H804_E

H804_E
English
Thank you for your purchase of this Citizen watch.
Before using the watch, read this instruction manual carefully to ensure
correct use.
After reading the manual, store it in a safe place for future reference.
Visit the Citizen website (http://www.citizenwatch-global.com/) to view
visual guides for operation of your watch. Some models may be equipped
with external features (calculation scale, tachymeter, etc.). Visual guides for
operation of such external features can also be found on the website.
To check the movement number
Engraving position example
A case number—4 alphanumeric characters and 6 or
more alphanumeric characters—is engraved on the
case back. (Figure on the right)
The first 4 characters of the case number represent
the movement number of the watch. In the example
" is the movement number.
on the right, "
The engraving position may
differ depending on watch model.
1
Safety precautions (IMPORTANT)
This manual contains instructions that should be strictly followed at all times
not only for optimal use, but to prevent any injuries to yourself, other persons or
property.
We encourage you to read the entire booklet (especially, pages 60 to 71) and
understand the meaning of the following symbols:
■Safety advisories are categorized and depicted in this manual as follows:
2
DANGER
Highly likely to cause death or serious injury
WARNING
Can cause serious injury or death
CAUTION
Can or will cause minor or moderate injury or damage
English
Safety precautions (IMPORTANT)
■Important instructions are categorized and depicted in this manual as follows:
Warning (caution) symbol followed by instructions that should
be followed or precautions that should be observed.
Warning (caution) symbol followed by prohibited matters.
3
Before using this watch
After unpacking, the following must be done before using the watch:
◆ C
hecking the power reserve Page 17
Check the charge level of the watch.
◆Setting the World Time Page 22
Select the city for which you want to indicate the time and date.
◆Checking the time signal reception Page 41
Check the result of the time signal reception.
This watch has a rechargeable cell which is charged
by exposing the dial to light.
Expose the dial to light regularly to charge the watch.
For details of charging, see pages 12 to 19.
4
English
Before using this watch
◆Protective Stickers
Be sure to remove any protective stickers that may be on your watch (case back,
band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between
the protective stickers and the parts, which may result in a skin rash and/or
corrosion of the metal parts.
◆Band adjustment
We do not recommend attempting to adjust the watch band yourself. If not
adjusted correctly, the band may become detached leading to an injury or loss
of your watch. (Some retailers may supply a band adjustment tool with your
purchase).
For band adjustment, we recommend you consult the retailer where the watch was
purchased or your nearest Authorized Citizen Service Center. Some repair shops
may charge a nominal fee for adjustment if the watch was not purchased directly
from them.
5
Before using this watch
◆
How to use a specially designed crown/push button
Some models are equipped with a specially designed crown and/or push button to
prevent accidental operation.
Screw down crown and screw down push button
Unlock the crown prior to operate your watch.
Unlock
Screw
down
crown
Screw
down push
button
6
Lock
Rotate the crown
counterclockwise
until it releases from
the case.
Push the crown in to
the case. With gentle
pressure towards the
case, rotate the crown
clockwise to secure it
to the case. Be sure to
tighten firmly.
Rotate the
locking screw
counterclockwise, and
loosen until it stops.
Rotate the locking
screw clockwise,
and tighten firmly.
Recessed buttons
English
Before using this watch
ress the button with a narrow-tipped object such
P
as a wooden toothpick.
7
Table of contents
Features…………………………………………………………………
Component identification … …………………………………………
Charging your watch……………………………………………………
Using the chronograph…………………………………………………
Setting the World Time…………………………………………………
Setting Summer Time… ………………………………………………
Notes on the time signal reception……………………………………
Checking the time signal reception…………………………………
Receiving the time signal manually (On demand reception)… ……
Adjusting the time/calendar manually… ……………………………
Checking and correcting the current reference position… …………
8
10
11
12
20
22
26
33
41
43
45
50
Troubleshooting… ……………………………………………………
Eco-Drive (solar powered) watch handling precautions… …………
Water resistance … ……………………………………………………
Precautionary items and usage limitations… ………………………
Specifications……………………………………………………………
English
Table of contents
54
60
64
66
72
9
Features
"Radio controlled watch"
Receives a time signal from one of the
five signal stations located in four regions
and automatically adjusts the time and
calendar.
"Eco-Drive"
No need for periodical changing
of rechargeable cells. The watch is
charged by light.
"Chronograph"
Measures the elapsed time up to
60 minutes.
"Perpetual calendar"
"World Time"
Easy to see the time and calendar of cities all
over the world.
* "Eco-Drive" is Citizen's original technology.
10
No need for date correction at the
end of each month.
The leap year is also updated
automatically.
Chronograph minute
hand
FEN
Power reserve level
Minute hand
ATH
RU
H
L
SC
C
NY
DAC
Crown
BKK
10
20
C
AN
S
NO
00
BJ
CHI
RX
S
M
T
W
70
30
T
60
40
50
F
S
90
80
Upper right
button (B)
Date indication
OFF
DEL
OK
L
I
12
HN
20
30
SMT
KH
40
24
ON
B
10
DX
60
50
LAX
Second hand or
chronograph second
hand
Summer Time
indication (ON/OFF)
PAR
O
DEN
Reception result
indication
(OK/RX/NO)
LON
RI
Hour hand
24-hour hand
PDL
English
Component identification
O
TY
Lower right
button (A)
Day of the week
indication
Chronograph
1/20 second hand
* The illustrations in this instruction manual may differ from the actual appearance of your watch.
* A solar cell is placed under the dial.
City indication
MD
L
AD
Y
AKL
NOU
SYD
11
Charging your watch
This watch has a rechargeable cell which is charged by exposing the dial to light, such
as direct sunlight or fluorescent lamps.
After taking off the watch, put it in a location where the dial is exposed to bright light,
such as by a window.
The watch can be charged effectively when the
dial is exposed to sunlight as shown in the
figure.
For optimal performance, be sure to:
• Charge the watch by exposing it to direct
sunlight for five to six hours at least once a
month.
• Avoid leaving the watch in a dark place for
long periods of time.
12
• If the watch is obscured from light by long sleeves frequently, supplemental
charging may be needed to ensure continual operation.
• Do not charge the watch at high temperature (about 60°C/140°F or higher).
13
English
Charging your watch
Charging your watch
◆ When the watch reaches a low charge state
(insufficient charge warning function)
When the power reserve becomes low, the second hand moves once every two
seconds. This is the insufficient charge warning function. Be sure to fully charge
your watch.
• When the watch is sufficiently charged, the second hand will move normally.
• If you do not charge the watch for
2 days or longer after the insufficient
charge warning movement has begun,
the watch will be depleted of all
power and stop.
• When in the insufficient charge
warning state, the current time and
date are indicated. However, you
cannot configure or confirm settings,
or operate the chronograph.
14
◆ Charging time by environment
Below are the approximate times required for charging when exposing the watch
dial to light continuously. Please use this table as a reference only.
Environment
Charging time (approx.)
Illuminance
To start working
To become fully
To
work
for
one
(lx)
normally when the charged when the
day
cell is discharged cell is discharged
Outdoors (sunny)
100,000
5 minutes
40 minutes
30 hours
Outdoors (cloudy)
10,000
11 minutes
1 hour
40 hours
20 cm (7-7/8 inches)
from a fluorescent
lamp (30W)
3,000
40 minutes
2.5 hours
130 hours
Interior lighting
500
4 hours
14 hours
920 hours
Maximum run time from full charge: Approx. 6 months (in normal operation),
approx. 10 months (with power save feature)
15
English
Charging your watch
Charging your watch
◆ Power save feature
When the watch is not exposed to light for 30 minutes or longer, such as when
you store it in a dark place, the second hand automatically stops to save the
power.
However, the watch continues to work internally.
• When the crown is in position 1 or 2, the power save feature will not activate.
• The power save feature can not be activated manually.
◆ To cancel the power save feature
When the watch is exposed to light sufficient for charging, the power save feature
is automatically canceled and normal time indication will resume.
16
◆ Checking the power reserve
Check the current power reserve.
0 1 2
Ⓐ
50
40
1. Ensure that the crown is in position 0 .
2. Press the lower right button Ⓐ .
The chronograph minute hand moves to indicate
the power reserve.
• For details on the power reserve level, see the
next page.
3. Press the lower right button Ⓐ to finish the
check procedure.
• The current time indication will resume
automatically when leaving the watch for
approx. 10 seconds.
You can not perform this operation when using
the chronograph.
17
English
Charging your watch
Charging your watch
The power reserve level
Level
Power
reserve
level
3
2
50
10 50
10 50
10 50
10
40
20 40
20 40
20 40
20
Approx. 180 to 130 days Approx. 130 to 30 days
Power reserve
Approximate is sufficient for
duration of all features and
operation at functions. Optimal
performance is
each level
achieved at this
level.
18
Power reserve is
sufficient for all
operations at this
level.
1
0
Approx. 30 to 2 days
Approx. 2 days
Power reserve is
getting low.
The watch should
be fully charged
to ensure optimal
performance.
Power reserve is
not sufficient for
normal operation.
The watch must
be fully charged.
The watch must be charged immediately.
• When the power reserve is at level 1 or 0, the chronograph minute hand always
indicates the power reserve level.
• When the power reserve is at level 0, the current time and date are indicated.
However, you cannot configure or confirm settings, or operate the chronograph.
19
English
Charging your watch
Using the chronograph
The chronograph can measure up to 60 minutes in units of 1/20 seconds.
60
50
40
30
10
ON
20
OFF
Chronograph
minute hand
SMT
Chronograph
second hand
Ⓑ
0 1 2
OK
RX
NO
90
80
70
60
00
50
Ⓐ
S
10
20
30
40
S
20
1. Ensure that the crown is in position 0 .
2. Press the upper right button Ⓑ .
3. Press the upper right button Ⓑ to start
measurement.
4. Press the upper right button Ⓑ to suspend
measurement.
M
T
W
T
F
The watch enters the chronograph mode.
• As shown in the figure, the chronograph
minute, chronograph second, and chronograph
1/20 second hands point in the 12 o’clock
direction.
Chronograph 1/20
second hand
• Pressing the upper right button Ⓑ again will
resume the measurement operation.
5.Press the lower right button Ⓐ to reset the measured time.
• Make sure to reset the time after finishing measurement.
6. Press the lower right button Ⓐ again to return to current time indication.
• The current time indication will resume automatically when leaving the watch for
approx. 3 hours.
• When 30 seconds have elapsed after the measurement is started (or restarted), the
chronograph 1/20 second hand stops at the zero second position. However, the
measurement is still conducted.
• The chronograph cannot be used when the power reserve is at level 0. Even when
the power reserve is at level 1, we recommend charging the watch before using
the chronograph.
• Do not pull out the crown during chronograph measurement operation.
The measurement will stop.
21
English
Using the chronograph
Setting the World Time
The watch can indicate the time and date of any of the 26 cities in the world you choose.
• When using the watch in an area not listed in the table below, select and set the city
with the same time difference.
PDL
LON
PAR
1. Pull the crown out to position .
DX
FEN
ATH
B
RU
RIO
0 1 2
C
I
NY
KH
KH
B
SC
DX
L
H
CHI
I
DEL
BJS
L
O
MD
L
AD
Y
NOU
TY
SYD
BJ
S
BKK
AKL
DAC
C
AN
DEL
LAX
BKK
DAC
DEN
HN
O
L
AKL
22
NOU
SYD
AD
TY
The second hand indicates the current city
setting; the chronograph minute hand indicates
the summer time ON/OFF setting; and the
chronograph 1/20 second hand indicates the
summer time auto/manual setting.
• Setting Summer Time Page 26
2. Rotate the crown to select the city for which
you want to indicate the time and date.
• Move the second hand to select the city by
referring to "second hand position" in the city
indication table.
3. Push the crown in to position 0 to finish
the setting.
◆ City indication table
Abbreviation
LON
PAR
ATH
RUH
City indication or second hand position
*
*
*
Time difference Signal from...
LONDON
0 sec.
0
PARIS
2 sec.
+1
ATHENS
4 sec.
+2
RIYADH
7 sec.
+3
+4
DXB
DUBAI
9 sec.
KHI
KARACHI
11 sec.
+5
DEL
DELHI
14 sec.
+5.5
DAC
DACCA
16 sec.
+6
BKK
BANGKOK
18 sec.
+7
BJS/HKG
BEIJING/HONGKONG
21 sec.
+8
Germany
China
23
English
Setting the World Time
Setting the World Time
Abbreviation
Time difference Signal from...
TOKYO
23 sec.
+9
ADL
ADELAIDE
25 sec.
+9.5
SYD
SYDNEY
28 sec.
+10
NOU
NOUMEA
30 sec.
+11
AKL
AUCKLAND
32 sec.
+12
MDY
MIDWAY ISLANDS
35 sec.
−11
HNL
HONOLULU
37 sec.
−10
ANCHORAGE
39 sec.
−9
LOS ANGELES
42 sec.
−8
DENVER
44 sec.
−7
CHICAGO
46 sec.
−6
NEW YORK
49 sec.
−5
ANC
LAX
DEN
CHI
NYC
24
City indication or second hand position
TYO
**
**
**
**
**
Japan
USA
Abbreviation
City indication or second hand position
Time difference Signal from...
SCL
SANTIAGO
51 sec.
−4
RIO
RIO DE JANEIRO
53 sec.
−3
FERNANDO DE NORONHA
56 sec.
−2
AZORES
58 sec.
−1
FEN
PDL
*
USA
Germany
• The city indications displayed on the watch may be different, depending on the
model.
• For a city indicated by *, the summer time indication and the standard time
indication are linked together.
• For a city indicated by **, the summer time indication and the standard time
indication are linked together.
• The time difference in the table above is based on UTC.
• The time difference may change depending on the country or area.
25
English
Setting the World Time
Setting Summer Time
◆ Summer time
Summer Time is a system adopted in some countries/areas to gain an extra hour
of daylight during summer by advancing clocks by one hour. In an area where the
summer time is in effect, the time signal contains a summer time check signal.
When receiving the summer time check signal, this watch automatically enables/
disables (turns ON/OFF) the Summer Time setting.
• Summer Time can be manually disabled in an area where the time signal can be
received but the summer time is not in effect. (See pages 30 and 31.)
• Summer Time can be manually enabled even if the watch is outside the
area. (See pages 30 and 31.)
• The summer time rules may change depending on the country or area.
• A summer time period is different depending on the country or area.
26
◆ Checking the time currently shown
Summer Time indication (ON/OFF)
(Chronograph minute hand)
0 1
1. Pull the crown out to position .
The second hand indicates the current city
setting; the chronograph minute hand indicates
the summer time ON/OFF setting; and the
chronograph 1/20 second hand indicates the
summer time auto/manual setting.
• Check the settings by referring to the table in
the next page.
Auto/Manual indication
(Chronograph 1/20 second
hand)
27
English
Setting Summer Time
Setting Summer Time
Summer Time indication (ON/OFF)
Auto/Manual indication
(Chronograph minute hand)
(Chronograph 1/20 second hand)
Enable Summer Time(ON)
60
50
40
10
30
20
Automatic setting (12 o’clock
direction)
ON
SMT
OK
OFF
RX
NO
90
80
70
60
00
50
S
10
20
30
40
M
T
W
T
F
S
Enable Standard Time (OFF)
60
Manual setting (6 o’clock
direction)
50
10
ON
40
20
SMT
OK
OFF
RX
30
NO
90
80
70
60
00
50
S
10
20
30
40
S
• Switching ON/OFF of Summer Time → (See page 30)
• Auto/manual switching of Summer Time → (See page 31)
28
M
T
W
T
F
Description
Automatically switch
between Summer Time
and Standard Time by
receiving the signal.
• When a summer time
check signal is received,
the summer time ON/
OFF setting is changed.
Manually switch between
Summer Time and
Standard Time.
• Even if a summer time
check signal is received,
the summer time ON/OFF
setting is not changed.
To automatically
enable Summer
Time when using
the watch in an area
where the time signal
can be received:
RX
To enable Summer
Time manually when
the time signal can
not be received:
OK
OK
NO
90
80
70
60
00
50
S
10
20
30
40
60
M
T
W
50
T
40
T
50
F
10
30
ON
SMT
20
OFF
10
ON
20
OFF
10
ON
20
OFF
S
RX
NO
90
80
70
60
00
50
S
10
20
30
40
60
M
W
T
40
T
50
F
30
SMT
Set the auto/manual
setting to auto (the watch
will automatically change
the summer time ON/OFF
setting when receiving a
summer time check signal.)
Turn the summer time
ON/OFF setting to ON
when you want to enable
Summer Time.
S
To prevent the watch
from automatically
enabling Summer
Time through signal
reception:
OK
RX
NO
90
80
70
60
00
50
S
10
20
30
40
60
M
W
T
F
40
30
SMT
Set the auto/manual
setting to manual and
turn the summer time
ON/OFF setting to OFF.
S
29
English
Setting Summer Time
Setting Summer Time
◆ Switching ON/OFF of Summer Time
Ⓑ
0 1 2
1. Pull the crown out to position .
The chronograph minute hand indicates the current
summer time ON/OFF setting.
2.Press the upper right button Ⓑ to switch the
summer time setting.
Each time you press the upper right button Ⓑ , the
chronograph minute hand points SMT ON and SMT
OFF alternately to indicate the summer time ON/
OFF setting is switched.
50
40
30
10
ON
SMT
20
OFF
3. Push the crown in to position 0 to finish the
setting.
◆ Auto/manual switching of Summer Time
Ⓑ
0 1 2
S
M
OK
T
RX
W
F
S
OK
RX
NO
90
80
70
60
Ⓐ
00
50
S
10
20
30
40
S
The chronograph 1/20 second hand indicates the
current auto/manual setting.
2. Press and hold the lower right button Ⓐ for
two or more seconds.
Each time you hold down the lower right button
Ⓐ for two or more seconds, the chronograph 1/20
second hand points the 12 o’clock direction (auto)
and the 6 o’clock direction (manual) alternately.
T
NO
1. Pull the crown out to position .
M
T
W
T
F
While manual setting is enabled, the summer time
ON/OFF setting is not changed even when the watch
receives the time signal. Take the procedure described
in the previous page to change the ON/OFF setting.
3. Push the crown in to position 0 to finish the
setting.
31
English
Setting Summer Time
Setting Summer Time
◆ The time shown for each city
The watch shows and memorizes Summer Time/standard time in common for
the following cities/time differences in each area so you do not need to change
them for each city/time differences.
• If you show the standard time manually for a city/time differences, the watch
always shows the standard time for that city/time difference regardless of the
time shown for others in the same area.
Areas receiving the signal from USA
Areas receiving the signal from Germany
City
Time difference
City
Anchorage/ANC
−9
London/LON
Time difference
0
L.Angeles/LAX
−8
Paris/PAR
+1
Denver/DEN
−7
Athens/ATH
+2
Chicago/CHI
−6
Azores/PDL
−1
New York/NYC
−5
For cities/time differences other than those listed above, the time shown last is memorized for each.
32
English
Notes on the time signal reception
There are three ways to receive the time signal:
The second hand indicates the reception result (OK/NO). (See page 41)
Methods
Explanations
Automatic
reception
Receives the signal at 2:00 a.m. every day. If reception is unsuccessful, the
watch tries to receive at 3:00 a.m.
On demand
reception
Starts receiving the signal when you want to adjust the time and date.
(See page 43.)
Recovery
automatic
reception
Automatically receives the signal once after charging when the watch
stops due to insufficient charge.
• Even when this watch receives the time signal successfully, the accuracy of the displayed
time will be dependent on the reception environment and internal processing.
• If the watch is not able to receive the signal, it will operate normally within an accuracy
range of ±15 seconds per month.
33
Notes on the time signal reception
◆ When receiving the time signal
Remove the watch and place it on a stable surface where it can receive the signal
better, such as next to a window.
• The reception antenna is located at the 9:00
position of the watch. Place the watch with
the 9:00 position facing toward the station.
• Do not move the watch during time signal
reception.
• The watch will not receive the time signal
when in a low charge state as indicated by
the second hand moving in two second
increments (the insufficient charge
warning). Charge the watch before
reception.
34
◆ Note on the time signal
This watch receives the time signal from one of the five signal stations located in
four regions, and automatically corrects the time and date.
The receivable signal stations are listed as follows:
Signal stations
Fukushima station, Japan
Kyushu station, Japan
Kind of the
time signal
JJY
Fort Collins station, Denver, Colorado, USA
WWVB
Mainflingen station, Southeast Frankfurt, Germany
DCF77
Shangqiu station, Henan, China
BPC
• Refer to the maps on pages 36 to 38 to see the locations of the signal stations and their
receivable area roughly.
35
English
Notes on the time signal reception
Notes on the time signal reception
JJY (Japan):
Approx. 2,000 km
Kyushu station
36
JJY (Japan):
Approx. 1,500km
Fukushima station
WWVB (USA):
Approx. 3,000km
Fort Collins station
37
English
Notes on the time signal reception
Notes on the time signal reception
DCF77 (Germany):
Approx. 1,500km
Mainflingen station
38
BPC (China):
Approx. 1,500km
Shangqiu station
◆ Poor reception areas
It may be difficult to receive the time signal properly under certain environmental
conditions or in areas susceptible to radio noise.
• Extremely hot or cold locations
• Near high-tension
electrical lines, railway
overhead wires or
communication facilities
• Inside vehicles
• Inside reinforced concrete
buildings, between tall
buildings, mountains, or
underground
• Near electrical equipment or
office appliances
• Near mobile phones that are in
use
39
English
Notes on the time signal reception
Notes on the time signal reception
◆ When signal reception is poor
High-tension electrical lines or other structures near your house may block the
path to the signal station. This may result in a poor environment for receiving the
time signal.
With reference to pages 36 to 38, search for a better place for reception.
Then, attempt to receive the time signal following the procedure on page 43.
• If the window contains a wire netting in it, open the window or change the
location for better reception.
40
English
Checking the time signal reception
Check the result of the last signal reception.
0 1 2
1. Ensure that the crown is in position 0 .
2. Press the lower right button Ⓐ .
The chronograph 1/20 second hand indicates the
signal reception result.
• For details on the reception result, see the next page.
S
M
OK
T
RX
W
T
NO
F
S
OK
RX
NO
Ⓐ
90
80
70
60
3. Press the lower right button Ⓐ to finish the
check procedure.
• The current time indication will resume
automatically when leaving the watch for approx.
10 seconds.
20
30
You can not perform this operation when using
the chronograph.
41
Checking the time signal reception
◆ Time signal reception result
OK
Indication RX
NO
Result
Meaning
S
S
M
90
80
10
90
OK
T
20 80
10
90
OK
T
20 80
10
20
70
60
30 70T
NO
40
60
30 70T
NO
40
60
30
40
OK
Reception has
succeeded.
RX
W
F
S
NO
Reception has failed.
The time and data/
calendar have not been
corrected.
• For details on time signal reception, see page 33.
42
S
M
RX
W
F
S
Receiving
RX
S
English
Receiving the time signal manually (On demand reception)
You can adjust the watch by receiving the time signal any time when the time and
date are not correct or the reception result is "NO."
• The signal station is different depending on the city
set. Confirm the current city setting.
• You can not perform this operation when using the
chronograph.
0 1 2
S
M
OK
T
RX
W
T
NO
1. Ensure that the crown is in position 0 .
2. Press and hold the lower right button Ⓐ for
two or more seconds.
F
S
OK
RX
NO
Ⓐ
90
80
70
60
20
The result of the last signal reception is displayed,
then on-demand reception starts. (2-30 minutes)
• The chronograph 1/20 second hand indicates "RX."
30
43
Receiving the time signal manually (On demand reception)
• The watch will not receive the time signal when in a low charge state as indicated by
the second hand moving in two second increments (the insufficient charge warning).
• If the current location is different from the city you set, the watch will not receive the
time signal.
• Press and hold the lower right button Ⓐ for two or more seconds to cancel the signal
reception.
• The reception operation is complete when normal time indication resumes.
44
English
Adjusting the time/calendar manually
Manually adjust the time/calendar when the watch cannot receive the time signal.
Ⓑ
0 1 2
1. Pull the crown out to position .
2. Press and hold the upper right button Ⓑ for
two or more seconds.
The second hand moves to the 30-second position
and the chronograph minute hand moves to the
60-minute position.
Ⓑ
0 1 2
3. Pull the crown out to position .
The second hand moves to the 0 second position,
and it becomes possible to adjust the time/calendar.
45
Adjusting the time/calendar manually
②
4.Press the upper right button Ⓑ to select the
correction target.
Ⓑ
0 1 2
Each time you press the upper right button Ⓑ ,
the correction target changes as follows and the
corresponding hand slightly moves.
① Time (minutes/hours/24 hour time)→ ② date →
③ day of the week → ④ year and month→ back to ①
S
M
T
W
T
F
S
④
③
①
① Time
24
② Date
24-hour
hand
12
The minute, hour,
24-hour hands move
in conjunction with
one another.
46
③ Day of the week
60
50
40
30
10
ON
20
OFF
SMT
When the chronograph
minute hand rotates five
times, the date advances
by one day.
OK
RX
NO
90
80
70
60
00
50
S
10
20
30
40
S
M
T
W
T
F
④ Year and month
The chronograph
1/20 second
hand indicates
the day of the
week.
5.Rotate the crown to adjust each setting.
• If you spin the crown quickly, the hands for the time and date will move continuously.
To slow down and stop them, slightly rotate the crown.
• To move the date forward or backward by one day, slightly rotate the crown.
• The date changes at around 0:00 am. It takes about five seconds for the displayed date
to completely change.
• The year and month are indicated by the minute hand. Adjust them by referring to the
figure in the next page.
6. Repeat procedures 4 and 5.
7. Push the crown in to position to finish the setting.
The second hand starts moving from the 0 second position, and time/calendar indication
will resume.
• Push in the crown by referring to a reliable time source.
47
English
Adjusting the time/calendar manually
Adjusting the time/calendar manually
◆ Month and year indications
December
The number of years and months since the leap year is
indicated by minute marks.
[Month]
January
December: between 12:00 and 01:00
January: between 01:00 and 02:00
February: between 02:00 and 03:00
[Year]
Leap year
1st year
2nd year
3rd year
Leap year
1st year
2nd year
3rd year
48
February
March
Leap year:
Hour marker in each month
1st year since leap year:
1st min. marker in each month
2nd year since leap year:
2nd min. marker in each month
3rd year since leap year:
3rd min. marker in each month
You can get the actual year from the number of years passed from the leap year by
referring to the following table:
Indication of the second hand
Passed year
Year
Leap year
2012, 2016, 2020
1st min. marker
1st year
2013, 2017, 2021
2nd min. marker
2nd year
2014, 2018, 2022
3rd min. marker
3rd year
2015, 2019, 2023
Hour marker
49
English
Adjusting the time/calendar manually
Checking and correcting the current reference position
◆ What is the reference position?
The base position for all the hands to indicate the time and date. If the reference
position is not at the correct position, the time and functions are not indicated
correctly.
Figure: Correct reference positions
• Hands: All point in the 12 o’clock
direction.
• Date: Between "31" and "1"
50
◆ Checking and correcting the current reference position
Ⓑ
0 1 2
1. Ensure that the crown is in position 0 .
2. Press and hold the upper right button Ⓑ for ten
seconds.
All hands and the date indicator move to indicate the current
reference position.
Correct the reference position by taking the following steps if
the position is not accurate.
3. Pull the crown out to position .
This will enable you to correct the reference position.
51
English
Checking and correcting the current reference position
Checking and correcting the current reference position
④
4.Press the upper right button Ⓑ to select the
Ⓑ
correction target.
0 1 2
Each time you press the upper right button Ⓑ ,
the correction target changes as follows and the
corresponding hand slightly moves.
③
① Chronograph 1/20 second hand →
② Chronograph minute hand/date indication →
③ Minute hand/hour hand/24-hour hand →
④ Second hand → back to ① →
②
①
hronograph
①C
1/20 second hand
hronograph minute hand/
②C
date indication
24
60
OK
RX
NO
90
80
70
60
00
50
30
40
S
52
50
S
10
20
M
T
W
40
10
30
20
ON
SMT
OFF
T
F
③ Minute hand/hour hand/
24-hour hand
24-hour hand
The chronograph minute hand
and the date indication move
in conjunction with each other.
12
The minute, hour,
24-hour hands move
in conjunction with
one another.
④ Second hand
5. Rotate the crown to correct the reference position of the active hand/
indication.
• When you rotate the crown quickly, each hand will move continuously. To slow down
and stop them, slightly rotate the crown.
6. Push the crown in to position 0 to finish the correction.
7. Press the upper right button Ⓑ to return to current time indication.
53
English
Checking and correcting the current reference position
Troubleshooting
If you have a problem with your watch, check the table below.
Problems with time signal reception.
Symptoms
Remedies
Push the crown in to position .
Avoid things likely to interfere with the time signal and
place the watch with the 9:00 position facing toward
Reception is unsuccessful the station.
in a receivable area.
Do not move the watch until the reception has finished.
When the second hand moves once every two
seconds, the watch cannot receive the time signal.
Charge the watch.
Check and correct the current reference position.
The correct time and date
are not indicated after
Check the city setting.
successful reception.
Check the summer time setting.
54
Page
—
34, 39
34
14
51
22
27
The hands do not work properly.
Symptoms
The hands move in an
unexpected direction.
The second hand moves
once every two seconds.
Remedies
Page
Stop the chronograph.
20
Charge the watch.
14
Push the crown in to position .
—
Charge the watch by exposing it to direct sunlight until
the second hand starts moving once every one seconds.
After charging, signal reception automatically starts.
(Recovery automatic reception)
14
The watch does not enter
the chronograph mode.
The chronograph cannot be used when the power
reserve is at level 0. Charge the watch.
12
The chronograph minute
hand does not point in
the 12 o’clock direction.
When the power reserve is insufficient, level 1 is
displayed for the power reserve. Charge the watch.
12
The hands start turning
rapidly as you take the
watch out of the case.
The watch is canceling the power save feature. Wait until
the rapid movement stops.
16
All hands stop moving.
55
English
Troubleshooting
Troubleshooting
The time and/or date is incorrect.
Symptoms
The time and/or date is
incorrect.
The date changes at
around 12:00 p.m.
56
Remedies
Page
Check the city setting.
22
Change the summer time setting.
27
Check and correct the current reference position.
51
Receive the time signal to adjust the time and date.
43
Set the time and date manually.
45
Check and correct the current reference position.
51
Receive the time signal to adjust the time and date.
43
Adjust the time manually.
45
Others
Symptoms
The hands do not move
even if the watch is
charged.
Remedies
Charge the watch by exposing it to direct
sunlight for five to six hours. If the problem
is not solved after charging, contact the
Authorized Service Center or the store where
you purchased your watch.
Page
12
57
English
Troubleshooting
Troubleshooting
◆ All Reset
When the watch does not work properly, you can reset all the settings. If the
power reserve is insufficient, charge the watch first.
Check before performing All Reset.
After performing All Reset, you need to configure all the settings again. Set the
watch again by following the procedures below.
1. Correct the reference position. See page 51.
2. Set the city. See page 22.
• To set Summer Time, see page 27.
3. Set the time.
To adjust the time by receiving the time signal, see page 43. To adjust the time
manually, see page 45.
58
◆ Performing All Reset
Perform this operation after checking the contents of the previous page in this
manual.
1. Pull the crown out to position .
Ⓑ
2.Hold down both the lower right button Ⓐ and the
upper right button Ⓑ for four or more seconds.
0 1 2
Ⓐ
All Reset will be performed.
The settings will be reset as follows:
The settings after All Reset
• Reference positions of hands/date : Positions when the crown is pushed in.
• Calendar
: Leap year, January/Sunday
• City
: LON (London)
• Summer Time
: OFF (Standard time)
• Switching of Summer Time : Auto
59
English
Troubleshooting
Eco-Drive (solar powered) watch handling precautions
<Always Make Sure to Recharge Frequently>
•Please note that if you wear long sleeves, the watch may stop as a
result of being covered by your sleeve and blocked from the light.
•When you take off the watch, try to place it in as bright a location
as possible. This will ensure optimal operation.
60
CAUTION
Recharging Precautions
• Do not charge the watch at a high temperature (about
60°C/140°F or higher) as doing so may cause the
movement to malfunction.
Examples:
• Charging the watch too close to a light source which
generates a large amount of heat such as an incandescent
lamp or halogen lamp.
* When charging under an incandescent lamp, be sure to
leave 50 cm (19-11/16 inch) or more between the lamp
and the watch to avoid exposing the watch to excessive
heat.
• Charging the watch in a location where the temperature
may become extremely high such as on the dashboard of
a vehicle.
61
English
Eco-Drive (solar powered) watch handling precautions
Eco-Drive (solar powered) watch handling precautions
<Replacement of Rechargeable Cell>
• This watch utilizes a special rechargeable cell that does not require regular replacement.
However power consumption may increase after using the watch for a number of years due
to wear of internal components and deterioration of oils. This may cause stored power to be
depleted at a faster rate. For optimal performance, we recommend having your watch
inspected (chargeable to the owner) by an Authorized Service center to ensure operation is
within factory specifications.
WARNING
Handling of Rechargeable Cell
• The rechargeable cell should never be removed from the watch.
If for any reason it becomes necessary to remove the rechargeable cell from the watch, keep
out of the reach of children to prevent accidental swallowing.
If the rechargeable cell is accidentally swallowed, consult a doctor immediately.
• Do not dispose of the rechargeable cell with ordinary garbage. Please follow the instructions
of your municipality regarding collection of batteries to prevent the risk of fire or
environmental contamination.
62
WARNING
Use Only the Specified Battery
• Never use a battery other than the rechargeable cell specified for use in this watch.
Although the watch structure is designed so that it will not operate when another type of
battery is installed, if a silver battery or other type of battery is installed in the watch and the
watch is recharged, there is the risk of overcharging which may cause the battery to rupture.
This can cause damage to the watch and injury to the wearer.
When replacing the rechargeable cell, always make sure to use the designated rechargeable cell.
63
English
Eco-Drive (solar powered) watch handling precautions
Water resistance
WARNING
Water Resistance
• Refer to the watch dial and the case back for the indication of the water resistance of your
watch. The following chart provides examples of use for reference to ensure that your watch is used
properly. (The unit “1bar” is roughly equal to 1 atmosphere.)
• WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar.
• Non-water resistant models are not designed to come into contact with any moisture. Take care not
to expose a watch with this rating to any type of moisture.
64
Name
Indication
Dial or Case back
Specification
Non-water resistant
Non-water resistant watch
—
Everyday-use water resistant
watch
WATER RESIST(ANT)
Upgraded everyday-use water
resistant watch
WATER RESIST(ANT)
5 bar
WATER RESIST(ANT)
10/20 bar
Water resistant to
3 atmospheres
Water resistant to
5 atmospheres
Water resistant to
10 or 20 atmospheres
Water-related use
Minor exposure
Swimming and
to water (washing general washing
face, rain, etc.)
work
Skin diving,
marine sports
Scuba diving
using an air tank
Operate the crown
or button when
the watch is wet
NO
NO
NO
NO
NO
OK
NO
NO
NO
NO
OK
OK
NO
NO
NO
OK
OK
OK
NO
NO
65
English
Water resistance
• Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for
occasional accidental splashing.
• Upgraded water resistance for daily use (to 5 atmospheres) means that the watch may be worn while
swimming, but is not to worn while skin diving.
• Upgraded water resistance for daily use (to 10/20 atmospheres) means that the watch may be worn
while skin diving, but not while scuba or saturated diving using helium gas.
Precautionary items and usage limitations
CAUTION
To Avoid Injury
• Be particularly careful when wearing your watch while holding a small child, to avoid injury.
• Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself
and others.
• Do NOT wear your watch while in a sauna or other location where your watch may become
excessively hot, since there is the risk of burns.
• Be careful when putting on and taking off your watch, since there is a risk of damaging your
fingernails, depending on the manner in which the band is fastened.
• Take off your watch before going to bed.
CAUTION
Precautions
• Always use the watch with the crown pushed in (normal position). If the crown is of the screw
lock-type, make sure it is securely locked.
• Do NOT operate the crown or any push buttons when the watch is wet. Water may enter the
watch causing damage to vital components.
• If water enters the watch or the watch fogs up and does not clear up even after a long time,
consult your dealer or Authorized Service Center for inspection and/or repair.
66
• Even if your watch has a high level of water resistance, please be careful of the following.
• If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a
dry cloth.
• Do not pour water from a tap directly onto your watch.
• Take off your watch before taking a bath.
• If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in
for repair. Otherwise, pressure inside the watch will increase, and parts (crystal, crown, push button,
etc.) may come off.
CAUTION
When Wearing Your Watch
<Band>
• Leather, genuine skin and rubber (urethane) bands will deteriorate over time due to
perspiration, body oils and dirt. Be sure to replace the band periodically.
• The durability of a leather band may be affected when wet (fading, peeling of adhesive), owing
to the properties of the material. Moreover, wet leather may cause a rash.
• It is recommended to take off the watch if it gets wet, even if the watch itself is water resistant.
67
English
Precautionary items and usage limitations
Precautionary items and usage limitations
• Do not wear the band too tightly. Try to leave enough space between the band and your skin to allow
adequate ventilation.
• The rubber (urethane) band may be stained by dyes or soil present in or on clothing or other
accessories. Since these stains may not be removable, caution is required when wearing your watch
with items that tend to easily transfer color (articles of clothing, purses, etc.). In addition, the band
may be deteriorated by solvents or moisture in the air. Replace with a new one when it has lost
elasticity or become cracked.
• Please request adjustment or repair of the band in the following cases:
• You notice an abnormality with the band due to corrosion.
• The pin of the band is protruding.
• We do not recommend attempting to adjust the watch band yourself. Special expertise and
experience is required for proper adjustment. If not adjusted correctly, the band may become
detached leading to loss of your watch. (Some retailers may supply a band adjustment tool with your
purchase).
For band adjustment, we recommend you consult the retailer from where the watch was purchased
or your nearest Authorized Citizen Service Center. Some repair shops may charge a nominal fee for
adjustment if the watch was not purchased directly from them.
<Temperature>
• The watch may stop or the function of the watch may be impaired in extremely high or low
temperature. Do not use the watch in places where the temperature is outside the operating
temperature range as stated in the specifications.
68
<Magnetism>
• Analog quartz watches are powered by a step motor that uses a magnet. Subjecting the watch to
strong magnetism from the outside can cause the motor to operate improperly and prevent the watch
from keeping time accurately. Do not allow the watch to come into close proximity to magnetic
health devices (magnetic necklaces, magnetic elastic bands, etc.) or the magnets used in the latches
of refrigerator doors, clasps used in handbags, the speaker of a cell phone, electromagnetic cooking
devices and so on.
<Strong Shock>
• Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions and/or
performance deterioration as well as damage to the case and bracelet.
<Static Electricity>
• The integrated circuits (IC) used in quartz watches are sensitive to static electricity. Please note the
watch may operate erratically or not at all if exposed to intense static electricity.
<Chemicals, Corrosive Gasses and Mercury>
• If paint thinner, benzene or other solvents or products containing these solvents (including gasoline,
nail-polish remover, cresol, bathroom cleaners and adhesives, water repellent, etc.)
are allowed to come into contact with the watch, they may discolor, dissolve or crack the materials.
Be careful when handling these chemicals. Contact with mercury such as that used
in thermometers may also cause discoloration of the band and case.
69
English
Precautionary items and usage limitations
Precautionary items and usage limitations
<Protective Stickers>
• Be sure to remove any protective stickers that may be on your watch (case back, band, clasp, etc.).
Otherwise, perspiration or moisture may enter the gaps between the protective stickers and the parts,
which may result in a skin rash and/or corrosion of the metal parts.
CAUTION
Always Keep Your Watch Clean
• Rotate the crown while it is pressed in fully and press the buttons periodically so they do not become
stuck due to accumulations of foreign matter.
• The case and band of the watch come into direct contact with the skin in the same manner as
undergarments. Corrosion of the metal or unnoticed soiling such as that caused by perspiration and
dirt can soil sleeves and other portions of clothing. Keep your watch clean at all times.
• The case and band of the watch come into direct contact with the skin. If you think there is something
wrong, discontinue wearing the watch immediately and consult your physician.
In the case of accumulation of sweat or dirt on a metal band or case, clean thoroughly using
a brush and neutral detergent. In the case of a leather band, wipe clean using a dry cloth.
• Leather bands may become discolored by perspiration or dirt. Always keep your leather band clean
by wiping with a dry cloth.
70
Caring for Your Watch
• Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth.
• For a metallic, plastic or rubber (urethane) watchband, wash any dirt off with water. Remove the
small amounts of dirt trapped between the crevices of the metallic band with a soft brush.
• For a leather band, wipe off dirt using a dry cloth.
• If you will not be using your watch for an extended period of time, carefully wipe off any
perspiration, dirt or moisture and store in a proper location, avoiding locations subject to excessively
high or low temperatures and high humidity.
<When Luminous Paint is used for your watch>
The paint on the dial and hands helps you with reading the time in a dark place. The luminous
paint stores light (daylight or artificial light) and glows in a dark place.
It is free from any radioactive substance or any other material harmful to a human body or
environment.
• The light emission gradually becomes weaker as time passes.
• The duration of the light (“glow”) will vary depending on the brightness, types of and
distance from a light source, exposure time, and the amount of the paint.
• The paint may not glow and/or may dissipate quickly if exposure to light was not sufficient.
71
English
Precautionary items and usage limitations
Specifications
Model
H80*
Type
Analog solar-powered watch
Timekeeping
Within ±15 seconds per month when worn at normal operation
accuracy
(without the time temperatures (between +5°C/41°F and +35°C/95°F)
signal reception)
Operating
-10°C/14°F ~ +60°C/140°F
temperature range
• Time: hours, minutes, seconds, 24-hour time
Display functions • Calendar: Date, day of the week
• Power reserve: 4 levels
Maximum run
time from full
charge
72
• Fully charged to fully discharged:
Approximately ten months (with power save feature)
Approximately six months (without power save feature)
• Power reserve upon insufficient charge warning function:
Approximately two days
* Maximum run time shown is effective under following conditions.
• The chronograph is used once per day for 60 minutes.
• The automatic reception is performed once per day.
Battery
Rechargeable cell (lithium button cell), 1pc.
Additional
functions
• Solar power function • Overcharging prevention function
• Insufficient charge warning function (two-second interval movement) • Energy saving function (power save feature)
• Receiving time signal (automatic, on demand, automatic recovery)
Signal stations: Japan (East/West)/USA/Germany/China
* When the time difference is corrected, the signal station is switched.
• Indicating the state of reception (RX, OK or NO)
• Indicating the result of the last reception
• Automatic selection of time signal stations
• Summer Time (ON/OFF, Auto/Manual)
• Chronograph (up to 60 minutes in 1/20 second increments)
• City setting (26 cities)
• Perpetual calendar (until February 28th, 2100)
• Checking and correcting the reference position
Specifications are subject to change without prior notice.
73
English
Specifications
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
