GENERAL
REPLACEMENT PARTS
Models D1EH and D1EM units are factory assembled cooling
only air conditioners designed for outdoor installation on a
rooftop or a slab. Field-installed electric heater accessories are
available to provide electric heat combined with electric cooling.
Refer to Replacement Parts Manual for complete listing of
replacement parts on this equipment.
The units are completely assembled on rigid, but easily
removable base rails. All piping, refrigerant charge, and
electrical wiring is factory installed and tested. The units require
only electric power and duct connections at the point of
installation.
This product must be installed in strict compliance
with the enclosed installation instructions and any
applicable local, state, and national codes
including, but not limited to, building, electrical,
and mechanical codes.
The electric heaters have nickel-chrome resistance wire
elements and utilize single point power connection.
INSPECTION
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier's freight bill. A separate
request for inspection by the carrier's agent should be made in
writing. Refer to Form 50.15-NM for additional information.
Improper installation may create a condition
where the operation of the product could cause
personal injury or property damage.
REFERENCE
Additional information on the design, installation, operation and
service of this equipment is available in the following reference
forms:
• 55.70-N1
-General Installation
• 55.70-N2
-Pre-start & Post-start Check List
• 035-16605-003-E-0605 -Electric Heater Accessory
352'8&7 120(1&/$785(
'
(
+
$
352'8&7 &$7(*25<
'
92/7$*( &2'(
6LQJOH 3DFNDJH $LU&RQGLWLRQHU
$LU &RROHG
352'8&7 *(1(5$7,21
1(: RU &XUUHQW 'HVLJQ
352'8&7 ,'(17,),(5
(+ 6((5&RROLQJ0RGHOV
(0 6((5&RROLQJ0RGHOV
Unitary Products Group
120,1$/ &22/,1*
&$3$&,7< 0%+
%78+ %78+
%78+ %78+
%78+ %78+
%78+
)$&725<
,167$//(' (/(&75,& +($7
$
1R (OHFWULF +HDW ,QVWDOOHG
3
128552-YIM-A-0605
INSTALLATION
angle iron frame providing adequate support under the
compressor/condenser section.
LIMITATIONS
5.
These units must be installed in accordance with the following
national and local safety codes.
RIGGING OR HANDLING
1.
National Electrical Code ANSI/NFPS No. 70 or Canadian
Electrical Code Part 1, C22.1 (latest editions).
2.
Local plumbing and waste water codes and other
applicable local codes.
Care must be exercised when moving the unit. Do not remove
any packaging until the unit is near the place of installation. Rig
unit with slings placed under the unit. Spreader bars of
sufficient length should be used across the top of the unit.
Refer to Table 1 for unit application data and to Tables 5 and 6
for electric heat application data.
If components are to be added to a unit to meet local codes,
they are to be installed at the dealer's and/or the customer's
expense.
Size of unit for proposed installation should be based on heat
loss/heat gain calculations made in accordance with industry
recognized procedures identified by the Air Conditioning
Contractors of America.
Maintain level tolerance of unit to 1/8" maximum.
BEFORE LIFTING A UNIT, MAKE SURE THAT ITS WEIGHT
IS DISTRIBUTED EQUALLY ON THE CABLES SO THAT IT
WILL LIFT EVENLY.
Units may also be moved or lifted with a fork-lift. Slotted
openings in the skid are provided for this purpose. Forks must
pass completely through the base.
TABLE 2: UNIT WEIGHTS
UNIT
SIZE
TABLE 1: UNIT APPLICATION DATA
208/230V2
Voltage Variation
460V
Min. / Max.1
575V
Wet Bulb Temperature (°F) of Air on
Evaporator Coil,
Min. / Max.
Dry Bulb Temperature (°F) of Air on
Condenser Coil,
Min.3 / Max.
SHIPPING OPERATING
WEIGHT
WEIGHT
(lbs.)
(lbs.)
018
024
030
036
042
048
060
187 / 253
432 / 504
540 / 630
57 / 72
45 / 120
1. Rated in accordance with ARI Standard 110, utilization
range “A”.
2. “T1" transformer primary tap must be moved from the
230 volt connection to the 208 volt connection for low
voltage applications of 208 volt and below.
3. A low ambient accessory is available for operation
down to 0°F
330
338
340
341
348
376
456
325
333
335
336
343
371
451
CORNER WEIGHTS
(location, lbs.)
“A”
“B”
“C”
“D”
89
78
76
86
91
80
78
88
86
83
83
87
92
81
79
89
94
83
80
91
94
89
94
99
127
122
101
106
³'´
)5217
2)
81,7
&(17(52)*5$9,7<
³$´
³&´
³%´
LOCATION
FIGURE 1: CENTER OF GRAVITY
Use the following guidelines to select a suitable location for
these units.
Refer to Table 2 for unit weights and to Figure 1 for approximate
center of gravity.
1.
Unit is designed for outdoor installation only.
2.
Condenser must have an unlimited supply of air. Where a
choice of location is possible, position unit on either north
or east side of building.
3.
4.
4
For ground level installation, a level pad or slab should be
used. The thickness and size of the pad or slab used
should meet local codes and unit weight. Do not tie the
slab to the building foundation.
For roof top installation, be sure the structure will support
the weight of the unit plus any field installed components.
Unit must be installed on a level roof curb or appropriate
CLEARANCES
All units require certain clearances for proper operation and
service. Refer to Figure 7 for the clearances required for
combustion, construction, servicing and proper unit operation.
:
Do not permit overhanging structures or shrubs to
obstruct the condenser air discharge outlet.
Unitary Products Group
128552-YIM-A-0605
DUCT WORK
SERVICE ACCESS
These units are adaptable to downflow use as well as rear
supply and return air duct openings. To convert to downflow,
use the following steps:
Access to all serviceable components is provided by the
following removable panels:
• Blower service access
• Electrical/filter access
• Compressor service access
1.
Remove the duct covers found in the bottom return and
supply air duct openings. There are four (4) screws
securing each duct cover (save these screws to use later).
2.
Install the duct covers, removed in step one, to the rear
supply and return air duct openings. Secure with the four
(4) screws used in step one.
3.
Seal the duct covers with silicone caulking.
Downflow units must have an L-shaped supply duct without any
outlets or registers located directly below the supply outlet of
the unit.
Duct work should be designed and sized according to the
methods of the Air Conditioning Contractors of America
(ACCA), as set forth in their Manual D.
A closed return duct system shall be used. This shall not
preclude use of economizers or ventilation air intake. Flexible
joints may be used in the supply and return duct work to
minimize the transmission of noise.
When fastening duct work to the side duct flanges on
the unit, insert the screws through the duct flanges only.
DO NOT insert the screws through the casing. Outdoor
duct work must be insulated and waterproofed.
NOTE: Be sure to note supply and return openings.
Refer to Figure 7 for information concerning rear and bottom
supply and return air duct openings.
FILTERS
Single phase units are shipped without a filter and is the
responsibility of the installer to secure a filter in the return air
ductwork or install a Filter/Frame Kit (1FF0114).
A filter rack and a filters are standard on three phase units.
Filters must always be used and must be kept clean. When
filters become dirt laden, insufficient air will be delivered by the
blower, decreasing your units efficiency and increasing
operating costs and wear-and-tear on the unit and controls.
Filters should be checked monthly especially since this unit may
be used for both heating and cooling.
Refer to Figure 7 for location of these access panels and
minimum clearance.
THERMOSTAT
The room thermostat should be located on an inside wall
approximately 56" above the floor where it will not be subject to
drafts, sun exposure or heat from electrical fixtures or
appliances. Follow manufacturer's instructions enclosed with
the thermostat for general installation procedure. Four, five or
six color coded insulated wires (minimum #18 AWG) should be
used to connect thermostat to unit. See Figure 2.
POWER AND CONTROL WIRING
Field wiring to the unit must conform to provisions of the current
N.E.C. ANSI/NFPA No. 70 or C.E.C. and/or local ordinances.
The unit must be electrically grounded in accordance with local
codes or, in their absence, with the N.E.C./C.E.C. Voltage
tolerances which must be maintained at the compressor
terminals during starting and running conditions are indicated
on the unit Rating Plate and Table 1.
The wiring entering the cabinet must be provided with
mechanical strain relief.
A fused or HACR breaker disconnect switch should be field
provided for the unit. If any of the wire supplied with the unit
must be replaced, replacement wire must be of the type shown
on the wiring diagram.
Electrical line must be sized properly to carry the load. Each
unit must be wired with a separate branch circuit fed directly
from the meter panel and properly fused.
Refer to Figure 2 for typical field wiring and to the appropriate
unit wiring diagram for control circuit and power wiring
information.
COMPRESSORS
Units are shipped with compressor mountings factory-adjusted
for shipping.
Loosen compressor mounting bolts half turn before
operating unit.
CONDENSATE DRAIN
A condensate trap is required to be installed in the condensate
drain. The plumbing must conform to local codes. Use a sealing
compound on male pipe threads. Install the condensate drain
line (¾“ NPTF) to spill into an open drain.
Unitary Products Group
COOLING
The following sequences of operation are based on using a
standard single-stage cooling thermostat.
5
128552-YIM-A-0605
TABLE 3: PHYSICAL DATA
MODELS
018
9x6
½
2
13
4.38
22
¼
1,800
1
20
12.9
5/5
EVAPORATOR CENTRIFUGAL BLOWER (Dia. x Wd. in.)
BLOWER
FAN MOTOR HP (Three Speed, Direct Drive))
ROWS DEEP
EVAPORATOR
FINS PER INCH
COIL
FACE AREA (Sq. Ft.)
PROPELLER DIA. (in.)
CONDENSER
FAN MOTOR HP
FAN
NOM. CFM TOTAL
ROWS DEEP
CONDENSER
FINS PER INCH
COIL
FACE AREA (Sq. Ft.)
CHARGE
REFRIGERANT 22 (lbs./oz.)
FILTER
FACE AREA (Sq. Ft.) / Qty. / Size
COMPRESSOR HERMETIC, QTY. = 1 (Type)
Recip.
MODELS
EVAPORATOR CENTRIFUGAL BLOWER (Dia. x Wd. in.)
BLOWER
FAN MOTOR HP (ECM)1
ROWS DEEP
EVAPORATOR
FINS PER INCH
COIL
FACE AREA (Sq. Ft.)
PROPELLER DIA. (in.)
CONDENSER
FAN MOTOR HP
FAN
NOM. CFM TOTAL
ROWS DEEP
CONDENSER
FINS PER INCH
COIL
FACE AREA (Sq. Ft.)
CHARGE
REFRIGERANT 22 (lbs./oz.)
FILTER
FACE AREA (Sq. Ft.) / Qty. / Size
COMPRESSOR HERMETIC, QTY. = 1 (Type)
024
10 x 8
½
2
15
4.38
22
¼
1,800
1
20
12.9
5/3
Recip.
DEH
030
036
042
10 x 8
10 x 8
11 x 10
½
½
½
2
3
3
15
13
15
4.38
4.38
4.38
22
22
22
¼
¼
¼
1,800
1,800
2,400
1
1
1
20
20
20
12.9
12.9
12.9
4/7
4/11
5/10
2.14 / 1 / 14" x 22"
Scroll
Scroll
Scroll
024
10 x 8
½
2
15
4.38
22
¼
1,800
1
20
12.9
4/10
030
10 x 8
½
2
15
4.38
22
¼
1,800
1
20
12.9
4/13
Recip.
Recip.
DEM
036
042
10 x 8
11 x 10
3
½
4
3
3
13
16
4.38
4.38
22
22
¼
¼
1,800
2,400
1
1
20
20
12.9
12.9
4/6
4/12
2.14 / 1 / 14" x 22
Scroll
Scroll
048
11 x 10
½
3
16
5.63
22
1
3
060
11 x 10
1
3
16
5.63
22
1
3
3,000
1
20
16.4
7/0
3,000
1
20
16.4
9/0
Scroll
Scroll
048
11 x 10
3
16
5.63
22
¼
3,000
1
20
16.4
6/0
060
11 x 10
1
3
16
5.63
22
¼
3,000
1
20
16.4
7/12
Scroll
Scroll
3
4
1. ECM = Electrically Controlled Motor
6
Unitary Products Group
128552-YIM-A-0605
&21752/ :,5,1*
81,7 7(50,1$/ 675,3
7+(50267$7
0LQLPXPZLUHVL]HRI$:*
ZLUHVKRXOGEHXVHGIRUDOOILHOG
LQVWDOOHGYROWZLUH
127(
+($7 $17,&,3$7256+28/'%(6(7
$7 $036)25$// 02'(/6
92/7 75$16)250(5
352*5$00$%/(
7+(50267$7 21/<
2QO\UHTXLUHGRQXQLWVZLWK
VXSSOHPHQWDOHOHFWULFKHDW
&$87,21 /DEHO DOO ZLUHV SULRU WR GLVFRQQHFWLRQ ZKHQ VHUYLFLQJ FRQWUROV :LULQJ HUURUV FDQ
FDXVH LPSURSHU DQG GDQJHURXV RSHUDWLRQ 9HULI\ SURSHU RSHUDWLRQ DIWHU VHUYLFLQJ
32:(5:,5,1*
5()(572(/(&75,&$/ '$7$
7$%/(6726,=(7+(',6
&211(&7 6:,7&+:,5,1*
29(5&855(17 3527(&7,21
5()(572(/(&75,&$/ '$7$
7$%/(6726,=(7+(',6
&211(&7 6:,7&+:,5,1*
29(5&855(17 3527(&7,21
FIGURE 2: TYPICAL FIELD WIRING DIAGRAM
TABLE 4: ELECTRICAL DATA (BASIC UNIT)
MODEL
DEH
POWER
SUPPLY
018
024
030
036
042
030
036
042
030
036
042
036
042
048
060
208/230-1-60
208/230-1-60
208/230-1-60
208/230-1-60
208/230-1-60
208/230-3-60
208/230-3-60
208/230-3-60
460-3-60
460-3-60
460-3-60
575-3-60
575-3-60
575-3-60
575-3-60
MODEL
DEM
POWER
SUPPLY
024
030
036
042
048
060
042
048
060
042
048
060
042
208/230-1-60
208/230-1-60
208/230-1-60
208/230-1-60
208/230-1-60
208/230-1-60
208/230-3-60
208/230-3-60
208/230-3-60
460-3-60
460-3-60
460-3-60
575-3-60
MAX.
VOLTAGE
MIN.
COMPRESSOR COND.
MAX.
TRANSFORMER
UNIT
HACR
SUPPLY
LIMITATIONS1
CIRCUIT
FAN
FUSE
SIZE
BREAKER POWER
AIR BLOWER
AMPACITY SIZE
MOTOR,
MIN. MAX. RLA
LRA
(VA)
FACTORY
SIZE
MOTOR, FLA
(AMPS) 2 (AMPS)
FLA
(AMPS)
187
253
7.1
48.0
1.1
2.6
12.5
15
15
.96
40
187
253
9.3
57.0
1.1
2.6
15.3
20
20
.96
40
187
253
15.0
72.5
1.1
2.6
22.5
30
30
.96
40
187
253
17.2
88.0
1.1
3.5
26.1
35
35
.96
40
187
253
20.0
104.0
1.1
3.5
29.6
40
40
.96
40
187
253
10.0
63.0
1.1
2.6
16.2
25
25
.96
75
187
253
11.4
77.0
1.1
3.5
18.9
25
25
.96
75
187
253
13.9
88.0
1.1
3.5
22.0
30
30
.96
75
432
504
5.0
31.0
0.6
1.4
8.3
15
15
.96
75
432
504
5.7
39.0
0.6
1.8
9.5
15
15
.96
75
432
504
6.4
44.0
0.6
1.8
10.4
15
15
.96
75
540
630
4.7
31.0
0.4
1.5
7.8
15
15
.96
75
540
630
5.4
34.0
0.4
1.5
8.7
15
15
.96
75
540
630
5.8
36.0
0.6
2.0
9.8
15
15
.96
75
540
630
6.4
40.0
0.6
2.8
11.4
15
15
.96
75
VOLTAGE
MAX.
MIN.
MAX.
COMPRESSOR COND.
LIMITATIONS1
TRANSFORMER
UNIT
HACR
SUPPLY
CIRCUIT
FUSE
FAN
SIZE
BREAKER POWER
AIR BLOWER
AMPACITY SIZE
MOTOR,
MIN. MAX. RLA
LRA
(VA)
FACTORY
SIZE
MOTOR, FLA
2
(AMPS)
(AMPS)
FLA
(AMPS)
187
253
10
55
1.1
4.3
17.9
25
25
0.96
40
187
253
11.2
68
1.1
4.3
19.4
30
30
0.96
40
187
253
17.2
88
1.1
4.3
26.9
35
35
0.96
40
187
253
21
115
1.6
6.8
34.8
50
50
0.96
40
187
253
20.5
115
1.3
7.3
34.7
45
45
0.96
40
187
253
28.8
169
1.3
9.4
46.8
60
60
0.96
40
187
253
13.4
89
1.6
6.8
25.2
35
35
0.96
75
187
253
14.1
90
1.3
7.3
26.2
35
35
0.96
75
187
253
19.3
123
1.3
9.4
34.8
45
45
0.96
75
432
504
6.4
45
0.8
6.8
15.7
20
20
0.96
75
432
504
7.1
45
0.7
7.3
13.2
20
20
0.96
75
432
504
7.5
49.5
0.7
9.4
14.8
20
20
0.96
75
540
630
6
38
0.6
6.8
15.2
20
20
0.96
75
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element, time delay type.
Unitary Products Group
7
128552-YIM-A-0605
TABLE 5: ELECTRICAL DATA (COOLING/ELECTRIC HEAT) DEH018, 024, 030, 036, 042, 048 AND 060
COMPRESSOR
OUTDOOR.
SUPPLY
FAN
AIR BLOWER
MOTOR,
MOTOR, FLA
FLA
MODEL
DEH
POWER
SUPPLY
RLA
LRA
018
208/230-1-60
9.0
48.0
1.1
2.6
024
208/230-1-60 11.2
60.0
1.1
2.6
030
208/230-1-60 12.0
73.0
1.1
2.6
036
208/230-1-60 17.3
94.0
1.1
3.5
042
208/230-1-60 20.5
120.0
1.1
3.5
030
208/230-3-60 10.0
63.0
1.1
2.6
036
208/230-3-60 10.9
78.0
1.1
3.5
042
208/230-3-60 14.1
110.0
1.1
3.5
030
460-3-60
5.0
31.0
0.6
1.4
036
460-3-60
5.8
40.0
0.6
1.8
042
460-3-60
7.1
54.0
0.6
1.8
036
575-3-60
4.5
32.0
0.4
1.5
042
575-3-60
5.8
44.0
0.4
1.5
048
575-3-60
5.8
36.0
0.6
2.0
060
575-3-60
6.4
40.0
0.6
2.8
ELECTRIC HEAT ACCESSORY
MODEL
NO.
STAGE
KW
TOTAL
AMPS
2NH04500506
2NH04500706
2NH04500506
2NH04500706
2NH04501006
2NH04500506
2NH04500706
2NH04501006
2NH04501506
2NH04500506
2NH04500706
2NH04501006
2NH04501506
2NH04500506
2NH04500706
2NH04501006
2NH04501506
2NH04501025
2NH04501525
2NH04501025
2NH04501525
2NH04501025
2NH04501525
2NH04501046
2NH04501546
2NH04501046
2NH04501546
2NH04501046
2NH04501546
2NH04501058
2NH04501558
2NH04501058
2NH04501558
2NH04501058
2NH04501558
2NH04502058
2NH04502558
2NH04501058
2NH04501558
2NH04502058
2NH04502558
1
2
1
2
2
1
2
2
2
1
2
2
2
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
2
2
3.8/5.0*
5.6/7.5*
3.8/5.0*
5.6/7.5*
7.5/10.0*
3.8/5.0*
5.6/7.5*
7.5/10.0*
11.3/15.0*
3.8/5.0*
5.6/7.5*
7.5/10.0*
11.3/15.0*
3.8/5.0*
5.6/7.5*
7.5/10.0*
11.3/15.0*
7.5/10.0*
11.3/15.0*
7.5/10.0*
11.3/15.0*
7.5/10.0*
11.3/15.0*
10.0**
15.0**
10.0**
15.0**
10.0**
15.0**
10.0***
15.0***
10.0***
15.0***
10.0***
15.0***
20.0***
25.0***
10.0***
15.0***
20.0***
25.0***
18.1/20.8
27.1/31.3
18.1/20.8
27.1/31.3
36.1/41.7
18.1/20.8
27.3/31.3
36.1/41.7
54.2/62.5
18.1/20.8
27.1/31.3
36.1/41.7
54.2/62.5
18.1/20.8
27.1/31.3
36.1/41.7
54.2/62.5
20.8/24.1
31.3/36.1
20.8/24.1
31.3/36.1
20.8/24.1
31.3/36.1
12.0
18.0
12.0
18.0
12.0
18.0
9.6
14.4
9.6
14.4
9.6
14.4
19.2
24.1
9.6
14.4
19.2
24.1
MIN.
CIRCUIT
AMPACITY
(AMPS)
25.8/29.3
37.1/42.3
25.8/29.3
37.1/42.3
48.4/55.3
25.8/29.3
37.1/42.3
48.4/55.3
71.0/81.4
26.9/30.4
38.2/43.4
49.5/56.5
72.1/82.5
30.2/30.4
38.2/43.4
49.5/56.5
72.1/82.5
29.3/33.3
42.3/48.4
30.4/34.4
43.5/49.5
30.4/34.4
43.5/49.5
16.8
24.3
17.3
24.8
17.3
24.8
13.9
19.9
13.9
19.9
14.5
20.5
26.6
32.6
15.5
21.5
27.6
33.6
MAX.
MAX.
HACR2
FUSE
BREAKER
SIZE1
SIZE
(AMPS)
(AMPS)
30/30
30/30
40/45
40/45
30/30
30/30
40/45
40/45
50/60
50/60
30/30
30/30
40/45
40/45
50/60
50/60
80/90
80/90
35/40
35/40
40/45
40/45
50/60
50/60
80/90
80/90
40/40
40/40
50/50
50/50
50/60
50/60
80/90
80/90
30/35
30/35
45/50
45/50
35/35
35/35
45/50
45/50
35/35
35/35
45/50
45/50
20
20
25
25
20
20
25
25
20
20
25
25
15
15
20
20
15
15
20
20
15
15
25
25
30
30
35
35
20
20
25
25
30
30
35
35
1. Dual element, time delay type.
2. Standard circuit breakers may be used in Canada and on applications over 60 amps where the heaters are separately fused.
*. KW listed is for 240 volts, use Table 15 for 208 or 230 volts.
**. KW listed is for 480 volts, use Table 15 for 460 volts.
***.KW listed is for 600 volts, use Table 15 for 575 volts.
Nominal
Voltage
240
480
600
8
Voltage
208
230
460
575
KW Capacity
Multiplier
0.75
0.92
0.92
0.92
Unitary Products Group
128552-YIM-A-0605
TABLE 6: ELECTRICAL DATA (COOLING/ELECTRIC HEAT) DEM024, 030, 036, 042, 048 AND 060
COMPRESSOR
MODEL
DEM
POWER
SUPPLY
OUTDOOR.
SUPPLY
FAN
AIR BLOWER
MOTOR,
MOTOR, FLA
FLA
RLA
LRA
024
208/230-1-60 10.0
55.0
1.1
4.3
030
208/230-1-60 11.0
68.0
1.1
4.3
036
208/230-1-60 17.2
94.0
1.1
7.3
042
208/230-1-60 21.1
115.0
1.6
6.8
048
208/230-1-60 20.5
115.0
1.3
7.3
060
208/230-1-60 28.8
169.0
1.3
9.4
042
208/230-3-60 13.4
89.0
1.6
6.8
048
208/230-3-60 14.1
90.0
1.3
7.3
060
208/230-3-60 19.3
123.0
1.3
9.4
042
460-3-60
6.4
45.0
0.75
6.8
048
460-3-60
7.1
45.0
0.7
7.3
060
460-3-60
7.5
49.5
0.7
9.4
042
575-3-60
6.4
38.0
0.6
6.8
ELECTRIC HEAT ACCESSORY
MODEL
NO.
STAGE
KW
TOTAL
AMPS
2NH04500506
2NH04500706
2NH04501006
2NH04500506
2NH04500706
2NH04501006
2NH04501506
2NH04500506
2NH04500706
2NH04501006
2NH04501506
2NH04500506
2NH04500706
2NH04501006
2NH04501506
2NH04501006
2NH04501506
2NH04502006
2NH04502506
2NH04501006
2NH04501506
2NH04502006
2NH04502506
2NH04501025
2NH04501525
2NH04501025
2NH04501525
2NH04502025
2NH04502525
2NH04501025
2NH04501525
2NH04502025
2NH04502525
2NH04501046
2NH04501546
2NH04501046
2NH04501546
2NH04502046
2NH04502546
2NH04501046
2NH04501546
2NH04502046
2NH04502546
2NH04501058
2NH04501558
1
2
2
1
2
2
2
1
2
2
2
1
2
2
2
2
2
2
2
2
2
2
2
1
1
1
1
2
2
1
1
2
2
1
1
1
1
2
2
1
1
2
2
1
1
3.8/5.0*
5.6/7.5*
7.5/10.0*
3.8/5.0*
5.6/7.5*
7.5/10.0*
11.3/15.0*
3.8/5.0*
5.6/7.5*
7.5/10.0*
11.3/15.0*
3.8/5.0*
5.6/7.5*
7.5/10.0*
11.3/15.0*
7.5/10.0*
11.3/15.0*
15.0/20.0*
18.8/25.0*
7.5/10.0*
11.3/15.0*
15.0/20.0*
18.8/25.0*
7.5/10.0*
11.3/15.0*
7.5/10.0*
11.3/15.0*
15.0/20.0*
18.8/25.0*
7.5/10.0*
11.3/15.0*
15.0/20.0*
18.8/25.0*
10.0**
15.0**
10.0**
15.0**
20.0**
25.0**
10.0**
15.0**
20.0**
25.0**
10.0***
15.0***
18.1/20.8
27.1/31.3
36.1/41.7
18.3/20.8
26.9/31.3
36.1/41.7
54.2/62.5
18.1/20.8
27.1/31.3
36.1/41.7
54.2/62.5
18.1/20.8
27.1/31.3
36.1/41.7
54.2/62.5
36.1/41.7
54.2/62.5
72.2/83.3
90.3/104.2
36.1/41.7
54.2/62.5
72.2/83.3
90.3/104.2
20.8/24.1
31.3/36.1
20.8/24.1
31.3/36.1
41.7/48.1
52.1/60.1
20.8/24.1
31.3/36.1
41.7/48.1
52.1/60.1
12.0
18.0
12.0
18.0
24.1
30.1
12.0
18.0
24.1
30.1
10.0
15.1
MIN.
CIRCUIT
AMPACITY
(AMPS)
28.2/31.4
39.0/44.4
50.4/57.5
28.2/31.4
39.0/44.4
50.4/57.5
73.3/83.5
27.7/31.2
39.0/44.2
50.3/57.3
72.9/83.3
31.1/34.5
42.4/47.6
53.6/60.6
76.2/86.6
54.3/61.2
76.8/87.3
99.4/113.3
122.0/139.3
56.9/63.8
79.5/89.9
102.0/115.9
124.6/142.0
34.6/38.6
47.6/53.6
35.2/39.2
48.2/54.2
61.2/69.3
74.3/84.3
37.8/41.8
50.8/56.9
63.9/71.9
76.9/86.9
23.5
31.1
24.2
31.7
34.6
42.2
20.9
28.4
35.9
43.5
21.1
27.5
MAX.
MAX.
HACR2
FUSE
BREAKER
SIZE1
SIZE
(AMPS)
(AMPS)
30/35
30/35
40/45
40/45
60/60
60/60
30/35
30/35
40/45
40/45
60/60
60/60
80/80
80/80
35/40
35/40
40/45
40/45
60/60
60/60
80/90
80/90
35/35
35/35
45/50
45/50
60/70
60/70
80/80
80/80
60/70
60/70
80/90
80/90
100/125 100/125
125/150 125/150
70/70
70/70
80/90
80/90
110/125 110/125
125/150 125/150
35/40
35/40
50/60
50/60
40/40
40/40
50/60
50/60
70/70
70/70
80/90
80/90
50/50
50/50
60/60
60/60
70/80
70/80
80/90
80/90
25
25
35
35
25
25
35
35
35
35
45
45
25
25
30
30
40
40
45
45
25
25
30
30
1. Dual element, time delay type.
2. Standard circuit breakers may be used in Canada and on applications over 60 amps where the heaters are separately fused.
*. KW listed is for 240 volts, use Table 15 for 208 or 230 volts.
**. KW listed is for 480 volts, use Table 15 for 460 volts.
***.KW listed is for 600 volts, use Table 15 for 575 volts.
Nominal
Voltage
240
480
600
Unitary Products Group
Voltage
208
230
460
575
KW Capacity
Multiplier
0.75
0.92
0.92
0.92
9
128552-YIM-A-0605
CHECKING SUPPLY AIR CFM
4.
To check the supply air CFM after the initial balancing has been
completed:
1.
Remove the two ¼ inch dot plugs in the duct panel.
2.
Insert at least 8 inches of ¼ inch tubing into each of these
holes for sufficient penetration into the airflow on both
sides of the indoor coil.
3.
Knowing the pressure drop across a dry coil, the actual
CFM through the unit can be determined from the curve in
Coil Delta P vs. Supply Air CFM figure.
Failure to properly adjust the total system air quantity
can result in extensive system damage.
Using an inclined manometer, determine the pressure drop
across the dry evaporator coil. Since the moisture on an
evaporator coil may vary greatly, measuring the pressure
drop across a wet coil under field conditions would be
inaccurate. To ensure a dry coil, the compressors should
be deactivated while the test is being run.
After readings have been obtained, remove the tubes and
reinstall the two ¼ inch plugs removed in Step 1.
NOTE: De-energize the compressors before taking any test
measurements to ensure a dry indoor coil.
'(+'(0&RLO'HOWD3YV¶$LUIORZ
7RQ
,'&RLO'HOWD3
7RQ
7RQ
7RQ
7RQ
$LUIORZ&)0
FIGURE 3: COIL DELTA P VS AIRFLOW
10
Unitary Products Group
128552-YIM-A-0605
TABLE 7: D1EH018 SUPERHEAT CHARGING TABLE
OUTDOOR|
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
55
57
59
61
63
65
67
69
71
73
(°F)
65
17.1
19.8
22.5
25.3
28.0
30.7
33.4
33.7
34.1
34.3
70
11.7
14.9
18.0
21.2
24.4
27.5
30.7
31.3
31.9
32.5
75
6.3
9.9
13.5
17.1
20.8
24.4
28.0
28.9
29.8
30.6
80
9.0
13.1
17.2
21.2
25.3
26.4
27.6
28.7
85
9.0
13.6
18.1
22.6
24.0
25.4
26.8
90
6.8
10.2
13.6
17.0
19.4
21.9
24.3
95
6.8
9.0
11.3
14.8
18.3
21.8
100
5.3
7.0
8.8
12.6
16.4
20.3
105
6.2
10.4
14.6
18.7
110
8.2
12.7
17.2
115
6.0
10.8
15.7
75
34.8
33.1
31.5
29.9
28.3
26.8
25.3
24.1
22.9
21.7
20.5
TABLE 8: D1EH024 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
33.5
33.7
33.9
34.1
34.3
34.6
34.8
35.1
35.4
35.7
70
30.5
30.9
31.3
31.6
32.0
32.4
32.8
33.4
34.0
34.6
75
27.6
28.1
28.6
29.1
29.7
30.2
30.7
31.6
32.5
33.4
80
24.6
25.3
26.0
26.7
27.3
28.0
28.7
29.9
31.1
32.2
85
21.6
22.5
23.3
24.2
25.0
25.8
26.7
28.2
29.6
31.1
90
14.6
16.0
17.4
18.8
20.3
21.7
23.1
25.2
27.3
29.4
95
7.5
9.5
11.5
13.5
15.6
17.6
19.6
22.3
25.0
27.8
100
5.9
7.6
9.3
11.1
12.8
14.5
16.2
18.9
21.6
24.2
105
5.7
7.2
8.6
10.0
11.4
12.9
15.5
18.1
20.7
110
6.1
7.3
8.4
9.5
12.1
14.6
17.2
115
5.3
6.1
8.7
11.2
13.7
75
36.0
35.2
34.3
33.4
32.5
31.5
30.5
26.9
23.3
19.8
16.2
TABLE 9: D1EH030 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
21.6
22.5
23.4
24.3
25.3
26.2
27.1
27.5
28.0
28.4
70
18.0
19.3
20.5
21.7
23.0
24.2
25.4
26.0
26.6
27.1
75
14.5
16.1
17.6
19.1
20.7
22.2
23.8
24.5
25.2
25.9
80
11.0
12.8
14.7
16.5
18.4
20.3
22.1
23.0
23.8
24.7
85
7.4
9.6
11.8
14.0
16.1
18.3
20.5
21.5
22.4
23.4
90
5.6
7.9
10.3
12.6
15.0
17.3
18.8
20.3
21.9
95
6.6
9.1
11.6
14.1
16.2
18.3
20.3
100
5.4
7.2
9.1
11.0
13.5
16.1
18.7
105
5.3
6.6
7.8
10.9
14.0
17.1
110
8.3
11.9
15.5
115
5.7
9.8
14.0
75
28.8
27.7
26.6
25.5
24.4
23.4
22.4
21.3
20.3
19.2
18.1
TABLE 10: D1EH036 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
6.5
8.5
10.6
12.6
14.7
16.8
18.8
21.3
23.7
26.1
70
5.4
7.3
9.1
11.0
12.8
14.7
16.6
19.1
21.6
24.2
75
6.0
7.6
9.3
11.0
12.7
14.3
16.9
19.6
22.2
80
6.2
7.7
9.1
10.6
12.1
14.8
17.5
20.2
85
6.0
7.3
8.5
9.8
12.6
15.4
18.2
90
5.4
6.5
7.5
8.6
11.6
14.5
17.4
95
5.6
6.5
7.4
10.5
13.6
16.6
100
5.5
6.3
9.1
12.0
14.9
105
5.1
7.8
10.4
13.1
110
6.4
8.9
11.3
115
5.1
7.3
9.5
75
28.6
26.7
24.8
22.9
21.1
20.4
19.7
17.7
15.7
13.7
11.8
1
Unitary Products Group
11
128552-YIM-A-0605
TABLE 11: D1EH042 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
24.9
25.4
26.0
26.6
27.2
27.8
28.3
28.6
28.9
29.2
70
21.6
22.3
23.0
23.7
24.3
25.0
25.7
26.4
27.2
28.0
75
18.4
19.2
19.9
20.7
21.5
22.3
23.0
24.2
25.5
26.7
80
15.2
16.0
16.9
17.8
18.6
19.5
20.4
22.0
23.7
25.4
85
12.0
12.9
13.9
14.8
15.8
16.8
17.7
19.8
22.0
24.1
90
7.9
8.8
9.8
10.7
11.7
12.7
13.6
16.8
19.9
23.1
95
5.7
6.6
7.6
8.6
9.5
13.7
17.9
22.1
100
5.6
6.4
7.2
8.0
11.7
15.4
19.1
105
5.3
5.9
6.6
9.8
12.9
16.1
110
5.1
7.8
10.5
13.1
115
5.8
8.0
10.2
75
29.5
28.7
27.9
27.1
26.3
26.3
26.3
22.8
19.3
15.8
12.3
TABLE 12: D1EM024 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
20.8
22.5
24.2
25.8
27.5
29.1
30.8
31.5
32.2
32.8
70
19.8
21.5
23.1
24.8
26.4
28.1
29.8
30.4
31.1
31.8
75
18.8
20.5
22.1
23.8
25.4
27.1
28.7
29.4
30.1
30.7
80
17.8
19.4
21.1
22.7
24.4
26.0
27.7
28.3
29.0
29.7
85
16.8
18.4
20.0
21.7
23.3
25.0
26.6
27.3
28.0
28.6
90
13.7
15.2
16.7
18.3
19.8
21.3
22.9
24.2
25.5
26.9
95
10.6
12.0
13.4
14.8
16.3
17.7
19.1
21.1
23.1
25.1
100
8.2
9.3
10.3
11.4
12.5
13.5
14.6
16.5
18.4
20.3
105
5.8
6.6
7.3
8.0
8.7
9.4
10.1
11.9
13.7
15.5
110
5.2
5.6
7.3
9.0
10.7
115
5.9
75
33.5
32.5
31.4
30.4
29.3
28.2
27.1
22.2
17.3
12.4
7.5
TABLE 13: D1EM030 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
16.0
17.7
19.4
21.1
22.9
24.6
26.3
27.7
29.2
30.6
70
15.0
16.7
18.4
20.1
21.8
23.5
25.3
26.7
28.1
29.6
75
13.9
15.7
17.4
19.1
20.8
22.5
24.2
25.6
27.1
28.5
80
12.9
14.6
16.3
18.0
19.7
21.4
23.2
24.6
26.0
27.5
85
11.9
13.6
15.3
17.0
18.7
20.4
22.1
23.5
25.0
26.4
90
7.2
9.5
11.8
14.2
16.5
18.8
20.8
22.7
24.7
95
6.7
9.6
12.6
15.5
18.0
20.5
22.9
100
5.8
8.0
10.2
12.4
14.8
17.3
19.8
105
6.4
7.8
9.2
11.7
14.1
16.6
110
5.4
6.1
8.5
11.0
13.4
115
5.3
7.8
10.2
75
32.1
31.0
30.0
28.9
27.9
26.6
25.4
22.2
19.0
15.9
12.7
TABLE 14: D1EM036 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
21.6
22.5
23.4
24.3
25.3
26.2
27.1
27.5
28.0
28.4
70
18.0
19.3
20.5
21.7
23.0
24.2
25.4
26.0
26.6
27.1
75
14.5
16.0
17.6
19.1
20.7
22.2
23.8
24.5
25.2
25.9
80
11.0
12.8
14.7
16.5
18.4
20.3
22.1
23.0
23.8
24.7
85
7.4
9.6
11.8
14.0
16.1
18.3
20.5
21.5
22.4
23.4
90
5.6
7.9
10.3
12.6
15.0
17.3
18.8
20.3
21.9
95
6.6
9.1
11.6
14.1
16.2
18.3
20.3
100
5.4
7.2
9.1
10.9
13.5
16.1
18.7
105
5.3
6.6
7.8
10.9
14.0
17.1
110
8.3
11.9
15.5
115
5.7
9.8
14.0
75
28.8
27.7
26.6
25.5
24.4
23.4
22.4
21.3
20.3
19.2
18.1
12
Unitary Products Group
128552-YIM-A-0605
TABLE 15: D1EM042 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
9.6
12.0
14.4
16.8
19.2
21.6
24.0
26.4
28.8
31.2
70
8.9
11.0
13.1
15.3
17.4
19.5
21.7
23.9
26.2
28.5
75
8.1
10.0
11.9
13.7
15.6
17.4
19.3
21.5
23.7
25.8
80
7.4
9.0
10.6
12.2
13.8
15.4
17.0
19.0
21.1
23.2
85
6.7
8.0
9.3
10.6
12.0
13.3
14.6
16.6
18.5
20.5
90
5.4
6.7
8.0
9.2
10.5
11.8
14.1
16.4
18.6
95
5.3
6.5
7.8
9.0
11.6
14.2
16.8
100
5.0
5.9
6.8
9.3
11.8
14.2
105
7.0
9.3
11.7
110
6.9
9.1
115
6.5
75
33.6
30.8
28.0
25.2
22.4
20.9
19.4
16.7
14.0
11.3
8.6
TABLE 16: D1EH048 SUPERHEAT CHARGING TABLE
OUTDOOR
SUPERHEAT AT COMPRESSOR SUCTION (°F), AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE (°F)
TEMPERATURE
(°F)
55
57
59
61
63
65
67
69
71
73
65
27.6
27.8
28.0
28.1
28.3
28.5
28.7
29.2
29.1
30.3
70
23.3 223.8
24.3
24.8
25.4
25.9
26.4
27.2
28.0
28.8
75
19.0
19.8
20.7
21.5
22.4
23.3
24.1
25.2
26.2
27.3
80
14.7
15.9
17.0
18.2
19.4
20.6
21.4
23.1
24.5
25.8
85
10.4
11.9
13.4
14.9
16.5
18.0
19.5
21.1
22.7
24.3
90
6.8
8.3
9.8
11.3
12.9
14.4
15.9
18.2
20.4
22.7
95
6.3
7.8
9.2
10.7
12.2
15.2
18.4
21.2
100
5.1
6.4
7.7
8.9
10.2
12.7
15.1
17.6
105
5.0
6.1
7.2
8.2
10.1
12.0
13.9
110
5.4
6.3
7.6
8.9
10.3
115
5.1
5.9
6.6
75
30.8
29.6
28.3
2.1
25.9
25.0
24.2
20.0
15.8
11.6
7.4
Unitary Products Group
13
128552-YIM-A-0605
',6&+$5*(35(6685(
:%
:%
:%
:%
287'225'5<%8/%7(03(5$785(
FIGURE 4: D1EM060 DISCHARGE PRESSURE/TEMPERATURE (UTILIZES A THERMAL EXPANSION VALVE)
68&7,2135(6685(#&)0
7"
7"
7"
7"
287'225'5<%8/%7(03(5$785(
FIGURE 5: D1EM060 SUCTION PRESSURE/TEMPERATURE (UTILIZES A THERMAL EXPANSION VALVE)
68&7,2135(6685(#&)0
:%
:%
:%
:%
287'225'5<%8/%7(03(5$785(
FIGURE 6: D1EM060 SUCTION PRESSURE/TEMPERATURE (UTILIZES A THERMAL EXPANSION VALVE)
14
Unitary Products Group
128552-YIM-A-0605
+,*+92/7$*(&211
',$.12&.287
)5217
&2035(6625
6(59,&($&&(66
&203$570(17 3$1(/
+,*+92/7$*(&211
',$.12&.287
/2:92/7$*(&211
³',$.12&.287
³$´
81,7 6,=(
29(5$//
6,'(6833/<
$,523(1,1*
',0(16,21
³$´
5()5,*(5$17
&211(&7,216
6,'(5(7851
$,523(1,1*
(/(&75,&$/),/7(5
6(59,&($&&(66
&203$570(17 3$1(/
+,*+92/7$*(&211
',$.12&.287
29(5$//
29(5$//
/2:92/7$*(&211
³',$.12&.287
81,7 &21'(16$7(
&211(&7,21 ³137,
75$3 5(48,5('
)5217
$OOGLPHQVLRQVDUHLQLQFKHV7KH\DUH
VXEMHFWWRFKDQJHZLWKRXWQRWLFH&HUWLILHG
GLPHQVLRQVZLOOEHSURYLGHGXSRQUHTXHVW
+,*+92/7$*(
³[ ',$
&211
.12&.287
6,'(6833/<
$,523(1,1*
%$&.
&21'(16(5
&2,/
6,'(5(7851
$,523(1,1*
&21'(16$7(
'5$,1 ³137,
%277206833/<
$,523(1,1*
&/($5$1&(6
0LQLPXP
)URQW
%DFN
/HIW6LGH)LOWHU$FFHVV 5LJKW6LGH
%HORZ8QLW )RU&RQGHQVHU
$ERYH8QLW $LU'LVFKDUJH
8QLWVPD\EHLQVWDOOHGRQFRPEXVWLEOHIORRUVPDGHIURPZRRGRUFODVV$
%RU&URRIFRYHULQJPDWHULDO
8QLWVPXVWEHLQVWDOOHGRXWGRRUV2YHUKDQJLQJVWUXFWXUHVRUVKUXEV
VKRXOGQRWREVWUXFWRXWGRRUDLUGLVFKDUJHRXWOHW
%277205(7851
$,523(1,1*
FIGURE 7: DIMENSIONS AND CLEARANCES
Unitary Products Group
15
128552-YIM-A-0605
SEQUENCE OF OPERATION FOR DEH
MODELS
SEQUENCE OF OPERATION FOR DEM
MODELS
COOLING
COOLING
WITH POWER TO UNIT AND THERMOSTAT IN COOLING
MODE.
The following sequences of operation are based on using a
standard single-stage cooling thermostat.
1.
2.
3.
If the fan switch on the thermostat is in the “ON” position,
the 24 volts at “G” will energize the “K1" relay on the fan
control board, close the ”K1" relay contacts, and energize
the indoor blower motor. If the fan switch is in the “AUTO”
position, the blower will operate only when there is a call
for cooling by the thermostat.
On a call for cooling, the thermostat will send 24 volts to “Y”
on the fan control board. The 24 volt signal will energize
contactor “M1", and power will be supplied to the
compressor and outdoor fan motor. If the fan switch on the
thermostat is on the ”AUTO" position, the thermostat will
also send a 24 volt signal to “G” on the fan control board
and the indoor blower will operate as indicated in step 1.
When the demand for cooling has been satisfied, the “M1"
contactor will be de-energized when the 24 volt ”Y" signal
is removed. If the fan switch on the thermostat is energized
when the 24 volt “Y” signal is removed. If the fan switch on
the thermostat is in the “ON” position, the indoor blower will
continue to run. If the fan switch is in the “AUTO” position,
the 24 volt “G” signal will be removed, and after a 60
second delay, the “K1" relay will open and de-energize the
indoor blower motor.
HEATING
WITH POWER TO UNIT AND THERMOSTAT IN HEATING
MODE.
1.
If the fan switch on the thermostat is in the “ON” position,
the 24 volts at “G” will energize the “K1" relay contacts, and
energize the indoor blower motor. If the fan switch on the
thermostat is in the ”AUTO" position, the blower will
operate only when there is a call for heating by the
thermostat.
2.
On a call for heating, the thermostat will send 24 volts to
“W1" on the fan control board. The 24 volts signal will
energize relay ”K2" on the fan control board, and the first
stage of electric heat will be energized.
3.
When the heating demand is satisfied, the electric heat will
be de-energized when the 24 volt “W1" and ”W2" signals
are removed. If the fan switch on the thermostat is in the
“ON” position, the indoor blower will continue to run. If the
fan switch is in the “AUTO” position, the “K1" relay will
open and de-energize the indoor blower motor after the
appropriate time delay.
Please refer to Table 14 and 15 for more information.
WITH POWER TO UNIT AND THERMOSTAT IN COOLING
MODE.
1.
If the fan switch on the thermostat is in the “ON” position,
the 24 volts at “G” will be sent to the ECM indoor motor and
the blower will operate at the programmed airflow. If the fan
switch is in the “AUTO” position, the blower will operate at
the programmed airflow only when there is a call for
cooling by the thermostat.
2.
On a call for cooling, the thermostat will send 24 volts to “Y”
on the fan control board. The 24 volt signal will energize
contactor “M1", and power will be supplied to the
compressor and outdoor fan motor. If the fan switch on the
thermostat is on the ”AUTO" position, the thermostat will
also send a 24 volt signal to “G” on the fan control board
and the indoor blower will operate as indicated in step 1.
3.
When the demand for cooling has been satisfied, the “M1"
contactor will be de-energized when the 24 volt ”Y" signal
is removed. If the fan switch on the thermostat is in the
“ON” position, the indoor blower will continue to run. If the
fan switch is in the “AUTO” position, the 24 volt “G” signal
will be removed, and after a 30 second delay, the indoor
blower motor will shut down.
HEATING
WITH POWER TO UNIT AND THERMOSTAT IN HEATING
MODE.
1.
If the fan switch on the thermostat is in the “ON” position,
the 24 volts at “G” will be sent to the ECM indoor motor and
the blower will operate at the programmed airflow. If the fan
switch is in the “AUTO” position, the blower will operate at
the programmed airflow only when there is a call for
heating by the thermostat.
2.
On a call for heating, the thermostat will send 24 volts to
“W1" on the fan control board. The 24 volts signal will
energize relay ”K2" on the fan control board, and the first
stage of electric heat will be energized. The indoor blower
will operate as indicated in step 1.
3.
On units with 2 (two) stages of electric heat, the second
bank of heaters will be energized by a 24 volt signal to “W2"
on the fan control board. After a 20 second delay, the third
bank of heaters will be energized if the unit is so equipped.
4.
When the heating demand is satisfied, the electric heat will
be de-energized when the 24 volt “W1" and ”W2" signals
are removed. If the fan switch on the thermostat is in the
“ON” position, the indoor blower will continue to run. If the
fan switch is in the “AUTO” position, the indoor motor will
shut off after the appropriate time delay.
Please refer to Table 14 and 15 for more information.
16
Unitary Products Group
128552-YIM-A-0605
TABLE 17: THERMOSTAT SIGNALS (SINGLE PHASE UNITS)
SIGNAL STATE
“G”
ON
SIGNAL STATE
BOARD FUNCTION
OFF FAN INSTANT OFF
ON
“G”
“y”
BOARD FUNCTION
FAN INSTANT ON
FAN INSTANT ON
COMPRESSOR AND OUTDOOR FAN INSTANT ON
COMPRESSOR AND OUTDOOR FAN INSTANT OFF
ON
“W1”
OFF FAN 60 SECOND DELAY OFF ON DEH MODELS
FAN INSTANT ON
HEATER BANK 1 (HTR 1) INSTANT ON
HEATER BANK 1 (HTR 1) INSTANT OFF
OFF FAN 10 SECOND DELAY OFF
FAN 30 SECOND DELAY OFF ON DEM MODELS
FAN INSTANT ON
HEATER BANK 1 (HTR 1) INSTANT ON
HEATER BANK 2 (HTR 2 & HTR 3) 10 SEC. DELAY ON
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1) INSTANT ON
OFF
HEATER BANK 1 (HTR 1) INSTANT OFF
FAN 10 SECOND DELAY OFF
OFF HEATER BANK 1 (HTR 1) ½ SEC. DELAY OFF
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1) INSTANT ON
HEATER BANK 2 (HTR 2 & HTR 3) 10 SEC. DELAY ON
HEATER BANK 3 (HTR 4 & HTR 5) 20 SEC. DELAY ON
ON
“G”
“W1"
ON
“W2"
“G”
“W1"
”W2”
HEATER BANK 3 (HTR 4 & HTR 5) INSTANT OFF
HEATER BANK 2 (HTR 2 & HTR 3) ½ SEC. DELAY ON
HEATER BANK 2 (HTR 2 & HTR 3) INSTANT OFF
FAN 10 SECOND DELAY OFF
“G”
“W1"
”W2”
FAN INSTANT ON
HEATER BANK 1 (HTR 1) INSTANT ON
HEATER BANK 2 (HTR 2 & HTR 3) 10 SEC. DELAY ON
HEATER BANK 3 (HTR 4 & HTR 5) 20 SEC. DELAY ON
HEATER BANK 3 (HTR 4 & HTR 5) INSTANT OFF
HEATER BANK 2 (HTR 2 & HTR 3) ½ SEC. DELAY ON
OFF HEATER BANK 1 (HTR 1) 1 SECOND DELAY ON
FAN 10 SECOND DELAY OFF
OFF HEATER BANK 1 (HTR 1) 1 SECOND DELAY ON
FAN 10 SECOND DELAY OFF
TABLE 18: THERMOSTAT SIGNALS (THREE PHASE UNITS)
SIGNAL STATE
“G”
“G”
“y”
FAN INSTANT ON
OFF
FAN INSTANT OFF
ON
FAN INSTANT ON
COMPRESSOR AND OUTDOOR FAN INSTANT ON
OFF
COMPRESSOR AND OUTDOOR FAN INSTANT OFF
FAN 60 SECOND DELAY OFF ON DEH MODELS
FAN 30 SECOND DELAY OFF ON DEM MODELS
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT ON
SIGNAL STATE
BOARD FUNCTION
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT ON
OFF
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT OFF
FAN 10 SECOND DELAY OFF
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT ON
HEATER BANK 2 (HTR 4, 5 & 6) 10 SEC. DELAY ON
OFF
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT OFF
FAN 10 SECOND DELAY OFF
OFF
HEATER BANK 2 (HTR 4, 5 & 6) INSTANT OFF
HEATER BANK 1 (HTR 1, 2 & 3) ½ SEC. DELAY OFF
FAN 10 SECOND DELAY OFF
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT ON
HEATER BANK 2 (HTR 4, 5 & 6) 10 SEC. DELAY ON
ON
FAN INSTANT ON
HEATER BANK 1 (HTR 1, 2 & 3) INSTANT ON
HEATER BANK 2 (HTR 4, 5 & 6) 10 SEC. DELAY ON
“G”
“W1"
“G”
“W1"
”W2”
BOARD FUNCTION
ON
“W1”
“W2"
OFF
HEATER BANK 2 (HTR 4, 5 & 6) ½ SEC. DELAY OFF
HEATER BANK 1 (HTR 1, 2 & 3) 1 SECOND DELAY OFF
FAN 10 SECOND DELAY OFF
Unitary Products Group
“W1"
”W2”
OFF
HEATER BANK 2 (HTR 4, 5 & 6) ½ SEC. DELAY ON
HEATER BANK 1 (HTR 1, 2 & 3) 1 SECOND DELAY ON
FAN 10 SECOND DELAY OFF
17
128552-YIM-A-0605
MAINTENANCE
NORMAL MAINTENANCE
Exercise care when cleaning the coil so that the coil fins
are not damaged.
Prior to any of the following maintenance procedures,
shut off all power to the unit, to avoid personal injury.
Do not permit the hot condenser air discharge to be
obstructed by overhanging structures or shrubs.
TROUBLESHOOTING
Periodic maintenance consists of changing or cleaning filters
and general cleaning of the outdoor coil.
FILTERS - Inspect once a month. Replace Disposable or clean
Permanent Type as necessary. DO NOT replace Permanent
Type with Disposable.
MOTORS - Indoor and outdoor fan motors are permanently
lubricated and require no maintenance.
OUTDOOR COIL - Dirt should not be allowed to accumulate on
the outdoor coil surface or other parts in the air circuit. Cleaning
should be as often as necessary to keep the coil clean. Use a
brush, vacuum cleaner attachment, or other suitable means. If
water is used to clean the coil, be sure that the power to the unit
is shut off prior to cleaning.
Troubleshooting of components necessarily requires
opening the electrical control box with the power
connected to the unit. Use extreme care when working
with live circuits! Check the unit nameplate for the
correct line voltage and set the volt meter to the correct
range before making any connections with line terminal
The wire number or color and terminal designations
referred to may vary. Check the wiring label inside the
control box access panel for the correct wiring.
If the variable speed motor found in the DPH048 and DPH060
models operates erratically, check the fan control board for the
presence of a c break-off tab. Remove tab if present.
18
Unitary Products Group
128552-YIM-A-0605
Notes for wiring diagrams on pages 19 thru 25.
Legend for wiring diagrams on pages 19 thru 25.
-F9
-6
(N O T U S E D )
-
2 -M 3
, 2 3 0 V C O IL
- -
Unitary Products Group
- -
19
128552-YIM-A-0605
OPTIONAL CCH
S / P CONFIGURATION
CCH
BLK
SEE
DETAIL
"A"
L1
BLK
T1
D / P CONFIGURATION
CCH
BLK
BLK
L1
L2
M1 - 2
T2
L2
DETAIL "A"
15695BASH0301
FIGURE 8: TYPICAL WIRING DIAGRAM (208/230-1-60 POWER SUPPLY) DEH MODELS
20
Unitary Products Group
128552-YIM-A-0605
SEE
DETAIL
"A"
15556BBSH0301
FIGURE 9: TYPICAL WIRING DIAGRAM (208/230-1-60 POWER SUPPLY) DEM MODELS
Unitary Products Group
21
128552-YIM-A-0605
FIGURE 10:TYPICAL WIRING DIAGRAM (208/230-3-60 POWER SUPPLY) DEM MODELS
22
Unitary Products Group
128552-YIM-A-0605
FIGURE 11:TYPICAL WIRING DIAGRAM (208/230-3-60 POWER SUPPLY) DEM MODELS
Unitary Products Group
23
128552-YIM-A-0605
FIGURE 12:TYPICAL WIRING DIAGRAM (460-3-60 and 575-3-60 POWER SUPPLY) DEH MODELS
24
Unitary Products Group
128552-YIM-A-0605
FIGURE 13:TYPICAL WIRING DIAGRAM (460-3-60 POWER SUPPLY) DEM MODELS
Unitary Products Group
25
128552-YIM-A-0605
26
Unitary Products Group
128552-YIM-A-0605
Unitary Products Group
27
Subject to change without notice. Printed in U.S.A.
Copyright © 2005 by Unitary Products Group. All rights reserved.
Unitary
Products
Group
128552-YIM-A-0605
Supersedes: 66266-YIM-B-1004
5005
York
Drive
Norman
OK
73069
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
