LEVEL & LEAK DETECTION
LEVEL TRANSMITTER
LD34, LD35 SERIES DELTASPAN
DESCRIPTION
The Flowline DeltaSpan LD34 and LD35 Series smallbore submersible pressure level transmitters provide
continuous level measurement up to 100 ft (30.4m) of water
column with a 4-20 mA signal output. Select the LD34 Series
liquid level sensor for monitoring of relatively clean water.
Application examples include ballast tanks, ground water,
surface water, dewatering, down hole and remediation. Select
the LD35 Series liquid level sensor for dirty, foaming or
slurry type liquids. Application examples include sewage lift
stations industrial slurries, industrial sumps, landfill leachate,
reservoirs, sludge pits and oil tankers.
FEATURES
• Welded 316 SS body and 316 SS nose cap provide
years of trouble free service (LD34)
• Tapered body top prevents damage or snaring when
removing from installation (LD34)
• Incorporates lighting and surge protection
• Provides precise output readings with its ±0.25% of full
scale accuracy (LD34)
• Robust PTFE coated FKM fluroelsatomer diaphragm
provides a non-stick surface for aggressive fluids
(LD35)
10
LD35
LD34
Supply Voltage
Signal Output
Maximum Output
Impedance mA
Accuracy
Proof Pressure
Process Temperature
Measurement Range
LD34
LD35
Cable Length
S101 & S111
S121 & S131
10 to 33 VDC
4-20 mA, two-wire @ 1000Ω
1000Ω @ 30 VDC
± 0.25% of full scale
2 x full scale
-4° to 176°F (-20° to 80°C)
up to 100 ft (30.5m)
up to 30 ft (9.1m)
40 ft (12.2m) (LD34)
60 ft (18.3m) (LD34)
S141
S151
SX01 & SX11
SX21 & SX31
Cable Type
70 ft (21.3m) (LD34)
100 ft (30.5m) (LD34)
40 ft (12.2m) (LD35)
60 ft (18.3m) (LD35)
Polyurethane cable jacket, ETFE
cable jacket (LD35 only)
CE, RoHS
Approvals
Weight
LD34
0.24 lb (0.11 kg)
0.30 lb (0.14 kg)
1 year
LD35
Warranty
LEVEL & LEAK DETECTION
SPECIFICATIONS
DIMENSIONS
0.625" (15.87 mm)
(+) Red
(-) Black
(Clear) Vent
Shld
6.25"
(158.30 mm)
LD34
0.625" (15.87 mm)
(+) Red
(-) Black
(Clear) Vent
Shld
1.188"
(30.16 mm)
5.94"
(150.83 mm)
LD35
March 2014
WE MAKE IT EASY.
kele.com
888-397-5353 USA
603
NEW!
LEVEL & LEAK DETECTION
LEVEL TRANSMITTER
LD34, LD35 SERIES DELTASPAN
ORDERING INFORMATION
MODEL
DESCRIPTION
LD34
Small-bore pressure level transmitter, clean liquid applications
LD35
Small-bore pressure level transmitter, dirty liquid applications
CABLE JACKET
S1
Polyurethane
S2* ETFE
RANGE ft (m)
10
01
0-11.55 (0-3.5)
11
0-15 (0-4.6)
21
0-20 (0-6.1)
31
0-30 (0-9.1)
41** 0-50 (0-15.2)
LEVEL & LEAK DETECTION
51** 0-100 (0-30.5)
Example: LD34-S111 Small-bore pressure level
transmitter for clean liquid applications
with polyurenthane cable jacket and
0-15 ft range
*Cable jacket option only available for LD35 Series
**Ranges only available for LD34 Series
604
S111
LD34
888-397-5353 USA
DCPA-1.2
DCP-1.5-W
kele.com
RELATED PRODUCTSPAGE
Power supply, 120 VAC IN to 24 VAC/24 VDC OUT
994
Power supply, 24 VAC IN to 24 VDC OUT
995
