Trendnet TE100-P1U 1-Port Print Server Quick Installation Guide

Troubleshooting
1. I inserted the Utility CD-ROM into my computer's CD-ROM Drive but the installation menu does
not appear automatically. What should I do?
1. For Windows 7, if the installation menu does not appear automatically, click on the Windows
Icon on the bottom left hand corner of the screen, click the “Search programs and files” box,
type D:\autorun.exe, where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM
Driver, and then press the ENTER key on your keyboard
2. For Windows Vista, if the installation menu does not appear automatically, click Start, click the
Start Search box, type D:\autorun.exe where "D" in "D:\autorun.exe" is the letter
assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard.
3. For 98SE/XP/2000, if the window does not appear automatically, click Start, click Run and
type D:\autorun.exe where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM Drive,
and then press the ENTER key on your keyboard.
2. The PS Wizard / PS Utility is unable to see my print server. What should I do?
1. Double check your hardware connections; make sure that the print server and printer are
powered ON and are properly connected.
2. Click Discover.
3. Disable any software firewall programs (e.g. ZoneAlarm). If your computer is running
Windows 7, XP, or Vista, disable the built in firewall program.
3. My printer does not print the entire document. What should I do?
Windows 7
1. Click on the Windows icon on the bottom left-hand corner of the screen.
2. Click Devices and Printers.
3. Right click on the printer and select Printer Properties.
4. Click the Advanced tab.
5. Uncheck Enable advanced printing features.
6. Click Apply.
7. Click OK.
Windows Vista
1. Click on the Windows icon on the bottom left-hand corner of the screen.
2. Click Control Panel.
3. Click Classic View.
4. Click Printers.
5. Right click on the printer and select Properties.
6. Click the Advanced tab.
7. Uncheck Enable advanced printing features.
8. Click Apply.
9. Click OK.
7
4. I successfully added a printer to my computer and I can print a test page, but I cannot print
anything from Microsoft Word or other applications.
Make sure the printer is set as your default printer.
1. On Windows 7, click the Windows icon ?
Devices and Printers and verify that your printer icon
has a check on it.
2. On Windows Vista, click the Start Icon ?
Control Panel ?
Classic View ?
Printers and verify
that your printer icon has a check on it.
3. On Windows XP/2000/2003/98SE Server, click Start and then click Printers & Faxes, verify that
your printer icon has a check on it.
5. I configured my print server to automatically receive an IP Address from a DHCP server, and
now I cannot go into the Print Server's web utility.
1. Open PS Wizard (See 4. Add the Printer to your PC) to locate your print server's IP Address.
2. For MAC users, press the Reset button at the back of the TE100-P1U, hold the button for 15
seconds, release the button, and enter http://192.168.0.1 in a web browser to access the web
utility feature.
6. How do I setup the TE100-P1U on a Mac?
Type in http://192.168.0.1 in you browser to logon to the built-in web configuration
If you still encounter problems or have any questions regarding the TE100-P1U, please contact
TRENDnet's Technical Support Department.
8
Copyright ©2010. All Rights Reserved. TRENDnet.
