ERserver
xSeries 455
Option Installation Guide
ERserver
xSeries 455
Option Installation Guide
SC88-P919-80
Note: Before using this information and the product it supports, read the general information in “Notices”,
on page 63.
First Edition (November 2003)
© Copyright International Business Machines Corporation 2003. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.
Contents
Safety
. . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Chapter 1. Introduction . . . . . . . . .
Related publications . . . . . . . . . .
Notices and statements used in this book . .
Major components of the xSeries 455 server .
Midplane board LEDs . . . . . . . . . .
Processor board internal connectors and LEDs
PCI-X board internal connectors and LEDs . .
Memory board internal connectors and LEDs .
Memory switch card LEDs . . . . . . . .
I/O-board internal connectors . . . . . . .
Light path diagnostics panel . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
1
1
2
3
5
5
7
7
8
8
9
Chapter 2. Installing options . . . . . . . . . . .
Installation guidelines . . . . . . . . . . . . . .
System reliability considerations . . . . . . . . .
Working inside a server with power on . . . . . . .
Handling static-sensitive devices . . . . . . . . .
Server power features . . . . . . . . . . . . . .
Turning on the server . . . . . . . . . . . . .
Turning off the server . . . . . . . . . . . . .
Opening the cover . . . . . . . . . . . . . . .
Removing and replacing the bezel . . . . . . . . . .
Removing and replacing a hot-swap power supply . . . .
Installing an adapter . . . . . . . . . . . . . . .
Cabling a ServeRAID adapter . . . . . . . . . .
Installing a hot-swap hard disk drive . . . . . . . . .
Installing a CD-ROM or DVD-ROM drive . . . . . . .
Installing memory . . . . . . . . . . . . . . . .
Removing and replacing DIMMs . . . . . . . . .
Hot-replacing DIMMs. . . . . . . . . . . . . .
Installing and replacing a microprocessor and power module
Replacing and troubleshooting fans . . . . . . . . .
Replacing fan 1 or 2 . . . . . . . . . . . . . .
Replacing fan 3 or 4 . . . . . . . . . . . . . .
Replacing the battery . . . . . . . . . . . . . .
Completing the installation. . . . . . . . . . . . .
Closing the cover . . . . . . . . . . . . . . .
Installing the server in a rack. . . . . . . . . . .
Connecting the cables . . . . . . . . . . . . .
Updating your server configuration. . . . . . . . .
Backing up and restoring the nonvolatile variables . . . .
Creating a backup copy of the nonvolatile EFI variables .
Restoring the nonvolatile EFI variables . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
13
13
13
13
14
14
14
15
16
16
18
19
22
24
25
26
28
29
30
37
37
38
40
41
42
42
42
55
56
56
56
Chapter 3. Input/output connectors
Gigabit Ethernet connectors . . . .
RXE Expansion Port connectors . .
RXE Management Port connector . .
SCSI connector . . . . . . . .
Serial connector . . . . . . . .
SMP Expansion Port connectors . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
59
60
60
60
60
61
61
© Copyright IBM Corp. 2003
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
iii
Universal Serial Bus connectors . . . . . . . . . . . . . . . . . . 61
Video connector . . . . . . . . . . . . . . . . . . . . . . . . 61
Appendix. Notices . . . . . . . . . . . . . . . .
Edition notice . . . . . . . . . . . . . . . . . .
Trademarks . . . . . . . . . . . . . . . . . . .
Important notes. . . . . . . . . . . . . . . . . .
Product recycling and disposal . . . . . . . . . . . .
Battery return program . . . . . . . . . . . . . . .
Electronic emission notices . . . . . . . . . . . . .
Federal Communications Commission (FCC) statement . .
Industry Canada Class A emission compliance statement .
Australia and New Zealand Class A statement . . . . .
United Kingdom telecommunications safety requirement. .
European Union EMC Directive conformance statement . .
Taiwanese Class A warning statement . . . . . . . .
Chinese Class A warning statement . . . . . . . . .
Japanese Voluntary Control Council for Interference (VCCI)
Power cords . . . . . . . . . . . . . . . . . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
statement
. . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
63
63
64
64
65
65
66
66
66
66
66
66
67
67
67
67
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
iv
xSeries 455: Option Installation Guide
Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto, lea la información de seguridad.
© Copyright IBM Corp. 2003
v
Läs säkerhetsinformationen innan du installerar den här produkten.
Statement 1:
DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
v Do not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical
storm.
v Connect all power cords to a properly wired and grounded electrical
outlet.
v Connect to properly wired outlets any equipment that will be attached to
this product.
v When possible, use one hand only to connect or disconnect signal
cables.
v Never turn on any equipment when there is evidence of fire, water, or
structural damage.
v Disconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
v Connect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached
devices.
To Connect:
To Disconnect:
1. Turn everything OFF.
1. Turn everything OFF.
2. First, attach all cables to devices.
2. First, remove power cords from outlet.
3. Attach signal cables to connectors.
3. Remove signal cables from connectors.
4. Attach power cords to outlet.
4. Remove all cables from devices.
5. Turn device ON.
vi
xSeries 455: Option Installation Guide
Statement 2:
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
a module containing a lithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.
Do not:
v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3:
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
v Do not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
v Use of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not view directly
with optical instruments, and avoid direct exposure to the beam.
Safety
vii
Statement 4:
≥ 18 kg (39.7 lb)
≥ 32 kg (70.5 lb)
≥ 55 kg (121.2 lb)
CAUTION:
Use safe practices when lifting.
Statement 5:
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current
from the device, ensure that all power cords are disconnected from the power
source.
2
1
viii
xSeries 455: Option Installation Guide
Statement 8:
CAUTION:
Never remove the cover on a power supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact
a service technician.
Statement 10:
CAUTION:
Do not place any object weighing more than 82 kg (180 lb) on top of
rack-mounted devices.
>82 kg (180 lb)
WARNING: Handling the cord on this product or cords associated with accessories
sold with this product, will expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash
hands after handling.
ADVERTENCIA: El contacto con el cable de este producto o con cables de
accesorios que se venden junto con este producto, pueden exponerle al plomo, un
elemento químico que en el estado de California de los Estados Unidos está
considerado como un causante de cancer y de defectos congénitos, además de
otros riesgos reproductivos. Lávese las manos después de usar el producto.
Safety
ix
x
xSeries 455: Option Installation Guide
Chapter 1. Introduction
This Option Installation Guide contains instructions for installing, removing, and
connecting optional devices that your server supports.
Related publications
In addition to this Option Installation Guide, the following documentation comes with
your server:
v User’s Guide
This publication is in Portable Document Format (PDF) on the IBM® xSeries™
Documentation CD. It contains general information about your server.
v Installation Guide
This printed publication contains instructions for setting up your server and basic
instructions for installing some options.
v Safety Information
This publication is in PDF on the IBM xSeries Documentation CD. It contains
translated caution and danger statements. Each caution and danger statement
that appears in the documentation has a number that you can use to locate the
corresponding statement in your language in the Safety Information book.
v Rack Installation Instructions
This printed publication contains instructions for installing your server in a rack.
v Hardware Maintenance Manual and Troubleshooting Guide
This publication is in PDF on the IBM xSeries Documentation CD. It contains
information to help you solve problems yourself, and it contains information for
service technicians.
Depending on your server model, additional publications might be included on the
IBM xSeries Documentation CD.
Your server might have features that are not described in the documentation that
you received with the server. The documentation might be updated occasionally to
include information about those features, or technical updates might be available to
provide additional information that is not included in your server documentation.
These updates are available from the IBM Web site. Complete the following steps
to check for updated documentation and technical updates:
1. Go to http://www.ibm.com/pc/support/.
2.
3.
4.
5.
© Copyright IBM Corp. 2003
In the Learn section, click Online publications.
On the ″Online publications″ page, in the Brand field, select Servers.
In the Family field, select xSeries 455.
Click Display documents.
1
Notices and statements used in this book
The caution and danger statements that appear in this book are also in the
multilingual Safety Information book, which is on the IBM xSeries Documentation
CD. Each statement is numbered for reference to the corresponding statement in
the Safety Information book.
The following notices and statements are used in the documentation:
v Notes: These notices provide important tips, guidance, or advice.
v Important: These notices provide information or advice that might help you avoid
inconvenient or problem situations.
v Attention: These notices indicate potential damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in which
damage could occur.
v Caution: These statements indicate situations that can be potentially hazardous
to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.
v Danger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
2
xSeries 455: Option Installation Guide
Major components of the xSeries 455 server
The orange color on components and labels in the server indicates hot-swap or
hot-plug components. You can install or remove these components while the server
is running, provided that the server is configured to support hot-swap and hot-plug
features.
The blue color on components and labels indicates touch points, where a
component can be gripped, a latch moved, and so on.
The following illustration shows the location of major components in your server.
Chapter 1. Introduction
3
Note: The illustrations in this document might differ slightly from your hardware.
DIMM
access
doors
DIMM
Microprocessor
Power
module
Microprocessor
baffle
Fan 4
VRM
Fan 3
Fan 2
Fan 1
:
E
T
O
N
R
O
F
R
E
P
O
R
P
,
W
LO
F
IR
A
E
C
LA
P
E
R
N
FA
,
W
LO
F
IR
A
S
E
T
U
IN
M
X
O
B
2
F
O
R
E
P
O
R
P
IN
H
IT
W
R
O
F
T
N
O
R
F
:
E
T
O
N
E
C
LA
P
E
R
Retention
bracket
N
FA
S
E
T
U
IN
M
X
O
B
2
F
O
IN
H
IT
W
T
N
O
R
F
Thumbscrews
EMC shield
Bezel
Hard disk
drive
Hot-swap
power supply
DVD-ROM
drive
4
xSeries 455: Option Installation Guide
Midplane board LEDs
The following illustration shows the LEDs on the midplane board.
I/O board error LED
Remote Supervisor Adapter error LED
PCI-X board error LED
Midplane board error LED
VRM error
LED
Processor board error LED
Memory board error LED
Processor board internal connectors and LEDs
The following illustrations show the internal connectors and LEDs on the processor
board.
Microprocessor 3 socket
Microprocessor 3
power module socket
Microprocessor 3
power module
cable connector
Microprocessor 1
power module socket
Microprocessor 1
power module
cable connector
Microprocessor 1 socket
Chapter 1. Introduction
5
Power-good
LED
Microprocessor 3
error LED
VRM
error
LED
Microprocessor 3
power module
error LED
Microprocessor 1
power module
error LED
Microprocessor 1
error LED
Reverse side
Microprocessor 4 socket
Microprocessor 4 power
module socket
Microprocessor 4 power
module cable connector
Microprocessor 2 power
module socket
Microprocessor 2 power
module cable connector
Microprocessor 2 socket
Microprocessor 4 error LED
Microprocessor 4 power
module error LED
Microprocessor 2 power
module error LED
Microprocessor 2 error LED
6
xSeries 455: Option Installation Guide
PCI-X board internal connectors and LEDs
The following illustration shows the internal connectors and LEDs on the PCI-X
board.
PCI-X slot 4
(100 MHz)
PCI-X slot 5
(133 MHz)
PCI-X slot 6
(133 MHz)
PCI-X slot 3
(100 MHz)
PCI-X slot 2
(66 MHz)
Attention LED
Power LED
PCI-X slot 1
(66 MHz)
Memory board internal connectors and LEDs
The following illustration shows the internal connectors and LEDs on the memory
board.
DIMM slots
DIMM error LED
(14 places)
DIMM error LED
(14 places)
Chapter 1. Introduction
7
Memory switch card LEDs
The following illustration shows the LEDs on the memory switch card.
Port 1 power LED
Memory hot-plug
enabled LED
Port 2 power LED
I/O-board internal connectors
The following illustration shows the internal connectors on the I/O board.
Riser card
connector
SCSI B
connector
I/O VRM
Fan 4
connector
Fan 3
connector
Fans 1 and 2
connectors
Power/reset
connector
SCSI A
connector
8
xSeries 455: Option Installation Guide
USB cable
connector
Media bays
connector
Light path diagnostics panel
The following illustration shows the light path diagnostics panel.
To access the light path diagnostics panel, press on the front of the panel.
For more information about light path diagnostics, see the Hardware Maintenance
Manual and Troubleshooting Guide on the IBM xSeries Documentation CD.
The following table describes the LEDs on the light path diagnostics panel.
Table 1. Light path diagnostics
LED
Problem
Action
None
An error has occurred and cannot be
diagnosed, or the ASM processor has failed.
The error is not represented by a Light Path
Diagnostic LED.
Check the system error log for more
information about the error.
CPU
A microprocessor has failed.
v Check the microprocessor failure LEDs on
the system board.
Note: If you have installed more than one
microprocessor, check the reverse side of
the processor board for lit microprocessor
failure LEDs.
v If a microprocessor error LED is lit, make
sure that the microprocessor is installed
correctly. See “Installing and replacing a
microprocessor and power module” on
page 30 for installation instructions.
If the problem remains, call for service.
Chapter 1. Introduction
9
Table 1. Light path diagnostics (continued)
LED
Problem
Action
MEMORY
A memory error occurred.
v Check the DIMM failure LEDs on the
memory board.
v Replace the DIMM indicated by the lit DIMM
failure LED.
DASD
A hard disk drive error occurred.
Check the LEDs on the hard disk drives and
replace the indicated drive.
PCI-X BUS
An error occurred on a PCI bus.
v Check the error log for additional
information.
v If you cannot isolate the failing adapter from
the information in the error log, try to
determine the failing adapter by removing
one adapter at a time from the failing PCI-X
bus and restarting the server after each
adapter is removed.
If the problem remains, call for service.
FAN
A fan has failed or is operating too slowly.
Check the LEDs on the fans and replace the
indicated fan.
A failing fan can also cause the TEMP LED to
be lit.
TEMP
The system temperature has exceeded a
threshold level.
v Determine whether a fan has failed. If it has,
replace it.
v Make sure that air vents are not blocked.
v Make sure that the room temperature is not
too high. (See the User’s Guide on the IBM
xSeries Documentation CD for temperature
information.)
If the problem remains, call for service.
NMI
A machine check error has occurred.
Check the error log to identify the condition.
BOARD
A system board has failed.
v Check the LEDs on the top of the server to
determine which of the boards failed.
v Remove ac power from the server; then,
reconnect the server to ac power and restart
the server.
If the problem remains, call for service.
EVENT LOG
A system warning has occurred.
Check the error log to diagnose the condition.
PS1 and PS2
The indicated power supply has failed.
Replace the power supply.
If the problem remains, call for service.
VRM
One of the VRMs has failed.
v Remove ac power from the server; then,
reconnect the server to ac power and restart
the server.
v Check the error log for additional
information.
If the problem remains, call for service.
NON REDUND
10
The power supplies are no longer redundant,
or a power supply has failed.
xSeries 455: Option Installation Guide
v Determine whether a power supply has
failed. If it has, replace it.
v Use a higher voltage ac power source, or
remove optional devices from the server
until redundancy is restored, if redundancy
is required.
Table 1. Light path diagnostics (continued)
LED
Problem
Action
OVER SPEC
The power supplies are using more power than Replace the failed power supply, or remove
the maximum rating.
optional devices from the server.
Chapter 1. Introduction
11
12
xSeries 455: Option Installation Guide
Chapter 2. Installing options
This chapter provides detailed instructions for installing hardware options in your
server.
Installation guidelines
Before you begin to install options in your server, read the following information:
v Read the safety information beginning on page v and the guidelines in “Handling
static-sensitive devices” on page 14. This information will help you work safely
with your server or options.
v Make sure that you have an adequate number of properly grounded electrical
outlets for your server, monitor, and any other devices that you will connect to the
server.
v Back up all important data before you make changes to disk drives.
v You do not need to turn off the server to install or replace hot-swap or hot-plug
components, or hot-plug Universal Serial Bus (USB) devices.
v The orange color on components and labels identifies hot-swap or hot-plug
components. You can install or remove hot-swap and hot-plug components while
the server is running, provided that the server is configured to support this
capability. See the instructions in this chapter for more information about
removing and installing hot-swap and hot-plug components.
v For a list of supported options for your server, go to
http://www.ibm.com/pc/us/compat/.
Note: Some preconfigured servers have a unique list of supported options. See the
software documentation that comes with those servers for more information.
System reliability considerations
To help ensure proper cooling and system reliability, make sure that:
v The top cover is closed during normal operation.
v Each of the drive bays has either a drive or a filler panel installed.
v There is space around the server to allow the cooling system to work properly.
v Cables for optional adapters are routed according to the instructions that are
provided with the adapters.
v All microprocessors have the same cache size and type, and the same clock
speed.
v For proper cooling, do not leave the cover open for more than 15 minutes.
v A failed fan is replaced within 48 hours.
v Do not remove a defective power supply until a replacement is available.
v For redundant and hot-swappable operation, the power supplies are connected to
200-240 V ac.
v If you replace a hot-swap drive, remove the defective drive and wait 15 seconds
before you install a new drive.
Working inside a server with power on
Your server supports hot-swap devices and is designed to operate safely while
turned on with the cover removed. Follow these guidelines when you work inside a
server that is turned on:
© Copyright IBM Corp. 2003
13
v Avoid loose-fitting clothing on your forearms. Button long-sleeved shirts before
working inside the server; do not wear cuff links while you are working inside the
server.
v Do not allow your necktie or scarf to hang inside the server.
v Remove jewelry, such as bracelets, rings, necklaces, and loose-fitting wrist
watches.
v Remove items from your shirt pocket (such as pens or pencils) that could fall into
the server as you lean over it.
v Avoid dropping any metallic objects, such as paper clips, hair pins, or screws,
into the server.
Handling static-sensitive devices
Attention: Static electricity can damage electronic devices and your system. To
avoid damage, keep static-sensitive devices in their static-protective package until
you are ready to install them.
To reduce the possibility of electrostatic discharge, observe the following
precautions:
v Limit your movement. Movement can cause static electricity to build up around
you.
v Handle the device carefully, holding it by its edges or its frame.
v Do not touch solder joints, pins, or exposed printed circuitry.
v Do not leave the device where others can handle and damage it.
v While the device is still in its anti-static package, touch it to an unpainted metal
part of the system unit for at least 2 seconds. This drains static electricity from
the package and from your body.
v Remove the device from its package and install it directly into the system unit
without setting down the device. If it is necessary to set down the device, place it
in to its static-protective package. Do not place the device on your system unit
cover or on a metal surface.
v Take additional care when handling devices during cold weather. Heating reduces
indoor humidity and increases static electricity.
v Wear a properly grounded wrist strap against your skin to help eliminate static
electricity from your body.
Server power features
When the server is connected to an ac power source but is not turned on, the
operating system does not run, and all core logic except for the service processor is
shut down; however, the server can respond to requests from the service processor,
such as a remote request to turn on the server. The power-on LED flashes to
indicate that the server is connected to ac power but is not turned on.
Turning on the server
Approximately 20 seconds after the server is connected to ac power, the
power-control button becomes active, and you can turn on the server and start the
operating system by pressing the power-control button. The server can also be
turned on in any of the following ways:
v If a power failure occurs while the server is turned on, the server will restart
automatically when power is restored.
14
xSeries 455: Option Installation Guide
v If ac power is present, the server can be turned on from the Remote Supervisor
Adapter user interface.
v The Wake on LAN® feature can turn on the server.
Notes:
1. The power supplies are hot-swappable and redundant only at 200-240 V ac.
2. Both power supplies must be connected to the power source for operation at
100-127 V ac.
3. During normal operation, both power supplies must be installed for proper
operation.
4. While the server is powering up, the power-on LED on the front of the server is
lit. When the server is connected to ac power but is not turned on, the power-on
LED on the front of the server flashes.
5. When you press the power-control button on any server in a scalable partition,
all servers in the scalable partition will be turned on. If the servers do not turn
on when the power-control button is pressed, see the Hardware Maintenance
Manual and Troubleshooting Guide on the IBM xSeries Documentation CD.
Turning off the server
When you turn off the server and leave it connected to ac power, the server can
respond to requests from the service processor, such as a remote request to turn
on the server. To remove all power from the server, you must disconnect it from the
power source.
Some operating systems require an orderly shutdown before you turn off the server.
See your operating-system documentation for information about shutting down the
operating system.
Statement 5:
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current
from the device, ensure that all power cords are disconnected from the power
source.
2
1
The server can be turned off in any of the following ways:
v You can turn off the server from the operating system, if your operating system
supports this feature. After an orderly shutdown of the operating system, the
server will be turned off automatically.
v You can press the power-control button to start an orderly shutdown of the
operating system and turn off the server, if your operating system supports this
feature.
Chapter 2. Installing options
15
v If the operating system stops functioning, you can press and hold the
power-control button for more than 4 seconds to turn off the server.
v If the server is connected to an Advanced System Management interconnect
network, the server can be turned off from the Remote Supervisor Adapter user
interface.
Notes:
1. You might need to press and hold the power-control button for more than 4
seconds to cause an immediate shutdown of the server. You can use this
feature if the operating system stops functioning.
2. If you disconnect the server from the power source, wait approximately 15
seconds for the server to stop running before you open the cover. Watch for the
power-on LED on the front of the server to stop flashing.
3. When you press the power-control button on any server in a scalable partition,
all servers in the scalable partition will be turned off. If the servers do not turn
off when the power-control button is pressed, see the Hardware Maintenance
Manual and Troubleshooting Guide on the IBM xSeries Documentation CD.
Opening the cover
Complete the following steps to open the server cover:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Slide the server out from the rack.
Latch
N
T
O
:
E
R
O
F
P
P
O
R
E
R
A
F
IR
,
W
O
L
R
E
C
A
L
P
E
:
FA
E
T
O
N
N
H
IT
W
IN
A
F
E
T
IR
U
IN
M
R
X
O
B
2
F
O
E
P
O
R
P
T
N
O
R
F
R
O
F
S
,
W
O
L
R
E
E
C
A
L
P
N
FA
F
H
IT
W
T
N
O
R
IN
U
IN
M
X
O
B
2
F
O
S
E
T
3. Pull the release latch on the left side of the top cover to the right.
4. Using the finger hole in the release latch, open the left side of the cover; then,
open the right side of the cover.
Attention: For proper cooling and airflow, close the cover before turning on
the server. Operating the server for extended periods of time (over 15 minutes)
with the cover open might damage server components.
Removing and replacing the bezel
Complete the following steps to remove the bezel:
1. Press on the two tabs at the top edge of the bezel, and pull the top of the bezel
slightly away from the server.
16
xSeries 455: Option Installation Guide
2. Press on the two tabs at the bottom edge of the bezel, and pull the bezel off the
server. Store the bezel in a safe place.
4
P
C
I
B
o
a
rd
5
S
y
s
te
m
M
a
n
a
g
e
m
e
n
t
B
o
a
6
rd
U
p
p
e
r
E
O
C
I/
C
B
o
a
rd
C
o
L
1
r
n
e
o
w
m
o
m
C
U
E
R
C
F
N
u
m
b
e
rs
M
id
la
2
p
n
e
B
o
a
rd
3
L
ig
h
t-P
a
th
D
ia
g
n
o
s
tic
s
N
:
E
T
O
O
F
R
P
O
R
P
R
E
A
IR
F
L
,
W
O
E
R
P
L
C
A
:
N
R
H
P
R
,
W
O
S
E
L
F
T
U
IR
IN
A
X
O
M
E
B
2
F
IN
O
P
O
R
T
N
IT
W
O
F
O
R
F
FA
E
E
T
O
N
E
R
P
L
E
C
A
FA
W
H
T
N
IT
O
R
N
F
IN
IN
X
O
M
B
2
F
O
E
T
U
S
Complete the following steps to replace the bezel:
1. Align the four tabs on the bezel with the slots in the server chassis.
2. Press firmly against the front of the bezel until it snaps into place.
4
I
C
P
rd
a
o
B
5
m
te
s
y
S
t
n
e
m
e
g
a
n
a
M
rd
a
o
B
6
r
e
p
p
U
rd
a
o
B
C
E
C
O
I/
1
r
e
w
o
L
n
o
m
m
o
C
C
E
C
U
R
F
rs
e
b
m
u
N
2
e
n
la
p
id
M
rd
a
o
B
3
th
a
t-P
h
ig
L
s
tic
s
o
n
g
ia
D
:
E
T
O
N
R
O
F
R
E
P
O
R
P
,
W
O
L
F
IR
A
E
C
A
L
P
E
R
2
S
E
T
U
IN
M
,
W
O
L
F
IR
A
X
O
B
R
E
P
O
R
P
F
O
IN
H
IT
W
R
O
F
T
N
O
R
F
N
FA
:
E
T
O
N
E
C
A
L
P
E
R
N
FA
S
E
T
U
IN
M
X
O
B
2
F
O
IN
H
IT
W
T
N
O
R
F
17
Chapter 2. Installing options
Removing and replacing a hot-swap power supply
Your server comes with two hot-swap power supplies, which you can remove and
replace without turning off the server. The following illustration shows the locations
of the power supplies on the front of the server.
Power LEDs
Power supply 1
Power supply 2
Power-on LED
Power-control
button
Reset button
Power-supply
latch
Handle
Before you remove or replace a power supply, review the following information.
Notes:
1. The power supplies are hot-swappable and redundant only at 200-240 V ac.
2. Both power supplies must be connected to the power source for operation at
100-127 V ac.
3. During normal operation, both power supplies must be installed for proper
operation and cooling.
If you install or remove a power supply, observe the following precautions.
Statement 8:
CAUTION:
Never remove the cover on a power supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact
a service technician.
Complete the following steps to remove and replace a power supply:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Remove the front bezel (see “Removing and replacing the bezel” on page 16).
18
xSeries 455: Option Installation Guide
3. To remove the power supply from the server, press the latch; then, lift the
handle on the power supply to the open position and pull the power supply out
from the server.
4. Install the new power supply.
Power supply
Power-supply
latch
AC LED
DC LED
Power-supply handle
(in open position)
a. Place the handle on the power supply in the open position.
b. Slide the power supply into the chassis and press the handle to the closed
position.
5. Verify that the dc power LED and the ac power LED on the power supply are lit,
indicating that the power supply is operating correctly.
6. Replace the front bezel on the server (see “Removing and replacing the bezel”
on page 16).
Installing an adapter
Attention: Before you remove or replace the Remote Supervisor Adapter or clear
the nonvolatile random access memory (NVRAM), be sure to make a backup copy
of the nonvolatile EFI variables. See “Backing up and restoring the nonvolatile
variables” on page 56 for more information.
The following notes describe the types of adapters that your server supports and
other information that you must consider when installing an adapter:
v The following illustration shows the location and bus speeds of the PCI-X
expansion slots on the PCI-X board.
Chapter 2. Installing options
19
Note: The illustrations in this publication might differ slightly from your hardware.
PCI-X slot 4
(100 MHz)
PCI-X slot 5
(133 MHz)
PCI-X slot 3
(100 MHz)
PCI-X slot 2
(66 MHz)
PCI-X slot 6
(133 MHz)
Attention LED
Power LED
PCI-X slot 1
(66 MHz)
v Locate the documentation that comes with the adapter and follow those
instructions in addition to the instructions in this section. If you need to change
the switch settings or jumper settings on your adapter, follow the instructions that
come with the adapter.
v Video adapters are not supported.
v Some full-length adapters have extension handles or brackets installed. Before
installing the adapter, you must remove the extension handle or bracket.
v Your server supports six hot-plug 64-bit adapters in the expansion slots on the
PCI-X board, as shown in the following table.
Bus
Slot
Supported adapter speed (MHz)
A
1
66
A
2
66
B
3
100 (133 if slot 4 is empty)
B
4
100 (133 if slot 3 is empty)
C
5
133
D
6
133
v You can install both PCI and PCI-X adapters on the same bus. However, if you
install a PCI adapter and a PCI-X adapter on the same bus, the PCI-X features
of the PCI-X adapter will be disabled, and the adapter will function as a PCI
adapter.
v You can install PCI or PCI-X adapters of speeds faster than what is labeled for a
particular PCI-X bus. For example, if you install two 133 MHz adapters into slots
that are labeled as 100 MHz slots, the adapters will operate at 100 MHz.
v If you install a 33 MHz and a 66 MHz adapter on the same bus, the bus speed
will match that of the slower adapter.
20
xSeries 455: Option Installation Guide
v If a single 133 MHz adapter is installed on PCI-X bus B (slots 3 and 4) and the
other slot on PCI-X bus B is empty, the adapter will operate at 133 MHz.
v Your server supports 3.3 V and universal adapters; it does not support 5.0 V
adapters.
v The system scans PCI-X slots to assign system resources. The system attempts
to start the first device found. The search order is: PCI-X slots 1, 2, 6, 5, 3, and
4. If an optional remote I/O enclosure is attached, the scan continues with PCI-X
slots 11, 12, 9, 10, 7, 8, 17, 18, 15, 16, 13, and 14.
Complete the following steps to install an adapter.
Attention: When you handle static-sensitive devices, take precautions to avoid
damage from static electricity. For details about handling these devices, see
“Handling static-sensitive devices” on page 14.
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Disable the PCI-X slot through your operating system before you insert or
remove a PCI or PCI-X adapter.
Note: Some operating systems do not support the enabling and disabling of a
PCI-X slot. If your operating system does not support this function, turn
off the server and peripheral devices, and disconnect the power cords
and all external devices from the back of the server before proceeding.
3. Open the top cover.
Tab
Adapter guide
Adapter
retention
latch
PCI-X
divider
Attention
LED
Power
LED
N
T
O
E
:
F
O
R
P
O
R
P
E
R
A
IR
F
L
,
W
O
R
E
P
L
:
FA
E
E
T
O
C
A
N
N
W
H
IN
O
O
R
T
P
N
IT
R
O
R
O
F
F
M
U
IR
IN
A
X
O
R
B
E
2
F
P
T
,
W
O
S
L
E
F
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
4. Follow the cabling instructions, if any, that come with the adapter. Route the
adapter cables before you install the adapter.
Chapter 2. Installing options
21
5. Follow the instructions that come with the adapter to set jumpers or switches, if
any.
6. Install the adapter:
a. If you are installing a full-length adapter, open the blue adapter guide by
lifting the front edge, as shown in the illustration.
b. Push the orange adapter-retention latch toward the rear of the server and
open the tab.
c. Remove the expansion-slot cover.
d. Carefully grasp the adapter by its top edge or upper corners, and align it
with the connector on the PCI-X board.
Note: Some long adapters have extension handles or brackets. Before
installing a long adapter, you must remove the extension handle or
bracket.
e. Press the adapter firmly into the adapter connector.
Attention: When you install an adapter, make sure that the adapter is
correctly seated in the connector. Improperly seated adapters might cause
damage to the PCI-X board or to the adapter.
f. Push down on the blue adapter guide to keep the adapter steady.
g. Close the tab; then, push down on the blue adapter-retention latch until it
clicks into place, securing the adapter.
7. Connect the internal cables to the adapter.
8. If you disabled the slot in step 1, enable the slot.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Cabling a ServeRAID adapter
Some xSeries 455 models come with an optional IBM ServeRAID™ adapter
installed to control hard disk drives. If you are installing an optional IBM ServeRAID
adapter, see the ServeRAID documentation and the cabling information in this
section to install the ServeRAID adapter.
Servers that do not come with an IBM ServeRAID adapter installed come with two
SCSI cables:
v One end of the first SCSI cable is attached to a SCSI connector on the I/O
board, and the other end is attached to the SCSI backplane behind fans 3 and 4.
v The second SCSI cable is preinstalled along the inside of the server and both
ends are loose inside the server. When you install a ServeRAID adapter, you can
optionally connect this cable to the adapter and to the SCSI backplane to control
the internal hard disk drives.
The following procedure describes the internal cabling for installing a ServeRAID
adapter.
Complete the following steps to cable the ServeRAID adapter:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Turn off the server and peripheral devices, and disconnect the power cords and
all external cables; then, open the cover.
22
xSeries 455: Option Installation Guide
3. Remove fans 3 and 4, which are located just behind the PCI-X slots (see “Major
components of the xSeries 455 server” on page 3 for the locations of the fans).
4. Disconnect the short SCSI cable from the SCSI backplane and the SCSI
connector on the I/O board; then, store this short cable in a safe place for future
use.
SCSI connector
on I/O board
SCSI backplane
N
E
T
O
:
R
O
F
O
R
P
R
E
P
A
IR
L
F
,
W
O
P
E
R
E
C
A
L
N
IN
O
O
R
T
P
N
H
IT
W
R
O
O
R
F
F
N
FA
:
E
T
O
S
,
W
O
L
F
E
T
U
IR
A
X
O
IN
M
B
2
F
R
E
P
R
C
A
L
P
E
E
N
FA
T
H
IT
W
N
O
R
F
IN
M
X
O
B
2
F
O
IN
U
S
E
T
5. Install the ServeRAID adapter in a PCI-X slot (see “Installing an adapter” on
page 19). Install the ServeRAID adapter in PCI-X slot 6, if the adapter will
control the internal hard disk drives.
Connect to
ServeRAID adapter
Preinstalled
SCSI cable
Connect to
SCSI backplane
N
E
T
O
:
F
R
O
P
O
R
E
P
R
IR
A
,
W
O
L
F
R
P
E
C
A
L
E
:
E
T
O
N
FA
IT
W
H
IN
2
IN
S
E
,
W
O
L
F
T
U
IR
A
X
O
M
B
R
E
P
F
O
O
R
T
P
N
O
R
N
F
R
O
F
C
A
L
P
E
R
E
N
FA
F
N
IT
W
O
R
O
IN
H
T
U
IN
X
O
M
B
2
F
E
T
S
6. Locate the preinstalled SCSI cable; then, attach the connector on the cable to
the ServeRAID adapter.
7. Locate the connector on the opposite end of the SCSI cable and connect it to
the SCSI backplane.
8. Reinstall fans 3 and 4.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Chapter 2. Installing options
23
Installing a hot-swap hard disk drive
Complete the following steps to install or replace a hot-swap hard disk drive.
Attention:
v When you handle static-sensitive devices, take precautions to avoid damage
from static electricity. For details about handling these devices, see “Handling
static-sensitive devices” on page 14.
v Before you hot-swap a drive, make sure that it is defective. If you partially or
completely remove a good drive instead of a defective one, your server might
lose data.
v If you replace a hot-swap drive, remove the defective drive and wait 15 seconds
before you install a new drive.
1. Inspect the drive for any signs of damage.
2. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
3. Check the instructions that come with the drive for more information about
installing the drive.
4. Remove the filler panel or defective hard disk drive from the hard disk drive bay.
Attention: Only replace a hard disk drive if the amber hard disk drive error
LED is lit continuously.
Filler panel
5. Install the new hard disk drive in the drive bay:
a. Make sure that the handle on the hard disk drive tray is in the open position.
b. Slide the drive into the bay until it stops.
c. Push the handle on the front of the hard disk drive closed.
d. Check the hard disk drive status LED to verify that the hard disk drive is
operating properly.
If the amber hard disk drive error LED for a drive is lit continuously, that
individual drive is faulty and needs to be replaced. If the green hard disk
drive activity LED is flashing, the drive is being accessed.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
24
xSeries 455: Option Installation Guide
Installing a CD-ROM or DVD-ROM drive
The following notes describe the types of CD-ROM or DVD-ROM drives that your
server supports and other information that you must consider when installing a
CD-ROM or DVD-ROM drive:
v Your xSeries 455 server supports up to two CD-ROM drives, or two DVD-ROM
drives, or a combination.
v If you have only one IDE device installed, it must be installed in the right
removable-media bay. CD-ROM or DVD-ROM drives can be installed in either
removable-media bay.
Complete the following steps to install a CD-ROM or DVD-ROM drive in your
server:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Turn off the server and peripheral devices, and disconnect the power cords and
all external devices from the back of the server.
3. Push the drive-eject button to the right.
4. Remove the filler panel or defective drive from the drive bay.
5. Inspect the drive for any signs of damage.
6. Slide the CD-ROM or DVD-ROM drive into the drive bay until it stops.
Removable
media bays
:
E
T
O
N
R
O
F
R
E
P
O
R
P
,
W
O
L
F
IR
A
Filler panel
E
C
A
L
P
E
R
IN
H
IT
W
S
E
T
U
IN
M
,
W
O
L
F
IR
A
X
O
B
2
F
O
R
E
P
O
R
P
T
N
O
R
F
R
O
F
N
FA
:
E
T
O
N
E
C
A
L
P
E
R
N
FA
S
E
T
U
IN
M
X
O
B
2
F
O
IN
H
IT
W
T
N
O
R
F
CD-ROM
or DVD drive
CD-ROM drive
eject button
Tab
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Complete the following steps to remove a CD-ROM or DVD-ROM drive in your
server:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
Chapter 2. Installing options
25
2. Turn off the server and peripheral devices, and disconnect the power cords and
all external devices from the back of the server.
3. Push the drive-eject button to the right.
4. Using the tab, pull the CD-ROM or DVD-ROM drive partially out of the server;
then, grasp the drive and remove it from the server.
5. Install a filler panel or drive in the drive bay.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Installing memory
The following notes describe the types of dual inline memory modules (DIMMs) that
your server supports and other information that you must consider when installing
DIMMs:
v Your server supports 512 MB, 1 GB, and 2 GB DIMMs, for a maximum of 56 GB
of system memory. Your server supports up to twenty-eight 2.5 V, 184 pin,
PC2100, ECC DDR SDRAM, 133 MHZ DIMMs. Go to the ServerProven® list at
http://www.ibm.com/pc/compat/ for a list of memory modules you can use with
your server.
v Your server comes with a minimum of two 512 MB DIMMs, installed in slots 1
and 14. When installing additional DIMMs, you must install two DIMMS at a time,
in the order shown in the following table to maintain performance.
Table 2. DIMM installation sequence
Pair
DIMM connectors (port 1)
Pair
DIMM connectors (port 2)
1
1 and 14
2
15 and 28
3
2 and 13
4
16 and 27
5
3 and 12
6
17 and 26
7
4 and 11
8
18 and 25
9
5 and 10
10
19 and 24
11
6 and 9
12
20 and 23
13
7 and 8
14
21 and 22
Port 1
Port 2
DIMM error LEDs
are built into each handle
26
xSeries 455: Option Installation Guide
v Each DIMM in a pair must be of the same size and technology to ensure that the
server will operate properly.
v You can configure your server to use memory mirroring and memory scrubbing.
For detailed information about configuring your server and using these features,
see the User’s Guide on the IBM xSeries Documentation CD.
v When using memory mirroring, you must install two pairs of DIMMs at a time.
The four DIMMs in each bank must be identical. The following table shows the
pairs that are in each bank. See Table 2 on page 26 for the DIMM connector pair
assignments.
Table 3. Memory mirroring DIMM installation sequence
Bank
DIMM pairs
Bank
DIMM pairs
1
1 and 2
5
9 and 10
2
3 and 4
6
11 and 12
3
5 and 6
7
13 and 14
4
7 and 8
v You can replace a failed DIMM while the server is on, provided that you have
enabled memory mirroring and that you have installed all DIMMs in the sequence
to support memory mirroring.
If a problem with a DIMM is detected, light path diagnostics will light the
system-error LED on the front of the server, indicating that there is a problem
and guide you to the defective DIMM. When this occurs, first identify the
defective DIMM; then, remove and replace the DIMM. See “Hot-replacing
DIMMs” on page 29 for instructions.
The following illustration shows the LEDs on the DIMM access door:
Port 1 power LED
Memory hot-plug
enabled LED
Port 2 power LED
N
E
T
O
:
F
O
R
O
R
P
R
E
P
F
IR
A
,
W
O
L
E
R
P
L
W
H
T
O
R
P
N
IT
R
O
R
N
F
O
F
FA
:
E
E
T
O
C
A
N
IN
M
R
X
O
B
E
2
F
O
P
T
L
F
IR
U
IN
A
E
S
,
W
O
E
R
C
A
L
P
E
FA
N
O
R
F
W
H
IT
N
T
M
T
U
IN
X
O
B
2
F
IN
O
S
E
Port 1 power LED: When this LED is off, it indicates that power is removed from
the port and that you can replace a failed DIMM.
Memory hot-plug enabled LED: When this LED is lit, it indicates that hot-swap
memory is enabled. When this LED is flashing, it indicates that data is being
mirrored on the replacement DIMMs.
Port 2 power LED: When this LED is off, it indicates that power is removed from
the port and that you can replace a failed DIMM.
Chapter 2. Installing options
27
v When you install or remove DIMMs, the server configuration information
changes. When you restart the server, the server displays a message indicating
that the memory configuration has changed.
Removing and replacing DIMMs
Complete the following steps to install a DIMM in your server with the server turned
off:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Turn off the server and peripheral devices, and disconnect the power cords and
all external cables; then, open the server cover.
Attention: When you handle static-sensitive devices, take precautions to
avoid damage from static electricity. For details about handling these devices,
see “Handling static-sensitive devices” on page 14.
3. Open the DIMM access door that covers the DIMM connector into which you
will be installing the DIMM.
4. Install the new DIMM:
a. Open the retaining clip on each end of the DIMM connector.
b. Touch the static-protective package containing the DIMM to any unpainted
metal surface on the server. Then, remove the DIMM from the package.
Attention: To avoid breaking the retaining clips or damaging the DIMM
connectors, open and close the clips gently.
c. Turn the DIMM so that the DIMM keys align correctly with the slot.
d. Insert the DIMM into the connector by aligning the edges of the DIMM with
the slots at the ends of the DIMM connector. Firmly press the DIMM straight
down into the connector by applying pressure on both ends of the DIMM
simultaneously. The retaining clips snap into the locked position when the
DIMM is firmly seated in the connector. If there is a gap between the DIMM
and the retaining clips, the DIMM has not been correctly inserted; open the
28
xSeries 455: Option Installation Guide
retaining clips, remove the DIMM, and then reinsert it.
DIMM slot 15
DIMM slot 28
DIMM slot 1
DIMM slot 14
5. Close the DIMM access door.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Hot-replacing DIMMs
Complete the following steps to install a DIMM in your server with the server turned
on:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Open the top cover and verify that the memory hot-plug enabled LED on the
DIMM access door is lit before removing and replacing the DIMM.
Attention: When you handle static-sensitive devices, take precautions to
avoid damage from static electricity. For details about handling these devices,
see “Handling static-sensitive devices” on page 14.
3. Open the DIMM access door and verify that the memory port power LED is off
before replacing a DIMM. Then, open the retaining clip on each end of the
DIMM connector and remove the DIMM from the server.
Chapter 2. Installing options
29
4. Install the new DIMM:
a. Open the retaining clip on each end of the DIMM connector.
b. Touch the static-protective package containing the DIMM to any unpainted
metal surface on the server. Then, remove the DIMM from the package.
Attention: To avoid breaking the retaining clips or damaging the DIMM
connectors, open and close the clips gently.
c. Turn the DIMM so that the DIMM keys align correctly with the slot.
d. Insert the DIMM into the connector by aligning the edges of the DIMM with
the slots at the ends of the DIMM connector. Firmly press the DIMM straight
down into the connector by applying pressure on both ends of the DIMM
simultaneously. The retaining clips snap into the locked position when the
DIMM is firmly seated in the connector. If there is a gap between the DIMM
and the retaining clips, the DIMM has not been correctly inserted; open the
retaining clips, remove the DIMM, and then reinsert it.
DIMM slot 15
DIMM slot 28
DIMM slot 1
DIMM slot 14
5. Close the DIMM access door and verify that the memory port power LED is lit.
Note: The memory hot-plug enabled LED flashes to indicate that data is being
mirrored on the replacement DIMMs. Wait until the LED stops flashing before
you hot-replace DIMMs again.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Installing and replacing a microprocessor and power module
The following notes describe the type of microprocessor that your server supports
and other information that you must consider when installing and replacing a
microprocessor:
v Your server supports up to four Intel® Itanium 2 microprocessors.
v Update the server system abstraction layer/extensible firmware interface
(SAL/EFI) code. To download the most current level of SAL/EFI code for the
server, go to http://www.ibm.com/pc/support/.
v You will need the following tools:
– 2.5-mm hex (Allen) wrench (provided with the microprocessor option)
– T15 Torx wrench (provided with the microprocessor option)
30
xSeries 455: Option Installation Guide
v To order additional microprocessor options, contact your IBM marketing
representative or authorized reseller.
v Populate the microprocessor sockets in numeric order. Install the first
microprocessor in microprocessor socket 1, the second microprocessor in
microprocessor socket 2, and so on.
v The following illustrations show the locations of the microprocessor connectors
on the processor board.
Note: The illustrations in this publication might differ slightly from your hardware.
Front
Microprocessor 3
baffle
Microprocessor 3
power module socket
Microprocessor 3
power module
cable connector
Microprocessor 1
power module
Microprocessor 1
power module
cable connector
Microprocessor 1
Back
Microprocessor 4 socket
Microprocessor 4 power
module socket
Microprocessor 4 power
module cable connector
Microprocessor 2 power
module socket
Microprocessor 2 power
module cable connector
Microprocessor 2 socket
Important: To ensure proper server operation after you install replacement or
additional microprocessors, install only microprocessors that have the same
cache size and type, and the same clock speed. For a list of microprocessors
supported by your server, go to the ServerProven list at
http://www.ibm.com/pc/us/compat/.
Complete the following steps in the prescribed order to install and replace a
microprocessor.
Attention: Failure to complete the following steps in the prescribed order might
cause damage to the microprocessor pins and cause the microprocessor to fail.
Chapter 2. Installing options
31
1. Read the safety information beginning on page v and “Installation guidelines”
on page 13.
2. Turn off the server and peripheral devices, and disconnect the power cords
and all external cables; then, open the cover.
3. Remove the memory-board assembly from the server.
Attention: When you handle static-sensitive devices, take precautions to
avoid damage from static electricity. For details about handling these devices,
see “Handling static-sensitive devices” on page 14.
a. Pull up on the levers to detach the memory-board assembly.
b. Carefully remove the memory-board assembly from the server and set it
aside.
:
E
T
O
N
R
O
F
R
E
P
O
R
P
,
W
O
L
F
IR
A
E
C
A
L
P
E
R
IN
H
IT
W
S
E
T
U
IN
M
,
W
O
L
F
IR
A
X
O
B
2
F
O
R
E
P
O
R
P
T
N
O
R
F
R
O
F
N
FA
:
E
T
O
N
E
C
A
L
P
E
R
N
FA
S
E
T
U
IN
M
X
O
B
2
F
O
IN
H
IT
W
T
N
O
R
F
4. Remove the shipping thumbscrews from the right side of the server.
5. Lift the retention bracket from the server.
Lift tabs
N
T
O
:
E
O
F
R
O
R
P
E
P
R
A
IR
,
W
O
L
F
R
P
E
E
C
A
L
:
FA
E
T
O
N
N
H
IN
O
O
R
T
P
N
IT
W
R
O
R
F
O
F
M
IN
F
S
E
T
U
IR
A
X
O
R
B
2
F
E
P
,
W
O
L
R
P
E
C
A
L
E
FA
N
N
O
R
F
IT
W
O
IN
M
X
O
B
2
F
IN
H
T
S
E
T
U
Shipping
thumbscrews
32
xSeries 455: Option Installation Guide
6. Loosen the blue thumbscrews securing the EMC shield; then, remove the EMC
shield from the server.
Thumbscrews
7. Remove the processor-board assembly from the server.
Attention: When you handle static-sensitive devices, take precautions to
avoid damage from static electricity. For details about handling these devices,
see “Handling static-sensitive devices” on page 14.
a. Press to unlock the levers securing the processor-board assembly and pull
up on the levers to release the processor-board assembly.
b. Slide the assembly toward the right side of the server.
c. Carefully remove the processor-board assembly from the server and place
it on a flat, level surface.
Levers
N
T
O
:
E
O
F
R
O
R
P
P
R
E
IR
A
,
W
O
L
F
P
E
R
C
A
L
N
E
E
T
O
FA
:
N
T
O
R
P
N
IN
H
IT
W
R
O
R
F
O
F
M
IR
E
T
U
IN
A
X
O
R
B
2
F
O
E
P
,
W
O
S
L
F
R
P
E
C
A
L
E
N
FA
F
N
H
IT
W
O
R
T
IN
U
IN
X
O
M
B
2
F
O
S
E
T
8. If you are installing a new microprocessor, go to step 9 on page 34; otherwise,
continue.
Chapter 2. Installing options
33
Attention: Failure to complete the instructions in the prescribed order might
cause damage to the microprocessor pins and cause the microprocessor to
fail.
Microprocessor
Power module
a. Using the T-handled Torx wrench provided with the microprocessor option,
completely loosen the power-module screws.
b. Slide the power module from the microprocessor and remove the power
module.
c. Completely loosen the heat-sink screws.
d. Use the hex wrench provided with the microprocessor option to open the
socket lock and remove the microprocessor.
Unlocked
Locked
Locking
flag
9. Install the microprocessor and power module:
a. Remove the microprocessor baffle from the microprocessor socket. Keep
the microprocessor baffle for future use.
b. Remove the protective tape covering the microprocessor socket, if there is
any.
34
xSeries 455: Option Installation Guide
Attention: Inserting the microprocessor in a locked connector might
damage the pins and cause the microprocessor to fail.
Power module
Microprocessor
Microprocessor
baffle
c. Make sure that the socket lock is in the fully open (unlocked) position to
permit inserting the microprocessor. Use the hex wrench that is provided
with the microprocessor option to open the lock, if necessary.
Chapter 2. Installing options
35
Note: Examine the socket lock of an installed microprocessor to identify
the locking flag in the locked position.
Unlocked
Locked
Locking
flag
Attention: When you handle static-sensitive devices, take precautions to
avoid damage from static electricity. For details about handling these devices,
see “Handling static-sensitive devices” on page 14.
d. Touch the static-protective package containing the microprocessor to any
unpainted metal surface on the server. Then, remove the microprocessor
and power module from the package.
Attention:
1) Forcing the microprocessor socket lock clockwise beyond the closed
position might damage the socket locking mechanism. Before you
install a microprocessor in the socket, use the hex wrench that is
provided with the microprocessor option to close and open the socket
lock to observe the locking flag in the closed position. Also, note the
resistance of the locking mechanism in the closed position. When
installing the microprocessor, do not force the socket lock clockwise
beyond the closed position. If you need to see the microprocessor
socket lock clearly, shine a flashlight over the microprocessor
connector.
2) Make sure that the microprocessor is aligned and seated correctly
before you proceed. To avoid bending the pins on the microprocessor,
do not use excessive force when pressing it into the socket.
e. Insert the microprocessor gently into the connector. The microprocessor
rests flat on the retention mechanism when properly seated.
f. Lock the socket lock, using the hex wrench that is provided with the
microprocessor option.
g. Tighten the heat-sink screws to secure the microprocessor, using the
T-handled Torx wrench that is provided with the microprocessor option.
h. Slide the power module gently into the microprocessor.
i. Tighten the power-module screws to secure the power module.
36
xSeries 455: Option Installation Guide
j. Connect the power-module cable to the power module and to the adjacent
power-module cable connector.
10. Carefully install the processor-board assembly and retention bracket.
11. Install the EMC shield on the rear of the server; then, hand-tighten the blue
thumbscrews to secure the EMC shield.
12. Carefully install the memory-board assembly.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Replacing and troubleshooting fans
Your xSeries 455 server has four hot-swap fan assemblies, two 150 mm x 51 mm
fans and two 150 mm x 38 mm fans. The two 150 mm x 51 mm fans (fan 1 and fan
2) are located toward the front of the server and are used to cool the memory board
and processor board. The two 150 mm x 38 mm fans (fan 3 and fan 4) are located
just behind the PCI-X board and are used to cool the power supplies, PCI-X slots,
and other components.
Note: The illustrations in this document might differ slightly from your hardware.
Fan 4
Latch release
N
T
O
E
:
F
O
R
P
O
R
P
E
Fan 2
R
A
IR
F
L
,
W
O
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
Fan 3
N
T
O
E
:
F
O
R
P
O
R
P
E
R
A
IR
F
L
,
W
O
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
Fan 1
Each fan has an LED to help you detect a problem. When the fan is operating
correctly, this LED is off. If a fan stops working, light path diagnostics will light the
system-error LED on the front of the server, indicating that there is a problem, and
guide you to the defective fan. When this occurs, first identify the defective fan;
then, using the applicable procedure, remove and replace the fan.
Replacing fan 1 or 2
As shown in the illustration, fans 1 and 2 are located on the right side of the server.
These fans are redundant; if one fails, the remaining fan will temporarily speed up
to properly cool the server components.
Chapter 2. Installing options
37
Attention:
A fan must be replaced within 48 hours of failing.
Complete the following steps to replace fan 1 or 2:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Remove the fan from the server:
a. Place your fingers into the two finger holes on the top of the fan and
squeeze them together.
Note: The illustrations in this document might differ slightly from your
hardware.
Fan 4
Latch release
N
T
O
E
:
F
O
R
P
O
R
P
E
Fan 2
R
A
IR
F
L
,
W
O
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
Fan 3
N
T
O
E
:
F
O
R
P
O
R
P
E
R
A
IR
F
L
,
W
O
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
Fan 1
b. Lift the fan out of the server.
3. Turn the new fan so that the LED on the top of the fan is to the right side of the
server.
4. Push the replacement fan assembly into the server until it clicks into place.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Replacing fan 3 or 4
As shown in the illustration, fan 3 and fan 4 are located in front of the PCI-X slots.
These fans are redundant; if one fails, the remaining fan will temporarily speed up
to properly cool server components.
Attention:
A fan must be replaced within 48 hours of failing.
Complete the following steps to replace fan 3 or 4:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13.
2. Remove the fan from the server:
38
xSeries 455: Option Installation Guide
a. Press the latch release to the right and let the handle come up.
Note: The illustrations in this document might differ slightly from your
hardware.
Fan 4
Latch release
N
T
O
E
:
F
O
R
P
O
R
P
E
Fan 2
R
A
IR
F
L
,
W
O
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
Fan 3
N
T
O
E
:
F
O
R
P
O
R
P
E
R
A
IR
F
L
,
W
O
R
E
P
L
C
A
E
FA
W
O
R
N
F
IT
N
H
T
IN
O
IN
X
O
M
B
2
F
U
T
E
S
Fan 1
b. Grasp the handle and lift the fan out of the server.
3. Turn the new fan so that the latch release on the top of the fan is to the right
side of the server.
4. With the handle raised, push the replacement fan assembly into the server until
it clicks into place.
5. Push the handle down until it clicks into place under the latch release.
If you have other options to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 41.
Chapter 2. Installing options
39
Replacing the battery
When replacing the battery you must replace it with a lithium battery of the same
type, from the same manufacturer. To avoid possible danger, read and follow the
safety statement below.
To order replacement batteries, call 1-800-772-2227 within the United States, and
1-800-465-7999 or 1-800-465-6666 within Canada. Outside the U.S. and Canada,
call your IBM reseller or IBM marketing representative.
Note: After you replace the battery, you must reconfigure your server and reset the
system date and time.
Statement 2:
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
a module containing a lithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.
Do not:
v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Complete the following steps to replace the battery:
1. Read the safety information beginning on page v and “Installation guidelines” on
page 13. Follow any special handling and installation instructions supplied with
the replacement battery.
2. Turn off the server and peripheral devices, and disconnect the power cords and
all external cables from the server; then, open the cover (see “Opening the
cover” on page 16 for details).
3. Remove fans 3 and 4 from the server (see “Replacing fan 3 or 4” on page 38
for details).
40
xSeries 455: Option Installation Guide
4. Remove the battery:
a. Use one finger to press the top of the battery clip away from the battery.
b. Lift and remove the battery from the socket.
5. Insert the new battery:
a. Use one finger to press the top of the battery clip away from the battery.
b. Press the battery into the socket until it clicks into place. Make sure that the
battery clip holds the battery securely.
6. Install fans 3 and 4 in the server (see “Replacing fan 3 or 4” on page 38 for
details).
7. Close the server cover, and connect the cables.
8. Turn on the server.
9. Start the Configuration/Setup Utility program and set configuration parameters.
v Set the system date and time.
v Set the power-on password.
v Reconfigure your server.
Completing the installation
To complete your installation, close the server cover, install your server in a rack,
reconnect all cables that you disconnected earlier, and for certain options, run the
Configuration/Setup Utility program. Follow the instructions in this section.
Attention: For proper cooling and airflow, close the server cover before or shortly
after turning on the server. Operating the server for extended periods of time (over
15 minutes) with the server cover open might damage server components.
Chapter 2. Installing options
41
Closing the cover
Close the cover by first closing the right side; then, close the left side and press
down to latch the two halves of the cover in place.
:
E
T
O
N
R
O
F
R
E
P
O
R
P
,
W
O
L
F
IR
A
E
C
A
L
P
E
R
IN
H
IT
W
S
E
T
U
IN
M
,
W
O
L
F
IR
A
X
O
B
2
F
O
R
E
P
O
R
P
T
N
O
R
F
R
O
F
N
FA
:
E
T
O
N
E
C
A
L
P
E
R
N
FA
S
E
T
U
IN
M
X
O
B
2
F
O
IN
H
IT
W
T
N
O
R
F
Installing the server in a rack
Detailed cabling instructions, including the use of the cable management arm
(which comes with the server) are in the Rack Installation Instructions that come
with the server.
Connecting the cables
The following illustration shows the locations of the input and output connectors on
your server.
Notes:
1. You must turn off the server before connecting or disconnecting cables from
your server.
2. See the documentation that comes with your external devices for additional
cabling instructions. It might be easier for you to route cables before you
connect the devices to the server.
3. Cable identifiers are printed on the cables that come with your server and
options. Use these identifiers to connect the cables to the correct connectors.
4. There are two optional IBM Eserver xSeries 455 SMP Expansion cable kits
available to connect the SMP Expansion Port connectors.
v 4-way to 8-way Scalability Kit (comes with two 2.5 m (8.2 feet) SMP
Expansion cables).
v 8-way to 16-way Supplemental Kit (comes with three 2.5 m (8.2 feet) SMP
Expansion cables and one 3.5 m (11.6 feet) SMP Expansion cable).
5. If your server comes with an operating system installed, see the documentation
that comes with your software for additional cabling instructions.
6. To effectively manage the cables on your server, keep groups of cables secured
together, and do not run cables across the back of the server. Use cable ties to
42
xSeries 455: Option Installation Guide
bundle similar cables together. Use hook-and-loop fasteners to secure the cable
bundles to the vertical rails of the rack cabinet.
Attention: Do not secure cables too tightly. Overtightening can cause internal
damage to the cables.
System power
connector (1)
RXE Expansion Port (B)
connector
System power
connector (2)
Serial connector
Remote
Supervisor
Adapter
connectors
and LEDs
Ethernet
LEDs
SMP Expansion Port 1 connector
SMP Expansion Port 2 connector
SMP Expansion Port 3 connector
SCSI connector
RXE Management Port connector
USB 1 connector
USB 2 connector
Gigabit Ethernet
connectors
RXE Expansion
Port (A) connector
Video connector
SMP Expansion cabling
The cabling information in this section is for multi-node configurations using two or
four servers. A node is one of multiple servers in a configuration interconnected
through the SMP Expansion Ports to share system resources.
Complete the following steps to configure and cable a multi-node configuration:
1. Update the SAL/EFI code and the service processor firmware. To download the
most current level of SAL/EFI code and service processor firmware, go to
http://www.ibm.com/pc/support/. For more information:
v Read the release notes included with the SAL/EFI code.
v See the Remote Supervisor Adapter User’s Guide on the IBM xSeries
Documentation CD.
2. Configure the nodes using the Configuration/Setup Utility program. See the
User’s Guide on the IBM xSeries Documentation CD.
3. Cable the configuration using the instructions in this section.
4. Configure the scalable partition. See “Configuring a scalable partition” in the
User’s Guide on the IBM xSeries Documentation CD.
5. Make sure the service processor on each node is configured and connected to
the network. See the Remote Supervisor Adapter User’s Guide on the IBM
xSeries Documentation CD.
Two-node configuration: A two-node configuration requires the 4-way to 8-way
Scalability Kit option. Complete the following steps to cable a two-node
configuration for up to 8-way operation:
Chapter 2. Installing options
43
1. Remove the protective covers from the connectors on the ends of the cables.
Protective cover
2. Label each end of the SMP Expansion cables according to where they will be
connected to each server. See the following illustration.
Node 1
1
2
3
Node 2
1
2
3
3. Connect the SMP Expansion cables to node 1:
a. Connect one end of an SMP Expansion cable to port 1 on node 1; then,
route the cable through the node 1 cable-management arm.
b. Connect one end of an SMP Expansion cable to port 3 on node 1; then,
route the cable through the node 1 cable-management arm.
Cable-management arm
SMP Expansion cables
44
xSeries 455: Option Installation Guide
4. Connect the SMP Expansion cables to node 2:
a. Locate the SMP Expansion cable that is connected to port 1 on node 1;
then, connect the opposite end of the cable to port 1 of node 2. Next, route
the cable through the node 2 cable-management arm.
b. Locate the SMP Expansion cable that is connected to port 3 on node 1;
then, connect the opposite end of the cable to port 3 of node 2. Next, route
the cable through the node 2 cable-management arm.
5. Connect the Remote Supervisor Adapter Ethernet connector on each server to a
network or to each other with an Ethernet crossover cable. This connection is
needed so that the Remote Supervisor Adapters can communicate and manage
scalable partitions.
6. Route any remaining cables through the cable-management arms.
7. Secure the cables in the cable-management arms with the hook-and-loop straps
that come with your server.
8. Go to “RXE Expansion cabling” on page 48 and complete that procedure, if you
are connecting the configuration to a remote I/O enclosure.
Four-node configuration: A four-node configuration requires one 4-way to 8-way
Scalability Kit option and one 8-way to 16-way Supplemental Kit option. Complete
the following steps to cable a four-node configuration for up to 16-way operation:
1. Remove the protective covers from the connectors on the ends of the cables.
Protective cover
Chapter 2. Installing options
45
2. Label each end of the SMP Expansion cables according to where they will be
connected to each server. See the following illustration.
Node 1
1
2
3
Node 2
1
2
3
Node 3
1
2
3
Node 4
1
2
3
3. Connect the SMP Expansion cables to node 1:
a. Connect one end of an SMP Expansion cable to port 1 on node 1; then,
route the cable through the node 1 cable-management arm. Use a 2.5 m
(8.2 feet) SMP Expansion cable for this connection.
b. Connect one end of an SMP Expansion cable to port 2 on node 1; then,
route the cable through the node 1 cable-management arm. Use a 3.5 m
(11.6 feet) SMP Expansion cable for this connection.
c. Connect one end of an SMP Expansion cable to port 3 on node 1; then,
route the cable through the node 1 cable-management arm. Use a 2.5 m
(8.2 feet) SMP Expansion cable for this connection.
46
xSeries 455: Option Installation Guide
Cable-management arm
SMP Expansion cables
4. Connect the SMP Expansion cables to node 2:
a. Connect one end of an SMP Expansion cable to port 1 on node 2; then,
route the cable through the node 2 cable-management arm. Use a 2.5 m
(8.2 feet) SMP Expansion cable for this connection.
b. Connect one end of an SMP Expansion cable to port 2 on node 2; then,
route the cable through the node 2 cable-management arm. Use a 2.5 m
(8.2 feet) SMP Expansion cable for this connection.
c. Locate the SMP Expansion cable that is connected to port 3 on node 1;
then, connect the opposite end of the cable to port 3 of node 2. Next, route
the cable through the node 2 cable-management arm.
5. Connect the SMP Expansion cables to node 3:
a. Locate the SMP Expansion cable that is connected to port 1 on node 1;
then, connect the opposite end of the cable to port 1 of node 3. Next, route
the cable through the node 3 cable-management arm.
b. Locate the SMP Expansion cable that is connected to port 2 on node 2;
then, connect the opposite end of the cable to port 2 of node 3. Next, route
the cable through the node 3 cable-management arm.
c. Connect one end of an SMP Expansion cable to port 3 on node 3; then,
route the cable through the node 3 cable-management arm. Use a 2.5 m
(8.2 feet) SMP Expansion cable for this connection.
6. Connect the SMP Expansion cables to node 4:
a. Locate the SMP Expansion cable that is connected to port 1 on node 2;
then, connect the opposite end of the cable to port 1 of node 4. Next, route
the cable through the node 4 cable-management arm.
b. Locate the SMP Expansion cable that is connected to port 2 on node 1;
then, connect the opposite end of the cable to port 2 of node 4. Next, route
the cable through the node 4 cable-management arm.
c. Locate the SMP Expansion cable that is connected to port 3 on node 3;
then, connect the opposite end of the cable to port 3 of node 4. Next, route
the cable through the node 4 cable-management arm.
Chapter 2. Installing options
47
7. Connect the Remote Supervisor Adapter Ethernet connector on each server to
the network. This connection is needed so that the Remote Supervisor
Adapters can communicate and manage scalable partitions.
8. Route any remaining cables through the cable-management arms.
9. Secure the cables in the cable-management arms with the hook-and-loop
straps that come with your server.
10. Go to “RXE Expansion cabling” and complete that procedure, if you are
connecting the configuration to one or more remote I/O enclosures.
RXE Expansion cabling
There are two RXE Expansion Port connectors on the rear of the server. Use these
ports to connect the server to a remote I/O enclosure and to expand the number of
PCI-X slots that are available for use by the server. For detailed information about
cabling the RXE Expansion Port connectors, see the documentation that comes
with the remote I/O enclosure.
One server: Complete the following steps to connect the server to a remote I/O
enclosure with one expansion kit installed.
xSeries 455
RXE-100
RXE Expansion
Port A
connector
RXE Expansion Port connector
1. Remove the protective covers from the connectors on the ends of the cables.
Protective cover
2. Using an RXE Expansion cable, connect one end of the cable to the RXE
Expansion Port A connector on the server.
48
xSeries 455: Option Installation Guide
3. Connect the opposite end of the cable to an RXE Expansion Port connector on
the remote I/O enclosure.
Go to “RXE Management cabling” on page 52.
Complete the following steps to connect the server to a remote I/O enclosure with
two expansion kits installed.
RXE Expansion Port B
connector
xSeries 455
RXE-100
RXE Expansion
Port A
connector
RXE Expansion Port connectors
1. Remove the protective covers from the connectors on the ends of the cables.
Protective cover
2. Using an RXE Expansion cable, connect one end of the cable to the RXE
Expansion Port A connector on the server.
3. Connect the opposite end of the cable to an RXE Expansion Port connector on
the remote I/O enclosure.
4. (Optional) Using an RXE Expansion cable, connect one end of the cable to the
RXE Expansion Port B connector on the server. Connect the opposite end to an
RXE Expansion Port connector on the remote I/O enclosure.This cable
connection provides fail-over support.
Go to “RXE Management cabling” on page 52.
Chapter 2. Installing options
49
Two stand-alone servers: Complete the following steps to connect two
stand-alone servers sharing one remote I/O enclosure.
1. Determine which server will be connected to port A of the remote I/O enclosure
and which will be connected to port B.
2. Remove the protective covers from the connectors on the ends of the cables.
Protective cover
3. Using an RXE Expansion cable, connect one end of the cable to the RXE
Expansion Port A connector on the remote I/O enclosure.
4. Connect the opposite end of the cable to the RXE Expansion Port A connector
on the applicable server.
5. Using an RXE Expansion cable, connect one end of the cable to the RXE
Expansion Port B connector on the remote I/O enclosure.
6. Connect the opposite end of the cable to the RXE Expansion Port A connector
on the applicable server.
Go to “RXE Management cabling” on page 52.
Multi-node configurations: Complete the following steps to connect a remote I/O
enclosure to a two-node or four-node configuration. For information about cabling
the RXE Management Port connectors, see “RXE Management cabling” on page 52
50
xSeries 455: Option Installation Guide
page 52.
Notes:
1. You can connect a remote I/O enclosure to both nodes of a two-node
configuration. If the remote I/O enclosure has only one expansion kit installed,
you can connect the RXE Expansion Port A connector on the primary server to
the remote I/O enclosure.
2. You can connect a remote I/O enclosure to nodes 1 and 2 or nodes 3 and 4 of
a four-node configuration. You can also connect remote I/O enclosures to both
nodes 1 and 2 and nodes 3 and 4 of a four-node configuration.
1. Remove the protective covers from the connectors on the ends of the cables.
Protective cover
Chapter 2. Installing options
51
2. Using an RXE Expansion cable, connect the RXE Expansion Port A connector
on one server to the remote I/O enclosure.
3. Using an RXE Expansion cable, connect the RXE Expansion Port A connector
on the other server to the remote I/O enclosure.
4. (Optional) Using an RXE Expansion cable, connect the RXE Expansion Port B
connector on one server to the RXE Expansion Port B connector on the other
server. This cable connection provides fail-over support.
Go to “RXE Management cabling”.
RXE Management cabling
There is one RXE Management Port connector on the back of the server. Use this
port to connect the server to the management port of an optional remote I/O
enclosure. This port is used to manage the PCI-X slots in a remote I/O enclosure,
including slot assignments and managing access. For details about how the server
and remote I/O enclosure work together, see the documentation that comes with the
enclosure.
One server: Complete the following steps to connect the server RXE
Management Port connector to a remote I/O enclosure.
Note: Use the following instructions regardless of whether your remote I/O
enclosure has one or two expansion kits installed.
xSeries 455
RXE Management Port
connector
RXE Management A (in) Port
connector
RXE-100
RXE Management A (out) Port
connector
RXE Management B (in) Port
connector
1. Using an RXE Management cable, connect one end of the cable to the RXE
Management Port connector on the server.
2. Connect the opposite end of the cable to the RXE Management A (in) Port
connector on the remote I/O enclosure.
3. Using a jumper cable, connect the RXE Management A (out) Port on the remote
I/O enclosure to the RXE Management B (in) Port on the remote I/O enclosure.
Two stand-alone servers: Complete the following steps to connect the RXE
Management Port connectors of two stand-alone servers to a remote I/O enclosure.
Note: The configuration shown in the following illustration is two servers that are
independent of each other. Notice that there are no interconnecting cables
52
xSeries 455: Option Installation Guide
between the two servers.
RXE Management A
(in) Port
xSeries 455
RXE Management Port
xSeries 455
RXE Management B
(in) Port
RXE Management Port
1. Using an RXE Management cable, connect one end of the cable to the RXE
Management Port connector on one of the servers.
2. Connect the opposite end of the cable to the RXE Management A (in) Port
connector on the remote I/O enclosure.
3. Using an RXE Management cable, connect one end of the cable to the RXE
Management Port connector on the other server.
4. Connect the opposite end of the cable to the RXE Management A (in) Port
connector on the remote I/O enclosure.
Multi-node configurations: Complete the following steps to connect a remote I/O
enclosure to a two-node or four-node configuration.
Note: You can connect a remote I/O enclosure to both nodes of a two-node
configuration. If the remote I/O enclosure has only one expansion kit
installed, you can connect the RXE Management Port connector on the
primary server to the RXE Management A (in) Port on the remote I/O
Chapter 2. Installing options
53
enclosure.
RXE Management A
(in) Port
Node 1
RXE Management Port
Node 2
RXE Management B
(in) Port
RXE Management Port
RXE Management A
(in) Port
Node 3
RXE Management Port
Node 4
RXE Management B
(in) Port
B
RXE Management Port
1. Using an RXE Management cable, connect the RXE Management Port
connector on one server to the remote I/O enclosure.
2. Using an RXE Management cable, connect the RXE Management Port
connector on the other server to the remote I/O enclosure.
Power cabling
Your server comes with two power cords that can be connected to an external
source, such as a properly grounded electrical outlet. Your server can also use two
power cords that can be connected to a primary power unit inside the rack cabinet,
such as a properly grounded power distribution unit or uninterruptible power supply.
Complete the following steps to connect the power cords:
1. Connect the power cords to the system power connectors on the rear of the
server.
Notes:
a. The power supplies are hot-swappable and redundant only at 200-240 V ac.
b. Both power supplies must be connected to the power source for operation at
100-127 V ac.
c. During normal operation, both power supplies must be installed for proper
operation.
2. Connect the other end of the power cord to a properly grounded electrical outlet
or a power distribution unit inside the rack cabinet.
Note: Connecting the power cords into an electrical outlet might cause the
server to start automatically. This is an acceptable action.
54
xSeries 455: Option Installation Guide
3. See “Turning on the server” on page 14 for detailed information about turning on
the server.
SCSI cabling
There is one SCSI connector on the back of the server. Use this connector to
connect the server to an optional SCSI device such as a storage enclosure. For
information about how to connect the option to your server, see the documentation
that comes with the option.
USB cabling
There are three USB connectors, one on the front and two on the back of the
server. Use these connectors to connect the server to an optional USB device. For
information about how to connect the option to your server, see the documentation
that comes with the device.
Serial cabling
There is one serial connector on the back of the server. Use this connector to
connect the server to a modem or other optional serial device. For information
about how to connect this device to your server, see the documentation that comes
with the device.
Video cabling
There is one video connector on the back of the server. Use this connector to
connect the server to a monitor or optional console switch. For information about
how to connect this device to your server, see the documentation that comes with
the device.
Gigabit Ethernet cabling
There are two Ethernet connectors on the back of the server. Use these connectors
to connect the server to a LAN.
Note: A third Ethernet connector is on the Remote Supervisor Adapter. This
connector is used for specific supervisory functions; do not confuse it with
the Gigabit Ethernet connectors.
Remote Supervisor Adapter cabling
Your server comes with a Remote Supervisor Adapter. For information about cabling
the Remote Supervisor Adapter connectors, see the User’s Guide on the IBM
xSeries Documentation CD.
Updating your server configuration
When you start your server for the first time after you add or remove an internal
option or an external SCSI device, you might see a message telling you that the
configuration has changed. See the User’s Guide on the IBM xSeries
Documentation CD for more information about the Configuration/Setup Utility
program.
Some options have device drivers that you need to install. See the documentation
that comes with the device for information about installing any required device
drivers.
If your server comes with two microprocessors or if your server comes with one
microprocessor and you have installed one or more additional microprocessors,
your server can now operate as an SMP server. Therefore, you might need to
upgrade your operating system to support SMP. See the User’s Guide on the IBM
xSeries Documentation CD and your operating-system documentation for additional
information.
Chapter 2. Installing options
55
If you have a RAID configuration on your server using the integrated SCSI
controller and you have installed or removed a hard disk drive, you might need to
reconfigure your disk arrays. See the RAID documentation on the IBM xSeries
Documentation CD for more information about reconfiguring your disk arrays.
If you install a different type of RAID adapter in your server, see the documentation
that comes with the adapter for information about viewing and changing SCSI
settings for attached devices.
Backing up and restoring the nonvolatile variables
The Extensible Firmware Interface (EFI) code in the xSeries 455 server stores its
variables with nonvolatile attributes in NVRAM on the Remote Supervisor Adapter.
Before you remove or replace the Remote Supervisor Adapter or clear the NVRAM,
be sure to make a backup copy of the nonvolatile EFI variables. After you install a
new Remote Supervisor Adapter, you must restore the EFI variables that were
previously stored in NVRAM. The following EFI variables are stored in NVRAM on
the Remote Supervisor Adapter:
v Console definitions
v Boot options / Drivers
v Boot order / Timeout
You can use the xSeries 455 Backup and Restore utilities to back up or restore the
nonvolatile EFI variables that are stored in NVRAM.
Creating a backup copy of the nonvolatile EFI variables
Complete the following steps to create a backup copy of the EFI variables:
1. Make sure that the formatted media where you plan to store the backup file is
inserted in the drive.
2. Start the server.
3. Select EFI Shell from the EFI Firmware Boot Manager.
Note: If EFI shell is not a choice in the list, the server has a customized startup
configuration. Contact your system administrator for instructions.
4. Change to the file system for the formatted media where you want to store the
backup copy.
5. Type the following EFI command to create a backup copy of the EFI variables:
backup filename
where filename is the name you want to assign to the backup copy, for
example, efibckup.001
6. Type dir or Is to verify that the backup file was created successfully.
The backup procedure is now completed.
Restoring the nonvolatile EFI variables
Complete the following steps to restore the nonvolatile EFI variable settings:
1. Make sure that the formatted media that contains the backup copy of the EFI
variables is inserted in the drive.
2. Start the server.
3. Select EFI Shell from the EFI Firmware Boot Manager.
56
xSeries 455: Option Installation Guide
4.
5.
6.
7.
8.
Note: If EFI shell is not a choice on the list, the server has a customized
startup configuration. Contact your system administrator for instructions.
Change to the file system that contains the backup copy of the EFI variables.
Type dir or Is to verify that the backup file was created successfully.
Type the following EFI command to restore the EFI variables:
restore filename
where filename is the name you assigned to the backup copy
When the message Delete existing non-volatile efi variables [y/n]
appears, type Y.
Type reset to reset the system.
The restore procedure is now completed.
Chapter 2. Installing options
57
58
xSeries 455: Option Installation Guide
Chapter 3. Input/output connectors
Your server has the following input/output connectors:
v Two Gigabit Ethernet (RJ-45)
v Two RXE Expansion Port
v One RXE Management Port
v One SCSI
v One serial
v Three SMP Expansion Port
v Three Universal Serial Bus (USB)
v One video
The following illustration shows the locations of these connectors.
System power
connector (1)
RXE Expansion Port (B)
connector
System power
connector (2)
Serial connector
Remote
Supervisor
Adapter
connectors
and LEDs
Ethernet
LEDs
SMP Expansion Port 1 connector
SMP Expansion Port 2 connector
SMP Expansion Port 3 connector
SCSI connector
RXE Management Port connector
USB 1 connector
USB 2 connector
Gigabit Ethernet
connectors
RXE Expansion
Port (A) connector
Video connector
The following sections describe these connectors.
Your server also has an additional Ethernet connector, an additional serial
connector, and an Advanced System Management (ASM) Interconnect connector on
the Remote Supervisor Adapter. See the Remote Supervisor Adapter documentation
on the IBM xSeries Documentation CD for more information.
© Copyright IBM Corp. 2003
59
Gigabit Ethernet connectors
The following illustration shows a Gigabit Ethernet connector.
8
1
Connect a Category 3, 4, or 5 unshielded twisted-pair cable to this connector. The
100BASE-TX and 1000BASE-T Fast Ethernet standards require Category 5 or
higher cabling.
See the User’s Guide on the IBM xSeries Documentation CD for more information
about the Ethernet controller.
RXE Expansion Port connectors
Use the RXE Expansion Port connectors to connect your server to a remote I/O
enclosure. The following illustration shows an RXE Expansion Port connector.
48
2
47
1
RXE Management Port connector
Use the RXE Management Port connector to connect your server to a remote I/O
enclosure. The following illustration shows an RXE Management Port connector.
1
8
SCSI connector
The integrated dual-channel Ultra320 small computer system interface (SCSI)
controller supports one internal and one external independent SCSI connector. The
internal connector is integrated on the I/O board. The external connector is on the
rear of the server. The following illustration shows an external SCSI connector.
60
34
1
68
35
xSeries 455: Option Installation Guide
Serial connector
Use a serial connector to connect a serial device. The following illustration shows a
serial connector.
5
1
6
9
Configure a serial console device to accept the following settings:
Baud rate
115200
Data bit
8
Parity
None
Stop bits
1
Flow control
None
SMP Expansion Port connectors
Use an SMP Expansion Port connector to connect nodes for multi-node
configurations. The following illustration shows an SMP Expansion Port connector.
48
2
47
1
Universal Serial Bus connectors
Use a Universal Serial Bus (USB) connector to connect a USB device. USB
technology transfers data at up to 12 Mb per second (Mbps) with a maximum of
127 devices and a maximum signal distance of 5 meters (16 ft) per segment. Using
Plug and Play technology, USB devices are configured automatically. The following
illustration shows a USB connector.
1
4
Use a 4-pin cable to connect devices to USB 1, USB 2, and USB 3. If you plan to
attach more than three USB devices, you must use a hub to connect the devices.
Video connector
The integrated video controller provides the video connector. The connector is on
the rear of the server. The following illustration shows a video connector.
5
1
15
11
Chapter 3. Input/output connectors
61
62
xSeries 455: Option Installation Guide
Appendix. Notices
This information was developed for products and services offered in the U.S.A.
IBM may not offer the products, services, or features discussed in this document in
other countries. Consult your local IBM representative for information on the
products and services currently available in your area. Any reference to an IBM
product, program, or service is not intended to state or imply that only that IBM
product, program, or service may be used. Any functionally equivalent product,
program, or service that does not infringe any IBM intellectual property right may be
used instead. However, it is the user’s responsibility to evaluate and verify the
operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you any
license to these patents. You can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Some states do not allow disclaimer of express or
implied warranties in certain transactions, therefore, this statement may not apply to
you.
This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. IBM may make improvements and/or
changes in the product(s) and/or the program(s) described in this publication at any
time without notice.
Any references in this information to non-IBM Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those
Web sites. The materials at those Web sites are not part of the materials for this
IBM product, and use of those Web sites is at your own risk.
IBM may use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you.
Edition notice
© COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 2003.
All rights reserved.
U.S. Government Users Restricted Rights — Use, duplication or disclosure
restricted by GSA ADP Schedule Contract with IBM Corp.
© Copyright IBM Corp. 2003
63
Trademarks
The following terms are trademarks of International Business Machines Corporation
in the United States, other countries, or both:
Active Memory
Active PCI
Active PCI-X
Alert on LAN
C2T Interconnect
Chipkill
EtherJet
e-business logo
Eserver
FlashCopy
IBM
IntelliStation
NetBAY
Netfinity
NetView
OS/2 WARP
Predictive Failure Analysis
PS/2
ServeRAID
ServerGuide
ServerProven
TechConnect
ThinkPad
Tivoli
Tivoli Enterprise
Update Connector
Wake on LAN
XA-32
XA-64
X-Architecture
XceL4
XpandOnDemand
xSeries
Lotus, Lotus Notes, SmartSuite, and Domino are trademarks of Lotus Development
Corporation and/or IBM Corporation in the United States, other countries, or both.
Intel, MMX, and Pentium are trademarks of Intel Corporation in the United States,
other countries, or both.
Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in
the United States, other countries, or both.
UNIX is a registered trademark of The Open Group in the United States and other
countries.
Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States, other countries, or both.
Other company, product, or service names may be trademarks or service marks of
others.
Important notes
Processor speeds indicate the internal clock speed of the microprocessor; other
factors also affect application performance.
CD-ROM drive speeds list the variable read rate. Actual speeds vary and are often
less than the maximum possible.
When referring to processor storage, real and virtual storage, or channel volume,
KB stands for approximately 1000 bytes, MB stands for approximately 1 000 000
bytes, and GB stands for approximately 1 000 000 000 bytes.
64
xSeries 455: Option Installation Guide
When referring to hard disk drive capacity or communications volume, MB stands
for 1 000 000 bytes, and GB stands for 1 000 000 000 bytes. Total user-accessible
capacity may vary depending on operating environments.
Maximum internal hard disk drive capacities assume the replacement of any
standard hard disk drives and population of all hard disk drive bays with the largest
currently supported drives available from IBM.
Maximum memory may require replacement of the standard memory with an
optional memory module.
IBM makes no representation or warranties regarding non-IBM products and
services that are ServerProven, including but not limited to the implied warranties of
merchantability and fitness for a particular purpose. These products are offered and
warranted solely by third parties.
IBM makes no representations or warranties with respect to non-IBM products.
Support (if any) for the non-IBM products is provided by the third party, not IBM.
Some software may differ from its retail version (if available), and may not include
user manuals or all program functionality.
Product recycling and disposal
This unit contains materials such as circuit boards, cables, electromagnetic
compatibility gaskets, and connectors which may contain lead and copper/beryllium
alloys that require special handling and disposal at end of life. Before this unit is
disposed of, these materials must be removed and recycled or discarded according
to applicable regulations. IBM offers product-return programs in several countries.
Information on product recycling offerings can be found on IBM’s Internet site at
http://www.ibm.com/ibm/environment/products/prp.shtml.
Battery return program
This product may contain a sealed lead acid, nickel cadmium, nickel metal hydride,
lithium, or lithium ion battery. Consult your user manual or service manual for
specific battery information. The battery must be recycled or disposed of properly.
Recycling facilities may not be available in your area. For information on disposal of
batteries outside the United States, go to
http://www.ibm.com/ibm/environment/products/batteryrecycle.shtml or contact your
local waste disposal facility.
In the United States, IBM has established a collection process for reuse, recycling,
or proper disposal of used IBM sealed lead acid, nickel cadmium, nickel metal
hydride, and battery packs from IBM equipment. For information on proper disposal
of these batteries, contact IBM at 1-800-426-4333. Have the IBM part number listed
on the battery available prior to your call.
In the Netherlands, the following applies.
Appendix. Notices
65
Electronic emission notices
Federal Communications Commission (FCC) statement
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the
interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to
meet FCC emission limits. Properly shielded and grounded cables and connectors
must be used in order to meet FCC emission limits.IBM is not responsible for any
radio or television interference causedby using other than recommended cables and
connectors or by using other than recommended cables and connectors or by
unauthorized changes or modifications to this equipment. Unauthorized changes or
modifications could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Industry Canada Class A emission compliance statement
This Class A digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
Australia and New Zealand Class A statement
Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
United Kingdom telecommunications safety requirement
Notice to Customers
This apparatus is approved under approval number NS/G/1234/J/100003 for indirect
connection to public telecommunication systems in the United Kingdom.
European Union EMC Directive conformance statement
This product is in conformity with the protection requirements of EU Council
Directive 89/336/EEC on the approximation of the laws of the Member States
relating to electromagnetic compatibility. IBM cannot accept responsibility for any
failure to satisfy the protection requirements resulting from a nonrecommended
modification of the product, including the fitting of non-IBM option cards.
66
xSeries 455: Option Installation Guide
This product has been tested and found to comply with the limits for Class A
Information Technology Equipment according to CISPR 22/European Standard EN
55022. The limits for Class A equipment were derived for commercial and industrial
environments to provide reasonable protection against interference with licensed
communication equipment.
Attention: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
Taiwanese Class A warning statement
Chinese Class A warning statement
Japanese Voluntary Control Council for Interference (VCCI) statement
Power cords
For your safety, IBM provides a power cord with a grounded attachment plug to use
with this IBM product. To avoid electrical shock, always use the power cord and
plug with a properly grounded outlet.
IBM power cords used in the United States and Canada are listed by Underwriter’s
Laboratories (UL) and certified by the Canadian Standards Association (CSA).
Appendix. Notices
67
For units intended to be operated at 115 volts: Use a UL-listed and CSA-certified
cord set consisting of a minimum 18 AWG, Type SVT or SJT, three-conductor cord,
a maximum of 15 feet in length and a parallel blade, grounding-type attachment
plug rated 15 amperes, 125 volts.
For units intended to be operated at 230 volts (U.S. use): Use a UL-listed and
CSA-certified cord set consisting of a minimum 18 AWG, Type SVT or SJT,
three-conductor cord, a maximum of 15 feet in length and a tandem blade,
grounding-type attachment plug rated 15 amperes, 250 volts.
For units intended to be operated at 230 volts (outside the U.S.): Use a cord set
with a grounding-type attachment plug. The cord set should have the appropriate
safety approvals for the country in which the equipment will be installed.
IBM power cords for a specific country or region are usually available only in that
country or region.
68
IBM power cord part
number
Used in these countries and regions
02K0546
China
13F9940
Australia, Fiji, Kiribati, Nauru, New Zealand, Papua New Guinea
13F9979
Afghanistan, Albania, Algeria, Andorra, Angola, Armenia, Austria,
Azerbaijan, Belarus, Belgium, Benin, Bosnia and Herzegovina,
Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape
Verde, Central African Republic, Chad, Comoros, Congo
(Democratic Republic of), Congo (Republic of), Cote D’Ivoire
(Ivory Coast), Croatia (Republic of), Czech Republic, Dahomey,
Djibouti, Egypt, Equatorial Guinea, Eritrea, Estonia, Ethiopia,
Finland, France, French Guyana, French Polynesia, Germany,
Greece, Guadeloupe, Guinea, Guinea Bissau, Hungary, Iceland,
Indonesia, Iran, Kazakhstan, Kyrgyzstan, Laos (People’s
Democratic Republic of), Latvia, Lebanon, Lithuania, Luxembourg,
Macedonia (former Yugoslav Republic of), Madagascar, Mali,
Martinique, Mauritania, Mauritius, Mayotte, Moldova (Republic of),
Monaco, Mongolia, Morocco, Mozambique, Netherlands, New
Caledonia, Niger, Norway, Poland, Portugal, Reunion, Romania,
Russian Federation, Rwanda, Sao Tome and Principe, Saudi
Arabia, Senegal, Serbia, Slovakia, Slovenia (Republic of),
Somalia, Spain, Suriname, Sweden, Syrian Arab Republic,
Tajikistan, Tahiti, Togo, Tunisia, Turkey, Turkmenistan, Ukraine,
Upper Volta, Uzbekistan, Vanuatu, Vietnam, Wallis and Futuna,
Yugoslavia (Federal Republic of), Zaire
13F9997
Denmark
14F0015
Bangladesh, Lesotho, Maceo, Maldives, Namibia, Nepal,
Pakistan, Samoa, South Africa, Sri Lanka, Swaziland, Uganda
14F0033
Abu Dhabi, Bahrain, Botswana, Brunei Darussalam, Channel
Islands, China (Hong Kong S.A.R.), Cyprus, Dominica, Gambia,
Ghana, Grenada, Iraq, Ireland, Jordan, Kenya, Kuwait, Liberia,
Malawi, Malaysia, Malta, Myanmar (Burma), Nigeria, Oman,
Polynesia, Qatar, Saint Kitts and Nevis, Saint Lucia, Saint Vincent
and the Grenadines, Seychelles, Sierra Leone, Singapore, Sudan,
Tanzania (United Republic of), Trinidad and Tobago, United Arab
Emirates (Dubai), United Kingdom, Yemen, Zambia, Zimbabwe
14F0051
Liechtenstein, Switzerland
14F0069
Chile, Italy, Libyan Arab Jamahiriya
xSeries 455: Option Installation Guide
IBM power cord part
number
Used in these countries and regions
14F0087
Israel
1838574
Antigua and Barbuda, Aruba, Bahamas, Barbados, Belize,
Bermuda, Bolivia, Brazil, Caicos Islands, Canada, Cayman
Islands, Costa Rica, Colombia, Cuba, Dominican Republic,
Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras,
Jamaica, Japan, Mexico, Micronesia (Federal States of),
Netherlands Antilles, Nicaragua, Panama, Peru, Philippines,
Taiwan, United States of America, Venezuela
24P6858
Korea (Democratic People’s Republic of), Korea (Republic of)
34G0232
Japan
36L8880
Argentina, Paraguay, Uruguay
49P2078
India
49P2110
Brazil
6952300
Antigua and Barbuda, Aruba, Bahamas, Barbados, Belize,
Bermuda, Bolivia, Caicos Islands, Canada, Cayman Islands,
Colombia, Costa Rica, Cuba, Dominican Republic, Ecuador, El
Salvador, Guam, Guatemala, Haiti, Honduras, Jamaica, Mexico,
Micronesia (Federal States of), Netherlands Antilles, Nicaragua,
Panama, Peru, Philippines, Saudi Arabia, Thailand, Taiwan,
United States of America, Venezuela
Appendix. Notices
69
70
xSeries 455: Option Installation Guide
Index
A
E
adapter
boot options 21
considerations 21
expansion slot locations 21
hot-plug devices 21
installing 21
ServeRAID 22
slot identification 19, 21
working with 19
attention notices 2
electronic emission Class A notice
expansion enclosure 52
expansion slots
location 19
type 19
F
fan
assemblies 37
fans
replacing and troubleshooting
replacing fans 1 and 2 37
replacing fans 3 and 4 38
FCC Class A notice 66
B
battery replacement
40
C
cable
management 43
cabling
ServeRAID adapter 22
caution statements 2
Class A electronic emission notice
components
location of 3
connector and port locations 59
connectors
adapter 19
cable 42
DIMM 26
external port 55
Gigabit Ethernet 60
microprocessor 30
port 42
RXE Expansion Port 60
RXE Management Port 60
SCSI 55
serial 61
Ultra320 SCSI 60
USB 55, 61
video 55, 61
cooling 13
cover
close 42
removing 16
D
danger statements 2
DIMMs
considerations 28
hot-swap 26
order of installation 26
© Copyright IBM Corp. 2003
66
37
G
Gigabit Ethernet connector
60
H
66
handling static-sensitive devices
hard disk drive
installing 24
hardware, major 3
hot-swap and hot-plug devices
DIMMs 26
power supplies 18
hot-swap power supply
installing 18
14
I
I/O connectors 59
important notices 2
installation
order, microprocessors 30
installing
adapters 21
battery 40
DIMMs 26
hard disk drive 24
hot-swap DIMMs 26
hot-swap power supply 18
memory module 26
microprocessors 30
options 13
PCI adapters 19
internal connectors
memory board 7
PCI-X 7
processor board 5
71
M
RXE-100
management cable 43
memory board
internal connectors 7
memory board illustration 26
memory switch card illustration 8
microprocessor
heat sink 30
installing 30
order of installation 30
power module 30
Web site 30
microprocessor board illustration 30
51, 54
S
serial connector 61
ServeRAID adapter, cabling
slots
See expansion slots
SMP
Expansion Port
connector 61
Standby mode 14
starting the server 14
statements and notices 2
system
reliability 13
N
notes 2
notes, important 64
notices
electronic emission 66
FCC, Class A 66
notices and statements 2
22
T
thermal material
heat sink 32
trademarks 64
turning off the server 15
turning on the server 14
O
option
installing 13
order of installation
memory modules 26
microprocessors 30
order of installation, microprocessors
U
31
V
P
PCI
bus identification 21
expansion slots 19
PCI-X
internal connectors 7
pointing device
connector 61
power cords 67
power supply
installing 18
operating requirements 18
power-control button shield 14
R
reliability, system 13
removing
memory-board assembly 30
microprocessor-board assembly 30
replacing
fans 1 and 2 37
fans 3 and 4 38
RXE
Remote Expansion Enclosure 51, 54
RXE Expansion Port connector 60
RXE Management Port connector 60
72
Ultra320 SCSI connector 60
United States electronic emission Class A notice
United States FCC Class A notice 66
USB connectors 61
xSeries 455: Option Installation Guide
video connector
61
W
Web site
compatible options 26, 31
DIMM specifications 28
microprocessor information 31
working inside server with power on
13
66
Part Number: 88P9198
