209 West Grant Street
PO Box 149
Onarga, IL 60955
(815) 268-4303
877-331-5161
Fax (815) 268-4313
www.procommproducts.com
Citizen Band Performance Antennas…………………….………………………….….2
Citizen Band No Ground Antennas…………………………………………………... 3
Citizen Band Base Load Antennas…………………….………………………………4-5
Citizen Band Top Load Fiberglass Antennas…………………………………………...6
Citizen Band Fiberglass Antenna Kits………………………………………………….7
Citizen Band Base Station Antenna…………………………………………………… 8
Citizen Band CB Glass Mount/AM FM Antenna Kits…………………………………9
Mobile TV Antennas…………………………………………………………………..10
Mobile TV Accessories………………………………………………………………...11
Scanner Antennas and Kits…………………………………………………………….12
Antenna Mounts and Cable Adapters…………………………………………………..13
Aluminum Mounts/Stainless Steel Mounts ……………………………………….....14-15
Antenna/Radio Mount Accessories…………………………………….………………16
Radio Accessories/Connectors…………………………………………….…………...17
Cable Assemblies…………………………………………………………….…………18
Bulk Coax……………………………….……………………………………………...19
Amateur Antennas……………………………………………………..……………20-21
Amateur Antenna Kits……………………………………………………………….....21
Microphones and Speakers……………………………………………………….…….22
Cellular Dual Band Antennas………………………………………………….….…….23
Cellular Glass Mount Antennas………………………………………………….….…..24
Cellular Glass Mount Accessories……………………………………………..………...25
Cellular Magnet Mount Antennas………………………………………………..……...26
Cellular Surface Mount Antennas………………………………………………..……...27
Cellular Window Clip Antennas……………………………………………………..….28
Cellular Mount Accessories…………………………………………………….……… 28
Connectors…………………………………………………………………….…….29-30
Citizen
Band
Hi-Power Performance Antenna
• 10,000 Watt Rated
Open Coil Performance Antenna
• 5000 Watt Rated
• 3” Outside Diameter Coil
• Lightweight Aircraft Aluminum
• Lightweight Aircraft Aluminum
• Durable Oversize Stainless Steel Whip– 48” .200 Diameter
• Ultra Broad Band Performance
• Durable Oversize Stainless Steel Whip
• 36” .125 Outside Diameter Stainless Steel Whip
• Ultra Broad Band Performance
• Field Tunable
• Field Tunable
• 5’6” Total Height
• Available in Polished Aluminum and Multiple Colors
Model No.
• 48” Total Height
• Available in Black (BK) and Polished Aluminum
Finish
MM490—Polished Aluminum
BK490—Black
BL490—Blue
PU490—Purple
RD490—Florescent Red
Model No.
CH58—Polished Aluminum
CH58BK—Black Anodized
Replacement Parts
MM490WT– 48” Tapered Whip
MM490WS– Screws for Whip Ferrule
Replacement Parts
RW-CH58- Whip
WS-CH58- Screws
• 10,000 Watt Power Handling Capability
• Ultra Broad Bandwidth 10 & 11 Meter Frequency
• Heavy Duty Double Coil Design for Demanding Applications
• 36” 17-7 Quality Stainless Steel Whip
• Available in Chrome or Black Chrome Finish
• Total Height 66”
Model No.
T215—Chrome
T215B— Black
2
Citizen
Band
CB- No Ground
Fiberglass Antenna Kit
•
•
•
•
•
•
•
5/16” Fiberglass Tunable Tip Antenna
Stainless Steel Mirror Mount for Durability and Long Life
Patented Chrome Dome Cable Connection
17’ High Quality Low Loss RG58 Coax with Molded PL259 Connector
500 Watt Rated
Kits Available with 3’ or 4’ Antenna Length
Available in Black (BK), White (W), or Red (R)
Model No.
CB-NG3—3’ Kits
CB-NG4—4’ Kits
*Made in the USA*
CB - No Ground
Window Clip Antenna Kit
•
•
•
•
•
24” Mini Base Load Antenna
Aluminum Window Clip Mount
Patented Chrome Dome Connector
17’ High Quality Belden Coax Cable
Available in Black or White
Model No.
CB-NGWC17
*Made in the USA*
CB - No Ground
Fiberglass Antenna
•
•
•
•
•
•
1/2 Wave Voltage Fed Antenna, No Ground Required
Will Work on Fiberglass Vehicles, Boats, RV’s and Even Motorcycles
10-11 Meter Range, Overall Length 48”
Slide Tuning for Low SWR and Sideband Use
3/8”x24 Thread Mounting
SO239 Connector
Model No.
G23—3’
G24—4’
*Made in the USA*
3
Citizen
Band
Kits Available:
Base Load Tunable CB Antenna
Magnet Mount
• Innovative Tunable Base Load CB
• 3” Heavy Duty Chrome
Plated Magnet Mount
• Patented Chrome Dome
Termination
• 12’ RG58 Cable with
PL259’s
• Impulse Antenna
Model No
IMP3000M
IMP4000M
Antenna
• Field Tunable for Lowest SWR
• Rated 350 Watts
• 17-7 Stainless Steel Whip
• Fits Standard 3/8-24 Mounts
• Factory Tested and Tuned
Model No
IMP3000 - 30”
IMP4000 - 40”
*Made in the USA*
30
40
Magnet Mount
• Base Loaded Antenna Pre-Tuned for 27
MHz
• Unique High Performance Design for a
Low SWR
• Field Tunable, No Cutting - Adjust Rings
24
48
Base Loaded 1/4 Wave Antenna
• 5/16” Diameter Fiberglass Base with 16 Gauge
Copper Wire
• 17-7 .100 Diameter Stainless Steel Whip
• Adjustable Stainless Steel Whip can be Raised
or Lowered for Superior SWR
• Chrome Plated 3/8-24 Threaded Base
• Available in Black or White
36
Model No
JBC1300—36”
JBC1400—48”
JBC1500—60”
• 3” Heavy Duty Chrome
Plated Magnet Mount
• Patented Chrome Dome
Termination
• Kwik Tune Antenna
• 15 RG58 Cable with PL259’s
Model No
JBC112-08
JBC112-24
JBC112-36
JBC112-48
Model No
JBC800– 8”
JBC2400—24”
JBC3600—36”
JBC4800—48”
36
Truck Lip Mount
• Heavy Duty Truck Lip Mount
• Kwik Tune Antenna
• Chrome Plated 3/8-24 Threaded Base
60 48
Model No
IMP3000MM
IMP4000MM
• 12’ RG58 Cable with
PL259’s
for Superior Performance
4
• Heavy Duty 3-Way Mirror
Mount w/ SO239 Connector
• 12’ RG58 Cable with
PL259’s
• Impulse Antenna
Kits Available:
Base Load Tunable CB Antenna
8”
Mirror Mount
Model No
JBC105-8
JBC105-24
JBC105-36
JBC105-48
Base Load Half-N-Half Antenna
• 3500 Watt Rated
• Base Loaded Quarter Wave Antenna
• Massive 1/2” Fiberglass Base with High Power 14
•
•
•
•
•
Gauge Copper Wire
17-7 1/8” Diameter Stainless Steel Whip
Oversized Chrome Plated Ferrules
3/8— 24 Stainless Steel Mounting Screw
Tunable for Optimum SWR
Available in Black Only
Model No
MBL-3B– 36”
MBL-4B– 48”
Citizen
Band
Magnet Mount Antenna
Heavy Duty CB Magnet Mounts
• 36” Base Loaded Antenna
• Powerful 3” Magnet with Protective
Base
• Unique Design: Base Load May Be
Removed from Magnet
• 17’ Pre-Wired RG58 Cable to PL259
Connector
• JBC103S Includes Heavy Duty
Spring
• Rated 75 Watts
•
•
•
•
•
9” Super Flexible CB Antenna
Powerful 3” Magnet with Protective Base
10’ Low Loss RG58 Cable w/PL259 Connector
Weatherproof Encapsulated Connections
Rated 25 Watts
Model No.
Model No.
JBC103 - 36”
JBC103S - with Shock Spring
JBC101
Replacement Whips
103
103S
CB-Low Profile Magnet Mount
• 15” Low Profile Fiberglass
CB Antenna
• Base Tunable
• Powerful 3” Magnet
• 12’ High Quality RG58 Cable with
PL259 Connector
• 75 Watt Rated
Sleeve
Tuning
Model No.
CB270
*Made in the USA*
Heavy Duty Rubber Duck Antenna
•
•
•
•
•
Virtually Unbreakable Conductive Rubber
CB Antenna
Flexible and Tough; Great for High
Stress Areas
14 1/2” Total Height
Easy Tuning with Base Tuning Ring Design
Standard 3/8” x 24 Ferrule
Ring
Tuning
Model No.
150
Antenna Only
150M Kit Includes 3” Heavy Duty Chrome Dome
Magnet Mount, 12’ RG58AU Coax and Molded
PL259 Connector
5
Citizen
Band
5/16” Composite Wound Fiberglass Whips
300 Watt Rated
•
•
•
•
•
Internal Helically Wound Fiberglass Antenna
Contains Linear Load 22 Ga. Wire
5/16” Fiberglass with 3/8”x24 Ferrule
3’ or 4’
Black or White Finish
Model No
FR3 - 36”
FR4 - 48”
*Made in the USA*
1/4” Flexi-Whips
500 Watt Rated
• Top Loaded 1/4 Wave Helically Wound Antenna
• 22 Gauge Copper Wire
• Factory Tuned - Field Adjustable
• Available in Black (B), White (W), Red (R), Black/Gold (BG),
White Gold (WG)
Model No
JBCF200— 24”
JBCF300 - 36”
JBCF400 - 48”
*Made in the USA*
5/16” Solid Fiberglass CB
Antenna with Weather Trap
• Top Loaded 1/4 Wave Helically
Wound Antenna
• 16 Gauge Copper Wire
• 1000 Watt Rated
• Factory Tuned - Field Adjustable
• Available in Black, White, Red,
Black/Gold, White Gold
Model No
JBCW200 - 24”
JBCW300 - 36”
JBCW400-48”
*Made in the USA*
6
5/16” Fiberglass Whips
750 Watt Rated
• Top Loaded 1/4 Wave Helically Wound Antenna
• 20 Gauge Copper Wire
• Factory Tuned - Field Adjustable
• Available in Black (B), White (W), Red (R), Black/Gold (BG),
White Gold (WG) or Red, White and Blue
Model No
JBC200 - 24”
JBC300 - 36”
JBC400 - 48”
301RWB-Red. White & Blue 36”
401RWB-Red, White & Blue 48”
*Made in the USA*
3/8” Fiberglass Whips
1000 Watt Rated
• Top Loaded 1/4 Wave Helically Wound Antenna
• Heavy Duty 3/8” Diameter Solid Fiberglass
• 18 Gauge Copper Wire
• Factory Tuned - Field Adjustable
• Available in Black (B), White (W), Red (R), Black/Gold (BG),
White Gold (WG)
Model No
JBC200-1 - 24”
JBC300-1 - 36”
JBC400-1 - 48”
*Made in the USA*
1/4” Flexible Fiberglass CB
Antenna with Weather Trap
• Flexes Nearly 360˚
• Top Loaded 1/4 Wave Helically
Wound
• 22 Gauge Copper Wire
• 500 Watt Rated
• Available in Black, White, Red,
Model No
JBCFW300 - 36”
JBCFW400 - 48”
*Made in the USA
5/16” Fiberglass Whips
750 Watt Rated
•
•
•
•
•
• Top Loaded 1/4 Wave Helically Wound Antenna with
Tunable Tip
• 20 Gauge Copper Wound Wire
• .100 dia. 17-7 Stainless Steel Tunable Tip
• Factory Tuned - Field Adjustable
• Available in Black (B), or White (W),
• Available in 3’ or 4’ only
Model No
WT300-36’
WT400-48”
*Made in the USA*
3/8” Fiberglass Whips
1000 Watt Rated
Citizen
Band
Top Loaded 1/4 Wave Helically Wound Antenna
Heavy Duty 3/8” Diameter Solid Fiberglass
18 Gauge Copper Wire
Factory Tuned - Field Adjustable
Available in Black (B), or White (W)
Model No
T200-1 - 24”
T300-1 - 36”
T400-1 - 48”
T500-1 - 60”
*Made in the USA*
Kits Available:
Standard
Standard
Standard
• 3-Way Aluminum Mirror Mount with
Heavy Duty Chrome Plated SO-239
• 9’ Low Loss RG-58 or RG-59 Coax with
Molded PL2589 Connectors– Soldered
Connection
Model No
Singles
Duals
HSS995-FR3
HSD995-FR3
HSS995-FR4
HSD995-FR4
• 3-Way Aluminum Mirror Mount with
Heavy Duty Chrome Plated SO-239
• 9’ Low Loss RG-58 or RG-59 Coax with
Molded PL2589 Connectors– Soldered
Connection
Model No
Singles
Duals
HSS995-F2
HSD995-F2
HSS995-F3
HSD995-F3
HSS995-F4
HSD995-F4
• 3-Way Aluminum Mirror Mount with
Heavy Duty Chrome Plated SO-239
• 9’ Low Loss RG-58 or RG-59 Coax with
Molded PL2589 Connectors– Soldered
Connection
Model No
Singles
Duals
HSS995-2
HSD995-2
HSS995-3
HSD995-3
HSS995-4
HSD995-4
Terminator Series
Terminator Series
• Patented Terminator Stud Connector
• 3-Way Deluxe Aluminum Mirror Mount
• 18’ Low Loss RG58 or RG59 Coax and
Molded PL259 with Teflon Dielectric
Model No
Singles
Duals
TS991-FR3
TD991-FR3
TS991-FR4
TD991-FR4
• Patented Terminator Stud Connector
• 3-Way Deluxe Aluminum Mirror Mount
• 18’ Low Loss RG58 or RG59 Coax and
Molded PL259 with Teflon Dielectric
Model No
Singles
Duals
TS991-F2
TD991-F2
TS991-F3
TD991-F3
TS991-F4
TD991-F4
FME Series
FME Series
• 3-Way Aluminum Mirror Mount with Heavy
Duty FME Stud
• 9’ Low Loss RG58 or RG59 Coax with
Slimline Nipple Connector to Molded
UHF Connector
Model No
Singles
Duals
TS996-FR3
TD996-FR3
TS996-FR4
TD996-FR4
• 3-Way Aluminum Mirror Mount with Heavy
Duty FME Stud
• 9’ Low Loss RG58 or RG59 Coax with
Slimline Nipple Connector to Molded
UHF Connector
Model No
Singles
Duals
TS996-F2
TD996-F2
TS996-F3
TD996-F3
TS996-F4
TD996-F4
Terminator Series
• Patented Terminator Stud Connector
• 3-Way Deluxe Aluminum Mirror Mount
• 18’ Low Loss RG58 or RG59 Coax and
Molded PL259 with Teflon Dielectric
Model No
Singles
Duals
TS991-2
TD991-2
TS991-3
TD991-3
TS991-4
TD991-4
FME Series
• 3-Way Aluminum Mirror Mount with
Heavy Duty FME Stud
• 9’ Low Loss RG58 or RG59 Coax with
Slimline Nipple Connector to Molded
UHF Connector
Model No
Singles
Duals
TS996-2
TD996-2
TS996-3
TD996-3
TS996-4
TD996-4
*Add (B) for Black, (W) for White, (BG) for Black/Gold
(WG) for White/Gold and ( R) for Red*
7
Citizen
Band
CB Base Station Antenna
•
Now With Tuning Rings!!
•
Two –Section Omni Directional 1/2 Wave CB Base Station
Threaded Tuning
2000 Watt P.E.P
10—12 Meter
Rugged Fiberglass Construction with Chrome Plated Ferrules
Single Coil Circuit for Optimum Tuning and Reliability
Includes Mounting Hardware
Extremely Easy to Install and Operate
UPS Shippable; 12 per case
•
•
•
•
•
•
•
•
Model No.
PAT-12
*Made In The USA*
•
•
•
•
Improves Performance by 30%
Installs at the Base of the PAT-12
Includes 4 -6 Foot Long Fiberglass Radials with Aluminum
Mounting Hub
UPS Shippable; 12 per case
Model No.
PAT-12GPK
*Made In The USA*
8
Citizen
Band
• Quality Stainless Steel Rod
• Length: 24”-52”
• Diameter: .100 or .125
All Stingers Come with Coronas
.125 Diam.
.100 Diam.
30SS-T-30”
36/125SS-T-36”
32SS-T -32”
48/125SS-T-48”
40SS-T-40”
42SS-T –42”
48SS-T-48”
52SS-T-52”
Custom Lengths Available
Chrome Plated Brass Bases
Model No
CB52– Base for .100 Rod
CB55– Base for .125 Rod
• 102” 17-7 Stainless Steel Element
• Chrome Plated 3/8-24 Threaded Base
Model No
JBC1020-Whip w/Heavy Duty Double Set Screw
Removable Ferrule
JBC1020C-Whip w/Permanent Pressed on Base
and Weather Seal O-Ring
*Made In The USA*
Replacement Parts
102SS-T-Whip w/Tip only
B102-Removable Base Ferrule w/Double Set
Screws
High Performance On-Glass CB Antenna
• New Tuning Collar makes tuning easier than
•
•
•
•
ever!
Optimized Removable 1/2 Wave Fiberglass Whip
Easy Installation
16’ RG58U Low Loss Cable with Soldered PL259
50 Watt Rated
Model No
VCBGM
*Made in the USA*
• 22” Collinear Antenna
• Center Load Encapsulated in Flexible Plas-
tic
• Easy Installation
• Freq: 25—30 MHz
• Low SWR (2.0 or Less) 15’ RG58U Coax
with PL-259 Connector
Model No
CBGM
Replacement Parts Available
VCB-MF Mast and Foot
RMT-KT Remount Kit
AM/FM Horizontal Mirror
Mount Kit
AM/FM Mirror Mount Kit
• 21” AM/FM On-Glass Antenna Kit
• 30” Stainless Steel Antenna
• 30” Stainless Steel Antenna
• 17-7 Stainless Steel Coil Antenna
• Horizontal Mirror Mount with
• Heavy Duty Slimline Mirror
AM/FM On-Glass Antenna Kit
• 15” Coax Cable with Motorola
Plug
• 9’ RG58AU Coaxial Cable with
Model No
PC-GMFM
Mount with Chrome Plated
SO239
Chrome Plated S0239
Molded PL-259 to Motorola
Plug
• 9’ RG58AU Coaxial Cable with
Model No
JBC332-FM
Molded PL-259 to Motorola
Plug
Model No
JBC362H-FM
SSFM– 30” Replacement 17-7 Stainless Steel Antenna
108MM-PL– 9’ RG58 Coax Cable; PL-259 to Motorola Plug
9
UHF/
VHF
Mobile TV Antenna
Patented
• Omni-Directional
• Long Range Reception
Shown With
Optional CB
Antenna
• Delivers the Best Performance of any Antenna in its Class
• Available in Mirror Mount or Magnet/Surface Mount
• Available in White or Black
• Can be Painted to Match Vehicle Finish
• 3/8—24 Threaded Antenna Port Built In so another Antenna can be Added
• Kit Includes 12’ RG59 Low Loss Cable, Mounting Hardware (including S0239 for optional
Antenna Hook-up), and Easy Instructions
Mirror Mount
Built-In 3/8—
24 Antenna
Port
Magnet Mount
Model No:
117—Mirror Mount
117M—Magnet/Surface Mount
117A—Mirror Mount with Amplifier
117AM—Magnet/Surface Mount with Amplifier
Please place a B or W after Desired part Number to Specify Black or White
Clear Plastic Clamshell Packaging.
Can Be Hung on a Wall Set or Free
Standing Base for Showcase or Counter
Display
•
•
•
•
•
3-16” Length 1/4” Diameter Fiberglass Radiating Elements
Omni-Directional Performance
Heavy Duty Aluminum Antenna Mounting Nut
9’ Low Loss RG59 Coax-100% Shielded Coax– F-Connector Termination
Available in Black [B], White [W], or Red [R]
Model No:
3D-M – Heavy Duty 5” Magnet Mount
3D-MM – 3-Way Deluxe Aluminum Mirror Mount (shown)
3D-WC – Window Clip
*Made in the USA*
10
UHF/
VHF
• 2-16” Length 1/4” Diameter Fiberglass Elements
• Heavy Duty Aluminum Antenna Mounting Nut
• 9’ Low Loss RG59 Coax-100% Shielded Coax– F-
Connector Termination
• Available in Black [B], White [W]. or Red [R]
Model No
JBCTV-1– Mirror Mount
JBCTV-1M Magnet Mount
JBCTV-1WC– Window Clip
*Made in the USA*
Mobile TV Antenna
Amplifier
• 15 dB Gain; 50-900 MHz
• For UHF/VHF/FM
Model No
TV-A15
VHF-UHF Splitter
• 1-75 OHM Input; 2-300
Ohm Output
Model No
TV-SP75
Standard Splitter
• 75-3000 OHM
Model No
SPLITTER
Quality RG59U “F”
Connector Cable Assemblies
Model No
• ProComm’s Exclusive Encapsulated VHF Loading Coil/
•
•
•
•
UHF Trap
Unique Black ABS Molded Circuit for TV Reception and
75 OHM Impedance
12’ Belden 75 OHM Low Loss RG59 Cable
F Connector
Black Powder Coated Stainless Steel 14” Long Elements
Model No
MTV2-M– Magnet Mount
MTV2-MM- Mirror Mount
MTV2-WC– Window Clip
*Made in the USA*
803F-3’
806F-6’
812F-12’
825F-25’
850F-50’
8100F-100’
16”- 1/4” Dia.
Replacement Fiberglass TV
Antenna Elements
Model No
TV-RWB– Black
TV-RWW-White
TV-RWR-Red
9’ RG59 Cable
PL-to-F Connector
Model No
HS9PL-F
Replacement Hub with SO239 Connector
Model No
TV-HUB– Rabbit Ear 2 Element Kit
3D-HUB– 3DTV 3 Element Kit
11
Scanner
30-1200 MHz
• 30-1200 MHz
• Ideal for ALL Band Scanners:
•
•
•
•
•
•
Low Band, High Band, and UHF Frequencies
Easy to Assemble and Install
High Quality Stainless Steel and Chrome Plated Components
Mounts on 1 1/4-2” Mast Pipe
Antenna Connection: SO-239
Available with 50’ or 75’ of Low Loss Coax Cable
Available with your Choice of High Quality Connectors
Replacement Cable For Spider Antennas
Motorola Plug
BNC Connector
HS825M– 25’
HS825BN-25’
HS850M– 50’
HS850BN-50’
HS875M– 75’
HS875BN-75’
HS8100M– 100’
HS8100BN-100’
Model No
SP-800– Spider Antenna Only
SP-800/50– Antenna with 50’ Cable
SP-800/75– Antenna with 75’ Cable
*Made in the USA*
18” Fiberglass Scanner Antenna
• Fits all Standard 3/8 x 24 Mounts
• 25-960 MHz
Model No
JBC380
18” Stainless Steel Scanner Antenna
• Fits all Standard 3/8 x 24 Mounts
• 25-960 MHz
Model No
JBC180
Kits Available:
3” Magnet Mount
•
•
•
•
•
• 3” Chrome Plated Magnet w/Chrome Dome
Termination
Multiband Receiving Antenna
• 12’ RG58 95% Shielded Coax
• Available with BNC (/BN) or Motorola Plug (/
Cellular Look Styling
22” 17-7 Stainless Steel Whip
Covers Full Frequency Range: 30-1200 MHz
Includes 15’ Belden RG58/U 95% Coax with Transmission Coupler Box
• Available with your Choice of Connectors: Motorola Plug
(/M) or BNC (/BN)
Model No
PC-SGM/M– With Motorola Plug
PC-SGM/BN-With BNC Connector
*Made in the USA*
Glass Mount Replacement Parts
SGM-RM- Replacement Antenna Mast Only
SGM-RMF-Replacement Antenna Mast and Foot
RMT-KT - Remount Kit includes Double Side Tape and Alcohol
Cleaning Pad
M)
Model No
JBC380M3– Fiberglass Antenna Kit
JBC180M3– Stainless Steel Antenna Kit
3-Way Mirror Mount
• Heavy Duty Aluminum Mount
• 9’ RG58 95% Shielded Coax
• Available with BNC (/BN) or Motorola Plug (/M)
Model No
JBC380MM– Fiberglass Antenna Kit
JBC180MM– Stainless Steel Antenna Kit
Aluminum Fender Mount
• 9’ RG58 95% Shielded Coax
• Available with BNC (/BN) or Motorola Plug
(/M)
• Wide Banded Scanner Antenna– Freq: 25MHz to 1.2GHz
• 18” Black powder Coated Stainless Steel Element
• ProComm Exclusive Hermetically Sealed, Waterproof,
Molded Circuit
• 12’ Belden RG174 Low Loss Cable
• Available with your Choice of Connectors:
Model No
JBC290M– Magnet Mount
JBC290MM– Mirror Mount
JBC290WC– Window Clip
*Made in the USA*
12
Model No
JBC380FM– Fiberglass Antenna Kit
JBC180FM– Stainless Steel Antenna Kit
Trunk Lip Mount
• 9’ RG58 95% Shielded Coax
• Available with BNC (/BN) or Motorola
Plug (/M)
Model No
JBC380TL– Fiberglass Antenna Kit
JBC180TL– Stainless Steel Antenna Kit
12’ RG58PL-Motorola Plug
144MMPL
Weatherproof Trunk lip Mount
• For Standard 3/8-24 Antennas
• RG58AU Coax
• Molded PL259 Connectors
Model No
JBC105
JBC105-1 –No Coax
5” Heavy Duty Magnet Mount
•
•
•
•
Chrome Plated Housing
Standard 3/8—24 Mounting
18’ RG58AU 95% Braided Coax
Molded PL259 Connectors
Model No
Super Heavy Duty Trunk Mount
JBC115
• For LARGE Antennas
• 18’ Coax and PL259 Connector
Model No
JBC105S/H
3” Heavy Duty Magnet Mount
•
•
•
•
Chrome Plated Housing
Standard 3/8—24 Mounting
RG58AU 95% Braided Coax
Molded PL259 Connectors
Model No
JBC110-12— 12’ RG58AU Coax
JBC110-18— 18’ RG58AU Coax
JBC110B– 12– Black; 12’ RG58AU Coax
JBC110B– 18- Black; 18’ RG58AU Coax
• Heavy Duty Aluminum Fender Mount
• Heavy Duty Chrome Plated Double Hex Nut
• Uses ProComm’s Patented Weatherproof
Terminator Connector
• High Quality RG58 Cable with Nipple Connector
• NIP-UHF Adapter Included
• Accepts Standard 3/8 x 24 Antennas
Model No
JBC472C- 18’ Cable
Low-Profile Heavy Duty
Surface Mount Kit
• Heavy Duty Roof or Flat Surface Mount
• Dual O-Ring Waterproof Design
• Uses ProComm’s Patented Terminator
Connector
• High Quality RG58 Cable with Nipple Connector
• NIP-UHF Adapter Included
• Accepts Standard 3/8 x 24 Antennas
Model No
TSM-18– 18’ Cable
12SMMPL
• PL259 to Terminator Stud Mount
12MFPL
12BNSO
• 18’ Lengths Only
Model No
HS818T-N Singles RG58
HSDH818T-N– Duals RG59
• 12” RG58 Cable
• Male Motorola to Male PL259
• Ideal for Prewired Trucks
• 12” RG58 Cable
• Female Motorola to Male PL259
• Ideal for Prewired Trucks
Terminator Series Replacement Parts
• Replacement Cable for Terminator Antenna
Citizen
Band
12DMFPL
DHN-38— Chrome Plated Double Hex Nuts
NYS-38– Nylon Step Washers
STR– 38– Aluminum Star Washers
12MFBN
• 12” RG58 Cable
• BNC to SO239 Connector
• To be used with External CB Antenna to
Handheld CB Radio
• 12” RG59 Cable
• Two Female Motorola to Male PL259
• Hooks Up to Dual Prewired Trucks
• 12” RG58 AU Connector
• Motorola Female to BNC Connector
• Allows Existing Motorola-type Antenna System
To be converted to Handheld Scanners using
BNC Hook-up
13
Citizen
Band
Heavy Duty
Stud
Connector
JBC900
JBC901 with Lug
Standard
Non-Corrosive
Brass SO239
JBC910
Heavy-Duty
Non-Corrosive
Chrome-Plated
Brass SO239
JBC910H
Heavy Duty
FME Stud
JBC920
Extra Heavy-Duty
SO239 for BIG
Antenna Systems
JBC930
1 1/8” Omni Grip
Mirror Mount
Slimline Mirror Mount
JBC535 with HD SO239
JBC530 with Stud
JBC531 Mount Only
JBC362 with HD SO239
JBC363 with Stud
JBC365 with FME Stud
JBC361 Mount Only
1 1/4” Omni Grip
Mirror Mount
JBC545 with HD SO239
JBC540 with Stud
JBC541 Mount Only
Heavy Duty Slimline Mirror Mount
Deluxe 3-Way Mirror Mount
JBC362H with HD SO239
JBC363H with Stud
JBC365H with FME Stud
JBC361H Mount Only
JBC995 with HD SO239
JBC990 with Stud
JBC996 with FME Stud
JBC991 Mount Only
Extra Heavy Duty 3-Way Mirror
Mount for BIG Antenna Systems
Heavy Duty Double Groove
Mirror Mount
JBC935 Double Groove Mount
with SO239
JBC935H Heavy Duty Double
Groove Mount with SO239
JBC995H with HD SO239
JBC990H with Stud
JBC996H with FME Stud
JBC991H Mount Only
Heavy Duty
Aluminum 3-Way
Mirror Mount with Top
Beehive Mount
Heavy Duty Bumper Mount
JBC482 with HD SO239
JBC483 with Stud
JBC485 with FME Stud
JBC481 Mount Only
SO-239 for PL-PL
Connections
Add SS for Stainless Steel
JBC993
360 ˚ Adjustable Bar Mirror Mount
JBC592 with HD SO239
JBC593 with Stud
JBC595 with FME Stud
JBC591 Mount Only
Heavy Duty Stainless
Steel Stud
Connector
JBC900SS
Super Heavy Duty
Oversized All Stainless
Steel SO239
Heavy Duty Deluxe 3 Way
Mirror Mount
JBC991SS
JBC995SS-with HD SO239
Includes Allen Wrench
JBC930SS
Stainless Steel Trailer Hitch Mount
14
SSTH20– Mount Only
SSTH21-with Stud
SSTH25– Heavy Duty SO239
SSTH35– Extra Heavy Duty SO239
Stainless Steel Truck/
Fender Mount
SFM
Citizen
Band
180 ˚ Adjustable Bar Mirror Mount
JBC492 with HD SO239
JBC493 with Stud
JBC495 with FME Stud
JBC491 Mount Only
6” Standard Flat Bar Mount
JBC436 with HD SO239
JBC437 with Stud
JBC435 Mount Only
6” Horizontal Mirror Mount
JBC332 with HD SO239
JBC333 with Stud
JBC335 with FME Stud
JBC331 Mount Only
45˚ Mirror Mounts for Gooseneck Mirrors
JBC462 with HD SO239
JBC463 with Stud
JBC465 with FME Stud
JBC461 Mount Only
Quick Release Hinge Mount
JBC830 with HD SO239
JBC831 with Stud
JBC833 Mount Only
Ford Flat Bar Mount
JBC338 with HD SO239
JBC337 with Stud
JBC336 Mount Only
Dual Antenna Aluminum Mirror Mount
JBC440 with 2 HD SO239’s
JBC441 with 2 Stud’s
JBC443 Mount Only
4” Horizontal Mirror Mount
JBC332S with HD SO239
JBC333S with Stud
JBC335S with FME Stud
JBC331S Mount Only
3” Short Heavy Duty Horizontal
Mirror Mount
JBC332SH with HD SO239
JBC333SH with Stud
JBC335SH with FME Stud
JBC331SH Mount Only
Quick Release Vise Grip Mount
Heavy Duty Gutter Mount
Standard Fender Mount
JBC955 with HD SO239
JBC950 with Stud
JBC951 Mount Only
JBC802 with HD SO239
JBC803 with Stud
JBC801 Mount Only
JBC472 with HD SO239
JBC473 with Stud
JBC471 Mount Only
Heavy Duty Ball Mount with 3
1/2” Black Mounting Plate and
Barrel Spring
JBC986
Heavy Duty Ball Mount with
3 1/2 Black Mounting Plate
JBC985-3 with Lug Connector
JBC985-3P with UHF Connector
Deluxe Two-Sided Mirror
Mount
JBC1095 with 2 –HD SO239’s
JBC1090 with 2 - Studs
JBC1096 with 2 - FME Studs
JBC1091 Mount Only
Patented
Chrome Dome Surface Mount
Heavy Duty Surface Mount
Lug Termination
Heavy Duty Surface Mount with
SO239 and Star Locking Washer
SM-CD59/8X
SM-CD58K
JBC504
JBC989
15
Citizen
Band
• Eliminates the need for Mating
SO239/PL-259 Connectors
• All Soldered Connections
• Eliminates Mechanical Losses
• Moisture and Corrosion Resistant Design
• Unlimited power Handling
• Field Serviceable
• Industry Standard 3/8” x 24 Thread Hookup
Heavy Duty Stainless
Steel 5” Spring
Add H for Double Groove
Add 8X for Low Loss Mini 8
MW498
Heavy Duty Barrel
Spring
2 1/2” Medium Duty
Spring
Heavy Duty Quick Disconnect
with Chrome Plated Brass Body
Stainless Steel Spring & Pin
180˚ Antenna Swivel
JBC403
6” Stainless Steel Mounting
Bar For Volvo Trucks
SSR50
JBC305
JBC305SS for Stainless
JBC303
JBC201L
Universal Radio Hump
Mount
JBC1000
JBC2700
16
Model No.
MW498-75– (Connector Only) for RG58
MW498-76- (Connector Only) for RG59/RG8X
Medium Duty Stainless
Steel 4” Spring
JBC404
CB Slide Mounting
Bracket Suitable for
Most CB Radios
Stud Mount
Patented
Standard Adjustable Radio
Bracket
2” - 9 ½”
JBC1200
Adjustable Quick Release
Radio Bracket
2” - 9 ½”
JBC1250
JBC100
Large Adjustable Radio
Bracket
4” - 13” Wide Body Radios
JBC1200L
• 2 Pin Molded Plug
• 20 GA CB Power Cord with 2 Amp. Fuse
JBCPC-2
• 2 Pin Molded Plug
• 20 GA Power Cord with 2 Amp. Fuse &
Cigarette Lighter Plug
JBCPC-2P
• 3 Pin Molded Plug
• 20 GA Power Cord with 2 Amp. Fuse
JBCPC-3
• 3 Pin Molded Plug
• 20 GA Power Cord with 2 Amp. Fuse &
Cigarette Lighter Plug
JBCPC-3P
• 3 Pin Molded Plug
• 16 GA Heavy Duty Power Cord with 3
Amp. Fuse
JBCPC-3H
• 3 Pin Molded Plug
• 16 GA Heavy Duty Power Cord with 3
Amp. Fuse & Cig. Lighter Plug
JBCPC-3PH
Citizen
Band
3 Piece Male Cigarette Lighter Plug with
Spring Loaded 3 Amp Fuse, Single Ground
Tab & Molded Rubber Strain Relief
MCP
180˚ 5 Pin Din Mic Connector with
Locking Quick Release
JBC-C5X
Fully Molded Cig. Lighter Male-2 Female “Y”
Adapter
CPO1-2CSF
Fully Molded Cig. Lighter Male-3 Female “Y”
Adapter
CPO1-3CSF
Magnetic Mic Holder
JBCMH1
Ultra-Classic Amphenol
PL-259A
Kalibur PL259 Connector
KPL259 Bakelite Dielectric
KPL259T Teflon Dielectric
KPLS259 Silver/Teflon Dielec-
Female UHF T Adapter
PL-1714
BNC Male UHF Female
BNC-44
JBC-C4—Female 4 Pin Screw On
Mic Connector
JBC-C5—Female 5 Pin Screw On
Mic Connector
2 Piece Female Cigarette Lighter
Receptacle with Molded Rubber
Strain Reliefs
FCR
Hook-N-Loop Adhesive
VEL-26—2”x6” Strip
VEL-14—1”x4” Strip
4MM Plastic Radio Replacement Knobs
JBC4KNP
5MM Plastic Replacement Knobs
JBC5KNP
6MM Plastic Replacement Knobs
JBC6KNP
3 Finger Mic Holder
JBCMH2
Male UHF Crimp for RG-58
PL-259C-58
Male UHF Crimp for RG-59
PL-259C-59
Male UHF Crimp for RG-8X
PL259C-8X
Adhesive Plastic Mic Holder
JBCMH3
Glow In The Dark Holder
JBCMH3G
4MM All Brass Radio Replacement Knobs
JBC4KN
5MM All Brass Replacement Knobs
JBC5KN
6MM All Brass Replacement Knobs
JBC6KN
Plastic Buddy Hook
JBCMH4
Glow in the Dark
JBCMH4G
Metal Buddy Hook
JBCMH5
PL-259 Reducer for RG-58
Field Install PL-259 for RG8U
UG-175
Installs with Pocket Knife
PL-259 Reducer for RG-59/RG-8X
and Pliers
UG-176
58FCP
3” UHF Double Female Bulkhead
UG-363
UHF Male-Female T Adapter
PL-1713
BNC Male Motorola Female
BNC-26
FME-58 Screw on Nipple for RG-58
FME-59 Screw on Nipple for RG-59
FME-8X Screw on Nipple for RG-8X
Cig. Lighter Male-2 Female Adapter
JBCMCP-2F
Cig. Lighter Male-3 Female Adapter
JBCMCP-3F
UHF Double Female Adapter
PL-258
Male Motorola Plug
MP-2
UHF Double Male
PL-260
BNC Male Crimp Connector
BNC-10- For RG58
UHF Female Nipple Adapter
FME-02
Nipple-Male BNC
NIP-11
Female UHF Crimp for RG-58
PL-259FC-58
Female UHF Crimp for RG-59
PL-259FC-59
Right Angle Male UHF-Female UHF
UG-644
Encapsulating Weather Boot for PL-259
SR-29B
Slimline Nipple Connector
NIP-58– For RG58
NIP-8X– For Mini 8
Nipple-Male UHF
NIP-13
17
Citizen
Band
•
Belden Cable
•
Amphenol and Kalibur Connectors Available
•
All Hand Soldered Connec-
•
100 % Tested
*Made In The USA*
•
•
•
•
•
MINI 8
Bare Copper Stranded
Conductor
Foam Dielectric
95% Bare Copper
Braid Available in
Gray, Black or Clear
Plug to Plug or Plug to
Lug; Add L for Lug
Lengths Available at
Right
1-8X……...12”
1.5-8X…..18”
3-8X……...3’
6-8X……...6’
9-8X……...9’
12-8X…….12’
18-8X…….18’
20-8X…..20’
21-8X…….21’
25-8X…...25’
50-8X…..50’
75-8X…...75’
•
•
•
•
•
•
Super Mini 8 with
Teflon dielectric PL259’s !
Tinned Copper Stranded
Conductor
Foam Dielectric
96% Tinned Copper Braid
Available in Clear Jacket Only
Plug to Plug or Plug to Lug;
Add L for Lug
Lengths Available at Right
3-S8XC…...3’
6-S8XC…..6’
9-S8XC…..9’
12-S8XC….12’
18-S8XC….18’
20-S8XC..20’
21-S8XC……..21’
25-S8XC…...25’
50-S8XC…..50’
75-S8XC…...75’
100-S8XC..100’
Super Dual Mini 8 with
Teflon dielectric PL259’s !
• True 75 OHM Impedance
• Tinned Copper Stranded
•
•
•
•
Conductor
Cellular Foam Polyethylene
Dielectric
96% Tinned Copper Braid
Available in Clear Jacket Only
Lengths Available at Right
Plug– Plug
SD8X9…….9’
SD8X12…..12’
SD8X18….18’
SD8X21….21’
Plug-Lug
SD8X9L…...9’
SD8X12L…...12’
SD8X18L…..18’
SD8X21L…...21’
100-8X…….100’
•
•
•
•
•
•
RG58
Bare Copper Stranded
Center Conductor
Polyethylene Dielectric
95% Bare Copper
Braid
Available in Black
Jacket Only
Plug to Plug or Plug to
Lug; Add L for Lug
Lengths Available at
Right
RG58
• Stranded Coax
• Molded Plug-Plug
PL259’s or Plug to
Lug; add L for Lug
• Lengths at Right
18
803PL…...3’
806PL.…..6’
809PL.…..9’
812PL...….12’
818PL..….18’
821PL......21’
825PL…..25’
850PL….50’
875PL….75’
8100PL...100’
809L…….9
812L……..12’
818L…….18’
821L…….21’
HS803PL……..3’
HS806PL……..6’
HS809PL……..9’
HS812PL……...12’
HS818PL……..18’
HS809L……….9’
HS812L……….12’
HS818L……...18’
HS821L……...21’
•
•
•
•
•
•
RG59
Bare Copper Stranded Conductor
Foam Polyethylene Dielectric
95% Bare Copper Braid
Available in Black Jacket Only
Plug to Plug or Plug to Lug
Lengths Available at Right
RG59
• Dual Coax
• Molded Plug-Plug
PL259’s or Plug to Lug;
add L for Lug
• Lengths at Right
PL-PL
DH9P...…..9’
DH12P...….12’
DH18P...….18’
DH21P.......21’
PL-Lug
DH9L..…….9’
DH12L……..12’
DH18L…….18’
DH21L…….21’
HSDH9P……...9’
HSDH12P…….12’
HSDH18P…….18’’
HSDH9L……...9’
HSDH12L…….12’
HSDH18L…...18’
•
•
•
•
•
•
Low Loss RG8U
Bare Copper Stranded
Conductor
Foam Dielectric
95% Bare Copper Braid
Available in Black, or
White
Plug to Plug
Lengths Available at
Right
RG8X
• Mini 8 Coax
• Molded Plug-Plug
PL259’s or Plug to
Lug; add L for Lug
• Lengths at Right
1RG8U……..12”
1.5RG8U…..18”
3RG8U….….3’
6RG8U….....6’
9RG8U……..9’
12RG8U…...12’
18RG8U…...18’
20RG8U....20’
21RG8U…...21’
25RG8U…..25’
50RG8U…..50’
75RG8U…..75’
100RG8U...100’
HS3-8X……3’
HS6-8X…...6’
HS9-8X…...9’
HS12-8X…...12’
HS18-8X…..18’
HS9-8XL…...9’
HS12-8XL…..12.’
HS18-8XL…..18’
Citizen
Band
Ground-Enhancing Low Loss Mini Cable Assemblies
• Unique Double Braid Cable For Maximum Shielding
• Aluminum Magnesium Alloy Exposed Exterior Ground Enhancing Braid To Ensure
Optimum SWR and Improved Operation
• Ultra High Quality Super Mini 8 Low Loss Cable For the Best Performance
• 98% Tinned Copper Braid and Tinned Copper Conductor
• All Soldered Kalibur Bakelite PL-259 Connectors
Singles
Duals
AF3-3 Foot
AF9– 9 Foot
AF12– 12 Foot
AF18- 18 Foot
AF9D– 9 Foot
AF12D-12 Foot
AF18D– 18 Foot
500 ft. Spools Standard
Special Lengths & Volume Purchases Available
*Made in the USA*
•
•
•
•
•
•
•
•
•
•
•
•
RG58U95
RG58AU95
(Black Jacket)
(Black Jacket)
20 Ga. Solid Bare Copper
Solid Polyethylene— .116
Bare Copper Braid— 95%
50 OHM Impedance
RG58U-500
RG58U-1000
•
•
•
•
20 Ga. (19x33) Stranded Bare Copper
Solid Polyethylene— .116
Bare Copper Braid— 95%
50 OHM Impedance
RG58AU-500
RG58AU-1000
RG174
RG59AU95
RG8UB
(Black Jacket)
(Black Jacket)
(Black Jacket)
26 Ga. (7x34) Stranded Bare Copper
Solid Polyethylene— .060
Tinned Copper Braid— 95%
50 OHM Impedance
RG174-1000
• 20 Ga. (19x33) Stranded
Bare Copper
• Solid Polyethylene— .116
• Bare Copper Braid— 95%
• 75 OHM Impedance
RG59AU-500
RG59AU-1000
• 13 Ga. (7x21) Stranded Bare
Copper
• Solid Polyethylene— .146
• Bare Copper Braid— 95%
• 50 OHM Impedance
RG8UB-500
RG8X Mini 8
(Grey (G), Clear, ( C ), or Black (B) Jacket)
•
•
•
•
16 Ga. (19x28) Stranded Bare Copper
Cellular Foam Polyethylene— .155
Bare Copper Braid— 95%
50 OHM Impedance
RG8X-500
RG8X-1000
RG8UW
S8XC Super Mini 8
RG213
SD8XC Super Dual Mini 8
(White Jacket)
(Clear Jacket)
(Black Jacket)
(Clear Jacket)
• 13 Ga. (7x21) Stranded Bare
Copper
• Solid Polyethylene— .285
• Bare Copper Braid—95%
• 50 OHM Impedance
RG213-500
• 20 Ga. (19x28) Stranded Tinned
Copper
• Cellular Foam Polyethylene— .155
• Tinned Copper Braid—96%.
• True 75 OHM Impedance
SD8XC-500
13 Ga. (7x21) Stranded Bare Copper • 16 Ga. (19x28) Stranded Tinned
Copper
Cellular Foam Polyethylene— .285
•
Cellular Foam Polyethylene— .155
Bare Copper Braid— 95%
•
Tinned Copper Braid—96%
50 OHM Impedance
• 50 OHM Impedance
RG8UW-500
S8XC-500
S8XC-1000
SD8XC-1000
19
Amateur
PC Series
5/8 Wave 3db Gain VHF Antenna
•
•
•
•
•
•
•
•
•
Bottom Section: 3/8” Fiberglass with 18 GA. Wire
Top Section: .125” 17-7 Stainless Steel (Adjustable)
Power Rated at 500 Watts P.E.P
Bottom Ferrule is Standard 3/8” x 24 Thread
Available in Black (B), White (W), Red ( R ) or Clear
(WG)
Model No.
Band
Bandwidth
PCF6
PCF10
PCF12
PCF15
PCF17
PCF20
PCF30
PCF40
PCF75
6 Meters
10 Meters
12 Meters
15 Meters
17 Meters
20 Meters
30 Meters
40 Meters
75 Meters
1000 KHz
550 KHz
300 KHz
210 KHz
175 KHz
150 KHz
100 KHz
75 KHz
40 KHz
5/16” Dia. Fiberglass Base
16 Ga. Copper Wire
17-7 Stainless Steel Whip
350 Watt Rated
Model No
PC144— 144-149 MHz
PC150— 150-160 MHz
PC220— 220-225 MHz
* Made in the USA*
SS-FM20
Stainless Steel Antenna
• 20” 17-7 Stainless Steel VHF Quarterwave Antenna
• 3/8” x 24 Thread Ferrule
Model No
SS-FM20
CD144M
2 Meter Magnet Mount Antenna Kit
• SS-FM20 Stainless Steel Antenna
• 3” Chrome Magnet Mount
• 12’ RG58 Cable with PL259 or BNC Connector
Model No
CD144M
Add /BN for BNC Connector
• First of Its Kind Shortened HF Antennas
• Bottom Section– 3/8’ Fiberglass with 20 ga. Wire
• Top Section– .100 17-7 Stainless Steel Tip
(Adjustable)
• Power Rating 350 Watts
Model No.
CS6
CS10
CS12
CS15
CS17
CS20
CS30
CS40
CS75
Band
Bandwidth
6 Meters
10 Meters
12 Meters
15 Meters
17 Meters
20 Meters
30 Meters
40 Meters
75 Meters
800 KHz
175 KHz
140 KHz
110 KHz
95 KHz
80 KHz
100 KHz
40 KHz
36 KHz
PC144M
Combo Kit
•
•
•
•
Includes 2 Antenna Systems for Optimum
Performance and Flexibility
1 SS-FM20 Stainless Steel Antenna
1— PC144 5/8 Wave Fiberglass Base Antenna
3” Chrome Dome Magnet Mount
12’ Low Loss Cable with PL259 or BNC Connector
Model No
PC144M
20
Amateur
•
•
•
•
•
•
•
Durable 17-7 .100 Dia Stainless Steel Element
Long Lasting Black Powder Coating
Black ABS Plastic Housing
NMO Style Mounting
Moisture Seal Internal O ring
Stainless Steel Contact Spring
Soldered Gold Contact Plate
VHF Frequency:
118-225 MHz
Model No.
PCQ1 (Field Tunable)
PCV136
PCV144
PCV152
PCV162
PCV220
Freq.
118-960
136-144
144-152
152-162
162-174
220-225
UHF Frequency:
118-806 Mhz
Model No.
PCQ1 (Field Tunable)
PCU406
PCU420
PCU435
PCU450
PCU470
PCU490
PCU800
Freq.
118-960
406-420
420-435
435-450
450-470
470-490
490-512
800-806
Includes Cable and PL259 Connector
NMO 3-Way Mirror Mount
CTMM/PL
NMO Surface Mount
MSM/PL
NMO Low Profile Fender
Mount
SFM/PL
NMO High Profile Fender Mount
CFM/PL
Dual Band Magnet Mount Kits
•
•
•
•
•
•
Mast Components: .100” 17-7 Stainless Steel
All Brass Phase Shifting Components
Hermetically Sealed
14 Ga. Steel Magnet Cup 2 3/8” dia.
Black Powder Coated
Includes Cable and PL259 Connector
Model No,
144/440 MHz 2 Meter– 70cm
PC144-440
150-158 / 461-470 MHz Business Bands
PC150-461
Add /BN to Model No. for BNC Connector
*Made In The USA*
• 2 Meter, 70 cm Magnet Kit
• 144-148 and 440-450 MHz
• 1— 1/8” Dia. Black ABS Base with Rare Earth Magnet;
Black Stainless Steel Whip
• Includes 12’ RG174 Cable with BNC Connector
• Max Power: 50 Watts (2M)
25 Watts (70cm)
Model No.
MT144-440
Ultra Heavy Duty Triple Magnet Mount
• 3— 5” Magnets on Heavy Aluminum Frame for Super
Stability!
• 3/8” - 24 Thread Dome Stud
• 18’ RG58 Low Loss Cable with PL259 Connector
Model No.
PCTM5
As Above Except with NMO Antenna Mount
PCTM5NMO
3”NMO Magnet Mount
CMAG/PL
NMO Trunk Mount
TLM/PL
Ultra Heavy Duty Quadruple Magnet
• 4— 5” Magnets on Heavy Aluminum Frame for Super
Stability!
• 3/8” - 24 Thread Dome Stud
• 18’ RG58 Low Loss Cable with PL259 Connector
Model No.
PCTM54
As Above Except with NMO Antenna Mount
PCTM54NMO
21
• High Sensitivity Microphone Cartridge
• Ergonomic Hand Contour Design
• Blue LED Operation Indicator
• Textured ABS Plastic Housing and Thumb Lever
• Contoured Black Mesh Microphone Grill
• 9’ Heavy Duty Mil Spec Microphone Cord with Strain Relief
• High Quality Chrome Plated 4 or 5 Pin Microphone Connector
• Hand Assembled and Tested
Model No.
PSM4— 4 Pin Dynamic
PSM4NC— 4 Pin Noise Canceling Mic
PSM4PM— 4 Pin Power
• 4” - 8 OHM 10 Watt External
Speaker
• 10’ Cord
• 3.55MM Plug
• Swivel Mounting Base
JBCSP-1
•
•
•
•
•
4” - 8 OHM 10 Watt External Speaker
P.A. Talk Back & Noise Canceling
10’ Cord
3.55MM Plug
Swivel Mounting Base
PSM5– 5 Pin Dynamic
PSM5NC-5 Pin Noise Canceling
PSM5PM— 5 Pin Power Mic
•
•
•
•
•
4” - 8 OHM 10 Watt External Speaker
Noise Canceling
10’ Cord
3.55MM Plug
Swivel Mounting Base
JBCSP-2
•
•
•
•
JBCSP-4
JBCSP-3
• 2 1/4”- 8 OHM 5 Watt Weatherproof External
Speaker
• 6’ Cord
• 3.55MM Plug
• Swivel Mounting Bracket
JBCSP-5
• Attractive Wedge Style External Speaker
• Weatherproof 8 OHM Impedance
• Complete with Mounting Hardware
JBCSP-8
2 1/4”- 8 OHM 5 Watt External Speaker
6’ Cord
3.55MM Plug
Includes Sun Visor Clip and Dashboard Mount
Bracket
• 8 OHM Surface Mount External Speaker
• Only 1 1/2” Diameter!
• Housing Rotates 360˚ for optimum
Performance
• Complete with Mounting Hardware
JBCSP-6
•
•
•
•
5” Marine Style
White Enamel Weatherproof
Indoor/Outdoor
15 Watt Rating
JBCPA-5W
Improves the dynamic range of CB or Amateur Radio! Amplifies the signal and reduces the noise!
The NOISE CLIPPER………….
Because don't you already have
enough static in your life!!!!!!!!!
.
22
JBCNR400
Cellular
•
•
•
•
•
Dual Band— 800 and 1900 MHz Cellular Digital and Analog Phones
Durable ABS Molded Dual Phase Shift PCS/Cellular Whip
Low Profile Coupler Box for Glass Mount
Magnet Mount and Window Clip uses ProComm’s Mini RG174 Low Loss Coaxial Cable
To Specify Connector Type Add to Model No- /TN for TNC, /LTN for Loose TNC,
/MU for Mini UHF, /LMU for Loose Mini UHF, /NIP for Slimline Nipple, /EZ for
EZ Kit
Operating Frequencies:
Cellular 829-896 MHz. 5dB Gain
PCS 1700-1900 MHz 3dB Gain
Model No
DB35GM– Glass Mount Cellular Antenna Kit
DB35M– Magnet Mount Cellular Antenna Kit
DB35WC– Window Clip Cellular Antenna Kit
DB35SM– Surface Mount Cellular Antenna Kit
ANT-DB35– Surface Mount Antenna Only
*Made In The USA*
Replacement Parts
RM-DB35GM– Replacement Mast for Glass Mount
RM-DB35M– Replacement Mast for Magnet Mount
RM-DB35A—Replacement Mast for Surface Mount
ANT-DB35
•
•
•
•
•
Dual Band— 800 and 1900 MHz Cellular Digital and Analog Phones
Advanced Printed Circuit Board Technology
Tuned Ground Plane Radials for Optimum Cellular Reception
12’ of High Spec Low Loss RG174 Cable with Nipple Connector for Superior
Cellular Performance
Fits Standard 3/8-24 Mounts
Operating Frequencies:
Cellular- 824-896 MHz.
PCS- 1700-1900 MHz
Model No
CT400– 24” Cellular Trucker Antenna
*Made In The USA*
23
Cellular
Frequency: 824-896 Mhz
•
•
•
•
•
•
High Quality Black Powder Coating for Long Lasting Finish
.100 Stainless Steel Elements for Durability
Superior SWR— <1.5:1
Euro-Style Design
Also Available for 896-960 MHz
7db Hi Performance
•
Every Kit Includes:
RG58 Stranded Conductor 96% Braid Cable
Your Choice of Connector:
Chrome TNC w/Molded Strain Relief
Slimline Nipple Connector
Chrome Mini UHF w/Molded Strain Relief
EZ Kit: Nipple Connector w/both TNC and MU
Adapters
5db
Whistle Free Antenna Kit
• 5 db Whistle Free Whip
with Base
• Antenna Coupler Box
• 15’ Belden Cable Assembly with Connectors
• Alcohol Cleaning Swab
PCGM-5
3db
Open Coil Antenna Kit
• 3 db Open Coil Whip with
Base
• Antenna Coupler Box
• 15’ Belden Cable Assembly with Connectors
• Alcohol Cleaning Swab
PCGM-3
•
•
•
•
•
•
•
Antenna Kit
7db Hi Performance
Whip with Base
Antenna Coupler Box
15’ Belden Cable Assembly with Connectors
Alcohol Cleaning Swab
PCGM-7
To Specify Connector Type:
Add To Model No:
/TN for TNC; /LTN for Loose TNC
/MU for Mini UHF; /LMU for Loose Mini UHF
/NIP for Slimline Nipple; /EZ for EZ Kit
3db Open Coil Antenna
Antenna Coupler Box
12’ Coax with Connectors
Alcohol Swab
GM-3
• 5db Closed Coil
Antenna
• Antenna Coupler Box
• 12’ Coax with Connectors
• Alcohol Swab
GM-5
*Made In The USA*
24
Cellular
All Brass NMO Mount
Glass Mount Replacement Mast
For All Styles of ProComm Series
Glass Mount Antennas
Model No
RM-14– Unity Gain
RM-3— 3db
RM-5— 5db
RM-7– 7db
• Gold Plated Contact
• Soldered Ground Lug
• Black Plastic Protective Cap
Model No
MOTO34– Standard Design
MOTO38– 3/8” Thick Plate Design
3 Way Aluminum Mirror Mount
Model No.
JBC991
Stainless Steel Truck/Fender Mount
Replacement Mast and Base
Model No.
SFM
For All Styles of ProComm Series
Glass Mount Antennas
Model No
RFM-14– Unity Gain
RFM-3— 3db
RFM-5— 5db
RFM-7– 7db
Base Only
Replacement Base For All Styles of
ProComm Series Glass Mount
Antennas
Model No
RF
*Made In The USA*
15’ Belden Low Loss
RG58 Stranded Conductor
96% Braid Cable
Your Choice of Connectors
TNC-Mini UHF Connectors
15’ TNC/MU
Mini UHF-Mini UHF Connectors
15’ MU/MU
Glass Mount Coupler Box
For All Styles of ProComm Series
Glass Mount Antennas
MU-Butt Cut Connectors
15’ MU
Model No
RCB
RCB-DB
Kit Contains Nipple Connector
with Both TNC & MU Adapters
15’ EZ
Adhesive Remount Kit
For All Styles of ProComm Series
Model No
RMT-KT
Call ProComm
for ALL your Custom Cable
Assembly Needs!
25
Cellular
•
•
•
•
•
•
•
•
•
Frequency:
Attaches to Inside Vehicle Window
Voltage Fed, Dual Band Cellular/PCS
ProComm’s Exclusive Low Loss RG174 Cable
Available with Right Angle Nokia, TNC or Nipple Connector
Slim Line Design for Easy Transportation
Only 5” Overall Height
Doubles the Signal Strength
Easy Release Suction Cups
Versatile Mounting on all Glass Surfaces
Cellular:
PCS:
824-896 MHz 1.7-1.99 GHz
Gain: 3dB
Impedance: 50 Ohm
Height: 5” Overall
Whip: 17-7 Stainless Steel
Cable: 8’ Low Loss RG174
Connector: Right Angle Nokia (NK),
TNC (/TN), Nipple (NIP), or MU (/MU)
Model No.
MB-SC2
*Made in the USA*
Available with Your Choice of Connectors:
TNC, MUHF, NIP, or NK
Model #: MB-SC2/TN, MU, NIP, or NK
•
•
•
•
•
Frequency:
25 Watts Power
Unity Gain
50 OHM Impedance
17-7 Stainless Steel Whip
With 10’ RG174U Cable
Cellular:
824-960 MHz
PCS:
1.7-1.99 GHz
*Made In The USA*
Available with Your Choice of Connectors:
TNC, MUHF, or NIP
Model #: MB-MM2/TN, MU, NIP, SMA, or SMB
Frequency: 824-896 Mhz
•
•
•
•
2 1/2” Mini Magnet Mount with No Scratch Protective Base
12’ Low Loss ProComm RG58/AU— 96% Coax
ProComm’s Exclusive Molded Weatherproof Base Circuit
Quality Factory Terminated Connectors
ECM-7
ECM-5
ECM-14
To Specify Connector Type:
Add After Model Number:
/TN for TNC; /MU For Mini UHF;
/NIP for Slimline Nipple; /EZ for EZ
Kit
26
Unity Gain
Antenna
ECM-3
3 db
Open
Coil
Antenna
5 db
Whistle
Free
Antenna
7 db
Hi
Performance
Antenna
Cellular
Frequency: 824-896 Mhz
•
•
•
•
•
Quality 17-7 .100 Diameter Stainless Steel Elements
Black Powder Coating Finish
All Soldered Terminations
NMO Style Mounting with Spring Contact
Corrosion Resistant— Brass Threaded Contact Pin
To Specify Connector Type:
Add After Model Number:
/TN for TNC; /MU For Mini UHF;
/NIP for Slimline Nipple; /EZ for EZ Kit
ANT-14
Freq: 824-896 MHz
VSWR: < 1:1.5
Height: 5”
CMAG Series
Deluxe Magnet Mount Kit
•
•
•
•
•
3” Low Profile Magnet Mount
All Brass NMO Mount w/Gold Contact Pin
15’ Low Loss Belden RG58/AU 96% Coax
No Scratch protective Base
Durable Black Finish
Model No
CMAG– Mount Only
CMAG-14— Unity Kit
CMAG-3— 3db Kit
CMAG-5– 5db Kit
CMAG-7– 7db Kit
CMAG-EF– 3db Elv. Kit
CFM Series
High Profile Fender Mount Kit
• Aluminum Fender Mount
• All Brass NMO Mount w/Gold Contact Pin
• 12’ Low Loss Belden RG58/AU 96% Coax
Model No
CFM– Mount Only
CFM-3— 3db Kit
CFM-5– 5db Kit
CFM-7– 7db Kit
CFM-EF– 3db Elv. Kit
ANT-3
CTMM Series
Mirror Mount Kit
• 3 Way Aluminum Mirror Mount
• All Brass NMO Mount w/Gold Contact Pin
• 12’ Low Loss Belden RG58/AU 96% Coax
Model No
CTMM- Mount Only
CTMM-3— 3db Kit
CTMM-5— 5db Kit
CTMM-7– 7db Kit
CTMM-EF– 3db Elv. Kit
SFM Series
Low Profile Fender Mount Kit
• Stainless Steel 90˚ Fender Mount
• All Brass NMO Mount w/Gold Contact Pin
• 12’ Low Loss Belden RG58/AU 96% Coax
Model No
SFM- Mount Only
SFM-3— 3db Kit
SFM-5— 5db Kit
SFM-7– 7db Kit
SFM-EF– 3db Elv. Kit
ANT-5
ANT-7
Freq: 824-896 MHz Freq: 824-896 MHz Freq: 824-896 MHz
VSWR: < 1:1.5
VSWR: < 1:1.5
VSWR: < 1:1.5
Height: 14”
Height: 14 3/4”
Height: 20 1/2”
EF-3
Freq: 824-896 MHz
VSWR: < 1:1.5
Height: 20 ”
TLM Series
Trunk Mount Kit
• Low Profile Trunk Mount
• All Brass NMO Mount w/Gold Contact Pin
• 18’ Low Loss Belden RG58/AU 96% Coax
Model No
TLM- Mount Only
TLM-3— 3db Kit
TLM-5— 5db Kit
TLM-7– 7db Kit
TLM-EF– 3db Elv. Kit
MSM Series
Surface Mount Kit
• All Brass NMO Surface Mount w/Gold Contact Pin
• Available w/15’ or 18’ Low Loss Belden
RG58/AU— 96% Coax
• Protective Plastic Cap
• Available for 3/8” Thick Plate Design (/38)
MSM-15 15’ Cable
MSM– Mount Only
MSM-14– Unity Kit
MSM-3— 3db Kit
MSM-5— 5db Kit
MSM-7– 7db Kit
MSM-EF- 3db Elv. Kit
MSM-18 18’ Cable
MSM/18-14– Unity Kit
MSM/18-3— 3db Kit
MSM/18-5— 5db Kit
MSM/18-7– 7db Kit
MSM/18-EF- 3db Elv. Kit
27
Cellular
Frequency: 824-896 Mhz
• Stainless Steel Elements with Black Powder
Coated Finish
• Soldered Antenna Terminations
• Black Anodized Aluminum Window Bracket
• Weatherproof Molded Circuit
• Soldered Circuit Terminations
• 12’ Low Loss RG174 Coax Cable
• Protective Vinyl Pad
*Made In The USA*
To Specify Connector Type:
Add To Model No:
/TN for TNC; /LTN for Loose TNC
/MU for Mini UHF; /LMU for Loose Mini UHF
/NIP for Slimline Nipple; /EZ for EZ Kit
•
•
•
•
•
•
•
PC-WC3
PC-WC5
PC-WC14
Frequency: 806-896 MHz
VSWR: < 1. 5 : 1
300 Watts Maximum Power
50 Ohms Input Impedance
Sturdy, Durable Aluminum
12’ Low Loss RG174 Coax Cable
Protective Vinyl Pad
Y850-4– 4 Element 9dB Gain
Y850-8– 8 Element 12dB Gain
For Black /B, For White /W
Double Female Y Cord Adapter
CPO1-2CSF
Triple Female Y Cord Adapter
CPO1-3CSF
2 Piece Female Cigarette
Lighter Receptacle
FCR
28
3 Piece Male Cigarette Lighter Plug
with 3 Amp Fuse
MCP
Flex Mounts
Supports Up to 7 lbs.
Complete w/all Hardware and Metal Plate
*Made In The USA*
5FM— 5”
7FM— 7”
9FM— 9”
11FM— 11”
13FM— 13”
15FM— 15”
23FM- 23”
27FM- 27”
TNC Female for NEC Cellular
Phones
Male UHF Female Crimp for
RG58
TNC-3
MPL-01
Mini UHF Female Crimp for RG59
MPL-01-59
TNC Male Crimp For Proflex
TNC-8
TNC Male Crimp For RG58
TNC-10
TNC Male Crimp For Belden 9913
TNC-9913C
Mini UHF Male Crimp for RG58
MPL-03IP
Mini UHF Male Crimp for RG58
(Black)
MPL-03B
Nipple– Mini UHF Female
NIP-5
Nipple-N Male
NIP-9
Nipple– Mini UHF Male
NIP-10
Nipple-Male BNC
NIP-11
TNC Female Bulkhead for RG58
TNC-11
Mini UHF Female Bulkhead
MPL-04
Nipple-Male TNC
NIP-12
TNC Female Crimp for RG58
TNC-15
Mini UHF Double Female
MPL-06
TNC Male Right Angle Crimp for
RG58
TNC-16
Nipple-Male UHF
NIP-13
Mini UHF Male-Mini UHF Female
Right Angle
MPL-08
TNC Double Female
TNC-33
Mini UHF Male-UHF Female
MPL-12
TNC Male-TNC Female Right Angle
TNC-35
Mini UHF Male-TNC Female
MPL-14
TNC “T” Connector
TNC-38
Rotatable Nipple for RG58
NIP-58
Rotatable Nipple for RG59
NIP-59
Rotatable Nipple for RG8X
NIP-8X
Rotatable Nipple For RG174
NIP-174
Mini UHF Female-UHF Male
MPL-16
TNC Male– UHF Female
TNC-45
Mini UHF Female-TNC Male
MPL-18
TNC Male– BNC Female
TNC-46
TNC Push-On Male Crimp for RG58
TNC-66
Push-On Male TNC Connector
TNC-77
Push-On Male Mini UHF Crimp for
RG58
MPL-66
Mini UHF Male Crimp for RG174
MPL-174
TNC Female Crimp for RG174
TNC-174F
TNC Male Crimp for RG174
TNC-174M
29
BNC Male Crimp for RG8X
N Male Clamp Style For RG8U
BNC-8X
BNC Male Crimp for RG58
BNC-10
BNC Male Crimp for RG59
BNC-59
N-01
N-Male Clamp Style for Belden
9913
N-01-9913
N-Male Crimp for Belden
N-01-9913C
BNC Male Crimp for RG174
BNC-174
BNC Female Bulkhead Chassis
BNC-11
BNC Female Crimp for RG58
BNC-15
BNC Male-Female Motorola
BNC-26
BNC Male-Female UHF
BNC-44
BNC Male– Female TNC
BNC-51
Small Strain Relief for RG58
SR-MU
30
N Female Clamp Style for RG8U
N-02
N Male Crimp for RG58
N-11
N Male Crimp for RG8X
N-112
N Male Crimp for RG213
N-01-9913C
SMA Crimp for RG58
SMA-19-58
SMA Male-TNC Female
SMA-31
SMA Male-Mini UHF Female
SMA-33
SMA Female-BNC Female
SMA-39
SMA Female-TNC Male
SMA-40
SMA Female-TNC Female
SMA-41
SMA Female-Mini UHF Male
SMA-42
SMA Female-Mini UHF Female
SMA-43
Large Strain Relief for RG58
SR-58L
BACK ORDERS
ProComm strives to ship all orders as soon as possible. Any back orders totaling less than $100.00 will
be cancelled. If back order is caused by vendor material shortage, the back order will be cancelled and
you will be notified.
DELIVERY
Our normal shipping time is within one week after we receive your order (holidays and weekends
excluded). Sometimes, however, material shortages or specially assembled or custom products can cause
unscheduled delays.
FREIGHT POLICY
All orders are shipped FOB Onarga, Illinois. Freight will be charged on all invoices. If order is $1500.00
or more and paid within terms, freight may be deducted.
RETURNS
No returns will be accepted without prior factory approval. Return items must be shipped to us
freight prepaid. All non-defective products will be returned to customer, or customer will be charged a
25% restocking fee.
PAYMENT TERMS
Credit terms– net 30 days from shipment date– are available to approved accounts. Call us to request a
credit application. We also accept Visa, MasterCard, American Express, or C.O.D.
PRICE CHANGES
Prices and specifications are subject to change without notice. ProComm reserves the right to correct typographical errors on all price sheets, sales flyers, and catalog sheets.
All prices are stated in United States currency.
MINIMUM ORDER
Orders will be accepted for minimum of $100.00 only.
DAMAGES
All merchandise leaves our plant in perfect condition. If damaged, claims should be filed by BUYER
against CARRIER within 10 days of invoice.
WARRANTY
All ProComm products are warranted against defective workmanship and material if failure results from
these factors with one (1) year of purchase. ProComm does not assume any liabilities for any incidental or
consequential damages of any kind, and our liability shall not exceed the original price of that product.
Warranty does not cover misuse or abuse of any product.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
