CCTV Camera
■
EN-VI50K Series
■ Features
◆
Weatherproof IR Camera
◆
SONY / SHARP Color CCD
◆ 72
pcs ¢5mm IR-LED, IR Range 50M
◆
3-Axis Bracket, Easy For Installation
◆
Built-in 4--9mm Manual Zoom Lens
■ Size Chart
■ Specifications
EN-VI50K-38
EN-VI50K-32
1/3 SONY
1/3 SONY
540 TVL
420 TVL
Picture Elements
PAL:795(H)×596(V); NTSC:811(H)×508(V)
PAL:500(H)×582(V); NTSC:510(H)×492(V)
Min. Illumination
0.2 Lux /F2.0
0.8 Lux /F2.0
Model Name
Image Device
Resolution
TV System
PAL/NTSC
Lens Furnished
4--9 mm Manual Zoom Lens (Optional 2.8--12mm Manual Zoom Lens)
Infrared Luminary
72 pieces ¢5 mm IR-LED
Illuminate Distance
50 M
Wavelength
850 nm
Waterproofing Criterion
IP 66
S/N Ratio
More than 48dB
Electronic Shutter
NTSC:1/60~1/100,000, PAL:1/50~1/110,000
Gamma
0.45
White Balance
Auto
Gain Control
Auto
Sync. System
Internal
Video Output
1 Vp-p / 75 Ohms
Power Supply
DC12V±10%
Operation Temperature
-10℃ ~ +50℃ RH95% Max
Dimension
204 x 84 x 85 mm
Weight
1600g
Design and specifications are subject to change without notice.
