Canon DR-M1060 User manual

User Manual
• Please read this manual before operating this
scanner.
• After you finish reading this manual, store it in
a safe place for future reference.
FCC REGULATIONS (For 120 V model)
RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUE
(For 120 V models)
Document Scanner, Model M111201
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with Class B limits in
Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in the manual. If such changes or modifications
should be made, you could be required to stop operation of the
equipment.
Canon U.S.A. Inc.
One Canon Park, Melville, NY 11747, U.S.A.
Tel. No. (800)652-2666
Cet appareil numérique respecte les limites de bruits radioélectriques
applicables aux appareils numériques de Classe B prescrites dans la
norme sur le matériel brouilleur: “Appareils Numériques”, NMB-003
édictée par l’Industrie Canada.
International ENERGY STAR® Office Equipment Program
As an ENERGY STAR® Partner, CANON
ELECTRONICS INC. has determined that this
machine meets the ENERGY STAR® Program
guidelines for energy efficiency.
The International ENERGY STAR® Office Equipment
Program is an international program that promotes
energy saving through the use of computers and other office
equipment. The program backs the development and dissemination of
products with functions that effectively reduce energy consumption. It
is an open system in which business proprietors can participate
voluntarily. The targeted products are office equipment, such as
computers, monitors, printers, fax, machine, copiers, and scanners.
The standards and logos are uniform among participating nations.
This model doesn’t provide setting options for power management.
European Union (and EEA) only.
This symbol indicates that this product is not to be disposed
of with your household waste, according to the WEEE
Directive (2002/96/EC) and your national law. This product
should be handed over to a designated collection point,
e.g., on an authorized one-for-one basis when you buy a
new similar product or to an authorized collection site for recycling
waste electrical and electronic equipment (EEE). Improper handling of
this type of waste could have a possible negative impact on the
environment and human health due to potentially hazardous
substances that are generally associated with EEE. At the same time,
your cooperation in the correct disposal of this product will contribute
to the effective usage of natural resources. For more information
about where you can drop off your waste equipment for recycling,
please contact your local city office, waste authority, approved WEEE
scheme or your household waste disposal service. For more
information regarding return and recycling of WEEE products, please
visit www.canon-europe.com/environment.
(EEA: Norway, Iceland and Liechtenstein)
RADIO INTERFERENCE REGULATIONS (For 120 V
models)
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the interferencecausing equipment standard entitled “Digital Apparatus”, ICES-003 of
the Industry Canada.
2
Für EMVG
Copyright
Dieses Produkt ist zum Gebrauch im Wohnbereich, Geschäfts-und
Gewerbebereich sowie in Kleinbetrieben vorgesehen.
Copyright 2014 by CANON ELECTRONICS INC. All rights reserved.
No part of this publication may be reproduced or transmitted in any
form or by any means, electronic or mechanical, including
photocopying and recording, or by any information storage or retrieval
system without the prior written permission of CANON
ELECTRONICS INC.
Model Names
The following name may be provided for the safety regulations in each
sales region of the Document Scanner.
DR-M1060: Model M111201
Disclaimers
Trademarks
The information in this document is subject to change without notice.
• Canon and the Canon logo are registered trademarks, of Canon Inc.
in the United States and may also be trademarks or registered
trademarks in other countries.
• imageFORMULA is a trademark of CANON ELECTRONICS INC.
• Microsoft, Windows, Windows Vista, PowerPoint, and SharePoint
are registered trademarks or trademarks of Microsoft Corporation in
the United States and other countries.
• Microsoft product screen shot(s) reprinted with permission from
Microsoft Corporation.
• ENERGY STAR® is a registered trademark of the United States
Environmental Protection Agency.
• ISIS is a registered trademark of Emc Corporation in the United
States.
• eCopy PDF Pro is a trademark or registered trademark of Nuance
Communications, Inc. and its affiliates in the United States and/or
other countries.
• Adobe, the Adobe logo, Acrobat, the Adobe PDF logo, and Adobe
Reader are either registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries.
CANON ELECTRONICS INC. MAKES NO WARRANTY OF ANY
KIND WITH REGARD TO THIS MATERIAL, EITHER EXPRESS OR
IMPLIED, EXPECT AS PROVIDED HEREIN, INCLUDING WITHOUT
LIMITATION, THEREOF, WARRANTIES AS TO MARKETABILITY,
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OF USE OR NON-INFRINGEMENT. CANON ELECTRONICS INC.
SHALL NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR
EXPENSES RESULTING FROM THE USE OF THIS MATERIAL.
CANON ELECTRONICS INC. IS NOT LIABLE FOR THE STORAGE
AND HANDLING OF DOCUMENTS SCANNED WITH THIS
PRODUCT, OR THE STORAGE AND HANDLING OF RESULTING
SCANNED IMAGE DATA.
IF YOU INTEND TO DISCARD THE ORIGINALS OF SCANNED
DOCUMENTS, YOU THE CUSTOMER ARE RESPONSIBLE FOR
INSPECTING THE SCANNED IMAGES AND VERIFYING THAT
DATA IS INTACT.
THE MAXIMUM LIABILITY OF CANON ELECTRONICS INC.
UNDER THIS WARRANTY IS LIMITED TO THE PURCHASE PRICE
OF THE PRODUCT COVERED BY THE WARRANTY.
• Other product and company names herein may be the trademarks
of their respective owners. However, the TM and ® symbols are not
used in this document.
3
Setup Guide
STEP 1
Please read first.
Checking the Accessories
If any of the items listed below are missing or damaged, contact your local authorized Canon dealer or service representative.
Scanner
USB Cable
AC Adapter/Power Cord
Setup Guide
Setup Disc
Warranty Card
(U.S.A. and Canada only)
• Items included in this manual are subject to change without notice.
• You must keep the machine’s packaging and packing materials for storing or transporting the machine.
• The shape of the power plug varies by country and region.
4
Setup Disc Contents
Third-Party Software
Install the following software necessary for using the scanner from the
supplied Setup Disc.
• CaptureOnTouch
This is a dedicated scanning application for this product.
• CapturePerfect 3.1
This is a scanning application for the DR series scanner.
• Scanner Driver
This is the scanner driver for this product.
The following software applications are also included on the supplied
Setup Disc. For details on installing these applications, refer to the
Readme.txt file.
• eCopy PDF Pro Office
Nuance Communications PDF creation/editing software.
IMPORTANT
When scanning with third-party software, user the scanner driver of
this scanner to configure scanning conditions. For details on how to
open the scanner driver, refer to the manuals supplied with each
software application.
After taking the scanner out of the box, remove the protective parts (▼) from the scanner.
5
STEP 2
Installing the Software
System requirements
• Use the USB interface provided as standard with your computer.
However, normal operation is not guaranteed with all USB
interfaces, even if present as standard equipment on the computer.
For details, consult your local authorized Canon dealer.
• Scanning speeds are lower if your computer’s standard USB
interface is USB Full-Speed (equal to USB 1.1.)
• The USB cable you are using should be the one originally included
with the scanner.
• If the CPU, memory, interface card, and other specifications do not
satisfy the installation requirements, the scanning speed may be
greatly reduced and transmission may take a long time.
• Even if the computer satisfies the system requirements, the
scanning speed may vary, depending on the specifications and
operating environment of the computer and the specified scan
settings.
• The scanner drivers provided with the scanner do not necessarily
operate on all ISIS or TWAIN-compatible applications. For details,
contact your application software retailer.
To use the scanner, your computer must satisfy the following system
requirements.
Computer
CPU:
Memory:
Hard disk:
USB interface:
Monitor:
Optical drive:
Intel Core 2 Duo 1.66GHz or faster
1GB or more
3 GB or more available space required for
installation of all software
Hi-Speed USB2.0
Resolution of 1024 × 768 (XGA) or better
recommended.
Drive capable of reading DVDs.
Operating system
• Microsoft Windows XP Service Pack 3 or later
• Microsoft Windows XP x64 Edition Service Pack 2 or later
• Microsoft Windows Vista Service Pack 2 or later (32-bit and 64-bit
editions)
• Microsoft Windows 7 Service Pack 1 or later (32-bit and 64-bit
editions)
• Microsoft Windows 8 (32-bit and 64-bit editions)
• Microsoft Windows 8.1 (32-bit and 64-bit editions)
• Microsoft Windows Server 2008 R2
• Microsoft Windows Server 2012 R2
Precautions for Use in 64-bit Operating Systems
• The ISIS/TWAIN driver supplied with this product supports
scanning with 32bit applications only.
• Even with 32-bit applications, not all ISIS/TWAIN compliant
applications are guaranteed to operate.
• Scanning speed may vary depending on the specifications of your
computer.
Other requirements
• An ISIS-compatible application or a TWAIN-compatible application
that is compatible with the above operating systems.
• .NET Framework 3.5 or later
IMPORTANT
• If you do not know the requirements for your computer system,
contact the store where you purchased the computer or the
manufacturer of the computer for more information.
• If you use the scanner with Windows, use the latest USB 2.0 driver
made available by Microsoft. For details, consult your local
authorized Canon dealer.
6
Software Installation
2
Click [Typical Installation].
IMPORTANT
• Install the software before connecting the scanner to the computer.
• Log on to Windows as an Administrator.
• Close all other applications before installing the software.
1
Insert the software setup disc into the disk drive of the
computer.
The setup menu automatically starts up when you insert the disc
into the drive. (If the menu does not start up, execute setup.exe
from the disc.)
Hint
If you want to reinstall only specific software that you have
previously uninstalled, select [Custom Installation] and specify
the software.
3
For Windows 8.1/8/7/Vista
If the following screen appears, click [Yes] or [Permissions].
7
Click [Install].
4
5
Follow the instructions on the screen to complete
installation.
Hint
Installing the EMC Cloud Capture Function
EMC Captiva Cloud Runtime provides components that enable
web-based applications. To enable this function, the applications
must be compatible. Install this only if you are using compatible
applications.
8
Click [Exit] to finish installing the software.
STEP 3
Connecting to a Computer
Connect the scanner to the computer and the power supply.
IMPORTANT
• Do not connect the scanner to the computer before installing the software.
• Before connecting the scanner to the computer, verify that the power of the scanner is OFF.
If the power is ON, turn it OFF.
USB cable (included with the scanner)
AC adapter (included with the scanner)
To the power outlet
9
STEP 4
Turning the Power ON
The power of the scanner can be turned ON and OFF with the power
button on the front of the scanner.
1
2
When the scanner is properly connected to the computer, the
(CaptureOnTouch) icon appears on the taskbar as follows.
Make sure that the scanner and computer are connected
properly.
If the taskbar icon appears as , the scanner is not properly
connected to the computer. Check the status of the power switch and
USB cable.
Press the power button.
Turning Off the Power
Press and hold the power button until the indicator goes out.
IMPORTANT
Power button
• After turning the scanner off, wait at least 10 seconds before turning
it back on.
• If you will not be using the scanner for an extended period, you
should disconnect the power cord from the AC outlet for safety.
The power button lights blue when the power turns ON.
Hint
The scanner’s auto power off setting is enabled by default, and the
scanner will turn off automatically if it is not operated for 4 hours.
For details on how to disable this setting, see “Auto Power Off Setting”
on p. 74.
Hint
A balloon message such as shown below appears on the task bar. If
you wait a while, automatic scanner recognition will end and the
scanner will become ready to use.
Ð
This completes setup.
10
Introduction
CapturePerfect 3.1 operation guide
Thank you for purchasing the Canon imageFORMULA DR-M1060
Document Scanner.
Please read the following manuals carefully and familiarize yourself
with the functions of the scanner before use to ensure you sufficiently
understand the functions and make the most of the scanner’s
capabilities. After reading the manuals, store them in a safe place for
future reference.
Manuals for the Scanner
Documentation for this scanner consists of the following manuals.
● Setup Guide
This describes setup procedures for the scanner. Read this manual
when you first use the scanner.
● User Manual (this manual)
This manual contains the operating procedures of the scanner.
(PDF electronic manual only)
Hint
• The User Manual and CapturePerfect 3.1 operation guide are
installed with the software as electronic manuals in the following
location.
User Manual
• The manual is registered to the following location in Windows 8.1.
11
Symbols Used in This Manual
The following symbols are used in this manual to explain procedures,
restrictions, handling precautions, and instructions that should be
observed for safety.
WARNING
Indicates a warning concerning operations that may lead to death
or injury to persons if not performed correctly. To use the scanner
safely, always pay attention to these warnings.
CAUTION
Indicates a caution concerning operations that may lead to injury to
persons, or damage to property if not performed correctly. To use
the scanner safely, always pay attention to these cautions.
IMPORTANT
Indicates operational requirements and restrictions. Be sure to
read these items carefully to operate the scanner correctly, and
avoid damaging the scanner.
Hint
Indicates a clarification of an operation, or contains additional
explanations for a procedure. Reading these notes is highly
recommended.
12
Table of Contents
Setup Guide ......................................................................... 4
Introduction ....................................................................... 11
Setting the Scanner Driver .......................................... 50
Configuration and Functions of the Scanner Driver .............. 50
Setting Basic Scanning Conditions ....................................... 52
Symbols Used in This Manual.................................................... 12
More Advanced Scanning Methods............................ 62
Before Using the Scanner.......................... 14
Using a Patchcode for Scanning ........................................... 62
Important Safety Instructions ..................................... 14
Maintenance .............................................. 65
Installation Location .............................................................. 14
AC Adapter............................................................................ 14
Moving the Scanner .............................................................. 15
Handling ................................................................................ 15
Disposal ................................................................................ 16
When sending the scanner for repairs .................................. 16
Daily Maintenance ........................................................ 65
Features of the Scanner .............................................. 17
Names and Functions of Parts ................................... 19
Cleaning the Scanner............................................................ 65
Cleaning the Inside of the Scanner ....................................... 65
Cleaning the Sensor Glass and the Rollers .......................... 65
Adjusting the Reduction Ratio ............................................... 68
Replacing Consumable Parts................................................ 69
Auto Power Off Setting.......................................................... 74
Basic Operation ......................................... 22
Troubleshooting ........................................ 76
Common Problems and Solutions..............................
Software Troubleshooting...........................................
Useful tips .....................................................................
Clearing Paper Jams, Skewed Documents, Stapled
Documents, and Feed Errors ......................................
Uninstalling the Software ............................................
Documents ................................................................... 22
How to Place Documents ............................................ 24
Switching the Feed and Eject Methods................................. 24
Placing Documents ............................................................... 25
Placing Cards........................................................................ 27
Placing Folded Documents ................................................... 27
Setting the Long Document Mode......................................... 28
Detecting a document double feed ....................................... 30
Detecting Skewed Documents .............................................. 32
Detecting Staples and Feed Errors ....................................... 33
76
78
79
81
83
Appendix .................................................... 84
Specifications ............................................................... 84
Replacement Parts................................................................ 85
Option.................................................................................... 85
About the Flatbed Scanner Unit 101/201 .............................. 85
Dimensions............................................................................ 86
Scanning methods ..................................... 35
Scanning with CaptureOnTouch ................................ 35
What is CaptureOnTouch?.................................................... 35
Starting and Exiting CaptureOnTouch ................................. 35
Scan First .............................................................................. 36
Select Scan Job .................................................................... 38
Operating the scanner with the operating panel buttons....... 41
Scanner Settings................................................................... 41
Setting the Output Method .................................................... 44
Environmental Settings ......................................................... 45
Index ...............................................................................87
Scanning with CapturePerfect.................................... 48
Scanning with CapturePerfect............................................... 48
13
Before Using the Scanner
Important Safety Instructions
● Avoid locations that are subject to vibration.
● Avoid exposing the scanner to rapid changes in temperature. If the
room in which the scanner is installed is cold but rapidly heated,
water droplets (condensation) may form inside the scanner. This
may result in a noticeable degradation in scanning quality. The
following conditions are recommended for optimal scanning quality:
Room temperature: 10 °C to 32.5 °C (50 °F to 90.5 °F)
Humidity: 20% to 80% RH
● Avoid installing the scanner near equipment that generates a
magnetic field (e.g. speakers, televisions, or radios.)
To ensure the safe operation of this scanner, be sure to read the
safety warnings and precautions described below.
Installation Location
The performance of this scanner is affected by the environment in
which it is installed. Make sure that the location where the scanner is
installed meets the following environmental requirements.
● Provide adequate space around the scanner for operation,
maintenance, and ventilation.
AC Adapter
100mm (3.94")
100mm
(3.94")
● Connect only to a power outlet of the rated voltage and power
supply frequency (120 V, 60 Hz or 220-240 V, 50/60 Hz depending
on your region).
● Do not connect other electrical equipment to the same power outlet
to which the scanner is connected. Also, when using an extension
cord, make sure that the extension cord is rated for the current
requirements of the scanner.
● Never try to take the AC adapter apart or modify it in any way, as
this is dangerous.
● The power cord may become damaged if it is often stepped on or if
heavy objects are placed on it.
● Do not use the power cord while it is coiled.
● Do not pull directly on the power cord. When disconnecting the
power cord, grasp the plug and remove it from the outlet.
● Keep the area around the power cord clear of objects so that the
power cord can be disconnected easily in an emergency.
● Do not use an AC adapter other than the one provided with the
scanner. Do not use the AC adapter provided with the scanner with
other products.
● If you have any questions regarding the power supply, contact your
local authorized Canon dealer or service representative for further
information.
100mm
(3.94")
● When scanning documents using the straight path, provide
adequate space in back of the scanner for scanned document
output.
● Avoid installing the machine in direct sunlight. If this is unavoidable,
use curtains to shade the scanner.
● Avoid locations where a considerable amount of dust accumulates
as dust may adversely affect the inside of the scanner.
● Avoid warm or humid locations, such as in the vicinity of a water
faucet, water heater, or humidifier. Avoid locations where ammonia
gas is emitted. Avoid locations near volatile or flammable materials,
such as alcohol or paint thinner.
14
● The supplied power cord set is intended for use with this scanner
only. Do not use it with other electronic equipment. In addition, do
not use power cord sets other than the one supplied with the
scanner. Doing so may result in fire or electric shock.
● Do not take the scanner apart or modify it.
● Never try to take the AC adapter apart or modify it in any way, as
this is dangerous.
● Do not use flammable spray near the scanner.
● When cleaning the scanner, push the power button to turn it OFF
and disconnect the power cord from the power supply.
● Clean the scanner using a slightly dampened cloth which has been
well wrung out. Never use alcohol, benzene, paint thinner, or any
other flammable substances.
● If the scanner makes strange noises, or gives off smoke, heat, or
strange odors, or the scanner does not function or other
abnormalities occur when you use the machine, immediately push
the power button to turn it off, and disconnect the power plug from
the power outlet. Then, contact your local authorized Canon dealer
or service representative to have the unit serviced.
● Do not drop the scanner, or subject it to impact or strong shock.
Should the scanner ever become damaged, immediately push the
power button to turn it OFF, and disconnect the power plug from the
power outlet. Then, contact your local authorized Canon dealer or
service representative to have the unit serviced.
● Before moving the scanner, be sure to push the power button to turn
it OFF, and disconnect the power plug from the power outlet
● To customers with cardiac pacemakers
The scanner generates a weak magnetic field. If customers using
cardiac pacemakers experience any abnormalities, move away
from the scanner and consult a physician.
Moving the Scanner
● When moving the scanner, always hold it with both hands to avoid
dropping it.
● Make sure to disconnect the interface cable and AC adapter before
moving the scanner. If the scanner is transported with these items
connected, the plugs and connectors may be damaged.
Handling
WARNING
Note the following precautions whenever using the scanner. Failure to
do so may result in a fire or electric shock.
● Never use alcohol, benzene, paint thinner, aerosol sprays, or any
other highly flammable substance near the scanner.
● Do not cut, damage, or modify the power cord. Do not place heavy
objects on the power cord, and do not pull or excessively bend the
power cord.
● Never connect the power cord when your hands are wet.
● Do not connect the scanner to a multi plug power strip.
● Do not knot or coil the power cord as this may result in a fire or
electric shock. When connecting the power cord, make sure that the
power plug is securely and completely inserted into the power
outlet.
CAUTION
● Do not install the scanner on a surface that is unstable or tilted, or
in an area subject to excessive vibrations, as this may cause the
scanner to fall, resulting in personal injury or damage to the
scanner.
15
● Never place small metal objects such as staples, paper clips, or
jewelry on the scanner. These items may fall into the scanner, and
cause a fire or electric shock. Should such objects ever fall inside
the scanner, immediately push the power button to turn it OFF, and
disconnect the power plug from the power outlet. Then, contact
your local authorized Canon dealer or service representative to
have the unit serviced.
● Do not install the scanner in a humid or dusty location. Doing so
might cause a fire or electric shock.
● Do not place objects on top of the scanner. Such objects may tip or
fall over, resulting in personal injury.
● Connect only to a power outlet of the rated voltage and power
supply frequency (120 V, 60 Hz or 220-240 V, 50/60 Hz depending
on your region). Doing so might cause a fire or electric shock.
● When unplugging the power cord, grasp it firmly by its plug. Do not
pull directly on the power cord, as this may damage or expose the
cord’s internal wiring, resulting in a fire or electric shock.
● Leave sufficient space around the power plug so that it can be
unplugged easily. If objects are placed around the power plug, you
will be unable to unplug it in an emergency.
● Do not allow water or flammable substances (alcohol, paint thinner,
benzene, etc.) to spill into the scanner, as this may result in a fire or
electric shock. Doing so might cause a fire or electric shock.
● Push the power button to turn the scanner OFF for safety when not
using the scanner for a long period of time, such as overnight. Also,
push the power switch to turn it OFF, and disconnect the power cord
from the power outlet for safety when the machine will not be used
for an extended period of time, such as during consecutive
holidays.
● Do not block the ventilation holes. Doing so might cause
overheating.
● Do not wear loose clothing or jewelry that may get caught in the
scanner while you are using it, as this may result in personal injury.
Be extra careful of neckties and long hair. If anything becomes
caught in the scanner, immediately disconnect the power cord to
stop the scanner.
● Be careful when loading paper into the scanner and when removing
jammed paper, as it is possible to cut your hand on the edge of a
sheet of paper.
TEMPERATURE WARNING
● Parts on which this warning is affixed can become very hot, and
improper handling of these parts may result in burns. To ensure
safe operation, follow the instructions of the warning carefully.
Disposal
When disposing of this scanner, be sure to follow all local ordinances
and laws or consult with the retailer who sold you the scanner.
When sending the scanner for repairs
When a request is made for repairs, the scanner needs to be sent to
the specified address. When sending the scanner, use the packing
box in which it came. Firmly secure the scanner with packaging
material when you place it in the packing box.
16
Features of the Scanner
● Auto Resolution Detection
When enabled in the CaptureOnTouch or scanner driver settings,
this function detects the content of documents and determines the
scanning resolution automatically.
● Folio Scan
You can scan folded documents. The scanner will scan both sides
and combine the scanned images into a single image.
By using this function in conjunction with Long Document mode,
you can scan documents up to the A1 size.
● Deskew
The scanner is equipped with a deskew function that straightens
images before saving them when documents are scanned askew.
The scanned images are straightened, as opposed to the actual
document sheets.
● Ultrasonic Double Feed Detection
Ultrasonic waves are used to detect pages that are fed at the same
time, and scanning stops if a double feed is detected.
● Double Feed Detection Ignore
When a double feed is detected, the DFR button on the operation
panel is lit. You can continue scanning by pressing the DFR button.
● Text Enhancement Modes
The scanner is equipped with an Advanced Text Enhancement
Mode to enhance the text of documents with dark or uneven
backgrounds, and an Advanced Text Enhancement II mode to
enhance the text when both the text and background are light.
These modes may not work, depending on the type of document.
● Color Drop-out
The scanner is equipped with a Color Drop-out function that
enables you to specify a color for the scanner to omit from the
scanned image during black and white or grayscale scanning.
● Skip Blank Page Function
The scanner is equipped with a Skip Blank Page function that
enables you to scan a document without storing images of blank
pages, regardless of whether each page of the document is twosided or one-sided. Both sides are scanned, but saving the image
is skipped for scan images judged to be from a blank page.
The main features of the DR-M1060 document scanner are described
below.
● Highly Efficient Scanning with A3 Compatibility
The front-side input/output U-turn path design allows smooth
feeding and output of documents. The scanner supports a variety of
document sizes, handling documents that are up to A3 in size.
● Fast Document Feeding
A4 documents can be scanned at a speed of up to 60 pages per
minute in any scanning mode, including black and white, grayscale,
and color.
* Scanning conditions: A4 horizontal, duplex, 200 dpi
● Two Eject Paths for Scanning a Variety of Documents
Use the space saving U-turn path to scan paper of standard
thickness, or use the straight path to scan cards and other thick
documents.
● High Image Quality
The 600 dpi optical resolution sensor incorporated in the scanner
enables documents to be scanned with high image quality.
● USB 2.0 Interface
The scanner supports Hi-Speed USB 2.0.
● Color/Grayscale Support
Documents can be scanned in 24-bit color or 256-level grayscale.
● Supports a Variety of Scanning Modes
The scanner supports the following scanning modes, depending on
the document type:
• Single-sided or double-sided scanning (with Skip Blank Page
function)
• Continuous or single sheet feed
● Card Scan
You can scan business or ID cards.
● Paper Size Detection
The scanner automatically detects the size of a scanned document
and eliminates any unnecessary space around the edges of the
image when storing the image, even when storing a document of
irregular size.
● Auto Color Detection
The scanner detects whether the scanned document is in color,
grayscale, or black and white, and saves the image accordingly.
17
● Prescan Function
The scanner is equipped with a Prescan function that allows you to
adjust the contrast and brightness of a prescanned image and then
send the adjusted image to the application software, without
needing to scan the document again.
● Character/Line Emphasis Function
If characters and lines in scanned images are not clearly visible, you
can use this function to adjust their thickness during scanning.
● Skew Detection Function
The scanner automatically stops operation when documents are
fed at an excessive slant to prevent damage to documents.
● Staple Detection
When documents that are stapled together are detected, the
scanner automatically stops the scanning operation.
● Feed Error Detection
When a feed error is detected, the scanner automatically stops the
scanning operation.
● Start Scanning from the Operating Panel
You can start scanning by launching CaptureOnTouch with the
operating panel buttons. By default, Job No.1 is assigned to Scan
First, which allows you to easily scan a document by just following
the instructions on the screen.
● Auto Start
The scanner is equipped with an auto start function, which enables
scanning to be automatically started when a document placed in the
feeder is detected.
● Sleep Mode
The scanner is designed to save energy by automatically entering
the sleep mode if 10 minutes elapse without scanning or another
operation being performed.
Hint
Some functions may not be available depending on the software you
are using.
18
Names and Functions of Parts
Front View (With the Feed Tray Open)
A
F
B
G
H
C
I
J
K
L
D
E
M
A Eject Support
G Eject Stopper
Open this when scanning documents that are 150 mm (A5
horizontal) or longer.
Raise this to stop the leading edge of ejected documents and
prevent them from falling off of the scanner.
B Eject Support Extension
H Document Eject Tray / Upper Unit
Extend this when scanning documents that are longer than
279 mm (LTR, vertical).
Scanned documents are output here.
Open this when cleaning the inside of the scanner or replacing
rollers.
C Feed Support
I Operating Panel
Extend this when loading documents that are longer than 150 mm
(A5 horizontal).
A range of scanning operations can be performed with this, such
as starting and stopping scans, executing registered jobs, and
cancelling double feed detection. (See p. 20)
D Feed Support Extension
Extend this when loading documents that are longer than 216 mm
(LTR horizontal).
J Power button
Press this to turn on the scanner. The button remains lit while the
power is on.
Press and hold the button until the light goes out to turn off the
scanner.
E Document Feed Tray
Place the document.
F OPEN Lever
Raise this to open the upper unit.
19
C USB Connector
The power button lights or flashes as follows depending on the
scanner status.
Power Button Indication
Description
Lit
Power is on
Flashing
Sleep mode
Connect the supplied USB cable to this connector.
D Power Connector
Connect the supplied AC adapter to this connector.
Operating Panel
K Feed Selection Lever
Use this to change the way documents are fed.
Set the lever to the lower position when scanning documents
consecutively. (See p. 24)
Set the lever to the upper position when scanning documents one
page at a time or scanning multi-page documents that are fastened
together. (See p. 24)
A
1
2
B
C
3
D
E
4
L LED Indicator (Orange)
This lights during non separation feeding mode.
M Document Guides
Align the document guides with both edges of the document to
ensure that the document feeds straightly.
A Job No. Indicator
This displays the number of the job selected with the operating
panel, errors, and other information.
Back View
B Job Select Button
This selects registered jobs. Every time the button is pressed, the
Job No. displayed in the Job No. Indicator changes.
C DFR (Double Feed Release) Button
This is lit when a document double feed is detected. Pressing this
button cancels the double feed detection function, allowing you to
continue scanning.
1
A
2
B
D Stop Button
C
3
This stops active jobs.
E Start Button
D
This executes the job displayed in the Job No. Indicator.
A Straight Path Tray
When using the straight path, scanned documents are output here.
B Kensington Slot
Connect an anti-theft key chain or the like.
20
Displayed Error Codes
When a scanning error occurs, the following error codes are displayed
in the Job No. Indicator.
: displayed when the upper unit is open.
: displayed when a paper jam is detected.
: displayed when a double feed is detected while scanning.
: displayed when skewed documents, staples, or feed errors are
detected.
: displayed for other errors.
Other Displays
When the straight path tray is opened or closed, the eject method is
displayed in the Job No. Indicator.
: flashes during straight path mode.
: animates during U-turn path mode.
21
Basic Operation
Documents
The scanner can scan documents ranging in size from business cards
to A3. (Up to A1 size is possible with folio scanning in Long Document
mode.) The document sizes that this scanner can scan are shown
below.
IMPORTANT
The documents to be scanned must satisfy certain criteria. Read the
following items carefully.
• When scanning multiple documents of different sizes, place the
documents so that they cover the entire span of the feed rollers by
aligning the centers and leading edges of the documents.
Plain Paper
Size
Width: 50.8 mm to 300 mm (2" to 11.8")
Length: 70 mm to 432 mm (2.8" to 17")
Up to 3,000 mm (118.1") in Long Document mode
Paper thickness
U-turn path (page separation):
27 to 128 g/m2 (0.04 to 0.15 mm)
U-turn path (bypass):
27 to 164 g/m2 (0.04 to 0.2 mm)
Straight path:
27 to 255 g/m2 (0.04 to 0.3 mm)
Loading capacity (for 80 g/m2 paper)
A4 size or smaller:
Maximum of 60 sheets
Larger than A4 size:
Maximum of 25 sheets
Align the leading
edges
Feed roller
Align the centers
• It is recommended that documents exceeding 432 mm (17") size
are fed one sheet at a time.
• Scanning documents before the ink is dry can cause problems with
the scanner. Always make sure that the ink on a document is dry
before scanning it.
• Scanning documents that are written in pencil or similar material
may make the rollers and scanning glass dirty, which can lead to
smudges on the scanned image and transfer the dirt to subsequent
documents. Always clean the internal parts of the scanner after
scanning such documents.
• When scanning a two-sided document that is printed on thin paper,
the image on the opposite side of each page may show through. In
this case, adjust the scanning intensity in the application software
before scanning the document.
22
• Laminated documents may not be scanned correctly, depending
on the document.
• It is recommended that thin documents be fed one page at a time.
• Scanning the following types of documents can cause a paper jam
or malfunction. To scan such a document, make a photocopy of the
document and then scan the photocopy.
There are creases or
fold lines.
Carbon paper
There are curls.
The surface is coated.
There are tears.
Extremely thin document
such as semi-transparent
thin paper.
There are clips or
staples.
Documents with excessive
paper dust particles.
CAUTION
• Use the straight path when scanning cards.
• Embossed cards may not be able to be scanned correctly,
depending on the type of embossment.
Business Card
Size:
Width: 50.8 mm to 55 mm (2" to 2.2")
Length: 85 mm to 91 mm (3.4" to 3.6")
Paper thickness: 128 to 380 g/m2 (0.15 to 0.45 mm)
Orientation:
Vertical feeding only
Eject method:
Straight path only
IMPORTANT
If a stack of business cards cannot be fed properly, reduce the
number of cards in the stack.
Postcard
Size:
Width: 89 mm to 108 mm (3.5" to 4.3")
Length: 127 mm to 152 mm (5" to 6")
Paper thickness: 128 to 300 g/m2 (0.15 to 0.4 mm)
Eject method:
Straight path only
Card (plastic)
Size:
Card thickness:
54 mm x 86 mm (2.1" x 3.4") (ISO standard)
0.76 mm (0.03") or less, 1.4 mm (0.055") or less
for the embossment
Orientation:
Vertical feeding only
Eject method:
Straight path only
Loading capacity: 3 cards (non-embossed), 1 card (embossed)
23
How to Place Documents
Standard feeding is used to feed documents one page at a time. Non
separation feeding is used to feed bound or fastened multi-page
documents or folded documents without separating them.
Switching the Feed and Eject
Methods
Feed and Eject Methods for Different Document Types
Switch the feed and eject methods based on the type of document you
are scanning.
The U-turn path is used when the straight path tray at the rear of the
scanner is closed, and the straight path is used when it is opened.
U-turn path
Standard feeding
Straight path
Non separation
feeding
Document type
Feed
method
Eject
method
Plain paper
Either
Either
Business cards
Either
Straight
path
Place cards vertically.
Plastic cards
Either
Straight
path
Place cards vertically.
Thick paper
Either
Straight
path
Thin paper
Either
Either
Bound or
fastened paper
(e.g., invoices)
Non separation
feeding
Either
Long
documents
Non separation
feeding
Either
Half-folded
paper
Non separation
feeding
Either
Remarks
Hint
When scanning documents that contain both plain paper and plastic
cards, place the cards at the top and use the straight path.
Standard feeding is used when the feed selection lever at the front of the
scanner is lowered, and non separation feeding is used when it is raised.
24
3
Placing Documents
1
Ordinarily, you should scan with the straight path tray at the rear
of the scanner closed (U-turn path).
When scanning business cards, plastic cards, or other documents
you do not want to bend, open the straight path tray (straight
path).
For details on the eject methods for each document type, see
p. 24.
Switch the feed method based on the type of document
you are scanning.
When scanning plain paper or business cards, set the feed
selection lever to the standard feeding position (lower position).
The pages of a multi-page document will be separated and fed
one page at a time.
When scanning bound or fastened paper (e.g., invoices), set the
feed selection lever to the non separation feeding position (upper
position). As documents are scanned without page separation,
place the documents one page at a time (one set in the case of
bound or fastened paper).
For details on the feed methods for each document type, see
p. 24.
Straight path
4
2
Switch the eject method based on the type of document
you are scanning.
Open the document feed tray.
25
If you are scanning long documents with the U-turn path,
extend the document feed support and open the eject
support.
When scanning documents longer the LTR horizontal (216 mm),
extend the feed support and eject support extensions.
5
6
Adjust the document guides to fit the width of the
document to be scanned.
Place the document.
After placing the document, align the document guides with both
edges of the document.
IMPORTANT
• When placing documents into the feed tray, take care not to cut
your hand on the edges of the paper.
• Make sure that the document does not exceed the loading limit
marks ( ) on the document guides. Up to 60 pages of ordinary
plain paper (80 g/m2) can be loaded at the same time.
• Before you place a document, check to make sure it does not
contain paper clips, staples, or other small metal objects. These
items may cause a fire or electrical shock, damage the document,
or cause a paper jam or scanner malfunction.
• Do not wear loose clothing or jewelry that may get caught in the
scanner while you are using it, as this may result in personal injury.
Be extra careful of neckties and long hair. If anything gets caught in
the scanner, immediately turn OFF the power switch, and
disconnect the power cord from the power outlet to stop scanning.
• Always smooth out any folds or curls in your documents before
placing them into the feeder. If the leading edge of a document is
curled, it may cause a paper jam.
• If feeding stops due to a system error or paper jam while the
scanner is scanning, resolve the problem, make sure that the
scanned image of the last page that was successfully fed has been
stored, and then resume scanning the remaining document pages.
26
• After you finish scanning, close the document feed tray, document
eject extension support, and straight path tray to prevent damage
to the scanner while it is not being used.
• When scanning multi-page documents that are fastened together
(e.g., invoices), place the document so that the fastened edge is
toward the feed tray.
• Be careful when scanning paper that is longer than A3 size or thin
paper, as the documents may fall off of the eject tray after scanning.
• When using the straight path, documents will be ejected from the
rear of the scanner. Do not place any obstructions near the
document eject outlet. To ensure that the documents are ejected
smoothly, make sure that the scanner is placed on a smooth, flat
surface.
4
5
Adjust the document guides to fit the width of the card to
be scanned.
Place the card.
Up to three non-embossed cards can be placed vertically at one
time. Embossed cards must be placed one at a time and vertically.
CAUTION
• Use the straight path when scanning cards.
• Embossed or laminated cards may not be scanned correctly,
depending on the card.
• Ultrasonic double feed detection will not function properly when
scanning cards. Clear the [Detect by Ultrasonic] check box in the
[Feeding] tab.
Placing Cards
1
2
3
Placing Folded Documents
Folio scanning allows you to scan documents that are larger than A3
and that do not fit in the feeder. To use the function, fold the document
in half lengthwise and place it into the feeder. The scanner will scan
both sides and combine the scanned images into a single image.
By using this function in conjunction with Long Document mode, you
can scan documents up to the A1 size.
Set the feed selection lever to the standard feeding
position (lower position).
Open the document feed tray.
Open the straight path tray.
1
CAUTION
Open the straight path tray when scanning cards. Scanning with
the U-turn path may damage the card.
2
27
Set the feed selection lever to the non separation feeding
position (upper position).
Open the document feed tray.
3
Hint
Fold the document in half.
• The front side of the folded document will appear on the left side of
the combined image.
• The maximum size for the combined image is A1. When scanning a
folded document of a size other than the standard formats, set
[Page Size] on the scanner driver settings screen to [Match original
size]. (See p. 42)
Crease the document firmly down its center to fold the document
in half. Fold the document so that its edges are neatly aligned. If
the document is not folded properly, paper jams may occur or
distortions may appear in the combined scanned image.
IMPORTANT
A portion of the scanned image will be missing at the fold line.
4
Setting the Long Document Mode
Place the document with the folded edge facing right.
The length of documents that can be scanned with the scanner is
normally 432 mm (17"), but you can scan documents up to 3,000 mm
(118.1") long by setting the scanner to the Long Document mode.
After placing the document, align the document guides with both
edges of the document.
Front
Back
IMPORTANT
By selecting the Long Document mode and setting the [Paper Size]
in the scanner driver settings screen to auto-detection, documents of
up to 3,000 mm (118.1") (2,700 mm (106.3") with 600 dpi) in length
can be scanned. Note the following when using the Long Document
mode:
• When scanning in the Long Document mode, if the document is
placed on the scanner in a skewed position, it may hit the edges of
the feeding area and be damaged. Be careful to place the
document so that it is not skewed.
• When scanning with the Long Document mode, paper jam
detection may react slowly, resulting in damage to the document.
Be careful to avoid paper jams.
• When scanning long documents, make sure to set the feed
selection lever to “non separation feeding mode,” and scan the
documents one page at a time.
• When scanning large-sized documents with the Long Document
mode, scanning may be slower. Errors also occur due to memory
shortage, and scanning may be disabled.
• Be careful when scanning paper that is longer than A3 or letter
(LTR) size or thin paper, as the documents may fall off of the eject
tray after scanning.
IMPORTANT
Adjust the document guides to fit the width of the document.
Otherwise, the image may scan as skewed or shifted.
28
1
2
3
Start Windows and log in as a user with administrator
privileges.
Click [CANON DR-M1060 USB] and click [Properties].
Scanner properties are displayed.
4
Click the Start button, and then click [All Programs],
[Canon DR-M1060], and [Canon imageFORMULA Utility].
Click the [Maintenance] tab, and then select a Long
Document mode.
Select [Long Document Mode (1000 mm)] or [Long Document
Mode (3000 mm)] depending on the length of the document.
Hint
Canon imageFORMULA Utility is registered to the following
location in Windows 8.1.
5
imageFORMULA Utility starts.
29
Click [OK].
4
Detecting a document double feed
This scanner includes a function to detect document double feeds. By
using this function, the scanner will automatically stop when it detects
that multiple documents have been fed at the same time. You can also
specify whether to save the scanned image after scanning has
finished and continue scanning the document (double feed detection
ignore function).
To use the double feed detection function, you must first open the
scanner driver settings screen and enable double feed detection. It is
also necessary to set [Rapid recovery system] to use the double feed
detection ignore function.
To use the double feed detection ignore function, open
the [Others] tab and select the [Rapid recovery system]
check box.
Setting procedure
1
2
3
The settings screen for the scanner driver appears. (See
p. 50)
Click the [Feeding] tab.
5
6
Select either the [Detect by Length] or the [Detect by
Ultrasonic] check box (or both).
30
Click the [OK] button and close the settings screen.
Place the document as described in the “Placing
Documents” procedure on p. 25.
What to do when a double feed is
detected
Double feed detection error code
When not using the double feed detection ignore function
If a document double feed is detected during scanning, document
feeding stops when the double fed documents are ejected. When this
happens, the following error code is displayed in the Job No. Indicator
of the operating panel.
Double feed detection error code
Also, the [Rapid Recovery System] screen appears to enable you to
specify whether to continue scanning.
Also, a message screen is displayed to notify you that a double feed
has been detected. For example, the following screen is displayed in
CapturePerfect.
When this happens, stop the scanning in the application and then
scan the documents again.
When using the double feed detection ignore function
If a document double feed is detected during scanning, document
feeding stops when the double fed documents are ejected. The
following error code is displayed in the Job No. Indicator of the
operating panel, and the DFR button lights.
31
Buttons of
[Rapid Recovery
System] Screen
Buttons of
Operating
Panel
Description
[SAVE &
CONTINUE]
DFR button
Saves the preview image as a
scanned image and scans the
rest of the document.
[STOP]
Stop button
Discards the preview image and
stops scanning.
Start button
Discards the preview image and
continues scanning. Place the
double fed document again
before clicking this button.
[DISCARD &
CONTINUE]
3
Select the [Skew Detection] check box.
Detecting Skewed Documents
This scanner includes a function that can detect when a document has
been fed at a slant. When this function is used, the scanner will stop a
scanning operation automatically when it detects a skewed document
that exceeds a fixed angle, thereby preventing damage to the
document.
This function is useful for documents that are 148 mm (5.9") or larger
in width.
To use the skew detection function, open the scanner driver settings
screen and enable the skew detection function beforehand.
4
5
Place the document as described in “Placing
Documents” (see p. 25).
IMPORTANT
When this function is enabled, small documents and documents
that have been placed to the left or right of the center of the feed
inlet may be detected as skewed, and the scanning operation
may stop. Place documents in the center of the feed inlet, or
disable the skew detection function.
Setting procedure
1
2
Click the [OK] button to close the settings screen.
Open the scanner driver settings screen. (See p. 50)
Click the [Feeding] tab.
32
When a skewed document is detected
Detecting Staples and Feed Errors
Feeding automatically stops when a skewed document is detected
during scanning. The following error code is also displayed in the Job
No. Indicator of the operating panel.
This scanner includes a function that can detect documents that are
stapled together and a function that can detect feed errors.
When these functions are used, the scanner will stop a scanning
operation automatically when a stapled document is fed or a feed error
occurs, thereby preventing damage to the document.
The feed error detection function is useful for documents that are
148 mm (5.9") or larger in width.
To use the staple detection or feed error detection function, open the
scanner driver settings screen and enable the staple detection or feed
error detection function beforehand.
Skew detection error code
Setting procedure
1
2
3
4
Also, a message screen is displayed to notify you that a skewed
document has been detected.
Hint
If [Rapid recovery system] is enabled in the [Others] tab of the
scanner driver settings screen, the following screen appears instead
of the above message screen. In such cases, reload the document
and click [Yes] to continue scanning.
33
Start CapturePerfect. (See p. 48)
Open the scanner driver settings screen. (See p. 50)
Click the [Feeding] tab.
Select the [Staple Detection] or [Paper feed error
detection] check box.
5
6
Hint
Click the [OK] button and close the settings screen.
• When [Rapid recovery system] is enabled in the [Others] tab of the
scanner driver settings screen, the following screen appears
instead of the above message screen. In such cases, place the
document again, and then click [Yes] to resume scanning.
Place the document as described in “Placing
Documents” (see p. 25).
When a stapled document or feed error is
detected
Feeding automatically stops when a stapled document or feed error is
detected during scanning. The following error code is also displayed
in the Job No. Indicator of the operating panel.
• When sensors at both sides of the feed inlet detect the bent corner
of a stapled document, an error message appears and feeding
stops.
Staple detection may not operate properly in the following cases
where bending does not occur in documents.
– The document is stapled at two or more corners.
– The document is size smaller than STMT/A5.
Staple or feed error detection error code
A notification that a feed error was detected also appears on the
screen.
34
Scanning methods
Scanning with CaptureOnTouch
Operating the scanner with the operating panel buttons
What is CaptureOnTouch?
You can start scanning by selecting a job from the scanner’s operating
panel.
CaptureOnTouch is a scanning application that allows you to scan a
document with a simple operation by following the instructions on the
screen.
Save to folder
Save the file to a specified folder.
(Network)
Scanner
Format for saving image files
Excluding times when [Print] is selected as the output method, you
can specify any of the following file formats for scanned images.
• PDF format
• TIFF format
• JPEG format
• BMP format
• PPTX format (file format for Microsoft PowerPoint 2007 and later)
Print
Print with a specified
printer.
Send to application
Open the scanned image file
in a specified application.
Starting and Exiting CaptureOnTouch
By default, CaptureOnTouch becomes resident in the system when
you start your computer.
Attach to E-mail
Start the e-mail application
and attach the scanned image
file to new e-mail
Double-click
(CaptureOnTouch icon) in the taskbar to start
CaptureOnTouch and display the main window.
Hint
CaptureOnTouch is provided with multiple scanning methods that can
be selected according to the purpose and application.
• You can also start CaptureOnTouch from the Start menu. Click
[Start] – [All Programs] – [Canon DR-M1060] – [DR-M1060
CaptureOnTouch].
• When [Make CaptureOnTouch resident] is turned on by using the
[Basic settings] tab on the [Environmental settings], this shortens
the time from pressing the scanner start button to the start of
scanning. For details, see “Environmental Settings” on p. 45.
Scan First
Scan a document and then select the output method. This method
allows you to easily scan a document by just following the instructions
on the screen.
Select Scan Job
Register scanning settings from the scanning conditions to the output
method as jobs, and then scan a document by just selecting the job
that suits your purpose. This method is convenient when you want to
repeat scanning using a set procedure.
35
Exiting CaptureOnTouch
Scan First
Click
at the top of the window to close the CaptureOnTouch main
window. When doing so, the main window closes but CaptureOnTouch
is kept as resident in the system.
To stop CaptureOnTouch being resident in the system, click the
(CaptureOnTouchiconj in the taskbar, and select [Exit] from the
menu.
Scan a document and then select the output method. This method
allows you to easily scan a document by just following the instructions
on the screen.
Operation Flow
Scan the document
▼
Configure the output settings
▼
Output the scanned images
1
2
CaptureOnTouch becomes no longer resident in the system and the
icon disappears from the taskbar.
Place the document in the scanner.
Click [Scan First].
Restarting CaptureOnTouch
To use CaptureOnTouch after it is no longer resident in the system,
restart it by following the procedure below. CaptureOnTouch will start
and become resident in the system again.
• Click [Start] – [All Programs] – [Canon DR-M1060] – [DR-M1060
CaptureOnTouch].
The top screen of Scan First appears.
36
3
IMPORTANT
Set the scan method in the top screen.
If you configure scanning conditions that consume a large
amount of the computer’s memory, scanning may stop because
of insufficient memory. If an error message appears due to
insufficient memory while scanning is in progress, exit the
application, change the scanning conditions, and then try
scanning again.
A
B
Hint
If a document is scanned when [Enable continuous scanning] is
set to [ON], the Continuous Scanning screen (see p. 43) appears
when the scanning of the document is finished.
A Specify whether to enable continuous scanning. When
scanning multiple documents as one scanned image or
splitting up a large document to scan in parts, select [ON] to
enable continuous scanning.
B Specify whether to scan the document in full auto mode. When
you want to specify arbitrary scanning conditions, select [OFF]
and configure the scanner settings. (See p. 41)
4
Click the Start button.
If you place the next document and click [Scan], scanning of the
document starts.
When scanning of all the documents is finished, click [Next step].
The document is scanned. While scanning is in progress, the
number of pages scanned is displayed in addition to the scanner
settings.
When scanning is finished, the Output settings screen appears.
37
5
Select Scan Job
Configure the settings related to output and then output
the scanned images.
Register scanning settings from the scanning conditions to the output
method as jobs, and then scan a document by just selecting the job
that suits your purpose. This method is convenient when you want to
repeat scanning using a set procedure.
Operation Flow
A
Register the job
▼
B
Select the job
▼
Scan the document
▼
A Configure the settings related to output. (See p. 44)
B Click this button to output the scanned images. The button
name differs for each output method. For example, it is [Save]
when the output method is set to [Save to folder].
When output is finished, the complete screen appears. Scan First
is now finished.
Output the scanned images
Registering and Editing Jobs
In CaptureOnTouch, up to 9 jobs can be registered for use with Select
Scan Job.
1
Hint
• Clicking [Return to top] returns to the main screen of Scan First.
• When output methods apart from [Attach to E-mail] or [Print] are
specified, you can click [Open storage folder] to open the folder in
which the scanned images were saved.
38
Click the
button.
2
4
Enter the job name, and press the Enter key.
Click [Output settings], and configure the output settings.
The output setting items differ depending on the specified output
method. For details on the setting items, see the Help of
CaptureOnTouch.
Hint
Job numbers up to 9 are added (in numerical order) to the end of
the set job name. By specifying the job number with the operating
panel, you can start scanning after pressing the operating panel
button. (See p. 41)
3
Specify the output method of the job. (See p. 44)
Selecting a Job and Scanning
1
Place the document in the scanner. (See p. 24)
The top screen of Select Scan Job appears.
2
39
Click a job.
Hint
Hint
• If you set [Enable continuous scanning] to [ON], you can
continue to scan additional documents after all the pages of the
initial document are scanned.
• If you set [Check output after scanning] to [ON], you can check
the output settings after scanning.
3
• Clicking [Return to top] returns to the top screen of Select Scan Job.
• When output methods apart from [Attach to E-mail] or [Print] are
specified, you can click [Open storage folder] to open the folder in
which the scanned images were saved.
When [Enable continuous scanning] is set to [ON]
The Continuous Scanning screen (see p. 43) appears when all the
pages of the document are scanned.
If you want to scan another document, place the document in the
scanner and then click [Scan].
When scanning of all the documents is finished, click [Next step].
Click the Start button.
The document is scanned. While scanning is in progress, the
number of pages scanned is displayed in addition to the scanner
settings.
When all the pages of the document are scanned, the scanned
images are output according to the registered job settings and the
complete screen appears.
IMPORTANT
If you configure scanning conditions that consume a large amount of
the computer’s memory, scanning may stop because of insufficient
memory. If an error message appears due to insufficient memory
while scanning is in progress, exit the application, change the
scanning conditions, and then try scanning again.
40
When [Check output after scanning] is set to [ON]
4
The Output Confirmation screen appears before the scanned images
are output.
Change the settings for the output method if necessary and then click
the output button. The name of the output button differs for each
selected output method.
Press the Start button in the operating panel.
CaptureOnTouch is launched and the scanning of the selected job
starts.
Hint
When scanning jobs selected with the operating panel buttons,
the CaptureOnTouch main window automatically closes 5
seconds after the output process finishes.
Scanner Settings
By default, CaptureOnTouch scans with scanning conditions that
match the document because scanning in full auto mode is enabled.
If you want to specify, for example, the scanning mode and document
size, you can configure the desired scanning conditions in the scanner
settings.
The scanner setting items are common to Scan First and Select Scan
Job.
When Scan First:
Operating the scanner with the
operating panel buttons
You can start scanning by selecting a job from the scanner’s operating
panel.
1
2
3
Set a job number every time a job is registered with
CaptureOnTouch.
Place the document in the scanner.
Press the Job Select button in the operating panel to
display the required job number in the Job No. Indicator.
For Scan First, configure the scanner settings before you start
scanning.
The job numbers of jobs displayed in the operating panel are
allocated as follows.
Job No.
Job
1
Scan First (default / modifiable)
2 to 9
Jobs registered with CaptureOnTouch.
41
When Select Scan Job:
Scanning Side
Specify whether to scan only one side or both sides of a document.
When [Skip blank page] is specified, any blank paged detected within
the document is skipped during scanning.
Automatically straightens skewed images
When a document is scanned skewed, the skewed scanned images
are detected and then straightened.
Rotate image to match orientation of text
The orientation of text in scanned images is detected, and the images
are rotated so that the text is correctly oriented.
Use advanced settings dialog box
For Select Scan Job, configure the scanner settings for each job.
Configure scanner settings other than the basic items in the advanced
settings dialog box (scanner driver). To open the scanner driver,
select [ON] and then click the
button.
Setting Basic Items
Scanner settings include the basic items that are configured in
[Scanner Setting], and the setting items that are configured in the
advanced settings dialog box. The settings in the advanced settings
dialog box are applied for settings other than the basic items.
The settings in the driver settings dialog box are applied for any other
settings.
Color mode
Select from the following modes for scanning documents.
Detect automatically Detects whether the document is color or gray
and then scans.
24-bit Color
Scans the document in color.
Grayscale
Scans the document in Grayscale.
Black and White
Scans the document in black and white (binary).
For details on the setting items, see the Help of the driver settings
dialog box.
Page Size
Specify the page size of the document.
If you specify [Match original size], the page size of the scanned
document is detected and the images are saved at the detected size.
Dots per inch
Specify the scanning resolution.
When [Detect automatically] is specified, the resolution is detected
automatically from the content of the scanned document.
42
Operation in Continuous Scanning
Screen
Hint
The driver settings dialog box includes setting items that are the
same as the basic items in [Scanner Settings], but the setting for
each of the them is stored separately. Which settings are used during
scanning differs as follows depending on the setting of the [Use
advanced settings dialog box] check box.
Setting of [Use
advanced settings
dialog box]
Basic items
Other than basic
items
OFF
Settings of [Scanner
Settings]
Settings of the
advanced settings
dialog box of the
scanner driver
ON
Settings of the advanced settings dialog box
of the scanner driver
If a document is scanned with either Scan First or Select Scan Job
when [Enable continuous scanning] is set to [ON] in the Start screen,
the Continuous Scanning screen appears when all of the pages of the
placed document have been fed. You can confirm the scanned
images and then continue scanning.
A
B
C
A Thumbnail Display Area
Displays the thumbnail images of the scanned document. The
following operations are possible.
Click a thumbnail image to display a preview of that scanned image
in the preview area.
Drag thumbnail images to change the positions of pages.
Click
on a thumbnail image to delete the scanned image for that
page (Scan First only).
B Preview Area
Displays the preview images of the scanned document.
43
C Preview Controls
Control the preview images and cancel or continue scanning with
the following buttons.
Tools (Name)
Setting the Output Method
CaptureOnTouch is provided with various output methods for
processing scanned images.
The output method specification is common to Scan First and Select
Scan Job.
Description
(Zoom in)
Enlarges the preview image.
(Fit page)
Enlarges or reduces the preview image
to fit the current window size.
For Scan First, select an output method in the output method selection
screen which appears after scanning, and then specify each of the
output method items.
(Zoom out)
Reduces the preview image.
Select Scan Job:
(Rotate left)
Rotates the image 90 degrees
counterclockwise. (Scan First only)
(Rotate right)
Rotates the image 90 degrees
clockwise. (Scan First only)
(Rotate 180)
Rotates the image 180 degrees. (Scan
First only)
(Cancel)
Cancels the image scanning operation
and returns to the top screen.
Scan First:
(Scan)
Starts scanning of the next document.
(Next step)
Proceeds to the next step in the scan
process.
(Page Number /
Total Number of
Pages)
Displays the current page and total
number of pages.
For Select Scan Job, specify the output method separately for each
job.
The setting items related to output differ depending on the output
method.
Save to folder
Saves the scanned images to a specified folder. When you specify this
output method, configure the settings for the image files to be saved.
Attach to E-mail
Attaches the scanned images to new e-mail in the e-mail application.
When you specify this output method, configure the settings for the
image files to be attached to e-mail.
To use this feature, an e-mail application such as Windows Mail or
Outlook Express (both of these applications come standard with the
operating system) that supports MAPI (Microsoft Messaging
Application Programming Interface) needs to be specified as the default
program of the operating system.
44
Print
Environmental Settings
To configure the environmental settings of CaptureOnTouch, open the
[Environmental settings] dialog box.
Click
(CaptureOnTouch icon) in the taskbar, and select
[Environmental settings] from the menu.
Prints the scanned images with a specified printer. When you specify
this output method, specify the printer for printing.
The following describes the setting items of each tab displayed in the
[Environmental settings] dialog box.
Send to application
[Basic settings] Tab
On the [Basic settings] tab, configure the following settings.
Saves the scanned image file in a specified folder and then opens it
with a specified application. When you specify this output method,
click the [Application]
button and specify the executable file of an
application that can open image files. In addition, configure the
settings of the image file to be saved
Other Output Methods
In an environment in which Microsoft SharePoint Server has been
introduced, you can send scanned images to a Microsoft SharePoint
site. To do so, select [Save in Microsoft SharePoint] as the output
method, and configure the setting for the image files to be sent.
You must also open the advanced settings dialog box and configure
settings such as the URL of the Microsoft SharePoint site, account
information, and the save destination folder. For details on settings,
see the help (click the [Help] button in the settings screen).
Launch method setting
By default, CaptureOnTouch becomes resident in the system when
you start your computer. Clear the [Make CaptureOnTouch resident]
check box to not make CaptureOnTouch resident in the system.
IMPORTANT
The Microsoft SharePoint plug-in supports only the Windows
authentication format. Scanned images cannot be sent to Microsoft
SharePoint sites that use other authentication formats.
Display setting for when scanner connected
Select the [CaptureOnTouch appears when the scanner is connected]
checkbox to open the main screen of CaptureOnTouch automatically
when the scanner is connected to the computer. This setting is only
enabled when CaptureOnTouch is running (or resident in the system).
45
Back Up / Restore
Maximum size of attached file
Use the [Back Up] and [Restore] buttons to back up the configuration
file (settings, registered jobs, etc.) of CaptureOnTouch and restore the
settings from the backup data.
Select the [Display confirmation message if file size exceeds the
above] check box to display a confirmation message when an
attached file exceeds the maximum size.
• For Scan First, a confirmation message appears if the file size of
scanned images is larger than the file size set here.
• For Select Scan Job, a confirmation message appears if the set file
size is exceeded during scanning.
IMPORTANT
Please note that when a job with the output method set to [Save in
Microsoft SharePoint] is registered, the setting items related to
SharePoint will not be backed up.
[Theme] Tab
[Back Up] button
Back up the settings of CaptureOnTouch to a backup file (*.cot). You
can store the initial settings of CaptureOnTouch by performing a
backup before you first use CaptureOnTouch.
On the [Theme] tab, specify the appearance of the main screen of
CaptureOnTouch.
[Restore] button
Restore the settings from the backup registry file.
When using multiple computers, you can back up the environmental
settings of one computer and restore these settings on the other
computers so that all of the computers have the same settings.
[E-mail settings] Tab
On the [E-mail settings] tab, set the maximum size for the image files
to be attached to e-mail.
Select theme
Specify the appearance type for the main screen of CaptureOnTouch
with [Select theme].
46
[Plugin] Tab
On the [Plugin] tab, confirm the plugins that have been added to
CaptureOnTouch.
[Maintenance] tab
With the [Maintenance] tab, you can output log files for
CaptureOnTouch maintenance purposes.
47
Scanning with CapturePerfect
3
Scanning with CapturePerfect
Select [Canon DR-M1060] and click [OK].
This section describes procedures from launching CapturePerfect to
selecting a scanner, as well as procedures for scanning with the [Scan
batch to file] function.
See the “CapturePerfect Operating Guide” or help for details.
1
From the Windows task bar, click [Start] and then select
[All Programs].
Hint
Then click [CapturePerfect 3.1] followed by [CapturePerfect 3.1].
2
If [Canon DR-M1060] does not appear, reinstall the scanner
driver. (See p. 7)
Click [Select Scanner] in the [Scan] menu.
4
Set the default paper size and click [OK].
Hint
• The [Configure Device Settings] dialog box appears when
selecting [Canon DR-M1060] and clicking [OK] for the first time
in the [Select Scanner] dialog box, and when [Settings] is
clicked in the [Select Scanner] dialog box.
• These settings will apply when [Default] is clicked in the ISIS
driver dialog box.
• For the TWAIN driver, the default size will be set to A4 and this
cannot be modified.
5
48
Click [Scanner Setting] in the [Scan] menu.
6
10 If the placed document is removed, the scan will be
Configure the scanning conditions. (See p. 50)
interrupted and the [Continue Scanning] dialog box
appears. To continue scanning, add a document and click
[Continue Scanning] To stop scanning, click [Cancel
Scan].
11 When scanning is finished, click [Exit] in the [File] menu.
7
8
9
Place the document. (See p. 24)
Click [Scan Batch to File] in the [Scan] menu.
Configure the save destination, the name of the file to be
saved and the file format, and then click [Save] to start
scanning.
IMPORTANT
If you configure scanning conditions that consume a large
amount of the computer’s memory, scanning may stop because
of insufficient memory. If an error message appears due to
insufficient memory while scanning is in progress, exit the
application and try scanning again using different scanning
condition settings.
49
Setting the Scanner Driver
When you scan a document in an ISIS compatible application
(CapturePerfect, etc.) or TWAIN compatible application
(CaptureOnTouch, etc.), open the scanner driver and configure the
scanning conditions and other settings.
This section describes the configuration and functions of the scanner
driver.
Hint
Depending on the ISIS compatible application, the application may
have its own screen for setting scanning conditions. If the scanner
driver is opened in such an application, setting items related to the
functions provided by the scanner driver other than scanning
conditions will be displayed on the [Basic] tab.
Configuration and Functions of the
Scanner Driver
The scanner driver consists of the following tabs.
Hint
For details on the setting screen, see the Help of the scanner driver.
Click the [Help] button of the driver to display help related to the
corresponding tab or dialog box.
[Basic] tab
[Brightness] tab
Configure basic scanning conditions such as the mode, page size,
resolution, and scanning side.
In addition, you can click the [Area] button and specify the area to be
scanned.
50
[Others] tab
Adjust the brightness and contrast of scanned images.
In addition, you can also click [Gamma] and set the gamma correction
value for scanned images.
[Image processing] tab
Configure special scan method and image processing settings.
[Imprinter / Addon Dialog] tab
Set the processing method for scanned images.
[Feeding] tab
Configure settings for text that can be added onto scanned images.
Specify scanner operations related to document feeding.
51
• [Detect automatically] detects whether the document is in color,
grayscale, or black and white. You can configure advanced settings
related to the detection method by clicking [Setting]. For details, see
the Help.
Setting Basic Scanning Conditions
This section provides an overview of the basic setting items that are
the minimum requirements when configuring the scanner settings.
Page Size
Confirming Basic Conditions for
Scanning
Select the page size that matches the document to be scanned.
When you scan a document, make sure you confirm the [Color mode],
[Page Size], [Dots per inch], and [Scanning Side] basic conditions in
the Basic settings dialog box.
If [Match original size] is selected, the edges of the document are
detected and images that match the size of the document are saved.
Color mode
Select the scanning mode.
• [Advanced Text Enhancement] and [Advanced Text Enhancement
II] remove or process the background color and background
surrounding text to enhance the text for easy reading. When
[Advanced Text Enhancement II] is selected, you can make the text
in scanned images easier to read by adjusting the contrast on the
[Brightness] tab.
52
Dots per inch
Scanning Side
Select the scanning resolution.
Select which of the sides of the document to scan.
• Higher resolutions provide clearer images but result in larger file
sizes and slower scanning.
• When [Detect automatically] is specified, the resolution is detected
automatically from the content printed in the document.
• The [Moire Reduction] setting in the [Image processing] tab is
enabled when the resolution is 300 dpi or lower, while the [Image
Quality] setting is enabled when the resolution is set to 400 dpi or
600 dpi.
If the scanning side is set to [Skip blank page], the images of blank
pages are deleted when images are saved.
Image Quality
Select the scanning quality for images.
This can be configured when [Dots per inch] is set to [400 dpi] or
[600 dpi].
53
Specifying the Scan Area
• When [Speed priority] is selected, a 400-/600-dpi image is generated
from the image scanned at 300 dpi. The scanning speed will be
faster, but the quality will be slightly reduced.
• When [Image quality priority] is selected, documents will always be
scanned at 600 dpi. When [Dots per inch] is set to [400 dpi], a 400dpi image will be generated from the image scanned at 600 dpi. The
scanning speed will be slightly reduced.
Configure the following settings when you want to specify the area of
the document to be scanned.
Specifying an area
Specify the area of the document to be scanned in the Scan Area
dialog box, which is opened from the [Area] button on the [Basic] tab.
Scanning Documents of Unregistered
Page Sizes
You can register a non-standard page size that has not been
registered as a page size by naming and registering it as a custom
page size in the Custom Paper Size dialog box, which is opened from
the [Save] button on the [Basic] tab.
54
Configuring Scanner Settings According
to Purpose
When you do not want to scan colored lines and text
Specify the color (red, green, blue, all colors) to be ignored (dropped
out) in the color drop-out settings on the [Image processing] tab, and
that color will be removed from the scanned image.
Set the scanning conditions according to the scanning purpose.
When you want to delete the images of the blank pages in
two-sided documents
Set the scanning side setting to [Skip Blank Page] on the [Basic] tab
to delete the images of the blank pages in the document.
When you want to enhance a particular color
Specify the color (red, green, blue) to be enhanced in the color dropout settings on the [Image processing] tab, and that color will be
enhanced in the scanned image.
If [Skip Blank Page] is selected, the [Setting] button is enabled, and
you can adjust the level for judging whether pages are blank.
55
When you want to enhance contours in images
When you want to enhance text that is difficult to read
because of factors such as the background of the
scanned document
Adjust the edge emphasis setting on the [Image processing] tab.
Select [Advanced Text Enhancement] or [Advanced Text
Enhancement II] in the mode setting on the [Basic] tab. The
background behind the text is removed or processed so that the text
is emphasized for better readability.
When you want to make lines and text in scanned images
thicker or thinner
Drag the [Character Emphasis] slider in the [Image processing] tab to
make lines and text in the scanned images thicker or thinner.
• Advanced Text Enhancement is suitable for a document with a light
background color or a document with a non-uniform background
(such as a pattern). If the background is uniform, it is removed where
it surrounds the text, and if the background is non-uniform, it is
processed to enhance text readability.
• Advanced Text Enhancement II is suitable for scanning a document
with a uniform background color and light text and background. If the
background is non-uniform, such as a pattern, the background may
not be able to be completely removed and the text may become
difficult to read. If necessary, you can make the text in scanned
images easier to read by adjusting the contrast on the [Brightness]
tab.
56
When you want to detect multiple pages fed at the same
time
When you want to match the orientation of images to the
text when scanning a mixture of pages with different text
orientations
Select the [Double Feed Detection] check box on the [Feeding] tab.
You can enable either one or both of [Detect by Ultrasonic] and
[Detect by Length].
Select [Text orientation recognition] in [Document Orientation] on the
[Others] tab. The text orientation on each page is detected, and the
scanned image is rotated in 90-degree increments to correct the
orientation.
When you want to rotate the images of a document placed
horizontally to correct the orientation
Specify the rotation angle in [Document Orientation] on the [Others] tab.
57
When you want to use batch separation for scanning
When [Patchcode] is set, batch separation can be performed by using
a patchcode. (See p. 62)
When [Blank Page] is set, batch separation is performed when an
image of a blank page is inserted.
When you want to divide and scan a document, you can separate a
batch at the timing with which each next document is placed and
scanned. (Only enabled for applications that support batch
separation.) In this case, set the scanner driver as follows.
• Set [Feeding Option] on the [Feeding] tab to [Panel-Feeding] or
[Automatic Feeding].
Hint
• When [Batch Separation] is set to [Patchcode] or [Blank Page], [New
File] cannot be specified for [Increment Trigger] and [Reset Trigger]
under [Counter] in the [Imprinter / Addon Dialog] tab.
• When [Increment Trigger] or [Reset Trigger] is set to [New File]
under [Counter] in the [Imprinter / Addon Dialog] tab, [Patchcode] or
[Blank Page] cannot be specified for [Batch Separation].
When you want to use multistream settings for scanning
Multi-stream allows you to output multiple different scanned images
with a single scan operation, and output scanned images with different
scanning conditions for each of the front and back pages (multistream
settings).
When you want to use the multistream settings for scanning, select
the [Use MultiStream] checkbox on the [Others] tab to display the
setting items related to multistream, and then configure the setting
items in the following order.
• Set [Batch Separation] on the [Others] tab to [Auto].
When [Batch Separation] is set to [Auto], the batch is separated after
the next document is placed and scanning is continued.
58
A When you want to specify different scanning conditions for the front
and back pages of a document, select [Skip Blank Page] or [Both]
for [Scanning Side] on the [Basic] tab in advance.
B Specify the number of scanning conditions to apply in [Stream
count of Front]. Up to three can be specified.
C Select [Front 1st], and then open the other tabs and set the
scanning conditions. Depending on the value specified for [Stream
count of Front], configure the remaining [Front 2nd] and [Front 3rd]
in the same way.
D When specifying the scanning conditions of the back, configure the
settings in the same way as described in B to C. In this case,
specify [Stream count of Back], and then set the scanning
conditions for each of [Back 1st] to [Back 3rd].
To scan barcodes
Installing a barcode module (optional) allows you to scan barcodes in
the document. Click the [Barcode] button on the [Others] tab to
configure barcode scanning conditions.
Hint
The following shows the setting conditions that can be set in the
multistream settings.
See Help for details about settings.
Tab
Items that can be set
[Basic] tab
[Color mode] and [Dots per inch]
(excluding [Auto-detection] for both)
When you want to remove dots and notches that appear
in documents
[Brightness] tab
[Brightness] and [Contrast]
[Image processing] tab
[Edge emphasis], [Color drop-out], and
[Character Emphasis]
You can remove dots and notches protruding from object outlines that
appear in documents from scanned images.
[Feeding] Tab
None (all disabled)
[Others] Tab
None (only [Use MultiStream] is enabled)
• Select the [Erase Dot] check box to automatically remove isolated
black dots (3 x 3 dot size) from white backgrounds (or white dots
from black backgrounds).
59
• Select the [Erase Notch] check box to remove notches that protrude
from object outlines in scanned images.
When you want to save a scanner driver setting
When you finish configuring a setting, click the [Save] button of [User
Preference] to save the setting.
The saved setting is registered to the list. You can delete a setting
from the list with the [Delete] button, and save or load a configuration
file with the [Back Up] or [Restore] button.
60
Function Restrictions Depending on Mode Setting
Some of the setting items in each of the driver tabs are disabled as follows depending on the setting for [Color Mode] on the [Basic] tab.
[Brightness] tab
[Others] Tab
Setting value
Contrast
Setting value
Prescan
Detect Automatically
O
Detect Automatically
X
Black and White
O
Black and White
O
Error Diffusion
O
Error Diffusion
O
Advanced Text Enhancement
X
Advanced Text Enhancement
O
Advanced Text Enhancement II
O
Advanced Text Enhancement II
O
256-level Gray
O
256-level Gray
O
24-bit Color
O
24-bit Color
O
(O: Available for setting, X: Not available for setting)
(O: Available for setting, X: Not available for setting)
[Image processing] tab
Edge
emphasis
Color
drop-out
Background
smoothing
Prevent Bleed Through /
Remove Background
Erase Dot
Erase
Notch
Character
Emphasis
Detect Automatically
O
X
O
1) 1)
O
2) 2)
O
3) 3)
O
3) 3)
Black and White
O
O
X
O
O
O
O
Error Diffusion
O
O
X
O
X
O
O
Advanced Text Enhancement
O
O
X
X
O
O
O
Advanced Text Enhancement II
X
O
X
X
O
O
O
256-level Gray
O
O
O
O
X
X
X
24-bit Color
O
X
O
O
X
X
X
Setting value
O
(O: Available for setting, X: Not available for setting)
1)
Not available for setting if all of the following conditions in the [Auto Image Type Detection Settings] dialog box are met.
• [Detection mode] is not set to [Color or Gray]
• [Mode in case of binary] in the [Settings for in case of binary] tab is set to [Advanced Text Enhancement] or [Advanced Text Enhancement II]
2)
Not available for setting if either one of the following two conditions are met.
• [Detection mode] in the [Auto Image Type Detection Settings] dialog box is set to [Color or Gray]
• [Mode in case of binary] in the [Settings for in case of binary] tab is set to [Error Diffusion]
3)
Not available for setting if [Detection mode] is set to [Color or Gray] in the [Auto Image Type Detection Settings] dialog box.
61
More Advanced Scanning Methods
The following operations are performed when using patchcodes for
scanning.
Using a Patchcode for Scanning
DR-M1060 supports batch separation (automatic file separation)
functions by using patchcodes.
By tucking patchcode sheets supplied with this scanner into a
document and scanning it, the scanner can automatically separate
files by images of documents containing patchcode sheets (or
documents after the patchcode sheet).
1
Print patchcode with a printer.
Click [Start] – [All Programs] – [Canon DR-M1060] and then select
[Patchcode] from the menu.
Patchcodes can be printed in A4 and letter (LTR) sizes. Open the
application and print a patchcode that is the same size as the
document to be scanned.
Hint
• This function can be used with the supplied CapturePerfect
software. Other applications that support this function include ISIScompatible applications. It is not supported by TWAIN-compatible
applications.
• Patchodes are included with this product in PDF format.
Applications that can read PDF files such as the supplied
CapturePerfect are required to use this function.
The following patchcodes are installed together with the scanner
driver as PDF files.
Type of
Patchcode
PATCH (FILE A)
PATCH II (FILE B)
Pattern
Description
Files are separated from
the page after the page
printed with this patchcode.
You specify in the
application whether to
include the page printed
with the patchcode in the
scanned image.
Hint
The patchcode sheets are registered to the program list in
Windows 8.1.
Files are separated from
the page printed with this
patchcode. The page with
the printed patchcode is
always included in the
scanned image.
62
• Keep the patchcode sheet clean. Take particular care to keep
the patchcode detection range area clean. Also, do not bend,
fold or crease the sheet.
2
Place the documents in the scanner after inserting the
patchcode sheet in front of the page that separates the
files.
Insert the patchcode sheets at
the beginning of documents to
change file separation.
3
IMPORTANT
• Patchcodes must be printed in their normal size. If patchcodes
are enlarged or reduced, they may not be recognized correctly.
• When copying provided patchcodes to create different sized
patchcodes, ensure that the patchcode fits inside the effective
range shown in the following diagram. Also, when copying
patchcodes, ensure that they are the same size and shade as
the original.
5 mm (0.2")
Patchcode
When using CapturePerfect, select [Patchcode] in the [Batch
Separator] settings.
5 mm (0.2")
5 mm
(0.2")
(effective range for detecting patchcodes)
In an application, specify a patchcode as a type of batch
separation.
94 mm
(3.7")
63
When using other ISIS-compatible applications, open the scanner
driver settings screen and select [Patchcode] in [Batch
Separation] on the [Others] tab.
64
Maintenance
Daily Maintenance
Clean the scanner on a regular basis, as described below, to maintain
peak scanning quality.
Cleaning the Inside of the Scanner
Dust or paper particles inside the scanner may cause lines or
smudges to appear on scanned images. Use a dry cloth, for example,
to periodically remove dust and paper particles from the inside of the
scanner. Use compressed air to remove any dust that cannot be
removed with the cloth. After finishing a large scanning job, turn OFF
the scanner and then clean out any paper particles remaining inside
the scanner.
CAUTION
• When cleaning the scanner and the inside of the scanner, turn OFF
the power switch and disconnect the power cord from the power
outlet.
• Do not use spray cleaners to clean the scanner. Precision
mechanisms, such as the light source, may get wet, and cause a
malfunction.
• Never use paint thinner, alcohol, or other organic solvents to clean
the scanner. The exterior of the scanner may become deformed,
discolored, or melted. It may also cause a fire or electric shock.
Cleaning the Sensor Glass and the
Rollers
If scanned images contain streaks, or if the scanned documents
become dirty, the sensor glass or rollers inside the scanner may be
dirty. Clean them periodically.
Cleaning the Scanner
To clean the outside of the scanner, wipe off any dirt with a cloth that
has been dampened with water and thoroughly wrung out, and then
wipe the scanner dry with a clean dry cloth.
1
65
Open the document feed tray.
2
4
Raise the OPEN lever, and open the upper unit.
Wipe any dirt off the scanning glass.
Wipe any dirt off the scanning glass with a cloth that has been
dampened with water and thoroughly wrung out, and then wipe
the glass dry with a clean, dry and soft cloth.
3
Use a dry cloth, for example, to remove dust and paper
particles from the inside of the scanner.
Use compressed air to remove any dust that cannot be removed
with the cloth.
Scanning Glass
CAUTION
Do not spray water or neutral detergent directly on the scanner.
Precision mechanisms, such as the light source, may get wet,
and cause a malfunction.
TEMPERATURE WARNING
The inside of the scanner can become very hot after continuous
operation. Do not touch the scanning glass and metallic portions
of the retard roller directly.
Be sure to allow sufficient cooling before performing cleaning or
replacement.
IMPORTANT
Scratches on the sensor glass may cause marks on the images,
as well as feeding errors. If there are scratches on the sensor
glass, contact your local authorized Canon dealer or service
representative.
66
5
7
Clean the rollers.
Clean the rollers while turning them.
Wipe the rollers with a cloth that has been dampened with water
and thoroughly wrung out, and then use a clean, dry and soft cloth
to wipe away any moisture.
8
9
Rollers
6
Remove the retard roller and feed roller. (See p. 71, p. 72)
IMPORTANT
Remove the retard roller and feed roller from the scanner to clean
them, and be sure to reattach them to the scanner when cleaning
is finished.
67
Wipe the removed rollers with a cloth that has been
dampened with water and thoroughly wrung out.
Reattach the retard roller and feeding roller. (See p. 71,
p. 72)
Close the upper unit by gently pushing down on the left
and right sides. Push until it clicks into place to make
sure that it is completely closed.
10 Close the document feed tray.
Adjusting the Reduction Ratio
As the rollers installed in the scanner wear out, scanned images may
become stretched in the vertical direction. If this happens, you can
reduce the amount of stretching of the image by adjusting the
reduction ratio.
1
2
imageFORMULA Utility starts.
Start Windows and log in as a user with administrator
privileges.
Click the Start button, and then click [All Programs],
[Canon DR-M1060], and [Canon imageFORMULA Utility].
Hint
Canon imageFORMULA Utility is registered to the following
location in Windows 8.1.
68
3
4
Click [Canon DR-M1060 USB] and click [Properties].
Replacing Consumable Parts
Scanner properties are displayed.
The feed roller and retard roller are consumable parts.
The feed roller and retard roller wear with scanning. If the feed roller
and retard roller are worn, documents may not feed correctly and
paper jams and double feeds may occur.
When more than 250,000 pages have been fed (total number of pages
fed by the scanner), a message prompting you to replace the rollers is
displayed when the computer is started.
Click the [Maintenance] tab and then change the value of
[Reduction ratio adjustment].
The adjustment value can be set within the range from -3.0% to
3.0%.
If this message begins to be displayed at startup, purchase an
exchange roller kit and replace the worn parts with the consumable
parts included in the kit (feed roller and retard roller). See p. 85 for
details about the exchange roller kit.
Furthermore, the counter in the scanner that records the number of
pages fed also needs to be reset when you replace the rollers. (See
p. 73)
5
Opening and Closing the Upper Unit
Click [OK] to close the scanner properties.
1
69
Open the document feed tray.
2
3
Raise the OPEN lever, and open the upper unit.
Close the upper unit by gently pushing down on the left
and right sides. Push until it clicks into place to make
sure that it is completely closed.
Hint
The location of each of the consumable parts is shown below.
Feed Roller
4
Retard roller (inside
the upper unit)
70
Close the document feed tray.
Replacing the Retard Roller
3
Remove the retard roller.
4
Install the new retard roller.
TEMPERATURE WARNING
The inside of the scanner can become very hot after continuous
operation. Do not touch the scanning glass and metallic portions of
the retard roller directly.
Be sure to allow sufficient cooling before performing cleaning or
replacement.
1
2
Slide the roller cover from the left to the center while
opening it.
Raise the securing lever for the retard roller toward you,
and slide it to the left.
5
71
Slide the securing lever for the retard roller to the right,
and lower it backward.
6
3
Press the roller cover to close it.
Lower the feed roller toward you while removing it from
the left.
Replacing the Feed Roller
1
Lift the securing lever for the feed roller forward.
2
Slide the securing lever for the feed roller to the left.
72
4
Remove the feed roller.
5
Attach the right joint of the new feed roller.
6
7
Attach the left side of the feed roller, and slide the
securing lever for the feed roller to the right.
Raise the feed roller toward the back until the securing
lever clicks into place.
imageFORMULA Utility starts.
Resetting the counter
1
2
3
Start Windows and log in as a user with administrator
privileges.
Click [Canon DR-M1060 USB] and click [Properties].
Scanner properties are displayed.
Click the Start button, and then click [All Programs],
[Canon DR-M1060], and [Canon imageFORMULA Utility].
Hint
Canon imageFORMULA Utility is registered to the following
location in Windows 8.1.
73
4
Auto Power Off Setting
Click the [Maintenance] tab and then select [Reset].
The scanner automatically turns off if 4 hours elapse without scanning
or another operation being performed.
To disable this setting, follow the procedure below.
1
2
Start Windows and log in as a user with administrator
privileges.
Click the Start button, and then click [All Programs],
[Canon DR-M1060], and [Canon imageFORMULA Utility].
Hint
Canon imageFORMULA Utility is registered to the following
location in Windows 8.1.
The counter for [Current Rollers] resets.
5
Click [OK] to close the scanner properties.
74
imageFORMULA Utility starts.
3
Click [Canon DR-M1060 USB] and click [Properties].
Scanner properties are displayed.
4
5
Click the [Maintenance] tab and then clear the [Turn off
automatically after 4 hours] check box.
Click [OK] to close the scanner properties.
75
Troubleshooting
Common Problems and Solutions
This section provides recommended solutions to common problems.
If you have a problem that is not solved by the following, contact your
local authorized Canon dealer.
Problem 1
The scanner will not turn on.
Solutions
Confirm that the AC adapter is plugged firmly into a
power outlet.
Problem 2
The scanner is not recognized.
Solutions
(1) Confirm that the scanner is properly connected to
the computer with a USB cable.
(2) Confirm that the scanner is turned on. See the
previous problem (1) if the scanner does not turn
on.
(3) The computer’s USB interface may not support the
scanner. The scanner cannot be guaranteed to
work with all USB interfaces.
(4) Confirm that the supplied USB cable is used to
connect the scanner to the computer. The scanner
cannot be guaranteed to work with all available
USB cables.
(5) If the scanner is connected to the computer via a
USB hub, try removing the hub and connecting
directly to the computer.
Problem 3
Documents feed askew (scanned images are
slanted).
Solutions
(1) Align the document guides to fit the documents as
closely as possible, and load the documents so that
they feed straightly.
(2) Enable [Skew Detection] in the scanner driver
settings.
(3) If many pages have been scanned since roller
cleaning, clean the rollers. If documents still feed
askew, roller replacement or other maintenance
may be needed. See Chapter 7 Maintenance for
roller replacement procedures.
76
Problem 4
Both sides are not scanned even when the Duplex
scanner driver setting is enabled.
Solutions
In CaptureOnTouch and CapturePerfect, executing a
job for which single-sided (simplex) scanning is
registered will always result in simplex scanning,
regardless of scanner driver settings.
To perform duplex scanning, either change the job
setting or create another job for duplex scanning.
Problem 5
If white lines or streaks appear in scanned images.
Solutions
Clean both sides of the scanner glass, and the rollers.
If a sticky substance such as glue or correction fluid is
found, carefully wipe with just enough pressure to clean
the area where the lines appear. If the problem cannot
be solved by cleaning, the internal glass may be
scratched. Contact your local authorized Canon dealer.
Problem 6
Pages are missing.
Solutions
When the scanner driver’s [Scanning Side] setting is
[Skip Blank Page], documents with very little black may
be unintentionally skipped. Click the [Setting] button
and decrease the [Set the likelihood of skipping blank
page] value, or select another scan mode setting such
as [Simplex] or [Duplex]. If pages are skipped due to
the document double feeding, see “Problem 7
Documents jam (or double-feed)”.
Problem 7
Documents jam (or double-feed).
Solutions
(1) If the roller has been installed correctly, clean it if
necessary.
(2) Proper scanning may not be possible when
document pages stick together due to static
electricity. Fan the documents before you load
them.
(3) Set the scanner to Non separation feeding mode,
and manually feed the scanner one page at a time.
Problem 8
Scanned images are saved in TIFF instead of JPEG
format.
Problem 11
Scanned images of multiple pages cannot be saved
in a single JPEG or BMP file.
Solutions
When documents are scanned with CapturePerfect
while [Color Mode] is set to [Detect automatically] in the
scanner driver, documents detected as black and white
are automatically saved in TIFF format, even if the file
type is specified as JPEG format. This occurs because
JPEG format does not support black and white binary
format images. If you want to save all images in JPEG
format, change the scanning [Color Mode] to either [24bit Color] or [256-level Gray].
Solutions
Multiple scanned images cannot be saved in a single
JPEG or BMP file. Save the images in either multi-page
TIFF or PDF format.
Problem 9
Each scanned image of a multi-page document is
saved as a separate document.
Solutions
• With CaptureOnTouch, you can scan multiple pages
into one image file when TIFF or PDF file format is
selected. To do this, select [File type], click the
button, and select [Save all pages as one file] in the
displayed dialog box.
• When you select [Scan Batch to File] from the [Scan]
menu in CapturePerfect, a dialog box appears with a
[Multi Page Settings] pull-down that allows you to
select [Single Page]. If you select [Single Page] here,
each page of a multi-page document is saved as a
separate image file. To save multiple pages to a
single image file, select [Multi Page (All Pages)].
Problem 10
All of the placed documents have been scanned,
but the scanned image does not appear on the
application.
Solutions
When [Panel-Feeding] or [Automatic Feeding] is
selected as the feeding method on the scanner driver’s
setting screen, a scanning operation will not continue
after all of the documents are fed, as the scanner
awaits additional documents to be fed. You can finish
the operation and send the scanned images to the
application by pressing the Stop button on the
operating panel.
77
Problem 12
Memory becomes insufficient and scanning stops.
Solutions
If you configure scanning conditions that use a large
amount of the computer’s memory, scanning may stop
because of insufficient memory. Although this depends
on the computer’s memory size, the possibility of
insufficient memory increases if any of the following
scanning conditions overlap.
• [Color Mode] is set to [24-bit Color]
• A large page size (e.g. A3) is specified as the [Page
Size]. Alternatively, the page size is set to [Scanner’s
Maximum].
• A high resolution (600dpi etc.) is specified for [Dots
per inch].
If an error message appears due to insufficient memory
while scanning is in progress, exit the application,
change the scanning conditions (e.g. reduce the
resolution or page size) and then try scanning again. In
addition, the amount of memory used can be contained
by turning off [Moire Reduction] and [Prevent Bleed
Through / Remove Background] if they are set to on.
Problem 13
The CapturePerfect and CaptureOntouch plug-ins
and Captiva Cloud do not function.
Solutions
• Install .NET Framework if it is not already installed.
• If you are using Windows Server 2008 R2 / Windows
Server 2012 R2, verify that Microsoft .NET
Framework is enabled. If .NET Framework is disabled
on the operating system, the above applications will
not function.
Software Troubleshooting
This section describes troubleshooting problems and solutions for
operating the supplied software (CaptureOnTouch and
CapturePerfect).
If scanning is too slow
(1) Close other running programs, if any.
(2) Scanning can be slowed down by memory shortage caused by
memory-resident applications such as anti-virus programs. Close
such memory-resident programs if necessary to free up memory
space.
(3) When insufficient hard disk space is available, the scanner may
be unable to create the necessary temporary files for scanned
data. Delete unneeded data on the hard disk to free up more
space.
(4) Scanning is slow if the computer’s USB port is not Hi-Speed USB
2.0 compliant.
(5) If using a common USB cable that is not Hi-Speed USB 2.0
compliant, replace the cable with the supplied compliant cable.
(6) When the scanner is connected to the computer via a USB hub
that is not Hi-Speed USB 2.0 compliant, remove the hub and
connect the scanner directly to the computer.
If scanned image files cannot be opened in an application
(1) Scanned images saved as multi-page TIFF files can be opened
only by programs that support this file format.
(2) Images saved as compressed TIFF files (single- as well as multipage) can only be opened by programs that support the
compressed format. This can occur with programs that are not
compatible with CaptureOnTouch or CapturePerfect. In this case,
select “None” as the image file compression format before
scanning.
78
Useful tips
Here are some useful tips for scanning documents.
Can I copy or back up scanner setting configurations?
CaptureOnTouch
Scanner settings are backed up from the Environment settings. See
also the following question, “Can I copy or back up CaptureOnTouch
settings?”.
CapturePerfect
Scanner setting configurations cannot be copied or backed up in
CapturePerfect.
Where are scanned images saved? Can the save destination be
changed?
Images are saved to the following locations, according to program
settings.
For example, save locations such as the following can be set in
CaptureOnTouch.
CaptureOnTouch
• For Scan First scanning, files are saved in the folder specified on the
Output Settings screen.
• For selected job scanning, files are saved in the folder specified on
the [Output setting] during job registration.
CapturePerfect
• During normal scanning operations such as single-page scanning,
the image file save destination can be specified each time scanning
is performed.
• When scanning using a registered job, files are saved to the folder
specified by the job settings.
Can I copy or back up CaptureOnTouch settings?
The setting configurations can be backed up and restored using
[Back up/Restore] on the [Basic settings] tab on the [Environmental
settings] dialog box.
What rules apply to scanned image file names?
In CaptureOnTouch, scanned image file names are constructed
according to the settings in the [File name settings] dialog box. This
dialog box appears when you click the
button on the [File name] on
the Scan First output settings screen, and on the [Output setting] tab
on the Register new job screen.
Scanned image file names are constructed partly or wholly according
to the following three settings in the dialog box.
How are the scan settings configured?
CaptureOnTouch
• For Scan First scanning, click [Scanner setting] on the first (top)
screen to display available scan settings.
• For selected job scanning, click [Scanner setting] during job
registration to display available scan settings.
CapturePerfect
• For normal scanning, click [Scanner Setting] from the [Scan] menu
to open the scanner driver setting screen, and make settings there.
• Scan job settings are made for each job.
How do I save multiple pages in one file, or save one file per
page?
When scanned images are saved in BMP or JPEG format, each image
is always saved in a separate file.
When scanned images are saved in PDF or TIFF format, you can
specify multi- or single-page files. See also “Problem 9” in “Common
Problems and Solutions”.
Setting
Description
Start file
name with
character
string
Any specified text string to be included in the file
name.
Add date and
time
Appends the date and time to file names. Select
the date format from the list box. YYYY = year,
MM = month, and DD = day of month. The time is
appended after the date.
Add counter
to file name
Append serial numbers in the order of scanned
image saving. Specify the number of digits and
starting number.
A sample file name is displayed as the [File name] in the [File name
settings] dialog box.
79
CapturePerfect
The rules for the file names of scanned images and the folder in which
scanned images are saved can be set and then applied during
scanning. For details, see the “Operating Guide” or help of
CapturePerfect.
How do I print scanned data?
CaptureOnTouch
• For Scan First scanning, select [Print] on the Output Method
selection screen.
• For selected job scanning, select [Print] as the [Output method
selection] when registering the job.
CapturePerfect
Scan using the [Scan Batch to Printer] function. Alternatively, register
a job with a printer selected as the output destination.
How do I scan half-folded documents (folio scanning)?
Fold the document in half, and set it in the scanner with the fold at the
right. Specify half-size document (the size after folding) and select
[Folio] for the [Scanning side], then scan. For details, see p. 27.
How do I save scanned data in a shared folder?
CaptureOnTouch
• For Scan First scanning, select [Save to folder] on the output method
selection screen, and specify the shared folder as the save
destination on the Output Setting screen.
• For selected job scanning, select [Save to folder] in [Output method
selection] during job registration, and specify the shared folder as
the save destination on the Output Setting screen.
CapturePerfect
Scan using the [Scan Batch to File] (or [Scan Page]) function.
Alternatively, register a job with the output destination as a file, and set
the save destination to the shared folder.
How can I skip blank pages, and scan only non-blank pages?
Specify [Skip Blank Page] on the scanner driver setting screen, then
scan.
How do I scan cards?
Place the cards in the scanner vertically. Specify the size of the card
(or [Match original size]) in the scanner settings, and then scan. For
details, see p. 27.
Is it possible to add or insert images in a scanned image file?
CapturePerfect includes a function to add or insert pages in scanned
image files. Refer to the CapturePerfect Operation Guide for details.
How do I paste OCR results from CapturePerfect into Excel or
Word?
After scanning with OCR recognition enabled in CapturePerfect, click
[Modify Barcode/OCR] in the [Edit] menu to open the [Modify Barcode/
OCR] dialog box, where you can copy the text in the [OCR Characters]
box. Alternatively, PDF files that were scanned with OCR enabled can
be opened with an application, where the desired text can be copied.
How can I attach scanned data to an e-mail (or send it as e-mail)?
CaptureOnTouch
• For Scan First scanning, select [Attach to E-mail] on the output
method selection screen.
• For selected job scanning, select [Attach to E-mail] as the [Output
method selection] when registering the job.
CapturePerfect
Scan using the [Scan Batch to Mail] function. Alternatively, register a
job with the output destination as e-mail.
What is the best way to scan business cards or photos?
Set [Page Size] to [Match original size] on the scanner driver setting
screen, then scan. Alternatively, register the size of the cards or
photos to be scanned. For details, see p. 54.
How do I add Bates numbering to scanned images?
Enter the necessary items under [Text] in the [Imprinter/Addon Dialog]
tab on the scanner driver setting screen, then scan.
How do I load and scan documents with mixed sizes?
Set [Page Size] to [Match original size] on the scanner driver setting
screen, then scan. For details, see p. 52.
80
Clearing Paper Jams, Skewed Documents, Stapled Documents, and
Feed Errors
When paper jams and skewed documents are detected during
scanning, the following error codes are displayed in the scanner’s
display panel and scanning is interrupted.
2
Raise the OPEN lever, and open the upper unit.
Paper jam error code
Skew, staple, or feed error detection error code
When a paper jam or double feed occurs during scanning, use the
following procedures to clear them.
CAUTION
Be careful when removing jammed paper. take care not to cut your
hand on the edges of the paper.
1
Hint
Remove the document.
The “C” error code appears in the operating panel when the
upper unit is open..
81
3
4
Remove the jammed document.
Close the upper unit by gently pushing down on the left
and right sides. Push until it clicks into place to make
sure that it is completely closed.
TEMPERATURE WARNING
The inside of the scanner can become very hot after continuous
operation. Do not touch the scanning glass and metallic portions
of the retard roller directly.
Be sure to allow sufficient cooling before performing cleaning or
replacement.
After removing the jammed paper, check to see if the last page
was scanned correctly, and then continue scanning.
Hint
When the [Rapid recovery system] check box is enabled in the
scanner driver settings screen, you can resume a scanning operation
even if it is interrupted by a paper jam by removing the document and
resuming from the document that was being fed when the interruption
occurred.
As the image of the document that was being fed at the time of the
interruption may not be saved in such cases, be sure to verify the last
scanned image before resuming the operation.
IMPORTANT
Make sure to pull the document out carefully, without applying too
much force. If the jammed paper tears while you are pulling it out,
make sure to remove any remaining pieces from inside the
scanner.
82
Uninstalling the Software
If the ISIS/TWAIN driver, CaptureOnTouch or CapturePerfect is not
operating normally, follow the procedure below to uninstall them.
Then, re-install the software from the Setup disc. (See p. 7)
IMPORTANT
Log on to Windows as an Administrator.
1
2
From the Windows task bar, click the [Start] button and
then [Control Panel].
Click [Uninstall a program] ([Add or Remove Programs] in
Windows XP).
The [Uninstall or change a program] dialog box appears.
3
From the Programs list, select the software you want to
remove and then click [Remove].
The delete confirmation screen appears.
4
5
Click [Yes].
Click [Finish].
Uninstallation of the software is now complete.
83
Appendix
Specifications
Main Unit
Scanning Sensor
Light source
Scanning Side
Scanning modes
Contact image sensor
LED
Simplex/duplex
Black and White, Error Diffusion, 256-level
Grayscale, Advanced Text Enhancement,
Advanced Text Enhancement II, 24-bit Color
Scanning resolution (Primary Scan Lines x Secondary Scan Lines)
100 x 100dpi/150 x 150dpi/200 x 200dpi/
240 x 240dpi/300 x 300dpi/400 x 400dpi/
600 x 600dpi
Scanning Speed (Conditions: Core i7 2.8 GHz CPU, 4 GB memory,
A4 horizontal document size)
Grayscale
Simplex 200dpi 60 pages/min.
300dpi 60 pages/min.
Duplex
200dpi 120 images/min.
300dpi 120 images/min.
24-bit Color
Simplex 200dpi 60 pages/min.
300dpi 40 pages/min.
Duplex
200dpi 120 images/min.
300dpi 80 images/min.
Interface
Hi-Speed USB 2.0
Other functions
Folio scanning, double feed detection ignore
External Dimensions
When trays are closed: 424 mm (16.7") (W) ×
246 mm (9.7") (D) × 120 mm (4.7") (H)
When trays are opened: 424 mm (16.7") (W) ×
440 mm (17.3") (D) × 210 mm (8.3") (H)
Weight (without AC adapter)
Aprpoximately 6.1 kg (13.5 lb)
Power Supply (using AC adapter)
DC24V 1.3A
Power Consumption
Scanning: Maximum 32.5 W
In the Sleep mode: Maximum 2.5 W
With power switch OFF: Maximum 0.5 W
Noise
Not more than 56 dB
Operating Environment
Temperature: 10°C to 32.5°C (50°F to 90.5°F)
Type
Desktop sheetfed scanner
Scanning Document Size
Plain Paper
Size
Width: 50.8 mm to 300 mm (2" to 11.8")
Length: 70 mm to 432 mm (2.8" to 17") (You can
scan documents up to 3,000 mm (118.1") long by
setting the scanner to the Long Document mode.)
Paper weight: U-turn path (page separation): 27 to 128 g/m2
(0.04 mm to 0.15 mm)
U-turn path (bypass): 27 to 164 g/m2 (0.04 mm to
0.2 mm)
Straight path: 27 to 255 g/m2 (0.04 mm to 0.3 mm)
Loading capacity:
A4 size or smaller: Maximum of 60 sheets
Larger than A4 size: Maximum of 25 sheets
(for 80 g/m2 paper in both case)
Business Card
Size:
Width: 50.8 mm to 55 mm (2" to 2.2")
Length: 85 mm to 91 mm (3.4" to 3.6")
Paper thickness:
128 to 380 g/m2 (0.15 mm to 0.45 mm)
Orientation:
Vertical feeding only
Eject method: Straight path only
Postcard
Size:
Width: 88.9 mm to 108 mm (3.5" to 4.3")
Length: 127 mm to 152.4 mm (5" to 6")
Paper thickness:
128 to 300 g/m2 (0.15 mm to 0.4 mm)
Eject method: Straight path only
Card
Size:
54 mm x 86 mm (2.2" x 3.4") (ISO standard)
Card thickness: 0.76 mm (0.03") or less, 1.4 mm (0.055") or less
for the embossment
Orientation:
Vertical feeding only
Eject method: Straight path only
Loading capacity:
3 cards (non-embossed), 1 card (embossed)
84
Humidity: 20% to 80% RH
About the Flatbed Scanner Unit 101/
201
AC Adapter (100 to 240 V type)
Model Number
Input
Output
Weight
MG1-4558
AC100 to 240V, 50/60 Hz, 1.1 to 0.58 A
DC24V 2.0A
Approximately 0.4kg (0.9 lb) (including power
cord)
The optional Flatbed Scanner Unit 101/201 can be connected to and
used with this scanner.
System requirements
The computer must comply with the necessary system requirements
of Flatbed Scanner Unit 101/201.
The scanner driver of Flatbed Scanner Unit 101/201 needs to be
installed to use the unit.
Replacement Parts
Exchange roller kit (product code: 9691B001)
Kit to replace the rollers (feed roller unit, retard roller).
• For the replacement procedure, see “Replacing Consumable Parts”
on p. 69.
• Contact your local authorized Canon dealer or service
representative for detailed information about the replacement parts.
About Use with CaptureOnTouch
About Assigning Function to Start Button
When you connect Flatbed Scanner Unit 101/201, you can assign
Scan First of CaptureOnTouch or any job to the start button of Flatbed
Scanner Unit 101/201.
Option
Limitation of Full Auto Mode
Barcode module (product code: 1922B001)
2D code module (product code: 1922B003)
Add-on module to recognize barcodes/2D codes printed on
documents during scanning,
Flatbed scanner unit 101 (product code: 4101B001)
Flatbed scanner unit that can be connected to and used with a DR
scanner. Connecting the unit to this scanner enables you to use this
scanner as a flatbed scanner with an automatic document feeder.
Flatbed scanner unit 201 (product code: 6240B001)
Flatbed scanner unit that can be connected to and used with a DR
scanner and supports A3-size documents.
When a document is scanned with Flatbed Scanner Unit 101/201, Full
Auto mode of CaptureOnTouch may not function effectively.
Limitation of Restarting with Start Button
When CaptureOnTouch is set not to be resident in memory,
CaptureOnTouch cannot be restarted by pressing the start button on
Flatbed Scanner Unit 101/201 after you end CaptureOnTouch.
About Setting up the Scanner Driver
When functions of this scanner cannot be selected with the Flatbed
Scanner Unit 101/201 settings dialog box, click [Option] in the dialog
box to open the scanner driver and make the required settings.
Specifications are subject to change without notice due to product
improvements.
85
Dimensions
246 mm
(9.7")
424 mm (16.7")
210 mm
(8.3")
120 mm
(4.7")
440 mm (17.3")
86
Index
A
R
Adjusting the Reduction Ratio .................................................... 68
Auto Power Off Setting ............................................................... 74
Reset
Counter ................................................................................ 73
Rollers
Cleaning ............................................................................... 65
Replacing ............................................................................. 69
C
CaptureOnTouch
Environmental Settings ........................................................ 45
Restarting ............................................................................ 36
Scan First ............................................................................. 36
Select Scan Job ................................................................... 38
Starting ................................................................................ 35
Card ........................................................................................... 27
Connecting ................................................................................... 9
D
S
Scanner Driver
Basic Settings ...................................................................... 52
Configuring Settings According to Purpose ......................... 55
Scanning Glass
Cleaning ............................................................................... 65
Setup ............................................................................................ 4
Start Button ................................................................................ 20
Stop Button ................................................................................. 20
System Requirements .................................................................. 6
DFR button ...........................................................................20, 31
Documents
Card ..................................................................................... 27
Folded documents, placing .................................................. 27
Loading Documents ............................................................. 24
Double feed detection ................................................................ 30
T
Third-Party Software .................................................................... 5
I
Installing ....................................................................................... 7
J
Job
Editing .................................................................................. 38
Registering ........................................................................... 38
Select and scan ................................................................... 39
Job No. Indicator ........................................................................ 20
Job Select Button ....................................................................... 20
O
Operating Panel ......................................................................... 20
P
Patchcode .................................................................................. 62
Power ......................................................................................... 10
87
CANON ELECTRONICS INC.
1248, SHIMOKAGEMORI, CHICHIBU-SHI, SAITAMA 369-1892, JAPAN
CANON U.S.A. INC.
ONE CANON PARK, MELVILLE, NY 11747, U.S.A.
CANON CANADA INC.
6390 DIXIE ROAD, MISSISSAUGA, ONTARIO L5T 1P7, CANADA
CANON EUROPA N.V.
BOVENKERKERWEG 59, 1185 XB AMSTELVEEN, THE NETHERLANDS
CANON LATIN AMERICA, INC.
ONE CANON PARK, MELVILLE, NY 11747, U.S.A.
CANON AUSTRALIA PTY. LTD.
1 THOMAS HOLT DRIVE, NORTH RYDE, SYDNEY. N.S.W, 2113. AUSTRALIA
CANON SINGAPORE PTE. LTD.
1 HARBOUR FRONT AVENUE #04-01, KEPPEL BAY TOWER, SINGAPORE 098632
CANON HONGKONG COMPANY LTD.
19TH FLOOR, THE METROPOLIS TOWER, 10 METROPOLIS DRIVE, HUNGHOM, KOWLOON, HONG KONG.
CANON KOREA BUSINESS SOLUTIONS INC.
BS TOWER, 607 TEHERAN-RO, GANGNAM-GU, SEOUL, KOREA
CANON INDIA PVT. LTD
7TH FLOOR, TOWER B DLF CYBER TERRACES DLF PHASE III GURGAON - 122002 HARYANA, INDIA
PUB. CE-IE-0960
© CANON ELECTRONICS INC. 2014
