2012 COMPLETE LINE OF AUDIO VISUAL MOUNTING SOLUTIONS PRODUCT CATALOG

2012 COMPLETE LINE OF AUDIO VISUAL MOUNTING SOLUTIONS  PRODUCT CATALOG

COMPLETE LINE OF AUDIO VISUAL MOUNTING SOLUTIONS

PRODUCT CATALOG

2012

TABLE OF CONTENTS

Customer Care

...................................................pg# 2

Installation Safety and Sales Training

......pg# 3

Custom Solutions

.............................................pg# 4

FLAT PANEL MOUNTS

Flat Panel Mounts Table of Contents Tab

Find The Perfect Mounting Solution

............... pg# 5

Flat Panel Universal Mount Chart .................... pg# 6-10

Ultra Slim Universal Flat, Tilt,

Articulating & Motorized Wall Mounts

.......... pg# 11-23

Universal Flat,

Tilt & Articulating Wall Mounts ............................ pg# 24-32

Universal Flat, Tilt,

Pivot & Articulating Wall Mounts

....................... pg# 33-58

Display-Specific Flat & Tilt Wall Mounts

...... pg# 59-60

Peerless PRO Flat, Tilt, Fixed Tilt,

Pivot & Articulating Wall Mounts ....................... pg# 61-77

Universal Tablet Mounts

.......................................... pg# 78-79

Modular Wall Mount

............................... pg# 80

PLA Series Articulating Wall Arms

................... pg# 81-84

In-wall Mounts .................................................................. pg# 85-87

Rotational Mounts ......................................................... pg# 88

Corner Mounts

................................................................. pg# 89-90

Conversion Kits

............................................................... pg# 91

Ceiling Mounts ................................................................. pg# 92-98

Desktop Mounts ............................................................. pg# 99-111

Stands & Carts

................................................................ pg# 112-125

Outdoor Mounts, Enclosures

& Wind Rated Mounts ................................................ pg# 126-132

PROJECTOR & WHITEBOARD MOUNTS

Projector Mounts Table of Contents Tab

Spider

®

Universal Projector Adapter Intro ... pg# 133

Projector Mount and Accessories

Selection Guide ............................................................. pg# 134

Projector Mounts .......................................................... pg# 135-149

Security Projector Mounts .................................... pg# 150

Projector Enclosure

.................................................... pg# 151

Extension Columns ..................................................... pg# 152

Short Throw Projector Mounts .......................... pg# 153

Whiteboard Mounts .................................................... pg# 154-155

AV ACCESSORIES

AV Accessories Table of Contents Tab

Cables .......................................................................................... pg# 157-162

Cable Management Channel .................................... pg# 163

AV Component Rack Systems

................................. pg# 164-165

AV Shelves

................................................................................ pg# 166-167

AV Component Shelves ................................................. pg# 168

AV Component Shelf Accessory Brackets .... pg# 169

Game Console Security Mounts & Covers

... pg# 170-171

Speaker Mounts

.................................................................. pg# 172-175

Camera Mounts ................................................................... pg# 176

DIGITAL SIGNAGE

Digital Signage Table of Contents Tab

Video Wall Mounts ..............................................

pg# 177-180

Digital Menu Board Kit .......................................

pg# 181

Portable Video Wall Cart ...................................

pg# 182

Dual Display Ceiling Mounts .............................

pg# 183

Media Player Storage Mounts .........................

pg# 184

HOSPITALITY MOUNTS

Hospitality Mounts Table of Contents Tab

Set Top Box Storage Mounts .......................

pg# 185

Pull-out Swivel Wall Mount ...........................

pg# 186

Desktop Swivel Mounts ................................

pg# 187

Display Base Lock-down Security Kits .........

pg# 188

MOUNTING ACCESSORIES

Mounting Accessories Table of Contents Tab

Mount Accessories ............................................................pg# 189

Ceiling Plates & Accessories ......................................pg# 190-192

Extensions & Accessories

............................................pg# 193-194

Arms & Wall Plates

.............................................................pg# 195

Wall Plates & Harware ....................................................pg# 196

In-Wall Accessories Boxes .........................................pg# 197

Shelves and Casters

.........................................................pg# 198

Security and Safety

............................................................pg# 199

Enclosure Accessories ...................................................pg# 200

Index by Model Number

.....................pg# 201-204

Terms & Conditions

......................................pg# 205

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Follow us on

LOOK FOR THESE SYMBOLS...

Flat Panel Mounts VESA ® Pattern Mounting Pattern Distance From Wall Distance From Ceiling Height Adjustment Tilt Tilt | Swivel | Roll Landscape to portrait

Projector Mounts Mounting Pattern Distance From Ceiling Distance From Wall Tilt | Swivel | Roll

Quickship

Item

®

Quick Ship Item

Max Load UL Listed Made in USA

EN 60065

TUV Rheinland TUV/GS RoHS European Conformity Seismic Safety Multiple Boxes

Scan this QR code* to view a video about

Peerless-AV on your Smartphone or tablet, or visit videos.peerless-av.com.

*Download a free QR Reader at your devices’ app store.

MountFinder

TM

@ www.peerless-av.com

It is easy to select the perfect mounting solution for any application with the help of the most advanced mount-to-display compatibility resource in the industry -- the

Peerless-AV MountFinder™. Found at www.peerless-av.com, this easy-to-use compatibility tool searches thousands of models to find the perfect mounting solution based on your precise needs.

It is simple: answer a few basic questions and you can be assured you just purchased the best mount for the installation.

1

WILL THE MOUNT FIT YOUR DISPLAY?

There are three ways to find the mounting solution best suited to the display or projector of choice.

2

1

Enter the manufacturer of the display or projector

*

2

Enter the model number of the display or projector

*

3

Search by screen size

**

*

This search option will provide you with mounting solutions that passed compatibility tests with the flat panel display.

**

It is recommended that you know the manufacturer and model number of the flat panel screen prior to purchasing a mount to ensure 100% compatibility.

WHAT ARE THE APPLICATION STYLES AND FUNCTIONALITY

REQUIRED FOR YOUR INSTALLATION?

Find the best mounting solution for your application by sorting the compatibility results with the `Quick Search’ selection menu on the right-hand side of your display.

4

3

4

Select the desired flat panel placement

Wall

Ceiling

Desktop

Cart

5

Choose the style or functionality needed for the install

Flat

Flat and Tilting

Tilting

Pivot/ Tilt and Swivel

Articulating

In-Wall

Enclosure

If you completed all of the above steps and are unable to find the mounting solution that fits your needs, just call our expert Customer Care team at

800-865-2112 and we will assist you with identifying the ideal solution.

5

TIP!

By scrolling over the (?) to the side of the style of the mount available you will be provided with a brief description of the styles functionality.

Universal Ultra Slim Flat

Wall Mount

For 23" to 46" Ultra-thin Flat Panel Displays

1.

Ultra slim design holds displays only 0.33"

(8mm) from the wall

2.

Industrial strength Velcro ® latching system holds display in place against the wall plate preventing accidental bump-off or horizontal adjustment

3.

Easy three-step installation, mount the wall plate, attach display adapters to display, hang display

4.

Horizontal display adjustment up to 6"

(152mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns up to 450 x

402mm (17.73"W x 15.82"H)

1

2

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.33" (8mm)) may not provide sufficient space for proper ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

4. Input/output connection must be properly orientated to accommodate mounting 0.33" (8mm) from the wall.

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUF640P

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

450 x 402mm

(

17.73"W x 15.82"H)

Many flat panel displays have mounting hole patterns larger than dimensions above. Use

MountFinder™ to verify mount compatibility.

VESA

®

Pattern

Universal Models:

Up to 400 x 400mm

SPECIFICATIONS

Distance from Wall

0.33"

(8mm)

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

20.69" x 17.95" x 0.33"

(526 x 456 x 8mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

CERTIFICATIONS

4.7lb

(2.13kg)

17.95"

(456mm)

15.82

(402mm)

.88"

(22mm)

20.69"

(526mm)

17.73"

(450mm)

MAX.

FRONT VIEW

16.00"

(406mm)

WALL PLATE

.33"

(8mm) 1.11"

(28mm)

2.81"

(71mm)

SIDE VIEW

.85"

(22mm)

17.83"

(453mm)

ADAPTER BRACKET

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

ACCESSORIES

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC952:

Above Display SUF Security

Lock Accessory .................... pg# 199

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

11

Universal Ultra Slim Flat

Wall Mount

For 32" to 56" Ultra-thin Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUF650P

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

742 x 449mm

(29.23"W x 17.67"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

0.33"

(8mm)

Max Load

150lb

(68kg)

Product Dimensions (W x H x D)

Mounting Surfaces

32.19" x 21.80" x 0.33"

(818 x 554 x 8mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

7.6lb

(3.44kg)

CERTIFICATIONS

1.

Ultra slim design holds displays only 0.33"

(8mm) from the wall

2.

Industrial strength Velcro ® latching system holds display in place against the wall plate preventing accidental bump-off or horizontal adjustment

3.

Easy three-step installation, mount the wall plate, attach display adapters to display, hang display

4.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns up to 742 x 449mm

(

29.23"W x 17.67"H)

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.33" (8mm)) may not provide sufficient space for proper ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

4. Input/output connection must be properly orientated to accommodate mounting 0.33" (8mm) from the wall.

Patented

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

1

2

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC952:

Above Display SUF Security

Lock Accessory .................... pg# 199

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

12

4.81"

(122mm)

32.19"

(818mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

29.23"

(742mm)

MAX.

1.00"

(25mm)

1.06"

(27mm)

3.03"

(77mm)

2.80"

(71mm)

0.85"

(22mm)

VERTICAL ADAPTER

21.64"

(550mm)

0.33"

(8mm)

ISOMETRIC VIEW

21.80"

(554mm)

17.67"

(449mm)

MAX.

FRONT VIEW

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Ultra Slim Flat

Wall Mount

For 37" to 65" Ultra-thin Flat Panel Displays

1.

Ultra slim design holds displays only 0.33"

(8mm) from the wall

2.

Industrial strength Velcro ® latching system holds display in place against the wall plate preventing accidental bump-off or horizontal adjustment

3.

Easy three-step installation, mount the wall plate, attach display adapters to display, hang display

4.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns up to 825 x 449mm

(32.48"W x 17.67"H)

1

2

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.33" (8mm)) may not provide sufficient space for proper ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

4. Input/output connection must be properly orientated to accommodate mounting 0.33" (8mm) from the wall.

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUF660P

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

825 x 449mm

(

32.48"W x 17.67"H)

VESA

®

Pattern

Universal Models:

Up to 800 x 400mm

SPECIFICATIONS

Distance from Wall

0.33"

(8mm)

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

35.44" x 21.80" x 0.33"

(900 x 554 x 8mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

CERTIFICATIONS

7.8lb

(3.53kg)

4.81"

(122mm)

21.80"

(554mm)

35.44"

(900mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

32.48"

(825mm)

MAX.

FRONT VIEW

1.00"

(25mm)

1.06"

(27mm)

3.03"

(77mm)

17.67"

(449mm)

MAX.

2.80"

(71mm)

0.85"

(22mm)

21.64"

(550mm)

ISOMETRIC VIEW

VERTICAL ADAPTER

0.33"

(8mm)

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC615:

6-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC952:

Above Display SUF Security

Lock Accessory .................... pg# 199

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

13

Universal Ultra Slim Flat

Wall Mount

For 23" to 46" Ultra-thin Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUF641

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 to 425mm

(in 25mm increments)

SPECIFICATIONS

Distance from Wall

0

.

19"

(5mm)

Max Load

150lb

(68kg)

Product Dimensions (W x H x D)

Mounting Surfaces

20.00" x 5.50" x 0.19"

(508 x 140 x 5mm)

Wood stud, concrete and cinder block

Ship Weight

4lb

(1.8kg)

CERTIFICATIONS

ACCESSORIES

ACC952:

Above Display SUF Security

Lock Accessory .................... pg# 199

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

1.

Ultra slim design holds displays only 0.19"

(5mm) from the wall

2.

Locking arm holds flat panel display in place and prevents accidental bump-offs and unwanted horizontal adjustments

3.

Theft resistant security screw on locking arm

4.

Easy three-step installation, mount the wall plate, hang the flat panel display and insert the locking arm

5.

Fits displays with horizontal mounting hole patterns from 75 to 425mm (in 25mm increments)

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.19" (5mm)) may not provide sufficient space for proper ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

4. Input/output connection must be properly orientated to accommodate mounting 0.19" (5mm) from the wall.

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

6.00"

(152mm)

21.44"

(545mm)

LOCKING ARM

20.00"

(508mm)

16.00"

(406mm)

2.95"

(75mm)

16.73"

(425mm)

MAX.

FRONT VIEW

ISOMETRIC VIEW

1.34"

(34mm)

0.98"

(25mm)

3.50"

(89mm)

5.50"

(140mm)

SIDE VIEW

.19in

5mm

1

2

3

14

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Ultra Slim Flat

Wall Mount

For 32" to 56" Ultra-thin Flat Panel Displays

1.

Ultra slim design holds displays only 0.19"

(5mm) from the wall

2.

Locking arm holds flat panel display in place and prevents accidental bump-offs and unwanted horizontal adjustments

3.

Theft resistant security screw on locking arm

4.

Easy three-step installation, mount the wall plate, hang the flat panel display and insert the locking arm

5.

Fits displays with horizontal mounting hole patterns from

150 to 400mm and

550 to 700mm (in 25mm increments)

7.00"

(178mm)

33.44"

(849mm)

LOCKING ARM

32.00"

(813mm)

24.00"

(610mm)

20.00"

(508mm)

16.00"

(406mm)

ISOMETRIC VIEW

1.34"

(34mm)

0.98"

(25mm)

3.48"

(88mm)

5.50"

(140mm)

0.19"

(5mm)

1

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.19" (5mm)) may not provide sufficient space for proper ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

4. Input/output connection must be properly orientated to accommodate mounting 0.19" (5mm) from the wall.

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

2

3

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUF651

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

150 to 400 and 550 to 700mm

(in 25mm increments)

SPECIFICATIONS

Distance from Wall

0

.

19"

(5mm)

Max Load

150lb

(68kg)

Product Dimensions (W x H x D)

Mounting Surfaces

32.00" x 5.50" x 0.19"

(813 x 140 x 5mm)

Wood stud, concrete and cinder block

Ship Weight

5.8lb

(2.61kg)

CERTIFICATIONS

ACCESSORIES

ACC952:

Above Display SUF Security

Lock Accessory .................... pg# 199

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

2.95"

(75mm)

5.91"

(150mm)

27.56"

(700mm)

MAX.

FRONT VIEW

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

15

Universal Ultra Slim Flat

Wall Mount

For 37" to 65" Ultra-thin Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUF661

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

150 to 400 and 550 to 800mm

(in 25mm increments)

SPECIFICATIONS

Distance from Wall

0

.

19"

(5mm)

Max Load

150lb

(68kg)

Product Dimensions (W x H x D)

Mounting Surfaces

35.25" x 5.50" x 0.19"

(895 x 140 x 5mm)

Wood stud, concrete and cinder block

Ship Weight

6.1lb

(2.75kg)

CERTIFICATIONS

1.

Ultra slim design holds displays only 0.19"

(5mm) from the wall

2.

Locking arm holds flat panel display in place and prevents accidental bump-offs and unwanted horizontal adjustments

3.

Theft resistant security screw on locking arm

4.

Easy three-step installation, mount the wall plate, hang the flat panel display and insert the locking arm

5.

Fits displays with horizontal mounting hole patterns from

150 to 400mm and

550 to 800mm (in 25mm increments)

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.19" (5mm)) may not provide sufficient space for proper ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

4. Input/output connection must be properly orientated to accommodate mounting 0.19" (5mm) from the wall.

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

ACCESSORIES

ACC952:

Above Display SUF Security

Lock Accessory .................... pg# 199

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

7.00"

(178mm)

36.75"

(933mm)

LOCKING ARM

35.25"

(895mm)

24.00"

(610mm)

20.00"

(508mm)

16.00"

(406mm)

5.91"

(150mm)

ISOMETRIC VIEW

0.98"

(25mm)

3.48"

(88mm)

5.50"

(140mm)

0.19"

(5mm)

16.00"

(406mm)

31.50"

(800mm)

MAX.

FRONT VIEW

2.95"

(75mm)

SIDE VIEW

1

2

3

16

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

i[email protected]

ONLINE:

www.peerless-av.com

Universal Ultra Slim Tilt

Wall Mount

For 22" to 40" Ultra-thin Flat Panel Displays

1.

Holds display 0.68"

(17mm) from the wall

2.

Display can be extended up to 3.88"

(98mm) from the wall allowing for hand-free installation access to the back of the display

3.

Full motion tilt allows

4.

Display adapter simply hooks onto wall plate for quick and easy installation

4

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.68" (17mm)) may not provide sufficient space for proper heat ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

1

2

3

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUT632P

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

Tilt

0.68"-3.88"

(17-98mm)

+17.5/-5°

Max Load

60lb

(27kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

8.75" x 9.35" x 0.68"-3.88"

(222 x 237 x 17-98mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

4lb

(1.8kg)

CERTIFICATIONS

7.87"

(200 mm)

2.95"

(75 mm)

7.87"

(200 mm)

3.94"

(100 mm)

2.95"

(75 mm)

9.35"

(237 mm)

.68"

(17 mm)

8.75"

(222 mm)

FRONT VIEW

3.94"

(100 mm)

1"

(25 mm)

8"

(203 mm)

7.84"

(199 mm)

MAX

.28"

(7 mm)

WALL PLATE DETAIL

.81"

(203 mm)

2.98"

(76 mm)

SIDE VIEW

17.5°

2"

(51 mm)

3.88"

(98 mm)

TILT VIEW

ACCESSORIES

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

17

Universal Ultra Slim Tilt

Wall Mount

For 32" to 46" Ultra-thin Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUT645P

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

603 x 408mm

(23.75"W x 16.06"H)

SPECIFICATIONS

Distance from Wall

Tilt

0.68"-5.88"

(17-149mm)

+17.5/-5°

Max Load

100lb

(45kg)

Product Dimensions (W x H x D)

Mounting Surfaces

29.00" x 17.25" x 0.68"-5.88"

(736 x 438 x 17-149mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

11lb

(5kg)

CERTIFICATIONS

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

1.

Holds display 0.68"

(17mm) from the wall

2.

Display can be extended up to 5.88"

(149mm) from the wall allowing for hands-free installation access to the back of the display

3.

Full motion tilt allows for

+17.5/-5°

4.

Display adapters simply hook onto wall plate for quick and easy installation

5.

Horizontal adjustment up to 8" (203mm) for centering display

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.68" (17mm)) may not provide sufficient space for proper heat ventilation on some displays.

Refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

4.25"

(108 mm)

1"

(25 mm)

29"

(736 mm)

23.75"

(603 mm)

MAX

26.18"

(665mm)

24"

(610 mm)

20"

(508 mm)

16"

(406mm)

16.06"

(408 mm)

MAX

17.25"

(438 mm)

.68"

(17 mm)

.88"

(22 mm)

11"

(279 mm)

3.30"

(84 mm)

6.62"

(168 mm)

7.12"

(180 mm)

17.5°

2"

(51 mm)

5.88"

(149 mm)

4

1

2

3

18

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Ultra Slim Tilt

Wall Mount

For 37" to 60" Ultra-thin Flat Panel Displays

1.

Holds displays 0.68"

(17mm) from the wall

2.

Display can be extended up to 5.88"

(149mm) from the wall allowing for hands-free installation access to the back of the display

3.

Full motion tilt allows for

+17.5/-5°

4.

Display adapters simply hook onto wall plate for quick and easy installation

5.

Horizontal adjustment up to 8" (203mm) for centering display on wall

4

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The depth of this mount (0.68" (17mm)) may not provide sufficient space for proper heat ventilation on some displays.

Please refer to the manufacturer’s requirements for mounting the display before installation.

3. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

1

2

3

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUT660P

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

801 x 408mm

(31.53"W x 16.06"H)

SPECIFICATIONS

Distance from Wall

Tilt

0.68"-5.88"

(17-149mm)

+17.5/-5°

Max Load

100lb

(45kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

36.63" x 17.25" x 0.68"-5.88"

(930 x 438 x 17-149mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

11.5lb

(5.2kg)

CERTIFICATIONS

36.63"

(930 mm)

31.53"

(801 mm)

MAX

4.25"

(108 mm)

36.43"

(925 mm)

24"

(610 mm)

20"

(508 mm)

1"

(25 mm)

16"

(406 mm)

15.5"

(393 mm)

16"

(406 mm)

16.06"

(408 mm)

MAX

17.25"

(438 mm)

.68"

(17 mm)

7.12"

(180 mm)

17.5°

.88"

(22 mm)

2"

(51 mm)

3.30"

(84 mm)

6.62"

(168 mm)

5.88"

(149 mm)

ACCESSORIES

ACC615:

6-pack Metal Stud

Fastener Kit ........................ pg# 196

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

19

Universal Ultra Slim Articulating

Wall Arm

For 32" to 46" Ultra-thin Flat Panel Displays

MODELS

Includes standard hardware (hex or Phillips) for attaching display to mount

Universal Models:

SUA746PU

*

Dedicated Models:

SUA737

*

Gloss black

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

450 x 402mm

(17.73"W x 15.81"H)

VESA

®

Pattern

Universal Models:

200 x 100, 200 x 200

400 x 200 and 400 x 400mm

Dedicated Models:

200 x 100, 200 x 200mm

SPECIFICATIONS

Distance from Wall

SUA746PU:

SUA737:

Tilt | Swivel | Roll

1.27"-24.15"

(32-613mm)

1.29"-24.17"

(33-614mm)

+15/-5° | ±90° | ±5°

Max Load

60lb

(27kg)

Product Dimensions

(W x H x D)

SUA746PU:

20.15" x 16.75" x 1.27"-24.15"

(512 x 425 x 32-613mm)

SUA737:

15.85" x 13.00" x 1.29"-24.17"

(403 x 330 x 33-614mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and cinder block

SUA746PU:

SUA737:

CERTIFICATIONS

14lb

(6.35kg)

10.5lb

(4.76kg)

Pending

ACCESSORIES

ACC919:

Security Fasteners ............... pg# 195

ACC-SB:

Soundbar/Center Channel

Accessory Mount ................. pg# 185

IBA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 193

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 193

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 193

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 193

20

16.75"

(425mm)

7.87"

(200mm)

UPDATED DESIGN!

1.

Arm retracts to 1.27"

(32mm) and extends up to

24.15" (613mm) from wall

2.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

3.

Up to ±90° of side-to-side swivel

4.

Added ±5° of roll for postinstallation display leveling without the use of tools

SUA737

7.87"

(200mm)

20.15"

(512mm)

17.73"

(450mm)

4.82"

(122mm)

3.94"

(100mm)

15.81"

(402mm)

15.85"

(403mm)

4.82"

(122mm)

SUA746PU

SUA737

13.00"

(330mm)

1.27" - 26.12"

(32mm - 663mm)

1.29" - 25.57"

(33 - 649mm)

SUA746PU

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

ADAPTER PLATE

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

1

2

Universal Ultra Slim Articulating

Wall Arm

For 37" to 55" Ultra-thin Flat Panel Displays

UPDATED DESIGN!

1.

Arm retracts to 1.34"

(34mm) and extends up to 24.19" (615mm) from wall

2.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

3.

Up to ±90° of

4.

Added ±5° of roll for postinstallation display leveling without the use of tools

1

2

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUA751PU

*

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

825 x 439mm

(32.49"W x 17.27"H)

VESA

®

Pattern

Universal Models:

200 x 100, 200 x 200

400 x 200, 400 x 400 and 800 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

1.34"-24.19"

(34-615mm)

+15/-5° | ±90° | ±5°

Max Load

100lb

(45kg)

Product Dimensions

(W x H x D)

35.21" x 19.00" x 1.34"-24.19"

(894 x 483 x 34-615mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and cinder block

CERTIFICATIONS

25lb

(11.34kg)

13.49"

(343mm)

22.00"

(559mm)

16.00"

(406mm)

19.38"

(492mm)

WALL PLATE

35.21"

(894mm)

32.49"

(825mm)

MAX.

11.76"

(299mm)

9.50"

(241mm)

FRONT VIEW

17.27"

(439mm)

1.67"

(42mm)

0.98"

(25mm)

1.90"

(48mm)

19.00"

(483mm)

VERTICAL ADAPTER

1.34"

(34mm)

SIDE VIEW

RETRACTED

ISOMETRIC VIEW

24.19" - 26.61"

(615mm - 676mm)

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

ACCESSORIES

ACC925:

Security Fasteners ................ pg# 199

ACC-SB:

Soundbar/Center Channel

Accessory Mount ................. pg# 189

BA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

21

Universal Ultra Slim Articulating

Wall Arm

For 42" to 65" Ultra-thin Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SUA765PU

*

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

854 x 439mm

(33.6"W x 17.27"H)

VESA

®

Pattern

Universal Models:

100 x 100, 200 x 100,

200 x 200, 400 x 200,

400 x 400 and 800 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

1.24"-28.16"

(32-715mm)

+15/-5° | ±72.5° | ±1°

Max Load

100lb

(45kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

38.17" x 19.00" x 1.24"-28.16"

(969 x 483 x 32-715mm)

Ship Weight

Wood stud, concrete and cinder block

CERTIFICATIONS

31lb

(14.06kg)

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC-SB:

Soundbar/Center Channel

Accessory Mount ................. pg# 189

BA2(-W), IBA2AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA3(-W), IBA3AC(-W):

Recessed Cable

Management and Power

Storage Accessory Box ......... pg# 197

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

22

1.

Dual-arm design enhances the stability of the articulating motion

2.

Arm retracts to 1.24"

(32mm) and extends up to 28.16" (715mm) from wall

3.

One-Touch™ tilt adjustment of +15/-5° without the use of tools

4.

Up to ±72.5° of

5.

±1° of roll for

post-installation

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

2. The display must have a flat mounting surface, or mounting holes need to be on the furthest back surface of the display.

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

12.25"

(311mm)

17.27"

(439mm)

22.00"

(559mm)

16.00"

(406mm)

9.25"

(235mm)

5.73"

(145mm)

WALL PLATE

38.17"

(969mm)

33.60"

(854mm)

MAX.

FRONT VIEW

2.31"

(59mm)

13.49"

(343mm)

1.67"

(42mm)

0.98"

(25mm)

VERTICAL ADAPTER

1.24"

(32mm)

SIDE VIEW

1.90"

(48mm)

19.00"

(483mm)

ISOMETRIC VIEW

28.16"

(715mm)

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

2

3

Ultra Slim Motorized

Wall Mount

For 23" to 46" Ultra-thin Flat Panel Displays

1.

Arm retracts to 1.375"

(34.9mm) and extends up to 8.375" (212.7mm) from wall

2.

Pivots up to 40º (20º in each direction)

3.

Remote control operation with

preset positions

4.

Automatic display centering and wall detection

5.

Near silent (25dB)

Display Mounting Requirements

1. Designed for use with displays that are less than 2" (50.8mm) deep.

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

1

2

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

MM746PU

*

* Designed for use with displays that are less than 2" (50.8mm) deep

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

200 x 200, 300 x 300 and 400 x 400mm

SPECIFICATIONS

Distance from Wall

Swivel

1.375"-8.375"

(34.9-212.7mm)

Up to 40º

(20º in each direction)

Max Load

110lb

(50kg)

Product Dimensions (W x H x D)

19.06" x 10.47"-16.70" x 1.375-8.375"

(484 x 266-424 x 35-212.7mm)

Mounting Surfaces

Wood stud and concrete

Ship Weight

26lb

(11.79kg)

19.06"

(484mm)

16.70"

(424mm)

2.19"

(56mm)

4.37"

(111mm)

9.29"

(236mm)

1.06"

(27mm)

10.39"

(264mm)

WALL PLATE

FRONT VIEW

19.06"

(484mm)

17.40"

(442mm)

9.06"

(230mm)

FRONT VIEW

1.37"

(35mm)

10.47"

(266mm)

SIDE VIEW

ISOMETRIC VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

23

Universal Flat

Wall Mount

For 32" to 46" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SFX645

Includes standard hardware (hex or Phillips) for attaching display to mount

SFX645P

Ravens black

SCREEN ADAPTER

Mounting Pattern

Universal Models:

452 x 433mm

(17.79"W x 17.04"H)

VESA ® Pattern

Universal Models:

Up to 400 x 400mm

SPECIFICATIONS

Distance from Wall

1.21"

(31mm)

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

19.37" x 18.00" x 1.21"

(492 x 457 x 31mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

6.5lb

(2.95kg)

CERTIFICATIONS

Pending

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACCXT302:

Video Conferencing Shelf ...... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

ACCXT402:

Recessed Power Outlet with Low Voltage

In-Wall Cable Routing ............. pg# 189

1.

Low-profile design holds display 1.21" (31mm) from wall

2.

Up to 1" (25mm) of vertical adjustment on each universal display adapter bracket for post-installation leveling and height adjustment fine-tuning

3.

Up to 13" (330mm) of horizontal display adjustment for centering display on wall

4.

Open wall plate design allows for total wall access, increasing electrical and cable management options

5.

Easy-Glide™ design ensures that the display is securely attached to the wall plate

6.

Universal display adapter brackets easily hook onto wall plate for fast installation

7.

Fits displays with mounting hole patterns from 75 x 75mm

(2.95"W x 2.95"H) to 452 x

433mm (17.79"W x 17.04"H)

Reseller Authorization Required

TECHNICAL DRAWINGS

1

Patent Pending

For expanded product information and technical data visit www.peerless-av.com

4

9.15"

(232mm)

8.15"

(207mm)

17.79"

(452mm)

MAX.

19.37"

(492mm)

6.03"

(153mm)

16.00"

(406mm)

17.88"

(454mm)

WALL PLATE

3.57"

(91mm)

17.04"

(433mm)

MAX.

1.00"

(25mm)

0.75"

(19mm)

1.71"

(43mm)

0.85"

(22mm)

18.00in

457mm

1.21"

(31mm)

VERTICAL ADAPTER

ISOMETRIC VIEW

FRONT VIEW

SIDE VIEW

24

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 32" to 55" Flat Panel Displays

1.

Low-profile design holds display 1.21" (31mm) from wall

2.

Up to 1" (25mm) of vertical adjustment on each universal display adapter bracket for post-installation leveling and height adjustment fine-tuning

3.

Up to 25" (635mm) of horizontal display adjustment for centering display on wall

4.

Open wall plate design allows for total wall access, increasing electrical and cable management options

5.

Easy-Glide™ design ensures that the display is securely attached to the wall plate

6.

Universal display adapter brackets easily hook onto wall plate for fast installation

7.

Fits displays with mounting hole patterns from 75 x 75mm (2.95"W x 2.95"H) to 744 x 433mm

(29.29"W x 17.04"H)

Patent Pending

For expanded product information and technical data visit www.peerless-av.com

9.15"

(232mm)

30.87"

(784mm)

6.03"

(153mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

29.38"

(746mm)

WALL PLATE

29.29"

(744mm)

MAX.

FRONT VIEW

1.00"

(25mm)

8.15"

(207mm)

0.75"

(19mm)

1.71"

(43mm)

0.85"

(22mm)

18.00"

(457mm)

3.57"

(91mm)

17.04"

(433mm)

MAX.

VERTICAL ADAPTER

1.21"

(31mm)

SIDE VIEW

1

4

Reseller Authorization Required

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SFX650

Includes standard hardware (hex or Phillips) for attaching display to mount

SFX650P

Ravens black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

744 x 433mm

(29.29"W x 17.04"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

1.21"

(31mm)

Max Load

120lb

(54kg)

Product Dimensions

(W x H x D)

30.87" x 18.00" x 1.21"

(784 x 457 x 31mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

8.3lb

(3.76kg)

CERTIFICATIONS

ISOMETRIC VIEW

Pending

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACCXT302:

Video Conferencing Shelf ...... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

ACCXT402:

Recessed Power Outlet with Low Voltage

In-Wall Cable Routing ............. pg# 189

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

25

Universal Flat

Wall Mount

For 46" to 70" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SFX660

Includes standard hardware (hex or Phillips) for attaching display to mount

SFX660P

Ravens black

SCREEN ADAPTER

Mounting Pattern

Universal Models:

827 x 433mm

(32.54"W x 17.04"H)

VESA

®

Pattern

Universal Models:

Up to 700 x 600mm

SPECIFICATIONS

Distance from Wall

1.21"

(31mm)

Max Load

150lb

(68kg)

Product Dimensions (W x H x D)

Mounting Surfaces

34.12" x 18.00" x 1.21"

(867 x 457 x 31mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

9.7lb

(4.4kg)

CERTIFICATIONS

Pending

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACCXT302:

Video Conferencing Shelf ...... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

ACCXT402:

Recessed Power Outlet with Low Voltage

In-Wall Cable Routing ............. pg# 189

1.

Low-profile design holds display

1.21" (31mm) from wall

2.

Up to 1" (25mm) of vertical adjustment on each universal display adapter bracket for post-installation leveling and height adjustment fine-tuning

3.

Up to 24" (610mm) of horizontal display adjustment for centering display on wall

4.

Open wall plate design allows for total wall access, increasing electrical and cable management options

5.

Easy-Glide™ design ensures that the display is securely attached to the wall plate

6.

Universal display adapter brackets easily hook onto wall plate for fast installation

7.

Fits displays with mounting hole patterns from 75 x 75mm (2.95"W x 2.95"H) to 827 x 433mm

(32.54"W x 17.04"H)

Reseller Authorization Required

TECHNICAL DRAWINGS

1

Patent Pending

For expanded product information and technical data visit www.peerless-av.com

4

9.15"

(232mm)

34.12"

(867mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

32.63"

(829mm)

WALL PLATE

6.03"

(153mm)

1.00"

(25mm)

8.15"

(207mm)

32.54"

(827mm)

MAX.

0.75"

(19mm)

1.71"

(43mm)

0.85"

(22mm)

3.57"

(91mm)

17.04"

(433mm)

MAX.

VERTICAL ADAPTER

1.21"

(31mm)

18.00"

(457mm)

FRONT VIEW

SIDE VIEW

ISOMETRIC VIEW

26

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 32" to 46" Flat Panel Displays

1.

Low-profile design holds display

1.69" (43mm) from wall

2.

Increased security with included

Master Lock 510KAD keyed-alike padlock on SXT645L only

3.

Universal tilt adapter brackets offer up to +15/-5° of One-Touch™ tilt adjustment in one easy motion

4.

Included IncreLok

TM

feature offers fixed ilt lock in 5° increments when used

5.

Up to 1" (25mm) of vertical adjustment on each universal display adapter bracket for post-installation leveling and height adjustment fine-tuning

6.

Up to 13" (330mm) of horizontal display adjustment for centering display on wall

7.

Open wall plate design allows for total wall access, increasing electrical and cable management options

8.

Universal tilt adapter brackets easily hook onto wall plate for fast installation

9.

Fits displays with mounting hole patterns from 100 x 100mm (3.94"W x 3.94"H) to 431 x 433mm (16.96"W x 17.04"H)

10.

5º of negative tilt offers 3" (76mm) of space for hands-free, behind the display access

Patent Pending

For expanded product information and technical data visit www.peerless-av.com

9.15"

(232mm)

19.37"

(492mm)

16.00"

(406mm)

17.88"

(454mm)

WALL PLATE

16.96"

(431mm)

3.00"

(76mm)

FRONT VIEW

1.00"

(25mm)

6.03"

(153mm)

8.15"

(207mm)

17.04"

(433mm)

MAX.

1.69"

(43mm)

SIDE VIEW

0.76"

(19mm)

2.73"

(69mm)

0.85"

(22mm)

18.00"

(457mm)

7

3

5

2

Reseller Authorization Required

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

STX645

STX645L

Ravens black Locking

Includes standard hardware (hex or Phillips) for attaching display to mount

STX645P

Ravens black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

431 x 433mm

(16.96"W x 17.04"H)

VESA

®

Pattern

Universal Models:

Up to 400 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt

1.69"-6.55"

(43-166mm)

+15/-5°

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

19.37" x 18.00" x 1.69"-6.55"

(492 x 457 x 43-166mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

9.1lb

(4.13kg)

CERTIFICATIONS

VERTICAL ADAPTER

6.55"

(166mm)

15°

-5°

SIDE VIEW

FORWARD TILT

3.00"

(76mm)

SIDE VIEW

BACKWARD TILT

ISOMETRIC VIEW

Pending

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACCXT302:

Video Conferencing Shelf ...... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

ACCXT402:

Recessed Power Outlet with Low Voltage

In-Wall Cable Routing ............. pg# 189

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

27

Universal Tilt

Wall Mount

For 32" to 55" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

STX650

STX650L

Ravens black Locking

Includes standard hardware (hex or Phillips) for attaching display to mount

STX650P

Ravens black

SCREEN ADAPTER

Mounting Pattern

Universal Models:

723 x 433mm

(28.46"W x 17.04"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt

1.69"-6.55"

(43-166mm)

+15/-5°

Max Load

120lb

(54kg)

Product Dimensions (W x H x D)

Mounting Surfaces

30.87" x 18.00" x 1.69"-6.55"

(784 x 457 x 43-166mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

11lb

(4.99kg)

CERTIFICATIONS

Pending

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACCXT302:

Video Conferencing Shelf ...... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

ACCXT402:

Recessed Power Outlet with Low Voltage

In-Wall Cable Routing ............. pg# 189

1.

Low-profile design holds display

1.69" (43mm) from wall

2.

Increased security with included

Master Lock 510KAD keyed-alike padlock on STX650L only

3.

Universal tilt adapter brackets offer up to +15/-5° of One-Touch™ tilt adjustment in one easy motion

4.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

5.

Up to 1" (25mm) of vertical adjustment on each universal display adapter bracket for post-installation leveling and height adjustment fine-tuning

6.

Up to 24" (610mm) of horizontal display adjustment for centering display on wall

7.

Open wall plate design allows for total wall access, increasing electrical and cable management options

8.

Universal tilt adapter brackets easily hook onto wall plate for fast installation

9.

Fits displays with mounting hole patterns from 100 x 100mm (3.94"W x 3.94"H) to 723 x 433mm (28.46"W x 17.04"H)

10.

5º of negative tilt offers 3" (76mm) of space for hands-free, behind the display access

Reseller Authorization Required

TECHNICAL DRAWINGS

Patent Pending

For expanded product information and technical data visit www.peerless-av.com

7

3

5

2

9.15"

(232mm)

30.87"

(784mm)

6.03"

(153mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

29.38"

(746mm)

WALL PLATE

28.46"

(723mm)

1.00"

(25mm)

8.15"

(207mm)

0.76"

(19mm)

2.73"

(69mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL ADAPTER

1.69"

(43mm)

6.55"

(166mm)

15°

ISOMETRIC VIEW

-5°

FRONT VIEW

3.00"

(76mm)

17.04"

(433mm)

SIDE VIEW

SIDE VIEW

FORWARD TILT

3.00"

(76mm)

SIDE VIEW

BACKWARD TILT

28

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 46" to 70" Flat Panel Displays

1.

Low-profile design holds display

1.69" (43mm) from wall

2.

Increased security with included

Master Lock 510KAD keyed-alike padlock on STX660L only

3.

Universal tilt adapter brackets offer up to +15/-5° of One-Touch™ tilt adjustment in one easy motion

4.

Included IncreLok

TM

feature offers fixed tilt lock in 5° increments when used

5.

Up to 1" (25mm) of vertical adjustment on each universal display adapter bracket for post-installation leveling and height adjustment fine-tuning

6.

Up to 23" (584mm) of horizontal display adjustment for centering display on wall

7.

Open wall plate design allows for total wall access, increasing electrical and cable management options

8.

Universal tilt adapter brackets easily hook onto wall plate for fast installation

9.

Fits displays with mounting hole patterns from 100 x 100mm (3.94"W x 3.94"H) to 805 x 433mm (31.71"W x 17.04"H)

10.

5º of negative tilt offers 3" (76mm) of space for hands-free, behind the display access

Patent Pending

For expanded product information and technical data visit www.peerless-av.com

9.15"

(232mm)

34.12"

(867mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

32.63"

(829mm)

WALL PLATE

6.03"

(153mm)

1.00"

(25mm)

8.15"

(207mm)

31.71"

(805mm)

0.76"

(19mm)

2.73"

(69mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL ADAPTER

1.69"

(43mm)

6.55"

(166mm)

15°

ISOMETRIC VIEW

-5°

FRONT VIEW

3.00"

(76mm)

17.04"

(433mm)

SIDE VIEW

7

3

5

2

Reseller Authorization Required

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

STX660

STX660L

Ravens black Locking

Includes standard hardware (hex or Phillips) for attaching display to mount

STX660P

Ravens black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

805 x 433mm

(31.71"W x 17.04"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt

1.69"-6.55"

(43-166mm)

+15/-5°

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

34.12" x 18.00" x 1.69"-6.55"

(867 x 457 x 43-166mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

11.7lb

(5.31kg)

CERTIFICATIONS

SIDE VIEW

FORWARD TILT

3.00"

(76mm)

SIDE VIEW

BACKWARD TILT

Pending

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACCXT302:

Video Conferencing Shelf ...... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

ACCXT402:

Recessed Power Outlet with Low Voltage

In-Wall Cable Routing ............. pg# 189

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

29

Articulating

Wall Arm

For 40" to 52" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SAX755PU

black

SCREEN ADAPTER

Mounting Pattern

Universal Models:

661 x 449mm

(26.03"W x 17.69"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

2.54"-26.41"

(65-671mm)

+15/-5° | ±90° | ±90°

Max Load

80lb

(36kg)

Landscape to Portrait

Display can be rotated landscape to portrait without removing the display

Product Dimensions

(W x H x D)

Mounting Surfaces

29.00" x 19.50" x 2.54"-26.41"

(737 x 495 x 65-671mm)

CERTIFICATIONS

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

OSHPD Approval Pending

Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC955:

Component Shelf Accessory ... pg#189

ACCXT100:

Left & Right Speaker

Accessory Mount .................. pg# 189

ACCXT200:

Soundbar and Center

Channel Accessory Mount ..... pg# 189

ACCXT300:

Video Conferencing

Shelf Accessory .................... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

30

1.

Low-profile when retracted at 2.54" (65mm) and can extend up to 26.41" (671mm) from the wall

2.

Internal cable management provides ample area to run cables to complete a clean, professional installation

3.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

4.

±5° of roll for post-installation leveling

5.

Display can be rotated from landscape to portrait without removing the display

6.

±0.5" (13mm) of vertical adjustment for postinstallation height adjustment fine-tuning

7.

Single stud wall plate design increases electrical and cable management options

Reseller Authorization Required

TECHNICAL DRAWINGS

5.00

(127mm)

3.13"

(79mm)

0.88"

(22mm)

1.46"

(37mm)

0.66"

(17mm)

19.50"

(495mm)

14.50"

(368mm)

17.00"

(432mm)

7.25"

(184mm)

4.26"

(108mm)

WALL PLATE

29.00"

(737mm)

26.03"

(661mm)

MAX.

7.87"

(200mm)

7.87"

(200mm)

17.69"

(449mm)

MAX.

VERTICAL ADAPTER

2.54"

(65mm)

15°

ISOMETRIC VIEW

26.41" - 29.07"

(671 - 738mm)

FRONT VIEW SIDE VIEW

SIDE VIEW

EXTENDED

1

For expanded product information and technical data visit www.peerless-av.com

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 40" to 63" Flat Panel Displays

1.

Low-profile when retracted at

2.6" (66mm) and can extend up to 26.54" (674mm) from the wall

2.

Internal cable management provides ample area to run cables to complete a clean, professional installation

3.

Stylish wall plate covers create a finished look and are easy to install and remove

4.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

5.

±5° of roll for post-installation leveling

6.

Display can be rotated from landscape to portrait without removing the display

7.

±0.5" (13mm) of vertical adjustment for postinstallation height adjustment fine-tuning

8.

Open wall plate design increases electrical and cable management options

9.

Removable cover for wall plate knockout included

Optional Accessory ACCXT400

For expanded product information and technical data visit www.peerless-av.com

1

2

9

Reseller Authorization Required

TECHNICAL DRAWINGS

.88"

(22mm)

19.00"

(483mm)

19.70"

(500mm)

17.70"

(450mm)

7.87"

(200mm)

5.61"

(142mm)

0.88"

(22mm)

1.46"

(37mm)

0.66"

(17mm)

19.50"

(495mm)

16.00"

(406mm)

WALL PLATE

5.20"

(132mm)

29.00"

(737mm)

26.03"

(661mm)

MAX.

7.87"

(200mm)

17.69"

(449mm)

MAX.

2.60"

(66mm)

VERTICAL ADAPTER

15°

26.54" - 29.19"

(674 - 742mm)

FRONT VIEW SIDE VIEW

SIDE VIEW

EXTENDED

ISOMETRIC VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SAX762PU

black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

661 x 449mm

(26.03"W x 17.69"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

2.60"-26.54"

(66-674mm)

+15/-5° | ±90° | ±90°

Max Load

110lb

(50kg)

Landscape to Portrait

Display can be rotated landscape to portrait without removing the display

Product Dimensions

(W x H x D)

Mounting Surfaces

29.00" x 19.5" x 2.60"-26.54"

(737 x 495 x 66-674mm)

CERTIFICATIONS

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

OSHPD Approval Pending

Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC955:

Component Shelf Accessory ... pg#189

ACCXT100:

Left & Right Speaker

Accessory Mount .................. pg# 189

ACCXT200:

Soundbar and Center

Channel Accessory Mount ..... pg# 189

ACCXT300:

Video Conferencing

Shelf Accessory .................... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

ACCXT400:

Recessed Power Outlet with Low

Voltage In-Wall Cable Routing .. pg# 189

31

Articulating

Wall Arm

For 50" to 71" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SAX772PU

black

SCREEN ADAPTER

Mounting Pattern

Universal Models:

813 x 607mm

(32.03"W x 23.91"H)

VESA

®

Pattern

Universal Models:

Up to 800 x 600mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

2.60"-26.54"

(66-674mm)

+15/-5° | ±90° | ±90°

Max Load

135lb

(61.23kg)

Landscape to Portrait

Display can be rotated landscape to portrait without removing the display

Product Dimensions (W x H x D)

Mounting Surfaces

35.00" x 24.75" x 2.60"-26.54"

(889 x 629 x 66-674mm)

CERTIFICATIONS

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

OSHPD Approval Pending

Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC955:

Component Shelf Accessory ... pg#189

ACCXT100:

Left & Right Speaker

Accessory Mount .................. pg# 189

ACCXT200:

Soundbar and Center

Channel Accessory Mount ..... pg# 189

ACCXT300:

Video Conferencing

Shelf Accessory .................... pg# 189

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

ACCXT400:

Recessed Power Outlet with Low

Voltage In-Wall Cable Routing .. pg# 189

32

1.

Low-profile when retracted at 2.6"

(66mm) and can extend up to 26.54"

(674mm) from the wall

2.

Internal cable management provides ample area to run cables to complete a clean, professional installation

3.

Stylish wall plate covers create a finished look and are easy to install and remove

4.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

5.

±5° of roll for post-installation leveling

6.

Display can be rotated from landscape to portrait without removing the display

7.

±0.5" (18mm) of vertical adjustment for post-installation height adjustment fine-tuning

8.

Dual arms for a more robust installation

9.

Open wall plate design increases electrical and cable management options

10.

Removable cover for wall plate knockout included

Reseller Authorization Required

TECHNICAL DRAWINGS

Optional Accessory ACCXT400

1

2

10

For expanded product information and technical data visit www.peerless-av.com

.88"

(22mm)

19.00"

(483mm)

0.88"

(22mm)

1.46"

(37mm)

0.66"

(17mm)

19.70"

(500mm)

17.70"

(450mm)

7.87"

(200mm)

5.61"

(142mm)

24.75"

(629mm)

16.00"

(406mm)

WALL PLATE

5.20"

(132mm)

35.00"

(889mm)

32.03"

(813mm)

MAX.

7.87"

(200mm)

23.91"

(607mm)

MAX.

2.60"

(66mm)

VERTICAL ADAPTER

15°

26.54" - 29.19"

(674 - 742mm)

FRONT VIEW SIDE VIEW

SIDE VIEW

EXTENDED

ISOMETRIC VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 10" to 24" Flat Panel Displays

1.

VESA ® 75 and 100mm compliant

2.

Non-VESA ® display adapter plates also available

3.

Low-profile design holds display 0.96" (24mm) away from the wall

4.

Display adapter plate simply hooks onto wall plate for quick and easy installation

1

4

3

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF630

SF630-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF630P

SF630P-S

Silver

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

0.96"

(24mm)

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

6.02" x 5.75" x 0.96"

(153 x 146 x 24mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

2.5lb

(1.13kg)

CERTIFICATIONS

2.95"

(75mm)

3.94"

(100mm)

0.96"

(24mm)

3.94"

(100mm)

5.07"

(129mm)

2.95"

(75mm)

FRONT VIEW

SIDE VIEW

0.38"

(10mm)

5.00"

(127mm)

6.02"

(153mm)

5.75"

(146mm)

ISOMETRIC VIEW

WALL PLATE

ø0.28"

(7mm)

TYP.

(4 PLCS.)

OSHPD Approval Pending

ACCESSORIES

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

33

Universal Flat

Wall Mount

For 22" to 40" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF632

Black

SF632-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF632P

SF632P-S

Silver

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

1.02"

(26mm)

Max Load

115lb

(52kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

8.75" x 9.35" x 1.02"

(222 x 237 x 26mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

4lb

(1.81kg)

CERTIFICATIONS

1.

VESA ® 75, 100, 200 x 100 and

200 x 200mm compliant

2.

Non-VESA ® display adapter plates also available

3.

Low-profile design holds display 1.02" (26mm) away from the wall

4.

Display adapter plate simply hooks onto wall plate for quick and easy installation

4.

Compatible with flat panels that use M8 screws

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

1

4

3

OSHPD Approval Pending

ACCESSORIES

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

6.02"

(153mm)

3.94"

(100mm)

5.75"

(146mm)

3.94"

(100mm)

2.95"

(75mm)

FRONT VIEW

8.75"

(222mm)

7.87"

(200mm)

2.95"

(75mm)

9.35"

(237mm)

7.87"

(200mm)

3.94"

(100mm)

7.87"

(200mm)

0.95"

(24mm)

SIDE VIEW

1.02"

(26mm)

3.94"

(100mm)

FRONT VIEW

ADAPTER PLATE

SIDE VIEW

ADAPTER PLATE

ISOMETRIC VIEW

0.38"

(10mm)

5.00"

(127mm)

6.02"

(153mm)

5.75"

(146mm)

WALL PLATE

34

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 23" to 46" Flat Panel Displays

1.

Open wall plate design allows for total wall access, increasing electrical and cable management options

2.

Low-profile design holds display only 1.2" (30mm) from the wall

3.

Easy-Glide TM design ensures display is securely attached to wall plate

4.

Horizontal display adjustment up to 6" (152mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns up to 450 x 329mm

(17.73"W x 12.94"H)

For expanded product information and technical data visit www.peerless-av.com

9.15"

(232mm)

19.37"

(492mm)

6.03"

(153mm)

16.00"

(406mm)

17.88"

(454mm)

WALL PLATE

17.73"

(450mm)

MAX.

1.00"

(25mm)

8.15"

(207mm)

12.94"

(329mm)

MAX.

0.76"

(19mm)

1.25"

(32mm)

0.82"

(21mm)

13.75"

(349mm)

VERTICAL ADAPTER

1.20"

(30mm)

1

3

5

2

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF640

SF640-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF640P

SF640P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

450 x 329mm

(

17.73"W x 12.94"H)

Many 42" flat panel displays have mounting hole patterns larger than dimensions above.

Use MountFinder™ to verify mount compatibility.

VESA ® Pattern

Universal Models:

Up to 400 x 300mm

SPECIFICATIONS

Distance from Wall

1.20"

(30mm)

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

19.37" x 13.75" x 1.20"

(492 x 349 x 30mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

5.7lb

(2.58kg)

ISOMETRIC VIEW

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

FRONT VIEW

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

35

Universal Flat

Wall Mount

For 32" to 56" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF650

Black

SF650-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF650P

SF650P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

742 x 433mm

(29.23"W x 17.05"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

1.70"

(43mm)

Max Load

175lb

(79kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

30.87" x 18.00" x 1.70"

(784 x 457 x 43mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

8lb

(3.62kg)

CERTIFICATIONS

1.

Open wall plate design allows for total wall access, increasing electrical and cable management options

2.

Low-profile design holds display only 1.7"

(43mm) from the wall

3.

Easy-Glide TM design ensures display is securely attached to wall plate

4.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns up to 742 x 433mm

(29.23"W x 17.05"H)

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

1

3

5

2

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

9.15"

(232mm)

30.87"

(784mm)

6.03"

(153mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

29.38"

(746mm)

WALL PLATE

29.23"

(742mm)

MAX.

FRONT VIEW

1.00in

25mm

8.15"

(207mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL ADAPTER

1.70"

(43mm)

17.05"

(433mm)

MAX.

ISOMERIC VIEW

SIDE VIEW

36

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 37" to 63" Flat Panel Displays

1.

Open wall plate design allows for total wall electrical and cable management options

2.

Easy-Glide TM design ensures display is securely attached to wall plate

3.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

4.

Universal display adapters easily hook onto wall plate for fast installation

5.

Fits displays with mounting hole patterns up to 825 x 433mm

(32.48"W x 17.05"H), including VESA ®

800 x 400mm

9.15"

(232mm)

For expanded product information and technical data visit www.peerless-av.com

34.12"

(867mm)

6.03"

(153mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

32.63"

(829mm)

WALL PLATE

32.48"

(825mm)

MAX.

1.00"

(25mm)

8.15"

(207mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL ADAPTER

1.25"

(32mm)

ISOMETRIC VIEW

1

2

4

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF660

SF660-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF660P

SF660P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

825 x 433mm

(

32.48"W x 17.05"H)

VESA ® Pattern

Universal Models:

Up to 800 x 400mm

SPECIFICATIONS

Distance from Wall

1.25"

(32mm)

Max Load

200lb

(90kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

34.12" x 18.00" x 1.25"

(867 x 457 x 32mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

9.4lb

(4.26kg)

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

FRONT VIEW

17.05"

(433mm)

MAX.

SIDE VIEW

SHALLOW ADAPTER

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

37

Universal Flat

Wall Mount

For 42" to 71" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF670

Black

SF670-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF670P

SF670P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

908 x 503mm

(35.75"W x 19.79"H)

SPECIFICATIONS

Distance from Wall

1.73"

(44mm)

Max Load

250lb

(113kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

37.75" x 20.63" x 1.73"

(959 x 524 x 44mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

13.1lb

(5.94kg)

CERTIFICATIONS

*

* With max load up to 200lb (90kg)

ACCESSORIES

ACC615:

6-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

1.

Low-profile design holds display only

1.73" (44mm) from

2.

Horizontal display adjustment up to 12"

(304mm) for centering display on wall

3.

Easy-Glide

TM

design ensures display is securely attached to wall plate

4.

Universal display adapters easily hook onto wall plate for fast installation

5.

Fits displays with mounting hole patterns up to 908 x 503mm

(35.75"W x 19.79"H)

6.

Wall plate knockouts provide wall access, improving cable management options

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

7.45"

(189mm)

16.00"

(406mm)

37.75"

(959mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

35.75"

(908mm)

MAX.

2.50"

(64mm)

5.50"

(140mm)

FRONT VIEW

1.00"

(25mm)

5.00"

(127mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

20.63"

(524mm)

4.00"

(102mm)

19.79"

(503mm)

MAX.

VERTICAL ADAPTER

1.73"

(44mm)

SIDE VIEW

ISOMETRIC VIEW

2

3

6

4

1

38

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 61" to 102" Flat Panel Displays

1.

Low-profile design holds display only

1.83" (46mm) from

2.

Horizontal display adjustment up to 12"

(304mm) for centering display on wall

3.

Safety latch ensures display is securely attached to wall plate

4.

Universal display adapters easily hook onto wall plate for fast installation

5.

Fits displays with mounting hole patterns up to 1111 x 745mm

(43.75"W x 29.31"H)

6.

Wall plate knockouts provide wall access, improving cable management options

7.

Supports M10

For expanded product information and technical data visit www.peerless-av.com

2

3

6

4

1

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

SF680

SF680-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SF680P

SF680P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

1111 x 745mm

(

43.75"W x 29.31"H)

SPECIFICATIONS

Distance from Wall

1.83"

(46mm)

Max Load

350lb

(158kg)

Product Dimensions (W x H x D)

Mounting Surfaces

45.75" x 30.25" x 1.83"

(1162 x 768 x 46mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

16.5lb

(7.48kg)

CERTIFICATIONS

*

* With max load up to 200lb (90kg)

7.45"

(189mm)

2.50"

(64mm)

16.00"

(406mm)

45.75"

(1162mm)

16.00"

(406mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

43.75"

(1111mm)

MAX.

1.00"

(25mm)

5.00"

(127mm)

4.00"

(102mm)

29.31"

(745mm)

MAX.

1.83"

(46mm)

ISOMETRIC VIEW

0.82"

(21mm)

1.25"

(32mm)

1.00"

(25mm)

30.25"

(768mm)

ACCESSORIES

ACC615:

6-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

5.50"

(140mm)

FRONT VIEW

SIDE VIEW VERTICAL ADAPTER

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

39

Universal Tilt

Wall Mount

For 10" to 24" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST630

Black

ST630-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST630P

ST630P-S

Silver

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

1.58"-2.23"

(40-57mm)

Tilt

+15/-5°

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

6.61" x 6.20" x 1.58"-2.23"

(168 x 157 x 40-57mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

2.9lb

(1.31kg)

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

1.

VESA ® 75 and 100mm compliant

2.

Non-VESA ® display adapter plates also available

3.

Up to +15/-5° of tilt without the use of tools

4.

Display adapter plate simply hooks onto wall plate for quick and easy installation

TECHNICAL DRAWINGS

5.15"

(131mm)

Patented

For expanded product information and technical data visit www.peerless-av.com

6.00"

(152mm)

4.50"

(114mm)

WALL PLATE

6.61"

(168mm)

3.94"

(100mm)

2.95"

(75mm)

1.58"

(40mm)

2.23"

(57mm)

15°

ISOMETRIC VIEW

6.20"

(157mm)

3.94"

(100mm)

2.95"

(75mm)

4.50"

(114mm)

FRONT VIEW SIDE VIEW

SIDE VIEW

15° TILT

3

4

40

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 22" to 40" Flat Panel Displays

1.

VESA ® 75, 100, 200 x

100 and 200 x 200mm compliant

2.

Non-VESA ® display adapter plates also available

3.

Up to +15/-5° of tilt without the use of tools

4.

Display adapter plate simply hooks onto wall plate for quick and easy installation

5.

Compatible with flat panels that use M8 screws

Patented

For expanded product information and technical data visit www.peerless-av.com

9.35"

(237mm)

7.87"

(200mm)

6.61"

(168mm)

3.94"

(100mm)

6.20"

(157mm)

3.94"

(100mm)

2.95"

(75mm)

2.95"

(75mm)

FRONT VIEW

8.75"

(222mm)

7.87"

(200mm)

4.50"

(114mm)

7.87"

3.94"

(100mm)

(200mm)

3.94"

(100mm)

FRONT VIEW

ADAPTER PLATE

1.58"

(40mm)

SIDE VIEW

1.66"

(42mm)

SIDE VIEW

ADAPTER PLATE

3

4

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST632

ST632-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST632P

ST632P-S

Silver

DISPLAY ADAPTER

VESA

®

Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

1.66" -2.91"

(42 -74mm)

Tilt

+15/-5°

Max Load

115lb

(52kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

8.75" x 9.35" x 1.66" -2.91"

(222 x 237 x 42 -74mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

4.4lb

(1.99kg)

CERTIFICATIONS

15°

2.23"

(57mm)

SIDE VIEW

15° TILT

2.91"

(74mm)

15°

ISOMETRIC VIEW

OSHPD Approval Pending

ACCESSORIES

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage

Media Plate with Duplex

Surge Suppressor ................ pg# 197

SIDE VIEW

ADAPTER PLATE

15° TILT

ISOMETRIC VIEW

ADAPTER PLATE

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

41

Universal Tilt

Wall Mount

For 13" to 37" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST635

Black

ST635-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST635P

ST635P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

245 x 241mm

(9.65"W x 9.48"H)

VESA

®

Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

2.63"-4.38"

(67-111mm)

Tilt

+15/-5°

Max Load

125lb

(56kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

13.77" x 10.30" x 2.63"-4.38"

(350 x 262 x 67-111mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

6.6lb

(2.99kg)

1.

Open wall plate design allows for total wall access, increasing electrical and cable management options

2.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

3.

Easy-Grip TM ratcheting handle locks tilt angle into place

4.

Universal display adapters easily hook onto wall plate for fast installation

5.

Fits displays with mounting hole patterns up to 245 x

241mm (9.65"W x 9.48"H), including VESA ® 75, 100,

200 x 100, and 200 x 200mm

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

1

2

3

4

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

11.00"

(279mm)

9.51"

(241mm)

8.15"

(207mm)

6.03"

(153mm)

8.00

"

(203 mm)

WALL PLATE

13.77"

(350mm)

9.65"

(245mm)

MAX.

1.00"

(25mm)

9.15"

(232mm)

9.48"

(241mm)

MAX.

FRONT VIEW

0.79"

(20mm)

1.25"

(32mm)

0.88"

(22mm)

10.30"

(262mm)

VERTICAL ADAPTER

2.63"

(67mm)

4.38"

(111mm)

15°

ISOMETRIC VIEW

SIDE VIEW

SIDE VIEW

15° TILT

42

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 23" to 46" Flat Panel Displays

1.

Open wall plate design allows for total wall access, increasing electrical and cable management options

2.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

3.

Easy-Grip TM ratcheting handle locks tilt angle into place

4.

Universal tilt adapters allow for

+15/-5° tilt adjustment in one easy motion

5.

Horizontal display adjustment up to 6" (152mm) for centering display on wall

6.

Universal display adapters easily hook onto wall plate for fast installation

7.

Fits displays with mounting hole patterns up to 458 x

329mm (18.02"W x 12.94"H)

Patented

For expanded product information and technical data visit www.peerless-av.com

19.37"

(492mm)

17.88"

(454mm)

8.15"

(207mm)

6.03"

(153mm)

16.00"

(406mm)

WALL PLATE

22.14"

(562mm)

18.02"

(458mm)

MAX.

FRONT VIEW

1.00"

(25mm)

9.15"

(232mm)

0.76"

(19mm)

1.25"

(32mm)

0.82"

(21mm)

13.75"

(349mm)

VERTICAL ADAPTER

2.63"

(67mm)

ISOMETRIC VIEW

15°

4.87"

(124mm)

12.94"

(329mm)

MAX.

SIDE VIEW

1

2

3

6

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST640

ST640-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST640P

ST640P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

458 x 329mm

(18.02"W x 12.94"H)

Many 42" flat panel displays have mounting hole patterns larger than dimensions above.

Use MountFinder™ to verify mount compatibility.

VESA ® Pattern

Universal Models:

Up to 400 x 300mm

SPECIFICATIONS

Distance from Wall

Tilt

2.63"-4.87"

(67-124mm)

+15/-5°

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

22.14" x 13.75" x 2.63"-4.87"

(562 x 349 x 67-124mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

8.5lb

(3.85kg)

SIDE VIEW

15° TILT

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 197

ACC309:

Video Conference Shelf ....... pg# 167

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

43

Universal Tilt

Wall Mount

For 32" to 56" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST650

Black

ST650-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST650P

ST650P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

750 x 449mm

(

29.52"W x 17.67"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

2.63"-5.71"

(67-145mm)

Tilt

+15/-5°

Max Load

175 lb

(79kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

33.64" x 18.50" x 2.63"-5.71"

(854 x 470 x 67-145mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

10.5lb

(4.76kg)

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

TECHNICAL DRAWINGS

1.

Open wall plate design allows for total wall access, increasing electrical and cable management options

2.

Universal tilt adapters allow for +15/-5° tilt adjustment in one easy motion

3.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

4.

Easy-Grip TM ratcheting handle locks tilt angle

5.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

6.

Universal display adapters easily hook onto wall plate for fast installation

7.

Fits displays with mounting hole

patterns: 750 x 449mm

(29.52"W x 17.67"H)

8.15"

(207mm)

30.87"

(784mm)

29.38"

(746mm)

6.03"

(153mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

33.64"

(854mm)

29.52"

(750mm)

MAX.

FRONT VIEW

Patented

For expanded product information and technical data visit www.peerless-av.com

1.00"

(25mm)

9.15"

(232mm)

17.67"

(449mm)

MAX.

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.50"

(470mm)

VERTICAL ADAPTER

2.63"

(67mm)

ISOMETRIC VIEW

15°

5.71"

(145mm)

SIDE VIEW SIDE VIEW

15° TILT

2

1

3

4

6

44

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 37" to 63" Flat Panel Displays

1.

Open wall plate design allows for total wall access, increasing electrical and cable management options

2.

Universal tilt adapters allow for +15/-5° tilt adjustment in one

3.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

4.

Easy-Grip TM ratcheting handle locks tilt angle

5.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

6.

Universal display adapters easily hook onto wall plate for fast installation

7.

Fits displays with mounting hole patterns of 832 x 449mm (32.75"W x 17.67"H), including

VESA ® 800 x 400mm

Patented

For expanded product information and technical data visit www.peerless-av.com

2

1

3

4

6

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST660

ST660-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST660P

ST660P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

832 x 449mm

(32.75"W x 17.67"H)

VESA ® Pattern

Universal Models:

Up to 800 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt

2.63"-5.71"

(67-145mm)

+15/-5°

Max Load

200 lb

(90kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

36.87" x 18.50" x 2.63"-5.71"

(936 x 470 x 67-145mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

11lb

(5kg)

8.15"

(207mm)

34.12"

(867mm)

32.63"

(829mm)

6.03"

(153mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

36.87"

(936mm)

32.75"

(832mm)

MAX.

FRONT VIEW

1.00"

(25mm)

9.15"

(232mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.50"

(470mm)

VERTICAL ADAPTER

2.63"

(67mm)

17.67"

(449mm)

MAX.

SIDE VIEW

ISOMETRIC VIEW

15°

5.71"

(145mm)

SIDE VIEW

15° TILT

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

45

Universal Tilt

Wall Mount

For 42" to 71" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST670

Black

ST670-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST670P

ST670P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

915 x 503mm

(36.04"W x 19.80"H)

SPECIFICATIONS

Distance from Wall

3.04"-6.41"

(77-163mm)

Tilt

+15/-5°

Max Load

250lb

(113kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

40.16" x 20.63" x 3.04"-6.41"

(1020 x 524 x 77-163mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

15.4lb

(6.98kg)

CERTIFICATIONS

*

* With max load up to 200lb (90kg)

ACCESSORIES

ACC615:

6-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

TECHNICAL DRAWINGS

1.

Universal tilt adapters allow for +15/-5° tilt adjustment in one

2.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

3.

Easy-Grip TM ratcheting handle locks tilt angle

4.

Horizontal display adjustment up to 12"

(304mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns of 915 x 503mm

(36.04"W x 19.80"H)

7.

Wall plate knockouts provide wall access improving cable management options

Patented

For expanded product information and technical data visit www.peerless-av.com

5.00"

(127mm)

16.00"

(406mm)

37.75"

(959mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

5.50"

(140mm)

40.16"

(1020mm)

36.04"

(915mm)

MAX

4.00"

(102mm)

5.50"

(140mm)

FRONT VIEW

1.00"

(25mm)

7.45"

(189mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

20.63"

(524mm)

VERTICAL BRACKET

3.04"

(77mm)

ISOMETRIC VIEW

15°

6.41"

(163mm)

2.50"

(64mm)

19.80"

(503mm)

MAX

SIDE VIEW

SIDE VIEW

15° TILT

3

7

5

1

2

46

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 61" to 102" Flat Panel Displays

1.

Universal tilt adapters allow for +15/-5° tilt adjustment in one

2.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

3.

Easy-Grip TM ratcheting handle locks tilt angle

4.

Horizontal display adjustment up to 12"

(304mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for fast installation

6.

Fits displays with mounting hole patterns of 1119 x 745mm

(44.04"W x 29.31"H)

7.

Wall plate knockouts provide wall access improving cable management options

8.

Supports M10 mounting bolts

Patented

For expanded product information and technical data visit www.peerless-av.com

5.00"

(127mm)

16.00"

(406mm)

45.75"

(1162mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

48.16"

(1223mm)

44.04"

(1119mm)

MAX

5.50"

(140mm)

4.00"

(102mm)

2.50

"

(64mm)

FRONT VIEW

1.00"

(25mm)

7.45"

(189mm)

2.50"

(64mm)

29.31"

(745mm)

MAX

1

2

3

7

5

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

ST680

ST680-S

Black

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

ST680P

ST680P-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

1119 x 745mm

(44.04"W x 29.31"H)

SPECIFICATIONS

Distance from Wall

Tilt

3.04"-8.77"

(77-223mm)

+15/-5°

Max Load

350lb

(158kg)

Product Dimensions (W x H x D)

Mounting Surfaces

48.16" x 30.25" x 3.04"-8.77"

(1223 x 768 x 77-223mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

18.2lb

(8.2kg)

CERTIFICATIONS

*

* With max load up to 200lb (90kg)

0.82"

(21mm)

1.25"

(32mm)

1.00"

(25mm)

30.25"

(768mm)

VERTICAL ADAPTER

3.04"

(77mm)

ISOMETRIC VIEW

15°

8.77"

(223mm)

ACCESSORIES

ACC615:

6-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC309:

Video Conference Shelf ....... pg# 166

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

SIDE VIEW SIDE VIEW

15° TILT

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

47

Pivot

Wall Mount

For 10" to 26" Flat Panel Displays

MODELS

Includes standard hardware (hex or Phillips) for attaching display to mount

Universal Models:

10" to 24" displays

SP730P

High gloss black

SP730P-S

High gloss silver

Universal Models:

10" to 26" displays

SP735P

High gloss black

SP735P-S

High gloss silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models

SP735P(-S):

200 x 162mm

(7.87"W x 6.39"H)

VESA ® Pattern

Universal Models

SP730P(-S):

75 and 100mm

SP735P(-S):

Up to 200 x 100mm

SPECIFICATIONS

Distance from Wall

SP730P(-S):

SP735P(-S):

2.19"-9.31"

(56-237mm)

2.71"-10.16"

(69-258mm)

Tilt | Swivel | Roll

±35° | ±90° | ±7°

Max Load

25lb

(11kg)

Product Dimensions (W x H x D)

SP730P(-S):

10.69" x 8.05" x 2.19"-9.31"

(272 x 204 x 56-237mm)

SP735P(-S):

13.19" x 8.05" x 2.71"-10.16"

(335 x 204 x 69-258mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

SP730P(-S):

SP735P(-S):

2.76lb

(1.2kg)

3.7lb

(1.7kg)

CERTIFICATIONS

ACCESSORIES

ACC918:

Security Fasteners ................ pg# 199

WSP700/WSP701:

Metal Stud Wall Plates for

16"/24" Center Metal Studs .. pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

48

1.

Arm extends up to

9.31" (237mm) from wall with SP730P models and

10.16" (258mm) with

SP735P(-S)

2.

One-Touch™ tilt mechanism allows adjustment of ±35° without the use

3.

Up to 90° of side-to-side swivel

4.

±7° of roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

SP730P

Holds 10"-24" displays

SP735P

Holds 10"-26" displays

1

5

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

6.87"

(175 mm)

8.05"

(204 mm)

2.19"

(56 mm)

3.94"

(100 mm)

MAX

6.85"

(174 mm)

TOP VIEW

3.94"

(100 mm)

MAX

8.05

(204 mm)

10.69"

(272 mm)

FRONT VIEW

2.71"

(69 mm)

TOP VIEW

7.87"

(200 mm)

MAX 13.19"

(335 mm)

6.39"

(162 mm)

MAX

FRONT VIEW

SIDE VIEW

RETRACTED

SIDE VIEW

RETRACTED

SP730P

2.19"

(56 mm)

SP735P

2.71"

(69 mm)

9.31"

(237 mm)

SIDE VIEW

EXTENDED

8.05"

(204 mm)

10.16"

(258 mm)

SIDE VIEW

EXTENDED

2.97"

(75 mm)

.49"

(13 mm)

WALL PLATE

6.50"

(165 mm)

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Pivot

Wall Mount

For 22" to 46" Flat Panel Displays

1.

Arm extends up to

11.8" (299mm) from wall with SP740P models and

12.55" (319mm) with

SP746PU models

2.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

3.

Up to ±90° of side-to-side swivel

4.

±5° of roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

6.

Compatible with flat panels that use M8 screws

SP740P

Holds 22"-40" displays

SP746PU

Holds 26"-46" displays

Patented

For expanded product information and technical data visit www.peerless-av.com

SP740P

14.24"

(362mm)

7.87"

(200mm)

9.35"

(237mm)

FRONT VIEW

7.87"

(200mm)

TOP VIEW

2.99"

(76mm)

SIDE VIEW

RETRACTED

SP746PU

17.00"

(432mm)

MAX.

18.75"

(476mm)

TOP VIEW

3.74"

(95mm)

16.06"

(408mm)

MAX.

17.00"

(432mm)

FRONT VIEW SIDE VIEW

RETRACTED

11.80"

(299mm)

SIDE VIEW

EXTENDED

12.55"

(319mm)

SIDE VIEW

EXTENDED

8.05"

(204mm)

3.00"

(76mm)

6.50"

(165mm)

WALL PLATE

.50"

(13mm)

1

5

TECHNICAL DRAWINGS

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

MODELS

Includes standard hardware (hex or Phillips) for attaching display to mount

Universal Models:

22" to 40" displays

SP740P

High gloss black

SP740P-S

High gloss silver

Universal Models:

26" to 46" displays

SP746PU

High gloss black

DISPLAY ADAPTER

Mounting Pattern

Universal Models

SP746PU:

432 x 408mm

(17"W x 16.06"H)

VESA ® Pattern

Universal Models

SP740P(-S):

75, 100, 200 x 100 and 200 x 200mm

SP746PU:

Up to 400 x 400mm

SPECIFICATIONS

Distance from Wall

SP740P(-S):

SP746PU:

Tilt | Swivel | Roll

Max Load

2.99"-11.80"

(76-299mm)

3.74"-12.55"

(95-319mm)

+15/-5° | ±90° | ±5°

80lb

(36kg)

Product Dimensions (W x H x D)

SP740P(-S):

14.24" x 9.35" x 2.99"-11.80"

(362-349 x 237 x 76-299mm)

SP746PU:

18.75" x 17.00" x 3.74"-12.55"

(476 x 432 x 95-319mm)

Mounting Surfaces

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

SP740P(-S):

SP746PU:

CERTIFICATIONS

6.7lb

(3kg)

7.7lb

(3.5kg)

OSHPD Approval Pending

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700/WSP701:

Metal Stud Wall Plates for

16"/24" Center Metal Studs .. pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

49

Pull-Out Pivot

Wall Mount

For 26" to 65" Flat Panel Displays

MODELS

Universal Models:

32" to 65" displays

Includes theft resistant hardware for attaching display to mount

SP850-UNL

Black

SP850-UNL-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

SP850-UNLP

SP850-UNLP-S

Silver

SP850-UNLP-GB

High gloss black

SP850-UNLP-GS

High gloss silver

Dedicated Models:

26" to 58" displays

Display adapter purchased separately for non-VESA ® displays*

Includes theft resistant hardware for attaching display to mount

SP850

Black

SP850-S

Includes standard hardware (hex or Phillips) for attaching display to mount

SP850P

SP850P-S

Silver

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

729 x 433mm

(28.7"W x 17.05"H)

VESA ® Pattern

Dedicated Models:

100 and 200 x 100mm

Non-VESA ® compliant displays require display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

(See drawing)

Tilt | Swivel | Roll

3.40"-11.90"

(86-302mm)

2.31"-10.68"

(59-271mm)

0°, 5° or 10° | ±45° | ±1°

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

Universal Models:

30.75" x 18.00" x 3.40"-11.90"

(781 x 457 x 86-302mm)

Dedicated Models:

21.00" x 9.76" x 2.31"-10.68"

(533 x 248 x 59-271mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and cinder block

Universal Models:

Dedicated Models:

39lb

(17.6kg)

22.7lb

(10.24kg)

CERTIFICATIONS

OSHPD Approval Pending

SP850(P)(-S)

ACCESSORIES

WSP816/WSP820/WSP824:

Metal Stud Wall Plates .......... pg# 196

50

1.

Arms extend up to

10.68" (271mm) from wall (plus thickness of adapter plate)

2.

Pull-out pivot with up to 90° rotation

3.

Included IncreLok TM feature offers 0°, 5° or 10° lockable tilt

4.

Built-in cable management

5.

±1° of roll for post installation display leveling

6.

Locking tab included for optional pivot restriction to one side

7.

Dedicated models include VESA ® 100 and

200 x 100mm compliant adapter plate

8.

Lock Key™ installation tool secures arms for display installation

TECHNICAL DRAWINGS

6.75"

(171mm)

10.68"

(271mm)

16.00"

(406mm)

6.00"

(152mm)

Dedicated Models

4

Patented

For expanded product information and technical data visit www.peerless-av.com

3.89"

(99mm)

2.31"

(59mm)

9.02"

(229mm)

3.00"

(76mm)

Universal Models

21.00"

(533mm)

1

8

Dedicated Models

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 10" to 24" Flat Panel Displays

1.

VESA ® 75 and

2.

Arm extends up to 16.06" (408mm)

3.

Three adjustable pivot points for versatile display positioning

4.

One-Touch™ tilt mechanism allows adjustment of ±35° without the use of tools

5.

±7° of roll for post installation display leveling

6.

Up to ±90° of

7.

Integrated cable

management system keep cables out of the way

8.

Display is centered on wall plate

9.

Non-VESA ® adapter plates also available

Patented

For expanded product information and technical data visit www.peerless-av.com

2

7

8

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA730P

High gloss black

SA730P-S

High gloss silver

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

2.19"-16.06"

(56-408mm)

±35° | ±90° | ±7°

Max Load

25lb

(11kg)

Product Dimensions (W x H x D)

Mounting Surfaces

9.60" x 8.05" x 2.19"-16.06"

(244 x 204 x 56-408mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

3.5lb

(1.5kg)

CERTIFICATIONS

9.60"

(244mm)

TOP VIEW

3.94"

(100mm)

2.95"

(75mm)

2.97"

(75mm)

8.05"

(204mm)

0.50"

(13mm)

6.50"

(165mm)

WALL PLATE

2.19"

(56mm)

ISOMETRIC VIEW

16.06"

(408mm)

ACCESSORIES

ACC918:

Security Fasteners ................ pg# 199

WSP700/WSP701:

Metal Stud Wall Plates for

16"/24" Center Metal Studs .. pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

2.95"

(75mm)

3.94"

(100mm)

FRONT VIEW

SIDE VIEW

RETRACTED

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

51

Articulating

Wall Arm

For 10" to 26" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA735P

High gloss black

SA735P-S

High gloss silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

7.93"W x 6.26"H

(201 x 159mm)

VESA

®

Pattern

Universal Models:

Up to 200 x 100mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel | Roll

3.03"-16.90"

(77-429mm)

±35° | ±90° | ±7°

Max Load

25lb

(11kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

12.08" x 8.05" x 3.03"-16.90"

(307 x 204 x 77-429mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

4.2lb

(1.9kg)

CERTIFICATIONS

1.

Universal display adapters provide compatibility with displays with up to a VESA ® 200 x 100mm mounting hole pattern

2.

Arm extends up to

from wall

3.

Three adjustable pivot points for versatile display positioning

4.

One-Touch™ tilt mechanism allows adjustment of ±35° without the use of tools

5.

±7° of roll for post installation display leveling

6.

Integrated cable management keeps cables out of the way

7.

Display is centered on wall plate

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

2

4

6

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700/WSP701:

Metal Stud Wall Plates for

16"/24" Center Metal Studs .. pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

6.73in

(171 mm)

3.03in

(77 mm)

TOP VIEW

12.08in

(307 mm)

7.93in

(201 mm)

MAX

8.05in

(204 mm)

6.26in

(159 mm)

MAX

FRONT VIEW

SIDE VIEW

RETRACTED

3.00in

(76 mm)

8.05in

(204 mm)

.49in

(13 mm)

6.50in

(165 mm)

3.03in

(77 mm)

WALL PLATE

16.90in

(429 mm)

SIDE VIEW

EXTENDED

52

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 22" to 40" Flat Panel Displays

1.

VESA ® 75, 100, 200 x

100 and 200 x 200mm compliant

2.

Arm extends up to 20.18"

(513mm) from wall

3.

Three adjustable pivot points for versatile display positioning

4.

One-Touch™ tilt mechanism allows adjustment of +15/-5° without the use of tools

5.

Up to ±90° of side-to-side swivel

6.

±5° of roll for post installation display leveling

7.

Integrated cable management keeps cables out of the way

8.

Display is centered on

9.

Non-VESA ® adapter plates also available

10.

Compatible with flat panels that use M8 screws

Patented

For expanded product information and technical data visit www.peerless-av.com

3.00"

(76mm)

0.50"

(13mm)

13.25"

(337mm)

8.05"

(204mm)

6.50"

(165mm)

9.35"

(237mm)

7.87"

(200mm)

TOP VIEW

8.75"

(222mm)

7.87"

(200mm)

3.94"

(100mm)

FRONT VIEW

WALL PLATE

3.35"

(85mm)

3.94"

(100mm)

7.87"

(200mm)

SIDE VIEW

RETRACTED

ISOMETRIC VIEW

20.18" - 21.41"

(513mm - 544mm)

2

7

8

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA740P

High gloss black

SA740P-S

High gloss silver

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

3.35"-20.18"

(85-513mm)

Tilt | Swivel | Roll

+15/-5° | ±90° | ±5°

Max Load

80lb

(36kg)

Product Dimensions (W x H x D)

Mounting Surfaces

13.25" x 9.35" x 3.35"-20.18"

(337 x 237 x 85-513mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

8.45lb

(3.8kg)

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700/WSP701:

Metal Stud Wall Plates for

16"/24" Center Metal Studs .. pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

53

Articulating

Wall Arm

For 26" to 46" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA746PU

High gloss black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

432 x 408mm

(17"W x 16.06"H)

VESA

®

Pattern

Universal Models:

Up to 400 x 400mm

SPECIFICATIONS

Distance from Wall

4.34"-20.92"

(110-531mm)

Tilt | Swivel | Roll

+15/-5° | ±90° | ±5°

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

18.75" x 17.00" x 4.34"-20.92"

(476 x 432 x 110-531mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

9.5lb

(4.3kg)

CERTIFICATIONS

1.

Universal display adapters provide compatibility with displays with up to a

VESA

®

400 x 400mm mounting hole pattern

2.

Arm extends up to

from wall

3.

Three adjustable pivot points for versatile display positioning

4.

One-Touch™ tilt mechanism allows adjustment of +15°/-5° without the use of tools

5.

±5° of roll for post installation display leveling

6.

Integrated cable management keeps cables out of the way

7.

Display is centered on wall plate

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

6

2

4

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700/WSP701:

Metal Stud Wall Plates for

16"/24" Center Metal Studs .. pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

3.00"

(76mm)

8.05"

(204mm)

WALL PLATE

18.75"

(476mm)

17.00"

(432mm)

MAX.

0.50"

(13mm)

6.50"

(165mm)

16.06"

(408mm)

MAX.

0.85"

(21mm)

1.25"

(32mm)

0.91"

(23mm)

17.00"

(432mm)

VERTICAL ADAPTER

4.34"

(110mm)

ISOMETRIC VIEW

20.92"

(531mm)

FRONT VIEW

SIDE VIEW

SIDE VIEW

EXTENDED

54

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 32" to 52" Flat Panel Displays

1.

Arm extends up to

27.43" (697mm) from wall (including thickness of display adapter)

2.

Integrated cable management provides ample area to run cables to complete a professional and discrete installation

3.

One-Touch™ tilt mechanism allows adjustment of +15°/-5° without the use of tools

4.

±5° of roll for post installation display leveling

5.

Display can be rotated from portrait to landscape without removing the display

6.

±0.5" (13mm) vertical adjustment for fine tuning display position

Universal Models

Patented

For expanded product information and technical data visit www.peerless-av.com

5.00"

(127mm)

14.50"

(368mm)

17.00"

(432mm)

WALL PLATE

28.68"

(728mm)

27.12"

(689mm)

MAX.

FRONT VIEW

17.29"

(439mm)

MAX.

0.77"

(20mm)

1.24"

(31mm)

0.67"

(17mm)

18.00"

(457mm)

VERTICAL ADAPTER

4.43"

(112mm)

SIDE VIEW

RETRACTED

Universal Models

ISOMETRIC VIEW

29.72"

(755mm)

27.43"

(697mm)

SIDE VIEW

EXTENDED

1

2

4

TECHNICAL DRAWINGS

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA752PU

High gloss black

Dedicated Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

Requires Display Adapter to be Purchased Separately*

SA752P

High gloss black

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

689 x 439mm

(27.12"W x 17.29"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

Dedicated Models: Requires display-specific PLP or LC adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

4.43"-27.43"

(113-697mm)

2.73"-25.73"

(69-654mm)

+15/-5° | ±90° | ±5°

Max Load

90lb

(41kg)

Landscape to Portrait

Display can be rotated from landscape to portrait without removing the display

Product Dimensions

(W x H x D)

Universal Models:

28.68" x 18.00" x 4.43"-27.43"

(728 x 457 x 113-697mm)

Dedicated Models:

15.2" x 17.00" x 2.73"-25.73"

(386 x 431 x 69-654mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

38lb

(17.3kg)

22lb

(10kg)

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC925:

Security Fasteners ................ pg# 199

WSP756:

Metal Stud Wall Plate ............ pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

55

Articulating

Wall Arm

For 37" to 60" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA761PU

High gloss black

Dedicated Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

Requires Display Adapter to be Purchased Separately*

SA761P

High gloss black

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

689 x 439mm

(27.12"W x 17.29"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

Dedicated Models: Requires display-specific PLP or LC adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

4.43"-27.55"

(113-700mm)

2.85"-25.85"

(72-657mm)

+15/-5° | ±90° | ±5°

Max Load

130lb

(59kg)

Landscape to Portrait

Display can be rotated from landscape to portrait without removing the display

Product Dimensions (W x H x D)

Universal Models:

28.68" x 20.23" x 4.43"-27.55"

(728 x 514 x 113-700mm)

Dedicated Models:

19.5" x 20.23" x 2.83"-25.83"

(495 x 514 x 72-656mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

45lb

(21kg)

33lb

(15kg)

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC925:

Security Fasteners ................ pg# 199

WSP756:

Metal Stud Wall Plate ............ pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

56

1.

Arm extends up to 27.55"

(700mm) from wall

(including thickness of display adapter)

2.

Integrated cable management provides ample area to run cables to complete a professional and discrete installation

3.

One-Touch™ tilt adjustment of +15°/-5° without the use of tools

4.

±5° of roll for post installation display leveling

5.

Display can be rotated from portrait to landscape without removing the display

6.

Minimalistic wall plate footprint for increased wall access and

Universal Models

1

7

7.

Horizontal adjustment up to 4.5" (114mm) for perfect display placement

8.

±0.5" (13mm) vertical adjustment for fine tuning display position

9.

Display is centered on

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

2

4

20.23"

(514mm)

17.98"

(457mm)

19.00"

(483mm)

16.00"

(406mm)

WALL PLATE

28.68"

(728mm)

27.12"

(689mm)

MAX.

FRONT VIEW

6.58"

(167mm)

16.05"

(408mm)

17.29"

(439mm)

MAX.

0.77"

(20mm)

1.24"

(31mm)

0.67"

(17mm)

18.00"

(457mm)

Universal Models

VERTICAL ADAPTER

4.43"

(113mm)

SIDE VIEW

RETRACTED

ISOMETRIC VIEW

27.55"

(700mm)

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 37" to 63" Flat Panel Displays

1.

Dual arm construction for added strength and smooth motion on larger displays

2.

Arms extends up to 27.55"

(700mm) from wall (including thickness of display adapter)

3.

Minimalistic wall plate footprint for increased wall access and improved aesthetic

4.

Horizontal adjustment up to 4.5"

(114mm) for perfect display placement

5.

Integrated cable management provides ample area to run cables to complete a professional and discrete installation

6.

One-Touch™ tilt mechanism allows adjustment of +15°/-5° without the use of tools

7.

±5° of roll for post installation display leveling

8.

Display can be rotated from portrait to landscape without removing the display

9.

±0.5" (13mm) vertical adjustment for fine tuning display position

10.

Display is centered on wall plate

Universal Models

Patented

For expanded product information and technical data visit www.peerless-av.com

20.23"

(514mm)

18.00"

(457mm)

19.00"

(483mm)

16.00"

(406mm)

WALL PLATE

28.68"

(728mm)

27.06"

(687mm)

MAX.

6.57"

(167mm)

16.07"

(408mm)

0.67"

(17mm)

1.24"

(31mm)

0.77"

(20mm)

18.00"

(457mm)

VERTICAL ADAPTER

4.43"

(113mm)

17.29"

(439mm)

MAX.

FRONT VIEW

SIDE VIEW

RETRACTED

ISOMETRIC VIEW

27.55"

(700mm)

SIDE VIEW

EXTENDED

1

2

5

7

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA763PU

High gloss black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

687 x 439mm

(27.06"W x 17.29"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

Universal Models:

Tilt | Swivel | Roll

4.43"-27.55"

(113-700mm)

+15/-5° | ±90° | ±5°

Max Load

200lb

(91kg)

Landscape to Portrait

Display can be rotated from landscape to portrait without removing the display

Product Dimensions (W x H x D)

Universal Models:

28.68" x 20.23" x 4.43"-27.55"

(728 x 514 x 113-700mm)

Mounting Surfaces

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

Universal Models:

55lb

(25kg)

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC925:

Security Fasteners ................ pg# 199

WSP756:

Metal Stud Wall Plate ............ pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

57

Articulating

Wall Arm

For 37" to 71" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

SA771PU

High gloss black

Dedicated Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

Requires Display Adapter to be Purchased Separately*

SA771P

High gloss black

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

827 x 439mm

(32.56"W x 17.29"H)

VESA

®

Pattern

Universal Models:

Up to 800 x 400mm

Dedicated Models: Requires display-specific PLP or LC adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

4.43"-27.55"

(113-700mm)

2.83"-25.83"

(72-656mm)

+15/-5° | ±90° | ±5°

Max Load

200lb

(91kg)

Landscape to Portrait

Display can be rotated from landscape to portrait without removing the display

Product Dimensions

(W x H x D)

Universal Models:

34.38" x 20.23" x 4.43"-27.55"

(873 x 514 x 113-700mm)

Dedicated Models:

19.20" x 20.23" x 2.83"-25.83"

(488 x 514 x 72-656mm)

Mounting Surfaces

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

Universal Models:

Dedicated Models:

72lb

(33kg)

43lb

(20kg)

CERTIFICATIONS

OSHPD Approval Pending

ACCESSORIES

ACC925:

Security Fasteners ................ pg# 199

WSP756:

Metal Stud Wall Plate ............ pg# 195

IBA4-W:

Easy Mount Recessed

Low Voltage Cable Plate ....... pg# 197

IBA5-W:

Recessed Low Voltage Media Plate with Duplex Surge Suppressor .. pg# 197

58

1.

Dual arm construction for added strength and smooth motion on larger displays

2.

Arms extends up to 27.55"

(700mm) from wall (including thickness of display adapter)

3.

Minimalistic wall plate footprint for increased wall access and improved aesthetic

4.

Horizontal adjustment up to 4.5" (114mm) for perfect display placement

5.

Integrated cable management provides ample area to run cables to complete a professional and discrete installation

6.

One-Touch™ tilt mechanism allows adjustment of +15°/-5° without the use of tools

7.

±5° of roll for post installation display leveling

8.

Display can be rotated from portrait to landscape without removing the display

9.

±0.5" (13mm) vertical adjustment for fine tuning display position

TECHNICAL DRAWINGS

Universal Models

Patented

For expanded product information and technical data visit www.peerless-av.com

1

2

5

7

19.00"

(483mm)

0.88"

(22mm)

18.00

(457mm)

16.00"

(406mm)

WALL PLATE

6.58"

(167mm)

16.07"

(408mm)

0.67"

(17mm)

1.24"

(31mm)

0.77"

(20mm)

18.00"

(457mm)

27.00"

(686mm)

VERTICAL ADAPTER

32.56"

(827mm)

MAX.

26.03"

(661mm)

MAX.

FOR USE WITH 65" SHARP DISPLAYS

Universal Models

34.38"

(873mm)

32.56"

(827mm)

MAX.

4.43"

(113mm)

15°

27.55" - 29.85"

(700 - 758mm)

ISOMETRIC VIEW

46.28"

(1175mm)

44.43"

(1128mm)

MAX.

20.23"

(514mm)

FRONT VIEW

17.29"

(439mm)

MAX.

SIDE VIEW

RETRACTED

SIDE VIEW

EXTENDED

17.15"

(436mm)

16.00"

(406mm)

MAX.

FOR USE WITH 65" PANASONIC DISPLAYS

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Display-Specific Flat

Wall Mount

For up to 71" Flat Panel Displays

1.

Measures 1.18" (30mm) from wall, plus thickness of adapter plate

2.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

3.

Easy-Glide™ design ensures display is securely attached to wall plate

4.

Choose from 16"

(406mm) only or 16"–24"

(406–610mm) stud center wall plate

5.

Fits any display-specific

PLP or LC adapter plate

6.

Model SF16D ships with

19.25" (489mm) wide wall plate, perfect for portrait style installations

7.

Wall plate knockouts provide wall access, improving cable management options

SF24D

3

SF16D

2

6

MODELS

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

SF16D

Black for up to 16" studs

SF24D

for up to 24" studs

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Dedicated Models: Requires display-specific PLP or LC adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

1.18"

(30mm)

Max Load

200lb

(90kg)

Product Dimensions (W x H x D)

SF16D:

19.25" x 9.83" x 1.18"

(489 x 250 x 30mm)

SF24D:

30.75" x 9.83" x 1.18"

(781 x 250 x 30mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

SF16D:

SF24D:

7.4lb

(3.4kg)

9.3lb

(4.2kg)

CERTIFICATIONS

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

19.25"

(489 mm)

SF16

30.75"

(781 mm)

SF24

9.83"

(250 mm)

5"

(127 mm)

1"

(25 mm)

16"

(406 mm)

1.1"

(28 mm)

4"

(102 mm)

9.83"

(250 mm)

5"

(127 mm)

1"

(25 mm)

24"

(610 mm)

16"

(406 mm)

20"

(508 mm)

2.75"

(70 mm)

1.1"

(28 mm)

2.75"

(70 mm)

4"

(102 mm)

4.5"

(114 mm)

1.18"

(30 mm)

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

59

Display-Specific Tilt

Wall Mount

For up to 71" Flat Panel Displays

MODELS

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

ST16D

Black for up to 16" studs

ST24D

for up to 24" studs

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Dedicated Models: Requires display-specific PLP or LC adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

3.01"

(76mm)

Tilt

+15/-5°

Max Load

200lb

(90kg)

Product Dimensions

(W x H x D)

ST16D:

19.25" x 10.48" x 3.01"

(489 x 266 x 76mm)

ST24D:

30.75" x 10.48" x 3.01"

(781 x 266 x 76mm)

Mounting Surfaces

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

ST16D:

ST24D:

10.1lb

(4.6kg)

12.2lb

(5.5kg)

2

1.

Tilt allows adjustment of +15/-5° without the use of tools

2.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

3.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

4.

Easy-Glide™ design ensures display is securely attached to wall plate

5.

Choose from 16"

(406mm) only or 16"–24"

(406–610mm) stud center wall plate

6.

Fits any display-specific

PLP or LC adapter plate

7.

Model ST16D ships with

19.25" (489mm) wide wall plate, perfect for portrait style installations

8.

Wall plate knockouts provide wall access, improving cable management options

TECHNICAL DRAWINGS

ST24D

ST16D

Patented

For expanded product information and technical data visit www.peerless-av.com

3

4

7

CERTIFICATIONS

ACCESSORIES

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

19.25"

(489 mm)

ST16D

30.75"

(781 mm)

ST24D

10.48"

(266 mm)

5"

(127 mm)

16"

(406 mm)

1.1"

(28 mm)

4"

(102 mm)

1"

(25 mm)

5"

(127 mm)

10.48"

(266 mm)

1"

(25 mm)

24"

(610 mm)

20"

16"

(406 mm)

(508 mm)

2.75"

(70 mm)

1.1"

(28 mm)

2.75"

(70 mm)

4"

(102 mm)

4.5"

(114 mm)

3.01"

(76 mm)

60

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 10" to 24" Flat Panel Displays

1.

VESA

®

75 and 100mm compliant

2.

Low-profile design holds display 0.68"

(17mm) from wall

3.

Display adapter plate simply slides into the wall plate for a quick and easy installation

For expanded product information and technical data visit www.peerless-av.com

5.63"

(143mm)

1

3

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PF630

black

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

0.68"

(17mm)

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

5.63" x 4.84" x 0.68"

(143 x 123 x 17mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

1.7lb

(.8kg)

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

4.84"

(123mm)

2.95"

(75mm)

WALL PLATE

3.94"

(100mm)

0.68"

(17mm)

ISOMETRIC VIEW

3.94"

(100mm)

2.95"

(75mm)

1.97"

(50mm)

1.97"

(50mm)

2.95"

(75mm)

FRONT VIEW

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

61

Universal Flat

Wall Mount

For 22" to 40" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PF632

black

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

0.73"

(19mm)

Max Load

115lb

(52kg)

Product Dimensions (W x H x D)

Mounting Surfaces

10.43" x 8.67" x 0.73"

(265 x 220 x 19mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

5.1lb

(2.5kg)

CERTIFICATIONS

1.

VESA ® 75, 100, 200 x

100 and 200 x 200mm compliant

2.

Low-profile design holds display 0.73" (19mm) from wall

3.

Display adapter plate simply slides into the wall plate for a quick and easy installation

1

3

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

10.43"

(265mm)

8.67"

(220mm)

7.87"

(200mm)

4.72"

(120mm)

3.94"

(100mm)

WALL PLATE

7.87"

(200mm)

7.09"

(180mm)

3.94"

(100mm)

1.97"

(50mm)

2.95"

(75mm)

1.97"

(50mm)

FRONT VIEW

2.95"

(75mm)

6.69"

(170mm)

ISOMETRIC VIEW

SIDE VIEW

0.73"

(19mm)

62

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Flat

Wall Mount

For 23" to 46" Flat Panel Displays

1.

Low-profile design holds display only 1.18"

(30mm) from the wall

2.

Horizontal display adjustment up to 6"

(152mm) for centering display on wall

3.

Universal display adapters easily hook onto wall plate for a quick installation

4.

Easy-Glide™ design ensures display is properly attached

to the wall plate

4.

Wall plate knockouts provide wall access, improving cable management options

For expanded product information and technical data visit www.peerless-av.com

5.00"

(127mm)

19.25"

(489mm)

1.00"

(25mm)

16.00"

(406mm)

WALL PLATE

17.25"

(438mm)

MAX.

7.45"

(189mm)

0.76"

(19mm)

1.25

"

(32mm)

0.82"

(21mm)

13.75"

(349mm)

VERTICAL ADAPTER

1.18"

(30mm)

2

4

3

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PF640

black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

438 x 329mm

(

17.25"W x 12.94"H)

Many 42" flat panel displays have mounting hole patterns larger than dimensions above.

Use MountFinder™ to verify mount compatibility.

VESA

®

Pattern

Universal Models:

Up to 400 x 300mm

SPECIFICATIONS

Distance from Wall

1.18"

(30mm)

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

19.25" x 13.75" x 1.18"

(489 x 349 x 30mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

5.6lb

(2.5kg)

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ISOMETRIC VIEW

4.00"

(102mm)

12.94"

(329mm)

MAX.

2.75"

(70mm)

FRONT VIEW

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

63

Universal Flat

Wall Mount

For 37" to 60" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PF660

black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

730 x 433mm

(28.75"W x 17.05"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

1.68"

(43mm)

Max Load

200lb

(90kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

30.75" x 18.00" x 1.68"

(781 x 457 x 43mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

9.88lb

(4.5kg)

CERTIFICATIONS

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

1.

Wall plate knockouts provide additional wall access for improved power and cable management

2.

Low-profile design

(43mm) from the wall

3.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

4.

Universal display adapters easily hook onto wall plate for a quick installation

5.

Easy-Glide™ design ensures display is properly attached

to the wall plate

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

64

5.00"

(127mm)

4.00"

(102mm)

30.75"

(781mm)

1.00"

(25mm)

7.45"

(189mm)

0.75"

(19mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

28.75"

(730mm)

MAX.

4.50"

(114mm)

FRONT VIEW

2.75"

(70mm)

17.05"

(433mm)

MAX.

VERTICAL ADAPTER

1.68"

(43mm)

SIDE VIEW

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

ISOMETRIC VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

3

1

5

4

Universal Tilt

Wall Mount

For 10" to 24" Flat Panel Displays

1.

VESA ® 75 and 100mm compliant

2.

+15/-5° tilt adjustment for finding the perfect viewing angle

3.

Low-profile design holds display 2.10" (53mm) from wall

4.

Display adapter plate simply slides onto the wall plate for a quick and easy installation

2

4

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PT630

black

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

2.10"-3.17"

(53-81mm)

Tilt

+15/-5°

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

5.46" x 4.75" x 2.10"-3.17"

(139 x 121 x 53-81mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

2.2lb

(0.99kg)

CERTIFICATIONS

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

4.55"

(116mm)

3.03"

(77mm)

4.75"

(121mm)

WALL PLATE

5.46"

(139mm)

3.94"

(100mm)

2.95"

(75mm)

2.10"

(53mm)

15°

ISOMETRIC VIEW

3.17"

(81mm)

3.94"

(100mm)

2.95"

(75mm)

FRONT VIEW

SIDE VIEW

SIDE VIEW

15° TILT

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

65

Universal Tilt

Wall Mount

For 22" to 40" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PT632

black

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

2.18"-3.84"

(55-98mm)

Tilt

+15/-5°

Max Load

115lb

(52kg)

Product Dimensions (W x H x D)

Mounting Surfaces

8.75" x 9.35" x 2.18"-3.84"

(222 x 237 x 55-98mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

3.5lb

(1.6kg)

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC215:

2-pack Metal Stud

Fastener Kit ......................... pg# 196

1.

VESA ® 75, 100, 200 x

100 and 200 x 200mm compliant

2.

+15/-5° tilt adjustment for finding the perfect viewing angle

3.

Low-profile design holds display 2.18" (55mm) from wall

4.

Display adapter plate simply slides onto the wall plate for a quick and easy installation

5.

Compatible with flat panels that use M8 screws

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

2

4

5.46"

(139mm)

3.94"

(100mm)

2.95"

(75mm)

3.94"

(100mm)

2.95"

(75mm)

FRONT VIEW

8.75"

(222mm)

7.87"

(200mm)

4.75"

(121mm)

2.10"

(53mm)

SIDE VIEW

2.18"

(55mm)

7.87"

(200mm)

3.94"

(100mm)

7.87"

(200mm)

9.35"

(237mm)

FRONT VIEW

ADAPTER PLATE

SIDE VIEW

ADAPTER PLATE

15°

3.17"

(81mm)

SIDE VIEW

15° TILT

15°

3.84"

(98mm)

SIDE VIEW

ADAPTER PLATE

15° TILT

ISOMETRIC VIEW

ISOMETRIC VIEW

ADAPTER PLATE

66

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Tilt

Wall Mount

For 23" to 46" Flat Panel Displays

1.

+15/-5° tilt adjustment for finding the perfect viewing angle

2.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

3.

Wall plate knockouts provide additional wall access for improved power and cable management

4.

Horizontal display adjustment up to 6"

(152mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for a quick installation

6.

Easy-Glide™ design ensures display is properly attached to the wall plate

Patented

For expanded product information and technical data visit www.peerless-av.com

7.45"

189mm

19.25"

(489mm)

1.00"

(25mm)

5.00"

127mm

0.76"

(19mm)

1.25"

(32mm)

0.82"

(21mm)

13.75"

(349mm)

2

6

5

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PT640

black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

446 x 329mm

17.54"W x 12.94"H

Many 42" flat panel displays have mounting hole patterns larger than dimensions above.

Use MountFinder™ to verify mount compatibility.

VESA

®

Pattern

Universal Models:

Up to 400 x 300mm

SPECIFICATIONS

Distance from Wall

2.57"-4.80"

(65-122mm)

Tilt

+15/-5°

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

21.66" x 13.75" x 2.57"-4.80"

(550 x 349 x 65-122mm)

Mounting Surfaces

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

8lb

(3.6kg)

CERTIFICATIONS

4.00"

(102mm)

16.00"

(406mm)

WALL PLATE

21.66"

(550mm)

17.54"

(446mm)

MAX.

12.94"

(329mm)

MAX.

VERTICAL ADAPTER

2.57"

(65mm)

4.80"

(122mm)

15°

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

2.75"

(70mm)

FRONT VIEW

SIDE VIEW SIDE VIEW

15° TILT

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

67

Universal Tilt

Wall Mount

For 37" to 60" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PT660

black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

738 x 449mm

(29.04"W x 17.67"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

2.56"-5.64"

(65-143mm)

Tilt

+15/-5°

Max Load

200lb

(90kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

33.16" x 18.5" x 2.56"-5.64"

(842 x 470 x 65-143mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

10.5lb

(4.7kg)

CERTIFICATIONS

ACCESSORIES

ACC925:

Security Fasteners ............... pg# 199

ACC415:

4-pack Metal Stud

Fastener Kit ......................... pg# 196

1.

+15/-5° tilt adjustment for finding the perfect viewing angle

2.

Included IncreLok TM feature offers fixed tilt lock in 5° increments when used

3.

Wall Plate knockouts provide additional wall access for improved power and cable management

4.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

5.

Universal display adapters easily hook onto wall plate for a quick installation

6.

Easy-Glide™ design ensures display is properly attached to the wall plate

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

30.75"

(781mm)

7.45"

(189mm)

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

WALL PLATE

33.16"

(842mm)

29.04"

(738mm)

MAX.

4.00"

(102mm)

4.50"

(114mm)

FRONT VIEW

2.75"

(70mm)

1.00"

(25mm)

5.00"

(127mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.50"

(470mm)

VERTICAL ADAPTER

2.56"

(65mm)

5.64"

(143mm)

ISOMETRIC VIEW

15°

17.67"

(449mm)

MAX.

SIDE VIEW

SIDE VIEW

15° TILT

2

6

5

68

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Fixed Tilt

Wall Mount

For 23" to 60" Flat Panel Displays

1.

Single rail design enables quick and simple installation

2.

Low-profile design holds display 2.00"

(51mm) from the wall with PFT660 models and

1.70" (43mm) from the wall with PFT640

3.

Safety tab ensures display is securely attached to wall plate

4.

Horizontal display adjustment up to 8"

(203mm) for centering display on wall

5.

Integrated fixed tilt angles of 0°, 2°, 5°, and 10° provide a variety of viewing

PFT660

PFT640

Patented

For expanded product information and technical data visit www.peerless-av.com

0° 2° 5° 10°

TECHNICAL DRAWINGS

1.57"

(40mm)

16.00"

(406mm)

19.25"

(489mm)

WALL PLATE

17.85"

(453mm)

MAX.

19.25"

(489mm)

.51"

(13mm)

1.00"

(25mm)

FRONT VIEW

13.76"

(350mm)

12.94"

(329mm)

MAX.

1.70"

(43mm)

PFT640

10°

2.68"

(68mm)

SIDE

VIEW 0°

SIDE

VIEW 10°

.76"

(19mm)

1.25"

(32mm)

.82"

(21mm)

13.75"

(349mm)

VERTICAL ADAPTER

16.00"

(406mm)

20.00"

(508mm)

24.00"

(610mm)

34.00"

(864mm)

32.60"

(828mm)

MAX.

2.00"

(51mm)

10°

2.93"

(74mm)

.42"

(11mm)

1.25"

(32mm)

2.65"

(67mm)

1.00"

(25mm)

34.00"

(864mm)

WALL PLATE

FRONT VIEW

17.05"

(433mm)

MAX.

18.51"

(470mm)

PFT660

SIDE

VIEW 0°

SIDE

VIEW 10°

18.00"

(457mm)

.85"

(22mm)

VERTICAL ADAPTER

1

3

5

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PFT640

Gloss black for 23" to 46" screens

PFT660

Gloss black for 37" to 60" screens

DISPLAY ADAPTER

Mounting Pattern

Universal Models

PFT640:

453 x 329mm*

(17.85"W x 12.94"H)

828 x 433mm

(32.60"W x 17.05"H)

* Many flat panel displays have mounting hole patterns larger than dimensions above.

Use MountFinder™ to verify mount compatibility.

VESA ® Pattern

Universal Models

PFT640:

Up to 400 x 300mm

PFT660:

Up to 800 x 400mm

SPECIFICATIONS

Distance from Wall

PFT640:

PFT660:

Tilt

1.70"-2.68"

(43-68mm)

2.00"-2.93"

(51-74mm)

0°, 2°, 5°, 10°

Max Load

PFT640:

100lb

PFT660:

175lb

Product Dimensions (W x H x D)

PFT640:

19.25" x 13.76" x 1.70"-2.68"

(489 x 350 x 43-68mm)

PFT660:

34.00" x 18.51" x 2.00"-2.93"

(864 x 470 x 51-74mm)

Mounting Surfaces

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

PFT640:

PFT660:

3.8lb

(1.72kg)

7lb

(3.1kg)

CERTIFICATIONS

ACCESSORIES

ACC215:

(for PFT640)

2-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC415:

(for PFT660)

4-pack Metal Stud

Fastener Kit ......................... pg# 196

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

69

Pivot

Wall Mount

For 10" to 24" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PP730

PP730-S

black

Gloss

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

2.36"-7.01"

(60-178mm)

Tilt | Swivel | Roll

±35° | ±90° | ±5°

Max Load

25lb

(11kg)

Product Dimensions (W x H x D)

Mounting Surfaces

8.11" x 5.50" x 2.36"-7.01"

(206 x 140 x 60-178mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

2.2lb

(1kg)

1.

Arm extends up to 7.01"

(178mm) from wall

2.

Two tensioned pivot points for up to 180° of side-to-side swivel

3.

One-Touch™ tilt mechanism offers up to ±35° of tilt

4.

±5° or roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

1

3

CERTIFICATIONS

Quickship

Item

®

OSHPD Approval Pending

ACCESSORIES

ACC918:

Security Fasteners ................ pg# 199

WSP700:

Metal Stud Wall Plate for 16" Center Metal Studs ... pg# 195

WSP701:

Metal Stud Wall Plate for 20" and 24" Center Metal Studs .. pg# 195

TECHNICAL DRAWINGS

8.13"

(207mm)

TOP VIEW

8.11"

(206mm)

4.66"

(118mm)

Patented

For expanded product information and technical data visit www.peerless-av.com

5

0.50"

(13mm)

2.25"

(57mm)

4.50"

(114mm)

5.50"

(140mm)

WALL PLATE

2.36"

(60mm)

2.95"

(75mm)

3.94"

(100mm)

4.87"

(124mm)

ISOMETRIC VIEW

8.38"

(213mm)

7.01"

(178mm)

FRONT VIEW

2.95"

(75mm)

3.94"

(100mm)

4.69"

(119mm)

SIDE VIEW

RETRACTED

SIDE VIEW

EXTENDED

70

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Pivot

Wall Mount

For 22" to 40" Flat Panel Displays

1.

Arm extends up to 7.88"

(200mm) from wall

2.

Two tensioned pivot points for up to 180° of side-to-side swivel

3.

Up to +15/-5° of tilt for the best viewing angle

4.

±5° of roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

6.

Compatible with flat panels that use M8 screws

Patented

For expanded product information and technical data visit www.peerless-av.com

10.13"

(257mm)

2.25"

(57mm)

0.50"

(13mm)

9.35"

(237mm)

TOP VIEW

8.75"

(222mm)

7.87"

(200mm)

3.94"

(100mm)

5.50"

(140mm)

4.50"

(114mm)

3.94"

(100mm)

7.87"

(200mm)

7.87"

(200mm)

WALL PLATE

3.23"

(82mm)

ISOMETRIC VIEW

9.55"

(243mm)

7.88"

(200mm)

4.63"

(118mm)

FRONT VIEW

SIDE VIEW

SIDE VIEW

EXTENDED

1

3

5

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PP740

black

PP740-S

Gloss

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

3.23"-7.88"

(82-200mm)

Tilt | Swivel | Roll

+15/-5° | ±90° | ±7°

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

10.13" x 9.35" x 3.23"-7.88"

(257 x 237 x 82-200mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

3.84lb

(1.74kg)

CERTIFICATIONS

Quickship

Item

®

OSHPD Approval Pending

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700:

Metal Stud Wall Plate for 16" Center Metal Studs ... pg# 195

WSP701:

Metal Stud Wall Plate for 20" and 24" Center Metal Studs .. pg# 195

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

71

Articulating

Wall Arm

For 10" to 24" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PA730

black

PA730-S

Gloss

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Wall

2.42"-14.46"

(61-367mm)

Tilt | Swivel | Roll

±35° | ±90° | ±5°

Max Load

25lb

(11kg)

Product Dimensions (W x H x D)

Mounting Surfaces

8.58" x 7.04" x 2.42"-14.46"

(218 x 179 x 61-367mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

2.82lb

(1.3kg)

CERTIFICATIONS

Quickship

Item

®

ACCESSORIES

ACC918:

Security Fasteners ................ pg# 199

WSP700:

Metal Stud Wall Plate for 16" Center Metal Studs ... pg# 195

WSP701:

Metal Stud Wall Plate for 20" and 24" Center Metal Studs .. pg# 195

1.

Arm extends up to

14.46" (367mm)

2.

Three adjustable pivot points for versatile display positioning

3.

One-Touch™ tilt mechanism offers up to ±35° of tilt

4.

±5° of roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

8.58"

(218mm)

TOP VIEW

3.94"

(100mm)

2.95"

(75mm)

7.04in

179mm

2.25"

(57mm)

0.50"

(13mm)

5.50"

(140mm)

WALL PLATE

2.42"

(61mm)

4.50"

(114mm)

2.95"

(75mm)

3.94"

(100mm)

ISOMETRIC VIEW

15.89"

(404mm)

14.46"

(367mm)

1

3

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

5

2.81"

(71mm)

FRONT VIEW

SIDE VIEW

RETRACTED

SIDE VIEW

EXTENDED

72

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 10" to 26" Flat Panel Displays

1.

Universal display adapters provide compatibility with displays with up to a

VESA

®

200 x 100mm mounting hole pattern

2.

Arm extends up to

3.

Three adjustable pivot points for versatile display positioning

4.

±5° of roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

6.

Display is centered on wall plate

Patented

For expanded product information and technical data visit www.peerless-av.com

2

5

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PA735F

PA735F-S

Gloss

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

200 x 159mm

(7.87"W x 6.26"H)

VESA

®

Pattern

Universal Models:

Up to 200 x 100mm

SPECIFICATIONS

Distance from Wall

3.08"-14.74"

(78-374mm)

Swivel | Roll

±90° | ±5°

Max Load

25lb

(11kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

9.77" x 8.53" x 3.08"-14.74"

(248 x 217 x 78-374mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

4.1lb

(1.8kg)

CERTIFICATIONS

9.45"

(240mm)

5.50"

(140mm)

WALL PLATE

2.25"

(57mm)

0.50"

(13mm)

4.50"

(114mm)

1.13"

(29mm)

TOP VIEW

7.87"

(200mm)

2.85"

(72mm)

FRONT VIEW

6.26"

(159mm)

MAX

8.53"

(217mm)

SIDE VIEW

RETRACTED

1.25"

(32mm)

0.88"

(22mm)

7.48"

(190mm)

VERTICAL ADAPTER

3.08in

78mm

ISOMETRIC VIEW

14.74"

(374mm)

SIDE VIEW

EXTENDED

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700:

Metal Stud Wall Plate for 16" Center Metal Studs ... pg# 195

WSP701:

Metal Stud Wall Plate for 20" and 24" Center Metal Studs .. pg# 195

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

73

Articulating

Wall Arm

For 22" to 40" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PA740

black

PA740-S

Gloss

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

3.27"-15.37"

(83-390mm)

Tilt | Swivel | Roll

+15/-5° | ±90° | ±5°

Max Load

80lb

(36kg)

Product Dimensions (W x H x D)

Mounting Surfaces

9.42" x 9.35" x 3.27"-15.37"

(239 x 237 x 83-390mm)

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

Ship Weight

5.89lb

(2.67kg)

CERTIFICATIONS

Quickship

Item

®

OSHPD Approval Pending

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700:

Metal Stud Wall Plate for 16" Center Metal Studs ... pg# 195

WSP701:

Metal Stud Wall Plate for 20" and 24" Center Metal Studs .. pg# 195

1.

Arm extends up to

15.37" (390mm)

2.

Three adjustable pivot points for versatile display positioning

3.

Up to +15/-5° of tilt for the best viewing angle

4.

±5° of roll for post installation display leveling

5.

Integrated cable management keeps cables out of the way

6.

Compatible with flat panels that use M8 screws

1

3

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

5

7.87"

(200mm)

3.94"

(100mm)

2.25"

(57mm)

0.50"

(13mm)

9.42"

(239mm)

TOP VIEW

7.87"

(200mm)

3.94"

(100mm)

9.23"

(234mm)

8.23"

(209mm)

7.87"

(200mm)

9.35"

(237mm)

WALL PLATE

3.27"

(83mm)

2.80"

(71mm)

FRONT VIEW

SIDE VIEW

ISOMETRIC VIEW

15.37"

(390mm)

SIDE VIEW

EXTENDED

74

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Articulating

Wall Arm

For 26" to 46" Flat Panel Displays

1.

Universal display adapters provide compatibility with displays with up to a

VESA ® 400 x 400mm mounting hole pattern

2.

Arm extends up to

from wall

3.

Three adjustable pivot points for versatile display positioning

4.

±5° of roll for post installation display leveling

5.

Integrated cable management keeps cables and cords out of the way

Patented

For expanded product information and technical data visit www.peerless-av.com

2

5

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PA746F

PA746F-S

Gloss

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

432 x 408mm

(17"W x 16.06"H)

VESA

®

Pattern

Universal Models:

Up to 400 x 400mm

SPECIFICATIONS

Distance from Wall

2.32"-14.74"

(59-374mm)

Swivel | Roll

±90° | ±5°

Max load

80lb

(36kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

18.75" x 17.00" x 2.32"-14.74"

(476 x 432 x 59-374mm)

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

8.5lb

(3.8kg)

CERTIFICATIONS

18.75"

(476mm)

17.00"

(432mm)

MAX.

2.25"

(57mm)

9.23"

(234mm)

0.50"

(13mm)

0.85"

(21mm)

1.25"

(32mm)

0.91"

(23mm)

17.00"

(432mm)

8.23"

(209mm)

WALL PLATE

VERTICAL ADAPTER

2.32"

(59mm)

ISOMETRIC VIEW

14.74"

(374mm)

ACCESSORIES

ACC919:

Security Fasteners ................ pg# 199

WSP700:

Metal Stud Wall Plate for 16" Center Metal Studs ... pg# 195

WSP701:

Metal Stud Wall Plate for 20" and 24" Center Metal Studs .. pg# 195

16.06"

(408mm)

MAX.

2.79"

(71mm)

FRONT VIEW SIDE VIEW

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

75

Articulating

Wall Arm

For 37" to 60" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PA760

black

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

730 x 433mm

(28.75"W x 17.03"H)

VESA

®

Pattern

Universal Models:

Up to 600 x 400mm

SPECIFICATIONS

Distance from Wall

Tilt | Swivel

5.13"-16.12"

(130-409mm)

+15/-5° | ±45°

Max Load

130lb

(59kg)

Product Dimensions

(W x H x D)

Mounting Surfaces

30.75" x 18.00" x 5.13"-16.12"

(781 x 457 x 130-409mm)

Ship Weight

Wood stud, concrete and cinder block

25lb

(11kg)

CERTIFICATIONS

1.

Arm extends up to 16.12"

(409mm) from the wall for virtually limitless viewing angles

2.

Retracts to 5.13" (130mm) keeping the display close to the wall

3.

One-Touch™ tilt mechanism offers up to +15/-5° of tilt angle adjustment

4.

Up to 45° of pivot motion to position the display in the desired location

5.

Integrated cable management keeps cables out of the way

6.

Display is centered

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

1

3

5

19.25"

(489mm)

16.00"

(406mm)

12.00"

(305mm)

1.00"

(25mm)

2.51"

(64mm)

8.25"

(210mm)

7.00"

(178mm)

6.00"

(152mm)

WALL PLATE

30.75"

(781mm)

28.75"

(730mm)

MAX.

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL ADAPTER

5.13"

(130mm)

ISOMETRIC VIEW

16.12"

(409mm)

17.03"

(433mm)

MAX.

FRONT VIEW

SIDE VIEW

RETRACTED

SIDE VIEW

EXTENDED

76

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Swivel and Tilt

Wall Mount

For 32" to 71" Flat Panel Displays

1.

15° swivel from left to right

2.

Offers 10° of forward tilt and 5° of backward tilt

3.

Mount enables leveling adjustment of display to sit level at any angle; no tools required

4.

Display mounts in landscape or portrait orientation

5.

PS-1 arm holds display

8.75" (222mm)

6.

PS-2 arm holds display

10.12" (257mm)

For expanded product information and technical data visit www.peerless-av.com

2

TECHNICAL DRAWINGS

MODELS

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

PS-1

Black for 32" to 50" displays

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Dedicated Models: Require display-specific PLP adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

PS-1:

PS-2:

8.75"

(222mm)

10.12"

(257mm)

Tilt | Swivel

+10°/-5° | ±15°

Max Load

PS-1:

PS-2:

150lb

(68kg)

225lb

(102kg)

Product Dimensions (W x H x D)

PS-1:

22.00" x 12.08" x 8.75"

(559 x 306 x 222mm)

PS-2:

22.00" x 12.04" x 10.12"

(559 x 305 x 257mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and cinder block

PS-1:

PS-2:

24lb

(11kg)

26.5lb

(12kg)

CERTIFICATIONS

22"

(559 mm)

8.75"

(222 mm)

PS-1

10"

(255 mm)

22"

(559 mm)

10.12"

(257 mm)

PS-2

11.54"

(293 mm)

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

77

Universal

Tablet Cradle

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching tablet to mount

PTM200

*

Black

PTM200-S

*

Silver

* Designed for use with tablets that are less than 0.75" (19mm) deep

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 x 75mm

SPECIFICATIONS

Max Load

5lb

(2.27kg)

Product Dimensions (W x H x D)

6.92"-11.42" x 4.48"-8.47" x 1.65"

(176-290 x 114-215 x 42mm)

Mounting Surfaces

Any 75 x 75mm VESA ® mount

ACCESSORIES

ACC954:

Theft Resistant Security Kit .... pg# 199

SF630 models:

SmartMount ® Universal

Flat Wall Mount ...................... pg# 33

ST630 models:

SmartMount ® Universal

Tilt Wall Mount ........................ pg# 40

SP730P models:

SmartMount ® Universal

Pivot Wall Mount ..................... pg# 48

SA730P models:

SmartMount ® Universal

Articulating Wall Arm ............... pg# 51

LCH/LCT/LCV/LCW/LCZ models:

Desktop Mounts ............ pg# 100-110

1.

Adjustable height and width, providing a universal fit for

2.

Easily attaches to any 75 x 75mm VESA ® mount

3.

Stylish cover for improved aesthetics

Note: Tablet and mount not included

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

11.42"

(290mm)

.75"

(19mm)

1

2

8.47"

(215mm)

7.97"

(202mm)

MAX.

11.21"

(285mm)

MAX.

FRONT VIEW

EXTENDED

6.92"

(176mm)

6.71"

(170mm)

MIN.

FRONT VIEW

RETRACTED

SIDE VIEW

EXTENDED

1.65"

(42mm)

4.48"

(114mm)

3.73"

(95mm)

MIN.

SIDE VIEW

RETRACTED

2.95"

(75mm)

ISOMETRIC VIEW

2.95"

(75mm)

REAR MOUNTING HOLES

78

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Universal Desktop

Tablet Mount

1.

Adjustable height and width, providing a universal fit for

2.

Stylish cover for improved aesthetics

3.

±30° of One-Touch TM tilt and swivel

4.

360° of roll for versatile placement options

5.

Option to place on desk or secure down with theft resistant security screws

6.

Two color options available for coordinating with tablet aesthetics

4

1

Note: Tablet not included

Patented

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching tablet to mount

PTM400S

*

Black

PTM400S-W

*

White

Includes standard hardware (hex or Phillips) for attaching tablet to mount

PTM400

*

Black

PTM400-W

*

White

* Designed for use with tablets that are less than 0.75" (19mm) deep

SPECIFICATIONS

Tilt | Swivel | Roll

±30° | ±30° | ±360°

Max Load

5lb

(2.27kg)

Landscape to Portrait

Tablet can be rotated from landscape to portrait without removing the tablet

Product Dimensions (W x H x D)

6.71"-11.21" x 9.35"-11.34" x 7.02"

(170-285 x 237-288 x 178mm)

Mounting Surfaces

Desktop

ACCESSORIES

ACC954:

Theft Resistant Security Kit .... pg# 199

6.71" - 11.21"

(170 - 285mm)

FRONT VIEW

6.39"

(162mm)

4.50"

(114mm)

7.02"

(178mm)

4.63"

(117mm)

TOP VIEW

0.75"

(19mm)

3.73" - 7.97"

(95 - 202mm)

9.35" - 11.34"

(237 - 288mm)

SIDE VIEW

30°

SIDE VIEW

TILTED

ISOMETRIC VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

79

Modular

Wall Mount

For 23" to 84" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant and standard hardware (hex or Phillips) for securing display to mount

ONE-TP

Black

DISPLAY ADAPTER

Mounting Pattern

Universal Models

1-plate Configuration:

445 x 673mm

(17.52"W x up to 26.48"H)

2-plate Configuration:

747 x 673mm

(29.4"W x up to 26.48"H)

3-plate Configuration:

1050 x 673mm

(41.32"W x up to 26.48"H)

SPECIFICATIONS

Distance from Wall

Tilt

3.26"

(83mm)

+15/-5°

Max Load

250lb

(113kg)

Product Dimensions

(W x H x D)

1-plate Configuration:

19.25" x 13.75" x 3.26"

(489 x 349 x 83mm)

2-plate Configuration:

31.13" x 27.32" x 3.26"

(791 x 694 x 83mm)

3-plate Configuration:

43.00" x 27.32" x 3.26"

(1092 x 694 x 83mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete, cinder block and metal stud

(Metal stud accessory required)

18.7lb

(8.5kg)

CERTIFICATIONS

ACCESSORIES

ACC415:

(for 1 and 2-plate configurations)

4-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC615:

(for 3-plate configuration)

6-pack Metal Stud

Fastener Kit ......................... pg# 196

ACC937:

M10 Mounting Hole

Adapters .............................. pg# 195

1.

Modular design expands mount to accommodate 23" to 84" displays

2.

Horizontal display adjustment up to 8"

(203mm)

3.

Tilt allows adjustment of +15/-5º without use

2

4

4.

Included IncreLok

TM feature offers fixed tilt lock in 5° increments when used

5.

Easy-Glide

TM

bracket design ensures display is securely attached to wall plate

6.

Fits displays with mounting hole patterns up to 1050 x 673mm

(41.32"W x 26.48"H)

7.

Portrait orientation for up to 50" displays with maximum mounting hole patterns of 445 x 673mm

(17.52"W x 26.48"H)

8.

Wall plate knockouts provide wall access for improved power and cable management

TECHNICAL DRAWINGS

3-plate configuration

2-plate configuration 1-plate configuration

Patented

For expanded product information and technical data visit www.peerless-av.com

5

4.12"

(105 mm)

1.06"

(27 mm)

19.25"

(489 mm)

16"

(406 mm)

6"

(152 mm)

31.13"

(791 mm)

24"

(610 mm)

16"

(406 mm)

1.54"

(39 mm)

3"

(76 mm)

7.2"

(183 mm)

1.75"

(44 mm)

1.75"

(44 mm)

2"

(51 mm)

17.52"

(445 mm)

MAX

26.48"

(673 mm)

MAX

.85"

(21 mm)

29.4"

(747 mm)

MAX

3.26"

(83 mm)

1.25"

(32 mm)

1.48"

(37 mm)

.85"

(21 mm)

12.29"

(312 mm)

27.32"

(694 mm)

13.75"

(349 mm)

15°

6.93"

(176 mm)

43"

3.5"

(89 mm)

(1092 mm)

16"

16"

(406 mm)

(406 mm)

27.32"

(694 mm)

41.32"

(1050 mm)

MAX

80

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

PLA Series

Articulating

Wall Arm

For 32" to 65" Flat Panel Displays

1.

Arm extends up to

30.52" (775mm) from

wall

2.

Three adjustable pivot points with up to 180° swivel for versatile display positioning

3.

+10/-5° of tilt

4.

±7° of roll for post installation display leveling

5.

Universal models adapt to displays hole patterns up to 731 x 433mm

(28.76"W x 17.05"H)

6.

Includes mesh cord sheath and cable ties to neatly

7.

Five horizontal arm positions at 2.6"

(66mm) centers for flexible lateral display placement

5.00"

(127mm)

19.75"

(502mm)

16.00"

(406mm)

WALL PLATE

30.75"

(781 mm)

28.76"

(731mm)

MAX.

FRONT VIEW

Universal Models

Dedicated Models

For expanded product information and technical data visit www.peerless-av.com

7.34"

(186mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

17.05"

(433mm)

VERTICAL BRACKET

5.37"

(136mm)

SIDE VIEW

ISOMETRIC VIEW

30.52"

(775mm)

5

6

7

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PLA50-UNL

Black

PLA50-UNL-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

PLA50-UNLP

PLA50-UNLP-S

Silver

PLA50-UNLP-GB

High gloss black

PLA50-UNLP-GS

High gloss silver

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

PLA50

Black

PLA50-S

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

731 x 433mm

(28.76"W x 17.05"H)

Dedicated Models: Requires display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

5.37"-30.52"

(136-775mm)

4.50"-29.3"

(114-744mm)

+10/-5° | ±90° | ±7°

Max Load

150lb

(68kg)

Product Dimensions (W x H x D)

Universal Models:

30.75" x 19.10" x 5.37"-30.52"

(781 x 486 x 136-775mm)

Dedicated Models:

19.75" x 18.70" x 4.50"-29.30"

(501 x 474 x 114-744mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

CERTIFICATIONS

43lb

(19.5kg)

28.5lb

(12.9kg)

SIDE VIEW

EXTENDED

ACCESSORIES

WSP716:

(Triple stud on 16" centers)

Metal Stud Wall Plate ........... pg# 195

WSP724:

(Triple stud on 16"-24" centers)

Metal Stud Wall Plate ........... pg# 195

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

81

PLA Series

Articulating

Wall Arm

For 37" to 65" Flat Panel Displays

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PLA60-UNL

Black

PLA60-UNL-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

PLA60-UNLP

PLA60-UNLP-S

Silver

PLA60-UNLP-GB

High gloss black

PLA60-UNLP-GS

High gloss silver

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

PLA60

Black

PLA60-S

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

731 x 433mm

(28.76"W x 17.04"H)

Dedicated Models: Requires display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

5.37"-32.37"

(136-822mm)

4.50"-31.20"

(114-792mm)

+10/-5° | ±90° | ±7°

Max Load

175lb

(79kg)

Product Dimensions (W x H x D)

Universal Models:

30.75" x 19.10" x 5.37"-32.37"

(781 x 486 x 136-822mm)

Dedicated Models:

19.75" x 19.12" x 4.50"-31.20"

(502 x 486 x 114-792mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

48.5lb

(21.9kg)

34.1lb

(15.4kg)

CERTIFICATIONS

1.

Arm extends up to 32.37" (822mm)

2.

Three pivot points with up to 180° swivel for versatile display positioning

3.

+10/-5° of tilt

4.

±7° of roll for post installation display leveling

5.

Universal models adapt to displays hole patterns up to 731 x 433mm

(28.76"W x 17.04"H)

6.

Includes mesh

cord sheath and cable ties to neatly

7.

Five horizontal arm positions at 2.6"

(66mm) centers for flexible lateral display placement

TECHNICAL DRAWINGS

10.00"

(254mm)

19.75"

(502mm)

16.00"

(406mm)

WALL PLATE

30.75"

(781mm)

28.76"

(731mm)

MAX.

Universal Models

Dedicated Models

For expanded product information and technical data visit www.peerless-av.com

13.50"

(343mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL BRACKETS

5.37"

(136mm)

ISOMETRIC VIEW

32.37"

(822mm)

5

6

7

ACCESSORIES

WSP716:

(Triple stud on 16" centers)

Metal Stud Wall Plate ........... pg# 195

WSP724:

(Triple stud on 16"-24" centers)

Metal Stud Wall Plate ........... pg# 195

FRONT VIEW

17.04"

(433mm)

SIDE VIEW

SIDE VIEW

EXTENDED

82

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

PLA Series

Articulating

Wall Arm with Vertical Adjustment

For 37" to 65" Flat Panel Displays

1.

Arm extends up to 32.27" (822mm) from wall

2.

Three pivot points with up to 180° swivel for versatile display positioning

3.

+10/-5° of tilt

4.

±7° of roll for post installation display leveling

5.

±1" (25.4mm) vertical adjustment located within reach behind display

6.

Universal models adapt to displays with mounting hole patterns up to 731 x 433mm

(28.76"W x 17.04"H)

7.

Includes mesh cord sheath and cable ties to neatly manage cables

8.

Five horizontal arm positions at 2.6"

(66mm) centers for flexible lateral display placement

Patented

Universal Models

Dedicated Models

For expanded product information and technical data visit www.peerless-av.com

10.00"

(254mm)

19.75"

(502mm)

16.00"

(406mm)

WALL PLATE

30.75"

(781mm)

28.76"

(731mm)

MAX.

FRONT VIEW

13.50"

(343mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

17.04"

(433mm)

VERTICAL BRACKETS

5.37"

(136mm)

SIDE VIEW

7

8

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

PLAV60-UNL

PLAV60-UNL-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

PLAV60-UNLP

Black

PLAV60-UNLP-S

Silver

PLAV60-UNLP-GB

High gloss black

PLAV60-UNLP-GS

High gloss silver

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

PLAV60

Black

PLAV60-S

Silver

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

731 x 433mm

(28.76"W x 17.04"H)

Dedicated Models: Requires display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

5.37"-32.37"

(136-822mm)

4.50"-31.20"

(114-792mm)

+10/-5° | ±90° | ±7°

Max Load

175lb

(79kg)

Product Dimensions (W x H x D)

Universal Models:

30.75" x 21.67" x 5.37"-32.37"

(781 x 550 x 136-822mm)

Dedicated Models:

19.75" x 21.67" x 4.50"-31.20"

(502 x 550 x 114-792mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

CERTIFICATIONS

50.6lb

(22.9kg)

36.2lb

(16.4kg)

ISOMETRIC VIEW

32.37"

(822mm)

6

5

SIDE VIEW

EXTENDED

ACCESSORIES

WSP716:

(Triple stud on 16" centers)

Metal Stud Wall Plate ........... pg# 195

WSP724:

(Triple stud on 16"-24" centers)

Metal Stud Wall Plate ........... pg# 195

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

83

PLA Series

Articulating

Dual Wall Arm with Vertical Adjustment

For 42" to 71" Flat Panel Displays

MODELS

Universal Models:

42" to 65" displays

Includes standard hardware (hex or Phillips) for attaching display to mount

PLAV70-UNL

PLAV70-UNL-S

Silver

Includes standard hardware (hex or Phillips) for attaching display to mount

PLAV70-UNLP

Black

PLAV70-UNLP-S

Silver

PLAV70-UNLP-GB

High gloss black

PLAV70-UNLP-GS

High gloss silver

Dedicated Models:

42" to 71" displays

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

PLAV70

Black

PLAV70-S

Silver

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

731 x 433mm

(28.76"W x 17.05"H)

Dedicated Models: Requires display-specific adapter to be purchased separately

.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

5.52"-32.52"

(140-826mm)

4.50"-29.30"

(114-744mm)

+10/-5° | ±45° | ±7°

Max Load

200lb

(90kg)

Product Dimensions (W x H x D)

Universal Models:

33.50" x 21.67" x 5.52"-32.52"

(851 x 550 x 140-826mm)

Dedicated Models:

19.75" x 21.67" x 4.50"-29.30"

(502 x 550 x 114-744mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

72.4lb

(32.9kg)

58.5lb

(26.5kg)

CERTIFICATIONS

1.

Arm extends up to 32.52" (826mm) from wall

2.

Up to 180° swivel

3.

+10/-5° of tilt

4.

±7° of roll for post installation display leveling

5.

±1" (25mm) located within reach behind display

6.

Universal models accommodate

42" to 65" displays hole patterns up to 731 x 433mm

(28.76"W x 17.05"H)

7.

Includes mesh

cord sheath and cable ties to neatly manage cables

8.

Three horizontal arm positions at 2.6"

(66mm) centers for flexible lateral display placement

Universal Models

Dedicated Models

TECHNICAL DRAWINGS

Patented

For expanded product information and technical data visit www.peerless-av.com

6

5

7

8

10.00"

(254mm)

19.75"

(502mm)

16.00"

(406mm)

WALL PLATE

33.50"

(851mm)

28.76"

(731mm)

MAX.

13.50"

(343mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL BRACKETS

5.52"

(140mm)

ISOMETRIC VIEW

32.52"

(826mm)

ACCESSORIES

WSP716:

(Triple stud on 16" centers)

Metal Stud Wall Plate ........... pg# 195

WSP724:

(Triple stud on 16"-24" centers)

Metal Stud Wall Plate ........... pg# 195

FRONT VIEW

17.05"

(433mm)

SIDE VIEW

SIDE VIEW

EXTENDED

84

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

In-Wall

Mount

For 22" to 40" Flat Panel Displays

3

1.

Installs between 16"

(406mm) wood stud centers

2.

Stud-locating tabs adjust 1/4" (6mm) left or right to accommodate

3.

Includes articulating mount for up to 40" displays

4.

Removable outlet receptacle and cable management access plates make installation easy

5.

Height adjustment points in box to set display in desired vertical position

6.

VESA

®

75, 100, 200 x 100 and 200 x 200mm compliant

7.

Can be inverted to position display to the right or the left

8.

Compatible with flat panels that use M8 screws

Patented

For expanded product information and technical data visit www.peerless-av.com

6

2

4

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

IM740P

High gloss black

IM740P-S

High gloss silver

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Wall

0.08"-12.05"

(2-306mm)

Tilt | Swivel | Roll

+15/-5° | ±45° | ±5°

Max Load

80lb

(36kg)

Product Dimensions (W x H x D)

16.25" x 14.50" x 3.92"-15.97"

(413 x 368 x 100-406mm)

Mounting Surfaces

Wood stud

Ship Weight

22.63lb

(57.4kg)

CERTIFICATIONS

3.77"

(96mm)

ø1.29"

(33mm)

14.50"

(368mm)

7.87"

(200mm)

13.75"

(349mm)

TOP VIEW

16.25"

(413mm)

5.37"

(136mm)

3.92"

(100mm)

9.35"

(237mm)

7.87"

(200mm)

3.94"

(100mm)

ADAPTER PLATE

12.05"

(306mm)

3.94"

(100mm)

7.87"

(200mm)

ISOMETRIC VIEW

6.43"

(163mm)

12.00"

(305mm)

FRONT VIEW

1.32"

(34mm)

SIDE VIEW

EXTENDED

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

85

In-Wall

Mount

For 32" to 71" Flat Panel Displays

MODELS

Universal Models:

32" to 65" displays

Includes standard hardware (hex or Phillips) for attaching display to mount

IM760PU

High gloss black

IM760PU-S

High gloss silver

Dedicated Models: :

32" to 71" displays

Includes standard hardware (hex or Phillips) for attaching display to mount

Display Adapter Purchased Separately for Non-VESA ® Displays*

IM760P

High gloss black

IM760P-S

High gloss silver

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

730 x 433mm

(28.75"W x 17.05"H)

VESA ® Pattern

Dedicated Models:

100, 200 x 100 and 200 x 200mm

Non-VESA ® compatible displays require display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

Universal Models:

Dedicated Models:

Tilt | Swivel | Roll

2.14"-19.88"

(54-505mm)

0.42"-18.09"

(11-459mm)

+10/-5° | ±45° | ±7°

Max Load

200lb

(90kg)

Product Dimensions (W x H x D)

Universal Models:

30.75" x 21.86" x 4.34"-23.80"

(780 x 555 x 110-604mm)

Dedicated Models:

19.46" x 21.86" x 4.38"-22.56"

(494 x 555 x 111-573mm)

Mounting Surfaces

Ship Weight

Wood stud and metal stud

(Metal stud accessory required)

Universal Models:

Dedicated Models:

42.6lb

(19.32kg)

58.49lb

(26.53kg)

CERTIFICATIONS

ACCESSORIES

ACC615:

(Supports up to 125lb (62kg) displays)

6-pack Metal Stud

Fastener Kit ..........................pg# 196

ACC925:

Security Fasteners ................pg# 199

1.

Installs between 16"

(406mm) wood stud centers

2.

Stud-locating tabs adjust 1/4"

(6mm) left or right to accommodate stud spacing

3.

Removable outlet receptacle and cable management access plates make installation easy

4.

Can be inverted to position display to the right or the left

5.

IM760P models are

VESA ® 100, 200 x 100 and 200 x 200mm compliant

TECHNICAL DRAWINGS

For expanded product information and technical data visit www.peerless-av.com

14.02"

(356mm)

3.92"

(99mm)

Ø1.50"

(38mm)

TOP VIEW

0.82"

(21mm)

28.75"

(730mm)

MAX.

4.34"

(110mm)

0.75"

(19mm)

1.25"

(32mm)

0.85"

(22mm)

18.00"

(457mm)

VERTICAL ADAPTER

2.14"

(54mm)

17.05"

(433mm)

MAX.

21.86"

(555mm)

FRONT VIEW

SIDE VIEW

RETRACTED

ISOMETRIC VIEW

19.88"

(505mm)

SIDE VIEW

EXTENDED

2

3

16.45"

(418mm)

86

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

In-Wall

Box

For up to 40" Flat Panel Displays

1.

Compatible with

PA730, PA740, PP730 &

PP740, sold separately

2.

Installs between 16"

(406mm) wood stud centers

3.

Stud-locating tabs adjust 1/4"

(6mm) left or right to accommodate stud spacing

4.

Removable outlet receptacle and cable management access plates make installation easy

5.

Three height adjustment points in box set display in desired vertical position

6.

Can be inverted to position display to the right or the left

7.

Display mount required

3

4

MODELS

Universal Models:

Includes standard hardware (hex or Phillips) for attaching display to mount

IB40

High gloss black

SPECIFICATIONS

Distance from Wall

0.08"

(2mm)

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

16.25" x 14.50" x 3.77"

(413 x 368 x 96mm)

Mounting Surfaces

Ship Weight

Wood stud

14.23lb

(6.45kg)

CERTIFICATIONS

5

For expanded product information and technical data visit www.peerless-av.com

TECHNICAL DRAWINGS

ø1.29"

(33mm)

13.75"

(349mm)

TOP VIEW

16.25"

(413mm) 3.77"

(96mm)

ACCESSORIES

PP730:

Pivot Wall Mount for 10" to 24"

Flat Panel Displays ................. pg# 70

PP740:

Pivot Wall Mount for 22" to 40"

Flat Panel Displays ................. pg# 71

PA730:

Articulating Wall Arm for 10" to 24"

Flat Panel Displays ................. pg# 72

PA740:

Articulating Wall Arm for 22" to 40"

Flat Panel Displays ................. pg# 74

ISOMETRIC VIEW

14.50"

(368mm)

12.00"

(305mm)

FRONT VIEW

1.32"

(34mm)

SIDE VIEW

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

87

Rotational

Mount Interface

For up to 71" Flat Panel Displays

MODELS

Dedicated Model:

Requires Peerless-AV wall mount, ceiling mount, cart or stand, sold separately.

Display Adapter Purchased Separately*

RMI1

Black

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Dedicated Model: Requires display-specific PLP adapter to be purchased separately.

SPECIFICATIONS

Distance from Wall

0.94"

(24mm)

Roll

360°

Max Load

175lb

(79kg)

Landscape to Portrait

Display can be rotated from landscape to portrait without removing the display

Product Dimensions

(W x H x D)

Mounting Surfaces

12.94" x 7.38" x 0.94"

(329 x 187 x 24mm)

Ship Weight

To be used with Peerless-AV

SF16D/24D and ST16D/24D wall mounts, ceiling mounts, carts or stands.

(Sold Separately)

5.5lb

(2.5kg)

CERTIFICATIONS

1.

Allows display to be orientated from landscape to portrait without removing the display from the mount

2.

Display can be rotated 360° without impediment

3.

Display roll angle can be locked in 15° increments

4.

Spring loaded handle makes adjusting the displays position simple

TECHNICAL DRAWINGS

ACCESSORIES

ACC170:

SR Cart and SS Stand

Adapter Plate ........................ pg# 195

7.38"

(187 mm)

Patented

For expanded product information and technical data visit www.peerless-av.com

10.38"

(264 mm)

12.94"

(329 mm)

8.5"

(216 mm)

2

4

3.25"

(83 mm)

6"

(152 mm)

6.5"

(165 mm)

3.25"

(83 mm)

3.25"

(83 mm)

6.5"

(165 mm)

.94" (24 mm)

88

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Corner

Mount

For 32" to 60" Flat Panel Displays

1.

Allows display to fit in corner where space is limited

2.

Includes SmartMount ®

SP850-UNL Pull-Out

Universal Models

3.

Expandable arms accommodate multiple display sizes without having to adjust wall mount placement

4.

SP850-UNL extends up to

10.75" (273mm), pull-out swivel with up to 90° rotation; 0°, 5° or 10°

IncreLok TM tilt

5.

Wall units accommodate speakers when used with smaller displays (wall unit maybe visible with some smaller displays)

6.

Optional shelf available

For expanded product information and technical data visit www.peerless-av.com

9.30"

(236 mm)

36.6" (930 mm) min.

43.8" (1113 mm) max.

2

4

6

TECHNICAL DRAWINGS

MODELS

Universal Kitted Models:

Includes SP850-UNL mount

Includes standard hardware (hex or Phillips) for attaching display to mount

CM850

Black

CM850-S

Silver

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

729 x 433mm

(28.70"W x 17.05"H)

SPECIFICATIONS

Distance from Corner

Tilt | Swivel | Roll

18.04"-25.79"

(458-655mm)

0°, 5° or 10° | ±45° | ±1°

Max Load

150lb

(68kg)

Product Dimensions

(W x H x D)

36.60"-43.08" x 9.30" x 18.04"-25.79"

(930-1113 x 236 x 458-655mm)

Mounting Surfaces

Wood stud, concrete and cinder block

Ship Weight

Box 1:

Box 2:

30.5lb

(13.8kg)

39lb

(17.7kg)

CERTIFICATIONS

18.04"

(458 mm)

ACCESSORIES

ACC324(-S):

Corner Mount Shelf .............. pg# 198

ACC930:

Fastener Kit for Speaker Mounts .............. pg# 199

18.04" min.

(458 mm)

15"

25.79" max.

(381 mm)

(655 mm)

36.6" (930 mm) min.

43.8" (1113 mm) max.

CM850(-S)

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

89

Corner

Mount

For 32" to 60" Flat Panel Displays

MODELS

Dedicated Model:

For 32"-50" displays

Require compatible flat/tilt wall mount

CM50

Black

CM50-S

For 40"-60" displays

Require compatible flat/tilt wall mount

CM60

Black

CM60-S

DISPLAY ADAPTER

Dedicated Model: Requires compatible flat/tilt wall mount to be purchased separately.

Compatible flat/tilt models include SF/ST640/650/660,

PF/PT640/660 and ONE-TP.

See pages 35-37, 43-45,

63-64, 67-68 and 80.

SPECIFICATIONS

Distance from Corner

CM50(-S):

CM60(-S):

Max Load

CM50(-S):

CM60(-S):

15"

(381mm)

15"

(381mm)

175lb

(79kg)

200lb

(90kg)

Product Dimensions

(W x H x D)

CM50(-S):

36.60"-43.80" x 9.30" x 15.00"

(930-1113 x 236 x 381mm)

CM60(-S):

36.60"-60.00" x 9.30" x 15.00"

(930-1524 x 236 x 381mm)

Mounting Surfaces

Wood stud, concrete and cinder block

Ship Weight

CM50(-S):

CM60(-S):

30lb

(13.6kg)

38lb

(17.2kg)

CERTIFICATIONS

1.

Allows display to fit in corner where space is limited

2.

CM50(-S) wall units expand to support compatible flat/tilt wall mounts for flat panel displays from 32"-50"

3.

CM60(-S) includes additional support plate to accommodate compatible flat/tilt wall mounts for flat panel displays from 40"-60"

4.

Wall units accommodate speakers when used with smaller displays (wall unit maybe visible with some smaller displays)

5.

Optional shelf available

TECHNICAL DRAWINGS

Dedicated Models

For expanded product information and technical data visit www.peerless-av.com

2

3

5

36.6" (930mm) min.

43.8" (1113mm) max.

36.6" (930mm) min.

60.0" (1524mm) max.

ACCESSORIES

ACC324(-S):

Corner Mount Shelf .............. pg# 198

ACC930:

Fastener Kit for Speaker Mounts .............. pg# 199

9.30"

(236 mm)

9.30"

(236 mm)

15"

(381 mm)

15"

(381 mm)

36.6" (930mm) min.

43.8" (1113mm) max.

CM50(-S)

36.6" (930mm) min.

60.0" (1524mm) max.

CM60(-S)

90

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Conversion

Kit

For up to 65" Flat Panel Displays

1.

Retrofits any Jumbo

® single or double

2.

Connects to any

1.5" (38.1mm) NPT pipe

3.

360° swivel for ceiling applications

4.

Tilts up to 20°

5.

Places flat panel display in the same location as previous

CRT display

6.

PLCK-UNL includes universal adapter plate for 32" to 65" displays, tilt box, extension column and connector

7.

PLCK-1 includes tilt box, extension column and connector. Requires display-specific adapter plate

Universal Models

Dedicated Models

Patented

For expanded product information and technical data visit www.peerless-av.com

7

2.2"

(56 mm)

2.2"

(56 mm)

30.75"

(781 mm)

2"

(51 mm)

20.58"

(523 mm)

14.88"

(378 mm)

5.71"

(145 mm)

3.25"

(83 mm)

(PLCK-1,

(PLCK-1,

PLCK-UNL without adapter plate)

22.58"

(574 mm)

10.24"

(260 mm)

7.45"

(189 mm)

(PLCK-1,

(PLCK-1,

PLCK-UNL without adapter plate)

28.7"

(729 mm)

ADAPTER BRACKET DETAIL

(PLCK-UNL ONLY)

Single Jumbo Wall Arm

Double Jumbo Wall Arm

Jumbo Ceiling

3

5

6

TECHNICAL DRAWINGS

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

PLCK-UNL

Black

Dedicated Models:

Display adapter purchased separately*

PLCK-1

Black

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal Models:

729 x 433mm

(28.70"W x 17.05"H)

Dedicated Models: Requires display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Ceiling

Universal Models:

Dedicated Models:

Tilt | Swivel

27.60"

(701mm)

22.58"

(574mm)

20° | 360°

Max Load

125lb

(56kg)

Product Dimensions

(W x H x D)

Universal Models:

30.75" x 27.60" x 4.60"

(781 x 701 x 116mm)

Dedicated Models:

10.24" x 22.58" x 3.25"

(260 x 574 x 83mm)

Mounting Surfaces

Ship Weight

Attached to Jumbo single wall arm, double wall arm models and 1.5" - 11.5"

(38-292mm) NPT pipe

Universal Models:

Dedicated Models:

23.9lb (10.8kg)

14.5lb (6.6kg)

CERTIFICATIONS

17.05"

(433 mm)

ACCESSORIES

ACC, CMJ, DCS, DCT Models:

Ceiling Plates .............. pg# 190-192

AEC, ALU and EXT Models:

Ceiling Extensions ............... pg# 193

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

91

Ceiling

Mount

For 15" to 24" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

With 9.80"-13.90" (249-353mm) extension:

PC930A

Black

With 13.78"-21.89" (350-556mm) extension:

PC930B

Black

With 20.24"-34.02" (514-864mm) extension:

PC930C

Black

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Ceiling

PC930A(-S)(-W):

PC930B(-S)(-W):

PC930C(-S)(-W):

Tilt | Swivel

9.80"-13.83"

(249-351mm)

13.78"-21.89"

(350-556mm)

20.24"-34.02"

(514-864mm)

+15/-5° | 360°

Max Load

50lb

(22kg)

Product Dimensions

(W x H x D)

PC930A(-S)(-W):

6.50" x 9.80"-13.90" x 6.50"

(165 x 249-353 x 165mm)

PC930B(-S)(-W):

6.50" x 13.78"-21.89" x 6.50"

(165 x 350-556 x 165mm)

PC930C(-S)(-W):

6.50" x 20.24"-34.02" x 6.50"

(165 x 514-864 x 165mm)

Mounting Surfaces

Ship Weight

Wood joist, concrete and truss

PC930A(-S)(-W):

PC930B(-S)(-W):

PC930C(-S)(-W):

4.85lb

(2.20kg)

5.4lb

(2.44kg)

6.64lb

(3.01kg)

CERTIFICATIONS

EN 60065

1.

VESA ® 75 and 100mm compliant

2.

Continuous tilt of

+15/-5° with optional lock in 5° increments

3.

Swivel adjustment within ceiling plate for display placement opportunities

4.

Internal cable management within extension channels for clean, clutter-free appearance

5.

Safety catch designed into extension channels to ensure user and equipment safety

TECHNICAL DRAWINGS

ø6.50"

(165mm)

"A"

4.75"

(121mm)

4.75"

(121mm)

FRONT VIEW

For expanded product information and technical data visit www.peerless-av.com

15°

SIDE VIEW

1.73in

44mm

SIDE VIEW

15° TILT

3.93"

(100mm)

3.93"

(100mm)

2.94"

(75mm)

2.94"

(75mm)

ADAPTER PLATE

ISOMETRIC VIEW

MODEL NO.

PC930A

PC930B

PC930C

MIN.

DIMENSION "A"

9.80" (249mm)

13.78" (350mm)

20.24" (514mm)

MAX.

13.90" (353mm)

21.89" (556mm)

34.02" (864mm)

4

5

92

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Ceiling

Mount

For 15" to 37" Flat Panel Displays

9.35"

(237mm)

1.

VESA

®

75, 100, 200 x 100 and 200 x

200mm compliant

2.

Continuous tilt of

+15/-5° with optional lock in 5° increments

3.

Swivel adjustment within ceiling plate for display placement opportunities

4.

Internal cable management within extension channels for clean, clutter-free appearance

5.

Safety catch designed into extension channels to ensure user and equipment safety

6.

Compatible with flat panels that use M8 screws

For expanded product information and technical data visit www.peerless-av.com

ø6.50"

(165mm)

8.75"

(222mm)

FRONT VIEW

"A"

15°

7.87"

(200mm)

7.87"

(200mm)

MAX.

3.94"

(100mm)

ADAPTER PLATE

TECHNICAL DRAWINGS

3.94"

(100mm)

7.87"

(200mm)

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

With 9.80"-13.90" (249-353mm) extension:

PC932A

PC932A-S

PC932A-W

With 13.78"-21.89" (350-556mm) extension:

PC932B

PC932B-S

PC932B-W

With 20.24"-34.02" (514-864mm) extension:

PC932C

PC932C-S

PC932C-W

DISPLAY ADAPTER

VESA ® Pattern

Universal Models:

75, 100, 200 x 100 and 200 x 200mm

SPECIFICATIONS

Distance from Ceiling

PC932A(-S)(-W):

PC932B(-S)(-W):

PC932C(-S)(-W):

Tilt | Swivel

9.80"-13.90"

(249-353mm)

13.78"-21.89"

(350-556mm)

20.24"-34.02"

(514-864mm)

+15/-5° | 360°

Max Load

80lb

(36kg)

Product Dimensions

(W x H x D)

PC932A(-S)(-W):

8.75" x 9.80"-13.90" x 6.50"

(222 x 249-353 x 165mm)

PC932B(-S)(-W):

8.75" x 13.78"-21.89" x 6.50"

(222 x 350-556 x 165mm)

PC932C(-S)(-W):

8.75" x 20.24"-34.02" x 6.50"

(222 x 514-864 x 165mm)

Mounting Surfaces

Ship Weight

Wood joist, concrete and truss

PC932A(-S)(-W):

PC932B(-S)(-W):

PC932C(-S)(-W):

6.4lb

(2.90kg)

6.85lb

(3.11kg)

8.1lb

(3.67kg)

CERTIFICATIONS

EN 60065

SIDE VIEW

1.80"

(46mm)

SIDE VIEW

15° TILT

MODEL NO.

PC932A

PC932B

PC932C

ISOMETRIC VIEW

MIN.

DIMENSION "A"

MAX.

9.80" (249mm) 13.90" (353mm)

13.78" (350mm) 21.89" (556mm)

20.24" (514mm) 34.02" (864mm)

4

5

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

93

Ceiling

Mount

For 13" to 29" Flat Panel Displays

MODELS

Universal Models:

Includes theft resistant hardware for attaching display to mount

LCC-18

LCC-18S

LCC-36

LCC-36S

Universal Models with Cable Management Covers:

Includes theft resistant hardware for attaching display to mount

LCC-18-C

Black

LCC-36-C

Black

DISPLAY ADAPTER

VESA

®

Pattern

Universal Models:

75 and 100mm

SPECIFICATIONS

Distance from Ceiling

LCC-18(S):

LCC-18-C(S):

LCC-36(S):

LCC-36-C(S):

Tilt | Swivel

19.35"-32.35"

(491-822mm)

20.26"-33.26"

(515-845mm)

36.85"-49.85"

(936-1266mm)

37.76"-50.76"

(959-1289mm)

+20/-5° | 360°

Max Load

40lb

(18kg)

Product Dimensions (W x H x D)

LCC-18(S):

5.00" x 19.35"-32.35" x 3.00"

(127 x 491-822 x 76mm)

LCC-18-C(S):

6.33" x 20.26"-33.26" x 6.33"

(161 x 515-845 x 161mm)

LCC-36(S):

5.00" x 36.85"-49.85" x 3.00"

(127 x 936-1266 x 76mm)

LCC-36-C(S):

6.33" x 37.76"-50.76" x 6.33"

(161 x 959-1289 x 161mm)

Mounting Surfaces

Ship Weight

Wood stud, concrete and various other applications

(Requires accessory)

LCC-18(S):

LCC-18-C(S):

LCC-36(S):

LCC-36-C(S):

4.6lb

(2.1kg)

7.3lb

(3.3kg)

6.2lb

(2.8kg)

10.6lb

(4.8kg)

CERTIFICATIONS

Quickship

Item

®

EN 60065

ACCESSORIES

ACC, CMJ, DCS, DCT Models:

Ceiling Plates .............. pg# 190-192

AEC, ALU and EXT Models:

Ceiling Extensions ............... pg# 193

ACC109:

Extension Column Connector .. pg# 193

1.

VESA ® 75 and 100mm compliant with non-VESA ® display adapter plates also available

2.

Cable management

cover models available for a clean look

3.

Continues tilt of +20/-5°

4.

0.75" (19mm) extension pipe for low-profile appearance and includes adapter to

1.5" (38mm) NPT pipe

5.

Portrait or landscape orientation

6.

Mounts in standard position

TECHNICAL DRAWINGS

LCC 18 models

19.35 (491mm) min.

32.35 (822mm) max.

LCC 36 models

36.85 (936mm) min.

49.85 (1266mm) max.

Standard

Position

94

LCC 18C models

20.26 (515mm) min.

33.26 (845mm) max.

LCC 36C models

37.76 (959mm) min.

50.76 (1289mm) max.

Standard Position

With Cover

6.3

(160 mm)

2

3

6

For expanded product information and technical data visit www.peerless-av.com

5

(127 mm)

3

(76 mm)

6.3

(160 mm)

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Ceiling

Mount

For 32" to 71" Flat Panel Displays

1.

0° to 20° adjustable tilt and 360° swivel

2.

Uses standard 1.5"

Universal Models

3.

Mount display vertically or horizontally with dedicated adapter plate

4.

Simple hook-on display installation

Dedicated Models

PLCM-UNL-CP

PLCM-1CP

For expanded product information and technical data visit www.peerless-av.com

18.00"

(457mm)

18.00"

(457mm)

2

PLCM-UN1-CP

PLCM-2

3

TECHNICAL DRAWINGS

18.00"

(457mm)

39.70"

(1008mm)

For expanded product information and technical data visit www.peerless-av.com

42.34"

(1075mm)

34.32"

TECHNICAL DRAWINGS

10.75"

(273mm)

15.79"

(401mm)

7.2"

(183mm)

17.05"

(433mm)

5.71"

(145mm)

28.76"

(731mm)

30.75"

(781mm)

PLCM-UNL-CP

10.24"

(260mm)

10.40" (264mm) MIN.

27.60" (701mm) MAX.

PLCM-UN1-CP

Model

PLCM-UNL-CP

PLCM-UNL

PLCM-UN1-CP

PLCM-UN1

PLCM-1CP

PLCM-1

PLCM-2

Screen Size Width Height

32"-65" 30.75"

(781mm)

42.34"

(1075mm)

32"-65"

30.75"

(781mm)

41.54"

(1055mm)

32"-55"

32"-55"

Up to 71"

Up to 71"

Up to 71"

27.60"

(701mm)

27.60"

(701mm)

18.00"

(457mm)

10.24"

(260mm)

10.24"

(260mm)

39.70"

(1008mm)

38.91"

(988mm)

34.32"

(872mm)

33.50"

(850mm)

5.71"

(145mm)

Depth

4.43"

(112mm)

4.43"

(112mm)

3.92"

(99mm)

3.92"

(99mm)

3.61"

(91mm)

3.25"

(82mm)

3.25"

(82mm)

Contents

Ceiling plate, adapter, column, base mount

Adapter, column, base mount

Ceiling plate, adapter, column, base mount

Adapter, column, base mount

Ceiling plate, column, base mount

Column, base mount

Base mount

PLCM-1CP

Max Load Ship Weight

200lb

(90kg)

33.3lb

(15.1kg)

200lb

(90kg)

30.3lb

(13.74kg)

125lb

(56kg)

125lb

(56kg)

225lb

(102kg)

225lb

(102kg)

225lb

(102kg)

30.1lb

(13.6kg)

27.4lb

(12.4kg)

18.7lb

(8.4kg)

16lb

(7.2kg)

7.5lb

(3.4kg)

MODELS

Universal Models:

(See chart for display size compatibility)

Includes theft resistant hardware for attaching display to mount

PLCM-UNL-CP

Black

PLCM-UNL

Black

PLCM-UN1-CP

Black

PLCM-UN1

Black

Dedicated Models:

(See chart for display size compatibility)

Display Adapter Purchased Separately*

PLCM-1

PLCM-1CP

Black

PLCM-2

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Mounting Pattern

Universal PLCM-UNL Models:

731 x 433mm

(28.76"W x 17.05"H)

Universal PLCM-UN1 Models:

701 x 401mm

(27.60"W x 15.70"H)

VESA ® Pattern

Universal Models:

Up to 600 x 400mm

Dedicated Models:

Requires display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Ceiling

See chart

Tilt | Swivel

+20° | 360°

Max Load

See chart

Product Dimensions (W x H x D)

See chart

Mounting Surfaces

Wood joist, concrete and various other applications

(May require accessory)

Ship Weight

See chart

CERTIFICATIONS

EN 60065

ACCESSORIES

ACC, CMJ, DCS, DCT Models:

Ceiling Plates .............. pg# 190-192

AEC, ALU and EXT Models:

Ceiling Extensions ............... pg# 193

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

95

Multi-Display Ceiling

Mount

For 32" to 50" Flat Panel Displays

MODELS

Dedicated Models:

Includes theft resistant hardware for attaching display to mount

Display adapter purchased separately*

MDJ700

MDJ710

Black

Black

MDJ720

Black

MDJ701

Curvilinear Display Black

MDJ711

MDJ721

Curvilinear Display Black

MDJ760

Circular Display Black

* Dedicated adapter plates come in flat black and include security fasteners

DISPLAY ADAPTER

Dedicated Models: Requires display-specific adapter to be purchased separately.

SPECIFICATIONS

Distance from Ceiling

1'-12' (305-3658mm)

Varies depending on ceiling plate and extension column used

Tilt | Swivel

+20° | 360°

Max Load

600-1200lb (272-545kg)

Depending on ceiling attachments used

Product Dimensions (Pipe Length)

MDJ700/701:

MDJ710/711:

MDJ720/721:

MDJ760:

120"

(3048mm)

180"

(4572mm)

240"

(6096mm)

48"

(1220mm)

Mounting Surfaces

Virtually all ceiling surfaces

(Requires accessory)

Ship Weight

MDJ700:

MDJ710:

MDJ720:

MDJ701:

MDJ711:

MDJ721:

MDJ760:

31lb

(14.1kg)

45lb

(20.4kg)

62lb

(28.1kg)

27lb

(20.4kg)

35lb

(15.9kg)

56lb

(24.5kg)

45lb

(20.4kg)

CERTIFICATIONS

1.

Multi-Display ceiling mount for 3 to 4 flat panel displays

2.

Three different configurations: in-line, curvilinear, and circular

3.

Choose desired ceiling drop length and drop length of equipment from pipe

4.

0° to 20° adjustable tilt

5.

360° swivel for

TECHNICAL DRAWINGS

PLCM-2

EXT or AEC

Circular configuration

In-line configuration

DCT

ADD

ACC600

PLP

For expanded product information and technical data visit www.peerless-av.com

ACCESSORIES

See chart for components needed to complete installation ...........pg# 97

Curvilinear configuration

96

To verify mount compatibility with any flat panel display or projector model use MountFinder TM at www.peerless-av.com

CALL: 630-375-5100

800-865-2112

FAX: 630-820-8537

800-359-6500

E-MAIL:

[email protected]

ONLINE:

www.peerless-av.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
