SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Table of Contents
Electronic Safe Locks
Electronic Lock Features Chart. . . . . . . . . . . . . . . . . . .2—3
6120 Model Motorized Electronic Safe Lock. . . . . . . . . . . . . 4
6123 Model Motorized Electronic Safe Lock. . . . . . . . . . . . . 5
6124 and 6125 Model Motorized Electronic Safe Locks . . . . 6
6126 and 6127 Motorized Audit Locks. . . . . . . . . . . . . . . . . 7
6128 and 6129 A-series™ ATM Locks. . . . . . . . . . . . . . . . . . . 8
6300 Model Multiple Compartment Electronic Safe Lock. . . 9
Titan™ PivotBolt™ Safe Lock . . . . . . . . . . . . . . . . . . . . . . . 10
Titan™ D-Drive™ Safe Lock. . . . . . . . . . . . . . . . . . . . . . . . . 11
6550 Model Electronic Vault Lock . . . . . . . . . . . . . . . . . . . 12
Sliding Mechanical Deadbolts. . . . . . . . . . . . . . . . . . . . . . . . . . 35
6140 Model Electronic Door Lock . . . . . . . . . . . . . . . . . . . . . . . 13
The Brute® Electronic Door Deadlatch. . . . . . . . . . . . . . . . . . . . 36
Keypads for Electronic Locks . . . . . . . . . . . . . . . . . . . . . 14—15
Accessories for Electronic Safe Locks. . . . . . . . . . . . . . . 16—17
Product Compliance and Certification. . . . . . . . . . . . . . . . . . . . 36
4500 Series Safe Deposit Locks. . . . . . . . . . . . . . . . . . . . . 32
4100 Series Cabinet Locks. . . . . . . . . . . . . . . . . . . . . . . . . 32
Key Blanks for Safe Deposit and Cabinet Locks. . . . . . . . . 33
Padlocks
8077AD Model Combination Padlock. . . . . . . . . . . . . . . . . . 34
951C Model High Security Padlock. . . . . . . . . . . . . . . . . . . 34
Extension 50 Model Mechanical Automatic Door Deadbolts. . . . 35
Panic Exit Devices
Arm-A-Dor ® Secure Panic Exit Hardware. . . . . . . . . . . . . . 37
2740 High Security Safe Lock for GSA Applications. . . . . . . . . 18
2890 PDL High Security Pedestrian Door Lock . . . . . . . . . . 19
Technical Specifications
6120 and 6123 Model Case Dimensions. . . . . . . . . . . . . . . 38
6124, 2126, 6128, 6300 Model Case Dimensions. . . . . . . . 38
6125, 6127, 6129 Model Case Dimensions with
Switch and Bolt Travel Information. . . . . . . . . . . . . . . . . 39
Titan™ PivotBolt™ Case Dimensions. . . . . . . . . . . . . . . . . . 40
Mechanical Safe Locks
Mechanical Safe Lock Features Chart . . . . . . . . . . . . . . . . 20
Group 2 Mechanical Safe Locks. . . . . . . . . . . . . . . . . . . . . 21
Group 2M Mechanical Safe Locks. . . . . . . . . . . . . . . . . . . . 22
Dials and Rings for Group 2 and Group 2M Locks. . . . . . . . 23
Group 1 and Group 1R Mechanical Safe Locks. . . . . . . . . . 24
Group 1 Model 2937 Mechanical Safe Lock . . . . . . . . . . . . 25
Parts and Accessories for Mechanical Safe Locks. . . . . . . 26
Time Locks and Time Movements. . . . . . . . . . . . . . . . . . . . . . . 27
Mechanical Vault Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Key-Op® Key Operated Safe Locks. . . . . . . . . . . . . . . . . . . . . . 29
Titan™ D-Drive™ Case Dimensions. . . . . . . . . . . . . . . . . . . 40
6550 Model Electronic Vault Lock Case Dimensions. . . . . . 41
Mechanical Lock Case Dimensions. . . . . . . . . . . . . . . . . . . 42
Mechanical Lock Bolt Variations. . . . . . . . . . . . . . . . . . . . . 43
Mechanical Vault Lock Case Dimensions . . . . . . . . . . . . . 44
Spacings and Depths for Safe Deposit Lock Keys. . . . . . . . 45
4200 and 4400 Series Safe Deposit Lock Dimensions. . . . 46
4100 Series Cabinet Lock Dimensions . . . . . . . . . . . . . . . . 47
4500 Series Safe Deposit Lock Dimensions . . . . . . . . . . . . 47
Warranty Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Safe Handle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6870 Model Key Operated Safe Lock. . . . . . . . . . . . . . . . . . . . . 30
Safe Deposit Locks
4200 and 4400 Series Safe Deposit Locks. . . . . . . . . . . . . 31
STANLEY, STANLEY in a notched rectangle, SARGENT AND GREENLEAF, S&G, Manipulation Proof MP, A-series, D-DRIVE, TITAN, PivotBolt, KEY-OP, THE BRUTE, ARM-A-DOR, and
SPY-PROOF are some of the trademarks of Stanley Black and Decker or its affiliates.
Windows is a trademark of Microsoft Corporation.
Dallas and iButton are trademarks of Dallas Semiconductor Corporation.
Zamak is a trademark of Horsehead Corp.
Delrin is a trademark of E.I. Dupont de Nemours and Company.
Medeco is a trademark of Medeco High Security Locks.
Corbin is a trademark of Corbin Russwin Inc.
Yale is a trademark of Yale Security Inc.
Diebold and Mosler are trademarks of Diebold, Incorporated.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 1
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
CHANGEABLE
TO DUAL USER
MODE
INCLUDED WITH
MULTIPLE USER
CONFIGURATION
✔
✔
S
RIE
0 SE
✔
✔
✔
ser
ies ™
630
✔
9 A-
✔
ser
ies ™
612
✔
8 A612
612
4S
MUL ERIES
IN
TI-U
SER
MOD
E
612
4 SE
R
DUA
I
L US ES IN
ER M
ODE
612
5 SE
MUL RIES
IN
TI-U
SER
MOD
E
612
5 SE
R
DUA
I
L US ES IN
ER M
ODE
612
6 SE
AUD RIES
IT L
OCK
612
7S
AUD ERIES
IT L
OCK
S
RIE
3 SE
612
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
Officer Code(s)
2
2
Administrator Code(s)
4
4
UL Listed Type 1
612
0 SE
RIE
S
Electronic Lock Features Chart
CEN B
VdS Class 2
A2P B/E
DNV 3492
Multiple User Mode
Dual User Mode
Manager/Employee
Mode
Management Reset
Code (MRC)
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
CHANGEABLE
TO DUAL USER
MODE
INCLUDED WITH
MULTIPLE USER
CONFIGURATION
✔
✔
✔
✔
✔
✔
✔
✔
Manager Code
1
Supervisor Code
User Codes
8
5
Total No. of Codes*
9
7
Time Delay Override
Code
Time Lock (7-Day
Repeating Schedule)
Penalty Lockout
Feature
Bolt Position Indicator
Compatible with
Biometric Keypad***
Locking Mechanism
1
(3 WHEN
DURESS IS
ENABLED)**
9**
✔
✔
✔
✔
3
3
1
6
6
8
1
7
2
(3 WHEN
DURESS IS
ENABLED)**
8
20
20
10
10
18
9
9**
9
29
29
16
16
20
ORDER DURESS
ORDER DURESS
ORDER DURESS
ORDER DURESS
ORDER DURESS
ORDER DURESS
ORDER DURESS
ORDER DURESS
MODULE 6102-090 MODULE 6102-090 MODULE 6102-090 MODULE 6102-090 MODULE 6102-090 MODULE 6102-090 MODULE 6102-090 MODULE 6102-090
Duress Capability
Time Delay
1
7
✔
✔
✔
✔
✔
✔
✔
✔
ORDER 6126-146 ORDER 6127-246
Programmer Code
Master Code
✔
✔
✔
✔
✔
✔
✔
✔
1-9 Min.
1-99 Min.
1-99 Min.
1-99 Min.
1-99 Min.
1-99 Min.
✔
✔
✔
✔
✔
1-99 Min.
1-99 Min.
1-99 Min.
1-99 Min.
✔
1-99 Min.
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
ORDER 6120-323 ORDER 6123-312 ORDER 6124-225 ORDER 6124-225 ORDER 6125-223 ORDER 6125-233 ORDER 6126-242 ORDER 6127-242 ORDER 6128-230 ORDER 6129-230
✔
✔
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
* Includes only codes that can be used to open the lock, but does not include special-purpose time delay override code(s) that may be available. Codes used only for programming and/or audit trail
management are not included in this number.
** If time delay override is not enabled, an additional user code is available, bringing the maximum number of user codes to 9 (8 codes are available if time delay override is enabled), with 3 of these
available when the duress function is enabled.
Page 2
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
TITA
N™
MUL PIVOT
TI-U
B
SER OLT ™ I
MOD N
E
TITA
N™
DUA PIVOT
L US
B
ER M OLT ™ I
ODE N
TITA
N™
MUL D-Dri
TI-U ve ™
IN
SER
MOD
E
TITA
N™
D
DUA
L US Drive ™
ER M IN
ODE
Electronic Lock Features Chart
UL Listed Type 1
CEN B
VdS Class 2
A2P B/E
DNV 3492
Multiple User Mode
Dual User Mode
TITAN™ D-DRIVE™ ELECTRONIC LOCK
Manager/Employee
Mode
Management Reset
Code (MRC)
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
Programmer Code
✔
✔
✔
✔
Supervisor Code
1
1
1
1
User Codes
7
7
7
7
Master Code
Officer Code(s)
Administrator Code(s)
Manager Code
TITAN™ PIVOTBOLT™ ELECTRONIC LOCK
Total No. of Codes*
Duress Capability
Time Delay
Time Delay Override
Code
Time Lock (7-Day
Repeating Schedule)
Penalty Lockout
Feature
Bolt Position Indicator
9
**
9
9
**
9
ORDER DURESS
ORDER DURESS
ORDER DURESS
ORDER DURESS
MODULE 6102-090 MODULE 6102-090 MODULE 6102-090 MODULE 6102-090
1-99 Min.
1-99 Min.
1-99 Min.
1-99 Min.
✔
✔
✔
✔
✔
✔
✔
✔
ORDER BPI KIT
2006-201
ORDER BPI KIT
2006-201
ORDER BPI KIT
2006-201
ORDER BPI KIT
2006-201
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
MOTOR DRIVE
Compatible with
Biometric Keypad
Locking Mechanism
* Includes only codes that can be used to open the lock, but does not include special-purpose time delay override code(s) that may be available. Codes used only for programming are not
included in this number.
** If time delay override is not enabled, an additional user code is available, bringing the maximum number of user codes to 9 (8 codes are available if time delay override is enabled), with 3 of
these available when the duress function is enabled.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 3
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
6120 Series Motorized Electronic Safe Lock
NON-DEADLOCK
ING
SPRING BOLT
TYPE 1
EY
IC K PAD
RE A D Y
BIOMETR
DEADLOCKING
SQUARE BOLT
• Underwriters Laboratories Listed Type 1, and RoHS (Reduction of Hazardous Substances) compliant.
• A motor-driven lock bolt offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Management reset code, one master code, and eight user codes.
• Management reset code (MRC) restores the lock to its original factory code if the master code is lost.
• Time delay up to 9 minutes.
• The 6120 Series incorporates a penalty time feature to prevent opening by entering sequential or random codes until a valid code is found.
• All programming is quickly and easily done via the keypad (no separate programming equipment required).
• The deadlocking square bolt model withstands 225 lbs. (1000 newtons) of bolt end pressure for a high level of security and durability in
boltwork blocking applications.
• Non-deadlocking spring bolt model is designed for lightweight and inner compartment doors that require the lock to latch and secure the door.
• Can be used with the Biometric Keypad, 2-battery keypad, standard 1-battery keypad, and the non-rotating low profile keypad.
Lock Bodies (only)
Square Bolt—Order Number
6120-309
6120-308
Latch Bolt—Order Number
6120-502
6120-504
Management Reset Code
field settable
factory set
Keypad
order separately below
order separately below
Keypads (only)
Two-Battery Keypads
6120-010
6120-012
6120-014
6120-016
6120-045
6120-046
Bezel Finish
buffed brass
buffed chrome
matte black
satin chrome
24k gold
14k gold
One-Battery Keypads
6120-210
6120-211
Bezel Finish
buffed chrome
satin chrome
buffed brass
24 karat gold
Bezel Finish
buffed chrome
buffed brass
Non-Rotating Low Profile Keypads
6130-400
Locks with Keypads
Order Number
6120-301
6120-302
6120-303
6120-305
6120-329
6120-330
6120-508
Biometric Keypads
6120-410
6120-411
6120-412
6120-413
Lock Type
square bolt
square bolt
square bolt
square bolt
square bolt
square bolt
spring bolt
Keypad
2-battery buffed brass
2-battery buffed chrome
2-battery matte black
2-battery satin chrome
1-battery chrome
1-battery brass
2-battery satin chrome
Page 4
Bezel Finish
buffed chrome
Notes
batteries not included
batteries not included
batteries not included
includes (2) 9-volt batteries
includes (1) 9-volt battery
includes (1) 9-volt battery
batteries not included
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
DEADLOCKING
SQUARE BOLT
EY
IC K PAD
NON-DEADLOCKING
SPRING BOLT
TYPE 1
RE A D Y
BIOMETR
6123 Series Motorized Electronic Safe Lock
• Underwriters Laboratories Listed Type 1, and RoHS (Reduction of Hazardous Substances) compliant.
• A motor-driven lock bolt offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Management reset code, one master code, one supervisor code, five user codes, and one time delay override code.
• Management reset code (MRC) restores the lock to its original factory code if the master code is lost.
• Time delay up to ninety-nine minutes, and three modes of operation (single control, dual control, and manager/employee mode).
• The 6123 Series incorporates a penalty time feature to prevent opening by entering sequential or random codes until a valid code is found.
• All programming is quickly and easily done via the keypad (no separate programming equipment required).
• T he deadlocking square bolt model withstands 225 lbs. (1000 newtons) of bolt end pressure for secure locking in boltwork blocking applications.
• Non-deadlocking spring bolt model is designed for lightweight and inner compartment doors that require the lock to latch and secure the door.
• Can be used with the Biometric Keypad, 2-battery keypad, standard 1-battery keypad, and the non-rotating low profile keypad.
Lock Bodies (only)
Square Bolt
Order Number
6123-301
6123-310
Latch Bolt
Order Number
6123-501
Management Reset
Code
field settable
factory set
Keypad
none (lock only)
none (lock only)
Keypads (only)
Two-Battery Keypads
6120-010
6120-012
6120-014
6120-016
6120-045
6120-046
Bezel Finish
buffed brass
buffed chrome
matte black
satin chrome
24k gold
14k gold
Biometric Keypads
6120-410
6120-411
6120-412
6120-413
Bezel Finish
buffed chrome
satin chrome
buffed brass
24 karat gold
One-Battery Keypads
6120-210
6120-211
Bezel Finish
buffed chrome
buffed brass
Non-Rotating Low Profile Keypads
6130-400
Bezel Finish
buffed chrome
Locks with Keypads
Order Number
6123-303
6123-304
6123-307
6123-505
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Lock Type
square bolt
square bolt
square bolt
spring bolt
Keypad
2-battery satin chrome
2-battery buffed chrome
2-battery matte black
2-battery satin chrome
Page 5
Notes
batteries not included
batteries not included
batteries not included
batteries not included
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
6124 and 6125 Series Motorized Electronic Safe Locks
TYPE 1
CLASS 2
B
A/B
• Underwriters Laboratories Listed Type 1, CEN B, VdS Class 2, A2P B/E, DNV 3492, and RoHS compliant.
• Both locks feature a motor-driven lock bolt which offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• The multiple user mode provides for a management reset code. The dual user mode does not provide for a management reset code.
• Both models offer one master code, one supervisor code, seven user codes, and one time delay override code.*
• Multiple user mode—Any of the lock’s codes can be used to open. Multiple user can also be switched to Manager/Employee mode, in which the
master and supervisor codes toggle the lock on and off for operation by the holders of user codes.
• Dual user mode—The standard multiple user lock can be permanently switched to dual user mode at setup, before the master code is changed
for the first time. Then the lock can only be opened if two separate codes are entered within one minute of each other. This provides a higher
level of access control.
• A penalty time feature to is provided to prevent opening by entering sequential or random codes until a valid code is found.
• A delay up to 99 minutes can be easily set, and provides for one time delay override code for cash carrier applications.
• The lock offers a duress capability, allowing a distress signal to be sent through the customer’s central alarm system in the event of an emergency. An optional duress module (part #6102-090) is required to use this function.
• The 6124 Series is designed for boltwork blocking applications that do not require direct attachment of the lock bolt to the safe’s boltwork.
• The 6125 Series is made for direct boltwork attachment and will push and pull 2.24 lbs. (10 newtons)—maximum load 5.6 lbs. (25 newtons).
• Some models are equipped with a bolt position indicator that closes a circuit when the lock bolt is in either the locked or unlocked position (see
part number table below).
* If a multiple user lock has the duress feature enabled, User PINs 4 through 8 are automatically disabled and are not available. A dual user lock always has all codes available for
use. In both models, the time delay override code uses PIN 9. If time delay override is disabled, PIN 9 functions like a standard user code.
Lock Bodies (only)
6124
6125
Management
Configuration
Order
Order
Reset Code
Number
Number
6124-143 6125-138 multiple user
yes2
6124-238 6125-237 multiple user
yes2
Time
Delay
1-99 min
1-99 min
Time
Delay
Override
yes
yes
Bolt
Position Duress
Indicator
no
yes1
yes
yes1
Duress requires an optional duress module (part #6102-090).
If the lock is switched to dual user mode, the Management Reset Code is not available.
1
2
These locks come with both M6 and ¼-20 mounting screws.
Keypads (only)
Two-Battery
Keypads
61KP-105
61KP-202
Bezel Finish
Tamper Indicating
Notes
satin chrome
satin chrome
no
yes
maintains U.L. Listing
maintains all ratings
Page 6
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
6126 and 6127 Series Motorized Audit Lock
TYPE 1
CLASS 2
B
A/B
• Underwriters Laboratories Listed Type 1, CEN B, VdS Class 2, A2P B/E, DNV 3492, and RoHS compliant.
• Both models feature a motor-driven lock bolt which offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Up to thirty users—Both models offer one programmer code, three manager codes, six supervisor codes, and twenty user codes.
• Multiple User, Dual Control, and Manager/Employee modes selectable and changeable at any time.
• 400-event, time and date stamped audit trail managed by easy-to-use PC-based software. To download audit trail data from the lock, you will
need the optional audit trail software kit (part #6103-130 or 6103-131).
• Both models incorporate a penalty time feature to prevent opening by entering sequential or random codes until a valid code is found.
• Both models offer time delay up to 99 minutes.
• Both models offer a duress capability, allowing a distress signal to be sent through the customer’s central alarm system in the event of an
emergency. An optional duress module (part #6102-090) is required to use this function.
• The 6126 Audit Lock is designed for boltwork blocking applications that do not require direct attachment of the lock bolt to the safe’s boltwork.
• The 6127 Audit Lock is designed for direct boltwork attachment and will push and pull 2.24 lbs. (10 newtons), with a maximum load of 5.6 lbs.
(25 newtons).
• Some models are equipped with a bolt position indicator that closes a circuit when the lock bolt is in either the locked or unlocked position (see
part number table below).
Locks and Lock Kits
6126 Audit Lock
Order Number
6126-142
6126-242
6126-146
6126-246
SERIAL ADAPTER/CABLE
USB ADAPTER/CABLE
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
6127 Audit Lock
Order Number
6127-242
6127-146
6127-246
Keypad
yes
yes
yes
yes
Keypad Extension
Included
yes
yes
yes
yes
Bolt Position Indicator
Included
no
yes
no
yes
Management
Reset Code
no
no
yes
yes
SG Audit Software runs on Windows® XP, Windows® 7, Windows® Server 2008, and Windows® Vista
operating systems. It includes a cable with a Dallas® key reader and a Dallas® iButton® for transferring
the audit information from the lock to your computer. Check your computer to see whether you will need
the serial adapter or USB adapter. The appropriate driver software is included with each type of adapter.
The keypad extension base and audit trail software kit are both needed to download, view, and manage
time and date-stamped audit information captured by a 6126, 6127, 6128, or 6129 lock.
6103-130—Audit trail software on CD, serial adapter with cable, and Dallas® iButton®.
6103-131—Audit trail software on CD, USB adapter with cable, and Dallas® iButton®.
6103-102—Key reader with USB adapter with cable only.
6104-006—Extra Dallas® iButton® (red fob).
6102-025—Alarm interface module for 6126, 6127, 6128, and 6129.
Page 7
ALARM INTERFACE MODULE
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
6128 and 6129 A-series™ ATM Locks
TYPE 1
CLASS 2
B
• Underwriters Laboratories Listed Type 1, VdS Class 2, CEN B, A2P B/E, and RoHS compliant.
• Both models feature a motor-driven lock bolt which offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Up to sixteen users in Bank Mode—One programmer code, two officer codes, four administrator codes, and ten user codes.
• Dual Control and Manager/Employee modes selectable and changeable at any time by entering a special keypad command.
• 400-event, time and date stamped audit trail managed by easy-to-use PC-based software. To read audit trail information, you will need the optional
audit trail software kit (part #6103-120). Time, date, and event duration information is generated and stored in the lock so that it is not susceptible to time drift.
• Snap-in touch key reader allows fast, accurate transfer of audit trail data.
• Both models incorporate a penalty time feature to prevent opening by entering sequential or random codes until a valid code is found.
• Both models offer time delay of one to ninety-nine minutes.
• Both models offer a duress capability, allowing a distress signal to be sent through the customer’s central alarm system in the event of an
emergency. A duress module (part #6102-090) or alarm interface module (part #6102-025) is required to use this function.
• The 6128 A-series™ Lock is made for boltwork blocking applications that do not require direct attachment of the lock bolt to the safe’s boltwork.
• The 6129 A-series™ Lock is designed for direct boltwork attachment and will push and pull 2.24 lbs. (10 newtons), with a maximum load of 5.6
lbs. (25 newtons).
• All models are equipped with a bolt position indicator that closes a circuit when the lock bolt is in either the locked or unlocked position.
• Both models can be opened via Dallas® iButton® keys in conjunction with one time codes (OTC) when service mode is enabled. Contact a
Sargent & Greenleaf sales representative (800 826-7652) for information about service mode and LMS software.
Lock Kits—lock, keypad, keypad extension, serial number plate
6128 A-series™
Order Number
6128-240
SERIAL ADAPTER/CABLE
USB ADAPTER/CABLE
6129 A-series™
Order Number
6129-240
Non-Tamper
Keypad Extension
Keypad
yes
yes
Bolt Position Indicator
Reset Code
yes
no
SG Audit Software runs on Windows® XP, Windows® 7, Windows® Server 2008, and Windows® Vista
operating systems. It includes a cable with a Dallas® key reader and a Dallas® iButton® for transferring
the audit information from the lock to your computer. Check your computer to see whether you will need
the serial adapter or USB adapter. The appropriate driver software is included with each type of adapter.
The keypad extension base and audit trail software kit are both needed to download, view, and manage
time and date-stamped audit information captured by a 6126, 6127, 6128, or 6129 lock.
6103-130—Audit trail software on CD, serial adapter with cable, and Dallas® iButton®.
6103-131—Audit trail software on CD, USB adapter with cable, and Dallas® iButton®.
6103-102—Key reader with USB adapter with cable only.
6104-006—Extra Dallas® iButton® (red fob).
6102-025—Alarm interface module for 6126, 6127, 6128, and 6129.
6128-500—A-seal box with 9-volt battery.
Page 8
©2012
A-seal BOX
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
6300 Series Multiple Compartment Electronic Safe Lock
• Three different field-settable modes of operation—multiple user, dual
control, and manager/employee mode.
• Many features are programmable from the keypad. Access more features
and make programming easier with the 6350-001 software kit.
• Keypad LCD displays text in English or Spanish.
• One programmer code, two supervisor codes, eighteen user codes.
• Select six, seven, or eight-digit code format for up to 100,000,000 different code possibilities.
• Time delay from 1 to 99 minutes.
• Assign time delay override authority to any code holder(s).
• Full function seven-day repeating time lock schedule with up to 27 special holiday overrides.
• Make any user subject to dual control with another code holder or make any user present a registered touch key to the keypad when entering a
code to operate the lock.
• Penalty lockout feature to prevent opening by entering sequential or random codes until a valid code is found.
• Duress capability is standard and built into the control unit.
• Keypad and control unit operate one or two locks independently.
• Bolt position indicator available by special request.
• 500-event time and date stamped audit trail managed by easy-to-use PC-based software (purchase separately), or view audit events on the
LCD keypad.
• Remote enable connections are built into the control unit.
• Powered by an AC plug-in transformer, with battery backup capability built in.
6300 Components
Order Number
6352-004
6160-101
6354-005
6350-001
Components
keypad and control unit
120-volt power supply
square bolt lock
software kit
Description
2-line LCD keypad and 6300 control unit
plug-in transformer for 120-volt AC mains
lock body with attached cable
lock programming and audit trail management software/hardware
SERIAL ADAPTER/CABLE
6350-001—Software kit with included touch keys
and serial interface reader/cable.
6103-102—USB adapter with cable only.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 9
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Titan™ PivotBolt™ Safe Lock
TYPE 1
CLASS 2
B
B
• Underwriters Laboratories Listed Type 1, VdS Class 2, CEN B, A2P B, DNV, and RoHS (Reduction of Hazardous Substances) compliant.
• The Titan™ PivotBolt™ lock features a new design, motor driven locking mechanism for an extra measure of security and longer battery life.
• Lock bolt retraction and extension is controlled by the movement of the safe’s boltwork.
• The Titan™ PivotBolt™ automatically locks to re-secure the safe whenever the container’s boltwork moves to the fully closed position, discouraging
the common (non-secure) practice of day-locking.
• The Titan™ PivotBolt™ is connected to the keypad only by cable, which means the lock does not need to be placed directly behind the keypad. It can
be located anywhere on the inside of the safe door.
• All PivotBolt models use the standard S&G Magic Module footprint, allowing for easy retrofit without the need for boltwork or mounting screw location changes. Plus, it’s universally handed and reversible for RH, LH, VU, and VD mounting.
• Three modes of operation: Multi-User, Manager/Employee, Dual Control.
•M
anagement reset code, one master code, one supervisor code, eight user codes, and one time delay override code*. The management reset code
(MRC) lets you set a new master code of your own choosing if the old master code is lost or forgotten.
• The Titan™ PivotBolt™ has a penalty time feature to prevent opening by entering sequential or random codes until a valid code is found.
• All programming is quickly and easily done via the keypad (no separate programming equipment required).
• The lock bolt model withstands 225 lbs. (1000 newtons) of bolt end pressure for a high level of security in boltwork blocking applications.
• Can be used with the S&G 2-battery keypad, standard 1-battery keypad, or the non-rotating low profile keypad.
* W hen a time delay override code is set, the number of available user codes is seven. If the lock is set to multiple user mode and duress is turned on, only User
Codes 2 and 3 are available. User Codes 4 – 8 are disabled. User Code 9 will be available to use if time delay override is not enabled. Loss of User Codes when
duress is enabled is required to meet EN1300 specifications for this product. If the lock is set to dual user mode, all codes always remain available.
Part Number
2006-100
2006-102
Description
Titan PivotBolt lock body with cable (no keypad)
Titan™ PivotBolt™ lock, cable, and a 6130-400 keypad
™
™
2006-201—Bolt Position Indicator (BPI)
This optional accessory consists of a special single pole, double throw switch designed to fit
into an existing cavity under the Titan’s removable front cover. The color-coded leads are already
connected. Now your lock can trigger alarms, CCTV recorders, or virtually any relay activated device.
Keypads (only)
One-Battery
Keypads
6120-210
6120-211
Non-Rotating Low
Profile Keypads
6130-400
Two-Battery Keypads
6120-010
6120-012
6120-014
6120-016
6120-045
6120-046
Bezel Finish
buffed chrome
buffed brass
Bezel Finish
buffed chrome
Page 10
Bezel Finish
buffed brass
buffed chrome
matte black
satin chrome
24k gold
14k gold
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Titan™ D-Drive™ Safe Lock
SIMPLIFIED NON-SOLENOID BLOCKING
DESIGN FOR HIGH DEPENDABILITY
TYPE 1
CLASS 2
B
B/E
• Underwriters Laboratories Listed Type 1, VdS Class 2, CEN B, A2P B, DNV, and RoHS (Reduction of Hazardous Substances) compliant.
• The Titan™ D-Drive™ lock features a new design, motor driven locking mechanism for an extra measure of security and longer battery life.
• Lock bolt retraction and extension is controlled by turning of the keypad, offering dependable manual control of the locking bolt. And the sure-grip,
low profile keypad gives a good, solid feel for the action of the lock.
• The Titan™ D-Drive™ uses an exclusive, no-twist cable design that virtually eliminates the risk of cable damage due to keypad rotation. The cable is
located in a recessed channel in the lock’s extruded aluminum spindle, safely out of harm’s way.
• The Titan™ D-Drive™ uses the standard S&G Magic Module footprint, allowing for easy retrofit without the need for boltwork or mounting screw
location changes. Plus, it’s universally handed for RH, LH, VU, and VD mounting.
• Three modes of operation:
Multi-User—The Master Code, Supervisor Code, and any User Code can open the lock with a single code.
Manager/Employee—Code holders can access the safe only when it’s been enabled by a Master Code or Supervisor Code holder.
Dual Control—Multi-User mode is the factory default, but Dual Control is keypad selectable as an alternate, permanent mode of operation.
Two different lock codes must be entered within one minute of each other to open the safe. This provides a higher level of security.
•M
anagement reset code, one master code, one supervisor code, eight user codes, and one time delay override code*. The management reset code
(MRC) lets you set a new master code of your own choosing if the old master code is lost or forgotten.
• The Titan™ D-Drive™ has a penalty time feature to prevent opening by entering sequential or random codes until a valid code is found.
• All programming is quickly and easily done via the keypad (no separate programming equipment required).
• The lock bolt model withstands 225 lbs. (1000 newtons) of bolt end pressure for a high level of security in boltwork blocking applications.
• An easy to install bolt position sensor switch can be added to trigger alarms, CCTV recorders, or virtually any relay activated security device.
* W hen a time delay override code is set, the number of available user codes is seven. If the lock is set to multiple user mode and duress is turned on, only User Codes 2 and 3 are available. User Codes 4 – 8 are disabled. User Code 9 will
be available to use if time delay override is not enabled. Loss of User Codes when duress is enabled is required to meet EN1300 specifications for this product. If the lock is set to dual user mode, all codes always remain available.
Part Number
2007-100
2007-102
2004-500
6130-200
Description
Titan D-Drive lock body with cable (no keypad or spindle)
Titan™ D-Drive™ lock, cable, spindle, keypad
Aluminum spindle only—8 inches (20.3 cm)
Rotating keypad only
™
™
2006-201—Bolt Position Indicator (BPI)
This optional accessory consists of a special single pole, double throw switch designed to fit into an existing cavity
under the Titan’s removable front cover. The color-coded leads are already connected. Now your lock can trigger alarms,
CCTV recorders, or virtually any relay activated device.
2004-700—Add extra boltwork attachment points to any Titan™ D-Drive™ lock with “wings.” Ideal for lightweight safes
without bolt control handles. Pushes and pulls 2.5 lbs. (11.12 Newtons). Part number 2004-700 is for a pair of wings.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 11
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Electronic Vault Lock
Bringing the security and
convenience of electronic
locks to vault applications
• Same mounting footprint as the S&G® 6400 and 6500 series mechanical vault locks for quick, easy retrofit in most applications. Replaces both
direct and indirect drive units.
• Automatically locks when the safe or vault door is closed and the boltwork is thrown.
• Powered by a model 6127 push/pull Audit Lock that is Underwriters Laboratories Listed Type 1, VdS Class 2, CEN B, A2P B/E, DNV 3492, and
RoHS compliant.
• Heavy duty motor-driven lock bolt offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Up to thirty users—one programmer code, three manager codes, six supervisor codes, and twenty user codes.
• Multiple User, Dual Control, and Manager/Employee modes selectable and changeable at any time via the keypad.
• 4 00-event, time and date stamped audit trail managed by easy-to-use PC-based software. To read audit trail information, you will need the
optional audit trail software kit (part #6103-130 or 6103-131).
• Snap-in touch key reader allows fast, accurate transfer of audit trail data.
• Penalty time feature prevents opening by entering sequential or random codes until a valid code is found.
• Time delay up to 99 minutes.
• Duress capability allows a distress signal to be sent through the customer’s central alarm system in the event of an emergency. An optional
duress module (part #6102-090) is required to use this function.
• Built in bolt position indicator closes a circuit when the lock bolt is in either the locked or unlocked position (see part number table below) to
trigger any relay-activated device.
• Recommended only for applications that include a secondary lock override or separate service door.
Electronic Vault Locks
Order Number
6550-112
6550-113
Description
roller bolt electronic vault lock with two-battery keypad and keypad extension (for reading audit trail)
square bolt electronic vault lock with two-battery keypad and keypad extension (for reading audit trail)
Page 12
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
EY
IC K PAD
RE A D Y
BIOMETR
6140 Series Electronic Door Lock
• Same mounting footprint and strikes as the mechanical S&G® Extension 50 automatic door lock.
• Powered by a model 6123 UL Listed Type 1 electronic safe lock.
• One master code, one supervisor code, five user codes, one time delay override code, three different operating modes (multiple user, dual user,
manager/employee mode)
• Motor-driven lock design offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Penalty time feature prevents opening by entering sequential or random codes until a valid code is found.
• Door locks automatically whenever it closes—automatic security for secure rooms and restricted areas.
• Inside release knob is always active for normal or emergency exit.
• Time delay—up to 99 minutes.
• All 6140 models are 100% compatible with the S&G® Biometric Keypad—add the security and convenience of fingerprint recognition technology to your 6140 door lock (purchase separately). The standard two-battery keypad 61KP-105 is also recommended for use with the 6140 door
lock. See keypad information on the following page.
• Three different heavy duty strikes are available to suit virtually all door and frame applications.
• Some models are equipped with a bolt position indicator that provides connections for both normally open and normally closed circuits. This
feature can be used to activate video recording equipment or any relay-activated device whenever the lock is opened from either the inside or
the outside. Switch rating is 200 VDC @ 0.5 amp.
6140 Door Lock
Order Number
6140-003
6140-004
Included Strike(s)
#1 and #3 for in-swing doors
#2 for out-swing doors
KEYPAD
LOCK BODY
#1 STRIKE
IN-SWING DOOR
LOCK BODY
IN-SWING DOOR
FRAME
KEYPAD
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
#3 STRIKE
FRAME
KEYPAD
Page 13
OUT-SWING DOOR
LOCK BODY
FRAME
#2 STRIKE
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Electronic Lock Keypads
The Biometric Keypad uses advanced fingerprint recognition technology to add extra security and convenience to any 6120, 6123, or 6140 door lock. Install it with a new lock, or use it as an easy retrofit upgrade
to an existing lock. It can be set to open a lock with fingerprint or code, or require both.
Part #6120-410 Buffed chrome finish
Part #6120-411 Satin chrome finish
Part #6120-412 Buffed brass finish
Part #6120-413 24 karat gold finish
The Time Lock Keypad adds the security and convenience of a fully programmable seven-day repeating
schedule time lock to 6124, 6125, 6126, 6127, and Titan™ PivotBolt™ electronic locks. The easy to read
LCD screen displays in English, Spanish, Portuguese, German, or Italian. Set one or two time lock periods
per day, with up to twenty special holidays and up to fifteen vacation periods that will override the repeating time lock schedule when needed. Automatic adjustment for Daylight Savings Time once the beginning
and ending dates have been set.
Part #6120-420 Satin chrome finish
The standard two-battery keypad can be used with lock models 6120, 6123,
Titan™ PivotBolt™, and the 6140 door lock.
Part #6120-010 Buffed brass finish
Part #6120-012 Buffed chrome finish
Part # 6120-014 Matte black finish
Part # 6120-045 24 karat gold finish
Part # 6120-046 14 karat gold finish
Part # 6120-016 Satin chrome finish
The 61KP-105 two-battery keypad is generally used with 6124, 6125, 6126, 6127, 6128, and 6129 locks. It
can also be used with 6120, 6123, Titan™ PivotBolt™, and the 6140 door lock.
The 61KP-201 is a tamper indicating keypad that is used exclusively with lock models 6124 and 6125 to
meet German VdS specifications. The 61KP-105 should be used for non-VdS applications.
Part #61KP-105 Satin chrome finish
Part #61KP-202 Satin chrome finish
Page 14
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
The one-battery keypad is ideal for use with 6120, 6123, and Titan™ PivotBolt™ locks. The battery is
kept in an easy-to-access battery compartment at the bottom of the keypad. The one-battery keypad is
designed to let you change the battery quickly and easily.
Part #6120-210 Buffed chrome trim ring
Part #6120-211 Buffed brass trim ring
The low profile keypad is only 1" high (25.4 mm) and designed for use with 6120, 6123, and Titan™
PivotBolt™ locks. The battery is kept in an easy-to-access battery compartment near the top of the
keypad. The one-battery keypad is designed to protect the lock cable from possible user damage after
installation. It is also smaller in diameter (3 ¾" or 95.2 mm) than other S&G® keypads for applications
where mounting space is limited.
Part #6130-400 Buffed chrome trim ring
The D-Drive™ rotating keypad is used only with Titan™ D-Drive™ safe locks. The blue button at the top of
the keypad indicates that it is for D-Drive™ applications. This small diameter (3 ¾" or 95.2 mm), rotating
keypad is only 1" (25.4 mm) high, and will fit most safes, even when mounting space is limited.
Part #6130-200 Buffed chrome trim ring
6130-100—The Spy-Proof® cover makes it difficult for anyone to see which buttons are
pressed as a code is entered. It’s easily added to any standard two-battery keypad (not for
use with one-battery keypads or the Biometric Keypad). It does not interfere with keypad
removal for battery replacement. Keypad not included.
6130-600—This Spy-Proof® cover is specially made to work with the D-Drive™ keypad used with S&G
Titan™ locks. It does not interfere with battery replacement. Keypad not included.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 15
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Electronic Safe Lock Accessories
SERIAL ADAPTER/CABLE
6350-001—6300 software kit with included data keys and serial interface reader/cable. Windows 95,
Windows 98, Windows ME, Windows 2000 and Windows XP-based application for programming
the 6300 multiple compartment safe lock and for reading, printing, and archiving audit trail
information.
6215-001—Time delay indicator mirrors the time delay period of a 6120 or 6123 lock, and can be remotely located.
Displays time delay and opening window. Built-in sounder echoes the time delay beeps emitted by the lock.
6120-060—Cables and junction box needed to hook up the 6215-001.
6120-050—20 cm (7.87) long cable extension.
6120-057—60 cm (23.62) long cable extension.
Both kits include wire ties and heat-shrink to provide secure, trouble free connections. Not for D-Drive™ locks.
6120-064—Control two locks with a single keypad, based on microswitch activation. Kit includes cable
assembly, attached microswitch, heat-shrink, wire ties, and tie blocks.
Not for D-Drive™ models.
7700-021—Magnetic self-stick Safe Light is designed to illuminate the keypad of your electronic lock when there just isn’t
enough ambient light to see the numbers easily. A quick press of the button gives you two minutes of red light right where
you need it. After two minutes, it shuts of automatically to increase battery life. This model extends out from the front of
the safe to accommodate electronic lock keypads. Display packaged, one per pack.
7700-020—This Safe Light model is the same as the 7700-021, but does not extend as far from the front of
the safe. It’s perfect for illuminating the dials of mechanical locks. Display packaged, one per pack.
7700-025—The Safe Light counter display is a self-merchandiser for retailers.
The display does NOT include Safe Lights.
Page 16
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Electronic Safe Lock Accessories
2006-201—Titan™ bolt position indicator (BPI), a special single pole, double throw switch designed to fit into an existing
cavity under the Titan’s removable front cover. The color-coded leads are already connected. Now your lock can trigger alarms,
CCTV recorders, or virtually any relay activated device. Lock not included.
2004-700—Add extra boltwork attachment points to any Titan™ D-Drive™ lock with “wings.” Ideal for lightweight safes without
bolt control handles. Pushes and pulls 2.5 lbs. (11.12 Newtons). Part number 2004-700 is for a pair of wings.
6102-090—Closes or opens an alarm circuit when the lock’s code is entered one number higher on the last code digit.
Requires connection to an existing alarm system. Use with a properly configured 6124, 6125, 6126, 6127, Titan™ PivotBolt™,
or Titan™ D-Drive™ lock.
6102-100—The same duress feature as the 6102-090 and remote enable. A 5 to 12 VDC input from any source will either
enable or disable the lock, depending on how you set the selector switch. The enable/disable portion of the module works
with any S&G® electronic safe lock, with the exception of the Model 6300, which has its own built-in enable/disable feature.
The duress feature works with any properly configured 6124, 6125, 6126, 6127, Titan™ PivotBolt™, or Titan™ D-Drive™ lock.
6101-203—The keypad extension base incorporates a port that allows the downloading of audit information from the lock
to a Dallas® iButton®. It mounts underneath the keypad. For use with 6126, 6127, 6128, and 6129 locks.
SERIAL ADAPTER/CABLE
USB ADAPTER/CABLE
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SG Audit Software runs on Windows® XP, Windows® 7, Windows® Server 2008, and Windows® Vista
operating systems. It includes a cable with a Dallas® key reader and a Dallas® iButton® for transferring
the audit information from the lock to your computer. Check your computer to see whether you will need
the serial adapter or USB adapter. The appropriate driver software is included with each type of adapter.
The keypad extension base and audit trail software kit are both needed to download, view, and manage
time and date-stamped audit information captured by a 6126, 6127, 6128, or 6129 lock.
6103-130—Audit trail software on CD, serial adapter with cable, and Dallas® iButton®.
6103-131—Audit trail software on CD, USB adapter with cable, and Dallas® iButton®.
6103-102—Key reader with USB adapter with cable only.
ALARM INTERFACE MODULE
6104-006—Extra Dallas® iButton® (red fob).
6102-025—Alarm interface module for 6126, 6127, 6128, and 6129.
6128-500—A-seal box with 9-volt battery for 6128 and 6129 locks
when a "close seal" code is needed.
A-seal BOX
Page 17
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Model 2740 High-Security Electromechanical Safe Lock
Meets Federal Specification FF-L-2740A
f or combination locks designed to be mounted on safes,
security files, vault doors, and similar items; and intended for
the protection of national security information.
• Approved for installation on all classes of GSA-approved security containers.
• Powered by a readily-available, long-life CR123A camera-type battery, with a CR2450 backup battery.
• Built in low battery indicator gives 100 obvious low battery warnings before the backup battery engages.
• Battery life has been tested in excess of 20,000 openings and closings.
• New design motor-driven lock mechanism offers a high level of security by eliminating the threat of vibration and bouncing attacks.
• Penalty Time feature prevents opening by entering sequential or random combinations until a valid combination is found.
• Familiar left-right-left dialing sequence is natural for those users who are already accustomed to using mechanical locks.
• No hard-to-read LCDs or confusing display icons or symbols to interpret.
• Single control and dual control modes.
• Built in relock trigger and thermal relock component for resistance to forced and covert entry attempts.
• Stainless steel lock bolt resists 600 lbs of end and side load.
• Bolt retracts flush with the end of the lock case and travels .461 inch, eliminating the need for an optional short bolt for Mosler retrofits.
• Bolt is drilled and tapped to accept most bolt extensions used in GSA containers.
• Simplified installation makes this the fastest, easiest to install lock in its category. A single brass spindle connects the dial to the lock. No
tubes to cut and deburr, and no delicate cables to contend with.
• Uses S&G’s “Magic Module” footprint, the standard of the industry, for ease of retrofit.
• Lock cover is retained unless the lock bolt is extended, eliminating the possibility of the safe or vault door being closed while the cover is
removed from the lock.
Part Number
2740-100
2740-102
2740-200
2740-103
2740-104
2740-105
2740-106
2740-107
2740-108
Description
2740 lock, dial, ring, dust cover, change key (no setup module)
2740 lock body and change key only (no dial, ring, or dust cover)
2740 setup module with cable and 9-volt battery
2740 Spy-Proof dust cover with (2) attaching screws
Spy-Proof dust cover retaining screws (package of 12 screws only)
2740 change key
2740 dial/spindle assembly (maximum 3.875 inch door thickness)
2740 stainless steel spline key with attaching screw (package of 5)
2740 dial ring with attaching screws
You’ll find numerous
2740 resources on
the web
2740 Setup Module (product no. 2740-200)
• A setup module is needed to calibrate the lock’s dial ring following installation.
• Setup module functions include: battery check, set single control mode, set dual control mode,
recover from lost combination, reset lock open latch condition, and dial calibration functions.
• Powered by its own 9-volt alkaline battery.
• Easily plugs into the lock’s change key port.
Page 18
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Model 2890 PDL Pedestrian Door Lock
Built to the Requirements of
Federal Specification FF-L-2890
• Surface mounted, automatic door deadbolt with pinch-proof strike for protection of SCIFs (Sensitive Compartmented Information Facilities) and
other areas where sensitive information and activities need to be protected.
• Incorporates an FF-L-2740A approved S&G model 2740 combination lock for maximum security and ease of operation.
• Accommodates both left-hand and right-hand doors, and is available with four different strikes for in-swing and out-swing doors.
• Inside turn knob allows quick, easy exit from inside the protected area.
• Integral blocking knob (or included key cylinder) can be used to prevent locking of the 2890 PDL when the secure area is occupied.
Part Number
2890-100
2890-200
2890-201
2890-202
2890-203
2890-204
2890-300
2890-301
2890-302
2890-303
2890-304
2890-400
2740-300
Description
2890 PDL lock, dial, ring (no dial ring mounting plate, no strike*)
2890 PDL lock, dial, ring, ‘N’ dial ring monting plate (no strike*)
2890 PDL lock, dial, ring, ‘N’ dial ring mounting plate, #1 strike
2890 PDL lock, dial, ring, ‘N’ dial ring mounting plate, #2 strike
2890 PDL lock, dial, ring, ‘N’ dial ring mounting plate, #3 strike
2890 PDL lock, dial, ring, ‘N’ dial ring mounting plate, #9 strike
2890 PDL lock, dial, ring, ‘D’ dial ring monting plate (no strike*)
2890 PDL lock, dial, ring, ‘D’ dial ring mounting plate, #1 strike
2890 PDL lock, dial, ring, ‘D’ dial ring mounting plate, #2 strike
2890 PDL lock, dial, ring, ‘D’ dial ring mounting plate, #3 strike
2890 PDL lock, dial, ring, ‘D’ dial ring mounting plate, #9 strike
2890 PDL deadbolt lock (no 2740 lock, dial, ring, dial ring mounting plate, no strike)
2740 lock, dial, ring, with special 2890 PDL lock bolt installed (no 2890 PDL, no dial
ring mounting plate, no strike)
* Use the illustrations below to select the proper strike for your application and order by the product number under the appropriate illustration.
LOCK BODY
LOCK BODY
INSWING DOOR
FRAME
#1 STRIKE
PRODUCT NO. 8497-001
Want to see how it’s
installed? Here’s your link
to the installation video.
FRAME
#2 STRIKE
PRODUCT NO. 8497-002
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 19
FRAME
#3 STRIKE
PRODUCT NO. 8497-003
LOCK BODY
OUTSWING DOOR
LOCK BODY
INSWING DOOR
ACTIVE DOOR
INACTIVE
DOOR
#9 STRIKE
PRODUCT NO. 8497-004
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
✔
✔
✔
✔
CNPP A2P
Theoretical
Combinations
Typical Dialing
Tolerance*
ries
856
0 Se
ries
0 Se
✔
✔
A/E
DNV 3492
Number of Wheels
855
✔
✔
CEN B
✔
✔
✔
VdS Class 2
China CCC
✔
✔
UL Listed Group 1R
CEN A
ries
ries
✔
UL Listed Group 1
VdS Class 1
0 Se
✔
843
✔
841
✔
0 Se
ries
665
1 Se
ries
ries
1 Se
✔
663
✔
663
✔
UL Listed Group 2M
0 Se
ries
674
1 Se
ries
1 Se
673
UL Listed Group 2
673
0 Se
ries
Mechanical Safe Lock Features Chart
B
B
B/E
✔
✔
✔
✔
✔
3
4
3
3
4
3
3
3
3
3
1,000,000
100,000,000
1,000,000
1,000,000
100,000,000
1,000,000
1,000,000
1,000,000
1,000,000
1,000,000
± 0.5
± 0.5
± 1.0
± 0.5
± 0.5
± 1.0
± 0.5
± 0.5
± 0.5
± 0.5
* Typical dialing tolerance is what you would expect to experience in an installed lock. Theoretical dialing tolerance is always slightly greater (usually about ± 0.4 numbers greater).
Page 20
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Group 2 Mechanical Safe Locks
• 6730 Series: Underwriters Laboratories Listed Group 2, VdS Class 1, CEN A, China CCC.
• The 6730 Series is widely recognized as the standard Group 2 lock of the industry.
• 6731 Series: U.L. Listed Group 2, VdS Class 2, CEN B, China CCC, RoHS compliant.
• Three brass and aluminum wheels provide 1,000,000 theoretical combinations. The
four-wheel 6731 model offers 100,000,000 theoretical combinations.
• Made to outperform other locks in the most demanding commercial applications.
• Internal relock trigger secures the lock in the event of a burglar’s punch attack.
• 4-way drive cam for mounting right-hand, left-hand, vertical-up, or vertical-down.
• Accepts a wide variety of dials in several attractive finishes (see page 23).
• The 6738 models are switch locks, offering duress and lever position switches,
GROUP 2
depending on the model ordered.
Lock Bodies (only)
Locks, Dials & Rings
Order Number
6730-010
6731-004
Order Number
6730-100
6730-101
6730-102
6730-103
6730-112
6731-111
No. of Wheels
3
4
No. of Wheels
3
3
3
3
3
4
Lock, Dial and Ring
GROUP 2
©2012
A
Sargent and Greenleaf
Revision date: 9/19/2012
Order Number
6741-106
CLASS 1
A
Notes
standard lock bolt
standard bolt
Notes
standard bolt, D300/R211 front reading B&W dial and ring
standard bolt, D003/R004 front reading B&W dial and ring
standard bolt, D220 Spy-Proof® B&W dial and ring
standard bolt, D690 front reading, key locking B&W dial and ring
standard bolt, D225 Spy-Proof®, key locking B&W dial and ring
standard bolt, D225 Spy-Proof®, key locking B&W dial and ring
• 6741 Series: Underwriters Laboratories Listed Group 2, CEN A,
VdS Class 1, CNPP A2P A/E RoHS compliant.
• Three die cast Zamak and aluminum wheels provide 1,000,000 theoretical combinations.
• Die cast push-pull lever with wider dialing tolerances makes the lock easy to dial and less
sensitive to bolt side and end pressure than standard levers.
• Designed and constructed to provide a high level of security at a moderate cost.
• Internal relock trigger secures the lock in the event of a burglar’s punch attack.
• Four-way drive cam for mounting right-hand, left-hand, vertical-up, or vertical-down.
• Accepts a wide variety of dials in several attractive finishes (see page 23).
Lock Body (only)
MODEL 6730
Order Number
6741-002
Number of
Wheels
3
Page 21
MODEL 6741
A
GROUP 2 CLASS 1
Number of Wheels
3
Notes
standard lock bolt
Notes
standard bolt, D300 front reading B&W dial and ring
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Group 2M Mechanical Safe Locks
MODEL 6630
B
GROUP 2M
• The 6630 Series is based on the 6730 lock design with added security features such as false wheel
gates and an eccentric roller in the lever nose.
• 6630 Series: Underwriters Laboratories Listed Group 2M, A2P B, DNV 3492.
• 6631 Series: Underwriters Laboratories Listed Group 2M, DNV 3492.
• Three brass and aluminum combination wheels provide 1,000,000 theoretical combinations.
The four-wheel 6631 Series provides 100,000,000 theoretical combinations.
• Designed and constructed to perform in the most demanding commercial applications.
• Internal relock trigger secures the lock in the event of a burglar’s punch attack.
• Four-way drive cam allows mounting right-hand, left-hand, vertical-up, or vertical-down.
• Accepts a wide variety of dials in several attractive finishes (see page 23).
Lock Bodies (only)
Order Number
6630-010
6631-004
MODEL 6651
GROUP 2M
A
Number of Wheels
3
4
Notes
standard lock bolt
standard lock bolt
• The 6651 Series is based on the 6630 lock, offering solid security at a reduced cost.
• Underwriters Laboratories Listed Group 2M, VdS Class 1, CEN A.
• False wheel gates and a roller lever provide increased resistance to manipulation.
• Three combination wheels made of Zamak® alloy and aluminum offer 1,000,000
theoretical combinations.
• Internal relock trigger secures the lock in the event of a burglar’s punch attack.
• Four-way drive cam allows mounting right-hand, left-hand, vertical-up, or vertical-down.
• Accepts a wide variety of dials in several attractive finishes (see page 23).
CLASS 1
Lock Body (only)
Order Number
6651-013
Number of Wheels
3
Notes
standard lock bolt and M6 (metric) mounting screws
Group 2 and 2M locks can be matched with a wide assortment of dials and rings, which may be ordered separately. See page 23.
Page 22
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dials and Rings for Group 2 and Group 2M Locks
D003 dial
R004 ring
B&W
D112 dial
R162 ring
B&W
D300 dial
R211 ring
satin chrome
D220 dial
R167 ring
B&W
D690 dial
R211 ring
satin chrome
D690 dial
R211 ring
B&W
D225 dial
R167 ring
satin chrome
D225 dial
R167 ring
B&W
• All dial and rings pictured above and listed in the table directly below can be used with any Group 2 or Group 2M-type lock (pages 21 and 22).
They are NOT for use with any Group 1 or Group 1R-type lock.
• All dials on this page incorporate a solid, machined brass spindle long enough to accommodate a 3.4 inch (86.5 mm) door thickness. Dials with
longer spindles are available as special order items.**
• All dials on this page (with the exception of the D003) incorporate spindles splined to 41 on the dial. This results in a forbidden zone of 90 to 10
in Group 2 and Group 2M combination locks. The D003 spindle is splined to 50, resulting in a forbidden zone of 0 to 20.
• Finishes, spindle lengths, and spindle splining locations other than those listed can be special ordered.**
• Select the correct dial for your Group 2-type or Group 2M-type lock from the chart below.
Dial
Ring
Finish
Description
D003-003
R004-002 B&W
front reading, small knob, spindle splined to 50
D112-002
R162-002 B&W
Spy-Proof® with a 4-pin tumbler key locking cylinder
D300-016
R211-002 B&W
front reading, large knob, non-key locking
D300-021
R211-004 satin chrome front reading, large knob, non-key locking
D220-008
R167-002 B&W
D690-007* R211-002 B&W
Spy-Proof®, large knob, key locking
front reading, key locking, large knob*
D690-012* R211-004 satin chrome front reading, key locking, large knob*
D225-008* R167-002 B&W
Spy-Proof®, key locking, large knob*
D225-014* R167-014 satin chrome Spy-Proof®, key locking, large knob*
Use with Lock Models
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
6630, 6631, 6651, 6730, 6731, 6738,
6741, 6748
* Dials marked with an asterisk come complete with an additional self-stick escutcheon that does not have a cutout for the key cylinder. It allows you to remove the old escutcheon,
remove the key cylinder, and install the new escutcheon to convert the key locking dial to a non-key locking dial.
** Additional terms and charges may apply to special order items.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 23
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Group 1 and Group 1R Mechanical Safe Locks
GROUP 1/1R
B
CLASS 2
D054 DIAL
R162 RING
• 8550 Series: Underwriters Laboratories Listed Group 1, VdS Class 2, CEN B, DNV 3492, CNPP A2P B/E.
• 8560 Series: Underwriters Laboratories Listed Group 1R.
• Three wheels (made of brass and aluminum or acetal resin) provide 1,000,000 theoretical combinations.
• Manipulation resistance tested and verified by Underwriters Laboratories to exceed 20 man-hours.
• The 8560 Series has also been tested against 20 man-hours of radiological imaging attacks by
Underwriters Laboratories.
• Internal relock trigger secures the lock in the event of a burglar’s punch attack.
• Mount right-hand, left-hand, vertical-up, or vertical-down.
Order Number
8550-003
8560-004
Lock Bodies
(only)
Locks, Dials & Rings
Dials & Rings (only)
for 8500 Series
GROUP 1/1R
D041 DIAL
R162 RING
Order Number
8550-100
8560-100
No. of Wheels
3
3
No. of Wheels
3
3
Notes
U.L. Listed Group 1 (metal wheels)
U.L. Listed Group 1R (acetal resin wheels)
Notes
U.L. Listed Group 1 lock with D054 Spy-Proof® B&W dial and ring
U.L. Listed Group 1R lock with D054 Spy-Proof® B&W dial and ring
Dial
D054-004
Ring
R162-002
B&W Spy-Proof® dial and matching ring (order each separately)
Notes
D540-004
R167-002
B&W, Spy-Proof® dial and matching ring (order each separately)
D540-006
R167-014
satin chrome, Spy-Proof® dial and matching ring (order each separately)
• The 8400 Series is the direct descendant of the original MP Manipulation Proof® combination lock.
• 8410 and 8415 models are Underwriters Laboratories Listed Group 1. 8430 and 8435 models are
Underwriters Laboratories Listed Group 1R.
• Tested and verified by Underwriters Laboratories to resist 20 man-hours of expert manipulation.
• Three combination wheels (made of brass and aluminum or acetal resin) offer 1,000,000 theoretical
unique combinations.
• Designed and constructed to perform in the most demanding applications.
• Internal relock trigger secures the lock in the event of a punch attack.
• Using a Centi-Spline dial, the lock can be mounted right-hand, left-hand, vertical-up, or vertical-down.
Order Number
8410-009
8415-002
Number of Wheels
3
3
Notes
U.L. Group 1 MP lock
Group 1 MP with attached tube for insulated safe applications
Locks, Dials & Rings
Order Number
8410-100
8430-101
Number of Wheels
3
3
Notes
Group 1 lock with B&W D041 Spy Proof dial and ring
Group 1R lock with B&W D041 Spy Proof dial and ring
Dial & Ring (only)
Dial
D041-010
Lock Bodies (only)
Parts for the 8400
Ring
R162-002
Notes
B&W Spy-Proof Centi-Spline dial and matching ring (order each separately)
®
U14 Inner Spindle
max. door thickness of
3.4" (86 mm)
U22 Slider
Drive Cam
Page 24
U18 Spline Key
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
2937 Model Group 1 Mechanical Safe Lock
Meets Federal Specification
FF-L-2937
GROUP 1
• Underwriters Laboratories Listed Group 1.
• Meets Federal Specification FF-L-2937.
• Stainless steel bolt withstands a minimum of 600 lbs. of side
and end load.
• Dial spindle incorporates carbide barrier pins and a shear line to
control the point of separation in a forced entry attempt.
• Three all metal wheels provide for 1,000,000 unique theoretical combinations.
• Resistance to expert manipulation tested and verified by Underwriters Laboratories to exceed 20
man-hours.
• Built to provide a high level of security for government and defense industry applications.
• Internal relock trigger secures the lock in the event of a burglar’s punch attack.
• Integral thermal relock component protects against thermal attacks.
• Two-way drive cam and two-way dial spindle combine to allow mounting right-hand, left-hand,
vertical-up, or vertical-down.
• Uses a standard S&G® three wheel change key (U8 or U9).
National Stock Number:
5340-01-566-7405
Locks, Dials & Rings
Order Number
No. of Wheels
2937-200
3
Notes
includes lock, dial* and ring, plus an extra, short, drilled and tapped lock bolt for some
Mosler retrofit applications
2937 Individual
Components
Order Number
2937-002
2937-003
2937-004
Description
®
Spy-Proof dial* only
dial ring and dust cover only
dust cover only
* Dial spindle length will accommodate a maximum door thickness of
3.6 (91.4 mm)
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 25
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Parts and Accessories for Mechanical Safe Locks
U32
U9
U10
U12
U8
U11
6730-0
03-140
6730-0
03-074
6730-0
03-069
6730-0
03-166
6730-0
03-167
U19
U18
U17
7600-002
U32 Long Four Wheel Change Key—Long handle change key for all standard size locks with four wheels.
U9 Long Three Wheel Change Key—Long handle change key for all standard size locks with three wheels.
U10 Timebination Change Key—For all Timebination time delay locks with three wheels.
U12 Standard Four Wheel Change Key—Regular change key for all standard size locks with four wheels.
U8 Standard Three Wheel Change Key—Regular change key for all standard size locks with three wheels.
U11 Vault Lock Change Key—Regular change key for all S&G® vault locks with four wheels made after 1956.
6730-003-140 Extra Long Brass Bolt—Extends 2.461" (62,5 mm) from end of lock case when locked, 2.109" (53,6 mm)
from case when unlocked.
6730-003-074 Long Brass Bolt—Extends 0.961" (24,4 mm) from end of lock case when locked, 0.609" (15,5 mm) from
case when unlocked.
6730-003-069 Standard Brass Bolt—Extends 0.461" (11,7 mm) from end of lock case when locked, 0.109" (2,8 mm)
from case when unlocked.
6730-003-166 Metric Tapped Brass Bolt—Extends 0.461" (11,7 mm) from end of lock case when locked, 0.109" (2,8
mm) from case when unlocked. Bolt is drilled and tapped to a depth of 10 mm for two 4 mm - .7 machine screws.
6730-003-167 Short Tapped Brass Bolt—Extends 0.352" (8,9 mm) from end of lock case when locked. Retracts flush to
lock case. Bolt is drilled and tapped to a depth of 3/8" (9,5 mm) for two 10-32 machine screws.
Spline Keys—Should be replaced with new whenever removed. Spline keys are solid brass.
U17 Standard Spline Key—For 6700 and 8500 series locks.
U18 Spline Key—For 8400 series locks only.
U19 Vault Lock Spline Key—For 6400 and 6500 series vault locks manufactured after 1956.
7600-002 Dial Ring Bearing—The Delrin® bearing inserts into the back of all S&G® dial rings (except when used with D112 dials) to
provide a bearing surface for the dial as it rotates within the ring.
(Delrin® is a registered trademark of Dupont)
Spindle Extension Kits—Used to add spindle length for thick safe or vault doors. Make sure the existing spindle hole is
large enough to accommodate the kit’s connecting collar. Spindle, extension collar, and spline keys are included in the kit.
7312-003—For standard locks. 5/16"-40 X 6" (152,4 mm) kit with .450" (11.4 mm) diameter collar.
7312-005—For vault locks. 3/8"-30 X 7" (177,8 mm) kit with .510" (13 mm) diameter collar.
9060-001 Wheel Pack—Brass and aluminum wheel pack for 2937, 6730, 8400, and 8500 series
locks. Includes flys and spacer washers. Two top flys are also included, one pointed for use in 8400
locks and a standard top fly for all other locks.
7600-005 Key Cylinder—Disc tumbler cylinder for rekeying or repairing key locking, convertible style dials, or to convert nonkey locking dials to the key locking function. Uses a standard Y13 keyway and five brass discs. When the cylinder is pushed into
the dial, a spring-loaded brass retainer snaps into position to hold the cylinder in place. Order insert 760-003 separately for
conversions. Keyed different only, with two keys per cylinder.
Dial Inserts—These metallic, self-stick inserts are used with all large knob, convertible S&G® dials.
7600-003—For all large knob, convertible dials that do incorporate a lock cylinder.
7600-004—For all large knob, convertible dials that do not incorporate a lock cylinder.
6700-001 Dust Cover—Clear plastic dust cover fits on Spy-Proof® dial rings. Recommended to deter certain types of
surreptitious entry techniques. Highly recommended for safes used to store valuable or sensitive information.
Page 26
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Time Locks and Time Movements
• Three-movement time locks offer double-redundancy for
dependability and accuracy.
• Two-movement time locks offer single-redundancy to provide
built-in movement backup at a reduced cost.
• All movements are precision 13-jewel Swiss mechanisms.
• All time locks on this page are Listed under U.L. Standard 887.
• All models include durable winding charts for easy calculation of
winding times.
• A self-adhesive warning label is packed with each time lock to
indicate the presence of a time lock on the vault or safe door.
Three-Movement Time Locks
Order Number
6370-004
6370-005
6370-006
6370-009
Movements
(3) 144 hour standard
(3) 144 hour reset
(3) 144 hour snap-action
(3) 168 hour reset
Notes
standard movements cannot be back-wound if over-set
reset movements can be back-wound if over-set
snap-action movements can be back-wound if over-set
reset movements can be back-wound if over-set
Movements
(2) 144 hour standard
(2) 144 hour reset
(2) 144 hour snap-action
Notes
standard movements cannot be back-wound if over-set
reset movements can be back-wound if over-set
snap-action movements can be back-wound if over-set
Two-Movement Time Locks
Order Number
6280-004
6280-005
6280-006
6242-001 Standard Time Lock Movement—Fits three-movement and two-movement time lock cases. The standard movement can
be set up to 144 hours. This is a “gradual unlocking” device. It cannot be back-wound if too much time is accidentally wound onto
the movement. Precision made, 13-jewel, Swiss mechanism.
6242-002 Reset Time Lock Movement—Fits three-movement and two-movement time lock cases. The reset movement
can be set up to 144 hours. This is a “gradual unlocking” device. It can be back-wound if too much time is accidentally
wound onto the movement. Precision made, 13-jewel, Swiss mechanism.
6242-003 Snap-Action Time Lock Movement—Fits three-movement and two-movement time lock cases.
The snap-action movement can be set up to 144 hours. This is an instant unlocking device, providing extra
security against vibration attacks on the vault door. It can be back-wound if too much time is accidentally
wound onto the movement. Precision made, 13-jewel, Swiss mechanism.
6242-409-004006 Reset Round Bottom Time Lock Movement—Fits three-movement and
two-movement time lock cases. The reset movement can be set up to 168 hours. This is a
“gradual unlocking” device. It can be back-wound if too much time is accidentally wound onto
the movement. Precision made, 13-jewel, Swiss mechanism. Not recommended for the twomovement time lock case.
6242-004 Filler Block—A filler block should be used in only one position of a threemovement time lock case if only two movements are used. The center position is
recommended.
6242-005 Time Lock Winding Key—For
winding all S&G® time lock movements.
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 27
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Mechanical Vault Locks
• 6435: Underwriters Laboratories Listed Group 1.
• 6430 and 6530: Underwriters Laboratories Listed Group 2M
Recognized Component.
• 6535: Underwriters Laboratories Listed Group 2.
• E xtra heavy duty construction for long life and exceptional
durability in vault applications.
• Four brass and aluminum combination wheels provide 100,000,000
theoretical combinations.
• Ultra-dependable gravity activated lever allows the lock to be
mounted right-hand or left-hand. Not for vertical-up or verticaldown applications.
Vault Lock Bodies (only)
Order Number
6430-002
6430-003
6430-004
6430-005
6435-003
6435-004
6435-005
6435-006
6435-008
6435-009
6530-001
6530-002
6530-003
6535-002
6535-005
6535-007
6535-010
Bolt Style
square
square
center extension
center extension
square
square
center extension
center extension
roller
upper extension
center extension
roller
square
roller
upper extension
center extension
square
Hand of Lock
right-hand only
left-hand only
right-hand only
left-hand only
right-hand only
left-hand only
right-hand only
left-hand only
left-hand only
right-hand only
reversible
reversible
reversible
reversible
reversible
reversible
reversible
U.L. Listing
Group 2M RC
Group 2M RC
Group 2M RC
Group 2M RC
Group 1
Group 1
Group 1
Group 1
Group 1
Group 1
Group 2
Group 2
Group 2
Group 2
Group 2
Group 2
Group 2
Drive
direct
direct
direct
direct
indirect
indirect
indirect
indirect
indirect
indirect
direct
direct
direct
indirect
indirect
indirect
indirect
Notes
U.L. Group 2M Recognized Component
U.L. Group 2M Recognized Component
U.L. Group 2M Recognized Component
U.L. Group 2M Recognized Component
can be field configured for center, upper, or lower drive
can be field configured for center, upper, or lower drive
can be field configured for center, upper, or lower drive
can be field configured for center, upper, or lower drive
can be field configured for center, upper, or lower drive
can be field configured for center, upper, or lower drive
field configurable for left-hand or right-hand mounting
field configurable for left-hand or right-hand mounting
field configurable for left-hand or right-hand mounting
field changeable for handing and type of indirect drive
field changeable for handing and type of indirect drive
field changeable for handing and type of indirect drive
field changeable for handing and type of indirect drive
Vault Locks Dials & Rings
Dial
Ring
D240-003 R167-002
D240-007 R167-014
D240 DIAL & RING
B&W
Notes
Spy-Proof , B&W, key locking, for maximum 6.5" (165,1 mm) door thickness
Spy-Proof®, satin chrome, key locking, for maximum 6.5" (165,1 mm) door thickness
®
D240 DIAL & RING
SATIN CHROME
Drive Configurations—In a direct drive vault lock the dial spindle enters the lock case directly. In an indirect drive vault lock the dial spindle
attaches to a drive gear located outside the lock case, so that the dial is not directly in line with the lock case, but above, below, or to
one side of the case. The drawings below (right) illustrate the three indirect drive configurations.
bottom indirect drive
center indirect drive
center extension
upper extension
lower extension
standard square bolt
top indirect drive
roller bolt
Bolt Variations—Vault locks can be equipped with one of five different bolts. The three extension models are designed to attach directly to
boltwork or a blocking bar. The standard square bolt is used to block moving boltwork. The roller bolt, seldom used today, opens to provide a path
into the lock case into which a boltwork extension can move. The five bolt configurations are illustrated above (left).
Page 28
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Key-Op® Key Operated Safe Lock
6804-033 Buffed chrome hinged
cover keyhole escutcheon
6804-008 Guide Tube—Fits into a matching recess in
the front of the lock case, and extends to the back of the
key hole escutcheon. It is meant to guide the key into the
lock, and is suitable for thick doors and insulated doors.
Tube length is 1 meter, and can easily be cut to length.
6804-009 Satin nickel finish
self-stick keyhole escutcheon
• Underwriters Laboratories Listed under Standard 437 as a Security Container Lock.
• Available in single and double bitted key versions.
• Same mounting footprint as S&G® standard size combination locks, with the key hole in the same place as the spindle hole. Key hole through
the safe door must be at least 9/16" (14,3 mm) in diameter.
• Keys are nickel plated brass for durability and long life.
Key-Op Locks with Keys
Order Number
6804-049
6824-005
6805-005
Key Retention
key retaining
key retaining
non-key retaining
Key Style
single bitted
double bitted
single bitted
Notes
includes (2) keys and (1) 6804-009 escutcheon
includes (2) keys and (1) 6804-009 escutcheon
includes (2) keys and (1) 6804-009 escutcheon
Keys per Package
1
2
3
25
2
Notes
single bit, for 3" (76,2 mm) max. door thickness
single bit, for 3" (76,2 mm) max. door thickness
single bit, for 3" (76,2 mm) max. door thickness
double bit, for 3" (76,2 mm) max. door thickness
double bit, for 3" (76,2 mm) max. door thickness
Key-Op Key Blanks and Pre-Cut Keys
Order Number
6804-019
6804-017
6804-018
6824-017
6824-016
Description
uncut key blank
pre-cut keys
pre-cut keys
uncut key blank
pre-cut keys
Safe Handle
Spindle not included.
2629-010
MADE TO EASILY ATTACH AND SECURE SPINDLES
ACCEPTS ½" (12.7 mm) DIAMETER SPINDLE
S&G® Satin Chrome Safe Handle
Order Number
2629-010
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Finish
satin chrome
Notes
1/2" (12,7 mm) pilot hole for handle shaft
Page 29
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
6870 Series Key Operated Safe Lock
PRE-CUT KEYS
KEY BIT
KEY STEM
• Underwriters Laboratories Listed under Standard 437 as a Security Container Lock.
• Same mounting footprint as S&G® standard size combination locks, with the key hole in the same place as the spindle hole. Key
hole through the safe door must be at least 1/2" (12,7 mm) in diameter, or a minimum of 5/8" (15,9 mm) if a guide tube is used.
• True double-bitted lock with nine opposing brass levers and a mechanism that permits changing to new keys in seconds, with no
special tools.
6870 Locks with Keys
Order Number
6870-016
6870-008
6870-028
Keys Included
3
2
4
Notes
keys are for a maximum door thickness of 2.26" (57,4 mm)
keys are for a maximum door thickness of 4.22" (107,1 mm)
keys are for a maximum door thickness of 4.22" (107,1 mm)
6870 Pre-Cut Key Sets
Two Key Set
6870-112
6870-132
6870-202
Three Key Set
6870-113
6870-133
6870-203
Four Key Set
6870-114
6870-134
6870-204
Notes
pre-cut keys for 2.26" (57,4 mm) max door thickness
pre-cut keys for 4.22" (107,1 mm) max door thickness
pre-cut bit sets for use with 6870-200 stem
Detachable Bits
Order Number
6870-200
6870-201
Notes
key stem only for detachable bit for 7.57" (192,3 mm) maximum door thickness
uncut detachable bit for use with key stem listed above
Key Blanks
Order Number
6870-110
6870-130
Notes
for 2.26" (57,4 mm) max door thickness
for 4.22" (107,1 mm) max door thickness
6870-310
ESCUTCHEON
6870-320 ESCUTCHEON
WITH COVER
6870-370 Guide Tube—Guides the key into the lock, and is suitable for thick doors and insulated doors.
Tube length is 1 meter, and can easily be cut to length. The tube is an option and is not included with locks. It
requires a 5/8 inch (0.625" or 15,9 mm) hole through the safe door and an escutcheon.
Page 30
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
4200 and 4400 Series Safe Deposit Locks
• All locks on this page are Listed by Underwriters
Laboratories under Standard 437.
• The 4200 and 4400 family of safe deposit locks represent
an industry standard trusted by financial institutions
worldwide for over 80 years.
• Factory matchwork is available upon request to match
many manufacturers’ guard keys, provided a sample of the guard key is made available to us.
• The pick resistant lever design also resists advanced decoding techniques.
• S&G® safe deposit locks are all key retaining for added security in daily operations.
• Two renter keys are provided with each lock. Renter sides are keyed different. Guard keys are not provided.
• All locks on this page have brass plated covers and plugs.
• The 4444 lock is designed as the primary lock for B and C-rate depository safes and for inner compartment doors. It incorporates
special burglary resistant features. Its bolt is drilled and tapped for an 8-32 machine screw to accommodate boltwork attachment.
4200 Series
Order
Number
4231-002
4231-008
4420-010
4420-042
Lock
Style
4231
4231
4420
4420
Renter Nose
Diameter
.672" (17 mm)
.672" (17 mm)
.672" (17 mm)
.672" (17 mm)
Guard Nose
Diameter
.672" (17 mm)
.672" (17 mm)
.672" (17 mm)
.672" (17 mm)
Lock
Style
4440
4440
4442
4442
4443
4443
4444
Renter Nose
Diameter
.672" (17 mm)
.672" (17 mm)
.840" (21,3 mm)
.840" (21,3 mm)
.840" (21,3 mm)
.840" (21,3 mm)
.672" (17 mm)
Guard Nose
Diameter
.672" (17 mm)
.672" (17 mm)
.672" (17 mm)
.672" (17 mm)
.840" (21,3 mm)
.840" (21,3 mm)
.672" (17 mm)
Hand of Lock
Nose Height
left-hand
right-hand
left-hand
right-hand
0.5" (12.7 mm)
0.5" (12.7 mm)
0.5" (12.7 mm)
0.5" (12.7 mm)
Hand of Lock
Nose Height
left-hand
right-hand
left-hand
right-hand
left-hand
right-hand
right-hand only
0.5" (12,7 mm)
0.5" (12,7 mm)
0.5" (12,7 mm)
0.5" (12,7 mm)
0.5" (12,7 mm)
0.5" (12,7 mm)
0.5" (12,7 mm)
Guard
Setting
SY3
SY3
#4
#4
4400 Series
.380 (9,5 mm)
2.69 (68,3) mm)
4420—designed for matchwork to all Corbin
guard keys (RH model shown here)
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
MOUNTING SURFACE
OF LOCK
.500
(12,7 mm)
All locks on this page (with the exception of
the 4444) have an extended bolt length of .40"
(10,2 mm), with a bolt throw of .31" (7,9 mm).
Page 31
1.28 (32.5 mm)
3.19 (81 mm)
.270 (6,9 mm)
LOCK BOLT
1.39 (35,3 mm)
1.38 (35,1 mm)
1.14 (29 mm)
3.19 (81 mm)
Guard
Setting
#4
#4
#4
#4
#4
#4
#4
1.39 (35,3 mm)
1.78 (45,2 mm)
Order
Number
4440-018
4440-070
4442-004
4442-014
4443-008
4443-028
4444-002
2.70 (68,6) mm)
4440—a standard of the safe deposit industry since 1922
These dimensions also apply to:
4231—designed for matchwork to the Yale SY3 guard key
4442—designed for matchwork to the Diebold 175 series
4443—designed for matchwork to the Mosler 5700 series
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
4500 Series Safe Deposit Locks
.380" (9,5 mm)
1.88" (47,6 mm)
LOCK BOLT
MOUNTING SURFACE
OF LOCK
.270" (6,9 mm)
1.84" (46,7 mm)
1.52" (38.5 mm)
3.95" (100,4 mm)
3.58" (90,9 mm)
• The centerline design of the 4500 Series allows the same lock to be mounted either left-hand or right-hand.
• Factory matchwork is available on request to match many manufacturers’ guard keys. A sample guard key must be provided.
• The 4500 Series is Listed by Underwriters Laboratories under Standard 437.
4500 Series
Order
Number
4544-020
4545-004
Lock Style
centerline
centerline
Renter Nose Diameter and
Lever Type
.672" (17 mm) — changeable
.672" (17 mm) — changeable
Guard Nose Diameter and
Lever Type
.672" (17 mm) — changeable
.672" (17 mm) — changeable
Nose Height
3/8" (9.5 mm)
1/2" (12.7 mm)
4100 Series Cabinet Locks
.380" (9,5 mm)
2.30" (58,3 mm)
MOUNTING SURFACE
OF LOCK
LOCK BOLT
1.52" (38.5 mm)
1.84" (46,7 mm)
.270" (6,9 mm)
1.89" (46,7 mm)
• The 4100 Series is a collection of single nose changeable key cabinet locks.
• Four nose heights to accommodate different door thicknesses.
• Attractive brass plated cover and plug.
• Supplied with two matching keys.
• Can be mounted right-hand or left-hand.
4100 Series
Order
Number
4110-003
4111-003
4112-003
4113-003
Lock
Style
4100
4100
4100
4100
Nose Height
Nose Diameter and Lever Type
1/8" (3,2 mm)
1/4" (6,4 mm)
3/8" (9,5 mm)
1/2" (12.7 mm)
.672" (17 mm) — changeable
.672" (17 mm) — changeable
.672" (17 mm) — changeable
.672" (17 mm) — changeable
Page 32
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Safe Deposit and Cabinet Lock Key Blanks
60
87H
92H
96
.062" (1,57 mm)
.280" (7,11 mm)
.070" (1,78 mm)
.390" (9,91 mm)
.315: (8.9 mm)
.070" (1,78 mm)
.315" (8,0 mm)
.080" (2,03 mm)
.275" (6,99 mm)
9609
.070" (1,78 mm)
.350" (8,89 mm)
SY3B
.063" (1,6 mm)
.243" (6,17 mm)
• All key blanks on this page are made of nickel-silver for long life and smooth operation.
• Silhouettes are slightly larger than actual size to allow you to lay a key on the drawing and see part of the line thickness around the
edges. Tolerances are ±.003" (0,076 mm) from listed dimensions. Cross sections are viewed as if looking from the bow of the key
toward the tip, or as if looking at the keyway broaching. Shading indicates tip projection and any other blade width variations.
Safe Deposit and Cabinet Lock Key Blanks
Order Number
9500-005
9500-001
9500-016
9500-003
9500-004
9500-002
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Designation
60
87H
92H
96
9609
SY3B
Notes
used for renter key with 4442 and 4443 Series safe deposit locks
standard guard key blank for 4420, 4440, 4442, 4444, and 4500 Series safe deposit locks
used for R132 Series key locking dial ring
standard renter key blank for 4231, 4420, 4440, 4444, 4100, and 4500 Series locks
used for the guard key with 4443 Series safe deposit locks
used for the guard key for the 4231 Series safe deposit lock (Yale matchwork)
Page 33
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
8077AD Combination Padlock
8077-043 Padlock Change Key—Replacement change key
for all 8077 padlocks. Comes with changing instructions.
National Stock Numbers:
5340 00 285 6523 (GSA)
5340 01 196 2568 (DLA)
5340 01 217 2009
All refer to the 8077AD padlock with hardened steel shackle.
• Built to conform to stringent government specifications, including 30 minute
protection against expert manipulation and 10 minute protection against surreptitious entry attack.
• Field changeable combination with the use of a change key.
• 125,000 possible combinations.
• Packaged with change key and complete operating/changing instructions.
CLEAR
OPENING
Dimensions and Specifications
shackle material: case hardened steel
shackle diameter: 5/16 (8 mm)
clear shackle opening when locked: 7/8 (22 mm)
overall dimensions: 4 5/32 (10,6 cm) high
2 3/8 (6,0 cm) wide
1 31/32 (5,0 cm) deep
weight: 1.75 lbs. (0,8 kilograms)
8077AD Padlock
Order
Number
8077-108
Dial
Shackle Material
Recommended Hasp Opening for Shackle
black
case hardened steel
3/8" (9,5 mm)
THROAT OPENING
951C High Security Padlock
CLEAR OPENING
Dimensions and Specifications
shackle material: hardened steel
shackle diameter: 1/2 (12.7 mm)
throat opening in shackle shroud: 3 /4 (19 mm) wide
7/16 (11,1) high
clear shackle opening when locked: 5/8 (15,8 mm)
overall dimensions: 4 11/16 (11,9 cm) high
2 3/4 (7,0 cm) wide
1 13/16 (4,4 cm) deep
weight: 4 lbs. (1,81 kilograms)
This is the commercial keyway (S1) version of the Model 951 padlock. Verify
that it meets applicable security requirements before ordering.
• This rugged, key retaining padlock is built to conform to rigid specifications for indoor and
outdoor high security applications—Ideal for perimeter security and any location requiring a high degree of resistance to forced entry.
• Easily field disassembled by use of a control key for service or rekeying.
• Equipped with a commerically available, high security Medeco® key cylinder.
• Cast stainless steel body.
• Body and shackle incorporate exotic barrier materials for maximum resistance against cutting, drilling, and sawing.
• Shrouded shackle offers 5/8" (15,8 mm) clear opening and provides a high degree of resistance against common wedging attacks.
951 Padlock
Order Number
Keying Information
951-009
keyed different
Keys
1 control key
2 operator keys
Notes
includes attached chain and clevis
Page 34
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Extension 50 Mechanical Automatic Door Deadbolt
• Surface mounted for ease of installation and suitability for a
wide range of applications.
• Automatic locking deadbolt mechanism incorporates an
inside release knob for rapid egress, and a manual
“dogging” switch to keep the device unlocked when the
secured area is occupied.
• Strikes available for both inswing and outswing doors.
• Equipped with either an 8400 or 8500 Series Group 1 or
Group 1R combination lock for a high level of security.
• An ideal security solution for indoor applications, such as ATM rooms, cash handling areas, research laboratories, etc.
• All units include a rectangular hardplate that is placed under the mounting plate to deter forced entry attacks.
• Interlocking strike (any model) prevents spreading of the door and frame.
• Hardened steel pins inside the locking bolt deter sawing and increase forced entry resistance.
Extension 50
Order
Number
8415-107
8435-106
8555-105
8565-105
Lock Model
8400 Group 1 aluminum & brass
8400 Group 1R acetal resin & brass
8500 Group 1 aluminum & brass
8500 Group 1R acetal resin & brass
#1 STRIKE
PRODUCT NO. 8497-001
LOCK BODY
INSWING DOOR
Lock Wheels
FRAME
Dial and Ring
Strike
included—D041/R162 B&W
included—D041/R162 B&W
included—D054/R162 B&W
included—D054/R162 B&W
not included-order separately
not included-order separately
not included-order separately
not included-order separately
OUTSWING DOOR
LOCK BODY
LOCK BODY
FRAME
ACTIVE DOOR
#9 STRIKE
PRODUCT NO. 8497-004
INACTIVE
DOOR
#3 STRIKE
PRODUCT NO. 8497-003
LOCK BODY
INSWING DOOR
FRAME
#2 STRIKE
PRODUCT NO. 8497-002
Sliding Mechanical Deadbolts
1881 DEADBOLT
• Full 1" (25,4 mm) bolt throw.
• Both models can be secured in the locked or unlocked position.
• Hardened steel bolt pins resist sawing and over one ton of thrust.
• Surface mount design for ease of installation and suitability to a wide range of applications.
• The 1881 model will accept any 5/16" (8 mm) diameter shackle padlock, such as the S&G® 8077AD.
• The 1883 model incorporates at 4-pin tumbler cylinder operated by keys cut on National D4291 blanks.
1883 DEADBOLT
1881 and 1883 Deadbolts
Non-Key Locking (requires padlock)
1881-001
1881-002
1881-003
1881-004
1881-005
#12 Double Door Strike
Product No. 1810-001
(strike only)
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Integral 4-Pin Key Cylinder
1883-001
1883-002
1883-003
1883-004
1883-005
#13 Mortise Floor Strike
Product No. 1810-002
(strike only)
Page 35
#14 Surface Mount
Strike
Product No. 1810-003
(strike only)
Included Strike
none
#12
#13
#14
#15
#15 Mortise Frame
Strike
Product No. 1810-004
(strike only)
National Stock Number
5340-01-210-5589
can apply to any 1881
deadbolt. When using
this National Stock
Number, specify which
strike is to be included,
or specify that no strike
is needed.
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
The Brute® Electronic Door Deadlatch
Electrical Specifications:
Required voltage: 24 VDC
DC coil resistance: 6 OHMS
Current: 5.5 to 6.5 AMPS
Minimum recommended wire size: 18 gauge
National Stock Numbers 5340-01-020-5681 and
6350-00-610-1962 can refer to any model of The Brute®
deadlatch. You must specify inswing or outswing and
strike number. This is the only way to ensure you receive
hardware suited to your application.
• Surface mounted for ease of installation and suitability for a wide range of applications.
• Inside release knob provides for rapid egress.
• Strikes available for both inswing and outswing doors.
• An ideal security solution for indoor applications, such as ATM rooms, cash handling areas, research laboratories, etc.
• Originally designed to be used with the (discontinued) S&G® Code/Tronic™ III access control device, The Brute® deadlatch can be
used with any control device that meets its electrical requirements.
• The Brute® deadlatch uses a heavy duty 12 VDC solenoid. The 24 VDC voltage requirement increases bolt retraction force and will
not harm the solenoid.
The Brute
Order
Number
8497-100
8497-101
8497-102
8497-103
8497-105
8497-106
Application
inswing door
outswing door
inswing door
outswing door
inswing door
outswing door
Included Strike(s)
OUTSWING DOOR
LOCK BODY
#1 for inswing doors
#2 for outswing doors
#3 for inswing doors
#9 for outswing double doors
none
none
FRAME
LOCK BODY
INSWING DOOR
FRAME
#2 STRIKE
PRODUCT NO. 8497-002
#1 STRIKE
PRODUCT NO. 8497-001
#9 STRIKE
PRODUCT NO. 8497-004
LOCK BODY
INSWING DOOR
FRAME
#3 STRIKE
PRODUCT NO. 8497-003
LOCK BODY
ACTIVE INSWING DOUBLE DOOR
INACTIVE
DOOR
Product Compliance and Certifications
Sargent & Greenleaf sells its products in some 140 countries. Different countries and regions create and adhere to their own
specifications for safes and locks. Because S&G does business in virtually all corners of the globe, our products are often submitted to various international testing agencies to verify that they meet particular specifications for the market(s) into which
they are being sold. This is why you will see some or all of these symbols on various product pages throughout this catalog.
The European Union has set forth guidelines to curb the use of substances which have been
determined to be detrimental to the environment. Individual member countries create their own
regulations based on the RoHS guidelines published by the European Union.
When you see the RoHS (Reduction of Hazardous Substances) symbol next to a product in this
catalog, it means this product has been certified acceptable under the RoHS
guidelines. For specific product information as it relates to this issue, go to this page on our
website: www.sargentandgreenleaf.com/rohs.php
Page 36
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Arm-A-Dor® Secure Panic Exit Hardware
ONE YEAR PARTS REPLACEMENT WARRANTY ON ALARM
COMPONENTS AND FIVE YEAR DEFECTIVE PARTS REPLACEMENT
WARRANTY ON ALL OTHER MECHANICAL COMPONENTS
• Conforms to these requirements: U.L. 305 Panic Device Rating, U.L. 10B Fire Exit Hardware, 3 hrs at 2000, Dade County (Florida)
Product Control Approved No. 07-1219.12 (Hurricane ), NFPA 101 Life Safety Code, UBC/ BOCA, ANSI 156.3, City of New York
Department of Buildings, MEA 292-96-E.
• Arm-A-Dor® secure panic hardware offers 24-hour protection, keeping intruders out while providing life-saving security within.
Developed for retail back door security by retail industry construction experts, Arm-A-Dor® has many commercial, industrial and
institutional applications.
• Surface mounted for ease of installation and suitability for a wide range of applications.
• Select a model that automatically locks whenever the door is closed, or one that must be manually locked, whichever suits your
particular application.
• Offers locking bar protection for security from the outside, single motion egress, and Life Safety compliance.
• Designed as a security system for service and emergency exits, the Arm-A-Dor® device is for exit-only doors and cannot be
configured to unlock from the outside.
• All models are US28 finish, exit-only, and can be mounted either left-hand or right-hand.
Arm-A-Dor ® Secure Panic Exit Hardware
Order Number
A101-001
A101-002*
A102-001
A102-002*
A101-F01
A101-F02*
A101-012
A101-013*
A101-014
A101-015*
Description
Door Size Alarm
automatic relock
3' to 4'
no
automatic relock
3' to 4'
yes
manual relock
3' to 4'
no
manual relock
3' to 4'
yes
automatic relock, fire rated
3' to 4'
no
automatic relock, fire rated
3' to 4'
yes
automatic relock, pre-assembled 3' only
no
automatic relock, pre-assembled 3' only
yes
automatic relock, pre-assembled 4' only
no
automatic relock, pre-assembled 4' only
yes
Fits Jambs
up to 6 3/4"
up to 6 3/4"
up to 6 3/4"
up to 6 3/4"
up to 6 3/4"
up to 6 3/4"
5 1/4" to 5 3/4"
5 1/4" to 5 3/4"
5 1/4" to 5 3/4"
5 1/4" to 5 3/4"
Notes
(2) 9 volt batteries included
(2) 9 volt batteries included
fire rated
(2) 9 volt batteries included
(2) 9 volt batteries included
(2) 9 volt batteries included
* Alarm units require a standard 1 1/8" mortise cylinder to allow the alarm control to be keyed into existing systems. For this reason, the mortise cylinder is not
supplied with the exit device, and is not available from S&G.
A103-002—RX (request for exit) Switch Kit for wiring into an existing system.
A103-003—Alarm sub-assembly to convert a non-alarmed unit to one with an alarm.
A104-001—Low Profile Installation Kit for installations where door jambs are deeper than 6 3/4".
A106-001—Standard Double Door Kit fits all models of Arm-A-Dor®.
A106-002—Low Profile Double Door Kit for installations where door jambs are deeper than 6 3/4".
A107-001—AC Adapter Kit for plug-in battery backup.
A107-002—AC Adapter Hardwire Kit for wiring the alarm into your electrical system with battery backup.
1881-003—Sliding deadbolt assembly with strike and integral padlock hasp for double door installations (see page 35).
1883-003—Sliding deadbolt assembly with strike and integral key lock for double door installations (see page 35).
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 37
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—6120 and 6123 Series Case
2.400 (61,0 mm)
1.624 (41,2 mm)
1.000 (25,4 mm)
Bolt extension:
Locked = .461
(11,71 mm)
Unlocked = .125
(3,18 mm)
0.468
(11,9 mm)
.312
7,9 mm
.281
7,1 mm
2.624 (66,6 mm)
3.320 (84,3 mm)
1.206 (30,6 mm)
CAUTION: SAFE BOLTWORK SHOULD NEVER MOVE CLOSER THAN .150 INCH (3.8 MM) TO THE BOLT END OF THE LOCK CASE.
Dimensions— 6124, 6126, 6128, 6300 Series Case
6124
6126
6128
6300
2.400 (61,0 mm)
.461
(11,71 mm)
.125
(3,18 mm)
1.000 (25,4 mm)
6124
6126
6128
6300
1.624" (41,2 mm)
Bolt extension:
Locked =
Unlocked =
.312
7,9 mm
.281
7,1 mm
2.624 (66,6 mm)
3.320 (84,3 mm)
1.165 (30 mm)
CAUTION: SAFE BOLTWORK SHOULD NEVER MOVE CLOSER THAN .150 INCH (3.8 MM)
TO THE BOLT END OF THE LOCK CASE.
Page 38
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions— 6125, 6127, 6129 Series Case
.461
(11,71 mm)
.125
(3,18 mm)
6125
6127
6129
2.400 (61,0 mm)
1.000 (25,4 mm)
6125
6127
6129
1.624" (41,2 mm)
Bolt extension:
Locked =
Unlocked =
.59 (15 mm)
M4­–.7 holes
.312
7,9 mm
.281
7,1 mm
2.624 (66,6 mm)
1.165 (30 mm)
3.320 (84,3 mm)
Specifications for the user-supplied switch needed to signal models 6125, 6127, and 6129 that safe boltwork is extended
and it is okay to extend the lock bolt:
Minimum voltage rating: 30 VDC
Minimum current rating: 50 milliamperes
Electrical contact material: silver
Switch operation: snap acting contacts
Contact configuration: lock bolt extends on contact closure
Switch actuator: recommend lever or roller actuator, depending on boltwork design
Switch operating life: minimum of 50,000 cycles
Switch connectors: recommend .110" (2.8 mm) X .020" (.5 mm) quick connect tabs
The bolt throw of the 6125, 6127, and 6129 can be adjusted. If
your application requires more than .46" (11,7 mm) bolt travel,
remove the bolt travel adjustment screw and add a .075" (2 mm)
thick spacer when attaching safe boltwork to the lock bolt.
Standard bolt extension:
Locked = 0.461 (11,71 mm)
Unlocked = 0 (flush with case)
Throw = 0.461 (11,71 mm)
Travel screw removed:
Locked = 0.461 (11,71 mm)
Unlocked = -0.08 (-2 mm) (recessed)
Throw =
0.54 (13,71 mm)
travel screw removed
BOLT TRAVEL SCREW
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 39
standard
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—Titan™ PivotBolt™ Case
0.370
(9,4 mm)
3.319
(84,3 mm)
1.084
(27,5 mm)
0.460
(11,7 mm)
0.305
(7,7 mm)
1.625 (41,3 mm)
2.625 (66,7 mm)
2.400
(61,0 mm)
1.200
(30,5 mm)
.990
(25,1 mm)
Dimensions—Titan™ D-Drive™ Case
0.375
(9,5 mm)
3.319
(84,3 mm)
1.084
(27,5 mm)
0.466
(11,8 mm)
0.310
(7,9 mm)
1.625 (41,3 mm)
2.625 (66,7 mm)
2.400
(61,0 mm)
1.200
(30,5 mm)
.990
(25,1 mm)
Page 40
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—Electronic Vault Lock Case
4.446 (112,93 mm)
3.475 (88,265 mm)
3.250
(82,55 mm)
2.296
(58,32 mm)
2.715
(68,96 mm)
5.465 (138,81 mm)
0.125
(3,18 mm)
0.678
(17,23 mm)
1.675
(42,54 mm)
1.109
(28,17 mm)
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 41
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
1.000 (25,4 mm)
1.937 (49,2 mm)
1.624 (41,2 mm)
2.397 (60,9 mm)
Dimensions—Standard Size Mechanical Lock Case
BOLT THROW IS
0.35 (8,9 MM)
2.624 (66,6 mm)
3.343 (84,9 mm)
THE DIMENSIONS LISTED ABOVE ARE VALID FOR ALL
2937, 6600, 6700, 8400, AND 8500 SERIES LOCKS.
0.281 (7,1 mm)
0.281 (7,1 mm)
BOLT IS .312
(7,9 MM) THICK
1.121 (28,5 mm)
2937, 6600, AND 6700, 8500
SERIES 3-WHEEL LOCKS
0.281 (7,1 mm)
BOLT IS .312
(7,9 MM) THICK
1.334 (33,8 mm)
BOLT IS .312
(7,9 MM) THICK
1.407 (35,7 mm)
6600 AND 6700 SERIES
4-WHEEL LOCKS
Page 42
8400
SERIES 3-WHEEL LOCKS
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—Standard Size Mechanical Lock Bolts
6730-0
03-140
6730-0
03 -
074
6730-0
03 -
069
6730-0
03-166
6730-0
03-167
©2012
6730-003-140 Extra Long Brass Bolt—Extends 2.461" (62,5 mm) from end of lock case when locked, 2.109" (53,6 mm)
from case when unlocked.
6730-003-074 Long Brass Bolt—Extends 0.961" (24,4 mm) from end of lock case when locked, 0.609" (15,5 mm) from
case when unlocked.
6730-003-069 Standard Brass Bolt—Extends 0.461" (11,7 mm) from end of lock case when locked, 0.109" (2,8 mm)
from case when unlocked.
6730-003-166 Metric Tapped Brass Bolt—Extends 0.461" (11,7 mm) from end of lock case when locked, 0.109" (2,8
mm) from case when unlocked. Bolt is drilled and tapped to a depth of 10 mm for two 4 mm - 7 pitch machine screws.
6730-003-167 Short Tapped Brass Bolt—Extends 0.352" (8,9 mm) from end of lock case when locked. Retracts flush to
lock case. Bolt is drilled and tapped to a depth of 3/8" (9,5 mm) for two 10-32 machine screws.
Sargent and Greenleaf
Revision date: 9/19/2012
Page 43
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—Mechanical Vault Lock Case
4.500 (114,3 mm)
1.492 (37,9 mm)
2.296 (58,3 mm)
3.250 (82,6 mm)
3.475 (88,3 mm)
2.350 (59,7 mm)
BOLT THROW IS
0.75 (19,1 MM)
2.130 (54,1 mm)
CASE HEIGHT IS 2.250 (57,15 MM) IF
GEAR PLATE IS USED FOR INDIRECT DRIVE
APPLICATIONS
Page 44
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Spacings and Depths for Safe Deposit Locks
Throat Cut
#7 Cut
#6 Cut
#5 Cut
#4 Cut
#3 Cut
#2 Cut
#1 Cut
Tip Stop
Renter Key
Throat Cut
#7 Cut
#6 Cut
#5 Cut
#4 Cut
#3 Cut
#2 Cut
#1 Cut
Tip Stop
CUT TO .087 ± .003
FOR ALL GUARD KEYS
WIDTH OF CUT
ALL DIMENSIONS ON THIS PAGE ARE IN INCHES.
Root Depths are Measured from Bottom of Blank
to the Bottom of the Cut
Spacing is from Tip Stop to Center of Cut
LOCK SERIES
CUT SPACING
1ST
CUT
2ND
CUT
3RD
CUT
4TH
CUT
5TH
CUT
6TH
CUT
7TH
CUT
THROAT
CUT
41XX
FROM TIP STOP
.167
.222
.271
.319
.367
.415
.470
1.0875
WIDTH OF CUT
.066
.052
.052
.052
.052
.052
.066
.105
FROM TIP STOP
.167
.222
.271
.319
.367
.415
.470
1.0875
WIDTH OF CUT
.066
.052
.052
.052
.052
.052
.066
.105
FROM TIP STOP
.167
.222
.271
.319
.367
.415
.470
1.0775
WIDTH OF CUT
.066
.052
.052
.052
.052
.052
.066
.105
FROM TIP STOP
.167
.222
.271
.319
.367
.422
1.0875
WIDTH OF CUT
.066
.052
.052
.052
.052
.066
.105
FROM TIP STOP
.167
.222
.271
.319
.378
1.0775
WIDTH OF CUT
.066
.052
.052
.052
.066
.105
44XX Renter
FROM TIP STOP
.167
.222
.271
.319
.367
.422
WIDTH OF CUT
.066
.052
.052
.052
.052
.066
44XX Guard
FROM TIP STOP
.167
.222
.271
.319
.378
1.0775
WIDTH OF CUT
.066
.052
.052
.052
.066
.105
45XX Renter
45XX Guard
4231 Renter
4231 Guard
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 45
1.0875
DEPTH DEPTH DEPTH DEPTH DEPTH DEPTH DEPTH DEPTH
0
1
2
3
4
5
6
7
.314
.298
.278
.258
.238
.218
.198
.178
.314
.298
.278
.258
.238
.218
.198
.178
.275
.255
.235
.215
.195
.175
.155
.135
.314
.298
.278
.258
.238
.218
.198
.178
.275
.314
.235
.298
.278
.195
.258
.238
.155
.218
.198
.105
.275
.235
.195
.155
.178
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—4200 and 4400 Series Safe Deposit Locks
1.39" (35,3 mm)
1.28" (32,5 mm)
1.38" (35,1 mm)
1.14" (29 mm)
1.39" (35,3 mm)
1.78" (45,2 mm)
3.19" (81 mm)
3.19" (81 mm)
2.69" (68,3 mm)
2.70" (68,6 mm)
4420—designed for matchwork to all Corbin
guard keys (RH model shown here)
4442—designed for matchwork to the Diebold
175 series (RH model shown here)
3.19" (81 mm)
1.39" (35,3 mm)
2.70" (68,6 mm)
2.70" (68,6 mm)
4231—designed for matchwork to the Yale SY3
guard key (RH model shown here)
4443—designed for matchwork to the Mosler
5700 series (RH model shown here)
3.19" (81 mm)
1.39" (35,3 mm)
1.28" (32,5 mm)
1.39" (35,3 mm)
2.70" (68,6 mm)
1.78" (45,2 mm)
3.19" (81 mm)
1.78" (45,2 mm)
2.70" (68,6 mm)
4440—a standard of the safe deposit industry
since 1922 (RH model shown here)
4444—designed for B and C-rate depository
safe doors (available RH only)
.380" (9,5 mm)
BOLT OFFSET
DIMENSIONS FOR
ALL 4200 AND
4400 SERIES SAFE
DEPOSIT LOCKS
MOUNTING SURFACE
OF LOCK
.270" (6,9 mm)
LOCK BOLT
1.28" (32,5 mm)
1.78" (45,2 mm)
1.39" (35,3 mm)
1.28" (32,5 mm)
1.78" (45,2 mm)
1.28" (32,5 mm)
3.19" (81 mm)
Page 46
All locks on this page (with the
exception of the 4444) have an extended
bolt length of .40" (10,2 mm), with a
bolt throw of .31" (7,9 mm).
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Dimensions—4100 Series Cabinet Lock
1.52" (38,5 mm)
1.84" (46,7 mm)
2.30" (58,3 mm)
1.89" (46,7 mm)
.380" (9,5 mm)
MOUNTING SURFACE
OF LOCK
BOLT OFFSET
DIMENSIONS FOR
ALL 4100 AND
4500 SERIES SAFE
DEPOSIT LOCKS
LOCK BOLT
.270" (6,9 mm)
All locks on this page (with the
exception of the 4444) have an extended
bolt length of .40" (10,2 mm), with a
bolt throw of .31" (7,9 mm).
Dimensions—4500 Safe Deposit Lock
1.88" (47,6 mm)
3.58" (90,9) mm)
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Page 47
1.84" (46,7 mm)
1.52" (38,5 mm)
3.95" (100,4 mm)
SARGENT AND GREENLEAF®
A Subsidiary of Stanley Security Solutions, Inc.
Sargent & Greenleaf
Sargent & Greenleaf S.A.
One Security Drive, Nicholasville, Kentucky 40356
Phone (800) 826-7652
FAX (800) 634-4843
Phone (859) 885-9411
FAX (859) 887-2057
9, chemin du Croset, 1024 Ecublens, Switzerland
Phone 41 21 694 34 00
FAX 41 21 694 34 09
S&G® products are sold throughout the world. Contact your nearest Sargent and Greenleaf Distributor for pricing and availability on
any of our products. For the latest product information and a complete listing of S&G® distributors, please visit our website:
www.sargentandgreenleaf.com
Packaging
Your distributor may choose to repackage items or sell products as single units or in lots containing fewer items than the
manufacturer’s standard package quantities. Check with your distributor for quantities and pricing before placing an order.
WARRANTY
Seller warrants that for one year* from the date of shipment from Seller's point of manufacture, the goods shall be free from defects
in material and workmanship, provided the goods are normally and properly used according to the Seller's written instructions.
THIS WARRANTY IS EXPRESSLY MADE IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. S&G DOES NOT
WARRANT THAT THE GOODS ARE MERCHANTABLE OR FIT FOR ANY PARTICULAR PURPOSE EXCEPT AS EXPRESSLY PROVIDED
HEREIN.
Seller's entire liability and Buyer's exclusive remedy in the event that the goods do not conform to the foregoing warranty shall be
Seller's repair or replacement of the goods (including payment of freight costs to and from point of Manufacture).
UNAUTHORIZED USE OF COMPONENTS NOT MANUFACTURED BY THE SELLER IN CONJUNCTION WITH SELLER’S PRODUCTS
INVALIDATES THE WARRANTY. ANY MODIFICATIONS TO PRODUCTS NOT PERFORMED BY S&G INVALIDATE THE WARRANTY.
SELLER SHALL HAVE NO LIABILITY FOR ANY CONSEQUENTIAL, INCIDENTAL, INDIRECT OR SPECIAL DAMAGES. SELLER DOES
NOT WARRANT ITS LOCK PRODUCTS TO BE IMPERVIOUS TO FORCIBLE OR SURREPTITIOUS ENTRY, AND SELLER SHALL HAVE NO
LIABILITY FOR DAMAGE TO OR LOSS OF PROPERTY SOUGHT TO BE PROTECTED BY ANY SUCH LOCK.
*6100 series electronic locks, 6300 series electronic locks, Titan 2006/2007 series electronic locks, 6730 series mechanical
combination locks, 2740 electromechanical locks, and Environmental Padlocks carry a two year warranty.
Arm-A-Dor® devices carry a five year parts warranty on mechanical components and a one year parts warranty on the alarm
components.
Technical information and information regarding certifications in this publication are accurate to the best of our ability at the time of publication. Sargent & Greenleaf does not, however, warrant the accuracy of such information and
assumes no responsibility for the application of such information published in this catalog.
Page 48
©2012
Sargent and Greenleaf
Revision date: 9/19/2012
Corporate Headquarters: One Security Drive, Nicholasville, KY 40356, USA
Telephone: 859-885-9411 Fax 859-887-2057
European Headquarters: 9, chemin du Croset, 1024 Ecublens, Switzerland
Telephone: 41 21 694 34 00 Fax 41 21 694 34 09
Document 630-681
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
