and then contact your local authorized
Canon dealer. Otherwise, this may result in a fire or electrical shock.
You cannot use Adobe Type Manager (ATM) Fonts.
6-36
Cause
You cannot use Adobe Type Manager (ATM) fonts with this printer
Remedy
Only use fonts that can be used with this printer.
Miscellaneous Problems
CD-ROM Setup does not appear automatically. (Windows 98/Me/Vista only)
Cause
CD-ROM Setup is not specified to appear automatically.
Remedy
For Windows 98/Me: Display the properties for the CD-ROM drive from [Device
Manager] and select [Auto insert notification] in the [Settings] sheet.
For Windows Vista: From [Control Panel], click [Play CDs or other media
automatically], select the [Use AutoPlay for all media and devices] check box,
and then set [Software and games] to [Install or run program].
The message [Specified Paper Incorrect] appears in the Printer Status Window.
The [Output Size] setting of the current print job is different from the [Output
Size] setting of the previous job.
Remedy
To print on the paper currently loaded in the printer, click [
] (Error
Recovery) in the Printer Status Window. To print on different paper than the
paper currently loaded in the printer, reload the new paper then click [
]
(Error Recovery) in the Printer Status Window.
Cause 2
[Detect Paper Size in Multi-purpose Tray] is selected.
Remedy
If you clear the checkmark from the [Detect Paper Size in Multi-purpose Tray]
checkbox, printing continues on the paper that is currently loaded in the printer
without displaying a message, regardless of the [Output Size] setting.
You can adjust the [Detect Paper Size in Multi-purpose Tray] setting in the
[Finishing Details] dialog box by clicking [Finishing Details] in the [Finishing]
sheet.
If you are using the printer sharing function on your computer, it takes a long time for the
Printer Status Window to obtain the printer status.
Cause
If you are using Windows XP Service Pack 2 or another operating system
equipped with Windows Firewall as a print server, communication with the client
computers is blocked by Windows Firewall.
Remedy
Start the print server and configure Windows Firewall to unblock
communications with the client computers. (See "Windows Firewall," on p. 7-8)
Miscellaneous Problems
6-37
6
Troubleshooting
Cause 1
When you are using the printer sharing function from the computer, the printer status does
not display correctly in the Printer Status Window.
Cause
The client computer is installed with an operating system equipped with
Windows Firewall, such as Windows XP Service Pack 2, and Windows Firewall
is blocking communication with the print server.
Remedy
Configure Windows Firewall to unblock communication with the server. (See
"Windows Firewall," on p. 7-8)
Troubleshooting
6
6-38
Miscellaneous Problems
Appendix
7
CHAPTER
This chapter describes the printer specifications and index.
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Hardware Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3
Printer Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Network Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-5
NetSpot Device Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Windows Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Configuring Windows Firewall to unblock communication with client computers . . . . . . . . . . . .7-9
Configuring Windows Firewall to block communication with client computers . . . . . . . . . . . . .7-11
Configuring Windows Firewall to unblock communication with the server . . . . . . . . . . . . . . . .7-12
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
Locating the Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
7-1
Specifications
Hardware Specifications
Type
Desktop Page Printer
Printing method
Electrophoto Method (On-demand fixing)
Print speed
Plain Paper (64 to 90 g/m2)
When printing A4 continuously
14 pages/min.
* The printing speed drops in steps depending on the
paper size, paper type, number of pages printed,
and fixing mode settings. (This is a safety feature
that prevents damage due to overheating.)
Warm-up time
0 seconds (10 seconds or less when the printer is on)
First print time
9.3 seconds or less (20°C (68°F), A4 size)
* Time from when print data is received.
Appendix
7
Multi-Purpose
Tray
A4, B5, A5, Legal, Letter, Executive, Envelope C5,
Envelope COM10, Envelope DL, Envelope Monarch,
Custom Paper Size (width 76.2 to 215.9 mm, height
127.0 to 355.6 mm)
Paper capacity: Approx. 150 sheets (64 g/m2)
Manual Feed
Tray
A4, B5, A5, Legal, Letter, Executive, Envelope C5,
Envelope COM10, Envelope DL, Envelope Monarch,
Index Card, Custom Paper Size (width 76.2 to
215.9 mm, height 127.0 to 355.6 mm)
Paper capacity: 1 sheet
Paper Sizes
Paper Output
Facedown
Output capacity
Output tray: Approx. 100 sheets (64 g/m2)
Lwad (declared A-weighted sound power level (1B =
10dB))
During standby:
Background noise level
Noise (Declared noise emission
During operation: 6.5 B or less
in accordance with ISO 9296)
Sound pressure level (Bystander position)
During standby:
Background noise level
During operation: 48 dB (A) or less
Operating environment
(Printer unit only)
7-2
Specifications
Operating environment temperature: 10 to 32.5°C (50
to 90.5°F)
Humidity: 20 to 80% RH (non-condensing)
Storage environment
(Printer unit only)
Storage Temperature Range: 0 to 35°C (32 to 95°F)
Humidity: 10 to 80% RH (non-condensing)
Host interface
Windows 98/Me: USB Full-Speed (USB1.1 equivalent)
Windows 2000/XP/Server 2003/Vista: USB 2.0
Hi-Speed/USB Full-Speed (USB1.1 equivalent)
Power
110 - 127 V (±10%) 50/60 Hz (±2 Hz)
220 - 240 V (±10%) 50/60 Hz (± 2 Hz)
Consumables Toner Cartridge
Weight
approx. 261W
approx. 2W
618W or less
220 - 240 V
Average during operation:
Average during standby:
Maximum:
approx. 259W
approx. 2W
726W or less
Printable pages: Approx. 2,000 pages*
* Canon genuine parts, and for A4 or Letter size paper
at 5% page coverage using the factory default print
density setting
Main Printer
Unit And
Included Parts
Main Printer Unit.................................Approx. 5.7 kg*
Toner Cartridge...................................Approx. 0.7 kg
* Excluding the toner cartridge
Consumables
Toner Cartridge
(Canon Genuine Parts).......................Approx. 0.7 kg
Software Specifications
Item
Specification
Printing software
CAPT (Canon Advanced Printing Technology)
Printable area
The area on the page excluding a 4 mm top margin, 6 mm
bottom margin, 5 mm left margin and 5 mm right margin
(for index card and envelopes, the top, bottom, left and
right margins are all 10 mm).
Specifications
7-3
7
Appendix
Power consumption
(at 20°C or 68°F)
110 - 127 V
Average during operation:
Average during standby:
Maximum:
Printer Dimensions
■ Printer
Front View
Front View
369.8
Multi-Purpose Tray
132
Appendix
7
7-4
Printer Dimensions
250.5
(mm)
216.7
63.9
281.1
Output Tray
(mm)
Optional Accessories
The LBP3000 can be used directly over a network by installing the optional network
adapter (AXIS1650).
For details on AXIS1650 and the supported operating systems, refer to the Axis
Communications website (http://www.axis.com)
Network Adapter
You can use the optional network adapter by connecting it to the LBP3000 using a
USB cable. The network adapter connects to the computers using peer to peer
networking. You can also connect to the printer via a print server.
Appendix
7
AXIS1650
Optional Accessories
7-5
LBP3000
TCP/IP
AXIS 1650
Client
Client
TCP/IP
LBP3000
AXIS 1650
Protocols that can be used
(i.e. TCP/IP, NetBEUI)
Print Server
7
Appendix
Client
Client
NOTE
• If you are using the network adapter, you should use the "NetSpot Device Installer" utility
software to initialize the default settings of the printer connected to the network.
• Refer to the instruction manual provided with the network adapter for details on the
network adapter.
• Contact the store where you purchased your LBP3000 for inquiries on purchasing the
network adapter.
7-6
Optional Accessories
NetSpot Device Installer
The supplied CD-ROM includes "NetSpot Device Installer", which is a utility that
initializes the settings of a printer connected to the network, as well as the printing
software (CAPT). The NetSpot Device Installer does not need to be installed on
your computer, but is simply used to initialize the network connection settings of the
printer.
For detailed information on the NetSpot Device Installer, refer to the users manual
included with the network adapter (AXIS 1650).
NOTE
Depending on the CD-ROM supplied, NetSpot Device Installer may not be included. If
NetSpot Device Installer is not included on the supplied CD-ROM, you can download it
from the Canon website.
Appendix
7
NetSpot Device Installer
7-7
Windows Firewall
Windows Firewall is a feature of Windows XP Service Pack 2 and other operating
systems that protects your computer by blocking unauthorized access over the
network.
If using the printer with an operating system equipped with Windows Firewall, you
need to set Windows Firewall to unblock communications.
You need to perform the following procedure on the print server (the computer that
is directly connected to the printer) and the clients (the computers that accesses
the printer via the network).
Setting
■ Installing the CAPT software from CD-ROM Setup:
Click [Yes] on the [Warning] dialog box that is displayed during
installation, and follow the instructions to configure Windows
Firewall to unblock communication with client computers.
Appendix
7
See
p. 3-5
Print server
■ When installing the CAPT Software from the [Printers and
Faxes] folder or the [Printers] folder/When installing the
p. 7-9
CAPT Software from [Windows Explorer]:
Use the [CAPT Windows Firewall Utility] to configure Windows
Firewall to unblock communication with client computers.
Clients
Configure Windows Firewall to unblock communication with the
print server.
p. 7-12
WARNING
If you want to copy the [CAPT Windows Firewall Utility] to your hard disk to run
it, copy all of the files (CNAB3FW.EXE, CAPTRGFW.DLL, CNAB3FW.INI) from the
[WF_UTIL] folder on the supplied "LBP3000 User Software" CD-ROM to your
hard disk.
7-8
Windows Firewall
Configuring Windows Firewall to unblock communication
with client computers
1
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If CD-ROM Setup appears, click [Exit].
If you are using Windows Vista and the [AutoPlay] dialog box appears, click
[Open folder to view files], and then proceed to Step 3.
2
3
From the [Start] menu, select [My Computer] ([Computer] for
Windows Vista), right-click the CD-ROM icon, and then select
[Open] from the pop-up menu.
Double-click [English], then [WF_UTIL], then [CNAB3FW.EXE].
The [CAPT Windows Firewall Utility] starts.
4
Click [Unblock].
Windows Firewall
7-9
7
Appendix
IMPORTANT
You can also run [CAPT Windows Firewall Utility] using the following procedures.
(The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive
name may differ depending on the computer you are using.)
- For an operating system other than Windows Vista: Select [Run] from the [Start]
menu, enter "D:\English\WF_UTIL\CNAB3FW.EXE", and then click [OK].
- For Windows Vista: Enter "D:\English\WF_UTIL\CNAB3FW.EXE" in [Start
Search] under the [Start] menu, and then press the [ENTER] key on your
keyboard.
NOTE
You cannot click [Unblock] if the firewall is already configured to unblock
communication with client computers.
5
Click [OK].
NOTE
To check if the Windows Firewall block has been properly cleared, use the following
procedure.
1. Display the [Windows Firewall] ([Windows Firewall Settings] for Windows
Vista) dialog box.
- For Windows XP: From the [Start] menu, select [Control Panel], and then click
[Network and Internet Connections] ➞ [Windows Firewall].
- For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞
[Windows Firewall].
- For Windows Vista: From the [Start] menu, select [Control Panel], and then
click [Allow a program through Windows Firewall]. (If the [User Account
Control] dialog box appears, click [Continue].)
2. Make sure that the [Canon LBP3000 RPC Server Process] check box is
selected in the [Exceptions] sheet in the [Windows Firewall] ([Windows
Firewall Settings] for Windows Vista) dialog box.
Appendix
7
Windows Firewall is now configured to unblock communication with client computers.
7-10
Windows Firewall
Configuring Windows Firewall to block communication
with client computers
1
Insert the supplied "LBP3000 User Software" CD-ROM into
the CD-ROM drive.
If CD-ROM Setup appears, click [Exit].
If you are using Windows Vista and the [AutoPlay] dialog box appears, click
[Open folder to view files], and then proceed to Step 3.
2
3
From the [Start] menu, select [My Computer] ([Computer] for
Windows Vista), right-click the CD-ROM icon, and then select
[Open] from the pop-up menu.
Double-click [English], then [WF_UTIL], then [CNAB3FW.EXE].
The [CAPT Windows Firewall Utility] starts.
4
Click [Block].
Windows Firewall
7-11
7
Appendix
IMPORTANT
You can also run [CAPT Windows Firewall Utility] using the following procedures.
(The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive
name may differ depending on the computer you are using.)
- For an operating system other than Windows Vista: Select [Run] from the [Start]
menu, enter "D:\English\WF_UTIL\CNAB3FW.EXE", and then click [OK].
- For Windows Vista: Enter "D:\English\WF_UTIL\CNAB3FW.EXE" in [Start
Search] under the [Start] menu, and then press the [ENTER] key on your
keyboard.
NOTE
You cannot click [Block] if the firewall is already configured to block communication
with client computers.
5
Click [OK].
Windows Firewall is now configured to block communication with client computers.
Configuring Windows Firewall to unblock communication
with the server
IMPORTANT
If you do not configure the following settings on the client computers, the printer status
may not be displayed correctly in the Printer Status Window and some functions may not
operate properly.
Appendix
7
1
Display the [Windows Firewall] ([Windows Firewall Settings]
for Windows Vista) dialog box.
For Windows XP: From the [Start] menu, select [Control Panel], and then click
[Network and Internet Connections] ➞ [Windows Firewall].
For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞
[Windows Firewall].
For Windows Vista: From the [Start] menu, select [Control Panel], and then click
[Allow a program through Windows Firewall]. (If the [User Account Control]
dialog box appears, click [Continue].)
7-12
Windows Firewall
2
On the [Exceptions] sheet in the [Windows Firewall]
([Windows Firewall Settings] for Windows Vista) dialog box,
place a checkmark next to [File and Printer Sharing], and click
the [OK] button.
7
Appendix
Windows Firewall is now configured to unblock communication with the server.
Windows Firewall
7-13
Index
A
F
Administrator Permissions, 3-23, 3-30, 3-34
[Advanced] Sheet, 4-29
AXIS1650, 7-5
Finishing Method, 4-41
[Finishing] Sheet, 4-23
Firewall, 7-8
Fixing Unit, 6-4
C
Appendix
7
Canceling, Pausing and Resuming Printing, 4-17
Canon Printer Uninstaller, 3-40, 3-42, 3-43
CAPT (Canon Advanced Printing Technology),
3-4
Cleaning
Fixing Unit, 5-14
Printer, 5-19
Client, 3-47, 3-61
[Color Management] Sheet, 4-29
Component Names, 1-4
[Configuration] Sheet, 4-30
Copies, 4-21
Custom Installation, 3-4
Custom Paper Size, 2-45, 4-22, 4-39
D
[Details] Sheet, 4-27
[Device Settings] Sheet, 4-30
Dimensions, 7-4
[General] Sheet, 4-27
Grayscale Settings, 4-46
H
Heavy Paper, 2-3, 2-5, 2-14
I
Important Safety Instructions, xiv
Index Card, 2-4, 2-6, 2-27
Installation
Manuals, 4-56
Printer Driver, 3-4
Installation Problems, 6-27
Installing the CAPT Software, 3-4
Installing the Client, 3-61
L
E
Easy Installation, 3-4
Editing Print Jobs, 4-52
Envelopes, 2-4, 2-6, 2-34
7-14
G
Index
Label Paper, 2-3, 2-5, 2-14
Loading Paper
Custom Paper Size, 2-45
Envelopes, 2-34
Heavy Paper, 2-14
M
Manual Feed Tray, 1-5, 2-20, 2-27, 2-38, 2-51
Manual Scaling, 4-22
Manuals, 4-56
Multi-Purpose Tray, 1-5, 2-15, 2-35, 2-45
N
NetSpot Device Installer, 7-7
Network Adapter, 7-5
Network Printer, 3-70
O
Online Help, 4-20
Online Manuals, 4-56
Optional Accessories, 7-5
Output Tray, 1-5
Output Tray Capacities, 2-13
Output Tray Types, 2-11
P
Page Layout, 4-22
Page Order, 4-22
[Page Setup] Sheet, 4-20
Page Size, 4-21
Paper
Printable Area, 2-5
Storage, 2-7
Paper Feed Roller, 6-5
Paper Guides, 1-5
Paper Indicator, 1-8
Paper Jams, 6-3
Paper Key, 1-8
Paper Output, 2-11
Paper Problems, 6-25
Paper Size
Setting, 2-24, 2-43, 2-56
Paper Sizes
Abbreviations, 2-5
List, 2-2
Paper Source Capacities, 2-10
[Paper Source] Sheet, 4-24
Paper Source Types, 2-9
Paper Sources, 2-9
Paper Type
Setting, 2-25
Paper Types
List, 2-3
Paper You Cannot Use, 2-6
Plug and Play
Windows 2000, 3-21
Windows 98/Me, 3-12
Windows Vista, 3-33
Windows XP/Server 2003, 3-28
[Ports] Sheet, 4-28
Poster Printing, 4-38
Power
Cord, 1-9
Power Indicator, 1-16
Socket, 1-6, 1-10
Turning Off, 1-16
Turning On, 1-15
Power Indicator, 1-8
Preview, 4-33
Print Quality, 4-44
Print Quality Problems, 6-22
Print Server, 3-47, 3-48
Printer
Cleaning, 5-19
Component Names, 1-4
Moving, 5-21
Precautions for Handling, 5-27
Storage, 5-28
Printer Dimensions, 7-4
Printer Driver
Installation, 3-4
Pages, 4-19
Uninstallation, 3-75
7
Appendix
Index Card, 2-27
Label Paper, 2-14
Plain Paper, 2-14
Transparency, 2-14
Local Installation, 3-47
Index
7-15
Appendix
7
Printer Port, 4-27
Printer Properties, 4-9, 4-15
Printer Status Window
[Cleaning], 4-66
Component Names, 4-61
Displaying, 4-63
Displaying Printer Status When Using a Print
Server, 4-67
Options Menu, 4-64
Preferences, 4-64
[Refresh], 4-66
[Resolve Error], 4-66
Printing, 2-14, 2-27, 2-34, 2-45, 4-2
Printing Multiple Pages on One Sheet, 4-34
Printing Orientation, 4-21
Printing Preferences, 4-7
Problems
Installation, 6-27
Other, 6-36
Print Quality, 6-22
When Nothing Prints, 6-26
[Profile] Sheet, 4-31
Sounds, 4-60
Specifications, 7-2
Storing Printouts, 2-8
System Requirements, 3-2
Q
U
[Quality] Sheet, 4-25
Uninstallation, 3-75
Manuals, 4-59
Usable Paper, 2-2
USB
Cable, 1-13, 3-6, 3-13, 3-22, 3-29, 3-33
Class Driver, 3-10, 3-17, 6-30
Connecting, 1-12
Connector, 1-6, 1-13, 3-6, 3-13, 3-22, 3-29,
3-33
Cover, 1-6
Port, 1-12
R
Rating Label, 1-6
Rear Paper Guide, 1-5
Restoring the Default Settings, 4-54
S
Scaling, 4-36
[Security] Sheet, 4-30
Serial Number, 7-18
Service Call Display, 6-18
Sharing Settings, 3-50, 3-54
[Sharing] Sheet, 4-28
Small Paper Guide, 1-5
7-16
Index
T
Test Page, 3-44
Toner Cartridge
Before Replacing, 5-2
Cleaning, 5-14
Handling, 5-16
Replacement, 5-7
Storage, 5-18
Toner Cartridge, 5-2
Toner Cartridge Guide, 1-7, 6-16
Top Cover, 1-5
Transfer Roller, 1-7, 6-5
Transparency, 2-3, 2-5, 2-14
Tray Cover, 1-5
Troubleshooting Map, 6-2
V
Ventilation Slots, 1-6
Viewing Printer Settings, 4-54
W
Windows Firewall, 7-8
Working with Profiles, 4-47
Appendix
7
Index
7-17
Locating the Serial Number
The printer serial number consists of four-alphabetic characters and a six-digit
number.
IMPORTANT
The labels are required for a service engineer to check the serial number for service or
maintenance. Do not peel off the serial numbers.
■ Printer Base
Appendix
7
Serial Number
■ Packing Box
Serial Number
7-18
Locating the Serial Number
USRM1-0509 (01)
©CANON INC. 2006
