Impressing solutions

• •

••••

• •

••

• •

••

• • • •

• •

• •

• •• ••

••

• • • • ••

• • • • • • • • • • • • • ••

•• ••••••

• • •

• • • • • • • • • • ••

Embedded Imaging | 1

Pharmaceutics | Agriculture

Medical | Logistics

Communication | Avionics | Consumer

Networking | Automotive

Wellness | Industrial | Solar Technology

Embedded Imaging

Digital Imaging

New product

VM-011: 5 MPix Camera 2-3

Concept

Embedded Imaging 4-5

Embedded Imaging Components 6 phyCam Imaging System 7

Matching Processor Modules 8

Products

Embedded Imaging Kits 10-11

Digital Cameras and

Sensor Boards 12

Lens Mount Options / Cables 14

Analog-Video Converter 15

USB Cameras 16-17

PC-Framegrabber 18

Ring Light 19

Lenses 20

OEM Success Story

Curetis Medical Diagnosis 9

Ziehm Imaging C-arm 9

Milesys Intercom System 21

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

2 | Embedded Imaging

N E W

VM-011: 5 MPix Camera

Phytec expands its portfolio of embedded imaging products with the new 5 megapixel VM-011 camera board, available in monochrome and color options. These boards are based on the Aptina MT9P031 and MT9P006 CMOS image sensor. They offer outstanding image quality due to high resolution above the HD standard and Aptina’s Digital

Clarity

®

technology. The phyCAM standard ensures an easy connection to microcontroller systems.

RECommEndEd FoR:

Pharmaceutics | Agriculture

Medical | Logistics

Communication

Industrial | Networking

Healthcare | Consumer

Image Resolution

Type of interface

Color / Monochrome

Image sensor (Aptina)

Optical format

Pixel size

Video output

Color format

Frame rate (full-size image)

Dynamic range

Shutter type

Programming via

Operational mode

Power supply

Power consumption approx.

Output standby approx.

Features (optional)

Operating temperature

PCB dimensions approx.

Mounting points

Connection

Cable connection

Part Number

phyCAM-P color (-COL) mono (-BW)

2592 x 1944

phyCAM-S+ (-LVDS) color (-COL) mono (-BW)

MT9P006 MT9P031

1/2.5“ 5.7 x 4.28 mm

MT9P006 MT9P031

1/2.5“ 5.7 x 4.28 mm

2.2 µm x 2.2 µm

8 / 10 Bit digital

BW = Y / COL = Bayer Pattern up to 15 fps

2.2 µm x 2.2 µm

8 Bit digital

BW = Y / COL = Bayer Pattern up to 12.5 fps

67.74 dB

Rolling

I

2

C Bus

Master

2.8 V DC

450 mW

2 mW

67.74 dB

I

Rolling

2

C Bus

Master

3.3 V DC

700 mW

60 mW

Strobe, Trigger

-25°C to +70°C

34 x 34 mm

4 x M2.5

Strobe, Trigger

-25°C to +70°C

34 x 34 mm

4 x M2.5

33-pin FFC 8-pin Hirose

Cables see page 14

VM-011-COL VM-011-BW

Cables see page 14

VM-011-COL-LVDS VM-011-BW-LVDS

All cameras are available with lens holder options. See page 14 for order options.

phyCAM-S+ (LVDS) phyCAM-P

phyCAM-S+

Serial LVdS interface with only eight wires. new: The expanded phyCAm-S+ standard offers pixel rates of up to 80 mHz and is compatible with phyCAm-S.

phyCAM-P

Parallel interface, reduces interface effort to a minimum.

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging | 3

Image Resolution

2592 x 1944

2048 x 1536

1920 x 1080

1600 x 1200

1280 x 1024

1280 x 720

1024 x 768

800 x 600

640 x 480

Name

-

QXGA

FullHD

UXGA

SXGA

HD

XGA

SVGA

VGA

Resolution options

max. Frame rate Mode

15

21 window window

31

31

42

60 window window window binning

90

65

123

123

53

63

63

47

90 window skipping binning window skipping binning window skipping binning

EMBEDDED IMAgINg KIt

• Vm-011-CoL-LVdS (phyCAm-S+),

5 mPixel Camera with m12 lens

• phyCARd

®

-L System on module

• Texas Instruments omAP3530

• ARm

®

Cortex

-A8 Core, 720 mHz

• ddR RAm 256 mB

• nAnd Flash 256 mB

• Ethernet 10/100 mbit/s

• I

2

C / I

2

S

• SPI / UART

• 3 x USB Host / 1 x USB oTG

• SdIo / mmC / JTAG

• VGA display 5" with Touch

• Pre-installed Linux-Image

• Tool-Cd with drivers, demos and

examples

• Serial / Ethernet cable, power adapter

• Free Start-up support

1/3"

1/3"

1/6"

1/4"

1/4"

1/6.5"

1/2.5"

1/2.5"

Format

1/2.5"

1/3"

1/3"

1/4"

1/4.5"

1/2.5"

1/5.5"

Part Numbers

Variable Resolution

You can adapt the resolution easily to your application via software:

• Window (ROI)

The image is read from a subset of the sensor.

• Binning

Adjacent pixels are combined.

• Skipping

Pixels are skipped when read out.

Embedded Imaging Kit phyFLEX

®

-i.MX6

Embedded Imaging Kit phyFLEX-i.MX6

KPCA-A-L1-Video-L01

Additional Embedded Imaging Kits

see page 10-11

.eu

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

4 | Embedded Imaging

Embedded Imaging

We integrate professional imaging into your device

more and more systems use cameras in order to implement efficient features that recently were either impossible or technically difficult to realize.

Image sensors are becoming more popular for a wide variety of applications such as measurement technology, quality control or identification tasks like code reading. Also an increasing number of industrial products use multimedia components to improve the user interface even up to augmented reality.

The powerful microcontrollers with integrated camera interfaces simplify the implementation of camera sensors like never before while making it even cheaper.

Efficient Solutions

In order to efficiently implement image processing in an oEm product an individual approach is required. no matter whether the camera is the core of the application or only creates an added value, the entire system needs to be planned accordingly. optics, illumination, image resolution and computing power are important factors to be considered as well as other requirements like size, power consumption and economic factors.

“We are fully committed to establish the benefits of image processing for

OEM products. Leverage our experience to build a competitive advantage!“

Martin Klahr

Division Management

Embedded Imaging

Dirk Bender

Embedded Imaging Specialist

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

.

take Advantage of our Experience

We offer embedded imaging as part of a wide range of microcontroller products and development services.

Our Digital Imaging specialists will make sure that all requirements for image processing tasks are met. Our experts develop scalable concepts that can be applied directly to our customers’ products. In addition, our experts will support you during your project development and offer customized solutions.

“We will support you during all development phases in order to make your product successful.“

Heiko Fendrich

Division Management Embedded Imaging

Embedded Imaging - optimized for OEM Products

due to our efforts you will be able to integrate cameras into your application as easy as sensors. Add-in instead of add-on will increase synergy within the application and therefore cost efficiency of your product. Simplify your solutions and add new features to your application.

Our embedded systems offer competitive advantages taking production costs and long-term availability. See the next page to find out how Phytec can help to simplify custom design with offshelf series components.

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

Embedded Imaging | 5

6 | Embedded Imaging

Embedded Imaging

Components

Customized for Your Application

Optimized for OEM Products

The Phytec phyCAm concept easily fulfills the requirements of compact and customized system solutions.

The standardized phyCAm interfaces offer a combination of scalable microcontroller-

Soms and matching imaging components. This way we are able to provide you with a complete system that is perfectly adapted to your application.

Individualization - the key to successful Products

Besides image acquisition there are usually additional requirements for an embedded solution. Typically features such as motor control systems, GPS, Audio, CAn or I/o-lines are required.

Furthermore we need to customize the hardware to mechanical dimensions. With the concept of a Som and an application specific carrier board we are able to meet these requirements. The graphic below shows that the development workflow of a customized system can be broken down into six easily manageable steps.

This potential for individualization is the key component of your concept. It is the distinguishing factor in matters of standard, ready-made components.

Interfaces to your Software

The phyCAm concept already offers support for application software at the operating system level. The necessary drivers for camera sensors and the controller camera interface are integrated in our BSPs. For example for Embedded Linux the V4L2-Interface standard is used.

1) SOM Selection

×

2) Camera Module Selection

3) Start with the appropriate

3 Development Kit

4) Hardware Adaption 6) Customized Embedded

6) Imaging System

5) Application

Software Development

×

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Imaging System

phyCAM

Imaging System

Flexible, Modular Digital Imaging Solution

The phyCAm line offers easy integration of camera sensors into embedded microprocessor systems. Phytec offers two interface options: to integrate a camera. data and control signals are transmitted via a 33-pin FFC cable.

This reduces the interface effort to a minimum, while offering compatibility with other camera types. phyCAm-P cameras are fully compatible with phyCoRE ® Soms. eight leads, and can have a length of up to six meters (20 ft) to allow for more separation between the camera head and the control device. Various phyCARd ® and phyFLEX ® Soms are compatible with the phyCAm-S.

All phyCAm cameras are available with the following lens mount options:

Sensor only

More Information:

• phyCAM product overview: page 12-13

M12 lens holder

6) Customized Embedded

6) Imaging System

Features

Interface

Cable length

Cost optimized design

Interchangeable camera

More than 8-bit color depth (per channel) flexible cable connection

Use of special camera features

Remote camera head

Maximum data throughput rates

Best EMC properties

Use with phyCORE

®

SOMs

Use with phyCARD

®

SOMs

Use with phyFLEX

®

SOMs

phyCAM-P

33 pol. parallel approx 30 cm

+

+

+

+

+

+

+

+

+

+

+

phyCAM-S

8 pol. LVDS approx. 5 m

++

+

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

C/CS-mount lens holder

Embedded Imaging | 7

8 | Embedded Imaging

Matching Microcontroller Modules

SOM

Camera interface

Operating system

Processor family

MMU / Image processor

Video accelerator(s)

phyFLEX

®

-iMX 6

phyCAM-S+ phyCAM-P

Linux 3.x

phyCORE

®

-

OMAP4460

phyCAM-P

Quad Cortex-A9

4 x 1 GHz

yes / yes

2 x IPUv3H

VPUv6

Linux 3.x

Dual Cortex-A9

2 x 1.2 GHz

yes / yes

ISS

IVA-HD

phyCARD

®

-L

(OMAP3530)

phyCAM-S

Linux 3.x

Cortex-A8

720 MHz

yes / yes

ISP

IVA2.2

phyCARD

®

-M

(i.MX35)

phyCAM-S

Linux 3.x or

WinCE 6.0

ARM1136

535 MHz yes / yes

IPU

phyCORE

®

i.MX357

phyCAM-P

Linux 3.x or

WinCE 6.0

ARM1136

535 MHz yes / yes

IPU

phyCARD

®

-S

(i.MX27)

phyCAM-S

phyCORE

®

i.MX27

phyCAM-P

Linux 3.x or

WinCE 6.0

ARM926

400 MHz yes / yes eMMA / MPEG4

Codec

Linux 3.x or

WinCE 6.0

ARM926

400 MHz yes / yes eMMA / MPEG4

Codec

Software Library Support

HALCON Workflow

Develop your Application Software Easily

The phyCAM concept makes image data easily available for the application software. data processing can easily and efficiently be executed by the use of off-shelf image processing libraries. This way you can take advantages of our modular hardware as well as standard software solutions.

Examples

OpenCV our camera drivers are compatible with openCV, a free software library with more than 2,500 algorithms for fast image processing. You can easily integrate openCV into your application software in order to process image data. This software is available on a free BSd licence base.

HALCON embedded The powerful image processing software HALCon embedded simplefies the development of efficient applications easy. In partnership with mVTec

Phytec offers a new way to implement industry-proven algorithms on selected microcontroller modules. HALCon offers algorithms in professionally maintained libraries as well as a convenient, graphically programming environment.

For more information about HALCon see: www.mvtec.com

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging | 9

OEM Success Stories

CUREtIS UNYVERO

The Unyvero™ Solution shortens the diagnosis of severe bacterial infections to a few hours.

Curetis´ universal sample preparation technology prepares dnA from many native samples in a few minutes - without the need for timeconsuming pre-culturing of the sample. Also, Curetis´ technology uniquely addresses the analysis of antibiotic resistances in addition to bacteria detection.

Phytec developed the imaging system and the control units of the devices in close cooperation with Curetis. The control units consist of several phyCARd – modules and an application-specific carrier board.

The imaging system is based on a standard Vm-010 camera module. Phytec developed a specific LEd lightening module for probe illumination.

The modular design allows the re-use of several components in different devices which accelerated the design process and therefore reduced time-to-market significantly.

ZIEHM IMAgINg gMBH

Ziehm Imaging is the specialist for mobile X-ray based imaging for clinical applications such as orthopedics, traumatology, vascular surgery and valve implantation. Ziehm Imaging enables a new dimension in mobile imaging and has been awarded several prizes.

Ziehm Imaging advanced developments in X-ray based surgery due to the latest technology such as oddC software and an extensive know-how in medical imaging. Ziehm Imaging uses a

Phytec Messtechnik System On Module in its C-arm mobile X-ray imaging systems.

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

10 | Embedded Imaging

Embedded Imaging Kits

Development Kits with Digital Cameras for Embedded Imaging get started with an Embedded Imaging Kit

Phytec Embedded Imaging Kits include all necessary components for an embedded system with integrated digital imaging.

Our kits enable customers to create their own individual digital imaging solutions fast and effectively. Even during the design phase, camera options can be adapted to system requirements due to the flexibility of the standardized camera interface.

The unified bus system of the phyCARd ® and phyFLEX ® concept also enables scaling of the computing power within systems that utilize our imaging hardware.

Software Drivers are included

our Embedded Imaging Kits include the appropriate software drivers to access the camera modules from customer application software. depending on the operating system, camera drivers can be accessed via the Linux V4L2 interface or Windows CE DirectShow.

Kit software contains demo applications to test the functions of integrated cameras and display captured images.

Images or image sequences can be saved in various formats.

For Linux, demo applications are based on the popular GStreamer framework. For Windows Embedded we provide demo applications with C++ source code.

Software

CPU

Memory

Interfaces

Kit-

Content

Architecture

Module

Camera interface

Operating sytem

Real time

BSP / Image

Bootloader

Toolchain

Compiler

Debug interface

Processor

Clock frequency

MMU

Video accelerator

Image Processor

RAM

SRAM

NOR Flash

NAND Flash

EEPROM

Ethernet

CAN

USB

RS232

Audio

SPI / I

2

C

RTC

CF / SD / MMC

Expansion bus

Camera

Module

Camera

Lens

Carrier Board

Mapper Board

Display

Touch

Tool-CD

QuickStart

Instructions

Schematics

Free Support

Part Number

ARM

®

Cortex

-A9

Embedded Imaging

Kit phyFLEX-i.MX 6

2 x phyCAM-S+

/ 2 x phyCAM-P

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

Freescale i.MX 6

4 x 1 GHz yes

2 x IPUv3H, VPUv6

ARM

®

Cortex

-A8

Embedded Imaging

Kit phyCARD-L

phyCAM-S

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

TI OMAP3530

720 MHz yes

ISP, IVA2.2 subsystem yes

1 GB DDR3

-

16 MB (SPI)

1 GB

4 kB

10/100/1000 Mbit/s yes

OTG HS, 2 x Host yes

256 MB DDR

-

-

256 MB

4 kB

10/100 Mbit/s

-

OTG HS, 3 x Host

2 x 2 x yes yes / yes yes

- / yes / yes yes

2 x phyCAM-S+ (8-pin)

/ 2 x phCAM-P (33-pin) yes yes / yes yes

- / yes / yes yes phyCAM-S (8-pin) phyFLEX

®

-i.MX 6

5 MPix color camera

VM-011-COL-M12 phyCARD

®

-OMAP3

5 MPix color camera

VM-011-COL-LVDS-M12

12 mm, M12 with IR cut 12 mm, M12 with IR cut yes yes yes

-

WVGA 7“ yes yes

VGA 5“ yes yes yes yes yes

KPFL-A-02-

Video-L01

yes yes yes

KPCA-A-L1-

Video-L01

ARM11

Embedded Imaging Kit phyCARD-M

phyCAM-S phyCAM-S

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio GNU

JTAG

Freescale i.MX357

JTAG

532 MHz yes

532 MHz yes

IPU IPU yes

128 MB DDR2

-

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes phyCAM-S (8-pin) phyCARD

®

-i.MX357

1.3 MPix color camera

VM-009-LVDS-M12

12 mm, M12 with IR cut yes

yes

-

VGA 5“ yes yes

VGA 5“ yes yes yes

128 MB DDR2

-

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes yes yes yes

KPCA-A-M1-

Video-L01

yes yes yes

KPCA-A-M1-

Video-W01

ARM9

Embedded Imaging Kit phyCARD-S

phyCAM-S phyCAM-S

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio

JTAG

Freescale i.MX27

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

-

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

-

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes phyCAM-S (8-pin) phyCARD

®

-i.MX27

WVGA color camera

VM-010-COL-LVDS-M12

12 mm, M12 with IR cut yes

yes

-

VGA 5“ yes yes

VGA 5“ yes yes yes yes yes

KPCA-A-S1-

Video-L01

yes yes yes

KPCA-A-S1-

Video-W01

ARM11

Embedded Imaging Kit i.MX35

phyCAM-P phyCAM-P

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio GNU

JTAG

Freescale i.MX357

JTAG

532 MHz yes

532 MHz yes

IPU IPU yes

128 MB DDR2

-

32 MB

1 GB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes

- / yes / yes yes yes

128 MB DDR2

-

32 MB

1 GB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes

- / yes / yes yes phyCAM-P (33-pin) phyCORE

®

-i.MX357

1.3 MPix color camera

VM-009-M12

12 mm, M12 with IR cut yes yes yes yes

QVGA 3.5“ yes yes

QVGA 3.5“ yes yes yes yes yes

KPCM-043-

Video-L01

yes yes yes

KPCM-043-

Video-W01

ARM9

Embedded Imaging Kit i.MX27

phyCAM-P phyCAM-P

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio

JTAG

Freescale i.MX27

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

256 kB

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

256 kB

32 kB

64 MB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes yes / yes / yes yes

32 kB

64 MB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes yes / yes / yes yes phyCAM-P (33-pin) phyCORE

®

-i.MX27

WVGA color camera

VM-010-COL-M12

12 mm, M12 with IR cut yes yes yes yes

QVGA 3.5“ yes yes

QVGA 3.5“ yes yes yes yes yes

KPCM-038-

Video-L

yes yes yes

KPCM-038-

Video-W01

You can combine each kit with different phyCAM cameras.

Please contact the Phytec sales team for more information.

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging Kits | 11

Software

CPU

Memory

Interfaces

Kit-

Content

Architecture

Module

Camera interface

Operating sytem

Real time

BSP / Image

Bootloader

Toolchain

Compiler

Debug interface

Processor

Clock frequency

MMU

Video accelerator

Image Processor

RAM

SRAM

NOR Flash

NAND Flash

EEPROM

Ethernet

CAN

USB

RS232

Audio

SPI / I

2

C

RTC

CF / SD / MMC

Expansion bus

Camera

Module

Camera

Lens

Carrier Board

Mapper Board

Display

Touch

Tool-CD

QuickStart

Instructions

Schematics

Free Support

Part Number

ARM

®

Cortex

-A9

Embedded Imaging

Kit phyFLEX-i.MX 6

2 x phyCAM-S+

/ 2 x phyCAM-P

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

Freescale i.MX 6

4 x 1 GHz yes

2 x IPUv3H, VPUv6

ARM

®

Cortex

-A8

Embedded Imaging

Kit phyCARD-L

phyCAM-S

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

TI OMAP3530

720 MHz yes

ISP, IVA2.2 subsystem yes

1 GB DDR3

-

16 MB (SPI)

1 GB

4 kB

10/100/1000 Mbit/s yes

OTG HS, 2 x Host yes

256 MB DDR

-

-

256 MB

4 kB

10/100 Mbit/s

-

OTG HS, 3 x Host

2 x 2 x yes yes / yes yes

- / yes / yes yes

2 x phyCAM-S+ (8-pin)

/ 2 x phCAM-P (33-pin) yes yes / yes yes

- / yes / yes yes phyCAM-S (8-pin) phyFLEX

®

-i.MX 6

5 MPix color camera

VM-011-COL-M12 phyCARD

®

-OMAP3

5 MPix color camera

VM-011-COL-LVDS-M12

12 mm, M12 with IR cut 12 mm, M12 with IR cut yes yes yes

-

WVGA 7“ yes yes

VGA 5“ yes yes yes yes yes

KPFL-A-02-

Video-L01

yes yes yes

KPCA-A-L1-

Video-L01

ARM11

Embedded Imaging Kit phyCARD-M

phyCAM-S phyCAM-S

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio GNU

JTAG

Freescale i.MX357

JTAG

532 MHz yes

532 MHz yes

IPU IPU yes

128 MB DDR2

-

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes phyCAM-S (8-pin) phyCARD

®

-i.MX357

1.3 MPix color camera

VM-009-LVDS-M12

12 mm, M12 with IR cut yes

yes

-

VGA 5“ yes yes

VGA 5“ yes yes yes

128 MB DDR2

-

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes yes yes yes

KPCA-A-M1-

Video-L01

yes yes yes

KPCA-A-M1-

Video-W01

ARM9

Embedded Imaging Kit phyCARD-S

phyCAM-S phyCAM-S

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio

JTAG

Freescale i.MX27

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

-

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

-

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes

-

128 MB

4 kB

10/100 Mbit/s

-

OTG HS, Host HS

1 x yes yes / yes yes

- / yes / yes yes phyCAM-S (8-pin) phyCARD

®

-i.MX27

WVGA color camera

VM-010-COL-LVDS-M12

12 mm, M12 with IR cut yes

yes

-

VGA 5“ yes yes

VGA 5“ yes yes yes yes yes

KPCA-A-S1-

Video-L01

yes yes yes

KPCA-A-S1-

Video-W01

ARM11

Embedded Imaging Kit i.MX35

phyCAM-P phyCAM-P

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio GNU

JTAG

Freescale i.MX357

JTAG

532 MHz yes

532 MHz yes

IPU IPU yes

128 MB DDR2

-

32 MB

1 GB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes

- / yes / yes yes yes

128 MB DDR2

-

32 MB

1 GB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes

- / yes / yes yes phyCAM-P (33-pin) phyCORE

®

-i.MX357

1.3 MPix color camera

VM-009-M12

12 mm, M12 with IR cut yes yes yes yes

QVGA 3.5“ yes yes

QVGA 3.5“ yes yes yes yes yes

KPCM-043-

Video-L01

yes yes yes

KPCM-043-

Video-W01

ARM9

Embedded Imaging Kit i.MX27

phyCAM-P phyCAM-P

Linux 3.x

RTpreempt yes / yes

Barebox

Eclipse

GNU

JTAG

WinCE 6.0

yes yes / yes

Eboot

Visual Studio incl.

Platform Builder

Visual Studio

JTAG

Freescale i.MX27

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

256 kB

400 MHz yes eMMA / MPEG4

Codec yes

128 MB DDR

256 kB

32 kB

64 MB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes yes / yes / yes yes

32 kB

64 MB

4 kB

10/100 Mbit/s yes

OTG HS, Host HS

2 x yes yes / yes yes yes / yes / yes yes phyCAM-P (33-pin) phyCORE

®

-i.MX27

WVGA color camera

VM-010-COL-M12

12 mm, M12 with IR cut yes yes yes yes

QVGA 3.5“ yes yes

QVGA 3.5“ yes yes yes yes yes

KPCM-038-

Video-L

yes yes yes

KPCM-038-

Video-W01

You can combine each kit with different phyCAM cameras.

Please contact the Phytec sales team for more information.

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

12 | Embedded Imaging

Digital Cameras and Sensor Boards

CMOS-Camera modules for direct connection to a microcontroller module

Ready-for-use camera boards for direct connection to a digital controller camera interface the phyCAM System

Perfect Integration of Cameras in OEM Products

Camera boards with phyCAm interface easily connect to the digital camera interface of the Phytec microcontroller board. It offers simple integration of camera technology for compact, customer specific products.

High Flexibility – Simple Customization

You can easily exchange both mircocontroller Soms and camera boards. This enables you to perfectly customize your solution to the requirements of the application. due to the compatible phyCAm interface, all cameras can be interchanged – even during design phase. All camera boards are standardized in size and have the same mounting points. We offer these cameras with and without C/CS mount or M12 lens mount. Therefore you can easily adapt the camera to the optical requirements of your application.

Software Drivers are Included

The board support packages (BSPs) of the compatible phyCORE

®

Soms already include the appropriate software drivers for the cameras.

Therefore, the cameras can be easily integrated into software applications for Windows

Embedded CE or Embedded Linux. You can access the camera drivers via Linux V4L2 interface or via GStreamer.

Camera board VM-010

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging | 13

Camera Boards

Example figures

Image Resolution

Interface type

Color / Monochrome

Image sensor (Aptina)

Optical format

Pixel size

Video output

Color format

Data shifting

2592 x 1944

phyCAM-P phyCAM-S+

(-LVDS) phyCAM-P

1280 x 1024

phyCAM-S

(-LVDS) phyCAM-P phyCAM-S

(-LVDS)

752 x 480

phyCAM-P phyCAM-S

(-LVDS) color

(-COL)

MT9

P006 mono

(-BW)

MT9

P031 color

(-COL)

MT9

P006 mono

(-BW)

MT9

P031 color

MT9M131

CMOS color

MT9M131

CMOS monochrome

MT9M001

CMOS monochrome

MT9M001

CMOS color

(-COL) mono

(-BW)

MT9V024

CMOS color

(-COL) mono

(-BW)

MT9V024

CMOS

1/2.5“ 5.7 mm x 4.28 mm 1/3“ 4.6 mm x 3.7 mm 1/2“ 6.66 mm x 5.32 mm 1/3“ 4.51 mm x 2.88 mm

2.2 µm x 2.2 µm 2.2 µm x 2.2 µm 3.6 µm x 3.6 µm 3.6 µm x 3.6 µm 5.2 µm x 5.2 µm 5.2 µm x 5.2 µm 6 µm x 6 µm 6 µm x 6 µm

8 / 10 Bit digital 8 Bit digital 8 / 10 Bit digital 8 Bit digital 8 / 10 Bit digital 8 Bit digital 8 / 10 Bit digital 8 Bit digital

-BW = Y / -COL = Bayer Pattern

YUV / RGB / Bayer Pattern

(configurable)

Y (mono) -BW = Y / -COL = Bayer Pattern

optional

1

(-MUX)

optional

1

(-MUX)

-

Frame rate

(full-size image)

Dynamic range

High dynamic range

Shutter type

Programming via

Operational mode up to 15 fps

67.74 dB

-

I

Rolling

2

C Bus up to 12.5 fps

67.74 dB

I

Rolling

2

-

C Bus to 15 fps

I

2

71 dB

-

Rolling

C Bus to 11 fps

I

71 dB

-

Rolling

2

C Bus to 30 fps

68.2 dB

I

Rolling

2

-

C Bus to 25 fps

I

68.2 dB

2

-

Rolling

C Bus to 60 fps to 60 fps

> 55 dB (linear) > 55 dB (linear)

> 80 to 100 dB > 80 to 100 dB

Global

I

2

C Bus I

Global

2

C Bus

Power supply

Power consumption approx.

Output standby approx.

Master

2.8 V DC

450 mW

Master

3.3 V DC

700 mW

Master

2.8 V DC

170 mW

Master

3.3 V DC

500 mW

Master / Slave

3.3 V DC

363 mW

Master

3.3 V DC

500 mW

Master / Slave

3.3 V DC

220 mW

Master

3.3 V DC

320 mW

2 mW 60 mW 300 mW 300 mW 100 µW 120 µW

Features (optional)

Strobe

Trigger

Strobe

Trigger

Strobe Strobe

Strobe

Trigger

Strobe

Trigger

Strobe

Trigger

LED Light

Strobe

Trigger

LED Light

Operating temperature -25°C to +70°C -25°C to +70°C -25°C to +70°C -25°C to +70°C 0°C to +70°C 0°C to +70°C -25°C to +85°C -25°C to +85°C

PCB dimensions approx. 34 x 34 mm

Mounting points 4 x M2.5

Connection 33-pin FFC

Cable connection

Part Number

34 x 34 mm

4 x M2.5

8-pin Hirose

Cables see page 14

VM-011

34 x 34 mm

4 x M2.5

33-pin FFC

34 x 34 mm

4 x M2.5

8-pin Hirose

Cables see page 14

VM-009

34 x 34 mm

4 x M2.5

33-pin FFC

34 x 34 mm

4 x M2.5

8-pin Hirose

Cables see page 14

VM-006

34 x 34 mm

4 x M2.5

33-pin FFC

34 x 34 mm

4 x M2.5

8-pin Hirose

Cables see page 14

VM-010

Note 1: The ’-MUX‘ option offers dynamic switching between 8-bit and 10-bit interface.

Note

The part number consists of the different options in the table columns. Example: VM-010-BW-

LVDS-M12: Camera board with monochrome sensor MT9V024, phyCAM-S Interface and M12 lens mount.

Select a matching lens on page 20.

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

14 | Embedded Imaging

Lens Mount Options

Each camera is available with or without m12 lens mount or C/CS lens mount.

Order options

Lens holder

Dimensions (mm), approx.

values, without lens

Weight

-

Sensor only

34 x 34 x 6

7 g

Delivery without lens mount. For matching lens mounts see page 20.

phyCAM Cables

-M12

M12 (0.5), S-mount

34 x 34 x 20

8 g

-H

C/CS-mount

34 x 34 x 17

24 g

WF062

phyCAM-P

33-pin Flat Foil Cable (FFC), 0.5 mm pitch,

Type A, connection on same side, reinforced

Part Number Length

WF043 0.2 m

WF057 0.4 m

phyCAM-S

8-pin LVDS cable, CAT5e shielded, RJ45 to Hirose DF13-08S-1.25C

WK216

Part Number

WK216-0.5

WK216-5.0

Length

0.5 m

5.0 m

WK295

trigger / Strobe Cable

JST connectors on both sides, 3-pin,

1 mm pitch

Part Number

WK295

Length

0.25 m

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging | 15

Analog Video Converter

PAL / NTSC Digitizer for Microcontroller SOMs

The video converter with four signal inputs and phyCAm-P as well as phyCAm-S interface offers integration of analog video sources in embedded imaging systems.

This converter (color-framegrabber) digitalizes analog video signals (TV systems PAL and nTSC) into a digital data stream. The phyCAm-S and phyCAm-P interface transfers the digital image data to the processor board as ITU-R 601 or ITU-R 656 YCbCr (4:2:2) data stream.

The converter is well suited for applications that already have analog cameras or where the distance to the camera is very high. Typical applications are surveillance systems, special purpose vehicles and the integration of analog image sources such as ultrasonic equipment.

Features

VM-008

Part Number

Resolution PAL / NTSC

Video decoder

Scanner system

Frames rate PAL / NTSC

Inputs

Input format

Outputs

Output format

Programming via

Power supply

Features (optional)

Operating temperature

Dimensions approx.

Mounting points

VM-008

720 x 576 / 720 x 480

Techwell 9910 interlaced

25 fps / 30 fps

3 BNC / 1 MiniDIN

3 FBAS / 1 S-Video phyCAM-P / -S

8 Bit digital, YCrCb

I

2

C Bus

3.3 V DC

EEPROM, LEDs

-25 °C to +85 °C

34 x 100 mm

4 x M2.5

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

16 | Embedded Imaging

USB Cameras

Ultra compact USB cameras with resolutions of up to 5-megapixel

USB Cameras for Industrial Applications

The USB-CAm series addresses industrial applications. They can be connected with a few simple steps to any computer providing an USB interface. due to the small metal housing

(only 36 mm x 36 mm x 25mm) with mounting threads on all four sides, USB-CAms can be mounted in almost all locations. We also offer the cameras without housing in volumes.

due to its excellent price performance ratio, system desigers can implement this 5-megapixel camera in locations where only cameras with lower resolutions have been used so far. You can easily adjust the image resolution by software to adapt the camera to various tasks.

The pan and scan feature offers adjustment of the active field of view without any mechanical adjustments. The new 1080p as well as 720p Hd formats offer excellent camera image adjustment to 16:9 screens.

Software Drivers and Demo Software are included

Shipment includes drivers for Windows 2000, Windows XP, Vista and Windows 7.

The USB-CAm is compatible to all software that uses the directX-interface. The free

SdK enables implementation into your own applications.

We also include a demo software for Windows that simplifies start-up. If you like to use Linux the free UVC interface drives gives access the camera. Therefore you can also connect these cameras to selected Phytec microcontroller boards with Embedded Linux via

V4L2.

the One for All - Concept

You can easily adjust the USB-CAM series cameras to their tasks with our software. The table on the right shows all resolutions can be adjusted with software:

• Region of interest (ROI)

The image is read from a part of the camera sensor only. Please note the virtually smaller

sensor size when selecting lenses. RoI increases the possible frame rate (fps).

• Binning

Binning combines several adjacent pixels into a single pixel and therefore increases sensitivity.

Accessories

USB cable

Trigger cable

WK184 - 1.5 m

WK297 - 3 m

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging | 17

Image Resolution 5 megapixels WVGA

Image Formats

Model

Color /

Monochrome

Optical format

2592 x 1944, 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768,

640 x 480; Binning Mode: 1280 x 960, 640 x 480

744 x 480, 640 x 480, 320 x 240

USB-CAM-051H USB-CAM-151H USB-CAM-052H USB-CAM-152H USB-CAM-003H USB-CAM-103H USB-CAM-004H USB-CAM-104H

monochrome

1/2.5” monochrome

1/2.5” color

1/2.5” color

1/2.5” monochrome

1/3” monochrome

1/3” color

1/3” color

1/3”

Image sensor

(Aptina)

Pixel Size

MT9P031, CMOS MT9P031, CMOS MT9P031, CMOS MT9P031, CMOS MT9V024, CMOS MT9V024, CMOS MT9V024, CMOS MT9V024, CMOS

Color format

Lens holder

Frame rate

Dynamic range

Shutter type

Reponsivity

Interface

2.2 µm x 2.2 µm 2.2 µm x 2.2 µm 2.2 µm x 2.2 µm 2.2 µm x 2.2 µm 6 µm x 6 µm

Y8

C/CS–Mount

Y8

C/CS–Mount

RGB32, RGGB

(RAW)

C/CS–Mount

RGB32, RGGB

(RAW)

C/CS–Mount

Y8

C/CS–Mount

6 fps bis zu 52 fps

8 Bit

Rolling

1.4 V/lux-sec

USB 2.0 HS

6 fps bis zu 52 fps

8 Bit

Rolling

1.4 V/lux-sec

USB 2.0 HS

6 fps bis zu 52 fps

8 Bit

Rolling

1.4 V/lux-sec

USB 2.0 HS

6 fps bis zu 52 fps

8 Bit

Rolling

1.4 V/lux-sec

USB 2.0 HS

60 fps bis zu

150 fps

8 Bit

Global

4.8 V/lux-sec

USB 2.0 HS

6 µm x 6 µm

Y8

C/CS–Mount

60 fps bis zu

150 fps

8 Bit

Global

4.8 V/lux-sec

USB 2.0 HS

6 µm x 6 µm

RGB32, RGGB

(RAW)

C/CS-Mount

60 fps bis zu

150 fps

8 Bit

Global

4.8 V/lux-sec

USB 2.0 HS

6 µm x 6 µm

RGB32, RGGB

(RAW)

C/CS–Mount

-

8 Bit

Global

4.8 V/lux-sec

USB 2.0 HS

Shutter speed 1/10,000 s to 30 s 1/10,000 s to 30 s 1/10,000 s to 30 s 1/10,000 s to 30 s 1/10,000 s to 1/4 s 1/10,000 s to 1/4 s 1/10,000 s to 1/4 s 1/10,000 s to 1/4 s

Gain 0 dB to 18 dB 0 dB to 18 dB 0 dB to 18 dB 0 dB to 18 dB 0 dB to 18 dB 0 dB to 18 dB 0 dB to 18 dB 0 dB to 18 dB

White Balance

AWB

Power supply

Power consumption

-

4.5 V to 5.5 V DC 4.5 V to 5.5 V DC 4.5 V to 5.5 V DC 4.5 V to 5.5 V DC 4.5 V to 5.5 V DC 4.5 V to 5.5 V DC 4.5 V to 5.5 V DC 4.5 V to 5.5 V DC

1.3 W

-

1.3 W

-6 dB to +6 dB

1.3 W

-6 dB to +6 dB

1.3 W

-

1.3 W

-

1.3 W

-6 dB to +6 dB

1.3 W

-6 dB to +6 dB

1.3 W

Feature (optional) -

Operating temp.

-5°C to +45°C

Dimensions approx.

36 mm x 36 mm x 25 mm ext. Trigger,

Digital-Output

-5°C to +45°C

36 mm x 36 mm x 25 mm

-

-5°C to +45°C

36 mm x 36 mm x 25 mm ext. Trigger,

Digital-Output

-5°C to +45°C

36 mm x 36 mm x 25 mm

-

-5°C to +45°C

36 mm x 36 mm x 25 mm ext. Trigger,

Digital-Output

-5°C to +45°C

36 mm x 36 mm x 25 mm

-

-5°C to +45°C

36 mm x 36 mm x 25 mm ext. Trigger,

Digital-Output

-5°C to +45°C

36 mm x 36 mm x 25 mm

Mounting points 1/4“, on all sides 1/4“, on all sides 1/4“, on all sides 1/4“, on all sides 1/4“, on all sides 1/4“, on all sides 1/4“, on all sides 1/4“, on all sides

Weight 70 g 70 g 70 g 70 g 70 g 70 g 70 g 70 g

USB Mini-B USB Mini-B USB Mini-B USB Mini-B Connection

Feature connection

Part Number

-

AK091

USB Mini-B

Hirose-socket

HR10A-7R-4P

AK093

-

AK092

USB Mini-B

Hirose-socket

HR10A-7R-4P

AK094

-

AK087

USB Mini-B

Hirose-socket

HR10A-7R-4P

AK089

-

AK088

USB Mini-B

Hirose-socket

HR10A-7R-4P

AK090

Method

5 MPix Models

Resolution

Region of interest

Binning mode

WVGA Models

2592 x 1944

2048 x 1536

1900 x 1080*

1600 x 1200

1280 x 960

1280 x 720*

1024 x 768

640 x 480

1280 x 960

640 x 480

* Hd formats (1080 p13 and 720 p25)

Format

1/2.5“

1/3“

1/3”*

1/4“

1/4.5“

1/5”*

1/5.5“

1/9“

1/2.5“

1/2.5“

fps

19

25*

27

52

6

9

13*

13

15

23

Reponsivity

1.4 V/lux-sec

1.4 V/lux-sec

1.4 V/lux-sec*

1.4 V/lux-sec

1.4 V/lux-sec

1.4 V/lux-sec*

1.4 V/lux-sec

1.4 V/lux-sec

5.6 V/lux-sec

22.4 V/lux-sec

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

18 | Embedded Imaging

PC-Framegrabber

C-rabber

Industrial Framegrabber Cards for PC-based Solutions

The pciGrabber-4x4 is the flagship product of our framegrabber line for standard PC systems.

Because it features four independent video decoders, this framegrabber card can digitalize four image sources in parallel. The pciGrabber-4x4 can easily be extended to 16 input channels by adding an expansion card.

The pciGrabber family includes also models with single video decoder and up to 4 multiplexed video inputs. due to the identical software interfaces for all members of the pciGrabber family, all Phytec framegrabbers are interchangeable.

This way investments in software development can be reduced to a minimum. Please see our website for our development kits: www.phytec.eu/imaging

Model

Composite inputs

Thereof BNC plugs

S-Video inputs

Thereof Mini-DIN plugs

Video decoders

User-EEPROM (256 Byte)

Bus system

TTL-I/O

Buffered I/O (0 V to 28 V)

I 2 C interface

Watchdog

Codejumper/-switch

Relais output

Color-/Greyscale-resolution

Programmable settings

Windows drivers

Linux drivers

HALCON / ActiVision

Part Number

16

4 (+12*)

-

-

4

4

pciGrabber-4x4

12

- (+12*)

4

4

4

4

6

2 (+4*)

2

2

2

2

pciGrabber-4express

3

2 (3**)

1

1

1

1

3

pciGrabber-4plus

9

- (3**)

1

- (9***)

1

1

1

1

1

1

1

eGrabber-4plus

3

2 x SMB

1

9

2 x SMB

1

1

1

1

1

1

1

8

-

1 optional

4

-

PCI-Express (PCIe x 1)

8

-

1 optional

4

8

-

1 optional

4

PCI-Express (PCIe x1)

12

1

1

-

4****

PCI

12

1

1

-

4****

PCI

12

1

1

-

4****

12

1

1

-

-

PC/104plus (PCI)

4**** 4**** 4**** -

768 x 576 pixel with 16 Mio. colors / 256 Greyscale. Scaling and setting of a region of interest (ROI) possible

Brightness ± 50% / Contrast 0% to 235%, Gamma correction

12

1

1

-

-

-

VD-012 VD-012-X1 VD-012-X2

Win 95, 98, ME, NT, 2000, XP, Vista, Windows7

BTTV-compatible

VD-011

compatible

VD-009-X1 VD-009 EPC-032 EPC-032-X1

* By use of one or more expansion cards VZ-012 (each card provides 4 add. BnC inputs)

** By use of combination-connector (HD-DB15) with cable WK-022

*** By use of combination-connector (HD-DB15) with cable WK-022 and WK-012

**** order option –RS (for example, Vd-011-RS)

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

Embedded Imaging | 19

Ring Light CLS49

LED Light for Lens Mounting

Ring Lights VZ-001 and VZ-002

Electronically regulated models with adjustable brightness

With its even and shadow-free illumination the ring light CLS49 offers ideal conditions for reliable operation of image processing systems. The ring light can be perfectly adjusted to the task by the usage of additional lens rings. The focusing lens ring concentrates the light to a defined area. You can achieve an uniform as well as low-reflectance illumination with the diffuser lenses.

The brightness can be adjusted by a trimmer on the backside of the ring light. The integrated regulator will keep the brightness constant within a wide input voltage range. We also offer unregulated versions.

Clamping screws offer simple mounting on the camera lens.

We offer custom variations upon demand.

Luminescent color brightness

Voltage range

White max. 78.000

Red max. 200.000

(mcd)

10 V to

18 V

20 V to

32 V

10 V to

18 V

20 V to

32 V

Front panels

Set of 3 (clear focusing, focusing diffuse and diffuse)

1 x clear, focusing

1 x focusing, diffuse

1 x diffuse

Set of 3 (clear focusing, focusing diffuse and diffuse)

1 x clear, focusing

1 x focusing, diffuse

1 x diffuse

Set of 3 (clear focusing, focusing diffuse and diffuse)

1 x clear, focusing

1 x focusing, diffuse

1 x diffuse

Set of 3 (clear focusing, focusing diffuse and diffuse)

1 x clear, focusing

1 x focusing, diffuse

1 x diffuse

Accessories

Part

Number

VZ-001-X1

VZ-001-X2

VZ-001-X3

VZ-001-X4

VZ-003-X1

VZ-003-X2

VZ-003-X3

VZ-003-X4

VZ-002-X1

VZ-002-X2

VZ-002-X3

VZ-002-X4

VZ-004-X1

VZ-004-X2

VZ-004-X3

VZ-004-X4

Features

• max. Intensity: 200,000 mcd (red), 78,000 mcd (white)

• Brightness: adjustable (stabilized)

• Number of LEDs: 24

• Colors: white, red

• Supply current: < 160 mA at 12 V

• Power supply: 10 V to 18 V DC or 20 V to 32 V DC

• Outside diameter: 75 mm

• Inside diameter: 49 mm

• Connection: cable with coaxial power-connector

• With integrated current stabilization

• Unregulated versions upon request

Components

Adaptor

Data

12 V, max. 2 A

Connection

DC Plug

Part Number

SV-023

For detailed product information and manuals please see our website: www.phytec.eu/europe/products/digital-imaging

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

20 | Embedded Imaging

Lenses

We offer a wide selection of C/CS-mount and M12 lenses

Fixed Focal Length

Focal length

4.8 mm

6.0 mm

8.5 mm

12 mm

16 mm

25 mm

35 mm

50 mm

50 mm

Iris range

1.8...C

1.2...C

1.5...C

1.2...22

1.4...22

1.4...22

1.6...16

2.8...22

1.4...C

MOD

0.2 m

0.2 m

0.2 m

0.2 m

0.3 m

0.3 m

Lens mount

C-Mount

C-Mount

Angle of view 1/3“

55°07‘

43°33‘

C-Mount 31°52‘

C-Mount 22°04‘

C-Mount

C-Mount

0.35 m C-Mount

0.9 m C-Mount

1.0 m C-Mount

16°55‘

10°58‘

7°51‘

5°30‘

5°30‘

Locking screws

yes yes yes yes yes yes yes yes yes

Part

Number

AO016

AO053

AO047

AO035

AO026

AO007

AO051

AO052

AO049

C/CS-Mount Zoom- and Vario-Lenses

C/CS-MOUNt LENSES

High quality PEnTAX video lenses. Excellent image quality for image processing as well as visualization applications.

The lenses offer manually adjustable apertures.

Fixing screws offer locking of the adjustment rings. The zoom and vario lenses are well suited for applications that require exact adjustment of the image section or for applications for which the object size changes often.

Focal length

3.0...8.0

manual

8.0...48.0

manual

12.5...75.0 manual

Iris range

1.0...C manual

1.2...C

manual

1.5...C manual

MOD

Lens mount

0.3 m CS-Mount

1.2 m

1.0 m

C-Mount

C-Mount

diameter, length

36.3 mm

44.4 mm

57 mm

95 mm

51 mm

90 mm

Locking screws

yes

-

Part

Number

AO020

AO006

AO018

Note

The lenses shown represent only a selection of our product line.

We will be happy to advise you if you need a lens with other specifications.

Produktpalette. Wir beraten Sie gerne, wenn Sie ein Objektiv mit anderen Eigenschaften benötigen.

Lens mount

Part

Number

0.5 mm / 1 mm / 5 mm / 10 mm / 20 mm / 40 mm

C/CS-mount AZ005

Die aufgeführten Objektive sind nur eine Auswahl aus unserer

C/CS-Adaptor

1 part anderen Eigenschaften benötigen.

LENSES, M12 x 0.5 (S-Mount)

M12 x 1 (D-Mount)

Focal length

Iris aperture

MOD

IR-cut

filter

suitable for sensors up to 1/3", 1 MPix

2.1 mm 2.0

0.4 m -

3.6 mm

3.6 mm

6 mm

6 mm

12 mm

1.8

1.8

2.0

2.0

2.0

0.4 m

0.4 m

0.4 m

0.4 m

0.4 m

yes*

yes*

-

12 mm 2.0

0.4 m yes*

suitable for sensors up to 1/2", 1.3 MPix

10 mm 2.8

0.4 m yes*

suitable for sensors up to 1/3", 5 MPix

12 mm 2.8

0.1 m -

12 mm 2.8

0.1 m yes*

Lens mount

S-Mount

Angle of view 1/3“

131°00’

Part

Number

AO031-1

S-Mount 72°16’ AO061

S-Mount 72°16’ AO061-C

S-Mount 43°33’ AO055

S-Mount 43°33’ AO055-C

S-Mount 22°04’ AO056

S-Mount 22°04’ AO056-C

S-Mount 34°58’ AO054

S-Mount 28°90’ AO062

S-Mount 28°90’ AO062-C

Focal length

2.3 mm

Iris aperture

4.0

MOD

Lens mount

D-Mount 0.3 m

4.0 mm

5.6 mm

8.0 mm

12 mm

4.0

4.0

4.0

4.0

0.3 m

0.3 m

0.3 m

0.3 m

D-Mount

D-Mount

D-Mount

D-Mount

25 mm 4.0

0.3 m D-Mount

With IR Filter, suitable for use with VCAM-003-2

Angle of view 1/3“

108°00’

63°53’

46°00’

33°19’

22°04’

10°58’

We are happy to customize M12 lenses according to your specifications as part of OEM projects.

Part

Number

AO027

AO038

AO030

AO029

AO039

AO040

* IR filter is recommended when color cameras are used

Contact : Germany +49 6131 9221-32 · [email protected] · www.phytec.de | Europe · www.phytec.eu

OEM Success Story

MILESYS

milesys has outstanding know-how in three main areas: voice communication, dynamic displays, validation and maintenance of electronic complex systems. This experience is based on the application of the latest embedded electronics, software and network technologies.

Milesys has four business lines:

• Call points and displays

• Voice recorders

• Telephone systems

• Validation and maintenance tools and monitoring

Milesys products that are based on Phytec SOMs:

Emergency call intercom for public places: The products are equipped with phyCARd ® -S on

Linux basis, have a phyCAM-S camera, IP/SIP network interface and PoE+ supply.

Communications center unit: Equipped with a 3.5” display, a phyCoRE ® -i.mX27 Som on

Linux basis, IP/SIP network interface and PoE+ supply.

the Phytec SOM advantages:

milesys chose phyCARd ® -S and phyCoRE ® -i.mX27 System on modules due to their outstanding quality. milesys also develops products for defense applications and therefore the

Soms are subject to increased demands.

Phytec developed an open source and mainline Linux BSP for milesys that offers application development with mPEG4/ H264 video compression as well as decompression feature.

France · www.phytec.fr | USA · www.phytec.com | India · www.phytec.in

Embedded Imaging | 21

Headquarters | Subsidiaries

Germany

PHYTEC Messtechnik GmbH

Robert-Koch-Straße 39

D-55129 Mainz

Phone: +49 6131 9221-32

Fax: +49 6131 9221-33 www.phytec.de

www.phytec.eu

France

PHYTEC France SARL

17, place St. Etienne

F-72140 Sillé le Guillaume

Phone:+33 2 43 29 22 33

Fax: +33 2 43 29 22 34 www.phytec.fr

USA

PHYTEC America LLC

203 Parfitt Way SW, Suite G100

Bainbridge Island, WA 98110

Phone: +1 206 780-9047

Fax: +1 206 780-9135 www.phytec.com

India

PHYTEC Embedded Pvt. Ltd.

#9/1, 1st Floor, 3rd Main,

8th Block, Opp: Police station,

Kormangala, Bangalore-560095

Phone: +91 8041307589 www.phytec.in

Distributors

Australia

Embedded Logic Solutions

Pty. Ltd.

PO Box 1078

Parramatta NSW 2124

Phone: +61 2 9687 1880

Fax: +61 2 9687 1881

Email: [email protected]

Web: www.emlogic.com.au

Benelux

INDES Integrated Development

Solutions BV

Het Voorburg 7

4101 KK Culemborg

Phone: +31 345 545 535

Fax: +31 345 545 530

Email: [email protected]

Web: www.indes.com

Great Britain

HITEX (UK) Ltd.

Millburn Hill Road

University of Warwick Science Park

Coventry CV4 7HS

Phone: +44 0 2476 69 2066

Fax: +44 0 2476 69 2131

Email: [email protected]

Web: www.hitex.co.uk

Turkey

^

Uludag Görükle Kampüsü

Görükle / BURSA Turkiye

Phone: +90 (224) 280 84 90

Fax: +90 (224) 280 84 92

Email: [email protected]

Web: www.teknotasarim.com

Malaysia / Singapur

Testech Electronics Pte. Ltd.

Blk 118, # 05-110, Aljunied Ave 2

Singapore 380118

Phone: +65 674 921 62

Fax: +65 674 942 46

Email: [email protected]

Web: www.testech-elect.com

Russia

Simecs Ltd.

Detskiy Lane, 5, Office 118

St. Petersburg Russia 196084

Phone: +7-812-677-0057

Fax: +7-812-677-1853

Email: [email protected]

Web: www.microcontroller.ru

Slovakia / Czech Republic

MicroLand spol. s.r.o.

Vinohradská 77

120 00 Praha 2 - Vinohrady

Phone: +420-221490-114

Fax: +420-221490-113

Email: [email protected]

Web: www.microland.cz

Spain

Matrix Electrónica S.L.

Alejandro Sánchez 109

28019 Madrid

Phone: +34 91 560 27 37

Fax: +34 91 565 28 65

Email: [email protected]

Web: www.matrix.es

••••••••••

••••••••••

••

• • • • • • • • ••

••

• • • • • • • • ••

••

• • • • • • • • ••

•••••

•••••

•••••

• • •• ••

• • •

• •

•• •

• • •• ••

• • •

• •

••• •

• • • •

••

••

••

••• •

• • • •

• ••••

••

• • ••••

•• ••••••

•• •

• •

• • •• ••

• • •

••• •

• • • •

• ••••

••

• • ••••

•• ••••••

•••• •••••••

•••• •••••••

••

••

••

••

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
