PDCD204
19’’ Rack Mount Professional Dual CD Player With Jog Dial
• Top Control unit
• Jog shuttle wheel
• Dual CD-disc drive
• 8 X over-sampling, 1 bit D/A converter
• Separate track skip and search buttons
• AUTOCUE function
• Installation possible in a 19’’ rack system
• Pitch speed control: +/-4%, +/-8%, +/-16%
PDCD4000
Professional Dual CD Player with DSP and Sampler
• Quick Start Within 0.015 Seconds
• Pitch Bend (8%, 16%, 32%, 100%)
• Single Auto Cue/Continuous Play/Relay/Outro
• Jog Dial for Frame-By-Frame Searching,
• Speed Control
• DSP Effects (Scratch, Flanger,
Reverb, Filter, Reverse)
• Dual Seamless Loops Per Deck
• Dual Sampler 8 Seconds Per Deck
• Disc Identify Loads 5 Cue Points
PDCDTP620M
• D/A Converter: 24 bits
• Frequency Response: 20Hz-20KHz
• Harmonic: 0.11%
• Signal/Noise Ratio: (85dB)
• Cross Talk: (-85dB)
• Output Level: 2V
• Load Impedance : more than 47Khms
• Speed Edge (pitch): (+/-18%)
• Power Supply: 100-240V AC 15W
• Dimensions: 19’’W x 3.6’’H x 41.5’’D
Rack Mount Professional Dual DJ Controller with Scratch, Loop, Mixer, USB, and SD Card Player
• Dual RCA Outputs
• Rack-Mount Design
• XLR Microphone Input
• Continuous Loop Mode
• USB and SD Card Player
• 10+ Track-Folder Search
• Dual Pitch Slide Control
• Search-Single Time Button
• Jog Wheel With Scratch Mode
• LCD Display & Blue Backlight
44
• (CDDA: 8%, 16%, 32% & 100%)
(MP3: 8%, 16%, 32% & 100%)
• +/-16% Pitch Bend with master Tempo
• Three mode time selection (Total Remaining/
Each remaining/ Elapsed playing time)
• MP3 folder compatible
• Sleep Shutdown Feature (30 Minute)
• Dual (storage/PC Link) USB Interface (PC
Only) FAT formatted Storage Devices
• RCA Line Audio & Digital Audio Output
• Fader Start Mixer Interface
• Relay External CD Audio Compatible
• LED Indicators and Illumination
• Power Supply 110/220V
• Unit Dimensions: 11’’(H) x 14.2’’(W) x 3.5’’(D)
Professional DJ Dual USB MP3/SD/USB Player w/ Scratch Function
• Large & Easy to Read LCD Display
• Tracks Programming
• Pitch Control (+/-6%, +/-12%, +/-18%)
• Loop Play/Reverse Play
• Brake Effect
• Play Via SD Card & USB Disk
• ID3 Information Display
• Dual USB/MP3/Full USB/MP3 Control
• Supports High Capacity SD Card (SDHC) &
High Capacity Storage Device (16GB)
PDJ480UM
when Disc is Reloaded
• Remote Fader Start
• Cue Function + 5 Hot Cue Points Per Deck
• Auto BPM with Tap Option
• Multiple Time Display Modes
• Anti-Shock Memory Buffer
• Digital Audio Outputs and RCA Outputs
• Remote Control: 18.9’’ x 5.2’’ x 1.5’’
• Main Unit: 18.9’’ x 3.3’’ x 9.7’’
• 110/220 Voltage Switchable
Digital DJ/CD/CD-R/MP3 Media Player & Controller
• Audio/CD/CD-R/MP3
• DJ Software Included
• Plays MP3 & WAV Files from USB Storage Devices
• Anti-shock using RAM buffer memory
• Extra large Jog Wheel w/ Scratch Control
• Scratch Effect Mode
• CD Text Enabled
• Multifunction Scroll Knob for MP3 Folder navigation
• Hot CUE with Three CUE Points
• CUE storage w/ Title/ Album/ Artist Display
• Next Track Fader w/ Time Control
• Dump Mode with beat Selector
• Single, Continuous and Repeat play modes
• Seamless Loop w/ Re-Loop & A/B Edit
• BPM read out (TAP)
• Pitch Control Slider with Preset Speed Settings
PDJ450U
• LOOP function (playback loop)
• Elapsed/Remaining Time Display
• Analogue and digital audio outputs
• 110/220 Voltage Selectable
• Drive Unir Dimensions:19’’W x 3.5’’H 10.3’’D
• Control Unit Dimensions:19’’W x 3.5’’H 2.6’’D
• RELAY function
(automatic switchover between CD drives)
• Dual RCA Inputs (Phono & Line)
• ID3 Tags for Track Information
• 3-Band EQ on Multiple Channels
• Pitch Bend Adjustment Range: 12%
• Anti-Shock Buffer Memory: 40 Seconds
• Dual Professional USB DJ MP3 & SD Card Player
• Dimensions: 18.98’’ W x 3.54’’ D x 3.14’’ H
• Power Supply: 100-240 V, 60/50 Hz
Pro CD/MP3 Players
PMIDI100
Professional Digital MIDI Controller w/VIRTUAL DJ Software Included
• Play/Pause
• Cue/Play
• Sync
• Seamless Loop/ Loop Trim
• Fast Search Forward or backward
• Scratch
• VIRTUAL DJ Software
• Effect Select and Parameter
Adjust(DEPTH, DELAY, LFO)
• Pitch Control
PDJSIU100
I Mixer Ipod DJ Player With DJ Scratch And Sound Effects
• I SCRATCH Is An Ipod Sound Effect Mixer Devise.
• It Has Special Sound Effect Programs
With DJ Scratch Simulation
• The I SCRATCH Can Be Used With Two
Different Combinations Of Signal Sources. Sound
Effects Of Flanger/Echo/Trans/Pan/Filter
• The IPod Will Be Charged When
Inserted Into I SCRATCH.
• One Universal IPod Docking Stations Accept All IPod Models.
PLTTB1
• Start/Stop Button
• 33/45 RPM
• Dimensions: 16.93’’W x 4.73’’H x 14.57’’D
• 110/220 V Auto Switching
Professional Belt Drive Turntable with USB Interface
• Easily Convert Vinyl To WAV and MP3 Formats
• USB Connection For Conversion
of Vinyl to Digital Media
• Internal Stereo Phono Pre Amplifier
• Plug Directly to Computer (PC & MAC)
PLTTB3U
• Line Output Can Be Recorded.
• JOG Wheel Simulates The Scratch
Feature On A DJ Turntable
• Power Supply: 5V 110/220 V
• Dimensions: 5.4’’ W x 8.9’’D
Professional Belt-Drive Turntable
• Pitch Control: +/- 16%
• Strobe Light Illumination
• Weighted Tone Arm
• Cartridge and Stylus Included
• Dust Cover Included
PLTTB2U
• Channel Fader
• Channel Gain
• Effect and Sample Control
• 3 Band EQ (Hi, Mid, Low knob)
• Track Select
• Channel Cue Monitor
• Headphone Output and Volume Control
• Master Tempo
• USB Bus Powered
• Switchable 33 1/3 and 45 RPM
• Headshell, Dust Cover & 45 Adapter Included
• Power Supply: AC 120V ~ 60HZ
• Dimensions: 3.68’’H x 14.17’’W x 13.59’’D
Belt Drive USB Turntable with Digital Recording Software
• Belt Drive Turntable
• +/-10% Variable Pitch Slider
• USB Connection For Conversion
of Vinyl to Digital Media
• Internal Stereo Phono Pre Amplifier
• Plug Directly to Computer (PC)
• Audacity Recording Software Included
• Line Level RCA Outputs with Built-in Preamp
• Fully Adjustable Counter Weight
& Anti-Skating Controls
• 33-1.3-45 RPM Speed Selector
• Soft Touch Start/Stop Buttons
• Removable Stroboscope Light (Not included)
• Headshell, Dust Cover & 45 Adapter Included
• Power Supply: 110V - 220V
• Dimensions: 3.86’’H x 16.5’’W x 13.4’’D
Pro CD/MP3 Players / MIDI Controllers / Turntables
55
PP444
Ultra Compact Phono Turntable Preamp
• Converts Your Phono Signal to a Line Level Signal
• State-of-the-art Phono Preamp To Accommodate Magnetic Pickups
• Ultra Low-Noise Audio Operational Amplifiers
Offer Outstanding Sound Performance
• Dedicated RCA and 1/4’ Output Connectors
• DC 12-Volt Adapter Included
• Connects to Turntable
• Input Sensitivity: 3mV at 50K Ohms (phono)
• Output: 2V max (P-P) at 10K Ohms
• Includes power adapter 12V DC
• THD: 0.08% @ 1KHz and 3mV
PP555
Input | S/N Ratio: 70dB | Frequency
Response: 20Hz To 20KHz @ 2dB
• Connects to Turntable Output to Bring Phono Level
Up to Line Level - 12V DC 110V Adaptor Included
• Dimensions: (W)3.54”x (H)2.13” x
(D)1.02” - Weight: 0.88 Lbs
• Input Sensitivity/Impedance/PHONO 3
mV / 50K Ohms - T.H.D: 0.08 for 1 KHz
3 MV Input - Output Level: 2V
• Load Impedance: 10K Ohms - Reference Voltage: 1V d
• S/N Ratio (A-WTD): 70 dB - Frequency
Ultra Compact Phono Turntable Pre-Amplifier w/ 9 V Battery Compartment
• Converts Your Phono Signal to a Line Level Signal
• 9 Volt Battery Compartment
• State-of-the-art Phono Preamp To Accommodate Magnetic Pickups
• Ultra Low-Noise Audio Operational Amplifiers
Offer Outstanding Sound Performance
• Dedicated RCA and 1/4’ Output Connectors
• DC 12-Volt Adapter Included
• Connects to Turntable
• Input Sensitivity: 3mV at 50K Ohms (phono)
• Output: 2V max (P-P) at 10K Ohms
• Includes power adapter 12V DC
PP999
Phono Turntable Pre-Amplifier
• Connects to Turntable Output to bring
Phono Level Up to Line Level
• 12V DC 110V Adaptor Included
• Load Impedance: 10K Ohms
• Reference Voltage: 1V
• Input Sensitivity / Impedance/
PHONO 3 mV / 50K Ohms
PHE300
•
•
•
•
•
•
•
•
•
•
•
•
•
66
• T.H.D. : 0.08 for 1 KHz 3 mV Input
• Output Level;2V
• S/N Ratio (with A-WTD);70 dB
• Frequency Response:20 Hz ~ 20 KHz ±2dB
• Dimensions (WHD):3.54”x2.13” x1.02”
• Weight : 0.88 Lbs
2-Channel Hum/Noise Destroyer
Removes AC Hum Noise
Breaks Ground Loops Safely
Maintains Highest Sonic Quality
High-Performance Ultra-Compact Design
High-Quality Components and Exceptioally Rugged Construction
(2) 1/4-Inch IRS Inputs and Outputs for
PHE400
• THD: 0.08% @ 1KHz and 3mV
Input | S/N Ratio: 70dB | Frequency
Response: 20Hz To 20KHz @ 2dB
• Connects to Turntable Output to Bring Phono Level
Up to Line Level - 12V DC 110V Adaptor Included
• Dimensions: (W)3.54”x (H)2.13” x
(D)1.02” - Weight: 0.88 Lbs
• Input Sensitivity/Impedance/PHONO 3
mV / 50K Ohms - T.H.D: 0.08 for 1 KHz
3 MV Input - Output Level: 2V
• Load Impedance: 10K Ohms - Reference Voltage: 1V d
2-Mono or 1 Stereo Signal
Automatically Converts Unbalanced to
Balanced Signal Without Any Signal Loss
•
Hum Eliminator 2-Channel Box with XLR Jacks
60 Hz Noise Removal
Removes AC Hum Noise
Breaks Ground Loops Safely
Maintains Highest Sonic Quality
Passive Device: No Power Required
High-Performance Ultra-Compact Design
1/4-Inch TRS Phone and XLR Inputs
and Outputs on 2-Channels
Pre-Amps
•
•
•
•
Audiophile High-Quality Components
and Exceptionally Rugged Construction
Automatically Converts Unbalanced to
Balanced Signal Without Any Signal Loss
Uses 11:1 Isolation Transformers to Break
Loop Antenna and Balance Audio Lines
Automatically Translates Signal Voltages to
Match Difference in Ground Potentials
PS430
•
•
•
•
Compact 1-Channel 48V Phantom Power Supply
DC 12-Volt Adapter Included
Ultra Low-Noise Audio Performance
Selectable +12 / +48 V Power Supply
On/off Power Switch and LED Indicator
PMX5U
• MIC1-2: 22m /v600 OHMS
• Phono1-2: 17mV/50k Ohms
• Line1-2: 175mV/50k Ohms
• CD:1v/50k Ohms
• Output Level: Amp: 2.0V/10-KOhm
• Frequency Response: 20HZ – 20KHZ +/-2dB
• Talk over attenuation: -16dB
• S/N: Ratio (at 1KHZ)
• MIC: >75dB/22mV Input
• Phono:>55dB/17mV Input
• Line:>80dB/175mV Input
• CD: >80dB/1V Input
• Dimensions: (H)2’’X (W)9.3’’ X(D)4.9’’
10’’ 3-Channel Professional Mixer
• 1 x 1/4’’ DJ Mic Input
• 6 Line RCA Inputs
• 2 Convertible Turntable RCA
Inputs w/ Ground Screw
• Rotary High/Mid/Low EQ Controls for Each Channel
• Gain Control and CUE Switch for Each Channel
• Dual Mode Master LED Display Left/Right
or Cue Output LED Display Meters
• Master and Cue Meter Selector
• DJ Mic Auto Talkover with LED Indicator
PYD1919
•
High-Quality Components and
Rugged Construction
Provides 48V DC Phantom Power
Supply for Any Condenser Microphone
Professional 2-Stereo Channel DJ Mixer W/ USB SD Card Player
• Professional 2-Stereo Channel DJ Mixer
• Super-Smooth Ultra Slide Fades
• Dual MIC Input
• The MIC Bal. Control Two MIC Level
Balance Or Close One MIC Input
• The Phono/Line Switch Selects One Of The
Input Pairs On The Respective Channel
• Single Cd Input Channel
• Mono/Stereo Output Switch
• Output Meter: Indicate The Levels Of
The Left And Right Master Channels
• MIC Talkover
• Power Supply With Adaptor: 110v AC
• Input Sensitivity Impedance
PYD1030
•
• Mic Volume Control
• Rotary High and Low EQ Controls for Mic
• User Replaceable CH1/CH3 Crossfader
• Crossfader Reverse and Slope Selectors
• Master and Cue Volume Controls
• CUE MIX Control
• Master and Record RCA Outputs
• Headphones 1/4’’ Output
• AC Adapter Included 115/230V Switchable
• Dimensions: 10’’W x 3 9/32’’H x 12’’D
4-Channel Professional Mixer
• 2 Turntable/8 Line Level (CD, Cassette
Deck, MiniDisc, etc.)/2 Mic Inputs
• 10-band Graphic Equalizer for
Right and Left Channels
• Effects Send and Receive
• Effect and EQ on/off Switches
• Blue LED Level Display Meters
• Red Light Illuminated Power on/off Switch
• Blue Light Illuminated Channel Volume Control
• Top Mounted 12V BNC Connector for
Gooseneck Lamp (not included)
• Dual Mic Inputs with Talkover
• MIC 1 XLR- 1/4’’ Combo Jack
• Individual Rotary Controls and Kill Switches
for Mic Bass, Mid-range and Treble
• Independent Gain Controls for
each of the 4 Input sources
• Record Output
• Channel CUE Switch
• Assignable AB Crossfader
• Headphone Level Control
• Zone Output can be used as
second output for Booth
• Turntable Inputs convertible to
accept Line Level Inputs
• Headphone CUE/PGM Control
• Master and Zone Balance Controls
• Master/Zone and Stereo/Mono Switches
• User Replaceable Dual Railed Crossfader
• Amp Output Including 1/4’’ and RCA Jacks
• Master and Zone Channel Volume Controls
• Dimensions (WxDxH):19’’x 9 7/16’’ x 4 1/4’’
• 115/230 Voltage Switchable
DJ Mixers
77
PYD2808
19’’ Rack Mount 4 Channel Professional Mixer with Digital Echo and SFX
• 2 Turntable/8 Line Level (CD, Cassette
Deck, Minidisk, Etc)/ 2 Mic Inputs
• 7-Band Graphic Equalizer for
Right and Left Channels
• ECHO on/off Switch
• ECHO Delay/Repeat/Level Controls
• Six Digital Sound Effects
• Sound Effect SPEED and VOLUME Controls
• Dual Color LED Level Display
• Blue Light Illuminated Channel and
Master Volume Controls
• Top Mounted 12V BNC Connector for
Gooseneck Lamp (not included)
• Dual Mic Inputs with Talkover
• Mic 1 XLR-¼” Combo Input Jack
PEMP6
6 Channel Professional Stereo Console Mixer
• 6 Input Channels With Xlr Connection
• Low Noise, High Precision Microphone Preamplifiers
• 6 Trs ¼” Line Input
• Switchable Phantom Power 48v
• 6 Insert Odbu Inputs (Trs) Phone
• 2 Xlr Main Output
• 2 RCA REC Out
• 2 RCA Input
• 2 TRS ¼” In Line Monitor Out
• PFL (Pre-Fader Listen) Switches Allow
Isolated Monitoring Of Individual Channels
PMX1205
• 2 X 12 Segment L.E.D. Meters For
Visual Level Monitoring
• All Input Channels Feature Signal And Peak
Indicators For Visual Signal Monitoring
• Aux / Effect Sends / Returns
• PFL (Pre-Fader Listen) Switch
• AC 110/220 Adapter
• Dimensions: 16.1’’H x 12.8’’W x 4.7’’D
16 Channel Professional Digital (DSP) Console Stereo Mixer
• 16 input channels
• 10 MIC/4 Stereo/line inputs XLRTRS 1/4’’.Phone/RCA Inputs
• High Precision MIC Preamp
• 7 Band Stereo Graphic Equlizer
• Phantom Power Switch 48V
• 3-Band Cannel Equlizer (High-Mid-Low)
• Internal Digetal Effects Processor
• 2x12 Segment LED Meter For Level Monitoring
88
Visual Level Monitoring
• Built In Channel Audio Compressors With Their Threshold
• All Input Channels Feature Signal And Peak
Indicators For Visual Signal Monitoring
• Aux / Effect Sends / Returns
• PFL (Pre-Fader Listen) Switch
• Ac Adapter 110v/220v
• Dimensions:16.1’’h X 12.8’’w X 4.7’’d
12 Channel Professional Digital (DSP) Console Mixer
• 12 Inputs Channels
• 10 Mic + 4 Stereo Line Inputs
• 6 Buses (Stereo And 4 Groups)
• Low Noise, High Precision Mic Preamps
• Phantom Power Switch,& Insert I/0
• 3 – Band EQ On Each Channel (Mid Sweep) & HPF
• Illuminated. On / Off Switches
• Built – In Digital Effects
• 3 Aux Sends & 2 Stereo Aux Returns
PMX1609
• All Input Channels Features LED Peak
Indicators For Visual Signal Monitoring
• 3 – Band EQ(High – Mid – Low)
On Each Input Channel
• Illuminated On / Off Switches
• Mute Switch On Each Channel
• Aux / Effect
• Sends / Return
• 2 x 10 segment L.E.D. for visual level monitoring
• Mute switch on each channel
• Intuitive and comprehensive solo system
• Headphone output
12 Channel Digital DSP Console Mixer With Built-in Sound Effects
• 12 Inputs Channels
• 6 Mic + 4 Stereo Line Inputs
• 6 Buses (Stereo And 4 Groups)
• Low Noise, High Precision Mic Preamps
• Phantom Power Switch,& Insert I/0
• 3 – Band EQ On Each Channel (Mid Sweep) & HPF
• Illuminated. On / Off Switches
• Built – In Digital Effects
• 3 Aux Sends & 2 Stereo Aux Returns
• 2 X 12 Segment L.E.D. Meters For
PMX1209
• Booth Output
• Record Output
• CUE Level Control
• 1/4’’ Headphone Jack
• Assignable AB Crossfader
• Turntable Inputs convertible to
accept Line Level Inputs
• Headphone CUE/PGM Control
• CUE Switch for CH1/2/3/4 and Mic
• Master and Booth Volume Controls
• User Replaceable Dual Railed Crossfader
• Master Stereo/Mono and EQ on/off Switches
• Individual Rotary Controls for Mic Bass and Treble
• Amp Output Including ¼’’ and RCA Jacks
• Dimensions:19’’W x 9 15/32’’D x 3 3/16’’H
Console Mixers
• Peak LED Indicator Level Input
• Low noise,high precision mic preamps
• Illuminated ON/OFF switches
• Aux Effect sends/returns
• PFL(Pre-Fader LIsten)Switch
• Rack mount brackets included for ultimate flexibility
• AC 110/220 Adapter
• Dimension: 16.7’’ x 16.1’’ x 4.7’’
PAD10MXU
2 Channel Mini Mixer With USB Audio Interface
• Combo Input Connector Female/XLR And
¼ ‘’ Phone Jack For MIC/Line Inputs.
• Line 3/2 Stereo Line Inputs RCA Plugs,To
Connect Cd, Mp3 Tape Deck, Players.
• Main Out RCA Plugs To Connect The
Mixer, Receiver Or Amplifier.
• Signal Output Thru The Headphones
• Line/INSTR SW Input Select Switch Set
• Line 2/3 Level This Control Adjusts The
Volume Of Signal Input Of Line 2/3.
PAD20MXU
• Peak Led It Lights Up Went The Input
Signal Of Ch1 Is Too High.
• Ch 1 Gain This Control Adjust The
Volume Of Signal Input Of Ch1.
• Phantom Power Supply On XLR Connector Of Ch1.
• Phantom Led Indicates That Phantom Power Is On.
• USB Audio Interface
• Master Lets You Control Mixer’s
Overall Volume Level
• Clip Led Lights Up When Main Output Signal High
2 Channel Mini Mixer With USB Audio Interface
• Combo Input Connector Female/XLR And
¼ ‘’ Phone Jack For MIC/Line Inputs.
• Line 3/2 Stereo Line Inputs RCA Plugs,To
Connect Cd, Mp3 Tape Deck, Players.
• Main Out RCA Plugs To Connect The
Mixer, Receiver Or Amplifier.
• Signal Output Thru The Headphones
• Line/INSTR SW Input Select Switch Set
• Line 2/3 Level This Control Adjusts The
Volume Of Signal Input Of Line 2/3.
• Peak Led It Lights Up Went The Input
Signal Of Ch1 Is Too High.
PEXM810
• Ch 1 Gain This Control Adjust The
Volume Of Signal Input Of Ch1.
• Phantom Power Supply On XLR Connector Of Ch1.
• Phantom Led Indicates That Phantom Power Is On.
• USB Audio Interface
• Master Lets You Control Mixer’s
Overall Volume Level
• Clip Led Lights Up Went The Main
Output Signal Is Too High
• Monitor To Control Volume Output
Of The Monitor Jack.
• Power Led Indicates That The
8 Channel Professional Audio Mixer with Phantom Power
• Low noise 8 channel Mic/Line-mixer
• 4 mono inputs with COMBO-sockets, +48v
Phantom-power and balanced line inputs
• Stereo inputs can also be operated mono
• 3-band EQ for all input
• Aux-Send per channel for control-
PEXM1202
ling external effectors
• Stereo Aux-Return with balanced jack sockets
• Separate Main Mix , Booth and headphones outputs
• Tape inputs assignable to master
Booth / headphones
• Precise 10-LED meter
12 Channel Professional Audio Mixer with 3 Band EQ
• 3-band EQs for warm and musical sound
• 4 state-of-the-art Mic Preamps comparable
to stand-alone boutique preamps
• Premium ultra low-noise, high
headroom analog mixer
• 1 post fader FX per channel for external FX devices
• CD/tape inputs assignable to main mix or
PEXM1204
control room/phones outputs - Power: 110V
• Main mix outputs plus separate control
room,phones and stereo CD/tape outputs
• FX to control room function helps to monitor effect
signal via headphones and control room outpus
• Long-wearing 60-mm master fader
and sealed rotary controls
Studio Grade 24 Bit 12 Channel Stereo Mixer w/Built-In FX Processor/Digital Effects
• 3-band EQs for warm and musical sound
• Studio-grade 24-bit stereo FX processor
with 99 awesome presets including
reverb, chorus, flanger, delay, pitch
shifter and various multi-effects
• 4/6/8/10 Mic Preamps comparable to
stand-alone boutique preamps
• 2 aux sends per channel: 1 pre/post fader
switchable for monitoring/FX applications, 1 post
fader (for internal FX or as external send)
• Peak LEDs, mute/alt 3-4, solo and
PFL functions on all channels
• 2 subgroups w/ separate outputs
for added routing flexibility
• 2 multi-functional stereo aux returns with flexible routing
• Balanced main mix outputs with gold-plated XLR
connectors plus separate control
room, headphones and stereo tape outputs
• Control room/phones outputs w/
multi-input source matrix
• Tape inputs assignable to main mix or
control room/phones outputs
• 60-mm faders and sealed rotary controls
• Internal autorange power supply for maximum flexibility
(100 - 240 V~)
audio, superior transient response/low
power consumption for energy saving
• Rack mount brackets included for ultimate flexibility
• High-quality components and exceptionally fine finishing ensure long life
• Premium ultra low-noise, high headroom analog mixer
• Power Supply: 110V
• Dimensions: (H) 7.125’’ x (W) 12.875’’ x (D) 16’’
Console Mixers / USB Interfaces
99
PYD1270
12-Channel 2-Bus Console Mixer
• 4 Mono Input Channels (CH 1, 2, 3, 4)
• 4 Stereo Input Channels (CH 5/6, 7/8, 9/10, 11/12)
• Master & Phones/Control Room Level Controls
• EFX Send Level Control
• Stereo Headphones Jack
• Main & Control Room Out Jacks 1/4’’
• Mono Effects Send 1/4’’
• Effects Send Routable to Control Room
• Stereo Tape In & Out Jacks RCA
• Tape Input Routing to Control Room and/or Mix
• 5 Segment Dual LED Level Meters
• Mono Channel Section
PYD6070
6-Channel 2-Bus Console mixer
• 2 Mono Input Channels (CH 1, 2)
• 2 Stereo Input Channels (CH 3/4, 5/6)
• Master & Phones/Control Room Level Controls
• EFX Return Level Control
• Stereo Headphones Jack
• Main & Control Room Out Jacks 1/4’’
• Mono Effects Send, Stereo Return 1/4’’
• Stereo Tape In & Out Jacks RCA
• Tape Input Routing to Control Room and/or Mix
• 5 Segment Dual LED Level Meters
• Mono Channel Section
• Gain, Pan, Aux Send & Level Controls
PMXL8
ternal Effect and Monitoring
• Digital of the effect system inside
• Separate master Mix/ Control Room
and Headphone Outputs
• 2 Track Inputs Assignable to Master
Mix/ Control/ Headphone Output
• Highly Accurate 10 Segment bargraph Meters
• Power Amplifier Output Impedance: 2 x 800 Watts @ 4 Ohm
• 110 Volt/ 220 Volt Switchable
• Dimensions: 29(H) x 19(W) x 7(D) Inch
6 Channel 500 Watts Digital Powered Stereo Mixer W/DSP
• 6 Mono Input Channels
• Ultra low Noise Stereo Digital Effect Mixer, Rugged Design
• Power Supply Ensures Superior Signal Integrity
• Channel MIC/Line 6 Mono
• Channel EQ : 3 Band
• Main Buses: 1 Stereo
• Group Buses: 1 Stereo
10
10
• 2 AUX Send per Channel for External Effect and Monitoring
• Digital of the effect system inside
• Separate master Mix/ Control Room
and Headphone Outputs
• 2 Track Inputs Assignable to Master
Mix/ Control/ Headphone Output
• Highly Accurate 10 Segment bargraph Meters
• Power Amplifier Output Impedance: 2 x 500 W 4 Ohm
• 110 Volt/ 220 Volt Switchable
16 Channel 1600 Watts Digital (DSP) Powered Mixer
• 16 Mono Input channels w gold
plated XLR Balanced Inputs
• Ultra-Low noise discrete Mic Preamps
with +48 V Phantom Power
• 0/2 Stereo Input Channels w/ Balanced TRS Jacks
• Extremely High Headroom offering more dynamic range
• Balanced Inputs for highest signal integrity
• Ultra-Musical 3-Band EQ+FREQ on all Mono
Channels and 4-band EQ on all stereo channels
• Peak LED’s all Mono and Stereo Channels
• 2 AUX Send per Channel for Ex-
PMX608
• 3 Band EQ
• Peak Indicator
• +48V Phantom Power Switchable
• XLR Balanced Mic Input
• 1/4’’ TRS Balanced/Unbalanced Line
Input Stereo Channel Section
• 3 Band EQ
• Balance, Aux Send & Level Controls
• 1/4’’ TRS Balanced/Unbalanced Line Inputs
• AC Adapter Inlcuded: 110V
• Dimensions: 8.4’’W x 1.6’’H x 8.9’’D
8 Channel 500 Watts Digital (DSP) Powered Stereo Mixer
• 8 Mono Input channels w gold
plated XLR Balanced Inputs
• Ultra-Low noise discrete Mic Preamps
with +48 V Phantom Power
• 0/2 Stereo Input Channels w/ Balanced TRS Jacks
• Extremely High Headroom offering more dynamic range
• Balanced Inputs for highest signal integrity
• Ultra-Musical 3-Band EQ+FREQ on all Mono
Channels and 4-band EQ on all stereo channels
• Peak LED’s all Mono and Stereo Channels
PMXL16
• Gain, Pan, Aux Send & Level Controls
• 3 Band EQ
• Peak Indicator
• +48V Phantom Power Switchable
• XLR Balanced Mic Input
• 1/4’’ TRS Balanced/Unbalanced Line
Input Stereo Channel Section
• 3 Band EQ
• Balance, Aux Send & Level Controls
• 1/4’’ TRS Balanced/Unbalanced Line Inputs
• AC Adapter 110V
• Dimensions: 10.6’’W x 1.6’’H x 8.9’’D
Console Mixers
• Graphic EQ (MAIN): 2 x 7 Band
• Phantom Power: +48V
• Effect: 16DSP
• DJ Function
• Power Output: (4 Ohms) 500 Watts
• 110/220 Voltage Switchable
• Dimensions: 17.91’’H x 17.72’’W x 5.91’’D Inches
PMX808
8 Channel 600 Watts Digital Powered Stereo Mixer W/DSP
• 8 XLR On Mono Microphone/
Line Channels Mic Inputs
• 8 x 1/4” Line/High Impedance Input.
• RCA Tape Stereo Record Input
• Ultra low Noise Stereo Digital Effect Mixer, Rugged Design
• High Performance Mic Preamp With
Switchable Phantom Power
• 3-Band Equalizer With Low Mid And High Controls
• Led Meters For Visual Level Monitoring
• Power Supply Ensures Superior Signal Integrity
• Channel MIC/Line 8 Mono
PMX1208
12 Channel 1000 Watts Amplified Ultra Low Noise Stereo digital Effect
• 12 XLR Mono/Microphone/Line Channels Inputs
• 12 x 1/4’’ Line/High Impedence Inputs
• Ultra low Noise Stereo Digital Effect Mixer
• Rugged Design
• RCA Tape REC Output
• Power Supply Ensures Superior Signal Integrity
• Channel MIC/Line 12 Mono
• 3 Band Equlizer With Low Mid And High Controls
• LED Meters For Visual Level Monitoring
• Main Buses: 1 Stereo
PMX1608
• Effect: 16 (DSP)Digital Stereo Processing
• DJ Function
• Power Output:1200 Watts At 4 Ohms
• Headphone Monitor Output
• 110/220 Voltage Switchable
• Dimension: 30.91’’ x 17.72’’ x 5.91’’
150 Watt 4 Channel Powered PA Mixer / Amplifier
• 4 Balanced Microphone Inputs
with Phantom Power.
• 4 x 1/4” Line/High Impedance Input.
• Tape/CD Line Inputs
• Built-In Reverb with Individual Control
• Volume Control For Each Channel.
PMX601
• Group Buses: 1 Stereo
• Graphic EQ (MAIN): 2 x 7 Band
• High Performane Mic Preamp With Phantom Power
• Phantom Power: +48V
• Effect: 16 Digital Stereo Processing (DSP)
• DJ Function
• Power Output:1000 Watts at 4 Ohms
• 110/220 Voltage
• Dimension: 25.71’’ x 17.72’’ x 5.91’’
16 Channel 1200 Watts Ultra Low Noise Stereo digital Effect Mixer With
• 16 XLR ON Mono Microphone/
Licne Channels Mic Input
• 16 x 1/4’’ Line/High Impedance Input
• RCA Tape REC Output
• Ultra low Noise Stereo Digital Effect Mixer
• Rugged Design
• Power Supply Ensures Superior Signal Integrity
• Channel MIC/Line 16 Mono
• Channel EQ : 3 Band
• Main Buses: 1 Stereo
• Group Buses: 1 Stereo
• Graphic EQ (MAIN): 2 x 7 Band
• Phantom Power: +48V
PMX401
• Channel EQ : 3 Band
• Main Buses: 1 Stereo
• Group Buses: 1 Stereo
• Graphic EQ (MAIN): 2 x 7 Band
• Phantom Power: +48V
• Effect: 16DSP
• DJ Function
• Power Output: (4 Ohms) 600 Watts
• 110/220 Voltage Switchable
• Phones Output
• Dimension: 20.51’’ x 17.72’’ x 5.91’’
• Equalizer Control For Each Input
• Master EFFX Control with Echo
• Line Audio RCA Output
• Maximum Power: 150 Watts/4 Ohms
• Power Output 110V
• Dimensions: 20’’W x 5.25’’H x 9.25’’D
150 Watt 6 Channel Powered PA Mixer/Amplifier
• 6 Balanced Microphone Inputs
with Phantom Power.
• 6 x 1/4” Line/High Impedance Input.
• Microphone Input Impedance:600
Ohms ,Input Level:-60db
• High Impedance Input :10k Ohms Input Level:-20db
• Tape Input Impedance:10k Ohms ,Input Level:-20db
• Power Output 150 Watts
• Rec Output Impedance: 1k Ohms
Output Level:-10db
• 5-Band Graphic Equalizer
• Each Channel Tone Control Effect Control
• Rec Output
• Master Volume Control
• Channel Tone Adjust (High/Low±15db)
• Aux/Tape/Effect Feedback Input
• Effect Send
• Phones Output
Console Mixers / Powered Mixers
1111
PMX801
200 Watt 8 Channel Powered PA Mixer/Amplifier
• 8 x 1/4” Line/High Impedance Input.
• 8 XLR Mic Inputs With Phantom Power
• RCA Input (Left/Right Ch.)
• REC RCA Output (L/R)
• Bass-Treble Control Each Channel
• Return Sound Effect Control For Each Channel
• Tape Stereo Input
• Microphone Input Impedance:600
Ohms ,Input Level:-60db
• High Impedance Input :10k Ohms Input Level:-20db
• Tape Input Impedance:10k Ohms ,Input Level:-20db
PMX804
8 Channel 400 Watts Professional Powered PA Mixer/Amplifier
• 8 Mono Input Channel
• XLR input
• Balanced Line Input
• 2 stereo Input Channels With Balanced Trs Jacks
• Peak Led Mono And Stereo Channels
• 1/2’’ Aux Effects Send/Return Loop
PMX1006
• 1/2’’ Aux Effects Send/Return Loop
• 7 Band Mono Or Stereo Equalizer
• Total Power 600 Watts 4 Ohms
• Dimension 21’’H x 20’’W x 12.59’’D
• 110/220 Volt Switchable
• Weight 30.86 LBS
12 Channel 1000 Watts Powered Mixer
• 12 Channel
• INPUT PAD SWITCH, PAD-20dB
• 3-band tone control ±15dB
• High 12 KHz, Mid 2 KHz Low 100Hz
• Mon, Effect, Main level control
• Master controller
• Dual 5-Band led level display
• Dual 7-Band Graphic equalizer ±12dB
• Digital effect
• Effect External foot switch
• Phantom power +48V supply
• 500 Watts + 500 Watts power amplifier
• Stereo output or bridge output
12
12
• Stereo output or bridge output
• Effect output
• Tape record output
• Mon output
• Main output
• Power output
• Effect foot switch jacks
• 8-Line low-z balance input
• 10-Line high-z unbalance input
• AUX input
• Stereo tape input
• 110/220 Voltage Switchable
• Dimension: 21.65’’ x 12.20’’ x 11.61’’
12 Channel Powered 600 Watts PA Mixer/Amplifier
• 12 Channel Input Channels
• Balanced Line Inputs
• XLR input
• Two Stereo Input Channels
• Balanced Trs Jacks
• Peak Led Mono And Stereo Channels
PMX1206
• 7 Band Mono Or Stereo Equalizer
• Total Power Output 400 Watts
• 17.32’’H x 10.23’’W x 10.82’’D
• 110/220 Voltage Switchable
• 26 LBS
10 Channel 800 Watts Powered Stereo Mixer
Specifications
• 10 Channel
• INPUT PAD SWITCH, PAD-20dB
• 3-band tone control ±15dB
• High 12 KHz, Mid 2 KHz Low 100Hz
• Mon, Effect, Main level control
• Master controller
• Dual 5-Band led level display
• Dual 7-Band Graphic equalizer ±12dB
• Digital effect
• Effect External foot switch
• Phantom Power +48V
• 400 Watts + 400 Watts power amplifier
PMX1204
• Power Output 200 Watts
• Rec Output Impedance: 1k Ohms
Output Level:-10db
• 5-Band Graphic Equalizer
• Master Volume Control
• Channel Tone Adjust (High/Low±15db)
• Aux/Tape/Effect Feedback Input
• Effect Send
• Phones Output
• Power Output 110V
• Dimensions: 20’’W x 8’’H x 12’’D
Powered Mixers
• Effect output
• Tape record output
• Monitor output
• Main output
• Power output
• Effect foot switch jacks
• 8-Line low-z balance input
• 10-Line high-z unbalance input
• AUX input
• Stereo tape input
• 110/220 Voltage Switchable
• Dimension: 23.82’’ x 12.20’’ x 11.61’’
PMX1406
14 Channel 1200 Watts Digital Powered Mixer W/DSP
• 14 Channel
• INPUT PAD SWITCH, PAD-20dB
• 3-band tone control ±15dB
• High 12 KHz, Mid 2 KHz Low 100Hz
• Mon, Effect, Main level control
• Master controller
• Dual 5-Band led level display
• Dual 7-Band Graphic equalizer ±12dB
• Digital effect
• Effect External foot switch
• Phantom power +48V supply
• 600 Watts + 600 Watts Power amplifier
• Stereo output or bridge output
PMX402M
4 Channel 400 Watts Powered Mixer w/ MP3 USB Input
• Master output: 400 Watts 4 Ohms
• With USB 2.0 Terminal and LCD
• 5-Band graphic equalizer
• Each channel tone control
• Effect control
• TAPE input, REC output
• Channel tone adjust (high/low+/-15dB)
PMX602M
• AUX/TAPE/effect feedback input
• Effect send
• Master volume control
• Phantom + 15V
• 110/220 voltage switchable
• Dimension: 17.32’’ x 12.01’’ x 7.87’’
8 Channel 800 Watts Powered Mixer w/MP3 Input
• Master output: 800 Watts 4 Ohms
• With USB 2.0 Terminal and MP3 LCD Display
• 5-Band graphic equalizer
• Each channel tone control
• Effect control
• TAPE input, REC output
• Channel tone adjust (high/low+/-15dB)
PMX830I - PMX630I
•
•
•
•
•
•
•
•
•
•
•
• AUX/TAPE/effect feedback input
• Effect send
• Master volume control
• Phantom + 15V
• 110/220 voltage switchable
• Dimension: 15.75’’ x 12.01’’ x 7.87’’
6 Channel 600 Watts Powered Mixer w/ MP3
• Master output: 600 Watts 4 Ohms
• With USB 2.0 Terminal and MP3 LCD Display
• 5-Band graphic equalizer
• Each channel tone control
• Effect control
• TAPE input, REC output
• Channel tone adjust (high/low+/-15dB)
PMX802M
• Effect output
• Tape record output
• Monitor output
• Main output
• Power output
• Effect foot switch jacks
• 8-Line low-z balance input
• 10-Line high-z unbalance input
• AUX input
• Stereo tape input
• 110/220 Voltage Switchable
• Dimension: 25.98’’ x 12.20’’ x 11.61’’
• AUX/TAPE/effect feedback input
• Effect send
• Master volume control
• Phantom + 15V
• 110/220 voltage switchable
• Dimension: 20.28’’ x 12.01’’ x 7.87’’
6 Channel & 8 Channel 800 Watt Professional Mixer - iPod Dock, MP3 Player Input, SD/USB Flash
iPod Dock
Effect Control & Send
Master Volume Control
TAPE Input & REC Output
5-Band Graphic Equalizer
110/220 Voltage Switchable
Tone Controls for Each Channel
AUX/TAPE/EFFECT feedback Input
SD and USB Flash Memoy Card Readers
Channel Tone Adjust (High/Low +/-15dB)
Built-in USB 2.0 Terminal and MP3 LCD Display
Powered Mixers
13
13
PMX408M
6 Channel 600 Watts Powered Mixer w/MP3 & USB Input
• Power Output: STEREO 2 x 300 Watts
• With USB 2.0 Terminal And LCD MP3 Display
• Channel: 6 Mono
• Channel EQ: High Low 2 Band
• Graphic EQ (Main): 7 Band
PEXM801
10 Channel Balanced Studio Grade IMP Audio Mixer with Pre-Amp
• 2 new state-of-the-art, studiograde IMP ‘’Invisible’’ Mic
Preamps
• 130 dB dynamic range for 24-bit, 192 kHz
sampling rate inputsUltra-wide 60 dB gain range
• Lowest possible distortion
0.0007% (20 Hz - 20 kHz)
• Integrated 24-bit digital stereo FX
processor with 100 awesome
• Effective,3-band EQ plus switchable low-cut filter
P1001AT
• Auto Station Seek Function
• Digital Fluorescent Output Display
• 1 RCA Dedicated for Preamp Output
• 1 RCA Dedicated for Record Line Output
• 2 Mono RCA Dedicated for Subwoofer Output
• Separate Gain Control of Pre-Amp &
Subwoofer
• Dimensions: 19’’ W x 3.1’’ H x 13’’ D
• AM/FM Quartz Synthesized
1000 Watts Hybrid Receiver & Pre-Amplifier W/AM-FM Tuner/Ipod Docking
• Ipod docking station (Ipod not included)
• Powers 4 loudspeakers
• Separate gain control for preamp and subwoofer
• 1000 watts peak power
• 450 watts @ 2 ohms
• 360 watts @ 4 ohms
• 200 watts @ 8 ohms
• Inputs: RCA (2 audio sources)
• Outputs: Banana binding post (to speakers)
• 1 RCA dedicated for record line output
14
14
• Auto Station Seek Function
• Digital Fluorescent Output Display
• 1 RCA Dedicated for Preamp Output
• 1 RCA Dedicated for Record Line Output
• 2 Mono RCA Dedicated for Subwoofer Output
• Separate Gain Control of Pre-Amp &
Subwoofer
• Dimensions: 19’’ W x 3.1’’ H x 13’’ D
• AM/FM Quartz Synthesized
3000 Watt Hybrid Pre-Amplifier with AM/FM Tuner - Audio Inputs & Outputs
• 850 Watt @ 2 Ohms
• 550 Watt @ 4 Ohms
• 300 Watt @ 8 Ohms
• Auto Seek and Store
• 110-220V Switchable
• Digital Karaoke System
• 3,000 Watt Peak Power
• Weight: 14.3 lbs (6.5 kg)
• Mounts into 19-Inch Rack
P1002AI
• Digital Fluorescent Output Display
• iPod / MP3 Player Input with Cable
• 1 RCA Dedicated for Preamp Output
• 1 RCA Dedicated for Record Line Output
• Outputs: Banana Binding Post (to Speakers)
• 2 Mono RCA Dedicated for Subwoofer Output
• Separate Gain Controls for Preamp and Subwoofer
• Dimensions: 19’’w x 3.1’’h x 13’’d (483 x
2000 Watt Hybrid Pre-Amplifier with AM/FM Tuner - Audio Inputs & Outputs
• 600 Watt @ 2 Ohms
• 450 Watt @ 4 Ohms
• 240 Watt @ 8 Ohms
• Auto Seek and Store
• 110-220V Switchable
• Digital Karaoke System
• 2000 Watt Peak Power
• Weight: 14.3 lbs (6.5 kg)
• Mounts into 19-Inch Rack
P3001AT
• Clip LEDs on all mono channels
• 10 balanced high-headroom line inputs
with +4/-10 level selection
• FX send control per channel
• Main mix outputs plus separate control room,
phones and stereo CD/tape outputs
• CD/tape inputs assignable
• Switchable +48 V phantom power
• Dimensions: 4’’ x (W) 9.3’’ x (D) 13.2’’
• 110v Power Supply
1000 Watts Hybrid Pre-Amplifier w/AM/FM Tuner
• 450 Watts @ 2 Ohms
• 360 Watts @ 4 Ohms
• 200 Watts @ 8 Ohms
• 110-220V Switchable
• 1000 Watt Peak Power
• Auto Radio Station Seek
• Inputs: RCA (2 Sudio Sources)
• AM/FM Quartz Synthesized Tuner
P2001AT
• Phantom Power: +48V
• ECHO: DSP
• AC 110v/220v Switchable
• Dimensions: 17.32’’H X 10.23’’W X 10.82’’D
• Weight: 11.5KG
• 2 mono RCA dedicated for subwoofer output
• 1 RCA dedicated for preamp output
• Digital fluorescent output display meter
• iPod / MP3 input with cable
• 110-220V Switchable
• AM/FM Quartz Synthesized Tuner
• Auto Station Seek
• Dimensions: 19”w x 3.1”h x 13”d
• Weight: 14.3 lbs
Powered Mixers / Hybrid Pre-Amplifiers
P2002ABTI
2000 Watts Hybrid Receiver & Pre-Amplifier W/AM-FM Tuner/Ipod Docking Station & Bluetooth
• Ipod docking station (Ipod not included)
• Bluetooth function
• Powers 4 loudspeakers
• Separate gain control for preamp and subwoofer
• 2000 watts peak power
• 600 watts @ 2 ohms
• 460 watts @ 4 ohms
• 240 watts @ 8 ohms
• Inputs: RCA (2 audio sources)
• Outputs: Banana binding post (to speakers)
P3002AI
3000 Watts Hybrid Receiver & Pre-Amplifier W/AM-FM Tuner/Ipod Docking Station
• Ipod docking station (Ipod not included)
• Powers 4 loudspeakers
• Separate gain control for preamp and subwoofer
• 3000 watts peak power
• 800 watts @ 2 ohms
• 550 watts @ 4 ohms
• 300 watts @ 8 ohms
• Inputs: RCA (2 audio sources)
• Outputs: Banana binding post (to speakers)
• 1 RCA dedicated for record line output
P1501ATU
• 2 mono RCA dedicated for subwoofer output
• 1 RCA dedicated for preamp output
• Digital fluorescent output display meter
• iPod / MP3 input with cable
• 110-220V Switchable
• AM/FM Quartz Synthesized Tuner
• Auto Station Seek
• Dimensions: 19’’w x 3.1’’h x 13’’d
• Weight: 17.2 lbs
1500 Watts Hybrid Pre Amplifier w/ AM/FM Tuner/ USB
• Separate gain control for preamp and subwoofer
• 1500 Watts Peak Power
• 500 Watts @ 2 ohms
• 400 Watts @ 4 Ohms
• 220 watts @ 8 ohms
• Inputs: RCA (2 Audio Sources)
• Outputs: Banana Binding Post (to Speakers)
• 1 RCA dedicated for Preamp output
• 2 Mono RCA dedicated for Subwoofer Output
P3201ATU
• 1 RCA dedicated for record line output
• 2 mono RCA dedicated for subwoofer output
• 1 RCA dedicated for preamp output
• Digital fluorescent output display meter
• iPod / MP3 input with cable
• 110-220V Switchable
• AM/FM Quartz Synthesized Tuner
• Auto Station Seek
• Dimensions: 19’’w x 3.1’’h x 13’’d
• Weight: 15.4 lbs
• 1 RCA dedicated for Preamp Output
• Digital Flourescent Output Display Meter
• iPod/ MP3 Input with Cable
• USB Reader Function
• Dimensions: 19” (W) x 3.5”(H) x 13”(D)
• Weight: 14.7 Lbs
• 110/220V Switchable
• AM/FM Quartz Synthesized Tuner
3000 Watts Hybrid Pre Amplifier w/ AM/FM Tuner/ USB
• Separate gain control for preamp and subwoofer
• 3000 Watts Peak Power
• 800 Watts @ 2 ohms
• 550 Watts @ 4 Ohms
• 300 watts @ 8 ohms
• Inputs: RCA (2 Audio Sources)
• Outputs: Banana Binding Post (to Speakers)
• 1 RCA dedicated for Preamp output
• 2 Mono RCA dedicated for Subwoofer Output
• 1 RCA dedicated for Preamp Output
• Digital Flourescent Output Display Meter
• iPod/ MP3 Input with Cable
• USB Reader Function
• Dimensions: 19” (W) x 3.5”(H) x 13”(D)
• Weight: 14.7 Lbs
• 110/220V Switchable
• AM/FM Quartz Synthesized Tuner
PWMA3003T - PWMA2003T - PWMA1003T
1000, 2000 & 3000 Watts Hybrid Pre-Amplifier W/AM-FM Tuner/USB/Dual Wireless Mic
• Dual VHF High Band Wireless Microphones
• Inputs: RCA (2 Audio Sources)
• Outputs: Banana Binding Post
• 1 RCA Dedicated For Record Line Output
• 2 Mono RCA Dedicated For Subwoofer Output
• 1 RCA Dedicated For Preamp Output
• Separate Gain Control For
Preamp And Subwoofer
• Digital Fluorescent Output Display Meter
• Ipod / MP3 Input With Cable
• USB Reader Function
• Removable Rack-Mount Brackets
• 110-220V Switchable
• AM/FM Quartz Synthesized Tuner
• Auto Station Seek
Hybrid Pre-Amplifiers
15
15
PEA4000
Professional 4000 Watts Stereo Power Amplifier
• 4000 Watts Max Peak Power Amplfier
• Two Channels Stereo Or Bridge (Mono) Output
• Independent Volume Control For Each Channel
• Balanced XLR And ¼’’ TRS Inputs
• High Speed Coolng Fan
• Lowest Noise –Smooth Operation
• Signal And Clip Led Indicators For
Protection And Performance
• Speakon-Binding Post Speaker Terminals
• Thermal And Overload Protection
• Power Output: 260W (RMS, Stereo, 8 OHM)
• Power Output: 400W (RMS, Stereo, 4OHM)
PEA6000
Professional 6000 Watts Stereo Power Amplifier
• 6000 Watts Max Peak Power Amplfier
• Two Channels Stereo Or Bridge (Mono) Output
• Independent Volume Control For Each Channel
• Balanced XLR And ¼’’ TRS Inputs
• High Speed Coolng Fan
• Lowest Noise –Smooth Operation
• Signal And Clip Led Indicators For
Protection And Performance
• Speakon-Binding Post Speaker Terminals
• Thermal And Overload Protection
• Power Output: 520W (RMS, Stereo, 8 OHM)
• Power Output: 800W (RMS, Stereo, 4OHM)
PEXA3000
• Dual Output Level Controls
• High Performance Ring Transformer
• Soft Start Limiter
• Ground Lift Switch
• LED Indicator Lights
• Heavy Duty Fan Cooled Aluminum Heatsink
• 110 220Volt Power Supply
• Dimensions: 16.25”D x 19”W x 5.75”H
19’’ Rack Mount 8000 Watts Professional Power Amplifier w/ Digital SMT Technology
• 8000 Watts Peak Power
• 4000 Watts x 2 @ 2 Ohms
• 2000 Watts x 2 @ 4 Ohms
• 1000 Watts x 2 @ 8 Ohms
• LCD Display - Power, Level, Temperature,
• Protection, Working Mode, Limiter
• SMT Technology Circuitry
• Switchable Stereo & Bridged Modes
16
16
• Dual Output Level Controls
• High Performance Ring Transformer
• Soft Start Limiter
• Ground Lift Switch
• LED Indicator Lights
• Heavy Duty Fan Cooled Aluminum Heatsink
• 110 220 Volt Power Supply
• Dimensions: 16.25’’D x 19’’W x 5.75’’H
19’’ Rack Mount 5000 Watts Professional Digital Power Amplifier w/SMT Technology
• 5000 Watts Peak Power
• 2500 Watts x 2 @ 2 Ohms
• 1250 Watts x 2 @ 4 Ohms
• 625 Watts x 2 @ 8 Ohms
• LCD Display - Power, Level, Temperature,
• Protection, Working Mode, Limiter
• SMT Technology Circuitry
• Switchable Stereo & Bridged Modes
PEXA8000
• Power Output: 2000W (Bridged, 8 OHM)
• Power Output: 4000W (Max Peak)
• Distortion (Typical): 10K Ohm Balance :> 20K Ohm
• S/N: >103Db
• Frequency Response: 20Hz-20
KHz, +0/-0 Specification.5dB
• Raise Rate: >45V/Us
• Damping Factor: >220
• Cross Talk: <-78db @ 8 OHM
• Power Supply:115V-60Hz
• Dimensions: 3.5’’H X 19’’W X 15.9’’D
19’’ Rack Mount 3000 Watt Professional Power Amplifier w/ Digital SMT Technology
• 3000 Watts Peak Power
• 1500 Watts x 2 @ 2 Ohms
• 750 Watts x 2 @ 4 Ohms
• 375 Watts x 2 @ 8 Ohms
• LCD Display - Power, Level, Temperature,
• Protection, Working Mode, Limiter
• SMT Technology Circuitry
• Switchable Stereo & Bridged Modes
PEXA5000
• Power Output: 800W (Bridged, 8 OHM)
• Power Output: 4000W (Max Peak)
• Distortion (Typical): 10K Ohm Balance :> 20K Ohm
• S/N: >103Db
• Frequency Response: 20Hz-20
KHz, +0/-0 Specification.5dB
• Raise Rate: >45V/Us
• Damping Factor: >220
• Cross Talk: <-78db @ 8 OHM
• Power Supply:115V-60Hz
• Dimensions: 3.5’’H X 19’’W X 15.9’’D
Power Amplifiers
• Dual Output Level Controls
• High Performance Ring Transformer
• Soft Start Limiter
• Ground Lift Switch
• LED Indicator Lights
• Heavy Duty Fan Cooled Aluminum Heatsink
• 110 Volt Power Supply
• Dimensions: 16.25”D x 19”W x 5.75”H
PPA200
19’’ Rack 2000 Watt Professional DJ Power Amplifier
• 1000 Watts x 2 Power Amplifier
• Dual Output Level Controls and Illumination
• Protection Indicator
• Power On/Off Switch
• Stereo/Mono Selector
• Stereo or Bridged Power Into 4 or 8 Ohms
• Dual RCA Combo Inputs
• Binding Post Outputs
PPA300
19’’ Rack 3000 Watt Professional DJ Power Amplifier
• 1500 Watts x 2 Power Amplifier
• Dual Output Level Controls and Illumination
• Protection Indicator
• Power On/Off Switch
• Stereo/Mono Selector
• Stereo or Bridged Power Into 4 or 8 Ohms
• Dual RCA Combo Inputs
• Binding Post Outputs
PPA450
• Blue Color LED Display
• Ground Lift Switch
• AC Accessory Inlet
• 110/220 Voltage Selector
• Heavy Duty Fan Cooled Aluminum Heatsink
• Dimensions: 3 15/32” H x 19” W x 10 11/16” D
• Weight 20.28 LBS
19’’ Rack Mount 2100 Watt Professional Power Amplifier
• 230 + 230 Watts @ 8 Ohms
• 460 + 460 Watts @ 4 Ohms
• 920 + 920 Watts @ 2 Ohms
• Soft Start limiter
• Protection Indicator
• Power On / Off Switch
• Dual 1/ and Dual RCA Inputs
• Stereo Mono Parallel Selector
• High Quality Ring Transformer
PQA3100
• Blue Color LED Display
• Ground Lift Switch
• AC Accessory Inlet
• 110/220 Voltage Selector
• Heavy Duty Fan Cooled Aluminum Heatsink
• Dimensions: 3 15/32” H x 19” W x 10 11/16” D
• Weight 18.52 LBS
19’’ Rack 4500 Watt Professional DJ Power Amplifier
• 2250 Watts x 2 Power Amplifier
• Dual Output Level Controls and Illumination
• Protection Indicator
• Power On/Off Switch
• Stereo/Mono Selector
• Stereo or Bridged Power Into 4 or 8 Ohms
• Dual RCA Combo Inputs
• Binding Post Outputs
PQA2100
• Blue Color LED Display
• Ground Lift Switch
• AC Accessory Inlet
• 110/220 Voltage Selector
• Heavy Duty Fan Cooled Aluminum Heatsink
• Dimensions: 3 15/32” H x 19” W x 10 11/16” D
• Weight 16.76 LBS
• Stereo Power into 4 Or 8 Ohms
• Dual Output Level Controls and Illumination
• 1050 Watts x 2 Power Amplifier
525 Watts x 2 RMS
• Outputs: Dual Speakon - 1/4’’ - Banana Plugs
19’’ Rack Mount 3100 Watts Professional Power Amplifier
• 1550 Watts x 2 Power Amplifier 775 Watts x 2 RMS
• 380 + 380 [email protected] 8 Ohms
• 760 + 760 Watts @ 4 Ohms
• 1520 + 1520 Watts @ 2 Ohms
• 2550 Watts RMS
• Protection Indicator
• Dual 1/ and Dual RCA Inputs
• Outputs: Dual Speakon / 1/4’’ /
Banana Plugs Speaker
• Dual Output Level Controls and Illumination
• High Quality Ring Transformer
• Soft Start limiter
• Power On / Off Switch
• Stereo Mono Parallel Selector
• Stereo Power into 4 Or 8 Ohms
• Led Display
• Ground lift Switch
• Heavy Duty Fan Cooling Aluminum Heatsing
• 115/230 Voltage Selector
• Dimensions: 5.75’’H x 19’’W x 14.37’’D
Power Amplifiers
17
17
PQA4100
19’’ Rack Mount 4100 Watts Professional Power Amplifier W/Digital SMT Technology
• 2050 Watts x 2 Power Amplifier 1025 Watts x 2 RMS
• 500 +500 @ 8 Ohms
• 1000 + 1000 @ 4 Ohms
• 2000+2000 @ 2 Ohms
• Protection Indicator
• Dual 1/ and Dual RCA Inputs
• Outputs: Dual Speakon / 1/4’’ /
Banana Plugs Speaker
PQA5100
• Dual Output Level Controls and Illumination
• High Quality Ring Transformer
• Soft Start Limiter
• Power On / Off Switch
• Stereo Mono Parallel Selector
• Stereo Into 4 Or 8 Ohms
• LED Display
• Ground Lift Switch
• Heavy Duty Fan Cooling Aluminum Heatsing
19’’ Rack Mount 5100 Watts Professional Power Amplifier W/Digital SMT Technology
• 2550 Watts x 2 Power Amplifier 1275 Watts x 2 RMS
• 600 + 600 Watts @ 8 Ohms
• 1200 +1200 Watts @ 4 Ohms
• 2400 + 24000 Watts @ 2 Ohms
• Protection Indicator
• Dual 1/ and Dual RCA Inputs
• Outputs: Dual Speakon / 1/4’’ /
PSA2000
Banana Plugs Speaker
• Dual Output Level Controls and Illumination
• High Quality Ring Transformer
• Soft Start limiter
• Power On / Off Switch
• Stereo Mono Parallel Selector
• Stereo Power into 4 Or 8 Ohms
• Led Display
1U Rack Mount 2000 Watts Power Stereo Amplifier
• Independent Volume Control For Each Channel
• Power Output: 100W X 2 RMS (8 Ohms)
• Power Output: 200W X 2 RMS (4 Ohms)
• Power Output: 400W (Bridge, 8 Ohms)
• Power Output: 2000W Max Peak
• Total Harmonic Distortion: Less Than 0.1%
• Input Sensitivity & Impedance:
0.775V RMS, 10K Ohms
• Signal-To-Noise Ratio: More Then 100dB
• Frequency Response: +/-0.5dB, 20Hz-20 KHz
• Balanced XLR And ¼ “TRS Inputs
• High Speed Cooling Fan
• Lowest Noise –Smooth Operation
• Signal And Clip Led Indicators For
Protection And Performance
• Binding Post Speaker Terminals
• Thermal And Overload Protection
• Power Supply: 115V-60Hz /
PTA1004U - PTA1404U - PTA3004U
1000, 2000 & 3000 Watts Professional Power Amplifiers With USB/SD Cards / Blue LCD Display w/ Built in Crossover
•
•
•
•
•
•
•
•
•
Two-Speed Fan
Two Channels
High-Out Jacks
Low cut switch
Input Level:+4db
Distortion:=1.0%
Two Way Crossover
Speakon Connectors
Thru/Low Out jacks
PCO800
•
•
•
•
•
•
•
•
•
19’’ Rack Mount 1800 Watt Power Conditioner w/ 8 Outlets
• Triple Mode Varistor Surge And Spike Protection
• Eight Rear Outlets (With Room For 4 ‘’ Wall Warts’’)
Controlled By A Front Panel Switch
• 15 Amp Rating (1800 W) With Rear
Panel Circuit Breaker (UL)
18
18
110/220 Volt Switchable
Signal/Noise Ratio:=102db
3.5mm Aux CD/MP3 Input Jack
Sub- Sonic (Low Cut) Filter
2x5 Led Input Level Indicator
Input Impedance: Balance 20ko
Crossover switch (150Hz X over)
Dual Binding Post Speaker Output
Overload And Protection Indicator
Power Amplifiers
• Rugged Single Rack Space Metal
Housing For Maximum Reliability
• Power:110V-60Hz
• Dimensions: 19’’W X 1 3/4’’H X 7 3/4’’D
• Weight: 5.20 Lbs
•
•
•
•
•
•
•
Thru/Low Out And High Out ¼’’ Jacks
Blue Luxury LCD Display for MP3 Function
Three Speakon Connectors
(CH A/CH B/Bridge)
Frequency Response:20hz-20khz
Less Than±0.5db
Combo Inputs Connector Xlr/1/4’’Phone
Double-Decoder MP3 Function compatible w/
USB Memory Sticks/ MP3/WMA Files
PCO820
19’’ Rack Mount 8 Outlets 1800 Watt Power Conditioner W/Voltage Meter
• Triple Mode Varistor Surge And Spike Protection
• Eight Rear Outlets (With Room For 4 ‘Wall
Warts’) Controlled By A Front Panel Switch
• 15 Amp Rating (1800 W) With Rear
Panel Circuit Breaker (UL)
• Two Added Front Panel Slide-Out,
Swiveling Lights For Rack
• Illumination And Dimmer Controls
To Adjust Lamp Brightness
PCO850
•
•
•
•
•
•
• Large LED Numeric Meter That Displays
Incoming AC Line Voltage And 2 Voltage Condition
Indicators Standard Voltage And Over Voltage
• Rugged Single Rack Space Metal
Housing For Maximum Reliability
• Dimensions: 19 ‘’ W X 1 3/4 ‘’H X 8 3/4 ‘’D
• Weight: 6 Lbs
• Power: 110V-60Hz
Standard Level Power Conditioning with Wall Wart Spacing, Pullout Lights, 15 Amp & 9 Outlets
8 Rear-Panel Outlets & 1 Front-Panel Outlet
AC Noise-Filtering Reduces Radio Frequency
(RFI) & Electromagnetic Interference (EMI)
Rear Outlets Have Been Spaced to Accomodate
Even the Bulkiest of Wall Warts and Adapters
Equipment Protection: Standard Level Spike
& Surge Protection Ensures afety & Clean Power
15 Amp Rating with Circuit Breaker
Spike & Surge Protection Ensures
PDBC10
•
•
•
8 Outlet Rack Mount Power Supply Center w/Each Outlet Switch
• Can offer 8 power supply for other units
• Built-In Switch For Each Outlet
• Rack mount brackets
PDBC50
•
•
•
• 110/220V compitable
• 19’’L X 3.1’’W X 1.7’’H
Rackmount PDU Power Strip - 8-Outlet 15A 1800VA
110 Volt
Rugged Metal Housing
Requires 1U of Rack Space
PDBC60
•
•
•
•
•
• Styles: Bar And Dot
• Can Offer 8 Power Supplies For Other Units
• 3 Pins AC Outlets
• 110/220V Switchable
• Dimensions: 16.8”W X 7.1”H X 2.4”D
• Weight: 2.9 Lbs
1U Rack Mount Power Supply Strip 15A 1800VA
A Must for Every DJ
AC Power Center Eliminates Extension
Cords and Wires
Nine Power Switches with Blue
PFN31
Manages AC Power for Connected Devices
8 Rear-Panel Outlets & 1 Front-Panel Outlet
8 Outlet Power Supply Center W/ DB Display
• Dual L.E.D Signal Level Meter
• Level Input Signal Control
• 2 RCA Input Plug
• 2 RCA Output Plug
• Two Kinds Of Signal Input Volume Display
• L.E.D. Mode Selector
PDBC70
2 Retractable LED Front-Panel
LightFixtures with Dimmer Control
Equipment Stays Safe & Power Stays Clean Two Retractable Incandescent Light
Fixtures with Dimmer Control for Custom
& Convenient Rack Illumination
•
Illumination Located on Front Panel
The Perfect Solution for Switching and Managing
Light and Sound Equipment
19’’ Rack Mount Cooling Fan System
• Complete kit for three fan unit that will quietly cool
your cabinet and any other multimedia centers
• Three 90MM ball bearing metal case fan included
• Easy to install
• Screws are included for install
• Power Source 110V
• Dimensions:19’’X 4.3’’ X 1.7’’
Signal Processors / Power Conditioners / Fan Systems
19
19
PFN41
19” Rack Mount Cooling Fan System W/Temperature Display
• Four cooler master 80mm ball bearing case fan
• Three Numbers Blue Display Screen
Show The Inner Temperature For Cabinet
Or Other Multimedia Centers
• The Unit Has Sensors To Check
PDSP850
19’’ Rack Mount Professional Digital Sampler
• 24 Seconds Sampling Time
• Up to 3 Memory Banks
• 1, 2 & 3 Banks Memory Modes
• Single/Repeat Modes
• Large Start/Stop Button for Easy Operation
• Sampler Mic Input
• Source Selector
• Input Gain Control
• Pitch Control +/- 1/2 Octave
PPEQ100
• 3 Pairs of Audio Outputs (Main, Tape 1, & Tape 2)
• Signal-to-Noise Ratio: 95dB
• THD: 0.03%
• 110/220 Voltage Selectable
• Rack Mountable
• Dimensions: 19”W x 11.1”D x 3.5”H
Dual Channel 12 Band Graphic Equalizer
• Constant Q Circuitry with a 3% Center Frequency Accuracy
• Variable Input Level Controls
• Dual Blue LED Level Meters
• Variable Meter Sensitivity
• Post/Pre Switch
• Source Selector
20
20
• Bass/Midrange/High gain control
• Left/Right Channel Volume gain control
• 110/220V power switch
• Removable Rack Mount Brackets
• Dimensions: 17’’w x 9’’h x 2.2’’d
• Weight: 5 lbs
Dual 10 Band Stereo Graphic Equalizer w/Spectrum Display
• 10 Bands of Equalization(Per
Channel),with a Range of (+/-) 12dB
• Center Frequencies: 30Hz, 60Hz, 120Hz, 250Hz,
500Hz, 1KHz, 2KHz, 4KHz, 8KHz,& 16KHz
• 10-Band Multicolor Spectrum Analyzer Display
• 4 Pairs of Audio Inputs (Audio,”Video”
Aux, Tape 1, & Tape 2)
PPEQ86
• Removable Rack Mount Brackets
• VFD Spectrum Graphic Display Screen
• 110v/220v Switchable Power Source
• Dimensions: 16.9’’ x 9.3’’ x 2’’
19” Rack Mount Dual 10 Band Stereo Graphic Equalizer
• Dual VU Meters level monitor
• Dual 10 bands Eq with blue leds
• 2 RCA line input
• 2 RCA line Output
• 2 RCA line Output for REC
• VFD display screen
PPEQ200
• Sampler Level & Pan Controls
• Phono, Line 1 & Line 2 Inputs
• Line & Rec Outputs
• 1/4’’ Mic Output
• Ground Screw for Turntables
• Single Rack Space Unit
• 110/220 Voltage Switchable
• Dimensions: 1.75’’ x 19’’ x 6’’
19’’ Rack Mount Dual 10 Band 4 Source Input Stereo Spectrum Graphic
• Dual 10 Bands Eq With Blue Leds
• Four Audio Source Line Input
• 4 RCA line input
• 2 RCA line Output
PPEQ150
Any Part Temperature
• Power 110V 60HZ
• Screws are included for easy install
• Dimensions: 19” X 4.3” X 2.4”.
• Weight: 3.5 LBS
• Red Illuminated Power Switch
• Line 1/Line 2 & Tape RCA Inputs
• Line and Tape RCA Outputs
• Ground/Lift Switch
• Rack Mountable
• 110/220 Voltage Switchable
• Dimensions: 19’’ x 5.2’’ x 7.4’’
Samplers / Graphic Equalizers
PDJR1
Rack-Mountable Drawer
• Key Lock - Full steel enclosure
• Great for storing cellphone, wallet, iPod, cables and cash
• Removable ears / handles
PHA40
4 Channel Stereo Headphone Amplifier
• Power On LED Indicator
• Stereo Headphone Output Level Controls
• Stereo Headphone 1/4’’ TRS Output Jacks
PHPDJ1
Professional DJ Turbo Headphones
• Plug: Gold Plated 1/8’’ (3.5 Mm)
Stereo Plug With 1/4’’ Adaptor
• Wide Frequency Range Delivers
Full Bass And Detailed Highs
• Optimized Performance For Use With Most
Pro And Consumer Audio Devices
• Closed-Back, Circumaural Design
Rests Comfortably Over The Ears
PHPDJ2
• Impedance: 600 Ohms
• Sensitivity: -74 +/- 3dB
• On/Off Switch for Onstage Control
• 15 Foot XLR (F) - 1/4” (M) Microphone cable
Professional Moving Coil Dynamic Handheld Microphone
• Moving Coil Dynamic Uni-Directional Element
• Steel Mesh Ball Shaped Grill
• Frequency Response: 50Hz~15KHz
• 600 Ohm Output Impedance (+/-)30%
• Microphone Sensitivity: -54db
And Reduces Background Noise
• Single-Sided Cord With Oxygen-Free Copper Wires
• Driver Size: 50mm
• Sensitivity (S.P.L): 115dB±3dB/mW (at 1 KHz)
• Impedance: 32 Ohms ± 15%
• Max. Input Power: 100mW
• Frequency Range: 20~22,000Hz
• Length of Cable: 9FT
Dynamic Microphone
• Unidirectional Pickup Pattern
• Durable Metal Construction
• Clear, Transparent Sound
• Frequency Response: 50Hz-12kHz
PDMIK1
And Reduces Background Noise
• Single-Sided Cord With Oxygen-Free Copper Wires
• Driver Size: 50mm
• Sensitivity (S.P.L): 115dB±3dB/mW(at 1KHz)
• Impedance: 32 Ohms ± 15%
• Max. Input Power: 100mW
• Frequency Range: 20~22,000Hz
• Length of Cable: 7FT
Professional DJ Turbo Headphones
• Plug: Golden-Plated 1/8’’ (3.5 Mm)
Stereo Plug With 1/4’’ Adaptor
• Wide Frequency Range Delivers
Full Bass And Detailed Highs
• Optimized Performance For Use With Most
Pro And Consumer Audio Devices
• Closed-Back, Circumaural Design
Rests Comfortably Over The Ears
PPMIK
• Stereo 1/4’’ TRS Source Input Jack
• 12V/150mA DC Power Supply Included
• Dimensions: 4.07’’W x 1.18’’H x 2.24’’D
(+/-)3db(0dB=1V/Pa @ 1KHz)
• On/Off Broadcasting Switch
• 6.5 Foot XLR (F) - 1/4” (M) Microphone
cable with 300 Ohms Outputs
• Microphone Dimensions: 6.7’’ x 1.7’’ x 0.3’’
DJ Drawer / DJ Headphones / Microphones
21
21
PDMIK2
Professional Moving Coil Dynamic Handheld Microphone
• Moving Coil Dynamic Uni-Directional Element
• Durable Zinc Alloy Metal Construction
• Steel Mesh Ball Shaped Grill
• Frequency Response: 50Hz~15KHz
• 600 Ohm Output Impedance (+/-)30%
• Microphone Sensitivity: -54db
PDMIK4
(+/-)3db(0dB=1V/Pa @ 1KHz)
• On/Off Broadcasting Switch
• 15 Foot XLR (F) - 1/4” (M) Microphone
cable with 600 Ohms Outputs
• Microphone Dimensions : 7.7’’ x 0.8’’ x 1.0’’
Dynamic Microphone with Carry Case
• Unidirectional Pickup Pattern
• Durable Metal Construction
• Clear, Transparent Sound
• Frequency Response: 50Hz~15000Hz
• Neodymium Magnet Designed for High Output
• Sensitivity: -73 +-3dB
PDMIC58
Professional Moving Coil Dynamic Handheld Microphone
• Moving Coil Dynamic Uni-Directional Element
• Durable Zinc Alloy Metal Construction
• Steel Mesh Ball Shaped Grill
• Frequency Response: 50Hz~15KHz
• 600 Ohm Output Impedance (+/-)30%
PDMIC78
PDMICKT80
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Steel mesh, ball-shaped grill
Easy transport carrying case
Impedance: 600 Ohms outputs
Durable zinc alloy metal construction
Sensitivity([email protected]) -55±dB
Frequency response: 50Hz~ 12KHz
Steel mesh, ball-shaped grill
Easy transport carrying case
Impedance: 600 Ohms outputs
Microphone and Tripod Stand With Extending Boom & Mic Cable Package
• Includes a Handheld Dynamic Microphone
• Dynamic vocal microphone with smooth midfrequency presence rise for
excelent voice projection
• Ultra-wide frequency response for a
brilliant and transparent sound
• Shock mount system to cut down handling noise
• Includes Mic Stand and Mic Holder With Boom
22
22
• Microphone Sensitivity: -54dB
(+/-)3db(0dB=1V/Pa @ 1KHz)
• 15 Foot XLR (F) - 1/4” (M) Microphone
cable with 600 Ohms Outputs
Dynamic Cardioid Vocal Microphones With Clips, 3-Pack
Dynamic vocal and instrument microphone
with on/off switch for excellent studio
and live performance
High-quality components and exceptionally
rugged construction ensure long life
Dedicated vocal and instrument mic
delivers unbelievable quality
high signal output lets your voice cut through
Moving coil, dynamic Uni-directional element
Durable zinc alloy metal construction
Sensitivity([email protected]) -55±dB
Frequency response: 50Hz~ 12KHz
PMKSM20
• Microphone Sensitivity: -54dB
(+/-)3db(0dB=1V/Pa @ 1KHz)
• 15 Foot XLR (F) - 1/4” (M) Microphone
cable with 600 Ohms Outputs
Professional Moving Coil Dynamic Handheld Microphone
• Moving Coil Dynamic Uni-Directional Element
• Durable Zinc Alloy Metal Construction
• Steel Mesh Ball Shaped Grill
• Frequency Response: 50Hz~15KHz
• 600 Ohm Output Impedance (+/-)30%
•
• Mic Body Material: Zinc Alloy
• Impedance: 600 Ohms
• On/Off Switch for Onstage Control
• Rugged Carrying Case
• 15 Foot XLR (F) - 1/4” (M) Microphone cable
Microphones
• Glossy Black Finish - Constructed
with Strong Lightweight Tubing
• Microphone Stand Adjustable
Height From3.28 - 5.5 Ft
• Microphone Boom Lenth: 7.48’’
• 1/4’’ Microphone Cable 15 Ft
PMSAX1
Instrument/Saxaphone XLR Condenser Microphone
• Trumpet Saxaphone Silent Brass
And Most Wind Instrument
• Element: Back Electret Condenser
• Polar Pattern: Uni-directional
• Frequency Response: 50Hz- 16KHz
• Sensitivity: -46dB± 3dB
• Output Impedance: 250Ω± 30%
• Max.Input SPL: 130dB
PDKM7
7 Microphone Wired Drum Kit with Carry Case & Mounting Accessories
• S/N Ratio: 70dB
• Connector: Standard XLR
• Power Supply: Phantom 24-48V
• Polar Pattern: Uni-Directional
• Max Input SPL: NA/NA/130dB(@1kHz<1%T.H.D.)
• Output Impedance: 400Ω± 30%/500Ω± 30%/200Ω
• Sensitivity: -58dB(+/-)3dB/-53dB(+/-)3dB/-45dB
• Frequency Response: 50Hz-15kHz/
50Hz -14kHz/50Hz-18kHz
• Compact Drum MicS for Close & Precise Recording
• Universal Drum Mounts (Can be used
PLM3
PLMC15
PLMS30
• Cable: 2 x 1.0M
• Weight: 21g/18g
• Dimension: 12.2mm
• Connector: Standard 3.5mm + 1/4’’ Adaptor
• Color: Black
• Accessories: Windscreen,Clip
Lavalier Electret Omnidirectional Condenser Microphone
• Element; Condenser
• Polar Pattern; Omnidirectional
• Full, 360-Degree Coverage. Clip It On And
• Professional Performance Microphone
• 6m Shielded Low Noise Cable
• Fixed Tie-Clip
• Sensitivity: 3.5mv/Pa
• Impedance: 1000 ohm
• Frequency Response: (100-15000) Hz
• Powered By AA Battery (Not Included)
Wired Lavalier Mini XLR Uni-Directional Microphone (Works with Shure System)
• Color: Black
• Weight: 21g/18g
• Dimension: 12.2mm
• Max.Input SPL: 130dB
• Sensitivity: -46dB± 3dB
• Connector: 4pin Mini XLR
• Power Supply: DC 1.5V-10V
• Output Impedance: 1kΩ± 30%
• Accessories: Windscreen,Clip
• Polar Pattern: Uni-directional
• Frequency Response: 50Hz- 16KHz
• Element: Back Electret Condenser
Headworn Omni-Directional Microphone (3.5mm / 1/4’’)
• Color: Beige
• Wired Boom
• Cable Length: 1.2M
• Max.Input SPL: 130dB
• Sensitivity: -44dB± 3dB
• Power Supply: DC 1.5V-10V
• Output Impedance: 1kΩ± 30%
• Polar Pattern: Omni-directional
on most stan dard drum rims)
• Element: Moving Coil Dynamic//
Back Electret Condenser
• High-Performance Microphones Tuned
to Capture Everything From Low-End
Punch to Sensitive/Flat Sound
• Accessories: Windscreens, Carry Case,
Mounting Brackets, Mic Holders
• Dimensions: 17.5” x 12” x 3.7”
• Weight: 6.6 Lbs.
Wired Lavalier 3.5mm/ 1/4’’ Uni-Directional Microphone
• Element: Back Electret Condenser
• Polar Pattern: Uni-directional
• Frequency Response: 50Hz- 16KHz
• Sensitivity: -46dB± 3dB
• Output Impedance: 1kΩ± 30%
• Max.Input SPL: 130dB
• Power Supply: DC 1.5V-10V
PMEM1
• Power Supply: Phantom 48V
• Cable: Φ2*3.0M
• Weight: 56g
• Dimension: 15mm
• Connector: XLR Plug
• Color: Black
• Accessories: Windscreen Clip,
Adaptor for Phantom 48V
• Frequency Response: 20Hz- 20KHz
• Element: Back Electret Condenser
• Weight: 10g (not including Adaptor)
• Connector: Standard 3.5mm
Plug (or 1/4’’ Adapter)
• Accessories: 2 Windscreens & 1/8”
Stereo Jack to 1/4” Adapter
Lavalier Microphones
23
23
PMEMS10
In Ear Mini XLR Omni-Directional Microphone (For Shure System)
• Wired Boom
• Element: Back Electret Condenser
• Polar Pattern: Omni-directional
• Frequency Response: 20Hz- 20KHz
• Sensitivity: -44dB± 3dB
• Output Impedance: 1k Ohms± 30%
• Max.Input SPL: 130dB
PMHM2
Omni-directional Head Worn Microphone (3.5mm / 1/4’’ Connectors)
• Color: Beige
• Wired Headset Boom
• Max.Input SPL: 130dB
• Sensitivity: -45dB± 3dB
• Cable Length: Φ1.5*1.2M
• Power Supply: DC 1.5V-10V
• Output Impedance: 1kΩ± 30%
PMHMS20
PMEMKT5
• 3.5mm mini-plug Adapter Included for use with
most cameras and home recording systems
• Integrated 6-foot cable
• Condenser element
• frequency response:30Hz- 20Hz
6-Inch Clamp On Microphone Pop Filter
• Pop Filter For Vocal Microphones
• Designed For Professional Vocal Recording Environments
• Stops Plosives And Protects Your Microphone
• Includes Boom And Microphone Stand Clamp
• Swivel Mount For Easy Positioning;
Flexible Gooseneck Holder
• Reduces Plosives And P-Pops
During Vocal Performance
Dual Function Wireless or Wired Microphone System
• Complete Wireless System
• Microphone Directivity: Unidirectional
• Can also be used as a Wired Mic
• 3 Position Mic Switch
24
24
•Fits left or right ear and retaining band holds mic in place
•Includes three windscreens, clothing cable clip and carry case
•Omnidirectional pickup pattern, off-axis
linear frequency response
•Four cable adapters for compatibility with
Lavalier Omnidirectional Condenser Microphone
• 1/4’’ Plug for Pro Audio Devices
• High-quality condenser miniature
lavalier microphone
• Great for video use, also ideal for
aerobics/dance/sports instructors
PDWM94
• Polar Pattern: Omni-directional
• Frequency Response: 20Hz- 20KHz
• Element: Back Electret Condenser
• Color: Beige/Matches Various Skin Types
• Accessories: 2 Windscreens
Wired Headset Boom Mini XLR Omni-Directional Microphone
•Detachable cable
•Color: Beige (tan)
•Cable Length: 48 Inches
•Headset can fit over either ear
•Micro-miniature condenser with 2.5mm capsule
•Adjustable drip ring helps protect
mic element from sweat
PCMLVC33
• Polar Pattern: Omni-directional
• Element: Back Electret Condenser
• Weight: 12g (not including Adaptor)
• Frequency Response: 20Hz- 20KHz
• Connector: Standard 3.5mm
Plug (or 1/4” Adaptor)
• Accessories: 2 Windscreens & 1/8”
Wired Headset Boom Mini XLR Omni-Directional Microphone
• Weight: 15g
• Max.Input SPL: 130dB
• Cable Length: 1.2Meters
• Sensitivity: -45dB± 3dB
• Connector: 4 Pin Mini XLR
• Power Supply: DC 1.5V-10V
• Output Impedance: 1kΩ± 30%
PEPF20
• Power Supply: DC 1.5V-10V
• Cable:1.5 x 1.2M
• Weight: 13g
• Dimension: 5MM
• Connector: 4 Pin Mini XLR
• Color: Skin
• Accessories: Windscreen
• Operation range: Up To 45 ft.
• 12 Foot XLR (F) - 1/4” (M)
Microphone cable included
• Batteries Included
Lavalier Microphones
PDWM96
Lavalier Wireless Microphone System
• Bodypack Transmitter w/Clip-on
Lavalier Microphone
• Receiver w/ 1/4’’ Plug
PDWM100
Dual Function Wireless/Wired Microphone System
• Can also be used as a Wired Mic
• Microphone Directivity: Unidirectional
• 3 Position Mic Switch
• Detachable Mic Antenna
• Operation range: 45-90 ft.
• Signal LED Indicator
PDWM2100
• Frequency Response: 50Hz~16KHz
• Operation Range: 50-180 Meters
• Signal to Noise Ratio: 90dB
• Receiver Power Supply: AC 110/240V
• Microphone Power Source: 9 Volt
(Battery Not Included)
• Receiver Dimensions:1.7’’ x 16.5’’.x 7.3
• Microphone Dimensions: 12.7’’L x 4.9’’W x 5.9 ‘’D
Dual VHF Wireless Microphone System
• Professional VHF Wireless System
• Two Microphones Included
• Detachable Mic Antenna
• Audio Mute Circuitry For Quiet Operation
• Multi-Function 2 Color Display
• Dual Volume Controls
• Dual Volume Controls
• 1/4’’ and XLR Mixed Outputs
• Operation range: Up To 90 ft.
• 110V/220V selectable
• Batteries and 1/4’’ Output Cables Included
• Dimensions: 16.54” W x 1.77”H x 8.66”D
Professional Dual Table Top VHF Wireless Microphone System
• Professional VHF 2 Channel Wireless System
• Dual Table Top Microphones Included
• Dual Telescoping Receiver Antennas
• Dual Volume Controls
• On/Off Broadcasting Switch
• Mixed 1/4’’ Outputs
• Dynamic Range: 92dB
• Total Harmonic Distortion: 0.5%
PDWM2300
• Frequency Response: 60Hz~12KHz
• Operation Range: 50-150 Meters
• Signal to Noise Ratio: 80dB
• Receiver Power Supply: AC 110V
• Microphone Power Source: 9 Volt
• Receiver Dimensions: 1.0’’ x 7.9’’ x 11.4’’
• Microphone Dimensions: 9.6’’ x 1.9’’ x 1.3’’
Dual VHF Wireless Microphone System
• Professional VHF Wireless System
• Two Microphones Included
• Power On/Standby/Off Switch
• Red/Green LED to Identify Mics
• Dual Telescoping Receiver Antennas
• Dual AF Level Meters
• Channel Signal Indicators
PDWM2150
• Telescoping Receiver Antenna
• 12 ft. XLR to 1/4’’ Mic Cable included
• 4 ft. 1/8’’ to 1/4’’ Audio Cable included
• Dimensions: 4.72’’ x 3.15’’ x 1.10’’
Professional Dual VHF Wireless Handheld Microphone System
• Professional VHF 2 Channel Wireless System
• Dual Handheld Microphones Included
• Dual Telescoping Receiver Antennas
• Rotary Volume Controls with Digital Readout
• On/Off Broadcasting Switch
• Mixed ¼’’ Outputs
• Dynamic Range: 80dB
• Total Harmonic Distortion: 0.5%
PDWM2000
• Volume Control
• Super Compact Design
• Operation range: Up To 60 ft.
• XLR and 1/4’’ Mixed Outputs
• Operation range: Up To 90 ft.
• Batteries and 1/4’’ Audio Cable Included
• 110V/220V selectable
• Dimensions: 12.99’’ x 6.89’’ x 1.97’’
Wireless Microphone Systems
25
25
PDWM2450
Wireless 2 Channel VHF Microphone System With 2 Microphones
Receiver
• Rack mountable VHF system is
perfect for large Events
• Telescoping antennas
• Independent volume control for each microphone
• LCD display with level indicators for each Microphone
• Sensitivity: 60dB
• Signal-to-Noise: >60 dB
• Image Rejection: >50dB
PDWM2500
Dual VHF Wireless Microphone System
• Professional Dual VHF System
• Two Handheld Microphones Included
• Power On/Off Switch
• Mute Switch
• Power and Low Battery LED Indicators
• Dual RF Indicators
PDWM2550
• Dual Volume Controls
• XLR and 1/4’’ Mixed Outputs
• Operation Range: Up To 90 ft.
• Batteries and 1/4’’ Audio Cable Included
• Dimensions: 2.08”H x 12.83”W x 7.87”D
• 110V/220V Selectable
4 Mic VHF Wireless Rack Mount Microphone System
• Professional VHF Wireless System
• Two Handheld Microphones
• Two Belt Pack Transmitters w/
Lavalier and Headset Mics
• Power On/Standby/Off Switch
• 4 x 9V Batteries and 1/4’’ Audio Cable Included
• RF Indicators
26
26
• 1/4” & XLR Mixed Unbalanced OutputS
• Rack Mountable
• Available Frequencies (Hz): Set 1 - 201.15,
180.8 / Set 2 - 212.6, 190.1 / Set 3 - 214.2,
193.0 / Set 4 - 215.5, 174.8
• Operating Range: Up to 150ft
• Dimensions: 8.73’’W x 5.51’’D x 1.8’’H
Dual VHF Rechargeable Wireless Microphone System
• Built-In Chargers for both Microphones
• Charger LED Indicator
• Professional VHF Wireless System
• Two Microphones Included
• Detachable Mic Antenna
• Audio Mute Circuitry For Quiet Operation
• Multi-Function 2 Color Display
PDWM4300
• Total Harmonic Distortion: 0.5%
• Frequency Response: 40Hz~18KHz
• Operation Range: 50-180 Meters
• Signal to Noise Ratio: 105dB
• Receiver Power Supply: AC 110
• Microphone Power Source: 8.4 Volt Rechargeable
• Receiver Dimensions:1.8’’ X 18.9’’ X 1.3’’
• Microphone Dimensions: 9.6’’ X .7” X 0.5’’
Two Channels VHF Wireless Microphone
• One Handheld Microphone
• One Belt Pack Transmitter with Headset MIC
• Power On/Standby/ Off Switch
• 2 x 9V Batteries, AC/DC Adapter
& ¼’’Audio Cable Included
• RF, AF & Power Indicators
• Individual Volume Controls
PDWM3000
• Dual AF Level Meters
• Dual Volume Controls
• 1/4’’ Individual and 1/4” Mixed Output
• Operation Range: Up To 240 ft.
• 2 x 9V Batteries and 1/4’’ Audio Cable Included
• Dimensions: 1.5”H x 7.75”W x 5.30”D
19’’ Rack Mount Dual VHF Wireless Rechargeable Handheld Microphone System
• Professional VHF 2 Channel Wireless System
• Dual Handheld Microphones Included
• Dual Telescoping Receiver Antennas
• Dual Volume Controls With Digital Readout
• Dual Charging System
• On/Off Broadcasting Switch
• XLR Individual line outputs & Mixed 1/4’’ Output
• Dynamic Range: 100dB
PDWM2700
• Audio Frequency Response: 85-12000HZ
• System Distortion: Microphone
• On/off switch for simple operation
• Ergonomic design fits the hand perfectly
• Maximum Deviation Range: 30 KHz (Max)
• Frequency Stability: ±0.005%
• RF Output Power: 35dB
• Current Consumption: <30mA
• Operate Range: 130 – 200 ft.
• Battery: 9V*2
• AF Level Meters
• Individual Volume Controls
• 1/4’’ Individual and 1/4” & XLR Mixed Output
• Operation Range: Up to 240 ft.
• Power Supply:110/220 V
• Dimensions: 16.5’’ x 8.2’’ x 1.8’’
Wireless Microphone Systems
PDWM4400
Rack Mount 4 Mic VHF Rack Mount Wireless Lavalie/ Headset System
• Professional VHF Wireless System
• 4 Belt Pack Transmitters w/
Lavalier and Headset Mics
• Power On/Standby/Off Switch
• 4 x 9V Batteries and 1/4” Audio Cable Included
• RF Indicators
• AF Level Meters
• Individual Volume Controls
PDWM5000
4 Mic VHF Wireless Microphone System
• Professional VHF Wireless System
• Quartz Lock for Drift-Free Operation
• Four Microphones Included
• Power On/Standby/Off Switch
• Audio Mute Circuitry For Quiet Operation
• Advanced Companding Circuitry
• AF Signal LED Segment Meter On Each Channel
• Individual Channel Volume Controls
PDWM5500
• Frequency Response: 50Hz~16KHz
• Operation Range: 50-180 Meters
• Signal to Noise Ratio: 90dB
• Receiver Power Supply: AC 110/240V
• Microphone Power Source: 9 Volt
• Receiver Dimensions Without Rack
Mount: 1.8’’ x 16.5’’ x 8.7’’
• Receiver Dimensions With Rack Mount 1.8’’x 18.9’’ x 8.7’’
8 Channel Wireless Microphone System - Rack Mountable with 4 La-
• 4 Belt Packs
• 4 Lavalier Mics
• 4 Headset Mics
• 4 Handheld Mics
• Mixed 1/4” XLR Outputs
• Signal to Noise Ratio: 90 dB
• Operation Range: 150 - 600 ft
• Frequency Response: 50Hz~16KHz
• Operation Range: 50-180 Meters
• Signal to Noise Ratio: 90dB
• Receiver Power Supply: AC 110/240V
• Microphone Power Source: 9 Volt
• Receiver Dimensions Without Rack
Mount: 1.8’’ x 16.5’’ x 8.7’’
• Receiver Dimensions With Rack Mount 1.8’’x 18.9’’ x 8.7’’
8 Mic Professional Handheld VHF Wireless Microphone System
• Professional VHF 8 Channel Wireless System
• Eight Hand held Microphones Included
• Dual Telescoping Receiver Antennas
• Eight Volume Controls
• On/Off Broadcasting Switch
• 1/4’’ Individual line outputs & Mixed 1/4’’ Outputs
• Dynamic Range: 92dB
• Total Harmonic Distortion: 0.5%
PDWM8700
• Individual Channel Volume Controls w/ LED Display
• Individual 1/4’’ Unbalanced Outputs
• XLR Balanced and 1/4’’ Unbalanced Mixed Output
• Operation Range: Up To 240 ft.
• Batteries and 1/4’’ Audio Cables Included
• 110V/220V Selectable
• Rack Hardware Included
Professional conference Desktop VHF Wireless Microphone System
• Professional VHF 8 Channel Wireless System
• Eight Table Top Microphones Included
• Dual Telescoping Receiver Antennas
• Eight Volume Controls
• On/Off Broadcasting Switch
• One mixed microphone output 1/4’’ and XLR jacks
• Dynamic Range: 92dB
• Total Harmonic Distortion: 0.5%
PDWM8400
• Individual 1/4’’ Unbalanced Outputs
• 1/4’’ Unbalanced Mixed Output
• Operation Range: Up To 240 ft.
• Battery Life: Approx. 12 Hours
• Batteries and 1/4’’ Audio Cables Included
• 110V/220V Selectable
• Rack Hardware Included
• Dimensions: 2.04”H x 19.09”W x 9.44”D
4 Mic VHF Wireless Microphone System
• Professional VHF Wireless System
• Quartz Lock for Drift-Free Operation
• Four Microphones Included
• Power On/Standby/Off Switch
• Power LED Indicates Status
• Audio Mute Circuitry For Quiet Operation
• Advanced Companding Circuitry
• AF Signal LED Segment Meter On Each Channel
PDWM8300
• 1/4’’ Individual and 1/4” & XLR Mixed Output
• Frequency Range: VHF 160-270MHz
• Available Frequencies (Hz): Set 1 - 215.5, 174.8,
200.6, 180.8 / Set 2 - 212.6, 190.1, 214.2, 193.0
• Operation Range: Up to 240 ft.
• Power Supply:110/220 V
• Dimensions: 1.8”H x 16.5”W x 8.2”D
• Total Harmonic Distortion: 0.5%
• Four Telescoping Receiver Antennas
• Frequency Response: 50 Hz - 16 kHz
• 8 Volume Controls (1 for Each Channel)
• Receiver Dimensions With Rack Mount: 1.8’’ x 18.9’’ x 8.7’’
• Receiver Dimensions Without Rack
Mount: 1.8’’ x 16.5’’ x 8.7’’
Wireless Microphone Systems
27
27
PDWM8900
8 Channel Wireless Microphone System - Rack Mountable with 8 Clip-On Lavalier Mics & 8 Headsets
• 8 Belt Packs
• 8 Lavalier Mics
• 8 Headset Mics
• Mixed 1/4” XLR Outputs
• Signal to Noise Ratio: 90 dB
• Operation Range: 150 - 600 ft
• Receiver Dimensions With Rack Mount: 1.8’’ x 18.9’’ x 8.7’’
• Total Harmonic Distortion: 0.5%
• Dual Telescoping Receiver Antennas
PDWM2400
Wireless Dual Channel UHF Microphone System With 2 Microphones
Receiver
• UHF system is perfect for large Events
• Foldable antennas
• Independent volume control for each microphone
• Power indicators for each microphone
• Sensitivity: 80dB
• Signal-to-Noise: > 80 dB
• Image Rejection: > 50dB
• Audio Frequency Response: 80-12000HZ
PDWM2600
• On/off switch for simple operation
• Ergonomic design fits the hand perfectly
• Color-coded mics for easy identification
• Maximum Deviation Range: 50 KHz (Max)
• Frequency Stability: ±0.005%
• RF Output Power: 40dB
• Current Consumption: <100mA
• Operate Range: 200 – 260 ft.
• Battery: 1.5V*2 AA
Wireless Professional UHF Dual Channel Microphone System With 2 Microphones
Receiver
• Rack mountable UHF system is
perfect for large Events
• Foldable antennas
• Independent volume control for each microphone
• LCD display with relevant information
• Frequency Range: 614-698MHz
• Adjustable frequency FOr adding more Mic’s
• Sensitivity: 90dB
• Signal-to-Noise: >90 dB
• Image Rejection: >80dB
28
28
• 1/4” & XLR Mixed Unbalanced Outputs
• Operation range: Up To 150 ft.
• 1/4’’ Audio Cable Included
• 110V/220V selectable
• Half Space Rack Mountable
• Rack Ears Included
• Dimensions: 8.4’’ x 5.3’’ x 1.8’’
• Microphone Runs On AA Batteries
Professional UHF Wireless Microphone System With 2 Microphones
Receiver
• Rack mountable UHF system is
perfect for large Events
• Foldable antennas
• Independent volume control for each microphone
• LCD display shows frequency of each microphone
• Sensitivity: 80dB
• Signal-to-Noise:>80 dB
• Image Rejection:>60dB
• Audio Frequency Response: 80-12500HZ
• System Distortion:Microphone
PDWM3300
• System Distortion: Microphone
• Mute switch lets you cut the power
at the Touch of a button
• Maximum Deviation Range: 35 KHz (Max)
• Frequency Stability: ±0.005%
• RF Output Power: 40dB
• Current Consumption:<50mA
• Operate Range: 160 – 200 ft.
• Battery: 9V*2
Dual UHF Wireless Microphone System
• Professional Dual UHF
• Two Microphones Included
• Power On/Standby/Off Switch
• Audio Mute Circuitry For Quiet Operation
• Advanced Companding Circuitry
• Dual RF Indicators
• Dual AF Level Meters
• Dual Volume Controls
PDWM2800
• Frequency Response: 50 Hz - 16 kHz
• 8 Volume Controls (1 for Each Channel)
• Receiver Dimensions Without Rack
• Mount: 1.8’’ x 16.5’’ x 8.7’’
• Audio Frequency Response: 75-14500HZ
• System Distortion: Microphones
• On/off switch for simple operation
• Ergonomic design fits the hand perfectly
• Maximum Deviation Range: 60 KHz (Max)
• Frequency Stability: ±0.005%
• RF Output Power: 40dB
• Current Consumption: <100mA
• Operate Range: 200 – 260 ft.
• Battery: 1.5V*2 AA
Wireless Microphone Systems
PDWM3500
•
•
•
•
•
•
•
•
System Distortion: <1%
Image Rejection: >80dB
Frequency Range: 614-698MHz
Current Consumption: < 400mA
Power supply: DC12V~17V/600MA
Sensitivity: <2UV (12dB SINAD)
Audio Output Level: 800mV(600O)
Audio Frequency Response: 75-14500HZ
PDWM3700
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
LCD display with relevant information
Adjustable frequency FOr adding more Mic’s
Dynamic Range: >90dB
Signal-to-Noise: >90 dB
Rack mountable UHF system is
perfect for large Events
Foldable antennas
Independent volume control for each microphone
•
•
•
•
•
•
(18dBm3mW);10dBm (10mW)
Dynamic Range: 120dB
Harmonic distortion +_ Noise:.1%(20Hz to 20kHz)
S/N Ratio: >90dB (20Hz TO 20kHz)
Sensitivity: -50dB
Output delay: 10-30ms (selectable)
Digital channel: Two way UART
interface, Baud rate: 9600bps.
Rack Mount 4 Channel Desktop Conference UHF Wireless Microphone System
RF indicators
AF Level meters
S/Noise ratio: =110dB
Input Sensitivity: -90dB
Working distance: 50-80 m
Individual Volume Control
On/Off Broadcasting Switch
Frequency Stability: ±10ppm
Mobile Anti-interference cartridge
Volume Control on meeting microphone
Battery requirement: 2 X1.5V (AA size)
PDWM4700
•
•
LCD display with relevant information
Adjustable frequency FOr adding more Mic’s
Dynamic Range: >90dB
Signal-to-Noise: >90 dB
Rack mountable UHF system is
perfect for large Events
Foldable antennas
Independent volume control for each microphone
Professional Rack Mount Dual Channel 2.4G Wireless Handheld Microphone System
Two Handheld Microphones
Strong anti-interference, many sets
could be used at same time
Two LCD screens on Receiver
1/4” mixed input, 2 XLR individual balance inputs
Carrier Frequency: 18-20KHz
Frequency spread: ADFHSS, 1330 times/second
Transmitting power: Max
PDWM4650
•
•
•
•
•
Professional UHF Dual Channel Wireless Microphone System with Adjustable Frequency
System Distortion: <1%
Image Rejection: >80dB
Frequency Range: 614-698MHz
Current Consumption: < 400mA
Power supply: DC12V~17V/600MA
Sensitivity: <2UV (12dB SINAD)
Audio Output Level: 800mV(600O)
Audio Frequency Response: 75-14500HZ
PDWM3800
•
•
Professional UHF Dual Channel Wireless Microphone System with Adjustable Frequency
•
•
•
•
•
•
•
•
1/4” mixed input, 1/4” individual
input, 1 XLR mixed balance input.
Carrier Frequency: 470-608 or
614-698 MHz (FCC range)
Selectable Channels: 1 channel per microphone
Power supply:110V/220V
Audio Digital Interface: 12S output,
44.1k sampling, 24 bit PCM
Working Distance: 50-80 m
Battery Requirement: 2 X 1.5V (AA size)
Power supply: 110V/220V
Professional Rack Mount Dual Desktop UHF Selectable Frequency Wireless Microphone System
S/Noise ratio: =110dB
Power supply:110V/220V
Individual Volum Control
On/Off Broadcasting Switch
Two LCD screens on receiver
Frequency Stability: ±0.005%
Working distance: 50-100 Meters
LCD screen on meeting microphone
•
•
•
•
•
•
•
•
Mobile Anti-interference cartridge Input Sensitivity: -12dB (80dB S/N)
Battery requirement: 2 X 1.5V (AA size)
IR SYNC UHF Selectable Wireless Microphone
1/4” individual input, 1 XLR mixed balance input
Selectable Channels: 200 channels per microphone
Carrier Frequency: 470-608 or 614698 MHz (FCC range)
Wireless Microphone Systems
29
29
PMP10
Mini Handheld Megaphone Bull Horn Voice Amplifier
• Output: 10 Watts
• Battery Light Indicators
• Can Be Heard Up To 700 Feet Away
• Adjustable Volume Control and Wrist Strap
PMP20
•
•
•
•
•
•
Compact Professional Power Megaphone
Used by U.S. Armed Forces
For Indoor/Outdoor Use
Maximum Power Output: 20 Watt
2 Audio Functions: Voice & Siren Modes
Voice Mode: Amplifies your voice as
spoken into the microphone
Siren Mode: Amplifies an alert/siren tone
through the megaphone speaker
PMP30
PMP35R
PMP37RLE
•
•
•
•
•
•
•
30
30
•
•
•
Ergonomic Pistol Grip and Light-Weight Chassis
Battery Powered by 4 x “C” Type
Batteries (1.5V), Not Included
Dimensions: Diameter 5.4” x Length 8.6”
1/4 Mile Range
Weight: 1.5 Lbs.
• Tough Housing
• Built-In Siren
• Uses 4 X D Batteries (Not Included)
• Dimensions: Diameter 6 1/4 X Length 10
• Weight: 1.15 Lbs
Professional Megaphone / Bullhorn w/ Siren & Voice Recorder
• Voice Recording Capabilities
• 10 Second Integrated Audio Memory
• Repeat Recorded Audio With Ease
• Power: 30 Watts
• 800 Yard Range
• Used By U.S. Army, Navy, Air Force And Marines
• For Indoor/Outdoor Use
• Variable Volume Control
• Tough ABS Housing
• Built-In Siren
• Uses 4 X D Batteries (Not Included)
• Dimensions: 6.25’’H x 6.25”W x 10”L
• Weight: 1.15 Lbs
Professional Megaphone / Bullhorn with Siren & LED Lights
Power: 30 Watts
800 Yard Range
Used By U.S. Army, Navy, Air Force And Marines
For Indoor/Outdoor Use
Variable Volume Control
Tough Housing
Built-In Siren
PMP38R
•
•
Professional Megaphone / Bullhorn with Siren
• Power: 30 Watts
• 800 Yard Range
• Used By U.S. Army, Navy, Air Force And Marines
• For Indoor/Outdoor Use
• Variable Volume Control
•
•
•
•
•
•
•
• Requires 3 AAA Batteries (Not Included)
• Dimensions: Diameter 3 1/4’’ X Length 5 3/8’’
• Weight: 0.46 Lbs
•
•
•
•
Uses 4 X D Batteries (Not Included)
Dimensions: Diameter 6 1/4 X Length 10
LED Lights & LED Light Mode Function
Weight: 1.15 Lbs
Professional Lithium Rechargeable Batteries Megaphone 30 Watt Megaphone / Bullhorn with Siren
30 Watts Power Peak Rechargeable
Lithium Battery (Charger Included)
Battery powered by 4 x D Batteries, Not Included
10 Seconds Integrated Audio Memory
Record and Replay Audio Function
3 Audio Modes: Record, Siren, and Talk
Ergonomic Pistol Grip and Light-Weight Chassis
Megaphones
•
•
•
•
Used by U.S. Armed Forces
For Indoor/Outdoor Use
800 Yard Range
Dimensions: Diameter 6 1/4’’ x Length 10’’
PMP40
Professional Megaphone / Bullhorn w/Siren and Handheld Mic
• Powers Up to 40 Watts
• 1000 Yard Range
• Used By U.S. Army, Schools, And More
• For Indoor/Outdoor Use
• Variable Volume Control
PMP45R
Professional Dynamic Megaphone With Recording Function/Detachable
• Powers Up to 40 Watts
• 10 Second Integrated Audio Memory
• Replay and Recording Audio Function
• 1000 Yard Range
• Used By U.S. Army, Schools, And More
• For Indoor/Outdoor Use
• Variable Volume Control
PMP43IN
PMP48IR
•
•
•
•
•
•
•
•
•
•
3 Audio Modes: Record, Siren, and Talk
Ergonomic Pistol Grip and Light-Weight Chassis
Used by U.S. Armed Forces
For Indoor/Outdoor Use
1,000 Yard Range
Dimensions: Diameter 8” x Length 13 1/8”
Professional Piezo Dynamic Megaphone
• Powerfull Piezo Driver And Large Bell Diameter
For Projection Range Up To One Mile
• 2 Modes Talk And Siren
• For indoor/outdoor use
• Variable volume control
• Eronomic Pistol Grip And Light Weight Chasis
PMP53IN
• Powered By 8 x C batteries, not included
• Dc 12v 2.5Amp please check the polarity of the plug the center and the outside
contacts Power Supply (Not Included)• Dimensions: diameter 9’’ x length 13 3/4’’
• Weight: 2.86 lbs
50 Watts Professional Piezo Dynamic Megaphone w/3.5mm Aux-In For
• Powerfull Piezo Driver And Large Bell Diameter
For Projection Range Up To One Mile
• 2 Modes: Talk And Siren
• For Indoor/Outdoor Use
• Variable Volume Control
• Plug In Any External Source With 3.5mm
PMP55R
• Built-In Siren
• Plug In Any External Source With 3.5mm
Aux-In Jack -- Perfect for iPod/iPhone
• Uses 6 X D Batteries, Not Included
• Dimensions: Diameter 8’’ X Length 13 1/8’’
• Weight: 2.20 Lbs
Professional Megaphone / Bullhorn w/Siren and Handheld Mic
Power 40 Watts Peak Plug in Any External
Source w/ 3.5mm Aux-In Jack
Rechargeable Lithium Battery (Charger Included)
Battery powered by 6 x D Batteries, Not Included
10 Seconds Integrated Audio Memory
Record and Replay Audio Function
PMP50
• Tough Housing
• Built-In Siren
• Operates by Rechargeable Batteries Included
or 6 X D Batteries (Not Included)
• Dimensions: Diameter 8’’ X Length 13 1/8’’
• Weight:2.70Lbs
40 Watts Professional Megaphone / Bullhorn w/Siren and 3.5mm Aux-In
• Up to 40 Watts Power
• 1000 Yard Range
• Used By U.S. Army, Schools, And More
• For Indoor/Outdoor Use
• Variable Volume Control
• Tough Housing
•
• Tough Housing
• Built-In Siren
• Uses 6 X D Batteries, Not Included
• Dimensions: Diameter 8’’ X Length 13 1/8’’
• Weight: 2.20 Lbs
Aux-In Jack -- Perfect for iPod/iPhone
• Eronomic Pistol Grip And Lightweight Chassis
• Powered By 8 x C Batteries - Not Included
• Runs On DC 9v Power Supply - Not Included
• Dimensions: Diameter 9’’ x Length 13 3/4’’
Professional Piezo Dynamic Megaphone With Recording Function & Re-
• Powers Up to 50 Watts
• Powerful Piezo Driver And Large Bell Diameter
• Projection Range Up To One Mile
• 10 Second Integrated Audio Memory
• Replay and Recording Audio Function
• 3 Modes Talk, Record and Siren
• For indoor/outdoor use
• Variable volume control
• Ergonomic Pistol Grip And Light Weight Chassis
• Operates by rechargeable batteries included
or 8 x C Batteries (not Included)
• DC 12V Power Supply (Not Included)
• Dimensions: diameter 9’’ x length 13 3/4’’
• Weight: 3.72 lbs
Megaphones
31
31
PMP58U
Professional Piezo Dynamic 50 Watts Megaphone With USB Function
• Powerful Piezo Driver and Large Bell Diameter
For Projection Range Up To One Mile
• 2 Modes Talk And Siren
• For Indoor/Outdoor Use
• Variable Volume Control
• Ergonomic Pistol Grip And Light Weight Chasis
• USB Input to Play Your Music And Recordings
• Power Output 50 Watts
• Powered By 8 X C Batteries, Not Included
PMP59IR
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Professional Piezo Dynamic Megaphone W/ Talk And Siren
Power 50 Watts Peak
Plug in Any External Source w/
3.5mm Aux-In Jack
Rechargeable Lithium Battery (Charger Included)
Battery powered by 8 x D Batteries, Not Included
10 Seconds Integrated Audio Memory
Record and Replay Audio Function
3 Audio Modes: Record, Siren, and Talk
PMP57LIA
•
•
•
•
•
Ergonomic Pistol Grip and Light-Weight Chassis
Used by U.S. Armed Forces
For Indoor/Outdoor Use
1,200 Yard Range
Dimensions: Diameter 9” x Length 13 3/4”
Professional Piezo Dynamic Megaphone W/ Talk And Siren
Used by U.S. Armed Forces
For Indoor/Outdoor Use
Maximum Power Output: 50 Watt
10 Seconds Integrated Audio Memory
Built-in SD & USB Flash Memory Card Readers
Ergonomic Pistol Grip and Light-Weight Chassis
Rechargeable Lithium Battery (Charger Included)
Battery Powered by 8 x “C”
Batteries, Not Included
6 Audio Functions Including Talk,
Siren & USB/SD
PAMP75
• DC 12v 2.5Amp please check the polarity of the plug the center and the outside
contacts Power Supply (Not Included)
• Dimensions: Diameter 9’’ X Length 13 3/4’’
• Weight: 2.86 Lbs
•
•
•
•
•
Comes with Lithium Rechargeable
Battery - Lasts up to 16 Hours
Plug in MP3 Players or External Devices
to the 3.5mm Aux-In Jack
Dimensions: Diameter 9.44” x Length 13.77”
1,200 Yard Range
Weight: 3.5 Lbs.
150 Watts Portable Amplifier Loudspeaker PA System Microphone Included
• 1/4’’ Mic Sockets, Aux Input Is 6.35mm
• 1 Handheld Cardioid Dynamic Mic
• Powerful 150 Watt Pa Reverberant Horn
Delivers 108db Sound Pressure Level
over the 450 Hz - 4 KHz Audio Range
• Reach Crowds Up To 3000
• Covers The Length Of A Football Field
• Great for Athletic Events
• 110V AC Adapter
PWMA80UFM
100 W Portable PA System w/ Included Wireless Lavalier Microphone
• Wireless Lavalier Microphone
With Belt Clip Included
• Charges In 4 Hours
• Works For 8 Hours On A Full Charge
• Plays MP3s From Micro SD Card or USB Stick
• FM Radio
• 3.5mm Aux-In Jack For Digital Music
Player, iPod, iPhone, etc.
32
32
Megaphones
• 3.5mm Aux-Out Jack - Connect
To A More Powerful Amp
• Max Output: 100 W
• Frequency Response: 200 Hz-15 KHz
• Power Consumption: 150 mA
• Battery Capacity: 1800 mA Lithium
• Material: ABS Plastic
• Dimensions: 6.5’’ x 4.5’’ x 2.8’’
PWMA50S - PWMA50W - PWMA50B
50 Watt Portable, Waist-Band Portable PA System With Headset Mic
• Small Super Powerful Voice Amplifier
• Used by Teachers, Coaches, Tour
Guides, Presentations, US Army
• Built In Rechargeable Lithium Batteries
That Last Up To 12 Hours Of Continuous Use Before Needing A Charge
• Projection Range Up To 1/2 Mile
• Includes Headset Microphone
• AUX Input For MP3 Player Or Ipod
• Frequency Response: 100hz ± 13db1khz ± 1db
• Current Consumption: 150ma
• Charging Time:6 Hours
• Speaker Sensitivity: 53 Dbv/A +- 3 Db
• Unit Includes Charger Belt Clip,
Adjustable Waist Band Strap,
• Rechargeable 7.4 Volt Lithium Battery
• Colors: Silver, Black, White
• Speaker Dimensions 3.86’’ X 3.62’’ X 1.85’’
• Weight: 0.88Lbs
PWMA50S
PWMA50W
PWMA60UB - PWMA60US - PWMA60UW
• Listen to Your Music or your recordings W/ the USB Input
• Unit Includes Charger Belt Clip, Waist Ban,d Strap
• Small Super Powerful Voice Amplifier
• Used by Teachers, Coaches, Tour Guides, US Army
• Built In Rechargeable Lithium Batteries That Last Up To
12 Hours Of Continuous Use Before Needing A Charge
• Projection Range Up To 1/2 Mile
• Includes Headset Microphone
• AUX Input For MP3 Player Or Ipod
• Frequency Response: 100hz ± 13db1khz ± 1db
• Current Consumption: 150ma
• Charging Time: 6 Hours
• Speaker Sensitivity: 53 Dbv/A +- 3 Db
• Rechargeable 7.4 Volt Lithium Battery
PWMA150
PWMA60US
PWMA60UB
PWMA60UW
• Built-In Recahrgable Batteries With 3 Hours
Life - Recharges Completely In Just 7 Hours
• Designed Carrying Handle For Effortless Portability
• 1 1/4’’ Mic Input and 1 Aux 3.5mm Output
• Weight: 5.52 LBS
• Powers by AC 110V
• Dimensions: 11.23’’L, 6.11’’W 7.1’’H
• Total Power Output: 400 Watt
• Battery Indicator Lights
• Mics Included:1 Handheld,1 Headser/Lavalier
• 110/220 V Switchable
Dual Channel 400 Watt Wireless PA System W/USB/SD/MP3, 2 VHF Wireless Microphones (1 Lavalier, 1 Handheld)
• 6’’ Full Range Speaker
• 400 Watts Peak Power
• 8 Ohm Impedance
• USB/SD/MMC Card Reader Function
• LCD Card Reader Display For
Number of song & Play Time
• Internal Rechargeable Battery
• 3.5mm Input Jack With Cable
• Colors Silver, White, Black
• Speaker Dimensions 3.86’’ X 3.62’’ X 1.85’’
• Weight: 0.88Lbs
Dual Channel 400 Watt Wireless PA System w/USB/SD and 2 VHF Wireless Microphones (1 Lavalier, 1 Handheld)
• 8 Ohm Impedance
• Dual Channel System
• 3.5mm Aux Input Jack For iPod MP3 Players
• USB, SD MMC Memory Card Readers
• 6-Inch Full Range Speaker
• Internal Rechargeable Battery
PWMA170
50 Watt Portable, USB Waist-Band Portable PA System With Headset
Portable PA Wireless Speaker System Amplifier With Belt Pack Lavalier/ Headsets w/Two Microphone Inputs
• Ultra-Compact, Portable PA System Ideal For
Business Meetings, Tour Guides, Classroom
Activities, And Various Other Applications
• Wireless Belt Pack Lavalier/ Headset Mic
Included • Full-Range Loudspeaker With
Enormous Power And Incredible Sonic
Performance In A Super-Light Package
PWMA160
PWMA50B
• 1 Mic Inputs and 1 Guitar Input
• Bass/Treble/Echo Control on Main Channel
• Includes Two Wireless Microphones: VHF
Handheld Mic and Lavalier/Headset Mic
• Mic, MP3, Power, and Charging Indicator LEDs
• DC 12V Input For Car Use
• 110V/220V Switchable
Portable PA Systems
33
33
PCMX240I
Battery Powered Portable PA System W/Ipod Docking Station
• Portable PA System
• Powered By Internal Rechargeable Battery
• Microphone Included
• Line/ MIC Input With Volume Control
• RCA Input
• Line Output
• Ipod Docking station
• Master Control
PCMX260MB
Battery Powered Portable PA System w/USB/SD/MP3 Inputs(Microphone Included)
• Portable PA system
• Powered By Internal Rechargeable Battery
• Microphone Included
• USB 2.0/ SD Card Terminal And LCD
• Line/ MIC Input with Volume Control
• RCA Input
• Line Output
• Master Control
• Built-In 7 AH Rechargeable Battery
PCMX265B
Loop (In, Out, Re-Loop), Pitch Control
• Each Input Has Its Own Independent Gain Control
• Master Gain Control
• Battery Level Indicator On Back
• Link Output To Connect To An External Speaker Via 1/4’’ Jack
• Peak Power: 400 W MAX
• Standard Pole Mount: 3.15’’ Depth, 1.40’’ Diameter
• 110/220 V Switchable
• Dimensions: 13.8’’ W X 16.9’’ H X 9.64’’ D
• Color: White
Rechargeable Portable PA System with Wireless MIC
• Built-In 12 V 1.2A Rechargeable batteries
• Built-In one Channel VHF Wireless Receiver
• Wireless Handheld Mic
• 1 MIC Input
• Separate Wired MIC & Wireless MIC Volume Controls
• REC Out
• Power, RF & Charge LED Indicators
• Power ON/OFF Switch
• AC 120V / 60HZ/
34
34
• One Combo XLR/TRS (1/4’’) Jack for Balanced Mic
• Easily Navigate Music Folders Using Built-In Controls
• Auxiliary RCA Jacks for External Music Player (CD Player, iPod)
• Powerful DJ Controls, Including Cue,
Reverse, Loop, Pitch Control
• Link Output: Connect to External Speaker Via 1/4’’ Jack
• Dimensions: 13.8’’ W X 16.9’’ H X 9.64’’ D
Battery Powered Portable PA System With USB/SD, DJ Controls, And Aux Inputs
• Internal Rechargeable Battery
Lasts Up To 12 Hours
• One Combo XLR/TRS (1/4’’) Jack
For Balanced Microphone
• One 1/4” Jack For Instrument Or Microphone
• Auxiliary RCA Jacks For External
Music Player (CD Player, iPod)
• Play MP3 Files From SD Card Or USB Stick
• Easily Navigate Folders Of Music
Using The Built-In Controls
• Powerful DJ Controls, Including Cue, Reverse,
PWMA100
• Telescoping Handle & Caster Wheels
• 200 Watts Peak Power
• 35mm Speaker Stand Mount
• 2 Way Full Range Speaker
• Heavy-Duty Aluminum Construction
• 1-3/8” PA Speaker Stand Mountable
• Professional Quality Microphone Included
• 110/220V Switchable
• Size: 18.52’’H X 15.5’’W X 11.5’’D
Portable PA System with Rechargeable Battery, USB Port, SD Slot, DJ Controls & Aux Inputs
• Master Gain Control
• 110/220 V Switchable
• Battery Level Indicator
• Peak Power: 400 Watt MAX
• Each Input Has Independent Gain Control
• Play MP3 Files From SD Card or USB Stick
• One 1/4’’ Jack For Instrument Or Microphone
• Standard Pole Mount: 3.15’’ Depth, 1.40’’ Diameter
• Internal Rechargeable Battery Lasts Up To 12 Hours
PCMX265W
• Built-In 7 AH Rechargeable Battery
• Telescoping Handle & Caster Wheels
• 400 Watts Peak Power .
• 35mm Speaker Stand Mount
• 2 Way Full Range Speaker
• 110/220V Switchable
• Ipod Not Included
• Size: 18.52’’H x 15.5’’W x 11.5’’D
• DC12~15V For Car Plug
Charger(Adapter Not Included)
• Power Output: 80 Watts
• Available Frequencies (Hz): Set 1 - 201.15,
180.8 / Set 2 - 212.6, 190.1 / Set 3 - 214.2,
193.0 / Set 4 - 215.5, 174.8
• Operating Range: Up to 100Ft
• Color.White
• Dimensions:6.9”W x 4.3”D x 9.7”H
• Weight: 9.7lb
Portable PA Systems
PWMA200
Rechargeable Portable PA System with Wireless Lavalier/Headset MIC
• Built-in 12 V 1.2A Rechargeable batteries
• Built-in One Channel VHF Wireless Receiver
• Wireless Lavaliere/Headset MIC
• 1 Bonus Wired Microphone Included
• FM Radio
• 1 Microphone Input
• Separate Wired MIC & Wireless MIC Volume Controls
• REC Line Out
• Power, RF & Charge LED Indicators
PWMA600
100 Watt Wireless Battery Powered PA System
• Unit Powered by Internal Rechargeable Battery Pack
• XLR 1/4’’ Combo Mic Input
• Stereo RCA Aux Input and Output
• Built In Recharger for 9V Mic Battery
• Independent Volume Gain for Each Input
• Bass and Treble Controls
• On Air, Charge & Power LED Indicators
• Wired and Wireless Handheld Mics Included
• 6.5’’ Full-Range Speaker
PWMA3600
• 100W RMS, 200W Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure for Increased Bass Response
• Telescoping Handle & Caster Wheels
• 35mm Speaker Stand Mount
• Operating Frequency: 177-205 MHz
• 110/220 Voltage Switchable
• Weight: 26.5 lbs.
300 Watt Wireless Rechageable Portable PA System With Lavalier Microphone
• 8’’ Full Range Woofer
• 300 Watts Peak Power
• Includes Wireless Lavalier Microphone
• 2 Mic Input and 1 Guitar Input
• 1 Audio Input For Any External Audio Device
• Stereo RCA Output On Rear Pannel
• 1/4” Output On Front Panel
• Portable Enclosure with Telescoping Handle and Caster Wheels
• 100W RMS, 200W Peak Power
• Unit Battery Life: >4 Hours
• Mic Battery Life: >5 Hours
• Operation Range: 90 Feet
• Ported Enclosure for Increased Bass Response
• Carry Handle
• 35mm Speaker Stand Mount
• Frequency Response: 100Hz-15KHz
• 110/220 Voltage Switchable
• Dimensions: 23.8’’ x 10.24’’ x 13.39’’
• Weight: 30.54
200W VHF Wireless Battery Powered PA System
• Unit Powered by Internal Rechargeable Battery Pack
• 2 Mic, 1 Guitar, and 1 Audio 1/4’’ Inputs
• Echo, Bass and Treble Controls
• RF, Charge, Low Batt & Power LED Indicators
• Dynamic Wireless Mic w/ 3 Position Power Switch & LED
• Operation range: 100 ft.
• 8’’ Full range Speaker
PWMA260
• 50W RMS, 100W Peak Power
• Unit Battery Life: >4 Hours
• Mic Battery Life: >5 Hours
• Operation Range: 100 Feet
• Ported Enclosure for Increased Bass Response
• Carry Handle For Easy Transport
• Operating Frequency: 228.10 MHz
• 110/220 Voltage Switchable
• Dimensions: 10.6’’ x 7.9’’ x 6.2’’
• Weight: 17.6 lbs
200 Watt Wireless Battery Powered PA System
• Unit Powered by Internal Rechargeable Battery Pack
• 3 Channel Mixer
• Two XLR 1/4’’ Combo Mic Inputs
• Stereo RCA Aux Input and Output
• Binding Post Output for External Speaker
• Independent Volume Gain for Each Input
• Master Volume, Bass and Treble Controls
• On Air, Charge & Power LED Indicators
• Wireles Handheld Mic Included
• 8’’ Woofer with 2.5’’ Compression Tweeter
PWMA230
• Power ON/OFF Switch
• AC 120V / 60HZ/
• DC12~15V For Car Plug Charger
(Adapter Not Included)
• Power Output: 80 Watts
• Frequency Range: 160 ~ 270 MHz
• Operating Range: Up to 100Ft
• Color.Black
• Dimensions: 7.1’’W x 4.3’’D x 11.8 H
• Weight: 9.7lb
• 35mm Speaker Stand Mount Hole
• RF, Charge, Low Battery, and Power LED Indicators
• Dimensions:10.6’’ x 9.3’’ x 14.6’’
• 110V/220V Switchable
Portable PA Systems
35
35
PWMA330
300 Watt VHF Wireless Battery Powered PA System W/Echo
• Unit Powered By Internal Rechargeable Battery Pack
• One VHF Wireless Mic With FCC Certificate
• 2 Mic, 1 Guitar And 1 Audio ¼’’ Input
• One 6.35mm Male To 3.5mm
Stereo Female Adaptor
• Echo, Bass And Treble Controls
• RF, Rechargeable, Low Batt And
Power LED Indicator
PWMA370
300 Watt Dual Channel Wireless Rechageable Portable PA System With Handheld Mic
• 8’’ Full Range Woofer
• 300 Watts Peak Power
• Includes 1 Wireless VHF Handheld Microphone
and 1 Lavalier/Headset Microphone
• 2 Mic Inputs/ 1 Guitar Input
• 1 Audio Input For Any External Audio Device
• Stereo RCA Output
PWMA430U
PWMA860I
• 2 Microphone Inputs & Guitar Inputs
• Audio 1/4’’ Input For Ipod/Mp3 Player
• Bass and Treble Controls
• Stereo RCA Output On Rear Pannel
• 35mm Speaker Stand Mount Hole
• 1/4’’ Output On Front Panel
• RF, Charge, Low Battery, and Power LED Indicators
• Dimensions:10.6’’ x 9.3’’ x 14.6’’
• 110V/220V Switchable
500W VHF Wireless Portable PA System /Echo W/Ipod Dock
• Docking System Suitable For Nano & Classic Ipod
• Unit Powered By Internal Rechargeable Battery Pack
• One VHF Wireless Mic With FCC Certificate
• 2 Mic, 1 Guitar And 1 Audio ¼’’ Input
• One 6.35mm Male To 3.5mm
Stereo Female Adaptor
• Echo, Bass And Treble Controls
• RF, Rechargeable, Low Batt And
Power LED Indicator
PWMA890UI
• 1/4’’ Output On Front Panel
• 35mm Speaker Stand Mount Hole
• Portable Enclosure with Telescoping Handle and Caster Wheels
• RF, Charge, Low Battery, and Power LED Indicators
• Dimensions:10.6’’ x 9.3’’ x 14.6’’
• 110V/220V Switchable
300 Watt Wireless Rechageable Portable PA System With FM/USB/SD
• 8’’ Full Range Woofer
• 300 Watts Peak Power
• USB/SD Card Reader
• LCD Card Reader Display For
Number of song & Play Time
• FM Radio With Frequency Display, Auto Scan, Presets
• Portable Enclosure with Telescoping Handle and Caster Wheels
• Handheld Wireless Mic With 3
Position Power Switch
• Operation Range: 100ft
• 8’’ Woofer And 3’’ Compression Tweeter
• 250W RMS, 500W Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure For Increased Bass Response
• Telescoping Handle & Caster Wheels
• Operating Frequency: 169-216mhz
500 Watt Dual Channel Wireless Rechageable Portable PA System
• 8’’ Woofer With Tweeter
• 500 Watts Peak Power
• Includes 1 Wireless VHF Handheld Microphone
and 1 Wireless Lavalier/Headset Microphone
• iPod/iPhone Dock Charges Device and Plays Music
• USB/SD Card Reader For Digital Music
• LCD Card Reader Display For
Number of song & Play Time
• 2 Microphone Inuts and 1 Guitar Inputs
• 1 Audio Inputs 1/4’’ For Any External Audio Device
• Stereo RCA Output on Rear Pannel
36
36
• Handheld Wireless Mic With 3
Position Power Switch
• Operation Range: 100ft
• 8’’ Full Range Speaker
• 150W RMS, 300W Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure For Increased Bass Response
• Telescoping Handle & Caster Wheels
• 1/4” Output On Front Panel
• 3.5mm Retractable Cable for Auxillary Input
Compatible With Any Digital Music Player
• Portable Enclosure with Telescoping Handle and Caster Wheels
• 35mm Speaker Stand Mount Hole
• RF, Charge, Low Battery, and Power LED Indicators
• Dimensions:10.6’’ x 9.3’’ x 17.5’’
• 110V/220V Switchable
Portable PA Systems
PWMA930I
600 Watt VHF Wireless Portable PA System/Echo W/Ipod Dock
• Docking System Suitable For Nano & Classic Ipod
• Unit Powered By Internal Rechargeable Battery Pack
• One VHF Wireless Mic With FCC Certificate
• 2 Mic, 1 Guitar And 1 Audio ¼’’ Input
• One 6.35mm Male To 3.5mm
Stereo Female Adaptor
• Echo, Bass And Treble Controls
• RF, Rechargeable, Low Batt And
Power LED Indicator
PWMA940BTI
600 Watts VHF Wireless Portable PA System w/Microphone,i-Pod Dock & Bluetooth
• Docking System Suitable for Most Ipods
• Bluetooth Audio Connectivity For All Phones
• Unit Powered by Internal Rechargeable Battery Pack
• One VHF wireless Mic with FCC Certificate
• 2 Mic, 1 Guitar and 1 Audio 1/4’’ Input
• One 6.35mm Male to 3.5mm
Stereo Female Adaptor
• Echo, Bass and Treble Controls
• RF, Recharge, Low Batt and Power LED Indicators
• Handheld Wireless Mic with 3 Posi-
PWMA970
• Handheld Wireless Mic With 3 Position Power Switch & Led
• Operation Range: 100ft
• 10” 3 Way Woofer,Mid And Tweeter
• 400w Rms, 800w Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure for Increased Bass Response
• Telescoping Handle & Caster Wheels
• Operating Frequency: 169-216MHz
800 Watt VHF Wireless Portable PA System/Echo w/iPod Dock
• Ipod/MP3 Input Jack with a 3.5mm Cable
• Docking System Suitable for Nano & Classic iPod
• Unit Powered by Internal Rechargeable Battery Pack
• One VHF Wireless Mic with FCC Certificate
• 2 Mic, 1 Guitar and 1 Audio ¼’’ Input
• One 6.35mm Male to 3.5mm
Stereo Female Adaptor
• Echo, Bass and Treble Controls
• RF, Rechargeable, Low Batt and
Power LED Indicator
• Stereo RCA Output
• 1/4” Output On Front Panel
• 3.5mm Retractable Cable for Auxillary Input
Compatible With Any Digital Music Player
• 35mm Speaker Stand Mount Hole
• Portable Enclosure with Telescoping Handle and Caster Wheels
• RF, Charge, Low Battery, and Power LED Indicators
• Dimensions:10.6’’ x 9.3’’ x 14.6’’
• 110V/220V Switchable
800 Watt VHF Wireless Battery Powered Pa System W/Echo/Ipod/MP3 Input Jack
• Ipod/Mp3 Input Jack With A 3.5mm Cable
• Unit Powered By Internal Rechargeable Battery Pack
• One Vhf Wireless Mic With Fcc Certificate
• 2 Mic, 1 Guitar And 1 Audio 1/4’’ Input
• One 6.35mm Male To 3.5mm
Stereo Female Adaptor
• Echo, Bass And Treble Controls
• Rf, Rechargeable, Low Batt And
Power Led Indicator
PWMA1080I
tion Power Switch & LED
• Operation Range: 100ft
• 8’’ Woofer and 3 Compression Tweeters
• 300W RMS, 600W Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure for Increased Bass Response
• Telescoping Handle & Caster Wheels
• Operating Frequency: 169-216MHz
• 110/220 Voltage Switchable
• Dimension: 10.6’’x 9.3’’x 14.6’’
300 Watt Dual Channel Wireless Rechageable Portable PA System
• 8’’ Full Range Woofer
• 300 Watts Peak Power
• Includes 2 Wireless VHF Handheld Microphones
• iPod/iPhone Dock Charges Your
Device and Plays Music
• USB/SD Card Reader For Digital Music
• FM Radio With Auto Scan and Presets
• LCD Card Reader Display For
Number of song & Play Time
• 2 Mic Inputs/1 Guitar Input
• 1 Audio Input For any External audio Device
PWMA1050
• Handheld Wireless Mic With 3 Position Power Switch & LED
• Operation Range: 100ft
• 8’’ Woofer
• 300W RMS, 600W Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure For Increased Bass Response
• Telescoping Handle & Caster Wheels
• Operating Frequency: 169-216mhz
• Handheld Wireless Mic with 3 Position Power Switch & LED
• Operation Range: 100ft
• 10’’ Woofer and Mid and Tweeter
• 400W RMS, 800W Peak Power
• Unit Battery Life: Approx. 5 Hours
• Mic Battery Life: Approx. 45 Hours
• Ported Enclosure for Increased Bass Response
• Telescoping Handle & Caster Wheels
• Operating Frequency: 169-216MHz
• 110/220 Voltage Switchable
Portable PA Systems
37
37
PWMA1090UI
800 Watt Dual Channel Wireless Rechageable Portable PA System
• 10’’ Three-Way Speaker With Woofer,
Mid-Range, and Tweeter
• 800 Watts Peak Power
• Includes 1 Wireless VHF Handheld Microphone
and 1 Wireless Lavalier/Headset Microphone
• iPod/iPhone Dock Charges Your
Device and Plays Music
• USB/SD Card Reader For Digital Music
• LCD Card Reader Display For
Number of song & Play Time
• FM Radio With Auto Scan and Presets
• 3.5mm Retractable Cable for Auxillary Input
PPHP898A
400 Watts 8’’ 2-Way Plastic Molded Powered/Amplified Speaker System
• 8’’Subwoofer
• 1’’ Titanium Compression Driver
• XLR Mic Input
• XLR & Stereo RCA Line Input
• XLR Line Output
• Master Volume, Bass & Treble Control
• Output: 400 Watts Peak/ 200 RMS
PPHP1098A
• Sensitivity: 92 dB 1W/M
• Impedance: 8 ohm
• Crossover Frequency: 3.0K Hz
• 35mm Speaker Stand Mount
• Dimensions: 23.6” H x 18” W x 13.2” D
• Weight: 31 lbs
1000 Watt 15’’ Two-Way PA Speaker
• 15” Woofer
• 1.75” Titanium Compression Driver
• 1/4” Jacks
• Frequency response: (-10dB): 35Hz-20KHz
• 2 Way Ported Enclosure for Extra Bass Response
• Power Max: 1000 Watts
• Power RMS: 500 Watts
38
38
• Power Output: 500 Watts RMS, 1000 Watts Peak
• Crossover Frequency: 3.0K Hz
• 110/220 Voltage Selectable
• 35mm Speaker Stand Mount
• Dimensions: W 20” (f) 12” (b) x D 16” x H 28.5”
• Weight: 49 lbs
• Wheels Handles Included
800 Watt 12’’ Two-Way Plastic Molded Loudspeaker
• 12” Woofer
• 1.5” Titanium Compression Driver
• 1/4” Jacks
• Frequency response: (-10dB): 47Hz -18 KHz
• 2 Way Ported Enclosure for Extra Bass Response
• Power Max: 800 Watts
• Power RMS: 400 Watts
PPHP1593
• Frequency Response: 45Hz-20Khz
• Metal Grill to protect the woofer / Plastic Cabinet
• Crossover Frequency: 3.0Khz
• 35mm Speaker Stand Mount
• Power: AC 115 - 220 Voltage Selectable
• Dimensions: 15.7’’W X 14.6’’D X 21.3’’H
15’’ Two-Way Powered PA Speaker (1000 Watt)
• 15” Woofer
• 1.75” Titanium Compression Driver
• Full Featured 3 Channel Mixer
• Dual XLR and 1/4” Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4” Line Outputs
• Master Volume, Bass Treble Controls
• Frequency response: 35-20 KHz
PPHP1293
• Frequency Response: 45Hz-20Khz
• Metal Grill to protect the woofer / Plastic Cabinet
• Crossover Frequency: 3.0Khz
• 35mm Speaker Stand Mount
• Power: AC 115- 220 Voltage Selectable
• Dimensions: 13.8’’W X 11.8’’D X 19.3’’H
600 Watt 10’’ 2-Way Plastic Molded Powered PA speaker System
• 10’’Subwoofer
• 1’’ Titanium Compression Driver
• XLR Mic Input
• XLR & Stereo RCA Line Input
• XLR Line Output
• Master Volume, Bass & Treble Control
• Output: 600 Watts Peak/ 300 RMS
PPHP1598A
Compatible With Any Digital Music Player
• Stereo RCA Output and 1/4” Output On Front Panel
• 2 Microphone Inputs and 1 Guiatr Inputs
• 1 Audio Input
• Portable Enclosure with Telescoping Handle and Caster Wheels
• 35mm Speaker Stand Mount Hole
• RF, Charge, Low Battery, and Power LED Indicators
• Dimensions:12.2’’ x 10.2’’ x 22.3’’
• 110V/220V Switchable
• Sensitivity: 97 dB 1 W/M
• Impedance: 8 ohm
• Crossover Frequency: 3.0K Hz
• 35mm Speaker Stand Mount
• Dimensions: 28” H x 18.8” W x 15.2” D
• Weight: 42 lbs
• Wheels Handles Included
PA Loudspeaker Cabinets
PPHP895
400 Watts 8’’ 2 Way Plastic Molded Speaker System
• 8’’ Woofer
• 1’’ Titanium Compression Driver
• Dual 1/4 And Speakon Jacks Input
• 2-Way Ported Enclosure For Extra Bass Response
• Ptc Driver Protect
• Power Max: 400 Watts
• Power RMS: 200 Watts
PPHP1095
600 Watts 10’’ 2 Way Plastic Molded Speaker System
• 10’’ Woofer
• 1’’ Titanium Compression Driver
• Dual 1/4 And Speakon Jacks Input
• 2-Way Ported Enclosure For Extra Bass Response
• Ptc Driver Protect
• Power Max: 600Watts
• Power RMS: 300Watts
• Impedance: 80HM+/-20%
PPHP1295
• AC 115V-230V
• Dimensions: 13.8’’ x 11.8’’ x 19.3’’
600 Watts 10’’ Powered 2 Way Plastic Molded Speaker System
• 10’’ Woofer
• 1’’ Titanium Compression Driver
• Xlr Mic Input
• Xlr & Stereo Rca Line Input
• Xlr Line Output
• Master Volume,Bass&Treble Control
• [email protected] SPL: 108dB
• Impedance: 8 Ohms
• Crossover Frequency: 2.8 KHz
• Inputs: Dual Speakon (Parallel)
• 35mm Speaker Stand Mount
• Dimensions: 27.5’’H x 17.5’’W x 14.1’’D
• Weight: 39.7 lbs
400 Watts 8’’ Powered 2 Way Plastic Molded Speaker System
• 8’’ Woofer
• 1’’ Titanium Compression Driver
• Xlr Mic Input• Xlr & Stereo Rca Line Input
• Xlr Line Output
• Master & Mic Volume Control
• Frequency Response: 45HZ-20KHZ
• Power Output: 200Watts Rms, 400Watts Peak
• Crossover Frequency: 3.0KHZ
• 35MM Speaker Stand Mount
PPHP1085A
• Sensiticity: 100 +/- 3DB
• Frequency Pesponse: 45HZ - 20KHZ
• Metal Grill To Protect The Woofer
• Plastic Cabinet
• Crossover frequency: 3.0 KHZ
• 35mm Speaker Stand Mount
• Dimensions:14.0’’x18.5’’x25.0’’
900 Watt 2-Way 15’’ Portable Loudspeaker
• Rugged, Light-Weight Co-Polymer Enclosure
• Multi-angle enclosure for Front of House
or Stage MonitorApplication
• Power Rating: 375W RMS 900W Peak
• 15’’ Woofer, 2’’ Kapton VC
• 1’’ Titanium Compression Driver, Ferro-Fluid Cooled
• Frequency Response (+/-3dB): 35Hz-20kHz
PPHP885A
• Sensiticity: 95+/-3DB
• Frequency Response: 45HZ - 20KHZ
• Metal Grill To Protect The Woofer
• Plastic Cabinet
• Crossover frequency: 3.0 KHZ
• 35 mm Speaker Stand Mount
• Dimensions: 15.7’’x14.6’’x21.3’’
800 Watts 12’’ 2 Way Plastic Molded Speaker System
• 12’’ Woofer
• 2.5’’ Titanium Compression Driver
• Dual 1/4 And Speakon Jacks Input
• 2-Way Ported Enclosure For Extra Bass Response
• Ptc Driver Protect
• Power Max: 800Watts
• Power Rms: 400Watts
• Impedance: 80HM +/- 20%
PPHP1595
• Impedance: 80HM+/-20%
• Sensitivity: 95+/-3DB
• Frequency Response: 45HZ-20KHZ
• Metal Grill To Protect The Woofer/Plastic Cabinet
• Crossover Frequency: 3.0KHZ
• 35MM Speaker Stand Mount
• Dimensions: 13.8’’ x 11.8’’ x 19.3’’
• Frequency Response: 45HZ-20KHZ
• Power Output: 300Watts Rms, 600Watts Peak
• Crossover Frequency: 3.0KHZ
• 35MM Speaker Stand Mount
• AC 115V-230V
• Dimensions: 15.7’’ x 14.6’’ x 21.3’’
PA Loudspeaker Cabinets
39
39
PPHP1285A
800 Watts 12’’ Powered 2 Way Plastic Molded Speaker System
• 12’’ Woofer
• 2.5’’ Titanium Compression Driver
• Xlr Mic Input
• Xlr & Stereo Rca Line Input
• Xlr Line Output
• Master Volume, Bass & Treble Control
PPHP1585A
1000 Watts 15’’ Powered 2 Ways Plastic Molded Speaker system
• 15’’ Woofer
• 3’’ Titanium Compression Driver
• Xlr Mic Input
• Xlr & Stereo Rca Line Input
• Xlr Line Output
• Master Volume, Bass & Treble Control
PPHP1288A
• Frequency response: 47-18 KHz
• Power Output: 400 Watts RMS, 800 Watts Peak
• Crossover Frequency: 3.0K Hz
• 35mm Speaker Stand Mount
• 110/220 Voltage Selectable
• Dimensions: :25’’H x 14’’W x 18.5’’D
1000 Watts 15’’ Two-Way Active/Powered Plastic Molded Speaker
• 15’’ Woofer
• 1.75’’ Titanium Compression Driver
• Full Featured 3 Channel Mixer
• Dual XLR and 1/4’’ MIC Inputs
• XLR & Stereo RCA Line Inputs
• XLR and 1/4’’ Line Outputs
• Master Volume, Bass Treble Controls
PPHP1299AI - PPHP1599AI
• Power Switch and Digital amplifier
• Built-in Ipod Docking Station
• USB
• Titanium Compression Driver
• MP3 control with LCD display
• XLR and 1/4” Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4” Line Outputs
• Volume, Bass Treble Controls
• 2-Way, 2-Speaker Professional speaker
• High Efficiency Mid-Low Woofer
• 35mm Titanium Dome Horn Driver
PPHP129WMU
• Frequency response: 35-20 KHz
• Power Output: 500 Watts RMS, 1000 Watts Peak
• Crossover Frequency: 3.0K Hz
• 110/220 Voltage Selectable
• 35mm Speaker Stand Mount
• Dimensions:29.5’’H x 20.5’’W x 19’’D
• Weight: 49 lbs
12’’ 1000 Watt & 15” 1600 Watt Powered 2 Way Full Range Loud Speaker System
• PTC Driver Protect
• Impedance: 8 Ohm ±20%
• Sensitivity: 101±3dB
• Frequency Response: 50Hz-20 KHz (-3dB)
• Metal Grill To Protect The Woofer/Plastic Cabinet
• Crossover Frequency: 3.5K Hz
• 35mm Speaker Stand Mount
• 110/220 AC
12” 1000 Watt Portable Loudspeaker System - Built-in Rechargeable Battery, FM Radio, LCD Readout
• LCD Readout Display
• Bluetooth Capability
• 2 Microphones Included
• Microphone/Guitar Inputs
• Sensitivity: 93db(+/-2db)
• USB & SD Card Slot Readers
• Frequency Response: 55-18k HZ
• Total Power Output: 1,000 Watt
• Wireless Remote Control Included
• Tweeter: 34mm Driver 12.5oz. 8Ohm
40
40
• Frequency Response: 45Hz - 20Khz
• Power Output: 500 Watts Rms, 1000 Watts Peak
• Crossover Frequency: 3.0 KHZ
• 35mm Speaker Stand Mount
• AC 115V-230V
• Dimensions:20.5’’ x 19.0’’ x 29.5’’
800 Watts Powered 12’’ Two-Way Plastic Molded Speaker System
• 12’’ Woofer
• 1.5’’ Titanium Compression Driver
• Full Featured 3 Channel Mixer
• XLR Mic Input
• XLR & Stereo RCA Line Input
• XLR Line Output
• Master Volume, Bass Treble Controls
PPHP1588A
• Frequency Response: 45Hz - 20Khz
• Power Output: 200 Watts RMS, 800 Watts Peak
• Crossover Frequency: 3.0 Khz
• 35mm Speaker Stand Mount
• AC 115V - 200V
• Dimensions:14.0’’ x 18.5’’ x 25.0’’
• Subwoofer: 40 oz. - 2” KSV - Impedance: 4 Ohm
• Power Output: 30 Watt RMS
100 Watt Peak Power
• Wired/Wireless Microphone Com
patible (VHF 30 Meters)
Built-in Rechargeable Battery
with 4 Hour Battery Life
• Dimensions (WxDxH): 13.4” x 12.2” x 22.6”
PA Loudspeaker Cabinets
PPHP1259
500 Watt 12’’ 2 Way Full Range Loud PA Speaker
• 12’’ Woofer
• 1.5’’ Titanium Compression Driver
• Frequency Range (-10 dB): 47Hz - 18KHz
• 2-Way Ported Enclosure for Extra Bass Response
• 1/4’’ and Speakon Jacks
• Power Max: 500 Watts
• Power RMS: 250 Watts
PPHP1559
700 Watt 15’’ Two-Way Plastic Molded Speaker Cabinet
• 15’’ Woofer
• 1.75’’ Titanium Compression Driver
• Frequency Range (-10 dB): 35Hz - 20KHz
• 2-Way Ported Enclosure for Extra Bass Response
• 1/4’’ and Speakon Jacks
• Power Max: 700 Watts
• Power RMS: 350 Watts
PPHP150A
PPHP103MU
• 3.5mm Aux-In Compatible With All Digital
Music Players, Including iPhone
• Frequency Response: 45 Hz-20 KHz
• Power Output: 300 Watts RMS, 600 Watts Peak
• Crossover Frequency: 3.0 KHz
• Integrated 35mm Speaker Stand Mount
• Dimensions: 14.2’’ W x 11.4’’ D x 21.3’’ H
600 Watts 10’’ 2 Way Plastic PA Speaker
• 10’’ Woofer
• 1’’ Titanium Compression Driver
• Dual 1/4 And Speakon Jacks Input
• 2-Way Ported Enclosure For Extra Bass Response
• Ptc Driver Protect
• Power Max: 600Watts
• Power RMS: 300Watts
• Impedance: 80HM+/-20%
• Sensiticity: 95+/-3DB
• Frequency Response: 45HZ - 20KHZ
• Metal Grill To Protect The Woofer
• Plastic Cabinet
• Crossover frequency: 3.0 KHZ
• 35 mm Speaker Stand Mount
• Dimensions: 15.7’’ x 14.6’’ x 21.3’’
600 Watts 10’’ Powered 2 Way PA Speaker
• 10’’ Woofer
• 1’’ Titanium Compression Driver
• 3.5mm iPod Input
• XLR Mic Input
• XLR & Stereo Rca Line Input
• XLR Line Output
• Power Output: 1200 Watts
• Impedance: 8 Ohm ±20%
• Sensitivity: 101±3dB
• Frequency Response: 40Hz-22 KHz (-3dB)
• Metal Grill To Protect The Woofer, Plastic Cabinet
• Crossover Frequency: 3.5K Hz
• 35mm Speaker Stand Mount
• 110/220 Voltage Selectable
• Dimensions: 18.3’’W x 15.8’’D x 27.2’’H
10’’ 600 Watt Powered Two-Way PA Speaker with MP3/USB/SD Playback
• 10’’ Woofer
• Compression Driver with 1’’ Titanium Diaphragm
• Full Featured 3 Channel Mixer
• XLR and 1/4’’ Mic Inputs
• XLR & Stereo RCA Line Input
• XLR and 1/4’’ Line Outputs
• Master Volume, Treble, and Bass Controls
• Plays MP3s From SD Card / USB Stick
PPHP106A
• Sensitivity: 97dB 1W/1M
• Nominal Impedance: 8 Ohm
• Integrated 35mm Speaker Stand Mount
• Crossover Frequency: 3.0K Hz
• 35mm Speaker Stand Mount
• Dimensions: 29.2’’H x 20’’W x 15.6’’D
• Weight:42 lbs.
15’’ 1200 Watt Powered 2 Way Full Range Loud Speaker System
• 15’’ Subwoofer
• 2-Way, 2-Speaker Professional speaker
• 1.7” Titanium Compression Driver
• Dual XLR and 1/4” Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4” Line Outputs
• Master Volume, Bass Treble Controls
• High Efficiency Mid-Low Woofer
• 35mm Titanium Dome Horn Driver
• PTC Driver Protect
PPHP104
• Sensitivity: 92dB 1W/1M
• Nominal Impedance: 8 Ohm
• 35mm Speaker Stand Mount
• Metal Grill To Protect The Woofer/Plastic Cabinet
• Crossover Frequency: 3.0K Hz
• Dimensions: 22.6’’H x 16.1’’W x 12’’D
• Weight: 31 lbs.
• Master Volume,Bass&Treble Control
• Frequency Response: 45HZ-20KHZ
• Power Output: 300Watts Rms, 600Watts Peak
• Crossover Frequency: 3.0KHZ
• 35MM Speaker Stand Mount
• AC 115V-230V
PA Loudspeaker Cabinets
41
41
PPHP123MU
12’’ 1000 Watt Powered Two-Way PA Speaker with MP3/USB/SD/3.5mm Input
• 12’’ Woofer
• Compression Driver with 1.75’’ Titanium Diaphragm
• Full Featured 3 Channel Mixer
• XLR and 1/4’’ Mic Inputs
• XLR & Stereo RCA Line Input
• XLR and 1/4’’ Line Outputs
• Master Volume, Treble, and Bass Controls
• Plays MP3s From SD Card / USB Stick
PPHP1037UB
•
•
•
•
•
•
•
•
10’’700 Watt Powered Two-Way Speaker With MP3/USB/SD/Bluetooth, Record Function & Remote Control
10’’ Woofer
Compression Driver with 1.75’’ Titanium Diaphragm
Full Featured 3 Channel Mixer
XLR and 1/4’’ Mic Inputs
RCA Line input
XLR and 1/4” Line Output
Master Volume, Treble, and Bass Controls
3.5mm Aux-In Compatible With All
Digital Music Players, Including iPhone
Bluetooth Streaming Music Function
Recording to USB SD card function
IR Remote Control
Frenquency : 46HZ-3KHZ - Sensitivity : 98db
•
•
•
•
PPHP1237UB
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Voice coil :1.75inch
Magnet : 50oz.170mm
Impendance : 8ohm - Sensitivity : 110db/m.w
Frequency Range : 600Hz-20Khz
Diaphragm matrial : Titanium
Voice coil : Kapton 44.4mm(1.4inch)
Frequency responese: 30-22Khz
Power output : 450watts RMS, 900 Watt peak
Crossover Frequency : 2.2Khz
110/220 voltage selectable
Carrying wheels and handle
Dimensions: 16.5”W X 13.7”D X25.1”H
Weight :34lbs
•
•
•
•
•
•
•
•
•
•
•
•
•
Voice coil : 75mm,3inch
Magnet : 60oz.170mm
Sensitivity : 110db/m.w - Impendance : 4ohm
Frequency Range : 600Hz-20Khz
Diaphragm matrial : Titanium
Voice coil : Kapton 44.4mm(1.75inch)
Frequency responese: 30-22Khz
Power output : 600watts RMS, 1200Watts peak
Crossover Frequency : 2.2Khz
110/220 voltage selectable
Carrying wheels and handle
Dimensions: 19”W X 15.7”D X29.1”H
Weight :42lbs
1000 Watts 12’’ Powered 2 Way Plastic Molded PA Speaker With Wheels
• 12’’ Woofer
• 1.34’’ Titanium Compression Driver
• 3.5mm iPod Input
• XLR Mic Input
• XLR & Stereo Rca Line Input
• XLR Line Output
• Master Volume, Bass & Treble Control
42
42
Voice coil : 75mm,3inch
Magnet : 60oz.170mm
Impendance : 4ohm - Sensitivity : 110db/m.w
Frequency Range : 600Hz-20Khz
Diaphragm matrial : Titanium)
Frequency responese: 30-22Khz
Power output : 350watts RMS, 700Watts peak
Crossover Frequency : 2.2Khz
110/220 voltage selectable
Integrated 35mm Speaker Stand Mount
Carrying wheels and handle
Dimensions: 14.1”W X 11.4”D X21.2”H
Weight :23lbs
15’’1200 Watt Powered Two-Way Speaker With MP3/USB/SD/Bluetooth, Record Function & Remote Control
15’’ Woofer
Compression Driver with 1.75’’ Titanium Diaphragm
Full Featured 3 Channel Mixer
XLR and 1/4’’ Mic Inputs
XLR and Stereo RCA Line input
XLR and 1/4” Line Output
Master Volume, Treble, and Bass Controls
3.5mm Aux-In Compatible With All
Digital Music Players, Including iPhone
Bluetooth Streaming Music Function
Recording to USB SD card function
IR Remote Control
Frenquency : 46HZ-3KHZ - Sensitivity : 98db
PPHP126A
•
•
•
•
•
•
•
•
•
•
•
•
•
12’’900 Watt Powered Two-Way Speaker with MP3/USB/SD/Bluetooth, Record Function & Remote Control
12’’ Woofer
Full Featured 3 Channel Mixer
XLR and 1/4’’ Mic Inputs
XLR and Stereo RCA Line input
XLR and 1/4” Line Output
Master Volume, Treble, and Bass Controls
3.5mm Aux-In Compatible With All
Digital Music Players, Including iPhone
Bluetooth Streaming Music Function
Recording to USB SD card function
IR Remote Control
Sensitivity : 98db
Frenquency : 46HZ-3KHZ
PPHP1537UB
• 3.5mm Aux-In Compatible With All Digital
Music Players, Including iPhone
• Frequency Response: 30 Hz-22 KHz
• Power Output: 500 Watts RMS, 1,000 Watts Peak
• Crossover Frequency: 2.2 KHz
• Integrated 35mm Speaker Stand Mount
• Dimensions: 16.5’’ W x 13.8’’ D x 25.2’’ H
• Frequency Response: 45Hz - 20Khz
• Power Output:1000 Watts Peak
and 500 Watts RMS
• Crossover Frequency: 3.0 Khz
• 35mm Speaker Stand Mount
• Wheels and Carrying Handle For easy Transport
• AC 115V - 200V
PA Loudspeaker Cabinets
PPHP127AI
12’’ 1200 Watt Powered 2 Way Full Range PA Speaker w/Built-In iPod Dock USB SD and Remote Control
• 12’’ Subwoofer
• Power Switch and Digital Amplifier
• Built-in iPod Docking Station
• Play MP3 Music From USB/SD Card
• Remote Control For USB/SD Functions
• 1.34’’ Titanium Compression Driver
• XLR and 1/4’’ Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4’’ Line Outputs
• Volume, Bass Treble Controls
• 2-Way Professional speaker
• High Efficiency Mid-Low Woofer
PPHP128AI
12’’ 1200 Watt Powered 2 Way Full Range PA Speaker w/Built-In iPod Dock USB SD and Remote Control
• 12’’ Subwoofer
• Power Switch and Digital Amplifier
• Built-in iPod Docking Station
• Play MP3 Music From USB/SD Card
• Remote Control For USB/SD Functions
• 1.34’’ Titanium Compression Driver
• XLR and 1/4’’ Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4’’ Line Outputs
• Volume, Bass Treble Controls
• 2-Way Professional speaker
• High Efficiency Mid-Low Woofer
PPHP153MU
• Frequency Response: 45Hz - 20Khz
• Power Output: 600 Watts RMS 1200 Watts Peak
• Wheels and Carrying Handle For Easy Transport
• Crossover Frequency: 3.0 KHZ
• 35mm Speaker Stand Mount
• AC 115V-230V
15’’ 1400 Watt Portable Powered 2 Way Full Range PA Speaker w/Built-in iPod Dock USB SD and Remote
• 15’’ Subwoofer
• Built-in iPod Dock
• Play MP3 Music Direct From USB/SD card
• Remote Control For USB SD card Songs
• Power Switch and Digital Amplifier
• 1.75’’ Titanium Compression Driver
• XLR and 1/4” Mic Inputs
• XLR Stereo RCA Line Input
• XLR and 1/4’’ Line Outputs
• Master Volume, Bass Treble Controls
• 2-Way, 2-Speaker Professional speaker
• 3.5mm Aux-In Compatible With All Digital
Music Players, Including iPhone
• Frequency Response: 30 Hz-22 KHz
• Power Output: 500 Watts RMS, 1000 Watts Peak
• Crossover Frequency: 2.2 KHz
• Integrated 35mm Speaker Stand Mount
• Dimensions: 19.3’’ W x 15.7’’ D x 29.1’’ H
• Weight: 58.8 lbs
1200 Watts 15’’ Powered 2 Way Plastic Molded PA Speaker With Wheels For Easy Transport
• 15’’ Woofer
• 1.75’’ Titanium Compression Driver
• 3.5mm iPod Input
• XLR Mic Input
• XLR & Stereo Rca Line Input
• XLR Line Output
• Master Volume, Bass & Treble Control
PPHP157AI
• 35mm Titanium Dome Horn Driver
• Carrying Handle For Easy Transport
• PTC Driver Protect
• Power Output: 700 Watts RMS 1400 Watts Peak
• Impedance: 8 Ohm ±20%
• Sensitivity: 101±3dB
• Frequency Response: 50Hz-20 KHz (-3dB)
• Metal Grill To Protect The Woofer/Plastic Cabinet
• Carrying wheels included for easy transport
• 35mm Speaker Stand Mount
• Microphone and Mic Cable Included
• Remote Control Included
15’’ 1000 Watt Powered Two-Way PA Speaker with MP3/USB/SD Playback
• 15’’ Woofer
• Compression Driver with 1.75’’ Titanium Diaphragm
• Full Featured 3 Channel Mixer
• XLR and 1/4’’ Mic Inputs
• XLR & Stereo RCA Line Input
• XLR and 1/4’’ Line Outputs
• Master Volume, Treble, and Bass Controls
• Plays MP3s From SD Card / USB Stick
PPHP156A
• 35mm Titanium Dome Horn Driver
• Carrying Handle For Easy Transport
• PTC Driver Protect
• Power Output: 600 Watts RMS 1200 Watts Peak
• Impedance: 8 Ohm ±20%
• Sensitivity: 101±3dB
• Frequency Response: 50Hz-20 KHz (-3dB)
• Metal Grill To Protect The Woofer/Plastic Cabinet
• Crossover Frequency: 3.5K Hz
• 35mm Speaker Stand Mount
• 110/220 AC
• High Efficiency Mid-Low Woofer
• 35mm Titanium Dome Horn Driver
• PTC Driver Protect
• Power Output: 600 Watts RMS 1400 Watts Peak
• Impedance: 8 Ohm ±20%
• Sensitivity: 101±3dB
• Frequency Response: 40Hz-22 KHz (-3dB)
• Metal Grill To Protect The Woofer/Plastic Cabinet
• Crossover Frequency: 3.5K Hz
• 35mm Speaker Stand Mount
• 110/220 AC
PA Loudspeaker Cabinets
43
43
PPHP803MU
8’’ 600 Watts Powered Two-Way PA Speaker with MP3/USB/3.5mm Input
• 8’’ Woofer
• Compression Driver with 1’’ Titanium Diaphragm
• 3 Separate Volume Controls
• 1/4’’ Mic Inputs
• RCA Line Input
• 1/4’’ Line Outputs
• Master Volume
• Plays MP3s / USB Stick
PPHP86A
400 Watts Two-Way 8’’ Powered PA Speaker System
• 8’’ Woofer
• 1’’ Titanium Compression Driver
• 3.5mm iPod Input
• XLR Mic Input
• XLR & Stereo Rca Line Input
• XLR Line Output
PADH1079
• Built in Crossover Network
• Power Handling: 300 Watts RMS/600 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 15’’W x 14’’D x 25’’H
15 Inch 800 Watt 2 Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 15’’x 17’’ Super Horn Midrange/Tweeter
• 15’’ Subwoofer 2.5’’ Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 40 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
44
44
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 3KHz
• Power Handling: 300 Watts RMS/600 Watts Peak
• Frequency Response: 40-20K HZ
• Sensitivity (1w/1m): 97 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 17.75’’W x 26’’H x 16’’D
600 Watt 12’’ 2 - Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 12’’x 14’’ Super Horn Midrange/Tweeter
• 12’’ Subwoofer 2’’ Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
PADH151
• Dual Speakon Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 4KHz
• Power Handling: 250 Watts RMS/500 Watts Peak
• Frequency Response: 40-20K HZ
• Sensitivity (1w/1m): 97 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 15.25’’W x 20’’H x 12.75’’D
600 Watt 12’’ Two-Way Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 4’’x12’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• 12’’ Subwoofer 2’’ Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
PADH121
• Master Volume, Bass & Treble Control
• Frequency Response: 45HZ-20KHZ
• Power Output: 200 Watts RMS, 400 Watts Peak
• Crossover Frequency: 3.0KHZ
• 35MM Speaker Stand Mount
• AC 115V-230V
500 Watt 10’’ Two-Way Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 4’’x10’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• 10’’ Subwoofer 1.5’’ Kapton VC
• Woofer Magnet Weight:50 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
PADH1279
• 3.5mm Aux-In Compatible With All Digital
Music Players, Including iPhone
• Frequency Response: 45 Hz-20 KHz
• Power Output: 300 Watts RMS, 600 Watts Peak
• Crossover Frequency: 3.0 KHz
• Integrated 35mm Speaker Stand Mount
• Dimensions: 11.8’’ W x 9.8’’ D x 17.3’’ H
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 400 Watts RMS/800 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
PA Loudspeaker Cabinets
PADH181
1000 Watt 18’’ 2 - Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 16’’x 20’’ Super Horn Midrange/Tweeter
• 18’’ Subwoofer 3’’ Kapton VC
• Woofer Magnet Weight: 120 oz
• Compression Tweeter Magnet Weight: 40 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built in Crossover Network
PADH124
1200 Watt Dual 12’’ 3 Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 12’’x 14’’ Super Horn Midrange/Tweeter
• Dual 12’’ Subwoofer 2’’ Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
PADH152
• Caster Wheels Included
• Dual Speakon Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network
• Power Handling: 700 Watts RMS/1400 Watts Peak
• Frequency Response: 20-20K HZ
• Sensitivity (1w/1m): 108 dB
• Impedance: 8 Ohms
• Dimensions: 54’’W x 24.4’’D x 18’’H
• Weight: 121 lbs
1600 Watt Dual 15’’ 3 Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 15’’x 17’’ Super Horn Midrange/Tweeter
• Dual 15’’ Subwoofer 2.5’’ Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 40 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built in Crossover Network
• Caster Wheels Included
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 2KHz/5KHz
• Power Handling: 600 Watts RMS/1200 Watts Peak
• Frequency Response: 30-20K HZ
• Sensitivity (1w/1m): 108 dB
• Impedance: 8 Ohms
• Dimensions: 21.25’’W x 17.5’’D x 47’’H
• Weight: 117 lbs
1400 Watt Dual 18’’ 8-Way Stage Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 5’’x15’’ Super Horn Midrange/Tweeter
• 1.5’’ Titanium Compression Driver Loaded in Horn
• Five Piezo Tweeters
• Two 18’’ Subwoofers 3’’ Kapton VC
• Woofer Magnet Weight: 100 oz
• Compression Tweeter Magnet Weight: 24 oz
• Quad Ports for Added Bass Response
• Heavy Duty Handles for Easy Portability
PADH153
• Built in Crossover Network
• Power Handling: 600 Watts RMS/1200 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 18’’W x 16’’D x 46’’H
1200 Watt Dual 15’’ 8-Way Stage Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 5’’x15’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• Five 3’’ Piezo Tweeters
• Two 15’’ Subwoofers 2.5’’ Kapton VC
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Quad Ports for Added Bass Response
• Heavy Duty Handles for Easy Portability
PADH182
• Power Handling: 500 Watts RMS/1000 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 22’’W x 18’’D x 34’’H
• Power Handling: 800 Watts RMS/1600 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Built in Crossover Network
• Power Handling: 1000 Watts RMS/2000 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 22’’W x 18’’D x 53’’H
PA Loudspeaker Cabinets
45
45
PADH183
2000 Watt Dual 18’’ 3 Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 16’’x 20’’ Super Horn Midrange/Tweeter
• Dual 18’’ Subwoofer 3’’ Kapton VC
• Woofer Magnet Weight: 120 oz
• Compression Tweeter Magnet Weight: 40 oz
• Ported Enclosure for Added Bass Response
PADH1549
15’’ 1000 Watts 2-Way Speaker Cabinet
• Subwoofer 2.5’’Kapton VC
• 12’’x 18’’ Super Horn Midrange/Tweeter
• Tweeter: 1.75’’ Titanium Compression Driver
• Woofer Magnet:90oz
• Tweeter Magnet:24oz
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Build-in Crossover:
PADH1569
• Frequency Response:20Hz-20KHz
• Imedance:8 Ohm
• Max Power:4000W
• Power RMS:2000W
• Sensitivity(1w/1m):110dB
• Dimensions:57.8’’Hx25’’W20.4’’D
300 Watt 8’’ Two-Way Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 3’’x7’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• 8’’ Subwoofer 1.5’’ Kapton VC
• Woofer Magnet Weight: 40 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
46
46
• Build-in Crossover:
• Frequency Responce:30Hz-20KHz
• Impedance:8 Ohm
• Max Power:2000W
• Power RMS:1000W
• Sensitivity(1w/1m):107dB
• Dimensions:42.4’’Hx18.6’’Wx16.2’’D
2 x 21’’ 4000 Watts Dual Speaker Cabinet
• 2x21’’Subwoofer 4.0’’Kapton VC
• 12’’x18.8 Super Horn Midrange/Tweeter
• 1.75’’Titanium Compression Driver
• Woofer Magnet:200oz
• Tweeter Magnet:24oz
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Build-in Crossover:
PADH879
• Heavy Duty Handles for Easy Portability
• Dual Speakon Dual 1/4” Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 500Watts RMS/ 1000 Watts Peak
• Frequency Response: 35-20K Hz
• Sensitivity (1w/1m): 107dB
• Impedance: 8 Ohms
• Dimensions: 19.8” (W) x 16” (D) x 34.4” (H)
2 x 15’’ 2000 Watts Dual Speaker Cabinet
• 2x15’’ Subwoofer 2.5’’ Kapton VC
• 5’’x15’’ Super Horn Midrange/Tweeter
• Tweeter:1.75’’ Titanium Compression Driver
• Woofer Magnet:90oz
• Tweeter Magnet:24oz
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
PADH2172
• Frequency Response:30Hz-20KHz
• Impedance:8 Ohm
• Max Power:1000W
• Power RMS:500W
• Sensitivity(1w/1m):10dB
• 35mm Speaker Stand Mount
• Dimensions: 31’’H x 21.2’’W x 17’’D
1000 Heavy Duty 2 Way Pa Loud-speaker Cabinet
• Heavy Duty MDF Construction
w/ Reinforced Corners
• 6” x 17” Super Horn Midrange/ Tweeter
• 1.5” Titanium Compression Driver Loaded in Horn
• Five Piezo Tweeters
• 15” Subwooofer 2.5” Kapton VC
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclousure for Added Bass Response
PADH1572
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• 35mm Speaker Stand Mount
• Dimensions: 15’’W x 14’’D x 38’’H
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 5KHz
• Power Handling: 150 Watts RMS/300 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 96 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 13.5’’W x 19’’H x 12’’D
PA Loudspeaker Cabinets
PADH1579
800 Watt 15’’ Two-Way Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 4’’x12’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• 15’’ Subwoofer 2.5’’ Kapton VC
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
PADH1289
600 Watt 12’’ Five-Way PA Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 5’’x 12’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• Three Piezo Tweeters
• 12’’ Subwoofer 2’’ Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
PADH1589
• Dual Speakon Dual 1/4’’ Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 500 Watts RMS/1000 Watts Peak
• Frequency Response: 20-20K HZ
• Sensitivity (1w/1m): 107 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Caster Wheels Included
• Dimensions: 38’’W x 22.8’’D x 18’’H
18’’ 1600 Watts 2-Way Speaker Cabinet
• 18’’ Subwoofer 3.0’’ Kapton VC
• 12’’x18’’ Super Horn Midrange/Tweeter
• Tweeter:1.75’’ Titanium Comperession Driver
• Woofer Magnet:100oz
• Tweeter Magnet: 24oz
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 400 Watts RMS/800 Watts Peak
• Frequency Response: 35-20K HZ
• Sensitivity (1w/1m): 107 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 21’’W x 15’’D x 30.5’’H
• Weight: 65 lbs
1000 Watt 18’’ Seven-Way Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 5’’x15’’ Super Horn Midrange/Tweeter
• 1.5’’ Titanium Compression Driver Loaded in Horn
• Five Piezo Tweeters
• 18’’ Subwoofer 3’’ Kapton VC
• Woofer Magnet Weight: 100 oz
• Compression Tweeter Magnet Weight: 24 oz
• Heavy Duty Handles for Easy Portability
• Ported Enclosure for Added Bass Response
PADH1849
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 300 Watts RMS/600 Watts Peak
• Frequency Response: 50-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 18’’W x 14’’D x 27.5’’H
• Weight: 50 lbs
800 Watt 15’’ Six-Way Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 5’’x15’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• Four Piezo Tweeters
• 15’’ Subwoofer 2.5’’ Kapton VC
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Heavy Duty Handles for Easy Portability
• Ported Enclosure for Added Bass Response
PADH1889
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 2KHz
• Power Handling: 400 Watts RMS/800 Watts Peak
• Frequency Response: 40-20K HZ
• Sensitivity (1w/1m): 98 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount
• Dimensions: 20’’W x 30’’H x 18’’D
• Build-in Crossover:
• Frequency Response: 25Hz-20KHz
• Impendence: 8 Ohm
• Max Power: 1600W
• Power RMS: 800W
• Sensitivity (1w/1m): 110dB
• Dimensions:34.6’’Hx22.6’’Wx17’’D
PA Loudspeaker Cabinets
47
47
PADH2149
21’’ Speaker Cabinet System
• 21’’ Subwoofer 4.0’’ Kapton VC
• 12’’x18’’ Super Horn Midrange/Tweeter
• Tweeter:1.75’’ Titanium Compresssion Driver
• Woofer Magnet: 24oz
• Tweeter Magnet: 24oz
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
PADH212
1600W Heavy Duty 7 Way Pa Loud-speaker Cabinet
• Heavy Duty MDF Construction
w/ Reinforced Corners
• 5” x 12” Super Horn Midrange/ Tweeter
• 1.5” Titanium Compression Driver Loaded in Horn
• Four Piezo Tweeters
• 2 x 12” Subwooofer 2” Kapton VC
• Woofer Magnet Weight: 80 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclousure for Added Bass Response
PADH215
PADH21580
• Caster Wheels Included
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 2KHz
• Power Handling: 700 Watts RMS/1400 Watts Peak
• Frequency Response: 20-20K HZ
• Sensitivity (1w/1m): 100 dB
• Impedance: 8 Ohms
• Dimensions: 19.7’’W x 15.8’’D x 46’’H
Dual 10’’ Heavy Duty 3-Way Speaker Cabinet
• Heavy Duty MDF Construction
• 6’’ x 7’’ Super Horn Midrange/ Tweeter
• 1.35’’ Titanium Compression Driver Loaded in Horn
• 2 x 10’’ Subwooofer 1.5’’ Kapton VC
• Woofer Magnet Weight: 30 oz
• Compression Tweeter Magnet Weight: 15 oz
• Ported Enclousure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• One Speakon One 1/4’’ Jack
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 300 Watts RMS / 600 Watts Peak
• Frequency Response: 40-20K Hz
• Sensitivity (1w/1m): 91dB
• Impedance: 8 Ohms
• Dimensions: 14.8’’W x 38’’H x 14.4’’D
Dual 12’’ Heavy Duty 3-Way Speaker Cabinet
• Heavy Duty MDF Construction
• 6’’ x 7’’ Super Horn Midrange/ Tweeter
• 1.35’’ Titanium Compression Driver Loaded in Horn
• 2 x 12’’ Subwooofer 1.5’’ Kapton VC
• Woofer Magnet Weight: 40 oz
• Compression Tweeter Magnet Weight: 15 oz
• Ported Enclousure for Added Bass Response
• Heavy Duty Handles for Easy Portability
48
48
• Heavy Duty Handles for Easy Portability
• Dual Speakon Dual 1/4” Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 1000Watts RMS/ 2000 Watts Peak
• Frequency Response: 35-20K Hz
• Sensitivity (1w/1m): 107dB
• Impedance: 8 Ohms
• Dimensions: 19.8” (W) x 16” (D) x 48.8” (H)
1400 Watt Dual 15’’ 3-Way Stage Speaker Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• 10’’x18’’ Super Horn Midrange/Tweeter
• 1.5’’ Titanium Compression Driver Loaded in Horn
• Two 15’’ Subwoofers 2.5’’ Kapton VC
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Metal Handles for Easy Portability
PPAD122
• Heavy Duty Handles for Easy Portability
• Dual Speakon Dual 1/4” Jacks
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 800Watts RMS/ 1600 Watts Peak
• Frequency Response: 50-20K Hz
• Sensitivity (1w/1m): 98dB
• Impedance: 8 Ohms
• Dimensions: 16” (W) x 15.2” (D) x 44.2” (H)
15’’ 2000 Watts PA Speaker Cabinet
• Heavy Duty MDF Construction
w/ Reinforced Corners
• 6” x 17” Super Horn Midrange/ Tweeter
• 1.5” Titanium Compression Driver Loaded in Horn
• Five Piezo Tweeters
• 2 x 15” Subwooofer 2.5” Kapton VC
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclousure for Added Bass Response
PPAD102
• Build-in Crossover:
• Frequency Respoce: 20Hz-20KHz
• Impendance: 8 Ohm
• Max Power: 1000 Watts
• Power RMS: 500 Watts
• Sensitivity (1w/1m):110dB
• Dimensions: 37.4’’Hx25.4’’Wx18.4’’D
• One Speakon One 1/4’’ Jac
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 400 Watts RMS / 800 Watts Peak
• Frequency Response: 30-20K Hz
• Sensitivity (1w/1m): 92dB
• Impedance: 8 Ohms
• Dimensions: 17.2’’W x 42’’H x 16.8’’D
PA Loudspeaker Cabinets
PPAD12
12” Heavy Duty 2-Way Stage Monitor Speaker Cabinet
• Heavy Duty MDF Construction
• 6” x 7” Super Horn Midrange/ Tweeter
• 1.35” Titanium Compression Driver Loaded in Horn
• 12” Subwooofer 1.5” Kapton VC
• Woofer Magnet Weight: 40 oz
• Compression Tweeter Magnet Weight: 15 oz
• Ported Enclousure for Added Bass Response
• Heavy Duty Handles for Easy Portability
PPAD15
15’’ Heavy Duty 2-Way Stage Monitor Speaker Cabinet
• Heavy Duty MDF Construction
• 8’’ x 10’’ Super Horn Midrange/ Tweeter
• 1.75’’ Titanium Compression Driver Loaded in Horn
• 15’’ Subwooofer 2’’ Kapton VC
• Woofer Magnet Weight: 50 oz
• Compression Tweeter Magnet Weight: 24 oz
• Ported Enclousure for Added Bass Response
• Heavy Duty Handles for Easy Portability
PPADR128
PPADR158
• Heavy Duty Handles for Easy Portability
• One Speakon One 1/4’’ Jack
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 400 Watts RMS / 800 Watts Peak
• Frequency Response: 30-20K Hz
• Sensitivity (1w/1m): 93dB
• Impedance: 8 Ohms
• Dimensions: 24.8’’W x 28.8’’H x 16’’D
4 Way DJ Tweeter System
• Four 3’’ Horn Piezo Tweeters
• Quick Connect Terminals
• Power Handling: 150 Watts RMS/300 Watts Peak
• Frequency Response: 4kHz-27kHZ
• Sensitivity (1w/1m): 97 dB
• Impedance: 8 Ohms
• Dimensions: 20.84’’W x 6’’H x 9.85’’D
• Weight: 11 lbs
5-Way DJ Tweeter System
• Four 3.5” Horn Piezo Tweeters
• 4” x 14” Super Horn Midrange/Tweeter
• Quick Connect Terminals
• Built In Crossover Network
• Power Handling: 150 Watts RMS/300 Watts Peak
• Heavy Duty Handles for Easy Portability
• One Speakon One 1/4’’ Jack
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 300 Watts RMS / 600 Watts Peak
• Frequency Response: 40-20K Hz
• Sensitivity (1w/1m): 92dB
• Impedance: 8 Ohms
• Dimensions: 21.6’’W x 25.6’’H x 15.2’’D
15’’ Heavy Duty 3-Way Stage Monitor Speaker Cabinet
• Heavy Duty MDF Construction
• 8’’ x 10’’ Super Horn Tweeter
• 1.35’’ Titanium Compression Driver Loaded in Horn
• 15’’ Subwooofer 2’’ Kapton VC
• Woofer Magnet Weight: 50 oz
• Compression Tweeter Magnet Weight: 15 oz
• 8’’ Midrange Midbass Driver
• Midbass Driver Magnet Weight: 20 oz
• Ported Enclousure for Added Bass Response
PAHT5
• One Speakon One 1/4’’ Jack
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 400 Watts RMS / 800 Watts Peak
• Frequency Response: 30-20K Hz
• Sensitivity (1w/1m): 93dB
• Impedance: 8 Ohms
• Dimensions: 28.8’’W x 18.6’’H x 15.2’’D
12’’ Heavy Duty 3-Way Stage Monitor Speaker Cabinet
• Heavy Duty MDF Construction
• 6’’ x 7’’ Super Horn Tweeter
• 1.35’’ Titanium Compression Driver Loaded in Horn
• 12’’ Subwooofer 1.5’’ Kapton VC
• Woofer Magnet Weight: 40 oz
• Compression Tweeter Magnet Weight: 15 oz
• 6.5’’ Midrange Midbass Driver
• Midbass Driver Magnet Weight: 15 oz
• Ported Enclousure for Added Bass Response
PAHT4
• One Speakon One 1/4’’ Jack
• Binding Post Terminals
• Built in Crossover Network
• Power Handling: 300 Watts RMS / 600 Watts Peak
• Frequency Response: 40-20K Hz
• Sensitivity (1w/1m): 92dB
• Impedance: 8 Ohms
• Dimensions: 25.2’’W x 15.8’’H x 14.4’’D
• Frequency Response: 800Hz-20kHz
• Sensitivity (1w/1m): 91 dB
• Impedance: 8 Ohms
• Dimensions: 17.4’’W x 10.2’’H x 12’’D
• Weight: 14.3 Lbs
Stage Monitors
49
49
PAHT6
6 Way DJ Tweeter System
• Six 2.5’’ Horn Piezo Tweeters
• Quick Connect Terminals
• Power Handling: 150 Watts RMS/300 Watts Peak
• Frequency Response: 4kHz-27kHZ
PAHT7
6-Way DJ Tweeter System
• Four 3.4’’ Horn Piezo Tweeters
• Dual 4’’ x 7’’ Super Horn Midrange/Tweeter
• Quick Connect Terminals
• Built In Crossover Network
• Power Handling: 150 Watts RMS/300 Watts Peak
PAHT8
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 3KHz
• Power Handling: 300 Watts RMS/600 Watts Peak
• Frequency Response: 40-20K HZ
• Sensitivity (1w/1m): 101 dB
• Impedance: 8 Ohms
• Dimensions: 25.6’’W x 17.3’’H x 13’’D
800 Watt 15’’ Two-Way Stage Monitor Speaker System
• Heavy Duty MDF Construction w/
Reinforced Corners
• 10’’x18’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• 15’’ Subwoofer 2.5’’ Kapton VC
• Non-Press Paper Cone w/Cloth Edge
• Woofer Magnet Weight: 90 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
50
50
• Frequency Response: 1kHz-27kHz
• Sensitivity (1w/1m): 94 dB
• Impedance: 8 Ohms
• Dimensions: 23.2’’W x 13’’H x 17.2’’D
• Weight: 30 lbs
600 Watt 12’’ Two-Way Stage Monitor Speaker System
• Heavy Duty MDF Construction w/
Reinforced Corners
• 10’’x18’’ Super Horn Midrange/Tweeter
• 1’’ Titanium Compression Driver Loaded in Horn
• 12’’ Subwoofer 2’’ Kapton VC
• Non-Press Paper Cone w/Cloth Edge
• Woofer Magnet Weight: 75 oz
• Compression Tweeter Magnet Weight: 20 oz
• Ported Enclosure for Added Bass Response
PASC15
• Dimensions: 16.8’’W x 9.2’’H x 12’’D
• Weight:15 Lbs
5 Way DJ Tweeter System
• Four 2.5’’ Horn Piezo Tweeters
• 7.5’’ x 6.125’’ Super Horn Midrange/Tweeter
• Titanium Compression Driver 1’’ VC Loaded in Horn
• Compression Tweeter Magnet Weight: 20 oz
• Heavy-Duty Carrying Strap for Easy Portability
• Quick Connect Terminals
• Built In Crossover Network 5KHz
• Power Handling: 150 Watts RMS/300 Watts Peak
PASC12
• Frequency Response: 800Hz-20kHz
• Sensitivity (1w/1m): 92 dB
• Impedance: 8 Ohms
• Dimensions: 17.4’’W x 9.4’’H x 12’’D
• Weight: 13.2 Lbs
8 Way DJ Tweeter System
• Eight 3.4’’ Super Horn Tweeters
• PVC Finish
• Sensitivity (1w/1m): 97 dB
• Power Handling: 150W RMS / 300W Peak
• Frequency Response: 4K-27K Hz
• Impedance: 8 Ohms
PAHT9
• Sensitivity (1w/1m): 97 dB
• Impedance: 8 Ohms
• Dimensions: 19.5’’W x 5.5’’H x 10’’D
• Weight: 9 lbs
Stage Monitors
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
• Built In Crossover Network 2KHz
• Power Handling: 400 Watts RMS/800 Watts Peak
• Frequency Response: 35-20K HZ
• Sensitivity (1w/1m): 102 dB
• Impedance: 8 Ohms
• Dimensions: 27.5’’W x 17.3’’H x 13.4’’D
PASW15
800 Watt 15’’ Stage PA Subwoofer Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• Black PVC Finish
• 15’’ Subwoofer 2.5’’ Kapton VC
• Woofer Magnet Weight: 90 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
PASW18
1000 Watt 18’’ Stage PA Subwoofer Cabinet
• Heavy Duty MDF Construction w/
Reinforced Corners
• Black PVC Finish
• 18’’ Subwoofer 3’’ Kapton VC
• Woofer Magnet Weight: 100 oz
• Ported Enclosure for Added Bass Response
• Heavy Duty Handles for Easy Portability
• Dual Speakon & Dual 1/4’’ Jacks
• Binding Post Terminals
PSTUDIO5
PSTUDIO6
• RMS SPL: 101.5dB at 1 Meter
• Input Connectors: RCA Unbalanced,
XLR-F & TRS (1/4’’) Balanced
• Dynamic Power: 150 Watts RMS / 300 Peak
• Protection: RF interference, Thermal Protection
• Power Requirements: 110V / 220V w/
Detachable 2 Conductor Cord
• 4-8 Ohm Impedance
• Dimensions: 11.41’’H x 9.21’’W x 6.77’’D
• Net weight: 5.6 Kg (SOLD AS SINGLE NOT PAIR)
6.5’’ 350 Watt 2-Way Bass Reflex Amplified Studio Monitor Speaker
• Two-Way Stereo Desktop Monitor
• Built in High Amplifier/High Freq. Filter
and Low Freq. Filter Select
• 6’’ Diameter Glass Fiber Cone,
Magnetically Shielded
• High Temperature Voice Coil
• 1’’ Diameter, Magnetically Shielded
Silk Dome Tweeter
• Frequency Response: 50Hz - 20kHz
• Crossover Frequency: 5kHz
• RMS SPL: 101.5dB at 1 Meter
• Input Connectors: RCA Unbalanced,
XLR-F & TRS (1/4’’) Balanced
• Dynamic Power: 175 Watts RMS / 350 Peak
• Protection: RF Interference, Thermal Protection
• Power Requirements: 110V / 220V w/
Detachable 2 Conductor Cord
• Cabinet: High Quality Vinyl Laminated High Density MDF
• 4-8 Ohm Impedance
• Dimensions: 12.6’’H x 10.2’’W x 8.5’’D
• Net weight: 5.6 Kg (SOLD AS SINGLE NOT PAIR)
8’’ High Power High Performance Midbass
• 8’’ Paper Cone/2’’ Voice Coil
• Die-Cast Frame/Aluminium Phase Plug
• 40 Oz Magnet Structure
• 400 Watts Rms/800 Watts Peak Power
PBW8S
• 4 Ohm Impedance
• Sensitivity: 96Db
• Frequency Response:F0-8Khz
8’’ High Power High Performance Midbass
• 8’’ Paper Cone
• Oversize 1.5’’ High Temperature
Ccar Voice Coil, Til Bobbin
• Linear Phase Plug
• 80 OZ Magnet Structure
• Built In Crossover Network 500 Hz
• Power Handling: 500 Watts RMS/1000 Watts Peak
• Frequency Response: 20-400HZ
• Sensitivity (1w/1m): 97 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount (Top)
• Dimensions: 23’’W x 17.8’’D x 26.8’’H
• Weight: 70 lbs
5.25’’ 300 Watt 2-Way Bass Reflex Amplified Studio Monitor Speaker
• Two-Way Stereo Desktop Monitor
• Built in High Amplifier/High Freq. Filter
and Low Freq. Filter Select
• 5.25’’ Diameter Glass Fiber Cone,
Magnetically Shielded
• High Temperature Voice Coil
• 1’’ Diameter, Magnetically Shielded
Silk Dome Tweeter
• Frequency Response: 55Hz - 20kHz
• Crossover Frequency: 5kHz
PFM8
• Binding Post Terminals
• Built In Crossover Network 800 Hz
• Power Handling: 400 Watts RMS/800 Watts Peak
• Frequency Response: 20-500HZ
• Sensitivity (1w/1m): 95 dB
• Impedance: 8 Ohms
• 35mm Speaker Stand Mount (Top)
• Dimensions: 18’’W x 15.8’’D x 23’’H
• 280 Watts Rms / 560 Watts Peak Power
• 3 OHM Impedance
• Sensitivity : 96db
• Frequency Response: 95-5KHZ
• Mounting Depth: 2.87’’
Stage Monitors / Midbass Speakers
51
51
PBW10S
10’’ High Power High Performance Midbass
• 10’’ Paper Cone
• 2’’ High Temperature CCAR Voice Coil, TIL Bobbin
• Linear Phase Plug
• 100 Oz Magnet Structure
• 500 Watts Rms / 1000 Watts Peak Power
PCW8S
8’’ High Power High Performance Midbass
• 8’’ Paper Cone
• Oversize 1.5’’ High Temperature
CCAR Voice Coil, TIL Bobbin
• 80 Oz Magnet Structure
• 280 Watts RMS / 560 Watts Peak Power
PCW10S
• 800 Watts Rms/1600 Watts Peak
• Frequency Response:FO-2.5kHz
• Sensitivity:99db 1W/1M
• Net Weight::12.5Kg
18’’ 2000 Watt Professional 8 OHM Replacement Subwoofer
• Excellent Replacement PA Woofer
• Paper Cone Reinforcement System
• 125Oz Ferrite Magnet
• 4” Voice coil
• 8 Ohm Impedance
PDW15125
• 1000 Watts Rms/2000 Watts Peak
• Frequency Response:FO-2kHz
• Sensitivity:100db 1W/1M
• Net Weight::12.6KG
15’’ Performance Optimized High Power Subwoofer
• 15’’ High Power Subwoofer
• 8 Ohm Impedance
• 500W RMS/1000W Peak Power
• 36 Hz Resonance
• Frequency Response: 36 Hz - 4K Hz
• Sensitivity: [email protected]: 103 dB
52
52
• 450 Watts Rms/900 Watts Peak
• Frequency Response:FO-5kHz
• Sensitivity:97db 1W/1M
• Net Weight::7.37Kg
15’’ 1600 Watt Professional 8 OHM Replacement Subwoofer
• Excellent Replacement PA Woofer
• Paper Cone Reinforcement System
• 125Oz Ferrite Magnet
• 4” Voice coil
• 8 Ohm Impedance
PDW188
• 3 OHM Impedance
• Sensitivity : 100db
• Frequency Response: 65-4khz
• Mounting Depth: 3.15’’
12’’ 900 Watt Professional 8 OHM Replacement Subwoofer
• Excellent Replacement PA Woofer
• Paper Cone Reinforcement System
• 80Oz Ferrite Magnet
• 3” Voice coil
• 8 Ohm Impedance
PDW158
• 3 OHM Impedance
• Sensitivity : 96db
• Frequency Response: 95-5KHZ
• Mounting Depth: 2.87’’
10’’ High Power High Performance Midbass
• 10’’ Paper Cone
• 2’’ High Temperature CCAR Voice Coil, TIL Bobbin
• 100 OZ Magnet Structure
• 500 Watts RMS / 1000 Watts Peak Power
PDW128
• 3 Ohm Impedance
• Sensitivity : 100DB
• Frequency Response: 65-4KHZ
• Mounting Depth: 3.15’’
• Magnet Weight: 200 Oz
• 4’’ Aluminum Voice Coil
• Diameter: 15.8’’
• Mounting Depth: 6.7’’
• Die-Cast Aluminum Frame LJD
Misbass Speakers / Pro Subwoofers
PDW18125
18’’ Performance Optimized High Power Subwoofer
• 18’’ High Power Subwoofer
• 8 Ohm Impedance
• 800W RMS/1600W Peak Power
• 33 Hz Resonance
• Frequency Response: 33 Hz - 4K Hz
• Sensitivity: [email protected]: 101 dB
PDW21250
21’’ Performance Optimized High Power Subwoofer
• 21’’ High Power Subwoofer
• 8 Ohm Impedance
• 1000W RMS/2000W Peak Power
• 22 Hz Resonance
• Frequency Response: 22 Hz - 4K Hz
• Sensitivity: [email protected]: 107 dB
PMW8A
PMW12A
• Stamped Steel Basket
• Strong Black Paper Cone
• Cloth Edge Suspension
• Bumped & Vented Pole Piece
• 8 Ohms Impedance
500 Watt Professional Premium PA 8’’ Woofer
• 200 Watts RMS/500 Watt Peak
• Sensitivity (1W @ 1M): 89.2 dB
• Frequency Response: 55-6 KHz
• 40 oz Magnet
• 1.5’’ Kapton Voice Coil
• Stamped Steel Basket
• Strong Black Paper Cone
• Cloth Edge Suspension
• Bumped & Vented Pole Piece
• 8 Ohms Impedance
600 Watt Professional Premium PA 10’’ Woofer
• 200 Watts RMS/600 Watt Peak
• Sensitivity (1W @ 1M): 89.2 dB
• Frequency Response: 50-5 KHz
• 50 oz Magnet
• 1.5’’ Kapton Voice Coil
• 8 Ohm impedance
• Sensitivity: 94 dB
• Frequency Response: 200-5KHz
• Monting Depth: 3.03”
400 Watt Professional Premium PA 6’’ Woofer
• 150 Watts RMS/400 Watt Peak
• Sensitivity (1W @ 1M): 88.5 dB
• Frequency Response: 60-7 KHz
• 30 oz Magnet
• 1’’ Kapton Voice Coil
PPA10
• 8 Ohm Impedance
• Sensitivity: 98dB
• Frequency Response: 100-10KHz
• Mounting Depth: 3.43”
12” High Power Performance Midbass
• 12” Paper Coating Cone
• 2” High Temperature KAPTON Voice Coil
• 80 Oz Magnet Structure
• Sealed Back Design
• 500 Watts RMS/ 1000 Watts Peak Power
PPA8
• Magnet Weight: 350 Oz
• 4’’ Aluminum Voice Coil
• Diameter: 21.8’’
• Mounting Depth: 10.2’’
• Die-Cast Aluminum Frame LJD
8’’ Paper Cone Mid-woofer
• 8” Paper Cone
• 1.5” High Temperature KAPTON Voice Coil
• 45 Oz Magnet Structure
• 220 Watts RMS / 440 Watts Peak Power
PPA6
• Magnet Weight: 200 Oz
• 4’’ Aluminum Voice Coil
• Diameter: 19’’
• Mounting Depth: 8.3’’
• Die-Cast Aluminum Frame LJD
• Stamped Steel Basket
• Strong Black Paper Cone
• Cloth Edge Suspension
• Bumped & Vented Pole Piece
• 8 Ohms Impedance
Pro Subwoofers
53
53
PPA12
700 Watt Professional Premium PA 12’’ Woofer
• 200 Watts RMS/700 Watt Peak
• Sensitivity (1W @ 1M): 90 dB
• Frequency Response: 35-4 KHz
• 60 oz Magnet
• 2’’ Kapton Voice Coil
PPA15
800 Watt Professional Premium PA 15’’ Woofer
• 250 Watts RMS/800 Watt Peak
• Sensitivity (1W @ 1M): 90.2 dB
• Frequency Response: 30-3 KHz
• 70 oz Magnet
• 2.5’’ Kapton Voice Coil
PPA18
• Frequency Response: 450Hz - 7kHz
• Sealed Back Design
• 8 Ohm Impedance
• Mounting Depth: 2’’
6.5’’ High Power High Performance Midrange Driver
• 6.5’’ Paper Coating Cone
• 1’’ High Temperature KAPTON Voice Coil
• 25 Oz Magnet Structure
• Sealed Back Design
• 150 Watts RMS / 300 Watts Peak Power
54
54
• Sensitivity: 92dB
• Frequency Response: 70Hz - 9kHz
• 8 Ohm Impedance
• Mounting Depth: 2.75’’
5’’ High Performance Midrange Driver
• 100 Watts RMS/200 Watts Peak
• 5’’ Paper Coating Cone
• 1’’ High Temperature Aluminum Voice Coil
• 15 oz Magnet Structure
• Sensitivity: 92dB
PDMR6
• Sensitivity: 90dB
• Frequency Response: 80Hz - 7kHz
• 8 Ohm Impedance
• Mounting Depth: 2’’
6.5’’ High Performance Mid-Bass Woofer
• 125 Watts RMS/250 Watts Peak
• 6.5’’ Paper Coating Cone
• 1’’ High Temperature Aluminum Voice Coil
• 25 oz Magnet Structure
PDMR5
• Stamped Steel Basket
• Strong Black Paper Cone
• Cloth Edge Suspension
• Bumped & Vented Pole Piece
• 8 Ohms Impedance
5’’ High Performance Mid-Bass Woofer
• 100 Watts RMS/200 Watts Peak
• 5’’ Paper Coating Cone
• 1’’ High Temperature Kapton Voice Coil
• 15 oz Magnet Structure
PDMW6
• Stamped Steel Basket
• Strong Black Paper Cone
• Cloth Edge Suspension
• Bumped & Vented Pole Piece
• 8 Ohms Impedance
1000 Watt Professional Premium PA 18’’ Woofer
• 300 Watts RMS/1000 Watt Peak
• Sensitivity (1W @ 1M): 94 dB
• Frequency Response: 25-3 KHz
• 100 oz Magnet
• 3’’ Kapton Voice Coil
PDMW5
• Stamped Steel Basket
• Strong Black Paper Cone
• Cloth Edge Suspension
• Bumped & Vented Pole Piece
• 8 Ohms Impedance
Pro Subwoofers
• 8 Ohm Impedance
• Sensitivity : 93dB
• Frequency Response: 200-5KHz
• Mounting Depth: 2.76’’
PDMR8
8’’ 360 Watt High Power High Performance Midrange Driver
• 8’’ Paper Coating Cone
• 1.5’’ High Temperature KAPTON Voice Coil
• 35 Oz Magnet Structure
• Sealed Back Design
• 180 Watts RMS/ 360 Watts Peak Power
PDMR9
5’’ Dome Type Midrange Speaker
• 2’’ Glass Fiber Diaphragm Butyl Rubber Surround
• 2’’ High Temperature Voice Coil
• 25 oz Magnet Structure
• 100 Watts RMS/200 Watts Peak Power
PM8DC
• Sensitivity:103db 1W/1M
• 8 Ohm Impedance
• 120 Watts RMS/240 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
1.12” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 1.12” (28.6mm) Flat Aluminum Voice Coil
• 20 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
• Sensitivity: 95dB SPL !W 1M
• 8 Ohm Impedance
• 250 Watts RMS/500Watss Peak Power
• Fits Horns with 1 3/8” x 18 TPI Threads
1.5’’ Titanium Screw On Horn Driver 8 Ohm 1-3/8’’ x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 1.5’’ (44.4mm) Flat Aluminum Voice Coil
• 13.5 oz Magnet Structure
• Frequency Response:1500Hz-20KHz
PDS221
• Sensitivity:99db 1W/1M
• 8 Ohm Impedance
• 100 Watts RMS/200 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
1.5” Aluminum Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter
• Compression Driver
• 1.5’’(35mm) Flat Aluminum Voice Coil
• 30 Oz. Magnet Structure
• Frequency Resp: 1.5K-20KHz
PDS182
• 4 Ohm Impedance
• Sensitivity: 96Db
• Frequency Response:F0-8Khz
1’’ Neodymium/Titanium Screw On Horn Driver 8 Ohm 1-3/8’’ x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Neodymium Magnet /Titanium Diaphragm
• 1’’ (44.4mm) Flat Aluminum Voice Coil
• 21 oz Magnet Structure
• Frequency Response:2000Hz-20KHz
PDS122
• 4-8 Ohm Impedance
• Sensitivity: 95dB
• Frequency Response: 400Hz - 6k Hz
• Mounting Depth: 1 1/2’’
8’’ High Power High Performance Midbass
• 8’’ Paper Cone/2’’ Voice Coil
• Steel Frame/Dust Cup
• 40 Oz Magnet Structure
• 400 Watts Rms/800 Watts Peak Power
PDS111
• 8 Ohm impedance
• Sensitivity: 94 dB
• Frequency Response: 200-5KHz
• Monting Depth: 3.03’’
• Sensitivity: 102dB @ 1W/ 1M
• 8 Ohm Impedance
• 150 Watts RMS /300 Watts Peak Power
• Fits Horms With 1-3/8” x 18 TPI Threads
• Overall Dimensions: 3.2” Diameter x 3” Depth
Pro Subwoofers / Horn Drivers
55
55
PDS222
1’’ Screw On Neodymium Horn Driver
• Throat Diameter: 25.4mm(1 in)
• Mounting Screw: 1-3/8’’-18TPI
• Nominal Impedance: 8 OHM
• Rated Power: 100W (RMS)
• MAX Power: 200 W
• Sensitivity(1W/1M): 101dB/w/m
PDS322
1.35’’ Screw On Neodymium Horn Driver
• Throat Diameter: 25.4mm(1 in)
• Mounting Screw: 1-3/8’’-18TPI
• Nominal Impedance: 8 OHM
• Rated Power: 200 W (RMS)
• MAX Power: 300W
• Sensitivity(1W/1M): 103dB/w/m
PDS333
• Sensitivity: 103dB @ 1W/ 1M
• 8 Ohm Impedance
• 200 Watts RMS /400 Watts Peak Power
• Fits Horms With 1-3/8” x 18 TPI Threads
• Overall Dimensions: 4” Diameter x 3.3” Depth
1.35’’ Titanium Ceramic Screw On Horn Driver At 8 Ohms
• Throat Diameter: 25.4mm(1 in)
• Mounting Screw: 1-3/8’’-18TPI
• Nominal Impedance: 8 OHM
• Rated Power: 200 W RMS, 400 W MAX
• Sensitivity(1W/1M): 103dB/w/m
• Frequency Response: 1-20 kHz
56
56
• Sensitivity: 104dB @ 1W/1M
• 8 Ohm Impedance
• 200 Watts RMS/400 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
1.35” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 1.35” (34.4mm) Flat Aluminum Voice Coil
• 25 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
PDS345
• Sensitivity: 102dB @ 1W/1M
• 8 Ohm Impedance
• 200 Watts RMS/400 Watts Peak
• Terminals 250 Type
• Fits Horns with 1 3 /8’’ x 18 TPI Threads
1.35” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 1.35’’ (34.4mm) Flat Aluminum Voice Coil
• 20 oz Magnet Structure
• Frequency Response: 1kHz - 20kHz
PDS344
• Voice Coil Diameter: 34.4mm(1.35 in)
• Diaphragm Material: Titanium
• Magnet: Neodymium
• Outside Diameter: 3.34 in.
• Net Weight: 0.55 lbs.
1.35” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 1.35’’ (34.4mm) Flat Aluminum Voice Coil
• 12 oz Magnet Structure
• Frequency Response: 1kHz - 20kHz
PDS342
• Frequency Response: 1.2-20 kHz
• Voice Coil Diameter: 34.4mm(1.35 in)
• Diaphragm Material: Titanium
• Magnet: Ceramic
• Outside Diameter: 3.68 in.
• Net Weight: 2.03 lbs.
1.35’’ Screw On Neodymium/Titanium Horn Driver
• Throat Diameter: 25.4mm(1 in)
• Mounting Screw: 1-3/8’’-18TPI
• Nominal Impedance: 8 OHM
• Rated Power:200 W (RMS) MAX 400w
• Sensitivity(1W/1M): 103dB/w/m
• Frequency Response: 1.2-20 kHz
PDS341
• Frequency Response: 1-20 kHz
• Voice Coil Diameter: 25.4mm(1 in)
• Diaphragm Material: Polyester
• Magnet: Neodymium
• Outside Diameter: 2.91 in.
• Net Weight: 0.5 lbs.
Horn Drivers
• Voice Coil Diameter: 34.4mm(1.35 in)
• Diaphragm Material: Titanium
• Magnet: Ceramic
• Outside Diameter: 3.93 in.
• Net Weight: 2.91 lbs.
PDS351
1.35’’ Titanium Neodymium Screw On Horn Driver At 8 Ohms
• Throat Diameter: 25.4mm(1 in)
• Mounting Screw: 1-3/8’’-18TPI
• Nominal Impedance: 8 OHM
• Rated Power: 200 W (RMS), 400 W MAX
• Sensitivity(1W/1M): 104dB/w/m
PDS382
1.75’’ Titanium Screw On Horn Driver 8 Ohm 1-3/8’’ x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 1.75’’ (44.4mm) Flat Aluminum Voice Coil
• 21 oz Magnet Structure
• Frequency Response:1000Hz-20KHz
PDS432
• Voice Coil Diameter: 44.4mm(1.75 in)
• Diaphragm Material: Titanium
• Magnet: Ceramic
• Outside Diameter: 4.72 in.
• Net Weight: 2.31 lbs.
2.02” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 2.02’’ (51.2mm) Flat Aluminum Voice Coil
• 30 oz Magnet Structure
• Frequency Response: 500Hz - 18kHz
• Sensitivity: 105dB @ 1W/ 1M
• 8 Ohm Impedance
• 250 Watts RMS /500 Watts Peak Power
• Fits Horns with 1-3/8” x 18 TPI Threads
• Overall Dimensions: 5.3” Diameter x 3.43” Depth
1.75’’ Titanium Ceramic Screw On Horn Driver At 8 Ohms
• Throat Diameter: 25.4mm(1 in)
• Mounting Screw: 1-3/8’’-18TPI
• Nominal Impedance: 8 OHM
• Rated Power: 300 W RMS, 600 W MAX
• Sensitivity(1W/1M): 103dB/w/m
• Frequency Response: 1-20 kHz
PDS521
• Sensitivity: 105dB @ 1W/1M
• 8 Ohm Impedance
• 250 Watts RMS/500 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
1.75” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 1.75” (44.4mm) Flat Aluminum Voice Coil
• 40 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
PDS445
• 500 Watts Max.
• Frequency Response: 400 Hz - 9000 Hz
• SPL: 102dB (1W/1M)
1.75” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 1.75’’ (44.4mm) Flat Aluminum Voice Coil
• 30 oz Magnet Structure
• Frequency Response: 1kHz - 20kHz
PDS444
• Sensitivity: 104dB @ 1W/1M
• 8 Ohm Impedance
• 200 Watts RMS/400 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
High Power Tweeter Compression Horn Driver
• 2’’ Cloth Diaphragm
• 30 oz. Magnet
• 2’’ High-Temperature Voice Coil
• 8 Ohm Impedance
PDS442
• Frequency Response: 1.2-20 kHz
• Voice Coil Diameter: 34.4mm(1.35 in)
• Diaphragm Material: Titanium
• Magnet: Neodymium
• Net Weight: 0.88 lbs.
• Sensitivity: 107dB @ 1W/1M
• 8 Ohm Impedance
• 300 Watts RMS/600 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
Horn Drivers
57
57
PDS541
2” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 2’’ Flat Aluminum Voice Coil
• 60 oz. Magnet Structure
• Frequency Response: 1.5kHz-18kHz
PDS682
3’’ Titanium 8 Ohm Horn Bolt On Driver
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 3’’ (50.8mm) Flat Aluminum Voice Coil
• 50oz Magnet Structure
• Frequency Response:600Hz-18KHz
• Sensitivity:105db 1W/1M
PDS741
PDS772
• 25mm Voice Coil Size
• 8 Ohm Impedance
• Dimensions: 3.35”h x 3.35”w x 2.75”d
4’’ x 10’’ Horn Tweeter
• Max Power Rating: 200 Watts
• 20 oz Magnet
• Sensitivity: 102dB @ 1W/1M
• Frequency Response: 1kHz - 15kHz
• 25mm Voice Coil Size
• 8 Ohm Impedance
• Dimensions: 4.3”h x 10.6”w x 8.25”d
4’’ x 4’’ Horn Tweeter
• Max Power Rating: 150 Watts
• 15 oz Magnet
• Sensitivity: 105dB @ 1W/1M
• Frequency Response: 1kHz - 18kHz
58
58
• Sensitivity: 107dB @ 1W/1M
• 8 Ohm Impedance
• 300 Watts RMS/600 Watts Peak
• Terminals 205 Type
• Fits Horns with 1 3/8’’ x 18 TPI Threads
3’’ x 3’’ Horn Tweeter
• Max Power Rating: 120 Watts
• 15 oz Magnet
• Sensitivity: 100dB @ 1W/1M
• Frequency Response: 1kHz - 15kHz
PH44
• Sensitivity: 106dB @ 1W/ 1M
• 8 Ohm Impedance
• 300 Watts RMS /600 Watts Peak Power
• Fits Horms With 1-3/8” x 18 TPI Threads
• Overall Dimensions: 5.5” Diameter x 3.8” Depth
2.84” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 2.84’’ (72.2mm) Flat Aluminum Voice Coil
• 50 oz Magnet Structure
• Frequency Response: 500Hz - 18kHz
PH391
• 8 Ohm Impedance
• 300 Watts Watts Rms /600 Watts
Peak Power Handing
• Fits Horns With Four M6 Threaded Holes 90
Apart on 4’’ (102mm) Diameter Circle
• Overall Dimensions: 7’’ Diameter x 3.2’’ Depth
2” Titanium Horn Driver 8 Ohm 1-3/8” x 18 TPI
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 2” (50.8mm) Flat Aluminum Voice Coil
• 60 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
PH25
• Sensitivity: 102dB
• 8 Ohm Impedance
• 300 Watts RMS/600 Watts Peak Power
• Terminals 205-Type
• Fits Horns with 1 3 /8’’ x 18 TPI Threads
• 25mm Voice Coil Size
• 8 Ohm Impedance
• Dimensions: 4.5”h x 4.5”w x 4.45”d
Horn Drivers / Tweeters
PSN1165
4.35’’ Dispersion Horn Piezo Tweeter
• 4.35’’ Square Super Horn Tweeters
• Frequency Response: 1.8kHz - 30kHz
• SPL: 93dB @ 1W/1M
• Excellent Transient Response
• Low Distortion
• Typical Impedance Appears as .3 UF Capacitor
• Light Weight Highly Reliable
PSN1167
400 Watt 3.5’’ Dispersion Horn Piezo Tweeter
• 3.5’’ Square Piezo Horn Tweeter
• Frequency Response: 3.5KHz-25KHZ
• SPL: 93dB @ 1W/1M
• Excellent Transient Response
• Low Distortion
• Typical Impedance Appears as. 12 UF Capacitor
• Light Weight Higly Reliable
• 200 Watts RMS/400 Watts Peak
PSN1176
• Neodymium Magnet System
• Removable Chrome Fronting
• 4 Ohm Impedance
• Hi-Tech & Clean Look
1.5” Aluminum Horn Driver 8 Ohm 4-Bolt
• Midrange/Tweeter
• Compression Driver
• 1.5’’(35mm) Flat Aluminum Voice Coil
• 30 Oz. Magnet Structure
• Frequency Resp: 1.5K-20KHz
PDB352
• 200 Watts RMS/400 Watts Peak
• Complete Pair In Gift Box
• Suited 4-8 Ohm Impedance Aplications
• A 30 Ohm Series Resistor is Recommended to
Assure Stability of Extended Range Amplifiers
Preclude Hazard of Amplifier Burn-Out
1’’ Dynamic Horn Midrange/Tweeter
• Max Power Rating: 200 Watts
• Sensitivity: 96 dB (1W/1M)
• Frequency Response: 2k-22kHz
• Aluminum Die-Cast Cooler
PDB252
• Complete Pair In Gift Box
• Suited 4-8 Ohm Impedance Aplications
• A 30 Ohm Series Resistor is Recommended to
Assure Stability of Extended Range Amplifiers
Preclude Hazard of Amplifier Burn-Out
• Overall Dimensions: 3.5’’ x 3.5’’
• Cutout Dimensions: 2.75 x 2.75’’
• Screw Holes: 2.8’’
400 Watt 3’’ x 7.5’’ Dispersion Horn Piezo Tweeter
• 3” x 7.5” Square Piezo Horn Tweeter
• Frequency Response: 3.5KHz-20KHZ
• SPL: 94dB @ 1W/1M
• Excellent Transient Response
• Low Distortion
• Typical Impedance Appears as. 1 UF Capacitor
• Light Weight Higly Reliable
PKD480
• 200 Watts RMS/400 Watts Peak
• Complete Pair In Gift Box
• Suited 4-8 Ohm Impedance Applications
• A 30 Ohm Series Resistor is Recommended to
Assure Stability of Extended Range Amplifiers
Preclude Hazard of Amplifier Burn-Out
• Sensitivity: 95dB SPL !W 1M
• 8 Ohm Impedance
• 250 Watts RMS/500Watss Peak Power
• Fits Horns with Four M6 Threaded Holes 90
• Apart on 3’’ (76mm) Diameter Circle
1.35” Titanium Horn Driver 8 Ohm 4-Bolt
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 1.35” (34.4mm) Flat Aluminum Voice Coil
• 25 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
• Sensitivity: 103dB @ 1W/ 1M
• 8 Ohm Impedance
• 200 Watts RMS /400 Watts Peak Power
• Fits Horns with Fou M6 Threaded Holes 90
Apart on 2.36” (60mm) Diameter Circle
• Overall Dimensions: 4” Diameter x 2.5” Depth
Tweeters
59
59
PDB512
2.02” Titanium Horn Driver 8 Ohm 5-Bolt
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 2.02’’ (51.2mm) Flat Aluminum Voice Coil
• 30 oz Magnet Structure
• Frequency Response: 500Hz - 18kHz
• Sensitivity: 107dB @ 1W/1M
• 8 Ohm Impedance
PDB552
1.75” Titanium Horn Driver 8 Ohm 4-Bolt
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 1.75” (44.4mm) Flat Aluminum Voice Coil
• 40 Oz Magneture Structure
• Frequency Response: 800Hz-20KHz
PDB658
• Sensitivity: 106dB @ 1W/ 1M
• 8 Ohm Impedance
• 300 Watts RMS /600 Watts Peak Power
• Fits Horns With Four M6 Threaded Holes
90 Apart on 3” (76mm) Diameter Circle
• Overall Dimensions: 5.5” Diameter x 3” Depth
2” Titanium Horn Driver 8 Ohm 4-Bolt
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 2” (50.8mm) Flat Aluminum Voice Coil
• 90 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
60
60
• Voice Coil Diameter: 74.8mm(3 in)
• Diaphragm Material: Titanium
• Magnet: Ceramic
• Outside Diameter: 6.69 in.
• Net Weight: 11.5 lbs.
• Shorting copper cap for extended HF response
2” Titanium Horn Driver 8 Ohm 4-Bolt
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 2” (50.8mm) Flat Aluminum Voice Coil
• 60 Oz Magnet Structure
• Frequency Response: 800Hz-20KHz
PDB832
• 8 Ohm Impedance
• 400 Watts RMS/800 Watts Peak
• Terminals 205 Type
• Fits Horns with Four M6 Threaded Holes
• 90 Apart on 4’’ (102mm) Diameter Circle
3’’ Titanium Bolt On Horn Driver
• Throat Diameter: 35.5mm(1.4 in)
• Mounting Screw: 4-M6-Φ102
• Nominal Impedance: 8 OHM
• Rated Power: 400 W RMS, 800 W MAX
• Sensitivity(1W/1M): 105dB/w/m
• Frequency Response: 500Hz – 17 kHz
PDB782
• Frequency Reponse: 800-17KHz
• Voice Coil Diameter: 63.8mm(2.5 in)
• Diaphragm Material: Titanium
• Magnet: Ceramic
• Net Weight: 8.8 lbs.
3” Titanium Horn Driver 8 Ohm 4-Bolt
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• 3’’ (76.2mm) Flat Aluminum Voice Coil
• 50 oz Magnet Structure
• Frequency Response: 1kHz - 20kHz
• Sensitivity: 107dB @ 1W/1M
PDB758
• Sensitivity: 105dB @ 1W/ 1M
• 8 Ohm Impedance
• 250 Watts RMS /500 Watts Peak Power
• Fits Horns with Fou M6 Threaded Holes 90
Apart on 3” (76mm) Diameter Circle
• Overall Dimensions: 5.3” Diameter x 2.6” Depth
2.5’’ Bolt On Titanium Ceramic Horn Driver
• Throat Diameter: 35.5mm(1.4 in)
• Mounting Screw: 4-M6-F102
• Nominal Impedance: 8 OHM
• Rated Power: 350 W RMS, 700 W Max
• Sensitivity(1W/1M): 105dB/w/m
PDB752
• 250 Watts RMS/500 Watts Peak
• Terminals 205 Type
• Fits Horns with Three M6 Threaded Holes
120¦’ba Apart on 2.24’’ (57mm) Diameter Circle
• Two M6 Threaded Holes 180¦’ba Apart
on 3’’ (76.2mm) Diameter Circle
Tweeters
• Sensitivity: 106dB @ 1W/ 1M
• 8 Ohm Impedance
• 500 Watts RMS /1000 Watts Peak Power
• Fits Horns With Four M6 Threaded Holes 90
Apart on 4” (102mm) Diameter Circle
• Overall Dimensions: 7” Diameter x 3.2” Depth
PDB952
4’’ Titanium 8 Ohm Horn Bolt On Driver
• Midrange/Tweeter Compression Horn Driver
• Titanium Diaphragm
• Terminals 205-Type
• 4’’ (50.8mm) Flat Aluminum Voice Coil
• 116oz Magnet Structure
• Frequency Response:400Hz-15KHz
• Sensitivity:99db 1W/1M
PDB958
4’’ Bolt On Titanium Neodymium Horn Driver
• Throat Diameter 50.8mm(2 in)
• Mounting Screw 4-M6-F102
• Nominal Impedance 8 OHM
• Rated Power 500 W RMS, 1000 W MAX
• Sensitivity(1W1M) 107dBwm
• Frequency Response 450 Hz – 13 kHz
PDBT13
• Sensitivity: 98dB
• Frequency Response: 2 kHz - 25 kHz
• Mylar Crossover Capacitor Included
• 4-8 Ohms Impedance
• 3.75’’ Diameter - 2’’ Mounting Depth
1.75’’ Heavy Duty Aluminum Die-Cast Titanium Super Tweeter
• 1.75’’ Titanium Super Tweeter
• Die Cast Aluminum Frame
• Crossover capacitor Included
• 300 Watts RMS
• 600 Watts Max. Power
PDBT23
• 150 Watts RMS/300 Watts Peak
• Sensitivity: 99dB
• Frequency Response: 2kHz - 25kHz
• Mylar Crossover Capacitor Included
• 3.75’’ Diameter - 2’’ Mounting Depth
3.75’’ Aluminum Bullet Titanium Horn Tweeter
• 3.75’’ Aluminum Horn
• 1’’ Super Tweeter
• 20 oz Magnet Structure
• 1’’ High Temperature Kapton Voice Coil
• Ferro Fluid Enhanced Voice Coil
• 150 Watts RMS/300 Watts Peak
PDBT21F
• 4 Ohm Impedance
• 350 Watts Max.
• Frequency Repsonse: 3.5 kHz - 23 kHz
• SPL: 98dB (1W/1M)
3.75’’ Aluminum Bullet Titanium Horn Tweeter
• 3.75’’ Aluminum Horn
• 1’’ Super Tweeter
• 20 oz Magnet Structure
• 1’’ High Temperature Kapton Voice Coil
• Diamond Chrome Cutting Finish
• Ferro Fluid Enhanced Voice Coil
PDBT19
• Voice Coil Diameter 99.2mm(4 in)
• Diaphragm Material Titanium
• Magnet Neodymium
• Outside Diameter 6.35 in.
• Net Weight 9.0 lbs.
• Shorting copper cap for extended HF response
3.75” Super Bullet Horn Tweeter
• 3.75’’ Aluminum Die-Cast Bullet Horn
• 1’’ Titanium Diaphragm
• 20 oz. Magnet
• 1’’ High-Temperature Voice Coil
PDBT18
• 8 Ohm Impedance
• 1200 Watts Watts Rms /600 Watts
Peak Power Handing
• Fits Horns With Four M6 Threaded Holes 90
Apart on 4” (102mm) Diameter Circle
• Overall Dimensions: 7’’ Diameter x 3.2’’ Depth
• 30 Oz. Magnet Structure
• Sensitivity: 106dB/w/m
• Impedance: 4-8 Ohm
• Freq. Resp.:2,000Hz - 25,000Hz
1.75” Die-Cast Titanium Super Tweeter
• Die Cast Plastic Frame
• 180 Watts RMS/360 Watts Max
• 4 Ohm Impedance
• Frequency Response: 3 KHz-18 KHz
• Sensitivity: 98 dB/w/m
• Number of bolt holes: 4
• Bolt hole dimension: 4.5mm×6mm(4×)
• Diameter: F120mm
• Mounting depth: 53mm
• Total depth: 61 mm
Tweeters
61
61
PDBT28
1’’ Heavy Duty Titanium Super Tweeter
• 1’’ Titanium Super Tweeter
• Diamond Chrome Cutting Finish
• Die-Cast Aluminum Frame
• 1’’ High Temperature Kapton Voice Coil
• 30 oz Magnet Structure
• 150 Watts RMS/300 Watts Peak
PDBT29
1’’ Aluminum Housing Super Bullet Tweeter with Titanium Voice Coil
• Diaphragm Material: Titanium
• Voice Coil Size: 1’’(25.4mm)
• Impedance: 4 Ohm
• Sensitivity: 100db/W/M
• Frequency Response: 3-20 kHz
PDBT31
• Die-Cast Aluminum Frame
• Ferro Fluid Enhanced Voice Coil
• Sensitivity: 104dB
• Frequency Response: 2kHz - 20kHz
• Mylar Crossover Capacitor Included
• 3.9’’ Diameter - 2.6’’ Mounting Depth
1.5’’ Aluminum Housing Super Bullet Tweeter with Titanium Voice Coil
• Diaphragm Material: Titanium
• Voice Coil Size: 1.5’’ (37.6mm)
• Impedance: 4 Ohm
• Sensitivity: 102db/W/M
• Frequency Response: 2.5-20 kHz
62
62
• Frequency Response: 2kHz-25kHz
• Sensitivity: 110dB/w/m
• Crossover Capacitor Included
1.5’’ Heavy Duty Titanium Super Tweeter
• 1.5’’ Titanium Super Tweeter
• Diamond Chrome Cutting Finish
• 1.5’’ High Temperature Kapton Voice Coil
• 30 oz Magnet Structure
• 150 Watts RMS/300 Watts Peak
• 4-8 Ohms Impedance
PDBT39
• Frequency Response: 2kHz-22kHz
• Sensitivity: 108dB/w/m
• Dimensions: 2.25’’ Diameter, 2.75’’ Depth
1’’ Titanium Super Tweeter
• 1’’ Titanium Super Tweeter
• Die Cast Aluminum Frame
• 500 Watts Max
• 4-8 Ohms Impedance
PDBT38
• Frequency Response: 2 kHz - 25 kHz
• Sensitivity: 106dB/w/m
• 30 oz. Magnet Structure
1’’ Titanium Super Tweeter
• 1’’ Titanium Super Tweeter
• Die Cast Aluminum Frame
• 500 Watts Max
• 4-8 Ohms Impedance
PDBT37
• Rated Power Input (RMS): 150w
• MAX Power Handling: 300w
• Magnet Weight/Type: 12 Oz. Ferrite Magnet
• Baffle Material: ABS + PSF
1.5” Heavy Duty Titanium Super Tweeter
• 1.5’’ Titanium Super Tweeter
• Die-Cast Aluminum Frame
• 250 Watts RMS/500 Watts Max.
• 4 Ohm Impedance
PDBT35
• 4-8 Ohms Impedance
• Ferro Fluid Enhanced Voice Coil
• Sensitivity: 104dB
• Frequency Response: 2kHz - 20kHz
• Mylar Crossover Capacitor Included
• 3.125’’ Diameter - 2’’ Mounting Depth
Tweeters
• Rated Power Input (RMS): 200w
• MAX Power Handling: 400w
• Magnet Weight/Type: 18 Oz Ferrite Magnet
• Baffle Material: ABS + PSF
PDBT43
1.75’’ Die-Cast Titanium Super Tweeter
• Die Cast Plastic Frame
• 400 Watts RMS/800 Watts Max
• 4 Ohm Impedance
• Frequency Response: 2.5 KHz-20 KHz
• Sensitivity: 102 dB/w/m
PDBT45
Extra Heavy Duty Titanium Super Bullet Tweeter
• Cloth Diaphragm
• 400 Watts Max./ 1.75” Voice Coil
• 15 Oz Magnet/ 4~16 Ohm
PDBT48
• Number of bolt holes: 4
• Bolt hole dimension: F5mm (4×)
• Diameter: F91mm
• Mounting depth: 55.5mm
• Total depth: 61 mm
3’’ Extra Heavy Duty Titanium Super Bullet Tweeter
• 3’’ Titanium Super Tweeter
• Die-Cast Aluminum Frame
• Diamond Chrome Cutting Finish
• 3’’ High Temperature Kapton Voice Coil
• 100 oz Magnet Structure
• 500 Watts RMS/1000 Watts Peak
PDBT59
• 300 Watts RMS/600 Watts Peak
• Sensitivity:106 dB/w/m
• Impedance:4-8 Ohm
• Freq.Resp.:2,000HZ-25,000HZ
1’’ Die-Cast Titanium Super Tweeter
• Die Cast Plastic Frame
• 150 Watts RMS/300 Watts Max
• 4 Ohm Impedance
• Frequency Response: 2.5 KHz-20 KHz
• Sensitivity: 100 dB/w/m
PDBT58
• Sensitivity: 106 dB/ w/ m
• Crossover Capacitor Included
• 3 1/8” Diameter/ 2” Mounting Depth
2’’ Titanium Super Tweeter
• 2’’ Titanium Super Tweeter
• Die Cast Aluminum Fram
• Crossover Capacitor Included
• 40oz Magnet Structure
PDBT53
• 4.45’’ Diameter - 3.25’’ Mounting Depth
• 1500-20,000Hz/ 104dB/ w/ m
2’’ Heavy Duty Aluminum Die-Cast Titanium Super Tweeter
• 2” Titanium Super Tweeter
• Die Cast Aluminum Frame
• 600 Watts Max./ 4~8 Ohm
• Freq. Resp: 2000-25,000 Hz
PDBT49
• Number of bolt holes: 4
• Bolt hole dimension: F5.3mm(4×)
• Diameter: F131.2mm
• Mounting depth: 82mm
• Total depth: 102 mm
• 4-8 Ohms Impedance
• Ferro Fluid Enhanced Voice Coil
• Sensitivity: 109dB
• Frequency Response: 2kHz - 25kHz
• Mylar Crossover Capacitor Included
• 5’’ Diameter - 2’’ Mounting Depth
1.75’’ Aluminum Housing Super Bullet Tweeter with Titanium Voice Coil
• Diaphragm Material: Titanium
• Voice Coil Size: 1.75’’(44.4mm)
• Impedance: 4 Ohm
• Sensitivity: 102db/W/M
• Frequency Response: 2-20 kHz
• Rated Power Input (RMS): 500w
• MAX Power Handling: 1000w
• Magnet Weight/Type: 16 Oz Ferrite Magnet
• Baffle Material: ABS + PSF
Tweeters
63
63
PDBT63
1.8’’ Die-Cast cloth Super Tweeter
• Die Cast Plastic Frame
• 360 Watts RMS/720 Watts Max
• 4 Ohm Impedance
• Power: 40W
• Frequency Response: 2 KHz-25 KHz
• Sensitivity: 105 dB/w/m
PDBT68
3’’ Heavy Duty Aluminum Die-Cast Titanium Super Tweeter
• 3” Titanium Super Tweeter
• Die Cast Aluminum Frame
• 1200 Watts Max./ 4~8 Ohm
• Freq. Resp: 2000-25,000 Hz
PDBT78
• Throat Diameter: 26mm
• Mounting Type: Zinc Screw Insert 1 3/8’’- 18 UNEF
• Dimensions: 6.4”h x 11.9”w x 4.4”d
Screw-On Type Constant Radiation Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV)-6 dB:90°x40°
• Cut Off Frequency: 1000 Hz
64
64
• Throat Diameter: 25.40mm (1’’)
• Mounting Flange Diameter: 76mm
• Mounting Hole Diameter: 5.6mm
• Dimensions: 7 7/8’’H x 12 1/2’’W x 10’’D
Screw-On Type Constant Radiation Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV)-6 dB:90°x40°
• Cut Off Frequency: 1000 Hz
PH714
• Throat Diameter: 26mm
• Mounting Type: Zinc Screw Insert 1 3/8’’- 18 UNEF
• Dimensions: 11.6”H x 11.6”W x 9.8”D
Screw-On Type Constant Directivity Horn
• Material: ABS Glass Fiber
• Nominal Coverage Angle (HxV)6 dB: 90-’ba x 40-’ba
• Cut Off Frequency: 800 Hz
PH612
• 4-8 Ohms Impedance
• Sensitivity: 112 dB/W/M
• Frequency Response: 2kHz - 25kHz
• Mylar Crossover Capacitor Included
• Dimensions: 4’’ x 5’’ / 3’’ Mounting Depth
Screw-On Type Constant Radiation Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV)-6 dB:90°x40°
• Cut Off Frequency: 1000 Hz
PH515
• Sensitivity: 114 dB/ w/ m
• Crossover Capacitor Included
• 5” Diameter/ 2” Mounting Depth
2’’ Titanium Super Tweeter
• Die Cast Aluminum Frame
• Diamond Chrome Cutting Finish
• 2’’ High Temperature Kapton Voice Coil
• 20oz Magnet Structure
• 350 Watts RMS/700 Watts Peak
PH12S
• Number of bolt holes: 4
• Bolt hole dimension: 4.5mm×6mm(4×)
• Diameter: F124.5mm
• Mounting depth: 83mm
• Total depth: 91 mm
Tweeters
• Throat Diameter: 26mm
• Mounting Type: Zinc Screw Insert 1 3/8’’ - 18 UNEF
• Dimensions: 6.25”h x 16.5”w x 8.65”d
PH715
Bolt-On Type Constant Directivity Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV) 6dB:90 x 40
• Cut Off Frequency: 1000 Hz
• Throat Diameter: 26mm
• Mounting Flange Diameter: 100mm
PH810
Screw-On Type Radiation Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV)6 dB: 90¦’ba x 40¦’ba
PH818
• 11 Pre-set Drum Kit with up to 4 Variations
• Sound Generator: 16-bit/44.1 kHz 3D Sound Quality
• Natural Motion Cymbal Pads and
Cymbal Choke Capabilities
• Natural Response Drum Head with 128
Level Force Velocities Sensor
• Include: 5 Drum Pads, 2 Cymbal Pads, 2
Drum Sticks, Hi-Hat Pedal, Bass Drum Pedal,
Digital Sound Module, Necessary Connection
Cables, Drum Rack & User Manual
• (Laptop and iPod Not Included)
Electronic Drum Set with Natural Response Drums - Includes 5 Drum Pads
• Drum Sticks Included
• Natural Response Pads
• 3.5mm Headphone Jack
• Fully Adjustable Drum Rack
• Runs on AC 110/220 Auto-Switching
• Built-In Reverb Switch & Metronome
• Mounting Hole Diameter: 6.5mm
• Mounting Holes Number: 4N
• Bolt Circle Diameter: 102mm (4’’) - 76mm (3’’)
• Unit Dimensions: 8.8”h x 17”w x 7.7”d
Electric Thunder Drum Kit With MP3 Recorder
• MIDI In/Out
• Headphone Jack
• Instruction DVD
• Built-in Metronome
• Built-in Reverb Switch
• Fully Adjustable Drum Rack
• A-B Looping Learning Feature
• Built-in MP3 Player/Recorder
• Compact, All-in-One Drum Solution
• Stereo Line-in for Portable MP3 Device
• 110V~220V Auto Switch Power Adapter
PED03
• Throat Diameter: 30mm (1.2’’)
• Dimensions: 7.9”H x 17.6”W x 6.9”D
Bolt-on Type Constant Directivity Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV)-6 dB:90°x40°
• Cut Off Frequency: 1000 Hz
• Throat Diameter: 36mm
• Mounting Flange Diameter: 114mm
PED02M
• Cut Off Frequency: 1000 Hz
• Throat Diameter: 26 mm
• Mounting Type: Zink Screw Insert 1 3/8’’ - 18 UNEF
Screw-On Type Constant Radiation Horn
• Material: ABS Resin
• Nominal Coverage Angle (HxV)-6 dB:90°x40°
• Cut Off Frequency:1000 Hz
PH916
• Mounting Hole Diameter: 6mm
• Mounting Holes Number: 4N
• Bolt Circle Diameter: 81mm - 3’ (76mm)
• Dimensions: 7.8’ x 7.8’ x 4.2’
• 11 Pre-Set Drum Kit with up to 4 Variations
• 2 Pedals Included: Hi-Hat Pedal and Bass Pedal
Electronic Drum Kits
65
65
PED04
Professional Electric Drum Kit
• MIDI In/Out
• Stereo Line-in
• Headphone Jack
• Built-in Metronome
• Cables and Drum Lock
• Built-in Reverb Switch
• Fully Adjustable Drum Rack
• Natural Response Drum Heads
• 128 Level Force Velocities Sensor
• Compact, All-in-one Drum Kit Solution
• 110V~220V Auto Switch Power Adapter
PED07
Professional Electronic Drum Kit - All-in-One Drumming System with Drums for Dummies Instructional CD & Book
• MIDI In/Out
• Headphone Jack
• Fully Adjustable Drum Rack
• Built-In Reverb Switch & Metronome
• 110V ~ 220V Auto Switch Power Adapter
• Stereo Line-In for iPods/MP3 Players
• 11 Pre-Set Drum Kit with up to 4 Variations
• Sound Generator: 16-bit/44.1 kHz 3D Sound Quality
• Natural Motion Cymbal Pads &
Cymbal Choke Capabilities
• Natural Response Drum Heads
with 128 Level Force Velocities
•Package Includes: Digital Sound Module,
PTED01
PTED05
5 Drum Pads, 2 Drum Sticks, Hi-Hat
Pedal & Bass Drum Pedal
Electronic Table Digital Drum Kit Top w/ 7 Pad Digital Drum Kit
• LED Control Display
• Headphone & USB Outputs
• Kick, Hi-Hat & DC Power Inputs
• USB Port Doubles as MIDI In/Out
• 7 Drum Pads with Touch Sensitivity
• 11 Pre-set Drum Kit with up to 4 Variations
• Sound Generator: 16-bit/44.1 kHz 3D Sound Quality
ROCK Drum Kit Includes:
• Digital Sound Module
• Bass Drum Pedal
• Hi-Hat Pedal
• 2 Drum Sticks
• 5 Drum Pads
• User Manual
• Drum Rack
• 2 Different Voice Metronome System
• 215 Percussion Voices & 128 GM Voices
• 25 Preset Drum Kits & 5 User Drum Kits
• Dimensions: 19.65” (L) x 14.5” (W) x 6.2” (D)
Electronic Tabletop Digital Drum Kit
with Instructional Drum For Dummies CD & Book
• LED Control Display
• Headphone & USB Outputs
• Kick, Hi-Hat & DC Power Inputs
• USB Port Doubles as MIDI In/Out
• 7 Drum Pads with Touch Sensitivity
• 2 Different Voice Metronome System
• 215 Percussion Voices & 128 GM Voices
• 25 Preset Drum Kits & 5 User Drum Kits
• Dimensions: 19.65” (L) x 14.5” (W) x 6.2” (D)
66
66
Electronic Drum Kits / Banjo
PBJ60
5 String Banjo
• Top Material: REMO Drumhead
• Mahogany Neck, Back, and Side
• Chrome Plated Hardware
• Rosewood Fingerboard
• Maplewood Bridge
• Weight: 4.9 lbs.
PGAKT10BL
Soprano Ukulele Mini Guitar Starter Package All Ages - Blue
• 4 String Ukulele in Blue
• Color Matched Fingerboard and Bridge
• Painted Laminate Top, Back, & Sides
• Gig Bag with Backpack Style Straps
• High Quality Tuning Machines
PGAKT10PK
Soprano Ukulele Mini Guitar Starter Package All Ages - Pink
• 4 String Ukulele in Pink
• Color Matched Fingerboard and Bridge
• Painted Laminate Top, Back, & Sides
• Gig Bag with Backpack Style Straps
• High Quality Tuning Machines
PUKT15NT
• Durable ABS Binding
• Black Plastic Pickguard
• Guitar Pitch Pipe Tuner Included
• Complete Set of Extra Strings
• Attached Pickguard
• 3 Pearloid Picks
Professional Full Size Acoustic 6 String Guitar w/ Spruce Top
• 42’’ Full Size Acoustic Guitar
• Rosewood Fretboard
• Spruce Top
• Mahogany Back & Sides
• 25.5 Classical Scale
• Scale Length: 17 Inches
• Neck: Hardwood
• Top, Back, Sides, Fingerboard: Linden Plywood
• Bridge: Hard Wood
Professional Full Size Acoustic Guitar Package w/ Accessories
• Rosette Linden Laminate
• Ebonized Maple Bridge And Fingerboard
• Linden Laminate Top, Back, & Sides
• 42’’ 25.5 Scale Full Size Guitar
• Heavy Duty Gig Bag
• Nylon Guitar Strap
• Chrome Tuning Machines
PGA44
• Scale Length: 14 Inches
• Neck: Hardwood
• Top, Back, Sides, Fingerboard: Linden Plywood
• Bridge: Hard Wood
26’’ Tenor Ukulele Kit With Bag, Picks, Pitch Pipe,Straps, Maple/Brown
• Beautiful Tenor-Style Ukulele
• Includes Black Gigbag For Storage And Transport
• Easily Tunable
• Fretboard: Linden Plywood, 16 Frets
PGA20
• Scale Length: 14 Inches
• Neck: Hardwood
• Top, Back, Sides, Fingerboard: Linden Plywood
• Bridge: Hard Wood
21’’ Soprano Ukelele With Bag, Picks, Maple/Brown Color
• Beautiful Soprano-Style Ukulele
• Includes Black Gigbag For Storage And Transport
• Easily Tuneable
• Fretboard: Linden Plywood, 12 Frets
PUKT12BR
• Soprano Ukulele Tuner Included
• 3 Picks
• Nylon Strings w/ Tie Down Bridge
• 22’’ Total Length
21’’ Soprano Ukulele Guitar Package With Bag, Picks,For Beginners and Professionals (Natural Color)
• Beautiful Soprano-Style Ukulele
• Includes Black Gigbag For Storage And Transport
• Easily Tuneable
• Fretboard: Linden Plywood, 12 Frets
PUKT15BR
• Soprano Ukulele Tuner Included
• 3 Picks
• Nylon Strings w/ Tie Down Bridge
• 22’’ Total Length
• Chrome Tuning Machines
• Durable ABS Binding
• Tortoise Pickguard
• Warranty Card - One Year Warranty
Eukeleles / Acoustic Guitars
67
67
PGAKT30
30’’ Inch Beginner Jamer, Acoustic Guitar w/ Carrying Case & Accessories
• 30 inch children guitar
• Body type--Classic
• Specification: 30”
• Top: Linden plywood
• Back & Sides: Linden plywood
• Neck: Nanmu
• Fingerboard: Maple wood
PGAKT39
39’’ Inch Beginner Jammer, Acoustic Guitar w/ Carrying Case & Accessories
• 39 inch acoustic guitar
• Body type: acoustic cutaway
• Specification: 39”
• Top: Linden plywood
• Back & Sides: Linden plywood
• Neck: Nanmu
• Fingerboard: Maple wood
• Bridge: Maple wood
PGAKT40N
PGAKT40SB
• Nut Width: 43mm
• Number of Frets: 20
• Binding: ABS
• Rosette Style: Decal
• Color: Sunburst
• Gig Bag, Strap, Picks, Pitch Pipe,
and Spare Strings Included
Professional Full Size 6 String Electric Guitar w/ Satin Slate Metallic Finish
• Double Cutaway Paulownia Body
• Maple Fretboard
• Maple Neck
• Two Piece Construction w/ Bolt on Neck
• Three Magnetic Pickups
• Two Tone Controls
• Volume Control
• Full Size 25.5 Scale
• Tremolo Bridge w/ Adjustable Saddles
• Removable Whammy Bar
• 8 Foot ¼’’ Patch Cord
• White Pick Guard
• 5-Way Selector Switch
• Satin Metallic Silver Finish
• Chrome Plated Tuning Machines
• 39’’ Full Size Guitar
• Warranty Card - One Year Warranty
Professional Full Size 6 String Electric Guitar w/ Sunburst Finish
• Cutaway Paulownia Body
• Maple Fretboard
• Maple Neck
• Two Piece Construction w/ Bolt on Neck
• Two Magnetic Pickups
• Tone and Volume Control w/ Chrome knobs
• Full Size 25.5 Scale
• Hardtail Bridge w/ Adjustable Saddles
68
68
• Nut Width: 43mm
• Number of Frets: 20
• Binding: ABS
• Rosette Style: Decal
• Color: Natural
• Gig Bag, Strap, Picks, Pitch Pipe,
and Spare Strings Included
41’’ Acoustic-Electric Guitar Package With Gig Bag, Strap, Picks, Tuner, and Strings (Sunburst Color)
• Electronics: Pre-amp With Treble,
Mid, and Bass Controls
• Scale Length: 650mm/41’’
• Body Top: Spruce Laminate
• Body Back & Side: Linden Laminate
• Fretboard Material: Rosewood
• Bridge Material: Rosewood
PGEKT35
• Machine Head: Chrome Open
• Number of frets: 21
• Binding type: single plastic binding
• Nut width/type –4.2CM
• Scale length –46.5CM
• Bracing type: common style, ladder bracing
String type: Steel
41’’ Acoustic-Electric Guitar Package With Gig Bag, Strap, Picks, Tuner, and Strings (Natural Color)
• Electronics: Pre-amp With Treble,
Mid, and Bass Controls
• Scale Length: 650mm/41’’
• Body Top: Spruce Laminate
• Body Back & Side: Linden Laminate
• Fretboard Material: Rosewood
• Bridge Material: Rosewood
PGE25
• Bridge: Maple wood
• Machine Head: Chrome Open
• Number of frets: 19
• Binding type: common style
• Nut width/type: 4.1CM
• Scale length: 33.5CM
• 8 Foot ¼” Patch Cord
• White Pick Guard
• 3-Way Selector Switch
• Sunburst Finish
• Chrome Plated Tuning Machines
• 39’’ Full Size Guitar
• Warranty Card - One Year Warranty
Acoustic / Acoustic-Electric Guitars
PGE55
Professional 42’’ Deluxe Sunburst Finish Electric Guitar
• Body type: Ash/Flame Maple Top
• Rosewood Fingerboard and Maple Neck
• Chrome Die-cast Machine Head
• Bolt on Neck
• 25.5’’ Scale
• 22 Frets
PGE75
Professional 42’’ Semi Hollow Deluxe Sunburst Mahogany Electric Guitar
• Body type: Mahogany/Quilted Maple Top
• Maple Fingerboard Maple Neck
• Chrome Die-cast Machine Head
• Bolt on Neck
• 25.5’’ Scale
PEGKT15B
• Rated power output: 10 watts
• Nominal input level <700mV (RMS)
• Speaker size: 6.5’’
• Controls: Volume, channel select,
switch, Gain, treble, middle, bass
• Power supply: 110V @ 50 Hz
• Power consumption: 0.012 W/h
Amplifier specifications:
• Rated power output: 10 watts
• Nominal input level <700mV (RMS)
• Speaker size: 6.5’’
• Controls: Volume, channel select,
switch, Gain, treble, middle, bass
• Power supply: 110V @ 50 Hz
• Power consumption: 0.012 W/h
Beginner Electric Guitar Package Red
Electric Guitar Features:
• Color: Red
• Body type: Basswood
• Controls: 1 volume, 2 tone
• Number of pickups: 3
• Type of pickups: Single pickups
• String type: Metal
• Fretboard material: Rosewood
• Neck material: Maplewood
• Nut width: 1.7’’
• Scale length: 25.5’’
Amplifier Specifications:
Beginner Electric Guitar Package Grey Silver
Electric Guitar Features:
• Color: Grey-Silver
• Body type: Basswood
• Controls: 1 volume, 2 tone
• Number of pickups: 3
• Type of pickups: Single pickups
• String type: Metal
• Fretboard material: Rosewood
• Neck material: Maplewood
• Nut width: 1.7’’
• Scale length: 25.5’’
PEGKT15R
• 22 Frets
• 3-Way Selector Switch
• Volume and Tony Rotary Controls
• Pickups: Two Dual Coil Single Pickups
Beginner Electric Guitar Package Black
Electric Guitar Features:
• Color: Black
• Body type: Basswood
• Controls: 1 volume, 2 tone
• Number of pickups: 3
• Type of pickups: Single pickups
• String type: Metal
• Fretboard material: Rosewood
• Neck material: Maplewood
• Nut width: 1.7’’
• Scale length: 25.5’’
PEGKT15GS
• 5-Way Selector Switch
• Volume and Tony Rotary Controls
• Three Pickups: One Humbucker,
Two Dual Coil Single Pickups
• Tremolo Bridge
• Includes Protective Gig Bag
Amplifier specifications:
• Rated power output: 10 watts
• Nominal input level <700mV (RMS)
• Speaker size: 6.5’’
• Controls: Volume, channel select,
switch, Gain, treble, middle, bass
• Power supply: 110V @ 50 Hz
• Power consumption: 0.012 W/h
Electric Guitar Packages
69
69
PEGKT15SB
Beginner Electric Guitar Package - Sun Burst
Electric Guitar Features:
• Color: Sun-Burst
• Body type: Basswood
• Controls: 1 volume, 2 tone
• Number of pickups: 3
• Type of pickups: Single pickups
• String type: Metal
• Fretboard material: Rosewood
• Neck material: Maplewood
• Nut width: 1.7’’
• Scale length: 25.5’’
PGEKT30
PGEKT453SB
PGEKT45BK
• Nylon Guitar Strap
• Full Set of Replacement Strings
• 3 Pearloid Guitar Picks
• 10 Foot ¼’’ patch cord
• 39’’ Full Size Scale
• Natural Sunburst Finish
• Hex Key for Neck Adjustments
• Warranty Card - One Year Warranty
Professional 42’’ Electric Guitar Package
• Color: Sunburst
• 6-String Single Cutaway Electic Guitar
• Body Material: Basswood
• Fingerboard Material: Rosewood
• Neck Material: Maple
• Chrome Die-cast Machine Head
• Set-in Neck
• 22 Frets
• 3-Way Selector Switch
• Rotary Controls: 2 Volume, 2 Tone
• Pickups: 2 Humbucker
• Included accessories: Spare Steel Strings
• Digital Tuner: KGT-200
• Includes 3 Picks
• Nylon Gig Band with Carry Strap
• 10 Foot 1/4’’ Guitar Cable
• 15 Watt Amplifier with 6.5’’ Speaker
Professional 42’’ Electric Guitar Package Black Color
• Color: Black
• 6-String Single Cutaway Electic Guitar
• Body Material: Basswood
• Fingerboard Material: Rosewood
• Neck Material: Maple
• Chrome Die-cast Machine Head
• Set-in Neck
• 22 Frets
• 3-Way Selector Switch
• Rotary Controls: 2 Volume, 2 Tone
• Pickups: 2 Humbucker
• Included accessories: Spare Steel Strings
• Digital Tuner: KGT-200
• Includes 3 Picks
• Nylon Gig Band with Carry Strap
• 10 Foot 1/4” Guitar Cable
• 15 Watt Amplifier with 6.5’’ Speaker
Professional Full Size Electric Bass Guitar Package w/ Amplifier
• Double Cutaway Basswood Body
• Maple Fretboard
• Maple Neck
• Two Piece Construction w/ Bolt on Neck
• Three Magnetic Pickups
• Tone and Volume Control w/ Chrome knobs
• Chrome Plated Tuning Machines
• Warranty Card
• Pyle Pro 15B Bass Amplifier w/ 4 Channel
Equalizer, Headphone Output, and 6.5’’ Woofer
70
70
• Rated power output: 10 watts
• Nominal input level <700mV (RMS)
• Speaker size: 6.5’’
• Controls: Volume, channel select,
switch, gain, treble, middle, bass
• Power supply: 110V @ 50 Hz
• Power consumption: 0.012 W/h
Professional Full Size Electric 6 String Guitar Package w/ Amplifier
• Double Cutaway Paulownia Body
• Maple Fretboard
• Maple Neck
• Two Piece Construction w/ Bolt on Neck
• Three Magnetic Pickups
• Tone and Volume Control w/ Chrome knobs
• Chrome Plated Tuning Machines
• Tremolo Bridge w/ Removable Whammy Bar
• Warranty Card
• Pyle Pro KE-10U Amplifier Overdrive
Distortion, Two Channel Equalizer,
Headphone Output, and 6.5’’ Speaker
PGEKT50
Amplifier Specifications:
• Nylon Guitar Strap
• Full Set of Replacement Strings
• 3 Pearloid Guitar Picks
• 10 Foot ¼’’ patch cord
• 44’’ Full Size Scale
• Grey Sunburst and Black Finish
• Hex Key for Neck Adjustments
• Warranty Card - One Year Warranty
Electric Guitar Packages
PGEKT18
Unfinished Strat Electric Guitar Kit - You Build The Guitar
• Kit Includes All Parts And Instructions To
Build A Complete Playable Guitar
• All Holes Are Pre-Drilled, Complete With
Strings And Electric Cord; Available
In Right-Handed Versions Only
• Basswood Body With Sanding Sealer
• Maple Neck, Rosewood Fretboard
With Sanding Sealer
• All Chrome Hardware
• Pickguard With Pickups And Electronics Prewired
• Solid Select Maple Neck With A Fretted Rose-
PGT10
Mini Clip-On Tuner For Chromatic/Guitar/Bass/Violin
• Clip-on digital tuner
• Large, easy-to-read LCD screen
PPDLA1
• Output Impedance: 10K?
• Current Draw: 12ma(DC 9V)
• Residual Noise: -105dbu (IHF-A, Typ.)
• Controls: Pedal Switch, Effect Level,
F. Back Knob, D. Time Knob
• Power Supply: DC 9V; Dry Battery (6F22/9V), AC Adaptor
Guitar Tuning Pedal With Superb Accuracy
• Easily Tune Any String On Your Guitar
With This Easy-To-Use Pedal
• Simply Plug Your Guitar’s Input Into The Unit
• You Can Even Use The Pass Through To
Hear Yourself Play While You Tune Up
• Normal Input Level: -20dbu
• Input Impedance: 1M?
• Normal Output Level: -20dbu
• Output Impedance: 10K?
• Normal Output Level: -20dbu
• Output Impedance: 10K?
• Current Draw: 14ma(DC 9V)
• Residual Noise: -105dbu (IHF-A, Typ.)
• Controls: Pedal Switch, Effect Level, Rate, Depth
• Power Supply: DC 9V; AC Adaptor
Super Guitar Effect Delay Pedal With Delay Time, Feedback, And Level Controls
• Delay Pedal Creates An Unbelievable Sound,
Allowing You To Create Rich Guitar Textures
• Adjust Delay Time, Feedback, And Level
Controls For The Exact Sound You Want
• Adjust Portamento From 12.5 To 300 ms
• Normal Input Level: -20dbu
• Input Impedance: 1M?
• Normal Output Level: -20dbu
PPDLT2
• Jack: Input, Output, Ac Adaptor
• Power Supply: DC 9v; Ac Adaptor
• Controls: Pedal Switch, Level, Attack, Decay, Sens
• Indicators: Check Indicator (Serves
Also As Battery Check Indicator)
• Current Draw: 90ma, (DC 9v)
• Dimensions: 2.83’’ X 5.04’’ X 2.36’’
• Weight: 0.86 Lbs
Super Guitar Chorus Effect Pedal with Depth, Speed, And Level Controls
• Generates A Beautiful, Thick Chorus Effect With An Amazing Sound
• Depth, Speed, And Level Controls Allow
You To Fully Customize The Effect
• Normal Input Level: -20dbu
• Input Impedance: 1M?
PPDLD3
• Ultra-sensitive vibration sensor for accurate tuning in loud environment
Super Guitar Multi-Effect Pedal With Overdrive, Distortion, Chorus, And
• Guitar Effects Pedal With Multiple Effects
• Overdrive Gives You That Classic Crunchy Sound
• Distortion Boosts The Sound For The HeavyMetal Effect You Need To Rock Out
• Chorus Multiplies Your Sound For A Huge Sound
• Digital Delay Lets You Create
Beautiful Texture Effects
• Recommended Load Impedance: 10 K Or Greater
• Residual Noise: -101dbu (IHF-A, Typ.)
PPDLC1
wood Fingerboard, Body Made Of All-Select
Basswood, Headstock Is A Blank Peghead
Shape With Tuning Machine Holes Pre-Drilled
• Adjustable Truss Rod All Hardware
Is Heavily Nickel Plated
• Electronic Parts Are Mounted To The
Pickguard And Ready For Installation
• Solid Select Maple Neck With A Fretted Rosewood
Fingerboard, Body Made Of All-Select Basswood
• Headstock Is A Blank Peghead Shape With
Tuning Machine Holes Pre-Drilled.
• Current Draw: 25ma(DC 9V)
• Residual Noise: -106dbu (IHF-A, Typ.)
• Tuning Frequency Range: 31.7722
Hz (C2)----4022.9040 Hz(B4)
• Tuning Precision: ±2 Cent
• Jack: Input, Output1 ,Output2 AC Adaptor
• Controls: Pedal Switch
• Power Supply: DC 9V; AC Adaptor
Tuners / Guitar Pedals
71
71
PPDLP02
DC Pedal Board Power Supply For Up To 10 Guitar Effects Pedals At 9 Volts
• A Universal Power Supply For All BatteryOperated Guitar Pedal Effect
• Comes Complete With Cables And
A Detachable AC Power Cord
• Powers Up To 10 Effects Pedals @ 9 V Each
• One Unit Replaces 10 Power Adapters –
Great For Saving Space And Electricity
PPDLP03
Universal DC Pedal Board Power Supply - Powers Up To 10 Guitar Effects
• Powers Up To 10 Effects Pedals
• Input: AC 110-240V, 15VA, 50/60Hz
• Enclosed In A Robust ABS Plastic Case
• Includes 10 Cables To Connect Each Pedal
• Output: 6 X 9V DC 100mA, 4 X 18V DC 200mA
• Powers 4 Outlets Dunlop/MXR Pedals At 18 Volts
• 6 Outlets Power Standard Battery
Operated Pedals At 9 Volts
PPDLS1
• Comes Complete with Cables and
Detachable AC Power Cord
• Universal Power Supply For All BatteryOperated Guitar Pedal Effects
• One Unit Replaces 10 Power Adapters –
Great For Saving Space And Electricity
• (Guitar Effects Pedals Not Included)
Acoustic Keyboard/Piano Sustain Pedal
• Piano Style Acoustic Sustain Pedal
• Specially Designed Rubber Bottom Floor Grips
PPDLS10
PPDLS10
• Includes 6 Ft. Cable With ¼’’ Mono Plug
• Polarity Selector Switch For Maximum Compatibility
• Pedal Structure: Thermoplastic
ABS With Metal Pedal
• Type: Sustain Temporary Switch
• Controls: Polarity Switch
• Rating: 0.3A/30v DC
Heavy Duty On/Off Pedal For Keyboards/Guitars/Amps And Synthesizers
• Pedal Acts As On/Off Switch For Your Keyboard
Or Synthesizer
• Works With Most Digital Keyboards And
Synthesizers
• Rubber grip keep your pedal In place while playing
• Pedal Structure: Thermoplastic Aluminum Chassis
With Anti-Skid Feet And Recessed Slots
PPDLWW1
• Works with all 1/4’’ Input Keyboards
Piano-Style Sustain Pedal For Keyboards And Synthesizers
• Classic Piano-Style Pedal Works With Most
Digital Keyboards And Synthesizers
• Designed To Work And Feel Just Like
Acoustic Piano’s Sustain Pedal
• Specially Designed Rubber Bottom
Grips The Floor While You Play
• High-Quality Chrome Foot Pedal With
Expressive Half-Pedal Capabilities
• Controls: LED Diode
• Output: 1/4’’ Mono Jack, 6 Ft.
Cable With Mono Plug
• Power Rating: 0.3A/30v DC
• Current Drain: <10mA (LED)
• Power: 9V Battery (Not Included)
Wah-Wah Electric Guitar Pedal
• Wah-Wah Effects Pedal
• Designed for Electric Guitars
• True Bypass Switch
72
72
• Input: AC 110-240V, 15VA, 50/60Hz
• Output: 10 X 9V DC 100mA
• Enclosed In A Robust ABS Plastic Case
• Includes 10 Cables To Connect Each Pedal
• Specially Designed Rubber Bottom Floor Grips
• Instrument & Amplifier 1/4’’ Ports
Guitar Pedals / Accessories
PPG260A
80 Watts Portable Guitar Amplifier
• Heavy Duty Wood Construction
• 20 Watts RMS/80 Watts Peak
• 6. 5’’ High Definition Speaker
• Volume, Bass and Treble Controls
• 1/4’’ Phone Jack Input
PPG460A
150 Watts High Power Guitar Amplifier
• Heavy Duty Wood Construction
• 30 Watts RMS/150 Watts Peak
• 8’’ High Definition Speaker
• Volume, Bass, Mid and Treble Controls
• 1/4’’ Phone Jack Input
• 1/4’’ Headphone Jack
PRAGE45
• Volume Control
• 1/4’’ Headphone Jack for Silent Rehearsing
• Frequency Response: 20 Hz to 15 kHz
• Dimensions: 10’’ x 6.1’’ x 11.4’’
• Weight: 7.7 lbs.
30 Watts Vamp-Series Amplifier With 3-Band EQ and Overdrive
• 6’’ Speaker
• Two Channels: Clean and Overdrive
For a Crunchy, Powerful Sound
• Gain Control for Overdrive
• Rated Power: 30 Watts
• 3-Band EQ: Control Treble, Mid-range, and Bass
• 1/4’’ Headphone Jack for Silent Practicing
• 1/4’’ Foot Switch Jack
• Reverb Knob For Professional Effect
• Load Impedance: 4 ohms
• Rated Power: 75 Watts
• Signal/Noise Ratio: > 70dB
• Frequency Response: 20 Hz - 16 kHz
• Weight: 29.1 lbs.
20 Watts Vamp-Series Amplifier With 3-Band EQ
• 6’’ Speaker
• Two Channels: Clean and Overdrive
For a Crunchy, Powerful Sound
• Gain Control for Overdrive
• Rated Power: 20 Watts
• 3-Band EQ: Control Treble, Mid-Range, and Bass
PVAMP30
• 1/4’’ Headphone Jack for Silent Practicing
• 1/4’’ Foot Switch Jack
• Load Impedance: 4 ohms
• Rated Power: 45 Watts
• Signal/Noise Ratio: > 70dB
• Frequency Response: 20 Hz - 16 kHz
• Weight: 26.22 lbs.
75 Watts Rage-Series Electric Guitar Amplifier With Overdrive
• 10’’ Speaker
• Two Channels: One Clean, One Fuzzy Overdrive
• Clean Channel Has volume,
Treble, and Bass controls
• Overdrive Channel Has Gain, Volume,
Treble, Middle, and Bass controls
• High and Low Level 1/4’’ Inputs
• Stereo RCA Jacks with Volume Control
on Back to Play Along to CD
PVAMP20
• 1/4’’ Line Out
• Carry Handle
• Bass Expander Circuit
• Power On/Off Switch w/LED Indicator
• AC110/220 Voltage Switchable
• Dimensions: 13’’W x 16’’H x 9.75’’D
45 Watts Rage-Series Electric Guitar Amplifier With Overdrive
• 6’’ Speaker
• Two Channels: One Clean, One Fuzzy Overdrive
• Clean Channel Has Volume,
Treble, and Bass Controls
• Overdrive Channel Has Gain, Volume,
Treble, Middle, and Bass Controls
• High and Low Level 1/4’’ Inputs
• Stereo RCA Jacks with Volume Control
on Back to Play Along to CD
PRAGE75
• 1/4’’ Headphone Jack
• Carry Handle
• Power On/Off Switch w/LED Indicator
• AC110/220 Voltage Switchable
• Dimensions: 9.66’’W x 10.25’’H x 6.25’’D
• Volume Control
• 1/4’’ Headphone Jack for Silent Rehearsing
• 1/4’’ Output Jack for Hooking Up External Speakers
• Frequency Response: 20 Hz to 15 kHz
• Dimensions: 13.2’’ x 7.7’’ x 11.6’’
• Weight: 13.2 lbs.
Guitar Amplifiers
73
73
PVAMP60
60 Watt Vamp-Series Amplifier With 3-Band EQ, Overdrive, And Digital Delay
• 8’’ Speaker
• High and Low Level Inputs
• Two Channels: Clean and Overdrive
For a Crunchy, Powerful Sound
• Gain Control for Overdrive
• Rated Power: 60 Watts
• 3-Band EQ: Control Treble, Mid-range, and Bass
PVAMP120
120 Watt Vamp-Series Amplifier With 3-Band EQ, Overdrive, And Effects Loop
• 12’’ Speaker
• High and Low Level Inputs
• Two Channels: Clean and Overdrive
For a Crunchy, Powerful Sound
• Gain Control for Overdrive
• Rated Power: 120 Watts
• 3-Band EQ: Control Treble, Mid-Range, and Bass
PDC21
• Volume control
• 1/4’’ Headphone Jack for Silent Rehearsing
• 1/4’’ Foot Pedal Jack
• Two 1/4’’ Jacks For an Effects Loop
• Frequency Response: 20 Hz to 15 kHz
• Dimensions: 19.5’’ x 8.86’’ x 16.33’’
• Weight: 27.6 lbs.
1/4’’ Instrument To Balanced & Unbalanced (1/4’’/XLR) Direct Box
• Construction: All Steel Chassis
• Ground Lift: Switch-Able Ground Lift
• Balanced Output: 600 Balanced XLR Jack
• Instrument Input: 50K Unbalanced TS Jack
• Parallel (Link) Out: 50K Unbalanced TS Jack
• Input Attenuation: Switch-Able (0db, -20db,-40db)
• Dimension: 4.72’’ X 3.01’’ X 1.77’’• The DC-21
PDC22
• Volume Control
• 1/4’’ Headphone Jack for Silent Rehearsing
• 1/4’’ Output Jack for Hooking Up External Speakers
• Frequency Response: 20 Hz to 15 kHz
• Dimensions: 15.75’’ x 8.27’’ x 13.58’’
• Weight: 22 lbs.
Is One of The Most Useful and Versatile Tools
Available Indispensable in Enabling Easy
Interfacing and Connection Between Various
Audio Gear in Numerous Applications.
Dual 1/4’’ Instrument To Balanced & Unbalanced (1/4’’ XLR) Direct Box
• Construction: All Steel Chassis
• Ground Lift: Switch-Able Ground Lift
• Balanced Output: 600 Balanced XLR Jack
• Instrument Input: 50K Unbalanced TS Jack
• Parallel (Link) Out: 50K Unbalanced TS Jack
• Input Attenuation: Switch-Able (0db,-20db,-40db)
• Two High-Quality Direct Boxes In
One Convenient Enclosure
• Dimension: 5.5’’ x 4.72 x 1.57 ‘’
PDC300
Exclusive Hot Active Direct Box - Unbalanced 1/4’’ And XLR To Balanced XLR
• Rugged, Road-Proof Case
• Ground Lift Switch Eliminates Typical Ground Loop Problems
• Link Output Allows For Direct Connection
• Internal Battery Automatically Shuts Down
When Phantom Power Is Connected
• Frequency Response: 20Hz - 20kHz
• Noise Level (22Hz - 22khz, Input Shorted): -100dbu
• THD+N (10Hz-22khz): 0.01%[email protected] RMS,1khz
• Max. Input Level (1%THD): +6 dbu
74
74
• Input: One 1/4’’ Phone Jack, Unbalanced, One
XLR Connector, Balanced Or Unbalanced
• Output: One XLR Connector, Balanced
• Link Output: One 1/4’’ Phone Jack, Unbalanced
• PAD Switch: 0db, -20db, -40db Setting
• Ground Lift Switch
• Battery: 9V
• Dimensions: 6.22’’ X 3.94’’ X 1.97’’
• Weight: 0.88 lbs.
Guitar Amplifiers / Direct Boxes
PCT10
8 Plug Pro Audio Cable Tester
• Enables quick convenient continuity cable testing for all type of cables
• LED’s confirm each conductor continuity and connection
• 6-Way Switch for selecting connections to be tested
• Includes internal battery and ground connection status check
• Rugged, compact, metal construction for long life and reliability
• Tests cables with all types combinations of the following connections
• 3.5mm TRS Jack
PCT40
• 1/4’’ TRS Jacks
• 3 Pin XLR Male
• 3 Pin XLR Female
• RCA Phono
• 4 Pin Speakon
• Banana Plugs
• 9V Batter (Not Included)
12 Plug Pro Audio Cable Tester
• Enables quick convenient continuity cable testing for all type of cables
• LED’s confirm each conductor continuity and connection
• 6-Way Switch for selecting connections to be tested
• Includes internal battery and ground connection status check
• Rugged, compact, metal construction for long life and reliability
• Tests cables with all types combinations of the following connections
• USB
• 1/4’’ TRS Jacks
• 3 Pin XLR Male
• 3 Pin XLR Female
• 5 pin XLR
PCT60
13 IN 1 Audio Cable Tester (Tests 1/4’’ (TRS) /1/8’’ (3.5mm)
• Enables Quick Convenient Continuity
Cable Testing For All Type Of Cables
• LEDS Confirm Each Conductor’s
Continuity and Connection
• Switch for Selecting Connections to Be Tested
• Includes Internal Battery and Ground
Connection Status Check
• Rugged, Compact, Metal Construc-
PAD6
• Common EQ Function
• With One 1/8’’ Microphone Input jack
• With One 1/8’’ Headphone Output jack
• With One 1/8’’ Phono /Line Input jack
• Dimensions: 6.2’’W x 1.2’’D x 5.2’’H
Linear PCM Recorder
• Linear PCM (Pulsed Code Modulation) In WAV format
• Built-In 2GB Flash Memory
• Varies Recording Sampling Freq. & Bit
(From 22.05kHz 16bit – 96kHz 24bit)
• Mono & Stereo recording Selection
• Display : 35mm x 20mm w/ 128 x 64 dot
• Voice Recording Time
• Linear PCM Stereo Mode:22.05KHz 16bit
705.6kbps, Recording Time = 5.2Hours.
• 96KHz 24bit 4608kbps, Recording Time = 48Min.
• Linear PCM Mono Mode
• 22.05KHz 16bit 352.8kbps, Recording Time = 10.5Hours.
• 96KHz 24bit 2304kbps, Recording Time = 1.6Hours.
• MP3 Stereo: 128kbps, Recording time = 28.3Hours
tion for Long life and Reliability
• Tests Cables with All Types Combinations of the Following Connections
• 1/4’’ (TRS) /1/8’’ (3.5mm)/XLR (3-pin)/XLR
(5-pin)/Speakon (4-pin)/Speakon (8-Pin)/
RCA/TT/Bantam/RJ45/USB-A/USB-B/DIN
(3-pin, 5-pin, 7-pin, or 8-pin)/DIN (4-Pin)
USB Audio Interface & Recorder & SD Card
• Offer 2 Kinds Power (5V) Ways Supply
• DC In Battery (with LED Indication)
• 4 Signal Input: SD Card, USB, PHONO & Line
• Common Play & Control Function (MP3/WMA Formats)
• With Recording Function & Adjustable Value of Record Volume
PPR80
• RCA Phono
• 4 Pin Speakon
• 4 Pin S Type Jack
• Banana Plugs
• 4 pin s Type Jack
• 3-Pin Din
• 5-Pin Din
• 8-Pin Din
• Rj45
• 9v Battery (Not Included)
• MP3 Mono Mode 32kbps, Recording time = 113Hours
• Built-In SD Card Slot (Up to 16 GB, Support SDHC)
• 4 Message Folders Selection (A/B/C/D)
• Built-In Microphone & Stereo Speakers
• Built-In External Mic. Jack, Ear Phone & Line-in Jack
• Delay Recording : 5/10/30/60 Seconds
• Hold On/Off
• Dot Matrix LCD Full Function Display
• Repeat 1 & Repeat All Selection
• USB 2.0
• Accessories: Earphone / USB Cable
• Power: 2 x ‘’AA’’ Batteries (Not Including)
• Dimension: 112 x 60 x 22 mm
• MP3 Subject To Customer Request & License
Direct Boxes / Cable Testers
75
75
PCBL10F1
PCBL1F12
12 Gauge 1Ft RCA Male
To 3-Pin XLR Male Audio
Cable
Premium Quality 12 Ft 1/4’’ To Premium Quality 25 Ft 1/4’’ To
1/4’’ Guitar/Instrument/Amp
1/4’’ Guitar/Amp/Instrument
Cable W/Fabric Shielding
Cable W/Fabric Shielding
Premium Quality 15 Ft
Dual 1/4’’ Male To 1/4’’
Male Jack
PCBL2F3
PCBL2F6
PCBL38FT6
PCBL1F25
PCBL34
Premium Quality 3 Ft Dual
1/4’’ Male To 1/4’’ Male
Jack
Premium Quality 6 Ft Dual
1/4’’ Male To 1/4’’ Male
Jack
PCBL3F1
PCBL3F3
1 Ft 1/4’’ Stereo Male To 1
XLR Male And XLR Female Y-Cable
3 Ft 1/4’’ Stereo Male To 1 12 Gauge Compatible With
XLR Male And XLR FeSpeakon Connector Male
male Y-Cable
To 1/4’’ Female Cable
12 Gauge 6Ft RCA Male
To 3.5mm’’ Male Cable
PCBL43FT3
PCBL43FT6
PCBL4F25
12 Gauge 3Ft 3.5mm Male
Stereo To Dual 1/4’’ Male
Mono Y-Cable Adapter
76
76
12 Gauge 1/4’’ Female To
Dual Banana Plug Cable
PCBL2F15
PCBL41
PCBL4F12
12 Gauge 3.5mm 6Ft Male 12 Gauge 12Ft 1/4’’ Male
Stereo To Dual 1/4’’ Male To Right Angle 1/4’’ Male
Mono Y-Cable Adapter
Phono Instrument/Amp
Pro Cables & Adapters
6 Ft 12 Gauge 3.5mm
Male To Dual XLR Female
Cable
PCBL42FT6
Gauge 25Ft 1/4’’ Male
To Right Angle 1/4’’ Male
Speaker Amp Cable
PCBL4F6
PCBL9F1
PCBLG6
12 Gauge Right Angle
Metal 1/4 To 1/4 Guitar
Patch Cable 6 Inch
12 Gauge 1Ft 1/4’’ Male
To 1/4’’ Male Phono
Speaker Cable
PCBLG7F3
PCBLG7I06
PCBLGF12
PCBLGF25
12 Gauge 3Ft 1/4’’ Male
To 1/4’’ Male Speaker
Cable
12 Gauge 6 Inches 1/4’’
Male To 1/4’’ Male
Speaker Cable
Coiled 12Ft 1/4’’ Male To
1/4’’ Right Angle Male Guitar/
Instrument/Speaker Phono
Cable
Coiled 25Ft 1/4’’ Male
To 1/4’’ Right Angle Male
Speaker Cable
PCBLGF6
PCBLGF100
PCBLGF300
PCBLGF500
PPBB15
PPBB30
PPFMXLR01
PPFMXLR15
15 Feet 12 Gauge Banana Plug To Banana Plug
Speaker Cable
30 Feet 12 Gauge Banana
Plug To Banana Plug
Speaker Cable
12 Gauge 6 Inch 1/4’’ To
XLR Female Cable
15ft. XLR Male to XLR Female Microphone Cable
6 Ft 1/4’’ Male To Right
Angle 1/4’’ Male Phono
Cable
Coiled 6Ft 1/4’’ Male To
1/4’’ Right Angle Male Guitar/Instrument/Amp Cable
12 Gauge 1Ft RCA Male
To 3-Pin XLR Female Audio Cable
100Ft 12 AWG Spool
Speaker cable With Rubber Jacket
300Ft 12 AWG Spool
Speaker cable With Rubber Jacket
PCBLG7F1
500Ft 12 AWG Spool
Speaker cable With Rubber Jacket
Pro Cables & Adapters
77
77
PPJJ15
PPJJ30
PPJJ50
PPJX20
15ft. 12 Gauge Professional Speaker Cable 1/4’’
to 1/4’’
30ft. 12 Gauge Professional Speaker Cable 1/4’’
to 1/4’’
50ft. 12 Gauge Professional Speaker Cable 1/4’’
to 1/4’’
20 Feet 12 Gauge Professional 1/4’’ Phono To XLR
Male
PPJX50
PPMCL15
PPMCL30
PPMCL50
50 Feet 12 Gauge Professional Speaker Cable 1/4’’
to XLR Male
15ft. Symmetric Microphone Cable XLR Female
to XLR Male
30ft. Symmetric Microphone Cable XLR Female
to XLR Male
50ft. Symmetric Microphone Cable XLR Female
to XLR Male
PPMJL15
PPMJL30
PPMJL50
PPRCJ05
15ft. Professional Microphone Cable 1/4’’ Male to
XLR Female
30ft. Professional Microphone Cable 1/4’’ Male to
XLR Female
50ft. Professional Microphone Cable 1/4’’ Male to
XLR Female
Dual 5ft. Professional Audio Link Cable 1/4’’ Male to
RCA Male
PPRCX05
PPSJ15
PPSJ30
PPSJ50
Dual 5ft. Professional
Audio Link Cable XLR
Female to RCA Male
78
78
15ft. 12 Gauge Professional
30ft. 12 Gauge Professional
Speaker Cable Compatible With Speaker Cable Compatible With
Speakon Connector to 1/4’’
Speakon Connector to 1/4’’
Pro Cables & Adapters
50ft. 12 Gauge Professional
Speaker Cable Compatible With
Speakon Connector to 1/4’’
PPSS15
PPSS30
PPSS50
PPSN811
15’ Foot Professional Speaker Cable Male Compatible
With Speakon Connector
to Male Compatible With
Speakon Connector
30’ Foot Professional Speaker Cable Male Compatible
With Speakon Connector
to Male Compatible With
Speakon Connector
50’ Foot Professional Speaker Cable Male Compatible
With Speakon Connector
to Male Compatible With
Speakon Connector
10 Ft. 8 Channel XLR
Male to XLR Female
Snake Cable
PPSN813
PPSN814
PPSN815
PPSN817
10 Ft. 8 Channel XLR
Male to 1/4’’ Male Unbalanced
10 Ft. 8 Channel Unbalanced 1/4’’ Male to 1/4’’
Male Snake Cable
10 Ft. 8 Channel RCA
Male to RCA Male Snake
Cable
10 Ft. 8 Channel RCA
Male to 1/4’’ Male Unbalanced Snake Cable
PPSN817
PPSN821
PPSN823
PPSN827
10 Ft. 8 Channel Balanced
(Stereo) 1/4’’ Male to 1/4’’
Male Snake Cable
20 Ft. 8 Channel XLR
Male to XLR Female
Snake Cable
20 Ft. 8 Channel XLR
Male to 1/4’’ Male Unbalanced Snake Cable
20 Ft. 8 Channel RCA
Male to RCA Male Snake
Cable
More great products and detailed product-specific information @
PyleAudio.com
Pro Cables & Adapters
79
79
PGS304
Folding Guitar Stand
• Depth: 13’’
• Set-up Width Positions
• Set-up Height: 17’’
• Fold-up Height: 18’’
PGS313
• Cradle Depth Opening: 13’’
• Square Steel Tube Size: 1’’L X 0.6’’W X 16’’H
• Round Steel tube Size: Ø1’’ X 11’’
• Weight: 0.8 lbs.
Guitar Wall Hanger
• Depth From Mounting Source :6’’
• Weight Capacity : 35 lbs
• Made For All Regular-Size Necked Instruments
PKS312
Folding Tripod Guitar Stand
• Holds Virtually Any Acoustic Or
Electric Guitar Or Bass
• Flush End Caps To Protect Your Instrument
• Security Strap
• Black Velveteen Rubber
• Matte Black Powder Coat Finish
• 17mm Tubing (Top Section)
• Stepped Yoke For Gravity-Assisted Stability
PGST20
Guitar Foot Stool
• Height Adjustable From 5’’ To 10’’
• Durable Black Anodized Finish
• Ridged Non-slip Rubber Tread
• Support Bar Locks Into Sturdy Brackets
PKS20
• Welded With Heavy-Duty Steel Construction
• Steel Base Supports With NonMarking Rubber End Caps
• Height: 39.5’’
• Weight Capacity: 198 lbs
Keyboard Stand with Music Stand and Microphone Boom
• X Braced Design For Maximum Stability
• Secure-Lock Center Clutch Height
Adjustment System
• Adjustable From 20’’ To 63’’ Playing Height
For Seated To Standing Positions
• Full Close Position For Easy Storage
• Welded, Heavy-Duty 1-Inch Square
80
80
• Adjustment Levels
• Folds Flat For Compact Storage
• Height: 10’’
• WEIGHT:0.4 lbs.
Double X Braced Heavy Duty Keyboard Stand
• Double X Braced Design For Maximum Stability
• Secure-Lock Center Clutch Height
Adjustment System
• Adjustable From 19.7’’ X 39.4’’ Playing
Height For Seated To Standing Positions
• Full Close Position For Easy Storage
PKS30
• Rolled Edge Of Bottom Section For Easy Setup
• Non-Scratching Height Adjustment Knob
• 22mm Tubing (Bottom Section)
• Solid Steel Rod With Keyway
• Heavy-Duty Sheet Metal Leg Housing
• Non-Slip End Cap Feet
• Dimension :6’’L X 6’’W X 34’’H
And Round Steel Construction
• Stable 16” Long Steel Base Supports
With Non-Marking Rubber End Caps
• Weight Capacity: 80 lbs.
• Collapsible Music Holder
• Microphone Stand
• Music Stand And Microphone Stand Removable
Musical Equipment Stands
PKS60
Two Tier Double X Braced Heavy-Duty DJ Coffin / Keyboard Stand
• Double X 2 Tier Steel Braced
Heavy Duty Keyboard Stand
• Secure-Lock Center Clutch Height
Adjustment System
• For Use Of Keyboards and DJ Players
• Adjustable From 39 1/4’’ X 51 1/4’’ Playing
Height For Seated To Standing Positions
PKS78
Heavy Duty Fully Adjustable Slant Keyboard Stand
• Keyboard Stand Supports Most 88-Key
Keyboards And DJ Equipment
• All Steel Construction Provides Maximum
Sturdiness And Ensures Excellent Support
• Features Telescoping Depth To Accommodate Virtually Any Size Keyboard
• Fully Adjustable Tiers Can Be Quickly
Set At Any Of The Height Positions
PAS10
• Bench Seat Size: Ø12’’
• Load capacity: 275Lbs
• Seat thickness :2’’
• Weight: 8 lbs.
Adjustable X-Style Keyboard Bench
Steel Construction
Legs Fold Flat For Storage
3 Convenient Height Positions
Height Adjustment From 16’’ To 24’’
Cushion Thickness: 1.5’’
• Heavy duty wheels
• Some assembly required
• With Gooseneck Microphone Holder
• Size: 46H’’ x 18.5’’ x 21.65’’
Double Braced Folding Padded Drum Throne - Keyboard Bench - Guitar
• Construction: Steel
• Legs fold flat for storage
• 6 Convenient Height Positions
• Height: From 17’’ To 24’’
• Cushion Thickness: 2’’
PKST60
• Strong Steel Frame for Stability
• Rubberized Feet Prevent Slippage
• Top Platform Dimensions:
14.0’’H X 16.1’’W X 4.7’’D
• Height Adjustment Range: 12.4” To 24.8’’
• Depth Range: 15.5’’ to 23.7’’ Width: 16.8’’
• Load Capacity: 90Lbs
DJ Stand W/Gooseneck and Mic Holder
• Top slant capacity - 4U
• Bottom slant capacity - 3U
• Front capacity - 16U
• Reinforced steel frame
• Gooseneck microphone holder
PKST50
• Height Adjustable For Your Convenience
• Tripod Base Provides Additional
Security And Support
• Easy To Set Up And Tear Down
• Maximum Weight Capacity:150.0 Lbs.
• Setup Height: From: 20’’ To 43.0’’
• .Product Weight: 10.0lbs.
• Length Of Tier: 18’’
Heavy-Duty Stage Monitor Or Guitar Amp/DJ Coffin/KeyBoard Stand
• Securely Holds Small Amps and Combos
With Up To Two 12”Speakers
• Full-Circle Tilt Adjustable Amp Platform
Allows For Exact Amp Positioning
• 5 Height Adjustment Position with
Spring-Loaded Locking Pin
• Back Leg Folds Forward For Easy Portability
PDJSD3
• Adjustable Width : From 14’’ To 38’’
• Full Close Position For Easy Storage
• Long Steel Base Supports With NonMarking Rubber End Caps
• Height: 51’’
• Load Capacity: 220 lbs
Bench Seat Size: 21’’L X 9’’W
Load Capacity: 275lbs.
Seat Thickness:1.5’’
Weight: 9 lbs.
Musical Equipment Stands
81
81
PLPTS2
Pro DJ Laptop Tripod Adjustable Stand For Notebook Computer
• Portable Laptop/Notebook Desk/Workstation
• Easily Adjustable Height
• Stand For Musicians, DJs, Based Performances
• Set-up Height From 16’’ To 28’’
PLPTS3
• Black High Gloss Finish
• Steel Frame Construction
• Dimensions: 16’’L x 16’’W x 4’’H
Pro DJ Laptop Tripod Adjustable Stand For Notebook Computer
• Portable Laptop/Notebook Desk/Workstation
• Easily Adjustable Height
• Set-up Height From 28’’ To 41’’
• Wood Material Counter Construction
PLPTS4
• Black High Gloss Finish
• Stand For Musicians, DJs, Based Performances
• Steel Frame Construction
• Dimensions: 23’’L x 16’’Wx 4’’H
Pro DJ Laptop Tripod Adjustable Stand For Notebook Computer
• Portable Laptop/Notebook Desk/Workstation
• Easily Adjustable Height
• Set-up Height From 28’’ To 46’’
• Stand For Musicians, DJs, Based Performances
PLPTS25
• Wood Material Counter Construction
• Black High Gloss Finish
• Steel Frame Construction
• Dimensions:28’’L x 16’’W x 5’’H
Laptop Computer Stand For DJ
• Ideal For Holding Your Laptop, CD Player/
Controller, EFX Machine Or Lighting Controller
• This Versatile Stand Can Stand Alone On Any
Flat Surface For Quick And Easy Set-Up
PLPTS26
• Features 4 Easy Line-It-Up Height Adjustments
• Platform Dimensions: 9.25(w) x 10.8(d) Inches
• Height Range: 6.3 - 10.9 inches
• Weight Capacity: 8 lbs.
Laptop Computer Stand For DJ W/Storage Shelf
• Ideal For Holding Your Laptop, CD Player/
Controller, EFX Machine Or Lighting Controller
• Includes a Storage Shelf
• This Versatile Stand Can Stand Alone On Any
Flat Surface For Quick And Easy Set-Up
PLPTS30
• Features 4 Easy Line-It-Up Height Adjustments
• Platform Dimensions: 9.25’’w x 10.8’’D
• Height Range: 6.3 - 10.9 inches
• Weight Capacity: 8 lbs.
Laptop Computer Stand For DJ With Flat Bottom Legs
• Ideal For Holding Your Laptop, CD Player/
Controller, EFX Machine Or Lighting Controller
• This Versatile Stand Can Stand Alone On Any
Flat Surface For Quick And Easy Set-Up
• Features 4 Easy Line-It-Up Height Adjustments
PMKS15
•
•
•
•
•
•
82
82
• Platform Dimensions: 9.25’’ (w) x 10.8’’ (d)
• Flat Bottom Legs Lets You Slide This Stand
Underneath A Mixer Or DJ Controller
• Height Range: 6.3’’ - 10.9’’
• Weight Capacity: 8 lbs.
Universal Microphone Stand - Adjustable & Extendable
Black Glossy Finish
Lock-Tight Pivot Knob
Round Metal Base Plate
Easy Adjust Extending Arm
M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
•
•
•
•
•
Strong, Durable & Lightweight Construction
Height Adjustable from 27.5-Inches to 51-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 9 Lbs.
Color: Black
Musical Equipment Stands
PMKS18
•
•
•
•
•
•
Glossy Black Finish
Round Metal Base Plate
Lock-Tight Tension Knob
(2) M-6 Microphone Holders Included
Reinforced Engineered Plastic Joints
Strong, Durable & Lightweight Construction
PMKS19
•
•
•
•
•
•
•
•
•
•
•
•
Height Adjustable from 27.5-Inches to 52-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 2.7 Lbs.
Color: Black
•
•
•
•
•
•
Rugged Roller-Wheels Legs w/ Locking Mechanism
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 5.5 Lbs.
Color: White
Universal Microphone Stand with Adjustable & Pivotable Gooseneck
•
•
•
•
•
Strong, Durable & Lightweight Construction
Height Adjustable from 31.5-Inches to 60-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 9.4 Lbs.
Color: Black
Universal Tripod Microphone Stand - Adjustable & Extendable
Glossy Black Finish
Anti-Slip Tripod Legs
Lock-Tight Tension Knob
M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
Strong, Durable & Lightweight Construction
PMKS40
•
•
•
•
•
•
•
•
Universal Rolling Tripod Microphone Stand - Adjustable & Extendable
Glossy Black Finish
Round Metal Base Plate
Lock-Tight Tension Knob
M-6 Microphone Clip Included
Adjustable & Pivotable Gooseneck
Reinforced Engineered Plastic Joints
PMKS38
Height Adjustable from 37.5-Inches to 65-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 9 Lbs.
Color: Black
•
•
Lock-Tight Tension Clamp
Polished Easy-Clean Finish
M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
Strong, Durable & Lightweight Construction
Height Adjustable from 27.5-Inches to 52-Inches
PMKS32
•
•
•
•
•
•
•
•
Universal Tripod Microphone Stand - Height Adjustable
Glossy Black Finish
Anti-Slip Tripod Legs
Lock-Tight Tension Knob
M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
Strong, Durable & Lightweight Construction
PMKS22
•
•
•
•
•
•
Universal Dual-Holding Microphone Stand - Height Adjustable
•
•
•
•
Height Adjustable from 37.5-Inches to 63-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 5.5 Lbs.
Color: Black
Universal Microphone Stand - Height Adjustable
Black Glossy Finish
Lock-Tight Pivot Knob
Round Metal Base Plate
Easy Adjust Extending Arm
M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
•
•
•
•
•
Strong, Durable & Lightweight Construction
Height Adjustable from 27.5-Inches to 57-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 9.4 Lbs.
Color: Black
Musical Equipment Stands
83
83
PMKS45
•
•
•
•
•
•
•
Glossy Black Finish
Lock-Tight Tension Knob
Fold-Out True-Grip Tripod Legs
M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
Strong, Durable & Lightweight Construction
Height Adjustable from 37.5-Inches to 63-Inches
PMKSKT35
•
•
•
•
•
•
•
Universal Tripod Microphone Stand - Adjustable & Extendable
•
•
•
•
•
•
•
•
• Length Of Boom: 33.46’’
• External Thread Size: 5/8 x27
• Base Diameter: 235mm (9.25 in.)
• Weight: 9.92lbs
Compact Base Microphone Stand
• Height Adjustment From 19’’ To 26’’
• Boom Length: 16’’
• Compact Weighted Base
• Perfect For Base Drums And Guitar Amp Milking
• Iron Die-Casting
84
84
• Constructed With Strong, Lightweight Tubing
• MIC Holder Included
• Dimensions: L3.5’’X W3.5’’X H38’’
• WEIGHT : 3.7 Lbs
Compact Base Black Microphone Stand
• Die-Cast And Steel Construction
• Sleek Black Finish
• Ultra-Light For Easy Transport
• MIC Holder Included
• Height Adjustment From 33.5” to 60.24’’
PMKS7
• Matt Black Finish
• Comes with Microphone Clip
• Constructed with Strong, Lightweight Tubing
Tripod Microphone Stand W/ Extending Boom
• Telescopes To 5.5 Feet
• Boom Extends To 28 ‘’
• Fast & Smooth Boom And Height Adjustments
• Knob Boom Adjustment
• Gloss Black Finish
PMKS5
Height Adjustable from 27.5-Inches to 52-Inches
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Boom Length: 24-Inches
Total Weight: 3.0 Lbs.
Carry Bag Included
Color: Black
Tripod Microphone Stand w/Boom
• Telescopes to Boom From 36” to 65”
• Boom Extends to 28’’
• Fast & Smooth Boom and Height Adjustments
• Vise Boom Adjustment
PMKS3
Rugged Roller-Wheels Legs with Locking Mechanism
USA Standard 5/8-Inch Microphone
Adaptor and Threading
Total Weight: 5.5 Lbs.
Color: Black
(2) Universal Tripod Microphone Stands - Adjustable & Extendable
Glossy Black Finish
Anti-Slip Tripod Legs
Comes with 2 Mic Stands
Lock-Tight Tension Knob
(2) M-6 Microphone Holder Included
Reinforced Engineered Plastic Joints
Strong, Durable & Lightweight Construction
PMKS2
•
•
• Clutch And T-Bar Adjustment Points
• Black Finish
• Base Weight : 3.3lbs
• Base Dimensions: 6’’L X 5’’W X 2’’H
• Dimensions:19’’L X 6’’W X 5’’H
Musical Equipment Stands
PMKS8
U-Base Gooseneck Desktop Microphone Stand
• Die Casting Iron U Shape Stand
• Adjustable Positioning
• Mic Holder Included
PMKS9
Heavy Duty Compact Base Boom Microphone Stand
• Boom Microphone Stand Perfect
For The Studio And Concerts
• Height Adjustment From 37.5’’- 59.0’’
• Boom Length: 31.5’’
• Compact Weighted Base
• Clutch And T-Bar Adjustment Points
PMKSKT10
• Adjustable Height From 10.6’’ to 12.6’’
• Support Weight: 5 Lbs.
Adjustable Desk Microphone Stand (Black)
• Equipped With Adjustable-Height Shaft
• Ideal For recording Podcasts Or
Other Desktop Applications
• Die-Cast Iron Clutch
• Adjustable Height From 4.7’’ to 8.7’’
• Support Weight: 5 Lbs.
Adjustable Desktop Tripod Microphone Stand
• Convenient Desk Tripod Microphone Stand
• Ideal For Recording Podcasts Or Other Desktop
Applications
PMKSDT30
Seconds With The Twist Of A Knob
• All Controls, Buttons And Connectors Are Accessible When Your Ipad Is Clipped On
• Multi-Mount Design Provides Both Horizontal
And Vertical Orientation Of Your Ipad
• Can Be Mounted On The Vertical Part Of A Mic
Stand, Or On A Horizontal Boom For Limitless
• Also Compatible With The iPad 1 -- Requires Adjustment
Adjustable Desktop Tripod Microphone Stand
• Convenient Desk Tripod Microphone Stand
• Ideal For Recording Podcasts Or
Other Desktop Applications
PMKSDT26
• Fast & Smooth Boom & Height Adjustments
• Gloss Black Finish
• Constructed w/ Strong Lightweight Tubing
• Microphone Cable Lenght 20Ft
• 2 MIC Holders Included
• Dimensions: 40.15’’ L x 13’’ W x 9.29’’ H
Multimedia iPad and Microphone Stand - Adjustable to Fit All iPad
• Sturdy, Durable Construction With Sure-Grip
Touch Points — Securely Holds Your Ipad
Without Scratching Or Marring It
• Universal Stand Clip Securely Attaches
To Virtually Any Microphone Stand
• Multi-Angle Adjustment Allows Precise Positioning For Optimal Stage Or Studio Viewing
• Quick-Snap Clips Provide Fast, Secure Ipad Insertion
• Fast Installation — On Your Mic Stand In
PMKSDT25
• Silver And Black Finish
• Base Dimensions: 9.25’’
• Folded Height: 38.6’’
• Product Weight:11.0Lbs
Dual Tripod Microphone Stand Kit w/ Dual 1/4’’ to XLR Mic Cables & 1
• Kit Included 2 Mic Stands 2 Mic Cables and 1 Bag
• Bag Included for Easy Transport
• 12 Guage Microphone Cables
• Each Mic Stand Telescopes from 3Ft to 5.4 Ft
• Each Boom Extens to 2.6 Total Height & can be
extend up to 8FT
PMKSPAD1
• Base Spread: 5.6 in. x 6.75 in
• Weight: 2.6lbs
• Dimensions: L 5.5’’ X W 7’’ X H 11.8
• Height Adjustable From 8.7’’ To 10.7’’
• Base: 6’’ Diameter
• Support Weight: 5 Lbs.
• Weight: 1.5 Lbs.
Musical Equipment Stands
85
85
PMS1
Heavy Duty Tripod Music Note Stand
• Adjustable Height Leveling
• Long-Lasting Steel Construction
• Folds Compactly For Convenient Transport
PMSM9
Heavy Duty Tripod Microphone And Music Note Stand
• Adjustable Height Leveling
• Microphone Boom With Mic Holder
• Music Notes Holder
• Long-Lasting Steel Construction
PMS55
• 4 Hanging Point Bolts
• Ideal For Mobile DJ’s And Bands
• Collapses down for easy transport
• Load Capacity :80lbs.
• Unit Dimensions:59’’H x 7’’W x 6’’D
DJ Lighting Truss System with Integrated Crossbar Stand
• Dual Black Tri-pod Extends From 7.8FT To 13FT
• 1.5’’ Diameter Heavy Duty Steel Construction
• Two 5ft. Truss I-Beams That Fit Together
to Create a 10ft. Trussing Span
• Black High Gloss Finish
86
86
• Load Capacity :100lbs.
• Ideal for mobile DJs and bands
• Collapses down for easy transport
• Unit Dimensions: 59’’H x 7’’W x 6’’D
DJ Lighting Tripod Stand w/T-bar
• Heavy Duty Steel Construction
• Black High Gloss Finish
• Tripod with 1 T-bar
• Black High Gloss Finish
• Setup Height From 5 Feet To 15Feet
• Safety Pin Lockers
PPLS209
• Height Adjustable 20.4’’ to 51.5’’
• Folded height:23.2’’
• Weight: 2.5Lbs
DJ Lighting Tripod Stand w/T-bar/Dual Side Bar
• Heavy Duty Steel Construction
• Tripod with 1 T-bar & 2 side bars
• Black High Gloss Finish
• Setup Height From 7.5 Feet to 15 Feet
• Safety Pin Lockers
• 8 Hanging Point Bolts
PPLS206
• Folds Compactly For Convenient Transport
• Desk Size: 19’’L X 14 ‘’W
• Height Adjustable: From 39’’To 65’’
• Weight: 9 lbs.
Lightweight Sheet Music Stand
• Adjustable Height Leveling
• Long-Lasting Steel Construction
• Folds Compactly For Convenient Transport
PPLS203
• Desk Size: 19’’L X 14 ‘’W
• Height Adjustable From 26’’ To 55’’
• Weight: 8 lbs.
• Safety Pin Lockers
• Suitable for Lighting, Fog & Bubble Machines
• Load Capacity: 264 lbs.
• Unit Dimensions: 60’’H x 11’’W x 9’’D
Musical Equipment Stands
PMDK101
Heavy-Duty Aluminum Anodizing Dual Speaker Stand & 21FT Speakon
• Two Speaker Stands
• Set Up Height From 3.6 to 6.8 Feet
• Black Aluminum Anodized Stand w/Metal Lock
• Tube Diameter: 35mm (1.375’’)
• Loading Capacity: 100 lbs.
PMDK102
Heavy-Duty Aluminum Anodizing Dual Speaker Stand & 1/4’’ Phono
• Two Speaker Stands
• Set Up Height from 3.6 To 6.8 FT
• Black Aluminum Anodized Stand w/Metal Lock
• Tube Diameter: 35mm (1.375’’)
• Loading Capacity: 100 lbs.
PSTK103
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
• Pyle Pro Speaker Stand Gig Bag
• Dimensions: 40.35’’ L X 12.2’’ W X 11.2’’ H
• Weight: 40 lbs
6.6 ft Heavy-Duty Dual Speaker Stand with Traveling Bag Kit
• Two Speaker Stands
• Set Up Height From 3.94 Feet To 6.6 Feet
• Black SteelAnodized Stand
• Tube Diameter: 35mm/ 40mm (1.375’’/1.575’’)
• Loading Capacity: 132 Lbs.
PSTND2
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
• Pyle Pro Speaker Stand Gig Bag
• Dimensions:44’’L X 11’’W X 11’’H
• Weight: 50 lbs.
Heavy-Duty Dual Speaker Stand with Traveling Bag Kit
• Two Speaker Stands
• Set Up Height From 3.3 Feet To 6 Feet
• Black SteelAnodized Stand
• Tube Diameter: 35mm / 40mm (1.375’’/1.575’’)
• Loading Capacity: 110 Lbs.
PSTK106
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
• Individual Drawstring Speaker Stand Gig Bag
• Two 21 ft. 12 Gauge 1/4” to 1/4’’ Speaker Cables
Heavy-Duty Aluminum Anodizing Dual Speaker Stand with Traveling Bag
• Two Speaker Stands
• Set Up Height From 5 Feet To 8 Feet
• Black Aluminum Anodized Stand w/Metal Lock
• Tube Diameter: Ø35mm/ Ø40mm(1.375’’/1.575’’)
• Loading Capacity: 100 bs.
PSTK105
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
• Individual Drawstring Stand Gig Bag
• Two 21 ft. 12 Gauge Speakon Cables
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
• Pyle Pro Speaker Stand Gig Bag
• Dimensions: 44.1’’ L X 11.4’’ W X 17.32’’ H
• Weight: 43 lbs.
6 FT. Tripod Speaker Stand
• Telescopes to 6 Feet
• Tube Diameter: 35mm (1.375’’)
• Loading Capacity: 132 lbs.
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
PSTND25
•
•
•
6 FT. Tripod Speaker Stand
Set Up Height From 3.28 To 6 Feet
Black Anodized Aluminum Stand w/Metal Loc
Reversible Tube Provides
Industry Standard Diameters
•
•
•
•
Tube Diameter: 35mm/38mm (1.375’’/1.5’’)
Loading Capacity: 110 lbs.
Constructed with Strong, Lightweight Tubin
Safety Pin for Maximum Strength and Securit
Musical Equipment Stands
87
87
PSTND3
Height Adjustable Anodized Aluminum Sub-Woofer Mounted Speaker
• Telescopes to 58’’
• For use with a Subwoofer Cabinet
w/Top Mounting Hole
• Black Anodized Aluminum Stand
PSTND4
6.5 Feet 2-Way Anodized Aluminum Tripod Speaker Stand
• Set Up Height From 3.6 To 6.6 Feet
• Black Anodized Aluminum Stand w/Metal Lock
• Reversible Tube Provides Industry Standard Diameters
PSTND5
• Maximum Load Capacity : 77 lbs.
• Measures 13.80’’ From Center Of
Pole Mount To Mounting Plate
• 16.45’’L X 4.53’’W X 9.06’’H
• Color : Black
Foot Pedal WIND UP Heavy Duty Tripod Speaker Stand
• Set Up Height From 3.6 To 6.6 Feet
• Larger Diameter, Anodized Tubing and
Metal Reinforced Clamps Securely Support More Weight Than Other Stands
• Easy wind up and down With A foot Pedal
88
88
• Measures 13.80’’ From Center Of
Pole Mount To Mounting Plate
• L 16.54’’ X W 4.53 ‘’ X H 9.06 ‘’
• Color: Black
Pair Of Wall Mount Speaker Bracket With Adjustable Lock
• Adjustable Plate To Secure All Size Speakers
• Holds Speakers That Are Equipped with
Standard 35mm (1.375’’) Ploe Mounts
• Made of Heavy Duty Welded Steel
• Mount To Wall With Screws And Toggle Bolts
PSTND90
try Standard Diameters
• Tube Diameter: 35mm/38mm (1.375’’/1.5’’)
• Loading Capacity: 150 lbs.
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength And Security
Wall Mount Speaker Bracket (Pair)
• Holds Speakers That Are Equipped With
Standard 35mm (1.375’’) Pole Mounts
• Made Of Heavy Duty Welded Steel
• Mount to wall with screws and toggle bolts
• Maximum Load Capacity: 77lbs
PSTND7
• Tube Diameter: 35mm/38mm (1.375’’/1.5’’)
• Loading Capacity: 100 lbs.
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
6.0 Feet 2-Way Anodized Aluminum Tripod Speaker Stand
• Set Up Height From 3.9 To 6.0 Feet
• Black Anodized Aluminum Stand w/Metal Lock
• Larger Diameter Tubing And Metal Reinforced Clamps Securely Support More
Weight Than Other Stands
• Reversible Tube Provides Indus-
PSTND6
• Tube Diameter: 35mm (1.375’’)
• Loading Capacity: 100 lbs.
• Constructed with Strong, Lightweight Tubing
• Safety Pin for Maximum Strength and Security
• Reversible Tube Provides Industry Standard Diameters
• Tube Diameter: 35mm/55mm(1.375’’/2.16”)
• Loading Capacity:350 Lbs.
• Constructed with Strong, Lightweight Tubing
Musical Equipment Stands
PSTND13
One Pair of Heavy Duty Steel Double Support Bookshelf Speaker Stand
• One Pair of Speaker Stand For A
Bookshelf / Monitor / Speaker Stand
• Perfect For Home, Project Or Professional Recording Studios
• All-Steel, Attractive Design Incorporating Cable Management
• Vertical Columns May Be Sand Loaded To
Deaden Sound And Increase Stability
• Heavy-Duty Steel Construction With Black Finish
PSTND14
• Conceals Cables For A Great Looking Setup
• Double-Support Provides Security
And Strength With Style
• Adjustable Spikes On Bottom
For Additional Stability
• Maximum Weight Capacity: 35.0Lbs.
• Setup Height: 13’’
• Product Weight:5.6Lbs
• Tube Diameter:2 Pcs X 1.2’’ × 12.0’’
One Pair of Heavy-Duty Steel Triple Support Bookshelf / Monitor Speaker
• Pair of Speaker Stand For A Large Bookshelf Speaker
• Perfect For Home, Project Or Professional Recording Studios
• Steel, Attractive Design Incorporating Cable Management
• Vertical Columns May Be Sand Loaded To
Deaden Sound And Increase Stability
• Heavy-Duty Steel Construction With Black Finish
• Conceals Cables For A Great Looking Setup
• Triple-Support Provides Security And Strength With Style
PSTND16
Heavy Duty Steel Triangle Base Height Adjustable Bookshelf Speaker
• Speaker Stand For A Bookshelf Speaker
• Designed For Home, Project And
Professional Recording Studios
• Stable, Three-Point Triangle Base With
Adjustable Leveling Floor Spikes
• Heavy-Duty Steel Construction With Black Finish
• Conceals Cables For A Great Looking Setup
• Double-Support Provides Security
PSBGSS
PSBGMSC
• Durable Vinyl Construction
• Dimensions: L10’’ x W6’’ x H2’’
Heavy Duty Vinyl Microphone Stand Bag
• Professional Microphone Stand Bag
• Durable Vinyl Construction
• Dimensions: 7’’L x 5’’W x 2’’
Heavy Duty Lighting Stand Bag
• Professional DJ Tripod Lighting Stand Bag
• Durable Vinyl Construction
And Strength With Style
• Adjustable Spikes On Bottom
For Additional Stability
• Maximum Weight Capacity: 100Lbs
• Setup Height from 24.’’ - 47.5’’
• Product Weight: 10.6 Lbs.
• Top Plate Dimensions:9’’ X 9’’
• Weight Capacity: 100lbs
Heavy Duty Vinyl Speaker Stand Bag
• Professional DJ Tripod Speaker Stand Bag
• Holds Most Speaker Stands
PSBGLS
• Adjustable Spikes On Bottom For Additional Stability
• Maximum Weight Capacity: 75lbs.
• Setup Height: 38’’
• Product Weight: 8.90 Lbs.
• Base Plate Size:8.3’’ × 11.3’’
• Top Plate Dimensions: 7’’ X 9.5’’
• Tube Diameter:4 Pcs X 1.2’’ × 36.0’’
• Dimensions: 3.1’’ X 9.8’’ X 36.2’’
• Dimensions: 60”L X 10”W X 12”H.
Musical Equipment Stands
89
89
Coming Soon From Pyle:
PDWM1800
Professional Wireless Handheld Microphone System
Receiver Specifications
• RF Frequency Range: 460-970 MHz
• Image & Spurious Rejection: >70 dB
• Receiving Sensitivity: -105 dB
• Border Upon Channel Rejection: > 70 dB
• T.H.D.: < 1%
• Audio Output Level: 0-300 mV
• Power Requirements: 13-15V
DC nominal 200 mA
• Dimensions 17.5 x 13.5 x 4.3 cm
PDWM1902
Professional Wireless Handheld Microphone System
Receiver Specifications
• RF Frequency Range: 460-970 MHz
• Image & Spurious Rejection: >70 dB
• Receiving Sensitivity: -105 dB
• Signal / Noise Ratio: -105dB
• Border Upon Channel Rejection: > 70 dB
• T.H.D.: < 1%
• Audio Output Level: 0-300 mV
• Power Requirements: 13-15V
DC nominal 200 mA
• Dimensions 17.5 x 13.5 x 4.3 cm
PDWM3450
Handheld Transmitter Specifications
• RF Frequency Range: 460-970 MHz
• RF Output: >10 dBm
• Modulation Type: FM
• Max Deviation: ± 40 KHz
• Spurious Emission: > 55 dBc
• Nominal Current Drain: < 40mA
• Power Requirements: 2 x 1.5 V AA
• Dimensions: 23.5 x 5 x 5 cm
Professional Microphone System with (2) Bodypack Transmitters, (1) Headset & (1) Lavalier Microphone
Receiver Specifications
• T.H. D.: <1%
• Frequency Range: 460-970 MHz
• Image Spurious Rejection: >70 dB
• Receiving Sensitivity: -105 dB
• Signal / Noise Ratio: -105 dB
• Audio Output Level: 0-300 mV
• Border Upon Channel Rejection: > 70 dB
• Power Requirements: 13-15V
DC nominal 500 mA
• Dimensions 17.5 x 13.5 x 4.3 cm
90
90
Plug-In Transmitter Specifications
• RF Frequency Range: 460-970 MHz
• RF Output: >10 dBm
• Modulation Type: FM
• Max Deviation: ± 68 KHz
• Spurious Emission: > 55 dBc
• Nominal Current Drain: < 100mA
• Power Requirements: 1 x 1.5 V AA
• Dimensions: 11.2 x 2.9 x 2.8 cm
Professional 2-Channel Wireless Handheld Transmitter Microphone System
Receiver Specifications
• T.H. D.: <1%
• Frequency Range: 460-970 MHz
• Image Spurious Rejection: >70 dB
• Receiving Sensitivity: -105 dB
• Signal / Noise Ratio: -105 dB
• Audio Output Level: 0-300 mV
• Border Upon Channel Rejection: > 70 dB
• Power Requirements: 13-15V
DC nominal 500 mA
• Dimensions 17.5 x 13.5 x 4.3 cm
PDWM3400
Handheld Transmitter Specifications
• RF Frequency Range: 460-970 MHz
• RF Output: >10 dBm
• Modulation Type: FM
• Max Deviation: ± 40 KHz
• Spurious Emission: > 55 dBc
• Nominal Current Drain: < 40mA
• Power Requirements: 2 x 1.5 V AA
• Dimensions: 23.5 x 5 x 5 cm
Professional Wireless Handheld Microphone System w/ (2) Plug-In Transmitters
Receiver Specifications
• Frequency Range: 460-970 MHz
• RF Image Spurious Rejection: >80 dB
• Receiving Sensitivity: -105 dB
• Signal / Noise Ratio: -90dB
• Border Upon Channel Rejection: > 80 dB
• Power Requirements: 13-15V
DC nominal 200 mA
• Dimensions 48.31 x 21.3 x 4.3 cm
PDWM3375
Handheld Transmitter Specifications
• RF Frequency Range: 460-970 MHz
• RF Output: >10 dBm
• Modulation Type: FM
• Max Deviation: ± 40 KHz
• Spurious Emission: > 55 dBc
• Nominal Current Drain: < 40mA
• Power Requirements: 2 x 1.5 V AA
• Dimensions: 23.5 x 5 x 5 cm
Bodypack Transmitter Specifications
• RF Frequency Range: 460-970 MHz
• RF Output: >10 dBm
• Modulation Type: FM
• Max Deviation: ± 40 KHz
• Spurious Emission: > 53 dBc
• Nominal Current Drain: < 40mA
• Power Requirements: 2 x 1.5 V AA
• Dimensions: 10.5 x 6 x 3 cm
Notes:
91
91
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
