© 2006 Samsung Electronics Co., Ltd. All rights reserved.
This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this manual.
• CLX-3160N and CLX-3160FN are model names of Samsung Electronics Co., Ltd.
• Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd.
• PCL and PCL 6 are trademarks of Hewlett-Packard company.
• Microsoft, Windows, Windows 98, Windows Me, Windows 2000 and Windows XP are registered trademarks of Microsoft Corporation.
• UFST® and MicroType™ are registered trademarks of Monotype Imaging Inc.
• TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc.
• All other brand or product names are trademarks of their respective companies or organizations.
Contact SAMSUNG WORLD WIDE
If you have any comments or questions regarding Samsung products, contact the SAMSUNG customer care center.
Country Customer Care Center Web Site
CANADA
MEXICO
U.S.A
ARGENTINE
BRAZIL
CHILE
COSTA RICA
ECUADOR
EL SALVADOR
GUATEMALA
JAMAICA
1-800-SAMSUNG
(7267864)
01-800-SAMSUNG
(7267864)
1-800-SAMSUNG
(7267864)
0800-333-3733
0800-124-421
800-726-7864 (SAMSUNG) www.samsung.com/cl
0-800-507-7267 www.samsung.com/latin
1-800-10-7267
800-6225
1-800-299-0013
1-800-234-7267
PANAMA
PUERTO RICO
800-7267
1-800-682-3180
REP. DOMINICA 1-800-751-2676
TRINIDAD &
TOBAGO
1-800-7267-864 www.samsung.com/ca www.samsung.com/mx www.samsung.com
www.samsung.com/ar www.samsung.com/br www.samsung.com/latin www.samsung.com/latin www.samsung.com/latin www.samsung.com/latin www.samsung.com/latin www.samsung.com/latin www.samsung.com/latin www.samsung.com/latin
VENEZUELA
BELGIUM
CZECH
REPUBLIC
DENMARK
FINLAND
FRANCE
GERMANY
HUNGARY
ITALIA
LUXEMBURG
1-800-100-5303
02 201 2418
844 000 844
38 322 887
09 693 79 554
08 25 08 65 65
(€ 0,15/min)
01805 - 121213
(€ 0,12/min)
06 40 985 985
199 153 153
02 261 03 710 www.samsung.com/latin www.samsung.com/be www.samsung.com/cz www.samsung.com/dk www.samsung.com/fi www.samsung.com/fr www.samsung.de
www.samsung.com/hu www.samsung.com/it www.samsung.lu
ii
Country Customer Care Center Web Site
NETHERLANDS 0900 20 200 88
(€ 0,10/min)
NORWAY
POLAND
231 627 22
0 801 801 881
PORTUGAL
SLOVAKIA
SPAIN
SWEDEN
80 8 200 128
0850 123 989
902 10 11 30
08 585 367 87
U.K
RUSSIA
UKRAINE
AUSTRALIA
CHINA
HONG KONG
INDIA
0870 242 0303
8-800-200-0400
8-800-502-0000
1300 362 603
800-810-5858
010- 6475 1880
2862 6001
INDONESIA
JAPAN
MALAYSIA
PHILIPPINES
3030 8282
1600 1100 11
0800-112-8888
0120-327-527
1800-88-9999
1800-10-SAMSUNG
(7267864) www.samsung.com/nl www.samsung.com/no www.samsung.com/pl www.samsung.com/pt www.samsung.com/sk www.samsung.com/es www.samsung.com/se www.samsung.com/uk www.samsung.ru
www.samsung.com/ur www.samsung.com/au www.samsung.com.cn
www.samsung.com/hk www.samsung.com/in www.samsung.com/id www.samsung.com/jp www.samsung.com/my www.samsung.com/ph
SINGAPORE
THAILAND
TAIWAN
VIETNAM
1800-SAMSUNG (7267864) www.samsung.com/sg
1800-29-3232
02-689-3232 www.samsung.com/th
0800-329-999
1 800 588 889 www.samsung.com/tw www.samsung.com/vn
SOUTH AFRICA 0860 7267864 (SAMSUNG) www.samsung.com/za
U.A.E
800SAMSUNG (7267864) www.samsung.com/mea
C
ONTENTS
5. Loading originals and print media
iii
(CLX-3160FN only)
Sending a fax
Receiving a fax
Other ways to fax
10. Fax setup (CLX-3160FN only)
iv
12. Ordering supplies and accessories
(CLX-3160FN only
)
........................................................................................................ 15.2
v
Important Precautions and Safety Information
When using this machine, these basic safety precautions should always be followed to reduce risk of fire, electric shock and injury to people:
1.
Read and understand all instructions.
2.
Use common sense whenever operating electrical appliances.
3.
Follow all warnings and instructions marked on the machine and in the literature accompanying the machine.
4.
If an operating instruction appears to conflict with safety information, heed the safety information. You may have misunderstood the operating instruction. If you cannot resolve the conflict, contact your sales or service representative for assistance.
5.
Unplug the machine from the AC wall socket and/or telephone jack before cleaning. Do not use liquid or aerosol cleaners. Use only a damp cloth for cleaning.
6.
Do not place the machine on an unstable cart, stand or table. It may fall, causing serious damage.
7.
Your machine should never be placed on, near or over a radiator, heater, air conditioner or ventilation duct.
8.
Do not allow anything to rest on the power. Do not locate your machine where the cords will be abused by persons walking on them.
9.
Do not overload wall outlets and extension cords. This can diminish performance, and may result in the risk of fire or electric shock.
10. Do not allow pets to chew on the AC power, telephone or PC interface cords.
11. Never push objects of any kind into the machine through case or cabinet openings.
They may touch dangerous voltage points, creating a risk of fire or shock. Never spill liquid of any kind onto or into the machine.
12. Your machine may have a heavy cover for optimal pressure on the document for the best scanning and/or faxing (usually the flatbed-type machine). In this case, replace the cover after placing document on the scan glass, by holding and moving it down slowly until it seats on its location.
13. To reduce the risk of electric shock, do not disassemble the machine. Take it to a qualified service technician when repair work is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly could cause electric shock when the unit is subsequently used.
14. Unplug the machine from the telephone jack, PC and AC wall outlet and refer servicing to qualified service personnel under the following conditions:
•When any part of the power cord, plug or connecting cable is damaged or frayed.
•If liquid has been spilled into the machine.
•If the machine has been exposed to rain or water.
•If the machine does not operate properly after instructions have been followed.
•If the machine has been dropped, or the cabinet appears damaged.
•If the machine exhibits a sudden and distinct change in performance.
15. Adjust only those controls covered by the operating instructions. Improper adjustment of other controls may result in damage, and may require extensive work by a qualified service technician to restore the machine to normal operation.
16. Avoid using this machine during a lightning storm. There may be a remote risk of electric shock from lightning. If possible, unplug the AC power and telephone cord for the duration of the lightning storm.
17 The Power cord supplied with your machine should be used for safe operation. If you are using a cord which is longer than 2 m with 110 V machine, then it should be 16 AWG a
or bigger.
18. Use only No.26 AWG
*
or larger telephone line cord.
19. SAVE THESE INSTRUCTIONS.
Laser Safety Statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a
Class I laser product conforming to the requirements of IEC 825.
Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to laser radiation above a Class I level during normal operation, user maintenance or prescribed service condition.
WARNING
Never operate or service the printer with the protective cover removed from Laser/
Scanner assembly. The reflected beam, although invisible, can damage your eyes.
When using this product, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury to persons:
Ozone Safety
During normal operation, this machine produces ozone. The ozone produced does not present a hazard to the operator. However, it is advisable that the machine be operated in a well ventilated area.
If you need additional information about ozone, please request your nearest Samsung dealer.
ix a AWG: American Wire Gauge
Mercury Safety
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE
RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR
FEDERAL LAWS. For details see lamprecycle.org, eiae.org, or call 1-800-
Samsung
Power Saver
This printer contains advanced energy conservation technology that reduces power consumption when it is not in active use.
When the printer does not receive data for an extended period of time, power consumption is automatically lowered.
Recycling
Please recycle or dispose of the packaging material for this product in an environmentally responsible manner.
Correct Disposal of This Product (Waste Electrical &
Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
Radio Frequency Emissions
FCC Information to the User
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or x television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or experienced radio TV technician for help.
C
AUTION
:
Change or modifications not expressly approved by the manufacturer responsible for compliance could void the user's authority to operate the equipment.
Canadian Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled
“Digital Apparatus”, ICES-003 of the Industry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.
Fax Branding
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone facsimile machine unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission the following information:
(1) the date and time of transmission
(2) identification of either business, business entity or individual sending the message; and
(3) telephone number of either the sending machine, business, business entity or individual.
The Telephone Company may make changes in its communications facilities, equipment operations or procedures where such action is reasonably required in the operation of its business and is not inconsistent with the rules and regulations in FCC
Part 68. If such changes can be reasonably expected to render any customer terminal equipment incompatible with telephone company communications facilities, or require modification or alteration of such terminal equipment, or otherwise materially affect its use or performance, the customer shall be given adequate notice in writing, to allow the customer an opportunity to maintain uninterrupted service.
Ringer Equivalence Number
The Ringer Equivalence Number and FCC Registration Number for this machine may be found on the label located on the bottom or rear of the machine. In some instances you may need to provide these numbers to the telephone company.
The Ringer Equivalence Number (REN) is a measure of the electrical load placed on the telephone line, and is useful for determining whether you have “overloaded” the line.
Installing several types of equipment on the same telephone line may result in problems making and receiving telephone calls, especially ringing when your line is called. The sum of all Ringer Equivalence Numbers of the equipment on your telephone line should be less than five in order to assure proper service from the telephone company. In some cases, a sum of five may not be usable on your line. If any of your telephone equipment is not operating properly, you should immediately remove it from your telephone line, as it may cause harm to the telephone network.
WARNING:
FCC Regulations state that changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
In the event that terminal equipment causes harm to the telephone network, the telephone company should notify the customer that service may be stopped. However, where prior notice is impractical, the company may temporarily cease service, providing that they: a) promptly notify the customer.
b) give the customer an opportunity to correct the equipment problem.
c) inform the customer of the right to bring a complaint to the Federal Communication
Commission pursuant to procedures set out in FCC Rules and Regulations Subpart E of Part 68.
You should also know that:
• Your machine is not designed to be connected to a digital PBX system.
• If you intend to use a computer modem or fax modem on the same phone line as your machine, you may experience transmission and reception problems with all the equipment. It is recommended that no other equipment, except for a regular telephone, share the line with your machine.
• If your area experiences a high incidence of lightning or power surges, we recommend that you install surge protectors for both the power and the telephone lines. Surge protectors can be purchased from your dealer or telephone and electronic specialty stores.
• When programming emergency numbers and/or making test calls to emergency numbers, use a non-emergency number to advise the emergency service dispatcher of your intentions. The dispatcher will give you further instructions on how to actually test the emergency number.
• This machine may not be used on coin service or party lines.
• This machine provides magnetic coupling to hearing aids.
• You may safely connect this equipment to the telephone network by means of a standard modular jack, USOC RJ-11C.
Declaration of Conformity (European Countries)
Approvals and Certifications
The CE marking applied to this product symbolizes Samsung
Electronics Co., Ltd. Declaration of Conformity with the following applicable 93/68/EEC Directives of the European Union as of the dates indicated:
January 1, 1995
: Council Directive 73/23/EEC Approximation of the laws of the member states related to low voltage equipment.
January 1, 1996
: Council Directive 89/336/EEC (92/31/EEC), approximation of the laws of the Member States related to electromagnetic compatibility.
March 9, 1999
: Council Directive 1999/5/EC on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity.
A full declaration, defining the relevant Directives and referenced standards can be obtained from your Samsung Electronics Co., Ltd. representative.
EC Certification
Certification to 1999/5/EC Radio Equipment & Telecommunications
Terminal Equipment Directive (FAX)
This Samsung product has been self-certified by Samsung for pan-European single terminal connection to the analogue public switched telephone network (PSTN) in accordance with Directive 1999/5/EC. The product has been designed to work with the national PSTNs and compatible PBXs of the European countries:
In the event of problems, you should contact the Euro QA Lab of Samsung Electronics
Co., Ltd. in the first instance.
The product has been tested against TS 103 021. To assist in the use and application of terminal equipment which complies with this standard, the European
Telecommunication Standards Institute (ETSI) has issued an advisory document (EG
201 121) which contains notes and additional requirements to ensure network compatibility of TS 103 021 terminals. The product has been designed against, and is fully compliant with, all of the relevant advisory notes contained in this document.
Replacing the Fitted Plug (for UK Only)
I
MPORTANT
The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct 13 amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do not use the plug until you have another fuse cover.
Please contact the people from you purchased the machine.
The 13 amp plug is the most widely used type in the UK and should be suitable.
However, some buildings (mainly old ones) do not have normal 13 amp plug sockets.
You need to buy a suitable plug adaptor. Do not remove the moulded plug.
W
ARNING
If you cut off the moulded plug, get rid of it straight away.
You cannot rewire the plug and you may receive an electric shock if you plug it into a socket.
I
MPORTANT WARNING
: You must earth this machine.
The wires in the mains lead have the following color code:
• Green and Yellow: Earth
• Blue: Neutral
• Brown: Live
If the wires in the mains lead do not match the colors marked in your plug, do the following:
You must connect the green and yellow wire to the pin marked by the letter “E” or by the safety ‘Earth symbol’ or colored green and yellow or green.
You must connect the blue wire to the pin which is marked with the letter “N” or colored black.
You must connect the brown wire to the pin which is marked with the letter “L” or colored red.
You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.
xi
xii
1
Introduction
Thank you for purchasing this Samsung multifunctional product. Your machine provides printing, copying, scanning, and faxing (CLX-3160FN only) functions.
This chapter includes:
•
•
•
•
Special features
Your new machine is equipped with special features that improve print quality. You can:
Print with excellent quality and speed
• You can print in full range of colors using cyan, magenta, yellow, and black.
• You can print with a resolution of up to 2400 dpi
[Best]. See the Software Section.
• In Black and White mode, your machine prints
A4-sized paper at up to 16 ppm a
and letter-sized paper at up to 17 ppm. In Color mode, your machine prints A4-sized or letter sized paper at up to 4 ppm.
Handle paper flexibly
• The manual feeder supports letterhead, envelopes, labels, transparencies, custom-sized media, postcards, and heavy paper. The manual
feeder holds up 1 sheet of paper.
• The 150-sheet tray 1 and 250-sheet optional
tray 2 support plain paper in various sizes.
Create professional documents
• Print Watermarks. You can customize your documents with words, such as “Confidential.”
See the Software Section.
• Print Posters. The text and pictures of each page of your document are magnified and printed across the sheet of paper and can then be taped together to form a poster. See the Software
Section.
Save time and money
• You can print multiple pages on one single sheet of paper to save paper.
• You can use preprinted forms and letterhead with plain paper. See the Software Section.
• This machine automatically conserves
electricity by substantially reducing power consumption when not in use.
Expand your machine’s capacity
• You can add a 250-sheet optional tray 2 to your machine. This tray lets you add paper to the machine less often.
• You can print images directly from a PictBridgecompatible device.
Print in various environments
• You can print with Windows 98/Me/2000/XP (include 64bit).
• Your machine is compatible with a variety of Linux systems.
• Your machine is compatible with a variety of Macintosh systems.
• Your machine comes with a network interfaces.
Use USB flash memory devices
If you have a USB memory device, you can use it in various ways with your machine.
• You can scan documents and save them to the device.
• You can directly print data stored to the device.
You can back up data and restore backup files to the machine’s memory.
Machine features
The table below lists a general overview of features supported by your machine.
(I: Installed, O: Option, NA: Not Available)
Features
USB 2.0
USB Memory
Network Interface
(Ethernet 10/100 Base TX)
Fax Function
PictBridge I
I
I
I
CLX-3160N CLX-3160FN
I
I
NA I
I
I a. pages per minute
1.1
<Introduction>
Printer overview
These are the main components of your machine:
Front view
Rear view
* The figure above shows an CLX-3160FN with all available accessories.
1
ADF (automatic document feeder) a document width guides
10 tray 1
2
3
6
7
4
5
8
9 document input tray document output tray control panel output tray
USB memory port front cover optional tray 2
11 output support
12 manual feeder paper width guides
13 manual feeder
14
15
16
17
18 scanner lid scanner glass waste toner container toner cartridge imaging unit a. Automatic document feeder is used as ADF in this user’s guide.
1.2
<Introduction>
* The figure above shows an CLX-3160FN with all available accessories.
1
2 extension telephone
socket (EXT) a network port
3 power switch
4 rear cover a. CLX-3160FN only.
5
6
7 power receptacle
USB port telephone line socket
(LINE) a
Control panel overview(
CLX-3160FN
)
1
2
3
4
5
Speed buttons: Allows you to store frequently-dialed fax numbers and enter them with the touch of a few buttons.
Shift: Allows you to shift the speed buttons to access numbers 16 through 30.
Address Book: Allows you to store frequently used fax numbers in memory or search for stored fax numbers or email addresses.
Resolution: Adjusts the document resolution for the current fax job.
Redial/Pause: In Standby mode, redials the last number, or in Edit mode, inserts a pause into a fax number.
13
14
15
16
17
Back: Sends you back to the upper menu level.
Status: Shows the status of your machine. See page 1.5.
Darkness: Adjusts the document brightness for the current copy job.
Original Type: Selects the document type for the current copy job.
Reduce/Enlarge: Makes a copy smaller or larger than the original.
6
7
Fax: Activates Fax mode.
Copy: Activates Copy mode.
18
USB Print: Allows you to directly print files stored on a USB Memory device when it is inserted into the USB memory port on the front of your machine.
19 Number keypad: dials a number or enters alphanumeric characters.
8
9
10
Scan/Email: Activates Scan mode.
Display: Shows the current status and prompts during an operation.
Menu: Enters Menu mode and scrolls through the available menus.
20 On Hook Dial: Engages the telephone line.
21
Stop/Clear: Stops an operation at any time. In Standby mode, clears/cancels the copy options, such as the darkness, the document type setting, the copy size, and the number of copies.
22 Color Start: Starts a job in Color mode.
11
Scroll buttons: Scroll through the options available in the selected menu, and increase or decrease values.
12 OK: Confirms the selection on the screen.
23 Black Start: Starts a job in Black and White mode.
1.3
<Introduction>
Control panel overview
(CLX-3160N)
1
2
3
6
7
8
9
4
5
Copy: Activates Copy mode.
Scan/Email: Activates Scan mode.
Display: Shows the current status and prompts during an operation.
OK: Confirms the selection on the screen.
Back: Sends you back to the upper menu level.
Status: Shows the status of your machine. See page 1.5.
Darkness: Adjusts the document brightness for the current copy job.
10
11
12
Original Type: Selects the document type for the current copy job.
Reduce/Enlarge: Makes a copy smaller or larger than the original.
Address Book: Allows you to search for stored email addresses.
Menu: Enters Menu mode and scrolls through the available menus.
Scroll buttons: Scroll through the options available in the selected menu, and increase or decrease values.
13
USB Print: Allows you to directly print files stored on a USB Memory device when it is inserted into the USB memory port on the front of your machine.
14 Number keypad: Dials a number or enters alphanumeric characters.
15
Stop/Clear: Stops an operation at any time. In Standby mode, clears/ cancels the copy options, such as the resolution, the document type setting, the copy size, and the number of copies.
16 Color Start: Starts a job in Color mode.
17 Black Start: Starts a job in Black and White mode.
Note
• Use the recessed area on the right of the control panel for storing clips to bind printouts
1.4
<Introduction>
Understanding the Status LED
The Status LED on the control panel shows the status of your machine.
See the table below to know your machine’s status.
Off
Green
Red
Status
On
Blinking
On
Blinking
Description
• The machine is off-line.
• The machine is in Power Save mode. When data is received, or any button is pressed, it switches to on-line automatically.
The machine is on-line and can be used.
• When the backlight slowly blinks, the machine is receiving data from the computer.
• When the backlight fast blinks, the machine is printing data.
• The toner cartridge is totally exhausted.
Remove the old toner cartridge and install a
• A paper jam has occurred. To solve the
• The front cover is open. Close the front cover.
• There is no paper in the tray. Load paper in the tray.
• The machine has stopped due to a major error.
Check the display message. See page 14.5 for
details on the meaning of the error message.
• A minor error occurs and the machine is waiting an error to be cleared. Check the display message. When the problem is cleared, the machine resumes.
• The toner cartridge is low. Order a new toner cartridge. You can temporarily improve print quality by redistributing the toner. See page
Finding more information
You can find information for setting up and using your machine from the following resources, either printed or onscreen.
Quick Install
Guide
Provides information on setting up your machine and, therefore, be sure to follow the instructions in the guide to get the machine ready.
Online User’s
Guide
Provides you with step-by-step instructions for using your machine’s full features, and contains information for maintaining your machine, troubleshooting, and installing accessories.
This user’s guide also contains the Software
Section providing you with information on how to print documents with your machine on various operating systems, and how to use the supplied software utilities.
Note
• You can access the user’s guides in other languages from the Manual folder on the Printer software CD.
Network Printer
User’s Guide
Contained on the network utilities CD, provides you with information on setting up and connecting your machine to a network.
Printer Driver
Help
Website
Provides you with help information on printer driver properties and instructions for setting up the properties for printing. To access a printer driver help screen, click Help from the printer properties dialog box.
If you have Internet access, you can get help, support, printer drivers, manuals, and order information from the Samsung website, www.samsungprinter.com.
1.5
<Introduction>
Selecting a location
Select a level, stable place with adequate space for air circulation. Allow extra space for opening covers and trays.
The area should be well-ventilated and away from direct sunlight or sources of heat, cold, and humidity. Do not set the machine close to the edge of your desk or table.
Clearance space
• Front: 482.6 mm (enough space so that the paper tray can be removed)
• Back: 100 mm (enough space for ventilation)
• Right: 100 mm (enough space for ventilation)
• Left: 100 mm (enough space for ventilation)
Caution
• When you move the printer, do not tilt or turn it upside down.
Or the inside of the printer may be contaminated by toner, which can cause damage to the printer or bad printing quality.
1.6
<Introduction>
2
System setup
This chapter gives you an overview of menus available on your machine and step-by-step instructions for setting up the machine’s systems.
This chapter includes:
•
•
•
•
Changing the default mode (CLX-3160FN only)
•
Setting sounds (CLX-3160FN only)
•
Entering characters using the number keypad
•
* Menus in the colored characters are available only with CLX-3160FN.
Fax Feature
Darkness
Multi Send
Delay Send
Priority Send
Forward
Secure Receive
Add Page
Cancel Job
Fax Setup
Sending
Redial Times
Redial Term
Prefix Dial
ECM Mode
Send Report
Image TCR
Dial Mode
Receiving
Receive Mode
Ring to Answer
Stamp Rcv Name
Rcv Start Code
Auto Reduction
Discard Size
Junk Fax Setup
DRPD Mode
Change Default
Resolution
Darkness
Auto Report
Copy Feature
Copy Collation
2-Up
4-Up
ID Copy
Poster Copy
Clone Copy
Erase Bkgd.
Menu overview
The control panel provides access to various menus to set up the machine or use the machine’s functions. These menus can be accessed by pressing Menu. Refer to the following diagram. Menus available in
Fax, Copy, or Scan mode vary.
Note
• Some menus may not appear in the display depending on your country. If so, it is not applicable to your machine.
Copy Setup
Change Default
Copies
Reduce/Enlarge
Darkness
Original Type
Scan Feature
USB Memory
Scan Size
Original Type
Resolution
Scan Color
Scan Format
Scan Size
Original Type
Resolution
Scan Color
Network
TCP/IP
Ethernet Speed
Clear Setting
Network Info
System Setup
(continued)
Paper Setup
Paper Size
Paper Type
Paper Source
Sound/Volume
Key Sound
Alarm Sound
Speaker
Ringer
Report
Maintenance
Remote Service
Supplies Life
Color
Serial Number
Clear Setting
System Setup
Machine Setup
Machine ID
Machine Fax No.
Date & Time
Clock Mode
Language
Default Mode
Power Save
Scan PWR Save
Timeout
NetScanTimeout
Altitude Adj.
Auto Continue
Import Setting
Export Setting
Scan Setup
Change Default
USB Memory
2.1
<System setup>
Changing the display language
To change the language that appears on the control panel, follow these steps:
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Language appears and press OK.
4 Press the Scroll buttons until the language you want appears and press OK.
5 Press Stop/Clear to return to Standby mode.
Setting the date and time
The current date and time are shown on the display when your machine is on and ready to work. For the CLX-3160FN, all of your faxes will have the date and time printed on them.
Note
• If power to the machine is cut off, you need to reset the correct time and date once the power has been restored.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Date & Time appears and press OK.
4 Enter the correct time and date using the number keypad.
Month = 01 to 12
Day = 01 to 31
Year = requires four digits
Hour = 01 to 12 (12-hour mode)
00 to 23 (24-hour mode)
Minute = 00 to 59
Note
• The date format may differ from country to country
You can also use the Scroll buttons to move the cursor under the digit you want to correct and enter a new number.
5 To select AM or PM for 12-hour format, press the or button or any number button.
When the cursor is not under the AM or PM indicator, pressing the
or button immediately moves the cursor to the indicator.
You can change the clock mode to 24-hour format (e.g. 01:00 PM as 13:00). For details, see the next section.
6 Press OK to save the time and date.
When you enter a wrong number, Out of Range appears and the machine does not proceed to the next step. If this happens, simply reenter the correct number.
7 Press Stop/Clear to return to Standby mode.
Changing the clock mode
You can set your machine to display the current time using either a 12hour or 24-hour format.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Clock Mode appears and press OK.
4 Press the Scroll buttons to select the other mode and press OK.
5 Press Stop/Clear to return to Standby mode.
Changing the default mode
(CLX-3160FN only)
Your machine is preset to Fax mode. You can switch this default mode between Fax mode and Copy mode.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Default Mode appears and press
OK.
4 Press the Scroll buttons until the default mode you want appears and press OK.
5 Press Stop/Clear to return to Standby mode.
2.2
<System setup>
Setting sounds
(CLX-3160FN only)
You can control the following sounds:
• Key Sound: Turns the key sound on or off. With this option set to On , a tone sounds each time a key is pressed.
• Alarm Sound: Turns the alarm sound on or off. With this option set to
On , an alarm tone sounds when an error occurs or fax communication ends.
• Speaker: Turns on or off the sounds from the telephone line through the speaker, such as a dial tone or a fax tone. With this option set to
Comm. which means “Common,” the speaker is on until the remote machine answers.
You can adjust the volume level using On Hook Dial.
• Ringer: Adjusts the ringer volume. For the ringer volume, you can select Off, Low, Mid, and High.
Speaker, ringer, key sound, and alarm sound
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Sound/Volume appears and press
OK.
3 Press the Scroll buttons until the sound option you want appears and press OK.
4 Press the Scroll buttons until the desired status or volume for the sound you have selected appears and press OK.
5 If necessary, repeat steps 3 through 5 to set other sounds.
6 Press Stop/Clear to return to Standby mode.
Speaker volume
1 Press On Hook Dial. A dial tone sounds from the speaker.
2 Press the Scroll buttons until you hear the volume you want.
3 Press Stop/Clear to save the change and return to Standby mode.
Note
• You can adjust the speaker volume only when the telephone line is connected.
Entering characters using the number keypad
As you perform various tasks, you may need to enter names and numbers. For example, when you set up your machine, you enter your name or your company’s name, and the fax number. When you store fax numbers or email addresses in memory, you may also enter the corresponding names.
Entering alphanumeric characters
1 When you are prompted to enter a letter, locate the button labeled with the character you want. Press the button until the correct letter appears on the display.
For example, to enter the letter O, press 6, labeled with MNO.
Each time you press 6, the display shows a different letter, M, N, O,
m, n, o and finally 6.
You can enter special characters, such as space, plus sign, and etc. For details, see the below section.
2 To enter additional letters, repeat step 1.
If the next letter is printed on the same button, move the cursor by pressing the right Scroll button and then press the button labeled with the letter you want. The cursor will move to the right and the next letter will appear on the display.
You can enter a space by pressing 1 twice.
3 When you have finished entering letters, press OK.
6
7
4
5
1
2
3
8
9
0
Key
Keypad letters and numbers
Assigned numbers, letters, or characters
1 Space
A B C a b c 2
D E F d e f 3
G H I g h i 4
J K L j k l 5
M N O m n o 6
P Q R S p q r s 7
T U V t u v 8
W X Y Z w x y z 9
+ - , . ‘ / * # & @ 0
2.3
<System setup>
Correcting numbers or names
If you make a mistake while entering a number or name, press the left
Scroll button to delete the last digit or character. Then enter the correct number or character.
Inserting a pause
With some telephone systems, you must dial an access code (9, for example) and listen for a second dial tone. In such cases, you must insert a pause in the telephone number. You can insert a pause while you are setting up speed buttons or speed dial numbers.
To insert a pause, press Redial/Pause at the appropriate place while entering the telephone number. A - appears on the display at the corresponding location.
Using the save modes
Power Save mode
Power Save mode allows your machine to reduce power consumption when it is not in actual use. You can turn this mode on and select a length of time for which the machine waits after a job is printed before it switches to a reduced power state.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Power Save appears and press OK.
4 Press the Scroll buttons until the time setting you want appears and press OK.
5 Press Stop/Clear to return to Standby mode.
Scan Power Save mode
Scan Power Save mode allows you to save power by turning off the scan lamp. The scan lamp under the scanner glass automatically turns off when it is not in actual use to reduce power consumption and extend the life of the lamp. The lamp automatically wakes up after some warm-up time when you start scanning.
You can set the length of time for which the scan lamp waits after a scan job is completed before it switches to the power save mode.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Scan PWR Save appears and press
OK.
4 Press the Scroll buttons until the time setting you want appears and press OK.
5 Press Stop/Clear to return to Standby mode.
2.4
<System setup>
3
Software overview
This chapter gives you an overview of the software that comes with your machine. Further details about installing and using the software are explained in the Software Section.
This chapter includes:
•
•
•
Supplied software
You must install the printer and scanner software using the supplied CDs after you have set up your machine and connected it to your computer.
Each CD provides you with the following software:
CD
Printer software CD
Windows
Linux
Contents
• Printer driver: Use this driver to take full advantage of your printer’s features.
• Scanner driver: TWAIN and
Windows Image Acquisition (WIA) drivers are available for scanning documents on your machine.
• Smart Panel: This program allows you to monitor the machine’s status and alerts you when an error occurs during printing.
• SmarThru a
: This is the accompanying Windows-based software for your multifunctional machine.
• Network Scan: This program allows you to scan a document on your machine and save it to a networkconnected computer.
• User’s Guide in PDF
• Printer driver: Use this driver to run your machine from a Linux computer and print documents.
• SANE: Use this driver to scan documents.
• Smart Panel: This program allows you to monitor the machine’s status and alerts you when an error occurs during printing.
CD
Printer software CD
(continued)
Macintosh
Contents
• Printer driver: Use this driver to run your machine from a Macintosh.
• Scanner driver: TWAIN driver is available for scanning documents on your machine.
• Smart Panel: This program allows you to monitor the machine’s status and alerts you when an error occurs during printing.
network utilities CD
Windows
• SyncThru™ Web Admin Service:
Use this web-based program to remotely manage, monitor, and troubleshoot network printers.
• Set IP: Use this program to set your machine’s TCP/IP addresses.
• Network Printer User’s Guide in
PDF a. Allows you to edit a scanned image in many ways using a powerful image editor and to send the image by email. You can also open another image editor program, like Adobe Photoshop, from SmarThru. For details, please refer to the onscreen help supplied on the SmarThru program.
Printer driver features
Your printer drivers support the following standard features:
• Paper orientation, size, source and media type selection
• Number of copies
In addition, you can use various special printing features. The following table shows a general overview of features supported by your printer drivers:
Printer Driver
Feature
Windows
O
Macintosh
O
Linux
O Print quality option
Multiple pages per sheet (N-up)
Poster printing
Booklet Printing
Fit to page printing
Scale printing
Different source for first page
Watermark
Overlay
O
O
O
O
O
O
O
O
O
X
X
O
O
O
X
X
O (2, 4)
X
X
X
X
X
X
X
3.1
<Software overview>
System requirements
Before you begin, ensure that your system meets the following requirements:
Windows
Item
Operating system
CPU
RAM
Free disk space
Requirements Recommended
Windows 98/Me/2000/XP
Windows 98/
Me/2000
Windows XP
Pentium II
400 MHz or higher
Pentium III
933 MHz or higher
64 MB or more
Windows 98/
Me/2000
Windows XP
Windows 98/
Me/2000
Windows XP
128 MB or more
300 MB or more
1 GB or more
Pentium III
933 MHz
Pentium IV
1 GHz
128 MB
256 MB
1 GB
5 GB
Internet
Explorer
5.0 or higher
Note
• For Windows 2000/XP, users who have an administrator right can install the software.
Linux
CPU
RAM
Free disk page
Software
Item
Operating system
Requirements
• RedHat 8.0 ~ 9.0
• Fedora Core 1, 2, 3, 4
• Mandrake 9.2 ~ 10.1
• SuSE 8.2 ~ 9.2
Pentium IV 1 GHz or higher
256 MB or higher
1 GB or higher
• Linux Kernel 2.4 or higher
• Glibc 2.2 or higher
• CUPS
• SANE(for MFP device only)
Notes
• It’s necessary to claim swap partition of 300 MB or larger for working with large scanned images.
• The Linux scanner driver supports the optical resolution at maximum.
Macintosh
Item
Operating system
RAM
Free disk space
Connection
Requirements
Macintosh 10.3 ~ 10.4
128 MB
200 MB
USB interface, Network interface
3.2
<Software overview>
4
Network setup
This chapter gives you step-by-step instructions for setting up your machine for network connections.
This chapter includes:
•
•
•
•
•
Restoring the network configuration
•
Printing a network configuration page
Introduction
Once you have connected your machine to a network with an RJ-45
Ethernet cable, you can share the machine with other network users.
You need to set up the network protocols on the machine to use it as your network printer. Protocols can be set up by the following two methods:
Via network administration programs
You can configure your machine’s print server settings and manage the machine via the following programs that came with your machine:
• SyncThru™ Web Admin Service: A web-based printer management solution for network administrators. SyncThru™ Web
Admin Service provides you with an efficient way of managing network devices and lets you remotely monitor and troubleshoot network printers from any site with corporate intranet access.
• SyncThru™ Web Service: A web server embedded to your network print server, which allows you to:
- Configure the network parameters necessary for the machine to connect to various network environments.
- Customize printer, copy, and fax settings.
• SetIP: A utility program allowing you to select a network interface and manually configure the addresses for use with the TCP/IP protocol.
For further details, refer to the user’s guide on the network utilities CD that came with your machine.
Via the control panel
You can set up the following basic network parameters through the machine’s control panel:
• Configure TCP/IP
• Configure EtherTalk
Supported operating systems
The following table shows the network environments supported by the machine:
Item
Network interface
Requirements
• Ethernet 10/100 Base-TX
Network operating system
• Windows 98/Me/2000/XP
• Various Linux OS
• Macintosh OS 10.3 ~ 10.4
Network protocols
• TCP/IP on Windows
• IPP, SNMP
Dynamic addressing server
• DHCP, BOOTP
• TCP/IP: Transmission Control Protocol/Internet Protocol
• IPP: Internet Printing Protocol
• SNMP: Simple Network Management Protocol
• DHCP: Dynamic Host Configuration Protocol
• BOOTP: Bootstrap Protocol
Configuring TCP/IP
Your machine can be set up with a variety of TCP/IP network information, such as an IP address, a subnet mask, a gateway, and DNS addresses.
There are several ways in which your machine can be assigned a TCP/
IP address, depending on your network.
• Static addressing: A TCP/IP address is assigned manually by the system administrator.
• Dynamic addressing via BOOTP/DHCP: A TCP/IP address is assigned automatically by the server.
Note
• Before configuring TCP/IP, you need to set the network protocol to TCP/IP.
Static addressing
To enter a TCP/IP address from your machine’s control panel, take the following steps:
1 Press Menu until Network appears on the bottom line of the display and press OK.
2 Press OK when TCP/IP appears.
3 Press the Scroll buttons until Static appears and press OK.
4 Press OK when IP Address appears.
4.1
<Network setup>
5 Enter a byte between 0 and 255 using the number keypad and press the Scroll buttons to move between bytes.
Repeat this to complete the address from the 1st byte to the 4th byte.
6 When you have finished, press OK.
7 Repeat steps 5 and 6 to configure the other TCP/IP parameters: subnet mask and gateway address.
8 Press the Scroll buttons until Static appears and press OK.
9 Press the Scroll buttons until Primary DNS appears and press
OK.
10 Enter each byte of the address and press OK.
11 Press the Scroll buttons until Secondary DNS appears and press
OK.
12 Enter each byte of the address and press OK.
13 Press Stop/Clear to return to Standby mode.
Dynamic addressing (BOOTP/DHCP)
To have a TCP/IP address assigned automatically by the server, take the following steps:
1 Press Menu until Network appears on the bottom line of the display.
2 Press OK when TCP/IP appears.
3 Press the Scroll buttons until DHCP or BOOTP appears and press
OK.
4 Press Stop/Clear to return to Standby mode.
Setting Ethernet speed
You can select the communication speed for Ethernet connections.
1 Press Menu until Network appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Ethernet Speed appears and press
OK.
3 Press the Scroll buttons until the speed you want appears and press OK.
4 Press Stop/Clear to return to Standby mode.
Restoring the network configuration
You can return the network configuration to its default settings.
1 Press Menu until Network appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Clear Setting appears and press
OK.
3 Press OK when Yes appears to restore the network configuration.
4 Power the machine off and back on.
Printing a network configuration page
The Network Configuration page shows how the network interface card on your machine is configured.
1 Press Menu until Network appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Network Info. appears and press
OK.
3 Press OK when Yes appears.
The Network Configuration page prints out.
4.2
<Network setup>
5
Loading originals and print media
This chapter introduces you to how to load originals and print media into your machine.
This chapter includes:
•
•
•
•
Setting the paper size and type
2 Place the original face down on the scanner glass and align it with the registration guide at the top left corner of the glass.
Loading originals
You can use the scanner glass or ADF to load an original for copying, scanning, and sending a fax.
On the scanner glass
Make sure that no originals are in the ADF. If an original is detected in the ADF, the machine gives it priority over the original on the scanner glass. To get the best scan quality, especially for colored or gray-scaled images, use the scanner glass.
1 Lift and open the scanner lid.
3 Close the scanner lid.
Notes
• Leaving the scanner lid open while copying may affect copy quality and toner consumption.
• Dust on the scanner glass may cause black spots on the printout. Always keep it clean.
• If you are copying a page from a book or magazine, lift the scanner lid until its hinges are caught by the stopper and then close the lid. If the book or magazine is thicker than 30 mm, start copying with the lid open.
In the ADF
Using the ADF, you can load up to 50 sheets of paper (75 g/m for one job.
2
, 20 lb)
When you use the ADF:
• Do not load paper smaller than 142 x 148 mm (5.6 x 5.8 inches) or larger than 216 x 356 mm (8.5 x 14 inches).
• Do not attempt to load the following types of paper:
- carbon-paper or carbon-backed paper
- coated paper
- onion skin or thin paper
- wrinkled or creased paper
- curled or rolled paper
- torn paper
• Remove all staples and paper clips before loading.
• Make sure any glue, ink, or correction fluid on the paper is completely dry before loading.
• Do not load originals that include different sizes or weights of paper.
• Do not load booklets, pamphlets, transparencies, or documents having other unusual characteristics.
5.1
<Loading originals and print media>
To load an original into the ADF:
1 Load the original face up into the ADF. Make sure that the bottom of the original stack matches the paper size marked on the document input tray.
2 Adjust the document width guides to the paper size.
Selecting print media
You can print on a variety of print media, such as plain paper, envelopes, labels, and transparencies. Always use print media that meet the guidelines for use with your machine. Print media that does not meet the guidelines outlined in this user’s guide may cause the following problems:
• Poor print quality
• Increased paper jams
• Premature wear on the machine.
Properties, such as weight, composition, grain, and moisture content, are important factors that affect the machine’s performance and the output quality. When you choose print materials, consider the following:
• Desired outcome: The print media you choose should be appropriate for your project.
• Size: You can use any size media that fits easily within the paper adjusters of the paper tray.
• Weight: Your machine supports print media weights as follows:
- 16 to 43 lb bond (60 to 163 g/m
2
) for the tray 1 and manual feeder
- 16 to 24 lb bond (60 to 90 g/m 2 ) for the optional tray 2
• Brightness: Some print media are whiter than others and produce sharper, more vibrant images.
• Surface smoothness: The smoothness of the print media affects how crisp the printing looks on the paper.
Notes
• Some print media may meet all of the guidelines in this section and still not produce satisfactory results. This may be the result of improper handling, unacceptable temperature and humidity levels, or other variables over which Samsung has no control.
• Before purchasing large quantities of print media, ensure that it meets the requirements specified in this user’s guide.
Caution
• Using print media that does not meet these specifications may cause problems, requiring repairs. Such repairs are not covered by Samsung’s warranty or service agreements.
Note
• Dust on the ADF glass may cause black lines on the printout.
Always keep it clean.
5.2
<Loading originals and print media>
Supported print media types and sizes
Type
Plain paper
Envelope
Size
Letter
Legal
Folio
Oficio
A4
JIS B5
Executive
A5
A6
ISO/Envelope B5
Envelope Monarch
Envelope COM-10
Envelope No.9
Envelope DL
Envelope C5
Envelope C6
Envelope size 6 3/4
Dimensions
215.9 x 279 mm (8.5 x 11 inches)
215.9 x 355.6 mm (8.5 x 14 inches)
215.9 x 330.2 mm (8.5 x 13 inches)
215 x 343 mm (8.5 x 13.5 inches)
210 x 297 mm (8.27 x 11.69 inches)
182 x 257 mm (7.17 x 10.12 inches)
184.2 x 266.7 mm (7.25 x 10.5 inches)
148.5 x 210 mm (5.85 x 8.27 inches)
105 x 148.5 mm (4.13 x 5.85 inches)
176 x 250 mm(6.93 x 9.84 inches)
98.4 x 190.5 mm (3.88 x 7.5 inches)
105 x 241 mm (4.12 x 9.5 inches)
98 x 225 mm (3.86 x 8.86 inches)
110 x 220 mm (4.33 x 8.66 inches)
162 x 229 mm (6.38 x 9.02 inches)
114 x 162 mm (4.49 x 6.38 inches)
92 x 165 mm (3.62 x 6.5 inches)
Weight
• 60 to 90 g/m
2
(16 to 24 lb bond) for the optional tray
2
• 60 to 105 g/m
2
(16 to 28 lb bond) for the tray 1 and manual feeder
75 to 90 g/m
2
(20 to 24 lb)
Capacity a
• 1 sheet for the manual feeder
• 150 sheets of 75 g/m
2
(20 lb bond) paper for the tray 1
• 250 sheets of 75 g/m
2
(20 lb bond) paper for the optional tray 2
1 sheet for the manual feeder or tray 1
Transparency b
Letter, A4 Refer to the Plain paper section 138 to 146 g/m
2
(37 to 39 lb)
1 sheet for the manual feeder or tray 1
Labels
Card stock
Minimum size (custom)
Maximum size (custom)
Letter, Legal, Folio,
Oficio, A4, JIS B5,
Executive, A5, A6
Letter, Legal, Folio,
Oficio, A4, JIS B5,
Executive, A5, A6
Refer to the Plain paper section
Refer to the Plain paper section
120 to 150 g/m
105 to 163 g/m
2
2
(32 to 40 lb)
(28 to 43 lb)
76 x 127 mm (3 x 5 inches)
216 x 356 mm (8.5 x 14 inches)
60 to 163 g/m
2
(16 to 43 lb bond) a. Maximum capacity may differ depending on media weight, thickness, and environmental conditions.
b. Recommended media: Transparency for a Color Laser Printers produced by HP, Xerox and 3M.
It is not recommended to use paperbacked transparencies such as Xerox 3R91334, which can cause a jam or be scratched.
1 sheet for the manual feeder or tray 1
1 sheet for the manual feeder or tray 1
1 sheet for the manual feeder or tray 1
5.3
<Loading originals and print media>
Media sizes supported in each mode
Mode
Copy mode
Print mode
Fax mode a
Size
Letter, A4, Legal,
Oficio, Folio,
Executive, JIS B5, A5,
A6
Source
• tray 1
• optional tray 2
• manual feeder
All sizes supported by the machine
Letter, A4, Legal
• tray 1
• optional tray 2
• manual feeder
• tray 1
• optional tray 2 a. CLX-3160FN only
Guidelines for selecting and storing print media
When selecting or loading paper, envelopes, or other print materials, keep these guidelines in mind:
• Always use print media that conform with the specifications listed on
• Attempting to print on damp, curled, wrinkled, or torn paper can cause paper jams and poor print quality.
• For the best print quality, use only high quality copier grade paper specifically recommended for use in laser printers.
• Avoid using the following media types:
- Paper with embossed lettering, perforations, or a texture that is too smooth or too rough
- Erasable bond paper
- Multi-paged paper
- Synthetic paper and thermally reactive paper
- Carbonless paper and Tracing paper.
Use of these types of paper could result in paper jams, chemical smells, and damage to your machine.
• Store print media in its ream wrapper until you are ready to use it.
Place cartons on pallets or shelves, not on the floor. Do not place heavy objects on top of the paper, whether it is packaged or unpackaged. Keep it away from moisture or other conditions that can cause it to wrinkle or curl.
• Store unused print media at temperatures between 15 o
C and 30 o
C
(59 o
F to 86 o
F). The relative humidity should be between 10% and
70%.
• Store unused print media in a moisture-proof wrap, such as a plastic container or bag, to prevent dust and moisture from contaminating your paper.
• Load special media types one sheet at a time through the manual feeder to avoid paper jams.
• To prevent print media, such as transparencies and label sheets, from sticking together, remove them as they print out.
5.4
<Loading originals and print media>
Guidelines for special print media
Media type
Envelopes
Guidelines
• Successful printing on envelopes depends upon the quality of the envelopes. When selecting envelopes, consider the following factors:
- Weight: The weight of the envelope paper should not exceed 90 g/m 2 (24 lb) or jamming may occur.
- Construction: Prior to printing, envelopes should lie flat with less than 6 mm
(0.25 inches) curl, and should not contain air.
- Condition: Envelopes should not be wrinkled, nicked, or otherwise damaged.
- Temperature: You should use envelopes that are compatible with the heat and pressure of the machine during operation.
• Use only well-constructed envelopes with sharp and well creased folds.
• Do not use stamped envelopes.
• Do not use envelopes with clasps, snaps, windows, coated lining, self-adhesive seals, or other synthetic materials.
• Do not use damaged or poorly made envelopes.
• Be sure the seam at both ends of the envelope extends all the way to the corner of the envelope.
Acceptable
Unacceptable
• Envelopes with a peel-off adhesive strip or with more than one flap that folds over to seal must use adhesives compatible with the machine’s fusing temperature of 180° C (356° F) for
0.1 second. The extra flaps and strips might cause wrinkling, creasing, or jams, and may even damage the fuser.
• For the best print quality, position margins no closer than 15 mm (0.6 inches) from the edges of the envelope.
• Avoid printing over the area where the envelope’s seams meet.
Media type
Transparencies
Guidelines
• To avoid damaging the machine, use only transparencies designed for use in laser printers.
• Transparencies used in the machine must be able to withstand 180° C (356° F), the machine’s fusing temperature.
• Place them on a flat surface after removing them from the machine.
• Do not leave them in the paper tray for long periods of time. Dust and dirt may accumulate on them, resulting in spotty printing.
• To avoid smudging caused by fingerprints, handle them carefully.
• To avoid fading, do not expose printed transparencies to prolonged sunlight.
• Ensure that transparencies are not wrinkled, curled, or have any torn edges.
Caution
Recommended media: Transparency for a
Color Laser Printers produced by HP, Xerox and 3M.
It is not recommended to use paperbacked transparencies such as Xerox 3R91334, which can cause a jam or be scratched.
Labels
• To avoid damaging the machine, use only labels designed for use in laser printers.
• When selecting labels, consider the following factors:
- Adhesives: The adhesive material should be stable at 180° C (356° F), the machine’s fusing temperature.
- Arrangement: Only use labels with no exposed backing between them. Labels can peel off sheets that have spaces between the labels, causing serious jams.
- Curl: Prior to printing, labels must lie flat with no more than 13 mm (5 inches) of curl in any direction.
- Condition: Do not use labels with wrinkles, bubbles, or other indications of separation.
• Make sure that there is no exposed adhesive material between labels. Exposed areas can cause labels to peel off during printing, which can cause paper jams. Exposed adhesive can also cause damage to machine components.
• Do not run a sheet of labels through the machine more than once. The adhesive backing is designed for only a single pass through the machine.
• Do not use labels that are separating from the backing sheet or are wrinkled, bubbled, or otherwise damaged.
Media type
Card stock or custom-sized materials
Preprinted paper
Guidelines
• Do not print on media smaller than 76 mm
(3 inches) wide or 127 mm (5 inches) long.
• In the software application, set margins at least
6.4 mm (0.25 inches) away from the edges of the material.
• Letterhead must be printed with heat-resistant ink that will not melt, vaporize, or release hazardous emissions when subjected to the machine’s fusing temperature of 180° C (356° F) for 0.1 second.
• Letterhead ink must be non-flammable and should not adversely affect printer rollers.
• Forms and letterhead should be sealed in a moisture-proof wrapping to prevent changes during storage.
• Before you load preprinted paper, such as forms and letterhead, verify that the ink on the paper is dry. During the fusing process, wet ink can come off preprinted paper, reducing print quality.
5.5
<Loading originals and print media>
Loading paper
In the tray 1
Load the print media you use for the majority of your print jobs in the tray
1. The tray 1 can hold a maximum of 150 sheets of 20 lb plain paper.
You can purchase an optional tray 2 and attach it below the tray 1 to load an additional 250 sheets of paper. For order information for an optional
optional tray 2, see page 12.1.
Loading paper in the tray 1
1 Pull the tray out of the machine.
2 Open the paper cover.
5 Flex the paper sheets back and forth to separate pages and then fan them while holding one edge. Tap the edges of the stack on a flat surface to even it up.
6 Load paper with the print side up.
Make sure not to overfill the tray and that all four corners are flat in the tray and under the brackets, as shown below. Overfilling the tray may cause a paper jam.
3 Adjust the size of tray until it sound click.
4 Enlarge the tray by adjusting the paper width guide.
7 Squeeze the paper length guide and slide in it until it lightly touches the end of the paper stack.
5.6
<Loading originals and print media>
8 Close the paper cover.
9 Slide the tray 1 back into the machine.
Changing the size of the paper in the tray 1
To load longer sizes of paper, such as Legal-sized paper, you need to adjust the paper guides to extend the paper tray.
To change the tray 1 size to other size, you must adjust the paper length guide properly.
1 Pull the tray 1 out of the machine. Open the paper cover and remove paper from the tray 1 if necessary.
2 Pressing and unlatching the guide lock in the top of the tray, pull the tray out manually.
3 Load paper into the tray.
You can load letterhead with the design side face up. The top edge of the sheet with the logo should be go into the machine first.
After loading paper, set the paper type and size for the tray 1. See
page 5.9 for copying and faxing or the Software Section for PC-
printing.
Notes
• Due to insufficient paper in the tray, the paper length guide can be pushed to inside, load enough paper.
• If you experience problems with paper feed, place one sheet at a time in the manual feeder.
• You can load previously printed paper. The printed side should be facing down with an uncurled edge into the machine. If you experience problems with paper feed, turn the paper around. Note that print quality is not guaranteed.
4 Slide the paper length guide until it lightly touches the end of the paper stack. Squeeze the paper width guide and slide it to the edge of the paper stack without causing it to bend.
5.7
<Loading originals and print media>
For paper smaller than Letter-sized, return the paper guides to their original positions and adjust the paper length guide and paper width guide.
In the manual feeder
The manual feeder can hold special sizes and types of print material, such as transparencies, postcards, note cards, labels, and envelopes. It is useful for single page printing on letterhead or colored paper.
To load paper in the manual feeder:
Caution
• When you do the printing job from the manual feeder, clear the paper in the tray 1 away.
1 Load the paper with the side to be printed on facing up.
Notes
• Do not push the paper width guides far enough to cause the material to warp.
• If you do not correctly adjust the paper width guides, it may cause a paper jams.
5 Close the paper cover.
6 Slide the tray 1 back into the machine.
Depending on the media type you are using, keep the following loading guidelines:
• Envelopes: Flap side down and with the stamp area on the top left side.
• Transparencies: Print side up and the top with the adhesive strip entering the machine first.
• Labels: Print side up and top short edge entering the machine first.
• Preprinted paper: Design side up with the top edge toward the machine.
• Card stock: Print side up and the short edge entering the machine first.
• Previously printed paper: Previously printed side down with an uncurled edge toward the machine.
5.8
<Loading originals and print media>
2 Squeeze the manual feeder paper width guides and adjust them to the width of the paper. Do not force too much, or the paper will be bent, which will result in a paper jam or skew.
Setting the paper size and type
After loading paper in the paper tray, you need to set the paper size and type using the control panel buttons. These settings will apply to Copy and Fax modes. For PC-printing, you need to select the paper size and type in the application program you use on your PC.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Paper Setup appears and press OK.
3 Press OK when Paper Size appears.
4 Press the Scroll buttons until the paper tray you want appears and press OK.
5 Press the Scroll buttons until the paper size you are using appears and press OK.
6 Press Back to return to the upper level.
7 Press the Scroll buttons until Paper Type appears and press OK.
8 Press the Scroll buttons until the paper type you are using appears and press OK.
9 Press Stop/Clear to return to Standby mode.
3 After loading paper, set the paper type and size for the manual
feeder. See page 5.9 for copying and faxing or the Software
Section for PC-printing.
Note
• The settings made from the printer driver override the settings on the control panel.
Caution
• If you want to print several pages with the manual feeder, wait the machine complete the printing one page, then place a paper on the manual feeder. Otherwise it may cause the paper jam.
Tips on using the manual feeder
• Load only one size of print media at a time in the manual feeder.
When you print out many pieces of paper at once, tray 1 use is recommended.
• To prevent paper jams, do not add paper when there is still paper in the manual feeder. This also applies to other types of print media.
• Print media should be loaded face up with the top edge going into the manual feeder first and be placed in the center of the tray.
• Always load only the print media specified in page 5.2 to avoid paper
jams and print quality problems.
• Flatten any curl on postcards, envelopes, and labels before loading them into the manual feeder.
5.9
<Loading originals and print media>
6
Copying
This chapter gives you step-by-step instructions for copying documents.
This chapter includes:
•
•
•
Changing the settings for each copy
•
Changing the default copy settings
•
•
Selecting the paper tray
After loading the print media for copy output, you must select the paper tray you will use for copy jobs.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Paper Setup appears and press OK.
3 Press the Scroll buttons until Paper Source appears and press
OK.
4 Press OK when Copy Tray appears.
5 Press the Scroll buttons until the paper tray you want appears and press OK.
6 Press Stop/Clear to return to Standby mode.
Copying
1 Press Copy.
Ready to Copy appears on the top line of the display.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Enter the number of copies using the number keypad, if necessary.
4 If you want to customize the copy settings including copy size, darkness, and original type, by using the control panel buttons.
If necessary, you can use special copy features, such as poster
copying, 2- or 4-up copying. See page 6.2.
5 Press Color Start to begin color copying.
Or, press Black Start to begin black and white copying.
Note
• You can cancel the copy job during an operation. Press Stop/
Clear, and the copying will stop.
Changing the settings for each copy
Your machine provides default settings for copying so that you can quickly and easily make a copy. However, if you want to change the options for each copy, use the copy function buttons on the control panel.
Note
• If you press Stop/Clear while setting the copy options, all of the options you have set for the current copy job will be canceled and returned to their default status. Or, they will automatically return to their default status after the machine completes the copy in progress.
Darkness
If you have an original containing faint markings and dark images, you can adjust the brightness to make a copy that is easier to read.
To adjust the darkness of copies, press Darkness. Each time you press the button, the following modes are available:
• Normal: Works well with standard typed or printed originals.
• Light: Works well with dark print.
• Dark: Works well with light print or faint pencil markings.
Original Type
The original type setting is used to improve the copy quality by selecting the document type for the current copy job.
To select the document type, press Original Type. Each time you press the button, the following modes are available:
• Text: Use for originals containing mostly text.
• Text/Photo: Use for originals with mixed text and photographs.
• Photo: Use when the originals are photographs.
6.1
<Copying>
Reduced or enlarged copy
By using the Reduce/Enlarge button, you can reduce or enlarge the size of a copied image from 25% to 400% when you copy original documents from the scanner glass, or from 25% to 100% from the ADF.
To select from the predefined copy sizes:
1 Press Reduce/Enlarge.
2 Press Reduce/Enlarge or the Scroll buttons until the size setting you want appears and press OK.
To scale the copy by directly entering the scale rate:
1 Press Reduce/Enlarge.
2 Press Reduce/Enlarge or the Scroll buttons until Custom appears and press OK.
3 Enter the scale rate and press OK to save the selection.
Note
• When you make a reduced copy, black lines may appear at the bottom of your copy.
Changing the default copy settings
The copy options, including darkness, original type, copy size, and number of copies, can be set to those most frequently used. When you copy a document, the default settings are used unless they have been changed by using the corresponding buttons on the control panel.
1 Press Copy.
2 Press Menu until Copy Setup appears on the bottom line of the display and press OK.
3 Press OK when Change Default appears.
4 Press the Scroll buttons until the setup option you want appears and press OK.
5 Press the Scroll buttons until the setting you want appears and press OK.
6 Repeat steps 4 through 5, as needed.
7 Press Stop/Clear to return to Standby mode.
Note
• While you are setting copy options, pressing Stop/Clear cancels the changed settings and restores the defaults.
Using special copy features
You can use the following copy features:
Collation
You can set the machine to sort the copy job. For example, if you make 2 copies of a 3 page original, one complete 3 page document will print followed by a second complete document.
1 Press Copy.
2 Load originals face up into the ADF.
For details about loading an original, see page
3 Enter the number of copies using the number keypad.
4 Press Menu until Copy Feature appears on the bottom line of the display and press OK.
5 Press OK when Copy Collation appears.
6 Press the Scroll buttons to select the color mode you want.
There are two types of mode as following:
•Yes-Color: Color copy
•Yes-Mono: Black and White copy
7 Press OK to begin copying.
One complete document will print followed by the second complete document.
6.2
<Copying>
2-up or 4-up copying
Your machine can print 2 or 4 original images reduced to fit onto one sheet of paper.
2 or 4-up copying is available only when you load originals into the ADF.
2-up copying
1
3
2
4
4-up copying
1 Press Copy.
2 Load originals face up in the ADF.
For details about loading an original, see page
3 Press Menu until Copy Feature appears on the bottom line of the display and press OK.
4 Press the Scroll buttons until 2-Up or 4-Up appears and press OK.
5 Press the Scroll buttons to select the color mode you want.
There are two types of mode as following:
•Yes-Color: Color copy
•Yes-Mono: Black and White copy
6 Press OK to begin copying.
Note
• You cannot adjust the copy size using the
Reduce/Enlarge button for making a 2- or
4-up copy.
ID card copying
Your machine can print 2-sided originals on one sheet of A4-, Letter-, Legal-, Folio-, Oficio-, Executive-, B5-,
A5-, or A6-sized paper.
When you copy using this feature, the machine prints one side of the original on the upper half of the paper and the other side on the lower half without reducing the size of the original. This feature is helpful for copying a small-sized item, such as a name card.
This copy feature is available only when you place originals on the scanner glass.
1 Press Copy.
2 Place a single original face down on the scanner glass.
For details about loading an original, see page
3 Press Menu until Copy Feature appears on the bottom line of the display and press OK.
4 Press the Scroll buttons until ID Copy appears and press OK.
Place Front Side and Press[Start] appears on the display.
5 Press OK, Color Start or Black Start.
Your machine begins scanning the front side and shows Place Back Side and Press[Start].
6 Open the scanner lid and turn the original over.
Note
• If you press Stop/Clear or if no buttons are pressed for approximately 30 seconds, the machine cancels the copy job and returns to Standby mode.
7 Press Color Start to begin color copying.
Or, press Black Start to begin black and white copying.
Note
• If the original is larger than the printable area, some portions may not be printed.
6.3
<Copying>
Poster copying
Your machine can print an image onto 9 sheets of paper (3x3). You can paste the printed pages together to make one poster-sized document.
This copy feature is available only when you place originals on the scanner glass.
1 Press Copy.
2 Place a single original face down on the scanner glass.
For details about loading an original, see page
3 Press Menu until Copy Feature appears on the bottom line of the display and press OK.
4 Press the Scroll buttons until Poster Copy appears and press OK.
5 Press the Scroll buttons to select the color mode you want.
There are two types of mode as following:
•Yes-Color: Color copy
•Yes-Mono: Black and White copy
6 Press OK to begin copying.
Note
• You cannot adjust the copy size using the
Reduce/Enlarge button when making a poster.
Your original is divided into 9 portions. Each portion is scanned and printed one by one in the following order:
Clone copying
Your machine can print multiple image copies from the original document on a single page. The number of images is automatically determined by the original image and paper size.
This copy feature is available only when you place originals on the scanner glass.
1 Press Copy.
2 Place a single original face down on the scanner glass.
For details about loading an original, see page
3 Press Menu until Copy Feature appears on the bottom line of the display and press OK.
4 Press the Scroll buttons until Clone Copy appears and press OK.
5 Press the Scroll buttons to select the color mode you want.
There are two types of mode as following:
•Yes-Color: Color copy
•Yes-Mono: Black and White copy
6 Press OK to begin copying.
Note
• You cannot adjust the copy size using the
Reduce/Enlarge button while making a clone copy.
6.4
<Copying>
Erasing background images
You can set the machine to print an image without its background. This copy feature removes the background color and can be helpful when copying an original containing color in the background, such as a newspaper or a catalog. This copy feature is only for mono copying.
1 Press Copy.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Press Menu until Copy Feature appears on the bottom line of the display and press OK.
4 Press the Scroll buttons until Erase Bkgd. appears and press OK.
5 Press the Scroll buttons to select On and press OK.
6 Press Stop/Clear to return to Standby mode.
7 Enter the number of copies using the number keypad.
8 Press Black Start to begin mono copying.
Setting copy timeout
You can set the time the machine waits before it restores the default copy settings, if you do not start copying after changing them on the control panel.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until Timeout appears and press OK.
4 Press the Scroll buttons until the time setting you want appears.
Selecting Off means that the machine does not restore the default settings until you press Black Start or Color Start to begin copying, or Stop/Clear to cancel.
5 Press OK to save your selection.
6 Press Stop/Clear to return to Standby mode.
6.5
<Copying>
7
Basic printing
This chapter explains common printing tasks.
Printing a document
Your machine allows you to print from various Windows, Macintosh, or
Linux applications. The exact steps for printing a document may vary depending on the application you use.
For details about printing, see the Software Section.
Canceling a print job
If the print job is waiting in a print queue or print spooler, such as the printer group in Windows, delete the job as follows:
1 Click the Windows Start menu.
2 For Windows 98/2000/Me, select Settings and then Printers.
For Windows XP, select Printers and Faxes.
3 Double-click the Samsung CLX-3160 Series icon.
4 From the Document menu, select Cancel Printing (Windows 98/
Me) or Cancel (Windows 2000/XP).
Note
• You can also access this window by simply double-clicking the printer icon at the bottom right corner of the Windows desktop.
You can also cancel the current job by pressing Stop/Clear on the control panel.
7.1
<Basic printing>
8
Scanning
Scanning with your machine lets you turn pictures and text into digital files that can be stored on your computer. Then you can fax or email the files, upload them to your website, or use them to create projects that you can print.
This chapter includes:
•
•
Scanning to an application using a local connection
•
Scanning using a network connection
•
Changing the settings for each scan job
•
Changing the default scan settings
•
Note
• The maximum resolution that can be achieved depends upon various factors, including computer speed, available disk space, memory, the size of the image being scanned, and bit depth settings. Thus, depending on your system and what you are scanning, you may not be able to scan at certain resolutions, especially using enhanced resolution.
Scanning basics
Your machine offers the following ways to scan an image using a local connection:
• Via one of the preset imaging applications. Scanning an image launches the selected application, enabling you to control the scanning process. See the next section.
• Via the SmarThru™ program supplied with your machine. Scanning an image launches SmarThru™ and enables you to control the scanning process.
• Via the Windows Images Acquisition (WIA) driver. See the Software
Section.
• To a portable USB memory device, if inserted into the USB memory
port on your machine. See page 11.2.
Also, you can send scanned images to several destinations using a network connection:
• To your networked computer via the Network Scan program. You can scan an image from the machine, if network-connected, to the computer where the Network Scan program is running.
Scanning to an application using a local connection
1 Make sure that your machine and computer are turned on and properly connected to each other.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Press Scan/Email.
Ready to Scan appears on the top line of the display.
4 Press the Scroll buttons until Scan to Appl. appears on the bottom line of the display and press OK.
5 Press the Scroll buttons until the application you want to use appears and press OK.
• Microsoft Paint: Sends the scanned image to Microsoft Paint.
• Email: Sends the scanned image to your default email program on your computer. A new message windows opens with the image attached.
• My Documents: Saves the scanned image in the default folder,
My Documents, on your computer.
• SmarThru: Sends the scanned image to SmarThru™, installed with the printer driver.
• OCR: Sends the scanned image to the OCR program for text recognition.
Note
• You can add more TWAIN-compliant software for scanning, such as Adobe Photoshop Deluxe, or Adobe
Photoshop, from the Printer Settings Utility. See the
Software Section.
6 On the selected application, adjust the scan settings and begin scanning.
For details, please refer to the application user’s guide.
8.1
<Scanning>
Scanning using a network connection
If you have connected your machine to a network and set up network parameters correctly, you can scan and send images over the network.
Preparing for network scanning
Before using your machine’s network scanning features, you need to add the machine to the Network Scan program for scanning to a network client.
Adding the machine to the Network Scan program
First, install the Network Scan program. See the Software Section.
To scan images from your machine to your computer through the network, you need to register the machine as an authorized network scanner in the Network Scan program.
1 In Windows, select Start Programs Samsung Network
Printer Utilities Network Scan Network Scan.
The Samsung Network Scan Manager window opens.
2 Click the Add Device button or double-click the Add Device icon.
3 Click Next.
4 Select Browse for a scanner. (recommended), or select Connect
to this scanner. and enter the IP address of your machine.
5 Click Next.
A list of the scanners on your network appears.
6 Select your machine from the list and enter a name, user ID, and
PIN (Personal Identification Number) for the machine.
Notes
• For the scanner name, the model name of your machine is automatically entered, but can be changed.
• You can enter an ID of up to 8 characters. The first character must be a letter.
• The PIN must be 4 digits.
7 Click Next.
8 Click Finish.
Your machine is added to the Network Scan program and you can now scan images through the network.
Note
• You can change the scanner properties of your machine and the scan settings from the Samsung Network Scan
Manager window. Click Properties and set the options in each tab.
Registering authorized users
To send an email, you need to register authorized users using
SyncThru™ Web Service. You can add up to 50 users.
1 Enter your machine’s IP address as the URL in a browser and click
Go to access the web site of your machine.
2 Click Machine Settings and User Authentication.
3 Click ADD.
4 Select the index number where the corresponding entry will be stored, from 1 to 50.
5 Enter your name, user ID, password, and e-mail address.
You need to enter the registered user ID and password in the machine when you start scanning to email from the control panel.
6 Click Apply.
Setting up an e-mail account
To scan and send an image as an email attachment, you need to set up network parameters using SyncThru™ Web Service.
1 Enter your machine’s IP address as the URL in a browser and click
Go to access the web site of your machine.
2 Click Machine Settings and E-mail Setup.
3 Select IP Address or Host Name.
4 Enter the IP address in dotted decimal notation or as a host name.
5 Enter the server port number, from 1 to 65535.
The default port number is 25.
6 Put a check mark in SMTP Requires Authentication to require authentication.
7 Enter the SMTP server login name and password.
8 Click Apply.
8.2
<Scanning>
Scanning to a network client
Network Scan allows you to remotely scan an original from your networkconnected machine to your computer in JPEG, TIFF, or PDF file format.
Scanning
1 Make sure that your machine and the computer are connected to a network and Network Scan is running on the computer.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Press Scan/Email.
4 Press the Scroll buttons until Network Scan appears on the bottom line of the display and press OK.
5 Select the Scroll buttons until the ID you have set in the Samsung
Network Scan Manager window and press OK.
6 Enter the PIN you have set in the Samsung Network Scan
Manager window and press OK.
7 If the scan destination is your computer folders, press the Scroll buttons until My Documents appears on the bottom line of the display and press OK.
Note
If the scan destination is your computer application, press the Scroll buttons until the application you want appears and press Color Start or Black Start. Scanning is started.
8 Press the Scroll buttons until the scan setting option you want appears and press OK. Or, press Color Start or Black Start to immediately start scanning using the default settings.
• Resolution: Sets the image resolution.
• Scan Color: Sets the color mode.
• Scan Format: Sets the file format in which the image is to be saved. When you select TIFF or PDF, you can select to scan multiple pages.
9 Press the Scroll buttons until the desired status appears and press
OK.
10 press Color Start or Black Start to start scanning. Your machine begins scanning the original to the computer where the program is running.
Setting network scan timeout
If the Network Scan program on your computer does not send a refresh request and does not scan a job within a specified timeout period, your machine cancels the scan job. You can change this timeout setting as needed.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press the Scroll buttons until NetScanTimeout appears and press
OK.
4 Enter the desired timeout value and press OK.
The change will be broadcast over the network and will apply to all clients connected to the network.
5 Press Stop/Clear to return to Standby mode.
Scanning to Email
You can scan and send an image as an email attachment. You first need to set up your email account in SyncThru™ Web Service. See page
Before scanning, you can set the scan options for your scan job. See
1 Make sure that your machine is connected to a network.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Press Scan/Email.
4 Press the Scroll buttons until Scan to Email appears on the bottom line of the display and press OK.
5 Enter the recipient’s email address and press OK.
If you have set up Address Book, you can use a speed button or a speed email or group email number to retrieve an address from
6 To enter additional addresses, press OK when Yes appears and repeat step 5.
To continue to the next step, press the Scroll buttons to select No and press OK.
7 If the display asks if you want to send the email to your account, press the Scroll buttons to select Yes or No and press OK.
Note
This prompt does not appear if you have activated the
Send To Self option in the email account setup.
8 Enter an email subject and press OK.
9 Press the Scroll buttons until the file format you want appears and press OK or Start.
The machine begins scanning and then sends the email.
10 If the machine asks if you want to log off your account, press the
Scroll buttons to select Yes or No and press OK.
11 Press Stop/Clear to return to Standby mode.
8.3
<Scanning>
Changing the settings for each scan job
Your machine provides you with the following setting options to allow you to customize your scan jobs.
• Scan Size: Sets the image size.
• Original Type: Sets the original document’s type.
• Resolution: Sets the image resolution.
• Scan Color: Sets the color mode.
• Scan Format: Sets the file format in which the image is to be saved.
If you select TIFF or PDF, you can select to scan multiple pages.
Depending on the selected scan type, this option may not appear.
To customize the settings before starting a scan job:
1 Press Scan/Email.
2 Press Menu until Scan Feature appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until the scan type you want appears and press OK.
4 Press the Scroll buttons until the scan setting option you want appears and press OK.
5 Press the Scroll buttons until the desired status appears and press
OK.
6 Repeat steps 4 and 5 to set other setting options.
7 When you have finished, press Stop/Clear to return to Standby mode.
Changing the default scan settings
To avoid having to customize the scan settings for each job, you can set up default scan settings for each scan type.
1 Press Scan/Email.
2 Press Menu until Scan Setup appears on the bottom line of the display and press OK.
3 Press OK when Change Default appears.
4 Press the Scroll buttons until the scan type you want appears and press OK.
5 Press the Scroll buttons until the scan setting option you want appears and press OK.
6 Press the Scroll buttons until the desired status appears and press
OK.
7 Repeat steps 5 and 6 to change other settings.
8 To change the default settings for other scan types, press Back and repeat from step 4.
8.4
<Scanning>
9 Press Stop/Clear to return to Standby mode.
Setting up Address Book
You can set up Address Book with the email addresses you use frequently via SyncThru™ Web Service and then easily and quickly enter email addresses by entering the location numbers assigned to them in Address Book.
Registering speed email numbers
1 Enter your machine’s IP address as the URL in a browser and click
Go to access the web site of your machine.
2 Click Machine Settings and E-mail Setup.
3 Click Local Address Book and ADD.
4 Select a location number and enter the user name and e-mail address you want.
5 Click Apply.
Note
You can also click Import and obtain your address book from your computer.
Configuring group email numbers
1 Enter your machine’s IP address as the URL in a browser and click
Go to access the web site of your machine.
2 Click Machine Settings and E-mail Setup.
3 Click Group Address Book and ADD.
4 Select a group number and enter the group name you want.
5 Select speed email numbers that will be included in the group.
6 Click Apply.
Using Address Book entries
To retrieve an email address, use the following ways:
Speed email numbers
When you are prompted to enter a destination address while sending an email, enter the speed email number at which you stored the address you want.
• For a one-digit speed email location, press and hold the corresponding digit button from the number keypad.
• For a two- or three-digit speed email location, press the first digit button(s) and then hold down the last digit button.
If you are an CLX-3160FN user, you can also press the speed buttons at which you stored the address you want.
You can also search through memory for an entry by pressing Address
Group email numbers
To use a group email entry, you need to search for and select it from memory.
When you are prompted to enter a destination address while sending an
email, press Address Book. See page 8.4
Searching Address Book for an entry
There are two ways to search for an address in memory. You can either scan from A to Z sequentially or search by entering the first letters of the name associated with the address.
Searching sequentially through memory
1 If necessary, press Scan/Email.
2 Press Address Book until Search & Send appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until the number category you want appears and press OK.
4 Press OK when All appears.
5 Press the Scroll buttons until the name and address you want appears. You can search upwards or downwards through the entire memory in alphabetical order.
Searching with a particular first letter
1 If necessary, press Scan/Email.
2 Press Address Book until Search & Send appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until the number category you want appears and press OK.
4 Press the Scroll buttons until ID appears and press OK.
5 Enter the first few letters of the name you want and press OK.
6 Press the Scroll buttons until the name you want appears and press OK.
Printing Address Book
You can check your Address Book settings by printing a list.
1 Press Address Book until Print appears on the bottom line of the display.
2 Press OK. A list showing your speed button settings, and the speed/group email entries print out.
8.5
<Scanning>
9
Faxing
(CLX-3160FN only)
The fax feature is available only on the CLX-3160FN. This chapter gives you information about using your machine as a fax machine.
This chapter includes:
•
•
Adjusting the document settings
•
•
•
•
•
•
•
•
Receiving automatically in Fax mode
•
Receiving manually in Tel mode
•
Receiving manually using an extension telephone
•
Receiving automatically in Ans/Fax mode
•
Receiving faxes using DRPD mode
•
Receiving in secure receiving mode
•
•
Sending a fax to multiple destinations
•
•
•
Sending a fax
Setting the fax header
In some countries, you are required by law to indicate your fax number on any fax you send. The Machine ID, containing your telephone number and name or company name, will be printed at the top of each page sent from your machine.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press OK when Machine Setup appears.
3 Press OK when Machine ID appears.
4 Enter your name or the company name using the number keypad.
You can enter alphanumeric characters using the number keypad, and include special symbols by pressing the 0 button.
For details on how to enter alphanumeric characters, see page 2.3.
5 Press OK to save the ID.
6 Press the Scroll buttons until Machine Fax No. appears and press
OK.
7 Enter your fax number using the number keypad and press OK.
8 Press Stop/Clear to return to Standby mode.
Adjusting the document settings
Before starting a fax, change the following settings according to your original’s status to get the best quality.
Resolution
The default document settings produce good results when using typical text-based originals. However, if you send originals that are of poor quality, or contain photographs, you can adjust the resolution to produce a higher quality Fax.
1 Press Resolution.
2 Press Resolution or the Scroll buttons until the option you want appears.
3 Press OK to save your selection.
9.1
<Faxing (CLX-3160FN only)>
Recommended resolution settings for different original document types are described in the table below:
Mode
Standard
Fine
Super Fine
Photo Fax
Recommended for:
Originals with normal sized characters.
Originals containing small characters or thin lines or originals printed using a dot-matrix printer.
Originals containing extremely fine detail. Super
Fine mode is enabled only if the machine with which you are communicating also supports the
Super Fine resolution.
Notes
• For memory transmission, Super Fine mode is not available. The resolution setting is automatically changed to Fine.
• When your machine is set to Super Fine resolution and the fax machine with which you are communicating does not support
Super Fine resolution, the machine transmits using the highest resolution mode supported by the other fax machine.
Originals containing shades of gray or photographs.
Note
• The resolution setting is applied to the current fax job. To
change the default setting, see page 10.2.
Darkness
You can select the default contrast mode to fax your originals lighter or darker.
1 Press Fax.
2 Press Menu, and then OK when Fax Feature appears on the bottom line of the display.
3 Press OK when Darkness appears.
4 Press the Scroll buttons until the option you want appears and press OK.
5 Press Stop/Clear to return to Standby mode.
Note
• The darkness setting is applied to the current fax job. To
change the default setting, see page 10.2.
Sending a fax automatically
1 Press Fax.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
Ready to Fax appears on the top line of the display.
3 Adjust the resolution and the darkness to suit your fax needs.
4 Enter the receiving fax machine’s number.
You can use speed buttons, speed dial numbers, or group dial numbers. For details about storing and searching for a number, see
5 Press Color Start or Black Start.
6 If an original is placed on the scanner glass, select Yes to add another page. Load another original and press OK.
7 When you have finished, select No at the Another Page? prompt.
After the number is dialed, the machine begins sending the fax when the receiving fax machine answers.
Note
• When you want to cancel a fax job, press Stop/Clear at any time while sending.
Sending a fax manually
1 Press Fax.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Adjust the resolution and the darkness to suit your fax needs. See
4 Press On Hook Dial. You hear a dial tone.
5 Enter the receiving fax machine’s number.
You can use speed buttons, speed dial numbers, or group dial numbers. For details about storing and searching for a number, see
6 Press Color Start or Black Start when you hear a high-pitched fax signal from the remote fax machine.
Note
• When you want to cancel a fax job, press Stop/Clear at any time while sending.
9.2
<Faxing (CLX-3160FN only)>
Confirming a transmission
When the last page of your original has been sent successfully, the machine beeps and returns to Standby mode.
When something goes wrong while sending your fax, an error message appears on the display. For a list of error messages and their meanings,
see page 14.5. If you receive an error message, press Stop/Clear to
clear the message and try to send the fax again.
You can set your machine to print a confirmation report automatically
each time sending a fax is completed. For further details, see page 10.1.
Automatic redialing
When the number you have dialed is busy or there is no answer when you send a fax, the machine automatically redials the number every three minutes, up to seven times according to the factory default settings.
When the display shows Retry Redial?, press OK to redial the number without waiting. To cancel the automatic redialing, press Stop/Clear.
To change the time interval between redials and the number of redial
Redialing the last number
To redial the number you called last:
1 Press Redial/Pause.
2 When an original is loaded in the ADF, the machine automatically begins to send.
If an original is placed on the scanner glass, select Yes to add another page. Load another original and press OK. When you have finished, select No at the Another Page? prompt.
Receiving a fax
Selecting the paper tray
After loading the print media for fax output, you have to select the paper tray you will use for the fax reception.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Paper Setup appears and press OK.
3 Press the Scroll buttons until Paper Source appears and press
OK.
4 Press the Scroll buttons until Fax Tray appears and press OK.
5 Press the Scroll buttons until the paper tray you want appears and press OK.
6 Press Stop/Clear to return to Standby mode.
Changing receiving modes
1 Press Fax.
2 Press Menu until Fax Setup appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Receiving appears and press OK.
4 Press OK when Receive Mode appears.
5 Press the Scroll buttons until the fax reception mode you want appears.
• In Fax mode, the machine answers an incoming fax call and immediately goes into the fax reception mode.
• In Tel mode, you can receive a fax by pressing On Hook Dial and then Color Start or Black Start. You can also pick up the handset of the extension phone and then press the remote receive code.
• In Ans/Fax mode, an answering machine attached to your machine answers an incoming call, and the caller can leave a message on the answering machine. If the fax machine senses a fax tone on the line, the machine automatically switches to Fax
mode to receive the fax. See page 9.4.
• In DRPD mode, you can receive a call using the Distinctive Ring
Pattern Detection (DRPD) feature. Distinctive Ring is a telephone company service which enables an user to use a single telephone line to answer several different telephone numbers. For further
6 Press OK to save your selection.
9.3
<Faxing (CLX-3160FN only)>
7 Press Stop/Clear to return to Standby mode.
Notes
• When the memory is full, the printer can no longer receive any incoming fax. Secure free memory to resume by removing data stored in the memory.
• To use the Ans/Fax mode, attach an answering machine to the EXT socket on the back of your machine.
• If you do not want other people to view your received documents, you can use secure receiving mode. In this mode, all of the received faxes are stored in memory. For
further details, see page 9.5.
Receiving automatically in Fax mode
Your machine is preset to Fax mode at the factory. When you receive a fax, the machine answers the call on a specified number of rings and automatically receives the fax.
To change the number of rings, see page
Receiving manually in Tel mode
You can receive a fax call by pressing On Hook Dial and then pressing
Black Start or Color Start when you hear a fax tone from the remote machine.
The machine begins receiving a fax and returns to Standby mode when the reception is completed.
Receiving manually using an extension telephone
This features works best when you are using an extension telephone connected to the EXT socket on the back of your machine. You can receive a fax from someone you are talking to on the extension telephone without going to the fax machine.
When you receive a call on the extension phone and hear fax tones, press the keys 9 on the extension phone. The machine receives the fax.
Press the buttons slowly in sequence. If you still hear the fax tone from the remote machine, try pressing 9 once again.
9 is the remote receive code preset at the factory. The first and the last asterisks are fixed, but you can change the middle number to whatever you wish. For details about changing the code, see page
Receiving automatically in Ans/Fax mode
To use this mode, you must attach an answering machine to the EXT socket on the back of your machine.
If the caller leaves a message, the answering machine stores the message as it would normally. If your machine detects a fax tone on the line, it automatically starts to receive the fax.
Notes
• If you have set your machine to Ans/Fax mode and your answering machine is switched off, or no answering machine is connected to EXT socket, your machine automatically goes into Fax mode after a predefined number of rings.
• If your answering machine has a user-selectable ring counter, set the machine to answer incoming calls within 1 ring.
• If you are in Tel mode (manual reception) when the answering machine is connected to your machine, you must switch off the answering machine, or the outgoing message from the answering machine will interrupt your phone conversation.
Receiving faxes using DRPD mode
Distinctive Ring is a telephone company service which enables an user to use a single telephone line to answer several different telephone numbers. The particular number someone uses to call you is identified by different ringing patterns, which consist of various combinations of long and short ringing sounds. This feature is often used by answering services who answer telephones for many different clients and need to know which number someone is calling in on to properly answer the phone.
Using the Distinctive Ring Pattern Detection (DRPD) feature, your fax machine can learn the ring pattern you designate to be answered by the fax machine. Unless you change it, this ringing pattern will continue to be recognized and answered as a fax call, and all other ringing patterns will be forwarded to the extension telephone or answering machine plugged into the EXT socket. You can easily suspend or change DRPD at any time.
Before using the DRPD option, Distinctive Ring service must be installed on your telephone line by the telephone company. To set up DRPD, you will need another telephone line at your location, or someone available to dial your fax number from outside.
To set up the DRPD mode:
1 Press Fax.
2 Press Menu until Fax Setup appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Receiving appears and press OK.
4 Press the Scroll buttons until DRPD Mode appears and press OK.
Waiting Ring appears on the display.
9.4
<Faxing (CLX-3160FN only)>
5 Call your fax number from another telephone. It is not necessary to place the call from a fax machine.
6 When your machine begins to ring, do not answer the call. The machine requires several rings to learn the pattern.
When the machine completes learning, the display shows
Completed DRPD Setup.
If the DRPD setup fails, Error DRPD Ring appears. Press OK when DRPD Mode appears and start over from step 4.
7 Press Stop/Clear to return to Standby mode.
When the DRPD feature is set up, the DRPD option is available for the receiving mode setting. To receive faxes in DRPD mode, you need to set the menu to DRPD.
Notes
• DRPD must be set up again if you re-assign your fax number, or connect the machine to another telephone line.
• After DRPD has been set up, call your fax number again to verify that the machine answers with a fax tone. Then have a call placed to a different number assigned to that same line to be sure the call is forwarded to the extension telephone or answering machine plugged into the EXT socket.
Receiving in secure receiving mode
You may need to prevent your received faxes from being accessed by unauthorized people. You can turn on secure receiving mode to restrict printing of received faxes when the machine is unattended. In secure receiving mode, all incoming faxes go into memory. When the mode is deactivated, any stored faxes are printed.
Activating secure receiving mode
1 Press Fax.
2 Press Menu and then press OK when Fax Feature appears on the bottom line of the display.
3 Press the Scroll buttons until Secure Receive appears and press
OK.
4 Press the Scroll buttons until On appears and press OK.
5 Enter a four-digit password you want to use and press OK.
Note
• You can activate secure receiving mode without setting a password, but cannot protect your faxes.
6 Re-enter the password to confirm it and press OK.
7 Press Stop/Clear to return to Standby mode.
When a fax is received in secure receiving mode, your machine stores it in memory and shows Secure Receive to let you know that there is a fax received.
9.5
<Faxing (CLX-3160FN only)>
Printing received faxes
1 Access the Secure Receive menu by following steps 1 through 3 in
“Activating secure receiving mode.”
2 Press the Scroll buttons until Print appears and press OK.
3 Enter the four-digit password and press OK.
The machine prints all of the faxes stored in memory.
Deactivating secure receiving mode
1 Access the Secure Receive menu by following steps 1 through 3 in
“Activating secure receiving mode.”
2 Press the Scroll buttons until Off appears and press OK.
3 Enter the four-digit password and press OK.
The mode is deactivated and the machine prints all faxes stored in memory.
4 Press Stop/Clear to return to Standby mode.
Receiving faxes in memory
Since your machine is a multi-tasking device, it can receive faxes while you are making copies or printing. If you receive a fax while you are copying or printing, your machine stores incoming faxes in its memory.
Then, as soon as you finish copying or printing, the machine automatically prints the fax.
Also, your machine receives faxes and stores them in its memory when there is no paper in the tray or no toner in the installed toner cartridge.
Other ways to fax
Sending a fax to multiple destinations
You can use the Multiple Send feature, which allows you to send a fax to multiple locations. Originals are automatically stored in memory and sent to a remote station. After transmission, the originals are automatically erased from memory. You can not send a color fax using this feature.
1 Press Fax.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Adjust the document resolution and darkness to suit your fax
4 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
5 Press the Scroll buttons until Multi Send appears and press OK.
6 Enter the number of the first receiving fax machine and press OK.
You can use speed buttons, speed dial numbers. You can enter
Group Dial Number using Address Book Button. For details, see
7 Enter the second fax number and press OK.
The display asks you to enter another fax number to send the document.
8 To enter more fax numbers, press OK when Yes appears and repeat steps 6 and 7. You can add up to 10 destinations.
Note
• Once you entered a group dial number, you cannot enter another group dial numbers anymore.
9 When you have finished entering fax numbers, press the Scroll buttons to select No at the Another No.? prompt and press OK.
The original is scanned into memory before transmission. The display shows memory capacity and the number of pages being stored in memory.
10 If an original is placed on the scanner glass, select Yes to add another pages. Load another original and press OK.
When you have finished, select No at the Another Page? prompt.
The machine begins sending the fax to the numbers you entered in the order in which you entered them.
Sending a delayed fax
You can set your machine to send a fax at a later time when you will not be present. You can not send a color fax using this feature.
1 Press Fax.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Adjust the document resolution and darkness to suit your fax
4 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
5 Press the Scroll buttons until Delay Send appears and press OK.
6 Enter the number of the receiving machine using the number keypad.
You can use speed buttons, speed dial numbers. You can enter
Group Dial Number using Address Book Button.For details, see
7 Press OK to confirm the number. The display asks you to enter another fax number to which to send the document.
8 To enter more fax numbers, press OK when Yes appears and repeat steps 6 and 7. You can add up to 10 destinations.
Note
• Once you entered a group dial number, you cannot enter another group dial numbers anymore.
9 When you have finished entering fax numbers, press the Scroll buttons to select No at the Another No.? prompt and press OK.
10 Enter the job name you want and press OK.
For details on how to enter alphanumeric characters, see page 2.3.
If you do not want to assign a name, skip this step.
11 Enter the time using the number keypad and press OK, or Black
Start.
Note
• If you set a time earlier than the current time, the fax will be sent at that time on the following day.
The original is scanned into memory before transmission. The display shows memory capacity and the number of pages being stored in memory.
12 If an original is placed on the scanner glass, select Yes to add another page. Load another original and press OK.
When you have finished, select No at the Another Page? prompt.
The machine returns to Standby mode. The display reminds you that you are in Standby mode and that a delayed fax is set.
9.6
<Faxing (CLX-3160FN only)>
Adding pages to a delayed fax
You can add pages to the delayed transmissions previously reserved in your machine’s memory.
1 Load the originals to be added and adjust document settings.
2 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
3 Press OK when Add Page appears.
4 Press the Scroll buttons until the fax job you want appears and press OK.
The machine scans the original into memory and shows the total number of pages and the number of the added pages.
Canceling a delayed fax
1 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Cancel Job appears and press OK.
3 Press the Scroll buttons until the fax job you want appears and press OK.
4 Press OK when Yes appears.
The selected fax is deleted from memory.
Sending a priority fax
Using the Priority Fax feature, a high priority fax can be sent ahead of reserved operations. The original is scanned into memory and immediately transmitted when the current operation is finished. In addition, priority transmission will interrupt a Multiple Send operation between stations (i.e., when the transmission to station A ends, before transmission to station B begins) or between redial attempts.
1 Press Fax.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Adjust the document resolution and darkness to suit your fax
4 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
5 Press the Scroll buttons until Priority Send appears and press
OK.
6 Enter the number of the receiving machine.
You can use speed buttons, speed dial numbers, or group dial
numbers. For details, see page 10.3.
7 Press OK to confirm the number.
8 Enter the job name you want and press OK.
The original is scanned into memory before transmission. The display shows memory capacity and the number of pages being stored in memory.
9 If an original is placed on the scanner glass, select Yes to add another page. Load another original and press OK.
When you have finished, select No at the Another Page? prompt.
The machine shows the number being dialed and begins sending the fax.
Forwarding faxes
You can forward your incoming and outgoing faxes to another fax machine or email address.
Forwarding sent faxes to another fax machine
You can set the machine to send copies of all outgoing faxes to a specified destination, in addition to the fax numbers you entered.
1 Press Fax.
2 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Forward appears and press OK.
4 Press OK when Fax appears.
5 Press the Scroll buttons until Send Forward appears and press
OK.
6 Press the Scroll buttons to select On and press OK.
7 Enter the number of the fax machine to which faxes are to be sent and press OK.
8 Press Stop/Clear to return to Standby mode.
Subsequent sent faxes will be forwarded to the specified fax machine.
Forwarding sent faxes to email address
You can set the machine to send copies of all outgoing faxes to a specified destination, in addition to the email address you entered.
1 Press Fax.
2 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Forward appears and press OK.
4 Press the Scroll buttons until E-mail appears and press OK.
9.7
<Faxing (CLX-3160FN only)>
5 Press the Scroll buttons until Send Forward appears and press
OK.
6 Press the Scroll buttons to select On and press OK.
7 Enter your email address and press OK.
8 Enter the email address to which faxes are to be sent and press
OK.
9 Press Stop/Clear to return to Standby mode.
Subsequent sent faxes will be forwarded to the specified email address.
Forwarding received faxes to another fax machine
You can set your machine to forward incoming faxes to another fax number during a specified time period. When a fax arrives at your machine, it is stored in memory. Then, the machine dials the fax number that you have specified and sends the fax.
1 Press Fax.
2 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Forward appears and press OK.
4 Press OK when Fax appears.
5 Press the Scroll buttons until Rcv. Forward appears and press
OK.
6 Press the Scroll buttons until Forward appears and press OK.
To set the machine to print out a fax when fax forwarding has been completed, select Forward&Print.
7 Enter the number of the fax machine to which faxes are to be sent and press OK.
8 Enter the starting time and press OK.
9 Enter the ending time and press OK.
10 Press Stop/Clear to return to Standby mode.
Subsequent received faxes will be forwarded to the specified fax machine.
Forwarding received faxes to email address
You can set your machine to forward incoming faxes to the email address you entered.
1 Press Fax.
2 Press Menu until Fax Feature appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Forward appears and press OK.
4 Press the Scroll buttons until E-mail appears and press OK.
5 Press the Scroll buttons until Rcv. Forward appears and press
OK.
6 Press the Scroll buttons until Forward appears and press OK.
To set the machine to print out a fax when fax forwarding has been completed, select Forward&Print.
7 Enter your email address and press OK.
8 Enter the email address to which faxes are to be sent and press
OK.
9 Press Stop/Clear to return to Standby mode.
Subsequent sent faxes will be forwarded to the specified email address.
9.8
<Faxing (CLX-3160FN only)>
10
Fax setup
(CLX-3160FN only)
This chapter gives you information on setting up your machine for receiving and sending faxes.
This chapter includes:
•
Changing the fax setup options
•
Changing the default document settings
•
Printing sent fax report automatically
•
Changing the fax setup options
Your machine provides you with various user-selectable options for setting up the fax system. You can change the default settings for your preferences and needs.
To change the fax setup options:
1 Press Fax.
2 Press Menu until Fax Setup appears on the bottom line of the display and press OK.
3 Press the Scroll buttons to select Sending or Receiving and press
OK.
4 Press the Scroll buttons until the menu item you want appears and press OK.
5 Press the Scroll buttons until the desired status appears or enter the value for the option you have selected, and press OK.
6 If necessary, repeat steps 4 through 5.
7 Press Stop/Clear to return to Standby mode.
Sending options
Option
Redial Times
Redial Term
Prefix Dial
Description
You can specify the number of redial attempts. If you enter 0, the machine will not redial.
Your machine can automatically redial a remote fax machine if it was busy. You can set an interval between attempts.
You can set a prefix of up to five digits. This number dials before any automatic dial number is started. It is useful for accessing a PABX exchange.
Option
ECM Mode
Image TCR a b
Send Report
Dial Mode
Description
This mode helps with poor line quality and makes sure any faxes you send are sent smoothly to any other ECM-equipped fax machine. Sending a fax using ECM may take more time.
You can set your machine to print a confirmation report showing whether a transmission was successful, how many pages were sent, and more. The available options are On, Off, and On-
Error, which prints only when a transmission is not successful.
You can prevent the actual faxed material from being included in the confirmation report for privacy or security protection.
This setting may not be available depending on your country. If you cannot reach this option, your machine does not support this feature.
You can set the dial mode for your machine to either tone dialling or pulse dialling. If you have a public telephone system or a private branch exchnage(PBX) system, you may need to select
Pulse. Contact your local telephone company if you are not sure which dial mode to use.
If you select Pulse, some phone system features might not be available. It can also take longer to dial a fax or phone number.
a. Error Correction Mode b. Transmission Confirmation Report
Receiving options
Option
Receive Mode
Ring to Answer
Stamp Rcv
Name
Rcv Start Code
Description
You can select the default fax receiving mode.
For details on receiving faxes in each mode, see
You can specify the number of times the machine rings before answering an incoming call.
This option allows the machine to automatically print the page number, and the date and time of reception at the bottom of each page of a received fax.
This code allows you to initiate fax reception from an extension phone plugged into the EXT socket on the back of the machine. If you pick up the extension phone and hear fax tones, enter the code. It is preset to 9 at the factory.
10.1
<Fax setup (CLX-3160FN only)>
Option
Auto
Reduction
Discard Size
Junk Fax Setup
DRPD Mode a
Description
When receiving a fax containing pages as long as or longer than the paper loaded in the paper tray, the machine can reduce the size of the original to fit the size of the paper loaded in the machine.
Turn on this feature if you want to automatically reduce an incoming page.
With this feature set to Off, the machine cannot reduce the original to fit onto one page. The original will be divided and printed in actual size on two or more pages.
When receiving a fax containing pages as long as or longer than the paper in your machine, you can set the machine to discard a specific length from the end of the received fax. The machine will print the received fax on one or more sheets of paper, minus the data that would have been on the specified discard segment.
When the received fax contains pages larger than the paper in your machine, and Auto Reduction has been turned on, the machine will reduce the fax to fit on the existing paper, and nothing will be discarded.
This setting may not be available depending on your country. Using this feature, the system will not accept faxes sent from remote stations whose numbers are stored in the memory as junk fax numbers. This feature is useful for blocking any unwanted faxes.
When you turn on this feature, you can access the following options to set junk fax numbers.
• Add: allows you to set up to 10 fax numbers.
• Delete: allows you to delete the desired junk fax number.
• Delete All: allows you to delete all junk fax numbers.
This mode enables a user to use a single telephone line to answer several different telephone numbers. In this menu, you can set the machine to recognize which ring patterns to answer. For details about this feature, see page
a. Distinctive Ring Pattern Detection
Changing the default document settings
The fax options, including resolution and darkness, can be set to the most frequently used modes. When you send a fax, the default settings are used if they are not changed by using the corresponding button and menu.
1 Press Fax.
2 Press Menu until Fax Setup appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Change Default appears and press
OK.
4 Press OK when Resolution appears.
5 Press the Scroll buttons until the resolution you want appears and press OK.
6 Press the Scroll buttons until Darkness appears and press OK.
7 Press the Scroll buttons until the darkness you want appears and press OK.
8 Press Stop/Clear to return to Standby mode.
Printing sent fax report automatically
You can set the machine to print a report with detailed information about the previous 50 communication operations, including time and dates.
1 Press Fax.
2 Press Menu until Fax Setup appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Auto Report appears and press OK.
4 Press the Scroll buttons until On appears and press OK.
5 Press Stop/Clear to return to Standby mode.
10.2
<Fax setup (CLX-3160FN only)>
Setting up Address Book
You can set up Address Book with the fax numbers you use most frequently. Your machine provides you with the following features for setting up Address Book:
• Speed buttons
• Speed/Group dial numbers
Note
• Before beginning to store fax numbers, make sure that your machine is in Fax mode.
Speed buttons
The 15 speed buttons on the control panel lets you store frequently-used fax numbers. You will be able to enter a fax number with the touch of a button. By utilizing the Shift button, you can store up to 30 numbers on the speed buttons.
There are two ways to assign numbers to speed buttons. Examine the procedures below and use the appropriate way which you prefer:
Registering after pressing a speed button
1 Press Fax.
2 Press one of the speed buttons.
3 Press OK when Yes appears.
4 Enter the name you want and press OK.
For details on how to enter alphanumeric characters, see page 2.3.
5 Enter the fax number you want to store and press OK.
Registering after entering a number first
1 Press Fax.
2 Enter the fax number you want to store.
3 Press one of the speed buttons.
4 Press OK when Yes appears.
Note
• If you press a speed button already assigned, the display asks if you want to overwrite. Press OK to confirm Yes and continue. To start over with another speed button, select No.
5 Enter the name you want and press OK.
For details on how to enter alphanumeric characters, see page 2.3.
6 Press OK to confirm the number.
Using speed buttons
When you are prompted to enter a fax number while sending a fax:
• To retrieve a number from speed buttons 1 to 15, press the corresponding speed button and press OK.
• To retrieve a number from speed buttons 16 to 30, press Shift and then the corresponding speed button, and press OK.
Speed dial numbers
You can store up to 240 frequently-used fax numbers in speed dial numbers.
Registering a speed dial number
1 Press Fax.
2 Press Address Book until New & Edit appears on the bottom line of the display and press OK.
3 Press OK when Speed Dial appears.
4 Enter a speed dial number between 0 and 239 and press OK.
If an entry is already stored in the number you choose, the display shows the name to allow you to change it. To start over with another speed dial number, press Back.
5 Enter the name you want and press OK.
For details on how to enter alphanumeric characters, see page 2.3.
6 Enter the fax number you want and press OK.
7 Press Stop/Clear to return to Standby mode.
Editing speed dial numbers
1 Press Address Book until New & Edit appears on the bottom line of the display and press OK.
2 Press OK when Speed Dial appears.
3 Enter the speed dial number you want to edit and press OK.
4 Change the name and press OK.
5 Change the fax number and press OK.
6 Press Stop/Clear to return to Standby mode.
Using speed dial numbers
When you are prompted to enter a destination number while sending a fax, enter the speed dial number at which you stored the number you want.
• For a one-digit (0-9) speed dial number, press and hold the corresponding digit button on the number keypad.
• For a two- or three-digit speed dial number, press the first digit button(s) and then hold down the last digit button.
10.3
<Fax setup (CLX-3160FN only)>
You can also search through memory for an entry by pressing Address
Group dial numbers
If you frequently send the same document to several destinations, you can group these destinations and set them under a group dial number.
You can then use a group dial number to send a document to all of the destinations within the group. You can set up to 200 (0 through 199) group dial numbers using the destination’s existing speed dial numbers.
Registering a group dial number
1 Press Fax.
2 Press Address Book until New & Edit appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until Group Dial appears and press OK.
4 Enter a group dial number between 0 and 199 and press OK.
5 Enter a speed dial number and press OK.
6 Press OK when speed dial information appears correctly.
7 Press OK when Yes appears.
8 Repeat steps 5 and 6 to include other speed dial numbers into the group.
9 When you have finished, press the Scroll buttons to select No at the Another No.? prompt and press OK.
10 Press Stop/Clear to return to Standby mode.
Editing a group dial number
You can delete a specific entry from a group or add a new number to the selected group.
1 Press Address Book until New & Edit appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Group Dial appears and press OK.
3 Enter the group dial number you want to edit and press OK.
4 Enter the speed dial number you want to add or delete and press
OK.
If you entered a new speed dial number, Add? appears.
If you enter a speed dial number stored in the group, Delete? appears.
5 Press OK to add or delete the number.
6 Press OK when Yes appears to add or delete more numbers and repeat steps 4 and 5.
7 When you have finished, press the Scroll buttons to select No at the Another No.? prompt and press OK.
10.4
<Fax setup (CLX-3160FN only)>
8 Press Stop/Clear to return to Standby mode.
Using group dial numbers
To use a group dial entry, you need to search for and select it from memory.
When you are prompted to enter a fax number while sending a fax, press
Address Book. See below.
Searching Address Book for an entry
There are two ways to search for a number in memory. You can either scan from A to Z sequentially, or you can search by entering the first letters of the name associated with the number.
Searching sequentially through the memory
1 If necessary, press Fax.
2 Press Address Book until Search & Dial appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until the number category you want appears and press OK.
4 Press OK when All appears.
5 Press the Scroll buttons until the name and number you want appears. You can search upwards or downwards through the entire memory in alphabetical order.
Searching with a particular first letter
1 If necessary, press Fax.
2 Press Address Book until Search & Dial appears on the bottom line of the display and press OK.
3 Press the Scroll buttons until the number category you want appears and press OK.
4 Press the Scroll buttons until ID appears and press OK.
5 Enter the first few letters of the name you want and press OK.
6 Press the Scroll buttons until the name you want appears and press OK.
Deleting a Address Book entry
You can delete entries in Address Book one by one.
1 Press Address Book until Delete appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until the number category you want appears and press OK.
3 Press the Scroll buttons until the searching method you want appears and press OK.
Select Search All to search for an entry by scanning through all entries in Address Book.
Select Search ID to search for an entry by the first few letters of the name.
4 Press the Scroll buttons until the name you want appears and press OK.
Or, enter the first letters and press OK. Press the Scroll buttons until the name you want appears and press OK.
5 Press OK.
6 Press OK when Yes appears to confirm the deletion.
7 Press Stop/Clear to return to Standby mode.
Printing Address Book
You can check your Address Book settings by printing a list.
1 Press Address Book until Print appears on the bottom line of the display.
2 Press OK. A list showing your speed button settings, and speed dial and group dial entries prints out.
10.5
<Fax setup (CLX-3160FN only)>
11
Using USB flash memory
This chapter explains how to use a USB memory device with your machine.
This chapter includes:
•
•
Plugging in a USB memory device
•
Scanning to a USB memory device
•
Printing from a USB memory device
•
Backing up data (CLX-3160FN only)
•
•
Printing directly from a digital camera
About USB memory
USB memory devices are available with a variety of memory capacities to give you more room for storing documents, presentations, downloaded music and videos, high resolution photographs, or whatever other files you want to store or move.
You can do the following on your machine using a USB memory device:
• Scan documents and save them on a USB memory device.
• Print data stored on a USB memory device.
• Back up Address Book entries and the system settings of your machine.
• Restore backup files to the machine’s memory.
• Format the USB memory device.
• Check the available memory space.
Plugging in a USB memory device
The USB memory port on the front of your machine is designed for USB
V1.1 and USB V2.0 memory devices. Your machine supports USB memory devices with FAT16/FAT32 and sector size 512Byte.
Check your USB memory devices’ file system from your dealer.
You must use only an authorized USB memory device with an A plug type connector.
Use only a metal/shielded
USB memory device.
Note
• There are two USB plug types.
Insert a USB memory device into the USB memory port on the front of your machine.
Cautions
• Do not remove the USB memory device while the machine is in operation, or writing to or reading from USB memory. This may damage your machine.
• If your USB memory device has certain features, such as security settings and password settings, your machine may not automatically detect it. For details about these features, see the device’s User’s Guide.
11.1
<Using USB flash memory>
Scanning to a USB memory device
You can scan a document and save the scanned image onto a USB memory device. There are two ways of doing this: you can scan to the device using the default settings, or you can customize your own scan settings.
Scanning
1 Insert a USB memory device into the USB memory port on your machine.
2 Load originals face up into the ADF, or place a single original face down on the scanner glass.
For details about loading an original, see page 5.1.
3 Press Scan/Email.
4 Press OK when Scan to USB appears on the bottom line of the display.
5 Press OK, Color Start or Black Start when USB appears.
Regardless of the button you press, the color mode is decided as
customized. See “Customizing Scan to USB” on page 11.2.
Your machine begins scanning the original, and then asks if you want to scan another page.
6 Press OK when Yes appears to scan more pages. Load an original and press Color Start or Black Start.
Regardless of the button you press, the color mode is decided as
customized. See “Customizing Scan to USB” on page 11.2.
Otherwise, press the Scroll buttons to select No and press OK.
After scanning is complete, you can remove the USB memory device from the machine.
Customizing Scan to USB
You can specify image size, file format, or color mode for each scanning to USB job.
1 Press Scan/Email.
2 Press Menu until Scan Feature appears on the bottom line of the display and press OK.
3 Press OK when USB Memory appears.
4 Press the Scroll buttons until the setting option you want appears and press OK.
You can set the following options:
• Scan Size: Sets the image size.
• Original Type: Sets the original document’s type.
• Resolution: Sets the image resolution.
• Scan Color: Sets the color mode. If you select Mono in this option, you can not select JPEG in Scan Format.
• Scan Format: Sets the file format in which the image is to be saved. When you select TIFF or PDF, you can select to scan multiple pages. If you select JPEG in this option, you can not select Mono in Scan Color.
5 Press the Scroll buttons until the desired status appears and press
OK.
6 Repeat steps 4 and 5 to set other setting options.
7 When you have finished, press Stop/Clear to return to Standby mode.
You can change the default scan settings. For details, see page 8.4.
Printing from a USB memory device
You can directly print files stored on a USB memory device. You can print
TIFF, BMP, JPEG.
Direct Print option supported file types:
• BMP: BMP Uncompressed
• TIFF: TIFF 6.0 Baseline
• JPEG: JPEG Baseline
To print a document from a USB memory device:
1 Insert a USB memory device into the USB memory port on your machine. If one has already been inserted, press USB Print.
Your machine automatically detects the device and reads data stored on it.
2 Press the Scroll buttons until the folder or file you want appears and press OK.
If you see D in the front of a folder name, there are one or more files or folders in the selected folder.
3 If you selected a file, skip to the next step.
If you selected a folder, press the Scroll buttons until the file you want appears.
4 Press the Scroll buttons to select the number of copies to be printed or enter the number.
5 Press OK, Color Start or Black Start to start printing the selected file.
There are two types of mode as following:
• OK or Color Start: Color print
• Black Start: Black and White print
After printing the file, the display asks if you want to print another job.
6 Press OK when Yes appears to print another job, and repeat from step 2.
Otherwise, press the Scroll buttons to select No and press OK.
11.2
<Using USB flash memory>
7 Press Stop/Clear to return to Standby mode.
Backing up data
(CLX-3160FN only)
Data in the machine’s memory can be accidentally erased due to power failure or storage failure. Backup helps you protect your Address Book entries and the system settings by storing them as backup files on a USB memory device.
Backing up data
1 Insert the USB memory device into the USB memory port on your machine.
2 Press Menu until System Setup appears on the bottom line of the display and press OK.
3 Press OK when Machine Setup appears.
4 Press the Scroll buttons until Export Setting appears and press
OK.
5 Press the Scroll buttons until the option you want appears.
• Address Book: Backs up all Address Book entries.
• Setup Data: Backs up all system settings.
6 Press OK to begin backing up the data.
The data is backed up to the USB memory.
7 Press Stop/Clear to return to Standby mode.
Restoring data
1 Insert the USB memory device on which the backup data is stored in to the USB memory port.
2 Press Menu until System Setup appears on the bottom line of the display and press OK.
3 Press OK when Machine Setup appears.
4 Press the Scroll buttons until Import Setting appears and press
OK.
5 Press the Scroll buttons until the data type you want appears and press OK.
6 Press the Scroll buttons until the file containing the data you want to restore appears and press OK.
7 Press OK when Yes appears to restore the backup file to the machine.
8 Press Stop/Clear to return to Standby mode.
Managing USB memory
You can delete image files stored on a USB memory device one by one or all at once by reformatting the device.
Caution
• After deleting files or reformatting a USB memory device, files cannot be restored. Therefore, confirm that you no longer need the data before deleting it.
Deleting an image file
1 Insert the USB memory device into the USB memory port on your machine.
2 Press Scan/Email.
3 Press OK when Scan to USB appears on the bottom line of the display.
4 Press the Scroll buttons until File Manage appears and press OK.
5 Press OK when Delete appears.
6 Press the Scroll buttons until the folder or file you want appears and press OK.
Note
• If you see D in the front of a folder name, there are one or more files or folders in the selected folder.
If you selected a file, the display shows the size of the file for about
2 seconds. Go to the next step.
If you selected a folder, press the Scroll buttons until the file you want to delete appears and press OK.
7 Press OK when Yes appears to confirm your selection.
8 Press Stop/Clear to return to Standby mode.
Formatting a USB memory device
1 Insert the USB memory device into the USB memory port on your machine.
2 Press Scan/Email.
3 Press OK when Scan to USB appears on the bottom line of the display.
4 Press the Scroll buttons until File Manage appears and press OK.
5 Press the Scroll buttons until Format appears and press OK.
6 Press OK when Yes appears to confirm your selection.
7 Press Stop/Clear to return to Standby mode.
11.3
<Using USB flash memory>
Viewing the USB memory status
You can check the amount of memory space available for scanning and saving documents.
1 Insert the USB memory device into the USB memory port on your machine.
2 Press Scan/Email.
3 Press OK when Scan to USB appears on the bottom line of the display.
4 Press the Scroll buttons until Check Space appears and press
OK.
The available memory space appears on the display.
5 Press Stop/Clear to return to the Standby mode.
Printing directly from a digital camera
This machine supports the PictBridge feature. You can print images directly from any PictBridge-compatible device, such as a digital camera, camera phone, and camcorder. You do not need to connect it to a computer.
1 Turn on the machine.
2 Connect your PictBridge-compatible device to the memory port on the front of the machine using the USB cable supplied with the device.
3 Send an order to print images from the PictBridge-compatible device.
11.4
<Using USB flash memory>
12
Ordering supplies and accessories
This chapter provides information on purchasing supplies and accessories available for your machine.
•
•
•
Supplies
When the toner runs out or, the life span of the supplies expires you can order the following types of toner cartridges and supplies for your machine:
Type
Black toner cartridge
Cyan toner cartridge
Magenta toner cartridge
Yellow toner cartridge
Imaging unit
Waste toner container
Yield a
Part number
Approx. 2,000 pages CLP-K300A
Approx. 1,000 pages CLP-C300A
Approx. 1,000 pages CLP-M300A
Approx. 1,000 pages CLP-Y300A
CLP-R300A Approx. 20,000 black pages or
50,000 images
Approx. 5,000 images b
(1,250 color pages)
CLP-W300A a. Average A4-/letter sized page count based on 5% coverage of indivisual colors on each page. Usage conditions and print patterns may cause results to vary. b. Image counts based on one color on each page. If you print documents in full color(Cyan, Magenta, Yellow, Black), the life of this item will be reduced by
25%.
Accessories
You can purchase and install accessories to enhance your machine’s performance and capacity.
The following accessories are available for your machine:
Accessory
Optional tray 2
Description
If you are experiencing frequent paper supply problems, you can attach an additional 250 sheets of plain paper tray.
Part number
CLX-S3160A
How to purchase
To order Samsung-authorized supplies or accessories, contact your local Samsung dealer or the retailer where you purchased your machine, or visit www.samsungprinter.com
and select your country/region for information on calling for technical support.
12.1
<Ordering supplies and accessories>
13
Maintenance
This chapter provides information for maintaining your machine and the toner cartridge.
This chapter includes:
•
•
•
•
Maintaining the toner cartridge
•
•
Replacing the Waste Toner Container
•
•
Managing your machine from the website
•
Checking the machine’s serial number
Printing reports
Your machine can provide various reports with useful information you will need. The following reports are available:
Reports in the colored cells are only available with CLX-3160FN.
Report/List
Configuration
Supplies Info
Address Book
Description
This list shows the status of the user-selectable options. You may print this list to confirm your changes after changing settings.
This list shows the current status of consumables in your machine.
This list shows all of the fax numbers and email addresses currently stored in the machine’s memory.
Send Report
Sent Report
This report shows the fax number, the number of pages, the elapsed time of the job, the communication mode, and the communication results for a particular fax job.
You can set up your machine to automatically print a transmission confirmation report after
This report shows information on the faxes and emails you have recently sent.
You can set the machine to automatically print this report every 50 communications. See
Fax Rcv Report This report shows information on the faxes you have recently received.
Report/List
Schedule Jobs
Junk Fax
Report
Network Info.
NetScan
Report
User Auth List
Description
This list shows the documents currently stored for delayed faxes along with the starting time and type of each operation.
This list shows the fax numbers specified as junk fax numbers. To add or delete numbers to or from this list, access the Junk Fax Setup menu.
This list shows information on your machine’s network connection and configuration.
This report shows information for the Network
Scan records including IP address, time and date, the number of pages scanned, and results.
This report is automatically printed every
50 network scan jobs.
This list shows authorized users who are allowed to use the email function.
Printing a report
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Report appears and press OK.
3 Press the Scroll buttons until the report or list you want to print appears and press OK.
To print all reports and lists, select All Report.
4 Press OK when Yes appears to confirm printing.
The selected information prints out.
Other available reports
(CLX-3160FN only)
Your machine prints the following reports automatically or depending on your setting.
• Multi-communication Report: prints automatically after sending faxes from more than one location.
• Power Failure Report: prints out automatically when power is restored after a power failure if any data loss occurs due to the power failure.
13.1
<Maintenance>
Clearing memory
You can selectively clear information stored in your machine’s memory.
Caution
• For CLX-3160FN users, before clearing the memory, make sure that all fax jobs have been completed, or you will lose those jobs.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Clear Setting appears and press
OK.
3 Press the Scroll buttons until the item you want to clear appears.
The options in the colored cells are available only with CLX-
3160FN.
Options
All Settings
Fax Setup
Copy Setup
Scan Setup
System Setup
Network
Description
Clears all of the data stored in memory and resets all of your settings to the factory default.
Restores all of the fax options to the factory default.
Restores all of the copy options to the factory default.
Restores all of the scan options to the factory default.
Restores all of the system options to the factory default.
Restores all of the network options to the factory default.
Address Book Clears all of the fax number and email address entries stored in memory.
Sent Report Clears all records of sent faxes and emails.
Fax Rcv
Report
NetScan
Report
Clears all records of received faxes.
Clears the information on network scan sessions in memory.
4 Press OK when Yes appears.
5 Press OK again to confirm clearing.
6 Repeat steps 3 through 5 to clear another item.
7 Press Stop/Clear to return to Standby mode.
Cleaning your machine
To maintain print and scan quality, follow the cleaning procedures below each time the toner cartridge is replaced or if print and scan quality problems occur.
Caution
• Cleaning the cabinet of the machine with cleaning materials containing large amounts of alcohol, solvent, or other strong substances can discolor or distort the cabinet.
Cleaning the outside
Clean the cabinet of the machine with a soft lint-free cloth. You can dampen the cloth slightly with water, but be careful not to let any water drip onto or into the machine.
Cleaning the inside
During the printing process, paper, toner, and dust particles can accumulate inside the machine. This buildup can cause print quality problems, such as toner specks or smearing. Cleaning the inside of the machine clears or reduces these problems.
1 Turn the machine off and unplug the power cord. Wait for the machine to cool down.
2 Open the front cover and pull the imaging unit out of the machine using the handle on its bottom.
13.2
<Maintenance>
3 Extend the top handle on the imaging unit and then use it to pull the imaging unit out of the machine completely.
5 Pull the imaging unit about half and push it until it sounds ‘click’.
Repeat this action two or three times.
Cautions
• To prevent damage to the imaging unit, do not expose it to light for more than a few minutes. Cover it with a piece of paper, if necessary.
• Do not touch the green surface on the imaging unit with your hands or any other material. Use the handle on it to avoid touching this area.
• Be careful not to scratch the surface of the imaging unit.
4 With a dry lint-free cloth, wipe away any dust and spilled toner.
6 Push the imaging unit until it sounds ‘click’ in to the machine.
Note
• After cleaning, let the printer to dry completely.
7 Close the front cover firmly.
Caution
• If the front cover is not completely closed, the machine will not operate.
8 Plug in the power cord and turn the machine on.
Caution
• If there is a cracking sound, re-install the imaging unit. The imaging unit is not properly installed.
13.3
<Maintenance>
Cleaning the scan unit
Keeping the scan unit clean helps ensure the best possible copies. We suggest that you clean the scan unit at the start of each day and during the day, as needed.
1 Slightly dampen a soft lint-free cloth or paper towel with water.
2 Open the scanner lid.
3 Wipe the surface of the scanner glass and ADF glass until it is clean and dry.
1
2
3
4
1
2
3
4 white sheet
ADF glass scanner lid scanner glass
4 Wipe the underside of the scanner lid and white sheet until it is clean and dry.
5 Close the scanner lid.
Maintaining the toner cartridge
Toner cartridge storage
To get the most from the toner cartridge, keep the following guidelines in mind:
• Do not remove the toner cartridge from its package until ready for use.
• Do not refill the toner cartridge. The machine warranty does not cover damage caused by using a refilled cartridge.
• Store toner cartridges in the same environment as your machine.
• To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes.
Expected cartridge life
The life of the toner cartridge depends on the amount of toner that print jobs require. When printing text at 5% coverage, a new toner cartridge lasts an average of 2,000 pages for black and white printing and 1,000 pages for each color printing. However, the toner cartridge that is shipped with the printer prints 1,500 pages for black and white, 700 pages for colors.
The actual number may also be different depending on the print density of the pages you print on, and the number of pages may be affected by operating environment, printing interval, media type, and media size. If you print a lot of graphics, you may need to change the cartridge more often.
Redistributing toner
When the toner cartridge is near the end of its life:
• White streaks or light printing occurs.
• Toner Low appears on the display.
• The Status LED blinks red.
If this happens, you can temporarily reestablish print quality by redistributing the remaining toner in the cartridge. In some cases, white streaks or light printing will still occur even after you have redistributed the toner.
1 Open the front cover.
2 Pull the corresponding toner cartridge out.
3 Holding the toner cartridge, thoroughly roll it 5 or 6 times to distribute the toner evenly inside the cartridge.
13.4
<Maintenance>
Note
• If toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water. Hot water sets toner into fabric.
4 Grasp the toner cartridge and align it with the corresponding slot inside the machine. Insert it back into its slot until it clicks into place.
3 Pull the corresponding toner cartridge out.
4 Take a new toner cartridge out of its package.
5 Holding the toner cartridge, thoroughly roll it 5 or 6 times to distribute the toner evenly inside the cartridge.
5 Close the front cover. Make sure that the cover is securely closed.
Replacing the toner cartridge
The machine uses four colors and has a different toner cartridge for each one: yellow (Y), magenta (M), cyan (C), and black (K).
When the toner cartridge is completely empty:
• Toner Empty appears on the display.
• The Status LED lights red.
• The machine stops printing. For the CLX-3160FN, incoming faxes are saved in memory.
At this stage, the toner cartridge needs to be replaced. For order
information for toner cartridges, see page 12.1.
1 Turn the machine off, then wait a few minutes for the machine to cool.
2 Open the front cover.
6 Remove the cartridge cap.
Note
• If toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water. Hot water sets toner into fabric.
13.5
<Maintenance>
7 Grasp the toner cartridge and align it with the corresponding slot inside the machine. Insert it into its slot until it clicks into place.
8 Close the front cover. Make sure that the cover is securely latched and then turn the machine on.
Caution
• If the front cover is not completely closed, the machine will not operate.
Note
• If the installation is completed properly, a guide report is printed out automatically. Wait for about 1.5 minutes for the machine to get ready.
• When printing text at 5% coverage, you can expect a toner cartridge life of about 2,000 pages for black and white printing and 1,000 pages for color printing.
Sending new toner notification
(CLX-3160FN only)
You can set your machine to automatically send a fax to your service company or dealer to notify them that your machine requires a new toner cartridge when the toner cartridge needs to be replaced. The fax number needs to be set by your dealer prior to using this feature, otherwise the machine cannot send a notification even though you turn this service on.
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Maintenance appears and press
OK.
3 Press the Scroll buttons until Remote Service appears and press
OK.
4 Enter a password and press OK.
5 Re-enter the password and press OK.
6 Press the Scroll buttons to select On and press OK.
7 Press Stop/Clear to return to Standby mode.
Once this feature has been enabled, you need to enter the password each time you disable or enable it.
13.6
<Maintenance>
Replacing the Imaging Unit
The life of the imaging unit is approximately 20,000 pages for black or
50,000 image printing whichever comes first. When the life span of the imaging unit has expired, Replace Imaging Unit appears on the display of the control panel, indicating the imaging unit needs to be replaced.
Otherwise your printer stops printing.
To replace the imaging unit:
1 Turn the machine off, then wait a few minutes for the machine to cool.
2 Open the front cover.
3 Remove all of the toner cartridges and waste toner container from the machine.
5 Extend the top handle on the imaging unit and then use it to pull the imaging unit out of the machine completely.
6 Take a new imaging unit out of its package. Remove the protective devices on both sides of the imaging unit and the paper protecting the surface of the imaging unit.
4 Pull the imaging unit out of the machine using the handle on its bottom.
Cautions
• Don’t use sharp objects, such as a knife or scissors, to open the imaging unit package. You could damage the surface of the imaging unit.
• Be careful not to scratch the surface of the imaging unit.
• To prevent damage, do not expose the imaging unit to light for more than a few minutes. Cover it with a piece of paper to protect it if necessary.
13.7
<Maintenance>
7 Holding the handles on the new imaging unit, push the imaging unit until it sounds ‘click’ into the machine.
9 Insert the toner cartridges and waste toner container into their corresponding slots until they click into place.
8 Remove four dummy caps which are on the toner cartridge entrances of the imaging unit. When you remove the dummy cap from the cartridge, lift the handle up and pull it out.
10 Close the front cover firmly.
Caution
• If the front cover is not completely closed, the machine will not operate.
11 Turn the machine on.
Note
• After rebooting, your machine will automatically reset the counter for the imaging unit.
• If the installation is completed properly, a guide report is printed out automatically. Wait for about 1.5 minutes for the machine to get ready.
Caution
• If there is a cracking sound, re-install the imaging unit. The imaging unit is not properly installed.
Caution
• If you force too much to the dummy caps, it may cause problem.
13.8
<Maintenance>
Replacing the Waste Toner Container
The life of the waste toner container unit is approximately 1,250 pages for full color 5% image printing or 5,000 pages for black printing. When the life span of the waste toner container has expired, Replace/Install
Waste Toner Tank appears on the display of the control panel, indicating the waste toner container needs to be replaced. Otherwise your printer stops printing.
To replace the waste toner container:
1 Turn the machine off, then wait a few minutes for the machine to cool.
2 Open the front cover.
3 Pull the waste toner container out of the machine using its handle.
6 Insert the new container into position and then push it to make sure that it is firmly seated in place.
7 Close the front cover firmly.
Caution
• If the front cover is not completely closed, the machine will not operate.
8 Turn the machine on.
Note
• After rebooting, your machine will automatically reset the counter for the waste toner container.
Note
• Make sure that you lay the waste toner container on a flat surface so that the toner does not spill.
4 Remove the container’s cap from the ontainer as shown below, and use it to close the waste toner container opening.
Caution
• Do not tilt or turn over the container.
5 Take a new waste toner container out of its package.
13.9
<Maintenance>
Maintenance Parts
To avoid print quality and paper feed problems resulting from worn parts and to maintain your printer in top working condition the following items will need to be replaced at the specified number of pages or when the life span of each item has expired.
Items
ADF rubber pad
Transfer belt
Transfer roller
Fuser unit
Tray rubber pad
Pickup roller
Yield (Average)
Approx. 20,000 pages
Approx. 60,000 images
Approx. 100,000 pages
Approx. 100,000 black pages or
50,000 color pages
Approx. 250,000 pages
Approx. 50,000 pages
Samsung highly recommends that an authorized service provider, dealer or the retailer where you bought printer performs this maintenance activity.
Checking replaceables
If you experience frequent paper jams or printing problems, check the number of pages the machine has printed or scanned. Replace the corresponding parts, if necessary.
The following information are available for checking the replaceable elements of your machine:
• Supplies Info: prints the supply information page.
• Total: displays the total number of pages printed.
• ADF Scan: displays the number of pages scanned using the ADF.
• Platen Scan: displays the number of pages scanned using the scanner glass.
• Imaging Uint, Transfer Belt, Fuser, TransferRoller, Tray1 Roller,
Tray2 Roller: displays the number of pages printed each item.
To check the replaceables:
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Maintenance appears and press
OK.
3 Press the Scroll buttons until Supplies Life appears and press
OK.
4 Press the Scroll buttons until the item you want appears and press
OK.
5 If you selected to print a supply information page, press OK to confirm.
6 Press Stop/Clear to return to Standby mode.
Replacing the ADF rubber pad
You will need to replace the ADF rubber pad when there seems to be a consistent problem with paper pickup or when its specified yield is reached.
1 Open the ADF cover.
2 Rotate the bushing on the right end of the ADF roller toward the
ADF and remove the roller from the slot.
1
2 bushing
ADF roller
3 Remove the ADF rubber pad from the ADF, as shown.
4 Insert a new ADF rubber pad into place.
1 ADF rubber pad
13.10
<Maintenance>
1
2
1
5 Align the left end of the ADF roller with the slot and push the right end of the roller into the right slot. Rotate the bushing on the right end of the roller toward the document input tray.
Checking the machine’s serial number
When you call for service or register as a user on the Samsung website, the machine’s serial number may be required.
You can check the serial number by taking the following steps:
1 Press Menu until System Setup appears on the bottom line of the display and press OK.
2 Press the Scroll buttons until Maintenance appears and press
OK.
3 Press the Scroll buttons until Serial Number appears and press
OK.
4 Check your machine’s serial number.
5 Press Stop/Clear to return to Standby mode.
6 Close the ADF cover.
Managing your machine from the website
If you have connected your machine to a network and set up TCP/IP network parameters correctly, you can manage the machine via
Samsung’s SyncThru™ Web Service, an embedded web server. Use
SyncThru™ Web Service to:
• View the machine’s device information and check its current status.
• Change TCP/IP parameters and set up other network parameters.
• Change the printer properties.
• Set the machine to send email notifications to let you know the machine’s status.
• Get support for using the machine.
To access SyncThru™ Web Service:
1 Start a web browser, such as Internet Explorer, from Windows.
2 Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address field and press the Enter key or click Go.
Your machine’s embedded website opens.
13.11
<Maintenance>
14
Troubleshooting
This chapter gives helpful information for what to do if you encounter an error.
This chapter includes:
•
•
•
Understanding display messages
•
Clearing document jams
When an original jams while passing through the ADF, Document Jam appears on the display.
1 Remove any remaining pages from the ADF.
2 Open the ADF cover.
1
4 Close the ADF cover. Then load the removed pages, if any, back into the ADF.
Note
• To prevent document jams, use the scanner glass for thick, thin, or mixed paper-type originals.
Exit misfeed
1 Open the scanner lid.
2 Turn the release knob to the direction as shown to remove the misfed paper from the document output tray.
1
2
1
3 Pull the jammed paper gently out of the ADF.
ADF cover
1
2 release knob scanner lid
3 Close the scanner lid. Then load the removed pages back into the
ADF.
14.1
<Troubleshooting>
Roller misfeed
1 Open the scanner lid.
2 Seize the misfed paper, and remove the paper from the feed area by carefully pulling it to the right using both hands.
In the tray 1
1 Open and close the front cover. The jammed paper is automatically ejected from the machine.
If the paper does not exit, go to the next step.
2 Pull the tray 1 out of the machine.
3 Remove the jammed paper by gently pulling it straight out.
3 Close the scanner lid. Then load the removed pages back into the
ADF.
Clearing paper jams
When a paper jam occurs, Paper Jam appears on the display. Refer to the table below to locate and clear the paper jam.
Message
Paper Jam 0
Open/Close Door
Paper Jam 1
Open/Close Door
Paper Jam 2
Check Inside
Manual Feeder
Paper Jam 0
Location of jam
In the paper feed area (tray 1, optional tray 2)
Go to the next colume,
In the paper exit area
In the fuser area or around the toner cartridge
In the paper feed area
Caution
• To avoid tearing the paper, pull out the jammed paper gently and slowly. Follow the instructions in the following sections to clear the jam.
If the paper does not move when you pull, or if you do not see the
paper in this area, check the paper exit area. See page 14.4.
4 Insert the tray 1 into the machine until it snaps into place. Printing automatically resumes.
14.2
<Troubleshooting>
In the optional tray 2
1 Pull the optional tray 2 out of the machine.
4 Open the jam cover in the optional tray 2.
5 Pull the jammed paper out in the direction shown.
2 Remove the jammed paper from the machine.
3 Insert the tray 1 into the machine until it snaps into place. Printing automatically resumes.
If the paper does not move when you pull, or if you do not see the paper in this area, go to the next step.
6 Close the jam cover. Printing automatically resumes.
14.3
<Troubleshooting>
In the mamual feeder
1 Pull the tray 1 out.
2 Push the manual feeder tab down.
In the paper exit area
1 Open and close the front cover. The jammed paper is automatically ejected from the machine.
2 Gently pull the paper out of the output tray.
3 Pull the Jammed paper out of the manual feeder.
If you do not see the jammed paper or if there is any resistance when you pull, stop and go to the next step.
3 Open the rear cover.
4 If you see the jammed paper, pull it straight up. Skip to step 8.
4 Insert the tray 1 into the machine until it snaps into place. Printing automatically resumes.
If you still do not see the paper, go to the next step.
14.4
<Troubleshooting>
5 Open the fuser door.
6 Locate the jammed paper and pull it out.
1
1 fuser door
7 Close the fuser door.
8 Close the rear cover. Printing automatically resumes.
Tips for avoiding paper jams
By selecting the correct media types, most paper jams can be avoided.
When a paper jam occurs, follow the steps outlined on page 14.2.
• Follow the procedures on page 5.6. Ensure that the adjustable guides
are positioned correctly.
• Do not overload the tray. Ensure that the paper level is under the brackets of the tray 1.
• Do not remove paper from the tray while your machine is printing.
• Flex, fan, and straighten paper before loading.
• Do not use creased, damp, or highly curled paper.
• Do not mix paper types in a tray.
• Use only recommended print media. See page 5.2.
• Ensure that the recommended print side of print media is facing up in the mamual tray and tray 1.
14.5
<Troubleshooting>
Understanding display messages
Messages appear on the control panel display to indicate the machine’s status or errors. Refer to the tables below to understand the messages’ meaning and correct the problem if necessary. Messages and their meanings are listed in alphabetical order.
Note
• When you call for service, it is very convenient to tell the service representative the display message.
Messages in the colored cells are available only with CLX-3160FN.
Message
[Color]
Toner Empty
[Color]
Toner Low
[Color] Toner
Supply Error
[COMM. Error]
[Incompatible]
[Line Error]
[No Answer]
Meaning
The color toner cartridge has run out. The machine stops printing.
The corresponding color toner cartridge is almost empty.
Suggested solutions
Replace the color toner cartridge with a new one. See page
Take out the toner cartridge and thoroughly shake it.
By doing this, you can temporarily reestablish printing operations.
The machine received several papers with many images, and it can not supply the toner properly.
The machine has a communication problem.
The machine has received a fax from which is registered as a junk fax.
Your machine cannot connect with the receiving fax machine or has lost contact because of a problem with the phone line.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
Ask the sender to try again.
The received fax data will be deleted.
Reconfirm junk fax
Try again. If the problem persists, wait an hour or so for the line to clear and try again.
Or, turn the ECM mode on. See page
The receiving fax machine has not answered after several redial attempts.
Try again. Make sure that the receiving machine is operational.
Message
[Stop Pressed]
Cancel?
Yes
Connection Error
Data Read Fail
Check USB Mem.
Data Write Fail
Check USB Mem.
Deve Home Sensor
Error
Document Jam
Door Open
Enter Again
File Format
Not Supported
Fuser Fan
Locked
Meaning
Stop/Clear has been pressed during an operation.
Suggested solutions
Try again.
Your machine’s memory has become full while trying to store an original into memory.
Connection with the
SMTP server failed.
To cancel the fax job, press the OK button to accept Yes.
If you want to send those pages that have been successfully stored, press the OK button to accept No. You should send the remaining pages later, when memory is available.
Check the server settings and the network cable.
Time expired while reading data.
Storing to the USB memory failed.
Try again.
There is a problem in the fuser unit.
Check the available
USB memory space.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
The loaded original has jammed in the
ADF.
The front cover or rear cover is not securely latched.
You entered an unavailable item.
The selected file format is not supported.
There is a problem in the cooling fan of the machine.
Clear the jam. See
Close the cover until it locks into place.
Enter the correct item again.
Use the correct file format.
Open and then close the front cover.
Group Not
Available
Install
[Color] Toner
Install
[Part]
Invalid
[Color] Toner
Invalid
[Part]
Message
Line Busy
Low Heat Error
Cycle Power
LSU Hsync Error
Cycle Power
LSU Motor Error
Cycle Power
Main Motor
Locked
Meaning
You have tried to select a group location number where only a single location number can be used, such as when adding locations for a
Multiple Send operation.
The color toner cartridge is not installed.
The corresponding part of the machine is not installed.
Suggested solutions
Use a speed dial number or dial a number manually using the number keypad.
Install the color toner cartridge.
Install the part into your machine.
The color toner cartridge you have installed is not for your machine.
The color part of the machine is not for your machine.
Install the a
Samsung-genuine color toner cartridge designed for your machine.
Install the a
Samsung-genuine part designed for your machine.
The receiving fax machine did not answer or the line is already engaged.
Try again after a few minutes.
There is a problem in the fuser unit.
A problem has occurred in the LSU
(Laser Scanning
Unit).
A problem has occurred in the LSU
(Laser Scanning
Unit).
There is a problem in the main motor.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
Open and then close the front cover.
14.6
<Troubleshooting>
Message
Mail Exceeds
Server Support
Memory Full
Manual Feeder
Paper Empty
Manual Feeder
Paper Jam 0
Network Error
Not Assigned
One Page is
Too Large
Open Heat Error
Cycle Power
Operation
Not Assigned
Out-Bin Full
Over Heat Error
Cycle Power
Paper Jam 0
Open/Close Door
Meaning
The mail size is larger than the supported size by
SMTP server.
Suggested solutions
Divide your mail or reduce the resolution.
The memory is full.
There is no paper in the manual feeder.
Paper has jammed in the feeding area of the manual feeder.
There is a problem with the network.
The speed button or speed dial number you tried to use has no number assigned to it.
Single page data exceeds the configured mail size.
Delete unnecessary fax jobs and retransmit after more memory becomes available.
Alternatively, split the transmission into more than one operation.
Load paper in the manaul feeder.
Clear the jam. See
Contact your network administrator.
Enter the number manually using the number keypad or store the number or address.
There is a problem in the fuser unit.
There is a problem in the fuser unit.
Paper has jammed in the feeding area of the tray.
Reduce the resolution and try again.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
You are in the Add
Page/Cancel Job operation, but there are no jobs stored.
The output tray of the machine is full of paper.
Check the display to see if there are any scheduled jobs.
Remove paper.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
Clear the jam. See
14.7
<Troubleshooting>
Message
Paper Jam 1
Open/Close Door
Paper Jam 2
Check Inside
Tray 1
Paper Mismatch
Tray 2
Paper Mismatch
Tray 2
Paper jam 0
Power Failure
Refilled
[Color] Toner
Replace
[Color] Toner
Replace
[Part]
Replace
[Part] Soon
Meaning
Paper has jammed in the paper exit area.
Paper has jammed
In the fuser area or around the toner cartridge
The paper size specified in the printer properties does not match the paper you are loading.
The paper size specified in the printer properties does not match the paper you are loading.
Paper has jammed
In the paper feed area.
Power has turned off then on and the machine’s memory has not been back up.
The toner cartridge you have installed is not genuine or refilled.
Suggested solutions
Clear the jam. See
Clear the jam. See
Load the correct paper in the tray 1.
Load the correct paper in the tray 2.
Clear the jam. See
The job which you were trying to do before the power failure must be completely re-done.
The print quality may get poor if the refilled toner cartridge is installed, since its characteristics may significantly differ from the genuine.
We recommend
Samsung-genuine color toner cartridge.
This message appears between
Toner Empty and
Toner Low status.
Replace the toner cartridge with a new
The life of the part expires totally.
The life of the part expires soon.
Replace the part with a new one. Call for service.
call for service.
Replace/Install
Waste Toner Tank
Retry Redial?
Scanner locked
SCF
Message
Cover Open
Send Error
(AUTH)
Send Error
(DNS)
Send Error
(POP3)
Send Error
(SMTP)
Send Error
(Wrong Config)
Transfer Belt
Error
Tray 1
Paper Empty
Tray 2
Paper Empty
Meaning
The life span of the waste toner tank has expired and the printer will stop printing until a new waste toner tank is placed into the printer.
The machine is waiting for a specified time interval to redial a previously busy station.
Suggested solutions
You can press OK to immediately redial, or
Stop/Clear to cancel the redial operation.
The scanner module is locked
Unlock the scanner and press Stop/
Clear.
The jam cover in the optional tray 2 is open.
There is a problem in SMTP authentication.
There is a problem in DNS.
There is a problem in POP3.
There is a problem in SMTP.
There is a problem on the network interface card.
A problem has occurred in the transfer belt in the machine.
There is no paper in the tray 1.
There is no paper in the optional tray 2.
Close the jam cover in the optional tray 2.
Configure the authentication setting.
Configure the DNS setting.
Configure the POP3 setting.
Change to the available server.
Configure your network interface card correctly.
Unplug the power cord and plug it back in. If the problem persists, please call for service.
Load paper in the tray
Load paper in the optional tray 2.
Solving other problems
The following chart lists some conditions that may occur and the recommended solutions. Follow the suggested solutions until the problem is corrected. If the problem persists, please call for service.
Paper feeding problems
Condition
Paper is jammed during printing.
Suggested solutions
Clear the paper jam. See page 14.2.
Paper sticks together.
Multiple sheets of paper do not feed.
Paper does not feed into the machine.
The paper keeps jamming.
• Ensure that there is not too much paper in the tray. The tray can hold up to 150 sheets of paper, depending on the thickness of your paper.
• Make sure that you are using the correct type
• Remove paper from the tray and flex or fan the paper.
• Humid conditions may cause some paper to stick together.
• Different types of paper may be stacked in the tray. Load paper of only one type, size, and weight.
• If multiple sheets have caused a paper jam,
clear the paper jam. See page 14.2.
• Remove any obstructions from inside the machine.
• Paper has not been loaded correctly. Remove paper from the tray and reload it correctly.
• There is too much paper in the tray. Remove excess paper from the tray.
• The paper is too thick. Use only paper that meets the specifications required by the
• If an original does not feed into the machine, the ADF rubber pad may require to be
• There is too much paper in the tray. Remove excess paper from the tray. If you are printing on special materials, use the mamual tray.
• An incorrect type of paper is being used. Use only paper that meets the specifications
required by the machine. See page 5.2.
• There may be debris inside the machine. Open the front cover and remove the debris.
• If an original does not feed into the machine, the ADF rubber pad may require to be
14.8
<Troubleshooting>
Condition
Transparencies stick together in the paper exit.
Envelopes skew or fail to feed correctly.
Suggested solutions
Use only transparencies specifically designed for laser printers. Remove each transparency as it exits from the machine.
Ensure that the paper guides are against both sides of the envelopes.
Printing problems
Condition
The machine does not print.
Possible cause Suggested solutions
The machine is not receiving power.
The machine is not selected as the default printer.
Check the power cord connections. Check the power switch and the power source.
Select Samsung CLX-3160
Series as your default printer in your Windows.
Check the machine for the following:
• The front cover is not closed. Close the cover.
• Paper is jammed. Clear the paper jam. See 14.2.
• No paper is loaded. Load paper. See 5.6.
• The toner cartridge is not installed. Install the toner cartridge.
If a system error occurs, contact your service representative.
The connection cable between the computer and the machine is not connected properly.
Disconnect the printer cable and reconnect it.
The connection cable between the computer and the machine is defective.
The port setting is incorrect.
The machine may be configured incorrectly.
If possible, attach the cable to another computer that is working properly and print a job. You can also try using a different printer cable.
Check the Windows printer setting to make sure that the print job is sent to the correct port. If the computer has more than one port, make sure that the machine is attached to the correct one.
Check the printer properties to ensure that all of the print settings are correct.
Condition
The machine does not print.
(continued)
The machine selects print materials from the wrong paper source.
A print job is extremely slow.
Half the page is blank.
Possible cause
The printer driver may be incorrectly installed.
Suggested solutions
Repair the printer software.
See the Software Section.
The machine is malfunctioning.
The paper source selection in the printer properties may be incorrect.
The job may be very complex.
If you are using
Windows 9x/Me, the
Spool Setting may be set incorrectly.
The page orientation setting may be incorrect.
The paper size and the paper size settings do not match.
Check the display message on the control panel to see if the machine is indicating a system error.
The document size is so big that the hard disk space of the computer is not enough to access the print job.
Get more hard disk space and print the document again.
For many software applications, the paper source selection is found under the Paper tab within the printer properties. Select the correct paper source.
See the printer driver help screen.
Reduce the complexity of the page or try adjusting the print quality settings.
From the Start menu, choose Settings and then
Printers. Right-click the
Samsung CLX-3160 Series machine icon, choose
Properties, click the Details tab, and then choose the
Spool Settings button.
Select the desired spool setting.
Change the page orientation in your application. See the printer driver help screen.
Ensure that the paper size in the printer driver settings matches the paper in the tray.
Or, ensure that the paper size in the printer driver settings matches the paper selection in the software application settings you use.
14.9
<Troubleshooting>
Condition
The machine prints, but the text is wrong, garbled, or incomplete.
Possible cause
The printer cable is loose or defective.
The wrong printer driver was selected.
Suggested solutions
Disconnect the printer cable and reconnect. Try a print job that you have already printed successfully. If possible, attach the cable and the machine to another computer and try a print job that you know works. Finally, try a new printer cable.
Check the application’s printer selection menu to ensure that your machine is selected.
The software application is malfunctioning.
The operating system is malfunctioning.
The toner cartridge is defective or out of toner.
Try printing a job from another application.
Exit Windows and reboot the computer. Turn the machine off and then back on again.
Redistribute the toner, if
If necessary, replace the toner cartridge.
Check the file to ensure that it does not contain blank pages.
Pages print, but are blank.
The file may have blank pages.
Some parts, such as the controller or the board, may be defective.
The illustrations print incorrectly in Adobe
Illustrator.
The setting in the software application is wrong.
Contact a service representative.
Select Download as Bit
Image in the TrueType
Options window of the graphic properties and print the document again.
Printing quality problems
If the inside of the machine is dirty or paper has been loaded improperly, you may notice a reduction in print quality. See the table below to clear the problem.
Condition
Light or faded print
Toner specks
Aa Bb Cc
Aa Bb Cc
Aa Bb Cc
Aa Bb Cc
Aa Bb Cc
Suggested solutions
If a vertical white streak or faded area appears on the page:
• The toner supply is low. You may be able to temporarily extend the toner cartridge life.
See page 13.4. If this does not improve the
print quality, install a new toner cartridge.
• The paper may not meet paper specifications; for example, the paper is too
moist or too rough. See page 5.2.
• If the entire page is light, the print resolution setting is too low. Adjust the print resolution.
See the help screen of the printer driver.
• A combination of faded or smeared defects may indicate that the toner cartridge needs cleaning.
• The surface of the LSU part inside the machine may be dirty. Clean the LSU. See
• The paper may not meet specifications; for example, the paper is too moist or too
• The transfer roller may be dirty. Clean the
inside of your machine. See page 13.2.
• The paper path may need cleaning. See
Dropouts
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
If faded areas, generally rounded, occur randomly on the page:
• A single sheet of paper may be defective.
Try reprinting the job.
• The moisture content of the paper is uneven or the paper has moist spots on its surface.
Try a different brand of paper. See page 5.2.
• The paper lot is bad. The manufacturing processes can cause some areas to reject toner. Try a different kind or brand of paper.
• Change the printer option and try again. Go to printer properties, click Paper tab, and set type to Thick. Refer to the Software
Section for details.
• If these steps do not correct the problem, contact a service representative.
14.10
<Troubleshooting>
Condition
Vertical lines
Color or Black background
Toner smear
Suggested solutions
If black vertical streaks appear on the page:
• The drum inside the toner cartridge has probably been scratched. Remove the toner cartridge and install a new one. See page
If white vertical streaks appear on the page:
• The surface of the LSU part inside the machine may be dirty. Clean the LSU. See
If the amount of background shading becomes unacceptable:
• Change to a lighter weight paper. See page
• Check the machine’s environment: very dry
(low humidity) or high humidity (higher than
80% RH) conditions can increase the amount of background shading.
• Remove the old toner cartridge and install a
• Clean the inside of the machine. See page
• Check the paper type and quality. See page
• Remove the toner cartridge and install a
Vertical repetitive defects
A a B b C c
A a B b C c
A a B b C c
A a B b C c
A a B b C c
If marks repeatedly appear on the printed side of the page at even intervals:
• The toner cartridge may be damaged. If a repetitive mark occurs on the page, print a cleaning sheet several times to clean the
cartridge; see page 13.4. After the printout,
if you still have the same problems, remove the toner cartridge and install a new one.
• Parts of the machine may have toner on them. If the defects occur on the back of the page, the problem will likely correct itself after a few more pages.
• The fusing assembly may be damaged.
Contact a service representative.
Condition
Background scatter
A
Misformed characters
Suggested solutions
Background scatter results from bits of toner randomly distributed on the printed page.
• The paper may be too damp. Try printing with a different batch of paper. Do not open packages of paper until necessary so that the paper does not absorb too much moisture.
• If background scatter occurs on an envelope, change the printing layout to avoid printing over areas that have overlapping seams on the reverse side.
Printing on seams can cause problems.
• If background scatter covers the entire surface area of a printed page, adjust the print resolution through your software application or the printer properties.
• If characters are improperly formed and producing hollow images, the paper stock may be too slick. Try a different paper. See
• If characters are improperly formed and producing a wavy effect, the scanner unit may need service. For service, contact a service representative.
Page skew
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Curl or wave
• Ensure that the paper is loaded properly.
• Check the paper type and quality. See page
• Ensure that the paper or other material is loaded correctly and the guides are not too tight or too loose against the paper stack.
• Ensure that the paper is loaded properly.
• Check the paper type and quality. Both high temperature and humidity can cause paper
• Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray.
14.11
<Troubleshooting>
Condition
Wrinkles or creases
Suggested solutions
• Ensure that the paper is loaded properly.
• Check the paper type and quality. See page
• Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray.
Back of printouts are dirty
Check for leaking toner. Clean the inside of
Solid Color or
Black pages
A
Loose toner
• The toner cartridge may not be installed properly. Remove the cartridge and reinsert it.
• The toner cartridge may be defective and need replacing. Remove the toner cartridge
and install a new one. See page 13.5.
• The machine may require repair. Contact a service representative.
Character Voids
A
• Clean the inside of the machine. See page
• Check the paper type and quality. See page
• Remove the toner cartridge and install a
• If the problem persists, the machine may require repair. Contact a service representative.
Character voids are white areas within parts of characters that should be solid black:
• If you are using transparencies, try another type of transparency. Because of the composition of transparencies, some character voids are normal.
• You may be printing on the wrong surface of the paper. Remove the paper and turn it around.
• The paper may not meet paper
14.12
<Troubleshooting>
Condition
Horizontal stripes
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Curl
An unknown image repetitively appears on a next few sheets or loose toner, light print, or contamination occurs.
Suggested solutions
If horizontally aligned black streaks or smears appear:
• The toner cartridge may be installed improperly. Remove the cartridge and reinsert it.
• The toner cartridge may be defective.
Remove the toner cartridge and install a
• If the problem persists, the machine may require repair. Contact a service representative.
If the printed paper is curled or paper does not feed into the machine:
• Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray.
• Change the printer option and try again. Go to printer properties, click Paper tab, and set type to Thin. Refer to the Software
Section for details.
Your printer is probably being used at an altitude of 2,500 m (8,200 ft) or above.
The high altitude may affect the print quality such as loose toner or light imaging. You can set this option through Printer Settings
Utility or Printer tab in printer driver’s properties. Refer to the Software Section for details.
Copying problems
Condition
Copies are too light or too dark.
Smears, lines, marks, or spots appears on copies.
Copy image is skewed.
Blank copies print out.
Suggested solutions
Use Darkness to darken or lighten the background of the copies.
• If defects are on the original, press
Darkness to lighten the background of your copies.
• If no defects are on the original, clean the
• Ensure that the original is face down on the scanner glass or face up in the ADF.
• Check that the copy paper is loaded correctly.
Ensure that the original is face down on the scanner glass or face up in the ADF.
Condition
Image rubs off the copy easily.
Frequent copy paper jams occur.
Toner cartridge produces fewer copies than expected before running out of toner.
Suggested solutions
• Replace the paper in the tray with paper from a new package.
• In high humidity areas, do not leave paper in the machine for extended periods of time.
• Fan the stack of paper, then turn it over in the tray. Replace the paper in the tray with a fresh supply. Check/adjust the paper guides, if necessary.
• Ensure that the paper is the proper paper weight. 75 g/m 2 (20 lb bond) paper is recommended.
• Check for copy paper or pieces of copy paper remaining in the machine after a paper jam has been cleared.
• Your originals may contain pictures, solids, or heavy lines. For example, your originals may be forms, newsletters, books, or other documents that use more toner.
• The machine may be turned on and off frequently.
• The scanner lid may be left open while copies are being made.
Scanning problems
Condition
The scanner does not work.
Suggested solutions
• Make sure that you place the original to be scanned face down on the scanner glass, or face up in the ADF.
• There may not be enough available memory to hold the document you want to scan. Try the Prescan function to see if that works. Try lowering the scan resolution rate.
• Check that the USB cable is connected properly.
• Make sure that the USB cable is not defective. Switch the cable with a known good cable. If necessary, replace the cable.
• Check that the scanner is configured correctly. Check scan setting in the
SmarThru Configuration or the application you want to use to make certain that the scanner job is being sent to the correct port.
Condition
The unit scans very slowly.
Message appears on your computer screen:
• “Device can't be set to the H/W mode you want.”
• “Port is being used by another program.”
• “Port is
Disabled.
• “Scanner is busy receiving or printing data.
When the current job is completed, try again.”
• “Invalid handle.”
• “Scanning has failed.”
Suggested solutions
• Check if the machine is printing received data. If so, scan the document after the received data has been printed.
• Graphics are scanned more slowly than text.
• Communication speed slows in scan mode because of the large amount of memory required to analyze and reproduce the scanned image. Set your computer to the
ECP printer mode through BIOS setting. It will help to increase the speed. For details about how to set BIOS, refer to your computer user’s guide.
• There may be a copying or printing job in progress. When that job is complete, try your job again.
• The Selected port is currently being used.
Restart your computer and try again.
• The printer cable may be improperly connected or the power may be off.
• The scanner driver is not installed or the operating environment is not set up properly.
• Ensure that the machine is properly connected and the power is on, Then restart your computer.
• The USB cable may be improperly connected or the power may be off.
14.13
<Troubleshooting>
Network Scan problems
Condition
I cannot find a scanned image file.
I cannot find the scanned image file after scanning.
I forgot my ID and PIN.
I cannot view the Help file.
I cannot use the
Samsung
Network Scan
Manager.
Suggested solutions
You can check the scanned file’s destination in the Advanced page in the Network Scan program’s Properties screen.
• Check if the scanned file’s application is on your computer.
• Check Open immediately with the default
application in the Advanced page in the
Network Scan program’s Properties screen to open the scanned image immediately after scanning.
Check your ID and PIN in the Server page in the
Network Scan program’s Properties screen.
To view the Help file, you need to have Internet
Explorer 4 service pack 2 or above.
Check your operating system. Supporting operating systems are Windows 98/Me/2000/XP.
Fax problems
(CLX-3160FN only)
Condition
The machine is not working, there is no display and the buttons are not working.
Suggested solutions
• Unplug the power cord and plug it in again.
• Ensure that there is power to the electrical outlet.
No dial tone sounds.
• Check that the phone line is connected properly.
• Check that the phone socket in the wall is working by plugging in another phone.
The numbers stored in memory do not dial correctly.
Make sure that the numbers are stored in memory correctly. Print a Phone Book list,
The original does not feed into the machine.
• Make sure that the paper is not wrinkled and you are putting it in correctly. Check that the original is the right size, not too thick or thin
• Make sure that the ADF is firmly closed.
• The ADF rubber pad may need to be
Condition
Faxes are not received automatically.
The machine does not send.
The incoming fax has blank spaces or is of poorquality.
Suggested solutions
• The receiving mode should be set to Fax.
• Make sure that there is paper in the tray.
• Check to see if the display shows any error message. If it does, clear the problem.
• Make sure that the original is loaded in the
ADF or on the scanner glass.
• Sending should show up on the display.
• Check the fax machine you are sending to, to see if it can receive your fax.
• The fax machine sending you the fax may be faulty.
• A noisy phone line can cause line errors.
• Check your machine by making a copy.
• The toner cartridge may be empty. Replace
the toner cartridge, referring to page 13.5.
Some of the words on an incoming fax are stretched.
There are lines on the originals you send.
The machine dials a number, but a connection with the other fax machine fails.
Faxes do not store in memory.
The fax machine sending you the fax had a temporary document jam.
Check your scan unit for marks and clean it.
The other fax machine may be turned off, out of paper, or cannot answer incoming calls.
Speak with the other machine operator and ask her/him to sort out the problem.
There may not be enough memory space to store the fax. If the display shows the Memory
Full message, delete from memory any faxes you no longer need and then try again to store the fax.
Blank areas appear at the bottom of each page or on other pages, with a small strip of text at the top.
You may have chosen the wrong paper settings in the user option setting. For details
about paper settings, see page 5.2.
14.14
<Troubleshooting>
Common Windows problems
Condition
“File in Use” message appears during installation.
“Error Writing to
LPTx” message appears.
Suggested solutions
Exit all software applications. Remove all software from the StartUp Group, then restart
Windows. Reinstall the printer driver.
• Ensure that the cables are connected correctly, the machine is on.
• If bi-directional communication is not turned on in the driver, it will also cause this message.
“General
Protection Fault”,
“Exception OE”,
“Spool32”, or
“Illegal Operation” messages appear.
Close all other applications, reboot Windows and try printing again.
“Fail To Print”, “A printer timeout error occurred.” messages appear.
The printer does not print PDF file correctly. Some parts of graphics, text, or illustrations are missing.
These messages may appear during printing.
Just keep waiting until the machine finishes printing. If the message appears in standby mode or after printing has been completed, check the connection and/or whether an error has occurred.
Incompatibility between the PDF file and the
Acrobat products:
Printing the PDF file as an image may solve this problem. Turn on Print As Image from the
Acrobat printing options.
N OTE : It will take longer to print when you print a PDF file as an image.
Note
• Refer to Microsoft Windows 98/Me/2000/XP User’s Guide that came with your PC for further information on Windows error messages.
Common Linux problems
Condition
The machine does not print.
Suggested solutions
• Check if the printer driver is installed in your system. Open Unified Driver configurator and switch to the Printers tab in Printers configuration window to look at the list of available printers.
Make sure that your machine is displayed on the list. If not, please, invoke Add new printer wizard to set up your device.
• Check if the printer is started. Open
Printers configuration and select your machine on the printers list. Look at the description in the Selected printer pane.
If its status contains “(stopped)” string, please, press the Start button. After that normal operation of the printer should be restored. The “stopped” status might be activated when some problems in printing occurred. For instance, this could be an attempt to print document when port is claimed by a scanning application.
• Check if the port is not busy. Since functional components of MFP (printer and scanner) share the same I/O interface (port), the situation of simultaneous access of different
“consumer” application to the same port is possible. To avoid possible conflicts, only one of them at a time is allowed to gain control over the device. The other
“consumer” will encounter “device busy” response. You should open ports configuration and select the port assigned to your printer. In the Selected port pane you can see if the port is occupied by some other application. If this is the case, you should wait for completion of the current job or should press Release port button, if you are sure that the present owner is not functioning properly.
• Check if your application has special print option such as “-oraw”. If “-oraw” is specified in the command line parameter then remove it to print properly. For Gimp front-end, select
“print” -> “Setup printer” and edit command line parameter in the command item.
14.15
<Troubleshooting>
Condition
The machine does not print.
Some color images come out all black.
Some color images come out in unexpected color.
The machine does not print whole pages and its output is half page printed.
Suggested solutions
The CUPS (Common Unix Printing
System) version distributed with SuSE
Linux 9.2 (cups-1.1.21) has a problem with ipp (Internet Printing Protocol) printing.
Use the socket printing instead of ipp or install later version of CUPS (cups-1.1.22 or higher).
This is a known bug in Ghostscript (until
GNU Ghostscript version 7.05) when the base color space of the document is indexed color space and it is converted through CIE color space. Because
Postscript uses CIE color space for Color
Matching System, you should upgrade
Ghostscript on your system to at least
GNU Ghostscript version 7.06 or later. You can find recent Ghostscript versions at www.ghostscript.com.
This is a known bug in Ghostscript (until
GNU Ghostscript version 7.xx) when the base color space of the document is indexed RGB color space and it is converted through CIE color space.
Because Postscript uses CIE color space for Color Matching System, you should upgrade Ghostscript on your system to at least GNU Ghostscript version 8.xx or later. You can find recent Ghostscript versions at www.ghostscript.com.
It is a known problem that occurs when a color printer is used on version 8.51 or earlier of Ghostscript, 64-bit Linux OS, and reported to bugs.ghostscript.com as
Ghostscript Bug 688252.
The problem is solved in AFPL
Ghostscript v. 8.52 or above. Download the latest version of AFPL Ghostscript from http://sourceforge.net/projects/ ghostscript/ and install it to solve this problem.
Condition
The machine does not appear on the scanners list.
Suggested solutions
• Check if your machine is attached to your computer. Make sure that it is connected properly via the USB port and is turned on.
• Check if the scanner driver for your machine is installed in your system.
Open Unified Driver configurator, switch to Scanners configuration, then press
Drivers. Make sure that driver with a name corresponding to your machine's name is listed in the window. Check if the port is not busy. Since functional components of MFP (printer and scanner) share the same I/O interface
(port), the situation of simultaneous access of different “consumer” application to the same port is possible.
To avoid possible conflicts, only one of them at a time is allowed to gain control over the device. The other “consumer” will encounter “device busy” response.
This can usually happen while starting scan procedure, and appropriate message box appears.
• To identify the source of the problem, you should open ports configuration and select the port assigned to your scanner. port's symbol /dev/mfp0 corresponds to LP:0 designation displayed in the scanners’ options, /dev/ mfp1 relates to LP:1 and so on. USB ports start at /dev/mfp4, so scanner on
USB:0 relates to /dev/mfp4 respectively and so forth sequentially. In the
Selected port pane you can see if the port is occupied by some other application. If this is the case, you should wait for completion of the current job or should press Release port button, if you are sure that the present port's owner is not functioning properly.
14.16
<Troubleshooting>
The machine does not scan.
Condition
I cannot scan via Gimp
Front-end.
Suggested solutions
• Check if a document is loaded into the machine.
• Check if your machine is connected to the computer. Make sure if it is connected properly if I/O error is reported while scanning.
• Check if the port is not busy. Since functional components of MFP (printer and scanner) share the same I/O interface (port), the situation of simultaneous access of different
“consumer” application to the same port is possible. To avoid possible conflicts, only one of them at a time is allowed to gain control over the device. The other
“consumer” will encounter “device busy” response. This can usually happen while starting scan procedure, and appropriate message box will be displayed.
To identify the source of the problem, you should open ports configuration and select the port assigned to your scanner. port’s symbol /dev/mfp0 corresponds to LP:0 designation displayed in the scanners’ options, /dev/ mfp1 relates to LP:1 and so on. USB ports start at /dev/mfp4, so scanner on
USB:0 relates to /dev/mfp4 respectively and so forth sequentially. In the
Selected port pane you can see if the port is occupied by some other application. If this is the case, you should wait for completion of the current job or should press Release port button, if you are sure that the present port’s owner is not functioning properly.
• Check if Gimp Front-end has
“Xsane: Device dialog.” on the “Acquire” menu. If not, you should install Xsane plug-in for Gimp on the your computer.
You can find Xsane plug-in package for
Gimp on Linux distribution CD or Gimp home page. For the detail information, refer to the Help for Linux distribution
CD or Gimp Front-end application.
If you wish to use other kind of scan application, refer to the Help for application.
Condition
I encounter error
“Cannot open port device file” when printing a document.
The printer does not print PDF file correctly.
Some parts of graphics, text, or illustrations are missing.
Suggested solutions
Please avoid changing print job parameters (via LPR GUI, for example) while a print job is in progress. Known versions of CUPS server break the print job whenever print options are changed and then try to restart the job from the beginning. Since Unified Linux Driver locks port while printing, the abrupt termination of the driver keeps the port locked and therefore unavailable for subsequent print jobs. If this situation occurred, please, try to release the port.
Incompatibility between the PDF file and the Acrobat products:
Printing the PDF file as an image may solve this problem. Turn on Print As
Image from the Acrobat printing options.
N OTE : It will take longer to print when you print a PDF file as an image.
Common Macintosh problems
Condition
The printer does not print
PDF file correctly. Some parts of graphics, text, or illustrations are missing.
Suggested solutions
Incompatibility between the PDF file and the Acrobat products:
Printing the PDF file as an image may solve this problem. Turn on Print As
Image from the Acrobat printing options.
N OTE : It will take longer to print when you print a PDF file as an image.
The document has printed, but the print job has not disappeared from the spooler in Mac OS
10.3.2.
Some letters are not displayed normally during the Cover page printing.
Update your Mac OS to OS 10.3.3. or higher.
This problem is caused because Mac
OS can not create the font during the
Cover page printing. English alphabet and numbers are displayed normally at the Cover page.
14.17
<Troubleshooting>
15
Specifications
This chapter includes:
•
•
•
Scanner and copier specifications
•
Facsimile specifications (CLX-3160FN only)
General specifications
ADF
Warm-up time
Operating environment
Display
Item
ADF document size
Paper input capacity
Paper output capacity
Power rating
Power consumption
Noise level a
Description
Up to 50 sheets (20 lb bond, 75 g/m 2 )
Width: 5.6 to 8.5 inches (142 to 216 mm)
Length: 5.8 to 14 inches (148 to 356 mm)
Tray 1: 150 multi-pages for plain paper
(20 lb bond, 75 g/m
2
), 1 page for label, card stock, transparency, and envelope (16 to
43 lb bond, 60 to 163 g/m
2
) manual feeder: 1 page for plain paper, label, card stock, transparency, and envelope (16 to 43 lb bond, 60 to 163 g/m
2
)
Optional tray 2: 250 multi pages for plain paper (16 to 24lb bond, 60 to 90 g/m
2
)
Output tray: 100 sheet (face down)
110 - 127 VAC / 220 - 240 VAC
For the hertz and current, see the Rating label on the machine.
Average: 350 W
Power save mode: Less than 30 W
Standby mode: Less than 35 dBA
Printing: Less than 49 dBA (color printing)
Less than 49 dBA (black and white printing)
Copying mode: Less than 52 dBA
Less than 35 seconds (from sleep mode)
Temperature: 59
(10 o
C to 32.5
o o
C)
F to 90.5
o
F
Humidity: 20% to 80% RH
16 characters x 2 lines
Item
Toner cartridge life b
Memory
External dimension
(W x D x H)
Weight
Package weight
Duty cycle
Description
Black
Color
2,000 pages at 5% Coverage
(Shipped with 1,500 pages Starter toner cartridge)
1,000 pages at 5% coverage
(Shipped with 700 pages Starter toner cartridge)
128 MB (Non extendable)
466 x 429 x 486 mm
(18.3 x 16.8 x 19.1 inches)
20.5 Kg (including consumables)
Paper: 3.3 Kg, Plastic: 0.6 Kg
Monthly print: Up to 24,200 images a. Sound Pressure Level, ISO 7779 b. The number of pages may be affected by operating environment, printing interval, media type, and media size.
Printer specifications
Item
Printing method
Printing speed
Print resolution
Printer language
Interface a
First print out time
OS Compatibility b
Description
Laser Beam Printing
Black &
White
Up to 16 ppm in A4
17 ppm in Letter
Color
Up to 4 ppm in A4 or Letter
Black &
White
Color
From ready: Less than 14 seconds
From coldboot: Less than 45 seconds
From ready: Less than 26 seconds
From coldboot: Less than 57 seconds
Up to 2,400 x 600 dpi effective output
SPL-C (Samsung Printer Language Color)
Windows 98/Me/2000/XP
Various Linux OS (USB only)
Macintosh 10.3 ~ 10.4
High Speed USB 2.0
Ethernet 10/100 Base TX (Embedded type) a. Print speed will be affected by operating system used, computing performance, application software, connecting method, media type, media size, and job complexity.
b. Please visit www.samsungprinter.com
to download the latest software version.
15.1
<Specifications>
Scanner and copier specifications
Item
Compatibility
Scanning method
Resolution
Description
TWAIN standard / WIA standard
ADF and Flat-bed Color CCD (Charge
Coupled Device) module
Optical: 600 x 1,200 dpi (mono and color)
Enhanced: 4,800 x 4,800 dpi
Scanner glass: 11.7 inches (297 mm)
ADF: 14 inches (356 mm)
Effective scanning length
Effective scanning width
Color bit depth
Max 8.2 inches (208 mm)
Mono bit depth
Copy speed a
Copy resolution
Zoom rate
Multiple copies
Grayscale
24 bit
1 bit for Linearity & Haftone
8 bit for Gray mode
Black & white
Color
Up to 16 ppm in A4 (17 ppm in
Letter)
Up to 4 cpm in A4 or Letter
Scan: up to 600 x 300 (text, text/photo)
up to 600 x 600 (photo using platen)
up to 600 x 300 (photo using ADF)
Print: up to 600 x 600 (text, text/photo) up to 1200 x 1200 (photo using platen) up to 600 x 600 (photo using ADF)
Scanner glass: 25 to 400%
ADF: 25 to 100%
1 to 99 pages
256 levels a. Copy Speed is based on Single Document Multiple Copy.
Facsimile specifications
(CLX-3160FN only)
Item
Compatibility
Applicable line
Description
ITU-T Group 3
Public Switched Telephone Network (PSTN) or behind PABX
MH/MR/MMR/JBIG/JPEG
33.6 Kbps
Data coding
Modem speed
Transmission speed
Approx. 3 seconds/page a
Maximum document length
Resolution
Memory
Halftone
Auto dialer
Scanner glass: 11.7 inches (297 mm)
Automatic document glass: 14 inches
(356 mm)
Standard: 203 x 98 dpi
Fine: 203 x 196 dpi
Super Fine: 300 x 300 dpi
Photo: 203 x 196 dpi
Color: 200 x 200 dpi
4 MB
256 levels
Speed buttons (up to 30 numbers)
Speed dialing (up to 240 numbers) a. Transmission time applies to memory transmission of text data with ECM compression using only ITU-T No.1 Chart.
15.2
<Specifications>
I
NDEX
Numerics
A accessories
Address Book
Ans/Fax mode, receiving mode 9.4
B
C
cleaning
copying
D
DRPD (Distinctive Ring Pattern Detection)
E
Erasing background, special copy 6.5
F
faxing
G
I
J jam, clear
1
K
L
loading originals
loading paper
M
N network scan
Network Scan program
network setup
new toner notification, send 13.6
n-up (multiple pages per sheet)
O originals
P
paper jam, clear
paper load
paper size
paper tray, set
paper type
print quality problems, solve 14.10
printing
problem, solve
R receiving a fax
redialing
replacing
S
scanner glass
scanning
sending a fax
special print media, guidelines 5.4
specifications
supplies
system requirements
T
toner cartridge
2
U
USB flash memory
V volume, adjust
W waste toner container
Samsung Printer
Software section
S
OFTWARE SECTION
C
ONTENTS
Chapter 1:
NSTALLING
P
RINTER
S
OFTWARE IN
W
INDOWS
Chapter 2:
ASIC
P
RINTING
Chapter 3:
DVANCED
P
RINTING
1
Chapter 4:
HARING THE P RINTER L OCALLY
Chapter 5:
SING S MART P ANEL
Chapter 6:
CANNING
Chapter 7:
SING Y OUR P RINTER IN L INUX
2
Chapter 8:
SING Y OUR P RINTER WITH A M ACINTOSH
3
1
Installing Printer
Software in Windows
This chapter includes:
• Reinstalling Printer Software
Installing Printer Software
You can install the printer software for local printing or network printing. To install the printer software on the computer, perform the appropriate installation procedure depending on the printer in use.
A printer driver is software that lets your computer communicate with your printer. The procedure to install drivers may differ depending on the operating system you are using.
All applications should be closed on your PC before beginning installation.
Installing Software for Local Printing
A local printer is a printer directly attached to your computer using the printer cable supplied with your printer, such as a USB or parallel cable. If your printer is attached to a network, skip
this step and go to “Installing Software for Network Printing” on page 7.
You can install the printer software using the typical or custom method.
N
OTE : If the “New Hardware Wizard” window appears during the installation procedure, click in the upper right corner of the box to close the window, or click Cancel.
Typical Installation
This is recommended for most users. All components necessary for printer operations will be installed.
1
Make sure that the printer is connected to your computer and powered on.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation window appears.
If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.
3
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe
Acrobat Reader for you.
4
Select Typical installation for a local printer. Click
Next.
4
Installing Printer Software in Windows
N
OTE : If your printer is not already connected to the computer, the following window will appear.
7
To register yourself as a user of Samsung Printers in order to receive information from Samsung, select the checkbox and click Finish. You are now sent to the Samsung web site.
Otherwise, just click Finish.
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click
Next, and No on the following screen. Then the installation will start and a test page will not be printed at the end of the installation.
• The installation window that appears in this User’s
Guide may differ depending on the printer and interface in use.
5
After the installation is finished, a window asking you to print a test page appears. If you choose to print a test page, select the checkbox and click Next.
Otherwise, just click Next and skip to step 7.
6
If the test page prints out correctly, click Yes.
If not, click No to reprint it.
N
OTE : After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Custom Installation
You can choose individual components to install.
1
Make sure that the printer is connected to your computer and powered on.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation window appears.
If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.
5
Installing Printer Software in Windows
3
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe
Acrobat Reader for you.
4
Select Custom installation. Click Next.
N
OTE : If your printer is not already connected to the computer, the following window will appear.
5
Select your printer and click Next.
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click
Next, and No on the following screen. Then the installation will start and a test page will not be printed at the end of the installation.
• The installation window that appears in this User’s
Guide may differ depending on the printer and interface in use.
6
Select the components to be installed and click Next.
N
OTE : You can change the desired installation folder by clicking [Browse].
7
After the installation is finished, a window asking you to print a test page appears. If you choose to print a test page, select the checkbox and click Next.
Otherwise, just click Next and skip to step 9.
8
If the test page prints out correctly, click Yes.
If not, click No to reprint it.
6
Installing Printer Software in Windows
9
To register yourself as a user of Samsung Printers in order to receive information from Samsung, select the checkbox and click Finish. You are now sent to the Samsung web site.
Otherwise, just click Finish.
If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.
Installing Software for Network
Printing
When you connect your printer to a network, you must first configure the TCP/IP settings for the printer. After you have assigned and verified the TCP/IP settings, you are ready to install the software on each computer on the network.
You can install the printer software using the typical or custom method.
Typical Installation
This is recommended for most users. All components necessary for printer operations will be installed.
1
Make sure that the printer is connected to your network and powered on. For details about connecting to the network, see the supplied printer’s User’s Guide.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation window appears.
3
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe
Acrobat Reader for you.
4
Select Typical installation for a network printer. Click
Next.
7
Installing Printer Software in Windows
5
The list of printers available on the network appears.
Select the printer you want to install from the list and then click Next.
N
OTE : After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Custom Installation
You can choose individual components to install and set a specific IP address.
1
Make sure that the printer is connected to your network and powered on. For details about connecting to the network, see the supplied printer’s User’s Guide.
2
Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation window appears.
If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.
• If you do not see your printer on the list, click Update to refresh the list, or select Add TCP/IP Port to add your printer to the network. To add the printer to the network, enter the port name and the IP address for the printer.
To verify your printer’s IP address or the MAC address, print a Network Configuration page.
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name manually or find a shared printer by clicking the Browse button.
N
OTE : To search the network printer, the firewall should be disabled.
6
After the installation is finished, a window appears asking you to print a test page and to register yourself as a user of Samsung Printers in order to receive information from
Samsung. If you so desire, select the corresponding checkbox(es) and click Finish.
Otherwise, just click Finish.
3
Click Next.
• If necessary, select a language from the drop-down list.
• View User’s Guide: Allows you to view the User’s
Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe
Acrobat Reader for you.
8
Installing Printer Software in Windows
4
Select Custom installation. Click Next.
T
IP : If you want to set a specific IP address on a specific network printer, click the Set IP Address button. The Set IP
Address window appears. Do as follows:
5
The list of printers available on the network appears.
Select the printer you want to install from the list and then click Next. a. Select a printer to be set with a specific IP address from the list.
b. Configure an IP address, subnet mask, and gateway for the printer manually and click Configure to set the specific IP address for the network printer.
c. Click Next.
6
Select the components to be installed. After selecting the components, the following window appears. You can also change the printer name, set the printer to be shared on the network, set the printer as the default printer, and change the port name of each printer. Click Next.
• If you do not see your printer on the list, click Update to refresh the list, or select Add TCP/IP Port to add your printer to the network. To add the printer to the network, enter the port name and the IP address for the printer.
To verify your printer’s IP address or the MAC address, print a Network Configuration page.
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name manually or find a shared printer by clicking the Browse button.
N
OTE : To search the network printer, the firewall should be disabled.
To install this software on a server, select the Setting up
this printer on a server checkbox.
7
After the installation is finished, a window appears asking you to print a test page and to register yourself as a user of Samsung Printers in order to receive information from
Samsung. If you so desire, select the corresponding checkbox(es) and click Finish.
9
Installing Printer Software in Windows
Otherwise, just click Finish.
network, enter the port name and the IP address for the printer.
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name manually or find a shared printer by clicking the Browse button.
You will see a component list so that you can reinstall any item individually.
N
OTE : If your printer is not already connected to the computer, the following window will appear.
N
OTE : After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Reinstalling Printer Software
You can reinstall the software if installation fails.
1
Start Windows.
2
From the Start menu select Programs or All Programs
→ your printer driver name → Maintenance.
3
Select Repair and click Next .
4
The list of printers available on the network appears.
Select the printer you want to install from the list and then click Next.
• If you do not see your printer on the list, click Update to refresh the list, or select Add TCP/IP Port to add your printer to the network. To add the printer to the
10
Installing Printer Software in Windows
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click
Next, and No on the following screen. Then the installation will start and a test page will not be printed at the end of the installation.
• The reinstallation window that appears in this User’s
Guide may differ depending on the printer and interface in use.
5
Select the components you want to reinstall and click
Next .
If you installed the printer software for local printing and you select your printer driver name, the window asking you to print a test page appears. Do as follows: a. To print a test page, select the check box and click
Next .
b. If the test page prints out correctly, click Yes.
If it doesn’t, click No to reprint it.
6
When the reinstallation is done, click Finish.
Removing Printer Software
1
Start Windows.
2
From the Start menu select Programs or All Programs
→ your printer driver name → Maintenance.
3
Select Remove and click Next.
You will see a component list so that you can remove any item individually.
4
Select the components you want to remove and then click
Next.
5
When your computer asks you to confirm your selection, click Yes.
The selected driver and all of its components are removed from your computer.
6
After the software is removed, click Finish.
11
Installing Printer Software in Windows
2
Basic Printing
This chapter explains the printing options and common printing tasks in Windows.
This chapter includes:
Printing a Document
N
OTES :
• Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
However the composition of the printer properties window is similar.
• Check the Operating System(s) that are compatible with your printer. Please refer to the OS Compatibility section of Printer Specifications in your Printer User’s
Guide.
• If you need to know the exact name of your printer, you can check the supplied CD-ROM.
The following procedure describes the general steps required for printing from various Windows applications. The exact steps for printing a document may vary depending on the application program you are using. Refer to the User’s Guide of your software application for the exact printing procedure.
1
Open the document you want to print.
2
Select Print from the File menu. The Print window is displayed. It may look slightly different depending on your application.
The basic print settings are selected within the Print window. These settings include the number of copies and print range.
Make sure that your printer is selected.
3
Select your printer driver from the Name drop-down list.
To take advantage of the printer features provided by your printer driver, click Properties or Preferences in the
application’s Print window. For details, see “Printer
If you see Setup, Printer, or Options in your Print window, click it instead. Then click Properties on the next screen.
Click OK to close the printer properties window.
4
To start the print job, click OK or Print in the Print window.
Printing to a file (PRN)
You will sometimes need to save the print data as a file for your purpose.
To create a file:
1
Check the Print to file box at the Print window.
2
Select the folder and assign a name of the file and then click OK.
12
Basic Printing
Printer Settings
You can use the printer properties window, which allows you to access all of the printer options you need when using your printer. When the printer properties are displayed, you can review and change the settings needed for your print job.
Your printer properties window may differ, depending on your operating system. This Software User’s Guide shows the
Properties window for Windows 98.
Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
If you access printer properties through the Printers folder, you can view additional Windows-based tabs (refer to your
Windows User’s Guide) and the Printer tab (see “Printer Tab” on page 16).
N
OTES :
• Most Windows applications will override settings you specify in the printer driver. Change all print settings available in the software application first, and change any remaining settings using the printer driver.
• The settings you change remain in effect only while you are using the current program. To make your changes
permanent, make them in the Printers folder.
• The following procedure is for Windows XP. For other
Windows OS, refer to the corresponding Windows User's
Guide or online help.
1. Click the Windows Start button.
2. Select Printers and Faxes.
3. Select your printer driver icon.
4. Right-click on the printer driver icon and select
Printing Preferences.
5. Change the settings on each tab, click OK.
Layout Tab
The Layout tab provides options to adjust how the document appears on the printed page. The Layout Options includes
Multiple Pages per Side, Poster Printing and Booklet
Printing . See “Printing a Document” on page 12 for more
information on accessing printer properties.
Paper Orientation
Paper Orientation allows you to select the direction in which information is printed on a page.
• Portrait prints across the width of the page, letter style.
• Landscape prints across the length of the page, spreadsheet style.
• Rotate 180 Degrees allows you to rotate the page, 180 degrees.
13
Basic Printing
Portrait
Landscape
Layout Options
Layout Options allows you to select advanced printing options.
You can choose Multiple Pages per Side, Poster Printing and
Booklet Printing.
• For details, see “Printing Multiple Pages on One Sheet of Paper
• For details, see “Printing Posters” on page 19.
• For details, see “Printing Booklets” on page 19.
Double-sided Printing
Double-sided Printing allows you to print on both sides of paper. If this option does not appear, your printer does not have this feature.
• For details, see “Printing on Both Sides of Paper” on page 20.
Paper Tab
Use the following options to set the basic paper handling specifications when you access the printer properties. See
“Printing a Document” on page 12 for more information on
accessing printer properties.
Click the Paper tab to access various paper properties.
Copies
Copies allows you to choose the number of copies to be printed.
You can select 1 to 999 copies.
Size
Size allows you to set the size of paper you loaded in the tray.
If the required size is not listed in the Size box, click Custom.
When the Custom Paper Setting window appears, set the paper size and click OK. The setting appears in the list so that you can select it.
Source
Make sure that Source is set to the corresponding paper tray.
Use Manual Feeder when printing on special materials like envelopes and transparencies. You have to load one sheet at a time into the Manual Tray or Multi-Purpose Tray.
If the paper source is set to Auto Selection, the printer automatically picks up print material in the following tray order:
Manual Tray or Multi-Purpose Tray, Tray n.
Type
Set Type to correspond to the paper loaded in the tray from which you want to print. This will let you get the best quality printout. If not, print quality may not be acheived as you want.
Thin: Less than 19 lb (70 g/m
2
) thin paper.
Thick: 24 lb to 32 ib (90~ 120 g/m
2
) thick paper.
Cotton: 20 lb to 24 lb (75~90 g/m
2
) cotton paper such as Gilbert
25 % and Gilbert 100 %.
Plain Paper: Normal plain paper. Select this type if your printer is monochrome and printing on the 16 lb (60 g/m 2) cotton paper.
Recycled Paper: 20 lb to 24 lb (75~90 g/m 2 ) recycled paper.
Color Paper: 20 lb to 24 lb (75~90 g/m 2 ) color-backgrounded paper.
First Page
This property allows you to print the first page using a different paper type from the rest of the document. You can select the paper source for the first page.
For example, load thick stock for the first page into the Multipurpose Tray, and plain paper into Tray n. Then, select Tray n in the
Source
option and Multi-Purpose Tray in the First Page option.
Scaling Printing
Scaling Printing allows you to automatically or manually scale your print job on a page. You can choose from None, Reduce/
Enlarge, and Fit to Page.
• For details, see “Printing a Reduced or Enlarged Document” on page 20.
• For details, see “Fitting Your Document to a Selected Paper
14
Basic Printing
Graphics Tab
Use the following Graphic options to adjust the print quality for
Click the Graphic tab to display the properties shown below..
Advanced Options
You can set advanced settings by clicking the Advanced
Options button.
• TrueType Options: This option determines what the driver tells the printer about how to image the text in your document.
Select the appropriate setting according to the status of your document. This option may be available only in
Windows 9x/Me, depending on your particular printer model.
- Download as Bitmap: When this option is selected, the driver will download the font data as bitmap images.
Documents with complicated fonts, such as Korean or
Chinese, or various other fonts, will print faster in this setting.
- Print as Graphics: When this option is selected, the driver will download any fonts as graphics. When printing documents with high graphic content and relatively few TrueType fonts, printing performance (speed) may be enhanced in this setting.
• Print All Text To Black: When the Print All Text To Black option is checked, all text in your document prints solid black, regardless of the color it appears on the screen.
• Print All Text To Darken: When the Print All Text To Darken option is checked, all text in your document is allowed to print darker than on a normal document. Some printers do not support this feature.
Quality
The Resolution options you can select may vary depending on your printer model.
The higher the setting, the sharper the clarity of printed characters and graphics. The higher setting also may increase the time it takes to print a document.
Color Mode
You can choose color options. Setting to Color typically produces the best possible print quality for color documents. If you want to print a color document in grayscale, select Grayscale. If you want to adjust the color options manually, select Manual and click the Color Adjust or Color Matching button.
• Color Adjust : You can adjust the appearance of images by changing the settings in the Levels option.
• Color Matching : You can adjust the appearance of images by changing the settings in the Settings option.
15
Basic Printing
Extras Tab
the printer properties.
Click the Extras tab to access the following feature:
About Tab
Use the About tab to display the copyright notice and the version number of the driver. If you have an Internet browser, you can connect to the Internet by clicking on the web site icon.
See “Printing a Document” on page 12 for more information
about accessing printer properties.
Printer Tab
If you access printer properties through the Printers folder, you can view the Printer tab. You can set the printer configuration.
The following procedure is for Windows XP. For other Windows
OS, refer to the corresponding Windows User's Guide or online help.
1
Click the Windows Start menu.
2
Select Printers and Faxes.
3
Select your printer driver icon.
4
Right-click on the printer driver icon and select
Properties.
5
Click the Printer tab and set the options.
Watermark
You can create a background text image to be printed on each
page of your document. For details, see “Using Watermarks” on page 21.
Overlay
Overlays are often used to take the place of preprinted forms and
letterhead paper. For details, see “Using Overlays” on page 22.
Output Options
• Print Subset: You can set the sequence in which the pages print. Select the print order from the drop-down list.
- Normal (1,2,3): Your printer prints all pages from the first page to the last page.
- Reverse All Pages (3,2,1): Your printer prints all pages from the last page to the first page.
- Print Odd Pages: Your printer prints only the odd numbered pages of the document.
- Print Even Pages: Your printer prints only the even numbered pages of the document.
16
Basic Printing
Using a Favorite Setting
The Favorites option, which is visible on each properties tab, allows you to save the current properties settings for future use.
To save a Favorites item:
1
Change the settings as needed on each tab.
2
Enter a name for the item in the Favorites input box.
3
Click Save.
When you save Favorites, all current driver settings are saved.
To use a saved setting, select the item from the Favorites drop down list. The printer is now set to print according to the
Favorites setting you selected.
To delete a Favorites item, select it from the list and click
Delete.
You can also restore the printer driver’s default settings by selecting Printer Default from the list.
Using Help
Your printer has a help screen that can be activated by clicking the Help button in the printer properties window. These help screens give detailed information about the printer features provided by the printer driver.
You can also click from the upper right corner of the window, and then click on any setting.
17
Basic Printing
3
Advanced Printing
This chapter explains printing options and advanced printing tasks.
N
OTE :
• Your printer driver Properties window that appears in this
User’s Guide may differ depending on the printer in use.
However the composition of the printer properties window is similar.
• If you need to know the exact name of your printer, you can check the supplied CD-ROM.
This chapter includes:
• Printing Multiple Pages on One Sheet of Paper (N-Up
• Printing on Both Sides of Paper
• Printing a Reduced or Enlarged Document
• Fitting Your Document to a Selected Paper Size
1 2
3 4
Printing Multiple Pages on One
Sheet of Paper (N-Up Printing)
You can select the number of pages to print on a single sheet of paper. To print more than one page per sheet, the pages will be reduced in size and arranged in the order you specify. You can print up to 16 pages on one sheet.
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
From the Layout tab, choose Multiple Pages per Side in the Layout Type drop-down list.
3
Select the number of pages you want to print per sheet
(1, 2, 4, 6, 9, or 16) in the Pages per Side drop-down list.
4
Select the page order from the Page Order drop-down list, if necessary.
Check Print Page Border to print a border around each page on the sheet.
5
Click the Paper tab, select the paper source, size, and type.
6
Click OK and print the document.
18
Advanced Printing
Printing Posters
This feature allows you to print a single-page document onto 4,
9, or 16 sheets of paper, for the purpose of pasting the sheets together to form one poster-size document.
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
Click the Layout tab, select Poster Printing in the
Layout Type drop-down list.
3
Configure the poster option:
You can select the page layout from Poster<2x2>,
Poster<3x3>, or Poster<4x4>. If you select
Poster<2x2>, the output will be automatically stretched to cover 4 physical pages.
Printing Booklets
9
8
9 8
This printer feature allows you to print your document on both sides of the paper and arranges the pages so that the paper can be folded in half after printing to produce a booklet.
1
To change the print settings from your software
application, access the printer properties. See “Printing a
2
From the Layout tab, choose Booklet Printing from the
Type drop-down list.
N
OTE : The booklet printing option is available when A4,
Letter, Legal, or Folio size is selected in the Size option on the
Paper tab.
3
Click the Paper tab, and select the paper source, size, and type.
4
Click OK and print the document.
5
After printing, fold and staple the pages.
Specify an overlap in millimeters or inches to make it easier to pasting the sheets together.
0.15 inches
0.15 inches
4
Click the Paper tab, select the paper source, size, and type.
5
Click OK and print the document. You can complete the poster by pasting the sheets together.
19
Advanced Printing
Printing on Both Sides of Paper
You can print on both sides of a sheet of paper. Before printing, decide how you want your document oriented.
The options are:
• None
• Long Edge , which is the conventional layout used in book binding.
• Short Edge , which is the type often used with calendars.
2
2
2
3
5
â–² Long Edge
5
3
3
5 2
5
3
â–² Short Edge
N
OTE :
• Do not print on both sides of labels, transparencies, envelopes, or thick paper. Paper jamming and damage to the printer may result.
• To use double-sided printing, you can use only the following paper sizes: A4, Letter, Legal, and Folio, with a weight of
20~24 lbs (75~90 g/m²).
1
To change the print settings from your software
application, access printer properties. “Printing a
2
From the Layout tab, select the paper orientation.
3
From the Double-sided Printing section, select the binding option you want.
4
Click the Paper tab and select the paper source, size, and type.
5
Click OK and print the document.
N
OTE : If your printer does not have a duplex unit, you should complete the printing job manually. The printer prints every other page of the document first. After printing the first side of your job, the Printing Tip window appears. Follow the onscreen instructions to complete the printing job.
A
Printing a Reduced or Enlarged
Document
You can change the size of a page’s content to appear larger or smaller on the printed page.
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
From the Paper tab, select Reduce/Enlarge in the
Printing Type drop-down list.
3
Enter the scaling rate in the Percentage input box.
You can also click the or button.
4
Select the paper source, size, and type in Paper Options.
5
Click OK and print the document.
Fitting Your Document to a
Selected Paper Size
This printer feature allows you to scale your print job to any selected paper size regardless of the digital document size. This can be useful when you want to check fine details on a small document.
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
From the Paper tab, select Fit to Page in the Printing
Type drop-down list.
3
Select the correct size from the Output size drop-down list.
4
Select the paper source, size, and type in Paper Options.
5
Click OK and print the document.
20
Advanced Printing
Using Watermarks
The Watermark option allows you to print text over an existing document. For example, you may want to have large gray letters reading “DRAFT” or “CONFIDENTIAL” printed diagonally across the first page or all pages of a document.
There are several predefined watermarks that come with the printer, and they can be modified, or you can add new ones to the list.
Using an Existing Watermark
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
Click the Extras tab, and select the desired watermark from the Watermark drop-down list. You will see the selected watermark in the preview image.
3
Click OK and start printing.
N
OTE : The preview image shows how the page will look when it is printed.
Creating a Watermark
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
Click the Extras tab, and click the Edit button in the
Watermark section. The Edit Watermarks window appears.
3
Enter a text message in the Watermark Message box.
You can enter up to 40 characters. The message displays in the preview window.
When the First Page Only box is checked, the watermark prints on the first page only.
4
Select watermark options.
You can select the font name, style, size, or grayscale level from the Font Attributes section and set the angle of the watermark from the Message Angle section.
5
Click Add to add a new watermark to the list.
6
When you have finished editing, click OK and start printing.
To stop printing the watermark, select (No Watermark) from the Watermark drop-down list.
Editing a Watermark
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
Click the Extras tab and click the Edit button in the
Watermark section. The Edit Watermarks window appears.
3
Select the watermark you want to edit from the Current
Watermarks list and change the watermark message and options.
4
Click Update to save the changes.
5
Click OK until you exit the Print window.
Deleting a Watermark
1
To change the print settings from your software
application, access printer properties. See “Printing a
2
From the Extras tab, click the Edit button in the
Watermark section. The Edit Watermarks window appears.
3
Select the watermark you want to delete from the Current
Watermarks list and click Delete.
4
Click OK until you exit the Print window.
21
Advanced Printing
Dear ABC
Regards
WORLD BEST
WORLD BEST
Using Overlays
What is an Overlay?
An overlay is text and/or images stored in the computer hard disk drive (HDD) as a special file format that can be printed on any document. Overlays are often used to take the place of preprinted forms and letterhead paper. Rather than using preprinted letterhead, you can create an overlay containing the exact same information that is currently on your letterhead. To print a letter with your company’s letterhead, you do not need to load preprinted letterhead paper in the printer. You need only tell the printer to print the letterhead overlay on your document.
Creating a New Page Overlay
To use a page overlay, you must create a new page overlay containing your logo or image.
1
Create or open a document containing text or an image for use in a new page overlay. Position the items exactly as you wish them to appear when printed as an overlay.
2
To save the document as an overlay, access printer
properties. See “Printing a Document” on page 12.
3
Click the Extras tab, and click Edit button in the Overlay section.
4
In the Edit Overlay window, click Create Overlay.
5
In the Create Overlay window, type a name of up to eight characters in the File name box. Select the destination path, if necessary. (The default is C:\Formover).
6
Click Save. The name appears on the Overlay List box.
7
Click OK or Yes to finish creating.
The file is not printed. Instead it is stored on your computer hard disk drive.
N
OTE : The overlay document size must be the same as the documents you print with the overlay. Do not create an overlay with a watermark.
Using a Page Overlay
After an overlay has been created, it is ready to be printed with your document. To print an overlay with a document:
1
Create or open the document you want to print.
2
To change the print settings from your software
application, access printer properties. See “Printing a
3
Click the Extras tab.
4
Select the desired overlay from the Overlay drop-down list box.
5
If the overlay file you want does not appear in the
Overlay list, click Edit button and Load Overlay, and select the overlay file.
If you have stored the overlay file you want to use in an external source, you can also load the file when you access the Load Overlay window.
After you select the file, click Open. The file appears in the
Overlay List box and is available for printing. Select the overlay from the Overlay List box.
6
If necessary, click Confirm Page Overlay When
Printing. If this box is checked, a message window appears each time you submit a document for printing, asking you to confirm your wish to print an overlay on your document.
If this box is not checked and an overlay has been selected, the overlay automatically prints with your document.
7
Click OK or Yes until printing begins.
The selected overlay downloads with your print job and prints on your document.
N
OTE : The resolution of the overlay document must be the same as that of the document you will print with the overlay.
Deleting a Page Overlay
You can delete page overlays that you no longer use.
1
In the printer properties window, click the Extras tab.
2
Click the Edit button in the Overlay section.
3
Select the overlay you want to delete from the Overlay
List box.
4
Click Delete Overlay.
5
When a confirming message window appears, click Yes.
6
Click OK until you exit the Print window.
22
Advanced Printing
4
Sharing the Printer
Locally
You can connect the printer directly to a selected computer, which is called “host computer,” on the network.
The following procedure is for Windows XP. For other Windows
OS, refer to the corresponding Windows User's Guide or online help.
N
OTES :
• Check the Operating System(s) that are compatible with your printer. Please refer to the OS Compatibility section of
Printer Specifications in your Printer User’s Guide.
• If you need to know the exact name of your printer, you can check the supplied CD-ROM.
Setting Up a Host Computer
1
Start Windows.
2
From the Start menu select Printers and Faxes.
3
Double-click your printer driver icon.
4
From the Printer menu, select Sharing.
5
Check the Share this printer box.
6
Fill in the Shared Name field, and then click OK.
Setting Up a Client Computer
1
Right-click the Windows Start button and select Explorer.
2
Open your network folder in the left column.
3
Click the shared name.
4
From the Start menu select Printers and Faxes.
5
Double-click your printer driver icon.
6
From the Printer menu, select Properties.
7
From the Ports tab, click Add Port.
8
Select Local Port and click New Port.
9
Fill in the Enter a port name field with the shared name.
10
Click OK and click Close.
11
Click Apply and click OK.
23
Sharing the Printer Locally
5
Using Smart Panel
Smart Panel is a program that monitors and informs you of the status of the printer, and allows you to customize the printer’s settings. Smart Panel is installed automatically when you install the printer software.
N
OTES :
• To use this program, you need:
- Windows 98 or higher To check for Operating System(s) that are compatible with your printer, refer to Printer
Specifications in your Printer User’s Guide.
- Mac OS X 10.3 or higher
- Linux. To check for Linux systems that are compatible with your printer, refer to Printer Specifications in your Printer
User’s Guide.
- Internet Explorer version 5.0 or higher for flash animation in HTML Help.(Only for Windows)
• If you need to know the exact name of your printer, you can check the supplied CD-ROM.
Understanding Smart Panel
If an error occurs while printing, Smart Panel appears automatically, showing the error.
You can also launch Smart Panel manually. Double-click the
Smart Panel icon on the Windows task bar (in Windows), or
Notification Area (in Linux). You can also click it on the status bar (in Mac OS X).
Double-click this icon in Windows.
Click this icon in Mac OS X.
Click this icon in Linux.
24
Using Smart Panel
If you are a Windows user, from the Start menu, select
Programs or All Programs → your printer driver name →
Smart Panel.
N
OTES :
• If you have already installed more than one Samsung printer, first select the printer model you want in order to use the corresponding Smart Panel. Right-click (in Windows or Linux) or click (in Mac OS X) the Smart Panel icon and select your printer name.
• The Smart Panel window and its contents shown in this
Software User’s Guide may differ depending on the printer or Operating System in use.
The Smart Panel program displays the current status of the printer, the level of toner remaining in the toner cartridge(s) and various other information. You can also change settings.
1
2
4
5
3
1
Toner Level
You can view the level of toner remaining in the toner cartridge(s). The printer and the number of toner cartridge(s) shown in the above window may differ depending on the printer in use. Any printers do not have this feature.
2 Buy Now
You can order replacement toner cartridge(s) online.
3 Troubleshooting Guide
You can view Help to solve problems.
4 Printer Setting
You can configure various printer settings in the Printer Settings
Utility window. Any printers do not have this feature.
N
OTE : If your printer is connected to a network and you are a
Windows user, the SyncThru Web Service window appears instead of the Printer Settings Utility window. Mac OS X and
Linux do not support network environments.
5 Driver Setting (Only for Windows)
You can use the printer properties window, which allows you to access all of the printer options you need for using your
printer. For details, See “Printer Settings” on page 13.
Opening the Troubleshooting
Guide
Using the troubleshooting guide, you can view solutions for error status problems.
Right-click (in Windows or Linux) or click (in Mac OS X) the
Smart Panel icon and select Troubleshooting Guide.
Using Printer Settings Utility
Using the Printer Settings Utility, you can configure and check print settings.
1
Right-click (in Windows or Linux) or click (in Mac OS X) the
Smart Panel icon and select Printer Setting.
2
Change the settings.
3
To send the changes to the printer, click the Apply button.
N
OTES : If your printer is connected to a network, the
SyncThru Web Service window appears instead of the
Printer Settings Utility window.
Using Onscreen Help File
For more information about Printer Settings Utility, click .
Changing the Smart Panel
Program Settings
Right-click (in Windows or Linux) or click (in Mac OS X) the
Smart Panel icon and select Options.
The following window opens.
• Display when job is finished for network printer: The computer shows the Smart Panel popup window or balloon when your job is complete in Windows. (Only for
Windows network-supported printers.)
• Display when error occurs during printing: The computer shows the Smart Panel popup window or balloon when an error occurs during printing.
• Display with: You can select how the computer shows you a message. If you select Popup window (smart
panel), the message appears in the Smart Panel popup window in Windows and Mac OS X.
• Launch Job Monitor when the job is saved in the
printer: If you store print jobs on the printer’s hard disk, the computer opens the Job Monitor window in Windows.
(Only for Windows network-supported printers with built-in hard disks.)
• Schedule an automatic status checking every: The computer updates the printer status regularly. Setting the value close to 1 second causes the computer to check the printer status more frequently, thereby allowing a faster response to any printer error.
25
Using Smart Panel
6
Scanning
Scanning with your machine lets you turn pictures and text into digital files on your computer. Then you can fax or e-mail the files, display them on your web site or use them to create projects that you can print using Samsung SmarThru software or the WIA driver.
This chapter includes:
• Scanning Using Samsung SmarThru
• Scanning Process with TWAIN-enabled Software
• Scanning Using the WIA Driver
N
OTES :
• Check the Operating System(s) that are compatible with your printer. Please refer to the OS Compatibility section of Printer Specifications in your Printer User’s
Guide.
• You can check your printer name in the supplied CD-
ROM.
• The maximum resolution that can be achieved depends upon various factors, including computer speed, available disk space, memory, the size of the image being scanned, and bit depth settings. Thus, depending on your system and what you are scanning, you may not be able to scan at certain resolutions, especially using enhanced dpi.
Scanning Using Samsung
SmarThru
Samsung SmarThru is the accompanying software for your machine. With SmarThru, scanning is the proverbial piece of cake.
N
OTE : You can use SmarThru 4 in Windows 98 or higher.
Uninstalling Samsung SmarThru
N
OTE : Before beginning uninstallation, ensure that all applications are closed on your computer.
1
From the Start menu, select Programs.
2
Select SmarThru 4, and then select Uninstall SmarThru
4.
3
When your computer asks you to confirm, click OK.
4
Click Finish.
You may be prompted to restart your computer. In this case you must shut the computer down and then restart it before the changes will be saved.
26
Scanning
Using Samsung SmarThru
Follow these steps to start scanning using the SmarThru:
1
Make sure that your machine and computer are turned on and properly connected to each other.
2
Place your photograph or page on the document glass or ADF.
3
Once you have installed Samsung SmarThru, you will see the SmarThru 4 icon on your desktop. Double-click the
SmarThru 4 icon.
Double-click this icon.
The SmarThru 4 window opens.
Make sure that your printer is selected.
•Scan To
Allows you to scan an image and save it to an application or folder, email it, or publish it on a web site.
•Image
Allows you to edit an image you have saved as a graphic file and send it to a selected application or folder, email it, or publish it on a web site.
•Copy
Allows you to produce professional quality copies. You can make black and white or color copies of an image if your machine supports it, and customize the copy settings.
Allows you to print images you have saved. You can print images in black and white or color mode if your machine supports it.
•Fax
Allows you to fax images or files you have saved on your computer. This is available when your machine supports the fax feature.
4
Click Scan To. The Scan To menu bar appears on the
SmarThru 4 window.
Scan To menu bar
Adjust the scan settings.
Click to start scanning.
Scan To lets you use the following services:
•Application
Scanning an image and placing it in an image editor application, such as Paint or Adobe Photoshop.
Scanning an image and emailing it. Allows you to scan an image, preview it, and email it.
N
OTE : To send an image by e-mail, you must have a mail client program, like Outlook Express, which has been set up with your e-mail account.
•Folder
Scanning an image and saving it to a folder. Allows you to scan an image, preview it, and save it to the folder of your choice.
•OCR
Scanning an image and performing text recognition.
Allows you to scan an image, preview it, and send it to the
OCR program for text recognition.
- Recommended Scan Option for OCR
- Resolution: 200 or 300 dpi
- Image Type: Grayscale or Black & White
•Web
Scanning an image, previewing it, and publishing it on a web site, using the specified file format for the image you want to publish.
27
Scanning
•Settings
Customizing settings of Scan To basic functions. Allows you to customize settings for Application, E-mail, OCR, and Web functions.
5
Click the service icon according to your job.
6
SmarThru 4 opens for the selected service. Adjust the scan settings.
7
To start scanning, click Scan.
N
OTE : If you want to cancel the scan job, click Cancel.
Using Onscreen Help File
For more information about SmarThru, click at the top right corner of the window. The SmarThru Help window opens and allows you to view onscreen help supplied on the SmarThru program.
Scanning Process with TWAINenabled Software
If you want to scan documents using other software, you will need to use TWAIN-compliant software, such as Adobe
PhotoDeluxe or Adobe Photoshop. The first time you scan with your machine, select it as your TWAIN source in the application you use.
The basic scanning process involves a number of steps:
1
Make sure that your machine and computer are turned on and properly connected to each other.
2
Load the document(s) face up into the ADF.
OR
Place a single document face down on the document glass.
3
Open an application, such as PhotoDeluxe or Photoshop.
4
Open the TWAIN window and set the scan options.
5
Scan and save your scanned image.
N
OTE : You need to follow the program’s instructions for acquiring an image. Please refer to the user’s guide of the application.
Scanning Using the WIA Driver
Your machine also supports the Windows Image Acquisition
(WIA) driver for scanning images. WIA is one of the standard components provided by Microsoft  Windows  XP and works with digital cameras and scanners. Unlike the TWAIN driver, the WIA driver allows you to scan and easily manipulate images without using additional software.
N
OTE : The WIA driver works only on Windows XP with USB port.
1
Load the document(s) face up into the ADF.
OR
Place a single document face down on the document glass.
2
From the Start menu on your desktop window, select
Settings, Control Panel, and then Scanners and
Cameras.
3
Double click your scanner driver icon. The Scanner and
Camera Wizard launches.
4
Choose your scanning preferences and click Preview to see how your preferences affect the picture.
5
Click Next.
6
Enter a picture name, and select a file format and destination to save the picture.
7
Follow the on-screen instructions to edit the picture after it is copied to your computer.
N
OTE : If you want to cancel the scan job, press the Cancel button on the Scanner and Camera Wizard.
28
Scanning
7
Using Your Printer in
Linux
You can use your machine in a Linux environment.
This chapter includes:
• Installing the Unified Linux Driver
• Using the Unified Driver Configurator
• Configuring Printer Properties
Getting Started
The supplied CD-ROM provides you with Samsung’s Unified
Linux Driver package for using your machine with a Linux computer.
Samsung’s Unified Linux Driver package contains printer and scanner drivers, providing the ability to print documents and scan images. The package also delivers powerful applications for configuring your machine and further processing of the scanned documents.
After the driver is installed on your Linux system, the driver package allows you to monitor a number of machine devices via fast ECP parallel ports and USB simultaneously.
The acquired documents can then be edited, printed on the same local or network machine devices, sent by e-mail, uploaded to an FTP site, or transferred to an external OCR system.
The Unified Linux Driver package is supplied with a smart and flexible installation program. You don't need to search for additional components that might be necessary for the Unified
Linux Driver software: all required packages will be carried onto your system and installed automatically; this is possible on a wide set of the most popular Linux clones.
Installing the Unified Linux
Driver
Installing the Unified Linux Driver
1
Make sure that you connect your machine to your computer. Turn both the computer and the machine on.
2
When the Administrator Login window appears, type in
root
in the Login field and enter the system password.
N
OTE : You must log in as a super user (root) to install the printer software. If you are not a super user, ask your system administrator.
3
Insert the printer software CD-ROM. The CD-ROM will automatically run.
If the CD-ROM does not automatically run, click the icon at the bottom of the desktop. When the Terminal screen appears, type in:
If the CD-ROM is secondary master and the location to mount is /mnt/cdrom,
[root@localhost root]#mount -t iso9660 /dev/hdc /mnt/ cdrom
[root@localhost root]#cd /mnt/cdrom/Linux
[root@localhost root]#./install.sh
N
OTE : The installation program runs automatically if you have an autorun software package installed and configured.
4
When the welcome screen appears, click Next.
29
Using Your Printer in Linux
5
When the installation is complete, click Finish.
The installation program has added the Unified Driver
Configurator desktop icon and Samsung Unified Driver group to the system menu for your convenience. If you have any difficulties, consult the onscreen help that is available through your system menu or can otherwise be called from the driver package windows applications, such as Unified Driver Configurator or Image
Manager.
Uninstalling the Unified Linux Driver
1
When the Administrator Login window appears, type in
root
in the Login field and enter the system password.
N
OTE : You must log in as a super user (root) to install the printer software. If you are not a super user, ask your system administrator.
2
Insert the printer software CD-ROM. The CD-ROM will automatically run.
If the CD-ROM does not automatically run, click the icon at the bottom of the desktop. When the Terminal screen appears, type in:
If the CD-ROM is secondary master and the location to mount is /mnt/cdrom,
[root@localhost root]#mount -t iso9660 /dev/hdc /mnt/ cdrom
[root@localhost root]#cd /mnt/cdrom/Linux
[root@localhost root]#./uninstall.sh
N
OTE : The installation program runs automatically if you have an autorun software package installed and configured.
3
Click Uninstall.
4
Click Next.
30
Using Your Printer in Linux
5
Click Finish.
Using the Unified Driver
Configurator
Unified Linux Driver Configurator is a tool primarily intended for configuring Printer or MFP devices. Since an MFP device combines the printer and scanner, the Unified Linux Driver
Configurator provides options logically grouped for printer and scanner functions. There is also a special MFP port option responsible for the regulation of access to an MFP printer and scanner via a single I/O channel.
After installing the Unified Linux driver, the Unified Linux Driver
Configurator icon will automatically be created on your desktop.
Opening the Unified Driver
Configurator
1
Double-click Unified Driver Configurator on the desktop.
You can also click the Startup Menu icon and select
Samsung Unified Driver and then Unified Driver
Configurator.
2
Press each button on the Modules pane to switch to the corresponding configuration window.
Printers Configuration button
Scanners Configuration button
Ports Configuration button
Printers Configuration
Printers configuration has the two tabs: Printers and Classes.
Printers Tab
You can see the current system’s printer configuration by clicking on the printer icon button on the left side of the Unified
Driver Configurator window.
Switches to Printer configuration.
Shows all of the installed printer.
Shows the status, model name and
URI of your printer.
You can use the following printer control buttons:
• Refresh: renews the available printers list.
• Add Printer: allows you to add a new printer.
• Remove Printer: removes the selected printer.
• Set as Default: sets the current printer as a default printer.
• Stop/Start: stops/starts the printer.
• Test: allows you to print a test page to check if the machine is working properly.
• Properties: allows you to view and change the printer
properties. For details, see page 33.
You can use the onscreen help by clicking Help.
3
After changing the configurations, click Exit to close the
Unified Driver Configurator.
31
Using Your Printer in Linux
Classes Tab
The Classes tab shows a list of available printer classes.
Ports Configuration
In this window, you can view the list of available ports, check the status of each port and release a port that is stalled in busy state when its owner is terminated for any reason.
Shows all of the printer classes.
Shows the status of the class and the number of printers in the class.
• Refresh : Renews the classes list.
• Add Class... : Allows you to add a new printer class.
• Remove Class : Removes the selected printer class.
Scanners Configuration
In this window, you can monitor the activity of scanner devices, view a list of installed Samsung MFP devices, change device properties, and scan images.
Switches to
Scanners configuration.
Shows all of the installed scanners.
Shows the vendor, model name and type of your scanner.
• Properties... : Allows you to change the scan properties
and scan a document. See page 34.
• Drivers... : Allows you to monitor the activity of the scan drivers.
32
Using Your Printer in Linux
Switches to ports configuration.
Shows the port type, device connected to the port and status
Shows all of the available ports.
• Refresh : Renews the available ports list.
• Release port : Releases the selected port.
Sharing Ports Between Printers and Scanners
Your machine may be connected to a host computer via the parallel port or USB port. Since the MFP device contains more than one device (printer and scanner), it is necessary to organize proper access of “consumer” applications to these devices via the single I/O port.
The Samsung Unified Linux Driver package provides an appropriate port sharing mechanism that is used by Samsung printer and scanner drivers. The drivers address their devices via so-called MFP ports. The current status of any MFP port can be viewed via the Ports Configuration. The port sharing prevents you from accessing one functional block of the MFP device, while another block is in use.
When you install a new MFP device onto your system, it is strongly recommended you do this with the assistance of an
Unified Driver Configurator. In this case you will be asked to choose I/O port for the new device. This choice will provide the most suitable configuration for MFP’s functionality. For MFP scanners I/O ports are being chosen by scanner drivers automatically, so proper settings are applied by default.
Configuring Printer Properties
Using the properties window provided by the Printers configuration, you can change the various properties for your machine as a printer.
1
Open the Unified Driver Configurator.
If necessary, switch to Printers configuration.
2
Select your machine on the available printers list and click
Properties.
3
The Printer Properties window opens.
Printing a Document
Printing from Applications
There are a lot of Linux applications that you are allowed to print from using Common UNIX Printing System (CUPS). You can print on your machine from any such application.
1
From the application you are using, select Print from the
File menu.
2
Select Print directly using lpr.
3
In the LPR GUI window, select the model name of your machine from the Printer list and click Properties.
Click.
The following five tabs display at the top of the window:
•General: allows you to change the printer name, location and description. The name entered in this tab displays on the printer list in Printers configuration.
•Connection: allows you to view or select another port. If you change the printer port from USB to parallel or vice versa while in use, you must re-configure the printer port in this tab.
•Driver: allows you to view or select another printer driver. By clicking Options, you can set the default device options.
•Jobs: shows the list of print jobs. Click Cancel job to cancel the selected job and select the Show completed
jobs check box to see previous jobs on the job list.
•Classes: shows the class that your printer is in. Click
Add to Class to add your printer to a specific class or click Remove from Class to remove the printer from the selected class.
4
Click OK to apply the changes and close the Printer
Properties Window.
4
Change the printer and print job properties.
33
Using Your Printer in Linux
The following four tabs display at the top of the window.
•General - allows you to change the paper size, the paper type, and the orientation of the documents, enables the duplex feature, adds start and end banners, and changes the number of pages per sheet.
•Text - allows you to specify the page margins and set the text options, such as spacing or columns.
•Graphics - allows you to set image options that are used when printing images/files, such as color options, image size, or image position.
•Device: allows you to set the print resolution, paper source, and destination.
5
Click Apply to apply the changes and close the Properties window.
6
Click OK in the LPR GUI window to start printing.
7
The Printing window appears, allowing you to monitor the status of your print job.
To abort the current job, click Cancel.
Printing Files
You can print many different types of files on the Samsung machine device using the standard CUPS way - directly from the command line interface. The CUPS lpr utility allows you do that. But the drivers package replaces the standard lpr tool by a much more user-friendly LPR GUI program.
To print any document file:
1
Type
lpr <file_name>
from the Linux shell command line and press Enter. The LPR GUI window appears.
When you type only
lpr
and press Enter, the Select file(s) to print window appears first. Just select any files you want to print and click Open.
2
In the LPR GUI window, select your printer from the list, and change the printer and print job properties.
For details about the properties window, see page 33.
3
Click OK to start printing.
Scanning a Document
You can scan a document using the Unified Driver Configurator window.
1
Double-click the Unified Driver Configurator on your desktop.
2
Click the button to switch to Scanners Configuration.
3
Select the scanner on the list.
Click your scanner.
When you have only one MFP device and it is connected to the computer and turned on, your scanner appears on the list and is automatically selected.
If you have two or more scanners attached to your computer, you can select any scanner to work at any time. For example, while acquisition is in progress on the first scanner, you may select the second scanner, set the device options and start the image acquisition simultaneously.
4
Click Properties.
5
Load the document to be scanned face up into the ADF
(Automatic Document Feeder) or face down on the document glass.
6
Click Preview in the Scanner Properties window.
34
Using Your Printer in Linux
The document is scanned and the image preview appears in the Preview Pane.
Drag the pointer to set the image area to be scanned.
7
Change the scan options in the Image Quality and Scan
Area sections.
•Image Quality: allows you to select the color composition and the scan resolution for the image.
•Scan Area: allows you to select the page size. The
Advanced button enables you to set the page size manually.
If you want to use one of the preset scan option settings, select from the Job Type drop-down list. For details about
the preset Job Type settings, see page 35.
You can restore the default setting for the scan options by clicking Default.
8
When you have finished, click Scan to start scanning.
The status bar appears on the bottom left of the window to show you the progress of the scan. To cancel scanning, click Cancel.
9
The scanned image appears in the new Image Manager tab.
10
When you are finished, click Save on the toolbar.
11
Select the file directory where you want to save the image and enter the file name.
12
Click Save.
Adding Job Type Settings
You can save your scan option settings to retrieve for a later scanning.
To save a new Job Type setting:
1
Change the options from the Scanner Properties window.
2
Click Save As.
3
Enter the name for your setting.
4
Click OK.
Your setting is added to the Saved Settings drop-down list.
To save a Job Type setting for the next scan job:
1
Select the setting you want to use from the Job Type dropdown list.
2
The next time you open the Scanner Properties window, the saved setting is automatically selected for the scan job.
To delete a Job Type setting:
1
Select the setting you want to delete from the Job Type drop-down list.
2
Click Delete.
The setting is deleted from the list
Using the Image Manager
The Image Manager application provides you with menu commands and tools to edit your scanned image.
Use these tools to edit the image.
If you want to edit the scanned image, use the toolbar.
For further details about editing an image, see page 35.
35
Using Your Printer in Linux
You can use the following tools to edit the image:
Tools Function
Saves the image.
Cancels your last action.
Restores the action you canceled.
Allows you to scroll through the image.
Crops the selected image area.
Zooms the image out.
Zooms the image in.
Allows you to scale the image size; you can enter the size manually, or set the rate to scale proportionally, vertically, or horizontally.
Allows you to rotate the image; you can select the number of degrees from the dropdown list.
Allows you to flip the image vertically or horizontally.
Allows you to adjust the brightness or contrast of the image, or to invert the image.
Shows the properties of the image.
For further details about the Image Manager application, refer to the onscreen help.
36
Using Your Printer in Linux
8
Using Your Printer with a Macintosh
Your printer supports Macintosh systems with a built-in USB interface or 10/100 Base-TX network interface card. When you print a file from a Macintosh computer, you can use the CUPS driver by installing the PPD file.
N
OTE
:
Some printers do not support a network interface. Make sure that your printer supports a network interface by referring to Printer Specifications in your Printer User’s Guide.
This chapter includes:
• Installing Software for Macintosh
Installing Software for
Macintosh
The CD-ROM that came with your printer provides you with the
PPD file that allows you to use the CUPS driver or Apple
LaserWriter driver (only available when you use a printer which supports the PostScript driver) , for printing on a
Macintosh computer.
Also, it provides you with the Twain driver for scanning on a
Macintosh computer.
Install the Printer driver
1
Make sure that you connect your printer to the computer.
Turn on your computer and printer.
2
Insert the CD-ROM which came with your printer into the
CD-ROM drive.
3
Double-click CD-ROM icon that appears on your
Macintosh desktop.
4
Double-click the MAC_Installer folder.
5
Double-click the MAC_Printer folder.
6
Double-click the Samsung SPLC Installer icon.
7
Enter the password and click OK.
8
The Samsung SPL Installer window opens. Click Continue and then click Continue.
9
Select Easy Install and click Install.
10
After the installation is finished, click Quit.
Uninstalling the Printer driver
Uninstall is required if you are upgrading the software, or if installation fails.
1
Insert the CD-ROM which came with your printer into the
CD-ROM drive.
2
Double-click CD-ROM icon that appears on your
Macintosh desktop.
3
Double-click the MAC_Installer folder.
4
Double-click the MAC_Printer folder.
5
Double-click the Samsung SPLC Installer icon.
6
Enter the password and click OK.
7
The Samsung SPL Installer window opens. Click Continue and then click Continue.
8
Select Uninstall and then click Uninstall.
9
When the uninstallation is done, click Quit.
37
Using Your Printer with a Macintosh
Install the Scan driver
1
Make sure that you connect your printer to the computer.
Turn on your computer and printer.
2
Insert the CD-ROM which came with your printer into the
CD-ROM drive.
3
Double-click CD-ROM icon that appears on your
Macintosh desktop.
4
Double-click the MAC_Installer folder.
5
Double-click the MAC_Twain folder.
6
Double-click the Samsung ScanThru Installer icon.
7
Enter the password and click OK.
8
Click Continue.
9
Click Install.
10
Click Continue.
11
After the installation is finished, click Quit.
Uninstalling the Scan driver
1
Insert the CD-ROM which came with your printer into the
CD-ROM drive.
2
Double-click CD-ROM icon that appears on your
Macintosh desktop.
3
Double-click the MAC_Installer folder.
4
Double-click the MAC_Twain folder.
5
Double-click the Samsung ScanThru Installer icon.
6
Enter the password and click OK.
7
Click Continue.
8
Select Uninstall from the Installation Type and then Click
Uninstall.
9
Click Continue.
10
When the uninstallation is done, click Quit.
Setting Up the Printer
Set up for your printer will be different depending on which cable you use to connect the printer to your computer—the network cable or the USB cable.
For a Network-connected Macintosh
N
OTE : Some printers do not support a network interface. Before connecting your printer, make sure that your printer supports a network interface by referring to Printer Specifications in your Printer User’s
Guide.
1
Follow the instructions on “Installing Software for
Macintosh” on page 37 to install the PPD and Filter files on
your computer.
2
Open Print Setup Utility from the Utilities folder.
3
Click Add on the Printer List.
4
Select the IP Printing tab.
5
Select Socket/HP Jet Direct in Printer Type.
WHEN PRINTING A DOCUMENT CONTAINING MANY
PAGES, PRINTING PERFORMANCE MAY BE
ENHANCED BY CHOOSING SOCKET FOR PRINTER
TYPE OPTION.
6
Enter the printer’s IP address in the Printer Address field.
7
Enter the queue name in the Queue Name field. If you cannot determine the queue name for your printer server, try using the default queue first.
8
Select Samsung in Printer Model and your printer in
Model Name.
9
Click Add.
10
Your printer’s IP address appears on the Printer List, and is set as the default printer.
For a USB-connected Macintosh
1
Follow the instructions on “Installing Software for
Macintosh” on page 37 to install the PPD and Filter files on
your computer.
2
Open Print Setup Utility from the Utilities folder.
3
Click Add on the Printer List.
4
Select the USB tab.
5
Select Samsung in Printer Model and your printer in
Model Name.
6
Click Add.
Your printer appears on the Printer List, and is set as the default printer.
38
Using Your Printer with a Macintosh
Printing
N
OTES :
• The Macintosh printer’s properties window that appears in this User’s Guide may differ depending on the printer in use.
However the composition of the printer properties window is similar.
• You can check your printer name in the supplied CD-
ROM.
Printing a Document
When you print with a Macintosh, you need to check the printer software setting in each application you use. Follow these steps to print from a Macintosh.
1
Open a Macintosh application and select the file you want to print.
2
Open the File menu and click Page Setup (Document
Setup in some applications).
3
Choose your paper size, orientation, scaling, and other options and click OK.
Make sure that your printer is selected.
Changing Printer Settings
You can use advanced printing features when using your printer.
From your Macintosh application, select Print from the File menu. The printer name which appears in the printer properties window may differ depending on the printer in use. Except for the name, the composition of the printer properties window is similar.
Layout Setting
The Layout tab provides options to adjust how the document appears on the printed page. You can print multiple pages on one sheet of paper.
Select Layout from the Presets drop-down list to access the
following features. For details, see “Printing Multiple Pages on
One Sheet of Paper” on the next column.
â–²
Mac OS 10.3
â–² Mac OS 10.3
4
Open the File menu and click Print.
5
Choose the number of copies you want and indicate which pages you want to print.
6
Click Print when you finish setting the options.
39
Printer Features Setting
The Printer Features tab provides options for selecting the paper type and adjusting print quality.
Select Printer Features from the Presets drop-down list to access the following features:
Printing Multiple Pages on One Sheet of Paper
You can print more than one page on a single sheet of paper.
This feature provides a cost-effective way to print draft pages.
1
From your Macintosh application, select Print from the
File menu.
2
Select Layout.
â–² Mac OS 10.3
Paper Type
Set Type to correspond to the paper loaded in the tray from which you want to print. This will let you get the best quality printout. If you load a different type of print material, select the corresponding paper type.
Resolution(Quality)
The Resolution options you can select may vary depending on your printer model.
You can select the printing resolution. The higher the setting, the sharper the clarity of printed characters and graphics. The higher setting also may increase the time it takes to print a document.
Color Mode
You can set the color options. Setting to Color typically produces the best possible print quality for color documents. If you want to print a color document in grayscale, select Grayscale.
â–² Mac OS 10.3
3
Select the number of pages you want to print on one sheet of paper on the Pages per Sheet drop-down list.
4
Select the page order from the Layout Direction option.
To print a border around each page on the sheet, select the option you want from the Border drop-down list.
5
Click Print, and the printer prints the selected number of pages on one side of each page.
40
Scanning
If you want to scan documents using other software, you will need to use TWAIN-compliant software, such as Adobe
PhotoDeluxe or Adobe Photoshop. The first time you scan with your machine, select it as your TWAIN source in the application you use.
The basic scanning process involves a number of steps:
• Place your photograph or page on the document glass or
ADF.
• Open an application, such as PhotoDeluxe or Photoshop.
• Open the TWAIN window and set the scan options.
• Scan and save your scanned image.
N
OTE : You need to follow the program’s instructions for acquiring an image. Please refer to the User’s Guide of the application.
41
S
OFTWARE SECTION
I
NDEX
A advanced printing, use
B booklet printing
C canceling scan
D document, print
Macintosh
Windows
double-sided printing
E
Extras properties, set
F favorites settings, use
G
Graphics properties, set
H help, use
I install printer driver
Macintosh
Windows
installing
Linux software
L
Layout properties, set
Macintosh
Windows
Linux driver, install
printer properties
printing
scanning
M
Macintosh driver install
uninstall
printing
scanning
setting up the printer
MFP driver, install
Linux
N n-up printing
Macintosh
Windows
O orientation, print
Windows
overlay create
delete
P
Paper properties, set
paper size, set
paper source, set
Windows
42 paper type, set
Macintosh
poster, print
print document
fit to page
from Macintosh
from Windows
N-up
Macintosh
Windows
overlay
poster
PRN
scaling
watermark
print resolution
printer driver, install
Linux
printer properties
Linux
printer properties, set
Macintosh
Windows
printer resolution, set
Macintosh
Windows
printer software install
Macintosh
Windows
uninstall
Macintosh
Windows
printing booklets
double-sided
from Linux
R resolution printing
S scanning
Linux
SmarThru
TWAIN
WIA driver
scanning from Macintosh
setting darkness
favorites
image mode
resolution
Macintosh
Windows
toner save
true-type option
software install
Macintosh
Windows
reinstall
Windows
system requirements
Macintosh
uninstall
Macintosh
Windows
status monitor, use
T toner save, set
TWAIN, scan
U uninstall, software
Macintosh
Windows
uninstalling
MFP driver
Linux
W watermark create
delete
edit
WIA, scan
43
Ver. 1.07
