Omega iSD-TC Owner Manual

User’s Guide

Chart

Address http://192.168.1.200

High 70.0 / Low 39.0

Max. 65.1 / Min. 47.9

Temperature 1

100

Readings

54.2 F

Chart Web Link

Recording: ON

Setup

50.8 F

High 78.0 / Low 25.0

Max. 69.9 / Min. 30.1

Temperature 2

100

10.0

C/Div

10.0

C/Div

0

Thu Sep 16 08:00:00 PDT 2009

Data Source: Live

Alarm Relay Set Points: Bold

Help [?]

X-axis:

1 Hour/Div

1 Day

Y-axis (left): Temperature 1

Y-axis (right): Temperature 2

Style: Bold

Style: Bold

0

Thu Sep 17 12:05:07 PDT 2009

Save Chart

Print Chart

Shop on line at

®

®

omega.com e-mail: [email protected]

For Latest Product Manuals omegamanual.info

Dual Thermocouple over the Internet

TABLE OF CONTENTS

Part 1: INTRODUCTION

1.1 Safety and EMC Considerations .....................................................................2

1.2 Before You Begin .............................................................................................2

1.3 Description .......................................................................................................2

Part 2: HARDWARE

2.1 Dimensions ......................................................................................................4

2.2 Wall Mounting ..................................................................................................5

2.3 Parts of the iServer Unit ..............................................................................6

2.4 Disassembly Instruction..............................................................................7

2.4.1 Battery Installation .........................................................................8

2.5 Network Communication Interfaces ...........................................................8

2.5.1 10/100 BASE-T RJ-45 Pinout ..........................................................8

2.5.2 Connecting iServer to PC/Hub/Switch/Router ..............................8

2.6 Relay Wiring Connections...........................................................................9

PART 3 NETWORK CONFIGURATION

3.1 Network Protocols......................................................................................10

3.2 Ethernet (MAC) Address ............................................................................10

3.3 DHCP ...........................................................................................................11

3.4 DNS ...........................................................................................................11

3.5 IP Address ...................................................................................................11

3.6 Port Number................................................................................................12

PART 4 OPERATIONS ...................................................................................................12

4.1 IP Address Assignment .............................................................................12

4.1.1 DHCP (Method 1)............................................................................12

4.1.2 ARP HTTPget Commands (Method 2) ..........................................12

4.1.3 Direct Connection (Method 3).......................................................13

4.1.4 iConnect Software (Method 4) ......................................................17

4.2 Access and Configuration Using a Web Browser ...................................19

4.3 LOGIN and ADMINISTRATOR Passwords................................................19

4.4 Setup ..........................................................................................................20

4.4.1 Overview .........................................................................................20

4.4.2 Network...........................................................................................21

4.4.2.1 IP Configuration ......................................................................21

4.4.2.2 Ethernet Port............................................................................23

4.4.3 Configuration .................................................................................23

4.4.3.1 Data and Time..........................................................................23

4.4.3.2 Server .......................................................................................25

4.4.3.3 Sensors ....................................................................................26

4.4.3.4 Contact Closures.....................................................................28

4.4.3.5 Alarm Relays............................................................................29

4.4.4 Management ...................................................................................31

4.4.4.1 Setup .......................................................................................31

4.4.4.1 Setup .......................................................................................31

SNMP Simple Network Management Protocol ................................31

SMTP Simple Mail Transfer Protocol................................................32

4.4.4.1.1 Sending Text Messages to a Cell Phone........................32

i

TABLE OF CONTENTS (continued)

4.4.4.2 Alarms ......................................................................................32

4.4.5 Security...........................................................................................34

4.4.6 Recording .......................................................................................36

4.4.6.1 Start Recording ..................................................................36

4.4.6.2 Status ..................................................................................38

4.4.6.3 Data Retrieval .....................................................................39

4.4.6.4 Format SD Card ..................................................................40

4.4.7 System ............................................................................................40

4.4.7.1 Reboot ......................................................................................40

4.4.7.2 Defaults ....................................................................................41

4.4.7.3 Upgrade....................................................................................41

4.4.7.4 Download Configuration.........................................................42

4.4.7.5 Upload Configuration..............................................................43

4.4.8 Diagnostics ....................................................................................43

4.4.9 Log Out ...........................................................................................43

4.5 Readings .....................................................................................................44

4.5.1 HTML ...............................................................................................44

4.5.2 Java .................................................................................................45

4.6 Chart ..........................................................................................................46

4.7 Web Link .....................................................................................................47

4.8 Telnet Setup ................................................................................................48

4.8.1 Telnet Connection..........................................................................48

4.9 HTTPget Program.......................................................................................49

4.9.1 HTTPget using Port 2000 ..............................................................50

4.10 Flash Card Reader....................................................................................51

4.10.1 Opening .txt Data Files ................................................................52

4.11 iLog Software............................................................................................53

PART 5 SPECIFICATIONS............................................................................................55

APPENDIX A GLOSSARY ............................................................................................57

APPENDIX B IP Address..............................................................................................58

APPENDIX C ARP Commands ....................................................................................59

APPENDIX D IP Netmask .............................................................................................60

APPENDIX E ASCII Chart.............................................................................................61

APPENDIX E ASCII Control Codes .............................................................................62

APPENDIX F iLog Error Messages .............................................................................63

APPENDIX G Java Runtime Environment Setup........................................................64

APPENDIX H SNMP ......................................................................................................66

LIST OF FIGURES:

Figure 1.1 iServer and iLD Big Display on the Ethernet Network...............................3

Figure 2.1 Dimensions ....................................................................................................4

Figure 2.2 Wall Mounting................................................................................................5

Figure 2.3 Parts of the iServer Unit ...............................................................................6

Figure 2.4 Opening the Unit ...........................................................................................7

Figure 2.5 Battery Installation ........................................................................................8

ii

LIST OF FIGURES (continued)

Figure 2.6 RJ45 Pinout ...................................................................................................8

Figure 2.7 Relay and I/O Contact Connections ............................................................9

Figure 3.1 Labeling ..................................................................................................10

Figure 4.1 ARP and httpget Commands on a DOS Window......................................13

Figure 4.2 Connecting Computer Directly to iServer.................................................14

Figure 4.3 Network Connections .................................................................................14

Figure 4.4 Local Area Connection ...............................................................................14

Figure 4.5 Changing TCP/IP Properties on Your Computer ......................................15

Figure 4.6 iServer Welcome Page................................................................................15

Figure 4.7 Pinging the iServer from MS-DOS Prompt ...............................................16

Figure 4.8 Assigning an IP Address using iConnect .................................................17

Figure 4.9 Accessing the iServer’s using iConnect...................................................18

Figure 4.10 iServer Welcome Page..............................................................................19

Figure 4.11 LOGIN and ADMINISTRATOR Passwords ...............................................19

Figure 4.12 Overview ..................................................................................................20

Figure 4.13 Network: IP Configuration .......................................................................21

Figure 4.14 Network: Ethernet Configuration.............................................................23

Figure 4.15 Configuration Menu: Date and Time.......................................................24

Figure 4.16 Configuration Menu: Server .....................................................................25

Figure 4.17 Configuration Menu: Sensors ..................................................................26

Figure 4.18 Configuration Menu: Contact Closures ..................................................28

Figure 4.19 Configuration Menu: Alarm Relays .........................................................29

Figure 4.20 Management Menu: Setup........................................................................31

Figure 4.21 Management Menu: Alarms......................................................................32

Figure 4.22 Security Menu............................................................................................34

Figure 4.23 Recording Menu: Start Recording ...........................................................36

Figure 4.24 Recording Menu: Status ...........................................................................38

Figure 4.25 Recording Menu: Data Retrieval ..............................................................39

Figure 4.26 Recording Menu: Format SD Card ..........................................................40

Figure 4.27 System: Reboot .........................................................................................40

Figure 4.28 System: Defaults .......................................................................................41

Figure 4.29 System: Upgrade.......................................................................................41

Figure 4.30 System: Download Configuration ...........................................................42

Figure 4.31 System: Upload Configuration ................................................................43

Figure 4.32 Diagnostics ................................................................................................43

Figure 4.33 Readings: HTML ........................................................................................44

Figure 4.34 Readings: Java ..........................................................................................45

Figure 4.35 Adjustable Chart........................................................................................46

Figure 4.36 Web Link ..................................................................................................47

Figure 4.37 Tera Term Telnet Connection Screen ......................................................48

Figure 4.38 Telnet to Port 2002 – p command ............................................................49

Figure 4.39 Telnet to Port 2002 – ? command ............................................................49

Figure 4.40 Recorded Data File Directory ...................................................................52

Figure 4.41 Example of data recorded on the SD card, standard text (.txt) file format .52

Figure 4.42 iLog Software Logging Data ....................................................................53

Figure C.1 ARP Commands and Responses ..............................................................59

Figure G.1 Java 1.7 Screen Shot .................................................................................64

iii

LIST OF TABLES

Table 2.1 Parts of iServer Unit........................................................................................6

Table 4.1 iLog Excel Applications................................................................................54

Table F-1 iLog Error Messages ....................................................................................63

Table H-1 SNMP MIB-2 71

Table H-2 SNMP Trap ..................................................................................................66

iv

NOTES, WARNINGS and CAUTIONS

Information that is especially important to note is identified by the following labels:

• NOTE

• WARNING or CAUTION

• IMPORTANT

• TIP

NOTE: Provides you with information that is important to successfully setup and use the iServer.

CAUTION: Tells you about the risk of electrical shock.

CAUTION: Risk of danger. Tells you of circumstances or practices that can affect the instrument’s functionality and must refer to accompanying documents.

TIP: Provides you helpful hints.

•

•

•

•

•

•

•

•

•

•

•

•

•

•

FEATURES

Two Temperature Channels

Web Server

Virtual Chart Recorder

Two Relay Alarms

Two Contact Closures

2GB SD Flash Memory Card

Password Protection

Email Alarms

Data Logging

Real Time Clock

Accurate Readings

SNMP Trap

LCD Display

Back-up Battery 9Vdc

1

PART 1

INTRODUCTION

1.1 Safety and EMC Considerations

Refer to the CE Approvals Section.

EMC Considerations

• Whenever EMC is an issue, always use shielded cables.

• Never run signal and power wires in the same conduit.

• Use twisted-pair wires for signal connections.

• Install Ferrite Bead(s) on signal wires close to the instrument if EMC problems persist.

Failure to follow all instructions and warnings may result in injury!

1.2 Before You Begin

Inspecting Your Shipment: Remove the packing slip and verify that you have received everything listed. Inspect the container and equipment for signs of damage as soon as you receive the shipment. Note any evidence of rough handling in transit. Immediately report any damage to the shipping agent. The carrier will not honor damage claims unless all shipping material is saved for inspection. After examining and removing the contents, save the packing material and carton in the event reshipment is necessary.

Customer Service: If you need assistance, please contact the Customer Service

Department nearest you.

Manuals, Software: The latest Operation Manual as well as free configuration software

(iConnect) and datalogging software (iLog) are available at the website listed on the

cover page of this manual or on the CD-ROM enclosed with your shipment.

1.3 Description

Monitor Temperature over the Internet -- The iSD provides Web-based temperature monitoring in critical equipment and locations such as computer server rooms, clean rooms, laboratories, museums, warehouses, or any remote facility.

View and record temperature on two independent thermocouple channels, over an

Ethernet network or the Internet with no special software—just a Web browser.

Email Alarms -- The device can trigger an alarm if temperature goes above or below a set point that you determine. Your alarm can be sent by email to a single user or to a group distribution list, including text messages to cell phones and PDA’s.

Physical Threats -- The iSD-TC includes screw terminals for two contact closures that work with common alarm sensors. You can instruct the iSD monitor to send an alarm if a door is opened, a window is broken, or a fire sprinkler goes off.

Power Failure -- The iSD monitor can trigger an alarm if the AC power fails. The iSD-TC will continue to collect data for two days powered by a standard 9 Volt alkaline battery

(included). A failure on the Ethernet network will not interrupt data recording.

Local Alarms -- The iSD monitor includes two 1.5 Amp output relays that are controlled by the alarm conditions you select. The relays can trigger flashing lights and a siren for example to alert personnel near the scene.

With the easy Web-based setup page, the two relays can be programmed for two temperature inputs, and high or low set points, as well as alarm conditions triggered by contact closures. The relays can also be programmed to turn off when conditions return to normal, or programmed to remain latched and require a manual reset.

2

1.3 Description (continued)

View Charts and Graphs on the Web -- The iSD serves Active Web Pages to display real time readings, display charts of temperature, or log data in standard data formats for use in a spreadsheet or data acquisition program such as Excel or Visual Basic.

The virtual chart viewed on the web page is a JAVA™ Applet that records a chart over the LAN or Internet in real time. With the iSD, there is no need to invest time and money learning a proprietary software program to log or chart the data.

Chart scales are fully adjustable on the fly. For example, the chart can display one minute, one hour, one day, one week, one month or one year. Temperature can be charted across the full span or within any narrow range. The iSD can display and chart absolute measurements in two locations and a differential measurement between the two locations.

The iSD can take thermocouple types J, K, T, E, R, S, B, C, N, and L measuring temperatures up to 1,820°C (3,308°F). The iSD includes a pair of type K thermocouples.

Link to Web CAM or IP Camera -- The Web page includes a link to a “Web Cam” or “IP camera” (not included). If you get a message about an alarm condition, you can quickly click on the link to view the actual scene over the Internet.

SD Flash Memory Card -- The iServer comes complete with a removable 2 GB SD

Flash Memory card that can store up to seven years of readings taken at ten second intervals. The data is recorded on widely available SD (Secure Digital) flash cards. The format is a simple text file that is easily imported to spreadsheets and other programs. It can be read on a PC or MAC with a USB card reader. You can also download the data remotely over an Ethernet network or the Internet.

Installation and operation of the iServer requires no special training, tools, or software.

The device connects to any Ethernet network with standard cable and is powered by a universal 100 to 240 Vac adapter which is supplied with the product.

Award-Winning Technology -- The iSD is simple to install and use, and features the award-winning iServer technology that requires no special software except a Web

Browser. The iSD connects to an Ethernet Network with a standard RJ45 connector and sends data in standard TCP/IP packets. It is easily configured with a simple menu using a Web Browser and can be password protected. From within an Ethernet LAN or over the Internet, the user simply types its IP address or an easy to remember name such as

"Cleanroom 5" or "Midwest Server Room" in any Web Browser, and the iSD-TC serves a

Web Page with the current readings.

Example:

A standard web browser can be used to monitor and chart temperature. The browser can also be used to configure the device’s IP address, passwords for access and all configuration parameters. An iLD Big Display can display the temperature values received from an iServer over the Ethernet or the Internet.

The following example (see Figure 1.1) illustrates how you can hookup an iServer and iLD to your network:

3

1.3 Description (continued)

COMPUTER with

Standard Web Browser

SMTP SNMP Server

COL

ON

TX

RX Temperature 1

Temperature 2

Figure 1.1 iServer and iLD Big Display on the Ethernet Network

PART 2 HARDWARE

2.1 Dimensions

130.2 [5.13]

33.3

[1.31]

Dimensions are in mm with inches in [ ].

C/ F TIME/IP BKLT

DUAL TEMPERATURE

RECORDING

DHCP

LINK/ACT

100 BASE-T

Figure 2.1 Dimensions

4

If unit is to be mounted on a flat surface, you may take the bottom rubber feet off the unit.

2.2 Wall Mounting

Position unit where required. Mark and drill the two #4 screw holes.

After bracket is mounted on the wall, align back of unit over the three bracket clips, once engaged, slide downward, the unit will snap in place.

DRILL 3.17 [0.125]

USE TWO, #4

FLAT HEAD SCREWS

TO MOUNT BRACKET

ADDITIONAL MOUNTING OPTION-

TO RETAIN UNIT TO MOUNTING BRACKET

USE #4 X 1/4" LONG SELF-TAPPING SCREW

29.5 [1.16] 34.4 [1.36]

88.1 [3.47]

CLIPS (3)

14.9 [0.59]

46.1 [1.81] 38.1 [1.50]

130.2 [5.13]

REAR WIRE

ENTRY AREA

23.8 [0.94]

UNIT OUTLINE

38.1 [1.50] 6.1 [0.24]

Dimensions are in mm with inches in [ ].

Figure 2.2 Wall Mounting

It is recommended that you ground your unit by connecting a wire to the

Return/Ground position of the relay connector, see Figure 2.6.

5

2.3 Parts of the iServer Unit

9Vdc Battery

(under cover)

The 9V battery is the back-up power for the recording function only.

Removable Plug

Connector for

Input and Outputs

(under cover)

Buttons

TOP VIEW

32 Digit LCD Display

SD Flash

Memory

Card

C/ F TIME/IP BKLT

Cover

Screw

(2 plcs)

RECORDING

DHCP

LINK/ACT

100 BASE-T iServer LEDs

ETHERNET

9-12 Vdc

+

1 8 dc Power Input

SD Flash

Memory

Card

Standby

Button

Figure 2.3 Parts of the iServer Unit

Table 2.1 Parts of iServer Unit

ETHERNET RJ45 interface for 10/100BASE-T connection.

RESET Button: Momentary (Push and Release) resets power on unit; Push and Hold for

10 seconds to reset unit to factory defaults and reset power.

100 BASE-T LED (Green) On: Indicates 100 Mbps; LED Off: Indicates 10 Mbps.

LINK/ACT

DHCP

LED (Green) On/Blinking: Indicates good network link and network activities

(receiving or sending packets).

LED (Yellow): When DHCP is enabled, once the iServer receives the IP parameters from the DHCP server this LED will turn Solid yellow.

RECORDING LED (Green) Blinking Fast: Indicates that the unit is recording. LED Blinking: during back-up battery operation according to sampling rate, or recording interval if recording is ON.

°C/°F Button: Press to change LCD display units of measurement between °C and °F.

Press and Hold along with TIME/IP button during power-on, this will enable

DHCP mode.

TIME/IP Button: Press repeatedly to change LCD display from: 1) Date and Time;

2) iServer’s IP address; 3) Temperature1, Temperature 2. Press and Hold along with °C/°F button during power up, this will enable DHCP mode.

6

2.3 Parts of the iServer Unit (continued)

BKLT Button: Push and Hold to display Backlight on LCD when it is running on the back-up battery (backlight is always on while running on the ac adapter).

STBY Button: 1) Stops the recording; 2) Press before ejecting Flash Card.

NOTE: display will show “Safe to Eject SD” after button has been pressed

2.4 Disassembly Instruction

You may need to open the unit for one of the following reasons:

• To wire relay connector or I/O connector. (Refer to Figure 2.6)

• To connect or replace the battery.

Disconnect the power supply before proceeding.

• Make sure the flash memory card is fully inserted (or removed), before removing the cover.

Remove cover, by removing 2 mounting screws on each side.

COVER

Press STBY before ejecting

Flash Card.

NOTE: display will show “Safe to

Eject SD” after button has been pressed.

SD FLASH

CARD

BATTERY

LOCATION

MOUNTING

SCREWS (2)

RELAY

CONNECTOR

TRAY

I/O CONTACT

CONNECTOR

THERMOCOUPLE

CONNECTORS

ETHERNET &

DC POWER

CONNECTORS

Figure 2.4 Opening the Unit

7

2.4.1 Battery Installation

9 VDC BATTERY

INSULATOR COVER

TRAY

REMOVE BATTERY CLIP

INSULATOR COVER AND

STORE AGAINST BATTERY

WHEN BATTERY IS BEING USED.

KEEP INSULATOR COVER

ON BATTERY CLIP

WHEN BATTERY IS NOT

BEING USED

Figure 2.5 Battery Installation

2.5 Network Communication Interfaces

2.5.1 10/100 BASE-T RJ-45 Pinout

The 10/100BASE-T Ethernet network system is used in the iServer for network connectivity. The 10 Mbps or

100 Mbps twisted-pair Ethernet system operates over two pairs of wires. One pair is used for receiving data signals and the other pair is used for transmitting data signals. This means that four pins of the eight-pin connector are used.

6

7

4

5

8

Pin Name Description

1 +Tx + Transmit Data

2

3

-Tx

+RX

- Transmit Data

+ Receive Data

N/C

N/C

-Rx

N/C

N/C

Not Connected

Not Connected

- Receive Data

Not Connected

Not Connected

Figure 2.6 RJ45 Pinout

For CE compliance at 100 Mbps: use shielded cable, opposite end of cable must be grounded.

2.5.2 Connecting iServer to PC/Hub/Switch/Router

The iServer’s Ethernet interface can automatically detect the Rx and Tx lines on a twisted pair Ethernet cable (MDI/MDIX Auto Cross). Therefore, to connect an iServer to a

PC/Hub/Switch/Router, either a straight-through or a cross-over cable can be used.

On certain devices (like iServer), it is possible for the hardware to automatically correct errors in cable selection, making the distinction between a “straightthrough” cable and a “cross-over” cable unimportant. This capability is known as

“Auto MDI/MDIX”.

8

2.6 Relay and I/O Wiring Connections

To access the Relay and I/O Connectors you must remove the cover, refer to Section 2.4.

It is recommended that you ground your unit by connecting a wire to the

Ground/Return position of the relay connector or by wrapping a wire around the case’s bottom screw. Refer to Figure 3.1 for location.

Figure 2.7 Relay and I/O Contact Connections

9

PART 3

NETWORK CONFIGURATION

3.1 Network Protocols

The iServer can be connected to an Ethernet network communicating through standard

IP protocols including TCP, UDP, SNMP, SMTP, ARP, HTTP (WEB access), DNS, DHCP,

ICMP, SNTP, and Telnet.

3.2 Ethernet (MAC) Address

MAC (Media Access Control) address is a unique hardware number for Ethernet devices like computers, network switches, print servers, etc. When you're connected to an

Ethernet LAN using a computer you can see a table of IP addresses called “ARP table” stored on that computer. The ARP table relates IP addresses of devices on a network to their corresponding MAC addresses. The MAC address can be found on a label attached to your Ethernet device and it contains 6 bytes (12 characters) of hexadecimal numbers XX:XX:XX:XX:XX:XX hex

For example: 0A:0C:3D:0B:0A:0B

Remove the small label with the default IP address of 192.168.1.200 and there will be room to put your IP address. See Figure 3.1

1

SCREW FOR

GROUNDING UNIT

REMOVE DEFAULT IP ADDRESS LABEL

AND PUT NEW CUSTOMER'S IP ADDRESS

Figure 3.1 Labeling

FIRMWARE

VERSION #

MAC ADDRESS LABEL

IN HEX CODE

3.3 DHCP

DHCP, Dynamic Host Configuration Protocol, enables computers and network devices to receive their IP configurations from a DHCP server.

If DHCP is enabled on your iServer, as soon as the iServer that is connected to the network is powered on, there will be an exchange of information between the iServer and the DHCP server. As a result, the DHCP server will assign an IP address, a Gateway address, a Subnet Mask, and a DNS address to the iServer. Note that the DHCP server must be correctly configured to make such assignments.

If fixed or static IP address is desired, the DHCP function must be disabled.

The iServer is shipped with DHCP disabled (factory default).

The DHCP can be enabled by accessing the iServer’s web server and selecting Network menu (refer to Section 4.4.2) or by pressing and holding the two front buttons °C/°F and

TIME/IP during power-on (refer to Section 2.3).

It’s very important to communicate with the network administrator in order to understand DHCP and its existing configurations on the host server before enabling DHCP on the iServer.

The iServer is shipped with a default static IP address of 192.168.1.200 and

Subnet Mask of 255.255.255.0.

3.4 DNS

DNS, Domain Name System, enables computers and devices to be recognized over a network based on a specific name instead of IP addresses.

For example, instead of having to use http://192.168.1.200 (IP address), you would use

http://isdb870 or any name up to sixteen alphanumeric characters defined as a Host

Name in the iServer’s web server.

The default Host Name for an iServer is "isd" followed by the last four digits of the MAC address of that iServer unit.

On Windows servers where DHCP and DNS are separate functions it is very important to configure the DHCP server to communicate with DNS in order for the iServer’s Host Name to correctly respond. If you cannot access the iServer using its Host Name, please contact your network administrator to make sure

DHCP and DNS servers are linked together.

If DNS server address is setup, all Host Names reported during weblink configuration

(i.e. SMTP server IP, SNTP server IP, SNMP trap server IP, etc.) will be translated into IP addresses.

3.5 IP Address

Every active device connected to the TCP/IP network must have a unique IP address.

This IP address is used to build a connection to the iServer.

All network devices like computers that use TCP/IP protocol to communicate with each other should have a unique 32-bit address called IP address. The IP address is divided into two portions, the network ID and the host ID. For instance, every computer on the same network uses the same network ID. At the same time, all of them have different host IDs. For more details about the IP address see Appendix B.

11

3.6 Port Number

All TCP connections are defined by the IP address and a port number. A port number is an internal address that provides a TCP/IP interface between an application software on a computer and a device on the network or between two devices on the network.

There are two default TCP port (socket) numbers assigned to the iServer:

1) Port 2000: Once a TCP connection is made to the iServer using port 2000 or any port number that is configured on the iServer for Local Port (see Network menu,

Section 4.4.2), the iServer can then be polled for variables like temperature, humidity, etc. using commands. For the list of commands see Section 4.9.1.

2) Port 2002: This port is the iServer’s network console port for reading or changing the settings within the iServer. For the list of settings refer to Section 4.8.1. For both of the above cases, for example, a Telnet application can be used.

PART 4

OPERATIONS

Depending on user’s preference and network setup, the iServer can be configured in several ways:

Using the latest versions of Web browsers like Internet Explorer, Firefox, Opera, or

Safari (iPhone) the iServer’s Web server can be accessed, see Section 4.2.

It can also be configured using a TCP connection to port 2002 using a command line interface, see Section 4.8.1.

The iCONNECT Configuration Software can also be used to find and configure the iServer over the Ethernet, see Section 4.1.2.

Before you configure the iServer, you will need to assign an IP address to the unit. Refer to Section 4.1.1, 4.1.2 or 4.1.3.

4.1 IP Address Assignment

4.1.1 DHCP (Method 1)

The DHCP server will assign an IP address, see Section 3.3.

4.1.2 ARP HTTPget Commands (Method 2)

You can download the HTTPget program from our web site to use it for this section.

1. From the Command line (DOS prompt) where you keep the HTTPget.exe file, type the following: arp -s 128.100.101.76 00-03-34-00-b8-70 press the <Enter> key

128.100.101.76, for example, is the IP address that you want to assign to your iServer and 00-03-34-00-b8-70 is the MAC address of your iServer labeled on the bottom of the unit.

2. From the same prompt, type the following HTTPget command: httpget -r -S “00000000” 128.100.101.76:1 press the <Enter> key

00000000 is the default ADMINISTRATOR password in your iServer unit and

128.100.101.76:1 is the IP address that your iServer will accept on TCP port 1. At this point, you have successfully assigned 128.100.101.76 IP address to your iServer.

Continued on the following page.

12

4.1.2 ARP HTTPget Commands (Method 2) (continued)

The above IP address of 128.100.101.76 is an example to show how these commands work. To get a valid IP address on your network you need to consult with your IT department.

Figure 4.1 shows the screen shot of an actual DOS window with the above commands executed.

C:\>arp -s 128.100.101.76 00-03-34-00-b8-70

C:\>httpget -r -S “00000000” 128.100.101.76:1

New IP is assigned. The unit will reset in 10 seconds.

C:\>

Figure 4.1 ARP and HTTPget Commands on a DOS Window

4.1.3 Direct Connection (Method 3)

The iServer is shipped with a default IP address of 192.168.1.200 and Subnet Mask of

255.255.255.0.

To start, connect your iServer directly to your PC using a straight or cross-over Ethernet cable and power it on.

Make sure that the Network LINK/ACT LED on the iServer and your Ethernet switch is solid ON. Refer to Figure 4.2.

If you are going to use a Web browser or Telnet program to access the iServer using its default IP address of 192.168.1.200, you need to make sure that the PC from which you’re establishing the connection has an IP address that is in the same range as the iServer’s IP address.

For example, you can assign your PC an IP address of 192.168.1.x, where x is any number from 1 to 254.

Your PC’s IP address cannot be the same as the iServer’s IP address.

You also need to make sure that your PC’s subnet mask is 255.255.255.0.

This is a good way to access the iServer over the network and make any configuration changes needed.

Changing your PC’s IP address is temporary and it’s only for the purpose of accessing the iServer for initial configurations like assigning a new IP address, subnet mask, etc.

Once the iServer is configured you can put your PC back to its original IP settings.

If 192.168.1.200 is already in use on your network, connect the iServer directly to your computer using a CAT5 Ethernet cable (either straight or cross-over cable will be detected by the iServer) and proceed as described below.

13

4.1.3 Direct Connection (Method 3) (continued) iServer with default IP address of 192.168.1.200

Computer’s

Ethernet Port

(RJ45 connection)

After connecting the iServer to computer, power it on.

LINK/ACT LED should be

SOLID green

RECORDING

DHCP

LINK / ACT

100 BASE-T

Ethernet Cable

Plug in the

Power Adapter

Figure 4.2 Connecting Computer Directly to iServer

1) Click on your Windows “Start” menu and select

“Control Panel” from the list options.

Double click on the “Network Connections” icon

Figure 4.3 Network Connections

2) You now have “Network Connections” window opened.

The “Local Area Connection” icon has all the settings for your ethernet connection.

Double click on this icon.

Figure 4.4 Local Area Connection

14

4.1.3 Direct Connection (Method 3) (continued)

3) Click on “Properties” button

Select “Internet Protocol

(TCP/IP)” and click on

“Properties” button

Fill out the fields for the IP address 192.168.1.100 and

Subnet mask 255.255.255.0 as indicated below. Press

OK and also on all the other remaining windows.

Figure 4.5 Changing TCP/IP Properties on Your Computer

4) Now you may need to reboot your computer.

5) Once your PC is back up, open your browser and type the iServer’s default IP address of 192.168.1.200 in the “Address” window of your browser and press the

Enter key.

You will soon be inside the Welcome page (see Figure 4.6) of the iServers WEB server and from there you can access all the menus.

iSD-TC Welcome Page

Address http://192.168.1.200

Readings

Setup

Chart

Web Link

Figure 4.6 iServer Welcome Page

15

4.1.3 Direct Connection (Method 3) (continued)

To verify a good connection to the iServer, from a DOS prompt on your computer type "ping 192.168.1.200" and press Enter.

You should get a reply as shown in Figure 4.7.

If you don’t receive a reply it means that you do not have a network connection between your PC and the iServer.

Check your IP address, subnet mask, and gateway address.

C:\>ping 192.168.1.200

Pinging 192.168.1.200 with 32 bytes of data:

Reply from 192.168.1.200: bytes=32 time=15ms TTL=64




Pinging statistics for 192.168.1.200:

Packets: Sent=4, Received=4, Lost=0 (0% loss)

Approximate round trip times in milli-seconds:

Minimum=8ms, Maximum=15ms, Average=9ms

Figure 4.7 Pinging the iServer from MS-DOS Prompt

16

4.1.4 iConnect Software (Method 4)

The iServer can be assigned an IP Address by using the iConnect software.

a) Download the iConnect software from the website listed on the cover of this manual

(software section).

b) Install iConnect software on a networked PC. This software is compatible with

Windows 95, 98, NT, 2000, and XP. c) Use iConnect to assign an IP address to the iServer and access its web pages for configuration.

You can also use any standard web browser to access the iServer’s web pages.

Consult with your IT department for obtaining an IP address.

Figure 4.8 Assigning an IP Address using iConnect

1) Place the IP address in this box.

2) Take the MAC address from the label attached to the bottom of the iServer and place it in this box.

3) Click here to send the above IP address to the iServer.

4) After the IP address is assigned to the iServer, click here to access it’s web pages.

5) Click here to Ping the iServer whose IP address is shown in the IP address box.

6) Click here to find all the iServer’s on your network .

7) The IP addresses for the iServer’s found by the iConnect will be listed here.

8) These fields indicate the IP address and the subnet mask of the PC on which the iConnect is running.

17

4.1.4 iConnect Software (Method 4) (continued) d) To access the iServer for Configuration:

Click on the “View Webpage” button, you will access the iServer’s welcome page.

To take advantage of the iServer’s full capability use any standard web browser to access the iServer’s web pages as described in Section 4.2.

Figure 4.9 Accessing the iServer’s using iConnect

18

4.2 Access and Configuration Using a Web Browser

•

Start your web browser.

•

In the URL field, type http://192.168.1.200 (iServer’s default IP address).

•

The Welcome Page, will be displayed. iSD-TC Welcome Page

Address http://192.168.1.200

Readings

Setup

Chart

Web Link

Figure 4.10 iServer Welcome Page

In order to access the iServer’s web pages, users may be prompted for a password, as shown below.

4.3 LOGIN and ADMINISTRATOR Passwords

Login Administrator Login

Address http://192.168.1.200

Address http://192.168.1.200

Readings Chart Web Link Setup

Password:

LOGIN

OK


ADMINISTRATOR

Password: OK

Figure 4.11 LOGIN and ADMINISTRATOR Passwords

There are 2 different access levels:

1.

LOGIN Password is required to access the iServer’s Readings, Chart, and Web Link pages unless it’s disabled. The default password is 12345678.

2. ADMINISTRATOR Password is required to access the iServer’s Setup menu unless it’s disabled. The default password is 00000000.

Refer to Section 4.4.5 for Password setup.

19

4.4 Setup

Clicking the Setup button on the Welcome page (see Figure 4.10) will provide access to the Menu Panel (see Figure 4.12).

Using this Panel you can configure the iServer entirely.

4.4.1 Overview

Once the Administrator password is entered, the Overview page will appear which provides a summary of important parameters within the iServer.

All the fields are read-only.

Overview

Address http://192.168.1.200


Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Model

Firmware Version

DHCP

MAC Address

IP Address

Subnet Mask

Gateway Address

Hostname

Ethernet Port

Web Server Port

Recording

Uptime iSD-TC x.x

Disabled

00:03:34:00:b8:70

192.168.1.200

255.255.255.0

0.0.0.0 isdb870

Auto

80

OFF

1 day, 00:00:00 hh:mm:ss

Figure 4.12 Overview

20

4.4.2 Network

This menu provides network configurations including IP parameters and Ethernet interface options. Fields are described below.

4.4.2.1 IP Configuration

Network

Address http://192.168.1.200


IP Configuration Ethernet Port

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

DHCP

MAC Address

IP Address

Subnet Mask

Gateway Address

DNS Address

Host Name

Protocol

00:03:34:00:b8:70

192.168.1.200

255.255.255.0

0.0.0.0

0.0.0.0

isdb870

TCP

2000 Local Port

Web Server Port

Web Link Title

Web Link Address

80

WebLink www.123abc.com

Save Changes Reset

Figure 4.13 Network: IP Configuration

DHCP – If the box is checked the iServer will dynamically request an IP address, a subnet mask, a gateway address, and a DNS address from the DHCP server. By default the DHCP option is disabled. For more information about DHCP, see Section 3.3.

DHCP can be enabled by pressing and holding the two front buttons ºC/ºF and

TIME/IP during power-on (refer to Section 2.3).

MAC Address – This Indicates the hardware address of the iServer and it is nonconfigurable. For more information about MAC Address, see Section 3.2.

IP Address – This indicates the IP address of the iServer. The iServer’s default IP address is 192.168.1.200. When DHCP is enabled this field will be dimmed. Consult with your IT department for obtaining an IP address.

Subnet Mask – It’s a 32-bit number that is used to determine which part of the IP address is the network portion and which part is the host portion. When DHCP is enabled this field will be dimmed. The iServer’s default Subnet Mask is 255.255.255.0. Consult with your IT department for obtaining a subnet mask.

21

4.4.2.1 IP Configuration (continued)

Gateway Address – This points to the router that forwards traffic to a destination address outside of the subnet on which the iServer resides. This is the IP address of the router which functions as a gateway. When DHCP is enabled this field will be dimmed.

The iServer’s default Gateway address is 0.0.0.0. Consult with your IT department for obtaining a gateway address.

DNS Address – In order to use the hostname to access the iServer, the DNS server on your network must be configured, refer to Section 3.4. iServer plays the role of a DNS client, in the sense that the iServer will actively query the DNS server for the IP address associated with a particular domain name. When DHCP is enabled this field will be dimmed. The iServer’s default DNS address is 0.0.0.0. Consult with your IT department for obtaining a DNS address.

Host Name – If DHCP is enabled, the iServer will send this name to the DHCP server.

This name is used so that the iServer can be accessed based on a specific name instead of an IP address. For example, instead of using http://192.168.1.200 (IP address), you would use http://isdb870 or any name up to sixteen (16) alphanumeric characters. The default Host Name for an iServer is "isd" followed by the last four digits of the MAC address of that particular iServer.

On Windows servers where DHCP and DNS are separate functions it’s very important to configure the DHCP server to communicate with DNS in order for the iServer’s Host Name to correctly respond. If you cannot access the iServer using its Host Name, please contact your network administrator to make sure

DHCP and DNS servers are linked together.

Protocol – It’s the network protocol the iServer communicates with the Ethernet

Network. Options are TCP and UDP. The default is TCP.

Local Port – The default port is 2000. Refer to Section 3.6.

Web Server Port – The default port is 80. This is the primary port number for the HTTP protocol used for communication between internet browsers and web sites/web servers.

Web servers open this port then listen for incoming connections from web browsers.

Similarly, when a web browser is given an IP address (like the iServer’s IP address), it assumes that the iServer’s web server is listening for connections on port 80. If this port is changed to anything but 80 then on the browser the new port number must be indicated with a colon ( : ) after the IP address. For example, if the Web Server Port is changed to 500, you will then need to type http://192.168.1.200:500 on the browser to access the iServer’s web server.

One of the applications where the Web Server Port number may need to change is when users want to access the iServer’s web server from outside the local area network (i.e. Internet). By setting up “Port Forwarding” inside a router that is the gateway to that local area network this task can be accomplished. “Port

Forwarding” technique uses the Web Server Port number to forward the Internet connection to the iServer on the LAN.

Web Link Title – This is a text field that appears on the button on the iServer’s Web Link

Page, refer to Section 4.7. This can describe the Web Link Address assigned below.

Web Link Address – This provides a link to any TCP/IP node on the network or any

Web link on the Internet. Examples would be www.123abc.com or if you have a device with an embedded Web server (just like the iServer) once you enter its IP address in this field and click on the Web Link button on the iServer’s Welcome page you'll be able to access your device using the same browser interface.

22

4.4.2.2 Ethernet Port

Ethernet Port

Address http://192.168.1.200


IP Configuration Ethernet Port

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Auto-Negotiation

Speed

Duplex

100 Mbps

Full

Save Changes Reset

10 Mbps

Half

Figure 4.14 Network: Ethernet Configuration

Auto-Negotiation – It is the link, in terms of speed and duplex, between the iServer and another Ethernet device like an Ethernet switch.

If Auto-Negotiation box is checked, the iServer will auto-negotiate the speed and duplex with the attached Ethernet device. If any of the other options are selected, the speed and duplex will be fixed.

It’s important to have the same Ethernet port configuration on the iServer and the attached Ethernet device. If iServer cannot auto-negotiate with the attached Ethernet node it will default to 10 Mbps and Half-Duplex. Once Auto-Negotiation is checked, other fields under this category will be dimmed. By default the Auto-Negotiation is checked.

If the iServer detects the link to be 100 Mbps the 100 BASE-T LED will be solid green.

4.4.3 Configuration

This menu provides configurations for the real-time clock, server parameters, sensors, and alarm relays settings. Fields are described below.

4.4.3.1 Date and Time

Current Date – This field indicates the iServer’s real time clock date. The format is

yyyy/mm/dd. When there is no date defined, the iServer will be defaulted to 2099/01/01 and be shown in red to alert you that it has not yet been set..

Current Time – This field indicates the iServer’s real time clock time. The format is military time (24-hour) and it is entered as hh:mm:ss.

Change Date and Time – By clicking on this option the real data and time can be entered.

23

4.4.3.1 Data and Time (continued)

Date and Time

Address http://192.168.1.200


Date and Time

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Server Sensors Contact Closures

Date and Time

Current Date

Current Time

Change Date and Time

Time Server

Network Time Server

NTS Address

Alarm Relays

2099/01/01 (yyyy/mm/dd)

00:00:00

Time Zone (GMT-08:00)Pacific Time(US&Canada)

Save Changes Cancel

Figure 4.15 Configuration: Date and Time

Once the AC adaptor is disconnected from the iServer and there is no battery back-up, the iServer will lose its date and time settings.

Once the iServer is rebooted from any web page, the iServer will lose its date and time settings whether or not the back-up battery is installed.

If the iServer is setup to get it’s time from a Network Time Server, then the time will be re-assigned after the reboot.

Network Time Server – If there is a time server on the network or the Internet, the iServer will get the real date and time once the Network Time Server’s IP address is provided. Default is unchecked.

NTS Address – The field to enter the Network Time Server’s IP address.

The U.S. National Institute of Standards and Technology (NIST) publishes a list of time servers on the Internet used by the NIST Internet Time Service (ITS). The list includes each server’s name, IP address, and location in the United States. As of the publication date of this manual, links to the list can be found at http://tf.nist.gov.

Time Zone – If Network Time Server option is checked, the correct time zone must be selected for the correct time display.

24

4.4.3.2 Server

Server

Address http://192.168.1.200


Date and Time Server

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Server

Server Type

Interval

Time Stamp

Sensors Contact Closures Alarm Relays

Disconnect After Data Sent

Save Changes

Command

5 secs

Reset

Figure 4.16 Configuration Menu: Server

Server Type – Options are Command and Continuous.

If Command is selected the iServer will respond to commands sent from a network host

(for the list of commands refer to Section 4.9.1).

If Continuous is selected the iServer will send temperature 1, temperature 2, differential values, contact closure and alarm relay status once every time amount selected in the

Interval box.

The Command and Continuous modes operate when a network host opens a TCP connection to the iServer’s IP address with port 2000.

In UDP Command mode, iServer will respond back with a UDP packet (to the _ address and port) if a host application sends a UDP command to iServer’s IP address with port 2000.

In UDP Continuous mode, iServer starts sending continuous data if a host application sends a trigger or UDP packet to iServer’s IP address with port 2000.

Interval – This is the time interval (in seconds) between each data transmission when the iServer is in Continuous mode. The default value is set to 5 seconds and the minimum is 2 seconds.

Time Stamp – If checked, the iServer will stamp the data with date and time before sending it out to a network host. This will apply to Command and Continuous modes.

Default is unchecked.

Disconnect After Data Sent – If checked, once the iServer responds back with data, the iServer will close the TCP connection that had been made from the network host.

This feature should be used if data acquisition software expects data to be ended by closing TCP connection from the client.

25

4.4.3.3 Sensors

This page is where the Sensor Parameters are defined. Reading 1 is for Thermocouple

Input 1, Reading 2 is for Thermocouple Input 2, and Reading 3 is for the difference between Input 1 and Input 2.

Sensors

Address http://192.168.1.200

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out


Server Sensors Contact Closures

Reading 1

Description Temperature 1 Unit C

End Character 0x

TC Type

Adjust by

K Type

0D

Scale & Offset

Reading 2

Description Temperature 2 Unit C

Alarm Relays

Data Format T0000.0C

Cold Junction

Offset 0.0

Reading Low 0.0

Reading High 100.0

End Character 0x 0D

TC Type K Type

Data Format T0000.0C

Cold Junction

Adjust by Offset Offset 0.0

Reading Low 0.0

Reading High 100.0

Reading 3

Description Differential

End Character 0x 0D

Unit C

Data Format D0000.0C

Display

Ref. Low 0.0

Ref. High 100.0

Display

Ref. Low 0.0

Ref. High 100.0

Display

Save Changes Reset

Figure 4.17 Configuration Menu: Sensors

Description – This can be a name for the sensor or where the sensor is located. This field is text only and can have up to 16 alphanumeric characters. This description will appear wherever Reading 1, 2 or 3 is displayed on the web server.

Unit – This is the unit of measurement for temperature. It can be either C for Celsius or F for Fahrenheit.

Once the unit is selected, either C or F, it will be a global change throughout the web server, as well as on the LCD display. If you use the front C/F buttons to change the unit of temperature it will have no affect on the web pages.

Display – If checked, the variable (i.e. Temperature1, Temperature2, Differential) will be displayed on the Readings and Chart applets, as well as data transmission in

Continuous mode (see Server Type Section 4.4.3.2). The default is checked.

26

4.4.3.3 Sensors (continued)

End Character – The iServer can attach a character (in Hex) to the end of temperature data packet. This will apply to either Continuous or Command mode. If 00 is entered there will be no character attached. The default is 0D (Hex representation of <CR>).

Data Format – This indicates the format of the temperature reading being displayed on a network host when Continuous transmission is used (see Server Type Section 4.4.3.2).

TC Type – This provides a list of thermocouple types to select from.

The types are J, K, T, E, R, S, B, C, N, and DINJ.

If Disabled is selected the display on the iServer and the Reading page will display

Disabled.

The default is K Type. For the list of Thermocouple types and their range and accuracy see Section 5.

Cold Junction – Click on the link and follow instructions to perform cold junction compensation for the selected thermocouple channel.

Cold junction compensation will allow you to adjust (calibrate) the thermocouple reading in reference to 0°C environment.

A correct TC Type must be selected before doing cold junction compensation.

Adjust by – If it’s determined that the reading is slightly off this field can be used to adjust the reading. The options are Offset and Scale & Offset.

Using the Offset method you can manually assign a numerical value to adjust the reading. For example if the actual reading is 55 where it should be 54 you can enter -1 in the Offset field.

The Scale & Offset method uses two points to adjust the reading within the entire temperature range. For example, if at the lower point the actual reading is 10 where it should be 12 and at the higher point the actual reading is 200 where it should 195, here is how the numbers are entered.

Reading Low 10.0

Reading High 200.0

Ref. Low 12.0

Ref. High 195.0

The adjusting numbers can be positive or negative with one decimal point.

The adjusting values must be assigned after the Unit of temperature (C or F) is selected. If the unit of temperature is changed, you must readjust the values for a correct result.

27

4.4.3.4 Contact Closure

Contact Closures

Address http://192.168.1.200


Server Sensors Contact Closures Alarm Relays

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Contacts

Contact 1

Description

Display

Output

Output

Disable

Contact In1

Active Low

Contact 2

Description

Display

Disable

Contact In2

Type Unlatch

Clear Latch

Display

Record all alarm events on the flash memory

Save Changes Reset

Retrieve

Figure 4.18 Configuration Menu: Contact Closures

Contact 1 & 2 – This configures the first and second Contact Closures on the iServer.

For wiring and pin-outs see Section 2.6. The options for Contact 1 & 2 are Disable,

Normally Open, and Normally Close. Default is Disable.

Normally Open and Normally Close are the initial states of the Contact Closure. For example, if it’s set for Normally Open, the iServer will display NORMAL status as long as the contact is open. Once the contact is closed the iServer will change the status to

ACTIVE.

If Disable option is selected the Contact Closures will be inoperable.

Description – This is a text-only field and can take up to 16 alphanumeric characters.

This can be the name of a device connected to the Contact (i.e. Alarm) or the location.

This name is displayed on the Readings webpage and responded to Command and

Continuous mode connections. Defaults are Contact In1 and Contact In2.

End Character – This means that the iServer will send a character (in Hex) after sending the state of the Contact Closure in Continuous or Command mode. Default is 0D

(Hex representation of <CR>).

Display – If checked the status of Contacts will be displayed on the Readings webpage and responded to Command and Continuous mode connections. Default is unchecked.

Output – The options are Active High and Active Low. The Output will be High or Low if the Contact 1 or Contact 2 status is changed. Default is Active Low.

28

4.4.3.4 Contact Closure (continued)

End Character – This means that the iServer will send a character (in Hex) after sending the state of the Output in Continuous or Command mode. Default is 0D (Hex representation of <CR>).

Type – The options are Unlatch and Latch. Default is Unlatch.

If it’s set to Unlatch, once the Contact is back to NORMAL the Output will automatically change to its original state.

If it’s set to Latch, once the Contact is back to NORMAL the Output will remain unchanged until the user clicks on the Clear Latch button.

Display – If checked the status of the Output will be displayed on the Readings webpage and responded to Command and Continuous mode connections. Default is unchecked.

Record contact events on the flash memory – If checked the Output status with stamped date and time will be recorded into an ASCII file on the flash memory card. By clicking the Retrieve button the file will be open. Default is unchecked.

4.4.3.5 Alarm Relays

This section would allow the two relays on the iServer to be configured as needed. For physical connections and pin-outs refer to Section 2.6.

Alarm Relays

Address http://192.168.1.200


Server Sensors Contact Closures Alarm Relays

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Relay 1

Description

Status

Type

Temperature

Alarm Relay 1

Disable

Unlatch

Clear Latch

Set Point High 0.0

Set Point Low 0.0

Relay 2

Description

Status

Type

Set Point High

Set Point Low

Humidity

Alarm Relay 2

Disable

Unlatch

Clear Latch

0.0

0.0

Display Display

Record all alarm events on the flash memory

Save Changes Reset

Retrieve

Figure 4.19 Configuration Menu: Alarm Relays

Relay 1 and Relay 2 – This configures the first and second relays on the iServer. The options for each are temperature 1, temperature 2, and differential.

This means that both Relays can be set for temperature 1 or both Relays can be set for

temperature 2, or one can be set for temperature 1 and one for differential.

29

4.4.3.5 Alarm Relays (continued)

Description – This is a text field for naming the device connected to the relay or it could be the location where the device is installed. This field can take up to 16 alphanumeric characters. This name will be displayed anywhere on the web pages associated with alarm relays; for example the Readings applet.

Defaults are Alarm Relay1 and Alarm Relay2.

Status – The options are Disable, Low, High, and Low or High. The default is Disable.

If Low is selected Set Point Low must be given a value and once the sensor reading falls below that value the relay will change status.

If High is selected Set Point High must be given a value and once the sensor reading rises above that value the relay will change status.

If Low or High is selected Set Point Low and High must be given values and relay status will change once the sensor reading is outside that range.

If Disable is selected relays will be deactivated.

Alarm status with the associated set point will be shown on the chart applet as well.

Type – The options are Unlatch and Latch. The default is Unlatch.

If Unlatch is selected and the relay is activated, once the sensor reading goes back within the Set Point range, the alarm will be deactivated automatically.

If Latch is selected, once the sensor reading goes back within the Set Point range, the relay will remain active until the user clears it by clicking on the Clear Latch button.

Set Point High – This is the field for the upper Set Point.

Set Point Low – This is the field for the lower Set Point.

End Character – This is the character (in Hex) that the iServer will send along with the alarm status.

This applies to either Continuous or Command mode described on the Server page, under the Configuration menu (Section 4.4.3.2).

The default is 0D meaning a Carriage Return character will be sent after the value.

Display – This would indicate whether to display the status of the alarm relays on the

Readings applet as well as the TCP Command and Continuous modes, and any other related fields.

The default is unchecked.

Record all alarm events on the flash memory – If checked, all the alarm events with stamped date and time will be recorded on the flash memory card.

By pressing the Retrieve button the ASCII log file will be opened.

The default is unchecked.

Using the web server, the log file can be retrieved if the file size is 32 KB or smaller. For a larger file size you must use a flash card reader to open the log file. Refer to Section 4.10.

30

4.4.4 Management

This page provides the iServer’s email, SNMP and alarm settings. SNMP (Simple

Network Management Protocol) is the protocol used by network management systems to communicate with network devices that respond to SNMP connections for the purpose of problem detections and corrections.

If SNMP and/or SMTP features are desired, please make sure iServer’s network setting as well as SNMP trap server and SMTP mail server are setup properly. Failure to do so may cause iServer to be unresponsive while waiting for these servers to reply back.

Fields are described below.

4.4.4.1 Setup

Setup

Address http://192.168.1.200

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out


Setup Alarms

Simple Network Management Protocol

SNMP Response Enabled

SNMP Community

Contact

Location

SNMP Trap Server

Simple Mail Transfer Protocol

SMTP Server

SMTP Server Port

From:

To:

Subject:

Reminder Interval

Transmission Delay

0.0.0.0

25

Save Changes Reset

60

1 public

None

None

0.0.0.0

mins mins

Figure 4.20 Management Menu: Setup

Simple Network Management Protocol

SNMP Response Enabled – If this option is checked the iServer will respond to network nodes broadcasting SNMP requests. The default is unchecked.

Make sure your network is setup properly (gateway, etc) before using SNMP feature

SNMP Community – Every SNMP communication takes place using a community string. The default is Public.

Contact – This text field specifies the contact person for this node, together with information on how to contact this person. This field takes up to 16 alphanumeric characters.

Location – This text field specifies the location of the iServer. For example it can be

“control station”, which is the place where the iServer is located. This field takes up to 16 alphanumeric characters.

SNMP Trap Server – This field contains the IP address of the SNMP trap server located somewhere on the network. The trap server listens for SNMP traps coming from the iServer when there is an alarm condition (refer to Alarms Section 4.4.4.2 under the

Management page).

31

4.4.4.1 Setup (continued)

Simple Mail Transfer Protocol

SMTP Server – This field specifies the IP Address of the SMTP server.

1) You must have an email server (SMTP server) on your network in order to receive emails generated by the iServer.

2) iServer does not support SMTP server authentication.

SMTP Server Port – This specifies the TCP port used by the SMTP Server. The default is 25.

From – This field specifies the name of the person who sends the email. It can also be an email address.

To – This field specifies the email address of the recipient. This field can take up to 200 alphanumeric characters; limited to 4 addresses of 50 characters each. Each address should be separated by a comma, without spaces. Ex: [email protected],[email protected]

You can create a “distribution group address” if you need to have more email addresses.

Subject – This field specifies the subject of the email. Emails for all the alarms will have this common subject line. Example of a subject can be “Alarm from iServer”.

Reminder Interval – This field sets a reminder interval for email and/or trap to be sent again. The allowed minimum value is 1 minute. If it’s set to 0 the iServer will not send a reminder email. The default is 60 minutes.

Power Reset alarm is only sent once, regardless of reminder interval.

Transmission Delay – Once the iServer alarm condition is met, this is the amount of time the alarm condition is met before iServer sends any email or trap. If it’s set to 0, email and/or trap will be sent immediately. The default is 1 minute.

4.4.4.1.1 Sending Text Messages to a Cell Phone

In the SMTP To field, you can use the following format to have the iServer send a text message to your cell phone. Since most cell phones are capable of receiving text messages you just need to find the correct email format for your cell phone provider.

T-Mobile [email protected]

Virgin Mobile [email protected]

AT&T

Sprint [email protected] [email protected]

Verizon

Nextel [email protected]

[email protected]

“phone_number” is your 10 digit cell phone number.

32

4.4.4.2 Alarms

Alarms

Address http://192.168.1.200


Setup Alarms

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Events

Power Reset

Probe Disconnected

Recording Stopped

Low 0.0

Temperature2

Differential

Low

Low

Low

Low 0.0

0.0

SD Card 10% Memory Left

Low Battery

Relay 1 Activated

Relay 2 Activated

Contact 1 Activated

Contact 2 Activated

High

High

High 0.0

0.0

0.0

Save Changes Reset

Figure 4.21 Management Menu: Alarms

Email SNMP Trap

There is text box next to each event. The text content will be the body of the email.

This includes events or conditions. Once a condition is met the iServer will send an email or/and an SNMP trap if either one or both are checked. Fields are described below.

Multiple alarm events can be checked and for each event an email and/or a trap will be sent.

Temperature 1– The options are Low, High, and Low or High.

If Low is selected the Low field must be given a value (lower than that value is an alarm condition).

If High is selected the High field must be given a value (higher than that value is an alarm condition).

If Low or High is selected the Low and High fields must be given values (outside the band is an alarm condition).

Temperature 2 – The same as Temperature 1 defined above.

Differential – The same as Temperature 1 defined above.

There is text box next to each event. The text content will be the body of the email.

Power Reset – This refers to the iServer being powered off and back on (power reset).

If the option is checked the iServer will automatically send one email or/and an SNMP trap after rebooting, regardless of reminder interval.

Probe Disconnected – If the probe attached to the iServer is disconnected that is considered as an alarm condition.

33

4.4.4.2 Alarms (continued)

Recording Stopped – If the iServer is recording, once the recording is stopped (no matter what the cause was) an email or/and a trap will be sent.

SD Card 10% Memory Left – An alarm will be triggered if 10% or less memory left on the flash card.

Low Battery – If the 9V battery lowers to about 7V, the iServer will prompt an alarm.

Relay 1 Activated – If relay 1 is activated the iServer will prompt an alarm. See Alarm

Relays section under the Configuration page (Section 4.4.3.5).

Relay 2 Activated – If relay 2 is activated the iServer will prompt an alarm. See Alarm

Relays section under the Configuration page (Section 4.4.3.5).

Contact 1 Activated – If contact 1 is activated the iServer will prompt an alarm. See

Contact Closures section under the Configuration page (Section 4.4.3.4).

Contact 2 Activated – If contact 2 is activated the iServer will prompt an alarm. See

Contact Closures section under the Configuration page (Section 4.4.3.4).

4.4.5 Security

This page provides security and access settings for the iServer. Fields are described below.

Security

Address http://192.168.1.200


Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Login Password

Admin Password

Local Port Password

Telnet Console Access

Web Server Access

12345678

00000000

Secured Readings and Charts

IP Exclusivity

Enable

No IP Address

1 0.0.0.0

2

3

4

0.0.0.0

0.0.0.0

0.0.0.0

Save Changes Reset

Change

Change

Change

Figure 4.22 Security Menu

34

4.4.5 Security (continued)

Login Password – To access Readings, Chart, and Web Link menus this password is required. The password length can be up to 16 alphanumeric case-sensitive characters.

To change the password click on Change.

Empty box means no password is required. The default Login Password is 12345678.

Administrator Password – To access Setup menu this password is required. The password length can be up to 16 alphanumeric case-sensitive characters. To change the password click on Change.

Empty box means no password is required. The default Administrator Password is

00000000.

This password will also be prompted when Telnet connection to port 2002 is made. Port 2002 is the Telnet console port that allows users to configure some of the parameters that can be configured through the web server.

Local Port Password – To access the iServer (via TCP or UDP socket connection to port 2000) this password is required. The maximum length can be up to 16 alphanumeric case-sensitive characters.

Empty box means no password is required. The default is none.

Telnet Console Access – If it is unchecked, Telnet console connection to port 2002 will be blocked. The iServer must be rebooted for the change to take place. The default is

checked.

Web Server Access – If it is unchecked, the iServer’s Web server will not be accessed.

The iServer must be rebooted for the change to take place. The default is checked.

When the Web Server Access is not enabled, the iServer needs to be configured using Telnet console.

If someone needs to access the Web Server again, use the Telnet console to enable it.

Secured Readings and Charts – If it is checked the Login password will be required to display Readings and Chart applets. The default is checked.

IP Exclusivity – This table contains the IP addresses that are allowed to communicate with the iServer over TCP or UDP connection. This means if the table is empty connections from all IP nodes are allowed to the iServer. If enabled, all packets from IP addresses not on this list are ignored and thrown away.

35

4.4.6 Recording

This section includes all the parameters and settings for data recording, SD flash card and recording status, data retrieval, and formatting the SD card. Fields are described below.

4.4.6.1 Start Recording

Start Recording

Address http://192.168.1.200

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out


Start Recording Status Data Retrieval Format SD Card

Current Date: 2099/01/01 (yyyy/mm/dd) Current Time: 00:00:00

Interval

Type Wrap

(1-3600)seconds

Set Date and Time

Start Date yyyy/mm/dd

Stop Date yyyy/mm/dd

Title

Quick Start Recording

Category Continuous

Start Time

Stop Time hh:mm:ss(24 hours) hh:mm:ss(24 hours)

Set Weekdays (only for scheduled recording)

Mon Tue Wed Thur Fri Sat Sun

Start Recording

Figure 4.23 Recording Menu: Start Recording

Interval – This is the time interval between each data. It can be between 1 to 3600 seconds.

Title – This is the header for each recorded data file on the SD flash card.

Quick Start Recording – If this button is clicked recording will start immediately.

Make sure your Current Date and Time are correct.

Type – The options are Wrap and Non-Wrap.

If Wrap is selected once the SD flash card is full the iServer will delete the old data stored on the card in order to record the new data. Each time a new recording takes place an old record will be deleted.

If Non-Wrap is selecetd the iServer will stop recording once the SD flash card is full.

36

4.4.6.1 Start Recording (continued)

Category – The options are Continuous and Scheduled.

In Continuous recording Start Date and Start Time fields are required. If there is not an

End Date and End Time, the recording will continue non-stop.

In Scheduled recording, any of the days can be selected and the recording will take place only on those days. Here are some important notes about the Scheduled recording:

• The Start Date, Start Time, and Stop Time must be defined. The Stop Date does not apply to Scheduled recording. This means that the Scheduled recording will never stop until the user decides to stop it.

• If the Start Date is one of the selected days recording will start on that day.

• If the Start Date is not one of the selected days recording will start on the next 1st selected day.

• The Start Time and the Stop Time apply to every single day that is selected.

• The Start Time is the time that recording will start on those selected days.

• The Stop Time is the time that recording will stop on those selected days.

• The Start Time must be earlier (at least 20 seconds) than the stop time.

• Let’s say today we’re configuring the unit for Scheduled recording. If the Start Time is earlier than the Current Time (real time clock) and today is one of the selected days, the recording will start immediately.

• Scheduled recording is suitable for users who want to start and stop recording at certain times on certain days. Users who want to have continuous recording three days a week, for instance, this feature can also be used. Just make sure to select start and stop times that would link the three days together.

For example, we need to have 3 days (72 hrs) a week continuous recording

(Monday, Tuesday, and Wednesday) with recording Interval of 1 minute. The Start

Time should be 00:00:00 and the Stop Time should be 23:59:00. This will connect all 3 days together and it will run on weekly bases.

Start Date – This is the date on which the data recording must start.

Start Time – This is the time that the recording will start. It’s based on a 24-hour format.

The Start Time must be at least twenty seconds after the Current Time (real time).

Stop Date – This is the date on which the data recording will stop. Stop Date does not apply to Scheduled recording.

Stop Time – This is the time that the recording will stop. It’s based on a 24-hour format.

A failure on the Ethernet network will not interrupt data recording.

37

4.4.6.2 Status

This page describes the Recording and SD flash card status. All the fields on this page are read-only.

Status

Address http://192.168.1.200

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out


Start Recording Status Data Retrieval

Current Date: 2099/01/01

Recording Status

Recording OFF

StartDate (yyyy/mm/dd)

(yyyy/mm/dd) StopDate

Category

Interval

StartTime

StopTime

Type

Title

Format SD Card

Current Time: 00:00:00

(hh:mm:ss)(24 hours)

(hh:mm:ss)(24 hours)

SD Card Status

SD Card Detected

SD Card Write Protected

Total Flash Size

Available Flash Size

YES

NO

1925456(KB)

1925452(KB)

Battery Status

Check Battery

Uptime 0 days,00:00:00 hh:mm:ss

Figure 4.24 Recording Menu: Status

38

4.4.6.3 Data Retrieval

This page can be used to retrieve the recorded data from the SD flash card and save it into an ASCII file.

Using the Retrieve EndDate field select the date (year, month, and day) that is the end date for the retrieved data.

Then use Retrieve Period field to identify the duration of the retrieved data; selections are: 1 Day, 1 Week, 1 Month and 1 Year.

The year, month and day dates are taken from your computer.

Now, you can press on the Start Data Retrieval button to log the data into a file.

The file is a text document with extension .data. It can be opened in Excel or Notepad or any software package that can read text files.

The fields are separated by a semi-colon (

;

) see Figure Figure 4.41 for a sample text file.

Data Retrieval

Address http://192.168.1.200

Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out



Retrieve End Date

Retrieve Period

2011

1 Day

Month

Start Data Retrieval

1

Figure 4.25 Recording Menu: Data Retrieval

Refer to Section 4.10.1 for steps that may help you to open the data file in an ASCII or Excel application.

The data recorded on the SD card can be read on a PC or MAC using a USB or any standard card reader. The file format is text and is easily imported to spread sheets and other programs. For details see Section 4.10.

39

4.4.6.4 Format SD Card

Clicking on Format SD Card button will start formatting the flash card inside the iServer.

Formatting the SD card will erase all data on the card. Allow up to 2 minutes for format to be completed which then it will display "SD Card Formatted".

Format SD Card

Address http://192.168.1.200



Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Format SD Card

Formatting SD Card will erase all data.

Allow up to 2 minutes to format.

While card is being formatted, please wait for message:

“SD Card Formatted” before continuing.

Figure 4.26 Recording Menu: Format SD Card

4.4.7 System

This menu provides various options to reboot, restore defaults, upgrade firmware and download/upload configuration for the iServer. Fields are described below.

4.4.7.1 Reboot

Reboot

Address http://192.168.1.200


Reboot Defaults Upgrade Download Configuration Upload Configuration

Overview

Network

Configuration

Management

Security

Recording

System

Di ti

Reboot

Figure 4.27 System: Reboot

Reboot – This option resets the power on the iServer.

If the iServer is recording data the reboot option will stop the recording.

It will also set the real date/time back to default unless the Network Time Server option from Configuration page, is enabled.

40

4.4.7.2 Defaults

Clicking on this button will put the iServer back to its default settings.

Defaults

Address http://192.168.1.200



Overview

Network

Configuration

Management

Security

Recording

System

Restore Factory Defaults

Figure 4.28 System: Defaults

4.4.7.3 Upgrade

Upgrade Firmware

Address http://192.168.1.200



Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Filename: iSD-TC*.bin

Upgrade

Browse...

Please make sure no other clients are connected to the device.

Consult manual for complete instructions.

Figure 4.29 System: Upgrade

Upgrade – This option loads a new firmware into the iServer over the network. The firmware is a binary file with .bin extension. This file must be kept on the same PC from which the iServer is accessed.

Once the firmware upload is completed the iServer will power reset itself. This typically takes about 30 seconds.

When doing firmware upgrade on the iServer, there should be NO other ongoing or new Web server (HTTP) connections made to the device; otherwise, the iServer will not upgrade the firmware. You can do either of the following to prevent this from happening:

1. Connect the iServer directly to the PC using a straight or crossed Ethernet cable. This will also help to have a faster firmware upload.

2. From the “Network” menu, change the Web Server Port, for example, to 500 (default is 80), save the change, and reset the power on your iServer. The next time you will access the iServer’s Web server, you must type http://192.168.1.200:500 where

192.168.1.200 is the IP address of the iServer and 500 is the new Web server port

(HTTP port).

Either one of the above options will make you the only user on that iServer.

41

4.4.7.3 Upgrade (continued)

After you have successfully upgraded your device, you can verify the firmware version number on the “Overview” page (see Section 4.4.1).

It’s recommended to set the iServer to default settings after the firmware is upgraded.

See above Section 4.4.7.2 on how to set the iServer to default settings.

Applying default settings will change the iServer’s settings to factory defaults.

If those settings are important to you and you do not want to reconfigure the iServer, you will need to do the following steps.

From the “System” menu:

1) “Download” the iServer’s configuration settings, Section 4.4.7.4.

2) “Upgrade” the iServer with the new firmware, Section 4.4.7.3.

3) Set the iServer to “Default” settings. The iServer’s IP address is now

192.168.1.200.

4) “Upload” the same configuration you obtained from step 1 onto the iServer,

Section 4.4.7.5.

4.4.7.4 Download Configuration

Clicking on this button will download the configuration file that contains all the settings stored in the iServer and use it as a reference.

Download

Address http://192.168.1.200



Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Download Configuration File

Figure 4.30 System: Download Configuration

42

4.4.7.5 Upload Configuration

Upload Configuration

Address http://192.168.1.200



Overview

Network

Configuration

Management

Security

Recording

System

Upload Configuration File *.cfg

Browse...

Please make sure no other clients are connected to the device.

Figure 4.31 System: Upload Configuration

Upload Configuration – Using this option to upload the configuration file into the iServer. It is recommended to download and store a working copy of this configuration file in case the device is configured improperly.

You can set the iServer to its default settings and upload the configuration file back into the iServer.

4.4.8 Diagnostics

This page provides the number of Ethernet packets received or transmitted. Pressing the

Reset Counter button will set the counts to zero.

Diagnostics

Address http://192.168.1.200


Overview

Network

Configuration

Management

Security

Recording

System

Diagnostics

Log Out

Ethernet

Packets

Received

4437

Transmitted

6073 Reset Counter

Figure 4.32 Diagnostics

4.4.9 Log Out

Once you click on Log Out, you will be logged out, and taken back to the Welcome page.

43

4.5 Readings

This page displays temperature 1, temperature 2, differential, and the status of the alarm relays and recording.

It can be displayed either as an HTML page or a Java applet.

4.5.1 HTML

Readings

Address http://192.168.1.200


HTML Java

Temperature 1

Temperature 2

Differential

Contact1

Contact2

Output

Recording

23.0 C

47.3 C

11.0 C

NORMAL

ACTIVE

ACTIVE LOW

ON

Refresh 2 Seconds Auto Update

Figure 4.33 Readings: HTML

Refresh – Adding a time value in seconds will automatically update the HTML page with fresh readings.

44

4.5.2 Java

If Java option is chosen installation of Java Runtime is required (refer to Appendix G).

Readings

Address http://192.168.1.200


HTML Java

Temperature 1

Temperature 2

Differential

Contact1

Contact2

Output

Recording

23.0 C

47.3 C

11.0 C

NORMAL

ACTIVE

ACTIVE LOW

ON

Refresh 2 Seconds Auto Update

Help [?]

Figure 4.34 Readings: Java

Data Logging – This option will require the Java Policy file to be setup.

Press on Help[?] for details.

An alternate way to set up the Java Policy can be found in Appendix G.

Once the Java Policy file is completed, click on Data Logging button to log the data displayed on this page into a file. The file is in comma separated values (.csv) format, which can be opened in Excel or as ASCII. The fields are separated by a comma (

,

).

When the button is ACTIVE it means that the data is currently being logged into a file.

The value in seconds in the Refresh box determines how often the data is being logged.

The default is 2 seconds.

If you want to access the “Chart” and/or the “Readings” applet from outside your local network on which the iServer is connected, you must allow ports 1001

(Readings) and 2003 (Chart) on your Router.

If a blank screen appears without any “java application running” or image of a

“Java logo”, please verify you have the latest Java Runtime Environment installed and configured according to the instructions (refer to Appendix G). If you do not have Java Runtime Environment installed, you may download it from our website

(in the software section) or contact the Customer Service Department nearest you.

“Java and the Java Coffee Cup Logo are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries."

45

4.6 Chart

This page charts the temperature1, temperature 2, and differential, in real-time across the full span or within any narrow range (such as 20 to 30ºC). The time-base can display one minute, one hour, one day, one week, one month or one year.

Chart

Address http://192.168.1.200

Readings

High 150.0 / Low 78.0

Max. 130.1 / Min. 95.9

Temperature

200

Chart Web Link

108.2 F

Recording: ON

Setup

50.8 %

High 78.0 / Low 25.0

Max. 69.9 / Min. 30.1

Humidity

100

20.0

C/Div

10.0

%/Div

0

Thu Sep 16 08:00:00 PDT 2009

Data Source: Live

Alarm Relay Set Points: Bold

Help [?]

1 Hour/Div

X-axis: 1 Day

Y-axis (left): Temperature Style: Bold

Y-axis (right): Humidity Style: Bold

0

Thu Sep 17 12:05:07 PDT 2009

Save Chart

Print Chart

Figure 4.35 Adjustable Chart

If a blank screen appears without any “java application running” or image of a

“Java logo”, please verify you have the latest Java Runtime Environment installed and configured according to the instructions (refer to Appendix G).

If you do not have Java Runtime Environment, you may download it from our website (in the software section) or contact the Customer Service Department nearest you.

High / Low – If Alarm Relays are enabled (in the Configuration menu), the set point values for High and Low alarms will be listed and graphed on the chart.

Max. / Min. – This shows the maximum and minimum values for each variable indicated on the Y-axis.

46

4.6 Chart (continued)

Data Source – The options are Live and Recorded.

If Live is selected the real-time data will be charted for the time indicated on the X-axis.

If Recorded is selected the stored data on the SD card will be charted for the time indicated on the X-axis.

Alarm Relay Set Points – This option will hide or chart (normal) the set point values.

The bold option will thicken the displayed set point lines.

If Alarm Relays are disabled (in the Configuration menu) the set points for High and Low alarms will not be graphed or displayed on the chart.

X-axis – This indicates the time, options includes one minute, one hour, one day, one

week, one month or one year.

Y-axis – The left Y-axis is dedicated to temperature 1. Either temperature 2 or

differential can be selected for the right Y-axis.

Style – This option will hide or chart (normal) the graph of the variables (temperature 1, temperature 2, and differential). The bold option will thicken the displayed graphs.

Save Chart – Save the current graph in PNG (Portable Network Graphics) format. The filename has extension .png. This option will require the Java Policy file to be setup.

Press on Help[?] for details. An alternate way to set up the Java Policy can be found in

Appendix G.

Print Chart – The displayed chart will be printed once the button is clicked.

If you want to access the “Chart” and/or the “Readings” applet from outside your local network on which the iServer is connected, you must allow ports 1001

(Readings) and 2003 (Chart) on your Router.

4.7 Web Link

This page is configured from the Network menu under IP configuration.

Refer to Section 4.4.2.1.

Web Link

Address http://192.168.1.200


Web Link

Figure 4.36 Web Link

47

4.8 Telnet Setup

With a telnet program, you can connect to the iServer using its IP address and TCP Port

2000. In Continuous mode (refer to Configuration:Sensors page Section 4.4.3.2), the telnet session will receive continuous data (temperature 1, temperature 2, and differential) from the iServer. In Command mode, a command can be sent to query the iServer.

Refer to Section 4.9.1 for list of commands. (temperature 1, temperature 2, and differential)

4.8.1 Telnet Connection

Telnet stands for Telecommunications Network, it is a protocol that provides a way for users to connect to a node with a valid IP address anywhere on an Ethernet network or the Internet . You can open a Telnet session using a terminal emulation programs like

Tera Term (downloadable from the internet), which is a free software for Windows.

You can initiate a telnet connection by typing the IP address of the iServer, and Port

2002 for logging into the iServer’s telnet consol port (see Figure 4.37). By telneting to

Port 2000, you will be able to access temperature 1, temperature 2, and differential, readings.

The default password for Telnet Login is 00000000 and can be changed if desired.

Tera Term: New Connection

TCP/IP: Host: 192.168.1.200

TCP port#: 2002

Telnet

Protocol: UNSPEC

Serial:

COM1: Communications Port {COM1

OK Cancel Help

Figure 4.37 Tera Term Telnet Connection Screen

Once the connection is established you will be prompted for an Administrator Password

(default is 00000000). Telnet console port (2002) allows users to configure some parameters within the iServer. Figure 4.39 shows the parameters that can be changed.

After connecting to the iServer, you can use the following commands to read, modify, and get help.

p

?

s displays the current settings (Figure 4.38) displays all the available options as well as an example on how to enter a command (Figure 4.39) set a new configuration (see the example in Figure 4.39), sending the command c is required to permanently store the new settings c q

RESET restart the iServer.

FACTORY set the iServer to it’s factory default settings, the RESET command is required after the FACTORY command permanently store the new settings quit the telnet session

48

4.8.1 Telnet Connection (continued)

1.0

Administrator Password?00000000

iSD-TC> iSD-TC>Configuration Commands:

1.0

Administrator Password?00000000

iSD-TC> iSD-TC>p

Model: iSD-TC

Firmware Ver: 1.0

DP: Disabled (0)

MC: 00:03:34:00:B9:B6

IP: 192.168.1.200

SM: 255.255.255.0

GW: 0.0.0.0

LP: 12345678

SP: 00000000

CP:

TC: Enabled (1)

WS: Enabled (1)

SR: Enabled (1) iSD-TC>

Figure 4.38

Telnet to Port 2002 – p command iSD-TC>

Figure 4.39

Telnet to Port 2002 – ? command

4.9 HTTPget Program

The HTTPget software is used to send a single HTTP or TCP request to an iServer product. In contrast, the telnet or Hyperterminal programs allow a continuous connection with multiple requests to be sent to the iServer product.

Generally HTTPget is used for simply programming an IP address to the iServer or for quickly obtaining a reading of from a device.

The iServer product must be configured from the configuration web page so that the

"Server Type" value is set to "Command", refer to Section 4.4.3.2.

49

4.9.1 HTTPget using Port 2000

You can setup and read the information from the iServer by using the HTTPget program.

The following program can be used to read data from the iServer by using TCP port

2000. The command string is sent to this TCP port, then the response can be read back from the same socket.

The HTTPget.exe file is used to setup and read information from the iServer. This file can be downloaded from the website listed on the cover of this manual (software section).

Notes on using HTTPget :

The HTTPget.exe program should be installed to the windows directory (usually c:\winnt or c:\windows)

1.

Open up a command window (or have a DOS window) a) Click on start menu b) Click on "Run" c) In the dialog box that appears, type "cmd" or "command" and click on "OK" button.

d) A command window should now appear.

2.

If you now type "httpget" and press the "enter" key, the program options should be displayed.

3.

Next run HTTPget with the options displayed below httpget -r -S “*SRTC\r” 192.168.1.200:2000 where:

-r –S are parameters needed for the command string

*SRTC is the command as the following:

*SRTC

*SRTF

*SRHC

*SRHF

*SRDC

*SRDF

*SRA1

*SRA2

Read the temperature in C, celcius (Channel 1)

Read the temperature in F, fahrenheit (Channel 1)

Read the temperature in C (Channel 2)

Read the temperature in F (Channel 2)

Read the differential in C

Read the differential in F

Read alarm set points for relay 1

Read alarm set points for relay 2

*SRB

*SRBF

Read the temperature in C and humidity

Read the temperature in F and humidity

*SRYS

Indicate AC or DC power and battery status

*SRYRST

Reset Power on

*SR_XD1

Disable alarm condition check for relay 1

*SR_XD2

Disable alarm condition check for relay 2

50

4.9.1 HTTPget using Port 2000 (continued)

*SR_XC1

*SR_XC2

*SR_XE1

Reset relay 1 latch condition

Reset relay 2 latch condition

*SR_XE2

Re-enable alarm condition check for relay 1 (must be executed after *SR_XD1)

Re-enable alarm condition check for relay 2 (must be executed after *SR_XD2)

*SR_XP1

*SR_XP2

*SR_XH1

*SR_XH2

*SR_XL1

Close relay 1 for < 200 mSec

Close relay 2 for < 200 mSec

Close relay 1

Close relay 2

Open relay 1

*SR_XL2

*SR_XR1

*SR_XR2

*SRT2

*SRH2

*SRD2

Open relay 2

Read current state of relay 1

Read current state of relay 2

Status of Contact 1 (Disable, Normal, Active)

Status of Contact 2 (Disable, Normal, Active)

Status of the Output associated with the Contacts

(Active High, Active Low)

\r is the carriage return termination character

192.168.1.200 is an IP address

2000 is a socket port number

Response:

076.6 (in Deg.F format)

4.10 Flash Card Reader

The data recorded on the SD card can be read on a PC or MAC with a USB or any standard card reader.

The format is a simple “.txt” text file that is easily imported in MS Excel or MS WordPad or any software package that can read text files (see Figure 4.41).

The entire recording session is saved into a file kept in the root directory.

The name of this file is S followed by the date the recording was started , so for example:

S20100401.txt is April 1st, 2010.

The same recording data is also saved into daily files located in a series of month and year directories in which the recording took place (see Figure 4.40).

51

4.10 Flash Card Reader (continued)

E:\

File Edit View Favorites Tools Help

Name

2010

Events

S20100401.txt

Size

15,598KB

Type

File Folder

File Folder

Text Document

Date Modified

4/01/2010 8:08AM

4/01/2010 8:08AM

5/02/2010 1:08PM

E:\2010


Name

04

05

Size Type

File Folder

File Folder

Date Modified

4/01/2010 8:08AM

5/02/2010 1:08PM

E:\2010\04


Name

20100401.txt

20100402.txt

20100403.txt

20100404.txt

20100405.txt

20100406.txt

20100407.txt

Size

598 KB

598 KB

598 KB

598 KB

598 KB

598 KB

598 KB

Type

Text Document

Text Document

Text Document

Text Document

Text Document

Text Document

Text Document

Date Modified

4/02/2010 12:00AM

4/03/2010 12:00AM

4/04/2010 12:00AM

4/05/2010 12:00AM

4/06/2010 12:00AM

4/07/2010 12:00AM

4/08/2010 12:00AM

Figure 4.40 Recorded Data File Directory

#2010/04/02;09:00:00;23.3C;36.6C;13.3C;

#2010/04/02;09:00:10;23.1C;36.5C;13.4C;

#2010/04/02;09:00:20;23.3C;36.6C;13.3C;

#2010/04/02;09:00:30;23.3C;36.4C;13.1C;

#2010/04/02;09:00:40;23.1C;36.6C;13.5C;

Figure 4.41

Example of data recorded on the

SD card, standard text (.txt) file format

4.10.1 Opening .txt Data Files

1. Right-click on the data file and select Open with Wordpad. This will display the ASCII data in WordPad.

2. From the Edit menu select the Replace option to replace all the with

,

(commas).

;

(semicolons)

3. From the File menu select Save As and save the file with an extension .csv (Comma

Separated Value).

4. This .csv file can now be opened in Excel with the correct format.

Alternatively, you can do the following--

1 Open Excel. Go to File, Open, select Files of Type: Choose Text files (*.prn, *.txt,

*.csv), and then select the data file you wish to open.

2. A Text Import Wizard should pop-up.

Select Delimited type of file, then Next.

Click on semicolon as the Delimiter type, then Next.

The screen should show how the file is being divided into columns, click on Finish.

3 From the File menu select Save As and save the file with an extension .csv.

The next time you open this file it will open in Excel automatically.

You may remove the letters C or F and D from the recorded values (using the

Replace option of Excel or Wordpad). This will enable you to create charts of the data.

52

4.11 iLog Software

This is an Excel application software that can log temperature 1, temperature 2 and the differential from the iServer over the local network (Ethernet) or the internet. a) Download the iLog software from the website listed in this manual.

b) Install iLog software on a networked PC. This software is compatible with Windows

95, 98, NT, 2000, XP, Windows Vista and Windows 7 (32 and 64-bit). c) If you have Excel 2007 or higher, when installing iLog choose “Custom” installation option and on the next window check the box for “Excel 2007 Apps” and continue the installation to the end.

d) For complete information of how to use the iLog software, click on the HELP button.

e) There is a list of Error Messages in Appendix F.

Figure 4.42 iLog Software Logging Data

The Options button will let you select the product model.

Choose iSE-TC from the Model Selection pull-down menu (from General tab).

53

iLog Software (continued)

Table 4.1 iLog Excel Applications

The iLog application actually consists of several Excel files, though most supported devices can be accessed by the main iLog program. The main program is listed as

"iLog", plus a version number, under the Start Menu program links (those links available by clicking the Start button on the Windows taskbar).

In the following table, the iLog File column shows how many sensors are logged by the main iLog file. If more than 3 sensors are available, then the Alternate column shows how many sensors the device can support. Devices with more than 3 sensors will have their own Excel file. For these files, click on the model device found in the Start Menu.

Networked Product iTHX-W, iTHX-2 iTHX-M, iTHX-SD iTHX-W Dual Probe iSE-TC, iSD-TC iSE-TH, iSD-TH iBTHX-W, iBTHX-D iBTX-W/-D, iBTX-M, iBTX-SD iPTX-W iTCX iTH Controller iVI iSeries iDRX/iDRN

INF-B iLog File

3 column

3 column

1st probe / 3 column

3 column

3 column

3 column

2 column

2 column

3 column

3 column

3 column

1 column

1 column

1 column

Alternate

6 column

5 column

5 column

4 column

4 column

Wireless Devices

The "Auto" column shows number of columns per remote device that are possibly displayed.

The Full column shows number of columns allocated per device for the "Full" spreadsheet, which will be able to display all data for all active devices.

Networked Product zSeries Receiver and Remotes wiSeries with zED Remotes

UWTC REC-3 and Remotes wiSeries with UWTC Remotes

Auto

1 to 4 column / device


1 or 2 column / device


Full

4 column / 32 device




The active wireless devices, when shown in the Excel application, will be shown with the device number and the units returned.

54

PART 5

SPECIFICATIONS

SENSOR SPECIFICATIONS

Thermocouple Input

Temperature Range:

Temperature Accuracy:

Resolution: refer to Thermocouple Chart refer to Thermocouple Chart

1°/0.1°

Temperature Stability: 0.08°C/°C

Thermocouple Cold End Tracking: 0.05°C/°C

Thermocouple Lead Resistance:

Thermocouple Type (ITS 90):

100 ohm max.

J, K, T, E, R, S, B, C, N, L

L

Input Type

Iron - Constantan

CHROMEGA

CHROMEGA

®

®

- ALOMEGA

Copper - Constantan

- Constantan

Pt / 13%Rh-Pt

Pt / 10%Rh-Pt

30%Rh-Pt / 6%Rh-Pt

5%Re-W / 26%Re-W

Nicrosil - Nisil

J DIN

®

Range Accuracy

-210 to 760°C / -346 to 1400°F 0.4°C / 0.7°F

-260 to -160°C / -160 to 1372°C 1.0°C / 0.4°C

-436 to -256°F / -256 to 2502°F 1.8°F / 0.7°F

-270 to -190°C / -190 to 400°C 1.0°C / 0.4°C

-454 to -310°F / -310 to 752°F 1.8°F / 0.7°F

-270 to -220°C / -220 to 1000°C 1.0°C / 0.4°C

-454 to -364°F / -364 to 1832°F 1.8°F / 0.7°F

-50 to 40°C / 40 to 1768°C

-58 to 104°F / 104 to 3214°F

1.0°C / 0.5°C

1.8°F / 0.9°F

-50 to 100°C / 100 to 1768°C 1.0°C / 0.5°C

-58 to 212°F / 212 to 3214°F 1.8°F / 0.9°F

600 to 1820°C

1112 to 3308°F

0 to 2320°C / 32 to 4208°F

1.0°C

1.8°F

0.4°C / 0.7°F

-250 to -100°C / -100 to 1300°C 1.0°C / 0.4°C

-418 to -148°F / -148 to 2372°F 1.8°F / 0.7°F

-200 to 900°C / -328 to 1652°F 0.4°C / 0.7°F

55

iSERVER SPECIFICATIONS

Interfaces

Ethernet (RJ45):

Supported Protocols:

LED Indicators:

LCD Display:

Memory Data Flash Card:

Relay Outputs:

Alarm I/Os

Fixed or auto-negotiating 10/100Base-T; Auto MDI/MDIX

TCP, UDP, SNMP, SMTP, SNTP , ARP, ICMP, DNS, DHCP,

HTTP, and Telnet

100 BASE-T, Network Link and Activity, DHCP, Recording

32 digits, 4.8 x 9.7mm (0.19 x 0.38”)

2 GB SD Flash Card for 8 months of data storage at

1 second recording intervals, or 7 years at 10 seconds

Two relays 1.5 A @ 30 Vdc

Two contact inputs TTL 0.5 mA with 10K pull-up; one open collector output 150 mA @ 30 Vdc

16 samples/second max.

Sample Rate:

Management:

Embedded WEB Server:

Device configuration and monitoring through embedded

WEB server

Serves WEB pages containing real-time data and live updated charts within definable time intervals.

POWER

Power Input:

Consumption:

Safety Qualified

9 to 12 Vdc

4W ac Power Adapter (included) Nominal Output: 9 Vdc @ 0.5 A

Input: 100 to 240 Vac, 50/60Hz

Back-up Battery: 9 Vdc, alkaline. 30 hours at 10 second recording intervals, or 60 hours at 1 minute intervals

ENVIRONMENTAL

Operating Temperatures iServer Unit:

Battery: ac Power Adapter:

Industrial Cable:

Storage Temperature:

Material:

0 to 60°C (32 to 140°F)

-18 to 55°C (-0.4 to 131°F)

0 to 40°C (32 to 104°F)

-40 to 125°C (-40 to 257°F)

-40 to 85°C (-40 to 185°F)

SS 304 case with wall mount bracket iServer Housing Dimensions: 88.1H x 130.2W x 33.3D mm (3.47 x 5.13 x 1.31”)

Weight: 462 g (1.02 lbs.), including battery

GENERAL

Agency Approvals:

Software:

FCC-B, CE

Compatible with Windows operating systems

Firmware upgrade from Ethernet

OPC Server

iConnect: Configuration software for the Ethernet interface

iLog: Macro for automatic data logging in MS Excel

56

Appendix A GLOSSARY

User of this manual should be familiar with following definitions:

ARP (Address Resolution Protocol) is a protocol for mapping an Internet Protocol address

(IP address) to a physical machine address that is recognized in the local network. For example, the IP address in use today is an address that is 32-bits long. In an Ethernet local area network, however, addresses for attached devices are 48-bits long. (The physical machine address is also known as a Media Access Control or MAC address.) A table, usually called the ARP cache, is used to maintain a correlation between each MAC address and its corresponding IP address.

ARP provides the protocol rules for making this correlation and providing address conversion in both directions.

Ethernet is a network protocol defined by the IEEE 802.3 standard. Ethernet-based networks use MAC Address rather then IP Address to exchange data between computers. By using ARP and adding TCP/IP support, Ethernet devices may be connected as part of the

Internet. An Ethernet LAN typically uses coaxial cable or special grades of twisted pair wires.

The most commonly installed Ethernet systems are called 10BASE-T and provide transmission speeds up to 10 Mbps. Devices are connected to the cable and compete for access using a

Carrier Sense Multiple Access with Collision Detection (CSMA/CD) protocol.

IP (Internet Protocol) is the method or protocol by which data is sent from one computer to another on the Internet.

IP address (Internet Protocol address) is a 32-bit number that identifies each sender or receiver of information that is sent in packets across the Internet.

IP Netmask is a 32-bit pattern of bits used to determine which part of the IP address is the network portion and which part is the host portion.

MAC (Media Access Control) Address is your computer's unique hardware number. When you're connected to the Internet from your computer, a correspondence table relates your IP address to your computer's physical (MAC) address on the LAN.

Ping is a utility that tests the network connectivity. It is used to determine if the host is capable of exchanging information with another host.

Port number/Socket number is a way to identify a specific process to which an Internet or other network message is to be forwarded when it arrives at a server. It is a predefined address that serves as a route from the application to the Transport layer or from the Transport layer to the application of the TCP/IP system.

Sockets are a method for communication between a client program and a server program in a network and defined as "the endpoint in a connection." Information transferred across the

Internet primarily occurs between sockets.

SMTP Simple Mail Transfer Protocol is an Internet standard for electronic mail (email) transfer across the Internet. SMTP clients usually use SMTP to send email messages by specifying the

SMTP server. The email server uses SMTP to both send and receive email messages.

SNMP Simple Network Management Protocol is a network monitoring protocol to monitor devices connected to an Ethernet Network.

TCP/IP (Transmission Control Protocol/Internet Protocol) is the basic communication language or protocol of the Internet. When you are set up with direct access to the Internet, your computer is provided with a copy of the TCP/IP program just as every other computer that you may send messages to or get information from also has a copy of TCP/IP. TCP/IP often is used as a general term to indicate generic access to the Internet.

UDP/IP (User Datagram Protocol/Internet Protocol) is the TCP/IP standard protocol that allows an application program on one machine to send a datagram to an application program on another. The UDP can be either in Broadcast or Directed form. The Broadcast UDP transmits data to every node on the same network. The Directed UDP transmits data to one node only.

57

Appendix B IP Address

An IP address is a unique 32-bit address assigned to a computer and includes:

• A network ID number identifying a network.

• A host ID number identifying a computer on the network.

All IP addresses have been divided into three smaller groups (classes) A, B and C

• Class A addresses have 8-bits of network ID and 24-bits of host ID. They can support a large number of hosts, approximately 2 = 16,777,216 computers per network.

The IP addresses range in binary from 00000001.xxxxxxxx.xxxxxxxx.xxxxxxxx

to 01111111.xxxxxxxx.xxxxxxxx.xxxxxxxx

The IP addresses range in decimal from 1.x.x.x to 127.x.x.x

Class A network ID’s support a very large number of hosts.

• Class B addresses have 16-bits of network ID and 16-bits of host ID. They can support approximately 2 16 = 65,536 computers per network.

The IP addresses range in binary from 10000000 00000000.xxxxxxxx.xxxxxxxx

to 10111111 11111111.xxxxxxxx.xxxxxxxx

The IP addresses range in decimal from 128.0.x.x TO 191.255.xxx.xxx

Class B network ID’s support a medium number of hosts.

• Class C addresses have 24-bits of network ID and 8-bits of host ID. They can support approximately 2

8

= 256 computers per network.

The IP addresses range in binary from 11000000.00000000.00000000.xxxxxxxx to 11011111.11111111.11111111.xxxxxxxx

The IP addresses range in decimal from 192.0.0.xxx to 223.255.255.xxx

Class C network ID’s support a small number of hosts.

The rest of the addresses are divided into two classes, D and E.

Class D networks are not assigned to the host. They are used for multicasting.

The address range from 224.x.x.x to 239.x.x.x

Class E networks are experimental or reserved addresses.

The address range from 240.x.x.x to 247.x.x.x

58

Appendix C ARP Commands

ARP is the Internet layer protocol responsible for matching or obtaining the MAC

(hardware) address that corresponds to a particular IP address. The ARP command allows the user to view the current contents of the ARP cache of the local computer

(residing on the same network). Microsoft includes the ARP.EXE utility for viewing and modifying the ARP cache with its Windows products. The following ARP commands can be used to view cache entries:

• arp –a fi Use this command to view all ARP cache entries.

• arp –a plus IP address fi Use this command to view ARP cache entries associated with one particular interface on a network with multiple adapters.

• arp –g fi Same as arp –a.

• arp –N fi Use this command to display ARP entries for specific network interface.

• arp – s plus IP address plus Physical address fi Use this command to manually add a permanent static entry to the ARP cache.

• arp –d fi Use this command to manually delete a static entry.

Ping the destination computer using IP address first before using the arp -a command.

The following window shows examples of arp commands and responses.

• Your computer has an IP address of 192.168.1.118

• The destination computer has an IP address of 192.168.1.96

Figure C.1 ARP Commands and Responses

59

Appendix D IP Netmask

IP Netmask or Subnet Mask is a 32-bit pattern of ones and zeros used to determine network portion of an IP address from the host portion of the IP address. Subnet mask is a network ID that is created by borrowing bits from host portion of IP address and using them as part of a network ID. The table below shows a default subnet mask for address

Classes A, B, and C. Each bit that is set to "1" in the subnet mask corresponds to the bit in the IP address that is to be used as the network ID. Each bit that is set to "0" in the subnet mask corresponds to a bit in the IP address that is to be used as the host ID.

Address Class

Class A

Class B

Class C

11111111

11111111

11111111

Mask Binary Value

00000000

11111111

11111111

00000000

00000000

11111111

00000000

00000000

00000000

Mask Decimal Value or Dotted Notation

255.0.0.0

255.255.0.0

255.255.255.0

If your network requires more network ID’s, you can extend the default subnet mask to include additional bits from the host ID. This allows for additional network ID’s within the network. The table below shows some examples of subnet masks and bits moved from the hosts ID to create a new subnet.

Mask Dotted Notation

255.0.0.0 (Default)

255.192.0.0

255.224.0.0

255.240.0.0

255.248.0.0

255.252.0.0

11111111

11111111

11111111

11111111

11111111

11111111

Mask Binary

Class A

00000000

11000000

11100000

11110000

11111000

11111100

00000000

00000000

00000000

00000000

00000000

00000000

00000000

00000000

00000000

00000000

00000000

00000000

Mask Bits

4

5

6

0

2

3

255.255.0.0

255.255.128.0

255.255.192.0.0

…………….........

255.255.255.252

255.255.0.0 (Default)

255.255.192.0

…………….........

255.255.255.252

255.255.255.0 (Default)

255.255.255.192

………………….

255.255.255.254

11111111

11111111

11111111

. . . . . . . .

11111111

11111111

11111111

. . . . . . . .

11111111

11111111

11111111

. . . . . . . .

11111111

11111111

11111111

11111111

. . . . . . . .

00000000

10000000

11000000

. . . . . . . .

11111111 11111111

Class B

11111111

11111111

. . . . . . . .

00000000

11000000

. . . . . . . .

11111111 11111111

Class C

11111111

11111111

. . . . . . . .

11111111

11111111

11111111

. . . . . . . .

11111111

00000000

00000000

00000000

. . . . . . . .

11111100

00000000

00000000

. . . . . . . .

11111100

00000000

11000000

. . . . . . . .

11111100

8

9

10

.

22

0

2

.

14

0

2

.

6

To determine the number of valid hosts ID’s remaining after subnetting, use the following equation: 2 n – 2, where n is the number of octet digits left after the subnet mask.

60

Hex

1C

1D

1E

1F

18

19

1A

1B

14

15

16

17

10

11

12

13

0C

0D

0E

0F

08

09

0A

0B

04

05

06

07

00

01

02

03

28

29

2A

2B

2C

2D

2E

24

25

26

27

20

21

22

23

Appendix E

ASCII Dec

Char

CAN

EM

SUB

ESC

FS

GS

RS

US

DLE

DC1

DC2

DC3

DC4

NAK

SYN

ETB

BS

HT

LF

VT

FF

CR

SO

SI

NUL

SOH

STX

ETX

EOT

ENQ

ACK

BEL

-

,

.

)

(

*

+

$

%

&

‘

SP

!

"

#

28

29

30

31

24

25

26

27

20

21

22

23

16

17

18

19

12

13

14

15

08

09

10

11

04

05

06

07

00

01

02

03

40

41

42

43

44

45

46

36

37

38

39

32

33

34

35

Dec

92

93

94

95

88

89

90

91

84

85

86

87

80

81

82

83

76

77

78

79

72

73

74

75

68

69

70

71

64

65

66

67

104

105

106

107

108

109

110

96

97

98

99

100

101

102

103

ASCII Chart

Binary

No Parity

00010000

00010001

00010010

00010011

00010100

00010101

00010110

00010111

00011000

00011001

00011010

00011011

00011100

00011101

00011110

00011111

00000000

00000001

00000010

00000011

00000100

00000101

00000110

00000111

00001000

00001001

00001010

00001011

00001100

00001101

00001110

00001111

00100000

00100001

00100010

00100011

00100100

00100101

00100110

00100111

00101000

00101001

00101010

00101011

00101100

00101101

00101110

61

ASCII

Char

]

\

^

_

X

Y

Z

[

T

U

V

W

P

Q

R

S

L

M

N

O

H

I

J

K

D

E

F

G

@

A

B

C l m n h

I j k d e f g b c

` a

Hex

5C

5D

5E

5F

58

59

5A

5B

54

55

56

57

50

51

52

53

4C

4D

4E

4F

48

49

4A

4B

44

45

46

47

40

41

42

43

68

69

6A

6B

6C

6D

6E

64

65

66

67

60

61

62

63

Binary

No parity

01010000

01010001

01010010

01010011

01010100

01010101

01010110

01010111

01011000

01011001

01011010

01011011

01011100

01011101

01011110

01011111

01000000

01000000

01000010

01000011

01000100

01000101

01000110

01000111

01001000

01001001

01001010

01001011

01001100

01001101

01001110

01001111

01100000

01100001

01100010

01100011

01100100

01100101

01100110

01100111

01101000

01101001

01101010

01101011

01101100

01101101

01101110

Appendix E

8

9

;

:

4

5

6

7

<

=

>

?

1

2

3

/

0

56

57

58

59

52

53

54

55

60

61

62

63

47

48

49

50

51

3C

3D

3E

3F

38

39

3A

3B

34

35

36

37

2F

30

31

32

33

ASCII Chart Continuation

00101111

00110000

00110001

00110010

00110011

00110100

00110101

00110110

00110111

00111000

00111001

00111010

00111011

00111100

00111101

00111110

00111111 o p q r s t u v w x y z

|

{

}

~

DEL

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

7C

7D

7E

7F

78

79

7A

7B

74

75

76

77

6F

70

71

72

73

01101111

01110000

01110001

01110010

01110011

01110100

01110101

01110110

01110111

01111000

01111001

01111010

01111011

01111100

01111101

01111110

01111111

ASCII Control Codes

ASCII Dec Hex Ctrl Key Definition ASCII Dec Hex Ctrl Key Definition

Char Equiv.

Char Equiv.

NUL 00 00 Crtl @ Null Character DC1 17 11 Crtl Q Data Control 1

- XON

SOH 01 01 Crtl A Start of

Header

DC2 18 12 Crtl R Data Control 2

STX 02 02 Crtl B Start of Text DC3 19 13 Crtl S Data Control 3

- XOFF

ETX 03 03 Crtl C End of Text DC4 20 14 Crtl T Data Control 4

EOT 04 04 Crtl D End of NAK 21 15 Crtl U Negative

ENQ 05 05 Crtl E

Transmission

Inquiry SYN 22 16 Crtl V

Acknowledge

Synchronous

Idle

ACK 06 06 Crtl F Acknowledge ETB 23 17 Crtl W End of Trans

Block

BEL 07 07 Crtl G Bell CAN 24 18 Crtl X Cancel

BS 08 08 Crtl H Back Space EM 25 19 Crtl Y End of Medium

HT 09 09 Crtl I Horizontal

Tabulation

SUB 26 1A Crtl Z Substitute

LF 10 0A Crtl J

VT 11 0B Crtl K

FF 12 0C Crtl L

Line Feed

Vertical

Tabulation

Form Feed

ESC 27 1B Crtl [ Escape

FS 28 1C Crtl \ File Separator

GS 29 1D Crtl ]

CR 13 0D Crtl M Carriage

Return

RS 30 1E Crtl |

Group

Separator

Record

Separator

SO 14 0E Crtl N

SI 15 0F Crtl O

DLE 16 10 Crtl P

Shift Out

Shift In

Data Link

Escape

US 31 1F Crtl _ Unit Separator

SP 32 20 Space

62

Appendix F iLog Error Messages

Table F-1 iLog Error Messages

Error # Description

-8003 User stopped logging readings.

-10005 Failed to find the iServer.

Note

Ethernet cable is disconnected, iServer is powered off, connections across the firewall require longer

“connection to socket time out” setting.

-10006 Windows socket was closed.

-10007

-10008

Windows socket error.

The iServer failed to respond to a request.

Wrong IP or wrong Port number was used.

Wrong IP or wrong Port number was used.

-10011 Response came empty.

-10012 Device responded with

"Serial Time Out" string.

No data was sent.

Possibly the iLog is configured for wrong product model.

-10014 Terminal Server Mode when the Port is Try to set “disconnect after data configured to disconnect after sending data.

sent” under Configuration/Server

-15100 Error on obtaining the temperature reading.


-1 Device responded with

"Command not found" string.


63

Appendix G Java Runtime Environment Setup

G.1 Java Runtime Environment Setup

If your computer does not have Java installed, please download from java.sun.com. You can change the Java setting by clicking its icon in Control Panel. To load the applet, you have to enable the web browser and disable cache.

G.1.1 Java Runtime Environment 1.7 Setup instructions

1. Go to your computer's Control Panel. Open the Java Plug-in.

Figure G.1 Java 1.7 Screen Shot

The "Data Logging" button on the "Readings" page, "Save Chart" button on the

"Chart" page, and the "Retrieve" button on the "Recording Data Retrieval" page will not be active if the instructions explained in the above are not followed.

64

G.2 Browser Proxy Selection

Accessing iServer within your internal network

• Usually when the computer and iServers are on an internal network, you will not use

Proxy server access.

• You should un-check the "Use Browser Settings" option on the "Proxy" tab.

Accessing iServers units using the internet

• Often the web browser will use Proxy server access to the internet. In such cases, the default Java runtime settings on the "Proxy" tab should suffice. The default setting is the "Use Browser Settings" option.

• If the default proxy setting doesn't work, then you may have a situation where the proxy settings of the web browser are incorrect.

Diagnostics:

If the web page of the iServer appears, then the HTTP Proxy is working fine.

If the data isn't updated on the iServer upon selecting the "Readings" or "Chart" web page, there may be a problem with access through a winsock proxy server. In such cases your network administrator will need to provide the winsock proxy server and port

#s. .

These values should be entered into the Socks line on the "Proxy" tab (of the Java

Plugin control panel) or into the "connections" tab on the View,Internet Options dialog and make sure that the Proxy tab shows that the "Use Browser Settings" option is not selected (i.e. when you specify proxy connections in the Java Plugin control panel).

Accessing iServer units over Peer-to-Peer network

A simple peer-to-peer network is setup by disconnecting from the main network (as users will often do when trying to do initial setup of the iServer) and then connecting the iServer to another computer using an ethernet hub, an ethernet switch, or a Cross-over cable connection.

Often when using a peer-to-peer network, the Java plugin and the web browser (such as

Internet Explorer) have internet connections configured to connect through proxy servers. In such case, you will need to simply assign the final IP address on this peer to peer network and then view the iServer charts after connecting the iServer into the regular network. Otherwise you can disable the Java plug-in's "Use Browser Settings" temporarily and then reconfigure the Java plug-in settings for regular network access after testing the iServer chart access on your peer-to-peer network.

The "Use Browser Settings" should not be selected. And the HTTP and Socks proxy entries s hould be blank. Also, setup the internet browser so that proxy servers are disabled.

65

Appendix H SNMP

Table H-1 SNMP MIB-2

Version: SNMPv1 Private Enterprise Number: .1.3.6.1.4.1.34089

MIB-2 (RFC 1213) supported: System Group

Object Identifier Object

(OID)

.1.3.6.1.2.1.1.1

Description sysDescr The name and version identification of the product

.1.3.6.1.2.1.1.2

.1.3.6.1.2.1.1.3

.1.3.6.1.2.1.1.4

.1.3.6.1.2.1.1.5

Access

Read-only sysObjectID The authoritative identification Read-only of the network management subsystem contained in the product. This value is allocated within the SMI enterprises subtree (1.3.6.1.4.1).

Read-only sysUpTime The time since the system was last re-initialized.

sysContact The contact person for this node, together with information on how to contact this person.

Read-write sysName The hostname of this node.

Read-write

Default iSD-TC/ X.XX

X.XX is the firmware version

.1.3.6.1.4.1.34089.X.X

X.X is the product system object ID

None

.1.3.6.1.2.1.1.6

.1.3.6.1.2.1.1.7

sysLocation The physical location of this node.

sysServices The set of services that this product primarily offers.

The value is a sum of network layer services implemented.

Read-write

Read-only

Table H-2 SNMP Trap

SNMP Trap (RFC 1157) version: SNMPv1

Generic trap type: enterpriseSpecific(6)

Specific Trap Alarm Description

0 Reading 1

1 Reading 2

4

5

2

3

6

Reading 3

Reserved

Power reset

Sensor disconnected

Recording stopped isdXXXX

XXXX are the last

4 characters of the

MAC address

None

76

Services include application, end-to-end and internet

Specific Trap Alarm Description

7 SD card 10% memory left

8 Low battery

9

10

11

12

Relay 1 activated

Relay 2 activated

Contact 1 activated

Contact 2 activated

66

NOTES

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

NOTES

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

______________________________________________________________________________

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of one (1) year from the date of purchase. In addition to OMEGA’s standard warranty period, OMEGA Engineering will extend the warranty period for one (1) additional year if the warranty card enclosed with each instrument is returned to OMEGA.

If the unit malfunctions, it must be returned to the factory for evaluation. OMEGA’s Customer Service Department will issue an

Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of having been damaged as a result of excessive corrosion; or current, heat, moisture or vibration; improper specification; misapplication; misuse or other operating conditions outside of OMEGA’s control. Components which wear are not warranted, including but not limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any damages that result from the use of its products in accordance with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by it will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR

REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESS OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL

IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive, and the total liability of OMEGA with respect to this order, whether based on contract, warranty, negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for consequential, incidental or special damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way, OMEGA assumes no responsibility as set forth in our basic WARRANTY/DISCLAIMER language, and, additionally, purchaser will indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in such a manner.

RETURN REQUESTS/INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING

ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM

OMEGA’S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return package and on any correspondence.

The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.

FOR WARRANTY RETURNS, please have the following information available BEFORE contacting OMEGA:

1. Purchase Order number under which the product was

PURCHASED,

2. Model and serial number of the product under warranty, and

3. Repair instructions and/or specific problems relative to the product.

FOR NON-WARRANTY REPAIRS, consult OMEGA for current repair charges. Have the following information available

BEFORE contacting OMEGA:

1. Purchase Order number to cover the COST of the repair,

2. Model and serial number of product, and

3. Repair instructions and/or specific problems relative to the product.

OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest in technology and engineering.

© Copyright 2013 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.

TRADEMARK NOTICE:

®

, omega.com

® , , and

® are Trademarks of OMEGA ENGINEERING, INC.

PATENT NOTICE: This product is covered by one or more of the following patents: U.S. Pat. No. Des. 336,895; 5,274,577/

CANADA 2052599; 2052600 / ITALY 1249456; 1250938 / FRANCE BREVET No. 91 12756 / SPAIN 2039150; 2048066 / UK

PATENT No. GB2 249 837; GB2 248 954 / GERMANY DE 41 34398 C2. Other US and International Patents pending or applied for.

Where Do I Find Everything I Need for

Process Measurement and Control?

OMEGA…Of Course!

Shop on line at omega.com

TEMPERATURE

R Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies

R Wire: Thermocouple, RTD & Thermistor

R Calibrators & Ice Point References

R Recorders, Controllers & Process Monitors

R Infrared Pyrometers

PRESSURE, STRAIN AND FORCE

R Transducers & Strain Gauges

R Load Cells & Pressure Gauges

R Displacement Transducers

R Instrumentation & Accessories

FLOW/LEVEL

R Rotameters, Gas Mass Flowmeters & Flow Computers

R Air Velocity Indicators

R Turbine/Paddlewheel Systems
