2007 SAMSUNG VSS GENERAL CATALOGUE
Digital Security
Solutions
www.securitysamsung.com
Vol. 4
Vol. 4
SAMSUNG Video Security Systems
2007 GENERAL CATALOGUE
* Design and specifications are subject to change without notice.
SAMSUNG ELECTRONICS CO.,LTD.
Digital AV Division
VSS marketing, 416, Maetan 3 Dong, YeongTong-Gu, Suwon City, Kyeonggi-Do, Korea, 443-742
Tel: +82-31-277-3341~3347 Fax: +82-31-277-3489 http://www.securitysamsung.com
Distributed by
Digital Video Security System Technology
CAMERA
Natural image, clear definition
Everything made by Samsung is distinct and superior.
-Samsung Offers the Best Selection in High Security SystemsSamsung provides not only tremendous variety in product selection,
but also products that are both cost competitive and of the finest quality.
• Utilization of Samsung’s state-of-the-art semiconductor technologies and its accumulated network and vision (video) technology.
• Various assortment of DVRs, Cameras, Monitors, System Controllers, Network Security Systems, Time Lapse VCRs, etc.
• Samsung will contribute to the expansion of the security business by developing new products for a safety system aimed at the future digital era.
Samsung will continue to maintain its firm position as a world top manufacturer.
CAMERA 3p
Comparison Chart by model
Box Type & Zoom Lens Camera
Dome Camera
SmartDome Camera &
Accessory & Installation
MONITOR 53p
Comparison Chart by model
LCD Monitor
Other Monitor
DVR 61p
Comparison Chart by model
New Standalone DVR
PC based DVR
TIMELAPSE VCR 81p
Real Time Recoder
NETWORK SECURITY 83p
Comparison Chart by model
VIDEO SERVER
WEB Transmitter
CONTROLLER 89p
Quad Switchers
Comparison
Chart by Model
Box Type &
Zoom Lens Camera
SBC-330A(P) / 300AP
SBC-331A(P) / 301AP
SCC-100BP / SCC-130B(P)
SCC-101BP / SCC-131B(P)
SCC-B1391(P) / B1091P
SCC-B2303(P) / SCC-B2003P
SCC-B2305(P) / SCC-B2005P
SCC-B2307P / SCC-B2007P
SCC-B2300 / SCC-B2391(P)
SCC-C4201(P) / C4203(P)
SCC-C4301(P) / SCC-C4303A(P)
SCC-C4205(P) / C4305(P)C
SCC-C4207(P) / SCC-C4307(P)
Dome Camera
SCC-B5203(P)
SCC-B5300(G)(P)/B5301(G)(P)
B5303(G)(P)/B5305(G)(P)
SCC-B5351(G)(P)
SCC-931T(P)
SCC-C9302(P)
SmartDome
Camera &
Accessory
SCC-641(P)/SCC-643A(P)
SCC-C6403(P)
SCC-C6407(P)
SSC-1000(P)
SSC-2000(P)
SHG-120
SHG-220
SADT-101WM
SADT-100CM
SBR-100DCM
SADT-110CM
SADT-100WM
SADT-100PM
Installation
Samsung Security System l 03
Digital Video Security System Technology
MONITOR
SMT-171(P) / SMT-190(P)
MONITOR
Comparison Chart by Model
Models
Professional 17"/19" Tempered Glass TFT-LCD Monitor
SMT-171P/190P
SMC-150FP
SMC-152FP
SMC-210FP
SMC-212FP/
SMC-211FP
PAL
PAL
PAL
PAL
PAL
17”/19” TFT LCD
15”CRT
15”CRT
21”CRT
21”CRT
0.66mm
0.66mm
0.74mm
0.74mm
Spec
System
Picture tube
Stripe Pitch
Stripe Pitch
Stripe Pitch
Stripe Pitch
Resolution
Horizontal
Frequency Stability
Vertical
Frequency Stability
Audio Output
S-VHS Input
1280 x 1024 @ 60Hz
400lines
400lines
500lines
500lines
31KHz ~ 82KHz (SMT-171(P))
16.25KHz ± 500Hz
16.25KHz ± 500Hz
16.25KHz ± 500Hz
16.25KHz ± 500Hz
50Hz ± 4Hz
50Hz ± 4Hz
50Hz ± 4Hz
50Hz ± 4Hz
1.5W
1.5W
1.5W
1.5W
o
x
x
x
212FP: x
Voltage
DC 12V
AC90~260V
AC90~260V
AC90~260V
AC90~260V
50/60Hz
50/60Hz
50/60Hz
50/60Hz
Max. 36W (SMT-171(P)), Max. 42W (SMT-190(P))
63W
63W
70W
70W
5.96kg (SMT-171(P)), 6.61kg (SMT-190(P))
13.0kg
13.0kg
25.0kg
25.0kg
ABS
Metal
Metal
Metal
Metal
382.4 x 200 x 390.5 mm (SMT-171(P))
365 x 341 x 391 mm
365 x 341 x 391 mm
490 x 444 x 482 mm
490 x 444 x 482 mm
SMT-171/190
SMC-150F
SMC-152F
SMC-211F
NTSC
NTSC
NTSC
NTSC
17”/19” TFT LCD
15”CRT
15”CRT
21”CRT
0.66mm
0.66mm
0.74mm
Stripe Pitch
Stripe Pitch
Stripe Pitch
1280 x 1024 @ 60Hz
400lines
400lines
500lines
31KHz ~ 82KHz (SMT-171(P))
15.75KHz ± 500Hz
15.75KHz ± 500Hz
15.75KHz ± 500Hz
60Hz ± 4Hz
60Hz ± 4Hz
60Hz ± 4Hz
Summary
SMT-171(P)/190(P) are 17"/19" TFT LCD monitors for surveillance use with two BNC inputs/outputs, one
S-Video input/output and one VGA input. Their superior 3D Comb Filter, CTI and De-Interlace functions
help producing sharper images and a tempered glass attached to the front panel secures better
strength. System ID function enables users to control several monitors with one remote controller.
31KHz ~ 80KHz (SMT-190(P))
50Hz ~ 77Hz (SMT-171(P))
50Hz ~ 75Hz (SMT-190(P))
211FP: o
Power Consumption
Weight
Case
Dimensions(WxHxD)
430 x 200 x 428 mm (SMT-190(P))
Models
Spec
System
Picture tube
Resolution
Horizontal
Frequency Stability
Vertical
Frequency Stability
Audio Output
S-VHS Input
Voltage
Power Consumption
Weight
Case
Dimensions(WxHxD)
31KHz ~ 80KHz (SMT-190(P))
50Hz ~ 77Hz (SMT-171(P))
50Hz ~ 75Hz (SMT-190(P))
1.5W
1.5W
1.5W
o
x
x
o
DC 12V
AC90~260V
AC90~260V
AC90~260V
50/60Hz
50/60Hz
50/60Hz
Max. 36W (SMT-171(P)), Max. 42W (SMT-190(P))
63W
63W
70W
5.96kg (SMT-171(P)), 6.61kg (SMT-190(P))
13.0kg
13.0kg
25.0kg
ABS
Metal
Metal
Metal
382.4 x 200 x 390.5 mm (SMT-171(P))
365 x 341 x 391 mm
365 x 341 x 391 mm
490 x 444 x 482 mm
430 x 200 x 428 mm (SMT-190(P))
54
SMT-171(P)/190(P) use Wise-View TFT-LCDTM‚ panel manufactured by SAMSUNG and support VESA
Standard wall mount system. These products are compatible with various types of power sources and
can be used in both NTSC and PAL environments.
Samsung Security System l 55
Digital Video Security System Technology
MONITOR
SMT-150F(P) / SMT-152F(P)
SMT-171(P) / SMT-190(P)
15” Flat Color Monitor
Professional 17"/19" Tempered Glass TFT-LCD Monitor
Features
• Displays a full, flat 17", 19" diagonal image
• High resolution (actice native:1280 x 1024 @ 60Hz)
• High Contrast Ratio (700:1)
• High Brightness (300cd/m2)
• Wide Viewing Angle (H:150°/V:135°)
• Screen aspect ratio : 5:4
• Pixel Pitch : 17” : 0.264 x 0.264(mm), 19” : 0.294 x 0.294(mm)
• Output Color : 17” : 16.2 million, 19” : 16.7 million (256 RGB Level)
• Power Consumption : 17” : 36W, 19” : 42W
• Advanced Interface: 2 CVBS (2 LOOP OUT),
SVHS (1 LOOP OUT), analog VGA input
• VESA wall mount
• Tempered glass
SMT-171(P) : 390.5
SMT-190(P) : 428
Dimensions (unit : mm)
SMT-171(P) : 382.4
SMT-190(P) : 430
200
Specifications
SMT-171(P)
Video
2Ch input 1.0Vp-p, 75Ω terminated, loop-through out
S-Video
1Ch input(Y/C), loop-through out
VGA
1Ch input
Resolution
Frequency
SMT-190(P)
Composite
1280 x 1024 @ 60Hz
Horizontal(KHz)
31KHz ~ 82KHz
31KHz ~ 80KHz
Vertical(Hz)
50Hz ~ 77Hz
50Hz ~ 75Hz
VGA Mode
[email protected],[email protected],[email protected]/75Hz
[email protected]/75Hz,[email protected]/75Hz
Power Consumption
Max. 36W
Power Supply
DC12V/4A
Environmental Considerations
LCD Panel Spec
Dimensions(WxDxH)
56
Max. 42W
Operation Temperature
50°F~104°F(10°C~40°C)
Operation Humidity
10%~80%,Non-condensing
Storage Temperature
-4°F~113°F(-20°C~45°C)
Storage Humidity
5%~95%,Non-condensing
Size
17" Diagonal AM-TFT
19” Diagonal AM-TFT
Active Display Area
337.92 x 270.336 mm
376.32 x 301.056 mm
Pixel Pitch
0.264 mm(H) x 0.264 mm(V)
0.294 mm(H) x 0.294 mm(V)
Brightness
300cd/m2
Contrast Ratio
700:1
Response Time
8ms
Viewing Angle(L/R/T/B)
75/75/75/60
Net
382.4 x 200 x 390.5 mm
430 x 200 x 428 mm
Net Weight
5.96Kg
6.61Kg
Packing
436 x 225 x 476 mm
490 x 225 x 506 mm
Summary
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
SMC-150F(P)/152F(P) is a 15" color monitor housed in a metal case featuring looping video and audio
circuits. This color monitor features a metal case, sturdy construction and is designed and built as a
security monitor. With 400 lines of resolution, this monitor delivers high quality video images in a compact 15"Flat format. SMC-150F(P)/152F(P) is equipped with a worldwide compatible power supply (both
NTSC and PAL). Automatic 75 Ohms terminations and on screen display-programming make this monitor an ideal choice for system integration and other viewing environments. SMC monitor series are
world renowned for the high quality video image.
Samsung Security System l 57
Digital Video Security System Technology
MONITOR
SMC-210FP / SMC-211F(P) / SMC-212FP
SMT-150F(P) / SMT-152F(P)
21” Flat Screen Color Monitor
15” Flat Color Monitor
Features
• 15" Flat CRT
• 400 TV lines of horizontal resolution
• NTSC/PAL Multiple system
• Selectable looping video inputs(SMC-150F)
• Automatic 75 ohm termination
• Worldwide multiple system (NTSC/PAL)
• Auto sequential switching function (SMC-152F)
• Auto skip and time adjustment (SMC-152F)
• Maximum 1.5W speaker output
• Metal cabinet
Rear Panel
341
Dimensions (unit : mm)
AUDIO IN
CAMERA IN
MONITOR
OUT
VCR
IN
AUDIO
OUT
AUDIO IN
(VCR)
R : AUTO
G : MANUAL
R : VCR
AUTO
CH1
CH2
CH3
CH4
CAMERA
MENU
▼ VOLUME ▲
POWER
DATA
7
VCR
365
SMC-150F(P)
391
SMC-152F(P)
Specifications
Picture Tube
SMC-152F(P)
38cm(15”), 0.66mm Stripe type, In line gun, 90°Deflection
38cm(15”), 0.60mm Stripe type, In line gun, 90°Deflection
Input
2 BNC, 1 Vp-p
4 BNC, 1 Vp-p
Output
2 BNC, 75 ohm
1 BNC, 75 ohm
Input
2 RCA, Line level 500mV, 47Kohm(Hi-Impeadance)
4 RCA, Line level 500mV, 47Kohm(Hi-Impeadance)
Output
2 RCA
1 RCA
Control front
Volume Up/Down, Contrast, Bright, Color, Tint, Sharp, Input select
Volume Up/Down, Contrast, Bright, Color, Tint, Sharp, Input select
Connection rear
Video A, B(2CH Composite), VCR(1CH)
Camera 1,2,3,4 (4CH Composite), VCR(1CH)
Audio A, B(2CH), VCR(1CH)
Audio 1,2,3,4 (4CH), VCR(1CH)
Pull in range ±500Hz
Pull in range ±500Hz
Holding range ±600Hz
Holding range ±600Hz
Pull in range ±4Hz
Pull in range ±4Hz
Holding range ±4Hz
Holding range ±4Hz
Pull in range ±400Hz
Pull in range ±400Hz
Holding range ±500Hz
Holding range ±500Hz
Convergence
0.4mm Max (Center)
0.4mm Max (Center)
Operating Temperature
-10 ~ +50°C
-10 ~ +50°C
Operating Humidity
10% ~90%
10% ~90%
Power Source
120VAC, 60Hz 230VAC, 50Hz (Rating voltage)
120VAC, 60Hz 230VAC, 50Hz (Rating voltage)
Video
Audio
Stabilization
Horizontal
Vertical
Sub carrier
58
SMC-150F(P)
90 TO 260VAC(Voltage range)
90 TO 260VAC(Voltage range)
Power Consumption
Approx. 63W
Approx. 63W
Dimension(W x H x D)
365 x 341 x 391(mm)
365 x 341 x 391(mm)
Weight
Approx. 13Kg(with packing)
Approx. 13Kg(with packing)
Packing
470 x 480 x 445
Summary
SMC-210FP/211F(P)/212FP is a 21” color monitor housed in a metal case featuring looping video and
audio circuits. This color monitor features a metal case, sturdy construction and was designed and built
as a security monitor. With 500 lines of resolution this monitor delivers high quality video images in a
compact 21”Flat format. SMC-210FP/211F(P)/212FP is equipped with a worldwide compatible power
supply allowing it to function in both NTSC and PAL environments. Automatic 75 Ohms terminations and
on screen display-programming make this monitor an ideal choice for system integration and other
viewing environments. SMC monitor series are world renowned for high quality video imaging.
470 x 480 x 445
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Samsung Security System l 59
Digital Video Security System Technology
DVR
SMC-210FP / SMC-211F(P) / SMC-212FP
21” Flat Screen Color Monitor
Natural image, clear definition
Features
• 21” Flat CRT
• 500 TV lines of horizontal resolution
• NTSC/PAL multiple system
• Selectable looping video inputs (2 BNC, 1 Y/C)
• Automatic 75 ohm termination
• Worldwide multiple system
• Auto sequential switching function (SMC-212F)
• Auto skip and time adjustment (SMC-212F)
• Built-in digital comb filter, LTI, CTI
• Maximum 1.5W speaker output
• Metal cabinet
Rear Panel
444
Dimensions (unit : mm)
AUDIO IN
CAMERA IN
AC IN
1
2
3
4
MONITOR
OUT
VCR
IN
AUDIO OUT AUDIO IN
R : AUTO
G : MANUAL
R : VCR
VCR
AUTO
CH1
CH2
CH3
CH4
MENU
▼ VOLUME ▲
POWER
DATA
7
CAMERA
490
SMC-210FP
482
SMC-212FP
SMC-211F(P)
Specifications
SMC-210F(P) / 211F(P)
SMC-212F(P)
53cm(21”), 0.74mm Stripe type, In line gun, 90°Deflection
53cm(21”), 0.74mm Stripe type, In line gun, 90°Deflection
Input
2 BNC, 1 Vp-p
4 BNC, 1 Vp-p
Output
2 BNC, 75 ohm
1 BNC, 75 ohm
S-VHS jack, 1Vp-p(Y), 0,286Vp-p(C), 1CH (SMC-211F)
S-VHS jack, 1Vp-p(Y), 0,286Vp-p(C), 1CH
Input
2 RCA, Line level 500mV, 47Kohm(Hi-Impeadance)
4 RCA, Line level 500mV, 47Kohm(Hi-Impeadance)
Output
2 RCA
1 RCA
Control front
Volume Up/Down, Contrast, Bright, Color, Tint, Sharp, Input select
Volume Up/Down, Auto, Contrast, Bright, Color, Tint, Sharp, Input select
Connection rear
Video A, B(2CH Composite), VCR(1CH)
Camera 1,2,3,4 (4CH Composite), VCR(1CH)
Audio A, B, C(3CH)
Audio A, B, C(3CH)
Pull in range ±500Hz
Pull in range ±500Hz
Holding range ±600Hz
Holding range ±600Hz
Pull in range ±4Hz
Pull in range ±4Hz
Holding range ±4Hz
Holding range ±4Hz
Pull in range ±400Hz
Pull in range ±400Hz
Holding range ±500Hz
Holding range ±500Hz
Convergence
0.5mm Max (Center)
0.5mm Max (Center)
Operating Temperature
-10 ~ +50°C
-10 ~ +50°C
Operating Humidity
10% ~90%
10% ~90%
Power Source
120VAC, 60Hz 230VAC, 50Hz (Rating voltage)
120VAC, 60Hz 230VAC, 50Hz (Rating voltage)
90 TO 260VAC(Voltage range)
90 TO 260VAC(Voltage range)
Power Consumption
Approx. 70W
Approx. 70W
Dimension(W x H x D)
490 x 444 x 482 (mm)
490 x 444 x 482 (mm)
Weight
Approx. 25Kg(with packing)
Approx. 25Kg(with packing)
Packing
620 x 585 x 570
620 x 585 x 570
Picture Tube
Video
Y/C in
Audio
Stabilization
Horizontal
Vertical
Sub carrier
60
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Comparison
Chart by Model
New
Standalone DVR
SHR-2040(P)
SHR-2042(P)
SHR-2080(P)
SHR-2082(P)
SHR-2160(P)
SHR-2162(P)
SHR-4081(P)
SHR-4160P
PC based DVR
SPR-7116(P)
SPR-7416(P)
Samsung Security System l 61
Digital Video Security System Technology
CAMERA
SCC-130B / SCC-130BP / SCC-100BP
CAMERA Natural image, clear definition
1/3” Standard, Color Digital Camera
Box Type Camera
SBC-330A(P) / 300AP
SBC-331A(P) / 301AP
SCC-130B(P) / 100BP
SCC-130B(P) / 100BP
SCC-B1391(P) / B1091P
SCC-B2300
CCD
Picture Elements
Resolution(H)
Min. Illumination
Lens
Sync.
1/3 inch B/W
EIA:270K Pixels / CCIR:320K Pixels
420 TV lines
0.05lux
1/3 inch B/W
EIA:410K Pixels / CCIR:470K Pixels
570 TV lines
0.05lux
1/3 inch Super-HAD
NTSC:270K Pixels / PAL:320K Pixels
330 TV lines
0.15lux
1/3 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
520 TV lines
0.3lux
1/3 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
540 TV lines
0.3lux
1/3 inch Super-HAD
NTSC:270K Pixels / PAL:320K Pixels
00(Color) / 420(B/W) TV lines
0.2(Color) / 0.03(B/W)lux
Internal/Line Lock
Internal/Line Lock
Internal/Line Lock
Internal/Line Lock
Internal/Line Lock
Internal/Line Lock
Models
SCC-B2391(P) / B2091P
SCC-B2303(P) / B2003P
SCC-B2307P / B2007P
SCC-B2305(P) / B2005P
1/3 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
40(Color) / 570(B/W) TV lines
0.3(Color) / 0.06(B/W)lux
1/3 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
00(Color) / 530(B/W) TV lines
0.002(Color) / 0.004(B/W)lux
1/3 inch EX-View
PAL : 470K Pixels
00(Color) / 530(B/W) TV lines
0.001(Color) / 0.002(B/W)lux
1/3 inch Super-HAD PS
NTSC:410K Pixels / PAL:470K Pixels
00(Color) / 530(B/W) TV lines
0.002(Color) / 0.004(B/W)lux
Internal/Line Lock
Internal/Line Lock
Internal/Line Lock
Internal/Line Lock
Models
Spec
Spec
CCD
Picture Elements
Resolution(H)
Min. Illumination
Lens
Sync.
Zoom Lens Camera
Models
SCC-C4201(P) / C4301P
SCC-C4203A(P) / C4303AP SCC-C4205(P)/C4305P
SCC-C4207(P)/C4307P
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.01lux
x22 Zoom
Internal/Line Lock(C4301P Only)
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.01(Color) / 0.003(B/W) Lux
x22 DayNight Zoom
Internal/Line Lock(C4303AP Only)
1/4 inch EX-View PS
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.002(Color) / 0.0002(B/W) Lux
x32 DayNight Zoom
Internal/Line Lock(C4307P Only)
Spec
CCD
Picture Elements
Resolution(H)
Min. Illumination
Lens
Sync.
1/4 inch EX-View PS
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.005(Color) / 0.0002(B/W) Lux
x22 DayNight Zoom
Internal/Line Lock(C4305P Only)
Fixed Dome Camera
Models
SCC-B5300(G)(P)
SCC-B5301(G)(P) 1 /
SCC-B5203(S)(P)
B5303(G)(P) 2 / B5305(G)(P) 3
SCC-B5351(G)(P)
1/3 inch Super-HAD
NTSC:270K Pixels / PAL:320K Pixels
330 TV lines
0.3lux
f=3.8mm
Internal/Line Lock
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.5lux
f=3.8mm 1 / f=2.9mm 2 / f=8.0mm 3
Internal/Line Lock
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.3lux
f=3.4~9mm Auto Iris
Internal/Line Lock
Spec
CCD
Picture Elements
Resolution(H)
Min. Illumination
Lens
Sync.
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.3lux
f=3.0mm
Internal
Summary
Anti-Vandal Camera
Models
SCC-931T(P)
This color camera is capable of superb observation, thanks to its state-of-the-art implementation of 1/3” CCD (270,000
pixels for NTSC, 320,000 pixels for PAL) with economical price.
SCC-C9302(F)(P)
Spec
CCD
Picture Elements
Resolution(H)
Min. Illumination
Lens
Sync.
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.01lux
x12 Zoom
Internal/Line Lock
Through the use of SONY CCD and the outstanding digital signal processor, this camera provides extremely sharp
image quality. By using backlight compensation function, it is able to give brighter and sharper images of an object
darkened by background lighting or sunlight. Particularly, it applies the highly sensitive Super-HAD CCD, which allows
optimum observation of parking lots or building interiors that are dimly lit at best.
1/4 inch Ex-View PS
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.002(Color) / 0.0002(B/W) Lux
x12 DayNight Zoom
Internal/Line Lock
SmartDome Camera
Models
SCC-641(P)
SCC-643A(P)
SCC-C6403(P)
SCC-6405(P)
SCC-C6407(P)
SCC-C6475(P)
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.01lux
x22 Zoom
Internal/Line Lock
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.01(Color) / 0.003(B/W) Lux
x22 DayNight Zoom
Internal/Line Lock
1/4 inch Super-HAD
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.005(Color) / 0.0005(B/W) Lux
x32 DayNight Zoom
Internal/Line Lock
1/4 inch Ex-View PS
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.005(Color) / 0.0002(B/W) Lux
x22 DayNight Zoom
Internal/Line Lock
1/4 inch Ex-View PS
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.002(Color) / 0.0002(B/W) Lux
x32 DayNight Zoom
Internal/Line Lock
1/4 inch Ex-View PS
NTSC:410K Pixels / PAL:470K Pixels
480 TV lines
0.005(Color) / 0.0002(B/W) Lux
x22 DayNight Zoom
Internal/Line Lock
Spec
CCD
Picture Elements
Resolution(H)
Min. Illumination
Lens
Sync.
04
Through the perfect Auto/Manual white balance function, the camera ensures accurate representation of colors under any
environment. It has switchs, with which it can selectively use the line-lock or flickerless function. By adopting the ELC function, it can use the manual Iris lens economically. Without ELC function, it can use the automatic lens of DC type or video
selectively.
Its mechanism is designed to accommodate with any C/CS lens mount adaptor. The camera supports easy installation since it can be mounted either on the top or the bottom of the camera adapter. In the case of SCC-100BP, since
it is designed to make use of the AC230V power source, it can be employed by being directly plugged into the receptacle. In case of SCC-130B(P), both AC24V and DC12V (nonpolar) are available with the use of power adapter.
Samsung Security System l 05
Digital Video Security System Technology
CAMERA
SCC-131B / SCC-131BP / SCC-101BP
SCC-130B / SCC-130BP / SCC-100BP
1/3” High Resolution, Color Digital Camera
1/3” Standard, Color Digital Camera
Features
• DSP (Digital Signal Processor)
• 1/3" 320,000 pixels, super HAD CCD (SCC-130B : 270,000 pixels)
• Horizontal resolution (330 TV lines)
• Back light compensation circuitry
• External synchronization with linelock
• Accepts 2 types of auto-Iris lenses (DC/Video)
• Accepts CS/C-mount without adaptor
• Power Input (100BP : AC230V / 130B(P) : AC24V/DC12V compatible)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
65
Rear Panel
52
7.5
133
SCC-100BP
SCC-130BP
SCC-130B
Specifications
SCC-130B
Camera Type
Scanning
Min. scene Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Environmental
Conditions
Power
Physical
Specification
06
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
BLC
AGC
ELC
Line Lock
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
OSD
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-130BP
SCC-100BP
Color
Super-HAD CCD
1/3 inch
537 x 597
500 x 582
537 x 597
500 x 582
Summary
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.15 Lux
On
On
Off/On(Max. 1/120Ksec)
Off/On
ATW / AWC
330 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
AI(Video/DC)
No
-10˚ C ~ +50˚ C
Less than 90%
AC24V(50Hz)±10%
AC24V(60Hz)±10%
3W
This color camera is capable of superb observation, thanks to its state-of-the-art implementation of 1/3" CCD (410,000 pixels for NTSC, 470,000 pixels for PAL) with economical price.
Through the use of SONY CCD and the outstanding digital signal processor, this camera provides extremely sharp image
quality. By using backlight compensation function it is able to give brighter and sharper images of an object darkened by
background lighting or sunlight. Particularly, it applies the highly sensitive Super-HAD CCD, which allows optimum observation of parking lots or building interiors that are dimly lit at best.
Through the perfect Auto/Manual white balance function, the camera ensures accurate representation of colors under any environment. It has switchs, with which it can selectively use the line-lock or flickerless function. By adopting the ELC function, it can
use the manual Iris lens economically. Without ELC function, it can use the automatic lens of DC type or video selectively.
AC220V~240V(50Hz)
4W
Yes
65 x 52 x 133 mm
450g
550g
10,560 / 21,870
530 x 241 x 182 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Its mechanism is designed to accommodate with any C/CS lens mount adaptor. The camera supports easy installation
since it can be mounted either on the top or the bottom of the camera adapter. SCC-101BP, since it is designed to make
the use of AC230V power source, can be employed by being directly plugged into the receptacle. In case of SCC-131B(P),
both AC24V and DC12V (nonpolar) are available with the use of power adapter.
Samsung Security System l 07
Digital Video Security System Technology
CAMERA
SCC-B1391 / SCC-B1391P / SCC-B1091P
SCC-131B / SCC-131BP / SCC-101BP
1/3" 540 TV Lines, Color Digital Camera
1/3” High Resolution, Color Digital Camera
Features
• DSP (Digital Signal Processor)
• 1/3" 470,000 pixels, super HAD CCD (SCC-131B : 410,000 pixels)
• Horizontal resolution (520 TV lines)
• Back light compensation circuitry
• External synchronization with linelock
• Accepts 2 types of auto-iris lenses (DC/Video)
• Accepts CS/C-mount without adaptor
• Power input(101BP : AC230V / 131B(P) : AC24V/DC12V compatible)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
133
52
7.5
65
Rear Panel
SCC-101BP
SCC-131BP
SCC-131B
Specifications
SCC-131B
Camera Type
Scanning
Min. scene Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Environmental
Conditions
Power
Physical
Specification
08
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
BLC
AGC
ELC
Line Lock
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
OSD
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-131BP
SCC-101BP
Color
Super-HAD CCD
1/3 inch
811 x 508
768 x 494
795 x 596
752 x 582
Summary
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.3 Lux
On
On
Off/On(Max. 1/120Ksec)
Off/On
ATW / AWC
520 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
AI(Video/DC)
No
-10˚ C ~ +50˚ C
Less than 90%
AC24V(50Hz)±10%
AC24V(60Hz)±10%
3W
As color cameras that adopt the 1/3" state-of-the-art CCD (410,000 pixels for NTSC, 470,000 pixels for PAL), this product realize
the high resolving power of horizontal resolution (540 TV lines) through the use of Hi-Tech Digital Signal Process. Through the use
of SONY Super-HAD CCD and the outstanding digital signal process, these cameras provide extremely sharp image quality. By
using BLC (Back Light Compensation) function, they are able to give brighter and sharper images of an object darkened by background lighting or sunlight.
Also, these products have excellent CCD sensitivity, which especially allows optimum observation of parking lots or building interiors even under the low light conditions. Through the perfect Auto/Manual white balance function, these cameras
ensure accurate representation of colors under any environment. These products have switches, with which users can
selectively use the line-lock or flickerless function.
AC220V~240V(50Hz)
4W
Yes
65 x 52 x 133 mm
450g
550g
10,560 / 21,870
530 x 241 x 182 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
By adopting the ELC function, these products can use the Manual Iris Lens economically. Without ELC function, these products can use the automatic lens of DC type or video selectively. Their mechanism is designed to accommodate with any
C/CS lens mount adapter. These cameras support easy installation since they can be mounted either on the top or the
bottom of the camera adapter. These products can operate on both AC24V and DC12V (SCC-B1091(P) : AC230V).
Samsung Security System l 09
Digital Video Security System Technology
CAMERA
SCC-B2303/SCC-B2303P/SCC-B2003P
SCC-B1391 / SCC-B1391P / SCC-B1091P
1/3” High Resolution, Day/Night Color Digital Camera
1/3" 540 TV Lines, Color Digital Camera
Features
• Hi-resolution DSP (Digital Signal Processing)
• 1/3" 470,000pixels super HAD CCD(SCC-B1391:410,000pixels)
• Horizontal resolution of 540 TV lines
• Back light compensation circuitry
• External synchronization with linelock
• Accepts 2 types of auto-iris lenses (DC/Video)
• Accept CS/C-mount lens (with C-mount adaptor)
• Power input (SCC-B1391(P) : AC24V/DC12V Compatible, SCC-B1091(P) : AC230V)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
128.5
118.5
10
55
65
Rear Panel
SCC-B1391P
SCC-B1391
1391
Summary
This color camera incorporates the 1/3" Super-HAD CCD (410,000 pixels for NTSC, 470,000 pixels for PAL) and as such can operate 24 hours a day by automatically switching to color mode during the day and black and white (B/W) mode at night.
Specifications
* SCC-B1091P model is same as SCC-B1391 except for power input (AC230V)
SCC-B1391
Camera Type
Scanning
Min. Scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
Environmental
Conditions
Power
Physical
Specification
10
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency - Internal Mode
Horizontal Frequency - Line-lock Mode
Vertical Frequency - Internal Mode
Vertical Frequency -Line-lock Mode
Color
BLC
AGC
ELC
Line Lock
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD) - Net
Weight - Net
Loading Quantity(20/40ft)
Packing
SCC-B1391P
SCC-B1091P
Color
Super-HAD CCD
1/3 inch
811 x 508
768 x 494
The camera utilizes the low light function that incorporates the AGC function and low-speed shutter, so that along with the
Day/Night function, it can represent clear images even under diffused conditions such as dimly lit parking lots or building
interiors. By way of its perfect white balance function, the camera ensures accurate representation of colors under any setting. Through the use of the MICOM, the camera can be controlled perfectly, and combined with the OSD, the MICOM
provides various additional functions. Its exceptional BLC (Back Light Compensation) function ensures perfect backlight
compensation effect every time by allowing the user to setup five preset zones, positions or sizes for the object darkened
by backlighting.
795 x 596
752 x 582
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.3 Lux
On
On
Off/On(Max.1/100Ksec)
Off/On
ATW/MANUAL
540 TV Lines
350 TV Lines
VBS 1.0Vp-p
50
AI (Video/DC)
-10˚ C ~ +50˚ C
Less than 90%
AC24V(50Hz)±10%
AC24V(60Hz)±10%
3W
In addition, it can be applied for various purposes since it has a Motion Detection function, a Camera ID indication function
that indicates the camera ID up to 20 digits, a Digital 10x zooming function, a PIP function, a Line-Lock function for vertical
adjustment, etc. It also has a built-in Samsung protocol, which enables remote control if the 232C Jig is installed externally.
AC220V~240V(50Hz)
4W
Yes
65 x 52 x 133mm
450 g
It employs the SONY CCD and utilizes a superior Digital Signal Processor to supply sharp images of high resolution. Under
illumination higher than a certain level, it provides outstanding color images in color mode and clear images in B/W mode
under low level illumination.
550g
10,560 / 21,870
540 x 241 x 251 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
By adopting the ELC function, it can use the manual Iris lens economically. Without ELC function, it can use the automatic lens of DC type or video selectively. Its mechanism is designed to accommodate with any C/CS lens mount adaptor.
The camera supports easy installation since it can be mounted either on the top or the bottom of the camera adapter.
Designed to make use of the AC230V power source, SCC-2003P can be employed by being directly plugged into the
receptacle. In cases of the SCC-B (P), both AC24V and DC12V (nonpolar) are available with the use of power adapter.
Samsung Security System l 11
Digital Video Security System Technology
CAMERA
SCC-B2305/SCC-B2305P/SCC-B2005P
SCC-B2303/SCC-B2303P/SCC-B2003P
1/3” High Resolution, WDR & Day/Night Color Digital Camera
1/3” High Resolution, Day/Night Color Digital Camera
Features
• Day/Night camera • DSP (Digital Signal Processor)
• 1/3" 470,000pixels, super HAD CCD (SCC-B2303 : 410,000pixels)
• Horizontal resolution (500(color)/530(B/W) TV lines)
• Back light compensation for the various light conditions
• External synchronization with linelock
• Motion detection • On-screen menus (Multi-language)
• Picture in picture on digital zoom
• Accepts 2 types of auto-iris lenses (DC/Video)
• Accepts CS/C-mount lens (with C-mount adaptor)
• Power input (AC24V/DC12V compatible)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
130.5
120.5
10
SCC-B2003P
55
65
Rear Panel
SCC-B2303P
SCC-B2303
Summary
Specifications
SCC-B2303
Camera Type
Scanning
Min. scene Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
Alarm
Environmental
Conditions
Power
Physical
Specification
12
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency--Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Day/Night
Motion Detection
D-Zoom
High Speed Shutter
Sense Up
PIP
BLC
AGC
ELC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
Mount Type
OSD
Output
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-B2303P
SCC-B2003P
Color
Super-HAD CCD
1/3 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
AC24V(60Hz)±10%
DC12V+10%/-5%
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.3 Lux (Sense Up x128 : 0.002)
0.06 Lux (Sense Up x128 : 0.0004)
Color / BW / AUTO / EXT
Off / On
Off ~ x10
Off ~ 1 / 10Ksec
Off ~ x128
Off/On
Off/On
Off/On
Off/On(Max. 1/100Ksec)
Off/On
Off/On
ATW / AWC / MANUAL
500/530(Color/BW) TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB
AI(Video/DC)
C / CS
Yes
1
-10˚ C ~ +50˚ C
Less than 90%
AC24V(50Hz)±10%
DC12V+10%/-5%
4.5W
Yes
65 x 55 x 130.5 mm
450g
10,560 / 21,870
530 x 241 x 182 mm
As a color camera that adopts the 1/3" progressive Super-HAD CCD (410,000 pixels for the NTSC, 470,000 pixels for the
PAL), this product employs a WDR (Wide Dynamic Range) function that can provide clear images even under backlight
circumstances where intensity of illumination varies excessively. It also contains a Day/Night function that automatically
switches to color mode during the day and B/W mode at night, enabling 24 hours a day observation. Different from the
existing BLC (Back Light Compensation) function used under backlighting environments, the WDR function allows user
to monitor 2 locations with different illumination simultaneously. If installed at an entrance or beside a window, both the
interior and exterior of a building can be monitored concurrently.
It employs the SONY CCD and utilizes a superior Digital Signal Processor to supply sharp images of high resolution. It
also utilizes the low light function that incorporates the AGC function and low-speed shutter, so that along with the
Day/Night function, it can represent clear images even under diffused conditions such as dimly lit parking lots or building interiors. By way of its perfect white balance function, the camera ensures accurate representation of colors under
any setting. Through the use of the MICOM, the camera can be controlled perfectly, and being combined with the OSD,
the MICOM provides various additional functions.
In addition, it can be applied for various purposesit since it has a Motion Detection function, a Camera ID indication function that indicates the camera ID up to 20 digits, privacy protect function, a Digital 10x zooming function, a PIP function,
a Line-Lock function for vertical adjustment, etc. It also has a built-in Samsung protocol, which enables remote control if
the 232C Jig is installed externally.
AC220V~240V(50Hz)
By adopting the ELC function, it can use the manual Iris lens economically. Without ELC function, it can use the automatic lens of DC type or video selectively. Its mechanism is designed to accommodate with C/CS lens mount adaptor. The
camera supports easy installation since it can be mounted either on the top or the bottom of the camera adapter.
5.0W
550g
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Designed to make use of the AC230V power source, SCC-B2005(P) can be employed by being directly plugged into the
receptacle. In cases of the SCC-B2305P, both AC24V and DC12V (nonpolar) are available with the use of power adapter.
Samsung Security System l 13
Digital Video Security System Technology
CAMERA
SCC-B2307P / SCC-B2007P
SCC-B2305/SCC-B2305P/SCC-B2005P
1/3” Ex-view High Resolution, Day/Night Color Digital Camera
1/3” High Resolution, WDR & Day/Night Color Digital Camera
Features
• WDR function (Dynamic range NTSC : x64, PAL : x80) • Day/Night function
• DSP (Digital Signal Processor)
• 1/3" 470,000Pixels,progressive super HAD CCD (SCC-B2305 : 410,000Pixels)
• Horizontal resolution (500(color)/530(B/W) TV lines) a minimum scene illumination
• High sensitivity with a minimum scene illumination
• Back light compensation for the various light conditions
• External synchronization with linelock
• 8 privacy zones (privacy mask function)
• Motion detection
• On-screen menus (Multi-language)
• Accepts 2 types of auto-Iris lenses (DC/Video) • Accepts CS/C-mount lens (with C-mount adaptor)
• Power input (AC24V/DC12V compatible)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
130.5
120.5
10
SCC-B2005P
55
65
Rear Panel
SCC-B2305P
SCC-B2305
Summary
Specifications
SCC-B2305
Camera Type
Scanning
Min. scene Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Environmental
Conditions
Power
Physical
Specification
14
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency--Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Number of privacy Zone
Day/Night
Motion Detection
D-Zoom
High Speed Shutter
Sense Up
PIP
BLC
AGC
ELC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
Mount Type
OSD
Output
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-B2305P
SCC-B2005P
Color
Super-HAD PS CCD
1/3 inch
811 x 508
768 x 494
795 x 596
752 x 582
It employs the SONY CCD and utilizes a superior Digital Signal Processor to supply sharp images of high resolution.
Under illumination higher than a certain level, it provides outstanding color images in color mode and clear images in
B/W mode under low level illumination.
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
It also utilizes the low light function that incorporates the AGC function and low-speed shutter, so that along with the
Day/Night function, it can represent clear images even under diffused conditions such as dimly lit parking lots or building interiors. By way of its perfect white balance function, the camera ensures accurate representation of colors under
any setting. Through the use of the MICOM, the camera can be controlled perfectly, and being combined with the OSD,
the MICOM provides various additional functions. Its exceptional BLC (Back Light Compensation) function ensures perfect backlight compensation effect every time by allowing the user to setup five preset zones, positions or sizes for the
object darkened due to backlighting.
0.3 Lux (Sense Up x160 : 0.002)
0.06 Lux (Sense Up x160 : 0.0004)
8
Color / BW / AUTO / EXT
Off / On
Off ~ x10
Off ~ 1 / 10Ksec
Off ~ x128
Off/On
Off/On
Off/On
Off/On(Max. 1/100Ksec)
Off/On
Off/On
ATW / AWC / MANUAL
500/530(Color/BW) TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB
AI(Video/DC)
C / CS
Yes
1
-10˚ C ~ +50˚ C
Less than 90%
AC24V(60Hz)±10%
DC12V+10%/-5%
AC220V~240V(50Hz)
4.5W
In addition, it can be applied for various purposes since it has a Motion Detection function, a Camera ID indication function that indicates the camera ID up to 20 digits, a Digital 10x zooming function, a PIP function, a Line-Lock function for
vertical adjustment, etc. It also has a built-in Samsung protocol, which enables remote control if the 232C Jig is installed
externally.
AC24V(50Hz)±10%
DC12V+10%/-5%
5.0W
Yes
65 x 55 x 130.5 mm
450g
This color camera adopts the 470,000 pixel 1/3" Ex-view CCD, which enables observation of 24 hours a day by automatically switching to color mode during the day and to B/W mode at night. This camera has low smear, wide dynamic range and sensitivity two times higher than cameras employing general type CCDs. Above all, it has excellent sensitivity at the infrared band, making it highly suitable for the observation of roads at night.
550g
By adopting the ELC function, it can use the manual Iris lens economically. Without ELC function, it can use the automatic lens of DC type or video selectively. Its mechanism is designed to accommodate with any C/CS lens mount adaptor.
The camera supports easy installation since it can be mounted either on the top or the bottom of the camera adapter.
.
Designed to make use of the AC230V power source, SCC-B2007P can be employed by being directly plugged into the
receptacle. In case of the SCC-B2307P, both AC24V and DC12V (nonpolar) are available with the use of power adapter.
10,560 / 21,870
530 x 241 x 182 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Samsung Security System l 15
Digital Video Security System Technology
CAMERA
SCC-B2300 / SCC-B2391
SCC-B2391P / SCC-B2091P
SCC-B2307P / SCC-B2007P
1/3” Ex-view High Resolution, Day/Night Color Digital Camera
1/3" 400 TV Lines, Day/Night Color Digital Camera (SCC-B2300)
1/3" 540 TV Lines, Day/Night Color Digital Camera (SCC-B2391/SCC-B2391P/B2091P)
Features
• Day/Night camera • DSP (Digital Signal Processor)
• 1/3" 470,000 pixels, Ex-view super HAD CCD
• Horizontal resolution (500(color)/530(B/W) TV lines)
• Back light compensation for the various light conditions
• External synchronization with linelock
• Motion detection • On-screen menus (Multi-language)
• Picture in picture on digital zoom
• Accepts 2 types of auto-Iris lenses (DC/Video)
• Accepts CS/C-mount lens (with C-mount adaptor)
• Power input (SCC-B2307P : AC24V/DC12V compatible/SCC-B2007P : AC230V)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
130.5
120.5
55
65
Rear Panel
10
SCC-B2007P
SCC-B2307P
Specifications
SCC-B2307P
Camera Type
Scanning
Min. scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Environmental
Conditions
Power
Physical
Specification
16
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency--Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Day/Night
Motion Detection
Wide Dynamic Range
High Speed Shutter
Sense Up
PIP
BLC
AGC
ELC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
Mount Type
OSD
Output
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
Color
Ex-View CCD
1/3 inch
795 x 596
752 x 582
Interlace
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.2Lux (Sense Up x128 : 0.001)
0.03Lux (Sense Up x128 : 0.0002)
Color / BW / AUTO / EXT
Off/On
Off~x10
Off~1/10Ksec
Off ~ x128
Off/On
Off/On
Off/On
Off/On(Max. 1/100Ksec)
Off/On
Off/On
ATW / AWC / MANUAL
500/530(Color/BW) TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB
AI(Video/DC)
C/CS
Yes
1
-10˚ C ~ +50˚ C
Less than 90%
AC24V(50Hz)±10% / DC12V+10%/-5%
4.5W
Yes
65 x 55 x 130.5 mm
450g
10,560 / 21,870
530 x 241 x 182 mm
SCC-B2007P
Summary
As color cameras that adopt the 1/3" state-of-the-art CCD (SCC-B2391(P)/B2091(P)) : 410,000 pixels for NTSC, 470,000 pixels for PAL, SCC-B2300 : 270,000 pixels), these products realize the high resolving power of horizontal resolution (SCCB2391(P)/B2091(P) : 540 TV lines, SCC-B2300 : 400 TV lines) through the use of Hi-Tech Digital Signal Process. These products also contain a Day/Light function that automatically switches to color mode during the day and to B/W mode at night,
enabling 24 hours a day observation. Through the use of SONY Super-HAD CCD and the outstanding digital signal process,
these camera provide extremely sharp image quality. By using BLC (Back Light Compensation) function, they are able to give
brighter and sharper images of an object darkened by background lighting or sunlight.
Also, these products have excellent CCD sensitivity, which especially allows optimum observation of parking lots or
building interiors that are dimly lit at best. Through the perfect Auto/Manual white balance function, these cameras
ensure accurate representation of colors under any environment. These products have switches, with which users can
selectively use the line-lock or flickerless function.
AC220V~240V(50Hz)
5.0W
550g
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
By adopting the ELC function, these products can use the Manual Iris Lens economically. Without ELC function, these
products can use the automatic lens of DC type or video selectively. Their mechanism is designed to accommodate
with any C/CS lens mount adapter. These cameras support easy installation since they can be mounted either on the
top or the bottom of the camera adapter. These products can operate on both AC24V and DC12V (SCC-B2091(P) :
AC230V).
Samsung Security System l 17
Digital Video Security System Technology
CAMERA
SCC-B2300 / SCC-B2391
SCC-B2391P / SCC-B2091P
SCC-C4201 / SCC-C4203A
SCC-C4201P / SCC-C4203AP
1/3" 400 TV Lines, Day/Night Color Digital Camera (SCC-B2300)
1/3" 540 TV Lines, Day/Night Color Digital Camera (SCC-B2391/SCC-B2391P/B2091P)
1/4” Zoom Lens Camera
Features
• Day/Night camera • Hi-resolution DSP (Digital Signal Processing)
• 1/3" 470,000pixels super HAD CCD (SCC-B2391:410,000pixels)
1/3" 270,000 pixels super HAD CCD (SCC-B2300)
• Horizontal resolution of 540/570 TV lines for SCC-B2391(P)/B2091P
Horizontal resolution of 400/420 TV lines for SCC-B2300
• Back light compensation circuitry • External synchronization with linelock
• Accepts 2 types of auto-iris lenses (DC/Video)
• Accept CS/C-mount lens (with C-mount adaptor)
• Power input (SCC-B2300/B2391(P) : AC24V/DC12V Compatible, SCC-B2091P : AC230V)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
Rear Panel
128.5
118.5
10
B2300
SCC-B2300
128.5
118.5
10
55
65
SCC-B2300
SCC-B2391(P)
2391
SCC-B2391(P)
Specifications
* SCC-B2091P model is same as SCC-B2391 except for power input (AC230V)
SCC-B2300
Camera Type
Scanning
Min. Scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
Environmental
Conditions
Power
Physical
Specification
18
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency - Internal Mode
Horizontal Frequency - Line-lock Mode
Vertical Frequency - Internal Mode
Vertical Frequency -Line-lock Mode
Color
B/W
Day/Night
BLC
AGC
ELC
Line Lock
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Lens Drive Type
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD) - Net
Weight - Net
Loading Quantity(20/40ft)
Packing
SCC-B2391
SCC-B2391P
SCC-B2091P
Color
Super-HAD CCD
1/3 inch
537 x 505
505 x 492
811 x 508
768 x 494
795 x 596
752 x 582
Summary
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.2 Lux
0.03 Lux
This product is a high performance surveillance camera with 220x zooming power afforded by implementation of 22x
optical zoom and 10x digital zoom. It includes various significant functions that existing surveillance cameras have
such as: (1) low illumination surveillance function that makes it possible to take pictures under the worst lighting conditions, (2) white balance function that makes natural images according to the lighting, (3) backlight compensation
function that perfectly compensates the dark areas on objects created by the backlighting even under a spotlight, (4)
auto focus function that adjusts the focus according to the movement of an object, (5) and RS485/wired remote control function.
(The SCC-C4203A(P) is a day/night camera equipped with the Day/Night function for 24 hour-a-day surveillance by
switching modes between Color and B/W according to the surrounding illumination to secure the optimum image.)
0.3 Lux
0.06 Lux
AUTO / EXT
On
On
On(Max.1/100Ksec)
Off/On
ATW / MANUAL
540/570(Color/BW) TV Line
350 TV Lines
VBS 1.0Vp-p
50 dB
AI (Video/DC)
-10 ˚ C ~ +50 ˚ C
Less than 90%
AC24V(50Hz) ± 10%
DC12V+10%/-5%
400/420(Color/BW) TV Line
AC24V(60Hz) ± 10%
DC12V+10%/-5%
3W
Yes
68(W) x 55(H) x 128.5(D)mm
450 g
10,560 / 21,870
540 x 241 x 251 mm
As a zoom lens integrated camera designed to be used for various applications, this product can be simply installed
at lower configuration cost than the lens detachable camera. Since this product supports both the RS-485 communication interface and the wired remote control, user can use remote control conveniently.
AC220V ~ 240V(50Hz)
4W
550 g
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
If used with the RS-485 communication protocol, this camera can be remote controlled up to 128 units per system
with the DVR and various controllers including SSC-1000 and SSC-2000. If the wired remote control is utilized, it can
perform zooming, focusing and menu manipulating simply with the SCC-RC130.
Samsung Security System l 19
Digital Video Security System Technology
CAMERA
SCC-C4201 / SCC-C4203A
SCC-C4201P / SCC-C4203AP
SCC-C4205 / SCC-C4305
SCC-C4205P / SCC-C4305P
1/4” Zoom Lens Camera
220x Power Zoom, WDR, D/N Camera
Features
• Superior images through DSP (Digital Signal Processor)
• 1/4" 470,000 pixels, Super HAD CCD (SCC-C4201 / C4203A:410,000pixels)
• Horizontal resolution of more than 480 lines
• 10-bit A/D converter • Motion detection
• Optical 22x zoom (f=3.6~79.2mm), 10x digital zoom lens (Maximum 220x zoom)
• Outstanding signal-to-noise (S/N) ratio (52dB)
• Both RS-485 communication interface & wired remote control function
• Day&Night function (SCC-C4203A(P))
• Minimum illumination of 0.01Lux (C4203A(P) : 0.003Lux for the B/W)
Dimensions (unit : mm)
60.5
108.5
Rear Panel
11
59.5
8
Front Panel
DIGITAL COLOR CAMERA SCC-C4201
Specifications
SCC-C4201
Camera Type
Scanning
Min. scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
20
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Vertical Frequency--Internal Mode
Color
B/W
Day/Night
Motion Detection
D-Zoom
High Speed Shutter
Sense Up
PIP
BLC
AGC
Line Lock
Camera ID
White Balance
Number of Preset
Horizontal
Vertical
VBS 1.0Vp-p
52
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Output
RS485, Voltage control
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-C4203A
SCC-C4201P
SCC-C4203A
Color
Super-HAD CCD
1/4 inch
811 x 508
768 x 494
-
795 x 596
752 x 582
Interlace
15,734 Hz
15,625 Hz
59.94 Hz
50 Hz
0.3 Lux (Sense Up X4 30IRE), 0.01 Lux (Sense Up X128)
0.04 Lux (Sense Up X128 : 0.003 Lux):(SCC-C4203A Only)
Color / BW / Auto
Color / BW / Auto
Off/On
Off ~ X10
Off ~ 1/10Ksec
Off ~ X128
Off/On
Off/On
Off/On
No
Max 20 Character
ATW / AWC / MANUAL
128
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB
3.6 ~ 79.2 mm
22X
F1.6(Wide), F3.8(Tele)
2˚ 3’(H) x 1˚ 7’(V)
47˚ 9’(H) x 36˚ 9’(V)
Yes
1
RS485, Voltage control
-10˚ C ~ +50˚ C
Less than 90%
DC12V ±10%
5W
Yes
60.5 x 59.5 x 119.5 mm
375g
10,560 / 21,870
530 x 241 x 182 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-C4X05(P) is the best camera available from Samsung in terms of zoom. With 22x optical lens, a maximum of
220x zoom is available when combined with 10x digital zoom.
Employing the latest SONY 1/4 inch WDR Ex-view HAD CCD, a sharp and clear image can be produced even an illumination difference between the inside and outside exist. The SCC-C4X05(P) is equipped with the Day/Night function
for 24hours-a-day surveillance by switching modes between Color and B/W according to the surrounding illumination
to secure the optimum image.
Privacy-Zone option enables to hide a pre-specified area to protect privacy, and RS485 Cable Remote Control makes
it easier for users to operate the cameras.
It is the user-friendly surveillance camera that comes with various useful functions such as White Balance function
that ensures accurate representation of colors under any environment without producing a picture that is either more
red or blue, and Auto-Focus function that automatically adjusts focus in response to the movement of the object.
Samsung Security System l 21
Digital Video Security System Technology
CAMERA
SCC-C4205 / SCC-C4305
SCC-C4205P / SCC-C4305P
SCC-C4301 / SCC-C4303A
SCC-C4301P / SCC-C4303AP
220x Power Zoom, WDR, D/N Camera
1/4” Zoom Lens Camera
Features
• x22 motorized optical zoom with x10 digital zoom
• Horizontal resolution (480 TV Lines)
• WDR function, D/N function
• Motion detection function with alarming output
• Remote-Control (Zoom, focus, Iris open-close)
• 1 Alarm output (Motion Detection)
• 1/4 Inch WDR Ex-view PS CCD
• DSP (Digital Signal Processing)
• External synchronization with linelock (SCC-C4305(P)_only)
• On-screen menus (Multi-Language)
• Minimum scene Illumination (Color : 0.005Lux, sens up X160)
Dimensions (unit : mm)
60.5
108.5
11
8
142.5
Rear Panel
11
59.5
8
Front Panel
DIGITAL COLOR CAMERA SCC-C4201
Specifications
SCC-C4205
Camera Type
Scanning
Min. scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
22
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency--Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Day/Night
Motion Detection
Wide Dynamic Range
D-Zoom
High Speed Shutter
Sens Up
BLC
AGC
Line Lock
Camera ID
White Balance
Number of Privacy Zone
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity (20/40ft)
Packing
SCC-C4305
SCC-C4205P
SCC-C4305P
Color
Ex-View PS CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
-
15,625 Hz
15,750 Hz
-
59.94Hz
-
-
DC12V+10%/-5%
5.7W
59.5 x 60.5 x 115.7mm
390g
828 / 1692
112 x 95 x 170mm
60 Hz
0.2 Lux(Sense Up x 40, 0.005 Lux(Sense Up x 128)
0.07 Lux(Sense Up x 40, 0.0002 Lux(Sense Up x 128)
Color / BW / Auto / EXT
Off/On
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x160
Off/On
Off/LOW/HIGH
Off/On
Max 20 Character
ATW-1 / ATW-2 / AWC / MANUAL
8 ea
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3.6 ~ 79.2 mm
22X
F1.6(Wide), F3.8(Tele)
2˚ 3'(H) x 1˚ 7'(V)
47˚ 9'(H) x 36˚ 9'(V)
Yes
1
Yes
-10 ˚ C ~ +50 ˚ C
Less than 90%
AC24(60Hz)
DC12V+10%/-5%
DC12V+10%/-5%
6W
5.7W
Yes
59.5 x 60.5 x 149.9mm
59.5 x 60.5 x 115.7mm
515g
390g
928 / 1880
828 / 1692
114 x 97 x 205mm
112 x 95 x 170mm
15,625 Hz
50Hz
50 Hz
Off/On
AC24(50Hz)
DC12V+10%/-5%
6W
59.5 x 60.5 x 149.9mm
515g
928 / 1880
114 x 97 x 205mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
This product is a high performance surveillance camera with 220x zooming power afforded by implementation of 22x
optical zoom and 10x digital zoom. (The SCC-C4303A(P) is a day/night camera equipped with the Day/Night function
for 24 hours-a-day surveillance by switching modes between Color and B/W according to the surrounding illumination to secure the optimum image.)
The camera includes various significant functions that existing surveillance cameras have such as: (1) low illumination
surveillance function that makes it possible to take pictures under the worst lighting conditions, (2) white balance function that makes natural images according to the lighting, (3) backlight compensation function that perfectly compensates the dark areas on objects created by the backlighting even under a spotlight, (4) auto focus function that adjusts
the focus according to the movement of an object, (5) and RS485/wired remote control function.
As a zoom lens integrated camera designed to be used for various applications, this product can be simply installed
at lower configuration cost than the lens detachable camera. Since this product supports both the RS-485 communication interface and the wired remote control, user can perform remote control conveniently. If used with the RS-485
communication protocol, this camera can be remote controlled up to 128 units per system with the DVR and various
controllers including SSC-1000 and SSC-2000. If the wired remote control is utilized, it can perform zooming, focusing and menu manipulating simply with the SCC-RC130.
This product can operate on both DC12V and AC24V. When operated on AC24V, either internal or external power frequency synchronization method can be selected as a vertical synchronization method.
Samsung Security System l 23
Digital Video Security System Technology
CAMERA
SCC-C4301 / SCC-C4303A
SCC-C4301P / SCC-C4303AP
SCC-C4207 / SCC-C4307
SCC-C4207P / SCC-C4307P
1/4” Zoom Lens Camera
320x Power Zoom, WDR, D/N Camera
Features
• Superior images through DSP (Digital Signal Processor)
• 1/4" 470,000pixels, super HAD CCD (SCC-C4301 / C4303A : 410,000pixels)
• Horizontal resolution of more than 480 lines
• 10-bit A/D converter • Motion detection
• Optical 22x zoom (f=3.6~79.2mm), 10x digital zoom lens (Maximum 220x zoom)
• Outstanding signal-to-noise (S/N) ratio (52dB)
• Both RS-485 communication interface & wired remote control function
• Day&Night function (SCC-C4303A(P))
• Minimum illumination of 0.01Lux (C4303A(P) : 0.003Lux for the B/W)
Dimensions (unit : mm)
60.5
142.5
Rear Panel
11
59.5
8
Front Panel
Specifications
SCC-C4301
Camera Type
Scanning
Min. scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
24
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency--Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Day/Night
Motion Detection
D-Zoom
High Speed Shutter
Sense Up
PIP
BLC
AGC
Line Lock
Camera ID
White Balance
Number of Preset
Horizontal
Vertical
VBS 1.0Vp-p
52
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Output
RS485, Voltage control
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-C4303A
SCC-C4301P
SCC-C4303AP
Color
Super-HAD CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,625 Hz
15,750 Hz
15,625 Hz
59,94 Hz
50 Hz
60Hz
50 Hz
0.3 Lux (Sense Up X4 30IRE, 0.01 Lux (Sense Up X128)
0.04 Lux (Sense Up X128 : 0.003 Lux): (SCC-C4303A(P) Only)
Color/ BW / Auto
Color/ BW / Auto
Off/On
Off ~ X10
Off ~ 1/10Ksec
Off ~ X128)
Off/On
Off/On
Off/On
Off/On
Max 20 Character
ATW/AWC/MANUAL
128
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB
3.6 ~ 79.2 mm
22X
F1.6(Wide), F3.8(Tele)
2˚ 3’(H) x 1˚ 7’(V)
47˚ 9’(H) x 36˚ 9’(V)
Yes
1
RS485, Voltage control
-10˚ C ~ +50˚ C
Less than 90%
AC24V(60Hz) ±10% / DC12V+10%/-5%
AC24V(50Hz) ±10% / DC12V+10%/-5%
5W
Yes
60.5 x 59.5 x 153.5 mm
500g
8,280 / 8,800
530 x 241 x 217 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-C4X07(P) is the best camera available from Samsung in terms of zoom. With 32x optical lens, a maximum of
320x zoom is available when combined with 10x digital zoom.
Employing the latest SONY 1/4 inch WDR Ex-view HAD CCD, a sharp and clear image can be produced even an illumination difference between the inside and outside exist. The SCC-C4X07(P) is equipped with the Day/Night function
for 24hours-a-day surveillance by switching modes between Color and B/W according to the surrounding illumination
to secure the optimum image.
Privacy-Zone option enables to hide a pre-specified area to protect privacy, and RS485 Cable Remote Control makes
it easier for users to operate the cameras.
It is the user-friendly surveillance camera that comes with various useful functions such as White Balance function
that ensures accurate representation of colors under any environment without producing a picture that is either more
red or blue, and Auto-Focus function that automatically adjusts focus in response to the movement of the object.
Samsung Security System l 25
Digital Video Security System Technology
CAMERA
SCC-C4207 / SCC-C4307
SCC-C4207P / SCC-C4307P
SCC-B5203S / SCC-B5203SP
High-resolution, Fixed Mini-Dome Color Digital Camera
320x Power Zoom, WDR, D/N Camera
Features
• x32 motorized optical zoom with x10 digital zoom
• 1/4 Inch WDR Ex-view HAD CCD
• Horizontal resolution (480 TV Lines)
• DSP (Digital Signal Processing)
• WDR function, D/N function
• External synchronization with linelock (SCC-C4207(P)_only)
• On-screen menus (Multi-Language)
• Motion detection function with alarming output
• Remote-Control (Zoom, focus, Iris open-close) • Minimum scene Illumination (Color : 0.002Lux, sens up X160)
• 1 Alarm output (Motion Detection)
Dimensions (unit : mm)
11
11
115.7
60.5
59.5
149.9
SCC-C4207
SCC-C4307
Specifications
SCC-C4207
Camera Type
Scanning
Min. scene
Illumination
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
26
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency--Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Day/Night
Motion Detection
Wide Dynamic Range
D-Zoom
High Speed Shutter
Sens Up
BLC
AGC
Line Lock
Camera ID
White Balance
Number of Privacy Zone
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity (20/40ft)
Packing
SCC-C4307
SCC-C4207P
SCC-C4307P
Color
Ex-View PS CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
-
15,625 Hz
15,750 Hz
-
59.94Hz
-
-
DC12V+10%/-5%
15,625 Hz
50Hz
60 Hz
0.09 Lux(Sense Up x 4, 15 IRE, Sense Up x 128 : 0.002 Lux)
0.009 Lux(Sense Up x 4, 15 IRE, Sense Up x 128 : 0.0002 Lux)
Color / BW / Auto / EXT
Off/On
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x160
Off/On
Off / LOW / HIGH
Off/On
Max 20 Character
ATW-1 / ATW-2 / AWC / MANUAL
8 ea
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3.55 ~ 113 mm
32X
F1.69(Wide), F4.17(Tele)
1˚ 78'(H) x 1˚ 34'(V)
41˚ 5'(H) x 43˚ 01'(V)
Yes
1
Yes
-10 ˚ C ~ +50 ˚ C
Less than 90%
AC24(60Hz)
DC12V+10%/-5%
DC12V+10%/-5%
5.5W
6W
59.5 x 60.5 x 115.7mm
390g
828 / 1692
112 x 95 x 170mm
59.5 x 60.5 x 149.9mm
515g
928 / 1880
114 x 97 x 205mm
50 Hz
Off/On
Summary
SCC-B5203(S)(P) is an economical, high-performance color surveillance camera which adopted the latest 1/3” CCD
(410,000 pixels for NTSC, 470,000 pixels for PAL).
As its distinct f=3.0mm lens and 1/3” CCD offers wide view angle, this mini-dome camera is perfect for the use in narrow areas like in the elevator. Its small, dome-like shape (85(ø)x54(H)mm) is easy to install on the ceiling and no external housing is necessary for install. This elegantly designed camera is available in black and silver.
5.5W
AC24(50Hz)
DC12V+10%/-5%
6W
59.5 x 60.5 x 115.7mm
390g
828 / 1692
112 x 95 x 170mm
59.5 x 60.5 x 149.9mm
515g
928 / 1880
114 x 97 x 205mm
Yes
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
This camera employs the SONY CCD and utilizes a superior Digital Signal Processor to supply sharp images of high
horizontal resolution (520 TV lines), while powerful BLC (Back Light Compensation) function ensures perfect backlight
compensation effect recovering brighter and clearer images out of indistinct, dark images. Super-HAD CCD guarantees superior sensitivity and Auto White Balance function helps ensures accurate representation of colors.
Samsung Security System l 27
Digital Video Security System Technology
CAMERA
SCC-B5300G/SCC-B5300GP/SCC-B5301G/SCC-B5303G
SCC-B5305G/SCC-B5301GP/SCC-B5303GP/SCC-B5303GP
SCC-B5203S / SCC-B5203SP
High-resolution, Fixed Mini-Dome Color Digital Camera
Fixed Dome Color Digital Camera
Features
• DSP (Digital Signal Processing)
• 1/3" 470,000pixels super HAD CCD (SCC-B5203(S) : 410,000pixels)
• Horizontal resolution (520 TV lines)
• Lens : f = 3.0mm
• Back light compensation circuitry
• Power Input (DC12V)
• Built-in ground fault isolation transformer
• SCC-B5203S(P) : Silver Body-Color / SCC-B5203(P) : Black Body-Color
Dimensions (unit : mm)
54
85
SCC-B5203S
SCC-B5203
Specifications
SCC-B5203(S)
Camera Type
Scanning
Min. scene Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
Environmental
Conditions
Power
Physical
Specification
28
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Vertical Frequency-Internal Mode
Color
Range-Panning
Range-Tilting
BLC
AGC
ELC
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Aperture Ratio
Viewing Angle
Operating Temperature
Humidity
Power Requirement
Power Consumption
Dimensions(ø x H)-Net
Weight-Net
Loading Quantity(20/40ft)
Etc.-Body Color
Packing
SCC-B5203(S)P
Color
Super-HAD CCD
1/3 inch
811 x 508
768 x 494
Summary
795 x 596
752 x 582
Interlace
15,734 Hz
59.94 Hz
15,625 Hz
50 Hz
0.3 Lux
330˚ (Manual)
15˚ ~ 90˚ (Manual)
On
On
On(Max.1/120Ksec)
ATW / AWC
520 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3 mm
F2
95˚ (H) x 71˚ (V)
-10˚ C ~ +50˚ C
Less than 90%
DC12V+10%/-5%
2W
85(ø) x 54(H) mm
125g
15,840 / 31,680
B5203 : Black / B5203S : Silver
This color camera is capable of superb observation, thanks to its state-of-the-art implementation of 1/3” CCD 410,000
pixels (NTSC), and 470,000 pixels (PAL) at an economical price. (B5300(G)(P):270,000 pixels (NTSC), 320,000 pixels
(PAL))
B5300 and B5301 models: both equipped with a 3.8 mm (focal length) lens and optical low pass filter, they can be
used at ordinary places. B5303 model: equipped with a 2.9 mm (focal length) lens and optical low pass filter, it can
be used in small spaces like an elevator. B5305: equipped with an 8.0 mm (focal length) telephoto lens and optical
low pass filter, it can be used in long and narrow spaces such as a corridor.
This product is an aesthetically designed dome type camera, which can be installed on ceilings without the need for
separate external housing. It is available in either black or white finish. Through the use of SONY CCD and outstanding digital signal processor, this camera provides extremely sharp image quality. By using its backlight compensation
function it is able to give brighter and sharper images of an object darkened by background lighting or sunlight. It is
highly sensitive since it employs the Super-HAD CCD. It also represents correct color using the Auto White Balance
function, and has no color rolling by employing the automatic line-lock switching system.
B5203P : Black / B5203SP : Silver
Both AC24V and DC12V (nonpolar) are available with the use of power adapter.
118 x 101 x 118 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Samsung Security System l 29
Digital Video Security System Technology
CAMERA
SCC-B5300G/SCC-B5300GP/SCC-B5301G/SCC-B5303G
SCC-B5305G/SCC-B5301GP/SCC-B5303GP/SCC-B5303GP
SCC-B5351G / SCC-B5351GP
Vari-Focal Fixed Dome Color Digital Camera
Fixed Dome Color Digital Camera
Features
• DSP (Digital Signal Processor)
• 1/3" NTSC : 410,000 / PAL : 470,000(B5300(G) : 270,000 / B5300(G)P : 320,000)pixels
• Horizontal resolution : 480 TV lines (B5300 : 330 TV lines)
• Lens : f = 3.8mm (B5300(G)(P), B5301(G)(P)) / 2.9mm (B5303(G)(P)) / 8mm (B5305(G)(P))
• Back light compensation circuitry
• External synchronization with linelock (Auto change with using power)
• Power input (AC24V/DC12V compatible) • Built-in ground fault isolation transformer
Dimensions (unit : mm)
Rear Panel
67
100
SCC-B5300GP
SCC-B5301GP
SCC-B5303GP
SCC-B5305GP
SCC-B5300P
SCC-B5301P
SCC-B5303P
SCC-B5305P
SCC-B5300GP
SCC-B5301GP
SCC-B5303GP
SCC-B5305GP
SCC-B5300P
SCC-B5301P
SCC-B5303P
SCC-B5305P
Specifications
SCC-B5300(G)
Camera Type
Scanning
Min. Scene illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
Environmental
Conditions
Power
Physical
Specification
Color
Device
Size
Pixels-Total
Pixels-Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mod
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mod
Color
Range-Panning
Range-Tilting
BLC
AGC
ELC
Line Lock
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Aperture Ratio
Viewing Angle
Operating Temperature
Humidity
Power Requirement
Power Consumption
Dimensions ( W x D x H )-Net
Weight
Loading Quantity (20/40ft)
Etc.-Body Color
Package
30
SCC-B5300(G)P
SCC-B5301(G)
SCC-B5303(G)
SCC-B5305(G)
SCC-B5301(G)P
SCC-B5303(G)P
SCC-B5305(G)P
Color
Super-HAD CCD
1/3 inch
537 x 505
510 x 492
537 x 597
500 x 582
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
811 x 508
768 x 494
795 x 596
752 x 582
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
Interlace
0.3 Lux
0.5 Lux
132˚ (Manual)
90
˚ (Manual)
On
On
On(Max.1/100Ksec)
Off(DC power) / On(AC power)
ATW
330 TV Lines
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
B5301(G)(P) : 3.8mm / B5303(G)(P) : 2.9mm / B5305(G)(P) : 8.0mm
3.8 mm
F2
B5301(G)(P):74˚ (H) x 54˚ (V) / B5303(G)(P):94˚ (H) x 74˚ (V) /
74˚ (H) x 54˚ (V)
B5305(G)(P):30˚ (H) x 23˚ (V)
-10˚ C ~ +50˚ C
Less than 90%
AC24V(60Hz)+10%
AC24V(50Hz)+10%
AC24V(60Hz)+10%
AC24V(50Hz)+10%
DC12V+10%/-5%
DC12V+10%/-5%
DC12V+10%/-5%
DC12V+10%/-5%
3W
100(ø) x 67(H)mm
180g
10,560 / 21,870
B5300 : Black
B5300P : Black
B5301/03/05 : Black
B5301P/03P/05P : Black
B5300G : Gray
B5300GP : Gray
B5300G/03G/05G : Gray B5301GP/03GP/05GP : Gray
540 x 241 x 182 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-B5351(G)(P) is high performance dome type color camera that adopts the most advanced 410,000 pixel 1/3”
CCD (470,000 pixels for PAL). It is designed to have artistic appearance to match with the interior of buildings where
It is installed. By employing 3.4~9 mm (focal length) Vari-Focal lens, it affords various view angles according to the
installation environment. The low pass filter and digital signal processor help represent true colors. It is an aesthetically designed dome type camera, which can be installed on ceilings without the need of separate external housing.
It is available in either black or white finish.
Through the use of SONY CCD and the outstanding digital signal processor, this camera provides extremely sharp
image quality. By using its backlight compensation function it is able to give brighter and sharper images of an object
darkened by background lighting or sunlight. Particularly, it applies the highly sensitive Super-HAD CCD, and supports
perfect auto white balance function, ensuring accurate representation of colors under any environment. It also supports the auto line-lock function to prevent color rolling.
Both AC24V and DC12V (nonpolar) are available with the use of power adapter.
Samsung Security System l 31
Digital Video Security System Technology
CAMERA
SCC-931T / SCC-931TP
SCC-B5351G / SCC-B5351GP
1/4” High Resolution, Anti-Vandal Dome Color Digital Camera,
Motorized 12x Zoom Lens
Vari-Focal Fixed Dome Color Digital Camera
Features
• DSP (Digital Signal Processor)
• 1/3" NTSC : 410,000 / PAL : 470,000 pixels super HAD CCD
• Horizontal resolution (480 TV Lines)
• Lens : f = 3.4 ~ 9mm auto iris
• Back light compensation circuitry
• External synchronization with linelock
• Power input (AC24V/DC12V compatible)
• Built-in ground fault isolation transformer
100
Dimensions (unit : mm)
118
SCC-B5351G
SCC-B5351GP
SCC-B5351
SCC-B5351P
Specifications
Summary
SCC-B5351(G)
Camera Type
Scanning
Min. scene Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
Environmental
Conditions
Power
Physical
Specification
32
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
Range-Panning
Range-Tilting
BLC
AGC
FLK
Line Lock
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
Lens Drive Type
Operating Temperature
Humidity
Power Requirement
Power Consumption
Dimensions(ø x H)-Net
Weight-Net
Loading Quantity(20/40ft)
Etc.-Body Color
Packing
SCC-B5351(G)P
Color
Super-HAD CCD
1/3 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,750Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.3 Lux
345˚ (Manual)
90˚ (Manual)
On
On
Off/On
Off/On
ATW
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3.4~9 mm
F1.6(Wide), F2.4(Tele)
31˚ (H) x 23˚ (V)
83˚ (H) x 62˚ (V)
AI (DC)
-10˚ C ~ +50˚ C
Less than 90%
AC24V(60Hz)±10% / DC12V+10%/-5%
It employs the SONY CCD and utilizes a superior Digital Signal Processor to supply sharp images of high resolution.
It also utilizes the low light function that incorporates the AGC function with low-speed shutter, representing clear
images even under diffused conditions such as dimly lit parking lots or building interiors. With its perfect white balance function, the camera ensures accurate representation of colors under any setting. Through the use of the
MICOM, the camera can be controlled perfectly, and combined with the OSD, the MICOM provides various additional functions.
AC24V(50Hz)±10% / DC12V+10%/-5%
3W
118(ø) x 100(H) mm
250g
4,080 / 8,160
B5351 : Black / B5351G : White
SCC-931T(P) is a dome type color camera that adopts up-to-date 410,000 pixels 1/4” CCD (470,000 pixels for PAL). It
ensures outstanding observation with excellent color sensitivity and high resolution. It is elegantly designed using die
cast aluminum and has an anti-vandal PC (polycarbonate) dome cover that can withstand impact. With perfectly
designed mechanism, it provides waterproof/shockproof functions complying with IP66 requirements. The camera
uses a 12x (f=3.6~43.2mm) motorized zoom lens and along with the 10x digital zoom it can actualize 120x zooming.
Through perfect setups of the Auto/OnePush/Manual Focus and Lens Block functions, it provides various view
angles.
B5351P : Black / B5351GP : White
Its exceptional BLC (Back Light Compensation) function ensures perfect backlight compensation by allowing user to
setup and adjust position and size of the monitoring zones for the object darkened by backlighting. SCC-931T(P) can
be applied for various purposes through its multi-functions such as motion Detection function, a Camera ID indication
function that indicates the camera ID up to 20 digits, a PIP function, and a Line-Lock function for vertical adjustment.
It can also be remote-controlled via the RS485 function and other various protocol supports.
Both AC24V and DC12V (nonpolar) are available with the use of power adapter.
587 x 435 x 359 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Samsung Security System l 33
Digital Video Security System Technology
CAMERA
SCC-C9302F / SCC-C9302FP
SCC-931T / SCC-931TP
1/4" High Resolution, Anti-Vandal, D/N Dome Color Digital Camera
1/4” High Resolution, Anti-Vandal Dome Color Digital Camera,
Motorized 12x Zoom Lens
Features
• High impact, vandal resistant dome (Shock/water/dust proof : IP66 grade)
• x12 motorized optical zoom with x10 digital zoom • DSP (Digital Signal Processor)
• 1/4” 410,000 (PAL 470,000) super HAD CCD
• Horizontal resolution (480 TV Lines)
• Back Light Compensation for the various light conditions
• External synchronization with linelock
• Motion detection function with alarming output
• On-screen menus (Multi-language)
• Picture in Picture on digital zoom
• Remote control: RS485 (Half duplex)
• Power input (AC24V/DC12V compatible)
• Built-in ground fault isolation transformer
Dimensions (unit : mm)
Rear Panel
96.5
132
94
Specifications
SCC-931T
Camera Type
Scanning
Min. scene Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
34
Color
Device
Size
Pixels - Total
Pixels - Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
Range-Panning
Range-Tilting
Motion Detection
D-Zoom
High Speed Shutter
Sense Up
PIP
BLC
AGC
Line Lock
Anti Vandal
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom Ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
Lens Drive Type
OSD
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (ø x H)-Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-931TP
Color
Super-HAD CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
1 Lux(Sense Up x128 : 0.01)
360˚ (Manual)
90
˚ (Manual)
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x128
Off/On
Off/On
Off/On
Off/On
Yes
Max 12 Character
ATW / AWC / MANUAL
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB (AGC Off)
3.6 ~ 43.2 mm
x12
F1.8(Wide), F2.6(Tele)
4˚ 7’(H) x 3˚ 6’(V)
52˚ 8’(H) x 40˚ 3’ (V)
AI (DC)
Yes
1
Yes
-10 ˚ C ~ +50 ˚ C
Less than 90%
AC24V(60Hz)±10% / DC12V+10%/-5%
AC24V(50Hz)±10% / DC12V+10%/-5%
6W
Yes
132(ø) x 96.5(H) mm
1000g
4,080 / 8,160
443 x 335 x 160 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-C9302/SCC-C9302F is a high resolution, high performance dome-type color surveillance camera which adopts
the latest 1/4” CCD (410,000 pixels for NTSC, 470,000 pixels for PAL). It is elegantly designed using die-cast aluminum
and equipped with anti-vandal polycarbonate cover that withstands deliberate shock. This perfectly designed equipment is waterproof and dust-free, and complies with IP66 Standard.
This camera’s 12x (f=3.6-43.2mm) Motorized Zoom Lens enables the maximum of 120x zoom when combined with
10x digital zoom, while its one Auto Focus/Manual Focus Lens Block settings offer various view angles.
Employing the SONY 1/4” Progressive WDR EX-View CCD, this color camera comes with the WDR (Wide Dynamic
Range) function which supplies perfectly clear images even under the backlight condition with huge light difference.
Also, its Day/ Night function and low light function ensures distinctive images for 24 hours a day.
Its Privacy Zone function helps protect privacy by hiding up to eight pre-specified areas.
Its perfect White Balance function reproduces accurate colors under any circumstance while MICOM enables a perfect control of cameras and offers wide variety of functions when incorporated with OSD. Other available multi-purpose functions include Line-Lock, Home Position (using alarm input), Motion Detection that detects moving objects,
and Camera ID Indication that displays camera IDs up to 20 digits.
The remote control of cameras is available through RS 485 function and other supported protocols.
Two models (Surface Mount Model & Flush (Recessed) Mount Model) are available for different set up conditions.
AC24V/ DC12V compatible.
Samsung Security System l 35
Digital Video Security System Technology
CAMERA
SCC-641 / SCC-641P
SCC-643A / SCC-643AP
SCC-C9302F / SCC-C9302FP
1/4" High Resolution, Anti-Vandal, D/N Dome Color Digital Camera
SmartDome Camera
Features
• High impact, vandal resistant dome (Shock/water/dust proof : IP66 grade)
• x12 motorized optical zoom with x10 digital zoom
• DSP (Digital Signal Processing)
• 1/4" 410,000 (PAL : 470,000) pixels Ex-view CCD
• Horizontal resolution (480 TV Lines)
• WDR function, D/N function
• External synchronization with linelock
• Motion detection function with alarming output
• Home position function with alarm input
• On-screen menus (Multi-language)
• Remote control: RS485 (Half duplex)
• Power Input (AC24V/DC12V compatible) • Built-in ground fault isolation transformer
• SCC-C9302(P) : Surface mount type, SCC-C9302F(P) Flush (Recessed) mount type
Dimensions (unit : mm)
29.8
121.1
121.1
150
113
150
SCC-C9302
SCC-C9302F
Specifications
SCC-C9302(F)
Camera Type
Scanning
Min. Scene Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
36
Color
Device
Size
Pixels-Total
Pixels-Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Range-Panning
Range-Tilting
Day/Night
Motion Detection
Wide Dynamic Range
D-Zoom
High Speed Shutter
Sens Up
BLC
Line Lock
Anti Vandal
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
Lens Drive Type
OSD
Input
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
Dimensions (ø x H)-Net
Weight-Net
Package
SCC-C9302(F)P
Color
Ex-View PS CCD
1/4 inch
811 x 508
768 x 494
Summary
795 x 596
752 x 582
Interlace
15,734 Hz
15,750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.002 Lux(15IRE, Sense Up x 128)
0.0002 Lux(15IRE, Sense Up x 128)
360 ˚ (Manual)
90 ˚ (Manual)
Color / BW / Auto
Off/On
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x160
Off/On
Off/On
Yes
Max 20 Character
ATW-1 / ATW-2 / AWC / MANUAL
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
52dB
3.6 ~ 43.2 mm
x12
F1.8(Wide), F2.6(Tele)
4˚ 7'(H) x 3˚ 6'(V)
52˚ 8'(H) x 40˚ 3'(V)
AI (DC)
Yes
1
1
Yes
-10 ˚ C ~ +50 ˚ C
Less than 90%
AC24V(60Hz)±10% / DC12V+10%/-5%
AC24V(50Hz)±10% / DC12V+10%/-5%
6W
150(ø) x 121(H) mm
SCC-C9302F : 880g / SCC-C9302 : 1100g
SCC-C9302FP : 880g / SCC-C9302P : 1100g
SCC-C9302F : 1400g / SCC-C9302 : 1600g
SCC-C9302FP : 1400g / SCC-C9302P : 1600g
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
This product employs a 10x digital zoom and 22x built-in optical lens to offer up to 220x zoom and can correctly catch
an object at a long distance range via the Auto Focus function. Its Digital Signal Processor (DSP) system represents
clear and high quality images of objects under either bright or dark settings. It can observe objects clearly under dark
circumstances by realizing high sensitivity that allows observation under minimum illumination of 0.01Lux (Sense Up
x128). SCC-643A(P) have the Day/Night function as well as the Privacy Zone (8 areas) function by which the user can
mask a certain area to protect privacy.
This camera can be panned 360° and tilted 90° conveniently with its 64 steps of Manual Pan/Tilt operations. With the
moving speed of up to 240°/sec during the preset mode, user can instantly observe desired points. It provides a
remote control interface of RS-485 (Full-Duplex and Half-Duplex)/ RS-422 and can organize up to 128 cameras in a
single system with Samsung’s exclusive controllers (SSC-1000 and SSC-2000).
One of the main features of this product is that it provides various AUTO functions that can be defined by the user. Its
Preset function is distinguished from that of cameras of other manufacturers. Not only it can set 128 camera locations,
zooms, and focuses of cameras but it can also perform video setups for the corresponding locations. Thus user can
preset and save each video control such as iris control, shutter speed and white balance. This feature enables the
expansion of applications of the smart dome under an assortment of installation circumstances.
The Scan function executes touring of preset locations in order to observe critical places rapidly. The camera also
supports the Auto Pan function that pans the camera to observe a place designated by user at a constant speed to
designated directions, and the Pattern function that saves and replays the 30 seconds’ Pan/Tilt/Zoom operation by
user (up to 3 operations). It also provides powerful Alarm In/Out and Motion Detection functions. Four inputs and three
outputs are available for the Alarm function. Alarm and motion detection functions can be used by connecting to the
Preset and Pattern functions defined by the user.
Samsung Security System l 37
Digital Video Security System Technology
CAMERA
SCC-C6403 / SCC-C6403P
SCC-641 / SCC-641P
SCC-643A / SCC-643AP
320x Power Zoom, Cost effective D/N Smart Dome Camera
SmartDome Camera
Dimensions (unit : mm)
Features
ø151
177
94.5
• 22x (f=3.6~79.2mm) optical lens, and built-in 10x digital zoom lens
(Maximum 220x zoom-in, AF function)
• RS-485 (Half duplex • Full duplex) / RS-422 remote control.
• DSP (Digital Signal Processor) IC suitable
• Day & Night function (SCC-643A(P)).
• Minimum illumination of 0.01 Lux (SCC-641(P))
Minimum illumination of 0.01 Lux for Color, 0.003 Lux for B/W(SCC-643A(P))
• 360° endless horizontal rotation and 0~90° vertical rotation. Rapid search at
the maximum rotating speed of 240°/sec.
• Motion detection.
• Alarm in : 4Ch, Alarm out : 3Ch.
• More than 480 lines of horizontal resolution.
• Preset function (Up to 128 locations).
• Auto functions that can be defined by the user (Preset, auto-pan, and scan).
• Privacy zone function for 8 locations (SCC-643A(P)).
ø159.5
Rear Panel
Specifications
SCC-C641
Camera Type
Scanning
Min. Scene
Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
38
Color
Device
Size
Pixels-Total
Pixels-Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Speed-Manual Pan
Speed-Preset Pan
Speed-Manual Tilt
Speed-Preset Tilt
Range-Panning
Range-Tilting
Number of Scan
Number of Auto PAN
Number of Preset
Number of Pattern
Number of Privacy Zone
Day/Night
Motion Detection
Wide Dynamic Range
D-Zoom
High Speed Shutter
Sense Up
PIP
BLC
AGC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
52
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Input
Output
RS485/RS-422
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions -Net
Weight-Net
Loading Quantity(20/40ft)
Packing
SCC-C641P
SCC-643A
SCC-643AP
Color
Super-HAD CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,625 Hz
15,734 Hz
15,625 Hz
15,750 Hz
15,625 Hz
15,750 Hz
15,625 Hz
59.94 Hz
50Hz
59.94 Hz
50Hz
60 Hz
50 Hz
60 Hz
50 Hz
0.3 Lux (Sense Up X4 30IRE), 0.01 Lux (Sense Up X128)
0.3 Lux (Sense Up X4 30IRE), 0.01 Lux (Sense Up X128)
0.003 Lux
0.003 Lux
0.8˚ /sec ~ 90˚ /sec
240˚ /sec
0.8˚ /sec ~ 45˚ /sec
150˚ /sec
360(endless)
0˚ /sec ~ 90˚ /sec
1
1
128
3
8
Yes
Yes
Yes(2X ~ 10X)
Yes(OFF ~ 1/10K)
Yes(X2 ~ X128)
Off/On
Off/On
Off/On
Off/On
Max 12 Character
ATW / AWC / MANUAL
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
52 dB
3.6 ~ 79.2 mm
22X
F1.6(Wide), F3.8(Tele)
2˚ 3'(H) x 1˚ 7'(V)
47˚ 9'(H) x 36˚ 9'(V)
Yes
4
3
RS485 Half / Full Duplex, RS-422
-10 ˚ C ~ +50 ˚ C
Less than 90%
AC24V(60Hz) ±10%
AC24V(50Hz) ±10%
AC24V(60Hz) ±10%
AC24V(50Hz) ±10%
18W
Yes
159.5(ø) x 177(H)
1,700g
756 / 1,776
378 x 308 x 275 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-C6403(P) is one of the best cameras available from Samsung in terms of zoom. With 32x optical lens, a maximum of 320x zoom is available when combined with 10x digital zoom and it adopts the SONY 1/4” IT Type S-HAD
CCD.
Its quick and accurate PAN/ TILT function enables users to move around freely within the screen and to instantly
observe desired points.
It automatically switches to B/W mode when the image is hardly distinct during night or when sufficient light is unavailable.
It is the user-friendly surveillance camera that comes with various useful functions such as White Balance function
that ensures accurate representation of colors under any setting, and Auto-Focus function that automatically adjusts
focus in response to the movement of the object.
Samsung Security System l 39
Digital Video Security System Technology
CAMERA
SCC-C6405 / SCC-C6405P
SCC-C6403 / SCC-C6403P
220x Power Zoom, WDR, D/N Smart Dome Camera
320x Power Zoom, Cost effective D/N Smart Dome Camera
Features
• x32 motorized optical zoom with x10 digital zoom
• 1/4 Inch IT Type S-HAD CCD
• DSP (Digital Signal Processing)
• Motion detection function with alarming output
• Inner rotor BLDC motor
• Minimum scene illumination (Color : 0.005Lux, Sens up X128)
• High-speed PAN/TILT (400 º /sec)
• Horizontal Resolution (480 TV lines)
• Day/Night function
• On-screen menus (Multi-language)
• More than 480 lines of horizontal resolution
• 4 alarm inputs, 3 alarm outputs
Dimensions (unit : mm)
177
94.5
ø151
ø159.5
Specifications
SCC-C6403
Camera Type
Scanning
Min. Scene
Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
40
Color
Device
Size
Pixels-Total
Pixels-Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Speed-Manual Pan
Speed-Preset Pan
Speed-Manual Tilt
Speed-Preset Tilt
Range-Panning
Range-Tilting
Number of Auto PAN
Number of Preset
Number of Pattern
Day/Night
Motion Detection
D-Zoom
High Speed Shutter
Sens Up
BLC
AGC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Input
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Package
SCC-C6403P
Color
Super-HAD CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,625 Hz
15,750 Hz
15,625 Hz
59.94 Hz
50 Hz
60 Hz
50 Hz
0.15 Lux(Sense Up x 4, 15IRE), 0.005Lux(Sense Up x 128)
0.015 Lux(Sense Up x 4, 15IRE), 0.0005Lux(Sense Up x 128)
0.1˚ /sec~180˚ /sec(64Step)
400 ˚ /sec(max)
0.1˚ /sec~90˚ /sec(64Step)
200 ˚ /sec(max)
350˚ (Non-Endless)
0˚ ~ 90˚
4 ea
128 ea
3 ea
Color / BW / Auto
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x128
Off/On
Off / Low / High
On/Off
Off/On
ATW-1 / ATW-2 / AWC / MANUAL
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3.55 ~ 113 mm
32X
F1.69(Wide), F4.17(Tele)
1˚ 78'(H) x 1˚ 34'(V)
41˚ 5'(H) x 43˚ 01'(V)
Yes
4
3
Yes
-10˚ C ~ +50 ˚ C
Less than 90%
AC24V(60Hz) ±10%
AC24V(50Hz) ±10%
18W
Yes
159.6(ø) x 177(H) mm
1700g
912 / 1824
382 x 260 x 307 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-C6405(P) is one of the best cameras available from Samsung in terms of zoom. With 22x optical lens, a maximum of 220x zoom is available when combined with 10x digital zoom.
Employing the latest SONY 1/4 inch WDR Ex-view HAD CCD, a sharper image will be available even when surrounding is too dark or too bright. Its quick and accurate PAN/ TILT function enables users to move around freely within the
screen and to instantly observe desired points. Also, it automatically switches to B/W mode when the image is hardly distinct during night or when sufficient light is unavailable.
Privacy-Zone option enables to hide a pre-specified area to protect privacy, and RS485 Cable Remote Control makes
it easier for users to operate the cameras.
It is the user-friendly surveillance camera that comes with various useful functions such as White Balance function
that ensures accurate representation of colors under any setting, and Auto-Focus function that automatically adjusts
focus in response to the movement of the object.
Samsung Security System l 41
Digital Video Security System Technology
CAMERA
SCC-C6407 / SCC-C6407P
SCC-C6405 / SCC-C6405P
320x Power Zoom, WDR, D/N Smart Dome Camera
220x Power Zoom, WDR, D/N Smart Dome Camera
Features
• x22 motorized optical zoom with x10 digital zoom
• High-speed PAN/TILT (400 º /sec)
• 1/4Inch WDR Ex-view HAD CCD
• Horizontal resolution (480 TV Lines)
• DSP (Digital Signal Processing)
• WDR function
• Day/Night function
• External eynchronization with linelock
• Motion detection function with alarming output
• On-screen menus (multi-language)
• Innor rotor BLDC motor
• Minimum scene illumination (color : 0.005Lux,sens up X160) • 4 alarm inputs, 3 alarm outputs • Privacy zone
Dimensions (unit : mm)
177
94.5
ø151
ø159.5
Specifications
SCC-C6405
Camera Type
Scanning
Min. Scene
Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
42
Color
Device
Size
Pixels-Total
Pixels-Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Speed-Manual Pan
Speed-Preset Pan
Speed-Manual Tilt
Speed-Preset Tilt
Range-Panning
Range-Tilting
Number of Auto PAN
Number of Preset
Number of Pattern
Number of Privacy Zone
Day/Night
Motion Detection
Wide Dynamic Range
D-Zoom
High Speed Shutter
Sens Up
BLC
AGC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Input
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Package
SCC-C6405P
Color
Ex-View PS CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15.734 Hz
15.750 Hz
59.94 Hz
60 Hz
15,625 Hz
15,625 Hz
50 Hz
50 Hz
0.2 Lux(Sense Up x 4), 0.005Lux(Sense Up x 160)
0.07 Lux(Sense Up x 4), 0.0002Lux(Sense Up x 160)
0.1˚ /sec~180˚ /sec(64Step)
400˚ /sec(max)
0.1˚ /sec~90˚ /sec(64Step)
200˚ /sec(max)
360˚ /sec(Endless)
0˚ ~180˚
4 ea
128 ea
3 ea
8 ea
Color / BW / Auto
Off/On
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x160
Off/On
Off / Low / High
On/Off
Off/On
ATW-1 / ATW-2 / AWC / MANUAL
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3.6 ~ 79.2 mm
32X
F1.6(Wide), F3.8(Tele)
2˚ 3'(H) x 1˚ 7'(V)
47˚ 9'(H) x 36˚ 9'(V)
Yes
4
3
Yes
-10˚ C ~ +50˚ C
Less than 90%
AC24V(60Hz) ±10%
AC24V(50Hz) ±10%
18W
Yes
159.6(ø) x 177(H)mm
1700g
912 / 1824
382 x 260 x 307 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-C6407(P) is one of the best cameras available from Samsung in terms of zoom. With 32x optical lens, a maximum of 320x zoom is available when combined with 10x digital zoom.
Employing the latest SONY 1/4 inch WDR Ex-view HAD CCD, a sharper image will be available even when surrounding is too dark or too bright. Its quick and accurate PAN/ TILT function enables users to move around freely within the
screen and to instantly observe desired points. Also, it automatically switches to B/W mode when the image is hardly distinct during night or when sufficient light is unavailable.
Privacy-Zone option enables to hide a pre-specified area to protect privacy, and RS485 Cable Remote Control makes
it easier for users to operate the cameras.
It is the user-friendly surveillance camera that comes with various useful functions such as White Balance function
that ensures accurate representation of colors under any setting, and Auto-Focus function that automatically adjusts
focus in response to the movement of the object.
Samsung Security System l 43
Digital Video Security System Technology
CAMERA
SCC-C6475 / SCC-C6475P
SCC-C6407 / SCC-C6407P
IP Smart Dome Camera with WDR, X22 Zoom and Day&Night
320x Power Zoom, WDR, D/N Smart Dome Camera
Features
• x32 motorized optical zoom with x10 digital zoom
• High-speed PAN/TILT (400 º /sec)
• 1/4Inch WDR Ex-view HAD CCD
• Horizontal resolution (480 TV Lines)
• DSP (Digital Signal Processing)
• WDR function
• Day/Night function
• External eynchronization with linelock
• Motion detection function with alarming output
• On-screen menus (multi-language)
• Innor rotor BLDC motor
• Minimum scene illumination (color : 0.002Lux,sens up X160) • 8 alarm inputs, 3 alarm outputs • Privacy zone
Dimensions (unit : mm)
177
94.5
ø151
ø159.5
Specifications
SCC-C6407
Camera Type
Scanning
Min. Scene
Illumination
PAN/TILT
Functions
Resolution
Video Output
S/N Ratio
Lens
OSD
Alarm
Remote Control
Environmental
Conditions
Power
Physical
Specification
44
Color
Device
Size
Pixels-Total
Pixels-Effective
System
Horizontal Frequency-Internal Mode
Horizontal Frequency-Line-lock Mode
Vertical Frequency-Internal Mode
Vertical Frequency-Line-lock Mode
Color
B/W
Speed-Manual Pan
Speed-Preset Pan
Speed-Manual Tilt
Speed-Preset Tilt
Range-Panning
Range-Tilting
Number of Auto PAN
Number of Preset
Number of Pattern
Number of Privacy Zone
Day/Night
Motion Detection
Wide Dynamic Range
D-Zoom
High Speed Shutter
Sens Up
BLC
AGC
Line Lock
Camera ID
White Balance
Horizontal
Vertical
VBS 1.0Vp-p
S/N Ratio
Focal Length
Zoom ratio
Aperture Ratio
Viewing Angle-Tele
Viewing Angle-Wide
OSD
Input
Output
RS485
Operating Temperature
Humidity
Power Requirement
Power Consumption
LED Indicator
Dimensions (WxHxD)-Net
Weight-Net
Loading Quantity(20/40ft)
Package
SCC-C6407P
Color
Ex-View PS CCD
1/4 inch
811 x 508
768 x 494
795 x 596
752 x 582
Interlace
15,734 Hz
15,625 Hz
15,750 Hz
15,625 Hz
59.94 Hz
50 Hz
60 Hz
50 Hz
0.09 Lux(Sense Up x 4, 15IRE), 0.002Lux(Sense Up x 128)
0.009 Lux(Sense Up x 4, 15IRE), 0.0002Lux(Sense Up x 128)
0.1˚ /sec~180˚ /sec(64Step)
400˚ /sec(max)
0.1˚ /sec~90˚ /sec(64Step)
200˚ /sec(max)
360˚ /sec(Endless)
0˚ ~180˚
4 ea
128 ea
3 ea
8 ea
Color / BW / Auto
Off/On
Off/On
Off ~ x10
Off ~ 1/10Ksec
Off ~ x160
Off/On
Off / Low / High
On/Off
Off/On
ATW-1 / ATW-2 / AWC / MANUAL
480 TV Lines
350 TV Lines
VBS 1.0Vp-p
50dB
3.55 ~ 113 mm
32X
F1.69(Wide), F4.17(Tele)
1˚ 78'(H) x 1˚ 34'(V)
41˚ 5'(H) x 43˚ 01'(V)
Yes
8
3
Yes
-10˚ C ~ +50˚ C
Less than 90%
AC24V(60Hz) ±10%
AC24V(50Hz) ±10%
22W
Yes
159.6(ø) x 177(H)mm
1700g
912 / 1824
382 x 260 x 307 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCC-6475 is an IP dome camera based on Embedded OS, having the same function with SCC-6405 but being available for connection in any environment among ADSL, Cable modem, and LAN.
Users will be provided with an exclusive viewer manufactured by SAMSUNG.
This viewer supports not only Remote Monitoring and Pan/Tilt/Zoom In/Out but also customizing logos and banners to
the user.
The protocols to be supported include DDNS, DHCP, TCP/IP, UDP/IP, HTTP, FTP, SMTP, RTP/RTSP, NTP, and PPPoE.
The maximum transmission speed reaches 30ips and recording may continue for as long as 10 min in a local PC.
SCC-6475 provides a variety of housings and mounts depending on the installation environment, having installation
accessories such as Indoor Housing, Outdoor Housing, Wall Mount Adaptor, Pole Mount Adaptor, Corner Mount
Adaptor, Ceiling Mount Adaptor, and Ceiling Mount Bracket.
Samsung Security System l 45
Digital Video Security System Technology
CAMERA
SSC-1000(P)
SCC-C6475 / SCC-C6475P
SmartDome Controller
IP Smart Dome Camera with WDR, X22 Zoom and Day&Night
Features
• 1/4" Ex-view P/S 410K CCD
• 480 TV lines of horizontal resolution
• Built-in X22 optical zoom lens (X10 D-Zoom)
• Sensitivity : 0.2 lux (X4 sens-up, color)
• 360º endless PAN (Slip-ring)
• Preset speed : pan (400º /sec), tilt (200º /sec)
• Remote control : RS-485, RS-422
• MPEG4 and MJPEG, max. 25fps (@VGA)
• 10/100 base-T (RJ-45)
• Support various network protocol(HTTP, FTP, SMTP, TCP, UDP, IP, DHCP, DNS, ARP, NTPPPPoE, DDNS, RTP, RTSP)
Dimensions (unit : mm)
Rear Panel
177
94.5
ø151
ø159.5
Specifications
SCC-C6475(P)
Camera Section
Pan/Tilt Section
Network Section
Environment
Browser
Compression
Hardware
Network
Same as SCC-C6405(P)
Same as SCC-C6405(P)
Server
Client
Web browser
MPEG4 / MJPEG
Flash memory
OS
SDRAM
Power Source
Ambient Operating Temperature
Dimensions
Ethernet
Network Protocol
Video Resolution
NTSC
PAL
Quality
Video Quality
MJPEG
Performance
MPEG4
Connection Users MJPEG
MPEG4
Alarm Control
Recording
IP Notification
IP Installer
Software Upgrade
Access Level
Security
Time Setting
PTZ Control
Sequence
Language
ETC Section
Power Source
Power Consumption
Ambient Operating Temperature
Dimensions
Weight
46
OS
OS
CPU
Memory
Graphic Accelerator
Network Protocol
DDNS
ADSL
Cable Modem
Video trasnfer protocol
VGA
VGA
VGA
VGA
Multicast
Multicast
FTP, SMTP
Pre-Alarm
Post-Alarm
Recording
FTP, SMTP
IP address Installation
Firmware Upgrade
Login Sccess Level
IP Filtering
Time Setting
Pan/Tilt/Zoom control
Sequence
Language
Embedded Linux : Support
Win 2k/XP : Support
PentiumIII 1GHz Higher
Memory : 256Mb Higher
DirectX 8.1 hjiger
Internet explorer 5.0 higher
do not support simultaneous operation
8 Mbyte
embedded Linux
32Mbyte
8.4V DC,500mA (using the supplied AC adapter)
0C - +40C (32F - 104F) degree
93 mm (H) x 61 mm (W) x 43 mm (D)
10/100BaseT
DHCP, TCP/IP, UDP/IP, HTTP, FTP, SMTP, RTP/RTSP, NTP, PPPoE
Notification Support for Dynamic IP
Only PPPoE Support
DHCP Support
TCP, UDP (Multicast, Unicast) support
640x480
640x480
High, Midium, Low
Max 25 fps
Max 25 fps
Max - 10 Users
Max - 20 Users
MJPEG only support (MPEG4 is not supported)
On alarm, Image will be sent by FTP, SMTP
Max Total 60 images
Max Total 60 images
Max 10min recordcan be recorded when PC Hard Disk
available space is bigger than 20% of total space
The ip address is sent by FTP and (or) SMTP, when a dynamic ip is received
IP installation function (XP, win 2000 support)
Firmware upgrade by web browser
Guest, Administrator, Operator, User
IP filtering
Setting by a NTP server on the internet
Auto pan, preset, scan function support
1CH/ 4Ch sequence support
English Only
24 V AC, 60 Hz or 50 Hz
20 W
-10°C to +50°C (14°F to 122°F)
DOME : 147 ( ø ), Outline : 159.6 ( ø ) x 177(H) (Adapter:23.5(H)mm)
approx. 1.7 kg
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SSC-1000 can be used to control SCC-641/643, SCC-931T and SCC-421A IC series (Intelligent Cameras).
SSC-1000 features a backlight LCD, a four-direction joystick, camera call up and camera programming buttons.
Up to eight SSC-1000 devices may be used in the system configuration. SSC-1000 can control up to 32 IC series
cameras or SDM-160 multiplexers utilizing RS-485 protocol.
Samsung Security System l 47
Digital Video Security System Technology
CAMERA
SSC-2000(P)
SSC-1000(P)
Touch Screen System Keyboard
SmartDome Controller
Features
• Long distance control : Up to 1.2km on RS-485 communication.
• IC (Intelligent Camera) series controller for :
SCC-641 - Motorized speed dome
SCC-643A - Motorized Day/Night speed dome
SCC-C4201A - Motorized zoom camera
SCC-931T - Armored motorized zoom camera
• Controls up to 128 smart dome cameras or SDM-160 multiplexers
• Up to 8 SSC-1000 controllers in each system
Dimensions (unit : mm)
Rear Panel
65
205
315
Specifications
SSC-1000(P)
Communication
Display
Interface Type
RS-485
Connector Type
Modular Type x 2, D-Sub x 1
Baud Rate
4,800/9,600/19,200/38,400 bps
LCD
20 x 4 line
LED
Menu, Preset, Pattern, Scan, Auto Pan
Auto Pan, Reset
Switching & Control
Video Switching
Sequence, Tour, Salvo
Pan/Tilt & Lens Control
Pan left/right
Tilt up/down
lris open/ close
Focus far/ near
Zoom tele/wide
Preset, Auto pan, Scan, Pattern
External Machinery Control
48
Summary
Aux1, Aux2, Aux3, Aux4
Power Source
DC 9V, 500mA
Dimensions (W x H x D)
315 x 65 x 205 mm
Weight
Approx. 1.1Kg (excluding packing materials)
RS-485 Connector
No 3(Yellow) : DATA “+”, No 5(Red) : DATA “-”
D-SUB Connector
No 2 : DATA “+”, No 3 : DATA “-”
Packing
502 x 272 x 190 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
SSC-2000, system keyboard, is a controller that controls Cameras, DVR, Multiplexer and other devices by using
RS-485 communication. it is easy to operate with a user-friendly on-screen menu, touch screen, and robust keys.
The 3-axis joystick supports control of PTZ functions. This keyboard can control up to 256 cameras and other serially controlled devices such as mutiplexers and DVRs. Maximum 32 keyboards can be connected simultaneously
and controlled from different places.
Samsung Security System l 49
SSC-2000(P)
SmartDome & Dome Camera Accessory
Touch Screen System Keyboard
Comparison Chart by Model
SHG-120 (Indoor Housing)
Dimension (unit :mm)
Features
Summary
Features
• Long distance control : Up to 1.2km on RS-485 communication.
• Maximum 32 keyboards can be connected simultaneously
• 5.7” graphic panel
• Durable 3-axis PTZ joystick
• User friendly touch screen interface
• Camera, DVR and multiplexer selection
• Jog/Shuttle controls
SHG-120 is applied to the
installation of Smartdome
camera on the wall and
ceiling.
• Aluminum Body
Dimensions (unit : mm)
SHG-220 (Outdoor Housing)
Rear Panel
Dimension (unit :mm)
Summary
Features
SHG-220 is applied to the installation
of Smartdome camera outside the
wall and ceiling. It was designed to tolerate harsh environment and earned IP
66 standards certification.
• Built-in Fan & Heater
• Aluminum Body
• Clear Dome
: high impact polycarbonate
• IP 66 Certification
SADT-100WM/101WM/102WM (Wall Mount Adaptor)
61.3
Summary
198.7
SADT-100WM is applied when SHG-120 (Indoor housing) of SHG-220
(Outdoor housing) is installed on the outside/inside the wall. SADT101WM/102WM are applied when SCC-931T/9302(F) (Anti-Vandal
camera) are installed on the outside/inside the wall.
34.2
117.1
427.8
Dimension (unit :mm)
SADT-100PM (Pole Mount Adaptor)
Dimension (unit :mm)
Features
• Indoor or Outdoor Applications
• Supports up to 88 Pounds(40Kg)
• Metal body
Specifications
Interface Type (RS-485)
Interface Type (RS-232C)
SADT-110CM (Corner Mount Adaptor)
Connector Type
Port
Baud Rate
Connector Type
Port
Baud Rate
LCD Panel
Viewing Angle
Inclination Angle
LED
Pan/Tilt & Lens Control
DVR Control
Power
Power Consumption
Dimensions(W x D x H)
Weight
Packing
50
PAN
Tilt
Iris
Focus
Zoom
SW
Jog/Shuttle
Net
Package
Net
Package
SSC-2000(P)
Features
4P Terminal Type
1 Port
4,800/9,600/19,200/38,400bps
D-SUB 9P
1 Port
600/1,200/2,400/4,800/9,600/19,200/38,400/57,600bps
5.7” Graphic Panel(320 x240 line) + Touch Panel
Left(39˚), Right(32˚), Rear(10˚), Front(30˚)
Min(8.4˚), Max(15.9˚)
Monitor, Camera, Multiplexer, DVR
Left/Right
Up/Down
Close/Open
Near/Far
Tele/Wide
Preset, Pattern, Auto Pan, Scan
RW, Stop, Play, FF, REC.
Forward/Reverse, Play/Reverse Play/FF/RW
DC12V, 600mA
BELOW 3W
427.8 x 198.7 x 117.1
496 x 206 x 288 mm
1.36Kg
2.6Kg
502 x 272 x 190 mm
• Indoor or Outdoor Applications
• Supports up to 97 Pounds(44Kg)
• Metal body
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
SADT-100CM (Ceiling Mount Adaptor)
Dimension (unit :mm)
Dimension (unit :mm)
Features
• Metal body
• Indoor or Outdoor Applications
• Supports up to 70 Pounds(32Kg)
• Rugged Construction
SBR-100DCM (Ceiling Mount Bracket)
Dimension (unit :mm)
Features
• Supports up to 35 Pounds(16Kg)
• Rugged Construction
• Metal body
Samsung Security System l 51
Digital Video Security System Technology
MONITOR
SmartDome & Dome Camera Accessory
Installation
Natural image, clear definition
SHG-120
COVER TOP
BOSS
LEVER
CAMERA ADAPTOR
CASE BODY
LEVER
CASE BODY
BOSS
SHG-220
CAMERA ADAPTOR
PIN
CAMERA ADAPTOR
2
CAMERA
CAMERA
ADAPTOR
BOSS
1
CAMERA
LEVER
15 DEGREE
SADT-100WM/101WM
SCREW (BH M4 x L22)
WALL MOUNT ADAPTOR
BOSS
GASKET
DUMMY PLATE
BACK PLATE
GASKET
GASKET ATTACHMENT AFTER
SEPARATING DUMMY PLATE
WALL MOUNT ADAPTOR
SADT-100PM
CABLE GLAND
BACK PLATE
STAINLESS STEEL
MOUNTING STRAP
POLE MOUNT
ADAPTOR
WALL MOUNT ADAPTOR
SADT-110CM
CABLE GLAND
BACK PLATE
WALL MOUNT ADAPTOR
CORNER MOUNT ADAPTOR
SADT-100CM
Comparison
Chart by Model
CONCRETE CEILING
CEILING BOARD
TEFLON TAPE
1.5” NPT PIPE
LCD Monitor
DECORATION COVER
TEFLON TAPE
HOUSING
SMT-171(P)/SMT-190(P)
Other Monitor
SBR-100DCM
SMC-150F(P)/SMC-152F(P)
SMC-210FP/211F(P)/212FP
NUT
NUT
TURN CLOCKWISE
52
COVER BODY
Samsung Security System l 53
Digital Video Security System Technology
DVR
SHR-2040(P)
DVR
Comparison Chart by Model
Models
4 Channel Standalone Digital Video Recorder
SHR-2040(P)
SHR-2042(P)
SHR-2080(P)
SHR-2082(P)
160GB
160GB
160GB
160GB
250GB x 2
250GB x 3
250GB x 4
250GB x 3
100(SHR-2040P)
100(SHR-2042P)
200(SHR-2080P)
200(SHR-2082P)
120(SHR-2040)
120(SHR-2042)
240(SHR-2080)
240(SHR-2082)
RS-485(P/T/Z)
RS-485(P/T/Z)
RS-485(P/T/Z)
RS-485(P/T/Z)
LAN
LAN
LAN
LAN
Spec
HDD Basic
Max,Expansion
Display Speed(ips)
Remote Control
CD-RW
Data Back up
CD-RW
USB 2.0
USB 2.0
USB 2.0
USB 2.0
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)
Triplex
Triplex
Triplex
Triplex
DC12V, 50/60Hz
AC100~240V, 50/60Hz
AC100~240V, 50/60Hz
AC100~240V, 50/60Hz
3.3kg
6.5kg
6.9kg
7.8kg
215 x 88 x 337 mm
430 x 88 x 400 mm
430 x 88 x 400 mm
430 x 88 x 400 mm
Models
SHR-2160(P)
SHR-2162(P)
SHR-4081(P)
SHR-4160(P)
160GB
160GB
160GB
160GB
250GB x 4
250GB x 3
250GB x 4
250GB x 4
400(SHR-2160P)
400(SHR-2162P)
200(SHR-4081P)
400(SHR-4160P)
480(SHR-2160)
480(SHR-2162)
240(SHR-4081)
480(SHR-4160)
RS-485(P/T/Z)
RS-485(P/T/Z)
RS-485(P/T/Z)
RS-485(P/T/Z)
LAN
LAN
LAN
LAN
Spec
HDD Basic
Max,Expansion
Display Speed(ips)
Remote Control
CD-RW
Data Back up
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)
Models
IEEE 1394 Interface
USB 2.0
USB 2.0
USB 2.0
USB 2.0
Triplex
Triplex
Triplex
Triplex
AC100~240V, 50/60Hz
AC100~240V, 50/60Hz
AC100~240V, 50/60Hz
AC100~240V, 50/60Hz
6.9kg
7.8kg
6.5kg
6.5kg
430 x 88 x 400 mm
430 x 88 x 400 mm
430 x 88 x 400 mm
430 x 88 x 400 mm
SPR-7116(P)
SPR-7416(P)
Video Input
16CH Composite Video(NTSC/PAL)
16CH Composite Video(NTSC/PAL)
Video Output
RGB(PC) : 1CH, Composite(Normal Monitor) : 1CH
RGB(PC) : 1CH, Composite(Normal Monitor) : 1CH
Recording Speed
Max. 120/100 ips(NTSC/PAL)
Max. 480/400 ips(NTSC/PAL)
Display Mode
1, 4, 9, 16 split screen, full screen, 16CH real time monitoring
1, 4, 9, 16 split screen, full screen, 16CH real time monitoring
480/400 ips (NTSC/PAL)
480/400 ips (NTSC/PAL)
Auto/Manual back up through HDD, CD-RW, DVD, Network Drive
Auto/Manual back up through HDD, CD-RW, DVD, Network Drive
Spec
Data backup
Auto/Manual back up through HDD, CD-RW, DVD, Network Drive
Auto/Manual back up through HDD, CD-RW, DVD, Network Drive
Power Requirements
AC100~240V, 5Amax, 60Hz
AC100~240V, 5Amax, 60Hz
Weight
Approx.18Kg
Approx.18Kg
Dimension(WxHxD)
431(W)x177(H)x459(D)
431(W)x177(H)x459(D)
Summary
SHR-2040(P) is a 4-channel MPEG4 real time Digital Video Recorder capable of 120(100)ips recording rate in CIF
mode.
It can also record the 4-channel synchronized audio and various kinds of resolution (CIF/Half D1).
* CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Each channel provides various recording rates to save HDD consumption.
External interface method is USB 2.0 (Front:1, Rear:1).
62
Samsung Security System l 63
Digital Video Security System Technology
DVR
SHR-2042(P)
SHR-2040(P)
4-Channel Standalone Digital Video Recorder with built-in CD-RW
4 Channel Standalone Digital Video Recorder
Features
• 4 Channel video & audio realtime recording capability.
• High picture quality : MPEG4 • Remote monitoring and control through network (LAN)
• Various recording features (Normal, schedule, motion, alarm)
• Recording during replay (Triplex)
• Various N/W environments support (LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
• USB2.0 Interface : USB memory/USB external HDD/external CD-RW, DVD-RW backup
Dimensions (unit : mm)
Rear Panel
337
215
ALRAM
HDD
NETWORK BACK UP
REC
MODE
2
3
4
AUDIO
PTZ
ALRAM
ZOOM
FREEZE
SEARCH
MENU
TELE
WIDE
VIEW
PRESET
88
DIGITAL VIDEO RECORDER SHR-2040
1
215
Specifications
Operating System
Storage
Internal
Capacity
External
Video
Inputs
Outputs
Basic
Max. Expansion
USB HDD
Composite
Composite Through
Composite
S-Video
VGA
Compression
Compression Rate
Very High
High
Standard
Low
Display Speed(images/sec)
Display Resolution
Recording Recording Mode
/Search
Search / PB Mode Search
PB
Recording Speed(Images/sec)
Recording Resolution
Auto Switching
Live Division Screen
Audio
Inputs
Outputs
Compression
Recording
Alarm
Inputs
Outputs
Pre Alarm
Post Alarm
Motion Detection
Network
Backup
USB 2.0
Serial I/F(RS-485)
Watermark
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)mm
Packing
64
SHR-2040P
SHR-2040
Embedded OS
160GB
250GB x 2
1EA (Max. 250GB)
4Ch
4Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
8.1KB(352x288), 20.6KB(720 x 288)
6.1KB(352x288), 15.7KB(720 x 288)
4.8KB(352x288), 12.1KB(720 x 288)
2.9KB(352x288), 7.8KB(720 x 288)
100
720 x 576
Time Lapse, Event Alarm/Motion/Video Loss,
Schedule(Time/Date/Camera)
Event Search(Alarm/Motion/Video Loss), Date/Time Search,
Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FB, Forward Frame Advance,
Reverse Frame Advance
100(352 x 288), 50(720 x 288), 25(720x576, 1CH mode only)
CIF(352 x 288), Half D1(720 x 288), D1(720x576, 1CH mode only)
0, 3, 5, 10, 20, 30sec
Single, Quad, PIP, Sequence, Freeze, x2 Zoom
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
4 Alarm In
2 Alarm Out, 1 Alarm Reset
Off, 5,10, 20, 30sec
Off, 5,10, 20, 30sec, 1, 3, 5,10, 20min
Area setting
Ethernet : 10/100Base T, Static IP,
Dynamic IP(DHCP), ADSL(PPPoE)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
DC12V, 4.5A(External Adaptor)
3.3kg
215 x 88 x 337 mm
436 x 329 x 189 mm
Embedded OS
160GB
250GB x 2
1EA (Max. 250GB)
4Ch
4Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
6.7KB(352x240), 17.2KB(720 x 240)
5.0KB(352x240), 13.2KB(720 x 240)
3.9KB(352x240), 10.0KB(720 x 240)
2.4KB(352x240), 6.3KB(720 x 240)
120
720 x 480
Time Lapse, Event Alarm/Motion/Video Loss,
Schedule(Time/Date/Camera)
Event Search(Alarm/Motion/Video Loss), Date/Time Search,
Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FB, Forward Frame Advance,
Reverse Frame Advance
120(352 x 240), 60(720 x 240), 30(720x480, 1CH mode only)
CIF(352 x 240), Half D1(720 x 240), D1(720x480, 1CH mode only)
0, 3, 5, 10, 20, 30sec
Single, Quad, PIP, Sequence, Freeze, x2 Zoom
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
4 Alarm In
2 Alarm Out, 1 Alarm Reset
Off, 5,10, 20, 30sec
Off, 5,10, 20, 30sec, 1, 3, 5,10, 20min
Area setting
Ethernet : 10/100Base T, Static IP,
Dynamic IP(DHCP), ADSL(PPPoE)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
DC12V, 4.5A(External Adaptor)
3.3kg
215 x 88 x 337 mm
436 x 329 x 189 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
The SHR-2042 offers 4-channel MPEG4 Real time Digital Video Recorder capable of 120(100)ips recording rate(in CIF
mode). The SHR-2042 also record the 4-channel synchronized audio.
The DVR can record various kinds of resolution(CIF/Half D1)
Each channel provides various recording rates to save HDD consumption.
External interface methods are USB2.0(Front:1, Rear:1).
*.CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Samsung Security System l 65
Digital Video Security System Technology
DVR
SHR-2080(P)
SHR-2042(P)
8-Channel Standalone Digital Video Recorder
4-Channel Standalone Digital Video Recorder with built-in CD-RW
Features
• 4 Channel video & audio realtime recording capability.
• Built-in CD-RW for backup
• High picture quality : MPEG4
• Remote monitoring and control through network (LAN)
• Various recording features (Normal, schedule, motion, alarm)
• Recording during replay (Triplex)
• Various N/W environments support(LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
• USB2.0 Interface : USB memory/USB external HDD/CD-RW, external DVD-RW backup
Dimensions (unit : mm)
Front Panel
88
400
430
430
Specifications
Operating System
Storage
Internal
Capacity
Video
External
Inputs
Outputs
Basic
Max. Expansion
CD-RW
USB HDD
Composite
Composite Through
Composite
S-Video
VGA
Compression
Compression Rate
Very High
High
Standard
Low
Display Speed(images/sec)
Display Resolution
Recording Recording Mode
/Search
Search / PB Mode Search
PB
Recording Speed(Images/sec)
Recording Resolution
Auto Switching
Live Division Screen
Audio
Inputs
Outputs
Compression
Recording
Alarm
Inputs
Outputs
Pre Alarm
Post Alarm
Motion Detection
Network
Backup
USB 2.0
Serial I/F(RS-485)
Watermark
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)mm
Packing
66
SHR-2042P
SHR-2042
Embedded OS
160GB
250GB x 3
for Backup
Max. 250GB, 1EA
4Ch
4Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
8.1KB(352x288), 20.6KB(720x288)
6.1KB(352x288), 15.7KB(720x288)
4.8KB(352x288), 12.1KB(720x288)
2.9KB(352x288), 7.8KB(720x288)
100
720x576
Time Lapse
Event Alarm/Motion/Video Loss Schedule(Time/Date/Camera)
Event Search(Alarm/Motion/Video Loss), Date/Time Search
Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FB, Forward Frame Advance, Reverse Frame Advance
100(352x288), 50(720x288), 25(720x576, 1CH mode only)
CIF(352x288), Half D1(720x288), D1(720x576, 1CH mode only)
0, 3, 5, 10, 20, 30sec
Single, Quad, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
4 Alarm, 1 Alarm Reset
2 Alarm Out
Off, 5, 10, 20, 30sec
Off, 5,10, 20, 30sec, 1, 3, 5,10, 20min
Area Setting
Ethernet : 10/100 Base T, Static IP,
Dynamic IP(DHCP), ADSL(PPPoE)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
6.5kg
430 x 88 x 400 mm
559 x 517 x 204 mm
Embedded OS
160GB
250GB x 3
for Backup
Max. 250GB, 1EA
4Ch
4Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
6.7KB(352x240), 17.2KB(720x240)
5.0KB(352x240), 13.2KB(720x240)
3.9KB(352x240), 10.0KB(720x240)
2.4KB(352x240), 6.3KB(720x240)
120
720x480
Time Lapse
Event Alarm/Motion/Video Loss Schedule(Time/Date/Camera)
Event Search(Alarm/Motion/Video Loss), Date/Time Search
Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FB, Forward Frame Advance, Reverse Frame Advance
120(352x240), 60(720x240), 30(720x480, 1CH mode only)
CIF(352x240), Half D1(720x240), D1(720x480, 1CH mode only)
0, 3, 5, 10, 20, 30 sec
Single, Quad, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
4 Alarm, 1 Alarm Reset
2 Alarm Out
Off, 5, 10, 20, 30sec
Off, 5,10, 20, 30sec, 1, 3, 5,10, 20min
Area Setting
Ethernet : 10/100 Base T, Static IP,
Dynamic IP(DHCP), ADSL(PPPoE)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
6.5kg
430 x 88 x 400 mm
559 x 517 x 204 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
The SHR-2080 offers 8-channel MPEG4 Digital Video Recorder capable of 120(100)ips recording rate(in CIF mode).
The SHR-2080 also records the 4-channel synchronized audio.
This product can record various kinds of resolution(CIF/Half D1)
Each channel provides various recording rates to save HDD consumption.
External interface methods are USB2.0.
*.CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Samsung Security System l 67
Digital Video Security System Technology
DVR
SHR-2082(P)
SHR-2080(P)
8-Channel Standalone Digital Video Recorder with built-in CD-RW
8-Channel Standalone Digital Video Recorder
Features
• 8 Channel video 120 (100) ips recording capability.
• High picture quality : MPEG4
• Remote monitoring and control through network (LAN)
• Various recording features (Normal, schedule, motion, alarm)
• Recording during replay (Triplex)
• Various N/W environments support(LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
• USB2.0 Interface : USB memory/USB external HDD/USB external CD-RW
• IR remote control feature
Dimensions (unit : mm)
Front Panel
88
400
430
430
Specifications
Operating System
Storage
Internal
Capacity
External
Video
Inputs
Outputs
Basic
Max. Expansion
USB HDD
Composite
Composite Through
Composite
S-Video
VGA
Compression
Compression Rate Very High
High
Standard
Low
Display Speed(images/sec)
Display Resolution
Recording Recording Mode
/Search
Search / PB Mode Search
PB
Recording Speed(Images/sec)
Recording Resolution
Auto Switching
Live Division Screen
Audio
Inputs
Outputs
Compression
Recording
Alarm
Inputs
Outputs
Pre Alarm
Post Alarm
Motion Detection
Network
Backup
USB 2.0
Serial I/F(RS-485)
Watermark
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)mm
68
SHR-2080P
SHR-2080
Embedded OS
160GB
250GB x 4
Max. 250GB, 1EA
8Ch
8Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
10.25KB(352x288), 17.6KB(720x288)
7.75KB(352x288), 13.4KB(720x288)
6KB(352x288), 10.25KB(720x288)
3.75KB(352x288), 6.7KB(720x288)
200
720x576
Time Lapse, Event Alarm/Motion/Video Loss
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Forward Frame Advance
100(352x288), 50(720x288)
CIF(352x288), Half D1(720x288)
0, 3, 5, 10, 20, 30sec
Single, Division(4,6,7,8,9), PIP, Sequence, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
8 Alarm, 1 Alarm Reset
4 Alarm Out
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area Setting
Ethernet : 10/100 Base T, ADSL Static IP
ADSL Dynamic IP(PPPoE), Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
6.9kg
430 x 88 x 400 mm
Embedded OS
160GB
250GB x 4
Max. 250GB, 1EA
8Ch
8Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
8.5KB(352x240), 14.6KB(720x240)
6.4KB(352x240), 11.25KB(720x240)
4KB(352x240), 8.5KB(720x240)
3KB(352x240), 5.4KB(720x240)
240
720x480
Time Lapse, Event Alarm/Motion/Video Loss
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Reverse Frame Advance
120(352x240), 60(720x240)
CIF(352x240), Half D1(720x240)
0, 3, 5, 10, 20, 30sec
Single, Division(4,6,7,8,9), PIP, Sequence, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
8 Alarm, 1 Alarm Reset
4 Alarm Out
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area Setting
Ethernet : 10/100 Base T, ADSL Static IP
ADSL Dynamic IP(PPPoE), Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
6.9kg
430 x 88 x 400 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
The SHR-2082 offers 8-channel MPEG4 Digital Video Recorder capable of 120(100)ips recording rate(in CIF mode).
The SHR-2082 also records the 4-channel synchronized audio.
This product can record various kinds of resolution(CIF/Half D1).
Each channel provides various recording rates to save HDD consumption.
SHR-2082 include CD-RW and external interface methods are USB2.0.
*.CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Samsung Security System l 69
Digital Video Security System Technology
DVR
SHR-2160(P)
SHR-2082(P)
16-Channel Standalone Digital Video Recorder
8-Channel Standalone Digital Video Recorder with built-in CD-RW
Features
• 8 Channel video 120 (100) ips recording capability.
• High picture quality : MPEG4
• Remote monitoring and control through network (LAN)
• Various recording features (Normal, schedule, motion, alarm)
• Recording during replay (Triplex)
• Various N/W environments support(LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
• USB2.0 Interface : USB memory/USB external HDD
• Built in CD-RW • IR remote control feature
Dimensions (unit : mm)
Front Panel
88
400
430
430
Specifications
Operating System
Storage
Internal
Capacity
Video
External
Inputs
Outputs
Basic
Max. Expansion
CD-RW
USB HDD
Composite
Composite Through
Composite
S-Video
VGA
Compression
Compression Rate
Very High
High
Standard
Low
Display Speed(images/sec)
Display Resolution
Recording Recording Mode
/Search
Search / PB Mode Search
PB
Recording Speed(Images/sec)
Recording Resolution
Auto Switching
Live Division Screen
Audio
Inputs
Outputs
Compression
Recording
Alarm
Inputs
Outputs
Pre Alarm
Post Alarm
Motion Detection
Network
Backup
USB 2.0
Serial I/F(RS-485)
Watermark
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)mm
70
SHR-2082P
SHR-2082
Embedded OS
160GB
250GB x 3
for Backup
Max. 250GB, 1EA
8Ch
8Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
10.25KB(352x288), 17.6KB(720x288)
7.75KB(352x288), 13.4KB(720x288)
6KB(352x288), 10.25KB(720x288)
3.75KB(352x288), 6.7KB(720x288)
200
720x576
Time Lapse, Event Alarm/Motion/Video Loss
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Forward Frame Advance
100(352x288), 50(720x288)
CIF(352x288), Half D1(720x288)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9), PIP, Sequence, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
8 Alarm, 1 Alarm Reset
4 Alarm Out
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area Setting
Ethernet : 10/100 Base T, ADSL Static IP
ADSL Dynamic IP(PPPoE), Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
7.8kg
430 x 88 x 400 mm
Embedded OS
160GB
250GB x 3
for Backup
Max. 250GB, 1EA
8Ch
8Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
8.5KB(352x240), 14.6KB(720x240)
6.4KB(352x240), 11.25KB(720x240)
4KB(352x240), 8.5KB(720x240)
3KB(352x240), 5.4KB(720x240)
240
720x480
Time Lapse, Event Alarm/Motion/Video Loss
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Reverse Frame Advance
120(352x240), 60(720x240)
CIF(352x240), Half D1(720x240)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9), PIP, Sequence, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
8 Alarm, 1 Alarm Reset
4 Alarm Out
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area Setting
Ethernet : 10/100 Base T, ADSL Static IP
ADSL Dynamic IP(PPPoE), Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
7.8kg
430 x 88 x 400 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
The SHR-2160 offers 16-channel MPEG4 Digital Video Recorder capable of 120(100)ips recording rate(in CIF mode).
The SHR-2160 also records the 4-channel synchronized audio.
This product can record various kinds of resolution(CIF/Half D1).
Each channel provides various recording rates to save HDD consumption.
External interface methods are USB2.0.
*.CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Samsung Security System l 71
Digital Video Security System Technology
DVR
SHR-2162(P)
SHR-2160(P)
16 Channel Standalone Digital Video Recorder with built-in CD-RW
16-Channel Standalone Digital Video Recorder
Features
• 16 Channel Video 120 (100) ips recording capability.
• High picture quality : MPEG4
• Remote monitoring and control through network (LAN)
• Various recording features (Normal, schedule, motion, alarm)
• Recording during replay (Triplex)
• Various N/W environments support(LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
• USB2.0 Interface : USB memory/USB external HDD/USB external CD-RW
• IR remote control feature
Dimensions (unit : mm)
Front Panel
88
400
430
430
Specifications
SHR-2160P
Operating System
Storage
Internal
Capacity
External
Video
Inputs
Outputs
Basic
Max. Expansion
USB HDD
Composite
Composite Through
Composite
S-Video
VGA
Compression
Compression Rate
Very High
High
Standard
Low
Display Speed(images/sec)
Display Resolution
Recording Recording Mode
/Search
Search / PB Mode Search
PB
Recording Speed(Images/sec)
Recording Resolution
Auto Switching
Live Division Screen
Audio
Inputs
Outputs
Compression
Recording
Alarm
Inputs
Outputs
Pre Alarm
Post Alarm
Motion Detection
Network
Backup
USB 2.0
Serial I/F(RS-485)
Watermark
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)mm
72
SHR-2160
Embedded OS
160GB
250GB x 4
Max. 250GB, 1EA
16Ch
16Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
12.4KB(352x288), 21KB(720x288)
9.4KB(352x288), 16KB(720x288)
7.25KB(352x288), 12.4KB(720x288)
4KB(352x288), 6.7KB(720x288)
400
720x576
Time Lapse, Event Alarm/Motion/Video Loss
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Forward Frame Advance
100(352x288), 50(720x288)
CIF(352x288), Half D1(720x288)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9, 16), PIP, Sequence, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
16 Alarm, 1 Alarm Reset
4 Alarm Out
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area Setting
Ethernet : 10/100 Base T, ADSL Static IP
ADSL Dynamic IP(PPPoE), Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Duplex
AC 100~240V, 50/60Hz
6.9kg
430 x 88 x 400 mm
Embedded OS
160GB
250GB x 4
Max. 250GB, 1EA
16Ch
16Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
10.25KB(352x240), 17.6KB(720x240)
7.6KB(352x240), 13.5KB(720x240)
6KB(352x240), 10.25KB(720x240)
3.75KB(352x240), 6.5KB(720x240)
480
720x480
Time Lapse, Event Alarm/Motion/Video Loss
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Reverse Frame Advance
120(352x240), 60(720x240)
CIF(352x240), Half D1(720x240)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9, 16), PIP, Sequence, x2 Zoom, Freeze
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
16 Alarm, 1 Alarm Reset
4 Alarm Out
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area Setting
Ethernet : 10/100 Base T, ADSL Static IP
ADSL Dynamic IP(PPPoE), Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Duplex
AC 100~240V, 50/60Hz
6.9kg
430 x 88 x 400 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SHR-2162(P) is a 16-channel MPEG4 real time Digital Video Recorder capable of 120(100)ips recording rate in CIF
mode. It can also record the 4-channel synchronized audio and various kinds of resolution (CIF/Half D1).
* CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Each channel provides various recording rates to save HDD consumption.
External interface method is USB 2.0 (Front:1, Rear:1).
SHR-2162(P) includes CD-RW.
Samsung Security System l 73
Digital Video Security System Technology
DVR
SHR-4081(P)
SHR-2162(P)
Real Time 8Ch Standalone Digital Video Recorder
16 Channel Standalone Digital Video Recorder with built-in CD-RW
Features
• 16 Channel video 120 (100) ips recording capability.
• High picture quality : MPEG4
• Remote monitoring and control through network (LAN)
• Various recording features (Normal, schedule, motion, alarm)
• Recording during replay (Triplex)
• Various N/W environments support (LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
• USB 2.0 interface : USB memory/USB external HDD
• IR remote control feature
Dimensions (unit : mm)
Front Panel
88
400
430
430
Specifications
Operating System
Storage
Internal
Capacity
Video
External
Inputs
Outputs
Basic
Max. Expansion
CD-RW
USB HDD
Composite
Composite Through
Composite
S-Video
VGA
Compression
Compression Rate Very High
High
Standard
Low
Display Speed(images/sec)
Display Resolution
Recording Recording Mode
/Search
Search / PB Mode Search
PB
Recording Speed(Images/sec)
Recording Resolution
Auto Switching
Live Division Screen
Audio
Inputs
Outputs
Compression
Recording
Alarm
Inputs
Outputs
Pre Alarm
Post Alarm
Motion Detection
Network
Backup
USB 2.0
Serial I/F(RS-485)
Watermark
Multiplex function
Power Requirements
Weight
Dimensions(WxHxD)mm
74
SHR-2162P
SHR-2162
Embedded OS
160GB
250GB x 3
for Backup
1EA (Max. 250 GB)
16Ch
16Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
12.4KB(352x288), 21KB(720x288)
9.4KB(352x288), 16KB(720x288)
7.25KB(352x288),12.4KB(720x288)
4KB(352x288), 8KB(720x288)
400
720 x 576
Time Lapse, Event Alarm/Motion/Video Loss,
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Data/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Forward Frame Advance
100(352 x 288), 50(720 x 288)
CIF(352 x 288), Half D1(720 x 288)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9, 16), PIP, Sequence, Freeze, x2 Zoom
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
16 Alarm In
4 Alarm Out, 1 Alarm Reset
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area setting
Ethernet : 10/100Base T, ADSL Static IP, ADSL Dynamic IP(PPPoE)
Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
7.8kg
430 x 88 x 400 mm
Embedded OS
160GB
250GB x 3
for Backup
1EA (Max. 250 GB)
16Ch
16Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
10.25KB(352x240), 17.6KB(720x240)
7.6KB(352x240), 13.5KB(720x240)
6KB(352x240), 10.25KB(720x240)
3.75KB(352x240), 6.5KB(720x240)
480
720 x 480
Time Lapse, Event Alarm/Motion/Video Loss,
Schedule(Time/Date/Camera)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Data/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FR, Reverse Frame Advance
120(352 x 240), 60(720 x 240)
CIF(352 x 240), Half D1(720 x 240)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9, 16), PIP, Sequence, Freeze, x2 Zoom
4Ch, RCA
1Ch, RCA
ADPCM
4Ch
16 Alarm In
4 Alarm Out, 1 Alarm Reset
0, 5, 10, 20, 30sec
0, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area setting
Ethernet : 10/100Base T, ADSL Static IP, ADSL Dynamic IP(PPPoE)
Cable Network(Dynamic IP)
Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW, DVD-RW(+R Only)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
7.8kg
430 x 88 x 400 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SHR-4081(P) is a 8-Channel MPEG4 Digital Video Recorder capable of 240 (200)ips recording rate in CIF mode.
It can record 8-channel synchronized audio and various kinds of resolution (CIF/HalfD1/FullD1).
* CIF : 352x240 (352x288)
HalfD1 : 720x240 (720x288)
FullD1 : 720x480 (720x576)
Each channel provides various recording rates to save HDD consumption.
External interface methods are USB2.0 (Front:1, Rear:1) and IEEE1394.
Samsung Security System l 75
Digital Video Security System Technology
DVR
SHR-4160(P)
SHR-4081(P)
16 Channel Standalone Digital Video Recorder
Real Time 8Ch Standalone Digital Video Recorder
Features
• 8 Channel video 240(200)ips recording capability
• High picture quality : MPEG4 Video, G.726 Audio compression
• Remote monitoring and control through network
• Convenient search function with JOG/Shuttle
• Various recording features (Normal, schedule, motion, alarm, video loss, panic)
• Recording during replay (Triplex mode) • Max 4 internal HDD (HDD x 4)
• Backup I/F : USB2.0 (External HDD, Memory, CD-R, CD-RW, DVD+R), IEEE1394 (External HDD)
• Various network environments support(LAN : Static/Dynamic, ADSL : Static/Dynamic(PPPoE))
Dimensions (unit : mm)
Front Panel
400
430
POWER
PTZ
FREEZE
SEARCH
MENU
TELE
WIDE
VIEW
PRESET
REC
ALARM
PANIC
REC LOCK
ZOOM
NETWORK
BACK UP
HDD
88
DIGITAL VIDEO RECORDER SHR-4081
OPEN
430
Specifications
SHR-4081P
SHR-4081
Embedded OS
Basic
160G
Max. Expansion
250G x 4
USB HDD
1EA. (Max. 250GB)
IEEE 1394
Max 6EA (Daisy Chain Connection), Max. HDD size : 1.5TB (250GB x 6)
Composite
Video
8 Ch
Inputs
Composite Through 8 Ch
Composite
2 Ch (Main, Spot)
Outputs
S-Video
1 Ch
VGA
1 Ch
MPEG4
Compression
Compression Rate Very High(Level7,8) 7.3~14.0KB(352x288), 9.8~19.5KB(720x288), 19.5~73.2(720x576)
High(Level5,6)
5.9~12.2KB(352x288), 8.3~17.1KB(720x288), 16.6~48.8(720x576)
Standard(Level3,4) 4.9~9.8KB(352x288), 6.8~14.0KB(720x288), 13.7~39.1(720x576)
Low(Level1,2)
3.9~6.1KB(352x288), 5.1~8.9KB(720x288), 10.7~29.3(720x576)
Display Speed(images/sec)
200
Display Resolution
720 x 576
Recording Recording Mode
Time Lapse, Event(Alarm/Motion/Video Loss),
/Search
Schedule(Time/Date/Camera), Emergency REC(Panic)
Search / PB Mode Search
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
PB
Play, Stop, Pause, FF, FB, Jog, Shuttle
Recording Speed(images/sec)
200(352x288), 100(720x288), 50(720x576)
Recording Resolution
CIF(352x288), Half D1(720x288), Full D1(720x576)
Auto Switching
0, 3, 5, 10, 20, 30sec
Live Division Screen
Single, Division(4,6,7,8,9), PIP, Sequence, Freeze, x2 Zoom
Audio
Inputs
8Ch, RCA
Outputs
1Ch, RCA
Compression
G.726
Recording
8Ch, RCA
Alarm
Inputs
8 Alarm In
Outputs
4 Alarm Out, 1 Alarm Reset
Pre Alarm
Off, 5, 10, 20, 30Sec
Post Alarm
Off, 5, 10, 20, 30Sec, 1, 3, 5, 10, 20min
Motion Detection
Area setting
Network
Ethernet : 10/100 Base T, Static IP
Dynamic IP(DHCP), ADSL(PPPoE)
Backup
USB2.0
Front 1, Rear 1port, External HDD, USB Memory, External CD-RW,
DVD RW(+R Only), IEEE1394(Rear 1port, External HDD
Serial I/F (RS-485)
PTZ Device Control, System Key Board
Watermark
Yes
Multiplex function
Triplex
Power Requirements
AC 100 ~ 240V, 50/60Hz
Weight
6.5Kg
Dimensions(WxHxD)mm
430x88x400 mm
Operating System
Storage
Internal
Capacity
External
76
Embedded OS
160G
250G x 4
1EA. (Max. 250GB)
Max 6EA (Daisy Chain Connection), Max. HDD size : 1.5TB (250GB x 6)
8 Ch
8 Ch
2 Ch (Main, Spot)
1 Ch
1 Ch
MPEG4
6.1~14.0KB(352x240), 8.1~19.5KB(720x240), 16.3~73.2(720x480)
4.9~12.2KB(352x240), 6.9~17.1KB(720x240), 13.8~48.8(720x480)
4.1~9.8KB(352x240), 5.7~14.0KB(720x240), 11.4~39.1(720x480)
3.3~6.1KB(352x240), 4.3~8.9KB(720x240), 9.0~29.3(720x480)
240
720 x 480
Time Lapse, Event(Alarm/Motoin/Video Loss),
Schedule(Time/Date/Camera), Emergency REC(Panic)
Calendar Search, Event Search(Alarm/Motion/Video Loss), Date/Time
Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FB, Jog, Shuttle
240(352x240), 120(720x240), 60(720x480)
CIF(352x240), Half D1(720x240), Full D1(720x480)
0, 3, 5, 10, 20, 30sec
Single, Division(4,6,7,8,9), PIP, Sequence, Freeze, x2 Zoom
8Ch, RCA
1Ch, RCA
G.726
8Ch, RCA
8 Alarm In
4 Alarm Out, 1 Alarm Reset
Off, 5, 10, 20, 30Sec
Off, 5, 10, 20, 30Sec, 1, 3, 5, 10, 20min
Area setting
Ethernet : 10/100 Base T, Static IP
Dynamic IP(DHCP), ADSL(PPPoE)
Front 1,Rear 1port,External HDD,USB Memory,External CD-RW,
DVD RW(+R Only), IEEE1394(Rear 1port, External HDD
PTZ Device Control, System Key Board
Yes
Triplex
AC 100 ~ 240V, 50/60Hz
6.5Kg
430x88x400 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SHR-4160(P) is a 16-channel MPEG4 Digital Video Recorder capable of 360(300)ips recording rate in CIF mode.
It can record 8-channel synchronized audio and various kinds of resolution (CIF/Half D1/Full D1).
* CIF : 352x240(352x288)
Half D1 : 720x240(720x288)
Full D1 : 720x480(720x576)
Each channel provides various recording rates to save HDD consumption.
External interface methods are USB 2.0 (Front:1, Rear:1) and IEEE1394.
Samsung Security System l 77
Digital Video Security System Technology
DVR
SPR-7116(P) / SPR-7416(P)
SHR-4160(P)
16 Channel PC Based Digital Video Recorder
16 Channel Standalone Digital Video Recorder
Features
• 16 Channel video 360 (300) ips recording capability
• High picture quality : MPEG4
• Remote monitoring and control through network (LAN)
• Convenient search function with JOG/Shuttle
• Various recording features (Normal, schedule, motion, alarm, video loss, panic) • Recording during replay (Triplex)
• USB 2.0 Interface : USB memory/USB external HDD/external CD-RW, DVD-RW backup
• Various N/W environments support(LAN : Static/Dynamic, ADSL : Static/Dynamic (PPPoE))
Dimensions (unit : mm)
Front Panel
Rear Panel
400
430
POWER
PTZ
ZOOM+
ZOOM-
FOCUS+
FOCUS_
FREEZE
ALARM
SEARCH
MENU
REC
PANIC
REC
LOCK
ZOOM
NETWORK
ENTER
SET
BACK UP
HDD
88
DVR COMBO SHR-4160
OPEN
430
Specifications
SHR-4160P
Operating System
Storage
Internal
Capacity
External
SHR-4160
Embedded OS
Basic
160GB
Max. Expansion
250GB x 4
USB HDD
1EA. (Max. 250GB)
IEEE 1394
Max. 6EA(Daisy Chain Connection), Max. HDD size : 1.5TB(250GB x 6)
Composite
16Ch
Video
Inputs
Composite Through 16Ch
Composite
2Ch(Main, Spot)
Outputs
S-Video
1Ch
VGA
1Ch
MPEG4
Compression
Compression Rate Very High(Level 7, 8) 7.3~14.0KB(352x288), 9.8~19.5KB(720x288), 19.5~73.2(720x576)
High(Level 6, 5)
5.9~12.2KB(352x288), 8.3~17.1KB(720x288), 16.6~48.8(720x576)
Standard(Level 4, 3) 4.9~9.8KB(352x288), 6.8~14.0KB(720x288), 13.7~39.1(720x576)
Low(Level 2, 1)
3.9~6.1KB(352x288), 5.1~8.9KB(720x288), 10.7~29.3(720x576)
400
Display Speed(images/sec)
720 x 576
Display Resolution
Recording Recording Mode
Time Lapse, Event(Alarm/Motion/Video Loss),
/Search
Schedule(Time/Date/Camera), Emergency REC(Panic)
Search
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Search / PB Mode
Date/Time Search, Go to First/Last Search, Backup Search
PB
Play, Stop, Pause, FF, FB, Jog, Shuttle
300(352 x 288), 200(720 x 288), 100(720 x 576)
Recording Speed(Images/sec)
CIF(352x288), Half D1(720 x 288), Full D1(720 x 576)
Recording Resolution
Auto Switching
0, 3, 5, 10, 20, 30sec
Live Division Screen
Single, Division(4, 6, 7, 8, 9,16), PIP, Sequence, Freeze, x2 Zoom
Audio
8Ch, RCA
Inputs
1Ch, RCA
Outputs
G. 726
Compression
8Ch
Recording
Alarm
16 Alarm In
Inputs
4 Alarm Out, 1 Alarm Reset
Outputs
Off, 5, 10, 20, 30sec
Pre Alarm
Off, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Post Alarm
Motion Detection
Area setting
Network
Ethernet : 10/100 Base T, Static IP,
Dynamic IP(DHCP), ADSL(PPPoE)
Backup
USB2.0(Front 1, Rear 1 port, External HDD, USB Memory, External CD-RW,
DVD-RW(+R Only), IEEE 1394(Rear 1 port, External HDD)
Serial I/F(RS-485)
PTZ Device Control, System Key Board
Watermark
Yes
Multiplex function
Triplex
Power Requirements
AC 100~240V, 50/60Hz
Weight
6.5kg
Dimensions(WxHxD)mm
430 x 88 x 400 mm
559 x 517 x 204 mm
Packing
78
160GB
250GB x 4
1EA. (Max. 250GB)
Max. 6EA(Daisy Chain Connection), Max. HDD size : 1.5TB(250GB x 6)
16Ch
16Ch
2Ch(Main, Spot)
1Ch
1Ch
MPEG4
6.1~14.0KB(352x240), 8.1~19.5KB(720x240), 16.3~73.2(720x480)
4.9~12.2KB(352x240), 6.9~17.1KB(720x240), 13.8~48.8(720x480)
4.1~9.8KB(352x240), 5.7~14.0KB(720x240), 11.4~39.1(720x480)
3.3~6.1KB(352x240), 4.3~8.9KB(720x240), 9.0~29.3(720x480)
480
720 x 480
Time Lapse, Event(Alarm/Motion/Video Loss),
Schedule(Time/Date/Camera), Emergency REC(Panic)
Calendar Search, Event Search(Alarm/Motion/Video Loss),
Date/Time Search, Go to First/Last Search, Backup Search
Play, Stop, Pause, FF, FB, Jog, Shuttle
360(352 x 240), 240(720 x 240), 120(720 x 480)
CIF(352 x 240), Half D1(720 x 240), Full D1(720 x 480)
0, 3, 5, 10, 20, 30sec
Single, Division(4, 6, 7, 8, 9,16), PIP, Sequence, Freeze, x2 Zoom
8Ch, RCA
1Ch, RCA
G. 726
8Ch
16 Alarm In
4 Alarm Out, 1 Alarm Reset
Off, 5, 10, 20, 30sec
Off, 5, 10, 20, 30sec, 1, 3, 5, 10, 20min
Area setting
Ethernet : 10/100 Base T, Static IP,
Dynamic IP(DHCP), ADSL(PPPoE)
USB2.0(Front 1, Rear 1 port, External HDD, USB Memory,
External CD-RW, DVD-RW(+R Only), IEEE 1394(Rear 1 port, External HDD)
PTZ Device Control, System Key Board
Yes
Triplex
AC 100~240V, 50/60Hz
6.5kg
430 x 88 x 400 mm
559 x 517 x 204 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
The SPR series are high-performance 16-Channel digital video recorder capable of 120/480(100/400)ips record rate.
SPR-7416 : in case of 16 camera recording, 30(25) ips record per each camera
Higher recording rate machines(SPR-7416) are suitable for Casino, Bank, Fast-traffic security, Relation to Cashier business.
SPR-7116 : in case of 16 camera recording, 7(6) ips record per each camera Big Market, Shopping Mall, Factory facility,
Apartment Guard business, an Emergency & serious patient room of Hospital. Private Commercial Building, Chain Store
business, Large Parking Building Safety, Hotel(Lobby, Passage)Safety, School(Educational organization) Safety.
SPR series are extremely easy to use through intuitive graphical user interface.
Equipped with a watchdog system, the working status is constantly monitored and self-wake up if any errors is happened.
Compare to conventional analog CCTV system, SPR series offer solutions with high picture quality(no attenuation by
repeatitive recording),advanced search function, efficient alarm handling, remote monitoring & playback by N/W(TCP/IP).
SPR series can control speed dome camera without telemetry keyboard.
By using newly developed motion compression technology, SPR series save HDD expense.
Samsung Security System l 79
Digital Video Security System Technology
VCR
SVR-24PRT/SVR-960(P)RT
SPR-7116(P) / 7416(P)
Real Time Recorder
16 Channel PC Based Digital Video Recorder
Features
- Process multiple images
- Processes image through motion detection
- Select up to 5 areas per image and control its
sensibility.
- Improved image quality (Clear and flexible)
- Zoom in/out
- Adjust brightness, contrast, smooth & sharpness,
search speed, display delay
- Warning sound occurs when there is any movement
- Automatically control 16channel with setup time
- Automatically controls (On/Off) light and siren.
- Display images into 1,4,9,16 split screen or into
panorama
• Recording and search
- Recording schedule by week day, saturday, sun- - Images that were recorded by multiple cameras
can be seen at once
day, and holiday.
- Recording table is configured by data,camera,and time. - It simultaneously records and searches a channel
• Monitoring
- Resolution : 640 x 480, 640 x 240, 320 x 240,
160 x 120
- Ave. compressed file size is the best compression rate worldwide(160 x 120 : 1KB, 320 x 240 :
2.5KB, 640 x 480 : 6KB)
- Multi-channel display with 16 cameras (1,4,6,9,
and 16split screen)
- Multiple recording can be done by each 16 sensors
- Possible to produce several outputs when an
alarm operates
- Watchdog
Dimensions (unit : mm)
with audio.
- When using PTZ camera, it remotely controls
camera's Pan/Tilt/Zoom
- Watermark
- Emergency screen transmission
- Output from External monitor
- Check the original password for security of system
- Stores back up data using HDD, CD-RW, DVD,
network
• Control and monitoring from remote area
- Enable to search images through LAN
- All of 16 sites can connect to the one specific site
at once and it detects, searches, and controls
each site.
- Detects from remote area using LAN
Front Panel
177
431
481
177
431
440
172
177
459
453
Specifications
SPR-7116
Main Spec.
Video Input
Video Output
Recording resolution mode
Recording speed(Frame/sec)
Compression Method
Compression rate
Watermark
Audio Recording
Disaplay mode & Number of
Frame
Auto switching
Playback display mode
Sensor Input
Alarm Output
Motion Detection
Camera/Sensor
Pan/Tilt/Zoom Control
Transmisssion speed
Data backup
Power requirements
Weight
Dimensions
80
SPR-7416
CPU : Intel P-VI 2.8GHz
SDRAM 512MB
VGA : ATI VGA 128MB
LAN : 10 / 100 MB
Built-in CD-RW Drive
O/S : Windows 2000 Professional
16CH Composite Video(NTSC/PAL)
RGB(PC) : 1CH, Composite(Normal Monitor) : 1CH
160x120, 320x240, 640x240, 640x480 (NTSC)
Max. 120/100 ips(NTSC/PAL)
Modified H.263
Average 2.5KB/Frame (320x240: NTSC / 352x288: PAL standard resolution)
Able to check the authentication of the restored image
1CH
1, 4, 9, 16 split screen, full screen, 16CH real time monitoring
480/400 ips (NTSC/PAL)
1~10 seconds
Simultaneously playback each channel from 4,9,16 split screen.
16CH : NO(Normal Open Type) or NC(Normal Close Type)
Output through16CH of NO/NC
Selectable detection sensitivity and area
M : N operation
Pan/Tilt/Zoom Camera control through RS-422 connection
LAN : 120 Frames/sec(Max), ISDN : 3~10 Frames/sec, PTSN : 1~ 5
Frames/sec
Auto/Manual back up through HDD, CD-RW, DVD, Network Drive
AC100~240V, 5Amax, 60Hz
Approx.18Kg
431(W)x177(H)x459(D)
CPU : Intel P-VI 2.8GHz
SDRAM 512MB
VGA : ATI VGA 128MB
LAN : 10 / 100 MB
Built-in CD-RW Drive
O/S : Windows 2000 Professional
16CH Composite Video(NTSC/PAL)
RGB(PC) : 1CH, Composite(Normal Monitor) : 1CH
160x120, 320x240, 640x240, 640x480 (NTSC)
Max. 480/400 ips(NTSC/PAL)
Modified H.263
Average 2.5KB/Frame (320x240: NTSC / 352x288: PAL standard resolution)
Able to check the authentication of the restored image
1CH
1, 4, 9, 16 split screen, full screen, 16CH real time monitoring
480/400 ips (NTSC/PAL)
1~10 seconds
Simultaneously playback each channel from 4,9,16 split screen.
16CH : NO(Normal Open Type) or NC(Normal Close Type)
Output through16CH of NO/NC
Selectable detection sensitivity and area
M : N operation
Pan/Tilt/Zoom Camera control through RS-422 connection
LAN : 120 Frames/sec(Max), ISDN : 3~10 Frames/sec, PTSN : 1~ 5
Frames/sec
Auto/Manual back up through HDD, CD-RW, DVD, Network Drive
AC100~240V, 5Amax, 60Hz
Approx.18Kg
431(W)x177(H)x459(D)
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
Real-Time VCR is a new VCR product capable of capturing more image data through the increased recording density about 3 times higher than the existing Time Lapse VCR.
SVR-24PRT supports three recording modes of 6H, 18H, and 30H on a standard E-180 tape, full-time video recording of 8, 24 or 40 hours can be made without changing the tape. SVR-960(P)RT supports recording modes of L6,
L18, L30H, 72,120, 168, 240, 480, and 950Hr on a standard E-180 (NTSC:T-120) tape, full-time video recording of up
to 40 hours can be made without changing the tape.
For added convenience in control and search, Jog/Shuttle Dial has been implemented to facilitate the fast screen
search,
slow replay, and field-unit control.
Samsung Security System l 81
Digital Video Security System Technology
NETWORK SECURITY
SVR-24PRT/SVR-960(P)RT
Real Time Recorder
Natural image, clear definition
Features
• Alarm recording function : 2Hrs of recording time mode (SVR-24PRT)L6H, L18H, L30H modes (SVR-960(P)RT)
• Built-In time/date generator
• Diamond like carbon head, 4-head
• Super clear picture
• Field/Frame recording function
• Timer recording (with 15 programs for a week (SVR-24PRT))(with 10 programs for a week (SVR-960(P)RT))
• Repeat recording and series recording function
• Power loss memory function
: checks the recording performance (SVR-24PRT)
• Record check function
: saves the last four hours from power failure to recovery (SVR-24PRT)
: checks the recorder to make sure the recording is normally progressing
• Back-Up time : approx. 1year
Front/Rear Panel
286
Dimensions (unit : mm)
430
90.5
430
Specifications
SVR-24PRT
SVR-960(P)RT
Environmental
Conditions
Power Requirements
Rotary Head Helical Scanning System
Rear BNC jack(1.0Vp-p Unbalanced, 75 ohms)
26 µm DA Head(EP Head), Diamond Like Carbon
L6, L18, L30 Modes(E-180)
-8dBm
-8dBm
11.12mm/sec (L6Hr Mode)
REC/RB Speed Mode :
: L6, L18, L30Hr, oooH (E-180)
Series REC, Repeat REC, 1-Shot REC
Less than 100sec(E-180)
JOG/Shuttle Control
Clock Display, Date Display 3-Code
Back-Up Time : 1 year, REC Lock
FLT/LED-Digit : FLT
HSR(FF/REW Time ≤ 100sec)
Auto ATR
Basic Speed : LP
Slow/Still/Reverse Play/Search,
Z-Search(SP/LP) : x5/x7, x9/x15
Field/Advance/Field Slow
Loading Type : Full Loading
Alarm REC/Recoll/Search/LED Display
: High REC
Reset Button, Display Position
: 4-Position, Usage Time, Count memory
Operating Temperature : 5~40°C
Operating Humidity : Less than 80%
AC100~240V, 50Hz
Power Consumption
Weight (kg)
Dimension(WxHxD)mm
Packing
16W
Approx. 4.3Kg
430 x 90.5 x 286 mm
500 x 386 x 198 mm
Rotary Head Helical Scanning System
Rear BNC Jack(1.0Vp-p Unbalanced, 75 ohms)
26 µm DA Head(EP Head), Diamond Like Carbon
L6,L18,L30 Modes(E-160: PAL / T-120:NTSC)
-8dBm, 600
-8dBm
11.12mm/sec (L6Hr Mode)
REC/PB Speed Mode :
L6, L18,L30H, 72,120,168,240,480,960Hr, oooH (E-180:PAL,T-120:NTSC)
Series REC, Repeat REC, 1-shot
Less than 100sec(E-160 : PAL / T-120 : NTSC)
JOG/Shuttle Control
Clock Display, Date Display 3-Code
Back-Up Time : 1 Year, REC Lock
FLT/LED-Digit : FLT
HSR(FF/REW Time ≤ 100sec)
Auto ATR
Basic Speed : NTSC(SLP),PAL(LP)
Slow/Still/Reverse Play/Search,
Z-Search(SP/SLP(NTSC), LP(PAL)) : x5/x7, x9/x15
Field/Advance/Field Slow
Loading Type : Full Loading
Alarm REC/Recoll/Search/LED Display
: High REC(SVR-960NRT), REC-Lock
Reset Button, Display Position
: 4-Position, Usage Time, Count memory
Operating Temperature : 5~40°C
Operating Humidity : Less than 80%
AC100~240V, 50Hz (PAL)
AC120, 60Hz (NTSC,except for Latin America)
16W
Approx. 4.3Kg
430 x 90.5 x 286 mm
500 x 386 x 198 mm
Video
Audio
Tape Speed
Recording System
High Speed Rewind
Control
OSD
Timer
Remain
ATR
Syscon
Alarm
Clock Display
82
Recording Method
Input/Output
Head
Recording Mode
Input (RCA Jack)
Output (RCA Jack)
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Comparison
Chart by Model
VIDEO SERVER
SNT-1010(P)
Network Camera
SNC-L200/L200W
Samsung Security System l 83
Digital Video Security System Technology
NETWORK SECURITY
SNT-1010
VIDEO SERVER
Dual Codec(MPEG-4(ASP), MJPEG), Dual Stream, Video motion detection and pre/post-alarm buffer, E-mail/FTP Transfer, Replay Viewing
Comparison Chart by Model
Models
CAMERAS(SNC-L200)
CAMERAS(SNC-L200W)
Image Sensor
Pan/Tilt Range
Pan/Tilt Speed
Network Connection
Network Service
Image Compression
Video Streaming Format
1/4" 320,000 Pixels CMOS Pixels
1/4" 320,000 Pixels CMOS Pixels
Pan (50 º )/Tilt (40 º Down~ 10 º Up)
Pan (50 º )/Tilt (40 º Down~ 10 º Up)
50/Sec
50/Sec
10/100Base-T
10/100Base-T
Static IP, Cable Modem, ADSL, IP Router
Static IP, Cable Modem, ADSL, IP Router
JPEG
JPEG
M-JPEG
M-JPEG
Models
VIDEO SERVER(SNT-1010)
Spec
Spec
Video Input
Video Output
Audio
Composite 1 Channel
1 BNC (Loop Through Out)
Mono 1 chanel
Bidirectional audio
Network Connection
Network Service
Video Streaming Format
Video resolution(NTSC)
Power Requirement(V)
Power Consumption(W)
Dimensions (WxDxH)
10/100Base-T
Cable Modem, VDSL, ADSL with IP Router, Static IP,DHCP
MPEG-4,M-JPEG
D1:720x480, VGA:640x480, CIF:352x240, QCIF:176x112
DC 8.4V (External Adaptor)
5W
W160 X D136 X H33 mm
Summary
The SNT-1010 is a high-performace, dual codec, dual stream, single input video encoding unit. It compresses the single camera input into two MPEG or MJPEG video and G.711 audio stream data simultaneously.
In addition, it transmits the stream data out through network on realtime basis in order to remotly monitor and record
it repectively.
Pan/tilt/zoom control is done over the serial port, enabling PTZ and dome camera handling over the network.
84
Samsung Security System l 85
Digital Video Security System Technology
NETWORK SECURITY
SNC-L200 / L200W
SNT-1010
Wired Network Camera/Wireless (Wi-Fi) Network Camera
Dual Codec(MPEG-4(ASP), MJPEG), Dual Stream, Video motion detection and pre/post-alarm buffer, E-mail/FTP Transfer, Replay Viewing
Features
• High quality(D1) at 30/25 Images per second
• Simultaneous Motion JPEG and MPEG-4 streams
• Video motion detection and pre/post-alarm buffer
• Video Signal Noise Reduction
• Easy Network Setup such as UPnP function, DDNS
• Support for PTZ and dome cameras
• Bidirectional Audio Support
Dimensions (unit : mm)
160
136
AUDIO
IN OUT
NETWORK STATUS POWER
SNT-1010
VIDEO
IN
OUT
IP
D
Front Panel
33
S
Specifications
Sub-items
Environment
Hardware
Network
Video
Audio
Compression
Video resolution
Server
Client
Flash memory
SDRAM
Ethernet
Network Protocol
IN
OUT
connector
Input/Output
Bidirectional audio
Video
Audio
NTSC
PAL
Frame Rate
Video Quality
Motion Detection
Connection Users
Alarm I/O
Alarm Event
Description
OS
OS
Network Protocol
Streaming
UPnP
DDNS
D1
VGA
CIF
QCIF
D1
VGA
CIF
QCIF
NTSC
PAL
Quality
Sensitivity
Alarm Input
Video Loss
Motion Detection
Schedule
IP installer
Replay Viewing
Software Upgrade
Access Level
IP Notification
Time setting
PTZ control
1CH Recording Playback
Viewer Customizing
SDK
Environmental Conditions
Power
Physical Specification
86
Ip address installation
Firmware upgrade
Login access Level
Dynamic IP Notify
Time setting
Pan/Tilt/Zoom control
Recording/Playback
HTTP API
Application program interface
Windows API
Windows API
Operating Temperature(°C)
Humidity(%)
Power Requirement(V)
Power Consumption(W)
Dimensions (WxDxH)
Weight
Embedded Linux
Windows 2000 / Windows XP
16M byte
64M byte
10/100BASE-T
TCP, UDP, NTP, HTTP, DHCP
TCP, UDP(Unicast, Multicast)
Supporting Auto Network Configuration
Supporting Samsung DDNS and Public DDNS servers
Composite 1 Channel
1 BNC (Loop Through Out) - Auto Termination
3.5 mm jacks
Mono 1 chanel / Mono 1 channel,
Full duplex
MPEG-4, M-JPEG
G.711, 64kbps 8kHz sampling
720x480
640x480
352x240
176x112
720x576
640x576
352x288
176x144
30, 15, 7.5, 3, 1 FPS
25, 12.5, 6.25, 3, 1 FPS
Very High, High, Normal, Low, Very Low
High, Medium, Low
Max 20 Users
Input : 4, Output : 2
PRE / POST Recording : Max 30 sec
Image transfer : FTP, E-mail / Notification : notify to viewer and file server / Alarm Out
Image transfer : FTP, E-mail / Notification : notify to viewer and file server / Alarm Out
Image transfer : FTP, E-mail / Notification : notify to viewer and file server / Alarm Out
Image transfer : FTP, E-mail
IP installation function ( XP, Windows 2000 support )
MJPEG frame buffering for replay Buffering 1~5 image per second
Firmware upgrade by web browser
Guest, Administrator, Operator, User
SMTP(E-mail), FTP
NTP , Time Zone, Summer Time setting
Auto pan, preset, scan function support
Max 10min record can be recorded when PC Hard Disk available space is bigger than 20% of total space
Logo customizing, Banner customizing
Provides functionality to set/retrieve internal parameter values.
ActiveX components for viewing streams from video camera and controlling
0°C ~ +40°C
20% ~ 85% RH
DC8.4V (External Adaptor)
5W
W160 X D136 X H33 mm
0.42KG
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SNC-L200(wired) and SNC-L200W(wireless) are the network cameras which enable surveillance from remote PC
under various networking environments such as ADSL, cable and modem. Its compact design fits to any interior environment. The images shot by these network cameras can be monitored and even Pan/Tilt control can be realized at
remote site through a Multi-viewer designed by Samsung. The camera automatically saves pre/post-images to users
PC when it detects motion and issues an alarm. UPnP function makes it easy for users to set up IP and connect to
network under various networking environments. An easy to install SNC-L200W model adopts IEEE 802.11b for operation under wireless LAN environment.
Samsung Security System l 87
Digital Video Security System Technology
CONTROLLERS
SCQ-041AP
SNC-L200 / L200W
4 Channel Digital Color Quad Switcher
Wired Network Camera/Wireless (Wi-Fi) Network Camera
Features
• 1/4" 320,000 pixels CMOS • Preset function (Max=8)
• Remote Pan/Tilt contol
• Power Pan (±50°) /Tilt (+10° ~ -40°)
• Flash LED for night vision
• PIR Sensor
• Pre Alarm / Auto Alarm
• Privacy function
• UPnP supportable
• Supports various protocol (TCP/IP, UDP, ARP, HTTP, SMTP, FTP, Telnet, DHCP, PPPoE)
• Supports WAP 2.0 (USA)
• IEEE 802.11b (SNC-L200W)
• Remote Recording with Free Multi-Viewer Management Software; Up to 16 CH Recording, 1CH Playback
Dimensions (unit : mm)
Front Panel
63.5
44
75
105
SNC-L200
SNC-L200W
Specifications
Camera
Network & Server
Image Sensor
White Balance
Focus
Min. Scene Illumination
Pan/Tilt Range
Pan/Tilt Speed
Number of Preset
Flash LED-LED Lens Degree
Flash LED-Lux/Range
PIR Sensor-Left/Right
PIR Sensor-Up/Down
PIR Sensor-Range
Network Connection
Network Service
Network Protocol
Image Compression
Video Streaming Format
Resolition
Frame Rate-640x480
Frame Rate-320x240
File Size-640x480
File Size-320x240
File Size-160x120
Authentification
IP Router(AP)-LinkSys
IP Router(AP)-Netgear
IP Router(AP)-D-Link
Simultaneous Viewer
Pre-Alarm
Camera Recording
Frame Rate Control
Free DDNS Compatible
WAP-O.S
WAP-WAP Version
WAP-Browser
WAP-display size
WAP-Video Codec
WAP-Service area
WAP-URL support
Wireless-Protocol
Wireless-Frequency
Wireless-Range
Wireless-Throughput
Power Requirement
Power Consumption
Weight-Net
Dimension(WxHxD)-Net
88
SNC-L200
SNC-L200W
1/4" 320,000 Pixels CMOS Pixels
Auto
Fixed 1m ~ Infinity
1 ~ 10,000 Lux
Pan(50 º Left ~ 50 º Right)/Tilt(40 º Down~ 10 º Up)
50 º /Sec
8 ea
45 º
8 Lux/3 m
40 º
85 º
3m
10/100Base-T
Fixed IP, Cable Modem, ADSL, DHCP, IP Router
TCP/IP, UDP, ARP, HTTP, SMTP, FTP, Telnet, DHCP, PPPoE
JPEG
M-JPEG
640x480, 320x240, 160x120
15 fps
30 fps
12KB(Low), 17KB(Normal), 25KB(High)
4KB(Low), 7KB(Normal), 9KB(High)
2KB(Low), 3KB(Normal), 4KB(High)
ID/Password Authentification
WRT54G
WGR614v4
DI-624+
10 Persons
yes
yes (save on users PC via network)
1.0/5.0/10.0/15.0/30.0 Fps
yes (A free Service that require upgrade)
Embedded Linux
WAP2.0
open browser
160x120, 320x240
M-JPEG
USA
yes
1/4" 320,000 Pixels CMOS Pixels
Auto
Fixed 1m ~ Infinity
1 ~ 10,000 Lux
Pan(50 º Left ~ 50 º Right)/Tilt(40 º Down~ 10 º Up)
50 º /Sec
8 ea
45 º
8 Lux/3 m
40 º
85 º
3m
10/100Base-T
Fixed IP, Cable Modem, ADSL, DHCP, IP Router
TCP/IP, UDP, ARP, HTTP, SMTP, FTP, Telnet, DHCP, PPPoE
JPEG
M-JPEG
640x480, 320x240, 160x120
15 fps
30 fps
12KB(Low), 17KB(Normal), 25KB(High)
4KB(Low), 7KB(Normal), 9KB(High)
2KB(Low), 3KB(Normal), 4KB(High)
ID/Password Authentification
WRT54G
WGR614v4
DI-624+
10 Persons
yes
yes (save on users PC via network)
1.0/5.0/10.0/15.0/30.0 Fps
yes (A free Service that require upgrade)
Embedded Linux
WAP2.0
open browser
160x120, 320x240
M-JPEG
USA
yes
IEEE 802.11b
2.4 Ghz
100 ~ 150 feet
11 Mbps
8.4V DC, 1A
5W
400g
105 x 75 x 63.5 mm
8.4V DC, 1A
5W
400g
105 x 75 x 48 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Summary
SCQ-041AP is a digital 4-screen display device that enables the composite display of up to 4 Video signals from
external devices such as the surveillance camera on a single monitor screen. It enables the initial encryption of up to
8 alphanumeric characters for each channel on a connected monitor screen and allows the wider range of application design by offering the time display, external alarm signal, and remote controlling.
SCQ-041AP is suitable for
- Police station
- Corporate security
- Factory facility
- Apartment guard business
- Department store
- School (Educational organization) safety
Samsung Security System l 89
MEMO
SCQ-041AP
4 Channel Digital Color Quad Switcher
Features
• 4 Channel camera input
• 240 horizontal resolution (quad display only)
• Adjustable date/time display
• Single display mode for each channel
• Automatic channel switch (in auto switcher mode)
• Channel loss detect and alert (buzzer sound and display on the screen)
• Freeze function
• Simultaneous record of quad screen display
• RS-232C remote control
Front/Rear Panel
12 44
350
Dimensions (unit : mm)
430
Specifications
SCQ-041AP
Video
Input
Video Output
Output 1
Output 2
Horizontal Resolution
Remote Control
Alarm/Loss list
Alarm Input
Alarm Output
Memory backup
Reset
Alarm Hold Time
Auto Switcher
Character Indication (OSD)
Title
Date & Time
Alarm Indication
Channel Loss
Video Loss Detection
Quantization Bit number
Sampling of Frequency
Environmental Conditions
Power Requirement
Power Consumption
Weight
Outside Dimension (W x H x D)
Packing
90
Camera 4 Input : 1.0Vp-p, 75Ω Auto Termination,
Loop through output, BNC Type, CVBS
Quad screen only display, 1.0Vp-p, 75Ω, CVBS
User can choose among quad screen display, single screen display and automatic switcher screen display options.
240TV Lines(Quad Display Mode)
Available by using an RS-232C cable.
Saving Max. 8
4 Ch Input
Relay Maked Active, TTL "LOW" Level
*Contact rating(resistive) : 2A, 30V DC or0.5A, 125V AC
More than 1 year
Open Collector “L” Level, Pulse Width + more than 150ms
5,10, 20, 30, 60, 90, 120, 180 seconds, M
(Manual is activated only the moment Alarm inputs)
0 to 30 seconds
User must set time in the menu
Each channel indicates maximum 8 characters
(Alpha-Numeric, Special Characters)
Year/Month/Day/, Hour:Minute:Second
"A"
"LOSS"
4 Channels
8Bit(256 Steps)
28.63636MHz
Operating Temperature : 0°C ~ 40°C
Operating Humidity : 20 ~ 85% RH
AC100~240V, 50Hz
Less than 10W
Approx. 3.8kg(excluding packing materials)
430 x 44 x 350 mm(16.9 x 1.7 x 13.7inch)
500 x 436 x 135 mm
* "P" indicates PAL model & "N" or no specific alphabet after the model name indicates NTSC model.
Samsung Security System
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
