Product & Reference Catalog
POWDER TRAINING
AND CERTIFICATION
Ramset has designed and engineered the right powder
actuated tool for your applications. To ensure you use a
powder actuated tool correctly, please take the time to
review the Operator's Safety and Operating Instruction
Manual packaged with each tool. These manuals are also
available for download on the Ramset website.
To assure safety on the jobsite, OSHA and ANSI require
that all powder actuated tool users become trained and
certified for the particular tool being used. One way
Ramset enables you to receive this training is through
our website training program. This innovative approach
to education combines interactive web-based training
techniques and online testing with immediate feedback to
provide you a rich learning environment.
The course consists of approximately 30 pages of usage,
safety and troubleshooting material.
Upon completion of this brief course you will have the
opportunity to take an online exam. Instructions for taking
these exams are provided at the end of the course.
With successful completion of the exam, you have the
opportunity to print a certification card.
As an industry leader in powder actuated fastening
systems. Ramset continues to provide the most effective
and comprehensive instructor and operator training
programs available.
Visit www.ramset.com
Tool Selection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Conduit / Cable Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Powder Fastener & Load Selection Chart . . . . . . . . . . . . . . . . . . . . . 4
Beam/Purlin
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Gas and Pneumatic Fastening Systems
T3MAG
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TrakFast
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
T3SS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
GypFast
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
GypFast Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
GypFast Air HD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Metal Stud Support
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Strut Clamps
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Rod Hangers
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Acoustical
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Low-Voltage
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Powder Fastening Systems
R25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
XT540
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SA270
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cobra
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Viper
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
D45A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
D60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
721
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MasterShot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
J-Master Tool L-1700. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
T3SS Pole Tools EPOL6 and EPOL8. . . . . . . . . . . . . . . . . . . 18
Tool Accessories (Extension Poles). . . . . . . . . . . . . . . . . . . 19
Tool Accessories (Batteries, Fuel Cells, Chargers, etc). . . . . 20
Construction and Drywall Adhesives. . . . . . . . . . . . . . . . . . . . . . . . 21
Ramset Lasers (RL510 and RL2+). . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fasteners
Gas Tool Fasteners (T3MAG, TrakFast). . . . . . . . . . . . . . . . . 23
GypFast Tool Fasteners. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Gas Tool Fasteners (T3ss). . . . . . . . . . . . . . . . . . . . . . . . . . 26
Powder Fasteners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Powder Loads
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Into To Gas Technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Harware Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Part Number Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Wood
SAMMYS for Wood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Sammy Swivelhead for Wood. . . . . . . . . . . . . . . . . . . . . . . 61
Sidewinders for Wood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Steel
SAMMYS for Steel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Sammy Swivelhead for Steel. . . . . . . . . . . . . . . . . . . . . . . 63
Sidewinders for Steel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
SAMMY XPress. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
SAMMT XPress It Installation Tool . . . . . . . . . . . . . . . . . . . 64
Concrete
SAMMYS for Concrete . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Sammy Swivelhead for Concrete. . . . . . . . . . . . . . . . . . . . 65
Swivelhead for Concrete. . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Concrete / Wood Installation Kit . . . . . . . . . . . . . . . . . . . . . 66
Approvals
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Suggested Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Fasteners – How They Work. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Toubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Performance/Submittal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
LEED Credits
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Buy American Act
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
CONCRETE ANCHORING SYSTEMS
Electrical Contractor Applications. . . . . . . . . . . . . . . . . . . . . . . . . . 70
Mechanical Contractor Applications. . . . . . . . . . . . . . . . . . . . . . . . 71
Trubolt Wedge Anchors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
LDT Anchors
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Multi-Set II Drop In Anchors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Dynabolt Sleeve Anchors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
www.ramset.com
Stud Anchors
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Redi-Drive Anchors
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Tapcon
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
EZ Ancor
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Poly-Set Anchors
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
1
Selection Guide
Tooldescriptiontypical building trade*
T3MAG
n 45-Pin Magazine
n One Step Fuel Injection & Eject
Gas Powered Tools
n Fully Automatic
n Weight: 9.2 lbs.
n Maximum Pin Length: 1"
TF1100
n Length: 17"
n 42 Pin Magazine
n Height: 15-1/2"
n Fully Automatic
n Weight: 8.375 lbs.
n 2 Year Warranty
n Maximum Pin Length: 1-1/2"
T3SS
n Single Shot Gas Tool
n One Step Fuel Injection & Eject
n 2 Year Warranty
n 150 Pin Coil
n Fully Automatic
n 2 Year Warranty
air (pneumatic systems)
n Height: 15"
n 2 Year Warranty
GYPFAST
.22 cal single shot
n Length: 18-1/2"
GYPFAST (AIR)
n 150 Pin Coil
n Fully Automatic
n 2 Year Warranty
GYPFAST (AIR HD)
n 150 Pin Coil
n Fully Automatic
n 2 Year Warranty
Walls & Ceilings
Walls & Ceilings
n Length: 13-1/2"
n Height: 15"
n Weight: 7.0 lbs.
Electrical/Mechanical
n Maximum Pin Length: 1-1/2"
n Length: 16"
n Height: 13"
n Weight: 8.9 lbs. (9.7 with nails)
Exterior sheathing
n Maximum Pin Length: 2-1/2"
n Length: 12"
n Height: 13"
n Weight: 5.5 lbs.
Exterior sheathing
And framing
n Maximum Pin Length: 2-1/2"
n Length: 13.5"
n Height: 14.5"
n Weight: 6.0 lbs.
Exterior sheathing
And framing
n Maximum Pin Length: 2-1/2"
721
n Length: 13-1/2"
n Single Shot
n Weight: 4.3 lbs.
n 3 Year Warranty
n Muzzle Bushing O.D.: 5/8"
Walls & Ceilings
n Maximum Pin Length: 1-1/2"
MasterShot
n Single Shot
n 90 Day Year Warranty
n Length: 15"
n Weight: 4.4 lbs.
n Muzzle Bushing O.D.: 3/4"
Wood framing
n Maximum Pin Length: 3"
*Building trade shown as suggestions. Tools are not limited to these trades.
2
www.ramset.com
selection Guide
.25 cal strip
Tooldescriptiontypical building trade*
R25
n Semi-Automatic
n 1 Year Warranty
n Length: 11.6'"
n Weight: 4.3 lbs.
n Muzzle Bushing O.D.: 3/4"
Walls & Ceilings
n Maximum Pin Length: 1-1/2"
.25 cal disc tools
D45A
n Automatic Piston Return
n Weight: 4.5 lbs.
n 3 Year Warranty
n Muzzle Bushing O.D.: 5/8"
n Length: 15"
n Maximum Pin Length: 2"
Walls & Ceilings
D60
n Semi-Automatic
n Length: 12-1/2"
n Power Adjustable
n Weight: 4.9 lbs.
n 3 Year Warranty
n Muzzle Bushing O.D.: 3/4"
Electrical/Mechanical
n Maximum Pin Length: 2-3/8"
(2-1/2" w/Washer)
XT540
n Automatic Piston Return
n Length: 19'"
n Power Adjust
n Weight: 5.5 lbs.
n 3 Year Warranty
n Muzzle Bushing O.D.: 7/8"
Walls & Ceilings
n Maximum Pin Length: 3"
SA270
.27 cal strip tools
n Semi-Automatic
n Power Adjust
n 3 Year Warranty
n Length: 15.3'"
n Weight: 5.45 lbs.
n Muzzle Bushing O.D.: 5/8"
Wood framing
n Maximum Pin Length: 3"
COBRA
n Semi-Automatic
n Length: 13-1/4'"
n Economical
n Weight: 4.5 lbs.
n 1 Year Warranty
n Muzzle Bushing O.D.: 9/16"
Wood framing
n Maximum Pin Length: 2-1/2"
(3" w/Washer)
VIPER
n Automatic Piston Return
n Length: 17'"
n Designed Specifically for
Overhead Applications
n Weight: 4.5 lbs.
Acoustical/overhead
n Maximum Pin Length: 1-1/2"
n 3 Year Warranty
*Building trade shown as suggestions. Tools are not limited to these trades.
www.ramset.com
3
T O T H I S B A S E M aterial
CONCRETE
FASTENER
LENGTH
(inches)
INTERIOR NON-LOAD
BEARING DRYWALL TRACK
25 - 20 GAGE
EXTERIOR PERIMETER
DRYWALL TRACK
3/4
1-1/4
GAS
TOOL
F asten T his M aterial
2 x 4 , 2 x 6 LUMBER
1/2" PLYWOOD
3/4" PLYWOOD
1 x 4, 1 x 6 WOOD
1/2" or 5/8" GYPSUM
SHEATHING
1-1/4
2-1/2
1-1/4
1-1/2
-
FASTENER
POWDER LOAD
#3 GRN .25cal STRIP
TF1100
D45A
#2 BRN .25cal DISC
T3MAG
721
#2 BRN .22cal SINGLE
N.R.
N.R.
N.R.
N.R.
N.R.
LENGTH
(inches)
R25
18 -12 GAGE
CLIPS or BRACKETS for
STEEL FRAMING
POWDER
TOOL
STEEL BEAM - 3/16" to 1/2" THICK
1/2
GAS
TOOL
POWDER
TOOL
POWDER LOAD
R25
#4 YEL .25cal STRIP
TF1100
D45A
#4 YEL .25cal DISC
T3MAG
721
#4 YEL .22cal SINGLE
SA270
#3 GRN .27cal STRIP
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
D45A
#4 YEL .25cal DISC
D45A
#4 YEL .25cal DISC
COBRA
#4 YEL .27cal STRIP
COBRA
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
D45A
#4 YEL .25cal DISC
D45A
#4 YEL .25cal DISC
COBRA
#4 YEL .27cal STRIP
COBRA
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
COBRA
#5 RED .27cal STRIP
COBRA
#5 RED .27cal STRIP
1/2
1/2
1-7/8
N.R.
N.R.
N.R.
MasterShot
#4 YEL .22cal SINGLE
MasterShot
#4 YEL .25cal DISC
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
COBRA
#4 YEL .27cal STRIP
COBRA
#4 YEL .27cal STRIP
D45A
#4 YEL .25cal DISC
D45A
#4 YEL .25cal DISC
XT540
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
COBRA
#4 YEL .27cal STRIP
COBRA
#4 YEL .27cal STRIP
D45A
#4 YEL .25cal DISC
D45A
#4 YEL .25cal DISC
XT540
#4 YEL .27cal STRIP
XT540
#4 YEL .27cal STRIP
N.R.
N.R.
1
1-1/4
-
N.R.
N.R.
N.R.
N.R.
NOTES:
1) This chart is presented as a guide only. Start with the lightest load available. If the fastener does not completely set, use the next higher load and repeat the process.
2) Product suggestions may not be suitable for all types of base materials.
3) N.R. is Not Recommended
4
www.ramset.com
POWDER FASTENER &
LOAD SELECTION CHART
CONCRETE BLOCK
FASTENER
LENGTH
(inches)
GAS
TOOL
POWDER
TOOL
R25
1
1
1
2-1/2
1-1/2
2
FASTENER
POWDER LOAD
GAS
TOOL
#3 GRN .25cal STRIP
D45A
#2 BRN .25cal DISC
T3MAG
721
#2 BRN .22cal SINGLE
T3MAG
LENGTH
(inches)
TF1100
TF1100
MORTAR JOINT (horizontal only)
1
POWDER
TOOL
FASTENER
POWDER LOAD
R25
#3 GRN .25cal STRIP
TF1100
D45A
#2 BRN .25cal DISC
T3MAG
721
#2 BRN .22cal SINGLE
SA270
#2 BRN .27cal STRIP
COBRA
#3 GRN .27cal STRIP
#3 GRN .27cal STRIP
SA270
#3 GRN .27cal STRIP
COBRA
#3 GRN .27cal STRIP
TF1100
COBRA
#3 GRN .27cal STRIP
T3MAG
D45A
#2 BRN .25cal DISC
D45A
#2 BRN .25cal DISC
R25
#3 GRN .25cal STRIP
R25
#3 GRN .25cal STRIP
SA270
#3 GRN .27cal STRIP
SA270
#3 GRN .27cal STRIP
TF1100
XT540
#3 GRN .27cal STRIP
TF1100
COBRA
#3 GRN .27cal STRIP
T3MAG
D45A
#2 BRN .25cal DISC
T3MAG
D45A
#2 BRN .25cal DISC
721
#3 GRN .22cal SINGLE
R25
#3 GRN .25cal STRIP
SA270
#4 YEL .27cal STRIP
SA270
#4 YEL .27cal STRIP
N.R.
TF1100
N.R.
XT540
#3 GRN .27cal STRIP
COBRA
#4 YEL .27cal STRIP
1
2-1/2
N.R.
LENGTH
(inches)
SA270
1
LIGHT GAGE STEEL 18-12gage
XT540
#3 GRN .27cal STRIP
COBRA
#4 YEL .27cal STRIP
GAS
TOOL
-
N.R.
N.R.
-
N.R.
N.R.
-
N.R.
N.R.
-
N.R.
N.R.
MasterShot
#4 YEL .22cal SINGLE
MasterShot
#4 YEL .22cal SINGLE
SA270
#3 GRN .27cal STRIP
SA270
#3 GRN .27cal STRIP
COBRA
#3 GRN .27cal STRIP
COBRA
#3 GRN .27cal STRIP
D45A
#3 GRN .25cal DISC
D45A
#3 GRN .25cal DISC
MasterShot
#3 GRN .22cal SINGLE
MasterShot
#3 GRN .22cal SINGLE
SA270
#3 GRN .27cal STRIP
SA270
#3 GRN .27cal STRIP
TF1100
COBRA
#3 GRN .27cal STRIP
COBRA
#3 GRN .27cal STRIP
GYPFAST
D45A
#3 GRN .25cal DISC
D45A
#3 GRN .25cal DISC
XT540
#4 YEL .27cal STRIP
MasterShot
#3 GRN .22cal SINGLE
1-1/2
2
TF1100
N.R.
POWDER POWDER
LOAD
TOOL
TF1100
1-1/2
GYPFAST
GYPFAST AIR
N.R.
AIR HD (for 12G)
1-1/2
GYPFAST AIR
N.R.
AIR HD (for 12G)
GYPFAST
-
N.R.
N.R.
-
N.R.
N.R.
1-1/2
GYPFAST AIR
N.R.
GYP AIR HD (for 12g)
www.ramset.com
5
GAS TECHNOLOGY
T3MAG
• Gas Technology
• 2 Year Warranty
• Weight: 9.2 lbs.
• 45-Pin Magazine
• Length: 18-1/2"
• Pin Guide O.D.: .590
• One Step Fuel Injection
• Height: 15"
• Maximum Pin Length: 1"
ADVANTAGES
• Higher stick rate
• Fitted dust shield
• 25% more power
• Battery charger provides constant
charging even with low voltage drops
• Easy push down force
• Deep leg track capacity
• 45-pin magazine capability
• 2 Year Warranty
(6 months on wearable parts)
• No License Required
FEATURES
T3MAG Increase Your Range with
Overhead Power
Fuel cell and battery
The Power of the T3MAG allows you to
consistently shoot where no other gas tool has
gone before. The .125 diameter pin is specifically
engineered to work in the toughest concrete and
steel where other pins cannot perform. The new
T3MAG system delivers power that rivals other
gas and powder systems.
T3 fuel cell
Part No. T3FUEL
Replaces conventional
powder loads and drives
more than 1000 pins
Most common fasteners
PIN #
DESCRIPTION
T3012
T3012S
T3034B
T3034S
T3100
1/2" steel pin with T3 fuel cell
1/2" premium steel pin with fuel cell
3/4" concrete pin with T3 fuel cell
3/4" step shank pin with T3 fuel cell
1" concrete pin with T3 fuel cell
Fuel injection means
no additional steps of
preparing a fuel cell.
Click the fuel cell in place
and the tool is ready to go.
Fasteners on page 23.
Easy battery loading. Battery rest
position allows you to turn off the
tool without fully removing the
battery.
Settling aggregate is
the biggest reason for
overhead pin failure.
With the T3’s 1/2 steel pin
you can even shoot into the
web of steel.
Part No. B0092
The 6-volt Ni-Cd battery can drive more
than 3000 shots per charge
APPLICATIONS
The T3 has enough power to fasten into hard concrete and steel and
still will not blow through hollow block.
6
Will not spall hollow block like powder
actuated.
Perfect for hat channel applications.
www.ramset.com
GAS TECHNOLOGY
TRAKFAST TF1100
• Gas Technology
• Length: 17"
• Maximum cycles/second: 2
• Fully Automatic
• Height: 15-1/2"
• Fuel cell: 1000 shots
• 1-1/2" Pin Capacity
• Weight: 8.375 lbs.
• 42 Pin Magazine Capacity
• Maximum Capacity:
42 pins
• Battery (charged):
3000 shots
ADVANTAGES
• SPEED: Three to five times faster than
powder tools. 42-pin magazine reduces
load time.
• NO CHANGING LOADS: TrakFast uses a
fuel cell, not a load. No need to inventory
different colored loads
• EASY TO USE: Tool automatically resets
piston. No recoil, tool absorbs shock
resulting in less operator fatigue.
• NARROW
NOSE & PROFILE: Allows tool
to reach inside deep leg track (1-5/8"
wide x 2" high).
• NO LICENSING REQUIRED: Unlike powderactuated tools, no licensing is required.
• 2 Year Warranty (6 months on wearable
parts).
FEATURES
Still the most revolutionary fastening system in the
construction industry!
Since its introduction in 1991, TrakFast has been the tool of choice for both interior and
exterior contractors. The TrakFast Automatic Fastening System fastens all types of track,
from standard track to hat channel, deep leg, Z, and J channel. Contractors continue to
report tremendous savings when using TrakFast for high production fastening. They have
learned that TrakFast’s actual cost in place beats all other systems. The increased speed
and productivity of TrakFast allows the contractor to bid more competitively, complete the
job sooner and move on to the next job. Anyone can use TrakFast—just load the pins and
fire. It’s that easy!
TrakFast’s power comes from
the battery and fuel cell
TrakFast ICC ESR-2579 is the only approval that
allows you to fasten into any location on a hollow
block wall and won’t blow away block like a
powder tool.
Most common fasteners
PIN #
FPP012S
FPP034B
Pin length
in.
(MM)
1/2
3/4
12.7
19.1
The 6-volt rechargeable Ni-CD battery
can drive approximately 3000 shots
per charge. The clean burning fuel cell
can drive over 1000 pins and keeps
the tool cleaner than powder
actuated tools.
Fastening System Productivity
In the time it takes you
to drive two pins with
a powder tool, you can
drive up to 10 pins
with TrakFast!
Most common
application
Track to steel
Track to concrete
Fasteners on page 23.
APPLICATIONS
Track to steel
www.ramset.com
Lath attachment—using
one-inch TrakFast discs and
magnetic probe adapter
Furring attachment—perfect
fastening every time in soft
and hard base materials
Plywood attachment—
using TrakFast plywood to
steel pin
Track to concrete
7
GAS TECHNOLOGY
T3SS
• 2 Year Warranty
(6 months on wearable
parts)
• Gas Technology
• Single Pin Gas Tool
• Fuel Injection
• Cross Over Technology
• Length:13-1/2"
• Height: 15"
• Weight: 7.0 lbs.
• Pin Guide O.D.: 1/2"
Standard, 7/8" Magnetic
• Maximum Pin Length:
1-1/2"
ADVANTAGES
• Sets the standard for single-shot
applications
• 5 times faster than traditional drill and
anchor methods
• Replaces the need for tools like the DX35
• Reduced installation costs—up to 75%
• Quiet enough to work in tenant occupied
buildings
• Removable rear foot
• Interchange nose
• Reduced operator fatigue
VERSATILE, fastens to solid concrete,
hollow block, pan deck and steel.
FEATURES
Crossing over from powder to gas
Ramset is serious when it comes to driving job speed by
creating the T3SS—the single shot tool that will help move
contractors from powder to gas.
The T3SS provides the benefits of shooting a gas tool,
including reduced installation time and operator fatigue for
the contractor who normally shoots a muzzle loaded
powder tool.
No more fines for unspent loads
on the jobsite.
To make the T3SS the most versatile gas tool in the industry,
Users can change out nosepieces to accommodate any fastening need. From metal-to-concrete, hard
concrete or steel, pan deck, block and just about surface you can think of the T3SS works for you.
APPLICATIONS
Fastener and magnetic nosepiece
Fuel cell and battery
T3 fuel cell
Part No. T3FUEL
The optional interchangeable nosepiece (Part Number
M150200) is able to shoot a variety of M series fasteners.
12HSMP034 clip assembly
used to secure conduit
M034 fastener used to hang
HVAC Duct Strap
Pole tool
Fuel injection means
no additional steps of preparing
a fuel cell. Click the fuel cell in
place and the tool is ready to go.
Part Nos. EPOL6 and EPOL8
Part No. B0092
M100 fastener used
to attach a junction
box
Most common fasteners
Easy battery loading.
Battery rest position
allows you to turn off
the tool without fully
removing the battery.
8
Replaces conventional powder
loads and drives more than
1000 pins
PIN #
Description
12HSMP034
MP034TH
M100
14THRHMP034
1/2" One hole strap with 3/4" pin
3/4" Plated pin with top hat
1" Pin with gold domed washer
1/4" Threaded rod hanger
The 6-volt Ni-Cd battery can drive
more than 3000 shots per charge
Fasteners on page 26.
www.ramset.com
GAS TECHNOLOGY
GYPFAST
• Part No.: GYPFAST
• Height: 13"
• Diameter: .140" Nominal
• Fully Automatic
• Weight: 8.9 lbs.
(9.7 with nails)
• Head Style:5/16" dia.
bugle head
• Lengths: 1", 1-1/2", 2"
and 2-1/2"
• Finish: Climacoat Long Life
Polymer
• 2-1/2" Pin Capacity
• Length: 16"
ADVANTAGES
• Exterior Gypsum sheathing to steel framing
• Exterior walls
• Plywood and OSB sheathing/flooring
• Windows/door bucks
• Fiber cement panel attachment
• Specialty exterior sheathing attachment
• Blocking
• Woven wire mesh or expanded metal lath
to steel framing
FEATURES
• Fully automatic system with 150 nail
capacity is 3-5 times faster than screwing.
• Fast set-up and tear down – insert battery,
fuel cell and nail coil – eliminates need for
extension cord, hoses and compressors.
• Aggressive, patented nail shank design
provides high pullout performance.
Fully Automatic Cordless Gas Fastening
System for Attaching Exterior Sheathing to
Light Gauge Steel Framing
Fuel cell
Part No. TFUEL
Battery
Part No. 405176
• Woven wire mesh or expanded metal lath
to steel framing
• 2 year warranty
• Contoured bugle head style provides high
pullover (wind) resistance.
Fasteners on page 25.
Most common fasteners
PIN #
Magnetic Nose Probe
Part No. 2761910
• Long life Climacoat™ finish is 10 times
more corrosion resistant than electro-zinc
plating.
.140" dia. knurled shank
5/16" dia. bugle head
Master carton
Application
in.
(MM)
GF100
1
25.4
4,800 nails/ctn (48 - 100
Metal to Metal Attachment
ct. coils) 5 fuel cells
GF112
1-1/2
38.1
6,000 nails/ctn (40- 150 Single Layer of Exterior Sheathing, Wood
ct. coils) 6 fuel cells Furring and Blocking
GF200
2
50.8
4,800 nails/ctn (32 - 150 Double Layer of Exterior Gypsum
ct. coils) 5 fuel cells Sheathing, Wood Furring and Blocking
GF212
2-1/2
63.5
2,700 nails/ctn (18 - 150 Multi-Layers of Sheathing, Wood Blockct. coils) 3 fuel cells ing, and Dimensional Lumber
APPLICATIONS
Plated 1" Lathing Disc
Part No. LD100
Plated 1-1/4" Lathing
Disc Part No. LD114
Exterior Gypsum sheathing to steel framing, Plywood and OSB sheathing/flooring, Fiber cement
panel attachment, Blocking Exterior walls, Windows/door bucks, Specialty exterior sheathing
attachment, Woven wire mesh or expanded metal lath to steel framing.
OSB and plywood to iSPAN joists
www.ramset.com
9
AIR TOOLS
GYPFAST AIR
• Part No.: GYPFASTAIR
• Weight: 5.5 lbs.
• Fully Automatic
• Lengths: 1", 1-1/2", 2"
and 2-1/2"
• 2-1/2" Pin Capacity
• Length: 12"
• Diameter .140’’ Nominal
• Head Style 5/16" dia.
bugle head
• Finish: Climacoat Long
Life Polymer
• Height: 13"
ADVANTAGES
• High performance pneumatic fastening
system is 3-5 times faster than screws.
• Aggressive, patented nail shank design
provides high pullout performance.
• 150 nails in a coil reduces reloading –
improves productivity.
• Works with the Magnetic Probe (part
number 2731910) for lathing discs
LD100 & LD114
• Collation provides smooth, consistent
operation with no flagging or breakage.
• Switch from sequential to bump fire.
GYPFAST AIR HD
• Part No.: GYPFASTAIRHD
• Weight: 6 lbs
• Fully Automatic
• Lengths: 1", 1-1/2", 2" and 2-1/2"
• 2-1/2" Pin Capacity
• Diameter .140" Nominal
• Length: 13.5"
• Head Style 5/16" dia. bugle head
• Height: 14.5"
• Finish: Climacoat Long Life Polymer
ADVANTAGES
• High performance pneumatic fastening
system is 3-5 times faster than screws.
• 150 nails in a coil reduces reloading –
improves productivity.
• Switch from sequential to bump fire.
• Aggressive, patented nail shank design
provides high pullout performance.
• Works with 12 gauge studs
• Collation provides smooth, consistent
operation with no flagging or breakage.
Applications
Exterior Gypsum sheathing to steel framing (20-14 gauge), Plywood and OSB sheathing/flooring, Wood furring to steel
framing, Fiber cement panels to steel framing, Woven wire mesh or expanded metal lath to steel framing
OSB and plywood to iSPAN joists
Fasteners on page 25.
10
www.ramset.com
Powder fastening
Over a half century of leadership in powder actuated tools and fasteners
The first powder actuated tools (PATs) were used for repairing damaged ship
hulls during World War I. This application continued through World War II, when
the son of the original inventor, Stanley Temple, developed and implemented the
technology for commercial use. In 1947, the "Tempotool" was introduced to the
construction industry.
To ensure safety on the jobsite, OSHA and ANSI require that all PAT users become
trained and certified for the particular tool being used. One way Ramset enables
you to receive this training is through our website training program. This innovative
approach to education combines interactive web-based training techniques and
online testing with immediate feedback to provide you a rich learning environment.
Ramset Fasteners was founded in 1948 to handle distribution and sales for
the construction trades. In 1949, Ramset’s accredited Operator Program was
officially launched. Today this highly successful training program has instructed
over 1,000,000 trades people in the safe use of PATs.
The course consists of approximately 30 pages of usage, safety and troubleshooting
material.
Online Powder Training and Certification
As an industry leader in powder actuated fastening systems, Ramset
continues to provide the most effective and comprehensive instructor and
operator training programs available.
Only properly trained and licensed operators are described in ANSI Standard A
10.3 and/or local regulations may operate powder actuated tools. ITW Ramset
distributors offer complete training programs for end users. Contact your local
Ramset distributor for complete details.
Ramset has designed and engineered the right powder actuated tool (PAT)
for your applications. To ensure you use a PAT correctly, please take the time
to review the Operator’s Safety and Operating Instruction Manual packaged
with each tool. These manuals are also available for download on the
Ramset website.
Upon completion of this brief course you can take an online exam. With
successful completion of the exam, you can print a certification card.
Today, Ramset continues to bring the industry the products, service and
innovation that they have come to expect from the leader in powder fastening.
All geared to help contractors do their job faster, more safely and more
productively.
www.ramset.com
R25
• .25 Caliber Strip Tool
• Length: 11.6"
• Semi-Automatic
• Maximum Pin Length: 1-1/2"
• .25 Caliber Strip Loads:
3 (Green), 4 (Yellow), 5 (Red)
• 1 Year Warranty
• Weight: 4.3 lbs.
ADVANTAGES
• Rugged metal housing
• Popular drywall track tool
• Rubber cushion grip
• 1 Year Warranty
Most common fasteners
PIN #
1506B
SP58TH
Shank Length
IN.
(MM)
3/4
5/8
19.0
15.9
Most common application
Track to concrete
Track to steel
Fasteners on pages 29 and 30.
COMMON REPLACEMENT PARTS
www.ramset.com
• SC325207A Piston Assembly
• SC306010 Fastener Guide
• SC301011A Shear Clip (Pkg of 3)
• SC326009 Front Barrel/Baseplate
11
.27 caliber strip TOOLS
XT540
The most powerful tool in its class
The Ramset XT540 was specifically designed for the commercial framer for heavy-duty interior
& exterior applications. The XT540's combination of high power and durability make it perfect for
these applications:
• Driving 1-1/4” embedment for perimeter track
• Fastening track & clips to structural steel
• Track to hard concrete
• Excellent compliment to your Ramset TrakFast program
Features
• Length: 19"
• .27 Caliber Strip Tool
• 3 Year Warranty
• Automatic Piston Return
• Muzzle Bushing O.D.: 7/8"
• .27 Caliber Strip Loads:
3 (Green), 4 (Yellow), 5 (Red)
• Power Adjust
• Weight: 5.5 lbs.
• 3" Pin Capacity
ADVANTAGES
Durable, Reliable, Powerful, Automatic
• Very Powerful
• Trigger lock & hand guard to increase safety
• Spring return front end—
no manual resetting of the piston
• Low recoil
• Ergonomically balanced
• Power adjust—dial down 2 full load levels
• Rugged soft grip handle
• Works with Magnetic Muzzle (Part# 100227)
& Lathing Discs
Most common fasteners
PIN #
SP58TH
SP34
M100BB
SP114
Shank Length
IN.
(MM)
5/8
3/4
1
1-1/4
15.9
19.1
25.4
31.8
Most common application
Track to steel
Track to concrete
Track to concrete
Track to concrete
Fasteners on pages 28 and 30.
COMMON REPLACEMENT PARTS
• PA37037 Piston
12
• 100167 Piston Return Spring
www.ramset.com
.27 caliber strip TOOLS
SA270
• .27 Caliber Strip Tool
• .27 caliber 10-shot strip
loads: 3 (Green),
4 (Yellow), 5 (Red)
• Semi-Automatic
• Power Adjust
• Weight: 5.45 lbs.
• Muzzle Bushing O.D.: 5/8"
• Maximum Pin Length:
3" straight pin
• 3 Year Warranty
• Length: 15.3"
ADVANTAGES
• Very Powerful
• Twist lock front end—easy to clean
• Excellent balance—easy to use all day long
• Rugged polyamide housing—reduces heat
transfer and maximizes operator comfort
• Rubber grip on front barrel—
eliminates pinched fingers and hands
• Soft, recoil-absorbing handle—
for increased operator comfort
Most common fasteners
Shank Length
IN.
(MM)
PIN #
1516SDC (washered)
1524SDP(washered)
SP58TH
2-1/2
3
5/8
63.5
76.2
15.9
Most common application
2" x 4" to concrete
2" x 4" to concrete
Track to steel
Fasteners on pages 29 and 30.
COMMON REPLACEMENT PARTS
• 27833 Piston with Ring
Cobra
• Length: 13-1/4"
• .27 caliber 10-shot strip
loads: 3 (Green), 4 (Yellow),
• Muzzle Bushing O.D.: 9/16"
5 (Red)
• Maximum Pin Length:
• Weight: 4.5 lbs.
2-1/2" (3" w/washer)
• .27 Caliber Strip Tool
• Semi-Automatic
• Economical
ADVANTAGES
• Fastens up to 3" standard Ramset drive
pins and threaded studs—ideal for
general construction applications
• Semi-automatic .27-caliber tool —
uses strip loads
• Padded recoil-absorbing handle—
for greater operator comfort
• Full one-year warranty
Most common fasteners
PIN #
1524SDP (washered)
1524SDC (washered)
1506B
Shank Length
IN.
(MM)
3
2-1/2
3/4
76.2
63.5
19.1
Most common application
2" x 4" concrete
2" x 4" concrete
Drywall track to concrete
Fasteners on page 29.
COMMON REPLACEMENT PARTS
• SC301200A Piston and Ring
www.ramset.com
• SC301012 Pawl (stop)
13
.27 caliber strip TOOLS
Viper
• Weight: 4.5 lbs.
• .27 Caliber Strip Tool
• 3 Year Warranty
• Semi-Automatic
• Length: 17"
• .27 caliber 10-shot strip
loads: 3 (Green), 4 (Yellow),
• Maximum Pin Length:
5 (Red)
1-1/2"
• Designed Specifically for
Overhead Applications
ADVANTAGES
• Automatic load advance: Load is advanced
consistently each time the Viper is fired.
• Simplified Barrel Retention Collar: No tools
are required for assembly or disassembly.
• Automatic Piston return: No time spent
manually resetting or cycling the tool. Allows
you to work faster.
• Stable Steel Collar: The Viper screws
securely into the end of the extension
pole with the steel collar ensuring a more
durable and rigid connection.
• Overdrive Protection: Heavy duty buffer
system prevents front end damage caused
by piston overdrive —especially through
sprayed-on insulation.
• Uses existing Viper pole system: Works with
the existing family of durable Ramset poles.
• Open Front-end design: Completely
redesigned open-ended muzzle keeps your
tool cleaner longer.
FASTENERS
• electrical pin/clip assemblies
Preassembled Pin & Clips for some of the most
common electrical applications increase jobsite speed
for the electrician.
Extension poles
Fixed Length
Length
Part #
6'
8'
VPOL6
VPOL8
Most common fasteners
Shank Length
in.
(MM)
PIN #
14TRHSS10
SDC125
SPC114
1
1-1/4
1-1/4
25.4
31.8
31.8
Most common
application
Threaded Rod Hanger
Ceiling Clip
Ceiling Clip
Fasteners on pages 28 and 31.
• standard pin/clip assemblies
SDC Fasteners are designed with special dimples on
the angle clips which act as a shim and assure a snug
fit between the structural member and the clip.
• PowerPoint® Pin/clip assemblies
SPC Fasteners are assembled with the patented
technology of PowerPoint pins for penetration in hard
concrete and steel. The uniform shape and finish of the
engineered tip results in more consistent performance
in your toughest situations.
telescoping
The Viper was engineered
specifically for overhead
applications.
(adjustable in 1' increments)
Length
Part #
6'-12'
6’-18'
TVPOL612
TVPOL618
COMMON REPLACEMENT PARTS
• MVP500AP Advance Lever Assembly
• MVP140 Piston
extend
you
reachr
14
The Viper screws solidly
onto a pole for high reach
and secure operation for
ceiling applications.
www.ramset.com
.25 caliber disc TOOLS
D45A
• Muzzle Bushing O.D.: 5/8"
• .25 caliber 10-shot disc
loads: 2 (Brown), 3 (Green),
• Maximum Pin Length:
4 (Yellow), 5 (Red)
2" (2-1/2" w/washer)
• Weight: 4.5 lbs.
• 3 Year Warranty
• Length: 15"
• .25 Caliber Disc Tool
• Semi-Automatic
• Automatic Piston Return
ADVANTAGES
• Most durable, powerful powder tool—
designed for high production use in
steel and concrete
• Heavy-duty buffer system—prevents
front-end tool damage for longer tool life
• 33% faster than semi-automatic tools—
saves time and labor costs
• Ramset Disc Technology—loads only
advance after firing—eliminates 10-20%
of load waste
Most common fasteners
3/8" Muzzle Bushing
available for limited
applications
Part Number
32330038M
Shank Length
IN.
(MM)
PIN #
SP58TH
SP12
1506B
5/8
1/2
3/4
Most common application
15.9
12.7
19.1
Track to steel
Track to hard steel
Track to concrete
Fasteners on pages 29 and 30.
COMMON REPLACEMENT PARTS
• 323110 Muzzle Bushing Shroud
• 30645 Piston
D60
• Muzzle Bushing O.D.: 3/4"
• .25 caliber 10-shot disc
loads: 2 (Brown), 3 (Green),
• Maximum Pin Length:
4 (Yellow)
2-3/8" (2-1/2" w/washer)
• Weight: 4.9 lbs.
• .25 Caliber Disc Tool
• Semi-Automatic
• Power Adjustable
• 3 Year Warranty
• Length: 12-1/2"
ADVANTAGES
• Quick power adjustment—gives eight
levels of power with only one load level
for a variety of applications
• Rugged polyamide housing—reduces
heat transfer and maximizes operator
comfort
• Soft, recoil-absorbing handle—for
increased operator comfort
• Ramset Disc Technology—loads only
advance after firing—eliminates 10-20%
of load waste
Most common fasteners
PIN #
Shank Length
IN.
(MM)
M100BB
1643W
1
1
25.4
25.4
Thread Length
IN.
MM
3/4
19.1
Most common application
Sheet metal to concrete
Electrical box to concrete
Fasteners on pages 28 and 30.
COMMON REPLACEMENT PARTS
• 30691 Piston
www.ramset.com
• 135220 Pawl Assmebly
15
.22 caliber single shot
721
• Length: 13-1/2"
• .22 Caliber Single Shot Tool • .22 caliber, single-shot
loads: 2 (Brown), 3 (Green),
• Muzzle Bushing O.D.: 5/8"
• Single Shot
4 (Yellow)
• Maximum Pin Length:
• 3 Year Warranty
• Weight: 4.3 lbs.
1-1/2"
ADVANTAGES
• Rugged metal housing—holds up for years
• Low recoil—reduces operator fatigue on
large jobs
• Simple to clean—saves on labor costs
• Rubber cushion grip—for maximum
operator comfort
• Only two moving parts to clean—easy
maintenance; saves time
• Narrow 5/8" muzzle bushing—for easy
access in tight fastening areas
• Automatic cartridge ejection system—
increases operator speed and productivity
Most common fasteners
PIN #
1506B
M100BB
SP58TH
Shank Length
IN.
(MM)
3/4
1
5/8
Most common application
19.1
25.4
15.9
Track to concrete
Track to concrete
Track to steel
Fasteners on pages 28-30.
common replacement parts
• 33657 Piston Ring Assembly
• 12258 Barrel Extension
MASTERSHOT
• .22 Single Shot Tool
• Trigger Operated Powder
Actuate Tool
• 90 Day Warranty
• Uses standard .22 caliber
single shot powder loads:
2 (Brown), 3 (Green),
4 (Yellow)
• Length: 15"
• Muzzle Bushing O.D.: 3/4"
• Maximum Pin Length: 3"
• Weight: 4.4 lbs.
ADVANTAGES
• Designed for frequent use providing
professional fastening results in a
variety of concrete, masonry or steel
applications
• The MasterShot is a traditional trigger
operated tool
• Positive barrel and load retention prevents
barrel from opening freely, allowing easy
horizontal and overhead fastening
• Powder load automatically ejects after
each use
• Heavy-duty construction
• Ergonomic design for operator comfort
Most common fasteners
PIN #
1524SDP (washered)
1516SDC (washered)
1506B
Shank Length
IN.
(MM)
3
2-1/2
3/4
76.2
63.5
19.1
Most common application
2" x 4" to concrete
2" x 4" to concrete
Drywall to concrete
Fasteners on page 29.
2" x 4" to concrete slab
16
Track to floor
www.ramset.com
J-Master tool
J-Master Tool L-1700
• For Attachment of Hanger Wire Clips
J-Clip® (L1701) and Clip-Pur® (L1801)
• A Non-Powder Alternative
• 19 gauge clip
ADVANTAGES
• For strong, reliable attachment of hanger
wire from open web bar joists or purlins
• Fast, easy installation from floor level
• No ladders or scaffolding necessary
• Threads easily into any 1/2" threaded pipe
• No hammering, punching holes or
wrapping wire
• Two magnetized strips included for
use in attachment of Clip-Pur (L1801)
clips for use with the j-master® tool
Threads easily into any
1/2" threaded pipe
J-clip (l1701)
Clip-pur (l1801)
252 lb. Allowance working load
(4:1 safety factor)
217 lb. Allowable working load
(4:1 safety factor)
• Strong, reliable attachment
of pre-tied hanger wire
• Fast, easy attachment of pre-tied
hanger wire from Z-Purlins
• Use for open web bar
joists or purlins
• Disengages from J-Master tool
after installation
• Each clip fits 1/16"-1/4"
flanges
Easy installation
Easy installation
1. Attach a 1/2" pipe extension (dielectric
pole available) to the threaded end of a
J-Master tool, and place pre-wired J-Clip
into tool.
1. Attach J-Master tool to end of threaded 1/2"
pipe or dielectric pole. Lay pre-tied Clip-Pur
against magnetized strips.
2. Attach a 1/2" pipe extension (dielectric
pole available) to the threaded end of a
J-Master tool, and place pre-wired J-Clip
into tool.
2. Raise the Clip-Pur up to the purlin. Position the
clip on the 45° flange and give a downward tug,
the clip is now in position.
3. Disengage the tool by lifting up and out.
Spring Steel Fasteners
J-Clip attached to the J-Master Tool
Clip-Pur attached to the J-Master Tool
Ask about our
Black Claw Spring Steel Clips
www.ramset.com
17
t3ss pole tool
EPOL6 / EPOL8 t3ss 6' AND 8" pole tools
ADVANTAGES
• Easy to operate: Comfortable “motorcycle"
grip replaces handbrake mechanisms
• No hose clamps required: Simple to
assemble
• Sturdy design: 25% thicker than similar
poles for greater support
• Also fits Ramset R150 tools
• Pole weight: 5lbs
Extend Your Reach!
New ergonomic design balances the tool directly over the pole for a lightweight feel
easy to assemble
EPOL6: 6 foot long
EPOL8: 8 foot long
Log on to www.ramset.com for a video on attaching the pole tool to the T3SS
common replacement parts
• 10-24SHCS Screw Package for T3
• T3SPACER Spacer (pkg 4)
• T3TRIGACT Trigger Activator Rod
18
www.ramset.com
Tool accessories
Extension Poles
ADVANTAGES
• Eliminates scaffolding or ladders
• Top-quality hand lever
• Uses existing powder tools
• Lightweight cast aluminum housing fits
tool snugly and provides tool protection
• Rubber "motorcycle" grip for operator
comfort and to reduce recoil level
• Delrin™ coupler on cable makes pole
di-electric
• Trigger bar adjusts easily for individual
tools
• Nyloc™ nuts keep your adjustment fixed
solidly on the trigger bar
Poles for ramset and Hilti® tools
Length
Part #
6'
8'
PTSEMI6
PTSEMI8
fits: Ramset D60, SA270, D45A, Rocket, Cobra, HILTI DX36
Hilti® is a registered trademark of Hilti, Corp.
Ramset Pole
Tools are an
excellent choice
for high-reach
fastening
applications.
Poles for ramset viper
Fixed Length
Length
Part #
6'
8'
VPOL6
VPOL8
telescoping
(adjustable in 1' increments)
Length
Part #
6'-12'
6'-18'
TVPOL612
TVPOL618
6'–12' or 6'–18' Telescoping Extension Pole
Fast, easy
installation
from floor level
eliminates
lift baskets,
scaffolds and
ladders.
www.ramset.com
19
Tool accessories
Tool Cleaning Kit
n Wood Handle Wire Brush
n Round Wire Brushes:
Small, medium, large
n Package of 10 Scrubs:
Hand and tool cleaners
Part No. PATCK
Part No. TFUEL
Fuel Cell–TrakFast
Qty: 12
Part No. 7505012
Battery–TF1100
Qty: 1
Part No. RFUEL
Fuel Cell–T2, R150, E150 & M150
Qty: 12 (6–2 packs)
Part No. B0092
Battery–T3SS & T3MAG
Qty: 1
Part No. 7505142
Battery Charger–T2 & R150, E150 & M150
Qty: 1
Part No. 100018
Disc Holding Probe
(for TF1100 One Piece Nose)
Qty: 1
20
Cleaning Kit
Qty: 1
Part No. T3FUEL
Fuel Cell–T3SS & T3MAG
Qty: 12 (6–2 packs)
Part No. 334000
Battery–T2 & R150, E150 & M150
Qty: 1
Part No. LD100
Plated 1" Lathing Disc 22g
Qty: 1,000 per box
Works with all magnetic probes
Part No. 7405173
Disc Holding Probe
(for TF1100 Telescoping Nose)
Qty: 1
Part No. M150200
Magnetic nose Piece
(for R150 and T3SS)
Qty: 1
Part No. 405176
Battery–GYPFAST
Qty: 1
Part No. LD114
Plated 1-1/4" Lathing Disc
(GYPFAST)
Qty: 1,000 per box
Part No. B0237
Disc Probe
(T3MAG)
Qty: 1
Part No. B0022
Battery Charger–TF1100, T3SS & T3MAG
Qty: 1
Part No. 100227
Magnetic Muzzle for XT540
Qty: 1
Part No. 2761910
Gas Mag Probe
(GYPFAST)
Qty: 1
Part No. 2731910
Gyp Air Probe
(GYPFAST)
Qty: 1
www.ramset.com
Construction adhesives
SC200 Sound Control Sealant
ADVANTAGES
• Designed to seal drywall gaps and reduce
sound transmission in STC rated walls
• Water-based for easy clean up, won’t
compromise fire-rated walls
• Non-flammable and paintable
• Increases sound absorption up to 128%
• Works on all partition gaps including: top
track, around outlets and bottom track
Suggested specifications
• Meets ASTM E84, ASTM C919, ASTM E90
UL report R25562
• Optimal 0/0 rating for flame spread/smoke
developed (UL classified)
• 28 oz tube/12 tubes per carton
• Meets requirements for LEED EQ Credit 4.1
• Ultra Low VOC Contents 24g/L
DA100 Drywall Adhesive
ADVANTAGES
• Designed to bond gypsum board to wood
or steel studs
• Hides framing defects up to 3/8"
• 28 oz. tube/12 tubes per carton
• Reduces nail pops
• Up to 66% fewer fasteners required
* DA100 NOT FOR SALE IN AREAS WITH HEAVY VOC RESTRICTIONS
www.ramset.com
21
Lasers
RL510 Rotating Laser
• Fully automatic rotating laser that can be used for leveling, vertical alignment, plumbing and
squaring.
APPLICATIONS
• Installing suspended ceilings
• Soffits
• Stud & track layout
• Variety of interior alignment tasks
Features
RL510 Interior Kit
includes, rotating
laser, integrated
motorized wall
• Automatic self leveling • Easy field calibration
mount, rechargeable
in both horizontal and • 1 year warranty
and alkaline battery
vertical modes
packs remote control, target card, laser
enhancing glasses, and impact esistant
• Manual leveling mode for
carrying case.
slopes or inclined planes
• Integrated motorized
wall mount adjustable
by remote control
• Choice of beams:
rotating, scanning,
chalk line
RL2+ Cross/Plumb Laser
APPLICATIONS
WALLS & CEILINGS
• Soffits
• Drywall track layout
• Trim, windows and door frames
• Suspended ceilings
ELECTRICAL
• Leveling of cable tray
• Plumb Points for
coring and overhead
lighting positioning
• Outlets
• Setting rack points
Features
• Cross line and plumb points all in one easy
to use laser
• Locking mechanism (pendulum lock)
increases the durability and preserves
calibration
• Locked line mode allows for more complicated
layouts; i.e., sloped areas, tile patterns
• Audible out-of-level alert
• Rugged rubber housing protects precision
laser components
• Built in 1⁄4-20 thread for tripod
• 2 year warranty
RL3 3 POINT Laser
APPLICATIONS
WALLS & CEILINGS
• Drywall track layout
• Trim, windows and door frames
ELECTRICAL
• Plumb points for coring and positioning
lighting
Features
• Locking mechanism (pendulum lock)
increases the durability and preserves
calibration
• Audible out-of-level alert
• Built in 1⁄4-20 thread for tripod
• Rugged rubber housing protects precision
laser components
• Third beam can be turned off to increase
battery life
• 2 year warranty
REVOLUTIONARY UNIVERSAL STAND
• Integrated laser stand works on studs and floor (patent pending)
• Magnetic: Powerful magnets easily secures to steel stud,
even 25 gauge dimpled stud
22
• Stand height provides easy visual access to chalk lines or plumb point
• Works with 2" deep leg track
• Stand can bump the track to allow for plumb point alignment
www.ramset.com
GAS TOOL FASTENERS
Ramset Collated Gas Tool Fasteners are specifically engineered for optimal
performance in Ramset Gas Power Tools using fastener magazines.
Selection chart
T3mag fuel/pin pack
1000 PINS AND 1 FUEL CELL PER BOX Larger .125 shank diameter offers improved success rate (15 pin strip)
PART NUMBER
T3012
T3012S
T3034B
T3034S*
T3100
Shank diameter = .125
Head diameter = .250
PIN LENGTH
IN.
(MM)
1/2
1/2
3/4
3/4
1
(12.7)
(12.7)
(19.1)
(19.1)
(25.4)
DESCRIPTION
1/2" steel pin with T3 fuel cell
1/2" premium steel pin with T3 fuel cell
3/4" concrete pin with T3 fuel cell
3/4" step shank pin with T3 fuel cell
1" concrete pin with T3 fuel cell
*Shank diameter= .104/.125
TrakFast standard
fuel/pin pack
1000 PINS AND 1 FUEL CELL PER BOX For high volume, repetitive fastenings to concrete and steel such as drywall track to concrete
PART NUMBER
PIN LENGTH
IN.
(MM)
DESCRIPTION
FPP012
1/2
(12.7)
1/2" Plated steel pin
FPP012S*
1/2
(12.7)
1/2" Premium Plated step shank pin
FPP034B
3/4
(19.1)
3/4" Black pin
FPP034S*
3/4
(19.1)
3/4" Premium Plated step shank pin
FPP100
1
(25.4)
1" Plated pin
FPP114
1-1/4
(31.8)
1-1/4" Plated Pin
Shank diameter = .109
Head diameter = .250
* Shank diameter = .104/.118
* Head diameter = .250
TrakFast breakaway
Strip fuel/pin pack
Collation designed to breakaway on impact. For high volume, repetitive fastenings to concrete such
1000 PINS AND 1 FUEL CELL PER BOX as wood furring to concrete
PART NUMBER
FPP034T
FPP100T
FPP114T
FPP112T
PIN LENGTH
IN.
(MM)
3/4
1
1-1/4
1-1/2
(19.1)
(25.4)
(31.8)
(38.1)
DESCRIPTION
3/4" Plated pin
1" Plated pin
1-1/4" Plated Pin
1-1/2" Plated Pin
Shank diameter = .109
Head diameter = .250
Sold in master cartons of 5000 minimum. Cartons cannot be split.
www.ramset.com
23
GAS TOOL FASTENERS
PLY138 Trakfast Plywood Pin
for attaching plywood
to metal studs
• Fastener Length: 1-3/8"
• Shank Diameter: .100 dia. (before knurl)
• Head Diameter: .250
• Can Be Used With:
Wood Sheathings: 3/8", 1/2", 5/8", 3/4"
Steel Stud Gauges: 16, 18, 20
• Helical Knurled Shank
• Mechanical Zinc Plated
Advantages
1000 pins and 1 fuel cell per box
vs screws
• 3 - 5 times faster than screw installation. No
worrying about electrical cords.
vs air systems
• No set-up and tear down time. No hassling with
compressors or hoses.
Strip
• Collation strip breaks away upon impact,
allowing the head of the pin to recess into the
wood for a nice, clean look
pins
• Hardened steel pin ensures a clean penetration
of the fastener — no dimpling of the stud
• 10-pin strips transfer easily from the operator’s
pouch to the TrakFast tool, eliminating waste
24
• Knurled helical shank gives the fastener superior
holding values
• Zinc plated for corrosion resistance
www.ramset.com
GYPFAST TOOL FASTENERS
GAS TOOL FASTENERS Selection chart
GYPFAST
Part No.
Fastener Description
.140" Dia. Knurled Shank
5/16" Dia. Bugle Head
Master Carton
Quantity
Master
Carton
Weight
Applications
GF112
1-1/2" (38mm)
6,000 nails/ctn
(40- 150 ct. coils) 6 fuel cells
37 lbs.
Single Layer of Exterior Sheathing, Wood
Furring and Blocking
GF200
2" (51mm)
4,800 nails/ctn
(32 - 150 ct. coils) 5 fuel cells
38 lbs.
Double Layer of Exterior Gypsum
Sheathing, Wood Furring and Blocking
GF212
2-1/2" (64mm)
2,700 nails/ctn
(18 - 150 ct. coils) 3 fuel cells
26 lbs.
Multi-Layers of Sheathing, Wood
Blocking, and Dimensional Lumber
Corrosion Resistance:
Climacoat Long Life Polymer
Salt Spray Results (ASTM B117)
Driven: 1560 hours, 10% or less red rust
UnDriven: 3240 hours, 10% or less red rust
AIR TOOL FASTENERS Selection chart
GYPFAST AIR
Part No.
Fastener Description
.140" Dia. Knurled Shank
5/16" Dia. Bugle Head
Master Carton
Quantity
Master
Carton
Weight
Applications
GF112A
1-1/2" (38mm)
6,000 nails/ctn
(40- 150 ct. coils)
36 lbs.
Single Layer of Gypsum Sheathing, Wood
Furring and Blocking
GF200A
2" (51mm)
4,800 nails/ctn
(32 - 150 ct. coils)
37 lbs.
Double Layer of Gypsum Sheathing, Wood
Furring and Blocking
GF212A
2-1/2" (64mm)
2,700 nails/ctn
(18 - 150 ct. coils)
26 lbs.
Multi-Layers of Sheathing, Wood
Blocking
Tools and Techniques
• Always read operators manual for instruction on proper use and safety.
• Adjust depth sensitive nosepiece to achieve proper
seating of fastener to work surface.
www.ramset.com
• Consult sheathing manufacturer’s guidelines for
appropriate fastener and fastening pattern.
• Point of nail must penetrate 1/2" minimum beyond steel.
25
T3SS Electrical accessories
Gas tool fasteners
(Pre-assembled, Single-Shot)
The fasteners are designed for use in Ramset Single-Shot Gas Tools (R150, T3SS)
Selection chart
For suspended ceilings, piping and other items using 1/4" or 3/8"
Threaded rod hanger threaded rod. Fastener is pre-assembled to a 16 gage threaded rod
hanger. 100 per jar.
UL
PART
NUMBER
DESCRIPTION
14TRHMP034
1/4" Rod hanger with 3/4" plated pin
38TRHMP034
3/8" Rod hanger with 3/4" plated pin
Shank diameter = .104/.125
Available in
convenient jars!
Head diameter = .300
Used to attach conduit or armored cable to concrete. Fastener pre-
One hole strap assembled to a 16 gage conduit strap. 100 per jar, 3/8" 200 per jar.
PART
NUMBER
DESCRIPTION
38HSMP034*
UL
UL
12HSMP034
1/2" Hole strap with 3/4" plated pin
34HSMP034
3/4" Hole strap with 3/4" plated pin
10HSMP034
1" Hole strap with 3/4" plated pin
Shank diameter = .104/.125
Conduit clamp
3/8" Hole strap with 3/4" plated pin
Head diameter = .300 *38HSMP034 = 18 gage, 200 per jar
The new durable plastic containers
mean less waste on the jobsite, or
in the back of a truck. Their widemouth design makes it easy to grab
what you need.
Used to attach conduit to concrete. Pin pre-assembled to an 18 gage
conduit strap. 1/2" 50 per jar and 3/4" 25 per jar.
PART
NUMBER
DESCRIPTION
12CCMP034L
1/2" Conduit clamp with 3/4" plated pin
34CCMP034L
3/4" Conduit clamp with 3/4" plated pin
Shank diameter = .104/.125 Head diameter = .300
Ceiling Clip Assembly
Pre-assembled Ceiling Clip. Plated 14 gage clip. 100 per jar.
PART
NUMBER
DESCRIPTION
34CLIP
3/4" wide angle clip w/ 3/4" length pin
Shank diameter = .104/.125
26
Each T3ss gas accessory and pin
label provides vital holding value
information—taking away the
guess work.
Head diameter = .300
www.ramset.com
GAS TOOL FASTENERS
(Pre-assembled, Single-Shot)
Selection chart
Used to install temporary lighting and secure low voltage cable to concrete, uses a standard cable tie up to 3/8" in
Tie strap holder width. Fastener is pre-assembled to a 22 gage tie strap holder. 50 per jar.
PART
NUMBER
DESCRIPTION
TSHMP034
Tie strap holder with 3/4" plated pin
Shank diameter = .104/.125
Head diameter = .300
Mechanical pin Used for the attachment of light gage metal to concrete and steel such as HVAC duct strap to concrete. Plated pin
with washer pre-assembled to a 1/2" domed washer. 200 per jar, 1" 100 per jar.
MUST USE WITH MAGNETIC WORK
CONTACT ELEMENT (M150200)
1/4-20 threaded stud
PART
NUMBER
DESCRIPTION
M012
1/2" Plated step pin with dome washer
M034
3/4" Plated pin with domed washer
M034BB
3/4" Premium step pin with domed washer
M100
1" Plated pin with domed washer
Shank diameter = .125, Step Pin .104/.118
Head diameter = .300 (M012 = .250)
*Will fit R150 & T3SS with optional work contact element, P/N: M150200
Used to attach electrical components to concrete where removability of the component is required. Plated threaded
stud. 200 per jar.
PART
NUMBER
DESCRIPTION
SHANK LENGTH
14STUD
1/2"
5/8"
Shank diameter = .125
NOT MADE IN USA
TOP HAT PIN
Used for general purpose fastening to concrete.
Plated pin with top hat. 200 per jar.
PART
NUMBER
DESCRIPTION
MPO34TH
Shank diameter = .125
3/4" Plated pin with top hat
Head diameter = .300
Pre-Assembled 2" Bridle Ring supports low voltage, data com, signal, and control cables
Bridle ring 50 per box.
PART
NUMBER
DESCRIPTION
BR2
2" Bridal ring
Shank diameter = .125
www.ramset.com
27
Powder fasteners
These Mechanical/Electrical Assemblies are designed
to be used in either Gas or Powder Actuated Tools.
The unique fastener design increases fastening
success rate while providing outstanding performance.
Selection chart
Hybrid pin
For general purpose attachments to concrete.
PowerPoint step shank pin pre-assembled to 1/2" washer. 500 per jar.
PART
NUMBER
DESCRIPTION
ALL POWDER TOOLS
M100BB
1" PowerPoint step shank pin with 1/2" domed washer & flute
•
Shank diameter = .125/.150 Head diameter = .300
One hole
conduit strap
Used to attach conduit or armored cable to concrete.
PowerPoint fastener pre-assembled to a 16 gage conduit strap. 100 per box.
PART
NUMBER
DESCRIPTION
ALL POWDER TOOLS
38HSSS10
3/8" Hole strap with w/1 premium pin
12HSSS10
1/2" Hole strap with w/1 premium pin
•
•
•
•
34HSSS10
3/4" Hole strap with w/1 premium pin
10HSSS10
1" Hole strap with w/1-1/4" premium pin
Shank diameter = .125/.150
38HSSS10 = 18 gage
Threaded
rod hanger
UL
For suspended ceilings, piping, and other items using 1/4" or 3/8" threaded rod.
PowerPoint fastener pre-assembled to a 16 gage threaded rod hanger. 100 per box.
PART
NUMBER
DESCRIPTION
ALL POWDER TOOLS
14TRHSS10
1/4" Rod hanger w/1" premium pin
38TRHSS10
3/8" Rod hanger w/1" premium pin
•
•
Shank diameter = .125/.150
28
Head diameter = .300
Head diameter = .300
www.ramset.com
POWDER FASTENERS
We maintain only the highest standards in the materials, production techniques and
quality control measures used to manufacture our fasteners, assuring consistent,
optimum quality in every fastener.
FASTENER TERMINOLOGY SUFFIX
K = Knurled
X = Collated
B = Black
SD = Washer
E = Ramguard
TH = Top Hat
Advantages
ITW Ramset powder actuated fasteners are specifically fabricated to meet the
exacting requirements of toughness and durability that enable them to penetrate
dense concrete and structural quality steel. All Ramset fasteners with .300 head will
fit into tools with 8mm barrels.
C = 100 count
M = 1000 count
Selection chart
Black track pins
Designed for use in concrete and structural steel applications. Available in 100-pack or 1000-pack per box.
PART
NUMBER
SHANK LENGTH
IN.
(MM)
1506B
3/4
Shank diameter = .145
plated pins
721/
R25
ROCKET
D60/
D45A
SA270
XT540
COBRA
MASTERSHOT/
RS22
•
•
•
•
•
•
•
(19.1)
Head diameter = .300
Designed for use in concrete and structural steel applications. 100 per box.
PART
NUMBER
SHANK LENGTH
IN.
(MM)
1503K
1/2 Knurled
(12.7)
1506
3/4
(19.1)
1508
1
(25.4)
1510
1-1/4
(31.8)
1512
1-1/2
(38.1)
1514
2
(50.8)
1516
2-1/2
(63.5)
1524
3
(76.2)
Shank diameter = .145
721/
R25
ROCKET
D60/
D45A
SA270
XT540
COBRA
MASTERSHOT/
RS22
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Head diameter = .300
Washer increases bearing surface against the material to be fastened.
washered pins 100 per box. 16 gage metal washer. 7/8" diameter washer after 16 gage.
PART
NUMBER
1506SD
SHANK LENGTH
IN.
(MM)
3/4
721/
R25
ROCKET
D60/
D45A
SA270
XT540
COBRA
MASTERSHOT/
RS22
(19.1)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
1508SD
1
(25.4)
1510SD
1-1/4
(31.8)
1512SD
1-1/2
(38.1)
1514SD
2
(50.8)
1516SDC
2-1/2
(63.5)
1524SDP*
3
(76.2)
*Square washer indicates 3" pin has been installed
www.ramset.com
Shank diameter = .145
Head diameter = .300
29
POWDER FASTENERS
Selection chart
PowerPoint pins Used for fastening into harder steel and concrete. Premium steel and hard concrete pin. 100 per box.
PART
NUMBER
SHANK LENGTH
IN.
(MM)
SP12
1/2
(12.7)
SP58
5/8
(15.9)
3/4
(19.1)
SP34
Shank diameter = .150
721/
R25
ROCKET
D60/
D45A
SA270
XT540
COBRA
MASTERSHOT/
RS22
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Head diameter = .300
powerpoint Used for fastening into harder steel and concrete. Premium steel and hard concrete pin.
step shank pins Pin for fastening into harder steel and concrete. 100 per box. (M100BB 500 per jar)
PART
NUMBER
SHANK LENGTH
IN.
(MM)
M100BB
1
(25.4)
SP100
1
(25.4)
SP114
1-1/4
(31.8)
SP112
1-1/2
(38.1)
SP178
1-7/8
(47.6)
721/
R25
ROCKET
D60/
D45A
SA270
XT540
COBRA
MASTERSHOT/
RS22
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Shank diameter = .150/.180 Head diameter = .300
M100BB shank diameter = .125/.150 with 1/2" washer
Increases bearing surface against material to be fastened for improved attachment to inconsistent base materials.
Top hat drive pin 100 per box.
PART
NUMBER
SHANK LENGTH
IN.
(MM)
SP58TH
†
1906
†
1908
5/8
3/4
1
Shank diameter = .145 (15.9)
(19.1)
(25.4)
(SP58TH = .150)
721/
R25
ROCKET/
D45A
D60
SA270
XT540
COBRA
MASTERSHOT/
RS22
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Head diameter = 8mm
(SP58TH = .300)
Coated to improve corrosion resistance in treated lumber and other applications.
Ramguard pins 100 per box. Recommended for threaded lumber applications.
PART
NUMBER
SHANK LENGTH
IN.
(MM)
1516E
1524E
1516SDE
1524SDE*
SP178E
2-1/2
3
2-1/2
3
1-7/8
Shank diameter = .145
Head diameter = .300
721/
R25
AUTOFAST D60/D45A ROCKET/
SA270
•
•
•
•
•
(63.5)
(76.2)
(63.5)
(76.2)
(47.6)
•
•
•
•
•
•
•
(SP178E = .150/.180)
*Square washer indicates 3" pin has been installed
XT540
COBRA
MASTERSHOT/
RS22
•
•
•
•
•
•
•
•
•
•
•
•
•
•
* 1500 Series Coated with RamGuard
* SP Series Coated with Triple Zinc
1/4 - 20
For applications the require removability. 100 per box.
THREADED STUD
PART
NUMBER
†
1623WK
†
1643W
THREAD
LENGTH
IN. (MM)
3/4
3/4
(19.1)
(19.1)
SHANK LENGTH
IN.
(MM)
1/2 Knurled
1
(12.7)
(25.4)
Shank diameter = .145
Use 1623WK for Steel Base Materials
721/ ROCKET D60/ SA270 XT540 COBRA VIPER
R25
D45A
•
•
•
•
•
•
•
•
•
•
•
•
MASTERSHOT/
RS22
•
•
Use 1643W for Concrete Base Materials
† NOT MADE IN USA
30
www.ramset.com
POWDER FASTENERS
Selection chart
TRUE EMBEDMENT PIN
U
E
EMBED
Sized a 1/16" longer than nominal length to provide a True Embedment. 100 per box.
M
E
N
T
TR
The Ramset .157 True Embedment Pin is sized to provide you with True Embedment depths in track up to 14
gauge. You are assured to meet the required embedment depths into concrete or steel without compensating
for the track depth. The pin heads are also stamped for easy identification after installation.
PART
NUMBER
PIN LENGTH
TE12
RA
©
MSET
EMBEDMENT
LENGTH
IN.
(MM)
721/
R25
VIPER
D60
ROCKET/
SA270
D45A
COBRA
XT540
IN.
(MM)
0.545
(13.8)
1/2
(25.4)
•
•
•
•
•
•
TE34
13/16
(20.6)
3/4
(31.8)
•
•
•
•
•
•
TE100
1-1/16
(27)
1
(25.4)
•
•
•
•
•
•
TE114
1-5/16
(33.3)
1-1/4
(31.8)
•
•
•
•
•
•
TE112
1-9/16
(39.7)
1-1/2
(38.1)
•
•
•
•
•
•
Shank diameter = .157
Head diameter = .320
Embedment depth is easily identifiable by
head stamps.
Ceiling clip
Designed for suspending ceilings and other overhead applications. Pin preassembled to a 14 gage clip. 1000 per box.
assemblies
PART
NUMBER
IN.
SDC100
SDC125*
1
1-1/4
PIN LENGTH
(MM)
(25.4)
(31.8)
*Available in 100-Pack (P/N: SDC125C) Shank diameter = .145
721
VIPER
D60
ROCKET/
SA270
D45A
COBRA
XT540
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Head diameter = .300
PowerPoint pins
Designed for difficult overhead applications. Pin preassembled to a 14 gage angle clip. 1000 per box
with ceiling clips
PART
NUMBER
IN.
SPC78
SPC114
7/8
1-1/4
Shank diameter = .150
PIN LENGTH
(MM)
(SPC114 = .150/.180)
(22.2)
(31.8)
721
VIPER
D60
ROCKET/
SA270
D45A
COBRA
XT540
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Head diameter = .300
Fastener
General purpose 3/4" wide angle clip. 14 gage angle clip. 100 clips per box.
angle clip
PART
NUMBER
DESCRIPTION
1202CF
Angle clip
(no pin)
Hole diameter: 5/16" & 13/64"
www.ramset.com
31
POWDER LOADS
High Quality and Dependability
ITW Ramset powder loads and tools match tolerances to provide optimum power
within recognized national velocity standards. Available in color-coded 10-load
discs, 10-load strips, and 100-load boxes.
Advantages Powder Guide
Power level is designated by the load level number marked on each box; also by
the color of the box and each powder load. As the number increases, the power
level increases.
Caution Always test-fasten with the lowest power level for your tool. If more power
is necessary, use the next highest power level until proper level and fastening is
achieved. Refer to operator's manual for more specific details. Observe all safety
reminders. Tool operators must be trained and qualified as required by federal law.
Failure to use properly can result in serious injury or death to users or bystanders.
Now Available - LEAD FREE
RS27 Series
Disc Series
RS25 Series
CW Series
Selection chart
Ramset loads for low velocity tools
COMPATIBLE TOOLS
PART
NUMBER
POWER
LEVEL
COLOR
CALIBER/TYPE
PACKAGING
2D60
3D60
4D60
2
3
4
Brown
Green
Yellow
.25 Disc
.25 Disc
.25 Disc
all 10 disc
10 discs/box
D60, D45A and AutoFast
RAMSET
OTHERS
5D45
5
Red
.25 Disc
10 discs/box
D45A and AutoFast
3RS25
4RS25
5RS25
3
4
5
Green
Yellow
Red
.25 Strip
.25 Strip
.25 Strip
all 10 strip
10 strips/box
R25
DX-35
22CW
32CW
42CW
2
3
4
Brown
Green
Yellow
.22 Single
.22 Single
.22 Single
all 100/box
721, M70, RS22, HD22, Mastershot
DXE37, DXE72
3RS27
3
Green
.27 Strip
all 10 strip
10 strips/box
4RS27
4
Yellow
.27 Strip
all 10 strip
10 strips/box
5RS27
5
Red
.27 Strip
all 10 strip
10 strips/box
DX-350, DX-351, DX-36M,
DX-451, DX460
6RS27
6
Purple
.27 Strip
all 10 strip
10 strips/box
DX-451, DX-460
3NL27
3
Green
.27 Strip
all 10 strip
10 strips/box
4NL27
4
Yellow
.27 Strip
all 10 strip
10 strips/box
5NL27
5
Red
.27 Strip
all 10 strip
10 strips/box
DX-350, DX-351, DX-36M, DX460
SA270, Cobra, Viper,
Rocket and XT540
SA270, Cobra, Viper,
Rocket and XT540
DX-350, DX-351, DX-36M,
DX-451, DX460
POWDER LOAD IDENTIFICATION
.25 and .27 caliber strips available in 1000 pack
*1000-Pak/100 Strips/Box
Hilti® is a registered trademark of Hilti, Corp.
32
1
Grey
2
Brown
3
4
GreenYellow
Lower power
5
6
Red
Purple
Higher power
www.ramset.com
intro to gas technology
ITW saw a challenge: how to create a portable tool that delivered
the power of pneumatic tools without the hoses and compressors. In
1991, ITW Paslode conquered the challenge with the revolution of gaspowered technology. The cordless Impulse Finish Nailer delivered the
power of pneumatic tools without cluttering job sites.
With the thought of Driving Jobsite Speed while creating a safer work
environment, ITW Ramset built upon the Paslode technology and in
1992 introduced the TrakFast to the drywall trade. It forever changed
the way the world worked. In 2003, ITW Ramset followed up on the
success of the TrakFast with the T3SS which is setting the standard
for electrical and mechanical contractors.
Gas significantly lowers cost-in-place, reduces stress on the employee,
and it's much quieter to use than drilling or powder actuated tools
(PATs), so you can work in occupied buildings. There are times when
you need the power and accuracy of our PATs—like the speed of our
D45A disc tool, or the work horse, nearly maintenance-free 721 single
shot PAT. But constant use of these tools can be noisy and overly jarring
on the body.
• No Licensing Required
• Fast and Easy to Use
• Quiet—No Recoil
• No Cords or Hoses
• Long Fuel Cell & Battery Life
Drywall Electrical
Mechanical
When the conditions are right, gas is the right choice.
The industry transitions to gas technology
Problem:
Problem:
“My guys work on block all day long—from electrical
boxes to furring. I've tried powder tools and they
blow holes in block. What makes the Ramset
technology different?"
Solution:
“I don’t want to have to re-license my guys to
work with gas technology"
Since there are no loads, there's no licensing needed.
In fact, Union Trainers have begun including the Ramset
Gas Tools in training classes, and students can't believe
how easy the tools are to work with.
Solution:
Ramset technology has patented
overdrive technology built in to
every gas-powered tool. The tool works under
the same principal as a combustion engine. A
little gas, a little spark and a powerful shot,
without the recoil associated with powder.
In addition, the gas powered tools are totally
portable and can be used for almost all your
jobs—without the worry of having unspent loads
on your jobsite.
The Inside Story
Powder
Always
High PSI concrete
Medium PSI concrete
Low PSI concrete
substrate material
Steel
Gas Preferred
Gas
Pan deck
Grout filled block
daily shot frequency
Low
www.ramset.com
Medium
High
Very high
The patented Ramset technology delivers
precisely balanced power eliminating the
damage caused by overdrive in PATs.
SPARK PLUG
FUEL PORT
How it works: As the nosepiece is depressed,
a rechargeable battery turns on the fan
motor. In less than a second: a precise
amount of fuel is injected into the combustion chamber. When the trigger is pulled, a
spark creates an explosion that drives the
piston into the fastener, and the fastener
in the work surface. The action creates a
vacuum that pulls the piston back to the
start position.
FAN MOTOR
In fact the technology is so precise it won't
blow through a pop can.
CYLINDER
COMBUSTION
CHAMBER
PISTON
ASSEMBLY
33
SUGGESTED SPECIFICATIONS
Ramset provides the architect and
engineer the following suggested
language and helpful information for
the purpose of fastening specifications.
Plywood to Metal Framing
or Truss
Part Number PLY138
Fasteners used shall have a 0.100
nominal shank diameter with helical knurl
and a length of 1-3/8-inches.
Track or Clip to Steel Beam
Part Number 1503K (pg.29)
Fasteners used shall have a 0.300
head with a 0.145 knurled shank
diameter and a length of 1/2-inches.
Part Number SP58TH (pg.30)
Fasteners used shall be designated
power point type with a 0.150 nominal
shank diameter and a length of
5/8-inches.
Part Number TE12 (pg.31)
Fasteners used shall have a 0.320 head
with a 0.157 knurled shank diameter
and a length of .545 inches.
Part Number TE100 (pg.31)
Fasteners shall be designated “True
Embedment” type with a 0.320 head
with a 0.157 shank and length of 1.0625
providing minimum of 1” of embedment
in up to 14ga track. Fastener shall have
the embedment depth of 1” stamped
on head.
Interior Partition Track
to Concrete
Part Number T3034B (pg.23)
Fasteners shall be designated
T3 Type with a 0.125 nominal
shank diameter and a length
of 3/4 inch.
Exterior Sheathing
to Metal Stud
Part Number GF112 (pg.25)
Fasteners designated
“GYPFAST" and have a
helical knurled shank
with a 1-1/2" Length
Exterior Perimeter
Track to Concrete
Part Number 1510SD (pg.29)
Fasteners used shall have
a 0.145 nominal shank
diameter and a length
of 1-1/4 inches. The
fastener shall have a
pre-assembled 7/8-inch
washer.
Part Number SP114 (pg.30)
Fasteners used shall be
designated PowerPoint
type with a 0.150/.180 stepped
shank and a length of 1-1/4
inches.
For assistance with specifications and/or substitutions, contact Technical Service at 800-726-7386.
34
www.ramset.com
Fasteners – how they work
Selecting the correct fastener length
Power level guide for loads
Selecting the correct fastener length
High quality fasteners provide consistent and
reliable performance in concrete, block, masonry,
and steel applications. Choosing the correct fastener
for the job will assure professional results.
A Determine thickness of material being attached.
All loads are color coded and load level
numbered. As the number increases, the
power level increases.
Always start with the lightest load. If the
fastener does not set completely, use the
next higher load and repeat the process.
b Fastener must be long enough to drive
approximately 1" into concrete, cement block or
penetrate thickness of steel.
Least
2 ... Brown Powerful
3 ... Green
4 ... Yellow
5 ... Red
Most
Powerful
Typical USES
WOOD attachment
material*
2x4
Concrete base material
Structural steel base
Commonly Used
Fastener
Commonly Used
Load
Commonly Used
Fastener
Commonly Used
Load
1516SDC (2-1/2")
Yellow #4
1514SD
(2")
SP178 (1-7/8")
Red #5
Red #5
3/4" Plywood for furring strip
1512
(1-1/2")
Yellow #4
1510
(1-1/4")
Yellow #4
1/4" - 1/2"
1510
(1-1/4")
Green #3
SP34
(3/4")
Yellow #4
* Use Ramguard Pin for treated lumber.
THIN GAGE STEEL
Concrete base material
Commonly Used
Fastener
Commonly Used
Load
Structural steel base
Commonly Used
Fastener
Electrical Junction Boxes
M100BB
(1")
Green #3
SP58TH
Shelf Brackets
M100BB
(1")
Green #3
SP34
(3/4")
Yellow #4
(3/4")
Brown #2
SP12
(1/2")
Yellow #4
(1-1/4")
Yellow #4
SP12
(1/2")
Yellow #4
Interior Drywall Track
Perimeter Track
1506B
1510
(5/8")
Commonly Used
Load
Yellow #4
NOTE: This chart is presented as a guide only. Start with the lightest load. If the fastener does not set completely, use the next higher load and repeat the process.
Product suggestions may not be suitable for all types of base materials. Contact Technical Services if you have further questions.
www.ramset.com
35
Fasteners – how they work
Description
Fastening to concrete
As the fastener enters the concrete, extreme pressures and heat are created.
This creates a bond that provides high loading strength in concrete snugly
and provides tool protection.
Fastening to steel
The resilience of steel provides a clamping effect to the
fastener. This combined with the tremendous heat that is
created, provides a welding and clamping effect to give
maximum holding power.
Fastening placement and penetration
The following represents the minimum edge and spacing requirements, plus base material thickness requirements:
Concrete
Steel
1. Edge distance. Do not fasten closer than 3 inches from the edge of concrete. If the
concrete cracks, the fastener may not hold and may allow the fastener to ricochet,
causing serious injury or death to the operator or bystanders.
1. Edge distance. The recommended edge distance for a
fastener to the edge of steel is 1/2 inch. Never fire the
tool within 1/2 inch of the edge of a steel base material
because the steel may bend or break off, allowing the
fastener to ricochet, causing serious injury or death to the
operator or bystanders.
2. Recommended minimum fastener spacing. Setting fasteners too close together
can cause the concrete to crack. The recommended MINIMUM DISTANCE between
fastening is three (3) inches. Never attempt a fastener application too close to another
previously inserted fastener to prevent the second fastener from ricocheting off the
previously installed fastener. A ricochet can result in serious injury or death to the
operator or bystanders.
3. Concrete thickness. It is important that the concrete be at least three (3) times as
thick as the fastener penetration. If the concrete is too thin, the compressive forces
forming at the fastener’s point can cause the free face of the concrete to break away.
This creates a dangerous condition from flying concrete and/or the fastener and also
results in a reduction of fastener holding power.
2. Recommended minimum fastener spacing. The
recommended minimum distance between fastening is
1 inch. Never attempt a fastening application too close to
another previously inserted fastener to prevent the second fastener from ricocheting
off the previously installed fastener. A ricochet can result in serious injury or death to
the operator or bystanders.
3. Steel thickness. Do not fasten into steel base material thinner than the fastener shank
diameter. Holding power will be reduced and the fastener may be over-driven, creating
a dangerous situation to the operator or bystanders due to a free-flying fastener.
How to select a powder actuated fastener
• Drive pins are used to directly fasten an object (permanent installation).
• Threaded studs are used where the object fastened is to be removed or where shimming is required. The following shows how to determine shank
and thread length. Required penetration is determined by load requirement (illustrated in the following examples).
Ramset fasteners may be specified by their type or catalog number to satisfy fastening requirements.
Permanent Installation
To Concrete
inimum
M
Shank =
Length
To Concrete
inimum
M
Thickness Shank = of Material +
Length
(M)
Thread Thickness
Length = of Material +
(A)
(M)
Allowance*
For Nut
& Washer
Shank Length = 1"
Thickness Required
of Material + Penetration
(M)
(P)
To Steel
36
Removable Installation
*Allowance for thickness of nut & washer = thread
size (i.e. allow 1/4" for 1/4-20 thread, etc.)
To Steel
Thickness
1/4 Min.
of Steel + Point
(T)
Allowance
Thread Thickness
Length = of Material +
(A)
(M)
Allowance*
For Nut
& Washer
Shank Length = 1/2"
www.ramset.com
TROUBLESHOOTING
Concrete symptom
Fastener does not hold
in base material or base
material spalls
Fastener does not
penetrate deep enough
Cause
• High strength concrete
• Hard or large aggregate in concrete
fastener penetrates
too deep
Cause
• Fastener too short for application
• Tool power level too high
ACTION
ACTION
• Use shorter fastener
• Use PowerPoint pin
• Use load with a different power level
• Use longer fastener
• Use a lighter powder load
Cause
Fastener bends
• Fastener too long
• Tool power level too low
Cause
ACTION
• Fastener hit large aggregate on entry
• Concrete too hard
• Fastener hit rebar just under
the surface
• Use shorter fastener
• Use a stronger powder load
ACTION
• Use shorter fastener
• Use PowerPoint pin
• Make sure tool is perpendicular to
the work surface
• Move over 3 inches, try to fasten again
Steel symptom
Fastener does not
penetrate the surface
Cause
• Driving power too low
• Material may be too hard for forced
entry fastener
fastener does not hold
in base material
• Use gas system tools with smaller Shank
pin or Tek pin
• Increase powder load level
• Use PowerPoint pin
Cause
• Driving power is too low
• Fastener is too long
• Material may be too hard for forced
entry fastener
ACTION
• Increase powder load level
• Reduce fastener length
www.ramset.com
• Steel base material too thin
ACTION
ACTION
Fastener breaks
or bends
Cause
fastener does not
fully penetrate steel
Cause
• Driving power too low
• Steel base material too thick
• Application limit may have been reached
ACTION
• Increase powder load level
• Use PowerPoint pin
37
PERFORMANCE /SUBMITTAL
Ramset fasteners may be specified by their type or catalog number to satisfy fastening requirements.
Pin specifications
Approvals/listings
• iCC Evaluation Service, Inc.
• Made from AISI 1060-1065 steel. Austempered to a core hardness of
52-56 Rc
• Typical tensile strength: 270,000 psi
• Typical shear strength: 162,000 psi
#ESR-2579 TrakFast Pins
#ESR-1955 T3 Fasteners
• City of Los Angeles
• Standard finishes
Proprietary black
Mechanical zinc plate to a minimum thickness of .0002 meets
requirements of ASTM B695
Electroplated zinc with yellow chromate
Ramguard
#RR-25739 T3 pins
#RR-25264 TrakFast pins
Collated Gas Fasteners In Concrete (TrakFast, T2 And T3)
PART
NUMBER
SERIES
MINIMUM
PENETRATION
(INCH)
0.109
5/8
3/4
60
60
434
595
55
80
546
650
55
55
453
583
75
95
615
699
55
55
472
571
95
115
685
749
0.104/0.118
3/4
.....
.....
.....
.....
.....
.....
.....
.....
51
256
83
418
2000 PSI
TENSION (LBS)
FPP Straight Shank
FPP Step Shank
INSTALLED IN STONE AGGREGATE CONCRETE
CONCRETE COMPRESSIVE STRENGTH
ALLOWABLE LOAD - Ultimate Load
3000 PSI
SHANK
DIAMETER
(INCH)
SHEAR (LBS)
2000 PSI
TENSION (LBS)
SHEAR (LBS)
83
107
.....
109
156
.....
4000 PSI
TENSION (LBS)
SHEAR (LBS)
78
104
60
0.104/0.125
PART
NUMBER
SERIES
SHANK
DIAMETER
(INCH)
MINIMUM
PENETRATION
(INCH)
0.109
5/8
3/4
35
80
234
630
55
100
403
756
30
40
239
330
205
235
0.104/0.118
3/4
.....
.....
.....
.....
.....
.....
.....
5/8
3/4
5/8
84
108
.....
418
540
.....
108
173
.....
540
864
.....
72
93
54
361
470
269
242
288
230
0.125
0.104/0.125
426
593
357
80
195
117
5/8
3/4
5/8
FPP Straight Shank
FPP Step Shank
T3
Straight Shank
T3 Step Shank
611
855
.....
SHEAR (LBS)
T3
Straight Shank
T3 Step Shank
0.125
414
541
.....
TENSION (LBS)
574
977
587
4000 PSI
TENSION (LBS)
SHEAR (LBS)
6000 PSI
TENSION (LBS) SHEAR (LBS)
.....
.....
107
.....
.....
533
.....
.....
191
.....
.....
957
INSTALLED IN LIGHTWEIGHT CONCRETE / DECK / BLOCK
ALLOWABLE LOAD - Ultimate Load
3000 PSI
LIGHT WEIGHT CONCRETE
TENSION (LBS)
SHEAR (LBS)
3000 PSI LIGHT WEIGHT
CONCRETE WITH METAL DECK
TENSION (LBS)
SHEAR (LBS)
HOLLOW CONCRETE MASONRY
UNITS (CMU ANY LOCATION)
TENSION (LBS) SHEAR (LBS)
1025
1248
35
.....
347
......
50
.....
435
.....
.....
36
184
58
290
1210
1442
1150
20
.....
71
243
.....
357
34
.....
123
264
.....
613
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance with ICC AC70 & ASTM E1190.
Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Values shown in concrete are for the
fastener only. Connected members must be investigated separately. Note 5: Cyclic, fatigue, shock loads, and other design criteria may require a different safety factor. Note 6: Job
site testing may be required to determine actual job site values. Note 7: Minimum edge distance in concrete is 3 inches unless otherwise approved. Note 8: For SI: 1 lbf = 4.448 N, 1
inch = 25.4 mm, 1 ksi = 6.89MPa. Note 9: T3 straight shank allowable tension value in face shell of hollow CMU is 133 lbs.
38
www.ramset.com
PERFORMANCE /SUBMITTAL
Electrical Fasteners in Concrete
GAS ASSEMBLIES
MP034TH*, M034*
M100*, BR2*
14STUD
M034BB
34 CLIP
38HSMP034, 12HSMP034
34HSMP034, 10HSMP034
114HSMP034, 14TRHMP034
38TRHMP034, TSHMP034
12CCMP034L, 34CCMPO34L
POWDER ASSEMBLIES
FASTENER PART
NUMBER
M100BB, 38HSSS10
12HSSS10, 34HSSS10
10HSSS10, 14TRHSS10,
38TRHSS10
SHANK
DIA.
(INCH)
INSTALLED IN STONE AGGREGATE CONCRETE
HOLLOW BLOCK
CONCRETE COMPRESSIVE STRENGTH
Grade N, Type 1
ALLOWABLE LOAD - Ultimate Load
3000 PSI Light weight
FACE SHELL
4000 PSI
6000 PSI
Min 1-1/4" face thickness
LOWER FLUTE
TENSION
SHEAR
TENSION
SHEAR
TENSION
SHEAR
TENSION
SHEAR
(LBS)
(LBS)
(LBS)
(LBS)
(LBS)
(LBS)
(LBS)
(LBS)
MINIMUM
PENETRATION
(INCH)
0.125
0.104/.118
0.104/.125
5/8
3/4
5/8
3/4
5/8
78
104
91
51
62
0.104/.125
5/8
60 357
117 587
107 533
191 957
54 269
230 1150
71 357
123 613
0.125/.150
3/4
107 559
213 1067
161 803
248 1240
96 478
231 1156
102 512
166 831
0.125
80
195
.....
83
.....
426
593
454
256
310
574
977
.....
418
.....
62
132
57
.....
106
308
658
373
.....
528
....
206
.....
.....
.....
.....
1057
.....
.....
.....
72
93
.....
.....
44
361
470
.....
.....
220
242
288
.....
.....
.....
1210
1442
.....
.....
.....
133
84
.....
36
.....
691
444
.....
184
.....
.....
84
.....
58
.....
.....
446
.....
290
.....
* ESR-1955 pin data applies. Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance
with ICC AC70 & ASTM E1190 Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Values
shown in concrete are for fastener only. Connected members must be investigated separately. Note 5: Cyclic, fatigue, shock loads and other design criteria may require a different
safety factor. Note 6: Job-site testing may be required to determine actual job site values. Note 7: Minimum edge distance is 3 inches unless otherwise approved. In hollow block
applications, no more than one fastener per cell. Note 8: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa.
Gas Fasteners in Steel
PART
NUMBER
SHANK
DIAMETER
(INCH)
TYPE OF
SHANK
3/16 (.1875)
TENSION (LBS)
SHEAR (LBS)
INSTALLED IN A36 STRUCTURAL STEEL
STEEL THICKNESS INCHES
ALLOWABLE LOAD - Ultimate Load
1/4 (.250)
TENSION (LBS)
3/8 (.375)
SHEAR (LBS)
TENSION (LBS)
SHEAR (LBS
186 1076 7
FPP012
0.109
SMOOTH
195 1047
292 1570
223 1220
278 1526
181 1048 7
M012
FPP012S
0.104/0.118
SMOOTH
..... .....
..... .....
148 744
157 787
166 832 7
157 787 7
T3012
0.125
SMOOTH
63 676
162 1356
239 1285
211 1417
113 914 8
197 1327 8
T3012S
0.125
TAPER
SMOOTH
..... .....
..... .....
237 1184
356 1782
189 943 10
392 1960 7
INSTALLED IN ASTM A 572 GRADE 50 STEEL
STEEL THICKNESS INCHES
T3012
0.125
SMOOTH
103 733
222 1682
147 950
119 973
147 856 9
112 1014 9
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance with ICC AC70 & ASTM E1190.
Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Cyclic, fatigue, shock loads and other design
criteria may require a different safety factor. Note 5: Job site testing may be required to determine actual job site values. Note 6: Values shown are for fastenings that have the entire
pointed end of the fastener driven through the steel plate; except as noted below. Note 7: Fastener penetration is .31" minimum. Note 8: Fastener penetration is .29" minimum.
Note 9: Fastener penetration is .27" minimum. Note 10: Fastener penetration is .25" minimum. Note 11: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa
www.ramset.com
39
PERFORMANCE /SUBMITTAL
PLY138 TrakFast Plywood to Steel Pin Performance Tables
ALLOWABLE SHEAR FOR WIND OR SEISMIC FORCES IN POUNDS PER FOOT FOR HORIZONTAL PLYWOOD DIAPHRAGMS WITH STEEL FRAMING
PLYWOOD
GRADE
MINIMUM
STEEL
GAGE 4, 6
Structural 1
Grades other than
Structural 1
20
16
20
16
MINIMUM
PANEL
THICKNESS
(Inches)
7/16
15/32
7/16
15/32
BLOCKED DIAPHRAGM PIN SPACING (Inches) 5, 6
Pin spacing at diaphragm boundaries (all cases), at
continuous panel edges parallel to load
(cases 3 &4) and at the panel edges (cases 5 & 6)
ALLOWABLE LOAD
6
4
2-1/2
UNBLOCKED DIAPHRAGM PIN
SPACING (Inches) 5, 6
Pins spaced 6 inches max.
at supported edges
Case 1
All other
(no unblocked edges
configurations
or continuous joints
(cases 2, 3, 4, 5 & 6)
parallel to load)
2
Pin spacing at other panel edges
6
6
4
3
185
205
165
185
280
305
250
275
420
460
380
415
475
520
430
470
185
205
165
185
140
150
125
140
Note 1: These values are for short-time loads due to wind or earthquake and shall be reduced by 25 percent for normal loading. Note 2: The pin shall be long enough
to penetrate through the thickness of the steel a minimum of 1/4 inch. Note 3: Minimum width of framing is 1-1/2 inches. Note 4: These shear values also apply to
framing made of thicker steel. Note 5: Spacing of fasteners along intermediate framing members is 12 inches on center. Note 6: The minimum panel edge distance
is 3/8 inch. Note 7: Values shown reflect a 5:1 safety factor. Note 8: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa
Note: Framing is permitted to be oriented in either direction for diaphragms, provided sheathing is designed for vertical loading.
ALLOWABLE WITHDRAWAL LOADS IN POUNDS PER FASTENER DUE TO WIND OR SEISMIC FORCES FOR PLYWOOD AND LUMBER ATTACHED TO STEEL
FRAMING 1, 2, 3, 4
PIN DIAMETER
(Inches)
MINIMUM STEEL
THICKNESS
(Gage or Inches)
0.100
0.100
0.100
0.100
22
20
18
16
MINIMUM THICKNESS OF PLYWOOD (Inches)
ALLOWABLE LOAD - Ultimate Load
3/8
15
20
30
40
7/16
15
25
35
45
15/32
.....
25
40
60
19/32
.....
25
40
60
Note 1: Plywood shall be Structural 1 rated. For other grades, values shall be reduced by 10 percent. Note 2: These values are for loads due to wind or earthquake
and shall be reduced by 25 percent for other applications. Note 3: Minimum panel edge distance is 3/8 inch. Note 4: The pin shall be long enough to penetrate
through the metal a minimum of 1/4 inch. Note 5: Values shown reflect a 8:1 safety factor. Note 6: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa
40
www.ramset.com
PERFORMANCE /SUBMITTAL
PLY138 TrakFast Plywood to Steel Pin Performance Tables
ALLOWABLE SHEAR FOR WIND FORCES IN POUNDS PER FOOT FOR PLYWOOD SHEAR WALLS WITH STEEL FRAMING
PLYWOOD
GRADE
Structural 1
Grades other than
Structural 1
MINIMUM STEEL
GAGE 5
MINIMUM PANEL
THICKNESS (Inches)
22
22
22
20
20
20
22
22
22
20
20
20
3/8 6
7/16 6
15/32
3/8 6
7/16 6
15/32
3/8 6
7/16 6
15/32
3/8 6
7/16 6
15/32
PIN SPACING, ALL PANEL EDGES (Inches)
ALLOWABLE LOAD
6
120
130
145
155
170
205
110
120
130
140
155
185
4
180
195
215
235
255
305
165
175
195
210
230
275
3
240
260
290
310
340
410
215
235
260
280
310
370
2
305
330
365
395
435
520
275
300
330
360
390
470
Note 1: Values are for loads imposed by wind and shall be reduced by 25 percent for normal loading. Note 2: The pin shall be long enough to penetrate through the
metal framing a minimum of 1/4 inch. Note 3: The minimum panel edge distance for pin placement is 3/8 inch. Note 4: Spacing of fasteners along intermediate
framing members is 6 inches on center for 3/8 inch and 7/16 inch panels when studs are 24 inches on center and 12 inches on center when studs are 16 inches
on center. For other panel thickness, spacing along intermediate framing members is 12 inches from center. Note 5: Framing to be spaced 24 inches on center or
closer except as provided in Footnote 6. Note 6: The values for 3/8-inch and 7/16-inch panels may be increased by 20 percent and 10 percent, respectively, for
framing spaced 16 inches on center. Note 7: Values shown reflect a 5:1 safety factor. Note 8: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa
ALLOWABLE LATERAL LOADS IN POUNDS PER FASTENER DUE TO WIND OR SEISMIC FORCES FOR STRUCTURAL1 PLYWOOD AND LUMBER ATTACHED TO
STEEL FRAMING1, 2, 3, 4, 6
PIN DIAMETER
(INCHES)
MINIMUM PANEL
THICKNESS (Inches)
0.100
0.100
0.100
22
20
16
MINIMUM THICKNESS OF PLYWOOD (Inches)
ALLOWABLE LOAD
3/8
80
105
105
7/16
80
105
105
15/32
80
115
115
19/32
80
115
170
23/32
80
115
170
1-1/8
80
115
170
Note 1: Plywood shall be Structural 1 rated. For other grades, values shall be reduced by 10 percent. Note 2: These values are for loads due to wind or earthquake
and shall be reduced by 25 percent for other applications. Note 3: Minimum panel edge distance for placement is 1 inch from the fastener to the sheathing edge
measured in the direction of the load and 3/8 inch measured perpendicular to the direction of the load. Note 4: The pin shall be long enough to penetrate through
the metal a minimum of 1/4 inch. Note 5: Values for 16 gage also apply to 14 gage. Note 6: The above values apply to groups of at least five fasteners. For fewer
fasteners in a group, use one-half of the tabulated value. Note 7: Values shown reflect a 5:1 safety factor. Note 8: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi =
6.89MPa
www.ramset.com
41
PERFORMANCE /SUBMITTAL
GypFast fasteners for the attachment of gypsum sheathing to light gage steel framing
pin specifications
approvals/listings
• Made from AISI 1060-1065 steel. Austempered to a core hardness of 52-56 Rc
• iCC Evaluation Service, Inc.
• Typical tensile strength: 270,000 psi
• Typical shear strength: 162,000 psi
#ESR-2174 GypFast Gypsum Sheathing
#ER-5380 GypFast Plywood Sheathing
• City of Los Angeles
• Standard finishes
Mechanical zinc plate to a minimum thickness of .0002 meets
requirements of ASTM B695
Climacoat
#RR-25638 GypFast
Allowable Negative Loads Using Ramset GypFast Fasteners
SHEATHING TYPE
MINIMUM STEEL
STUD GAGE
1/2" GP DensGlass Gold Exterior
Sheathing
20g to 12g
MAXIMUM STEEL
STUD SPACING (in)
FASTENER SPACING (in)
ALLOWABLE NEGATIVE
LOAD (psf)
24
8
6
16
8
8
24
8
24
16
8
32
24
8
12
16
8
16
24
8
18
16
8
24
24
8
30
16
8
40
5/8" GP DensGlass Gold Fireguard
Type X Sheathing
20g to 12g
1/2" USG Sheetrock
Brand Sheathing
20g to 12g
5/8" USG Sheetrock Brand Fire Code
Type X Sheathing
20g to 12g
1/2" USG Fiberock
Brand Aquatough
20g to 12g
5/8" USG Securock
Glass-Mat Sheathing
18g
16
8
35
5/8" CertainTeed GlasRoc
Sheathing Type X
18g
24
8
20
5/8" CertainTeed GlasRoc
Sheathing Type X
16g
24
8
18
National Gypsum e2XP
Extended Exposure Sheathing
18g
16
8
39
Note 1: Tested in accordance with ASTM E330. Note 2: Values shown reflect a 3:1 safety factor. Note 3: The fasteners must be driven to a depth at which the shank pierces the
steel, such that the tip protrudes from the base metal a minimum of 1/2-inch. Note 4: Tabulated values do not allow any overdriving of fasteners into sheathing.
corrosion data astm b117 salt spray
GF112
S-12 SELF DRILL SCREW
1560 hours (10% Red Rust)
Driven
3240 Hours (10% Red Rust)
UnDriven
24 Hours (5% Red Rust)
GypFast Fastener has Climacoat Long Life Polymer Coating; S-12 Screw has .0002" Electrozinc and Clear Chromate.
42
www.ramset.com
PERFORMANCE /SUBMITTAL
GypFast fasteners for the attachment of plywood sheathing to light gage steel framing
pin specifications
approvals/listings
• Made from AISI 1060-1065 steel. Austempered to a core hardness of 52-56 Rc
• iCC Evaluation Service, Inc.
• Typical tensile strength: 270,000 psi
• Typical shear strength: 162,000 psi
• Standard finishes
Mechanical zinc plate to a minimum thickness of .0002 meets
requirements of ASTM B695
Climacoat
#ESR-2174 GypFast Gypsum Sheathing
#ER-5380 GypFast Plywood Sheathing
• City of Los Angeles
#RR-25638 GypFast
Allowable Withdrawl and Lateral Loads For A GypFast Fastener Used to Attach Structural
Plywood Panels to Steel Framing Members 1,2,3
MINIMUM STEEL
THICKNESS
(gage)4
MINIMUM THICKNESS OF STRUCTURAL PANELS
3/8 Inch
15/32 Inch
19/32 Inch
MINIMUM THICKNESS OF STRUCTURAL PANELS
23/32 Inch
3/8 Inch
Withdrawl Loads (pounds)
15/32 Inch
19/32 Inch
23/32 Inch
Lateral Loads (pounds)
14
90
90
95
120
135
160
190
215
16
90
90
90
110
135
160
165
185
18
90
90
90
90
135
160
160
160
20
70
70
70
70
110
130
130
130
22
50
50
50
50
110
110
110
110
For SI: 1 Inch = 25.4 mm, 1 Pound = 4.448 N.
1 Tabulated values are for loads due to wind or earthquake, and must be reduced by 25 percent for other applications.
2 Tabulated values allow for no more than 20 percent of the fasteners to be overdriven more than 1/16 inch.
3 Minimum edge distance and spacing are 3/8 inch and 3 inches, respectively.
4 Section 2.2.3 describes minimum base-material thicknesses associated with gages.
Allowable Shear for Wind Forces For Structural Plywood Shear Walls Attached to Light Gage
Steel Studs With GypFast Fasteners1,2,3 (pounds per foot)
PANEL TYPE
MINIMUM PANEL
THICKENESS
MINIMUN GAGE6
3/8
Structural I or
Rated Sheathing
and Siding
3/8
15/32
3/8
3/8
15/32
3/8
3/8
15/32
19/32
23/32
19/32
23/32
19/32
23/32
FASTENER SPACING 4,5
(INCHES ON CENTER)
FRAMING
22
20
18
16
14
SPACING (INCHES ON CENTER)
6
4
3
2
16
180
270
360
459
24
16 or 24
16
24
16 or 24
16
24
16 or 24
16 or 24
16 or 24
16 or 24
16 or 24
16 or 24
16 or 24
144
170
180
144
208
214
171
253
259
259
266
296
304
345
216
255
270
216
313
321
257
380
389
389
399
445
456
517
288
340
360
288
417
428
342
506
518
518
532
593
608
690
367
433
459
367
531
546
437
645
661
661
679
756
776
879
For SI: 1 Inch = 25.4 mm, 1 Pound/Lineral Foot = 0.0146 N/mm.
www.ramset.com
43
PERFORMANCE/SUBMITTAL
Ramset fasteners may be specified by their type or catalog number to satisfy fastening requirements.
Pin specifications
Approvals/listings
• Made from AISI 1060-1065 steel. Austempered to a core hardness of 52-56 Rc
• iCC Evaluation Service, Inc.
• Typical tensile strength: 270,000 psi
#ESR-2690 Sill Plate
#ESR-1799 Powder Pins & Clips
• Typical shear strength: 162,000 psi
• City of Los Angeles
• Standard finishes
Proprietary black
Mechanical zinc plate to a minimum thickness of .0002 meets requirements of ASTM B695
Ramguard
#RR-22668 Powder pins
FASTENERS IN NORMAL WEIGHT CONCRETE
SHANK
DIAMETER
(INCH)
MINIMUM
PENETRATION
(INCH)
1500/1600 SERIES
0.145
3/4
1
1-1/4
1-1/2
SP
0.150
3/4
SP SERIES
.150/.180
1
1-1/4
1-1/2
1900
0.145
3/4
PART
NUMBER SERIES
INSTALLED IN STONE AGGREGATE CONCRETE
CONCRETE COMPRESSIVE STRENGTH
ALLOWABLE LOAD - Ultimate Load
4000 PSI
2000 PSI
TENSION (LBS)
50 655
152 943
159 1078
154 1450
.....
.....
154 1043
207 1553
..... .....
105
694
SHEAR (LBS)
66
166
265
340
.....
739
1229
1665
2027
.....
200 1173
230 1636
..... .....
71
458
6000 PSI
TENSION (LBS) SHEAR (LBS) TENSION (LBS)
100 511
157 937
179 1043
209 1357
104 552
182 1342
267 1538
342 1712
.....
.....
.....
.....
.....
.....
.....
.....
SHEAR (LBS)
.....
.....
.....
.....
.....
.....
.....
.....
150
803
105
786
81
493
82
454
243
298
384
1307
1749
2126
175
218
391
1037
1471
1957
189
213
239
1125
1568
1886
210
305
594
1177
1780
2968
101
685
99
627
.....
.....
.....
.....
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance with ICC AC70
& ASTM E1190. Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Values
shown in concrete are for the fastener only. Connected members must be investigated separately. Note 5: Cyclic, fatigue, shock loads, and other design criteria
may require a different safety factor. Note 6: Job site testing may be required to determine actual job site values. Note 7: Minimum edge distance is 3 inches unless
otherwise approved. Note 8: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa
44
www.ramset.com
Performance/submittal
Fastener In Steel
PART
NUMBER
SERIES
SHANK
DIA
(INCH)
1500/
1600
0.145
SP
0.150
PART
NUMBER
SERIES
SHANK
DIA
(INCH)
1500/
1600
0.145
SP
0.150
TYPE OF
SHANK
INSTALLED IN A36 STRUCTURAL STEEL-STEEL THICKNESS (INCHES)
ALLOWABLE LOAD - Ultimate Load
3/16
1/4
SHEAR
(LBS)
TENSION
(LBS)
1/2
SHEAR
(LBS)
3/4
SHEAR
(LBS)
SMOOTH
81 790
373 2039
181 1269 273 1642 397 2169
KNURLED
296 1633
636 3516
584 3384 659 3822 680 3755
489 2771 243 1328 8 277 1514 8
730 4030 253 1459 8 293 1632 8
SMOOTH
385 2107
662 3618
445 2549 477 2736 393 2145
574 3137
TYPE OF
SHANK
TENSION
(LBS)
3/8
TENSION
(LBS)
TENSION
(LBS)
SHEAR
(LBS)
948 5180
597 3500
TENSION
(LBS)
SHEAR
(LBS)
..... .....
..... .....
..... .....
..... .....
8
234 1244 356 1895 8
INSTALLED IN A572 GRADE 50 STRUCTURAL STEEL-STEEL THICKNESS (INCHES)
ALLOWABLE LOAD - Ultimate Load
3/16
TENSION
(LBS)
1/4
SHEAR
(LBS)
TENSION
(LBS)
..... .....
..... .....
3/8
1/2
SHEAR
(LBS)
TENSION
(LBS)
SHEAR
(LBS)
..... .....
..... .....
..... .....
SMOOTH
..... .....
KNURLED
260 1609
499 3182 579 3411
725 4272 383 2216 7 595 3431 7
SMOOTH
356 2123
569 3394 554 3232
637 3710
604 3447
602 3437
TENSION
(LBS)
3/4
SHEAR
(LBS)
TENSION
(LBS)
SHEAR
(LBS)
..... .....
..... .....
..... .....
..... .....
..... .....
..... .....
..... .....
..... .....
814 4473 9 820 4503 9 243 1362 8 381 2141 8
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance with ICC AC70
& ASTM E1190. Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Cyclic,
fatigue, shock loads, and other design criteria may require a different safety factor. Note 5: Job site testing may be required to determine actual job site values.
Note 6: Values shown are for fastenings that have the entire pointed end of the fastener driven through the steel plate; except as noted below. Note 7: Fastener
penetration is 3/8" minimum. Note 8: Fastener penetration is 7/16" minimum. Note 9: Fastener penetration is 1/2" minimum Note 10: For SI: 1 lbf = 4.448 N, 1 inch
= 25.4 mm, 1 ksi = 6.89MPa
Fastener In Lightweight Concrete
PART
NUMBER SERIES
SHANK
DIAMETER
(INCH)
MINIMUM
PENETRATION
(INCH)
ALLOWABLE WORKING VALUES INSTALLED IN 3000 PSI LIGHTWEIGHT CONCRETE
ALLOWABLE LOAD - Ultimate Load
3000 PSI LIGHTWEIGHT W/DECKING
LOWER FLUTE TENSION
1500 SERIES
0.145
SP SERIES
.150/.180
3/4
1
1-1/4
1-1/2
1
1-1/4
1-1/2
76 395
134 668
157 784
233 1163
119 593
175 957
179 1055
LOWER FLUTE SHEAR
260
265
269
346
336
372
426
1409
1505
1344
1728
1679
1860
2128
3000 PSI LIGHTWEIGHT
TENSION
167
200
333
391
226
329
406
837
998
1664
1957
1129
1644
2030
SHEAR
179
228
400
410
250
377
380
894
1141
2090
2050
1249
1885
1900
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance with ICC AC70
& ASTM E1190. Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Values
shown in concrete are for the fastener only. Connected members must be investigated separately. Note 5: Cyclic, fatigue, shock loads, and other design criteria may
require a different safety factor. Note 6: Job site testing may be required to determine actual job site values. Note 7: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi
= 6.89MPa
www.ramset.com
45
Performance/submittal
Angle Clip In Concrete
PART
NUMBER
SERIES
SHANK
DIAMETER
(INCH)
INSTALLED IN STONE AGGREGATE CONCRETE
CONCRETE COMPRESSIVE STRENGTH
ALLOWABLE LAOD - Ultimate Load
4000 PSI
6000 PSI
MINIMUM
PENETRATION
(INCH)
TENSION (LBS)
SDC100
SDC125
SDC125
SPC78
SPC114
PART
NUMBER
SERIES
SDC100
SDC125
SDC125
SPC78
SPC114
SPC
SDC
SHEAR (LBS)
OBLIQUE (LBS)
TENSION (LBS)
SHEAR (LBS)
0.145
7/8
115
575
120
1014
145
726
.....
.....
.....
0.145
0.150
.150/.180
1-1/8
3/4
1-1/8
130
155
127
744
897
811
167
188
226
1090
1050
1130
205 1032
..... .....
181 904
.....
150
169
.....
788
853
..... .....
153 949
300 1500
SHANK
DIAMETER
(INCH)
MINIMUM
PENETRATION
(INCH)
0.145
7/8
0.145
0.150
.150/.180
1-1/8
3/4
1-1/8
LOWER FLUTE
TENSION (LBS)
67
.....
ALLOWABLE WORKING VALUES
INSTALLED IN 3000 PSI LIGHTWEIGHT CONCRETE
ALLOWABLE LOAD - Ultimate Load
3000 PSI LIGHTWEIGHT WITH METAL DECKING
LOWER FLUTE
LOWER FLUTE
UPPER FLUTE
SHEAR (LBS)
OBLIQUE (LBS)
TENSION (LBS)
335
237
1186
90
94 471
59 293
157 786
276
202
272
1378
1109
1358
119 596
65 323
153 766
104
448
OBLIQUE (LBS)
.....
.....
..... .....
140 769
223 1114
UPPER FLUTE
SHEAR (LBS)
571
310
1678
106 528
84 419
180 899
319
324
334
1597
1622
1673
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Testing conducted in accordance with ICC AC70
& ASTM E1190. Note 3: Safety factors are based on coefficient of variation. In accordance with ICC AC70, the safety factor will be no less than 5. Note 4: Values
shown in concrete are for the clip assembly only. Connected members must be investigated separately. Note 5: Cyclic, fatigue, shock loads, and other design
criteria may require a different safety factor. Note 6: Job site testing may be required to determine actual job site values. Note 7: Minimum edge distance is 3 inches
unless otherwise approved. Note 8: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa. Note 9: Metal deck is 20g.
LADD 652 Angle Clip Assmebly
PART
NUMBER
SERIES
SHANK
DIAMETER
(INCH)
ALLOWABLE WORKING VALUES INSTALLED IN STONE AGGREGATE CONCRETE
CONCRETE COMPRESSIVE STRENGTH
ALLOWABLE LOAD - Ultimate Load
3000 PSI
4000 PSI
MINIMUM
PENETRATION
(INCH)
TENSION (LBS)
LADD CEILING
SYSTEM
0.152
1-1/8
211
1688
SHEAR (LBS)
.....
.....
TENSION (LBS)
193
1544
SHEAR (LBS)
.....
.....
Note 1: ALLOWABLE loads are shown in the LARGE BOLD font, Ultimate loads are shown in smaller italic font. Note 2: Except as noted, values shown reflect an 8 to 1
safety factor. Note 3: Values shown are for concrete at the designed strength and are for the clip system only. Note 4: Cyclic, fatigue or shock loads and other design
criteria may require a different safety factor. Note 5: Job site testing may be required to determine actual job site values. Note 6: Edge distance is 3 inches unless
otherwise approved. Note 7: For SI: 1 lbf = 4.448 N, 1 inch = 25.4 mm, 1 ksi = 6.89MPa
46
www.ramset.com
LEED Credits
What is LEED?
The purpose of Leadership in Energy and Environmental Design (LEED) is to construct buildings in an energy efficient
manner and reduce the buildings’ energy consumption. As a result, these buildings can help conserve nonrenewable energy resources; decrease dependence on foreign oil; and lower greenhouse gas emissions.
Ramset LEED Credit EQ 4.1
EQ 4.1 was developed with the intent to reduce the quality of indoor air contaminants that are odorous, irritating, and/or
harmful to the comfort and well being of installers and occupants.
Ramset’s SC200 sound control sealant meets LEED EQ credit 4.1 for low emitting VOC materials and earns 1 LEED point.
Ramset LEED Credit MR 5.1
MR 5.1 was developed with the intent to increase
demand for building materials and products that are extracted
and manufactured within the region, thereby supporting the use of
indigenous resources and reducing the environmental impact resulting
from transportation.
Ramset’s pins, sealants, spring steel products, electrical accessories
and anchors may meet the requirements for LEED MR 5.1 if your
project falls within 500 miles of our manufacturing facilities.
Rockland, MA (02370)
Sealant
Addison, IL (60101) Spring Steel
Elk Grove Village, IL (60007) EZ Anchor
Itasca, IL (60143)Tapcon/GypFast & Fasteners
Michigan City, IN (46360)
Wedge Anchors
LDT Anchors
Paris, KY (40361)
Powder & Gas Fasteners
How to calculate LEED MR 5.1
LEED MR Credit 5.1 is calculated on a 500 mile radius from/to
distribution points. Use Google Maps to calculate the distance to
your project from:
Location
Zip Code Product
Addison, IL
60101
Elk Grove Village, IL
60007
Spring Steel
EZ Anchor
Itasca, IL
60143
Tapcon/GypFast & Fasteners
Michigan City, IN
46360
Wedge & LDT Anchors
Rockland, MA 02370
Sealant
Paris, KY
40361
Powder & Gas Fasteners
Recycling
Ramset Recycles
Ramset has always recognized the value of utilizing recycled materials
where available.
The raw material sourced for the manufacture of Ramset pins contains
approximately 10-20% mill scrap when it is converted to wire material. The plastic
and casing material in our loads typically consists of 10% recycled material.
Our packaging also contains post-consumer recycled material. The paper board
(inner cartons) containers are typically made from 40% recycled material;
corrugated cartons typically contain 30-35% recycled material.
Ramset has also instituted a recycling program at its Glendale Heights facility for
the batteries used in its gas powered tools.
www.ramset.com
47
Buy American Act
Dedicated to American Made Products
The American Recovery and Reinvestment Act of 2009 requires that all construction
materials for federal, state and local stimulus projects must be manufactured in the
United States.
Ramset is unique in the world of construction tools, fasteners and sealant manufacturing.
Overall, 98% of Ramset fasteners and accessories are made in the USA.
Unlike our competitors you know you are buying American made products and supporting
the American economy and workers when you buy Ramset. Ramset’s parent company,
Illinois Tool Works (NYSE: ITW) employees more than 25,000 Americans.
Manufacturer
Tools
Fasteners
Ramset Tools:
TrakFast
GypFast
T3SS
T3Mag
Rocket
Rocketmag
D45A
Glendale Heights, IL
Glendale Heights, IL
Glendale Heights, IL
Glendale Heights, IL
Glendale Heights, IL
Glendale Heights, IL
Glendale Heights, IL
Paris, KY
Paris, KY
Paris, KY
Paris, KY
Paris, KY
Paris, KY
Paris, KY
Ramset Manufacturing:
Powder Loads Manufacturing
Gas Fuel Cells Production
Sealant Manufacturing
Spring Steel Manufacturing
Wedge Anchors and LDT Anchors Manufacturing
Tapcon Manufacturing
EZ Anchor Manufacturing
T
AN AC
05
SEC. 16
d
steel, an
n,
iro
n,
in
uced
usion of
erican iro
(3) incl red goods prod se the
e of Am goods.
ea
tu
05—Us
SEC. 16 manufactured
manufac States will incr more
ted
d
d
by
propria
e Unite
project
steel, an
ap
l
th
s
al
er
nd
the fu
the ov
by
of
e
of
e
bl
st
la
on
co
(a) N
rcent.
ade avai a project
pe
m
e
25
is
l departthan
or otherw ay be used for
a Federa that it
tion,
m
es
e head of
n, altera
this Act
(c) If th ency determin plicanstructio ir of a public
co
ap
ag
e
e
or
th
th
for
repa
l
ment
aive
ance, or work unless al
d on a
ary to w
mainten
is necess ection (a) base ), the
or public d manufac(b
subs
n
of
tio
n
an
ec
building
e
tio
l,
n, stee
der subs
oject ar
agency
pr
un
iro
or
e
e
t
ng
th
th
in
of
findi
rtmen
ates.
ods used
the depa Federal Regis
tured go in the United St
head of
tion
h in the
t apply
justifica
l publis
n
al
no
produced
te
l
sh
al
rit
(a) sh
being
iled w
s
n
ta
is
se
tio
n
de
ca
ec
a
io
is
ter
(b) Subs
tegory of deral
the prov
se or ca
Fe
as to why
in any ca e head of the
ied in
th
volved
waived.
be appl
in which t or agency in
n shall
io
ct
en
se
United
departm
(d) This consistent with
aat—
r intern
ner
would
)
de
an
(a
m
un
finds th
n
a
ns
bsectio
ligatio
blic
ying su
States ob ements.
ith the pu
(1) appl
w
Rere
nt
ag
te
ica
mer n
nsis
tional
be inco
HR 1, “A t of 2009",
ed from
t Ac
;
vant
*Excerpt Reinvestmen
interest
1605
the rele
d
d
on
an
cti
an
ry
l,
Se
cove
stee
not
XVI,
(2) iron, red goods are
n A, Title
Divisio
ates in
tu
manufac in the United St ailable
av
produced and reasonably ory
t
ct
sufficien and of a satisfa
s
quantitie
or
quality;
MERIC
BUY A
Oxford, MS
Pontotoc, MS
Rockland, MA
Addison, IL
Michigan City, IN
Itasca, IL
Elk Grove Village, IL
The following is a sampling of government projects that have
utilized the Buy American Act using Ramset products:
48
•
Aberdeen Proving Grounds Project C4 (9 buildings)
•
Fort Belvoir Hospital (6 buildings)
•
Fort Bragg
•
Fort Detrick Department of Army Vacancies Serviced
•
Fort Meade (6 buildings)
•
National Maritime Intelligent Center
•
Norfolk Naval Base
www.ramset.com
Spring Steel Fasteners
Specifications
LOAD RATING
COATINGS
The fasteners within this catalog are
designed with two load limits:
Pre-Galvanized Zinc: This coating
of zinc is applied directly at the mills
by rolling the material through molten
zinc. Parts fabricated from this material
have exposed edges where the
material has been cut; but the zinc
near the uncoated metal becomes a
sacrificial anode to protect the bare
areas for a short period of time. These
parts are recommended for indoor use
in dry areas.
Static Load Limit is a rated stationary
load limit. The listed static load
capacity has a safety factor of three.
Ultimate Static Load is the rated
stationary load limit which, if exceeded,
may cause failure of the fastener.
Fasteners with no load ratings are to
be used for positioning only and not
supporting loads.
Load limits are for loads applied
VERTICALLY except as may be
diagrammed otherwise. The load
capacity of a fastener having more than
one component is equal to the load
capacity of the lower rated component.
MATERIALS
Steel: We specify commercial quality
(CQ) hot rolled pickled and oil (HRPO)
or cold rolled (CR) steel for our parts
where a specific material specification
is not needed.
Spring Steel: We specify a high
carbon, cold rolled, annealed, spring
steel for all Black Claw™ products.
Zinc Plated or Electro-Galvanized:
We have our parts plated after
fabrication to commercial quality
standards, and recommend them for
indoor, relatively dry environments.
Zinc plating is the process by which a
coating of zinc is deposited on the steel
by electrolysis from a bath of zinc salts.
A maximum of .5 mills of zinc can be
applied by this method.
Phosphate and Oil: We have most
of our high carbon spring steel
parts (Black Claw™) coated with
this process after fabrication and
heat-treating. The process applies a
base of crystalline zinc phosphate of
1000 milligrams a square foot and
then a synthetic organic corrosion
inhibitor with a particular infinity for
zinc compounds. These parts are
recommended for indoor, non-corrosive
environments.
Technical Support: 1.800.241.5640
Conduit / Cable Support
Vertical
Vertical
Vertical
Wire
or
Rod
Wire
oror
Rod
Wire
Rod
Vertical
Vertical
Vertical
Flange
Flange
Flange
25lbs
25
LBS
2525
LBS
LBS
Horizontal
Horizontal
Horizontal
Flange
Flange
Flange
50lbs
50
LBS
50
LBS
50
LBS
100lbs
100
LBS
100
100
LBS
LBS
• Supports conduit and all
types of cable from rods
or flanges
• Note: FSBX bat wings are
designed for positioning
only; no load rating
Description FSBX
FS1
FS2
FS3
FS4
bat wing support clip MC, AC OR BX and #12 to #8 wire 1/2" bat wing
3/4" bat wing
1" bat wing
1 1/4" bat wing
Pkg Qty
Ramset #
Description APS
fits 1/8" to 3/8" flanges threaded for 1/4"–20
Ramset #
Description 100
100
100
100
100
FXBX
FS2
• Attaches conduit or boxes to flanges, wire or rod
• Fits 1/8" to 3/8" flanges; attaches to #12 wire
through 3/8" rod; attaches #10–24 or 1/4"–20
Threaded Bridle Rings (position only)
50 LBS
Ramset #
25lbs
50lbs
25 LBS
50 LBS
Pkg Qty
100
25 LBS
• Attaches conduit to flanges, wire or rod
Pkg Qty
APSKC1234 latching conduit clamp 1/2"–3/4"
• Available both non-keyholed and keyholed for
1/4"–20 screw
• Ultimate static load limit: 100lbs vertical;
25lbs horizontal
KC1234T
25lbs
25
25LBS
LBS
Lbs
1515
Lbs
Ramset #
Description KC38
KC1234
KC1234T
3/8" conduit clamp with thread impression for 1/4"–20 stud
1/2" and 3/4" conduit clamp
1/2" and 3/4" conduit clamp with thread impression for 1/4"–20 stud
Pkg Qty
• No fastener required
Holding values are for accessories and do not include anchoring method.
• Available both non-keyholed and keyholed for
1/4"–20 screw
Ramset #
Description HIC50
HIC75
1/2" snap into place EMT
3/4" snap into place EMT
100
100
100
100lbs
100
100LBS
LBS
HIC75
15lbs
100
Pkg Qty
100
100
• Ultimate static load limit: 25lbs vertical; 15lbs
horizontal
Holding values are for accessories and do not include anchoring method.
• No fastener required
Ramset #
Description • Designed to quickly secure one conduit run
to another
HIC7575
3/4" to 3/4" conduit
25lbs
25 25
LbsLbs
Pkg Qty
100
• Ultimate Static Load Limit: 25lbs
• Note: Top conduit to be used for support only, not a
raceway
50
www.ramset.com
Conduit / Cable Support
Side Mount Flange Push Clip
SFC1875
15lbs
Ramset #
Description
SFC1875
SFC18100
3/4" conduit side mount for 1/8" to 1/4" flange
1" conduit side mount for 1/8" to 1/4" flange
Static Load Pkg Qty
15lbs
15lbs
100
100
15 Lbs
• Suspends conduit from bottom of beam
• Will pivot 360 degrees
• Installs with hammer only
Side Mount Flange Latch Clip
SFC516KC1
25lbs
25 LBS
• Suspends conduit from side of beam
• Will pivot 360 degrees
• Installs with hammer only
Ramset #
Description
SFC18KC1234
SFC18KC1
SFC18KC114
SFC18KC2
SFC516KC1234
SFC516KC1
SFC516KC114
SFC516KC112
SFC916KC38
SFC916KC1234
SFC916KC1
1/2" to 3/4" conduit side mount for 1/8" to 1/4" flange
1" conduit side mount for 1/8" to 1/4" flange
1 1/4" conduit side mount for 1/8" to 1/4" flange
2" conduit side mount for 1/8" to 1/4" flange
1/2" to 3/4" conduit side mount for 5/16" to 1/2" flange
1" conduit side mount for 5/16" to 1/2" flange
1 1/4" conduit side mount for 5/16" to 1/2" flange
1 1/2" conduit side mount for 5/16" to 1/2" flange
3/8" conduit side mount for 9/16" to 3/4" flange
1/2" to 3/4" conduit side mount for 9/16" to 3/4" flange
1" conduit side mount for 9/16" to 3/4" flange
Static Load Pkg Qty
25lbs
25lbs
25lbs
25lbs
25lbs
25lbs
25lbs
25lbs
25lbs
25lbs
25lbs
100
100
100
100
100
100
100
100
100
100
100
Holding values are for accessories and do not include anchoring method.
Bottom Flange Push Clip
BC1875
25lbs
25 Lbs
Ramset #
Description
BC1850
BC1875
1/2" conduit bottom mount for 1/8" to 1/4" flange
3/4" conduit bottom mount for 1/8" to 1/4" flange
Static Load Pkg Qty
25lbs
25lbs 100
100
Holding values are for accessories and do not include anchoring method.
• Suspends conduit from bottom of beam
• Will pivot 360 degrees
• Installs with hammer only
Bottom Flange Latch Clip
75lbs
BC516KC1
75 LBS
• Suspends conduit from bottom of beam
• Will pivot 360 degrees
• Installs with hammer only
Ramset #
Description
BC18KC38
BC18KC1234
BC18KC1
BC18KC114
BC516KC38 BC516KC1234
BC516KC1
BC516KC114
BC516KC112
BC516KC2 BC916KC38
BC916KC1234
3/8" conduit bottom mount for 1/8" to 1/4" flange
1/2" to 3/4" conduit bottom mount for 1/8" to 1/4" flange
1" conduit bottom mount for 1/8" to 1/4" flange
1 1/4" conduit bottom mount for 1/8" to 1/4" flange
3/8" conduit bottom mount for 5/16" to 1/2" flange
1/2" to 3/4" conduit bottom mount for 5/16" to 1/2" flange
1" conduit bottom mount for 5/16" to 1/2" flange
1 1/4" conduit bottom mount for 5/16" to 1/2" flange
1 1/2" conduit bottom mount for 5/16" to 1/2" flange
2" conduit bottom mount for 5/16" to 1/2" flange
3/8" conduit bottom mount for 9/16" to 3/4" flange
1/2" to 3/4" conduit bottom mount for 9/16" to 3/4" flange
Static Load Pkg Qty
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
75lbs
100
100
100
100
100
100
100
100
100
100
100
100
Holding values are for accessories and do not include anchoring method.
CBS18KC1234
CBS18KC1234
Ramset #
Description
CBS18KC1234
CBS18KC1234ST
CBS18KC38
conduit box support for 1/2"-3/4" conduit, has “star" hole for 1/4"–20
conduit box support for 1/2"-3/4" conduit with 1/4"–20 stud
conduit box support for 3/8" conduit with 1/4"–20 stud
Pkg Qty
25
25
25
• Secures conduit and electrical boxes to most structures
• Provides conduit support on both sides of electrical box
• With hole for screw or threaded rod mount or with 1/4"–20 x 5/8" stud
www.ramset.com
51
Beam/ Purlin
• Fast installation; fits beam flange to 1/2"
Ramset # Description
• Used with 1/4" and 3/8" threaded rod, "S" hooks,
conduit hangers, electrical boxes, and #10–24 or 1/4"20 bridle rings
500
Pkg Qty
beam clamp up to 1/2" flange – 1/4" to 3/8" threaded rod
100
• Static load capacity: 100lbs
• Used with conduit hangers #0 to #5, bridle rings
and threaded rod
600
• Case hardened steel set screw tapped at an
angle, locks on beam
Ramset #
Description
600
602
602B
1/2" universal beam clamp 1/4"–20 50
3/4" universal beam clamp – 3/8" bottom only 25
3/4" universal beam clamp 3/8"–16 flange; 3/8" rod 25
Pkg Qty
• Zinc plated steel or stainless steel
• Used with conduit hangers, bridle rings and
drop rods, 3/8" to 1/2"
• Tapped for rods bottom and back on all sizes
700
• Malleable zinc plated steel
Ramset # Description
700
701
702
703
• Can be used to suspend boxes, fixtures
and bridle rings to beam flanges 1/8" to
3/4" thick
• Beam clamp with 1.4"–20 x 3/8" staked
stud used to suspend box from bottom of
beam
BC18
75lbs
BC18ST
75 Lbs
100lbs
100 Lbs
• Ultimate static load limit: 75lbs or 100lbs
Pkg Qty
1/2" flange malleable beam clamp for 1/4"–20; tapped bottom and back
3/4" flange malleable beam clamp for 5/16"–18
3/4" flange malleable beam clamp for 3/8"–16
7/8" flange malleable beam clamp for 1/2"–13
Ramset # Description BC18
BC18ST
BC516
BC516ST
BC916
50
25
25
25
Pkg Qty
1/8" to 1/4" flange beam clamp with 1/4"–20 thread
1/8" to 1/4" flange with 1/4"–20 x 3/8" staked stud
5/16" to 1/2" flange beam clamp with 1/4"–20 thread
5/16" to 1/2" flange with 1/4" to 20 x 3/8" staked stud
9/16" to 3/4" flange beam clamp with 1/4"–20 thread
100
100
100
100
100
Holding values are for accessories and do not include anchoring method.
• Note: static load limits cannot be combined
• Offered with or without nut and bolt attached
Ramset #
Description
• Zinc plated steel
A0600B
A1600B
A2600B
1/2" EMT, 3/8" to 1/2" Rigid, beam clamp to conduit hanger
3/4" EMT, 3/4" Rigid, beam clamp to conduit hanger
1" EMT, 1" Rigid, beam clamp to conduit hanger
Pkg Qty
100
100
100
A0600B
• Static load capacity: 100lbs vertical, 25lbs horizontal
Ramset #
Description
500KC1234
500KC1234B
Pkg Qty
1/2" and 3/4" beam clamp to conduit – vertical 1/2" and 3/4" beam clamp to conduit – horizontal
100
100
500KC1234
• Installed with hammer on bulb tees and beams with
static load capacity of 200lbs
• Clearance for 1/4" bolt in tab
SFC18
• Installed without power tools
• Compensates for angle of purlin
• Static load capacity: 100lbs
PH
PH14T
52
Ramset #
Description
SFC18
SFC516
SFC916
1/8" to 1/4" flange beam clamp
5/16" to 1/2" flange beam clamp
9/16" to 3/4" flange beam clamp
Ramset #
PH
PH14T
PH38T
PKC1234
Pkg Qty
Description 100
100
100
Pkg Qty
Z-Purlin with 1/4" bottom hole
Z-Purlin for 1/4" threaded rod
Z-Purlin for 3/8" threaded rod
1/2" or 3/4" conduit to Z-Purlin
100
100
100
100
PKC1234
www.ramset.com
Beam/ Purlin
• Fits 1/16" to 1/4" vertical flanges
Ramset #
• Accommodates tooling for floor installations
L1701 (J-Clip)
• Fast easy attachment of pre-tied hanger wire from Z-Purlins
Ramset #
Description • Fits 1/16" to 1/4" thick Z-Purlin
L1801 (Clip-Pur)
1/16" to 1/4" angled Z-Purlin
Description 1/16" to 1/4" for vertical flange
Pkg Qty
100
Pkg Qty
300
• 217lbs allowable working load
• Works with L1701 and L1801
Ramset #
• For strong, reliable attachment of hanger wire from open web bar
joists or purlins
L-1700
Description Pkg Qty
J-Master installation tool
1
• Threads easily into any 1/2" threaded pipe— no hammering,
punching holes or wrapping wire
• Two magnetized strips included
• Fast, easy installation from floor level, no ladders or scaffolding necessary
• Suspends #12, #10, #9 or #8 wire, 1/4" or 3/8"
plain or threaded rod from vertical flanges (FH)
Ramset #
Description FH116
FH532
RF53214T
RF53238T
1/16" to 5/16" vertical flange
5/32" to 1/4" vertical flange
5/32" to 1/4" vertical flange for #8 wire or 1/4" threaded rod
5/32" to 1/4 vertical flange for 3/8" threaded rod
• Suspends 1/4" or 3/8" threaded rod from vertical
flanges 1/16" to 1/4" thick (RF)
FH116
• Static load capacity: 160lbs (RF)
Pkg Qty
100
100
100
100
RF53214T
ABC25
ABC25
www.ramset.com
VBC25
• Fits 1/16" to 1/4" thick
Z-Purlin (ABC25) or vertical
flanges (VBC25)
Ramset #
Description ABC25
VBC25
1/16"-1/4" for angled flange (Z purlin) for S-hooks, perf. strap & wire
1/16-1/4" for vert flange for S-hooks, perforated strap & wire
• Accommodates tooling for
floor installations
Works with Caddy® VAFT or Ramset L1700 installation tools.
Pkg Qty
100
100
53
Metal Stud Support
• Supports electrical boxes located between studs on 16" or 24"
centers; boxes attach using self-tapping screws
• Made from pre-galvanized steel
BMB16
• Designed to secure horizontal runs of Rigid, IMT, AC,
MC, BX, or PVC through metal studs
BAKC1234
Ramset # Description BMB16
BMB16D
BMB24
BMB24D
Pkg Qty
1 1/2" box mounting bracket – 16" centers
2 1/2" box mounting bracket – 16" centers
1 1/2" box mounting bracket – 24" centers
2 1/2" box mounting bracket – 24" centers
Ramset # Description 50
50
50
50
Pkg Qty
BAKC1234 1/2", 3/4" latching conduit support thru metal studs 100
BA75
1/2", 3/4" push conduit support thru metal studs
100
BA75
• Conduit to stud fastener
Ramset # Description Pkg Qty
• Designed to quickly secure horizontal runs of Rigid, EMT, AC, MC,
BX, or PVC to metal studs
SBKC1234
SBKC1
SB75
SB100
• Flexible conduit/cable fastener
Ramset # Description • Push clip attaches BX, MC or AC cable to metal studs
BXC
• Installed using a hammer only
Ramset # Description • Secures boxes to most metal studs
S1900
• Screw attached support for box and conduit
Ramset # Description • For use with either metal or wood studs
SS
• Screw attached support for electrical boxes
Ramset # Description Pkg Qty
FBO23
FBO234
FBO6
100
100
100
SBKC1234
1/2" or 3/4" conduit to metal stud
1" conduit to metal stud
3/4" conduit, 1/2" rigid to metal stud
1" conduit, 3/4" rigid to metal stud
100
100
100
100
SB75
• Made from pre-galvanized steel
FBO234
• Clips on electrical boxes for additional support
SBS
100
Pkg Qty
hammer-on electrical box support to stud
100
Pkg Qty
4" box stud support clip used with self-tapping screws 100
box support for 2 1/2" and 3 1/2" studs
box support for 4" studs
box support for 6" studs
Ramset # Description SBS
SBS3.5
SBS6
SBS3.5
Pkg Qty
MC, AC, or BX to metal stud
Pkg Qty
2 1/2" to 4" box support premarked: bendable
3 1/2" far side box support
6" far side box support
• Bracket supports electrical boxes from floor or channels
Ramset # Description • Can be used at three heights
BS18
floor mounted - box support
100
100
100
Pkg Qty
50
• Made from pre-galvanized steel
54
www.ramset.com
Metal Stud Support
• No tools required
• Mounts quickly in the back of the box–just push in
and snap tight
Ramset # Description DLS1
push-in far side box support – for various stud wall depths
Pkg Qty
100
• Designed for 3 5/8" steel studs
• May be used on standard 1 1/2" or 2 1/8" deep boxes
• Protects wires from damage by metal studs
Ramset # Description • All pieces are the same shape, eliminating the hassle of
stocking right and left grommet parts
G100
grommets for metal studs
Pkg Qty
100 pr
• Easy to install. No tools required
• Complies with 2002 NEC Article 300.4(1)
• Quick installation
Ramset # Description Pkg Qty
• One-piece break-away design
BST
100 sets
secures electrical box to finished drywall
• Box is supported by drywall—no stud is necessary
• Prevents box from pulling out of drywall
• Made from pre-galvanized steel
• Mounts standard outlets and wall switches in oversize openings,
lending stability and preventing broken cover plates
Ramset # Description OR
mounts standard outlets in oversize openings
Pkg Qty
100
• Made from pre-galvanized steel
Strut Clamps
• Universal pipe clamp
Ramset # Description • Same pipe fits EMT, GRC/IMC & standard piping
MSU050EG 1/2" universal pipe clamp
100
• Parts are made on punch press dies from hot rolled, pickled and
oiled steel which conforms to the ASTMA-366, A-575 and A-576
standards
MSU075EG 3/4" universal pipe clamp
100
MSU100EG 1" universal pipe clamp
100
MSU125EG 1 1/4" universal pipe clamp
100
• Parts are zinc plated after fabrication
MSU150EG 1 1/2" universal pipe clamp
50
MSU200EG 2" universal pipe clamp
50
MSU250EG 2 1/2" universal pipe clamp
50
MSU300EG 3" universal pipe clamp
50
MSU350EG 3 1/2" universal pipe clamp
25
MSU400EG 4" universal pipe clamp
25
• Zinc plated nut and bolt included with each part
www.ramset.com
Pkg Qty
55
Rod Hangers
RA14
RA14T
R1814
RA14
• Suspends #8 wire, 1/4" and 3/8" plain or threaded rod
from overhead mountings with a clearance hole for
1/4" bolt
Ramset # Description #8 wire or 1/4" plain rod – side mount
100
RA38
3/8" plain rod
100
• Static load capacity: not to exceed 160lbs
RA14
#8 wire or 1/4" plain rod – bottom mount
100
• Hangers made from high carbon steel; zinc phosphate
and oil finish; angle bracket made from pre-galvanized
steel
RA38T
3/8" threaded rod with thread impression – bottom mount
100
RA14T
1/4" threaded rod with thread impression – bottom mount
100
• Suspends #8 wire (RA14 only), 1/4" and 3/8" plain rod
from overhead mountings with a clearance hole for 1/4"
bolt
Ramset # Description • Static load capacity: not to exceed 160lbs
• Static Load Capacity for R51614 & R91614 not to exceed
200lbs
R1814T
Pkg Qty
RO14
• No nut required
R1814
R51614
R91614
R1814T
R1838T
R51614T
R51638T
Pkg Qty
1/8" to 1/4" flange for #8 wire or 1/4" plain rod
5/16" to 1/2" flange for 1/4" plain rod
9/16" to 3/4" flange for 1/4" plain rod 1/8" to 1/4" flange for 1/4" threaded rod
1/8" to 1/4" flange for 3/8" threaded rod
5/16" to 1/2" flange for 1/4" threaded rod
5/16" to 1/2" flange for 3/8" threaded rod
100
100
100
100
100
100
100
• Suspends strapping thru 1" wide from beam flanges
1/8" to 3/4" thick, parallel or at right angles to beam
Ramset # Description PSF18
1/8" to 1/4" strap hanger
100
• Static load capacity: 200lbs
PSF516
5/16" to 1/2" strap hanger
100
PSF916
9/16" to 3/4" strap hanger
100
PSF18R
1/8" to 1/4" twisted strap hanger
100
PSF516R
5/16" to 1/2" twisted strap hanger
100
PSF916R
9/16" to 3/4" twisted strap hanger
100
PSF18
Pkg Qty
Acoustical
• Top mounted acoustical T-bar fastener
Ramset # Description • Riveted assembly fits 3/8" to 1" conduit
TBKC1234 1/2", 3/4" T-bar fastener conduit clamp – top
Pkg Qty
100
• Supports boxes and conduit above T-bar
• Clip-on positive support for troffers and lay-in fixtures
Ramset # Description • Complies with NEC Article 410-16 means of support
FT
Pkg Qty
lay in and troffer light fixture support clips for acoustical support
100
• Fits round or rectangular head T-bars
• Supports electrical fixtures to T-bar 15/16" wide
Ramset # Description • Assembled with 1" OD wing nut washer
SCT3
Pkg Qty
twist-on T-Bar hanger with 1/4"–20 x 5/8" stud with washer
100
• 1/4"–20 stud 5/8" long
• Box to T-Bar fastener • Works with BBC
Ramset # Description • Snap-on 24" span box hanger with dual height
adjustment allows flush or 3/4" offset mount
TBAR
box to T-Bar snap-on fixture with 24" span
Pkg Qty
50
• Zinc plated steel with Black Claw™ spring steel
hardware included
56
• Attaches 1-1/2" lathers channel to #8 wire and 1/4"
plain rod
Ramset # Description • No installation tools required
Not for use in plaster applications
LC112
lathers channel hanger
Pkg Qty
50
www.ramset.com
Low-Voltage
648RS
• Cost effective alternative to cable tray
Ramset # Description • Wide surface saddle provides support without stress for
category 5, fiber-optic, and other
sensitive voice/datacom cables
646RS
1 1/2" bridle ring with 1/4"–20 thread with saddle
50
648RS
2" bridle ring with 1/4"–20 thread with saddle
50
654RS
4" bridle ring with 1/4"–20 thread with saddle
50
Pkg Qty
• Available as assembled units or saddle only for retrofit
• Saddle molded onto 4" bridle ring
648R
• Supports communications cable and other low voltage
uses
Ramset # Description 646R
1 1/2" bridle ring with 1/4"–20 thread
100
• Used with beam clamps
648R
2" bridle ring with 1/4"–20 thread
100
Pkg Qty
• Zinc plated steel
• Provides base for securing communications lines without
use of electrical box
Ramset # Description WBF1
Pkg Qty
low voltage mounting bracket
100
• Mounts standard plate
• Hardware included
Ramset #
Description • Cost effective alternative to expensive cable tray
J200
2" J-Hook
50
• Accommodates category 5, fiber-optic and interduct
J200500
2" J-Hook
50
• Provides support without stress to sensitive voice/data cables
J200B500
2" J-Hook
50
J200600
2" J-Hook
50
J200B600
2" J-Hook
50
J200SFC18
2" J-Hook
50
• Cable wire retainer is supplied with every part
J200BBC18
2" J-Hook
50
• Unique design eliminates the need for attachment plate when stacking
J200APS
2" J-Hook
50
J200ABC25
2" J-Hook
50
J200VBC25
2" J-Hook
50
• Continuous wide-base radius supports natural curve of cable,
eliminating kinking and bending
J200APS
J200B600
• Holds up to 80 category 5E and 50 category 6 strands
J200ABC25
Pkg Qty
The versatile J-Hook System can come preassembled with Beam Clamps, Bat Wings,
Hammer-On Flange and Purlin Clips.
J200VBC25
J200SFC18
J200BBC18
J200600
J200B500
J200
J200500
• Made from pre-galvanized steel
Hardware Accessories
BBC
1202CF
www.ramset.com
72013
• Box to bar fastener (BBC)
Ramset # Description • T-Bar mounting and retaining clips (BBC)
BBC
T-bar box mounting clip with screw
100
• Zinc plated steel (BA)
1202CF
angle bracket 1/4" mounting hole
100
72013
#12 Jack Chain – per 100’
Pkg Qty
1
57
B-Line
Ramset
Alpha-numeric according to B-line part numbers
B-Line #
Ramset #
Ramset #
B-Line #
Ramset #
TBAR
BG24E58
SFC516KC112
BH7
1202CF
BA15
FT
BG24U58
BC516KC112
BH9
72013
BA416
SCT3
BG32E58
SFC18KC2
BH912
PSF916
BB1
SS
BG6
KC38
BH912R
PSF916R
BB10
WBF1
BG6E912
SFC916KC38
BL1400C442
A0600B
BB116D
BMB16D
BG6S18
CBS18KC38
BL1410C442
A1600B
BB18
BS18
BG6U24
BC18KC38
BL1420C442
A2600B
BB18
BS18
BG6U58
BC516KC38
BM1
G100
BB216
BMB16
BG6U912
BC916KC38
BP12
HIC75
BB224
BMB24
BG812
KC1234
BP12B5
SB75
BB224D
BMB24D
BG8124T
KC1234T
BP12E24 SFC1875
BB27
BBC
BG812A6
TBKC1234
BP12H7
BA75
BB32
OR
BG812B5
SBKC1234
BP12P12
HIC7575
BB33
BST
BG812C1
500KC1234B
BP12U24
BC1875
BB423
FBO23
BG812C2
500KC1234
BP16B5
SB100
BB44
FBO234
BG812E24 SFC18KC1234
BP16E24 SFC18100
BB46
FBO6
BG812E58 SFC516KC1234
BP8
HIC50
BB7
DLS1
BG812E58 SFC916KC1234
BP8U24
BC1850
BB7
SBS
BG812F13
PKC1234
BPC12
MSU075EG
BB9
S1900
BG812H7
BAKC1234
BPC16
MSU100EG
BC1
500
BG812S18
CBS18KC1234
BPC20
MSU125EG
BC442
600
BG812S18S
CBS18KC1234ST
BPC24
MSU150EG
BC4426
602
BG812U24
BC18KC1234
BPC32
MSU200EG
BC4426
602B
BG812U58 BC516KC1234
BPC40
MSU250EG
BCH32
J200
BG812U912
BC916KC1234
BPC48
MSU300EG
BE24
SFC18
BG812W2
APSKC1234
BPC56
MSU350EG
BE58
SFC516
BGU3258
BC516KC2
BPC64
MSU400EG
BE912
SFC916
BH1E24
R1814
BPC8
MSU050EG
BF1
FH116
BH1E58
R51614
BR204T
646R
BF12
PH
BH1E912
R91614
BR324T
648R
BF156
SBS3.5
BH1H7
RA14
BR32A
648RS
BF196
SBS6
BH1H8
RO14
BRS32
BR2S
BF2
FH532
BH24
PSF18
BRS64A
654RS
BF3
L1701**
BH24R
PSF18R
BU24
BC18
BF3
VBC25*
BH2H7
RA38
BU24S
BC18ST
BF4
ABC25*
BH4E24
R1814T
BU58
BC516
BF4
L1801**
BH4E58
R51614T
BU58S
BC516ST
BG16B5
SBKC1
BH4F12
PH14T
BU912
BC916
BG16E24
SFC18KC1
BH4F2
RF53214T
BW12
FS2
BG16E58
SFC516KC1
BH4H7
RA14T
BW16
FS3
BG16E912
SFC916KC1
BH58
PSF516
BW2
APS
BG16U24
BC18KC1
BH58R
PSF516R
BW20
FS4
BG16U58
BC516KC1
BH6E24
R1838T
BW4
FSBX
BG20E24
SFC18KC114
BH6E58
R51638T
BW8
FS1
BG20E58
SFC516KC114
BH6EH7
RA38T
BX9
BXC
BG20U24
BC18KC114
BH6F12
PH38T
BG20U58
BC516KC114
BH6F2
RF53238T
* Works with Caddy® VAFT or Ramset L1700
58
B-Line #
BA12
Part Number reference
**Works with Ramset L1700
www.ramset.com
®
Part Number reference
Alpha-numeric according to Caddy ® part numbers
CADDY® #
Ramset #
Ramset
CADDY® #
CADDY® #
Ramset #
Ramset #
122
PH
6MB18A
CBS18KC38
H4
FBO234
1224TI
PH14T
6TI24
R1838T
H6
FBO6
1226TI
PH38T
6TI58
R51638T
J1A35
SBS
123812M
PKC1234
6TIB
RA38T
J1A6
SBS6
12P
HIC75
70824
R1814
K12
FS2
12P12P
HIC7575
70858
R51614
K16
FS3
12P24
BC1875
708912
R91614
K20
FS4
12P24SM
SFC1875
708AB
RA14
K8
FS1
12PF
SB75
708AO
RO14
KX
FSBX
16M24
BC18KC1
766
SBS3.5
M24
BC18
16M24SM
SFC18KC1
766A
DLS1
M24S
BC18ST
16M58
BC516KC1
770
72013
M58
BC516
16M58SM
SFC516KC1
812M
KC1234
M58S
BC516ST
16M912SM
SFC916KC1
812M24
BC18KC1234
M912
BC916
16MF
SBKC1
812M24SM
SFC18KC1234
MPLS
WBF1
16P24SM
SFC18100
812M4I
KC1234T
MSF
S1900
16PF
SB100
812M58
BC516KC1234
MSR24
PSF18R
20M24
BC18KC114
812M58SM
SFC516KC1234
MSR58
PSF516R
20M24SM
SFC18KC114
812M912
BC916KC1234
MSR912
PSF916R
20M58
BC516KC114
812M912SM
SFC916KC1234
MSS24
PSF18
20M58SM
SFC516KC114
812MATA
TBKC1234
MSS58
PSF516
24M58
BC516KC112
812MB18A
CBS18KC1234
MSS912
PSF916
24M58SM
SFC516KC112
812MB18S
CBS18KC1234ST
RLC
OR
32M24SM
SFC18KC2
812MF
SBKC1234
SGB16A
BMB16
32M58
BC516KC2
8P
HIC50
SGB16A
BMB16D
350
SS
8P24
BC1850
SGB24A
BMB24
449
BXC
AB
1202CF
SGB24A
BMB24D
4BRT20
646R
AF14
ABC25*
SK125I
MSU075EG
4BRT32
648R
AF14
L1801**
SK165I
MSU100EG
4BRT32WS
648RS
BC
500
SK205I
MSU125EG
4G8, 4G16
SCT3
BC200
600
SK245I
MSU150EG
4H24
SFC18
BC200 CD0B
A0600B
SK325I
MSU200EG
4H58
SFC516
BC200 CD1B
A1600B
SK405I
MSU250EG
4H912
SFC916
BC200 CD2B
A2600B
SK485I
MSU300EG
4TI24
R1814T
BC400
602B
SK565I
MSU350EG
4TI58
R51614T
BC812M
500KC1234
SK645I
MSU400EG
4TIB
RA14T
BC812MSM
500KC1234B
SK85I
MSU050EG
4Z34
APS
BHC
BBC
VAFT
L1700
4Z34812M
APSKC1234
CAT32
J200
VF14
FH116
512
TBAR
DS12A
BST
VF14
FH532
515(A)
FT
ESG1
G100
VF14
L1701**
6AB
RA38
FB12P
BA75
VF14
VBC25*
6M
KC38
FB812M
BAKC1234
VF144T1
RF53214T
6M24
BC18KC38
FBS12
BS18
VF146T1
RF53238T
6M58
BC516KC38
FBS16
BS18
6M912
BC916KC38
FBS18
BS18
6M912SM
SFC916KC38
H23
FBO23
* Works with Caddy® VAFT or Ramset L1700
www.ramset.com
Caddy
**Works with Ramset L1700
CADDY ® is the registered trademark of ERICO International Corporation
59
Suspended Anchoring Systems
Specifications
Engineering Note
In 1996, the anchors listed by UL were tested in plate steel
that measured .188” and .118”. Subsequent testing was
done for z-purlin applications in May 1997 using (.037”) or
20 gauge steel. Most recently in 2008, testing with the new
Sammy X-Press® was completed using (.030”) or 22 gauge
steel metal deck.
Sammys® Nut Drivers
Special nut drivers were designed to be used with Sammys.
When the appropriate nut drivers are used for installation,
the driver spins freely on the screw after installation is
complete and eliminates the expected wrist snap, reduces
over-torque, and prevents screw failure.
Metric Products
Metric versions of the Sammy anchors are available at
www.itwbuildex.com
Sammys for Seismic
Please visit www.itwbuildex.com for our current Seismic
product offering.
Vibratory Environments
For attaching or anchoring in high vibratory environments,
special care should be taken not just for building
attachments but also for the hangers or assemblies being
supported. Consult local code authorities for accepted
anchoring devices.
Composite Joist/Truss
Truss manufacturers vary installation recommendations for
composite joist. UL testing was completed to validate that
Sammys and Sidewinders SWG 20 and SWG 25-380 can
be installed into the top cord of a truss. Sammy GST 20 can
be installed into the center of the lower cord of a composite
joist. Penetration of the upright center web is permitted by
some joist manufacturers. Consult truss manufacturer for
recommended installation point.
Pre-drilling may be required by joist manufacturers. If
so, pre-drill pilot hole 1/8” smaller than root diameter of
fastener.
Consult the table below:
Model
Root Diameter
Hole Size
GST 20
.182
1/8”
GST 25-380
.280
7/32”
SWG 20
.182
1/8”
SWG 25-380
.280
7/32”
To increase efficiency of the installation process, sleeve
tools, bit receivers, and wood bits are available for predrilling.
NFPA/NEC Standards
All UL and FM testing complies with NFPA 13 and NEC
standards. Check with your local (AHJ) Authority Having
Jurisdiction to confirm application and usage.
UL Listings / FM Approvals
UL and FM reports are available at
www.itwbuildex.com
Warranty • Disclaimer of Warranty
Proper fastener connection design takes into account
where and how fasteners are used. Allowance for special
characteristics in materials, differences in materials,
differences in types of materials being joined, unique or
unusual environmental service or installation conditions and
the safety factors required by anticipating normal or short
term loading conditions must be considered. Due to possible
differences in specifications, applications, and interpretation
of results, purchasers and specifiers must make their own
evaluation of the products, to determine the suitability of these
products for intended use. All warranties of Buildex products
will be honored through Ramset. All warranties of Buildex
products, expressed or implied, including the
warranties of merchantability and fitness
for particular purposes are specifically
excluded except for the following:
Buildex will repair or replace any
product which, within twelve
months after sale by Buildex
or its distributors, is found by
Buildex to be defective in
material or workmanship
- normal wear and tear
accepted. This is the sole
warranty of Buildex and the
sole remedy available to
distributor or buyer. Buildex
shall not be liable for any
injury, loss or damage, direct,
indirect, or consequential,
arising out of the use of, or
the inability to use, any Buildex
product.
®
SAMMYS for Wood
Installs VERTICALLY into the bottom of wood structures easily and quickly!
Not less than
2" nominal width
(1-1/2")
Wood Flooring
Product Features
• No pre-drilling required.
Not less than
3" nominal
thickness (2-1/2")
(depth or side
of vertical member)
For vertical use install in center of lower face.
• Quick to install using the Sammy
Nut Driver with an 18V cordless
drill/driver.
Wood Joist
• Saves time from traditional
methods.
Double Sheetrock
Ceiling
• Reduces installation cost.
Minimum 2" embedment into base
material for NFPA 13 compliance.
Composite / Truss
• Made in the U.S.A.
Consult truss manufacturer for
recommended installation point.
*Pre-drilling may be required for GST
25-380 . Tool available on page 10.
Rod
Size
Part Number
Description
Ultimate
Pullout (lbs)
Qty
Nut Driver
1/4"
GST 100
1" SAMMY for WOOD 1/4" ROD
210 (7/16" OSB)
670 (3/4" Ply)
125
#14 Black
1/4"
3/8"
1/2"
GST 200
GST 20
GST 3
2" SAMMY for WOOD 1/4" ROD
2" SAMMY for WOOD 3/8" ROD
3" SAMMY for WOOD 1/2" ROD
1760 (Fir)
1760 (Fir)
2275 (Fir)
125
125
125
#14 Black
#14 Black
#14SW Red
®
SAMMY Swivel Head for Wood
Installs VERTICALLY and swivels up to 17° in wood structure
Product Features
• Eliminates distortion of threaded rod.
• Accommodates up to 3 ½" x 12 pitch roof.
• Allows 17° deflection from vertical.
Rod
Size
Part Number
Description
• Saves time from traditional methods.
• Reduces installation cost.
• Made in the U.S.A.
Ultimate
Pullout (lbs)
Qty
Nut Driver
3/8"
SH-GST 20
2" SWIVEL HEAD for WOOD 3/8" ROD
1257 (Fir)
125
#14 Black
3/8"
SH-GST 30
3" SWIVEL HEAD for WOOD 3/8" ROD
1720 (Fir)
125
#14 Black
SPECIAL NUT DRIVER SYSTEM
The nut drivers were designed with a unique spin-off feature which provides a fast
and safe installation each time. When the face of the driver comes into contact
with the material you are installing into, continue drilling until nut driver spins free.
Installation is then complete. Warranty requires the use of the appropriate nut driver
for installations.
www.ramset.com
#14 Black
Nut Driver
Part # 8113910
#14 SW Red
Nut Driver
Part # 8114910
61
®
SIDEWINDERS for Wood
Installs HORIZONTALLY into the side of wood structures easily and quickly!
Product Features
Not less than 2" nominal width
(1-1/2") up to 3-1/2" pipe; not less than
3" (2-1/2") nominal width 4" & 5" pipe
• No pre-drilling required.
Floor Joist
• Quick to install using the Sammy
Nut Driver with an 18V cordless
drill/driver.
Minimum 2-1/2" from bottom for
branch lines. Minimum 3" from
bottom for main lines. Exception: This
requirement shall not apply to 2" or
thicker nailing strips resting on top of
steel beams.
• Saves time from traditional
methods.
• Reduces installation cost.
• Made in the U.S.A.
Rod
Size
Part Number
1/4"
1/4"
3/8"
SWG 100
SWG 200
SWG 20
Description
1" SIDEWINDER for WOOD 1/4" ROD
2" SIDEWINDER for WOOD 1/4" ROD
2" SIDEWINDER for WOOD 3/8" ROD
INSTALLATION STEPS - VERTICAL INTO WOOD & STEEL:
Qty
Nut Driver
622 (Fir)
1725 (Fir)
1725 (Fir)
125
125
125
#14SW Red
#14SW Red
#14SW Red
INSTALLATION STEPS - HORIZONTAL INTO WOOD & STEEL:
1. Insert the appropriate nut driver into a 3/8" or 1/2" portable drill.
1. Insert the appropriate nut driver into a 3/8" or 1/2" portable drill.
2. Insert the SAMMYS into the #14 (black) nut driver (p/n 8113910). Drill
should be in a vertical position.
2. Insert the SAMMYS into the #14SW (red) nut driver (p/n 8114910). With drill
unit in a horizontal position and at a right angle to the structural member,
begin installation.
3. Push the face of the nut driver tight to the member. When the
nut driver spins freely on the SAMMYS, stop drill and remove.
4. The SAMMYS is now ready to receive 1/4", 3/8", 1/2" or metric
all thread rod, bolt stock. (The 1/2" requires the #14SW red nut driver)
Note: When installing DSTR, follow the above instructions,
then add retainer nut and torque to 20 foot lbs. for maximum
pullout in purlin steel.
62
Ultimate
Pullout (lbs)
3. When the nut driver spins free on the SAMMYS, stop the drill and
remove.
4. The unit is now ready to receive 1/4", 3/8" or metric all thread rod or
bolt stock.
Note: When installing SWDR, follow the above instructions, then add retainer
nut and torque to 20 foot lbs. for maximum pullout in purlin steel.
www.ramset.com
®
SAMMYS for Steel
Installs VERTICALLY into the bottom of steel structures easily and quickly!
Product Features
no rilling
pre-d
• Made with Teks® self-drilling fasteners
no pre-drilling required.
required
• Install into steel range from 22 gauge –
1/2" thicknesses.
• Saves time from traditional methods.
• Reduces installation cost.
• Quick to install using the Sammy Nut Driver
with an 18V cordless drill/driver.
Rod
Size
Part
Number
Ultimate
Pullout (lbs)
Qty
1/4"
1/4"
1/4"
1/4"
3/8"
3/8"
3/8"
DSTR 100
DST 150
DST 200
TEK 500
DSTR 1
DSTR 1-1/2
DSTR 516
1" SAMMY for STEEL 1/4" ROD
1-1/2" SAMMY for STEEL 1/4" ROD
2" SAMMY for STEEL 1/4" ROD
1-1/2" SAMMY for STEEL 1/4" ROD
1" SAMMY for STEEL 3/8" ROD W/NUT
1-1/2" SAMMY for STEEL 3/8" ROD
1-1/4" SAMMY for STEEL 3/8" ROD W/NUT
1510 (20 ga.)
970 (16 ga.)
446 (20 ga.)
3125 (3/16")
1510 (20 ga.)
1510 (3/16")
2200 (20 ga.)
125
125
125
125
125
125
125
3/8" DST 10
1" SAMMY for STEEL 3/8" ROD
446 (20 ga.)
970 (16 ga.)
125 #14 Black
3/8" DST 25
2-1/2" SAMMY for STEEL 3/8" ROD
446 (20 ga.)
970 (16 ga.)
125 #14 Black
3/8" TEK 50
1-1/2" SAMMY for STEEL 3/8" ROD
3125 (3/16")
125 #14 Black
2" 2-1/2" SAMMY for STEEL 1/2" ROD
446 (20 ga.)
970 (16 ga.)
125 #14SW Red
1/2" DST 2.0
Description
®
SAMMY Swivel Head for Steel
Nut Driver
#14 Black
#14 Black
#14 Black
#14 Black
#14 Black
#14 Black
Installs VERTICALLY and swivels up to 17° in steel structure
Product Features
• Eliminates distortion of threaded rod in
sloped roof applications.
• Installs into angled Z-Purlin; Allows threaded rod to
hang plumb.
• Accommodates 3-1/2 x 12 pitch.
• Allows 17° deflection from vertical.
Rod
Size
Part Number
3/8"
SH-DSTR 1
Description
1" SWIVEL HEAD for STEEL 3/8" ROD
Ultimate
Pullout (lbs)
Qty
Nut Driver
3220 (3/16")
125
#14 Black
SPECIAL NUT DRIVER SYSTEM
The nut drivers were designed with a unique spin-off feature which provides a fast
and safe installation each time. When the face of the driver comes into contact
with the material you are installing into, continue drilling until nut driver spins free.
Installation is then complete. Warranty requires the use of the appropriate nut driver
for installations.
www.ramset.com
#14 Black
Nut Driver
Part # 8113910
#14 SW Red
Nut Driver
Part # 8114910
63
®
SIDEWINDERS for Steel
Installs HORIZONTALLY into the side of steel structures easily and quickly!
Product Features
no rilling
pre-d
• Made with Teks® self-drilling fasteners - no pre-drilling
required.
required
• Install into steel range from 22 gauge – 1/2" thicknesses.
• Saves time from traditional methods.
• Reduces installation cost.
• Quick to install using the Sammy Nut Driver with an 18V
cordless drill/driver.
Rod
Size
Part Number
1/4"
3/8"
3/8"
SWD 100
SWD 15
SWDR 516
Ultimate
Pullout (lbs)
Description
1" SIDEWINDER for STEEL 1/4" ROD
1-1/2" SIDEWINDER for STEEL 3/8" ROD
1-1/4" SIDEWINDER for STEEL 3/8" ROD W/NUT
1477 (16ga.)
1477 (16ga.)
2480 (20ga.)
Qty
Nut Driver
125
125
125
#14SW Red
#14SW Red
#14SW Red
Sammy X-Press ®Installs into Metal Deck, Purlin, or Tubular Steel
Product Features
• The Sammy X-Press expands to provide direct
vertical attachment in:
- Metal Deck (22-16 gauge)
- Z-Purlin (18-16 gauge)
(XP)
Patent No.
6,935,821
• The Sammy X-Press Swivel allows you to hang
plumb in extreme roof pitches:
- 89° in Z-Purlin
- 45° in metal deck for 12/12 pitch
for
(SXP)
Patent Pending
extreorme
variant
• The Sammy X-Press Sidewinder expands to
provide horizontal attachment in:
- 16 ga - 3/16" steel - purlin, tubular steel.
• Installs in seconds, saving time & installation
costs.
• Use in applications where access to the back of
the installed fastener is
prohibited. ie. metal roof deck, tubular
steel, or vapor barrier fabric.
• Less jobsite material needed.
• No retaining nut required.
• Provides design flexibility.
s
roof pitche
Rod
Size
Ultimate
Pullout (lbs)
Part Number
Description
Qty
1/4"
XP 200
X-Press for METAL DECK 1/4" ROD
1146 (22 ga)
125
3/8"
XP 20
X-Press for METAL DECK 3/8" ROD
1146 (22 ga)
125
3/8"
XP 35
X-Press for PURLIN 3/8" ROD
1783 (16 ga)
125
125
Vertical Mount
(SWXP)
3/8"
SXP 20
Swivel X-Press
1061 (22 ga Vertical)
829 (45° Off Vertical)
3/8"
SXP 35
Swivel X-Press
1675 (16 ga Vertical)
1558 (89° Off Vertical)
125
SWXP 35
Sidewinder X-Press for PURLIN 3/8" ROD
1798 (16 ga)
125
Horizontal Mount
Patent Pending
3/8"
Sammy X-Press It
®
Installation Tool
Part
Number
UXPIT
UXPIT
XPDB
Description
X-Press Universal Installation Tool
25/64" X-Press Drill Bit
Each Qty
1
1
Patent Pending
64
www.ramset.com
®
SAMMYS for Concrete
Installs VERTICALLY into the bottom of concrete structures easily and quickly!
Product Features
• Easy two step process (Drill hole &
drive Sammy concrete anchor).
• ¼" pre-drilled pilot hole required.
• Concrete Installation Tool available for
a one tool installation process.
Product Features - Swivelhead
• Installs vertically and swivels up to 89° in
wood & concrete structures.
• Eliminates distortion of threaded rod.
• 1/4" pre-drilled pilot hole required.
• Concrete installation tool available for a one
piece installation process.
• Made in the U.S.A.
Metal Deck
SAMMYS®
SWIVELHEAD
for Concrete
Rod
Size
Part Number
1/4"
3/8"
3/8"
1/2"
3/8"
1/2"
CST 200
CST 20
CST 20-SS
CST 2
SH-CST20
SH-CST30
®
SIDEWINDERS for Concrete
Description
Ultimate
Pullout (lbs)
Qty
Nut Driver
1-3/4" SAMMY for CONCRETE 1/4" ROD
1-3/4" SAMMY for CONCRETE 3/8" ROD
1-3/4" SAMMY for CONCRETE 3/8" ROD
1-3/4" SAMMY for CONCRETE 1/2" ROD
1-3/4" SWIVEL HEAD for CONCRETE 3/8" ROD
1-3/4" SWIVEL HEAD for CONCRETE 1/2" ROD
2400
2400
2400
2400
2537
2537
125
125
125
125
125
125
#14 Black
#14 Black
#14 Black
#14SW Red
#14 Orange
#14 Orange
Installs HORIZONTALLY into side of concrete structures easily & quickly!
Product Features
• Easy two step process (Drill hole & drive Sammy
concrete anchor).
• ¼" pre-drilled pilot hole required.
• Concrete Installation Tool available for a one tool
installation process.
www.ramset.com
Rod
Size
Part
Number
1/4"
3/8"
SWC 200
SWC 20
Description
1-3/4" SIDEWINDER for CONCRETE 1/4" ROD
1-3/4" SIDEWINDER for CONCRETE 3/8" ROD
Ultimate
Pullout (lbs)
2450
2450
Qty
Nut Driver
125
125
#14SW Red
#14SW Red
65
SPECIAL NUT DRIVER SYSTEM
The nut drivers were designed with a unique spin-off feature which provides a fast
and safe installation each time. When the face of the driver comes into contact
with the material you are installing into, continue drilling until nut driver spins free.
Installation is then complete. Warranty requires the use of the appropriate nut driver
for installations.
Concrete / Wood Installation Kit
(a)
#14 SW Red
#14 Black
Nut Driver
Nut Driver
Part # 8113910 Part # 8114910
#14 SH Orange
Nut Driver
Part # 8273910
The only tool needed to install SAMMYS & SIDEWINDERS
Part Number
8122910
Description
Concrete Installation Kit (a)
8113910
8114910
8116910
8117910
HEX 250
SDS B250
Kit includes the following items:
#14 Black Nut Driver (b)
#14 SW Red Nut Driver (c)
#250 Bit (1/4") (d)
SDS Bit (1/4") (e)
HEX 250 Bit Receiver (1/4") (g)
SDS B250 Bit Receiver (1/4")*
Each Qty
1
1
1
1
1
1
*Only sold separately - not included in kit.
INSTALLATION STEPS - VERTICAL INTO CONCRETE:
INSTALLATION STEPS - HORIZONTAL INTO CONCRETE:
1. Using an SDS 250 carbide tip bit or a HEX RECEIVER with a #250
carbide tip bit, pre-drill the concrete member to a depth of 2" with an
electric impact/drill set on impact mode.
1. Using an SDS 250 carbide tip bit or a HEX RECEIVER with a #250
carbide tip bit, predrill the concrete member to a depth of 2" with an
impact/drill set on impact mode.
2. After pre-drilling has been completed, install the SLEEVE TOOL over
the bit (the bit should remain in the drill), and insert the #14 (black)
nut driver (p/n 8113910) into the opposite end (see Vertical Installation
note above).
2. After pre-drilling has been completed, install the SLEEVE TOOL
over the bit (the bit should remain in the drill), and insert the #14SW (red)
nut driver (p/n 8114910) into the opposite end.
3. Insert the concrete screw into the nut driver.
4. Place tip of screw into the pre-drilled hole, turn impact/drill unit to drill
mode and begin insertion. When the nut driver spins free on the
screw, installation is complete. Stop and remove drill.
5. The concrete screw is ready to receive 1/4", 3/8", 1/2", or metric all
thread rod or bolt stock. (#14SW red nut driver used with 1/2" screw)
NOTE: Use a 1200 maximum RPM drill for installation.
NOTE: Do not install concrete screws while the drill unit is in impact mode
— doing so will destroy the pullout factor of the screw.
66
3. Install the SWC screw into the nut driver.
4. Place tip of screw into the pre-drilled hole, turn impact/drill unit to
drill mode and begin insertion. When the nut driver spins free on the
SWC screw, installation is complete. Stop and remove drill.
5. The SWC screw is ready to receive 1/4", 3/8" or metric all thread rod
or bolt stock.
NOTE: Use a 1200 maximum RPM drill for installation.
NOTE: Do not install concrete screws while the drill unit is in impact mode —
doing so will destroy the pullout factor of the fastener.
www.ramset.com
APPROVALS
SAMMYS® FOR WOOD
Pipe Hanger
Part No.
Model
Rod
Size
Mount
Direction
UL Max
Pipe Size
UL Test
Load (lbs)
8007957
8020957
8008957
8068925
8010957
8009925
8022925
8021957
8073925
8139957
8141957
GST 10
SWG 10
GST 20
GST 20-SS
GST 30
GST 25-380
SWG 25-380
SWG 20
SWG 20-SS
SH-GST 20
SH-GST 30
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
Vertical
Horizontal
Vertical
Vertical
Vertical
Vertical
Horizontal
Horizontal
Horizontal
17° Angle off Vertical
17° Angle off Vertical
CPVC 1-1/2"
CPVC 1-1/2"
2-1/2"
2-1/2"
4"
4"
3-1/2" - 4"*
2-1/2" - 3"**
2-1/2"
3"
4"
300
300
850
850
1500
1500
1500
1050
850
1050
1500
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
SAMMYS® FOR STEEL
UL Min Wood FM Max
Thickness
Pipe Size
FM Test
Load (lbs)
FM Min Wood
Thickness
4"
1475
1-1/2"
4"
1475
1-1/2"
4"
4"
1475
1475
1-1/2"
1-1/2"
Pipe Hanger
Part No.
Model
Rod
Size
Mount
Direction
UL Max
Pipe Size
UL Test
Load (lbs)
UL Min. Steel
Thickness
FM Max
Pipe Size
FM Test
Load (lbs)
FM Min.
Steel
Thickness
8038957
8037957
8039957
8045957
8046957
8055957
8056957
8054957
8137957
DSTR 1
DSTR 1-1/2
DSTR 516
DST 516
TEK 50
SWDR 1
SWDR 516
SWDR 1-1/2
SH-DSTR 1
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
Vertical
Vertical
Vertical
Vertical
Vertical
Horizontal
Horizontal
Horizontal
17° Angle off Vertical
4"
4"
4"
4"
4"
4"
4"
4"
4"
1500
1500
1500
1500
1500
1500
1500
1500
1500
.035"
.035"
.037"
.188"
.250"
.037"
.037"
.037"
.035"
8150922
XP 20
3/8"
Vertical
2-1/2"
850
.027"
8153922
XP 35
3/8"
Vertical
4"
1500
.060"
8294922
8295922
8293957
SXP 20
SXP 35
SWXP 35
3/8"
3/8"
3/8"
Vertical or up to 45°
Vertical or up to 89°
Horizontal
2"
3-1/2"
3-1/2"
750
1250
1250
.027"
.060"
.060"
4"
4"
4"
4"
4"
4"
4"
4"
4"
2"
4"
2"
4"
2"
2"
1475
1475
1475
1475
1475
1475
1475
1475
1475
940
1475
940
1475
635
635
.105"
.105"
.105"
.188"
.188"
.060"
.060"
.060"
.105"
.029"
.105"
.029"
.105"
.029"
.029"
UL Test
Load (lbs)
UL Min
PSI
FM Max
Pipe Size
FM Test
Load (lbs)
FM Min
PSI
SAMMYS® FOR CONCRETE
Part No.
8059957
8061957
8150922
8150922
Model
CST 20
SWC 20
XP 20
XP 20
Rod
Size
Mount
Direction
3/8"
3/8"
3/8"
3/8"
Vertical
Horizontal
Vertical
Vertical
Pipe Hanger
*SWG 25-380 Maximum pipe size in composite wood joist allowed by UL is 3-1/2"
*SWG 25-380 Maximum pipe size in wood timber or joist allowed by UL is 4"
**SWG 20 Maximum pipe size in composite wood joist allowed by UL is 2-1/2"
**SWG 20 Maximum pipe size in wood timber or joist allowed by UL is 3"
www.ramset.com
UL Max
Pipe Size
2-1/2"
2-1/2"
850
850
4"
1475
4"
1475
Pre-Pour Structural @ 3000psi
Post-Pour Range II LWC < 35 PCF (lbs/ft3)
3000
3000
UL compliance with NEC Standards.
UL and FM tests were performed in compliance with NFPA 13 Standards.
Fastening requirement: 5 times weight of water-filled schedule 40 pipe plus 250 pounds.
67
APPROVALS
SAMMYS® FOR STEEL
Luminaire Fitting
Part No.
Model
Rod
Size
Mount
Direction
8150922
XP 20
3/8"
Vertical
8153922
XP 35
3/8"
Vertical
8181922
XP 200
1/4"
Vertical
8294922
SXP 20
3/8"
8295922
SXP 35
3/8"
8293957
SWXP 35
3/8"
SAMMYS® FOR STEEL
Part No.
Model
UL Load
Rating
(lbs)
UL Min. Steel
Thickness
283
500
283
500
500
.027"
.060"
.027"
.060"
.060"
3/8"
3/8"
3/8"
3/8"
3/8"
Vertical
Vertical
Vertical
Vertical
Horizontal
8149957
CZ2000
1/4" or 3/8"
Onto Vertical Rod
185
250
185
250
185
250
170
80
250
80
80
.027"
.035"
.027"
.035"
.027"
.035"
.027"
.027"
.060"
.060"
.060"
Conduit, Tubing, and Cable
Mount
Direction
XP 20
XP 35
SXP 20
SXP 35
SWXP 35
UL Min Steel
Thickness
Vertical
45°
Vertical
90°
Horizontal
Rod
Size
8150922
8153922
8294922
8295922
8293957
UL Load
Rating (lbs)
Listed Application
Max 4 trade size EMT, RMC, and IMC & 5 trade size rigid PVC conduit
Max 4 trade size EMT & 6 trade sze RMC, IMC, and rigid PVC conduit
Max 4 trade size EMT, RMC, and IMC & 5 trade size rigid PVC conduit
Max 4 trade size EMT & 6 trade sze RMC, IMC, and rigid PVC conduit
Max 4 trade size EMT & 6 trade sze RMC, IMC, and rigid PVC conduit
UL Listed 4S16 - Cable Hanger, Cat. No. C-Z2000 Plenum Rated,
Complies w/ NEC Standards
Sheet Steel Sizes
Sheet Steel Gauges
Gauge No.
Nominal Decimal Equivalent
68
22 ga.
.030"
20 ga.
.036"
18 ga.
.048"
16 ga.
.060"
14 ga.
.075"
12 ga.
.105"
3/16"
.188"
1/4"
.250"
www.ramset.com
Anchoring Systems
CONCRETE ANCHORING SYSTEMS
Electrical Contractor Applications
Redi-Drive
•Available in special 3/8"
version for precast planks
•Available in sizes 1/4" thru
3/4" internal thread diameters
Junction Box/ Panel
Boards
Pg. 97
•Simple to install
•Drill hole, hammer
Redi-Drive into hole
•Available in several
head styles and lengths
Multi-Set
Pg. 86
Pg. 101
tapcon
Suspended
Lighting
Conduit Clip
•Counter sunk flathead
style for flush installation
•Works in concrete or block
•Available in 3/16" and 1/4"
diameters
Pg. 97
Transformers Switch Gear
Electrical Enclosures
Redi-Drive
•Simple to install
•Drill hole, hammer
Redi-Drive into hole
•Available in several head
styles and lengths
•2006 IBC & 2009 IBC Compliant
•All seismic zone and cracked con•Used with rod coupler crete approved
•1/4" to 1" diameters •Thru fixture fastening
TRUBOLT
Pg. 72
Pg. 72
TRUBOLT +
TRUBOLT
•Available in carbon,
hot dipped galvanized, 304 and 316
stainless steel
Pg. 80
Pg. 91
LDT
Multi-Set
•Available in special 3/8"
version for precast planks
•Available in sizes 1/4" thru
3/4" internal thread diameters
•Available in special 3/8"
version for precast planks
•Available in sizes 1/4" thru
3/4" internal thread diameters
PIPE DRIVE
Multi-Set
Pg. 86
DYNABOLT
•Counter sunk and
threshold head styles
also available
•Works in concrete,
block and brick
Pg. 72
Pg. 86
•2006 IBC & 2009 IBC Compliant
•All seismic zone and cracked
concrete approved
•Thru fixture fastening
Wall Mounted
Lighting
70
Pg. 72
Unistrut-Cable
Tray/Conduit
TRUBOLT +
•Works in solid concrete,
hollow block and brick
•Cuts a thread into the
mounted surface
•Finished head appearance
Suspended
Pipe or Conduit
•Single piece anchors
(no couplers!)
•Drill hole, hammer in
•1/4" and 3/8" internally
threaded inserts
www.ramset.com
CONCRETE ANCHORING SYSTEMS
Mechanical Contractor Applications
Machinery and
Equipment
•Simple to install–drill
hole and hammer in
•Fire resistant
LDT
Redi-Drive
Pg. 80
•Vibration resistant
•Removable
Pg. 97
Ductwork/HVAC
Pipe/Strut
Attachment
Multi-Set
Pg. 86
•Available in special 3/8" version for prestressed concrete
•Available in 1/4" thru 3/4"
internal thread diameters
Heavy-Duty
Pipe Support
•2006 IBC &
2009 IBC Compliant
•All seismic zone and
cracked concrete approved
•Thru fixture fastening
•Available in special 3/8"
version for prestressed concrete
•Available in 1/4" thru 3/4"
internal thread diameters
TRUBOLT +
Pg. 72
Multi-Set
Pg. 72
TRUBOLT
•Carbon, hot dipped
galvanized, 304 and 316
stainless steel
•1/4" to 1" diameters
www.ramset.com
PIPE DRIVE
•1-piece design (no couplers!)
•Drill hole, hammer in
•1/4" and 3/8" internal threads
Pg. 86
Pipe Support,
Fire Sprinkler
71
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
Trubolt ® Wedge Anchors
Wedge Type Anchors—
specified for anchorage into concrete
Trubolt Wedge anchors feature a stainless steel expansion clip, threaded
stud body, nut and washer. Anchor bodies are made of plated carbon
steel, hot-dipped galvanized carbon steel, type 304 stainless steel or type
316 stainless steel as identified in the drawings or other notations.
The exposed end of the anchor is stamped to identify anchor length.
Stampings should be preserved during installation for any subsequent
embedment verification.
Use carbide tipped hammer drill bits made in accordance with ANSI
B212.15-1994 to install anchors.
Anchors are tested to ACI 355.2 and ICC-ES AC193. Anchors are listed by
the following agencies as required by the local building code: ICC-ES, UL,
FM, City of Los Angeles, California State Fire Marshal and Caltrans.
ADVANTAGES
APPLICATIONS
n 2006 International Building Code (IBC) Compliant
Anchoring machinery and
conveyors is a common
wedge anchor application.
The Trubolt is fully
threaded to allow a large
range of embedment and
fixture thickness.
n Versatile fully threaded design is standard on sizes up to 3/4"
diameter and 10" length
n Anchor diameter equals hole diameter
n Standard carbon and stainless steel anchors
n 360° contact with concrete assures full expansion for reliable
working loads
Seismic Wedge Anchor
cracked concrete approval
controls tension & shear
simultaneously.
n Non bottom-bearing, may be used in hole depth exceeding anchor
length
n Can be installed through the work fixture, eliminating hole spotting
n Inspectable torque values, indicating proper installation
Fully Threaded
Advantage
Trubolt’s fully threaded
feature eliminates
subsurface obstruction
problems.
Fully threaded design
accommodates various
material thicknesses at
the same embedment.
One anchor length saves
time and money.
length indication code*
Code
A
B
C
D
E
F
G
H
I
J
Length of Anchor
1-1/2 < 2 (38.1 < 50.8)
2 < 2-1/2 (50.8 < 63.5)
2-1/2 < 3 (63.5 < 76.2)
3 < 3-1/2 (76.2 < 88.9)
3-1/2 < 4 (88.9 < 101.6)
4 < 4-1/2 (101.6 < 114.3)
4-1/2 < 5 (114.3 < 127.0)
5 < 5-1/2 (127.0 < 139.7)
5-1/2 < 6 (139.7 < 152.4)
6 < 6-1/2 (152.4 < 165.1)
Code
Length of Anchor
K
6-1/2 < 7 (165.1 < 177.8)
L
7 < 7-1/2 (177.8 < 190.5)
M
7-1/2 < 8 (190.5 < 203.2)
N
8 < 8-1/2 (203.2 < 215.9)
O
8-1/2 < 9 (215.9 < 228.6)
P
9 < 9-1/2 (228.6 < 241.3)
Q
9-1/2 < 10 (241.3 < 254.0)
R
10 < 11 (254.0 < 279.4)
S
11 < 12 (279.4 < 304.8)
T
12 < 13 (304.8 < 330.2)
*Located on top of anchor for easy inspection.
72
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
APPROVALS / LISTINGS
FEATURES
Length ID Head Stamp—
provides for
embedment inspection
after installation
ICC Evaluation Service, Inc. # ESR-2251
– Category 1 performance rating
– 2006 IBC compliant
– Meets ACI 318 ductility requirements
– Tested in accordance with ACI 355.2 and ICC-ES AC193
– For use in seismic zones A & B
– 1/4", 3/8" & 1/2" diameter anchors listed in ESR-2251
Underwriters Laboratories
Factory Mutual
City of Los Angeles - #RR2748
California State Fire Marshall
Caltrans
Meets or exceeds U.S. Government G.S.A. Specification A-A-1923A Type 4
(formerly GSA: FF-S-325 Group II, Type 4, Class 1)
Fully Threaded Design
Cold-Formed—
manufacturing process
adds strength
Stainless steel split
expansion ring
Anchor Body—available
in zinc-plated steel, hotdipped galvanized steel,
304 stainless steel and
316 stainless steel
Trubolt® Wedge Anchor
ICC Evaluation Service, Inc. # ESR-2427
-Category 1 performance rating
-2006 IBC and 2009 IBC compliant
-Meets ACI 318 ductility requirements
-Tested in accordance with ACI 355.2 and ICC-ES AC193
-Listed for use in seismic zones A, B, C, D, E, & F
-3/8", 1/2", 5/8" and 3/4" diameter anchors listed in ESR-2427
City of Los Angeles - #RR25867
Installation Steps
1. Select a carbide drill bit with a
diameter equal to the anchor diameter.
Drill hole to any depth exceeding the
desired embedment. See chart for
minimum recommended embedment.
2. C lean hole or continue drilling
additional depth to accommodate
drill fines.
www.ramset.com
3. A ssemble washer and nut, leaving nut
flush with end of anchor to protect
threads. Drive anchor through material
to be fastened until washer is flush to
surface of material.
4. Expand anchor by tightening nut 3-5
turns past the hand tight position, or to
the specified torque requirement.
73
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
Carbon Steel with Zinc Plating
PART NUMBER
THREAD LENGTH
In. (mm)
ANCHOR DIA. &
DRILL BIT SIZE
(THREADS)
PER INCH
OVERALL LENGTH
IN. (mm)
MAX. THICKNESS OF
MATERIAL TO BE FASTENED
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
CWS-3830
1-5/8
(41.3)
3/8" - 16
3
(76.2)
5/8
(15.9)
50/
5.3
400/ 42
CWS-3836
2-3/8
(60.3)
3/8" - 16
3-3/4
(95.3)
1-3/8
(34.9)
50/
5.9
300/ 35
CWS-3850
3-5/8
(92.1)
3/8" - 16
5
(127.0)
2-5/8
(66.7)
50/
7.3
250/ 37
CWS-1236
2-1/8
(54.0)
1/2" - 13
3-3/4
(95.3)
3/4
(19.1)
25/
5.7
150/ 34
CWS-1244
2-7/8
(73.0)
1/2" - 13
4-1/2
(114.3)
1-1/2
(38.1)
25/
7.0
150/ 40
CWS-1254
3-7/8
(98.4)
1/2" - 13
5-1/2
(139.7)
2-1/2
(63.5)
25/
8.0
150/ 49
CWS-1270
5-3/8
(136.5)
1/2" - 13
7
(177.8)
4
(101.6)
25/
9.2
150/ 55
CWS-5850
3-3/16
(81.0)
5/8" - 11
5
(127.0)
1-1/8
(28.6)
10/
4.7
100/ 48
CWS-5860
4-3/16 (106.4)
5/8" - 11
6
(152.4)
2-1/8
(54.0)
10/
5.4
50/
28
CWS-5870
5-3/16 (131.8­)
5/8" - 11
7
(177.8)
3-1/8
(79.4)
10/
6.2
30/
19
CWS-5884
5-3/4
(146.0)
5/8" - 11
8-1/2
(215.9)
4-5/8
(117.5)
10/
8.0
30/
25
CWS-3454
3-5/8
(92.1)
3/4" - 10
5-1/2
(139.7)
1-1/2
(38.1)
50/
7.6
30/
38
CWS-3462
4-3/8
(111.1)
3/4" - 10
6-1/4
(158.8)
2-1/4
(57.2)
10/
8.5
30/
26
CWS-3470
5-1/8
(130.2)
3/4" - 10
7
(177.8)
3
(76.2)
10/
9.0
30/
27
CWS-3484
5-3/4
(146.0)
3/4" - 10
8-1/2
(215.9)
4-1/2
(114.3)
10/
10.5
30/
32
CWS-34100
5-3/4
(146.0)
3/4" - 10
10
(254.0)
6
(152.4)
10/
11.9
30/
36
Meets ASTM B633 SC1, Type III specifications for electroplating of 5um = .0002" thickness. This coating is well suited for non-corrosive environments.
Trubolt ® Carbon Steel with Hot-Dipped Galvanizing
PART NUMBER
THREAD LENGTH
In. (mm)
ANCHOR DIA. &
DRILL BIT SIZE
(THREADS)
PER INCH
1/2" - 13
OVERALL LENGTH
IN. (mm)
MAX. THICKNESS OF
MATERIAL TO BE FASTENED
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
WS-1226G
1-1/4
(31.8)
2-3/4
(69.9)
1/8
(3.2)
25/
4.8
200/
39
WS-1242G
2-3/4
(69.9)
4-1/4
(108.0)
1-1/2
(38.1)
25/
6.7
150/
41
WS-1254G
4
(101.6)
5-1/2
(139.7)
2-3/4
(69.9)
25/
8.0
150/
49
WS-1270G
5-1/2
(139.7)
7
(177.8)
4-1/4
(108.0)
25/
9.7
150/
59
3-1/2
(88.9)
1/8
(3.2)
10/
3.7
100/
38
6
(152.4)
2-5/8
(66.7)
10/
5.6
50/
29
4-3/4
(120.7)
3/4
(19.1)
10/
7.5
60/
46
WS-5834G
1-3/4
(44.5)
WS-5860G
4-1/4
(107.9)
5/8" - 11
WS-3446G
2-7/8
(73.0)
WS-3454G
3-5/8
(92.1)
5-1/2
(139.7)
1-1/2
(38.1)
10/
8.4
50/
42
WS-3484G
5-3/4
(146.0)
8-1/2
(215.9)
4-1/2
(114.3)
10/
12.5
30/
38
3/4" - 10
Meets ASTM A153 Class specifications for hot-dipped galvanizing > 45um = .002". It is highly recommended for damp, humid environments near coastal regions. Hotdipped galvanized Trubolts have a coating thickness of zinc that is almost 10 times as thick as electroplating. This creates greater corrosion resistance at a minimal cost.
Typical Applications—Railings, Signage, Awnings, etc.
Environment—Rural/Suburban (exterior environment—essentially unpolluted areas)
Level of Corrosion—Low to Medium
74
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
Trubolt ® Carbon Steel with Zinc Plating
PART NUMBER
THREAD LENGTH
In. (mm)
ANCHOR DIA. &
DRILL BIT SIZE
(THREADS)
PER INCH
1/4" - 20
OVERALL LENGTH
IN. (mm)
MAX. THICKNESS OF
MATERIAL TO BE FASTENED
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
WS-1416
3/4
(19.1)
1-3/4
(44.5)
3/8
(9.5)
100/
3.1
1000/
32
WS-1422
1-1/4
(31.8)
2-1/4
(57.2)
7/8
(22.2)
100/
3.6
1000/
37
WS-1432
2-1/4
(57.2)
3-1/4
(82.6)
1-7/8
(47.6)
100/
4.7
800/
39
WS-3822
1-1/8
(28.6)
2-1/4
(57.2)
3/8
(9.5)
50/
4.1
500/
41
WS-3826
1-5/8
(41.3)
2-3/4
(69.9)
7/8
(22.2)
50/
4.7
400/
39
WS-3830
1-3/4
(44.5)
3
(76.2)
1-1/8
(28.6)
50/
5.0
400/
41
WS-3836
2-1/2
(63.5)
3-3/4
(95.3)
1-7/8
(47.6)
50/
5.9
300/
36
WS-3850
3-3/4
(95.2)
5
(127.0)
3-1/8
(79.4)
50/
7.4
250/
38
WS-3870
3-7/8
(98.4)
7
(177.8)
5-1/8
(130.2)
50/
10.4
250/
53
WS-1226
1-1/4
(31.8)
2-3/4
(69.9)
1/8
(3.2)
25/
4.6
200/
38
WS-1236
2-1/4
(57.2)
3-3/4
(95.3)
1
(25.4)
25/
5.7
150/
35
WS-1242
2-3/4
(69.9)
4-1/4
(108.0)
1-1/2
(38.1)
25/
6.2
150/
38
WS-1244
3
(76.2)
4-1/2
(114.3)
1-3/4
(44.5)
25/
6.5
150/
39
WS-1254
4
(101.6)
5-1/2
(139.7)
2-3/4
(69.9)
25/
7.7
150/
47
WS-1270
5-1/2
(139.7)
7
(177.8)
4-1/4
(108.0)
25/
9.3
150/
57
WS-5834
1-3/4
(44.5)
3-1/2
(88.9)
1/8
(3.2)
10/
3.6
100/
37
WS-5842
2-1/2
(63.5)
4-1/4
(108.0)
7/8
(22.2)
10/
4.1
100/
42
WS-5850
3-1/4
(82.6)
5
(127.0)
1-5/8
(41.3)
10/
4.7
100/
48
WS-5860
4-1/4
(107.9)
6
(152.4)
2-5/8
(66.7)
10/
5.4
50/
28
WS-5870
5-1/4
(133.4)
7
(177.8)
3-5/8
(92.1)
10/
6.2
30/
19
WS-5884
5-3/4
(146.0)
8-1/2
(215.9)
5-1/8
(130.2)
10/
8.0
30/
25
WS-58100
5-3/4
(146.0)
10
(254.0)
6-5/8
(168.3)
10/
9.4
30/
29
WS-3442
2-3/8
(60.3)
4-1/4
(108.0)
1/4
(31.8)
10/
6.8
60/
42
WS-3446
2-7/8
(73.0)
4-3/4
(120.7)
3/4
(19.1)
10/
7.4
60/
45
WS-3454
3-5/8
(92.1)
5-1/2
(139.7)
1-1/2
(38.1)
10/
8.1
50/
41
WS-3462
4-3/8
(111.1)
6-1/4
(158.8)
2-1/4
(57.2)
10/
9.1
30/
28
WS-3470
5-1/8
(130.2)
7
(177.8)
3
(76.2)
10/
9.7
30/
30
WS-3484
5-3/4
(146.0)
8-1/2
(215.9)
4-1/2
(114.3)
10/
12.3
30/
38
WS-34100
5-3/4
(146.0)
10
(254.0)
6
(152.4)
10/
14.0
30/
43
WS-34120
1-3/4
(44.5)
12
(304.8)
8
(203.2)
10/
16.6
30/
51
WS-7860
2-1/2
(63.5)
6
(152.4)
1-3/8
(34.9)
5/
6.3
25/
32
WS-7880
2-1/2
(63.5)
8
(203.2)
3-3/8
(85.7)
5/
8.1
15/
25
WS-78100
2-1/2
(63.5)
10
(254.0)
5-3/8
(136.5)
5/
9.8
15/
30
WS-10060
2-1/2
(63.5)
6
(152.4)
1/2
(12.7)
5/
8.3
25/
43
WS-10090
2-1/2
(63.5)
9
(228.6)
3-1/2
(88.9)
5/
11.6
15/
36
WS-100120
2-1/2
(63.5)
12
(304.8)
6-1/2
(165.1)
5/
15.0
15/
46
2-1/8
(54.0)
9/32-hole (7.1)
3.6
1000/
2-1/8
(54.0)
9/32-hole (7.1)
3/8" - 16
1/2" - 13
5/8" - 11
3/4" - 10
7/8" - 9
1" - 8
Tie Wire
TW-1400
N/A
TW-1400 K
N/A
1/4"
100/
BULK
36
BULK
Meets ASTM B633 SC1, Type III specifications for electroplating of 5um = .0002" thickness.
This material is well suited for non-corrosive environments.
Typical Applications—Structural Columns,
Machinery, Equipment, etc.
Environment—Interior (non-corrosive)
Level of Corrosion—Low
www.ramset.com
75
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
Trubolt ® Type 304 Stainless Steel
PART NUMBER
THREAD LENGTH
In. (mm)
ANCHOR DIA. &
DRILL BIT SIZE
(THREADS)
PER INCH
1/4" - 20
OVERALL LENGTH
IN. (mm)
MAX. THICKNESS OF
MATERIAL TO BE FASTENED
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
WW-1416
3/4
(19.1)
1-3/4
(44.5)
3/8
(9.5)
100/
3.2
1000/
32
WW-1422
1-1/4
(31.8)
2-1/4
(57.2)
7/8
(22.2)
100/
3.7
1000/
37
WW-1432
2-1/4
(57.2)
3-1/4
(82.6)
1-7/8
(47.6)
100/
4.8
800/
39
WW-3822
1-1/8
(28.6)
2-1/4
(57.2)
3/8
(9.5)
50/
4.1
500/
41
WW-3826
1-5/8
(41.3)
2-3/4
(69.9)
7/8
(22.2)
50/
4.8
400/
39
WW-3830
1-3/4
(44.5)
3
(76.2)
1-1/8
(28.6)
50/
5.1
400/
42
WW-3836
2-1/2
(63.5)
3-3/4
(95.3)
1-7/8
(47.6)
50/
6.0
300/
37
WW-3850
3-3/4
(95.3)
5
(127.0)
3-1/8
(79.4)
50/
7.5
250/
39
WW-1226
1-1/4
(31.8)
2-3/4
(69.9)
1/8
(3.2)
25/
4.7
200/
38
WW-1236
2-1/4
(57.2)
3-3/4
(95.3)
1
(25.4)
25/
5.8
150/
36
WW-1242
2-3/4
(69.9)
4-1/4
(108.0)
1-1/2
(38.1)
25/
6.3
150/
39
WW-1254
3
(76.2)
5-1/2
(139.7)
2-3/4
(69.9)
25/
7.7
150/
47
WW-1270
3-1/2
(88.9)
WW-5834
1-3/4
(44.5)
WW-5842
2-1/2
WW-5850
WW-5860
3/8" - 16
1/2" - 13
7
(177.8)
4-1/4
(108.0)
25/
9.4
150/
57
3-1/2
(88.9)
1/8
(3.2)
10/
3.6
100/
37
(63.5)
4-1/4
(108.0)
7/8
(22.2)
10/
4.2
100/
43
3-1/4
(82.6)
5
(127.0)
1-5/8
(41.3)
10/
4.8
100/
49
4-1/4
(107.9)
6
(152.4)
2-5/8
(66.7)
10/
5.5
50/
28
WW-5870
3-1/2
(88.9)
7
(177.8)
3-5/8
(92.1)
10/
6.2
30/
20
WW-5884
3-1/2
(88.9)
8-1/2
(215.9)
5-1/8
(130.2)
10/
8.0
30/
25
WW-3442
2-3/8
(60.3)
4-1/4
(108.0)
1/4
(1.6)
10/
6.8
60/
42
WW-3446
2-7/8
(73.0)
4-3/4
(120.7)
3/4
(19.1)
10/
6.7
60/
41
WW-3454
3-5/8
(92.1)
5-1/2
(139.7)
1-1/2
(38.1)
10/
7.5
50/
38
WW-3470
3-1/2
(88.9)
7
(177.8)
3
(76.2)
10/
9.2
30/
28
WW-3484
3-1/2
(88.9)
8-1/2
(215.9)
4-1/2
(114.3)
10/
12.3
30/
38
WW-34100
1-3/4
(44.5)
WW-10060
2-1/2
(63.5)
WW-10090
2-1/2
(63.5)
5/8" - 11
3/4" - 10
1"
- 8
10
(254.0)
6
(152.4)
10/
13.5
30/
42
6
(152.4)
1/2
(12.7)
5/
8.3
25/
43
9
(228.6)
3-1/2
(88.9)
5/
11.4
15/
35
* For continuous extreme low temperature applications, use stainless steel.
Serves many applications well. It withstands rusting in architectural and food processing environments and resists organic chemicals, dye stuffs
and many inorganic chemicals.
Typical Applications—Cladding, Stadium Seating, etc.
Environment—Urban (slight to moderate degree of pollution)
Level of Corrosion—Medium
76
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
Trubolt ® Type 316 Stainless Steel
PART NUMBER
SWW-1422
THREAD LENGTH
In. (mm)
1-1/4
(31.8)
ANCHOR DIA. &
DRILL BIT SIZE
(THREADS)
PER INCH
OVERALL LENGTH
IN. (mm)
1/4" - 20
2-1/4
3/8" - 16
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
(22.2)
100/
3.7
1000/
37
MAX. THICKNESS OF
MATERIAL TO BE FASTENED
In. (mm)
(57.2)
7/8
3-1/4
(82.6)
1-1/8
(28.6)
100/
4.8
1000/
39
2-1/4
(57.2)
3/8
(9.5)
50/
4.1
500/
41
2-3/4
(69.9)
7/8
(22.2)
50/
4.8
400/
39
SWW-1432
2-1/4
(57.2)
SWW-3822
1-1/8
(28.6)
SWW-3826
1-5/8
(41.3)
SWW-3830
1-3/4
(44.5)
3
(76.2)
1-1/8
(28.6)
50/
5.2
400/
42
SWW-3836
2-1/2
(63.5)
3-3/4
(95.5)
1-7/8
(47.6)
50/
6.0
300/
37
SWW-3850
3-3/4
(95.3)
SWW-1226
1-1/4
(31.8)
SWW-1236
2-1/4
SWW-1242
2-3/4
SWW-1254
5
(127.0)
3-1/8
(79.4)
50/
7.5
250/
39
2-3/4
(69.9)
1/8
(3.2)
25/
4.7
200/
39
(57.2)
3-3/4
(95.3)
1
(25.4)
25/
5.8
150/
36
(69.9)
4-1/4
(108.0)
1-1/2
(38.1)
25/
6.5
150/
40
3
(76.2)
5-1/2
(139.7)
2-3/4
(69.9)
25/
7.8
150/
48
SWW-5842
2-1/2
(63.5)
4-1/4
(108.0)
7/8
(22.2)
10/
4.2
100/
43
SWW-5850
3-1/4
(82.6)
5
(127.0)
1-5/8
(41.3)
10/
4.8
100/
49
SWW-5870
3-1/2
(88.9)
SWW-3446
2-1/4
(57.2)
SWW-3454
3
(76.2)
1/2" - 13
5/8" - 11
3/4" - 10
7
(177.8)
3-5/8
(92.1)
10/
6.7
30/
21
4-3/4
(120.7)
3/4
(19.1)
10/
6.8
60/
41
5-1/2
(139.7)
1-1/2
(38.1)
10/
8.1
50/
41
* For continuous extreme low temperature applications, use stainless steel.
Contains more nickel and chromium than Type 304, and 2%-3% molybdenum, which gives it better corrosion resistance. It is especially more
effective in chloride environments that tend to cause pitting.
Typical Applications—Pumps, Diffusers, Gates, Weir Plates, etc.
Environment—Industrial (moderate to heavy atmospheric pollution)
Level of Corrosion—Medium to High
Combined Tension and Shear
Loading—for Trubolt Anchors
Allowable loads for anchors subjected to
combined shear and tension forces are
determined by the following equation:
(Ps/Pt ) 5/3 + (Vs/Vt ) 5/3 < 1
Typical Applications—Tunnels, Dams, Tiles, Lighting Fixtures, etc.
Environment—Marine (heavy atmospheric pollution)
Level of Corrosion—High
www.ramset.com
Ps = Applied tension load
Vs = Applied shear load
Pt = Allowable tension load
Vt = Allowable shear load
77
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
PERFORMANCE TABLES
Ultimate Tension and Shear Values (Lbs/kN) in Concrete*
ANCHOR
DIA.
In. (mm)
INSTALLATION
TORQUE
Ft.Lbs.
(Nm)
1/4 (6.4)
4 (5.4)
3/8 (9.5)
25 (33.9)
DEPTH OF
EMBEDMENT
In. (mm)
1-1/8
55 (74.6)
3/4 (19.1)
7/8 (22.2)
1 (25.4)
110 (149.2)
250 (339.0)
300 (406.7)
(5.2)
f’c = 6000 PSI (41.4 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1,400 (6.2)
1,780 (7.9)
1,400 (6.2)
1,900 (8.5)
1,400 (6.2)
(49.2)
2,100 (9.3)
1,680 (7.5)
3,300 (14.7)
1,680 (7.5)
3,300 (14.7)
1,680 (7.5)
(54.0)
2,260
1,680 (7.5)
3,300 (14.7)
1,680 (7.5)
3,300 (14.7)
1,680 (7.5)
(10.1)
1-1/2
(38.1)
1,680
(7.5)
2,320 (10.3)
2,240
(10.0)
2,620 (11.7)
2,840 (12.6)
3,160 (14.1)
3
(76.2)
3,480
(15.5)
4,000 (17.8)
5,940 (26.4)
4,140 (18.4)
6,120 (27.2)
4,500 (20.0)
(101.6)
4,800
(21.4)
4,000 (17.8)
5,940 (26.4)
4,140 (18.4)
6,120 (27.2)
4,500 (20.0)
2-1/4
6
90 (122.0)
1,180
f’c = 4000 PSI (27.6 MPa)
SHEAR
Lbs. (kN)
2-1/8
4-1/8
5/8 (15.9)
(28.6)
f’c = 2000 PSI (13.8 MPa)
TENSION
Lbs. (kN)
1-15/16
4
1/2 (12.7)
ANCHOR
TYPE
2-3/4
WS-Carbon or
WS-G
Hot-Dipped
(57.2)
Galvanized
or
(104.8)
WW-304 S.S.
(152.4)
or
(69.9) SWW-316 S.S.
4,660
(20.7)
4,760 (21.2)
5,100 (22.7)
4,760 (21.2)
7,040 (31.3)
7,040 (31.3)
4,660
(20.7)
7,240 (32.2)
9,640 (42.9)
7,240 (32.2)
10,820 (48.1)
8,160 (36.3)
5,340
(23.8)
7,240 (32.2)
9,640 (42.9)
7,240 (32.2)
10,820 (48.1)
8,160 (36.3)
6,580
(29.3)
7,120 (31.7)
7,180 (31.9)
7,120 (31.7)
9,720 (43.2)
9,616 (42.8
5-1/8
(130.2)
6,580
(29.3)
9,600 (42.7)
14,920 (66.4)
11,900 (52.9)
16,380 (72.9)
12,520 (55.7)
7-1/2
(190.5)
7,060
(31.4)
9,600 (42.7)
15,020 (66.8)
11,900 (52.9)
16,380 (72.9)
12,520 (55.7)
3-1/4
(82.6)
7,120
(31.7)
10,120 (45.0)
10,840 (48.2)
13,720 (61.0)
13,300 (59.2)
15,980 (71.1)
6-5/8
(168.3)
10,980 (48.8)
20,320 (90.4)
17,700 (78.7)
23,740 (105.6)
20,260 (90.1)
23,740 (105.6)
10
(254.0)
10,980 (48.8)
20,320 (90.4)
17,880 (79.5)
23,740 (105.6)
23,580 (104.9)
23,740 (105.6)
3-3/4
(95.3)
9,520
(42.3)
13,160 (58.5)
14,740 (65.6)
16,580 (73.8)
17,420 (77.5)
19,160 (85.2)
6-1/4
(158.8)
14,660 (65.2)
20,880 (92.9)
20,940 (93.1)
28,800 (128.1)
24,360 (108.4)
28,800 (128.1)
8
(203.2)
14,660 (65.2)
20,880 (92.9)
20,940 (93.1)
28,800 (128.1)
24,360 (108.4)
28,800 (128.1)
4-1/2
(114.3)
13,940 (62.0)
16,080 (71.5)
20,180 (89.8)
22,820 (101.5)
21,180 (94.2)
24,480 (108.9)
7-3/8
(187.3)
14,600 (64.9)
28,680 (127.6)
23,980 (106.7)
37,940 (168.8)
33,260 (148.0)
38,080 (169.4)
9-1/2
(241.3)
18,700 (83.2)
28,680 (127.6)
26,540 (118.1)
37,940 (168.8)
33,260 (148.0)
38,080 (169.4)
* Allowable values are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values.
* For Tie-Wire Wedge Anchor, TW-1400, use tension data from 1/4" diameter with 1-1/8" embedment.
* For continuous extreme low temperature applications, use stainless steel.
Ultimate Tension and Shear Values (Lbs/kN) in Lightweight Concrete*
ANCHOR
DIA.
In. (mm)
3/8 (9.5)
1/2 (12.7)
INSTALLATION
TORQUE
Ft.Lbs.
(Nm)
25 (33.9)
55 (74.6)
DEPTH OF
EMBEDMENT
In. (mm)
110 (149.2)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1,175
(5.2)
1,480
(6.6)
1,900
(8.5)
3,160
(14.1)
3 (76.2)
2,825
(12.6)
2,440
(10.9)
2,840
(12.6)
4,000
(17.8)
2-1/4 (57.2)
3 (76.2)
5 (127.0)
3/4 (19.1)
SHEAR
Lbs. (kN)
LOWER FLUTE OF STEEL DECK
WITH LIGHTWEIGHT CONCRETE FILL
f’c = 3000 PSI (20.7 MPa)
1-1/2 (38.1)
4 (10 1.6)
90 (122.0)
LIGHTWEIGHT CONCRETE
f’c = 3000 PSI (20.7 MPa)
TENSION
Lbs. (kN)
3 (76.2)
5/8 (15.9)
ANCHOR
TYPE
3-1/4 (82.6)
5-1/4 (133.4)
WS-Carbon or
WS-G
Hot-Dipped
Galvanized
or
WW-304 S.S.
or
SWW-316 S.S.
2,925
(13.0)
2,855
(12.7)
3,400
(15.1)
5,380
(23.9)
3,470
(15.4)
3,450
(15.3)
4,480
(19.9)
6,620
(29.4)
4,290
(19.1)
3,450
(15.3)
4,800
(21.4)
6,440
(28.6)
4,375
(19.5)
4,360
(19.4)
4,720
(21.0)
5,500
(24.5)
6,350
(28.2)
6,335
(28.2)
6,580
(29.3)
9,140
(40.7)
8,880
5,390
(24.0)
7,150
(31.8)
5,840
(26.0)
7,295
(32.5)
10,750
(47.8)
7,040
(31.3)
(39.5)
N/A
* Allowable values are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values.
78
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
TRUBOLT WEDGE ANCHORS
PERFORMANCE TABLES
Recommended Edge and Spacing Distance Requirements for Shear Loads*
1/4 (6.4)
ANCHOR
TYPE
DEPTH OF
EMBEDMENT
In. (mm)
ANCHOR
DIA.
In. (mm)
1-1/8
(28.6)
1-15/16 (49.2)
3/8 (9.5)
1/2 (12.7)
5/8 (15.9)
MIN. EDGE
DISTANCE AT WHICH
THE LOAD FACTOR
APPLIED = .20
In. (mm)
1-5/16
(33.3)
N/A
3-15/16
(100.0)
2
(50.8)
1-15/16
(49.2)
1
(25.4)
N/A
3-7/8
(98.4)
1-15/16
(49.2)
(38.1)
2-5/8
(66.7)
1-3/4
(44.5)
N/A
3-3/4
(95.3)
3
(76.2)
1-1/2
2-1/4
(57.2)
3-15/16
(100.0)
2-9/16
(65.1)
N/A
4-1/8
(104.8)
5-3/16
(131.8)
3-1/8
(79.4)
1-9/16
(69.9)
(130.2)
3/4 (19.1)
3-1/4
(82.6)
6-5/8
(168.3)
7/8 (22.2)
3-3/4
(95.3)
6-1/4
(158.8)
4-1/4
(108.0)
7-3/8
(187.3)
MIN. ALLOWABLE
SPACING BETWEEN
ANCHORS In. (mm)
LOAD FACTOR
APPLIED = .40
(50.8)
(76.2)
WS-Carbon
or
WS-G
Hot-Dipped
Galvanized
or
WW-304 S.S.
or
SWW-316 S.S.
SPACING REQUIRED
TO OBTAIN MAX.
WORKING LOAD
In. (mm)
2
1-1/2
2-3/4
(25.4)
MIN. EDGE
DISTANCE AT WHICH
THE LOAD FACTOR
APPLIED = .60
In. (mm)
3
5-1/8
1
EDGE DISTANCE
REQUIRED TO
OBTAIN MAX
WORKING LOAD
In. (mm)
5-1/4
(133.4)
2-5/8
(66.7)
(38.1)
6
(152.4)
3
(76.2)
7-7/8
(200.0)
3-15/16
(100.0)
(39.7)
6-3/16
(157.2)
3-1/8
(79.4)
9-5/8
(244.5)
4-13/16
(122.2)
1-15/16 (49.2)
7-11/16
(195.3)
3-7/8
(98.4)
11-3/8
(288.9)
5-11/16
(144.5)
4-13/16
(122.2)
3-1/8
(79.4)
6-7/16
(163.5)
3-7/8
(98.4)
N/A
5-11/16
(144.5)
3-3/4
(95.3)
N/A
6-5/16
(160.3)
5
(127.0)
2-1/2
6-9/16
(166.7)
4-5/16
(109.5)
N/A
8-1/2
(215.9)
6-1/4
(158.8)
3-1/8
7-7/8
(200.0)
5-1/8
(130.2)
N/A
10-1/16
(255.6)
7-3/8
(187.3)
(63.5)
(79.4)
3-11/16 (93.7)
9-15/16
(252.4)
5
(127.0)
13-1/8
(333.4)
6-9/16
(166.7)
12-1/2
(317.5)
6-1/4
(158.8)
15-3/4
(400.1)
7-7/8
(200.0)
14-3/4
(374.7)
7-3/8
(187.3)
* Spacing and edge distances shall be divided by 0.75 when anchors are placed in structural lightweight concrete. Linear interpolation may be used for intermediate spacing and edge distances.
Recommended Edge and Spacing Distance Requirements for Tension Loads*
ANCHOR
DIA.
In. (mm)
1/4 (6.4)
3/8 (9.5)
1/2 (12.7)
5/8 (15.9)
3/4 (19.1)
7/8 (22.2)
1
(25.4)
DEPTH OF
EMBEDMENT
In. (mm)
1-1/8
1-15/16
2-1/8
1-1/2
3
4
2-1/4
4-1/8
6
2-3/4
5-1/8
7-1/2
3-1/4
6-5/8
10
3-3/4
6-1/4
8
4-1/2
7-3/8
9-1/2
(28.6)
(49.2)
(54.0)
(38.1)
(76.2)
(101.6)
(57.2)
(104.8)
(152.4)
(69.9)
(130.2)
(190.5)
(82.6)
(168.3)
(254.0)
(95.3)
(158.8)
(203.2)
(114.3)
(187.3)
(241.3)
ANCHOR
TYPE
WS-Carbon or
WS-G
Hot-Dipped
Galvanized
or
WW-304 S.S.
or
SWW-316 S.S.
EDGE DISTANCE
REQUIRED TO
OBTAIN MAX
WORKING LOAD
In. (mm)
2
1-15/16
1-5/8
2-5/8
3
3
3-15/16
3-1/8
4-1/2
4-13/16
3-7/8
5-5/8
5-11/16
5
7-1/2
6-9/16
6-1/4
6
7-7/8
7-3/8
7-1/8
(50.8)
(49.2)
(41.3)
(66.7)
(76.2)
(76.2)
(100.0)
(79.4)
(114.3)
(122.2)
(98.4)
(142.9)
(144.5)
(127.0)
(190.5)
(166.7)
(158.8)
(152.4)
(200.0)
(187.3)
(181.0)
MIN. EDGE
DISTANCE AT WHICH
THE LOAD FACTOR
APPLIED = .65
In. (mm)
1
1
13/16
1-5/16
1-1/2
1-1/2
2
1-9/16
2-1/4
2-7/16
1-15/16
2-13/16
2-7/8
2-1/2
3-3/4
3-5/16
3-1/8
3
3-15/16
3-11/16
3-9/16
(25.4)
(25.4)
(20.6)
(33.3)
(38.1)
(38.1)
(50.8)
(39.7)
(57.2)
(61.9)
(49.2)
(71.4)
(73.0)
(63.5)
(95.3)
(84.1)
(79.4)
(76.2)
(100.0)
(93.7)
(90.5)
SPACING REQUIRED
TO OBTAIN MAX.
WORKING LOAD
In. (mm)
3-15/16
3-7/8
3-3/16
5-1/4
6
6
7-7/8
6-3/16
9
9-5/8
7-1/16
11-1/4
11-3/8
9-15/16
15
13-1/8
12-1/2
12
15-3/4
14-3/4
14-1/4
(100.0)
(98.4)
(81.0)
(133.4)
(152.4)
(152.4)
(200.0)
(157.2)
(228.6)
(244.5)
(195.3)
(285.8)
(288.9)
(252.4)
(381.0)
(333.4)
(317.5)
(304.8)
(400.1)
(374.7)
(362.0)
MIN. ALLOWABLE
SPACING BETWEEN
ANCHORS In. (mm)
LOAD FACTOR
APPLIED = .70
2
1-15/16
1-5/8
2-5/8
3
3
3-15/16
3-1/8
4-1/2
4-13/16
3-7/8
5-5/8
5-11/16
5
7-1/2
6-9/16
6-1/4
6
7-7/8
7-3/8
7-1/8
(50.8)
(49.2)
(41.3)
(66.7)
(76.2)
(76.2)
(100.0)
(79.4)
(114.3)
(122.2)
(98.4)
(142.9)
(144.5)
(127.0)
(190.5)
(166.7)
(158.8)
(152.4)
(200.0)
(187.3)
(181.0)
* Spacing and edge distances shall be divided by 0.75 when anchors are placed in structural lightweight concrete. Linear interpolation may be used for intermediate spacing and edge distances.
www.ramset.com
79
CONCRETE ANCHORING SYSTEMS
LARGE DIAMETER TapcoN (LDT) ANCHORS
LDT Anchor
Self-Threading Anchors
(3/8" & 1/2")
SPECIFIED FOR ANCHORAGE INTO CONCRETE
The LDT anchor is a high performance anchor that cuts its
own threads into concrete.
Anchor bodies are made of hardened carbon steel and zinc
plated, Grade 5.
LDT
Self-threading The anchors shall have a finished hex washer head with
Anchor
anti-rotation serrations to prevent anchor back-out. The
head of the anchor is stamped with a length identification
code for easy inspection.
(5/8" & 3/4")
Sawtooth™
The anchor shall be installed with carbide tipped hammer
drill bits made in accordance to ANSI B212.15-1994.
Sawtooth Threads™, now available on 5/8" and 3/4"
ADVANTAGES
Save time
Easily Installed
nInstalls in less than half the time of wedge
anchors or adhesive anchors
nSimply drill a pilot hole and drive the LDT anchor
by hand or impact
Easily Removed
nNo torching or grinding required to remove
anchors
Save money
Lower drill bit Costs
nUse standard ANSI bits instead of proprietary bits
nSingle piece design, no nut and washer to
assemble
Use Standard ANSI Bits
nNo special proprietary bits to purchase or lose
nReduce chances for anchor failure due to
incorrect bit usage
LDT SIZE
ANSI
STANDARD
DRILL BIT
DIAMETER
A
ANCHOR HEAD
(SOCKET SIZE)
DIAMETER
Improved performance in large
diameter holes
n Superior performance to wedge anchor
n Higher loads in shallow embedments
n Closer edge/spacing distance than
mechanical anchors
n More threads for better thread engagement and
higher pullout resistance
n Durable induction-hardened tip
Easy installation
n Easy 2-step installation, simply drill a pilot hole
and drive
n Installs in less than half the time of a wedge anchor
n Efficient thread cutting
n Use standard drill bit sizes
n Single piece design—no nut and washer Patented Sawtooth ™ thread
assembly
design drives easily into conn Easily removed
crete to optimize pullout performance and installation speed
WASHER
DIAMETER
B
C
MINIMUM
EMBEDMENT
HOLE DEPTH
A
USE IN
CMU
CONCRETE
HOLLOW
GROUT-FILLED
LDT 3/8"
5/16"
9/16"
13/16"
1-1/2"
2-1/2"
YES
YES
YES
LDT 1/2"
7/16"
3/4"
1"
2-1/2"
3-1/2"
YES
NO
YES
LDT 5/8"
1/2"
13/16"
1-3/16"
2-3/4"
3-3/4"
YES
NO
YES
LDT 3/4"
5/8"
15/16"
1-5/16"
3-1/4"
4-1/4"
YES
NO
YES
80
B
C
www.ramset.com
CONCRETE ANCHORING SYSTEMS
LARGE DIAMETER TapcoN (LDT) ANCHORS
APPLICATIONS
APPROVALS/LISTINGS
Racking, shelving and conveyors
are just a few high volume
applications ideal for Large
Diameter Tapcon (L­DT­™). The
ease and speed of installation of
the LDT can reduce installation
time to less than half the time of
typical systems used today.
For installation speed, high
performance and easy removability,
LDT is the anchor of choice.
Miami-Dade County – #04-1025.08
Florida Building Code
Installation Steps
Installation Steps for Concrete, Lightweight Concrete
and Metal Deck
1.Using the proper size carbide bit (see chart)
drill a pilot hole
at least 1" deeper than anchor
C
embedment.
2.Using an electric impact wrench, or socket
The LDT’s finished head and
lack of exposed threads virtually
eliminates tire damage on fork
lift trucks.
wrench (hand install) insert anchor into hole and
tighten anchor until fully seated. (see chart for
socket size) (do not over tighten).­­
Installation Steps for Hollow or Grout-Filled CMU
(3/8" and 1/2" diameter)
features
Easy Installation
Installs into concrete by hand or
impact wrench
Anti-rotation Serrated Washer
Prevents anchor back-out
Extra Large Hex Washer Head
With increased bearing surface
Length Identification Head Stamp
For embedment inspection after
installation
Hi-Lo Threads
Cuts its own threads into concrete
for greater pull-out resistance
1.Using a 5/16" (for 3/8" LDT) or 7/16" (for 1/2"
LDT) carbide tipped bit, drill a pilot hole at least
1" deeper than anchor embedment.
2. Using a socket wrench insert anchor into hole
and hand tighten anchor until fully seated.
(9/16" socket for 3/8" and 3/4" socket for
1/2") (do not over tighten).­­
LDT’s can be installed by hand or
with an impact wrench
Installation by hand—is easy, simply using a
socket wrench
LDT 3/8" and 1/2" are available with
TM
coating
1,000 hours salt spray ASTM B117. Approved for use in ACQ and
MCQ lumber*
*Excessive content of copper in the ACQ and MCQ lumber may affect the
anchor finish.
www.ramset.com
Installation by impact wrench—is recommended
for faster installations or for high volume
projects. Installation with impact wrench—
is not recommended for hollow block.
81
CONCRETE ANCHORING SYSTEMS
LARGE DIAMETER TapcoN (LDT) ANCHORS
LDT Carbon and Stainless Steel
PART NUMBER
CARBON STEEL
ZINC PLATED
PART NUMBER
CARBON STEEL
COATING
LDT-3816
——
TM
PART NUMBER
FOR 410
STAINLESS STEEL
SLDT-3816
ANCHOR
DIA. In.
(mm)
3/8 (9.5)
EFFECTIVE
LENGTH In.
(mm) (see detail)
DRILL BIT
DIA. In.
(mm)
5/16 (7.9)
1-3/4
(44.5)
MAX. THICKNESS
OF MATERIAL TO BE
FASTENED In. (mm)
1/4 (6.4)
QTY/WT
PER BOX
lbs.
50/ 3.0
QTY/WT PER MASTER
CARTON lbs.
400/ 24.0
LDT-3824
——
SLDT-3824
3/8 (9.5)
5/16 (7.9)
2-1/2
(63.5)
1 (25.4)
50/ 4.5
400/ 34.0
LDT-3830
LDT-3830
SLDT-3830
3/8 (9.5)
5/16 (7.9)
3
(76.2)
1-1/2 (38.1)
50/ 5.0
400/ 40.0
LDT-3840
LDT-3840
SLDT-3840
3/8 (9.5)
5/16 (7.9)
4
(101.6)
2-1/2 (63.5)
50/ 6.5
400/ 52.0
LDT-3850
LDT-3850
SLDT-3850
3/8 (9.5)
5/16 (7.9)
5
(127.0)
3-1/2 (89.0)
40/ 7.5
320/ 60.0
LDT-1230
LDT-1230
SLDT-1230
1/2 (12.7)
7/16 (11.1)
3
(76.2)
1/2 (12.7)
25/ 4.5
150/ 27.0
LDT-1240
LDT-1240
SLDT-1240
1/2 (12.7)
7/16 (11.1)
4
(101.6)
1-1/2 (38.1)
25/ 6.0
150/ 36.6
LDT-1250
LDT-1250
SLDT-1250
1/2 (12.7)
7/16 (11.1)
5
(127.0)
2-1/2 (63.5)
25/ 7.6
150/ 45.6
LDT-1260
——
——
1/2 (12.7)
7/16 (11.1)
6
(152.4)
LDT-5830
——
——
5/8 (15.9)
1/2 (12.7)
3
(76.2)
4 (101.6)
1/4 (6.4)
20/ 9.0
120/ 54.0
10 / 3.5
100 / 35.0
LDT-5840
——
——
5/8 (15.9)
1/2 (12.7)
4
(101.6)
1-1/4 (31.8)
10 / 4.0
100 / 40.0
LDT-5850
——
——
5/8 (15.9)
1/2 (12.7)
5
(127.0)
2-1/4 (57.1)
10 / 4.7
100 / 47.0
LDT-5860
——
——
5/8 (15.9)
1/2 (12.7)
6
(152.4)
3-1/4 (82.6)
10 / 5.4
50 / 27.0
LDT-3444
——
——
3/4 (19.1)
5/8 (15.9)
4-1/2
(114.3)
1-1/4 (31.8)
10 / 7.4
50 / 37.0
LDT-3454
——
——
3/4 (19.1)
5/8 (15.9)
5-1/2
(139.7)
2-1/4 (57.1)
10 / 8.1
50 / 40.5
LDT-3462
——
——
3/4 (19.1)
5/8 (15.9)
6-1/4
(158.8)
3 (76.2)
10 / 9.1
30 / 27.3
* The stainless steel LDT‘s will be gold in color in order to differentiate them from the carbon steel anchors.
Effective
Carbon Steel with Zinc Plating: Meets ASTM B695
and B633 specifications for zinc plating of 5um = .0002" thickness. This coating is well suited for non-corrosive
Length
interior environments. Carbon Steel with EnvireX Coating: Provides additional corrosion protection for outdoor applications.
Length indication code*
Effective
Length
Code
Length of Anchor In. (mm)
A
1-1/2 < 2
B
C
2
2-1/2 < 3
D
E
DESIGN GUIDE
HOLE DIAMETER IN
FIXTURE In. (mm
7/16
(11.1)
82
SUGGESTED LDT
DIAMETER In. (mm)
3/8
(9.5)
1/2
(12.7)
3/8
(9.5)
9/16
(14.3)
1/2
(12.7)
5/8
(15.9)
1/2
(12.7)
3/4
(19.1)
5/8
(15.9)
7/8
(22.2)
3
3/4
G
denotes
available with
coating
TM
< 3-1/2
3-1/2 < 4
F
For proper selection of anchor diameters based upon
predrilled holes in base plates and fixtures.
< 2-1/2
4
< 4-1/2
4-1/2 < 5
H
5
< 5-1/2
(38.1 < 50.8)
(50.8 < 63.5)
(63.5 < 76.2)
(76.2 < 88.9)
(88.9 < 101.6)
(101.6 < 114.3)
(114.3 < 127.0)
(127.0 < 139.7)
I
5-1/2 < 6
(139.7 < 152.4)
J
6
(152.4 < 165.1)
< 6-1/2
* Located on top of anchor for easy inspection.
(19.1)
www.ramset.com
CONCRETE ANCHORING SYSTEMS
LARGE DIAMETER TapcoN (LDT) ANCHORS
PERFORMANCE TABLES
Ultimate Tension and Shear Values (Lbs/kN) in Concrete
ANCHOR
DIA.
In. (mm)
3/8 (9.5)
1/2 (12.7)
5/8 (15.9)
3/4 (19.1)
DEPTH OF
EMBEDMENT
In. (mm)
f’c = 2000 PSI (13.8 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
f’c = 3000 PSI (20.7 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
f’c = 4000 PSI (27.6 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1-1/2
(38.1)
1,336
(5.9)
2,108
(9.4)
1,652
(7.3)
2,764
(12.3)
1,968
(8.8)
3,416
(15.2)
2
(50.8)
1,492
(6.6)
3,036
(13.5)
2,024
(9.0)
3,228
(14.4)
2,552
(11.4)
3,420
(15.2)
2-1/2
(63.5)
3,732
(16.6)
3,312
(14.7)
3,748
(16.7)
3,364
(15.0)
3,760
(16.7)
3,424
(15.2)
3-1/2
(88.9)
5,396
(24.0)
3,312
(14.7)
6,624
(29.5)
3,368
(15.0)
7,852
(34.9)
3,428
(15.2)
2
(50.8)
3,580
(15.9)
5,644
(25.1)
3,908
(17.4)
6,512
(29.0)
4,236
(18.8)
7,380
(32.8)
3-1/2
(88.9)
7,252
(32.3)
6,436
(28.6)
8,044
(35.8)
7,288
(32.4)
8,836
(39.3)
8,140
(36.2)
4-1/2
(114.3)
10,176 (45.3)
7,384
(32.8)
10,332
(46.0)
7,968
(35.4)
10,488
(46.7)
8,552
(38.0)
2-3/4
(69.9)
5,276
(23.5)
8,656
(38.5)
6,560
(29.2)
11,064
(49.2)
7,844
(34.8)
13,476
(59.9)
3-1/2
(88.9)
7,972
(35.5)
10,224 (45.5)
9,848
(43.8)
12,144
(54.0)
11,724
(52.2)
14,060
(62.5)
4-1/2
(114.3)
11,568 (51.5)
12,316 (54.8)
13,432
(59.8)
13,580
(60.4)
16,892
(75.1)
14,840
(66.0)
3-1/4
(82.6)
6,876
7,140
9,756
(43.4)
10,728
(47.7)
12,636
(56.2)
14,316
(63.6)
4-1/2
(114.3)
10,304 (45.8)
13,120 (58.4)
14,424
(64.2)
16,868
(75.0)
18,540
(82.5)
20,612
(91.7)
5-1/2
(139.7)
13,048 (58.0)
17,908 (79.7)
18,156
(80.8)
21,718
(96.9)
23,268
(130.5)
25,652
(114.1)
(30.6)
(31.8)
Allowable Tension and Shear Values (Lbs/kN) in Concrete
Carbon and Stainless Steel
ANCHOR
DIA.
In. (mm)
3/8
1/2
5/8
3/4
(9.5)
(12.7)
(15.9)
(19.1)
DEPTH OF
EMBEDMENT
In. (mm)
f’c = 2000 PSI (13.8 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
f’c = 3000 PSI (20.7 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
f’c = 4000 PSI (27.6 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1-1/2
(38.1)
334
(1.5)
527
(2.3)
413
(1.8)
691
(3.1)
492
(2.1)
854 (3.8)
2
(50.8)
373
(1.7)
759
(3.4)
506
(2.2)
807
(3.6)
638
(2.8)
855 (3.8)
2-1/2
(63.5)
933
(4.2)
828
(3.7)
937
(4.2)
841
(3.7)
940
(4.2)
856 (3.8)
3-1/2
(88.9)
1,349 (6.0)
828
(3.7)
1,656 (7.4)
842
(3.7)
1,963
(8.7)
857 (3.8)
2
(50.8)
895
(4.0)
1,411
(6.3)
(4.3)
1,628 (7.2)
1,059
(4.7)
1,845 (8.2)
3-1/2
(88.9)
1,813 (8.0)
1,609
(7.2)
2,011 (8.9)
977
1,822 (8.1)
2,209
(9.8)
2,035 (9.0)
4-1/2
(114.3)
2,544 (11.3)
1,846
(8.2)
2,583 (11.5)
1,992 (8.9)
2,622
(11.7)
2,138 (9.5)
2-3/4
(69.9)
1,319 (5.9)
2,164
(9.7)
1,640 (7.3)
2,766 (12.3)
1,961
(8.7)
3,369 (15.0)
3-1/2
(88.9)
1,993 (8.9)
2,556
(11.4)
2,462 (10.9)
3,036 (13.5)
2,931
(13.0)
3,515 (15.6)
4-1/2
(114.3)
2,892 (12.9)
3,079
(13.7)
3,358 (14.9)
3,395 (15.1)
4,223
(18.8)
3,710 (16.5)
3-1/4
(82.6)
1,719 (7.6)
1,785
(7.9)
2,439 (10.8)
2,682 (11.9)
3,159
(14.0)
3,579 (15.9)
4-1/2
(114.3)
2,576 (11.5)
3,280
(14.6)
3,606 (16.0)
4,217 (18.7)
4,635
(20.6)
5,153 (22.9)
5-1/2
(139.7)
3,262 (14.5)
4,477
(19.9)
4,539 (20.2)
5,445 (24.2)
5,817
(25.9)
6,413 (28.5)
* Allowable values are based upon a 4 to 1 safety factor. (Ultimate/4)
www.ramset.com
83
CONCRETE ANCHORING SYSTEMS
LARGE DIAMETER TapcoN (LDT) ANCHORS
PERFORMANCE TABLES
Recommended Edge and Spacing Distance Requirements for Tension Loads*
Carbon and Stainless Steel
ANCHOR
DIA.
In. (mm)
3/8
1/2
(9.5)
(12.7)
DEPTH OF
EMBEDMENT
In. (mm)
EDGE DISTANCE
REQUIRED TO
OBTAIN MAX
WORKING LOAD
In. (mm)
LOAD FACTOR APPLIED AT
MIN. EDGE DISTANCE
1-3/4 Inches (44mm)
SPACING DISTANCE
REQUIRED TO OBTAIN
MAX. WORKING LOAD
In. (mm)
LOAD FACTOR APPLIED
AT MIN. SPACING DISTANCE
3 Inches (76mm)
1-1/2
(38.1)
2
(50.8)
70%
6
(152.4)
44%
2
(50.8)
2
(50.8)
70%
6
(152.4)
44%
2-1/2
(63.5)
3
(76.2)
70%
6
(152.4)
44%
3-1/2
(88.9)
4
(101.6)
70%
6
(152.4)
44%
2
(50.8)
2-1/4
(57.2)
65%
8
(203.2)
27%
3-1/2
(88.9)
3
(76.2)
65%
8
(203.2)
27%
4-1/2
(114.3)
4
(101.6)
65%
8
(203.2)
27%
* Edge and spacing distance shall be divided by .75 when anchors are placed in structural lightweight concrete. Linear interpolation may be used for intermediate spacing and edge distances.
For 5/8" and 3/4" LDT Anchors, the critical edge distance for these anchors is 10 times the anchor diameter. The edge distance of these anchors may be reduced to 1-3/4" provided a 0.65 load
factor is used for tension loads, a 0.15 load factor is used for shear loads applied perpendicular to the edge, or a 0.60 load factor is used for shear loads applied parallel to the edge. Linear interpolation
may be used for intermediate edge distances.
Recommended Edge and Spacing Distance Requirements for Shear Loads*
Carbon and Stainless Steel
ANCHOR
DIA.
In. (mm)
3/8
1/2
(9.5)
(12.7)
DEPTH OF
EMBEDMENT
In. (mm)
EDGE DISTANCE
REQUIRED TO
OBTAIN MAX
WORKING LOAD
In. (mm)
LOAD FACTOR APPLIED AT
MIN. EDGE DISTANCE
1-3/4 Inches (44mm)
SPACING DISTANCE
REQUIRED TO OBTAIN
MAX. WORKING LOAD
In. (mm)
LOAD FACTOR APPLIED
AT MIN. SPACING DISTANCE
3 Inches (76mm)
1-1/2
(38.1)
3
(76.2)
25%
6
(152.4)
57%
2
(50.8)
4
(101.6)
25%
6
(152.4)
57%
2-1/2
(63.5)
5
(127.0)
25%
6
(152.4)
57%
3-1/2
(88.9)
5
(127.0)
25%
6
(152.4)
57%
2
(50.8)
5
(127.0)
25%
8
(203.2)
60%
3-1/2
(88.9)
5
(127.0)
25%
8
(203.2)
60%
4-1/2
(114.3)
5-1/2
(139.7)
25%
8
(203.2)
60%
* Edge and spacing distances shall be divided by .75 when anchors are placed in structural lightweight concrete. Linear interpolation may be used for intermediate spacing and edge distances.
Ulitmate Tension Load (Lbs/kN) in Concrete Block
Anchors should be installed by hand in hollow block
ANCHOR
DIA.
In. (mm)
DEPTH OF
EMBEDMENT
In. (mm)
3/8
(9.5)
1-1/2 (38.1)
1/2
(12.7)
2-1/2 (63.5)
84
HOLLOW CONCRETE BLOCK
TENSION Lbs. (kN)
916
(4.1)
N/A
GROUT FILLED CONCRETE BLOCK
SHEAR Lbs. (kN)
3,176
N/A
(14.1)
TENSION Lbs. (kN)
SHEAR Lbs. (kN)
1,592
(7.1)
3,900
(17.3)
5,924
(26.4)
6,680
(29.7)
www.ramset.com
CONCRETE ANCHORING SYSTEMS
LARGE DIAMETER TapcoN (LDT) ANCHORS
PERFORMANCE TABLES
Allowable Tension and Shear* (Lbs/kN) in Concrete Block
Anchors should be installed by hand in hollow block
ANCHOR
DIA.
In. (mm)
DEPTH OF
EMBEDMENT
In. (mm)
3/8
(9.5)
1-1/2 (38.1)
1/2
(12.7)
2-1/2 (63.5)
HOLLOW CONCRETE BLOCK
TENSION Lbs. (kN)
229
GROUT FILLED CONCRETE BLOCK
SHEAR Lbs. (kN)
(1.0)
794
N/A
TENSION Lbs. (kN)
(3.5)
N/A
SHEAR Lbs. (kN)
398
(1.8)
975
(4.3)
1,481
(6.6)
1,670
(7.4)
* Allowable values are based upon a 4 to 1 safety factor. (Ultimate/4)
Anchoring Overhead in 3000 PSI Lightweight Concrete On Metal Deck
ANCHOR
3/8" LDT
DRILL HOLE
DIAMETER
In. (mm)
5/16" (7.9)
EMBEDMENT
In. (mm)
3000 PSI (20.7 MPa) CONCRETE
ULTIMATE TENSION LOAD
Lbs. (kN)
1-1/2 (38.1)
ALLOWABLE WORKING LOAD
Lbs. (kN)
Upper Flute
2,889
(12.9)
722
(3.2)
Lower Flute
1,862
(8.3)
465
(2.1)
The Easy, Fast, High Performing, Removable Tapcon
Anchor, Now Available in 3/8" and 1/2" Diameter
For use in concrete
and concrete block
1/2" LDT
1/2" adhesive
5/8" wedge
installs in 1/2 the time
Difficult to remove
permanent application
Easily removed
Exposed threads
Exposed threads
finished head
5-Step installation
Difficult to remove
Cure time
Drill bit size required
LDT anchors specify a
smaller & less expensive drill
bit than those required with
the 1/2" adhesive threaded
rod or the 5/8" wedge.
hole Depth required
At 4-1/2" embedment the
LDT anchor will give you
performance (2000 PSI
concrete) similar to 1/2"
adhesive anchor of the
same depth or 5/8" wedge
anchors at 7" deep.
(2000 PSI concrete)
www.ramset.com
7/16" drill bit
4-1/2"
9/16" drill bit
5/8" drill bit
4-1/2"
7"
85
CONCRETE ANCHORING SYSTEMS
Multi-Set II Drop-IN ANCHORS
Multi-Set II Internally Threaded Heavy-Duty Anchoring Systems
Drop-In, Shell-Type Anchors
SPECIFIED FOR ANCHORAGE INTO CONCRETE
Drop-In, shell-type anchors feature an internally threaded, all-steel shell with expansion cone insert
and flush embedment lip. Anchors are manufactured from zinc-plated carbon steel, 18-8 stainless steel
and 316 stainless steel.
Anchors should be installed with carbide tipped hammer drill bits made in accordance to ANSI
B212.15-1994 specifications.
Anchors should be tested to ASTM E488 criteria and listed by ICC-ES. Anchors should also be listed by
the following agencies as required by the local building code: UL, FM, City of Los Angeles, California
State Fire Marshal and Caltrans.
Multi-Set II Drop-In Anchors
ADVANTAGES
Depth Charge Stop Drill and RX Drop-In Anchors
ADVANTAGES
RM Drop-In Anchor
Ideal for Hollow-Core, Pre-Cast Plank and Post Tension Slabs
n Lipped anchor body keeps
anchor flush
n Easy installation
n Keeps all rods same length
n Easy inspection
TM
n Available in carbon steel,
18-8 and 316 stainless steel
RL Drop-In Anchor
n Below surface setting
for easy patch work
n Higher performance
potential with deep
embedment setting
n Optimized for use in
hollow-core, pre-cast plank
and post-tension slabs
n Lip keeps anchor flush
during installation
n Shallow drilling—fast
installation
Coil Thread Anchor
RX Drop-In
Anchor
n Quick thread attachment —
ideal for 1 sided forming
n Use coil rod on job
n 2 diameters (1/2" and 3/4")
See page 88 for kits
86
www.ramset.com
CONCRETE ANCHORING SYSTEMS
Multi-Set II Drop-IN ANCHORS
APPLICATIONS
APPROVALS / LISTINGS
Pumps and heavy piping are
common applications for larger
diameter Multi-Set Drop-In
Anchors.
Meets or exceeds U.S. Government G.S.A. Specification A-A-55614
Type 1 (Formerly GSA: FF-S-325 Group VIII)
Underwriters Laboratories
Factory Mutual
City of Los Angeles – #RR2748
Cable tray and strut suspended
from concrete ceilings are ideal
Multi-Set applications. In posttension or hollow-core slabs use
the RX-38.
The Multi-Set Anchor is the
standard for pipe-hanging. The
RM version has a retainer lip
to keep all anchors flush at
the surface, keeping all your
threaded rod the same length.
California State Fire Marshal
Caltrans
INSTALLATION STEPS
To set anchor flush with surface:
1. Drill hole to required embedment
(see Table on page XX).
2. Clean hole with pressurized air.
FEATURES
Expander Slots—allow for
easy setting and superior
performance
3. Drive anchor flush with surface of concrete.
Cone Insert—that expands the
anchor when driven with setting
tool and hammer
Body—available in zinc-plated
steel, 18-8 stainless steel, and
316 stainless steel
Easy Depth Inspection—keeps
threaded rod drop lengths
consistent
Retainer Lip—to keep anchor
flush with surface
For use with threaded rods or
headed bolts
(supplied by contractor)
4. Expand anchor with setting tool provided (see
chart on page XX). Anchor is properly expanded
when shoulder of setting tool is flush with top of
anchor.
To set anchor below surface:
Drill hole deeper than anchor length. Thread bolt into anchor.
Hammer anchor into hole until bolt head is at desired depth.
Remove bolt and set anchor with setting tool.
TM
Multi-Set II Depth Charge Bits
PART
NUMBER
DESCRIPTION
DRILLING
DEPTH
DCX-138
3/8" Depth Charge Stop Drill
3/4"
DCX-112
1/2" Depth Charge Stop Drill
1"
www.ramset.com
n Shoulder prevents over drilling
n Less likely to hit reinforcing steel
or post-tension cable in concrete
n No lost time or energy drilling
farther than necessary
n Anchor is set at a specified depth,
does not drop too far into hole
87
CONCRETE ANCHORING SYSTEMS
Multi-Set II Drop-IN ANCHORS
PART NUMBER RT-138
1 setting tool per master carton
PART NUMBER RTX-138
For use with RX-38 only.
PART NUMBER RTX-112
For use with RX-12 only.
Multi-Set II Drop-In Anchors
USER/TYPE
APPLICATION
BASE
MATERIAL
CORROSION
RESISTANCE
LEVEL
DROP-IN
ANCHOR
TYPE
RM
Solid concrete/
lightweight fill
deck
HVAC/Fire
Sprinkler
Plumber
(Pipe-fitter)
Hollow-core
pre-cast or
Post-tension
RX
Solid concrete
Medium
High
SSRM**
316 S.S.
CL-Coil
Threaded
Solid concrete
Solid concrete/
lightweight fill
deck
* 1 setting tool per master carton.
BOLT SIZE
THREADS
PER INCH
DRILL BIT
DIA. In. (mm)
THREAD
DEPTH In.
(mm)
RM-14
RT-114
1/4" - 20
3/8 (9.5)
3/8
1
(25.4)
1-5/8 (41.3)
QTY/WT
PER BOX
Lbs.
100/ 2.6
QTY/WT PER
MASTER
CTN Lbs.*
1000/ 28
RM-38
RT-138
3/8" - 16
1/2 (12.7)
1/2
(12.7)
RM-12
RT-112
1/2" - 13
5/8 (15.9)
3/4
(19.1)
7/8 (22.2)
1
(25.4)
2-1/2 (63.5)
25/ 7.8
125/ 41
1-1/4 (31.8)
3-3/16 (81.0)
25/ 11.9
100/ 49
100/ 3.5
1000/ 36
2
(50.8)
50/ 3.4
500/ 36
50/ 5.8
400/ 49
RM-58
RT-158
5/8" - 11
RM-34
RT-134
3/4" - 10
RX-38
RTX-138
3/8" - 16
1/2 (12.7)
3/8
(9.5)
3/4 (19.1)
RX-12
RTX-112
1/2" - 13
5/8 (15.9)
1/2
(12.7)
1
(25.4)
50/ 3.0
500/ 31
1
(25.4)
100/ 2.7
1000/ 28
1-5/8 (41.3)
50/ 3.4
500/ 36
50/ 6.0
400/ 50
1
(25.4)
SRM-14
RT-114
1/4" - 20
3/8 (9.5)
3/8
(9.5)
SRM-38
RT-138
3/8" - 16
1/2 (12.7)
1/2
(12.7)
SRM-12
RT-112
1/2" - 13
5/8 (15.9)
3/4
(19.1)
7/8 (22.2)
1
(25.4)
2-1/2 (63.5)
25/ 18.0
125/ 42
1-1/4 (31.8)
3-3/16 (81.0)
25/ 12.0
100/ 50
SRM-58
RT-158
5/8" - 11
SRM-34
RT-134
3/4" - 10
1
(25.4)
2
(50.8)
SSRM-38
RT-138
3/8" - 16
1/2 (12.7)
1/2
(12.7)
50/ 3.4
500/ 36
SSRM-12
RT-112
1/2" - 13
5/8 (15.9)
3/4
(19.1)
2
(50.8)
50/ 6.0
400/ 50
CL-12
RT-112
1/2" - 6
5/8 (15.9)
3/4
(19.1)
2
(50.8)
50/ 5.7
400/ 47
CL-34
RT-134
3/4" - 4.5
3-3/16 (81.0)
25/ 11.9
100/ 49
RL-14
RT-114
1/4" - 20
100/ 2.6
1000/ 28
Low
1
(25.4)
3/8 (9.5)
1-1/4 (31.8)
3/8
1-5/8 (41.3)
(9.5)
1
(25.4)
RL-38
RT-138
3/8" - 16
1/2 (12.7)
1/2
(12.7)
RL-12
RT-112
1/2" - 13
5/8 (15.9)
3/4
(19.1)
7/8 (22.2)
1
(25.4)
2-1/2 (63.5)
25/ 7.8
125/ 41
1-1/4 (31.8)
3-3/16 (81.0)
25/ 11.9
100/ 49
RL-58
RT-158
5/8" - 11
RL-34
RT-134
3/4" - 10
1
(25.4)
1-5/8 (41.3)
2
(50.8)
50/ 3.4
500/ 36
50/ 5.8
400/ 49
** For continuous extreme low temperature, use stainless steel.
Multi-Set II
Combined Tension and Shear Loading
for Multi-Set Anchors
Allowable loads for anchors subjected to combined shear and
tension forces are determined by the following equation:
(Ps/Pt ) 5/3 + (Vs /Vt ) 5/3 < 1
Ps = Applied tension load
Vs = Applied shear load
Pt = Allowable tension load
Vt = Allowable shear load
88
(9.5)
EMBEDMENT
MIN. HOLE
DEPTH In.
(mm)
Low
RL (w/o lip)
Concrete Cutting/
Sawing
Contractor/
Misc. Metal
SETTING
TOOL PART
NUMBER*
Low
SRM
Solid concrete/
lightweight fill
deck
Concrete
Contractor,
General
COntractor,
Highway
Low
PART
NUMBER
PART
NUMBER
RX-38
RX Drop-In Kits
DESCRIPTION
3/8" drop-in using 1/2" drill bit
RTX-138
Setting Tool
DCX-138
Depth Charge Stop Drill
RX-38KIT
Contains: 1,000 RX-38 Anchors, 5 RTX-138 Setting Tools and 2
DCX-138 Depth Charge Stop Drills
RX-12
1/2" drop-in using 5/8" drill bit
RTX-112
Setting Tool
DCX-112
Depth Charge Stop Drill
RX-12KIT
Contains: 500 RX-12 Anchors, 3 RTX-112 Setting Tools and 1
DCX-112 Depth Charge Stop Drill
www.ramset.com
CONCRETE ANCHORING SYSTEMS
Multi-Set II Drop-IN ANCHORS
PERFORMANCE TABLES
Ultimate Tension and Shear Values (Lbs/kN) in Concrete*
BOLT DIA.
In. (mm)
ANCHOR DIA.
In. (mm)
MIN. EMBEDMENT
DEPTH In. (mm)
1/4
(6.4)
3/8
(9.5)
3/8
(9.5)
1/2
(12.7)
1
(25.4)
1/2
(12.7)
5/8
(15.9)
5/8
(15.9)
7/8
(22.2)
2-1/2 (63.5)
3/4
(19.1)
1
(25.4)
3-3/16 (81.0)
1-5/8 (41.3)
2
(50.8)
ANCHOR TYPE
RM, RL or
CL-Carbon
or
SRM-18-8 S.S.
or SSRM-316 S.S.
TENSION
SHEAR Lbs. (kN)
f’c = 2000 PSI
(13.8 MPa)
f’c = 4000 PSI
(27.6 MPa)
f’c = 6000 PSI
(41.4 MPa)
f’c > 2000 PSI
(13.8 MPa)
1,680 (7.5)
2,360 (10.5)
2,980
(13.3)
1,080 (4.8)
2,980 (13.3)
3,800 (16.9)
6,240
(27.8)
3,160 (14.1)
3,300 (14.7)
5,840 (26.0)
8,300
(36.9)
4,580 (20.4)
5,500 (24.5)
8,640 (38.4)
11,020 (49.0)
7,440 (33.1)
8,280 (36.8)
9,480 (42.2)
12,260 (54.5)
10,480 (46.6)
* Allowable values are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values.
* For continuous extreme low temperature applications, use stainless steel.
Ultimate Tension and Shear Values (Lbs/kN) in Lightweight Concrete*
BOLT DIA.
In. (mm)
ANCHOR DIA.
In. (mm)
MIN. EMBEDMENT
DEPTH In. (mm)
ANCHOR TYPE
LIGHTWEIGHT CONCRETE
f’c = 3000 PSI (20.7 MPa)
TENSION
Lbs. (kN)
3/8
(9.5)
1/2
(12.7)
1-5/8 (39.7)
1/2
(12.7)
5/8
(15.9)
5/8
(15.9)
7/8
(22.2)
2-1/2 (63.5)
3/4
(19.1)
1
(25.4)
3-3/16 (81.0)
2
(50.8)
RM, RL or
CL-Carbon or
SRM-18-8 S.S.
or SSRM-316 S.S.
LOWER FLUTE OF STEEL DECK WITH
LIGHTWEIGHT CONCRETE FILL
f’c = 3000 PSI (20.7 MPa)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
2,035
(9.1)
1,895
(8.4)
3,340
(14.9)
4,420
(19.6)
2,740
(12.2)
2,750
(12.2)
3,200
(14.2)
4,940
(22.0)
4,240
(18.9)
4,465
(19.9)
5,960
(26.5)
5,840
(26.0)
5,330
(23.7)
6,290
(28.0)
8,180
(36.4)
9,120
(40.6)
* Allowable values are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values.
Recommended Edge and Spacing Distance Requirements*
BOLT DIA.
In.(mm)
DRILL BIT SIZE
In. (mm)
1/4 (6.4)
3/8
(9.5)
3/8 (9.5)
1/2
(12.7)
1/2 (12.7)
5/8
(15.9)
EMBEDMENT
DEPTH
In. (mm)
1
(25.4)
1-5/8 (41.3)
2
(50.8)
5/8 (15.9)
7/8
(22.2)
2-1/2 (63.5)
3/4 (19.1)
1
(25.4)
3-3/16 (81.0)
ANCHOR
TYPE
EDGE DISTANCE
REQUIRED TO OBTAIN
MAX. WORKING LOAD
In. (mm)
MIN. EDGE DISTANCE AT
WHICH LOAD FACTOR APPLIED
=.80 FOR TENSION
=.70 FOR SHEAR
In. (mm)
1-3/4
(44.5)
7/8
(22.2)
CL-Carbon or
2-7/8
(73.0)
1-7/16
(36.5)
SRM-18-8 S.S.
3-1/2
(88.9)
1-3/4
(44.5)
4-3/8
(111.1)
2-3/16
(55.6)
5-5/8
(142.9)
2-13/16
(71.4)
RM, RL or
or
SSRM-316 S.S.
SPACING
REQUIRED TO OBTAIN
MAX. WORKING LOAD
In. (mm)
3-1/2
(88.9)
5-11/16 (144.5)
MIN. ALLOWABLE SPACING
BETWEEN ANCHORS LOAD
FACTOR APPLIED
= .80 FOR TENSION
=.70 FOR SHEAR
In. (mm)
1-3/4
(44.5)
2-7/8
(73.0)
7
(177.8)
3-1/2
(88.9)
8-3/4
(222.3)
4-3/8
(111.1)
11-3/16 (284.2)
5-5/8
(142.9)
* Spacing and edge distances shall be divided by 0.75 when anchors are placed in structural lightweight concrete. Linear interpolation may be used for intermediate spacing and edge distances.
www.ramset.com
89
CONCRETE ANCHORING SYSTEMS
Multi-Set II Drop-IN ANCHORS
PERFORMANCE TABLES
Ultimate Tension and Shear Values (Lbs/kN) in Concrete
BOLT
DIA.
In. (mm)
DRILL BIT
SIZE
In. (mm)
EMBEDMENT
In. (mm)
2500 PSI (17.2 MPa) CONCRETE
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
4000 PSI (27.6 MPa) CONCRETE
TENSION
Lbs. (kN)
HOLLOW CORE
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
3/8 (9.5)
1/2 (12.7)
3/4
(19.1)
1,571
(7.0)
2,295
(10.2)
1,987
(8.8)
2,903
(12.9)
1,908 (8.5)
2,401
(10.7)
1/2 (12.7)
5/8 (15.9)
1
(25.4)
2,113
(9.4)
2,585
(11.5)
2,673
(11.9)
3,270
(14.5)
2,462 (11.0)
2,401
(10.7)
* The tabulated values are for RX anchors installed at a minimum of 12 diameters on center and minimum edge distance of 6 diameters for 100 percent anchor efficiency. Spacing and edge distance may be
reduced to 6 diameters spacing and 3 diameter edge distance provided the values are reduced 50 percent. Linear Interpolation may be used for intermediate spacings and edge margins.
Anchoring Overhead in 3000 PSI Lightweight Concrete On Metal Deck
ANCHOR
RX-38 Drop-In
DRILL HOLE
DIAMETER
In. (mm)
1/2 (12.7)
EMBEDMENT
In. (mm)
3/4
(19.1)
3000 PSI (20.7 MPa) CONCRETE
ULTIMATE TENSION LOAD
Lbs. (kN)
ALLOWABLE WORKING LOAD
Lbs. (kN)
Upper Flute
1,410
(6.3)
353
(1.6)
Lower Flute
1,206
(5.4)
301
(1.3)
20 Gauge
Metal Deck
Lower Flute
RX Drop-In
Installed in
Upper Flute
* Allowable values are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values.
90
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
DYNABOLT SLEEVE ANCHORS
Dynabolt Sleeve Anchors
®
Sleeve Type Anchors
specified for anchorage into concrete, grout-filled concrete
block
Dynabolt
Masonry
Sleeve
Anchor
Dynabolt
Hex Nut Sleeve Anchor
Sleeve type anchors feature a split expansion sleeve over
a threaded stud bolt body and integral expander, nut and
washer.
Anchors are made of Plated Carbon Steel, or Type 18-8
Stainless Steel.
Anchors should be installed with carbide tipped hammer
drill bits made in accordance to ANSI B212.15-1994
ADVANTAGES
n Anchor diameter equals hole diameter
n Available in hex head and six other head
styles
n Available 1/4 - 3/4" diameter up to
6-1/4" length
n Zinc plated carbon steel and 304
stainless steel
n Provides full 360° hole contact over
large area and reduces concrete stress
n Heavy-loading capacity
n Preassembled for faster, easier
installations
n Dynabolt can be installed through object
to be fastened
n Sleeve design improves holding power
n No pre-spotting of holes necessary
APPROVALS / LISTINGS
Available Head Styles
Full range of head style, corrosion protection, and sizes makes the Dynabolt Sleeve
the right product for almost any application.
Phillips Hex Nut
Acorn Nut
Tie Wire
Round Head
Flat Head
(FS)
(HN)
(AN)
(TW)
(RS)
Threshold
Flat Head
(TH)
InSTALLATION STEPS
1. Use a bit with a diameter
equal to the anchor. See
selection chart to determine
proper size bit for anchor
used. Drill hole to any
depth exceeding minimum
embedment. Clean hole.
2. Insert assembled
anchor into hole,
so that washer or
head is flush with
materials to be
fastened.
3.Expand anchor
by tightening
nut or head 2
to 3 turns.
APPLICATIONS
Meets or exceeds U.S. Government G.S.A.
Specification A-A-1922A (Formerly GSA:
FF-S-325 Group II, Type 3, Class 3)
Factory Mutual
California State Fire Marshal
Electrical junction boxes are common applications for the Dynabolt
Sleeve anchor because it works
well in solid concrete, concrete
block, and brick. It is also available
in several finished head styles.
www.ramset.com
The Dynabolt Sleeve anchor
works well in hollow materials
like brick and block. It is available in zinc-plated carbon steel
and 304 stainless steel.
Door and window frames are
commonly attached to the
structure with Dynabolt Sleeve
anchors because of their finished
& threshold head styles and performance in block & brick.
91
CONCRETE ANCHORING SYSTEMS
®
DYNABOLT SLEEVE ANCHORS
ACORN
NUT
HEAD
STYLE
Dynabolt Carbon Steel with Zinc Plating
PART
NUMBER
ANCHOR
DIA. & DRILL
BIT SIZE
AN-1405
1/4"
AN-1413
AN-1422
HN-1413
HEX NUT
5/8
(15.9)
3/16"
/24
1/2
(12.7)
1/8
(3.2)
100/
1.9
1000/
20
1-3/8
(34.9)
3/16"
/24
1-1/8
(28.6)
1/4
(6.4)
100/
2.6
1000/
27
3/16"
/24
1-1/8
(28.6)
1-1/8
(28.6)
100/
3.7
1000/
38
3/16"
/24
1-1/8
(28.6)
1/4
(6.4)
100/
2.3
1000/
24
2-1/4
(57.2)
3/16"
/24
1-1/8
(28.6)
1-1/8
(28.6)
100/
3.4
1000/
35
5/16"
1-1/2
(38.1)
1/4"
/20
1-1/4
(31.8)
1/4
(6.4)
100/
4.0
1000/
41
2-1/2
(63.5)
1/4"
/20
1-1/4
(31.8)
1-1/4
(31.8)
100/
5.9
800/
47
3/8"
1-7/8
(47.6)
5/16"
/18
1-1/2
(38.1)
3/8
(9.5)
50/
3.5
500/
36
3
(76.2)
5/16"
/18
1-1/2
(38.1)
1-1/2
(38.1)
50/
4.9
400/
40
1/2"
5/8"
2-1/4
(57.2)
3/8"
/16
1-7/8
(47.6)
3/8
(9.5)
25/
3.3
250/
34
3
(76.2)
3/8"
/16
1-7/8
(47.6)
1-1/8
(28.6)
25/
4.0
200/
33
4
(101.6)
3/8"
/16
1-7/8
(47.6)
2-1/8
(54.0)
25/
5.3
200/
44
2-1/4
(57.2)
1/2"
/13
2
(50.8)
1/4
(6.4)
25/
6.3
150/
38
HN-5830
3
(76.2)
1/2"
/13
2
(50.8)
1
(25.4)
25/
7.0
150/
46
HN-5842
4-1/4
(108.0)
1/2"
/13
2
(50.8)
2-1/4
(57.2)
10/
3.9
100/
41
HN-5860
6
(152.4)
1/2"
/13
2
(50.8)
4
(101.6)
10/
4.9
50/
25
2-1/2
(63.5)
5/8"
/11
2-1/4
(57.2)
1/4
(6.4)
10/
4.7
50/
25
HN-3440
4
(101.6)
5/8"
/11
2-1/4
(57.2)
1-3/4
(44.5)
5/
3.2
50/
33
HN-3462
6-1/4
(158.8)
5/8"
/11
2-1/4
(57.2)
4
(101.6)
5/
4.3
50/
44
3/4"
1-1/2
(38.1)
3/16"
/24
1-1/8
(28.6)
3/8
(9.5)
100/
1.9
1000/
21
2-1/4
(57.2)
3/16"
/24
1-1/8
(28.6)
1-1/8
(28.6)
100/
2.7
1000/
28
FS-1430
3-1/8
(79.4)
3/16"
/24
1-1/8
(28.6)
2
(50.8)
100/
3.8
1000/
38
FS-1440
4
(101.6)
3/16"
/24
1-1/8
(28.6)
2-7/8
(73.0)
100/
4.7
1000/
48
FS-1411
PHILLIPS FLAT HEAD*
QTY/WT PER
MASTER
CARTON lbs.
(57.2)
HN-1240
HN-3424
TIE ROUND THRESHOLD
WIRE HEAD
HEAD
QTY/WT PER
BOX lbs.
(34.9)
HN-1230
HN-5822
MAX. THICKNESS
OF MATERIAL TO
BE FASTENED
In. (mm)
2-1/4
HN-3830
HN-1222
MIN. EMBEDMENT
In, (mm)
1-3/8
HN-1624
HN-3817
BOLT DIA./
THREADS PER
INCH
1/4"
HN-1422
HN-1614
EFFECTIVE ANCHOR
LENGTH*
In. (mm)
FS-1420
FS-3826
FS-3840
1/4"
(head dia.
.477)
3/8"
(head dia.
.722)
2-7/8
(73.0)
5/16"
/18
1-1/2
(38.1)
1-3/8
(34.9)
50/
3.8
500/
40
4
(101.6)
5/16"
/18
1-1/2
(38.1)
2-1/2
(63.5)
50/
5.3
400/
44
FS-3850
5
(127.0)
5/16"
/18
1-1/2
(38.1)
3-1/2
(88.9)
50/
5.6
300/
40
FS-3860
6
(152.4)
5/16"
/18
1-1/2
(38.1)
4-1/2
(114.3)
50/
8.0
300/
48
TH-1420
1/4" (head
dia. .385)
2-1/4
(57.2)
3/16"
/24
1-1/8
(28.6)
1-1/8
(28.6)
100/
2.5
1000/
25
RS-1426
1/4"
2-7/8
(73.0)
3/16"
/24
1-1/8
(28.6)
1-3/4
(44.5)
100/
3.7
1000/
38
TW-1614
5/16"
1-1/2
(38.1)
1/4"
/20
1-1/2
(38.1)
9/32
(7.1)
100/
hole
4.9
1000/
50
* Phillips flat head uses a standard 80°– 82° counter sink.
Typical Applications—Shelf ledgers,
electrical boxes, conduit
Environment—Interior (non-corrosive)
Level of Corrosion—Low
* Effective Anchor Length
A
A
A
(FS) (HN) (RS)
92
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
DYNABOLT SLEEVE ANCHORS
Dynabolt Type 304 Stainless Steel
ANCHOR
DIA. & DRILL
BIT SIZE
SHN-1413
1/4"
1-3/8
SHN-3817
3/8"
1-7/8
1/2"
SHN-1230
SHN-1240
HEAD
STYLE
PART
NUMBER
HEX NUT
SHN-3830
MIN. EMBEDMENT
In, (mm)
MAX. THICKNESS
OF MATERIAL TO
BE FASTENED
In. (mm)
QTY/WT PER
BOX lbs.
QTY/WT PER
MASTER
CARTON lbs.
(34.9)
3/16"
/24
1-1/8
(28.6)
1/4
(6.4)
100/
2.3
1000/
24
(47.6)
5/16"
/18
1-1/2
(38.1)
3/8
(9.5)
50/
3.5
500/
36
3
(76.2)
5/16"
/18
1-1/2
(38.1)
1-1/2
(38.1)
50/
4.9
400/
40
2-1/4
(57.2)
3/8"
/16
1-7/8
(47.6)
3/8
(9.5)
25/
3.3
250/
34
3
(76.2)
3/8"
/16
1-7/8
(47.6)
1-1/8
(28.6)
25/
4.0
200/
33
4
(101.6)
3/8"
/16
1-7/8
(47.6)
2-1/8
(54.0)
25/
5.3
200/
44
SHN-5842
5/8"
4-1/4
(108.0)
1/2"
/13
2
(50.8)
2-1/4
(57.2)
10/
3.9
100/
41
PHILLIPS FLAT
HEAD*
BOLT DIA./
THREADS PER
INCH
SFS-1420
1/4"
2-1/4
(57.2)
3/16"
/24
1-1/8
(28.6)
1-1/8
(28.6)
100/
2.7
1000/
28
3-1/8
(79.4)
3/16"
/24
1-1/8
(28.6)
3
(76.2)
100/
3.8
1000/
38
2-7/8
(73.0)
5/16"
/18
1-1/2
(38.1)
1-3/8
(34.9)
50/
3.8
500/
40
4
(101.6)
5/16"
/18
1-1/2
(38.1)
2-1/2
(63.5)
50/
5.3
400/
44
ROUND
HEAD
SHN-1222
EFFECTIVE ANCHOR
LENGTH*
In. (mm)
SRS-1420
2
(50.8)
3/16"
/24
1-1/8
(28.6)
7/8
(22.2)
100/
2.7
1000/
28
SFS-1430
SFS-3826
3/8"
SFS-3840
1/4"
* Flat head uses a standard 80°– 82° counter sink. For continuous extreme low temperature applications, use stainless steel.
PERFORMANCE TABLES
Ultimate Tension and Shear Values in Concrete (Lbs/kN)*
BOLT DIA.
In. (mm)
INSTALLATION
TORQUE
FT. Lbs. (Nm)
ANCHOR
DIA.
In. (mm)
ANCHOR
TYPE
(STEEL)
MIN.
EMBEDMENT
DEPTH In. (mm)
2000 PSI (13.8 MPa)
TENSION
Lbs. (kN)
3000 PSI (20.7 MPa)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
4000 PSI (27.6 MPa)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1/4
(6.4)
3.5
(4.7)
3/16
(4.8)
1-1/8
(28.6)
1,200 (5.3)
1,620
(7.2)
1,600
(7.1)
1,620
(7.2)
2,100
(9.3)
1,620
(7.2)
5/16
(7.9)
8
(10.8)
1/4
(6.4)
1-1/4
(31.8)
1,400 (6.2)
2,040
(9.1)
1,920
(8.5)
2,220
(9.9)
2,600
(11.6)
2,400
(10.7)
1,620 (7.2)
2,560
(11.4)
2,240
(10.0)
2,800
(12.5)
3,100
(13.8)
3,040
(13.5)
2,220 (9.9)
4,000
(17.8)
3,140
(14.0)
4,500
(20.0)
4,400
(19.6)
5,000
(22.2)
7,240
8,080
(35.9)
3/8
(9.5)
14
(19.0)
5/16
(7.9)
1-1/2
Carbon
(38.1) or Stainless
1/2
(12.7)
20
(27.1)
3/8
(9.5)
1-7/8
(47.6)
5/8
(15.9)
48
(65.1)
1/2 (12.7)
2
(50.8)
3,080 (13.7)
6,440
(28.6)
4,400
(19.6)
(32.2)
6,120
(27.2)
3/4
(19.1)
90
(122.0)
5/8 (15.9)
2-1/4
(57.2)
4,200 (18.7)
10,200
(45.4)
6,060
(27.0) 11,600 (51.6)
8,900
(39.6) 13,100 (58.3)
Ultimate Tension and Shear Values in Lightweight Concrete (Lbs/kN)*
ANCHOR
DIA.
In. (mm)
INSTALLATION
TORQUE
FT. Lbs. (Nm)
BOLT DIA.
In. (mm)
MIN.
EMBEDMENT
DEPTH In. (mm)
ANCHOR
TYPE
(STEEL)
f'c = 4000 PSI (27.6 MPa)
TENSION
Lbs. (kN)
f'c = 6000 PSI (41.4 MPa)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1/4
(6.4)
3.5
(4.7)
3/16
(4.8)
1-1/8
(28.6)
1,080
(4.8)
1,160
(5.2)
1,220
(5.4)
1,940
5/16
(7.9)
8
(10.8)
1/4
(6.4)
1-1/4
(31.8)
1,260
(5.6)
1,680
(7.5)
1,440
(6.4)
2,220
(9.9)
3/8
(9.5)
14
(19.0)
5/16
(7.9)
1-1/2
(38.1)
1,620
(7.2)
2,300
(10.2)
2,240 (10.0)
2,800
(12.5)
1/2
(12.7)
20
(27.1)
3/8
(9.5)
1-7/8
(47.6)
2,600
(11.6)
3,920
(17.4)
3,160 (14.1)
4,840
(21.5)
5/8
(15.9)
48
(65.1)
1/2 (12.7)
2
(50.8)
3,240
(14.4)
5,600
(24.9)
4,300 (19.1)
7,840
(34.9)
3/4
(19.1)
90
(122.0)
5/8 (15.9)
2-1/4
(57.2)
3,640
(16.2)
8,640
(38.4)
5,800 (25.8)
12,480
(55.5)
www.ramset.com
Carbon
or Stainless
(8.6)
93
CONCRETE ANCHORING SYSTEMS
®
DYNABOLT SLEEVE ANCHORS
PERFORMANCE TABLES
Ultimate Tension and Shear Values in Concrete Masonry Units (Lbs/kN)*
ANCHOR INSTALLATION
TORQUE
DIA.
In. (mm) Ft. Lbs. (Nm)
BOLT.
DIA.
In. (mm)
MIN.
EMBEDMENT
DEPTH
In. (mm)
1/4 (6.4)
3.5 (4.7)
3/16 (4.8)
1-1/8
(28.6)
3/8 (9.5)
15 (20.3)
5/16 (7.9)
1-1/2
(38.1)
ANCHOR
TYPE
(STEEL)
25 (33.9)
3/8
(9.5)
1-7/8
(47.6)
5/8 (15.9)
55 (74.6)
1/2
(12.7)
2
(50.8)
3/4 (19.1)
90 (122.0)
5/8
(15.9)
2-1/2
(63.5)
HOLLOW CORE
TENSION
Lbs. (kN)
Carbon
Stainless
1/2 (12.7)
LIGHTWEIGHT
GROUT FILLED
SHEAR
Lbs. (kN)
1,120 (5.0)
1,360 (6.0)
640 (2.8)
1,620 (7.2)
MEDIUM WEIGHT
HOLLOW CORE
GROUT FILLED
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
1,120 (5.0)
1,360 (6.0)
1,120 (5.0)
1,620 (7.2)
1,120 (5.0)
1,360 (6.0
640 (2.8)
1,620 (7.2)
640 (2.8)
1,620 (7.2)
640 (2.8)
1,620 (7.2)
Carbon
1,360 (6.0)
2,560 (11.4)
1,360 (6.0)
2,560 (11.4)
1,360 (6.0)
2,560 (11.4)
1,360 (6.0)
2,560 (11.4)
Stainless
1,160 (5.2)
2,560 (11.4)
1,160 (5.2)
2,560 (11.4)
1,160 (5.2)
2,560 (11.4)
1,160 (5.2)
2,560 (11.4)
Carbon
2,220 (9.9)
4,000 (17.8)
2,220 (9.9)
4,000 (17.8)
Stainless
2,100 (9.3)
4,000 (17.8)
2,100 (9.3)
4,000 (17.8)
Carbon
3,080 (13.7)
6,440 (28.6)
3,080 (13.7)
6,440 (28.6)
Stainless
3,080 (13.7)
6,440 (28.6)
2,820 (12.5)
6,440 (28.6)
Carbon
4,200 (18.7)
10,200 (45.4)
4,200 (18.7)
10,200 (45.4)
* Allowable values are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values. The tabulated values are for anchors installed in a minimum of 12 diameters on center and a minimum edge
distance of 6 diameters for 100 percent anchor efficiency. Spacing and edge distance may be reduced to 6 diameter spacing and 3 diameter edge distance, provided the values are reduced 50 percent.
Linear interpolation may be used for intermediate spacings and edge distances.
Combined Tension and Shear Loading—for Dynabolt Anchors
Allowable loads for anchors subjected to combined shear and tension forces are determined by the following equation:
(Ps/Pt ) + (Vs /Vt ) ≤ 1
Ps = Applied tension load
94
Vs = Applied shear load
Pt = Allowable tension load
Vt = Allowable shear load
www.ramset.com
CONCRETE ANCHORING SYSTEMS
STUD ANCHORS
Stud Anchors
Stud Type Anchors
Bottom-Bearing,
specified for anchorage into concrete
Stud
Anchor
Hammer-Driven
Stud Anchors feature a bolt body and pre-assembled
expander plug. Anchors should be installed with carbide
tipped hammer drill bits made in accordance to ANSI
B212.15-1994.
Anchors
Anchors are tested to ASTM E488 criteria. Anchors are
listed by the following agencies as required: UL and FM.
ADVANTAGES
n Fast and easy to install
n Same drill size as anchor size
n Bottom-bearing design is ideal for jacking and leveling applications
n Install anchor directly through fixture
n Hammer-driven expansion design eliminates torque requirements,
for dependable holding capacity
FEATURES
Installation Steps
1. Drill hole same diameter as anchor to
embedment specified in chart. Clean hole.
External Threads for easy
equipment setting
Stamped part number on body
2. Drive anchor with expander plug in bottom,
through material to be fastened.
Pre-assembled expander plug—
easy anchor to set—drill and
hammer in—anchor is bottom
bearing
3. Expand anchor by driving anchor over plug with
APPROVALS / LISTINGS
hammer.
Meets or exceeds U.S. Government G.S.A. specification A-A-55614 Type
2 (Formerly GSA: FF-S-325 Group VIII, Type 2)
Factory Mutual
California State Fire Marshal
Note: Recommended thickness of concrete for bottom-bearing
anchors = embedment depth + three times anchor diameter
Underwriters Laboratories
www.ramset.com
95
CONCRETE ANCHORING SYSTEMS
STUD ANCHORS
Stud Anchors
PART NUMBER
HOLE OR BIT SIZE
(THREADS)
In. (mm)
JS-14C
1/4" - 20
JS-14H
JS-14M
JS-38C
3/8" - 16
JS-38H
JS-38M
JS-12C
1/2" - 13
OVERALL LENGTH
In. (mm)
STUD LENGTH
In. (mm)
THREAD LENGTH
In. (mm)
MIN. EMBEDMENT
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
1-3/4
(44.5)
3/4
(19.1)
5/8
(15.9)
1-3/8 (34.9)
100/ 2.6
1000/
26
2-1/4
(57.2)
1-1/8
(28.6)
7/8
(22.2)
1-3/8 (34.9)
100/ 3.1
1000/
31
3-1/4
(82.6)
2-1/8
(54.0)
7/8
(22.2)
1-3/8 (34.9)
100/ 4.5
1000/
45
2-1/4
(57.2)
1
(25.4)
3/4
(19.1)
1-5/8 (41.3)
50/ 3.6
500/
36
3
(76.2)
1-5/8
(41.3)
1-1/4
(31.8)
1-5/8 (41.3)
50/ 4.5
500/
45
3-3/4
(95.3)
2-1/4
(57.2)
1-1/4
(31.8)
1-5/8 (41.3)
50/ 5.7
500/
57
2-3/4
(69.9)
1-1/8
(28.6)
7/8
(22.2)
1-7/8 (47.6)
25/ 3.9
250/
39
JS-12H
4-1/4
(108.0)
2-1/2
(63.5)
2
(50.8)
1-7/8 (47.6)
25/ 5.6
250/
56
JS-12M
5-1/4
(133.4)
3-5/8
(92.1)
2
(50.8)
1-7/8 (47.6)
25/ 7.0
250/
70
JS-58H
5/8" - 11
5
(127.0)
3
(76.2)
2-1/4
(57.2)
2-3/8 (60.3)
10/ 4.1
100/
42
JS-34H
3/4" - 10
6-1/4
(158.8)
3-3/4
(95.3)
2-1/2
(63.5)
2-7/8 (73.0)
10/ 7.6
50/
59
PERFORMANCE TABLES
Ultimate Tension and Shear Values in Concrete (Lbs/kN)*
ANCHOR
DIA.
In. (mm)
1/4
MIN. EMBEDMENT
DEPTH In. (mm)
f'c = 2000 PSI (13.8 MPa)
TENSION
Lbs. (kN)
(6.4)
1-3/8 (34.9)
1,120
3/8
(9.5)
1-5/8 (41.3)
1/2
(12.7)
1-7/8 (47.6)
5/8
(15.9)
3/4
(19.1)
f'c = 4000 PSI (27.6 MPa)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
(5.0)
580
(2.6)
1,500
(6.7)
1,640
(7.3)
1,740
(7.7)
2,280
(10.1)
3,160
(14.1)
3,360
(14.9)
2,680
(11.9)
5,320
(23.7)
4,020
(17.9)
5,100
(22.7)
2-3/8 (60.3)
3,200
(14.2)
5,460
(24.3)
5,520
(24.6)
6,820
(30.3)
2-7/8 (73.0)
4,020
(17.9)
8,100
(36.0)
7,520
(33.5)
8,560
(38.1)
Allowable loads are based upon a 4 to 1 safety factor. Divide by 4 for allowable load values.
Recommended Edge and Spacing Distance Requirements
ANCHOR
DIA.
In. (mm)
MIN. EMBEDMENT
DEPTH In. (mm)
EDGE DISTANCE REQUIRED
TO OBTAIN MAX. WORKING
LOAD In. (mm)
MIN. EDGE DISTANCE AT WHICH
LOAD FACTOR APPLIED
= .90 FOR TENSION
=.65 FOR SHEAR
In. (mm)
SPACING REQUIRED TO OBTAIN
MAX. WORKING LOAD
In. (mm)
MIN. ALLOWABLE SPACING BETWEEN
ANCHORS LOAD FACTOR APPLIED
=.90 FOR TENSION
=.50 FOR SHEAR
In. (mm)
1/4
(6.4)
1-3/8
(34.9)
2-7/16
(61.9)
1-1/4 (31.8)
4-13/16
(122.2)
2-7/16
(61.9)
3/8
(9.5)
1-5/8
(41.3)
2-7/8
(73.0)
1-7/16 (36.5)
5-11/16
(144.5)
2-7/8
(73.0)
1/2
(12.7)
1-7/8
(47.6)
3-5/16
(84.1)
1-11/16 (42.9)
6-9/16
(166.7)
3-5/16
(84.1)
5/8
(15.9)
2-3/8
(60.3)
4-3/16
(106.4)
2-1/8 (54.0)
8-5/16
(211.1)
4-3/16
(106.4)
3/4
(19.1)
2-7/8
(73.0)
5-1/16
(128.6)
2-9/16 (65.1)
10-1/16
(255.6)
5-1/16
(128.6)
*Linear interpolation may be used for intermediate spacing and edge distances.
96
www.ramset.com
CONCRETE ANCHORING SYSTEMS
REDI-Drive ANCHORS
REDI-DRIVE Anchors
High Performance
Without Torquing
Light-Duty Hammer-Drive Masonry Anchors
specified for anchorage into concrete, Block and Brick
The Redi-Drive is a high performance small diameter one-piece hammer-drive
anchor. The anchor holds based on a friction principle—the shank diameter is larger
than the drill hole size. Anchors shall be installed with
carbide-tipped hammer drill bits made in accordance
Redi-Drive
to ANSI B212.15-1994.
High
Performance
Hammer-Drive
Anchor
Tie
Wire
Finished
Head
Pipe Drive
Forming
Anchor
The Redi-Drive is available in four types…mushroom
head, pipe-hanging (1/4" & 3/8") FM approved (on
3/8"), Tie-Wire, and double-head forming versions.
Anchor performance in solid concrete at one inch
embedment shall exceed 400 lbs. allowable tension
load and 750 lbs. allowable shear load.
ADVANTAGES
n High performance provides superior holding values in concrete
and other masonry materials
n Fire resistant
n Available in 3/4", 1-1/8", 1-5/8", 2", 2-1/2", and 3" lengths
n Most economical steel anchor available
n Provides fast, high performance drive-type fastening without
torquing or need for special setting equipment
n Tamper resistant
n Standard 3/16" drill hole size—cheaper bit and faster installation
­­ simple as using a nail.
As
Drive into predrilled holes for tremendous holding
strength in concrete. Compressive strength is created by forcing a
larger diameter fastener into a smaller size hole.The greater the degree
of contact the greater the holding power.
Only 2 Points
of Contact
One-fourth the
holding power
of Redi-Drive
.250
Shank
Diameter
.260
www.ramset.com
.190
Shank
Diameter
.260
Only 3 Points
of Contact
Half the
holding power
of Redi-Drive
.215
Shank
Diameter
100% Contact
More contact—
more holding
power!
97
CONCRETE ANCHORING SYSTEMS
REDI-Drive ANCHORS
APPLICATIONS
Signage and other light duty
metal products are common
applications for the Redi-Drive.
It has superior performance in
block, brick and solid concrete,
and is tamper-proof.
INSTALLATION STEPS FOR REDI-DRIVE & FORMING
ANCHORS
1. Drill a proper-sized diameter hole at a
minimum depth (see chart on page 84, ANSI
B212.15–1994).
2. Clean hole.Please note hole is 3/16" but
Wood attachments to concrete are common RediDrive applications, whether
permanent or temporary.
Electrical boxes and conduit
clips that need permanent
attachment are ideal applications for the Redi-Drive. It
works well in all base materials
and is fast and economical.
diameter of Redi -Drive is 1/4" (except for PD8134 and FD8-234)
3.Insert anchor through material to be fastened
(insert tie-wire or pipe version Redi-Drive
anchors into drilled holes) and drive anchor
with a 3-lb. hammer until the head is flush with
surface or desired embedment.
Anchor is
now set for
Redi-Drive
Anchor.
Anchor is now
set for Forming
Anchor.
INSTALLATION STEPS FOR REDI-DRIVE TIE-WIRE
ANCHORS
FEATURES
Tamper-Proof—mushroom head
1. Drill a proper-sized diameter hole at a
minimum depth (see chart on page 78,
ANSI B212.15–1994).
100% Hole Contact—.215 shank
in .198 hole
2. Clean hole.Please note hole is 3/16" but
diameter of Redi -Drive is 1/4" (except for
PD8-134 and FD8-234)
3.Insert anchor through material to be fasDog-Point—for easy insertion
and installation
tened (insert tie-wire or pipe version RediDrive anchors into drilled holes) and drive
anchor with a 3-lb. hammer until the head
is flush with surface or desired embedment.
APPROVALS / LISTINGS
Meets or exceeds U.S. Government G.S.A. Specification FF-S-325
Group VI
Anchor is now set.
Factory Mutual (3/8" pipe-drive)
98
www.ramset.com
CONCRETE ANCHORING SYSTEMS
REDI-Drive ANCHORS
INSTALLATION STEPS FOR REDI-PIPE-DRIVE ANCHORS
3.Insert anchor through material to be fastened (insert
1. Drill a proper-sized diameter hole
tie-wire or pipe version Redi-Drive anchors into drilled
holes) and drive anchor with a 3-lb. hammer until the
head is flush with surface or desired embedment.
at a minimum depth (see chart on
page 84, ANSI B212.15–1994).
2. Clean hole.
Anchor is now set.
Redi-Drive Anchors
TOTAL LENGTH
In. (mm)
1/16 (1.6)
1/4 (6.4)
100/ 1.4
1000/ 15
(19.1)
3/8
(9.5)
1/4 (6.4)
100/ 1.6
1000/ 17
(19.1)
7/8
(22.2)
1/4 (6.4)
100/ 2.2
1000/ 23
(19.1)
1-1/4 (31.8)
1/4 (6.4)
100/ 2.6
1000/ 26
(19.1)
1-3/4 (44.5)
1/4 (6.4)
100/ 3.2
1000/ 33
(19.1)
2-1/4 (57.2)
1/4 (6.4)
100/ 3.7
1000/ 37
HEAD HEIGHT
In. (mm)
HEAD SIZE
In. (mm)
RD4-034
7/16 (11.1)
3/16 (4.8)
RD4-118
7/16 (11.1)
3/16 (4.8)
1-1/8 (28.6)
3/4
RD4-158
7/16 (11.1)
3/16 (4.8)
1-5/8 (41.3)
3/4
RD4-200
7/16 (11.1)
3/16 (4.8)
(50.8)
3/4
RD4-212
7/16 (11.1)
3/16 (4.8)
2-1/2 (63.5)
3/4
RD4-300
7/16 (11.1)
3/16 (4.8)
3/4
2
3
(76.2)
QTY/WT
PER
MASTER
CARTON
lbs.
11/16 (17.5)
DRILL BIT SIZE
In. (mm)
(19.1)
QTY/WT
PER BOX lbs.
MAX. FIXTURE
THICKNESS
In. (mm)
HEAD DIA.
In. (mm)
3/4
CLEARANCE
HOLE SIZE
In. (mm)
MIN.
EMBEDMENT
In. (mm)
PART
NUMBER
Typical Applications—Electrical boxes, conduit clips, and duct work
PART
NUMBER
HEAD SIZE
O.D.
In. (mm)
DRILL BIT SIZE
In. (mm)
TOTAL LENGTH
In. (mm)
MIN.
EMBEDMENT
In. (mm)
TD4-112
3/16 (4.8)
3/16 (4.8)
2-1/8 (54.0)
1-1/4 (31.8)
5/8
(15.9)
9/32" hole
QTY/WT
PER BOX lbs.
100/ 3.5
QTY/WT
PER
MASTER
CARTON
lbs.
*
1000/ 35
Tie Wire Typical Applications—Acoustical ceilings, suspended electrical fixture, pencil rod
INTERNAL
THREADED
DIA. O.D,
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER
CARTON lbs.
PART
NUMBER
INTERNAL
THREAD SIZE
I. D.
DRILL BIT SIZE
In. (mm)
TOTAL LENGTH
In. (mm)
MIN.
EMBEDMENT
In. (mm)
HEAD HEIGHT
In. (mm)
PD4-112
1/4 - 20"
3/16 (4.8)
2-1/8 (54.0)
1-1/4 (31.8)
5/8
(15.9)
13/32 (10.3)
100/ 3.0
1000/ 30
PD8-134
3/8 - 16"
1/4 (6.4)
2-1/2 (63.5)
1-3/4 (44.5)
3/4
(19.1)
9/16 (14.3)
100/ 6.0
1000/ 61
Pipe Hanging Typical Applications—Fire sprinkler, water lines, steam/gas, cable tray, electrical conduits
HEAD HEIGHT
In. (mm)
HEAD SIZE
In. (mm)
QTY/WT
PER BOX lbs.
QTY/WT
PER
MASTER
CARTON
lbs.
PART
NUMBER
HEAD SIZE
O.D.
In. (mm)
DRILL BIT SIZE
In. (mm)
TOTAL LENGTH
In. (mm)
MIN.
EMBEDMENT
In. (mm)
FD6-234
7/16 (11.1)
3/16 (4.8)
2-3/4 (69.9)
1-1/4 (31.8)
100/ 3.1
1000/ 31
FD8-234
7/16 (11.1)
1/4 (6.4)
2-3/4 (69.9)
1-1/4 (31.8)
100/ 5.6
1000/ 56
Forming Wood attachments to concrete are common Redi-Drive applications, whether permanent or temporary
* NOT MADE IN USA
www.ramset.com
99
CONCRETE ANCHORING SYSTEMS
REDI-Drive ANCHORS
Redi-Drive Setting Tool
PART
NUMBER
DESCRIPTION
QTY/WT PER
BOX
QTY/WT PER
MASTER CARTON
RDST
REDI-DRIVE SETTING TOOL
1/1
1/1
Installs Redi-Drive anchors in tight and hard to access areas—easily and quickly. Just place anchor in rubber “holding cap," place against work
surface and hammer in anchors.
PERFORMANCE TABLES
Anchoring Overhead in 3000 PSI Lightweight Concrete On Metal Deck
ANCHOR
DRILL HOLE DIA.
In. (mm)
3/8" Pipe Drive
1/4
EMBEDMENT
In. (mm)
(6.4)
3000 PSI (20.7 MPa) CONCRETE
ULTIMATE TENSION LOAD
Lbs. (kN)
1-1/2 (38.1)
ALLOWABLE WORKING LOAD
Lbs. (kN)
Upper Flute
1,099
(4.9)
275
(1.2)
Lower Flute
994
(4.4)
249
(1.1)
Safe working loads for single installations under static loading conditions should not exceed 25% of the ultimate capacity.
Ultimate Tension and Shear Values (Lbs/kN) in Concrete, Hollow Block and Grout Filled
SHANK DIA.
ANCHOR
Redi-Drive
EMBEDMENT
In. (mm)
4500 PSI (31.0 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
CMU (HOLLOW BLOCK) PSI (MPa)
CMU (GROUT FILLED) PSI (MPa)
TENSION
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
SHEAR
Lbs. (kN)
3/4
(19.1)
1,215
(5.4)
1,857
(8.3)
382
(1.7)
683
(3.0)
731
(3.3)
1,614
(7.2)
1
(25.4)
1,667
(7.4)
3,112
(13.8)
392
(1.7)
987
(4.4)
870
(3.9)
1,766
(7.9)
1-1/4 (31.8)
2,373
(10.6)
3,355
(14.9)
398
(1.8)
1,381
(6.1)
1,543
(6.9)
2,778
(12.4)
* Tie-Drive or1/4"
Pipe-Drive
1-1/4 (31.8)
2,372
(10.6)
3/8" Pipe-Drive
1-1/2 (38.1)
2,090
(9.3)
Safe working loads for single installations under static loading conditions should not exceed 25% of the ultimate capacity.
The tabulated values are for anchors installed in a minimum of 12 diameters on center and a minimum edge distance of 10 diameters for 100 percent anchor efficiency.Space and edge distance may be
reduced to six diameters spacing and five diameter edge distance provided values are reduced 50%. Linear interpolation may be used for intermediate spacing and edge
The Redi-Drive is the most versatile of
all of these products. It can be used
at all these embedment depths and
is superior in pull-out performance to
these competitive anchors.
* NOT MADE IN USA
Embedment in 4500 psi Concrete
*Rawl Spike ® cannot be installed in 3/4" embedment
Rawl Spike ® is a registered trademark of Powers Fastening, Inc.
100
www.ramset.com
CONCRETE ANCHORING SYSTEMS
Tapcon
®
Tapcon® Condrive 1000 Tool Kit
(D)
Condrive 1000 Installation Tool
SPECIFIED FOR ANCHORAGE INTO CONCRETE,
BRICK OR BLOCK
(C)
(E)
The key to Tapcon’s fast and easy installation is the multipurpose Condrive Installation Tool. The drive sleeve, along with
the hex head and phillips sockets provide the installer with
the flexibility necessary for the complete variety of Tapcon
applications (tool does not include drill bit).
Condrive® 1000 - A multi-purpose tool designed for
installation of Tapcon hex head and Phillips flat head anchors
up to 3-3/4" long. If driving hex head Tapcon, driver will
automatically disengage. The Condrive 1000 has a reusable
plastic case.
Condrive Tools are designed to specifically install Tapcon
Anchors and to fit standard hammer drills.
(B)
Magnetic
(A)
Part No. C1000
(Does not include drill bit)
APPLICATIONS
ADVANTAGES
n Fast change from drilling to driving
n Eliminates need to change out chucks and bits
n Eliminates need for two tools
n Special nut driver is recessed for torque control to reduce
The picture shows the Condrive
1000 Installation Kit in action.
The kit makes for fast and easy
change over from drill bit to
driver and controls the driving
torque to prevent thread stripping and head snapping in hard
base materials.
head breakage
n Includes bits for all sizes hex and Phillips head
Tapcon® Starter Kit
Condrive 1000 Spare Parts
PART NO.
DESCRIPTION
QTY/WT
(A) 7901001
Drill Adapter
1/.06
(B) 7901002
Sleeve
1/.01
7901003
Black Band
1/.02
7901004
5/32" Ball Bearing
1/.02
(C) 7901006
3/16" Socket
1/.04
(D) 7901007
1/4" Socket
1/.05
7901008
#2 Phillips bit for 3/16" anchor
1/.10
7901009
#3 Phillips bit for 1/4" anchor
1/.12
(E) 7901010
Phillips Socket
1/.44
7902006
Set Screw
1/.02
7902008
1/16" Ball Bearing
1/.02
7902010
1/8" Hex Key
1/.10
www.ramset.com
Part Number: 7904050
Kit Contains:
1 Box HW4-114 (includes 1 drill bit)
1 Box HW4-134 (includes 1 drill bit)
1 Condrive 1000
101
CONCRETE ANCHORING SYSTEMS
®
Tapcon ANCHORS
Blue Climaseal™
Tapcon® Anchors with Blue Climaseal™ (The "Original" Tapcon)
STRAIGHT SHANK
BITS FOR
3/16" TAPCON
PART NO.
BIT
LENGTH
In. (mm)
PART NO.
1/4"
FLAT HEAD
PART NO.
3/16"
FLAT HEAD
PART NO.
1/4"
HEX HEAD
PART NO.
3/16"
HEX HEAD
RECOMMENDED
TAPCON LENGTH
In. (mm)
FIXTURE
THICKNESS
INCHES
STRAIGHT SHANK
BITS FOR
1/4" TAPCON
PART NO.
0" – 1/4"
1-1/4 (31.8)
HW3-114
HW4-114
PF3-114
PF4-114
3-1/2 (88.9)
7900814
7901014
1/4" – 3/4"
1-3/4 (44.5)
HW3-134
HW4-134
PF3-134
PF4-134
3-1/2 (88.9)
7900814
7901014
3/4" – 1-1/4"
2-1/4 (57.2)
HW3-214
HW4-214
PF3-214
PF4-214
4-1/2 (114.3)
7900818
7901018
1-1/4 “ – 1-3/4"
2-3/4 (69.9)
HW3-234
HW4-234
PF3-234
PF4-234
4-1/2 (114.3)
7900818
7901018
1-3/4" – 2-1/4"
3-1/4 (82.6)
HW3-314
HW4-314
PF3-314
PF4-314
5-1/2 (139.7)
7900822
7901022
2-1/2" – 3"
4 (101.6)
HW3-400
HW4-400
PF3-400
PF4-400
5-1/2 (139.7)
7900822
7901022
Diameter: 3/16" and 1/4" Thread Form: Advanced Threadform Technology™
Point Type: Nail Finish: Blue Climaseal™
All boxes of ITW Tapcon come packaged with matching carbide-tipped bit. Tapcon is packaged 100 pieces per box and 500 pieces per master carton except HW4-600 and
PF4-600 (400 in master carton).
Stainless Steel
Tapcon® Stainless Steel Anchors
FIXTURE
THICKNESS
INCHES
PART NO.
1/4"
FLAT HEAD
PART NO.
3/16"
FLAT HEAD
PART NO.
1/4"
HEX HEAD
RECOMMENDED
TAPCON LENGTH
In. (mm)
STRAIGHT SHANK
BITS FOR
1/4" TAPCON
PART NO.
STRAIGHT SHANK
BITS FOR
3/16" TAPCON
PART NO.
BIT
LENGTH
In. (mm)
0" – 1/4"
1-1/4 (31.8)
SHW4-114
3434907
SPF4-114
3-1/2 (88.9)
7900814
7901014
1/4" – 3/4"
1-3/4 (44.5)
SHW4-134
3418907
SPF4-134
3-1/2 (88.9)
7900814
7901014
3/4" – 1-1/4"
2-1/4 (57.2)
SHW4-214
3419907
SPF4-214
4-1/2 (114.3)
7900818
7901018
1-1/4 – 1-3/4"
2-3/4 (69.9)
SHW4-234
3420907
SPF4-234
4-1/2 (114.3)
7900818
7901018
1-3/4" – 2-1/4"
3-1/4 (82.6)
SHW4-314
3421907
SPF4-314
5-1/2 (139.7)
7900822
2-1/4" – 2-3/4"
3-3/4 (95.3)
SHW4-334
3322907
SPF4-334
5-1/2 (139.7)
7900822
7901022
7901022
Diameter: 3/16" and 1/4" Thread Form: Original Notched Hi-Lo™
Point Type: Nail Finish: 410 Stainless Steel with Silver Climaseal™
All boxes of ITW Tapcon come packaged with matching carbide-tipped bit. Tapcon is packaged 100 pieces per box and 500 pieces per master carton except 3461907
(400 in master carton).
102
www.ramset.com
CONCRETE ANCHORING SYSTEMS
®
Tapcon ANCHORS
PERFORMANCE TABLE
Ultimate Tension and Shear Values (Lbs/kN) in Concrete
ANCHOR
DIA.
In. (mm)
3/16 (4.8)
1/4 (6.4)
f’c = 2000 PSI (13.8 MPa)
f’c = 3000 PSI (20.7 MPa)
f’c = 4000 PSI (27.6 MPa)
f’c = 5000 PSI (34.5 MPa)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
(25.4)
600 (2.7)
720 (3.2)
625 (2.8)
720 (3.2)
650 (2.9)
720 (3.2)
800 (3.6)
860 (3.8)
1-1/4 (31.8)
845 (3.7)
720 (3.2)
858 (3.8)
720 (3.2)
870 (3.9)
720 (3.2)
1,010 (4.5)
860 (3.8)
1-1/2 (38.1)
1,090 (4.8)
860 (3.8)
1,090 (4.8)
860 (3.8)
1,090 (4.8)
860 (3.8)
1,220 (5.4)
860 (3.8)
1-3/4 (44.5)
1,450 (6.5)
870 (3.9)
1,455 (6.5)
870 (3.9)
1,460 (6.5)
990 (4.4)
1,730 (7.7)
990 (4.4)
1
MIN. DEPTH OF
EMBEDMENT
In. (mm)
1
(25.4)
750 (3.3)
900 (4.0)
775 (3.4)
900 (4.0)
800 (3.6)
1,360 (6.1)
950 (4.2)
1,440 (6.4)
1-1/4 (31.8)
1,050 (4.7)
900 (4.0)
1,160 (5.2)
900 (4.0)
1,270 (5.6)
1,360 (6.1)
1,515 (6.7)
1,440 (6.4)
1-1/2 (38.1)
1,380 (6.1)
1,200 (5.3)
1,600 (7.2)
1,200 (5.3)
1,820 (8.1)
1,380 (6.1)
2,170 (9.7)
1,670 (7.4)
1-3/4 (44.5)
2,020 (9.0)
1,670 (7.4)
2,200 (9.8)
1,670 (7.4)
2,380 (10.6)
1,670 (7.4)
2,770 (12.3)
1,670 (7.4)
Safe working loads for single installation under static loading should not exceed 25% of the ultimate load capacity.
Ultimate Tension and Shear Values (Lbs/kN) in Hollow Block
LIGHTWEIGHT BLOCK
ANCHOR
EMBEDMENT
In. (mm)
ANCHOR
DIA.
In. (mm)
TENSION
Lbs. (kN)
MEDIUM WEIGHT BLOCK
SHEAR
Lbs. (kN)
TENSION
Lbs. (kN)
SHEAR
Lbs. (kN)
3/16 (4.8)
1 (25.4)
220 (1.0)
400 (1.8)
340 (1.5)
730 (3.2)
1/4 (6.4)
1 (25.4)
250 (1.1)
620 (2.8)
500 (2.2)
1,000 (4.4)
Safe working loads for single installation under static loading should not exceed 25% of the ultimate load capacity.
NOTE: 3/16" Tapcon requires 5/32" bit, 1/4" Tapcon requires 3/16" bit.
Tapcon® SDS Bits
PART
NUMBER
DESCRIPTION
7900814
5/32 X 3-1/2 BIT TAPCON
7900818
5/32 X 4-1/2 BIT TAPCON
7900822
5/32 X 5-1/2 BIT TAPCON
790059
5/32 X 7 SDS BIT TAPCON
7901014
3/16 X 3-1/2 BIT TAPCON
7901018
3/16 X 4-1/2 BIT TAPCON
7901022
3/16 X 5-1/2 BIT TAPCON
7901026
3/16 X 6-1/2 BIT TAPCON
7901030
3/16 X 7-1/2 BIT TAPCON
7901060
5" SDS BIT TAPCON
7901059
7" SDS BIT TAPCON
www.ramset.com
103
CONCRETE ANCHORING SYSTEMS
E-Z ANCOR
®
E-Z ANCOR® The Origninal Self-Drilling Drywall Anchor
specified for anchorage into gypsum
wallboard
The E-Z Ancor is a one-piece self-drilling
E-Z Ancor anchor designed for optimal holding
Selfperformance in gypsum wallboard. Available
Drilling
in zinc or high strength engineered plastic
Anchor
(non-conductive). Ideal anchor for 3/8", 1/2"
and 5/8" gypsum wallboard.
ADVANTAGES
PART
NUMBER
DESCRIPTION
EZ100
SELF THDNG ZINC DRYWALL ANCHOR
100/1.6
1000/17.0
EZPPL100
SELF THDNG PLASTIC DRYWALL ANCHOR
100/0.1
1000/ 4.2
EZP25
EZ ANCOR KIT PLASTIC
1/0.9
10/ xx
EZ25
EZ ANCOR KIT
1/0.9
10/10­
EZT-50
EX TOGGLE
APPLICATIONS
n Fast—no pre-drilling
n Electrical fixtures
n HVAC fixtures
n Bathroom accessories
n Shelving
n Closet organizers
n Curtain rods
n Signage
n Easy—just use #2 phillips bit
n Clean and neat—tri-cut point drills a
small hole and seats flush
n Corrosion resistance
n Removable—easily backed out of wallboard
n Breakaway point for easy usage when cavity
is shallow
E-Z Ancor® Kits
Starter Kit
Part Number: EZ25
Kit Contains:
25 Zinc Anchors
25 Screws
104
QTY/WT PER
MASTER
CARTON
lbs.
QTY/WT
PER BOX
lbs.
PERFORMANCE TABLE
MAXIMUM
FIXTURE
THICKNESS
ULTIMATE PULLOUT LBS.
GYPSUM BOARD THICKNESS
ULTIMATE SHEAR LBS.
GYPSUM BOARD THICKNESS
3/8"
1/2"
5/8"
3/8"
1/2"
5/8"
3/4"
40
50
75
135
150
200
www.ramset.com
CONCRETE ANCHORING SYSTEMS
POLY-SET ANCHORS
Poly-Set Anchors
Plug Anchors
The Truly Versatile
Plug Anchor
specified for anchorage into ALL BASE MATERIALS
The Poly-Set is a polyethylene expansion
anchor designed for fastening into drywall,
hollow block, brick and solid concrete.
Poly-Set
Plug
Anchor
ADVANTAGES
PS-0608SP
1012SP
n Unique twisting action provides superior holding over standard plug anchors
n Resistant to moisture, chemicals or atmospheric conditions—can be used anywhere
n Pre-packaged in kits with matching screws and carbide-tipped drill bit
n Works well in all base materials
INSTALLATION STEPS
For Solid Concrete
1.Drill hole at least 1/4" deeper
than anchor length and insert
anchor until flange is flush.
For Hollow Material
1.Drill hole and insert anchor
until flange is flush.
2.Fasten fixture by inserting sheet
2.Fasten fixture by inserting
metal screw through fixture and
into anchor.
sheet metal screw through
fixture and into anchor.
3.Tighten screw.
3.Expand anchor after screw head is
against fixture, tighten screw the
number of additional turns indicated
on the chart to the right.
DRYWALL
THICKNESS
PS-0608S
PS-1012S
3/8"
7-9 Turns
1/2"
5-7 Turns
8-9 Turns
5/8"
3-4 Turns
6-7 Turns
3/4"
1-2 Turns
4-5 Turns
Approximate number of additional turns after
screw head is against fixture for indicated
thickness of hollow wall.
Poly-Set Anchors
PART NUMBER
DRILL BIT SIZE
ANCHOR LENGTH
SCREW SIZE
GRIP RANGE
QTY/WT
PER BOX lbs.
QTY/WT
PER MASTER CARTON lbs.
PS-0608SP
3/16
1-1/4
#6 - 8
3/8 - 3/4
100/ 0.9
1000/ 2
PS-1012SP
9/32
1-7/16
#10-12
1/2 - 1
100/ 1.8
1000/ 4
PERFORMANCE TABLE
Average Ultimate Tension Load in Various Base Materials
PART
NUMBER
DRYWALL
(1/2")
CONCRETE
(200PSI)
CONCRETE
(4000PSI)
HOLLOW
BLOCK (CMU)
PS-0608SP
110 lbs.
225 lbs.
265 lbs.
235 lbs
PS-1012SP
145 lbs.
355 lbs.
390 lbs.
385 lbs
www.ramset.com
Poly-Set Kits
PART
NUMBER
DRILL
BIT SIZE
KIT CONTAINS
GRIP
RANGE
QTY/WT
PER BOX
QTY/WT PER
MASTER
CARTON
PS-0608SKP
3/16
100 1-1/4" ANCHORS/
100 #8 SCREWS
3/8-3/4
1/1.0
10.11
PS-1012SKP
9/32
50 1-7/16" ANCHORS/
50 #12 SCREWS
1/2-1
1/1.2
12/12
105
ITW Ramset
700 High Grove Blvd.
Glendale Heights, IL 60139
Phone: 630-825-7900
800-RAMSET6 (1-800-726-7386)
Fax: 630-893-1270­
www.ramset.com
Customer Service Locations
700 High Grove Blvd
Glendale Heights, IL 60139
Phone: 800-241-5640
Fax: 866-726-8134
7:00am–5:30pm (CST, M–F)
3405 Dallas Hwy SW
Bldg 800 Ste #810
Marietta, Georgia 30064
Phone: 800-241-5640
Fax: 800-966-0901
7:00am–5:30pm (CST, M–F)
Technical Service
and Application
Assistance
The most frequently requested ITW Ramset performance data, approvals, MSDS, tool schematics, etc.
are available on our website at www.ramset.com.
Our application engineers are ready to assist you with any type of application or code approval question
during any phase of your project.
700 High Grove Blvd.
Glendale Heights, IL 60139
[email protected]
Phone: 800-726-7386
8:00am–5:00pm (CST, M–F)
Fax: 630-893-1291
Ramset Factory Tool Repair Stations
The most up-to-date list of Authorized Repair Centers in your area can be found on our website at www.ramset.com.
Midwest:
Chicago, IL
700 High Grove Blvd.
Glendale Heights, IL 60130
Phone: 800-726-7386
Fax: 630-694-4677
[email protected]
East:
Allentown, PA
330 Weiss Street, Suite 3
Topton, PA 19562
Phone: 610-682-0551
Fax: 610-682-0557
[email protected]
www.ramsetrepair.com:
Tools can be sent direct to the factory
service center by logging onto
www.ramsetrepair.com
Operator Training, Test and License Available on the Internet
Only properly trained and licensed operators as described in ANSI Standard A 10.3 and/or local regulations may operate powder
actuated tools. ITW Ramset distributors offer complete training programs for end users. Contact your local Ramset distributor for
complete details.
A Ramset powder actuated tool Operator’s Training, Test and License program is also available at www.ramset.com.
Ramset
700 High Grove Blvd., Glendale Heights, IL 60139
Customer Service: 1.800.241.5640
www.ramset.com
106
©
2011 Illinois Tool Works, Inc.
Ramset, TRAKFAST, and Viper are trademarks of ITW Ramset and Illinois Tool Works,Inc.
www.ramset.com
ITW Ramset is a wholly owned subsidiary of Illinois Tool
Works (NYSE: ITW)
PLC-02/11
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
