PRODUCT CATALOG
ICELAND
SWEDEN
RUSSIA
FINLAND
NORWAY
NETHERLANDS
ESTONIA
DENMARK
U.K.
CANADA
BELGIUM
LUXEMBOURG
PORTUGAL
U. S. A.
FRANCE
SPAIN
LITHUANIA
LATVIA
BELARUS
GERMANY POLAND
SLOVAKIA
CZECH REP.
UKRAINE
HUNGARY
ITALY
SWITZERLAND
SLOVENIA
GREECE
MALTA
CYPRUS
MEXICO
About OmniMount
GUATEMALA
For 36 years OmniMount has upheld its
position as a global leader in product
innovation. From the beginning,
OmniMount honed its skills as a pioneer in
the field of audio mounts and, as the once
separated worlds of hi-fi and video fused
into home theater, continued to build on its
strong foundation and heritage with a
complete portfolio of mounting solutions.
The OmniMount product line has grown to
include flat panel TV mounts, AV wall
shelves, ceiling and projector mounts,
professional AV racks and carts, speaker
mounts and stands, and a line of specialty
AV accessory products that maximize the
home theater experience. OmniMount's
talented team of in-house industrial
designers and engineers is recognized
throughout the consumer electronics
industry for producing innovative and
reliable products, and is regularly honored
with industry awards for groundbreaking
design, precise attention to detail, superior
quality and long-term reliability. In 2012,
OmniMount joined Ergotron, Inc., a leader
in display mounting, furniture and mobility
solutions. The OmniMount sales
headquarters is located in Phoenix,
Arizona, with global headquarters in
St. Paul, Minnesota and overseas in
Amersfoort, Netherlands.
COSTA RICA
HONDURAS
PUERTO
RICO
THAILAND
JAMAICA
HONG
KONG
PHILIPPINES
MALAYSIA
PANAMA
SINGAPORE
COLOMBIA
ECUADOR
INDONESIA
PERU
AUSTRALIA
CHILE
ARGENTINA
URUGUAY
Table of Contents
A Nortek Company
Lifestyle innovations for home and work
OmniMount, a division of Ergotron, Inc., is a member of the Nortek
family. Like other Nortek companies, OmniMount is driven by
constant innovation with a singular, unified purpose: to make our
customers’ lives better. All Nortek brands are conceived of out-ofthe-box thinking, fueled by cutting-edge technology and ignited by a
robust management philosophy that promotes operational
excellence. From product design to performance and support,
every Nortek product group sets a new standard and improves how
our global customers live and work.
Learn more at www.nortek-inc.com
Why OmniMount
TV Wall Mounts
OmniElite Series
ActionMount Series
OmniSelect Series
OmniClassic Series
EZMount Series
OmniPro Series
WorkFit Computer Mounts
iPad® Mounts
AV Wall Shelves
Ceiling Mounts & Projector Mounts
Rack Systems & Carts
Speaker Stands & Mounts
OmniMount Essentials
Line Drawings
4
8
9
11
14
17
21
22
24
26
28
30
36
40
44
46
Why OmniMount
It’s our mission to develop solid relationships by providing
high-quality products, valuable marketing tools and excellent
customer service. Established in 1978, OmniMount products
have defined home cinema and are trusted by the most
demanding tech enthusiasts. With more than 36 years of
experience, we understand the industry better than anyone
and are dedicated to listening and delivering.
OMNIMOUNT.COM
The OmniMount website makes it easy to find
in-depth product information, including
installation manuals and product specifications
sheets, recent news coverage and press releases,
and general updates via the OmniMount blog.
It also boasts live chat customer service. Multiple
languages are available by selecting country/
region from the pull-down menu in the upper
right. It’s also compatible with mobile devices,
making it easily accessible while on the go.
OMNIMOUNT FINDER
Recognizing that product compatibility is
paramount to you and your customers, we’ve
updated our OmniMount Finder. It’s easy to
search by TV brand and model number and get
reliable results.
WORLD-CLASS PACKAGING
& IN-STORE DISPLAYS
AWARD-WINNING
PRODUCTS & INNOVATION
Whether displaying product at retail or in a
showroom, OmniMount's clearly marked color
coding and compatibility specs make it easy to
quickly and confidently find the right solution.
OmniMount strives to produce the highest
quality mounts on the market, as well as
constantly pushing the limits of innovation.
The result is a collection of products that has
been recognized by the consumer electronics
industry and regularly honored with
distinguished industry awards.
CUSTOMER CARE
OmniMount provides 24/7 phone support in the
US and world-class coverage across the globe.
“I have to write and thank you for the
absolutely best customer service …”
~ Heinrich S, customer
“I could not be happier. I did not think this
kind of service existed anymore …”
~ David K, customer
QUALITY
INSTALLATION VIDEOS
Created for nearly every product OmniMount
sells, the in-depth step-by-step installation
videos instill confidence in novice installers and
offer up tips and tricks for more seasoned pros.
omnimount1978
4
WHY OMNIMOUNT
OmniMount is an active user of Twitter
and Facebook, and regularly interacts with
customers via social channels.
EMAIL NEWSLETTERS
DEALER RESOURCE
CENTER
We're refining our communications process to
better serve you with information relevant to
your business and the industry events that you
attend. Join the OmniMount Newsletter list
via the website signup form.
Our goal is to make doing business easy
and mutually beneficial. The OmniMount
dealer resource center provides quick
access to product images, logos, literature
and sales collateral.
WHY OMNIMOUNT
5
Choosing the right mount
1-2-3
Easy Install
We strive to make every out-of-box experience
simple and intuitive, using just a few tools.
CERTIFIED
1
Attach rails to TV
2
Install mount on wall
3
For years there were three types of TV wall mounts: Fixed, Tilt and Full Motion. OmniMount is
responsible for launching a fourth category: Interactive. OmniMount's interactive mounts are
designed with patented Constant Force™ technology and move TVs like no other mounts on the
market. Let our innovation set you apart from the pack.
FIXED
Hang TV on mount
LOWEST PROFILE
Very low profile mounts for
dedicated viewing areas
SAFE & CERTIFIED
Our products undergo a testing regimen that is establishing
the benchmark and exceeding the industry’s most rigid
certifications. OmniMount strives to provide the highest
levels of trouble-free product performance and longevity,
delivering peace of mind to customers.
Every product is tested to
UL2442 standards,
the most advanced standards
created by UL
TILT
REDUCES GLARE
Tilt your TV down to avoid screen glare or
achieve a better viewing angle
FULL MOTION
TRUTH IN MOUNTING
To ensure truth in mounting, OmniMount products go through a rigorous testing process in a facility
dedicated to the manufacture and distribution of OmniMount products. Cycle testing is done on
every moving feature, not just full motion, for guaranteed performance.
FLEXIBILITY
Pull your TV away from the wall and tilt,
pan or swivel for multi-room viewing
The OmniMount facility performs 100% end-of-line testing, life-cycle testing, and a host of other
in-process tests, ensuring the highest quality products.
• Up to 7,500-cycle test applied to height-adjustable mechanisms, ensuring years of trouble-free
height adjustment
• All product functions are endurance tested to expected life of the product
• 100% functional test for every product
• Cycle testing performed on sample basis per product
reliability criteria
• Load Testing: 4x load test (meets or exceeds UL requirements)
ensures product safety for the rigors of public use
6
WHY OMNIMOUNT
INTERACTIVE
MAXIMUM MOVEMENT
Height adjustment and full motion
functionality featuring patented
Constant Force™ technology
WHY OMNIMOUNT
7
NEW! OMNIELITE SERIES
The OmniElite series is a flagship line of mounts for
larger, lighter TVs. Whether looking for a fixed, tilt or
full motion mount, the OmniElite series will provide
a solution with all the bells and whistles for a truly
superior installation.
FULL MOTION
Full motion with left and right pan
(great for rooms with multiple
viewing areas)
Low profile design
Cast aluminum arms for superior
strength
Highly stylized to complement HD
and Ultra HD panels
Unique joint design offers easy,
smooth movement of the TV
OE80FM
UL 2442 rated and tested to
6,000 cycles
MEDIUM FULL MOTION MOUNT
Special channel routes cables from
TV to wall, concealing wires
Lift n’ Lock™ makes installation a
three-step process
TV tilts forward to reduce screen
glare (great for rooms with windows)
Installer-friendly mounting template
5-year warranty
Available in Black
TV Wall Mounts
Fits most: 32–52" (82–132 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Mounting profile: 2.5" (6.4 cm)
Maximum extension: 19.5” (49.5 cm)
Universal & VESA compliant: 200x100 to
600x400
Tilt: 0 to +10°
Post installation leveling: Yes
Mounting: Single-stud or solid wall
OE150FM
LARGE FULL MOTION MOUNT
DESIGNED WITH PATENTED
GRAVITY TILT AND PRECISE
TOLERANCES TO MAKE
ADJUSTING A TV EASY AND
RELIABLE
8
TV WALL MOUNTS
Fits most: 47–80" (119–203 cm) TVs
Supports up to: 150 lbs (68 kg)
Mounting profile: 2.6" (6.6 cm)
Maximum extension: 16.7" (42.4 cm)
Universal & VESA compliant: 200x100
to 800x400
Tilt: 0 to +10°
Post installation leveling: Yes
Mounting: Double-stud or solid wall
TV WALL MOUNTS
9
NEW! OMNIELITE SERIES
ACTIONMOUNT SERIES
TILT
Low profile design
GROUP VIEWING
TV tilts forward to reduce screen
glare (great for rooms with windows)
Hosting a party for the big game has
never been easier! Pull the TV away
from the wall and raise it to a higher
position for great viewing angles.
Highly stylized to complement HD
and Ultra HD panels
Sit. Stand. Stretch. Play – all at the perfect angle. The
ActionMount Series by OmniMount takes interactivity
with your TV to the next level.
UL 2442 rated for guaranteed safety
PLAY
Lift n’ Lock makes installation a
three-step process
Installer-friendly mounting template
Kickstand holds TV for easy wiring
OE80T
OE150T
MEDIUM TILT MOUNT
LARGE TILT MOUNT
5-year warranty
Fits most: 27–47" (69–119 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Mounting profile: 1.5" (3.8 cm)
Universal & VESA compliant: 200x200 to
400x400
Tilt: up to +10°
Mounting: Double-stud or solid wall
Fits most: 47–80" (119–203 cm) TVs
Supports up to: 150 lbs (68 kg)
Mounting profile: 1.4" (3.5 cm)
Universal & VESA compliant: 200x200 to
600x600
Tilt: up to +10°
Mounting: 16" or 24" double-stud; solid wall
Available in Black
Post installation leveling
GAMING
Push the TV close to the wall for
more room to play, or pull it out and
drop it low to get into the action.
FIXED
FITNESS
Low profile design
Fixed position ideal for dedicated
viewing areas
Bring the TV low for exercise on the
floor, like yoga, or collapse it against
the wall for the most room to kick,
punch and stretch.
EXTENDS
."
PLAY20
PLAY20X
INTERACTIVE TV MOUNT
INTERACTIVE TV MOUNT
Fits most: 19–32" (49–81 cm) TVs/displays
Supports: 7–20 lbs (3.2–9.1 kg)
Mounting profile: 3.9" (10 cm)
Maximum extension: 16.6" (42 cm)
Horizontal movement: 30" (76 cm)
Vertical adjustment: 13" (33 cm)
Tilt: +5° to -70° / Pan: 180° / Rotation: 180°
VESA compliant: 75x75 to 200x200
Fits most: 19–32" (49–81 cm) TVs/displays
Supports: 7–20 lbs (3.2–9.1 kg)
Mounting profile: 3.9" (10 cm)
Maximum extension: 25.6" (65 cm)
Horizontal movement: 48" (122 cm)
Vertical adjustment: 13" (33 cm)
Tilt: +5° to -70° / Pan: 180° / Rotation: 180°
VESA compliant: 75x75 to 200x200
PLAY25
PLAY25X
INTERACTIVE TV MOUNT
INTERACTIVE TV MOUNT
Fits most: 19–37" (49–94 cm) TVs/displays
Supports: 7–25 lbs (3.2–11.4 kg)
Tilt: +5° to -70°
Vertical adjustment: 20" (51 cm)
Mounting profile: 4.4" (11.2 cm)
Maximum extension: 21.4" (54 cm)
Rotation: 360° with 0° lockout
VESA compliant: 75x75 to 200x200
Fits most: 19–37" (49–94 cm) TVs/displays
Supports: 7–25 lbs (3.2–11.4 kg)
Tilt: +5° to -70°
Vertical adjustment: 20" (51 cm)
Mounting profile: 4.4" (11.2 cm)
Maximum extension: 33.5" (85 cm)
Rotation: 360° with 0° lockout
VESA compliant: 75x75 to 200x200
Highly stylized to complement HD
and Ultra HD panels
UL 2442 rated for guaranteed safety
Lift n’ Lock makes installation a
three-step process
Installer-friendly mounting template
OE80F
OE200F
MEDIUM FIXED MOUNT
LARGE FIXED MOUNT
Fits most: 37–52" (94–132 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Mounting profile: 0.7" (1.8 cm)
Universal & VESA compliant: 200x200 to
400x400
Mounting: Double-stud or solid wall
Fits most: 52-90" (132–228 cm) TVs
Supports up to: 200 lbs (90 kg)
Mounting profile: 0.7" (1.8 cm)
Universal & VESA compliant: 400x400 to
600x400
Mounting: 16" or 24" double-stud; solid wall
Post installation leveling
5-year warranty
Available in Black
Revolutionary design allows you to
interact with your TV when watching
movies, gaming, exercising and more
Offers smooth, continuous
movement of the TV in all directions
Patented Constant Force™
technology enables light-touch
adjustments without knobs or levers
Enhance picture and 3D viewing with
the right screen angle
Improves ergonomic viewing for TVs
mounted high on the wall
Tilt, pan and swivel for maximum
viewing flexibility
Screen can be rotated for portrait or
landscape viewing
EXTENDS
."
Cable management clips route wires
Includes complete hardware kit
Single-stud or solid wall mounting
5-year warranty
Available in Polished aluminum
10
TV WALL MOUNTS
TV WALL MOUNTS
11
ACTIONMOUNT SERIES
ACTIONMOUNT SERIES
THE LIFT IS THE FIRST LOW PROFILE
PLAY
WALL MOUNT TO OFFER SMOOTH LIFT/
LOWER MOVEMENT OF A TV. USERS CAN
LIFT
ADJUST THEIR TV FOR ANY ACTIVITY,
POSITIONING IT FOR BEST PICTURE
AND COMFORT WHILE WATCHING
MOVIES, GAMING, EXERCISING OR
OPTIMIZING 3D. THE LIFT IS EQUIPPED
EXTENDS
."
WITH PATENTED CONSTANT FORCE™
PLAY40
PLAY40DS
PLAY70
INTERACTIVE TV MOUNT
INTERACTIVE TV MOUNT
INTERACTIVE TV MOUNT
Fits most: 30–55" (76–140 cm) TVs/displays
Supports: 18–40 lbs (8.2–18.2 kg)
Tilt: +10° to -15°
Pan: 180°
Mounting profile: 5.5" (14 cm)
Maximum extension: 24" (61 cm)
Horizontal movement: 20" (51 cm)
Vertical adjustment: 20" (51 cm)
Post-installation leveling: +/-5°
VESA compliant: 200x100 to 600x400
Mounting: Single-stud or solid wall
Available in Polished aluminum
Fits most: 30–55" (76–140 cm) TVs/displays
Supports: 18–40 lbs (8.2–18.2 kg)
Tilt: +10° to -15°
Pan: 180°
Mounting profile: 5.5" (14 cm)
Maximum extension: 24" (61 cm)
Horizontal movement: 42" (107 cm)
Vertical adjustment: 20" (51 cm)
Post-installation leveling: +/-5°
VESA compliant: 200x100 to 600x400
Mounting: Double-stud or solid wall
Available in Black
Fits most: 40–60" (101–152 cm) TVs/displays
Supports: 35–70 lbs (15.9–31.8 kg)
Tilt: +15° to -10°
Pan: 180°
Mounting profile: 6.5" (16.5 cm)
Maximum extension: 28" (71 cm)
Horizontal movement: 21.1" (53.5 cm)
Vertical adjustment: 20" (51 cm)
VESA compliant: 200x100 to 600x400
Mounting: Single-stud or solid wall
Available in Polished aluminum
TECHNOLOGY, PROVIDING FLUID, LIGHTTOUCH ADJUSTMENTS FOR EFFORTLESS
LIFTING AND LOWERING OF A TV.
LIFT30
LIFT30X
INTERACTIVE TV MOUNT
INTERACTIVE TV MOUNT
Fits most: 27–42" (69–107 cm) TVs/displays
Fits most: 27–42" (69–107 cm) TVs/displays
Supports up to: 12–30 lbs (5.4-13.6 kg)
Mounting profile: 4.3" (10.9 cm)
Maximum extension: 10.8" (27.3 cm)
VESA compliant: 100x100 to 400x400
Tilt: 0° to 10°
Horizontal movement: 13" (33 cm)
Vertical adjustment: 10" (25.4 cm) of travel
Mounting: Single wood stud or solid wall
Supports up to: 12–30 lbs (5.4–13.6 kg)
Mounting profile: 2.7" (6.9 cm)
VESA compliant: 100x100 to 400x400
Vertical adjustment: 10" (25.4 cm) of travel
Mounting: Single wood stud or solid wall
Lift and lower your TV to achieve
the best picture and sound
Move with only a light touch; no
knobs or levers required
Ideal for multipurpose rooms and
TV activities
Post-installation leveling
Lift n’ Lock makes installation a
three-step process
PLAY70DS
Includes complete hardware kit
for easy installation
INTERACTIVE TV MOUNT
5-year warranty
Available in Black
Fits most: 30–60" (76–152 cm) TVs/displays
Supports: 35–70 lbs (15.9–31.8 kg)
Tilt: +15° to -10°
Pan: 180°
Mounting profile: 6.5" (16.5 cm)
Maximum extension: 28" (71 cm)
Horizontal movement: 21.1" (53.5 cm)
Vertical adjustment: 20" (51 cm)
VESA compliant: 200x100 to 600x400
Mounting: Double-stud or solid wall
Available in Black
LIFT50
LIFT70
INTERACTIVE TV MOUNT
INTERACTIVE TV MOUNT
Fits most: 40–50" (102–127 cm) TVs/displays
Fits most: 46–65" (117–165 cm) TVs/displays
Supports up to: 45–70 lbs (20.4–31.8 kg)
Vertical adjustment: 16" (40.6 cm)
Tilt: up to 10°
Mounting profile: 2.7" (6.9 cm)
VESA compliant: 200x200 to 400x400
Mounting: Single-stud and drywall
or solid wall
Supports up to: 30–50 lbs (13.6–22.7 kg)
Vertical adjustment: 16" (40.6 cm)
Tilt: up to 10°
Mounting profile: 2.7" (6.9 cm)
SEE IT IN ACTION
Scan the code below or visit
omnimount.com/127 to see how
the LIFT50 and LIFT70 work.
VESA compliant: 200x200 to 400x400
Mounting: Single-stud and drywall
or solid wall
The PLAY products are equipped with
patented Constant Force™ technology
providing fluid, light-touch adjustments
for effortless arm movement.
12
TV WALL MOUNTS
TV WALL MOUNTS
13
OMNISELECT SERIES
OMNISELECT SERIES
The OmniSelect Series is designed to make
repositioning a TV smooth and easy while ensuring
that it stays in the desired place. Quality craftsmanship
ensures a lifetime of dependable performance.
TILT
DESIGNED WITH PATENTED
Equipped with patented gravity tilt,
providing perfect tension no matter
where you place your TV
GRAVITY TILT AND PRECISE
TOLERANCES TO MAKE
ADJUSTING A TV EASY AND
RELIABLE
FULL MOTION
OS50FM
OS80FM
OS120FM
SMALL FULL MOTION MOUNT
MEDIUM FULL MOTION MOUNT
LARGE FULL MOTION MOUNT
Fits most: 13–37" (33–94 cm) TVs
Supports up to: 50 lbs (22.7 kg)
Tilt: +10° to -1°
Mounting profile: 2.3" (5.7 cm)*
Extension from wall: 11.4" (28.9 cm)*
VESA compliant: 75x75 to 200x200
Post installation leveling: +/-3°
Mounting: Single-stud or solid wall
*adapters add 0.3" (8 mm)
Fits most: 32–50" (82–127 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Tilt: +10° to -3°
Mounting profile: 2.8" (7 cm)*
Extension from wall: 14.6" (37 cm)*
VESA compliant: 100x100 to 400x400
Post installation leveling: +/-3°
Mounting: Single-stud or solid wall
*adapters add 0.1" (5 mm)
Fits most: 42–70" (107–178 cm) TVs
Supports up to: 120 lbs (54.4 kg)
Tilt: +10° to -3°
Mounting profile: 3.0" (7.6 cm)*
Extension from wall: 16.5" (42 cm)*
VESA compliant: 100x100 to 600x400
Post installation leveling: +/-3°
Mounting: Single-stud, Double-stud or solid wall
Wall plate offers lateral adjustment to center TV
*adapters add 0.1" (5 mm)
Lift n’ Lock allows you to easily
attach your TV to the mount
PANS
Adequate spacing between TV and
wall allows for cooling
OS40TP
OS50T
Provides ample room for cables and
wires between TV and wall
SMALL TILTING MOUNT
SMALL TILTING MOUNT
Durable powder coat finish
Fits most: 13–37" (33–94 cm) TVs
Supports up to: 40 lbs (18.1 kg)
Tilt: +10° to -3°
Pan: 25°
Mounting profile: 3.0" (7.6 cm)*
VESA compliant: 75x75 to 200x200
Mounting: Single-stud or solid wall
Offers 25° of pan for side-to-side movement
to find the perfect viewing angle
Offers 6° of post-installation leveling of the
mount
*adapters add 0.3" (6 mm)
Fits most: 13–37" (33–94 cm) TVs
Supports up to: 50 lbs (22.7 kg)
Tilt: Up to +18°
Mounting profile: 2.1" (5.2 cm)*
VESA compliant: 75x75 to 200x200
Mounting: Single-stud or solid wall
Low 2.1" (52 mm) mounting profile
*adapters add 0.2" (6 mm)
Simple to install and use
Ships fully assembled
Includes adapters for greater VESA
compatibility
Includes complete hardware kit
5-year warranty
Available in Black
Low 2.1" (54 mm) mounting profile
Tilt up to 10° to reduce glare
Low profile design nests TV close to
the wall
Equipped with patented gravity tilt,
providing perfect tension no matter
where you place your TV
Tilts to reduce screen glare
Pans left and right between rooms or
seating areas
Lift n’ Lock enables easy three-step
installation
Fluidly repositions TV and holds in
desired position
Lift n’ Lock enables easy three-step
installation
Special channel routes cables from
TV to wall
Leveling feature for fine-tune
adjustments
Die-cast arm for strength and style
Includes complete hardware kit
5-year warranty
Available in Black
14
TV WALL MOUNTS
Offers adequate spacing between
TV and wall for cooling and cable
management
OS80T
OS120T
MEDIUM TILTING MOUNT
LARGE TILTING MOUNT
Fits most: 37–55" (94–140 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Tilt: Up to 10°
Mounting profile: 2.1" (5.4 cm)
Universal & VESA compliant: 100x100 to
400x400
Mounting: Double-stud or solid wall
Fits most: 37–70" (94–178 cm) TVs
Supports up to: 120 lbs (54.4 kg)
Tilt: Up to 10°
Mounting profile: 2.1" (5.4 cm)
Universal & VESA compliant: 100x100 to
600x400
Mounting: 16" or 24" double-stud; solid wall
Endcaps present a clean sideview
Sliding lateral on-wall adjustment
Safety latches prevent TV from
sliding off mount
Single wall plate allows for quick and
simple installation
Durable powder coat finish
Includes complete hardware kit
5-year warranty
Available in Black
TV WALL MOUNTS
15
OMNISELECT SERIES
OMNICLASSIC SERIES
FIXED
Low profile design
Lift n’ Lock allows you to easily
attach your TV to the mount
The OmniClassic Series provides a complete range of full motion, tilt and fixed
mounting solutions for basic installations. Each mount is designed with simplicity
and reliability.
Allows for simple leveling
adjustments post-installation
Offers adequate spacing between
TV and wall for cooling and cable
management
FULL MOTION
Durable powder coat finish
OS50F
OS120F
SMALL FIXED MOUNT
LARGE FIXED MOUNT
Fits most: 13–37" (33–94 cm) TVs
Supports up to: 50 lbs (22.7 kg)
Mounting profile: 1.1" (2.8 cm)*
VESA compliant: 75x75 to 200x200
Mounting: Single-stud or solid wall
Low 1.1" (2.8 cm) mounting profile
Includes adapters for greater VESA
compatibility
Ships fully assembled
*adapters add 0.2" (6 mm)
Fits most: 37–70" (94–178 cm) TVs
Supports up to: 120 lbs (54.4 kg)
Mounting profile: 1.6" (4.1 cm)
VESA compliant: 100x100 to 600x400
Mounting: 16" or 24" double-stud; solid wall
Low 1.6" (4.1 cm) mounting profile
Simple to install and use
Includes complete hardware kit
Tilt, pan and swivel for maximum
viewing flexibility
5-year warranty
Integrated cable management
Available in Black
Tilt forward or back to reduce glare
or for overhead installations
Pan display left or right to view from
multiple rooms or seating areas
Included adapters fit a wide range of
VESA patterns
Sliding lateral on-wall adjustment
Lift n’ Lock enables easy three-step
installation
Endcaps present a clean sideview
Includes complete hardware kit
Safety locks prevent TV from sliding off mount
5-year warranty
Single wall plate allows for quick and simple
installation
Available in Black
OC40FM
OC40FMX
SMALL FULL MOTION MOUNT
SMALL FULL MOTION MOUNT
Fits most: 13-37" (33–94 cm) TVs
Supports up to: 40 lbs (18.1 kg)
Tilt: +15° to -5°
Pan: up to 180°
Mounting profile: 3.2" (8.2 cm)*
Maximum extension: 9.5" (24 cm)*
VESA compliant: 75x75 to 200x200
Mounting: Single-stud or solid wall
Safety screw secures TV to mount
*adapters add 0.2" (6 mm)
Fits most: 13–37" (33–94 cm) TVs
Supports up to: 40 lbs (18.1 kg)
Tilt: +15° to -5°
Pan: +90° to -90°
Mounting profile: 3" (7.6 cm)*
Maximum extension: 13.7" (35 cm)*
VESA compliant: 75x75 to 200x200
Mounting: Single-stud or solid wall
*adapters add 0.2" (6 mm)
OS80F
MEDIUM FIXED MOUNT
Fits most: 37–55" (94–140 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Mounting profile: 1.7" (4.2 cm)
Universal & VESA compliant: 100x100 to
400x400
Mounting: Double-stud or solid wall
Low 1.7" (4.2 cm) mounting profile
Sliding lateral on-wall adjustment
Endcaps present a clean sideview
Safety latches prevent TV from sliding
off mount
Single wall plate allows for quick and simple
installation
16
TV WALL MOUNTS
TV WALL MOUNTS
17
OMNICLASSIC SERIES
OMNICLASSIC SERIES
FULL MOTION
TILT
Tilt, pan and swivel for maximum
viewing flexibility
Integrated cable management
Low profile offers sufficient room
for cable connections and cooling
while keeping TV close to the wall
Tilt forward or back to reduce glare
or for overhead installations
Tilt TV forward to reduce glare or
for overhead installations
Pan display left or right to view from
multiple rooms or seating areas
Lift n’ Lock feature offers easy,
three-step installation
Included adapters fit a wide range of
VESA patterns
OC80FM
OC120FM
Lift n’ Lock enables easy three-step
installation
MEDIUM FULL MOTION MOUNT
LARGE FULL MOTION MOUNT
Includes complete hardware kit
5-year warranty
Available in Black
Fits most: 37–63" (94–160 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Tilt: +15° to -5°
Pan: Up to 180°
Mounting profile: 3.2" (8.2 cm)*
Maximum extension: 14" (35.7 cm)*
VESA compliant: 200x200 to 600x400
Mounting: Single-stud or solid wall
Low 3.2" (8.2 cm) mounting profile
*adapters add 0.2" (6 mm)
Fits most: 43–70" (109–178 cm) TVs
Supports up to: 120 lbs (54.4 kg)
Tilt: +15° to -1°
Mounting profile: 3.8" (9.7 cm)*
Maximum extension: 19" (48.3 cm)*
VESA compliance: 200x200 to 600x400
Mounting: Double-stud or solid wall
2.9" (7.4 cm) of lateral adjustment makes TV
centering possible
Open frame provides ample room for power
and AV cutouts behind TV
*adapters add 0.17" (4 mm)
TILT
OC150T
OC175T
Vertical rails fit VESA and non-VESA
TVs and slide on wall plate for minor
left/right repositioning
LARGE TILTING MOUNT
LARGE TILTING MOUNT
Locking bar secures TV to mount
Fits most: 37–80" (94–203 cm) TVs
Supports up to: 150 lbs (68 kg)
Mounting profile: 1.7" (4.3 cm)
Universal & VESA compliant: 200x200 to
600x400
Tilt: 0° / +5° / +10°
Mounting: 16" or 24" double-stud; solid wall
Open frame provides ample room for power
and AV cutouts behind TV
Fits most: 37–80" (94–203 cm) TVs
Supports up to: 175 lbs (79.4 kg)
Mounting profile: 2.7" (6.9 cm)
Universal & VESA compliant: 100x100 to
600x400
Tilt: Up to +15°
Mounting: 16" or 24" double-stud; solid wall
Pinned tilt offers uniformity for panels
mounted side-by-side
Ideal for TVs with bottom or side-loading
connectors
Horizontal wall plate requires only two holes
for quick installation
Wall plate has integrated level
Small footprint provides ample room
for power and AV cutouts behind TV
Includes complete hardware kit
5-year warranty
Available in Black
Low profile offers sufficient room
for cable connections and cooling
while keeping TV close to the wall
Tilt TV forward to reduce glare or
for overhead installations
Lift n’ Lock feature offers easy,
three-step installation
OC80T
OC100T
MEDIUM TILTING MOUNT
MEDIUM TILTING MOUNT
Fits most: 23–42" (58–107 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Tilt: +15° to -5°
Mounting profile: 2.3" (5.8 cm)
Universal & VESA compliant: 100x100 to
400x300
Mounting: Double-stud or solid wall
Open frame provides ample room for power
and AV cutouts behind TV
Fits most: 23–42" (58–107 cm) TVs
Supports up to: 100 lbs (45.4 kg)
Mounting profile: 1.7" (4.3 cm)
Universal & VESA compliant: 100x100 to
400x300
Tilt: 0° / +5° / +10°
Mounting: Double-stud or solid wall
Pinned tilt offers uniformity for panels
mounted side-by-side
Ideal for TVs with bottom or side-loading
connectors
Horizontal wall plate requires only two holes
for quick installation
Wall plate has integrated level
Small footprint provides ample room
for power and AV cutouts behind TV
18
TV WALL MOUNTS
Vertical rails fit VESA and non-VESA
TVs and slide on wall plate for minor
left/right repositioning
Locking bar secures TV to mount
Includes complete hardware kit
5-year warranty
Available in Black
TV WALL MOUNTS
19
OMNICLASSIC SERIES
EZMOUNT SERIES
FIXED
Low profile offers sufficient room for
cable connections and cooling while
keeping TV close to the wall
Lift n’ Lock feature offers easy,
three-step installation
OC40F
The EZMount is the world’s easiest, strongest, most
discreet way to hang a flat panel TV. It’s truly a
revolutionary mounting system designed for do-ityourselfers looking to hang a TV anywhere – with or
without studs. It mounts in three easy steps, offers an
impressively low mounting profile and comes with just
about everything you need to mount it right in the box.
Locking bar secures TV to mount
Includes complete hardware kit
5-year warranty
Available in Black
Vertical rails fit VESA and non-VESA
TVs and slide on wall plate for minor
left/right repositioning
SMALL FIXED MOUNT
Fits most: 13–37" (33–94 cm) TVs
Attach
Supports up to: 40 lbs (18.1 kg)
Mounting profile: 0.5" (1.3 cm)*
VESA compliant: 75x75 to 200x200
Mounting: Single-stud or solid wall
*adapters add 0.2" (6 mm)
Lift n’ Lock makes installation a
three-step process
Safety screw secures TV to mount
Adapters for VESA compatibility up
to 200x200 included
Includes complete hardware kit
5-year warranty
Available in Black
OC80F
OC100F
MEDIUM FIXED MOUNT
MEDIUM FIXED MOUNT
Fits most: 23–42" (58–107 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Mounting profile: 1.6" (4.1 cm)
Universal & VESA compliant: 100x100 to
400x300
Mounting: Double-stud or solid wall
Open frame provides ample room for power
and AV cutouts behind TV
Fits most: 23–42" (58–107 cm) TVs
Supports up to: 100 lbs (45.4 kg)
Mounting profile: 1.3" (3.3 cm)
Universal & VESA compliant: 100x100 to
400x300
Mounting: Double-stud or solid wall
Ideal for TVs with bottom or side-loading
connectors
Horizontal wall plate requires only two holes
for quick installation
Wall plate has integrated level
Small footprint provides ample room
for power and AV cutouts behind TV
Mount
OMF
OMH
SMALL FIXED MOUNT
MEDIUM FIXED MOUNT
Fits most: 13–46" (33–117 cm) TVs
Supports up to: 40 lbs (18.1 kg) in drywall and
80 lbs (36.3 kg) in a single stud or concrete
Mounting profile: 1" (2.5 cm)
Universal & VESA compliant: 100x100 to
400x400
Mounting: Drywall, single-stud or solid wall
Fits most: 32–60" (81–152 cm) TVs
Supports up to: 80 lbs (36.3 kg)
Mounting profile: 1.3" (3.3 cm)
VESA compliant: Universal & 200–600 mm
wide
Leveling: +/- 5°
Mounting: Single-stud or solid wall
Hang
Revolutionary design allows you to
interact with your lightweight TV
and is perfect for kitchen, dorm,
bathroom and home office activities
OC150F
20
TV WALL MOUNTS
Mount your TV with total ease and
confidence anywhere – no studs
required
OC175F
LARGE FIXED MOUNT
LARGE FIXED MOUNT
Fits most: 37–80" (94–203 cm) TVs
Supports up to: 150 lbs (68 kg)
Mounting profile: 1.3" (3.3 cm)
Universal & VESA compliant: 200x200 to
600x400
Mounting: 16" or 24" double-stud; solid wall
Ideal for TVs with bottom or side-loading
connectors
Horizontal wall plate requires only two holes
for quick installation
Wall plate has integrated level
Small footprint provides ample room
for power and AV cutouts behind TV
Fits most: 37–90" (94–229 cm) TVs
Precut installation template with
mounting holes for simple and
accurate mounting
Lift n’ Lock allows you to easily
attach your TV to the mount
Supports up to: 175 lbs (79.4 kg)
Mounting profile: 1.7" (4.4 cm)
Universal & VESA compliant: 100x100 to
600x400
Mounting: 16" or 24" double-stud; solid wall
Open frame provides ample room for power
and AV cutouts behind TV
THE SIMPLE, SLEEK DESIGN
LOOKS GREAT AND INSTALLS IN
UNDER 10 MINUTES
Installs in just minutes with included
drill bit, level and installation
template
Wall brackets rotate 90° to lock TV
in place
Designed to install in under 10
minutes
Sleek look complements modern TVs
Low profile for floating effect
Lift n’ Lock feature offers easy,
three-step installation
Foam wedge holds TV away from
wall for one-person wiring
Locking mechanism prevents
accidental TV removal
Requires only two mounting holes
Includes complete hardware kit
5-year warranty
Available in Polished aluminum
Includes complete hardware kit
5-year warranty
Available in Black
TV WALL MOUNTS
21
OMNIPRO SERIES
OMNIPRO SERIES
The OmniPro series gives pro installers a handful of high end products that easily meet
the requirements of most installations – no need to explore a myriad of options or place
special orders. These products can be easily carried around in a truck and installed
whenever the need arises.
TILT
FIXED
Low profile offers sufficient room
for cable connections and cooling
while keeping TV close to the wall
Tilt TV to reduce glare or for
overhead installations
Lift n’ Lock feature makes singleperson installation possible
Open frame provides ample room for
power and AV cutouts behind TV
FULL MOTION
Vertical rails fit VESA and
non-VESA TVs
Arms completely nest for a discreet
3.4" (8.5 cm)* mounting profile
Vertical rails slide on wall plate for
minor left/right repositioning
Tilt, pan and swivel for maximum
viewing flexibility
Locking bar secures TV to mount
Steel tube double-arm construction
for maximum strength and durability
Includes universal adapter for
greater VESA compatibility
Rack-and-pinion tilt mechanism for
effortless adjustment
Integrated cable management with
quick-snap covers guide wires
Built-in screen leveling
Lift n’ Lock for quick installation
Sliding on-wall adjustment (6" lateral;
2" vertical)
Wide wall plate design for 16", 24" or
600 mm studs
Safety screw secures TV to mount
Wall plate covers conceal mounting
hardware
Includes installation template for
simple and accurate mounting
3.4"
(8.5 cm)
CI250FM
EXTRA LARGE FULL MOTION MOUNT
Fits most: 42–90" (107-229 cm) TVs
Supports up to: 250 lbs (113.4 kg)
Tilt: +15° to -5°
Mounting profile: 3.4" (8.5 cm)*
Maximum extension: 25.1" (63.7 cm)*
Universal & VESA compliant: 200x100 to
900x500
Mounting: Double-stud or solid wall
*adapter adds 0.8" (2 cm)
With OmniMount’s CI250FM, your
customers will get everything they want
in one mount – the functionality and
versatility of a full motion mount in a
compact and discreet design
Includes complete hardware kit
5-year warranty
Available in Black
CI175T
CI175F
LARGE TILTING MOUNT
LARGE FIXED MOUNT
Fits most: 37–80" (94–203 cm) TVs
Supports up to: 175 lbs (79.4 kg)
Mounting profile: 2.7" (6.9 cm)
Universal & VESA compliant: 100x100 to
600x400
Tilt: Up to +15°
Mounting: 16" or 24" double-stud; solid wall
Fits most: 37–90" (94–229 cm) TVs
Supports up to: 175 lbs (79.4 kg)
Mounting profile: 1.7" (4.4 cm)
Universal & VESA compliant: 100x100 to
600x400
Mounting: 16" or 24" double-stud; solid wall
Low profile offers sufficient room
for cable connections and cooling
while keeping TV close to the wall
Lift n’ Lock feature makes singleperson installation possible
Open frame provides ample room for
power and AV cutouts behind TV
Vertical rails fit VESA and
non-VESA TVs
Vertical rails slide on wall plate for
minor left/right repositioning
Locking bar secures TV to mount
Includes complete hardware kit
5-year warranty
Available in Black
5-year warranty
Available in Black
Safety screw secures TV
to mount
22
TV WALL MOUNTS
TV WALL MOUNTS
23
WORKFIT COMPUTER MOUNTS
Stand up and innovate! This sleek, height-adjustable workstation is made so that you
can stand more, sit less, and become healthier doing so. The advanced ergonomics and
uncompromising style of the WorkFit are proportioned so that your body, space and
passion all function in perfect harmony.
WORKFIT-A
WORKFIT-A VESA MOUNT
WORKFIT-P
SIT-STAND WORKSTATION
SIT-STAND WORKSTATION
SIT-STAND WORKSTATION
24-431-227
24-433-026
24-432-227
Fits most: 21.5–27" (54.6–68.5 cm) screens
Supports up to: 12–27.5 lbs* (5.5–12.5 kg)
Tilt: 30° (Screen tilt of 30° built into iMac base)
Keyboard tray tilt range: 20°
Lift: 19" (48 cm)
Pan: 180°
Mounting: Desk Clamp or Grommet Mount
Optimized for the latest iMac®
*see website for details
Aluminum construction
Fluid, one-touch motion with
patented CF™ technology
Designed to perfectly complement
the look of your Mac®
Keyboard tilts
Fits most: Screens up to 27" (68.5 cm)
Supports up to: 9–24 lbs* (4.1–10.9 kg)
Tilt: 30°
Keyboard tray tilt range: 20°
Lift: 19" (48 cm)
Pan: 180°
VESA compliant: 75x75 to 100x100
Mounting: Desk Clamp or Grommet Mount
*see website for details
Supports up to: 10 lbs (4.5 kg )
Lift: 20" (51 cm)
Pan: 360°
Mounting: Desk Clamp or Grommet Mount
Clamps to back edge of desks up to
31.5" (800 mm) deep
Generous worksurface, perfect for
laptops
Grommet mounts through holes in
desks up to 29.5" (749 mm) deep
Aluminum construction
5-year warranty
Fluid, one-touch motion with
patented CF technology
Designed to perfectly complement
the look of your Mac
Clamps to back edge of desks or
grommet mounts through holes
0.78–2.56" (20–65 mm) thick
WorkFit
24
WORKFIT
5-year warranty
WORKFIT
25
iPAD MOUNTS
With home automation and general iPad use being all the rage, naturally there came
a need for iPad mounts and stands. Our collection of cases, wall mounts and surface
stands work together to create the ideal balance of mobility and comfort, offering a
great solution for iPad devices being used in multiple rooms for multiple purposes.
Articulating Wall Mount
CASE & ADJUSTABLE STAND
CASE & MOUNT
FOR iPAD mini™
FOR iPAD mini
FOR iPAD AIR™
FOR iPAD AIR
FOR iPAD GEN 2-3-4
FOR iPAD GEN 2-3-4
3 convenient attachment and usage options:
Use as a desktop stand
Mount under your cabinet
Attach to a wall
Adjust the tilt and angle for perfect viewing
Fold flat for transporting
Ultra thin protective case
Works with Apple® Smart Cover®
Case and Stand duo offers versatility and
protection for your device
Case cutouts allow access to camera and
controls
Slim design and tactile surface
Simple, magnetic connection
Ultra-thin protective case
Works with Apple Smart Cover
Case and Mount duo offers versatility and
protection for your device
Mount or move your iPad in seconds
Case cutouts allow access to camera and
controls
Slim design and tactile surface
Mount on wall or any VESA 100 mount
Help keep your iPad safe, secure and
in perfect view for hands-free use
whenever, wherever
Table Top Stand
iPad Mounts
®
Perfect when using an iPad for home
automation and control
Great for use in the kitchen,
bedroom and office
5-year warranty
Under-Cabinet Mount
26
iPAD MOUNTS
Simple, magnetic connection offers
easy on, easy off
MOUNT
FOR iPAD
Increase the versatility of your iPad with
additional wall mounts
Store or display an iPad in the kitchen,
bedroom, office, bathroom, hallway and more
Easily move an iPad from one place to the next
Mount on wall or to any VESA 100 mount,
like a full motion wall mount, for even greater
flexibility
Works with OmniMount iPad protective case
iPAD MOUNTS
27
AV WALL SHELVES
OmniMount wall shelves offer a fresh approach to managing cables and components.
Designed as affordable, space-saving accessories to your TV or simply as stand-alone
pieces, these solutions allow you to neatly organize components under a TV without
running connections through the wall.
BLADE SERIES
Low 1.2" (30 mm) profile complements
ultra-thin TVs
Simple installation with one-piece
frame and flip-down shelf
Modular design makes pieces
stackable
Ideal for placing components like
DVD players, cable boxes, video game
consoles and more, near the TV
DID YOU KNOW?
The Blade Series has integrated
cable management that hides
wires and routes them to
components.
Integrated cable management hides
wires
Can be mounted under a flat panel or
as a stand-alone unit
5-year warranty
Satin Black finish is paintable to match
any wall color
BLADE2
LOW-PROFILE AV WALL SHELVES
Two cascading tempered glass shelves
support up to 35 lbs (15.9 kg) (double-stud) or
25 lbs (11.4 kg) (single-stud) each
Mounting profile: 1.2" (3 cm)
Mounting: Single- or double-stud
Color: Satin Black with black glass
Dimensions: 22.3"w x 24"h x 16.2"d
(565 mm x 610 mm x 411 mm)
Glass thickness: 6 mm
BLADE SERIES WALL FURNITURE PIECES
Blade1 without cover
COMBINE FUNCTION WITH COOL.
WITH LOW MOUNTING PROFILES
THAT MAKE THEM THE PERFECT
COMPLEMENT TO ULTRA-THIN TVs AND
AV Wall Shelves
28
AV WALL SHELVES
SHELVES THAT FLIP DOWN FOR EASE
OF INSTALLATION, THESE PIECES ARE
GREAT ADDITIONS TO YOUR HOME
THEATER.
Blade1 with cover
BLADE1
LOW-PROFILE AV WALL SHELF
Tempered glass shelf supports up to
35 lbs (15.9 kg) (double-stud) or 25 lbs (11.4 kg)
(single-stud)
Mounting profile: 1.2" (3 cm)
Mounting: Single- or double-stud
Color: Satin Black with black glass
Dimensions: 22.5"w x 11.9"h x 16.1"d
(572 mm x 302 mm x 409 mm)
Glass thickness: 6 mm
AV WALL SHELVES
29
AV WALL SHELVES
AV WALL SHELVES
TRIA SERIES
MOD1
ECS
COMINGSOON!
LOW-PROFILE AV WALL SHELF
LOW-PROFILE AV WALL SHELF
Supports up to: 30 lbs (13.6 kg) maximum
shelf capacity
Mounting profile: 0.94" (2.4 cm)
Mounting: Single-stud
Dimensions: 17.5"w x 13.7"h x 13.4"d
(445 mm x 351 mm x 337 mm)
Glass thickness: 6 mm
Supports up to: 30 lbs (13.6 kg) maximum
shelf capacity
Pan: 15˚ left and right
Mounting: Single-stud
Dimensions: 18.0"w x 9.1"h x 20.1"d
(457 mm x 231 mm x 571 mm)
Tempered glass thickness: 8 mm
OWS22
Ideal for placing components like
DVD players, cable boxes, video game
consoles and more, near the TV
Pivoting arm for side-to-side
movement
Stackable with additional MOD1s to
create a multiple shelf solution
Includes complete hardware kit
Engineered from extruded
aluminum with an anodized finish to
complement newer TVs
Wall plate hides bolts
5-year warranty
WALL SHELF
Supports up to: 22 lbs (10 kg) maximum
shelf capacity
Shelf dimensions: 16.5"w x 9.0"h x 11.4"d
(420 mm x 230 mm x 290 mm)
Tempered glass thickness: 5 mm
TRIA
TRIA 2
TRIA 1
ADJUSTABLE AV WALL SHELF
ADJUSTABLE AV WALL SHELF
ADJUSTABLE AV WALL SHELF
Three tempered glass shelves support up to
30 lbs (13.6 kg) each
Mounting: Single-stud
Dimensions: 17.5"w x 50"h x 16.5"d
(445 mm x 1270 mm x 419 mm)
Glass thickness: 6 mm
Compatible with Tria 1 and Tria 2
Two tempered glass shelves support up to
30 lbs (13.6 kg) each
Mounting: Single-stud
Dimensions: 17.5"w x 32.5"h x 16.5"d
(445 mm x 826 mm x 419 mm)
Glass thickness: 6 mm
Compatible with Tria 1
Tempered glass shelf supports up to 30 lbs
(13.6 kg)
Mounting: Single-stud
Dimensions: 17.5"w x 16.5"h x 16.5"d
(445 mm x 419 mm x 419 mm)
Glass thickness: 6 mm
Compatible with Tria 2
Available in Black with clear glass
Integrated cable management hides
wires
Fully adjustable shelves at 1"
increments
Refined construction and
components for smaller packaging
THE ELEGANTÉ COMPONENT WALL SHELF IS
Integrated cable management hides
wires
5-year warranty
AN EASY-TO-INSTALL SHELVING SOLUTION
Paintable and trimmable covers
Available in Black with black glass
THAT CAN BE USED WITH OR WITHOUT A
Easy to install
TV. THE PIVOTING ARM MAKES IT IDEAL FOR
Can be used with or without TV
CORNER MOUNTING AND ALLOWS YOU TO
5-year warranty
POSITION THE SHELF AS NEEDED.
Available in Black with black glass
WHY TRIA WALL FURNITURE?
Wall furniture makes it possible to hide wires from the component
to the outlet without having to run them through the wall.
THE TRIA SERIES WALL SHELVES OFFER
HASSLE-FREE SHELVING AND CABLE
MANAGEMENT SOLUTIONS SUITABLE FOR
ANY ENVIRONMENT AND CAN BE USED WITH
THE MOD1 IS A LOW-PROFILE AV WALL SHELF
THAT CAN BE USED ALONE OR STACKED
WITH ADDITIONAL PIECES TO ORGANIZE
COMPONENTS RIGHT UNDER YOUR TV.
30
AV WALL SHELVES
OR WITHOUT A TV. USER-FRIENDLY FEATURES
LIKE ADJUSTABLE SHELVES AND PAINTABLE,
TRIMMABLE COVERS MAKE THEM GREAT FOR
ANY APPLICATION.
AV WALL SHELVES
31
Ceiling Mounts
CEILING
MOUNTS
DCM250
DOUBLE TILT TV MOUNT
Fits most: 32–65" (81–165 cm) TVs
Supports up to: 250 lbs (113.4 kg)
Tilt: Up to 25° in 5° increments
Pipe drop: 24"
VESA compliant: 200x100 to 600x400
Mounting: Ceiling
Supports two panels for back-to-back
mounting
Portrait or landscape orientation
Includes universal adapter(s), ceiling
plate and Grade 5 hardware kit
Tension adjustment for variable tilt
or locking pin for precise positioning
Route cables through pipe and
ceiling plate for a clean installation
Lift n’ Lock for a fast, one-person
install
Standard thread works with any 1.5"
NPT pipe
Threaded bottom pipe for additional
accessories
Anti-theft security hardware
& Projector
Mounts
32
CEILING MOUNTS & PROJECTOR MOUNTS
5-year warranty
Available in Black
CEILING MOUNTS & PROJECTOR MOUNTS
33
CEILING MOUNTS
PROJECTOR MOUNTS
Portrait or landscape orientation
Complete out-of-box solution
includes ceiling plate, projector
mount and all necessary hardware
Includes universal adapter(s), ceiling
plate and Grade 5 hardware kit
Lift n’ Lock for a fast, one-person
install
Tension adjustment for variable tilt
or locking pin for precise positioning
Route cables through pipe and
ceiling plate for a clean installation
NPT extension pipes available in 12",
18" and 24" lengths
Lift n’ Lock for a fast, one-person
install
Available in Black
5-year warranty
Standard thread works with any 1.5"
NPT pipe
Threaded bottom pipe for additional
accessories
Anti-theft security hardware
5-year warranty
SCM125
Available in Black
SINGLE TILT TV MOUNT
Fits most: 32–65" (81–165 cm) TVs
Supports up to: 125 lbs (56.7 kg)
Tilt: Up to 25° in 5° increments
Pipe drop: 24"
VESA compliant: 200x100 to 600x400
Mounting: Ceiling
The SCM125 is equipped with a pin tilt
mechanism which tilts the TV at precise
increments making it well-suited for
single or multiple TV installations
PJT40's omni-directional turnbuckle
design makes positioning
the projector easy:
pitch and roll are interchangeable
and micro adjustments
are done by hand
PJT40
3N1-PJT/PRO-PJT
UNIVERSAL PROJECTOR MOUNT
UNIVERSAL PROJECTOR MOUNT
Fits: Small to large projectors
Supports up to: 40 lbs (18.1 kg)
Pitch: +/-16.5°
Roll: +/-16.5°
Yaw: +/-180°
Mounting: Single-stud or solid ceiling
Material: Steel
All exposed hardware has unique penta
shape for security
Patent-pending MicroDial™ design means
pitch and roll are interchangeable, and micro
adjustments are done by hand
Patent-pending QuickLock™ feature for
sliding connectors to the correct mounting
position; no tools required
Projector mount connectors can be tucked
up for a lower profile or extended to access
projector controls
Fits: Small to large projectors
Supports up to: 40 lbs (18.1 kg)
Pitch: +/- 15°
Roll: +/- 15°
Yaw: +/- 180°
Universal mounting pattern fits projectors
with any hole pattern
Legs adjustable from 5" to 19.8" diagonally for
small to large projectors
ACCESSORIES
34
CEILING MOUNTS & PROJECTOR MOUNTS
1.5" NPT EXTENSION PIPES
PFC-A
NPT12–12" Extension Pipe
NPT18–18" Extension Pipe
NPT24–24" Extension Pipe
Available in Black
FEMALE PIPE ADAPTER
For use with standard
1.5" NPT pipe
Integrated cable management
hides wires
Available in Black and Platinum
CEILING MOUNTS & PROJECTOR MOUNTS
35
Rack Systems & Carts
ENCLOSED RACK SYSTEMS
OmniMount offers several professional grade rack
systems for managing components and giving an
organized, polished look to any AV installation.
Standard 19" rack enclosure works
with all standard 19" rack accessories
Heavy-gauge steel construction
Fully enclosed cooling system with
top and bottom ventilation
Includes pre-installed cooling fans
on top
Lockable tempered-glass left- or
right-hinged front door
Removable side panels for easy
servicing
Adjustable feet level and stabilize
rack without interfering with casters
Top and bottom cable routing
knockouts
Front and back can be swapped and
are on hinges
Side panels are lockable (locks not
included)
Accepts front or rear rack mounted
components
RE18
ENCLOSED HALF-RACK SYSTEM
Includes:
(1) 18 space rack
(3) 2U space shelves: 16" deep
(3) 2U space solid blanks
Weight capacity:
RE18 supports up to 500 lbs (226.8 kg)
2U shelf supports up to 50 lbs (22.7 kg)
Caster base provides easy placement
inside closets or against walls
Ships assembled
Includes complete hardware kit
5-year warranty
Available in Black
ALL OMNIMOUNT RACKS
SHIP FULLY ASSEMBLED
36
RACK SYSTEMS & CARTS
RACK SYSTEMS & CARTS
37
ENCLOSED RACK SYSTEMS
THE PROHDCART
OFFERS:
The OmniMount PROHDCART provides vertical
adjustment and cable management to meet all your
mobile media needs.
Standard 19" rack enclosure works
with all standard 19" rack accessories
Heavy-gauge steel construction
Fully enclosed cooling system with
top and bottom ventilation
Includes pre-installed cooling fans
on top
SUPERIOR
PRODUCT DESIGN
Lockable tempered-glass left- or
right-hinged front door
Removable side panels for easy
servicing
Adjustable feet level and stabilize
rack without interfering with casters
Top and bottom cable routing
knockouts
Front and back can be swapped and
are on hinges
Side panels are lockable (locks not
included)
Accepts front or rear rack mounted
components
Caster base provides easy placement
inside closets or against walls
Ships assembled
RE27
RE42
ENCLOSED HALF-RACK SYSTEM
ENCLOSED HALF-RACK SYSTEM
Includes:
(1) 27 space rack
(5) 2U space shelves: (1) 18" deep; (4) 16" deep
(5) 2U space solid blanks
Weight capacity:
RE27 supports up to 750 lbs (340.2 kg)
2U shelf supports up to 50 lbs (22.7 kg)
Includes:
(1) 42-space rack
(2) 5U-space shelves with cable ties: 20" deep
(7) 2U-space shelves: 16" deep
(9) 2U-space solid blanks
Weight capacity:
RE42 supports up to 1100 lbs (500 kg)
5U shelf supports up to 100 lbs (45.4 kg)
2U shelf supports up to 50 lbs (22.7 kg)
Includes complete hardware kit
5-year warranty
Available in Black
ACCESSORIES
RE2USHELF
RE5USHELF
Add-on for the RE18,
RE27 and RE42 for managing
additional components
Accommodates heavier and extra-deep
components
Vented for component cooling
Durable powder coat finish
Shelf clamp secures component
Easy to install
Includes complete hardware kit
Supports up to: 50 lbs (23 kg)
Available in Black
Add-on for the RE18,
RE27 and RE42 for
managing additional
components
Accommodates heavier and extra-deep
components
Vented for component cooling
Durable powder coat finish
Shelf clamp secures component
Easy to install
Includes complete hardware kit
Supports up to: 100 lbs (45 kg)
Available in Black
RE2UBLANK
Add-on for the RE18, RE27 and
RE42 for a clean appearance
Durable powder
coat finish
Easy to install
Includes complete hardware kit
Available in Black
38
RACK SYSTEMS & CARTS
CARTS
Fully enclosed
cooling system
with top and
bottom ventilation
• Included adapters to fit a wide
range of TVs or LCD displays
• Integrated cable management
channels for organizing cables
(shown)
• Additional accessories
available (for custom tailored
units)
Telescoping post with locking pin
allows for height adjustment from 52”
to 72" in 1" increments
Includes universal adapter for
greater panel compatibility
Lift n’ Lock for quick installation
Displays can be mounted in portrait
or landscape orientation
Adjustable and lockable shelf comes
with component strap and can be
repositioned in 1" increments
Shelf can be positioned in front
or back to hide components when
needed
Integrated in-post cable management
CONVENIENT
FUNCTIONALITY
• Height adjustment to fit most
viewing needs (shown)
• Displays can be mounted
in portrait or landscape
orientation
• Caster base with four locking,
non-scuffing wheels for safe
and easy movement
PROHDCART
HEAVY-DUTY TV CART
Fits most 37–65" TVs
Supports up to: 125 lbs (56.7 kg)
(sum of shelves, components and TV)
Shelf capacity: 40 lbs (18.1 kg)
Tilt: +15° to -5°
Universal and VESA compliant: 200x100 to
900x500
AC cord wrap for hassle-free
transport
Nesting base for easy storing of
multiple carts
Caster base with four locking, nonscuffing 4" wheels provides safe and
easy movement over any surface
Rubberized bumpers won’t scuff
walls or doors
Quick assembly
Additional shelves available as an
accessory
Includes complete hardware kit
5-year warranty
Available in Black
Lockable
tempered glass
left- or righthinged front door
HASSLE-FREE
INSTALLATION
Top and bottom
cable routing
knockouts
• Speedy assembly and
installation
• Includes complete
hardware kit
Locking caster
base provides
easy placement
inside closets or
against walls –
adjustable feet
level and stabilize
RACK SYSTEMS & CARTS
39
SPEAKER STANDS & MOUNTS
Being not only the originator, but also the leader of
the category, there is no doubt that OmniMount offers
the most reliable and durable speaker mounts on the
market today.
GEMINI SERIES
Height adjustable post allows for
ideal listening position
Includes interchangeable bases for
four color options
In-post cable management hides up
to 14-gauge speaker wire
Steel isolation spikes minimize
vibration and stabilize base
5-year warranty
Available in Black
GEMINI 1
MEDIUM SATELLITE SPEAKER STAND
Fits most: Medium satellite speakers
Supports speakers up to: 8 lbs (3.6 kg)
Includes: Two speaker stands
Dimensions: 8.5"w x 31–45"h x 10.5"d
(216 mm x 787–1143 mm x 267 mm)
Includes four universal adapters for
maximum speaker compatibility
31" to 45" height adjustable post allows for
ideal listening position
GEMINI 2
LARGE SATELLITE SPEAKER STAND
Speaker Stands & Mounts
40
SPEAKER STANDS & MOUNTS
Fits most: Large bookshelf speakers
Supports speakers up to: 20 lbs (9.1 kg)
Includes: Two speaker stands
Dimensions: 11.5"w x 24"h x 13"d
(292 mm x 610 mm x 330 mm)
31" (787 mm) height with included extension
24" or 31" height for ideal listening position
(7" extension included)
Brushed
Stainless Steel
Cherry
High Gloss
Black
Espresso
SPEAKER STANDS & MOUNTS
41
SPEAKER STANDS & MOUNTS
ELO SERIES
SPEAKER MOUNTS
AUDIOBASICS™ SERIES
STAINLESS STEEL SERIES
Mount on wall or ceiling
Polymer-injected ball controls
resonance frequencies for better
sound
Stainless steel hardware for strength
and durability
Suitable for all-weather use
ELO
SMALL SATELLITE SPEAKER STAND
Fits most: Small satellite speakers
Supports speakers up to: 4 lbs (1.8 kg)
Includes: Two speaker stands
Dimensions: 11"w x 26–36"h x 10"d
(279 mm x 660–914 mm x 254 mm)
Includes three universal adapters for
maximum speaker compatibility
AB1
AB2
MICRO SATELLITE SPEAKER MOUNT
MEDIUM SATELLITE SPEAKER MOUNT
Fits most: Small satellite speakers
Supports up to: 2.5 lbs (1.1 kg)
Base rotation: 360°
Pan: 180°
Tilt: +/- 30°
Fits most: Bookshelf speakers
Supports up to: 8 lbs (3.6 kg)
Base rotation: 360°
Pan: 180°
Tilt: +/- 30°
Injection molded, glass reinforced
nylon
Includes two extensions that create
three different lengths
Suitable for all-weather use
Includes complete hardware kit
Maximum flexibility
5-year warranty
Mount on wall or ceiling
Available in Black
Ball and clamp design for greater
mounting flexibility
Includes clamp and jaw
Includes complete hardware kit
5-year warranty
Available in Black
5.0 W/C
10.0 W/C
SATELLITE SPEAKER MOUNT
BOOKSHELF SPEAKER MOUNT
Fits most: Satellite speakers
Supports up to: 5 lbs (2.3 kg)
Thread size: 4 mm or 5 mm
Tilt: +/-30°
Pan: 180°
Base rotation: 360°
Fits most: Bookshelf speakers
Supports up to: 10 lbs (4.5 kg)
Thread size: 1/4"-20
Tilt: +/-30°
Pan: 180°
Base rotation: 360°
STAINLESS STEEL
SPEAKER MOUNTS
OFFER:
26" to 36" height adjustable post
allows for ideal listening position
6 mm tempered glass base with
steel post
In-post cable management hides up to
14-gauge speaker wire
Rubberized isolation feet minimize
vibration and protect floors
SUPERIOR
PRODUCT DESIGN
5-year warranty
Available in High Gloss Black with
black glass
OCSBA
• Polymer-injected ball controls
resonance frequencies for
better sound (shown)
• Stainless steel hardware for
strength and durability
• Suitable for all-weather use
Easily attach most sound bars under
wall mounted TV
Works with most brands or styles of
TV mount
OCSBA ROTATES
Improves audio quality, especially
when used with full motion TV
mounts
FOR MULTIPLE INSTALLATION
Attaches to the back of a TV and
requires no holes in the wall
CONFIGURATIONS
Great for medium and large TVs
Includes all mounting hardware
5-year warranty
Available in Black
42
SPEAKER STANDS & MOUNTS
HASSLE-FREE
INSTALLATION
OCSBA
UNIVERSAL SOUND BAR MOUNT
Supports up to: 30 lbs (13.6 kg)
Fits most: 32" or larger TVs
• Ball and clamp design for
greater mounting flexibility
(shown)
• Includes complete
hardware kit
SPEAKER STANDS & MOUNTS
43
CABLE MANAGEMENT
Modular design allows for any
configuration
Covers can be cut to desired length
Paint to match any wall
OmniMount Essentials
Mount using screws or double sided
adhesive (both included)
Route wires vertically or horizontally
with 90° elbow
Includes installation template
CMK
4.3" CABLE MANAGEMENT KIT
Modular design allows for any configuration
Covers can be cut to desired length
Paint to match any wall
Routes wires vertically or horizontally with
90° elbow
Includes (3) 16" x 4.3" covers, (1) 90° elbow,
(2) end caps and installation template
CMK MINI
2.3" CABLE MANAGEMENT KIT
Modular design allows for any configuration
Covers can be cut to desired length
Paint to match any wall
Routes wires vertically or horizontally with
90° elbow
Includes (3) 16" x 2.3" covers, (1) 90° elbow,
(2) end caps and installation template
SAFETY KIT
OECMS
Works with any flat panel TV
CABLE MANAGEMENT SLEEVE
Prevents tipping to protect children
and pets
Form-fitting neoprene material is flexible
and allows for multiple cables
Cutouts every 2" provide multiple entry/exit
points for cables
Black/white sleeve is reversible to fit into
any environment
Ideal for flat panel TVs on furniture
within arm’s reach or in high-traffic
areas
Works with wood studs or
concrete wall
Steel cables are easily adjustable
using tensioning clamp
OESK
SAFETY KIT
Includes: 2 cables & hardware kit
Simple to install
Includes two adjustable length steel
cables and complete hardware kit
5-year warranty
Available in Black
SCREEN CLEANER
Multipurpose gel screen cleaner for
any viewing surface
Safely removes dirt, dust and
fingerprints
Alcohol- and ammonia-free non-drip
formula
Anti-static cleaner repels dust
Breathable case allows cloth to dry
Non-abrasive microfiber won’t
scratch surfaces
44
OMNIMOUNT ESSENTIALS
OESC2
2 OZ SCREEN CLEANER
Includes cleaning mitt
Stores in its own single DVD case
OMNIMOUNT ESSENTIALS
45
Line Drawings
inches (mm)
TV WALL MOUNTS
More line drawings available on OmniMount.com
OMNIELITE SERIES
16.7
(424)
19.5
(495)
8.9
(226)
Line Drawings
7.3
(185)
2.5
(64)
21.1
(535)
2.6
(66)
6.4
(163) 16.7
(424)
10.7
(271)
OE80FM — page 9
OE150FM — page 9
29.1
(738)
8.9
(225)
10.7
(271)
19.8
(504)
19.8
(504)
400.0
OE150T — page 10
0.7
(17)
32.2
(818)
0.7
(17)
25.0
TYP
400.0
25.0
TYP
21.6
(549)
OE80T — page 10
20.2
(513)
1.4
(35)
1.5
(38)
OE80F — page 10
OE200F — page 10
ACTIONMOUNT SERIES
16.7
14.0 (424)
(356)
23.0
(585)
11.5 (293)
25.8
(655)
2.9 (73)
4.2
(107)
12.5
(317)
6.3
(161)
7.4
(187)
7.4
(189)
13.7
(348)
PLAY20 (TOP VIEW) — page 11
1.9
(48)
14.9
(378)
PLAY20 (SIDE VIEW) — page 11
PLAY20X (SIDE VIEW) — page 11
20
(508)
3.4
(86)
12
(304) 20.1
(511)
4.1
(103)
8.4
(213)
3.1
(78)
PLAY25 (SIDE VIEW) — page 11
46
LINE DRAWINGS
PLAY25 (SIDE VIEW) — page 11
LINE DRAWINGS
47
Line Drawings
inches (mm)
TV WALL MOUNTS
TV WALL MOUNTS
ACTIONMOUNT SERIES
ACTIONMOUNT SERIES
19.5
(496)
15
(381)
9.2
(234)
2.8
(69)
3.5
(90)
13.8
(351)
PLAY40 (SIDE VIEW) — page 12
9.2
(234)
20.1
(510)
9.5
(242)
5.5
(140)
20.1
(511)
2.7
(69)
24.5
(622)
20.1
(510)
8.9
(225)
inches (mm)
20.2
12.2 (514)
(310)
2.7
(69)
10.7
(271)
10.4°
24
(610)
4.2
(108)
9.5°
20.2
12.2 (514)
(310)
4.2
(108)
19.5
(495)
*adapter adds .2" (5mm)
PLAY40 (TOP VIEW) — page 12
PLAY40DS (SIDE VIEW)— page 12
LIFT50 (SIDE VIEW) — page 13
LIFT70 (FRONT VIEW) — page 13
LIFT70 (SIDE VIEW) — page 13
OMNISELECT SERIES
10.1
(257)
6.0
(153)
25.3
(642)
10.1
(256)
14.0
(355)
3.3
(83)
20.1
(511)
PLAY70 (SIDE VIEW) — page 12
29.7
(755)
26.1
(664)
PLAY70 (TOP VIEW) — page 12
7.6
(192)
3.9 14.1
(100) (357)
PLAY70DS (FRONT VIEW) — page 12
6.5
(164)
10°
15.1
(384)
15.1
(384)
14.7
(375)
OS50FM (SIDE VIEW) — page 14
OS80FM (FRONT VIEW) — page 14
16.6
(423)
25.0
(634)
2.9
(75)
3.1
(81)
10
(254)
17.2
(437)
LIFT30 — page 13
20.1
(511)
OS80FM (SIDE VIEW) — page 14
8.7
(220)
10.7
(271)
12.1
(307)
7.6
(192)
OS50FM (FRONT VIEW) — page 14
11.3
(287)
6.1
(154)
PLAY70DS (SIDE VIEW) — page 12
17.2
(437)
6.3
(159)
2.7
(69)
16.7
(425)
17.2
(437)
2.6
(65)
28.0
(711)
4.2
(106)
PLAY40DS (TOP VIEW)— page 12
11.7
(296)
10.3
(261)
OS120FM (FRONT VIEW) — page 14
3.3
(84)
OS120FM (SIDE VIEW) — page 14
10°
(200)
(100)
18.0°
10
(254)
24
(610)
8.7
(220)
(200) (100)
11.1
(281)
LIFT30X (FRONT VIEW) — page 13
LIFT30X (SIDE VIEW) — page 13
3°
LIFT50 (FRONT VIEW) — page 13
OS40TP (FRONT VIEW) — page 15
48
LINE DRAWINGS
OS40TP (SIDE VIEW) — page 15
OS50T — page 15
LINE DRAWINGS
49
Line Drawings
inches (mm)
inches (mm)
TV WALL MOUNTS
TV WALL MOUNTS
OMNISELECT SERIES
19 (482)
100-400
16.9 100(430) 400
24.0
(610)
OS80T (SIDE VIEW) — page 15
9.4
(239)
13.7
(349)
11.0
(280)
OS120T (FRONT VIEW) — page 15
19.0 (482)
100-400
OS120T (SIDE VIEW) — page 15
OC40FMX (SIDE VIEW) — page 17
100-600
1.7
(42)
(9)
OS80F — page 16
OS120F (FRONT VIEW) — page 16
1.6
(41)
18.9
(479)
2.4
(61)
5.3
(135)
OS50F — page 16
OC80FM (SIDE VIEW) — page 18
18.8
(478)
100400
16.9 100(430) 400
OC80FM — page 18
20.2
(514)
8.5
(215)
(200)
14.0
(357)
3.2
(82)
16.7 100(424)400
1.1
(28)
(200)
OMNICLASSIC SERIES
0 TO 10° TILT
2.1
(54)
28 (711)
100-600
2.1
(54)
11.6
(294)
14.5
(368)
10.2
(260)
6.6
(167)
OC120FM (FRONT VIEW) — page 17
8.2
(209)
OC120FM (SIDE VIEW) — page 17
OC80T (FRONT VIEW) — page 18
32
(812)
1.2
(30)
20.8
(529)
1.6
(41)
2X 13.8
(350)
12.6
(320)
19.9
(505)
1.4
(35)
1.2
(30)
OS120F (SIDE VIEW) — page 16
9.9
(251)
8.7 (220)
7.9 (200)
3.9 (100)
3.0 (75)
3.0
(76)
8.1
(207)
LINE DRAWINGS
OC40FM (SIDE VIEW) — page 17
OC150T (FRONT VIEW) — page 19
OS175T (FRONT VIEW) — page 19
21.7
(550)
18.9
(479)
.5
(13)
10.2
(259)
14.5
(368)
13.8
(350)
1.3
(32)
Ø.3
(7)
9.5
(240)
OC40FM (FRONT VIEW) — page 17
3.0 3.9 8.7
(75) (100) (220)
8.2
(208)
6.1
(155)
.8
(20)
7.9
(200)
3.2
(82)
50
29.9
(760)
OC100T (FRONT VIEW) — page 18
OMNICLASSIC SERIES
21
(533)
16.9 14.7
(429) (373)
OC40F — page 20
OC80F (FRONT VIEW)— page 20
OC100F — page 20
OC40FMX — page 17
LINE DRAWINGS
51
Line Drawings
inches (mm)
inches (mm)
TV WALL MOUNTS
WORKFIT & iPAD MOUNTS
OMNICLASSIC SERIES
WORKFIT
30.8
(783)
32
(812)
1.3
(32)
18
(456)
14.7
(373)
16.9
(429)
12.4
(315)
21
(533)
1.57 (40)
0.98 (25)
9.8
(248)
5.5 (139)
1.57
(40)
Ø 3.4
(87)
.71
(18)
.71
(18)
4.7(119)
5
(126)
WORKFIT-A — page 25
4.3
(109)
4.7(119)
WORKFIT-A VESA MOUNT — page 25
iPAD MOUNTS
EZMOUNT SERIES
.71 (18)
.71 (18)
18.4
22.7 (467)
(576)
10.2
(260)
WORKFIT-A — page 25
OC175F (FRONT VIEW) — page 20
3.5
(90)
18.4
22.7 (467)
(576)
10.2
(260)
OC150F — page 20
32.8
(832)
2.8
(71)
3.5
(90)
4.3
(109)
27.4
(695)
.59 (15)
26.8
(681)
1.14
(29)
0.42 (11)
7.5 (190)
8
(205)
9.67
(246)
9.62
(244)
1.57
(40)
OMF — page 21
iPAD mini CASE — page 27
OMH — page 21
iPAD AIR CASE — page 27
iPAD GEN 2-3-4 CASE — page 27
3.94
(100)
6 (150)
2.5 (62)
CUSTOM INSTALLER SERIES
27.87
(708)
1.97 (50)
32
(812)
+15°
to -5°
16.34
(415)
14.7
(373)
32
(812)
14.7
21
(533) (373)
6.3
(161)
21
(533)
7.5
(191)
3.75
(95)
6.2 (157)
iPAD STAND — page 27
CI250FM (FRONT VIEW) — page 22
52
LINE DRAWINGS
0.5 (13)
1.3
(32)
13.6
(345)
1.57 (40)
6.85 (174)
0.41 (10)
CI175T (FRONT VIEW) — page 23
5
(127)
3.94
(100)
5 (127)
iPAD STAND — page 27
iPAD WALL MOUNT — page 27
CI175F (FRONT VIEW) — page 23
LINE DRAWINGS
53
Line Drawings
inches (mm)
AV WALL SHELVES
TV CEILING MOUNTS & PROJECTOR MOUNTS
22.3
(565)
CEILING MOUNTS
1.2
(30)
11.22
.9 (285)
(22)
18.6
(473)
24
(610)
22.5
(572)
12.4
(314)
11.9
(302)
0.2
(6)
8.3
(211)
3.9
(98)
BLADE2 (FRONT VIEW) — page 29
18.5
(469)
15
(381)
0.2
(6)
Ø 0.3
(8.5)
0.2
(6)
BLADE2 (SIDE VIEW) — page 29
.96
(24)
(6)
37.3
(948)
30.3
(770)
7.9 11.8 17.7
(200) (300) (450)
11.8-23.6
(300-600)
4.4
(111)
SCM125 — page 34
2.14
(54)
3.2
(81)
16.0 (406)
7.9
(200)
R1.5
(39)
7.1
(179)
9.1
(231)
6.7 (170)
MOD1 (FRONT VIEW) — page 30
5.6 (141)
16.5°
MOD1 (SIDE VIEW) — page 30
PJT40 — page 35
ECS — page 30
PJT40 — page 35
1.3 (33)
3.6 (91)
3N1-PJT — page 35
ACCESSORIES
TRIA SERIES
4.2 (107)
16.5 (419)
50 (1270)
17.5 (445)
4.5 (114)
TRIA — page 31
11.2 (285)
Shelves are
adjustable at
1" (25mm)
15 (381)
increments
15 (381)
*4.2 inches
(107mm)
without
end-cap
1.9 (48)
16.5 (419)
16.5 (419)
11.2 (285)
Shelves are
adjustable at
1" (25mm)
increments
LINE DRAWINGS
2.8 (71)
13.9
(353)
20.1 (571)
3.55
(90)
7.17
(182)
SCM125 — page 34
18.0
(457)
3.43
(87)
20°
PROJECTOR MOUNTS
.9
(23)
12.5
(318)
13.7
(348)
+15°
3.9
(100)
DCM250 — page 33
ECS
17.5 (445)
7.9 11.8 17.7
(200) (300) (450)
11.8-23.6
(300-600)
BLADE1 — page 29
MOD1 SERIES
3.31
(84)
3.9
(100)
4.0
(101)
Ø 0.3
(8.5)
28.1
(713)
(1 5-1
27 9.
-5 8
02
)
BLADE SERIES
54
inches (mm)
4.5 (114)*
17.5 (445)
TRIA 2 — page 31
32.5
(826)
Shelves are
adjustable at
1" (25mm)
increments
15 (381)
1.6
(41)
1.6
(41)
0.8
(19)
11.2
(285)
16.5 (419)
*4.2 inches
(107mm)
without
end-cap
1.9 (48) 1.9 (48)
1.6
(41)
12
(305)
18 (457)
1.8
(45)
4.5 (114)*
17.5 (445)
TRIA 1 — page 31
1 (26)
24 (610)
1.8
(45)
1.8
(45)
1 (26)
2.6
(65)
3.3
(83)
1.0 (25)
1 (26)
NPT12 / NPT18 / NPT24— page 35
PFC-A — page 35
LINE DRAWINGS
55
Line Drawings
inches (mm)
ENCLOSED RACKS & CARTS
inches (mm)
SPEAKER STANDS & MOUNTS
GEMINI SERIES
2.28
(58)
13.39
(340)
23.62
(600)
54.5
(1384)
38.90
(988)
ELO SERIES
31
(787)
24
(610)
1.5 (38)
23.62
(600)
RE18 (TOP VIEW) — page 37
RE18 (SIDE VIEW) — page 37
23.6
(600)
10.3
(260)
RE27 (SIDE VIEW) — page 38
18.1
(459)
17.2
(437)
37
(940)
RE42 (SIDE VIEW) — page 38
51.1-72 (1300-1829)
(1" increments)
34.4
(875)
19.6
(497)
16.5
83.4
(2120) (419)
2.87 (73)
6.0 (152)
PROHDCART — page 39
R0.1
(3)
0.4 (9)
2.6 (65)
0.9 (22)
RE2USHELF— page 38
56
LINE DRAWINGS
0.1
(2)
6.5 (166)
20.2
(512)
0.1 THK
(2)
19
(483)
8.7 (222)
3.7
(94)
4.8
(122)
2.28
(58)
AB1 — page 42
AB1 — page 42
OPTION A (BACK) — page 42
OPTION B (BACK) — page 42
OCSBA
2.4 (60)
16.3
(413)
0.1 THK (2)
3.5 (88)
17.2
(436)
1.3 (32)
ELO — page 42
3.54
(90)
1.69 (43)
2.0 (51)
15.9
(404)
3.86
(98)
12-43.5
(305-1105)
ACCESSORIES
3.3 (84)
GEMINI 1 — page 41
11
(279)
AUDIOBASICS SERIES
2.56
(65)
PROHDCART — page 39
10
(254)
10.5
(267)
8.5
(216)
GEMINI 2 — page 41
3.9-21.7
(100-550)
80.9
74.3 (2055)
(1887)
11.5
(292)
11.8-35.4 (300-900)
15.5
(395)
18.3
(465)
2.4 (61)
26-36
(660-914)
31-45
(787-1143)
3.5
(88)
19.0
(483)
3.2
(82)
0.4 (9)
0.2 (6)
0.8 (21)
RE5USHELF— page 38
RE2UBLANK— page 38
OPTION C (BACK) — page 42
LINE DRAWINGS
57
Line Drawings
inches (mm)
SPEAKER MOUNTS
STAINLESS STEEL SERIES
2.80 (71)
2.99 (76)
2.99 (76)
2.80
(71)
3.94
(100)
2.8
(71)
5.24
(133)
1.42 (36)
5.0 W/C — page 43
10.0 W/C — page 43
VESA MOUNT INTERFACES
OMNIMOUNT TV MOUNTS ARE
COMPLIANT WITH THE
VESA © INTERFACE STANDARD
OmniMount products are engineered
in accordance with the Flat Display
Mounting Interface (FDMI) Standard,
otherwise known as the Mounting
Interface Standard (MIS), defined by VESA. When choosing a
TV, look for VESA Mounting Compliance for ease of attachment
to any OmniMount wall mount, articulating monitor arm or other
VESA-compliant mounting solution.
The VESA standard defines dimensions of a TV’s four-hole
attachment interface and the screws used to fit those holes. It
also dictates the placement of the hole pattern on the back of
the TV. For attachment to VESA mounts, this invariably means
the hole pattern should be centered on a TV’s back (denoted in a
VESA label with the letter “C” as in VESA FDMI MIS-D, 100, C).
58
LINE DRAWINGS
Ergotron – Omnimount • 4409 East Baseline Road, Ste 130 • Phoenix, AZ 85042
1-800-MOUNT-IT (800-668-6848) • www.omnimount.com
OmniMount is a registered trademark and brand of Ergotron, Inc. ©2014
Ergotron, Inc. is a Nortek Company
870-01-047-EA
2014 July
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
