Settings in the configuration tool
Double-click on the Peripherals folder in the Project Manager in the configuration
tool for the operator terminal.
Right-click on Expansion Port and select EM-Fieldbus. Then drag Controller 1 or
Controller 2 with the corresponding driver to the EM-Fieldbus icon. To change the
selected driver, select Properties from the Project menu.
For further information, please see the information for the driver.
Expansion Module for Profibus DP
Installation
MA00791 2005-09
English
Installation of Expansion Module for Profibus DP
Installation of Expansion Module for Profibus DP
Installation of Expansion Module for Profibus DP
Space Requirements
The expansion module is used for the operator terminal to communicate via
Profibus DP. The correct driver must be installed in the operator terminal.
Important
Read the entire installation instructions prior to installing and using this equipment. Only qualified personnel may install, operate or repair this equipment.
Users must acquire the appropriate knowledge to use the equipment properly.
The manufacturer does not assume any responsibility for modified, altered or
renovated equipment.
THE MANUFACTURER SHALL NOT BE LIABLE TO ANYONE FOR
ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTAL DAMAGES RESULTING FROM THE INSTALLATION, USE OR REPAIR OF THIS EQUIPMENT, WHETHER ARISING IN TORT,
CONTRACT, OR OTHERWISE. BUYER’S SOLE REMEDY SHALL BE
THE REPAIR, REPLACEMENT, OR REFUND OF PURCHASE PRICE,
AND THE CHOICE OF THE APPLICABLE REMEDY SHALL BE AT
THE SOLE DISCRETION OF THE MANUFACTURER.
Attention:
Observe precautions for handling electrostatic sensitive devices.
70 mm
30 mm
Installation
1. Unpack and check the delivery. If damage is found, notify the supplier.
M3x6 - 4 pcs
Note:
Place the terminal on a stable surface during installation. Dropping it or letting it
fall may cause damage.
2. Disconnect the operator terminal from the power supply.
3. Remove the plastic cover from the expansion port.
Technical Data
Size, W x H x D
87 x 70 x 30 mm
Weight
0,1 kg
4. Secure the expansion module in position, using the provided screws.
5. Connect the operator terminal to the power supply.
Installation of Expansion Module for Profibus DP
Installation of Expansion Module for Profibus DP
Installation of Expansion Module for Profibus DP
Space Requirements
The expansion module is used for the operator terminal to communicate via
Profibus DP. The correct driver must be installed in the operator terminal.
Important
Read the entire installation instructions prior to installing and using this equipment. Only qualified personnel may install, operate or repair this equipment.
Users must acquire the appropriate knowledge to use the equipment properly.
The manufacturer does not assume any responsibility for modified, altered or
renovated equipment.
THE MANUFACTURER SHALL NOT BE LIABLE TO ANYONE FOR
ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTAL DAMAGES RESULTING FROM THE INSTALLATION, USE OR REPAIR OF THIS EQUIPMENT, WHETHER ARISING IN TORT,
CONTRACT, OR OTHERWISE. BUYER’S SOLE REMEDY SHALL BE
THE REPAIR, REPLACEMENT, OR REFUND OF PURCHASE PRICE,
AND THE CHOICE OF THE APPLICABLE REMEDY SHALL BE AT
THE SOLE DISCRETION OF THE MANUFACTURER.
Attention:
Observe precautions for handling electrostatic sensitive devices.
70 mm
30 mm
Installation
1. Unpack and check the delivery. If damage is found, notify the supplier.
M3x6 - 4 pcs
Note:
Place the terminal on a stable surface during installation. Dropping it or letting it
fall may cause damage.
2. Disconnect the operator terminal from the power supply.
3. Remove the plastic cover from the expansion port.
Technical Data
Size, W x H x D
87 x 70 x 30 mm
Weight
0,1 kg
4. Secure the expansion module in position, using the provided screws.
5. Connect the operator terminal to the power supply.
Settings in the configuration tool
Double-click on the Peripherals folder in the Project Manager in the configuration
tool for the operator terminal.
Right-click on Expansion Port and select EM-Fieldbus. Then drag Controller 1 or
Controller 2 with the corresponding driver to the EM-Fieldbus icon. To change the
selected driver, select Properties from the Project menu.
For further information, please see the information for the driver.
Expansion Module for Profibus DP
Installation
MA00791 2005-09
English
