Epson PowerLife Home 20 Specifications

Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information contained herein is designed only for use with
this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of
this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to
strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original Epson Products or Epson Approved Products by
Seiko Epson Corporation.
Epson is a registered trademark and Exceed Your Vision is a trademark of Seiko Epson Corporation.
PrivateLine and PowerLite are registered trademarks and Extra Care, Epson Connection, and Epson Store are
service marks of Epson America, Inc.
Pixelworks, DNX, and the DNX logo are trademarks of Pixelworks, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. Epson disclaims any and all rights in those marks.
© 2005 Epson America, Inc.
2
10/05
CPD-20172R1
Contents
5
Registration and Warranty
Projector Parts
Projector Controls
Optional Accessories
About This Manual
Getting More Information
5
6
7
8
9
9
Using the Projector
11
Choosing a Location
Adjusting the Picture
Controlling Your Presentation
Adjusting the Volume
Freezing the Action
Turning Off the Picture and Sound
Using the Projector’s Menu System
Changing Menu Settings
Adjusting the Appearance of the Picture
Using Advanced Picture Settings
Using On-screen Display Features
Customizing Projector Operation
Viewing Lamp Usage and Other Information
Restoring the Default Settings
11
13
15
15
15
15
16
16
17
19
21
22
23
24
Caring for the Projector
25
Cleaning the Lens
Cleaning the Projector Case
25
25
Contents
English
Welcome!
3
4
Cleaning and Replacing the Air Filters
Replacing the Lamp
Resetting the Lamp Timer
Storing the Projector
Transporting the Projector
26
27
29
29
29
Problem Solving
31
What To Do When the Lights Flash
Solving Projector Problems
Solving Picture Problems
Where To Get Help
31
32
34
38
Specifications and Notices
39
Projector Specifications
Important Safety Information
FCC Compliance Statement
39
42
44
Declaration of Conformity
Epson America, Inc. Limited Warranty
45
45
Index
47
Contents
Welcome!
The Epson® PowerLite® Home 20 Theater Projector lets you enjoy high-quality projection in
the relaxing environment of your own home. It offers these powerful features:
■
Adjustable color modes with built-in cinema filter for great viewing
■
16:9 LCD panel for wide format projection
■
Flexible setup configurations for front or rear projection and ceiling-mounted installation
■
Short lens focus; you can project a 120-inch diagonal image with the projector just
10 feet away
■
1200 ANSI lumens
■
1000:1 contrast ratio
■
Parental control through the projector’s child lock function
■
Lock port for optional Kensington® MicroSaver® anti-theft device
■
Toll-free two-year priority technical support
Registration and Warranty
The Epson PowerLite Home 20 projector comes with a basic two-year carry-in warranty. For
details, see page 45.
In addition, Epson offers free Extra CareSM Home Service during your warranty period. In the
unlikely event of an equipment failure, you won’t have to wait for your unit to be repaired.
Instead, Epson will ship you a replacement unit anywhere in the United States or Canada,
usually via overnight delivery. See your Extra Care Home Service brochure for details.
We encourage you to please register your projector. To register, simply fill out the registration
card that came with your projector and mail it to Epson. Or you can register online at
http://www.epson.com/webreg. Registering also lets you receive special updates on new
accessories, products, and service.
Welcome!
5
Projector Parts
Horizontal lens shift
Vertical lens shift
Control panel
Zoom ring
Focus ring
Lamp cover
Infrared receiver
(for remote control)
Lens cover
Ventilation slots
Adjustable
feet
Video port
(composite video)
Audio ports
S-video port
Lamp cover release slot
Input B (computer)
Speaker
Infrared receiver
Component video port
Control port (for
service use only)
6
Welcome!
Kensington
security lock
AC power inlet
Projector Controls
Power button
Turns the projector on and off
Menu button
Displays or hides
projector menus
Power light
Indicates
operating status
Aspect button
Changes the
picture’s aspect ratio
Warning light
Alerts you to
problems
Source button
Switches the
video input source
Power buttons
Turn the projector
on and off
Source buttons
Switch between equipment
connected to the projector
Esc button
Exits the current
function or menu
udlr Arrow buttons
Navigate menus
Keystone correction buttons
Adjust screen shape
Enter button
Selects menu options
Volume buttons
Adjust speaker volume
A/V Mute button
Turns off audio and video
Aspect button
Changes the picture’s
aspect ratio
Still button
Freezes the picture and sound
Auto button
Optimizes computer images
Picture buttons
Adjust brightness, contrast,
color temperature, and skin
tones. Also let you select a color
mode or recall memory settings.
Menu button
Displays or hides
projector’s menus
udlr Arrow and Enter buttons
Navigate menus and select menu
options
Keystone buttons
Adjust screen shape
Volume buttons
Adjust speaker volume
ESC button
Exits the current function
or menu
Welcome!
7
Optional Accessories
Epson provides the following optional accessories for the projector:
Product
Part number
Replacement lamp
ELPLP33
Air filter replacement
ELPAF09
Customized carrying cases:
Samsonite® wheeled soft case
Samsonite soft shoulder bag
ELPKS35
ELPKS43
Ceiling mount
ELPHT020
Suspension adapter
ELPHTAPL
False ceiling plate
ELPHTFCP
Kensington security lock
ELPSL01
S-video cable
F8V308X25
You can purchase these accessories from an Epson authorized reseller. To find the nearest
reseller, please call 800-GO-EPSON (800-463-7766). To purchase online, visit
www.epsonstore.com (U.S. sales only). In Canada, please call (800) 463-7766 for reseller
referral.
8
Welcome!
About This Manual
See the Quick Setup sheet to connect the projector to your video or computer equipment.
This book contains information on using the projector, in addition to maintenance
instructions, troubleshooting tips, important safety instructions, specifications, and warranty
information.
Please follow these guidelines as you read through the manual:
Warnings: Must be followed carefully to avoid bodily injury.
Cautions: Must be observed to avoid damage to your equipment.
Notes: Contain important information about your projector.
Tips: Contain helpful projection tips.
Getting More Information
Need additional help? Take advantage of Epson’s automated support services 24 hours a day
at http://support.epson.com. Use this site to view FAQs (Frequently Asked Questions) or
product information and e-mail your questions to Epson support.
If you need more help, you can use the Epson PrivateLine® Support service. Call
(800) 637-7661 and enter the PIN on the PrivateLine support card that came with your
projector.
Welcome!
9
10
Welcome!
Using the Projector
Follow the instructions in this section to choose a location for the projector, adjust the
picture, control projector operation, and use the menu system.
Choosing a Location
You can set up the projector for these four viewing arrangements:
Front/Ceiling
Rear/Ceiling
Front
Rear
If you install the projector in a rear or overhead position, you need to invert and/or mirror the
image by selecting the correct Projection option (see page 20). Professional installation is
recommended if you want to attach the projector to the ceiling.
Ideally, place the projector at a height so its
lens is between the top and bottom of the
screen. That way, you can keep the projector
level and use the vertical lens shift dial to
position the image (see page 13). This
produces the best-looking picture.
If you place the projector above or below
screen level, you have to tilt it up or down to
aim the image at the screen; this distorts the
shape of the image, but you can correct it
with the projector’s Keystone function (see page 14).
Using the Projector
11
To project a rectangular (non-distored) image, you do
not need to align the projector exactly with the center
of the screen. By using the horizontal lens shift dial,
you can place the projector to the left or right of the
screen’s center, by up to 25 percent of the image’s
width when projecting with a 16:9 aspect ratio. Make
sure the projector faces straight ahead (at a 90-degree
angle to the screen).
Projector can be moved from
center by up to 25 percent of
the image’s width
90°
Note: If you place the projector too far left or right, your
image will not be rectangular.
Place the projector at a suitable distance from the
screen to obtain the desired image size, as indicated
below. Note that the Zoom adjustment also affects image size.
Image size (16:9)
Projection distance
30 in. (26 × 15 in.)
2.4 to 3.7 feet
40 in. (35 × 20 in.)
3.2 to 4.9 feet
60 in. (51 × 28 in.)
4.9 to 7.4 feet
80 in. (71 × 39 in.)
6.6 to 9.9 feet
100 in. (87 × 47 in.)
8.2 to 12.4 feet
200 in. (173 × 98 in.)
16.5 to 24.8 feet
300 in. (260 × 146 in.)
24.8 to 37.3 feet
When placing the projector, keep these considerations in mind:
12
■
Make sure there is plenty of space for ventilation around and under the projector. Do not
set the projector on top of loose materials that could block the vents underneath.
■
Make sure the projector is within 6 feet of a grounded electrical outlet or extension cord.
Using the Projector
Adjusting the Picture
Follow the steps on the Quick Setup sheet to connect the projector to your equipment, turn it
on, and select the image source. Once you see your picture, you may need to make certain
adjustments.
Note: If you don’t see a picture, or the picture doesn’t look right, see page 34 for troubleshooting
instructions.
1. Rotate the focus ring to sharpen the picture, or the zoom ring to reduce or enlarge it.
Focus ring
Focus and
zoom rings
Zoom ring
2. If the image is not centered on the screen, use the horizontal and vertical lens shift dials
to adjust its position.
Up
Down
Left
Right
Note: The lens shift feature cannot move the image both horizontally and vertically by the full
amount. For example, if you have moved the image all the way up, then you cannot shift it all
the way to the right or left at the same time.
Using the Projector
13
3. If you still need to raise the height of the image after using the vertical lens shift dial, lift
the front of the projector and rotate the adjustable feet until the image is positioned
correctly. You can also use the feet to correct the angle of the image if it’s tilted
horizontally.
4. If you raise or lower the image by tilting the projector, the image becomes “keystoned”
and looks like
or . To return the image to a rectangular shape, use the
or
Keystone button on the projector or remote control.
5. To change the picture’s aspect ratio (ratio between length and height), press the Aspect
button on the projector or remote control. Choose from these settings:
■
Auto
To automatically display the image in the correct size.
■
Normal
For standard TV broadcasts, computer images, or images having a 4:3 aspect ratio.
■
Squeeze
For DVDs or video recordings made in a compressed (anamorphic) 16:9 format,
sometimes called “Squeeze Mode.”
■
Zoom
For images having a 16:9 aspect ratio (wide-screen or letterbox format).
Note: If you display a 4:3 image using the Zoom setting, the edges of the image will be cut off.
You can use the Zoom Caption option to resize and position the image to your liking (see
page 19).
6. Use the Picture buttons on the remote control to adjust the brightness,
contrast, and color. See page 17 for more information about using these
settings.
Note: Before selecting the Color Mode or other picture settings, make sure the
Setup Level is set correctly (see page 20).
14
Using the Projector
Controlling Your Presentation
Use these settings to control the projector’s speaker volume, temporarily freeze the picture, or
turn off the picture and sound.
Adjusting the Volume
When an audio source is connected to the projector’s Audio port, use the and
Volume
buttons on the projector or remote control to adjust the sound output from of the projector’s
speaker.
Freezing the Action
To freeze the action temporarily on the screen, press the
Still button on the remote control. This freezes any moving
images until you press the Still button again.
Note: The sound from your video source continues to be heard
while the image is frozen. You need to press the pause button
on your video source if you wish to resume playback where
you stopped it.
Still
button
A/V Mute
button
Turning Off the Picture and Sound
You can use the A/V Mute button on the remote control to
darken your screen and turn off the sound.
■
To turn off the picture and sound, press the A/V Mute
button. The screen goes dark.
■
To turn the picture and sound back on, press the
A/V Mute button again.
Note: Your video source continues to play while the screen is dark. You should pause the video if
you wish to resume playback where you stopped it.
Using the Projector
15
Using the Projector’s Menu System
You can use the projector’s on-screen menus to fine-tune the image quality, check lamp usage,
and customize projector features.
■
The Image menu controls the look and quality of the picture. It offers several ways to
adjust the color and improve the sharpness and clarity of the picture.
■
The Settings menu lets you set the child lock or sleep mode, adjust the position and size
of the picture, select front or rear projection, and customize other projector features.
■
The Info menu provides information about lamp status and video or computer settings.
■
The Reset menu lets you reset the lamp timer, clear the projector’s Memory settings, or
return all the menu settings to their factory defaults.
You can use the buttons on the projector or remote control to display the menus and change
settings. Follow the steps in the next section.
Changing Menu Settings
1. Press the Menu button on the projector or remote control. You see the main menu
screen:
Main menus
Options
Note: The available options depend on which type of equipment is connected to the projector.
2. Use the u and d arrow buttons on the projector or remote control to highlight the
desired menu, then press the Enter button to select it.
16
Using the Projector
3. If you see a list of options, use the u and d arrow buttons to highlight the option you
want, then press Enter to select it. (Enabled settings are indicated by a green light.)
If you see a slider bar like the one shown below, use the l and r arrow buttons to adjust
the setting.
4. Press the Esc button to return to the previous menu, or the Menu button to exit the
menu system.
Adjusting the Appearance of the Picture
The Image menu lets you make a variety of adjustments to the projected image to get the best
color and quality.
Note: Before selecting the Color Mode or other picture settings, make sure the Setup Level is set
correctly (see page 20).
Choosing the Color Mode
The Color Mode adjusts the brightness, contrast, and color for various common viewing
environments. Use this setting to quickly obtain a good picture.
Press the Menu button. Select Image > Color Mode and then choose from these options:
■
Dynamic
For projecting in bright rooms; images have greater color intensity.
■
Living Room
For projecting in rooms with a lot of ambient light.
■
Natural
For projecting in subdued lighting; increases contrast and makes flesh tones appear more
natural.
■
Theatre
For projecting in dark rooms; enhances the appearance of movies with dark scenes.
■
Theatre Black 1 or 2
For projecting in fully darkened rooms; lamp brightness decreases and image contrast
increases.
Using the Projector
17
Using Picture Quality Settings
Before adjusting the image with these settings, make sure you have already selected the best
Color Mode, as described on page 17.
Note: All settings apply to (and are retained for) only the currently selected input source (Input A,
Input B, Video, or S-Video). If you use more than one source, you should adjust the settings
separately for each one.
Press the Menu button. Select Image > Picture Quality and then choose from these options:
■
Brightness
Adjusts the brightness of the picture.
■
Contrast
Adjusts the contrast between light and dark parts of the picture.
■
Color Saturation (video only)
Adjusts the color depth of the picture.
■
Tint (video only)
Adjusts the hue of the picture by shifting the color balance between green and magenta.
■
Color Temp.
Adjusts red and blue tones. A lower color temperature produces a picture with more red
(warmer tones), while a higher color temperature produces more blue (cooler tones).
■
Skin Tone
Makes fine adjustments to the tint, adjusting the balance of green to magenta. This
adjustment is saved with the specific Color Mode you have selected (if you switch Color
Modes, a different Skin Tone setting will apply).
■
Sharpness
Makes lines and edges more distinct.
Adjusting Computer Images
In addition to the settings listed above, you can also adjust the following settings when
projecting from a computer.
■
Auto Setup
Select Image > Auto Setup. Leave this setting on so that the projector automatically
adjusts the tracking, sync, and position of the image.
■
Tracking
Select Image > Picture Quality > Tracking. Lets you manually eliminate unwanted
vertical lines. Easiest to adjust when the image contains fine detail, such as black text on a
white background.
18
Using the Projector
■
Sync
Select Image > Picture Quality > Sync. Corrects fuzziness by synchronizing the
projector with the computer’s tracking signal. For best results, adjust the tracking first.
Saving and Recalling Picture Settings
You can use the projector’s Memory feature to save the current picture quality settings as a
group. This lets you quickly recall them for future use.
1. Press the Menu button, then select Image > Save Memory.
2. Select Memory 1, Memory 2, or Memory 3, then press the Enter button to save your
settings.
3. Press the Menu button to exit the menu system.
4. To recall the settings, press the Memory button on the remote control (or press the
Menu button and select Image > Load Memory). Select the memory setting you wish
to use, then press Enter. The screen is adjusted with your settings.
Using Advanced Picture Settings
Use these options to select basic settings for your picture, such as its position, size, and
orientation, and compatible signal formats for your connected video equipment.
Press the Menu button. Select Settings > Screen and then choose from these options:
■
Position
Use the u, d, l, r arrow buttons to move the picture to a different position on the
screen.
■
Progressive
Leave this setting OFF when viewing video so that interlaced-to-progressive conversion is
carried out (best for fast-moving pictures). If you notice flickering while viewing still
images, switch this setting to ON.
■
Aspect
Selects the picture’s aspect ratio (see page 14).
■
Zoom Caption
Lets you adjust the screen so that subtitles are visible (available only when you’ve selected
the Zoom aspect ratio). Use Vertical Size to adjust the proportions of the image, and
Zoom Position to move the image up or down.
Using the Projector
19
■
Output Scaling (component video only)
Lets you see the edges of the image that are not normally visible. Select Larger to view
both the hidden and visible parts of the image. Normal displays images at standard size.
■
Keystone
Corrects vertical keystone distortion (when your image looks like
the projector). Makes the image somewhat smaller.
■
or
from tilting
Projection
Mirrors and/or inverts the image as needed, depending on the projector’s location relative
to the screen:
■
For this projector position . . .
Use this setting . . .
In front of the screen
Front
In front of the screen, mounted
upside-down on the ceiling
Front/Ceiling
Behind the screen
Rear
Behind the screen, mounted upside-down
on the ceiling
Rear/Ceiling
Setup Level
Adjusts the threshold at which dark areas of the image are rendered black. For
compatibility with most video equipment sold in the United States, set to 7.5%
(7.5 IRE).
If you need to select the video signal format for any video equipment connected to the
projector, select Settings > Input Signal and then choose from these options:
■
Video Signal (composite and S-video signals only)
Leave this setting on Auto to automatically detect the video format of your equipment. If
you notice a lot of interference in the image, or no image is being projected, select the
format specified in your equipment’s manual.
■
Input A (component and RGB video signals only)
Specifies the format for the video source connected to the Input A (component/RGB)
port. Select either Component or RGB Video.
20
Using the Projector
Using On-screen Display Features
Use these settings to control the appearance of the on-screen menus, display a background
image or color, create a startup screen, and choose a menu language.
Press the Menu button. Select Settings > On-Screen Display and then choose from these
options:
■
Menu Color
Use this option to change the color scheme of the menu from purple and orange
(Color 1) to black and white (Color 2).
■
Message
Turn this option off if you don’t want to display information messages on the screen,
such as the No Signal message, image source, color mode, and aspect ratio.
■
Background Color
Select the screen color (Black or Blue) or a custom Logo to display when you press the
A/V Mute button on the remote control or when no image signal is present.
Note: To create a custom logo, see “Creating a Custom Logo” below. If you turn on the
Startup Screen option (next item below), your logo also appears when the projector is warming
up.
■
Startup Screen
Turn on this option to display the Epson logo or your custom logo whenever the
projector starts.
Creating a Custom Logo
You can create a custom logo that displays when the projector is warming up, not receiving a
signal, or when you press the A/V Mute button on the remote control.
1. To capture the image, first set the projector to display the image you want to use.
2. Press the Menu button, then select Settings > User’s Logo. Follow the instructions on
the screen, selecting the part of the screen you want to capture, and then choosing a
“zoom rate” to set its magnification level.
3. When done, change the Background Color setting to Logo, as described above.
Choosing a Menu Language
To change the language you want to use for the projector menus, press the Menu button,
then select Settings > Language.
Using the Projector
21
Customizing Projector Operation
Use these settings to activate the Direct Power ON feature, set the child lock or sleep mode,
and make the fan run faster for high-altitude operation.
Press the Menu button. Select Settings > Operation and then choose from these options:
■
Direct Power ON
Use this feature to turn on the projector automatically when you plug it into an electrical
outlet.
Note: When this feature is used, the projector may turn itself on after power outages, or after
any temporary interruption of power. Make sure your electrical outlet isn’t controlled by a wall
switch or timer.
■
Sleep Mode
When Sleep Mode is on, the projector turns off the lamp if it has not received any input
signals for the specified amount of time (5, 10, or 30 minutes). You can also turn Sleep
Mode off.
■
Child Lock
When this feature is on, the projector does not come on unless you press and hold the
P Power button on the control panel for three seconds. (The remote control operates
normally.)
■
Fan Speed
When using the projector at an altitude above 5000 feet (1500 meters), select High to
ensure that the internal temperature is regulated properly. Set to Normal for lower
elevations.
22
Using the Projector
Viewing Lamp Usage and Other Information
Use the Info menu to view information about the display settings of your input source and
the number of hours the lamp has been used.
Press the Menu button and select Info. If the projector is connected to video equipment, you
see these settings:
If the projector is connected to a computer, you see these settings:
The life span of the lamp is about 3000 hours if the Color Mode is consistently set to Theatre
Black, and 2000 hours if any other Color Mode is used. If the number shown is close to the
limit, make sure you have a spare lamp handy.
Note: Lamp life results vary depending on environmental conditions and usage. Turn the projector
off when not in use. Continuous 24-hour-a-day use may reduce the overall life of the product.
After you change the lamp, you need to reset the lamp timer. See pages 27 to 29 for
instructions on replacing the lamp and resetting the timer.
Note: The Lamp Hours shows 0H (zero hours) until you’ve used the lamp for at least 10 hours.
Using the Projector
23
Restoring the Default Settings
The Reset menu lets you reset the lamp timer, clear the projector’s Memory settings, or return
all the projector settings to their factory default values.
Note: The Image menu and Settings menu also have their own Reset function that lets you clear
only the settings in those menus. The Reset function in the Settings menu clears all settings except
for Aspect, Child Lock, Fan Speed, Input A, and Language.
Press the Menu button, then select Reset. You see this screen:
Choose from these options:
■
Reset All
Resets all settings to their factory default values. The only settings not affected by this
option are Child Lock, Input A, Language, Memory settings, and Lamp Hours.
■
Memory Reset
Clears all settings saved using the projector’s Memory feature (see “Saving and Recalling
Picture Settings” on page 19).
■
Lamp-Hours Reset
Resets the lamp timer to 0H (zero hours). See page 23.
24
Using the Projector
Caring for the Projector
Your projector needs little maintenance. All you need to do on a regular basis is keep the lens
clean. You also need to clean the air filter periodically to prevent overheating.
Warning: Before you clean any part of the projector, turn it off and unplug the power cord. Never
open any cover on the projector, except the lamp and filter covers. Dangerous electrical voltages in
the projector can injure you severely. Do not try to service this product yourself, except as
specifically explained in this User’s Guide.
The only parts you should replace are the lamp and air filter. If another part needs replacing,
contact Epson or a qualified servicer (see page 38).
Follow the instructions in this section to clean the lens and projector case, clean and replace
the air filter, replace the lamp, and store or transport the projector.
Cleaning the Lens
Clean the lens whenever you notice dirt or dust on the surface.
■
Use a canister of compressed air to remove dust.
■
To remove dirt or smears, use lens-cleaning paper. If necessary, moisten a soft cloth with
lens cleaner and gently wipe the lens surface.
Caution: Never rub the lens with abrasive materials.
Cleaning the Projector Case
Before you clean the case, turn off the projector and unplug the power cord.
■
To remove dirt or dust, wipe the case with a soft, dry, lint-free cloth.
■
To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral
detergent. Then wipe the case.
Caution: Never use wax, alcohol, benzene, thinner, or other chemical detergents. These can
damage the case.
Caring for the Projector
25
Cleaning and Replacing the Air Filters
Clean the air filters on the bottom of the projector after every 100 hours of use. If they’re not
cleaned periodically, they can become clogged with dust, preventing proper ventilation. This
can cause overheating and damage the projector.
1. Turn off the projector and wait for the P power light to stop flashing.
2. Unplug the power cord and disconnect any cables.
3. Turn the projector over. Then use a small vacuum
cleaner designed for computers and other office
equipment to clean the filters, as shown.
If you cannot clean the removable filter or it is broken,
replace it. Contact an authorized Epson reseller at
800-GO-EPSON (800-463-7766) and ask for part
number ELPAF09. In Canada, please call (800)
463-7766 for reseller referral.
4. If you need to replace the filter, press the tab in and lift the cover up.
5. Remove the old filter and replace it with a new one.
6. Replace the cover.
26
Caring for the Projector
Replacing the Lamp
The life span of the lamp is about 3000 hours if the Color Mode is consistently set to Theatre
Black, and 2000 hours if any other Color Mode is used. You can check how long the lamp
has been used, as described on page 23. If the number shown is close to the limit, make sure
you have a spare lamp handy.
Note: Lamp life results vary depending on environmental conditions and usage. Turn the projector
off when not in use. Continuous 24-hour-a-day use may reduce the overall life of the product.
It’s time to replace the lamp when:
■
The projected image gets darker or starts to deteriorate.
■
The projector’s warning light flashes red at half second
intervals.
■
The message Replace the lamp appears on the screen
when you start projecting.
Warning light
Contact an authorized Epson reseller at 800-GO-EPSON (800-463-7766). Request part
number ELPLP33. In Canada, please call (800) 463-7766 for reseller referral.
Be sure to read the “Important Safety Information” on page 42 before replacing the lamp.
Follow these steps to replace the lamp:
1. Turn off the projector and wait for the P power light to stop flashing.
2. Unplug the power cord and any cables.
3. If the projector has been on, let it cool for at least an hour.
Warning: Let the lamp cool before replacing it. If the lamp breaks, handle the shards carefully
to avoid injury. If your projector is mounted on the ceiling, take it down before beginning this
procedure.
4. Insert a small screwdriver into the lamp cover release slot, pushing it in gently to release
the lamp cover.
.
Caring for the Projector
27
5. Loosen the two silver screws holding the lamp in place. (You can’t remove these screws.)
6. Grasp the lamp as shown and pull it straight out.
Note:
The lamp(s) in this product contain mercury. Please consult your state and local
regulations regarding proper disposal or recycling. Do not place in the trash.
7. Gently insert the new lamp and tighten its screws.
Caution: Don’t touch the glass portion of the lamp with your bare hands; the invisible residue
left by the oil on your hands may shorten the lamp life. Use a cloth or gloves to handle the new
lamp assembly.
8. To replace the lamp cover, insert the tabs and then snap the cover into place. (The
projector won’t work if the lamp cover is loose.)
After replacing the lamp, you need to reset the lamp timer, as described in the next section.
28
Caring for the Projector
Resetting the Lamp Timer
1. Press the Menu button on the projector or remote control.
2. Select the Reset menu, and then select Lamp-Hours Reset.
3. When you see a prompt asking whether you want to execute the command, highlight Yes
and press the Enter button.
4. When you’re finished, press Esc or Menu.
The lamp usage timer displays 0H (zero hours) until you’ve used the lamp for at least 10
hours.
Storing the Projector
If you need to store the projector for a while, do the following:
■
Make sure the temperature and humidity of the storage area are within the recommended
range for the projector (14 to 140 °F [–10 to 60 °C] and 10 to 90% relative humidity).
■
Attach the lens cover and retract the feet.
■
Remove the batteries from the remote control.
■
Package the projector in its original packaging or equivalent (as described in the following
section).
Transporting the Projector
Note: Epson shall not be liable for any damages incurred during transportation.
The projector contains many glass and precision parts. If you need to transport it, follow these
guidelines to prevent damage:
■
When shipping the projector for repairs, use the original packaging material if possible. If
you do not have the original packaging, use equivalent materials, placing plenty of
cushioning around the projector. Be sure the carrier is capable of transporting fragile
equipment and is aware that the projector is fragile.
■
When you are hand-carrying the projector, grasp it by its left and right sides, using the
recessed hand grips underneath.
Caring for the Projector
29
30
Caring for the Projector
Problem Solving
This section explains how to interpret the projector’s status lights, solve problems with the
picture and remote control, and contact technical support.
What To Do When the Lights Flash
The lights on top of the projector indicate the
projector’s status and let you know when a
problem occurs.
If the projector isn’t working correctly, first turn
it off, let it cool, and unplug it. Then plug the
power cord back in and turn on the projector. If
this doesn’t solve the problem, check the status
lights on top of the projector.
Power light
Warning light
The P power light is orange.
The projector is in sleep mode. Unplug it or press the P Power button to turn it on.
The P power light is flashing green.
The projector is warming up. Wait for the picture to appear.
The P power light is flashing orange and you can’t turn on the projector.
The lamp is cooling down. Wait until the light stops flashing, then press the P Power
button.
The P power light does not come on.
Make sure the power cord is connected securely both at the power outlet and the projector.
Problem Solving
31
The
warning light is flashing orange.
High-speed cooling is in process. If the projector gets too hot again, projection stops
automatically. Make sure there is plenty of space around and under the projector for
ventilation. Clean or replace the air filters if necessary (see page 26). If you are using the
projector at an altitude above 5000 feet (1500 meters), switch the Fan Speed setting to High
(see page 22).
The
warning light is red.
The projector is too hot and has turned itself off. Let it cool for five minutes, then turn it back
on. Make sure there is plenty of space around and under the projector for ventilation. Clean
or replace the air filters if necessary (see page 26). If you are using the projector at an altitude
above 5000 feet (1500 meters), switch the Fan Speed setting to High (see page 22).
The
warning light is flashing red at half second intervals.
The lamp needs to be replaced. See page 27.
The
warning light is flashing red at one second intervals.
■
The lamp cover may be loose or off. Make sure it’s securely fastened. See page 28.
■
There is an internal problem. Unplug the projector and contact Epson. See page 38.
Solving Projector Problems
The projector doesn’t turn on.
■
Check the P power light. If it’s dark, the projector is not receiving power. Make sure the
power cord is securely attached at both ends. Check that the electrical outlet isn’t
controlled by a timer, wall switch, or power strip switch, which may be interrupting the
power.
■
If the P power light is orange, the projector is in sleep mode. Press the P Power button
to turn on the projector.
If the Child Lock is being used (see page 22), you have to press and hold the projector’s
P Power button for at least 3 seconds to turn on the projector. (The remote control,
however, operates normally.)
■
32
If the P power light is green and not flashing, the projector is operating normally. Make
sure the lens cover is off. Press the A/V Mute button on the remote control to make sure
the picture hasn’t been turned off temporarily.
Problem Solving
The projector turns itself off after a period of time.
The projector’s Sleep Mode function may be turned on. This causes the projector to turn
itself off if it hasn’t received any input signals for a specified period of time. You can turn the
Sleep Mode setting off. See page 22.
The projector turns on by itself.
If you are using the Direct Power ON feature, the projector turns on automatically when you
plug it into an electrical outlet (see page 22). It may also turn itself on after power outages, or
after any temporary interruption of power. Make sure your electrical outlet isn’t controlled by
a wall switch or timer.
There is no sound coming from the projector.
■
Make sure audio cables are connected to the Audio port, and your audio equipment is
turned on.
■
Use the
and
Volume buttons on the projector or remote control to adjust the
sound output from the projector’s speaker.
■
Press the A/V Mute button on the remote control to make sure the picture and sound
haven’t been turned off temporarily.
The projector doesn’t respond to remote control commands.
■
Make sure you’re within 20 feet of the projector, and within range of the projector’s front
or back sensor (approximately 30° left or right, and 15° above or below).
■
You may need to replace the remote control’s batteries. Make sure they’re inserted with
the positive (+) ends facing the bottom of the remote, as shown on the Quick Setup sheet.
■
Dim the room lights and turn off any fluorescent lights. Make sure the projector is not in
direct sunlight.
■
Turn off nearby equipment that emits infrared energy, such as a radiant room heater.
Problem Solving
33
Solving Picture Problems
You see a screen with the message No Signal displayed.
■
Make sure your video equipment is turned on.
■
Make sure your cable(s) are connected correctly, as described in the Quick Setup sheet.
■
Use the Source button(s) on the projector or remote control to select the correct input
source. Allow a few seconds for the projector to sync up.
■
Press the Menu button and select Info. Make sure the resolution or video signal format
shown for your connected equipment is listed as a compatible format on page 41.
No picture appears on the screen.
■
Make sure the projector is turned on (the P power light is green and not flashing).
■
Make sure the lens cover is off.
■
Press the A/V Mute button on the remote control to make sure the picture hasn’t been
turned off temporarily.
■
If you’re projecting from a laptop, you may need to set it to display on an external
monitor, as described below.
If you’re using a PC laptop:
Press the function key that lets you display on an external monitor. It’s often labeled with
an icon such as
, but it may also be labeled CRT/LCD. You may have to hold down
the Fn key while pressing it, or restart your laptop. Check your laptop’s manual or online
help.
On most systems, the
key lets you toggle between the LCD screen and the
projector, or display on both at the same time. Allow a few seconds for the projector to
sync up after pressing it.
Depending on your computer’s video card, you might need to use the Display utility in
the Control Panel to make sure that both the LCD screen and external monitor port are
enabled. See your computer’s documentation for details.
34
Problem Solving
If you’re using a Macintosh® laptop with OS X:
1. Select System Preferences from the Apple® menu and click Displays.
2. Click Detect Displays.
3. To display the entire desktop on both your projector screen and LCD screen, click
the Arrange (or Arrangement) tab. (If you don’t see this tab, make sure it isn’t
hidden by another window.)
4. Click Mirror Displays in the lower corner of the screen. One of the monitor icons
automatically moves on top of the other.
Click here
If you’re using a Macintosh laptop with OS 9.x or earlier:
1. From the Apple menu, select Control Panels, then click Monitors and Sound.
2. Click the Arrange icon, and then drag one monitor icon on top of the other.
Click here
Drag one
monitor icon on
top of the other
If the Arrange option isn’t available, you may need to select one of the Simulscan
resolutions. Click the Monitor icon and then select a Simulscan resolution from the
Resolution box. (Allow a few seconds for the projector to sync up.)
Problem Solving
35
The picture is upside-down or reversed.
Change the setting for the Projection option in the Settings menu. See page 20.
The image doesn’t fit on the screen correctly, or it is stretched or compressed.
■
Press the Aspect button to select a different aspect ratio. See page 14.
■
Check the Zoom Caption and Output Scaling settings. See pages 19 and 20.
■
Use the Position setting in the Settings menu to reposition the image on the screen. See
page 19.
The picture is wider at the top or bottom.
You’ve tilted the projector to raise or lower the image, causing it to become “keystoned.” Use
the
or
Keystone button on the projector or remote control to correct the problem.
Better yet, place the projector at a height approximately between the top and bottom of the
screen, keeping it level, and then use the vertical lens shift dial to position the image (see
page 13). You won’t have to correct for keystone distortion this way, and you’ll get a
better-looking image.
The picture is taller on the left or right side.
The projector is set at an angle to the screen. Face it squarely toward the screen, and then use
the horizontal lens shift dial to center the image. See pages 12 and 13.
The picture contains static or noise.
36
■
Make sure your cable is securely connected at both ends.
■
Excessive cable length may cause interference. The practical length of the cable depends
on the type of cable used, its quality, and the complexity of your connections. Consider
using a signal amplifier.
■
If you’re displaying the same image on your computer and projector screen, try turning
off your laptop’s LCD display.
■
Check the settings in the Video Signal and Input A options in the Settings menu to
make sure they’re correct for your video equipment. See page 20.
■
Make sure the Progressive setting is set to OFF when viewing video. If you notice
flickering while viewing still images, switch the setting to ON. See page 19.
Problem Solving
The picture is blurry.
■
There may be dirt on the lens. Clean the lens as described on page 25.
■
Make sure the lens is not fogged by condensation. If you’ve just moved the projector from
a cold environment, wait a couple of minutes before using it.
■
Adjust the focus using the focus ring. See page 13.
■
Make sure the projector is placed the correct distance from the screen: no closer than
2.4 feet (73 cm) and no farther than 45.7 feet (13.9 m).
■
Adjust the Sharpness setting in the Image menu. See page 18.
■
If you’re using the Keystone adjustment, be aware that it lessens image quality. You may
wish to decrease the projection angle to reduce the amount of keystone correction
needed, or use the lens shift dials to position the image. See page 13.
■
If you’re projecting from a computer, press the Auto button on the remote control. If
you see no improvement, you may need to adjust the Tracking and Sync. See page 18.
The picture looks too light or too dark.
■
Make sure the Setup Level is set correctly (see page 20). If it’s not, dark or black parts of
the picture may look washed-out.
■
Press the Color Mode button on the remote control to select the best setting for your
viewing environment.
■
Adjust the Brightness and Contrast settings in the Image menu. See page 18.
Note: These settings should be adjusted separately for each video source you’re using.
■
If the picture looks darker than it used to, you may need to replace the lamp. See page 27.
The colors on the screen don’t look right.
■
Press the Color Mode button on the remote control to select the best setting for your
viewing environment.
■
Adjust the following settings in the Image menu: Color Saturation, Tint, Color Temp.,
and Skin Tone. See page 18.
Note: These settings should be adjusted separately for each video source you’re using.
■
Check the settings in the Video Signal and Input A options in the Settings menu to
make sure they’re correct for your video equipment. See page 20.
■
If your video equipment is connected with component video cables, make sure all three
connectors are securely attached at both ends.
Problem Solving
37
Where To Get Help
Epson provides technical assistance 24 hours a day at http://support.epson.com. Here you
can access troubleshooting information, download product documentation, and receive
technical advice through e-mail.
To use the Epson PrivateLine Support service, call (800) 637-7661 and enter the PIN on the
Epson PrivateLine Support card that came with your projector. This is the fastest way of
speaking to a live representative, and it’s free. This service is available 6 AM to 6 PM, Pacific
Time, Monday through Friday, for the duration of your warranty period.
You may also speak with a projector support specialist by dialing one of these numbers:
■
U.S.: (562) 276-4394, 6 AM to 6 PM, Pacific Time, Monday through Friday
■
Canada: (905) 709-3839, 6 AM to 6 PM, Pacific Time, Monday through Friday
Toll or long distance charges may apply.
Before you call, please have the following information ready:
■
Product name (Epson PowerLite Home 20)
■
Product serial number (located on the bottom of the projector)
■
Computer configuration, if you’re projecting from a computer
■
Description of the problem
You can purchase screens, carrying cases, or other accessories from an Epson authorized
reseller. To find the nearest reseller, please call 800-GO-EPSON (800-463-7766). To
purchase online, visit www.epsonstore.com (U.S. sales only). In Canada, please call
(800) 463-7766 for reseller referral.
38
Problem Solving
Specifications and Notices
This section includes projector specifications, safety instructions, and other important information
about your projector.
Projector Specifications
General
Type of display
Poly-silicon TFT active matrix
Size of LCD panels
0.55 inch (14 mm) wide
Lens
F=1.7 to 2.1, f=13.7 to 20.5 mm
Resolution
(native format)
854 × 480 pixels, 480p
Brightness
1200 lumens (ANSI)
Color reproduction
24 bit, 16.8 million colors
Contrast ratio
1000:1
Image size
30 to 300 inches (0.76 to 7.6 m)
Projection distance
2.4 to 45.7 feet (0.73 to 13.9 m)
Internal sound system
1 W monaural
Zoom ratio
1:1.5
Lens shift (maximum)
50% vertically, 25% horizontally
Optical aspect ratio
16:9
Noise level
33 dB (all color modes except Theatre Black)
28 dB (Theatre Black color mode)
Keystone correction
Vertical: –30° to +30°
Remote Control
Range
Approx. 20 feet (6 m)
Battery
AA × 2
Specifications and Notices
39
Projection Lamp
Type
135 W UHE (Ultra High Efficiency)
Part number
ELPLP33
Lamp life
Approx. 2000 hours (all color modes except Theatre Black)
Approx. 3000 hours (Theatre Black mode)
Note: Lamp life results vary depending on environmental conditions and usage. Turn the projector
off when not in use. Continuous 24-hour-a-day use may reduce the overall life of the product.
Dimensions
Height
4.4 inches (111 mm), excluding feet
Width
14.7 inches (373 mm)
Depth
11.6 inches (295 mm)
Weight
7.8 lb. (3.5 kg)
Electrical
Rated voltage
100 to 240 VAC
Rated frequency
50/60 Hz
Power consumption
Operating: 200 W
Standby: 4 W
Environmental
Temperature
Operating: 41 to 95 °F (5 to 35 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Humidity
Operating: 20 to 80% RH, non-condensing
Storage: 10 to 90% RH, non-condensing
Operating altitude
0 to 7,500 ft (0 to 2,286 m)
Safety and Approvals
United States
FCC 47CFR Part 15B Class B (DoC)
UL1950 Rev. 3
Canada
ICES-003 Class B
CSA C22.2 No. 950-95 (cUL)
PixelworksTM DNXTM ICs are used in this projector.
40
Specifications and Notices
Compatible Video Formats
The projector supports digital video (SDTV, HDTV), analog TV (NTSC, PAL, SECAM), and various
monitor display formats. Images are automatically resized, if necessary, to display in the projector’s
native resolution.
Note: To project images from a computer, set the computer’s video card at a refresh rate (vertical
frequency) compatible with the projector; see below for compatible formats.
Digital video formats
Mode
Refresh Rate (Hz)
Resolution
HDTV (750p)
HDTV (1125i)
HDTV (1125i)
SDTV (525i)
SDTV (525p)
SDTV (625i)
SDTV (625p)
60
60
50
60
60
50
50
1280 × 720
1920 × 1080
1920 × 1080
640 × 480
640 × 480
768 × 576
768 × 576
Mode
Refresh Rate (Hz)
Resolution
VGAEGA
70
640 × 350
VGA—60
VESA—72
VESA—75
VESA—85
60
72
75
85
640 ×
640 ×
640 ×
640 ×
480
480
480
480
SVGA—56
SVGA—60
SVGA—72
SVGA—75
SVGA—85
56
60
72
75
85
800 ×
800 ×
800 ×
800 ×
800 ×
600
600
600
600
600
XGA—60
XGA—70
XGA—75
XGA—85
60
70
75
85
1024 ×
1024 ×
1024 ×
1024 ×
MAC13
MAC16
MAC19
MAC19—60
67
75
75
59
640 × 480
832 × 624
1024 × 768
1024 × 768
Monitor display formats
768
768
768
768
Specifications and Notices
41
Analog TV formats
Mode
Refresh Rate (Hz)
NTSC
NTSC 4:43
PAL
N-PAL
M-PAL
PAL—60
SECAM
60
60
50
50
60
60
50
Important Safety Information
Follow these safety instructions when setting up and using the projector:
42
■
Except as specifically explained in this User’s Guide, do not attempt to service this product
yourself. Refer all servicing to qualified service personnel.
■
Never open any cover on the projector, except the lamp and filter covers. Dangerous electrical
voltages inside the projector can severely injure you.
■
The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small
children to avoid any risk of suffocation.
■
Never look into the projector lens when the lamp is turned on; the bright light can damage your
eyes. Never let children look into the lens when it is on.
■
Don’t place the projector on an unstable cart, stand, or table. Also, don’t stand on the projector or
place heavy objects on it.
■
Never push objects through the cabinet slots or spill liquid into the projector.
■
Do not use the projector near water or sources of heat.
■
Use a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Unplug the projector from
the wall outlet before cleaning.
■
Never try to remove the lamp immediately after use. Doing so will result in serious burns. Before
removing the lamp, turn off the projector and wait for the lamp to cool completely.
■
The lamp is fragile and can easily break. If the lamp breaks, handle the projector with extreme care
to avoid injury from broken glass. If the projector is mounted to a ceiling, take it down before
replacing the lamp, or pieces of broken glass could fall into your eyes or mouth.
■
Do not use the lamp after the lamp replacement period has elapsed, because the possibility of lamp
breakage increases. When the lamp replacement message appears, replace the lamp with a new one
as soon as possible.
■
The lamp(s) in this product contain mercury. Please consult your state and local regulations
regarding disposal or recycling. Do not place in the trash.
Specifications and Notices
■
The lamp in this projector is under high internal pressure and may make a loud noise if it breaks.
If it breaks, ventilate the room to prevent mercury gas inside the lamp from being inhaled or
coming into contact with the eyes or mouth.
■
Do not bring your face close to the projector while it is in use, to prevent inhaling or contact with
the gases inside the lamp if it breaks.
■
If the lamp breaks and gas from the lamp or fragments of broken glass are inhaled or get into the
eyes or mouth, or if any other ill effects are noticed, immediately seek medical advice.
■
Use the type of power source indicated on the projector. If you’re not sure of the power available,
consult the power company.
■
If you use the projector in a country other than where you purchased it, use the correct power cord
for that country.
■
Place the projector near a wall outlet where the plug can be easily unplugged.
■
Don’t place the projector where the cord can be walked on. This may result in fraying or damage
to the plug.
■
Don’t insert the plug into an outlet with dust present, and insert the plug firmly into the outlet.
Failure to do so could result in sparks or fire.
■
Don’t handle the plug with wet hands.
■
Don’t overload wall outlets, extension cords, or integral convenience receptacles. This can cause
fire or electric shock.
■
Unplug the projector from the wall outlet and refer servicing to qualified service personnel under
the following conditions: when the power cord or plug is damaged or frayed; if liquid has been
spilled into the projector, or if it has been exposed to rain or water; if it doesn’t operate normally
when you follow the operating instructions, or if it exhibits a distinct change in performance,
indicating a need for service; if it has been dropped or the housing has been damaged.
■
If there is an electrical storm, do not touch the power plug, otherwise you may receive an electric
shock.
■
Keep the projector unplugged when not in use for extended periods.
■
Keep the batteries for the remote control out of the reach of children. Batteries are choking hazards
and can be very dangerous if swallowed. If they are swallowed, seek medical attention immediately.
■
Replace the batteries as soon as they run out.
■
Do not expose batteries to heat or flame.
■
Dispose of used batteries according to local regulations.
■
Remove the batteries if you won’t be using the projector for a long period of time.
■
Don’t block the slots and openings in the projector case. They provide ventilation and prevent the
projector from overheating. Don’t operate the projector on a sofa, rug, or other soft surface, or in a
closed-in cabinet unless proper ventilation is provided.
■
Material or paper may get stuck against the air filter underneath the projector while it is in use.
Remove anything from underneath the projector that might get stuck against the air filter in this
way.
Specifications and Notices
43
■
Don’t place the projector or remote control on top of heat-producing equipment or in a heated
place, such as a car.
■
Don’t use the projector outside of the required temperature range (see page 40). Doing so may
cause an unstable display and could lead to projector damage.
■
Don’t store the projector outside of the required temperature range (see page 40) or in direct
sunlight for long periods of time. Doing so may cause damage to the case.
WARNING: The cord included with this product contains chemicals, including lead, known to the
State of California to cause birth defects or other reproductive harm. Wash hands after handling.
(provided in accordance with Proposition 65 in Cal. Health & Safety Code § 25249.5 et seq)
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio or television reception. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause interference to radio
and television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
■
Reorient or relocate the receiving antenna.
■
Increase the separation between the equipment and receiver.
■
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
■
Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC
Certification of this device and may cause interference levels which exceed the limits established by the
FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment
interface cable with this device. If this equipment has more than one interface connector, do not leave
cables connected to unused interfaces. Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
For Canadian Users
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
44
Specifications and Notices
Declaration of Conformity
According to 47CFR, Part 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU
Boards and Power Supplies used with Class B Personal Computers:
We:
Located at:
Epson America, Inc.
3840 Kilroy Airport Way
MS 3-13
Long Beach, CA 90806
Telephone: (562) 290-5254
Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and
15 of the FCC rules as a Class B digital device. Each product marketed is identical to the representative
unit tested and found to be compliant with the standards. Records maintained continue to reflect the
equipment being produced can be expected to be within the variation accepted, due to quantity
production and testing on a statistical basis as required by 47CFR §2.909. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Trade Name:
Epson
Type of Product: Projector
Model:
EMP-TW20
Marketing Name: PowerLite Home 20
Epson America, Inc. Limited Warranty
What Is Covered: Epson America, Inc. (“Epson”) warrants to the original end user customer that the
Epson product enclosed with this limited warranty statement, if purchased new and operated only in
the United States or Canada, conforms to the manufacturer’s specifications and will be free from
defects in workmanship and materials for a period of two (2) years from the date of original purchase
(except that the warranty period is 90 days for projector lamps). For warranty service, you must provide
proof of the date of original purchase.
What Epson Will Do To Correct Problems: Should your Epson projector require service during the
warranty period, Epson will, at its option, exchange or repair the projector without charge for parts or
labor. If Epson authorizes an exchange for the defective unit, Epson will ship a replacement projector to
you, freight prepaid, to an address in Canada or the U.S. (excluding Puerto Rico and U.S. Possessions).
Shipments to other locations will be made freight collect. You are responsible for securely packaging
the defective unit and returning it to Epson within five (5) working days of receipt of the replacement.
Epson requires a debit or credit card number to secure the cost of the replacement projector in the
event that you fail to return the defective one. If your projector is being repaired by carry-in warranty
service, please bring the product securely packaged in its original container or an equivalent to your
Epson Dealer or Epson Customer Care Center. Epson will, at its option, repair or replace on an
exchange basis the defective unit, without charge for parts or labor. When warranty service involves the
Specifications and Notices
45
exchange of the product or of a part, the item replaced becomes Epson property. The exchanged
product or part may be new or previously repaired to the Epson standard of quality, or, at Epson’s
option, may be another model of like kind and quality. Exchange or replacement products assume the
remaining warranty period of the product covered by this limited warranty, except that each
replacement lamp carries the limited 90-day warranty stated above.
What This Warranty Does Not Cover: This warranty covers only normal use of the product in the
United States and Canada. 24-hour-per-day use of this product causes unusual strain and is not
considered normal use. This warranty does not cover consumables (e.g., fuses), other than lamps. This
warranty does not apply to refurbished or reconditioned products, and this warranty is not transferable.
Epson is not responsible for warranty service should the Epson label or logo or the rating label or serial
number be removed or should the product fail to be properly maintained or fail to function properly as
a result of misuse, abuse, improper installation, neglect, improper shipping, damage caused by disasters
such as fire, flood, and lightning, improper electrical current, software problems, interaction with
non-Epson products, or service other than by an Epson Authorized Servicer. Postage, insurance, or
shipping costs incurred in presenting your Epson product for carry-in warranty service are your
responsibility. If a claimed defect cannot be identified or reproduced in service, you will be held
responsible for costs incurred.
THE WARRANTY AND REMEDY PROVIDED ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHER EXPRESS OR IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. SOME LAWS DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES.
IF THESE LAWS APPLY, THEN ALL EXPRESS AND IMPLIED WARRANTIES ARE LIMITED
TO THE WARRANTY PERIOD IDENTIFIED ABOVE. UNLESS STATED HEREIN, ANY
STATEMENTS OR REPRESENTATIONS MADE BY ANY OTHER PERSON OR FIRM ARE
VOID. EXCEPT AS PROVIDED IN THIS WRITTEN WARRANTY, NEITHER EPSON
AMERICA, INC. NOR ITS AFFILIATES SHALL BE LIABLE FOR ANY LOSS,
INCONVENIENCE, OR DAMAGE, INCLUDING DIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, RESULTING FROM THE USE OR INABILITY TO USE THE
EPSON PRODUCT, WHETHER RESULTING FROM BREACH OF WARRANTY OR ANY
OTHER LEGAL THEORY. IF THE REMEDY ABOVE FAILS, EPSON’S ENTIRE LIABILITY
SHALL BE LIMITED TO A REFUND OF THE PRICE PAID FOR THE EPSON PRODUCT
COVERED BY THIS LIMITED WARRANTY.
In Canada, warranties include both warranties and conditions.
Some jurisdictions do not allow limitations on how long an implied warranty lasts, and some
jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitations and exclusions may not apply to you. This warranty gives you specific legal rights,
and you may also have other rights, which vary from jurisdiction to jurisdiction.
To locate the Authorized Epson Servicer nearest you, call the Epson ConnectionSM at
(800) 637-7661 + PIN or (562) 276-4394 in the U.S. and (905) 709-3839 in Canada, or write to:
Epson America, Inc., P.O. Box 93012, Long Beach, CA 90809-3012.
46
Specifications and Notices
Index
A
A/V Mute button, 7, 15
Accessories, 8, 38
Air filters
cleaning and replacing, 26
ordering, 8
Anti-theft device, 8
Aspect button, 7
Aspect ratio, adjusting, 14, 36
Audio problems, 33
Auto button, 7, 37
Contrast, adjusting, 14, 18
Control panel, projector, 7
D
Dark image, 37
Declaration of Conformity, 45
Default settings, resetting, 24
Direct Power ON, 22, 33
Distance, projection, 12, 39
Documentation, 9
B
E
Background Color setting, 21
Blurry picture, 37
Brightness
adjusting, 14, 18
lamp, 5, 27, 39
Buttons, 7
Electrical specifications, 40
Epson
accessories, 8, 38
Home Service, 5
PrivateLine Support, 38
technical support, 9, 38
C
F
Cable, 8
Ceiling projection, 11, 20
Child Lock, 22, 32
Cleaning
air filters, 26
lens and projector case, 25
Color Mode, 14, 17, 23, 27, 37
Color Mode button, 7
Color problems, 37
Color temperature, adjusting, 18
Computers
adjusting image, 18 to 19
compatible video formats, 41 to 42
projecting from, 34 to 35
Contrast ratio, 5, 39
Fan speed, 22, 32
FCC Compliance Statement, 44
Feet, adjustable, 14
Filters, see Air filters
Focus ring, 6, 13
Freezing the image, 15
H
HDTV, compatible formats, 41
Help, 38
High altitude mode, 22, 32
Home Service, 5
Horizontal lens shift, 12 to 13
Index
47
I
blurry, 37
distorted, 36
inverted or backwards, 36
noisy, 36
size, 12, 39
too light or dark, 37
wrong colors, 37
Menus
adjusting on-screen display, 21
adjusting picture quality, 17 to 20
customizing projector operation, 22
resetting, 24
using, 16 to 17
viewing projector information, 23
Moving projector, 29
N
K
No Signal message, 34
Kensington
anti-theft device, 8
lock port, 6
Keystone correction, 11, 14, 20, 36, 39
O
L
Lamp
brightness, 5, 27, 39
ordering, 8, 27
replacing, 27 to 28
specifications, 40
usage timer, resetting, 29
viewing usage, 23
Language, menu, 21
Laptop, projecting from, 34 to 35
Lens shift, 6, 11 to 13, 39
Lens, cleaning, 25
Lights, projector, 31 to 32
Lock, see Child lock
Logo, creating, 21
M
Maintenance, 25 to 29
Memory button, 7
Memory settings, using, 19
Menu button, 7, 16
48
Index
Optional accessories, 8
Output Scaling setting, 20
Overhead projection, 11
Overheating, 12, 26, 32
P
Parts, identifying, 6 to 7
adjustments, 13 to 14, 17 to 20
problems, 34 to 37
repositioning, 19
turning off, 15
Pixelworks DNX, 41
Positioning projector, 11 to 12
Presentation, controlling, 15
Problems
audio, 33
overheating, 12, 26, 32
picture, 34 to 37
projector, 32 to 33
remote control, 33
Progressive setting, 19
Projection distance, 12, 39
Projection setting, 11, 20
Projector
choosing location, 11 to 12
cleaning, 25
control panel, 7
dimensions, 40
distance from screen, 12, 39
feet, 14
lights, 31 to 32
maintenance, 25 to 29
menus, 16 to 24
parts, 6
positioning, 11 to 12
problems, 32 to 33
resetting default values, 24
speaker, 39
storing, 29
transporting, 29
R
Rear projection, 11, 20
Registration, 5
Remote control
buttons, 7
problems, 33
Replacing lamp, 27 to 28
Reset menu, 24
Resetting lamp timer, 29
Resolution, 39
Sound
adjusting, 15
problems, 33
turning off, 15
Source buttons, 7
Sources, switching, 34
Speaker, projector, 39
Specifications
compatible video formats, 41 to 42
electrical, 40
environmental, 40
general, 39
lamp, 40
remote control, 39
Squeeze mode, 14
Startup Screen setting, 21
Still button, 15
Storing projector, 29
Support, see Technical support
Sync, 19, 37
T
Technical support, 9, 38
Temperature, projector, 12, 26, 32
Tint, adjusting, 18
Tracking, 18, 37
Transporting projector, 29
TV video formats, 41 to 42
S
U
Safety
approvals, 40
instructions, 42 to 44
Saturation, color, 18
Saving picture settings, 19
Screen distance, 12, 39
SDTV, compatible formats, 41
Setup Level setting, 20
Size, image, 12, 39
Skin Tone setting, 18
Sleep Mode, 22, 31, 32, 33
User’s Logo setting, 21
V
Ventilation, 12, 26, 32
Vertical lens shift, 11, 13
Video
cable, 8
compatible formats, 41 to 42
signal format, selecting, 20
Volume, adjusting, 15
Index
49
W
Warranty, 5, 45 to 46
Washed-out picture, 37
Z
Zoom Caption setting, 14, 19
Zoom ring, 6, 13
Zoom setting, 14
50
Index
