Conversational Interactions: Capturing Dialogue Dynamics
Arash Eshghi, Julian Hough, Matthew Purver (QMUL, London)
Ruth Kempson, Eleni Gregoromichelaki (KCL London)
1 Background
A common position in the philosophy of language has been the separation of the ‘intentionality’ of natural language (NL) and thought from the exercise of the capacities and epistemic resources that underpin
perception and action. From this point of view, an adequate theory of meaning is given in a formal theory
of ‘truth’ for NL (see e.g. Davidson (1967); Larson and Segal (1995); Montague (1970)). Such a theory
for NL provides a systematic account of the finite system of resources that enables the user of the theory
to understand every sentence of the language. However, when we turn to examine the employment of this
knowledge in realistic settings, i.e. in communication, it was believed that by stepping outside this methodology, we would inevitably be led to have “abandoned not only the ordinary notion of a language, but we
have erased the boundary between knowing a language and knowing our way around in the world generally.” (Davidson, 1986). As a response to this danger, until recently, a common methodology in Theoretical
Linguistics has been “to try to isolate coherent systems that are amenable to naturalistic inquiry and that
interact to yield some aspects of the full complexity. If we follow this course, we are led to the conjecture
that there is a generative procedure that “grinds out” linguistic expressions with their interface properties,
and performance systems that access these instructions and are used for interpreting and expressing one’s
thoughts” (Chomsky, 2000, 29, emphasis ours). This methodological principle that dictates strict separation
of the (modelling of) linguistic knowledge (competence) and the application of this knowledge in actual
situations of language use (performance) has been called into question recently by several researchers interested in modelling the capacities underpinning NL use. Contrary to the standard “autonomy of syntax”
hypothesis, grammatical models have recently begun to appear that reflect aspects of performance to varying
degrees (Hawkins, 2004; Phillips, 2003; Lombardo and Sturt, 2002; Ginzburg and Cooper, 2004; Kempson
et al., 2001; Cann et al., 2005b; Ginzburg, 2012). One type of motivation for this shift is that a number
of researchers have recently pointed out that a range of metacommunicative acts (in track 2: Clark (1996))
running in parallel with the communicative acts (in track 1) have to be characterised as part of the grammar
itself (e.g. Purver (2006); Fernández (2006); Ginzburg (2012); Gregoromichelaki et al. (forthcoming)). Another type of motivation, espoused by Dynamic Syntax (DS, Kempson et al. (2001); Cann et al. (2005b)), is
the demonstration that standard syntactic phenomena can be explained in a cognitively non-arbitrary fashion
by taking a fundamental feature of real-time processing - the concept of underspecification and incremental
goal-directed update - as the basis for the formulation of syntactic constraints.
In the domain of semantics and pragmatics, there has long been work emphasising the role of underspecification in the derivation of meaning and formulating notions of ‘procedural meaning’ that cannot be
accommodated under the truth-theoretic conceptions of semantics (see e.g. Sperber and Wilson (1995);
Levinson (2002)). Further inadequacies of traditional semantic theories have been further highlighted by
the pioneering work of Robin Cooper and colleagues who, along with DRT and related frameworks, have
drawn attention to the importance of formalising the contribution of an extended, structured notion of the
(multi-modal) context in supplying an adequate theory of interpretation for NLs. In this attempt to provide
an adequate theory of language understanding, attention has shifted away from a strict formulation of a truth
theory to the modelling of the structure of the information manipulated during perception and action as it
interfaces with linguistic processing (see e.g. Larsson (2011)). Inspired by work in Situation Semantics and
DRT the most recent formulation of this effort has been via the employment of Type Theory with Records
(TTR), a transparent representation format allowing the specification and seamless interaction of multiple
types of information. In recent years this has led to a significant expansion of the data deemed appropriate
for inclusion in a formal theory of interpretation, namely, the modelling of the use of language in interaction
and the demands that this places on appropriate semantic models (see e.g. Ginzburg and Cooper (2004);
Ginzburg (2012)).
In this paper, we set out the case for combining Dynamic Syntax (DS, Kempson et al., 2001; Cann et al.,
2005b) and the Type Theory with Records framework (TTR, Cooper, 2005) in a single model (DS-TTR)
in order to capture what is in our view the most fundamental aspect of linguistic knowledge, namely, its
exercise in interactive settings like conversational dialogue. DS is an action-based formalism that specifies
the ‘know-how’ that is employed in linguistic processing, in contrast to standard formalisms which codify
(specifically linguistic) propositional knowledge of rules. At the heart of the DS approach is the assumption
that grammatical constraints are all defined in terms of the progressive growth of representations of content,
with partial interpretations built step-by-step during interaction with context on a more or less word-byword basis. In consequence, DS is well-placed to provide the basis for a fine-grained integrational model
of language use that incorporates various aspects of the interface with perception and action in a single
representation. The data we present below show that such a model is required to account for the syntactic
properties of various phenomena that arise as a result of language use in interaction, instead of characterising them as “dysfluencies” or “performance phenomena”, hence outside the remit of core grammar or
truth-theoretic characterisations. The representations required for the modelling of such phenomena can
be provided in a straightforward manner by the TTR framework which allows for the fine-grained incrementality appropriate for showing how such representations can be progressively established and which is
at the heart of what DS is committed to capturing. The basis for this is the recursive nature of the TTR
records and record type format through its notion of subtyping. This allows the specification of underspecified objects, through partially specified types, which can be progressively specified/instantiated as more
information becomes available. As a result, the formulation of highly structured models of context, where
uniform representations of multiple types of information can be supplied and their interaction modelled,
becomes achievable (see e.g. Larsson, 2011). In addition, TTR employs a general type-theoretic apparatus
with functions and function types so that standard compositional lambda calculus techniques are available
for defining interpretations, thus capturing the systematicity and productivity of linguistic semantic knowledge. When combined with a grammar formalism in which “syntax” itself is defined as driving incremental
growth of interpretation, strict word-by-word incrementality of semantic content representations becomes
definable, enabling the maximum amount of semantic information to be extracted from any partial utterance and represented as a record type to which fields are added incrementally as more words are processed
in turn. Furthermore, inference, as one of a range of operations, is definable over these sub-propositional
record types, so that TTR is particularly well suited for representing how partial semantic information is
step-wise accumulated and exploited. And because types can be treated as objects in their own right, it also
becomes possible to integrate the reification and manipulation of both contents and grammatical resources
for metarepresentational/metalinguistic purposes.
In sum, as we will demonstrate in what follows, the combination of these two components, DS and TTR,
opens up the means of characterising phenomena that go far beyond the data expressible within standard
syntactic and semantic theories. We also show that such phenomena cannot be handled without radically
2
modifying the competence-performance distinction as standardly drawn. The more orthodox view, as we
will show, far from being a harmless abstraction that will eventually seamlessly integrate with a unified
explanation of the capacities that underpin language use, turns out to have provided a distorted view of the
NL phenomenon, resulting in a misleading formulation of the nature of knowledge required for understanding and production in realistic settings (for philosophical arguments supporting this view see also Millikan
(2004); McDowell (1998)).
2 The scope of grammar
2.1
Linguistic knowledge: the standard view and the view from the DS-TTR perspective
Standardly, the formulation of grammars abstracts away from use as it is assumed that use of language is
an operation that must have at its core propositional knowledge of an independently specifiable syntactic
theory and a theory of meaning. Syntax is confined to the licensing of sentence-strings and so delimiting
the set of well-formed sentences of the language; and semantics is then defined as the application to that
set of structured strings of a truth theory yielding propositions as denotations, this being the interface point
at which the contribution of grammar stops and pragmatics takes over. As a consequence of this stance,
classical truth-based semantic theories have enshrined Frege’s Context Principle which holds that one should
“never ask for the meaning of a word in isolation, but only in the context of a proposition” (see e.g. Davidson
(1967)). Under such a view, it is only as they play a role in whole sentences that individual words or
phrases can be viewed as meaningful. One of the reasons behind this stance is that the basic units of
linguistic understanding are taken to be propositional speech acts, as the minimal moves in conversation, and
steps of inference as expressed via either classical logical calculi or inductive generalisations are invariably
modelled as involving propositions as premises and conclusions. Since most standard pragmatic models take
such inferences as the basis for explaining communication, via complex propositional reasoning regarding
propositional attitudes like speaker intentions, it is a requirement that the grammar delivers such objects as
input to further pragmatic processing. Given this standard view of grammar, as independent of language use,
even (psycholinguistic) models within the language-as-action tradition bifurcate the concept of ‘language’
as languageu (that is, language-in-use), to be distinguished from languages (that is, language structure)- see
e.g. Clark (1996).
In contrast, the procedural architecture of Dynamic Syntax (DS) that models “syntax” as “knowledgehow” incorporates into the grammar two features usually associated with parsers, namely, incrementality
and fine-grained context-dependence. These features are argued to constitute the explanatory basis for
many idiosyncrasies of NLs standardly taken to pose syntactic/morphosyntactic/semantic puzzles (see Cann
et al. (2005a); Kempson and Kiaer (2010), and papers in Kempson et al. (2011b), also Chatzikyriakidis and
Kempson (2011)). This revision of what kind of knowledge a ‘grammar’ encapsulates is appropriate for
combining it with some of the foundational assumptions that underlie the employment of TTR by Cooper
and colleagues, namely, the provision of an integrated architecture that handles the integration of perception
and action in language use. As standard in TTR, the semantic contribution of utterances can be taken as
operations on fine-grained structured representations of contexts but, extending its expressivity, the incorporation of incrementality within the grammar formalism is justified by the application of the grammar-defined
principles to a much broader remit of data than is possible in conventional grammars, in particular to include
the rich set of data displayed in conversational exchanges.
2.2
Incrementality, radical context-dependence and dialogue phenomena
2.2.1 The (non-)autonomy of syntax
In conversation, evidence for incrementality is provided by the fact that, as can be seen in (1), dialogue
utterances are fragmentary and subsentential, yet, intelligible actions can be performed all the same in the
context of the ongoing interaction with interlocutors and the physical environment:
3
(1)
A:
B:
C:
B:
D:
B:
A:
Context: Friends of the Earth club meeting
So what is that? Is that er... booklet or something?
It’s a [[book]]
[[Book]]
(Answer/Acknowledgement/Completion)
Just ... [[talking about al you know alternative]]
(Continuation)
[[ On erm... renewable yeah]]
(Extension)
energy really I think... (Completion)
Yeah
(Acknowledgment)
[BNC:D97]
Moreover, this interactivity is buttressed by the ability of the participants to manifest their progressive understanding as they “ground” each other’s (subsentential) contributions through back-channel contributions
such as yeah, mhm, etc (see e.g. Allen et al. (2001)). Moreover, the placing of items like inserts, repairs,
hesitation markers etc. far from being “errors (random or characteristic) in applying knowledge of language
in actual performance” (Chomsky, 1965, p. 3), follows systematic patterns that show subtle interaction with
grammatical principles at a sub-sentential level (Levelt, 1983; Clark and Fox Tree, 2002):
(2) well, . I mean this . uh Mallet said Mallet was uh said something about uh you know he felt it would
be a good thing if u:h . if Oscar went, (1.2.370)
This implies that dialogue phenomena like self-repair, interruptions, extensions, corrections etc. require modelling of the participants’ incremental understanding/production; and if, as we will show, particular NL grammars are required to provide the licensing of such constructions then such grammars
need to be equipped to deal with partial/non-fully-sentential constructs. Modular approaches to the grammar/pragmatics interface deny that this is an appropriate strategy. Instead they propose that the grammar
delivers underspecified propositional representations as input to pragmatic processes that achieve full interpretations and discourse integration (see e.g. Schlangen (2003), following an SDRT model). However,
an essential feature of language use in dialogue is the observation that on-going interaction and feedback
shapes utterances and their contents (see e.g. Goodwin (1981), Clark (1996), among many others), hence it
is essential that the grammar does not have to licence whole propositional units for semantic and pragmatic
evaluation to take place. And this is the strategy DS adopts as it operates with partial constructs that are
fully licensed and integrated in the semantic representation immediately. This has the advantage that online syntactic processing can be taken to be implicated in the licensing of fragmentary utterances, even when
these are spread across interlocutors (split utterances), without having to consider such “fragments” as elliptical sentences (Merchant, 2004), or as contributing pragmatically derived propositional contents (Stainton,
2006) or non well-formed in any respect. And this is essential for a realistic account of dialogue as people
can seamlessly take over from each other in conversation. They may seek to finish what someone else has
in mind to say as in (3), but equally, they may interrupt to alter what someone else has proffered, taking the
conversation in a different or even contrary direction, as in (4) and (5) :
(3) Gardener: I shall need the mattock.
Home-owner: The...
Gardener: mattock. For breaking up clods of earth.[BNC]
(4) (A mother, B son)
A: This afternoon first you’ll do your homework, then wash the dishes and then
B: you’ll give me £10?
(5) (A and B arguing:)
A: In fact what this shows is
B: that you are an idiot
4
Furthermore, this is a form of exchange that children can join in from a very early age to complete someone
else’s utterance, as witness the English nursery game Old MacDonald had a Farm:
(6) A: Old MacDonald had a farm. E-I-E-I-O. And on that farm he had a
B: cow.
A: And the cow goes
B: Moo.
And carers may trade on this ability, e.g. in talking in a nursery class, again from a very early age:
(7) (teacher to first of a set of children sitting in a circle)
A: Your name is ...
B: Mary
A: (turning to next child) And your name is...
C: Susie
and so on
A respondent, as in (6) and (7) the child, may just complete a frame set out by the dialogue initiator.
However, commonly, participants may, in some sense, “just keep going” from where their interlocutor had
got to, contributing the next little bit:
(8) A: We’re going to London
B: to see Granny?
A: if we have time.
Such exchanges can indeed be indefinitely extended, so that each contributor may only be contributing some
intermediate add-on without either of them knowing in advance the end-point of the exchange:
(9) (a) A: Robin’s arriving today
(b) B: from?
(c) A: Sweden
(d) B: with Elisabet?
(e) A: and a dog, a puppy and very bouncy
(f) B: but Robin’s allergic
(g) A: to dogs? but it’s a Dalmatian.
(h) B: and so?
(j) A: it won’t be a problem. No hairs.
The upshot of this is that it is often hard to tell where one sentence begins and the next starts. Does the
exchange in (9) consist just of one sentence or perhaps two - i.e. all that precedes “problem” plus the final
“No hairs”? Or does it consist of one sentence for each fragment as individually uttered?
Faced with this kind of dilemma, it might be tempting to dismiss the phenomenon altogether as a dysfluency of conversational dialogue, but the problem is not merely one of incompleteness in characterisation of
a single sub-area of language use. The form of these “fragments” is not random but, to the contrary, follows
the licensing conditions specified by the NL grammar – syntactic dependencies of the most fundamental sort
hold between the subsentential parts:
(10) A: I’m afraid I burned the buns.
B: Did you burn
A: myself? No, fortunately not.
5
(11) A: D’you know whether every waitress handed in
B: her taxforms? A: or even any payslips?
Given that the standard motivation behind the sententialist/propositionalist bias in syntax and semantics is
the assumption that only sentences/propositions can be used in the performance of speech acts, it might seem
but a minor extension to include such phenomena under some propositional/sentential reconstruction with
additional encoded or inferred speech act specifications. This strategy has been applied in many cases of
ellipsis where either an underlying sentence is constructed and in greater part deleted (e.g. Merchant (2004))
or in recent models of dialogue where a speech act specification and a propositional content are constructed
by operations on context (see e.g. Ginzburg (2012)). However, the phenomenon is much more general than
such analyses suggest. People can take over from one another at any arbitrary point in an exchange, setting
up the anticipation of possible dependencies to be fulfilled. We have already seen that it can be between a
preposition and its head, (9b-c), between a head and its complement (9f-g), between one conjunct and the
next (9d-j) etc. (10) involves a split between a reflexive pronoun and its presented antecedent. (11) involves
a split between a quantifying expression and some pronoun that it binds, and then across a disjunction
and another shift of speakers to a negative polarity item dependent on that initially presented quantifier. (3)
involves a split between determiner and noun. The upshot is that switch of participant roles is possible across
ALL syntactic dependencies (Purver et al., 2009): participants in a dialogue seem, in some sense, to be able
to speak with a single voice, even while yet directing the conversation as they individually wish. Unless
the grammar reflects the possibility of such dependencies to be set and fulfilled across participants (or, in
fact as we will see below (12)-(17) in interaction with the physical environment) not a single grammatical
phenomenon will have successfully been provided with a complete, uniform characterisation.
On the other hand, any attempt to reflect this type of context-dependence, and the attendant sense of
continuity it gives rise to, through grammar-internal specifications will have to involve constraints on fragment construal that go well beyond what is made available in terms of denotational content: indeed such
constraints will have to include the full range of syntactic and morphosyntactic dependencies. As Ginzburg
and Cooper (2004); Ginzburg (2012) observe (following similar observations in Morgan (1973, 1975)), in
all case-sensitive languages there is sensitivity of “fragment” expressions to some notion of recoverable
antecedent syntactic environment, so that invariably the fragment uttered has to match the morphosyntactic
requirements set by the expression to which it is providing an extension. For all such cases, a semantic/pragmatic characterisation on its own will not be sufficient, and syntactic licensing is essential. However
the puzzle is not yet complete. As has already been demonstrated by Stainton (2006), speakers can perform
genuine speech acts via use of subsentential constituents without needing first to recover complete syntactic sentences or sentence contents. Nevertheless, contrary to Stainton’s assumptions, such “fragments” too
need to respect the morphosyntactic requirements of the relevant NL, a fact indicating the employment of
the grammar at a subsentential level, even when derivation of the speech act content is achieved purely
pragmatically:
(12) Context: A and B enter a room and see a woman lying on the floor:
A to B: Schnell, den Arzt/*der Arzt
[German]
“Quick, the doctorACC /*the doctorN OM ”
But these data are also problematic for any account that analyses such phenomena in purely linguistic terms
by defining rules that make reference to (covert) antecedent utterances with some specified NL syntactic
form (see e.g. Ginzburg (2012)). For, like anaphora and standard elliptical phenomena, most dialogue
phenomena, clarifications, extensions, corrections etc. can occur without linguistic antecedents:
(13) A is contemplating the space under the mirror while re-arranging the furniture and B brings her a
chair:
6
tin karekla tis mamas?/*i karekla tis mamas? Ise treli?
[Greek]
the chair of mum’sACC /*the chairN OM of mum’s. Are you crazy?
(14) A sees Bill entering the building and turing to C exclaims:
A: o Giannis(?)/*ton Gianni(?)
[Greek]
the JohnN OM /*the JohnACC
[clarification]
[assertion(/clarification)]
(15) A is looking for her keys and B points to a desk:
B: your desk? I’ve looked there.
[clarification]
(16) A is handing a brush to B:
A: for painting the wall?
(17) A is pointing to Bill:
B: No, his sister
[clarification]
[correction]
Hence accounts that rely on rules that require reference to some salient linguistic form of utterance antecedent are not general enough for the phenomena at hand. What is needed, in our view, are representations
of both (linguistic) content and context in which multiple (multi-modal) sources of information are all expressed in a single format. This will enable the modelling of linguistic resources that can make reference
to and modify such representations in an incremental manner. On the DS-TTR account, as we shall see,
morphosyntactic particularities, for example, do not warrant distinct levels of explanation in the update
mechanisms needed for fragment construal, for morphological information, like all other aspects of morphosyntactic and syntactic specification is defined in terms of the constraints the morphological form imposes on appropriate integration into a structured content representation, effecting a specified update. Seen
from this perspective, these dialogue data, far from being set aside as beyond the reach of grammar, in fact
demonstrate how the grammar needs to be equipped with fine-grained licensing mechanisms that operate at
the subsentential level with sensitivity to the time linear progress of interaction between the agents and the
evolving context in which their interaction takes place.
2.2.2 Pragmatic/semantic “competence” and radical context-dependence in dialogue
These data are significant for pragmatics also. There has been an assumption held by almost all those
working in pragmatics that the supposedly isolatable sentence meaning made available by the grammar
should feed into a theory of performance that explains how, relative to context, such “sentences” can be
uttered on the presumption that the audience will come to understand the propositional content which the
speaker has (or could have) in mind. However, participants may well understand what each other is saying
and switch roles well before any such propositional content could be interpreted to constitute the object
relative to which some agent or other could hold a propositional attitude. These switches take place, recall, at any arbitrary point in the constructive process. Intentions of the parties to the dialogue may only
emerge/develop during the exchange (Mills and Gregoromichelaki, 2010), and so cannot be intrinsic to all
processes of communicative understanding, as is so generally assumed, for example, in the only existing
formal model of completions, that of Poesio and Rieser (2010):
(18) A: Oh. They don’t mean us to be friends, you see. So if we want to be . . .
B: which we do
A: then we must keep it a secret. [natural data]
(19) Daughter: Oh here dad, a good way to get those corners out
Dad: is to stick yer finger inside.
Daughter: well, that’s one way (Lerner 1991)
7
(20) M: It’s generated with a handle and
J: Wound round?
[BNC]
M: Yes, wind them round and this should, should generate a charge
There is negotiation here, as to what is the best way to continue a partial structure as proffered by either
party, with intentions of either party with respect to that content, possibly only emerging as a result of the
negotiation. Utterances may also be multi-functional, so that more than one speech act can be expressed in
one and the same utterance:
(21) A: Are you left or
B: Right-handed
(22) Lawyer: Do you wish your wife to witness your signature, one of your children, or..?
Customer: Joe.
So there is no single proposition or indeed speech act that the individual speaker/hearer may have carried
out.
The commitment to the recovery of propositions or propositional speech act contents as a precondition
for either successful linguistic processing or effective interaction (Grosz and Sidner (1986)) has therefore
to be modified; and so too does the presumption of there having to be explicit plans/intentions on the part
of the speaker (Poesio and Rieser, 2010; Carberry, 1990). To the contrary, these data provide evidence that
the grammar itself and its mechanisms can be exploited by all participants in a conversation as the means
to progress that interaction at a subsentential level before any such speech-act or propositional content becomes available. In fact, in many cases, the participants can simply rely on the setting up of grammatical
dependencies and the parallel in both speaker and hearer inducement to fulfil them in order to perform possibly composite speech acts (grammar-induced speech acts, Gregoromichelaki et al. (forthcoming)) without
even requiring steps of inference or recovery of propositions (see also (7) and (11) above):
(23) Jim: The Holy Spirit is one who ...gives us?
Unknown: Strength.
Jim: Strength. Yes, indeed. .... The Holy Spirit is one who gives us? .....
Unknown: Comfort. [BNC HDD: 277-282]
(24) George: Cos they [unclear] they used to come in here for water and bunkers you see.
Anon 1: Water and?
George: Bunkers, coal, they all coal furnace you see, ... [BNC, H5H:59-61]
(25) A: And you’re leaving at ...
B: 3.00 o’clock
(26) Therapist: What kind of work do you do?
Mother: on food service
Therapist: At ...
Mother: uh post office cafeteria downtown main point office on Redwood
Therapist: Okay [Jones & Beach 1995]
Such cases show, in our view, that “fragmentary” interaction in dialogue should be modelled as such, i.e.
with the grammar defined to provide mechanisms that allow the participants to incrementally update the
conversational record without necessarily having to derive or metarepresent propositional speech act contents or contents of the propositional attitudes of the other participants as the sine qua non of successful
8
communication. In the exercise of their grammatical knowledge in interaction, participants justify Wittgenstein’s view that “understanding is knowing how to go on”. Metacommunicative interaction is achieved
implicitly in such cases via the grammatical mechanisms themselves without prior explicit commitment to
deterministic speech-act goals, even though participants can reflect and reify such interactions in explicit
propositional terms (see e.g. Purver et al. (2010)), should they so choose. The fact that such reifications
are possible, even though it requires that the dialogue model should provide the resources for handling them
when they are explicit, does not imply that they operate in the background when participants engage in
(unconscious, sub-personal) practices that can be described from the outside in explicit propositional terms.
The level of explanation for explicit descriptions of actions and implicit practices is not the same. In parallel with Brandom’s (1994) conception of the logical vocabulary as the means which allows speakers to
describe the inferential practices that underlie their language use, conversational participants manifest their
ability to “make explicit” the practices afforded to them implicitly by subpersonal procedures when either
communication breaks down or when they need to verbalise/conceptualise the significance of their actions
(for a similar view account of practices at other higher levels of coordination see Piwek (2011)).
The problem standard syntactic theories have in dealing with dialogue data can be traced to the assumption
that it is sentential strings that constitute the output of the grammar, along with the attendant methodological
principle debarring any attribute of performance within the grammar-internal characterisation to be provided.
The semantic literature, on the other hand, focuses on the assumption that NL meaning can be modelled
through a Tarski-inspired truth theory for NL. Neo-Davidsonians (e.g. Larson and Segal, 1995) further
assume that knowledge of language consists in tacit propositional knowledge of the truth theory; this tacit
knowledge is what enables individuals to produce and interpret speech appropriately in interaction with
others with the same tacit knowledge. However, Davidson himself acknowledges that the individualistic
perspective on what this knowledge consists in is inadequate:
. . . there must be an interacting group for meaning –even propositional thought, I would say– to
emerge. Interaction of the needed sort demands that each individual perceives others as reacting
to the shared environment much as he does; only then can teaching take place and appropriate
expectations be aroused. (Davidson, 1994)
In this respect, Cooper and colleagues (see e.g. Ginzburg (2012) who employs Cooper-inspired TTR methods) have achieved the significant advance of defining an explicit semantic model that does not restrict
itself to the modelling of informational discourse but instead attempts to describe the fine-grained structure
of conversational exchanges that result in participant coordination (see e.g. Pickering and Garrod (2004))
and explores the ontologies required in order to define how speech events can cause changes in the mental
states of dialogue participants. But, following standard assumptions, syntax is defined independently and
in effect statically (however, see Ginzburg (2012, ch. 7)) which, in our view, prevents the modelling of the
fine-grained incrementality observable in the split-utterance and repair data, a lacuna which the DS-TTR
combination aims to repair. As we will see below, when embedded in the action-based incremental architecture provided by DS, the view of the semantic landscape changes. The instrumentalist Davidsonian stance
towards the content assigned to subsentential constituents, as subordinate to sentential contents, has to be
revised in that subsentential contributions provide the locus for as much and as significant (externalised)
“inference” and coordination among participants as any propositional contributions. And to explain the relation between a provided partial structure as context and an update that completes or extends it, the concept
of context has to be structural to a level of granularity matching that of syntax.
3 DS-TTR for dialogue modelling
In turning to the modelling of conversational dialogue, we will need concepts of incrementality applicable
to both parsing and generation. Milward (1991) sets out two key concepts of strong incremental interpretation and incremental representation. These concepts apply to semantic incrementality, largely. Strong
9
incremental interpretation is the ability to make available the maximal amount of information possible from
an unfinished utterance as it is being processed, particularly the semantic dependencies of the informational
content (e.g. a representation such as λ x.like′ (john′ , x) should be available after processing “John likes”).
Incremental representation, on the other hand, is defined as a representation being available for each substring of an utterance, but not necessarily including the dependencies between these substrings (e.g. having
a representation such as john′ attributed to “John” and λ y. λ x.like′ (y, x) attributed to “likes” after processing “John likes”). But there are three further concepts pertaining to incrementality to bear in mind. In
order to express the incrementality intrinsic to syntax, we need to stipulate that these abilities exhibit word
by word incrementality, whereby all information affiliated with a word must be taken to update the structure
to which it applies as input immediately, whether structural, conceptual, or, if applicable, semantic. As we
shall see, it is this third notion which lies at the core of Dynamic Syntax, in which syntax is defined in
terms of such structural update. Furthermore, in order to model compound contributions as described in the
examples given thus far, it also becomes evident that the representations produced by parsing and generation should be interchangable, as will be discussed in section 4.1. Finally, the notion of an incrementally
constructed procedural context becomes important for modelling self-repair, a quality of the DS framework
described in section 3.2 and exploited in section 4.2.
3.1
Combining Dynamic Syntax and TTR
Dynamic Syntax is a parsing-directed grammar formalism,
Dynamic Syntax (DS, Kempson et al., 2001) is a grammar framework which models the word-by-word
incremental processing of linguistic input. Unlike many other formalisms, DS models the incremental building up of interpretations without presupposing or indeed recognising an independent level of syntactic processing. Thus, the output for any given string of words is a purely semantic tree representing its predicateargument structure; words and grammatical rules correspond to actions which incrementally license the
construction of such representations in tree format, employing a modal logic for tree description which provides operators able to introduce constraints on the further development of such trees (LOFT, Blackburn
and Meyer-Viol, 1994). The DS lexicon consists of lexical actions keyed to words, and also a set of globally applicable computational actions, both of which constitute packages of monotonic update operations
on semantic trees, and take the form of IF-THEN action-like rules which when applied yield semantically
transparent structures. For example, the lexical action corresponding to the word john has the preconditions
and update operations in example (27): if the pointer object (♦), which indicates the node being checked
on the tree, is currently positioned at a node that satisfies the properties of the precondition, (e.g. has the
requirement type ?T y(e)), then all the actions in the post-condition can be completed, these being simple
LOFT monotonic tree operations.
(27)
IF
THEN
ELSE
?T y(e)
put(T
y(e))
put( x : john )
abort
The trees upon which actions operate represent terms in the typed lambda calculus, with mother-daughter
node relations corresponding to semantic predicate-argument structure (see (1) below). In DS-TTR, the
nodes of such trees are annotated with a node type (e.g. T y(e)) and semantic formulae in the form of TTR
record types Cooper (2005). In the recent move to incorporate TTR into DS (Purver
et al., 2010, 2011),
following Cooper (2005), TTR record types consist of fields of the form l : T , containing a unique
label l in the record type and a type T which represents the node type of the DS tree at which the formula is
situated if it is a simple type, or else the final node type (e.g.
type t for a predicate at a T y(es → t) node).
Fields can be manifest (i.e. have a singleton type such as l=a : T ). Within record types there can be
10
dependent fields such as those whose singleton type is a predicate as in p=like(x,y) : t , where x and y
are labels in fields preceding it (i.e. are higher up in the graphical representation). Functions from record
type to record type in the variant of TTR we use here employ paths, and are of the form λr : l1 : T 1
l2=r.l1 : T 1 , an example being the formula at the type T y(es → t) node in the trees in (1) below, giving
DS-TTR the required functional application capability: functor node functions are applied to their sister
argument node’s formula, with the resulting β-reduced record type added to their mother1 .
We further adopt an event-based semantics along Davidsonian lines (Davidson, 1980). As shown below,
we include an event node (of type es ) in the representation: this allows tense and aspect to be expressed2 ,
allowing incremental modification to the the record type on the T y(es ) node during parsing and generation
after its initial placement in the initial axiom tree. The inclusion of an event node also permits a straightforward analysis of optional adjuncts as extensions of an existing semantic representation (see below section
4.1 and Appendix 1 for examples).
“John”
7−→
event : es
x=john : e
event : es








“arrived”
7−→
:
:
:
:
:
:
es
es
e
t
t
t








?T y(es → t)

event=e1
Ref T ime
x=john
p=arrive(event,x)
p1=Ref T ime<now
p2=event⊆Ref T ime
x=john : e
event=e1
 Ref T ime

 p1=Ref T ime<now
p2=event⊆Ref T ime
♦, ?T y(es → (e → t))
:
:
:
:

es
 λr1 : event :
es 
event=r1.event

t   x=john
t
p=arrive(event,x)
x=john
es

: es
: e 
: t
λr: x : e
 λr1 : event :
: e
event=r1.event
 x=r.x
p=arrive(event,x)
Figure 1: Parsing “John arrived”
DS-TTR parsing intersperses the testing and application of both lexical actions triggered by input words
and the execution of permissible sequences of computational actions, with their updates monotonically constructing the tree. Central to this perspective is the concept of structural underspecification with subsequent
update, a stance which is reflected by including among the tree-transitions to be induced, one which yields a
tree relation with no more characterisation than h↑∗ iT n(a); this dictates that the node so constructed should
be dominated by some node in a definable tree-domain later to be updated when a suitable fixed tree-node
relation becomes available. This approach, familiar in parsing implementations of long-distance dependency
(see ?, also Kaplan and Zaenen (1989) and the concept of functional uncertainty of LFG), is incorporated
into DS as a core structural transition of an unfixed node creation and subsequent merge with the matrix
tree, and is taken as the basis for a broad range of long-distance and other non-contiguous dependencies. All
such cases are made subject to resolution at some future point through the imposition of a requirement for a
fixed tree-node value ?∃xT n(x).
1
For functional application and Link-Evaluation (see Cann et al. (2005b, ch. 3), but also Appendix 1 for example DS-TTR
derivations involving Link-Evaluation), which require the intersection/concatenation of two record types, relabelling is carried out
when necessary to avoid leaving incorrect variable names in the record types in the manner of Cooper (2005) and Fernández (2006).
2
see Cann (2011) for the detailed Reichenbachian treatment of tense/aspect used here.
11
es

: es
: e 
: t
Seen in these terms, successful parses are sequences of action applications that lead to a tree which is
complete (i.e. has no outstanding requirements on any node, and has type T y(t) at its root node as in
(1)). Incomplete partial structures are maintained in the parse state on a word-by-word basis, giving DS its
incrementality, and with the DS-TTR composite it is now possible to make available a record type which
gives the maximal amount of semantic information available for partial as well as complete trees (see the
left tree in (1) above) by a simple tree compiling operation, which is schematically:
1. Decorate all terminal argument nodes (the left side nodes) lacking instantiated formulae with record
types containing a variable of the appropriate type.
2. Carry out functional application from the record types of compiled functor nodes to the record types of
their sister argument nodes in a bottom-up fashion, compiling a β-reduced record type at their mother
node. Relabel record type variables where necessary. For argument nodes with no sister functor nodes,
simply merge them (return the meet type (Cooper, 2005)) with the current root node’s record type.
This TTR compilation efficiently solves the problem of the previously implicit strong incremental semantic
representation in DS, as now maximal record types become available as each word is processed.
Finally, in DS, as well as matrix trees, (island) structures can be induced as locally independent simple
predicate-argument structures, so-called linked trees, which are twinned as an asymmetric non-structural
tree-dependency ensured through a sharing of formula terms at nodes in the two trees in question, incrementally imposed in the transition from development of one partial tree to the other (see Kempson et al., 2001).
Canonical cases are relative clause adjuncts (Cann et al., 2005b; Gregoromichelaki, 2006), but equally, the
LINK transition applies to a broad range of phenomena such as adjuncts and hanging-topic constructions.
Within DS-TTR, LINKs are elegantly evaluated as the intersection/concatenation (the meet operation, as in
Cooper (2005)) of the record-type accumulated at the top of a LINKed tree and the matrix tree’s root node
record type (see Appendix 1 for example derivations).
The advantage of the DS-TTR composite system is the meta-theoretical clarity it affords to the growth
process defined by the modular LOFT-TTR architecture. In particular, the LOFT underpinnings to the
mechanisms of tree-growth mean that the DS insight that core syntactic restrictions emerge as immediate
consequences of the LOFT-defined tree-growth dynamics is preserved without modification (See Cann et al.
(2005b), Cann et al. (2007); Kempson and Kiaer (2010); Kempson et al. (2011a); Chatzikyriakidis and
Kempson (2011)).
3.2
DS-TTR procedural context as a graph
Aside from the strong incremental interpretation that DS-TTR representations afford, in line with the stipulations for adequate models of dialogue, our model provides the incremental access to procedural context
required for modelling the phenomena reviewed above. For DS, this context is taken as including not only
the end product of parsing or generating an utterance (the semantic tree and corresponding string), but also
information about the dynamics of the parsing process itself – the lexical and computational action sequence
used to build the tree. As defined in Purver and Kempson (2004b); Purver et al. (2006), one possible model
for such a context can be expressed in terms of triples hT, W, Ai of a tree T , a word-sequence W and the
sequence of actions A, both lexical and computational, that are employed to construct the trees. In parsing,
the parser state P at any point is characterised as a set of these triples; in generation, the generator state G
consists of a goal tree TG and a set of possible parser states paired with their hypothesised partial strings S.
As will be addressed below, the definition of a parser/generator state in terms of parse states ensures equal
access to context for parsing and generation, as required, with each able to use a full representation of the
dynamic linguistic context produced so far.
A further modification provides the required incremental representation as stipulated above. This modification requires changing the view of linguistic context as centring around a set of essentially unrelated action
12
sequences; an alternative is to characterise DS procedural context as a Directed Acyclic Graph (DAG). Sato
(2011) shows how a DAG with DS actions for edges and (partial) trees for nodes allows a compact model
of the dynamic parsing process; and Purver et al. (2011) extend this to integrate it with a word hypothesis
graph (or “word lattice”) as obtained from a standard speech recogniser.
‘john’
W0
LEX=‘john’
predict
complete
thin
invisible
invisible
invisible
invisible
anticip
W1
LEX=‘arrives’
invisible
invisible
intro
invisible
invisible
invisible
LEX=‘john’
invisible
LEX=’arrives’
complete
*adjunct
invisible
invisible
invisible
LEX=‘john’
thin
invisible
complete
invisible
anticip
invisible
invisible
LEX=‘arrives’
invisible
thin
invisible
LEX=‘arrives’
invisible
Figure 2: DS context as DAG, consisting of parse DAG (circular nodes=trees, solid edges=lexical(bold)
and computational actions) groundedIn the corresponding word DAG (rectangular nodes=tree sets, dotted
edges=word hypotheses) with word hypothesis ‘john’ spanning tree sets W0 and W1.
The graphical characterization results in a model of context as shown in figure 2, a hierarchical model with
DAGs at two levels. At the action level, the parse graph DAG (shown in the lower half of figure 2 with solid
edges and circular nodes) contains detailed information about the actions (both lexical and computational)
used in the parsing or generation process: edges corresponding to these actions are connected to nodes
representing the partial trees built by them, and a path through the DAG corresponds to the action sequence
for any given tree. At the word level, the word hypothesis DAG (shown at the top of figure 2 with dotted
edges and rectangular nodes) connects the words to these action sequences: edges in this DAG correspond
to words, and nodes correspond to sets of parse DAG nodes (and therefore sets of hypothesized trees).
For any partial tree, the context (the words, actions and preceding partial trees involved in producing it)
is now available from the paths back to the root in the word and parse DAGs. Moreover, the sets of trees
and actions associated with any word or word subsequence are now directly available as that part of the
parse DAG spanned by the required word DAG edges. This, of course, means that the contribution of
any word or phrase can be directly obtained, fulfilling the criterion of incremental representation. It also
provides a compact and efficient representation for multiple competing hypotheses, compatible with DAG
representations commonly used in interactive systems, including the incremental dialogue system Jindigo
(Skantze and Hjalmarsson, 2010), a move that has been taken by Purver et al. (2011). Importantly, as
described below, the DS definition of generation in terms of parsing still means this model will be equally
available to both, and used in the same way by both modules. The criteria of interchangeability and equal
incremental access to context, essential for the modelling of covering compound contributions and selfrepairs (see below), are therefore satisfied.
3.3
DS-TTR Generation as Parsing
In turning to the DS-TTR account of generation, a number of preliminaries have first to be addressed.
First, as the split utterance data demonstrate, incremental behaviour needs to include allowing confirmation
behaviour as in (23), (20), continuations in utterances shared between the user and system as in (3), (4),
(7)-(23), but also user interruptions without discarding the semantic content built up so far to provide for
realistic clarification and self-repair capability such as in (2). And as these data have illustrated, individual
fragments may display more than one such attribute. As we have stipulated above, the three requirements
13
of exhibiting strong incremental interpretation, incremental representation on a word-by-word basis and
continual access to procedural context extends to the generation module, which must implement all information made available by selected expressions without delay. There is however also a fourth requirement
in generation: the generation of incremental dialogue phenomena of course requires incremental parsers
and dialogue management modules which can reason with the semantic representations it produces, so an
extrinsic necessity on the module is that it should have the property of representational interchangeability
with other modules. DS-TTR can meet these criteria, which conventional grammar frameworks, as we have
already seen, struggle to capture elegantly, particularly for examples such as (10) and (11).
Amongst recent developments in incremental generation, Guhe (2007) models incrementality in the conceptualization phase, developing a module which generates semantic input to the formulator incrementally.
While syntactic formulation is not the focus, the interface between the incremental conceptualizer and the
formulator is clearly defined: the conceptualizer’s incremental modification to pre-verbal messages characterizes downstream tactical generation and the modification of the messages with correction increments
causes self-repair surface forms to be realized. Buß and Schlangen (2011) recently introduced dialogue
management strategies in the same spirit and albeit less psychologically motivated, Skantze and Hjalmarsson (2010) provide a similar approach to Guhe’s conceptual change model in their implementation of incremental speech generation in a dialogue system. Generation input is defined in terms of canned-text speech
plans sent from the dialogue manager that are divided up into word-length speech units. The procedure
consists of the incremental vocalization of each unit, coupled with self-monitoring the plan in the sense of
Levelt (1989). As speech plans may change dynamically during interaction with a user, upon detection of
difference by the monitor through a simple string-based comparison of the incoming plan with the current
one, both covert and overt self-repairs can be generated, depending on the number of units in the plan realized at the point of detection. These approaches thus variously utilise a system of partial inputs to generation
components to reduce complexity burdens and top-down revision of string-based speech plans or syntactic
structures, however there is not a clear description of how an incremental semantic representation can be
tightly coupled with surface realisation to facilitate fine-grained build up of meaning during generation,
which is a prerequisite for generating interesting incremental dialogue phenomena. Skantze and Hjalmarsson’s model is a step towards coupling word-by-word generation and self-monitoring, however the lack of
incremental semantics and domain-general grammar makes scalability and integration with a parsing module difficult. Relating semantics to surface form via canned text restricts the system’s possible utterances
hugely even in one domain. And in an account such as this, based on full sentence characterisation with late
deletion, there is no semantic word-by-word incrementality to the form of explanation, so dynamic ongoing
alteration is precluded in principle.
In comparison to these, the DS system addresses the incrementality problem head on by incorporating
within the grammar formalism at least some of the necessary incrementality requirements for dialogue. And
this is extended to generation in a very direct way as Purver and Kempson (2004a) demonstrate. An incremental DS model of surface realisation can be neatly defined in terms of the DS parsing process and a
subsumption check against a goal tree. The DS generation process is word-by-word incremental with maximal tree representations continually available, and it effectively combines lexical selection and linearisation
into a single action due to the word-by-word iteration through the lexicon. Also, while no formal model of
self-repair has hitherto been proposed in DS (but see below section 4.2), self-monitoring is inherently part of
the generation process, as each word generated is parsed. However, while the Purver and Kempson (2004a)
DS generation model is incremental, it does not meet the criterion of strict incremental interpretation as
stipulated above, as maximal information about the dependencies between the semantic formulae in the tree
may not be computed until the tree is complete - this is an issue addressed in the developments reported here.
Also, in terms of logical input forms to generation, the goal tree needs to be constructed from the grammar’s
actions, so any dialogue management module must have full knowledge of the DS parsing mechanism and
lexicon, and so interchangeability of representation becomes difficult. For this reason several adjustments
14
are suggested below, given the new DS-TTR framework.
3.3.1 TTR goal concepts and subtype checking for lexicalisation
One straightforward modification to the DS generation model enabling representational interchangeability
with other modules is the replacement of the previously defined goal tree with a TTR goal concept, which
takes the form of a record type such as:


event=e1
: es
 Ref T ime=today : es 


 p1=Ref T imeevent : t 


: e 
(28) 
 x1=Sweden

 p2=f rom(event,x1) : t 


 x=robin
: e 
p=arrive(event,x)
: t
Importantly, the goal concept may be partial, in that the dialogue manager may further specify it, and it need
not correspond to a complete sentence, which is important for incremental dialogue management strategies
(Guhe, 2007; Buß and Schlangen, 2011), as it is needed for such examples as (1)-(3). This move also
means the dialogue manager may input goal concepts directly to the generator, and no considerations of
the requirements of the DS grammar are needed, in contrast to Purver and Kempson (2004a)’s approach.
The tree subsumption check in the original DS generation model can now be characterized again as a TTR
subtype relation check between the goal tree and the trees in the parse state’s compiled TTR formulae:
(29) Subtype relation check
For
record
types
p1
and
p2,
p1
⊑
p2
holds
just
in
case
for
each
field
l
:
T
2
in p2 there is a field
l : T 1 in p1 such that T 1 ⊑ T 2, that is to say just in case any object of type T 1 is also of type
T 2.3 The type inclusion relation is reflexive and transitive. (adapted from Fernández (2006, p.96))
An example of a successful generation path is shown in Figure 34 , where the incremental generation of
“john arrives” succeeds as the successful lexical action applications at transitions 1 7→ 2 and 3 7→ 4 are
interspersed with applicable computational action sequences at transitions 0 7→ 1 and 2 7→ 3 , at each stage
passing the subtype relation check with the goal (i.e. the goal is a subtype of the top node’s compiled record
type), until arriving at a tree that type matches the assigned goal concept in 4 in the rich TTR sense of type.
In implementational terms, there will in fact be multiple generation paths in the generation state, including
incomplete and abandoned paths, which can be incoporated into the DS notion of context as a DAG.
Another advantage of working with TTR record types rather than trees during generation is that selecting
relevant lexical actions from the lexicon can take place before generation begins through comparing the
semantic formulae of the actions to the goal concept. Subtype checking makes it possible to reduce the
computational complexity of lexical search through a pre-verbal lexical action selection. Informally, a
sublexicon SubLex can be created when the goal concept GoalT T R is inputted to the generator by the
following process:
(30) Pre-verbal lexicalisation
For all lexical actions Li in the lexicon, add to SubLex if GoalT T R is a subtype of the TTR record
type or range of the TTR record type function added by Li .
3
Importantly, this also
in this paper, this
holds in the case of manifest types, as while the notation l=v : T 2 is used
is
syntactic
sugar
for
l
:
T
2
,
so
in
these
cases
for
p1
⊑
p2
to
hold,
for
each
field
l
:
T
2
in
p2
there is a field
v
v
l : T 1v in p1 such that T 1v ⊑ T 2v
4
Since Figure 3 is given to display the generation path dynamics, event term specifications are omitted for simplicity.
15
Depending on a system designer or experimenter’s choice of how many fields a DS-TTR lexical action’s
TTR formulae has, the size of SubLex will vary. For instance if lexical actions for verbs lack a field for
tense information, several candidates may be selected in SubLex which are all valid supertypes of the goal
concept (e.g. likes, like, liked), and less appropriate candidates may be filtered out at a later stage. With
this move, the more lexicalised the grammar, the smaller SubLex will be, and consequently the smaller the
search space for generation. It is also worth noting that semantically underspecified lexical entries, such as
those for ‘do’-type auxiliaries used in verb phrase ellipsis, may be selected here by default, as the values
in their fields are null and inherit values from context (Kempson et al., 2011b), so anaphoric and elliptical
forms are readily available.
1
?T y(t),
0
p : t
♦, ?T y(t)
?T y(e), ♦
x : e
?Ty(e → t) λr
: x1 : e x=r.x1 : e
p=U (x) : t
x=john : e
p =U (x) : t
T y(e),
x=john : e
x=john : e
p=U (x) : t
7→
T y(e),
x=john : e
?T y(e → t), λr
: x1 : e x=r.x1 : e
p=U (x) : t
4
(TYPE MATCH)
‘arrives’
♦, T y(t),
7→
?T y(t), ♦
‘John’
7→
3
x
: e
p =U (x) : t
7→
?T y(t),
2
?T y(e
→ t), ♦
λr
:
x1 : e x=r.x1 : e
p=U (x) : t
x=john
: e
p=arrive(x) : t
Goal =
x=john
: e
p=arrive(x) : t
T y(e
→ t), T
y(e),
λr
:
x1 : e x=john : e
x=r.x1
: e
p=arrive(x) : t
Figure 3: Successful generation path in DS-TTR
3.4
Implementation: DyLan dialogue system
DyLan Eshghi et al. (2011), a prototype dialogue system utilising the DS-TTR implementation in parsing
and generation, has been implemented in Java5 within the incremental dialogue system framework Jindigo
(Skantze and Hjalmarsson, 2010), utilising the incremental unit (IU) graphs in the system module’s input
and output buffers based on Schlangen and Skantze (2009)’s IU model. Following Sato’s (2011) insight
that the procedural context of DS parsing can be characterized in terms of graphical search as described in
section 3.2 and following Purver et al.’s (2011) implementation, the parse state of the parsing module is
characterized as three linked directed acyclic graphs (DAGs): (1) a linearly constructed (no backtracking
allowed) word hypothesis graph, consisting of word hypothesis edge IUs between vertices Wn , which have
groundedIn links (i.e. dependency relations) to edges in (2) the DS parsing graph, which adds parse state
edge IUs between vertices Sn (whose internal state is a DS tree), which in turn have groundedIn relations to
edges in (3) the concept graph which has domain concepts as its IUs built between vertices Cn .
In generation, the architecture is the inverse of interpretation in virtue of there being a goal concept: (1)
the concept graph produces goal concepts and adds them as IU edges between vertices GCn , (2) the DS
parsing graph is incrementally constructed on a word-by-word basis by testing the lexical actions in the
5
Available from http://dylan.sourceforge.net/
16
sublexicon produced for current goal concept (see section 3.3), and (3) the word graph’s edges are added to
the output buffer of the module during word-by-word generation, but only committed (made available to
the downstream vocalizer) when they lead to trees whose TTR formulae for which the current goal concept
is a valid subtype (i.e. they form part of a valid generation path as in figure 3).
4 Incremental processing of dialogue phenomena
By way of explanation of the dialogue phenomena, we can now see how the overall DyLan dialogue system
deals with them in parsing and generation, using the mechanisms of DS-TTR as set out above.
4.1
Compound contributions
Previous formal and computational accounts of compound contributions (CCs) have focussed on completions in which, by definition, a responder succeeds in projecting a string the initial speaker had intended
to convey. The foremost implementation is that of Poesio and Rieser (2010), using the PTT model for incremental dialogue interpretation (Poesio and Traum, 1997; Poesio and Rieser, 2003) in combination with
LTAG (Demberg and Keller, 2008). The approach is grammar-based, incorporating syntactic, semantic and
pragmatic information via the lexicalised TAG grammar paired with their PTT model, providing an account
of the incremental interpretation process, incorporating lexical, syntactic and semantic information. Beyond
this, they provide a detailed account of how a suggested collaborative completion might be derived using inferential processes and the recognition of plans: by matching the partial representation at speaker transition
against a repository of known plans in the relevant domain, an agent can determine the components of these
plans which have not yet been made explicit and make a plan to generate them. This model therefore meets
many of the criteria defined above: both interpretation and representation are incremental, with semantic
and syntactic information being present; the use of PTT suggests that linguistic context can be incorporated
suitably. However, while reversibility might be incorporated by choice of suitable parsing and generation
frameworks, this is not made explicit; and the extensibility of the representations seems limited by TAG’s
approach to adjunction (extension via syntactic adjuncts seems easy to treat in this approach, but more general extension is less clear). The use of TAG also seems to restrict the grammar to licensing grammatical
strings, problematic for some CCs (e.g. examples (10) and (11) above, in which semantic dependencies
hold between the two parts of the CC); and the mechanism may not be sustainable for the broad range of
data where the participants make no attempt to match what the other party might have in mind. Moreover,
as with other syntactic accounts, whenever such mechanism is used, this will lead directly to predictions of
processing complexity that we have strong reason to believe will not be met.
In the DyLan model, a broad range of compound utterances now follows as an immediate consequence
of DS-TTR. The use of TTR record types removes the need for grammar-specific parameters; and the interchangeability of representations between parsing and generation means that the construction of a data
structure can become a collaborative process between dialogue participants, permitting a range of varied
user input behaviour and flexible system responses. This use of the same representations by parsing and
generation guarantees the ability to begin parsing from the end-point of any generation process, even midutterance; and to begin generation from the end-point of any parsing process: the successive sequential
exchanges between participants leading to a collaboratively completed utterance is directly predicted, as
in (8), (9) and elsewhere. Both parsing and generation models are now characterised entirely by the parse
context DAG with the addition for generation of a TTR goal concept. The transition from generation to
parsing becomes almost trivial: the parsing process can continue from the final node(s) of the generation
DAG, with parsing actions extending the trees available in the final node set as normal. Transition from
parsing to generation also requires no change of representation with the DAG produced by parsing acting
as the initial structure for generation (figure 4) though we require the addition of a goal concept to drive the
generation process. Given the incremental interpretation provided by the use of record types throughout, we
17
can now also see how a generator might produce such a goal at speaker transition:
Figure 4: Completion of a compound contribution using incremental DS-TTR record type construction with
parser and generator sharing a parse state.
The same record types are thus used throughout the system: as the concepts for generating system plans, as
the goal concepts in NLG, and for matching user input against known concepts in suggesting continuations.
Possible system transition points trigger alternation between modules in their co-construction of the shared
parse/generator; in DyLan this is provided by a simplistic dialogue manager with high-level methods without reference to syntax or lexical semantics. A goal concept can be produced by the dialogue manager at a
speaker transition by searching its domain concepts for a suitable subtype of the TTR record type built so
far, guaranteeing a grammatical continuation given the presence of appropriate lexical actions and allowing exchanges such as (1). This extends the method for compound contributions described in Purver and
Kempson (2004a), however now the dialogue manager has an elegant decision mechanism for aiding content selection. And, given the presumption of context, content and goal specifications all in terms of record
types, the ability to construct goals in a scenario without linguistic antecedents is also allowed for (12), (13)
and (15) above.
The data of compound contributions thus follows in full, even when either the goal record type for the
interrupter does not match that of the initiator as in (5), or when the goal record type does not correspond to
a complete domain concept, as in the successive fragment exchanges such as (9).This is achieved through
progressive extensions of the partial tree so far, either directly, or by adding LINKed trees as required for
adjunctive phenomena. This results in the word-by-word further specification of the record type at the root
of the matrix tree representing the maximal interpretation of the string/utterance so far. In Figure 5 we
give the progressive record-type specification for the exchange (31), a simplification of (9), showing how
incomplete structures may serve as both input and output for either party:
(31) A: Today Robin arrives
B: from
A: Sweden
Details of the tree derivations are omitted in Figure 5, but we have included these in Appendix 1, which
contains a fuller tree derivation for (31) plus an ‘other-correction’ as modelled identically to self-repair as
set out in the next section.



event
: es
 Ref T ime=today : es 
p
: t
7→
“A: Today”
7→
event=e1
 Ref T ime=today

 p1=Ref T imeevent

 x=robin
p=arrive(event,x)
:
:
:
:
:
“..Robin arrives”
es
es
t
e
t







7→
7→









event=e1
Ref T ime=today
p1=Ref T imeevent
x=robin
p=arrive(event,x)
x1
p2=f rom(event,x1)
“B: from?”
:
:
:
:
:
:
:
es
es
t
e
t
e
t
















7
→




7→
event=e1
Ref T ime=today
p1=Ref T imeevent
x=robin
p=arrive(event,x)
x1=Sweden
p2=f rom(event,x1)
“A: Sweden”
Figure 5: Incremental interpretation via TTR subtypes
As noted, more complex forms can be generated by incorporating LINKed trees, as is presumed in the
characterisation of the many extensions by the addition of an adjunct, as in (8), (11), (18) (See Appendix 1),
without any of these having to involve any extension of the formal DS vocabulary.
18
:
:
:
:
:
:
:
es
es
t
e
t
e
t










4.2
Self-repair
In this section, we present our initial model of self-repair. In generation, as a goal concept may be revised
shortly after or during the generation process due to a decision by the dialogue manager, trouble in generating
the next word may be encountered. DyLan’s repair function operates if there is an empty state, or no
possible DAG extension, after the semantic filtering stage of generation (resulting in no candidate succeeding
word edge) by restarting the generation procedure from the last committed parse state edge. It continues
backtracking by one vertex at a time in an attempt to extend the DS DAG until successful, as can be seen
in figure 6. Note that the previously committed word graph edge for London is not revoked, following
the principle that it has been in the public record and hence should, correctly, still be accessible. Clark
(1996) makes this point about utterances such as “the interview was.. it was alright” where the reparandum
(repaired material) still needs to be accessed for the anaphoric use of it to succeed.
Our protocol is consistent with Shriberg and Stolcke (1998)’s empirical observation that the probability
of retracing N words back in an utterance is more likely than retracing from N+1 words back, making the
repair as local as possible. Utterances such as “I go, uhh, leave from Paris” are generated incrementally, as
the repair is integrated with the semantics of the part of the utterance before the repair point, maximising reuse of existing semantic structure, while the time-linear word graph continues to extend but with the repair’s
edges groundedIn different paths of the parse DAG to the reparandum’s edges (as in Fig.6; see also (2)).
A subset of self-repairs, extensions, where the repair effects an “after-thought”, usually in transition relevant places in dialogue after apparently complete turns, is dealt with straightforwardly by our module: e.g.
(8), (1)-(3), (9), (18). The DS parser treats these as monotonic growth of the matrix tree through LINK
adjunction (Cann et al., 2005b), resulting in subtype extension of the root TTR record type. Thus, a change
in goal concept during generation will not always put demands on the system to backtrack, such as in generating the fragment after the pause in “I go to Paris . . . from London”. It is only at a semantics-syntax
mismatch where the revised goal TTR record type does not correspond to a permissible extension of a DS
tree in the DAG as in Fig.6, where overt repair will occur.
Figure 6: Incremental DS-TTR generation of a self-repair upon change of goal concept. Type-matched
record types are double-circled nodes and revoked edges indicating failed paths are dotted. Inter-graph
groundedIn links go from top to bottom.
Note that the mechanism for recovery of meaning in parsing a self-repaired utterance can be defined in a
similarly local way in our model, using the following definition:
(32) Repair IF from parsing word W there is no edge SEn able to be constructed from vertex Sn (no
parse) or if no domain concept hypothesis can be made through subtype relation checking, repair:
parse word W from vertex Sn−1 and and should that parse be successful add a new edge to the top
path, without removing any committed edges beginning at Sn−1 .
It is worth noting that in contrast to Skantze and Hjalmarsson’s (2010) string-based speech plan comparison
approach, there is no need to regenerate a fully-formed string from a revised goal concept and compare it
with the string generated thus far to characterize repair. Instead, repair is driven by attempting to extend
existing parse paths to construct the new target record type, retaining the semantic representation and the
procedural context of actions already built up in the generation process to avoid the computational demand
of constructing syntactic structures from afresh where possible.
4.3
Speech Acts and speaker/hearer attributions in DS/TTR
A further bonus of combining DS mechanisms with TTR record types as output decorations is the allowance
of a much richer vocabulary for such decorations, as empirically warranted. In particular, it provides a basis
19
from which speaker and hearer attributes may be optionally specified. In this connection, Purver et al. (2010)
propose a specification of fields with sub-field specifications, one a contxt sub-field for speaker-hearer values, the second, contnt, for familiar lambda-terms, a modification which allows a record of speaker-hearer
attributions to be optionally kept alongside function-argument content record type specifications so that the
different anaphor-dependency resolutions across switch of participant roles can be modelled as in (10)-(11)
without disturbing content compilation of the lambda terms. No details are given here (see Purver et al.
(2010) for details); but in principle with unification of record types available for record types of arbitrary
complexity, such specifications are unproblematic. The optionality of specification of speaker/hearer relations/attributes raises issues of what constitutes successful communication, in particular for Gricean and
proto-Gricean models in which recognition of the content of the speaker’s intentions is essential: Poesio
and Rieser (2010) is illustrative. We do not enter into this debate here, but merely note that this stance is
commensurate with the data of section 1 in which participants’ intentions may emerge or be subject to modification during the course of a conversation without jeopardising its success (see Gregoromichelaki et al.
(2011); ? for detailed discussion).
5 Conclusion
We have presented a formal framework for modelling conversational dialogue with parsing and generation
modules as controlled by a dialogue manager, both of which reflect word by word incrementality, using
a hybrid of Dynamic Syntax and Type Theory with Records. The composite framework allows access to
record types incrementally during generation, providing strict incremental representation and interpretation
for substrings of utterances that can be accessed by existing dialogue managers, parsers and generators
equally, allowing the articulation of syntactic and semantic dependencies across parser and generator modules. Characterising DS generation as a DAG in tandem with a DAG-based parser, in particular, allows easy
integration into incremental dialogue systems, and facilitates goal revision and self-repairing capabilities.
Retaining the DS assumption of tree growth as defined in LOFT as input to both parsing and generation systems preserves the original expressibility of syntactic generalisations unaltered. The model also allows for
experimentation with search techniques, which will be explored in coming work. The account of quantification of the earlier DS system Kempson et al. (2001) depended on the lower type account of quantification as
expressed through epsilon terms definable in the epsilon calculus. This system, though equivalent in expressive power to classical predicate logic, and hence relatively restricted given natural language expressivity,
is nonetheless not incommensurable with the more general type-dependent account of quantification (see
Fernando (2002), Cooper (2012)) made available by the Martin-Löf type-logical proof system. With the
work on developing the DS-TTR composite framework having reached current levels of formal explicitness,
work on exploring mappings from the DS model of quantification onto TTR accounts of quantificational
dependency that preserve the incrementality of scope dependency choice made available in that earlier DS
account thus now becomes the next important challenge on the horizon.
References
James Allen, George Ferguson, and Amanda Stent. An architecture for more realistic conversational systems. In Proceedings of the 2001 International Conference on Intelligent User Interfaces (IUI), January
2001.
Patrick Blackburn and Wilfried Meyer-Viol. Linguistics, logic and finite trees. Logic Journal of the Interest
Group of Pure and Applied Logics, 2(1):3–29, 1994.
Robert B. Brandom. Making it Explicit: Reasoning, Representing, and Discursive Commitment. Harvard
University Press, 1994.
Okko Buß and David Schlangen. Dium : An incremental dialogue manager that can produce selfcorrections. In Proceedings of SemDial 2011 (Los Angelogue), Los Angeles, CA, pages 47–54, 2011.
20
Ronnie Cann. Towards an account of the english auxiliary system: building interpretations incrementally. In
Ruth Kempson, Eleni Gregoromichelaki, and Christine Howes, editors, Dynamics of Lexical Interfaces.
Chicago: CSLI Press, 2011.
Ronnie Cann, Tami Kaplan, and Ruth Kempson. Data at the grammar-pragmatics interface: the case of
resumptive pronouns in English. Lingua, 115(11):1475–1665, 2005a. Special Issue: On the Nature of
Linguistic Data.
Ronnie Cann, Ruth Kempson, and Lutz Marten. The Dynamics of Language. Elsevier, Oxford, 2005b.
Ronnie Cann, Ruth Kempson, and Matthew Purver. Context and well-formedness: the dynamics of ellipsis.
Research on Language and Computation, 5(3):333–358, 2007.
S. Carberry. Plan recognition in natural language dialogue. the MIT Press, 1990.
Stergios Chatzikyriakidis and Ruth Kempson. Standard modern and pontic greek person restrictions: A
feature-free dynamic account. Journal of Greek Lingusitics, pages 127–166, 2011.
N. Chomsky. Aspects of the Theory of Syntax. MIT, Cambridge, MA, 1965.
Noam Chomsky. New Horizons in the Study of Language and Mind. Cambridge University Press, 2000.
Herbert H. Clark. Using Language. Cambridge University Press, 1996.
Herbert H. Clark and Jean E. Fox Tree. Using uh and um in spontaneous speaking. Cognition, 84(1):73–111,
2002.
Robin Cooper. Records and record types in semantic theory. Journal of Logic and Computation, 15(2):
99–112, 2005.
Robin Cooper. Type theory and semantics in flux. In Ruth Kempson, Nicholas Asher, and Tim Fernando,
editors, Handbook of the Philosophy of Science, volume 14: Philosophy of Linguistics, pages 271–323.
North Holland, 2012.
Donald Davidson. Truth and meaning. Synthese, 17:304–323, 1967.
Donald Davidson. Essays on Actions and Events. Clarendon Press, Oxford, UK, 1980.
Donald Davidson. A nice derangement of epitaphs. In E. Lepore, editor, Truth and Interpretation, pages
433–446. 1986.
Donald Davidson. The social aspect of language. In B. McGuiness and G. Oliveri, editors, The philosophy
of Michael Dummet. Kluwer Academic Publishers, 1994.
V. Demberg and F. Keller. A psycholinguistically motivated version of tag. In Proceedings of the International Workshop on Tree Adjoining Grammars, 2008.
A. Eshghi, M. Purver, and Julian Hough. Dylan: Parser for dynamic syntax. Technical report, Queen Mary
University of London, 2011.
Raquel Fernández. Non-Sentential Utterances in Dialogue: Classification, Resolution and Use. PhD thesis,
King’s College London, University of London, 2006.
Tim Fernando. Three processes in natural language interpretation. In W. Sieg, R. Sommer, and C. Talcott,
editors, Reflections on the Foundations of Mathematics: Essays in Honor of Solomon Feferman, pages
208–227. Association for Symbolic Logic, Natick, Mass., 2002.
Jonathan Ginzburg. The Interactive Stance: Meaning for Conversations. Oxford University Press, 2012.
Jonathan Ginzburg and Robin Cooper. Clarification, ellipsis, and the nature of contextual updates in dialogue. Linguistics and Philosophy, 27(3):297–365, 2004.
C. Goodwin. Conversational organization: Interaction between speakers and hearers. Academic Press,
New York, 1981.
21
E. Gregoromichelaki. Conditionals: A Dynamic Syntax Account. PhD thesis, King’s College London, 2006.
E. Gregoromichelaki, R. Cann, and R. Kempson. On coordination in dialogue: subsentential talk and its
implications. In Laurence Goldstein, editor, On Brevity. OUP, forthcoming.
Eleni Gregoromichelaki, Ruth Kempson, Matthew Purver, Greg J. Mills, Ronnie Cann, Wilfried MeyerViol, and Pat G. T. Healey. Incrementality and intention-recognition in utterance processing. Dialogue
and Discourse, 2(1):199–233, 2011.
Barbara J. Grosz and Candace L. Sidner. Attention, intentions, and the structure of discourse. Computational
Linguistics, 12(3):175–204, 1986.
Markus Guhe. Incremental Conceptualization for Language Production. NJ: Lawrence Erlbaum Associates,
2007.
J. Hawkins. Efficiency and Complexity in Grammars. Cambridge University Press, Cambridge, 2004.
Ronald Kaplan and Annie Zaenen. Long-distance dependencies, constituent structure, and functional uncertainty. In M. Baltin and A. Kroch, editors, Alternative Conceptions of Phrase Structure, pages 17–42.
University of Chicago Press, Chicago, Illinois, 1989.
R. Kempson and J. Kiaer. Multiple long-distance scrambling: Syntax as reflections of processing. Journal
of Linguistics, 46(01):127–192, 2010.
Ruth Kempson, Wilfried Meyer-Viol, and Dov Gabbay. Dynamic Syntax: The Flow of Language Understanding. Blackwell, 2001.
Ruth Kempson, Eleni Gregoromichelaki, and Christine Howes, editors. The Dynamics of Lexical Interfaces.
CSLI - Studies in Constraint Based Lexicalism, 2011a.
Ruth Kempson, Eleni Gregoromichelaki, Wifried Meyer-Viol, Matthew Purver, Graham
White, and Ronnie Cann.
Natural-language syntax as procedures for interpretation: the
dynamics of ellipsis construal.
In A. Lecomte and S. Tronçon, editors, Ludics, Dialogue and Interaction, number 6505 in Lecture Notes in Computer Science, pages
114–133. Springer-Verlag, Berlin/Heidelberg, 2011b.
ISBN 978-3-642-19210-4.
URL
http://www.eecs.qmul.ac.uk/ mpurver/papers/kempson-et-al11ludics.pdf.
R. Larson and G. Segal. Knowledge of Meaning: An Introduction to Semantic Theory. The MIT Press,
1995.
Staffan Larsson. The ttr perceptron: Dynamic perceptual meanings and semantic coordination. In Proceedings of the 15th Workshop on the Semantics and Pragmatics of Dialogue (SemDial 2011 - Los Angelogue),
pages 140–148, September 2011.
W.J.M. Levelt. Monitoring and self-repair in speech. Cognition, 14(1):41–104, 1983.
W.J.M. Levelt. Speaking: From Intention to Articulation. MIT Press, 1989.
S. C. Levinson. Pragmatics. Cambridge University Press, 2002.
Vincenzo Lombardo and Patrick Sturt. Incrementality and lexicalism: a treebank study. In S. Stevenson and
P. Merlo, editors, The Lexical Basis of Sentence Processing, pages 137–156. John Benjamins, 2002.
John McDowell. Meaning, Knowledge and Reality. Harvard University Press, 1998.
J. Merchant. Fragments and ellipsis. Linguistics and Philosophy, 27:661–738, 2004.
Ruth Millikan. The Varieties of Meaning: The Jean-Nicod Lectures. MIT Press, 2004.
G. Mills and E. Gregoromichelaki. Establishing coherence in dialogue: sequentiality, intentions and negotiation. In Proceedings of SemDial (PozDial), 2010.
22
David Milward. Axiomatic Grammar, Non-Constituent Coordination and Incremental Interpretation. PhD
thesis, University of Cambridge, 1991.
R. Montague. Universal grammar. Theoria, 36:373–398, 1970.
J. Morgan. Sentence fragments and the notion sentence. In Issues in linguistics: Papers in honor of Henry
and Renée Kahane, pages 719–751. 1973.
J.L. Morgan. Some interactions of syntax and pragmatics. In Peter Cole and Jerry L. Morgan, editors,
Syntax and Semantics, Volume 3: Speech Acts, volume 3, pages 289–303. Academic Press, 1975.
Colin Phillips. Linear order and constituency. Linguistic Inquiry, 34:37–90, 2003.
Martin Pickering and Simon Garrod. Toward a mechanistic psychology of dialogue. Behavioral and Brain
Sciences, 27:169–226, 2004.
Paul Piwek. Dialogue structure and logical expressivism. Synthese, 183:33–58, 2011.
Massimo Poesio and Hannes Rieser. Coordination in a PTT approach to dialogue. In Proceedings of the 7th
Workshop on the Semantics and Pragmatics of Dialogue (SEMDIAL), Saarbrücken, Germany, September
2003.
Massimo Poesio and Hannes Rieser.
Completions,
coordination,
and
ment
in
dialogue.
Dialogue
and
Discourse,
1:1–89,
2010.
http://elanguage.net/journals/index.php/dad/article/view/91/512.
alignURL
Massimo Poesio and David Traum. Conversational actions and discourse situations. Computational Intelligence, 13(3), 1997.
Matthew Purver. CLARIE: Handling clarification requests in a dialogue system. Research on Language and
Computation, 4(2-3):259–288, 2006.
Matthew Purver and Ruth Kempson. Incremental context-based generation for dialogue. In A. Belz,
R. Evans, and P. Piwek, editors, Proceedings of the 3rd International Conference on Natural Language
Generation (INLG04), number 3123 in Lecture Notes in Artifical Intelligence, pages 151–160, Brockenhurst, UK, July 2004a. Springer.
Matthew Purver and Ruth Kempson. Incrementality, alignment and shared utterances. In J. Ginzburg and
E. Vallduvı́, editors, Proceedings of the 8th Workshop on the Semantics and Pragmatics of Dialogue
(SEMDIAL), pages 85–92, Barcelona, Spain, July 2004b.
Matthew Purver, Ronnie Cann, and Ruth Kempson. Grammars as parsers: Meeting the dialogue challenge.
Research on Language and Computation, 4(2-3):289–326, 2006.
Matthew Purver, Christine Howes, Eleni Gregoromichelaki, and Patrick G. T. Healey.
Split
utterances in dialogue:
A corpus study.
In Proceedings of the 10th Annual SIGDIAL Meeting on Discourse and Dialogue (SIGDIAL 2009 Conference), pages 262–
271, London, UK, September 2009. Association for Computational Linguistics.
URL
http://www.dcs.qmul.ac.uk/ mpurver/papers/purver-et-al09sigdial-corpus.pdf.
Matthew Purver, Eleni Gregoromichelaki, Wilfried Meyer-Viol, and Ronnie Cann. Splitting the ‘I’s and
crossing the ‘You’s: Context, speech acts and grammar. In P. Łupkowski and M. Purver, editors, Aspects of Semantics and Pragmatics of Dialogue. SemDial 2010, 14th Workshop on the Semantics and
Pragmatics of Dialogue, pages 43–50, Poznań, June 2010. Polish Society for Cognitive Science.
Matthew Purver, Arash Eshghi, and Julian Hough. Incremental semantic construction in a dialogue system.
In J. Bos and S. Pulman, editors, Proceedings of the 9th International Conference on Computational
Semantics, pages 365–369, Oxford, UK, January 2011.
23
Yo Sato. Local ambiguity, search strategies and parsing in Dynamic Syntax. In E. Gregoromichelaki,
R. Kempson, and C. Howes, editors, The Dynamics of Lexical Interfaces. CSLI Publications, 2011.
David Schlangen. A Coherence-Based Approach to the Interpretation of Non-Sentential Utterances in Dialogue. PhD thesis, University of Edinburgh, 2003.
David Schlangen and Gabriel Skantze. A general, abstract model of incremental dialogue processing. In Proceedings of the 12th Conference of the European Chapter of the ACL (EACL 2009),
pages 710–718, Athens, Greece, March 2009. Association for Computational Linguistics. URL
http://www.aclweb.org/anthology/E09-1081.
Elizabeth Shriberg and Andreas Stolcke. How far do speakers back up in repairs? A quantitative model. In
Proceedings of the International Conference on Spoken Language Processing, pages 2183–2186, 1998.
Gabriel Skantze and Anna Hjalmarsson.
Towards incremental speech generation in dialogue systems.
In Proceedings of the SIGDIAL 2010 Conference, pages 1–8,
Tokyo, Japan, September 2010. Association for Computational Linguistics.
URL
http://www.sigdial.org/workshops/workshop11/proc/pdf/SIGDIAL01.pdf.
Dan Sperber and Deirdre Wilson. Relevance: Communication and Cognition. Blackwell, second edition,
1995.
R. Stainton. Words and Thoughts: Subsentences, Ellipsis, and the Philosophy of Language. Oxford University Press, 2006.
6 Appendix
This appendix provides a derivation for a split dialogue in which both input and output of intermediate
generation and parsing steps involve partial structures, with a final step of correction:
(33) A: Today Robin arrives
B: from
A: Sweden
B: with Elizabet?
A: no, Staffan.
Notice how the event node on the matrix tree is represented EVENT and then through expansion/modification of its type specification as successively EVENT1, EVENT2, etc so as to indicate its location on the tree during the build up of the other trees through LINK adjunction to it. The matrix tree type
specification is not repeatedly shown here across these various revisions for reasons of space.
24
?T y(t),

event=e1
: es
 Ref T ime=today : es 
p
: t

A: Today 7−→
T y(t),
event=e1
: es
Ref T ime=today : es
EVENT
T y(es),
event=e1 : es
Ty(es → t),
T y(es ),
λr1 : event : es
event=e1 : es
event=r1.event : es
Ref T ime=today : es
..Robin arrives 7−→
T y(t),
event=e1
: es
Ref T ime=today : es
T y(es ),
event=e1 : es 





♦?T
y(es → t), λr1
:
event : es event=r1.event : es
p
: t
♦, T y(t),
event=e1
Ref T ime=today
p1=Ref T imeevent
x=robin
p=arrive(event,x)
:
:
:
:
:
es
es
t
e
t






Ty(es → t),
λr1 : event : es
Ty(es → t),
Ref T ime=r1.event : es EVENT
λr1
:
event : es
T
y(e
s ),


 
event=r1.event : es
event=e1
: es
 Ref T ime
: e 
: es   x=robin
p=arrive(event,x) : t
p1=Ref T imeevent : t
T y(e →
(es → t)),
λr: x : e
T y(e),
 λr1 : event : es

x=robin : e
event=r1.event : es
 x=r.x
: e 
p=arrive(event,x) : t
Figure 7: Processing “A: Today, Robin arrives”
25
?T y(t),

event=e1
: es
 x1
: e 
p2=f rom(event,x1) : t

B: from? 7−→
A: Sweden
EVENT1
Ty(es → t), event : es
λr1
:


event=r1.event : es
 x1
: e 
p2=f rom(event,x) : t
T y(es ),
event=e1 : es
T y(e →
(es → t)),
λr : x1 : e
♦,+Q, ?T y(e),
 λr1 : event : es

x1 : e
event=r1.event
: es
 x1=r.x1
: e 
p2=f rom(event,x1) : t
?T y(t),


event=e1
: es
EVENT2
 x1=Sweden
: e 
p2=f rom(event,x1) : t
7−→
Ty(es → t), event : es
λr1
:


event=r1.event : es
 x1=Sweden
: e 
p2=f rom(event,x) : t
T y(es ),
event=e1 : es
T y(e →
(es → t)),
λr : x1 : e
T y(e),
 λr1 : event : es

x1=Sweden : e
event=r1.event
: es
 x1=r.x1
: e 
p2=f rom(event,x1) : t
B: with Elisabet?
7−→
T y(t), +Q

event=e1
: es
 x2=Elisabet
: e 
p3=with(event,x2) : t

EVENT3
Ty(es → t), event : es
λr1
:


event=r1.event
: es
 x2=Elisabet
: e 
p3=with(event,x2) : t
T y(es ),
event=e1 : es
T y(e →
(es → t)),
λr : x2 : e
♦, T y(e),
 λr1 : event : es

x2=Elisabet : e
event=r1.event
: es
 x2=r.x2
: e 
p3=with(event,x2) : t
26
Figure 8: Processing Fragment (continued from Figure 7): “B: from A: Sweden B: with Elisabet?”
A: No, Staffan
7−→
T y(t), +Q

event=e1
: es
 x2=Staf f an
: e 
p3=with(event,x2) : t

T y(es ),
event=e1 : es
EVENT4
Ty(es → t), event : es
λr1
:


event=r1.event
: es
 x2=Staf f an
: e 
p3=with(event,x2) : t
T y(e →
(es → t)),
λr : x2 : e
♦, T y(e),
 λr1 : event : es

x2=Staf f an : e
event=r1.event
: es
 x2=r.x2
: e 
p3=with(event,x2) : t
Figure 9: Result of processing “No, Staffan”: Other correction via backtracking along context DAG
27
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
