Partitions . Accessories . Lockers

Partitions . Accessories . Lockers

Washroom

Accessories

Partitions . Accessories . Lockers

Partitions . Accessories . Lockers

2

Turn your

washroom inTo a

showroom

wiTh The new asi

Welcome to the new ASI—the world’s leading manufacturer of commercial washroom accessories.

So what makes ASI so unique? For starters, we offer the most comprehensive selection of washroom accessories available anywhere. And we offer them from one source. We design, engineer and manufacture all of our products to work together seamlessly.

Welcome to choice, welcome to innovations, welcome to the new ASI.

How to use this brochure:

This brochure offers two ways to navigate our comprehensive portfolio of washroom accessories:

1

Navigate by collections—a family of complementary-designed products, see pages 6 & 7.

2

Navigate by specific product

category, see pages 8 & 9.

so why choose us?

The answer is

simple

Only ASI designs, engineers and manufactures fully integrated washroom accessories, partitions and lockers from one source.

A wide variety of baby safe solutions

Tested with up to 350 lb. load capacity—the highest in the industry.

Endless options in lockers

A wide range of colors and materials including steel, solid plastic and phenolic.

From towel dispensers to hand dryers and much more

ASI offers the largest collection of hand dryers, paper towel dispensers and washroom accessories in the industry.

4

1

No other manufacturer can do it all—it’s that simple

Only ASI offers the most complete collection of products for the modern washroom.

2

Stability—peace-of-mind one warranty

Why juggle multiple manufacturers’ warranties when you can have just one? With ASI you have the peace of mind that comes with dealing with a leader.

The industry’s most cutting-edge soap dispensers

From single dispensers to multi-feed systems, only ASI offers the easiest soap dispensers to install and maintain.

A wide array of mirror options

ASI offers mirrors for every application. Choose from channel frame, frameless, angle frame and tilting mirrors.

7

And much, much more

This is just the beginning of what ASI has to offer. And if you need a product you don’t see here, just call us at 914.476.9000 or visit www.asigroup.us.

6

Technology innovations—

ASI Access

Our 24/7 Customer Service

Tool to create and track orders; to enter quotes and convert quotes to orders and to view invoices.

The latest collection of partitions

ASI offers the most comprehensive collection of plastic, plastic laminate, powder coated, phenolic and stainless steel partitions from one source.

3

Our innovations come from listening to your needs

At a recent professional sports complex, an architect wanted a specific product. We customized and delivered hundreds of one-of-a-kind soap dispensing systems to meet their deadline.

Shower seats

A wide variety of folding and fixed shower seats that are easy to install and meet

ADA safety standards.

5

For discerning customers with prestigious projects

Our washroom accessories are featured in some of the world’s most prominent projects. Whether you are in

AT&T Stadium in Dallas or

Lincoln Center in NY, chances are you’ve seen ASI.

4

48-hour delivery— no one beats that

We are laser focused on delivering you exactly what you need—when you need it. Visit americanspecialties.com and view our Never Out Program.

5

O U R C O L L E C T I O N S

Four disTincT collecTions

To maTch any aesTheTic and perFormance need

6

1

Roval

™ Collection

This elegant, durable and exceptionally functional collection is engineered for high-profile settings. Subtle curves, one-piece seamless doors and flush tumbler locks, along with fully removable waste cans, strong hinges, an integral locking system and easy installation, make this collection ideal for the most aesthetically demanding applications.

P.

10

2

Profile

Collection

This visually appealing collection with rounded edges is manufactured with highly durable 16 gauge stainless steel doors and 20 gauge cabinets. Concealed heavy-duty

3

16

" (5 mm) diameter piano hinges ensure smooth and long-lived operation, and rimless keyed-alike flush tumbler locks offer strong security with an elegant look.

P.

18

While ASI offers hundreds of individual accessories, we have simplified the specifying process with our four distinct collections to serve your project

’ s individual needs.

And each of our four collections was designed as a suite of products that complement one another. Welcome to aesthetics and function in perfect harmony. Welcome to the new ASI.

3

Simplicity

Collection

This elegant collection combines seamless construction and crisp design lines to provide strength and comfort, beauty and durability, form and function.

18 gauge doors and 20 gauge cabinets conceal heavy-duty

3

16

" (5 mm) diameter piano hinges. All units are keyed alike.

P.

24

4

Traditional

Collection

The traditional collection has easily passed the test of time. These high- value products feature 22 gauge double-pan doors incorporating a

“no-flex” structural fiberboard core.

22 gauge cabinets, heavy-duty

3

16

"

(5 mm) diameter piano hinges and keyed-alike tumbler locks complete this broad product line.

P.

32

Partitions . Accessories . Lockers

7

O U R P R O D U C T S

welcome To The single largesT collecTion oF washroom accessories anywhere—bar none

Why mix and match disparate washroom accessory products from different manufacturers, when our company has designed, engineered and manufactured everything you need from one source? Welcome to simplicity. Welcome to the new ASI.

Hand Dryers

P.

42

Soap Dispensers

P.

46

Mirrors

P.

50

Feminine Hygiene Vendors and Disposals

P.

52

8

Specialty Accessories

P.

54

Toilet Tissue Dispensers

P.

60

Grab Bars

P.

66

Shower/Tub Accessories

P.

68

Baby Changing Stations

P.

72

Shelves

P.

76

Custodial Accessories

P.

78

Healthcare Accessories

P.

80

Hospitality Accessories

P.

84

Security Accessories

Partitions . Accessories . Lockers

P.

90

9

SHOWN: 20469 RECESSED

PAPER TOWEL DISPENSER

AND WASTE RECEPTACLE

Roval

Collection

Engineered for high-profile settings, this collection adds elegance, durability and exceptional functionality to any washroom without becoming the focal point.

This collection is ideal for the most aesthetically demanding applications. All features are functionally superior, quickly installed and easily maintained.

WHAT MAkES THE ROVAL

COLLECTION UNIqUE?

18-22

Gauge

staiNless steel coNstructioN

Our collection is constructed of stainless steel, which is tough, durable, stain-resistant and easy to clean.

iNtegral lockiNg systeM

Our durable, integral locking system prevents tampering and theft.

staked PiaNo HiNges

Our heavy-duty, staked piano hinges provide security and a neat appearance, and they stand up to heavy use.

reMovable waste recePtacle

Fully removable waste cans allow contents to be easily discarded for efficient ongoing maintenance and cleanliness.

ROVAL

COLLECTION PRODUCTS

MaNual aNd autoMatic

PaPer towel/ toilet tissue disPeNsers

Mirrors autoMatic

HaNd dryers

Partitions . Accessories . Lockers

11

12

204623 recessed PaPer towel disPeNser aNd reMovable waste recePtacle

Dispenses 350 C-fold, 475 multi-fold paper towels. 3.0 gal.

(11.2 L) removable stainless steel waste receptacle with a tumbler lock. 22 gauge type 304 stainless steel door in a satin finish with a flush lock and a heavy-duty

3

⁄ piano hinge on door.

16

" staked

Model oPtioNs:

204623-9 Collar for surface mounting.

unit size:

12 3 /

4

" x 28" x 6 1 /

2

"

(325 x 710 x 165 mm)

wall opening:

11¼" x 26 7 /

16

" x 3 15 /

16

"

(286 x 672 x 100 mm)

20469 recessed PaPer towel disPeNser aNd waste recePtacle

3

Dispenses 600 C-fold or 800 multi-fold paper towels.

14.8 gal. (56 L) removable waste receptacle. Door made of 18 gauge type 304 stainless steel with a heavy-duty

16

" staked piano hinge.

Model oPtioNs:

20469-9 Collar for surface mounting.

unit size:

17

3

/

8

" x 56

1

/

16

" x 9"

(441 x 1424 x 228 mm)

wall opening:

15

5

/

8

" x 54

3

/

8

" x 4"

(397 x 1381 x 102 mm)

R O V A L

TM

C O L L E C T I O N

204692a autoMatic recessed roll PaPer towel disPeNser aNd waste recePtacle

Fabricated of 18 gauge type 304 stainless steel. 17.8 gal.

(67.2 L) removable waste receptacle.

unit size:

17 3 /

8

" x 56 1 /

16

" x 10"

(441 x 1424 x 254 mm)

wall opening:

15 13 /

16

" x 54 11 /

16

" x 10"

(402 x 1389 x 254 mm)

2046921a recessed autoMatic roll PaPer towel disPeNser aNd waste recePtacle for adaag coMPliaNce

Smaller waste receptacle, 13.5 gal. (51.1 L), allows unit to be ADA compliant. Internal shelf is ideal for paper towel storage.

unit size:

17

3

/

8

" x 56

1

/

16

" x 10"

(441 x 1424 x 254 mm)

wall opening:

15

13

/

16

" x 54

11

/

16

" x 10"

(402 x 1389 x 254 mm)

Partitions . Accessories . Lockers

13

20826 surface MouNted waste recePtacle

Receptacle front and sides fabricated of 20 gauge type 304 stainless steel with satin finish. Capacity 12.8 gal. (48.8 L).

overall dimensions:

15 1 /

8

" x 23" x 8 1 /

2

"

(384 x 584 x 216 mm)

Model oPtioNs:

20826-t Closed top, spring-loaded door.

Capacity 12.8 gal. (48.8 L).

20458 seMi-recessed reMovable waste recePtacle

Easy maintenance—removable stainless steel waste receptacle locks into cabinet with a tumbler lock for security. Capacity 11.2 gal. (42.6 L). Fabricated of

20 gauge type 304 stainless steel with satin finish.

overall dimensions:

17 3 /

8

" x 27 3 /

4

" x 8 15 /

16

"

(441 x 705 x 227 mm)

14

20852 surface MouNted saNitary waste recePtacle

Lid and cabinet are each drawn one-piece construction.

Lid is secured to the cabinet with a heavy-duty multi-staked concealed piano hinge.

9 ⁄

64

"

overall dimensions:

7

1

/

4

" x 10" x 3

1

/

2

"

(185 x 253 x 89 mm)

20470 recessed saNitary NaPkiN disPosal

Heavy-duty 9 ⁄

64

" staked piano hinge adds to the robust construction. Drawn one-piece seamless door of 22 gauge type 304 stainless steel with a satin finish. 1.0 gal. (3.7 L) waste capacity.

overall dimensions:

12

13

/

16

" x 11" x 5

7

/

16

"

(325 x 280 x 138 mm)

R O V A L

TM

C O L L E C T I O N

20452 PaPer towel disPeNser

Dispenses 600 C-fold or 800 multi-fold paper towels.

Door fabricated of 18 gauge type 304 drawn one-piece stainless steel with satin finish. Door secured with

3

16

" staked piano hinge and flush tumbler lock.

overall dimensions:

12

3

/

4

" x 28" x 5

7

/

16

"

(324 x 711 x 137 mm)

204523a recessed autoMatic roll PaPer towel disPeNser

Fabricated of 22 gauge stainless steel with satin finish. Towels are dispensed one length at a time automatically when hands are placed in sensor zone until supply is depleted.

overall dimensions:

17

3

/

8

" x 27

3

/

4

" x 11

11

/

16

"

(441 x 705 x 297 mm)

20210 PaPer towel disPeNser

Dispenses 400 C-fold or 525 multi-fold paper towels.

Fabricated of 22 gauge type 304 stainless steel with satin finish. Fitted with tumbler lock and heavy-duty stainless steel staked piano hinge.

overall dimensions:

11

1

/

16

" x 13

9

/

16

" x 4

7

/

8

"

(281 x 345 x 124 mm)

20030 surface MouNted twiN Hide-a-roll toilet tissue disPeNser

Holds 2 rolls up to 5.25" (133 mm) diameter (double roll capacity 3600 sheets); top roll automatically drops in place when bottom roll is used up. Type 304 satin finish stainless steel cabinet and mechanism. Theft-resistant spindles with integral plated steel endpins. Model 20031 comes with flange for semi-recessing.

overall dimensions:

6

1

/

16

" x 12

1

/

8

" x 6

1

/

2

"

(154 x 308 x 165 mm)

Partitions . Accessories . Lockers

15

9013 recessed staiNless steel baby cHaNgiNg statioN

ADA-compliant unit features welded stainless steel construction for long and reliable use. Includes easy one-handed pull handle and concealed damped gas spring. The changing surface is high-impact-resistant plastic with a gloss finish for easy cleaning. Comes with a two-part adjustable safety strap and a 400 lb. (181 kg) load capacity to assure child protection.

overall dimensions:

Open: 37" x 25 1 /

2

" x 17 3 /

4

"

(940 x 648 x 451 mm)

wall opening:

34

1

/

4

" x 22

3

/

4

" x 3

3

/

4

"

(870 x 578 x 95 mm)

Closed: 37" x 25 1 /

2

" x 1 /

4

"

(940 x 648 x 6 mm)

9343 HorizoNtal soaP disPeNser

All-purpose soap valve. Unbreakable refill window, concealed fastening and hinged filler-top for vandal resistance. Capacity: 48 oz. (1.4 L).

overall dimensions:

7

1

/

4

" x 6

1

/

2

" x 3

11

/

16

"

(185 x 163 x 94 mm)

Spout Projection:

15

16

" (24 mm)

16

204684 recessed dual saNitary

NaPkiN aNd taMPoN disPeNser

Dispenses 31 napkins and 22 tampons. Door made of 18 gauge type 304 satin finish stainless steel, with two flush tumbler locks. Universal coin mechanism is convertible for

25 cents, 50 cents or free (no coin) operation. Coin boxes have different lock and key than doors.

overall dimensions:

17

5

/

16

" x 27

3

/

4

" x 5

5

/

8

"

(440 x 705 x 143 mm)

Model oPtioNs:

204684-9 Collar for surface mounting.

20477-sM surface MouNted seat cover disPeNser

Dispenses 250 seat covers. Fabricated of 20 gauge type 304 stainless steel with a satin finish.

overall dimensions:

15

3

/

4

" x 11" x 2

3

/

8

"

(400 x 280 x 60 mm)

R O V A L

TM

C O L L E C T I O N

20199 roval recessed HigH-sPeed

HaNd dryer

This high-performing hand dryer, with a drying time of 10-15 seconds, has a cover made of 18 gauge stainless steel and uniquely complements the Roval™

Collection with its bowed face and gently radiused edges. 5-year warranty.

decibel level:

69 dB-A @ 2M

White

(also available)

20200 tri-Umph

HigH-sPeed HaNd dryer

Satin look cover: ABS plastic with silver ions. Ergonomic— no need to bend over or bend knees. Air blows down and back from vents on one side. No water splash-back. Ultra hygienic—over 99% of airborne bacteria is eliminated with the removable Super Filter System. 5-year warranty.

decibel level:

65-69.8 dB-A @ 2M

Model oPtioNs:

20201 White finish

20655 roval

staiNless steel Mirror witH iNtegral sHelf

The gently radiused edges provide added strength and complement the curves of the ASI Roval™ Collection.

Mirror frame and 6" wide curved edge shelf are fabricated of 18 gauge type 304 stainless steel with satin finish.

Mirror frame has polished seamless mitered corners and

0.25" (6.4 mm) thick plate glass mirror. Warrantied for

15 years against silver spoilage. Choice of sizes.

20692 surface MouNted sHelf

Fabricated of 18 gauge type 304 stainless steel, the 6" wide shelf has a ¾" (19 mm) gently radiused edge that uniquely complements the curves of the ASI Roval™ Collection.

Choice of sizes.

overall dimensions:

6" x 12"-72"

(152 x 305-1829 mm)

Partitions . Accessories . Lockers

17

SHOWN: 9469 PAPER TOWEL

DISPENSER AND

WASTE RECEPTACLE

Profile

Collection

Manufactured with highly durable stainless steel doors and cabinets, this visually appealing collection with rounded edges stands the test of time.

Its concealed hinges ensure smooth and long-lived operation, and its locks offer strong security.

WHAT MAkES THE PROFILE COLLECTION UNIqUE?

16

Gauge

Heavy duty

Our 16 gauge stainless steel doors are attached to

20 gauge stainless steel cabinets with concealed

3 /

16

" (5 mm) diameter piano hinges to handle heavy use.

riMless tuMbler locks

Our rimless flush tumbler locks that are keyed alike provide convenience and security with an elegant look.

rouNded corNers

All doors have vertical edges rounded to a 3 /

4

"

(19 mm) radius with welded corners for strength and to ensure no sharp edges for safety.

easy lift out recePtacle

Fully removable stainless steel waste cans allow contents to be easily discarded for efficient ongoing maintenance and cleanliness.

PROFILE COLLECTION PRODUCTS

Multi-PurPose cabiNets

PaPer towel disPeNsers waste recePtacles

Partitions . Accessories . Lockers

19

20

9469 PAPER TOWEL DISPENSER AND WASTE

RECEPTACLE

Dispenses 600 C-fold or 800 multi-fold paper towels.

15.6 gal. (59 L) waste receptacle.

Unit Size:

17

1

/

4

" x 56" x 5

3

/

16

"

(440 x 1420 x 132 mm)

Wall Opening:

15

3

/

4

" x 54

1

/

2

" x 4"

(400 x 1384 x 102 mm)

9462 PAPER TOWEL DISPENSER AND WASTE

RECEPTACLE

Dispenses 600 C-fold, 800 multi-fold or 1100 single-fold paper towels. 9 gal. (34 L) stainless steel waste receptacle.

Unit Size:

17

1

/

4

" x 54" x 6

15

/

16

"

(438 x 1372 x 176 mm)

Wall Opening:

15

3

/

4

" x 52

1

/

2

" x 6"

(400 x 1334 x 152 mm)

P R O F I L E

C O L L E C T I O N

9467 PaPer towel disPeNser aNd waste recePtacle

Dispenses 600 C-fold or 900 multi-fold paper towels.

5 gal. (18.9 L) stainless steel waste receptacle.

Model oPtioNs:

94676

6" (150 mm) deep to also dispense 1100 single-fold towels and has push door and 7 gal. (26.5 L) capacity.

9467 unit size:

13" x 55" x 5

3

/

16

"

(330 x 1397 x 132 mm)

94676 unit size:

13" x 55" x 7

3

/

16

"

(330 x 1397 x 173 mm)

wall opening:

11

1

/

2

" x 53

1

/

2

" x 4

1

/

4

"

(290 x 1360 x 110 mm)

wall opening:

11

1

/

2

" x 53

1

/

2

" x 6

1

/

4

"

(290 x 1360 x 110 mm)

94696a autoMatic roll PaPer towel disPeNser aNd waste recePtacle

Proximity sensing no-touch unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide, 800 ft.

(244 m) long rolls. 10 gal. (37.8 L) stainless steel waste receptacle. Battery operated (4) D-size.

Model oPtioNs:

94696 Mechanical lever paper towel dispenser.

unit size:

16

1

/

16

" x 41

1

/

4

" x 10

11

/

16

"

(410 x 1050 x 225 mm)

wall opening:

14

5

/

8

" x 39

3

/

4

" x 10"

(371 x 1010 x 254 mm)

Partitions . Accessories . Lockers

21

94623 PaPer towel disPeNser aNd waste recePtacle

Dispenses 350 C-fold or 475 multi-fold paper towels and has a built-it 2 gal.

(7.6 L) stainless steel waste receptacle.

unit size:

14

1

/

4

" x 28" x 4

15

/

16

"

(360 x 710 x 125 mm)

wall opening:

12

3

/

4

" x 26

1

/

2

" x 4

1

/

4

"

(325 x 670 x 110 mm)

9452 PaPer towel disPeNser

Dispenses 600 C-fold or 800 multi-fold paper towels.

unit size:

14

1

/

4

" x 28" x 4

15

/

16

"

(360 x 710 x 125 mm)

wall opening:

12

3

/

4

" x 26

1

/

2

" x 4

1

/

4

"

(324 x 673 x 108 mm)

9457 PaPer towel disPeNser

Dispenses 350 C-fold or 475 multi-fold paper towels.

unit size:

12

3

/

4

" x 17

1

/

4

" x 4

15

/

16

"

(324 x 438 x 125 mm)

wall opening:

11

1

/

4

" x 15

3

/

4

" x 4

1

/

4

"

(286 x 400 x 102 mm)

22

9459 waste recePtacle

Stainless steel waste receptacle holds

4 gal. (15 L) of waste and has a self- closing panel that covers its opening.

unit size:

14 1 /

4

" x 28" x 4 15 /

16

"

(326 x 711 x 125 mm)

wall opening:

12 3 /

4

" x 26 1 /

2

" x 4 1 /

4

"

(325 x 675 x 110 mm)

9474 waste recePtacle

Stainless steel waste receptacle holds 12 gal. (45.4 L) of washroom waste materials.

unit size:

17 1 /

4

" x 40" x 7 3 /

16

"

(438 x 1016 x 183 mm)

wall opening:

15 3 /

4

" x 38 1 /

2

" x 6 1 /

4

"

(400 x 980 x 160 mm)

9468 dual NaPkiN/taMPoN veNdor

Dispenses 30 feminine napkins and 27 tampons using 25¢, 50¢ or free operation.

Its door has 2 tumbler locks. Its inside coin box has a separately keyed lock.

Model 94684 designed for 4" (102 mm) wall opening; dispenses 15 napkins and

23 tampons.

unit size:

17

1

/

4

" x 27

1

/

4

" x 6

15

/

16

"

(440 x 690 x 175 mm)

wall opening:

16" x 26" x 6

1

/

4

"

(406 x 660 x 159 mm)

P R O F I L E

C O L L E C T I O N

9471 saNitary NaPkiN disPosal

Features a self-closing stainless steel push door that covers the disposal opening along with a removable 1.9 gal. (7.2 L) stainless steel waste receptacle.

unit size:

10

5

/

8

" x 19

5

/

8

" x 4

15

/

16

"

(270 x 498 x 125 mm)

wall opening:

9

1

/

8

" x 18

1

/

8

" x 4

1

/

4

"

(232 x 460 x 108 mm)

9326 liquid soaP disPeNser

Dispenser has a covered stainless steel soap tank attached to the door, which hinges out for easy filling and cleaning. Its all-purpose valve dispenses liquid, lotion and detergent-type soaps, with a capacity of 52 fl. oz. (1.5 L).

unit size:

10

1

/

4

" x 6" x 7

3

/

16

"

(260 x 152 x 193 mm)

wall opening:

9" x 4

7

/

8

" x 4

1

/

4

"

(230 x 125 x 110 mm)

Spout Projection: 2

1

4

" (57 mm)

9343 surface MouNted soaP disPeNser

All-purpose valve dispenses liquid, lotion and detergent-type soaps, with a capacity of 48 fl. oz. It has an unbreakable refill window with concealed fastening and vandal-resistant hinged filler-top.

overall dimensions:

7

1

/

4

" x 6

1

/

2

" x 3

11

/

16

"

(185 x 163 x 94 mm)

Spout Projection:

15

16

" (24 mm)

9477 toilet seat cover disPeNser

Dispenses 500 seat covers.

9477-sM Surface mounted.

unit size:

17

1

/

4

" x 12

3

/

4

" x 3

5

/

16

"

(438 x 324 x 73 mm)

wall opening:

15

3

/

4

" x 11½" x 2

5

/

8

"

(400 x 290 x 65 mm)

9030 surface MouNted dual roll toilet tissue disPeNser

Type 304 stainless steel cabinet with mechanism for theft-resistant spindles holds 2 rolls up to 5

1

/

4

"

(135 mm) diameter (1800 sheets); the top roll automatically drops in place when the bottom roll is used up.

overall dimensions:

6" x 12" x 6 1 /

2

"

(150 x 300 x 165 mm)

9031 recessed dual roll toilet tissue disPeNser

Type 304 stainless steel cabinet with mechanism for theft-resistant spindles holds 2 rolls up to 5

1

/

4

" (135 mm) diameter (1800 sheets); the top roll automatically drops in place when the bottom roll is used up.

overall dimensions:

6" x 12" x 6 1 /

2

"

(150 x 300 x 165 mm) with flange for recessing

Partitions . Accessories . Lockers

23

SHOWN: 6467 PAPER TOWEL

DISPENSER AND

WASTE RECEPTACLE

Simplicity

Collection

Combining seamless construction and crisp design lines, this elegant collection provides strength, comfort, beauty and durability.

All units have keyed-alike tumbler locks for ease in maintenance. Automatic dispensers feature a proximity sensor activated dispensing mechanism.

WHAT MAkES THE SIMPLICITy COLLECTION UNIqUE?

18

Gauge

staiNless steel coNstructioN

3

Doors are fabricated with

18 gauge stainless steel for

20 gauge cabinets, which are attached with concealed

/

16

" (5 mm) diameter piano hinges for durability.

seaMless oNe-Piece cover-all door

The door is designed for a sleek and streamlined appearance, making it easy to maintain even with heavy use.

safe easy disPeNsiNg

Towel dispensers have hemmed opening for safe, easy dispensing, minimizing waste and ensuring hygienic use.

easy lift out recePtacle

Fully removable stainless steel waste cans allow contents to be easily discarded for efficient ongoing maintenance and cleanliness.

SIMPLICITy COLLECTION PRODUCTS

PaPer towel disPeNsers feMiNiNe

HygieNe veNdors soaP disPeNsers

Partitions . Accessories . Lockers

25

26

6462 PaPer towel disPeNser aNd waste recePtacle

Dispenses 800 multi-fold, or 600 C-fold towels, standard.

Provided adapter allows the flexibility to change the capacity to up to 1,100 single-fold paper towels. 9 gal.

(34 L) stainless steel waste receptacle.

Model oPtioNs:

6462-2 Stainless steel collar for semi-recessing in

4" (102 mm) walls.

6462-9 Stainless steel collar for surface mounting.

unit size:

17 1 /

4

" x 54" x 6 1 /

2

"

(438 x 1372 x 165 mm)

wall opening:

15 3 /

4

" x 52 1 /

2

" x 6"

(400 x 1335 x 150 mm)

6467 PaPer towel disPeNser aNd waste recePtacle

Dispenses 600 C-fold or 800 multi-fold paper towels.

5 gal. (18.9 L) stainless steel waste receptacle.

Model oPtioNs:

6467-9 Stainless steel collar for surface mounting.

unit size:

13" x 55" x 4

3

/

4

"

(330 x 1397 x 121 mm)

wall opening:

11

1

/

2

" x 53

1

/

2

" x 4

1

/

4

"

(290 x 1360 x 110 mm)

S I M P L I C I T y

C O L L E C T I O N

64676 PaPer towel disPeNser aNd waste recePtacle

Dispenses 600 C-Fold, 800 multi-fold or 1100 single-fold towels. 7 gal. (26.5 L) stainless steel waste receptacle.

Model oPtioNs:

64676-2 Stainless steel collar for semi-recessing in

4" (102 mm) walls.

64676-9 Stainless steel collar for surface mounting.

unit size:

13" x 55" x 6 1 /

2

"

(330 x 1397 x 145 mm)

wall opening:

11 1 /

2

" x 53 1 /

2

" x 6 1 /

4

"

(290 x 1360 x 160 mm)

64672 recessed coMbo tHree-iN-oNe

Three-in-one paper towel dispenser with waste receptacle and high-speed automatic hand dryer. Quick drying—less than 15 seconds. Dispenses 500 standard multi-fold or

400 standard C-fold paper towels and shall have a waste capacity of 6.8 gal (26 L). Durable 20 gauge stainless steel cover has a satin finish. Dryer has 5-year warranty.

unit size:

15 3 /

8

" x 55 3 /

8

" x 7 1 /

2

"

(391 x 1407 x 191 mm)

wall opening:

14 3 /

32

" x 54 3 /

8

" x 7 1 /

4

"

(358 x 1381 x 184 mm)

Partitions . Accessories . Lockers

27

28

0134 turbo-tuff

Quick drying, <15 seconds, operates automatically using infrared sensor with auto-resetting thermostat. Owner-adjustable air speed & temperature and on/off heating options. Dryer automatically shuts off after time-out when user removes hands from sensor zone. ADA compliant.

unit size:

12

19

/

32

" x 15

3

/

4

" x 4

1

/

16

"

(320 x 400 x 103 mm)

wall opening:

12

5

/

16

" x 15

3

/

16

" x 3

7

/

8

"

(313 x 386 x 98 mm)

64623 recessed PaPer towel disPeNser aNd waste recePtacle

Dispenses 350 C-fold or 475 multi-fold paper towels.

2 gal. (7.6 L) stainless steel waste receptacle.

Model oPtioNs:

64623-9 Stainless steel collar for surface mounting.

unit size:

14

1

/

4

" x 28" x 4

3

/

4

"

(362 x 711 x 121 mm)

wall opening:

12

3

/

4

" x 26

1

/

2

" x 4

1

/

4

"

(324 x 673 x 108 mm)

S I M P L I C I T y

C O L L E C T I O N

64696 roll PaPer towel disPeNser aNd waste recePtacle

Mechanically dispenses 8" or 9" (205 or 230 mm) wide,

800 ft. (244 m) long rolls in pre-set lengths of 2½", 4" or 5" (65, 100 or 125 mm) per stroke. 8.6 gal. (32.6 L) stainless steel waste receptacle.

Model oPtioNs:

64696-6 Stainless steel collar for semi-recessing in

4" (102 mm) walls.

64696-9 Stainless steel collar for surface mounting.

unit size:

16

1

/

16

" x 41

1

/

4

" x 9

5

/

8

"

(408 x 1048 x 245 mm)

wall opening:

14

5

/

8

" x 39

3

/

4

" x 9

1

/

4

"

(371 x 1010 x 235 mm)

64696a autoMatic roll PaPer towel disPeNser aNd waste recePtacle

Proximity sensing no-touch unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide,

800 ft. (244 m) long rolls. 8.6 gal. (32.6 L) stainless steel waste receptacle. Battery operated (4) D-size.

Model oPtioNs:

64696a-6 Stainless steel collar for semi-recessing in

4" (102 mm) walls.

64696a-9 Stainless steel collar for surface mounting.

unit size:

16

1

/

16

" x 41

1

/

4

" x 10

1

/

4

"

(408 x 1048 x 261 mm)

wall opening:

14

5

/

8

" x 39

3

/

4

" x 10"

(371 x 1010 x 254 mm)

Partitions . Accessories . Lockers

29

6457 PaPer towel disPeNser

Well-suited for the smaller washroom with less space and traffic, this unit dispenses 350 C-fold or 475 multi-fold paper towels.

unit size:

12

3

/

4

" x 17

1

/

4

" x 4

1

/

2

"

(324 x 438 x 114 mm)

wall opening:

11

1

/

4

" x 15

3

/

4

" x 4

1

/

4

"

(290 x 400 x 110 mm)

6452 PaPer towel disPeNser

Dispenses 600 C-fold or 800 multi-fold paper towels.

unit size:

14 1 /

4

" x 28" x 4 1 /

2

"

(362 x 711 x 114 mm)

wall opening:

12 3 /

4

" x 26 1 /

2

" x 4 1 /

4

"

(325 x 670 x 110 mm)

Model oPtioNs:

6452-9 Stainless steel collar for surface mounting.

30

6459 waste recePtacle

Stainless steel waste receptacle holds 4 gal. (15 L) of waste and has a self-closing panel that covers its opening.

unit size:

14 1 /

4

" x 28" x 4 1 /

2

"

(362 x 711 x 114 mm)

wall opening:

12 3 /

4

" x 26 1 /

2

" x 4 1 /

4

"

(325 x 675 x 110 mm)

6474 waste recePtacle

Stainless steel waste receptacle holds 12 gal. (45.4 L) of washroom waste materials.

unit size:

17 1 /

4

" x 40" x 6 3 /

4

"

(438 x 1016 x 171 mm)

wall opening:

15 3 /

4

" x 38 1 /

2

" x 6 1 /

4

"

(400 x 980 x 160 mm)

Model oPtioNs:

6474-2 Stainless steel collar for semi-recessing in

4" (102 mm) walls.

S I M P L I C I T y

C O L L E C T I O N

6468 dual NaPkiN/taMPoN veNdor

Dispenses 30 feminine napkins and 27 tampons. Available for 25¢, 50¢ or free operation. Its door has 2 tumbler locks.

Its inside coin box has a separately keyed lock.

Model 64684 designed for 4" (102 mm) wall opening; dispenses 15 napkins and 23 tampons.

unit size:

17 1 /

4

" x 27 1 /

4

" x 6 1 /

2

"

(438 x 692 x 165 mm)

wall opening:

16" x 26" x 6 1 /

4

"

(406 x 660 x 159 mm)

6471 saNitary NaPkiN disPosal

Features a self-closing stainless steel push door that covers the disposal opening along with a removable 1.9 gal. (7.2 L) stainless steel waste receptacle.

unit size:

10 5 /

8

" x 19 5 /

8

" x 4 1 /

2

"

(270 x 498 x 114 mm)

wall opening:

9 1 /

8

" x 18 1 /

8

" x 4"

(232 x 460 x 102 mm)

6477 toilet seat cover disPeNser

Dispenses 500 seat covers.

unit size:

17

1

/

4

" x 12

3

/

4

" x 2

7

/

8

"

(438 x 324 x 73 mm)

wall opening:

15

3

/

4

" x 11½" x 2

1

/

2

"

(400 x 292 x 64 mm)

6326 liquid soaP disPeNser

Dispenser has a covered stainless steel soap tank attached to the door, which hinges out for easy filling and cleaning. Its all-purpose valve dispenses liquid, lotion and detergent-type soaps, with a capacity of

52 fl. oz. (1.5 L).

unit size:

10

1

/

4

" x 6" x 4

1

/

8

"

(260 x 152 x 105 mm)

Spout Projection: 2

1

2

" (64 mm)

wall opening:

9" x 4

7

/

8

" x 4"

(229 x 124 x 102 mm)

Partitions . Accessories . Lockers

31

SHOWN: 0469 PAPER TOWEL

DISPENSER AND

WASTE RECEPTACLE

Traditional

Collection

This time-honored collection provides exceptional value, offering a broad array of items for wellequipped washrooms. Double-pan doors incorporate a “no-flex” structural fiberboard core. Combining seamless construction and crisp design lines, this elegant collection provides strength, comfort, beauty and durability. All units have keyed-alike tumbler locks for ease in maintenance. Automatic dispensers feature a proximity sensor activated dispensing mechanism.

WHAT MAkES THE TRADITIONAL COLLECTION UNIqUE?

22

Gauge

staiNless steel coNstructioN

Fabricated with 22 gauge stainless steel with face trim, the recessed cabinet features one-piece construction with no miters or welding for durability.

double-PaN doors

The double-pan doors incorporate a “no-flex” structural fiberboard core, adding strength and endurance for long-term use.

safe easy disPeNsiNg

Towel dispensers have hemmed opening for safe, easy dispensing, minimizing waste and ensuring hygienic use.

easy lift out recePtacle

Fully removable stainless steel waste cans allow contents to be easily discarded for efficient ongoing maintenance and cleanliness.

TRADITIONAL COLLECTION PRODUCTS

Multi-PurPose cabiNets

PaPer towel disPeNsers waste recePtacles

Partitions . Accessories . Lockers

33

34

0462-ad PaPer towel disPeNser aNd waste recePtacle

Dispenses 350 C-fold or 475 multi-fold paper towels.

2 gal. (7.6 L) waste receptacle.

Model oPtioNs:

0462-ad-9 Stainless steel collar for surface mounting.

unit size:

14 1 /

14

" x 28" x 4 1 /

4

"

(362 x 711 x 108 mm)

wall opening:

12 3 /

4

" x 26 1 /

2

" x 4"

(324 x 673 x 102 mm)

0469 PaPer towel disPeNser aNd waste recePtacle

Dispenses 600 C-fold or 800 multi-fold paper towels.

12 gal. (46 L) stainless steel waste receptacle.

Model oPtioNs:

0469-2 Recessing steel collar for semi-recessing in

2" (50 mm) walls.

0469-9 Stainless steel collar for surface mounting.

0469-bl 18 gal. (68 L) waste receptacle. Projects 8"

(205 mm) from wall.

unit size:

17 1 /

4

" x 56" x 4 1 /

4

"

(438 x 1422 x 108 mm)

wall opening:

15 3 /

4

" x 54 1 /

2

" x 4"

(400 x 1384 x 102 mm)

T R A D I T I O N A L

C O L L E C T I O N

recessed PaPer towel disPeNser aNd waste recePtacle

Dispenses 600 C-fold, 800 multi-fold or 1100 single-fold paper towels. 12 gal. (46 L) stainless steel waste receptacle.

Model oPtioNs:

04697-4 Stainless steel collar for semi-recessing in 4"

(102 mm) walls.

04697-9 Stainless steel collar for surface mounting.

04697-bl 18 gal. (68 L) waste receptacle, projects 4"

(102 mm) from wall.

unit size:

17

1

/

4

" x 56" x 7

1

/

4

"

(438 x 1422 x 184 mm)

wall opening:

15

3

/

4

" x 54

1

/

2

" x 7

1

/

4

"

(400 x 1390 x 185 mm)

04692a autoMatic roll PaPer towel disPeNser aNd waste recePtacle

Proximity sensing no-touch unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide,

800 ft. (244 m) long rolls. Battery operated (4) D-size.

Model oPtioNs:

04692a-6 has stainless steel collar for semi-recessing in

4" (102 mm) walls; 04692a-9 has stainless steel collar for surface mounting; 04692 has a mechanical lever dispenser with 3 pre-set dispensing lengths; 04692-6 Same as 04692, but has stainless steel collar for semi-recessing in 4"

(102 mm) walls; 04692-9 Same as 04692, but has stainless steel collar for surface mounting.

unit size:

17 1 /

4

" x 56" x 10 1 /

4

"

(438 x 1422 x 260 mm)

wall opening:

15 3 /

4

" x 54 1 /

2

" x 10"

(400 x 1384 x 254 mm)

Partitions . Accessories . Lockers

35

36

0467 PaPer towel disPeNser aNd waste recePtacle

Dispenses 600 C-fold, 800 multi-fold or 1100 single-fold paper towels. 6 gal. (22.7 L) stainless steel waste receptacle.

Model oPtioNs:

0467-2 Stainless steel collar for semi-recessing in 4"

(102 mm) walls.

0467-9 Stainless steel collar for surface mounting.

unit size:

13" x 55" x 6

1

/

2

"

(330 x 1397 x 165 mm)

wall opening:

11

1

/

2

" x 53

1

/

2

" x 6

1

/

4

"

(290 x 1360 x 160 mm)

04693 recessed Pull core towel disPeNser aNd waste recePtacle

Dispenses one-pull core paper towel roll. 16 gal (60.6 L) stainless steel waste receptacle.

Model oPtioNs:

04693-6 Stainless steel collar for semi-recessing in 4"

(102 mm) walls.

04693-9 Stainless steel collar for surface mounting.

unit size:

17

1

/

4

" x 56" x 10

1

/

4

"

(438 x 1422 x 260 mm)

wall opening:

15

3

/

4

" x 54

1

/

2

" x 10

1

/

4

"

(400 x 1385 x 260 mm)

T R A D I T I O N A L

C O L L E C T I O N

046921A AUTOMATIC RECESSED ROLL TOWEL

DISPENSER AND WASTE RECEPTACLE

Proximity sensing no-touch unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide,

800 ft. (244 m) long rolls. 12 gal. (45.4 L) waste receptacle.

Operated with 4 D-size batteries.

MODEL OPTIONS:

046921A-6 has stainless steel collar for semi-recessing in

4" (102 mm) walls; 046921A-9 has stainless steel collar for surface mounting; 046921 has a mechanical lever dispenser with 3 pre-set dispensing lengths; 046921-6 Same as

046921, but has stainless steel collar for semi-recessing in 4" (102 mm) walls; 046921-9 Same as 046921, but has stainless steel collar for surface mounting.

Unit Size:

17

1

/

4

" x 56" x 10

1

/

4

"

(438 x 1422 x 260 mm)

Wall Opening:

15

3

/

4

" x 54

1

/

2

" x 10

1

/

4

"

(400 x 1390 x 260 mm)

046924A AUTOMATIC RECESSED ROLL TOWEL

DISPENSER AND WASTE RECEPTACLE

Proximity sensing no-touch recessed unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide, 800 ft. (244 mm) long rolls. 12 gal. (45.4 L) waste receptacle. Battery operated (4) D-size.

MODEL OPTIONS:

046924A-9 Stainless steel collar for surface mounting.

046924 Mechanical lever dispenser. Three pre-set dispensing lengths.

046924-9 Surface mounted with a mechanical lever dispenser.

Unit Size:

17

1

/

4

" x 56" x 9"

(438 x 1422 x 229 mm)

Wall Opening:

15

3

/

4

" x 54

1

/

2

" x 4"

(400 x 1384 x 102 mm)

Partitions . Accessories . Lockers

37

0457 PaPer towel disPeNser

Dispenses 350 C-fold or 500 multi-fold paper towels; well-suited for smaller washrooms with less space and traffic.

Model 0457-9 has stainless steel collar for surface mounting.

unit size:

12 3 /

4

" x 17 1 /

4

" x 4 1 /

4

"

(324 x 438 x 108 mm)

wall opening:

11 1 /

4

" x 15 3 /

4

" x 4"

(286 x 400 x 102 mm)

0452 PaPer towel disPeNser

Dispenses 600 C-fold or 800 multi-fold paper towels.

Model 0452-9 has stainless steel collar for surface mounting.

unit size:

14

1

/

4

" x 28" x 4

1

/

4

"

(326 x 711 x 108 mm)

wall opening:

12

3

/

4

" x 26

1

/

2

" x 4"

(324 x 673 x 102 mm)

045224a autoMatic roll PaPer towel disPeNser

Proximity sensing no-touch unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide, 800 ft. (244 m) long rolls.

Model oPtioNs:

045224a-9 has a stainless steel collar for surface mounting.

045224 and 045224-9 mechanical lever dispenser with 3 pre-set lengths.

unit size:

17

1

/

4

" x 30

1

/

2

" x 10

1

/

4

"

(438 x 775 x 260 mm)

wall opening:

15

3

/

4

" x 29" x 4"

(400 x 740 x 102 mm)

38

04523a autoMatic roll

PaPer towel disPeNser

No-touch unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide, 800 ft. (244 m) long rolls. Operates with (4) D-size batteries.

Model oPtioNs:

04523 and 04523-9 mechanical lever dispenser with 3 pre-sets.

04523a-9 has a stainless steel collar for surface mounting.

unit size:

17 1 /

4

" x 20" x 9 1 /

2

"

(440 x 510 x 241 mm)

wall opening:

15 3 /

4

" x 18½" x 9 1 /

2

"

(400 x 470 x 241 mm)

0458 waste recePtacle

Stainless steel waste container locks into cabinet, removable for servicing

Model 0458-9 has stainless steel collar for surface mounting.

unit size:

17

1

/

4

" x 30

1

/

2

" x 8"

(440 x 775 x 200 mm)

wall opening:

15

3

/

(400 x 740 mm)

4

" x 29" x (variable

*

)

* [0458 if 4" (102 mm) x 4" and 12 gals. (46 L);

0458-CX if ½" (13 mm) x 7½" (190 mm) and 12 gals.; 0458-DX if 8" (205 mm) x 4"

(102 mm) and 18 gals. (68 L)]

04733 waste recePtacle

Self-closing panel covers the receptacle opening, removable 3 gal. (11.4 L) stainless steel waste receptacle.

unit size:

14

1

/

4

" x 28" x 4

1

/

2

"

(326 x 711 x 114 mm)

wall opening:

12

3

/

4

" x 26

1

/

2

" x 4"

(324 x 673 x 102 mm)

T R A D I T I O N A L

C O L L E C T I O N

0210 PaPer towel disPeNser

Fabricated of 22 gauge stainless steel with satin finish, this unit dispenses 400 C-fold or 525 multi-fold paper towels without adjustment or adapters and is fitted with tumbler lock and heavy-duty stainless steel piano hinge.

overall dimensions:

11" x 14

5

8

" x 4

1

16

"

(280 x 370 x 102 mm)

0215 PaPer towel disPeNser—Petite

Same as 0210 but reduced capacity to dispense 200 C-fold or 275 multi-fold paper towels; well-suited for low traffic areas.

overall dimensions:

11" x 8" x 4"

(280 x 205 x 102 mm)

0439 recessed towel disPeNser

This cabinet has 2 push-up flaps for bottom-filling with towels and dispenses

600 C-fold or 800 multi-fold paper towels; designed to conceal the dispenser behind mirror or wall so only the towel tray opening is visible.

Note for Designers: Leave 6" min. (150 mm) clearance below towel tray opening for space to pull towels; units are installed before hanging mirror or applying finished wall.

8522 roll PaPer towel disPeNser

Mechanical unit dispenses a pre-set length per cycle from 8" or 9" (205 or 230 mm) wide, 800 ft. (244 m) long rolls.

overall dimensions:

13" x 17

3

/

4

" x 10

1

/

2

"

(330 x 451 x 267 mm)

Model oPtioNs:

8523a Automatic dispenser with

3 pre-set lengths. Operates with

(4) D-size batteries.

8165 roll PaPer towel disPeNser

Holds standard paper towel roll up to 6"

(150 mm) diameter; heavy-duty aluminum casting with satin-matte, silver-grey finish.

Designed for controlled delivery of towels, and its concealed locking device on molded plastic spindle prevents theft.

overall dimensions:

Unit measures 13" (330 mm) wide; projects 4

7

8

" (125 mm) from wall.

0245-ss PaPer towel disPeNser

Entirely fabricated of 22 gauge stainless steel. This unit dispenses 400 single-fold paper towels.

overall dimensions:

11

1

/

4

" x 6¼" x 5

5

8

"

(285 x 160 x 145 mm)

Partitions . Accessories . Lockers

39

0828 waste recePtacle

Fabricated of 22 gauge type 304 stainless steel with satin finish and hemmed top and bottom edges for safety; holds 6.7 gal. (25.4 L) of waste.

overall dimensions:

14" x 17" x 6 1 /

2

"

(355 x 430 x 165 mm)

0825 waste recePtacle

22 gauge stainless steel with satin finish; holds 17 gal. (64.4 L) with top and bottom hemmed edges; interior hooks for liner.

overall dimensions:

15 3 /

4

" x 21 7 ⁄

8

" x 11 3 /

4

"

(400 x 555 x 300 mm)

Model 0826 has 12 gal. (45 L) capacity with 15¼" x 23" x 8" (390 x 585 x 200 mm) dimensions.

0810 freestaNdiNg waste recePtacle

22 gauge stainless steel with satin finish; holds 13 gal. (49 L); self-closing doors on top with vinyl wall bumpers, rubber feet and hooks for liners.

overall dimensions:

13" x 30 1 /

2

" x 13"

(330 x 775 x 330 mm)

Model 0812 has 19 gal. (72 L) capacity with 13" x 38½" x 13" (330 x 978 x 330 mm) dimensions.

40

0811 freestaNdiNg oPeN waste recePtacle

Same features as Model 0810 except without top.

overall dimensions:

13" x 22" x 13"

(330 x 560 x 330 mm)

Model 0813 has 19 gal. (72 L) capacity with 13" x 30" x 13" (330 x 760 x 330 mm) dimensions.

0827 waste recePtacle

Fabricated of 22 gauge type 304 stainless steel with satin finish and hemmed top and bottom edges for safety; capacity of 2 gal. (7.6 L) of waste.

overall dimensions:

10 3 /

4

" x 9" x 4 3 /

4

"

(275 x 230 x 110 mm)

0829 corNer waste recePtacle

Fabricated of 22 gauge type 304 stainless steel with satin finish and hemmed top and bottom edges for safety; capacity of

15.5 gal. (59 L) of waste.

overall dimensions:

15" x 23" x 14 1 /

2

"

(380 x 585 x 370 mm)

T R A D I T I O N A L

C O L L E C T I O N

1000 circular couNter toP waste cHute

Provides waste deposit access to receptacle (not furnished) placed directly below chute; made of heavy gauge stainless steel with rolled flange and exposed surfaces that have satin finish.

unit size:

6

3

/

4

"

(170 mm) outside diameter

counter opening:

5

3

/

4

"

(146 mm) diameter

Model 1000a has a 9" (229 mm) outside diameter with a counter opening of 8

1

8

" (206 mm) diameter.

1001 couNter toP MouNted PaPer towel disPeNser/waste recePtacle

Capacity of 1 package of C-fold paper towels for loading by pushing through hinged dispensing flaps. Loose waste receptacle to be placed directly below waste door on the vanity floor is provided.

unit size:

14 1 /

4

" x 15" x 3 ⁄

32

"

360 x 380 x 2 mm)

counter opening:

12 1 /

2

" x 13 1 /

2

"

(320 x 340 mm)

1002 couNter toP MouNted PaPer towel disPeNser

Capacity of 1 package of C-fold paper towels for loading by pushing downward through hinged dispensing flaps.

unit size:

14

1

/

4

" x 8" x

3 ⁄

32

"

(360 x 150 x 2 mm)

counter opening:

12

1

/

2

" x 4

1

/

4

"

(318 x 108 mm)

1003 couNter toP MouNted waste recePtacle

Push door is self-closing. A 12" x 12" x 12" (305 x 305 x 305 mm) waste receptacle is furnished to be placed directly below waste door on the vanity floor.

unit size:

14 1 /

4

" x 10" x 3 ⁄

32

"

(360 x 255 x 2 mm)

counter opening:

12 1 /

2

" x 8 3 /

4

"

(320 x 220 mm)

Partitions . Accessories . Lockers

41

SHOWN: 20200 T R I -

Um ph

H I GH - S P E E D H A N D D R y E R

H A N D

D R Y E R S

TRI-

Umph

High-Speed Hand Dryer

This state-of-the-art, ergonomic, high-speed hand dryer is ultra-hygienic with an outstanding filter system. With air blowing down from vents on one side, users dry their hands in under 12 seconds.

This hand dryer allows users to triumph over germs with fast drying time in a comfortable, natural position without water splash-back. Easy to maintain, the TRI-Umph™ high-speed hand dryer makes perfect sense to meet washroom needs.

WHAT MAkES TRI-

Umph

UNIqUE?

<

12 seconds

fastest dryiNg tiMe

The

TRI-Umph

™ high-speed hand dryers take less than

12 seconds to completely dry hands.

No beNdiNg dowN

This unit is wall mounted at a comfortable height in order to permit a natural posture while drying the user‘s hands.

water doesN’t eNd uP oN tHe floor

Water blown from wet hands is pushed onto an absorbent and continuously evaporating ceramic plate, with any excess water channeled into a drip tray.

Eliminates

99% of bacteria

say goodbye to

Mold, Mildew aNd bacteria

Over 99% of airborne bacteria and particles as small as 0.3 microns are eliminated with this hand dryer’s removable three-layer filter system.

20200

TRI-

Umph

PRODUCT SPECIFICATIONS

features

• Fast drying

• Ultra-hygienic

• Ergonomic positioning

• Easy to clean and replace filters

• No puddles on the floor

diMeNsioNs

Unit size is

12

11

/

16

" x 22

1

/

16

" x 7

3

/

4

"

(322 x 560 x 196 mm)

Net weight: 19.8 lbs. (9 kg)

electric

Different models for operating voltage

110~120 V (50/60 Hz),

208~204 V (50/60 Hz) or 227 V (60 Hz);

900 W with heater on,

700 W with heater off

20201—White

Partitions . Accessories . Lockers

43

-92

Bright White

Stainless Steel

0198-93 turbo-dri Jr.

Powerful, quick drying, <15 seconds, yet quiet (69 dB-A); automatic operation and resetting thermostat with

2-second delayed turn off. Heavy-duty, one-piece-formed unit in white or satin stainless steel finish with 5-year warranty. Optional voltages available.

overall dimensions:

9

25

/

32

" x 6

5

/

8

" x 5

13

/

32

"

(248.3 x 168.2 x 137.5 mm)

-92

Bright White

Stainless Steel

0199-93 asi turbo-ada

Quick drying, <15 seconds, and automatic operation using infrared sensor with auto-resetting thermostat. Owneradjustable air speed & temperature and on/off heating options with shut off when user removes hands from sensor zone. Standard white cover; optional bright or satin stainless steel finish. Optional voltages available.

overall dimensions:

10

5

/

8

" x 8

15

/

32

" x 4"

(270 x 215 x 102 mm)

44

-92 -93

Bright Satin

Stainless Steel

0197 turbo-dri™ HaNd dryer

Quick drying, <12 seconds, and powerful, yet quiet, with 60-second auto shut off; automatic operation using infrared sensor with auto-resetting thermostat. Heavy- duty, one-piece-formed unit in bright or satin stainless steel finish. Optional voltages available.

overall dimensions:

8

1

/

16

" x 11

19

64

" x 7

5

/

64

"

(205 x 287 x 180 mm)

0134 turbo-tuff

Quick drying, <15 seconds, and operates automatically using infrared sensor with autoresetting thermostat. Owner-adjustable air speed

& temperature and on/off heating options. Dryer automatically shuts off after time-out when user removes hands from sensor zone. ADA compliant. Optional voltages available.

unit size:

12 19 /

32

" x 15 3 /

4

" x 4 1 /

16

"

(320 x 400 x 103 mm)

wall opening:

12 5 /

16

" x 15 3 /

16

" x 3 7 /

8

"

(313 x 386 x 98 mm)

H A N D

D R Y E R S

0141 PorcelaiN HaNd dryer

Quick drying, <30 seconds, and no-touch, energy efficient operation. Dries both hands and face. Refer to our webpage for more color options.

overall dimensions:

9

7

16

" x 9

41

64

" x 6

3

8

"

(240 x 245 x 162 mm)

electrical specifications:

Motor: 1 ⁄

8

HP-3150 RPM - Brushless

Air Output: 150 CFM - Temp 127° F (53° C)

64672 recessed coMbo tHree-iN-oNe

This three-in-one paper towel dispenser with waste receptacle and high-speed automatic hand dryer provides quick drying, <15 seconds. Dispenses 500 standard multi-fold or 400 standard C-fold paper towels and shall have a waste capacity of 6.8 gal (26 L).

Durable 20 gauge stainless steel cover has a satin finish. Dryer has 5-year warranty.

Optional voltages available.

wall opening:

14

3

/

32

" x 54

3

/

8

" x 7

1

/

4

"

(358 x 1381 x 184 mm)

0185-93 Profile™ steel cover witH

PorcelaiN eNaMel fiNisH

Quick drying, <25 seconds, and no-touch, energy efficient operation. Universal voltage; automatically adjusts to voltages of 100 to 240 VAC - 50/60 Hz. Modern design and durable. Refer to our webpage for more color options.

overall dimensions:

14

7

16

" x 10

13

16

" x 3

15

16

"

(367 x 275 x 100 mm)

ADA compliant.

-92

Bright White

Stainless Steel

0195 Profile™ cast iroN cover witH

PorcelaiN eNaMel fiNisH

Quick drying, <25 seconds, and no-touch, energy efficient operation. Universal voltage; automatically adjusts to voltages of 100 to 240 VAC - 50/60 Hz. Modern design and durable. Refer to our webpage for more color options.

overall dimensions:

15

3

32

" x 11

7

32

" x 3

15

16

"

(383 x 285 x 100 mm)

ADA compliant.

Partitions . Accessories . Lockers

45

SHOWN: 0390 EZ FILL™

SOAP DISPENSING SySTEM

S O A P

D I S P E N S E R S

Soap Dispensers

ASI offers a full range of soap dispensers, from manual and automatic operation, and single unit to

6-unit multi-feed. Each of our soap dispensers are easy to use and maintain.

You can choose from surface mounted, recessed or lavatory mounted models for lotion, powder or surgical soap dispensers to meet your washroom needs. Of special interest is our New EZ FILL™ top-fill multi-feed soap dispensing system.

WHAT MAkES EZ FILL™ SOAP DISPENSING SySTEM UNIqUE?

Up to

6 dispensers

Multi-feed systeM

Using infrared sensors, each of up to 6 automatic soap dispensers is fed by its own controllable peristaltic pump.

easy refill

Using a single soap reservoir, this top-fill system allows refill of up to 6 soap dispensers with 1 pour—for easy ongoing maintenance.

uNiversal reMote

Controls all dispensers with one remote, allowing flexibility in settings with a choice of 4 presets.

Up to

169 oz. capacity

raNge of sizes for all Needs

Holds 169 oz. (5 L) of liquid soap to supply up to six (6) individual EZ FiLL™ vanity mounted automatic soap dispenser units.

ez fill™ features

• Top-fill, expandable system

• Heavy-duty brass dispensers with chrome-plated finish

• Counter-mounted port has an anti-theft cover

• Easy to use

• This EZ FiLL™ system is electrically operated using batteries or alternating current

Partitions . Accessories . Lockers

47

20333 autoMatic deck MouNted soaP disPeNser

Constructed of polished type 304 stainless steel on exposed surfaces with batteryoperated, hands-free sensor. LEDs indicate function, battery condition and soap supply level on face front. Translucent tank.

Capacity: 54 oz. (1600 ml) of liquid soap.

overall dimensions:

4" x 21

1

2

"

(102 x 546 mm)

Spout Projection: 3

7

8

" (99 mm)

0362 autoMatic soaP disPeNser

Stainless steel soap dispenser in satin finish with proximity sensor. Unit is battery operated and has tamper- resistant viewing window. Suitable for dispensing higher viscosity soaps.

overall dimensions:

10

5

8

" x 4

13

16

" x 4

1

8

"

(122 x 270 x 105 mm)

0363 autoMatic soaP disPeNser

Same as 0362 except bright polished finish.

0360 autoMatic soaP disPeNser

Stainless steel, satin finish, proximity sensor, battery operated. Tamper- resistant soap level viewing window, removable lid with special lock and key.

Capacity: 35 fl. oz. (1000 ml).

overall dimensions:

4 7 ⁄

16

" x 9

1

4

" x 4 7 ⁄

8

"

(113 x 235 x 124 mm)

48

5001-ss cartridge soaP disPeNser

Surface mounted, stainless steel, satin finish 22 gauge door and body 16 gauge.

overall dimensions:

4

1

4

" x 11" x 4"

(110 x 280 x 100 mm)

5002 cartridge soaP disPeNser

Recessed mounted unit.

unit size:

7

1

4

" x 15" x 4

1

2

"

(184 x 381 x 115 mm)

wall opening:

5

3

4

" x 13

1

2

" x 4

1

4

"

(146 x 343 x 108 mm)

0361 autoMatic soaP disPeNser

White, high-impact plastic, proximity sensor, battery operated. Tamper- resistant soap level viewing window, swing open body with special lock and key. Capacity: 28 fl. oz. (800 ml).

overall dimensions:

3

5

8

" x 10

5

16

" x 4

3

8

"

(92 x 262 x 111 mm)

0326 recessed HorizoNtal soaP disPeNser

Stainless steel with satin finish, all-purpose soap valve, 52 fl. oz. (1.5 L) capacity.

unit size:

10

1

4

" x 6" x 4

1

2

"

(260 x 152 x 115 mm)

wall opening:

9" x 4

7

8

" x 4

1

4

"

(230 x 125 x 110 mm)

0327 recessed soaP disPeNser

34 oz. (1 L) capacity soap dispenser.

unit size:

6

3

4

" x 6

3

4

" x 4

1

8

"

(172 x 172 x 105 mm)

wall opening:

5

7

8

" x 5

7

8

" x 4"

(150 x 150 x 102 mm)

Spout Projection: 2 1 ⁄

2

" (64 mm)

S O A P

D I S P E N S E R S

0332 LAVATORY MOUNTED ALL-PURPOSE

SOAP DISPENSER

Corrosion-resistant valve with stainless steel spout and chrome plated brass escutcheon plate.

Unit Size:

3

7

16

" x 10

21

32

"

(87 x 271 mm)

MODEL OPTIONS:

0332

0332-C

0332-CD

0332-D

Capacity

34 oz. (1.0 L)

20 oz. (0.6 L)

20 oz. (0.6 L)

34 oz. (1.0 L)

Spout

4" (102 mm)

4" (102 mm)

6" (152 mm)

6" (152 mm)

0347 VERTICAL SOAP DISPENSER

0345 HORIZONTAL SOAP DISPENSER

40 fl. oz capacity soap dispenser in stainless steel; satin finish comes with an all-purpose valve and an tamper-resistant refill indicator.

0347 Unit Size:

4

13

16

" x 8

13

16

" 3

15

16

"

(122 x 208 x 100 mm)

0345 Unit Size:

8

1

8

" x 4¾" x 4"

(205 x 120 x 100 mm)

Spout projection:

15

16

" (24 mm)

9343 HORIZONTAL SOAP DISPENSER

All-purpose soap valve dispenses liquid, lotion and detergent-type soap.

Unbreakable refill window, concealed fastening and hinged filler-top for vandal resistance. Capacity: 48 fl. oz. (1.4 L).

Overall Dimensions:

7

1

4

” x 6

1

2

” x 3

11

16

(185 x 163 x 94 mm)

20365 AUTOMATIC FOAM SOAP

DISPENSER

A foam drop is dispensed out of the nozzle on unit bottom each time its batteryoperated sensor is activated. Capacity:

34 oz. (1000 ml) of liquid foaming soaps within a wide range of viscosity.

Overall Dimensions:

5

1

2

" x 10

7

8

" x 4"

(140 x 276 x 102 mm)

ADA compliant.

20364 AUTOMATIC SOAP DISPENSER

Hands-free, battery-operated soap dispenser. Dispensing cycles adjustable with tamper-proof magnetic key.

Seamless drawn type 304 stainless steel cover. Translucent removable internal tank for easy-to-view level.

LED indicates adjustment and operation. Capacity: 34 oz. (1000 ml).

ADA compliant.

20363 SURFACE MOUNTED VERTICAL

SOAP DISPENSER

Push button. Valve operation is ADA compliant, needing no more than 5 lbs. of pressure to actuate. Gently radiused edge complements the curves of the ASI

Roval™ Collection. Capacity: 57 oz. (1.7 L).

Overall Dimensions:

5

1

2

" x 10

13

16

" x 4"

(139 x 274 x 101 mm)

Spout Projection:

15

16

" (24 mm)

Partitions . Accessories . Lockers

49

50

Mirrors

ASI provides mirrors for every location, application and budget—virtually any size available. Choose from a variety of reflective surfaces and wall mountings, as well as styles ranging from frameless mirrors to mirrors with shelves and tilting features.

Mirror silver guaranteed for 15 years.

SHOWN: 20650 ROVAL

TM

STAINLESS STEEL MIRROR

0535 fiXed tilt Mirror

Offers visibility for wheelchair patients.

Frame fabricated of 20 gauge stainless steel with a satin finish. Mirror is tapered from 4" (102 mm) at top to 1" (25 mm) at bottom.

Width x Height

16" x 20" (41 x 51 cm)

16" x 24" (41 x 61 cm)

16" x 30" (41 x 76 cm)

18" x 24" (46 x 61 cm)

18" x 30" (46 x 76 cm)

18" x 36" (46 x 91 cm)

20" x 60" (51 x 152 cm)

24" x 24" (61 x 61 cm)

24" x 30" (61 x 76 cm)

24" x 36" (61 x 91 cm)

24" x 42" (61 x 108 cm)

24" x 48" (61 x 122 cm)

24" x 60" (61 x 152 cm)

24" x 72" (61 x 183 cm)

30" x 36" (76x 91 cm)

30" x 48" (76x 122 cm)

36" x 36" (91x 91 cm)

36" x 48" (91 x 122 cm)

48" x 30" (122 x 76 cm)

48" x 36" (122 x 91 cm)

60" x 24" (152 x 61 cm)

60" x 36" (152 x 91 cm)

72" x 36" (183 x 91 cm)

0535

0537

0600

0600T

standard Mirror sizes

0605

0620

0625

8026

20650

20650-B

20655

Custom sizes available upon request. Standard glazing is glass. Multiple glazing options available, visit americanspecialties.com.

20655-B

M I R R O R S

8026 fraMeless staiNless steel

Mirror

Fabricated of 20 gauge type 304 stainless steel polished to a #8 mirror finish with a ¼" (6 mm) return. Provided with ¼"

(6 mm) thick concealed tempered masonite backing and 4 mounting holes. Installer shall provide mounting screws to suit individual field conditions.

0600 aNgle fraMe Mirror

¾" x

5

8

" (19 x 16 mm) roll formed 18 gauge type 304 stainless steel angle has corners heliarc welded, ground and polished smooth to a uniform satin finish. Mirror is installed on a concealed hanging bracket that locks onto top and bottom of frame by tamper-proof set screws.

Back plate is one piece, attached to frame with theft-resistant locking device.

0600t adJustable tilt Mirror

Designed to provide easy visibility for wheelchair patients or return to upright position. Angle frame fabricated of

18 gauge stainless steel with corners welded and ground smooth. Tilts a full

6" (152 mm) with bottom mounted on full width stainless steel piano hinge.

0620 cHaNNel fraMe Mirror

½" x ½" x ½" (13 x 13 x 13 mm) 20 gauge type 304 satin finish stainless steel channel is a one-piece roll formed member that encases mirror and backing revealing a tight mitered corner. Mirror is installed on two wall brackets and held secure by theft-resistant screw.

0605 aNgle fraMe Mirror witH sHelf cHaNNel fraMe Mirror witH sHelf

18 gauge stainless steel shelf with satin finish and all edges returned and hemmed for maximum rigidity and safety. Shelf is welded to face frame and is 5"

(127 mm) wide.

20650 roval tM

staiNless steel Mirror

Gently radiused edges match the ASI

Roval™ design. Frame fabricated of

18 gauge type 304 stainless steel with satin finish and polished seamless mitered corners. 0.25" (6.4 mm) thick plate glass mirror. Warrantied for 15 years against silver spoilage. Choice of sizes.

Model oPtioNs:

20650-b Same as 20650 but tempered glass.

Partitions . Accessories . Lockers

51

Feminine Hygiene

ASI offers a wide range of feminine hygiene dispenser and disposal units, available as fully recessed, semi-recessed or surface mounted with various capacities. Type 304 stainless steel fabrication with satin finish on exposed surfaces and 18 gauge doors secured with concealed full length stainless steel hinges. Coin boxes are keyed separately from door lock for maximum security.

Available for 25¢, 50¢ or free operation.

SHOWN: 0468 RECESSED SANITARy

NAPkIN/TAMPON VENDOR

9471 Profile collectioN saNitary NaPkiN disPosal

Self-closing stainless steel push door covers disposal opening. Removable 1.9 gal. (7.2 L) stainless steel waste receptacle.

wall opening:

9¹/

8

" x 18¹/

8

" x 4

15

16

"

(230 x 460 x 125 mm)

6468 siMPlicity collectioN dual NaPkiN/ taMPoN veNdor

Dispenses 30 feminine napkins and 27 tampons.

Door locked by two tumbler locks. Inside coin box has separately keyed lock.

wall opening:

16" x 26" x 6¹/

2

"

(405 x 660 x 165 mm)

F E M I N I N E H y G I E N E V E N D O R S

A N D D I S P O S A L S

0464 recessed saNitary NaPkiN taMPoN veNdor

Dispenser includes two dispensing mechanisms, one for 27 tampons, the other for 30 feminine napkins. Furnished with an adjustable flange for recessing in wall depths from 1" to 6" (26 to 152 mm).

Model oPtioNs:

0864 Surface mounted.

unit size:

13

3

/

4

" x 28

1

8

" x 6¹/

2

wall opening:

" 12¹/

2

" x 26

5

8

" x 1" to 6"

(349 x 714 x 165 mm) (320 x 680 x 26 to 152 mm)

0468 recessed saNitary NaPkiN/ taMPoN veNdor

Dispenses 30 napkins and 27 tampons.

Model oPtioNs:

0468-2 Stainless steel collar for semi-recessing in 4" (102 mm) walls.

04684 Designed for 4" (102 mm) wall.

Dispenses 15 napkins, 23 tampons.

unit size:

17¹/

4

" x 27¹/

4

" x 6¹/

2

"

(438 x 692 x 165 mm)

wall opening:

16" x 26" x 6"

(406 x 660 x 152 mm)

204684 recessed dual saNitary

NaPkiN & taMPoN disPeNser

Dispenses 31 napkins and 22 tampons.

Door has 18 gauge type 304 satin finish stainless steel, with 2 flush tumbler locks.

Universal coin mechanism allows for 25¢,

50¢ or free (no coin) operation; different lock and key than doors.

Model oPtioNs:

204684-9 Collar for surface mounting.

unit size:

17 5 ⁄

16

" x 27 3 /

4

" x 5 5 ⁄

8

"

(440 x 705 x 143 mm)

wall opening:

15

5

8

" x 26

1

8

" x 4"

(397 x 664 x 10 mm)

6471 siMPlicity collectioN saNitary NaPkiN disPosal

Self-closing stainless steel push door covers disposal opening. 1.9 gal. (7.2 L) stainless steel waste receptacle.

wall opening:

9¹/

8

" x 18¹/

8

" x 4¹/

4

"

(230 x 460 x 110 mm)

20852 surface MouNted saNitary waste recePtacle

Lid and cabinet are each drawn onepiece construction. Lid is secured to the cabinet with a heavy-duty

9

64

" multi-staked concealed piano hinge.

overall dimensions:

7¹/

4

" x 10" x 3¹/

2

"

(185 x 253 x 89 mm)

recessed saNitary NaPkiN disPosal

Heavy-duty

9

64

" staked piano hinge adds to the robust construction. Drawn onepiece seamless door of 22 gauge type

304 stainless steel with a satin finish.

1.0 gal. (3.7 L) waste capacity.

overall dimensions:

12

13

/

16

" x 11" x 5

7

/

16

"

(325 x 280 x 138 mm)

Partitions . Accessories . Lockers

53

Specialty Accessories

With an extensive portfolio of washroom accessories,

ASI can provide whatever you need to promote the neat and orderly use of your facilities. These designs reflect our attention to detail for durability and easy maintenance.

SHOWN: 0785-Z TOWEL RING

7385 towel riNg

For bath and hand towels. Ring is 4½" (115 mm) wide, made of ¼" (6 mm) diameter stainless steel bar. Projects

2½" (65 mm) from wall. 5" (125 mm) high.

54

0785-z towel riNg

Ring is fabricated from rust resistant Zamac, with stainless steel wall bracket.

overall dimensions:

6

3

/

8

" x 1

5

/

8

"

(162 x 41 mm)

7301 towel PiN

Fabricated from stainless steel. Extends 3½" (90 mm) from wall.

overall dimensions:

2" x 2" x 3

1

/

2

(51 x 51 x 89 mm)

S P E C I A L T y

A C C E S S O R I E S

8425 clotHes Hook

Heavy-duty 11 gauge type 304 stainless steel with satin finish.

Hook projects 1¼" (32 mm) from wall and is 2¼" (55 mm) high.

7382 Hat aNd coat Hook

Double hook for both coats and hats;

5¼" x 3" (135 x 75 mm)

0751 Heavy-duty robe Hook

Concealed mounting satin chrome-plated brass, 3¼" (80 mm).

Model oPtioNs:

0751-a Exposed mounting, satin chrome-plated brass 3¼" (80 mm).

0714 coat aNd buMPer Hook

Fabricated from chrome-plated brass,

3" (75 mm). Neoprene bumper protects wall surface.

7340 siNgle robe Hook

Fabricated from stainless steel. Hook extends 1 5 ⁄

8

" (40 mm) from wall.

0740-z siNgle robe Hook

Fabricated from rust resistant Zamac, with stainless steel wall bracket.

overall dimensions:

2

1

/

8

" x 1

7

/

16

" x 2

1

/

8

"

(54 x 37 x 54 mm)

Partitions . Accessories . Lockers

55

7345 double robe Hook

4" (100 mm) wide stainless steel bar forms hook at each end. Unit extends 1

5

8

" (40 mm) from wall.

0745-z double robe Hook

Fabricated from triple chrome-plated rust resistant Zamac.

overall dimensions:

2 1 /

8

" x 1 7 /

16

" x 1 29 /

64

"

(54 x 36.5 x 37 mm)

56

Towel bar fabricated of 1" (25 mm) O.D. x 20 gauge, type 304 stainless steel with a satin finish and designed not to turn in support posts. Support posts fabricated of heavy solid cast brass with satin finish to match stainless steel. Available in 18", 24", 30" and 36" (460, 610, 760 and

915 mm) lengths.

0760-z square towel bar

18", 24", 30" and 36" (460, 610, 760 and 915 mm) long.

Fabricated from triple chrome-plated rust resistant Zamac.

overall dimensions:

18-36" x 1

7

/

16

" x 3

3

/

16

"

(457-914 x 37 x 81 mm)

S P E C I A L T y

A C C E S S O R I E S

7355 towel bar-rouNd

¾" (19 mm) diameter stainless steel towel bar and stainless steel mounting bracket. Available in 18", 24" and 30" (460, 610 & 760 mm) lengths. Extends 3¼"

(80 mm) from wall.

Polished stainless steel unit has spring actuated 6'

(150 mm) vinyl cord with white vinyl knob and locking nut to hold stretched line taut. Installs over bathtub or in shower.

7310 towel sHelf witH towel bar

8" (200 mm) deep consisting of four

3

8

" diameter stainless steel tubes, with ¼" (6 mm) diameter stainless steel towel bar below shelf, available 18" (460 mm) and

24" (610 mm). Overall height: 4¼" (110 mm); projects

8" (200 mm) from wall.

7311 towel sHelf witH towel bar

Heavy-duty unit with ¾" and

3

8

" diameter type 304 stainless steel tubing. Bright finish only. Available 20" (510 mm) and 24" (610 mm). Overall height: 6½" (165 mm); projects

8" (200 mm).

Partitions . Accessories . Lockers

57

7320 soaP disH

Drawn, one-piece stainless steel soap dish welded to support arm and flange.

Has two drain holes and two ridges to support bar of soap.

overall dimensions:

4

1

/

4

" x 2" x 4"

(108 x 51 x 102 mm)

0721-z soaP disH witHout draiN

Fabricated from triple chrome-plated rust resistant Zamac.

overall dimensions:

4" x 1

1

/

2

" x 3

1

/

4

"

(102 x 38 x 83 mm)

7335 tootHbrusH aNd tuMbler

Holder

Drawn, one-piece toothbrush holder is made of stainless steel. Has 2¼" (60 mm) diameter hole in center of unit to hold tumbler. Accommodates 6 toothbrushes.

overall dimensions:

4

1

/

4

" x 2" x 4"

(108 x 51 x 102 mm)

58

0735-z tootHbrusH & tuMbler

Holder

Fabricated from triple chrome-plated rust resistant Zamac.

overall dimensions:

3

7

/

8

" x 1

1

/

2

" x 3

1

/

4

"

(98 x 38 x 83 mm)

0719 door buMPer

Chrome-plated Zamac 2 3 ⁄

16

" (55 mm) diameter flange. Projects 1 7 ⁄

8

"

(50 mm).

0755-z rouNd towel bar

Triple chrome-plated rust resistant Zamac tubing. 18", 24", 30" and 36" (460, 610, 760 and 915 mm) long.

S P E C I A L T y

A C C E S S O R I E S

surface MouNted facial tissue disPeNser

Cabinet type 304 stainless steel, satin finish. Dispenses 300 single-ply or 150 two-ply sheets.

overall dimensions:

10

15

16

" x 5" x 2

1

8

"

(260 x 125 x 55 mm)

0259-ss recessed facial tissue disPeNser

Dispenses 300 single-ply or 150 double-ply tissue. Faceplate type

304 stainless steel satin finish.

overall dimensions:

11

7

8

" x 6

3

8

" x 2

1

/

4

"

(302 x 162 x 57 mm)

0002-sM staiNless steel surface

MouNted PaPer cuP disPeNser

Dispenses 100 flat bottom cups. Adjustable for 3 oz. through 6 oz. cups. Stainless steel with bright finish.

overall dimensions:

3" Diameter x 15"

(75 x 380 mm)

0484-Hc dual access seat cover aNd toilet tissue disPeNser

One side mounts flush to partition of barrier-free side to allow for grab bar.

Usable by both sides but serviced from one side. Holds 1000 seat covers and

4 rolls of toilet tissue.

unit size:

17

3

8

" x 30

5

8

" x 4

1

ADA compliant.

/

4

"

(441 x 778 x 108 mm)

Partition opening:

15

1

/

2

" x 28

7

8

"

(395 x 735 mm) adjustable for partitions in thickness from 1

/

2

" to 3¾" (13 to 95 mm)

dual access toilet tissue disPeNser witH NaPkiN disPosal

Mounts through partition, usable by both sides but serviced from one side. Holds

4 rolls of toilet tissue.

unit size:

17

3

8

" x 20" x 4 1 /

4

"

(440 x 510 x 110 mm)

Partition opening:

15 1 /

2

" x 18 1 /

4

"

(395 x 465 mm)

0481 dual access seat cover aNd toilet tissue disPeNser witH saNitary disPosal

Mounts through partition usable by both sides but serviced from one side.

Holds 1000 seat covers and 4 rolls of toilet tissue.

unit size:

17

3

8

" x 30

5

8

" x 4

1

/

4

"

(440 x 780 x 110 mm)

Partition opening:

15

1

/

2

" x 28

7

8

"

(395 x 735 mm)

Partitions . Accessories . Lockers

59

SHOWN: 74022-H TOILET TISSUE DISPENSER

T O I L E T T I S S U E

D I S P E N S E R S

Toilet Tissue Dispensers

ASI offers many different designs and styles to complement the features of your washroom setting. Engineered for heavy-duty use and easy maintenance, these units stand the test of time.

Choose from a wide range of features, based on your own washroom needs. All of these options are easy to install, easy to use, durable and affordably priced.

WHAT MAkES THESE DISPENSERS UNIqUE?

18-22

Gauge

staiNless steel coNstructioN

Our dispensers are made of stainless steel, which is tough, durable material that is stain-resistant and easy to clean.

tuMbler locks

Our tumbler locks provide convenience and security with an elegant look.

safe easy disPeNsiNg

Dispensing and storage options vary, from single roll to multiple rolls or jumbo roll dispensers.

viewiNg slot

Slot in front cover of jumbo roll dispensers provides easy visual indication of remaining tissue supply.

TOILET TISSUE DISPENSERS PRODUCT SPECIFICATIONS

features

• Easy to use and clean

• Spring-loaded chrome roller may apply

• Theft-resistant spindle and vandal-resistant locking device options

• Some models have built-in storage for additional rolls

diMeNsioNs

Unit dimensions vary by model.

See individual product descriptions for details.

Partitions . Accessories . Lockers

61

9030 surface MouNted dual roll toilet tissue disPeNser

Holds two rolls up to 5¼" (135 mm) diameter (1800 sheets). Top roll automatically drops in place when bottom roll is used up. Type 304 stainless steel cabinet and mechanism.

Theft-resistant spindles.

unit size:

6" x 12" x 6

1

2

"

(152 x 305 x 165 mm)

0030 surface MouNted dual roll toilet tissue disPeNser

Holds two rolls up to 5¼” (135 mm) diameter (1800 sheets). Top roll automatically drops in place when bottom roll is used up. Type

304 stainless steel cabinet and mechanism. Theft-resistant spindles.

unit size:

6" x 12" x 6

1

2

"

(152 x 305 x 165 mm)

0032 dual access PartitioN

MouNted dual roll toilet tissue disPeNser staiNless steel

Serves two toilet compartments by mounting through partition. Dispenses

4 toilet tissue rolls. Adjustable to accommodate partitions from ½" to

1¼" thick (13 to 32 mm).

unit size:

14" x 14 1 ⁄

8

" x 10"

(356 x 359 x 255 mm)

Partition opening:

12 1 ⁄

8

" x 12 1 ⁄

4

" x 1 ⁄

2

-2 1 ⁄

2

"

(308 x 311 x 13-64 mm)

0031 recessed dual roll toilet tissue disPeNser

Similar to 0030, but provided with flange for recess mounting.

unit size:

8" x 14" x 6 1 ⁄

2

"

(203 x 356 x 165 mm)

wall opening:

6 1 ⁄

4

" x 12 1 ⁄

4

" x 3 3 ⁄

8

"

(159 x 311 x 86 mm)

T O I L E T T I S S U E

D I S P E N S E R S

0039 low Profile surface MouNted twiN 9" JuMbo roll toilet tissue disPeNser

Holds two 9" (229 mm) diameter rolls of

2¼" or 3" (57 or 76 mm) diameter core.

When one roll is depleted, slide panel to expose other roll. Door cabinet and mounting plate fabricated of 18 gauge type

304 stainless steel with a satin finish. Door is hung on heavy-duty stainless steel pivot hinges. Equipped with tumbler lock.

overall dimensions:

20

1

2

" x 11

3

16

" x 4

11

16

"

(521 x 284 x 119 mm)

surface MouNted twiN 9"

JuMbo roll toilet tissue disPeNser

Holds two 9" (230 mm) diameter rolls of

2¼" or 3" (57 or 76 mm) diameter core.

When one roll is depleted, slide panel to expose other roll. Door cabinet and mounting plate fabricated of 18 gauge type 304 stainless steel with a satin finish.

Two viewing slots reveal toilet tissue rolls inside. Equipped with tumbler lock.

overall dimensions:

20

13

16

" x 11

3

8

" x 6

3

16

"

(530 x 290 x 160 mm)

0042 surface MouNted JuMbo roll toilet tissue disPeNser

Holds one roll up to 10" (254 mm) diameter of 1

5

8

" or 2¼" (41 or 57 mm) diameter core.

Outer cabinet is type 304 stainless steel with a satin finish. Unit has viewing slot and tumbler lock.

overall dimensions:

10

5

8

" x 4

1

2

"

(270 x 115 mm)

74022-H double toilet tissue Holder witH Hood

Recessed dual roll toilet paper holder with hood is fabricated of stainless steel type 304.

Rollers are made of chrome-plated ABS and spring-loaded.

Model oPtioNs:

74022 Same as 74022-H but without hood.

overall dimensions:

12 1 /

2

" x 6 1 /

4

"

(320 x 160 mm)

Partitions . Accessories . Lockers

63

0263-1 siNgle roll toilet tissue disPeNser

Single roll toilet tissue dispenser with controlled-delivery spindle. Holds and dispenses all standard core roll tissue up to 6 " (152 mm) diameter. Fabricated of heavy-duty aluminum casting with satin-matte, silver-grey finish.

Model oPtioNs:

0264-1 Double Roll Toilet Tissue Dispenser.

overall dimensions:

6

9

16

" x 1

3

4

" x 4

3

4

"

(167 x 44 x 120 mm)

0267 vaNdal-resistaNt Hood

14 gauge satin finish stainless steel for use only with 0264-1 (specified and purchased separately).

unit size:

14 1 ⁄

8

" x 7 3 ⁄

4

" x 6 1 ⁄

2

"

(359 x 197 x 175 mm)

0697-gal staiNless steel sHelf aNd double toilet tissue Holder

Shelf, 18 gauge type 304 stainless steel satin finish with front edge hemmed.

Holds two 1800 sheet toilet tissue rolls.

overall dimensions:

18" x 5"

(460 x 130 mm)

64

7305-b* surface MouNted toilet tissue Holder

Type 304 bright finish stainless steel with chrome-plated roller. Heavy gauge concealed bracket mounts on wall.

Holds 1800 sheet standard core roll.

7305-s – satin finish

7305-s/b overall dimensions:

7

3

4

" wide

(200 mm)

7305-2S / 2B – Holds 2 rolls.

overall dimensions:

13

1

2

" wide

(345 mm)

* For theft-resistant spindle add R-009 after model number.

double surface MouNted toilet tissue Holder cHroMe-

Plated steel

Provided with vandal-resistant locking device and mechanism to provide controlled delivery. High polish finish.

Dispenses two standard or 1800 sheet toilet tissue rolls.

overall dimensions:

12

3

8

" x 2

3

4

" x 4

1

4

"

(315 x 70 x 110 mm)

siNgle surface MouNted toilet tissue Holder overall dimensions:

6" x 2 3 ⁄

4

" x 4 1 ⁄

4

"

(150 x 70 x 110 mm)

7403 eXtra roll recessed toilet tissue Holder

Spring-loaded chrome roller. Extra roll stored behind roll in use.

Model oPtioNs:

7403-b Rec., Bright Stainless Steel

7403-s Rec., Satin Stainless Steel

NOTE: If drywall installation is required, add suffix

“D” to model number. If wetwall installation is required, add suffix “W” to model number

(no clamp is required for wetwall).

overall dimensions:

6

1

4

" x 6

1

4

"

(160 x 160 mm)

T O I L E T T I S S U E

D I S P E N S E R S

recessed toilet tissue Holder

Holds any standard core roll tissue up to

5" (127 mm) diameter. Die-cast of Zamac in seamless one-piece construction.

wall opening:

5

1

/

4

" x 5

1

/

4

" x 2"

(135 x 135 x 50 mm)

0477-sM surface MouNted toilet seat cover disPeNser

Dispenses 250 single or half-fold seat covers.

Fabricated of 22 gauge type 304 stainless steel with satin finish.

overall dimensions:

15

3

/

4

" x 11

1

/

4

" x 2

5

8

"

(400 x 285 x 67 mm)

recessed toilet seat cover disPeNser

Door has tumbler lock, dispenses 500 single or half-fold seat covers.

unit size:

17

1

/

4

" x 12

3

/

4

" x 2

3

8

"

(440 x 325 x 60 mm)

wall opening:

15

3

/

4

" x 11

1

/

4

" x 2

5

8

"

(400 x 280 x 67 mm)

20477-sM surface MouNted seat cover disPeNser

Dispenses 250 seat covers. Fabricated of

20 gauge type 304 stainless steel with a satin finish.

overall dimensions:

15

3

/

4

" x 11" x 2

3

8

"

(400 x 280 x 60 mm)

0705-z toilet PaPer Holder

Fabricated from triple chrome-plated rust resistant Zamac.

overall dimensions:

5

7

/

8

" x 1

7

/

16

" x 2

3

4

"

(149 x 37 x 70 mm)

7303 eXtra roll toilet tissue Holder

Extra roll of paper is placed over the horn type holder. Stainless steel set screw on bottom of flange locks unit to mounting plate.

r-009 tHeft-resistaNt sPiNdle

Note: R009 Theft-resistant spindle is available for any toilet tissue holder indicated with an asterisk, by adding

R009 suffix after model number.

Partitions . Accessories . Lockers

65

Grab Bars

All ASI grab bars are made in compliance with

ADA guidelines for strength requirements. Various configurations feature satin finish 18 gauge type

304 stainless steel (peened or smooth). These single structure units are heliarc welded, and mandrel bending ensures uniform bar diameters.

SHOWN: 3700 SNAP FLANGE

66

eXPosed MouNtiNg

3400 series

— 1¼" (32 mm) O.D.

3500 series

— 1½" (38 mm) O.D.

Features include flange of 3" (76 mm) diameter, 1 /

8

" (3 mm) thick type 304 stainless steel with a satin finish; exposed mounting screw holes are drilled and countersunk.

sNaP flaNge

3700 series

— 1¼" (32 mm) O.D.

3800 series

— 1½" (38 mm) O.D.

Features include cover that snaps over mounting flange dimples to conceal screws and concealed mounting flange of 3

1

/

8

" (79 mm) O.D. diameter with 2 screw holes and 3 locking dimples;

1

/

8

" (3 mm) thick, type 304 stainless steel.

Cover is type 304 stainless steel with a satin finish and

22 gauge, 3

3

/

16

" (81 mm) diameter.

grab bar coNfiguratioNs

The following standard shapes are typical configurations. Grab bars can be custom designed and manufactured to meet any specific architectural requirement.

Designers Note:

For a non-slip surface, specify suffix “P” (peened). When specifying grab bars insert the configuration type numbers listed below into the double zeros at the end of the grab bar series number.

Example 1: A 1½" (38 mm) concealed 18" x 33" (460 x 840 mm) horizontal grab bar has a model number — 3874. When a special size is needed add suffix “M” plus the size, to the closest standard bars.

Example 2: A 1½" (38 mm) concealed 23" x 37" (585 x 940 mm) horizontal grab bar has a model number 3874-M2337.

12" to 48 "

305 to 1219mm

type - 01

A

type - 02

A = 52"

(1321 mm)

A = 54"

(1372 mm)

A = 60"

(1524 mm)

A = 72"

(1829 mm)

type - 15

32"

813mm

16"

406mm

type - 04

Left hand shown, right hand opposite

Swings

Up

30"

762mm

type - 13

6"

152mm

10"

254mm

33"

838mm

52"

1321mm

type - 24

30"

762mm

B

30"

762mm

33"

838mm

type - 33

Right hand shown, left hand opposite

5"

127mm

12"

305mm

A

24"

610mm

type - 34

24"

610mm

1"

25mm

type - 50 type - 56 type - 57

A = 24"

(610 mm)

B = 36"

(914 mm)

A = 36"

(914 mm)

B = 54"

(1372 mm)

A = 42"

(1067 mm)

B = 54"

(1372 mm)

18"

457mm

Swings

Up

29"

137mm

type - 60

A = 18"

(457 mm)

B = 30"

(762 mm)

type - 62

A = 15 7 ⁄

8

"

(403 mm)

B = 30

7

8

"

(784 mm)

type - 74

A = 18

1

8

"

(457 mm)

B = 33

1

8

"

(838 mm)

type - 51

4"

102mm

12"

305mm

30"

762mm

18"

457mm

type - 75

27"

686mm

33"

838mm

6"

152mm

type - 54

33"

838mm

67

Partitions . Accessories . Lockers

Shower/Tub

Accessories

ASI provides a full range of shower and tub accessories that show attention to details to address the safety and comfort needs of users. All items—including shower seats and benches, tub seats, soap dishes and shower curtain rods—are designed to ensure secure installation and easy use.

SHOWN: 1214 HEAVy-DUTy SHOWER CURTAIN ROD

68

0398 recessed Heavy-duty staiNless steel soaP disH aNd bar

Type 304 stainless steel unit with bright polished finish exterior and sand blasted finish interior. Includes mounting clamp for stud walls.

overall dimensions:

7

1

8

" x 5"

(180 x 130 mm)

wall opening:

6

1

8

" x 4

1

8

" x 4"

(155 x 105 x 100 mm)

Model oPtioNs:

0399

Same as 0398, but includes kit for installing in cement wall.

0400

Without bar.

0401

Same as 0400, but includes kit for installing in cement wall.

0410-z recessed soaP disH witH bar

Die-cast of Zamac in seamless one-piece construction.

A plastic soap tray with drying ribs interlocks with housing for retention.

wall opening:

5

1

4

" x 5

1

4

" x 2"

(133 x 133 x 51 mm)

S H O W E R / T U B

A C C E S S O R I E S

7404 recessed soaP disH

Seamless one-piece construction fabricated of 22 gauge stainless steel type 304. Provided with a raised lip to retain soap.

overall dimensions:

6

1

4

" x 6

1

4

"

(160 x 160 mm)

7410 recessed soaP disH aNd bar

One-piece construction soap dish fabricated of 22 gauge

304 stainless steel. Includes a bar, held permanently between two posts at top of unit.

overall dimensions:

6

1

4

" x 6

1

4

"

(160 x 160 mm)

1204 eXtra Heavy-duty sHower curtaiN rod

3" (75 mm) diameter flanges of 20 gauge type 304 stainless steel with satin finish and 1

1

/

4

" (32 mm) diameter rod of 18 gauge type 304 stainless steel tubing with satin finish. Available in lengths up to 96"

(2440 mm); special order on longer lengths.

1214 Heavy-duty sHower curtaiN rod

20 gauge, 1" (25 mm) diameter rod.

Available in lengths up to 72" (1830 mm); for longer lengths, specify 1204.

Partitions . Accessories . Lockers

69

1224 coNcealed MouNtiNg sHower curtaiN rod

Chrome-plated brass with satin finish flanges and 1" (25 mm) diameter rod of 20 gauge type 304 stainless steel with satin finish.

One flange has set screw to lock rod and prevent rotation. Available in lengths up to 72" (1830 mm); for longer lengths, specify 1204.

1200-sHu sHower curtaiN

Hook

Stainless steel hook for rods 1"

(25 mm) and 1¼" (32 mm) diameter.

Size: 1 9 /

16

" x 2 5 /

8

"

(40 x 66 mm)

1200-v viNyl sHower curtaiN

Flame-resistant, anti-bacterial,

8 gauge white vinyl fabric with standard height of 72" (1830 mm).

Curtain should be 6" (150 mm) wider than opening up to 48"

(1220 mm) and 12" (305 mm) wider than opening exceeding

48" (1220 mm).

70

8208-r foldiNg sHower seat

Slats are fabricated with stainless steel in satin finish.

Model oPtioNs:

8208-l Similar to 8206-R, but with left hand seat.

0010 corNer sHower seat

Seat, support brackets and retainer clip are type 304 satin finish stainless steel. Seat is secured to one wall with full length piano hinge and support on other wall by bracket.

Size: 15

3

/

4

" x 15

3

/

4

"

(400 x 400 mm)

S H O W E R / T U B

A C C E S S O R I E S

8209 rectaNgular PHeNolic four-leg fold-uP sHower beNcH

Seat is white colored, black core phenolic. Frame, mounting bracket and retainer hook are type 304 satin finished stainless steel. Seat is 22

1

/

2

" (572 mm) deep and 48" (1219 mm) wide, projecting 24" (610 mm) from the wall when in the open position. When retracted, legs fold up to provide low profile against wall. ADA compliant.

8206-l foldiNg sHower seat

(Left Hand) Meets ADA Accessibility Guidelines and the needs of the physically disabled and elderly. Seat is ½"

(13 mm) thick, one piece solid, white colored, black core phenolic. Frame, support legs, flanges, and bracket are type 304 satin finish stainless steel. Features a reversible self-locking mechanism. Seat measures 33" (840 mm) wide and projects 22

7

8

" (580 mm) from wall.

Model oPtioNs:

8206-r Right hand seat.

8205-l Left hand seat with cushion covered in off-white Naugahyde ® .

8205-r Right hand seat with cushion covered in off-white Naugahyde

®

.

8203 coMPact foldiNg seat

5

/

16

" (8 mm) thick, one-piece, solid, white colored, black core phenolic seat. Frame, support legs, flanges and bracket are type 304 satin finish stainless steel. Features a self-locking mechanism. Seat measures 18" (460 mm) wide and projects 16" (405 mm) from wall.

Model oPtioNs:

8204 Seat is sponge cushion covered with off-white

Naugahyde

®

mounted on ½" (13 mm) thick marine grade plywood.

8207 Seat is fabricated of stainless steel, satin finish, slatted design.

8358 foldiNg tub seat

1

/

2

" (13 mm) thick, solid, white colored, black core phenolic seat. Frame, mounting bracket and retainer hook are type 304 satin finished stainless steel. Seat measures 15" (380 mm) deep and projects 33

3

/

4

" (860 mm) from wall.

Partitions . Accessories . Lockers

71

SHOWN: 9013-9 BABy CHANGING STATION

B A B Y C H A N G I N G

S T A T I O N S

Baby Changing Stations

ASI offers baby safe solutions for baby changing stations. All units are easy to install, durable and sanitary.

To meet your washroom needs, we offer numerous choices along with many ADA-compliant models.

WHAT MAKES OUR BABY CHANGING STATIONS UNIQUE?

up to

350 lb. capacity

LARGE WEIGHT

CAPACITY

Our baby changing stations have been tested using

ASTM F2285-04 and

EN 12221-1 protocol for a static load and in addition have been tested to hold a weight in excess of 350 lbs.

ADA ACCESSIBILITY

STANDARD COMPLIANT

Our units are engineered to comply with the standards set forth by the

American Disabilities Act for accessibility and safety.

EASY OPEN AND CLOSE

Our units are designed for easy one-handed operation and shaped to safely cradle a child’s body.

FDA approved

FUNGUS- AND BACTERIA-

RESISTANT SOLID

PLASTIC

The FDA-approved plastic can be used for our baby changing stations and has been shown to inhibit the growth of bacteria and fungus.

BABY CHANGING STATIONS PRODUCT SPECIFICATIONS

FEATURES

• Easy to install

• Sanitary, safe and strong

• All units fold up; no obstruction when not in use

• Easy to clean

DIMENSIONS

Unit dimensions vary by model.

See individual product descriptions for details.

Partitions . Accessories . Lockers

73

new

9014 HorizoNtal surface MouNted solid

Plastic baby cHaNgiNg statioN

This horizontal unit has a pull handle and concealed damped gas spring, assisting in easy operation.

Can be fabricated of FDA-approved fungus- and bacteria-resistant solid plastic. Unit is ADA compliant and supports a static load of 300 lbs. Its vinyl-coated, adjustable safety strap assures child protection.

overall dimensions:

Closed:

35 5 ⁄

32

" x 24 1 ⁄

4

" x 3 7 ⁄

8

"

(893 x 616 x 98 mm)

Open:

35 5 ⁄

32

"x 24 1 ⁄

4

" x 22"

(893 x 616 x 559 mm)

new

9015 vertical surface MouNted solid Plastic baby cHaNgiNg statioN

Vertical format. Unit is ADA compliant and shall support a static load of 300 lbs. and be tested in excess of 350 lbs.

overall dimensions:

Closed:

24 1 ⁄

4

" x 35

5

32

" x 3

7

8

"

(616 x 893 x 98 mm)

Open:

24 1 ⁄

4

" x 35

5

32

" x 32

7

8

"

(616 x 893 x 835 mm)

74

new 9018 HorizoNtal recessed MouNted staiNless steel baby cHaNgiNg statioN

Unit is ADA compliant and shall support a static load of

300 lbs. and be tested in excess of 350 lbs.

Model oPtioNs:

9018-9 With stainless steel collar for surface mounting.

overall dimensions:

Closed:

39 ⁄ ⁄ " x 28 ⁄ ⁄

4

" x ⁄ ⁄ "

(995 x 718 x 10 mm)

Open:

39 ⁄ " x 28 ⁄

4

" x 18 ⁄

2

"

(995 x 718 x 470 mm)

wall opening:

35 ⁄

2

" x 24 ⁄

2

" x 4" min

(902 x 622 x 102 mm)

new 9017 vertical recessed MouNted staiNless steel baby cHaNgiNg statioN

This vertical station has a door facing and collar made from 18 gauge 304 stainless steel. Can be fabricated of

FDA-approved fungus- and bacteria-resistant solid plastic.

ADA compliant and shall support a static load of 300 lbs.

Model oPtioNs:

9017-9 With stainless steel collar for surface mounting.

overall dimensions:

Closed:

28 1 ⁄

4

" x 39

5

32

" x

3

8

"

(718 x 995 x 10 mm)

Open:

28 1 ⁄

4

" x 39 5 ⁄

32

" x 29 3 ⁄

8

"

(718 x 995 x 746 mm)

wall opening:

24 1 ⁄

2

" x 35 1 ⁄

2

" x 4" min

(622 x 902 x 102 mm)

B A B y C H A N G I N G

S T A T I O N S

9012 surface MouNted baby cHaNgiNg statioN

Modern styling and easy-to-clean surface is fabricated of

100% high-density polyethylene. Easy opening/closing pneumatic mechanism has oversized hinge and safety stop system. The built-in dispenser for towels or sanitary liners, hooks for diaper bag and purse, plus multi-lingual instructions add friendliness and convenience. Unit is

ADA compliant and shall support a static load of 300 lbs.

Surface mounted. Only 4" (102 mm) deep when closed.

overall dimensions:

Closed:

36" x 22

1

4

" x 4"

(914 x 565 x 102 mm)

Open:

36" x 22

1

4

" x 20

7

16

"

(914 x 565 x 519 mm)

9013 recessed staiNless steel baby cHaNgiNg statioN

ADA-compliant unit features welded stainless steel for long and reliable use. Exposed surfaces are satin finish. Easy one-handed operation is assisted by a pull handle and concealed spring.

The changing surface is high-impact-resistant plastic for easy cleaning. Its adjustable safety strap and 400 lb. (181 kg) load capacity assures child protection. Complies with Handicapped

Accessibility codes.

Model oPtioNs:

9013-9 With stainless steel collar for surface mounting.

overall dimensions:

Open:

37" x 25

1

2

" x 17

3

4

"

(940 x 648 x 451 mm)

Closed:

37" x 25

1

2

" x

1

4

"

(940 x 648 x 6 mm)

wall opening:

34

1

4

" x 22

3

4

" x 3

3

4

"

(870 x 578 x 95 mm)

new 9020 toddler safety seat

This solid plastic seat, mounted on the inside of the toilet partition, either on the door or panel, allows a parent to take a toddler into the stall with them. Unit is ADA compliant. Unit shall support a static load of 50 lbs.

overall dimensions:

Closed:

12

1

2

" x 21

3

4

" x 5

1

2

"

(318 x 552 x 140 mm)

Open:

12

1

2

" x 21

3

4

" x 11

1

8

"

(318 x 552 x 283 mm)

Partitions . Accessories . Lockers

75

Shelves

ASI offers various configurations, sizes and styles, including platform, recessed and folding utility shelving—all sturdy, durable and constructed of stainless steel.

S H O W N : 2 0 6 9 2 S U R F A C E M O U N T E D S H E L F

76

0690 sHelf witH raised edges

Entire unit is formed of one piece of 18 gauge stainless steel having a 3 ⁄

8

" (10 mm) depression with a satin finish.

See chart for standard sizes.

Standard Sizes:

Length

12" (305 mm)

16" (410 mm)

18" (460 mm)

24" (610 mm)

30" (760 mm)

36" (915 mm)

48" (1220 mm)

60" (1520 mm)

72" (1840 mm)

0690

6" depth

(150 mm)

Model Numbers

0692

5", 6" or 8" depth

(125,150, 200 mm)

0694

5" depth

(125 mm)

S H E L V E S

0692 sHelf

Fabricated of 18 gauge stainless steel with a satin finish.

Front edge is hemmed for maximum rigidity and safety.

See chart for standard sizes.

0698 foldiNg utility sHelf for toilet coMPartMeNts

Fabricated of 18 gauge type 304 satin finish stainless steel with raised rim. It returns to upright position when not in use.

overall dimensions:

14

5

8

" x 5

13

16

"

(370 x 150 mm)

0412 recessed sHelf

This unit is fabricated of 22 gauge, all welded construction, stainless steel with a satin finish.

overall dimensions:

18" x 8" x 4

1

/

4

" min

(457 x 203 x 108 mm)

wall opening:

16

1

/

2

" x 6

1

/

2

" x 4" min

(419 x 165 x 102 mm)

0694 sHelf witH backsPlasH

Fabricated of 18 gauge stainless steel with a satin finish on exposed surfaces with 5" (127 mm) depth.

Partitions . Accessories . Lockers

77

Custodial Accessories

Fabricated of type 304 satin finish stainless steel, our one-piece constructed custodial accessories—with various configurations of mop and broom holders and utility hooks—help keep necessary cleaning tools and supplies organized and accessible.

SHOWN: 1315-3 SHELF WITH DRyING ROD,

MOP HOLDERS, HOOkS

78

1307-3 utility Hook striP witH 3 Hooks 26" (660mm)

Fabricated of type 304 stainless steel with satin finish, this strip is 4" (100 mm) high with edges returning

1

/

2

" (13 mm) to the wall.

Model oPtioNs:

1307-4 With 4 hooks 36" (915 mm)

1307-5 With 5 hooks 46" (1170 mm)

1307-6 With 6 hooks 56" (1420 mm)

1308-3 sHelf witH 4 utility Hooks aNd 3 MoP

Holders striP 34" (860mm)

Fabricated of type 304 satin finish stainless steel, this shelf is 8" (200 mm) deep with

3

/

4

" (19 mm) return for rigidity.

Mop holders are riveted to strip, and rubber cam is ribbed for grasping. Unit is 14

1

/

2

" (370 mm) high.

Model oPtioNs:

1308-4 4 mop holders/5 utility hooks, 44" (1120 mm) long.

C U S T O D I A L

A C C E S S O R I E S

1315-4 utility sHelf witH dryiNg rod, 4 MoP Holders aNd

3 rag Hooks, 36" (915 mm)

3

Fabricated of type 304 satin finish stainless steel, this shelf is 8" (200 mm) deep with

/

4

" (19 mm) return for rigidity. Mop holders are riveted to strip, and rubber cam is ribbed for grasping. Rod and hooks for wet rags are included.

Model oPtioNs:

1315-3 3 mop holders/2 rag hooks,

30" (760 mm)

1315-6 6 mop holders/5 rag hooks,

48" (1220 mm)

1306 Heavy-duty utility Hook

Heavy-duty 11 gauge stainless steel with satin finish.

0533-48 corNer guard

18 gauge type 304 stainless steel satin finish with

1

/

8

" finish; adhesive mounted.

overall dimensions:

48" x 4

1

/

4

" x 4

1

/

4

"

(1220 x 110 x 110 mm)

otHer sizes available uPoN request.

8215-5 MoP aNd brooM racks

5 holders, 46" (1170 mm) long. Fabricated from one-piece hi-hat channel stainless steel.

Model oPtioNs:

8215-3 3 holders, 26" (660 mm) long

8215-4 4 holders, 36" (914 mm) long

Partitions . Accessories . Lockers

79

SHOWN: 0515 TURNTABLE SPECIMEN PASS BOx

H E A L T H C A R E

A C C E S S O R I E S

Healthcare Accessories

ASI offers many different items that are specifically designed for healthcare settings. All of these items contribute to providing an organized and hygienic environment for patients and caregivers.

These items include medicine cabinets, specimen and bedpan cabinets, corner guards and surgical soap dispensers. All items are designed for ease of use, safety and durability.

WHAT MAkES OUR HEALTHCARE ACCESSORIES UNIqUE?

18-22

Gauge

staiNless steel coNstructioN

Our cabinets are made of stainless steel, which is tough, durable, stainresistant and easy to clean.

cyliNder lock

The design of our cylinder locks allows for the removal of the cylinder for sterilizing or autoclaving when necessary.

coNveNieNt Passage

Our specimen pass box and cabinet enables easy access and safe handling of specimens from patient area to laboratory.

adJustable sHelves

The design of our cabinets offers flexibility with adjustable shelves for ease in storage and use.

HEALTHCARE ACCESSORIES PRODUCT SPECIFICATIONS

features

• Easy to install

• Hygienic and safe to use

• Durable

• Easy to clean

diMeNsioNs

Unit dimensions vary by model.

See individual product descriptions for details.

Partitions . Accessories . Lockers

81

0952 recessed staiNless steel MediciNe cabiNet

Swing door mirror frame is type 304 stainless steel with satin finish. Mirror is ¼" (6 mm), guaranteed for 15 years against silver spoilage. Door has full length piano hinge and magnetic catch. Three removable stainless steel shelves.

wall opening:

16" x 22 3 /

4

" x 3 1 /

2

" min

(406 x 578 x 89 mm)

Model oPtioNs:

0952-b Larger than 0952.

overall dimensions:

24" x 26"

(610 x 660 mm)

overall dimensions:

18 1 /

4

" x 24 1 /

4

"

(465 x 620 mm)

0953 surface MouNted staiNless steel

MediciNe cabiNet

Swing door cabinet is fabricated of cold rolled steel with white baked enamel finish. Cabinet is provided with two removable shelves.

overall dimensions:

18 1 /

4

" x 24 1 /

4

" x 5 1 /

4

"

(464 x 616 x 134 mm)

Model oPtioNs:

8338 Smaller and has two adjustable white baked enamel steel shelves.

14 1 /

8

" x 20 3 /

16

" x 5"

(359 x 513 x 125 mm)

8339

16

3

Larger than 8338.

16

" x 22

3

16

" x 5"

(410 x 565 x 125 mm)

82

0515 turNtable sPeciMeN Pass boX

Fabricated of 18 gauge type 304 satin-finish stainless steel. Turntable cylinder is 12"

(305 mm) diameter with 10½" x 6" (270 x

150 mm) opening. Stainless steel selflubricating ball bearing plates mounted on top and bottom permit the unit to rotate freely. Positioned bullet catches prevent uncontrolled rotation. Entire inner assembly is encased in 1" (25 mm) wide trim.

Cylinder lock allows for the removal of the cylinder for sterilizing or autoclaving when necessary. Trim is adjustable for wall up to

7" (180 mm) thick.

8154 Pass tHrougH sPeciMeN cabiNet

Provides a convenient passage from patient-area into laboratory. Fabricated of 22 gauge type 304 satin-finish stainless steel. Internal latch prevents simultaneous door opening. Stainless steel tray is removable. Mounts in wall thickness of 1¾" to 5½" (45 to 135 mm).

0533-48 corNer guard

18 gauge type 304 stainless steel satin finish with

1

/

8

" finish; adhesive mounted.

overall dimensions:

48" x 4

1

/

4

" x 4

1

/

4

"

(1220 x 110 x 110 mm)

otHer sizes available uPoN request.

H E A L T H C A R E

A C C E S S O R I E S

0551 recessed bedPaN aNd uriNal bottle cabiNet

Recessed cabinet is 22 gauge type 304 satin finish stainless steel for storage of bedpan and urinal. Cabinet provided with ½" (13 mm) open space across top and bottom of door to allow air circulation.

Model oPtioNs:

0558-1 recessed bedPaN aNd wasHbasiN cabiNet

Holds one conventional type bedpan and one wash basin.

0349 foot oPerated surgical soaP disPeNser

Pneumatic pump mechanism, 32 oz. (.9 L) polyethylene container. Free turning spout is type 316 stainless steel.

96" (245 mm) long vinyl tubing attaches to anti-slip foot pump. Dispenses surgical soaps, antiseptic solutions and synthetic detergents.

overall dimensions:

4

1

/

4

" x 12

3

/

4

" x 9"

(108 x 324 x 228 mm)

Spout Projection: 4

3

4

" (121 mm)

0557 surface MouNted bedPaN rack

Surface mounted rack provides convenient storage for one conventional sized bedpan.

overall dimensions:

12" x 11"

(300 x 280 mm)

Model oPtioNs:

0556 surface MouNted bedPaN aNd uriNal rack

Larger for storing one conventional sized bedpan and one urinal bottle.

0559 surface MouNted double bedPaN rack

Similar to 0556, but designed to hold two conventional sized bedpans.

0350 surgical soaP disPeNser

Dispenses antiseptic solutions and synthetic detergent soaps. Chrome-plated brass body. Capacity: 16 oz. (0.5 L) white polyethylene globe.

overall dimensions:

3 3 /

8

" x 6 1 /

2

" x 5 1 /

8

"

(86 x 165 x 130 mm)

Partitions . Accessories . Lockers

83

SHOWN: 7383 TOWEL SHELF WITH HANGER ROD

H O S P I T A L I T y

A C C E S S O R I E S

Hospitality Accessories

ASI offers a wide range of options to accessorize the washroom setting. These items include towel bars and racks, clothes hooks, shelving and holders. All items are easy to install and easy to clean.

These items add a special touch and convenience for washroom users.

WHAT MAkES OUR HOSPITALITy ACCESSORIES UNIqUE?

304

Stainless Steel

LEED

Friendly

®

staiNless steel coNstructioN

Our heavy-duty items are made of high-quality 304 stainless steel, which is tough, durable, stainresistant and easy to clean.

MiNiMalistic, coNteMPorary aNd classic

Different styles allow you to choose what works best to complement your washroom.

leed

®

-frieNdly

The robust construction made of type 304 stainless steel is LEED ® -friendly and fits our sensibility about longer lifecycle building designs.

refiNed look, ricH fuNctioN

These accessories add a special touch to enhance the user’s experience in the washroom setting.

HOSPITALITy ACCESSORIES PRODUCT SPECIFICATIONS

features

• Easy to install

• Hygienic and safe to use

• Durable

• Easy to clean

diMeNsioNs

Unit dimensions vary by model.

See individual product descriptions for details.

Partitions . Accessories . Lockers

85

7313 soaP disH witH glass Holder

Clear glass holder has raised ribs to elevate soap slightly above surface to promote drying. May be removed for cleaning. All other parts of the unit are fabricated of satin-finish stainless steel.

overall dimensions:

4

5

16

" DiA x 4

7

8

"

(107 DiA x 124 mm)

7308 siNgle robe Hook

Extends 2

5

16

" (59 mm) from wall or door. Suitable for robes, clothing or small bags. Satin finish.

86

7312 double robe Hook

Two hooks, set apart at 90° on center, extend 2 bags. Satin finish.

3 ⁄

8

" (60 mm) from wall or door. Suitable for robes, clothing or small

7314 siNgle toilet PaPer roll Holder

The toilet paper placed on this bail-type holder has unrestricted feed. Its design allows for easy replacement by maintenance or even guests. All exposed surfaces have a satin finish. Paper bar is reversible to change handing.

overall dimensions:

5

3

16

" x 3

3

8

" x 2

9

16

"

(131 x 86 x 65 mm)

H O S P I T A L I T y

A C C E S S O R I E S

7314-H siNgle toilet PaPer roll Holder witH Hood

Satin-finish hood. Hood adds weight for easy tear and also protects paper roll from water droplets.

overall dimensions:

5

7

8

" x 5" x 2

9

16

"

(149 x 127 x 65 mm)

7316 sPare toilet PaPer Holder

Holds one roll of toilet paper. Extends 4" (102 mm) from wall. All exposed surfaces have a satin finish.

overall dimensions:

3

35

64

" DiA x 6

5

8

"

(90 DiA x 167 mm)

0259-ss recessed facial tissue disPeNser

Dispenses 300 single-ply or 150 double-ply tissues.

Faceplate of type 304 stainless steel satin finish.

overall dimensions:

11

11

16

" x 6

3

8

"

(300 x 160 mm)

7317 covered waste recePtacle

Freestanding covered garbage can. Lid opens by depressing foot pedal. Plastic pail with wire bail included.

Satin-finish stainless steel. Capacity: 2 gal (7.6 L).

overall dimensions:

8

9

32

" DiA x 12

3

4

"

(210 DiA x 324 mm)

Partitions . Accessories . Lockers

87

7387 toilet brusH aNd Holder

Tube handle, round splash guard and storage cylinder of this wall-mounted unit are fabricated of satin-finish stainless steel. Includes a drip cup at the bottom for easy cleaning. Brush is made of PVC with a polypropylene shaft.

15

1

2

" (394 mm) from bottom of base to top of handle and extends 5

1

8

" (131 mm) from wall. Allows for easy cleaning while maintaining an elegant washroom.

Model oPtioNs:

7388 Freestanding. 15" (381 mm) from bottom of base to top of handle.

0712 surface-MouNted retractable clotHes liNe

Polished stainless steel unit has spring actuated 6'

(1829 mm) vinyl cord with white vinyl knob and locking nut to hold stretched line taut. Installs over bathtub or in shower.

88

7383 towel sHelf witH HaNger rod

Heavy-duty unit with 3 /

4

" diameter type

304 stainless steel tubing. Stainless steel setscrew provided on bottom perimeter of flanges to lock unit to mounting plates.

overall dimensions:

23

5

8

" x 3

1

2

" x 8

15

16

"

(600 x 89 x 227 mm)

7381 suNdries sHelf

Type 304 stainless steel alloy of formed round wire construction and has 25 /

64

"

(10 mm) diameter. Solid retainer cross bar as front rim. Satin finish on all visible surfaces. Stainless steel setscrew provided on bottom perimeter of flanges to lock unit to mounting plates.

overall dimensions:

3

35

64

" x 12

7

8

" x 4

7

16

"

(90 x 327 x 114 mm)

7322 soaP basket

Type 304 stainless steel alloy of formed round wire construction and fabricated with heavy gauge solid rectangular cross section formed bar top rim. Satin finish on all visible surfaces. Stainless steel setscrew provided on bottom perimeter of flanges to lock unit to mounting plates.

overall dimensions:

11

15

32

" x 2

9

32

" x 6

1

2

(291 x 58 x 165 mm)

"

H O S P I T A L I T y

A C C E S S O R I E S

7306 towel riNg

Designed for hand towels, this 7" DIA

(178 mm) towel ring is formed from a tube. Extends 2½" (64 mm) from wall.

3

8

DIA (9.5 mm) satin-finish stainless steel

"

1201-a curved sHower curtaiN rod witH MouNtiNg brackets

Fabricated of type 304 stainless steel.

Tubing is 18 gauge, 1" DIA (25 mm) with a satin finish. Length is suitable for a

60" (1524 mm) wide enclosure either on opposite walls (-B) or across the face opening (-A) depending upon rod length chosen.

Model oPtioNs:

1201-b Curved shower curtain rod with mounting brackets for opposite walls

7307-18 rouNd towel bar

Satin-finish stainless steel tube and posts with round mounting brackets on ends. Extends 2

5

8 wall. 18" in length.

" (67 mm) from

Model oPtioNs:

7307-24 Same as 7307-18, but 24"

(610 mm) in length.

5

/

8

" DIA x 24"

(67 x 610 mm)

7311 towel sHelf witH towel bar

Heavy-duty unit with

3

4

" and

3

8

" diameter type 304 stainless steel tubing. Bright finish only. Available 20" (510 mm) and 24"

(610 mm). Overall height: 6

1

⁄ projects 8" (200 mm).

2

" (165 mm);

Partitions . Accessories . Lockers

89

Security Accessories

ASI offers many different items that are specifically designed for settings with high security requirements.

Features include design for contraband detection and clothes hooks that release when excessively loaded to deter self-harm actions.

SHOWN: 128-1 BOOk SHELF/CLOTHES HOOk—FRONT MOUNTING

Special “closure plate” for security applications

165 grab bar

Tubing 18 gauge and flanges

1

8

" (3 mm) thick stainless steel type 304 with satin finish. Closure plate is

1

8

" (3 mm) thick. All welded construction. Unit has three holes through each flange for front mounting.

90

170 retractable sHower seat—froNt

MouNtiNg

Seat folds up into cabinet. Fabricated of 12 gauge stainless steel, exposed surfaces have a satin finish. Seat has reinforced channels. Wall sub frame furnished with welded-on masonry anchors. Seat shall have a flush, stainless steel, self-latching pull handle, which is accessible when unit is closed.

sub frame opening:

15" x 15" x 2

3

/

4

"

(380 x 380 x 70 mm)

128-1 book sHelf/clotHes Hook—froNt

MouNtiNg

Shelf and back plate are 14 gauge stainless steel type 304 with satin finish. Hooks are 12 gauge stainless steel and back plate is 14 gauge stainless steel. Seams are welded and ground smooth.

Hooks snap down for safety if excessively loaded. Unit has six holes through back for front mounting.

overall dimensions:

18" x 11" x 8"

(460 x 280 x 200 mm)

S E C U R I T y

A C C E S S O R I E S

122 square clotHes Hook—rear MouNtiNg

Fabricated of 12 gauge type 304 stainless steel with a satin finish. Back plate is fabricated of 14 gauge stainless steel. If hook is excessively loaded, it will snap down for safety. Unit has four studs welded on back for rear mounting.

overall dimensions Projection:

4

1

/

4

" x 4

1

/

4

" x 2 1 ⁄

8

"

(110 x 110 x 55 mm)

120 clotHes Hook—froNt MouNtiNg

Bracket 11 gauge, hook 7 gauge type 304 stainless steel with satin finish. If hook is excessively loaded, it will snap down for safety. Unit has four holes through flange for front mounting.

overall dimensions:

3" x 5" x 3 1 ⁄

16

"

(75 x 130 x 80 mm)

110-1 square recessed toilet tissue

Holder—rear MouNtiNg

Fabricated of 14 gauge type 304 stainless steel with satin finish exterior, glass blasted satin finish interior 4

1

/

2

" (115 mm) deep accommodates one standard toilet tissue roll. Flange is 7" (180 mm) square.

recessed toilet tissue Holder

—rear MouNtiNg

Fabricated of 16 gauge type 304 stainless steel, satin finish exterior, glass blasted satin finish interior. 4

1

2

" (115 mm) interior depth accommodates one standard toilet tissue roll. Hidden contraband causes roll to project from holder allowing detection. Two “T” nuts welded on back for rear mounting.

overall dimensions:

7

1

/

4

" (185 mm) diameter

Model oPtioNs:

110-a 7

1 /

4

" (185 mm) diameter

Partitions . Accessories . Lockers

91

101 fraMed Mirror—rear MouNtiNg

Frame 14 gauge type 304 stainless steel with satin finish, corners welded and ground smooth. Unit provided with fiberboard backing and six “T” nuts welded on back for rear mounting. Specify glazing suffix required, visit americanspecialties.com and also specify wall thickness if greater than 6" (150 mm).

overall dimensions:

12" x 16" x 5 ⁄

8

"

(305 x 405 x 16 mm)

104 fraMed Mirror—froNt MouNtiNg

Unit consists of wall mounting plate fabricated of 7 gauge type 304 stainless steel with four countersunk mounting holes and eight tapped holes. Formed mirror fabricated of 18 gauge type 304 stainless steel with #8 mirror polish finish provided with eight dimpled holes through integral frame and

1

4

-20 x

1

4

" Torx

®

head screws for securing to wall mounting plate.

overall dimensions:

10 1 ⁄

16

" x 11 9 ⁄

16

" x 7 ⁄

16

"

(255 x 290 x 11 mm)

92

105 fraMed Mirror—froNt MouNtiNg

Frame 14 gauge type 304 stainless steel with satin finish, corners welded and ground smooth.

Front mounting furnished with Torx ® resistant 1

vandal

4

-20" x 2 (150 mm) machine screws.

Visit americanspecialties.com for glazing options.

overall dimensions:

12" x 16" x

5

8

"

(305 x 406 x 16 mm)

129 clotHes/towel Hook striP—froNt MouNtiNg

Fabricated of 14 gauge stainless steel type 304 with satin finish. Hooks snap down for safety if excessively loaded.

Six holes through back for front mounting.

overall dimensions:

18" long x 5

1

2

" x 2

1

8

"

(460 x 140 x 55 mm)

S E C U R I T y

A C C E S S O R I E S

127 clotHes/towel Hook striP—froNt MouNtiNg

Wall plate 14 gauge with beveled edges, 11 gauge brackets and four 7 gauge hooks. Stainless steel type

304 with satin finish. Hooks snap down for safety if excessively loaded. Unit has six mounting holes through back for front mounting.

overall dimensions:

11" x 5 1 ⁄

2

" x 3 1 ⁄

8

"

(280 x 140 x 80 mm)

130 recessed sHelf—rear MouNtiNg

Shelf 16 gauge type 304 stainless steel, corners welded and ground smooth. 1" (25 mm) wide beveled satin finish trim.

Interior glass blasted finish. Unit has four studs welded on back for rear mounting.

overall dimensions:

5 1 /

2

" x 16 1 /

2

"

(141 x 419 mm)

wall opening:

5 1 /

2

" x 16 1 /

2

"

(141 x 419 mm)

140 rear MouNtiNg recessed soaP disH

Soap dish 16 gauge stainless steel type 304 with satin finish. One-piece drawn construction with beveled trim and embossments for air circulation and drainage. Unit has two “T” nuts welded on back for rear mounting.

overall dimensions:

7

3

8

" X 6"

(215 x 155 mm)

wall opening:

6 1 /

2

" x 5 x 2 3 /

4

" min

(165 x 127 x 70 mm)

107 oNe-Piece fraMed Mirror witH rouNded corNers—froNt MouNtiNg

One-piece 18 gauge type 304 stainless steel formed mirror with #8 mirror polish finish, integral frame, rounded corners and six mounting holes.

overall dimensions:

12" x 16" x

1

4

"

(305 x 405 x 6 mm)

Partitions . Accessories . Lockers

93

94

I N D E x

O f P R O D u C T S B Y C A T E g O R Y

baby cHaNgiNg statioNs

20201

17/43

64672

27/45

Model

Page

9012

75

9013

16/75

9013-9

72/75

9014

74

9015

74

9017

74

9017-9

74

9018

9018-9

9020

74

74

75

custodial accessories

HealtHcare accessories

Model

Page

0349

83

0350

83

0515

80/82

0551

83

0556

83

0557

83

0558-1

83

0559

83

0952

82

0952-b

82

0953

82

8154

82

8338

82

8339

82

Model

Page

0533-48

79/82

1306

79

1307

78

1307-3

78

1307-4

78

1307-5

78

1307-6

78

1308-3

1308-4

1315-3

1315-4

1315-6

8215-3

8215-4

8215-5

94684

22

9471

23/52

Model

78

78

78/79

79

79

79

79

79

feMiNiNe HygieNe veNdors aNd disPosals

Model

Page

0464

53

0468

52/53

0468-2

53

04684

53

0864

53

20470

14/53

204684

16/53

204684-9

16/53

20852

14/53

6468

31/52

64684

31

6471

31/53

9468

22

grab bars

Page

3400/3500

3700/3800

66

66

HaNd dryers

Model

Page

0134

28/44

0141

45

0185

45

0195

45

0197

44

0199

44

20199

17

20200

17/42/43

HosPitality accessories

Model

Page

0259-ss

87

0712

88

1201

89

1201-a

89

1201-b

89

7306

89

7307-18

89

7307-24

89

7308

86

7311

89

7312

86

7313

86

7314

86

7314-H

87

7316

87

7317

87

7322

88

7381

88

7383

84/88

7387

88

7388

88

Mirrors

Model

0535

0537

0600

50

50

50/51

0600t

50/51

0605

50/51

0620

50/51

0625

50/51

20650

50/51

20650-b

50/51

20655

17/50

20655-b

50

8026

50/51

PaPer towel disPeNsers

Model

0210

0215

0439

Page

Page

39

39

0245-ss

39

39

PaPer towel disPeNsers

& waste recePtacles

Model

Page

0462-ad

34

0462-ad-9

34

0467

36

0467-2

36

0467-9

36

0469

32/34

0469-2

34

0469-9

34

0469-bl

34

04692

35

04692-6

35

04692-9

35

04692a

35

04692a-6

35

04692a-9

35

046921

37

046921-6

37

046921-9

37

046921a

37

046921a-6

37

046921a-9

37

046924

37

046924-9

37

046924a

37

046924a-9

37

04693

36

04693-6

36

04693-9

36

04697

35

04697-4

35

04697-9

35

04697-bl

35

1001

41

204623

12

204623-9

12

20469

10/12/18

20469-9

12

204692a

13

2046921a

13

0452

38

0452-9

38

0457

38

0457-9

38

045224

38

045224-9

38

045224a

38

045224a-9

38

04523

38

04523-9

38

04523a

38

04523a-9

38

1002

41

20210

15

20452

15

204523a

15

6452

30

6452-9

30

6457

30

8165

39

8522

39

8523a

39

9452

22

9457

22

94696a

21

6462

26

6462-2

26

6462-9

26

64623

28

64623-9

28

6467

24/26

6467-9

26

64672

27/45

64676

27

64676-2

27

64676-9

27

64696

29

64696-6

64696-9

64696a

29

29

29

64696a-6

29

8205-l

8205-r

8206-l

8206-r

8207

8208-l

8208-r

8209

8358

71

71

71

70/71

71

70

70

71

71

soaP disPeNsers

64696a-9

29

9462

20

94623

22

9467

21

94676

21

9469

20

Model

Page

0326

48

0327

48

0332

49

0332-c

49

0332-cd

49

0332-d

49

0345

49

security accessories

Model

101

104

105

107

110

92

92

92

93

91

110-1

110-a

120

122

127

91

91

93

128-1

Page

91

91

90

129

92

130

93

140

93

165

90

170

90

0346

48

0347

49

0349

48

0350

83

0360

48

0361

48

0362

48

0363

48

0390

46

20333

49

20363

49

20364

49

20365

49

5001-ss

48

5002

48

6326

31

9326

23

9343

16/23/49

sPecialty accessories sHelves

Model

0412

0690

0692

0694

0698

77

76

76/77

76/77

77

20692 sHower/tub accessories

Model

0010

0398

0399

0400

0401

17/76

1200-v

1204

1214

1224

7404

7410

8203

8204

Page

Page

70

68

68

68

68

0410-z

68

1200-sHu

70

70

69/70

68/69

70

69

69

71

71

Model

Page

0002-sM

59

0258-ss

59

0259-ss

59

0481

59

04813

59

0484-Hc

59

0712

57

0714

55

0719

58

0721-z

58

0735-z

58

0740-z

55

0745-z

56

0751

55

0751-a

55

0755-ss

56

0755-z

58

0760-z

56

0785-z

54

7301

54

7310

57

7311

57

7320

58

7335

58

7340

55

7345

56

7355

57

7382

55

7385

54

8425

55

toilet tissue disPeNsers

Model

Page

0030

62

0031

62

0032

62

0039

63

0040

63

0042

63

0263-1

64

0264-1

63

0267

64

0402-z

65

0477

65

0477-sM

65

0697-gal

64

0705-z

65

0710

64

0715

64

20030

15

20477-sM

16/65

6477

31

7303

65

7305-2b

64

7305-2s

64

7305-b

64

7305-s

64

7307

65

74022

64

74022-H

60/63

7403

64

7403-b

63

7403-s

63

9030

23/62

9031

23

9477

23

9477-sM

23

r-009

65

waste recePtacles

Model

Page

0458

38

0458-cX

38

0458-dX

38

0458-9

38

04733

38

0810

40

0811

40

0812

40

0813

40

0825

40

0826

40

0827

40

0828

40

0829

40

1000

41

1000a

41

1003

41

20458

14

20826

14

6459

30

6474

30

6474-2

30

9459

22

94623

22

94696a

21

9474

22

I N D E x

O f P R O D u C T S B Y M O D E L N u M B E R S

Model Page

0350

49/83

0360

48

0361

48

0362

48

0363

48

0390

46/47

0398

68

0399

68

0400

68

0401

68

0402-z

65

0410-z

68

0412

77

0439

39

0452

38

0452-9

38

045224

38

045224-9

38

045224a

38

045224a-9

38

04523

38

04523-9

38

04523a

38

04523a-9

38

0457

38

0457-9

38

0458

38

0458-9

38

0458-cX

38

0458-dX

38

0462-ad

34

0462-ad-9

34

0464

53

0467

36

0467-2

36

0467-9

36

0468

52/53

0468-2

53

0002-sM

0010

0030

0031

0032

0039

62

63

0040

63

0042

63

59

70

62

62

0134

28/44

0141

45

0185

45

0195

45

0197

44

0199

44

0210

39

0215

39

0245-ss

39

0258-ss

59

0259-ss

59/87

0263-1

64

0264-1

63

0267

64

0318

48

0318-a

48

0326

48

0327

48

0332

49

0332-c

49

0332-cd

49

0332-d

49

0347

49

0349

48/83

04813

59

0484-Hc

59

0515

80/82

0533-48

79/82

0535

50

0537

50

0551

83

0556

83

0557

83

0558-1

83

0559

83

0600

50/51

0600t

50/51

0605

50/51

0620

50/51

0625

50/51

0690

76

0692

76/77

0694

76/77

0697-gal

64

0698

77

0705-z

65

0710

64

0712

57/88

0714

55

0715

63

0719

58

0721-z

58

0735-z

58

0740-z

55

0745-z

56

0751

55

0751-a

55

0755-ss

56

0755-z

58

0760-z

56

0785-z

54

0810

40

04684

53

0469

32/34

0469-2

34

0469-9

34

0469-bl

34

04692

35

04692-6

35

04692-9

35

04692a

35

04692a-6

35

04692a-9

35

046921

37

046921-6

37

046921-9

37

046921a

37

046921a-6

37

046921a-9

37

046924

37

046924-9

37

046924a

37

046924a-9

37

04693

36

04693-6

36

04693-9

36

04697

35

04697-4

35

04697-9

35

04697-bl

35

04733

38

0477

65

0477-sM

65

0481

59

1003

41

1200-sHu

70

1200-v

70

1201

89

1201-a

89

1201-b

89

1204

69/70

1214

68/69

1224

70

1306

79

1307-3

78

1307-4

78

1307-5

78

1307-6

78

1308-3

78

1308-4

78

1315-3

78/79

1315-4

79

1315-6

79

20030

20199

20200

20201

20210

20333

20363

20364

20365

15

17

17/42/43

17/43

20452

204523a

20458

204623

204623-9

204684

204684-9

20469

20469-9

204692a

12

12

16/53

16/53

10/12/18

12

13

49

15

15

14

15

49

49

49

0811

40

0812

40

0813

40

0825

40

0826

40

0827

40

0828

40

0829

40

0864

53

0952

82

0952-b

82

0953

82

101

92

104

92

105

92

107

93

110

91

110-1

91

110-a

91

120

91

122

91

127

93

128-1

90

129

92

130

93

140

93

165

90

170

90

1000

41

1000a

41

1001

41

1002

41

64676-9

27

6468

64684

31/52

31

64696

29

64696-6

29

64696-9

29

64696a

29

64696a-6

29

64696a-9

29

6471

31/53

6474

30

6474-2

30

6477

31

7301

54

7303

65

7305-2b

64

7305-2s

64

7305-b

64

7305-s

64

7306

89

7307

65/87

7307-18

89

7307-24

89

7308

86

7310

57

7311

57/89

7312

86

7313

86

7314

86

7314-H

87

7315

64/87

7316

87

7317

87

7320

58

7322

88

7335

58

7340

55

7345

56

7355

57

2046921a

20470

20477-sM

20650

20650-b

20655

20655-b

20692

20826

20852

14

14

3400 series

66

3500 series

66

3700 series

66

3800 series

66

5001-ss

48

5002

48

13

14/53

16/65

50/51

50/51

17/50

50

17/76

6326

31

6452

30

6452-9

30

6457

30

6459

30

6462

26

6462-2

26

6462-9

26

64623

28

64623-9

28

6467

24/26

6467-9

26

64672

27/45

64676

27

64676-2

27

8425

55

8522

39

8523a

39

9012

75

9013

16/75

9013-9

72/75

9014

74

9015

74

9017

74

9017-9

74

9018

74

9018-9

74

9020

75

9030

23/62

9031

23

9326

23

9343

16/23/49

9452

22

9457

22

9459

22

9462

20

94623

22

9467

21

94676

21

9468

22

94684

22

9469

20

94696

21

94696a

21

9471

23/52

9474

22

9477

23

9477-sM

23

r-009

64

7381

88

7382

55

7383

84/88

7385

54

7387

88

7388

88

74022

64

74022-H

60/63

7403

64

7403-b

63

7403-s

63

7404

69

7410

69

8026

51

8154

82

8165

39

8203

71

8204

71

8205-l

71

8205-r

71

8206-l

71

8206-r

70/71

8207

71

8208-l

70

8208-r

70

8209

71

8215-3

79

8215-4

79

8215-5

79

8338

82

8339

82

8358

71

95

Partitions . Accessories . Lockers

Partitions . Accessories . Lockers

441 Saw Mill River Rd., Yonkers, NY 10701

914.476.9000 • americanspecialties.com

Partitions . Accessories . Lockers

Partitions . Accessories . Lockers

Partitions . Accessories . Lockers

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
