KERR PUMP CORPORATION SERVICE MANUAL EIGHTEENTH EDITION NEW PUMP WARRANTY A. Kerr Machine Co. (Kerr Pump Corporation) warrants its new pumps to be free from defective materials and/or workmanship for a period of one year from the date of sale by the Distributor, provided that the new pump is registered in accordance with Paragraph No. 2 hereof, properly installed and operated in accordance with the Company’s Service Manual, and all other terms of this warranty agreement are complied with by the purchaser. As hereinafter provided, this warranty includes the replacement of parts and labor to correct any deficiency. All defective parts must be returned to the Company’s Home Office for examination before this warranty is effective. This warranty applies to parts, which have been replaced under this warranty only so long as the original pump warranty is effective. This warranty is for the exclusive benefit of the purchaser and is not transferable. B. Each Distributor of a new pump will provide the customer with a registration blank furnished to him by the Company which must state the date of sale, be signed by the purchaser and the Distributor, and delivered to the Home Office of the Company within fifteen (15) days of the date of sale. C. In the event of a claim under this warranty, made within the one‐year warranty period, the purchaser must notify the Distributor, and the Distributor shall contact Kerr Pump Corporation before any repairs or service calls are made. D. All warranty claims must be sent to Kerr Pump Corporation Home Office on the authorized warranty claim form provided by Kerr Pump Corporation, and available from the Distributor before any warranty claim will be considered. It is understood that Kerr Pump Corporation will deteriorate due to ordinary wear, therefore, the following credits shall apply to all replacement parts, labor, surface freight, travel time and mileage allowance furnished under this warranty. i. For the first ninety (90) days from the date of sale by the Distributor, 100% credit will be allowed on a current list price basis. ii. From 91 to 180 days from the date of sale by the Distributor, 75% credit will be allowed on a current list price basis. iii. From 181 days to 270 days by the Distributor, 50% credit will be allowed on a current list price basis. iv.
From 271 days to one year after the date of sale by the Distributor, 25% credit will be allowed on a current list price basis. The credit given to the Distributor for replacement parts or pumps under this warranty is based upon the Distributor’s net cost paid Kerr Pumps for such replacement parts or pumps. E. In the event of a warranty claim under this warranty made within ninety (90) days of the date of sale by the Distributor, Kerr Pump Corporation, before any repairs are made, shall be contacted by the Distributor and given the option of having the Distributor either repair or replace the pump. F. Upon any claim under this warranty, other than a claim wherein Kerr Pump Corporation at its option replaced the pump as provided in Paragraph No. 5 hereof, the Distributor will make the necessary repairs an/or replacement, and Kerr Pump Corporation shall allow the cost of labor on warranty claims. The labor cost may include travel time not to exceed (8) hours of actual travel time. Kerr Pump Corporation will pay surface freight on warranty shipments. After making the necessary repairs and/or replacements, the Distributor will bill the customer for the full amount due for the repair. Thereafter, the Distributor will submit the warranty claim form provided by Kerr Pump Corporation to the Kerr Pump Corporation Home Office for consideration. In the event the warranty claim is honored by Kerr Pump Corporation a Credit Memorandum will be issued to the Distributor in the amount determined by the table in Paragraph No. 4 hereof. Thereafter, the customer’s invoice will be credited by the Distributor in the same percentage allowed the Distributor by Kerr Pump Corporation. If requested by Kerr Pump Corporation the purchaser or the Distributor shall return the alleged defective product to Kerr Pump Corporation factory, freight prepaid, for examination and testing. If Kerr Pump Corporation determines the product is defective Kerr Pump Corporation will either repair or replace such product with a like of Kerr Pump Corporation manufacture, f.o.b. to the Distributor or allow the Distributor credit to an amount equal to the invoiced value of the defective product. The responsibility of Kerr Pump Corporation is limited to the repairing or replacing defective material manufactured by it, provided Kerr Pump Corporation examination discloses to its satisfaction that such material has not been altered or repaired, other than by Kerr Pump Corporation approved procedures, subject to misuse, improper maintenance, negligence or accident. Kerr Pump Corporation will not be responsible for loss of liquid or for damage of any kind, or from any cause, to any person or property of any person, or for loss of revenue of profit, or for any other special incidental or consequential damages. G. The warranty applies only to new Kerr Pump Corporation. The Company specifically excludes from this warranty the following. i. All plungers, valves, plunger packing, valve springs, seals gaskets, and corrosion and/or erosion damage caused by the fluid handled by the Company’s pump. ii. In addition, after the expiration of the pump warranty all replacement parts are no longer in warranty. H. In extreme cases where in the opinion of Kerr Pump Corporation, if a pump has been misused or is being misused, Kerr Pump Corporation reserves the option to offer to redeem the pump from the purchaser. Should the purchaser refuse to allow the pump to be redeemed and chooses to continue improper operation, the warranty will be void. I. Any parts or equipment which Kerr Pump Corporation supplies and does not manufacture shall be subject only to the warranties of Kerr Pump Corporation vendors to the extent Kerr Pump Corporation can enforce such warranties. J. Any repairs to, alterations of, or work done on alleged defective products without Kerr Pump Corporation specific written authorization shall void Kerr Pump Corporation warranty applicable thereto. K. Any action for breach of warranty or other action under this agreement must be commenced within (1) year after such cause of action arises. This limited warranty is in lieu of all other warranties, expressed or implied, including any implied warranty or merchantability or fitness. TROUBLESHOOTING GUIDE Problem Unusual pounding, knocking broken valve spring Loss of pressure or volume Consistent, rhythmic knock Packing failure (Excessive) Abnormal wear of fluid end parts Abnormal wear of power end parts Heat in power end Reason/Solution •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Insufficient fluid at high speed. Suction line is improper size or is constricted. (Trash in line, valve partly opened, etc.) Possibility of gas in the fluid causing the roughness. Foreign matter may be holding valves open. Worn valves. Broken springs. Improper bearing adjustment. Worn bearings or connecting rods. NOTE: Valve noise is common and normal in high‐speed pumps. It should not cause concern unless it becomes erratic. Improper installation. Improper type of lubrication. Incorrect type of packing for particular installation. (Contact Kerr Pump Corporation if you are unsure.) Abrasive or corrosive fluid. Lack of oil, overload on pump, foreign matter in oil. A new pump will run hot for a short period (2 or 3 days). See above for persistent heating. Pump will operate near 140˚ F. under average conditions. Check for air in pump by bleeding at cover caps. Too much spring tension Reciprocating pumps have very limited pick up. INSTALLATION INSTRUCTIONS WARNING Read everything in this section before attempting to run or connect your pump. The importance of proper installation cannot be overstressed. As the reciprocating pump is almost unable to lift fluid, proper suction flooding is a must. This is the First step toward satisfactory operation. The Kerr Pumps Engineering Service will be happy to advise you in your installation problems. As almost every installation varies, you cannot exercise too much care in making certain your installation is proper. Before Starting The Pump, read carefully the maintenance section in the following pages. For best results, follow these installation guidelines. (A) PRESSURE RELIEF VALVE (REQUIRED) (B) BY‐PASSED FLUID SHOULD BE PIPED BACK IN SUCTION SUPPLY TANK WHEN POSSIBLE (C) (D) (E) (F) USE FLEXIBLE HOSE IN DISCHARGE LINE WHEN POSSIBLE DISCHARGE SHUT‐OFF VALVE (OPTIONAL‐USED FOR TOTAL SHUT‐DOWN OR SERVICE ONLY) DISCHARGE AND SUCTION ON EITHER SIDE OF FLUID END ON ALL MODELS. PULSATION “DAMPENERS” MAY BE USED IN EITHER THE SUCTION OR DISCHARGE PIPING OR BOTH. DISCHARGE DAMPENERS SHOULD BE CAPABLE OF HANDLING PUMP DISCHARGE MAXIMUM PRESSURE To start the pump, open the suction line valve and permit the intake chamber to fill on the pump. Air may be bled off by opening the valve covers slightly until there is a constant fluid flow. After bleeding, open the discharge line valve and start the pump. Roughness may occur from cavitation (air in line) or from starvation (lack of fluid). Eliminate these troubles before permitting continuous operation. 1)
2)
3)
4)
CENTERLINE OF PUMP SUCTION (INLET) TO BE SLIGHTLY
HIGHER THAN CENTERLINE OF SUCTION (INLET) VALVE - SO
ANY AIR IN SUCTION SYSTEM PROMPTLY REACHES PUMP
AND IS EXPELLED
SLOPE BYPASS LINE SO LOW POINT DRAIN WILL FULLY
EMPTYRELIEF AND CHOKE VALVES AND ALL LIQUID IN
BYPASS CIRCUIT
DO NOT LOCATE PIPING OR OTHER EQUIPMENT IN FRONT
OF OR ABOVE PUMP FLIUD END PREVENTING SERVICING –
REFER TO MANUFACTURER FOR MINIMUM CLEARANCES
LOCATE CHARGING PUMP AT POINT SHOWN. – IF
CHARGING PUMP IS NECESSARY (FOR VOLATILE FLUIDS,
FOR EXAMPLE)
5)
6)
7)
8)
IF DESIRED, A TWO-WAY MOTOR OPERATED BYPASS VALVE MAY
BE USED RATHER THAN MANUAL TYPE – IT SHOULD BE DESIGN TO
OPEN AUOMATICALLY WHILE STARTING OR STOPPING
BYPASS LINE SHOULD FEED LIQUID INTO TANK BELOW MINIMUM
LIQUID LEVEL
TO REMOVE PIPING STRAIN AND VIBRATION A FLEXIBLE HOSE,
EXPANSION JOINT OR SWIVLE JOINT PAIR SHOULD BE
POSITIONED TO MINIMIZE EFFECTS OF PIPING THERMAL
EXPANSION, CONTRACTION AND PIPING WEIGHT
SUCTION SIZED FOR 1 ½ TO 2 FT/SEC MAX FLOW RATE.
DISCHARGED SIZED FOR 8 TO 10 FT/SEC MAX FLOW RATE –
SUCTION AND DISCHARGE MUST BE SUPPORTED AND
ANCHORED
9)
TO PROTECT SUCTION SYSTEM AGAINST
HAZARD OF DISCHARGE PRESSURE ENTRY
(AS WHEN PUMP IS IDLE), A SMALL RELIEF
VALVE IS OFTEN CONNECTED HERE
10) ALL SYSTEM COMPONENTS MUST HAVE
ADEQUATE PRESSURE RATINGS FOR
OPERATING, STARTING AND UPSET
CONDITIONS. IN ORDER TO REDUCE
POTENTIAL HAZARDS, PARTICULAR
ATTENTION IS RECOMMENDED FOR THE
SURGE CONDITION THAT WILL RESULT
DOWNSTREAM OF THE REFLIEF VALVE
WHEN NORMAL DISCHARGE IS BLOCKED
-AS A GENERAL RULE, FLUID LEVEL MUST BE HIGHER THAN THE PUMP FLUID END AS PLUNGERS CANNOT LIFT FLUID. 10 FEET OF HEAD IS A GOOD RULE OF THUMB.
-CAUTION SHOULD BE TAKEN TO KEEP FITTINGS OUT OF THE SUCTION AND DISCHARGE PIPING AS THESE WILL RESULT IN POOR PERFORMANCE. EACH 90-DEGREE TURN IN
THESE LINES RESULTS IN GREAT LOSS OF PUMPING EFFICIENCY.
PREVENTIVE MAINTENANCE DAILY A. Check and Maintain Lubricant Levels. Standard Lubricant: Synthetic Lubricant: AGMA Grade (ASTM D 2422): 4 EP SAE Viscosity Grade (J306‐8): 75W‐90 ISO Viscosity Grade: 150 Viscosity in SSU @ 100 degree F: 625‐765 MONTHLY A.
B.
C.
D.
E.
F.
G.
Drain and refill crankcase. It is recommended that oil be changed after the first week of operation. Wash oil filler cap in kerosene. Check valves for excessive wear, broken or bent springs, etc. Check crankshaft bearings for endplay. (See section on crankshaft) Keep all nuts, studs, etc. tight. Check valve covers for leaks. Check all seals and gaskets for leaks PUMP CAPACITIES (APPROXIMATE) KD‐1250 2 qts. KT‐3350 KJ‐2250 KZ‐3150 3 qts. KT‐3400 16 qts. 2 qts. Use SAE 30 weight non‐detergent motor oil ONLY KM‐3250 4 qts. KB‐3500 20 qts. KM‐3300 4 qts. KA‐3500 36 qts. KP‐3300 R335/R340 12 qts. 16 qts. KSB‐6400 KSB‐6500 36 qts. 36 qts. Q5450 22.5 gal. KCP‐6300 24 qts. 16 qts. PLANETARY GEAR REDUCERS #6 17 ozs. #8 42 ozs. #9 42 ozs. B. If pump has lubricating facilities for stuffing boxes, check level of lubricant. C. Maintain packing gland tension on packing (Do not over‐tighten) D. Visually inspect pump for apparent trouble. E. Keep the pump clean. GENERAL Replace any work part before its eventual failure. Use the following instructions for removal and replacement of parts. Don’t hesitate to call on Kerr Pumps for help if necessary. SERVICE PROCEDURES (ALL MODELS) A. WING GUIDED VALVES i.
DISCHARGE VALVES: The discharge valve and seat can be exposed by first removing the discharge valve cover cap. Once the discharge cover cap has been removed you may lift out the discharge valve spring and the discharge valve. The valve seat will be held in place by a taper fit and must be “pulled” with an appropriate valve‐pulling tool (available from the Kerr Pumps Dealers). Once the valve and seat have been removed they should be resurfaced or replaced if badly worn. To replace the discharge valve, first clean and inspect the seat bore for washout defects and then drop the seat into the bore. Replace the valve into the seat and strike the top of the valve a couple of good blows utilizing a brass bar and hammer to seat the valve seat in the fluid end valve bore. Replace the valve spring and cover cap after inspecting the spring and the seal of the cover cap. ii.
SUCTION VALVES: The suction valves are located in the chamber directly below the suction or end valve cover caps. The suction valves are serviced in the identical manner as the discharge valves. Note: Discharge valves must be removed prior to any removal of the suction valves. Service Procedure for KZ‐3150 Valves iii.
DISCHARGE VALVES: The discharge valve and seat can be exposed by first removing the discharge valve cover plate. Once the discharge cover cap has been removed you may lift out the discharge valve spring, discharge valve and valve seat. Once the valve and seat have been removed they should be replaced if badly worn. To replace discharge valve, first clean and inspect the seat bore for wash out defects and then drop the seat into the bore. Replace valve in seat then valve spring and cover cap, always‐inspecting o’ring seals between seats and cover caps. iv.
SUCTION VALVES: The suction valves are located in the chamber directly below the discharge valve seat. The suction valves are serviced in the identical manner as the discharge valves. B. DISC TYPE VALVES: All disc‐type valves are exposed for removal in a similar manner as the wing‐guided valves. Instead of removing the valve body; the upper portion of the valve is removed by removal of the valve capscrew, spring retainer, valve spring, and valve spacer sleeve. The valve seat is then “pulled” from the fluid‐end utilizing an authorized Kerr Valve Puller. Note: In all Kerr Pumps with disc‐type valves the discharge and suction valves are identical. C. BALL AND SEAT VALVES: In pumps with block/billet type fluid‐ends the valves are ball and seat design. These are exposed for removal/inspection by removal of the appropriate valve cover. The flat seats are kept in place by a screw‐in valve retainer that can be best removed with a Kerr Valve Wrench made for the appropriate pump. Springs are normally incorporated with the discharge valves while the suction valves operate with a “free ball”. A copper washer/gasket is used under all valve seats for a seal. When installing or removing a flat type valve seat a good “rap” on top of the valve wrench will “seat/unseat” the seat and copper gasket prior final tightening or removal. Failure to “seat” the valve seat in this manner can result in the “washing out” of the fluid‐end. For pressurized suction, valves will need to be spring loaded. Call Kerr Pumps for this change. D. PLUNGERS: Following the removal of the suction valve, the plunger may be removed by breaking the union between the plunger and pony rod and forcing the plunger out the back of the fluid‐end. Loosening the packing nut/gland will facilitate the removal of the plunger. The reverse of this procedure is used to install a plunger. Lubrication and some slight force may be used to pass plunger through the packing. Always retighten the plunger and pony rod union periodically following the removal of the plunger to insure it is securely made up and will not vibrate loose. E. PLUNGER PACKING: This manual includes illustrations of the packing sets for each model pump. Generally, once the plunger has been removed from the pump, the packing can be exposed for removal by completely removing whatever device is used to tighten the packing (i.e. the packing or stuffing box nut or gland). There will be various amounts of metal rings and packing components depending upon the type of packing and the model of pump (refer to appropriate illustration or chart). After the removal of all rings and equipment from the stuffing box; thoroughly clean it and inspect for damage, which might keep the new packing from working properly. If the stuffing box is in satisfactory condition, install the new packing as per the appropriate illustration. It is a good idea to lubricate new packing with a light oil prior to installation. Most of the standard packing used in pumps should be tightened with the original equipment‐packing wrench while the pump is running under normal operating pressure. After a two or three hour run‐in, check the packing for tightness and re‐adjust as necessary. Packing should be checked for tightness on a periodic basis, but it is not a good idea to attempt to periodically tighten the packing as part of routine maintenance. This tends to “wear out” the packing prematurely. When the packing leaks in an excessive amount it should be replaced. There is no value in constantly “re‐tightening” leaking packing. If your pump is equipped with optional “spring loaded” packing, there is no adjustment in this equipment during its operational life. The stuffing box nut is initially tightened as much as possible and there is no further adjustment. Note: In all cases the spring goes in the stuffing box before the packing rings. When using the optional Kevlar or Teflon packing, be sure to rotate the “splits” so that none are “aligned” to insure that the packing holds properly. Normally, this packing is not lubricated and requires less tension on the stuffing box nut during operation. CAUTION: An “airtight” seal is not desirable with this plunger packing. Some slight dripage is desirable during operation. Attempts to tighten packing until it completely “seals off” will result in premature failure from too much friction. The Kevlar & Teflon packing must be allowed to drip a small amount to assure normal life. F. PONY ROD and PONY ROD PACKING: Kerr Pumps use two pony rod sealing arrangements, models KD‐1250, KJ‐2250, KM‐3250 and KCP‐6300 use a screw in seal gland, all other models use a bolt in seal gland, these glands use press in oil seals with snap ring retainers. Some Bolt in gland use adjustable packing arrangements with bolt in or screw in followers to adjust packing. By unscrewing plunger from pony rod a gap may be facilitated to allow the removal of the various sealing arrangements. A special wrench will be needed to remove and replace pony rod to crosshead. (This wrench is available from Kerr Dealers) All pony rods have a jam nut to align tighten pony rod to crosshead, care must be exercised in installing new seal on pony rod not to damage it. G. DISASSEMBLY OF POWER END CAUTION: Prior to disassembly of any power end, the plunger, pony rod, and pony rod seal housing must be removed. Expose the crankshaft and connecting rods by removing the pan cover. Connecting rod caps may now be removed and the connecting rod and crosshead should be shoved all the way to the rear (toward the fluid end) to facilitate crankshaft removal out either side as convenient. The connecting rods and crossheads may now be taken out the front cavity exposed by removing the crankshaft. Connecting rods may be removed from the crosshead by loosening the setscrew and driving out the wrist pin from the crosshead. A bronze bushing is used in the rod it may be driven out of the rod and replaced with a new bushing. Reassembly is the reverse of the above outlined sequence with the following considerations for “fits” or tolerance: i.
General: All Kerr components are machined on modern production machine tools and are of the same specifications and close tolerances you would expect in a modern automobile engine. It must be pointed out that at top speed (350 to 400 RPM) your pump will not even be approaching idle speed for a gasoline engine so “field fits” are possible and practical when making repairs and replacements away from the factory. All procedures outlined below are possible with only hand tools and absolutely no instruments, special tools, or gauges are needed. ii.
Connecting rod and wrist pin: Proper fit will find the wrist pin turning freely in its bore in the connecting rod, but it should have no “wobble” that is discernable up and down the main axis of the connecting rod. This looseness in the wrist pin fit is the most probable cause of “knocking” which is traceable to the power end of most all pumps. The only solution for loose fitting wrist pins is to discard the connecting rod wrist pin bushing and replace with a new one. If any wear is visible on the wrist pin it should always be replaced. iii.
Crankshaft End Play and Lateral adjustments: Adjustment of the Taper Roller bearings used in all Kerr Pumps is accomplished by removing or adding shims under the bearing housing. Shims are taken out or added until the crankshaft (without connecting rods) will turn freely, but with no endplay felt when attempting to pull or push the jackshaft end of the crankshaft along its long axis. Some lateral adjustment is possible by removing shims from one side of the crankshaft and adding them to the opposite side. (Note: Lateral adjustment is the “centering” of the crankshaft in the power frame housing.) iv.
Connecting Rod to Crankshaft fitting: Factory bored connecting rods will normally fit the standard crankshaft journal just by bolting the cap on the rod with the standard rod shims being used. If the caps do require adjustment this is accomplished by removing or adding various thicknesses of rod shims. The standard connecting rod shim used on all Kerr Pumps is 1/32” thick and is comprised of .002” laminates, which can be “pealed “ off separately. Proper fit of the connecting rod will allow the pump crankshaft to be rotated while not allowing in‐and‐out slack in the connecting rod along its long or main axis. A well‐fitted rod will have none of the in‐and‐out slack, but should be free enough to be moved from side to side on the rod journal. This insures the rod not being too tight. A point of caution when installing the connecting rod assembly in the pump is to make certain the oil holes in the rod are “UP” and not toward the bottom of the pump. This will result in lubrication failure in these parts and the pump will fail in a short period of time. An additionally important step is to make sure that the rod cap is bolted back on the rod as it came off. The rod and cap carry a “mark” or “number” which allows you to match them back properly. Failure to do this will cause the rod not to fit the journal for which it was made. H. Power End/Fluid End Connection: A common misconception is that there is some form of fluid seal between the power end and the fluid end. This is false. The fluid end is merely bolted to the power frame. It can be removed by breaking the plunger connection, backing off the packing nut or gland, removing the various fluid end bolts, and sliding the entire fluid end off the power frame. Corrosion may tend to seize the two components together making their separation difficult in some isolated cases. On models KP‐3300, KT‐3350/KT‐3400 and R335/R340 the bolted in stuffing box assemblies must be removed prior to removal of the entire fluid end. They are held in place by four studs each. On all other units the stuffing boxes can be left intact. On the remaining pumps (with the exception KD‐1250B, KJ‐2250B, KM‐3250B, and KCP‐
6300) the stuffing boxes are held in place in the fluid end by a friction or “press” fit. They should be removed with a hydraulic press if possible. These press‐in type stuffing boxes carry a gasket and/or an o‐ring to insure a good seal. The boxes on the KD‐1250B, KJ‐2250B, KM‐
3250B, and KCP‐6300 are screw‐in type and carry only a copper gasket. TECHNICAL DATA SHEET PCN: ______ T.D.S. NO. Supercedes PCN: _____ Date 4.2 03‐10‐06 SHORT TERM STORAGE PREPARATION PROCEDURE 1.0 SCOPE This procedure applies to Kerr Pumps ONLY. Storage procedures for any other unit components or accessories (gear reducers, engines, etc.) are to be prepared to the specific manufacture’s recommendations. 1.1 Short‐term storage is defined as storage and/or transient time less than six (6) months in an environment defined in Paragraph 2. If storage exceeding six months is expected, the Long Term Pump Storage Preparation Procedure should be followed. 1.2 Kerr Pumps will only prepared for short term storage if so specified in the purchaser or customer order control document. 2.0 STORAGE ENVIRONMENT A minimal environmental condition, to be met by the customer or purchaser, is a closed shelter to eliminate effects of sun, wind, sand or other debris. Large temperature and humidity changes should be avoided to prevent coating deterioration or contamination by moisture. 3.0 PRESERVATIVE PRODUCT 3.1 The specified rust preservative will protect the internal power end parts from corrosion due to atmospheric moisture, and may be left in the pump when filled with appropriate lubricant and placed into service. The elevated temperature of service will cause rapid depletion of the preventative protection. The following rust preventative products or their equivalents are recommended for use in Kerr Pumps and usually available in 5 gallon, 55 gallon containers: 3.2 CITGO: RUST‐O‐LINE OIL 10 SHELL: ENSIS OIL N 4.0 PROCEDURE 4.1 Preparation from; factory testing, inventory, or a distributor rebuild facility. ‐ Drain any oil that may be in the power end, and then fill the complete power end cavity with the specified rust preventative. After 15 to 20 minutes, drain the rust preventative back into its storage drum for future use. ‐ Remove and clean oil level gages, pressure gages and breather caps. Replace with pipe plugs in threaded openings. All breathers shall be replaced with airtight seals, plugs or gasketed plates. No venting is recommended as it may allow moist air in. TECHNICAL DATA SHEET PCN: ______ T.D.S. NO. Supercedes PCN: _____ Date 4.2 03‐10‐06 4.1.1
Remove the wiper box seals and cap/plug the seal opening. 4.1.2
Clean the pump outer surfaces prior to painting. 4.1.3
If painting is required mask crank and lubricator shaft surfaces and keyways. If painting does not apply, go to Para. 4.1.8. 4.1.4
Paint as specified by the customer order or as required. 4.1.5
Apply a thin layer of grease to the exposed oil seal lips. 4.1.6
Apply a thin layer of heavy rust preventative to the exposed crank and lubricator shaft surfaces and keyways. 4.1.7
Wrap the exposed crank and lubricator shafts with waxed tape. 4.1.8
Carefully wrap the following parts prior to placing them into polyurethane bags. Oil level gages, lube pressure gages, and breather caps. 4.1.9
Finish box, crate and mark the parts from Para. 4.1.2 after final inspection (see Para. 4.2.2). 4.2 Shipping/Receiving (New Pumps Only) 4.2.1 All pumps and accessories (as applicable) will be final inspected by Kerr Pump personnel prior to shipping. Any witnessed or third party inspection will be signed‐off by the purchaser or customer representative prior to final crating and shipment. 4.2.2 Export crating will be performed by either an approved Kerr Pump source or as specified by the purchaser or customer. Any third party inspection will be coordinated with the source. 4.2.3 Upon receipt of the shipment, the purchaser or customer is responsible for inspection and repair of damaged coatings at the expense of the shipper. 5.0 WARRANTY/START‐UP 5.1 5.2 5.3 Pumps prepared per the above procedure qualify for the “Standard Terms & Conditions” in force on the date of shipment. If the pump storage period is less than 6 months, follow the Short Term Pump Preparation Procedure. Prior to start‐up: 5.3.1
5.3.2
5.3.3
5.3.4
5.3.5
5.3.6
5.3.7
Remove all storage caps, plugs, and covers. Replace any damaged or cracked O‐rings or gaskets. Inspect power end shaft oil seals and replace if cracked, split or damaged. Install crankcase drain plug, lubrication level site glass and breather cap. Install, if applicable, any oil pressure and/or temperature gage. Check the connection of the plunger and pony rod to the crosshead prior to, and after, initial run‐in of the pump. Fill the crankcase to the proper level with the specified lubricant. TECHNICAL DATA SHEET PCN: ______ T.D.S. NO. Supercedes PCN: _____ Date 4.3 03‐10‐06 TITLE: LONG TERM STORAGE PREPARATION PROCEDURE 1.0 SCOPE This procedure applies to Kerr Pumps ONLY. Storage procedures for any other unit components or accessories (gear reducers, engines, etc.) are to be prepared to the specific manufacture’s recommendations. 1.1 Long‐term storage is defined as storage and/or transient time exceeding six (6) months in an environment defined in Paragraph 2. If storage for less than six months is expected, the Short Term Pump Storage Preparation Procedure should be followed. 1.2 Kerr Pumps will only prepare for short term storage if so specified in the purchaser or customer order control document. 2.0 STORAGE ENVIRONMENT A minimal environmental condition, to be met by the customer or purchaser, is a closed shelter to eliminate effects of sun, wind, sand or other debris. Large temperature and humidity changes should be avoided to prevent preventative deterioration or contamination by moisture. 3.0 RUST PREVENTATIVE PRODUCT 3.1 The recommended rust preservative should protect the internal power end parts from corrosion due to atmospheric moisture, and may be left in the pump when filled with appropriate lubricant and placed into service. The elevated temperature of service will cause rapid depletion of the preventative protection. 3.2 The following rust preventative products or their equivalents are recommended for use in Kerr Pumps and usually available in 5 gallon, 55 gallon containers: CITGO: RUST‐O‐LINE OIL 10 SHELL: ENSIS OIL N 4.0 PROCEDURE 4.1 Preparation from; factory testing, inventory, or a distributor rebuild facility. 4.1.1 Drain any oil that may be in the power end and then fill the complete power end cavity with the specified rust preventative. After 15 to 20 minutes, drain the rust preventative back into its storage drum for future use. 4.1.2 Remove all plungers, pony rods (if applicable), baffle discs, packing and junk rings. 4.1.3 Remove and clean oil level gages, pressure gages and breather caps. Replace with pipe plugs in threaded openings. TECHNICAL DATA SHEET PCN: ______ 4.1.4 4.1.5 4.1.6 4.1.7 4.1.8 4.1.9 4.1.10 4.1.11 4.1.12 4.1.13 4.2 4.2.2 4.2.3 Supercedes PCN: _____ T.D.S. NO. Date 4.3 03‐10‐06 All breathers shall be replaced with airtight seals, plugs or gasketed plates. No venting is recommended as it may allow moist air in. Remove the wiper box seals and cap/plug the seal opening. Clean the pump outer surfaces prior to painting. If painting is required mask crank and lubricator shaft surfaces and keyways. If painting does not apply, go to Para. 4.1.9. Paint as specified by the customer order or as required. Apply a thin layer of grease to the exposed oil seal lips. Apply a thin layer of heavy rust preventative to the exposed crank and lubricator shaft surfaces and keyways. Wrap the exposed crank and lubricator shafts with waxed tape. Carefully wrap the following parts prior to placing them into polyurethane bags. Oil level gages, lube pressure gages, and breather caps. Finish box, crate and mark the parts from Para. 4.1.10 after final inspection (see Para. 4.2.2). Shipping/Receiving (New Pumps Only) 4.2.1 5.0 All pumps and accessories (as applicable) will be final inspected by Kerr Pump personnel prior to shipping. Any witnessed or third party inspection will be signed‐off by the purchaser or customer representative prior to final crating and shipment. Export crating will be performed by either an approved Kerr Pump source or as specified by the purchaser or customer. Any third party inspection will be coordinated with the source. Upon receipt of the shipment, the purchaser or customer is responsible for inspection and repair of damaged coatings at the expense of the shipper. WARRANTY / START‐UP 5.1 Pumps prepared per the above procedure qualify for the “Standard Terms & Conditions” in force on the date of shipment. 5.2 If the pump storage period will exceed 6 months, follow the Long‐Term Pump Preparation Procedure. 5.3 Prior to start‐up: 5.3.1
Remove all storage caps, plugs, and covers. 5.3.2
Install the packing, junk rings, plungers, pony rods (if applicable), baffle discs, and wiper box seals. Replace any damaged or cracked O‐rings or gaskets. 5.3.3
Inspect power end shaft oil seals and replace if cracked, split or damaged. 5.3.4
Install crankcase drain plug, lubrication level site glass and breather cap. 5.3.5
Install, if applicable, any oil pressure and/or temperature gage. 5.3.6
Check the connection of the plunger and pony rod to the crosshead prior to, and after, initial run‐in of the pump. 5.3.7
Fill the crankcase to the proper level with the specified lubricant. KM-76M KM-77
KM-277
KM-75
KM-91
WINGDISC
KM-276 AP-71T AP-425 BOLTED TYPE PONY
KM-306
GUIDED SEAT SCREWED TYPE VALVE SEAT PONY ROD VALVE STUFFING
ROD
SEAT THREADED STUFFING BOXSEATING TOOL SEAL TOOL INSERT BOX NUT STUFFING BOX WRENCH
WRENCH
TOOL WRENCH
TRI-PIN
WRENCH
STEM
TYPE
TYPE
SPECIAL TOOLS
PULLER PULLER
FOR KD-1250, KD-2250, KM-3250, KM-3300
ASS'Y
ASS'Y
How To Put Inserts In Valves
Using Kerr Valve Insert Tool
1) Push Valve Insert over
valve legs. Hint: (Insert
will be more pliable if
heated first-- warm to the
touch not hot).
4) While holding valve down
with thumb, rotate around
valve with tool. (Similar to
mounting a tire on a rim).
2) Put Tool between
valve and valve
insert with groove
against valve.
3) Holding Valve
insert down with
thumb.
5) Continue rotating around
valve with tool until insert is
completely in groove.
INSTRUCTIONS FOR CHANGING WING/GUIDED VALVES (cont.)
7. Remove Suction Valves, springs,
and seats through End Port
10. Install Discharge Valves after Suction
Valves have been installed, always be
sure short springs are on Suction Valve
and Long Spring on Discharge Valves
8. To Install Suction Valve & Seat,
insert Valve Seat and Valve Body
through End Port
9. Use metal rod to drive valve seat
assembly into seating area using
several firm but, not heavy blows
with a hammer
11. Install Cover Caps and torque Cover
Plate capscrews to Kerr Pump Specs
INSTRUCTIONS FOR CHANGING DISC VALVES (Revision B)
1. Remove Capscrews from Top and
End Cover Plates
4. Screw Kerr Pump Valve Puller into
seat approximately ¾”
2. Remove Round Cover Caps; inspect
o’rings for damage;
3. Unscrew Valve Capscrew; Remove
Capscrew, Spring Retainer, Spring,
Spacer, and Disc
5. Hold Puller Stem from turning;
Rotate large nut until seat releases
6. Remove Valve Seat from Puller;
Remove remaining valves
INSTRUCTIONS FOR CHANGING DISC VALVES (Revision B) (cont.)
7. Remove Suction Valve Seat
Through End Port
8. To Install Valve Assembly; Insert
through End Port
9. Use a 1” wooden dowel rod to drive
valve seat assembly into seating area
using several firm but, not heavy
blows with a hammer; CAUTION:
heavy blows will damage valve
10. Torque valve capscrew to Kerr Pump
specs
11. Install Discharge Valve, following
procedure 9.
12. Install Cover Caps and torque Cover
Plate capscrews to Kerr Pump Specs
INSTRUCTIONS FOR CHANGING WING/GUIDED VALVES
1. Remove Capscrews from Top and
End Cover Plates
4. Insert Kerr Valve Seat Puller through
valve seat with eccentric offset to
engage valve seat. NOTE: Puller stud
may be removed when pulling
wing/guided valve seats.
2. Remove Round Cover Caps; inspect
o’rings for damage;
3. Remove Discharge Spring and
Discharge Valve
5. Hold Puller Stem from turning;
Rotate large nut until seat releases
6. Remove Valve Seat from Puller;
Spacer on Puller may need to be
removed when pulling Suction Valve
Seats; Remove remaining valves
INSTRUCTIONS FOR CHANGING WING/GUIDED VALVES (cont.)
7. Remove Suction Valves, springs,
and seats through End Port
10. Install Discharge Valves after Suction
Valves have been installed, always be
sure short springs are on Suction Valve
and Long Spring on Discharge Valves
8. To Install Suction Valve & Seat,
insert Valve Seat and Valve Body
through End Port
9. Use metal rod to drive valve seat
assembly into seating area using
several firm but, not heavy blows
with a hammer
11. Install Cover Caps and torque Cover
Plate capscrews to Kerr Pump Specs
A
6
5
3
1
A
PART
NUMBER
KM-54
KM-53
KM-52
KM-505
KM-50-1
KM-49-1
ITEM
NO.
1
2
3
4
5
6
PART
NUMBER
KM-47
KM-53
KM-52
KM-505
KM-50-1
KM-49-1
ITEM
NO.
1
2
3
4
5
6
PART
NUMBER
KM-47SS
KM-53
KM-52
KM-505
KM-50-1
KM-49-1
ITEM
NO.
1
2
3
4
5
6
KM-45DX DELRIN DISC DUPLEX STAINLESS STEEL SEAT
PART
DESCRIPTION
NUMBER
KM-47DX
VALVE SEAT, DISC TYPE, DUPLEX SS
KM-53
DELRIN DISC
KM-52
SPACER SLEEVE
KM-505
VALVE SPRING
KM-50-1
SPRING RETAINER, KM DISC VALVE
KM-49-1
CAPSCREW, SS 3/8"-16 UNC X 2" LG
DESCRIPTION
QTY.
VALVE SEAT, DISC TYPE, AB
DELRIN DISC
SPACER SLEEVE
VALVE SPRING
SPRING RETAINER, KM DISC VALVE
CAPSCREW, SS 3/8"-16 UNC X 2" LG
1
1
1
1
1
1
KM-45 DELRIN DISC MONEL SEAT
DESCRIPTION
QTY.
VALVE SEAT, DISC TYPE, MONEL
DELRIN DISC
SPACER SLEEVE
VALVE SPRING
SPRING RETAINER, KM DISC VALVE
CAPSCREW, SS 3/8"-16 UNC X 2" LG
1
1
1
1
1
1
KM-45SS DELRIN DISC STAINLESS STEEL SEAT
4
2
KM-48 DELRIN DISC ALUMINUM BRONZE SEAT
ITEM
NO.
1
2
3
4
5
6
SECTION A:A
DISC TYPE VALVE ASSEMBLIES
WITH NEW STYLE VALVE RETAINERS
DESCRIPTION
VALVE SEAT, DISC TYPE, SS
DELRIN DISC
SPACER SLEEVE
VALVE SPRING
SPRING RETAINER, KM DISC VALVE
CAPSCREW, SS 3/8"-16 UNC X 2" LG
QTY.
1
1
1
1
1
1
QTY.
1
1
1
1
1
1
KM-3250 PLUNGER TYPE PUMP TORQUE SPECIFICATIONS
9
7
2
1
3
4
5
WHEN ADJUSTING THE ENDPLAY
OF THE TAPERED ROLLER BEARINGS
USED ON THE CRANKSHAFT,
DIAL INDICATORS AND SHIMS MUST
BE PROPERLY USED. INCORRECT
BEARING ADJUSTMENT MAY RESULT
IN EXCESSIVE NOISE, TEMPERATURE, AND
REDUCED BEARING LIFE. Kerr Pumps
RECOMMENDS BETWEEN .000” - .005”
OF INTERNAL AXIAL CLEARANCE
(END PLAY OR SIDE TO SIDE) WHEN
ASSEMBLED. FINAL ADJUSTMENT
MUST BE MADE USING A DIAL INDICATOR.
INSURE THE CONNECTING RODS ARE
DISCONNECTED TO ALLOW FREE
CRANKSHAFT MOTION.
.000"-.005" SHAFT END PLAY
.003"-.004" CONNECTING ROD AT CRANKSHAFT
.001" .002" CONNECTING ROD AT WRIST PIN
8
6
*TORQUE SPECIFICATIONS
REFERENCE
1
2
3
4
5
6
7
8
9
DESCRIPTION
PAN COVER CAPSCREW
CONNECTING ROD CAPSCREW
BEARING HOUSING CAPSCREW
W RIST PIN SET SCREW AND JAM NUT
PONY ROD
PONY ROD PACKING GLAND
FLUID END CAP SCREW
PLUNGER TO PONY ROD
CROSSHEAD COVER PLATE CAPSCREW
TORQUE
9 ft-lb (12 Nm)
65 ft-lb (88 Nm)
50 ft-lb (68 Nm)
12 ft-lb (16 Nm)
500 ft-lb (678 Nm)
50 ft-lb (68 Nm)
90 ft-lb (122 Nm)
300 ft-lb (407 Nm)
10 ft-lb (14 Nm)
NOTE: WHEN USING LUBRICANTS,
REDUCE TORQUE AS FOLLOWS;
LUBRICANT
PERCENTAGE OF TORQUE
REDUCTION REQUIRED
OIL & GREASE
ANTI - SEIZE COMPOUND
REDUCE TORQUE 40%
REDUCE TORQUE 45%
6
1
4
7
8
3
2
5
REPEAT TORQUE
SEQUENCE THREE TIMES EACH
TOP AND FRONT PLATES
FLUID END COVERPLATE CAPSCREWS TORQUE TO:
110 FT/LBS (149 NM) WITH ANTI-SEIZE COMPOUND
KM-3250BC/KM-3300BC FLUID END
TORQUE SEQUENCE
KM-35
KM-37
KM-68-XXX
AP-74
KM-89
KM-88
KM-34AB
AP-16
KM-13
KM-15
KM-17
KM-69
KM-18
KM-26
KM-22
KM-25-000
KM-12
KM-11
KM-10
KM-36
AP-72
KM-37
KM-88G
AP-71
KM-86
KM-85
KM-90
KM-58L
DISCHARGE
SPRING
KM-42
DISCHARGE
VALVE
KM-44
SEAT
KM-300M
DISCHARGE
VALVE ASSEMBLY
KM-58S
SUCTION
SPRING
KM-43
SUCTION
VALVE
KM-44
SEAT
KM-305M
SUCTION
VALVE ASSEMBLY
KM-38
KM-27
KM-29
KM-28S
KM-28
KM-33
KM-87-XXX
KM-24
KM-19
AP-71
KM-2
KM-1
B
KM-87
*SOLD AS A SET
*KM-88 PACKING
NUT
TOP PHENOLIC
SPACER
*KM-88
PACKING
KM-85G
B
KM-48
DISC TYPE VALVE ASSEMBLY
(ALBZ SEAT)
KM-45
DISC TYPE VALVE ASSEMBLY
(MONEL SEAT)
KM-45SS
DISC TYPE VALVE ASSEMBLY
(STAINLESS STEEL SEAT)
KM-37
KM-90
LANTERN
RING
*KM-88
BOTTOM
KM-89
PACKING PHENOLIC
SPACER
RING
KM-85
STUFFING BOX
KM-3250
KM-29
TWO SEALS TO
CRANKCASE OIL
KM-28
PONY ROD
GLAND
KM-28S
SNAP RING
KM-28-A
PONY ROD
PACKING GLAND
ASSEMBLY
KM-3250BC PLUNGER TYPE PUMP TORQUE SPECIFICATIONS
10
7
2
9
1
3
4
5
6
8
WHEN ADJUSTING THE ENDPLAY
TORQUE SPECIFICATIONS
OF THE TAPERED ROLLER BEARINGS
USED ON THE CRANKSHAFT,
REFERENCE
DESCRIPTION
DIAL INDICATORS AND SHIMS MUST
1
PAN COVER CAPSCREW
BE PROPERLY USED. INCORRECT
2
CONNECTING ROD CAPSCREW
BEARING ADJUSTMENT MAY RESULT
3
BEARING HOUSING CAPSCREW
IN EXCESSIVE NOISE, TEMPERATURE, AND
4
WRIST PIN SET SCREW AND JAM NUT
REDUCED BEARING LIFE. Kerr Pumps
5
PONY ROD
RECOMMENDS BETWEEN .000” - .005”
6
PONY ROD PACKING GLAND
OF INTERNAL AXIAL CLEARANCE
7
FLUID END CAP SCREW
(END PLAY OR SIDE TO SIDE) WHEN
8
PLUNGER TO PONY ROD
ASSEMBLED. FINAL ADJUSTMENT
9
FLUID
END COVER PLATE CAPSCREWS
MUST BE MADE USING A DIAL INDICATOR.
INSURE THE CONNECTING RODS ARE
DISCONNECTED TO ALLOW FREE
CRANKSHAFT MOTION.
.000"-.005" SHAFT END PLAY
.003"-.004" CONNECTING ROD AT CRANKSHAFT
.001" .002" CONNECTING ROD AT WRIST PIN
10
CROSSHEAD COVER PLATE CAPSCREW
TORQUE
9 ft-lb (12 Nm)
65 ft-lb (88 Nm)
50 ft-lb (68 Nm)
12 ft-lb (16 Nm)
500 ft-lb (678 Nm)
50 ft-lb (68 Nm)
175 ft-lb (237 Nm)
300 ft-lb (407 Nm)
175 ft-lb (237 Nm)
10 ft-lb (14 Nm)
NOTE: WHEN USING LUBRICANTS,
REDUCE TORQUE AS FOLLOWS;
LUBRICANT
PERCENTAGE OF TORQUE
REDUCTION REQUIRED
OIL & GREASE
ANTI - SEIZE COMPOUND
REDUCE TORQUE 40%
REDUCE TORQUE 45%
18.375
2.000 SHAFT
1/2" X 1/4" KEYWAY
3.26
1"-NPT
4.8125
9.625
17.2
7.00
4X 7/16
MOUNT
HOLES
15.437
22.812
13.69
2"-NPT
9.125
9.7
.813
3.625
3.500 5.250
4.595
7.8
13.9
1 1/4"-NPT
DISCHARGE
3.000
11.0
5.5
12.0
2"-NPT
SUCTION
GENERAL DIMENSIONS FOR KM-3250BC
KM-3250BC
KM-21
KM-31
KM-69
KMC-XXX
KM-35BC
KM-74
KM-38
AP-16T
KM-13
KM-15
KM-17
KM-18
KM-1
KM-26
KM-22
KM-25-000
KM-12
KM-10
KM-31
KM-21
KM-34BC
AP-71
KM-58L
SPRING
KM-96HT
DISCHARGE
VALVE
KM-101
INSERT
KM-98HT
SEAT
AP-72
KM-87
KM-32
B
KM-19
KM-24
KM-27
KM-28
KM-33
KM-87
*SOLD AS A SET
*KM-88 PACKING
NUT
TOP PHENOLIC
SPACER
*KM-88
PACKING
KM-85G
KM-300HT
DISCHARGE
VALVE ASSEMBLY
KM-58S
SPRING
KM-97HT
SUCTION
VALVE
KM-101
INSERT
KM-98HT
SEAT
KM-305HT
SUCTION
VALVE ASSEMBLY
KM-37
B
KM-48
DISC TYPE VALVE ASSEMBLY
(ALBZ SEAT)
KM-45
DISC TYPE VALVE ASSEMBLY
(MONEL SEAT)
KM-45SS
DISC TYPE VALVE ASSEMBLY
(STAINLESS STEEL SEAT)
KM-90
LANTERN
RING
*KM-88
BOTTOM
KM-89
PACKING PHENOLIC
SPACER
RING
KM-85
STUFFING BOX
KM-11
AP-71
KM-2
KM-29
TWO SEALS TO
CRANKCASE OIL
KM-28
PONY ROD
GLAND
KM-28S
SNAP RING
KM-28-A
PONY ROD
PACKING GLAND
ASSEMBLY
KM-3250BC
Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐1 KM‐1TM KM‐1TMF KM‐1TMR KM‐2 KM‐2S KM‐3 KM‐4 KM‐5 KM‐6 KM‐7 KM‐8‐005 KM‐8‐010 KM‐8‐015 KM‐9 KM‐10 KM‐11 KM‐12 KM‐13 KM‐13T KM‐14 KM‐15 AP‐16 AP‐16T KM‐16D AP‐16‐03‐V KM‐17 KM‐18 KM‐19 KM‐20 KM‐21 Pump Case Pump Case, Top Mount Spacer, Front Short Top Mount Spacer, Rear Long Top Mount Crankshaft ‐ Heat Treated Crankshaft ‐ Steel Crankshaft Oil Seal Bearing Housing (Blind Side) Bearing Housing (Shaft Side) Bearing Housing Capscrews Bearing Housing Gaskets Main Bearing Adjusting Shims .005 Main Bearing Adjusting Shims .010 Main Bearing Adjusting Shims .015 Main Bearings Pan Cover Pan Cover Capscrews Pan Cover Gasket Crosshead Cover Plate Crosshead Cover Plate Theaded Cover Plate Capscrews Crosshead Cover Plate Gasket Breather Cap (Oil Filler) Breather Cap (Oil Filler) Threaded Style Oil Level Dip Stick Oil Filler Cap Label Crosshead Wrist Pin Wrist Pin Bushing Wrist Pin Set Screws & Nut Coverplate Capscrew 1 1 2 2 1 1 1 1 1 12 2 As Req. As Req. As Req. 2 1 10 1 1 1 2 1 1 1 1 1 3 3 3 3 16 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐22 KM‐24 KM‐24A KM‐25‐000 KM‐25‐015 KM‐25‐030 KM‐25‐045 KM‐25‐060 KM‐26 KM‐27 KM‐27C KM‐28 KM‐28A KM‐28S KM‐29 KM‐30 KM‐31 KM‐32 KM‐32C KM‐33 KM‐33H KM‐34AB KM‐34S KM‐34SS KM‐34BCAB KM‐34BCD KM‐34BCS KM‐34BCSS KM‐34BCDX KM‐34BCFSOS KM‐34BCFSSOS Connecting Rod Capscrew Connecting Rod Only (No Inserts ‐ Requires inserts both ends) Connecting Rod (Inserted Both Ends) Connecting Rod Insert Bearing (Std) Connecting Rod Insert Bearing (.015) Connecting Rod Insert Bearing (.030) Connecting Rod Insert Bearing (.045) Connecting Rod Insert Bearing (.060) Connecting Rod Shims (Laminated) Pony Rod with Jam Nut Installed Pony Rod for 5/8, 3/4, 7/8, 1 Ceramic Plunger Pony Rod Gland for Double Seal Pony Rod Gland Assy (KM‐28, KM‐28S, 2ea of KM‐29) Pony Rod Gland Snap Ring Pony Rod Oil Seal (Req. 2 per Set) Pony Rod Wiper Ring (Fiber) Top and End Cover Cap Plate for BC Cover Caps Plunger Washer Use With 1 & 1 1/4 (3/4 Female Thread) Pony Rod Washer (Use With Pony Rod KM‐27C) Pony Rod Splash Guard Pony Rod Splash Guard HSN Fluid End (ALBZ) Vessel Only Fluid End (Steel) Vessel Only Fluid End (Stainless Steel) Vessel Only Fluid End (Bolted Cap) (ALBZ) Vessel Only Fluid End (Bolted Cap) (Ductile) Vessel Only Fluid End (Bolted Cap) (Steel) Vessel Only Fluid End (Bolted Cap) (Stainless Steel) Vessel Only Fluid End (Bolted Cap) (Duplex Stainless) Vessel Only Fluid End (Bolted Cap) (Forged Steel) Vessel W/Flanges Fluid End (Bolted Cap) (Forged Stainless Steel) Vessel W/Flanges 6 3 3 3 3 3 3 3 6 3 3 3 3 3 3 sets 3 2 3 3 3 3 1 1 1 1 1 1 1 1 1 1 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐35AB KM‐35D KM‐35S KM‐35SS KM‐35BCAB KM‐35BCD KM‐35BCS KM‐35BCSS KM‐36AB KM‐36D KM‐36S KM‐36SS KM‐36BCAB KM‐36BCD KM‐36BCS KM‐36BCSS CP‐37‐875AB CP‐37‐100AB CP‐37‐125AB CP‐37‐875S CP‐37‐100S CP‐37‐125S CP‐37‐875SS CP‐37‐100SS CP‐37‐125SS KM‐37A KM‐37N KM‐38 KM‐39 KM‐40 KM‐41 Top Cover Cap (ALBZ) Top Cover Cap (Ductile) Top Cover Cap (Steel) Top Cover Cap (Stainless Steel) Top Cover Cap (Bolted Cap) (ALBZ) Top Cover Cap (Bolted Cap) (Ductile) Top Cover Cap (Bolted Cap) (Steel) Top Cover Cap (Bolted Cap) (Stainless Steel) End Cover Cap (ALBZ) End Cover Cap (Ductile) End Cover Cap (Steel) End Cover Cap (Stainless Steel) End Cover Cap (Bolted Cap) (ALBZ) End Cover Cap (Bolted Cap) (Ductile) End Cover Cap (Bolted Cap) (Steel) End Cover Cap (Bolted Cap) (Stainless Steel) Packing Ring 7/8 (AB) Packing Ring 1 (AB) Packing Ring 1 1/4 (AB) Packing Ring 7/8 (Steel) Packing Ring 1 (Steel) Packing Ring 1 1/4 (Steel) Packing Ring 7/8 (Stainless Steel) Packing Ring 1 (Stainless Steel) Packing Ring 1 1/4 (Stainless Steel) O'Ring,Stuffing Box & Cover Cap O‐Ring Stuffing Box & Cover Cap Fluid End Capscrew Discharge Valve (ALBZ) Suction Valve (ALBZ) Valve Seats (ALBZ) 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 9 8 3 3 6 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐42 KM‐42AR KM‐43 KM‐43AR KM‐44 KM‐44AR KM‐45 KM‐45SS KM‐45SS‐SS KM‐45T‐M KM‐45T‐SS KM‐45T‐DX KM‐45SS‐DX KM‐45DX KM‐47 KM‐47SS KM‐47DX KM‐48 KM‐49 KM‐49‐1 KM‐50 KM‐50‐1SS KM‐50‐1DX KM‐51 KM‐52 KM‐53 KM‐53SS KM‐53T KM‐54 KM‐54SS KM‐54DX Discharge Valve (Monel) Discharge Valve Monel Inserted Abrasive/Resistant Wing Guided Suction Valve (Monel) Suction Valve Monel Inserted Abrasive/Resistant Wing Guided Valve Seats (Monel) Abrasive Resistant Valve Seat Wing‐Guided Monel Delrin Valve Complete with Monel Seat Delrin Valve Complete with Stainless Steel Seat Stainless Steel Disc Valve Complete with Stainless Steel Seat Titanium Disc Valve Complete with Monel Seat Titanium Disc Valve Complete with Stainless Steel Seat Titanium Disc Valve with Duplex Stainless Seat Stainless Steel Disc Valve with Duplex Stainless Steel Seat Delrin Valve Complete with Duplex Stanless Steel Seat Valve Seat Monel Disc Type Valve Seat Stainless Steel Disc Type Valve Seat, Disc Type, Duplex SS Delrin Valve Complete with ALBZ Seat Capscrew Disc Type Valve Capscrew, SS 3/8"‐16 UNC X 2" LG Spring Retainer Disc Type Spring Retainer, KM Disc Valve Stainless Steel Spring Retainer, KM Disc Valve Duplex Stainless Spring Disc Type Sleeve Spacer Disc Type Delrin Disc Stainless Steel Disc Titanium Disc Valve Seat ALBZ Disc Type Valve Seat 316 S.S. Disc Type Valve Seat Duplex Stainless Disc Type 3 3 3 3 6 6 6 6 6 6 6 6 6 6 1 per valv 1 per valv 6 6 1 per valv 6 1 per valv 6 6 1 per valv 1 per valv 1 per valv 1 per valv 1 per valv 1 per valv 6 6 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐55 KM‐55AR KM‐56 KM‐56AR KM‐57 KM‐58L KM‐58S CP‐58V‐0805‐625 CP‐58V‐0805‐075 CP‐58V‐0805‐875 CP‐58V‐0805‐100 CP‐58V‐0805‐125 CP‐58V‐0758‐625 CP‐58V‐0758‐075 CP‐58V‐0758‐875 CP‐58V‐0758‐100 CP‐58V‐0758‐125 CP‐58VPK‐0758‐625 CP‐58VPK‐0758‐750 CP‐58VPK‐0758‐875 CP‐58VPK‐0758‐100 CP‐58VPK‐0758‐125 CP‐59 CP‐59‐625 CP‐59‐750 KM‐59‐200AB KM‐59‐200DX KM‐59‐200S KM‐59‐200SS KM‐59A‐150AB KM‐59A‐175AB Discharge Valve (Stainless Steel) Discharge Valve SS Inserted Abrasive/Resistant Wing Guided Suction Valve (Stainless Steel) Suction Valve SS Inserted Abrasive/Resistant Wing Guided Valve Seat (Stainless Steel) Valve Spring (Wing‐Guided) (Long) (Discharge) Valve Spring (Wing‐Guided) (Short) (Suction) 805 Pressure Rings Only 5/8" (3 Ea. Per Set) 805 Pressure Rings 3/4" (3 Ea. Per set) 805 Pressure Rings Only 7/8"(3 Ea. Per Set) 805 Pressure Rings Only 1"(3 Ea. Per Set) 805 Pressure Rings Only 1 1/4 (3 Ea. Per Set) 758 Pressure Rings Only 5/8" (3 Ea. Per Set) 758 Pressure Rings 3/4" (3 Ea. Per Set) 758 Pressure Rings Only 7/8" (3 Ea. Per Set) 758 Pressure Rings Only 1" (3 Ea. Per Set) 758 Pressure Rings Only 1 1/4" (3 Ea. Per Set) 758/PK Pressure Ring Only 5/8"(3 Ea. Per Set) 758/PK Pressure Ring Only 3/4" (3 Ea. Per Set) 758/PK Pressure Ring Only 7/8 (3 Ea..Per Set) 758/PK Pressure Ring Set Only (3 Ea. Per Set) 758/PK Pressure Ring Set Only 1 1/4" (3 Ea. Per Set) Packing Spring (for Spring Loaded Packing) 7/8, 1, 1 1/4 Packing Spring (for Spring Loaded Packing) 5/8 Packing Spring (for Spring Loaded Packing) 3/4 Packing Gland 2 (Bolted Type) (ALBZ) Packing Gland 2 (Bolted Type) (Duplex Stainless) Packing Gland 2 (Bolted Type) (Steel) Packing Gland 2 (Bolted Type) (Stainless Steel) Stuffing Box Gland Adapter 1 1/2 (ALBZ) Stuffing Box Gland Adapter 1 3/4 (ALBZ) 3 3 3 3 6 3 3 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 3 3 3 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐59A‐125S KM‐59A‐150S KM‐59A‐175S KM‐59A‐125SS KM‐59A‐150SS KM‐59A‐175SS KM‐59A‐125AB KM‐59SPCR KM‐60‐100AB KM‐60‐125AB KM‐60‐150AB KM‐60‐175AB KM‐60‐200AB KM‐60‐100S KM‐60‐125S KM‐60‐150S KM‐60‐175S KM‐60‐200S KM‐60‐100SS KM‐60‐125SS KM‐60‐150SS KM‐60‐175SS KM‐60‐200SS KM‐61‐100AB KM‐61‐125AB KM‐61‐150AB KM‐61‐175AB KM‐61‐200AB KM‐61‐100S KM‐61‐125S KM‐61‐150S Stuffing Box Gland Adapter 1 1/4 (Steel) Stuffing Box Gland Adapter 1 1/2 (Steel) Stuffing Box Gland Adapter 1 3/4 (Steel) Stuffing Box Gland Adapter 1 1/4 (Stainless Steel) Stuffing Box Gland Adapter 1 1/2 (Stainless Steel) Stuffing Box Gland Adapter 1 3/4 (Stainless Steel) Stuffing Box Gland Adapter 1 1/4 (ALBZ) Gland Spacer, Spring Loaded Packing Packing Ring 1 (ALBZ) Packing Ring 1 1/4 (ALBZ) Packing Ring 1 1/2 (ALBZ) Packing Ring 1 3/4 (ALBZ) Packing Ring 2 (ALBZ) Packing Ring 1 (Steel) Packing Ring 1 1/4 (Steel) Packing Ring 1 1/2 (Steel) Packing Ring 1 3/4 (Steel) Packing Ring 2 (Steel) Packing Ring 1 (Stainless Steel) Packing Ring 1 1/4 (Stainless Steel) Packing Ring 1 1/2 (Stainless Steel) Packing Ring 1 3/4 (Stainless Steel) Packing Ring 2 (Stainless Steel) Packing Lantern Ring (For Mechanical Lubrication) 1 (AB) Packing Lantern Ring (For Mechanical Lubrication) 1 1/4 (AB) Packing Lantern Ring (For Mechanical Lubrication) 1 1/2 (AB) Packing Lantern Ring (For Mechanical Lubrication) 1 3/4 (AB) Packing Lantern Ring (For Mechanical Lubrication) 2 (AB) Packing Lantern Ring (For Mechanical Lubrication) 1 (Steel) Packing Lantern Ring (For Mechanical Lubrication) 1 1/4 (Steel) Packing Lantern Ring (For Mechanical Lubrication) 1 1/2 (Steel) 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐61‐100SS KM‐61‐125SS KM‐61‐150SS KM‐61‐200SS KM‐63‐100 KM‐63‐125 KM‐63‐150 KM‐63‐175 KM‐63‐200 KM‐63G‐100 KM‐63G‐125 KM‐63G‐150 KM‐63G‐175 KM‐63G‐200 KM‐63K‐100 KM‐63K‐125 KM‐63K‐150 KM‐63K‐175 KM‐63K‐200 KM‐63PK‐200 KM‐63T‐100 KM‐63T‐125 KM‐63T‐150 KM‐63T‐175 KM‐63T‐200 KM‐64 KM‐65 KM‐65L KM‐66 KP‐67V‐0805‐200 KP‐67V‐0758‐200 Packing Lantern Ring (For Mechanical Lubrication) 1 (Stainless Steel) Packing Lantern Ring (For Mechanical Lubrication) 1 1/4 (Stainless Steel) Packing Lantern Ring (For Mechanical Lubrication) 1 1/2 (Stainless Steel) Packing Lantern Ring (For Mechanical Lubrication) 2 Stainless (Steel) 838 Plunger Packing (Non Adjustable) 1 838 Plunger Packing (Non Adjustable) 1 1/4 838 Plunger Packing (Non Adjustable) 1 1/2 838 Plunger Packing (Non Adjustable) 1 3/4 838 Plunger Packing (Non Adjustable) 2 858 Plunger Packing (Non Adjustable) 1 858 Plunger Packing (Non Adjustable) 1 1/4 858 Plunger Packing (Non Adjustable) 1 1/2 858 Plunger Packing (Non Adjustable) 1 3/4 858 Plunger Packing (Non Adjustable) 2 Kevlar Packing 1 Kevlar Packing 1 1/4 Kevlar Packing 1 1/2 Kevlar Packing 1 3/4 Kevlar Packing 2 Peak Packing 2 Teflon Packing 1 Teflon Packing 1 1/4 Teflon Packing 1 1/2 Teflon Packing 1 3/4 Teflon Packing 2 Packing Gland Stud Packing Gland Stud Nut Stuffing Box Lock Nut (Stainless Steel) Stuffing Box Stud Swivel Washer (Stainless Steel) 805 Pressure Rings 2 758 Pressure Rings 2 3 3 3 3 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 6 6 6 6 3 sets 3 sets Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KP‐67VPK‐0758‐200 KM‐67‐100 KM‐67‐125 KM‐67‐150 KM‐67‐175 KM‐67‐200 KM‐68‐625 KM‐68‐750 KM‐68‐875 KM‐68‐100 KM‐68‐125 KM‐68‐150 KM‐68‐175 KM‐68‐200 KM‐69 KM‐69DL AP‐72AB KM‐72 AP‐72S AP‐72SS AP‐74 KM‐75 KM‐76 KM‐76M KM‐77 AP‐77T KM‐85AB KM‐85S KM‐85SS KM‐85G KM‐85DX 758/PK Follower Pressure Rings 2 Plunger 1 (Stainless Steel) Plunger 1 1/4 (Stainless Steel) Plunger 1 1/2 (Stainless Steel) Plunger 1 3/4 (Stainless Steel) Plunger 2 (Stainless Steel) Plunger 5/8 (Colmonoy 730) Plunger 3/4 (Colmonoy 730) Plunger 7/8 (Colmonoy 730) Plunger 1 (Colmonoy 730) Plunger 1 1/4 (Colmonoy 730) Plunger 1 1/2 (Colmonoy 730) Plunger 1 3/4 (Colmonoy 730) Plunger 2 (Colmonoy 730) Plunger Chamber Cover Plunger Chamber Cover Drip Lube Reservoir 1/8 NPT Oil Level/Stuffing Box Hex Plug (AB) Cover Cap Wrench 1/8 NPT Oil Level/Stuffing Box Hex Plug (Steel) 1/8 NPT Oil Level/Stuffing Box Hex Plug (Stainless Steel) Grease Zert With Cap Bolted Type Stuffing Box Wrench Valve Puller Wing Type Valve Puller Wing Guide Pin Type Valve Puller Disc Type Valve Insert Tool Stuffing Box (ALBZ) Stuffing Box (Steel) Stuffing Box (Stainless Steel) Stuffing Box Gasket Stuffing Box (Duplex Stainless CD3M) 3 sets 3 3 3 3 3 3 3 3 3 3 3 3 3 1 1 3 1 3 3 3 3 1 1 1 1 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐87‐100AB KM‐87‐125AB KM‐87‐150AB KM‐87‐175AB KM‐87‐100CS KM‐87‐125CS KM‐87‐150CS KM‐87‐175CS KM‐87‐100SS KM‐87‐125SS KM‐87‐150SS KM‐87‐175SS KM‐88‐100 KM‐88‐125 KM‐88‐150 KM‐88‐175 KM‐88G‐100 KM‐88G‐125 KM‐88G‐150 KM‐88G‐175 KM‐88K‐100 KM‐88K‐125 KM‐88K‐150 KM‐88PK‐150 KM‐88T‐100 KM‐88T‐125 KM‐88T‐150 KM‐88T‐175 KM‐88V‐0805‐125 KM‐88V‐0805‐150 KM‐88V‐0805‐175 Stuffing Box Nut 1 (AB) Stuffing Box Nut 1 1/4 (AB) Stuffing Box Nut 1 1/2 (AB) Stuffing Box Nut 1 3/4 (AB) Stuffing Box Nut (Cast Steel) 1 Stuffing Box Nut (Cast Steel) 1 1/4 Stuffing Box Nut (Cast Steel) 1 1/2 Stuffing Box Nut (Cast Steel) 1 3/4 Stuffing Box Nut (Stainless Steel) 1 Stuffing Box Nut (Stainless Steel) 1 1/4 Stuffing Box Nut (Stainless Steel) 1 1/2 Stuffing Box Nut (Stainless Steel) 1 3/4 838 Plunger Packing (Non Adjustable) 1 838 Plunger Packing (Non Adjustable) 1 1/4 838 Plunger Packing (Non Adjustable) 1 1/2 838 Plunger Packing (Non Adjustable) 1 3/4 858 Plunger Packing (Non Adjustable) 1 858 Plunger Packing (Non Adjustable) 1 1/4 858 Plunger Packing (Non Adjustable) 1 1/2 858 Plunger Packing (Non Adjustable) 1 3/4 Kevlar Packing 1 Kevlar Packing 1 1/4 Kevlar Packing 1 1/2 Peak Packing 1 1/2 Teflon Packing 1 Teflon Packing 1 1/4 Teflon Packing 1 1/2 Teflon Packing 1 3/4 805 Pressure Rings 1 1/4 805 Pressure Rings 1 1/2 805 Pressure Rings 1 3/4 3 3 3 3 3 3 3 3 3 3 3 3 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐88V‐0758‐125 KM‐88V‐0758‐150 KM‐88V‐0758‐175 KM‐88VPK‐0758‐125 KM‐88VPK‐0758‐150 KM‐88VPK‐0758‐175 KM‐88‐125 KM‐88‐2070‐150 KM‐88K‐175 KM‐88K‐150 KM‐88K‐0210‐150 KM‐89‐100AB KM‐89‐125AB KM‐89‐150AB KM‐89‐175AB KM‐89‐100S KM‐89‐125S KM‐89‐150S KM‐89‐175S KM‐89‐100SS KM‐89‐125SS KM‐89‐150SS KM‐89‐175SS KM‐90‐100AB KM‐90‐125AB KM‐90‐150AB KM‐90‐175AB KM‐90‐100S KM‐90‐125S KM‐90‐150S KM‐90‐175S 758 Pressure Rings 1 1/4 758 Pressure Rings 1 1/2 758 Pressure Rings 1 3/4 758/PK Follower Pressure Rings 1 1/4 758/PK Follower Pressure Rings 1 1/2 758/PK Follower Pressure Rings 1 3/4 838 Plunger Packing (Non Adjustable) 1 1/4 210 Die Formed 1 1/4 " x 21/4" Kevlar Packing 1 3/4" 0210 Kevlar 1 1/2" 0210 Kevlar 1 1/2" Packing Ring 1 (ALBZ) Packing Ring 1 1/4 (ALBZ) Packing Ring 1 1/2 (ALBZ) Packing Ring 1 3/4 (ALBZ) Packing Ring 1 (Steel) Packing Ring 1 1/4 (Steel) Packing Ring 1 1/2 (Steel) Packing Ring 1 3/4 (Steel) Packing Ring 1 (Stainless Steel) Packing Ring 1 1/4 (Stainless Steel) Packing Ring 1 1/2 (Stainless Steel) Packing Ring 1 3/4 (Stainless Steel) Packing Lantern Ring 1 (AB) Packing Lantern Ring 1 1/4 (AB) Packing Lantern Ring 1 1/2 (AB) Packing Lantern Ring 1 3/4 (AB) Packing Lantern Ring 1 (Steel) Packing Lantern Ring 1 1/4 (Steel) Packing Lantern Ring 1 1/2 (Steel) Packing Lantern Ring 1 3/4 (Steel) 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐90‐100SS KM‐90‐125SS KM‐90‐150SS KM‐90‐175SS KM‐90K‐100AB KM‐90K‐125AB KM‐90K‐150AB KM‐90K‐175AB KM‐90K‐100S KM‐90K‐125S KM‐90K‐150S KM‐90K‐150S KM‐90K‐100SS KM‐90K‐125SS KM‐90K‐150SS KM‐90K‐175SS KM‐91 KM‐93SL‐125AB KM‐93SL‐125S KM‐93SL‐125SS KM‐93SL‐150AB KM‐93SL‐150S KM‐93SL‐150SS KM‐93SL‐175AB KM‐93SL‐175S KM‐93SL‐175SS KM‐93SL‐200AB KM‐93SL‐200S KM‐93SL‐200SS KM‐94SL‐125AB KM‐94SL‐125S Packing Lantern Ring 1 (Stainless Steel) Packing Lantern Ring 1 1/4 (Stainless Steel) Packing Lantern Ring 1 1/2 (Stainless Steel) Packing Lantern Ring 1 3/4 (Stainless Steel) Kevlar Packing Lantern Ring 1 Kevlar Packing Lantern Ring 1 1/4 Kevlar Packing Lantern Ring 1 1/2 Kevlar Packing Lantern Ring 1 3/4 Kevlar Packing Lantern Ring 1 (Steel) Kevlar Packing Lantern Ring 1 1/4 (Steel) Kevlar Packing Lantern Ring 1 1/2 (Steel) Kevlar Packing Lantern Ring 1 3/4 (Steel) Kevlar Packing Lantern Ring 1 (Stainless Steel) Kevlar Packing Lantern Ring 1 1/4 (Stainless Steel) Kevlar Packing Lantern Ring 1 1/2 (Stainless Steel) Kevlar Packing Lantern Ring 1 3/4 (Stainless Steel) Screwed Type Stuffing Box Wrench Spring Loaded Packing Adapters 1 1/4 (ALBZ) Spring Loaded Packing Adapters 1 1/4(Steel) Spring Loaded Packing Adapters 1 1/4 (Stainless Steel) Spring Loaded Packing Adapters 1 1/2 (ALBZ) Spring Loaded Packing Adapters 1 1/2(Steel) Spring Loaded Packing Adapters 1 1/2 (Stainless Steel) Spring Loaded Packing Adapters 1 3/4 (ALBZ) Spring Loaded Packing Adapters 1 3/4 (Steel) Spring Loaded Packing Adapters 1 3/4 (Stainless Steel) Spring Loaded Packing Adapters 2 (ALBZ) Spring Loaded Packing Adapters 2 (Steel) Spring Loaded Packing Adapters 2 (Stainless Steel) 805 Spring Loaded Packing Sets 1 1/4 (ALBZ) 805 Spring Loaded Packing Sets 1 1/4(Steel) 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 1 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐94SL‐125SS KM‐94SL‐150AB KM‐94SL‐150S KM‐94SL‐150SS KM‐94SL‐175AB KM‐94SL‐175S KM‐94SL‐175SS KM‐94SL‐200AB KM‐94SL‐200S KM‐94SL‐200SS KM‐94SLG‐125AB KM‐94SLG‐125S KM‐94SLG‐125SS KM‐94SLG‐150AB KM‐94SLG‐150S KM‐94SLG‐150SS KM‐94SLG‐175AB KM‐94SLG‐175S KM‐94SLG‐175SS KM‐94SLG‐200AB KM‐94SLG‐200S KM‐94SLG‐200SS KM‐94SLGPK‐125AB KM‐94SLGPK‐125S KM‐94SLGPK‐125SS KM‐94SLGPK‐150AB KM‐94SLGPK‐150S KM‐94SLGPK‐150SS KM‐94SLGPK‐175AB KM‐94SLGPK‐175S KM‐94SLGPK‐175SS 805 Spring Loaded Packing Sets 1 1/4 (Stainless Steel) 805 Spring Loaded Packing Sets 1 1/2 (ALBZ) 805 Spring Loaded Packing Sets 1 1/2(Steel) 805 Spring Loaded Packing Sets 1 1/2 (Stainless Steel) 805 Spring Loaded Packing Sets 1 3/4 (ALBZ) 805 Spring Loaded Packing Sets 1 3/4 (Steel) 805 Spring Loaded Packing Sets 1 3/4 (Stainless Steel) 805 Spring Loaded Packing Sets 2 (ALBZ) 805 Spring Loaded Packing Sets 2 (Steel) 805 Spring Loaded Packing Sets 2 (Stainless Steel) 758 Spring Loaded Packing Sets 1 1/4 (ALBZ) 758 Spring Loaded Packing Sets 1 1/4(Steel) 758 Spring Loaded Packing Sets 1 1/4 (Stainless Steel) 758 Spring Loaded Packing Sets 1 1/2 (ALBZ) 758 Spring Loaded Packing Sets 1 1/2(Steel) 758 Spring Loaded Packing Sets 1 1/2 (Stainless Steel) 758 Spring Loaded Packing Sets 1 3/4 (ALBZ) 758 Spring Loaded Packing Sets 1 3/4 (Steel) 758 Spring Loaded Packing Sets 1 3/4 (Stainless Steel) 758 Spring Loaded Packing Sets 2 (ALBZ) 758 Spring Loaded Packing Sets 2 (Steel) 758 Spring Loaded Packing Sets 2 (Stainless Steel) 758/PK Spring Loaded Packing Sets 1 1/4 (ALBZ) 758PK Spring Loaded Packing Sets 1 1/4(Steel) 758/PK Spring Loaded Packing Sets 1 1/4 (Stainless Steel) 758/PK Spring Loaded Packing Sets 1 1/2 (ALBZ) 758/PK Spring Loaded Packing Sets 1 1/2(Steel) 758/PK Spring Loaded Packing Sets 1 1/2 (Stainless Steel) 758/PK Spring Loaded Packing Sets 1 3/4 (ALBZ) 758/PK Spring Loaded Packing Sets 1 3/4 (Steel) 758/PK Spring Loaded Packing Sets 1 3/4 (Stainless Steel) 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐94SLGPK‐200AB KM‐94SLGPK‐200S KM‐94SLGPK‐200SS KM‐95AB KM‐95S KM‐95SL KM‐95SS KP‐95W‐225 KP‐95W‐250 KM‐95DX KM‐96HT KM‐97HT KM‐98HT KMC‐100 KM‐101R KM‐101A KM‐101N KM‐101V KM‐101B KM‐104‐625AB KM‐104‐750AB KM‐104‐875AB KM‐104‐100AB KM‐104‐125AB KM‐104‐625S KM‐104‐750S KM‐104‐875S KM‐104‐100S KM‐104‐125S KM‐104‐625SS KM‐104‐750SS 758/PK Spring Loaded Packing Sets 2 (ALBZ) 758/PK Spring Loaded Packing Sets 2 (Steel) 758/PK Spring Loaded Packing Sets 2 (Stainless Steel) Stuffing Box (Bolted Type) (ALBZ) Stuffing Box (Bolted Type) (Steel) Spring Loaded Packing Ring Springs (6 per set) Stuffing Box (Bolted Type) (Stainless Steel) Wave Spring 2‐1/4 OD Wave Spring 2‐1/2 OD Stuffing Box (Bolted Type) (Duplex Stainless CD3M) Discharge Valve, Heat Treated, A/R with Insert Suction Valve, Heat Treated, A/R with Insert Valve Seat, Heat Treated, A/R Plunger 1 (Ceramic) Abrasive Resistant Valve Insert Abrasive Resistant Valve Insert (Aflax) Abrasive Resistant Valve Insert (Nitrile) Abrasive Resistant Valve Insert Abrasive Resistant Valve Insert Blue 805 Spring Loaded Packing Set 5/8 (ALBZ) 805 Spring Loaded Packing Set 3/4 (ALBZ) 805 Spring Loaded Packing Set 7/8 (ALBZ) 805 Spring Loaded Packing Set 1 (ALBZ) 805 Spring Loaded Packing Set 1 1/4 (ALBZ) 805 Spring Loaded Packing Set 5/8 (Steel) 805 Spring Loaded Packing Set 3/4 (Steel) 805 Spring Loaded Packing Set 7/8 (Steel) 805 Spring Loaded Packing Set 1 (Steel) 805 Spring Loaded Packing Set 1 1/4 (Steel) 805 Spring Loaded Packing Set 5/8 (Stainless Steel) 805 Spring Loaded Packing Set 3/4 (Stainless Steel) 3 sets 3 sets 3 sets 3 3 3 sets 3 3 3 3 3 3 6 3 6 6 6 6 3 3 3 3 3 3 3 3 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐104‐875SS KM‐104‐100SS KM‐104‐125SS KM‐104G‐625AB KM‐104G‐750AB KM‐104G‐875AB KM‐104G‐100AB KM‐104G‐125AB KM‐104G‐625S KM‐104G‐750S KM‐104G‐875S KM‐104G‐100S KM‐104G‐125S KM‐104G‐625SS KM‐104G‐750SS KM‐104G‐875SS KM‐104G‐100SS KM‐104G‐125SS KM‐104GPK‐625AB KM‐104GPK‐750AB KM‐104GPK‐875AB KM‐104GPK‐100AB KM‐104GPK‐125AB KM‐104GPK‐625S KM‐104GPK‐750S KM‐104GPK‐875S KM‐104GPK‐100S KM‐104GPK‐125S KM‐104GPK‐625SS KM‐104GPK‐750SS KM‐104GPK‐875SS 805 Spring Loaded Packing Set 7/8 (Stainless Steel) 805 Spring Loaded Packing Set 1 (Stainless Steel) 805 Spring Loaded Packing Set 1 1/4 (Stainless Steel) 758 Spring Loaded Packing Set 5/8 (ALBZ) 758 Spring Loaded Packing Set 3/4 (ALBZ) 758 Spring Loaded Packing Set 7/8 (ALBZ) 758 Spring Loaded Packing Set 1 (ALBZ) 758 Spring Loaded Packing Set 1 1/4 (ALBZ) 758 Spring Loaded Packing Set 5/8 (Steel) 758 Spring Loaded Packing Set 3/4 (Steel) 758 Spring Loaded Packing Set 7/8 (Steel) 758 Spring Loaded Packing Set 1 (Steel) 758 Spring Loaded Packing Set 1 1/4 (Steel) 758 Spring Loaded Packing Set 5/8 (Stainless Steel) 758 Spring Loaded Packing Set 3/4 (Stainless Steel) 758 Spring Loaded Packing Set 7/8 (Stainless Steel) 758 Spring Loaded Packing Set 1 (Stainless Steel) 758 Spring Loaded Packing Set 1 1/4 (Stainless Steel) 758/PK Follower Spring Loaded Packing Set Complete 5/8 AB 758/PK Follower Spring Loaded Packing Set Complete 3/4 AB 758/PK Follower Spring Loaded Packing Set Complete 7/8 AB 758/PK Follower Spring Loaded Packing Set Complete 1 AB 758/PK Follower Spring Loaded Packing Set Complete 1 1/4 AB 758/PK Follower Spring Loaded Packing Set Complete 5/8 Steel 758/PK Follower Spring Loaded Packing Set Complete 3/4 Steel 758/PK Follower Spring Loaded Packing Set Complete 7/8 Steel 758/PK Follower Spring Loaded Packing Set Complete 1 Steel 758/PK Follower Spring Loaded Packing Set Complete 1 1/4 Steel 758/PK Follower Spring Loaded Packing Set Complete 5/8 SS 758/PK Follower Spring Loaded Packing Set Complete 3/4 SS 758/PK Follower Spring Loaded Packing Set Complete 7/8 SS 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐104GPK‐100SS KM‐104GPK‐125SS KM‐104‐625AB KM‐104‐625S KM‐104‐100S KM‐105AB KM‐105AB KM‐105SS KM‐105‐625AB KM‐105‐625S KM‐105‐625SS KM‐105‐750AB KM‐105‐750S KM‐105‐750SS KM‐105‐SL‐LRAB KM‐105‐SL‐LRS KM‐105‐SL‐LRSS KM‐105‐750SL‐LRAB KM‐105‐750SL‐LRS KM‐105‐750SL‐LRSS KM‐107AB KM‐107S KM‐107SS KM‐107‐625AB KM‐107‐625S KM‐107‐625SS KM‐107‐750AB KM‐107‐750S KM‐107‐750SS KM‐108‐750AB KM‐108‐875AB 758/PK Follower Spring Loaded Packing Set Complete 1 SS 758/PK Follower Spring Loaded Packing Set Complete 1 1/4 SS 805 Spring Loaded Packing Set 5/8 (ALBZ) 805 Spring Loaded Packing Set 5/8 (Steel) 805 Spring Loaded Packing Set 1 (Steel) Stuffing Box (ALBZ) 1 3/4 ID Stuffing Box (Steel) 1 3/4 ID Stuffing Box (Stainless Steel) 1 3/4 ID Stuffing Box (ALBZ) 1 1/8 ID Stuffing Box (Steel) 1 1/8 ID Stuffing Box (Stainless Steel) 1 1/8 ID Stuffing Box (ALBZ) 1 1/2 ID Stuffing Box (Steel) 1 1/2 ID Stuffing Box (Stainless Steel) 1 1/2 ID Stuffing Box (ALBZ) 1 3/4 ID Spring Loaded Lubricated Stuffing Box (Steel) 1 3/4 ID Spring Loaded Lubricated Stuffing Box (Stainless Steel) 1 3/4 ID Spring Loaded Lubricated Stuffing Box (ALBZ) 1 1/2 ID Spring Loaded Lubricated Stuffing Box (Steel) 1 1/2 ID Spring Loaded Lubricated Stuffing Box (Stainless Steel) 1 1/2 ID Spring Loaded Lubricated Stuffing Box Nut (ALBZ) Stuffing Box Nut (Steel) Stuffing Box Nut (Stainless Steel) Stuffing Box Nut 5/8 (ALBZ) Stuffing Box Nut 5/8 (Steel) Stuffing Box Nut 5/8 (Stainless Steel) Stuffing Box Nut 3/4 (ALBZ) Stuffing Box Nut 3/4 (Steel) Stuffing Box Nut 3/4 (Stainless Steel) Packing Spacer Ring 3/4 (ALBZ) Packing Spacer Ring 7/8 (ALBZ) 3 sets 3 sets 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐108‐100AB KM‐108‐125AB KM‐108‐750S KM‐108‐875S KM‐108‐100S KM‐108‐125S KM‐108‐750SS KM‐108‐875SS KM‐108‐100SS KM‐108‐125SS KM‐108SL‐625AB KM‐108SL‐625S KM‐108SL‐625SS KM‐108SL‐750AB KM‐108SL‐750S KM‐108SL‐750SS KM‐108SL‐875AB KM‐108SL‐875S KM‐108SL‐875SS KM‐108SL‐100AB KM‐108SL‐100S KM‐108SL‐100SS KM‐108SL‐125AB KM‐108SL‐125S KM‐108SL‐125SS KM‐109‐875AB KM‐109‐100AB KM‐109‐125AB KM‐109‐875S KM‐109‐100S KM‐109‐125S Packing Spacer Ring 1 (ALBZ) Packing Spacer Ring 1 1/4 (ALBZ) Packing Spacer Ring 3/4 (Steel) Packing Spacer Ring 7/8 (Steel) Packing Spacer Ring 1 (Steel) Packing Spacer Ring 1 1/4 (Steel) Packing Spacer Ring 3/4 (Stainless Steel) Packing Spacer Ring 7/8 (Stainless Steel) Packing Spacer Ring 1 (Stainless Steel) Packing Spacer Ring 1 1/4 (Stainless Steel) Spring Loaded Packing Adapters 5/8 (ALBZ) Spring Loaded Packing Adapters 5/8 (Steel) Spring Loaded Packing Adapters 5/8 (Stainless Steel) Spring Loaded Packing Adapters 3/4 (ALBZ) Spring Loaded Packing Adapters 3/4 (Steel) Spring Loaded Packing Adapters 3/4 (Stainless Steel) Spring Loaded Packing Adapters 7/8 (ALBZ) Spring Loaded Packing Adapters 7/8 (Steel) Spring Loaded Packing Adapters 7/8 (Stainless Steel) Spring Loaded Packing Adapters 1 (ALBZ) Spring Loaded Packing Adapters 1 (Steel) Spring Loaded Packing Adapters 1 (Stainless Steel) Spring Loaded Packing Adapters 1 1/4 (ALBZ) Spring Loaded Packing Adapters 1 1/4 (Steel) Spring Loaded Packing Adapters 1 1/4 (Stainless Steel) Packing Lantern Ring 7/8 (AB) Packing Lantern Ring 1 (AB) Packing Lantern Ring 1 1/4 (AB) Packing Lantern Ring 7/8 (Steel) Packing Lantern Ring 1 (Steel) Packing Lantern Ring 1 1/4 (Steel) 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐109‐875SS KM‐109‐100SS KM‐109‐125SS KM‐109SL‐LR‐750AB KM‐109SL‐LR‐750S KM‐109SL‐LR‐750SS KM‐109SL‐LR‐875AB KM‐109SL‐LR‐875S KM‐109SL‐LR‐875SS KM‐109SL‐LR‐100AB KM‐109SL‐LR‐100S KM‐109SL‐LR‐100SS KM‐109SL‐LR‐125AB KM‐109SL‐LR‐125S KM‐109SL‐LR‐125SS KM‐109SL‐LR‐750SS KM‐109SL‐LR‐875AB KM‐109SL‐LR‐875S KM‐109SL‐LR‐875SS KM‐111‐875 KM‐111‐100 KM‐111‐125 KM‐111G‐875 KM‐111G‐100 KM‐111G‐125 KM‐111T‐875 KM‐111T‐100 KM‐111T‐125 KM‐111K‐875 KM‐111K‐100 KM‐111K‐125 Packing Lantern Ring 7/8 (Stainless Steel) Packing Lantern Ring 1 (Stainless Steel) Packing Lantern Ring 1 1/4 (Stainless Steel) Spring Loaded Packing Lantern Ring 3/4 (ALBZ) Spring Loaded Packing Lantern Ring 3/4 (Steel) Spring Loaded Packing Lantern Ring 3/4 (Stainless Steel) Spring Loaded Packing Lantern Ring 7/8 (ALBZ) Spring Loaded Packing Lantern Ring 7/8 (Steel) Spring Loaded Packing Lantern Ring 7/8 (Stainless Steel) Spring Loaded Packing Lantern Ring 1 (ALBZ) Spring Loaded Packing Lantern Ring 1 (Steel) Spring Loaded Packing Lantern Ring 1 (Stainless Steel) Spring Loaded Packing Lantern Ring 1 1/4 (ALBZ) Spring Loaded Packing Lantern Ring 1 1/4 (Steel) Spring Loaded Packing Lantern Ring 1 1/4 (Stainless Steel) Spring Loaded Packing Lantern Ring 3/4 (Stainless Steel) Spring Loaded Packing Lantern Ring 7/8 (ALBZ) Spring Loaded Packing Lantern Ring 7/8 (Steel) Spring Loaded Packing Lantern Ring 7/8 (Stainless Steel) 838 Packing 7/8 838 Packing 1 838 Packing 1 1/4 858 Packing 7/8 858 Packing 1 858 Packing 1 1/4 Teflon Packing 7/8 Teflon Packing 1 Teflon Packing 1 1/4 Kevlar Packing 7/8 Kevlar Packing 1 Kevlar Packing 1 1/4 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐111‐875 KM‐111‐100 KM‐111‐125 KM‐111G‐875 KM‐111G‐100 KM‐111G‐125 KM‐111T‐875 KM‐111T‐100 KM‐111T‐125 KM‐111K‐875 KM‐111K‐100 KM‐111K‐125 KM‐112 KM‐113 838 Packing 7/8 838 Packing 1 838 Packing 1 1/4 858 Packing 7/8 858 Packing 1 858 Packing 1 1/4 Teflon Packing 7/8 Teflon Packing 1 Teflon Packing 1 1/4 Kevlar Packing 7/8 Kevlar Packing 1 Kevlar Packing 1 1/4 Pony Rod Splash Guard Complete Gasket Kit ‐‐ Contents: (1) KM‐3, (2) KM‐7, (1) KM‐12, (1) KM‐15, (3 SETS) KM‐29, (3) KM‐30, (3) KM‐33, (9) KM‐37, (3) KM‐85G, (3) KM‐112 Lubrication System Complete Drip Lubrication System Complete Force Feed Lubricator 3 Feed Lubrication System Less Lubricator Lubricator Hose Kit Complete 55 Single Pump for Forced Feed Lubricator Crankshaft Lubrication Sheave Lubricator Driven Sheave Lubrication Belt Lubricator Bracket Crankshaft, Hydraulic Drive 1 1/4 Straight Keyed Drive Crankshaft Splined for 14T 12/24 Crankshaft Splined for 17T 12/24 Crankshaft Splined Adapter for Auburn #6 Crankshaft Splined Adapter for 14T 12/24 Crankshaft Splined Adapter for 17T 12/24 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 sets 3 KM‐114 KM‐114DL AP‐114 KM‐115 KM‐115H AP‐116 KM‐117 AP‐117L‐6 KM‐118 KM‐119 KM‐121 KM‐122‐14T KM‐122‐17T KM‐124 KM‐124‐14T KM‐124‐17T 1 1 1 1 1 3 1 1 1 1 1 1 1 1 1 1 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐124‐6000 KM‐124 KM‐124‐14T KM‐124‐17T KM‐124‐6000 KM‐125‐6 KM‐125‐GM1 KM‐125‐GM2 KM‐125‐GM3A KM‐125‐GS3 KM‐125‐800W KM‐125‐3000 KM‐125‐4000 KM‐125‐4000E KM‐125‐6000 KMC‐125 KM‐125‐GM3A KM‐125‐GS3 KM‐125‐800W KM‐125‐3000 KM‐125‐4000 KM‐125‐4000E KM‐125‐6000 KM‐126 KM‐126 KM‐130 KM‐130 KM‐132 KM‐132 AP‐135 KMC‐150 6000 Hydraulic Motor Adapter 1 1/2 to 1 1/4 Crankshaft Splined Adapter for Auburn #6 Crankshaft Splined Adapter for 14T 12/24 Crankshaft Splined Adapter for 17T 12/24 6000 Hydraulic Motor Adapter 1 1/2 to 1 1/4 Bearing Housing, Hyd Drive for Auburn #6 Bearing Housing, Hyd Drive for SAI GM1 Series Bearing Housing, Hyd Drive for SAI GM2 Series Bearing Housing, Hyd Drive for SAI GM3A Series Bearing Housing, Hyd Drive for SAI GS3 Series Bearing Housing, White Hyd Mtr 800 Series 14 Tooth 4 Bolt C Bearing Housing, Bearingless 3000 Bearing Housing, Bearingless Hyd Mtr 4000 Bearing Housing, Eaton Hyd Mtr 14 Tooth 4 Bolt SAE A Bearing Housing, Hyd Mtr 6000 1‐1/2 Keyed Shaft 4 Bolt C Plunger 1 1/4 (Ceramic) Bearing Housing, Hyd Drive for SAI GM3A Series Bearing Housing, Hyd Drive for SAI GS3 Series Bearing Housing, White Hyd Mtr 800 Series 14 Tooth 4 Bolt C Bearing Housing, Bearingless 3000 Bearing Housing, Bearingless Hyd Mtr 4000 Bearing Housing, Eaton Hyd Mtr 14 Tooth 4 Bolt SAE A Bearing Housing, Hyd Mtr 6000 1‐1/2 Keyed Shaft 4 Bolt C Bearing Housing, Hyd Drive for 1 1/4 Straight Keyed Drive 4 Bolt SAE A Bearing Housing, Hyd Drive for 1 1/4 Straight Keyed Drive 4 Bolt SAE A Bearing Housing, Extensions Shaft Bearing Housing, Extensions Shaft Auxiliary Shaft Auxiliary Shaft Oil Seal, Bearing Housing Extension Shaft Plunger 1 1/2 (Ceramic) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 3 1 1 1 1 1 1 1 1 1 1 1 1 1 1 3 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KMC‐175 KMC‐200 KM‐276 KM‐277 KM‐300AB KM‐300SS KM‐300HT KM‐300M KM‐305AB KM‐305HT KM‐305SS KM‐305SS AP‐324‐6‐3 AP‐324‐6‐4 AP‐330 AP‐330H AP‐330S AP‐330B AP‐330‐1 AP‐330‐2 AP‐331 AP‐351 AP‐352 AP‐425 AP‐450 KM‐500DX KM‐500S KM‐500SS KM‐501CS KM‐501DX KM‐501SS Plunger 1 3/4 (Ceramic) Plunger 2 (Ceramic) Installation Tool for Pony Rod Seal Pony Rod Installation Wrench Discharge Valve Assy (ALBZ) (KM‐39, KM‐41 &KM‐ 58L) Stainless Steel Discharge Valve Assy (KM‐55, KM‐57 & KM‐58L) Abrasive Resistant Discharge Valve Complete (KM‐96HT, KM‐98HT & KM‐58L) Monel Discharge Valve Complete (KM‐42, KM‐44, KM‐58L) Suction Valve Assy (ALBZ) (KM‐40, KM‐41, & KM‐58S) Abrasive Resistant Suction Valve Complete (KM‐97HT, KM‐98HT & KM‐58S) Stainless Steel Suction Valve Complete (KM‐56, KM‐57 & KM‐58S) Stainless Steel Suction Valve Complete (KM‐56, KM‐57 & KM‐58S) # 6 Planetary Gear Assembly 3.75:1 14 Tooth Input Spline SAE C Bolt Mount # 6 Planetary Gear Assembly With 1 1/2 Male Input Shaft 4.5:1 SAE C 4 Bolt Drive Assembly 1‐1/2 Male Input Shaft Housing, SAE C 4 Bolt Drive Assembly 1‐1/2 Male Input Shaft Input Shaft, SAE C 4 Bolt Drive Assembly 1‐1/2 Male Input Shaft Bearings, SAE C 4 Bolt Drive Assembly 1‐1/2 Male Input Shaft Oil Seal, SAE C 4 Bolt Drive Assembly 1‐1/2 Male Input Shaft Snap Ring, SAE C 4 Bolt Drive Assembly 1‐1/2 Male Input Shaft O'Ring, #8 Auburn Input Drive Assembly Oil Level Sight Glass Oil Level Sight Plug Wrench, Stuffing Box Nut Sunstrand Motor Series 90 Valve Assembly (Duplex Stainless) KM‐501DX, KM‐504, KM‐505, KM‐506, KM‐508DX Valve Assembly (Cast Steel) KM‐501CS, KM‐502, KM‐503, KM‐504, KM‐505, KM‐506 Valve Assembly (Stainless) , KM‐501SS, KM‐504, KM‐505, KM‐506, KM‐508SS Valve Seat (Cast Steel Heat Treated) Valve Seat (Duplex Stainless) Valve Seat (316 Stainless Steel) 3 3 1 1 3 3 3 3 3 3 3 3 1 1 1 1 1 2 1 1 1 1 1 1 1 6 6 6 6 6 6 Kerr KM-3250/KM-3250BC Plunger Type Pump
Part Number
Description
# Req
KM‐502CS KM‐502DX KM‐502SS KM‐503 KM‐503A KM‐503N KM‐503V KM‐504 KM‐505 KM‐506 KM‐508DX KM‐508SS KMC‐750 KM‐800‐750 KM‐800‐875 KM‐800‐100 KM‐800‐125 KM‐800‐150 KM‐800‐175 KM‐800‐200 KM‐800‐175 KMC‐875 KMC‐875 Valve Body Inserted (Cast Steel Heat Treated) Valve Body (Duplex Stainless) Valve Body (316 Stainless Steel) Abrasive Resistant Valve Insert (Polyurethane) Abrasive Resistant Valve Insert (Aflax) Abrasive Resistant Valve Insert (Nitrile) Abrasive Resistant Valve Insert (Fluorocarbon) Guide Cage (Stainless Steel) Valve Spring Valve O‐Ring Valve Body, Metal to Metal Type (Duplex Stainless) Valve Seat, Metal to Metal Type (316 Stainless Steel) Plunger 3/4 (Ceramic) Kerramic Plunger 3/4 Kerramic Plunger 7/8 Kerramic Plunger 1 Kerramic Plunger 1 1/4 Plunger Kerramic 1 1/2 Plunger Kerramic 1 3/4 Plunger Kerramic 2 Plunger Kerramic 1 3/4 Plunger 7/8 (Ceramic) Ceramic Plunger 7/8" 6 6 6 6 6 6 6 6 6 6 6 6 3 3 3 3 3 1 1 1 1 3 3 All prices and part numbers are subject to change without prior notice.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
