User manual | KLA-218

KLA-218
GPS Vehicle Tracker
KLA-218 represents the perfect combination of GSM, GPRS and GPS technologies. It's a good tool
to protect your car from thief. With fleet management platform, it can help the car rent company,
logistical company, tax company etc. to improve the management efficiency a lot.As a professional
security and positioning company, we will provide you with more and better products and services.
Features:
•
•
•
•
•
•
•
•
•
•
•
•
High sensitive GPS chipset,GSM 850/900/1800/1900 Quad-band High sensitive GPS
chipset,GSM 850/900/1800/1900 Quad-band
Individual or fleet tracking
Cut engine(remote control oil)
GPS chip: SIRF IV
24 hours real-time tracking
Both SMS tracking and web tracking available
Remote Control/monitor
Alarm when original car alarm system alarm; Geo fence
Voice Monitor, Overspeed Alert, history playback, SOS Alarm when the power supply is
disconnected intentionally (with backup battery)
Remote controlling oil and circuit
Mileage statistics; ACC checking; cutting off power and alarm.
Compatible with the original anti-theft alarm
Specifications:
Content
GSM Frequenccy
GPS Chips
GPRS GPS Sensitivity GPS Accuracy GSM Accuracy Speed Accuracy Cold Status
Warm Status Hot Status
Maximum Altitude
Highest speed
Acceleration of gravity
Dimensions
Weight
Working Temperature
Humidity
Voltage Current
Battery
Standby time
Stuandy Average current
LED
Specification
900/1800/1900MHz or
850/900/1800/1900MHz
SIRF Star IV
Class 12, TCP/IP build in
GSM Module
-160dBm
10m(2D RM)
50-200m
0.1m/s
-38s
-32s
-2s
18000m
515m/s
<4g
72.0(L) x 38.0(W) x12.0(H)
mm
110g
-20°C--+65°C
5%---95%RH
7--30v DC
60mA(12v DC) --35mA(24v
DC)
Chargeable changeable
400mAh Li-ion battery
3 hours
<80MA
Indicate the working
condition and other
conditions of GPS & GSM
