D isp la y S o lu t io n s b y E x per t is e
DI G ITAL DI S P LAY S O LU T I ONS
2009
Digital Display Solutions
Display Solutions by Expertise
Since the mid-90s, the name HYUNDAI has been synonymous with the design and production of state-of-the-art
display technologies. Advanced devices offering sophisticated design and suprerior image quality – with ”builtin” future-proofing.
On the one hand the ongoing process of digitalization leads continuously to new fields of operation for digital displays. On the other hand the technical progress enables new capabilities in development and production. Being an
expert in display solutions HYUNDAI IT with it‘s products brings both together: new requirements from the market
and the new technical prospects from the production side. As a result, there are innovative display solutions which
will revolutionize the display market with state-of-the-art technology, new functions and new designs.
Join us on a voyage of discovery, and explore today what display solutions will be like tomorrow.
HYUNDAI IT : The name of choice for a broad range of future-oriented applications. The technology of tomorrow,
for today’s trend and quality conscious customers. Welcome to the future. Welcome to HYUNDAI IT.
Indoor & Outdoor Public Displays
More and more large-sized digital LCD screens are replacing existing analog display media for the presentation of information
and advertising messages. Combined with a professional “Content Management Software” and attractively created content
these “Digital Signage Systems” are launching to the next generation of public display devices. By using special “Out-OfHome” LCD panels HYUNDAI IT’s indoor and outdoor pubic displays ensure the presentation of digital signage contents in a
sharp, extremely bright picture quality. Meeting all necessary
technical requirements for professional display equipment these
enhanced displays ensure a reliable and failure-free operation in
any kind of indoor or outdoor environment. Providing an integrated video wall function as well as the options for touch screen
functionality and tempered glass surface the HYUNDAI IT DID’s
are the most flexible and versatile visual interface for all kind of
digital signage solution.
Touch Screen Monitors
3D Displays
HYUNDAI IT touch screen monitors combine the conventional
output function with a touch controlled input function. This bidirectional interface makes the screens the easiest solution for
interactive information flow and controlling of systems. Due to
their solid design the monitors are resistant to moisture and
dust and thus ensuring a long lifetime even if they are used for
applications with a high operational demand like public information kiosk systems.
Opening access to another dimension HYUNDAI IT’s 3D displays
provide a new experience in virtual reality. In combination with
professional computer added engineering software, 3D models can
be presented more visual enhancement and are thus closer to reality. Also for the post production of 3D movies and pictures as well
as for PC gaming the new 3D monitors will be the first choice. In
addition to 3D operations the displays can be used as conventional
monitors dealing with standard 2D content without restrictions.
Digital Signage | Outdoor Type
OUTDOOR MEDIA TYPE
OUTDOOR MEDIA TYPE
Enhanced Outdoor Displays for Digital Signage
The market for outdoor digital signage is growing worldwide. Providing different advantages compared
to conventional outdoor advertising media, digital signage will be an interesting media for advertisers,
outdoor media companies, cities and universities in the near future. Its high flexibility and the possibility
of just-in-time content changes makes digital signage the perfect media for reaching target groups in a
society which becomes more and more mobile.
HYUNDAI IT’s outdoor displays represent state-of-the-art display technology for any outdoor environment.
Meeting the highest industrial standards they are provide a high degree of operational reliability and superior quality image, which are important preconditions for attracting the attention of tody's audience.
All Weather Capable
Eqipped with an intelligent cooling and heating system, the outdoor displays are well suited for with standing any weather conditions from -40°C to +50°C.
Sunlight Proof
For installations in environments with the brightest lightning con­
ditions – even bright sunlight – HYUNDAI IT provides special displays which are based on the optical bonding technique. This provides to the advantage that glare and reflection on the screens are
reduced to a minimum while brightness is increased at the same
time. Due to a special coating the screens are protected against
UV radiation, also.
Ultra High Brightness
The displays are built with a backlight that is based on LEDs instead of con­ventional CCFL tubes. This combination enables an
exceptional luminance of over 2500 cd/m² which ensures operation during the day, as well as night.
Model Name
H460S
Screen Size
Display Panel
In order to ensure the highest possible reliability and to keep industrial quality standards the outdoor displays are meeting all requirements of IP 55 as a basic and those of IP65 optionally.
H705S
70“
1018.35 x 572.54 mm
1549.44 x 871.56 mm
Resolution
1366 x 768 (WXGA)
1920 x 1080 (UWXGA)
Aspect Ratio
16 : 9
16 : 9
Display Colors
16.7 Mil
16.7 Mil
Brightness (cd/m 2 ) /(Typ)
Contrast Ratio
2,500
2,000
4,000: 1
2,500:1
8
8
Viewing Angle (H /V )
178 /178
178 /178O
Life Time
30,000h
30,000h
LED
LED
O
Backlight Type
Input
Power
Requirement
O
O
O
VGA
1
1
HDMI
Option
Option
Voltage
Consumption
Auto Cooling System
Set (W X H X L)
1.2KW (Max 3.5KW)
Yes
Yes
27.6” X 58.8” X 8.2”
41.4” x 86.6” x 12.0”
0.45”
0.45”
174.16 lbs.
330.69 lbs.
Powder Coated, Powder Salty
Temperature Operational (O C)
-40/50 (min/max)
-40/50 (min/max)
Temperature Storage (O C)
-20/60 (min/max)
-20/60 (min/max)
Humidity (Non-Cond.) (%)
10 ~ 90
10 ~ 90
Computer
Technical details are subject of changes without further notice. Errors expected.
d
100 ~ 240 VAC
530W (Max 2.0KW)
Powder Coated, Powder Salty
EMI/EMC, Safety / International Protection
w
FCC, CE, cTUVus, TUV, CB / IP55-IP65
Option
h
Weight With Glass
100 ~ 240 VAC
w
h
Tempered Glass Thickness
Surface Treatment Visible Surfaces
Environmental
Conditions
IP 55/IP 65 Conformity
Active Display Area
O
Mechanical
Thanks to a special tempered security glass HYUNDAI IT’s outdoor
displays are protected against any vandalism attacks.
46“
Response Time (ms, GtG)
Connectivity
& ControL
Anti-Vandal Protection
d
Digital Signage | Metal Frame Type
METAL FRAME TYPE
Fields of Operation
METAL FRAME TYPE
According to the advanced product design, the HYUNDAI IT Digital Signage meets all necessary prerequisites to be used for several different kinds of digital signage solutions, such as:
• Information: arrival and departure information at the airport
• Advertising: in-store promotion in retail establishments
• Sales support: last minute offers in travel agencies
• Brand building: brand communication during exhibition & events
• Convenience: digital signage in restaurant waiting areas
• Presentation: conferencing & meeting environments
Special Out-Of-Home LCD Panel
By using commercial grade LCD panels for Out-OfHome applications the HYUNDAI IT Digital Signage
has a higher brightness and contrast than standard LCD TV panels. Our LCD panels enable you to
operate for During working time and
deliver clear and bright images in either the portrait or landscape format
without any losses of quality.
Fast Response Time
A fast response time of 8ms ensures the displaying of a clear
image quality without ghosting effects for fast moving video or
image contents.
High Connectivity
Providing an array of various professional input and output
connectors [HDMI, DVI, Component /Composite (BNC), VGA]
HYUNDAI IT Digital Signage provides an easy, and flexible choice
for connection to a full range of external A/V devices.
High Luminance & Contrast
Achieving a luminance of up to 700 cd/m² and working with a
smart dynamic contrast technology, the special Out-Of-Home panels ensure bright and sharp pictures with a facsimile depth, even
in brightly lighted environments.
Heat Control & Auto Cooling System
Regular LCD TV Panel
RS-232C Interface
HYUNDAI IT Out-Of-Home Panel
Metal Frame Housing
The HYUNDAI IT Digital Signage has a solid metal frame housing.
This ensures that the panel is well protected especially for public
area installations. In addition the metal frame gives the product a
high quality appearance.
Ultra-High Native Resolution
With a native resolution of 1366 x 768, HYUNDAI IT Digital Signage can display high-resolution data information on the LCD
screen with an aspect ratio of 16:9. The native HD
resolution ensures brighter and sharper images
when HD graphics and videos are displayed.
Wide Viewing Angle
The wider the panel’s viewing angle is the more viewers are able
to see the contents being displayed. This is important for both
meeting for both meeting environments
as well as public area installations. Having a wide vewing angle of 178° (h/v)
HYUNDAI IT Digital Signage brings the
displayed to the entire audience.
In order to avoid any image corruption or downtime by overheating HYUNDAI IT Digital Signage is equipped with an innovative
built-in fan & heat control system. This makes the display ready
for operation in any climatic environment.
For easy set-up and maintenance the built-in RS-232C port allows
the remote controlling and configuration of the display’s functions.
Wall Mounting
Industry standard Wall-Mounting holes in the rear of the cabinet
ensure compatibility and easy installation with universal wallmounting brackets.
Environment-Friendly
Being compliant with the European RoHS directive and working
with low power consumption during operation
and power saving mode (< 1W) the HYUNDAI
IT Digital Signage is very energy efficient.
Digital Signage | Special Features
SPECIAL FEATURES
SPECIAL FEATURES
Built-In Video Wall Function
Due to the built-in multi display wall function, the HYUNDAI IT Public Displays are well suited for
installing video wall configurations including up to 5 by 5 single units. In light of this, no additional
expensive equipment like video split processors are necessary.
Samples of Multi Display Wall Configurations
Daisy Chain Connection
In order to setup a multi display wall, the single units are linked
by a Daisy Chain connection over HDMI, Component or the
D-Sub interface. That implicates the advantage that just one
display (master unit) needs a direct connection to the video
source. The configuration of each display, regarding an individual
ID and its position in the wall matrix, can be easily set-up over the
on-screen menu or the RS232C interface. With all its advantages
the built-in type multi display wall function allows a flexible configuration and an easy installation.
SOURCE
HDMI/DVI
Component
D-Sub
Daisy Chain
Connection
Ultra Slim Bezel Design
Coping with an ultra slim bezel design the HYUNDAI IT Public
Displays are the ideal choice for the operation in video wall con­
figurations. Combined with the cutting edge function – which
allows displaying the full picture content – the smart design of the
HYUNDAI Public Displays ensure a maximum screen area with
unified images and a minimum of viewable interruptions.
Touch Screen Function (Option)
As an option, all HYUNDAI IT Public Displays can be equipped
with touch screen functionality. According to screen size and the
kind of application, two different touch screen technologies are
used: either the infrared ray matrix or infrared ray sensor technology. That makes the HYUNDAI IT Public Displays’s an versatile
touch screen product for interactive applications.
1.0 Inch
Type
Application
Light Transmission
Infrared (Matrix)
Graphics Intensive, Severe Duty,
Mission Critical Applications
92~100%
Response Time
16ms
Touch Accuracy
98.5~99%
Environment
Indoor/Outdoor
Operating Temp
-41°C ~ +70°C
Life
Surface Hardness
Input Mode
Function
Size
Usage
Tested to perform over 100 million
touc hes on a single point
5mm with Anti-Vandal
Bare or gloved finger, stylus, pen etc., any object that blocks light
Senses interruption of invisible
infrared array. Fully ADA compliant.
24” ~ 82”
Large Screen, DID
Technical details are subject of changes without further notice. Errors expected.
Tempered Security Glass (Option)
In order to protect the displays against vandal attacks and thus
avoiding additional costs during the operational period it is possible to cover the screens with a tempered security glass. Combined
with the ability to lock the keys for the on-screen menu and the
solid metal frame housing the HYUNDAI Public Displays are the
perfect visual equipment for the usage in high frequented public
areas.
Indoor Public Displays | Special Features
Wide View Displays
Wide view displays are characterized by their special aspect
ratio whose height is less than half of its width. This brings the
benefit that the wide view displays will fit into places where
displays with a regular height can’t be installed. For example
into the space between door and ceiling as well as installations in metros and trams are practical locations where these
solutions are used as signage or advertising displays.
Semi-Outdoor Displays (Optical Bonding)
For installations in environments with brightest lightning conditions –
even bright sunlight – HYUNDAI IT provides special displays which are
based on the optical bonding technique. This leads to the advantage that
glare and reflection on the screens are reduced to a minimum while brightness is increased at the same time. Due to a special coating the screens are
protected against UV radiation, too. A digital signage screen behind a shop
window which is regarded from the outdoor area is a typical application
field for this special solution.
Built-in MMP | Specification
Display
Video Output (Analog)
DivX 3.11,4.12,5.x | DivX prd, Xvid
Movie
MPEG4 SP | MPEG 1/2/4 ASP Support
Motion JPEG
720P
Yes
Yes
[email protected]
Audio(Music)
MPE,WMA | DOLBY AC3
USB
USB 1.1 FS (Host) | USB 2.0 HS (Host)
Yes
Multi Socket | CF Type II
4 in 1 | yes
Memory Socket
Compact Flash Card | Microdrive/ST1 Driver (CF Type II)
XD-Picture | Multi-Media Card | Secure Digital Card
Memory Stick/Duo | Memory Stick Pro/Duo
Subtitle | OSD Language
Interface
Video | Audio Output
Input Voltage
Merit
Technical details are subject of changes without further notice. Errors expected.
Yes
Yes
Yes | Yes | Yes
Yes | Yes
SMI,SRT,SSA,SUB | 11 languages
I2C
YPbPr | L,R
5V / 1.5A
Auto play, Play list
All-In-One Displays
HYUNDAI IT’s all-in-one
displays are combining
public display and built-in
player functionality. Being
equipped with a builtin PC, a set-top box or a
multi media player (MMP),
these all-in-one displays
enable easy installations
without any additional AV
equipment.
D405ML
D400ML
D420ML
D465ML
D460ML
(700 nit)
D460ML
(1500 nit)
D525ML
D575ML
D705ML
40“
40“
42“
46“
46“
46“
52“
57“
70“
Active Display Area (mm)
885.6 x 498.15
885.17 x 497.66
930.3 x 523.0
Number of Pixels
1920 x 1080
(WUXGA)
1366 x 768
(WXGA)
1366 x 768
(WXGA)
1920 x 1080
(WUXGA)
1366 x 768
(WXGA)
1366 x 768
(WXGA)
1920 x 1080
(WUXGA)
1920 x 1080
(WUXGA)
1920 x 1080
(WUXGA)
16:9
16:9
16:9
16:9
16:9
16:9
16:9
16:9
16:9
Model
Screen Size
Aspect Ratio
Display
Panel
Resolution
Input
Output
Display Colors
1018.08 x 572.67 1018.35 x 572.54 1018.35 x 572.54
1152 x 648
1251.36 x 703.89 1549.44 x 871.56
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
450 cd/m2
700 cd/m2
500 cd/m2
450 cd/m2
700 cd/m2
1,500 cd/m2
600 cd/m2
600 cd/m2
600 cd/m2
Contrast Ratio
4,000:1
2,000:1
800:1
4,000:1
2,000:1
3,000:1
1,700:1
2,000:1
1,500:1
Response Time
8 ms
8 ms
9 ms
8 ms
8 ms
8 ms
8 ms
8 ms
8 ms
Viewing Angle
178O/178O
178O/178O
178O/178O
178O/178O
178O/178O
180O/180O
178O/178O
178O/178O
178O/178O
Brightness (Typ)
Lifetime
50,000h
50,000h
50,000h
50,000h
50,000h
50,000h
50,000h
50,000h
50,000h
Monitor
1920 x 1080
1360 x 768
1360 x 768
1920 x 1080
1360 x 768
1360 x 768
1920 x 1080
1920 x 1080
1920 x 1080
1080p
1080i
( Multi Screen:
720p )
1080i
1080p
1080i
( Multi Screen
: 720p )
1080i
1080p
1080p
1080p
RGB (D-Sub)
1
1
1
1
1
1
1
1
1
HDMI
1
1
1
1
1
1
1
1
1
CVBS (BNC)
1
1
1
1
1
1
1
1
1
Component (BNC)
1
1
1
1
1
1
1
1
1
PC Audio
1
1
1
1
1
1
1
1
1
Component Audio
1
1
1
1
1
1
1
1
1
Composite Audio
1
1
1
1
1
1
1
1
1
RGB (D-Sub)
1
1
1
1
1
1
1
1
1
DTV
DVI (HDMI connector)
1
1
1
1
1
1
1
1
1
Composite (BNC)
1
1
1
1
1
1
1
1
1
Component (BNC)
1
1
1
1
1
1
1
1
1
RS232C
1
1
1
1
1
1
1
1
1
Speaker
1
1
1
1
1
1
1
1
1
Multi-screen Function (Loop)
HDMI, VGA (15pin D-Sub), Component (BNC), Composite (BNC)
OSD Language
Input Voltage
10 Lang (GB / DE / FR / ES / IT / PT / SE / DK / FI)
100~240VAC
100~240VAC
100~240VAC
100~240VAC
100~240VAC
100~240VAC
100~240VAC
100~240VAC
100~240VAC
200W
200W
200W
260W
260W
300W
320W
460 W
900 W
1
1
1
1
1
1
1
2
3
Auto Power Control (DPMS)
Option
Option
Option
Option
Option
Option
Option
Option
Option
Tempered Glass
Option
Option
Option
Option
Option
Option
Option
Option
Option
Touch Screen
Option
Option
Option
Option
Option
Option
Option
Option
Option
400 x 200
400 x 200
600 x 200,
600 x 400
600 x 200,
600 x 400
600 x 200,
600 x 400
600 x 200,
600 x 400
600 x 200,
600 x 400
600 x 200,
600 x 400
1200 (600) x 600
38.9 x 22.9 x 4.7
44.2 x 25.9 x 4.9
41.4 x 23.8 x 4.8
41.4 x 23.8 x 4.8
29.4 x 27.3 x 5.1
52.5 x 30.3 x 5.1
66.3 x 40 x 5.8
-
-
-
Power Consumption (typ)
Auto Cooling System
Feature
Wall Mounting Hole
(WxH mm)
Dimension Set (W x H x L)
(Inch)
Packed (WxDxH)
Weight
(With out
Glass)
37.7 x 21.9 x 118 36.1 x 20.8 x 4.8
41.1 x 10.1 x 26.4 41.1 x 10.1 x 26.4 44.1 x 10.1 x 28.5 46.6 x 10.1 x 29.4 46.6 x 10.1x 29.4 46.6 x 10.1 x 29.4
Set (lbs.)
63.9
61.7
70.5
83.8
80.5
80.5
101.9
171.5
209.4 lbs.
Packed (lbs.)
73.9
71.6
80.5
94.8
91.5
91.5
118.8
186.9
TBD
Approvals EMI/EMC, Safety
FCC, CE, cTUVus, TUV, CB
Temperature
0 OC - 40 OC
Humidity
20% - 80%
Accessories
Technical details are subject of changes without further notice. Errors expected.
Power cord, Manual, HDMI Cable, Remocon
Digital Signage | Stand Alone Type
STAND ALONE TYPE
STAND ALONE TYPE
Versatile Single Screen Information Signage
The HYUNDAI IT Stand-Alone Public Displays are the best solution for single screen information signage. Combining dynamic screen contents and the static depiction of your corporate identity the Stand-Alone Public
Displays are bringing the maximum brand communication to your customers. Exhibitions, hotel and offices
lobbies, customer waiting areas and retail shops are some examples for versatile fields of operation.
Like all HYUNDAI IT Public Displays products, the Stand-Alone Type is equipped with an Out-Of-Home LCD
Panel which brings the advantages of 24/7 operation, with high contrast and brightness as well as the
opportunity of using the panel in portrait or landscape format.
Flexible Content Management
Providing sufficient space in the cabinet and the availability of a
variety of video connectors the HYUNDAI IT Stand-Alone Public
Displays can be equipped with a PC or any other AV player. In
combination with digital signage software and the opportunity to
update the contents via LAN, WLAN or 3G the Stand-Alone Public
Displays are the easiest and most cost effective way to deliver
your messages to your target audience.
Full Protection
ITEM
In order to protect the high-tech components and ensure
a long life the housing is made of steel and can be locked.
The panel is protected by a special tempered glass which
supports a clear image of the screen contents.
Active Display Area (mm)
Number of Pixels
Panel
1920 x 1080 (WUXGA)
16:9
16.7 Mil.
Brightness
Resolution (Max)
Input
Connectivity
& Control
Output
Monitor
DTV
2
600 cd/m
2000:1
1700:1
8
8
178O / 178O
178O / 178O
50,000h
50,000h
1366 x 768
1920 x 1080
1080i
1080p
1
1
HDMI
1
1
Composite (BNC)
1
1
Component (BNC)
1
1
PC Audio
1
1
Component Audio
1
1
Composite Audio
1
1
RS232C
1
1
Analog RGB
1
1
HDMI
1
1
Composite (BNC)
1
1
Component (BNC)
1
1
RS232C
1
1
15W x 2ch
15W x 2ch
Yes
Yes
Auto Cooling System
Auto Power Control (DPMS)
Input Voltage
Consumption (typ)
Tempered Glass
Touch Screen (Option)
OSD Language
Approvals EMI/EMC, Safety
Dimension Set (WxHxL)
(Inch)
Stand Included (WxHxL)
Set Weight (lbs.)
2
700 cd/m
Analog RGB
Speaker (Ready)
Accessories
1366 x 768 (WXGA)
16.7 Mil.
Life Time
Feature
1152 x 648
Display Colors
View Angle (H/V)
Power
52”
1018.35 x 572.54
16:9
Response Time (ms)
Easy Individualization
D525SL I D525SLI
46”
Aspect Ratio
Contrast Ratio
Touch Screen Function (Option)
The Stand-Alone Public Displays are available as touch screen models. The infrared touch screen technology ensures ease of use, and
makes them ready for your interactive applications.
D460SL I D460SLI
Screen Size
Yes
Yes
100 - 240 VAC
100 - 240 VAC
260 W
320 W
Yes
Yes
IR Touch
IR Touch
10 Language (GB, DE, FR, ES, IT, PT, SE, DK, FI)
FCC, CE, cTUVus, TUV, CB
27.0” x 82.8” x 5.0”
30.6” x 82.8” x 6.8”
27.4” x 86.6” x 21.3”
30.9” x 86.6” x 21.3”
242.5
264.6
Power cord, Manual,
VGA/Audio Cable,
Remocon
Power cord, Manual,
VGA/DVI to HDMI/
Audio Cable, Remocon
Technical details are subject of changes without further notice. Errors expected.
Stereoscopic 3D Displays
STEREOSCOPIC 3D DISPLAYS
STEREOSCOPIC 3D DISPLAYS
Experience Real 3D Visuals with
Hyundai Widescreen 3D Display
In addition to conventional 2D operations HYUNDAI IT’s stereoscopic
3D displays make it possible to viewing 3D images with a breathtaking
three-dimensional effect. For example, 3D models created with CAD
software can be displayed more life like and thus allowing a presentation close to reality. Beside professional applications, Hyundai 3D displays are great for multimedia operation such as 3D games, movies or
pictures.
Hyundai 3D Monitor
W220S/W240S
Hyundai 3D Monitor S320D/S465D
Enjoy Real 3D Image with Hyundai IT Stereoscopic 3D Displays
Based on the stereoscopic 3D technology, the viewer is watching the 3D
contents through a polarized 3D display by wearing polarized 3D glasses.
A stereoscopic image presents the left and right eyes of the viewer with
different perspective viewpoints, just as the viewer sees the visual world.
From these two slightly different views, the eye-brain synthesizes an image of the world with stereoscopic depth.
Key Features
3D Software Package
• Moire, ghosting and flicker free
• High contrast ratio and fast response time
• HDMI with HDCP support
• Wide viewing angle
• Certified for Windows Vista
HYUNDAI IT’s 3D display include a software
package of the leading 3D software supplier
DDD.
This 3D software supports 3D drivers for
more than 64 PC Game titles through the
website.
• 3D Media Player • 3D Experience
• 3D Google Earth • 3D games driver
3D Visualizer/OpenGL driver(Option)
3D Visualizer enables selected third party
applications to work on HYUNDAI IT’s 3D
displays. Using 3D displays and 3D Visualizer,
3D models appear to have a real physical
depth, just like the actual objects they are
modelling.
(ex.) Side by Side format image
For more information on DDD’s TriDef software please visit http://www.tridef.com
Recommended System Requirements
Recognition of
left eye’s image.
Recognition of
right eye’s image.
- Intel® Core 2 Duo or Athlon™ 64 x 2 Dual-Core CPU, 1GB RAM
- NVIDIA® GeForce 6600 or ATI Radeon™ X800 with DVI output
- 100MB free disk space - Windows® XP, Vista 32-bit
- DirectX 9.0c compatible sound card
Circular Polarized Glass
Specifications
Model Name
Filter
Compatibility
3d Format
3D
Technology
Viewing Angle (H/V)
Supported 3d Resolution
Conversion
Viewing Distance (Recom.)
2D/3D compatible
2D/3D compatible
2D/3D compatible
2D/3D compatible
Horizontal interlaced
Horizontal interlaced
Horizontal interlaced
Horizontal interlaced
160°/10°
160°/10°
178°/ 20°( typ. CR:10)
178 O /20 O (typ. CR:10)
1680 x 1050
1920 x 1200
1360 x 768
1920 x 1080
2D/3D image convertible
2D/3D Image convertible
2D/3D Image convertible
2D/3D Image convertible
2.3 ft or 27.6 inch
5 ft
5 ft
A-Si TFT Active Matrix
A-Si TFT Active Matrix
22“ / 473.7 x 296.1 mm
24“ / 518.4 x 324 mm
32” / 697.6845 x 392.256 mm
46“ / 1018.4 x 572.5 mm
16:10
16:10
16:9
16:9
0.282 x 0.282 mm
0.270 x 0.270 mm
0.510 x 0.510 mm
0.530 x 0.530 mm
160O / 160O (CR:<=10)
178O / 178O (CR:<=10)
178 O / 178 O (CR:<=10)
178 O / 178 O (CR:<=10)
Contrast Ratio
1,000:1 / 10,000:1 (DCR)
1,000:1 / 10,000:1 (DCR)
3,000:1 / 6,000:1( DCR)
3,000:1 / 6,000:1 (DCR)
Response Time
5 ms (typical)
6 ms (typical)
8 ms ( G to G)
6 ms (typical)
300 cd/m 2 (typical)
500 cd/m 2 (typical)
500 cd/m 2 (typical)
500 cd/m 2 (typical)
Pixel Pitch (H/V)
Viewing Angle (H/V)
Brightness
Colors
Maximum / Recommended
Video
16.7 M
16.7 M
16.7 Mi
16.7 M
1680 x 1050 @ 60Hz
1920 x 1200 @ 60Hz
1360 x 768 @60Hz
1920 x 1080 @ 60Hz
480i/p, 576i/p, 720p, 1080i/p
480p, 576p, 720p, 1080i/p
480p, 576p, 720p, 1080i/p
480i/p, 576i/p, 720p, 1080i
Analog RGB / DVI-D
1/1
1/1
1/-
1/-
HDMI-HDCP / Component
1/-
1/1
1/1
1/1
S-Video/Composite
-/-
-/-
1/1
1/1
PC Audio
Yes
Yes
Yes
Yes
VESA DDC 2B
VESA DDC 2B
VESA DDC 2B
VESA DDC 2B
VESA DPMS
VESA DPMS
VESA DPMS
VESA DPMS
100-240V AC 2.0A / 45W(typ) /
Internal Power Supply
100-240V AC 2.0A / 85W(typ) /
Internal Power Supply
100-240V AC 5.0A / 150W(typ) /
Internal Power Supply
100-240V AC 5.0A / 230W(typ) /
Internal Power Supply
cTUVus, CB, EK, PSE, FCC, CE, VCCI, Energy Star
cTUVus, CB, FCC, CE
cTUVus, CB, FCC, CE
Internal loudspeaker 2 x 3 Watt, PC Audio in/out
Max. 10W x 2ch
Max. 10W x 2ch
Yes | Yes (200 x 100 mm)
Yes | Yes (580 x 420 mm)
Plug-and-Play
Power Management
Power
S465D
Circular polarized filter
A-Si TFT Active Matrix
Size: Diagonale / Display Area (H/V)
Input Signal
S320D
Circular polarized filter
2.3 ft or 27.6 inch
Aspect Ratio
Resolution
W240S
Circular polarized filter
A-Si TFT Active Matrix
Type
Panel
W220S
Circular polarized filter
Voltage / Consumption / Type
Safety & Regulations
Other
Features
Audio System
Stand
Type
Dimensions
Unit / Packed (W X H X D)
Weight
Unit / Packed
Kensington Slot / Wallmount Holes
Scope of Accessories
Yes | Yes (VESA: 100 x 100 mm)
Yes | Yes (VESA: 100 x 100 mm)
Tiltable, Height adjustable (option)
Tiltable, Height adjustable (option)
Tiltable
Tiltable
20.5“ x 16.2“ x 8.3“ / 24.2“ x 18.9“ x 7.7“
22.8“ x 17.9“ x 9.4“ / 26.7“ x 21.4“ x 8.1“
31.7“ x 24.3“ x 9.1“ / 35.5“ x 28.2“ x 11.9“
45“ x 33.2“ x 13.7“ / 50“ x 38.3“ x 17.8“
15.43 lbs. / 20.50 lbs.
21.82 lbs. / 30.42 lbs.
37.47 lbs. / 46.07 lbs.
66.13 lbs. / 85.31 lbs.
Power cable, DVI Cable, D-Sub Cable, Audio Cable, Quick Installation guide, 3D glasses, HDMI-DVI Cable ( S320D, S465D only ), CD-ROM : User manual, Driver, ICM profil, 3D software package
Technical details are subject of changes without further notice. Errors expected.
Premium LCD Monitor / Touch Screen Displays
PREMIUM LCD MONITOR
PREMIUM LCD MONITOR
Hight Definition Multimedia Interfact
More ergonomically designed stand
Higher resolution-Over 400% greater resolution than 720p HDTV
You are able to adjust the height, pivot, tilt and swivel of the moni-
for greater detail and lager display size. Higher refresh rates(up to
tor to make sure for your most comfortable position.
120Hz) for smoother motion, less blurring and better gaming (faster
response time) Deep Color-increasing the deep color from millions
Dynamic Contrast Ratio
to billions of color for smoother images and higher contrast ratio.
Measure of a display system, defined as the ratio of the luminance of
2ms Response time
Response time (milliseconds) is the time that it the pixels to turn
the brightest color (white) to that of the darkest color (black) that
the system is capable of producing.
from grey to grey or black to black.
Easy functions
The lower the response time, the faster the speed and the less blur-
Built in Speaker & Automatic adjustment function.
ring when you are watching fast moving video files or games.
Get in Touch with a New Interface
The HYUNDAI IT LCD touch screen monitors combine the newest touch screen technology and timeless design with an optimal price-performance ratio. They can be used for applications
in areas like POS, medical or monitoring & control.
Key Features
• reliable functionality thanks to 5-wire resistive touch screen
technology
• robust design by hard surface (3H) and well ruggd dual hinge stand
• sharp and brilliant pictures by high contrast and brightness
TOUCH SCREEN DISPLAYS
Model Name
Type
Touch Screen
Technology
USB 1.1
>81% (550nm wavelength, According to JIS-K7105)
>81% (550nm wavelength, According to JIS-K7105)
35 ms (max.)
35 ms (max.)
Bare Or Gloved Finger, Stylus Pen, Finger
Bare Or Gloved Finger, Stylus Pen, Finger
Type
A-Si TFT Active Matrix
A-Si TFT Active Matrix
Size
17inch Diagonal
19inch Diagonal
160° / 160° (horizontal / vertical)
160° / 160° (horizontal / vertical)
0,264 mm (W x H)
0,294 mm (W x H)
Pixel Pitch
Contrast Ratio
Luminance
Response Time
Colors
5ms
5ms
16.7 M
Maximal
1280 x 1024 @ 75 Hz
1280 x 1024 @ 75 Hz
Recommended
1280 x 1024 @ 60 Hz
1280 x 1024 @ 60 Hz
Analog
15-pin D-Sub
15-pin D-Sub
Digital
24-pin DVI-D
24-pin DVI-D
Horizontal
31k ~ 80 kHz
31k ~ 80 kHz
Vertical
Source
Consumption (Typ.)
Type
Other
Features
300 cd/m2 (typical)
376.3(H) x 301.1(V) mm
Power Management
Safety &
Regulations
1,000:1 (typical)
300 cd/m2 (typical)
16.7 M
Plug-and-Play
Power
1,000:1 (typical)
337.9(H) x 270.3(V) mm
Active Display Size( H x V)
Scanning
Frequency
5-Wire Resistive / Capacitive
Light Transmission
Viewing Angle
Input Signal
5-Wire Resistive / Capacitive
USB 1.1
Input Mode
Resolution
G90TR
Controller Interface
Response Time (Touch)
Panel
G70TR
Standard
56 ~ 76 Hz
56 ~ 76 Hz
VESA DDC 1/2B (EDID 1.3)
VESA DDC 1/2B (EDID 1.3)
VESA DPMS
VESA DPMS
100 ~ 240VAC 1.5Arms
100 ~ 240VAC 1.5Arms
32W
36W
Adaptor
Adaptor
NRTL, CB, TUV-GS, FCC, CE
NRTL, CB, TUV-GS, FCC, CE
RoHS , WEEE
RoHS, WEEE
RoHS, WEEE
Audio System
2 W X 2ch/Earphone Jack
2 W X 2ch/Earphone Jack
Kensington Slot
Yes
Yes
Wallmounting Holes
VESA: 75 x 75mm
VESA: 100 x 100mm
Stand
Dual Hinge Stand
Sustaining Stand
15.0“ x 15.9“ x 7.9“ | 17.1“ x 14.9“ x 5.5“
16.7“ x 13.6“ x 2.0“ | 18.6“ x 16.0“ x 6.2“
10.91 lbs. | 14.11 lbs.
11.02 lbs | 15.21 lbs
Dimensions
Unit | Packed (W X H X D)
Weight
Unit | Packed
Technical details are subject of changes without further notice. Errors expected.
Corporate Information
The HYUNDAI IT Story
HYUNDAI Electronics first set up a monitor division at its
electronics corporation in 1984. After launching the first
monochrome monitor, HYUNDAI continuously developed
its product range, rapidly expanding in expanding production to over 1 million units per year. HYUNDAI has
been a leading manufacturer of TFT displays in a variety
of sizes starting in the mid-1990s. In 2000, the monitor division
became a seperate company from the parent corporation
to become what is today Hyundai IT Corp. and associated
with 3 sales offices in Europe(HYUNDAI IT Europe GmbH),
USA(HYUNDAI IT Amrica Corp.) and Japan(HYUNDAI IT Japan.)
Full Product Portfolio
Being an expert in digital display solutions, HYUNDAI IT is offering a full range of products for both consumer as well as
professional customers:
LCD Monitor
Monitor + TV
3D Monitor
Touch Screen Monitor
LCD TV
3D LCD TV
Indoor Public Displays
Stand-Alone Type
Outdoor Public Displays
Display Solutions by Expertise
HEAD OFFICE - HYUNDAI IT CORP.
HYUNDAI IT AMERICA CORP.
San 136-1, Ami-ri, Bubal-eub, Ichon-si,
Kyungki-do, 467-701, The Republic of Korea
Tel. +82 31 639 8560 Fax. +82 31 636 4231
email : [email protected]
www.hyundaiIT.com
2051 Junction AVE., Suite 112
San Jose, CA 95131, USA
Tel. +1 408 954 8920 Fax. +1 408 954 8924
email : [email protected]
www.hyundaiIT.com
HYUNDAI IT EUROPE GmbH
HYUNDAI IT JAPAN
Geheimrat-Hummel-Platz 2 65239
Hochheim, Germany
Tel. +49 6146 904 0 Fax. +49 6146 904 110
email : [email protected]
www.hyundaiIT.eu
www.hyund aiI T .c om
Sunbridge Ogawamachi Bldg 4F, 2-2
Ogawamachi Kanda Chiyoda-Ku, Tokyo, Japan
Tel. +81 3 5259 7645 Fax. +81 3 5259 7559
email : [email protected]
www.hyundaiIT.jp
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
