The Audioarts modular D-75 comes with four stereo busses, dual-domain outputs,
sample rate conversion on all digital inputs, and interchangeable input module
daughter cards for easy analog-to-digital field switches. The hinged meterbridge
allows easy access to console dipswitch programming. LED meter displays have fullscale digital peak plus VU metering. All switching features LED illumination, and an
automatic timer, built-in machine interface and clock all come standard. The D-75
may also be ordered with an optional SuperPhone module, which supports two
callers. The D-75 is available in two mainframe sizes (20- and 12-channels) with three
configurations (loaded with 18 or 12 channels). Console Dim: 28.75" or 40.83"W x
24.5"D x 7.63"H.
• D-75 Features:
• Cue function with auto-dropout
• Full scale digital peak plus VU or PPM metering
• Built-in machine interface
• Separate Source Selection for control room and studio
• Two air tally relays and four stereo busses
• Any combination of mic, analog line or digital audio inputs
• Heavy-duty on/off switches, and all switches LED illuminated
• Most trusted consoles in the industry—built for years of reliable performance
• Flexible, modular digital design
• Easy analog-to-digital field switching
D7512
D752012
D752018
12-channel modular audio console
20/12 modular audio console
20/18 modular audio console
List $10,075.00
List $10,775.00
List $12,875.00
Modules/Accessories:
SP75
LS75
TR75FF
TR75SS
CP75
SuperPhone input module
6 position stereo line selector
Tape remote/full function
Tape remote/start-stop
Copy stand
List
List
List
List
List
$776.00
$358.00
$328.00
$328.00
$410.00
Contact BSW For Lowest Prices
Modular and
networkable!​
D75N12
Networkable For Even More Versatility
The D-75N is an enhanced version of the Audioarts D-75 digital audio console that
permits integration with the Audioarts AENET Digital Router, as well as the Audioarts
IOC-16 Digital Audio I/O Center. This allows the D-75N (normally a standalone audio
console) to access a digital audio network system on six of its input faders (while its
other inputs operate independently), to provide networked flexibility to an individual
studio. In addition, the six router channels (collectively called the NET-75 panel) allow
two local stereo analog sources to be made available to the network system. At the
same time the D-75N’s four output busses (Program, Audition, Auxiliary and Utility) are
made available to the main router system through the console’s network Cat-5 link.
When you’re ready to network your consoles, you simply connect them via Cat-5 cable
using Audioarts’ network products, such as the IOC16 and AENET. The IOC-16 audio
input/output center acts as a networked intermediate link between a D-75N digital
audio console and the central NET router. THE IOC-16 chassis rear accepts plug-in card
modules for a clean and easy wiring installation. Each unit accepts four input and four
output cards (analog or AES digital) and each card can handle four stereo signals.
The AENET Router is a high-speed central switch that links multiple studios (via Cat5 cable) with your technical operations center. Each of its eight links can handle 64
bi-directional data paths with embedded control signals, allowing you to centralize
shared audio resources and integrate eight separate D-75N digital audio consoles as a
working network. An Ethernet link handles administrative tasks, and a Clock port allows
synchronization to an external master clock. Call BSW today for more info and prices.
D75N12
D75N2012
D75N2018
IOC16
IOC4
ENET8
12/12 networkable audio console
20/12 networkable audio console
20/18 networkable audio console
8 AES I/O; 16 analog I/O interface
4 AES I/O; 8 analog I/O interface
8-port Audio Network Switch
Connect Eight Studios
with Just Eight Cat-5 Wires
System Setup Is Easy:
Simply plug your D-75N console into the Audioarts AENET Router
located in your engineering room (where ESAT Audio Centers
provide input, output and logic cards for use with shared sources
and destinations). Note: Consoles, Net Router components and
Cable are all sold separately.
SP75
LS75
14
SuperPhone input module
6 position stereo line selector
ESAT
ESAT
ESAT
List $10,075.00
List $10,775.00
List $12,875.00
List $8,495.00
List $3,695.00
List $5,245.00
Contact BSW For Lowest Prices
Modules/Accessories:
ESAT
List List $776.00
$358.00
Depend on BSW for the Best Selection and Lowest Prices
ENET flow diagram
Best From Audioarts and BSW
BROADCAST CONSOLES
Economical
Air Series
from
Audioarts​
BSW
Customer
Favorite
Extra
channel for
phone
callers!
Fully Loaded
12-Channel Console
The Audioarts Air 3 12-channel
tablemount radio console
delivers superb broadcast
quality and a great feature set at
an extremely attractive price.
• 12 stereo input fader channels
• Remote START logic for each fader
• 13th phone caller fader w/TB and auto MXM to caller
• Two program busses with balanced outputs (switchable stereo or mono mode)
• Two mic preamps
AIR3
List $3,675.00
• Studio output with independent source selection and CR to studio TB button
• External input feeds the monitor section (for live air or pre-delay air monitoring)
• USB connection for extra versatility
• RJ45 connectors for low cost wiring
Contact BSW For Lowest Prices
Small Station
Console Breaks
The Price Barrier
The compact Audioarts AIR
1 eight-channel console has
everything you need for on-air,
production, news applications,
remotes or podcasting at a
budget-friendly price.
AIR1 List $1,885.00
• Dual Program busses
(can be stereo or mono sum)
• CUE can automatically interrupt main monitor
when activated
• Switched Meter displays PGM 1, PGM 2 or EXT
• Monitor Source Select listens to PGM 1, PGM 2 or EXT
• Dual Monitor Outs
(both main stereo
monitor and headphone)
• Long-Throw Faders on inputs and monitors
• Dual Mic Preamps for super-quiet high
performance
• Solid-state illumination on all switches
• Built-in headphone amp with
+20dB output
Contact BSW For Lowest Prices
High Quality Digital Audio in
a Compact Package
The Audioarts X-12 DIGITAL radio console features a sleek,
low profile 12-fader control surface that’s as simple to
install and use as an analog console. Its I/O design allows
the use of analog or AES digital sources or a combination
of both. Input channels each have selectable A/B sources,
LED illuminated ON, OFF, and CUE switches, and access to
three stereo program busses. Monitoring functions with
level control are available for control room, headphone
and studio. There’s a built-in cue speaker and headphone
jack, both with its own amplifier and level control. In
addition to the main program bus meters, there is a stereo
pair of switched LED bargraph meters that can monitor a
variety of signals. The X-12 DIGITAL is also equipped with
a patchable USB port for audio transfer to and from a
computer or other device.
• 12-fader low-profile control surface
• Modular I/O design allows analog and digital I/O
• A/B sources on each channel strip
• LED-illuminated switches
• 3 stereo program busses
X-12
List $6,995.00
• Control room and studio monitor outputs with independent level controls
• Headphone output with built-in amplifier and level control
• Two pairs of bright LED bargraph meters
• CUE bus with built-in amplifier and speaker
• Patchable bidirectional USB port for computer audio
Contact BSW For Lowest Prices
