Dutchmen Komfort 2012 Brochure

Dutchmen Komfort 2012 Brochure
By Dutchmen
The Legacy Lives On
1
Front Lounge 3650FFL
in Trackstopper Decor
3650FFL
Kitchen
3650FFL Kitchen
and Front Lounge
Stunning Contemporary
Interior Design
Komfort’s new “Front Lounge” floor plan features an expansive
6’ 8” upper deck crowned ceiling, with taller slide rooms that
make way for expansive windowscaping providing plenty of
natural light and incredible views.
You’ll feel right at home with Komfort’s roomy kitchen featuring
a slide room that includes the dinette and standard 12 cu ft 4
door refrigerator and a flip down desk that could be used as an
appliance center.
3650FFL
3
Komfort’s custom furniture includes a
combination lounge sofa, dinette, air
mattress bed and large storage drawers.
4
3530FBH in Buckshot
G e n uin e
M a ple H ardwo o d
e rs
D o o rs a n d D ra w
Komfort features elegant European
style hardware. The hidden hinges are
fully adjustable and spring loaded to
keep cabinets closed tightly.
3530FBH
Beautiful
Residential
Hardware
Hidden Hinges
75 Lb. Capacity
Full Extension
Drawer Glides
Solid Surface
Counter Tops
High end solid surface counter
tops, undermount stainless
steel sink and a deluxe pull out
sprayer/faucet are standard
features on Komfort. This feature
is only available for Fifth Wheels.
55
Komfort’s 3130FRL floor plan
features massive amounts
of countertop space for even
the most discriminating chef.
The taller slide again allows
us to use larger windows that
provides plenty of natural
light and incredible views.
Beautiful Beauflor flooring
continues from the door all
the way to the recliners.
3130FRL
66
3130FRL
3130FRL in Buchshot Decor
Stunning Bedroom Suites
and Spacious Baths
OVER 6'8"
of HEAD ROOM
3530FBH
Step Down
Shower and Tub
(3530FBH only)
6'8" Ceiling Height
In Bedroom
Komfort’s fifth wheel bedroom design includes two industry
firsts! An innovative, laminated, crowned ceiling design and
the cedar suite full walk-in closet.
The arched ceiling design provides for more headroom than
any other product in its class, a full 6'8". Plus, increased
headroom in the bedroom allows our slide rooms to be taller
than most competitors.
The cedar suite walk in closet utilizes the entire front cap area
to create the largest amount of hanging space, a dedicated
shoe rack, shirt wardrobes and sliding drawers. Plus, the
storage area is prepped for a washer and dryer.
7
3130FRL
90° Extended
Turning Radius
Front Cap
Stacked Rail Chassis
Komfort’s expanded turning radius
front cap includes a back-up
mirror and LED lights to make
hitching-up a breeze.
1" Thick Insulated Baggage Doors
with Slam Latch Hardware
Komfort fifth wheels feature a stacked rail
chassis design. This chassis design uses
double I-beam frame rails to increase the
amount of storage space under the bath/
bedroom deck. Many models feature an
amazing 150 cubic feet of storage – almost
60% more than the competition!
Perfect for extended cab or
short bed trucks.
Komfort Power Package
Endless Komfort Package
Komfort’s power package includes a multi function remote control
for power accessories. Plus, a 10 gallon water heater and 8 cu. ft.
refrigerator. Standard on fifth wheels.
Heated/Enclosed
Underbelly
Heated, insulated and enclosed
underbelly tanks & valves are
all standard on Komfort travel
trailers and fifth wheels.
8
R Values
•R
40 in roof, floor and
behind front cap
• R24 in slide room floors
• R9 in walls
Main
Slide Out
Room
Stabilizer
Jacks
Patio
Light
Power
Awning
Multi Functi
on Remote
Front
Landing
Gear
Premium
Entertainment System
Premium Flooring
Komfort’s Premium Entertainment
System features the latest
technology in the Industry.
Fifth wheels include a 32"
LCD HD wide screen TV and
a Sony® 5.1 Dolby® digital stereo
system with sub woofer and five
surround sound speakers. The
system also includes an AM/FM/
CD/DVD player with an IPOD®
docking station. Travel
trailers feature a 32" LCD
HD (26" in 3050QB) wide
screen TV and a 12 volt
AM/FM/CD/DVD player with
IPOD® inputs.
Beauflor® Premium vinyl flooring is designed
to withstand extreme weather changesexcessive cold or heat. Plus it is more
durable than any other vinyl flooring. Notice
how Komfort runs the Beauflor® throughout
the coach —less carpet to clean!
Decor Choices
Buckshot
Washer Dryer Prep
Central Command Center
Our central command center groups together all of
your essential interior and exterior light switches, tank
monitors, awning controls and water heater switch.
Fifth Wheel Utility
Docking Station
Washer dryer
prep is a standard
feature on Komfort
fifth wheels.
(Not available on
3130FRL).
Trail-Air Equa-Flex
Suspension
Trackstopper
• Fresh and City Water
Fills
• Black Tank Flush
• By-Pass Valves
• 110V Outlet, Light,
Cable and
Satellite TV Hookups
• Quick Connect Hose
with Sprayer
Trail-Air Equa-Flex rubber equalizer
suspension system is standard on Komfort
fifth wheels. The system protects your
investment by allowing axles to travel
independently to reduce road vibrations
and create a smoother ride.
Circles Galore
9
Travel Trailers
FREE
STANDING
DINETTE
WITH LEAF
72" AIR MATTRESS SOFA
PASS-THRU STORAGE
WARDROBE
RECLINER
OHC
REFER
MICRO
OHC
LINEN
OHC
PANTRY
WARD
PASS-THRU STORAGE
SHOWER
WITH
SKYLIGHT
2720RL
WARDROBE
LINEN
WARDROBE
TV
WARDROBE
OHC
Unloaded Weight (lbs) . . . . . . . . . . . . 6,627
Hitch Weight (lbs) . . . . . . . . . . . . . . . . 711
Cargo Capacity (lbs) . . . . . . . . . . . . . . 1,773
Overall Height w/AC . . . . . . . . . . . . . 11' 6"
Overall Length . . . . . . . . . . . . . . . . . . 29' 4"
2410RK
Fresh Water Tank(s) . . . . . . . . . . . . . . . 52
Black Water Tank(s) . . . . . . . . . . . . . . . 42
Grey Water Tank(s) . . . . . . . . . . . . . . . . 84
Furnace BTU Output . . . . . . . . . . . . 30,000
Fresh Water Tank(s) . . . . . . . . . . . . . . . 52
Black Water Tank(s) . . . . . . . . . . . . . . . 42
Grey Water Tank(s) . . . . . . . . . . . . . . . . 42
Furnace BTU Output . . . . . . . . . . . . 30,000
FREE
STANDING
DINETTE
WITH LEAF
72" AIR MATTRESS SOFA
WARDROBE
SHOWER
OHC
REFER
PASS-THRU STORAGE
WARDROBE
OHC
60" X 80"
QUEEN BED
OHC
OHC
MICRO
AN
WARDROBE
GE
OH LE
D
RECLINER
RECLINER
OHC
OPT.
END
TABLE
PANTRY
OHC
Unloaded Weight (lbs) . . . . . . . . . . . . 7,212
Hitch Weight (lbs) . . . . . . . . . . . . . . . . 963
Cargo Capacity (lbs) . . . . . . . . . . . . . . 3,964
Overall Height w/AC . . . . . . . . . . . . . 11' 6"
Overall Length . . . . . . . . . . . . . . . . . . . . 34'
ENT CENTER
DREAM
DINETTE
REFER
60" X 80"
QUEEN BED
LINEN
OHC
MICRO
OHC
60" X 80"
QUEEN BED
OHC
SOFA
PANTRY
TV
OHC
RECLINER
2955RE
OHC
DINETTE
Unloaded Weight (lbs) . . . . . . . . . . . . 8,212
Hitch Weight (lbs) . . . . . . . . . . . . . . . . 950
Cargo Capacity (lbs) . . . . . . . . . . . . . . 2,964
Overall Height w/AC . . . . . . . . . . . . . 11' 6"
Overall Length . . . . . . . . . . . . . . . . . . 35' 2"
END TABLE
SHOWER
ENT
CENTER
WARDROBE
LINEN
SOFA
REFER
TV / OHC / DRESSER
LINEN
OHC
END TABLE
2650FL
OHC
FREE
STANDING
DINETTE
WITH LEAF
Fresh Water Tank(s) . . . . . . . . . . . . . . . 46
Black Water Tank(s) . . . . . . . . . . . . . . . 42
Grey Water Tank(s) . . . . . . . . . . . . . . . . 42
Furnace BTU Output . . . . . . . . . . . . 30,000
60" X 74"
QUEEN BED
BUNK BEDS
WARD
WARD
10
72" AIR MATTRESS SOFA
PANTRY
Unloaded Weight (lbs) . . . . . . . . . . . . 7,326
Hitch Weight (lbs) . . . . . . . . . . . . . . . 1,134
Cargo Capacity (lbs) . . . . . . . . . . . . . . 3,850
Overall Height w/AC . . . . . . . . . . . . . 11' 6"
Overall Length . . . . . . . . . . . . . . . . . . 32' 7"
MICRO
Fresh Water Tank(s) . . . . . . . . . . . . . . . 52
Black Water Tank(s) . . . . . . . . . . . . . . . 42
Grey Water Tank(s) . . . . . . . . . . . . . . . . 42
Furnace BTU Output . . . . . . . . . . . . 30,000
ENT. CENTER
OHC
60" X 74"
QUEEN BED
ENT
CENTER
TUB
WARD
LINEN
LAV
OHC
BUNK BEDS
REFER
MICRO
Unloaded Weight (lbs) . . . . . . . . . . . . 8,017
Hitch Weight (lbs) . . . . . . . . . . . . . . . 1,148
Cargo Capacity (lbs) . . . . . . . . . . . . . . 3,159
Overall Height w/AC . . . . . . . . . . . . . 11' 6"
Overall Length . . . . . . . . . . . . . . . . . . 34' 8"
OHC
3050QB
Fresh Water Tank(s) . . . . . . . . . . . . . . . 52
Black Water Tank(s) . . . . . . . . . . . . . . . 42
Grey Water Tank(s) . . . . . . . . . . . . . . . . 42
Furnace BTU Output . . . . . . . . . . . . 30,000
SOFA
DINETTE
OPTIONAL SOFA
& DINETTE
OHC
OHC
OHC
ENT CENTER
EN
PANTRY
STEPS
NIGHT
STAND
Fresh Water Tank(s) . . . . . . . . . . . . . . . 57
Black Water Tank(s) . . . . . . . . . . . . . . . 33
Grey Water Tank(s) . . . . . . . . . . . . . . . . 66
Furnace BTU Output . . . . . . . . . . . . 30,000
OHC
Unloaded Weight (lbs) . . . . . . . . . . . 10,044
Hitch Weight (lbs) . . . . . . . . . . . . . . . 2,127
Cargo Capacity (lbs) . . . . . . . . . . . . . . 5,050
Overall Height w/AC . . . . . . . . . . . . . 12' 7"
Overall Length . . . . . . . . . . . . . . . . . . . . 35'
SOFA
Fresh Water Tank(s) . . . . . . . . . . . . . . . 67
Black Water Tank(s) . . . . . . . . . . . . . . . 48
Grey Water Tank(s) . . . . . . . . . . . . . . . . 48
Furnace BTU Output . . . . . . . . . . . . 34,000
DINETTE
TRUNDLE BED - STD.
CLOSET
FAN
SHELF
W/D PREP
PANTRY
BUNK OVER WARD
ENT CTR
“CEDAR SUITE”
WALK-IN CLOSET
WITH W/D PREP
OHC
CHO
72" X 80"
KING BED
MEGA SHOWER
EN
T.
C
TV / OHC / DRESSER
Unloaded Weight (lbs) . . . . . . . . . . . . 9,563
Hitch Weight (lbs) . . . . . . . . . . . . . . . 1,970
Cargo Capacity (lbs) . . . . . . . . . . . . . . 5,937
Overall Height w/AC . . . . . . . . . . . . . . . 12'
Overall Length . . . . . . . . . . . . . . . . . . . . 32'
R
SHELF
2820RL
CLOSET
Fresh Water Tank(s) . . . . . . . . . . . . . . . 57
Black Water Tank(s) . . . . . . . . . . . . . . . 48
Grey Water Tank(s) . . . . . . . . . . . . . . . . 48
Furnace BTU Output . . . . . . . . . . . . 30,000
TV / OHC / DRESSER
MICRO
OHC
Unloaded Weight (lbs) . . . . . . . . . . . 11,640
Hitch Weight (lbs) . . . . . . . . . . . . . . . 2,526
Cargo Capacity (lbs) . . . . . . . . . . . . . . 3,860
Overall Height w/AC . . . . . . . . . . . . . 12' 7"
Overall Length . . . . . . . . . . . . . . . . . . . . 40'
Fresh Water Tank(s) . . . . . . . . . . . . . . . 67
Black Water Tank(s) . . . . . . . . . . . . . . . 96
Grey Water Tank(s) . . . . . . . . . . . . . . . . 96
Furnace BTU Output . . . . . . . . . . . . 34,000
OHC
SOFA
OHC
ENT. CENTER
MICRO
REFER
60" X 80"
QUEEN BED
SHOWER
L
OHC
OHC
Unloaded Weight (lbs) . . . . . . . . . . . 10,044
Hitch Weight (lbs) . . . . . . . . . . . . . . . 2,212
Cargo Capacity (lbs) . . . . . . . . . . . . . . 5,456
Overall Height w/AC . . . . . . . . . . . . 12' 10"
Overall Length . . . . . . . . . . . . . . . . . . 34' 4"
72" X 80"
KING BED
SHELF
W/D PREP
N
IN E
TV / OHC / DRESSER
SHELF
CLOSET
75" L-SOFA
WITH AIR BED
OHC
DESK
FAN
“CEDAR SUITE”
WALK-IN CLOSET
WITH W/D PREP
FAN
OHC
CLOSET
SHOWER
WITH
SKYLIGHT
FREE
STANDING
DINETTE
W/LEAF
STEPS
PANTRY
2920FRK
Fresh Water Tank(s) . . . . . . . . . . . . . . . 67
Black Water Tank(s) . . . . . . . . . . . . . . . 48
Grey Water Tank(s) . . . . . . . . . . . . . . . . 96
Furnace BTU Output . . . . . . . . . . . . 34,000
CLOSET
3530FBH
OUTSIDE
KITCHEN
12 CU.FT.
REFER
DINETTE
“CEDAR SUITE”
WALK-IN CLOSET
WITH W/D PREP
SHELF
REFER
R
SHELF
W/D PREP
TE
OH
TE
OHC
EN
REFER
CABINETS
60" X 80"
QUEEN BED
PANTRY
PANTRY
FAN
OHC
CLOSET
SUNKEN TUB
40" TV
FIREPLACE
DINETTE
OHC
3130FRL
OHC
OVERSIZED
BUNKS
MICRO
OHC
FREE
STANDING
DINETTE
WITH LEAF
72" SOFA
WITH
AIR BED
2620FRL
NIGHT
STAND
Unloaded Weight (lbs) . . . . . . . . . . . . 8,617
Hitch Weight (lbs) . . . . . . . . . . . . . . . 1,675
Cargo Capacity (lbs) . . . . . . . . . . . . . . 1,943
Overall Height w/AC . . . . . . . . . . . . . . . 12'
Overall Length . . . . . . . . . . . . . . . . . 31' 10"
60" X 80"
QUEEN BED
SHOWER
WITH
SKYLIGHT
OHC
WARDROBE
REFER
NIGHT
STAND
FAN
RECLINER
60" X 80"
QUEEN BED
LIN
REFER
MICRO
END
TABLE
OHC
ROCKER
EN
DRESSER
OHC
NIGHT
STAND
SHOWER
OHC
T.
C
WARDROBE
OHC
END
TABLE
EN
WARDROBE
RECLINER
ROCKER
SOFA
REFER
OPT. FIREPLACE
OHC
FREE
STANDING
DINETTE
WITH LEAF
72" SOFA SOFA SLEEPER
MICRO
ENT. CENTER
W/ DVD STORAGE
PANTRY
Fifth Wheels
CLOSET
W/D
PREP
MICRO
CLOSET / DRESSER
OHC
CLOSET
75" SOFA
3650FFL
Unloaded Weight (lbs) . . . . . . . . . . . 12,034
Hitch Weight (lbs) . . . . . . . . . . . . . . . 2,463
Cargo Capacity (lbs) . . . . . . . . . . . . . . 3,466
Overall Height w/AC . . . . . . . . . . . . . . . 12'
Overall Length . . . . . . . . . . . . . . . . . . 40' 2"
Fresh Water Tank(s) . . . . . . . . . . . . . . . 57
Black Water Tank(s) . . . . . . . . . . . . . . . 48
Grey Water Tank(s) . . . . . . . . . . . . . . . . 96
Furnace BTU Output . . . . . . . . . . . . 34,000
11
Standard and Optional Features
Komfort Platinum Exterior Package
• Platinum Fiberglass Exterior
• Fully Laminated Side and Rear Walls
• Frameless Windows
• 16" Load Range “E” Radial Tires*
• 15" Radial Tires Std (Travel Trailers)
• Equa-Flex Suspension*
• Easy Lube Axles
• “Eye Sight” Hitch-Vision Fiberglass Front Cap
with Expanded Turning Radius* (Fifth Wheels)
• Fiberglass Front Cap
• LED Loading Lights on Front Cap
• Stacked Rail Chassis Construction*
• Sewer Hose Storage
• Slam Latches on Primary Baggage Doors*
• Central Convenience Center*
• 6'4" Tall Entry Door With “Welcome Back” Light*
• LP Quick Disconnect
• Rear Ladder* (Option on TT’s)
• Tinted Safety Glass Windows
• Pivoting Entry Handle
• Front and Rear Stabilizer Jacks
• Electric Patio Awning
• Exterior 110V and Cable Connections
• Detachable Power Cord - 30 Amp TT’s, 50 Amp FW’s
Komfort Platinum Interior Package
• Beauflor® “No Crack” Premium Flooring
• Halogen Ceiling Lighting*
• Crowned Roof on Upper Deck*
• Crowned Roof Throughout (TT’s)
• Residential Wood Window Blinds in Living Area
• Wrought Iron Window Treatments with Curtains
• Maple Cabinetry with Hidden Hinges
• Upgraded Contemporary Styled Furniture
• Air Mattress Hide-A-Bed Sofa
• Solid Surface Kitchen Counter Tops*
• Stainless Steel Kitchen Sink with Pull Out Sprayer*
• “Cedar Suite” Walk In Closet (Most Models)*
• Washer/Dryer Prep (Most Models)*
• Designer Wall Board in Slide Rooms*
• Residential Cove Molding At Ceiling
• Chair Rail in Living Area
Komfort “Power Package” STD - FW’s,
• Wireless Remote Control System: (Operates)
- Power Front Landing Gear
- Power Rear Stabilizers
- Power Front and Rear Stabilizer (TT’s)
- Power Patio Awning
- Exterior Patio Light
- Main Slide Out Room
• 8 Cubic Foot Refrigerator
• 10 Gallon Gas/Electric/DSI Water Heater
Endless Komfort Package
• Extra Large Furnace
• Heated and Enclosed Underbelly and Plumbing
• Radiant Foil Insulation in the Roof, Floor and
Front Cap
Other Exterior Features
• Leaf Spring Suspension with Equa-Flex*
• Outside Speakers (TT’s)
• Hitch Light
• 6'4" Entry Door*
• “Welcome Back” Lighted Door
• LP Cover (TT’s)
• 30 Pound LP Bottles
• Extended Down Spouts
• TV Antenna
• Vented Attic
• Triple Entry Step
Other Interior Features
• Central Vacuum* (Req Opt)
• Beauflor® Flooring
• Night Shades In Bedroom
• Bath Skylight
• Glass Shower Door (See Floorplans)
• Tub/Shower Surround (See Floor Plans)
• Toilet Tissue Holder
• 12V Bath Exhaust Fan
• Convection Microwave*
• Large Oven (TT’s)
Other Interior Features (Continued)
• 3 Burner Cook Top
• 10 Gallon Gas/Electric/DSI Water Heater
• Sony 5.1 Surround Sound System with AM/FM/CD
DVD Player (Fifth Wheels)
• AM/FM/CD/DVD Stereo (Travel Trailers)
• Cable and Satellite Prep
• Bedroom TV Hookup with LCD TV Prep
• 13,500 BTU Ducted AC (TT’s)
• 15,000 BTU AC (STD FW’s, OPT TT’s)
• 8 Cu. Foot Double Door Refer (STD FW’s, OPT TT’s)
Options
• Bedroom Fireplace (3650 Only)
• Ground Control Auto Leveling System*
• Exterior Stereo with MP3 Connections*
• Queen Bed with Nightstands IPO King (3650 & 2820)
• Free Standing Dinette W/4 Chairs (STD on 2720, 2955,
3050, 3130)
• 12 Cubic Foot Side-By-Side Refer (STD in 3650)*
(N/A & 3530)
• Solid Wood Refrigerator Front
• Solid Surface Sink Covers*
• 21" Oven*
• Dual Pane Windows
• Fireplace* (STD on 3650)
• Maxx Air Fan with Rain Sensor in Bedroom
• Electric Tongue Jack (TT’s)
• Pull Out Bike Rack
• Rear Ladder* (STD FW’s, OPT TT’s)
• 15K BTU AC (STD FW’s, OPT TT’s)
• Second AC*
• Hide-A-Bed Sofa in Bunk Room (3530)
• Recliner/Glider IPO Swivel Rockers (TT’s)
• Super Sofa (Not available on 3130)
• Twin Convert-A-Lounge (3530 only)
• 22" LCD Bedroom TV
• Generator Prep*
• Aluminum Wheels
* Fifth Wheels Only
Komfort travel trailers and fifth wheels
are tested in a state-of-the-art pressurized
rain bay. Units are drenched with pressurized water sprayed on all sides of the
coach to simulate the harshest weather
conditions.
All units are tested with slides in the in
and out position, with over 4000 gallons
of water used in each test to assure a
water tight unit.
Real Weights!
Did you know that every
Komfort is weighed at
the factory as it leaves the
production line? Our certified
Acu-Weight includes options!
Most competitors publish only a base
weight that does not include options.
Make sure that you know what the “real”
weight of the unit is before you buy your
next travel trailer or fifth wheel.
Your Local Dealer
Follow “DutchmenRV” on
www.Komfort-RV.com
“Extreme Weather”
Pressurized
Rain Bay Testing
P.O. BOX 2164 • 2164 Caragana Court
Goshen, Indiana 46526
Sales: 574.537.0600 • Fax: 574.975.6274
Product information is as accurate as possible as of the date of publication of this brochure. Features, floor plans and specifications are subject to change without notice. Please also consult Dutchmen’s website at www.dutchmen.com for more current product information
and specifications. Tow Vehicle Disclaimer CAUTION: Owners of Dutchmen recreational vehicles are solely responsible for the selection and proper use of tow vehicles. All customers should consult with a motor vehicle manufacturer or their dealer concerning the purchase
and use of suitable tow vehicles for Dutchmen products. Dutchmen disclaims any liability or damages suffered as a result of the selection, operations, use or misuse of a tow vehicle. Dutchmen’s limited warranty does not cover damage to the recreational vehicle or the tow
vehicle as a result of the selection, operation, use or misuse of the tow vehicle.
07/12 © Thor Industries
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
