Dell Interactive Projector S510/S510n User’s Guide

Dell Interactive Projector S510/S510n User’s Guide
Dell Interactive Projector
S510/S510n
User’s Guide
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make
better use of your projector
CAUTION: A CAUTION indicates potential damage to hardware or
loss of data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
____________________
Information in this document is subject to change without notice.
© 2015 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written
permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP
and DLP logo are trademarks of TEXAS INSTRUMENTS INCORPORATED; Microsoft and
Windows are either trademarks or registered trademarks of Microsoft Corporation in
the United States and/or other countries.
Other trademarks and trade names may be used in this document to refer to either
the entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Model: Dell Interactive Projector S510/S510n
February 2015 Rev. A01
Contents
1
About Your Dell Projector .
. . . . . . . . . . . . . . . .
Projector Box Contents . . . . . .
Projector Top and Bottom View .
2
. . . . . . . . . . . . . .
5
7
. . . . . . . . . . . . . . . .
9
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
9
9
10
11
12
17
. . . . . . . . . . . . . . . . . . . .
31
Setting Up Your Projector .
Cleaning Projector's Mirror
Adjusting Projector Focus .
Adjusting Image Size . . . .
Adjusting Image Shape . . .
Using Remote Control . . .
Projector Connections . . .
3
Using Your Projector
. . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
Turning Projector On . . . . . . . . . . . . . . . .
Turning Projector Off . . . . . . . . . . . . . . . .
Menu Settings . . . . . . . . . . . . . . . . . . . . .
Using Interactive Pen (Only for S510) . . . . .
Using Intel® WiDi . . . . . . . . . . . . . . . . . . .
Using Miracast . . . . . . . . . . . . . . . . . . . . .
Using Wireless/LAN Display (DoWiFi/DoLAN)
Using USB Display (DoUSB) . . . . . . . . . . . .
Using PC-Free Presentation . . . . . . . . . . . .
Using Audio Projection . . . . . . . . . . . . . . .
Managing Projector with Web Browser . . . .
4
Troubleshooting Your Projector .
Specifications .
. . . . .
. . . . .
. . . . .
. . . . .
. . . . .
. . . . .
. . . . .
. . . . .
. . . . .
. . . .
. . . . .
31
31
32
51
59
68
74
91
94
102
111
. . . . . . . . .
130
. . . . . . . . . . . . .
. . . . . . . . . . . . .
135
136
138
140
. . . . . . . . . . . . . . . . . . . . . . . .
142
Guiding Signals . . . . . . . . . . .
Changing the Lamp . . . . . . . .
FAQS: . . . . . . . . . . . . . . . . .
Firewall Configuration and FAQ
5
5
RS232 Pin Assignment
. . . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
146
Contents
|
3
6
4
Contacting Dell
. . . . . . . . . . . . . . . . . . . . . . .
148
Contacting Crestron
. . . . . . . . . . . . . . . . . . . .
149
7
Appendix: Glossary
. . . . . . . . . . . . . . . . . . . .
150
|
Contents
1
About Your Dell Projector
Your projector comes with all the items shown below. Ensure that you have
all the items, and contact Dell if anything is missing.
Projector Box Contents
S510 Package Contents
Power cable
VGA cable (VGA to VGA)
Remote control
AAA Batteries (6)
A
A
A
Page Up
A
Page Down
Freeze
VGA
Video
HDMI
Source
Auto
Adjust
Blank
Screen
Video
Mode
A
A
Aspect
Ratio
CD User’s Guide and Documentation Mini USB cable (USB-A to Mini
USB-B)
Informacion Importante
ive
Interact
Dell™ 510n
S510/S
Project
or
Dell
oduc
Dell ™ Projector
TM
Proje
ctors
t Info
rmat
ion
Guid
Documen tation
S510/S510n
e
08K5P4A01
gh
ts
re
se
r
ve
d.
Contents:
• User's Guide
P/N 8K5P4 Rev.
A01
P/N 36.73901G001
January 2015
Made in China
01
©2
5D
e ll
In c
ll
. A
ri
IR Pen (2 pcs)/Pen tip cap (4 pcs)
Wrist strap (2 pcs)
About Your Dell Projector
5
S510n Package Contents
Power cable
VGA cable (VGA to VGA)
Remote control
AAA Batteries (6)
A
A
A
Page Up
A
Page Down
Freeze
VGA
Video
HDMI
Source
Auto
Adjust
Blank
Screen
Video
Mode
CD User’s Guide and Documentation
Informacion Importante
ive
Interact
Dell™ 510n
S510/S
Project
or
Dell
oduc
Dell ™ Projector
TM
Proje
ctors
t Info
rmat
ion
Guid
Documen tation
S510/S510n
e
08K5P4A01
gh
ts
re
se
r
ve
d.
Contents:
• User's Guide
P/N 8K5P4 Rev.
A01
P/N 36.73901G001
January 2015
Made in China
6
01
©2
5D
e ll
In c
ll
. A
A
A
Aspect
Ratio
ri
About Your Dell Projector
Projector Top and Bottom View
Top View
Bottom View
8
10
2 1
7
38.80
4
151.30
112.50
5
7
6 9
3
1
Power button
2
Temp LED
3
Lamp LED
4
IR receivers
5
Lamp cover
6
Camera (only for S510)
7
10 W speaker
8
Lens
163.00
9
Focus ring
10
Mounting holes for wall mount: Screw hole M4 x 8 mm depth.
Recommended torque <10 kgf-cm
About Your Dell Projector
7
CAUTION: Safety Instructions
1 Do not use the projector near appliances that generate a lot of heat.
2 Do not use the projector in areas where there is an excessive amount of
dust. The dust may cause the system to fail and the projector will
automatically shutdown.
3 Ensure that the projector is mounted in a well-ventilated area.
4 Do not block the ventilation slots and openings on the projector.
5 Ensure the projector operates between ambient temperatures (5 °C to
35 °C).
6 Do not try to touch the ventilation outlet as it can become very hot after
the projector has been turned on or immediately after it is turned off.
7 Do not look into the lens while the projector is on as it may cause injury to
your eyes.
8 Do not place any objects near or in front of the projector or cover its lens
while the projector is on as the heat may cause the object to melt or burn.
9 Do not use the wireless projector near cardiac pacemakers.
10 Do not use the wireless projector near medical equipment.
11 Do not use the wireless projector near microwave ovens.
NOTE:
•Do not attempt to wall mount the projector by yourself. It should be
installed by a qualified technician.
•Recommended Projector Wall Mount Kit (P/N: 7XY53). For more
information, see the Dell Support website at dell.com/support.
•For more information, see the Safety Information that shipped with
your projector.
•The S510/S510n projector can only be used indoors.
8
About Your Dell Projector
2
Setting Up Your Projector
Cleaning Projector's Mirror
1 Turn off the projector power and disconnect the power cord.
2 Let the projector cool for at least 30 minutes.
3 Use air blower bulb to blow off dust on the mirror or gently wipe the mirror
by using a microfiber cleaning cloth. Do not scrub the surface of the
mirror. It may scratch the mirror.
CAUTION: Do not spray cleaners or solvents directly on the
projector.
WARNING: Cleaning a wall-mounted projector can result in a fall
or injury. You can remove the projector from the wall-mounting
bracket to clean the projector's mirror.
Adjusting Projector Focus
1 Rotate the focus ring until the image is clear. The projector focuses at
distances ranging between 1.7 ft to 2.49 ft (0.517 m to 0.759 m ± 0.01 m).
1
1
Focus ring
Setting Up Your Projector
9
0.872’ (26.6 cm)
1.05’ (32 cm)
1.122’ (34.2 cm)
Projector to screen distance (d)
1.391’ (42.4 cm)
Adjusting Image Size
0.597’ (18.2 cm)
70" (177.8 cm)
80" (203.2 cm)
87.2" (221.49 cm)
90" (228.6 cm)
100" (254 cm)
10
Setting Up Your Projector
Adjusting Image Shape
Image size
Projector
base to top of
Height (cm) image (cm)
Width (cm)
[H]
[D]
Projector
base to
bottom of
image (cm)
[E]
Projection
Distance
(cm)
[A]
Projection
Distance
(cm)
[B]
Diagonal
(inch/cm)
[C]
51.7
18.2
70"/ 177.8 cm
148
92
120
28
60.1
26.6
80"/203.2 cm
172
107
139
32
65.5
32
87.2"/221.4 cm
187
117
151
34
67.7
34.2
90"/228.6 cm
193
121
156
35
75.9
42.4
100"/254 cm
217
136
175
39
* This graph is for user reference only.
* Offset Ratio: 125±5%
NOTE: The distance from mirror to the rear of projector: 33.5 cm
33.5 cm
[E]
Projection Distance [B]
Projection Distance [A]
Height Image
[D]
Height
[H]
Diagonal
[C]
Setting Up Your Projector
11
Using Remote Control
1
2
15
16
3
4
17
5
Aspect
Ratio
18
19
20
21
22
23
24
Page Up
Page Down
Freeze
VGA
Video
HDMI
Source
Auto
Adjust
Blank
Screen
Video
Mode
6
7
8
9
10
11
12
25
13
26
14
1
Power
Turns the projector on or off. For more
information, see "Turning Projector On" on
page 31 and "Turning Projector Off" on
page 31.
2
Up
Press to navigate through the On-Screen
Display (OSD) Menu items.
Right
Press to navigate through the On-Screen
Display (OSD) Menu items.
3
4
12
Down
Press to navigate through the On-Screen
Display (OSD) Menu items.
Setting Up Your Projector
5
Point the remote control at the screen,
press and hold the laser button to activate
the laser light.
Laser
CAUTION: Do not look at the laser
point when it is active. Avoid
directing the laser light on your eyes.
6
Aspect Ratio
7
Page up
Aspect
Ratio
Press to change the aspect ratio of a
displayed image.
Press to move to the previous page.
Page Up
NOTE: The Mini USB cable must be
connected if you want to use the
Page Up feature.
8
Keystone adjustment +
Press to adjust image distortion caused by
tilting the projector (-15/+15 degrees).
9
Page down
Press to move to the next page.
Page Down
NOTE: The Mini USB cable must be
connected if you want to use the
Page Down feature.
10
Keystone adjustment -
Press to adjust image distortion caused by
tilting the projector (-15/+15 degrees).
11
HDMI
HDMI
Press to choose HDMI source.
12
Video
Video
13
Video mode
The projector has preset configurations
that are optimized for displaying data
(presentation slides) or video (movies,
games, etc.).
Press the Video Mode button to toggle
between Presentation mode, Bright mode,
Movie mode, sRGB, or Custom mode.
Pressing the Video Mode button once will
show the current display mode. Pressing
the Video Mode button again will switch
between modes.
14
Blank screen
Press to hide/unhide the image.
15
Enter
Press to confirm the selection.
Press to choose Composite Video source.
Setting Up Your Projector
13
16
Left
Press to navigate through the On-Screen
Display (OSD) Menu items.
17
Menu
Press to activate the OSD.
18
Mute
Press to mute or un-mute the projector
speaker.
19
Volume up
Press to increase the volume.
20
Zoom +
Press to increase the image.
21
Volume down
Press to decrease the volume.
22
Zoom -
Press to decrease the image.
23
Freeze
Press to pause the screen image, then
press "Freeze" again to unfreeze the image.
24
VGA
25
Source
Press to switch between VGA-A, VGA-B,
Composite, HDMI-A, HDMI-B, Wireless
Display, USB Display, USB Viewer, Intel®
WiDi, and Internal Memory source.
26
Auto Adjust
Press to synchronize the projector with the
input source. Auto adjust does not operate
if the OSD is displayed.
14
Freeze
VGA
Press to choose VGA source.
Setting Up Your Projector
Installing Remote Control Batteries
NOTE: Remove the batteries from the remote control when not in
use.
1 Press the tab to lift the battery compartment cover.
2 Check the polarity (+/-) marking on the batteries.
1
2
according to the marking in the battery compartment.
AAA
AAA
3 Insert the batteries and align their polarity correctly
3
NOTE: Avoid mixing different types of batteries
or using new and old batteries together.
AAA
AAA
4 Slip the battery cover back.
4
Setting Up Your Projector
15
Remote Control Operating Range
Operating range
±40°
Angle
Distance
7 m/22.97 feet
Video
Mode
Page Down
HDMI
Blank
Screen
Auto
Adjust
Source
Page Up
Distance
Distance
Freeze
VGA
Video
Aspect
Ratio
Angle
Angle
Aspect
Ratio
Page Up
Page Down
Freeze
VGA
Video
HDMI
Source
Auto
Adjust
Blank
Screen
Video
Mode
NOTE: Actual operating range may slightly differ from the diagram.
Weak batteries will also prevent the remote control from properly
operating the projector.
16
Setting Up Your Projector
Projector Connections
1
2
3
4
5
6
7
8
9
Mini USB (Mini Type B)
10
connector for remote control,
interactive pen (only for S510),
and firmware upgrade
HDMI-B connector
11
HDMI-A/MHL connector for
support MHL feature
USB Type A connector for USB
Viewer
USB Type B connector
(DoUSB) for USB Display
VGA output (monitor loop
through) connector
RJ-45 connector
VGA-A input (D-sub)
connector
Audio-A input connector
Audio right-channel input
connector
12
Audio left-channel input
connector
Audio output connector
13
Power cord connector
14
Microphone connector
15
Composite Video connector
16
17
Audio-B input connector
VGA-B input (D-sub)
connector
RS232 connector
18
CAUTION: Before you begin any of the procedures in this section,
follow the Safety Instructions as described on page 8.
NOTE: Camera feature only support the S510 projector.
Setting Up Your Projector
17
Connecting to a Computer
Connecting to Computer for VGA Video
1
2
Power cord
VGA to VGA cable
3
USB-A to Mini USB-B cable
NOTE: The Mini USB cable must be connected if you want to use the
Page Up and Page Down features on the remote control.
18
Setting Up Your Projector
Connecting to Computer for HDMI Video and Audio
1
2
Power cord
HDMI cable
NOTE: The HDMI cable is not shipped with your projector. You can
purchase the HDMI cable on the Dell website at www.dell.com.
Setting Up Your Projector
19
Connecting to Computer for USB Video and Audio
1
2
Power cord
USB-A to USB-B cable
NOTE: Plug and Play. Only one USB cable is shipped with your
projector. An additional USB cable can be purchased on the Dell
website at www.dell.com.
20
Setting Up Your Projector
Connecting to Computer for RS232 Video
1
2
Power cord
RS232 (9-pin D-sub female to female
pin2-3 swap) cable
NOTE: The RS232 (9-pin D-sub female to female pin2-3 swap) cable
is not shipped with your projector. Consult a professional installer for
the cable and RS232 remote control software.
Setting Up Your Projector
21
Connecting to Computer for Intel® WiDi or Wireless Display (DoWiFi)
NOTE: Your computer should be equipped with a wireless adapter
and properly configured to detect another wireless connection. Refer
to your computer’s documentation on how to configure a wireless
connection.
NOTE: To connect a computer via Intel® WiDi, your computer must
be Intel® WiDi compatible.
For more information, see "Using Intel® WiDi" on page 59 and "Using
Wireless/LAN Display (DoWiFi/DoLAN)" on page 74.
22
Setting Up Your Projector
Connecting to Tablets and Smartphones for MHL Video and Audio
1
2
Power cord
MHL cable
NOTE: The MHL cable is not shipped with your projector.
NOTE:
a Your smartphone or tablet must support MHL function.
b Some smartphone or tablet need to connect the additional MHL
adapter or adapter cable, please contact your dealer of devices.
Setting Up Your Projector
23
Connecting to Tablets or Smartphones for Wireless Presentation
Using WiFi-Doc and MobiShow
NOTE: Dell S510/S510n supports wireless presentation from Android
and iOS devices. Download MobiShow and WiFi-Doc (Bundle Version)
mobile applications from Google Play or App Store. These
applications enable you to transmit supported content from your
Android or iOS devices wirelessly. After installing and launching the
application on your mobile device, enable Wi-Fi on your mobile
device and connect to the projector network, Dell S510 or S510n.
Files supported are:
Mobi Show
WiFi-Doc
Photos
MS Powerpoint
Photos
MS Powerpoint / Word /
Excel / Text / PDF
jpeg / jpg
PtG2 (converted from ppt)*
jpeg / jpg
ppt / pptx / doc / docx /
xls / xlsx / txt / pdf
For information on use of MobiShow and WiFi-Doc, go to Dell Support site,
dell.com/support and browse manuals for Dell S510/S510n.
* Please install the PtG2 Converter into your PC for file conversion of ppt into
PtG2 format. PtG2 Converter can be downloaded from dell.com/support.
24
Setting Up Your Projector
Connecting to Tablets or Smartphones for Wireless Streaming of
Video and Audio Using Miracast
For more information, see "Using Miracast" on page 68.
Setting Up Your Projector
25
Connecting to Video Sources
Connecting to External Monitor for Loop-Through VGA Video
1
2
Power cord
VGA to VGA cable
NOTE: Only one VGA cable is shipped with your projector. An
additional VGA cable can be purchased on the Dell website at
www.dell.com.
26
Setting Up Your Projector
Connecting to External Speakers
1
2
Power cord
Audio cable
NOTE: The audio cable is not shipped with your projector.
Setting Up Your Projector
27
Connecting to External USB Devices
USB Memory Storage
1
2
Power cord
USB flash disk
NOTE: The USB flash disk is not shipped with your projector.
For more information, see "Using PC-Free Presentation" on page 94
28
Setting Up Your Projector
Connecting to Local Area Network (LAN)
To project an image and control the projector that is connected to a
network through a RJ45 cable.
For configuring the network setting, refer to "Network Setup" on page 116.
Local Area Network (LAN)
1
2
Power cord
RJ45 cable
NOTE: The RJ45 cable is not shipped with your projector. You can
purchase the RJ45 cable on the Dell website at www.dell.com.
Setting Up Your Projector
29
Connecting to Commercial RS232 Control Box
1
2
Power cord
RS232 (9-pin D-sub female to female
pin2-3 swap) cable
Commercial RS232 control box
3
NOTE: The RS232 (9-pin D-sub female to female pin2-3 swap) cable
is not shipped with your projector. Consult a professional technician
to obtain the cable.
30
Setting Up Your Projector
3
Using Your Projector
Turning Projector On
NOTE: Turn on the projector before you turn on the source
(computer, DVD player, etc.). The Power button light blinks white
until pressed.
1 Connect the power cord and appropriate signal cables to the projector.
For information about connecting the projector, see "Setting Up Your
Projector" on page 9.
2 Press the Power button (see "Using Remote Control" on page 12 to locate
the Power button).
3 Turn on your source (computer, DVD player, etc.)
4 Connect your source to the projector using the appropriate cable. See
"Setting Up Your Projector" on page 9 for instructions to connect your
source to the projector.
5 By default, the input source of the projector is set to VGA-A. Change the
input source of the projector if necessary.
6 If you have multiple sources connected to the projector, press the Source
button on the remote control to select the desired source. See "Using
Remote Control" on page 12 to locate the Source button.
Turning Projector Off
CAUTION: Unplug the projector after properly shutting down as
explained in the following procedure.
1 Press the Power button. Follow the instruction displayed on screen to
properly turn off the projector.
NOTE: The "Press Power Button to Turn off Projector" message
will appear on the screen. The message disappears after 5 seconds
or you can press the Menu button to clear it.
2 Press the Power button again. The cooling fans continue to operate for
120 seconds.
3 To power off the projector quickly, press the Power button and hold for 1
second while the projector’s cooling fans are still running.
Using Your Projector
31
NOTE: Before you turn on the projector again, wait for 60 seconds
to allow the internal temperature to stabilize.
4 Disconnect the power cord from the electrical outlet and the projector.
Menu Settings
• The projector has a multi-language On-Screen Display (OSD) Menu that
can be displayed with or without an input source.
• Press the Menu button on the remote control to enter the Main Menu.
• To navigate through the tabs in the Main Menu, press the
or
buttons on the remote control.
• To select a submenu, press the
or
button on the remote control.
• To select an option, press the
or
buttons on the remote control.
When an item is selected, the color changes to dark blue.
• Use the
or
buttons on the remote control to adjust the settings.
• To go back to the Main Menu, press the
button on the remote control.
• To exit the OSD, press the Menu button directly on the remote control.
INPUT SOURCE
The Input Source menu allows you to select your projector's input source.
VGA-A—Press
to detect a VGA-A signal.
VGA-B—Press
to detect a VGA-B signal.
HDMI-A/MHL—Press
HDMI-B—Press
to detect a HDMI-A/MHL signal.
to detect a HDMI-B signal.
WIRELESS/LAN—Press
to activate the Input Source WIRELESS/LAN
menu.
NOTE: The WIRELESS/LAN can be used after the "Wireless and LAN"
option is turned on.
USB—Press
32
to activate the Input Source USB menu.
Using Your Projector
NOTE: The USB can be used after the "Wireless and LAN" option is
turned on.
COMPOSITE—Press
to detect a Composite Video signal.
INTERNAL MEMORY—Allows you to playback the photo, video, music, and
MS word, excel, powerpoint, and PDF files from internal memory of the
projector.
NOTE: The internal memory can be used after the "Wireless and
LAN" option is turned on.
NOTE:
STORAGE MODE—You may also connect USB cable in Internal
Memory source to execute copy, delete, move and more
instructions from your computer to projector internal memory.
When you connect the projector and computer via USB cable,
a USB Connected message will pop up and allow you to select
DoUSB or Storage Mode.
INPUT SOURCE WIRELESS/LAN
The Input Source Wireless/LAN menu allows you to activate the Intel®
WIDI/Miracast and Wireless/LAN Display.
INTEL® WIDI/MIRACAST—Press
to access the projector's Intel® WIDI or
Miracast Guide screen.
WIRELESS/LAN DISPLAY—Press
to access the projector's Wireless or
Using Your Projector
33
LAN Guide screen. See "Wireless/LAN Guide screen" on page 75.
INPUT SOURCE USB
The Input Source USB menu allows you to activate the USB Display and USB
Viewer.
USB DISPLAY—Allows you to display the computer/laptop screen to your
projector via the USB cable.
NOTE: If the DoUSB can't display, please see "Troubleshooting Your
Projector" on page 130.
USB VIEWER—Allows you to playback the photo, video, music, and MS word,
excel, powerpoint, and PDF files from your USB flash disk.
AUTO ADJUST
Auto Adjust automatically adjusts the projector's Horizontal, Vertical,
Frequency, and Tracking in PC mode.
34
Using Your Projector
BRIGHTNESS/CONTRAST
The Brightness/Contrast menu allows you adjust the brightness/contrast
settings of your projector.
BRIGHTNESS—Use
CONTRAST—Use
and
and
to adjust the brightness of the image.
to adjust the display contrast.
NOTE: If you adjust the settings for Brightness and Contrast the
projector automatically switches to Custom mode.
VIDEO MODE
The Video Mode menu allows you to optimize the display image:
Presentation, Bright, Movie, sRGB (provides more accurate color
representation), and Custom (set your preferred settings).
Using Your Projector
35
AUDIO VOLUME
The Audio Volume menu allows you adjust the Audio, Microphone, Master
volume settings of your projector.
AUDIO VOLUME—Press
to increase the audio volume and
decrease the audio volume.
to
MIC VOLUME—Press
to increase the microphone volume and
decrease the microphone volume.
Master Volume—Press
volume and
to increase the audio and microphone
decrease the audio and microphone volume.
AUDIO EQ
The Audio EQ menu allows you adjust the audio to boost or reduce
(attenuating) the levels of different frequencies in a signal.
36
Using Your Projector
to
ADVANCED SETTINGS
The Advanced Settings menu allows you to change settings for Image,
Display, Projector, LAN, Wireless, Menu, Power, and Information.
IMAGE SETTINGS (IN PC MODE)—Select and press
to activate image
settings. The image settings menu provides the following options:
COLOR TEMPERATURE—Allows you to adjust the color temperature. The
screen appears cooler at higher color temperatures and warmer at
lower color temperatures. When you adjust the values in the Color
Adjust menu, the Custom mode is activated. The values are saved in
the Custom mode.
RGB COLOR ADJUST—Allows you to manually adjust the colors red,
green, and blue.
WHITE INTENSITY—Press
intensity.
and use
and
to display white
COLOR SPACE—Allows you to select the color space. The options are:
RGB, YCbCr, and YPbPr.
VGA OUTPUT—Select On or Off the VGA output function at projector
standby status. Default is Off.
NOTE: If you adjust the settings for Color Temperature, RGB Color
Adjust, and White Intensity the projector automatically switches to
Custom mode.
Using Your Projector
37
IMAGE SETTINGS (IN VIDEO MODE)—Select and press
to activate image
settings. The image settings menu provides the following options:
COLOR TEMPERATURE—Allows you to adjust the color temperature. The
screen appears cooler at higher color temperatures and warmer at
lower color temperatures. When you adjust the values in the Color
Adjust menu, the Custom mode is activated. The values are saved in
the Custom mode.
RGB COLOR ADJUST—Allows you to manually adjust the colors red,
green, and blue.
SATURATION—Allows you to adjust the video source from black and
white to fully saturated color. Press
to increase the amount of
color in the image and
to decrease the amount of color in the
image.
SHARPNESS—Press
the sharpness.
to increase the sharpness and
to decrease
TINT—Press
to increase the amount of green in the image and
to decrease the amount of green in the image.
WHITE INTENSITY—Press
intensity.
and use
and
to display white
COLOR SPACE—Allows you to select the color space. The options are:
RGB, YCbCr, and YPbPr.
VGA OUTPUT—Select On or Off the VGA output function at projector
standby status. Default is Off.
NOTE:
1
38
If you adjust the settings for Color Temperature, RGB Color Adjust,
Saturation, Sharpness, Tint, and White Intensity the projector
automatically switches to Custom mode.
Using Your Projector
2
Saturation, Sharpness, and Tint only available when the input source
is from Composite.
IMAGE SETTINGS (NO INPUT SOURCE)—Select and press
to activate
image settings. The image settings menu provides the following options:
VGA OUTPUT—Select On or Off the VGA output function at projector
standby status. Default is Off.
DISPLAY SETTINGS (IN PC MODE)—Select and press
to activate display
settings. The display settings menu provides the following options:
HORIZONTAL POSITION—Press
move the image left.
VERTICAL POSITION—Press
the image down.
to move the image right and
to move the image up and
to
to move
FREQUENCY—Allows you to change the display data clock frequency to
match the frequency of your computer’s graphics card. If you see a
vertical flickering wave, use the Frequency control to minimize the
bars. This is a coarse adjustment.
TRACKING—Synchronize the phase of the display signal with the
graphic card. If you experience an unstable or flickering image, use
Tracking to correct it. This is a fine adjustment.
Using Your Projector
39
ASPECT RATIO—Allows you to select the aspect ratio to adjust how the
image appears. Options are: Origin, 16:10, and 4:3.
•Origin — Select Origin to maintain the aspect ratio of the image
projector according to the input source.
•16:10 — The input source scales to fit the width of the screen to
project a 16:10 screen image.
•4:3 — The input source scales to fit the screen and projects a 4:3
image.
ZOOM—Press
and
to zoom and view the image.
Adjust the image scale by pressing
or
and press
to view on your remote
control only.
ZOOM NAVIGATION—Press
to activate the
Zoom Navigation menu.
Use
screen.
to navigate the projection
3D FORMAT—Allows you to select the 3D format. Options are: Side By
Side, Side By Side Full, Top/Bottom, and Top/Bottom Full.
3D SYNC INVERT—If you see a discrete or overlapping image while
wearing DLP 3D goggles, you may need to execute 'Invert' to get
best match of left/right image sequence to get the correct image.
(For DLP 3D goggles)
NOTE:
When you want to create a 3D experience, you will need a
few other components including:
a "Active" 3D glasses with DLP Link™.
b 3D content. See "Note 2".
c 3D Player.
2 HDMI 1.4a 3D support and refresh rate are as below:
a [email protected] Hz Frame Packing
b [email protected]/60 Hz Frame Packing
c [email protected]/24 Hz Frame Packing
d [email protected] Hz Side by Side Half
e [email protected]/60 Hz Side by Side Half
f [email protected] Hz Top and Bottom
1
40
Using Your Projector
g
h
[email protected]/60 Hz Top and Bottom
[email protected]/24 Hz Top and Bottom
DISPLAY SETTINGS (IN VIDEO MODE)—Select and press
to activate
display settings. The display settings menu provides the following options:
ASPECT RATIO—Allows you to select the aspect ratio to adjust how the
image appears. Options are: Origin, 16:10, and 4:3.
•Origin — Select Origin to maintain the aspect ratio of image projector
according to the input source.
•16:10 — The input source scales to fit the width of the screen to
project a 16:10 screen image.
•4:3 — The input source scales to fit the screen and projects a 4:3
image.
ZOOM—Press
and
to zoom and view the image.
Adjust the image scale by pressing
or
and press
to view on your remote
control only.
ZOOM NAVIGATION—Press
to activate the
Zoom Navigation menu.
Use
screen.
to navigate the projection
3D FORMAT—Allows you to select the 3D format. Options are: Side By
Side, Side By Side Full, Top/Bottom, and Top/Bottom Full.
3D SYNC INVERT—If you see a discrete or overlapping image while
wearing DLP 3D goggles, you may need to execute 'Invert' to get
best match of left/right image sequence to get the correct image.
(For DLP 3D goggles)
Using Your Projector
41
NOTE:
When you want to create a 3D experience, you will need a
few other components including:
a "Active" 3D glasses with DLP Link™.
b 3D content. See "Note 2".
c 3D Player.
2 HDMI 1.4a 3D support and refresh rate are as below:
a [email protected] Hz Frame Packing
b [email protected]/60 Hz Frame Packing
c [email protected]/24 Hz Frame Packing
d [email protected] Hz Side by Side Half
e [email protected]/60 Hz Side by Side Half
f [email protected] Hz Top and Bottom
g [email protected]/60 Hz Top and Bottom
h [email protected]/24 Hz Top and Bottom
1
PROJECTOR SETTINGS—Select and press
to activate projector settings.
The projector settings menu provides the following options:
AUTO SOURCE—Select Off (the default) to lock the current input signal.
If you press the Source button when the Auto Source mode is set to
Off, you can manually select the input signal. Select On to auto detect
the available input signals. If you press the Source button when the
projector is on, it automatically finds the next available input signal.
PROJECTOR MODE—Allows you to select the projector mode,
depending upon how the projector is mounted.
•Rear Projection-Wall Mount — The projector reverses and turns the
image upside down. You can project from behind a translucent screen
with a wall-mounted projection (for regular projection).
•Front Projection-Wall Mount — The projector turns the image upside
down for wall-mounted projection.
42
Using Your Projector
CLOSED CAPTION—Select On to enable close caption and activate the
closed caption menu. Select appropriate closed caption options: CC1,
CC2, CC3, and CC4.
NOTE:
1
Closed caption option is available for NTSC only.
2 Closed captioning can only be enabled via Composite Video
input.
STARTUP SCREEN—Default is Dell logo as wallpaper. You can also select
Capture Screen option to capture the screen display. The following
message appears on the screen.
NOTE: To capture a full image, ensure that the input signal
connected to the projector is at 1280 x 800 resolution.
TEST PATTERN—Test Pattern is used to test focus and resolution.
You can enable or disable the Test Pattern by selecting Off, 1, or 2.
Test Pattern 1:
Test Pattern 2:
MINI USB FUNCTION—Allows you to select the Interactive Pen or
Remote Pg Ctrl.
NOTE: Mini USB function only support the S510 projector.
Using Your Projector
43
FACTORY RESET—Select Confirm and press
to reset all settings to
its factory default. The below warning message appears:
Reset items include both computer sources and Video source
settings.
LAN SETTINGS—Select and press
to activate LAN settings. The LAN
settings menu provides the following options:
WIRELESS AND LAN—Select Enabled to activate the Wireless and LAN
function. Select Disabled to deactivation the Wireless and LAN
function.
DHCP—If a DHCP server exists in the network to which the projector
is connected, the IP address will automatically be acquired when you
select DHCP On. If DHCP is Off, manually set the IP Address, Subnet
Mask, and Gateway. Use
and
to select the number of IP
address, Subnet Mask, and Gateway. Key in enter to confirm each
number and then use
and
to set the next item.
IP ADDRESS—Automatically or manually assigns the IP address to the
projector connected to the network.
SUBNET MASK—Configure the Subnet Mask of the network connection.
GATEWAY—Check the Gateway address with your network/system
administrator if you configure it manually.
DNS—Check the DNS Server IP address with your network/system
administrator if you configure it manually.
STORE—Press
settings.
44
to save the changes made in network configuration
Using Your Projector
NOTE:
Use
and
button to select IP Address, Subnet Mask,
Gateway, DNS, and Store.
2 Press the
button to enter IP Address, Subnet Mask,
Gateway or DNS to set the value. (The selected option is
highlighted in blue)
a Use
and
button to select the option.
b Use
and
button to set the value.
c After the setup is complete, press the
button to exit.
3 After the IP Address, Subnet Mask, Gateway, and DNS is set
button to store the settings.
up, select Store and press
4 If you select Store without pressing the Enter button, the
system will keep the original settings.
1
RESET—Press
to reset network configuration.
WIRELESS SETTINGS—Select and press
to activate wireless settings. The
wireless settings menu provides the following options:
DHCP SERVER—Allows you to enable DHCP server of the wireless.
START IP ADDRESS—Automatically or manually assigns the Start IP
address of the DHCP server to the projector connected to the wireless.
END IP ADDRESS—Automatically or manually assigns the End IP address
of the DHCP server to the projector connected to the wireless.
SUBNET MASK—Configure the Subnet Mask of the wireless connection.
GATEWAY—Check the Gateway address with your network/system
administrator if you configure it manually.
DNS—Check the DNS Server IP address with your network/system
administrator if you configure it manually.
STORE—Press
settings.
to save the changes made in wireless configuration
Using Your Projector
45
NOTE:
Use
and
button to select IP Address, Subnet Mask,
Gateway, DNS, and Store.
2 Press the
button to enter IP Address, Subnet Mask,
Gateway, or DNS to set the value. (The selected option is
highlighted in blue)
a Use
and
button to select the option.
b Use
and
button to set the value.
c After the setup is complete, press the
button to exit.
3 After the IP Address, Subnet Mask, Gateway, and DNS is set
button to store the settings.
up, select Store and press
4 If you select Store without pressing the Enter button, the
system will keep the original settings.
1
RESET—Press
to reset wireless configuration.
MENU SETTINGS—Select and press
to activate the menu settings. The
menu settings consists of the following options:
MENU POSITION—Allows you to change the position of the OSD menu
on the screen.
MENU TIMEOUT—Allows you to adjust the time for an OSD timeout. By
default, the OSD disappears after 20 seconds of non-activity.
MENU TRANSPARENCY—Select to change the transparency level of the
OSD background.
PASSWORD—When Password Protect is enabled, a Password Protect
screen requesting you to enter a password will be displayed when the
power plug is inserted into the electrical output and the power for the
projector is first turned on. By default, this function is disabled. You
can enable this feature by selecting Enabled. If the password has been
set before, key in the password first and select the function. This
46
Using Your Projector
password security feature will be activated the next time you turn on
the projector. If you enable this feature, you will be asked to enter the
projector’s password after you turn on the projector:
1
First time password input request:
a Go to Menu Settings, press
enable the password settings.
and then select Password to
b Enabling the Password function will pop up a change screen. Key in
a 4-digit number from the screen and press
.
c To confirm, enter the password again.
d If the password verification is successful, you may resume with
accessing the projector's functions and its utilities.
2
If you have entered an incorrect password, you will be given two more
chances. After three invalid attempts, the projector will automatically
turn off.
NOTE: If you forget your password, contact DELL or a
3
qualified service person.
To disable the password function, select the Disabled option to close
the function.
4
To delete the password, select the Delete option.
Using Your Projector
47
CHANGE PASSWORD—Key in the original password. Then, enter the new
password and confirm the new password again.
POWER SETTINGS—Select and press
to activate power settings. The
power settings menu provides the following options:
48
Using Your Projector
QUICK SHUTDOWN—Select On to turn off the projector with a single
press of the Power button. This function allows the projector to
quickly power off with an accelerated fan speed. Slightly higher
acoustic noise is expected during quick power off.
NOTE: Before you turn on the projector again, wait for 60
seconds to allow the internal temperature to stabilize. The
projector will take a longer time to turn on if you try to power
on immediately. Its cooling fan will run at full speed for about
30 seconds to stabilize the internal temperature.
POWER SAVING—By default, the projector is set to enter power saving
mode after 20 minutes of no activity. A warning message appears on
screen showing a 60 seconds countdown before switching to power
saving mode. Press any button during the countdown period to stop
the power-saving mode.
You can also set a different delay period to enter power saving mode.
The delay period is the time you want the projector to wait without an
input signal.
If an input signal is not detected during the delay period, the projector
turns off. To turn on the projector press the Power button.
DURING STANDBY—Select Wireless On or Off set the Wireless/LAN
model on/off while the projector is standby status (default is Wireless
Off).
LAMP MODE—Allows you to select the Normal, ECO, Dynamic, or
Extreme Dimming mode.
Normal mode operates at full power level. ECO mode operates at a
lower power level which may provide longer lamp life, quieter
operation, and dimmer luminance output on the screen.
DYNAMIC—Select and press
to activate dynamic feature.
EXTREME DIMMING—Select and press
feature.
LAMP HOUR RESET—Press
the lamp hour.
to activate extreme dimming
and select the Confirm option to reset
Using Your Projector
49
INFORMATION—The information menu displays the current S510 or S510n
projector settings.
LANGUAGE
Allows you to set the language for the OSD. Press
Language menu.
to activate the
HELP
If you encounter problems with your projector, you can access the help
menu for troubleshooting.
50
Using Your Projector
Using Interactive Pen (Only for S510)
System Requirements
NOTE: You computer must have the following minimum system
requirements:
Operating System:
•
Windows
Windows XP Professional service pack 3 32-bit, Windows 7 32bit/64-bit, Windows 8 32-bit/64-bit, and Windows 8.1 32-bit/64-bit
Windows .NET Framework 4.0 installation is required (You can
download it from the Microsoft site)
•
Mac
MacOS 10.6 and above
Minimum Hardware:
a
Windows processor type: Intel Core i3 or above
b
MAC processor type: Intel Core i2 duo or above
c
Windows/MAC RAM: 2 GB of RAM required or more are
recommended
d
Windows/MAC Min. HDD space: 110 MB of available hard-disk
space
Using Your Projector
51
About Your Interactive Pen (Only for S510)
You can navigate, select, and interact with your computer programs from the
projected screen using the interactive pens just as you would a mouse.
3
2
1
4
5
1
Power switch
2
Power indicator
As you turn on the pen, the power indicator flashes a few seconds
and goes off.
Green: Normal operation
Red: Battery is low
No light: Battery is empty
3
Wrist strap holder
4
Battery compartment access. Turn to open and replace batteries.
5
Pen tip
52
Using Your Projector
Replacing the Interactive Pen Tips (Only for S510)
NOTE: If the pen tip becomes damaged or no longer works well,
you should replace them.
Using Your Projector
53
Replacing the Interactive Pen Batteries (Only for S510)
NOTE: If the battery is low, the LED indicator starts flashing red as
you turn on the pen. You should replace with two new AAA batteries.
1 You can access the battery compartment by turning open the pen head.
2 Check the polarity (+/-) marking on the batteries.
3 Insert the batteries and align their polarity correctly according to the
marking on the pen head.
NOTE: Avoid mixing different types of batteries or using new and
old batteries together.
4 Place the pen head back, turn until the battery compartment access fully
closed.
54
Using Your Projector
Using Interactive Pen with Windows
1
Connect power, VGA, mini USB cables to projector.
Dell S510
2
Power on the projector by pressing the power button on the
remote control.
3
Connect VGA and mini USB cables to your computer.
MOLEX
Using Your Projector
55
4
The PenDriver install message will pop-up automatically after
you plug in the USB cable to your computer. Follow the onscreen instruction to complete setup.
The driver icon
will appear in your computer's notification
area if the driver has installed successfully.
If the Pen driver is not automatically installed, go to My
Computer and run "PenDriver.exe".
NOTE: You may require administrator-level access to install the
driver. Contact your network administrator for support.
Using Interactive Pen with Mac
5
Repeat steps 1 - 3 to turn on the projector power and connect
VGA and USB cables.
6
Search CD-ROM of the PenDriver in your computer.
7
Double-click PenDriver.zip file from the MAC folder.
8
Execute the PenDriver.app in the Download folder.
9
Refer to steps 5 - 7 to execute the initialize the control function
and start using your IR Pen.
56
Using Your Projector
Pen Calibration
10
Click the Pen driver
icon, select Calibrate pen and then
select Auto on the sub-menu.
If the "auto calibrate failed" message prompts, please take the
steps below for troubleshooting, then do auto calibrate again.
a
Turn lights off or reduce stray light to whiteboard
b
Do not walk in front of or move the projector
c
Adjust focus to sharpen the projected image
If the "auto calibrate still failed" message appears on screen,
please change to manual calibrate.
Manual Calibrate:
Click the Pen driver
icon, select Calibrate pen and then
select auto calibrate still failed on the sub-menu.
1
2
3
4
Using Your Projector
57
Touch the target marks on the screen. (Press the "ESC" key to
exit the calibration process). After the 4th point of calibration is
finished, please wait for 2 seconds while the calibration data is
saved.
11
Turn on the power switch of the IR Pen.
12
Point the IR Pen to the screen, and start using your IR Pen.
58
Using Your Projector
Using Intel® WiDi
System Requirements
NOTE: Your computer must have the following Intel® Wireless
Display system requirements:
System
Component
Processor
Requirement
One of the following processors is required:
2nd generation Intel® Core™ i3/i5/i7 Mobile
Processor
3rd Generation Intel® Core™ i3/i5/i7 Mobile and
Desktop Processor
4th Generation Intel® Core™ i3/i5/i7 Mobile and
Desktop Processor
Intel® Pentium® N3510 Processor
Intel® Celeron® N2805 Processor
Intel® Celeron® N2810 Processor
Intel® Celeron® N2910 Processor
Intel® Atom® Z3740 Processor
Intel® Atom® Z3740D Processor
Intel® Atom® Z3770 Processor
Intel® Atom® Z3770D Processor
Using Your Projector
59
Graphics
One of the following graphics solutions is
required:
Intel® Iris™ Pro Graphics 5200
Intel® Iris™ Graphics 5100
Intel® HD Graphics 5000
Intel® HD Graphics 4600
Intel® HD Graphics 4400
Intel® HD Graphics 4200
Intel® HD Graphics 4000
Intel® HD Graphics 3000 (mobile)
Intel® HD Graphics 2500
Intel® HD Graphics 2000 (mobile)
Wireless
One of the following wireless adapters is
required:
Intel® Centrino® Wireless-N 1000, 1030, 2200, or
2230
Intel® Centrino® Wireless-N 2200 for Desktop
Intel® Centrino® Advanced-N 6200, 6205, 6230,
or 6235
Intel® Centrino® Advanced-N 6205 for Desktop
Intel® Centrino® Wireless-N + WiMAX 6150
Intel® Centrino® Advanced-N + WiMAX 6250
Intel® Centrino® Ultimate-N 6300
Intel® Dual Band Wireless-N 7260
Intel® Dual Band Wireless-AC 7260
Intel® Dual Band Wireless-AC 7260 for Desktop
Intel® Dual Band Wireless-AC 3160
Intel® Wireless-N 7260
Broadcom BCM43228
Broadcom BCM43241
Broadcom BCM4352
60
Using Your Projector
Software
Intel® My Wi-Fi Technology (Intel® MWT) and
Intel® Wireless Display must be pre-installed and
enabled.
Operating System
One of the following operating systems is
required:
Microsoft Windows 7
Microsoft Windows 8
Microsoft Windows 8.1
Enable Intel® WiDi on Projector
1
Connect the power cable and press the power button.
2
Press the Menu button on the remote control.
Aspect
Ratio
Page Up
Page Down
NOTE: Use
,
,
, and
buttons to navigate and
to select.
Using Your Projector
61
3
Access the Input Source menu, select Wireless/LAN and then select
Intel® WIDI/Miracast on the sub-menu.
The Intel® WiDi Guide Screen shown below appears:
4
Take note of the ADAPTER NAME and PIN CODE. You will need this
information to log-in later.
Using Intel® WiDi with Microsoft Windows 7 and Windows 8
NOTE: Get the latest Get the latest Intel® WiDi Software to ensure
the best experience, go to
http://www.intel.com/go/wirelessdisplayupdate.
1
62
Type WiDi in your Windows search bar. If your computer has built-in
Intel® WiDi, you will see the "Intel® WiDi" application in your search
results.
Using Your Projector
2
Connect your computer to Dell Projector.
3
Key in Security Code as provided in Step 4 of Enable Intel® WiDi on
Projector, for pairing confirmation.
Using Intel® WiDi with Microsoft Windows 8.1
NOTE: The Intel® WiDi features are accessed differently in Windows
8.1, and the Intel® WiDi software is not needed.
1
Bring up the Devices Charm.
Using Your Projector
63
2
Select "Project".
3
Select "Add a wireless display".
4
Choose detected Dell Projector.
64
Using Your Projector
5
Key in PIN as provided in Step 4 of Enable Intel® WiDi on Projector for
pairing confirmation.
6
Screen is projected.
7
To adjust projection modes or disconnect, bring up the Devices
Charm, select "Project". Alternatively, use the shortcut "Win + P" for
direct toggle.
Using Your Projector
65
Renaming Intel® WiDi Adapter
1
Select "Settings".
2
Select "Current Display Settings".
3
You may type a new descriptive name for the adapter.
66
Using Your Projector
Intel® WiDi Support
For most up-to-date information, visit Intel® WiDi website at
www.intel.com/go/widi
Using Your Projector
67
Using Miracast
Enable Miracast on Projector
1
Connect the power cable and press the power button.
2
Press the Menu button on the remote control.
Aspect
Ratio
Page Up
Page Down
NOTE: Use
3
68
,
,
, and
buttons to navigate and
to select.
Access the Input Source menu, select Wireless/LAN and then select
Intel® WIDI/Miracast on the sub-menu.
Using Your Projector
The Screen Guide shown below appears:
4
Take note of the ADAPTER NAME and PIN CODE. You will need this
information to log-in later.
Using Miracast with Windows 8.1
5
Bring up the Devices Charm.
6
Select "Project".
Using Your Projector
69
7
Select "Add a wireless display".
8
Choose detected Dell Projector.
9
Key in PIN as provided in Step 4 of Enable Miracast on Projector for
pairing confirmation.
70
Using Your Projector
10
Screen is projected.
11
To adjust projection modes or disconnect, bring up the Devices
Charm, select "Project". Alternatively, use the shortcut "Win + P" for
direct toggle.
Using Miracast with Android 4.4 or higher
12
Go to "Settings
13
Go to "Display" menu.
" menu.
Using Your Projector
71
14
Turn on "Cast Screen".
15
Choose detected wireless display device i.e. Dell Projector-Dell.
16
Screen is projected.
17
Direct access to "Cast Screen" from Quick Settings shade if "Cast
Screen" is switched ON.
72
Using Your Projector
18
Swipe down to "Disconnect" from notification shade.
19
Tap on "Settings" in Cast Screen UI to rename or forget device.
Miracast Support
To use Miracast, you need a device running Android 4.4 or higher. If your
device is running 4.4 or lower, the Menu icon looks like this . If your device
is running 4.3 or lower, the Settings icon looks like this
.
For more information about Miracast, visit website at
https://support.google.com/nexus/answer/2865484?hl=en
Using Your Projector
73
Using Wireless/LAN Display (DoWiFi/DoLAN)
System Requirements
NOTE: Your computer must have the following minimum system
requirements:
Operating System:
• Windows
Microsoft Windows XP Home or Professional Service pack 2 (32-bit
recommended), Windows Vista 32-bit, and Windows 7 Home or
Professional 32-bit or 64-bit, Windows 8 32-bit or 64-bit
• MAC
MacBook and above, MacOS 10.5 and above
Minimum Hardware:
a Intel Dual Core 1.4 MHz or higher
b 256 MB of RAM required, 512 MB or more recommended
c 10 MB of available hard-disk space
d nViDIA or ATI graphic card with 64 MB VRAM or above
e Ethernet adapter (10/100 bps) for an Ethernet connection
f A supported WLAN adapter for a WLAN connection (any NDIS-compliant
802.11b or 802.11g or 802.11n Wi-Fi device)
Web browser
Microsoft Internet Explorer 6.0 or 7.0 (recommended) or 8.0, Firefox 2.0,
Safari 3.0, and above
Enable Wireless or LAN on Projector
1
74
Connect the power cable and press the power button.
Using Your Projector
2
Press the Menu button on the remote control.
Aspect
Ratio
Page Up
Page Down
NOTE: Use
,
,
, and
buttons to navigate and
to
select.
3
Access the Input Source menu, select Wireless/LAN and then select
Wireless/LAN Display on the sub-menu.
The Wireless Guide Screen shown below appears:
4
Take note of the Wireless Network (SSID), IP Address, and Access
Code. You will need this information to log-in in later.
Using Your Projector
75
Using Wireless Display or LAN Display with Windows
Install the Dell Projector Connection Manager on Your Computer by
Wireless
5
Connect your computer to the Dell Projector abcd wireless network.
NOTE:
• Your computer must have wireless network function to detect the
connection.
• When you connect to the Dell Projector abcd wireless network,
you will lose wireless connectivity with other wireless networks.
76
Using Your Projector
NOTE: Remember to turn off all proxies. (In Microsoft® Windows
Vista: Click Control Panel  Internet Options  Connections 
LAN Settings)
6
Open your internet browser. You will be automatically directed to the
S510 or S510n Web Management web page.
NOTE: If the web page does not load automatically, enter the IP
address (default IP address is 192.168.100.10) noted from the
projector’s screen in the browser’s address bar.
Using Your Projector
77
7
The S510 or S510n Web Management page opens. For first-time use,
click Download.
8
Select the appropriate operating system, then click Download.
78
Using Your Projector
9
Click Run to proceed with
the one-time installation
of the software.
NOTE: You may choose
to save the file and install
it at a later time. To do
this, click Save.
NOTE: Audio projection
function needs install extra driver only in Windows XP. If your
computer does not have the driver installed, a pop-up message will
appear on-screen prompting you to install the required driver. You
can download the “Audio Projection Driver” from the Dell Support
site at dell.com/support.
NOTE: If you are unable to install the application because of
inadequate rights on the computer, please contact your network
administrator.
10
The installation software will launch. Follow the on-screen instruction
to complete setup.
Using Your Projector
79
Launch the Dell Projector Connection Manager
Once the installation is complete, the program will launch and search
automatically. If the program does not launch automatically, you can
double-click the
icon on the desktop to start the application.
Login
Login with the Access Code provided in Step 4 of Using Wireless/LAN
Display (DoWiFi/DoLAN), then click OK.
80
Using Your Projector
Install the Dell Projector Connection Manager on Your Computer by LAN
11
The installation software will launch. Follow the on-screen instruction
to complete setup.
12
Repeat steps 6 - 10 to install Dell Projector Connection Manager.
Launch and Login the Dell Projector Connection Manager
Once the installation is complete, the program will launch and search
automatically. If the program does not launch automatically, you can
double-click the
icon on the desktop to start the application.
a
Click the "Manual Network Connection" (Fig.1).
b
Enter IP Address (Fig.2, default IP address: 192.168.100.10).
c
Enter Access Code (Fig.3).
(Fig.1)
(Fig.2)
(Fig.3)
Using Your Projector
81
Understanding the Buttons
After a successful log in, the following screen appears:
1
2
Item
1
Description
Status Bar
Settings
2
82
Click to activate the application settings.
Minimize button
Click to minimize the application.
Close button
Click to exit the application.
Controls Toolbar
Information
Click to display SSID, IP, and Access Code
information.
Share mode
Click to activate the share mode.
Display mode
Click to change the display mode.
Start
Click to start projection.
Pause
Click to pause projection.
Stop
Click to stop projection.
Audio
Click to toggle audio projection On/Off.
Using Your Projector
Using the Settings
Click
to display the settings menu.
RESOLUTION—Allows you to setup the resolution.
DISPLAY MODE—Allows you to setup the default projection mode.
Using Your Projector
83
AUDIO—Allows you to change the audio settings.
USB DONGLE—Allows you to create USB dongle. See "Make USB Token for
Plug & Show Projection" on page 86.
84
Using Your Projector
ABOUT—Display the application version.
Using Your Projector
85
Make USB Token for Plug & Show Projection
The Application Token lets you perform Plug and Show using a USB token.
1
From the application software, click
2
The following screen appears. Click Next.
3
Plug a flash drive into any of the USB ports on your computer. Select
the drive from the list, then click Next.
4
Click Finish to close the wizard.
86
Using Your Projector
> USB Dongle
Using Wireless Display or LAN Display with Mac
Launch the Dell Wireless Application Software on Your Computer by
Wireless
5
Connect your computer to the Dell Projector abcd wireless network.
6
Open your Safari browser. You will be automatically directed to the
S510 Web Management web page.
NOTE: If the web page does not load automatically, enter the IP
address (default IP address is 192.168.100.10) noted from the
projector’s screen in the browser’s address bar.
7
The S510 Web Management page opens. For first-time use, click
Download.
8
Select the appropriate operating system, then click Download.
9
Execute the Dell_S510.dmg file from downloaded folder.
10
Execute the Dell S510 Wireless Application from Dell S510 folder.
Using Your Projector
87
Login
Login with the Access Code provided in Step 4 of Using Wireless/LAN
Display (DoWiFi/DoLAN), then click Connect.
Launch the Dell Wireless Application Software on Your Computer by LAN
11
Connect the LAN cable to the projector and the computer.
12
Repeat steps 6 - 10 to launch the Dell Wireless Application.
Login
Login with the Access Code provided in Step 4 of Using Wireless/LAN
Display (DoWiFi/DoLAN), then click Connect.
88
Using Your Projector
Understanding the Buttons
After a successful log in, the following screen appears:
1
2
1
2
3
Item
Description
Status Bar
Displays IP and LOGIN CODE
information.
Menu
Click to activate the application menu.
Minimize button
Click to minimize the application.
Close button
Click to exit the application.
Controls Toolbar
Full screen
Click to project the image in full screen.
Split 1
Click to project the image in the upper
left corner of the screen.
Split 2
Click to project the image in the upper
right corner of the screen.
Split 3
Click to project the image in the lower
left corner of the screen.
Split 4
Click to project the image in the lower
right corner of the screen.
Stop
Click to stop projection.
Pause
Click to pause projection.
Audio Projection Click to enable audio projection.
3
Connection Status
Connection Icon Blinks when projection is in progress.
Using Your Projector
89
Projecting the Presentation
•
•
•
•
•
To project the presentation, click any of the projection buttons
To pause the presentation, click
. The icon turns green.
To continue the presentation, click
again.
To audio projection the presentation, click
.
To stop the presentation, click
.
.
NOTE: WLAN environment using 802.11g connection, and no
screen stretching.
Using the Menu
Click
to display the menu.
WEB MANAGEMENT—Click to open the Web Management page. See "Using
Interactive Pen (Only for S510)" on page 51.
SEARCH SERVER—Click to search and connect to wireless projector.
PROJECTION QUALITY—Allows you to set the projector quality is Blur but
Faster or Clear but Slower.
INFO—Click to display system information.
ABOUT—Click to display the application version.
EXIT—Click to close the application.
90
Using Your Projector
Using USB Display (DoUSB)
Display over USB with Windows
1
Connect the power cable and press the power button.
2
Connect the USB (type A to B) cable to the projector and the
computer.
3
When you connect the projector and computer via USB cable, a USB
Connected message will pop up and allow you to select DoUSB or
Storage Mode. Select "DoUSB" option to switch to the USB Display
source.
NOTE: If the DoUSB can't display, please see "Troubleshooting Your
Projector" on page 130.
Using Your Projector
91
Display over USB with Mac
1
Connect the power cable and press the power button.
2
Connect the USB (type A to B) cable to the projector and the
computer.
3
When you connect the projector and computer via USB cable, a USB
Connected message will pop up and allow you to select DoUSB or
Storage Mode. Select "DoUSB" option to switch to the USB Display
source.
NOTE: DoUSB function needs install driver in Mac operating system.
If your Mac computer does not have the driver installed, a pop-up
message will appear on-screen prompting you to install the required
driver. See "Install the DoUSB Driver" on page 93.
92
Using Your Projector
Install the DoUSB Driver
1
Double-click the "USB_DISPLAY" icon on the desktop.
2
Execute the "MAC_USB_Display.pkg" file from USB_DISPLAY
folder.
3
The installation software will launch. Follow the on-screen
instruction to complete setup.
4
When installation is completed, restart your computer.
Using Your Projector
93
Using PC-Free Presentation
Multimedia File Type Support
Photos
Image Type (Ext Name) Sub Type
Encode Type
Max Pixels
GIF
8000 x 8000
PNG
8000 x 8000
BMP
8000 x 8000
JPEG/JPG
Baseline
YUV420
8000 x 8000
YUV422
YUV440
YUV444
Progressive YUV420
8000 x 8000
YUV422
YUV440
YUV444
Video
File Format Max. Resolution
Max. Bit Max. Display
Rate (bps)
Audio
Format
Motion
JPEG
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
LPCM
AVI
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
MPEG-1
Layer 3
MPEG-4
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
MOV
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
ASF
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
MKV
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
WMV
1920 x 1080, 30fps 20 Mbps
1080p, 60 Hz
94
Using Your Projector
WMA
Music
Music Type (ext Name) Max. Sample Rate (KHz)
Max. Bit Rate (Kbps)
LPCM
48 KHz
320 Kbps
MPEG-1 Layer 3
48 KHz
320 Kbps
WMA
48 KHz
320 Kbps
WAV
48 KHz
320 Kbps
OGG
48 KHz
320 Kbps
Using Your Projector
95
Office Viewer File Type Support
The Office Viewer feature allows you to use MS Excel, MS Word, MS
PowerPoint, and PDF files.
Buttons Introduction
Use the up, down, left, and right buttons for navigation and
remote control to select.
Button
96
Up
Down
Left
No
function
No
function
Previous Next
page
page
Using Your Projector
Right
button on the
Enter
Menu
No
function
Back to
previous
menu
Setting up to present using External USB Storage
NOTE: A USB flash disk must be plugged into the projector if you
want to use the multimedia USB function.
Follow these steps to playback the Photo, Video, or Music files on your
projector:
1
Connect the power cable and turn on the projector by pressing the
power button.
2
Plug in a USB flash disk to your projector.
3
Press the Menu button on the remote control.
Aspect
Ratio
Page Up
Page Down
Using Your Projector
97
4
Access the Input Source menu, select USB and then select USB
Viewer on the sub-menu.
The USB Screen shown below appears:
5
98
Select the multimedia files: Photo, Video, Music, or Office Viewer,
and then press the
to start playing. Or select the Setup option to
change multimedia settings. See "Multimedia Setup" on page 101.
Using Your Projector
Setting up to present using Internal Memory Storage
Follow these steps to playback the Photo, Video, or Music files on your
projector:
1
Connect the power cable and turn on the projector by pressing the
power button.
2
Press the Menu button on the remote control.
Aspect
Ratio
Page Up
Page Down
3
Access the Input Source menu, select Internal Memory source.
Using Your Projector
99
The Internal Memory Screen shown below appears:
4
100
Select the multimedia files: Photo, Video, Music, or Office Viewer,
and then press the
to start playing. Or select the Setup option to
change multimedia settings. See "Multimedia Setup" on page 101.
Using Your Projector
Adjusting PC-Free Presentation Settings
The multimedia setup menu allows you to change settings for Photo, Video,
and Music.
NOTE: Multimedia setup menu and set are the same for the USB
and internal memory.
SLIDESHOW DURATION—Press
or
to select slideshow display interval.
The image will automatically switch to the next photo after the time out.
Options are: 5 seconds, 10 seconds, 30 seconds, and 1 minute.
SLIDESHOW REPEAT—Press
No Repeat.
or
to select slideshow repeat as Repeat or
VIDEO PLAY MODE—Press
or
to select movie play mode. Options are:
Play once, Repeat item, Repeat folder, and Shuffle.
MUSIC PLAY MODE—Press
or
to select movie play mode. Options are:
Play once, Repeat item, Repeat folder, and Shuffle.
Using Your Projector
101
Using Audio Projection
System Requirements
Audio Projection only supports the Wireless Display and LAN Display input
source.
Minimum system requirements are as follow:
Operating System:
•
Windows
Microsoft Windows XP™ Home or Professional Service pack 2/3 (32bit recommended), Windows Vista 32-bit, or Windows® 7 Home or
Professional 32-bit or 64-bit, Windows 8 32-bit or 64-bit
•
Mac
MacBook Pro and above, MacOS 10.5 and above
Minimum Hardware:
a
Intel® Core™ i5-460 MHz (2.53 GHz/Turbo 2.8 GHz) or greater
b
1 GB DDR3 VRAM independent graphics card or more
recommended
c
2 GB dual channel DDR3 SDRAM memory at 1066 MHz required or
more recommended
d
Gigabit Ethernet
e
Integrated 802.11 a/b/g/n Wi-Fi Device for a WLAN connection
NOTE: If your computer does not meet the minimum hardware
requirements, audio projection may have lag or noise. Meet the
recommended system requirements to have optimized performance
of audio projection.
NOTE: Audio projection function needs install extra driver only in
Windows XP, If your computer does not have the driver installed, a
pop-up message will appear on-screen prompting you to install the
required driver. You can download the "Audio Projection Driver" from
the Dell Support site at dell.com/support.
NOTE: Audio Projection function needs installed extra driver in Mac
operating system. If your Mac computer does not have the driver
installed, a pop-up message will appear on-screen prompting you to
install the required driver. You can download the "Soundflower"
driver from the some search engine sites (ex. Yahoo, MSN...). The
"Soundflower" driver is a free application.
102
Using Your Projector
NOTE: Ports / Protocol for connection to the projector for
projection via Ethernet:
UDP:
1047,
(backup: 1048, 1049)
TCP:
3268, 515, 1688, 1041
(backup: 389, 8080, 21)
Enable Wireless or LAN on Projector
1
Connect the power cable and press the power button.
2
Press the Menu button on the remote control.
Aspect
Ratio
Page Up
Page Down
3
Access the Input Source menu, select the Wireless/LAN and then
select the Wireless/LAN Display on the sub-menu.
Using Your Projector
103
The Wireless Guide Screen shown below appears:
4
Take note of the Wireless Network (SSID), IP Address, and Access
Code. You will need this information to log-in later.
Using Audio Projection with Windows
Install the Dell Projector Connection Manager on Your Computer by
Wireless
5
"Dell Projector Connection Manager" is required if the Wireless or LAN is
used for the audio projection set-up. Please download and install the
software the first time you use audio projection. If it is already installed,
skip Step 5 - 6.
NOTE: You only need to install the "Dell Projector Connection
6
104
Manager Software" once.
Dell Projector Connection Manager Software download and install
steps, you can refer to steps 6 to 10 of the "Using Wireless/LAN Display
(DoWiFi/DoLAN)" on page 74.
Using Your Projector
Launch the Dell Projector Connection Manager
Once the installation is complete, the program will launch and search
automatically. If the program does not launch automatically, you can doubleclick the
icon on the desktop to start the application.
Login
Login with the Access Code provided in Step 4 of Audio Projection
Installation, then click OK.
Install the Dell Projector Connection Manager on Your Computer by LAN
7
Connect the LAN cable to the projector and the computer.
8
Refer to step 6 to install Dell Projector Connection Manager.
Using Your Projector
105
Launch the Dell Projector Connection Manager
Once the installation is complete, the program will launch and search
automatically. If the program does not launch automatically, you can doubleclick the
icon on the desktop to start the application.
a
Click the "Manual Network Connection" (Fig.1).
b
Enter IP Address (Fig.2, default IP address: 192.168.100.10).
c
Enter Access Code (Fig.3).
(Fig.1)
106
Using Your Projector
(Fig.2)
(Fig.3)
Presentation Audio Projection
9
10
You are now logged into the Dell Projector Connection Manager.
Click the "Play" button in the application to starting the LAN or
wireless audio projection.
Click the "Audio Projection" button in the application to toggle audio
projection On/Off.
NOTE: Audio projection function needs install extra driver only in
Windows XP. If your computer does not have the driver installed, a
pop-up message will appear on-screen prompting you to install the
required driver. You can download the "Audio Projection Driver" from
the Dell Support site at dell.com/support.
Using Your Projector
107
11
Executing the Windows Media Player or others audio player software
(example: Winamp player...) on your computer.
Using Audio Projection with Mac
Launch the Dell Wireless Application Software on Your Computer by
Wireless
12
Connect your computer to the Dell Projector wireless network.
13
Open your Safari browser. You will be automatically directed to the
S510 Web Management web page.
NOTE: If the web page does not load automatically, enter the IP
14
address (default IP address is 192.168.100.10) noted from the
projector’s screen in the browser’s address bar.
The S510 Web Management page opens. For first-time use, click
Download.
15
Select the application operating system, then click Download.
16
Execute the Dell_S510.dmg file from downloaded folder.
17
Execute the Dell S510 Wireless Application from Dell S510 folder.
108
Using Your Projector
Login
Login with the Access Code provided in Step 4 of Audio Projection
Installation, then click Connect.
18
You are now logged into the S510 Wireless Application. Click "Play"
button in the application to starting the wireless or LAN projection.
19
Click "Audio Projection" button in the application to toggle audio
projection On/Off.
NOTE: Audio projection function needs installed extra driver in Mac
20
operating system. If your Mac computer does not have the driver
installed, a pop-up message will appear on-screen prompting you to
install the required driver. You can download the "Soundflower"
driver from the some search engine sites (ex. Yahoo, MSN...). The
"Soundflower" driver is a free application. See "Install the
Soundflower Driver" on page 110.
Executing the audio player software on your computer.
Using Your Projector
109
Launch the Dell Wireless Application Software on Your Computer by LAN
21
Connect the LAN cable to the projector and the computer.
22
Repeat steps 6 - 13 to launch and login the Dell Wireless Application.
Install the Soundflower Driver
1
You can download the "Soundflower" driver from the some search
engine sites (ex. Yahoo, MSN...). The "Soundflower" driver is a free
application.
2
Execute the “Soundflower.dmg" file from downloaded folder.
3
Execute the “Soundflower.pkg" file from Soundflower folder.
4
The installation software will launch. Follow the on-screen instruction
to complete setup.
110
Using Your Projector
Managing Projector with Web Browser
Configuring Network Setting
If the projector is connected to a network, you can access the projector using
a web browser. For configuring the network setting, refer to "LAN Settings" on
page 44.
Accessing Web Management
Use Internet Explorer 6.0 and above or Firefox 2.0 and above and enter the IP
address. You can now access Web Management and manage the projector
from a remote location.
Home Page
•
Access the Web Management Home page by entering the projector’s
IP address at the web browser. See "LAN Settings" on page 44.
•
Select the language for web management from the list.
•
Click any menu item on the left tab to access the page.
Using Your Projector
111
Download DoWiFi Projector Application
See also "Using Wireless/LAN Display (DoWiFi/DoLAN)" on page 74.
Click the Download button of the corresponding operating system of your
computer.
112
Using Your Projector
Conference Control
This allows you to host conference presentations from different sources
without using projector cables and lets you control how each presentation
will appear on screen.
NOTE: Without Conference Play Control, the last user to hit the
"Play" button on the application will take control of the full-screen
projection.
Computer Name: Lists the computers logged for conference control.
Play Control: Click the buttons to control how each computer’s projection
will appear on screen.
•
Full screen projection — The presentation from the computer
occupies the whole screen.
•
Split 1 - The presentation from the computer appears on the
upper left corner of the screen.
•
Split 2- The presentation from the computer appears on the
upper right corner of the screen.
•
Split 3- The presentation from the computer appears on the
lower left corner of the screen.
•
Split 4- The presentation from the computer appears on the
lower right corner of the screen.
•
Stop - Projection from the computer is stopped.
IP Address: Shows each computer’s IP Address.
NOTE: To end the conference, click Home.
Using Your Projector
113
Managing Projector Configuration
Admin
An administrator password is required to access the Admin page.
•
114
Admin Password: Enter the administrator password and then click
Login. The default password is "admin". To change the password, see
"Change Passwords" on page 119.
Using Your Projector
System Status
Displays the Network Status, Connection Status, and Projector Status
information.
Using Your Projector
115
Network Setup
See OSD section on page 44.
IP Setup
•
Choose Obtain an IP address automatically to assign an IP address
to the projector automatically, or Use the following IP address to
assign an IP address manually.
DHCP Server Setup
•
116
Choose Auto to automatically set up the Start IP, End IP, Frequency
Band, Subnet Mask, Default Gateway, and DNS Server address from
a DHCP server, or Disable to disable this function.
Using Your Projector
Wireless Setup
•
Choose Enable to set up the Region, SSID, SSID Broadcast,
Frequency Band, Channel, Encryption, Key and TX mode channel.
Choose Disable to disable the wireless set up.
SSID: Up to maximum length of 32 characters.
Encryption: You can disable WPA key or select one of 64-bit or 128bit in ASCII or HEX string.
Key: If Encryption is enabled, you have to set key value according to
the Encryption mode you selected.
RADIUS Server Setup
•
Set up the IP address, Port, and Key information.
GateKeeper
•
There are three options:
All Pass: Allow users to access the office network via the wireless
projector.
All Block: Block users from accessing the office network via the
wireless projector.
Internet Only: Block users from the office network, but still reserve
Internet connection capability.
Set Security For SNMP
•
Setup Write Community information.
Click the Apply button to save and apply changes. The projector must be
restarted for the changes to take effect.
Using Your Projector
117
Projection Setup
Projection Setup
•
Resolution: Allows you to select the resolution. Options are: XGA
(1024 x 768) and WXGA (1280 x 800).
•
Login Code: Select how you want the login code to be generated by
the projector. There are three options:
• Disable: Login code will not be required when logging in to the
system.
• Random: Default is Random. Login code will be randomly
generated.
• Use the following code: Enter a 4-digit code. This code will be
used to log in to the system.
Projector Setup
•
Set up the Projector Name, Location, and Contact information (up to
21 characters for each field).
Click the Apply button to save and apply changes. The projector must be
restarted for the changes to take effect.
118
Using Your Projector
Change Passwords
This page allows you to change the administrator password.
•
Enter New Password: Enter the new password.
•
Confirm New Password: Enter the password again and click Apply.
NOTE: Contact Dell if you forget your administrator password.
Using Your Projector
119
Reset to Default
Click the Apply button to restore the wireless/network setup to its factory
default settings.
Firmware Upgrade
Use the Firmware Upgrade page to update your projector’s wireless firmware.
NOTE: Please disable and enable wireless/network using the OSD to
restart the network card for the projector after firmware upgrade is
successful.
To start firmware update, follow these steps:
1
120
You can download the firmware files from dell.com/support.
Using Your Projector
2
Press Browse to select the file to update.
3
Click the Update button to start. Wait while the system updates the
firmware in your device.
CAUTION: Do not interrupt the update process as this may cause
the system to crash!
4
Click OK when the update is complete.
Using Your Projector
121
Projector Control Panel
Projector Information
•
Projector Status: There are five states: Lamp On, Standby, Power
Saving, Cooling, and Warming up. Click Refresh to refresh the status
and control settings.
•
Power Saving: Power Saving can be set to Off, 20, 60, 90, or 120
minutes. For more information, see "Power Saving" on page 49.
•
Alert Status: There are three alert states: Lamp warning, Low lamp
life, and Temperature warning. Your projector might lock up in the
protection mode if any of the alerts are activated. To exit the
protection mode, click Clear to clear the Alert Status before you
power on your projector.
122
Using Your Projector
Image Control
•
Projector Mode: Allows you to select the projector mode, depending
on how the projector is mounted. There are two projection modes:
Front Projection-Wall Mount and Rear Projection-Wall Mount.
•
Source Select: The Source Select menu allows you to select your
projector's input source. You can select VGA-A, VGA-B, Composite
Video, HDMI-A, HDMI-B, Wireless Display, USB Display, USB Viewer,
Intel® WiDi, or Internal Memory.
•
Video Mode: Select a mode to optimize the display image based on
how the projector is being used:
- Presentation: Best for presentation slides.
- Bright: Maximum brightness and contrast.
- Movie: For viewing movies and photos.
- sRGB: Provides a more accurate color representation.
- Custom: User-preferred settings.
•
Blank Screen: You can select On or Off.
•
Aspect Ratio: Allows you to select the aspect ratio to adjust how the
image appears.
•
Brightness: Select value to adjust the brightness of the image.
•
Contrast: Select value to adjust the display contrast.
Click the Auto Adjust button to adjust the settings automatically.
Audio Control
•
Volume: Select the value (0~20) for audio volume.
Click the Factory Reset button to restore the factory default settings.
Using Your Projector
123
Alert Setting
E-mail Alert
•
E-mail Alert: You can set whether to be notified by email (Enable) or
not (Disable).
•
To/Cc/From: You can enter email address of sender (From) and
recipients (To/Cc) to receive notification when an abnormality or
warning occurs.
•
Subject: You can enter the subject line of the email.
Click the E-mail Alert Test button to test the e-mail alert settings.
SMTP Setting
•
Out going SMTP server, User name, and Password should be
provided by your network administrator or MIS.
Alert Condition
•
You can select the abnormalities or warnings to be notified by email.
When any of the alert conditions occur, an email will be sent to the
recipients (To/Cc).
Click the Save button to the save settings.
NOTE: E-mail alert is designed to work with a standard SMTP server
using the default 25 port. It does not support encryption and
authentication (SSL or TLS).
124
Using Your Projector
Reboot System
Click Reboot to reboot the system.
Using Your Projector
125
Managing Projector with Crestron Roomview Connected
Item
Description
1
Power button
Click to toggle projector power On/Off.
2
Volume control bars Click up to increase the volume.
Click Mute to toggle projector speaker On/Off.
Click down to decrease the volume.
3
OSD navigation pad Click Menu to toggle projector OSD On/Off.
Use the arrow keys to navigate the OSD options
and click OK to select.
4
Brightness button
Click to adjust the projector display brightness.
5
Contrast button
Click to adjust the projector display contrast.
6
Freeze button
Click to toggle projector screen image freeze
On/Off.
7
Image mute button Click to toggle projector display On/Off. This
function will not turn the projector power
On/Off.
8
Sources list panel
126
Allows you to switch the projector's input
source.
Using Your Projector
Using the Tools Window
The following window is displayed when you click the Tools tab on the
operation window. You can use this window to change settings in the
projector that is currently connected.
Crestron Control
•
Make settings for Crestron® central controllers.
Projector
Item
Description
1
Projector Name
Enter a name to differentiate the projector that
is currently connected from other projectors
on the network. (The name can contain up to
15 single-byte alphanumeric characters.)
2
Location
Enter an installation location name for the
projector that is currently connected on the
network. (The name can contain up to 32
single-byte alphanumeric characters and
symbols.)
3
Assigned To
Enter a user name for the projector. (The name
can contain up to 32 single-byte alphanumeric
characters and symbols.)
Using Your Projector
127
Item
Description
4
DHCP
Select the Enabled check box to use DHCP.
You cannot enter an IP address if DHCP is
enabled.
5
IP Address
Enter the IP address to assign to the currently
connected projector.
6
Subnet Mask
Enter a subnet mask for the currently
connected projector.
7
Default Gateway
Enter the gateway address for the currently
connected projector.
8
DNS Server
Enter the DNS server IP address for the
currently connected projector.
9
Send
Click this button to confirm the changes made
to the projector.
User Password
Select the Enabled check box to require a password to open the operation
window on the computer.
Item
Description
1
New Password
Enter the new password when changing the
password to open the operation window. (Up
to 26 single-byte alphanumerical characters)
2
Confirm
Enter the same password as you entered in
New Password. If the passwords are not the
same, an error is displayed.
3
Send
Click this button to confirm the changes made
to the User Password.
128
Using Your Projector
Admin Password
Select the Enabled check box to require a password to open the Tools
window.
Item
Description
1
New Password
Enter the new password when changing the
password to open the Tools window. (The
name can contain up to 26 single-byte
alphanumeric characters.)
2
Confirm
Enter the same password as you entered in
New Password. If the passwords are not the
same, an error is displayed.
3
Send
Click this button to confirm the changes made
to the Admin Password.
Using Your Projector
129
4
Troubleshooting Your Projector
If you experience problems with your projector, see the following
troubleshooting tips. If the problem persists, contact Dell (see Contacting
Dell on page 148).
Problem
Possible Solution
No image appears on the
screen
• Ensure that you have chosen the correct
input source on the INPUT SOURCE
menu.
• Ensure the external graphics port is
enabled. If you are using a Dell laptop
computer, press
(Fn+F8). For
other computers, see your respective
documentation. If images are not
displayed properly, please upgrade the
video driver of your computer. For Dell
computers, see support.dell.com.
• Ensure that all the cables are securely
connected. See "Setting Up Your
Projector" on page 9.
• Ensure that the pins of the connectors
are not bent or broken.
• Ensure that the lamp is securely installed
(see "Changing the Lamp" on page 136).
• Use Test Pattern in the Projector Settings
of the Advanced Settings menu. Ensure
that the colors of the test pattern are
correct.
F8
CRT/LCD
Fn
130
Troubleshooting Your Projector
Problem (continued)
Partial, scrolling, or
incorrectly displayed image
Possible Solution (continued)
1 Press the Auto Adjust button on the
remote control.
2 If you are using a Dell laptop computer,
set the resolution of the computer to
WXGA (1280 x 800):
a Right-click the unused portion of your
Microsoft® Windows® desktop, click
Properties, and then select Settings
tab.
b Verify that the setting is 1280 x 800
pixels for the external monitor port.
c Press
(Fn+F8).
If you experience difficulty in changing
resolutions, or if your monitor freezes,
restart all the equipment and the
projector.
If you are not using a Dell laptop
computer, see your documentation. If
images are not displayed properly, please
upgrade the video driver of your
computer. For a Dell computer, see
support.dell.com.
The screen does not
display your presentation
If you are using a portable computer,
press
(Fn+F8).
Image is unstable or
flickering
Adjust the tracking in the OSD Display
Settings of the Advanced Settings menu
(in PC Mode only).
Image has vertical
flickering bar
Adjust the frequency in the OSD Display
Settings of the Advanced Settings menu
(in PC Mode only).
Troubleshooting Your Projector
131
Problem (continued)
Possible Solution (continued)
Image color is incorrect
• If the display receives the wrong signal
output from the graphics card, please set
the signal type to RGB in the OSD Image
Settings of the Advanced Settings tab.
• Use Test Pattern in the Projector
Settings of the Advanced Settings
menu. Ensure that the colors of the test
pattern are correct.
Image is out of focus
1 Adjust the focus ring on the projector
lens.
2 Ensure that the projection screen is
within the required distance from the
projector 1.96 ft [0.597 m] to 2.4 ft [0.731
m].
The image is stretched
when displaying a 16:9
DVD
The projector automatically detects the
input signal format. It will maintain the
aspect ratio of the projected image
according to input signal format with an
Original setting.
If the image is still stretched, adjust the
aspect ratio in the Display Settings of the
Advanced Settings menu in the OSD.
Image is reversed
Select Projector Settings of the
Advanced Settings from the OSD and
adjust the projector mode.
Lamp is burned out or
makes a popping sound
When the lamp reaches its end of life, it
may burn out and may make a loud
popping sound. If this occurs, the
projector does not turn back on. To
replace the lamp, see "Changing the
Lamp" on page 136.
LAMP light is solid amber
If the LAMP light is solid amber, replace
the lamp.
132
Troubleshooting Your Projector
Problem (continued)
Possible Solution (continued)
LAMP light is blinking
amber
If the LAMP light is blinking amber, the
lamp module connection may be
disrupted. Please check the lamp module
and ensure that it is properly installed.
If the LAMP lights and the Power light are
blinking amber, the lamp driver has failed
and the projector will automatically shut
down.
If the LAMP and TEMP lights are blinking
amber and the Power light is solid blue,
the color wheel has failed and the
projector will automatically shut down.
To clear the protection mode, press and
hold the POWER button for 10 seconds.
TEMP light is solid amber
The projector has overheated. The display
automatically shuts down. Turn the
display on again after the projector cools
down. If the problem persists, contact
Dell.
TEMP light is blinking
amber
If the projector fan fails, the projector will
automatically shut down. Try to clear the
projector mode by pressing and holding
the Power button for 10 seconds. Please
wait for about 5 minutes and try to power
up again. If the problem persists, contact
Dell.
The remote control is not
operating smoothly or
works only within a limited
range
The battery may be low. If so, replace with
two new AAA batteries.
Troubleshooting Your Projector
133
Problem (continued)
DoUSB not displaying
Possible Solution (continued)
• Windows
Display over USB Should run
automatically. To manually run USB
display, go to My Computer and run
"USB_Display.exe".
• MAC
a Go to CDROM: USB_DISPLAY and run
"MAC_USB_Display.pkg".
b Follow the on-screen instruction to
complete installed.
c Reboot system, and then re-connect
USB cable to the computer and the
projector.
NOTE: You may require
administrator level access to install
the driver. Contact your network
administrator for support.
IR Pen location offset
1 Ensure the output resolutions of the
projector and computer are 1280x800.
2 Select "second screen only" on the
computer.
134
Troubleshooting Your Projector
Guiding Signals
Control Buttons
Projector
Status
Description
Indicator
Power
TEMP
(Amber)
LAMP
(Amber)
White Flashing
OFF
OFF
Standby
mode
Projector in Standby mode. Ready to
power on.
Warming up
mode
Projector takes some time to warm
up and power on.
White
OFF
OFF
Lamp on
Projector in Normal mode, ready to
display an image.
Note: The OSD menu is not
accessed.
White
OFF
OFF
Cooling
mode
Projector is cooling to shutdown.
White
OFF
OFF
Projector
overheated
Air vents might be blocked or
ambient temperature may be above
35 °C. The projector automatically
shuts down. Ensure that the air vents
are not blocked and that the ambient
temperature is within operational
range. If the problem persists,
contact Dell.
OFF
AMBER
OFF
The lamp driver is overheated. The air
vents may be blocked. The projector
automatically shuts down. Turn the
display on again after the projector
cools down. If the problem persists,
contact Dell.
AMBER
AMBER
OFF
Fan
breakdown
One of the fans has failed. The
projector automatically shuts down.
If the problem persists, contact Dell.
OFF
AMBER
Flashing
OFF
Lamp driver
breakdown
The lamp driver has failed. The
projector automatically shuts down.
Unplug the power cord after three
minutes and then turn the display on
again. If this problem persists,
contact Dell.
AMBER Flashing
OFF
AMBER
Flashing
Color wheel cannot start. The
projector has failed and the projector
automatically shuts down. Unplug
the power cord after three minutes
and then turn on the projector. If this
problem persists, contact Dell.
White
AMBER
Flashing
AMBER
Flashing
Lamp failure
Lamp is defective. Replace the lamp.
OFF
OFF
AMBER
Fault - DC
supply (+12V)
Power supply has been interrupted.
The projector automatically shuts
down. Unplug the power cord after
three minutes and then turn on the
projector. If this problem persists,
contact Dell.
AMBER Flashing
AMBER
AMBER
Lamp module connection may be
disrupted. Check the lamp module
and ensure that it is properly
installed. If the problem persists,
contact Dell.
OFF
OFF
AMBER
Flashing
Lamp driver
overheated
Color Wheel
breakdown
Lamp module
connection
failed
Troubleshooting Your Projector
135
Changing the Lamp
CAUTION: Before you begin any of the procedures in this section,
follow the Safety Instructions as described on page 8.
Replace the lamp when the message "Lamp is approaching the end of its
useful life in the operation. Replacement suggested!
www.dell.com/lamps" appears on the screen. If this problem persists after
replacing the lamp, contact Dell. For more information, see "Contacting
Dell" on page 148.
CAUTION: Use an original lamp to ensure safe and optimal
working condition of your projector.
CAUTION: The lamp becomes very hot when in use. Do not
attempt to replace the lamp until the projector has been allowed to
cool down for at least 30 minutes.
CAUTION: Do not touch the bulb or the lamp glass at any time.
Projector lamps are very fragile and may shatter if touched. The
shattered glass pieces are sharp and can cause injury.
CAUTION: If the lamp shatters, remove all broken pieces from the
projector and dispose or recycle according to state, local, or federal
law. For more information see www.dell.com/hg.
1 Turn off the projector and disconnect the power cord.
2 Let the projector cool for at least 30 minutes.
3 Loosen the two screws that secure
the lamp cover, and remove the
cover.
4 Loosen the two screws that secure
the lamp.
5 Pull the lamp up by its metal handle.
NOTE: Dell may require lamps
replaced under warranty to be
returned to Dell. Otherwise,
contact your local waste
disposal agency for the address
of the nearest deposit site.
6 Replace with the new lamp.
7 Tighten the two screws that secure the lamp.
8 Replace the lamp cover and tighten the two screws.
136
Troubleshooting Your Projector
9 Reset the lamp usage time by selecting "Yes" for Lamp Reset in the OSD
Power Settings of the Advanced Settings menu (see Power Settings of
the Advanced Settings menu on page 48). When a new lamp module has
been changed, the projector will automatically detect and reset the lamp
hours.
CAUTION: Lamp Disposal (for the US only)
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST
BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE,
OR FEDERAL LAWS. FOR MORE INFORMATION, GO TO
WWW.DELL.COM/HG OR CONTACT THE ELECTRONIC INDUSTRIES
ALLIANCE AT WWW.EIAE.ORG. FOR LAMP-SPECIFIC DISPOSAL
INFORMATION, CHECK WWW.LAMPRECYCLE.ORG.
Troubleshooting Your Projector
137
FAQS:
I would like to remotely
access the projector via the
Internet. What is the best
setting for the browser?
To have the best setting for the browser,
please follow the below steps:
1 Open Control Panel
Internet
General tab
Options
Temporary Internet Files
Settings
Select Every visit to the pages.
2 Some firewall or anti-virus may block
the HTTP application. If possible, turn
off the firewall or anti-virus.
I would like to remotely
access the projector via
Internet. What socket port
number should I open for it
in the firewall?
Why am I unable to access
the projector via the
Internet?
The following are the TCP/IP socket ports
which the projector uses.
UDP/TCP
Port
Number
Description
TCP
80
Web
configuration
(HTTP)
UDP/TCP
25
SMTP: used for
email routing
between mail
servers
UDP/TCP
161
SNMP: Simple
Network
Management
Protocol
UDP
9131
AMX: used for
AMX discovery
1 Check whether your computer/laptop
is connected to the Internet.
2 Check with your MIS or network
administrator whether your
computer/laptop is in the same
subnet.
138
Troubleshooting Your Projector
Why am I unable to access
the SMTP server?
1 Check with your MIS or network
administrator whether the SMTP
server function is open for the
projector and the IP assigned to the
projector is allowed to access the
SMTP server. The projector’s SMTP
socket port number is 25, this cannot
be changed.
2 Check if the outgoing SMTP server,
user name, and password are set
correctly.
3 Some SMTP servers will check
whether the mail address of "From"
correlates with the "User name" and
"Password". For example, you use
[email protected] as the mail address in
"From". You should also use
[email protected] account information
for the User name and the password
to log in the SMTP server.
Why am I unable to receive
the test alert email even
though the projector already
indicates the test mail is
already sent?
It could be because the SMTP server
recognized the alert mail as a spam mail or
because of the SMTP server restriction.
Check with your MIS or network
administrator for the SMTP server’s setting.
Troubleshooting Your Projector
139
Firewall Configuration and FAQ
Q: Why can’t I access the Web Management Page?
A: Your computer’s firewall configuration may prevent you from accessing
the Web Management Web Page. Please refer to the following
configuration settings:
Firewall
Protection
McAfee Security
Center
Configuration
1 Launch McAfee Security Center (Start > All
Programs > McAfee > McAfee Security
Center).
2 On the personal firewall plus tab, click View
the Internet Applications List.
3 Find and select Dell Projector from the list.
4 Right-click on its Permissions column.
5 Select Allow Full Access from the pop-up
menu.
Norton AntiVirus
1 Open Norton AntiVirus (Start > All Programs >
Norton AntiVirus > Norton AntiVirus).
2 Click Options menu, then select Norton
AntiVirus.
3 On the Status page, select Internet Worm
Protection.
4 Find and select Dell Projector from the list of
programs.
5 Right-click on its Internet Access column.
6 Select Permit All from the pop-up menu.
7 Click OK.
Sygate Personal
Firewall
1 Open Sygate Personal Firewall (Start > All
Programs > Sygate > Sygate Personal
Firewall).
2 From the Running Applications list, find and
right-click on Dell Projector.
3 Select Allow from the pop-up menu.
140
Troubleshooting Your Projector
Firewall
Protection
Windows Firewall
Configuration
1 Open Windows Firewall (Start > All Programs
> Control Panel). Double-click on Windows
Firewall.
2 On the General tab, uncheck Don’t allow
exceptions.
3 On the Exceptions tab, click the Add
Program... button.
4 Find and select Dell Projector from the list of
programs, then click OK.
5 Click OK to confirm exceptions settings.
Zone Alarm
1 Open Zone Alarm Firewall (Start > All
Programs > Zone Labs > Zone Labs Center).
2 On the Program Control page, find and select
Dell Projector from the list.
3 Right-click on its Access-Trusted column.
4 Select Allow from the pop-up menu.
5 Right-click and select Allow for the
Access-Internet, Server-Trusted, and ServerInternet columns.
Troubleshooting Your Projector
141
5
Specifications
Light Valve
0.65" WXGA-800 S450 DMD, DarkChip3™
Brightness
3100 ANSI Lumens (Max.)
Contrast Ratio
Native: 2200:1 Typical
High Contrast Ratio Mode: 8000:1 Typical
Uniformity
85% Typical (Japan Standard - JBMA)
Number of Pixels
1280 x 800 (WXGA)
Aspect Ratio
16:10
Internal Flash
2 GB Memory (Max.)
Displayable Color
1.07 billion colors
Color Wheel Speed
2X
1 X for 3D Display
Projection Lens
F-Stop: F/ 2.6
Effective Focal length=654 mm ± 10 mm @
87.2 screen size
Fixed lens, digital zoom only
Throw ratio =0.35 wide and tele
Offset Ratio: 125%±5%
Projection Screen Size
70 ~ 100 inches (diagonal)
Projection Distance
1.7 ~ 2.49 ft (0.517 ~ 0.759 m ± 0.01 m)
Video Compatibility
Composite Video:
NTSC: M (3.58 MHz), 4.43 MHz
PAL: B, D, G, H, I, M, N, 60
SECAM: B, D, G, K, K1, L
Component Video input via VGA: 1080i, 720p,
576i/p, 480i/p
HDMI input: 1080p, 720p, 576i/p, 480i/p
Power Supply
142
Specifications
Universal AC 100-240 V 50-60 Hz with PFC
input
Power Consumption
Normal mode: 345 W ± 10% @ 110 Vac
(Network On)
Eco mode: 285 W ± 10% @ 110 Vac (Network
On)
Standby mode: < 0.5 W
S510/S510n networked standby: < 9.6W
Audio
2 speaker x 10 watt RMS
Noise Level
Normal mode: 36 dB(A)
Eco mode: 32 dB(A)
Projector Weight
16.76 lbs (7.6 kg)
IR Pen Weight
(only for S510)
55.2 g (with batteries)
Dimensions (W x H x D)
14.1 x 9.1 x 14.4 inches (357 x 231 x 367 mm)
14
.1"
(35
7m
m)
9.1"(231 mm)
14
.4"
(
7
36
m
m
)
IR Pen Dimensions (D x Φ) 6.39 x 0.71 (162.2 x 18 mm)
(only for S510)
Φ 0.71”
(18 mm)
6.39”(162.2 mm)
Specifications
143
Environmental
Operating temperature: 5 °C - 40 °C (41 °F104 °F)
Humidity: 80% maximum
Storage temperature: 0 °C to 60 °C
(32 °F to 140 °F)
Humidity: 90% maximum
Shipping temperature: -20 °C to 60 °C
(-4 °F to 140 °F)
Humidity: 90% maximum
I/O Connectors
Power: One AC power socket (3-pin - C14
inlet)
VGA input: Two 15-pin D-sub connectors
(Blue), VGA-A and VGA-B, for analog
RGB/Component input signals.
VGA output: One 15-pin D-sub connector
(Black) for VGA-A loop through.
Composite Video input: One Yellow RCA jack
for CVBS signal.
HDMI input: Two HDMI connector for
supporting HDMI 1.4a. HDCP compliant/one
with MHL.
Analog Audio input: Two 3.5 mm stereo mini
phone jack (Blue) and one pair of RCA
connector (Red/White).
Variable audio output: One 3.5 mm stereo mini
phone jack (Green).
USB (type B) port: One mini USB slave for
remote support and firmware upgrade.
RS232 port: One 9-pin D-sub for RS232
communication.
USB (type A) port: One USB connector for
multimedia playback
(Video/Music/Photo/Office Viewer).
USB (type B) port: One USB connector for
supporting USB display and USB memory
storage access (internal memory).
144
Specifications
RJ45 port: One RJ45 connector for control of
projector through network and LAN display.
Microphone
One 3.5 mm stereo mini phone jack (Pink).
Wireless
Wireless Standard: IEEE 802.11 a/b/g/n (1T2R)
OS environment: Windows 8/7/Vista/XP/2000,
MAC OS X
Support: Presentation slides and projector
control.
Allow connection up to 30 users at the same
time.
4-to-1 split screen. Allows four presentation
slides to be projected on screen.
Conference Control mode.
Supports Audio Projection (driver installation
may be required. Download from
dell.com/support).
Supports MobiShow and WiFi-Doc projection.
Lamp
OSRAM 280 W user-replaceable lamp
Lamp life
Normal mode: Up to 3000 hours
Eco mode: Up to 4000 hours
Dynamic eco cycle mode: Up to 5000 hours
NOTE: The lamp life rating for any projector is a measure of
brightness degradation only, and is not a specification for the time it
takes a lamp to fail and cease light output. Lamp life is defined as the
time it takes for more than 50 percent of a lamp sample population to
have brightness decrease by approximately 50 percent of the rated
lumens for the specified lamp. The lamp life rating is not guaranteed
in any way. The actual operating life span of a projector lamp will vary
according to operating conditions and usage patterns. Usage of a
projector in stressful conditions which may include dusty
environments, under high temperatures, many hours per day, and
abrupt powering-off will most likely result in a lamp’s shortened
operating life span or possible lamp failure.
Specifications
145
RS232 Pin Assignment
RS232 Protocol
•
Communication Settings
Connection settings
Value
Baud Rate
19,200
Data Bits
8
Parity
None
Stop Bits
1
•
Command types
To pop up the OSD menu and adjust the settings.
•
Control command Syntax (From PC to Projector)
[H][AC][SoP][CRC][ID][SoM][COMMAND]
•
Example: Power ON Command (Send low byte firstly)
--> 0xBE, 0xEF, 0x10, 0x05, 0x00, 0xC6, 0xFF, 0x11, 0x11, 0x01, 0x00, 0x01
•
Control Commands List
To view the latest RS232 code, go to the Dell Support site at support.dell.com.
To view the latest SNMP commands and list, go to the Dell Support site at
support.dell.com.
146
Specifications
Compatibility Modes (Analog/Digital)
Resolution
Refresh Rate
(Hz)
Hsync Frequency
(KHz)
Pixel Clock (MHz)
640 x 350
640 x 480
720 x 480 p60
720 x 576 p50
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
1024 x 768
1280 x 720 p50
1280 x 720 p60
1920 x 1080 i50
1920 x 1080 i60
1280 x 720
1024 x 768
1280 x 800
1366 x 768
1360 x 768
1024 x 768
1440 x 900
1280 x 1024
1400 x 1050
1280 x 800
1280 x 1024
1440 x 900
1680 x 1050
1280 x 960
1920 x 1080
1024 x 768
70.087
59.940
59.940
50.000
70.087
75.000
85.008
60.317
75.000
85.061
60.004
50.000
60.000
50.000
60.000
59.855
75.029
59.810
59.790
60.015
84.997
59.887
60.020
59.978
84.880
75.025
74.984
59.954
85.002
60.000
119.989
31.469
31.469
31.469
31.250
31.469
37.500
43.269
37.879
46.875
53.674
48.363
37.500
45.000
28.125
33.750
44.772
60.023
49.702
47.712
47.712
68.677
55.935
63.981
65.317
71.554
79.976
70.635
65.290
85.938
67.500
97.551
25.175
25.175
27.000
27.000
28.322
31.500
36.000
40.000
49.500
56.250
65.000
74.250
74.250
74.250
74.250
74.500
78.750
83.500
85.500
85.500
94.500
106.500
108.000
121.750
122.500
135.000
136.750
146.250
148.500
148.500
115.500
Specifications
147
6
Contacting Dell
For customers in the United States, call 800-WWW-DELL (800-999-3355).
NOTE: If you do not have an active Internet connection, you can find
contact information on your purchase invoice, packing slip, bill, or
Dell product catalog.
Dell provides several online and telephone-based support and service
options. Availability varies by country and product, and some services may
not be available in your area. To contact Dell for sales, technical support, or
customer service issues:
1 Visit go to www.dell.com/contactDell.
2 Select your region on the interactive map.
3 Select a Segment for Contact.
4 Select the appropriate service or support link based on your
need.
148
Contacting Dell
Contacting Crestron
Crestron provides phone based and online technical support options.
Availability varies by country, but an e-mail to [email protected]
can be directed appropriately for users in any country.
Technical Support
In the US and Canada
Phone: 877-516-5394
Email: [email protected]
Outside the US and Canada
Phone: +1 201-367-1037
Email: [email protected]
Contacting Dell
149
7
Appendix: Glossary
ANSI Lumens — A standard for measuring the brightness. It is calculated by
dividing a square meter image into nine equal rectangles, measuring the
lux (or brightness) reading at the center of each rectangle, and averaging
these nine points.
Aspect Ratio — The most popular aspect ratio is 4:3 (4 by 3). Early
television and computer video formats are in a 4:3 aspect ratio, which
means that the width of the image is 4/3 times the height.
Brightness — The amount of light emitted from a display or projection
display or projection device. The brightness of projector is measured by
ANSI lumens.
Color Temperature — The color appearance of white light. Low color
temperature implies warmer (more yellow/red) light while high color
temperature implies a colder (more blue) light. The standard unit for color
temperature is Kelvin (K).
Component Video — A method of delivering quality video in a format that
consists of the luminance signal and two separate chrominance signals
and are defined as Y'Pb'Pr' for analog component and Y'Cb'Cr' for digital
component. Component video is available on DVD players.
Composite Video — A video signal that combines the luma (brightness),
chroma (color), burst (color reference), and sync (horizontal and vertical
synchronizing signals) into a signal waveform carried on a single wire pair.
There are three kinds of formats, namely, NTSC, PAL, and SECAM.
Compressed Resolution — If the input images are of higher resolution than
the native resolution of the projector, the resulting image will be scaled to
fit the native resolution of the projector. The nature of compression in a
digital device means that some image content is lost.
Contrast Ratio — Range of light and dark values in a picture, or the ratio
between their maximum and minimum values. There are two methods
used by the projection industry to measure the ratio:
1 Full On/Off — measures the ratio of the light output of an all white image
(full on) and the light output of an all black (full off) image.
2 ANSI — measures a pattern of 16 alternating black and white rectangles.
The average light output from the white rectangles is divided by the
150
Glossary
average light output of the black rectangles to determine the ANSI contrast
ratio.
Full On/Off contrast is always a larger number than ANSI contrast for the
same projector.
dB — decibel — A unit used to express relative difference in power or
intensity, usually between two acoustic or electric signals, equal to ten
times the common logarithm of the ratio of the two levels.
Diagonal Screen — A method of measuring the size of a screen or a
projected image. It measures from one corner to the opposite corner. A 9
FT high, 12 FT wide, screen has a diagonal of 15 FT. This document
assumes that the diagonal dimensions are for the traditional 4:3 ratio of a
computer image as per the example above.
DHCP — Dynamic Host Configuration Protocol — A network protocol that
enables a server to automatically assign a TCP/IP address to a device.
DLP® — Digital Light Processing™ — Reflective display technology
developed by Texas Instruments, using small manipulated mirrors. Light
passing through a color filter is sent to the DLP mirrors which arrange the
RGB colors into a picture projected onto screen, also known as DMD.
DMD — Digital Micro-Mirror Device — Each DMD consists of thousands of
tilting, microscopic aluminum alloy mirrors mounted on a hidden yoke.
DNS — Domain Name System — An Internet service that translates domain
names into IP addresses.
Focal Length — The distance from the surface of a lens to its focal point.
Frequency — It is the rate of repetition in cycles per seconds of electrical
signals. Measured in Hz (Hertz).
HDCP — High-Bandwidth Digital-Content Protection — A specification
developed by Intel™ Corporation to protect digital entertainment across
digital interface, such as DVI, HDMI.
HDMI — High-Definition Multimedia Interface — HDMI carries both
uncompressed high definition video along with digital audio and device
control data in a single connector.
Hz (Hertz) — Unit of frequency.
IEEE802.11 — A set of standards for wireless local are network (WLAN)
communication. 802.11b/g/n uses the 2.4 GHz band.
Keystone Correction — Device that will correct an image of the distortion
(usually a wide-top narrow-bottom effect) of a projected image caused by
improper projector to screen angle.
Glossary
151
Maximum Distance — The distance from a screen the projector can be to
cast an image that is usable (bright enough) in a fully darkened room.
Maximum Image Size — The largest image a projector can throw in a
darkened room. This is usually limited by focal range of the optics.
Minimum Distance — The closest position that a projector can focus an
image onto a screen.
NTSC — National Television Standards Committee. North American
standard for video and broadcasting, with a video format of 525 lines at 30
frames per second.
PAL — Phase Alternating Line. A European broadcast standard for video
and broadcasting, with a video format of 625 lines at 25 frames per second.
Reverse Image — Feature that allows you to flip the image horizontally.
When used in a normal forward projection environment text, graphics, etc.
are backwards. Reverse image is used for rear projection.
RGB — Red, Green, Blue — typically used to describe a monitor that
requires separate signals for each of the three colors.
SECAM — A French and international broadcast standard for video and
broadcasting, closely related to PAL but with a different method of sending
color information.
SSID — Service Set Identifiers — A name used to identify the particular
wireless LAN to which a user wants to connect.
SVGA — Super Video Graphics Array — 800 x 600 pixels count.
SXGA — Super Extended Graphics Array, — 1280 x 1024 pixels count.
UXGA — Ultra Extended Graphics Array — 1600 x 1200 pixels count.
VGA — Video Graphics Array — 640 x 480 pixels count.
WEP — Wired Equivalent Privacy — This is a method for encrypting
communication data. The encryption key is created and notified only to the
communicating user, so the communication data cannot be decrypted by
a third party.
XGA — Extended Video Graphics Array — 1024 x 768 pixels count.
WXGA — Wide Extended Graphics Array — 1280 x 800 pixels count.
152
Glossary
Index
A
Audio-A input connector 17
Audio-B input connector 17
Composite Video connector
17
HDMI-A/MHL connector for
support MHL feature 17
HDMI-B connector 17
Microphone connector 17
Mini USB (Mini Type B) 17
Power cord connector 17
RJ-45 connector 17
RS232 connector 17
USB Type A connector for
USB Viewer 17
USB Type B connector
(DoUSB) for USB Display
17
VGA output (monitor loop
through) connector 17
VGA-A input (D-sub)
connector 17
VGA-B input (D-sub)
connector 17
Adjusting Projector Focus 9
Focus ring 9
C
Changing the Lamp 136
Connecting the Projector
Audio cable 27
Commercial RS232 control
box 30
HDMI cable 19
MHL cable 23
Power cord 18, 19, 20, 21, 23,
26, 27, 28, 29, 30
RJ45 cable 29
RS232 (9-pin D-sub female to
female pin2-3 swap)
cable 30
RS232 cable 21
To Computer 18
USB flash disk 28
USB-A to Mini USB-B cable 18
USB-A to USB-B cable 20
VGA to VGA cable 18, 26
Connection Ports
Audio left-channel input
connector 17
Audio output connector 17
Audio right-channel input
connector 17
Contact Dell 5, 133, 136
D
Dell
contacting 148, 150
Index
153
I
VIDEO MODE 35
Interactive Pen
Battery 52
Pen tip 52
Power indicator 52
Power switch 52
Wrist strap holder 52
P
phone numbers 148
R
Remote Control 12
M
Main Unit 7
10 W speaker 7
Camera 7
Focus ring 7
IR receivers 7
Lamp cover 7
Lamp LED 7
Lens 7
Power button 7
Temp LED 7
O
On-Screen Display
ADVANCED SETTINGS 37
AUDIO EQ 36
AUDIO VOLUME 36
AUTO ADJUST 34
BRIGHTNESS/CONTRAST 35
HELP 50
INPUT SOURCE 32
INPUT SOURCE
MULTIPLE
DISPLAY 33
INPUT SOURCE USB 34
LANGUAGE 50
154
Index
S
Specifications
Aspect Ratio 142
Audio 143
Brightness 142
Color Wheel Speed 142
Contrast Ratio 142
Dimensions 143
Displayable Color 142
Environmental 144
I/O Connectors 144
Internal Flash 142
IR Pen Dimensions 143
IR Pen Weight 143
Light Valve 142
Noise Level 143
Number of Pixels 142
Power Consumption 143
Power Supply 142
Projection Distance 142
Projection Lens 142
Projection Screen Size 142
Projector Weight 143
RS232 Protocol 146
Uniformity 142
Video Compatibility 142
support
contacting Dell 148, 150
T
telephone numbers 148
Troubleshooting
Contact Dell 130
Index
155
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
