TECHNICAL SALES GUIDE
Pioneer Digital Scroll Variable
Refrigerant Flow (VRF) Systems
Content
Introduction & nomenclature
Nomenclature & features
Configuration
Piping overview
Product combinations
Physical data (basic models)
Physical data (modular units)
Piping diagrams
Dimensional data (outdoor units)
Installation requirements
Cooling performance (outdoor units)
Heating performance (outdoor units)
Capacity correction
Wiring diagrams (outdoor units)
Inspection & handling
3
4
6
6
7
8
9
13
14
15
17
59
80
81
83
Ducted indoor units
Standard units & Options
Technical data ducted units
Dimensional data & piping system
Cooling performance data
83
84
84
86
88
Heating performance data
Fan performance
Wiring diagrams
93
96
99
Cassette Type Indoor Units
Physical data
Cooling performance
Heating performance
Dimensional data
Wiring diagram
101
102
103
106
107
108
Wall mounted indoor units
Physical data
Piping overview
Cooling performance
Heating performance
Wiring diagram
108
110
110
111
112
113
Refrigerant piping design
Oil trap design
113
123
Johnson Controls YORK® YES systems offer several advantages over other VRF and inverter type variable refrigerant flow
/ volume systems. YORK® VRF systems are technologically superior and use proven digital scroll technology. Unlike other
systems, YORK® VRF systems work efficiently in all the conditions among the operation range.
Our product reduces operating costs due to high full load efficiency and offers the freedom of flexible installations. With
YORK® VRF systems, it is possible to connect up to 48 indoor units to a single outdoor unit. A wide capacity output range,
intelligent controls and patented, advanced oil return technology provide long lasting comfort. The advanced technology
used in YORK® VRF systems eliminates hot and cold flashes experienced with other VRF systems, and ensures even levels of
comfort.
2
Introduction & Nomenclature
INTRODUCTION
6
This document is a technical sales guide for Johnson
Controls YORK ® YES systems. This manual covers the
necessary information for correct selection, system design,
installation, commissioning, startup and maintenance of the
unit.
Johnson Controls YORK® YES systems aim to provide you
with a comfortable indoor environment. Using the advanced
digital scroll technology, it can accurately maintain the ideal
room temperature while still saving energy. YORK® YES
system is a smart choice for better living.
This range of VRF products from Johnson Controls offers the
perfect combination of superior product quality, operating
efficiency and value for money. All units are manufactured
under strict quality control with full conformance to ISO
9001:2000 and ISO 14001.
The Johnson Controls YORK® YES air conditioners consist
of ceiling concealed / cassette / wall mount indoor units and
digital scroll outdoor condensing units.
The outdoor units are available in vertical air discharge
configurations, The cooling capacity ranges from 25.5 to
138kW with up to 3 modular units in combination. One
outdoor unit can drive up to 48 indoor units (model 340 and
above), and no matter what the room size or structure, there
is always a flexible combination.
Ceiling concealed indoor units range from 1.8 to 17.5kW
available in a range of 12 sizes. Ceiling cassette indoor units
range from 2.8 to 13kW in 8 sizes; while wall mounted indoor
units are available in 3 sizes with 3.2, 5.3 and 7kW cooling
capacities.
YORK® YES systems are suitable for a variety of applications
such as high rise apartment buildings, condominiums,
houses, offices, schools, shops, mosques, indoor play areas
and other similar applications. All units are designed with the
convenience of the customer and the end user in mind and
are factory assembled, tested, and supplied internally wired
and with refrigerant charge.
NOMENCLATURE (INDOOR UNITS)
Y
-1
1
2
3
4
5
D
-2
CC 034 H O F
-- -- -- -- -3 4 5 6
7
L E A
-- -- -8 9 10
York
Variable Refrigerant Flow (VRF)
Indoor unit type
CC : Ceiling concealed
HW : High wall
CK : Ceiling cassette
Cooling capacity code
Mode of operation
C : Cool only
H : Heat pump
0 C 3
-- -- -11 12 13
7
8
9
10
11
12
13
Auxiliary electric heater
O : No heater
2 : With 2 nos. heaters
Return plenum
N : None
B : With back return plenum
D : With bottom return plenum
F : With filter box and filter
Piping
L : Left
R : Right
Expansion device
E : Internal
O : External
Power supply
A : 220V / 1Ph / 50Hz
Design code
Design series number C: R410A
Application
3 : Export
NOMENCLATURE (OUTDOOR UNITS)
Y
-1
D
-2
0
-3
H 80
-- -4
5
E
-6
V
-7
V
-8
0 C 1
-- -- -9 10 11
E
-12
York
Variable Refrigerant Flow (VRF)
Outdoor unit
Mode of operation
C : Cool only
H : Heat pump
5 Cooling capacity code
6 Power supply
A : 220V/1Ph/50Hz
E : 380V/3Ph/50Hz
7 Structure
H : Horizontal discharge
V : Top discharge
8 Outdoor unit type
No mark : Single digital unit
V : Modular digital unit
F : Modular fixed unit
M : R22 Digital VRF Modular unit combination
N : R410A Digital VRF Modular unit combination
9 Design code
10 C: R410A
11 Design series number
1 : Export T1
3 : Export T3
12 Certification Mark
NO Mark: NO special certification
E: CE Mark
1
2
3
4
3
Nomenclature & System Features
SYSTEM FEATURES & BENEFITS
HIGH EFFICIENCY
In theory, digital scroll VRF system is more energy saving
than inverter VRF system as the power loss is less.
Sp ecial su b c ool ing cycl e guarantees sub cooli ng
temperature under any part load and long piping conditions,
to improve efficiency under any operating condition.
Additional high/low pressure sensors are added to guarantee
that the compressor runs under proper load according to
system requirements.
HIGH DEGREE OF SYSTEM RELIABILITY AS
COMPARED TO CONVENTIONAL VRF UNITS.
YES series digital scroll VRF units adopt new variable
capacity technology, eliminating the problematic AC-DC
converter, making the system design and controls compact.
Advanced oil return technology greatly increases the system
reliability. The oil return technology of YES series solves
the problem of compressor oil imbalance effectively. As the
operating time and internal pressure are different, some of
the compressors will have less oil resulting in damage to the
compressor. YES VRF systems use advanced oil return logic,
solenoid valves and oil receiver resulting in a balanced oil
distribution to each compressor.
COMPLETE SYSTEM PROTECTION ENSURE HIGH
RELIABILITY
Outdoor units have overload protection, phase sequence
and open phase protection, high discharge temperature
protection, high and low pressure cutouts and high current
protection. Indoor units have anti ice protection.
WIDER CAPACITY OUTPUT RANGE
10% ~ 100% capacity output range for single compressor
FAST COOLING AND HEATING
The refrigerant direct expansion system, together with
4
the digital scroll capacity control, quickly adjusts the room
temperature to the desired setting increasing your comfort
level and allowing conditioning each individual zone as it is
occupied.
ACCURATE TEMPERATURE CONTROL.
The 10 to 100% capacity control can instantly meet load
demand for either heating or cooling, to improve comfort
levels and lower operating costs result from being able to
control each zone or room individually.
QUIET OPERATION
The outdoor unit uses a multi-stage speed fan with quiet
operation, better meeting the load demand. The outdoor
fan is modulated by the condensing pressure and other
parameters. When the pressure is lower (such as in the
evening when the ambient is low), the outdoor fan reduces
speed or stops, and the noise is decreased.
BETTER DEHUMIDIFYING PERFORMANCE.
Compared with the conventional inverter control system,
YES series digital scroll VRF products can operate at lower
evaporating temperature with higher dehumidifying capacity,
thus continue to provide superior comfort throughout the
humid rainy season.
System Features
FLEXIBLE SELECTION
OUTDOOR UNIT FEATURES
One outdoor unit can drive up to 48 indoor units (model
340 and above), and no matter what the room size or
structure, there is always a flexible combination. Total indoor
unit capacity could be 50% to 130% of the outdoor unit
capacity, which make the selection more flexible.
Condensing units
are designed for
operation with
R410A refrigerant
and are available
in a vertical
air discharge
configuration for a
nominal capacity
ranging from 25.5
to 138kW with up
to 3 modular units
combination.
LONG PIPE TECHNOLOGY FACILITATES DESIGN
AND INSTALLATION
Maximum piping length is 150m while the vertical distance
between the outdoor unit and indoor unit is up to 50m. The
vertical distance between indoor units is up to 15m.
LOW ELECTROMAGNETIC INTERFERENCE
The advanced digital scroll capacity control needs no
frequency conversion, and does not produce high frequency
harmonics. Its superior electromagnetic compatibility means
it will not interfere with precise instruments such as some
measurement apparatus, pacemakers and home appliances
(e.g. mobile phone, TV, etc.) therefore increasing safety and
reliability.
INTELLIGENT CONTROL
Auto address setting
Manual indoor address setting takes a long time and will
always cause problems (duplicate the address, miss the
setting of some indoor units, etc.). Johnson Controls YORK®
YES series offer auto address setting function which makes
the address setting easy and free from mistakes. After the
connection of all communication wiring is finished, the
indoor unit address can be auto-set with a press on ’Auto
address setting’ button on outdoor control board.
Key card function
For hotels and intelligent residential applications, key card
function is available. 4 DIP switches are added on indoor
control board. When the DIP switches are set as ‘ON’, key
card function will be activated, and it will be deactivated
when the DIP switches are set as ‘OFF’.
Wired controllers are available as standard for ceiling
concealed and cassette indoor units. The controls are
microprocessor based and provide a user interface. Wireless
controllers are optional to ceiling concealed and cassette
indoor units and standard for wall mount indoor units. The
system also offers an auto restart to default setting.
Condensing units
are with digital
scroll or standard
scroll compressors
mounted on
rubber grommet
anti vibration mounts and complete with crankcase heaters.
All compressors have auto reset overload protection, high
and low pressure cutouts, discharge temperature, power
phase sequence lost and current protection for additional
compressor safety.
Unit casing is constructed of painted GI steel. Exterior
surfaces are cleaned and the load bearing panels are
adequately strengthened for maximum reliability.
Condenser coils are made of copper tubes mechanically
bonded to aluminum fins. Each coil is through pressure
tested at factory to detect any leaks.
Condensers are suitably protected to prevent damage at site
during handling and installation. Condenser fans are of axial
type with statically and dynamically balanced blades, directly
driven by BLDC, Class E Insulation and IP 23 grade type
motor ensuring quiet operation.
The fan motors are of permanently lubricated type with
internal thermal protection as standard. All shafts are
protected against rusting. All condensing units have factory
assembled contactors, relays and terminal blocks for easy
wiring during installation.
Options:
•• Condenser coil coated fins to pass 2000 hours salt spray
(ASTM B117) for corrosive environment are available as an
option.
5
Configuration
CONFIGURATION
Sheet Metal Frame
Control
Box
Fan
Motor
Sheet
metal
Piping
Compressor
Coil
Fan & Motor
Coil
Assembly
Note : Above figures shows the YDOH 80 –100 system. Actual equipment may vary from the picture.
PIPING SYSTEM
High pressure
sensor
Accumulator
Discharge
Pipe
Low pressure
sensor
Capillary
Subcooling EXV 3
Check valve
Unload valve
Oil tank
Fix Compressor
Digital Compressor
6
Oil seperator
Suction pipe
Combinations & Physical Data - Outdoor Units
(Basic Models)
COMBINATIONS
Capacity and Combination
Outdoor
Model
Type of Unit
80
Basic Model
100
120
140
Max # of indoor units
160
YDOH(C)xxE
VV-0C1
YDOH180
32
YDOH200
32
YDOH220
32
YDOH240
32
YDOH260
32
YDOH280
32
YDOH300
32
Variable Unit
Modular
YDOH320
Units
YDOH340
32
48
YDOH360
48
YDOH380
48
YDOH400
48
YDOH420
48
YDOH440
48
YDOH460
48
YDOH480
48
DATA SHEET - OUTDOOR UNITS (BASIC MODELS)
Following data table includes both cool only and heat pump models. YDOC refers to cooling only model and YDOH refers to
heat pump models. The data marked * is applicable to heat pump models only.
Model
YDOH80E
VV-0C1
YDOH100E
VV-0C1
YDOH120E
VV-0C1
YDOH140E
VV-0C1
YDOH160E
VV-0C1
Cooling Capacity
kW
25.5
28.5
32
41
46
Heating Capacity
kW
29
31.5
35
43
47
Power Supply
Cooling
Power Input
380V 3N ~50Hz
Compressors
kW
7.69
9.07
9.37
11.52
15.1
Fan
kW
0.45
0.45
0.72
1.14
1.14
A
16
18
20
25
31
Compressors
kW
7.51
8.08
8.09
9.57
12.3
Fan
1.14
Cooling Current Input
Heating
Power Input
kW
0.45
0.45
0.72
1.14
Heating Current
A
15
16
18
23
27
Maximum Power Input
kW
11.5
13
14
18
21
Maximum Current Input
A
22.2
23.8
29.1
34.1
40.1
Air Flow
m3/min
185
185
235
250
250
Dimension
Refrigerant
H
mm
W
mm
T
mm
Type
-
Charge
kg
Machine Weight
Connecting
Pipes
Gas
1000
1300
770
R410A
9
10
kg
270
270
mm
Φ19.05
Φ22.23
Liquid
mm
Oil
mm
Maximum number of indoor units
1650
12
320
380
Φ25.4
Φ9.52
380
Φ28.58
Φ12.7
Φ6.35
16
7
Physical Data (Modular Outdoor Units)
DATA SHEET - OUTDOOR UNITS (MODULAR MODELS)
Model
Standard Combination
YDOH180EVN
YDOH200EVN
YDOH220EVN
YDOH240EVN
YDOH80EVV+
YDOH100EVV+
YDOH100EVV+
YDOH100EVV+
YDOH100EVV
YDOH100EVV
YDOH120EVV
YDOH140EVV
Cooling Capacity
kW
54
57
60.5
69.5
Heating Capacity
kW
60.5
63
66.5
74.5
Compressors
kW
7.69+9.07
9.07+9.07
9.07+9.37
9.07+11.52
Fan
kW
0.45+0.45
0.45+0.45
0.45+0.72
0.45+1.14
A
16+18
18+18
18+20
18+25
Compressors
kW
7.51+8.08
8.08+8.08
8.08+8.09
8.08+9.57
Fan
0.45+1.14
Power Supply
Cooling
Power Input
380V 3N ~50Hz
Cooling Current Input
Heating
Power Input
kW
0.45+0.45
0.45+0.45
0.45+0.72
Heating Current
A
15+16
16+16
16+18
16+23
Maximum Power Input
kW
11.5+13
13+13
13+14
13+18
Maximum Current Input
A
22.2+23.8
23.8+23.8
23.8+29.1
23.8+34.1
Air Flow
m3/min
185+185
185+185
185+235
185+250
Refrigerant Type
-
Machine Weight
kg
270+320
270+380
R410A
270+270
270+270
Maximum number of indoor units
32
Model
Standard Combination
YDOH260EVN
YDOH280EN
YDOH300EVN
YDOH320EVN
YDOH100EVV+
YDOH120EVV+
YDOH140EVV+
YDOH160EVV+
YDOH160EVV
YDOH160EVV
YDOH160EVV
YDOH160EVV
Cooling Capacity
kW
74.5
78
87
92
Heating Capacity
kW
78.5
82
90
94
Power Supply
Cooling
Power Input
380V 3N ~50Hz
Compressors
kW
9.07+15.10
9.37+15.10
11.52+15.10
15.10+15.10
Fan
kW
0.45+1.14
0.72+1.14
1.14+1.14
1.14+1.14
A
18+31
20+31
25+31
31+31
Compressors
kW
8.08+12.30
8.09+12.30
9.57+12.30
12.30+12.30
Fan
Cooling Current Input
Heating
Power Input
kW
0.45+1.14
0.72+1.14
1.14+1.14
1.14+1.14
Heating Current
A
16+27
18+27
23+27
27+27
Maximum Power Input
kW
13+21
14+21
18+21
21+21
Maximum Current Input
A
23.8+40.1
29.1+40.1
34.1+40.1
40.1+40.1
185+250
235+250
250+250
250+250
410+420
420+420
Air Flow
m3/min
Refrigerant Type
-
Machine Weight
kg
Maximum number of indoor units
8
R410A
270+420
330+420
32
Physical Data (Modular Outdoor Units)
DATA SHEET - OUTDOOR UNITS (MODULAR MODELS)
Model
Standard Combination
YDOH340EVN
YDOH360EVN
YDOH380EVN
YDOH400EVN
YDOH100EVV+
YDOH100EVV+
YDOH100EVV+
YDOH100EVV+
YDOH100EVV+
YDOH100EVV+
YDOH120EVV+
YDOH140EVV+
YDOH140EVV
YDOH160EVV
YDOH160EVV
YDOH160EVV
Cooling Capacity
kW
98
103
106.5
115.5
Heating Capacity
kW
106
110
113.5
121.5
Compressors
kW
9.07+9.07+11.52
9.07+9.07+15.10
9.07+9.37+15.10
9.07+11.52+15.10
Fan
kW
0.45+0.45+1.14
0.45+0.45+1.14
0.45+0.72+1.14
0.45+1.14+1.14
A
18+18+25
18+18+31
18+20+31
18+25+31
Compressors
kW
8.08+8.08+9.57
8.08+8.08+12.30
8.08+8.09+12.30
8.08+9.57+12.30
Fan
Power Supply
Cooling
Power Input
380V 3N ~50Hz
Cooling Current Input
Heating
Power Input
kW
0.45+0.45+1.15
0.45+0.45+1.14
0.45+0.72+1.14
0.45+1.14+1.14
Heating Current
A
16+16+23
16+16+27
16+18+27
16+23+27
Maximum Power Input
kW
13+13+18
13+13+21
13+14+21
13+18+21
Maximum Current Input
A
23.8+23.8+34.1
23.8+23.8+40.1
23.8+29.1+40.1
23.8+34.1+40.1
185+185+250
185+185+250
185+235+250
185+250+250
270+330+420
270+410+420
Air Flow
m3/min
Refrigerant Type
-
Machine Weight
kg
R410A
270+270+410
270+270+420
Maximum number of indoor units
48
Model
Standard Combination
YDOH420EVN
YDOH440EVN
YDOH460EVN
YDOH480EVN
YDOH100EVV+
YDOH120EVV+
YDOH140EVV+
YDOH160EVV+
YDOH160EVV+
YDOH160EVV+
YDOH160EVV+
YDOH160EVV+
YDOH160EVV
YDOH160EVV
YDOH160EVV
YDOH160EVV
Cooling Capacity
kW
120.5
124
133
138
Heating Capacity
kW
125.5
129
137
141
Power Supply
Cooling
Power Input
380V 3N ~50Hz
Compressors
kW
9.07+15.10+15.10
9.37+15.10+15.10
11.52+15.10+15.10
15.10+15.10+15.10
Fan
kW
0.45+1.14+1.14
0.72+1.14+1.14
1.14+1.14+1.14
1.14+1.14+1.14
A
18+31+31
20+31+31
25+31+31
31+31+31
Compressors
kW
8.08+12.30+12.30
8.09+12.30+12.30
9.57+12.30+12.30
12.30+12.30+12.30
Fan
Cooling Current Input
Heating
Power Input
kW
0.45+1.14+1.14
0.72+1.14+1.14
1.14+1.14+1.14
1.14+1.14+1.14
Heating Current
A
16+27+27
18+27+27
23+27+27
27+27+27
Maximum Power Input
kW
13+21+21
14+21+21
18+21+21
21+21+21
Maximum Current Input
A
23.8+40.1+40.1
29.1+40.1+40.1
34.1+40.1+40.1
40.1+40.1+40.1
185+250+250
235+250+250
250+250+250
250+250+250
380+380+380
380+380+380
Air Flow
m3/min
Refrigerant Type
-
Machine Weight
kg
Maximum number of indoor units
R410A
270+380+380
48
9
Physical Data (Modular Outdoor Units)
TECHNICAL DATA - OUTDOOR UNITS (BASIC MODELS)
Outdoor Unit Models
Cooling
Nominal Capacities
Heating
YDOH80EVV-0C1 YDOH100EVV-0C1 YDOH120EVV-0C1 YDOH140EVV-0C1 YDOH160EVV-0C1
Btu/h
87,006
97,242
109,184
139,892
kW
25.5
28.5
32
41
46
kcal/h
21,930
24,510
27,520
35,260
39,560
Btu/h
98,948
107,478
119420
146,716
160,364
kW
29
31.5
35
43
47
kcal/h
24,940
27,090
30100
36,980
40,420
16.24
V/Ph/Hz
Power Supply
380-415/3/50
Ph
3
Power Consumption (cooling)
kW
8.14
9.52
10.09
12.66
Running Current(cooling)
A
16
18
20
25
31
Power Consumption (heating)
kW
7.96
8.53
8.81
10.71
13.44
Running Current(heating)
A
15
16
18
23
27
Refrigerant Type
-
Refrigerant Charge
kg
Model
Power Supply
Compressor
Fan
Fan Motor
Accumulator
9
9
10
ZPD61KCE-TFD-
ZPD72KCE-TFD-
ZPD72KCE-TFD-
433*1+
433*1+
433*1+
ZP57K3E-
ZP57K3E-
ZP72KCE-
TFD-422*1
TFD-422*1
TFD-420*1
12
12
ZPD72KCE-TFD-
ZPD61KCE-TFD-
433*1+
433*1+
ZP72KCE-
ZP57K3E-TFD-422*2
TFD-420*2
380-415/3/50
Ph
3
Quantity
Pcs
2
3
Compressor Type
-
Digital Scroll+ Fix Scroll(Tandem)
Digital Scroll+ Fix Scroll(Modular)
Oil Charge
L
1.892+1.656
1.774+1.656
1.892+1.774
1.892+1.656*2
Max. Operating Current
A
11.8+11.0
15.0+11.0
15.0+15.0
11.8+11.0*2
15.0*3
Nominal Current
A
8.5+8.1
9.8+8.1
9.8+9.7
8.5+8.1*2
9.8+9.7*2
1.892+1.774*2
Capacity
kW
13.6*2
16.6+13.6
16.6*2
13.6*3
16.6*3
Input Power
kW
4.93+4.61
5.75+4.61
5.75+5.65
4.93+4.61*2
5.75+5.65*2
Vibration Isolator
-
metal
Protection Device
-
Auto Reset Thermal Overload
Air flow volume
m3/h
Fan Type / Drive
-
10500
12500
17500
Propeller/Direct Drive
Blade Material
-
Diameter
mm
Φ700
Φ590
Quantity
Pcs
1
2
2
BLDC
BLDC
BLDC
Plastic
Φ590
Rotator Speed
rpm
870
1060
1075
Rated Running Current
A
2.05
1.64*2
2.59*2
Capacitance
μf
-
-
-
Rated Input
W
450
360*2
560*2
Quantity
Pcs
1
2
Volume
L
12
22
Diameter
mm
Φ220
Φ220
Height
mm
423
595
Connections ODF
mm
Φ25.4
Φ28.6
Model
Oil Separator
R-410A
V/Ph/Hz
Model
10
156,952
SX-5203
Connections ODF
mm
22.23
Diameter
mm
101.6
Height
mm
425
Physical Data (Modular Outdoor Units)
TECHNICAL DATA - OUTDOOR UNITS (BASIC MODELS)
Model/Brand
*EXV1/EXV2
VPF-32D23 / Hua lu
VPF-25D18 / Hua lu
Quantity
Pcs
1
2
2
Nominal Capacity
kW
38.7
23
38.7
Pipe Outer Diameter
inch
1/2" - 3/8"(out-in)
5/16" - 5/16"(out-in)
1/2" - 3/8"(out-in)
Port Size
mm
3.2
2.5
3.2
Pulse
p
Max.O.P.D
MPa
Power Supply
V
0-480
2.5
3.5
SPF-16D32 / Hua lu
Quantity
Pcs
1
Nominal Capacity
kW
9.5
Pipe Outer Diameter
mm
7.94 – 7.94(out-in)
Port Size
mm
1.6
Pulse
p
0-480
Max.O.P.D
MPa
3.63
Power Supply
V
DC 12V
Model/Brand
Port Size
Power Supply
* 4-Way Valve
STF-0715G
STF-1511G
mm
20
23
V/Ph/Hz
AC220/1/50
AC220/1/50
Ph
1
1
Connections ODF(Di/Su)
mm
22.23/28.58
22.23/28.58
0.3
Min. O.P.D
MPa
0.3
Max. O.P.D
MPa
3.1
3.1
Nominal Capacity
kW
21-53
39-59
Model
Gas Valve
Solenoid Valve
FDF2A65
Power Supply
V/Ph/Hz
220-240/1/50
Pipe Diameter
inch
1/4"
Port Size
mm
1.9
Min. O.P.D
MPa
0
Max. O.P.D
MPa
2.1
Quantity
Pcs
Model
Oil Valve
discharge
pressure
Pressure
Transducer
Power Supply
V/Ph/Hz
220-240/1/50
Pipe Diameter
inch
1/4"
Port Size
mm
1.2
Min. O.P.D
MPa
0
Max. O.P.D
MPa
2.1
Quantity
Pcs
High
Pressure
2
45CP2-7
Power Supply
VDC
5
Output Voltage Span
VDC
0.5-4.5
Pressure Span
MPaG
0.0 to 4.6
Quantity
Pcs
Model
suction
pressure
3
FDF2A73
Model
Pressure Switchs
2.5
DC 12V
Model/Brand
EXV3
VPF-32D23 / Hua lu
1
45CP2-5
Power Supply
VDC
5
Output Voltage Span
VDC
0.5-4.5
Pressure Span
MPaG
0.0 to 2.0
Quantity
Pcs
Model
Quantity
1
Pressure Switch 4.0MPa/3.1MPa-2m CH
Pcs
1
11
Physical Data (Modular Outdoor Units)
TECHNICAL DATA - OUTDOOR UNITS (BASIC MODELS)
Pressure Switchs
Model
Low Pressure
Quantity
Pressure Switch 0.15MPa/0.3MPa-2m CH
Pcs
1
Model
Crank Heater
ZR57-81 Crankcase heating
Power Consumption
W
35
35
Quantity
Pcs
2*2
2*3
Material
Tube
Diameter
Inner Groove Copper Tube
mm
7
Material
Fin
Aluminum
Row
-
2
3
FPI
-
14
13
Coil
Total Number of Tubes
Pcs
Length per tube
mm
116
2034
Total length
m
236
271
398
m2
4.818
5.529
8.137
Height
mm
Width
mm
Depth
mm
Machine Weight
kg
1650
1000
Thickness
Casing
260
mm
Type
mm
Liquid Pipe
mm
Oil Pipe
330
410
0.9-1.2
0.9-1.2
Polyester Paint
Polyester Paint
19.05
Brazing + Nuts
22.23
25.4
9.52
28.58
12.7
mm
Pcs
420
Electro-galvanized Steel
Brazing + Nuts
Gas Pipe
The maximum number of indoor units
270
Electro-galvanized Steel
Finish
Pipe Size
1,300
770
Material
12
2290
Total Tube inside surface Area
Dimension
Piping
174
2334
6.35
16
16
Piping Diagrams - Outdoor System
OUTDOOR SYSTEM PIPING DIAGRAM
Following figures and symbols are used in the system refrigerant piping diagram on page 14. Meaning of the symbols us is
described in following table.
No.
Symbol
1
TO in
Definition
2
TO out
Outdoor coil outlet temperature
3
TO air
Outdoor ambient temperature
4
Tliquid
Liquid pipe temperature
5
Tsubin
Sub-cooler inlet temperature
6
Tsubout
7
Exv3
8
Low pressure switch
Outdoor coil inlet temperature
Sub-cooler outlet temperature
Electronic Expansion Valve for sub-cooler
Pressure is lower than 0.15 MPa protection
9
PI
Low pressure transducer
10
PH
High pressure transducer
11
High pressure switch
12
PWM Valve
Pressure is higher than 4.0 MPa protection
13
DLT
Compressor discharge temperature, 115℃ protection
14
Voil1
Solenoid valve used for oil balance
15
Voil2
Solenoid valve used for oil balance
16
Voil3
Solenoid valve used for oil balance
17
Tsin
18
Oil Return Valve
Used for digital compressor to control the capacity of compressor
Accumulator inlet temperature (Suction temperature)
Used for oil return from accumulator
19
Subcooler
Lower the liquid temperature
20
Oil separator
Separate oil and refrigerant
21
Digital Comp.
Digital scroll compressor
22
Fix Comp.
23
Accumulator
24
Fan and Motor
Fixed compressor
Separate the liquid from gas
BLDC motor
HEAT PUMP Models: YDOH80, YDOH100, YDOH120
HEAT PUMP Models: YDOH140, YDOH160
13
Outdoor Unit Dimension
YDOH80/100EV series outdoor unit
YDOH120/140/160EVV series outdoor unit
Mounting hole spacing
Mounting hole spacing
YDOC (H) 80/100 has a single fan, since their appearance on the chart with the same schematic; YDOC (H) 120/140/160 for
dual fans, outline schematic with a slightly difference.
Dimension
Installation
Model
A
B
L
H1
U
W
YDOH80/100
574
213
1000
1650
798
770
4
YDOH120/140/160
834
233
1300
1650
1098
770
6
Installation Requirements
INSTALATION REQUIREMENTS –
OUTDOR UNITS
The installation space requirement shown in the figure is a
reference for cooling operation when the outdoor
Temperature is 35°C. If the design outdoor temperature
exceeds 35°C or the heat load exceeds maximum capacity in
all the outside unit, take an even larger space on the intake
shown in the figure.
14
Hole Quantity
WHEN INSTALLED AS A SINGLE UNIT
Size (mm)
Model
YDOC(H)80—160
A
B
C
D
≥200
≥100
500
≥100
•• The foundation is strong enough to support the weight of
the unit and the floor is flat to prevent vibration and noise
generation.
•• Locations where the unit’s suction vent and outlet vent
do not generally face the wind. Wind blowing directly into
the suction or outlet vents will interfere with the unit’s
operation. If necessary, install some kind of obstruction to
block the wind.
•• The space around the unit is adequate for servicing and
the minimum space for air inlet and air outlet is available.
•• The piping length between the outside unit and the indoor
unit may not exceed the allowable piping length.
WHEN INSTALLED IN SERIAL
A
B
C
D
E
F
YDOC(H)180~480EVM
Models
First
≥200
≥500
≥100
≥100
≥200
≥200
-0B
Second
≥300
-
≥200
-
≥400
≥400
Note :
1. For First.
a. Front wall or adjacent unit height should be lower than 1500mm. Backside
wall or adjacent unit height should be lower that 500mm. No height
limitation for the side wall.
Installation
Requirements
b. If the wall or adjacent unit height beyond the maximum, expand 1/2 h1 and
1/2 h2 distance on the A and B clearance.
2. No height limitation for Second.
OUTDOOR INSTALLATION BASE AND
PLACING THE UNIT
LOCATION SELECTION
The outdoor should be installed on a strong base to avoid
the noise. The base could be solid concrete and height
should be more than 150 mm.
A location that meets the following conditions should be
selected:
Make sure the unit is installed level on a sufficiently strong
base to prevent vibration and noise (see figure).
•• Select the location of the unit in such a way that neither
the discharged air nor the sound generated by the unit
disturbs anyone.
The height of the base should be at least 150mm from the
floor.
•• In places where air short-circuit will not happen, it should
ensure a sufficient space to prevent short circuit cycle when
installing several units.
Secure the unit to its base using foundation bolts. (Use four
commercially available M12-type foundation bolts, nuts, and
washers.) The foundation bolts should be inserted 21mm.
•• Places where there is no barrier at the air inlet and outlet.
15
A vibration isolator should be placed between the foundation
and the outdoor unit base (such as the installation of rubber
isolation pads and damp spring isolators, etc).
Model
A (unit
width)
mm
B(mounting
hole width)
mm
Mounting
hole
quantity
80/100
1000
798
4
120/140/160
1300
1098
6
After the outdoor unit has been installed, please check
whether the outdoor unit is horizontal and the tilt angle
should be less than 10°. If a vibration absorber is equipped,
please inspect whether it is horizontal after the vibration
absorber has been installed.
16
Isolation devices should be correctly selected and
installed according to design requirements to meet the
vibration isolating requirements and avoid the solid sound
transmission and the resonance phenomena. Models
should normally be provided by professional engineers and
constructed by professional personnel.
WARNING: When the outdoor unit is higher than the
lightning protection device of a building, the original lightning
protection device should be adjusted or a new lightning
protector should be provided additionally, so that the
protection device is higher than the unit and meets relevant
national requirements.
Cooling Performance - COOLING PERFORMANCE DATA – 80
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
17.2
2.8
20.5
3.4
23.8
4
25.5
4.3
27.2
4.7
30.5
5.3
32.2
5.5
12
17.2
2.9
20.5
3.5
23.8
4.1
25.5
4.4
27.2
4.8
30.5
5.5
32.2
5.5
14
17.2
2.9
20.5
3.5
23.8
4.2
25.5
4.5
27.2
4.9
30.5
5.6
31.4
5.5
16
17.2
3
20.5
3.6
23.8
4.3
25.5
4.6
27.2
5
30.4
5.6
31
5.6
18
17.2
3
20.5
3.7
23.8
4.3
25.5
4.7
27.2
5
29.9
5.8
30.6
5.9
20
17.2
3.1
20.5
3.7
23.8
4.5
25.5
4.9
27.2
5.4
29.6
6.1
30.2
6.1
21
17.2
3.1
20.5
3.8
23.8
4.6
25.5
5.1
27.2
5.6
29.4
6.2
29.9
6.3
23
17.2
3.2
20.5
4
23.8
5
25.5
5.5
27.2
6
28.9
6.5
29.5
6.6
25
17.2
3.4
20.5
4.3
23.8
5.3
25.5
5.9
27.2
6.4
28.1
6.8
29.1
6.9
27
17.2
3.6
20.5
4.6
23.8
5.7
25.5
6.3
27.2
6.9
27.7
7.1
28.7
7.1
29
17.2
3.9
20.5
4.9
23.8
6.1
25.5
6.7
27.1
7.3
27.2
7.4
28.3
7.4
31
17.2
4.1
20.5
5.2
23.8
6.5
25.5
7.2
26.6
7.6
26.9
7.7
27.9
7.7
33
17.2
4.4
20.5
5.6
23.8
6.9
25.5
7.6
26.2
7.9
26.4
8
27.4
8
35
17.2
4.6
20.5
5.9
23.8
7.4
25.5
8.1
25.8
8.2
27.2
8.2
27.1
8.3
37
17.2
4.9
20.5
6.3
23.8
7.8
25
8.4
25.4
8.5
26.1
8.5
26.6
8.6
39
17.2
5.2
20.5
6.7
23.8
8.4
24.7
8.7
24.9
8.8
25.6
8.8
26.2
8.9
42
17.2
5.5
20.5
7.1
23.8
8.8
24.3
9
24.5
9.1
24.7
9.1
25.7
9.2
44
17.2
5.8
20.5
7.5
23.8
9.3
23.9
9.3
24
9.4
23.9
9.4
25.3
9.5
9.8
46
17.2
6.2
20.5
7.8
23.8
9.8
23.5
9.6
23.6
9.6
23.1
9.7
25.1
10
15.5
2.5
18.4
3
21.4
3.6
23
3.9
24.5
4.1
27.4
4.7
30.4
5.3
12
15.5
2.5
18.4
3.1
21.4
3.6
23
3.9
24.5
4.2
27.4
4.8
30.4
5.4
14
15.5
2.6
18.4
3.1
21.4
3.7
23
4
24.5
4.3
27.4
4.9
30.4
5.5
16
15.5
2.6
18.4
3.2
21.4
3.8
23
4.1
24.5
4.4
27.4
5
30.4
5.6
18
15.5
2.7
18.4
3.3
21.4
3.9
23
4.2
24.5
4.5
27.4
5.1
29.9
5.8
20
15.5
2.7
18.4
3.3
21.4
3.9
23
4.2
24.5
4.6
27.4
5.5
29.5
6.1
21
15.5
2.8
18.4
3.4
21.4
4
23
4.4
24.5
4.8
27.4
5.7
29.4
6.2
23
15.5
2.8
18.4
3.5
21.4
4.3
23
4.7
24.5
5.2
27.4
6.1
28.9
6.5
25
15.5
3
18.4
3.7
21.4
4.6
23
5
24.5
5.5
27.4
6.5
28.5
6.8
27
15.5
3.2
18.4
4
21.4
4.9
23
5.4
24.5
5.9
27.4
7
28.1
7.1
29
15.5
3.4
18.4
4.2
21.4
5.2
23
5.7
24.5
6.3
27.1
7.3
27.7
7.4
31
15.5
3.6
18.4
4.5
21.4
5.6
23
6.1
24.5
6.7
26.6
7.6
27.2
7.7
33
15.5
3.8
18.4
4.8
21.4
5.9
23
6.5
24.5
7.2
26.3
7.9
26.9
8
35
15.5
4
18.4
5.1
21.4
6.3
23
7
24.5
7.6
25.8
8.2
26.4
8.2
37
15.5
4.3
18.4
5.4
21.4
6.7
23
7.4
24.5
8.1
25.5
8.5
26
8.5
39
15.5
4.5
18.4
5.8
21.4
7.1
23
7.9
24.5
8.7
25
8.8
25.6
8.8
42
15.5
4.8
18.4
6.1
21.4
7.6
23
8.4
24.5
9.2
24.7
9
25.2
9.1
44
15.5
5
18.4
6.4
21.4
8
23
8.8
24.5
9.7
24.3
9.3
24.8
9.4
46
15.5
5.3
18.4
6.8
21.4
8.4
23
9.3
24.5
10.2
23.9
9.6
24.4
9.7
10
13.8
2.2
16.4
2.7
19.1
3.1
20.4
3.4
21.7
3.6
24.4
4.1
27
4.7
12
13.8
2.3
16.4
2.7
19.1
3.2
20.4
3.4
21.7
3.7
24.4
4.2
27
4.7
14
13.8
2.3
16.4
2.8
19.1
3.2
20.4
3.5
21.7
3.8
24.4
4.3
27
4.8
16
13.8
2.3
16.4
2.8
19.1
3.3
20.4
3.6
21.7
3.8
24.4
4.4
27
4.9
18
13.8
2.4
16.4
2.9
19.1
3.4
20.4
3.6
21.7
3.9
24.4
4.5
27
5
20
13.8
2.4
16.4
2.9
19.1
3.4
20.4
3.7
21.7
4
24.4
4.6
27
5.4
21
13.8
2.4
16.4
3
19.1
3.5
20.4
3.7
21.7
4.1
24.4
4.8
27
5.6
23
13.8
2.5
16.4
3
19.1
3.6
20.4
4
21.7
4.3
24.4
5.1
27
6
25
13.8
2.6
16.4
3.2
19.1
3.9
20.4
4.3
21.7
4.7
24.4
5.5
27
6.4
27
13.8
2.7
16.4
3.4
19.1
4.1
20.4
4.6
21.7
5
24.4
5.9
27
6.9
29
13.8
2.9
16.4
3.6
19.1
4.4
20.4
4.8
21.7
5.3
24.4
6.3
27
7.3
31
13.8
3.1
16.4
3.9
19.1
4.7
20.4
5.2
21.7
5.7
24.4
6.7
27
7.6
33
13.8
3.3
16.4
4.1
19.1
5
20.4
5.5
21.7
6
24.4
7.1
27
7.9
35
13.8
3.5
16.4
4.3
19.1
5.3
20.4
5.9
21.7
6.4
24.4
7.6
27
8.2
37
13.8
3.7
16.4
4.6
19.1
5.7
20.4
6.2
21.7
6.8
24.4
8.1
27
8.5
39
13.8
3.9
16.4
4.9
19.1
6
20.4
6.6
21.7
7.3
24.4
8.6
27
8.7
42
13.8
4.1
16.4
5.2
19.1
6.4
20.4
7
21.7
7.7
24.4
9.1
27
9
44
13.8
4.3
16.4
5.5
19.1
6.7
20.4
7.4
21.7
8.1
24.4
9.7
27
9.3
46
13.8
4.5
16.4
5.8
19.1
7.1
20.4
7.8
21.7
8.6
24.4
10.2
27
9.6
17
Cooling Performance - COOLING PERFORMANCE DATA – 80
Capacity
factor(%)
70%
60%
50%
18
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
22
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
10
12.1
2
14.3
2.3
16.7
2.7
17.9
2.9
19
3.1
21.3
3.6
23.7
4
12
12.1
2
14.3
2.4
16.7
2.8
17.9
3
19
3.2
21.3
3.6
23.7
4.1
14
12.1
2
14.3
2.4
16.7
2.8
17.9
3
19
3.2
21.3
3.7
23.7
4.1
16
12.1
2.1
14.3
2.4
16.7
2.9
17.9
3.1
19
3.3
21.3
3.8
23.7
4.2
18
12.1
2.1
14.3
2.5
16.7
2.9
17.9
3.1
19
3.4
21.3
3.8
23.7
4.3
20
12.1
2.1
14.3
2.5
16.7
3
17.9
3.2
19
3.4
21.3
3.9
23.7
4.4
21
12.1
2.1
14.3
2.6
16.7
3
17.9
3.2
19
3.5
21.3
4
23.7
4.6
23
12.1
2.2
14.3
2.6
16.7
3.1
17.9
3.3
19
3.6
21.3
4.2
23.7
5.1
25
12.1
2.2
14.3
2.7
16.7
3.3
17.9
3.6
19
3.9
21.3
4.5
23.7
5.3
27
12.1
2.3
14.3
2.9
16.7
3.5
17.9
3.8
19
4.1
21.3
4.8
23.7
5.6
29
12.1
2.5
14.3
3.1
16.7
3.7
17.9
4
19
4.4
21.3
5.2
23.7
6
31
12.1
2.6
14.3
3.2
16.7
3.9
17.9
4.3
19
4.7
21.3
5.5
23.7
6.4
33
12.1
2.8
14.3
3.4
16.7
4.2
17.9
4.6
19
5
21.3
5.9
23.7
6.8
35
12.1
3
14.3
3.7
16.7
4.4
17.9
4.9
19
5.3
21.3
6.2
23.7
7.3
37
12.1
3.1
14.3
3.9
16.7
4.7
17.9
5.2
19
5.6
21.3
6.6
23.7
7.8
39
12.1
3.3
14.3
4.1
16.7
5
17.9
5.5
19
6
21.3
7.1
23.7
8.2
42
12.1
3.5
14.3
4.3
16.7
5.3
17.9
5.8
19
6.3
21.3
7.5
23.7
8.7
44
12.1
3.7
14.3
4.6
16.7
5.6
17.9
6.1
19
6.7
21.3
7.9
23.7
9.2
46
12.1
3.8
14.3
4.8
16.7
5.9
17.9
6.5
19
7
21.3
8.3
23.7
9.7
10
10.4
1.7
12.3
2
14.3
2.3
15.3
2.5
16.3
2.6
18.3
3
20.3
3.4
12
10.4
1.7
12.3
2
14.3
2.3
15.3
2.5
16.3
2.7
18.3
3
20.3
3.4
14
10.4
1.8
12.3
2.1
14.3
2.4
15.3
2.6
16.3
2.7
18.3
3.1
20.3
3.5
16
10.4
1.8
12.3
2.1
14.3
2.4
15.3
2.6
16.3
2.8
18.3
3.2
20.3
3.5
18
10.4
1.8
12.3
2.1
14.3
2.5
15.3
2.7
16.3
2.8
18.3
3.2
20.3
3.6
20
10.4
1.8
12.3
2.2
14.3
2.5
15.3
2.7
16.3
2.9
18.3
3.3
20.3
3.7
21
10.4
1.8
12.3
2.2
14.3
2.5
15.3
2.7
16.3
2.9
18.3
3.3
20.3
3.7
23
10.4
1.9
12.3
2.2
14.3
2.6
15.3
2.8
16.3
3
18.3
3.4
20.3
4
25
10.4
1.9
12.3
2.3
14.3
2.7
15.3
2.9
16.3
3.2
18.3
3.7
20.3
4.2
27
10.4
2
12.3
2.4
14.3
2.9
15.3
3.1
16.3
3.4
18.3
3.9
20.3
4.5
29
10.4
2.1
12.3
2.5
14.3
3
15.3
3.3
16.3
3.6
18.3
4.2
20.3
4.8
31
10.4
2.2
12.3
2.7
14.3
3.2
15.3
3.5
16.3
3.8
18.3
4.4
20.3
5.1
33
10.4
2.3
12.3
2.9
14.3
3.4
15.3
3.7
16.3
4.1
18.3
4.7
20.3
5.5
35
10.4
2.5
12.3
3
14.3
3.7
15.3
4
16.3
4.3
18.3
5
20.3
5.8
37
10.4
2.6
12.3
3.2
14.3
3.9
15.3
4.2
16.3
4.6
18.3
5.3
20.3
6.2
39
10.4
2.8
12.3
3.4
14.3
4.1
15.3
4.5
16.3
4.9
18.3
5.7
20.3
6.6
42
10.4
2.9
12.3
3.6
14.3
4.3
15.3
4.7
16.3
5.1
18.3
6
20.3
6.9
44
10.4
3.1
12.3
3.8
14.3
4.5
15.3
5
16.3
5.4
18.3
6.3
20.3
7.3
46
10.4
3.2
12.3
4
14.3
4.8
15.3
5.2
16.3
5.7
18.3
6.7
20.3
7.7
10
8.6
1.5
10.2
1.7
12
1.9
12.8
2.1
13.5
2.2
15.3
2.5
16.8
2.7
12
8.6
1.5
10.2
1.7
12
2
12.8
2.1
13.5
2.2
15.3
2.5
16.8
2.8
14
8.6
1.5
10.2
1.7
12
2
12.8
2.1
13.5
2.3
15.3
2.5
16.8
2.8
16
8.6
1.5
10.2
1.8
12
2
12.8
2.2
13.5
2.3
15.3
2.6
16.8
2.9
18
8.6
1.5
10.2
1.8
12
2.1
12.8
2.2
13.5
2.3
15.3
2.6
16.8
3
20
8.6
1.6
10.2
1.8
12
2.1
12.8
2.2
13.5
2.4
15.3
2.7
16.8
3
21
8.6
1.6
10.2
1.8
12
2.1
12.8
2.3
13.5
2.4
15.3
2.7
16.8
3
23
8.6
1.6
10.2
1.9
12
2.2
12.8
2.3
13.5
2.5
15.3
2.8
16.8
3.1
25
8.6
1.6
10.2
1.9
12
2.2
12.8
2.3
13.5
2.5
15.3
2.9
16.8
3.3
27
8.6
1.6
10.2
2
12
2.3
12.8
2.5
13.5
2.7
15.3
3.1
16.8
3.5
29
8.6
1.8
10.2
2.1
12
2.5
12.8
2.7
13.5
2.9
15.3
3.3
16.8
3.8
31
8.6
1.8
10.2
2.2
12
2.6
12.8
2.8
13.5
3
15.3
3.5
16.8
4
33
8.6
2
10.2
2.3
12
2.8
12.8
3
13.5
3.2
15.3
3.7
16.8
4.3
35
8.6
2.1
10.2
2.5
12
2.9
12.8
3.2
13.5
3.4
15.3
3.9
16.8
4.5
37
8.6
2.2
10.2
2.6
12
3.1
12.8
3.4
13.5
3.6
15.3
4.2
16.8
4.8
39
8.6
2.3
10.2
2.8
12
3.3
12.8
3.5
13.5
3.8
15.3
4
16.8
5.1
42
8.6
2.4
10.2
2.9
12
3.5
12.8
3.7
13.5
4
15.3
4.2
16.8
5.4
44
8.6
2.5
10.2
3.1
12
3.6
12.8
3.9
13.5
4.3
15.3
4.2
16.8
5.7
46
8.6
2.6
10.2
3.2
12
3.8
12.8
4.1
13.5
4.6
15.3
4.2
16.8
6
Cooling Performance - COOLING PERFORMANCE DATA – 100
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
19.2
3.3
22.9
4
26.6
4.7
28.5
5.1
30.4
5.5
34.1
6.2
36
6.5
12
19.2
3.3
22.9
4.1
26.6
4.8
28.5
5.2
30.4
5.6
34.1
6.4
36
6.4
14
19.2
3.4
22.9
4.1
26.6
4.9
28.5
5.3
30.4
5.7
34.1
6.5
35.1
6.4
16
19.2
3.5
22.9
4.2
26.6
5
28.5
5.4
30.4
5.8
34
6.6
34.6
6.5
18
19.2
3.5
22.9
4.3
26.6
5.1
28.5
5.5
30.4
5.9
33.5
6.8
34.2
6.8
20
19.2
3.6
22.9
4.4
26.6
5.2
28.5
5.8
30.4
6.3
33.1
7.1
33.7
7.2
21
19.2
3.6
22.9
4.4
26.6
5.4
28.5
6
30.4
6.6
32.8
7.3
33.5
7.4
23
19.2
3.7
22.9
4.7
26.6
5.8
28.5
6.4
30.4
7
32.3
7.6
33
7.7
25
19.2
4
22.9
5
26.6
6.2
28.5
6.9
30.4
7.5
31.4
8
32.6
8
27
19.2
4.2
22.9
5.4
26.6
6.6
28.5
7.3
30.4
8.1
30.9
8.3
32.1
83.4
29
19.2
4.5
22.9
5.7
26.6
7.1
28.5
7.8
30.3
8.6
30.4
8.7
31.7
8.7
31
19.2
4.8
22.9
6.1
26.6
7.6
28.5
8.4
29.8
8.9
30
9
31.2
9
33
19.2
5.1
22.9
6.5
26.6
8.1
28.5
8.9
29.3
9.2
29.5
9.3
30.7
9.4
35
19.2
5.4
22.9
6.9
26.6
8.6
28.5
9.5
28.9
9.6
30.4
9.6
30.3
9.7
37
19.2
5.8
22.9
7.4
26.6
9.2
28
9.8
28.4
9.9
29.1
10
29.8
10.1
39
19.2
6.1
22.9
7.8
26.6
9.8
27.6
10.2
27.9
10.2
28.6
10.3
29.3
10.4
42
19.2
6.5
22.9
8.3
26.6
10.3
27.1
10.5
27.4
10.6
27.6
10.7
28.8
10.8
44
19.2
6.8
22.9
8.7
26.6
10.9
26.7
10.9
26.8
10.9
26.7
11
28.2
11.1
46
19.2
7.2
22.9
9.1
26.6
11.5
26.3
11.2
26.3
11.3
25.8
11.4
28
11.5
10
17.3
2.9
20.6
3.5
23.9
4.2
25.7
4.5
27.4
4.9
30.7
5.5
34
6.2
12
17.3
3
20.6
3.6
23.9
4.3
25.7
4.6
27.4
4.9
30.7
5.7
34
6.4
14
17.3
3
20.6
3.7
23.9
4.3
25.7
4.7
27.4
5
30.7
5.8
34
6.5
16
17.3
3.1
20.6
3.7
23.9
4.4
25.7
4.8
27.4
5.1
30.7
5.9
34
6.6
18
17.3
3.1
20.6
3.8
23.9
4.5
25.7
4.9
27.4
5.2
30.7
6
33.5
6.8
20
17.3
3.2
20.6
3.9
23.9
4.6
25.7
5
27.4
5.4
30.7
6.4
33
7.1
21
17.3
3.2
20.6
3.9
23.9
4.7
25.7
5.1
27.4
5.6
30.7
6.7
32.8
7.3
23
17.3
3.3
20.6
4.1
23.9
5
25.7
5.5
27.4
6
30.7
7.1
32.3
7.6
25
17.3
3.5
20.6
4.4
23.9
5.3
25.7
5.9
27.4
6.4
30.7
7.6
31.8
8
27
17.3
3.7
20.6
4.7
23.9
5.7
25.7
6.3
27.4
6.9
30.7
8.2
31.4
8.3
29
17.3
3.9
20.6
5
23.9
6.1
25.7
6.7
27.4
7.4
30.3
8.6
30.9
8.6
31
17.3
4.2
20.6
5.3
23.9
6.5
25.7
7.2
27.4
7.8
29.8
8.9
30.4
9
33
17.3
4.4
20.6
5.6
23.9
6.9
25.7
7.6
27.4
8.4
29.4
9.2
30
9.3
35
17.3
4.7
20.6
6
23.9
7.4
25.7
8.1
27.4
8.9
28.9
9.6
29.5
9.6
37
17.3
5
20.6
6.3
23.9
7.8
25.7
8.7
27.4
9.5
28.5
9.9
29
10
39
17.3
5.3
20.6
6.7
23.9
8.4
25.7
9.2
27.4
10.1
28
10.2
28.6
10.3
42
17.3
5.6
20.6
7.1
23.9
8.8
25.7
9.8
27.4
10.7
27.6
10.6
28.2
10.7
44
17.3
5.9
20.6
7.5
23.9
9.3
25.7
10.3
27.4
11.3
27.1
10.9
27.7
11
46
17.3
6.2
20.6
7.9
23.9
9.8
25.7
10.9
27.4
11.9
26.7
11.3
27.3
11.4
10
15.4
2.6
18.3
3.1
21.4
3.7
22.8
3.9
24.3
4.2
27.2
4.8
30.2
5.5
12
15.4
2.7
18.3
3.2
21.4
3.7
22.8
4
24.3
4.3
27.2
4.9
30.2
5.5
14
15.4
2.7
18.3
3.2
21.4
3.8
22.8
4.1
24.3
4.4
27.2
5
30.2
5.7
16
15.4
2.7
18.3
3.3
21.4
3.9
22.8
4.2
24.3
4.5
27.2
5.1
30.2
5.8
18
15.4
2.8
18.3
3.3
21.4
3.9
22.8
4.3
24.3
4.6
27.2
5.2
30.2
5.9
20
15.4
2.8
18.3
3.4
21.4
4
22.8
4.3
24.3
4.7
27.2
5.4
30.2
6.3
21
15.4
2.9
18.3
3.5
21.4
4.1
22.8
4.4
24.3
4.8
27.2
5.6
30.2
6.5
23
15.4
2.9
18.3
3.5
21.4
4.3
22.8
4.7
24.3
5.1
27.2
6
30.2
7
25
15.4
3
18.3
3.7
21.4
4.5
22.8
5
24.3
5.5
27.2
6.4
30.2
7.5
27
15.4
3.2
18.3
4
21.4
4.9
22.8
5.3
24.3
5.8
27.2
6.9
30.2
8
29
15.4
3.4
18.3
4.2
21.4
5.2
22.8
5.7
24.3
6.2
27.2
7.3
30.2
8.6
31
15.4
3.6
18.3
4.5
21.4
5.5
22.8
6
24.3
6.6
27.2
7.8
30.2
8.9
33
15.4
3.8
18.3
4.8
21.4
5.9
22.8
6.4
24.3
7
27.2
8.3
30.2
9.2
35
15.4
4.1
18.3
5.1
21.4
6.2
22.8
6.8
24.3
7.5
27.2
8.9
30.2
9.6
37
15.4
4.3
18.3
5.4
21.4
6.6
22.8
7.3
24.3
8
27.2
9.5
30.2
9.9
39
15.4
4.6
18.3
5.7
21.4
7
22.8
7.8
24.3
8.5
27.2
10.1
30.2
10.2
42
15.4
4.8
18.3
6.1
21.4
7.5
22.8
8.2
24.3
9
27.2
10.7
30.2
10.6
44
15.4
5
18.3
6.4
21.4
7.9
22.8
8.7
24.3
9.5
27.2
11.3
30.2
10.9
46
15.4
5.3
18.3
6.8
21.4
8.3
22.8
91
24.3
10
27.2
11.9
30.2
11.2
19
Cooling Performance - COOLING PERFORMANCE DATA – 100
Capacity
factor(%)
70%
60%
50%
20
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
22
24
TC
kW
PI
kW
TC
kW
PI
kW
10
13.5
2.3
16
2.7
18.7
3.2
20
3.4
21.2
3.7
23.8
4.2
26.5
4.7
12
13.5
2.3
16
2.8
18.7
3.2
20
3.5
21.2
3.7
23.8
4.2
26.5
4.8
14
13.5
2.4
16
2.8
18.7
3.3
20
3.5
21.2
3.8
23.8
4.3
26.5
4.9
16
13.5
2.4
16
2.9
18.7
3.3
20
3.6
21.2
3.9
23.8
4.4
26.5
4.9
18
13.5
2.4
16
2.9
18.7
3.4
20
3.7
21.2
3.9
23.8
4.5
26.5
5
20
13.5
2.5
16
3
18.7
3.5
20
3.7
21.2
4
23.8
4.6
26.5
5.2
21
13.5
2.5
16
3
18.7
3.5
20
3.8
21.2
4.1
23.8
4.6
26.5
5.4
23
13.5
2.5
16
3.14
18.7
3.6
20
3.9
21.2
4.2
23.8
5
26.5
5.9
25
13.5
2.6
16
3.2
18.7
3.8
20
4.2
21.2
4.5
23.8
5.3
26.5
6.1
27
13.5
2.7
16
3.4
18.7
4.1
20
4.4
21.2
4.8
23.8
57
26.5
6.6
29
13.5
2.9
16
3.6
18.7
4.3
20
4.7
21.2
5.1
23.8
6
26.5
7
31
13.5
3.1
16
3.8
18.7
4.6
20
5
21.2
5.5
23.8
6.4
26.5
7.5
33
13.5
3.3
16
4
18.7
4.9
20
5.4
21.2
5.8
23.8
6.9
26.5
8
35
13.5
3.5
16
4.3
18.7
5.2
20
5.7
21.2
6.2
23.8
7.3
26.5
8.5
37
13.5
3.7
16
4.5
18.7
5.5
20
6
21.2
6.6
23.8
7.8
26.5
9.1
39
13.5
3.9
16
4.8
18.7
5.9
20
6.4
21.2
7
23.8
8.3
26.5
9.6
42
13.5
4.1
16
5.1
18.7
6.2
20
6.8
21.2
7.4
23.8
8.8
26.5
10
44
13.5
4.3
16
5.3
18.7
6.5
20
7.2
21.2
7.8
23.8
9.3
26.5
11
46
13.5
4.5
16
5.6
18.7
6.9
20
7.5
21.2
8.2
23.8
9.8
26.5
11
10
11.6
2
13.7
2.3
16
2.7
17
2.9
18.2
6.1
20.5
3.5
22.6
3.9
12
11.6
2
13.7
2.4
16
2.7
17
2.9
18.2
3.1
20.5
3.6
22.6
4
14
11.6
2.1
13.7
2.4
16
2.8
17
3
18.2
3.2
20.5
3.6
22.6
4.1
16
11.6
2.1
13.7
2.5
16
2.9
17
3.1
18.2
3.3
20.5
3.7
22.6
4.1
18
11.6
2.1
13.7
2.5
16
2.9
17
3.1
18.2
3.3
20.5
3.8
22.6
4.2
20
11.6
2.1
13.7
2.5
16
2.9
17
3.2
18.2
3.4
20.5
3.8
22.6
4.3
21
11.6
2.2
13.7
2.6
16
3
17
3.2
18.2
3.4
20.5
3.9
22.6
4.4
23
11.6
2.2
13.7
2.6
16
3
17
3.3
18.2
3.5
20.5
4
22.6
4.6
25
11.6
2.2
13.7
2.7
16
3.1
17
3.4
18.2
3.7
20.5
4.3
22.6
4.9
27
11.6
2.3
13.7
2.8
16
3.3
17
3.6
18.2
3.9
20.5
4.6
22.6
5.3
29
11.6
2.5
13.7
3
16
3.6
17
3.9
18.2
4.2
20.5
4.9
22.6
5.6
31
11.6
2.6
13.7
3.2
16
3.8
17
4.1
18.2
4.5
20.5
5.2
22.6
6
33
11.6
2.7
13.7
3.4
16
4
17
4.4
18.2
4.7
20.5
5.5
22.6
6.4
35
11.6
2.9
13.7
3.5
16
4.3
17
4.6
18.2
5
20.5
5.9
22.6
6.8
37
11.6
3.1
13.7
3.8
16
4.5
17
4.9
18.2
5.3
20.5
6.2
22.6
7.2
39
11.6
3.3
13.7
4
16
4.8
17
5.2
18.2
5.7
20.5
6.6
22.6
7.7
42
11.6
3.4
13.7
4.2
16
5.1
17
5.5
18.2
6
20.5
7
22.6
8.1
44
11.6
3.6
13.7
4.4
16
5.3
17
5.8
18.2
6.3
20.5
7.4
22.6
8.6
46
11.6
3.8
13.7
4.6
16
5.6
17
6.1
18.2
6.7
20.5
7.8
22.6
9
10
9.6
1.7
11.5
2
13.4
2.3
14.3
2.4
15.1
2.6
17
2.9
18.8
3.2
12
9.6
1.7
11.5
2
13.4
2.3
14.3
2.5
15.1
2.6
17
2.9
18.8
3.3
14
9.6
1.8
11.5
2
13.4
2.3
14.3
2.5
15.1
2.7
17
3
18.8
3.3
16
9.6
1.8
11.5
2.1
13.4
2.4
14.3
2
15.1
2.7
17
3
18.8
3.4
18
9.6
1.8
11.5
2.1
13.4
2.4
14.3
2.6
15.1
2.7
17
3.1
18.8
3.5
20
9.6
1.8
11.5
2.1
13.4
2.5
14.3
2.6
15.1
2.8
17
3.1
18.8
3.5
21
9.6
1.9
11.5
2.2
13.4
2.5
14.3
2.7
15.1
2.8
17
3.2
18.8
3.6
23
9.6
1.9
11.5
2.2
13.4
2.5
14.3
2.7
15.1
2.9
17
3.2
18.8
3.6
25
9.6
1.9
11.5
2.2
13.4
2.6
14.3
2.7
15.1
3
17
3.4
18.8
39
27
9.6
1.9
11.5
2.36
13.4
2.7
14.3
2.9
15.1
3.1
17
3.6
18.8
4.1
29
9.6
2.1
11.5
2.4
13.4
2.9
14.3
3.1
15.1
3.3
17
3.9
18.8
4.4
31
9.6
2.2
11.5
2.6
13.4
3.1
14.3
3.3
15.1
3.5
17
7.1
18.8
4.7
33
9.6
2.3
11.5
2.7
13.4
3.2
14.3
3.5
15.1
3.8
17
4.3
18.8
5
35
9.6
2.4
11.5
2.9
13.4
3.4
14.3
3.7
15.1
4
17
4.6
18.8
5.3
37
9.6
2.5
11.5
3.1
13.4
3.6
14.3
3.9
15.1
4.2
17
4.9
18.8
5.6
39
9.6
2.7
11.5
3.2
13.4
3.8
14.3
4.1
15.1
4.5
17
4.7
18.8
6
42
9.6
2.8
11.5
3.4
13.4
4
14.3
4.4
15.1
4.7
17
4.9
18.8
6.3
44
9.6
2.9
11.5
3.6
13.4
4.2
14.3
4.6
15.1
5
17
4.9
18.8
6.6
46
9.6
3
11.5
3.7
13.4
4.5
14.3
4.8
15.1
5.4
17
5
18.8
7
Cooling Performance - COOLING PERFORMANCE DATA – 120
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
21.6
3.5
25.7
4.2
29.9
5
32
5.4
34.1
5.8
38.3
6.6
40.4
6.9
12
21.6
3.5
25.7
4.3
29.9
5.1
32
5.5
34.1
5.9
38.3
6.8
40.4
6.8
14
21.6
3.6
25.7
4.4
29.9
5.2
32
5.6
34.1
6
38.3
6.9
39.4
6.8
16
21.6
3.7
25.7
4.5
29.9
5.3
32
5.7
34.1
6.1
38.1
7
38.9
6.9
18
21.6
3.7
25.7
4.5
29.9
5.4
32
5.8
34.1
6.3
37.6
7.2
38.4
7.3
20
21.6
3.8
25.7
4.6
29.9
5.6
32
6.1
34.1
6.7
37.1
7.6
379
7.6
21
21.6
3.9
25.7
4.7
29.9
5.8
32
6.3
34.1
7
36.9
7.7
37.6
7.8
23
21.6
4
25.7
5
29.9
6.2
32
6.8
34.1
7.5
36.3
8.1
31
8.2
25
21.6
4.2
25.7
5.3
29.9
6.6
32
7.3
34.1
8
.5.3
8.4
36.6
8.5
27
21.6
4.5
25.7
5.7
29.9
7.1
32
7.8
34.1
8.6
34.7
8.8
36
8.9
29
21.6
4.8
25.7
6.1
29.9
7.5
32
8.3
34
9.1
34.1
9.2
35.6
9.2
31
21.6
5.1
25.7
6.5
29.9
8
32
8.9
33.4
9.4
33.7
9.5
35
9.6
33
21.6
5.4
25.7
6.9
29.9
8.6
32
9.5
32.9
9.8
33.1
9.9
34.4
10
35
21.6
5.7
25.7
7.3
29.9
9.1
32
10.1
32.4
10.1
34.1
10.2
34
10.3
37
21.6
6.1
25.7
7.8
29.9
9.7
31.4
10.4
31.9
10.5
32.7
10.6
33.4
10.7
39
21.6
6.5
25.7
8.3
29.9
10.4
31
10.8
31.3
10.9
32.1
11
32.9
11.1
42
21.6
6.9
25.7
8.8
29.9
11
30.5
11.2
30.7
11.2
31
11.3
32.3
11.4
44
21.6
7.2
25.7
9.3
29.9
11.6
30
11.5
30.1
11.6
30
11.7
31.7
11.8
46
21.6
7.6
25.7
9.7
29.9
12.2
29.5
11.9
29.6
12
29
12.1
31.5
12.2
10
19.4
3.1
23.1
3.8
26.9
4.4
28.9
4.8
30.7
5.1
34.4
5.9
38.1
6.6
12
19.4
3.2
23.1
3.8
26.9
4.5
28.9
4.9
30.7
5.2
34.4
6
38.1
6.7
14
19.4
3.2
23.1
3.9
26.9
4.6
28.9
5
30.7
5.3
34.4
6.1
38.1
6.9
16
19.4
3.3
23.1
4
26.9
4.7
28.9
5.1
30.7
5.4
34.4
6.2
38.1
7
18
19.4
3.3
23.1
4
26.9
4.8
28.9
5.2
30.7
5.6
34.4
6.3
37.6
7.2
20
19.4
3.4
23.1
4.1
26.9
4.9
28.9
5.3
30.7
5.8
34.4
6.8
37
7.6
21
19.4
3.4
23.1
4.2
26.9
5
28.9
5.5
30.7
6
34.4
7.1
36.9
7.7
23
19.4
3.5
23.1
4.3
26.9
5.3
28.9
5.8
30.7
6.4
34.4
7.6
36.3
8.1
25
19.4
3.7
23.1
4.6
26.9
5.7
28.9
6.2
30.7
6.8
34.4
8.1
35.7
8.4
27
19.4
3.9
23.1
4.9
26.9
6.1
28.9
6.7
30.7
7.3
34.4
8.7
35.3
8.8
29
19.4
4.2
23.1
5.3
26.9
6.5
28.9
7.1
30.7
7.8
34
9.1
34.7
9.2
31
19.4
4.4
23.1
5.6
26.9
6.9
28.9
7.6
30.7
8.3
33.4
9.4
34.1
9.5
33
19.4
4.7
23.1
6
26.9
7.3
28.9
8..1
30.7
8.9
33
9.8
33.7
9.9
35
19.4
5
23.1
6.3
26.9
7.8
28.9
8.6
30.7
9.5
32.4
10.2
33.1
10.2
37
19.4
5.3
23.1
6.7
26.9
8.3
28.9
9.2
30.7
10.1
32
10.5
32.6
10.6
39
19.4
5.6
23.1
7.2
26.9
8.9
28.9
9.8
30.7
10.8
31.4
10.9
32.1
11
42
19.4
5.9
23.1
7.6
26.9
9.4
28.9
10.4
30.7
11.4
31
11.2
31.6
11.3
44
19.4
6.2
23.1
8
26.9
9.9
28.9
10.9
30.7
12
30.5
11.6
31.1
11.7
46
19.4
6.6
23.1
8.4
26.9
10.4
28.9
11.5
30.7
12.7
30
11.9
30.6
12.1
10
17.3
2.8
20.6
3.3
24
3.9
25.6
4.2
27.3
4.5
30.6
5.1
33.9
5.8
12
17.3
2.8
20.6
3.4
24
4
25.6
4.3
27.3
4.6
30.6
5.2
33.9
5.9
14
17.3
2.9
20.6
3.4
24
4
25.6
4.4
27.3
4.7
30.6
5.3
33.9
6
16
17.3
2.9
20.6
3.5
24
4.1
25.6
4.4
27.3
4.8
30.6
5.4
33.9
6.1
18
17.3
2.9
20.6
3.5
24
4.2
25.6
4.5
27.3
4.9
30.6
5.5
33.9
6.2
20
17.3
3
20.6
3.6
24
4.3
25.6
4.6
27.3
5
30.6
5.7
33.9
6.7
21
17.3
3
20.6
3.7
24
4.3
25.6
4.6
27.3
5.1
30.6
5.9
33.9
6.9
23
17.3
3.1
20.6
3.7
24
4.5
25.6
5
27.3
5.4
30.6
6.4
33.9
7.4
25
17.3
3.2
20.6
4
24
4.8
25.6
5.3
27.3
5.8
30.6
6.8
33.9
7.9
27
17.3
3.4
20.6
4.2
24
5.1
25.6
5.6
27.3
6.2
30.6
7.3
33.9
8.5
29
17.3
3.6
20.6
4.5
24
5.5
25.6
6
27.3
6.6
30.6
7.8
33.9
9.1
31
17.3
3.8
20.6
4.8
24
5.8
25.6
6.4
27.3
7
30.6
8.3
33.9
9.4
33
17.3
4.1
20.6
5.1
24
6.2
25.6
6.8
27.3
7.5
30.6
8.8
33.9
9.8
35
17.3
4.3
20.6
5.4
24
6.6
25.6
7.3
27.3
8
30.6
9.4
33.9
10.1
37
17.3
4.6
20.6
5.7
24
7
25.6
7.7
27.3
8.5
30.6
10.1
33.9
10.5
39
17.3
4.8
20.6
6.1
24
7.5
25.6
8.2
27.3
9
30.6
10.7
33.9
10.9
42
17.3
5.1
20.6
6.4
24
7.9
25.6
8.7
27.3
9.5
30.6
11.3
33.9
11.2
44
17.3
5.4
20.6
6.8
24
8.3
25.6
9.2
27.3
10.1
30.6
12
33.9
11.6
46
17.3
5.6
20.6
7.2
24
8.8
25.6
9.7
27.3
10.6
30.6
12.6
33.9
11.9
21
Cooling Performance - COOLING PERFORMANCE DATA – 120
Capacity
factor(%)
70%
60%
50%
22
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
15.1
2.4
18
2.9
21
3.4
22.4
3.6
23.9
3.9
26.7
4.4
29.7
5
12
15.1
2.5
18
2.9
21
3.4
22.4
3.7
23.9
4
26.7
4.5
29.7
5.1
14
15.1
2.5
18
3
21
3.5
22.4
3.8
23.9
4
26.7
4.6
29.7
5.1
16
15.1
2.5
18
3
21
3.5
22.4
3.8
23.9
4.1
26.7
4.7
29.7
5.2
18
15.1
2.6
18
3.1
21
3.6
22.4
3.9
23.9
4.2
26.7
4.7
29.7
5.3
20
15.1
2.6
18
3.1
21
3.7
22.4
4
23.9
4.3
26.7
4.8
29.7
5.5
21
15.1
2.7
18
3.2
21
3.7
22.4
4
23.9
4.3
26.7
4.9
29.7
5.7
23
15.1
2.7
18
3.2
21
3.8
22.4
4.1
23.9
4.5
26.7
5.3
29.7
6.3
25
15.1
2.8
18
3.4
21
4
22.4
4.4
23.9
4.8
26.7
5.6
29.7
6.5
27
15.1
2.9
18
3.6
21
4.3
22.4
4.7
23.9
5.1
26.7
6
29.7
7
29
15.1
3.1
18
3.8
21
4.6
22.4
5
23.9
5.5
26.7
6.4
29.7
7.4
31
15.1
3.3
18
4
21
4.9
22.4
5.3
23.9
5.8
26.7
6.8
29.7
7.9
33
15.1
3.5
18
4.3
21
5.2
22.4
5.7
23.9
6.2
26.7
7.3
29.7
8.5
35
15.1
3.7
18
4.5
21
5.5
22.4
6
23.9
6.6
26.7
7.7
29.7
9
37
15.1
3.9
18
4.8
21
5.9
22.4
6.4
23.9
7
26.7
8.2
29.7
9.6
39
15.1
4.1
18
5.1
21
6.2
22.4
6.8
23.9
7.4
26.7
8.8
29.7
10.2
42
15.1
4.3
18
5.4
21
6.6
22.4
7.2
23.9
7.9
26.7
9.3
29.7
10.8
44
15.1
4.6
18
5.7
21
6.9
22.4
7.6
23.9
8.3
26.7
9.8
29.7
11.4
46
15.1
4.8
18
5.9
21
7.3
22.4
8
23.9
8.7
26.7
10.3
29.7
12.1
10
13
2.1
15.4
2.5
18
2.9
19.1
3.1
20.4
3.3
23
3.7
25.4
4.2
12
13
2.1
15.4
2.5
18
2.9
19.1
3.1
20.4
3.3
23
3.8
25.4
4.2
14
13
2.2
15.4
2.6
18
3
19.1
3.2
20.4
3.4
23
3.9
25.4
4.3
16
13
2.2
15.4
2.6
18
3
19.1
3.2
20.4
3.5
23
3.9
25.4
4.4
18
13
2.2
15.4
2.6
18
3.1
19.1
3.3
20.4
3.5
23
4
25.4
4.5
20
13
2.3
15.4
2.7
18
3.1
19.1
3.4
20.4
3.6
23
4.1
25.4
4.6
21
13
2.3
15.4
2.7
18
3.2
19.1
3.4
20.4
3.6
23
4.1
25.4
4.6
23
13
2.3
15.4
2.8
18
3.2
19.1
3.5
20.4
3.7
23
4.3
25.4
4.9
25
13
2.4
15.4
2.8
18
3.3
19.1
3.6
20.4
3.9
23
4.6
25.4
5.2
27
13
2.5
15.4
3
18
3.5
19.1
3.9
20.4
4.2
23
4.9
25.4
5.6
29
13
2.6
15.4
3.2
18
3.8
19.1
4.1
20.4
4.5
23
5.2
25.4
6
31
13
2.8
15.4
3.4
18
4
19.1
4.4
20.4
4.7
23
5.5
25.4
6.4
33
13
2.9
15.4
3.6
18
4.3
19.1
4.6
20.4
5
23
2.9
25.4
6.8
35
13
3.1
15.4
3.8
18
4.5
19.1
4.9
20.4
5.3
23
6.2
25.4
7.2
37
13
3.3
15.4
4
18
4.8
19.1
5.2
20.4
5.7
23
6.6
25.4
7.7
39
13
3.5
15.4
4.2
18
5..1
19.1
5.6
20.4
6
23
7.1
25.4
8.2
42
13
3.6
15.4
4.5
18
5.4
19.1
5.9
20.4
6.4
23
7.5
25.4
8.6
44
13
3.8
15.4
4.7
18
5.6
19.1
6.2
20.4
6.7
23
7.9
25.4
9.1
46
13
4
15.4
4.9
18
5.9
19.1
6.5
20.4
7.1
23
8.3
25.4
9.6
10
10.8
1.8
12.9
2.1
15
2.4
16
2.6
17
2.7
19.1
3.1
21.1
3.4
12
10.8
1.9
12.9
2.1
15
2.4
16
2.6
17
2.8
19.1
3.1
21.1
3.5
14
10.8
1.9
12.9
2.2
15
2.5
16
2.6
17
2.8
19.1
3.2
21.1
3.5
16
10.8
1.9
12.9
2.2
15
2.5
16
2.7
17
2.9
19.1
3.2
21.1
3.6
18
10.8
1.9
12.9
2.2
15
2.6
16
2.7
17
2.9
19.1
3.3
21.1
3.7
20
10.8
1.9
12.9
2.3
15
2.6
16
2.8
17
3
19.1
3.3
21.1
3.7
21
10.8
2
12.9
2.3
15
2.6
16
2.8
17
3
19.1
3.4
21.1
3.8
23
10.8
2
12.9
2.3
15
2.7
16
2.9
17
3
19.1
3.4
21.1
3.9
25
10.8
2
12.9
2.4
15
2.7
16
2.9
17
3.1
19.1
3.6
21.1
4.1
27
10.8
2
12.9
2.4
15
2.9
16
3.1
17
3.3
19.1
3.8
21.1
4.4
29
10.8
2.2
12.9
2.6
15
3
16
3.3
17
3.5
19.1
4.1
21.1
4.7
31
10.8
2.3
12.9
2.7
15
3.2
16
3.5
17
3.8
19.1
4.3
21.1
5
33
10.8
2.4
12.9
2.9
15
3.4
16
3.7
17
4
19.1
4.6
21.1
5.3
35
10.8
2.6
12.9
3.1
15
3.6
16
3.9
17
4.2
19.1
4.9
21.1
5.6
37
10.8
2.7
12.9
3.2
15
3.8
16
4.2
17
4.5
19.1
5.2
21.1
6
39
10.8
2.8
12.9
3.4
15
4.1
16
4.4
17
4.8
19.1
5
21.1
6.3
42
10.8
3
12.9
3.6
15
4.3
16
4.6
17
5
19.1
5.2
21.1
6.7
44
10.8
3.1
12.9
3.8
15
4.5
16
4.9
17
5.4
19.1
5.2
21.1
7
46
10.8
3.2
12.9
4
15
4.7
16
5.1
17
5.7
19.1
5.3
21.1
7.4
Cooling Performance - COOLING PERFORMANCE DATA – 140
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
22
24
TC
kW
PI
kW
TC
kW
PI
kW
10
27.6
4.4
32.9
5.3
38.3
6.3
41
6.8
43.7
7.3
49.1
8.3
51.8
8.6
12
27.6
4.4
32.9
5.4
38.3
6.4
41
6.9
43.7
7.4
49.1
8.5
51.8
8.6
14
27.6
4.5
32.9
5.5
38.3
6.5
41
7
43.7
7.6
49.1
8.6
50.5
8.5
16
27.6
4.6
32.9
5.6
38.3
6.6
41
7.2
43.7
7.7
48.9
8.7
49.8
8.7
18
27.6
4.7
32.9
5.7
38.3
6.8
41
7.3
43.7
7.9
48.1
9
49.2
9.1
20
27.6
4.8
32.9
5.8
38.3
7
41
7.7
43.7
8.4
47.6
9.5
48.5
9.5
21
27.6
4.8
32.9
5.9
38.3
7.2
41
7.9
43.7
8.7
47.2
9.7
48.1
9.8
23
27.6
5
32.9
6.3
38.3
7.7
41
8.5
43.7
9.4
46.5
10.1
47.4
110.2
25
27.6
5.3
32.9
6.7
38.3
8.3
41
9.1
43.7
10
45.2
10.6
46.9
10.7
27
27.6
5.6
32.9
7.1
38.3
8.8
41
9.8
43.7
10.7
44.5
11
46.1
11.1
29
27.6
6
32.9
7.6
38.3
9.4
41
10.4
43.6
11.4
43.7
11.5
45.6
11.6
31
27.6
6.4
32.9
8.1
38.3
10.1
41
11.1
42.8
11.8
43.2
11.9
44.8
12
33
27.6
6.8
32.9
8.6
38.3
10.7
41
11.9
42.1
12.3
42.5
12.4
44.1
12.5
35
27.6
7.2
32.9
9.2
38.3
11.5
41
12.7
41.5
12.7
43.7
12.8
43.6
12.9
37
27.6
7.7
32.9
9.8
38.3
12.2
40.3
13.1
40.8
13.2
41.9
13.3
42.8
13.4
39
27.6
8.1
32.9
10.4
38.3
13
39.7
13.6
40.1
13.6
41.2
13.7
42.1
13.9
42
27.6
8.6
32.9
11
38.3
13.8
39
14
39.4
14.1
39.7
14.2
41.4
14.3
44
27.6
9.1
32.9
11.6
38.3
14.5
38.4
14.4
38.6
14.5
38.4
14.7
40.6
14.8
46
27.6
9.6
32.9
12.1
38.3
15.3
37.8
14.9
37.9
15
37.2
15.1
40.3
15.2
10
24.9
3.9
29.7
4.7
34.4
5.6
37
6
39.4
6.5
44.1
7.4
48.9
8.3
12
24.9
4
29.7
4.8
34.4
5.7
37
6.1
39.4
6.6
44.1
7.5
48.9
8.5
14
24.9
4
29.7
4.9
34.4
5.8
37
6.2
39.4
6.7
44.1
7.7
48.9
8.6
16
24.9
4.1
29.7
5
34.4
5.9
37
6.4
39.4
6.8
44.1
7.8
48.9
8.8
18
24.9
4.2
29.7
5.1
34.4
6
37
6.5
39.4
7
44.1
7.9
48.1
9
20
24.9
4.3
29.7
5.2
34.4
6.1
37
6.6
39.4
7.2
44.1
8.6
47.4
9.5
21
24.9
4.3
29.7
5.2
34.4
6.2
37
6.8
39.4
7.5
44.1
8.9
47.2
9.7
23
24.9
4.4
29.7
5.4
34.4
6.6
37
7.3
39.4
8
44.1
9.5
46.5
10.1
25
24.9
4.6
29.7
5.8
34.4
7.1
37
7.8
39.4
8.6
44.1
10.2
45.8
10.6
27
24.9
4.9
29.7
6.2
34.4
7.6
37
8.4
39.4
9.2
44.1
10.9
45.2
11
29
24.9
5.2
29.7
6.6
34.4
8.1
37
8.9
39.4
9.8
43.6
11.4
44.5
11.5
31
24.9
5.6
29.7
7
34.4
8.6
37
9.5
39.4
10.4
42.8
11.8
43.7
11.9
33
24.9
5.9
29.7
7.5
34.4
9.2
37
10.1
39.4
11.1
42.3
12.3
43.2
12.4
35
24.9
6.3
29.7
7.9
34.4
9.8
37
10.8
39.4
11.9
41.5
12.7
42.5
12.8
37
24.9
6.6
29.7
8.4
34.4
10.4
37
11.5
39.4
12.7
41
13.2
41.7
13.3
39
24.9
7.1
29.7
9
34.4
11.1
37
12.3
39.4
13.5
40.3
13.6
41.2
13.7
42
24.9
7.4
29.7
9.5
34.4
11.8
37
13
39.4
14.3
39.7
14.1
40.5
14.2
44
24.9
7.8
29.7
10
34.4
12.4
37
13.7
39.4
15.1
39
14.5
39.9
14.7
46
24.9
8.2
29.7
10.5
34.4
13.1
37
14.4
39.4
15.9
38.4
15
39.2
15.1
10
22.1
3.5
26.4
4.2
30.8
4.9
32.8
5.2
35
5.6
39.2
6.4
43.4
7.2
12
22.1
3.5
26.4
4.2
30.8
5
32.8
5.3
35
5.8
39.2
6.5
43.4
7.4
14
22.1
3.6
26.4
4.3
30.8
5
32.8
5.5
35
5.8
39.2
6.7
43.4
7.5
16
22.1
3.6
26.4
4.4
30.8
5.1
32.8
5.6
35
6
39.2
6.8
43.4
7.7
18
22.1
3.7
26.4
4.4
30.8
5.2
32.8
5.7
35
6.1
39.2
6.9
43.4
7.8
20
22.1
3.8
26.4
4.5
30.8
5.3
32.8
5.8
35
6.2
39.2
7.2
43.4
8.4
21
22.1
3.8
26.4
4.6
30.8
5.4
32.8
5.8
35
6.3
39.2
7.4
43.4
8.7
23
22.1
3.9
26.4
4.7
30.8
5.7
32.8
6.2
35
6.8
39.2
8
43.4
9.3
25
22.1
4
26.4
5
30.8
6
32.8
6.6
35
7.2
39.2
8.5
43.4
10
27
22.1
4.3
26.4
5.3
30.8
6.5
32.8
7.1
35
7.7
39.2
9.1
43.4
10.7
29
22.1
4.5
26.4
5.6
30.8
6.9
32.8
7.5
35
8.2
39.2
9.8
43.4
11.4
31
22.1
4.8
26.4
6
30.8
7.3
32.8
8
35
8.8
39.2
10.4
43.4
11.8
33
22.1
5.1
26.4
6.4
30.8
7.8
32.8
8.6
35
9.4
39.2
11.1
43.4
12.3
35
22.1
5.4
26.4
6.8
30.8
8.3
32.8
9.1
35
10
39.2
11.8
43.4
12.7
37
22.1
5.7
26.4
7.2
30.8
8.8
32.8
9.7
35
10.6
39.2
12.6
43.4
13.2
39
22.1
6.1
26.4
7.6
30.8
9.4
32.8
10.3
35
11.3
39.2
13.4
43.4
13.6
42
22.1
6.4
26.4
8.1
30.8
9.9
32.8
10.9
35
12
39.2
14.2
43.4
14.1
44
22.1
6.7
26.4
8.5
30.8
10.5
32.8
11.5
35
12.6
39.2
15
43.4
14.5
46
22.1
7
26.4
9
30.8
11
32.8
12.1
35
13.3
39.2
15.8
43.4
14.9
23
Cooling Performance - COOLING PERFORMANCE DATA – 140
Capacity
factor(%)
70%
60%
50%
24
Outdoor ambient
temperature (DB°C)
14
TC
kW
16
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
PI
kW
TC
kW
PI
kW
10
19.4
3
23.1
3.6
27
4.2
28.7
4.5
30.6
4.9
34.2
5.5
38.1
6.2
12
19.4
3.1
23.1
3.7
27
4.3
28.7
4.6
30.6
5
34.2
5.6
38.1
6.3
14
19.4
3.1
23.1
3.7
27
4.4
28.7
4.7
30.6
5
34.2
5.7
38.1
6.5
16
19.4
3.2
23.1
3.8
27
4.4
28.7
4.8
30.6
5.1
34.2
5.8
38.1
6.6
18
19.4
3.2
23.1
3.9
27
4.5
28.7
4.9
30.6
5.2
34.2
5.9
38.1
6.7
20
19.4
3.3
23.1
3.9
27
4.6
28.7
5
30.6
5.3
34.2
6.1
38.1
6.9
21
19.4
3.3
23.1
4
27
4.7
28.7
5
30.6
5.4
34.2
6.2
38.1
7.1
23
19.4
3.4
23.1
4.1
27
4.8
28.7
5.2
30.6
5.6
34.2
6.6
38.1
7.9
25
19.4
3.5
23.1
4.2
27
5.1
28.7
5.5
30.6
6
34.2
7.1
38.1
8.2
27
19.4
3.6
23.1
4.5
27
5.4
28.7
5.9
30.6
6.4
34.2
7.5
38.1
8.7
29
19.4
3.9
23.1
4.8
27
5.8
28.7
6.3
30.6
6.8
34.2
8
38.1
9.3
31
19.4
4.1
23.1
5
27
6.1
28.7
6.7
30.6
7.3
34.2
8.6
38.1
10
33
19.4
4.3
23.1
5.4
27
6.5
28.7
7.1
30.6
7.8
34.2
9.1
38.1
10.6
35
19.4
4.6
23.1
5.7
27
6.9
28.7
7.6
30.6
8.3
34.2
9.7
38.1
11.3
37
19.4
4.9
23.1
6
27
7.3
28.7
8
30.6
8.8
34.2
10.3
38.1
12.1
39
19.4
5.1
23.1
6.4
27
7.8
28.7
8.6
30.6
9.3
34.2
11
38.1
12.8
42
19.4
5.4
23.1
6.7
27
8.2
28.7
9
30.6
9.8
34.2
11.7
38.1
13.6
44
19.4
5.7
23.1
7.1
27
8.7
28.7
9.5
30.6
10
34.2
12.3
38.1
14.3
46
19.4
6
23.1
7.5
27
9.1
28.7
10
30.6
11
34.2
13
38.1
15.1
10
16.7
2.7
19.8
3.1
23
3.6
24.5
3.9
26.2
4.1
29.5
4.7
32.6
5.2
12
16.7
2.7
19.8
3.2
23
3.6
24.5
3.9
26.2
4.2
29.5
4.7
32.6
5.3
14
16.7
2.7
19.8
3.2
23
3.7
24.5
4
26.2
4.3
29.5
4.8
32.6
5.4
16
16.7
2.8
19.8
3.3
23
3.8
24.5
4.1
26.2
4.3
29.5
4.9
32.6
5.5
18
16.7
2.8
19.8
3.3
23
3.8
24.5
4.1
26.2
4.4
29.5
5
32.6
5.6
20
16.7
2.9
19.8
3.4
23
3.9
24.5
4.2
26.2
4.5
29.5
5.1
32.6
5.7
21
16.7
2.9
19.8
3.4
23
4
24.5
4.3
26.2
4.5
29.5
5.1
32.6
5.8
23
16.7
2.9
19.8
3.5
23
4
24.5
4.3
26.2
4.6
29.5
5.4
32.6
6.2
25
16.7
3
19.8
3.5
23
4.2
24.5
4.5
26.2
4.9
29.5
5.7
32.6
6.6
27
16.7
3.1
19.8
3.7
23
4.4
24.5
4.8
26.2
5.2
29.5
6.1
32.6
7
29
16.7
3.3
19.8
4
23
4.7
24.5
5.1
26.2
5.6
29.5
6.5
32.6
7.5
31
16.7
3.5
19.8
4.2
23
5
24.5
5.5
26.2
5.9
29.5
6.9
32.6
8
33
16.7
3.6
19.8
4.5
23
5.3
24.5
5.8
26.2
6.3
29.5
7.4
32.6
8.5
35
16.7
3.9
19.8
4.7
23
5.7
24.5
6.2
26.2
6.7
29.5
7.8
32.6
9
37
16.7
4.1
19.8
5
23
6
24.5
6.5
26.2
7.1
29.5
8.3
32.6
9.6
39
16.7
4.3
19.8
5.3
23
6.4
24.5
7
26.2
7.6
29.5
8.8
32.6
10.2
42
16.7
4.6
19.8
5.6
23
6.7
24.5
7.4
26.2
8
29.5
9.3
32.6
10.8
44
16.7
4.8
19.8
5.9
23
7.1
24.5
7.8
26.2
8.4
29.5
9.8
32.6
11.4
46
16.7
5
19.8
6.2
23
7.4
24.5
8.1
26.2
8.9
29.5
10.4
32.6
12
10
13.8
2.3
16.5
2.6
19
3
20.5
3.2
21.8
3.4
24.5
3.8
27.1
4.3
12
13.8
2.3
16.5
2.7
19
3.1
20.5
3.3
21.8
3.5
24.5
3.9
27.1
4.3
14
13.8
2.3
16.5
2.7
19
3.1
20.5
3.3
21.8
3.5
24.5
4
27.1
4.4
16
13.8
2.4
16.5
2.8
19
3.2
20.5
3.4
21.8
3.6
24.5
4
27.1
4.5
18
13.8
2.4
16.5
2.8
19
3.2
20.5
3.4
21.8
3.6
24.5
4.1
27.1
4.6
20
13.8
2.4
16.5
2.9
19
3.3
20.5
3.5
21.8
3.7
24.5
4.2
27.1
4.7
21
13.8
2.5
16.5
2.9
19
3.3
20.5
3.5
21.8
3.7
24.5
4.2
27.1
4.7
23
13.8
2.5
16.5
2.9
19
3.4
20.5
3.6
21.8
3.8
24.5
4.3
27.1
4.8
25
13.8
2.5
16.5
2.9
19
3.4
20.5
3.6
21.8
3.9
24.5
4.5
27.1
5.1
27
13.8
2.6
16.5
3.1
19
3.6
20.5
3.9
21.8
4.2
24.5
4.8
27.1
5.5
29
13.8
2.7
16.5
3.2
19
3.8
20.5
4.1
21.8
4.4
24.5
5.1
27.1
5.8
31
13.8
2.9
16.5
3.4
19
4.1
20.5
4.4
21.8
4.7
24.5
5.4
27.1
6.2
33
13.8
3
16.5
3.6
19
4.3
20.5
4.6
21.8
5
24.5
5.8
27.1
6.6
35
13.8
3.2
16.5
3.8
19
4.5
20.5
4.9
21.8
5.3
24.5
6.1
27.1
7
37
13.8
3.4
16.5
4.1
19
4.8
20.5
5.2
21.8
5.6
24.5
6.5
27.1
7.5
39
13.8
3.6
16.5
4.3
19
5.1
20.5
5.5
21.8
6
24.5
6.3
27.1
7.9
42
13.8
3.7
16.5
4.5
19
5.4
20.5
5.8
21.8
6.3
24.5
6.5
27.1
8.4
44
13.8
3.9
16.5
4.8
19
5.6
20.5
6.1
21.8
6.7
24.5
6.5
27.1
8.8
46
13.8
4.1
16.5
5
19
5.9
20.5
6.4
21.8
7.1
24.5
6.6
27.1
9.3
Cooling Performance - COOLING PERFORMANCE DATA – 160
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
31
5.6
37
6.8
42.9
8
46
8.7
49.1
9.3
55
12
31
5.7
37
6.9
42.9
8.2
46
8.9
49.1
9.5
55
10.7
58.1
11.1
10.9
58.1
14
31
5.8
37
7
42.9
8.3
46
9
49.1
9.7
55
11
11.1
56.7
10.9
16
31
5.9
37
7.2
42.9
8.5
46
9.2
49.1
9.9
18
31
6
37
7.3
42.9
8.7
46
9.4
49.1
10.1
54.8
11.2
55.9
11.1
54
11.6
55.2
20
31
6.1
37
7.5
42.9
8.9
46
9.9
49.1
10.8
11.7
53.4
12.1
54.4
12.2
21
31
6.2
37
7.5
42.9
9.3
46
10.2
49.1
23
31
6.4
37
8
42.9
9.9
46
10.9
49.1
11.2
53
12.4
54
12.6
12
52.2
13
53.2
25
31
6.8
37
8.6
42.9
10.6
46
11.7
13.1
49.1
12.9
50.7
13.6
52.6
13.7
27
31
7.2
37
9.1
42.9
11.3
46
29
31
7.7
37
9.8
42.9
12.1
46
12.5
49.1
13.8
49.9
14.1
51.8
14.3
13.4
48.9
14.6
49.1
14.8
51.1
31
31
8.2
37
10.4
42.9
12.9
14.8
46
14.3
48.1
15.2
48.5
15.3
50.3
15.4
33
31
8.7
37
11.1
42.9
35
31
9.2
37
11.8
42.9
13.8
46
15.2
47.2
15.7
47.6
15.9
49.5
16
14.7
46
16.2
46.6
16.3
49.1
16.5
48.9
16.6
37
31
9.8
37
12.6
42.9
15.7
39
31
10.4
37
13.4
42.9
16.7
45.2
16.8
45.8
16.9
47
17
48.1
17.2
44.6
17.4
45
17.5
46.2
17.6
47.2
17.8
42
31
11
37
14.1
42.9
17.7
43.8
18
44.2
18.1
44.6
44
31
11.6
37
14.9
42.9
15.6
43.1
18.5
43.3
18.7
43.1
18.2
46.4
18.4
18.8
45.6
46
31
12.3
37
15.5
42.9
19.6
42.4
19.1
42.5
19.2
41.7
19
19.4
45.2
19.6
10
27.9
5
33.3
6
38.6
7.1
41.5
7.7
44.2
8.3
12
27.9
5.1
33.3
6.1
38.6
7.3
41.5
7.8
44.2
8.4
49.5
9.5
54.8
10.7
49.5
9.6
54.8
14
27.9
5.2
33.3
6.3
38.6
7.4
41.5
8
44.2
10.8
8.6
49.5
9.8
54.8
16
27.9
5.3
33.3
6.4
38.6
7.5
41.5
8.2
11.1
44.2
8.7
49.5
10
54.8
18
27.9
5.4
33.3
6.5
38.6
7.7
41.5
11.3
8.3
44.2
8.9
49.5
10.2
54
20
27.9
5.5
33.3
6.6
38.6
7.8
41.5
11.6
8.5
44.2
9.3
49.5
11
53.2
12.1
21
27.9
5.5
33.3
6.7
38.6
8
41.5
8
44.2
9.6
49.5
23
27.9
5.6
33.3
7
38.6
8.5
41.5
9.4
44.2
10.3
49.5
11.4
53
12.4
12.2
52.2
25
27.9
5.9
33.3
7.4
38.6
9.1
41.5
10
44.2
11
49.5
13
13
51.3
13.6
27
27.9
6.3
33.3
7.9
38.6
9.7
41.5
10.7
44.2
11.7
49.5
13.9
50.7
14.1
29
27.9
6.7
33.3
8.5
38.6
10.4
41.5
11.4
44.2
12.6
48.9
14.6
49.9
14.7
31
27.9
7.1
33.3
9
38.6
11.1
41.5
12.2
44.2
13.4
48.1
15.2
49.1
15.3
33
27.9
7.6
33.3
9.6
38.6
11.8
41.5
13
44.2
14.3
47.4
15.7
48.5
15.9
35
27.9
8.1
33.3
10.2
38.6
12.6
41.5
13.9
44.2
15.2
46.6
16.3
47.6
16.5
37
27.9
8.5
33.3
10.8
38.6
13.4
41.5
14.8
44.2
16.2
46
16.9
46.8
17
39
27.9
9
33.3
11.5
38.6
14.3
41.5
15.7
44.2
17.3
45.2
17.5
46.2
17.6
42
27.9
9.5
33.3
12.2
38.6
15.1
41.5
16.7
44.2
18.3
44.5
18
45.5
18.2
44
27.9
10
33.3
12.8
38.6
15.9
41.5
17.6
44.2
19.3
43.8
18.6
44.7
18.8
46
27.9
10.5
33.3
13.5
38.6
16.7
41.5
18.5
44.2
20.4
43.1
19.2
44
19.4
10
24.8
4.4
29.6
5.3
34.5
6.3
36.8
6.7
39.2
7.2
43.9
8.2
48.7
9.3
12
24.8
4.5
29.6
5.4
34.5
6.4
36.8
6.8
39.2
7.4
43.9
8.4
48.7
9.5
14
24.8
4.6
29.6
5.5
34.5
6.5
36.8
7
39.2
7.5
43.9
8.6
48.7
9.6
16
24.8
4.7
29.6
5.6
34.5
6.6
36.8
7.1
39.2
7.7
43.9
8.7
48.7
9.8
18
24.8
4.7
29.6
5.7
34.5
6.7
36.8
7.3
39.2
7.8
43.9
8.9
48.7
10
20
24.8
4.8
29.6
5.8
34.5
6.8
36.8
7.4
39.2
8
43.9
9.2
48.7
10.7
21
24.8
4.9
29.6
5.9
34.5
6.9
36.8
7.5
39.2
8.1
43.9
9.5
48.7
11.1
23
24.8
5
29.6
6
34.5
7.3
36.8
8
39.2
8.7
43.9
10.2
48.7
11.9
25
24.8
5.1
29.6
6.4
34.5
7.7
36.8
8.5
39.2
9.3
43.9
10.9
48.7
12.8
27
24.8
5.5
29.6
6.8
34.5
8.3
36.8
9.1
39.2
9.9
43.9
11.7
48.7
13.7
29
24.8
5.8
29.6
7.2
34.5
8.8
36.8
9.7
39.2
10.6
43.9
12.5
48.7
14.6
31
24.8
6.2
29.6
7.7
34.5
9.4
36.8
10.3
39.2
11.3
43.9
13.4
48.7
15.2
33
24.8
6.5
29.6
8.2
34.5
10
36.8
11
39.2
12
43.9
14.2
48.7
15.7
35
24.8
6.9
29.6
8.7
34.5
10.6
36.8
11.7
39.2
12.8
43.9
15.2
48.7
16.3
37
24.8
7.3
29.6
9.2
34.5
11.3
36.8
12.5
39.2
13.6
43.9
16.2
48.7
16.9
39
24.8
7.8
29.6
9.8
34.5
12
36.8
13.2
39.2
14.5
43.9
17.2
48.7
17.4
42
24.8
8.2
29.6
10.4
34.5
12.7
36.8
14
39.2
15.4
43.9
18.2
48.7
18
44
24.8
8.6
29.6
10.9
34.5
13.4
36.8
14.8
39.2
16.2
43.9
19.3
48.7
18.6
46
24.8
9
29.6
11.6
34.5
14.1
36.8
15.5
39.2
17.1
43.9
20.3
48.7
19.2
25
Cooling Performance - COOLING PERFORMANCE DATA – 160
Capacity
factor(%)
70%
60%
50%
26
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
21.8
3.9
25.9
4.6
30
5.4
32.2
5.8
34.4
12
21.8
4
25.9
4.7
30
5.5
32.2
5.9
34.4
14
21.8
4
25.9
4.8
30
5.6
32.2
6
16
21.8
4.1
25.9
4.9
30
5.7
32.2
6.1
18
21.8
4.2
25.9
5
30
5.8
32.2
20
21.8
4.2
25.9
5.1
30
5.9
21
21.8
4.3
25.9
5.1
30
23
21.8
4.3
25.9
5.2
30
25
21.8
4.4
25.9
5.4
30
27
21.8
4.7
25.9
5.7
30
29
21.8
5
25.9
6.1
31
21.8
5.3
25.9
33
21.8
5.6
35
21.8
5.9
37
21.8
39
22
24
TC
kW
PI
kW
TC
kW
PI
kW
6.2
38.4
7.1
42.7
8
6.4
38.4
7.2
42.7
8.1
34.4
6.4
38.4
7.3
42.7
8.3
34.4
6.6
38.4
7.5
42.7
8.4
6.3
34.4
6.7
38.4
7.6
42.7
8.6
32.2
6.4
34.4
6.8
38.4
7.8
42.7
8.8
6
32.2
6.4
34.4
6.9
38.4
7.9
42.7
9.1
6.1
32.2
6.7
34.4
7.2
38.4
8.5
42.7
10.1
6.5
32.2
7.1
34.4
7.7
38.4
9
42.7
10.5
6.9
32.2
7.6
34.4
8.2
38.4
9.7
42.7
11.2
30
7.4
32.2
8.1
34.4
8.8
38.4
10.3
42.7
12
6.5
30
7.8
32.2
8.6
34.4
9.4
38.4
11
42.7
12.8
25.9
6.9
30
8.3
32.2
9.1
34.4
9.9
38.4
11.7
42.7
13.6
25.9
7.3
30
8.9
32.2
9.7
34.4
11
38.4
12.5
42.7
14.5
6.3
25.9
7.7
30
9.4
32.2
10
34.4
11
38.4
13.3
42.7
15.5
21.8
6.6
25.9
8.2
30
10
32.2
11
34.4
12
38.4
14.1
42.7
16.5
42
21.8
7
25.9
8.7
30
11
32.2
12
34.4
13
38.4
15
42.7
17.4
44
21.8
7.3
25.9
9.1
30
11
32.2
12
34.4
13
38.4
15.8
42.7
18.4
46
21.8
7.7
25.9
9.6
30
12
32.2
13
34.4
14
38.4
16.6
42.7
19.4
10
18.7
3.4
22.2
4
26
4.6
27.5
5
29.4
5.3
33.1
6
36.6
6.7
12
18.7
3.4
22.2
4.1
26
4.7
27.5
5
29.4
5.4
33.1
6.1
36.6
6.8
14
18.7
3.5
22.2
4.1
26
4.8
27.5
5.1
29.4
5.5
33.1
6.2
36.6
6.9
16
18.7
3.6
22.2
4.2
26
4.9
27.5
5.2
29.4
5.6
33.1
6.3
36.6
7.1
18
18.7
3.6
22.2
4.2
26
4.9
27.5
5.3
29.4
5.7
33.1
6.4
36.6
7.2
20
18.7
3.7
22.2
4.3
26
5
27.5
5.4
29.4
5.8
33.1
6.5
36.6
7.3
21
18.7
3.7
22.2
4.4
26
5.1
27.5
5.5
29.4
5.8
33.1
6.6
36.6
7.4
23
18.7
3.8
22.2
4.4
26
5.2
27.5
5.5
29.4
6
33.1
6.9
36.6
7.9
25
18.7
3.8
22.2
4.5
26
5.4
27.5
5.8
29.4
6.3
33.1
7.3
36.6
8.4
27
18.7
4
22.2
4.8
26
5.7
27.5
6.2
29.4
6.7
33.1
7.8
36.6
9
29
18.7
4.2
22.2
5.1
26
6.1
27.5
6.6
29.4
7.2
33.1
8.3
36.6
9.6
31
18.7
4.4
22.2
5.4
26
6.4
27.5
7
29.4
7.6
33.1
8.9
36.6
10.2
33
18.7
4.7
22.2
5.7
26
6.8
27.5
7.5
29.4
8.1
33.1
9.5
36.6
10.9
35
18.7
5
22.2
6
26
7.3
27.5
7.9
29.4
8.6
33.1
10
36.6
11.6
37
18.7
5.2
22.2
6.4
26
7.7
27.5
8.4
29.4
9.1
33.1
10.7
36.6
12.3
39
18.7
5.5
22.2
6.8
26
8.2
27.5
8.9
29.4
9.7
33.1
11.3
36.6
13.1
42
18.7
5.8
22.2
7.2
26
8.6
27.5
9.4
29.4
10
33.1
12
36.6
13.9
44
18.7
6.1
22.2
7.5
26
9.1
27.5
9.9
29.4
11
33.1
12.6
36.6
14.6
46
18.7
6.5
22.2
7.9
26
9.5
27.5
10
29.4
11
33.1
13.3
36.6
15.4
10
15.5
2.9
18.5
0.4
22
3.9
23
4.1
24.4
4.4
27.5
4.9
30.4
5.5
12
15.5
3
18.5
3.4
22
3.9
23
4.2
24.4
4.5
27.5
5
30.4
5.6
14
15.5
3
18.5
3.5
22
4
23
4.2
24.4
4.5
27.5
5.1
30.4
5.7
16
15.5
3
18.5
3.5
22
4.1
23
4.3
24.4
4.6
27.5
5.2
30.4
5.8
18
15.5
3.1
18.5
3.6
22
4.1
23
4.4
24.4
4.7
27.5
5.3
30.4
5.9
20
15.5
3.1
18.5
3.7
22
4.2
23
4.5
24.4
4.8
27.5
5.4
30.4
6
21
15.5
3.2
18.5
3.7
22
4.2
23
4.5
24.4
4.8
27.5
5.4
30.4
6.1
23
15.5
3.2
18.5
3.7
22
4.3
23
4.6
24.4
4.9
27.5
5.5
30.4
6.2
25
15.5
3.3
18.5
3.8
22
4.4
23
4.7
24.4
5.1
27.5
5.8
30.4
6.6
27
15.5
3.3
18.5
3.9
22
4.6
23
5
24.4
5.4
27.5
6.2
30.4
7
29
15.5
3.5
18.5
4.2
22
4.9
23
5.3
24.4
5.7
27.5
6.6
30.4
7.5
31
15.5
3.7
18.5
4.4
22
5.2
23
5.6
24.4
6
27.5
7
30.4
8
33
15.5
3.9
18.5
4.6
22
5.5
23
6
24.4
6.4
27.5
7.4
30.4
8.5
35
15.5
4.1
18.5
4.9
22
5.8
23
6.3
24.4
6.8
27.5
7.9
30.4
9
37
15.5
4.3
18.5
5.2
22
6.2
23
6.7
24.4
7.2
27.5
8.4
30.4
9.6
39
15.5
4.6
18.5
5.5
22
6.5
23
7.1
24.4
7.7
27.5
8.1
30.4
10.2
42
15.5
4.8
18.5
5.8
22
6.9
23
7.4
24.4
8.1
27.5
8.3
30.4
10.7
44
15.5
5
18.5
61
22
7.2
23
7.8
24.4
8.6
27.5
8.4
30.4
11.3
46
15.5
5.2
18.5
6.4
22
7.6
23
8.2
24.4
9.1
27.5
8.5
30.4
11.9
Cooling Performance - COOLING PERFORMANCE DATA – 180
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
12
22
24
TC
kW
PI
kW
TC
kW
PI
kW
10
36.4
6.1
43.4
7.4
50.4
8.7
54
9.4
57.6
10.1
64.6
11.6
68.2
12
36.4
6.2
43.4
7.5
50.4
8.9
54
9.6
57.6
10.3
64.6
11.8
68.2
12
14
36.4
6.3
43.4
7.7
50.4
9.1
54
9.8
57.6
10.5
64.6
12.1
66.5
11.9
16
36.4
6.4
43.4
7.8
50.4
9.3
54
10
57.6
10.8
64.4
12.2
65.6
12.1
18
36.4
6.5
43.4
8
50.4
9.4
54
10.2
57.6
11
63.4
12.6
64.8
12.7
20
36.4
6.7
43.4
8.1
50.4
9.7
54
10.7
57.6
11.8
62.7
13.2
63.9
13.3
21
36.4
6.7
43.4
8.2
50.4
10.1
54
11.1
57.6
12.2
62.2
13.5
63.4
13.6
23
36.4
6.9
43.4
8.7
50.4
10.8
54
11.9
57.6
13
61.2
14.2
62.4
14.3
25
36.4
7.4
43.4
9.3
50.4
11.5
54
12.7
57.6
14
59.5
14.8
61.7
14.9
27
36.4
7.9
43.4
9.9
50.4
12.3
54
13.6
57.6
15
58.6
15.4
60.8
15.5
29
36.4
8.4
43.4
10.6
50.4
13.2
54
14.5
57.4
15.9
57.6
16.1
60
16.1
31
36.4
8.9
43.4
11.3
50.4
14.1
54
15.5
56.4
16.5
56.9
16.6
59.1
16.8
33
36.4
9.5
43.4
12.1
50.4
15
54
16.5
55.4
17.1
55.9
17.3
58.1
17.4
35
36.4
10
43.4
12.8
50.4
16
54
17.7
54.7
17.7
57.6
17.9
57.4
18.1
37
36.4
10.7
43.4
13.6
50.4
17
53
18.3
53.8
18.4
55.2
18.5
56.4
18.7
39
36.4
11.4
43.4
14.5
50.4
18.1
52.3
18.9
52.8
19
54.2
19.2
55.4
19.3
42
36.4
12
43.4
15.4
50.4
19.2
51.4
19.5
51.8
19.6
52.3
19.8
54.5
20
44
36.4
12.7
43.4
16.2
50.4
20.3
50.6
20.1
50.9
20.3
50.6
20.5
53.5
20.6
46
36.4
13.4
43.4
16.9
50.4
21.4
49.8
20.8
49.9
20.9
49
21.1
53.1
21.3
10
32.8
5.5
39.1
6.6
45.3
7.8
48.7
8.4
51.8
9
58.1
10.3
64.4
11.6
12
32.8
5.5
39.1
6.7
45.3
7.9
48.7
8.5
51.8
9.2
58.1
10.5
64.4
11.8
14
32.8
5.6
39.1
6.8
45.3
8.1
48.7
8.7
51.8
9.3
58.1
10.7
64.4
12
16
32.8
5.7
39.1
6.9
45.3
8.2
48.7
8.9
51.8
9.5
58.1
10.9
64.4
12.2
18
32.8
5.8
39.1
7.1
45.3
8.4
48.7
9
51.8
9.7
58.1
11.1
63.4
12.6
20
32.8
5.9
39.1
7.2
45.3
8.5
48.7
9.2
51.8
10.1
58.1
11.9
62.4
13.2
21
32.8
6
39.1
7.3
45.3
8.7
48.7
9.5
51.8
10.4
58.1
12.4
62.2
13.5
23
32.8
6.1
39.1
7.6
45.3
9.3
48.7
10.2
51.8
11.2
58.1
13.2
61.2
14.2
25
32.8
6.4
39.1
8.1
45.3
9.9
48.7
10.9
51.8
12
58.1
14.2
60.3
14.8
27
32.8
6.8
39.1
8.6
45.3
10.6
48.7
11.7
51.8
12.8
58.1
15.2
59.5
15.4
29
32.8
7.3
39.1
9.2
45.3
11.3
48.7
12.4
51.8
13.6
57.4
15.9
58.6
16
31
32.8
7.8
39.1
9.8
45.3
12.1
48.7
13.3
51.8
14.6
56.4
16.5
57.6
16.6
33
32.8
8.2
39.1
10.4
45.3
12.8
48.7
14.2
51.8
15.5
55.7
17.1
56.9
17.3
35
32.8
8.8
39.1
11.1
45.3
13.7
48.7
15.1
51.8
16.6
54.7
17.8
55.9
17.9
37
32.8
9.3
39.1
11.8
45.3
14.6
48.7
16.1
51.8
17.7
54
18.4
55
18.5
39
32.8
9.8
39.1
12.5
45.3
15.5
48.7
17.1
51.8
18.8
53
19
54.2
19.2
42
32.8
10.4
39.1
13.2
45.3
16.4
48.7
18.1
51.8
19.9
52.2
19.6
53.4
19.8
44
32.8
10.9
39.1
13.9
45.3
17.3
48.7
19.1
51.8
21
51.4
20.2
52.5
20.5
46
32.8
11.5
39.1
14.7
45.3
18.2
48.7
20.1
51.8
22.1
50.6
20.9
51.6
21.1
10.1
10
29.2
4.8
34.7
5.8
40.5
6.8
43.2
7.3
46
7.9
51.6
9
57.1
12
29.2
4.9
34.7
5.9
40.5
6.9
43.2
7.4
46
8
51.6
9.1
57.1
10.3
14
29.2
5
34.7
6
40.5
7
43.2
7.6
46
8.2
51.6
9.3
57.1
10.5
16
29.2
5.1
34.7
6.1
40.5
7.2
43.2
7.8
46
8.3
51.6
9.5
57.1
10.7
18
29.2
5.2
34.7
6.2
40.5
7.3
43.2
7.9
46
8.5
51.6
9.7
57.1
10.9
20
29.2
5.3
34.7
6.3
40.5
7.4
43.2
8.1
46
8.7
51.6
10
57.1
11.7
21
29.2
5.3
34.7
6.4
40.5
7.5
43.2
8.1
46
8.8
51.6
10.4
57.1
12.1
23
29.2
5.4
34.7
6.5
40.5
7.9
43.2
8.7
46
9.4
51.6
11.1
57.1
13
25
29.2
5.6
34.7
6.9
40.5
8.4
43.2
9.2
46
10.1
51.6
11.9
57.1
13.9
27
29.2
5.9
34.7
7.4
40.5
9
43.2
9.9
46
10.8
51.6
12.7
57.1
14.9
29
29.2
6.3
34.7
7.9
40.5
9.6
43.2
10.5
46
11.5
51.6
13.6
57.1
15.9
31
29.2
6.7
34.7
8.4
40.5
10.2
43.2
11.2
46
12.3
51.6
14.5
57.1
16.5
33
29.2
7.1
34.7
8.9
40.5
10.9
43.2
12
46
13.1
51.6
15.5
57.1
17.1
35
29.2
7.5
34.7
9.4
40.5
11.6
43.2
12.7
46
13.9
51.6
16.5
57.1
17.7
37
29.2
8
34.7
10
40.5
12.3
43.2
13.5
46
14.8
51.6
17.6
57.1
18.4
39
29.2
8.5
34.7
10.6
40.5
13.1
43.2
14.4
46
15.8
51.6
18.7
57.1
19
42
29.2
8.9
34.7
11.3
40.5
13.8
43.2
15.2
46
16.7
51.6
19.8
57.1
19.6
44
29.2
9.4
34.7
11.9
40.5
14.6
43.2
16.1
46
17.6
51.6
21
57.1
20.2
46
29.2
9.8
34.7
12.6
40.5
15.3
43.2
16.9
46
18.6
51.6
22.1
57.1
20.8
27
Cooling Performance - COOLING PERFORMANCE DATA – 180
Capacity
factor(%)
70%
60%
50%
28
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
25.6
4.2
30.4
5.1
35
5.9
37.8
6.3
40.3
6.8
45.1
7.7
50.1
8.7
12
25.6
4.3
30.4
5.1
35
6
37.8
6.4
40.3
6.9
45.1
7.9
50.1
8.8
14
25.6
4.4
30.4
5.2
35
6.1
37.8
6.6
40.3
7
45.1
8
50.1
9
16
25.6
4.4
30.4
5.3
35
6.2
37.8
6.7
40.3
7.1
45.1
8.2
50.1
9.2
18
25.6
4.5
30.4
5.4
35
6.3
37.8
6.8
40.3
7.3
45.1
8.3
50.1
9.3
20
25.6
4.6
30.4
5.5
35
6.4
37.8
6.9
40.3
7.4
45.1
8.5
50.1
9.6
21
25.6
4.7
30.4
5.6
35
6.5
37.8
7
40.3
7.5
45.1
8.6
50.1
9.9
23
25.6
4.7
30.4
5.7
35
6.6
37.8
7.2
40.3
7.9
45.1
9.2
50.1
11
25
25.6
4.8
30.4
5.9
35
7.1
37.8
7.7
40.3
8.4
45.1
9.8
50.1
11.4
27
25.6
5.1
30.4
6.2
35
7.5
37.8
8.2
40.3
9
45.1
10.5
50.1
12.2
29
25.6
5.4
30.4
6.6
35
8
37.8
8.8
40.3
9.5
45.1
11.2
50.1
13
31
25.6
5.7
30.4
7
35
8.5
37.8
9.3
40.3
10
45.1
12
50.1
13.9
33
25.6
6.1
30.4
7.5
35
9.1
37.8
9.9
40.3
11
45.1
12.7
50.1
14.8
35
25.6
6.4
30.4
8
35
9.6
37.8
11
40.3
12
45.1
13.5
50.1
15.8
37
25.6
6.8
30.4
8.4
35
10
37.8
11
40.3
12
45.1
14.4
50.1
16.8
39
25.6
7.2
30.4
8.9
35
11
37.8
12
40.3
13
45.1
15.4
50.1
17.9
42
25.6
7.6
30.4
9.4
35
12
37.8
13
40.3
14
45.1
16.3
50.1
19
44
25.6
8
30.4
9.9
35
12
37.8
13
40.3
15
45.1
17.2
50.1
20
46
25.6
8.3
30.4
10
35
13
37.8
14
40.3
15
45.1
18.1
50.1
21.1
10
21.9
3.7
26
4.3
30
5
32.3
5.4
34.5
5.7
38.8
6.5
42.9
7.3
12
21.9
3.7
26
4.4
30
5.1
32.3
5.5
34.5
5.8
38.8
6.6
42.9
7.4
14
21.9
3.8
26
4.5
30
5.2
32.3
5.6
34.5
5.9
38.8
6.7
42.9
7.5
16
21.9
3.9
26
4.5
30
5.3
32.3
5.7
34.5
6.1
38.8
6.8
42.9
7.7
18
21.9
3.9
26
4.6
30
5.4
32.3
5.8
34.5
6.2
38.8
7
42.9
7.9
20
21.9
4
26
4.7
30
5.5
32.3
5.9
34.5
6.3
38.8
7.1
42.9
8
21
21.9
4
26
4.8
30
5.5
32.3
5.9
34.5
6.3
38.8
7.2
42.9
8.1
23
21.9
4.1
26
4.8
30
5.6
32.3
6
34.5
6.5
38.8
7.5
42.9
8.6
25
21.9
4.1
26
4.9
30
5.8
32.3
6.3
34.5
6.9
38.8
8
42.9
9.2
27
21.9
4.3
26
5.2
30
6.2
32.3
6.7
34.5
7.3
38.8
8.5
42.9
9.8
29
21.9
4.5
26
5.5
30
6.6
32.3
7.2
34.5
7.8
38.8
9.1
42.9
10.4
31
21.9
4.8
26
5.9
30
7
32.3
7.7
34.5
8.3
38.8
9.6
42.9
11.1
33
21.9
5.1
26
6.2
30
7.4
32.3
8.1
34.5
8.8
38.8
10.3
42.9
11.9
35
21.9
5.4
26
6.6
30
7.9
32.3
8.6
34.5
9.3
38.8
10.9
42.9
12.6
37
21.9
5.7
26
7
30
8.4
32.3
9.1
34.5
9.9
38.8
11.6
42.9
13.4
39
21.9
6
26
7.4
30
8.9
32.3
9.7
34.5
11
38.8
12.3
42.9
14.3
42
21.9
6.3
26
7.8
30
9.4
32.3
10
34.5
11
38.8
13
42.9
15.1
44
21.9
6.7
26
8.2
30
9.9
32.3
11
34.5
12
38.8
13.7
42.9
15.9
16.7
46
21.9
7
26
8.6
30
10
32.3
11
34.5
12
38.8
14.4
42.9
10
18.2
3.2
21.7
3.7
25
4.2
27
4.5
28.7
4.8
32.3
5.4
35.7
6
12
18.2
3.2
21.7
3.7
25
4.3
27
4.5
28.7
4.9
32.3
5.5
35.7
6.1
14
18.2
3.3
21.7
3.8
25
4.3
27
4.6
28.7
4.9
32.3
5.5
35.7
6.2
16
18.2
3.3
21.7
3.8
25
4.4
27
4.7
28.7
5
32.3
5.6
35.7
6.3
18
18.2
3.3
21.7
3.9
25
4.5
27
4.8
28.7
5.1
32.3
5.7
35.7
6.4
20
18.2
3.4
21.7
4
25
4.5
27
4.9
28.7
5.2
32.3
5.8
35.7
6.5
21
18.2
3.4
21.7
4
25
4.6
27
4.9
28.7
5.2
32.3
5.9
35.7
6.6
23
18.2
3.5
21.7
4
25
4.7
27
5
28.7
5.3
32.3
6
35.7
6.7
25
18.2
3.5
21.7
4.1
25
4.8
27
5.1
28.7
5.5
32.3
6.3
35.7
7.2
27
18.2
3.6
21.7
4.3
25
5
27
5.4
28.7
5.8
32.3
6.7
35.7
7.7
8.2
29
18.2
3.8
21.7
4.5
25
5.3
27
5.8
28.7
6.2
32.3
7.1
35.7
31
18.2
4
21.7
4.8
25
5.7
27
6.1
28.7
6.6
32.3
7.6
35.7
8.7
33
18.2
4.2
21.7
5.1
25
6
27
6.5
28.7
7
32.3
8.1
35.7
9.2
35
18.2
4.5
21.7
5.4
25
6.3
27
6.9
28.7
7.4
32.3
8.6
35.7
9.8
37
18.2
4.7
21.7
5.7
25
6.7
27
7.3
28.7
7.9
32.3
9.1
35.7
10.4
39
18.2
5
21.7
6
25
7.1
27
7.7
28.7
8.3
32.3
8.8
35.7
11.1
42
18.2
5.2
21.7
6.3
25
7.5
27
8.1
28.7
8.8
32.3
9
35.7
11.7
44
18.2
5.4
21.7
6.6
25
7.9
27
8.5
28.7
9.4
32.3
9.1
35.7
12.3
46
18.2
5.7
21.7
7
25
8.3
27
8.9
28.7
9.9
32.3
9.2
35.7
12.9
Cooling Performance - COOLING PERFORMANCE DATA – 200
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
38.4
6.6
45.8
8
53.2
9.4
57
10.2
60.8
10.9
68.2
12.5
72
13
12
38.4
6.7
45.8
8.1
53.2
9.6
57
10.4
60.8
11.2
68.2
12.8
72
12.9
14
38.4
6.8
45.8
8.2
53.2
9.8
57
10.6
60.8
11.4
68.2
13
70.2
12.8
16
38.4
6.9
45.8
8.4
53.2
10
57
10.8
60.8
11.6
67.9
13.2
69.2
13
18
38.4
7
45.8
8.6
53.2
10.2
57
11
60.8
11.8
66.9
13.6
68.5
13.7
20
38.4
7.2
45.8
8.8
53.2
10.5
57
11.6
60.8
12.7
66.2
14.2
67.4
14.4
21
38.4
7.3
45.8
8.8
53.2
10.9
57
12
60.8
13.1
65.7
14.6
66.9
14.7
23
38.4
7.4
45.8
9.4
53.2
11.6
57
12.8
60.8
14.1
64.6
15.3
65.9
15.4
25
38.4
8
45.8
10.1
53.2
12.4
57
13.7
60.8
15.1
62.9
15.9
65.1
16.1
27
38.4
8.5
45.8
10.7
53.2
13.3
57
14.7
60.8
16.1
61.8
16.6
64.1
16.7
29
38.4
9
45.8
11.4
53.2
14.2
57
15.7
60.6
17.1
60.8
17.3
63.4
17.4
31
38.4
9.6
45.8
12.2
53.2
15.2
57
16.8
59.5
17.8
60.1
17.9
62.3
18.1
33
38.4
10.2
45.8
13
53.2
16.1
57
17.8
58.5
18.5
59
18.6
61.3
18.8
35
38.4
10.8
45.8
13.8
53.2
17.2
57
19
57.8
19.1
60.8
19.3
60.6
19.5
37
38.4
11.5
45.8
14.7
53.2
18.3
56
19.7
56.7
19.8
58.3
20
59.5
20.2
39
38.4
12.2
45.8
15.7
53.2
19.5
55.2
20.4
55.7
20.5
57.3
20.7
58.5
20.9
42
38.4
12.9
45.8
16.6
53.2
20.7
54.3
21.1
54.7
21.2
55.2
21.4
57.5
21.5
44
38.4
13.7
45.8
17.5
53.2
21.9
53.4
21.7
53.7
21.9
53.4
22.1
56.5
22.2
46
38.4
14.4
45.8
18.2
53.2
23
52.5
22.4
52.7
22.6
51.7
22.7
56
22.9
10
34.6
5.9
41.2
7.1
47.8
8.4
51.4
9
54.7
9.7
61.3
11.1
67.9
12.5
12
34.6
6
41.2
7.2
47.8
8.5
51.4
9.2
54.7
9.9
61.3
11.3
67.9
12.7
14
34.6
6.1
41.2
7.3
47.8
8.7
51.4
9.4
54.7
10.1
61.3
11.5
67.9
13
16
34.6
6.2
41.2
7.5
47.8
8.8
51.4
9.6
54.7
10.2
61.3
11.7
67.9
13.2
18
34.6
6.3
41.2
7.6
47.8
9
51.4
9.7
54.7
10.5
61.3
12
66.9
13.6
20
34.6
6.4
41.2
7.8
47.8
9.2
51.4
9.9
54.7
10.9
61.3
12.9
65.9
14.2
21
34.6
6.5
41.2
7.8
47.8
9.3
51.4
10.3
54.7
11.2
61.3
13.3
65.7
14.6
23
34.6
6.6
41.2
8.2
47.8
10
51.4
11
54.7
12.1
61.3
14.3
64.6
15.3
25
34.6
6.9
41.2
8.7
47.8
10.7
51.4
11.8
54.7
12.9
61.3
15.3
63.6
15.9
27
34.6
7.4
41.2
9.3
47.8
11.4
51.4
12.6
54.7
13.8
61.3
16.4
62.9
16.6
29
34.6
7.8
41.2
9.9
47.8
12.2
51.4
13.4
54.7
14.7
60.6
17.1
61.8
17.3
31
34.6
8.4
41.2
10.5
47.8
13
51.4
14.3
54.7
15.7
59.5
17.8
60.8
17.9
33
34.6
8.9
41.2
11.2
47.8
13.8
51.4
15.3
54.7
16.8
58.8
18.5
60.1
18.6
35
34.6
9.4
41.2
11.9
47.8
14.8
51.4
16.3
54.7
17.9
57.8
19.1
59
19.3
37
34.6
10
41.2
12.7
47.8
15.7
51.4
17.3
54.7
19
57
19.8
58
20
39
34.6
10.6
41.2
13.5
47.8
16.7
51.4
18.5
54.7
20.3
56
20.5
57.3
20.7
42
34.6
11.2
41.2
14.3
47.8
17.7
51.4
19.5
54.7
21.5
55.1
21.2
56.3
21.4
44
34.6
11.8
41.2
15
47.8
18.7
51.4
20.6
54.7
22.7
54.2
21.8
55.4
22.1
46
34.6
12.4
41.2
15.8
47.8
19.6
51.4
21.7
54.7
23.9
53.4
22.5
54.5
22.7
10
30.8
5.2
36.6
6.2
42.8
7.3
45.5
7.9
48.6
8.5
54.5
9.7
60.3
10.9
12
30.8
5.3
36.6
6.4
42.8
7.4
45.5
8
48.6
8.6
54.5
9.8
60.3
11.1
14
30.8
5.4
36.6
6.5
42.8
7.6
45.5
8.2
48.6
8.8
54.5
10
60.3
11.3
16
30.8
5.5
36.6
6.6
42.8
7.7
45.5
8.4
48.6
9
54.5
10.2
60.3
11.5
18
30.8
5.6
36.6
6.7
42.8
7.9
45.5
8.5
48.6
9.2
54.5
10.4
60.3
11.8
20
30.8
5.7
36.6
6.8
42.8
8
45.5
8.7
48.6
9.3
54.5
10.8
60.3
12.6
21
30.8
5.7
36.6
6.9
42.8
8.1
45.5
8.8
48.6
9.5
54.5
11.2
60.3
13
23
30.8
5.8
36.6
7
42.8
8.5
45.5
9.3
48.6
10.2
54.5
12
60.3
14
25
30.8
6
36.6
7.5
42.8
9.1
45.5
10
48.6
10.9
54.5
12.8
60.3
15
27
30.8
6.4
36.6
8
42.8
9.7
45.5
10.6
48.6
11.6
54.5
13.7
60.3
16
17.1
29
30.8
6.8
36.6
8.5
42.8
10.4
45.5
11.3
48.6
12.4
54.5
14.7
60.3
31
30.8
7.2
36.6
9
42.8
11
45.5
12.1
48.6
13.2
54.5
15.7
60.3
17.8
33
30.8
7.7
36.6
9.6
42.8
11.7
45.5
12.9
48.6
14.1
54.5
16.7
60.3
18.5
35
30.8
8.1
36.6
10.2
42.8
12.5
45.5
13.7
48.6
15
54.5
17.8
60.3
19.1
37
30.8
8.6
36.6
10.8
42.8
13.3
45.5
14.6
48.6
16
54.5
19
60.3
19.8
39
30.8
9.1
36.6
11.5
42.8
14.1
45.5
15.5
48.6
17
54.5
20.2
60.3
20.5
42
30.8
9.6
36.6
12.1
42.8
14.9
45.5
16.4
48.6
18
54.5
21.4
60.3
21.1
44
30.8
10.1
36.6
12.8
42.8
15.7
45.5
17.3
48.6
19
54.5
22.6
60.3
21.8
46
30.8
10.6
36.6
13.6
42.8
16.5
45.5
18.2
48.6
20
54.5
23.8
60.3
22.5
29
Cooling Performance - COOLING PERFORMANCE DATA – 200
Capacity
factor(%)
70%
60%
50%
30
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
27
4.6
32.1
5.5
37
6.4
40
6.8
42.5
12
27
4.7
32.1
5.5
37
6.5
40
6.9
42.5
14
27
4.7
32.1
5.6
37
6.6
40
7.1
16
27
4.8
32.1
5.7
37
6.7
40
18
27
4.9
32.1
5.8
37
6.8
20
27
5
32.1
5.9
37
21
27
5
32.1
6
37
23
27
5.1
32.1
6.1
25
27
5.2
32.1
27
27
5.5
29
27
5.8
31
27
33
22
24
TC
kW
PI
kW
TC
kW
PI
kW
7.3
47.6
8.3
52.9
9.3
7.4
47.6
8.5
52.9
9.5
42.5
7.6
47.6
8.6
52.9
9.7
7.2
42.5
7.7
47.6
8.8
52.9
9.9
40
7.3
42.5
7.8
47.6
8.9
52.9
10.1
6.9
40
7.5
42.5
8
47.6
9.1
52.9
10.4
7
40
7.6
42.5
8.1
47.6
9.3
52.9
10.7
37
7.2
40
7.8
42.5
8.5
47.6
9.9
52.9
11.8
6.3
37
7.6
40
8.3
42.5
9
47.6
10.6
52.9
12.3
32.1
6.7
37
8.1
40
8.9
42.5
9.7
47.6
11.3
52.9
13.2
32.1
7.2
37
8.6
40
9.4
42.5
10
47.6
12.1
52.9
14
6.2
32.1
7.6
37
9.2
40
10
42.5
11
47.6
12.9
52.9
15
27
6.5
32.1
8.1
37
9.8
40
11
42.5
12
47.6
13.7
52.9
16
35
27
6.9
32.1
8.6
37
10
40
11
42.5
12
47.6
14.6
52.9
17
37
27
7.3
32.1
9.1
37
11
40
12
42.5
13
47.6
15.6
52.9
18.1
39
27
7.7
32.1
9.6
37
12
40
13
42.5
14
47.6
16.6
52.9
19.3
42
27
8.2
32.1
10
37
12
40
14
42.5
15
47.6
17.5
52.9
20.4
44
27
8.6
32.1
11
37
13
40
14
42.5
16
47.6
18.5
52.9
21.6
46
27
9
32.1
11
37
14
40
15
42.5
16
47.6
19.5
52.9
22.7
10
23.2
4
27.5
4.7
32
5.4
34.1
5.8
36.4
6.2
41
7
45.3
7.8
12
23.2
4
27.5
4.8
32
5.5
34.1
5.9
36.4
6.3
41
7.1
45.3
8
14
23.2
4.1
27.5
4.8
32
5.6
34.1
6
36.4
6.4
41
7.3
45.3
8.1
16
23.2
4.2
27.5
4.9
32
5.7
34.1
6.1
36.4
6.5
41
7.4
45.3
8.3
18
23.2
4.2
27.5
5
32
5.8
34.1
6.2
36.4
6.6
41
7.5
45.3
8.5
20
23.2
4.3
27.5
5.1
32
5.9
34.1
6.3
36.4
6.8
41
7.7
45.3
8.6
21
23.2
4.3
27.5
5.1
32
6
34.1
6.4
36.4
6.8
41
7.7
45.3
8.7
23
23.2
4.4
27.5
5.2
32
6.1
34.1
6.5
36.4
7
41
8.1
45.3
9.3
25
23.2
4.5
27.5
5.3
32
6.3
34.1
6.8
36.4
7.4
41
8.6
45.3
9.9
27
23.2
4.7
27.5
5.6
32
6.7
34.1
7.3
36.4
7.9
41
9.2
45.3
10.5
29
23.2
4.9
27.5
6
32
7.1
34.1
7.7
36.4
8.4
41
9.8
45.3
11.3
31
23.2
5.2
27.5
6.3
32
7.6
34.1
8.2
36.4
8.9
41
10.4
45.3
12
33
23.2
5.5
27.5
6.7
32
8
34.1
8.8
36.4
9.5
41
11.1
45.3
12.8
35
23.2
5.8
27.5
7.1
32
8.5
34.1
9.3
36.4
10
41
11.8
45.3
13.6
37
23.2
6.1
27.5
7.5
32
9
34.1
9.8
36.4
11
41
12.5
45.3
14.5
39
23.2
6.5
27.5
8
32
9.6
34.1
11
36.4
11
41
13.3
45.3
15.4
42
23.2
6.8
27.5
8.4
32
10
34.1
11
36.4
12
41
14
45.3
16.3
44
23.2
7.2
27.5
8.8
32
11
34.1
12
36.4
13
41
14.8
45.3
17.1
46
23.2
7.6
27.5
9.3
32
11
34.1
12
36.4
13
41
15.6
45.3
18
10
19.2
3.4
22.9
4
27
4.5
28.5
4.8
30.3
5.2
34.1
5.8
37.7
6.4
12
19.2
3.5
22.9
4
27
4.6
28.5
4.9
30.3
5.2
34.1
5.9
37.7
6.5
14
19.2
3.5
22.9
4.1
27
4.7
28.5
5
30.3
5.3
34.1
6
37.7
6.6
16
19.2
3.6
22.9
4.1
27
4.8
28.5
5.1
30.3
5.4
34.1
6.1
37.7
6.8
18
19.2
3.6
22.9
4.2
27
4.8
28.5
5.2
30.3
5.5
34.1
6.2
37.7
6.9
20
19.2
3.7
22.9
4.3
27
4.9
28.5
5.2
30.3
5.6
34.1
6.3
37.7
7
21
19.2
3.7
22.9
4.3
27
4.9
28.5
5.3
30.3
5.6
34.1
6.4
37.7
7.1
23
19.2
3.7
22.9
4.4
27
5.1
28.5
5.4
30.3
5.7
34.1
6.5
37.7
7.3
25
19.2
3.8
22.9
4.4
27
5.1
28.5
5.5
30.3
5.9
34.1
6.8
37.7
7.7
27
19.2
3.9
22.9
4.6
27
5.4
28.5
5.9
30.3
6.3
34.1
7.2
37.7
8.2
29
19.2
4.1
22.9
4.9
27
5.7
28.5
6.2
30.3
6.7
34.1
7.7
37.7
8.8
31
19.2
4.3
22.9
5.2
27
6.1
28.5
6.6
30.3
7.1
34.1
8.2
37.7
9.4
33
19.2
4.6
22.9
5.5
27
6.5
28.5
7
30.3
7.5
34.1
8.7
37.7
10
35
19.2
4.8
22.9
5.8
27
6.8
28.5
7.4
30.3
8
34.1
9.2
37.7
10.6
37
19.2
5.1
22.9
6.1
27
7.2
28.5
7.8
30.3
8.5
34.1
9.8
37.7
11.2
39
19.2
5.3
22.9
6.5
27
7.7
28.5
8.3
30.3
9
34.1
9.4
37.7
11.9
42
19.2
5.6
22.9
6.8
27
8.1
28.5
8.7
30.3
9.5
34.1
9.7
37.7
12.6
44
19.2
5.9
22.9
7.2
27
8.5
28.5
9.2
30.3
10
34.1
9.8
37.7
13.3
46
19.2
6.1
22.9
7.5
27
8.9
28.5
9.6
30.3
11
34.1
9.9
37.7
13.9
Cooling Performance - COOLING PERFORMANCE DATA – 220
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
22
24
TC
kW
PI
kW
TC
kW
PI
kW
10
40.8
6.8
48.6
8.2
56.4
9.7
60.5
10.5
64.6
11.3
72.4
12.9
76.4
13.4
12
40.8
6.9
48.6
8.3
56.4
9.9
60.5
10.7
64.6
11.5
72.4
13.1
76.4
13.3
14
40.8
7
48.6
8.5
56.4
10.1
60.5
10.9
64.6
11.7
72.4
13.4
74.5
13.2
16
40.8
7.1
48.6
8.6
56.4
10.3
60.5
11.1
64.6
11.9
72.1
13.6
73.5
13.4
18
40.8
7.3
48.6
8.8
56.4
10.5
60.5
11.3
64.6
12.2
71
14
72.7
14.1
20
40.8
7.4
48.6
9
56.4
10.8
60.5
11.9
64.6
13.1
70.2
14.7
71.6
14.8
21
40.8
7.5
48.6
9.1
56.4
11.2
60.5
12.3
64.6
13.5
69.7
15
71
15.2
23
40.8
7.7
48.6
9.7
56.4
12
60.5
13.2
64.6
14.5
68.6
15.7
70
15.8
25
40.8
8.2
48.6
10.4
56.4
12.8
60.5
14.2
64.6
15.5
66.7
16.4
69.1
16.5
27
40.8
8.7
48.6
11
56.4
13.7
60.5
15.1
64.6
16.6
65.6
17.1
68.1
17.2
29
40.8
9.3
48.6
11.8
56.4
14.6
60.5
16.1
64.3
17.6
64.6
17.9
67.3
17.9
31
40.8
9.9
48.6
12.6
56.4
15.6
60.5
17.3
63.2
18.3
63.7
18.5
66.2
18.6
33
40.8
10.5
48.6
13.4
56.4
16.6
60.5
18.4
62.1
19
62.7
19.2
65.1
19.4
35
40.8
11.2
48.6
14.3
56.4
17.7
60.5
19.6
61.3
19.7
64.6
19.9
64.3
20.1
37
40.8
11.9
48.6
15.2
56.4
18.9
59.4
20.3
60.2
20.4
61.9
20.6
63.2
20.8
39
40.8
12.6
48.6
16.1
56.4
20.1
58.6
21
59.1
21.1
60.8
21.3
62.1
21.5
42
40.8
13.3
48.6
17.1
56.4
21.3
57.6
21.7
58.1
21.8
58.6
22
61
22.2
44
40.8
14.1
48.6
18
56.4
22.5
56.7
22.4
57
22.5
56.7
22.7
60
22.9
46
40.8
14.9
48.6
18.8
56.4
23.7
55.8
23.1
55.9
23.2
54.8
23.4
59.5
23.6
10
36.7
6.1
43.8
7.3
50.8
8.6
54.6
9.3
58.1
10
65.1
11.4
72.1
12.9
12
36.7
6.1
43.8
7.4
50.8
8.8
54.6
9.5
58.1
10.2
65.1
11.6
72.1
13.1
14
36.7
6.3
43.8
7.6
50.8
8.9
54.6
9.7
58.1
10.4
65.1
11.9
72.1
13.4
16
36.7
6.4
43.8
7.7
50.8
9.1
54.6
9.8
58.1
10.6
65.1
12.1
72.1
13.6
18
36.7
6.5
43.8
7.9
50.8
9.3
54.6
10
58.1
10.8
65.1
12.3
71
14
20
36.7
6.6
43.8
8
50.8
9.5
54.6
10.2
58.1
11.2
65.1
13.3
70
14.7
21
36.7
6.7
43.8
8.1
50.8
9.6
54.6
10.6
58.1
11.6
65.1
13.7
69.7
15
23
36.7
6.8
43.8
8.4
50.8
10.3
54.6
11.3
58.1
12.4
65.1
14.7
68.6
15.7
25
36.7
7.2
43.8
9
50.8
11
54.6
12.1
58.1
13.3
65.1
15.8
67.5
16.4
27
36.7
7.6
43.8
9.6
50.8
11.8
54.6
13
58.1
14.2
65.1
16.8
66.7
17.1
29
36.7
8.1
43.8
10.2
50.8
12.5
54.6
13.8
58.1
15.2
64.3
17.6
65.6
17.8
31
36.7
8.6
43.8
10.9
50.8
13.4
54.6
14.8
58.1
16.2
63.2
18.3
64.6
18.5
33
36.7
9.1
43.8
11.6
50.8
14.3
54.6
15.7
58.1
17.3
62.4
19
63.7
19.2
35
36.7
9.7
43.8
12.3
50.8
15.2
54.6
16.8
58.1
18.4
61.3
19.7
62.7
19.9
37
36.7
10.3
43.8
13.1
50.8
16.2
54.6
17.9
58.1
19.6
60.5
20.4
61.6
20.6
39
36.7
10.9
43.8
13.9
50.8
17.2
54.6
19
58.1
20.9
59.4
21.1
60.8
21.3
42
36.7
11.5
43.8
14.7
50.8
18.2
54.6
20.1
58.1
22.1
58.5
21.8
59.8
22
44
36.7
12.1
43.8
15.5
50.8
19.2
54.6
21.3
58.1
23.4
57.6
22.5
58.8
22.7
46
36.7
12.7
43.8
16.3
50.8
20.2
54.6
22.4
58.1
24.6
56.7
23.2
57.9
23.4
10
32.7
5.4
38.9
6.4
45.4
7.6
48.3
8.1
51.6
8.7
57.8
10
64
11.2
12
32.7
5.5
38.9
6.6
45.4
7.7
48.3
8.3
51.6
8.9
57.8
10.1
64
11.4
14
32.7
5.5
38.9
6.7
45.4
7.8
48.3
8.5
51.6
9.1
57.8
10.3
64
11.6
16
32.7
5.7
38.9
6.8
45.4
8
48.3
8.6
51.6
9.2
57.8
10.6
64
11.9
18
32.7
5.7
38.9
6.9
45.4
8.1
48.3
8.8
51.6
9.4
57.8
10.7
64
12.1
20
32.7
5.8
38.9
7
45.4
8.3
48.3
8.9
51.6
9.6
57.8
11.2
64
13
21
32.7
5.9
38.9
7.1
45.4
8.4
48.3
9
51.6
9.8
57.8
11.5
64
13.4
23
32.7
6
38.9
7.2
45.4
8.8
48.3
9.6
51.6
10.5
57.8
12.4
64
14.4
25
32.7
6.2
38.9
7.7
45.4
9.4
48.3
10.3
51.6
11.2
57.8
13.2
64
15.4
27
32.7
6.6
38.9
8.2
45.4
10
48.3
11
51.6
12
57.8
14.2
64
16.5
29
32.7
7
38.9
8.7
45.4
10.7
48.3
11.7
51.6
12.8
57.8
15.1
64
17.6
31
32.7
7.5
38.9
9.3
45.4
11.3
48.3
12.5
51.6
13.6
57.8
16.1
64
18.3
33
32.7
7.9
38.9
9.9
45.4
12.1
48.3
13.3
51.6
14.5
57.8
17.2
64
19
35
32.7
8.4
38.9
10.5
45.4
12.8
48.3
14.1
51.6
15.5
57.8
18.3
64
19.7
37
32.7
8.9
38.9
11.2
45.4
13.7
48.3
15.1
51.6
16.5
57.8
19.5
64
20.4
39
32.7
9.4
38.9
11.8
45.4
14.5
48.3
16
51.6
17.5
57.8
20.8
64
21.1
42
32.7
9.9
38.9
12.5
45.4
15.4
48.3
16.9
51.6
18.5
57.8
22
64
21.8
44
32.7
10.4
38.9
13.2
45.4
16.2
48.3
17.9
51.6
19.6
57.8
23.3
64
22.5
46
32.7
10.9
38.9
14
45.4
17.1
48.3
18.8
51.6
20.6
57.8
24.5
64
23.2
31
Cooling Performance - COOLING PERFORMANCE DATA – 220
Capacity
factor(%)
70%
60%
50%
32
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
28.6
4.7
34
5.6
40
6.6
42.4
7
45.1
12
28.6
4.8
34
5.7
40
6.7
42.4
7.2
45.1
14
28.6
4.9
34
5.8
40
6.8
42.4
7.3
45.1
16
28.6
4.9
34
5.9
40
6.9
42.4
7.4
45.1
18
28.6
5
34
6
40
7
42.4
7.6
20
28.6
5.1
34
6.1
40
7.2
42.4
7.7
21
28.6
5.2
34
6.2
40
7.2
42.4
23
28.6
5.2
34
6.3
40
7.4
25
28.6
5.4
34
6.5
40
27
28.6
5.7
34
6.9
40
29
28.6
6
34
7.4
31
28.6
6.4
34
33
28.6
6.7
35
28.6
37
22
24
TC
kW
PI
kW
TC
kW
PI
kW
7.5
50.5
8.6
56.2
9.6
7.7
50.5
8.7
56.2
9.8
7.8
50.5
8.9
56.2
10
7.9
50.5
9.1
56.2
10.2
45.1
8.1
50.5
9.2
56.2
10.4
45.1
8.3
50.5
9.4
56.2
10.7
7.8
45.1
8.3
50.5
9.5
56.2
11
42.4
8.1
45.1
8.7
50.5
10.2
56.2
12.2
7.9
42.4
8.6
45.1
9.3
50.5
10.9
56.2
12.7
8.4
42.4
9.1
45.1
10
50.5
11.7
56.2
13.6
40
8.9
42.4
9.7
45.1
11
50.5
12.5
56.2
14.5
7.8
40
9.5
42.4
10
45.1
11
50.5
13.3
56.2
15.4
34
8.3
40
10
42.4
11
45.1
12
50.5
14.2
56.2
16.4
7.1
34
8.8
40
11
42.4
12
45.1
13
50.5
15.1
56.2
17.5
28.6
7.6
34
9.4
40
11
42.4
13
45.1
14
50.5
16
56.2
18.7
39
28.6
8
34
9.9
40
12
42.4
13
45.1
15
50.5
17.1
56.2
19.9
42
28.6
8.4
34
11
40
13
42.4
14
45.1
15
50.5
18.1
56.2
21.1
44
28.6
8.8
34
11
40
14
42.4
15
45.1
16
50.5
19.1
56.2
22.2
46
28.6
9.3
34
12
40
14
42.4
16
45.1
17
50.5
20.1
56.2
23.4
10
24.6
4.1
29.2
4.8
34
5.6
36.2
6
38.6
6.4
43.5
7.2
48.1
8.1
12
24.6
4.2
29.2
4.9
34
5.7
36.2
6.1
38.6
6.5
43.5
7.3
48.1
8.2
14
24.6
4.2
29.2
5
34
5.8
36.2
6.2
38.6
6.6
43.5
7.5
48.1
8.4
16
24.6
4.3
29.2
5.1
34
5.9
36.2
6.3
38.6
6.7
43.5
7.6
48.1
8.5
18
24.6
4.3
29.2
5.1
34
6
36.2
6.4
38.6
6.9
43.5
7.8
48.1
8.7
20
24.6
4.4
29.2
5.2
34
6.1
36.2
6.5
38.6
7
43.5
7.9
48.1
8.9
21
24.6
4.5
29.2
5.3
34
6.1
36.2
6.6
38.6
7
43.5
8
48.1
9
23
24.6
4.5
29.2
5.4
34
6.3
36.2
6.7
38.6
7.2
43.5
8.3
48.1
9.5
25
24.6
4.6
29.2
5.5
34
6.5
36.2
7
38.6
7.6
43.5
8.9
48.1
10.2
27
24.6
4.8
29.2
5.8
34
6.9
36.2
7.5
38.6
8.1
43.5
9.4
48.1
10.9
29
24.6
5.1
29.2
6.1
34
7.3
36.2
8
38.6
8.6
43.5
10.1
48.1
11.6
31
24.6
5.4
29.2
6.5
34
7.8
36.2
8.5
38.6
9.2
43.5
10.7
48.1
12.4
33
24.6
5.7
29.2
6.9
34
8.3
36.2
9
38.6
9.8
43.5
11.4
48.1
13.2
35
24.6
6
29.2
7.3
34
8.8
36.2
9.5
38.6
10
43.5
12.1
48.1
14
37
24.6
6.3
29.2
7.8
34
9.3
36.2
10
38.6
11
43.5
12.9
48.1
14.9
39
24.6
6.7
29.2
8.2
34
9.9
36.2
11
38.6
12
43.5
13.7
48.1
15.8
42
24.6
7.1
29.2
8.6
34
10
36.2
11
38.6
12
43.5
14.5
48.1
16.7
44
24.6
7.4
29.2
9.1
34
11
36.2
12
38.6
13
43.5
15.3
48.1
17.7
46
24.6
7.8
29.2
9.5
34
12
36.2
13
38.6
14
43.5
16
48.1
18.6
10
20.4
3.5
24.3
4.1
28
4.7
30.3
5
32.1
5.3
36.2
6
40
6.6
12
20.4
3.6
24.3
4.2
28
4.8
30.3
5.1
32.1
5.4
36.2
6.1
40
6.7
14
20.4
3.6
24.3
4.2
28
4.8
30.3
5.1
32.1
5.5
36.2
6.1
40
6.9
16
20.4
3.7
24.3
4.3
28
4.9
30.3
5.2
32.1
5.6
36.2
6.3
40
7
18
20.4
3.7
24.3
4.3
28
5
30.3
5.3
32.1
5.7
36.2
6.4
40
7.1
20
20.4
3.8
24.3
4.4
28
5.1
30.3
5.4
32.1
5.8
36.2
6.5
40
7.3
21
20.4
3.8
24.3
4.5
28
5.1
30.3
5.5
32.1
5.8
36.2
6.6
40
7.3
23
20.4
3.9
24.3
4.5
28
5.2
30.3
5.5
32.1
5.9
36.2
6.7
40
7.5
25
20.4
3.9
24.3
4.6
28
5.3
30.3
5.7
32.1
6.1
36.2
7
40
8
27
20.4
4
24.3
4.8
28
5.6
30.3
6
32.1
6.5
36.2
7.5
40
8.5
9.1
29
20.4
4.2
24.3
5
28
5.9
30.3
6.4
32.1
6.9
36.2
7.9
40
31
20.4
4.5
24.3
5.3
28
6.3
30.3
6.8
32.1
7.3
36.2
8.4
40
9.7
33
20.4
4.7
24.3
5.6
28
6.7
30.3
7.2
32.1
7.8
36.2
8.9
40
10.3
35
20.4
5
24.3
6
28
7
30.3
7.6
32.1
8.2
36.2
9.5
40
10.9
37
20.4
5.2
24.3
6.3
28
7.5
30.3
8.1
32.1
8.7
36.2
10.1
40
11.6
39
20.4
5.5
24.3
6.7
28
7.9
30.3
8.5
32.1
9.2
36.2
9.7
40
12.3
42
20.4
5.8
24.3
7
28
8.3
30.3
9
32.1
9.7
36.2
10
40
13
44
20.4
6
24.3
7.4
28
8.8
30.3
9.4
32.1
10
36.2
10.1
40
13.7
46
20.4
6.3
24.3
7.7
28
9.2
30.3
9.9
32.1
11
36.2
10.2
40
14.3
Cooling Performance - COOLING PERFORMANCE DATA – 240
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
15.1
22
24
TC
kW
PI
kW
TC
kW
PI
kW
10
46.9
7.7
55.8
9.3
64.8
11
69.5
11.9
74.2
12.7
83.2
14.6
87.8
12
46.9
7.8
55.8
9.4
64.8
11.2
69.5
12.1
74.2
13
83.2
14.9
87.8
15
14
46.9
7.9
55.8
9.6
64.8
11.4
69.5
12.3
74.2
13.2
83.2
15.2
85.6
14.9
16
46.9
8
55.8
9.8
64.8
11.6
69.5
12.6
74.2
13.5
82.8
15.3
84.4
15.2
18
46.9
8.2
55.8
10
64.8
11.9
69.5
12.8
74.2
13.8
81.6
15.8
83.5
16
20
46.9
8.4
55.8
10.2
64.8
12.2
69.5
13.5
74.2
14.8
80.7
16.6
82.2
16.7
21
46.9
8.5
55.8
10.3
64.8
12.7
69.5
13.9
74.2
15.3
80
17
81.6
17.1
23
46.9
8.7
55.8
11
64.8
13.5
69.5
14.9
74.2
16.4
78.8
17.8
80.4
17.9
25
46.9
9.3
55.8
11.7
64.8
14.5
69.5
16
74.2
17.6
76.6
18.5
79.4
18.7
27
46.9
9.9
55.8
12.5
64.8
15.5
69.5
17.1
74.2
18.8
75.4
19.3
78.2
19.5
29
46.9
10.5
55.8
13.3
64.8
16.6
69.5
18.2
73.8
19.9
74.2
20.2
77.3
20.3
31
46.9
11.2
55.8
14.2
64.8
17.7
69.5
19.5
72.6
20.7
73.2
20.9
76
21.1
33
46.9
11.9
55.8
15.2
64.8
18.8
69.5
20.8
71.4
21.5
72
21.7
74.8
21.9
35
46.9
12.6
55.8
16.1
64.8
20.1
69.5
22.2
70.4
22.3
74.2
22.5
73.8
22.7
37
46.9
13.4
55.8
17.1
64.8
21.4
68.3
22.9
69.2
23.1
71.1
23.3
72.6
23.5
39
46.9
14.3
55.8
18.2
64.8
22.8
67.3
23.7
67.9
23.9
69.8
24.1
71.4
24.3
42
46.9
15.1
55.8
19.3
64.8
24.1
66.2
24.5
66.7
24.7
67.3
24.9
70.1
25.1
44
46.9
15.9
55.8
20.3
64.8
25.5
65.1
25.3
65.5
25.5
65.2
25.7
68.9
25.9
46
46.9
16.8
55.8
21.2
64.8
26.8
64.1
26.1
64.2
26.3
63
26.5
68.3
26.7
10
42.2
6.9
50.3
8.3
58.3
9.7
62.7
10.5
66.7
11.3
74.8
12.9
82.8
14.6
12
42.2
6.9
50.3
8.4
58.3
9.9
62.7
10.7
66.7
11.5
74.8
13.2
82.8
14.8
14
42.2
7.1
50.3
8.6
58.3
10.1
62.7
10.9
66.7
11.7
74.8
13.4
82.8
15.1
16
42.2
7.2
50.3
8.7
58.3
10.3
62.7
11.1
66.7
11.9
74.8
13.7
82.8
15.4
18
42.2
7.3
50.3
8.9
58.3
10.5
62.7
11.3
66.7
12.2
74.8
13.9
81.6
15.8
20
42.2
7.4
50.3
9.1
58.3
10.7
62.7
11.6
66.7
12.7
74.8
15
80.4
16.6
21
42.2
7.5
50.3
9.1
58.3
10.9
62.7
12
66.7
13.1
74.8
15.5
80
17
23
42.2
7.7
50.3
9.5
58.3
11.6
62.7
12.8
66.7
14.1
74.8
16.6
78.8
17.8
25
42.2
8.1
50.3
10.2
58.3
12.4
62.7
13.7
66.7
15
74.8
17.8
77.6
18.5
27
42.2
8.6
50.3
10.8
58.3
13.3
62.7
14.6
66.7
16
74.8
19
76.6
19.3
29
42.2
9.1
50.3
11.6
58.3
14.2
62.7
15.6
66.7
17.1
73.8
19.9
75.4
20.1
31
42.2
9.7
50.3
12.3
58.3
15.2
62.7
16.7
66.7
18.3
72.6
20.7
74.2
20.9
33
42.2
10.3
50.3
13.1
58.3
16.1
62.7
17.8
66.7
19.5
71.7
21.5
73.2
21.7
35
42.2
11
50.3
13.9
58.3
17.2
62.7
19
66.7
20.8
70.4
22.3
72
22.5
37
42.2
11.6
50.3
14.8
58.3
18.3
62.7
20.2
66.7
22.2
69.5
23.1
70.7
23.3
39
42.2
12.4
50.3
15.7
58.3
19.5
62.7
21.5
66.7
23.6
68.3
23.9
69.8
24.1
42
42.2
13
50.3
16.6
58.3
20.6
62.7
22.8
66.7
25
67.2
24.6
68.7
24.9
44
42.2
13.7
50.3
17.5
58.3
21.7
62.7
24
66.7
26.4
66.1
25.4
67.6
25.7
26.5
46
42.2
14.4
50.3
18.4
58.3
22.9
62.7
25.3
66.7
27.8
65.1
26.2
66.5
10
37.5
6.1
44.7
7.3
52.1
8.6
55.5
9.2
59.3
9.9
66.4
11.3
73.5
12.7
12
37.5
6.2
44.7
7.4
52.1
8.7
55.5
9.4
59.3
10.1
66.4
11.5
73.5
12.9
14
37.5
6.3
44.7
7.5
52.1
8.8
55.5
9.6
59.3
10.2
66.4
11.7
73.5
13.2
16
37.5
6.4
44.7
7.7
52.1
9
55.5
9.7
59.3
10.5
66.4
11.9
73.5
13.4
18
37.5
6.5
44.7
7.8
52.1
9.2
55.5
9.9
59.3
10.7
66.4
12.1
73.5
13.7
20
37.5
6.6
44.7
8
52.1
9.4
55.5
10.1
59.3
10.9
66.4
12.6
73.5
14.6
21
37.5
6.6
44.7
8
52.1
9.5
55.5
10.2
59.3
11.1
66.4
13
73.5
15.2
23
37.5
6.8
44.7
8.2
52.1
9.9
55.5
10.9
59.3
11.9
66.4
14
73.5
16.3
25
37.5
7
44.7
8.7
52.1
10.6
55.5
11.6
59.3
12.7
66.4
14.9
73.5
17.4
27
37.5
7.4
44.7
9.3
52.1
11.3
55.5
12.4
59.3
13.5
66.4
16
73.5
18.7
29
37.5
7.9
44.7
9.9
52.1
12.1
55.5
13.2
59.3
14.4
66.4
17.1
73.5
19.9
31
37.5
8.4
44.7
10.5
52.1
12.8
55.5
14.1
59.3
15.4
66.4
18.2
73.5
20.7
33
37.5
8.9
44.7
11.2
52.1
13.7
55.5
15
59.3
16.4
66.4
19.4
73.5
21.5
35
37.5
9.5
44.7
11.9
52.1
14.5
55.5
16
59.3
17.5
66.4
20.7
73.5
22.3
37
37.5
10
44.7
12.6
52.1
15.4
55.5
17
59.3
18.6
66.4
22.1
73.5
23.1
39
37.5
10.6
44.7
13.4
52.1
16.4
55.5
18.1
59.3
19.8
66.4
23.5
73.5
23.8
42
37.5
11.2
44.7
14.1
52.1
17.4
55.5
19.1
59.3
21
66.4
24.9
73.5
24.6
44
37.5
11.8
44.7
14.9
52.1
18.3
55.5
20.2
59.3
22.1
66.4
26.3
73.5
25.4
46
37.5
12.3
44.7
15.8
52.1
19.3
55.5
21.2
59.3
23.3
66.4
27.7
73.5
26.2
33
Cooling Performance - COOLING PERFORMANCE DATA – 240
Capacity
factor(%)
70%
60%
50%
34
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
32.9
5.3
39.1
6.3
46
7.4
48.7
8
51.8
8.5
58
12
32.9
5.4
39.1
6.4
46
7.5
48.7
8.1
51.8
8.7
58
9.7
64.5
10.9
9.9
64.5
14
32.9
5.5
39.1
6.6
46
7.7
48.7
8.3
51.8
8.8
58
10
64.5
11.1
11.3
16
32.9
5.6
39.1
6.6
46
7.8
48.7
8.4
51.8
9
58
10.2
64.5
11.5
18
32.9
5.7
39.1
6.8
46
8
48.7
8.6
51.8
9.1
58
10.4
64.5
11.7
20
32.9
5.8
39.1
6.9
46
8.1
48.7
8.7
51.8
9.4
58
10.6
64.5
12.1
21
32.9
5.8
39.1
7
46
8.2
48.7
8.8
51.8
9.4
58
10.8
64.5
12.5
23
32.9
5.9
39.1
7.1
46
8.3
48.7
9.1
51.8
9.9
58
11.6
64.5
13.8
25
32.9
6.1
39.1
7.4
46
8.9
48.7
9.7
51.8
11
58
12.4
64.5
14.3
27
32.9
6.4
39.1
7.8
46
9.5
48.7
10
51.8
11
58
13.2
64.5
15.3
29
32.9
6.8
39.1
8.3
46
10
48.7
11
51.8
12
58
14.1
64.5
16.3
31
32.9
7.2
39.1
8.8
46
11
48.7
12
51.8
13
58
15
64.5
17.4
33
32.9
7.6
39.1
9.4
46
11
48.7
13
51.8
14
58
16
64.5
18.6
35
32.9
8
39.1
10
46
12
48.7
13
51.8
15
58
17
64.5
19.8
37
32.9
8.6
39.1
11
46
13
48.7
14
51.8
15
58
18.1
64.5
21.1
39
32.9
9
39.1
11
46
14
48.7
15
51.8
16
58
19.3
64.5
22.5
42
32.9
9.5
39.1
12
46
14
48.7
16
51.8
17
58
20.4
64.5
23.8
44
32.9
10
39.1
12
46
15
48.7
17
51.8
18
58
21.6
64.5
25.1
46
32.9
11
39.1
13
46
16
48.7
18
51.8
19
58
22.7
64.5
26.5
10
28.2
4.7
33.5
5.5
39
6.3
41.6
6.8
44.4
7.2
50
8.2
55.2
9.1
12
28.2
4.7
33.5
5.5
39
6.4
41.6
6.9
44.4
7.3
50
8.3
55.2
9.3
14
28.2
4.8
33.5
5.6
39
6.5
41.6
7
44.4
7.4
50
8.5
55.2
9.5
16
28.2
4.9
33.5
5.7
39
6.6
41.6
7.1
44.4
7.6
50
8.6
55.2
9.7
18
28.2
4.9
33.5
5.8
39
6.7
41.6
7.2
44.4
7.7
50
8.8
55.2
9.9
20
28.2
5
33.5
5.9
39
6.9
41.6
7.4
44.4
7.9
50
8.9
55.2
10
21
28.2
5
33.5
6
39
6.9
41.6
7.4
44.4
8
50
9
55.2
10.2
23
28.2
5.1
33.5
6.1
39
7.1
41.6
7.6
44.4
8.1
50
9.4
55.2
10.8
25
28.2
5.2
33.5
6.2
39
7.3
41.6
8
44.4
8.6
50
10
55.2
11.5
27
28.2
5.4
33.5
6.6
39
7.8
41.6
8.5
44.4
9.2
50
10.7
55.2
12.3
29
28.2
5.7
33.5
6.9
39
8.3
41.6
9
44.4
9.8
50
11.4
55.2
13.1
31
28.2
6.1
33.5
7.4
39
8.8
41.6
9.6
44.4
10
50
12.1
55.2
14
33
28.2
6.4
33.5
7.8
39
9.4
41.6
10
44.4
11
50
12.9
55.2
14.9
35
28.2
6.8
33.5
8.3
39
9.9
41.6
11
44.4
12
50
13.7
55.2
15.8
37
28.2
7.2
33.5
8.8
39
11
41.6
12
44.4
12
50
14.6
55.2
16.8
39
28.2
7.6
33.5
9.3
39
11
41.6
12
44.4
13
50
15.5
55.2
17.9
42
28.2
8
33.5
9.8
39
12
41.6
13
44.4
14
50
16.4
55.2
18.9
44
28.2
8.4
33.5
10
39
12
41.6
14
44.4
15
50
17.3
55.2
20
46
28.2
8.8
33.5
11
39
13
41.6
14
44.4
16
50
18.1
55.2
21
10
23.5
4
27.9
4.6
33
5.3
34.8
5.6
36.9
6
41.6
6.7
45.9
7.5
12
23.5
4.1
27.9
4.7
33
5.4
34.8
5.7
36.9
6.1
41.6
6.9
45.9
7.6
14
23.5
4.1
27.9
4.7
33
5.5
34.8
5.8
36.9
6.2
41.6
6.9
45.9
7.7
16
23.5
4.1
27.9
4.8
33
5.5
34.8
5.9
36.9
6.3
41.6
7.1
45.9
7.9
18
23.5
4.2
27.9
4.9
33
5.6
34.8
6
36.9
6.4
41.6
7.2
45.9
8
20
23.5
4.3
27.9
5
33
5.7
34.8
6.1
36.9
6.5
41.6
7.3
45.9
8.2
21
23.5
4.3
27.9
5
33
5.8
34.8
6.2
36.9
6.6
41.6
7.4
45.9
8.3
23
23.5
4.4
27.9
5.1
33
5.9
34.8
6.3
36.9
6.7
41.6
7.5
45.9
8.5
25
23.5
4.4
27.9
5.2
33
6
34.8
6.4
36.9
6.9
41.6
7.9
45.9
9
27
23.5
4.5
27.9
5.4
33
6.3
34.8
6.8
36.9
7.3
41.6
8.4
45.9
9.6
29
23.5
4.8
27.9
5.7
33
6.7
34.8
7.2
36.9
7.8
41.6
9
45.9
10.2
31
23.5
5
27.9
6
33
7.1
34.8
7.7
36.9
8.3
41.6
9.5
45.9
10.9
33
23.5
5.3
27.9
6.3
33
7.5
34.8
8.1
36.9
8.8
41.6
10.1
45.9
11.6
35
23.5
5.6
27.9
6.7
33
8
34.8
8.6
36.9
9.3
41.6
10.8
45.9
12.3
37
23.5
5.9
27.9
7.1
33
8.4
34.8
9.1
36.9
9.9
41.6
11.4
45.9
13.1
39
23.5
6.2
27.9
7.5
33
8.9
34.8
9.7
36.9
11
41.6
11
45.9
13.9
42
23.5
6.5
27.9
7.9
33
9.4
34.8
10
36.9
11
41.6
11.3
45.9
14.7
44
23.5
6.8
27.9
8.3
33
9.9
34.8
11
36.9
12
41.6
11.4
45.9
15.4
46
23.5
7.1
27.9
8.7
33
10
34.8
11
36.9
13
41.6
11.6
45.9
16.2
Cooling Performance - COOLING PERFORMANCE DATA – 260
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
50.2
8.9
59.9
10.8
69.5
12.7
74.5
13.8
79.5
14.8
89.1
16.9
94.1
12
50.2
9
59.9
11
69.5
13
74.5
14.1
79.5
15.1
89.1
17.3
94.1
17.5
14
50.2
9.2
59.9
11.2
69.5
13.2
74.5
14.3
79.5
15.4
89.1
17.6
91.8
17.4
16
50.2
9.3
59.9
11.4
69.5
13.5
74.5
14.6
79.5
15.7
88.8
17.8
90.5
17.6
18
50.2
9.5
59.9
11.6
69.5
13.8
74.5
14.9
79.5
16
87.5
18.4
89.5
18.5
20
50.2
9.7
59.9
11.8
69.5
14.2
74.5
15.6
79.5
17.2
86.5
19.3
88.1
19.4
21
50.2
9.8
59.9
11.9
69.5
14.7
74.5
16.2
79.5
17.7
85.8
19.7
87.5
19.9
23
50.2
10.1
59.9
12.7
69.5
15.7
74.5
17.4
79.5
19
84.5
20.6
86.1
20.8
25
50.2
10.8
59.9
13.6
69.5
16.8
74.5
18.6
79.5
20.4
82.1
21.5
85.1
21.7
27
50.2
11.5
59.9
14.5
69.5
18
74.5
19.9
79.5
21.8
80.8
22.4
83.8
22.6
29
50.2
12.2
59.9
15.5
69.5
19.2
74.5
21.2
79.2
23.2
79.5
23.4
82.8
23.5
31
50.2
13
59.9
16.5
69.5
20.5
74.5
22.7
77.8
24
78.5
24.3
81.5
24.5
33
50.2
13.8
59.9
17.6
69.5
21.8
74.5
24.1
76.5
25
77.2
25.2
80.2
25.4
35
50.2
14.6
59.9
18.7
69.5
23.3
74.5
25.8
75.5
25.9
79.5
26.1
79.2
26.3
37
50.2
15.6
59.9
19.9
69.5
24.8
73.2
26.6
74.2
26.8
76.2
27
77.8
27.3
39
50.2
16.6
59.9
21.2
69.5
26.4
72.2
27.6
72.8
27.7
74.8
28
76.5
28.2
42
50.2
17.5
59.9
22.4
69.5
28
71
28.5
71.5
28.7
72.2
28.9
75.2
29.2
44
50.2
18.5
59.9
23.6
69.5
29.6
69.8
29.4
70.2
29.6
69.8
29.8
73.8
30.1
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
17.6
46
50.2
19.5
59.9
24.7
69.5
31.1
68.7
30.3
68.8
30.5
67.5
30.8
73.2
31
10
45.2
8
53.9
9.6
62.5
11.3
67.2
12.2
71.5
13.1
80.2
15
88.8
16.9
12
45.2
8.1
53.9
9.7
62.5
11.5
67.2
12.4
71.5
13.4
80.2
15.3
88.8
17.2
14
45.2
8.2
53.9
9.9
62.5
11.7
67.2
12.7
71.5
13.6
80.2
15.6
88.8
17.6
16
45.2
8.4
53.9
10.1
62.5
11.9
67.2
12.9
71.5
13.9
80.2
15.9
88.8
17.8
18
45.2
8.5
53.9
10.3
62.5
12.2
67.2
13.2
71.5
14.2
80.2
16.2
87.5
18.4
20
45.2
8.7
53.9
10.5
62.5
12.4
67.2
13.4
71.5
14.7
80.2
17.4
86.1
19.3
21
45.2
8.8
53.9
10.6
62.5
12.6
67.2
13.9
71.5
15.2
80.2
18
85.8
19.7
23
45.2
8.9
53.9
11.1
62.5
13.5
67.2
14.9
71.5
16.3
80.2
19.3
84.5
20.6
25
45.2
9.4
53.9
11.8
62.5
14.5
67.2
15.9
71.5
17.5
80.2
20.7
83.1
21.5
27
45.2
10
53.9
12.6
62.5
15.4
67.2
17
71.5
18.6
80.2
22.1
82.1
22.4
29
45.2
10.6
53.9
13.4
62.5
16.5
67.2
18.1
71.5
19.9
79.2
23.2
80.8
23.4
31
45.2
11.3
53.9
14.3
62.5
17.6
67.2
19.4
71.5
21.2
77.8
24.1
79.5
24.2
33
45.2
12
53.9
15.2
62.5
18.7
67.2
20.6
71.5
22.7
76.8
25
78.5
25.2
35
45.2
12.8
53.9
16.1
62.5
20
67.2
22
71.5
24.2
75.5
25.9
77.2
26.1
37
45.2
13.5
53.9
17.2
62.5
21.2
67.2
23.4
71.5
25.8
74.5
26.8
75.8
27
39
45.2
14.4
53.9
18.2
62.5
22.6
67.2
25
71.5
27.4
73.2
27.7
74.8
28
42
45.2
15.1
53.9
19.3
62.5
23.9
67.2
26.4
71.5
29
72.1
28.6
73.6
28.9
44
45.2
15.9
53.9
20.3
62.5
25.3
67.2
27.9
71.5
30.7
70.9
29.5
72.4
29.8
46
45.2
16.7
53.9
21.4
62.5
26.6
67.2
29.4
71.5
32.3
69.8
30.5
71.3
30.8
10
40.2
7
47.9
8.5
55.9
9.9
59.5
10.7
63.5
11.5
71.2
13.1
78.8
14.7
12
40.2
7.2
47.9
8.6
55.9
10.1
59.5
10.9
63.5
11.7
71.2
13.3
78.8
15
14
40.2
7.3
47.9
8.8
55.9
10.3
59.5
11.1
63.5
11.9
71.2
13.6
78.8
15.3
16
40.2
7.4
47.9
8.9
55.9
10.5
59.5
11.3
63.5
12.1
71.2
13.9
78.8
15.6
18
40.2
7.5
47.9
9
55.9
10.7
59.5
11.5
63.5
12.4
71.2
14.1
78.8
15.9
20
40.2
7.7
47.9
9.2
55.9
10.9
59.5
11.7
63.5
12.6
71.2
14.6
78.8
17
21
40.2
7.7
47.9
9.3
55.9
11
59.5
11.8
63.5
12.9
71.2
15.1
78.8
17.6
23
40.2
7.9
47.9
9.5
55.9
11.5
59.5
12.6
63.5
13.8
71.2
16.2
78.8
18.9
25
40.2
8.2
47.9
10.1
55.9
12.3
59.5
13.5
63.5
14.7
71.2
17.4
78.8
20.3
27
40.2
8.7
47.9
10.8
55.9
13.1
59.5
14.4
63.5
15.7
71.2
18.6
78.8
21.7
29
40.2
9.2
47.9
11.5
55.9
14
59.5
15.3
63.5
16.8
71.2
19.9
78.8
23.2
31
40.2
9.8
47.9
12.2
55.9
14.9
59.5
16.4
63.5
17.9
71.2
21.2
78.8
24
33
40.2
10.4
47.9
13
55.9
15.9
59.5
17.5
63.5
19.1
71.2
22.6
78.8
25
35
40.2
11
47.9
13.8
55.9
16.9
59.5
18.5
63.5
20.3
71.2
24.1
78.8
25.9
37
40.2
11.7
47.9
14.6
55.9
17.9
59.5
19.8
63.5
21.6
71.2
25.7
78.8
26.8
39
40.2
12.3
47.9
15.5
55.9
19.1
59.5
21
63.5
23
71.2
27.3
78.8
27.7
42
40.2
13
47.9
16.4
55.9
20.2
59.5
22.2
63.5
24.4
71.2
28.9
78.8
28.6
44
40.2
13.7
47.9
17.3
55.9
21.3
59.5
23.4
63.5
25.7
71.2
30.6
78.8
29.5
46
40.2
14.3
47.9
18.3
55.9
22.4
59.5
24.7
63.5
27.1
71.2
32.2
78.8
30.4
35
Cooling Performance - COOLING PERFORMANCE DATA – 260
Capacity
factor(%)
70%
60%
50%
36
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
35.3
6.2
41.9
7.4
49
8.6
52.2
9.2
55.5
12
35.3
6.3
41.9
7.5
49
8.8
52.2
9.4
55.5
14
35.3
6.4
41.9
7.6
49
8.9
52.2
9.6
16
35.3
6.5
41.9
7.7
49
9
52.2
18
35.3
6.6
41.9
7.9
49
9.2
20
35.3
6.7
41.9
8
49
21
35.3
6.8
41.9
8.1
23
35.3
6.9
41.9
25
35.3
7
41.9
27
35.3
7.4
29
35.3
7.9
31
35.3
33
35
22
24
TC
kW
PI
kW
TC
kW
PI
kW
9.9
62.2
11.3
69.2
12.6
10
62.2
11.5
69.2
12.9
55.5
10
62.2
11.7
69.2
13.1
9.7
55.5
10
62.2
11.9
69.2
13.4
52.2
9.9
55.5
11
62.2
12.1
69.2
13.6
9.4
52.2
10
55.5
11
62.2
12.3
69.2
14
49
9.5
52.2
10
55.5
11
62.2
12.5
69.2
14.5
8.3
49
9.7
52.2
11
55.5
12
62.2
13.4
69.2
16
8.6
49
10
52.2
11
55.5
12
62.2
14.4
69.2
16.6
41.9
9.1
49
11
52.2
12
55.5
13
62.2
15.3
69.2
17.8
41.9
9.7
49
12
52.2
13
55.5
14
62.2
16.4
69.2
19
8.4
41.9
10
49
12
52.2
14
55.5
15
62.2
17.5
69.2
20.3
35.3
8.8
41.9
11
49
13
52.2
15
55.5
16
62.2
18.6
69.2
21.6
35.3
9.3
41.9
12
49
14
52.2
15
55.5
17
62.2
19.8
69.2
23
37
35.3
9.9
41.9
12
49
15
52.2
16
55.5
18
62.2
21
69.2
24.5
39
35.3
11
41.9
13
49
16
52.2
17
55.5
19
62.2
22.4
69.2
26.1
42
35.3
11
41.9
14
49
17
52.2
18
55.5
20
62.2
23.7
69.2
27.6
44
35.3
12
41.9
14
49
18
52.2
19
55.5
21
62.2
25.1
69.2
29.2
46
35.3
12
41.9
15
49
19
52.2
20
55.5
22
62.2
26.4
69.2
30.7
10
30.3
5.4
35.9
6.3
42
7.3
44.6
7.9
47.6
8.4
53.5
9.5
59.2
10.6
12
30.3
5.5
35.9
6.4
42
7.4
44.6
8
47.6
8.5
53.5
9.6
59.2
10.8
14
30.3
5.6
35.9
6.5
42
7.6
44.6
8.1
47.6
8.7
53.5
9.8
59.2
11
16
30.3
5.7
35.9
6.6
42
7.7
44.6
8.3
47.6
8.8
53.5
10
59.2
11.2
18
30.3
5.7
35.9
6.7
42
7.8
44.6
8.4
47.6
9
53.5
10.2
59.2
11.5
20
30.3
5.8
35.9
6.9
42
8
44.6
8.6
47.6
9.1
53.5
10.4
59.2
11.7
21
30.3
5.9
35.9
6.9
42
8.1
44.6
8.7
47.6
9.2
53.5
10.5
59.2
11.8
23
30.3
5.9
35.9
7
42
8.2
44.6
8.8
47.6
9.4
53.5
10.9
59.2
12.5
25
30.3
6
35.9
7.2
42
8.5
44.6
9.2
47.6
10
53.5
11.7
59.2
13.4
27
30.3
6.3
35.9
7.6
42
9
44.6
9.8
47.6
11
53.5
12.4
59.2
14.3
29
30.3
6.6
35.9
8.1
42
9.6
44.6
11
47.6
11
53.5
13.2
59.2
15.2
31
30.3
7
35.9
8.6
42
10
44.6
11
47.6
12
53.5
14.1
59.2
16.2
33
30.3
7.4
35.9
9.1
42
11
44.6
12
47.6
13
53.5
15
59.2
17.3
35
30.3
7.9
35.9
9.6
42
12
44.6
13
47.6
14
53.5
15.9
59.2
18.4
37
30.3
8.3
35.9
10
42
12
44.6
13
47.6
15
53.5
16.9
59.2
19.6
39
30.3
8.8
35.9
11
42
13
44.6
14
47.6
15
53.5
18
59.2
20.8
42
30.3
9.3
35.9
11
42
14
44.6
15
47.6
16
53.5
19
59.2
22
44
30.3
9.7
35.9
12
42
14
44.6
16
47.6
17
53.5
20
59.2
23.2
46
30.3
10
35.9
13
42
15
44.6
17
47.6
18
53.5
21.1
59.2
24.4
10
25.1
4.6
29.9
5.4
35
6.1
37.3
6.5
39.6
7
44.6
7.8
49.2
8.7
12
25.1
4.7
29.9
5.5
35
6.2
37.3
6.6
39.6
7.1
44.6
8
49.2
8.8
14
25.1
4.8
29.9
5.5
35
6.3
37.3
6.7
39.6
7.2
44.6
8.1
49.2
9
16
25.1
4.8
29.9
5.6
35
6.4
37.3
6.9
39.6
7.3
44.6
8.2
49.2
9.2
18
25.1
4.9
29.9
5.7
35
6.5
37.3
7
39.6
7.4
44.6
8.4
49.2
9.3
20
25.1
5
29.9
5.8
35
6.6
37.3
7.1
39.6
7.6
44.6
8.5
49.2
9.5
21
25.1
5
29.9
5.9
35
6.7
37.3
7.2
39.6
7.6
44.6
8.6
49.2
9.6
23
25.1
5.1
29.9
5.9
35
6.8
37.3
7.3
39.6
7.8
44.6
8.8
49.2
9.8
25
25.1
5.2
29.9
6
35
6.9
37.3
7.4
39.6
8
44.6
9.2
49.2
10.5
27
25.1
5.2
29.9
6.2
35
7.3
37.3
7.9
39.6
8.5
44.6
9.8
49.2
11.2
29
25.1
5.6
29.9
6.6
35
7.8
37.3
8.4
39.6
9
44.6
10.4
49.2
11.9
31
25.1
5.9
29.9
7
35
8.3
37.3
8.9
39.6
9.6
44.6
11.1
49.2
12.7
33
25.1
6.2
29.9
7.4
35
8.8
37.3
9.4
39.6
10
44.6
11.7
49.2
13.5
35
25.1
6.5
29.9
7.8
35
9.2
37.3
10
39.6
11
44.6
12.5
49.2
14.3
37
25.1
6.9
29.9
8.3
35
9.8
37.3
11
39.6
12
44.6
13.3
49.2
15.2
39
25.1
7.2
29.9
8.8
35
10
37.3
11
39.6
12
44.6
12.8
49.2
16.1
42
25.1
7.6
29.9
9.2
35
11
37.3
12
39.6
13
44.6
13.1
49.2
17
44
25.1
7.9
29.9
9.7
35
12
37.3
12
39.6
14
44.6
13.3
49.2
17.9
46
25.1
8.2
29.9
10
35
12
37.3
13
39.6
15
44.6
13.4
49.2
18.8
Cooling Performance - COOLING PERFORMANCE DATA – 280
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
52.6
9.1
62.7
11
72.8
13
78
14.1
83.2
15.1
93.3
17.3
98.5
17.9
12
52.6
9.2
62.7
11.2
72.8
13.3
78
14.4
83.2
15.4
93.3
17.6
98.5
17.8
14
52.6
9.4
62.7
11.4
72.8
13.5
78
14.6
83.2
15.7
93.3
18
96.1
17.7
16
52.6
9.6
62.7
11.6
72.8
13.8
78
14.9
83.2
16
93
18.2
94.7
18
18
52.6
9.8
62.7
11.9
72.8
14.1
78
15.2
83.2
16.3
91.6
18.8
93.7
19
20
52.6
10
62.7
12.1
72.8
14.5
78
16
83.2
17.5
90.5
19.7
92.3
19.9
21
52.6
10.1
62.7
12.2
72.8
15
78
16.5
83.2
18.1
89.8
20.2
91.6
20.4
23
52.6
10.3
62.7
13
72.8
16.1
78
17.7
83.2
19.5
88.4
21.1
90.2
21.3
25
52.6
11
62.7
13.9
72.8
17.2
78
19
83.2
20.9
86
22
89.1
22.2
27
52.6
11.7
62.7
14.8
72.8
18.4
78
20.3
83.2
22.3
84.6
22.9
87.8
23.1
29
52.6
12.5
62.7
15.8
72.8
19.7
78
21.7
82.9
23.7
83.2
24
86.7
24.1
31
52.6
13.3
62.7
16.9
72.8
21
78
23.2
81.5
24.6
82.2
24.8
85.3
25
33
52.6
14.1
62.7
18
72.8
22.3
78
24.7
80.1
25.5
80.8
25.7
83.9
26
35
52.6
15
62.7
19.2
72.8
23.8
78
26.3
79
26.4
83.2
26.7
82.9
26.9
37
52.6
15.9
62.7
20.4
72.8
25.4
76.6
27.2
77.7
27.4
79.7
27.6
81.5
27.9
39
52.6
16.9
62.7
21.7
72.8
27
75.6
28.2
76.3
28.4
78.3
28.6
80.1
28.9
42
52.6
17.9
62.7
22.9
72.8
28.6
74.3
29.1
74.9
29.3
75.6
29.6
78.7
29.8
44
52.6
18.9
62.7
24.2
72.8
30.2
73.1
30.1
73.5
30.3
73.1
30.5
77.3
30.8
46
52.6
19.9
62.7
25.2
72.8
31.9
71.9
31
72.1
31.2
70.7
31.5
76.7
31.7
10
47.4
8.1
56.4
9.8
65.5
11.6
70.3
12.5
74.9
13.4
83.9
15.3
93
17.3
12
47.4
8.2
56.4
10
65.5
11.8
70.3
12.7
74.9
13.7
83.9
15.6
93
17.6
14
47.4
8.4
56.4
10.2
65.5
12
70.3
13
74.9
13.9
83.9
15.9
93
17.9
16
47.4
8.5
56.4
10.4
65.5
12.2
70.3
13.2
74.9
14.2
83.9
16.2
93
18.2
18
47.4
8.7
56.4
10.6
65.5
12.5
70.3
13.5
74.9
14.5
83.9
16.5
91.6
18.8
20
47.4
8.8
56.4
10.8
65.5
12.7
70.3
13.7
74.9
15
83.9
17.8
90.2
19.7
21
47.4
8.9
56.4
10.9
65.5
12.9
70.3
14.2
74.9
15.5
83.9
18.4
89.8
20.2
23
47.4
9.1
56.4
11.3
65.5
13.8
70.3
15.2
74.9
16.7
83.9
19.8
88.4
21.1
25
47.4
9.6
56.4
12.1
65.5
14.8
70.3
16.3
74.9
17.8
83.9
21.2
87.1
22
27
47.4
10.2
56.4
12.9
65.5
15.8
70.3
17.4
74.9
19.1
83.9
22.6
86
22.9
29
47.4
10.9
56.4
13.7
65.5
16.8
70.3
18.5
74.9
20.4
82.9
23.7
84.6
23.9
31
47.4
11.6
56.4
14.6
65.5
18
70.3
19.8
74.9
21.7
81.5
24.6
83.2
24.8
33
47.4
12.3
56.4
15.5
65.5
19.2
70.3
21.1
74.9
23.2
80.4
25.5
82.2
25.7
35
47.4
13.1
56.4
16.5
65.5
20.4
70.3
22.5
74.9
24.7
79
26.5
80.8
26.7
37
47.4
13.8
56.4
17.5
65.5
21.7
70.3
24
74.9
26.3
78
27.4
79.4
27.6
39
47.4
14.7
56.4
18.6
65.5
23.1
70.3
25.5
74.9
28
76.6
28.4
78.3
28.6
42
47.4
15.5
56.4
19.7
65.5
24.5
70.3
27
74.9
29.7
75.4
29.3
77.1
29.6
44
47.4
16.3
56.4
20.8
65.5
25.8
70.3
28.5
74.9
31.3
74.2
30.2
75.9
30.5
46
47.4
17.1
56.4
21.9
65.5
27.2
70.3
30
74.9
33
73.1
31.2
74.6
31.5
10
42.1
7.2
50.1
8.6
58.5
10.2
62.3
10.9
66.5
11.7
74.5
13.4
82.5
15.1
12
42.1
7.3
50.1
8.8
58.5
10.3
62.3
11.1
66.5
12
74.5
13.6
82.5
15.3
14
42.1
7.4
50.1
8.9
58.5
10.5
62.3
11.4
66.5
12.2
74.5
13.9
82.5
15.6
16
42.1
7.6
50.1
9.1
58.5
10.7
62.3
11.6
66.5
12.4
74.5
14.2
82.5
15.9
18
42.1
7.7
50.1
9.2
58.5
10.9
62.3
11.8
66.5
12.7
74.5
14.4
82.5
16.3
20
42.1
7.8
50.1
9.5
58.5
11.1
62.3
12
66.5
12.9
74.5
15
82.5
17.4
21
42.1
7.9
50.1
9.6
58.5
11.3
62.3
12.1
66.5
13.2
74.5
15.5
82.5
18
23
42.1
8
50.1
9.7
58.5
11.8
62.3
12.9
66.5
14.1
74.5
16.6
82.5
19.4
25
42.1
8.3
50.1
10.4
58.5
12.6
62.3
13.8
66.5
15.1
74.5
17.7
82.5
20.7
27
42.1
8.8
50.1
11
58.5
13.4
62.3
14.7
66.5
16.1
74.5
19
82.5
22.2
29
42.1
9.4
50.1
11.7
58.5
14.3
62.3
15.7
66.5
17.1
74.5
20.3
82.5
23.7
31
42.1
10
50.1
12.5
58.5
15.2
62.3
16.7
66.5
18.3
74.5
21.7
82.5
24.6
33
42.1
10.6
50.1
13.3
58.5
16.2
62.3
17.8
66.5
19.5
74.5
23.1
82.5
25.5
35
42.1
11.3
50.1
14.1
58.5
17.2
62.3
19
66.5
20.8
74.5
24.6
82.5
26.4
37
42.1
11.9
50.1
15
58.5
18.3
62.3
20.2
66.5
22.1
74.5
26.2
82.5
27.4
39
42.1
12.6
50.1
15.9
58.5
19.5
62.3
21.5
66.5
23.5
74.5
27.9
82.5
28.3
42
42.1
13.3
50.1
16.8
58.5
20.6
62.3
22.7
66.5
24.9
74.5
29.6
82.5
29.2
44
42.1
14
50.1
17.7
58.5
21.8
62.3
24
66.5
26.3
74.5
31.2
82.5
30.2
46
42.1
14.7
50.1
18.7
58.5
22.9
62.3
25.2
66.5
27.7
74.5
32.9
82.5
31.1
37
Cooling Performance - COOLING PERFORMANCE DATA – 280
Capacity
factor(%)
70%
60%
50%
38
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
24
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
36.9
6.3
43.9
7.5
51
8.8
54.7
9.5
58.2
12
36.9
6.4
43.9
7.6
51
8.9
54.7
9.6
58.2
10
65.1
11.5
72.4
12.9
10
65.1
11.7
72.4
14
36.9
6.5
43.9
7.8
51
9.1
54.7
9.8
13.2
58.2
11
65.1
11.9
72.4
13.4
16
36.9
6.6
43.9
7.9
51
9.2
54.7
18
36.9
6.7
43.9
8
51
9.5
54.7
10
58.2
11
65.1
12.2
72.4
13.7
10
58.2
11
65.1
12.4
72.4
20
36.9
6.9
43.9
8.2
51
9.6
13.9
54.7
10
58.2
11
65.1
12.6
72.4
14.3
21
36.9
6.9
43.9
8.3
51
23
36.9
7
43.9
8.4
51
9.7
54.7
11
58.2
11
65.1
12.8
72.4
14.8
9.9
54.7
11
58.2
12
65.1
13.7
72.4
25
36.9
7.2
43.9
8.7
16.4
51
11
54.7
12
58.2
13
65.1
14.7
72.4
27
36.9
7.6
43.9
9.3
17
51
11
54.7
12
58.2
13
65.1
15.7
72.4
18.2
29
36.9
8
43.9
9.9
51
12
54.7
13
58.2
14
65.1
16.7
72.4
19.4
31
36.9
8.5
43.9
11
51
13
54.7
14
58.2
15
65.1
17.8
72.4
20.7
33
36.9
9
43.9
11
51
14
54.7
15
58.2
16
65.1
19
72.4
22.1
35
36.9
9.6
43.9
12
51
14
54.7
16
58.2
17
65.1
20.2
72.4
23.5
37
36.9
10
43.9
13
51
15
54.7
17
58.2
18
65.1
21.5
72.4
25.1
39
36.9
11
43.9
13
51
16
54.7
18
58.2
19
65.1
22.9
72.4
26.7
42
36.9
11
43.9
14
51
17
54.7
19
58.2
21
65.1
24.3
72.4
28.3
44
36.9
12
43.9
15
51
18
54.7
20
58.2
22
65.1
25.6
72.4
29.9
46
36.9
12
43.9
16
51
19
54.7
21
58.2
23
65.1
27
72.4
31.4
10
31.7
5.5
37.6
6.5
44
7.5
46.7
8
49.8
8.5
56.1
9.7
62
10.9
12
31.7
5.6
37.6
6.6
44
7.6
46.7
8.1
49.8
8.7
56.1
9.9
62
11.1
14
31.7
5.7
37.6
6.7
44
7.7
46.7
8.3
49.8
8.8
56.1
10.1
62
11.3
16
31.7
5.8
37.6
6.8
44
7.9
46.7
8.4
49.8
9
56.1
10.2
62
11.5
18
31.7
5.8
37.6
6.9
44
8
46.7
8.6
49.8
9.2
56.1
10.4
62
11.7
20
31.7
5.9
37.6
7
44
8.1
46.7
8.7
49.8
9.3
56.1
10.6
62
11.9
21
31.7
6
37.6
7.1
44
8.2
46.7
8.8
49.8
9.5
56.1
10.7
62
12.1
23
31.7
6.1
37.6
7.2
44
8.4
46.7
9
49.8
9.7
56.1
11.2
62
12.8
25
31.7
6.2
37.6
7.3
44
8.7
46.7
9.5
49.8
10
56.1
11.9
62
13.7
27
31.7
6.4
37.6
7.8
44
9.2
46.7
10
49.8
11
56.1
12.7
62
14.6
29
31.7
6.8
37.6
8.2
44
9.9
46.7
11
49.8
12
56.1
13.5
62
15.6
31
31.7
7.2
37.6
8.7
44
11
46.7
11
49.8
12
56.1
14.4
62
16.6
33
31.7
7.6
37.6
9.3
44
11
46.7
12
49.8
13
56.1
15.3
62
17.7
35
31.7
8
37.6
9.8
44
12
46.7
13
49.8
14
56.1
16.3
62
18.8
37
31.7
8.5
37.6
10
44
13
46.7
14
49.8
15
56.1
17.3
62
20
39
31.7
9
37.6
11
44
13
46.7
15
49.8
16
56.1
18.4
62
21.3
42
31.7
9.5
37.6
12
44
14
46.7
15
49.8
17
56.1
19.4
62
22.5
44
31.7
9.9
37.6
12
44
15
46.7
16
49.8
18
56.1
20.5
62
23.7
46
31.7
11
37.6
13
44
16
46.7
17
49.8
18
56.1
21.5
62
24.9
10
26.3
4.7
31.3
5.5
37
6.3
39
6.7
41.4
7.1
46.7
8
51.5
8.9
12
26.3
4.8
31.3
5.6
37
6.4
39
6.8
41.4
7.2
46.7
8.1
51.5
9
14
26.3
4.9
31.3
5.6
37
6.5
39
6.9
41.4
7.3
46.7
8.2
51.5
9.2
16
26.3
4.9
31.3
5.7
37
6.6
39
7
41.4
7.5
46.7
8.4
51.5
9.4
18
26.3
5
31.3
5.8
37
6.7
39
7.1
41.4
7.6
46.7
8.5
51.5
9.6
20
26.3
5.1
31.3
5.9
37
6.8
39
7.2
41.4
7.7
46.7
8.7
51.5
9.8
21
26.3
5.1
31.3
6
37
6.8
39
7.3
41.4
7.8
46.7
8.8
51.5
9.9
23
26.3
5.2
31.3
6
37
7
39
7.4
41.4
7.9
46.7
8.9
51.5
10.1
25
26.3
5.3
31.3
6.1
37
7.1
39
7.6
41.4
8.2
46.7
9.4
51.5
10.7
27
26.3
5.3
31.3
6.4
37
7.5
39
8.1
41.4
8.7
46.7
10
51.5
11.4
29
26.3
5.7
31.3
6.7
37
7.9
39
8.6
41.4
9.2
46.7
10.7
51.5
12.2
31
26.3
6
31.3
7.1
37
8.4
39
9.1
41.4
9.8
46.7
11.3
51.5
13
33
26.3
6.3
31.3
7.5
37
8.9
39
9.7
41.4
10
46.7
12
51.5
13.8
35
26.3
6.7
31.3
8
37
9.5
39
10
41.4
11
46.7
12.8
51.5
14.6
37
26.3
7
31.3
8.4
37
10
39
11
41.4
12
46.7
13.6
51.5
15.5
39
26.3
7.4
31.3
8.9
37
11
39
12
41.4
12
46.7
13.1
51.5
16.5
42
26.3
7.7
31.3
9.4
37
11
39
12
41.4
13
46.7
13.4
51.5
17.4
44
26.3
8.1
31.3
9.9
37
12
39
13
41.4
14
46.7
13.6
51.5
18.3
46
26.3
8.4
31.3
10
37
12
39
13
41.4
15
46.7
13.7
51.5
19.3
Cooling Performance - COOLING PERFORMANCE DATA – 300
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
TC
kW
16
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
PI
kW
TC
kW
PI
kW
10
58.6
10
69.9
12.1
81.2
14.3
87
15.4
92.8
16.6
104.1
19
109.9
19.7
12
58.6
10.1
69.9
12.3
81.2
14.6
87
15.8
92.8
16.9
104.1
19.4
109.9
19.6
14
58.6
10.3
69.9
12.5
81.2
14.8
87
16
92.8
17.3
104.1
19.7
107.2
19.5
16
58.6
10.5
69.9
12.7
81.2
15.2
87
16.4
92.8
17.6
103.7
20
105.6
19.8
18
58.6
10.7
69.9
13
81.2
15.4
87
16.7
92.8
17.9
102.1
20.6
104.5
20.8
20
58.6
10.9
69.9
13.3
81.2
15.9
87
17.5
92.8
19.2
101
21.6
102.9
21.8
21
58.6
11
69.9
13.4
81.2
16.5
87
18.1
92.8
19.9
100.2
22.1
102.1
22.3
23
58.6
11.3
69.9
14.3
81.2
17.6
87
19.5
92.8
21.3
98.7
23.2
100.6
23.3
25
58.6
12.1
69.9
15.3
81.2
18.9
87
20.8
92.8
22.9
95.9
24.2
99.4
24.4
27
58.6
12.9
69.9
16.3
81.2
20.2
87
22.3
92.8
24.5
94.4
25.1
97.9
25.4
29
58.6
13.7
69.9
17.4
81.2
21.6
87
23.8
92.4
26
92.8
26.3
96.7
26.4
31
58.6
14.6
69.9
18.5
81.2
23
87
25.4
90.9
27
91.7
27.2
95.2
27.5
33
58.6
15.5
69.9
19.7
81.2
24.5
87
27.1
89.3
28
90.1
28.2
93.6
28.5
35
58.6
16.4
69.9
21
81.2
26.1
87
28.9
88.2
29
92.8
29.3
92.4
29.6
37
58.6
17.5
69.9
22.3
81.2
27.9
85.4
29.9
86.6
30.1
88.9
30.3
90.9
30.6
39
58.6
18.6
69.9
23.8
81.2
29.7
84.3
30.9
85.1
31.1
87.4
31.4
89.3
31.7
42
58.6
19.7
69.9
25.1
81.2
31.4
82.9
32
83.5
32.2
84.3
32.4
87.8
32.7
44
58.6
20.7
69.9
26.5
81.2
33.2
81.5
33
82
33.2
81.6
33.5
86.2
33.8
46
58.6
21.9
69.9
27.7
81.2
34.9
80.2
34
80.4
34.2
78.9
34.5
85.5
34.8
10
52.8
8.9
62.9
10.8
73
12.7
78.5
13.7
83.5
14.7
93.6
16.8
103.7
19
12
52.8
9
62.9
10.9
73
12.9
78.5
14
83.5
15
93.6
17.2
103.7
19.3
14
52.8
9.2
62.9
11.1
73
13.2
78.5
14.2
83.5
15.3
93.6
17.5
103.7
19.7
16
52.8
9.4
62.9
11.4
73
13.4
78.5
14.5
83.5
15.6
93.6
17.8
103.7
20
18
52.8
9.5
62.9
11.6
73
13.7
78.5
14.8
83.5
15.9
93.6
18.1
102.1
20.6
20
52.8
9.7
62.9
11.8
73
14
78.5
15.1
83.5
16.5
93.6
19.5
100.6
21.6
21
52.8
9.8
62.9
11.9
73
14.2
78.5
15.6
83.5
17
93.6
20.2
100.2
22.1
23
52.8
10
62.9
12.4
73
15.2
78.5
16.7
83.5
18.3
93.6
21.7
98.7
23.2
25
52.8
10.5
62.9
13.2
73
16.2
78.5
17.9
83.5
19.6
93.6
23.2
97.1
24.2
27
52.8
11.2
62.9
14.1
73
17.3
78.5
19.1
83.5
20.9
93.6
24.8
95.9
25.1
29
52.8
11.9
62.9
15.1
73
18.5
78.5
20.4
83.5
22.3
92.4
26
94.4
26.2
31
52.8
12.7
62.9
16
73
19.7
78.5
21.7
83.5
23.8
90.9
27
92.8
27.2
33
52.8
13.5
62.9
17
73
21
78.5
23.2
83.5
25.4
89.7
28
91.7
28.2
35
52.8
14.3
62.9
18.1
73
22.4
78.5
24.7
83.5
27.1
88.2
29.1
90.1
29.3
37
52.8
15.2
62.9
19.2
73
23.8
78.5
26.3
83.5
28.9
87
30.1
88.6
30.3
39
52.8
16.1
62.9
20.5
73
25.4
78.5
28
83.5
30.8
85.4
31.1
87.4
31.4
42
52.8
17
62.9
21.6
73
26.8
78.5
29.7
83.5
32.6
84.2
32.1
86
32.4
44
52.8
17.9
62.9
22.8
73
28.3
78.5
31.3
83.5
34.4
82.8
33.1
84.6
33.5
34.5
46
52.8
18.7
62.9
24
73
29.8
78.5
33
83.5
36.2
81.5
34.2
83.2
10
47
7.9
55.9
9.5
65.3
11.1
69.5
12
74.2
12.9
83.1
14.7
92
16.5
12
47
8.1
55.9
9.7
65.3
11.3
69.5
12.2
74.2
13.1
83.1
14.9
92
16.8
14
47
8.2
55.9
9.8
65.3
11.5
69.5
12.5
74.2
13.3
83.1
15.2
92
17.2
16
47
8.3
55.9
10
65.3
11.7
69.5
12.7
74.2
13.6
83.1
15.6
92
17.5
18
47
8.4
55.9
10.1
65.3
12
69.5
12.9
74.2
13.9
83.1
15.8
92
17.9
20
47
8.6
55.9
10.4
65.3
12.2
69.5
13.2
74.2
14.2
83.1
16.4
92
19.1
21
47
8.7
55.9
10.5
65.3
12.4
69.5
13.3
74.2
14.5
83.1
17
92
19.8
23
47
8.8
55.9
10.6
65.3
12.9
69.5
14.2
74.2
15.4
83.1
18.2
92
21.2
25
47
9.2
55.9
11.4
65.3
13.8
69.5
15.1
74.2
16.5
83.1
19.5
92
22.7
27
47
9.7
55.9
12.1
65.3
14.7
69.5
16.2
74.2
17.6
83.1
20.8
92
24.3
29
47
10.3
55.9
12.9
65.3
15.7
69.5
17.2
74.2
18.8
83.1
22.3
92
26
31
47
11
55.9
13.7
65.3
16.7
69.5
18.4
74.2
20.1
83.1
23.8
92
27
33
47
11.6
55.9
14.6
65.3
17.8
69.5
19.6
74.2
21.4
83.1
25.3
92
28
35
47
12.4
55.9
15.4
65.3
18.9
69.5
20.8
74.2
22.8
83.1
27
92
29
37
47
13.1
55.9
16.4
65.3
20.1
69.5
22.2
74.2
24.3
83.1
28.8
92
30.1
39
47
13.8
55.9
17.4
65.3
21.4
69.5
23.6
74.2
25.8
83.1
30.7
92
31.1
42
47
14.6
55.9
18.4
65.3
22.6
69.5
24.9
74.2
27.3
83.1
32.5
92
32.1
44
47
15.3
55.9
19.4
65.3
23.9
69.5
26.3
74.2
28.8
83.1
34.3
92
33.1
46
47
16.1
55.9
20.6
65.3
25.1
69.5
27.7
74.2
30.4
83.1
36.1
92
34.1
39
Cooling Performance - COOLING PERFORMANCE DATA – 300
Capacity
factor(%)
70%
60%
50%
40
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
TC
kW
24
TC
kW
PI
kW
TC
kW
PI
kW
PI
kW
TC
kW
PI
kW
10
41.2
6.9
48.9
8.3
57
9.7
61
10
64.9
11
72.6
12.6
80.8
14.2
12
41.2
7.1
48.9
8.4
57
9.8
61
11
64.9
11
72.6
12.9
80.8
14.5
14
41.2
7.2
48.9
8.5
57
10
61
11
64.9
12
72.6
13.1
80.8
14.7
16
41.2
7.3
48.9
8.7
57
10
61
11
64.9
12
72.6
13.3
80.8
15
18
41.2
7.4
48.9
8.8
57
10
61
11
64.9
12
72.6
13.6
80.8
15.3
20
41.2
7.6
48.9
9
57
11
61
11
64.9
12
72.6
13.8
80.8
15.7
21
41.2
7.6
48.9
9.1
57
11
61
12
64.9
12
72.6
14.1
80.8
16.3
23
41.2
7.7
48.9
9.3
57
11
61
12
64.9
13
72.6
15.1
80.8
18
25
41.2
7.9
48.9
9.6
57
12
61
13
64.9
14
72.6
16.1
80.8
18.6
27
41.2
8.3
48.9
10
57
12
61
14
64.9
15
72.6
17.2
80.8
20
29
41.2
8.8
48.9
11
57
13
61
14
64.9
16
72.6
18.4
80.8
21.3
31
41.2
9.4
48.9
12
57
14
61
15
64.9
17
72.6
19.6
80.8
22.7
33
41.2
9.9
48.9
12
57
15
61
16
64.9
18
72.6
20.8
80.8
24.2
35
41.2
11
48.9
13
57
16
61
17
64.9
19
72.6
22.2
80.8
25.8
37
41.2
11
48.9
14
57
17
61
18
64.9
20
72.6
23.6
80.8
27.5
39
41.2
12
48.9
15
57
18
61
20
64.9
21
72.6
25.1
80.8
29.3
42
41.2
12
48.9
15
57
19
61
21
64.9
23
72.6
26.6
80.8
31
44
41.2
13
48.9
16
57
20
61
22
64.9
24
72.6
28.1
80.8
32.8
34.5
46
41.2
14
48.9
17
57
21
61
23
64.9
25
72.6
29.6
80.8
10
35.3
6.1
41.9
7.1
49
8.2
52
8.8
55.5
9.4
62.5
10.6
69.1
11.9
12
35.3
6.1
41.9
7.2
49
8.3
52
8.9
55.5
9.5
62.5
10.8
69.1
12.1
14
35.3
6.2
41.9
7.3
49
8.5
52
9.1
55.5
9.7
62.5
11
69.1
12.4
16
35.3
6.3
41.9
7.4
49
8.7
52
9.3
55.5
9.9
62.5
11.2
69.1
12.6
18
35.3
6.4
41.9
7.6
49
8.8
52
9.4
55.5
10
62.5
11.4
69.1
12.9
20
35.3
6.5
41.9
7.7
49
8.9
52
9.6
55.5
10
62.5
11.6
69.1
13.1
21
35.3
6.6
41.9
7.8
49
9
52
9.7
55.5
10
62.5
11.7
69.1
13.2
23
35.3
6.7
41.9
7.9
49
9.2
52
9.9
55.5
11
62.5
12.2
69.1
14.1
25
35.3
6.8
41.9
8.1
49
9.5
52
10
55.5
11
62.5
13.1
69.1
15
27
35.3
7.1
41.9
8.5
49
10
52
11
55.5
12
62.5
13.9
69.1
16
29
35.3
7.4
41.9
9
49
11
52
12
55.5
13
62.5
14.8
69.1
17.1
31
35.3
7.9
41.9
9.6
49
12
52
13
55.5
14
62.5
15.8
69.1
18.2
33
35.3
8.3
41.9
10
49
12
52
13
55.5
14
62.5
16.8
69.1
19.4
35
35.3
8.8
41.9
11
49
13
52
14
55.5
15
62.5
17.9
69.1
20.6
37
35.3
9.3
41.9
11
49
14
52
15
55.5
16
62.5
19
69.1
22
39
35.3
9.9
41.9
12
49
15
52
16
55.5
17
62.5
20.2
69.1
23.3
42
35.3
10
41.9
13
49
15
52
17
55.5
18
62.5
21.3
69.1
24.7
44
35.3
11
41.9
13
49
16
52
18
55.5
19
62.5
22.5
69.1
26
46
35.3
12
41.9
14
49
17
52
19
55.5
20
62.5
23.6
69.1
27.4
10
29.4
5.2
35
6
41
6.9
43.5
7.3
46.2
7.8
52
8.8
57.5
9.8
12
29.4
5.3
35
6.1
41
7
43.5
7.4
46.2
7.9
52
8.9
57.5
9.9
14
29.4
5.3
35
6.2
41
7.1
43.5
7.6
46.2
8.1
52
9
57.5
10.1
16
29.4
5.4
35
6.3
41
7.2
43.5
7.7
46.2
8.2
52
9.2
57.5
10.3
18
29.4
5.5
35
6.4
41
7.3
43.5
7.8
46.2
8.3
52
9.4
57.5
10.5
20
29.4
5.6
35
6.5
41
7.4
43.5
7.9
46.2
8.5
52
9.5
57.5
10.7
21
29.4
5.6
35
6.6
41
7.5
43.5
8.1
46.2
8.5
52
9.7
57.5
10.8
23
29.4
5.7
35
6.6
41
7.7
43.5
8.2
46.2
8.7
52
9.8
57.5
11
25
29.4
5.8
35
6.7
41
7.8
43.5
8.3
46.2
9
52
10.3
57.5
11.7
27
29.4
5.8
35
7
41
8.2
43.5
8.9
46.2
9.5
52
11
57.5
12.5
29
29.4
6.2
35
7.4
41
8.7
43.5
9.4
46.2
10
52
11.7
57.5
13.3
31
29.4
6.6
35
7.8
41
9.3
43.5
10
46.2
11
52
12.4
57.5
14.2
33
29.4
6.9
35
8.3
41
9.8
43.5
11
46.2
11
52
13.2
57.5
15.1
35
29.4
7.3
35
8.8
41
10
43.5
11
46.2
12
52
14
57.5
16
37
29.4
7.7
35
9.3
41
11
43.5
12
46.2
13
52
14.9
57.5
17
39
29.4
8.1
35
9.8
41
12
43.5
13
46.2
14
52
14.3
57.5
18.1
42
29.4
8.5
35
10
41
12
43.5
13
46.2
14
52
14.7
57.5
19.1
44
29.4
8.9
35
11
41
13
43.5
14
46.2
15
52
14.9
57.5
20.1
46
29.4
9.3
35
11
41
14
43.5
15
46.2
16
52
15.1
57.5
21.1
Cooling Performance - COOLING PERFORMANCE DATA – 320
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
62
11.2
73.9
13.6
85.8
16.1
92
17.4
98.2
18.7
110.1
21.3
116.2
12
62
11.4
73.9
13.8
85.8
16.4
92
17.7
98.2
19
110.1
21.8
116.2
22
14
62
11.6
73.9
14.1
85.8
16.7
92
18
98.2
19.4
110.1
22.2
113.4
21.9
16
62
11.8
73.9
14.3
85.8
17
92
18.4
98.2
19.8
109.7
22.4
111.7
22.3
18
62
12
73.9
14.6
85.8
17.4
92
18.8
98.2
20.1
108
23.2
110.5
23.4
20
62
12.3
73.9
14.9
85.8
17.9
92
19.7
98.2
21.6
106.8
24.3
108.8
24.5
21
62
12.4
73.9
15.1
85.8
18.5
92
20.4
98.2
22.4
106
24.9
108
25.1
23
62
12.7
73.9
16.1
85.8
19.8
92
21.9
98.2
24
104.3
26
106.4
26.2
25
62
13.6
73.9
17.2
85.8
21.2
92
23.4
98.2
25.7
101.4
27.1
105.1
27.4
27
62
14.4
73.9
18.3
85.8
22.7
92
25
98.2
27.5
99.8
28.3
103.5
28.5
29
62
15.4
73.9
19.5
85.8
24.2
92
26.7
97.8
29.2
98.2
29.6
102.3
29.7
31
62
16.4
73.9
20.8
85.8
25.8
92
28.6
96.1
30.3
96.9
30.6
100.6
30.9
33
62
17.4
73.9
22.2
85.8
27.5
92
30.4
94.5
31.5
95.3
31.7
99
32
35
62
18.5
73.9
23.6
85.8
29.4
92
32.5
93.2
32.6
98.2
32.9
97.8
33.2
37
62
19.6
73.9
25.1
85.8
31.3
90.4
33.6
91.6
33.8
94.1
34.1
96.1
34.4
39
62
20.9
73.9
26.7
85.8
33.3
89.1
34.8
89.9
35
92.4
35.3
94.5
35.6
42
62
22.1
73.9
28.2
85.8
35.3
87.6
35.9
88.3
36.1
89.1
36.4
92.8
36.8
44
62
23.3
73.9
29.8
85.8
37.3
86.2
37.1
86.7
37.3
86.3
37.6
91.2
37.9
46
62
24.6
73.9
31.1
85.8
39.3
84.8
38.2
85
38.5
83.4
38.8
90.4
39.1
10
55.9
10
66.5
12.1
77.2
14.3
83
15.4
88.3
16.5
99
18.9
109.7
21.3
12
55.9
10.2
66.5
12.3
77.2
14.5
83
15.7
88.3
16.9
99
19.3
109.7
21.7
14
55.9
10.4
66.5
12.5
77.2
14.8
83
16
88.3
17.2
99
19.6
109.7
22.1
16
55.9
10.5
66.5
12.8
77.2
15.1
83
16.3
88.3
17.5
99
20
109.7
22.5
18
55.9
10.7
66.5
13
77.2
15.4
83
16.6
88.3
17.9
99
20.4
108
23.2
20
55.9
10.9
66.5
13.3
77.2
15.7
83
16.9
88.3
18.5
99
21.9
106.4
24.3
21
55.9
11
66.5
13.4
77.2
15.9
83
17.5
88.3
19.2
99
22.7
106
24.9
23
55.9
11.2
66.5
13.9
77.2
17
83
18.8
88.3
20.6
99
24.4
104.3
26
25
55.9
11.8
66.5
14.9
77.2
18.2
83
20.1
88.3
22
99
26.1
102.7
27.1
27
55.9
12.6
66.5
15.9
77.2
19.5
83
21.4
88.3
23.5
99
27.9
101.4
28.3
29
55.9
13.4
66.5
16.9
77.2
20.8
83
22.9
88.3
25.1
97.8
29.2
99.8
29.4
31
55.9
14.3
66.5
18
77.2
22.2
83
24.4
88.3
26.8
96.1
30.4
98.2
30.6
33
55.9
15.1
66.5
19.2
77.2
23.6
83
26
88.3
28.6
94.9
31.5
96.9
31.7
35
55.9
16.1
66.5
20.3
77.2
25.2
83
27.8
88.3
30.5
93.2
32.7
95.3
32.9
37
55.9
17
66.5
21.6
77.2
26.8
83
29.6
88.3
32.5
92
33.8
93.6
34.1
39
55.9
18.1
66.5
23
77.2
28.5
83
31.5
88.3
34.6
90.4
35
92.4
35.3
42
55.9
19.1
66.5
24.3
77.2
30.2
83
33.3
88.3
36.6
89
36.1
90.9
36.4
44
55.9
20.1
66.5
25.7
77.2
31.8
83
35.2
88.3
38.7
87.6
37.2
89.5
37.6
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
22.1
46
55.9
21.1
66.5
27
77.2
33.5
83
37
88.3
40.7
86.2
38.4
88
38.8
10
49.7
8.9
59.1
10.7
69
12.5
73.5
13.5
78.4
14.4
87.9
16.5
97.3
18.6
12
49.7
9
59.1
10.8
69
12.7
73.5
13.7
78.4
14.8
87.9
16.8
97.3
18.9
14
49.7
9.2
59.1
11
69
13
73.5
14
78.4
15
87.9
17.1
97.3
19.3
16
49.7
9.4
59.1
11.2
69
13.2
73.5
14.3
78.4
15.3
87.9
17.5
97.3
19.6
18
49.7
9.5
59.1
11.4
69
13.5
73.5
14.5
78.4
15.6
87.9
17.8
97.3
20.1
20
49.7
9.7
59.1
11.7
69
13.7
73.5
14.8
78.4
15.9
87.9
18.5
97.3
21.4
21
49.7
9.7
59.1
11.8
69
13.9
73.5
14.9
78.4
16.2
87.9
19.1
97.3
22.3
23
49.7
9.9
59.1
12
69
14.5
73.5
15.9
78.4
17.4
87.9
20.5
97.3
23.9
25
49.7
10.3
59.1
12.8
69
15.5
73.5
17
78.4
18.6
87.9
21.9
97.3
25.5
27
49.7
10.9
59.1
13.6
69
16.5
73.5
18.2
78.4
19.8
87.9
23.4
97.3
27.3
29
49.7
11.6
59.1
14.4
69
17.7
73.5
19.3
78.4
21.1
87.9
25
97.3
29.2
31
49.7
12.3
59.1
15.4
69
18.8
73.5
20.6
78.4
22.6
87.9
26.7
97.3
30.3
33
49.7
13.1
59.1
16.4
69
20
73.5
22
78.4
24.1
87.9
28.5
97.3
31.5
35
49.7
13.9
59.1
17.4
69
21.3
73.5
23.4
78.4
25.6
87.9
30.4
97.3
32.6
37
49.7
14.7
59.1
18.5
69
22.6
73.5
24.9
78.4
27.3
87.9
32.4
97.3
33.8
39
49.7
15.6
59.1
19.6
69
24.1
73.5
26.5
78.4
29
87.9
34.5
97.3
34.9
42
49.7
16.4
59.1
20.7
69
25.4
73.5
28
78.4
30.7
87.9
36.5
97.3
36.1
44
49.7
17.2
59.1
21.8
69
26.8
73.5
29.6
78.4
32.4
87.9
38.5
97.3
37.2
46
49.7
18.1
59.1
23.1
69
28.2
73.5
31.1
78.4
34.1
87.9
40.6
97.3
38.3
41
Cooling Performance - COOLING PERFORMANCE DATA – 320
Capacity
factor(%)
70%
60%
50%
42
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
43.5
7.8
51.8
9.3
60
11
64.5
12
68.6
12
43.5
7.9
51.8
9.4
60
11
64.5
12
68.6
14
43.5
8.1
51.8
9.6
60
11
64.5
12
16
43.5
8.2
51.8
9.7
60
11
64.5
18
43.5
8.3
51.8
9.9
60
12
20
43.5
8.5
51.8
10
60
21
43.5
8.6
51.8
10
60
23
43.5
8.7
51.8
10
25
43.5
8.9
51.8
27
43.5
9.4
29
43.5
31
43.5
33
22
24
TC
kW
PI
kW
TC
kW
PI
kW
13
76.8
14.2
85.4
15.9
13
76.8
14.4
85.4
16.2
68.6
13
76.8
14.7
85.4
16.5
12
68.6
13
76.8
15
85.4
16.9
64.5
13
68.6
13
76.8
15.2
85.4
17.2
12
64.5
13
68.6
14
76.8
15.6
85.4
17.7
12
64.5
13
68.6
14
76.8
15.8
85.4
18.3
60
12
64.5
13
68.6
14
76.8
16.9
85.4
20.2
11
60
13
64.5
14
68.6
15
76.8
18.1
85.4
21
51.8
12
60
14
64.5
15
68.6
17
76.8
19.3
85.4
22.4
9.9
51.8
12
60
15
64.5
16
68.6
18
76.8
20.6
85.4
23.9
11
51.8
13
60
16
64.5
17
68.6
19
76.8
22
85.4
25.5
43.5
11
51.8
14
60
17
64.5
18
68.6
20
76.8
23.4
85.4
27.2
35
43.5
12
51.8
15
60
18
64.5
19
68.6
21
76.8
24.9
85.4
29
37
43.5
13
51.8
16
60
19
64.5
21
68.6
23
76.8
26.5
85.4
30.9
39
43.5
13
51.8
16
60
20
64.5
22
68.6
24
76.8
28.3
85.4
32.9
42
43.5
14
51.8
17
60
21
64.5
23
68.6
25
76.8
29.9
85.4
34.9
44
43.5
15
51.8
18
60
22
64.5
25
68.6
27
76.8
31.6
85.4
36.8
46
43.5
15
51.8
19
60
24
64.5
26
68.6
28
76.8
33.3
85.4
38.8
10
37.4
6.8
44.4
8
52
9.2
55
9.9
58.7
11
66.1
12
73.1
13.4
12
37.4
6.9
44.4
8.1
52
9.4
55
10
58.7
11
66.1
12.1
73.1
13.6
14
37.4
7
44.4
8.2
52
9.5
55
10
58.7
11
66.1
12.4
73.1
13.9
16
37.4
7.1
44.4
8.4
52
9.7
55
10
58.7
11
66.1
12.6
73.1
14.1
18
37.4
7.2
44.4
8.5
52
9.9
55
11
58.7
11
66.1
12.8
73.1
14.4
20
37.4
7.3
44.4
8.7
52
10
55
11
58.7
12
66.1
13.1
73.1
14.7
21
37.4
7.4
44.4
8.7
52
10
55
11
58.7
12
66.1
13.2
73.1
14.9
23
37.4
7.5
44.4
8.9
52
10
55
11
58.7
12
66.1
13.8
73.1
15.8
25
37.4
7.6
44.4
9
52
11
55
12
58.7
13
66.1
14.7
73.1
16.9
27
37.4
7.9
44.4
9.6
52
11
55
12
58.7
14
66.1
15.6
73.1
18
29
37.4
8.4
44.4
10
52
12
55
13
58.7
14
66.1
16.7
73.1
19.2
31
37.4
8.9
44.4
11
52
13
55
14
58.7
15
66.1
17.7
73.1
20.5
33
37.4
9.4
44.4
12
52
14
55
15
58.7
16
66.1
18.9
73.1
21.8
35
37.4
9.9
44.4
12
52
15
55
16
58.7
17
66.1
20.1
73.1
23.2
37
37.4
11
44.4
13
52
15
55
17
58.7
18
66.1
21.3
73.1
24.7
39
37.4
11
44.4
14
52
16
55
18
58.7
19
66.1
22.7
73.1
26.2
42
37.4
12
44.4
14
52
17
55
19
58.7
21
66.1
24
73.1
27.7
44
37.4
12
44.4
15
52
18
55
20
58.7
22
66.1
25.3
73.1
29.2
30.7
46
37.4
13
44.4
16
52
19
55
21
58.7
23
66.1
26.6
73.1
10
31.1
5.8
37
6.8
43
7.7
46
8.2
48.9
8.8
55
9.9
60.8
11
12
31.1
6
37
6.9
43
7.9
46
8.4
48.9
8.9
55
10
60.8
11.2
14
31.1
6
37
6.9
43
8
46
8.5
48.9
9
55
10.2
60.8
11.3
16
31.1
6.1
37
7.1
43
8.1
46
8.7
48.9
9.2
55
10.4
60.8
11.6
18
31.1
6.1
37
7.2
43
8.2
46
8.8
48.9
9.4
55
10.5
60.8
11.8
20
31.1
6.3
37
7.3
43
8.4
46
8.9
48.9
9.5
55
10.7
60.8
12
21
31.1
6.3
37
7.4
43
8.4
46
9
48.9
9.6
55
10.8
60.8
12.1
23
31.1
6.4
37
7.4
43
8.6
46
9.2
48.9
9.8
55
11
60.8
12.4
25
31.1
6.5
37
7.6
43
8.7
46
9.4
48.9
10
55
11.6
60.8
13.2
27
31.1
6.6
37
7.9
43
9.2
46
10
48.9
11
55
12.3
60.8
14.1
29
31.1
7
37
8.3
43
9.8
46
11
48.9
11
55
13.1
60.8
15
31
31.1
7.4
37
8.8
43
10
46
11
48.9
12
55
13.9
60.8
16
33
31.1
7.8
37
9.3
43
11
46
12
48.9
13
55
14.8
60.8
17
35
31.1
8.2
37
9.9
43
12
46
13
48.9
14
55
15.7
60.8
18
37
31.1
8.7
37
10
43
12
46
13
48.9
14
55
16.7
60.8
19.2
39
31.1
9.1
37
11
43
13
46
14
48.9
15
55
16.1
60.8
20.3
42
31.1
9.5
37
12
43
14
46
15
48.9
16
55
16.6
60.8
21.5
44
31.1
10
37
12
43
15
46
16
48.9
17
55
16.8
60.8
22.6
46
31.1
10
37
13
43
15
46
16
48.9
18
55
17
60.8
23.8
Cooling Performance - COOLING PERFORMANCE DATA – 340
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
66.1
10.9
78.8
13.2
91.4
15.7
98
16.9
104.6
18.2
117.3
20.8
123.8
12
66.1
11.1
78.8
13.5
91.4
16
98
17.3
104.6
18.6
117.3
21.2
123.8
21.5
14
66.1
11.3
78.8
13.7
91.4
16.3
98
17.6
104.6
18.9
117.3
21.7
120.8
21.4
16
66.1
11.5
78.8
14
91.4
16.6
98
18
104.6
19.3
116.8
21.9
119
21.7
18
66.1
11.7
78.8
14.3
91.4
16.9
98
18.3
104.6
19.7
115.1
22.6
117.7
22.8
20
66.1
12
78.8
14.6
91.4
17.4
98
19.2
104.6
21.1
113.8
23.7
115.9
23.9
21
66.1
12.1
78.8
14.7
91.4
18.1
98
19.9
104.6
21.8
112.9
24.3
115.1
24.5
23
66.1
12.4
78.8
15.7
91.4
19.4
98
21.4
104.6
23.4
111.1
25.4
113.3
25.6
25
66.1
13.2
78.8
16.8
91.4
20.7
98
22.9
104.6
25.1
108.1
26.5
112
26.7
27
66.1
14.1
78.8
17.8
91.4
22.1
98
24.4
104.6
26.9
106.3
27.6
110.3
27.8
29
66.1
15
78.8
19.1
91.4
23.7
98
26.1
104.1
28.5
104.6
28.8
108.9
29
31
66.1
16
78.8
20.3
91.4
25.2
98
27.9
102.4
29.6
103.3
29.9
107.2
30.1
33
66.1
17
78.8
21.7
91.4
26.9
98
29.7
100.6
30.7
101.5
31
105.4
31.3
35
66.1
18
78.8
23
91.4
28.7
98
31.7
99.3
31.8
104.6
32.1
104.1
32.4
37
66.1
19.2
78.8
24.5
91.4
30.6
96.3
32.8
97.6
33
100.2
33.3
102.4
33.6
39
66.1
20.4
78.8
26.1
91.4
32.5
94.9
33.9
95.8
34.1
98.4
34.4
100.6
34.7
42
66.1
21.6
78.8
27.6
91.4
34.5
93.3
35
94.1
35.3
94.9
35.6
98.9
35.9
44
66.1
22.7
78.8
29.1
91.4
36.4
91.8
36.2
92.3
36.4
91.9
36.7
97.1
37
46
66.1
24
78.8
30.3
91.4
38.3
90.3
37.3
90.5
37.6
88.8
37.9
96.3
38.2
10
59.5
9.8
70.9
11.8
82.3
13.9
88.4
15
94.1
16.2
105.4
18.5
116.8
20.8
12
59.5
9.9
70.9
12
82.3
14.2
88.4
15.3
94.1
16.5
105.4
18.8
116.8
21.2
14
59.5
10.1
70.9
12.2
82.3
14.5
88.4
15.6
94.1
16.8
105.4
19.2
116.8
21.6
16
59.5
10.3
70.9
12.5
82.3
14.7
88.4
15.9
94.1
17.1
105.4
19.5
116.8
22
18
59.5
10.5
70.9
12.7
82.3
15
88.4
16.2
94.1
17.4
105.4
19.9
115.1
22.6
20
59.5
10.6
70.9
12.9
82.3
15.3
88.4
16.5
94.1
18.1
105.4
21.4
113.3
23.7
21
59.5
10.8
70.9
13.1
82.3
15.5
88.4
17.1
94.1
18.7
105.4
22.2
112.9
24.3
23
59.5
10.9
70.9
13.6
82.3
16.6
88.4
18.3
94.1
20.1
105.4
23.8
111.1
25.4
25
59.5
11.6
70.9
14.5
82.3
17.8
88.4
19.6
94.1
21.5
105.4
25.5
109.4
26.5
27
59.5
12.3
70.9
15.5
82.3
19
88.4
20.9
94.1
22.9
105.4
27.2
108.1
27.6
29
59.5
13.1
70.9
16.5
82.3
20.3
88.4
22.3
94.1
24.5
104.1
28.5
106.3
28.7
31
59.5
13.9
70.9
17.5
82.3
21.7
88.4
23.8
94.1
26.1
102.4
29.6
104.6
29.8
33
59.5
14.8
70.9
18.7
82.3
23
88.4
25.4
94.1
27.9
101.1
30.7
103.3
31
35
59.5
15.7
70.9
19.8
82.3
24.6
88.4
27.1
94.1
29.8
99.3
31.9
101.5
32.1
37
59.5
16.6
70.9
21.1
82.3
26.1
88.4
28.9
94.1
31.7
98
33
99.8
33.3
39
59.5
17.7
70.9
22.4
82.3
27.8
88.4
30.7
94.1
33.8
96.3
34.1
98.4
34.4
42
59.5
18.6
70.9
23.7
82.3
29.4
88.4
32.5
94.1
35.7
94.8
35.2
96.8
35.6
44
59.5
19.6
70.9
25
82.3
31.1
88.4
34.3
94.1
37.7
93.3
36.3
95.3
36.7
46
59.5
20.6
70.9
26.3
82.3
32.7
88.4
36.1
94.1
39.7
91.8
37.5
93.7
37.9
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
21.6
10
52.9
8.7
63
10.4
73.5
12.2
78.3
13.1
83.6
14.1
93.6
16.1
103.7
18.1
12
52.9
8.8
63
10.6
73.5
12.4
78.3
13.4
83.6
14.4
93.6
16.4
103.7
18.5
14
52.9
9
63
10.8
73.5
12.6
78.3
13.7
83.6
14.6
93.6
16.7
103.7
18.8
16
52.9
9.1
63
10.9
73.5
12.9
78.3
13.9
83.6
14.9
93.6
17.1
103.7
19.2
18
52.9
9.3
63
11.1
73.5
13.1
78.3
14.2
83.6
15.2
93.6
17.4
103.7
19.6
20
52.9
9.4
63
11.4
73.5
13.4
78.3
14.5
83.6
15.5
93.6
18
103.7
20.9
21
52.9
9.5
63
11.5
73.5
13.6
78.3
14.6
83.6
15.9
93.6
18.6
103.7
21.7
23
52.9
9.7
63
11.7
73.5
14.2
78.3
15.5
83.6
16.9
93.6
20
103.7
23.3
25
52.9
10
63
12.5
73.5
15.1
78.3
16.6
83.6
18.1
93.6
21.4
103.7
24.9
27
52.9
10.6
63
13.2
73.5
16.2
78.3
17.7
83.6
19.4
93.6
22.9
103.7
26.7
28.5
29
52.9
11.3
63
14.1
73.5
17.2
78.3
18.9
83.6
20.6
93.6
24.4
103.7
31
52.9
12
63
15
73.5
18.3
78.3
20.1
83.6
22
93.6
26.1
103.7
29.6
33
52.9
12.8
63
16
73.5
19.5
78.3
21.5
83.6
23.5
93.6
27.8
103.7
30.7
35
52.9
13.6
63
16.9
73.5
20.8
78.3
22.8
83.6
25
93.6
29.6
103.7
31.8
37
52.9
14.3
63
18
73.5
22.1
78.3
24.3
83.6
26.6
93.6
31.6
103.7
33
39
52.9
15.2
63
19.1
73.5
23.5
78.3
25.8
83.6
28.3
93.6
33.6
103.7
34.1
42
52.9
16
63
20.2
73.5
24.8
78.3
27.3
83.6
30
93.6
35.6
103.7
35.2
44
52.9
16.8
63
21.3
73.5
26.2
78.3
28.9
83.6
31.6
93.6
37.6
103.7
36.3
46
52.9
17.6
63
22.6
73.5
27.5
78.3
30.3
83.6
33.3
93.6
39.6
103.7
37.4
43
Cooling Performance - COOLING PERFORMANCE DATA – 340
Capacity
factor(%)
70%
60%
50%
44
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
46.4
7.6
55.1
9.1
64
11
68.7
11
73.1
12
46.4
7.7
55.1
9.2
64
11
68.7
12
73.1
14
46.4
7.9
55.1
9.4
64
11
68.7
12
16
46.4
8
55.1
9.5
64
11
68.7
18
46.4
8.1
55.1
9.7
64
11
20
46.4
8.3
55.1
9.9
64
21
46.4
8.3
55.1
10
64
23
46.4
8.5
55.1
10
25
46.4
8.7
55.1
27
46.4
9.1
29
46.4
31
22
24
TC
kW
PI
kW
TC
kW
PI
kW
12
81.8
13.9
91
15.5
12
81.8
14.1
91
15.9
73.1
13
81.8
14.3
91
16.2
12
73.1
13
81.8
14.6
91
16.5
68.7
12
73.1
13
81.8
14.9
91
16.8
12
68.7
13
73.1
13
81.8
15.2
91
17.2
12
68.7
13
73.1
14
81.8
15.4
91
17.8
64
12
68.7
13
73.1
14
81.8
16.5
91
19.7
11
64
13
68.7
14
73.1
15
81.8
17.7
91
20.4
55.1
11
64
14
68.7
15
73.1
16
81.8
18.9
91
21.9
9.7
55.1
12
64
14
68.7
16
73.1
17
81.8
20.1
91
23.4
46.4
10
55.1
13
64
15
68.7
17
73.1
18
81.8
21.5
91
24.9
33
46.4
11
55.1
13
64
16
68.7
18
73.1
19
81.8
22.9
91
26.6
35
46.4
12
55.1
14
64
17
68.7
19
73.1
21
81.8
24.3
91
28.3
37
46.4
12
55.1
15
64
18
68.7
20
73.1
22
81.8
25.9
91
30.2
39
46.4
13
55.1
16
64
20
68.7
21
73.1
23
81.8
27.6
91
32.1
42
46.4
14
55.1
17
64
21
68.7
23
73.1
25
81.8
29.2
91
34
44
46.4
14
55.1
18
64
22
68.7
24
73.1
26
81.8
30.8
91
35.9
46
46.4
15
55.1
19
64
23
68.7
25
73.1
27
81.8
32.5
91
37.8
10
39.8
6.7
47.3
7.8
55
9
58.6
9.7
62.6
10
70.4
11.7
77.9
13.1
12
39.8
6.7
47.3
7.9
55
9.1
58.6
9.8
62.6
11
70.4
11.9
77.9
13.3
14
39.8
6.8
47.3
8
55
9.3
58.6
10
62.6
11
70.4
12.1
77.9
13.6
16
39.8
7
47.3
8.2
55
9.5
58.6
10
62.6
11
70.4
12.3
77.9
13.8
18
39.8
7
47.3
8.3
55
9.6
58.6
10
62.6
11
70.4
12.5
77.9
14.1
20
39.8
7.1
47.3
8.5
55
9.8
58.6
11
62.6
11
70.4
12.8
77.9
14.3
21
39.8
7.2
47.3
8.5
55
9.9
58.6
11
62.6
11
70.4
12.9
77.9
14.5
23
39.8
7.3
47.3
8.7
55
10
58.6
11
62.6
12
70.4
13.4
77.9
15.4
25
39.8
7.4
47.3
8.8
55
11
58.6
11
62.6
12
70.4
14.3
77.9
16.5
27
39.8
7.7
47.3
9.4
55
11
58.6
12
62.6
13
70.4
15.2
77.9
17.5
29
39.8
8.2
47.3
9.9
55
12
58.6
13
62.6
14
70.4
16.3
77.9
18.8
31
39.8
8.7
47.3
11
55
13
58.6
14
62.6
15
70.4
17.3
77.9
20
33
39.8
9.1
47.3
11
55
13
58.6
15
62.6
16
70.4
18.5
77.9
21.3
35
39.8
9.7
47.3
12
55
14
58.6
15
62.6
17
70.4
19.6
77.9
22.6
37
39.8
10
47.3
13
55
15
58.6
16
62.6
18
70.4
20.8
77.9
24.1
39
39.8
11
47.3
13
55
16
58.6
17
62.6
19
70.4
22.1
77.9
25.6
42
39.8
11
47.3
14
55
17
58.6
18
62.6
20
70.4
23.4
77.9
27.1
44
39.8
12
47.3
15
55
18
58.6
19
62.6
21
70.4
24.7
77.9
28.5
46
39.8
13
47.3
15
55
19
58.6
20
62.6
22
70.4
25.9
77.9
30
10
33.1
5.7
39.4
6.6
46
7.6
49
8
52.1
8.6
58.6
9.6
64.8
10.7
12
33.1
5.8
39.4
6.7
46
7.7
49
8.2
52.1
8.7
58.6
9.8
64.8
10.9
14
33.1
5.9
39.4
6.8
46
7.8
49
8.3
52.1
8.8
58.6
9.9
64.8
11.1
16
33.1
5.9
39.4
6.9
46
7.9
49
8.5
52.1
9
58.6
10.1
64.8
11.3
18
33.1
6
39.4
7
46
8
49
8.6
52.1
9.1
58.6
10.3
64.8
11.5
20
33.1
6.1
39.4
7.1
46
8.2
49
8.7
52.1
9.3
58.6
10.5
64.8
11.7
21
33.1
6.2
39.4
7.2
46
8.2
49
8.8
52.1
9.4
58.6
10.6
64.8
11.9
23
33.1
6.2
39.4
7.3
46
8.4
49
9
52.1
9.6
58.6
10.8
64.8
12.1
25
33.1
6.4
39.4
7.4
46
8.5
49
9.1
52.1
9.9
58.6
11.3
64.8
12.9
27
33.1
6.4
39.4
7.7
46
9
49
9.7
52.1
11
58.6
12
64.8
13.7
29
33.1
6.8
39.4
8.1
46
9.6
49
10
52.1
11
58.6
12.8
64.8
14.6
31
33.1
7.2
39.4
8.6
46
10
49
11
52.1
12
58.6
13.6
64.8
15.6
33
33.1
7.6
39.4
9.1
46
11
49
12
52.1
13
58.6
14.5
64.8
16.6
35
33.1
8
39.4
9.6
46
11
49
12
52.1
13
58.6
15.4
64.8
17.6
37
33.1
8.5
39.4
10
46
12
49
13
52.1
14
58.6
16.3
64.8
18.7
39
33.1
8.9
39.4
11
46
13
49
14
52.1
15
58.6
15.7
64.8
19.8
42
33.1
9.3
39.4
11
46
14
49
15
52.1
16
58.6
16.2
64.8
21
44
33.1
9.7
39.4
12
46
14
49
15
52.1
17
58.6
16.4
64.8
22.1
46
33.1
10
39.4
13
46
15
49
16
52.1
18
58.6
16.5
64.8
23.2
Cooling Performance - COOLING PERFORMANCE DATA – 360
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
69.4
12.2
82.8
14.7
96.1
17.4
103
18.9
109.9
20.3
123.2
23.2
130.1
24
12
69.4
12.4
82.8
15
96.1
17.8
103
19.3
109.9
20.7
123.2
23.6
130.1
23.9
14
69.4
12.6
82.8
15.3
96.1
18.1
103
19.6
109.9
21.1
123.2
24.1
126.9
23.8
16
69.4
12.8
82.8
15.6
96.1
18.5
103
20
109.9
21.5
122.8
24.4
125.1
24.2
18
69.4
13.1
82.8
15.9
96.1
18.9
103
20.4
109.9
21.9
120.9
25.2
123.7
25.4
20
69.4
13.3
82.8
16.2
96.1
19.4
103
21.4
109.9
23.5
119.6
26.4
121.9
26.6
21
69.4
13.5
82.8
16.4
96.1
20.1
103
22.2
109.9
24.3
118.6
27
120.9
27.3
23
69.4
13.8
82.8
17.4
96.1
21.5
103
23.8
109.9
26.1
116.8
28.3
119.1
28.5
25
69.4
14.7
82.8
18.6
96.1
23
103
25.5
109.9
27.9
113.6
29.5
117.7
29.8
27
69.4
15.7
82.8
19.9
96.1
24.6
103
27.2
109.9
29.9
111.7
30.7
115.9
31
29
69.4
16.7
82.8
21.2
96.1
26.3
103
29
109.4
31.7
109.9
32.1
114.5
32.3
31
69.4
17.8
82.8
22.6
96.1
28.1
103
31
107.6
32.9
108.5
33.3
112.7
33.5
33
69.4
18.9
82.8
24.1
96.1
29.9
103
33.1
105.8
34.2
106.7
34.5
110.8
34.8
35
69.4
20.1
82.8
25.7
96.1
31.9
103
35.3
104.4
35.4
109.9
35.8
109.4
36.1
37
69.4
21.3
82.8
27.3
96.1
34
101.2
36.5
102.5
36.7
105.3
37
107.6
37.4
39
69.4
22.7
82.8
29
96.1
36.2
99.8
37.8
100.7
38
103.5
38.3
105.8
38.6
42
69.4
24
82.8
30.7
96.1
38.4
98.1
39
98.9
39.3
99.8
39.6
103.9
39.9
44
69.4
25.3
82.8
32.4
96.1
40.5
96.5
40.3
97
40.5
96.6
40.9
102.1
41.2
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
46
69.4
26.7
82.8
33.8
96.1
42.7
94.9
41.5
95.2
41.8
93.4
42.1
101.3
42.5
10
62.5
10.9
74.5
13.1
86.4
15.5
92.9
16.7
98.9
18
110.8
20.5
122.8
23.2
12
62.5
11
74.5
13.3
86.4
15.8
92.9
17
98.9
18.3
110.8
20.9
122.8
23.6
14
62.5
11.2
74.5
13.6
86.4
16.1
92.9
17.4
98.9
18.6
110.8
21.3
122.8
24
16
62.5
11.4
74.5
13.9
86.4
16.4
92.9
17.7
98.9
19
110.8
21.7
122.8
24.4
18
62.5
11.6
74.5
14.1
86.4
16.7
92.9
18
98.9
19.4
110.8
22.2
120.9
25.2
20
62.5
11.8
74.5
14.4
86.4
17
92.9
18.4
98.9
20.1
110.8
23.8
119.1
26.4
21
62.5
12
74.5
14.5
86.4
17.3
92.9
19.1
98.9
20.8
110.8
24.7
118.6
27
23
62.5
12.2
74.5
15.1
86.4
18.5
92.9
20.4
98.9
22.4
110.8
26.5
116.8
28.3
25
62.5
12.9
74.5
16.2
86.4
19.8
92.9
21.8
98.9
23.9
110.8
28.3
115
29.5
27
62.5
13.7
74.5
17.2
86.4
21.1
92.9
23.3
98.9
25.5
110.8
30.3
113.6
30.7
29
62.5
14.5
74.5
18.4
86.4
22.6
92.9
24.8
98.9
27.3
109.4
31.7
111.7
32
31
62.5
15.5
74.5
19.5
86.4
24.1
92.9
26.5
98.9
29.1
107.6
33
109.9
33.2
33
62.5
16.4
74.5
20.8
86.4
25.7
92.9
28.3
98.9
31
106.2
34.2
108.5
34.5
35
62.5
17.5
74.5
22.1
86.4
27.3
92.9
30.2
98.9
33.1
104.4
35.5
106.7
35.8
37
62.5
18.5
74.5
23.5
86.4
29.1
92.9
32.1
98.9
35.3
103
36.7
104.8
37
39
62.5
19.7
74.5
25
86.4
31
92.9
34.2
98.9
37.6
101.2
38
103.5
38.3
42
62.5
20.7
74.5
26.4
86.4
32.8
92.9
36.2
98.9
39.8
99.6
39.2
101.8
39.6
44
62.5
21.8
74.5
27.9
86.4
34.6
92.9
38.2
98.9
42
98
40.5
100.2
40.9
46
62.5
22.9
74.5
29.3
86.4
36.4
92.9
40.2
98.9
44.2
96.5
41.7
98.5
42.1
10
55.6
9.6
66.2
11.6
77.3
13.6
82.3
14.6
87.8
15.7
98.4
17.9
109
20.2
12
55.6
9.8
66.2
11.8
77.3
13.8
82.3
14.9
87.8
16
98.4
18.2
109
20.5
14
55.6
10
66.2
12
77.3
14.1
82.3
15.2
87.8
16.3
98.4
18.6
109
20.9
16
55.6
10.2
66.2
12.2
77.3
14.3
82.3
15.5
87.8
16.6
98.4
19
109
21.3
18
55.6
10.3
66.2
12.4
77.3
14.6
82.3
15.8
87.8
17
98.4
19.3
109
21.8
20
55.6
10.5
66.2
12.7
77.3
14.9
82.3
16.1
87.8
17.3
98.4
20.1
109
23.3
21
55.6
10.6
66.2
12.8
77.3
15.1
82.3
16.2
87.8
17.6
98.4
20.7
109
24.2
23
55.6
10.8
66.2
13
77.3
15.8
82.3
17.3
87.8
18.9
98.4
22.2
109
25.9
25
55.6
11.2
66.2
13.9
77.3
16.8
82.3
18.4
87.8
20.2
98.4
23.8
109
27.7
27
55.6
11.8
66.2
14.7
77.3
18
82.3
19.7
87.8
21.5
98.4
25.5
109
29.7
29
55.6
12.6
66.2
15.7
77.3
19.2
82.3
21
87.8
23
98.4
27.2
109
31.7
31
55.6
13.4
66.2
16.7
77.3
20.4
82.3
22.4
87.8
24.5
98.4
29
109
32.9
33
55.6
14.2
66.2
17.8
77.3
21.7
82.3
23.9
87.8
26.1
98.4
30.9
109
34.2
35
55.6
15.1
66.2
18.9
77.3
23.1
82.3
25.4
87.8
27.8
98.4
33
109
35.4
37
55.6
16
66.2
20.1
77.3
24.6
82.3
27.1
87.8
29.6
98.4
35.1
109
36.7
39
55.6
16.9
66.2
21.3
77.3
26.1
82.3
28.7
87.8
31.5
98.4
37.4
109
37.9
42
55.6
17.8
66.2
22.5
77.3
27.6
82.3
30.4
87.8
33.3
98.4
39.6
109
39.2
44
55.6
18.7
66.2
23.7
77.3
29.1
82.3
32.1
87.8
35.2
98.4
41.9
109
40.4
46
55.6
19.6
66.2
25.1
77.3
30.7
82.3
33.8
87.8
37.1
98.4
44.1
109
41.6
45
Cooling Performance - COOLING PERFORMANCE DATA – 360
Capacity
factor(%)
70%
60%
50%
46
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
22
24
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
48.7
8.5
57.9
10
68
12
72.2
13
76.8
12
48.7
8.6
57.9
10
68
12
72.2
13
76.8
14
86
15.4
95.6
17.3
14
86
15.7
95.6
14
48.7
8.8
57.9
10
68
12
72.2
13
17.6
76.8
14
86
16
95.6
16
48.7
8.9
57.9
11
68
12
72.2
13
18
76.8
14
86
16.3
95.6
18.3
18
48.7
9
57.9
11
68
13
72.2
14
76.8
15
86
16.6
95.6
18.6
20
48.7
9.2
57.9
11
68
13
72.2
14
76.8
15
86
16.9
95.6
19.2
21
48.7
9.3
57.9
11
68
13
72.2
14
76.8
15
86
17.2
95.6
19.9
23
48.7
9.4
57.9
11
68
13
72.2
15
76.8
16
86
18.4
95.6
21.9
25
48.7
9.6
57.9
12
68
14
72.2
15
76.8
17
86
19.7
95.6
22.8
27
48.7
10
57.9
13
68
15
72.2
16
76.8
18
86
21
95.6
24.4
29
48.7
11
57.9
13
68
16
72.2
18
76.8
19
86
22.4
95.6
26
31
48.7
11
57.9
14
68
17
72.2
19
76.8
20
86
23.9
95.6
27.7
33
48.7
12
57.9
15
68
18
72.2
20
76.8
22
86
25.5
95.6
29.6
35
48.7
13
57.9
16
68
19
72.2
21
76.8
23
86
27.1
95.6
31.5
37
48.7
14
57.9
17
68
21
72.2
22
76.8
24
86
28.8
95.6
33.6
39
48.7
14
57.9
18
68
22
72.2
24
76.8
26
86
30.7
95.6
35.8
42
48.7
15
57.9
19
68
23
72.2
25
76.8
27
86
32.5
95.6
37.9
44
48.7
16
57.9
20
68
24
72.2
27
76.8
29
86
34.3
95.6
40
46
48.7
17
57.9
21
68
26
72.2
28
76.8
30
86
36.1
95.6
42.1
10
41.8
7.4
49.7
8.7
58
10
61.6
11
65.8
11
74
13
81.8
14.5
12
41.8
7.5
49.7
8.8
58
10
61.6
11
65.8
12
74
13.2
81.8
14.8
14
41.8
7.6
49.7
9
58
10
61.6
11
65.8
12
74
13.5
81.8
15.1
16
41.8
7.7
49.7
9.1
58
11
61.6
11
65.8
12
74
13.7
81.8
15.4
18
41.8
7.8
49.7
9.2
58
11
61.6
12
65.8
12
74
13.9
81.8
15.7
20
41.8
7.9
49.7
9.4
58
11
61.6
12
65.8
13
74
14.2
81.8
16
21
41.8
8
49.7
9.5
58
11
61.6
12
65.8
13
74
14.3
81.8
16.2
23
41.8
8.1
49.7
9.6
58
11
61.6
12
65.8
13
74
14.9
81.8
17.2
25
41.8
8.3
49.7
9.8
58
12
61.6
13
65.8
14
74
16
81.8
18.3
27
41.8
8.6
49.7
10
58
12
61.6
14
65.8
15
74
17
81.8
19.5
29
41.8
9.1
49.7
11
58
13
61.6
14
65.8
16
74
18.1
81.8
20.9
31
41.8
9.6
49.7
12
58
14
61.6
15
65.8
17
74
19.3
81.8
22.2
33
41.8
10
49.7
13
58
15
61.6
16
65.8
18
74
20.5
81.8
23.7
35
41.8
11
49.7
13
58
16
61.6
17
65.8
19
74
21.8
81.8
25.2
37
41.8
11
49.7
14
58
17
61.6
18
65.8
20
74
23.2
81.8
26.8
39
41.8
12
49.7
15
58
18
61.6
19
65.8
21
74
24.6
81.8
28.5
42
41.8
13
49.7
16
58
19
61.6
21
65.8
22
74
26
81.8
30.1
44
41.8
13
49.7
16
58
20
61.6
22
65.8
24
74
27.4
81.8
31.8
33.4
46
41.8
14
49.7
17
58
21
61.6
23
65.8
25
74
28.9
81.8
10
34.8
6.3
41.4
7.3
48
8.4
51.5
9
54.7
9.6
61.6
10.7
68.1
11.9
12
34.8
6.5
41.4
7.5
48
8.6
51.5
9.1
54.7
9.7
61.6
10.9
68.1
12.1
14
34.8
6.5
41.4
7.5
48
8.7
51.5
9.2
54.7
9.8
61.6
11
68.1
12.3
16
34.8
6.6
41.4
7.7
48
8.8
51.5
9.4
54.7
10
61.6
11.2
68.1
12.6
18
34.8
6.7
41.4
7.8
48
9
51.5
9.6
54.7
10
61.6
11.4
68.1
12.8
20
34.8
6.8
41.4
7.9
48
9.1
51.5
9.7
54.7
10
61.6
11.6
68.1
13.1
21
34.8
6.9
41.4
8
48
9.2
51.5
9.8
54.7
10
61.6
11.8
68.1
13.2
23
34.8
6.9
41.4
8.1
48
9.4
51.5
10
54.7
11
61.6
12
68.1
13.5
25
34.8
7.1
41.4
8.2
48
9.5
51.5
10
54.7
11
61.6
12.6
68.1
14.3
27
34.8
7.1
41.4
8.6
48
10
51.5
11
54.7
12
61.6
13.4
68.1
15.3
29
34.8
7.6
41.4
9
48
11
51.5
12
54.7
12
61.6
14.3
68.1
16.3
31
34.8
8
41.4
9.6
48
11
51.5
12
54.7
13
61.6
15.1
68.1
17.4
33
34.8
8.5
41.4
10
48
12
51.5
13
54.7
14
61.6
16.1
68.1
18.4
35
34.8
9
41.4
11
48
13
51.5
14
54.7
15
61.6
17.1
68.1
19.6
37
34.8
9.4
41.4
11
48
13
51.5
15
54.7
16
61.6
18.2
68.1
20.8
39
34.8
9.9
41.4
12
48
14
51.5
15
54.7
17
61.6
17.5
68.1
22.1
42
34.8
10
41.4
13
48
15
51.5
16
54.7
18
61.6
18
68.1
23.3
44
34.8
11
41.4
13
48
16
51.5
17
54.7
19
61.6
18.2
68.1
24.6
46
34.8
11
41.4
14
48
17
51.5
18
54.7
20
61.6
18.4
68.1
25.8
Cooling Performance - COOLING PERFORMANCE DATA – 380
Capacity
factor(%)
100%
90%
80%
Outdoor ambient
temperature (DB°C)
14
16
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
24.4
22
24
TC
kW
PI
kW
TC
kW
10
71.8
12.4
85.6
15
99.4
17.7
106.5
19.2
113.6
20.6
127.4
23.5
134.6
12
71.8
12.6
85.6
15.3
99.4
18.1
106.5
19.6
113.6
21
127.4
24
134.6
24.3
14
71.8
12.8
85.6
15.5
99.4
18.4
106.5
19.9
113.6
21.4
127.4
24.5
131.2
24.2
16
71.8
13
85.6
15.8
99.4
18.8
106.5
20.3
113.6
21.8
126.9
24.8
129.3
24.6
18
71.8
13.3
85.6
16.2
99.4
19.2
106.5
20.7
113.6
22.2
125
25.6
127.9
25.8
20
71.8
13.6
85.6
16.5
99.4
19.7
106.5
21.8
113.6
23.9
123.6
26.8
126
27
21
71.8
13.7
85.6
16.6
99.4
20.5
106.5
22.5
113.6
24.7
122.7
27.4
125
27.7
23
71.8
14
85.6
17.7
99.4
21.9
106.5
24.2
113.6
26.5
120.8
28.7
123.1
28.9
25
71.8
15
85.6
19
99.4
23.4
106.5
25.9
113.6
28.4
117.4
30
121.7
30.2
27
71.8
15.9
85.6
20.2
99.4
25
106.5
27.6
113.6
30.4
115.5
31.2
119.8
31.5
29
71.8
17
85.6
21.6
99.4
26.8
106.5
29.5
113.2
32.2
113.6
32.6
118.4
32.8
31
71.8
18.1
85.6
23
99.4
28.5
106.5
31.5
111.3
33.5
112.2
33.8
116.5
34.1
33
71.8
19.2
85.6
24.5
99.4
30.4
106.5
33.6
109.4
34.8
110.3
35
114.6
35.4
35
71.8
20.4
85.6
26.1
99.4
32.4
106.5
35.9
107.9
36
113.6
36.3
113.2
36.7
37
71.8
21.7
85.6
27.7
99.4
34.6
104.6
37.1
106
37.3
108.9
37.6
111.3
38
39
71.8
23.1
85.6
29.5
99.4
36.8
103.2
38.4
104.1
38.6
107
38.9
109.4
39.3
42
71.8
24.4
85.6
31.2
99.4
39
101.4
39.6
102.2
39.9
103.2
40.2
107.5
40.6
44
71.8
25.7
85.6
32.9
99.4
41.2
99.8
40.9
100.3
41.2
99.8
41.5
105.5
41.9
46
71.8
27.2
85.6
34.3
99.4
43.4
98.2
42.2
98.4
42.5
96.5
42.8
104.7
43.2
10
64.7
11.1
77
13.3
89.4
15.7
96
17
102.2
18.3
114.6
20.9
126.9
23.5
12
64.7
11.2
77
13.6
89.4
16
96
17.3
102.2
18.6
114.6
21.3
126.9
24
14
64.7
11.4
77
13.8
89.4
16.4
96
17.7
102.2
19
114.6
21.7
126.9
24.4
16
64.7
11.6
77
14.1
89.4
16.6
96
18
102.2
19.3
114.6
22.1
126.9
24.8
18
64.7
11.8
77
14.4
89.4
17
96
18.3
102.2
19.7
114.6
22.5
125
25.6
20
64.7
12
77
14.6
89.4
17.3
96
18.7
102.2
20.5
114.6
24.2
123.1
26.8
21
64.7
12.2
77
14.8
89.4
17.6
96
19.4
102.2
21.1
114.6
25.1
122.7
27.4
23
64.7
12.4
77
15.4
89.4
18.8
96
20.7
102.2
22.7
114.6
26.9
120.8
28.7
25
64.7
13.1
77
16.4
89.4
20.1
96
22.2
102.2
24.3
114.6
28.8
118.9
30
27
64.7
13.9
77
17.5
89.4
21.5
96
23.7
102.2
25.9
114.6
30.8
117.4
31.2
29
64.7
14.8
77
18.7
89.4
22.9
96
25.3
102.2
27.7
113.2
32.2
115.5
32.5
31
64.7
15.7
77
19.8
89.4
24.5
96
27
102.2
29.6
111.3
33.5
113.6
33.7
33
64.7
16.7
77
21.1
89.4
26.1
96
28.7
102.2
31.5
109.8
34.8
112.2
35
35
64.7
17.8
77
22.4
89.4
27.8
96
30.7
102.2
33.7
107.9
36.1
110.3
36.3
37
64.7
18.8
77
23.9
89.4
29.6
96
32.6
102.2
35.9
106.5
37.3
108.4
37.6
39
64.7
20
77
25.4
89.4
31.5
96
34.8
102.2
38.2
104.6
38.6
107
38.9
42
64.7
21.1
77
26.8
89.4
33.3
96
36.8
102.2
40.4
103
39.9
105.2
40.2
44
64.7
22.2
77
28.3
89.4
35.2
96
38.8
102.2
42.7
101.3
41.1
103.6
41.5
46
64.7
23.3
77
29.8
89.4
37
96
40.9
102.2
44.9
99.8
42.4
101.9
42.8
10
57.5
9.8
68.5
11.8
79.9
13.8
85.1
14.9
90.8
15.9
101.7
18.2
112.7
20.5
12
57.5
10
68.5
12
79.9
14
85.1
15.1
90.8
16.3
101.7
18.5
112.7
20.9
14
57.5
10.1
68.5
12.2
79.9
14.3
85.1
15.5
90.8
16.6
101.7
18.9
112.7
21.3
16
57.5
10.3
68.5
12.4
79.9
14.6
85.1
15.7
90.8
16.9
101.7
19.3
112.7
21.7
18
57.5
10.5
68.5
12.6
79.9
14.9
85.1
16
90.8
17.2
101.7
19.6
112.7
22.2
20
57.5
10.7
68.5
12.9
79.9
15.1
85.1
16.4
90.8
17.6
101.7
20.4
112.7
23.7
21
57.5
10.7
68.5
13
79.9
15.3
85.1
16.5
90.8
17.9
101.7
21.1
112.7
24.6
23
57.5
10.9
68.5
13.2
79.9
16
85.1
17.6
90.8
19.2
101.7
22.6
112.7
26.3
25
57.5
11.4
68.5
14.1
79.9
17.1
85.1
18.8
90.8
20.5
101.7
24.2
112.7
28.2
27
57.5
12
68.5
15
79.9
18.3
85.1
20.1
90.8
21.9
101.7
25.9
112.7
30.2
29
57.5
12.8
68.5
15.9
79.9
19.5
85.1
21.4
90.8
23.3
101.7
27.6
112.7
32.2
31
57.5
13.6
68.5
17
79.9
20.7
85.1
22.8
90.8
24.9
101.7
29.5
112.7
33.5
33
57.5
14.4
68.5
18.1
79.9
22.1
85.1
24.3
90.8
26.6
101.7
31.4
112.7
34.8
35
57.5
15.3
68.5
19.2
79.9
23.5
85.1
25.8
90.8
28.3
101.7
33.5
112.7
36
37
57.5
16.2
68.5
20.4
79.9
25
85.1
27.5
90.8
30.1
101.7
35.7
112.7
37.3
39
57.5
17.2
68.5
21.6
79.9
26.6
85.1
29.2
90.8
32
101.7
38
112.7
38.5
42
57.5
18.1
68.5
22.9
79.9
28.1
85.1
30.9
90.8
33.9
101.7
40.3
112.7
39.8
44
57.5
19
68.5
24.1
79.9
29.6
85.1
32.6
90.8
35.8
101.7
42.5
112.7
41.1
46
57.5
19.9
68.5
25.5
79.9
31.2
85.1
34.3
90.8
37.7
101.7
44.8
112.7
42.3
47
Cooling Performance - COOLING PERFORMANCE DATA – 380
Capacity
factor(%)
70%
60%
50%
48
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
50.4
8.6
59.9
10
70
12
74.6
13
79.4
12
50.4
8.8
59.9
10
70
12
74.6
13
79.4
14
50.4
8.9
59.9
11
70
12
74.6
13
16
50.4
9
59.9
11
70
13
74.6
18
50.4
9.2
59.9
11
70
13
20
50.4
9.4
59.9
11
70
21
50.4
9.4
59.9
11
23
50.4
9.6
59.9
12
25
50.4
9.8
59.9
27
50.4
10
29
50.4
31
22
24
TC
kW
PI
kW
TC
kW
PI
kW
14
88.9
15.7
98.9
17.6
14
88.9
15.9
98.9
17.9
79.4
14
88.9
16.2
98.9
18.3
14
79.4
15
88.9
16.6
98.9
18.6
74.6
14
79.4
15
88.9
16.8
98.9
19
13
74.6
14
79.4
15
88.9
17.2
98.9
19.5
70
13
74.6
14
79.4
15
88.9
17.5
98.9
20.2
70
14
74.6
15
79.4
16
88.9
18.7
98.9
22.3
12
70
14
74.6
16
79.4
17
88.9
20
98.9
23.1
59.9
13
70
15
74.6
17
79.4
18
88.9
21.4
98.9
24.8
11
59.9
14
70
16
74.6
18
79.4
19
88.9
22.8
98.9
26.4
50.4
12
59.9
14
70
17
74.6
19
79.4
21
88.9
24.3
98.9
28.2
33
50.4
12
59.9
15
70
18
74.6
20
79.4
22
88.9
25.9
98.9
30
35
50.4
13
59.9
16
70
20
74.6
21
79.4
23
88.9
27.5
98.9
32
37
50.4
14
59.9
17
70
21
74.6
23
79.4
25
88.9
29.3
98.9
34.1
39
50.4
15
59.9
18
70
22
74.6
24
79.4
26
88.9
31.2
98.9
36.3
42
50.4
15
59.9
19
70
23
74.6
26
79.4
28
88.9
33
98.9
38.5
44
50.4
16
59.9
20
70
25
74.6
27
79.4
29
88.9
34.9
98.9
40.6
46
50.4
17
59.9
21
70
26
74.6
28
79.4
31
88.9
36.7
98.9
42.8
10
43.3
7.5
51.3
8.8
60
10
63.7
11
68
12
76.5
13.2
84.6
14.8
12
43.3
7.6
51.3
9
60
10
63.7
11
68
12
76.5
13.4
84.6
15.1
14
43.3
7.7
51.3
9.1
60
11
63.7
11
68
12
76.5
13.7
84.6
15.3
16
43.3
7.9
51.3
9.2
60
11
63.7
12
68
12
76.5
13.9
84.6
15.6
18
43.3
7.9
51.3
9.4
60
11
63.7
12
68
13
76.5
14.2
84.6
15.9
20
43.3
8.1
51.3
9.6
60
11
63.7
12
68
13
76.5
14.4
84.6
16.2
21
43.3
8.1
51.3
9.6
60
11
63.7
12
68
13
76.5
14.6
84.6
16.4
23
43.3
8.3
51.3
9.8
60
11
63.7
12
68
13
76.5
15.2
84.6
17.5
25
43.3
8.4
51.3
10
60
12
63.7
13
68
14
76.5
16.2
84.6
18.6
27
43.3
8.8
51.3
11
60
13
63.7
14
68
15
76.5
17.2
84.6
19.8
29
43.3
9.2
51.3
11
60
13
63.7
15
68
16
76.5
18.4
84.6
21.2
31
43.3
9.8
51.3
12
60
14
63.7
16
68
17
76.5
19.6
84.6
22.6
33
43.3
10
51.3
13
60
15
63.7
17
68
18
76.5
20.9
84.6
24.1
35
43.3
11
51.3
13
60
16
63.7
18
68
19
76.5
22.2
84.6
25.6
37
43.3
12
51.3
14
60
17
63.7
19
68
20
76.5
23.5
84.6
27.2
39
43.3
12
51.3
15
60
18
63.7
20
68
21
76.5
25
84.6
28.9
42
43.3
13
51.3
16
60
19
63.7
21
68
23
76.5
26.5
84.6
30.6
44
43.3
14
51.3
17
60
20
63.7
22
68
24
76.5
27.9
84.6
32.3
46
43.3
14
51.3
18
60
21
63.7
23
68
25
76.5
29.3
84.6
33.9
10
35.9
6.4
42.8
7.5
50
8.6
53.3
9.1
56.6
9.7
63.7
10.9
70.4
12.1
12
35.9
6.6
42.8
7.6
50
8.7
53.3
9.2
56.6
9.9
63.7
11.1
70.4
12.3
14
35.9
6.6
42.8
7.7
50
8.8
53.3
9.4
56.6
10
63.7
11.2
70.4
12.5
16
35.9
6.7
42.8
7.8
50
9
53.3
9.6
56.6
10
63.7
11.4
70.4
12.8
18
35.9
6.8
42.8
7.9
50
9.1
53.3
9.7
56.6
10
63.7
11.6
70.4
13
20
35.9
6.9
42.8
8.1
50
9.2
53.3
9.9
56.6
11
63.7
11.8
70.4
13.3
21
35.9
7
42.8
8.1
50
9.3
53.3
10
56.6
11
63.7
12
70.4
13.4
23
35.9
7
42.8
8.2
50
9.5
53.3
10
56.6
11
63.7
12.2
70.4
13.7
25
35.9
7.2
42.8
8.3
50
9.6
53.3
10
56.6
11
63.7
12.8
70.4
14.6
27
35.9
7.3
42.8
8.7
50
10
53.3
11
56.6
12
63.7
13.6
70.4
15.5
29
35.9
7.7
42.8
9.2
50
11
53.3
12
56.6
13
63.7
14.5
70.4
16.6
31
35.9
8.1
42.8
9.7
50
12
53.3
12
56.6
13
63.7
15.4
70.4
17.7
33
35.9
8.6
42.8
10
50
12
53.3
13
56.6
14
63.7
16.4
70.4
18.8
35
35.9
9.1
42.8
11
50
13
53.3
14
56.6
15
63.7
17.4
70.4
19.9
37
35.9
9.6
42.8
12
50
14
53.3
15
56.6
16
63.7
18.5
70.4
21.1
39
35.9
10
42.8
12
50
14
53.3
16
56.6
17
63.7
17.8
70.4
22.4
42
35.9
11
42.8
13
50
15
53.3
16
56.6
18
63.7
18.3
70.4
23.7
44
35.9
11
42.8
14
50
16
53.3
17
56.6
19
63.7
18.5
70.4
25
46
35.9
12
42.8
14
50
17
53.3
18
56.6
20
63.7
18.7
70.4
26.2
Cooling Performance - COOLING PERFORMANCE DATA – 400
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
77.9
13.3
92.8
16.1
107.8
19
115.5
20.5
123.2
22.1
138.2
25.2
145.9
12
77.9
13.5
92.8
16.4
107.8
19.4
115.5
21
123.2
22.5
138.2
25.7
145.9
26
14
77.9
13.7
92.8
16.6
107.8
19.7
115.5
21.3
123.2
22.9
138.2
26.2
142.3
25.9
16
77.9
13.9
92.8
16.9
107.8
20.2
115.5
21.8
123.2
23.4
137.7
26.5
140.3
26.3
18
77.9
14.2
92.8
17.3
107.8
20.5
115.5
22.2
123.2
23.8
135.6
27.4
138.7
27.6
20
77.9
14.5
92.8
17.7
107.8
21.1
115.5
23.3
123.2
25.6
134.1
28.7
136.6
29
21
77.9
14.7
92.8
17.8
107.8
21.9
115.5
24.1
123.2
26.5
133
29.4
135.6
29.7
23
77.9
15
92.8
19
107.8
23.5
115.5
25.9
123.2
28.4
131
30.8
133.5
31
25
77.9
16.1
92.8
20.3
107.8
25.1
115.5
27.7
123.2
30.4
127.4
32.1
132
32.4
27
77.9
17.1
92.8
21.6
107.8
26.8
115.5
29.6
123.2
32.6
125.3
33.4
129.9
33.7
29
77.9
18.2
92.8
23.1
107.8
28.7
115.5
31.6
122.7
34.5
123.2
35
128.4
35.1
31
77.9
19.4
92.8
24.6
107.8
30.6
115.5
33.8
120.7
35.9
121.7
36.2
126.3
36.5
33
77.9
20.6
92.8
26.2
107.8
32.6
115.5
36
118.6
37.2
119.6
37.5
124.3
37.9
35
77.9
21.8
92.8
27.9
107.8
34.8
115.5
38.4
117
38.6
123.2
38.9
122.7
39.3
37
77.9
23.2
92.8
29.7
107.8
37
113.4
39.7
115
40
118.1
40.3
120.7
40.7
39
77.9
24.7
92.8
31.6
107.8
39.4
111.9
41.1
112.9
41.4
116
41.7
118.6
42.1
42
77.9
26.1
92.8
33.4
107.8
41.8
110
42.5
110.9
42.7
111.9
43.1
116.5
43.5
44
77.9
27.6
92.8
35.2
107.8
44.1
108.2
43.8
108.8
44.1
108.3
44.5
114.5
44.9
46
77.9
29.1
92.8
36.8
107.8
46.5
106.5
45.2
106.7
45.5
104.7
45.9
113.5
46.3
10
70.1
11.9
83.5
14.3
96.9
16.9
104.2
18.2
110.9
19.6
124.3
22.4
137.7
25.2
12
70.1
12
83.5
14.5
96.9
17.2
104.2
18.6
110.9
19.9
124.3
22.8
137.7
25.7
14
70.1
12.2
83.5
14.8
96.9
17.5
104.2
18.9
110.9
20.3
124.3
23.2
137.7
26.2
16
70.1
12.5
83.5
15.1
96.9
17.8
104.2
19.3
110.9
20.7
124.3
23.7
137.7
26.6
18
70.1
12.7
83.5
15.4
96.9
18.2
104.2
19.6
110.9
21.1
124.3
24.1
135.6
27.4
20
70.1
12.9
83.5
15.7
96.9
18.6
104.2
20
110.9
21.9
124.3
26
133.5
28.7
21
70.1
13.1
83.5
15.8
96.9
18.8
104.2
20.7
110.9
22.7
124.3
26.9
133
29.4
23
70.1
13.3
83.5
16.5
96.9
20.2
104.2
22.2
110.9
24.3
124.3
28.8
131
30.8
25
70.1
14
83.5
17.6
96.9
21.6
104.2
23.8
110.9
26
124.3
30.9
128.9
32.1
27
70.1
14.9
83.5
18.8
96.9
23
104.2
25.4
110.9
27.8
124.3
33
127.4
33.4
29
70.1
15.8
83.5
20
96.9
24.6
104.2
27.1
110.9
29.7
122.7
34.5
125.3
34.8
31
70.1
16.9
83.5
21.3
96.9
26.2
104.2
28.9
110.9
31.7
120.7
35.9
123.2
36.1
33
70.1
17.9
83.5
22.7
96.9
27.9
104.2
30.8
110.9
33.8
119.1
37.2
121.7
37.5
35
70.1
19.1
83.5
24
96.9
29.8
104.2
32.8
110.9
36.1
117
38.6
119.6
38.9
37
70.1
20.2
83.5
25.6
96.9
31.7
104.2
35
110.9
38.4
115.5
40
117.6
40.3
39
70.1
21.4
83.5
27.2
96.9
33.7
104.2
37.2
110.9
40.9
113.4
41.4
116
41.7
42
70.1
22.6
83.5
28.8
96.9
35.7
104.2
39.4
110.9
43.3
111.7
42.7
114.1
43.1
44
70.1
23.7
83.5
30.3
96.9
37.7
104.2
41.6
110.9
45.7
109.9
44.1
112.3
44.5
46
70.1
24.9
83.5
31.9
96.9
39.6
104.2
43.8
110.9
48.1
108.2
45.4
110.5
45.9
10
62.4
10.5
74.3
12.6
86.6
14.8
92.3
15.9
98.5
17.1
110.3
19.5
122.2
22
12
62.4
10.7
74.3
12.8
86.6
15
92.3
16.2
98.5
17.5
110.3
19.9
122.2
22.4
14
62.4
10.9
74.3
13.1
86.6
15.3
92.3
16.6
98.5
17.7
110.3
20.2
122.2
22.8
16
62.4
11.1
74.3
13.3
86.6
15.6
92.3
16.9
98.5
18.1
110.3
20.7
122.2
23.2
18
62.4
11.2
74.3
13.5
86.6
15.9
92.3
17.2
98.5
18.5
110.3
21
122.2
23.8
20
62.4
11.4
74.3
13.8
86.6
16.2
92.3
17.5
98.5
18.8
110.3
21.8
122.2
25.4
21
62.4
11.5
74.3
13.9
86.6
16.4
92.3
17.7
98.5
19.2
110.3
22.6
122.2
26.3
23
62.4
11.7
74.3
14.2
86.6
17.2
92.3
18.8
98.5
20.5
110.3
24.2
122.2
28.2
25
62.4
12.2
74.3
15.1
86.6
18.3
92.3
20.1
98.5
22
110.3
25.9
122.2
30.2
27
62.4
12.9
74.3
16.1
86.6
19.6
92.3
21.5
98.5
23.5
110.3
27.7
122.2
32.3
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
26.2
29
62.4
13.7
74.3
17.1
86.6
20.9
92.3
22.9
98.5
25
110.3
29.6
122.2
34.5
31
62.4
14.6
74.3
18.2
86.6
22.2
92.3
24.4
98.5
26.7
110.3
31.6
122.2
35.9
33
62.4
15.5
74.3
19.4
86.6
23.7
92.3
26
98.5
28.4
110.3
33.7
122.2
37.2
35
62.4
16.4
74.3
20.5
86.6
25.1
92.3
27.6
98.5
30.3
110.3
35.9
122.2
38.6
37
62.4
17.4
74.3
21.8
86.6
26.8
92.3
29.5
98.5
32.3
110.3
38.3
122.2
40
39
62.4
18.4
74.3
23.2
86.6
28.4
92.3
31.3
98.5
34.3
110.3
40.8
122.2
41.3
42
62.4
19.4
74.3
24.5
86.6
30.1
92.3
33.1
98.5
36.3
110.3
43.2
122.2
42.6
44
62.4
20.4
74.3
25.8
86.6
31.7
92.3
35
98.5
38.3
110.3
45.6
122.2
44
46
62.4
21.4
74.3
27.3
86.6
33.4
92.3
36.8
98.5
40.4
110.3
48
122.2
45.3
49
Cooling Performance - COOLING PERFORMANCE DATA – 400
Capacity
factor(%)
70%
60%
50%
50
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
54.7
9.2
65
11
76
13
81
14
86.1
12
54.7
9.4
65
11
76
13
81
14
86.1
14
54.7
9.5
65
11
76
13
81
14
16
54.7
9.7
65
12
76
14
81
18
54.7
9.8
65
12
76
14
20
54.7
10
65
12
76
21
54.7
10
65
12
23
54.7
10
65
25
54.7
11
27
54.7
29
54.7
31
54.7
33
22
24
TC
kW
PI
kW
TC
kW
PI
kW
15
96.4
16.8
107.3
18.8
15
96.4
17.1
107.3
19.2
86.1
15
96.4
17.4
107.3
19.6
15
86.1
16
96.4
17.7
107.3
19.9
81
15
86.1
16
96.4
18
107.3
20.3
14
81
15
86.1
16
96.4
18.4
107.3
20.9
76
14
81
15
86.1
16
96.4
18.7
107.3
21.6
12
76
14
81
16
86.1
17
96.4
20
107.3
23.9
65
13
76
15
81
17
86.1
18
96.4
21.4
107.3
24.8
11
65
14
76
16
81
18
86.1
20
96.4
22.9
107.3
26.5
12
65
14
76
18
81
19
86.1
21
96.4
24.4
107.3
28.3
13
65
15
76
19
81
20
86.1
22
96.4
26
107.3
30.2
54.7
13
65
16
76
20
81
22
86.1
24
96.4
27.7
107.3
32.2
35
54.7
14
65
17
76
21
81
23
86.1
25
96.4
29.5
107.3
34.3
37
54.7
15
65
18
76
22
81
24
86.1
27
96.4
31.4
107.3
36.6
39
54.7
16
65
19
76
24
81
26
86.1
28
96.4
33.4
107.3
38.9
42
54.7
17
65
21
76
25
81
27
86.1
30
96.4
35.4
107.3
41.2
44
54.7
17
65
22
76
26
81
29
86.1
32
96.4
37.4
107.3
43.5
46
54.7
18
65
23
76
28
81
30
86.1
33
96.4
39.4
107.3
45.8
10
46.9
8.1
55.7
9.5
65
11
69.1
12
73.7
13
83
14.2
91.8
15.8
12
46.9
8.1
55.7
9.6
65
11
69.1
12
73.7
13
83
14.4
91.8
16.1
14
46.9
8.3
55.7
9.8
65
11
69.1
12
73.7
13
83
14.7
91.8
16.4
16
46.9
8.4
55.7
9.9
65
12
69.1
12
73.7
13
83
14.9
91.8
16.7
18
46.9
8.5
55.7
10
65
12
69.1
13
73.7
13
83
15.2
91.8
17.1
20
46.9
8.7
55.7
10
65
12
69.1
13
73.7
14
83
15.5
91.8
17.4
21
46.9
8.7
55.7
10
65
12
69.1
13
73.7
14
83
15.6
91.8
17.6
23
46.9
8.9
55.7
11
65
12
69.1
13
73.7
14
83
16.3
91.8
18.7
25
46.9
9
55.7
11
65
13
69.1
14
73.7
15
83
17.4
91.8
19.9
27
46.9
9.4
55.7
11
65
14
69.1
15
73.7
16
83
18.5
91.8
21.3
29
46.9
9.9
55.7
12
65
14
69.1
16
73.7
17
83
19.7
91.8
22.7
31
46.9
11
55.7
13
65
15
69.1
17
73.7
18
83
21
91.8
24.2
33
46.9
11
55.7
14
65
16
69.1
18
73.7
19
83
22.4
91.8
25.8
35
46.9
12
55.7
14
65
17
69.1
19
73.7
20
83
23.8
91.8
27.4
37
46.9
12
55.7
15
65
18
69.1
20
73.7
22
83
25.2
91.8
29.2
39
46.9
13
55.7
16
65
19
69.1
21
73.7
23
83
26.8
91.8
31
42
46.9
14
55.7
17
65
20
69.1
22
73.7
24
83
28.4
91.8
32.8
44
46.9
15
55.7
18
65
22
69.1
24
73.7
26
83
29.9
91.8
34.6
46
46.9
15
55.7
19
65
23
69.1
25
73.7
27
83
31.4
91.8
36.4
10
39
6.9
46.4
8
54
9.2
57.8
9.8
61.4
10
69.1
11.7
76.3
13
12
39
7
46.4
8.1
54
9.3
57.8
9.9
61.4
11
69.1
11.9
76.3
13.2
14
39
7.1
46.4
8.2
54
9.5
57.8
10
61.4
11
69.1
12
76.3
13.4
16
39
7.2
46.4
8.4
54
9.6
57.8
10
61.4
11
69.1
12.2
76.3
13.7
18
39
7.3
46.4
8.5
54
9.8
57.8
10
61.4
11
69.1
12.5
76.3
13.9
20
39
7.4
46.4
8.7
54
9.9
57.8
11
61.4
11
69.1
12.7
76.3
14.2
21
39
7.5
46.4
8.7
54
10
57.8
11
61.4
11
69.1
12.8
76.3
14.4
23
39
7.6
46.4
8.8
54
10
57.8
11
61.4
12
69.1
13.1
76.3
14.7
25
39
7.7
46.4
8.9
54
10
57.8
11
61.4
12
69.1
13.7
76.3
15.6
27
39
7.8
46.4
9.3
54
11
57.8
12
61.4
13
69.1
14.6
76.3
16.6
29
39
8.3
46.4
9.8
54
12
57.8
13
61.4
14
69.1
15.5
76.3
17.7
31
39
8.7
46.4
10
54
12
57.8
13
61.4
14
69.1
16.5
76.3
18.9
33
39
9.2
46.4
11
54
13
57.8
14
61.4
15
69.1
17.5
76.3
20.1
35
39
9.8
46.4
12
54
14
57.8
15
61.4
16
69.1
18.6
76.3
21.3
37
39
10
46.4
12
54
15
57.8
16
61.4
17
69.1
19.8
76.3
22.7
39
39
11
46.4
13
54
16
57.8
17
61.4
18
69.1
19.1
76.3
24
42
39
11
46.4
14
54
16
57.8
18
61.4
19
69.1
19.6
76.3
25.4
44
39
12
46.4
14
54
17
57.8
19
61.4
20
69.1
19.8
76.3
26.7
46
39
12
46.4
15
54
18
57.8
19
61.4
22
69.1
20.1
76.3
28.1
Cooling Performance - COOLING PERFORMANCE DATA – 420
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
81.2
14.5
96.8
17.6
112.4
20.8
120.5
22.4
128.6
24.1
144.2
27.6
152.2
28.6
12
81.2
14.7
96.8
17.9
112.4
21.2
120.5
22.9
128.6
24.6
144.2
28.1
152.2
28.5
14
81.2
15
96.8
18.2
112.4
21.6
120.5
23.3
128.6
25.1
144.2
28.7
148.5
28.3
16
81.2
15.2
96.8
18.5
112.4
22
120.5
23.8
128.6
25.6
143.6
29
146.3
28.8
18
81.2
15.5
96.8
18.9
112.4
22.4
120.5
24.3
128.6
26
141.5
30
144.7
30.2
20
81.2
15.9
96.8
19.3
112.4
23.1
120.5
25.5
128.6
28
139.9
31.4
142.6
31.7
21
81.2
16
96.8
19.5
112.4
24
120.5
26.4
128.6
28.9
138.8
32.1
141.5
32.5
23
81.2
16.4
96.8
20.8
112.4
25.6
120.5
28.3
128.6
31
136.6
33.7
139.3
33.9
25
81.2
17.6
96.8
22.2
112.4
27.4
120.5
30.3
128.6
33.3
132.9
35.1
137.7
35.4
27
81.2
18.7
96.8
23.6
112.4
29.3
120.5
32.4
128.6
35.6
130.7
36.5
135.6
36.9
29
81.2
19.9
96.8
25.2
112.4
31.3
120.5
34.5
128
37.8
128.6
38.2
133.9
38.4
31
81.2
21.2
96.8
26.9
112.4
33.4
120.5
37
125.9
39.2
127
39.6
131.8
39.9
33
81.2
22.5
96.8
28.7
112.4
35.6
120.5
39.4
123.7
40.7
124.8
41
129.6
41.4
35
81.2
23.9
96.8
30.5
112.4
38
120.5
42
122.1
42.2
128.6
42.6
128
43
37
81.2
25.4
96.8
32.5
112.4
40.5
118.3
43.4
120
43.7
123.2
44.1
125.9
44.5
39
81.2
27
96.8
34.5
112.4
43.1
116.7
45
117.8
45.2
121
45.6
123.7
46
42
81.2
28.6
96.8
36.5
112.4
45.7
114.8
46.4
115.7
46.7
116.7
47.1
121.6
47.5
44
81.2
30.1
96.8
38.5
112.4
48.2
112.9
47.9
113.5
48.3
113
48.7
119.4
49.1
46
81.2
31.8
96.8
40.2
112.4
50.8
111.1
49.4
111.3
49.8
109.2
50.2
118.5
50.6
10
73.2
13
87.1
15.6
101.1
18.4
108.7
19.9
115.7
21.4
129.6
24.4
143.6
27.6
12
73.2
13.1
87.1
15.9
101.1
18.8
108.7
20.3
115.7
21.8
129.6
24.9
143.6
28.1
14
73.2
13.4
87.1
16.2
101.1
19.2
108.7
20.7
115.7
22.2
129.6
25.4
143.6
28.6
16
73.2
13.6
87.1
16.5
101.1
19.5
108.7
21.1
115.7
22.6
129.6
25.9
143.6
29.1
18
73.2
13.9
87.1
16.8
101.1
19.9
108.7
21.5
115.7
23.1
129.6
26.4
141.5
30
20
73.2
14.1
87.1
17.2
101.1
20.3
108.7
21.9
115.7
24
129.6
28.4
139.3
31.4
21
73.2
14.3
87.1
17.3
101.1
20.6
108.7
22.7
115.7
24.8
129.6
29.4
138.8
32.1
23
73.2
14.5
87.1
18
101.1
22
108.7
24.3
115.7
26.6
129.6
31.5
136.6
33.7
25
73.2
15.3
87.1
19.2
101.1
23.6
108.7
26
115.7
28.5
129.6
33.7
134.5
35.1
27
73.2
16.3
87.1
20.5
101.1
25.2
108.7
27.7
115.7
30.4
129.6
36.1
132.9
36.5
29
73.2
17.3
87.1
21.9
101.1
26.9
108.7
29.6
115.7
32.5
128
37.8
130.7
38.1
31
73.2
18.4
87.1
23.2
101.1
28.7
108.7
31.6
115.7
34.6
125.9
39.3
128.6
39.5
33
73.2
19.6
87.1
24.8
101.1
30.5
108.7
33.7
115.7
37
124.3
40.7
127
41
35
73.2
20.8
87.1
26.3
101.1
32.5
108.7
35.9
115.7
39.4
122.1
42.2
124.8
42.6
37
73.2
22
87.1
28
101.1
34.6
108.7
38.2
115.7
42
120.5
43.7
122.7
44.1
39
73.2
23.4
87.1
29.7
101.1
36.9
108.7
40.7
115.7
44.7
118.3
45.2
121
45.6
42
73.2
24.7
87.1
31.4
101.1
39
108.7
43.1
115.7
47.3
116.6
46.7
119.1
47.1
44
73.2
25.9
87.1
33.2
101.1
41.2
108.7
45.5
115.7
50
114.7
48.2
117.2
48.7
46
73.2
27.2
87.1
34.9
101.1
43.3
108.7
47.9
115.7
52.6
112.9
49.7
115.3
50.2
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
10
65.1
11.5
77.5
13.8
90.4
16.2
96.3
17.4
102.7
18.7
115.1
21.3
127.5
24
12
65.1
11.7
77.5
14
90.4
16.4
96.3
17.7
102.7
19.1
115.1
21.7
127.5
24.4
14
65.1
11.9
77.5
14.3
90.4
16.8
96.3
18.1
102.7
19.4
115.1
22.1
127.5
24.9
16
65.1
12.1
77.5
14.5
90.4
17.1
96.3
18.4
102.7
19.8
115.1
22.6
127.5
25.4
18
65.1
12.3
77.5
14.7
90.4
17.4
96.3
18.8
102.7
20.2
115.1
23
127.5
26
20
65.1
12.5
77.5
15.1
90.4
17.7
96.3
19.2
102.7
20.6
115.1
23.9
127.5
27.7
21
65.1
12.6
77.5
15.2
90.4
18
96.3
19.3
102.7
21
115.1
24.7
127.5
28.8
23
65.1
12.8
77.5
15.5
90.4
18.8
96.3
20.6
102.7
22.4
115.1
26.5
127.5
30.9
25
65.1
13.3
77.5
16.5
90.4
20
96.3
22
102.7
24
115.1
28.3
127.5
33
27
65.1
14.1
77.5
17.6
90.4
21.4
96.3
23.5
102.7
25.6
115.1
30.3
127.5
35.3
29
65.1
15
77.5
18.7
90.4
22.8
96.3
25
102.7
27.3
115.1
32.4
127.5
37.8
31
65.1
16
77.5
19.9
90.4
24.3
96.3
26.7
102.7
29.2
115.1
34.5
127.5
39.2
33
65.1
16.9
77.5
21.2
90.4
25.9
96.3
28.5
102.7
31.1
115.1
36.8
127.5
40.7
35
65.1
18
77.5
22.4
90.4
27.5
96.3
30.2
102.7
33.1
115.1
39.3
127.5
42.2
37
65.1
19
77.5
23.9
90.4
29.3
96.3
32.2
102.7
35.3
115.1
41.8
127.5
43.7
39
65.1
20.1
77.5
25.3
90.4
31.1
96.3
34.2
102.7
37.5
115.1
44.6
127.5
45.1
42
65.1
21.2
77.5
26.8
90.4
32.9
96.3
36.2
102.7
39.7
115.1
47.2
127.5
46.6
44
65.1
22.3
77.5
28.2
90.4
34.7
96.3
38.2
102.7
41.9
115.1
49.8
127.5
48.1
46
65.1
23.4
77.5
29.9
90.4
36.5
96.3
40.2
102.7
44.1
115.1
52.5
127.5
49.6
51
Cooling Performance - COOLING PERFORMANCE DATA – 420
Capacity
factor(%)
70%
60%
50%
52
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
57
10
67.8
12
79
14
84.5
15
89.8
12
57
10
67.8
12
79
14
84.5
15
89.8
14
57
10
67.8
12
79
15
84.5
16
16
57
11
67.8
13
79
15
84.5
18
57
11
67.8
13
79
15
84.5
20
57
11
67.8
13
79
15
21
57
11
67.8
13
79
23
57
11
67.8
14
25
57
12
67.8
27
57
12
29
57
31
33
22
24
TC
kW
PI
kW
TC
kW
PI
kW
16
100.6
18.4
111.9
20.6
16
100.6
18.7
111.9
21
89.8
17
100.6
19
111.9
21.4
16
89.8
17
100.6
19.4
111.9
21.8
16
89.8
17
100.6
19.7
111.9
22.2
84.5
17
89.8
18
100.6
20.1
111.9
22.8
16
84.5
17
89.8
18
100.6
20.4
111.9
23.6
79
16
84.5
17
89.8
19
100.6
21.9
111.9
26.1
14
79
17
84.5
18
89.8
20
100.6
23.4
111.9
27.1
67.8
15
79
18
84.5
20
89.8
21
100.6
25
111.9
29
13
67.8
16
79
19
84.5
21
89.8
23
100.6
26.7
111.9
30.9
57
14
67.8
17
79
20
84.5
22
89.8
24
100.6
28.5
111.9
33
57
14
67.8
18
79
22
84.5
24
89.8
26
100.6
30.3
111.9
35.2
35
57
15
67.8
19
79
23
84.5
25
89.8
27
100.6
32.2
111.9
37.5
37
57
16
67.8
20
79
24
84.5
27
89.8
29
100.6
34.3
111.9
40
39
57
17
67.8
21
79
26
84.5
28
89.8
31
100.6
36.5
111.9
42.6
42
57
18
67.8
22
79
27
84.5
30
89.8
33
100.6
38.7
111.9
45.1
44
57
19
67.8
24
79
29
84.5
32
89.8
34
100.6
40.9
111.9
47.6
46
57
20
67.8
25
79
30
84.5
33
89.8
36
100.6
43
111.9
50.1
10
49
8.8
58.1
10
68
12
72.1
13
76.9
14
86.6
15.5
95.8
17.3
12
49
8.9
58.1
11
68
12
72.1
13
76.9
14
86.6
15.7
95.8
17.6
14
49
9.1
58.1
11
68
12
72.1
13
76.9
14
86.6
16
95.8
18
16
49
9.2
58.1
11
68
13
72.1
14
76.9
14
86.6
16.3
95.8
18.3
18
49
9.3
58.1
11
68
13
72.1
14
76.9
15
86.6
16.6
95.8
18.7
20
49
9.5
58.1
11
68
13
72.1
14
76.9
15
86.6
16.9
95.8
19
21
49
9.5
58.1
11
68
13
72.1
14
76.9
15
86.6
17.1
95.8
19.2
23
49
9.7
58.1
12
68
13
72.1
14
76.9
15
86.6
17.8
95.8
20.4
25
49
9.9
58.1
12
68
14
72.1
15
76.9
16
86.6
19
95.8
21.8
27
49
10
58.1
12
68
15
72.1
16
76.9
17
86.6
20.2
95.8
23.2
29
49
11
58.1
13
68
16
72.1
17
76.9
19
86.6
21.6
95.8
24.8
31
49
12
58.1
14
68
17
72.1
18
76.9
20
86.6
22.9
95.8
26.5
33
49
12
58.1
15
68
18
72.1
19
76.9
21
86.6
24.4
95.8
28.2
35
49
13
58.1
16
68
19
72.1
20
76.9
22
86.6
26
95.8
30
37
49
14
58.1
17
68
20
72.1
22
76.9
24
86.6
27.6
95.8
31.9
39
49
14
58.1
18
68
21
72.1
23
76.9
25
86.6
29.3
95.8
33.9
42
49
15
58.1
19
68
22
72.1
24
76.9
27
86.6
31
95.8
35.9
44
49
16
58.1
20
68
24
72.1
26
76.9
28
86.6
32.7
95.8
37.8
46
49
17
58.1
20
68
25
72.1
27
76.9
29
86.6
34.4
95.8
39.8
10
40.7
7.5
48.4
8.7
57
10
60.3
11
64
11
72.1
12.7
79.6
14.2
12
40.7
7.7
48.4
8.9
57
10
60.3
11
64
12
72.1
13
79.6
14.4
14
40.7
7.8
48.4
9
57
10
60.3
11
64
12
72.1
13.1
79.6
14.7
16
40.7
7.9
48.4
9.1
57
11
60.3
11
64
12
72.1
13.4
79.6
15
18
40.7
7.9
48.4
9.3
57
11
60.3
11
64
12
72.1
13.6
79.6
15.2
20
40.7
8.1
48.4
9.5
57
11
60.3
12
64
12
72.1
13.9
79.6
15.5
21
40.7
8.2
48.4
9.5
57
11
60.3
12
64
12
72.1
14
79.6
15.7
23
40.7
8.3
48.4
9.6
57
11
60.3
12
64
13
72.1
14.3
79.6
16
25
40.7
8.4
48.4
9.8
57
11
60.3
12
64
13
72.1
15
79.6
17.1
27
40.7
8.5
48.4
10
57
12
60.3
13
64
14
72.1
16
79.6
18.2
29
40.7
9.1
48.4
11
57
13
60.3
14
64
15
72.1
17
79.6
19.4
31
40.7
9.5
48.4
11
57
14
60.3
15
64
16
72.1
18
79.6
20.7
33
40.7
10
48.4
12
57
14
60.3
15
64
17
72.1
19.2
79.6
22
35
40.7
11
48.4
13
57
15
60.3
16
64
18
72.1
20.4
79.6
23.3
37
40.7
11
48.4
14
57
16
60.3
17
64
19
72.1
21.6
79.6
24.8
39
40.7
12
48.4
14
57
17
60.3
18
64
20
72.1
20.8
79.6
26.3
42
40.7
12
48.4
15
57
18
60.3
19
64
21
72.1
21.4
79.6
27.8
44
40.7
13
48.4
16
57
19
60.3
20
64
22
72.1
21.7
79.6
29.2
46
40.7
14
48.4
17
57
20
60.3
21
64
24
72.1
21.9
79.6
30.7
Cooling Performance - COOLING PERFORMANCE DATA – 440
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
83.6
14.7
99.6
17.8
115.7
21
124
22.8
132.3
24.5
148.4
28
156.7
29
12
83.6
15
99.6
18.1
115.7
21.5
124
23.2
132.3
24.9
148.4
28.5
156.7
28.8
14
83.6
15.2
99.6
18.4
115.7
21.9
124
23.6
132.3
25.4
148.4
29.1
152.8
28.7
16
83.6
15.4
99.6
18.8
115.7
22.3
124
24.1
132.3
25.9
147.8
29.4
150.6
29.2
18
83.6
15.8
99.6
19.2
115.7
22.8
124
24.6
132.3
26.4
145.6
30.4
148.9
30.6
20
83.6
16.1
99.6
19.6
115.7
23.4
124
25.8
132.3
28.4
143.9
31.9
146.7
32.1
21
83.6
16.3
99.6
19.7
115.7
24.3
124
26.7
132.3
29.3
142.8
32.6
145.6
32.9
23
83.6
16.7
99.6
21
115.7
26
124
28.7
132.3
31.4
140.6
34.1
143.4
34.4
25
83.6
17.8
99.6
22.5
115.7
27.8
124
30.7
132.3
33.7
136.7
35.6
141.7
35.9
27
83.6
18.9
99.6
24
115.7
29.7
124
32.8
132.3
36.1
134.5
37.1
139.5
37.4
29
83.6
20.2
99.6
25.6
115.7
31.8
124
35
131.8
38.3
132.3
38.7
137.8
38.9
31
83.6
21.5
99.6
27.3
115.7
33.9
124
37.5
129.5
39.7
130.6
40.1
135.6
40.5
33
83.6
22.8
99.6
29.1
115.7
36.1
124
39.9
127.3
41.3
128.4
41.6
133.4
42
35
83.6
24.2
99.6
31
115.7
38.5
124
42.6
125.7
42.7
132.3
43.1
131.8
43.6
37
83.6
25.8
99.6
32.9
115.7
41
121.8
44
123.4
44.3
126.8
44.7
129.5
45.1
39
83.6
27.4
99.6
35
115.7
43.7
120.1
45.6
121.2
45.8
124.6
46.2
127.3
46.6
42
83.6
29
99.6
37
115.7
46.3
118.1
47.1
119
47.4
120.1
47.8
125.1
48.2
44
83.6
30.5
99.6
39.1
115.7
48.9
116.2
48.6
116.8
48.9
116.3
49.3
122.9
49.7
51.3
Outdoor ambient
temperature (DB°C)
14
16
22
TC
kW
24
PI
kW
TC
kW
PI
kW
46
83.6
32.2
99.6
40.8
115.7
51.5
114.3
50.1
114.6
50.5
112.4
50.9
121.9
10
75.3
13.2
89.7
15.8
104.1
18.7
111.8
20.2
119
21.7
133.4
24.8
147.8
28
12
75.3
13.3
89.7
16.1
104.1
19
111.8
20.6
119
22.1
133.4
25.3
147.8
28.4
14
75.3
13.6
89.7
16.4
104.1
19.4
111.8
21
119
22.5
133.4
25.8
147.8
29
16
75.3
13.8
89.7
16.7
104.1
19.7
111.8
21.4
119
22.9
133.4
26.2
147.8
29.5
18
75.3
14.1
89.7
17.1
104.1
20.2
111.8
21.8
119
23.4
133.4
26.7
145.6
30.4
20
75.3
14.3
89.7
17.4
104.1
20.6
111.8
22.2
119
24.3
133.4
28.8
143.4
31.9
21
75.3
14.5
89.7
17.6
104.1
20.9
111.8
23
119
25.1
133.4
29.8
142.8
32.6
23
75.3
14.7
89.7
18.3
104.1
22.3
111.8
24.6
119
27
133.4
31.9
140.6
34.1
25
75.3
15.5
89.7
19.5
104.1
23.9
111.8
26.3
119
28.8
133.4
34.2
138.4
35.6
27
75.3
16.5
89.7
20.8
104.1
25.5
111.8
28.1
119
30.8
133.4
36.6
136.7
37.1
29
75.3
17.6
89.7
22.2
104.1
27.2
111.8
30
119
32.9
131.8
38.3
134.5
38.6
31
75.3
18.7
89.7
23.6
104.1
29.1
111.8
32
119
35.1
129.5
39.8
132.3
40.1
33
75.3
19.8
89.7
25.1
104.1
31
111.8
34.1
119
37.5
127.9
41.3
130.6
41.6
35
75.3
21.1
89.7
26.7
104.1
33
111.8
36.4
119
40
125.7
42.8
128.4
43.1
37
75.3
22.3
89.7
28.4
104.1
35.1
111.8
38.8
119
42.6
124
44.3
126.2
44.7
39
75.3
23.7
89.7
30.1
104.1
37.4
111.8
41.3
119
45.3
121.8
45.8
124.6
46.2
42
75.3
25
89.7
31.9
104.1
39.5
111.8
43.7
119
48
119.9
47.3
122.5
47.8
44
75.3
26.3
89.7
33.6
104.1
41.7
111.8
46.1
119
50.7
118
48.8
120.6
49.3
46
75.3
27.6
89.7
35.4
104.1
43.9
111.8
48.6
119
53.4
116.1
50.4
118.6
50.9
10
67
11.6
79.7
14
93
16.4
99.1
17.6
105.7
18.9
118.5
21.6
131.2
24.4
12
67
11.9
79.7
14.2
93
16.7
99.1
18
105.7
19.3
118.5
22
131.2
24.8
14
67
12
79.7
14.5
93
17
99.1
18.4
105.7
19.7
118.5
22.4
131.2
25.3
16
67
12.3
79.7
14.7
93
17.3
99.1
18.7
105.7
20.1
118.5
22.9
131.2
25.8
18
67
12.4
79.7
15
93
17.6
99.1
19
105.7
20.5
118.5
23.3
131.2
26.3
20
67
12.7
79.7
15.3
93
18
99.1
19.4
105.7
20.9
118.5
24.2
131.2
28.1
21
67
12.8
79.7
15.4
93
18.2
99.1
19.6
105.7
21.3
118.5
25
131.2
29.2
23
67
13
79.7
15.7
93
19
99.1
20.9
105.7
22.8
118.5
26.8
131.2
31.3
25
67
13.5
79.7
16.7
93
20.3
99.1
22.3
105.7
24.4
118.5
28.7
131.2
33.5
27
67
14.3
79.7
17.8
93
21.7
99.1
23.8
105.7
26
118.5
30.7
131.2
35.8
29
67
15.2
79.7
18.9
93
23.2
99.1
25.4
105.7
27.7
118.5
32.8
131.2
38.3
31
67
16.2
79.7
20.2
93
24.6
99.1
27.1
105.7
29.6
118.5
35
131.2
39.7
33
67
17.1
79.7
21.5
93
26.2
99.1
28.8
105.7
31.5
118.5
37.3
131.2
41.3
35
67
18.2
79.7
22.8
93
27.9
99.1
30.6
105.7
33.6
118.5
39.8
131.2
42.7
37
67
19.3
79.7
24.2
93
29.7
99.1
32.7
105.7
35.8
118.5
42.4
131.2
44.3
39
67
20.4
79.7
25.7
93
31.5
99.1
34.7
105.7
38
118.5
45.2
131.2
45.7
42
67
21.5
79.7
27.1
93
33.3
99.1
36.7
105.7
40.3
118.5
47.8
131.2
47.3
44
67
22.6
79.7
28.6
93
35.2
99.1
38.8
105.7
42.5
118.5
50.5
131.2
48.8
46
67
23.7
79.7
30.3
93
37
99.1
40.8
105.7
44.7
118.5
53.2
131.2
50.3
53
Cooling Performance - COOLING PERFORMANCE DATA – 440
Capacity
factor(%)
70%
60%
50%
54
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
58.7
10
69.8
12
81
14
86.9
15
92.4
12
58.7
10
69.8
12
81
15
86.9
16
92.4
14
58.7
11
69.8
13
81
15
86.9
16
16
58.7
11
69.8
13
81
15
86.9
18
58.7
11
69.8
13
81
15
20
58.7
11
69.8
13
81
21
58.7
11
69.8
13
23
58.7
11
69.8
14
25
58.7
12
69.8
27
58.7
12
69.8
29
58.7
13
31
58.7
33
22
24
TC
kW
PI
kW
TC
kW
PI
kW
16
103.5
18.6
115.1
20.9
17
103.5
18.9
115.1
21.3
92.4
17
103.5
19.3
115.1
21.7
16
92.4
17
103.5
19.7
115.1
22.1
86.9
16
92.4
18
103.5
20
115.1
22.5
16
86.9
17
92.4
18
103.5
20.4
115.1
23.2
81
16
86.9
17
92.4
18
103.5
20.7
115.1
24
81
16
86.9
18
92.4
19
103.5
22.2
115.1
26.5
14
81
17
86.9
19
92.4
20
103.5
23.7
115.1
27.5
15
81
18
86.9
20
92.4
22
103.5
25.4
115.1
29.4
69.8
16
81
19
86.9
21
92.4
23
103.5
27.1
115.1
31.4
14
69.8
17
81
21
86.9
23
92.4
25
103.5
28.8
115.1
33.5
58.7
15
69.8
18
81
22
86.9
24
92.4
26
103.5
30.7
115.1
35.7
35
58.7
15
69.8
19
81
23
86.9
25
92.4
28
103.5
32.7
115.1
38
37
58.7
16
69.8
20
81
25
86.9
27
92.4
30
103.5
34.8
115.1
40.5
39
58.7
17
69.8
22
81
26
86.9
29
92.4
31
103.5
37.1
115.1
43.1
42
58.7
18
69.8
23
81
28
86.9
30
92.4
33
103.5
39.2
115.1
45.7
44
58.7
19
69.8
24
81
29
86.9
32
92.4
35
103.5
41.4
115.1
48.3
46
58.7
20
69.8
25
81
31
86.9
34
92.4
37
103.5
43.6
115.1
50.8
10
50.4
8.9
59.8
11
70
12
74.2
13
79.2
14
89.1
15.7
98.5
17.6
12
50.4
9
59.8
11
70
12
74.2
13
79.2
14
89.1
15.9
98.5
17.9
14
50.4
9.2
59.8
11
70
13
74.2
13
79.2
14
89.1
16.3
98.5
18.2
16
50.4
9.3
59.8
11
70
13
74.2
14
79.2
15
89.1
16.5
98.5
18.5
18
50.4
9.4
59.8
11
70
13
74.2
14
79.2
15
89.1
16.8
98.5
18.9
20
50.4
9.6
59.8
11
70
13
74.2
14
79.2
15
89.1
17.1
98.5
19.3
21
50.4
9.7
59.8
12
70
13
74.2
14
79.2
15
89.1
17.3
98.5
19.5
23
50.4
9.8
59.8
12
70
14
74.2
15
79.2
16
89.1
18
98.5
20.7
25
50.4
10
59.8
12
70
14
74.2
15
79.2
17
89.1
19.3
98.5
22.1
27
50.4
10
59.8
13
70
15
74.2
16
79.2
18
89.1
20.5
98.5
23.6
29
50.4
11
59.8
13
70
16
74.2
17
79.2
19
89.1
21.9
98.5
25.2
31
50.4
12
59.8
14
70
17
74.2
18
79.2
20
89.1
23.2
98.5
26.8
33
50.4
12
59.8
15
70
18
74.2
20
79.2
21
89.1
24.8
98.5
28.6
35
50.4
13
59.8
16
70
19
74.2
21
79.2
23
89.1
26.3
98.5
30.4
37
50.4
14
59.8
17
70
20
74.2
22
79.2
24
89.1
28
98.5
32.3
39
50.4
15
59.8
18
70
22
74.2
23
79.2
25
89.1
29.7
98.5
34.4
42
50.4
15
59.8
19
70
23
74.2
25
79.2
27
89.1
31.4
98.5
36.4
44
50.4
16
59.8
20
70
24
74.2
26
79.2
28
89.1
33.1
98.5
38.3
46
50.4
17
59.8
21
70
25
74.2
27
79.2
30
89.1
34.8
98.5
40.3
10
41.9
7.6
49.8
8.9
58
10
62
11
65.9
12
74.2
12.9
81.9
14.4
12
41.9
7.8
49.8
9
58
10
62
11
65.9
12
74.2
13.2
81.9
14.6
14
41.9
7.9
49.8
9.1
58
11
62
11
65.9
12
74.2
13.3
81.9
14.9
16
41.9
8
49.8
9.3
58
11
62
11
65.9
12
74.2
13.6
81.9
15.2
18
41.9
8
49.8
9.4
58
11
62
12
65.9
12
74.2
13.8
81.9
15.4
20
41.9
8.2
49.8
9.6
58
11
62
12
65.9
13
74.2
14.1
81.9
15.8
21
41.9
8.3
49.8
9.7
58
11
62
12
65.9
13
74.2
14.2
81.9
15.9
23
41.9
8.4
49.8
9.8
58
11
62
12
65.9
13
74.2
14.5
81.9
16.3
25
41.9
8.5
49.8
9.9
58
12
62
12
65.9
13
74.2
15.2
81.9
17.3
27
41.9
8.6
49.8
10
58
12
62
13
65.9
14
74.2
16.2
81.9
18.4
29
41.9
9.2
49.8
11
58
13
62
14
65.9
15
74.2
17.2
81.9
19.7
31
41.9
9.7
49.8
12
58
14
62
15
65.9
16
74.2
18.3
81.9
21
33
41.9
10
49.8
12
58
15
62
16
65.9
17
74.2
19.4
81.9
22.3
35
41.9
11
49.8
13
58
15
62
17
65.9
18
74.2
20.6
81.9
23.6
37
41.9
11
49.8
14
58
16
62
18
65.9
19
74.2
21.9
81.9
25.1
39
41.9
12
49.8
15
58
17
62
19
65.9
20
74.2
21.1
81.9
26.7
42
41.9
13
49.8
15
58
18
62
20
65.9
21
74.2
21.7
81.9
28.1
44
41.9
13
49.8
16
58
19
62
21
65.9
23
74.2
22
81.9
29.6
46
41.9
14
49.8
17
58
20
62
22
65.9
24
74.2
22.2
81.9
31.1
Cooling Performance - COOLING PERFORMANCE DATA – 460
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
89.7
15.6
106.9
18.9
124.1
22.3
133
24.1
141.9
25.9
159.1
29.6
168
30.8
12
89.7
15.9
106.9
19.2
124.1
22.7
133
24.6
141.9
26.4
159.1
30.2
168
30.6
14
89.7
16.1
106.9
19.6
124.1
23.2
133
25.1
141.9
27
159.1
30.8
163.9
30.4
16
89.7
16.4
106.9
19.9
124.1
23.7
133
25.6
141.9
27.5
158.5
31.2
161.5
30.9
18
89.7
16.7
106.9
20.3
124.1
24.1
133
26.1
141.9
28
156.2
32.2
159.7
32.5
20
89.7
17.1
106.9
20.8
124.1
24.8
133
27.4
141.9
30.1
154.4
33.8
157.3
34
21
89.7
17.2
106.9
20.9
124.1
25.8
133
28.3
141.9
31.1
153.2
34.5
156.2
34.9
23
89.7
17.7
106.9
22.3
124.1
27.6
133
30.4
141.9
33.3
150.8
36.2
153.8
36.4
25
89.7
18.9
106.9
23.9
124.1
29.5
133
32.6
141.9
35.8
146.7
37.7
152
38.1
27
89.7
20.1
106.9
25.4
124.1
31.5
133
34.8
141.9
38.2
144.3
39.3
149.6
39.6
29
89.7
21.4
106.9
27.1
124.1
33.7
133
37.1
141.3
40.6
141.9
41.1
147.8
41.3
31
89.7
22.7
106.9
28.9
124.1
35.9
133
39.7
138.9
42.1
140.1
42.6
145.5
42.9
33
89.7
24.2
106.9
30.8
124.1
38.2
133
42.3
136.6
43.8
137.8
44.1
143.1
44.5
35
89.7
25.7
106.9
32.8
124.1
40.8
133
45.1
134.8
45.3
141.9
45.7
141.3
46.2
37
89.7
27.3
106.9
34.9
124.1
43.5
130.6
46.7
132.4
46.9
136
47.4
138.9
47.8
39
89.7
29
106.9
37.1
124.1
46.3
128.8
48.3
130
48.6
133.6
49
136.6
49.4
42
89.7
30.7
106.9
39.3
124.1
49.1
126.7
49.9
127.7
50.2
128.8
50.7
134.2
51.1
44
89.7
32.4
106.9
41.4
124.1
51.8
124.6
51.5
125.3
51.9
124.7
52.3
131.8
52.7
46
89.7
34.2
106.9
43.2
124.1
54.6
122.6
53.1
122.9
53.5
120.6
53.9
130.7
54.3
10
80.8
14
96.2
16.8
111.6
19.8
119.9
21.4
127.7
23
143.1
26.3
158.5
29.6
12
80.8
14.1
96.2
17.1
111.6
20.2
119.9
21.8
127.7
23.4
143.1
26.8
158.5
30.2
14
80.8
14.4
96.2
17.4
111.6
20.6
119.9
22.2
127.7
23.9
143.1
27.3
158.5
30.8
16
80.8
14.6
96.2
17.7
111.6
20.9
119.9
22.7
127.7
24.3
143.1
27.8
158.5
31.3
18
80.8
14.9
96.2
18.1
111.6
21.4
119.9
23.1
127.7
24.8
143.1
28.3
156.2
32.2
20
80.8
15.2
96.2
18.4
111.6
21.8
119.9
23.5
127.7
25.8
143.1
30.5
153.8
33.8
21
80.8
15.3
96.2
18.6
111.6
22.1
119.9
24.4
127.7
26.6
143.1
31.6
153.2
34.5
23
80.8
15.6
96.2
19.4
111.6
23.7
119.9
26.1
127.7
28.6
143.1
33.9
150.8
36.2
25
80.8
16.5
96.2
20.7
111.6
25.3
119.9
27.9
127.7
30.6
143.1
36.3
148.4
37.7
27
80.8
17.5
96.2
22.1
111.6
27
119.9
29.8
127.7
32.6
143.1
38.8
146.7
39.3
29
80.8
18.6
96.2
23.5
111.6
28.9
119.9
31.8
127.7
34.9
141.3
40.6
144.3
40.9
31
80.8
19.8
96.2
25
111.6
30.8
119.9
33.9
127.7
37.2
138.9
42.2
141.9
42.5
33
80.8
21
96.2
26.6
111.6
32.8
119.9
36.2
127.7
39.7
137.2
43.8
140.1
44.1
35
80.8
22.4
96.2
28.3
111.6
35
119.9
38.6
127.7
42.4
134.8
45.4
137.8
45.7
37
80.8
23.7
96.2
30.1
111.6
37.2
119.9
41.1
127.7
45.1
133
46.9
135.4
47.4
39
80.8
25.2
96.2
32
111.6
39.6
119.9
43.8
127.7
48.1
130.6
48.6
133.6
49
42
80.8
26.5
96.2
33.8
111.6
41.9
119.9
46.3
127.7
50.9
128.6
50.2
131.4
50.7
44
80.8
27.9
96.2
35.6
111.6
44.2
119.9
48.9
127.7
53.7
126.6
51.8
129.3
52.3
46
80.8
29.3
96.2
37.5
111.6
46.6
119.9
51.5
127.7
56.6
124.6
53.4
127.2
53.9
10
71.8
12.3
85.5
14.8
99.8
17.4
106.3
18.7
113.4
20.1
127.1
22.9
140.7
25.8
12
71.8
12.6
85.5
15.1
99.8
17.7
106.3
19
113.4
20.5
127.1
23.3
140.7
26.3
14
71.8
12.7
85.5
15.3
99.8
18
106.3
19.5
113.4
20.8
127.1
23.8
140.7
26.8
16
71.8
13
85.5
15.6
99.8
18.3
106.3
19.8
113.4
21.3
127.1
24.3
140.7
27.3
18
71.8
13.2
85.5
15.9
99.8
18.7
106.3
20.2
113.4
21.7
127.1
24.7
140.7
27.9
20
71.8
13.4
85.5
16.2
99.8
19
106.3
20.6
113.4
22.1
127.1
25.7
140.7
29.8
21
71.8
13.5
85.5
16.4
99.8
19.3
106.3
20.8
113.4
22.6
127.1
26.5
140.7
30.9
23
71.8
13.8
85.5
16.6
99.8
20.2
106.3
22.1
113.4
24.1
127.1
28.4
140.7
33.2
25
71.8
14.3
85.5
17.7
99.8
21.5
106.3
23.6
113.4
25.8
127.1
30.4
140.7
35.5
27
71.8
15.2
85.5
18.9
99.8
23
106.3
25.2
113.4
27.6
127.1
32.6
140.7
38
29
71.8
16.1
85.5
20.1
99.8
24.6
106.3
26.9
113.4
29.4
127.1
34.8
140.7
40.6
31
71.8
17.1
85.5
21.4
99.8
26.1
106.3
28.7
113.4
31.4
127.1
37.1
140.7
42.1
33
71.8
18.2
85.5
22.7
99.8
27.8
106.3
30.6
113.4
33.4
127.1
39.5
140.7
43.8
35
71.8
19.3
85.5
24.1
99.8
29.5
106.3
32.5
113.4
35.6
127.1
42.2
140.7
45.3
37
71.8
20.4
85.5
25.7
99.8
31.4
106.3
34.6
113.4
37.9
127.1
45
140.7
46.9
39
71.8
21.6
85.5
27.2
99.8
33.4
106.3
36.8
113.4
40.3
127.1
47.9
140.7
48.5
42
71.8
22.8
85.5
28.8
99.8
35.3
106.3
38.9
113.4
42.7
127.1
50.7
140.7
50.1
44
71.8
23.9
85.5
30.3
99.8
37.3
106.3
41.1
113.4
45
127.1
53.6
140.7
51.7
46
71.8
25.1
85.5
32.1
99.8
39.2
106.3
43.2
113.4
47.4
127.1
56.4
140.7
53.3
Outdoor ambient
temperature (DB°C)
14
16
22
24
TC
kW
PI
kW
TC
kW
PI
kW
55
Cooling Performance - COOLING PERFORMANCE DATA – 460
Capacity
factor(%)
70%
60%
50%
56
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
62.9
11
74.8
13
87
15
93.2
16
99.2
12
62.9
11
74.8
13
87
15
93.2
17
99.2
14
62.9
11
74.8
13
87
16
93.2
17
16
62.9
11
74.8
14
87
16
93.2
18
62.9
12
74.8
14
87
16
20
62.9
12
74.8
14
87
17
21
62.9
12
74.8
14
87
23
62.9
12
74.8
15
25
62.9
12
74.8
27
62.9
13
74.8
29
62.9
14
31
62.9
33
22
24
TC
kW
PI
kW
TC
kW
PI
kW
17
111
19.7
123.5
22.1
18
111
20.1
123.5
22.6
99.2
18
111
20.4
123.5
23
17
99.2
18
111
20.8
123.5
23.4
93.2
17
99.2
19
111
21.2
123.5
23.9
93.2
18
99.2
19
111
21.6
123.5
24.6
17
93.2
18
99.2
19
111
22
123.5
25.4
87
17
93.2
19
99.2
20
111
23.5
123.5
28.1
15
87
18
93.2
20
99.2
22
111
25.2
123.5
29.1
16
87
19
93.2
21
99.2
23
111
26.9
123.5
31.2
74.8
17
87
21
93.2
22
99.2
24
111
28.7
123.5
33.3
15
74.8
18
87
22
93.2
24
99.2
26
111
30.6
123.5
35.5
62.9
16
74.8
19
87
23
93.2
25
99.2
28
111
32.6
123.5
37.8
35
62.9
16
74.8
20
87
25
93.2
27
99.2
30
111
34.6
123.5
40.3
37
62.9
17
74.8
22
87
26
93.2
29
99.2
31
111
36.9
123.5
43
39
62.9
18
74.8
23
87
28
93.2
31
99.2
33
111
39.3
123.5
45.7
42
62.9
19
74.8
24
87
29
93.2
32
99.2
35
111
41.6
123.5
48.4
44
62.9
20
74.8
25
87
31
93.2
34
99.2
37
111
43.9
123.5
51.2
46
62.9
21
74.8
27
87
33
93.2
36
99.2
39
111
46.3
123.5
53.9
10
54
9.5
64.1
11
75
13
79.6
14
84.9
15
95.6
16.6
105.7
18.6
12
54
9.6
64.1
11
75
13
79.6
14
84.9
15
95.6
16.9
105.7
19
14
54
9.7
64.1
12
75
13
79.6
14
84.9
15
95.6
17.2
105.7
19.3
16
54
9.9
64.1
12
75
14
79.6
15
84.9
16
95.6
17.5
105.7
19.6
18
54
10
64.1
12
75
14
79.6
15
84.9
16
95.6
17.8
105.7
20.1
20
54
10
64.1
12
75
14
79.6
15
84.9
16
95.6
18.2
105.7
20.4
21
54
10
64.1
12
75
14
79.6
15
84.9
16
95.6
18.3
105.7
20.7
23
54
10
64.1
12
75
14
79.6
15
84.9
17
95.6
19.1
105.7
22
25
54
11
64.1
13
75
15
79.6
16
84.9
18
95.6
20.4
105.7
23.4
27
54
11
64.1
13
75
16
79.6
17
84.9
19
95.6
21.7
105.7
25
29
54
12
64.1
14
75
17
79.6
18
84.9
20
95.6
23.2
105.7
26.7
31
54
12
64.1
15
75
18
79.6
20
84.9
21
95.6
24.6
105.7
28.4
33
54
13
64.1
16
75
19
79.6
21
84.9
23
95.6
26.3
105.7
30.3
35
54
14
64.1
17
75
20
79.6
22
84.9
24
95.6
27.9
105.7
32.2
37
54
15
64.1
18
75
22
79.6
23
84.9
25
95.6
29.6
105.7
34.3
39
54
15
64.1
19
75
23
79.6
25
84.9
27
95.6
31.5
105.7
36.4
42
54
16
64.1
20
75
24
79.6
26
84.9
29
95.6
33.3
105.7
38.5
44
54
17
64.1
21
75
25
79.6
28
84.9
30
95.6
35.1
105.7
40.6
46
54
18
64.1
22
75
27
79.6
29
84.9
32
95.6
36.9
105.7
42.7
10
44.9
8.1
53.4
9.4
62
11
66.5
12
70.7
12
79.6
13.7
87.9
15.2
12
44.9
8.3
53.4
9.6
62
11
66.5
12
70.7
12
79.6
14
87.9
15.5
14
44.9
8.4
53.4
9.6
62
11
66.5
12
70.7
13
79.6
14.1
87.9
15.8
16
44.9
8.4
53.4
9.8
62
11
66.5
12
70.7
13
79.6
14.4
87.9
16.1
18
44.9
8.5
53.4
10
62
12
66.5
12
70.7
13
79.6
14.6
87.9
16.4
20
44.9
8.7
53.4
10
62
12
66.5
12
70.7
13
79.6
14.9
87.9
16.7
21
44.9
8.8
53.4
10
62
12
66.5
13
70.7
13
79.6
15.1
87.9
16.9
23
44.9
8.9
53.4
10
62
12
66.5
13
70.7
14
79.6
15.3
87.9
17.2
25
44.9
9
53.4
11
62
12
66.5
13
70.7
14
79.6
16.1
87.9
18.3
27
44.9
9.1
53.4
11
62
13
66.5
14
70.7
15
79.6
17.1
87.9
19.6
29
44.9
9.7
53.4
12
62
14
66.5
15
70.7
16
79.6
18.3
87.9
20.8
31
44.9
10
53.4
12
62
15
66.5
16
70.7
17
79.6
19.4
87.9
22.2
33
44.9
11
53.4
13
62
15
66.5
17
70.7
18
79.6
20.6
87.9
23.6
35
44.9
12
53.4
14
62
16
66.5
18
70.7
19
79.6
21.9
87.9
25.1
37
44.9
12
53.4
15
62
17
66.5
19
70.7
20
79.6
23.3
87.9
26.6
39
44.9
13
53.4
15
62
18
66.5
20
70.7
21
79.6
22.4
87.9
28.3
42
44.9
13
53.4
16
62
19
66.5
21
70.7
22
79.6
23
87.9
29.8
44
44.9
14
53.4
17
62
20
66.5
22
70.7
24
79.6
23.3
87.9
31.4
46
44.9
15
53.4
18
62
21
66.5
23
70.7
25
79.6
23.6
87.9
33
Cooling Performance - COOLING PERFORMANCE DATA – 480
Capacity
factor(%)
100%
90%
80%
TC
kW
PI
kW
TC
kW
PI
kW
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
10
93
16.8
110.9
20.4
128.8
24.1
138
26
147.2
28
165.1
12
93
17.1
110.9
20.7
128.8
24.5
138
26.6
147.2
28.5
165.1
14
93
17.4
110.9
21.1
128.8
25
138
27.1
147.2
29.1
165.1
16
93
17.7
110.9
21.5
128.8
25.6
138
27.6
147.2
29.7
18
93
18
110.9
21.9
128.8
26
138
28.2
147.2
30.2
20
93
18.4
110.9
22.4
128.8
26.8
138
29.6
147.2
21
93
18.6
110.9
22.6
128.8
27.8
138
30.6
23
93
19.1
110.9
24.1
128.8
29.8
138
32.8
25
93
20.4
110.9
25.8
128.8
31.8
138
35.1
27
93
21.7
110.9
27.4
128.8
34
138
37.6
147.2
41.3
149.7
42.4
155.3
42.8
29
93
23.1
110.9
29.3
128.8
36.4
138
40.1
146.6
43.8
147.2
44.3
153.4
44.5
31
93
24.5
110.9
31.2
128.8
38.8
138
42.9
144.2
45.5
145.4
45.9
150.9
46.3
33
93
26.1
110.9
33.3
128.8
41.3
138
45.7
141.7
47.2
142.9
47.6
148.5
48.1
35
93
27.7
110.9
35.4
128.8
44.1
138
48.7
139.8
48.9
147.2
49.4
146.6
49.8
37
93
29.5
110.9
37.7
128.8
47
135.5
50.4
137.4
50.7
141.1
51.1
144.2
51.6
39
93
31.3
110.9
40.1
128.8
50
133.7
52.2
134.9
52.4
138.6
52.9
141.7
53.4
42
93
33.1
110.9
42.4
128.8
53
131.4
53.9
132.5
54.2
133.7
54.7
139.2
55.1
44
93
34.9
110.9
44.7
128.8
55.9
129.3
55.6
130
56
129.4
56.4
136.8
56.9
46
93
36.9
110.9
46.6
128.8
58.9
127.2
57.3
127.5
57.7
125.1
58.2
135.7
58.7
10
83.8
15.1
99.8
18.1
115.8
21.4
124.4
23.1
132.5
24.8
148.5
28.4
164.5
32
12
83.8
15.2
99.8
18.4
115.8
21.8
124.4
23.5
132.5
25.3
148.5
28.9
164.5
32.5
14
83.8
15.5
99.8
18.8
115.8
22.2
124.4
24
132.5
25.8
148.5
29.5
164.5
33.2
16
83.8
15.8
99.8
19.2
115.8
22.6
124.4
24.5
132.5
26.2
148.5
30
164.5
33.8
18
83.8
16.1
99.8
19.5
115.8
23.1
124.4
24.9
132.5
26.8
148.5
30.6
162
34.8
20
83.8
16.4
99.8
19.9
115.8
23.5
124.4
25.4
132.5
27.8
148.5
32.9
159.6
36.4
21
83.8
16.5
99.8
20.1
115.8
23.9
124.4
26.3
132.5
28.7
148.5
34.1
158.9
37.3
23
83.8
16.8
99.8
20.9
115.8
25.6
124.4
28.2
132.5
30.9
148.5
36.5
156.5
39.1
25
83.8
17.8
99.8
22.3
115.8
27.3
124.4
30.1
132.5
33
148.5
39.1
154
40.7
27
83.8
18.9
99.8
23.8
115.8
29.2
124.4
32.2
132.5
35.2
148.5
41.8
152.2
42.4
29
83.8
20.1
99.8
25.4
115.8
31.1
124.4
34.3
132.5
37.7
146.6
43.8
149.7
44.2
31
83.8
21.4
99.8
27
115.8
33.3
124.4
36.6
132.5
40.2
144.2
45.6
147.2
45.8
33
83.8
22.7
99.8
28.7
115.8
35.4
124.4
39.1
132.5
42.9
142.3
47.2
145.4
47.6
35
83.8
24.2
99.8
30.5
115.8
37.7
124.4
41.7
132.5
45.7
139.8
49
142.9
49.4
37
83.8
25.6
99.8
32.4
115.8
40.2
124.4
44.4
132.5
48.7
138
50.7
140.5
51.1
39
83.8
27.1
99.8
34.5
115.8
42.8
124.4
47.2
132.5
51.9
135.5
52.4
138.6
52.9
42
83.8
28.6
99.8
36.5
115.8
45.2
124.4
50
132.5
54.9
133.5
54.1
136.4
54.7
44
83.8
30.1
99.8
38.5
115.8
47.8
124.4
52.8
132.5
58
131.3
55.9
134.2
56.4
46
83.8
31.6
99.8
40.5
115.8
50.2
124.4
55.6
132.5
61.1
129.3
57.6
132
58.2
10
74.5
13.3
88.7
16
103.5
18.8
110.3
20.2
117.7
21.7
131.8
24.7
146
27.9
12
74.5
13.6
88.7
16.3
103.5
19.1
110.3
20.5
117.7
22.1
131.8
25.2
146
28.4
14
74.5
13.8
88.7
16.5
103.5
19.4
110.3
21
117.7
22.5
131.8
25.7
146
28.9
16
74.5
14
88.7
16.8
103.5
19.8
110.3
21.4
117.7
23
131.8
26.2
146
29.5
18
74.5
14.2
88.7
17.1
103.5
20.2
110.3
21.8
117.7
23.4
131.8
26.7
146
30.1
20
74.5
14.5
88.7
17.5
103.5
20.5
110.3
22.2
117.7
23.9
131.8
27.7
146
32.2
21
74.5
14.6
88.7
17.7
103.5
20.8
110.3
22.4
117.7
24.4
131.8
28.6
146
33.4
23
74.5
14.9
88.7
17.9
103.5
21.8
110.3
23.9
117.7
26
131.8
30.7
146
35.8
25
74.5
15.4
88.7
19.2
103.5
23.2
110.3
25.5
117.7
27.9
131.8
32.8
146
38.3
27
74.5
16.4
88.7
20.4
103.5
24.8
110.3
27.2
117.7
29.8
131.8
35.1
146
41
29
74.5
17.4
88.7
21.7
103.5
26.5
110.3
29
117.7
31.7
131.8
37.6
146
43.8
31
74.5
18.5
88.7
23.1
103.5
28.2
110.3
31
117.7
33.8
131.8
40.1
146
45.5
33
74.5
19.6
88.7
24.5
103.5
30
110.3
33
117.7
36.1
131.8
42.7
146
47.2
35
74.5
20.8
88.7
26
103.5
31.9
110.3
35.1
117.7
38.4
131.8
45.6
146
48.9
37
74.5
22
88.7
27.7
103.5
33.9
110.3
37.4
117.7
40.9
131.8
48.5
146
50.7
39
74.5
23.3
88.7
29.4
103.5
36.1
110.3
39.7
117.7
43.5
131.8
51.7
146
52.3
42
74.5
24.6
88.7
31.1
103.5
38.2
110.3
42
117.7
46.1
131.8
54.7
146
54.1
44
74.5
25.8
88.7
32.7
103.5
40.2
110.3
44.4
117.7
48.6
131.8
57.8
146
55.8
46
74.5
27.1
88.7
34.7
103.5
42.3
110.3
46.6
117.7
51.2
131.8
60.9
146
57.5
Outdoor ambient
temperature (DB°C)
14
16
22
TC
kW
24
PI
kW
TC
kW
PI
kW
32
174.3
33.2
32.6
174.3
33
33.3
170
32.8
164.5
33.7
167.6
33.4
162
34.8
165.7
35.1
32.4
160.2
36.4
163.3
36.7
147.2
33.6
158.9
37.3
162
37.7
147.2
36
156.5
39.1
159.6
39.3
147.2
38.6
152.2
40.7
157.7
41.1
57
Cooling Performance - COOLING PERFORMANCE DATA – 480
Capacity
factor(%)
70%
60%
50%
58
Outdoor ambient
temperature (DB°C)
14
16
Indoor ambient temperature(WB°C)
18
19
20
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
TC
kW
PI
kW
10
65.3
12
77.6
14
91
16
96.7
18
102.9
12
65.3
12
77.6
14
91
17
96.7
18
102.9
14
65.3
12
77.6
14
91
17
96.7
18
16
65.3
12
77.6
15
91
17
96.7
18
65.3
13
77.6
15
91
18
20
65.3
13
77.6
15
91
18
21
65.3
13
77.6
15
91
23
65.3
13
77.6
16
25
65.3
13
77.6
27
65.3
14
29
65.3
31
22
24
TC
kW
PI
kW
TC
kW
PI
kW
19
115.2
21.3
128.1
23.9
19
115.2
21.7
128.1
24.4
102.9
19
115.2
22
128.1
24.8
18
102.9
20
115.2
22.5
128.1
25.3
96.7
19
102.9
20
115.2
22.9
128.1
25.8
96.7
19
102.9
21
115.2
23.3
128.1
26.5
18
96.7
19
102.9
21
115.2
23.7
128.1
27.4
91
18
96.7
20
102.9
22
115.2
25.4
128.1
30.3
16
91
20
96.7
21
102.9
23
115.2
27.1
128.1
31.4
77.6
17
91
21
96.7
23
102.9
25
115.2
29
128.1
33.7
15
77.6
18
91
22
96.7
24
102.9
26
115.2
31
128.1
35.9
65.3
16
77.6
19
91
24
96.7
26
102.9
28
115.2
33
128.1
38.3
33
65.3
17
77.6
21
91
25
96.7
27
102.9
30
115.2
35.1
128.1
40.8
35
65.3
18
77.6
22
91
27
96.7
29
102.9
32
115.2
37.4
128.1
43.5
37
65.3
19
77.6
23
91
28
96.7
31
102.9
34
115.2
39.8
128.1
46.4
39
65.3
20
77.6
25
91
30
96.7
33
102.9
36
115.2
42.4
128.1
49.4
42
65.3
21
77.6
26
91
32
96.7
35
102.9
38
115.2
44.9
128.1
52.3
44
65.3
22
77.6
27
91
34
96.7
37
102.9
40
115.2
47.4
128.1
55.2
46
65.3
23
77.6
29
91
35
96.7
39
102.9
42
115.2
49.9
128.1
58.1
10
56.1
10
66.5
12
78
14
82.6
15
88.1
16
99.2
17.9
109.7
20.1
12
56.1
10
66.5
12
78
14
82.6
15
88.1
16
99.2
18.2
109.7
20.5
14
56.1
11
66.5
12
78
14
82.6
15
88.1
16
99.2
18.6
109.7
20.8
16
56.1
11
66.5
13
78
15
82.6
16
88.1
17
99.2
18.9
109.7
21.2
18
56.1
11
66.5
13
78
15
82.6
16
88.1
17
99.2
19.2
109.7
21.7
20
56.1
11
66.5
13
78
15
82.6
16
88.1
17
99.2
19.6
109.7
22
21
56.1
11
66.5
13
78
15
82.6
16
88.1
18
99.2
19.8
109.7
22.3
23
56.1
11
66.5
13
78
16
82.6
17
88.1
18
99.2
20.6
109.7
23.7
25
56.1
11
66.5
14
78
16
82.6
18
88.1
19
99.2
22
109.7
25.3
27
56.1
12
66.5
14
78
17
82.6
19
88.1
20
99.2
23.4
109.7
27
29
56.1
13
66.5
15
78
18
82.6
20
88.1
22
99.2
25
109.7
28.8
31
56.1
13
66.5
16
78
19
82.6
21
88.1
23
99.2
26.6
109.7
30.7
33
56.1
14
66.5
17
78
21
82.6
22
88.1
24
99.2
28.4
109.7
32.7
35
56.1
15
66.5
18
78
22
82.6
24
88.1
26
99.2
30.1
109.7
34.8
37
56.1
16
66.5
19
78
23
82.6
25
88.1
27
99.2
32
109.7
37
39
56.1
17
66.5
20
78
25
82.6
27
88.1
29
99.2
34
109.7
39.3
42
56.1
18
66.5
22
78
26
82.6
28
88.1
31
99.2
36
109.7
41.6
44
56.1
18
66.5
23
78
27
82.6
30
88.1
32
99.2
37.9
109.7
43.9
46
56.1
19
66.5
24
78
29
82.6
31
88.1
34
99.2
39.9
109.7
46.1
10
46.6
8.7
55.4
10
65
12
69
12
73.3
13
82.6
14.8
91.2
16.5
12
46.6
8.9
55.4
10
65
12
69
13
73.3
13
82.6
15.1
91.2
16.7
14
46.6
9
55.4
10
65
12
69
13
73.3
14
82.6
15.2
91.2
17
16
46.6
9.1
55.4
11
65
12
69
13
73.3
14
82.6
15.5
91.2
17.4
18
46.6
9.2
55.4
11
65
12
69
13
73.3
14
82.6
15.8
91.2
17.7
20
46.6
9.4
55.4
11
65
13
69
13
73.3
14
82.6
16.1
91.2
18
21
46.6
9.5
55.4
11
65
13
69
14
73.3
14
82.6
16.3
91.2
18.2
23
46.6
9.6
55.4
11
65
13
69
14
73.3
15
82.6
16.5
91.2
18.6
25
46.6
9.8
55.4
11
65
13
69
14
73.3
15
82.6
17.4
91.2
19.8
27
46.6
9.9
55.4
12
65
14
69
15
73.3
16
82.6
18.5
91.2
21.1
29
46.6
11
55.4
13
65
15
69
16
73.3
17
82.6
19.7
91.2
22.5
31
46.6
11
55.4
13
65
16
69
17
73.3
18
82.6
20.9
91.2
24
33
46.6
12
55.4
14
65
17
69
18
73.3
19
82.6
22.2
91.2
25.5
35
46.6
12
55.4
15
65
18
69
19
73.3
21
82.6
23.6
91.2
27.1
37
46.6
13
55.4
16
65
19
69
20
73.3
22
82.6
25.1
91.2
28.7
39
46.6
14
55.4
17
65
20
69
21
73.3
23
82.6
24.2
91.2
30.5
42
46.6
14
55.4
17
65
21
69
22
73.3
24
82.6
24.9
91.2
32.2
44
46.6
15
55.4
18
65
22
69
23
73.3
26
82.6
25.1
91.2
33.9
46
46.6
16
55.4
19
65
23
69
25
73.3
27
82.6
25.4
91.2
35.6
Heating Performance - HEATING PERFORMANCE DATA – 80
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
22.4
23.7
24.9
26.1
27.3
28.5
29.8
30.7
31.6
32.5
33.4
21.9
23.1
24.3
25.4
26.6
26.7
26.8
27.6
28.4
29.2
30.1
21.3
22.5
23.6
24.8
25.9
26.9
26.9
26.9
26.9
26.9
26.9
20.8
21.9
23
23.4
23.4
23.4
23.4
23.4
23.4
23.4
23.4
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
20.1
16.7
16.7
16.7
16.7
16.7
16.7
16.7
16.7
16.7
16.7
16.7
PI
kW
6.8
7
7.2
7.2
7.3
7.5
7.6
7.7
7.7
7.8
7.8
6.3
6.5
6.7
6.7
6.8
6.6
6.5
6.6
6.6
6.6
6.7
5.8
5.9
6.1
6.1
6.2
6.9
6.5
6.2
5.9
5.6
5.4
5.5
5.7
5.8
6.8
6.2
5.9
5.6
5.3
5
4.8
4.6
7.3
6.8
6.3
5.7
5.2
4.9
4.6
4.4
4.2
4
3.8
7.3
6.8
6.3
5.7
5.2
4.9
4.6
4.4
4.2
4
3.8
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
22.2
23.4
24.6
25.8
27
28.2
29.4
29.8
30.3
30.8
31.2
21.6
22.8
24
25.1
26.3
26.4
26.4
26.9
27.3
27.7
28.1
21.1
22.2
23.3
24.5
25.1
25.1
25.1
25.1
25.1
25.1
25.1
20.5
21.6
21.9
21.9
21.9
21.9
21.9
21.9
21.9
21.9
21.9
18.8
18.8
18.8
18.8
18.8
18.8
18.8
18.8
18.8
18.8
18.8
15.7
15.7
15.7
15.7
15.7
15.7
15.7
15.7
15.7
15.7
15.7
20.9
22.3
23.3
24.5
24.5
24.5
24.5
24.5
24.5
24.5
24.5
20.4
21.7
22
22
22
22
22
22
22
22
22
19.6
19.6
19.6
19.6
19.6
19.6
19.6
19.6
19.6
19.6
19.6
17.1
17.1
17.1
17.1
17.1
17.1
17.1
17.1
17.1
17.1
17.1
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
12.2
12.2
12.2
12.2
12.2
12.2
12.2
12.2
12.2
12.2
12.2
7.5
7.8
9.3
8.1
7.4
7
6.6
6.3
6
5.7
5.5
7
7.2
7.2
7
6.4
6
5.7
5.4
5.1
4.9
4.7
7.5
6.9
6.4
5.8
5.3
5
4.7
4.5
4.3
4.1
3.9
6.5
6
5.5
5
4.6
4.3
4.1
3.9
3.7
3.5
3.4
5.3
4.9
4.6
4.1
3.8
3.6
3.4
3.2
3.1
2.9
2.9
2.4
5
4.6
4.1
3.8
3.6
3.4
3.2
3.1
2.9
2.8
7
7.2
7.4
7.4
7.5
7.6
7.8
7.7
7.7
7.6
7.6
6.5
6.7
6.8
6.9
7
6.8
6.7
6.6
6.6
6.5
6.5
5.9
6.1
6.2
6.3
6.8
6.4
6.1
5.8
5.5
5.2
5
5.7
5.8
7.1
6.4
5.8
5.5
5.2
5
4.7
4.5
4.3
6.8
6.3
5.9
5.3
4.8
4.6
4.3
4.1
3.9
3.7
3.6
6.9
6.3
5.9
5.3
4.9
4.6
4.3
4.1
3.9
3.7
3.6
21.5
22.7
23.9
25
26.6
27.8
29
29
29
29
29
21
22.1
23.3
24.4
26
26.1
26.1
26.1
26.1
26.1
26.1
20.4
21.6
22.7
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
19.9
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
7.1
7.3
7.4
7.5
7.7
7.9
8
7.5
7.1
6.8
6.5
6.6
6.7
6.9
7
7.2
7.1
6.9
6.4
6.1
5.8
5.6
6
6.2
6.3
6.9
6.3
5.9
5.6
5.3
5.1
4.9
4.6
5.7
7.1
6.6
5.9
5.4
5.1
4.8
4.6
4.4
4.2
4
6.3
5.8
5.4
4.9
4.5
4.2
4
3.8
3.6
3.5
3.3
6.4
5.9
5.4
4.9
4.5
4.2
4
3.8
3.6
3.5
3.3
21.1
22.2
23.3
24.8
25.9
26.7
26.7
26.7
26.7
26.7
26.7
20.6
21.7
22.7
23.8
24
24
24
24
24
24
24
20.1
21.1
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
18.7
18.7
18.7
18.7
18.7
18.7
18.7
18.7
18.7
18.7
16
16
16
16
16
16
16
16
16
16
16
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
7.2
7.4
7.6
7.8
7.8
7.6
7.2
6.9
6.5
6.3
6
6.7
6.9
7
7.1
6.9
6.5
6.2
5.9
5.6
5.4
5.1
6.1
6.3
7
6.3
5.8
5.5
5.2
4.9
4.7
4.5
4.3
7
6.5
6
5.4
5
4.7
4.4
4.2
4
3.8
3.7
5.8
5.4
5
4.5
4.1
3.9
3.7
3.5
3.3
3.2
3
5.8
5.4
5
4.5
4.1
3.9
3.7
3.5
3.3
3.2
3.1
24
59
Heating Performance - HEATING PERFORMANCE DATA – 100
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
60
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
24.4
25.7
27
28.3
29.7
31
32.3
33.3
34.3
35.3
36.6
23.8
25.1
26.3
27.6
28.9
29
29.1
30
30.9
31.8
32.7
23.1
24.4
25.7
26.9
28.2
29.2
29.2
29.2
29.2
29.2
29.2
22.6
23.8
25
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
PI
kW
7.3
7.5
7.7
7.7
7.8
8
8.1
8.2
8.3
8.3
8.4
6.8
7
7.1
7.2
7.3
7.1
7
7
7.1
7.1
7.2
6.2
6.4
6.5
6.6
6.6
7.4
7
6.6
6.3
6
5.8
5.9
6.1
6.2
7.3
6.7
6.3
6
5.7
5.4
5.2
4.9
7.8
7.2
6.7
6.1
5.5
5.2
4.9
4.7
4.5
4.3
4.1
7.9
7.3
6.7
6.1
5.6
5.2
5
4.7
4.5
4.3
4.1
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
24.1
25.4
26.7
28
29.3
30.6
31.9
32.4
32.9
33.4
33.9
23.5
24.8
26
27.3
28.6
28.7
28.7
29.2
29.6
30.1
30.5
24.1
25.6
26.6
27.2
27.2
27.2
27.2
27.2
27.2
27.2
27.2
22.3
23.5
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
20.4
20.4
20.4
20.4
20.4
20.4
20.4
20.4
20.4
20.4
20.4
17
17
17
17
17
17
17
17
17
17
17
22.7
24.2
25.3
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
22.2
23.6
23.9
23.9
23.9
23.9
23.9
23.9
23.9
23.9
23.9
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
21.3
18.6
18.6
18.6
18.6
18.6
18.6
18.6
18.6
18.6
18.6
18.6
16
16
16
16
16
16
16
16
16
16
16
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
13.3
8
8.3
10
8.7
8
7.5
7.1
6.8
6.4
6.2
5.9
7.4
7.7
7.7
7.5
6.8
6.4
6.1
5.8
5.5
5.3
5
8.1
7.4
6.9
6.2
5.7
5.4
5.1
4.8
4.6
4.4
4.2
6.9
6.4
5.9
5.4
4.9
4.6
4.4
4.2
4
3.8
3.6
5.7
5.3
4.9
4.4
4
3.8
3.6
3.4
3.3
3.1
3
5.7
5.3
4.9
4.4
4.1
3.8
3.6
3.4
3.3
3.1
3
7.5
7.7
7.9
8
8
8.2
8.3
8.3
8.2
8.2
8.1
7
7.1
7.3
7.4
7.5
7.3
7.2
7.1
7.1
7
7
6.4
6.5
6.7
6.8
7.3
6.9
6.5
6.2
5.9
5.6
5.4
6.1
6.3
7.6
6.9
6.3
5.9
5.6
5.3
5.1
4.8
4.6
7.3
6.8
6.3
5.7
5.2
4.9
4.6
4.4
4.2
4
3.8
7.4
6.8
6.3
5.7
5.2
4.9
4.7
4.4
4.2
4
3.8
23.4
24.6
25.9
27.2
28.9
30.2
31.5
31.5
31.5
31.5
31.5
22.8
24
25.3
26.5
28.2
28.4
28.4
28.4
28.4
28.4
28.4
22.2
23.4
24.6
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
21.6
22.1
22.1
22.1
22.1
22.1
22.1
22.1
22.1
22.1
22.1
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
15.8
15.8
15.8
15.8
15.8
15.8
15.8
15.8
15.8
15.8
15.8
7.6
7.8
8
8
8.3
8.4
8.5
8
7.6
7.3
7
7
7.2
7.4
7.5
7.7
7.6
7.3
6.9
6.5
6.2
6
64
6.6
6.8
7.4
6.7
6.4
6
5.7
5.4
5.2
5
6.2
7.6
7
6.3
5.8
5.5
5.2
4.9
4.7
4.5
4.3
6.8
6.3
5.8
5.3
4.8
4.5
4.3
4.1
3.9
3.7
3.5
6.8
6.3
5.8
5.3
4.8
4.5
4.3
4.1
3.9
3.7
3.6
23
24.2
25.3
27
28.2
29
29
29
29
29
29
22.4
23.9
24.7
25.9
26.1
26.1
26.1
26.1
26.1
26.1
26.1
21.8
23
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
17.4
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
14.5
7.8
7.9
8.1
8.3
8.4
8.2
7.8
7.4
7
6.7
6.4
7.2
7.4
7.5
7.6
7.4
7
6.7
6.3
6
5.7
5.5
6.6
6.7
7.5
6.8
6.2
5.8
5.5
5.3
5
4.8
4.6
7.5
7
6.5
5.8
5.3
5
4.8
4.5
4.3
4.1
3.9
6.2
5.8
5.4
4.8
4.4
4.2
3.9
3.8
3.6
3.4
3.3
6.3
5.8
5.4
4.9
4.4
4.2
4
3.8
3.6
3.4
3.3
24
Heating Performance - HEATING PERFORMANCE DATA – 120
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
27.1
28.6
30
31.5
33
34.4
35.9
37
38.1
39.2
40.3
26.4
27.8
29.3
30.7
32.1
32.3
32.3
33.3
34.3
35.3
36.3
25.7
27.1
28.5
29.9
31.3
32.5
32.5
32.5
32.5
32.5
32.5
25.1
26.4
27.8
28.3
28.3
28.3
28.3
28.3
28.3
28.3
28.3
24.2
24.2
24.2
24.2
24.2
24.2
24.2
24.2
24.2
24.2
24.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
20.2
PI
kW
7.5
7.7
7.9
8
8.1
8.2
8.4
8.5
8.5
8.6
8.6
7
7.2
7.4
7.4
7.5
7.4
7.2
7.3
7.3
7.4
7.4
6.4
6.6
6.7
6.8
6.8
7.6
7.2
6.9
6.5
6.2
6
6.1
6.3
6.4
7.6
6.9
6.5
6.2
5.9
5.6
5.3
5.1
8.1
7.5
6.9
6.3
5.7
5.4
5.1
4.9
4.6
4.4
4.2
8.1
7.5
7
6.3
5.7
5.4
5.1
4.9
4.6
4.4
4.2
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
TC
kW
PI
kW
26.8
28.2
29.7
31.1
32.6
34
35.5
36
36.6
37.1
37.7
26.1
27.5
28.9
30.3
31.8
31.9
31.9
32.4
32.9
33.4
33.9
25.4
26.8
28.2
29.6
30.2
30.2
30.2
30.2
30.2
30.2
30.2
24.8
26.1
26.5
26.5
26.5
26.5
26.5
26.5
26.5
26.5
26.5
22.7
22.7
22.7
22.7
22.7
22.7
22.7
22.7
22.7
22.7
22.7
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
18.9
25.2
26.9
28.1
29.6
29.6
29.6
29.6
29.6
29.6
29.6
29.6
24.6
26.2
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
23.6
23.6
23.6
23.6
23.6
23.6
23.6
23.6
23.6
23.6
23.6
20.7
20.7
20.7
20.7
20.7
20.7
20.7
20.7
20.7
20.7
20.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
14.8
14.8
14.8
14.8
14.8
14.8
14.8
14.8
14.8
14.8
14.8
8.3
8.6
10.3
9
8.2
7.8
7.4
7
6.6
6.4
6.1
7.7
8
8
7.7
7
6.6
6.3
6
5.7
5.4
5.2
8.3
7.7
7.1
6.4
5.9
5.5
5.3
5
4.8
4.5
4.3
7.1
6.6
6.1
5.5
5.1
4.8
4.5
4.3
4.1
3.9
3.7
5.9
5.5
5.1
4.6
4.2
3.9
3.7
3.5
3.4
3.2
3.1
5.9
5.5
5.1
4.6
4.2
4
3.7
3.6
3.4
3.2
3.1
7.8
8
8.1
8.2
8.3
8.5
8.6
8.6
8.5
8.4
8.4
7.2
7.4
7.6
7.6
7.7
7.6
7.4
7.3
7.3
7.2
7.2
6.6
6.7
6.9
7
7.5
7.1
6.7
6.4
6.1
5.8
5.6
6.3
6.5
7.8
7.1
6.5
6.1
5.8
5.5
5.2
5
4.8
7.6
7
6.5
5.9
5.3
5.1
4.8
4.5
4.3
4.1
3.9
7.6
7
6.5
5.9
5.4
5.1
4.8
4.6
4.3
4.1
4
26
27.4
28.8
30.2
32.2
33.6
35
35
35
35
35
25.3
26.7
28.1
29.5
31.3
31.5
31.5
31.5
31.5
31.5
31.5
24.7
26
27.4
28
28
28
28
28
28
28
28
24.1
24.5
24.5
24.5
24.5
24.5
24.5
24.5
24.5
24.5
24.5
21
21
21
21
21
21
21
21
21
21
21
17.5
17.5
17.5
17.5
17.5
17.5
17.5
17.5
17.5
17.5
17.5
7.8
8
8.2
8.3
8.5
8.7
8.8
8.3
7.9
7.5
7.2
7.3
7.5
7.6
7.7
7.9
7.9
7.6
7.1
6.8
6.4
6.2
6.6
6.8
7
7.6
7
6.6
6.2
5.9
5.6
5.4
5.1
6.4
7.8
7.3
6.6
6
5.7
5.3
5.1
4.8
4.6
4.4
7
6.5
6
5.4
4.9
4.7
4.4
4.2
4
3.8
3.7
7
6.5
6
5.5
5
4.7
4.4
4.2
4
3.8
3.7
25.5
26.8
28.2
30
31.3
32.2
32.2
32.2
32.2
32.2
32.2
24.9
26.2
27.4
28.8
29
29
29
29
29
29
29
24.3
25.5
25.8
25.8
25.8
25.8
25.8
25.8
25.8
25.8
25.8
22.5
22.5
22.5
22.5
22.5
22.5
22.5
22.5
22.5
22.5
22.5
19.3
19.3
19.3
19.3
19.3
19.3
19.3
19.3
19.3
19.3
19.3
16.1
16.1
16.1
16.1
16.1
16.1
16.1
16.1
16.1
16.1
16.1
8
8.2
8.4
8.6
8.7
8.5
8
7.6
7.2
6.9
6.6
7.4
7.6
7.8
7.9
7.7
7.2
6.9
6.5
6.2
5.9
5.7
6.8
7
7.8
7
6.4
6
5.7
5.4
5.2
4.9
4.7
7.8
7.2
6.7
6
5.5
5.2
4.9
4.7
4.5
4.3
4.1
6.4
6
5.5
5
4.6
4.3
4.1
3.9
3.7
3.5
3.4
6.5
6
5.5
5
4.6
4.3
4.1
3.9
3.7
3.5
3.4
24
61
Heating Performance - HEATING PERFORMANCE DATA – 140
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
62
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
9.2
9.4
9.6
9.7
9.8
10
10.2
10.3
10.4
10.4
10.5
8.5
8.7
9
9
9.1
8.9
8.8
8.8
8.9
8.9
9
7.8
8
8.2
8.3
8.3
9.3
8.8
8.3
7.9
7.6
7.3
7.4
7.6
7.8
9.2
8.4
7.9
7.5
7.1
6.8
6.5
6.2
9.8
9.1
8.4
7.6
6.9
6.6
6.2
5.9
5.6
5.4
5.1
9.9
9.1
8.5
7.6
7
6.6
6.2
5.9
5.6
5.4
5.2
32.9
34.7
36.4
38.2
40
41.8
43.6
44.2
44.9
45.6
46.3
32.1
33.8
35.5
37.3
39
39.1
39.2
39.8
40.4
41
41.7
31.2
32.9
34.6
36.3
37.1
37.1
37.1
37.1
37.1
37.1
37.1
30.5
32.1
32.5
32.5
32.5
32.5
32.5
32.5
32.5
32.5
32.5
27.9
27.9
27.9
27.9
27.9
27.9
27.9
27.9
27.9
27.9
27.9
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
23.2
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
33.3
35.1
36.9
38.7
40.5
42.3
44.1
45.5
46.9
48.2
49.6
32.4
34.2
36
37.7
39.5
39.6
39.7
40.9
42.2
43.4
44.6
31.6
33.3
35
36.7
38.5
39.9
39.9
39.9
39.9
39.9
39.9
30.8
32.5
34.2
34.7
34.7
34.7
34.7
34.7
34.7
34.7
34.7
29.8
29.8
29.8
29.8
29.8
29.8
29.8
29.8
29.8
29.8
29.8
24.8
24.8
24.8
24.8
24.8
24.8
24.8
24.8
24.8
24.8
24.8
9.4
9.7
9.9
10
10.1
10.3
10.5
10.4
10.3
10.3
10.2
8.7
9
9.2
9.3
9.4
9.2
9
8.9
8.9
8.8
8.7
8
8.2
8.4
8.5
9.1
8.6
8.2
7.8
7.4
7.1
6.8
7.7
7.9
9.5
8.6
7.9
7.4
7
6.7
6.4
6.1
5.8
9.2
8.5
7.9
7.1
6.5
6.1
5.8
5.5
5.5
5
4.8
9.2
8.5
7.9
7.2
6.5
6.2
5.8
5.5
5.3
5
4.8
31.9
33.6
35.4
37.1
39.5
41.2
43
43
43
43
43
31.1
32.8
34.5
36.2
38.5
38.7
38.7
38.7
38.7
38.7
38.7
30.3
32
33.6
34.4
34.4
34.4
34.4
34.4
34.4
34.4
34.4
29.5
30.1
30.1
30.1
30.1
30.1
30.1
30.1
30.1
30.1
30.1
25.8
25.8
25.8
25.8
25.8
25.8
25.8
25.8
25.8
25.8
25.8
21.5
21.5
21.5
21.5
21.5
21.5
21.5
21.5
21.5
21.5
21.5
9.5
9.8
10
10.1
10.4
10.6
10.7
10.1
9.6
9.1
8.8
8.8
9.1
9.3
9.4
9.6
9.6
9.2
8.6
8.2
7.8
7.5
8.1
8.3
8.5
9.3
8.5
8
7.6
7.2
6.8
6.5
6.3
7.7
9.5
8.8
8
7.3
6.9
6.5
6.2
5.9
5.6
5.4
8.5
7.9
7.3
6.6
6
5.7
5.4
5.1
4.9
4.7
4.4
8.6
7.9
7.3
6.6
6
5.7
5.4
5.1
4.9
4.7
4.5
31.4
33
34.6
36.8
38.4
39.6
39.6
39.6
39.6
39.6
39.6
30.6
32.2
33.7
35.3
35.6
35.6
35.6
35.6
35.6
35.6
35.6
29.8
31.3
31.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
27.7
27.7
27.7
27.7
27.7
27.7
27.7
27.7
27.7
27.7
27.7
23.7
23.7
23.7
23.7
23.7
23.7
23.7
23.7
23.7
23.7
23.7
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
9.8
10
10.2
10.5
10.5
10.3
9.7
9.3
8.8
8.4
8.1
9.1
9.3
9.5
9.6
9.3
8.8
8.4
7.9
7.6
7.2
6.9
8.3
8.5
9.4
8.5
7.8
7.3
7
6.6
6.3
6
5.8
9.5
8.7
8.1
7.3
6.7
6.3
6
5.7
5.4
5.2
4.9
7.8
7.2
6.7
6.1
5.5
5.2
5
4.7
4.5
4.3
4.1
7.9
7.3
6.7
6.1
5.6
5.2
5
4.7
4.5
4.3
4.1
24
TC
kW
PI
kW
31
33
34.5
36.3
36.3
36.3
36.3
36.3
36.3
36.3
36.3
30.2
32.2
32.7
32.7
32.7
32.7
32.7
32.7
32.7
32.7
32.7
29
29
29
29
29
29
29
29
29
29
29
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
21.8
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
18.2
10.1
10.4
12.6
11
10
9.4
8.9
8.5
8.1
7.7
7.4
9.4
9.7
9.7
9.4
8.6
8.1
7.7
7.3
6.9
6.6
6.3
10.1
9.3
8.7
7.8
7.1
6.7
6.4
6.1
5.8
5.5
5.3
8.7
8
7.5
6.7
6.1
5.8
5.5
5.2
5
4.7
4.5
7.2
6.6
6.2
5.6
5.1
4.8
4.5
4.3
4.1
3.9
3.8
7.2
6.7
6.2
5.6
5.1
4.8
4.6
4.3
4.1
3.9
3.8
Heating Performance - HEATING PERFORMANCE DATA – 160
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
11.5
11.8
12.1
12.2
12.3
12.6
12.8
12.9
13
13.1
13.2
10.7
11
11.2
11.3
11.5
11.2
11
11.1
11.1
11.2
11.3
9.7
10
10.3
10.4
10.4
11.6
11
10.5
10
9.5
9.1
9.3
9.6
9.8
11.5
10.5
9.9
9.4
8.9
8.5
8.1
7.8
12.3
11.4
10.6
9.6
8.7
8.2
7.8
7.4
7.1
6.7
6.5
12.4
11.4
10.6
9.6
8.7
8.3
7.8
7.4
7.1
6.8
6.5
35.9
37.9
39.8
41.8
43.7
45.7
47.6
48.4
49.1
49.9
50.6
35
36.9
38.8
40.7
42.6
42.8
42.9
43.5
44.2
44.9
45.5
34.1
36
37.8
39.7
40.6
40.6
40.6
40.6
40.6
40.6
40.6
33.3
35.1
35.5
35.5
35.5
35.5
35.5
35.5
35.5
35.5
35.5
30.4
30.4
30.4
30.4
30.4
30.4
30.4
30.4
30.4
30.4
30.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
36.4
38.3
40.3
42.3
44.3
46.2
48.2
49.7
51.2
52.7
54.2
35.5
37.4
39.3
41.2
43.2
43.3
43.4
44.7
46.1
47.4
48.7
34.5
36.4
38.3
40.2
42
43.6
43.6
43.6
43.6
43.6
43.6
33.7
35.5
37.3
38
38
38
38
38
38
38
38
32.5
32.5
32.5
32.5
32.5
32.5
32.5
32.5
32.5
32.5
32.5
27.1
27.1
27.1
27.1
27.1
27.1
27.1
27.1
27.1
27.1
27.1
11.8
12.1
12.4
12.5
12.7
12.9
13.2
13.1
13
12.9
12.8
11
11.3
11.5
11.6
11.8
11.5
11.3
11.2
11.1
11
11
10
10.3
10.5
10.6
11.5
10.8
10.3
9.7
9.3
8.9
8.5
9.6
9.9
12
10.8
9.9
9.3
8.8
8.4
8
7.6
7.3
11.5
10.7
9.9
8.9
8.2
7.7
7.3
6.9
6.6
6.3
6
11.6
10.7
9.9
9
8.2
7.7
7.3
7
6.6
6.3
6.1
34.9
36.8
38.7
40.6
43.2
45.1
47
47
47
47
47
34
35.9
37.7
39.5
42.1
42.3
42.3
42.3
42.3
42.3
42.3
33.1
34.9
36.7
37.6
37.6
37.6
37.6
37.6
37.6
37.6
37.6
32.3
32.9
32.9
32.9
32.9
32.9
32.9
32.9
32.9
32.9
32.9
28.2
28.2
28.2
28.2
28.2
28.2
28.2
28.2
28.2
28.2
28.2
23.5
23.5
23.5
23.5
23.5
23.5
23.5
23.5
23.5
23.5
23.5
11.9
12.3
12.6
12.7
13
13.3
13.4
12.6
12
11.5
11
11.1
11.4
11.7
11.8
12.1
12
11.6
10.8
10.3
9.8
9.4
10.1
10.4
10.6
11.6
10.6
10
9.5
9
8.6
8.2
7.8
9.7
11.9
11.1
10
9.1
8.6
8.2
7.8
7.4
7
6.7
10.7
9.9
9.2
8.3
7.5
7.1
6.8
6.4
6.1
5.8
5.6
10.7
9.9
9.2
8.3
7.6
7.2
6.8
6.4
6.1
5.9
5.6
34.3
36
37.8
40.2
42
43.2
43.2
43.2
43.2
43.2
43.2
35.1
36.8
38.6
38.9
38.9
38.9
38.9
38.9
38.9
38.9
38.9
32.6
34.2
34.6
34.6
34.6
34.6
34.6
34.6
34.6
34.6
34.6
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
26
26
26
26
26
26
26
26
26
26
26
21.6
21.6
21.6
21.6
21.6
21.6
21.6
21.6
21.6
21.6
21.6
12.2
12.5
12.8
13.1
13.2
12.9
12.2
11.6
11.1
10.6
10.1
11.4
11.6
11.9
12
11.7
11.1
10.5
9.9
9.5
9
8.7
10.4
10.6
11.8
10.7
9.8
9.2
8.7
8.3
7.9
7.5
7.2
11.9
11
10.2
9.2
8.4
7.9
7.5
7.1
6.8
6.5
6.2
9.8
9.1
8.4
7.6
7
6.6
6.2
5.9
5.6
5.4
5.1
9.9
9.1
8.5
7.7
7
6.6
6.2
5.9
5.6
5.4
5.2
24
TC
kW
PI
kW
33.9
36.1
37.7
39.7
39.7
39.7
39.7
39.7
39.7
39.7
39.7
35.2
35.7
35.7
35.7
35.7
35.7
35.7
35.7
35.7
35.7
35.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
31.7
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
19.8
12.7
13.1
15.8
13.7
12.5
11.8
11.2
10.7
10.1
9.7
9.3
11.7
12.2
12.1
11.8
10.8
10.1
9.6
9.1
8.7
8.3
7.9
12.7
11.7
10.9
9.8
9
8.5
8
7.6
7.3
6.9
6.6
10.9
10.1
9.4
8.4
7.7
7.3
6.9
6.5
6.2
5.9
5.7
9
8.3
7.7
7
6.4
6
5.7
5.4
5.2
4.9
4.7
9
8.4
7.8
7
6.4
6
5.7
5.4
5.2
4.9
4.7
63
Heating Performance - HEATING PERFORMANCE DATA – 180
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
64
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
14.1
14.5
14.8
15
15.1
15.4
15.7
15.9
16
16.1
16.2
13.1
13.5
13.8
13.9
14
13.8
13.5
13.6
13.7
13.8
13.9
12
12.3
12.6
12.7
12.8
14.2
13.5
12.8
12.2
11.7
11.2
11.5
11.8
12
14.2
12.9
12.2
11.5
11
10.4
10
9.5
15.1
14
13
11.7
10.7
10.1
9.6
9.1
8.7
8.3
7.9
15.2
14
13
11.8
10.7
10.1
9.6
9.1
8.7
8.3
7.9
46.3
48.8
51.3
53.8
56.3
58.8
61.3
62.3
63.2
64.2
65.1
45.1
47.5
50
52.4
54.9
55.1
55.2
56
56.9
57.8
58.6
43.9
46.3
48.7
51.1
52.3
52.3
52.3
52.3
52.3
52.3
52.3
42.8
45.2
45.7
45.7
45.7
45.7
45.7
45.7
45.7
45.7
45.7
39.2
39.2
39.2
39.2
39.2
39.2
39.2
39.2
39.2
39.2
39.2
32.7
32.7
32.7
32.7
32.7
32.7
32.7
32.7
32.7
32.7
32.7
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
46.8
49.4
51.9
54.4
57
59.5
62.1
64
65.9
67.8
69.7
45.6
48.1
50.6
53.1
55.6
55.8
55.9
57.6
59.3
61
62.7
44.4
46.9
49.3
51.7
54.1
56.1
56.1
56.1
56.1
56.1
56.1
43.3
45.7
48.1
48.9
48.9
48.9
48.9
48.9
48.9
48.9
48.9
41.9
41.9
41.9
41.9
41.9
41.9
41.9
41.9
41.9
41.9
41.9
34.9
34.9
34.9
34.9
34.9
34.9
34.9
34.9
34.9
34.9
34.9
14.5
14.9
15.2
15.4
15.5
15.8
16.1
16
15.9
15.8
15.7
13.5
13.8
14.2
14.3
14.4
14.1
13.8
13.7
13.6
13.5
13.5
12.3
12.6
12.9
13.1
14
13.3
12.6
11.9
11.4
10.9
10.4
11.8
12.1
14.7
13.3
12.1
11.4
10.8
10.3
9.8
9.3
8.9
14.2
13.1
12.1
11
10
9.5
8.9
8.5
8.1
7.7
7.4
14.2
13.1
12.2
11
10
9.5
9
8.5
8.1
7.8
7.4
44.9
47.3
49.8
52.2
55.6
58
60.5
60.5
60.5
60.5
60.5
43.8
46.2
48.5
50.9
54.2
54.5
54.5
54.5
54.5
54.5
54.5
42.7
45
47.3
48.4
48.4
48.4
48.4
48.4
48.4
48.4
48.4
41.6
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
36.3
36.3
36.3
36.3
36.3
36.3
36.3
36.3
36.3
36.3
36.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
30.3
14.6
15
15.4
15.5
16
16.3
16.5
15.5
14.8
14.1
13.5
13.6
14
14.3
14.4
14.8
14.8
14.2
13.3
12.6
12.1
11.5
12.4
12.8
13.1
14.3
13
12.3
11.7
11.1
10.5
10
9.6
11.9
14.6
13.6
12.3
11.2
10.6
10
9.5
9.1
8.6
8.3
13.1
12.1
11.3
10.2
9.3
8.8
8.3
7.9
7.5
7.2
6.8
13.2
12.2
11.3
10.2
9.3
8.8
8.3
7.9
7.5
7.2
6.9
44.1
46.4
48.7
51.8
54.1
55.7
55.7
55.7
55.7
55.7
55.7
43
45.2
47.4
49.7
50.1
50.1
50.1
50.1
50.1
50.1
50.1
41.9
44.1
44.5
44.5
44.5
44.5
44.5
44.5
44.5
44.5
44.5
39
39
39
39
39
39
39
39
39
39
39
33.4
33.4
33.4
33.4
33.4
33.4
33.4
33.4
33.4
33.4
33.4
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
27.8
15
15.4
15.7
16.1
16.2
15.8
15
14.2
13.6
13
12.4
13.9
14.3
14.6
14.7
14.4
13.6
12.9
12.2
11.6
11.1
10.6
12.7
13
14.5
13.1
12
11.3
10.7
10.2
9.7
9.3
8.9
14.6
13.5
12.5
11.3
10.3
9.7
9.2
8.8
8.3
8
7.6
12.1
11.1
10.4
9.3
8.5
8
7.6
7.3
6.9
6.6
6.3
12.1
11.2
10.4
9.4
8.6
8.1
7.7
7.3
6.9
6.6
6.6
24
TC
kW
PI
kW
43.6
46.4
48.5
51.1
51.1
51.1
51.1
51.1
51.1
51.1
51.1
42.5
45.3
46
46
46
46
46
46
46
46
46
40.9
40.9
40.9
40.9
40.9
40.9
40.9
40.9
40.9
40.9
40.9
35.8
35.8
35.8
35.8
35.8
35.8
35.8
35.8
35.8
35.8
35.8
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
25.5
25.5
25.5
25.5
25.5
25.5
25.5
25.5
25.5
25.5
25.5
15.5
16.1
19.3
16.9
15.4
14.5
13.8
13.1
12.4
11.9
11.4
14.4
14.9
14.9
14.5
13.2
12.4
11.8
11.2
10.7
10.2
9.7
15.6
14.4
13.3
12
11
10.4
9.8
9.3
8.9
8.5
8.1
13.4
12.4
11.5
10.4
9.5
8.9
8.4
8
7.7
7.3
7
11.1
10.2
9.5
8.6
7.8
7.4
7
6.6
6.3
6
5.8
11.1
10.3
9.5
8.6
7.8
7.4
7
6.7
6.4
6.1
5.8
Heating Performance - HEATING PERFORMANCE DATA – 200
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
14.6
15
15.4
15.5
15.6
16
16.3
16.4
16.5
16.6
16.7
13.6
13.9
14.3
14.4
14.5
14.2
13.9
14.1
14.1
14.2
14.4
12.4
12.7
13
13.1
13.3
14.7
14
13.3
12.6
12.1
11.6
11.9
12.2
12.5
14.6
13.4
12.6
11.9
11.4
10.8
10.3
9.9
15.7
14.5
13.4
12.1
11.1
10.4
9.9
9.4
9
8.6
8.2
15.7
14.5
13.5
12.2
11.1
10.5
9.9
9.4
9
8.6
8.2
48.2
50.8
53.4
56
58.6
61.2
63.8
64.8
65.8
66.8
67.8
47
49.5
52
54.6
57.2
57.4
57.4
58.3
59.2
60.1
61
45.8
48.2
50.7
53.2
54.4
54.4
54.4
54.4
54.4
54.4
54.4
44.6
47
47.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
40.8
40.8
40.8
40.8
40.8
40.8
40.8
40.8
40.8
40.8
40.8
34
34
34
34
34
34
34
34
34
34
34
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
48.7
51.4
54
56.7
59.3
62
64.6
66.6
68.6
70.6
72.6
47.5
50.1
52.7
55.3
57.8
58.1
58.2
60
61.8
63.5
65.3
46.3
48.8
51.3
53.8
56.4
58.5
58.5
58.5
58.5
58.5
58.5
45.1
47.6
50
50.9
50.9
50.9
50.9
50.9
50.9
50.9
50.9
43.6
43.6
43.6
43.6
43.6
43.6
43.6
43.6
43.6
43.6
43.6
36.4
36.4
36.4
36.4
36.4
36.4
36.4
36.4
36.4
36.4
36.4
15
15.4
15.8
15.9
16.1
16.4
16.7
16.6
16.5
16.4
16.2
13.9
14.3
14.6
14.8
14.9
14.6
14.3
14.2
14.1
14
13.9
12.7
13.1
13.4
13.5
14.5
13.7
13
12.4
11.8
11.2
10.8
12.2
12.5
15.2
13.7
12.5
11.8
11.2
10.6
10.1
9.7
9.2
14.6
13.5
12.6
11.4
10.3
9.8
9.3
8.8
8.4
8
7.6
14.7
13.6
12.6
11.4
10.4
9.8
9.3
8.8
8.4
8
7.7
46.8
49.3
51.8
54.4
57.9
60.4
63
63
63
63
63
45.6
48.1
50.5
53
56.4
56.7
56.7
56.7
56.7
56.7
56.7
44.4
46.8
49.3
50.4
50.4
50.4
50.4
50.4
50.4
50.4
50.4
43.3
44.1
44.1
44.1
44.1
44.1
44.1
44.1
44.1
44.1
44.1
37.8
37.8
37.8
37.8
37.8
37.8
37.8
37.8
37.8
37.8
37.8
31.5
31.5
31.5
31.5
31.5
31.5
31.5
31.5
31.5
31.5
31.5
15.1
15.6
15.9
16.1
16.5
16.8
17.1
16
15.3
14.6
13.9
14.1
14.4
14.8
14.9
15.3
15.3
14.7
13.7
13.1
12.5
11.9
12.9
13.2
13.5
14.8
13.5
12.7
12.1
11.4
10.9
10.4
10
12.3
15.1
14.1
12.7
11.6
10.9
10.3
9.8
9.4
8.9
8.6
13.6
12.5
11.6
10.5
9.6
9.1
8.6
8.1
7.8
7.4
7.1
13.6
12.6
11.7
10.6
9.6
9.1
8.6
8.2
7.8
7.4
7.1
45.9
48.3
50.7
53.9
56.3
58
58
58
58
58
58
44.8
47.1
49.4
51.8
52.2
52.2
52.2
52.2
52.2
52.2
52.2
43.7
45.9
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
40.6
40.6
40.6
40.6
40.6
40.6
40.6
40.6
40.6
40.6
40.6
34.8
34.8
34.8
34.8
34.8
34.8
34.8
34.8
34.8
34.8
34.8
29
29
29
29
29
29
29
29
29
29
29
15.5
15.9
16.2
16.7
16.8
16.4
15.5
14.7
14
13.4
12.8
14.4
14.8
15.1
15.2
14.9
14
13.3
12.6
12
11.5
11
13.2
13.5
15
13.6
12.4
11.7
11.1
10.5
10
9.6
9.2
15.1
13.9
12.9
11.7
10.6
10.1
9.5
9.1
8.6
8.2
7.9
12.5
11.5
10.7
9.7
8.8
8.3
7.9
7.5
7.1
6.8
6.5
12.5
11.6
10.7
9.7
8.8
8.3
7.9
7.5
7.2
6.8
6.6
24
TC
kW
PI
kW
45.4
48.4
50.5
53.2
53.2
53.2
53.2
53.2
53.2
53.2
53.2
44.3
47.2
47.9
47.9
47.9
47.9
47.9
47.9
47.9
47.9
47.9
42.5
42.5
42.5
42.5
42.5
42.5
42.5
42.5
42.5
42.5
42.5
37.2
37.2
37.2
37.2
37.2
37.2
37.2
37.2
37.2
37.2
37.2
31.9
31.9
31.9
31.9
31.9
31.9
31.9
31.9
31.9
31.9
31.9
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
26.6
16.1
16.6
20
17.4
15.9
15
14.2
13.5
12.9
12.3
11.8
14.9
15.4
15.4
15
13.6
12.9
12.2
11.6
11
10.5
10.1
16.1
14.9
13.8
12.5
11.4
10.7
10.2
9.7
9.2
8.8
8.4
13.8
12.8
11.9
10.7
9.8
9.2
8.7
8.3
7.9
7.6
7.2
11.5
10.6
9.8
8.9
8.1
7.6
7.2
6.9
6.6
6.3
6
11.5
10.6
9.8
8.9
8.1
7.7
7.3
6.9
6.6
6.3
6
65
Heating Performance - HEATING PERFORMANCE DATA – 220
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
66
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
14.8
15.2
15.6
15.7
15.9
16.2
16.5
16.7
16.8
16.9
17
13.8
14.1
14.5
14.6
14.8
14.5
14.2
14.3
14.4
14.5
14.6
12.6
12.9
13.2
13.4
13.5
15
14.2
13.5
12.9
12.3
11.7
12
12.4
12.7
14.9
13.6
12.8
12.1
11.5
11
10.5
10
15.9
14.7
13.6
12.3
11.2
10.6
10.1
9.5
9.1
8.7
8.3
16
14.8
13.7
12.4
11.3
10.7
10.1
9.6
9.1
8.7
8.3
50.8
53.6
56.3
59.1
61.9
64.6
67.4
68.4
69.5
70.5
71.6
49.6
52.3
54.9
57.6
60.3
60.5
60.6
61.6
62.5
63.5
64.4
48.3
50.9
53.5
56.2
57.5
57.5
57.5
57.5
57.5
57.5
57.5
47.1
49.6
50.3
50.3
50.3
50.3
50.3
50.3
50.3
50.3
50.3
43.1
43.1
43.1
43.1
43.1
43.1
43.1
43.1
43.1
43.1
43.1
35.9
35.9
35.9
35.9
35.9
35.9
35.9
35.9
35.9
35.9
35.9
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
51.4
54.2
57
59.8
62.6
65.4
68.2
70.3
72.5
74.5
76.6
50.2
52.9
55.6
58.3
61.1
61.3
61.4
63.3
65.2
67.1
69
48.9
51.5
54.2
56.8
59.5
61.7
61.7
61.7
61.7
61.7
61.7
47.6
50.2
52.8
53.7
53.7
53.7
53.7
53.7
53.7
53.7
53.7
46.1
46.1
46.1
46.1
46.1
46.1
46.1
46.1
46.1
46.1
46.1
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
38.4
15.3
15.7
16
16.2
16.3
16.6
17
16.9
16.7
16.6
16.5
14.1
14.5
14.9
15
15.2
14.9
14.5
14.4
14.3
14.2
14.1
12.9
13.3
13.6
13.7
14.8
14
13.2
12.6
12
11.4
10.9
12.4
12.7
15.4
13.9
12.7
12
11.4
10.8
10.3
9.8
9.4
14.9
13.8
12.8
11.5
10.5
9.9
9.4
8.9
8.5
8.1
7.8
15
13.8
12.8
11.6
10.6
10
9.5
9
8.6
8.2
7.8
49.4
52
54.7
57.4
61.1
63.8
66.5
66.5
66.5
66.5
66.5
48.1
50.7
53.3
56
59.5
59.9
59.9
59.9
59.9
59.9
59.9
46.9
49.4
52
53.2
53.2
53.2
53.2
53.2
53.2
53.2
53.2
45.7
46.6
46.6
46.6
46.6
46.6
46.6
46.6
46.6
46.6
46.6
39.9
39.9
39.9
39.9
39.9
39.9
39.9
39.9
39.9
39.9
39.9
33.3
33.3
33.3
33.3
33.3
33.3
33.3
33.3
33.3
33.3
33.3
15.4
15.8
16.2
16.3
16.8
17.1
17.3
16.3
15.5
14.8
14.2
14.3
14.7
15.1
15.2
15.6
15.5
14.9
14
13.3
12.7
12.1
13.1
13.4
13.7
15
13.7
12.9
12.3
11.6
11.1
10.6
10.1
12.5
15.4
14.3
12.9
11.8
11.1
10.5
10
9.5
9.1
8.7
13.8
12.7
11.8
10.7
9.7
9.2
8.7
8.3
7.9
7.5
7.2
13.8
12.8
11.9
10.7
9.8
9.2
8.7
8.3
7.9
7.6
7.2
48.5
51
53.5
56.9
59.4
61.2
61.2
61.2
61.2
61.2
61.2
47.3
49.7
52.1
54.6
55.1
55.1
55.1
55.1
55.1
55.1
55.1
46.1
48.5
48.9
48.9
48.9
48.9
48.9
48.9
48.9
48.9
48.9
42.8
42.8
42.8
42.8
42.8
42.8
42.8
42.8
42.8
42.8
42.8
36.7
36.7
36.7
36.7
36.7
36.7
36.7
36.7
36.7
36.7
36.7
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
30.6
15.8
16.2
16.5
16.9
17
16.6
15.8
15
14.3
13.6
13
14.7
15
15.3
15.5
15.1
14.3
13.5
12.8
12.2
11.7
11.2
13.4
13.7
15.3
13.8
12.6
11.9
11.3
10.7
10.2
9.7
9.3
15.3
14.1
13.1
11.9
10.8
10.2
9.7
9.2
8.8
8.4
8
12.7
11.7
10.9
9.8
9
8.5
8
7.6
7.3
6.9
6.6
12.7
11.8
10.9
9.9
9
8.5
8
7.7
7.3
7
6.7
24
TC
kW
PI
kW
48
51
53.3
56.1
56.1
56.1
56.1
56.1
56.1
56.1
56.1
46.8
49.8
50.5
50.5
50.5
50.5
50.5
50.5
50.5
50.5
50.5
44.9
44.9
44.9
44.9
44.9
44.9
44.9
44.9
44.9
44.9
44.9
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
33.7
33.7
33.7
33.7
33.7
33.7
33.7
33.7
33.7
33.7
33.7
28.1
28.1
28.1
28.1
28.1
28.1
28.1
28.1
28.1
28.1
28.1
16.3
16.9
20.3
17.7
16.2
15.3
14.5
13.8
13.1
12.5
12
15.1
15.7
15.7
15.2
13.9
13.1
12.4
11.8
11.2
10.7
10.2
16.4
15.1
14
12.7
11.6
10.9
10.3
9.8
9.4
8.9
8.5
14.1
13
12.1
10.9
9.9
9.4
8.9
8.4
8
7.7
7.4
11.7
10.8
10
9
8.2
7.8
7.4
7
6.7
6.4
6.1
11.7
10.8
10
9
8.3
7.8
7.4
7
6.7
6.4
6.1
Heating Performance - HEATING PERFORMANCE DATA – 240
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
16.5
16.9
17.3
17.5
17.6
18
18.3
18.5
18.6
18.8
18.9
15.3
15.7
16.1
16.2
16.4
16.1
15.7
15.9
16
16.1
16.2
14
14.3
14.7
14.8
15
16.6
15.8
15
14.3
13.6
13
13.4
13.7
14.1
16.5
15.1
14.2
13.5
12.8
12.2
11.6
11.1
17.7
16.3
15.1
13.7
12.5
11.8
11.2
10.6
10.1
9.6
9.2
17.7
16.4
15.2
13.7
12.5
11.8
11.2
10.6
10.1
9.7
9.3
57
60.1
63.1
66.2
69.3
72.4
75.5
76.7
77.8
79
80.2
55.5
58.5
61.5
64.6
67.6
67.8
67.9
69
70.1
71.1
72.2
54.1
57
60
62.9
64.4
64.4
64.4
64.4
64.4
64.4
64.4
52.8
55.6
56.3
56.3
56.3
56.3
56.3
56.3
56.3
56.3
56.3
48.3
48.3
48.3
48.3
48.3
48.3
48.3
48.3
48.3
48.3
48.3
40.2
40.2
40.2
40.2
40.2
40.2
40.2
40.2
40.2
40.2
40.2
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
57.6
60.8
63.9
67
70.2
73.3
76.4
78.8
81.2
83.5
85.9
56.2
59.3
62.3
65.3
68.4
68.7
68.8
70.9
73
75.1
77.3
54.7
57.7
60.7
63.7
66.7
69.1
69.1
69.1
69.1
69.1
69.1
53.3
56.3
59.2
60.2
60.2
60.2
60.2
60.2
60.2
60.2
60.2
51.6
51.6
51.6
51.6
51.6
51.6
51.6
51.6
51.6
51.6
51.6
43
43
43
43
43
43
43
43
43
43
43
16.9
17.4
17.8
18
18.1
18.5
18.8
18.7
18.6
18.4
18.3
15.7
16.1
16.5
16.7
16.8
16.5
16.1
16
15.9
15.8
15.7
14.3
14.7
15.1
15.2
16.4
15.5
14.7
13.9
13.3
12.7
12.1
13.8
14.1
17.1
15.5
14.1
13.3
12.6
12
11.4
10.9
10.4
16.5
15.3
14.2
12.8
11.7
11
10.4
9.9
9.4
9
8.6
16.6
15.3
14.2
12.9
11.7
11.1
10.5
10
9.5
9.1
8.7
55.3
58.3
61.3
64.3
68.4
71.5
74.5
74.5
74.5
74.5
74.5
53.9
56.8
59.8
62.7
66.7
67.1
67.1
67.1
67.1
67.1
67.1
52.5
55.4
58.2
59.6
59.6
59.6
59.6
59.6
59.6
59.6
59.6
51.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
37.3
37.3
37.3
37.3
37.3
37.3
37.3
37.3
37.3
37.3
37.3
17.1
17.5
18
18.1
18.6
19
19.2
18.1
17.2
16.4
15.7
15.9
16.3
16.7
16.9
17.3
17.2
16.6
15.5
14.8
14.1
13.5
14.5
14.9
15.2
16.6
15.2
14.3
13.6
12.9
12.3
11.7
11.2
13.9
17.1
15.9
14.3
13.1
12.3
11.7
11.1
10.6
10.1
9.6
15.3
14.1
13.1
11.9
10.8
10.2
9.7
9.2
8.7
8.4
8
15.4
14.2
13.2
11.9
10.9
10.2
9.7
9.2
8.8
8.4
8
54.3
57.1
59.9
63.8
66.6
68.5
68.5
68.5
68.5
68.5
68.5
53
55.7
58.4
61.2
61.7
61.7
61.7
61.7
61.7
61.7
61.7
51.6
54.3
54.8
54.8
54.8
54.8
54.8
54.8
54.8
54.8
54.8
48
48
48
48
48
48
48
48
48
48
48
41.1
41.1
41.1
41.1
41.1
41.1
41.1
41.1
41.1
41.1
41.1
34.3
34.3
34.3
34.3
34.3
34.3
34.3
34.3
34.3
34.3
34.3
17.5
17.9
18.3
18.8
18.9
18.5
17.5
16.6
15.8
15.1
14.5
16.3
16.6
17
17.2
16.8
15.8
15
14.2
13.6
13
12.4
14.9
15.2
17
15.3
14
13.2
12.5
11.9
11.3
10.8
10.3
17
15.7
14.6
13.2
12
11.3
10.7
10.2
9.7
9.3
8.9
14.1
13
12.1
10.9
10
9.4
8.9
8.5
8.1
7.7
7.4
14.1
13.1
12.1
11
10
9.4
8.9
8.5
8.1
7.7
7.4
24
TC
kW
PI
kW
53.7
57.2
59.7
62.9
62.9
62.9
62.9
62.9
62.9
62.9
62.9
52.4
55.8
56.6
56.6
56.6
56.6
56.6
56.6
56.6
56.6
56.6
50.3
50.3
50.3
50.3
50.3
50.3
50.3
50.3
50.3
50.3
50.3
44
44
44
44
44
44
44
44
44
44
44
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
31.4
31.4
31.4
31.4
31.4
31.4
31.4
31.4
31.4
31.4
31.4
18.1
18.8
22.5
19.7
18
17
16.1
15.3
14.5
13.9
13.3
16.8
17.4
17.4
16.9
15.4
14.5
13.8
13.1
12.4
11.9
11.4
18.2
16.8
15.6
14.1
12.8
12.1
11.5
10.9
10.4
9.9
9.5
15.6
14.4
13.4
12.1
11
10.4
9.9
9.4
8.9
8.5
8.2
12.9
11.9
11.1
10
9.1
8.6
8.2
7.7
7.4
7.1
6.7
13
12
11.1
10
9.2
8.6
8.2
7.8
7.4
7.1
6.8
67
Heating Performance - HEATING PERFORMANCE DATA – 260
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
68
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
18.8
19.3
19.8
19.9
20.2
20.6
20.9
21.1
21.3
21.4
21.6
17.5
17.9
18.4
18.5
18.7
18.3
18
18.1
18.2
18.3
18.5
15.9
16.4
16.8
16.9
17.1
19
18
17.1
16.3
15.6
14.9
15.3
15.7
16.1
18.9
17.2
16.3
15.4
14.6
13.9
13.3
12.7
20.2
18.6
17.3
15.6
14.2
13.4
12.7
12.1
11.5
11
10.5
20.2
18.7
17.3
15.7
14.3
13.5
12.8
12.2
11.6
11
10.6
60
63.3
66.5
69.8
73
76.3
79.5
80.8
82
83.3
84.5
58.5
61.7
64.8
68
71.2
71.5
71.6
72.7
73.8
74.9
76.1
57
60.1
63.2
66.3
67.8
67.8
67.8
67.8
67.8
67.8
67.8
55.6
58.6
59.4
59.4
59.4
59.4
59.4
59.4
59.4
59.4
59.4
50.9
50.9
50.9
50.9
50.9
50.9
50.9
50.9
50.9
50.9
50.9
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
42.4
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
60.7
64
67.3
70.6
73.9
77.2
80.5
83
85.5
88
90.5
59.2
62.4
65.7
68.9
72.1
72.4
72.5
74.7
77
79.2
81.4
57.7
60.8
64
67.1
70.2
72.8
72.8
72.8
72.8
72.8
72.8
56.2
59.3
62.4
63.4
63.4
63.4
63.4
63.4
63.4
63.4
63.4
54.4
54.4
54.4
54.4
54.4
54.4
54.4
54.4
54.4
54.4
54.4
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
19.3
19.8
20.3
20.5
20.7
21.1
21.5
21.4
21.2
21.1
20.9
17.9
18.4
18.9
19
19.2
18.8
18.4
18.3
18.2
18
17.9
16.4
16.8
17.2
17.4
18.7
17.7
16.8
15.9
15.2
14.5
13.9
15.7
16.1
19.5
17.7
16.1
15.2
14.4
13.7
13
12.4
11.9
18.9
17.4
16.2
14.6
13.3
12.6
11.9
11.3
10.8
10.3
9.8
19
17.5
16.2
14.7
13.4
12.6
12
11.4
10.8
10.3
9.9
58.3
61.4
64.6
67.7
72.1
75.3
78.5
78.5
78.5
78.5
78.5
56.8
59.9
63
66.1
70.3
70.7
70.7
70.7
70.7
70.7
70.7
55.3
58.3
61.4
62.8
62.8
62.8
62.8
62.8
62.8
62.8
62.8
53.9
55
55
55
55
55
55
55
55
55
55
47.1
47.1
47.1
47.1
47.1
47.1
47.1
47.1
47.1
47.1
47.1
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
39.3
19.5
20
20.5
20.7
21.3
21.7
22
20.6
19.7
18.7
18
18.1
18.6
19.1
19.2
19.7
19.7
18.9
17.7
16.8
16.1
15.4
16.6
17
17.4
19
17.3
16.4
15.5
14.7
14
13.4
12.8
15.8
19.5
18.1
16.3
14.9
14.1
13.3
12.7
12.1
11.5
11
17.5
16.1
15
13.5
12.3
11.7
11
10.5
10
9.5
9.1
17.5
16.2
15
13.6
12.4
11.7
11.1
10.5
10
9.6
9.2
57.2
60.2
63.1
67.2
70.2
72.2
72.2
72.2
72.2
72.2
72.2
55.8
58.7
61.5
64.5
65
65
65
65
65
65
65
54.4
57.2
57.8
57.8
57.8
57.8
57.8
57.8
57.8
57.8
57.8
50.5
50.5
50.5
50.5
50.5
50.5
50.5
50.5
50.5
50.5
50.5
43.3
43.3
43.3
43.3
43.3
43.3
43.3
43.3
43.3
43.3
43.3
36.1
36.1
36.1
36.1
36.1
36.1
36.1
36.1
36.1
36.1
36.1
20
20.5
20.9
21.4
21.6
21.1
20
19
18.1
17.3
16.5
18.6
19
19.4
19.6
19.1
18.1
17.1
16.3
15.5
14.8
14.1
17
17.4
19.4
17.5
16
15.1
14.3
13.6
12.9
12.3
11.8
19.4
17.9
16.6
15
13.7
12.9
12.3
11.7
11.1
10.6
10.1
16.1
14.9
13.8
12.4
11.4
10.7
10.2
9.7
9.2
8.8
8.4
16.1
14.9
13.8
12.5
11.4
10.8
10.2
9.7
9.2
8.8
8.4
24
TC
kW
PI
kW
56.6
60.2
62.9
66.3
66.3
66.3
66.3
66.3
66.3
66.3
66.3
55.2
58.8
59.6
59.6
59.6
59.6
59.6
59.6
59.6
59.6
59.6
53
53
53
53
53
53
53
53
53
53
53
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
39.8
39.8
39.8
39.8
39.8
39.8
39.8
39.8
39.8
39.8
39.8
33.1
33.1
33.1
33.1
33.1
33.1
33.1
33.1
33.1
33.1
33.1
20.7
21.4
25.7
22.5
20.5
19.4
18.3
17.4
16.6
15.8
15.1
19.2
19.9
19.9
19.3
17.6
16.6
15.7
14.9
14.2
13.6
13
20.7
19.1
17.8
16.1
14.6
13.8
13.1
12.4
11.9
11.3
10.8
17.8
16.5
15.3
13.8
12.6
11.9
11.2
10.7
10.2
9.7
9.3
14.8
13.6
12.7
11.4
10.4
9.8
9.3
8.8
8.4
8.1
7.7
14.8
13.7
12.7
11.5
10.5
9.9
9.3
8.9
8.5
8.1
7.7
Heating Performance - HEATING PERFORMANCE DATA – 280
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
19
19.6
20
20.2
20.4
20.8
21.2
21.4
21.5
21.7
21.8
17.7
18.2
18.6
18.8
19
18.6
18.2
18.3
18.5
18.6
18.7
16.1
16.6
17
17.1
17.3
19.2
18.2
17.3
16.5
15.8
15.1
15.5
15.9
16.3
19.1
17.4
16.5
15.6
14.8
14.1
13.5
12.9
20.4
18.9
17.5
15.8
14.4
13.6
12.9
12.3
11.7
11.2
10.7
20.5
18.9
17.6
15.9
14.5
13.7
13
12.3
11.7
11.2
10.7
62.7
66.1
69.5
72.9
76.3
79.7
83.1
84.4
85.7
87
88.3
61.1
64.4
67.7
71.1
74.4
74.6
74.8
75.9
77.1
78.3
79.5
59.6
62.8
66
69.3
70.8
70.8
70.8
70.8
70.8
70.8
70.8
58.1
61.2
62
62
62
62
62
62
62
62
62
53.1
53.1
53.1
53.1
53.1
53.1
53.1
53.1
53.1
53.1
53.1
44.3
44.3
44.3
44.3
44.3
44.3
44.3
44.3
44.3
44.3
44.3
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
63.4
66.9
70.3
73.8
77.2
80.7
84.1
86.7
89.4
91.9
94.5
61.9
65.2
68.6
71.9
75.3
75.6
75.7
78
80.4
82.7
85
60.2
63.6
66.8
70.1
73.4
76.1
76.1
76.1
76.1
76.1
76.1
58.7
61.9
65.1
66.2
66.2
66.2
66.2
66.2
66.2
66.2
66.2
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
47.3
47.3
47.3
47.3
47.3
47.3
47.3
47.3
47.3
47.3
47.3
19.6
20.1
20.6
20.8
20.9
21.4
21.8
21.6
21.5
21.3
21.2
18.2
18.6
19.1
19.3
19.5
19.1
18.7
18.5
18.4
18.3
18.2
16.6
17
17.4
17.6
19
17.9
17
16.1
15.4
14.7
14
15.9
16.3
19.8
17.9
16.3
15.4
14.6
13.9
13.2
12.6
12
19.1
17.7
16.4
14.8
13.5
12.8
12.1
11.5
10.9
10.4
10
19.2
17.7
16.4
14.9
13.6
12.8
12.1
11.5
11
10.5
10
60.9
64.2
67.5
70.8
75.3
78.7
82
82
82
82
82
59.3
62.6
65.8
69
73.4
73.8
73.8
73.8
73.8
73.8
73.8
57.8
60.9
64.1
65.6
65.6
65.6
65.6
65.6
65.6
65.6
65.6
56.3
57.4
57.4
57.4
57.4
57.4
57.4
57.4
57.4
57.4
57.4
49.2
49.2
49.2
49.2
49.2
49.2
49.2
49.2
49.2
49.2
49.2
41
41
41
41
41
41
41
41
41
41
41
19.8
20.3
20.8
21
21.5
22
22.3
20.9
19.9
19
18.2
18.4
18.8
19.3
19.5
20
19.9
19.2
17.9
17.1
16.3
15.6
16.8
17.2
17.6
19.3
17.6
16.6
15.7
14.9
14.2
13.6
13
16
19.7
18.3
16.6
15.1
14.3
13.5
12.8
12.2
11.7
11.2
17.7
16.3
15.2
13.7
12.5
11.8
11.2
10.6
10.1
9.7
9.2
17.8
16.4
15.2
13.8
12.5
11.8
11.2
10.7
10.1
9.7
9.3
59.8
62.9
66
70.2
73.3
75.4
75.4
75.4
75.4
75.4
75.4
58.3
61.3
64.3
67.4
67.9
67.9
67.9
67.9
67.9
67.9
67.9
56.8
59.7
60.4
60.4
60.4
60.4
60.4
60.4
60.4
60.4
60.4
52.8
52.8
52.8
52.8
52.8
52.8
52.8
52.8
52.8
52.8
52.8
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
45.3
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
37.7
20.3
20.7
21.2
21.7
21.9
21.4
20.2
19.2
18.3
17.5
16.7
18.8
19.3
19.7
19.8
19.4
18.3
17.4
16.5
15.7
15
14.3
17.2
17.6
19.6
17.7
16.2
15.2
14.4
13.7
13.1
12.5
12
19.7
18.2
16.9
15.2
13.9
13.1
12.4
11.8
11.2
10.7
10.3
16.3
15
14
12.6
11.5
10.9
10.3
9.8
9.3
8.9
8.5
16.3
15.1
14
12.7
11.5
10.9
10.3
9.8
9.3
8.9
8.5
24
TC
kW
PI
kW
59.1
62.9
65.7
69.2
69.2
69.2
69.2
69.2
69.2
69.2
69.2
57.7
61.4
62.3
62.3
62.3
62.3
62.3
62.3
62.3
62.3
62.3
55.4
55.4
55.4
55.4
55.4
55.4
55.4
55.4
55.4
55.4
55.4
48.5
48.5
48.5
48.5
48.5
48.5
48.5
48.5
48.5
48.5
48.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
34.6
34.6
34.6
34.6
34.6
34.6
34.6
34.6
34.6
34.6
34.6
20.9
21.7
26.1
22.8
20.8
19.6
18.6
17.7
16.8
16
15.3
19.4
20.1
20.1
19.5
17.8
16.8
15.9
15.1
14.4
13.7
13.1
21
19.4
18
16.3
14.8
14
13.3
12.6
12
11.5
10.9
18
16.7
15.5
14
12.8
12
11.4
10.8
10.3
9.8
9.4
15
13.8
12.8
11.6
10.6
10
9.4
9
8.5
8.2
7.8
15
13.9
12.8
11.6
10.6
10
9.5
9
8.6
8.2
7.8
69
Heating Performance - HEATING PERFORMANCE DATA – 300
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
70
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
20.7
21.2
21.7
21.9
22.2
22.6
23
23.2
23.4
23.5
23.7
19.2
19.7
20.2
20.4
20.6
20.2
19.7
19.9
20
20.2
20.3
17.5
18
18.5
18.6
18.8
20.9
19.8
18.8
17.9
17.1
16.4
16.8
17.2
17.6
20.7
18.9
17.9
16.9
16.1
15.3
14.6
14
22.2
20.5
19
17.2
15.6
14.8
14
13.3
12.7
12.1
11.6
22.3
20.5
19.1
17.2
15.7
14.8
14.1
13.4
12.7
12.1
11.6
68.8
72.5
76.2
80
83.7
87.5
91.2
92.6
94
95.5
96.9
67.1
70.7
74.3
78
81.6
81.9
82.1
83.3
84.6
85.9
87.2
65.4
68.9
72.5
76
77.8
77.8
77.8
77.8
77.8
77.8
77.8
63.7
67.2
68
68
68
68
68
68
68
68
68
58.3
58.3
58.3
58.3
58.3
58.3
58.3
58.3
58.3
58.3
58.3
48.6
48.6
48.6
48.6
48.6
48.6
48.6
48.6
48.6
48.6
48.6
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
69.6
73.4
77.2
81
84.8
88.6
92.3
95.2
98.1
100.9
103.7
67.9
71.6
75.3
78.9
82.6
83
83.1
85.7
88.2
90.8
93.3
66.1
69.8
73.4
76.9
80.5
83.5
83.5
83.5
83.5
83.5
83.5
64.4
68
71.5
72.7
72.7
72.7
72.7
72.7
72.7
72.7
72.7
62.3
62.3
62.3
62.3
62.3
62.3
62.3
62.3
62.3
62.3
62.3
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
21.3
21.8
22.3
22.5
22.7
23.2
23.6
23.5
23.3
23.2
23
19.7
20.2
20.7
20.9
21.1
20.7
20.3
20.1
20
19.8
19.7
18
18.5
18.9
19.1
20.6
19.4
18.4
17.5
16.7
15.9
15.2
17.3
17.7
21.5
19.4
17.7
16.7
15.8
15
14.3
13.7
13.1
20.7
19.2
17.8
16.1
14.7
13.8
13.1
12.5
11.8
11.3
10.8
20.8
19.2
17.8
16.1
14.7
13.9
13.2
12.5
11.9
11.4
10.9
66.8
70.4
74.1
77.7
82.7
86.3
90
90
90
90
90
65.1
68.7
72.2
75.7
80.6
81
81
81
81
81
81
63.5
66.9
70.4
72
72
72
72
72
72
72
72
61.8
63
63
63
63
63
63
63
63
63
63
54
54
54
54
54
54
54
54
54
54
54
45
45
45
45
45
45
45
45
45
45
45
21.4
22
22.6
22.8
23.4
23.8
24.2
22.7
21.6
20.6
19.7
19.9
20.4
21
21.2
21.7
21.6
20.8
19.4
18.5
17.7
16.9
18.2
18.7
19.1
20.9
19.1
18
17.1
16.2
15.4
14.7
14.1
17.4
21.4
19.9
18
16.4
15.5
14.7
13.9
13.3
12.7
12.1
19.2
17.7
16.5
14.9
13.6
12.8
12.1
11.5
11
10.5
10
19.3
17.8
16.5
14.9
13.6
12.8
12.2
11.6
11
10.5
10.1
65.6
69
72.4
77
80.5
82.8
82.8
82.8
82.8
82.8
82.8
64
67.3
70.6
74
74.5
74.5
74.5
74.5
74.5
74.5
74.5
62.4
65.6
66.2
66.2
66.2
66.2
66.2
66.2
66.2
66.2
66.2
58
58
58
58
58
58
58
58
58
58
58
49.7
49.7
49.7
49.7
49.7
49.7
49.7
49.7
49.7
49.7
49.7
41.4
41.4
41.4
41.4
41.4
41.4
41.4
41.4
41.4
41.4
41.4
22
22.5
23
23.6
23.7
23.2
22
20.9
19.9
19
18.2
20.4
20.9
21.3
21.5
21
19.9
18.8
17.9
17
16.3
15.6
18.6
19.1
21.3
19.2
17.5
16.6
15.7
14.9
14.2
13.6
13
21.3
19.7
18.3
16.5
15.1
14.2
13.5
12.8
12.2
11.7
11.1
17.7
16.3
15.2
13.7
12.5
11.8
11.2
10.6
10.1
9.7
9.2
17.7
16.4
15.2
13.7
12.5
11.8
11.2
10.7
10.1
9.7
9.3
24
TC
kW
PI
kW
64.9
69.1
72.2
76
76
76
76
76
76
76
76
63.3
67.4
68.4
68.4
68.4
68.4
68.4
68.4
68.4
68.4
68.4
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
53.2
53.2
53.2
53.2
53.2
53.2
53.2
53.2
53.2
53.2
53.2
45.6
45.6
45.6
45.6
45.6
45.6
45.6
45.6
45.6
45.6
45.6
38
38
38
38
38
38
38
38
38
38
38
22.7
23.5
28.3
24.7
22.5
21.3
20.2
19.2
18.2
17.4
16.6
21.1
21.9
21.8
21.2
19.3
18.2
17.3
16.4
15.6
14.9
14.3
22.8
21
19.5
17.6
16.1
15.2
14.4
13.7
13
12.4
11.9
19.6
18.1
16.8
15.2
13.8
13.1
12.4
11.8
11.2
10.7
10.2
16.2
15
13.9
12.6
11.5
10.8
10.2
9.7
9.3
8.9
8.5
16.3
15
13.9
12.6
11.5
10.9
10.3
9.8
9.3
8.9
8.5
Heating Performance - HEATING PERFORMANCE DATA – 320
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
23
23.6
24.2
24.4
24.7
25.2
25.6
25.8
26
26.2
26.4
21.4
21.9
22.5
22.7
22.9
22.4
22
22.1
22.3
22.4
22.6
19.5
20
20.5
20.7
20.9
23.2
22
20.9
19.9
19
18.2
18.7
19.2
19.6
23.1
21
19.9
18.8
17.9
17
16.3
15.6
24.7
22.8
21.1
19.1
17.4
16.5
15.6
14.8
14.1
13.5
12.9
24.8
22.9
21.2
19.2
17.5
16.5
15.7
14.9
14.2
13.5
12.9
71.9
75.8
79.6
83.6
87.5
91.3
95.2
96.7
98.2
99.7
101.2
70.1
73.9
77.7
81.5
85.3
85.6
85.7
87.1
88.4
89.7
91.1
68.3
72
75.7
79.4
81.2
81.2
81.2
81.2
81.2
81.2
81.2
66.6
70.2
71.1
71.1
71.1
71.1
71.1
71.1
71.1
71.1
71.1
60.9
60.9
60.9
60.9
60.9
60.9
60.9
60.9
60.9
60.9
60.9
50.8
50.8
50.8
50.8
50.8
50.8
50.8
50.8
50.8
50.8
50.8
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
72.7
76.7
80.6
84.6
88.5
92.5
96.5
99.4
102.4
105.3
108.3
70.9
74.8
78.6
82.5
86.3
86.6
86.8
89.5
92.2
94.8
97.5
69.1
72.9
76.6
80.3
84.1
87.2
87.2
87.2
87.2
87.2
87.2
67.3
71
74.7
75.9
75.9
75.9
75.9
75.9
75.9
75.9
75.9
65.1
65.1
65.1
65.1
65.1
65.1
65.1
65.1
65.1
65.1
65.1
54.3
54.3
54.3
54.3
54.3
54.3
54.3
54.3
54.3
54.3
54.3
23.7
24.3
24.8
25.1
25.3
25.8
26.3
26.1
25.9
25.8
25.6
21.9
22.5
23.1
23.3
23.5
23
22.5
22.4
22.2
22.1
21.9
20
20.6
21.1
21.3
22.9
21.6
20.5
19.5
18.6
17.7
17
19.2
19.7
23.9
21.6
19.7
18.6
17.6
16.7
15.9
15.2
14.6
23.1
21.3
19.8
17.9
16.3
15.4
14.6
13.9
13.2
12.6
12
23.2
21.4
19.9
18
16.4
15.4
14.7
13.9
13.3
12.7
12.1
69.8
73.6
77.3
81.1
86.3
90.2
94
94
94
94
94
68
71.7
75.4
79.1
84.2
84.6
84.6
84.6
84.6
84.6
84.6
66.3
69.9
73.5
75.2
75.2
75.2
75.2
75.2
75.2
75.2
75.2
64.6
65.8
65.8
65.8
65.8
65.8
65.8
65.8
65.8
65.8
65.8
56.4
56.4
56.4
56.4
56.4
56.4
56.4
56.4
56.4
56.4
56.4
47
47
47
47
47
47
47
47
47
47
47
23.9
24.5
25.1
25.3
26
26.5
26.9
25.2
24
22.9
22
22.2
22.8
23.3
23.5
24.2
24
23.2
21.6
20.6
19.7
18.8
20.2
20.8
21.3
23.3
21.2
20
19
18
17.2
16.4
15.7
19.4
23.8
22.1
20
18.2
17.2
16.3
15.5
14.8
14.1
13.5
21.4
19.7
18.4
16.6
15.1
14.3
13.5
12.8
12.2
11.7
11.1
21.5
19.8
18.4
16.6
15.2
14.3
13.5
12.9
12.3
11.7
11.2
68.6
72.1
75.6
80.5
84
86.5
86.5
86.5
86.5
86.5
86.5
66.8
70.3
73.7
77.2
77.8
77.8
77.8
77.8
77.8
77.8
77.8
65.1
68.5
69.2
69.2
69.2
69.2
69.2
69.2
69.2
69.2
69.2
60.5
60.5
60.5
60.5
60.5
60.5
60.5
60.5
60.5
60.5
60.5
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
51.9
43.2
43.2
43.2
43.2
43.2
43.2
43.2
43.2
43.2
43.2
43.2
24.5
25.1
25.6
26.2
26.4
25.8
24.4
23.2
22.1
21.1
20.2
22.7
23.3
23.8
24
23.4
22.1
21
19.9
19
18.1
17.3
20.8
21.3
23.7
21.4
19.5
18.4
17.5
16.6
15.8
15.1
14.4
23.8
21.9
20.4
18.4
16.8
15.8
15
14.3
13.6
13
12.4
19.7
18.2
16.9
15.2
13.9
13.1
12.4
11.8
11.3
10.8
10.3
19.7
18.2
16.9
15.3
13.9
13.2
12.5
11.9
11.3
10.8
10.3
24
TC
kW
PI
kW
67.8
72.1
75.4
79.4
79.4
79.4
79.4
79.4
79.4
79.4
79.4
66.1
70.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
55.6
55.6
55.6
55.6
55.6
55.6
55.6
55.6
55.6
55.6
55.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
47.6
39.7
39.7
39.7
39.7
39.7
39.7
39.7
39.7
39.7
39.7
39.7
25.3
26.2
31.5
27.5
25.1
23.7
22.4
21.3
20.3
19.4
18.5
23.5
24.3
24.3
23.6
21.5
20.3
19.2
18.3
17.4
16.6
15.9
25.4
23.4
21.8
19.6
17.9
16.9
16
15.2
14.5
13.8
13.2
21.8
20.1
18.7
16.9
15.4
14.6
13.8
13.1
12.5
11.9
11.4
18.1
16.7
15.5
14
12.8
12
11.4
10.8
10.3
9.9
9.4
18.1
16.7
15.5
14
12.8
12.1
11.4
10.9
10.4
9.9
9.5
71
Heating Performance - HEATING PERFORMANCE DATA – 340
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
72
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
23.8
24.4
25
25.2
25.5
26
26.5
26.7
26.9
27.1
27.3
22.1
22.7
23.2
23.4
23.7
23.2
22.7
22.9
23
23.2
23.4
20.1
20.7
21.2
21.4
21.6
24
22.7
21.6
20.6
19.7
18.8
19.3
19.8
20.3
23.8
21.7
20.5
19.4
18.5
17.6
16.8
16.1
25.5
23.5
21.8
19.7
18
17
16.1
15.3
14.6
13.9
13.3
25.6
23.6
21.9
19.8
18.1
17.1
16.2
15.4
14.6
14
13.4
81.1
85.4
89.8
94.2
98.6
103
107.4
109.1
110.7
112.4
114.1
79
83.3
87.6
91.9
96.2
96.5
96.6
98.2
99.7
101.2
102.7
77
81.2
85.3
89.5
91.6
91.6
91.6
91.6
91.6
91.6
91.6
75.1
79.1
80.1
80.1
80.1
80.1
80.1
80.1
80.1
80.1
80.1
68.7
68.7
68.7
68.7
68.7
68.7
68.7
68.7
68.7
68.7
68.7
57.2
57.2
57.2
57.2
57.2
57.2
57.2
57.2
57.2
57.2
57.2
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
82
86.5
90.9
95.4
99.8
104.3
108.8
112.1
115.5
118.8
122.2
80
84.3
88.7
93
97.3
97.7
97.9
100.9
103.9
106.9
109.9
77.9
82.2
86.4
90.6
94.8
98.4
98.4
98.4
98.4
98.4
98.4
75.9
80.1
84.2
85.6
85.6
85.6
85.6
85.6
85.6
85.6
85.6
73.4
73.4
73.4
73.4
73.4
73.4
73.4
73.4
73.4
73.4
73.4
61.2
61.2
61.2
61.2
61.2
61.2
61.2
61.2
61.2
61.2
61.2
24.4
25.1
25.7
25.9
26.1
26.7
27.2
27
26.8
26.6
26.4
22.7
23.3
23.8
24.1
24.3
23.8
23.3
23.1
23
22.8
22.7
20.7
21.3
21.8
22
23.7
22.4
21.2
20.1
19.2
18.3
17.5
19.8
20.4
24.7
22.3
20.4
19.2
18.2
17.3
16.5
15.7
15
23.8
22
20.4
18.5
16.8
15.9
15.1
14.3
13.6
13
12.4
24
22.1
20.5
18.6
16.9
16
15.1
14.4
13.7
13.1
12.5
78.7
82.9
87.2
91.5
97.4
101.7
106
106
106
106
106
76.7
80.9
85
89.2
94.9
95.4
95.4
95.4
95.4
95.4
95.4
74.7
78.8
82.9
84.8
84.8
84.8
84.8
84.8
84.8
84.8
84.8
72.8
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
53
53
53
53
53
53
53
53
53
53
53
24.7
25.3
26
26.2
26.9
27.4
27.8
26.1
24.8
23.7
22.7
22.9
23.5
24.1
24.3
25
24.8
23.9
22.4
21.3
20.3
19.4
20.9
21.5
22
24
21.9
20.7
19.6
18.6
17.7
16.9
16.2
20
24.6
22.9
20.7
18.8
17.8
16.8
16
15.3
14.6
13.9
22.1
20.4
19
17.1
15.6
14.7
14
13.3
12.6
12.1
11.5
22.2
20.5
19
17.2
15.7
14.8
14
13.3
12.7
12.1
11.6
77.3
81.3
85.3
90.7
94.8
97.5
97.5
97.5
97.5
97.5
97.5
75.4
79.3
83.1
87.1
87.8
87.8
87.8
87.8
87.8
87.8
87.8
73.4
77.2
78
78
78
78
78
78
78
78
78
68.3
68.3
68.3
68.3
68.3
68.3
68.3
68.3
68.3
68.3
68.3
58.5
58.5
58.5
58.5
58.5
58.5
58.5
58.5
58.5
58.5
58.5
48.8
48.8
48.8
48.8
48.8
48.8
48.8
48.8
48.8
48.8
48.8
25.3
25.9
26.4
27.1
27.3
26.7
25.3
24
22.8
21.8
20.9
23.5
24
24.5
24.8
24.2
22.8
21.7
20.5
19.6
18.7
17.9
21.4
22
24.5
22.1
20.2
19
18
17.1
16.3
15.6
14.9
24.5
22.7
21
19
17.3
16.4
15.5
14.7
14
13.4
12.8
20.3
18.8
17.4
15.7
14.4
13.6
12.8
12.2
11.6
11.1
10.6
20.4
18.8
17.5
15.8
14.4
13.6
12.9
12.3
11.7
11.1
10.7
24
TC
kW
PI
kW
76.4
81.4
85
89.5
89.5
89.5
89.5
89.5
89.5
89.5
89.5
74.5
79.3
80.5
80.5
80.5
80.5
80.5
80.5
80.5
80.5
80.5
71.6
71.6
71.6
71.6
71.6
71.6
71.6
71.6
71.6
71.6
71.6
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
53.7
53.7
53.7
53.7
53.7
53.7
53.7
53.7
53.7
53.7
53.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
44.7
26.1
27.1
32.5
28.4
25.9
24.5
23.2
22
21
20
19.1
24.3
25.1
25.1
24.4
22.2
21
19.9
18.9
18
17.1
16.4
26.2
24.2
22.5
20.3
18.5
17.5
16.6
15.7
15
14.3
13.7
22.5
20.8
19.3
17.4
15.9
15
14.2
13.5
12.9
12.3
11.8
18.7
17.2
16
14.4
13.2
12.4
11.8
11.2
10.7
10.2
9.7
18.7
17.3
16
14.5
13.2
12.5
11.8
11.2
10.7
10.2
9.8
Heating Performance - HEATING PERFORMANCE DATA – 360
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
26.1
26.8
27.5
27.7
28
28.5
29.1
29.3
29.5
29.7
29.9
24.2
24.9
25.5
25.7
26
25.5
24.9
25.1
25.3
25.5
25.7
22.1
22.7
23.3
23.5
23.7
26.4
25
23.7
22.6
21.6
20.7
21.2
21.8
22.3
26.2
23.9
22.6
21.4
20.3
19.3
18.5
17.6
28
25.9
24
21.7
19.8
18.7
17.7
16.8
16
15.3
14.6
28.1
25.9
24.1
21.8
19.8
18.7
17.8
16.9
16.1
15.3
14.7
84.1
88.7
93.2
97.8
102.3
106.9
111.4
113.2
114.9
116.7
118.4
82
86.4
90.9
95.3
99.8
100.1
100.3
101.9
103.4
105
106.6
79.9
84.2
88.6
92.9
95
95
95
95
95
95
95
77.9
82.1
83.2
83.2
83.2
83.2
83.2
83.2
83.2
83.2
83.2
71.3
71.3
71.3
71.3
71.3
71.3
71.3
71.3
71.3
71.3
71.3
59.4
59.4
59.4
59.4
59.4
59.4
59.4
59.4
59.4
59.4
59.4
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
85.1
89.7
94.4
99
103.6
108.2
112.9
116.4
119.9
123.3
126.8
83
87.5
92
96.5
101
101.4
101.6
104.7
107.8
110.9
114.1
80.8
85.3
89.7
94
98.4
102.1
102.1
102.1
102.1
102.1
102.1
78.8
83.1
87.4
88.9
88.9
88.9
88.9
88.9
88.9
88.9
88.9
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
63.5
26.8
27.5
28.2
28.5
28.7
29.3
29.8
29.6
29.4
29.2
29
24.9
25.5
26.2
26.4
26.7
26.1
25.6
25.4
25.2
25.1
24.9
22.7
23.3
23.9
24.2
26
24.6
23.3
22.1
21.1
20.1
19.2
21.8
22.4
27.1
24.5
22.4
21.1
20
19
18.1
17.3
16.5
26.2
24.2
22.4
20.3
18.5
17.5
16.6
15.7
15
14.3
13.7
26.3
24.3
22.5
20.4
18.6
17.5
16.6
15.8
15
14.4
13.7
81.6
86.1
90.5
94.9
101
105.5
110
110
110
110
110
79.6
83.9
88.2
92.6
98.5
99
99
99
99
99
99
77.6
81.8
86
88
88
88
88
88
88
88
88
75.6
77
77
77
77
77
77
77
77
77
77
66
66
66
66
66
66
66
66
66
66
66
55
55
55
55
55
55
55
55
55
55
55
27.1
27.8
28.5
28.8
29.5
30.1
30.5
28.6
27.3
26
24.9
25.2
25.8
26.5
26.7
27.4
27.3
26.3
24.6
23.4
22.3
21.4
23
23.6
24.2
26.4
24.1
22.7
21.6
20.5
19.5
18.6
17.8
22
27
25.1
22.7
20.7
19.6
18.5
17.6
16.8
16
15.3
24.3
22.4
20.8
18.8
17.1
16.2
15.3
14.6
13.9
13.3
12.6
24.4
22.5
20.9
18.9
17.2
16.2
15.4
14.6
13.9
13.3
12.7
80.2
84.3
88.5
94.2
98.3
101.2
101.2
101.2
101.2
101.2
101.2
78.2
82.3
86.2
90.4
91.1
91.1
91.1
91.1
91.1
91.1
91.1
76.2
80.1
81
81
81
81
81
81
81
81
81
70.8
70.8
70.8
70.8
70.8
70.8
70.8
70.8
70.8
70.8
70.8
60.7
60.7
60.7
60.7
60.7
60.7
60.7
60.7
60.7
60.7
60.7
50.6
50.6
50.6
50.6
50.6
50.6
50.6
50.6
50.6
50.6
50.6
27.8
28.4
29
29.8
30
29.3
27.7
26.4
25.1
24
22.9
25.8
26.4
27
27.2
26.6
25.1
23.8
22.6
21.5
20.5
19.6
23.5
24.1
26.9
24.3
22.2
20.9
19.8
18.8
17.9
17.1
16.4
27
24.9
23.1
20.9
19
18
17
16.2
15.4
14.7
14.1
22.3
20.6
19.2
17.3
15.8
14.9
14.1
13.4
12.8
12.2
11.7
22.4
20.7
19.2
17.4
15.8
14.9
14.2
13.5
12.8
12.2
11.7
24
TC
kW
PI
kW
79.3
84.4
88.2
92.9
92.9
92.9
92.9
92.9
92.9
92.9
92.9
77.4
82.3
83.6
83.6
83.6
83.6
83.6
83.6
83.6
83.6
83.6
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
65
65
65
65
65
65
65
65
65
65
65
55.7
55.7
55.7
55.7
55.7
55.7
55.7
55.7
55.7
55.7
55.7
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
46.4
28.7
29.7
35.7
31.2
28.5
26.9
25.5
24.2
23
22
21
26.6
27.6
27.6
26.8
24.4
23
21.8
20.7
19.7
18.8
18
28.8
26.6
24.7
22.3
20.3
19.2
18.2
17.3
16.5
15.7
15
24.7
22.9
21.2
19.2
17.5
16.5
15.6
14.8
14.2
13.5
12.9
20.5
18.9
17.6
15.9
14.5
13.7
12.9
12.3
11.7
11.2
10.7
20.5
19
17.6
15.9
14.5
13.7
13
12.3
11.8
11.2
10.7
73
Heating Performance - HEATING PERFORMANCE DATA – 380
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
74
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
26.3
27
27.7
27.9
28.2
28.8
29.3
29.6
29.8
30
30.2
24.5
25.1
25.7
26
26.2
25.7
25.2
25.4
25.5
25.7
25.9
22.3
22.9
23.5
23.7
23.9
26.6
25.2
24
22.8
21.8
20.8
21.4
22
22.5
26.4
24.1
22.8
21.5
20.5
19.5
18.6
17.8
28.3
26.1
24.2
21.9
19.9
18.8
17.9
16.9
16.2
15.4
14.8
28.4
26.2
24.3
22
20
18.9
17.9
17
16.2
15.5
14.8
86.8
91.5
96.2
100.9
105.6
110.3
115
116.8
118.6
120.4
122.2
84.6
89.2
93.8
98.4
103
103.3
103.5
105.1
106.7
108.4
110
82.4
86.9
91.4
95.9
98.1
98.1
98.1
98.1
98.1
98.1
98.1
80.4
84.7
85.8
85.8
85.8
85.8
85.8
85.8
85.8
85.8
85.8
73.5
73.5
73.5
73.5
73.5
73.5
73.5
73.5
73.5
73.5
73.5
61.3
61.3
61.3
61.3
61.3
61.3
61.3
61.3
61.3
61.3
61.3
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
87.8
92.6
97.4
102.1
106.9
111.7
116.5
120.1
123.7
127.2
130.8
85.6
90.3
94.9
99.6
104.2
104.6
104.8
108
111.3
114.5
117.7
83.4
88
92.5
97
101.5
105.3
105.3
105.3
105.3
105.3
105.3
81.3
85.7
90.2
91.7
91.7
91.7
91.7
91.7
91.7
91.7
91.7
78.6
78.6
78.6
78.6
78.6
78.6
78.6
78.6
78.6
78.6
78.6
65.5
65.5
65.5
65.5
65.5
65.5
65.5
65.5
65.5
65.5
65.5
27.1
27.8
28.4
28.7
29
29.5
30.1
29.9
29.7
29.5
29.3
25.1
25.8
26.4
26.7
26.9
26.4
25.8
25.6
25.4
25.3
25.1
22.9
23.6
24.1
24.4
26.2
24.8
23.5
22.3
21.3
20.3
19.4
22
22.6
27.4
24.7
22.6
21.3
20.2
19.2
18.3
17.4
16.7
26.4
24.4
22.7
20.5
18.7
17.6
16.7
15.9
15.1
14.4
13.8
26.6
24.5
22.7
20.6
18.8
17.7
16.8
15.9
15.2
14.5
13.9
84.2
88.8
93.4
97.9
104.3
108.9
113.5
113.5
113.5
113.5
113.5
82.1
86.6
91
95.5
101.6
102.2
102.2
102.2
102.2
102.2
102.2
80
84.4
88.7
90.8
90.8
90.8
90.8
90.8
90.8
90.8
90.8
78
79.5
79.5
79.5
79.5
79.5
79.5
79.5
79.5
79.5
79.5
68.1
68.1
68.1
68.1
68.1
68.1
68.1
68.1
68.1
68.1
68.1
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
56.8
27.3
28.1
28.8
29
29.8
30.4
30.8
28.9
27.5
26.3
25.2
25.4
26.1
26.7
27
27.7
27.5
26.5
24.8
23.6
22.5
21.5
23.2
23.8
24.4
26.6
24.3
22.9
21.8
20.6
19.7
18.8
18
22.2
27.3
25.4
22.9
20.9
19.7
18.7
17.8
16.9
16.1
15.4
24.5
22.6
21
19
17.3
16.3
15.5
14.7
14
13.4
12.8
24.6
22.7
21.1
19
17.4
16.4
15.5
14.7
14
13.4
12.8
82.8
87
91.3
97.2
101.5
104.4
104.4
104.4
104.4
104.4
104.4
80.7
84.9
89
93.3
94
94
94
94
94
94
94
78.6
82.7
83.5
83.5
83.5
83.5
83.5
83.5
83.5
83.5
83.5
73.1
73.1
73.1
73.1
73.1
73.1
73.1
73.1
73.1
73.1
73.1
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
62.7
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
52.2
28
28.7
29.3
30
30.2
29.5
28
26.6
25.3
24.2
23.1
26
26.6
27.2
27.5
26.8
25.3
24
22.8
21.7
20.7
19.8
23.8
24.3
27.1
24.5
22.4
21.1
20
19
18.1
17.3
16.5
27.2
25.1
23.3
21.1
19.2
18.1
17.2
16.3
15.6
14.9
14.2
22.5
20.8
19.3
17.4
15.9
15
14.2
13.5
12.9
12.3
11.8
22.6
20.9
19.4
17.5
16
15.1
14.3
13.6
12.9
12.4
11.8
24
TC
kW
PI
kW
81.8
87.1
91
95.8
95.8
95.8
95.8
95.8
95.8
95.8
95.8
79.8
85
86.2
86.2
86.2
86.2
86.2
86.2
86.2
86.2
86.2
76.7
76.7
76.7
76.7
76.7
76.7
76.7
76.7
76.7
76.7
76.7
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
57.5
57.5
57.5
57.5
57.5
57.5
57.5
57.5
57.5
57.5
57.5
47.9
47.9
47.9
47.9
47.9
47.9
47.9
47.9
47.9
47.9
47.9
29
30
36.1
31.5
28.7
27.1
25.7
24.4
23.2
22.2
21.2
26.9
27.9
27.8
27
24.6
23.2
22
20.9
19.9
19
18.2
29.1
26.8
24.9
22.5
20.5
19.4
18.3
17.4
16.6
15.8
15.1
25
23.1
21.4
19.3
17.6
16.7
15.8
15
14.3
13.6
13.1
20.7
19.1
17.7
16
14.6
13.8
13.1
12.4
11.8
11.3
10.8
20.7
19.2
17.8
16
14.7
13.8
13.1
12.4
11.9
11.3
10.8
Heating Performance - HEATING PERFORMANCE DATA – 400
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
28
28.7
29.4
29.7
30
30.6
31.2
31.4
31.6
31.9
32.1
26
26.7
27.3
27.6
27.8
27.3
26.7
26.9
27.1
27.3
27.5
23.7
24.4
25
25.2
25.4
28.2
26.8
25.4
24.2
23.1
22.1
22.7
23.3
23.9
28.1
25.6
24.2
22.9
21.7
20.7
19.8
18.9
30
27.7
25.7
23.2
21.2
20
19
18
17.2
16.4
15.7
30.1
27.8
25.8
23.3
21.3
20.1
19
18.1
17.2
16.4
15.7
92.9
97.9
102.9
108
113
118.1
123.1
125
126.9
128.9
130.8
90.6
95.5
100.4
105.3
110.2
110.6
110.8
112.5
114.3
116
117.7
88.3
93
97.8
102.6
105
105
105
105
105
105
105
86
90.7
91.9
91.9
91.9
91.9
91.9
91.9
91.9
91.9
91.9
78.7
78.7
78.7
78.7
78.7
78.7
78.7
78.7
78.7
78.7
78.7
65.6
65.6
65.6
65.6
65.6
65.6
65.6
65.6
65.6
65.6
65.6
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
94
99.1
104.2
109.3
114.4
119.5
124.7
128.5
132.4
136.2
140
91.6
96.6
101.6
106.6
111.6
112
112.2
115.6
119.1
122.5
126
89.3
94.2
99
103.8
108.7
112.7
112.7
112.7
112.7
112.7
112.7
87
91.8
96.5
98.2
98.2
98.2
98.2
98.2
98.2
98.2
98.2
84.1
84.1
84.1
84.1
84.1
84.1
84.1
84.1
84.1
84.1
84.1
70.1
70.1
70.1
70.1
70.1
70.1
70.1
70.1
70.1
70.1
70.1
28.8
29.5
30.2
30.5
30.8
31.4
32
31.8
31.5
31.3
31.1
26.7
27.4
28.1
28.3
28.6
28
27.4
27.2
27
26.8
26.7
24.4
25
25.6
25.9
27.8
26.3
24.9
23.7
22.6
21.5
20.6
23.4
24
29.1
26.3
24
22.6
21.4
20.3
19.4
18.5
17.7
28.1
25.9
24.1
21.7
19.8
18.7
17.7
16.9
16
15.3
14.6
28.2
26
24.1
21.8
19.9
18.8
17.8
16.9
16.1
15.4
14.7
90.2
95.1
100
104.8
111.6
116.6
121.5
121.5
121.5
121.5
121.5
87.9
92.7
97.5
102.2
108.8
109.4
109.4
109.4
109.4
109.4
109.4
85.7
90.3
95
97.2
97.2
97.2
97.2
97.2
97.2
97.2
97.2
83.5
85.1
85.1
85.1
85.1
85.1
85.1
85.1
85.1
85.1
85.1
72.9
72.9
72.9
72.9
72.9
72.9
72.9
72.9
72.9
72.9
72.9
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
60.8
29
29.8
30.5
30.8
31.6
32.2
32.7
30.7
29.2
27.9
26.7
27
27.7
28.4
28.6
29.4
29.2
28.1
26.3
25.1
23.9
22.9
24.6
25.3
25.9
28.3
25.8
24.4
23.1
21.9
20.9
19.9
19.1
23.6
29
26.9
24.3
22.2
21
19.8
18.9
18
17.1
16.4
26
24
22.3
20.1
18.3
17.3
16.4
15.6
14.9
14.2
13.6
26.1
24.1
22.4
20.2
18.4
17.4
16.5
15.6
14.9
14.2
13.6
88.6
93.2
97.7
104
108.6
111.8
111.8
111.8
111.8
111.8
111.8
86.4
90.9
95.2
99.8
100.6
100.6
100.6
100.6
100.6
100.6
100.6
84.2
88.5
89.4
89.4
89.4
89.4
89.4
89.4
89.4
89.4
89.4
78.2
78.2
78.2
78.2
78.2
78.2
78.2
78.2
78.2
78.2
78.2
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
67.1
55.9
55.9
55.9
55.9
55.9
55.9
55.9
55.9
55.9
55.9
55.9
29.8
30.5
31.1
31.9
32.1
31.4
29.7
28.2
26.9
25.7
24.6
27.6
28.3
28.9
29.2
28.5
26.9
25.5
24.2
23.1
22
21
25.2
25.8
28.8
26
23.7
22.4
21.2
20.2
19.2
18.3
17.6
28.9
26.7
24.7
22.4
20.4
19.3
18.3
17.3
16.5
15.8
15.1
23.9
22.1
20.5
18.5
16.9
15.9
15.1
14.4
13.7
13.1
12.5
24
22.2
20.6
18.6
17
16
15.2
14.4
13.7
13.1
12.5
24
TC
kW
PI
kW
87.6
93.3
97.4
102.6
102.6
102.6
102.6
102.6
102.6
102.6
102.6
85.4
91
92.3
92.3
92.3
92.3
92.3
92.3
92.3
92.3
92.3
82.1
82.1
82.1
82.1
82.1
82.1
82.1
82.1
82.1
82.1
82.1
71.8
71.8
71.8
71.8
71.8
71.8
71.8
71.8
71.8
71.8
71.8
61.5
61.5
61.5
61.5
61.5
61.5
61.5
61.5
61.5
61.5
61.5
51.3
51.3
51.3
51.3
51.3
51.3
51.3
51.3
51.3
51.3
51.3
30.8
31.9
38.3
33.4
30.5
28.8
27.3
25.9
24.7
23.6
22.5
28.5
29.6
29.5
28.7
26.1
24.7
23.4
22.2
21.1
20.2
19.3
30.8
28.5
26.4
23.9
21.8
20.6
19.5
18.5
17.6
16.8
16.1
26.5
24.5
22.7
20.5
18.7
17.7
16.7
15.9
15.2
14.5
13.9
22
20.3
18.8
17
15.5
14.6
13.9
13.2
12.5
12
11.5
22
20.3
18.9
17
15.6
14.7
13.9
13.2
12.6
12
11.5
75
Heating Performance - HEATING PERFORMANCE DATA – 420
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
76
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
30.3
31.1
31.9
32.2
32.5
33.1
33.8
34
34.3
34.5
34.7
28.1
28.9
29.6
29.9
30.2
29.6
28.9
29.2
29.4
29.6
29.8
25.7
26.4
27.1
27.3
27.5
30.6
29
27.6
26.3
25.1
24
24.6
25.3
25.9
30.4
27.7
26.2
24.8
23.6
22.4
21.4
20.5
32.5
30
27.9
25.2
22.9
21.7
20.5
19.5
18.6
17.8
17
32.6
30.1
28
25.3
23
21.8
20.6
19.6
18.6
17.8
17
96
101.2
106.3
111.6
116.8
122
127.1
129.1
131.1
133.1
135.1
93.5
98.6
103.7
108.8
113.8
114.2
114.4
116.2
118
119.8
121.6
91.2
96.1
101
106
108.4
108.4
108.4
108.4
108.4
108.4
108.4
88.9
93.7
94.9
94.9
94.9
94.9
94.9
94.9
94.9
94.9
94.9
81.3
81.3
81.3
81.3
81.3
81.3
81.3
81.3
81.3
81.3
81.3
67.8
67.8
67.8
67.8
67.8
67.8
67.8
67.8
67.8
67.8
67.8
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
97.1
102.4
107.7
112.9
118.2
123.5
128.8
132.8
136.8
140.6
144.6
94.7
99.8
105
110.1
115.2
115.7
115.9
119.4
123
126.6
130.2
92.2
97.3
102.3
107.3
112.3
116.4
116.4
116.4
116.4
116.4
116.4
89.9
94.8
99.7
101.4
101.4
101.4
101.4
101.4
101.4
101.4
101.4
86.9
86.9
86.9
86.9
86.9
86.9
86.9
86.9
86.9
86.9
86.9
72.4
72.4
72.4
72.4
72.4
72.4
72.4
72.4
72.4
72.4
72.4
31.2
32
32.7
33
33.3
34
34.7
34.4
34.2
33.9
33.7
28.9
29.6
30.4
30.7
31
30.4
29.7
29.5
29.3
29.1
28.9
26.4
27.1
27.8
28
30.2
28.5
27
25.6
24.5
23.3
22.3
25.3
26
31.5
28.5
26
24.5
23.2
22
21
20.1
19.2
30.4
28.1
26.1
23.6
21.5
20.3
19.2
18.3
17.4
16.6
15.9
30.5
28.2
26.2
23.7
21.6
20.3
19.3
18.3
17.5
16.7
16
93.1
98.2
103.3
108.3
115.3
120.4
125.5
125.5
125.5
125.5
125.5
90.8
95.7
100.7
105.6
112.4
113
113
113
113
113
113
88.5
93.3
98.1
100.4
100.4
100.4
100.4
100.4
100.4
100.4
100.4
86.2
87.9
87.9
87.9
87.9
87.9
87.9
87.9
87.9
87.9
87.9
75.3
75.3
75.3
75.3
75.3
75.3
75.3
75.3
75.3
75.3
75.3
62.8
62.8
62.8
62.8
62.8
62.8
62.8
62.8
62.8
62.8
62.8
31.4
32.3
33.1
33.4
34.3
34.9
35.4
33.2
31.7
30.2
28.9
29.2
30
30.7
31
31.8
31.7
30.5
28.5
27.1
25.9
24.8
26.7
27.4
28
30.6
28
26.4
25
23.7
22.6
21.6
20.7
25.5
31.4
29.2
26.3
24
22.7
21.5
20.4
19.5
18.6
17.8
28.2
26
24.2
21.8
19.9
18.8
17.8
16.9
16.1
15.4
14.7
28.3
26.1
24.2
21.9
20
18.8
17.8
16.9
16.1
15.4
14.8
91.5
96.2
100.9
107.4
112.2
115.5
115.5
115.5
115.5
115.5
115.5
89.2
93.9
98.4
103.1
103.9
103.9
103.9
103.9
103.9
103.9
103.9
87
91.4
92.4
92.4
92.4
92.4
92.4
92.4
92.4
92.4
92.4
80.8
80.8
80.8
80.8
80.8
80.8
80.8
80.8
80.8
80.8
80.8
69.3
69.3
69.3
69.3
69.3
69.3
69.3
69.3
69.3
69.3
69.3
57.7
57.7
57.7
57.7
57.7
57.7
57.7
57.7
57.7
57.7
57.7
32.2
33
33.7
34.6
34.8
34
32.2
30.6
29.1
27.8
26.6
29.9
30.6
31.3
31.6
30.8
29.1
27.6
26.2
25
23.8
22.8
27.3
28
31.2
28.2
25.7
24.3
23
21.9
20.8
19.9
19
31.3
28.9
26.8
24.2
22.1
20.9
19.8
18.8
17.9
17.1
16.3
25.9
23.9
22.2
20.1
18.3
17.3
16.4
15.6
14.8
14.2
13.6
26
24
22.3
20.2
18.4
17.3
16.4
15.6
14.9
14.2
13.6
24
TC
kW
PI
kW
90.5
96.3
100.6
106
106
106
106
106
106
106
106
88.3
93.9
95.3
95.3
95.3
95.3
95.3
95.3
95.3
95.3
95.3
84.8
84.8
84.8
84.8
84.8
84.8
84.8
84.8
84.8
84.8
84.8
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
74.2
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
63.6
53
53
53
53
53
53
53
53
53
53
53
33.3
34.5
41.5
36.2
33
31.2
29.6
28.1
26.7
25.5
24.4
30.9
32.1
32
31.1
28.3
26.7
25.4
24.1
22.9
21.9
20.9
33.4
30.8
28.7
25.9
23.6
22.3
21.1
20.1
19.1
18.2
17.4
28.7
26.5
24.6
22.2
20.3
19.2
18.1
17.2
16.4
15.7
15
23.8
22
20.4
18.4
16.8
15.9
15
14.3
13.6
13
12.4
23.8
22
20.4
18.5
16.9
15.9
15.1
14.3
13.6
13
12.5
Heating Performance - HEATING PERFORMANCE DATA – 440
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
30.6
31.4
32.1
32.4
32.7
33.4
34
34.3
34.5
34.8
35
28.4
29.1
29.8
30.1
30.4
29.8
29.2
29.4
29.6
29.8
30
25.9
26.6
27.3
27.5
27.7
30.8
29.2
27.8
26.5
25.3
24.2
24.8
25.5
26.1
30.6
27.9
26.4
25
23.7
22.6
21.6
20.7
32.8
30.3
28.1
25.4
23.1
21.8
20.7
19.7
18.7
17.9
17.1
32.9
30.4
28.2
25.5
23.2
21.9
20.8
19.7
18.8
17.9
17.2
98.6
104
109.3
114.7
120
125.4
130.7
132.7
134.8
136.8
138.9
96.2
101.4
106.6
111.8
117
117.4
117.6
119.5
121.3
123.1
125
93.7
98.8
103.8
109
111.4
111.4
111.4
111.4
111.4
111.4
111.4
91.4
96.3
97.5
97.5
97.5
97.5
97.5
97.5
97.5
97.5
97.5
83.6
83.6
83.6
83.6
83.6
83.6
83.6
83.6
83.6
83.6
83.6
69.7
69.7
69.7
69.7
69.7
69.7
69.7
69.7
69.7
69.7
69.7
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
99.8
105.2
110.7
116.1
121.5
126.9
132.4
136.5
140.6
144.6
148.7
97.3
102.6
107.9
113.2
118.4
118.9
119.1
122.8
126.5
130.1
133.8
94.8
100
105.1
110.2
115.4
119.7
119.7
119.7
119.7
119.7
119.7
92.4
97.4
102.5
104.2
104.2
104.2
104.2
104.2
104.2
104.2
104.2
89.3
89.3
89.3
89.3
89.3
89.3
89.3
89.3
89.3
89.3
89.3
74.5
74.5
74.5
74.5
74.5
74.5
74.5
74.5
74.5
74.5
74.5
31.4
32.2
33
33.3
33.6
34.3
34.9
34.7
34.5
34.2
34
29.1
29.9
30.6
30.9
31.2
30.6
29.9
29.7
29.5
29.3
29.1
26.6
27.3
28
28.3
30.4
28.7
27.2
25.8
24.6
23.5
22.5
25.5
26.2
31.7
28.7
26.2
24.7
23.4
22.2
21.2
20.2
19.3
30.6
28.3
26.3
23.7
21.7
20.5
19.4
18.4
17.5
16.8
16
30.8
28.4
26.4
23.8
21.7
20.5
19.5
18.5
17.6
16.8
16.1
95.7
100.9
106.1
111.3
118.5
123.7
129
129
129
129
129
93.3
98.4
103.5
108.5
115.5
116.1
116.1
116.1
116.1
116.1
116.1
90.9
95.9
100.9
103.2
103.2
103.2
103.2
103.2
103.2
103.2
103.2
88.6
90.3
90.3
90.3
90.3
90.3
90.3
90.3
90.3
90.3
90.3
77.4
77.4
77.4
77.4
77.4
77.4
77.4
77.4
77.4
77.4
77.4
64.5
64.5
64.5
64.5
64.5
64.5
64.5
64.5
64.5
64.5
64.5
31.7
32.5
33.4
33.6
34.5
35.2
35.7
33.5
31.9
30.5
29.2
29.5
30.2
31
31.3
32.1
31.9
30.7
28.7
27.4
26.1
25
26.9
27.6
28.3
30.9
28.2
26.6
25.2
23.9
22.8
21.7
20.8
25.7
31.6
29.4
26.6
24.2
22.9
21.7
20.6
19.6
18.7
17.9
28.4
26.2
24.4
22
20
18.9
17.9
17
16.2
15.5
14.8
28.5
26.3
24.4
22.1
20.1
19
18
17.1
16.3
15.6
14.9
94.1
98.9
103.8
110.4
115.3
118.7
118.7
118.7
118.7
118.7
118.7
91.7
96.5
101.1
106
106.8
106.8
106.8
106.8
106.8
106.8
106.8
89.4
94
95
95
95
95
95
95
95
95
95
83.1
83.1
83.1
83.1
83.1
83.1
83.1
83.1
83.1
83.1
83.1
71.2
71.2
71.2
71.2
71.2
71.2
71.2
71.2
71.2
71.2
71.2
59.3
59.3
59.3
59.3
59.3
59.3
59.3
59.3
59.3
59.3
59.3
32.5
33.3
34
34.8
35.1
34.3
32.5
30.8
29.4
28
26.8
30.2
30.9
31.5
31.8
31.1
29.4
27.8
26.4
25.2
24
23
27.6
28.2
31.5
28.4
25.9
24.5
23.2
22
21
20
19.2
31.5
29.1
27
24.4
22.3
21
19.9
18.9
18
17.2
16.5
26.1
24.1
22.4
20.2
18.5
17.4
16.5
15.7
14.9
14.3
13.7
26.2
24.2
22.5
20.3
18.5
17.5
16.6
15.8
15
14.3
13.7
24
TC
kW
PI
kW
93
99
103.4
108.9
108.9
108.9
108.9
108.9
108.9
108.9
108.9
90.7
96.6
98
98
98
98
98
98
98
98
98
87.1
87.1
87.1
87.1
87.1
87.1
87.1
87.1
87.1
87.1
87.1
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
65.3
65.3
65.3
65.3
65.3
65.3
65.3
65.3
65.3
65.3
65.3
54.5
54.5
54.5
54.5
54.5
54.5
54.5
54.5
54.5
54.5
54.5
33.6
34.8
41.8
36.5
33.3
31.5
29.8
28.3
26.9
25.7
24.6
31.2
32.3
32.3
31.3
28.6
26.9
25.6
24.3
23.1
22
21.1
33.7
31.1
28.9
26.1
23.8
22.5
21.3
20.2
19.3
18.4
17.6
28.9
26.7
24.8
22.4
20.5
19.3
18.3
17.4
16.6
15.8
15.1
24
22.1
20.6
18.6
16.9
16
15.1
14.4
13.7
13.1
12.5
24
22.2
20.6
18.6
17
16
15.2
14.4
13.8
13.1
12.6
77
Heating Performance - HEATING PERFORMANCE DATA – 460
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
78
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
32.2
33
33.8
34.1
34.5
35.2
35.8
36.1
36.4
36.6
36.9
29.9
30.7
31.4
31.7
32
31.4
30.7
31
31.2
31.4
31.6
27.3
28
28.7
29
29.2
32.5
30.8
29.3
27.9
26.6
25.5
26.1
26.8
27.5
32.3
29.4
27.8
26.3
25
23.8
22.8
21.8
34.5
31.9
29.6
26.7
24.4
23
21.8
20.7
19.7
18.8
18
34.6
32
29.7
26.8
24.5
23.1
21.9
20.8
19.8
18.9
18.1
104.8
110.4
116.1
121.8
127.5
133.1
138.8
141
143.1
145.3
147.5
102.1
107.6
113.2
118.7
124.3
124.7
124.9
126.9
128.8
130.8
132.7
99.5
104.9
110.3
115.7
118.4
118.4
118.4
118.4
118.4
118.4
118.4
97
102.3
103.6
103.6
103.6
103.6
103.6
103.6
103.6
103.6
103.6
88.8
88.8
88.8
88.8
88.8
88.8
88.8
88.8
88.8
88.8
88.8
74
74
74
74
74
74
74
74
74
74
74
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
106
111.8
117.5
123.3
129
134.8
140.6
144.9
149.3
153.5
157.9
103.3
109
114.6
120.2
125.8
126.3
126.5
130.4
134.3
138.2
142.1
100.6
106.2
111.7
117.1
122.6
127.1
127.1
127.1
127.1
127.1
127.1
98.1
103.5
108.8
110.7
110.7
110.7
110.7
110.7
110.7
110.7
110.7
94.9
94.9
94.9
94.9
94.9
94.9
94.9
94.9
94.9
94.9
94.9
79.1
79.1
79.1
79.1
79.1
79.1
79.1
79.1
79.1
79.1
79.1
33.1
33.9
34.7
35.1
35.4
36.1
36.8
36.5
36.3
36
35.8
30.7
31.5
32.3
32.6
32.9
32.2
31.5
31.3
31.1
30.9
30.7
28
28.8
29.5
29.8
32
30.3
28.7
27.2
26
24.8
23.7
26.9
27.6
33.4
30.2
27.6
26
24.7
23.4
22.3
21.3
20.3
32.3
29.8
27.7
25
22.8
21.6
20.4
19.4
18.4
17.6
16.8
32.4
29.9
27.8
25.1
22.9
21.6
20.5
19.4
18.5
17.7
16.9
101.7
107.2
112.7
118.2
125.8
131.4
137
137
137
137
137
99.1
104.5
109.9
115.3
122.7
123.3
123.3
123.3
123.3
123.3
123.3
96.6
101.8
107.1
109.6
109.6
109.6
109.6
109.6
109.6
109.6
109.6
94.1
95.9
95.9
95.9
95.9
95.9
95.9
95.9
95.9
95.9
95.9
82.2
82.2
82.2
82.2
82.2
82.2
82.2
82.2
82.2
82.2
82.2
68.5
68.5
68.5
68.5
68.5
68.5
68.5
68.5
68.5
68.5
68.5
33.4
34.3
35.1
35.4
36.4
37.1
37.6
35.3
33.6
32.1
30.7
31
31.8
32.6
32.9
33.8
33.6
32.4
30.3
28.8
27.5
26.3
28.3
29.1
29.8
32.5
29.7
28
26.6
25.2
24
22.9
22
27.1
33.3
31
28
25.5
24.1
22.8
21.7
20.6
19.7
18.8
29.9
27.6
25.7
23.2
21.1
19.9
18.9
17.9
17.1
16.3
15.6
30
27.7
25.7
23.3
21.2
20
18.9
18
17.1
16.4
15.7
99.9
105
110.2
117.3
122.5
126
126
126
126
126
126
97.4
102.5
107.4
112.6
113.4
113.4
113.4
113.4
113.4
113.4
113.4
94.9
99.8
100.8
100.8
100.8
100.8
100.8
100.8
100.8
100.8
100.8
88.2
88.2
88.2
88.2
88.2
88.2
88.2
88.2
88.2
88.2
88.2
75.6
75.6
75.6
75.6
75.6
75.6
75.6
75.6
75.6
75.6
75.6
63
63
63
63
63
63
63
63
63
63
63
34.2
35
35.8
36.7
36.9
36.1
34.2
32.5
30.9
29.5
28.3
31.8
32.5
33.2
33.5
32.7
30.9
29.3
27.8
26.5
25.3
24.2
29
29.7
33.1
29.9
27.3
25.8
24.4
23.2
22.1
21.1
20.2
33.2
30.7
28.5
25.7
23.5
22.2
21
19.9
19
18.1
17.3
27.5
25.4
23.6
21.3
19.4
18.3
17.4
16.5
15.7
15
14.4
27.6
25.5
23.7
21.4
19.5
18.4
17.4
16.6
15.8
15.1
14.4
24
TC
kW
PI
kW
98.8
105.1
109.8
115.7
115.7
115.7
115.7
115.7
115.7
115.7
115.7
96.3
102.6
104.1
104.1
104.1
104.1
104.1
104.1
104.1
104.1
104.1
92.5
92.5
92.5
92.5
92.5
92.5
92.5
92.5
92.5
92.5
92.5
81
81
81
81
81
81
81
81
81
81
81
69.4
69.4
69.4
69.4
69.4
69.4
69.4
69.4
69.4
69.4
69.4
57.8
57.8
57.8
57.8
57.8
57.8
57.8
57.8
57.8
57.8
57.8
35.4
36.6
44.1
38.4
35.1
33.1
31.4
29.8
28.4
27.1
25.9
32.8
34
34
33
30.1
28.4
26.9
25.6
24.3
23.2
22.2
35.5
32.7
30.4
27.5
25.1
23.7
22.4
21.3
20.3
19.3
18.5
30.5
28.2
26.2
23.6
21.6
20.3
19.2
18.3
17.4
16.6
15.9
25.3
23.3
21.7
19.5
17.8
16.8
15.9
15.1
14.4
13.8
13.2
25.3
23.4
21.7
19.6
17.9
16.9
16
15.2
14.5
13.8
13.2
Heating Performance - HEATING PERFORMANCE DATA – 480
Outdoor ambient
Capacity factor(%) temperature (°C)
100%
90%
80%
70%
60%
50%
PI
kW
Indoor ambient temperature(DB°C)
18
20
22
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
34.5
35.4
36.3
36.6
37
37.7
38.4
38.8
39
39.3
39.6
32
32.9
33.7
34
34.4
33.7
33
33.2
33.4
33.7
33.9
29.2
30.1
30.8
31.1
31.3
34.8
33
31.4
29.9
28.5
27.3
28
28.8
29.5
34.6
31.6
29.8
28.2
26.8
25.5
24.4
23.3
37
34.2
31.7
28.7
26.1
24.7
23.4
22.2
21.2
20.2
19.4
37.1
34.3
31.8
28.8
26.2
24.8
23.5
22.3
21.2
20.3
19.4
107.8
113.7
119.4
125.3
131.2
137
142.8
145.1
147.3
149.6
151.8
105.1
110.8
116.5
122.2
127.9
128.4
128.6
130.6
132.6
134.6
136.6
102.4
108
113.5
119.1
121.8
121.8
121.8
121.8
121.8
121.8
121.8
99.9
105.2
106.6
106.6
106.6
106.6
106.6
106.6
106.6
106.6
106.6
91.3
91.3
91.3
91.3
91.3
91.3
91.3
91.3
91.3
91.3
91.3
76.1
76.1
76.1
76.1
76.1
76.1
76.1
76.1
76.1
76.1
76.1
16
DB
WB
TC
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
-8
-6
-4
-1
2.2
4.1
6
7.9
9.8
12
14
109.1
115
121
126.8
132.8
138.7
144.7
149.2
153.6
158
162.5
106.4
112.1
117.9
123.7
129.5
130
130.2
134.2
138.2
142.2
146.2
103.6
109.3
114.9
120.5
126.1
130.8
130.8
130.8
130.8
130.8
130.8
101
106.5
112
113.9
113.9
113.9
113.9
113.9
113.9
113.9
113.9
97.6
97.6
97.6
97.6
97.6
97.6
97.6
97.6
97.6
97.6
97.6
81.4
81.4
81.4
81.4
81.4
81.4
81.4
81.4
81.4
81.4
81.4
35.5
36.4
37.3
37.6
38
38.7
39.5
39.2
38.9
38.7
38.4
32.9
33.8
34.6
34.9
35.3
34.6
33.8
33.5
33.3
33.1
32.9
30.1
30.9
31.6
31.9
34.4
32.5
30.8
29.2
27.8
26.6
25.4
28.8
29.6
35.9
32.4
29.6
27.9
26.4
25.1
23.9
22.8
21.8
34.6
32
29.7
26.8
24.5
23.1
21.9
20.8
19.8
18.9
18.1
34.8
32.1
29.8
26.9
24.6
23.2
22
20.9
19.9
19
18.2
104.6
110.3
116
121.7
129.5
135.3
141
141
141
141
141
102
107.6
113.1
118.6
126.2
126.9
126.9
126.9
126.9
126.9
126.9
99.4
104.8
110.2
112.8
112.8
112.8
112.8
112.8
112.8
112.8
112.8
96.9
98.7
98.7
98.7
98.7
98.7
98.7
98.7
98.7
98.7
98.7
84.6
84.6
84.6
84.6
84.6
84.6
84.6
84.6
84.6
84.6
84.6
70.5
70.5
70.5
70.5
70.5
70.5
70.5
70.5
70.5
70.5
70.5
35.8
36.8
37.7
38
39
39.8
40.3
37.8
36.1
34.4
33
33.3
34.1
35
35.3
36.2
36.1
34.7
32.5
30.9
29.5
28.2
30.4
31.2
31.9
34.9
31.8
30.1
28.5
27
25.8
24.6
23.5
29.1
35.8
33.2
30
27.4
25.9
24.5
23.3
22.1
21.1
20.2
32.1
29.6
27.5
24.8
22.6
21.4
20.3
19.2
18.3
17.5
16.7
32.2
29.7
27.6
24.9
22.7
21.5
20.3
19.3
18.4
17.6
16.8
102.8
108.1
113.4
120.7
126
129.7
129.7
129.7
129.7
129.7
129.7
100.3
105.4
110.5
115.9
116.7
116.7
116.7
116.7
116.7
116.7
116.7
97.7
102.7
103.8
103.8
103.8
103.8
103.8
103.8
103.8
103.8
103.8
90.8
90.8
90.8
90.8
90.8
90.8
90.8
90.8
90.8
90.8
90.8
77.9
77.9
77.9
77.9
77.9
77.9
77.9
77.9
77.9
77.9
77.9
64.9
64.9
64.9
64.9
64.9
64.9
64.9
64.9
64.9
64.9
64.9
36.7
37.6
38.4
39.4
39.6
38.7
36.7
34.8
33.2
31.7
30.3
34.1
34.9
35.6
36
35.1
33.2
31.4
29.8
28.4
27.1
26
31.1
31.9
35.5
32.1
29.3
27.6
26.2
24.9
23.7
22.6
21.7
35.6
32.9
30.5
27.6
25.2
23.8
22.5
21.4
20.4
19.5
18.6
29.5
27.3
25.3
22.8
20.9
19.7
18.7
17.7
16.9
16.1
15.4
29.6
27.4
25.4
23
20.9
19.7
18.7
17.8
16.9
16.2
15.5
24
TC
kW
PI
kW
101.7
108.2
113.1
119
119
119
119
119
119
119
119
99.2
105.5
107.1
107.1
107.1
107.1
107.1
107.1
107.1
107.1
107.1
95.2
95.2
95.2
95.2
95.2
95.2
95.2
95.2
95.2
95.2
95.2
83.3
83.3
83.3
83.3
83.3
83.3
83.3
83.3
83.3
83.3
83.3
71.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
71.4
59.5
59.5
59.5
59.5
59.5
59.5
59.5
59.5
59.5
59.5
59.5
38
39.3
47.3
41.2
37.6
35.5
33.7
32
30.4
29.1
27.8
35.2
36.5
36.4
35.4
32.3
30.4
28.9
27.4
26.1
24.9
23.8
38.1
35.1
32.6
29.5
26.9
25.4
24
22.8
21.8
20.8
19.8
32.7
30.2
28.1
25.3
23.1
21.8
20.6
19.6
18.7
17.8
17.1
27.1
25
23.2
21
19.1
18.1
17.1
16.2
15.5
14.8
14.1
27.1
25.1
23.3
21
19.2
18.1
17.1
16.3
15.5
14.8
14.2
79
Capacity Corrections
COOLING CAPACITY CORRECTION - PIPING INDEX
Cooling capacity correction becomes necessary due to a height difference and piping length. Actual cooling capacity = rated
cooling capacity × piping correction index
40
30
72%
74%
76%
78%
80%
82%
84%
86%
88%
90%
92%
94%
0
96%
10
98%
20
100%
Outdoor Height Difference H(m)
50
-10
-20
-30
-40
0
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Refrigerant Pipe Equivalent Length L(m)
HEATING CAPACITY CORRECTION - PIPING INDEX
Heating capacity correction becomes necessary due to a height difference and piping length. Actual heating capacity =
rated heating capacity × piping correction index
Outdoor Height Difference H(m)
Refrigerant Pipe Equivalent Length L(m)
80
Wiring Diagrams - Outdoor Units
ELECTRICAL WIRING DIAGRAMS - OUTDOOR UNITS
OD Units with CE mark*
* Note: OD units with CE mark are options
81
Wiring DIagrams - Outdoor Units
ELECTRICAL WIRING DIAGRAMS - OUTDOOR UNITS
OD Units with CE mark*
* Note: OD units with CE mark are options
82
Inspection & Handling
INSPECTION & HANDLING OF OUTDOR UNITS
On receipt of the unit, the package should be checked and
any damage should be reported immediately to the carrier
claims agent.
When handling the unit, take into account the following:
•• Fragile, handle the unit with care. Keep the unit upright in
order to avoid compressor damage.
•• Define the transportation route.
•• If a forklift is to be used, pass the forklift arms through the
large openings on the bottom of the unit. (Refer to figure)
•• If hanging the unit, use a cloth sling to prevent damaging
the unit.
Keeping the following points in mind, suspend the unit
following the procedure shown in figure below:
•• Use a sling sufficiently strong to hold the mass of the unit.
•• Use 2 belts of at least 27 ft long.
•• Place extra cloth or boards in the locations where the
casing comes in contact with the sling to prevent damage.
•• Hoist the unit making sure it is being lifted at its center of
gravity
Ceiling Concealed Ducted Indoor Units
FEATURES
Ceiling Concealed Indoor fan coil units are available with
nominal capacity range of 1.8 to 17.5kW arranged for
blow through operation and suitable for indoor concealed
ducted installation. Units are factory assembled including
coil, electronic expansion valve, condensate drain pan,
fan motor(s), filters, mounting brackets and controls in an
insulated casing.
Unit casing is constructed of zinc coated, heavy gauge,
galvanized steel G90. Exterior surfaces are thoroughly
cleaned, phosphatized, and finished with weather resistant,
baked enamel. Top panels are insulated with foam.
Knockouts are provided for electrical power and refrigerant
piping connections. Panels are fastened with screws for ease
of service and cleaning.
Evaporator coils are constructed of copper tube and
aluminum fins. Each coil is thoroughly pressure tested at
factory to detect any leaks. The condensate drain pan is
constructed of powder coated GI with foam insulation.
Evaporator fans are of double inlet, double width, forward
curved, centrifugal type with direct drive three speed class
B insulation and IP 20 type motor that can be accessed from
the bottom and the rear panel.
They are statically and dynamically balanced for quiet
operation. The fan motors are of permanently lubricated type
with auto reset thermal overload protection as standard.
The shaft is protected against rusting. All fan motors are
resilient mounted to minimize vibration and noise and are of
permanent split capacitor type for high efficiency. All units
are provided with filters that are easily accessible from the
rear of the unit.
Wired control are available as standard. The controls shall
be microprocessor based and provide for a user interface.
The controls shall provide compressor delay protection, anti
ice sensor for indoor units, 3 speed fan control, and
auto fan function. Room temp setting and display shall be
available. Auto restart to default setting, clock and timer
functions are included.
The ESP can be adjusted to 0, 15 or 30Pa for
sizes YDCC018~YDCC053; 15, 40 or 80Pa for sizes
YDCC066~YDCC115 and 15, 50 or 100Pa for sizes
YDCC140 & YDCC175 in the field with the wired controller.
Units are tested and rated in accordance with China GB
standards.
83
STANDARD UNIT AND OPTIONS
Item
Standard Offer
Option
Wire controller is standard offering
Remarks
Wireless controller with receiver is as an option.
Wire controller has a receiver
1
to receive signal from wireless
Controller
controller directly when
installed together.
YDCC018~YDCC053 Standard offer is
nylon filter
2
Filter
YDCC066~YDCC175 nylon filter is an option
YDCC066~YDCC175 Standard offer is
aluminum filter
The Nano-TiO2 Sterilizer can
be installed in duct separately,
Duct mounted
3
Nano-TiO2
and cannot be controlled
Not Standard
by the indoor unit. Need a
Sterilizer
separate power supply.
DATA SHEET - CEILING CONCEALED DUCTED INDOOR UNITS
DATA SHEET - CEILING CONCEALED UNITS
YDCC018
H0FLEA-0C3
YDCC020
H0FLEA-0C3
YDCC025
H0FLEA-0C3
YDCC034
H0FLEA-0C3
YDCC045
H0FLEA-0C3
YDCC053
H0FLEA-0C3
kW
1.8
2.0
2.5
3.4
4.5
5.3
kW
2.2
2.2
3.0
3.9
4.95
5.8
380
380
450
600
800
930
Model
Cooling Capacity
Heating
Capacity*
without
electric
heater
Power supply
V/Ph/Hz
Air Flow Rate**
m3/h
Number of
Blade
Number of
Fan
Motor
Power
consumption
Operating
Current
220V/~/50Hz
-
2
-
1
W
40
40
55
75
100
110
A
0.35
0.35
0.35
0.40
0.46
0.52
External Static Pressure
Pa
0/15/30
Control method
-
remote control or wire control
Height
mm
226
Width
mm
Length
mm
855
1055
1175
kg
20
23
25
Dimension
Machine Weight
Liquid Pipe
mm
Connecting
Gas Pipe
mm
Pipes
Drainage
Pipe
84
mm
602
6.35
9.52
12.7
19.05(O.D)
YDCC066
H0FLEA-0C3
YDCC078
H0FLEA-0C3
YDCC095
H0FLEA-0C3
YDCC115
H0FLEA-0C3
YDCC140
H0FLEA-0C3
YDCC175
H0FLEA-0C3
kW
6.6
7.8
9.5
11.5
14
17.5
kW
6.8
8.2
11
13
16.5
19
1200
1360
1600
1900
2200
2700
Model
Cooling Capacity
Heating
without
Capacity*
electric heater
Power supply
V/Ph/Hz
Air Flow Rate**
m3/h
Number of
Blade
Number of
Motor
Power
Fan
consumption
Operating
Current
-
2
3
2
-
1
2
1
W
185
215
270
300
420
510
A
0.96
1.08
1.29
1.3
1.9
2.11
External Static Pressure
Pa
Control method
-
Dimension
Pipes
15/40/80
mm
245
Width
mm
576
Length
mm
kg
15/50/100
remote control or wire control
Height
Machine Weight
Connecting
220V/~/50Hz
1475
32
430
655
1805
33
1563
41
58
Liquid Pipe
mm
Gas Pipe
mm
15.88
Drainage Pipe
mm
19.05(O.D)
65
9.52
DATA SHEET - CEILING CONCEALED UNITS (ELECTRIC HEATER MODELS)
YDCC018
YDCC020
YDCC025
YDCC034
YDCC045
YDCC053
H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3
Model
Cooling Capacity
Heating
Capacity*
With 2# electric heater
With 4# electric heate
1.8
2
2.5
3.4
4.5
5.3
2.2+1
2.2+1
3.0+1
3.9+1
4.95+1
5.8+1.6
kW
-
-
-
-
-
5.8+2
600
800
930
Power supply
V/Ph/Hz
Air Flow Rate**
m3/h
220V/~/50Hz
380
380
450
Number of Blade
-
2
Number of Motor
-
1
With 2#
Power
Fan
kW
kW
Heater
With 4#
Consumption
Heater
With 2#
Operating
Heater
With 4#
Current
Heater
W
40+1000
40+1000
55+1000
75+1000
100+1000
110+1600
W
-
-
-
-
-
110+2000
A
0.35+4.5
0.35+4.5
0.35+4.5
0.40+4.5
0.46+4.5
0.52+7.3
A
-
-
-
-
-
0.52+9.0
External Static Pressure
Pa
0/15/30
Control method
-
remote control or wire control
Height
mm
226
Width
mm
Length
mm
885
1055
1175
kg
20
23
25
Dimension
Machine Weight
Connecting Pipes
Liquid Pipe
mm
Gas Pipe
mm
Drainage
Pipe
mm
602
6.35
9.52
12.7
19.05(O.D)
85
YDCC066
YDCC078
YDCC095
YDCC115
YDCC140
YDCC175
H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3 H0FLEA-0C3
Model
Cooling Capacity
With 2# electric
heater
With 4# electric
Heating Capacity*
heate
6.6
7.8
9.5
11.5
14
17.5
kW
6.8+1.6
8.2+2.0
11.0+2.0
13.0+2.0
16.5+3.2
19.0+3.2
kW
6.8+2.0
8.2+3.2
11.0+3.2
13.0+3.2
16.5+4.2
19.0+4.2
1200
1360
1600
Power supply
V/Ph/Hz
Air Flow Rate**
m3/h
220V/~/50Hz
1900
2200
2700
Number of Blade
-
2
3
2
Number of Motor
-
1
2
1
Power
Fan
kW
Consumption
Operating
Current
With 2# Heater
W
185+1600
215+2000
270+2000
300+2000
420+3200
510+3200
With 4# Heater
W
185+2000
215+3200
270+3200
300+3200
420+4200
510+4200
With 2# Heater
A
0.96+7.3
1.08+9.0
1.29+9.0
1.3+9.0
1.90+14.5
2.11+14.5
With 4# Heater
A
0.96+9.0
1.08+14.5
1.29+14.5
1.3+14.5
1.90+19.1
2.11+19.1
External Static Pressure
Pa
Control method
-
Dimension
15/50/100
remote control or wire control
Height
mm
245
430
Width
mm
576
655
Length
mm
Machine Weight
Connecting Pipes
15/40/80
1475
kg
32
1850
33
1563
41
Liquid Pipe
mm
Gas Pipe
mm
15.88
Drainage Pipe
mm
19.05(O.D)
58
65
9.52
Notes:
t Standard setting of the ESP is 15Pa, and extra 5Pa (YDCC018~YDCC053 Nylon filter) or 12Pa (YDCC066~YDCC175, Aluminum filter) pressure drop will be caused
by the filter, EXV.
t The standard offer is without electric heater. An option exists for auxiliary electric heater for heat pump.
t
* Data applicable to heat pump models only.
Dimensional Data & Piping System
LAYOUT & DIMENSIONS - CEILING CONCEALED UNITS
Models
A
B
C
D
E
Models
A
B
C
D
E
YDCC018/020/025
605
630
830
609
681
YDCC066/078
1205
1235
1450
1213
222
YDCC034
805
830
1030
809
881
YDCC095/115
1505
1535
1780
1513
237
YDCC045/053
910
935
1150
914
986
86
YDCC140/175
PIPING SYSTEM FOR CEILING CONCEALED DUCTED MODELS
Notes:
• Tlair = Room temperature (Air return temperature)
• Tin = Coil inlet temperature in cooling mode
• Tout = Coil outlet temperature in cooling mode
• EXV = Electrical expansion valve
• Heater = Electric heater, only available in heat pump models as an option.
87
Cooling Performance - Ducted Indoor Units
COOLING PERFORMANCE DATA - CEILING CONCEALED INDOOR UNITS
Indoor ambient temp.(°C)
Indoor
Unit
Model
YDCC018
YDCC020
88
Outdoor
ambient
temp.
(DB°C)
14WB
20DB
16WB
23DB
18WB
26DB
19WB
27DB
20WB
28DB
22WB
30DB
24WB
32DB
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
10
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
2.0
1.4
2.2
1.4
2.3
1.3
12
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.2
1.4
2.3
1.3
14
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.2
1.4
2.2
1.3
16
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.2
1.4
2.2
1.3
18
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.2
1.4
2.2
1.3
20
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.1
1.4
2.2
1.3
21
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.1
1.3
2.2
1.3
23
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.1
1.3
2.1
1.3
25
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.0
1.3
2.1
1.2
27
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
2.0
1.3
2.1
1.2
29
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.4
2.0
1.3
2.0
1.2
31
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.4
1.9
1.3
2.0
1.2
33
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.9
1.3
1.9
1.2
2.0
1.2
35
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.8
1.3
1.9
1.2
1.9
1.2
37
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.8
1.3
1.8
1.2
1.9
1.2
39
1.3
1.1
1.4
1.2
1.7
1.3
1.8
1.4
1.8
1.3
1.8
1.2
1.9
1.2
42
1.3
1.1
1.4
1.2
1.7
1.3
1.7
1.3
1.7
1.3
1.8
1.2
1.8
1.2
44
1.3
1.1
1.4
1.2
1.7
1.3
1.7
1.3
1.7
1.2
1.7
1.2
1.8
1.2
46
1.2
1.1
1.4
1.2
1.6
1.3
1.6
1.3
1.6
1.2
1.7
1.2
1.7
1.1
48
1.2
1.0
1.4
1.2
1.6
1.2
1.5
1.2
1.6
1.2
1.6
1.1
1.6
1.1
50
1.2
1.0
1.4
1.2
1.4
1.2
1.4
1.1
1.4
1.1
1.4
1.0
1.4
1.0
52
1.2
1.0
1.3
1.1
1.3
1.0
1.3
1.0
1.3
0.9
1.3
0.9
1.3
0.9
10
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.2
1.5
2.4
1.5
2.5
1.5
12
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.2
1.5
2.4
1.5
2.5
1.5
14
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.2
1.5
2.4
1.5
2.5
1.4
16
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.4
1.5
2.5
1.4
18
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.4
1.5
2.5
1.4
20
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.4
1.5
2.4
1.4
21
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.3
1.5
2.4
1.4
23
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.3
1.5
2.4
1.4
25
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.3
1.5
2.3
1.4
27
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.2
1.4
2.3
1.4
29
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.2
1.4
2.3
1.3
31
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.2
1.4
2.2
1.3
33
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.1
1.5
2.1
1.4
2.2
1.3
35
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.0
1.5
2.1
1.4
2.1
1.3
37
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.0
1.4
2.0
1.3
2.1
1.3
39
1.4
1.2
1.6
1.4
1.9
1.5
2.0
1.5
2.0
1.4
2.0
1.3
2.1
1.3
42
1.4
1.2
1.6
1.4
1.9
1.5
1.9
1.5
1.9
1.4
2.0
1.3
2.0
1.3
44
1.4
1.2
1.6
1.4
1.8
1.4
1.9
1.5
1.9
1.4
1.9
1.3
2.0
1.3
46
1.4
1.2
1.6
1.3
1.8
1.4
1.8
1.4
1.8
1.3
1.9
1.3
1.9
1.3
48
1.3
1.2
1.5
1.3
1.7
1.4
1.7
1.3
1.8
1.3
1.8
1.3
1.8
1.2
50
1.3
1.1
1.5
1.3
1.6
1.3
1.6
1.3
1.6
1.2
1.6
1.1
1.6
1.1
52
1.3
1.1
1.4
1.2
1.4
1.1
1.4
1.1
1.4
1.0
1.4
1.0
1.4
1.0
Indoor
Unit
Model
YDCC025
YDCC034
YDCC045
Outdoor
ambient
temp.
(DB°C)
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
14WB
20DB
TC
SHC
kW
kW
16WB
23DB
TC
SHC
kW
kW
Indoor ambient temp.(°C)
18WB
19WB
20WB
26DB
27DB
28DB
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
22WB
30DB
TC
SHC
kW
kW
24WB
32DB
SHC
TC
kW
kW
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.7
1.7
1.6
1.6
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.4
2.3
2.3
2.2
2.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.1
3.0
3.0
2.9
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
1.9
1.9
1.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.4
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.5
3.5
3.4
3.1
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.2
2.2
2.0
1.8
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.1
3.0
2.9
2.7
2.4
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.1
4.0
3.9
3.6
3.2
3.0
3.0
3.0
3.0
3.0
2.9
2.9
2.9
2.8
2.8
2.7
2.7
2.7
2.6
2.6
2.5
2.5
2.4
2.3
2.3
2.0
1.8
4.1
4.1
4.1
4.1
4.1
4.0
4.0
3.9
3.8
3.8
3.7
3.7
3.6
3.5
3.5
3.4
3.4
3.3
3.2
3.1
2.7
2.4
5.4
5.4
5.4
5.4
5.4
5.3
5.3
5.2
5.1
5.0
4.9
4.9
4.8
4.7
4.6
4.5
4.4
4.4
4.2
4.1
3.6
3.2
3.1
3.1
3.1
3.1
3.1
3.0
3.0
3.0
2.9
2.9
2.8
2.8
2.7
2.7
2.6
2.6
2.5
2.5
2.4
2.3
2.0
1.8
4.3
4.3
4.2
4.2
4.2
4.1
4.1
4.0
4.0
3.9
3.8
3.8
3.7
3.6
3.6
3.5
3.4
3.4
3.3
3.1
2.7
2.4
5.6
5.6
5.5
5.5
5.5
5.4
5.4
5.3
5.2
5.1
5.1
5.0
4.9
4.8
4.7
4.6
4.6
4.5
4.3
4.1
3.6
3.2
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.4
1.4
1.4
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.1
2.1
2.0
2.0
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.5
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.6
1.6
1.5
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.2
2.2
2.2
2.0
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.8
2.8
2.8
2.6
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.7
1.7
1.6
1.4
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.4
2.4
2.2
2.0
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.1
3.0
3.0
2.8
2.4
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.4
2.4
2.2
2.1
2.0
1.8
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.3
3.3
3.2
3.0
2.9
2.7
2.4
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.4
4.3
4.3
4.0
3.8
3.6
3.2
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.8
1.8
1.8
1.7
1.6
1.4
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.6
2.4
2.3
2.2
2.0
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.3
3.3
3.2
3.0
2.9
2.5
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.5
2.5
2.4
2.4
2.4
2.3
2.2
2.0
1.8
3.7
3.7
3.7
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.5
3.4
3.4
3.3
3.3
3.2
3.1
3.0
2.7
2.4
4.9
4.9
4.9
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.7
4.6
4.6
4.5
4.4
4.3
4.2
4.1
4.0
3.6
3.2
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.8
1.8
1.8
1.7
1.7
1.7
1.6
1.5
1.3
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.6
2.5
2.5
2.5
2.4
2.4
2.3
2.1
1.9
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.3
3.3
3.2
3.2
3.1
3.1
3.1
3.0
2.9
2.6
2.3
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.8
1.8
1.8
1.8
1.7
1.7
1.7
1.7
1.6
1.6
1.6
1.6
1.6
1.4
1.3
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.5
2.5
2.5
2.4
2.4
2.4
2.4
2.4
2.4
2.3
2.3
2.1
1.8
3.4
3.4
3.4
3.4
3.4
3.3
3.3
3.2
3.2
3.1
3.1
3.1
3.1
3.0
3.0
2.9
2.9
2.9
2.9
2.8
2.5
2.3
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.6
1.6
1.6
1.6
1.5
1.4
1.2
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.5
2.5
2.4
2.4
2.4
2.3
2.3
2.3
2.3
2.3
2.3
2.2
2.1
1.9
1.7
3.3
3.3
3.3
3.3
3.3
3.2
3.2
3.1
3.1
3.1
3.0
3.0
2.9
2.9
2.9
2.8
2.8
2.8
2.8
2.6
2.4
2.1
89
Indoor
Unit
Model
YDCC053
YDCC066
YDCC078
90
Outdoor
ambient
temp.
(DB°C)
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
14WB
20DB
TC
SHC
kW
kW
16WB
23DB
TC
SHC
kW
kW
Indoor ambient temp.(°C)
18WB
19WB
20WB
26DB
27DB
28DB
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
22WB
30DB
TC
SHC
kW
kW
24WB
32DB
SHC
TC
kW
kW
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.6
3.6
3.5
3.4
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.5
4.4
4.3
4.3
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.4
5.2
5.1
5.0
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.2
4.1
4.0
3.7
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.2
5.1
5.0
4.6
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.1
6.0
5.9
5.4
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.7
4.6
4.2
3.7
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.2
6.1
5.8
5.7
5.3
4.6
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.2
6.9
6.7
6.2
5.5
6.4
6.3
6.3
6.3
6.3
6.2
6.2
6.1
6.0
5.9
5.8
5.7
5.6
5.5
5.4
5.3
5.2
5.1
4.9
4.8
4.2
3.7
8.0
7.9
7.9
7.9
7.9
7.8
7.7
7.6
7.5
7.4
7.2
7.1
7.0
6.9
6.8
6.6
6.5
6.4
6.2
5.9
5.3
4.6
9.4
9.3
9.3
9.3
9.3
9.2
9.1
9.0
8.8
8.7
8.6
8.4
8.3
8.1
8.0
7.8
7.7
7.6
7.3
7.0
6.2
5.5
6.6
6.6
6.5
6.5
6.5
6.4
6.4
6.3
6.2
6.1
6.0
5.9
5.8
5.7
5.6
5.5
5.4
5.3
5.1
4.8
4.2
3.7
8.3
8.3
8.1
8.1
8.1
8.0
7.9
7.8
7.7
7.6
7.4
7.3
7.2
7.1
6.9
6.8
6.7
6.6
6.3
5.9
5.3
4.6
9.8
9.8
9.6
9.6
9.6
9.4
9.4
9.2
9.1
8.9
8.8
8.6
8.5
8.3
8.2
8.1
7.9
7.8
7.5
7.0
6.2
5.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.4
3.3
3.3
3.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.1
4.1
4.0
4.0
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.8
4.8
4.7
4.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.5
3.5
3.2
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.4
4.3
4.3
4.0
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.2
5.1
5.1
4.7
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
3.9
3.8
3.6
3.1
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
4.9
4.7
4.7
4.4
3.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.7
5.6
5.5
5.1
4.5
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.2
5.1
5.1
4.7
4.5
4.2
3.7
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.5
6.4
6.3
5.9
5.6
5.3
4.6
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.8
7.7
7.5
7.4
7.0
6.6
6.2
5.5
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.2
4.2
4.0
3.8
3.6
3.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.1
5.0
5.0
4.8
4.5
4.4
3.8
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.0
5.9
5.9
5.6
5.3
5.1
4.5
5.8
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.6
5.5
5.4
5.3
5.2
5.1
5.0
4.8
4.7
4.2
3.7
7.2
7.1
7.1
7.1
7.0
7.0
7.0
7.0
7.0
7.0
7.0
6.9
6.8
6.7
6.6
6.5
6.3
6.2
6.0
5.9
5.3
4.6
8.5
8.4
8.4
8.3
8.3
8.3
8.3
8.3
8.3
8.3
8.3
8.2
8.0
7.9
7.8
7.6
7.5
7.4
7.1
6.9
6.2
5.5
4.3
4.3
4.3
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.1
4.0
4.0
4.0
3.9
3.9
3.7
3.7
3.3
2.9
5.3
5.3
5.3
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.1
5.0
5.0
4.9
4.8
4.8
4.7
4.6
4.5
4.1
3.6
6.2
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.0
5.9
5.8
5.7
5.7
5.6
5.6
5.4
5.3
4.8
4.2
4.3
4.3
4.3
4.3
4.3
4.2
4.2
4.1
4.0
4.0
4.0
3.9
3.9
3.8
3.8
3.8
3.7
3.7
3.7
3.6
3.2
2.9
5.2
5.2
5.2
5.2
5.2
5.1
5.0
5.0
4.9
4.9
4.9
4.8
4.7
4.6
4.7
4.6
4.6
4.6
4.5
4.4
4.0
3.5
6.3
6.2
6.2
6.2
6.2
6.1
6.0
6.0
5.9
5.8
5.7
5.6
5.6
5.5
5.5
5.4
5.3
5.3
5.2
5.1
4.6
4.1
4.2
4.2
4.1
4.1
4.1
4.0
4.0
4.0
3.9
3.8
3.8
3.7
3.7
3.7
3.6
3.5
3.5
3.5
3.5
3.3
3.0
2.7
5.1
5.1
5.0
5.0
5.0
5.0
4.9
4.8
4.8
4.7
4.7
4.6
4.6
4.5
4.5
4.5
4.4
4.4
4.3
4.1
3.7
3.3
6.0
6.0
5.9
5.9
5.9
5.8
5.8
5.7
5.7
5.6
5.5
5.4
5.3
5.4
5.3
5.2
5.2
5.2
5.1
4.8
4.4
3.9
Indoor
Unit
Model
YDCC095
YDCC115
YDCC140
Outdoor
ambient
temp.
(DB°C)
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
14WB
20DB
TC
SHC
kW
kW
16WB
23DB
TC
SHC
kW
kW
Indoor ambient temp.(°C)
18WB
19WB
20WB
26DB
27DB
28DB
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
22WB
30DB
TC
SHC
kW
kW
24WB
32DB
SHC
TC
kW
kW
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.5
6.4
6.3
6.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
7.9
7.7
7.6
7.4
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.8
9.6
9.4
9.2
9.0
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.5
7.3
7.2
6.6
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.3
9.1
8.9
8.7
8.0
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.3
11.0
10.8
10.6
9.8
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.7
8.4
8.2
7.6
6.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.7
10.6
10.2
9.9
9.2
8.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
13.1
12.8
12.4
12.1
11.2
9.8
11.5
11.4
11.4
11.4
11.4
11.2
11.1
10.9
10.8
10.6
10.4
10.2
10.1
9.9
9.7
9.6
9.4
9.2
8.9
8.6
7.6
6.7
13.9
13.7
13.7
13.7
13.7
13.5
13.4
13.2
13.0
12.8
12.6
12.4
12.2
12.0
11.8
11.6
11.4
11.2
10.7
10.4
9.2
8.1
16.9
16.7
16.7
16.7
16.7
16.5
16.4
16.1
15.9
15.6
15.3
15.1
14.8
14.6
14.3
14.1
13.8
13.6
13.1
12.6
11.2
9.8
11.9
11.9
11.7
11.7
11.7
11.5
11.4
11.2
11.0
10.9
10.7
10.5
10.3
10.2
10.0
9.8
9.6
9.5
9.1
8.6
7.6
6.7
14.4
14.4
14.1
14.1
14.1
13.9
13.8
13.6
13.4
13.2
12.9
12.7
12.5
12.3
12.1
11.9
11.7
11.5
11.0
10.4
9.2
8.1
17.5
17.5
17.2
17.2
17.2
16.9
16.8
16.5
16.3
16.0
15.8
15.5
15.2
15.0
14.7
14.5
14.2
13.9
13.4
12.6
11.2
9.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.8
4.7
4.6
4.5
4.5
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.5
6.4
6.3
6.2
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
8.8
8.6
8.5
8.4
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.4
5.3
5.2
4.9
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.0
6.9
6.8
6.3
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.5
9.3
9.2
8.5
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.3
6.1
6.0
5.6
5.0
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.6
7.4
7.3
6.8
6.0
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.4
10.0
9.9
9.2
8.1
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.3
9.2
9.1
8.5
8.0
7.6
6.7
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.5
11.3
11.1
11.0
10.3
9.7
9.2
8.1
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
13.8
13.5
13.3
12.5
11.8
11.2
9.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.7
6.6
6.5
6.3
5.9
5.7
5.0
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.2
8.1
7.9
7.9
7.5
7.1
6.8
6.0
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.2
11.0
10.8
10.7
10.3
9.7
9.3
8.2
10.4
10.3
10.3
10.2
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.0
9.8
9.6
9.5
9.3
9.1
9.0
8.6
8.4
7.6
6.7
12.5
12.4
12.4
12.3
12.3
12.3
12.3
12.3
12.3
12.3
12.3
12.1
11.9
11.7
11.5
11.3
11.1
10.9
10.4
10.2
9.2
8.1
15.3
15.1
15.1
15.0
14.9
14.9
14.9
14.9
14.9
14.9
14.9
14.7
14.4
14.2
13.9
13.7
13.5
13.2
12.7
12.4
11.2
9.8
7.1
7.1
7.1
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
6.9
6.8
6.7
6.5
6.4
6.4
6.3
6.1
6.0
5.4
4.8
8.3
8.2
8.2
8.2
8.1
8.1
8.1
8.1
8.1
8.1
8.2
8.1
8.0
7.8
7.7
7.6
7.5
7.4
7.2
7.0
6.4
5.6
11.3
11.1
11.1
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.2
11.1
10.9
10.7
10.5
10.3
10.2
10.1
9.8
9.6
8.7
7.7
7.1
7.0
7.1
7.1
7.1
7.0
6.9
6.8
6.8
6.7
6.6
6.5
6.4
6.3
6.2
6.1
6.0
6.0
5.9
5.8
5.2
4.7
8.3
8.2
8.2
8.2
8.2
8.1
8.0
7.9
7.8
7.6
7.7
7.6
7.5
7.3
7.3
7.2
7.2
7.2
7.0
6.9
6.2
5.5
11.4
11.2
11.2
11.2
11.2
11.1
11.0
10.8
10.6
10.5
10.5
10.3
10.1
10.0
9.9
9.7
9.7
9.7
9.5
9.3
8.4
7.5
6.5
6.5
6.4
6.4
6.4
6.3
6.2
6.2
6.1
6.0
6.0
5.9
5.8
5.8
5.7
5.6
5.6
5.6
5.4
5.2
4.7
4.2
8.0
8.0
7.9
7.9
7.9
7.8
7.7
7.6
7.5
7.4
7.3
7.3
7.1
7.0
7.1
7.0
7.0
7.0
6.8
6.5
5.9
5.2
10.9
10.9
10.7
10.8
10.8
10.6
10.5
10.4
10.2
10.2
10.0
9.9
9.7
9.6
9.6
9.4
9.4
9.4
9.2
8.8
7.9
7.1
91
Indoor ambient temp.(°C)
Indoor
Unit
Model
YDCC175
92
Outdoor
ambient
temp.
(DB°C)
TC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
10
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
19.1
14.1
21.2
14.2
21.9
13.6
12
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.9
13.9
20.9
14.0
21.9
13.6
14
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.9
13.9
20.9
14.0
21.5
13.4
16
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
20.9
14.0
21.5
13.5
18
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
20.9
14.0
21.5
13.4
20
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
20.6
13.8
21.2
13.2
21
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
20.4
13.7
21.0
13.1
23
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
20.1
13.5
20.7
12.9
25
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
19.8
13.3
20.3
12.7
27
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
13.8
19.5
13.1
20.0
12.7
29
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.7
14.1
19.2
13.1
19.7
12.5
31
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.4
13.8
18.9
12.9
19.4
12.3
33
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
18.1
13.6
18.6
12.6
19.0
12.1
35
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
17.7
13.4
18.2
12.5
18.7
11.9
37
12.3
11.2
14.1
12.0
16.3
13.1
17.5
14.0
17.4
13.1
17.9
12.4
18.4
12.0
39
12.3
11.2
14.1
12.0
16.3
13.1
17.2
13.7
17.1
12.9
17.6
12.1
18.1
11.8
42
12.3
11.2
14.1
12.0
16.3
13.1
16.9
13.5
16.8
12.8
17.3
12.1
17.8
11.8
44
12.3
11.2
14.1
12.0
16.1
12.9
16.7
13.4
16.5
12.6
17.0
12.1
17.4
11.8
46
12.0
11.0
13.8
11.8
15.5
12.5
15.7
12.9
15.9
12.2
16.3
11.8
16.8
11.5
48
11.8
10.8
13.5
11.6
15.1
12.3
14.7
12.2
15.5
12.0
15.8
11.6
15.8
11.0
14WB
16WB
18WB
19WB
20WB
22WB
24WB
20DB
23DB
26DB
27DB
28DB
30DB
32DB
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
50
11.5
10.6
13.2
11.5
14.0
11.5
14.0
11.6
14.0
10.9
14.0
10.5
14.0
9.9
52
11.3
10.5
12.2
10.6
12.3
10.1
12.3
10.3
12.3
9.6
12.3
9.3
12.3
8.8
Heating Performance - Ducted Indoor Units
HEATING PERFORMANCE DATA - CEILING CONCEALED INDOOR UNITS
Indoor Unit
Model
YDCC018
YDCC020
YDCC025
YDCC034
Outdoor ambient temp.
Indoor ambient temp.(DB°C)
16
18
20
22
24
(°C,DB)
(°C,WB)
kW
kW
kW
kW
kW
-7
-7.5
1.7
1.7
1.6
1.6
1.6
-5
-5.5
1.8
1.8
1.7
1.7
1.7
-3
-3.6
1.9
1.9
1.8
1.8
1.8
0
-1
2.0
2.0
1.9
1.9
1.8
3
2
2.1
2.0
2.0
2.0
1.8
5
4
2.2
2.1
2.1
2.0
1.8
7
6
2.3
2.2
2.2
2.0
1.8
9
8
2.3
2.3
2.2
2.0
1.8
11
10
2.4
2.3
2.2
2.0
1.8
13
12
2.5
2.3
2.2
2.0
1.8
15
14
2.5
2.4
2.2
2.0
1.8
-7
-7.5
1.7
1.7
1.6
1.6
1.6
-5
-5.5
1.8
1.8
1.7
1.7
1.7
-3
-3.6
1.9
1.9
1.8
1.8
1.8
0
-1
2.0
2.0
1.9
1.9
1.8
3
2
2.1
2.0
2.0
2.0
1.8
5
4
2.2
2.1
2.1
2.0
1.8
7
6
2.3
2.2
2.2
2.0
1.8
9
8
2.3
2.3
2.2
2.0
1.8
11
10
2.4
2.3
2.2
2.0
1.8
13
12
2.5
2.3
2.2
2.0
1.8
15
14
2.5
2.4
2.2
2.0
1.8
-7
-7.5
2.3
2.3
2.2
2.2
2.2
-5
-5.5
2.4
2.4
2.3
2.3
2.3
-3
-3.6
2.6
2.5
2.5
2.4
2.4
0
-1
2.7
2.7
2.6
2.6
2.5
3
2
2.8
2.8
2.8
2.7
2.5
5
4
3.0
2.9
2.9
2.8
2.5
7
6
3.1
3.0
3.0
2.8
2.5
9
8
3.2
3.1
3.0
2.8
2.5
11
10
3.3
3.1
3.0
2.8
2.5
13
12
3.4
3.2
3.0
2.8
2.5
15
14
3.5
3.2
3.0
2.8
2.5
-7
-7.5
3.0
3.0
2.9
2.8
2.8
-5
-5.5
3.2
3.1
3.1
3.0
3.0
-3
-3.6
3.3
3.3
3.2
3.1
3.1
0
-1
3.5
3.5
3.4
3.3
3.3
3
2
3.7
3.6
3.6
3.5
3.3
5
4
3.8
3.8
3.7
3.6
3.3
7
6
4.0
4.0
3.9
3.6
3.3
9
8
4.1
4.0
3.9
3.6
3.3
11
10
4.2
4.1
3.9
3.6
3.3
13
12
4.4
4.1
3.9
3.6
3.3
15
14
4.5
4.2
3.9
3.6
3.3
93
HEATING PERFORMANCE DATA - CEILING CONCEALED INDOOR UNITS
Indoor Unit
Model
YDCC045
YDCC053
YDCC066
YDCC078
94
Outdoor ambient temp.
Indoor ambient temp.(DB°C)
16
18
20
22
24
(°C,DB)
(°C,WB)
kW
kW
kW
kW
kW
-7
-7.5
3.8
3.8
3.7
3.6
3.6
-5
-5.5
4.0
4.0
3.9
3.8
3.8
-3
-3.6
4.2
4.2
4.1
4.0
3.9
0
-1
4.5
4.4
4.3
4.2
4.2
3
2
4.7
4.6
4.5
4.4
4.2
5
4
4.9
4.8
4.7
4.6
4.2
7
6
5.0
5.0
5.0
4.6
4.2
9
8
5.1
5.0
5.0
4.6
4.2
11
10
5.3
5.1
5.0
4.6
4.2
13
12
5.4
5.2
5.0
4.6
4.2
15
14
5.6
5.2
5.0
4.6
4.2
-7
-7.5
4.5
4.4
4.3
4.2
4.2
-5
-5.5
4.7
4.7
4.5
4.4
4.4
-3
-3.6
5.0
4.9
4.8
4.7
4.6
0
-1
5.2
5.2
5.0
5.0
4.9
3
2
5.5
5.4
5.3
5.2
4.9
5
4
5.7
5.6
5.6
5.3
4.9
7
6
6.0
5.9
5.8
5.3
4.9
9
8
6.1
6.0
5.8
5.3
4.9
11
10
6.3
6.1
5.8
5.3
4.9
13
12
6.5
6.2
5.8
5.3
4.9
15
14
6.7
6.2
5.8
5.3
4.9
-7
-7.5
5.3
5.2
5.0
5.0
4.9
-5
-5.5
5.5
5.5
5.3
5.2
5.2
-3
-3.6
5.8
5.8
5.6
5.5
5.4
0
-1
6.1
6.0
5.9
5.8
5.7
3
2
6.4
6.3
6.2
6.1
5.7
5
4
6.7
6.6
6.5
6.3
5.7
7
6
7.0
6.9
6.8
6.3
5.7
9
8
7.2
7.0
6.8
6.3
5.7
11
10
7.4
7.1
6.8
6.3
5.7
13
12
7.6
7.2
6.8
6.3
5.7
15
14
7.8
7.3
6.8
6.3
5.7
-7
-7.5
6.3
6.3
6.1
6.0
5.9
-5
-5.5
6.7
6.6
6.4
6.3
6.3
-3
-3.6
7.0
6.9
6.7
6.6
6.5
0
-1
7.4
7.3
7.1
7.0
6.9
3
2
7.7
7.6
7.5
7.3
6.9
5
4
8.1
8.0
7.9
7.5
6.9
7
6
8.4
8.3
8.2
7.5
6.9
9
8
8.7
8.4
8.2
7.5
6.9
11
10
8.9
8.6
8.2
7.5
6.9
13
12
9.2
8.7
8.2
7.5
6.9
15
14
9.5
8.8
8.2
7.5
6.9
HEATING PERFORMANCE DATA - CEILING CONCEALED INDOOR UNITS
Indoor Unit
Model
YDCC095
YDCC115
YDCC140
YDCC175
Outdoor ambient temp.
Indoor ambient temp.(DB°C)
16
18
20
22
24
(°C,DB)
(°C,WB)
kW
kW
kW
kW
kW
-7
-7.5
8.5
8.5
8.1
8.0
7.9
-5
-5.5
8.9
8.9
8.6
8.5
8.5
-3
-3.6
9.4
9.3
9.0
8.8
8.8
0
-1
9.8
9.7
9.5
9.4
9.3
3
2
10.3
10.2
10.1
9.8
9.3
5
4
10.8
10.7
10.5
10.1
9.3
7
6
11.2
11.1
11.0
10.1
9.3
9
8
11.6
11.3
11.0
10.1
9.3
11
10
11.9
11.5
11.0
10.1
9.3
13
12
12.3
11.7
11.0
10.1
9.3
15
14
12.6
11.8
11.0
10.1
9.3
-7
-7.5
10.1
9.9
9.6
9.5
9.3
-5
-5.5
10.6
10.5
10.2
10.0
9.9
-3
-3.6
11.2
11.0
10.7
10.5
10.4
0
-1
11.7
11.6
11.2
11.1
10.9
3
2
12.2
12.1
11.9
11.6
10.9
5
4
12.8
12.6
12.5
12.0
10.9
7
6
13.3
13.2
13.0
12.0
10.9
9
8
13.8
13.4
13.0
12.0
10.9
11
10
14.2
13.6
13.0
12.0
10.9
13
12
14.6
13.8
13.0
12.0
10.9
15
14
15.0
14.0
13.0
12.0
10.9
-7
-7.5
14.5
14.5
14.5
14.4
14.4
-5
-5.5
15.1
15.1
15.0
15.0
14.4
-3
-3.6
15.7
15.7
15.6
15.4
14.4
0
-1
16.7
16.6
16.5
15.4
14.4
3
2
17.6
17.6
16.5
15.4
14.4
5
4
18.2
17.6
16.5
15.4
14.4
7
6
18.6
17.6
16.5
15.4
14.4
9
8
18.6
17.6
16.5
15.4
14.4
11
10
18.6
17.6
16.5
15.4
14.4
13
12
18.6
17.6
16.5
15.4
14.4
15
14
18.6
17.6
16.5
15.4
14.4
-7
-7.5
16.7
16.6
16.6
16.6
16.6
-5
-5.5
17.4
17.4
17.3
17.3
16.6
-3
-3.6
18.1
18.1
18.0
17.8
16.6
0
-1
19.2
19.2
19.0
17.8
16.6
3
2
20.3
20.2
19.0
17.8
16.6
5
4
21.0
20.2
19.0
17.8
16.6
7
6
21.4
20.2
19.0
17.8
16.6
9
8
21.4
20.2
19.0
17.8
16.6
11
10
21.4
20.2
19.0
17.8
16.6
13
12
21.4
20.2
19.0
17.8
16.6
15
14
21.4
20.2
19.0
17.8
16.6
95
Fan Performance Data - Ducted Indoor Units
EXTERNAL PRESSURE SETTING
Ceiling concealed type indoor units have 5 speed settings on the indoor control board. User can adjust and select the 3
speeds for High/Middle/Low fan speed according to the external static pressure. Out factory state, YDCC indoor unit ESP
(External static pressure) default setting is 15Pa. Please adjust the wring to set the ESP as per demand. You can select three
speeds (High/Mid/Low) from five.
Three cable colors Red, Brown, Black connected with the control board, stand for motor speed for Low, Mid and High
speed. The table below is for recommendation purposes only.
5
Indoor Models
0Pa
YDCC018-053
Red
15Pa
Fan wiring board post code
4
3
2
Brown
Black
Red
Brown
Black
Red
Brown
30Pa
YDCC066YDCC115
15Pa
Red
40Pa
Black
Red
Brown
Black
Red
Brown
80Pa
15Pa
YDCC140-175
Brown
Red
50Pa
Brown
Black
Red
Brown
Black
Red
Brown
100Pa
1
Black
Black
Black
FAN PERFORMANCE CURVES – YDCC018
YDCC018
Static
Pressure(Pa)
Fan Speed
setting
96
FAN PERFORMANCE CURVES – YDCC020
Air Flow (m3/h)
0
15
30
5
203
164
133
4
300
246
202
3
396
329
273
2
445
380
337
1
500
445
391
YDCC020
Static
Pressure(Pa)
Fan Speed
setting
Air Flow (m3/h)
0
15
30
5
203
164
133
4
300
246
202
3
396
329
273
2
445
397
337
1
500
445
391
FAN PERFORMANCE CURVES – YDCC025
YDCC025
Static
Pressure(Pa)
Fan Speed
setting
Air Flow (m3/h)
0
15
30
5
254
208
169
4
341
280
238
3
441
362
297
2
537
464
394
1
597
531
465
FAN PERFORMANCE CURVES – YDCC045
YDCC045
Static
Pressure(Pa)
Fan Speed
setting
FAN PERFORMANCE CURVES – YDCC034
YDCC034
Static
Pressure(Pa)
Fan Speed
setting
15
30
5
442
358
290
4
565
480
394
3
725
653
555
2
873
735
662
1
980
872
736
0
15
30
5
326
261
209
4
438
375
305
3
588
546
448
2
703
601
550
1
789
707
596
FAN PERFORMANCE CURVES – YDCC053
Air Flow (m3/h)
0
Air Flow (m3/h)
YDCC053
Static
Pressure(Pa)
Fan Speed
setting
Air Flow (m3/h)
0
15
30
5
570
462
369
4
750
615
510
3
990
842
715
2
1165
993
854
1
1309
1112
990
97
FAN PERFORMANCE CURVES – YDCC066
YDCC066
Static
Pressure(Pa)
Fan Speed
setting
Air Flow (m3/h)
98
Air Flow (m3/h)
40
80
5
715
579
469
5
846
685
555
4
935
767
629
4
1038
851
698
3
1239
1028
854
3
1418
1177
977
2
1392
1240
1054
2
1593
1423
1210
1
1547
1377
1213
1
1770
1576
1445
YDCC095
Static
Pressure(Pa)
setting
YDCC078
Static
Pressure(Pa)
15
FAN PERFORMANCE CURVES – YDCC095
Fan Speed
FAN PERFORMANCE CURVES – YDCC078
Fan Speed
setting
15
40
80
FAN PERFORMANCE CURVES – YDCC115
YDCC115
Static
Pressure(Pa)
Air Flow (m3/h)
0
15
30
Air Flow (m3/h)
15
40
80
5
918
744
602
5
1086
880
713
4
1253
1027
843
4
1438
1179
967
3
1657
1375
1142
3
1963
1629
1352
2
1841
1648
1401
2
2066
1942
1651
1
2046
1821
1612
1
2222
2000
1748
Fan Speed
setting
FAN PERFORMANCE CURVES – YDCC140
YDCC140
Static
Pressure(Pa)
Fan Speed
setting
FAN PERFORMANCE CURVES – YDCC175
Air Flow (m3/h)
0
15
YDCC175
Static
Pressure(Pa)
30
Air Flow (m3/h)
0
15
30
5
1156
937
759
5
1357
1099
891
4
1531
1255
1029
4
1797
1474
1209
3
2090
1735
1440
3
2453
2036
1690
2
2300
2068
1757
2
2700
2427
2063
1
2366
2129
1861
1
2777
2499
2185
Fan Speed
setting
Wiring Diagrams - Ducted Indoor Units
WIRING DIAGRAMS - CEILING CONCEALED INDOOR UNITS
YDCC018 TO 115
99
WIRING DIAGRAMS - CEILING CONCEALED INDOOR UNITS
100
YDCC 140 & 175
Cassette Type Indoor Units
CASSETTE INDOOR UNITS
STANDARD UNIT & OPTIONS
MAIN FEATURE OF CASSETTE INDOOR UNITS
Item
Standard
offer
Option
Remark
Wire
controller
has a
1
receiver
Controller
to receive
2
EXV BOX
3
Filter
Wired
Wireless
controller is
controller is as
standard
Built-in EXV is
an option.
standard.
Nylon filter is
standard offer
signal from
wireless
No option
No option
aluminum fins. Each coil is thoroughly pressure tested at
factory to detect any leaks. The condensate drain pan is
constructed from foam. Evaporator fans are centrifugal
type with direct drive three speed class B insulation and
IP 20 type motor that can be accessed from the bottom
panel. They are statically and dynamically balanced for quiet
operation. The fan motors are of permanently lubricated type
with auto reset thermal overload protection as standard.
Ceiling Cassette Indoor fan coil units are available with
nominal capacity range of 2.8 to 13kW. Units are factory
assembled including coil, electronic expansion valve,
condensate drain pan, condensate water pump, fan motor,
filters, mounting brackets and controls in an insulated casing.
Unit casing are constructed of GI steel and integrated with
fresh air inlet. Casing is insulated with foam. Knockouts
are provided for electrical power and refrigerant piping
connections. Panels are fastened with screws for ease of
service and cleaning.
Evaporator coils are constructed of copper tube and
All fan motors are resilient mounted to minimize vibration
and noise and are of permanent split capacitor type for high
efficiency. All units are provided with nylon filters that are
easily accessible from the bottom of the unit.
Wired control are available as standard. The controls shall
be microprocessor based and provide for a user interface.
The controls shall provide compressor delay protection, anti
ice sensor for indoor units, 3 speed fan control, and auto fan
function. Room temperature setting and display is available.
Auto restart to default setting, clock and timer functions
are included. Units are tested and rated in accordance with
China GB standards.
PIPING SYSTEM DIAGRAM OF CASSETTE INDOOR UNITS
Notes:
• Tlair: Room temperature (Air return temperature)
• EXV: Electrical expansion valve
• Tin: Coil inlet temperature in cooling mode
• Heater: Electric heater, only available in heat pump model as an option.
• Tout: Coil outlet temperature in cooling mode
101
Physical Data - Cassette Type Indoor Units
DATA SHEET – CASSETTE INDOOR UNITS
Model
YDCK036
H0NNEA0C3
YDCK046
H0NNEA0C3
YDCK090
H0NNEA0C3
YDCK072
H0NNEA0C3
YDCK056
H0NNEA0C3
YDCK130
H0NNEA0C3
YDCK110
H0NNEA0C3
Cooling Capacity
kW
2.8
3.6
4.6
5.6
7.2
9
11
13
Heating Capacity*
kW
3.2
4
5
6.3
8.2
10
13.5
15
Power supply
V/Ph/Hz
Air Flow Rate**
m3/h
510
750
750
1000
1360
1550
2040
2380
Number of
Blade
Number of
Motor
Power
Fan
consumption
Operating
Current
External Static Pressure
(ESP)
Control method
Dimension
220V/~/50Hz
-
1
-
1
W
45
70
90
115
160
230
240
A
0.2
0.32
0.41
0.52
0.85
1.05
1.09
Pa
0
-
remote control or wire control
Height
mm
Width
mm
570
730
930
Length
mm
570
730
930
mm
650×650×28
850×850×28
1050×1050×28
Panel Dimension (Width×
Height×Depth)
Machine Weight
kg
Liquid Pipe
mm
Connecting
Gas Pipe
mm
Pipes
Drainage
Pipe
102
YDCK028
H0NNEA0C3
mm
250
30
290
31.5
32
42
6.35
9.52
43
60
9.52
12.7
15.88
19.05 (O.D)
Cooling Performance - Cassette Type Indoor Units
COOLING PERFORMANCE DATA - CASSETTE INDOOR UNITS
Indoor
Unit
Model
YDCK028
YDCK036
Outdoor
ambient
temp.
(DB°C)
14 WB
20 DB
16 WB
23 DB
Indoor ambient temp.(°C)
18 WB
19 WB
20 WB
26 DB
27 DB
28 DB
22 WB
30 DB
24 WB
32 DB
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
KW
kW
kW
10
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
2.0
3.4
2.0
3.5
1.9
12
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
2.0
3.3
2.0
3.5
1.9
14
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
2.0
3.3
2.0
3.4
1.9
16
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.3
2.0
3.4
1.9
18
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.3
2.0
3.4
1.9
20
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.3
2.0
3.4
1.9
21
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.3
2.0
3.4
1.9
23
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.2
1.9
3.3
1.8
25
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.2
1.9
3.3
1.8
27
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
1.9
3.1
1.9
3.2
1.8
29
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
3.0
2.0
3.1
1.9
3.2
1.8
31
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
2.9
2.0
3.0
1.8
3.1
1.8
33
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
2.9
2.0
3.0
1.8
3.0
1.7
35
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
2.8
1.9
2.9
1.8
3.0
1.7
37
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
2.8
1.9
2.9
1.8
2.9
1.7
39
2.0
1.6
2.3
1.8
2.6
1.9
2.8
2.0
2.7
1.9
2.8
1.7
2.9
1.7
42
2.0
1.6
2.3
1.8
2.6
1.9
2.7
1.9
2.7
1.8
2.8
1.7
2.8
1.7
44
2.0
1.6
2.3
1.8
2.6
1.9
2.7
1.9
2.6
1.8
2.7
1.7
2.8
1.7
46
1.9
1.5
2.2
1.8
2.5
1.8
2.5
1.8
2.5
1.8
2.6
1.7
2.7
1.7
48
1.9
1.5
2.2
1.7
2.4
1.8
2.4
1.7
2.5
1.7
2.5
1.6
2.5
1.6
50
1.8
1.5
2.1
1.7
2.2
1.7
2.2
1.7
2.2
1.6
2.2
1.5
2.2
1.4
52
1.8
1.5
2.0
1.6
2.0
1.5
2.0
1.5
2.0
1.4
2.0
1.3
2.0
1.3
10
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.9
2.7
4.4
2.7
4.5
2.6
12
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.9
2.7
4.3
2.7
4.5
2.6
14
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.9
2.7
4.3
2.7
4.4
2.6
16
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.9
2.7
4.3
2.7
4.4
2.6
18
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
4.3
2.7
4.4
2.6
20
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
4.2
2.6
4.4
2.5
21
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
4.2
2.6
4.3
2.5
23
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
4.1
2.6
4.2
2.5
25
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
4.1
2.5
4.2
2.4
27
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
4.0
2.5
4.1
2.4
29
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.7
3.9
2.4
4.1
2.4
31
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.8
2.6
3.9
2.5
4.0
2.3
33
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.7
2.6
3.8
2.4
3.9
2.3
35
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.7
2.5
3.8
2.4
3.9
2.3
37
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.7
3.6
2.5
3.7
2.4
3.8
2.3
39
2.5
2.1
2.9
2.3
3.4
2.5
3.5
2.7
3.5
2.5
3.6
2.3
3.7
2.2
42
2.5
2.1
2.9
2.3
3.4
2.5
3.5
2.6
3.5
2.4
3.6
2.3
3.7
2.2
44
2.5
2.1
2.9
2.3
3.3
2.4
3.4
2.6
3.4
2.4
3.5
2.3
3.6
2.2
46
2.5
2.1
2.8
2.2
3.2
2.4
3.2
2.5
3.3
2.3
3.4
2.3
3.5
2.2
48
2.4
2.0
2.8
2.2
3.1
2.3
3.0
2.4
3.2
2.3
3.2
2.2
3.2
2.1
50
2.4
2.0
2.7
2.2
2.9
2.2
2.9
2.3
2.9
2.1
2.9
2.0
2.9
1.9
52
2.3
2.0
2.5
2.0
2.5
1.9
2.5
2.0
2.5
1.8
2.5
1.8
2.5
1.7
103
Indoor
Unit
Model
YDCK046
YDCK056
YDCK072
104
Outdoor
ambient
temp.
(DB°C)
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
14 WB
20 DB
TC
SHC
kW
kW
16 WB
23 DB
TC
SHC
kW
kW
Indoor ambient temp.(°C)
18 WB
19 WB
20 WB
26 DB
27 DB
28 DB
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
22 WB
30 DB
TC
SHC
kW
KW
24 WB
32 DB
TC
SHC
kW
kW
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.1
3.0
3.0
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.8
3.8
3.7
3.6
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
4.9
4.8
4.7
4.6
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.6
3.6
3.5
3.2
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.4
4.3
4.2
3.9
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.8
5.7
5.6
5.5
5.0
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.2
4.1
4.0
3.7
3.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.1
5.0
4.8
4.5
3.9
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.7
6.6
6.4
6.2
5.8
5.0
5.6
5.5
5.5
5.5
5.5
5.4
5.4
5.3
5.2
5.1
5.0
5.0
4.9
4.8
4.7
4.6
4.5
4.5
4.3
4.1
3.7
3.2
6.8
6.7
6.7
6.7
6.7
6.6
6.5
6.4
6.3
6.2
6.1
6.0
5.9
5.8
5.7
5.6
5.5
5.4
5.2
5.0
4.5
3.9
8.7
8.6
8.6
8.6
8.6
8.5
8.4
8.3
8.2
8.0
7.9
7.8
7.6
7.5
7.4
7.2
7.1
7.0
6.7
6.5
5.8
5.0
5.8
5.8
5.7
5.7
5.7
5.6
5.5
5.4
5.4
5.3
5.2
5.1
5.0
4.9
4.8
4.8
4.7
4.6
4.4
4.1
3.7
3.2
7.0
7.0
6.9
6.9
6.9
6.8
6.7
6.6
6.5
6.4
6.3
6.2
6.1
6.0
5.9
5.8
5.7
5.6
5.4
5.0
4.5
3.9
9.0
9.0
8.9
8.9
8.8
8.7
8.6
8.5
8.4
8.2
8.1
8.0
7.8
7.7
7.6
7.4
7.3
7.2
6.9
6.5
5.8
5.0
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.6
2.6
2.5
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.5
3.5
3.4
3.4
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.5
4.4
4.4
4.3
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.8
2.8
2.6
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.8
3.7
3.7
3.6
3.4
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.8
4.7
4.7
4.3
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.1
3.0
3.0
2.8
2.4
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.0
4.0
3.7
3.3
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.3
5.2
5.1
4.8
4.2
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.6
4.5
4.4
4.4
4.1
3.9
3.7
3.2
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.5
5.4
5.3
5.0
4.7
4.5
3.9
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.1
6.9
6.9
6.5
6.1
5.8
5.0
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.4
3.3
3.3
3.2
3.0
2.9
2.5
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.3
4.3
4.1
3.9
3.7
3.3
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.6
5.5
5.5
5.2
5.0
4.7
4.2
5.0
5.0
5.0
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.9
4.8
4.8
4.7
4.6
4.5
4.4
4.3
4.2
4.1
3.7
3.2
6.1
6.1
6.1
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
5.9
5.8
5.7
5.6
5.5
5.4
5.3
5.1
5.0
4.5
3.9
7.9
7.8
7.8
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.6
7.4
7.3
7.2
7.1
6.9
6.8
6.5
6.4
5.8
5.0
3.5
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.3
3.3
3.2
3.2
3.1
3.1
3.1
3.0
2.9
2.7
2.3
4.5
4.5
4.5
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.4
4.3
4.2
4.1
4.1
4.1
4.0
3.9
3.8
3.4
3.0
5.8
5.8
5.8
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.6
5.5
5.4
5.3
5.3
5.2
5.2
5.0
4.9
4.4
3.9
3.4
3.4
3.4
3.4
3.4
3.3
3.3
3.3
3.2
3.2
3.1
3.2
3.1
3.0
3.0
3.0
3.0
3.0
2.9
2.8
2.6
2.3
4.4
4.4
4.4
4.4
4.4
4.3
4.3
4.2
4.1
4.2
4.1
4.1
4.0
3.9
4.0
3.9
3.9
3.9
3.8
3.7
3.4
3.0
5.7
5.6
5.6
5.6
5.6
5.5
5.5
5.4
5.3
5.3
5.3
5.2
5.1
5.1
5.1
5.0
5.0
5.0
4.9
4.8
4.3
3.8
3.3
3.3
3.3
3.3
3.3
3.2
3.2
3.2
3.1
3.1
3.0
3.0
2.9
3.0
2.9
2.9
2.8
2.8
2.8
2.7
2.4
2.1
4.3
4.3
4.3
4.3
4.3
4.2
4.2
4.1
4.1
4.0
4.0
3.9
3.9
3.8
3.9
3.8
3.8
3.8
3.7
3.5
3.2
2.8
5.6
5.6
5.5
5.5
5.5
5.4
5.4
5.3
5.2
5.2
5.1
5.1
5.0
4.9
5.0
4.9
4.9
4.8
4.7
4.5
4.1
3.6
Indoor
Unit
Model
YDCK90
YDCK110
YDCK130
Outdoor
ambient
temp.
(DB°C)
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
10
12
14
16
18
20
21
23
25
27
29
31
33
35
37
39
42
44
46
48
50
52
14 WB
20 DB
TC
SHC
kW
kW
16 WB
23 DB
TC
SHC
kW
kW
Indoor ambient temp.(°C)
18 WB
19 WB
20 WB
26 DB
27 DB
28 DB
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
22 WB
30 DB
TC
SHC
kW
KW
24 WB
32 DB
TC
SHC
kW
kW
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.2
6.1
5.9
5.8
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.7
7.6
7.4
7.2
7.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
9.1
8.9
8.7
8.6
8.4
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.1
7.0
6.8
6.3
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.9
8.7
8.5
8.3
7.7
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.5
10.3
10.0
9.8
9.1
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.3
8.0
7.8
7.2
6.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.1
9.7
9.5
8.8
7.7
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
12.1
11.9
11.5
11.2
10.4
9.1
10.9
10.8
10.8
10.8
10.8
10.6
10.5
10.4
10.2
10.0
9.9
9.7
9.5
9.4
9.2
9.1
8.9
8.7
8.4
8.1
7.2
6.3
13.3
13.2
13.2
13.2
13.2
13.0
12.9
12.7
12.5
12.3
12.1
11.9
11.7
11.5
11.3
11.1
10.9
10.7
10.3
9.9
8.8
7.7
15.7
15.5
15.5
15.5
15.5
15.3
15.2
15.0
14.7
14.5
14.3
14.0
13.8
13.6
13.3
13.1
12.8
12.6
12.1
11.7
10.4
9.1
11.3
11.3
11.1
11.1
11.1
10.9
10.8
10.6
10.5
10.3
10.1
10.0
9.8
9.6
9.5
9.3
9.1
9.0
8.6
8.1
7.2
6.3
13.8
13.8
13.5
13.5
13.5
13.3
13.2
13.0
12.8
12.6
12.4
12.2
12.0
11.8
11.6
11.4
11.2
11.0
10.6
9.9
8.8
7.7
16.3
16.3
16.0
16.0
16.0
15.7
15.6
15.4
15.1
14.9
14.6
14.4
14.2
13.9
13.7
13.4
13.2
13.0
12.5
11.7
10.4
9.1
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.1
5.0
5.0
4.9
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.6
6.5
6.4
6.3
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
7.8
7.7
7.6
7.5
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.5
5.4
5.4
5.0
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.2
7.1
7.0
6.5
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.6
8.5
8.4
8.2
7.6
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
5.9
5.8
5.4
4.8
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.8
7.6
7.5
7.0
6.1
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.4
9.3
9.0
8.8
8.2
7.3
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
8.9
8.7
8.6
8.1
7.6
7.2
6.3
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
11.0
10.8
10.6
10.5
9.9
9.3
8.8
7.7
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
13.0
12.8
12.5
12.4
11.7
10.9
10.4
9.1
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.4
6.2
6.2
6.0
5.6
5.4
4.8
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.4
8.3
8.1
8.1
7.7
7.3
7.0
6.2
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.9
9.8
9.6
9.6
9.1
8.7
8.3
7.3
9.8
9.7
9.7
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.6
9.4
9.3
9.1
9.0
8.8
8.7
8.5
8.2
8.0
7.2
6.3
12.0
11.9
11.9
11.8
11.7
11.7
11.7
11.7
11.7
11.7
11.7
11.5
11.4
11.2
11.0
10.8
10.6
10.4
10.0
9.8
8.8
7.7
14.2
14.0
14.0
13.9
13.9
13.9
13.9
13.9
13.9
13.9
13.9
13.6
13.4
13.2
13.0
12.7
12.5
12.3
11.8
11.5
10.4
9.1
6.6
6.5
6.5
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.4
6.3
6.2
6.1
6.1
6.0
6.0
5.9
5.7
5.6
5.1
4.5
8.5
8.5
8.5
8.4
8.3
8.3
8.3
8.3
8.3
8.3
8.4
8.3
8.2
8.0
7.9
7.8
7.7
7.6
7.4
7.2
6.6
5.8
10.1
10.0
10.0
9.9
9.9
9.9
9.9
9.9
9.9
9.9
10.0
9.8
9.7
9.5
9.3
9.2
9.1
9.0
8.7
8.5
7.7
6.8
6.6
6.6
6.6
6.6
6.6
6.5
6.4
6.3
6.2
6.1
6.1
6.0
5.9
5.8
5.8
5.7
5.7
5.7
5.5
5.4
4.9
4.4
8.5
8.4
8.4
8.4
8.4
8.3
8.2
8.1
8.0
7.8
7.9
7.8
7.7
7.5
7.5
7.4
7.4
7.4
7.2
7.1
6.4
5.7
10.0
9.9
9.9
9.9
9.9
9.8
9.7
9.6
9.4
9.2
9.3
9.2
9.1
8.9
8.9
8.7
8.7
8.7
8.5
8.3
7.5
6.7
6.3
6.3
6.3
6.3
6.2
6.1
6.1
6.0
6.0
5.9
5.8
5.7
5.6
5.7
5.6
5.5
5.5
5.5
5.4
5.1
4.6
4.1
8.2
8.2
8.1
8.1
8.1
8.0
7.9
7.8
7.7
7.6
7.5
7.5
7.3
7.2
7.3
7.2
7.2
7.1
7.0
6.7
6.0
5.4
9.7
9.7
9.5
9.6
9.6
9.4
9.3
9.2
9.1
8.9
8.9
8.8
8.7
8.5
8.6
8.5
8.5
8.4
8.3
7.9
7.1
6.3
105
Heating Performance - Cassette Type Indoor Units
HEATING PERFORMANCE DATA - CASSETTE INDOOR UNITS
Indoor ambient temp.(DB°C)
Indoor ambient temp.(DB°C)
Indoor Outdoor ambient
temp.
Unit
Model (°C,DB) (°C,WB)
16
18
20
22
24
kW
kW
kW
kW
kW
-7
-7.5
2.8
2.8
2.8
2.8
2.8
-7
-7.5
7.2
7.2
7.2
7.2
7.2
-5
-5.5
2.9
2.9
2.9
2.9
2.8
-5
-5.5
7.5
7.5
7.5
7.5
7.2
-3
-3.6
3.1
3.1
3.0
3.0
2.8
-3
-3.6
7.8
7.8
7.8
7.7
7.2
0
-1
3.2
3.2
3.2
3.0
2.8
0
-1
8.3
8.3
8.2
7.7
7.2
3
2
3.4
3.4
3.2
3.0
2.8
3
2
8.8
8.7
8.2
7.7
7.2
5
4
3.5
3.4
3.2
3.0
2.8
5
4
9.1
8.7
8.2
7.7
7.2
7
6
3.6
3.4
3.2
3.0
2.8
7
6
9.2
8.7
8.2
7.7
7.2
9
8
3.6
3.4
3.2
3.0
2.8
9
8
9.2
8.7
8.2
7.7
7.2
11
10
3.6
3.4
3.2
3.0
2.8
11
10
9.2
8.7
8.2
7.7
7.2
13
12
3.6
3.4
3.2
3.0
2.8
13
12
9.2
8.7
8.2
7.7
7.2
15
14
3.6
3.4
3.2
3.0
2.8
15
14
9.2
8.7
8.2
7.7
7.2
-7
-7.5
3.5
3.5
3.5
3.5
3.5
-7
-7.5
8.8
8.7
8.7
8.7
8.7
-5
-5.5
3.7
3.7
3.6
3.6
3.5
-5
-5.5
9.2
9.2
9.2
9.2
8.7
-3
-3.6
3.8
3.8
3.8
3.7
3.5
-3
-3.6
9.5
9.5
9.5
9.4
8.7
0
-1
4.0
4.0
4.0
3.7
3.5
0
-1
10.1
10.1
10.0
9.4
8.7
3
2
4.3
4.3
4.0
3.7
3.5
3
2
10.6
10.6
10.0
9.4
8.7
5
4
4.4
4.3
4.0
3.7
3.5
5
4
11.1
10.6
10.0
9.4
8.7
7
6
4.5
4.3
4.0
3.7
3.5
7
6
11.3
10.6
10.0
9.4
8.7
YDCK028
YDCK036
YDCK046
YDCK056
106
Indoor
Unit
Model
YDCK072
YDCK090
Outdoor ambient
(°C,DB) (°C,WB)
16
18
20
22
24
kW
kW
kW
kW
kW
9
8
4.5
4.3
4.0
3.7
3.5
9
8
11.3
10.6
10.0
9.4
8.7
11
10
4.5
4.3
4.0
3.7
3.5
11
10
11.3
10.6
10.0
9.4
8.7
13
12
4.5
4.3
4.0
3.7
3.5
13
12
11.3
10.6
10.0
9.4
8.7
15
14
4.5
4.3
4.0
3.7
3.5
15
14
11.3
10.6
10.0
9.4
8.7
-7
-7.5
4.4
4.4
4.4
4.4
4.4
-7
-7.5
11.9
11.8
11.8
11.8
11.8
-5
-5.5
4.6
4.6
4.6
4.6
4.4
-5
-5.5
12.4
12.4
12.3
12.3
11.8
-3
-3.6
4.8
4.8
4.8
4.7
4.4
-3
-3.6
12.9
12.9
12.8
12.6
11.8
0
-1
5.1
5.0
5.0
4.7
4.4
0
-1
13.7
13.6
13.5
12.6
11.8
3
2
5.3
5.3
5.0
4.7
4.4
3
2
14.4
14.4
13.5
12.6
11.8
5
4
5.5
5.3
5.0
4.7
4.4
5
4
14.9
14.4
13.5
12.6
11.8
7
6
5.6
5.3
5.0
4.7
4.4
7
6
15.2
14.4
13.5
12.6
11.8
9
8
5.6
5.3
5.0
4.7
4.4
9
8
15.2
14.4
13.5
12.6
11.8
11
10
5.6
5.3
5.0
4.7
4.4
11
10
15.2
14.4
13.5
12.6
11.8
13
12
5.6
5.3
5.0
4.7
4.4
13
12
15.2
14.4
13.5
12.6
11.8
15
14
5.6
5.3
5.0
4.7
4.4
15
14
15.2
14.4
13.5
12.6
11.8
-7
-7.5
7.2
7.2
7.2
7.2
7.2
-7
-7.5
13.2
13.2
13.2
13.1
13.1
-5
-5.5
6.9
6.9
6.9
6.9
7.2
-5
-5.5
13.7
13.7
13.7
13.7
13.1
-3
-3.6
6.6
6.6
6.6
6.8
7.2
-3
-3.6
14.3
14.3
14.3
14.0
13.1
0
-1
6.2
6.3
6.3
6.8
7.2
0
-1
15.2
15.1
15.0
14.0
13.1
3
2
5.9
5.9
6.3
6.8
7.2
3
2
16.1
16.0
15.0
14.0
13.1
5
4
5.7
5.9
6.3
6.8
7.2
5
4
16.6
16.0
15.0
14.0
13.1
7
6
5.6
5.9
6.3
6.8
7.2
7
6
16.9
16.0
15.0
14.0
13.1
YDCK110
YDCK130
9
8
5.6
5.9
6.3
6.8
7.2
9
8
16.9
16.0
15.0
14.0
13.1
11
10
5.6
5.9
6.3
6.8
7.2
11
10
16.9
16.0
15.0
14.0
13.1
13
12
5.6
5.9
6.3
6.8
7.2
13
12
16.9
16.0
15.0
14.0
13.1
15
14
5.6
5.9
6.3
6.8
7.2
15
14
16.9
16.0
15.0
14.0
13.1
Dimensional Data - Cassette Type Indoor Units
LAYOUT & DIMENSIONS - CASSETTE INDOOR UNITS
Models
A(mm)
B(mm)
Models
L
S
H
H1
H2
H3
H4
H5
YDCK028/036/046
650
650
YDCK028/036
570
570
278
250
125
148
183
205
YDCK056/072/090
850
850
YDCK046
570
570
318
290
145
188
223
245
YDCK110/130
1050
1050
YDCK056/072/090
730
730
318
290
145
188
223
245
YDCK110/130
930
930
318
290
145
188
223
245
Models
Dimensions for
Opening
A (mm.) B (mm.)
Suspension Bolt
C (mm.)
D (mm.)
YDCK028/036/046
570
570
616
280
YDCK056/072/090
730
730
776
440
YDCK110/130
930
930
976
640
107
Wiring Diagrams
WIRING DIAGRAM - CASSETTE TYPE INDOOR UNITS
Wall Mounted Indoor Units
WALL MOUNTED INDOOR UNITS
MAIN FEATURE
Wall mounted indoor fan coil units are available with nominal
capacities of 3.2, 5.3 and 7 kW. Units are factory assembled
including coil, condensate drain pan, fan motor, filters,
mounting brackets and controls in an insulated casing.
Unit casing are constructed from plastic. Casing is insulated
with foam. Knockouts are provided for electrical power and
refrigerant piping connections. Panels are fastened with
screws for ease of service and cleaning.
Evaporator coils are constructed of copper tube and
aluminum fins. Each coil is thoroughly pressure tested at
factory to detect any leaks. The condensate drain pan is
constructed from foam.
Evaporator fans are tangential type with direct drive three
speed class B insulation and IP 20 type motor that can
be accessed from the front panel. They are statically and
dynamically balanced for quiet operation. The fan motors
are of permanently lubricated type with auto reset thermal
overload protection as standard. All fan motors are resilient
mounted to minimize vibration and noise and are of
permanent split capacitor type for high efficiency.
All units are provided with nylon filters that are easily
108
accessible from the front panel. Wireless remote control are
available as standard.
Units are tested and rated in accordance with China GB
standards.
STANDARD UNIT & OPTIONS
Standard
offer
Item
Option
Remark
The indoor
1
Controller
unit has
No option
receiver on
the panel
Wireless
controller is
standard
2
3
EXV BOX
Filter
External EXV
is standard
Nylon filter is
standard offer
Built-in EXV
No option
not available
as an option
No option
LAYOUT & DIMENSIONS
Model
W (mm)
H (mm)
D (mm)
YDHW032
1080
330
220
YDHW053
1080
330
220
YDHW070
1080
330
220
109
Physical Data & Piping - Wall Mounted Indoor Units
DATA SHEET
YDHW032HONNOA-0C3
YDHW053HONNOA-0C3
Cooling Capacity
Model
kW
3.2
5.3
7
Heating Capacity
kW
3.7
5.7
7.5
Power supply
V/Ph/Hz
Air Flow Rate**
m3/h
Number of
Blade
Number of
Fan
Motor
Power
consumption
Operating
220V/~/50Hz
600
800
-
1
-
1
60
60
70
A
0.3
0.3
0.35
External Static Pressure
Pa
0
Control method
-
remote control
Width
mm
1080
Height
mm
330
Depth
mm
220
Machine Weight
kg
15
Connecting
Liquid Pipe
mm
6.35
Pipes
Gas Pipe
mm
12.7
PIPING SYSTEM - WALL MOUNTED INDOOR UNITS
Notes
• Tlair = Room temperature
(Air return temperature)
• Tin =
Coil inlet temperature in cooling mode
• Tout = Coil outlet temperature in cooling mode
• EXV = Electrical expansion valve
110
1100
W
Current
Dimension
YDHW070HONNOA-0C3
Cooling & Heating Performance -Wall Mounted
Indoor Units
COOLING PERFORMANCE DATA - WALL MOUNTED INDOOR UNITS
Indoor
Unit
Model
YDHW032
YDHW053
14WB
20CDB
TC
SHC
kW
kW
16WB
23DB
TC
SHC
kW
kW
Indoor ambient temp.(°C)
18WB
19WB
20WB
26DB
27DB
28DB
TC
SHC
TC
SHC
TC
SHC
kW
kW
kW
kW
kW
kW
22WB
30DB
TC
SHC
kW
kW
24WB
32DB
TC
SHC
kW
kW
10
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.5
2.4
3.9
2.4
4.0
2.3
12
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.5
2.4
3.8
2.3
4.0
2.3
14
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.5
2.4
3.8
2.3
3.9
2.3
16
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.8
2.3
3.9
2.3
18
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.8
2.3
3.9
2.3
20
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.8
2.3
3.9
2.2
21
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.7
2.3
3.8
2.2
23
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.7
2.3
3.8
2.2
25
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.6
2.2
3.7
2.2
27
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.6
2.2
3.7
2.1
29
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.5
2.2
3.6
2.1
31
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.4
2.3
3.5
2.2
3.5
2.1
33
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.3
2.3
3.4
2.1
3.5
2.0
35
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.2
2.2
3.3
2.1
3.4
2.0
37
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.4
3.2
2.2
3.3
2.1
3.4
2.0
39
2.2
1.9
2.6
2.0
3.0
2.2
3.2
2.3
3.1
2.2
3.2
2.1
3.3
2.0
42
2.2
1.9
2.6
2.0
3.0
2.2
3.1
2.3
3.1
2.2
3.2
2.1
3.3
1.9
44
2.2
1.9
2.6
2.0
2.9
2.2
3.1
2.3
3.0
2.1
3.1
2.1
3.2
1.9
46
2.2
1.9
2.5
2.0
2.8
2.1
2.9
2.2
2.9
2.1
3.0
2.0
3.1
1.9
48
2.2
1.8
2.5
1.9
2.8
2.1
2.7
2.1
2.8
2.0
2.9
2.0
2.9
1.8
50
2.1
1.8
2.4
1.9
2.6
2.0
2.6
2.0
2.6
1.8
2.6
1.8
2.6
1.6
52
2.1
1.8
2.2
1.8
2.2
1.7
2.2
1.7
2.2
1.6
2.2
1.6
2.2
1.5
10
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.8
3.9
6.4
3.9
6.6
3.8
12
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.3
3.9
6.6
3.8
14
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.3
3.9
6.5
3.7
16
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.3
3.9
6.5
3.7
18
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.3
3.9
6.5
3.7
20
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.2
3.8
6.4
3.7
21
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.2
3.8
6.4
3.7
23
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.1
3.7
6.3
3.6
25
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
6.0
3.7
6.2
3.6
27
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
5.9
3.6
6.1
3.5
29
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.7
3.9
5.8
3.6
6.0
3.4
31
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.6
3.8
5.7
3.6
5.9
3.4
33
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.5
3.7
5.6
3.5
5.8
3.3
35
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.4
3.7
5.5
3.5
5.7
3.3
37
3.7
3.2
4.3
3.3
5.0
3.7
5.3
3.9
5.3
3.7
5.4
3.5
5.6
3.3
39
3.7
3.2
4.3
3.3
5.0
3.7
5.2
3.9
5.2
3.6
5.3
3.4
5.5
3.2
42
3.7
3.2
4.3
3.3
5.0
3.7
5.1
3.8
5.1
3.6
5.2
3.4
5.4
3.2
44
3.7
3.2
4.3
3.3
4.9
3.6
5.1
3.8
5.0
3.5
5.1
3.4
5.3
3.2
46
3.6
3.1
4.2
3.3
4.7
3.5
4.8
3.6
4.8
3.4
5.0
3.3
5.1
3.2
48
3.6
3.0
4.1
3.2
4.6
3.5
4.5
3.4
4.7
3.3
4.8
3.3
4.8
3.0
50
3.5
3.0
4.0
3.2
4.2
3.2
4.2
3.3
4.2
3.0
4.2
2.9
4.2
2.7
52
3.4
2.9
3.7
2.9
3.7
2.8
3.7
2.9
3.7
2.7
3.7
2.6
3.7
2.4
Outdoor
ambient
temp.(DB°C)
111
COOLING PERFORMANCE DATA - WALL MOUNTED INDOOR UNITS
YDHW070
10
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.6
5.1
8.5
5.0
8.8
4.9
12
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.6
5.1
8.4
4.9
8.8
4.9
14
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.6
5.1
8.4
4.9
8.6
4.8
16
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
8.4
4.9
8.6
4.8
18
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
8.4
4.9
8.6
4.8
20
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
8.2
4.9
8.5
4.8
21
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
8.2
4.8
8.4
4.7
23
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
8.1
4.8
8.3
4.7
25
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
7.9
4.7
8.1
4.6
27
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
7.8
4.7
8.0
4.5
29
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.5
5.0
7.7
4.7
7.9
4.5
31
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.3
4.9
7.6
4.6
7.8
4.4
33
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.2
4.8
7.4
4.5
7.6
4.4
35
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.1
4.8
7.3
4.4
7.5
4.3
37
4.9
4.1
5.6
4.3
6.5
4.8
7.0
5.0
7.0
4.7
7.2
4.5
7.4
4.4
39
4.9
4.1
5.6
4.3
6.5
4.8
6.9
4.9
6.9
4.6
7.0
4.4
7.2
4.3
42
4.9
4.1
5.6
4.3
6.5
4.8
6.7
4.8
6.7
4.6
6.9
4.4
7.1
4.3
44
4.9
4.1
5.6
4.3
6.4
4.7
6.7
4.8
6.6
4.5
6.8
4.4
7.0
4.3
46
4.8
4.0
5.5
4.2
6.2
4.6
6.3
4.6
6.4
4.4
6.5
4.3
6.7
4.2
48
4.7
3.9
5.4
4.2
6.0
4.5
5.9
4.4
6.2
4.3
6.3
4.2
6.3
4.0
50
4.6
3.9
5.3
4.1
5.6
4.2
5.6
4.2
5.6
3.9
5.6
3.8
5.6
3.6
52
4.5
3.8
4.9
3.8
4.9
3.7
4.9
3.7
4.9
3.4
4.9
3.4
4.9
3.2
HEATING PERFORMANCE DATA - WALL MOUNTED INDOOR UNITS
Indoor Unit
Model
YDHW032
YDHW053
YDHW070
112
Outdoor ambient temp.
(°C,DB)
(°C,WB)
16
kW
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7
-5
-3
0
3
5
7
9
11
13
15
-7.5
-5.5
-3.6
-1
2
4
6
8
10
12
14
-7.5
-5.5
-3.6
-1
2
4
6
8
10
12
14
-7.5
-5.5
-3.6
-1
2
4
6
8
10
12
14
3.4
3.6
3.7
3.9
4.2
4.3
4.4
4.4
4.4
4.4
4.4
5
5.2
5.4
5.8
6.1
6.3
6.4
6.4
6.4
6.4
6.4
6.2
6.4
6.7
7.1
7.5
7.7
7.9
7.9
7.9
7.9
7.9
Indoor ambient temp.(DB°C)
18
20
22
kW
kW
kW
24
kW
3.4
3.6
3.7
3.9
4.1
4.1
4.1
4.1
4.1
4.1
4.1
5
5.2
5.4
5.7
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.4
6.7
7.1
7.4
7.4
7.4
7.4
7.4
7.4
7.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
3.4
5
5
5
5
5
5
5
5
5
5
5
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
6.1
3.4
3.6
3.7
3.9
3.9
3.9
3.9
3.9
3.9
3.9
3.9
5
5.2
5.4
5.7
5.7
5.7
5.7
5.7
5.7
5.7
5.7
6.1
6.4
6.6
7
7
7
7
7
7
7
7
3.4
3.6
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
3.7
5
5.2
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
6.1
6.4
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
6.6
Wiring Diagrams
WIRING DIAGRAMS - WALL MOUNTED INDOOR UNITS
Refrigerant Pipe Design
REFRIGERANT PIPE DESIGN & SELECTION
COMBINATION RATIO OF CAPACITY
In the Johnson Controls YORK® VRF System, the combination ratio should comply with the following condition
ΣRated cooling capacity of Indoor Units
50% ≤——-----———————————————--————≤ 130%
Rated cooling capacity of Outdoor Units
and ΣRated cooling capacity of Indoor Units × (using factor at the same time) ≤ Rated cooling capacity of Outdoor Units.
Note:
• is the using factor at the same time of indoor units, it’s the ratio that the max. total cooling capacity of indoor units could start at the same time.
• ΣRated cooling capacity of Indoor units on the premise of units normal operation.
• If the two conditions mentioned above are not met, then another effort at unit selection is necessary.
PERMITTED TUBING LENGTH AND HEIGHT DIFERENCE
113
Outdoor unit capacity (kW)
Maximum pipe length between
Maximum permitted pipe length
25.5~138 kW
Actual pipe length (m) =
150
a+b+c+d+e+f
Equivalent pipe length (m)
Elevation difference between
Outdoor above (m)
Outdoor below (m)
outdoor/indoor units = H1
Elevation difference between indoor units = H2 (m)
Equivalent pipe length between first branch and last indoor unit (m)
outdoor/indoor units
Max. Elevation difference
Permitted pipe length for final branch
175
50
40
15
≤40
EQUIVALENT PIPE LENGTH
Equivalent pipe length is the converted pipe length after considering the pressure loss caused by elbow etc.
Equivalent pipe length =
Actual pipe length + Quantity of elbow x (equivalent length of elbow) + Quantity of Oil bending x (equivalent length of
Oil bending) + Equivalent length of branch. Each branch junction accounts for 0.5meter equivalent length, each branch
converging pipe accounts for 1.0 meter equivalent length. When the Y-type equivalent pipe length exceeds 90% of
maximum permitted pipe length, the size for gas side main pipe should be increased by 1-size.
Example : For 16kW outdoor unit, when the equivalent pipe length exceeds 65 m, the size for gas pipe should be changed
from 22.23 mm to 25.40 mm. When the the size for gas side main pipe is increased by 1-size, the derating factor for
capacity drop will be reduced.
Refrigerant Pipe Design
Equivalent length conversion table of elbows and oil storage elbows
Tube diameter
9.52
12.70
15.88
19.05
22.23
25.40
28.58
31.75
34.90
38.10
41.30
54.10
Equivalent length of elbow
0.18
0.20
0.25
0.35
0.40
0.45
0.50
0.55
0.60
0.65
0.75
0.95
Equivalent length of oil storge elbow
1.3
1.5
2.0
2.4
3.0
3.4
3.7
4.0
4.4
5.0
5.4
7.0
1. PIPE SIZE SELECTION
Outdoor unit capacity
Liquid tube
Gas tube
After the
branch
tube
connected
to the total
capacity of
indoor unit
<31.5kW
Liquid tube 31.5~48kW
48~71kW
<16kW
16~26kW
Gas tube 26~31.5kW
31.5~41kW
41~71kW
After the
Liquid tube
branch
tube
connected
to the total
capacity of Gas tube
indoor unit
114
<6kW
>=6kW
<3kW
3~6kW
6~14kW
>=14kW
YDOH(C)80
YDOH(C)100
YDOH(C)120
YDOH(C)140
YDOH(C)160
YDOH(C)180
Between outdoor unit and the first branch tube
φ9.52*0.8
φ12.7*0.8
φ15.88*1.0
φ19.05*1.0
φ22.23*1.0
φ25.4*1.0
φ28.58*1.0
Between branch tube and branch tube
φ9.52*0.8
φ12.7*0.8
φ15.88*1.0
φ15.88*1.0
φ19.05*1.0
φ22.23*1.0
φ25.4*1.0
φ28.58*1.0
Between indoor unit and branch tube
φ6.35*0.8
φ9.52*0.8
φ9.52*0.8
φ12.7*0.8
φ15.88*1.0
φ19.05*1.0
Outdoor unit capacity
YDOH(C)200 YDOH(C)220 YDOH(C)240 YDOH(C)260-300 YDOH(C)320-340 YDOH(C)360-480
Between outdoor unit and the first branch tube
Liquid tube
φ15.88*1.0
Gas tube
φ28.58*1.0
φ19.05*1.0
φ34.9*1.3
φ38.1*1.14
Between parallel branch tube and branch tube
φ9.52*0.8
<31.5kW
Liquid
31.5~48kW
φ12.7*0.8
tube
48~71kW
φ15.88*1.0
branch tube
71~180kW
φ19.05*1.0
connected
<16kW
φ15.88*1.0
to the total
16~26kW
φ19.05*1.0
After the
capacity of
Gas
26~31.5kW
φ22.23*1.0
indoor unit
tube
31.5~71kW
φ28.58*1.0
φ34.90*1.3
71~104kW
104~180kW
-
-
φ38.1*1.4
-
Between indoor unit and branch tube
After the
Liquid
<6kW
φ6.35*0.8
branch tube
tube
>=6kW
φ9.52*0.8
<3kW
φ9.52*0.8
connected
to the total
Gas
3~6kW
φ12.7*0.8
capacity of
tube
6~14kW
φ15.88*1.0
>=14kW
φ19.05*1.0
indoor unit
Note:
When the equivalent pipe length between outdoor units and indoor units is 90m or more, the size of main pipes (both gas side and liquid side) must be increased
according to the following table.
Outdoor Unit
Normal Installation
90m or more
Capacity Type
Liquid Pipe
Gas Pipe
Liquid Pipe
Gas Pipe
8 HP
Φ9.52
Φ19.05
Φ12.7
Φ22.23
10 HP
Φ9.52
Φ22.23
Φ12.7
Φ25.4
12 HP
Φ12.7
Φ25.4
Φ15.88
Φ28.58
16 HP
Φ12.7
Φ28.58
Φ15.88
Φ31.75
Φ15.88
Φ28.58
Φ19.05
Φ31.75
Φ19.05
Φ34.9
Φ22.23
Φ38.1
Φ19.05
Φ38.1
Φ22.23
Φ41.3
18HP
20HP
22HP
24HP
26HP
28HP
30HP
32HP
34HP
36HP
38HP
40HP
42HP
44HP
46HP
48HP
115
2. BRANCH KIT SELECTION
1st refrigerant branch kit:
Other refrigerant branch kit:
Branch Kit Type
Branch Kit Type
Outdoor Unit
Capacity Type
Liquid Pipe
Gas Pipe
indoor Capacity
Index (kW)
Liquid Pipe
Gas Pipe
8HP, 10HP
YBP-YL2B
YBP-YG2B
x < 26 kW
YBP-YL1B
YBP-YG1B
12HP~24HP
YBP-YL3B
YBP-YG3B
26 kW ≤ x < 31.5 kW
YBP-YL2B
YBP-YG2B
24HP~48HP
YBP-YL4B
YBP-YG4B
31.5 kW≤ x < 71 kW
YBP-YL3B
YBP-YG3B
71 kW ≤ x < 180 kW
YBP-YL4B
YBP-YG4B
Model
Import Diameter (mm)
Converter Tube
(Interior diameter *
Exterior diameter)
YBP-YL1B
Φ19.05*Φ22.23 (1)
YBP-YG1B
Φ15.88*Φ19.05 (1)
Φ12.7*Φ9.53 (1)
YBP-YL2B
YBP-YG2B
116
Φ22.23*Φ25.4 (1)
Φ19.05*Φ22.23 (1)
Model
Converter Tube
(Interior diameter *
Exterior diameter)
Import Diameter (mm)
Φ15.88*Φ19.05 (1)
YBP-YL3B
Φ12.7*Φ15.88 (1)
Φ28.58*Φ31.75 (1)
YBP-YG3B
Φ25.4*Φ28.58 (1)
Φ19.05*Φ22.23 (1)
Φ19.05*Φ22.23 (1)
YBP-YL4B
Φ9.53*Φ6.35 (1)
Φ38.1*Φ41.3 (1)
Φ34.93*Φ38.1 (1)
YBP-YG4B
Φ2.58*Φ35.1 (1)
Φ22.23*Φ19.05 (1)
Φ22.23*Φ15.88 (1)
Note
Each Y-type branch 1. h has a label of “Only for R410A”
2. Definition of interior and exterior diameter of converter
tube shown in the figure
Total Outdoor Unit
Capacity (kW)
Comb-type Branch
x < 26 kW
YBP-CL1B
YBP-CG1B
2.1 Comb-type Branch Selection and Specification
26 kW ≤ x < 41 kW
YBP-CL2B
YBP-CG2B
1. Comb-type Branch Selection (according to outdoor unit
41 kW ≤ x < 71 kW
YBP-CL3B
YBP-CG3B
capacity)
2. Comb-type branch specification and dimension
117
118
YBP-CG1B
YBP-CL1B
YBP-CG2B
YBP-CL2B
YBP-CG3B
YBP-CL3B
Refrigerant Pipe Design
Y - TYPE AND COMB TYPE BRANCH JOINT CONNECTION
1. CONNECTING TYPE BY PURE Y TYPE BRANCH JOINT:
Outdoor unit
2. CONNECTING BY PURE COMB-TYPE JOINT:
3. CONNECTING TYPE OF Y-TYPE JOINT AND
COMB-TYPE JOINT
Outdoor unit
Outdoor unit
119
4. BRANCH JOINT INSTALLATION REQUIREMENTS
• Y-type branch junction should be installed in horizontal mode or vertical mode.
HORIZONTAL
LINE
A
within ± 30°
A direction
B
OR
within ± 30°
HORIZONTAL
LINE
B direction
• Comb-type branch junction must be installed in
horizontal direction
2. Branch converging pipe must be installed in horizontal
direction.
SELECTION OF PIPE BETWEEN OUTDOOR UNIT
1) THE PIPING LENGTH AND DIAMETER BETWEEN
OUTDOOR UNITS
Caution:
1. The length of liquid pipe and gas pipe :L1+ L2≤5m, L2+ L3
≤5m, L3+ L4≤5m.
2. The diameter of liquid pipe and gas pipe: The size for L1,
L3 and L4 will be selected based on the model of outdoor
Unit. L2 = L3 + L4, L0 = L1 + L2
Select form the following table
Capacity
8 HP
• Wrong Connection
10 HP
12 HP~14HP
16 HP
18 HP~24HP
26 HP~34HP
36 HP~48HP
Liquid pipe (mm)
Φ9.52
Φ12.7
Φ15.88
Φ19.05
Gas pipe (mm)
Φ19.05
Φ22.23
Φ25.4
Φ28.58
Φ34.9
Φ38.1
2) OIL BALANCE PIPE
• The size for oil balance pipe is 6.35mm.
• The total length of oil balance pipe between adjacent units
is not more than 5m.
Caution:
1. After the comb type distributor, the Y type distributor
connection cannot be used again or the repeated
application of the comb type distributor is not allowed.
120
CORRECT INSTALLATION METHOD
If the distance between two outdoor units is more than two
meters, then in the gas piping a 200 mm high vertical trap
needs to be installed.
L1 ≤ 200mm, L2 ≤ 2m, L3 ≤ 2m, L4 ≤ 2m
3) INSTALLATION EXAMPLE
The location of Pipeline
a) Installation error:
EXV BOX SELECTION AND INSTALLATION
For high wall unit, external EXV is standard. No options are
available.
MODEL SELECTION
The model of EXV BOX must be consistent with the models
of the indoor units.
Correct installation method: Connecting pipe must be below
the cut-off valve location.
b) Installation error:
Indoor unit
EXV BOX
YDHW032/053/070
YDEXB-18-4C
Connection
Remarks
Nuts
Connection
121
Refrigerant Pipe Design
DIMENSIONS
INSTALLATION
When EXV BOX is installed in the liquid pipe of the indoor unit, the length between indoor unit and EXV box, should not
exceed 5m. After the installation finished please connect the EXV control line into the indoor unit PCB. Note that the control
cable connections must be reliable, and the clamp firmly fixed. External EXV box cannot be connected with units supplied
with built-in EXV, otherwise the indoor unit will have no refrigerant flow.
122
Wire Connection Example:
The EXV Box is supplied with a 3 mm core wire to connect indoor control board and EXV box. If the standard wire is not
long enough, please connect as explained in the below picture
Connected to the port
Add long-term connection
Oil trap Design
Please use the oil trap design in the piping system as shown below.
123
Johnson Controls provides
comfortable environments wherever
you Live, Work or Travel
Johnson Controls is the global leader that brings ingenuity to the places where people live, work
and travel. By integrating technologies, products and services, we create smart environments that
redefine the relationships between people and their surroundings. We anticipate consumer needs,
and then integrate technologies, products and services to make life better and easier.
The acquisition of YORK in December 2005 has made our offering more diverse, deepened our
market penetration and strengthened our market leadership. York products are now a premier
brand designed and manufactured by Johnson Controls.
Johnson Controls designs, manufactures and distributes a full range of YORK cooling and heating
systems for residential applications such as villas, apartments and light commercial buildings
such as shopping malls, restaurants and shops. Our comprehensive range of residential products
includes ducted and packaged air conditioning systems, decorative (ductless) mini split systems
and room air conditioners (RAC’s). Decorative splits include high walls, floor / ceiling (convertible),
cassettes, floor free-standing units, multi splits and a complete VRF range with digital scroll
technology.
Most products are offered with refrigerant R 22, or ‘Ozone Friendly’ refrigerants R 407C and R
410A.
YORK VRF systems offer a multitude of benefits such as energy saving, flexibility of design and
installation, superior comfort, multi speed indoor motors, a very high degree of reliability and
intelligent, interactive controls. Johnson Controls is the pioneer in Nano - TiO2 disinfection
technology and this is offered as an option with our YORK VRF systems.
Let us create the ideal environment for you.
Publication number : 036 VRFTSG 0309
Supersedes : None
We reserve the right to change in part or in whole the specifications without prior notice.
Johnson Controls Middle East Head Office
P.O. Box 31065, API World Tower,
Sheikh Zayed Road Dubai, United Arab Emirates.
Tel +9714 3326050 Fax +9714 3326074
URL : www.johnsoncontrols.com
Pioneer Digital Scroll VRF Systems
Page 96
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
