AVR401: 8-bit Precision A/D Converter

Features

Very Low Cost

High Precision

Auto-calibration Eliminates Component Inaccuracy

Measures Voltages for 0 to V

CC

Maximum Conversion Time: 1.1 ms

Introduction

This application note describes how to perform a kind of dual slope A/D conversion with an AVR microcontroller. The converter is very low cost, requiring only six discrete components in addition to the AVR. Five of the controller pins are used (see Figure 1).

This example is based on the AT90S1200 device, but any AVR device with a comparator can be used.

Figure 1. A/D Converter

V

CC

C

T

R

B

PB7

(AIN0) PB0

(AIN1) PB1

PB2

AT90S1200

R ref 1

V in

R in

R ref 2

PB3

8-bit

Microcontroller

Application

Note

Theory of Operation

The capacitor is charged with a constant current supplied by the transistor. The capacitor voltage will rise linearly. To discharge the capacitor, the AIN0-pin is set to output with a “0” applied. A reference voltage at V and R ref2

CC

/2 is supplied by the resistor network R ref1

. When the PB1 and PB2-pins are configured as inputs, the reference is turned off, and the voltage level at the AIN1-pin will be the input voltage V in

. By setting the pins as outputs and applying a “0” and a “1”, the level at the AIN1-pin will be V

CC

/2

(if the resistors are of equal size). The input resistor R in

have to be at least 100 times higher than the reference resistors R ref1

and R ref2

to avoid measurement errors.

Rev. 0953C–AVR–02/03

1

The algorithm used for the conversion is as follows:

1.

Turn on the reference.

2.

Charge the capacitor until the reference voltage is reached. Measure the time needed for this, T ref

.

3.

Turn off the reference and discharge the capacitor

4.

Charge the capacitor until the input voltage is reached. Measure the time needed for this, T in

.

The conversion cycle is shown in Figure 2.

The time measurement is performed by the Timer/Counter, which is expanded to nine bits by using the Timer/Counter Overflow Interrupt.

Figure 2. Conversion Cycle

Calculation

2

AVR401

Suppose that V

CC

is 5 volts. The relationship between the input voltage and the reference voltage is given by:

Equation 1

V in

=

V

×

T ref

T in

The ideal output from the conversion is an 8-bit number, where 0 volts corresponds to zero and 5 volts is 255. The reference voltage V

CC equation can be re-written as:

/2 thus corresponds to 128. The

Equation 2 V in

=

T in

×

128

-------------------------

T ref

However, with inaccuracy in the reference resistors, the reference voltage may vary slightly. To compensate for this, a calibration can be performed by applying a known voltage at the input, and compare this to the reference. If the applied calibration voltage is exactly 2.5 volts, the reference voltage can be found by the equation:

Equation 3 V ref

=

T

×

V cal

T cal

=

T

×

128

T cal

0953C–AVR–02/03

Configuration

Example

AVR401

The calibration cycle is executed by holding the PB7-pin high during Power-up. The calibration voltage is then applied, and the PB7-pin is set low. This starts calibration, and once performed, the value of the reference voltage is stored in EEPROM. During normal operation, the reference value is read from EEPROM, and the input voltage is calculated using Equation 1.

As the resulting output is to be eight bits, the timer should be of at least nine bits to maintain the resolution. The components should be chosen so that the nominal time charging the capacitor up to V

CC

is about 256 timer steps. In that way, inaccuracy in the component values and temperature changes are allowed, without causing the charging time to be longer than the maximum timer period, or too short, giving lower resolution.

To achieve sufficient accuracy, a prescaler factor of eight or higher should be used. The

AT90S1200 Timer/Counter0 is of only eight bits, so the ninth bit must be handled in software. The following example illustrates how the component values can be found.

First, decide which crystal frequency to operate at. With a 4 MHz crystal, the clock period is 250 ns. By setting the prescaler to CK/8, the Timer is incremented every 2 µs.

The maximum timer period with nine bits is 512 x 2 µs = 1,024 µs. From this, we set

2 x T

REF

to 512 µs.

The charging of a capacitor whit a constant current is described by the equation:

Equation 4

V

=

I

C

× ∆ t

We can find the required current when the capacitor size, the time and the voltage difference is known:

Equation 5

I =

V

×

C

∆ t

The capacitor will be charged up to V

CC

= 5 V, and with a 220 µF capacitor, the transistor must supply a current of 2.15 mA. The R

B

value is dependent upon the transistor’s h

FE

. For a BC558A pnp transistor, h sistor ideal for use, since any h

FE

FE

is in the range 125 to 250. This makes this tran-

value in the specified range can be used. To make sure the full range in h

FE

can be used, the average value, 188, is used in the calculations. The resulting base current is 11.4

µ

A.

The transistor is turned on by applying a “0” on the corresponding pin. At this current values, the transistor base-emitter voltage is about ÷0.1 V. The base resistor is found to be:

Equation 6 R

B

=

V + V

BE

I

B

=

4,9V

11,4

µ

A

=

430k

The reference voltage is generated by the divider network R ref1

and R ref2

. The R in

has to be much larger than these two, so that the input voltage will not influence with the reference voltage. 100 k

for R in

and 1 k

for each of R ref1

and R ref2

is suitable.

3

0953C–AVR–02/03

The transistor should be connected to a pin as long away from the comparator inputs as possible. When a pin is switched, a noise spike appear at the adjacent pins. This will cause problems when measuring low voltages, as the noise spike might trigger the comparator before the capacitor voltage has reached the measured voltage.

Figure 3 shows measured linearity for a 4 MHz clocked application using the component values calculated in the above example.

Figure 3. Measured Linearity

LINEARITY

O

U

T

P

U

T

250

200

150

L

U

V

A

E

100

50

0

0 1 2 3

INPUT VOLTAGE

4 5

Implementation

The software consist of several subroutines. The routines “reference” and “convert” handles the charging and timing. After they complete execution, the main program must perform the calculation needed. This is done using two subroutines that performs division and multiplication, “div17u” and “mul9”. There are also two delays used by the other routines and the main program. They are used to discharge the capacitor completely and to generate a delay between each conversion.

“reference” Subroutine –

Measures the Reference

Voltage

The routine discharges the capacitor, turns on the transistor and charges the capacitor until the capacitor voltage is equal to the reference voltage. The time from the beginning of the charging and until the voltages are equal is measured. The capacitor is then discharged again. The charging time is used together with the charging time from the

“convert” routine to calculate the input voltage.

This routine does not have to be called every time a conversion is performed, depending on variations in ambient temperature. Especially the parameter h

FE

in the transistor is quite temperature dependent, so if the ambient temperature is varying, the subroutine will have to be executed frequently. In the example program, the “reference” routine is called each time a conversion is performed.

Table 1. “reference” Subroutine Performance Figures

Parameter

Code Size

Value

24 words

Execution Cycles

Register Usage

Depends on the reference voltage.

:None

:2

:1

4

AVR401

0953C–AVR–02/03

0953C–AVR–02/03

AVR401

Table 2. “reference” Register Usage

Register Input Internal

R17

Output

Tref – Holds the time to reach the reference voltage.

R18

R20

TH – High part of timer.

temp

Figure 4. Flow Chart for “reference”

Reference

AIN0 as Output

(Discharge Capacitor)

PB2 and PB3 as Outputs

Delay

Clear Timer Variables

AIN0 as Input

(Capacitor Ready for Charging)

Turn on Transistor

(Charge Capacitor)

Yes ACO = 1?

(V cap

> V ?)

No

Timer > 0x1FF?

No

Yes

Store T ref

Stop Timer

Turn off Transistor

AIN0 as Output

(Discharge Capacitor)

PB2 and PB3 as Inputs

Return

5

“input” Subroutine –

Measures the Input

Voltage

The routine turns on the transistor and charges the capacitor until the capacitor voltage is equal to the input voltage. Then capacitor is then discharged. The time needed to do this is measured and stored in T in

.

There should be a few microseconds delay between two conversion cycles, to ensure that the capacitor is completely discharged. In the example program, this is done by calling a delay routine.

Table 3. “input” Subroutine Performance Figures

Parameter Value

Code Size

Execution Cycles

Register Usage

19 words

Depends on the input voltage

:2

:None

:1

Table 4. “input” Register Usage

Register

R14

Input Internal Output

TinH – High part of the input voltage charge time.

R15

R20 temp

TinL – Low part of the input voltage charge time.

6

AVR401

0953C–AVR–02/03

0953C–AVR–02/03

Figure 5. Flow Chart for “input”

Input

AIN0 as Input

(Capacitor Ready for Charging)

Clear Error Flag

Clear Timer Variables

Turn on Transistor

(Charge Capacitor)

Yes

ACO = 1?

(V cap

> V ?)

No

Timer > 0x1FF?

Yes

Set Error Flag

No

Store T in

Stop Timer

Turn off Transistor

AIN0 as Output

(Discharge Capacitor)

Return

AVR401

7

“T0_int” Interrupt

Service Routine

“mpy9u” 9 × 8 Bit

Multiplication

The only function for this routine is to increment the TH variable, so a 16-bit Timer is created. Only nine bits are used.

Table 5. “T0_int” Interrupt Performance Figures

Parameter Value

Code Size

Execution Cycles

Register Usage

2 words

9 – including the reti instruction

:None

:None

:1

This routine performs a 9 × 8 bit multiplication. The 9-bit multiplier must be stored in the

Carry Flag (MSB) and the “mp9u” Register. The multiplicand is stored in the “mc9u”

Register. The answer is placed in “C:m9uH:m9uL”. The registers used for the result are the same as those used for the input to the division routine. The routine is based on the

“mpy8u” multiplication routine described in application note AVR 200.

Table 6. “mpy9u” Subroutine Performance Figures

Parameter

Code Size

Value

11 words

Execution Cycles

Register Usage

83

:3

:None

:1

:C

Table 7. “mpy9u” Register Usage

Internal

Register

R0

Input

mc9u – Multiplicand mp9u – Multiplier R1

R2

C-flag

R20

Multiplier, ninth bit temp – Used as Loop Counter

Output

m9uL – Result Low byte m9uH – Result High byte

Result, 17th bit

8

AVR401

0953C–AVR–02/03

“div17u” 17/16 Bit

Division

Example Program

AVR401

This routine performs a 17/16 bit division. The 17-bit dividend must be stored in the

(C:didH:didL) variable, where the Carry Flag is most significant. The divisor is stored in the (divH:divL) variable. The result is placed in (resH:resL) and the reminder in

(remH:remL). The routine is based on the “div16u” multiplication routine described in application note AVR 200.

Table 8. “div17u” Subroutine Performance Figures

Parameter Value

Code Size

Execution Cycles

Register Usage

18 words

209 min, 292 max.

:6

:None

:1

:C

Table 9. “div17u” Register Usage

Register Input

R1

R2

C-flag

R3

R4

R5

R6 didL – Low part dividend didH – High part dividend

17th bit of dividend divL – Low part divisor divH – High part divisor

Internal Output

dresL – Low part result dresH – High part result remL – Low part reminder remH – High part reminder

The included example program performs repeated conversions. First, the charging time for the reference is measured, then for the input voltage. The result is output to Port D and Port B pin 4 (MSB). The result is inverted before it is output, so active low LEDs can be connected to show the result. This conversion cycle is repeated in an endless loop.

To perform a calibration the PB7-pin must be initially in high state and the capacitor has to be discharged. Afterwards the user should apply 2.5 volts at the input before setting the PB7-pin low. The calibrated V ref

is stored in EEPROM, where it is fetched at every normal Power-up.

9

0953C–AVR–02/03

Performance Figures

Table 10. Overall Performance Figures

Parameter

Code Size

Register Usage

Value

43 words - Conversion routines only (not mpy9u and div17u)

147 words - Complete application note

:9

:5

:None

Interrupt Usage

Peripheral Usage

Timer/Counter 0 Interrupt

Timer/Counter0

Analog Comparator

Port B, pin 0 to 3 and pin 7

Port D, all pins (example program only)

Port B, pin 4 (example program only)

The calibration routine can be skipped if only relative values are measured. The reference voltage is then assumed to be 128, which will also make the calculations easier.

The reference network can be substituted with a voltage reference to achieve even better accuracy. It is then possible to measure variations in V

CC voltage divider network to the input.

by connecting it via a

10

AVR401

0953C–AVR–02/03

AVR401

0953C–AVR–02/03

11

Atmel Headquarters

Corporate Headquarters

2325 Orchard Parkway

San Jose, CA 95131

TEL 1(408) 441-0311

FAX 1(408) 487-2600

Europe

Atmel Sarl

Route des Arsenaux 41

Case Postale 80

CH-1705 Fribourg

Switzerland

TEL (41) 26-426-5555

FAX (41) 26-426-5500

Asia

Room 1219

Chinachem Golden Plaza

77 Mody Road Tsimhatsui

East Kowloon

Hong Kong

TEL (852) 2721-9778

FAX (852) 2722-1369

Japan

9F, Tonetsu Shinkawa Bldg.

1-24-8 Shinkawa

Chuo-ku, Tokyo 104-0033

Japan

TEL (81) 3-3523-3551

FAX (81) 3-3523-7581

Atmel Operations

Memory

2325 Orchard Parkway

San Jose, CA 95131

TEL 1(408) 441-0311

FAX 1(408) 436-4314

Microcontrollers

2325 Orchard Parkway

San Jose, CA 95131

TEL 1(408) 441-0311

FAX 1(408) 436-4314

La Chantrerie

BP 70602

44306 Nantes Cedex 3, France

TEL (33) 2-40-18-18-18

FAX (33) 2-40-18-19-60

ASIC/ASSP/Smart Cards

Zone Industrielle

13106 Rousset Cedex, France

TEL (33) 4-42-53-60-00

FAX (33) 4-42-53-60-01

1150 East Cheyenne Mtn. Blvd.

Colorado Springs, CO 80906

TEL 1(719) 576-3300

FAX 1(719) 540-1759

Scottish Enterprise Technology Park

Maxwell Building

East Kilbride G75 0QR, Scotland

TEL (44) 1355-803-000

FAX (44) 1355-242-743

RF/Automotive

Theresienstrasse 2

Postfach 3535

74025 Heilbronn, Germany

TEL (49) 71-31-67-0

FAX (49) 71-31-67-2340

1150 East Cheyenne Mtn. Blvd.

Colorado Springs, CO 80906

TEL 1(719) 576-3300

FAX 1(719) 540-1759

Biometrics/Imaging/Hi-Rel MPU/

High Speed Converters/RF Datacom

Avenue de Rochepleine

BP 123

38521 Saint-Egreve Cedex, France

TEL (33) 4-76-58-30-00

FAX (33) 4-76-58-34-80

e-mail

[email protected]

Web Site

http://www.atmel.com

© Atmel Corporation 2003.

Atmel Corporation makes no warranty for the use of its products, other than those expressly contained in the Company’s standard warranty which is detailed in Atmel’s Terms and Conditions located on the Company’s web site. The Company assumes no responsibility for any errors which may appear in this document, reserves the right to change devices or specifications detailed herein at any time without notice, and does not make any commitment to update the information contained herein. No licenses to patents or other intellectual property of Atmel are granted by the Company in connection with the sale of Atmel products, expressly or by implication. Atmel’s products are not authorized for use as critical components in life support devices or systems.

ATMEL

®

and AVR

®

are the registered trademarks of Atmel.

Other terms and product names may be the trademarks of others.

Printed on recycled paper.

0953C–AVR–02/03 0M

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
