BLOWDOWN SEPARATOR
BDS SERIES
Safely Separates
Steam Vapor from Boiler Blow-Off Water
The HBC Blowdown Separator is designed to take water from the boiler during blowdown and reduce it to atmospheric pressure for
disposal. The HBC Separator accomplishes this by separating the subsequent flashed steam from the hot water. As the blowdown
enters the vessel, it is forced into a centrifugal pattern by means of a striking plate. The steam is vented to the atmosphere through a
top connection. The HBC Separator is built as per requirements Section VIII of the ASME Code and stamped by the National Board of
Pressure Vessel Inspectors. The Hurst Blowdown Separator provides an economical means of safe boiler blowdown.
The separator includes a structural steel support stand for
mounting to foundation. Options available are after cooler,
manual cooling valve assembly, automatic cooling valve
assembly, and exhaust heads.
H U R S T
P E R F O R M A N C E
S E R I E S
B O I L E R S
HURST BLOWDOWN SEPARATORS are built
to Section VIII, Division 1 of the ASME Code for
250 PSI design pressure.
(200 PSI design pressure with 150# ANSI flanges).
Blowdown separator
design pressure should
be a minimum of 25%
of the boiler maximum
allowable working
pressure (MAWP) as
recommended by the
National Board.
THREADED VENT & DRAIN STANDARD, FLANGED ARE OPTIONAL
SPECIFICATIONS
DIMENSION
3/4"-1 1/4"
ECONOMY
1 1/4"
1 1/2"-2"
2"-2 1/2"
BLOWDOWN BLOWDOWN BLOWDOWN
SEE
BD14X34
BD14X34-A
BD14X56
BDS8 NOTE
MODEL NUMBER
1
14
A TANK DIAMETER
8
14
14
32 3/4
54 1/4
34 3/4
26
B LENGTH
16
23
C DRAIN TO GROUND
24
24
57 3/4
56 3/4
42
80
D OVERALL HEIGHT
1 1/4"
1 1/4
2 1/2
E INLET SIZE
2"
4 1/2
3 1/2
3 1/2
3
F INLET LENGTH
10 7/8
7 1/2
10 7/8
10 7/8
G OVERALL RAD.
2 1/2
3
H VENT & DRAIN
4
6
40 3/4
32 1/2
38 3/4
60 1/4
I LENGTH W/FLG.
20
J FLANGE TO GROUND
13
21
21
80/100
227/257
225/255
355/395
WEIGHT NET/SHIPPING LBS.
NOTE 1: 8" DIAMETER SEPARATORS ARE DESIGNED FOR BOILERS NEEDING SHORT
DURATION BLOWDOWN ONLY, SUCH AS VERTICAL TUBELESS BOILERS
DIMEMSIONS SUBJECT TO CHANGE WITHOUT NOTICE, CERTIFIED DRAWINGS AVAILABLE ON REQUEST
ALL DIMENSIONS ARE IN INCHES
Inspected and
registered with the
National Board of
Boiler & Pressure
Vessel Inspectors.
Designed,
constructed and
stamped in
accordance with
the requirements
of the ASME
Boiler Codes.
HBC-09518
10/2012
