R&S®FSW-K40 Phase Noise User Manual (download version)

R&S®FSW-K40 Phase Noise User Manual (download version)
R&S®FSW-K40
Phase Noise Measurements
User Manual
(;×êä2)
User Manual
Test & Measurement
1173.9286.02 ─ 14
This manual applies to the following R&S®FSW models with firmware version 2.40 and higher:
●
R&S®FSW8 (1312.8000K08)
●
R&S®FSW13 (1312.8000K13)
●
R&S®FSW26 (1312.8000K26)
●
R&S®FSW43 (1312.8000K43)
●
R&S®FSW50 (1312.8000K50)
●
R&S®FSW67 (1312.8000K67)
●
R&S®FSW85 (1312.8000K85)
The following firmware options are described:
● R&S FSW-K40 (1313.1397.02)
© 2016 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Fax: +49 89 41 29 12 164
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
The following abbreviations are used throughout this manual: R&S®FSW is abbreviated as R&S FSW.
R&S®FSW-K40
Contents
Contents
1 Preface.................................................................................................... 5
1.1
About this Manual......................................................................................................... 5
1.2
Documentation Overview............................................................................................. 6
1.3
Conventions Used in the Documentation...................................................................7
2 Welcome to the Phase Noise Measurement Application................... 9
2.1
Starting the Application................................................................................................9
2.2
Understanding the Display Information....................................................................10
3 Measurements and Result Displays...................................................14
4 Measurement Basics........................................................................... 22
4.1
Spurs and Spur Removal........................................................................................... 22
4.2
Residual Effects.......................................................................................................... 23
4.3
Measurement Range................................................................................................... 24
4.4
Sweep Modes.............................................................................................................. 25
4.5
Trace Averaging.......................................................................................................... 25
4.6
Frequency Determination...........................................................................................27
4.7
Level Determination....................................................................................................30
4.8
Signal Attenuation...................................................................................................... 30
4.9
Using Limit Lines........................................................................................................ 31
4.10
Analyzing Several Traces - Trace Mode....................................................................33
4.11
Using Markers............................................................................................................. 35
5 Configuration........................................................................................36
5.1
Configuration Overview..............................................................................................36
5.2
Default Settings for Phase Noise Measurements.................................................... 37
5.3
Configuring the Frontend...........................................................................................38
5.4
Controlling the Measurement.................................................................................... 40
5.5
Configuring the Measurement Range....................................................................... 43
5.6
Performing Measurements.........................................................................................46
5.7
Configuring In- and Outputs...................................................................................... 48
5.8
Automatic Measurement Configuration....................................................................49
6 Analysis................................................................................................ 51
User Manual 1173.9286.02 ─ 14
3
R&S®FSW-K40
Contents
6.1
Configuring Graphical Result Displays.................................................................... 51
6.2
Configure Numerical Result Displays....................................................................... 56
6.3
Using Limit Lines........................................................................................................ 58
6.4
Using Markers............................................................................................................. 65
7 How to Configure Phase Noise Measurements.................................68
7.1
Performing a Basic Phase Noise Measurement.......................................................68
7.2
Customizing the Measurement Range...................................................................... 68
8 Remote Control Commands for Phase Noise Measurements......... 70
8.1
Common Suffixes........................................................................................................70
8.2
Introduction................................................................................................................. 71
8.3
Controlling the Phase Noise Measurement Channel...............................................76
8.4
Performing Measurements.........................................................................................80
8.5
Configuring the Result Display..................................................................................85
8.6
Configuring the Frontend...........................................................................................92
8.7
Controlling the Measurement.................................................................................... 95
8.8
Configuring the Measurement Range....................................................................... 99
8.9
Using Limit Lines...................................................................................................... 106
8.10
Graphical Display of Phase Noise Results............................................................. 117
8.11
Configure Numerical Result Displays..................................................................... 127
8.12
Using Markers........................................................................................................... 140
8.13
Configuring In- and Outputs.................................................................................... 146
8.14
Automatic Measurement Configuration..................................................................147
8.15
Using the Status Register........................................................................................ 148
8.16
Remote Control Example Scripts............................................................................ 154
List of Remote Commands (Phase Noise).......................................160
Index....................................................................................................165
User Manual 1173.9286.02 ─ 14
4
R&S®FSW-K40
Preface
About this Manual
1 Preface
1.1 About this Manual
This User Manual provides all the information specific to the application. All general
instrument functions and settings common to all applications and operating modes are
described in the main R&S FSW User Manual.
The main focus in this manual is on the measurement results and the tasks required to
obtain them. The following topics are included:
●
Welcome to the Phase Noise Application
Introduction to and getting familiar with the application
●
Typical applications
Example measurement scenarios in which the application is frequently used.
●
Measurements and Result Displays
Details on supported measurements and their result types
●
Phase Noise Measurement Basics
Background information on basic terms and principles in the context of the measurement
●
Phase Noise Measurement Configuration + Analysis
A concise description of all functions and settings available to configure measurements and analyze results with their corresponding remote control command
●
How to Perform Measurements with the Phase Noise Application
The basic procedure to perform each measurement and step-by-step instructions
for more complex tasks or alternative methods
●
Measurement Examples
Detailed measurement examples to guide you through typical measurement scenarios and allow you to try out the application immediately
●
Optimizing and Troubleshooting the Measurement
Hints and tips on how to handle errors and optimize the test setup
●
Remote Commands for Phase Noise Measurements
Remote commands required to configure and perform phase noise measurements
in a remote environment, sorted by tasks
(Commands required to set up the environment or to perform common tasks on the
instrument are provided in the main R&S FSW User Manual)
Programming examples demonstrate the use of many commands and can usually
be executed directly for test purposes
●
Annex
Reference material
●
List of remote commands
Alphabetical list of all remote commands described in the manual
●
Index
User Manual 1173.9286.02 ─ 14
5
R&S®FSW-K40
Preface
Documentation Overview
1.2 Documentation Overview
The user documentation for the R&S FSW consists of the following parts:
●
"Getting Started" printed manual
●
Online Help system on the instrument
●
User manuals and online manual for base unit and options provided on the product
page
●
Service manual provided on the internet for registered users
●
Instrument security procedures provided on the product page
●
Release notes provided on the product page
●
Data sheet and brochures provided on the product page
●
Application notes provided on the Rohde & Schwarz website
You find the user documentation on the R&S FSW product page mainly at:
http://www.rohde-schwarz.com/product/FSW > "Downloads" > "Manuals"
Additional download paths are stated directly in the following abstracts of the documentation types.
Getting Started
Introduces the R&S FSW and describes how to set up and start working with the product. Includes basic operations, typical measurement examples, and general information, e.g. safety instructions, etc.
Online Help
Offers quick, context-sensitive access to the information needed for operation and programming. It contains the description for the base unit and the software options. The
Online Help is embedded in the instrument's firmware; it is available using the icon
on the toolbar of the R&S FSW.
User Manuals and Online Manual
Separate manuals are provided for the base unit and the software options:
●
Base unit manual
Contains the description of the graphical user interface, an introduction to remote
control, the description of all SCPI remote control commands, programming examples, and information on maintenance, instrument interfaces and error messages.
Includes the contents of the Getting Started manual.
●
Software option manuals
Describe the specific functions of the option. Basic information on operating the
R&S FSW is not included.
The online manual provides the contents of the user manuals for the base unit and all
software options for immediate display on the internet.
User Manual 1173.9286.02 ─ 14
6
R&S®FSW-K40
Preface
Conventions Used in the Documentation
Service Manual
Describes the performance test for checking the rated specifications, module replacement and repair, firmware update, troubleshooting and fault elimination, and contains
mechanical drawings and spare part lists.
The service manual is available for registered users on the global Rohde & Schwarz
information system (GLORIS).
Instrument Security Procedures
Deals with security issues when working with the R&S FSW in secure areas.
Data Sheet and Brochures
The data sheet contains the technical specifications of the R&S FSW. Brochures provide an overview of the instrument and deal with the specific characteristics, see:
http://www.rohde-schwarz.com/product/FSW > "Downloads" > "Brochures and Data
Sheets"
Release Notes
Describes the firmware installation, new and modified features and fixed issues
according to the current firmware version. You find the latest version at:
http://www.rohde-schwarz.com/product/FSW > "Firmware"
Application Notes, Application Cards, White Papers, etc.
These documents deal with special applications or background information on particular topics, see:
http://www.rohde-schwarz.com/ > "Downloads" > "Applications".
1.3 Conventions Used in the Documentation
1.3.1 Typographical Conventions
The following text markers are used throughout this documentation:
Convention
Description
"Graphical user interface elements"
All names of graphical user interface elements on the screen, such as
dialog boxes, menus, options, buttons, and softkeys are enclosed by
quotation marks.
KEYS
Key names are written in capital letters.
File names, commands,
program code
File names, commands, coding samples and screen output are distinguished by their font.
Input
Input to be entered by the user is displayed in italics.
User Manual 1173.9286.02 ─ 14
7
R&S®FSW-K40
Preface
Conventions Used in the Documentation
Convention
Description
Links
Links that you can click are displayed in blue font.
"References"
References to other parts of the documentation are enclosed by quotation marks.
1.3.2 Conventions for Procedure Descriptions
When describing how to operate the instrument, several alternative methods may be
available to perform the same task. In this case, the procedure using the touchscreen
is described. Any elements that can be activated by touching can also be clicked using
an additionally connected mouse. The alternative procedure using the keys on the
instrument or the on-screen keyboard is only described if it deviates from the standard
operating procedures.
The term "select" may refer to any of the described methods, i.e. using a finger on the
touchscreen, a mouse pointer in the display, or a key on the instrument or on a keyboard.
1.3.3 Notes on Screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as much as possible of the provided functions and
possible interdependencies between parameters.
The screenshots usually show a fully equipped product, that is: with all options installed. Thus, some functions shown in the screenshots may not be available in your particular product configuration.
User Manual 1173.9286.02 ─ 14
8
R&S®FSW-K40
Welcome to the Phase Noise Measurement Application
Starting the Application
2 Welcome to the Phase Noise Measurement
Application
The R&S FSW-K40 is a firmware application that adds functionality to measure the
phase noise characteristics of a device under test with the R&S FSW signal analyzer.
This user manual contains a description of the functionality that the application provides, including remote control operation.
Functions that are not discussed in this manual are the same as in the Spectrum application and are described in the R&S FSW User Manual. The latest versions of the
manuals are available for download at the product homepage.
http://www2.rohde-schwarz.com/product/FSW.html.
Installation
Find detailed installing instructions in the Getting Started or the release notes of the
R&S FSW.
●
●
Starting the Application............................................................................................. 9
Understanding the Display Information................................................................... 10
2.1 Starting the Application
The phase noise measurement application adds a new type of measurement to the
R&S FSW.
To activate the the Phase Noise application
1. Select the MODE key.
A dialog box opens that contains all operating modes and applications currently
available on your R&S FSW.
2. Select the "Phase Noise" item.
The R&S FSW opens a new measurement channel for the Phase Noise application.
All settings specific to phase noise measurements are in their default state.
Multiple Measurement Channels and Sequencer Function
When you enter an application, a new measurement channel is created which determines the measurement settings for that application. The same application can be activated with different measurement settings by creating several channels for the same
application.
User Manual 1173.9286.02 ─ 14
9
R&S®FSW-K40
Welcome to the Phase Noise Measurement Application
Understanding the Display Information
The number of channels that can be configured at the same time depends on the available memory on the instrument.
Only one measurement can be performed at any time, namely the one in the currently
active channel. However, in order to perform the configured measurements consecutively, a Sequencer function is provided.
If activated, the measurements configured in the currently active channels are performed one after the other in the order of the tabs. The currently active measurement is
indicated by a symbol in the tab label. The result displays of the individual channels
are updated in the tabs (as well as the "MultiView") as the measurements are performed. Sequential operation itself is independent of the currently displayed tab.
For details on the Sequencer function see the R&S FSW User Manual.
2.2 Understanding the Display Information
The following figure shows the display as it looks for phase noise measurements. All
different information areas are labeled. They are explained in more detail in the following sections.
Figure 2-1: Screen layout of the phase noise measurement application
1
2
3
4
5
6
7
=
=
=
=
=
=
=
Toolbar
Channel bar
Diagram header
Result display
Softkey bar
Measurement status
Status bar
For a description of the elements not described below, please refer to the Getting Started of the R&S FSW.
User Manual 1173.9286.02 ─ 14
10
R&S®FSW-K40
Welcome to the Phase Noise Measurement Application
Understanding the Display Information
Measurement status
The application shows the progress of the measurement in a series of green bars at
the bottom of the diagram area. For each half decade in the measurement, the applications adds a bar that spans the frequency range of the corresponding half decade.
The bar has several features.
●
The numbers within the green bar show the progress of the measurement(s) in the
half decade the application currently works on.
The first number is the current, the second number the total count of measurements for that half decade. The last number is the time the measurement requires.
●
A double-click on the bar opens an input field to define the number of averages for
that half decade.
●
A right-click on the bar opens a context menu.
The context menu provides easy access to various parameters (resolution bandwidth, sweep mode etc.) that define the measurement characteristics for a half
decade. The values in parentheses are the currently selected values. For more
information on the available parameters see "Half Decades Configuration Table"
on page 46.
Channel bar information
The channel bar contains information about the current measurement setup, progress
and results.
Figure 2-2: Channel bar of the phase noise application
Frequency
Frequency the R&S FSW has been tuned to.
The frontend frequency is the expected frequency of the carrier. When frequency tracking or verification is on, the application might adjust the frontend
frequency.
Ref Level & Att
Reference level (first value) and attenuation (second value) of the R&S FSW.
When level tracking or verification is on, the application might adjust the frontend level.
Measurement
Complete phase noise measurement range. For more information see Chapter 4.3, "Measurement Range", on page 24.
Measured Level
DUT level that has been actually measured.
The measured level might differ from the frontend level, e.g. if you are using
level verification.
Initial Delta
User Manual 1173.9286.02 ─ 14
Difference between the nominal level and the first level that has been measured.
11
R&S®FSW-K40
Welcome to the Phase Noise Measurement Application
Understanding the Display Information
Drift
Difference between the 1st level that has been measured and the level that
has been measured last.
In continuous sweep mode, the drift is the difference between the 1st level that
has been measured in the 1st sweep and the level that has been measured
last.
Measured Frequency
DUT frequency that has been actually measured.
The measured frequency might differ from the frontend frequency, e.g. if you
are using level verification.
Initial Delta
Difference between the nominal frequency and the first frequency that has
been measured.
Drift
Difference between the 1st frequency that has been measured and the frequency that has been measured last.
In continuous sweep mode, the drift is the difference between the 1st frequency that has been measured in the 1st sweep and the frequency that has
been measured last.
SGL [#/#]
Sweep mode (single or continuous). If you use trace averaging, it also shows
the current measurement number out of the total number of measurements.
The following two figures show the relations between the frequency and level errors.
initial
offset
frequency
drift
fmeas_3
ffront
fmeas_2
fmeas_1
fmeas_4
f
Figure 2-3: Frequency errors
ffront = initial frequency set on the frontend
fmeas_x = actual frequency that has been measured
P
Pmeas_2
initial
offset
Pfront
level drift
Pmeas_1
Pmeas_3
Figure 2-4: Level errors
Pfront
Pfront
Pmeas_1
Pmeas_2
Pmeas_3
=
=
=
=
=
reference level if tracking = off
initial reference level if tracking = on
becomes reference level after first sweep if tracking = on
becomes reference level after second sweep if tracking = on
becomes reference level after third sweep if tracking = on
Window title bar information
For each diagram, the header provides the following information:
User Manual 1173.9286.02 ─ 14
12
R&S®FSW-K40
Welcome to the Phase Noise Measurement Application
Understanding the Display Information
Figure 2-5: Window title bar information of the phase noise application
1
2
3
4
5
=
=
=
=
=
Window number
Window type
Trace color and number
Trace mode
Smoothing state and degree
Status bar information
Global instrument settings, the instrument status and any irregularities are indicated in
the status bar beneath the diagram. Furthermore, the progress of the current operation
is displayed in the status bar.
User Manual 1173.9286.02 ─ 14
13
R&S®FSW-K40
Measurements and Result Displays
3 Measurements and Result Displays
Access:
The Phase Noise application measures the phase noise of a single sideband of a carrier.
It features several result displays. Result displays are different representations of the
measurement results. They may be diagrams that show the results in a graphic way or
tables that show the results in a numeric way.
In the default state of the application, only the graphical display of phase noise results
is active.
Phase Noise Diagram................................................................................................... 14
Residual Noise.............................................................................................................. 15
Spot Noise.....................................................................................................................16
Spur List........................................................................................................................ 17
Sweep Result List......................................................................................................... 18
Spectrum Monitor..........................................................................................................19
Frequency Drift..............................................................................................................20
Frequency and Level Stability....................................................................................... 21
Reference Measurement...............................................................................................21
Phase Noise Diagram
The phase noise diagram shows the power level of the phase noise over a variable frequency offset from the carrier frequency.
Measurement range
The unit of both axes in the diagram is fix. The x-axis always shows the offset frequencies in relation to the carrier frequency on a logarithmic scale in Hz. It always has a
logarithmic scale to make sure of a equal representation of offsets near and far away
from the carrier. The range of offsets that the x-axis shows is variable and depends on
the measurement range you have defined and the scope of the x-axis that you have
set.
For more information on the measurement range see Chapter 4.3, "Measurement
Range", on page 24.
If the measurement range you have set is necessary, but you need a better resolution
of the results, you can limit the displayed result by changing the x-axis scope. The
scope works like a zoom to get a better view of the trace at various points. It does not
start a new measurement or alter the current measurements results in any way.
The y-axis always shows the phase noise power level contained in a 1 Hz bandwidth in
relation to the level of the carrier. The unit for this information is dBc/Hz and is also fix.
Y-axis scale
The scale of the y-axis is variable. Usually it is best to use the automatic scaling that
the application provides, because it makes sure that the whole trace is always visible.
You can, however, also customize the range, the minimum and the maximum values
on the y-axis by changing the y-axis scale.
User Manual 1173.9286.02 ─ 14
14
R&S®FSW-K40
Measurements and Result Displays
The measurement results are displayed as traces in the diagram area. Up to six active
traces at any time are possible. Each of those may have a different setup and thus
show different aspects of the measurement results.
In the default state, the application shows two traces. A yellow one and a blue one.
Both result from the same measurement data, but have been evaluated differently. On
the first trace, smoothing has been applied, the second one shows the raw data.
For more information on trace smoothing see Chapter 4.5, "Trace Averaging",
on page 25.
Figure 3-1: Overview of the phase noise result display
The figure above shows a phase noise curve with typical characteristics. Frequency
offsets near the carrier usually have higher phase noise levels than those further away
from the carrier. The curve has a falling slope until the thermal noise of the DUT has
been reached. From this point on, it is more or less a straight horizontal line.
Remote command:
TRACe[:DATA]? on page 126
Residual Noise
The residual noise display summarizes the residual noise results in a table.
For more information on the residual noise results see Chapter 4.2, "Residual Effects",
on page 23.
The table consists of up to four rows with each row representing a different integration
interval. Each row basically contains the same information with the exception that the
first row always shows the results for the first trace and the other rows with custom
integration ranges the results for any one trace.
The residual noise information is made up out of several values.
User Manual 1173.9286.02 ─ 14
15
R&S®FSW-K40
Measurements and Result Displays
Type
Shows the number of the trace that is integrated (T[x]).
Start / Stop Offset
Shows the start and stop offset of the integration interval.
Int. PHN
Shows the Integrated Phase Noise.
The integral is calculated over the frequency range defined by the Start and Stop
Offset values.
PM
Shows the Residual PM result in degrees and rad.
FM
Shows the Residual FM results in Hz.
Jitter
Shows the Jitter in seconds.
For more information on residual noise see Chapter 4.2, "Residual Effects",
on page 23.
Remote command:
Querying Residual PM:
FETCh:PNOise<t>:RPM? on page 131
Querying Residual FM:
FETCh:PNOise<t>:RFM? on page 130
Querying Jitter:
FETCh:PNOise<t>:RMS? on page 130
Querying Integrated Phase Noise
Querying user ranges:
FETCh:PNOise<t>:USER<range>:RFM? on page 131
FETCh:PNOise<t>:USER<range>:RMS? on page 131
FETCh:PNOise<t>:USER<range>:RPM? on page 132
Spot Noise
Spot noise is the phase noise at a particular frequency offset (or spot) that is part of the
measurement range. It is thus like a fixed marker.
The unit of spot noise results is dBc/Hz. The application shows the results in a table.
The table consists of a variable number of 10x frequencies (depending on the measurement range), and a maximum of five user frequencies, with each row containing
the spot noise information for a particular frequency offset.
The spot noise information is made up out of several variables.
User Manual 1173.9286.02 ─ 14
16
R&S®FSW-K40
Measurements and Result Displays
Type
Shows where the spot noise offset frequency comes from. By default, the application evaluates the spot noise for the first offset frequency of a decade only (10x Hz,
beginning at 1 kHz). However, you can add up to five customized offsets frequencies that you want to know the phase noise for. If you want to use more custom
offsets, you can add another spot noise table.
The "User" label indicates a custom offset frequency.
Offset Frequency
Shows the offset frequency the spot noise is evaluated for. You may add any offset
that is part of the measurement range.
The number in brackets (T<x>) indicates the trace the result refers to.
Phase Noise
Shows the phase noise for the corresponding offset frequency.
The number in brackets (T<x>) indicates the trace the result refers to.
Note that the spot noise results are calculated for a particular trace only. You can
select the trace by tapping on the trace LED in the header of the result display.
Remote command:
Querying spot noise results on 10x offset frequencies:
CALCulate<n>:SNOise:DECades:X? on page 133
CALCulate<n>:SNOise:DECades:Y? on page 133
Querying custom spot noise results:
CALCulate<n>:SNOise<m>:Y? on page 135
Trace selection: DISPlay[:WINDow<n>]:TRACe<t>:SELect on page 135
Spur List
Spurs are peak levels at one or more offset frequencies and are caused mostly by
interfering signals. The application shows the location of all detected spurs in a table.
The table consists of a variable number of rows. For each detected spur, the table
shows several results.
Number
Shows the spur number. Spurs are sorted by their frequency, beginning with
the spur with the lowest frequency.
Offset Frequency
Shows the position (offset frequency) of the spur.
User Manual 1173.9286.02 ─ 14
17
R&S®FSW-K40
Measurements and Result Displays
Power
Shows the power level of the spur in dBc.
Jitter
Shows the jitter value of the spur in s.
In addition to the jitter for each spur, the result display also shows the Discrete Jitter and the Random Jitter at the end of the table.
●
The Discrete Jitter is the RMS value of all individual jitter values.
●
The Random Jitter is the difference of the overall jitter (as shown in the
Residual Noise result display) and the Discrete Jitter.
The result is an RMS value: RandomJitter2 = Jitter2 - DiscreteJitter2
For more information see Chapter 4.1, "Spurs and Spur Removal", on page 22.
Remote command:
FETCh:PNOise:SPURs? on page 136
FETCh:PNOise:SPURs:DISCrete? on page 136
FETCh:PNOise:SPURs:RANDom? on page 136
Sweep Result List
The sweep result list summarizes the results of the phase noise measurement.
The table consists of several rows with each row representing a half decade. The number of rows depends on the number of half decades analyzed during the measurement.
The sweep results are made up out of several values.
●
●
Results in a red font indicate that the frequency drift is so large that the frequency
has drifted into the range of a higher half decade. The result is therefore invalid.
Results in a green font indicate the half decade that is currently measured.
Start / Stop
Shows the start and stop offset of the half decade.
Sampling Rate
Shows the sample rate used in the corresponding half decade.
AVG
Shows the number of measurements performed in the half decade to calculate the
average (final) result.
Freq Drift
Shows the difference to the initial (nominal) frequency that was measured in the
half decade.
If you perform more than one measurement (averages) in the half decade, the
value is updated for each single measurement. The last value that has been measured in the half decade will remain in the table.
User Manual 1173.9286.02 ─ 14
18
R&S®FSW-K40
Measurements and Result Displays
Max Drift
Shows the highest difference to the initial (nominal) frequency that was measured
in the half decade.
Level Drift
Shows the difference to the initial (nominal) level that was measured in the half
decade.
If you perform more than one measurement (averages) in the half decade, the
value is updated for each single measurement. The last value that has been measured in the half decade will remain in the table.
Remote command:
Start offset: FETCh:PNOise:SWEep:STARt? on page 139
Stop offset: FETCh:PNOise:SWEep:STOP? on page 139
Sample rate: FETCh:PNOise:SWEep:SRATe? on page 139
Averages: FETCh:PNOise:SWEep:AVG? on page 137
Frequency drift: FETCh:PNOise:SWEep:FDRift? on page 138
Max drift: FETCh:PNOise:SWEep:MDRift? on page 138
Level drift: FETCh:PNOise:SWEep:LDRift? on page 138
Spectrum Monitor
The spectrum monitor shows the spectrum for the half decade that is currently measured.
Span
The span on the x-axis is defined by the start and stop frequency of the half decade
that is currently measured.
Y-axis scale
The scale of the y-axis is automatically determined according to the signal characteristics.
In I/Q mode, the result display contains two traces.
● The yellow trace ("raw trace") represents the live signal with the actual center frequency currently measured.
User Manual 1173.9286.02 ─ 14
19
R&S®FSW-K40
Measurements and Result Displays
●
The blue trace ("track trace") equalizes frequency drifting signals and thus shows a
stable version of the signal with the intended center frequency.
If necessary, you can turn the traces on and off. For more information see "Spectrum
Monitor: Raw Trace / Trk Trace (On Off)" on page 56.
The green vertical lines indicate the phase noise offset to be measured on in relation to
the displayed center frequency.The position of the two green line depends on the half
decade that is currently measured and the sample rate you have selected.
Remote command:
TRACe[:DATA]? on page 126
Frequency Drift
The frequency drift shows the instantenous frequency over time for the half decade
that is currently measured.
Time span
The displayed time span on the x-axis is defined by the time it takes to perform a measurement in the half decade that is currently measured. If the measurement time for a
particular half decade is very long (several seconds), the application probably updates
the result display several times. In that case, the application splits the measurement
into several "sub-measurements".
Y-axis scale
The scale of the y-axis is automatically determined according to the sample rate. For a
better resolution, the trace is offset by the first measured frequency value. Thus, the
trace always starts at 0 Hz. The initial correction value is displayed in the diagram as a
numeric result.
To get a better resolution of the time axis, use the zoom function.
If necessary, you can turn the trace on and off. For more information see "Frequency
Drift: Trace 1 (On Off)" on page 56.
User Manual 1173.9286.02 ─ 14
20
R&S®FSW-K40
Measurements and Result Displays
Frequency and Level Stability
The stability results show the current level and frequency drift characteristics of the
carrier signal compared to the initial frequency and level. In addition to the numerical
results, the result display also contains a graphical represenation of the drift characteristics.
The result display contains the following results.
● Carrier Stability
Difference between the 1st frequency that has been measured and the frequency
that has been measured last.
● Δ to Ref Level
Difference between the 1st level that has been measured and the level that has
been measured last.
The results correspond to the Level Drift and Frequency Drift results displayed in the
channel bar. For more information see "Channel bar information" on page 11
Note that the results are only valid for I/Q FFT measurements (see "Global Sweep
Mode" on page 45).
Reference Measurement
The reference measurement measures the inherent noise figure (DANL) of the
R&S FSW.
To determine the inherent noise, the application performs a measurement without the
signal at the input. The resulting trace shows the inherent noise of the R&S FSW only.
When you substract that inherent noise from the phase noise of the measurement with
trace mathematics, you get a trace that shows the phase noise of the DUT only.
Remote command:
CONFigure:REFMeas ONCE on page 81
User Manual 1173.9286.02 ─ 14
21
R&S®FSW-K40
Measurement Basics
Spurs and Spur Removal
4 Measurement Basics
The measurement basics contain background information on the terminology and principles of phase noise measurements.
Phase noise measurements in general determine the single sideband phase noise
characteristics of a device under test (DUT).
●
●
●
●
●
●
●
●
●
●
●
Spurs and Spur Removal........................................................................................ 22
Residual Effects...................................................................................................... 23
Measurement Range...............................................................................................24
Sweep Modes......................................................................................................... 25
Trace Averaging......................................................................................................25
Frequency Determination........................................................................................27
Level Determination................................................................................................ 30
Signal Attenuation...................................................................................................30
Using Limit Lines.....................................................................................................31
Analyzing Several Traces - Trace Mode................................................................. 33
Using Markers......................................................................................................... 35
4.1 Spurs and Spur Removal
Most phase noise results contain spurs. Spurs are peak levels at one or more offset
frequencies and are caused mostly by interfering signals. For some applications you
may want to specifically indentify the location of spurs. However, for some applications,
spurs do not matter in evaluating the results and you may want to remove them from
the trace in order to get a "smooth" phase noise trace.
Spur removal
The application allows you to (visually) remove spurs from the trace. Spur removal is
based on an algorithm that detects and completely removes the spurs from the trace
and fills the gaps with data that has been determined mathematically.
The spur removal functionality separates the actual spur power from the underlying
phase noise and displays the latter in a two-stage process. The first stage of spur
detection is based on an eigenvalue decomposition during the signal processing.
Spur threshold
During the second stage, the application uses statistical methods to remove a spur. A
spur is detected, if the level of the signal is above a certain threshold. The spur threshold is relative to an imaginary median trace that the application calculates.
If parts of the signal are identfied as spurs, the application removes all signal parts
above that level and substitutes them with the median trace.
User Manual 1173.9286.02 ─ 14
22
R&S®FSW-K40
Measurement Basics
Residual Effects
Figure 4-1: Spur detection and removal principle
4.2 Residual Effects
Residual noise effects are modulation products that originate directly from the phase
noise. It is possible deduct them mathematically from the phase noise of a DUT.
The application calculates three residual noise effects. All calculations are based on an
integration of the phase noise over a particular offset frequency range.
Residual PM
The residual phase modulation is the contribution of the phase noise to the output of a
PM demodulator. It is evaluated over the frequency range you have defined.
f stop
Residual PM  2 
 L( f
m ) df m
rad 
f start
with L( f )  single sideband phase noise [dBc/Hz]
Residual FM
The residual frequency modulation is the contribution of the phase noise to the output
of an FM demodulator. It is evaluated over the frequency range you have defined.
User Manual 1173.9286.02 ─ 14
23
R&S®FSW-K40
Measurement Basics
Measurement Range
f stop
Residual FM  2 
f
2
m L ( f m ) df m
Hz 
f start
with L( f m )  single sideband phase noise [dBc/Hz]
f m  frequency [Hz]
Jitter
The jitter is the RMS temporal fluctuation of a carrier with the given phase noise evaluated over a given frequency range of interest.
Jitter[s] 
ResidualPM [rad]
2  f 0
with f 0  Carrier frequency
Figure 4-2: Residual noise based on an integration between 10 kHz and 100 kHz offset
4.3 Measurement Range
Noise measurements determine the noise characteristics of a DUT over a particular
measurement range. This measurement range is defined by two offset frequencies.
The frequency offsets themselves are relative to the nominal frequency of the DUT.
The measurement range again is divided into several (logarithmic) decades, or, for
configuration purposes, into half decades.
User Manual 1173.9286.02 ─ 14
24
R&S®FSW-K40
Measurement Basics
Trace Averaging
Figure 4-3: Measurement range and half decades
This breakdown into several half decades is made to speed up measurements. You
can configure each half decade separately in the "Half Decade Configuration Table".
For quick, standardized measurements, the application provides several predefined
sweep types or allows you to configure each half decade manually, but globally.
The main issue in this context is the resolution bandwidth (RBW) and its effect on the
measurement time. In general, it is best to use a resolution bandwidth as small as possible for the most accurate measurement results. However, accuracy comes at the
price of measurement speed.
To avoid very long measurement times, the application provides only a certain range of
RBW that are available for each half decade.
4.4 Sweep Modes
Sweep modes define the data processing method.
Swept
The application performs a sweep of the frequency spectrum.
I/Q FFT
The application evaluates the I/Q data that has been collected and calculates the trace
based on that data.
4.5 Trace Averaging
The application provides several modes of trace averaging that you can use separately
or in any combination.
The order in which averaging is performed is as follows. For more details for each
averaging mode see below.
1. Half decade averaging.
User Manual 1173.9286.02 ─ 14
25
R&S®FSW-K40
Measurement Basics
Trace Averaging
The application measures each half decade a particular number of times before
measuring the next one.
2. Cross-correlation
The application performs a certain number of cross-correlation operations in each
half decade.
3. Sweep Count.
The application measures the complete measurement range a particular number of
times.
It again includes half decade averaging as defined.
After the measurement over the sweep count is finished, the application displays
the averaged results.
4. Trace smoothing.
Calculates the moving average for the current trace.
4.5.1 Half Decade Averaging
Define the number of measurements that the application performs for each half decade
before it displays the averaged results and measures the next half decade.
In combination with the RBW, this is the main factor that has an effect on the measurement time. Typically you will use a small number of averages for small RBWs because
small RBWs already provide accurate results and a high number of averages for high
RBWs to get more balanced results.
4.5.2 Sweep Count
The sweep count defines the number of sweeps that the application performs during a
complete measurements.
A sweep in this context is the measurement over the complete measurement range
once. A complete measurement, however, can consists of more than one sweep. In
that case the application measures until the number of sweeps that have been defined
are done. The measurement configuration stays the same all the time.
In combination with the Average trace mode and half decade averaging, the sweep
count averages the trace even more.
4.5.3 Trace Smoothing
(Software-based) smoothing is a way to visually remove anomalies in the trace that
may distort the results. The smoothing process is based on a moving average over the
complete measurement range. The number of samples included in the averaging process (the aperture size) is variable and is a percentage of all samples that the trace consists of.
User Manual 1173.9286.02 ─ 14
26
R&S®FSW-K40
Measurement Basics
Frequency Determination
Figure 4-4: Sample size included in trace smoothing
The application smoothes the trace only after the measurement has been finished and
the data has been analyzed and written to a trace. Thus, smoothing is really just an
enhancement of the trace display, not of the data itself. This also means that smoothing is always applied after any other trace averagings have been done, as these happen during the measurement itself.
You can turn trace smoothing on and off for all traces individually and compare, for
example, the raw and the smooth trace.
Linear smoothing is based on the following algorithm:
 x s  n1 

2
1
y ' s  
y x 
n
 x s  n1 
2



Equation 4-1: Linear trace smoothing
Logarithmic smoothing is based on the following algorithm:
  x  s  n1  y x   
1
2

 
y ' s  10  log10  
10 10   
n
 
  x  s  n1

2

 

Equation 4-2: Logarithmic trace smoothing
y(s) = logarithmic phase noise level
4.6 Frequency Determination
Nominal frequency
The nominal frequency is the output or center frequency of the DUT. To get correct
and valid measurement results, the application needs to know the real frequency of the
DUT.
User Manual 1173.9286.02 ─ 14
27
R&S®FSW-K40
Measurement Basics
Frequency Determination
Unverified signals
The R&S FSW tries to start the measurement as soon as you enter the phase noise
application. If it cannot verify a signal, it will try to start the measurement over and over.
To stop the repeated (and probably unsuccessful) signal verification, stop the measurement on the first verification failure.
The available (nominal) frequency range depends on the hardware you are using. For
more information see the datasheet of the R&S FSW.
If you are not sure about the nominal frequency, define a tolerance range to verify the
frequency. For measurements on unstable or drifting DUTs, use the frequency tracking
functionality.
Frequency verification
When you are using frequency verification, the application intiates a measurement that
verifies that the frequency of the DUT is within a certain range of the nominal frequency. This measurement takes place before the actual phase noise measurement.
Its purpose is to find strong signals within a frequency tolerance range and, if successful, to adjust the nominal frequency and lock onto that new frequency. The frequency
tolerance is variable. You can define it in absolute or relative terms.
Figure 4-5: Frequency and level tolerance
You can define both absolute and relative tolerances. In that case, the application uses
the higher tolerance to determine the frequency.
If there is no signal within the tolerance range, the application aborts the phase noise
measurement.
In the numerical results, the application always shows the frequency the measurement
was actually performed on. If the measured frequency is not the same as the nominal
frequency, the numerical results also show the deviation from the nominal frequency.
User Manual 1173.9286.02 ─ 14
28
R&S®FSW-K40
Measurement Basics
Frequency Determination
Frequency tracking
When you are using the frequency tracking, the application tracks drifting frequencies
of unstable DUTs. It internally adjusts and keeps a lock on the nominal frequency of
the DUT.
Figure 4-6: Frequency and level tracking
Tracking bandwidth
The tracking bandwidth defines the bandwidth within which the application tracks the
frequency.
Normally, the application adjusts the sample rate to the half decade it is currently measuring. For half decades that are near the carrier, the sample rate is small. Half decades far from the carrier use a higher sample rate. However, in case of drifting signals,
this method may result in data loss because the default bandwidth for a half decade
might be too small for the actual drift in the frequency. In that case, you can define the
tracking bandwidth which increases the sample rate if necessary and thus increases
the chance to capture the signal.
Figure 4-7: Frequency tracking with tracking bandwidth turned off (left) and a tracking bandwidth of
100 Hz (right)
User Manual 1173.9286.02 ─ 14
29
R&S®FSW-K40
Measurement Basics
Signal Attenuation
4.7 Level Determination
Nominal level
The nominal level in other terms is the reference level of the R&S FSW. This is the
level that the analyzer expects at the RF input.
The available level range depends on the hardware. For more information see the
datasheet of the R&S FSW.
Make sure to define a level that is as close to the level of the DUT to get the best
dynamic range for the measurement. At the same time make sure that the signal level
is not higher than the reference level to avoid an overload of the A/D converter and
thus deteriorating measurement results.
If you are not sure about the power level of the DUT, but would still like to use the best
dynamic range and get results that are as accurate as possible, you can verify or track
the level.
Level verification
When you are using the level verification, the application initiates a measurement that
determines the level of the DUT. If the level of the DUT is within a certain tolerance
range, it will adjust the nominal level to that of the DUT. Else, it will abort the phase
noise measurement.
Define a level tolerance in relation to the current nominal level. The tolerance range
works for DUT levels that are above or below the current nominal level.
Level tracking
For tests on DUTs whose level varies, use level tracking. If active, the application
keeps track of the DUTs level during the phase noise measurement and adjusts the
nominal level accordingly.
For a graphical representation of level verification and level tracking see the figures in
Chapter 4.6, "Frequency Determination", on page 27.
4.8 Signal Attenuation
Attenuation of the signal may become necessary if you have to reduce the power of
the signal that you have applied. Power reduction is necessary, for example, to prevent
an overload of the input mixer. An overload of the input mixer may lead to incorrect
measurement results or damage to the hardware if the signal power is too strong.
In the default state, the application automatically determines the attenuation according
to the reference level. If necessary, you can also define the attenuation manually.
When you attenuate the signal, the application adjusts graphical and numerical results
accordingly.
User Manual 1173.9286.02 ─ 14
30
R&S®FSW-K40
Measurement Basics
Using Limit Lines
Because the reference level and attenuation are interdependent, changing the attenuation manually may also adjust the reference level.
RF attenuation
RF attenuation is always available. It is a combination of mechanical and IF attenuation.
The mechanical attenuator is located directly after the RF input of the R&S FSW. Its
step size is 5 dB. IF attenuation is applied after the signal has been down-converted.
Its step size is 1 dB.
Thus, the step size for RF attenuation as a whole is 1 dB. Mechanical attenuation is
used whenever possible (attenuation levels that are divisible by 5). IF attenuation handles the 1 dB steps only.
Example:
If you set an attenuation level of 18 dB, 15 dB are mechanical attenuation and 3 dB are
IF attenuation.
If you set an attenuation level 0f 6 dB, 5 dB are mechanical attenuation and 1 dB is IF
attenuation.
Electronic attenuation
Electronic attenuation is available with R&S FSW-B25. You can use it in addition to
mechanical attenuation. The step size of electronic attenuation is 1 dB with attenuation
levels not divisible by 5 again handled by the IF attenuator. Compared to RF attenuation, you can define the amount of mechanical and electronic attenuation freely.
4.9 Using Limit Lines
Limit lines provide an easy way to verify if measurement results are within the limits
you need them to be. As soon as you turn a limit line on, the application will indicate if
the phase noise a trace displays is in line with the limits or if it violates the limits.
The application provides two kinds of limit lines. 'Normal' limit lines as you know them
from the Spectrum application and special thermal limit lines for easy verification of
thermal noise results.
Phase noise limit lines
Phase noise limit lines have been designed specifically for phase noise measurements. Their shape is based on the thermal noise floor of the DUT and the typical run
of the phase noise curve.
The typical slope of the phase noise curve depends on the offset from the DUT frequency. In the white noise range (the noise floor), far away from the carrier, the slope
is more or less 0 dB per frequency decade. In the colored noise segment, the slope is
greater than 0 dB. The slope, however, is not constant in that segment, but again is
typical for various carrier offset segments (or ranges).
User Manual 1173.9286.02 ─ 14
31
R&S®FSW-K40
Measurement Basics
Using Limit Lines
The application supports the definition of up to five ranges, each with a different slope.
The ranges themselves are defined by corner frequencies. Corner frequencies are
those frequencies that mark the boundaries of typical curve slopes. If you use all five
ranges, the result would be a limit line with six segments.
All segments have a slope of 10 dB per decade (f-1) by default.
In most cases, these special limit lines will suffice for phase noise measurements as
they represent the typical shape of a phase noise curve.
Figure 4-8: Typical looks of a special limit line
Normal limit lines
Normal limit lines on the other hand may have any shape and may consist of up to 200
data points. You can turn on up to 8 normal limit lines at the same time. Each of those
limit line can test one or several traces.
If you want to use them for phase noise measurements however, a limit line must be
scaled in the unit dBc/Hz and must be defined on a logarithmic scale on the horizontal
axis.
User Manual 1173.9286.02 ─ 14
32
R&S®FSW-K40
Measurement Basics
Analyzing Several Traces - Trace Mode
Figure 4-9: Possible looks of a normal limit line
4.10 Analyzing Several Traces - Trace Mode
If several sweeps are performed one after the other, or continuous sweeps are performed, the trace mode determines how the data for subsequent traces is processed.
After each sweep, the trace mode determines whether:
●
the data is frozen (View)
●
the data is hidden (Blank)
●
the data is replaced by new values (Clear Write)
●
the data is replaced selectively (Max Hold, Min Hold, Average)
Each time the trace mode is changed, the selected trace memory is cleared.
The R&S FSW provides the following trace modes:
Table 4-1: Overview of available trace modes
Trace Mode
Description
Blank
Hides the selected trace.
Clear Write
Overwrite mode: the trace is overwritten by each sweep. This is the default setting.
Max Hold
The maximum value is determined over several sweeps and displayed. The
R&S FSW saves the sweep result in the trace memory only if the new value is greater
than the previous one.
Min Hold
The minimum value is determined from several measurements and displayed. The
R&S FSW saves the sweep result in the trace memory only if the new value is lower
than the previous one.
Average
The average is formed over several sweeps. The sweep count determines the number
of averaging procedures.
View
The current contents of the trace memory are frozen and displayed.
User Manual 1173.9286.02 ─ 14
33
R&S®FSW-K40
Measurement Basics
Analyzing Several Traces - Trace Mode
If a trace is frozen ("View" mode), the instrument settings, apart from level range and
reference level, can be changed without impact on the displayed trace. The fact that
the displayed trace no longer matches the current instrument setting is indicated by the
icon on the tab label.
If the level range or reference level is changed, the R&S FSW automatically adapts the
trace data to the changed display range. This allows an amplitude zoom to be made
after the measurement in order to show details of the trace.
Trace averaging algorithm
In "Average" trace mode, the sweep count determines how many traces are averaged.
The more traces are averaged, the smoother the trace is likely to become.
The algorithm for averaging traces depends on the sweep mode and sweep count.
●
sweep count = 0 (default)
In continuous sweep mode, a continuous average is calculated for 10 sweeps,
according to the following formula:
Trace 
9 * Traceold  MeasValue
10
Figure 4-10: Equation 1
Due to the weighting between the current trace and the average trace, past values
have practically no influence on the displayed trace after about ten sweeps. With
this setting, signal noise is effectively reduced without need for restarting the averaging process after a change of the signal.
●
sweep count = 1
The currently measured trace is displayed and stored in the trace memory. No
averaging is performed.
●
sweep count > 1
For both "Single Sweep" mode and "Continuous Sweep" mode, averaging takes
place over the selected number of sweeps. In this case the displayed trace is
determined during averaging according to the following formula:
Tracen 
1  n 1

  (Ti )  MeasValuen 
n  i 1

Figure 4-11: Equation 2
where n is the number of the current sweep (n = 2 ... Sweep Count).
No averaging is carried out for the first sweep but the measured value is stored in
the trace memory. With increasing n, the displayed trace is increasingly smoothed
since there are more individual sweeps for averaging.
After the selected number of sweeps the average trace is saved in the trace memory. Until this number of sweeps is reached, a preliminary average is displayed.
When the averaging length defined by the "Sweep Count" is attained, averaging is
continued in continuous sweep mode or for "Continue Single Sweep" according to
the following formula:
User Manual 1173.9286.02 ─ 14
34
R&S®FSW-K40
Measurement Basics
Using Markers
Trace 
( N  1) * Traceold  MeasValue
N
where N is the sweep count
4.11 Using Markers
Markers are used to mark points on traces, to read out measurement results and to
select a display section quickly. The application provides 4 markers.
By default, the application positions the marker on the lowest level of the trace.You can
change a marker position in several ways.
●
Enter a particular offset frequency in the input field that opens when you activate a
marker.
●
Move the marker around with the rotary knob or the cursor keys.
●
Drag the marker around using the touchscreen.
4.11.1 Marker Types
All markers can be used either as normal markers or delta markers. A normal marker
indicates the absolute signal value at the defined position in the diagram. A delta
marker indicates the value of the marker relative to the specified reference marker (by
default marker 1).
In addition, special functions can be assigned to the individual markers. The availability
of special marker functions depends on whether the measurement is performed in the
frequency or time domain.
4.11.2 Activating Markers
Only active markers are displayed in the diagram and in the marker table. Active markers are indicated by a highlighted softkey.
By default, marker 1 is active and positioned on the maximum value (peak) of trace 1
as a normal marker. If several traces are displayed, the marker is set to the maximum
value of the trace which has the lowest number and is not frozen (View mode). The
next marker to be activated is set to the frequency of the next lower level (next peak)
as a delta marker; its value is indicated as an offset to marker 1.
A marker can only be activated when at least one trace in the corresponding window is
visible. If a trace is switched off, the corresponding markers and marker functions are
also deactivated. If the trace is switched on again, the markers along with coupled
functions are restored to their original positions, provided the markers have not been
used on another trace.
User Manual 1173.9286.02 ─ 14
35
R&S®FSW-K40
Configuration
Configuration Overview
5 Configuration
Access: MODE > "Phase Noise"
When you activate a measurement channel in the Phase Noise application, a measurement for the input signal is started automatically with the default configuration. The
"Phase Noise" menu is displayed and provides access to the most important configuration functions.
Automatic refresh of preview and visualization in dialog boxes after configuration changes
The R&S FSW supports you in finding the correct measurement settings quickly and
easily - after each change in settings in dialog boxes, the preview and visualization
areas are updated immediately and automatically to reflect the changes. Thus, you can
see if the setting is appropriate or not before accepting the changes.
●
●
●
●
●
●
●
●
Configuration Overview...........................................................................................36
Default Settings for Phase Noise Measurements................................................... 37
Configuring the Frontend........................................................................................ 38
Controlling the Measurement.................................................................................. 40
Configuring the Measurement Range..................................................................... 43
Performing Measurements......................................................................................46
Configuring In- and Outputs.................................................................................... 48
Automatic Measurement Configuration...................................................................49
5.1 Configuration Overview
Throughout the measurement channel configuration, an overview of the most important
currently defined settings is provided in the "Overview". The "Overview" is displayed
when you select the "Overview" icon, which is available at the bottom of all softkey
menus.
User Manual 1173.9286.02 ─ 14
36
R&S®FSW-K40
Configuration
Default Settings for Phase Noise Measurements
In addition to the main measurement settings, the "Overview" provides quick access to
the main settings dialog boxes. The individual configuration steps are displayed in the
order of the data flow. Thus, you can easily configure an entire measurement channel
from input over processing to output and analysis by stepping through the dialog boxes
as indicated in the "Overview".
In particular, the "Overview" provides quick access to the following configuration dialog
boxes (listed in the recommended order of processing):
1. Frontend
See Chapter 5.3, "Configuring the Frontend", on page 38.
2. Measurement Control
See Chapter 5.4, "Controlling the Measurement", on page 40.
3. Phase Noise Measurement
See Chapter 5.5, "Configuring the Measurement Range", on page 43.
4. Limit Analysis
See Chapter 6.3, "Using Limit Lines", on page 58.
5. Graphical Results
See Chapter 6.1, "Configuring Graphical Result Displays", on page 51.
6. Numerical Results
See Chapter 6.2, "Configure Numerical Result Displays", on page 56.
To configure settings
► Select any button in the "Overview" to open the corresponding dialog box.
Select a setting in the channel bar (at the top of the measurement channel tab) to
change a specific setting.
Preset Channel
Select the "Preset Channel" button in the lower lefthand corner of the "Overview" to
restore all measurement settings in the current channel to their default values.
Note that the PRESET key restores the entire instrument to its default values and thus
closes all measurement channels on the R&S FSW (except for the default Spectrum
application channel)!
Remote command:
SYSTem:PRESet:CHANnel[:EXECute] on page 79
5.2 Default Settings for Phase Noise Measurements
When you enter the phase noise application for the first time, a set of parameters is
passed on from the currently active application:
●
nominal or center frequency
●
nominal or reference level
User Manual 1173.9286.02 ─ 14
37
R&S®FSW-K40
Configuration
Configuring the Frontend
●
input coupling
After initial setup, the parameters for the measurement channel are stored upon exiting
and restored upon re-entering the channel. Thus, you can switch between applications
quickly and easily.
Apart from these settings, the following default settings are activated directly after a
measurement channel has been set to the Phase Noise application, or after a channel
preset:
Table 5-1: Default settings for phase noise measurement channels
Parameter
Value
Attenuation
Auto (0 dB)
Verify frequency & level
On
Frequency & level tracking
Off
Measurement range
1 kHz ... 1 MHz
Sweep type
Normal
X axis scaling
Measurement range
Y axis scaling
20 dBc/Hz ... 120 dBc/Hz
Smoothing
1%
Smoothing type
Linear
5.3 Configuring the Frontend
Access: "Overview" > "Input / Frontend"
The "Frontend" tab of the "Measurement Settings" dialog box contains all funtions necessary to configure the frontend of the RF measurement hardware.
Functions to configure the RF input described elsewhere:
●
Chapter 5.7.1, "Input Source Configuration", on page 48
User Manual 1173.9286.02 ─ 14
38
R&S®FSW-K40
Configuration
Configuring the Frontend
Nominal Frequency....................................................................................................... 39
Nominal Level............................................................................................................... 39
Mechanical Attenuator / Value...................................................................................... 39
Coupling........................................................................................................................ 39
Preamplifier................................................................................................................... 39
Nominal Frequency
Defines the nominal frequency of the measurement.
For more information see Chapter 4.6, "Frequency Determination", on page 27.
Remote command:
[SENSe:]FREQuency:CENTer on page 92
Nominal Level
Defines the nominal level of the R&S FSW.
For more informaation see .Chapter 4.7, "Level Determination", on page 30
Remote command:
[SENSe:]POWer:RLEVel on page 93
Mechanical Attenuator / Value
Turns mechanical attenuation on and off.
If on, you can define an attenuation level in 5 dB steps.
For more information see Chapter 4.8, "Signal Attenuation", on page 30.
Remote command:
Turning manual attenuation on and off:
INPut:ATTenuation:AUTO on page 94
Defining an attenuation level:
INPut:ATTenuation on page 93
Coupling
Selects the coupling method at the RF input.
AC coupling blocks any DC voltage from the input signal. DC coupling lets DC voltage
through.
For more information refer to the data sheet.
Remote command:
INPut:COUPling on page 94
Preamplifier
If the (optional) Preamplifier hardware is installed, a preamplifier can be activated for
the RF input signal.
You can use a preamplifier to analyze signals from DUTs with low output power.
For R&S FSW26 or higher models, the input signal is amplified by 30 dB if the preamplifier is activated.
For R&S FSW8 or 13 models, the following settings are available:
"Off"
Deactivates the preamplifier.
"15 dB"
The RF input signal is amplified by about 15 dB.
User Manual 1173.9286.02 ─ 14
39
R&S®FSW-K40
Configuration
Controlling the Measurement
"30 dB"
The RF input signal is amplified by about 30 dB.
Remote command:
INPut:GAIN:STATe on page 94
INPut:GAIN[:VALue] on page 95
5.4 Controlling the Measurement
Access: "Overview" > "Measurement Control"
The "Control" tab of the "Measurement Settings" dialog box contains all funtions necessary to control the sequence of the phase noise measurement.
Verify Frequency........................................................................................................... 40
Verify Level................................................................................................................... 41
On Verify Failed............................................................................................................ 41
Frequency Tracking...................................................................................................... 41
Level Tracking...............................................................................................................41
AM Rejection.................................................................................................................42
Max Freq Drift............................................................................................................... 42
Digital PLL.....................................................................................................................42
Decimation.................................................................................................................... 42
Online I/Q...................................................................................................................... 42
Verify Frequency
Turns frequency verification on and off.
If frequency verification is on, the R&S FSW initiates the phase noise measurement
only if the frequency of the DUT is within a certain frequency tolerance range. The tolerance range is either a percentage range of the nominal frequency or a absolute deviation from the nominal frequency.
If you define both an absolute and relative tolerance, the application uses the higher
tolerance level.
For more information see Chapter 4.6, "Frequency Determination", on page 27.
Remote command:
Verify frequency:
[SENSe:]FREQuency:VERify[:STATe] on page 96
Relative tolerance:
[SENSe:]FREQuency:VERify:TOLerance:RELative on page 96
User Manual 1173.9286.02 ─ 14
40
R&S®FSW-K40
Configuration
Controlling the Measurement
Absolute tolerance:
[SENSe:]FREQuency:VERify:TOLerance:ABSolute on page 96
Verify Level
Turns level verification on and off.
If level verification is on, the R&S FSW initiates the phase noise measurement only if
the level of the DUT is within a certain level tolerance range. The tolerance range is a
level range relative to the nominal level.
For more information see Chapter 4.7, "Level Determination", on page 30.
Remote command:
Verify level:
[SENSe:]POWer:RLEVel:VERify[:STATe] on page 98
Level tolerance:
[SENSe:]POWer:RLEVel:VERify:TOLerance on page 98
On Verify Failed
Selects the way the application reacts if signal verification fails.
Takes effect on both frequency and level verification.
"Restart"
Restarts the measurement if verification has failed.
"Stop"
Stops the measurement if verification has failed.
"Run Auto All"
Starts an automatic frequency and level detection routine if verification has failed. After the new frequency and level have been set, the
measurement restarts. For more information see Chapter 5.8, "Automatic Measurement Configuration", on page 49.
Remote command:
[SENSe:]SWEep:SVFailed on page 99
Frequency Tracking
Turns frequency tracking on and off.
If on, the application tracks the frequency of the DUT during the phase noise measurement and adjusts the nominal frequency accordingly. The application adjusts the frequency after each half decade measurement.
For more information see Chapter 4.6, "Frequency Determination", on page 27.
Remote command:
[SENSe:]FREQuency:TRACk on page 95
Level Tracking
Turns level tracking on and off.
If on, the R&S FSW tracks the level of the DUT during phase noise measurements and
adjusts the nominal level accordingly. The application adjusts the level after each half
decade measurement.
For more information see Chapter 4.7, "Level Determination", on page 30.
Remote command:
[SENSe:]POWer:TRACk on page 98
User Manual 1173.9286.02 ─ 14
41
R&S®FSW-K40
Configuration
Controlling the Measurement
AM Rejection
Turns the suppression of AM noise on and off.
If on, the application suppresses the AM noise that the signal contains in order to display phase noise as pure as possible.
AM rejection is available for the I/Q sweep mode.
Remote command:
[SENSe:]REJect:AM on page 99
Max Freq Drift
Defines the minimum bandwidth or sample rate used in the signal processing to
increase the probability of capture drifting signals.
The tracking bandwidth is valid for all half decades measured in I/Q mode.
Remote command:
[SENSe:]IQ:TBW on page 98
Digital PLL
Turns an additional frequency correction based on the I/Q data on and off.
If on, the application is able to track frequency changes during the I/Q data capture that
would otherwise fall into the half decade measurement bandwidth (see Max Freq Drift).
The digital PLL works for all half decades measured in I/Q mode.
Remote command:
[SENSe:]IQ:DPLL on page 97
Decimation
Turns decimation on and off.
When you turn on decimation, the samples that have already been used for a given
half decade are resampled in lower half decades. Reusing these samples results in
lower measurement times in the lower half decades, because less samples have to be
recorded there.
To get valid results for lower offset frequencies, make sure to use an appropriate sample rate.
This feature is especially useful when you are measuring half decades with very low
offset frequencies.
Using decimation is available for the "I/Q FFT" sweep mode.
Remote command:
[SENSe:]IQ:DECimation on page 97
Online I/Q
Turns the online measurement mode for I/Q measurements on and off.
When you turn the online measurement mode on, the application records smaller
amounts of data at a time. It is thus able to process that data faster, because it does
not have to wait until the I/Q capture buffer is full, before processing the data.. The
result is that the measurement results are updated faster.
User Manual 1173.9286.02 ─ 14
42
R&S®FSW-K40
Configuration
Configuring the Measurement Range
This mode is useful to measure the phase noise at small offset frequencies, because
the small bandwidths required to measure these offset frequencies usually lead to long
measurement times (and especially when you apply averaging).
In the Half Decade Configuration Table, half decades that are measured in online
mode are highlighted in a darker shade of green (compared to the shade of green that
is used to highlight the half decades that are taken into account in the measurement).
Light green = normal I/Q mode
Dark green = online I/Q mode
The online measurement mode is available under the following conditions:
● Only half decades with a frequency offset smaller than 30 kHz can be measured in
online mode.
● The half decades that you want to measure in online mode have to be set to "I/Q
FFT" sweep mode.
● Decimation has to be turned on.
● Sweep Forward has to be turned off.
Remote command:
[SENSe:]IQ:ONLine on page 97
5.5 Configuring the Measurement Range
Access: "Overview" > "Phase Noise Meas"
The "Phase Noise" tab of the "Measurement Settings" dialog box contains all funtions
necessary to configure the measurement range for phase noise measurements, including individual range settings.
Range Start / Stop.........................................................................................................44
Sweep Forward............................................................................................................. 44
Presets.......................................................................................................................... 44
Global RBW.................................................................................................................. 44
Global Average Count...................................................................................................45
Multiplier........................................................................................................................45
Global Sweep Mode......................................................................................................45
Global I/Q Window........................................................................................................ 45
Half Decades Configuration Table................................................................................ 46
User Manual 1173.9286.02 ─ 14
43
R&S®FSW-K40
Configuration
Configuring the Measurement Range
Range Start / Stop
Defines the frequency offsets that make up the measurement range.
Note that the maximum offset you can select depends on the hardware you are using.
If a "Preamplifier" on page 39 is used, make sure the entire frequency range is covered
by the preamplifier.
Remote command:
Measurement Range Start
[SENSe:]FREQuency:STARt on page 101
Measurement Range Stop
[SENSe:]FREQuency:STOP on page 101
Sweep Forward
Selects the sweep direction. Forward and reverse sweep direction are available.
Forward sweep direction performs a measurement that begins at the smallest frequency offset you have defined. The measurement ends after the largest offset has
been reached.
Reverse sweep direction performs a measurement that begins at the largest frequency
offset you have defined. The measurement ends after the smallest offset has been
reached. The reverse sweep is the default sweep direction because the application is
able to lock on a drifting carrier frequency in that case.
Remote command:
[SENSe:]SWEep:FORWard on page 105
Presets
Selects predefined measurement settings for each individual half decade that are used
for the measurement.
If the measurement settings differ from one of the preset states, the application displays a symbol ( ) at the label.
"Fast"
Fast measurements perform one measurement in each half decade.
No averaging takes place.
"Normal"
Normal measurements use averaging for some half decades, but with
respect to measurement speed.
"Average"
Average measurements use averaging for all half decades. However,
you have to put up with slower measurement speed.
"Manual"
Manual configuration of the measurement range.
Remote command:
[SENSe:]SWEep:MODE on page 106
Global RBW
Defines the resolution bandwidth for all half decades globally.
The resulting RBW is a percentage of the start frequency of the corresponding half
decade.
If the resulting RBW is not available, the application rounds to the next available bandwidth.
User Manual 1173.9286.02 ─ 14
44
R&S®FSW-K40
Configuration
Configuring the Measurement Range
You can also change the global bandwidth with the "RBW Global" softkey in the "Bandwidth" menu.
Remote command:
[SENSe:]LIST:BWIDth[:RESolution]:RATio on page 100
Global Average Count
Defines the number of measurements that the application uses to calculate averaged
results in each half decade.
The range is 1 to 10000.
Remote command:
[SENSe:]LIST:SWEep:COUNt on page 104
Multiplier
Turns a multiplier that changes the average count in each half decade on and off.
If on, you can define a value that multiplies the number of averages currently defined
for each half decade by that value.
When you turn it off, the original averages are restored and used again.
Example:
You have three half decades:
● 1st half decade average count: 1
● 2nd half decade average count: 3
● 3rd half decade average count: 5
If you turn the multiplier on and define a value of 5, the average count changes as follows:
● 1st half decade average count: 5
● 2nd half decade average count: 15
● 3rd half decade average count: 25
Remote command:
[SENSe:]LIST:SWEep:COUNt:MULTiplier on page 105
[SENSe:]LIST:SWEep:COUNt:MULTiplier:STATe on page 105
Global Sweep Mode
Selects the analysis mode for all half decades. The sweep mode defines the way the
application processes the data.
For more information see Chapter 4.4, "Sweep Modes", on page 25.
"Normal"
Uses spectrum analyzer data for the data analysis.
"I/Q / FFT"
Uses I/Q data for the data analysis.
Remote command:
[SENSe:]LIST:BWIDth:RESolution:TYPE on page 102
Global I/Q Window
Selects the window function for all half decades.
The window function is available for I/Q analysis.
User Manual 1173.9286.02 ─ 14
45
R&S®FSW-K40
Configuration
Performing Measurements
"Blackman
Harris"
Blackman Harris window.
"Chebychev"
Chebychev window.
"Gaussian"
Gaussian window.
"Rectangular"
Rectangular window.
Remote command:
[SENSe]:LIST:IQWindow:TYPE on page 102
Half Decades Configuration Table
Contains all functionality to configure the phase noise measurement range.
"Start"
Shows the offset frequency that the half decade starts with.
"Stop"
Shows the offset frequency that the half decade stops with.
Tip: Note that double-clicking on one of the start or stop offset values
is an easy way to adjust the measurement range.
"RBW"
Selects resolution bandwidth for the half decade.
To avoid invalid measurements and long measurement times, the
availability of RBW for each half decade is limited.
"Sweep Mode"
Selects the measurement mode. The measurement mode is the way
the application analyzes the data.
●
●
Swept
I/Q / FFT
For more information see Chapter 4.4, "Sweep Modes", on page 25.
"AVG"
Defines the number of averagings that the application performs
before the results for a half decade are displayed.
"Window"
Selects the window type for a half decade.
Window functions are available for I/Q measurements.
"Meas Time"
Shows an estimation of how long the measurement of a half decade
lasts.
Remote command:
RBW:
[SENSe:]LIST:RANGe<range>:BWIDth[:RESolution] on page 103
Sweep Mode
[SENSe:]LIST:RANGe<range>:FILTer:TYPE on page 103
Averages:
[SENSe:]LIST:RANGe<range>:SWEep:COUNt on page 104
Window:
[SENSe:]LIST:RANGe<range>:IQWindow:TYPE on page 103
5.6 Performing Measurements
Access: SWEEP
The "Sweep" menu contains all functionality necessary to control and perform phase
noise measurements.
User Manual 1173.9286.02 ─ 14
46
R&S®FSW-K40
Configuration
Performing Measurements
Functions to configure the sweep described elsewhere:
●
"Multiplier" on page 45
●
"Global Average Count" on page 45
Continuous Sweep/RUN CONT.................................................................................... 47
Single Sweep/ RUN SINGLE........................................................................................ 47
Continue Single Sweep.................................................................................................47
Sweep / Average Count................................................................................................ 47
Finish Half Decade........................................................................................................48
Continuous Sweep/RUN CONT
After triggering, starts the sweep and repeats it continuously until stopped. This is the
default setting.
While the measurement is running, the "Continuous Sweep" softkey and the RUN
CONT key are highlighted. The running measurement can be aborted by selecting the
highlighted softkey or key again. The results are not deleted until a new measurement
is started.
Note: Sequencer. Furthermore, the RUN CONT key controls the Sequencer, not individual sweeps. RUN CONT starts the Sequencer in continuous mode.
For details on the Sequencer, see the R&S FSW User Manual.
Remote command:
INITiate<n>:CONTinuous on page 81
Single Sweep/ RUN SINGLE
While the measurement is running, the "Single Sweep" softkey and the RUN SINGLE
key are highlighted. The running measurement can be aborted by selecting the highlighted softkey or key again.
Note: Sequencer. Furthermore, the RUN SINGLE key controls the Sequencer, not
individual sweeps. RUN SINGLE starts the Sequencer in single mode.
If the Sequencer is off, only the evaluation for the currently displayed measurement
channel is updated.
Remote command:
INITiate<n>[:IMMediate] on page 82
Continue Single Sweep
After triggering, repeats the number of sweeps set in "Sweep Count", without deleting
the trace of the last measurement.
While the measurement is running, the "Continue Single Sweep" softkey and the RUN
SINGLE key are highlighted. The running measurement can be aborted by selecting
the highlighted softkey or key again.
Remote command:
INITiate<n>:CONMeas on page 81
Sweep / Average Count
Defines the number of sweeps to be performed in the single sweep mode. Values from
0 to 200000 are allowed. If the values 0 or 1 are set, one sweep is performed.
The sweep count is applied to all the traces in all diagrams.
User Manual 1173.9286.02 ─ 14
47
R&S®FSW-K40
Configuration
Configuring In- and Outputs
If the trace modes "Average", "Max Hold" or "Min Hold" are set, this value also determines the number of averaging or maximum search procedures.
In continuous sweep mode, if sweep count = 0 (default), averaging is performed over
10 sweeps. For sweep count =1, no averaging, maxhold or minhold operations are performed.
Remote command:
[SENSe:]SWEep:COUNt on page 84
Finish Half Decade
Aborts the measurement in the current half decade and continues measuring the subsequent half decade.
Averaged results displayed for a half decade finished prematurely are based on the
number of measurements already done.
Remote command:
[SENSe:]SWEep:FHDecade on page 84
5.7 Configuring In- and Outputs
The "In- / Output" menu contains all functionality necessary to control and perform
phase noise measurements.
For more information on configuring the input mixer see the manual of the R&S FSW.
●
●
Input Source Configuration..................................................................................... 48
External Mixer Configuration...................................................................................49
5.7.1 Input Source Configuration
Access: "Overview" > "Input / Frontend" > "Input Source Config"
The "Radio Frequency" dialog box contains functionality to configure the input source.
Note that the "Radio Frequency (On Off)" button is unavailable in the R&S FSW-K40
Coupling........................................................................................................................ 48
Input Connector.............................................................................................................48
Coupling
Selects the coupling method at the RF input.
AC coupling blocks any DC voltage from the input signal. DC coupling lets DC voltage
through.
For more information refer to the data sheet.
Remote command:
INPut:COUPling on page 94
Input Connector
Selects the input source.
User Manual 1173.9286.02 ─ 14
48
R&S®FSW-K40
Configuration
Automatic Measurement Configuration
The Phase Noise application supports the following input sources:
● RF Input
● Analog Baseband Input
The "Baseband Input I" requires option R&S FSW-B71.
Remote command:
INPut:CONNector on page 146
5.7.2 External Mixer Configuration
The "External Mixer" dialog box contains functionality to configure an external mixer
(R&S FSW-B21).
Please refer to the User Manual of the R&S FSW for a detailed description on how to
configure the external mixer.
5.8 Automatic Measurement Configuration
Access: AUTO SET
The "Auto Set" menu contains all functionality necessary to determine measurement
parameters automatically.
Adjusting all Determinable Settings Automatically (Auto All)........................................ 49
Adjusting the Center Frequency Automatically (Auto Freq).......................................... 49
Setting the Reference Level Automatically (Auto Level)............................................... 50
Adjusting all Determinable Settings Automatically (Auto All)
Activates all automatic adjustment functions for the current measurement settings.
This includes:
●
●
Auto Frequency
Auto Level
Remote command:
[SENSe:]ADJust:ALL on page 147
Adjusting the Center Frequency Automatically (Auto Freq)
The R&S FSW adjusts the center frequency automatically.
The optimum center frequency is the frequency with the highest S/N ratio in the frequency span. As this function uses the signal counter, it is intended for use with sinusoidal signals.
Remote command:
[SENSe:]ADJust:FREQuency on page 147
User Manual 1173.9286.02 ─ 14
49
R&S®FSW-K40
Configuration
Automatic Measurement Configuration
Setting the Reference Level Automatically (Auto Level)
Automatically determines a reference level which ensures that no overload occurs at
the R&S FSW for the current input data. At the same time, the internal attenuators and
the preamplifier (for analog baseband input: the full scale level) are adjusted so the signal-to-noise ratio is optimized, while signal compression and clipping are minimized.
To determine the required reference level, a level measurement is performed on the
R&S FSW.
If necessary, you can optimize the reference level further. Decrease the attenuation
level manually to the lowest possible value before an overload occurs, then decrease
the reference level in the same way.
Remote command:
[SENSe:]ADJust:LEVel on page 147
User Manual 1173.9286.02 ─ 14
50
R&S®FSW-K40
Analysis
Configuring Graphical Result Displays
6 Analysis
The application provides various means and methods to analyze and evaluate measurement results.
●
●
●
●
Configuring Graphical Result Displays....................................................................51
Configure Numerical Result Displays......................................................................56
Using Limit Lines.....................................................................................................58
Using Markers......................................................................................................... 65
6.1 Configuring Graphical Result Displays
Access: "Overview" > "Graphical Results"
The "Graphical" tab of the "Results" dialog box and the "Trace" menu contain all funtions necessary to set up and configure the graphical phase noise result displays.
●
●
Scaling the Diagram................................................................................................51
Configuring Traces..................................................................................................53
6.1.1 Scaling the Diagram
X-Axis Scope.................................................................................................................51
X-Axis Start / Stop.........................................................................................................52
Half Decade.................................................................................................................. 52
Y Axis Scaling............................................................................................................... 52
Top / Range / Bottom.................................................................................................... 52
Auto Scale Once........................................................................................................... 53
X-Axis Scope
Selects the way the application scales the horizontal axis.
"Half Decade"
The horizontal axis shows one half decade that you can select.
"Manual"
The horizontal axis shows a detail of the measurement range that you
can define freely.
"Meas Range"
The horizontal axis shows the complete measurement range.
User Manual 1173.9286.02 ─ 14
51
R&S®FSW-K40
Analysis
Configuring Graphical Result Displays
Remote command:
DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe on page 121
X-Axis Start / Stop
Defines the start and stop frequency of the horizontal axis.
Note that the displayed frequency range is a detail of the measurement range. Regardless of the displayed frequency range, the application still performs all measurement
over the measurement range you have defined.
The range depends on the measurement range. and possible increments correspond
to the half decades.
Available for a manual "X Axis Scope".
Remote command:
X-axis start:
DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt on page 121
X-axis stop:
DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP on page 121
Half Decade
Selects the half decade that is displayed.
Available if you have selected the half decade "X Axis Scope".
Remote command:
DISPlay[:WINDow]:TRACe:X[:SCALe]:HDECade on page 120
Y Axis Scaling
Selects the type of scaling for the vertical axis.
"Auto"
Automatically scales the vertical axis.
"Top & Bottom"
Allows you to set the values at the top and bottom of the vertical axis.
"Top & Range"
Allows to set the value at the top of the vertical axis and its range.
"Bottom &
Range"
Allows you to set the value at the bottom of the vertical axis and its
range.
Remote command:
Automatic scaling:
DISPlay[:WINDow]:TRACe:Y[:SCALe]:AUTO on page 122
Manual scaling:
DISPlay[:WINDow]:TRACe:Y[:SCALe]:MANual on page 122
Top / Range / Bottom
Define the top and bottom values or the range of the vertical axis.
Top defines the top values of the vertical axis. The unit is dBm/Hz.
Bottom defines the bottom value of the vertical axis. The unit is dBm/Hz.
Range defines the range of the vertical axis. The unit is dB.
The availability of the three fields depends on the type of manual "Y Axis Scaling" you
have selected.
User Manual 1173.9286.02 ─ 14
52
R&S®FSW-K40
Analysis
Configuring Graphical Result Displays
Remote command:
Top:
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel on page 123
Range:
DISPlay[:WINDow]:TRACe:Y:[:SCALe] on page 122
Bottom:
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:LOWer on page 123
Auto Scale Once
Automatically scales the vertical axis for ideal viewing.
6.1.2 Configuring Traces
Trace Offset.................................................................................................................. 53
Trace Smoothing...........................................................................................................53
Smoothing Type............................................................................................................ 53
Trace Config..................................................................................................................54
└ Traces............................................................................................................. 54
└ Quick Config................................................................................................... 54
└ Trace Export................................................................................................... 55
└ Copy Trace..................................................................................................... 55
└ Trace Math......................................................................................................56
Spur Removal / Spur Threshold....................................................................................56
Frequency Drift: Trace 1 (On Off)................................................................................. 56
Spectrum Monitor: Raw Trace / Trk Trace (On Off)...................................................... 56
Trace Offset
Defines a trace offset in dB.
The trace offset moves the trace vertically by the level you have defined.
The range is from -200 dB to 200 dB.
Remote command:
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:OFFSet on page 124
Trace Smoothing
Defines the magnitude (or aperture) of trace smoothing in percent.
The range is from 1% to 20%. The aperture takes effect on all traces that you smooth.
For more information see Chapter 4.5.3, "Trace Smoothing", on page 26.
Remote command:
DISPlay[:WINDow]:TRACe<t>:SMOothing:APERture on page 119
Smoothing Type
Selects the method that the application uses to smooth the trace.
For more information see Chapter 4.5.3, "Trace Smoothing", on page 26.
"Linear"
Converts the data to linear values before smoothing the trace.
"Logarithmic"
Smoothes the (original) logarithmic data.
User Manual 1173.9286.02 ─ 14
53
R&S®FSW-K40
Analysis
Configuring Graphical Result Displays
"Median"
Smoothes the trace based on the median value of the sample.
Remote command:
DISPlay[:WINDow]:TRACe<t>:SMOothing:TYPE on page 119
Trace Config
Opens a dialog box to configure traces.
The application supports up to 6 traces with a different setup. In the diagram each
trace has a different color.
The diagram header of the measurement window contains the trace information,
including a color map, trace mode and smoothing percentage.
Note that trace configuration is also possible in the "Trace" softkey menu available via
the TRACE key.
Traces ← Trace Config
The "Traces" tab contains functionality to configure a trace.
"Trace Selection"
The "Trace 1" to "Trace 6" buttons select a trace. If a trace is
selected, it is highlighted orange.
Note that you cannot select a trace if its trace mode is "Blank".
"Trace Mode"
Selects the trace mode for the corresponding trace.
For more information see Chapter 4.10, "Analyzing Several Traces Trace Mode", on page 33.
"Smoothing"
Turns trace smoothing for the corresponding trace on and off.
For each trace, the application allows you to select the smoothing
type and percentage.
For more information see Chapter 4.5.3, "Trace Smoothing",
on page 26 (➙ "Graphical" tab).
"Spur
Removal"
Turns spur removal on a particular trace on and off.
You can define a threshold above which a spur is detected with the
Threshold parameter.
For more information see Chapter 4.1, "Spurs and Spur Removal",
on page 22.
Remote command:
Trace mode: DISPlay[:WINDow]:TRACe<t>:MODE on page 118
Trace smoothing: DISPlay[:WINDow]:TRACe<t>:SMOothing[:STATe]
on page 119
Spur removal: DISPlay[:WINDow]:TRACe<t>:SPURs:SUPPress on page 120
Quick Config ← Trace Config
Commonly required trace settings have been predefined and can be applied very
quickly by selecting the appropriate button.
User Manual 1173.9286.02 ─ 14
54
R&S®FSW-K40
Analysis
Configuring Graphical Result Displays
Preset All Traces
Resets all traces to their default mode.
Trace 1 - 2 mode = Clear Write; Trace 3 - 6 mode = Blank
Trace 1 smoothing = On, Trace 2 - 6 smoothing = Off
Set Trace Mode
Trace 1 mode: Max Hold
Max | Avg | Min
Trace 2 mode: Average
Trace 3 mode: Min Hold
Set Trace Mode
Trace 1 mode: Max Hold
Max | ClrWrite | Min
Trace 2 mode: Clear Write
Trace 3 mode: Min Hold
Trace Export ← Trace Config
The "Trace Export" tab contains functionality to export trace data.
"Export all
traces and all
table results"
Turns the export of all measurement results (traces and numerical
results) on and off.
If on, selecting a particular trace to export in the "Trace to Export"
dropdown menu is unavailable.
"Include Instru- Includes or excludes the measurement configuration as shown in the
ment Measure- channel bar from the export.
ment Settings"
"Trace to
Export"
Selects the trace that will be exported to a file.
"Decimal Separator"
Selects the decimal separator for floating-point numerals for the
ASCII Trace export. Evaluation programs require different separators
in different languages.
"Export Trace
to ASCII File"
Opens a file selection dialog box and saves the selected trace in
ASCII format to the specified file and directory.
Remote command:
Decimal separator:
FORMat:DEXPort:DSEParator on page 124
Export trace to ASCII file:
MMEMory:STORe<n>:TRACe on page 125
Selecting a trace:
FORMat:DEXPort:TRACes on page 124
Export the header:
FORMat:DEXPort:HEADer on page 124
Copy Trace ← Trace Config
Access: "Overview" > "Analysis" > "Traces" > "Copy Trace"
Or: TRACE > "Copy Trace"
Copies trace data to another trace.
The first group of buttons (labeled "Trace 1" to "Trace 6") selects the source trace. The
second group of buttons (labeled "Copy to Trace 1" to "Copy to Trace 6") selects the
destination.
User Manual 1173.9286.02 ─ 14
55
R&S®FSW-K40
Analysis
Configure Numerical Result Displays
Remote command:
TRACe<n>:COPY on page 126
Trace Math ← Trace Config
The "Trace Math" tab contains functionality to control trace mathematics.
"State"
Turns trace mathematics on and off.
"Expression"
Selects the mathematical operation.
Remote command:
State:
CALCulate<n>:MATH:STATe on page 118
Expression:
CALCulate<n>:MATH[:EXPression][:DEFine] on page 118
Spur Removal / Spur Threshold
Turns spur removal for all traces on and off and defines the threshold for spur removal.
For more information see Chapter 4.1, "Spurs and Spur Removal", on page 22.
Note that you can also remove spurs for individual traces in the "Trace Config" dialog
box.
Remote command:
Turn spur suppression on and off:
[SENSe:]SPURs:SUPPression on page 125
Set the threshold:
[SENSe:]SPURs:THReshold on page 126
Frequency Drift: Trace 1 (On Off)
Turns the trace displayed in the Frequency Drift result display on and off.
Spectrum Monitor: Raw Trace / Trk Trace (On Off)
Turns the traces displayed in the Spectrum Monitor result display on and off.
The "Raw Trace (On Off)" softkey controls the yellow trace.
The "Trk Trace (On Off)" softkey controls the blue trace.
6.2 Configure Numerical Result Displays
Access: "Overview" > "Numerical Results"
The "Numerical" tab of the "Results" dialog box contains all funtions necessary to set
up and configure the numerical phase noise result displays.
User Manual 1173.9286.02 ─ 14
56
R&S®FSW-K40
Analysis
Configure Numerical Result Displays
6.2.1 Configuring Residual Noise Measurements
Meas Range..................................................................................................................57
User Range................................................................................................................... 57
Meas Range
Turns the integration of the entire measurement range for residual noise calculations
on and off.
The range defined here is applied to all traces.
"On"
The application calculates the residual noise over the entire measurement range.
"Off"
The application calculates the residual noise over a customized
range.
The input fields next to the "On/Off" control become available to
define a customized integration range. The application shows two red
lines ("EL1" and "EL2") in the graphical result display to indicate the
custom range.
Remote command:
Turn customized range on and off:
CALCulate<n>:EVALuation[:STATe] on page 128
Define start point of custom range:
CALCulate<n>:EVALuation:STARt on page 127
Define end point of custom range:
CALCulate<n>:EVALuation:STOP on page 128
User Range
Defines a custom range for residual noise calculations. You have to assign a user
range to a particular trace.
In the default state, user ranges are inactive. "None" is selected in the dropdown
menu. If you assign the user range to a trace by selecting one of the traces from the
dropdown menu, the input fields next to the trace selection become active. In these
fields, you can define a start and stop offset frequency.
User Manual 1173.9286.02 ─ 14
57
R&S®FSW-K40
Analysis
Using Limit Lines
Remote command:
Selecting a trace:
CALCulate<n>:EVALuation:USER<range>:TRACe on page 129
Define start frequency of user range:
CALCulate<n>:EVALuation:USER<range>:STARt on page 129
Define stop frequency of user range:
CALCulate<n>:EVALuation:USER<range>:STOP on page 129
6.2.2 Configuring Spot Noise Measurements
On All Decade Edges....................................................................................................58
On User Defined Offsets / Offset Frequency................................................................ 58
On All Decade Edges
Turns the calculation of spot noise on all 10x offset frequencies on and off.
Remote command:
Turn on and off spot noise calculation on 10x offset frequencies:
CALCulate<n>:SNOise:DECades[:STATe] on page 133
Querying spot noise results on 10x offset frequencies:
CALCulate<n>:SNOise:DECades:X? on page 133
CALCulate<n>:SNOise:DECades:Y? on page 133
On User Defined Offsets / Offset Frequency
Turns custom spot noise frequencies on and off.
If on, the "Offset Frequency" input fields become available. You can measure the spot
noise for up to five custom offset frequencies. If active, the application adds those
spots to the spot noise table.
Remote command:
Turning spot noise marker on and off:
CALCulate<n>:SNOise<m>:STATe on page 134
CALCulate<n>:SNOise:AOFF on page 132
Positioning spot noise markers:
CALCulate<n>:SNOise<m>:X on page 134
Querying custom spot noise results:
CALCulate<n>:SNOise<m>:Y? on page 135
6.3 Using Limit Lines
Access: "Overview" > "Limit Analysis"
The "Limits" tab of the "Results" dialog box contains all funtions necessary to set up
and configure limit lines.
User Manual 1173.9286.02 ─ 14
58
R&S®FSW-K40
Analysis
Using Limit Lines
6.3.1 Using Phase Noise Limit Lines
Phase Noise Limit Line................................................................................................. 59
Selected Traces............................................................................................................ 59
Noise Floor....................................................................................................................59
Range x - Range y........................................................................................................ 59
Copy to User Limit Line.................................................................................................60
Phase Noise Limit Line
Selects the shape of the phase noise limit line.
For more information see Chapter 4.9, "Using Limit Lines", on page 31.
"None"
No limit line.
"Noise floor
and x Ranges"
Limit line defined by the noise floor and x corner frequencies and
slopes. The application supports up to 5 ranges.
Remote command:
CALCulate:PNLimit:TYPE on page 108
Selected Traces
Selects the trace(s) to assign a phase noise limit line to.
For more information see Chapter 4.9, "Using Limit Lines", on page 31.
Remote command:
CALCulate:PNLimit:TRACe on page 108
Noise Floor
Defines the noise floor level in dBm/Hz of the DUT.
For more information see Chapter 4.9, "Using Limit Lines", on page 31.
Remote command:
CALCulate:PNLimit:NOISe on page 107
Range x - Range y
Defines the corner frequencies and slope for a particular segment of phase noise limit
lines.
The slope defines the slope of the limit line segment to the left of the corner frequency.
User Manual 1173.9286.02 ─ 14
59
R&S®FSW-K40
Analysis
Using Limit Lines
For more information see Chapter 4.9, "Using Limit Lines", on page 31.
Remote command:
Corner frequencies:
CALCulate:PNLimit:FC5 on page 107
Slope:
CALCulate:PNLimit:SLOPe<segment> on page 109
Copy to User Limit Line
Creates a new user limit line from the data of a phase noise limit line.
The file is stored in the default folder for user limit lines. You can load and edit the limit
line via the "Select Limit Line" dialog box. For more information see "Select Limit Line"
on page 60.
Remote command:
CALCulate:PNLimit:COPY<k> on page 106
6.3.2 Selecting Standard Limit Lines
Access: "Overview" > "Limit Analysis" > "Line Config"
Select Limit Line............................................................................................................60
└ Name.............................................................................................................. 61
└ Unit..................................................................................................................61
└ Compatible......................................................................................................61
└ Visible............................................................................................................. 61
└ Check Traces..................................................................................................61
└ Comment........................................................................................................ 62
└ View Filter....................................................................................................... 62
└ New / Edit / Copy To....................................................................................... 62
└ Delete..............................................................................................................62
└ Disable All Lines............................................................................................. 62
Select Limit Line
The "Select Limit Line" dialog box contains functionality to include standard limit lines
in the measurement.
The dialog box consists of a table that shows all available limit lines and their characteristics and a few buttons to manage individual limit lines.
User Manual 1173.9286.02 ─ 14
60
R&S®FSW-K40
Analysis
Using Limit Lines
Name ← Select Limit Line
Shows the name of the limit line.
Unit ← Select Limit Line
Shows the unit of the limit line.
Compatible ← Select Limit Line
Shows if the limit line is compatible to the current measurement setup or not.
"Yes"
You can use the limit line because it is compatible to the current measurement setup.
"No"
You cannot use the limit line because it is compatible to the current
measurement setup.
Visible ← Select Limit Line
Displays a limit line in the diagram area.
You can display up to eight limit lines at the same time.
Remote command:
Display a limit line:
Lower limit: CALCulate<n>:LIMit<k>:LOWer:STATe on page 112
Upper limit: CALCulate<n>:LIMit<k>:UPPer:STATe on page 113
Query all visible limit lines:
CALCulate<n>:LIMit<k>:ACTive? on page 109
Check Traces ← Select Limit Line
Turns the limit check for a particular trace on and off.
Remote command:
Assign a limit line to a particular trace:
CALCulate<n>:LIMit<k>:TRACe on page 112
Activate the limit check:
CALCulate<n>:LIMit<k>:STATe on page 112
Querying limit check results:
CALCulate<n>:LIMit<k>:FAIL? on page 111
User Manual 1173.9286.02 ─ 14
61
R&S®FSW-K40
Analysis
Using Limit Lines
Comment ← Select Limit Line
Shows the comment of the selected limit line. If the limit line has no comment, this field
stays empty.
View Filter ← Select Limit Line
Turns filter for the list of limit lines on and off.
By default, the list includes all limit lines that are stored on the R&S FSW.
"Show Compatible"
Filters the list of limit lines by compatibility.
If on, the list includes only those limit lines that are compatible to the
current measurement setup.
"Show Lines
For PNoise"
Filters the list of limit lines by compatibility to phase noise measurements.
If on, the list includes only those limit lines that are compatible to
phase noise measurements.
New / Edit / Copy To ← Select Limit Line
All three buttons open the "Edit Limit Line" dialog box to create or edit limit lines.
When you use the "New" button, the dialog box contains no data.
When you use the "Edit" button, the dialog box contains the data of the previously
selected limit line.
When you use the "Copy To" button, the dialog box also contains a copy the data of
the previously selected limit line.
Remote command:
New:
CALCulate<n>:LIMit<k>:NAME on page 111
Copy:
CALCulate<n>:LIMit<k>:COPY on page 110
Delete ← Select Limit Line
Deletes the selected limit line.
Remote command:
CALCulate<n>:LIMit<k>:DELete on page 110
Disable All Lines ← Select Limit Line
Turns all active limit lines off.
6.3.3 Creating and Editing Standard Limit Lines
Access: "Overview" > "Limit Analysis" > "Line Config" > "New" / "Edit" > "Copy To"
Edit Limit Line................................................................................................................63
└ Name.............................................................................................................. 63
└ Comment........................................................................................................ 63
└ X-Axis..............................................................................................................63
└ Y-Axis..............................................................................................................64
└ Data Points..................................................................................................... 64
└ Insert Value.....................................................................................................64
User Manual 1173.9286.02 ─ 14
62
R&S®FSW-K40
Analysis
Using Limit Lines
└
└
└
└
Delete Value................................................................................................... 64
Shift X............................................................................................................. 64
Shift Y............................................................................................................. 64
Save................................................................................................................64
Edit Limit Line
The "Edit Limit Line" dialog box contains functionality to describe the shape of a limit
line.
Because limit lines have to meet certain conditions for phase noise measurements, the
availability of parameters is limited.
Name ← Edit Limit Line
Defines the name of a limit line.
Remote command:
CALCulate<n>:LIMit<k>:NAME on page 111
Comment ← Edit Limit Line
Defines a comment for the limit line.
A comment is not mandatory.
Remote command:
CALCulate<n>:LIMit<k>:COMMent on page 114
X-Axis ← Edit Limit Line
Defines the characteristics of the horizontal axis.
The characteristics consist of the unit, the scaling and the type of values.
In the Phase Noise application, the unit for the horizontal axis is always Hz. The scaling can either be logarithmic or linear
"Unit"
In the Phase Noise application, the unit is always Hz.
"Scaling"
In the Phase Noise application, the scaling of the horizontal axis is
always logarithmic.
"Type of Values"
The type of values can be absolute values or relative to the nominal
frequency.
User Manual 1173.9286.02 ─ 14
63
R&S®FSW-K40
Analysis
Using Limit Lines
Remote command:
Type of values:
CALCulate<n>:LIMit<k>:LOWer:MODE on page 115
CALCulate<n>:LIMit<k>:UPPer:MODE on page 116
Y-Axis ← Edit Limit Line
Defines the characteristics of the vertical axis.
The characteristics consist of the unit, the type of values and the usage of the line.
"Unit"
In the Phase Noise application, the unit is always dBc/Hz.
"Type of Values"
In the Phase Noise application, the type of values is always absolute.
"Line usage"
Selects if the limit line is used as an upper or lower limit line.
Data Points ← Edit Limit Line
The data points define the shape of the limit line. A limit line consists of at least 2 data
points and a maximum of 200 data points.
A data point is defined by its position in horizontal ("Position" column) and vertical
direction ("Value" column). The position of the data points have to be in ascending
order.
Remote command:
Horizontal data (position):
CALCulate<n>:LIMit<k>:CONTrol[:DATA] on page 114
Vertical data (value):
Lower limit: CALCulate<n>:LIMit<k>:LOWer[:DATA] on page 115
Upper limit: CALCulate<n>:LIMit<k>:UPPer[:DATA] on page 116
Insert Value ← Edit Limit Line
Insert a new limit line data point below the selected data point.
Delete Value ← Edit Limit Line
Deletes the selected limit line data point.
Shift X ← Edit Limit Line
Shifts each data point horizontally by a particular amount.
Remote command:
CALCulate<n>:LIMit<k>:CONTrol:SHIFt on page 114
Shift Y ← Edit Limit Line
Shifts each data point vertically by a particular amount.
Remote command:
Lower limit: CALCulate<n>:LIMit<k>:LOWer:SHIFt on page 116
Upper limit: CALCulate<n>:LIMit<k>:UPPer:SHIFt on page 117
Save ← Edit Limit Line
Saves the limit line or the changes you have made to a limit line.
User Manual 1173.9286.02 ─ 14
64
R&S®FSW-K40
Analysis
Using Markers
6.4 Using Markers
Access (marker position): MKR > "Marker Config" > "Markers"
Access (marker settings): MKR > "Marker Config" > "Marker Settings"
The "Marker Configuration" dialog box and the "Marker" menu contain all functionality
necessary to control markers.
The "Marker Configuration" dialog box consists of two tabs.
The "Markers" tab contains functionlity to define characteristics for each marker.
The "Marker Settings" tab contains general marker functionality.
Marker 1 ... Marker x..................................................................................................... 65
Marker Type.................................................................................................................. 66
Reference Marker......................................................................................................... 66
Assigning the Marker to a Trace................................................................................... 66
Marker Zoom.................................................................................................................66
All Markers Off.............................................................................................................. 66
Marker Table Display.................................................................................................... 67
Marker Info.................................................................................................................... 67
Marker 1 ... Marker x
Selects and turns the corresponding marker on and off.
Turning on a marker also opens an input field to define the horizontal position of the
marker.
In the "Marker Configuration" dialog box, you can also define the horizontal position of
each marker ("x-value").
By default, the first marker you turn on is a normal marker, all others are delta markers.
Remote command:
CALCulate<n>:MARKer<m>[:STATe] on page 140
CALCulate<n>:DELTamarker<m>[:STATe] on page 143
User Manual 1173.9286.02 ─ 14
65
R&S®FSW-K40
Analysis
Using Markers
Marker Type
Toggles the marker type.
The type for marker 1 is always "Normal", the type for delta marker 1 is always "Delta".
These types cannot be changed.
Note: If normal marker 1 is the active marker, switching the "Mkr Type" activates an
additional delta marker 1. For any other marker, switching the marker type does not
activate an additional marker, it only switches the type of the selected marker.
"Normal"
A normal marker indicates the absolute value at the defined position
in the diagram.
"Delta"
A delta marker defines the value of the marker relative to the specified reference marker (marker 1 by default).
Remote command:
CALCulate<n>:MARKer<m>[:STATe] on page 140
CALCulate<n>:DELTamarker<m>[:STATe] on page 143
Reference Marker
Defines a marker as the reference marker which is used to determine relative analysis
results (delta marker values).
Remote command:
CALCulate<n>:DELTamarker<m>:MREF on page 143
Assigning the Marker to a Trace
The "Trace" setting assigns the selected marker to an active trace. The trace determines which value the marker shows at the marker position. If the marker was previously assigned to a different trace, the marker remains on the previous frequency or
time, but indicates the value of the new trace.
If a trace is turned off, the assigned markers and marker functions are also deactivated.
Remote command:
CALCulate<n>:MARKer<m>:TRACe on page 141
Marker Zoom
Turns the marker zoom on and off.
The marker zoom magnifies the diagram area around marker 1 by a certain factor.
Turning on the zoom also opens an input field to define the zoom factor.
Remote command:
Turning on the zoom:
DISPlay[:WINDow:]ZOOM[:STATe] on page 146
Defining the zoom factor:
CALCulate:MARKer:FUNCtion:ZOOM on page 146
All Markers Off
Deactivates all markers in one step.
Remote command:
CALCulate<n>:MARKer<m>:AOFF on page 140
User Manual 1173.9286.02 ─ 14
66
R&S®FSW-K40
Analysis
Using Markers
Marker Table Display
Defines how the marker information is displayed.
"On"
Displays the marker information in a table in a separate area beneath
the diagram.
"Off"
Displays the marker information within the diagram area. No separate
marker table is displayed.
"Auto"
(Default) Up to two markers are displayed in the diagram area. If
more markers are active, the marker table is displayed automatically.
Remote command:
DISPlay:MTABle on page 145
Marker Info
Turns the marker information displayed in the diagram on and off.
Remote command:
DISPlay:MINFo[:STAT] on page 145
User Manual 1173.9286.02 ─ 14
67
R&S®FSW-K40
How to Configure Phase Noise Measurements
Customizing the Measurement Range
7 How to Configure Phase Noise Measurements
7.1 Performing a Basic Phase Noise Measurement
1. In the Spectrum application, define the center frequency of the DUT.
2. Enter the "Phase Noise" application.
The R&S FSW-K40 starts the measurement with the default configuration. The
default configuration defines most settings automatically.
If you need any custom configuration, define them after entering the Phase Noise
application.
3. Layout the display as required via the SmartGrid.
4. Open the "Overview" dialog box to configure the measurement.
5. Configure the frontend (frequency, level etc.) via the "Frontend" dialog box.
6. Define the measurement range via the "Phase Noise" dialog box.
7. Turn on frequency and level tracking via the "Control" dialog box.
8. Run a single sweep.
9. Turn on a marker and read out the results.
10. Read out the residual noise over the measurement range.
11. Customize a residual noise range and read out the results.
12. Freeze trace 1 and 2 (trace mode: View).
13. Turn on trace 3 and 4 (trace mode: Clear/Write).
14. Switch the measurement mode to "IQ FFT" in the "Phase Noise" dialog box.
15. Repeat the measurement.
7.2 Customizing the Measurement Range
The application provides several ways to customize. Each method features a different
level of details you can define.
1. Open the "Phase Noise" configuration via the "Overview" dialog box or the "Meas
Config" softkey menu.
2. Define the frequency offset range you'd like to measure in the corresponding fields.
User Manual 1173.9286.02 ─ 14
68
R&S®FSW-K40
How to Configure Phase Noise Measurements
Customizing the Measurement Range
3. Select the "Sweep Type".
a) Select sweep types "Fast", "Normal" or "Averaged" for automatic measurement
configuration.
For a custom configuration, proceed to set up each measurement parameter separately.
4. Define the "RBW", number of "Averages", sweep "Mode" and "I/Q Window" function.
a) Define the parameters globally for all (half) decades covered by the measurement range.
b) Define the parameters for each individual (half) decade covered by the measurement range in the "Half Decade Configuration Table".
User Manual 1173.9286.02 ─ 14
69
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Common Suffixes
8 Remote Control Commands for Phase
Noise Measurements
The following remote control commands are required to configure and perform phase
noise measurements in a remote environment. The R&S FSW must already be set up
for remote operation in a network as described in the base unit manual.
Universal functionality
Note that basic tasks that are also performed in the base unit in the same way are not
described here. For a description of such tasks, see the R&S FSW User Manual.
In particular, this includes:
●
Managing Settings and Results, i.e. storing and loading settings and result data.
●
Basic instrument configuration, e.g. checking the system configuration, customizing
the screen layout, or configuring networks and remote operation.
●
Using the common status registers (specific status registers for Pulse measurements are not used).
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
Common Suffixes....................................................................................................70
Introduction............................................................................................................. 71
Controlling the Phase Noise Measurement Channel.............................................. 76
Performing Measurements......................................................................................80
Configuring the Result Display................................................................................85
Configuring the Frontend........................................................................................ 92
Controlling the Measurement.................................................................................. 95
Configuring the Measurement Range..................................................................... 99
Using Limit Lines...................................................................................................106
Graphical Display of Phase Noise Results............................................................117
Configure Numerical Result Displays....................................................................127
Using Markers....................................................................................................... 140
Configuring In- and Outputs.................................................................................. 146
Automatic Measurement Configuration.................................................................147
Using the Status Register..................................................................................... 148
Remote Control Example Scripts.......................................................................... 154
8.1 Common Suffixes
In the R&S FSW Phase Noise Measurement application, the following common suffixes are used in remote commands:
User Manual 1173.9286.02 ─ 14
70
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Introduction
Table 8-1: Common suffixes used in remote commands in the R&S FSW Phase Noise Measurement
application
Suffix
Value range
Description
<m>
1 to 16
Marker
<n>
1 to 16
Window (in the currently selected measurement channel)
<t>
1 to 4
Trace
<k>
1 to 8
Limit line
8.2 Introduction
Commands are program messages that a controller (e.g. a PC) sends to the instrument or software. They operate its functions ('setting commands' or 'events') and
request information ('query commands'). Some commands can only be used in one
way, others work in two ways (setting and query). If not indicated otherwise, the commands can be used for settings and queries.
The syntax of a SCPI command consists of a header and, in most cases, one or more
parameters. To use a command as a query, you have to append a question mark after
the last header element, even if the command contains a parameter.
A header contains one or more keywords, separated by a colon. Header and parameters are separated by a "white space" (ASCII code 0 to 9, 11 to 32 decimal, e.g. blank).
If there is more than one parameter for a command, these are separated by a comma
from one another.
Only the most important characteristics that you need to know when working with SCPI
commands are described here. For a more complete description, refer to the User
Manual of the R&S FSW.
Remote command examples
Note that some remote command examples mentioned in this general introduction may
not be supported by this particular application.
8.2.1 Conventions used in Descriptions
Note the following conventions used in the remote command descriptions:
●
Command usage
If not specified otherwise, commands can be used both for setting and for querying
parameters.
If a command can be used for setting or querying only, or if it initiates an event, the
usage is stated explicitly.
●
Parameter usage
If not specified otherwise, a parameter can be used to set a value and it is the
result of a query.
Parameters required only for setting are indicated as Setting parameters.
User Manual 1173.9286.02 ─ 14
71
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Introduction
Parameters required only to refine a query are indicated as Query parameters.
Parameters that are only returned as the result of a query are indicated as Return
values.
●
Conformity
Commands that are taken from the SCPI standard are indicated as SCPI confirmed. All commands used by the R&S FSW follow the SCPI syntax rules.
●
Asynchronous commands
A command which does not automatically finish executing before the next command starts executing (overlapping command) is indicated as an Asynchronous
command.
●
Reset values (*RST)
Default parameter values that are used directly after resetting the instrument (*RST
command) are indicated as *RST values, if available.
●
Default unit
This is the unit used for numeric values if no other unit is provided with the parameter.
●
Manual operation
If the result of a remote command can also be achieved in manual operation, a link
to the description is inserted.
8.2.2 Long and Short Form
The keywords have a long and a short form. You can use either the long or the short
form, but no other abbreviations of the keywords.
The short form is emphasized in upper case letters. Note however, that this emphasis
only serves the purpose to distinguish the short from the long form in the manual. For
the instrument, the case does not matter.
Example:
SENSe:FREQuency:CENTer is the same as SENS:FREQ:CENT.
8.2.3 Numeric Suffixes
Some keywords have a numeric suffix if the command can be applied to multiple
instances of an object. In that case, the suffix selects a particular instance (e.g. a measurement window).
Numeric suffixes are indicated by angular brackets (<n>) next to the keyword.
If you don't quote a suffix for keywords that support one, a 1 is assumed.
Example:
DISPlay[:WINDow<1...4>]:ZOOM:STATe enables the zoom in a particular measurement window, selected by the suffix at WINDow.
DISPlay:WINDow4:ZOOM:STATe ON refers to window 4.
User Manual 1173.9286.02 ─ 14
72
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Introduction
8.2.4 Optional Keywords
Some keywords are optional and are only part of the syntax because of SCPI compliance. You can include them in the header or not.
Note that if an optional keyword has a numeric suffix and you need to use the suffix,
you have to include the optional keyword. Otherwise, the suffix of the missing keyword
is assumed to be the value 1.
Optional keywords are emphasized with square brackets.
Example:
Without a numeric suffix in the optional keyword:
[SENSe:]FREQuency:CENTer is the same as FREQuency:CENTer
With a numeric suffix in the optional keyword:
DISPlay[:WINDow<1...4>]:ZOOM:STATe
DISPlay:ZOOM:STATe ON enables the zoom in window 1 (no suffix).
DISPlay:WINDow4:ZOOM:STATe ON enables the zoom in window 4.
8.2.5 Alternative Keywords
A vertical stroke indicates alternatives for a specific keyword. You can use both keywords to the same effect.
Example:
[SENSe:]BANDwidth|BWIDth[:RESolution]
In the short form without optional keywords, BAND 1MHZ would have the same effect
as BWID 1MHZ.
8.2.6 SCPI Parameters
Many commands feature one or more parameters.
If a command supports more than one parameter, these are separated by a comma.
Example:
LAYout:ADD:WINDow Spectrum,LEFT,MTABle
Parameters may have different forms of values.
●
●
●
●
●
Numeric Values.......................................................................................................74
Boolean...................................................................................................................74
Character Data........................................................................................................75
Character Strings.................................................................................................... 75
Block Data...............................................................................................................75
User Manual 1173.9286.02 ─ 14
73
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Introduction
8.2.6.1
Numeric Values
Numeric values can be entered in any form, i.e. with sign, decimal point or exponent. In
case of physical quantities, you can also add the unit. If the unit is missing, the command uses the basic unit.
Example:
with unit: SENSe:FREQuency:CENTer 1GHZ
without unit: SENSe:FREQuency:CENTer 1E9 would also set a frequency of 1 GHz.
Values exceeding the resolution of the instrument are rounded up or down.
If the number you have entered is not supported (e.g. in case of discrete steps), the
command returns an error.
Instead of a number, you can also set numeric values with a text parameter in special
cases.
●
MIN/MAX
Defines the minimum or maximum numeric value that is supported.
●
DEF
Defines the default value.
●
UP/DOWN
Increases or decreases the numeric value by one step. The step size depends on
the setting. In some cases you can customize the step size with a corresponding
command.
Querying numeric values
When you query numeric values, the system returns a number. In case of physical
quantities, it applies the basic unit (e.g. Hz in case of frequencies). The number of digits after the decimal point depends on the type of numeric value.
Example:
Setting: SENSe:FREQuency:CENTer 1GHZ
Query: SENSe:FREQuency:CENTer? would return 1E9
In some cases, numeric values may be returned as text.
8.2.6.2
●
INF/NINF
Infinity or negative infinity. Represents the numeric values 9.9E37 or -9.9E37.
●
NAN
Not a number. Represents the numeric value 9.91E37. NAN is returned in case of
errors.
Boolean
Boolean parameters represent two states. The "ON" state (logically true) is represented by "ON" or a numeric value 1. The "OFF" state (logically untrue) is represented by
"OFF" or the numeric value 0.
User Manual 1173.9286.02 ─ 14
74
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Introduction
Querying boolean parameters
When you query boolean parameters, the system returns either the value 1 ("ON") or
the value 0 ("OFF").
Example:
Setting: DISPlay:WINDow:ZOOM:STATe ON
Query: DISPlay:WINDow:ZOOM:STATe? would return 1
8.2.6.3
Character Data
Character data follows the syntactic rules of keywords. You can enter text using a short
or a long form. For more information see Chapter 8.2.2, "Long and Short Form",
on page 72.
Querying text parameters
When you query text parameters, the system returns its short form.
Example:
Setting: SENSe:BANDwidth:RESolution:TYPE NORMal
Query: SENSe:BANDwidth:RESolution:TYPE? would return NORM
8.2.6.4
Character Strings
Strings are alphanumeric characters. They have to be in straight quotation marks. You
can use a single quotation mark ( ' ) or a double quotation mark ( " ).
Example:
INSTRument:DELete 'Spectrum'
8.2.6.5
Block Data
Block data is a format which is suitable for the transmission of large amounts of data.
The ASCII character # introduces the data block. The next number indicates how many
of the following digits describe the length of the data block. In the example the 4 following digits indicate the length to be 5168 bytes. The data bytes follow. During the transmission of these data bytes all end or other control signs are ignored until all bytes are
transmitted. #0 specifies a data block of indefinite length. The use of the indefinite format requires an NL^END message to terminate the data block. This format is useful
when the length of the transmission is not known or if speed or other considerations
prevent segmentation of the data into blocks of definite length.
User Manual 1173.9286.02 ─ 14
75
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Phase Noise Measurement Channel
8.3 Controlling the Phase Noise Measurement Channel
The following commands are necessary to control the measurement channel.
INSTrument:CREate:DUPLicate........................................................................................ 76
INSTrument:CREate[:NEW].............................................................................................. 76
INSTrument:CREate:REPLace.......................................................................................... 77
INSTrument:DELete......................................................................................................... 77
INSTrument:LIST?........................................................................................................... 77
INSTrument:REName.......................................................................................................79
INSTrument[:SELect]........................................................................................................79
SYSTem:PRESet:CHANnel[:EXECute].............................................................................. 79
INSTrument:CREate:DUPLicate
This command duplicates the currently selected measurement channel, i.e creates a
new measurement channel of the same type and with the identical measurement settings. The name of the new channel is the same as the copied channel, extended by a
consecutive number (e.g. "IQAnalyzer" -> "IQAnalyzer2").
The channel to be duplicated must be selected first using the INST:SEL command.
Example:
INST:SEL 'IQAnalyzer'
INST:CRE:DUPL
Duplicates the channel named 'IQAnalyzer' and creates a new
measurement channel named 'IQAnalyzer2'.
Usage:
Event
INSTrument:CREate[:NEW] <ChannelType>, <ChannelName>
This command adds an additional measurement channel.
The number of measurement channels you can configure at the same time depends on
available memory.
Parameters:
<ChannelType>
Channel type of the new channel.
For a list of available channel types see INSTrument:LIST?
on page 77.
<ChannelName>
String containing the name of the channel. The channel name is
displayed as the tab label for the measurement channel.
Note: If the specified name for a new channel already exists, the
default name, extended by a sequential number, is used for the
new channel (see INSTrument:LIST? on page 77).
Example:
INST:CRE IQ, 'IQAnalyzer2'
Adds an additional I/Q Analyzer channel named "IQAnalyzer2".
User Manual 1173.9286.02 ─ 14
76
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Phase Noise Measurement Channel
INSTrument:CREate:REPLace <ChannelName1>,<ChannelType>,<ChannelName2>
This command replaces a measurement channel with another one.
Setting parameters:
<ChannelName1>
String containing the name of the measurement channel you
want to replace.
<ChannelType>
Channel type of the new channel.
For a list of available channel types see INSTrument:LIST?
on page 77.
<ChannelName2>
String containing the name of the new channel.
Note: If the specified name for a new channel already exists, the
default name, extended by a sequential number, is used for the
new channel (see INSTrument:LIST? on page 77).
Example:
INST:CRE:REPL 'IQAnalyzer2',IQ,'IQAnalyzer'
Replaces the channel named 'IQAnalyzer2' by a new measurement channel of type 'IQ Analyzer' named 'IQAnalyzer'.
Usage:
Setting only
INSTrument:DELete <ChannelName>
This command deletes a measurement channel.
If you delete the last measurement channel, the default "Spectrum" channel is activated.
Parameters:
<ChannelName>
String containing the name of the channel you want to delete.
A measurement channel must exist in order to be able delete it.
Example:
INST:DEL 'IQAnalyzer4'
Deletes the channel with the name 'IQAnalyzer4'.
Usage:
Event
INSTrument:LIST?
This command queries all active measurement channels. This is useful in order to
obtain the names of the existing measurement channels, which are required in order to
replace or delete the channels.
Return values:
<ChannelType>,
<ChannelName>
User Manual 1173.9286.02 ─ 14
For each channel, the command returns the channel type and
channel name (see tables below).
Tip: to change the channel name, use the INSTrument:
REName command.
77
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Phase Noise Measurement Channel
Example:
INST:LIST?
Result for 3 measurement channels:
'ADEM','Analog Demod','IQ','IQ
Analyzer','IQ','IQ Analyzer2'
Usage:
Query only
Table 8-2: Available measurement channel types and default channel names in Signal and Spectrum
Analyzer mode
Application
<ChannelType>
Parameter
Default Channel Name*)
Spectrum
SANALYZER
Spectrum
1xEV-DO BTS (R&S FSW-K84)
BDO
1xEV-DO BTS
1xEV-DO MS (R&S FSW-K85)
MDO
1xEV-DO MS
3GPP FDD BTS (R&S FSW-K72)
BWCD
3G FDD BTS
3GPP FDD UE (R&S FSW-K73)
MWCD
3G FDD UE
802.11ad (R&S FSW-K95)
WIGIG
802.11ad
Amplifier Measurements (R&S FSW-K18)
AMPLifier
Amplifier
Analog Demodulation (R&S FSW-K7)
ADEM
Analog Demod
Avionics (R&S FSW-K15)
AVIonics
Avionics
cdma2000 BTS (R&S FSW-K82)
BC2K
CDMA2000 BTS
cdma2000 MS (R&S FSW-K83)
MC2K
CDMA2000 MS
DOCSIS 3.1 (R&S FSW-K192/193)
DOCSis
DOCSIS 3.1
GSM (R&S FSW-K10)
GSM
GSM
I/Q Analyzer
IQ
IQ Analyzer
LTE (R&S FSW-K10x)
LTE
LTE
Multi-Carrier Group Delay (R&S FSW-K17)
MCGD
MC Group Delay
Noise (R&S FSW-K30)
NOISE
Noise
Phase Noise (R&S FSW-K40)
PNOISE
Phase Noise
Pulse (R&S FSW-K6)
PULSE
Pulse
Real-Time Spectrum (R&S FSW-B160R/K160RE)
RTIM
Real-Time Spectrum
Spurious Measurements (R&S FSW-K50)
SPUR
Spurious
TD-SCDMA BTS (R&S FSW-K76)
BTDS
TD-SCDMA BTS
TD-SCDMA UE (R&S FSW-K77)
MTDS
TD-SCDMA UE
Transient Analysis (R&S FSW-K60)
TA
Transient Analysis
*) the default channel name is also listed in the table. If the specified name for a new channel already
exists, the default name, extended by a sequential number, is used for the new channel.
User Manual 1173.9286.02 ─ 14
78
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Phase Noise Measurement Channel
Application
<ChannelType>
Parameter
Default Channel Name*)
VSA (R&S FSW-K70)
DDEM
VSA
WLAN (R&S FSW-K91)
WLAN
WLAN
*) the default channel name is also listed in the table. If the specified name for a new channel already
exists, the default name, extended by a sequential number, is used for the new channel.
INSTrument:REName <ChannelName1>, <ChannelName2>
This command renames a measurement channel.
Parameters:
<ChannelName1>
String containing the name of the channel you want to rename.
<ChannelName2>
String containing the new channel name.
Note that you cannot assign an existing channel name to a new
channel; this will cause an error.
Example:
INST:REN 'IQAnalyzer2','IQAnalyzer3'
Renames the channel with the name 'IQAnalyzer2' to 'IQAnalyzer3'.
Usage:
Setting only
INSTrument[:SELect] <Application>
Selects the measurement application (channel type) for the current channel.
See also INSTrument:CREate[:NEW] on page 76.
For a list of available channel types see Table 8-2.
Parameters:
<Application>
PNOise
Phase noise measurements, R&S FSW–K40
SYSTem:PRESet:CHANnel[:EXECute]
This command restores the default instrument settings in the current channel.
Use INST:SEL to select the channel.
Example:
INST:SEL 'Spectrum2'
Selects the channel for "Spectrum2".
SYST:PRES:CHAN:EXEC
Restores the factory default settings to the "Spectrum2" channel.
Usage:
Event
Manual operation:
See "Preset Channel" on page 37
User Manual 1173.9286.02 ─ 14
79
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Performing Measurements
8.4 Performing Measurements
The following commands are necessary to perform measurements.
You can also perform a sequence of measurements using the Sequencer (see "Multiple Measurement Channels and Sequencer Function" on page 9).
ABORt............................................................................................................................ 80
CONFigure:REFMeas ONCE............................................................................................ 81
INITiate<n>:CONMeas..................................................................................................... 81
INITiate<n>:CONTinuous..................................................................................................81
INITiate<n>[:IMMediate]....................................................................................................82
INITiate<n>:SEQuencer:ABORt.........................................................................................82
INITiate<n>:SEQuencer:IMMediate....................................................................................82
INITiate<n>:SEQuencer:MODE......................................................................................... 83
[SENSe:]SWEep:COUNt...................................................................................................84
[SENSe:]SWEep:FHDecade..............................................................................................84
SYSTem:SEQuencer........................................................................................................85
ABORt
This command aborts the measurement in the current measurement channel and
resets the trigger system.
To prevent overlapping execution of the subsequent command before the measurement has been aborted successfully, use the *OPC? or *WAI command after ABOR and
before the next command.
For details see the "Remote Basics" chapter in the R&S FSW User Manual.
Note on blocked remote control programs:
If a sequential command cannot be completed, for example because a triggered sweep
never receives a trigger, the remote control program will never finish and the remote
channel to the R&S FSW is blocked for further commands. In this case, you must interrupt processing on the remote channel first in order to abort the measurement.
To do so, send a "Device Clear" command from the control instrument to the
R&S FSW on a parallel channel to clear all currently active remote channels. Depending on the used interface and protocol, send the following commands:
●
Visa: viClear()
●
GPIB: ibclr()
●
RSIB: RSDLLibclr()
Now you can send the ABORt command on the remote channel performing the measurement.
Example:
User Manual 1173.9286.02 ─ 14
ABOR;:INIT:IMM
Aborts the current measurement and immediately starts a new
one.
80
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Performing Measurements
Example:
ABOR;*WAI
INIT:IMM
Aborts the current measurement and starts a new one once
abortion has been completed.
Usage:
Event
SCPI confirmed
CONFigure:REFMeas ONCE
This command initiates a reference measurement that determines the inherent phase
noise of the R&S FSW.
Parameters:
ONCE
Example:
CONF:REFM ONCE
Initiates a reference measurement
Manual operation:
See "Reference Measurement" on page 21
INITiate<n>:CONMeas
This command restarts a (single) measurement that has been stopped (using ABORt)
or finished in single sweep mode.
The measurement is restarted at the beginning, not where the previous measurement
was stopped.
As opposed to INITiate<n>[:IMMediate], this command does not reset traces in
maxhold, minhold or average mode. Therefore it can be used to continue measurements using maxhold or averaging functions.
Suffix:
<n>
.
irrelevant
Usage:
Event
Manual operation:
See "Continue Single Sweep" on page 47
INITiate<n>:CONTinuous <State>
This command controls the sweep mode for an individual measurement channel.
Note that in single sweep mode, you can synchronize to the end of the measurement
with *OPC, *OPC? or *WAI. In continuous sweep mode, synchronization to the end of
the measurement is not possible. Thus, it is not recommended that you use continuous
sweep mode in remote control, as results like trace data or markers are only valid after
a single sweep end synchronization.
For details on synchronization see the "Remote Basics" chapter in the R&S FSW User
Manual.
User Manual 1173.9286.02 ─ 14
81
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Performing Measurements
Suffix:
<n>
.
irrelevant
Parameters:
<State>
ON | OFF | 0 | 1
ON | 1
Continuous sweep
OFF | 0
Single sweep
*RST:
1
Example:
INIT:CONT OFF
Switches the sweep mode to single sweep.
INIT:CONT ON
Switches the sweep mode to continuous sweep.
Manual operation:
See "Continuous Sweep/RUN CONT" on page 47
INITiate<n>[:IMMediate]
This command starts a (single) new measurement.
With sweep count or average count > 0, this means a restart of the corresponding
number of measurements. With trace mode MAXHold, MINHold and AVERage, the
previous results are reset on restarting the measurement.
You can synchronize to the end of the measurement with *OPC, *OPC? or *WAI.
For details on synchronization see the "Remote Basics" chapter in the R&S FSW User
Manual.
Suffix:
<n>
.
irrelevant
Usage:
Event
Manual operation:
See "Single Sweep/ RUN SINGLE" on page 47
INITiate<n>:SEQuencer:ABORt
This command stops the currently active sequence of measurements. The Sequencer
itself is not deactivated, so you can start a new sequence immediately using
INITiate<n>:SEQuencer:IMMediate on page 82.
To deactivate the Sequencer use SYSTem:SEQuencer on page 85.
Suffix:
<n>
.
irrelevant
Usage:
Event
INITiate<n>:SEQuencer:IMMediate
This command starts a new sequence of measurements by the Sequencer.
User Manual 1173.9286.02 ─ 14
82
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Performing Measurements
Its effect is similar to the INITiate<n>[:IMMediate] command used for a single
measurement.
Before this command can be executed, the Sequencer must be activated (see
SYSTem:SEQuencer on page 85).
Suffix:
<n>
.
irrelevant
Example:
SYST:SEQ ON
Activates the Sequencer.
INIT:SEQ:MODE SING
Sets single sequence mode so each active measurement will be
performed once.
INIT:SEQ:IMM
Starts the sequential measurements.
Usage:
Event
INITiate<n>:SEQuencer:MODE <Mode>
This command selects the way the R&S FSW application performs measurements
sequentially.
Before this command can be executed, the Sequencer must be activated (see
SYSTem:SEQuencer on page 85).
A detailed programming example is provided in the "Operating Modes" chapter in the
R&S FSW User Manual.
Note: In order to synchronize to the end of a sequential measurement using *OPC,
*OPC? or *WAI you must use SINGle Sequence mode.
For details on synchronization see the "Remote Basics" chapter in the R&S FSW User
Manual.
Suffix:
<n>
Parameters:
<Mode>
.
irrelevant
SINGle
Each measurement is performed once (regardless of the channel's sweep mode), considering each channels' sweep count,
until all measurements in all active channels have been performed.
CONTinuous
The measurements in each active channel are performed one
after the other, repeatedly (regardless of the channel's sweep
mode), in the same order, until the Sequencer is stopped.
CDEFined
First, a single sequence is performed. Then, only those channels
in continuous sweep mode (INIT:CONT ON) are repeated.
*RST:
User Manual 1173.9286.02 ─ 14
CONTinuous
83
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Performing Measurements
Example:
SYST:SEQ ON
Activates the Sequencer.
INIT:SEQ:MODE SING
Sets single sequence mode so each active measurement will be
performed once.
INIT:SEQ:IMM
Starts the sequential measurements.
[SENSe:]SWEep:COUNt <SweepCount>
This command defines the number of sweeps that the application uses to average
traces.
In case of continuous sweep mode, the application calculates the moving average over
the average count.
In case of single sweep mode, the application stops the measurement and calculates
the average after the average count has been reached.
Suffix:
<n>
Parameters:
<SweepCount>
.
Window
If you set a sweep count of 0 or 1, the R&S FSW performs one
single sweep.
Range:
*RST:
0 to 200000
200
Example:
SWE:COUN 64
Sets the number of sweeps to 64.
INIT:CONT OFF
Switches to single sweep mode.
INIT;*WAI
Starts a sweep and waits for its end.
Usage:
SCPI confirmed
Manual operation:
See "Sweep / Average Count" on page 47
[SENSe:]SWEep:FHDecade
This command stops the measurement in the current half decade and continues measuring in the subsequent half decade.
Example:
SWE:FHD
Aborts the current measurement and continues in the next half
decade.
Usage:
Event
Manual operation:
See "Finish Half Decade" on page 48
User Manual 1173.9286.02 ─ 14
84
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
SYSTem:SEQuencer <State>
This command turns the Sequencer on and off. The Sequencer must be active before
any other Sequencer commands (INIT:SEQ...) are executed, otherwise an error will
occur.
A detailed programming example is provided in the "Operating Modes" chapter in the
R&S FSW User Manual.
Parameters:
<State>
ON | OFF | 0 | 1
ON | 1
The Sequencer is activated and a sequential measurement is
started immediately.
OFF | 0
The Sequencer is deactivated. Any running sequential measurements are stopped. Further Sequencer commands (INIT:
SEQ...) are not available.
*RST:
Example:
0
SYST:SEQ ON
Activates the Sequencer.
INIT:SEQ:MODE SING
Sets single Sequencer mode so each active measurement will
be performed once.
INIT:SEQ:IMM
Starts the sequential measurements.
SYST:SEQ OFF
8.5 Configuring the Result Display
The commands required to configure the screen display in a remote environment are
described here.
●
●
General Window Commands.................................................................................. 85
Working with Windows in the Display..................................................................... 86
8.5.1 General Window Commands
The following commands are required to configure general window layout, independent
of the application.
DISPlay:FORMat............................................................................................................. 85
DISPlay[:WINDow<n>]:SIZE............................................................................................. 86
DISPlay:FORMat <Format>
This command determines which tab is displayed.
User Manual 1173.9286.02 ─ 14
85
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
Parameters:
<Format>
SPLit
Displays the MultiView tab with an overview of all active channels
SINGle
Displays the measurement channel that was previously focused.
*RST:
Example:
SING
DISP:FORM SPL
DISPlay[:WINDow<n>]:SIZE <Size>
This command maximizes the size of the selected result display window temporarily.
To change the size of several windows on the screen permanently, use the LAY:SPL
command (see LAYout:SPLitter on page 89).
Suffix:
<n>
Parameters:
<Size>
.
Window
LARGe
Maximizes the selected window to full screen.
Other windows are still active in the background.
SMALl
Reduces the size of the selected window to its original size.
If more than one measurement window was displayed originally,
these are visible again.
*RST:
Example:
SMALl
DISP:WIND2:SIZE LARG
8.5.2 Working with Windows in the Display
The following commands are required to change the evaluation type and rearrange the
screen layout for a measurement channel as you do using the SmartGrid in manual
operation. Since the available evaluation types depend on the selected application,
some parameters for the following commands also depend on the selected measurement channel.
LAYout:ADD[:WINDow]?...................................................................................................87
LAYout:CATalog[:WINDow]?.............................................................................................88
LAYout:IDENtify[:WINDow]?..............................................................................................88
LAYout:REMove[:WINDow]...............................................................................................88
LAYout:REPLace[:WINDow]..............................................................................................89
LAYout:SPLitter............................................................................................................... 89
LAYout:WINDow<n>:ADD?...............................................................................................91
LAYout:WINDow<n>:IDENtify?..........................................................................................91
LAYout:WINDow<n>:REMove........................................................................................... 92
LAYout:WINDow<n>:REPLace..........................................................................................92
User Manual 1173.9286.02 ─ 14
86
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
LAYout:ADD[:WINDow]? <WindowName>,<Direction>,<WindowType>
This command adds a window to the display in the active measurement channel.
This command is always used as a query so that you immediately obtain the name of
the new window as a result.
To replace an existing window, use the LAYout:REPLace[:WINDow] command.
Parameters:
<WindowName>
<Direction>
String containing the name of the existing window the new window is inserted next to.
By default, the name of a window is the same as its index. To
determine the name and index of all active windows, use the
LAYout:CATalog[:WINDow]? query.
LEFT | RIGHt | ABOVe | BELow
Direction the new window is added relative to the existing window.
<WindowType>
text value
Type of result display (evaluation method) you want to add.
See the table below for available parameter values.
Return values:
<NewWindowName> When adding a new window, the command returns its name (by
default the same as its number) as a result.
Example:
LAY:ADD? '1',LEFT,MTAB
Result:
'2'
Adds a new window named '2' with a marker table to the left of
window 1.
Usage:
Query only
Table 8-3: <WindowType> parameter values for Phase Noise application
Parameter value
Window type
FDRift
Frequency drift
MTABle
Marker table
PNOise
Phase noise diagram
RNOise
Residual noise table
SNOise
Spot noise table
SPECtrum
Spectrum monitor
SPURs
Spur list
SRESults
Sweep result list
STABility
Frequency and level stability indicator
User Manual 1173.9286.02 ─ 14
87
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
LAYout:CATalog[:WINDow]?
This command queries the name and index of all active windows in the active measurement channel from top left to bottom right. The result is a comma-separated list of
values for each window, with the syntax:
<WindowName_1>,<WindowIndex_1>..<WindowName_n>,<WindowIndex_n>
Return values:
<WindowName>
string
Name of the window.
In the default state, the name of the window is its index.
<WindowIndex>
numeric value
Index of the window.
Example:
LAY:CAT?
Result:
'2',2,'1',1
Two windows are displayed, named '2' (at the top or left), and '1'
(at the bottom or right).
Usage:
Query only
LAYout:IDENtify[:WINDow]? <WindowName>
This command queries the index of a particular display window in the active measurement channel.
Note: to query the name of a particular window, use the LAYout:WINDow<n>:
IDENtify? query.
Query parameters:
<WindowName>
String containing the name of a window.
Return values:
<WindowIndex>
Index number of the window.
Example:
LAY:WIND:IDEN? '2'
Queries the index of the result display named '2'.
Response:
2
Usage:
Query only
LAYout:REMove[:WINDow] <WindowName>
This command removes a window from the display in the active measurement channel.
Parameters:
<WindowName>
Example:
User Manual 1173.9286.02 ─ 14
String containing the name of the window.
In the default state, the name of the window is its index.
LAY:REM '2'
Removes the result display in the window named '2'.
88
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
Usage:
Event
LAYout:REPLace[:WINDow] <WindowName>,<WindowType>
This command replaces the window type (for example from "Diagram" to "Result Summary") of an already existing window in the active measurement channel while keeping
its position, index and window name.
To add a new window, use the LAYout:ADD[:WINDow]? command.
Parameters:
<WindowName>
String containing the name of the existing window.
By default, the name of a window is the same as its index. To
determine the name and index of all active windows in the active
measurement channel, use the LAYout:CATalog[:WINDow]?
query.
<WindowType>
Type of result display you want to use in the existing window.
See LAYout:ADD[:WINDow]? on page 87 for a list of available
window types.
Example:
LAY:REPL:WIND '1',MTAB
Replaces the result display in window 1 with a marker table.
LAYout:SPLitter <Index1>,<Index2>,<Position>
This command changes the position of a splitter and thus controls the size of the windows on each side of the splitter.
Compared to the DISPlay[:WINDow<n>]:SIZE on page 86 command, the
LAYout:SPLitter changes the size of all windows to either side of the splitter permanently, it does not just maximize a single window temporarily.
Note that windows must have a certain minimum size. If the position you define conflicts with the minimum size of any of the affected windows, the command will not work,
but does not return an error.
User Manual 1173.9286.02 ─ 14
89
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
Figure 8-1: SmartGrid coordinates for remote control of the splitters
Parameters:
<Index1>
The index of one window the splitter controls.
<Index2>
The index of a window on the other side of the splitter.
<Position>
New vertical or horizontal position of the splitter as a fraction of
the screen area (without channel and status bar and softkey
menu).
The point of origin (x = 0, y = 0) is in the lower left corner of the
screen. The end point (x = 100, y = 100) is in the upper right corner of the screen. (See Figure 8-1.)
The direction in which the splitter is moved depends on the
screen layout. If the windows are positioned horizontally, the
splitter also moves horizontally. If the windows are positioned
vertically, the splitter also moves vertically.
Range:
0 to 100
Example:
LAY:SPL 1,3,50
Moves the splitter between window 1 ('Frequency Sweep') and 3
('Marker Table') to the center (50%) of the screen, i.e. in the figure above, to the left.
Example:
LAY:SPL 1,4,70
Moves the splitter between window 1 ('Frequency Sweep') and 3
('Marker Peak List') towards the top (70%) of the screen.
The following commands have the exact same effect, as any
combination of windows above and below the splitter moves the
splitter vertically.
LAY:SPL 3,2,70
LAY:SPL 4,1,70
LAY:SPL 2,1,70
User Manual 1173.9286.02 ─ 14
90
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Result Display
LAYout:WINDow<n>:ADD? <Direction>,<WindowType>
This command adds a measurement window to the display. Note that with this command, the suffix <n> determines the existing window next to which the new window is
added, as opposed to LAYout:ADD[:WINDow]?, for which the existing window is
defined by a parameter.
To replace an existing window, use the LAYout:WINDow<n>:REPLace command.
This command is always used as a query so that you immediately obtain the name of
the new window as a result.
Suffix:
<n>
.
Window
Parameters:
<Direction>
LEFT | RIGHt | ABOVe | BELow
<WindowType>
Type of measurement window you want to add.
See LAYout:ADD[:WINDow]? on page 87 for a list of available
window types.
Return values:
<NewWindowName> When adding a new window, the command returns its name (by
default the same as its number) as a result.
Example:
LAY:WIND1:ADD? LEFT,MTAB
Result:
'2'
Adds a new window named '2' with a marker table to the left of
window 1.
Usage:
Query only
LAYout:WINDow<n>:IDENtify?
This command queries the name of a particular display window (indicated by the <n>
suffix) in the active measurement channel.
Note: to query the index of a particular window, use the LAYout:IDENtify[:
WINDow]? command.
Suffix:
<n>
Return values:
<WindowName>
.
Window
String containing the name of a window.
In the default state, the name of the window is its index.
Example:
LAY:WIND2:IDEN?
Queries the name of the result display in window 2.
Response:
'2'
Usage:
Query only
User Manual 1173.9286.02 ─ 14
91
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Frontend
LAYout:WINDow<n>:REMove
This command removes the window specified by the suffix <n> from the display in the
active measurement channel.
The result of this command is identical to the LAYout:REMove[:WINDow] command.
Suffix:
<n>
.
Window
Example:
LAY:WIND2:REM
Removes the result display in window 2.
Usage:
Event
LAYout:WINDow<n>:REPLace <WindowType>
This command changes the window type of an existing window (specified by the suffix
<n>) in the active measurement channel.
The result of this command is identical to the LAYout:REPLace[:WINDow] command.
To add a new window, use the LAYout:WINDow<n>:ADD? command.
Suffix:
<n>
Parameters:
<WindowType>
Example:
.
Window
Type of measurement window you want to replace another one
with.
See LAYout:ADD[:WINDow]? on page 87 for a list of available
window types.
LAY:WIND2:REPL MTAB
Replaces the result display in window 2 with a marker table.
8.6 Configuring the Frontend
The following commands are necessary to configure the frontend settings.
[SENSe:]FREQuency:CENTer...........................................................................................92
[SENSe:]POWer:RLEVel.................................................................................................. 93
INPut:ATTenuation...........................................................................................................93
INPut:ATTenuation:AUTO.................................................................................................94
INPut:COUPling...............................................................................................................94
INPut:GAIN:STATe.......................................................................................................... 94
INPut:GAIN[:VALue].........................................................................................................95
[SENSe:]FREQuency:CENTer <Frequency>
This command defines the nominal frequency.
User Manual 1173.9286.02 ─ 14
92
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Frontend
Parameters:
<Frequency>
Range:
0 to fmax
*RST:
fmax/2
Default unit: Hz
fmax is specified in the data sheet. min span is 10 Hz
Example:
FREQ:CENT 100 MHz
Defines a nominal frequency of 100 MHz.
Usage:
SCPI confirmed
Manual operation:
See "Nominal Frequency" on page 39
[SENSe:]POWer:RLEVel <Power>
This command defines the nominal level.
Parameters:
<Power>
Numeric value in dBm.
Range:
*RST:
-200 to 200
0
Example:
POW:RLEV -20
Defines a nominal level of -20 dBm.
Usage:
SCPI confirmed
Manual operation:
See "Nominal Level" on page 39
INPut:ATTenuation <Attenuation>
This command defines the total attenuation for RF input.
If you set the attenuation manually, it is no longer coupled to the reference level, but
the reference level is coupled to the attenuation. Thus, if the current reference level is
not compatible with an attenuation that has been set manually, the command also
adjusts the reference level.
Parameters:
<Attenuation>
Range:
see data sheet
Increment: 5 dB
*RST:
10 dB (AUTO is set to ON)
Example:
INP:ATT 30dB
Defines a 30 dB attenuation and decouples the attenuation from
the reference level.
Usage:
SCPI confirmed
Manual operation:
See "Mechanical Attenuator / Value" on page 39
User Manual 1173.9286.02 ─ 14
93
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Frontend
INPut:ATTenuation:AUTO <State>
This command couples or decouples the attenuation to the reference level. Thus, when
the reference level is changed, the R&S FSW determines the signal level for optimal
internal data processing and sets the required attenuation accordingly.
Parameters:
<State>
ON | OFF | 0 | 1
*RST:
1
Example:
INP:ATT:AUTO ON
Couples the attenuation to the reference level.
Usage:
SCPI confirmed
Manual operation:
See "Mechanical Attenuator / Value" on page 39
INPut:COUPling <CouplingType>
This command selects the coupling type of the RF input.
Parameters:
<CouplingType>
AC
AC coupling
DC
DC coupling
*RST:
AC
Example:
INP:COUP DC
Usage:
SCPI confirmed
Manual operation:
See "Coupling" on page 39
INPut:GAIN:STATe <State>
This command turns the preamplifier on and off. It requires the optional preamplifier
hardware.
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
INP:GAIN:STAT ON
Switches on 30 dB preamplification.
Usage:
SCPI confirmed
Manual operation:
See "Preamplifier" on page 39
User Manual 1173.9286.02 ─ 14
94
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Measurement
INPut:GAIN[:VALue] <Gain>
This command selects the gain if the preamplifier is activated (INP:GAIN:STAT ON,
see INPut:GAIN:STATe on page 94).
The command requires the additional preamplifier hardware option.
Parameters:
<Gain>
15 dB | 30 dB
The availability of gain levels depends on the model of the
R&S FSW.
R&S FSW8/13: 15dB and 30 dB
R&S FSW26 or higher: 30 dB
All other values are rounded to the nearest of these two.
*RST:
OFF
Example:
INP:GAIN:STAT ON
INP:GAIN:VAL 30
Switches on 30 dB preamplification.
Usage:
SCPI confirmed
Manual operation:
See "Preamplifier" on page 39
8.7 Controlling the Measurement
The following commands are necessary to control the sequence of the phase noise
measurement.
[SENSe:]FREQuency:TRACk............................................................................................ 95
[SENSe:]FREQuency:VERify:TOLerance:ABSolute............................................................. 96
[SENSe:]FREQuency:VERify:TOLerance:RELative............................................................. 96
[SENSe:]FREQuency:VERify[:STATe]................................................................................96
[SENSe:]IQ:DECimation................................................................................................... 97
[SENSe:]IQ:DPLL.............................................................................................................97
[SENSe:]IQ:ONLine..........................................................................................................97
[SENSe:]IQ:TBW............................................................................................................. 98
[SENSe:]POWer:RLEVel:VERify:TOLerance.......................................................................98
[SENSe:]POWer:RLEVel:VERify[:STATe]...........................................................................98
[SENSe:]POWer:TRACk................................................................................................... 98
[SENSe:]REJect:AM.........................................................................................................99
[SENSe:]SWEep:SVFailed................................................................................................99
[SENSe:]FREQuency:TRACk <State>
This command turns frequency tracking on and off.
Parameters:
<State>
ON | OFF
*RST:
User Manual 1173.9286.02 ─ 14
ON
95
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Measurement
Example:
FREQ:TRAC OFF
Turns off frequency tracking.
Manual operation:
See "Frequency Tracking" on page 41
[SENSe:]FREQuency:VERify:TOLerance:ABSolute <Frequency>
This command defines an absolute frequency tolerance for frequency verification.
If you define both an absolute and relative tolerance, the application uses the higher
tolerance level.
Parameters:
<Frequency>
Numeric value in Hz.
*RST:
1 kHz
Example:
FREQ:VER:TOL:ABS 100kHz
Defines a frequency tolerance range of 100 kHz.
Manual operation:
See "Verify Frequency" on page 40
[SENSe:]FREQuency:VERify:TOLerance:RELative <Percentage>
This command defines a relative frequency tolerance for frequency verification.
If you define both an absolute and relative tolerance, the application uses the higher
tolerance level.
Parameters:
<Percentage>
Numeric value in %, relative to the current nominal frequency.
Range:
1 to 100
*RST:
10
Default unit: PCT
Example:
FREQ:VER:TOL:REL 12
Defines a frequency tolerance of 12% in relation to the nominal
frequency.
Usage:
SCPI confirmed
Manual operation:
See "Verify Frequency" on page 40
[SENSe:]FREQuency:VERify[:STATe] <State>
This command turns frequency verification on and off.
Parameters:
<State>
ON | OFF
*RST:
ON
Example:
FREQ:VER ON
Turns on frequency verification.
Usage:
SCPI confirmed
User Manual 1173.9286.02 ─ 14
96
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Measurement
Manual operation:
See "Verify Frequency" on page 40
[SENSe:]IQ:DECimation <State>
This command turns decimation of results on and off.
Parameters:
<State>
ON | OFF
*RST:
ON
Example:
IQ:DEC ON
Turns on decimation.
Manual operation:
See "Decimation" on page 42
[SENSe:]IQ:DPLL <State>
This command turns the digital PLL on and off.
Parameters:
<State>
ON | OFF
Example:
IQ:DPLL ON
Turns the digital PLL on.
Manual operation:
See "Digital PLL" on page 42
[SENSe:]IQ:ONLine <State>
This command turns the I/Q online measurement mode on and off.
This mode is available for offset frequencies smaller than 30 kHz.
Note that you have to
●
turn on decimation with [SENSe:]IQ:DECimation
●
select the I/Q FFT mode for the affected half decades with [SENSe:
]BANDwidth|BWIDth[:RESolution]:TYPE
●
turn off forward sweep with [SENSe:]SWEep:FORWard
Parameters:
<State>
ON | OFF
Example:
SWE:FORW OFF
LIST:RANG9:FILT:TYPE IQFF
LIST:RANG8:FILT:TYPE IQFF
IQ:DEC ON
IQ:ONL ON
Configures a online measurement for the half decades between
3 kHz and 10 kHz and 10 kHz and 30 kHz.
Manual operation:
See "Online I/Q" on page 42
User Manual 1173.9286.02 ─ 14
97
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Controlling the Measurement
[SENSe:]IQ:TBW <Bandwidth>
This command defines the maximum tracking bandwidth (sample rate) for all half decades.
Parameters:
<Bandwidth>
Range:
60 mHz to 65.28 MHz
Increment: 10 mHz
*RST:
60 mHz
Example:
IQ:TBW 100HZ
Defines a tracking bandwidth of 100 Hz.
Manual operation:
See "Max Freq Drift" on page 42
[SENSe:]POWer:RLEVel:VERify:TOLerance <Level>
This command defines a relative level tolerance for level verification
Parameters:
<Level>
Numeric value in dB, relative to the nominal level.
*RST:
10 dB
Example:
POW:RLEV:TOL 5
Defines a level tolerance of 5 dB.
Usage:
SCPI confirmed
Manual operation:
See "Verify Level" on page 41
[SENSe:]POWer:RLEVel:VERify[:STATe] <State>
This command turns level verification on and off.
Parameters:
<State>
ON | OFF
*RST:
ON
Example:
POW:RLEV:VER ON
Turns on level verification.
Usage:
SCPI confirmed
Manual operation:
See "Verify Level" on page 41
[SENSe:]POWer:TRACk <State>
This command turns level tracking on and off.
Parameters:
<State>
ON | OFF
*RST:
User Manual 1173.9286.02 ─ 14
ON
98
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
Example:
POW:TRAC ON
Turns on level tracking.
Usage:
SCPI confirmed
Manual operation:
See "Level Tracking" on page 41
[SENSe:]REJect:AM <State>
This command turns the suppression of AM noise on and off.
Parameters:
<State>
ON | OFF
Example:
REJ:AM ON
Turns AM noise suppression on.
Manual operation:
See "AM Rejection" on page 42
[SENSe:]SWEep:SVFailed <State>
This command turns repeated tries to start the measurement if signal verification fails
on and off.
Parameters:
<State>
ON | OFF
If on, the application tries to verify the signal once and then
aborts the measurement if verification has failed.
*RST:
OFF
Example:
SWE:SVF ON
Stops the measurement if signal verification has failed.
Manual operation:
See "On Verify Failed" on page 41
8.8 Configuring the Measurement Range
The following commands are necessary to configure the phase noise measurement
range.
Table 8-4: <range> suffix assignment
Suffix
Half Decade
1
1 Hz ... 3 Hz
2
3 Hz ... 10 Hz
3
10 Hz ... 30 Hz
4
30 Hz ... 100 Hz
5
100 Hz ... 300 Hz
6
300 Hz ... 1 kHz
User Manual 1173.9286.02 ─ 14
99
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
Suffix
Half Decade
7
1 kHz ... 3 kHz
8
3 kHz ... 10 kHz
9
10 kHz ... 30 kHz
10
30 kHz ... 100 kHz
11
100 kHz ... 300 kHz
12
300 kHz ... 1 MHz
13
1 MHz ... 3 MHz
14
3 MHz ... 10 MHz
15
10 MHz ... 30 MHz
16
30 MHz ... 100 MHz
17
100 MHz ... 300 MHz
18
300 MHz ... 1 GHz
19
1 GHz ... 3 GHz
20
3 GHz ... 10 GHz
[SENSe:]LIST:BWIDth[:RESolution]:RATio....................................................................... 100
[SENSe:]BANDwidth|BWIDth[:RESolution]:TYPE.............................................................. 101
[SENSe:]FREQuency:STARt...........................................................................................101
[SENSe:]FREQuency:STOP............................................................................................101
[SENSe:]LIST:BWIDth:RESolution:TYPE..........................................................................102
[SENSe]:LIST:IQWindow:TYPE.......................................................................................102
[SENSe:]LIST:RANGe<range>:BWIDth[:RESolution]......................................................... 103
[SENSe:]LIST:RANGe<range>:FILTer:TYPE.................................................................... 103
[SENSe:]LIST:RANGe<range>:IQWindow:TYPE...............................................................103
[SENSe:]LIST:RANGe<range>:SWEep:COUNt.................................................................104
[SENSe:]LIST:SWEep:COUNt.........................................................................................104
[SENSe:]LIST:SWEep:COUNt:MULTiplier........................................................................ 105
[SENSe:]LIST:SWEep:COUNt:MULTiplier:STATe............................................................. 105
[SENSe:]SWEep:FORWard............................................................................................ 105
[SENSe:]SWEep:MODE................................................................................................. 106
[SENSe:]LIST:BWIDth[:RESolution]:RATio <Ratio>
This command defines the resolution bandwidth over all half decades.
User Manual 1173.9286.02 ─ 14
100
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
Parameters:
<Ratio>
Numeric value in %.
The resulting RBW is the percentage of the start frequency of
each half decade.
If the resulting RBW is not available, the application rounds to
the next available bandwidth.
Range:
*RST:
1 to 100
10
Example:
LIST:BWID:RAT 20
Defines a RBW of 20% of the start frequency of the corresponding half decade.
Manual operation:
See "Global RBW" on page 44
[SENSe:]BANDwidth|BWIDth[:RESolution]:TYPE <Mode>
This command selects the sweep mode for a all half decades globally.
Parameters:
<Mode>
IQ
Measurement based on I/Q data.
NORMal
Measurement based on spectrum analyzer data.
FFT
Measurement based on spectrum analyzer data. Kept for compatibility to R&S FSV.
*RST:
Example:
Depends on half decade
BAND:TYPE FFT
Selects FFT analysis for all half decades.
[SENSe:]FREQuency:STARt <Frequency>
This command defines the start frequency of the measurement range.
Parameters:
<Frequency>
Offset frequencies in half decade steps.
Range:
*RST:
1 Hz to 3 GHz
1 kHz
Example:
FREQ:STAR 10kHz
Defines a start frequency of 10 kHz.
Usage:
SCPI confirmed
Manual operation:
See "Range Start / Stop" on page 44
[SENSe:]FREQuency:STOP <Frequency>
This command defines the stop frequency of the measurement range.
User Manual 1173.9286.02 ─ 14
101
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
Parameters:
<Frequency>
Offset frequencies in half decade steps.
Range:
*RST:
3 Hz to 10 GHz
1 MHz
Example:
FREQ:STOP 10MHz
Defines a stop frequency of 10 MHz.
Usage:
SCPI confirmed
Manual operation:
See "Range Start / Stop" on page 44
[SENSe:]LIST:BWIDth:RESolution:TYPE <Mode>
This command selects the sweep mode for all half decades.
Parameters:
<Mode>
IQFFt
Measurement based on I/Q data.
NORMal
Measurement based on spectrum analyzer data.
FFT
Measurement based on spectrum analyzer data. Kept for compatibility to R&S FSV.
*RST:
Depends on half decade
Example:
LIST:BWID:RES:TYPE IQFF
Selects I/Q analysis mode for all half decades.
Manual operation:
See "Global Sweep Mode" on page 45
[SENSe]:LIST:IQWindow:TYPE <WindowFunction>
This command selects the window function for all half decades.
Window functions are available for I/Q sweep mode.
Parameters:
<WindowFunction>
RECtangular
GAUSsian
CHEBychev
BHARris
*RST:
Depends on the half decade
Example:
LIST:IQW:TYPE REC
Selects a rectangular FFT window.
Manual operation:
See "Global I/Q Window" on page 45
User Manual 1173.9286.02 ─ 14
102
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
[SENSe:]LIST:RANGe<range>:BWIDth[:RESolution] <RBW>
This command defines the resolution bandwidth for a particular half decade.
Suffix:
<range>
Parameters:
<RBW>
.
1...20
Selects the half decade.
For the suffix assignment see Table 8-4.
Numeric value in Hz.
Note that each half decade has a limited range of available
bandwidths.
*RST:
Depends on the half decade
Default unit: Hz
Example:
LIST:RANG9:BWID 100Hz
Selects a RBW of 100 Hz for the half decade from 1 kHz to 3
kHz.
Manual operation:
See "Half Decades Configuration Table" on page 46
[SENSe:]LIST:RANGe<range>:FILTer:TYPE <Mode>
This command selects the sweep mode for a particular half decade.
Suffix:
<range>
Parameters:
<Mode>
.
1...20
Selects the half decade.
For the suffix assignment see Table 8-4.
IQFFt
Measurement based on I/Q data.
NORMal
Measurement based on spectrum analyzer data.
FFT
Measurement based on spectrum analyzer data. Kept for compatibility to R&S FSV.
*RST:
Depends on half decade
Example:
LIST:RANG9:FILT:TYPE FFT
Selects FFT analysis for the ninth half decade.
Manual operation:
See "Half Decades Configuration Table" on page 46
[SENSe:]LIST:RANGe<range>:IQWindow:TYPE <WindowFunction>
This command selects the window function for a particular half decade.
Window functions are available for I/Q sweep mode.
User Manual 1173.9286.02 ─ 14
103
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
Suffix:
<range>
Parameters:
<WindowFunction>
.
1...20
Selects the half decade.
For the suffix assignment see Table 8-4.
RECtangular
GAUSsian
CHEBychev
BHARris
*RST:
Depends on the half decade
Example:
LIST:RANG:IQW:TYPE BHAR
Selects the Blackman Harris window function for the first half
decade.
Manual operation:
See "Half Decades Configuration Table" on page 46
[SENSe:]LIST:RANGe<range>:SWEep:COUNt <Measurements>
This command defines the number of measurements included in the averaging for a
half decade.
Suffix:
<range>
Parameters:
<Measurements>
.
1...20
Selects the half decade.
For the suffix assignment see Table 8-4.
Range:
*RST:
1 to 10000
Depends on the half decade
Example:
LIST:RANG9:SWE:COUN 15
Includes 15 measurements in the averaging of the ninth half
decade.
Usage:
SCPI confirmed
Manual operation:
See "Half Decades Configuration Table" on page 46
[SENSe:]LIST:SWEep:COUNt <Averages>
This command defines the number of measurements to be included in the averaging
for each and all half decades.
Parameters:
<Averages>
Range:
*RST:
1 to 10000
Depends on the half decade.
Example:
LIST:SWE:COUN 20
Defines 20 averages for all half decades.
Manual operation:
See "Global Average Count" on page 45
User Manual 1173.9286.02 ─ 14
104
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring the Measurement Range
[SENSe:]LIST:SWEep:COUNt:MULTiplier <Multiplier>
This command defines a multiplier that is applied to the average count in each half
decade.
Before you can use the command you have to turn on the multiplier with [SENSe:
]LIST:SWEep:COUNt:MULTiplier:STATe.
Parameters:
<Multiplier>
Numeric value.
Example:
LIST:SWE:COUN:MULT:STAT ON
LIST:SWE:COUN:MULT 5
Turns on the multiplier and multiplies the averages by 5.
Manual operation:
See "Multiplier" on page 45
[SENSe:]LIST:SWEep:COUNt:MULTiplier:STATe <State>
This command turns a multiplier that is applied to the average count in each half decade on and off.
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
See [SENSe:]LIST:SWEep:COUNt:MULTiplier
on page 105.
Manual operation:
See "Multiplier" on page 45
[SENSe:]SWEep:FORWard <State>
This command selects the measurement direction.
Specifies the sweep direction. When switched on the sweep direction is from the start
frequency to the stop frequency. When switched off the sweep direction is reversed
Parameters:
<State>
ON
Measurements in forward direction.
The measurements starts at the smallest offset frequency.
OFF
Measurement in reverse direction.
The measurement starts at the highest offset frequency.
*RST:
OFF
Example:
SWE:FORW ON
Selects forward measurements.
Usage:
SCPI confirmed
Manual operation:
See "Sweep Forward" on page 44
User Manual 1173.9286.02 ─ 14
105
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
[SENSe:]SWEep:MODE <Mode>
This command selects the type of measurement configuration.
Parameters:
<Mode>
AVERage
Selects a measurement configuration optimized for quality
results.
FAST
Selects a measurement configuration optimized for speed.
MANual
Selects manual measurement configuration.
NORMal
Selects a balanced measurement configuration.
*RST:
NORMal
Usage:
SCPI confirmed
Manual operation:
See "Presets" on page 44
8.9 Using Limit Lines
The following commands are necessary to set up and configure limit lines.
●
●
●
Using Phase Noise Limit Lines............................................................................. 106
Using Standard Limit Lines................................................................................... 109
Creating and Editing Standard Limit Lines............................................................114
8.9.1 Using Phase Noise Limit Lines
CALCulate:PNLimit:COPY<k>.........................................................................................106
CALCulate:PNLimit:FC1 <Frequency>............................................................................. 107
CALCulate:PNLimit:FC2 <Frequency>............................................................................. 107
CALCulate:PNLimit:FC3 <Frequency>............................................................................. 107
CALCulate:PNLimit:FC4 <Frequency>............................................................................. 107
CALCulate:PNLimit:FC5................................................................................................. 107
CALCulate:PNLimit:NOISe..............................................................................................107
CALCulate:PNLimit:TRACe.............................................................................................108
CALCulate:PNLimit:TYPE............................................................................................... 108
CALCulate:PNLimit:FAIL?...............................................................................................108
CALCulate:PNLimit:SLOPe<segment>.............................................................................109
CALCulate:PNLimit:COPY<k>
Creates a new user limit line from the data of a phase noise limit line.
User Manual 1173.9286.02 ─ 14
106
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Suffix:
<k>
.
1...8
Number of the limit line the phase noise limit line is copied to. An
existing limit line in that slot is overwritten.
Example:
CALC:PNL:COPY2
Copies the phase noise limit line to limit line 3.
Usage:
Event
Manual operation:
See "Copy to User Limit Line" on page 60
CALCulate:PNLimit:FC1 <Frequency>
CALCulate:PNLimit:FC2 <Frequency>
CALCulate:PNLimit:FC3 <Frequency>
CALCulate:PNLimit:FC4 <Frequency>
CALCulate:PNLimit:FC5 <Frequency>
This command defines the start frequency of a segment of a phase noise limit line.
CALCulate:PNLimit:FC1 is available for special phase noise limit lines with one segment or more.
CALCulate:PNLimit:FC2 is available for special phase noise limit lines with two segment or more.
CALCulate:PNLimit:FC3 is available for special phase noise limit lines with three segment or more.
CALCulate:PNLimit:FC4 is available for special phase noise limit lines with four segment or more.
CALCulate:PNLimit:FC5 is available for special phase noise limit lines with five segments.
Parameters:
<Frequency>
Offset frequency relative to the carrier frequency.
The minimum offset is 1 Hz. The maximum offset depends on
the hardware you are using.
*RST:
1 MHz
Example:
CALC:PNL:FC1 2MHZ
Defines a corner frequency at 2 MHz offset.
Manual operation:
See "Range x - Range y" on page 59
CALCulate:PNLimit:NOISe <NoiseLevel>
This command defines the noise floor level of the DUT.
The noise floor level is necessary for the calculation of a phase noise limit line.
User Manual 1173.9286.02 ─ 14
107
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Parameters:
<NoiseLevel>
Range:
-200 to 200
*RST:
0
Default unit: dBm/Hz
Example:
CALC:PNL:NOIS -150
Defines a noise floor level of 150 dBm/Hz.
Manual operation:
See "Noise Floor" on page 59
CALCulate:PNLimit:TRACe <Trace>
This command selects the trace to assign a phase noise limit line to.
Parameters:
<Trace>
Range:
*RST:
1 to 6
-
Example:
CALC:PNL:TRAC 1
Assigns the phase noise limit line to trace 1.
Manual operation:
See "Selected Traces" on page 59
CALCulate:PNLimit:TYPE <Shape>
This command selects the shape of a phase noise limit line.
Parameters:
<Shape>
FC1
Limit line defined by the noise floor and 1 corner frequency.
FC2
Limit line defined by the noise floor and 2 corner frequencies.
FC3
Limit line defined by the noise floor and 3 corner frequencies.
FC4
Limit line defined by the noise floor and 4 corner frequencies.
FC5
Limit line defined by the noise floor and 5 corner frequencies.
NONE
No limit line.
*RST:
NONE
Example:
CALC:PNL:TYPE FC2
Selects a limit line with 2 corner frequencies.
Manual operation:
See "Phase Noise Limit Line" on page 59
CALCulate:PNLimit:FAIL?
This command queries the limit check results for phase noise limit lines.
User Manual 1173.9286.02 ─ 14
108
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Return values:
<LimitCheck>
1
Limit check has passed.
0
Limit check has failed.
Example:
CALC:PNL:FAIL?
Queries the limit check result.
Usage:
Query only
CALCulate:PNLimit:SLOPe<segment> <Slope>
This command defines the slope for a phase noise limit line segment.
Suffix:
<segment>
Parameters:
<Slope>
.
1...5
Selects the limit line segment.
Level distance from the left border of the limit line segment to
the previous one.
*RST:
10
Default unit: dB
Example:
CALC:PNL:SLOP2 20
Defines a slope of 20 dB for the second limit line segment.
Manual operation:
See "Range x - Range y" on page 59
8.9.2 Using Standard Limit Lines
CALCulate<n>:LIMit<k>:ACTive?.................................................................................... 109
CALCulate<n>:LIMit<k>:CLEar[:IMMediate]......................................................................110
CALCulate<n>:LIMit<k>:COPY........................................................................................110
CALCulate<n>:LIMit<k>:DELete...................................................................................... 110
CALCulate<n>:LIMit<k>:FAIL?........................................................................................ 111
CALCulate<n>:LIMit<k>:NAME....................................................................................... 111
CALCulate<n>:LIMit<k>:LOWer:STATe............................................................................112
CALCulate<n>:LIMit<k>:STATe.......................................................................................112
CALCulate<n>:LIMit<k>:TRACe...................................................................................... 112
CALCulate<n>:LIMit<k>:TRACe<t>:CHECk......................................................................113
CALCulate<n>:LIMit<k>:UPPer:STATe............................................................................ 113
CALCulate<n>:LIMit<k>:ACTive?
This command queries the names of all active limit lines.
Suffix:
<n>, <k>
User Manual 1173.9286.02 ─ 14
.
irrelevant
109
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Return values:
<LimitLines>
String containing the names of all active limit lines in alphabetical order.
Example:
CALC:LIM:ACT?
Queries the names of all active limit lines.
Usage:
Query only
Manual operation:
See "Visible" on page 61
CALCulate<n>:LIMit<k>:CLEar[:IMMediate]
This command deletes the result of the current limit check.
The command works on all limit lines in all measurement windows at the same time.
Suffix:
<n>, <k>
.
irrelevant
Example:
CALC:LIM:CLE
Deletes the result of the limit check.
Usage:
SCPI confirmed
CALCulate<n>:LIMit<k>:COPY <Line>
This command copies a limit line.
Suffix:
<n>
.
Window
<k>
Limit line
Parameters:
<Line>
1 to 8
number of the new limit line
<name>
String containing the name of the limit line.
Example:
CALC:LIM1:COPY 2
Copies limit line 1 to line 2.
CALC:LIM1:COPY 'FM2'
Copies limit line 1 to a new line named FM2.
Manual operation:
See "New / Edit / Copy To" on page 62
CALCulate<n>:LIMit<k>:DELete
This command deletes a limit line.
Suffix:
<n>
.
Window
<k>
Limit line
User Manual 1173.9286.02 ─ 14
110
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Usage:
Event
Manual operation:
See "Delete" on page 62
CALCulate<n>:LIMit<k>:FAIL?
This command queries the result of a limit check in the specified window.
To get a valid result, you have to perform a complete measurement with synchronization to the end of the measurement before reading out the result. This is only possible
for single sweep mode.
See also INITiate<n>:CONTinuous on page 81.
Suffix:
<n>
.
Window
<k>
Limit line
Return values:
<Result>
0
PASS
1
FAIL
Example:
INIT;*WAI
Starts a new sweep and waits for its end.
CALC2:LIM3:FAIL?
Queries the result of the check for limit line 3 in window 2.
Usage:
Query only
SCPI confirmed
Manual operation:
See "Check Traces" on page 61
CALCulate<n>:LIMit<k>:NAME <Name>
This command selects a limit line that already exists or defines a name for a new limit
line.
Suffix:
<n>
.
Window
<k>
Limit line
Parameters:
<Name>
String containing the limit line name.
*RST:
Manual operation:
User Manual 1173.9286.02 ─ 14
REM1 to REM8 for lines 1 to 8
See "New / Edit / Copy To" on page 62
See "Name" on page 63
111
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
CALCulate<n>:LIMit<k>:LOWer:STATe <State>
This command turns a lower limit line on and off.
Before you can use the command, you have to select a limit line with CALCulate<n>:
LIMit<k>:NAME on page 111.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<State>
ON | OFF
*RST:
OFF
Usage:
SCPI confirmed
Manual operation:
See "Visible" on page 61
CALCulate<n>:LIMit<k>:STATe <State>
This command turns the limit check for a specific limit line on and off.
To query the limit check result, use CALCulate<n>:LIMit<k>:FAIL?.
Note that a new command exists to activate the limit check and define the trace to be
checked in one step (see CALCulate<n>:LIMit<k>:TRACe<t>:CHECk
on page 113).
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
CALC:LIM:STAT ON
Switches on the limit check for limit line 1.
Usage:
SCPI confirmed
Manual operation:
See "Check Traces" on page 61
CALCulate<n>:LIMit<k>:TRACe <TraceNumber>
This command links a limit line to one or more traces.
Note that this command is maintained for compatibility reasons only. Limit lines no longer need to be assigned to a trace explicitely. The trace to be checked can be defined
directly (as a suffix) in the new command to activate the limit check (see
CALCulate<n>:LIMit<k>:TRACe<t>:CHECk on page 113).
User Manual 1173.9286.02 ─ 14
112
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Suffix:
<n>
.
Window
<k>
Limit line
Example:
CALC:LIM2:TRAC 3
Assigns limit line 2 to trace 3.
Manual operation:
See "Check Traces" on page 61
CALCulate<n>:LIMit<k>:TRACe<t>:CHECk <State>
This command turns the limit check for a specific trace on and off.
To query the limit check result, use CALCulate<n>:LIMit<k>:FAIL?.
Note that this command replaces the two commands from previous signal and spectrum analyzers (which are still supported, however):
●
CALCulate<n>:LIMit<k>:TRACe on page 112
●
CALCulate<n>:LIMit<k>:STATe on page 112
Suffix:
<n>
.
Window
<k>
Limit line
<t>
Trace
Parameters:
<State>
ON | OFF
*RST:
Example:
OFF
CALC:LIM3:TRAC2:CHEC ON
Switches on the limit check for limit line 3 on trace 2.
CALCulate<n>:LIMit<k>:UPPer:STATe <State>
This command turns an upper limit line on and off.
Before you can use the command, you have to select a limit line with CALCulate<n>:
LIMit<k>:NAME on page 111.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<State>
ON | OFF
*RST:
OFF
Usage:
SCPI confirmed
Manual operation:
See "Visible" on page 61
User Manual 1173.9286.02 ─ 14
113
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
8.9.3 Creating and Editing Standard Limit Lines
CALCulate<n>:LIMit<k>:COMMent.................................................................................. 114
CALCulate<n>:LIMit<k>:CONTrol[:DATA].........................................................................114
CALCulate<n>:LIMit<k>:CONTrol:SHIFt...........................................................................114
CALCulate<n>:LIMit<k>:LOWer[:DATA]........................................................................... 115
CALCulate<n>:LIMit<k>:LOWer:MODE............................................................................115
CALCulate<n>:LIMit<k>:LOWer:SHIFt............................................................................. 116
CALCulate<n>:LIMit<k>:UPPer:MODE.............................................................................116
CALCulate<n>:LIMit<k>:UPPer[:DATA]............................................................................116
CALCulate<n>:LIMit<k>:UPPer:SHIFt.............................................................................. 117
CALCulate<n>:LIMit<k>:COMMent <Comment>
This command defines a comment for a limit line.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<Comment>
Manual operation:
String containing the description of the limit line. The comment
may have up to 40 characters.
See "Comment" on page 63
CALCulate<n>:LIMit<k>:CONTrol[:DATA] <LimitLinePoints>
This command defines the horizontal definition points of a limit line.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<LimitLinePoints>
Variable number of x-axis values.
Note that the number of horizontal values has to be the same as
the number of vertical values set with CALCulate<n>:
LIMit<k>:LOWer[:DATA] or CALCulate<n>:LIMit<k>:
UPPer[:DATA]. If not, the R&S FSW either adds missing values or ignores surplus values.
The unit is Hz.
*RST:
-
Usage:
SCPI confirmed
Manual operation:
See "Data Points" on page 64
CALCulate<n>:LIMit<k>:CONTrol:SHIFt <Distance>
This command moves a complete limit line horizontally.
User Manual 1173.9286.02 ─ 14
114
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
Compared to defining an offset, this command actually changes the limit line definition
points by the value you define.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<Distance>
Manual operation:
Numeric value.
The unit depends on the scale of the x-axis.
See "Shift X" on page 64
CALCulate<n>:LIMit<k>:LOWer[:DATA] <LimitLinePoints>
This command defines the vertical definition points of a lower limit line.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<LimitLinePoints>
Variable number of level values.
Note that the number of vertical values has to be the same as
the number of horizontal values set with CALCulate<n>:
LIMit<k>:CONTrol[:DATA]. If not, the R&S FSW either adds
missing values or ignores surplus values.
*RST:
Limit line state is OFF
Usage:
SCPI confirmed
Manual operation:
See "Data Points" on page 64
CALCulate<n>:LIMit<k>:LOWer:MODE <Mode>
This command selects the vertical limit line scaling.
Suffix:
<n>
.
Window
<k>
Limit line
Parameters:
<Mode>
ABSolute
Limit line is defined by absolute physical values.
The unit is variable.
RELative
Limit line is defined by relative values related to the reference
level (dB).
*RST:
Manual operation:
User Manual 1173.9286.02 ─ 14
ABSolute
See "X-Axis" on page 63
115
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Limit Lines
CALCulate<n>:LIMit<k>:LOWer:SHIFt <Distance>
This command moves a complete lower limit line vertically.
Compared to defining an offset, this command actually changes the limit line definition
points by the value you define.
Suffix:
<n>
.
Window
<k>
Limit line
Parameters:
<Distance>
Defines the distance that the limit line moves.
Manual operation:
See "Shift Y" on page 64
CALCulate<n>:LIMit<k>:UPPer:MODE <Mode>
This command selects the vertical limit line scaling.
Suffix:
<n>
.
Window
<k>
Limit line
Parameters:
<Mode>
ABSolute
Limit line is defined by absolute physical values.
The unit is variable.
RELative
Limit line is defined by relative values related to the reference
level (dB).
*RST:
Manual operation:
ABSolute
See "X-Axis" on page 63
CALCulate<n>:LIMit<k>:UPPer[:DATA] <LimitLinePoints>
This command defines the vertical definition points of an upper limit line.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<LimitLinePoints>
Variable number of level values.
Note that the number of vertical values has to be the same as
the number of horizontal values set with CALCulate<n>:
LIMit<k>:CONTrol[:DATA]. If not, the R&S FSW either adds
missing values or ignores surplus values.
*RST:
Usage:
User Manual 1173.9286.02 ─ 14
Limit line state is OFF
SCPI confirmed
116
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Manual operation:
See "Data Points" on page 64
CALCulate<n>:LIMit<k>:UPPer:SHIFt <Distance>
This command moves a complete upper limit line vertically.
Compared to defining an offset, this command actually changes the limit line definition
points by the value you define.
Suffix:
<n>
.
irrelevant
<k>
Limit line
Parameters:
<Distance>
Defines the distance that the limit line moves.
Usage:
Event
Manual operation:
See "Shift Y" on page 64
8.10 Graphical Display of Phase Noise Results
The following commands are necessary to set up and configure the graphical phase
noise result displays.
CALCulate<n>:MATH[:EXPression][:DEFine]....................................................................118
CALCulate<n>:MATH:STATe.......................................................................................... 118
DISPlay[:WINDow]:TRACe<t>:MODE.............................................................................. 118
DISPlay[:WINDow]:TRACe<t>:SMOothing:APERture........................................................ 119
DISPlay[:WINDow]:TRACe<t>:SMOothing[:STATe]........................................................... 119
DISPlay[:WINDow]:TRACe<t>:SMOothing:TYPE.............................................................. 119
DISPlay[:WINDow]:TRACe<t>:SPURs:SUPPress..............................................................120
DISPlay[:WINDow]:TRACe:X[:SCALe]:HDECade.............................................................. 120
DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe..................................................................121
DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt................................................................... 121
DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP....................................................................121
DISPlay[:WINDow]:TRACe:Y:[:SCALe].............................................................................122
DISPlay[:WINDow]:TRACe:Y[:SCALe]:AUTO....................................................................122
DISPlay[:WINDow]:TRACe:Y[:SCALe]:MANual................................................................. 122
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel..................................................................123
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:LOWer...................................................... 123
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:OFFSet..................................................... 124
FORMat:DEXPort:DSEParator........................................................................................ 124
FORMat:DEXPort:HEADer..............................................................................................124
FORMat:DEXPort:TRACes............................................................................................. 124
MMEMory:STORe<n>:TRACe.........................................................................................125
[SENSe:]SPURs:SUPPression........................................................................................ 125
[SENSe:]SPURs:THReshold........................................................................................... 126
TRACe<n>:COPY.......................................................................................................... 126
TRACe[:DATA]?............................................................................................................ 126
User Manual 1173.9286.02 ─ 14
117
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
CALCulate<n>:MATH[:EXPression][:DEFine] <Expression>
This command selects the mathematical expression for trace mathematics.
Before you can use the command, you have to turn trace mathematics on.
Suffix:
<n>
Parameters:
<Expression>
.
Window
(TRACE1-TRACE2)
Subtracts trace 2 from trace 1.
(TRACE1-TRACE3)
Subtracts trace 3 from trace 1.
(TRACE1-TRACE4)
Subtracts trace 4 from trace 1.
Example:
CALC:MATH:STAT ON
Turns trace mathematics on.
CALC:MATH:EXPR:DEF (TRACE1-TRACE3)
Subtracts trace 3 from trace 1.
Usage:
SCPI confirmed
Manual operation:
See "Trace Math" on page 56
CALCulate<n>:MATH:STATe <State>
This command turns the trace mathematics on and off.
Suffix:
<n>
.
Window
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
CALC:MATH:STAT ON
Turns on trace mathematics.
Usage:
SCPI confirmed
Manual operation:
See "Trace Math" on page 56
DISPlay[:WINDow]:TRACe<t>:MODE <Mode>
This command selects the trace mode.
Suffix:
<t>
.
Trace
Parameters:
<Mode>
WRITe | VIEW | AVERage | MAXHold | MINHold | BLANk
*RST:
User Manual 1173.9286.02 ─ 14
Trace 1/2: WRITe, Trace 3-6: BLANk
118
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Example:
INIT:CONT OFF
SWE:COUN 16
Turns on single sweep mode and defines a count of 16 measurements.
DISP:TRAC2:MODE AVER
Select average trace mode for trace 2.
INIT;*WAI
Performs the measurement (16 sweeps) with synchronization to
the end.
Manual operation:
See "Traces" on page 54
DISPlay[:WINDow]:TRACe<t>:SMOothing:APERture <Aperture>
This command defines the degree (aperture) of the trace smoothing.
A single aperture applies to all traces which require smoothing.
Suffix:
<t>
Parameters:
<Aperture>
.
Trace
Range:
1 to 20
*RST:
0
Default unit: PCT
Example:
DISP:TRAC:SMO:APER 5
Defines an aperture of 5%.
Usage:
SCPI confirmed
Manual operation:
See "Trace Smoothing" on page 53
DISPlay[:WINDow]:TRACe<t>:SMOothing[:STATe] <State>
This command turns trace smoothing for a particular trace on and off.
Suffix:
<t>
.
Trace
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
DISP:TRAC2:SMO ON
Turns on trace smoothing for trace 2.
Usage:
SCPI confirmed
Manual operation:
See "Traces" on page 54
DISPlay[:WINDow]:TRACe<t>:SMOothing:TYPE <Type>
This command selects the trace smoothing method.
User Manual 1173.9286.02 ─ 14
119
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Suffix:
<t>
Parameters:
<Type>
.
Trace
LINear
Linear smoothing.
LOGarithmic
Logarithmic smoothing.
MEDian
Median smoothing.
*RST:
LIN
Example:
DISP:TRAC2:SMO:TYPE LIN
Selects linear smoothing for trace 2.
Usage:
SCPI confirmed
Manual operation:
See "Smoothing Type" on page 53
DISPlay[:WINDow]:TRACe<t>:SPURs:SUPPress <State>
This command turns spur suppression on individual traces on and off.
Suffix:
<t>
.
Trace
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
DISP:TRAC3:SPUR:SUPP ON
Turns on spur suppression on trace 3.
Manual operation:
See "Traces" on page 54
DISPlay[:WINDow]:TRACe:X[:SCALe]:HDECade <HalfDecade>
This command selects the half decade to be displayed.
Before you can use the command you have to select the half decade scope for the xaxis with DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe.
Parameters:
<HalfDecade>
Start offset frequency of the half decade you want to display.
Note that the half decade you want to display has to be part of
the current measurement range.
Range:
*RST:
100 mHz...300 mHz to 3 GHz...10GHz
Half decade display is off.
Example:
DISP:TRAC:X:HDEC 1KHZ
Displays the half decade beginning with 1 kHz.
Manual operation:
See "Half Decade" on page 52
User Manual 1173.9286.02 ─ 14
120
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe <Scope>
This command selects the way the application scales the horizontal axis.
Parameters:
<Scope>
HDECade
Shows a particular half decade only.
You can select a particular half decade with .
MANual
Shows a custom part of the measurement range.
You can select the start and stop offsets with .
MRANGe
Shows the complete measurement range.
*RST:
MRANGe
Example:
DISP:TRAC:X:SCOP MRAN
Shows the complete measurement range on the x-axis.
Manual operation:
See "X-Axis Scope" on page 51
DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt <StartFrequency>
This command selects the start frequency of the display range.
Before you can use the command you have to select a manual display range for the xaxis with DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe.
Parameters:
<StartFrequency>
Start offset frequency of a half decade.
Note that the start offset you want to display has to be part of the
current measurement range.
Range:
*RST:
100 mHz to 3 GHz
Manual display range is OFF
Example:
DISP:TRAC:X:STAR 100HZ
Defines 100 Hz as the start of the display range.
Manual operation:
See "X-Axis Start / Stop" on page 52
DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP <StopFrequency>
This command selects the stop frequency of the display range.
Before you can use the command you have to select a manual display range for the xaxis with DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe.
Parameters:
<StopFrequency>
Stop offset frequency of a half decade.
Note that the stop offset you want to display has to be part of the
current measurement range.
Range:
*RST:
User Manual 1173.9286.02 ─ 14
300 mHz to 10 GHz
Manual display range is OFF
121
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Example:
DISP:TRAC:X:STOP 3KHZ
Defines 3 kHz as the end of the display range.
Manual operation:
See "X-Axis Start / Stop" on page 52
DISPlay[:WINDow]:TRACe:Y:[:SCALe] <Range>
This command defines the display range.
Note that you have to select manual y-axis scaling before you can use the command.
Parameters:
<Range>
Range:
1 to 200
*RST:
100
Default unit: dB
Example:
DISP:TRAC:Y 80
Defines a display range over 80 dB.
Manual operation:
See "Top / Range / Bottom" on page 52
DISPlay[:WINDow]:TRACe:Y[:SCALe]:AUTO <Mode>
This command turns automatic scaling of the vertical axis on and off.
Parameters:
<Mode>
ON
Automatic scaling is on.
OFF
Automatic scaling is off.
ONCE
Automatic scaling is performed once, then turned off again.
*RST:
ON
Example:
DISP:WIND2:TRAC:Y:SCAL:AUTO ONCE
Scales the vertical axis once.
Manual operation:
See "Y Axis Scaling" on page 52
DISPlay[:WINDow]:TRACe:Y[:SCALe]:MANual <Mode>
This command selects the type of manual scaling of the vertical axis.
User Manual 1173.9286.02 ─ 14
122
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Parameters:
<Mode>
BRANge
Scaling based on the value at the bottom of the diagram and the
axis range.
OFF
Turns manual scaling of the y-axis off.
TBOTtom
Scaling based on the values on the bottom and top of the diagram.
TRANge
Scaling based on the value at the top of the diagram and the
axis range.
*RST:
ON
Example:
DISP:WIND2:TRAC:Y:SCAL:MAN TRAN
Scaling of the vertical axis based on the top and the range of the
axis.
Manual operation:
See "Y Axis Scaling" on page 52
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel <Reference>
This command defines the reference value or upper border of the diagram area.
Note that you have to select manual y-axis scaling before you can use the command.
Parameters:
<Reference>
Range:
-200 to 0
*RST:
-20
Default unit: dBc/Hz
Example:
DISP:TRAC:Y:RLEV -50
Defines a reference value of -50 dBc/Hz.
Manual operation:
See "Top / Range / Bottom" on page 52
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:LOWer <LowerReference>
This command defines the reference value or upper border of the diagram area.
Note that you have to select manual y-axis scaling before you can use the command.
Parameters:
<LowerReference>
Range:
-400 to 1
*RST:
-120
Default unit: dBc/Hz
Example:
DISP:TRAC:Y:RLEV:LOW -100
Sets the bottom of the diagram to .100 dBc/Hz.
Manual operation:
See "Top / Range / Bottom" on page 52
User Manual 1173.9286.02 ─ 14
123
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:OFFSet <Offset>
This command defines the trace offset.
Parameters:
<Offset>
Range:
-200 to 200
*RST:
0dB
Default unit: dB
Example:
DISP:TRAC:Y:RLEV:OFFS -10
Defines a trace offset of -10 dB.
Manual operation:
See "Trace Offset" on page 53
FORMat:DEXPort:DSEParator <Separator>
This command selects the decimal separator for data exported in ASCII format.
Parameters:
<Separator>
COMMa
Uses a comma as decimal separator, e.g. 4,05.
POINt
Uses a point as decimal separator, e.g. 4.05.
*RST:
*RST has no effect on the decimal separator.
Default is POINt.
Example:
FORM:DEXP:DSEP POIN
Sets the decimal point as separator.
Manual operation:
See "Trace Export" on page 55
FORMat:DEXPort:HEADer <State>
If enabled, additional instrument and measurement settings are included in the header
of the export file for result data. If disabled, only the pure result data from the selected
traces and tables is exported.
Parameters:
<State>
ON | OFF | 0 | 1
*RST:
1
Usage:
SCPI confirmed
Manual operation:
See "Trace Export" on page 55
FORMat:DEXPort:TRACes <Selection>
This command selects the data to be included in a data export file (see MMEMory:
STORe<n>:TRACe on page 125).
User Manual 1173.9286.02 ─ 14
124
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Parameters:
<Selection>
SINGle
Only a single trace is selected for export, namely the one specified by the MMEMory:STORe<n>:TRACe command.
ALL
Selects all active traces and result tables (e.g. Result Summary,
marker peak list etc.) in the current application for export to an
ASCII file.
The <trace> parameter for the MMEMory:STORe<n>:TRACe
command is ignored.
*RST:
SINGle
Usage:
SCPI confirmed
Manual operation:
See "Trace Export" on page 55
MMEMory:STORe<n>:TRACe <Trace>, <FileName>
This command exports trace data from the specified window to an ASCII file.
Secure User Mode
In secure user mode, settings that are stored on the instrument are stored to volatile
memory, which is restricted to 256 MB. Thus, a "Memory full" error can occur although
the hard disk indicates that storage space is still available.
To store data permanently, select an external storage location such as a USB memory
device.
For details, see "Protecting Data Using the Secure User Mode" in the "Data Management" section of the R&S FSW User Manual.
Suffix:
<n>
.
Window
Parameters:
<Trace>
Number of the trace to be stored
<FileName>
String containing the path and name of the target file.
Example:
MMEM:STOR1:TRAC 3,'C:\TEST.ASC'
Stores trace 3 from window 1 in the file TEST.ASC.
Usage:
SCPI confirmed
Manual operation:
See "Trace Export" on page 55
[SENSe:]SPURs:SUPPression <State>
This command turns spur suppression on and off.
Parameters:
<State>
ON | OFF
*RST:
User Manual 1173.9286.02 ─ 14
ON
125
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Graphical Display of Phase Noise Results
Example:
SPUR:SUPP OFF
Turns spur suppression off.
Manual operation:
See "Spur Removal / Spur Threshold" on page 56
[SENSe:]SPURs:THReshold <Threshold>
This command defines the level threshold for spur removal.
Parameters:
<Threshold>
Range:
0 to 50
*RST:
0
Default unit: dB
Example:
SPUR:THR 10
Defines a spur threshold of 50 dB.
Manual operation:
See "Spur Removal / Spur Threshold" on page 56
TRACe<n>:COPY <TraceNumber>, <TraceNumber>
This command copies data from one trace to another.
Suffix:
<n>
Parameters:
<TraceNumber>,
<TraceNumber>
.
Window
TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 | TRACE6
The first parameter is the destination trace, the second parameter is the source.
(Note the 'e' in the parameter is required!)
Example:
TRAC:COPY TRACE1,TRACE2
Copies the data from trace 2 to trace 1.
Usage:
SCPI confirmed
Manual operation:
See "Copy Trace" on page 55
TRACe[:DATA]? <Trace>
This command queries the results of the graphical result displays.
Parameters:
<Trace>
User Manual 1173.9286.02 ─ 14
TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 | TRACE6
126
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Return values:
<Frequency>,
<Level>
Phase noise:
Coordinates of the phase noise trace as list of comma separated
values, beginning at the nearest offset frequency.
<OffsetFrequency1>,<Level1>,<OffsetFrequency2>,<Level2>,...
Spectrum monitor:
Coordinates of the spectrum trace as a list of comma separated
values, beginning at the left border of the display.
<Frequency1>,<Level1>,<Frequency2>,<Level2>,...
<Time>, <Frequency>Frequency drift:
Coordinates of the frequency drift trace as a list of comma separated values, beginning at the left border of the display.
<Time1>,<Frequency1>,<Time2>,<Frequency2>,...
Example:
TRAC? TRACE1
Queries the data of trace 1.
Usage:
Query only
Manual operation:
See "Phase Noise Diagram" on page 14
See "Spectrum Monitor" on page 19
8.11 Configure Numerical Result Displays
The following commands are necessary to configure the numerical phase noise result
displays.
●
●
●
●
●
●
Configuring Residual Noise Measurements..........................................................127
Reading Out Residual Noise Results....................................................................130
Configuring Spot Noise Measurements................................................................ 132
Reading Out the Spur List.....................................................................................135
Reading Out Measured Values............................................................................. 136
Reading Out the Sweep Result List...................................................................... 137
8.11.1 Configuring Residual Noise Measurements
CALCulate<n>:EVALuation:STARt...................................................................................127
CALCulate<n>:EVALuation[:STATe]................................................................................ 128
CALCulate<n>:EVALuation:STOP................................................................................... 128
CALCulate<n>:EVALuation:USER<range>:STARt.............................................................129
CALCulate<n>:EVALuation:USER<range>:STOP............................................................. 129
CALCulate<n>:EVALuation:USER<range>:TRACe............................................................129
CALCulate<n>:EVALuation:STARt <OffsetFrequency>
This command defines the start point of the residual noise integration range.
Before you can use the command, you have to turn on the measurement range integration with CALCulate<n>:EVALuation[:STATe] on page 128.
User Manual 1173.9286.02 ─ 14
127
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Suffix:
<n>
Parameters:
<OffsetFrequency>
.
Window
The minimum offset is 1 Hz. The maximum offset depends on
the hardware you are using.
*RST:
1 kHz
Example:
CALC:EVAL:STAR 1 kHz
Defines an start point of 1 kHz for the residual noise range.
Manual operation:
See "Meas Range" on page 57
CALCulate<n>:EVALuation[:STATe] <State>
This command turn integration of the measurement range for residual noise calculation
on and off.
Suffix:
<n>
Parameters:
<State>
.
Window
OFF
Calculates the residual noise over the entire measurement
range.
ON
Calculates the residual noise over a customized range.
*RST:
OFF
Example:
CALC:EVAL ON
Uses a customized offset range for residual noise calculation.
Manual operation:
See "Meas Range" on page 57
CALCulate<n>:EVALuation:STOP <OffsetFrequency>
This command defines the end point of the residual noise integration range.
Before you can use the command, you have to turn on the measurement range integration with CALCulate<n>:EVALuation[:STATe] on page 128.
Suffix:
<n>
Parameters:
<OffsetFrequency>
.
Window
The minimum offset is 1 Hz. The maximum offset depends on
the hardware you are using.
*RST:
1 MHz
Example:
CALC:EVAL:STOP 1 MHZ
Defines an end point of 1 MHz for the residual noise range.
Manual operation:
See "Meas Range" on page 57
User Manual 1173.9286.02 ─ 14
128
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
CALCulate<n>:EVALuation:USER<range>:STARt <OffsetFrequency>
This command defines the start point of a custom residual noise calculation range.
Before you can use the command, you have to assign the user range to a trace with
CALCulate<n>:EVALuation:USER<range>:TRACe on page 129.
Suffix:
<n>
Parameters:
<OffsetFrequency>
.
Window
The minimum offset is 1 Hz. The maximum offset depends on
the hardware you are using.
*RST:
1 MHz
Example:
CALC:EVAL:USER2:STAR 1khz
Defines a start point of 1 kHz for the second user range.
Manual operation:
See "User Range" on page 57
CALCulate<n>:EVALuation:USER<range>:STOP <OffsetFrequency>
This command defines the end point of a custom residual noise calculation range.
Before you can use the command, you have to assign the user range to a trace with
CALCulate<n>:EVALuation:USER<range>:TRACe on page 129.
Suffix:
<n>
Parameters:
<OffsetFrequency>
.
Window
The minimum offset is 1 Hz. The maximum offset depends on
the hardware you are using.
*RST:
1 MHz
Example:
CALC:EVAL:USER2:STOP 100kHz
Defines an end point of 100 kHz for the second user range.
Manual operation:
See "User Range" on page 57
CALCulate<n>:EVALuation:USER<range>:TRACe <Trace>
This command selects the trace for a custom residual noise calculation range.
Suffix:
<n>
.
Window
<range>
1...3
Selects the user range.
Parameters:
<Trace>
NONE
Turns a user range off.
TRACE1 ... TRACE6
Trace to assign the user range to.
User Manual 1173.9286.02 ─ 14
129
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Example:
CALC:EVAL:USER2:TRAC TRACE2
Assigns the second user range to trace 2.
Manual operation:
See "User Range" on page 57
8.11.2 Reading Out Residual Noise Results
FETCh:PNOise:IPN?......................................................................................................130
FETCh:PNOise<t>:RFM?................................................................................................130
FETCh:PNOise<t>:RMS?............................................................................................... 130
FETCh:PNOise<t>:RPM?............................................................................................... 131
FETCh:PNOise<t>:USER<range>:IPN?........................................................................... 131
FETCh:PNOise<t>:USER<range>:RFM?..........................................................................131
FETCh:PNOise<t>:USER<range>:RMS?......................................................................... 131
FETCh:PNOise<t>:USER<range>:RPM?......................................................................... 132
FETCh:PNOise:IPN?
This command queries the Integrated Phase Noise for the first trace.
Example:
FETC:PNO2:IPN?
Queries the Integrated Phase Noise for the first trace in the diagram.
Usage:
Query only
FETCh:PNOise<t>:RFM?
This command queries the residual FM for the first trace.
Suffix:
<t>
.
Trace
Example:
FETC:PNO2:RFM?
Queries the residual FM for the first trace in the diagram.
Usage:
Query only
Manual operation:
See "Residual Noise" on page 15
FETCh:PNOise<t>:RMS?
This command queries the residual RMS jitter for the first trace.
Suffix:
<t>
.
Trace
Example:
FETC:PNO2:RMS?
Queries the RMS jitter for the first trace in the diagram.
Usage:
Query only
Manual operation:
See "Residual Noise" on page 15
User Manual 1173.9286.02 ─ 14
130
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
FETCh:PNOise<t>:RPM?
This command queries the residual PM for the first trace.
Suffix:
<t>
.
Trace
Example:
FETC:PNO:RPM?
Queries the residual PM for the first trace of the diagram.
Usage:
Query only
Manual operation:
See "Residual Noise" on page 15
FETCh:PNOise<t>:USER<range>:IPN?
This command queries the Integrated Phase Noise for a particular user range.
The trace that is queried depends on CALCulate<n>:EVALuation:USER<range>:
TRACe.
Suffix:
<t>
.
Trace
<range>
1...3
Selects the user range.
Example:
FETC:PNO:USER2:IPN?
Queries the Integrated Phase Noise for user range 2.
Usage:
Query only
FETCh:PNOise<t>:USER<range>:RFM?
This command queries the residual FM for a particular user range.
The trace that is queried depends on CALCulate<n>:EVALuation:USER<range>:
TRACe.
Suffix:
<t>
.
Trace
<range>
1...3
Selects the user range.
Example:
FETC:PNO:USER2:RFM?
Queries the residual FM for user range 2.
Usage:
Query only
Manual operation:
See "Residual Noise" on page 15
FETCh:PNOise<t>:USER<range>:RMS?
This command queries the residual RMS jitter for a particular user range.
User Manual 1173.9286.02 ─ 14
131
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
The trace that is queried depends on CALCulate<n>:EVALuation:USER<range>:
TRACe.
Suffix:
<t>
.
Trace
<range>
1...3
Selects the user range.
Example:
FETC:PNO:USER2:RMS?
Queries the RMS jitter for user range 2.
Usage:
Query only
Manual operation:
See "Residual Noise" on page 15
FETCh:PNOise<t>:USER<range>:RPM?
This command queries the residual PM for a particular user range.
The trace that is queried depends on CALCulate<n>:EVALuation:USER<range>:
TRACe.
Suffix:
<t>
.
Trace
<range>
1...3
Selects the user range.
Example:
FETC:PNO:USER2:RPM?
Queries the residual PM for user range 2.
Usage:
Query only
Manual operation:
See "Residual Noise" on page 15
8.11.3 Configuring Spot Noise Measurements
CALCulate<n>:SNOise:AOFF......................................................................................... 132
CALCulate<n>:SNOise:DECades[:STATe]....................................................................... 133
CALCulate<n>:SNOise:DECades:X?............................................................................... 133
CALCulate<n>:SNOise:DECades:Y?............................................................................... 133
CALCulate<n>:SNOise<m>:STATe................................................................................. 134
CALCulate<n>:SNOise<m>:X......................................................................................... 134
CALCulate<n>:SNOise<m>:Y?........................................................................................135
DISPlay[:WINDow<n>]:TRACe<t>:SELect........................................................................ 135
CALCulate<n>:SNOise:AOFF
This command turns all spot noise markers off (custom and 10x markers).
Suffix:
<n>
User Manual 1173.9286.02 ─ 14
.
Window
132
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Example:
CALC:SNO:AOFF
Turns all spot noise markers off.
Usage:
Event
Manual operation:
See "On User Defined Offsets / Offset Frequency" on page 58
CALCulate<n>:SNOise:DECades[:STATe] <State>
This command turns the spot noise calculation on every 10x offset frequency on and
off.
Suffix:
<n>
.
Window
Parameters:
<State>
ON | OFF
*RST:
ON
Example:
CALC:SNO:DEC ON
Turns the spot noise calculation for each decade start on.
Manual operation:
See "On All Decade Edges" on page 58
CALCulate<n>:SNOise:DECades:X?
This command queries the horizontal poistion of the 10x offset frequency spot noise
markers.
Suffix:
<n>
Return values:
<OffsetFrequency>
.
Window
List of offset frequencies, one for each 10x spot noise marker.
The number of return values depends on the measurement
range.
Default unit: Hz
Example:
CALC:SNO:DEC:X?
Return values, e.g.:
1000,10000,100000,1000000
Usage:
Query only
Manual operation:
See "Spot Noise" on page 16
See "On All Decade Edges" on page 58
CALCulate<n>:SNOise:DECades:Y?
This command queries the vertical poistion of the 10x offset frequency spot noise markers.
Suffix:
<n>
User Manual 1173.9286.02 ─ 14
.
Window
133
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Return values:
<Level>
List of level values, one for each 10x spot noise marker. The
number of return values depends on the measurement range.
Default unit: dBc/Hz
Example:
CALC:SNO:DEC:Y?
Return values, e.g.:
-152.560974121094,-136.443389892578,
-145.932891845703,-152.560974121094
Usage:
Query only
Manual operation:
See "Spot Noise" on page 16
See "On All Decade Edges" on page 58
CALCulate<n>:SNOise<m>:STATe <State>
This command turns a custom spot noise marker on and off.
Suffix:
<n>
.
Window
<m>
1...5
Selects the spot noise marker.
Parameters:
<State>
ON | OFF
*RST:
All ON
Example:
CALC:SNO3:STATE ON
Turns spot noise marker 3 on.
Manual operation:
See "On User Defined Offsets / Offset Frequency" on page 58
CALCulate<n>:SNOise<m>:X <OffsetFrequency>
This command defines the horizontal position of a custom spot noise marker.
Suffix:
<n>
.
Window
<m>
1...5
Selects the spot noise marker.
Parameters:
<OffsetFrequency>
User Manual 1173.9286.02 ─ 14
The minimum offset is 1 Hz. The maximum offset depends on
the hardware you are using.
The default value varies for each of the five spot noise markers.
For marker 1 it is 1 kHz, for marker 2 it is 10 kHz, for marker 3 it
is 100 kHz, for marker 4 it is 1 MHz and for marker 5 it is
10 MHz
134
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Example:
CALC:SNO3:X 2MHz
Positions the third custom spot noise marker to an offset frequency of 2 MHz.
Manual operation:
See "On User Defined Offsets / Offset Frequency" on page 58
CALCulate<n>:SNOise<m>:Y?
This command queries the vertical position of a custom spot noise marker.
Suffix:
<n>
.
Window
<m>
1...5
Selects the spot noise marker
Return values:
<Level>
<numeric value>
Phase noise level at the marker position.
Default unit: dBc/Hz
Example:
CALC:SNO3:Y?
Queries the level of the third custom spot noise marker.
Usage:
Query only
Manual operation:
See "Spot Noise" on page 16
See "On User Defined Offsets / Offset Frequency" on page 58
DISPlay[:WINDow<n>]:TRACe<t>:SELect <Trace>
This command selects the trace for which spot noise results are calculated.
A trace can only be selected if it has been turned on ("Trace Mode" ≠ Blank).
Suffix:
<n>, <t>
.
irrelevant
Parameters:
<Trace>
Number of the trace you want to select.
Range:
*RST:
1 to 6
1
Example:
DISP:TRAC:SEL 2
Selects trace number 2.
Manual operation:
See "Spot Noise" on page 16
8.11.4 Reading Out the Spur List
FETCh:PNOise:SPURs?.................................................................................................136
FETCh:PNOise:SPURs:DISCrete?.................................................................................. 136
FETCh:PNOise:SPURs:RANDom?.................................................................................. 136
User Manual 1173.9286.02 ─ 14
135
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
FETCh:PNOise:SPURs?
This command queries the location and level of all spurs that have been detected.
Return values:
<Spurs>
Returns two values (frequency and level) for each each spur that
has been detected.
Example:
FETC:PNO:SPUR?
would return, e.g.
1999.232666,-0.639974,6494.312500,-0.760579,
19992.324219,-0.639974
Usage:
Query only
Manual operation:
See "Spur List" on page 17
FETCh:PNOise:SPURs:DISCrete?
This command queries the Discrete Jitter result.
Return values:
<Jitter>
Default unit: s
Example:
FETC:PNO:SPUR:DISC?
would return, e.g.
2.3e-08
Usage:
Query only
Manual operation:
See "Spur List" on page 17
FETCh:PNOise:SPURs:RANDom?
This command queries the Random Jitter result.
Return values:
<Jitter>
Default unit: s
Example:
FETC:PNO:SPUR:RAND?
would return, e.g.
3.59e-09
Usage:
Query only
Manual operation:
See "Spur List" on page 17
8.11.5 Reading Out Measured Values
FETCh:PNOise:MEASured:FREQuency?......................................................................... 137
FETCh:PNOise:MEASured:LEVel?.................................................................................. 137
User Manual 1173.9286.02 ─ 14
136
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
FETCh:PNOise:MEASured:FREQuency?
This command queries the carrier frequency that has been actually measured.
The measured frequency is shown in the channel bar.
Return values:
<Frequency>
Frequency in Hz.
Example:
FETC:PNO:MEAS:FREQ?
Queries the measured frequency.
Usage:
Query only
FETCh:PNOise:MEASured:LEVel?
This command queries the level of the DUT that has been actually measured.
The measured level is shown in the channel bar.
Return values:
<Level>
Level in dBm.
Example:
FETC:PNO:MEAS:LEV?
Queries the measured level.
Usage:
Query only
8.11.6 Reading Out the Sweep Result List
FETCh:PNOise:SWEep:AVG?.........................................................................................137
FETCh:PNOise:SWEep:FDRift?...................................................................................... 138
FETCh:PNOise:SWEep:LDRift?...................................................................................... 138
FETCh:PNOise:SWEep:MDRift?..................................................................................... 138
FETCh:PNOise:SWEep:SRATe?.....................................................................................139
FETCh:PNOise:SWEep:STARt?......................................................................................139
FETCh:PNOise:SWEep:STOP?.......................................................................................139
FETCh:PNOise:SWEep:AVG?
This command queries the number of measurements that have been performed in
each half decade.
Return values:
<Measurements>
Number of measurements as displayed in the Sweep Result
List.
The command returns one value for each half decade as a
comma separated list.
Example:
FETC:PNO:SWE:AVG?
would return, e.g.:
10,10,10,10,10
Usage:
Query only
User Manual 1173.9286.02 ─ 14
137
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Manual operation:
See "Sweep Result List" on page 18
FETCh:PNOise:SWEep:FDRift?
This command queries the frequency drift in each half decade.
Return values:
<Frequency>
Frequency drift as displayed in the Sweep Result List.
The command returns one value for each half decade as a
comma separated list.
Default unit: Hz
Example:
FETC:PNO:SWE:FDR?
would return, e.g.:
-203.565049124882,-198.254803592339,
-179.608235809952,-126.506989398971,
-95.0386250484735
Usage:
Query only
Manual operation:
See "Sweep Result List" on page 18
FETCh:PNOise:SWEep:LDRift?
This command queries the level drift in each half decade.
Return values:
<Level>
Level drift as displayed in the Sweep Result List.
The command returns one value for each half decade as a
comma separated list.
Default unit: dB
Example:
FETC:PNO:SWE:LDR?
would return, e.g.:
0.84823463324,6.55278904401,1.02393361087,
2.10021296216,5.28119567376
Usage:
Query only
Manual operation:
See "Sweep Result List" on page 18
FETCh:PNOise:SWEep:MDRift?
This command queries the maximum frequency drift in each half decade.
Return values:
<Frequency>
Frequency drift as displayed in the Sweep Result List.
The command returns one value for each half decade as a
comma separated list.
Default unit: Hz
User Manual 1173.9286.02 ─ 14
138
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configure Numerical Result Displays
Example:
FETC:PNO:SWE:MDR?
would return, e.g.:
2.17,11.45,105.11,219.37,553.48
Usage:
Query only
Manual operation:
See "Sweep Result List" on page 18
FETCh:PNOise:SWEep:SRATe?
This command queries the sampling rate used in each half decade.
Return values:
<SamplingRate>
Sampling rate as displayed in the Sweep Result List.
The command returns one value for each half decade as a
comma separated list.
Default unit: Hz
Example:
FETC:PNO:SWE:SRAT?
would return, e.g.:
25000,75000,250000,750000,2500000
Usage:
Query only
Manual operation:
See "Sweep Result List" on page 18
FETCh:PNOise:SWEep:STARt?
This command queries the start frequency offset of each half decade.
Return values:
<Frequency>
Frequency offset as displayed in the Sweep Result List.
The command returns one value for each half decade as a
comma separated list.
Default unit: Hz
Example:
FETC:PNO:SWE:STAR?
would return, e.g.:
1000,3000,10000,30000,100000
Usage:
Query only
Manual operation:
See "Sweep Result List" on page 18
FETCh:PNOise:SWEep:STOP?
This command queries the stop frequency offset of each half decade.
Return values:
<Measurements>
Frequency offset as displayed in the Sweep Result List.
The command returns one value for each half decade as a
comma separated list.
Default unit: Hz
User Manual 1173.9286.02 ─ 14
139
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Markers
Example:
FETC:PNO:SWE:STOP?
would return, e.g.:
3000,10000,30000,100000,300000
Usage:
Query only
Manual operation:
See "Sweep Result List" on page 18
8.12 Using Markers
The following commands are necessary to control markers.
●
●
●
●
Using Markers....................................................................................................... 140
Using Delta Markers..............................................................................................142
Configuring Markers..............................................................................................145
Using the Marker Zoom.........................................................................................146
8.12.1 Using Markers
CALCulate<n>:MARKer<m>:AOFF..................................................................................140
CALCulate<n>:MARKer<m>[:STATe]...............................................................................140
CALCulate<n>:MARKer<m>:TRACe................................................................................141
CALCulate<n>:MARKer<m>:X........................................................................................ 141
CALCulate<n>:MARKer<m>:Y?.......................................................................................142
CALCulate<n>:MARKer<m>:AOFF
This command turns all markers off.
Suffix:
<n>
.
Window
<m>
Marker
Example:
CALC:MARK:AOFF
Switches off all markers.
Usage:
Event
Manual operation:
See "All Markers Off" on page 66
CALCulate<n>:MARKer<m>[:STATe] <State>
This command turns markers on and off. If the corresponding marker number is currently active as a deltamarker, it is turned into a normal marker.
Suffix:
<n>
.
Window
<m>
Marker
User Manual 1173.9286.02 ─ 14
140
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Markers
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
CALC:MARK3 ON
Switches on marker 3.
Manual operation:
See "Marker 1 ... Marker x" on page 65
See "Marker Type" on page 66
CALCulate<n>:MARKer<m>:TRACe <Trace>
This command selects the trace the marker is positioned on.
Note that the corresponding trace must have a trace mode other than "Blank".
If necessary, the command activates the marker first.
Suffix:
<n>
.
Window
<m>
Marker
Parameters:
<Trace>
1 to 6
Trace number the marker is assigned to.
Example:
CALC:MARK3:TRAC 2
Assigns marker 3 to trace 2.
Manual operation:
See "Assigning the Marker to a Trace" on page 66
CALCulate<n>:MARKer<m>:X <Position>
This command moves a marker to a particular coordinate on the x-axis.
If necessary, the command activates the marker.
If the marker has been used as a delta marker, the command turns it into a normal
marker.
Suffix:
<n>
.
Window
<m>
Marker
Parameters:
<Position>
Numeric value that defines the marker position on the x-axis.
Default unit: Hz
Example:
User Manual 1173.9286.02 ─ 14
CALC:MARK2:X 1.7MHz
Positions marker 2 to frequency 1.7 MHz.
141
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Markers
CALCulate<n>:MARKer<m>:Y?
This command queries the position of a marker on the y-axis.
If necessary, the command activates the marker first.
To get a valid result, you have to perform a complete measurement with synchronization to the end of the measurement before reading out the result. This is only possible
for single sweep mode.
See also INITiate<n>:CONTinuous on page 81.
Suffix:
<n>
.
Window
<m>
Marker
Return values:
<Level>
Phase noise level of the marker.
Default unit: dBc/Hz
Example:
INIT:CONT OFF
Switches to single measurement mode.
CALC:MARK2 ON
Switches marker 2.
INIT;*WAI
Starts a measurement and waits for the end.
CALC:MARK2:Y?
Outputs the measured value of marker 2.
Usage:
Query only
8.12.2 Using Delta Markers
CALCulate<n>:DELTamarker<m>:AOFF.......................................................................... 142
CALCulate<n>:DELTamarker<m>:MREF......................................................................... 143
CALCulate<n>:DELTamarker<m>[:STATe].......................................................................143
CALCulate<n>:DELTamarker<m>:TRACe........................................................................ 143
CALCulate<n>:DELTamarker<m>:X................................................................................ 144
CALCulate<n>:DELTamarker<m>:Y?...............................................................................144
CALCulate<n>:DELTamarker<m>:AOFF
This command turns all delta markers off.
Suffix:
<n>
.
Window
<m>
irrelevant
Example:
CALC:DELT:AOFF
Turns all delta markers off.
Usage:
Event
User Manual 1173.9286.02 ─ 14
142
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Markers
CALCulate<n>:DELTamarker<m>:MREF <Reference>
This command selects a reference marker for a delta marker other than marker 1.
The reference may be another marker or the fixed reference.
Suffix:
<n>
.
Window
<m>
Marker
Parameters:
<Reference>
1 to 16
Selects markers 1 to 16 as the reference.
FIXed
Selects the fixed reference as the reference.
Example:
CALC:DELT3:MREF 2
Specifies that the values of delta marker 3 are relative to marker
2.
Manual operation:
See "Reference Marker" on page 66
CALCulate<n>:DELTamarker<m>[:STATe] <State>
This command turns delta markers on and off.
If necessary, the command activates the delta marker first.
No suffix at DELTamarker turns on delta marker 1.
Suffix:
<n>
.
Window
<m>
Marker
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
CALC:DELT2 ON
Turns on delta marker 2.
Manual operation:
See "Marker 1 ... Marker x" on page 65
See "Marker Type" on page 66
CALCulate<n>:DELTamarker<m>:TRACe <Trace>
This command selects the trace a delta marker is positioned on.
Note that the corresponding trace must have a trace mode other than "Blank".
If necessary, the command activates the marker first.
Suffix:
<n>
User Manual 1173.9286.02 ─ 14
.
Window
143
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Markers
<m>
Marker
Parameters:
<Trace>
Trace number the marker is assigned to.
Example:
CALC:DELT2:TRAC 2
Positions delta marker 2 on trace 2.
CALCulate<n>:DELTamarker<m>:X <Position>
This command moves a delta marker to a particular coordinate on the x-axis.
If necessary, the command activates the delta marker and positions a reference
marker to the peak power.
Suffix:
<n>
.
Window
<m>
Marker
Parameters:
<Position>
The position is relative to the reference marker.
The unit is Hz (offset frequency).
A query returns the absolute position of the delta marker.
Range:
Example:
The value range depends on the current measurement range.
CALC:DELT:X?
Outputs the absolute frequency/time of delta marker 1.
CALCulate<n>:DELTamarker<m>:Y?
This command queries the relative position of a delta marker on the y-axis.
If necessary, the command activates the delta marker first.
To get a valid result, you have to perform a complete measurement with synchronization to the end of the measurement before reading out the result. This is only possible
for single sweep mode.
See also INITiate<n>:CONTinuous on page 81.
Suffix:
<n>
.
Window
<m>
Marker
Return values:
<Level>
Phase noise level.
Default unit: dBc/Hz
User Manual 1173.9286.02 ─ 14
144
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using Markers
Example:
INIT:CONT OFF
Switches to single sweep mode.
INIT;*WAI
Starts a sweep and waits for its end.
CALC:DELT2 ON
Switches on delta marker 2.
CALC:DELT2:Y?
Outputs measurement value of delta marker 2.
Usage:
Query only
8.12.3 Configuring Markers
DISPlay:MINFo[:STAT]................................................................................................... 145
DISPlay:MTABle............................................................................................................ 145
DISPlay:MINFo[:STAT] <DisplayMode>
This command turns the marker information in all diagrams on and off.
Parameters:
<DisplayMode>
ON
Displays the marker information in the diagrams.
OFF
Hides the marker information in the diagrams.
*RST:
ON
Example:
DISP:MINF OFF
Hides the marker information.
Manual operation:
See "Marker Info" on page 67
DISPlay:MTABle <DisplayMode>
This command turns the marker table on and off.
Parameters:
<DisplayMode>
ON
Turns the marker table on.
OFF
Turns the marker table off.
AUTO
Turns the marker table on if 3 or more markers are active.
*RST:
AUTO
Example:
DISP:MTAB ON
Activates the marker table.
Manual operation:
See "Marker Table Display" on page 67
User Manual 1173.9286.02 ─ 14
145
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Configuring In- and Outputs
8.12.4 Using the Marker Zoom
CALCulate:MARKer:FUNCtion:ZOOM..............................................................................146
DISPlay[:WINDow:]ZOOM[:STATe]..................................................................................146
CALCulate:MARKer:FUNCtion:ZOOM <ZoomFactor>
This command defines the factor or magnitude of the marker zoom.
Parameters:
<ZoomFactor>
Range:
*RST:
1 to 20
Zoom OFF
Example:
CALC:MARK:FUNC:ZOOM 12
Zooms into the diagram with a factor of 10 around marker 1.
Manual operation:
See "Marker Zoom" on page 66
DISPlay[:WINDow:]ZOOM[:STATe] <State>
This command turns the marker zoom for marker 1 on and off.
Parameters:
<State>
ON | OFF
*RST:
OFF
Example:
DISP:ZOOM ON
Turns on the marker zoom.
Manual operation:
See "Marker Zoom" on page 66
8.13 Configuring In- and Outputs
The following commands are necessary to configure the frontend settings.
INPut:CONNector...........................................................................................................146
INPut:CONNector <ConnType>
Determines whether the RF input data is taken from the RF input connector or the
optional Analog Baseband I connector. This command is only available if the Analog
Baseband interface (R&S FSW-B71) is installed and active for input. It is not available
for the R&S FSW67 or R&S FSW85.
Parameters:
<ConnType>
RF
RF input connector
AIQI
Analog Baseband I connector
*RST:
User Manual 1173.9286.02 ─ 14
RF
146
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Automatic Measurement Configuration
Example:
INP:CONN:AIQI
Selects input from the analog baseband I connector.
Usage:
SCPI confirmed
Manual operation:
See "Input Connector" on page 48
8.14 Automatic Measurement Configuration
The following commands are necessary to determine measurement parameters automatically.
[SENSe:]ADJust:ALL......................................................................................................147
[SENSe:]ADJust:FREQuency.......................................................................................... 147
[SENSe:]ADJust:LEVel................................................................................................... 147
[SENSe:]ADJust:ALL
This command initiates a measurement to determine and set the ideal settings for the
current task automatically (only once for the current measurement).
This includes:
●
Center frequency
●
Reference level
Example:
ADJ:ALL
Usage:
Event
Manual operation:
See "Adjusting all Determinable Settings Automatically (Auto
All)" on page 49
[SENSe:]ADJust:FREQuency
This command sets the center frequency to the frequency with the highest signal level
in the current frequency range.
Example:
ADJ:FREQ
Usage:
Event
Manual operation:
See "Adjusting the Center Frequency Automatically (Auto Freq)"
on page 49
[SENSe:]ADJust:LEVel
This command initiates a single (internal) measurement that evaluates and sets the
ideal reference level for the current input data and measurement settings. This ensures
that the settings of the RF attenuation and the reference level are optimally adjusted to
the signal level without overloading the R&S FSW or limiting the dynamic range by an
S/N ratio that is too small.
User Manual 1173.9286.02 ─ 14
147
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using the Status Register
Example:
ADJ:LEV
Usage:
Event
Manual operation:
See "Setting the Reference Level Automatically (Auto Level)"
on page 50
8.15 Using the Status Register
The status reporting system stores information about the current state of the
R&S FSW. This includes, for example, information about errors during operation or
information about limit checks. The R&S FSW stores this information in the status registers and in the error queue. You can query the status register and error queue via
IEC bus.
The R&S FSW-K40 features several status registers that are specific to phase noise
measurements. Here is a description of those, including the corresponding remote
commands.
●
Status Registers for Phase Noise Measurements................................................ 148
8.15.1 Status Registers for Phase Noise Measurements
The figure below shows the status registers of the phase noise application.
User Manual 1173.9286.02 ─ 14
148
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using the Status Register
&
*)
not used
15
not used
15
not used
logic AND
15
logic OR
14
14
14
of all bits
13
13
13
12
12
12
11
11
11
10
10
10
9
9
9
8
8
8
Phase Noise Limit FAIL
7
7
7
LIMit 8 FAIL
6
6
6
LIMit 7 FAIL
5
5
5
LIMit 6 FAIL
4
4
LIMit 5 FAIL
3
3
3
LIMit 4 FAIL
2
2
VERIfy signal failed
2
LIMit 3 FAIL
1
1
SIGNal not found
1
LIMit 2 FAIL
0
0
No traces active
0
one register for
each channel
MEASuring
4
SRQ
STATus:QUEStionable:PNOise *)
STATus:OPERation
&
7
6
RQS/MSS
&
5
ESB
&
4
MAV
&
3
15
&
2
14
15
1
13
0
SRE
LIMit 1 FAIL
STATus:QUEStionable:LIMit<n> *)
not used
PNOise
12
STB
9
LIMit
8
CALibration (=UNCAL)
7
&
6
&
5
&
4
&
3
&
2
12
12
11
11
10
9
External REFerence
8
POWer
1
8
7
7
6
6
5
5
FREQuency
not used
13
13
9
10
15
14
10
11
&
not used
14
4
4
3
3
2
1
LO UNLocked
0
OVEN COLD
STATus:QUEStionable:FREQuency *)
2
IF Overload
1
UNDerload
0
OVERload
STATus:QUEStionable:POWer *)
0
STATus:QUEStionable
PPE
ISTflag
&
7 Power On
&
6 User Request
&
5 Command Error
&
&
4 Execution Error
Device Dependent
3
Error
2 Query Error
&
1
&
&
Error/ Event Output
ESE
Queue
Buffer
0 Operation Complete
ESR
Figure 8-2: Status registers for phase noise measurements
The R&S FSW structures the information hierarchically, with the Status Byte register
(STB) and the Service Request Enable mask register (SRE) being on the highest level.
The STB gets its information from the standard Event Status Register (ESR) and the
Event Status Enable mask register (ESE). The STB and ESR are both defined by IEEE
488.2. In addition to the ESR, the STB also gets information from the STATus:OPERation and STATus:QUEStionable registers. These are the link to the lower levels of the
status register and are defined by SCPI. They contain information about the state of
the instrument.
For a more comprehensive description of the status registers not mentioned here and
status register functionality in general see the manual of the base unit.
User Manual 1173.9286.02 ─ 14
149
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using the Status Register
●
●
●
●
●
8.15.1.1
STATus:QUEStionable Register........................................................................... 150
STATus:QUEStionable:POWer Register.............................................................. 150
STATus:QUEStionable:LIMit Register.................................................................. 151
STATus:QUEStionable:PNOise Register..............................................................151
Status Register Remote Commands.....................................................................152
STATus:QUEStionable Register
The STATus:QUEStionable register contains information about indefinite states
which may occur if the unit is operated without meeting the specifications.
Bit no
Meaning
0 to 2
Unavailable for phase noise measurements.
3
POWer
This bit is set if a questionable power occurs.
5 to 7
Unavailable for phase noise measurements.
8
CALibration
This bit is set if the R&S FSW is not calibrated.
9
LIMit
This bit is set if a limit line is violated.
10-12
Unavailable for phase noise measurements.
13
PNOise
This bit is set if the phase noise measurement is questionable.
8.15.1.2
14
Unavailable for phase noise measurements.
15
This bit is always 0.
STATus:QUEStionable:POWer Register
The STATus:QUEStionable:POWer register contains information about possible
overload situations that may occur during operation of the R&S FSW.
Bit no
Meaning
0
OVERload
This bit is set if an overload occurs at the RF input.
1
UNDerload
This bit is set if an underload occurs at the RF input.
2
IF OVerload
This bit is set if an overload occurs in the IF path.
3 to 14
Unavailable for phase noise measurements.
15
This bit is always 0.
User Manual 1173.9286.02 ─ 14
150
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using the Status Register
8.15.1.3
STATus:QUEStionable:LIMit Register
The STATus:QUEStionable:LIMit register contains information about limit lines
and the results of a limit checks.
The number of LIMit registers depends on the number of measurement windows available in any application.
Bit no
Meaning
0
LIMit 1 FAIL
This bit is set if limit line 1 is violated.
1
LIMit 2 FAIL
This bit is set if limit line 2 is violated.
2
LIMit 3 FAIL
This bit is set if limit line 3 is violated.
3
LIMit 4 FAIL
This bit is set if limit line 4 is violated.
4
LIMit 5 FAIL
This bit is set if limit line 5 is violated.
5
LIMit 6 FAIL
This bit is set if limit line 6 is violated.
6
LIMit 7 FAIL
This bit is set if limit line 7 is violated.
7
LIMit 8 FAIL
This bit is set if limit line 8 is violated.
8
Phase Noise LIMit FAIL
This bit is set if a limit of the phase noise limit line is violated.
8.15.1.4
9 to 14
Unavailable for phase noise measurements.
15
This bit is always 0.
STATus:QUEStionable:PNOise Register
The STATus:QUEStionable:PNOise register contains information about the status
of phase noise measurements.
Bit no
Meaning
0
No trace are active
This bit is set if no trace is on.
1
SIGNal not found
This bit is set if no valid signal could be found.
2
VERify
This bit is set if signal verification has failed.
User Manual 1173.9286.02 ─ 14
151
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using the Status Register
8.15.1.5
Bit no
Meaning
3 to 14
Unavailable for phase noise measurements.
15
This bit is always 0.
Status Register Remote Commands
STATus:OPERation[:EVENt]?......................................................................................... 152
STATus:QUEStionable[:EVENt]?.....................................................................................152
STATus:QUEStionable:LIMit[:EVENt]?............................................................................. 152
STATus:QUEStionable:PNOise[:EVENt]?.........................................................................152
STATus:QUEStionable:POWer[:EVENt]?......................................................................... 152
STATus:OPERation:CONDition?..................................................................................... 153
STATus:QUEStionable:CONDition?................................................................................. 153
STATus:QUEStionable:LIMit:CONDition?......................................................................... 153
STATus:QUEStionable:PNOise:CONDition?.....................................................................153
STATus:QUEStionable:POWer:CONDition?..................................................................... 153
STATus:OPERation:ENABle........................................................................................... 153
STATus:QUEStionable:ENABle.......................................................................................153
STATus:QUEStionable:LIMit:ENABle............................................................................... 153
STATus:QUEStionable:PNOise:ENABle...........................................................................153
STATus:QUEStionable:POWer:ENABle........................................................................... 153
STATus:OPERation:NTRansition.....................................................................................153
STATus:QUEStionable:NTRansition................................................................................ 153
STATus:QUEStionable:LIMit:NTRansition........................................................................ 153
STATus:QUEStionable:PNOise:NTRansition.................................................................... 153
STATus:QUEStionable:POWer:NTRansition.....................................................................153
STATus:OPERation:PTRansition.....................................................................................154
STATus:QUEStionable:PTRansition.................................................................................154
STATus:QUEStionable:LIMit:PTRansition.........................................................................154
STATus:QUEStionable:PNOise:PTRansition.....................................................................154
STATus:QUEStionable:POWer:PTRansition..................................................................... 154
STATus:OPERation[:EVENt]?
STATus:QUEStionable[:EVENt]?
STATus:QUEStionable:LIMit[:EVENt]? <ChannelName>
STATus:QUEStionable:PNOise[:EVENt]? <ChannelName>
STATus:QUEStionable:POWer[:EVENt]? <ChannelName>
These commands read out the EVENt section of the status register.
The commands at the same time delete the contents of the EVENt section.
Query parameters:
<ChannelName>
Usage:
User Manual 1173.9286.02 ─ 14
String containing the name of the channel.
The parameter is optional. If you omit it, the command works for
the currently active channel.
Query only
152
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Using the Status Register
STATus:OPERation:CONDition?
STATus:QUEStionable:CONDition?
STATus:QUEStionable:LIMit:CONDition? <ChannelName>
STATus:QUEStionable:PNOise:CONDition? <ChannelName>
STATus:QUEStionable:POWer:CONDition? <ChannelName>
These commands read out the CONDition section of the status register.
The commands do not delete the contents of the EVENt section.
Query parameters:
<ChannelName>
Usage:
String containing the name of the channel.
The parameter is optional. If you omit it, the command works for
the currently active channel.
Query only
STATus:OPERation:ENABle <SumBit>,<ChannelName>
STATus:QUEStionable:ENABle <SumBit>,<ChannelName>
STATus:QUEStionable:LIMit:ENABle <SumBit>,<ChannelName>
STATus:QUEStionable:PNOise:ENABle <SumBit>,<ChannelName>
STATus:QUEStionable:POWer:ENABle <SumBit>,<ChannelName>
These commands control the ENABle part of a register.
The ENABle part allows true conditions in the EVENt part of the status register to bereported in the summary bit. If a bit is 1 in the enable register and its associated event bit
transitions to true, a positive transition will occur in the summary bit reported to the
next higher level.
Parameters:
<SumBit>
<ChannelName>
Range:
0 to 65535
String containing the name of the channel.
The parameter is optional. If you omit it, the command works for
the currently active channel.
STATus:OPERation:NTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:NTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:LIMit:NTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:PNOise:NTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:POWer:NTRansition <SumBit>,<ChannelName>
These commands control the Negative TRansition part of a register.
Setting a bit causes a 1 to 0 transition in the corresponding bit of the associated register. The transition also writes a 1 into the associated bit of the corresponding EVENt
register.
Parameters:
<SumBit>
User Manual 1173.9286.02 ─ 14
Range:
0 to 65535
153
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Remote Control Example Scripts
<ChannelName>
String containing the name of the channel.
The parameter is optional. If you omit it, the command works for
the currently active channel.
STATus:OPERation:PTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:PTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:LIMit:PTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:PNOise:PTRansition <SumBit>,<ChannelName>
STATus:QUEStionable:POWer:PTRansition <SumBit>,<ChannelName>
These commands control the Positive TRansition part of a register.
Setting a bit causes a 0 to 1 transition in the corresponding bit of the associated register. The transition also writes a 1 into the associated bit of the corresponding EVENt
register.
Parameters:
<SumBit>
<ChannelName>
Range:
0 to 65535
String containing the name of the channel.
The parameter is optional. If you omit it, the command works for
the currently active channel.
8.16 Remote Control Example Scripts
This chapter contains a few remote control example scripts for particular phase noise
measurement and configuration tasks.
The first chapter contains a short sequence of commands to perform a complete phase
noise measurement. The subsequent chapters contain sequences of remote commands to perform special tasks for phase noise measurements like customizing the
half decade configuration table.
All examples are based on a measurement range from 100 Hz to 1 MHz.
8.16.1 Performing a Basic Phase Noise Measurement
//Enter Phase Noise application
INST:SEL PNO
//Perform a preset of the channel
SYST:PRES:CHAN
//Customizing the screen layout.
//Add residual noise window:
LAY:ADD? '1',BEL,RNO
//Add spot noise window:
LAY:ADD? '2',RIGH,SNO
//Configure single sweep measurement.
INIT:CONT OFF
//Define the measurement range.
User Manual 1173.9286.02 ─ 14
154
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Remote Control Example Scripts
FREQ:STAR 100HZ
FREQ:STOP 1MHZ
//Select the sweep type.
SWE:MODE AVER
//Turn on frequency tracking.
FREQ:TRAC ON
//Turn on level tracking.
POW:TRAC ON
//Start the measurement with synchronization.
INIT;*WAI
//Set a marker on trace 1 and query its position.
CALC:MARK ON
CALC:MARK:X 1MHZ
CALC:MARK:Y?
//Query the residual noise results of trace 2 over the measurement range.
CALC:EVAL ON
//Residual FM:
FETC:PNO2:RFM?
//Residual PM:
FETC:PNO2:RPM?
//Residual RMS jitter:
FETC:PNO2:RMS?
//Freeze trace 1 and trace 2.
DISP:TRAC:MODE VIEW
DISP:TRAC2:MODE VIEW
//Activate trace 3 and trace 4.
DISP:TRAC3:MODE WRIT
DISP:TRAC4:MODE WRIT
//Activate linear trace smoothing for trace 4.
DISP:TRAC4:SMO ON
DISP:TRAC4:SMO:TYPE LIN
DISP:TRAC:SMO:APER 1
//Select IQ sweep mode.
SWE:MODE MAN
LIST:BWID:RES:TYPE IQFF
//Repeat the measurement.
INIT;*WAI
8.16.2 Configuring the Measurement Range
Performing a customized IQ FFT measurement over the whole measurement
range
//Define the measurement range.
FREQ:STAR 100HZ
FREQ:STOP 1MHZ
//Define the measurement settings for all half decades in the measurement range.
SWE:MODE MAN
User Manual 1173.9286.02 ─ 14
155
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Remote Control Example Scripts
//Measurement bandwidth (in per cent of the decade frequency):
LIST:BWID:RAT 20
//Averages:
LIST:SWE:COUN 20
//Mode:
LIST:BWID:RES:TYPE IQFF
//Window function:
LIST:IQW:TYPE GAUS
Customizing a half decade configuration table
//Define the measurement range.
FREQ:STAR 100HZ
FREQ:STOP 1MHZ
//Define the contents of the table manually.
SWE:MODE MAN
//Customize the range from 100 Hz to 300 Hz.
//Measurement bandwidth:
LIST:RANG5:BWID 1HZ
//Sweep type:
LIST:RANG5:FILT:TYPE IQFF
//Window function:
LIST:RANG5:IQW:TYPE CHEB
//Averages:
LIST:RANG5:SWE:COUN 5
//Customize the range from 300 Hz to 1 kHz.
//Averages:
LIST:RANG6:SWE:COUN 5
8.16.3 Scaling the Display
Scaling the x-axis: displaying a half decade
//Select display of one half decade.
DISP:TRAC:X:SCOP HDEC
//Select the start frequency of the half decade.
DISP:TRAC:X:HDEC 1KHZ
//Display the full measurement range again.
DISP:TRAC:X:SCOP MRAN
Scaling the x-axis: customizing the x-axis range
//Select manual x-axis scaling.
DISP:TRAC:X:SCOP MAN
//Define the start frequency of the display range.
DISP:TRAC:X:STAR 30KHZ
//Define the stop frequency of the display range.
DISP:TRAC:X:STOP 300KHZ
User Manual 1173.9286.02 ─ 14
156
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Remote Control Example Scripts
Scaling the y-axis: scaling based on bottom value and range
//Select manual y-axis scaling.
DISP:TRAC:Y:MAN BRAN
//Define the bottom value.
DISP:TRAC:Y:RLEV:LOW -160
//Define the range.
DISP:TRAC:Y 60
Scaling the y-axis: scaling based on top value and range
//Select manual y-axis scaling.
DISP:TRAC:Y:MAN TRAN
//Define the top value.
DISP:TRAC:Y:RLEV -100
//Define the range.
DISP:TRAC:Y 60
Scaling the y-axis: scaling based on bottom and top value
//Select manual y-axis scaling.
DISP:TRAC:Y:MAN TBOT
//Define the bottom value.
DISP:TRAC:Y:RLEV:LOW -160
//Define the top value.
DISP:TRAC:Y:RLEV -100
8.16.4 Configuring Numerical Results
Defining a user range for residual noise results and query the results
//Select the trace for integration.
CALC:EVAL:USER2:TRAC TRACE1
//Define the start and stop frequencies of the integration range.
CALC:EVAL:USER2:STAR 100KHZ
CALC:EVAL:USER2:STOP 1MHZ
//Query the results.
//Residual FM:
FETC:PNO:USER2:RFM?
//Residual PM:
FETC:PNO:USER2:RPM?
//Residual RMS jitter:
FETC:PNO:USER2:RMS?
Working with spot noise results
//Turn on spot noise markers on every decade edge.
CALC:SNO:DEC ON
//Turn on spot noise markers at two additional offset frequencies.
CALC:SNO1:STAT ON
User Manual 1173.9286.02 ─ 14
157
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Remote Control Example Scripts
CALC:SNO1:X 50KHZ
CALC:SNO2:STAT ON
CALC:SNO2:X 500KHZ
//Read out spot noise marker results.
//Read out the decade edges:
CALC:SNO:DEC:X?
//Read out the marker positions on the decade edges:
CALC:SNO:DEC:Y?
//Read out customized spot noise marker results:
//At 50 kHz:
CALC:SNO1:Y?
//At 500 kHz:
CALC:SNO2:Y?
8.16.5 Using Limit Lines
Programming a phase noise limit line with three segments
//Define the level of the DUT's noise floor.
CALC:PNL:NOIS -134
//Select the number of line segments.
CALC:PNL:TYPE FC3
//Define the characteristics of the line segments.
CALC:PNL:FC1 300KHZ
CALC:PNL:SLOP1 10
CALC:PNL:FC2 30KHZ
CALC:PNL:SLOP2 20
CALC:PNL:FC3 3KHZ
CALC:PNL:SLOP3 30
//Assign the limit line to trace 1 and 2.
CALC:PNL:TRAC 1,2
//Query limit check results.
CALC:PNL:FAIL?
Programming a standard limit line
//Select or create the limit line by name.
CALC:LIM:NAME 'Phase Noise'
//Comment on the limit line.
CALC:LIM:COMM 'Limit line to test phase noise measurement'
//Define the horizontal data points of the limit line.
CALC:LIM:CONT 100HZ,1kHZ
//Define the vertical data points of an (upper) limit line.
//The unit is fix for phase noise measurements.
CALC:LIM:UPP -160,-170
//Shift the limit line 5 dBc/Hz down.
CALC:LIM:UPP:SHIF -5
//Turn the limit line on.
CALC:LIM:UPP:STAT ON
User Manual 1173.9286.02 ─ 14
158
R&S®FSW-K40
Remote Control Commands for Phase Noise Measurements
Remote Control Example Scripts
//Select the trace to check.
CALC:LIM:TRAC 3
//Turn on the limit check.
CALC:LIM:STAT ON
//Query the limit check results.
CALC:LIM:FAIL?
8.16.6 Using Markers
Using spot noise markers
See "Working with spot noise results" on page 157.
Using normal and delta markers
//Activate and position a normal marker (marker 1).
CALC:MARK ON
CALC:MARK:X 1MHZ
//Position marker 1 on trace 2.
CALC:MARK:TRAC 2
//Query the position of marker 1.
CALC:MARK:Y?
//Activate and position a delta marker (delta marker 1).
CALC:DELT ON
CALC:DELT:X -900KHZ
//Position the delta marker on trace 2.
CALC:DELT:TRAC 2
//Query the position of the delta marker.
CALC:DELT:Y?
//Turning all markers off
CALC:MARK:AOFF
CALC:DELT:AOFF
User Manual 1173.9286.02 ─ 14
159
R&S®FSW-K40
List of Remote Commands (Phase Noise)
List of Remote Commands (Phase Noise)
[SENSe:]ADJust:ALL..................................................................................................................................... 147
[SENSe:]ADJust:FREQuency........................................................................................................................ 147
[SENSe:]ADJust:LEVel..................................................................................................................................147
[SENSe:]BANDwidth|BWIDth[:RESolution]:TYPE......................................................................................... 101
[SENSe:]FREQuency:CENTer.........................................................................................................................92
[SENSe:]FREQuency:STARt......................................................................................................................... 101
[SENSe:]FREQuency:STOP..........................................................................................................................101
[SENSe:]FREQuency:TRACk.......................................................................................................................... 95
[SENSe:]FREQuency:VERify:TOLerance:ABSolute........................................................................................96
[SENSe:]FREQuency:VERify:TOLerance:RELative........................................................................................ 96
[SENSe:]FREQuency:VERify[:STATe]............................................................................................................ 96
[SENSe:]IQ:DECimation.................................................................................................................................. 97
[SENSe:]IQ:DPLL............................................................................................................................................ 97
[SENSe:]IQ:ONLine......................................................................................................................................... 97
[SENSe:]IQ:TBW............................................................................................................................................. 98
[SENSe:]LIST:BWIDth:RESolution:TYPE......................................................................................................102
[SENSe:]LIST:BWIDth[:RESolution]:RATio................................................................................................... 100
[SENSe:]LIST:RANGe<range>:BWIDth[:RESolution]................................................................................... 103
[SENSe:]LIST:RANGe<range>:FILTer:TYPE................................................................................................103
[SENSe:]LIST:RANGe<range>:IQWindow:TYPE..........................................................................................103
[SENSe:]LIST:RANGe<range>:SWEep:COUNt............................................................................................ 104
[SENSe:]LIST:SWEep:COUNt.......................................................................................................................104
[SENSe:]LIST:SWEep:COUNt:MULTiplier.................................................................................................... 105
[SENSe:]LIST:SWEep:COUNt:MULTiplier:STATe........................................................................................ 105
[SENSe:]POWer:RLEVel................................................................................................................................. 93
[SENSe:]POWer:RLEVel:VERify:TOLerance.................................................................................................. 98
[SENSe:]POWer:RLEVel:VERify[:STATe]....................................................................................................... 98
[SENSe:]POWer:TRACk..................................................................................................................................98
[SENSe:]REJect:AM........................................................................................................................................ 99
[SENSe:]SPURs:SUPPression...................................................................................................................... 125
[SENSe:]SPURs:THReshold......................................................................................................................... 126
[SENSe:]SWEep:COUNt................................................................................................................................. 84
[SENSe:]SWEep:FHDecade............................................................................................................................84
[SENSe:]SWEep:FORWard...........................................................................................................................105
[SENSe:]SWEep:MODE................................................................................................................................ 106
[SENSe:]SWEep:SVFailed.............................................................................................................................. 99
[SENSe]:LIST:IQWindow:TYPE.....................................................................................................................102
ABORt..............................................................................................................................................................80
CALCulate:MARKer:FUNCtion:ZOOM.......................................................................................................... 146
CALCulate:PNLimit:COPY<k>.......................................................................................................................106
CALCulate:PNLimit:FAIL?............................................................................................................................. 108
CALCulate:PNLimit:FC1 <Frequency>.......................................................................................................... 107
CALCulate:PNLimit:FC2 <Frequency>..........................................................................................................107
CALCulate:PNLimit:FC3 <Frequency>..........................................................................................................107
CALCulate:PNLimit:FC4 <Frequency>..........................................................................................................107
CALCulate:PNLimit:FC5................................................................................................................................ 107
CALCulate:PNLimit:NOISe............................................................................................................................ 107
User Manual 1173.9286.02 ─ 14
160
R&S®FSW-K40
List of Remote Commands (Phase Noise)
CALCulate:PNLimit:SLOPe<segment>......................................................................................................... 109
CALCulate:PNLimit:TRACe........................................................................................................................... 108
CALCulate:PNLimit:TYPE..............................................................................................................................108
CALCulate<n>:DELTamarker<m>:AOFF...................................................................................................... 142
CALCulate<n>:DELTamarker<m>:MREF......................................................................................................143
CALCulate<n>:DELTamarker<m>:TRACe.................................................................................................... 143
CALCulate<n>:DELTamarker<m>:X............................................................................................................. 144
CALCulate<n>:DELTamarker<m>:Y?........................................................................................................... 144
CALCulate<n>:DELTamarker<m>[:STATe]...................................................................................................143
CALCulate<n>:EVALuation:STARt................................................................................................................127
CALCulate<n>:EVALuation:STOP.................................................................................................................128
CALCulate<n>:EVALuation:USER<range>:STARt....................................................................................... 129
CALCulate<n>:EVALuation:USER<range>:STOP........................................................................................ 129
CALCulate<n>:EVALuation:USER<range>:TRACe...................................................................................... 129
CALCulate<n>:EVALuation[:STATe]............................................................................................................. 128
CALCulate<n>:LIMit<k>:ACTive?..................................................................................................................109
CALCulate<n>:LIMit<k>:CLEar[:IMMediate]..................................................................................................110
CALCulate<n>:LIMit<k>:COMMent............................................................................................................... 114
CALCulate<n>:LIMit<k>:CONTrol:SHIFt....................................................................................................... 114
CALCulate<n>:LIMit<k>:CONTrol[:DATA].....................................................................................................114
CALCulate<n>:LIMit<k>:COPY..................................................................................................................... 110
CALCulate<n>:LIMit<k>:DELete....................................................................................................................110
CALCulate<n>:LIMit<k>:FAIL?......................................................................................................................111
CALCulate<n>:LIMit<k>:LOWer:MODE........................................................................................................ 115
CALCulate<n>:LIMit<k>:LOWer:SHIFt.......................................................................................................... 116
CALCulate<n>:LIMit<k>:LOWer:STATe........................................................................................................ 112
CALCulate<n>:LIMit<k>:LOWer[:DATA]........................................................................................................115
CALCulate<n>:LIMit<k>:NAME..................................................................................................................... 111
CALCulate<n>:LIMit<k>:STATe.................................................................................................................... 112
CALCulate<n>:LIMit<k>:TRACe....................................................................................................................112
CALCulate<n>:LIMit<k>:TRACe<t>:CHECk..................................................................................................113
CALCulate<n>:LIMit<k>:UPPer:MODE......................................................................................................... 116
CALCulate<n>:LIMit<k>:UPPer:SHIFt...........................................................................................................117
CALCulate<n>:LIMit<k>:UPPer:STATe.........................................................................................................113
CALCulate<n>:LIMit<k>:UPPer[:DATA]........................................................................................................ 116
CALCulate<n>:MARKer<m>:AOFF............................................................................................................... 140
CALCulate<n>:MARKer<m>:TRACe.............................................................................................................141
CALCulate<n>:MARKer<m>:X...................................................................................................................... 141
CALCulate<n>:MARKer<m>:Y?.................................................................................................................... 142
CALCulate<n>:MARKer<m>[:STATe]........................................................................................................... 140
CALCulate<n>:MATH:STATe........................................................................................................................118
CALCulate<n>:MATH[:EXPression][:DEFine]............................................................................................... 118
CALCulate<n>:SNOise:AOFF....................................................................................................................... 132
CALCulate<n>:SNOise:DECades:X?............................................................................................................ 133
CALCulate<n>:SNOise:DECades:Y?............................................................................................................ 133
CALCulate<n>:SNOise:DECades[:STATe]................................................................................................... 133
CALCulate<n>:SNOise<m>:STATe...............................................................................................................134
CALCulate<n>:SNOise<m>:X....................................................................................................................... 134
CALCulate<n>:SNOise<m>:Y?..................................................................................................................... 135
CONFigure:REFMeas ONCE.......................................................................................................................... 81
User Manual 1173.9286.02 ─ 14
161
R&S®FSW-K40
List of Remote Commands (Phase Noise)
DISPlay:FORMat............................................................................................................................................. 85
DISPlay:MINFo[:STAT].................................................................................................................................. 145
DISPlay:MTABle............................................................................................................................................ 145
DISPlay[:WINDow:]ZOOM[:STATe]...............................................................................................................146
DISPlay[:WINDow]:TRACe:X[:SCALe]:HDECade......................................................................................... 120
DISPlay[:WINDow]:TRACe:X[:SCALe]:SCOPe............................................................................................. 121
DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt...............................................................................................121
DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP............................................................................................... 121
DISPlay[:WINDow]:TRACe:Y:[:SCALe]......................................................................................................... 122
DISPlay[:WINDow]:TRACe:Y[:SCALe]:AUTO............................................................................................... 122
DISPlay[:WINDow]:TRACe:Y[:SCALe]:MANual............................................................................................ 122
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel............................................................................................. 123
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:LOWer.................................................................................123
DISPlay[:WINDow]:TRACe:Y[:SCALe]:RLEVel:OFFSet............................................................................... 124
DISPlay[:WINDow]:TRACe<t>:MODE........................................................................................................... 118
DISPlay[:WINDow]:TRACe<t>:SMOothing:APERture...................................................................................119
DISPlay[:WINDow]:TRACe<t>:SMOothing:TYPE......................................................................................... 119
DISPlay[:WINDow]:TRACe<t>:SMOothing[:STATe]......................................................................................119
DISPlay[:WINDow]:TRACe<t>:SPURs:SUPPress........................................................................................ 120
DISPlay[:WINDow<n>]:SIZE............................................................................................................................86
DISPlay[:WINDow<n>]:TRACe<t>:SELect.................................................................................................... 135
FETCh:PNOise:IPN?..................................................................................................................................... 130
FETCh:PNOise:MEASured:FREQuency?..................................................................................................... 137
FETCh:PNOise:MEASured:LEVel?............................................................................................................... 137
FETCh:PNOise:SPURs:DISCrete?................................................................................................................136
FETCh:PNOise:SPURs:RANDom?............................................................................................................... 136
FETCh:PNOise:SPURs?............................................................................................................................... 136
FETCh:PNOise:SWEep:AVG?...................................................................................................................... 137
FETCh:PNOise:SWEep:FDRift?....................................................................................................................138
FETCh:PNOise:SWEep:LDRift?.................................................................................................................... 138
FETCh:PNOise:SWEep:MDRift?................................................................................................................... 138
FETCh:PNOise:SWEep:SRATe?.................................................................................................................. 139
FETCh:PNOise:SWEep:STARt?................................................................................................................... 139
FETCh:PNOise:SWEep:STOP?.................................................................................................................... 139
FETCh:PNOise<t>:RFM?.............................................................................................................................. 130
FETCh:PNOise<t>:RMS?..............................................................................................................................130
FETCh:PNOise<t>:RPM?..............................................................................................................................131
FETCh:PNOise<t>:USER<range>:IPN?........................................................................................................131
FETCh:PNOise<t>:USER<range>:RFM?......................................................................................................131
FETCh:PNOise<t>:USER<range>:RMS?......................................................................................................131
FETCh:PNOise<t>:USER<range>:RPM?......................................................................................................132
FORMat:DEXPort:DSEParator...................................................................................................................... 124
FORMat:DEXPort:HEADer............................................................................................................................ 124
FORMat:DEXPort:TRACes............................................................................................................................124
INITiate<n>:CONMeas.................................................................................................................................... 81
INITiate<n>:CONTinuous................................................................................................................................ 81
INITiate<n>:SEQuencer:ABORt...................................................................................................................... 82
INITiate<n>:SEQuencer:IMMediate.................................................................................................................82
INITiate<n>:SEQuencer:MODE.......................................................................................................................83
INITiate<n>[:IMMediate].................................................................................................................................. 82
User Manual 1173.9286.02 ─ 14
162
R&S®FSW-K40
List of Remote Commands (Phase Noise)
INPut:ATTenuation.......................................................................................................................................... 93
INPut:ATTenuation:AUTO............................................................................................................................... 94
INPut:CONNector.......................................................................................................................................... 146
INPut:COUPling...............................................................................................................................................94
INPut:GAIN:STATe..........................................................................................................................................94
INPut:GAIN[:VALue]........................................................................................................................................ 95
INSTrument:CREate:DUPLicate......................................................................................................................76
INSTrument:CREate:REPLace........................................................................................................................77
INSTrument:CREate[:NEW].............................................................................................................................76
INSTrument:DELete.........................................................................................................................................77
INSTrument:LIST?...........................................................................................................................................77
INSTrument:REName......................................................................................................................................79
INSTrument[:SELect].......................................................................................................................................79
LAYout:ADD[:WINDow]?................................................................................................................................. 87
LAYout:CATalog[:WINDow]?...........................................................................................................................88
LAYout:IDENtify[:WINDow]?............................................................................................................................88
LAYout:REMove[:WINDow]............................................................................................................................. 88
LAYout:REPLace[:WINDow]............................................................................................................................89
LAYout:SPLitter............................................................................................................................................... 89
LAYout:WINDow<n>:ADD?............................................................................................................................. 91
LAYout:WINDow<n>:IDENtify?........................................................................................................................91
LAYout:WINDow<n>:REMove.........................................................................................................................92
LAYout:WINDow<n>:REPLace........................................................................................................................92
MMEMory:STORe<n>:TRACe.......................................................................................................................125
STATus:OPERation:CONDition?...................................................................................................................153
STATus:OPERation:ENABle......................................................................................................................... 153
STATus:OPERation:NTRansition.................................................................................................................. 153
STATus:OPERation:PTRansition.................................................................................................................. 154
STATus:OPERation[:EVENt]?....................................................................................................................... 152
STATus:QUEStionable:CONDition?.............................................................................................................. 153
STATus:QUEStionable:ENABle.....................................................................................................................153
STATus:QUEStionable:LIMit:CONDition?..................................................................................................... 153
STATus:QUEStionable:LIMit:ENABle............................................................................................................153
STATus:QUEStionable:LIMit:NTRansition.....................................................................................................153
STATus:QUEStionable:LIMit:PTRansition.....................................................................................................154
STATus:QUEStionable:LIMit[:EVENt]?..........................................................................................................152
STATus:QUEStionable:NTRansition............................................................................................................. 153
STATus:QUEStionable:PNOise:CONDition?.................................................................................................153
STATus:QUEStionable:PNOise:ENABle....................................................................................................... 153
STATus:QUEStionable:PNOise:NTRansition................................................................................................ 153
STATus:QUEStionable:PNOise:PTRansition................................................................................................ 154
STATus:QUEStionable:PNOise[:EVENt]?..................................................................................................... 152
STATus:QUEStionable:POWer:CONDition?................................................................................................. 153
STATus:QUEStionable:POWer:ENABle........................................................................................................153
STATus:QUEStionable:POWer:NTRansition.................................................................................................153
STATus:QUEStionable:POWer:PTRansition.................................................................................................154
STATus:QUEStionable:POWer[:EVENt]?......................................................................................................152
STATus:QUEStionable:PTRansition..............................................................................................................154
STATus:QUEStionable[:EVENt]?.................................................................................................................. 152
SYSTem:PRESet:CHANnel[:EXECute]........................................................................................................... 79
User Manual 1173.9286.02 ─ 14
163
R&S®FSW-K40
List of Remote Commands (Phase Noise)
SYSTem:SEQuencer.......................................................................................................................................85
TRACe[:DATA]?.............................................................................................................................................126
TRACe<n>:COPY..........................................................................................................................................126
User Manual 1173.9286.02 ─ 14
164
R&S®FSW-K40
Index
Index
A
E
Abort measurement (remote control) ................................ 80
Aborting
Sweep ......................................................................... 47
Application cards ................................................................. 7
Application notes ................................................................. 7
Attenuation
Mechanical .................................................................. 39
Mechanical (remote control) ....................................... 92
Auto all .............................................................................. 49
Auto frequency .................................................................. 49
Auto level
Reference level ........................................................... 50
Softkey ........................................................................ 50
Automatic
Frequency detection (remote control) ....................... 147
Level detection (remote control) ............................... 147
Parameter detection (remote control) ....................... 147
Automatic scaling .............................................................. 53
Automatic scaling (remote control) .................................. 117
Average count ................................................................... 47
Averaging .................................................................... 45, 46
Averaging (remote control) ................................................ 99
Evaluation methods
Remote ....................................................................... 87
F
FFT window ....................................................................... 45
FFT window (remote control) ............................................ 99
Format
Data (remote) ............................................................ 124
Frequency
Nominal ....................................................................... 39
Nominal (remote control) ............................................ 92
Frequency tolerance ......................................................... 40
Frequency tolerance (remote control) ............................... 95
Frequency tracking ............................................................ 41
Frequency tracking (remote control) ................................. 95
Frequency verification ....................................................... 40
Frequency verification (remote control) ............................. 95
H
B
Half decades configuration table ....................................... 46
Hardware settings
Displayed .................................................................... 11
Brochures ............................................................................ 7
I
C
Initiate measurement (remote control) .............................. 80
Input
Connector (remote) ................................................... 146
Coupling (remote) ....................................................... 94
Installation ........................................................................... 9
Center frequency
Automatic configuration .............................................. 49
Closing
Channels (remote) ...................................................... 77
Windows (remote) ................................................. 88, 92
Continue single sweep
Softkey ........................................................................ 47
Continuous sweep
Softkey ........................................................................ 47
Conventions
SCPI commands ......................................................... 71
Copy trace (remote control) ............................................ 117
Copying
Measurement channel (remote) .................................. 76
Traces ......................................................................... 55
Coupling ...................................................................... 39, 48
Input (remote) ............................................................. 94
Coupling (remote control) .................................................. 92
D
Data format
Remote ..................................................................... 124
Data sheet ........................................................................... 7
Delta markers .................................................................... 66
Defining ....................................................................... 66
Delta markers (remote control) ....................................... 140
Duplicating
Measurement channel (remote) .................................. 76
User Manual 1173.9286.02 ─ 14
J
Jitter (remote control) ...................................................... 127
K
Keys
RUN CONT ................................................................. 47
RUN SINGLE .............................................................. 47
L
Level
nominal ....................................................................... 39
Nominal (remote control) ............................................ 92
Level tolerance .................................................................. 41
Level tolerance (remote control) ....................................... 95
Level tracking .................................................................... 41
Level tracking (remote control) .......................................... 95
Level verification ............................................................... 41
Level verification (remote control) ..................................... 95
Limit lines
Noise floor (remote control) ...................................... 106
Phase noise (remote control) .................................... 106
Standard (remote control) ......................................... 109
Limit lines (remote control) .............................................. 106
165
R&S®FSW-K40
M
Marker to Trace ................................................................. 66
Marker zoom (remote control) ......................................... 146
Markers ............................................................................. 35
Assigned trace ............................................................ 66
Deactivating ................................................................ 66
Delta markers ............................................................. 66
Table ........................................................................... 67
Type ............................................................................ 66
Markers (remote control) ................................................. 142
Maximizing
Windows (remote) ....................................................... 86
Measurement
Reference ................................................................... 81
Measurement channel
Creating (remote) .................................................. 76, 77
Deleting (remote) ........................................................ 77
Duplicating (remote) ................................................... 76
Querying (remote) ....................................................... 77
Renaming (remote) ..................................................... 79
Replacing (remote) ..................................................... 77
Measurement range .......................................................... 44
Measurement range (remote control) ................................ 99
Measurement time ............................................................ 46
Mechanical attenuation ..................................................... 39
Mechanical attenuation (remote control) ........................... 92
Multiple
Measurement channels ................................................ 9
N
Nominal frequency ............................................................ 39
Nominal frequency (remote control) .................................. 92
Nominal level ..................................................................... 39
Nominal level (remote control) .......................................... 92
O
Offset frequency
Start ............................................................................ 44
Start (remote control) .................................................. 99
Stop ............................................................................ 44
Stop (remote control) .................................................. 99
Online help .......................................................................... 6
Options
Preamplifier ................................................................. 39
Overview
Configuration .............................................................. 36
P
Preamplifier
Setting ......................................................................... 39
Softkey ........................................................................ 39
Presetting
Channels ..................................................................... 37
R
Range Start/Stop ............................................................... 44
Range Start/Stop (remote control) .................................... 99
RBW ............................................................................ 44, 46
RBW (remote control) ....................................................... 99
Reference level
Auto level .................................................................... 50
Reference marker ............................................................. 66
User Manual 1173.9286.02 ─ 14
Index
Reference measurement ................................................... 81
Release notes ..................................................................... 7
Remote commands
Basics on syntax ......................................................... 71
Boolean values ........................................................... 74
Capitalization .............................................................. 72
Character data ............................................................ 75
Data blocks ................................................................. 75
Numeric values ........................................................... 74
Optional keywords ...................................................... 73
Parameters ................................................................. 73
Strings ......................................................................... 75
Suffixes ....................................................................... 72
Residual FM (remote control) .......................................... 127
Residual noise
Integration range ......................................................... 57
Integration Range ....................................................... 57
Integration Range (remote control) ........................... 127
Residual noise (remote control) ...................................... 127
Residual PM (remote control) ......................................... 127
Resolution bandwidth .................................................. 44, 46
Resolution bandwidth (remote control) ............................. 99
Restoring
Channel settings ......................................................... 37
Results
Data format (remote) ................................................ 124
RF input
Connector (remote) ................................................... 146
RUN CONT
Key .............................................................................. 47
RUN SINGLE
Key .............................................................................. 47
S
Scaling
X-axis .......................................................................... 51
X-axis (remote control) ............................................. 117
Y-axis .......................................................................... 52
Y-axis (remote control) ............................................. 117
Scope
X-axis .......................................................................... 51
X-axis (remote control) ............................................. 117
Sequencer ........................................................................... 9
Aborting (remote) ........................................................ 82
Activating (remote) ...................................................... 82
Mode (remote) ............................................................ 83
Remote ....................................................................... 81
Single sweep
Softkey ........................................................................ 47
Smoothing
Traces ......................................................................... 26
Smoothing type ................................................................. 53
Smoothing type (remote control) ..................................... 117
Softkeys
Auto All ....................................................................... 49
Auto Freq .................................................................... 49
Auto Level ................................................................... 50
Continue Single Sweep .............................................. 47
Continuous Sweep ...................................................... 47
Marker to Trace .......................................................... 66
Norm/Delta .................................................................. 66
Preamp ....................................................................... 39
Single Sweep .............................................................. 47
Sweep count ............................................................... 47
166
R&S®FSW-K40
Spot noise
10_x Hz ....................................................................... 58
10_x Hz (remote control) .......................................... 127
user defined ................................................................ 58
user defined (remote control) .................................... 127
Spur removal ..................................................................... 56
Spur removal (remote control) ........................................ 117
Spur threshold ................................................................... 56
Spur threshold (remote control) ...................................... 117
Stop On Verify Failed ........................................................ 41
Suffixes
Common ..................................................................... 70
Remote commands ..................................................... 72
Sweep
Aborting ...................................................................... 47
Count .......................................................................... 47
Sweep count (remote control) ........................................... 80
Sweep direction ................................................................. 44
Sweep direction (remote control) ...................................... 99
Sweep mode ............................................................... 45, 46
Sweep mode (remote control) ........................................... 99
Sweep type ....................................................................... 44
Sweep type (remote control) ............................................. 99
T
Tolerance
frequency .................................................................... 40
frequency (remote control) .......................................... 95
level ............................................................................ 41
level (remote control) .................................................. 95
Trace configuration ........................................................... 54
Trace configuration (remote control) ............................... 117
Trace copy (remote control) ............................................ 117
Trace export ...................................................................... 55
Trace export (remote control) .......................................... 117
Trace math ........................................................................ 56
Trace math (remote control) ............................................ 117
Trace offset ....................................................................... 53
Trace offset (remote control) ........................................... 117
Trace smoothing ......................................................... 26, 53
Trace smoothing (remote control) ................................... 117
Traces
Copying ....................................................................... 55
Copying (remote control) .......................................... 126
Tracking
frequency .................................................................... 41
frequency (remote control) .......................................... 95
level ............................................................................ 41
level (remote control) .................................................. 95
Index
Layout (remote) .......................................................... 89
Maximizing (remote) ................................................... 86
Querying (remote) ....................................................... 88
Replacing (remote) ..................................................... 89
Splitting (remote) ........................................................ 86
Types (remote) ........................................................... 87
X
X-axis
Half decade ................................................................. 52
Half decade (remote control) .................................... 117
scope .......................................................................... 51
scope (remote control) .............................................. 117
Start ............................................................................ 52
Start (remote control) ................................................ 117
Stop ............................................................................ 52
Stop (remote control) ................................................ 117
Y
Y-axis
Scaling ........................................................................ 52
Scaling (remote control) ............................................ 117
Scaling automatic (remote control) ........................... 117
Y-axis scaling
Automatic .................................................................... 53
V
Verify frequency ................................................................ 40
Verify frequency (remote control) ...................................... 95
Verify level ......................................................................... 41
Verify level (remote control) .............................................. 95
W
White papers ....................................................................... 7
Window function ................................................................ 45
Window function (remote control) ..................................... 99
Window title bar information .............................................. 12
Windows
Adding (remote) .......................................................... 87
Closing (remote) ................................................... 88, 92
