Pressure Regulators
Mark 53/54 Series
Differential Back Pressure Regulators
The Jordan Mark 53 maintains a constant differential
between the inlet pressure and the pressure loaded
on top of the diaphragm. It can be used for both differential and remotely adjusted applications. The Mark
54 provides the same flow capacity as the Mark 53
but with less offset in controlled pressure due to larger
diaphragm.
Features
•
Mark 53/54 — maintains a constant differential
between the inlet pressure and the pressure
loaded to the top of the diaphragm.
•
Sliding Gate Seats — all of Jordan Valve’s differential regulators feature advanced sliding gate
seat technology.
—— Straight-through flow for reduced turbulence and quiet operation
—— Short stroke for fast response and accurate
regulation
—— Easily interchangeable Cv’s
—— Tight Shutoff
Specifications
Sizes: (Note: 1/4” (DN8) & 3/8”(DN12) use 1/2”(DN15)
body with reducer bushings)
•
Mark 53/53HP: 1/4” (DN8) through 2” (DN50)
•
Mark 54: 1/4” (DN8) through 3/4” (DN20)
End Connections:
•
Threaded — FNPT, BSPT, BSPP
•
ANSI Flanges — 150#, 300#
•
DIN Flanges — PN10/16, PN25/40
Body Materials:
•
Ductile Iron
•
Bronze
•
Carbon Steel — A216 WCB
•
Stainless Steel — SA351 CF8M
Trim Materials:
•
303 SST — Standard on Ductile Iron, Bronze, or
Carbon Steel valves
•
316SST — Standard on Stainless Steel valves
Seat Materials:
•
Jorcote on SST — Standard
•
Jorcote/Jordanic on SST — For severe service
•
Chrome Plated SST — Optional
Jordan Valve, a division of Richards Industries
3170 Wasson Road • Cincinnati, OH 45209
513.533.5600 • 800.543.7311 • 513.871.0105 (f)
[email protected] • www.jordanvalve.com
Mark 53 Differential Back Pressure Regulators
The valve is normally closed. The inlet pressure acts
beneath the diaphragm and is opposed by the force
of the adjusting spring plus the pressure of the loading fluid. As the inlet pressure overcomes the set point
(the combined pressures on top of the diaphragm), the
valve moves toward the open position, relieving the
necessary pressure to maintain the set point.
Mark 53/54 Differential Back Pressure Regulators
Specifications (Cont'd)
Diaphragm Materials
•
Stainless Steel — Standard
•
Buna-N
•
Viton
•
Jorlon
Options:
•
DB: Double bolting for higher pressure ratings
•
C: Closing cap for adjusting screw
•
B: Bleed valve on spring housing (available only
with option C closing cap above)
•
H: Handwheel and packing box
•
F: Flow-through spring housing. Permits “in-oil-line”
installation for fuel oil atomization and steam atomizing systems. Reduces the possibility of the oil asphalting on top of the diaphragm
•
D: Separated double diaphragm (prevents mixing
fluids in case of ruptured diaphragm)
•
HP: High pressure spring housing
•
H: Handwheel and packing box
Spring Housing Materials: Ductile Iron
Service: Steam, oil, gas, air, chemicals, and water
Shutoff: ANSI Class IV
Body Rating:
Body
Matl.
DI
BRZ
CS
SS
End
Conn.
-20 to
100˚F
200˚F
300˚F
400˚F
500˚F
600˚F
650˚F
T.E.
300
(600)
300
(600)
300
(600)
300
(600)
300
(600)
300
(600)
300
(600)
150#FE
PN20
250
235
215
200
170
140
125
300#FE
PN50
300
(600)
300
(600)
300
(600)
300
(525)
300
(495)
300
(465)
300
(450)
600#FE
PN100
300
(600)
300
(600)
300
(600)
300
(600)
300
(600)
300
(600)
300
(600)
T.E.
300
(500)
300
(475)
300
(425)
300
(375)
300
(325)
N/A
N/A
150#FE
PN20
225
215
195
170
150
N/A
N/A
300#FE
PN50
300
(500)
300
(475)
300
(425)
300
(375)
300
(325)
N/A
N/A
T.E.
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
150#FE
PN20
285
260
230
200
170
140
125
300#FE
PN50
300
(740)
300
(675)
300
(665)
300
(635)
300
(600)
300
(550)
300
(535)
600FE
PN100
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
T.E.
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
300
(905)
300
(890)
150#FE
PN20
275
240
215
195
170
140
125
300#FE
PN50
300
(720)
300
(620)
300
(560)
300
(515)
300
(480)
300
(450)
300
(445)
600#FE
PN100
300
(950)
300
(950)
300
(950)
300
(950)
300
(950)
300
(905)
300
(890)
Differential Pressure Control Ranges, PSI (BAR)
Model
Size
Ranges in psi (bar)
1/4" - 3/4"
(DN8 - 20)
MK53
1" - 2"
(DN25 DN50)
MK53HP
MK54
1/2" - 2"
(DN15-25)
1/4" - 3/4"
(DN8-20)
2-20
(0,14-1,39)
10-30
(0,69-2,07)
30-135
(2,07-9,31)
80-185
(5,52-12,76)
1/2-4 (0,030,28)
2-6
(0,14-0,41)
4-13 (0,280,90)
8-20 (0,551,38)
15-80
(1,03-5,52)
45-150 (3,1010,34)
75-190
(5,17-13,10)
100-320
(6,89-22,06)
150-450
(10,34-31,03)
1/2-5
(0,03-0,34)
2-10
(0,14-0,69)
2-20
(0,14-1,38)
10-30
(0,60-2,07)
20-50
(1,38-3,45)
20-70
(1,38-4,83)
40-105
(2,76-7,24)
25-150
(1,72-10,34)
30-170
(2,07-11,72)
20-45 (1,383,10)
Cv (Kv) Value & Maximum Differential Pressures
Note: Double bolting option is required to reach pressures indicated in
parenthesis ( ). For temperatures below -20°F or above 650°F, consult
factory
Note: To convert temperature to Celsius: subtract Fahrenheit temperature by 32, multiply result by 5, divide answer by 9, final answer to temperature in Celsius ((F-32)*5/9 = C). To convert PSI to BAR, divide by
14.5.
Maximum Dome Loading Pressure: the combined pressure of the spring setting (psig) and dome loading (psig)
must not exceed the body rating.
-2-
Cv (Kv)
0.84 (0,74)
1.6 (1,4)
2.5 (2,2)
4.4 (3,8)
6.4 (5,5)
9.5 (8,2)
15 (12,9)
25 (21,5)
30 (25,8)
Size (DN)
1/4" (DN8)
3/8" (DN12)
1/2" & 3/4"
(DN15 & DN20)
1" & 1-1/4"
(DN25 & DN32)
1-1/2" ( DN40)
Seat Material
Jorcote
Jorcote
Max. ∆P PSI (bar)
400 (27,6)
400 (27,6)
Jorcote
400 (27,6)
Jorcote
400 (27,6)
Jorcote
325 (22,4)
2" (DN50)
Jorcote
325 (22,4)
* Low Flow Trim: reduced Cv’s (Kv’s) can be placed in
any size valve as long as it is smaller than the standard
Cv (Kv) for that particular size. In addition, the following
special low flows can be provided:
1.6
(1,38)
0.84
(0,72)
0.42
(0,36)
0.21
(0,18)
0.02
(0.017)
0.008
(0,007)
0.004
(0,003)
0.002
(0,0017)
0.08
(0,07)
0.04
(0,03)
0.0008 (not in 316SS)
(0,0007)
