UK Retail Catalogue
2016-2017
retail catalogue I UK I £
www.audio-technica.com
Search & Filter Products
Compare Products
Check Product Pricing
Watch Latest Product Videos
Find Out ‘Where To Buy’
Find Service, Support & Warranty Information
Available in Multiple Languages
Follow us...
For all the latest updates and news.
audiotechnicaEU
@AudioTechnicaUK
AudioTechnicaEurope
index
contentspage
Professional studio headphones2
Studio microphones (lifetime warranty*)12
50 Series
40 Series
20 Series
Live sound microphones (lifetime warranty*)36
Artist Elite®
Artist Series
Multipurpose microphones50
Pro Series
Midnight Blues®
ATR Series
Broadcast & Production Microphones
Windscreens
58
Installed sound microphones80
Unipoint®
Propoint®
Engineered Sound (5 years warranty*)
Dante® (5 years warranty*)
Smartmixers®96
Conference Systems98
Wireless systems and Wireless accessories102
Turntables, Cartridges and Styli126
Accessories and Windscreens130
*Find warranty informations at:
http://eu.audio-technica.com/en/support/warranty/
Engineered Sound + Network Audio Microphones + ATUC-50
Extended 5-Year Warranty
For over 50 years, Audio-Technica has been designing and manufacturing
professional audio equipment to the most exacting standards.
Our Engineered Sound and Network Audio microphones are no exception.
Our full range of engineered sound microphones as well as the ATND971 and
ATND8677 network audio microphones now come with a 5-year warranty,
guaranteeing your new microphone against material or manufacturing defects
for 5 years from date of purchase.
Prices in GB Sterling including VAT (20%). Prices are subject to change without notice.
headphones professional studio monitor
ATH-R70x
£279.00
Professional open-back reference headphones
T he ATH-R70x is Audio-Technica’s first pair of professional
open-back reference headphones.
Together with the ATH-M70x, they stand as a flagship model
in Audio-Technica’s professional headphone lineup.
They incorporate an improved design of our popular 3D wing
support system to provide even greater comfort during the
prolonged use often required in professional settings. Robust
yet lightweight, and equipped with a unique,
dual-sided detachable cable that automatically maintains
proper stereo orientation (no matter how it’s attached),
the R70x headphones are built for lasting comfort,
convenience and audio purity.
Included accessories:
Unique, dual-sided detachable locking cable is L/R
signal independent, always ensuring proper stereo
orientation; protective carrying pouch.
Specifications
Type: Driver Diameter: Frequency Response:
Maximum Input Power:
Sensitivity: Impedance: ATH-R70x
Open-back dynamic
45 mm
5-40,000 Hz
1,000 mW
98 dB
470 ohms
2 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
headphones professional studio monitor
ATH-M70x
£239.00
Professional monitor headphones
he latest addition to the critically acclaimed M-Series line,
T
the ATH-M70x professional monitor headphones feature
proprietary 45 mm large-aperture drivers and are tuned to
accurately reproduce extreme low and high frequencies (5 to
40,000 Hz) while maintaining perfect balance. They are ideal
for studio mixing and tracking, FOH, DJing, mastering, postproduction, audio forensics and personal listening. Crafted for
lasting durability with space-saving design, the headphones
provide excellent sound isolation and are equipped with 90°
swiveling earcups for easy, one-ear monitoring.
Included accessories:
1.2 m-3 m coiled cable, 3 m straight cable,
1 m straight cable, 6.3 mm (1/4”) adapter,
protective case.
Specifications
Type: Driver Diameter: Frequency Response:
Maximum Input Power:
Sensitivity: Impedance: ATH-M70x
Closed-back dynamic
45 mm
5-40,000 Hz
2,000 mW
97 dB
38 ohms
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 3
headphones professional studio monitor
ATH-M50x
£139.00
Professional studio monitor headphones
This is the most critically acclaimed model in the M-Series
line, praised by top audio engineers and pro audio reviewers
year after year.
• E xceptional clarity throughout an extended frequency range,
with deep, accurate bass response.
• 90° swiveling earcups for easy, one-ear monitoring.
Included accessories:
Cables included:
studio
1.2 m – 3.0 m coiled
studio
3.0 m straight
4 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
portable
1.2 m short/straight
headphones professional studio monitor
ATH-M50xWH
ATH-M50xMG
LIMITED EDITION
ATH-M50xWH
£139.00
Professional studio monitor headphones
White version of M50x supplied with white cables and white
pouch.
ATH-M50xMG
£159.00
Professional studio monitor headphones
Limited Edition M50x in distinctive Matte Gray.
Specifications
Type: Driver Diameter: Frequency Response: Maximum Input Power: Sensitivity: Impedance: Weight: ATH-M50x / M50xWH / M50xMG
Closed-back dynamic
45 mm
15-28,000 Hz
1,600 mW at 1KHz
99 dB
38 ohms
285 g without cable/connector
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 5
headphones professional studio monitor
ATH-M40x
£89.00
Professional headphones
The high-performance M40x professional headphones are
tuned flat for incredibly accurate audio monitoring across an
extended frequency range.
• Tuned flat for incredibly accurate sound monitoring across the
entire frequency range.
• Circumaural design contours around the ears for excellent
sound isolation in loud environments.
• 90° swiveling earcups for easy, one-ear monitoring
Cables included:
studio
1.2 m – 3.0 m coiled
Specifications
Type: Driver Diameter: Frequency Response: Maximum Input Power: Sensitivity: Impedance: Weight: studio
3.0 m straight
ATH-M40x
Closed-back dynamic
40 mm
15-24,000 Hz
1,600 mW at 1KHz
98 dB
35 ohms
240 g without cable/connector
6 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
headphones professional studio monitor
ATH-M30x
ATH-M20x
ATH-M30x
£65.00
Professional monitor headphones
Featuring strong mid-range definition, these versatile
monitoring headphones are ideal in a variety of situations.
• Tuned for enhanced detail, with excellent mid-range
definition.
• Circumaural design contours around the ears for excellent
sound isolation in loud environments.
ATH-M20x
£45.00
Professional monitor headphones
The ATH-M20x professional monitor headphones are a great
introduction to the critically acclaimed M-Series line.
• Tuned for enhanced low-frequency performance.
Specifications
Type: Driver Diameter: Frequency Response: Maximum Input Power: Sensitivity: Impedance: Weight: ATH-M30xATH-M20x
Closed-back dynamic
40 mm
15-22,000 Hz
1,300 mW at 1KHz
96 dB
47 ohms
220 g without cable
Closed-back dynamic
40 mm
15-20,000 Hz
700 mW at 1KHz
96 dB
47 ohms
190 g without cable
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 7
headphones stereo dj headphones
Included detachable cables
ATH-PRO700MK2
ATH-PRO500MK2BK
ATH-PRO500MK2RD
ATH-PRO700MK2
£165.00
Professional DJ monitor headphones
Surround your senses with Audio-Technica’s sophisticated
technology and superior components of the PRO700MK2
headphones.
ATH-PRO500MK2 (BK-RD)
£139.00
Professional monitor headphones
Designed with the DJ in mind, Audio-Technica’s PRO500MK2
headphones deliver amazing sonic performance with 53 mm
large-diameter drivers, low-profile acoustic-efficient housings,
swiveling earpieces, and compact foldable design.
Available in black (BK) or red (RD).
PRO700MK2PRO500MK2 (BK-RD)
Type
Closed-back dynamic Closed-back dynamic
Driver Diameter:53mm
53mm
Magnet:Neodymium
–
Frequency Response 5-35,000Hz
10-30,000Hz
Max. Input Power 3,500mW
1,600mW
Impedance 68 ohms
38 ohms
Weight 305g
290g
Cable 1.2 - 3.0m detachable coiled cable 1.2m detachable straight cable
Connector 3.5mm gold-plated stereo plug with 6.3mm adapter
Specifications
8 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
headphones stereo dj headphones
ATH-PRO5MK3
ATH-PRO5MK3
£84.99
Professional DJ headphones for mixing and monitoring.
Detachable cable design provides multiple listening
options
• Developed 44mm large-diameter drivers provide accurate
sound reproduction for DJ.
• High magnetic power delivers powerful sound.
• High maximum input of 1,300mW achieves powerful, widerange frequency response.
• One-ear monitoring capability.
• Detachable cable with secure screw-on design.
• Two types of detachable cables included (coiled cable for DJ
use & cable with remote control and mic for smartphones).
Specifications
Headphone: ATH-PRO5MK3
Cable 1.2 - 3.0m coiled cord -
Microphone:
Connector Element:Condenser
Polar Pattern: Omnidirectional
Sensitivity: – 41dBV
Frequency response: 100 - 10,000Hz
Type
Closed-back dynamic
Driver Diameter:44mm
Magnet :
Neodymium
Frequency Response 10 ~ 25,000Hz
Maximum Input Power 1,300mW
Impedance 38 ohms
Weight 250g
1.2m with smartphone controller and mic
3.5mm gold-plated stereo plug with 6.3mm adapter
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 9
headphones broadcast stereo headset
BPHS1 included accessories:
cable, 3 windscreens,
spare connector screw
BPHS1-XF4 included accessories:
cable, 3 windscreens,
spare connector screw
cardioid
BPHS1
The BPHS1 is a rugged broadcast stereo headset with
closed-back circumaural (around-the-ear) ear cups and
a professional boom-mounted microphone that can be
worn from either side. It is designed for news and sports
broadcasting, announcing and interviews. Generously
padded circumaural ear cups provide acoustic isolation and
long-wearing comfort.
BPHS1
£159.00
Broadcast stereo headset
• C able termination: 3-pin XLRM-type connector for
microphone, 6.3 mm phone plug outputs for headphones.
BPHS1-XF4
£159.00
Communication headset
• C able terminations: 4-pin XLRF-type connector for usage
with intercom systems, mono headphone signal.
Specifications
BPHS1
Headphone Type Closed-back Dynamic
Headphone Driver 40 mm, neodymium magnet,
copper-clad aluminum wire voice coil
Microphone ElementDynamic
Microphone Polar PatternCardioid
Frequency Response
Headphone:20 -20,000 Hz
Microphone:40 -20,000 Hz
Open Circuit Sensitivity
Microphone: – 57 dB (1.4 mV) re 1V at 1 Pa*
Headphone: 100 dB
Maximum Input Power 1,600 mW at 1 kHz
Impedance
Headphone: 65 ohms
Microphone: 560 ohms
Weight 264 g
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
10 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
in-ear monitor headphones
ATH-E70
ATH-E50
ATH-E40
ATH-E70
£279.00
T hree balanced armature drivers
The ATH-E70 is the flagship model of the in-ear-monitor series.
Its accuracy and detail allow precise balancing of the mix, making
it the perfect choice for monitoring on stage and ENG mixing in
the studio. Offering high-resolution audio and an accurate
sound-stage, this model is designed for sound professionals who
demand the best.
ATH-E50
£140.00
Powerful single balanced armature drivers
The ATH-E5 0 features excellent isolation that ensures
confident, comfortable stage performance. To address the
evolution of modern music production, this model also excels
at providing a consistent reference in every sonic environment,
making it the ideal choice for the producer on the road.
ATH-E40
£69.00
Proprietary dual phase push-pull drivers
The ATH-E40 has a proprietary dual phase push-pull driver
design that improves fidelity and efficiency. The ATH-E40
delivers powerful bass along with balanced mid and high
frequencies to convey the full emotion of the music from the
stage to the studio.
Specifications
ATH-E70 ATH-E50ATH-E40
Type
Balanced armature
Balanced armature
Dynamic
Frequency Response 20 – 19,000 Hz
20 – 18,000 Hz
20 – 20,000 Hz
Sensitivity
109 dB/mW
107 dB/mW
107 dB/mW
Impedance
39 ohms
44 ohms
12 ohms
Weight (without cable) 9 g
9 g
10 g
Cable
Detachable 1.6 m with A2DC connectors
Connector
3.5 mm (1/8”) gold-plated stereo mini-plug, L-shaped
Accessories IncludedCarrying case, Carrying case, silicone eartips (XS/S/M/L)
6.3 mm (1/4”) adapter,
silicone eartips (XS/S/M/L),
Comply™ foam eartips (M)
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 11
50 series studio microphones
AT5040
cardioid
Audio-Technica’s premier studio vocal microphone, the AT5040
cardioid condenser offers remarkably musical high-fidelity
performance, with profound realism and depth, presence and
purity of sound. The AT5040 provides unprecedented dynamic
range, exceptionally low noise, high-SPL capability
and advanced internal shock mounting. Includes custom
AT8480 shock mount and hard-shell carrying case.
AT5040
£2.699.00 Cardioid condenser microphone
Designed as a first-choice vocal microphone, the AT5040
features an extremely smooth top end with controlled sibilance.
Large-diaphragm characteristics and fast transient response
also make it ideal for recording acoustic instruments such as
piano, guitar, strings and saxophone.
Included accessories:
AT8480 shock mount
for 5/8”-27 threaded stands;
protective carrying case.
12 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
50 series studio microphones
Four-part rectangular element
The first of our design criteria for the AT5040 was purity of
sound. To achieve this, Audio-Technica engineers developed
a four-part rectangular element, the pinnacle of our recent
breakthroughs in sound-capture technology. Four exquisitely
matched ultra-thin diaphragms function together (with outputs
proprietarily summed) as Audio-Technica’s largest-ever
element, providing combined surface area twice that of a
standard one-inch circular diaphragm.
By using four diaphragms in a single capsule, the AT5040
delivers the benefits of an exceptionally large diaphragm –
along with an extremely low noise floor – without increased
weight, decreased transient response or other drawbacks that
typically restrict diaphragm size.
Another key AT5040 design feature is advanced internal
shock mounting that effectively decouples the capsule from
the microphone body. For additional isolation, each AT5040 is
also provided with Audio-Technica’s innovative AT8480 shock
mount.
Advanced circuit design
To ensure optimum performance of the capsule, the AT5040’s
circuitry utilizes only discrete electronic components. Every
component for the circuit board assembly is carefully selected
based on its sound quality.
Our method of combining the outputs of four independent
elements in this patent-pending design is quite unique. By
means of this proprietary summing method we have been able
to quadruple the microphone’s sensitivity to -25 dBv, while
only doubling its noise level to a very low 5 dB SPL. This high
sensitivity allows the AT5040 to function optimally with a wide
range of microphone preamplifiers. All this while still providing
significant headroom, enough to accept 142dB SPL at 1kHz of
maximum sound pressure level.
100% quality control
Every AT5040 is hand assembled and individually inspected
for 100% quality control. Each microphone is enclosed in an
elegant housing of aluminum and brass with high-quality gray
finish for durability and low reflectivity.
Discrete components have been selected for optimized capsule
performance; in fact, every aspect of the microphone has been
carefully considered to minimize any effects on the audio signal.
SpecificationsAT5040
Element
Fixed-charge back plate, permanently polarized condenser
Frequency Response 20 -20,000 Hz
Open Circuit Sensitivity –25 dB (56.2 mV) re 1V at 1 Pa*
Impedance 50 ohms
Maximum Input Sound Level 142 dB SPL, 1 kHz at 1% T.H.D.
Noise 5 dB SPL
Dynamic Range (typical) 137 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio 89 dB, 1 kHz at 1 Pa*
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 13
50 series studio microphones
AT5045
cardioid
Audio-Technica’s premier studio instrument microphone,
the AT5045 cardioid condenser offers large-diaphragm,
side-address performance in a stick-type body.
The AT5045 provides unprecedented dynamic range,
exceptionally low noise, high-SPL capability and advanced
internal shock mounting.
AT5045
£1.299.00
Cardioid condenser instrument microphone
Pure, realistic sound quality for overheads, percussion, acoustic
guitar, strings and other acoustic instruments.
AT5045 accessories:
AT8481 shock mount
for 5/8”-27 threaded stands;
AT8165 windscreen;
protective carrying case.
AT5045P
£2.399.00 Pair of cardioid condenser instrument microphones
AT5045P accessories:
2 microphones,
2 AT8481 shock mount
for 5/8”-27 threaded stands;
2 AT8165 windscreen;
protective carrying case.
14 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
50 series studio microphones
Available as a single mic or as stereo pairs, the AT5045 is
a premier condenser instrument microphone that offers the
performance of a large-diameter, side-address condenser
in a convenient, stick-type body. In fact, despite the space
limitations imposed by its housing, the AT5045 boasts
Audio-Technica’s largest single diaphragm. The microphone’s
circuitry has been honed to the essentials, allowing the
AT5045 to achieve an unprecedented dynamic range that’s
one of the widest of any microphone on the market.
100% quality control
Every AT5045 is hand assembled and individually inspected
for 100% quality control. Each microphone is enclosed in an
elegant housing of aluminum and brass with a high-quality gray
finish for durability and low reflectivity. Discrete components
have been selected for optimized performance. The circuitry
and capsule assembly are mounted as a single block within
a floating internal shock mount, effectively decoupling the
capsule from the microphone body for excellent vibration
isolation. In fact, every aspect of the microphone has been
carefully considered to minimize any negative effects on the
audio signal.
The AT5045 instrument mic comes with Audio-Technica’s
innovative AT8481 isolation clamp, an AT8165 windscreen
and a protective carrying case that holds a single AT5045
microphone or a stereo pair of AT5045 microphones.
AT8482
£219.99
Optional shock mount for AT5045
AT8482
Optional
Shock Mount
AT8481
Shock Mount
SpecificationsAT5045
Element
Fixed-charge back plate, permanently polarized condenser
Frequency Response20 -20,000 Hz
Open circuit Sensitivity
–35 dB (17.7 mV) re 1V at 1 Pa*
Impedance
100 ohms
Maximum Input Sound Level
149 dB SPL, 1 kHz at 1% T.H.D.
Noise
8 dB SPL
Dynamic Range (typical)
141 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
86 dB, 1 kHz at 1 Pa*
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 15
40 series studio microphones
AT4080
figure-of-eight
With the groundbreaking AT4080, Audio-Technica achieves
the coveted ribbon microphone sound while solving the
problems of fragility and low output that have historically
plagued ribbon mics.
Equally at home in recording studios and live-sound settings,
the microphone features Audio-Technica’s innovative
MicroLinear™ ribbon imprint, which protects the dual ribbons
from lateral flexing and distortion. With 18 patents pending,
Audio-Technica’s innovative ribbon transducer advances the
evolution of ribbon microphone design.
Experience the difference.
AT4080
£719.00
Bidirectional active ribbon microphone
Included accessories:
AT8449/SV shock mount for
5/8”-27 threaded stands;
microphone dust cover;
protective carrying case.
SpecificationsAT4080
ElementRibbon
Frequency Response 20 -18,000 Hz
Open Circuit Sensitivity – 39 dB (11.2 mV) re 1V at 1 Pa*
Impedance 100 ohms
Maximum Input Sound Level 150 dB SPL, 1 kHz at 1% T.H.D.
Noise 22 dB SPL
Dynamic Range (typical) 128 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio 72 dB, 1 kHz at 1 Pa*
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
16 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
40 series studio microphones
AT4081
figure-of-eight
With its low-profile stick design, this microphone is a natural
for use on a wide range of instruments (horns, strings, drum
overheads, orchestras and more) and guitar cabinets in
recording studios and live-sound settings.
Equally at home in recording studios and live-sound settings,
the microphone features Audio-Technica’s innovative
MicroLinear™ ribbon imprint, which protects the dual ribbons
from lateral flexing and distortion. With 18 patents pending,
Audio-Technica’s innovative ribbon transducer advances the
evolution of ribbon microphone design.
Experience the difference.
AT4081 £499.00
Bidirectional active ribbon microphone
Included accessories:
AT8471 isolation clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”16 threaded adapter; windscreen;
protective carrying case.
SpecificationsAT4081
CapsuleRibbon
Frequency Response 30 -18,000 Hz
Open Circuit Sensitivity – 42 dB (7.9 mV), re 1V at 1 Pa*
Impedance 100 ohms
Maximum Input Sound Level 150 dB SPL, 1 kHz at 1% T.H.D.
Noise 25 dB SPL
Dynamic Range (typical) 125 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio 69 dB, 1 kHz at 1 Pa*
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 17
40 series studio microphones
AT4060a
cardioid
The AT4060a is a large-diaphragm cardioid condenser tube
microphone. It is designed for use in the most demanding
studio applications.
• Hand-selected tubes are individually tested and aged to
maintain peak performance.
• Wide dynamic range, low self-noise and high max SPL
capability.
• L arge coupling transformer provides superior low-frequency
linearity.
•T
he 2-micron-thick, vapor-deposited gold diaphragms
undergo a five-step aging process so that the optimum
characteristics achieved remain constant over years of use.
AT4060a
£1.349.00 Cardioid condenser tube microphone
Included accessories:
AT8560a tube microphone powering unit;
AT8447 shock mount for 5/8”-27 threaded
stands; 7,6m cable with 6-pin XLR-type
connectors; protective mic carrying case.
Specifications
Element
AT4060a
Externally polarized (DC bias) condenser
Frequency Response20 -20,000 Hz
Open Circuit Sensitivity
–34 dB (19.9 mV) re 1V at 1 Pa*
Impedance
200 ohms
Max. Input Sound Level
150 dB SPL, 1 kHz at 1% T.H.D.; 149 dB SPL, 1 kHz at 0.5% T.H.D.
Noise
19 dB SPL
Dynamic Range (typical)
131 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
75 dB, 1 kHz at 1 Pa*
Power Requirements
AT8560a tube microphone powering unit (100-240V AC)
Output Connector
3-pin XLRM-type (on tube microphone powering unit)
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
18 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
40 series studio microphones
AT4050ST
cardioid
figure-of-eight
Offering the realism of a live sound field, the AT4050ST is
a side-address condenser with cardioid and figure-of-eight
elements configured in a Mid-Side arrangement. This innovative
stereo condenser allows sound recordists the choice of selecting
a left-right stereo output or choosing discrete Mid-Side signals
for later manipulation; a remarkable flexibility.
AT4050ST
£1.199.00 Stereo condenser microphone with shock mount
Included accessories: AT8449 shock mount for
5/8”-27 threaded stands; 5/8”-27 to 3/8”-16
threaded adapter; microphone dust cover;
protective carrying case.
Specifications
AT4050ST
Element Externally-polarized (DC bias) condenser
Frequency Response 20 -18,000 Hz
Low Frequency Roll-off 80 Hz, 12 dB/octave
Open Circuit Sensitivity Stereo 90°: – 42 dB (7.9 mV) dB re 1V at 1 Pa*
Stereo 127°: – 41 dB (8.9 mV) dB re 1V at 1 Pa*
Mid: – 36 dB (15.8 mV) dB re 1V at 1 Pa*
Side: – 36 dB (15.8 mV) dB re 1V at 1 Pa*
Impedance 50 ohms
Max. Input Sound Level Mid and Side: 149 dB SPL, 1 kHz at 1% T.H.D.;
159 dB SPL, with 10 dB pad (nominal)
Noise Stereo 90°: 25 dB SPL
Stereo 127°: 16 dB SPL
Mid: 15 dB SPL
Side: 17 dB SPL
Dynamic Range (typical) Signal-to-Noise Ratio Mid: 134 dB, 1 kHz at Max SPL
Side: 32 dB, 1 kHz at Max SPL
Stereo 90°: 69 dB, 1 kHz at 1 Pa*
Stereo 127°: 78 dB, 1 kHz at 1 Pa*
Mid: 79 dB, 1 kHz at 1 Pa*
Side: 77 dB, 1 kHz at 1 Pa*
Switches 90°, 127°, M-S; Flat, roll-off; 10 dB pad (nominal)
Output Connectors Integral 5-pin XLRM-type
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 19
40 series studio microphones
AT4050
cardioid
omnidirectional
figure-of-eight
T he AT4050 offers a remarkable combination of high
SPL capability with transparent airy upper and mid range
frequencies complemented by a rich low-end quality.
Numerous legendary studio engineers agree that it is the
perfect studio tool for use on vocals, piano, strings, drum
overheads, guitar amps and ensembles.
AT4050SM
£579.00
Multi-pattern condenser microphone
with AT8449 shock mount.
AT4050SC
£619.00
Multi-pattern condenser microphone
with AT8430 stand clamp.
Included accessories:
Protective carrying case; microphone dust
cover; AT8449 shock mount (AT4050SM);
AT8430 stand clamp (AT4050SC)
Specifications
AT4050SM / AT4050SC
Element
Externally polarized condenser
Frequency Response20 -18,000 Hz
Open Circuit Sensitivity
– 36 dB (15.8 mV), re 1V at 1 Pa*
Impedance100 ohms
Maximum Input Sound Level
149 dB SPL, 1 kHz, T.H.D. 1% 159 dB SPL, with 10 dB pad (nominal)
Signal-to-Noise Ratio
77 dB, 1 kHz at 1 Pa*
Dynamic Range
132 dB, 1 kHz at Max SPL
Noise
17 dB SPL
Low Frequency Roll-Off
80 Hz, 12 dB/octave
Power Requirement
48V DC, 4.2 mA
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
20 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
40 series studio microphones
AT4047MP
cardioid
omnidirectional
figure-of-eight
udio-Technica’s AT4047MP delivers vintage sound in a multiA
pattern design with selectable omnidirectional, cardioid, and
figure-of-eight polar patterns. The microphone’s transformercoupled output and specially tuned element provide sonic
characteristics reminiscent of early F.E.T. studio microphone
designs. With a wide dynamic range, incredibly low self-noise
and high SPL capability, this versatile microphone excels on
vocals, strings, acoustic guitar, instrument ensembles, small
vocal groups and voiceovers.
AT4047MP
£659.00
Multi-pattern condenser microphone – vintage sound
Included accessories:
AT8449/SV shock mount
for 5/8”-27 threaded stands;
microphone dust cover;
protective carrying case.
Specifications
AT4047MP
Element
Externally-polarized (DC bias) condenser
Frequency Response 20 -18,000 Hz
Low Frequency Roll-off 80 Hz, 12 dB/octave
Open Circuit Sensitivity – 42 dB (7.9 mV), re 1V at 1 Pa*
Impedance 100 ohms
Max. Input Sound Level 155 dB SP L, 1 kHz at 1% T.H.D.; 165 dB SPL, with 10 dB pad (nominal)
Noise 14 dB
Dynamic Range (typical) 141 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio 80 dB, 1 kHz at 1 Pa*
Switches Polar selection; Flat, roll-off; 10 dB pad (nominal)
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 21
40 series studio microphones
AT4047SVSM
cardioid
AT4047SVSM accessories:
AT8449SV shock mount for 5/8”-27
threaded stands; protective carrying case
he precision engineered large diaphragm of the
T
AT4047SVSM provides a warm, vintage sonic characteristic
reminiscent of early F.E.T. studio microphone designs. The dual
diaphragm design maintains a precise polar pattern across the
full frequency range.
AT4047SVSM
£579.00
C ardioid condenser microphone
with AT8449SV shock mount.
SpecificationsAT4047SVSM
Element
Externally polarized (DC bias) condenser
Frequency Response20 -18,000 Hz
Open Circuit Sensitivity
– 35 dB (17.7 mV) ± 2 dB, re 1V at 1 Pa*
Impedance250 ohms
Max. Input Sound Level
149 dB SPL, 1 kHz, T.H.D. 1% 159 dB SPL, with 10 dB pad (nominal)
Signal-to-Noise Ratio
85 dB, 1 kHz at 1 Pa*
Dynamic Range
140 dB,1 kHz at Max SPL
Noise
9 dB SPL
Low Frequency Roll-Off
80 Hz, 12 dB/octave
Power Requirement
Phantom 48 V, 3.0 mA
Accessories Furnished
Protective carrying case AT8449SV shock mount
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
22 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
40 series studio microphones
AT4033a
AT4040SM
AT4040SC
cardioid
cardioid
A strong up front crisp sound characterizes the sonic signature
that created this studio classic.
AT4033aSM
£359.00
Cardioid condenser microphone with shock mount
A marriage of technical precision and artistic inspiration, the
AT4040 features an advanced large diaphragm, tensioned
specifically to provide smooth, natural sonic characteristics.
AT4040SM
£379.00
C ardioid condenser microphone
with AT8449 shock mount.
AT4040SC
£410.00
C ardioid condenser microphone
with AT8430 stand clamp.
Specifications
AT4033aSM
AT4040SM / SC
Element
Permanently polarized condenser Externally polarized condenser
Frequency Response30 -20,000 Hz
20 -20,000 Hz
Open Circuit Sensitivity – 32 dB (25.1 mV), re 1V at 1 Pa*
– 32 dB (25.1 mV), re 1V at 1 Pa*
Impedance100 ohms100 ohms
Max. Input Sound Level 145 dB SPL, 1 kHz at 1% T.H.D.
145 dB SPL, 1 kHz at 1% T.H.D.
155 dB SPL, with 10 dB pad (nominal)
155 dB SPL , with 10 dB pad (nominal)
Signal-to-Noise Ratio
Dynamic Range Noise
Low Frequency Roll-Off
Accessories Furnished
77 dB, 1 kHz at 1 Pa*
82 dB, 1 kHz at 1 Pa*
128 dB, 1 kHz at Max SPL
133 dB, 1 kHz at Max SPL
17 dB SPL
12 dB SPL
80 Hz, 12 dB/octave
80 Hz, 12 dB/octave
Protective carrying case
AT8449 shock mount
Protective carrying case
AT8449 shock mount (AT4040SM)
AT8430 stand clamp (AT4040SC)
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 23
40 series studio microphones
AT4041
cardioid
AT4041
£259.00
Cardioid condenser microphone
T he AT4041 features a transformerless output for a very
high SPL handling capability. The surface of the back plate
is precision milled, reducing unnatural frequency response
peaks and distortion.
Included accessories:
Protective carrying case;
AT8405a snap-in clamp;
AT8159 foam windscreen.
Specifications
AT4041
Element
Permanently polarized Condenser
Frequency Response20 -20,000 Hz
Open Circuit Sensitivity
– 36 dB (15.8 mV), re 1V at 1 Pa*
Impedance
100 ohms
Maximum Input Sound Level 145 dB SPL, 1 kHz at 1% T.H.D.
Signal-to-Noise Ratio
70 dB, 1 kHz at 1 Pa*
Dynamic Range
121 dB, 1 kHz at Max SPL
Noise
24 dB SPL
Low Frequency Roll-Off
80 Hz, 12 dB/octave
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
24 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
40 series studio microphones
AT4021
cardioid
AT4022
omnidirectional
Included accessories:
AT8405a stand clamp,
AT8159 windscreen, case.
AT4021
£289.00
Cardioid condenser microphone
T he AT4021 offers a flat, extended frequency response, high
maximum SPL and wide dynamic range. Its low self-noise
is perfectly suited for the most sophisticated recording
equipment. Its low-mass diaphragm improves transient
response and reduces handling and mechanical noise
transfer.
AT4022
£329.00
Omnidirectional condenser microphone
T he low-profile AT4022 is outstanding for piano, acoustic
guitar and other acoustic instruments. Offering a flat,
extended frequency response and wide dynamic range,
it handles high SPLs with ease. Its low-mass diaphragm
improves transient response and reduces handling/
mechanical noise transfer.
SpecificationsAT4021
AT4022
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response 20 -20,000 Hz
20 -20,000 Hz
Low Frequency Roll Off 80 Hz, 18 dB/octave
80 Hz, 18 dB/octave
Open Circuit Sensitivity – 34 dB (19.9 mV) re 1V at 1 Pa*
– 34 dB (19.9 mV) re 1V at 1 Pa*
Impedance 250 ohms
250 ohms
Max. Input Sound Level 146 dB SPL, 1 kHz at 1% T.H.D.; 146 dB SPL, 1 kHz at 1% T.H.D.;
156 dB SPL , with 10 dB pad (nominal)
156 dB SPL , with 10 dB pad (nominal)
Noise
Dynamic Range (typical) Signal-to-Noise Ratio
Switches 14 dB SPL
13 dB SPL
132 dB, 1 kHz at Max SPL
133 dB, 1 kHz at Max SPL
80 dB, 1 kHz at 1 Pa*
81 dB, 1 kHz at 1 Pa*
Flat, roll-off; 10 dB pad
Flat, roll-off; 10 dB pad
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 25
40 series studio microphones
AT4900b-48
AT4049b-EL
AT4051b-EL
AT4053b-EL
Microphone components
AT4900B-48
£279.00
Electronics / body only
AT4049B-EL
£179.00
Omnidirectional element only
AT4051B-EL
£179.00
C ardioid element only
AT4053B-EL
£179.00
H ypercardioid element only
26 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
40 series studio microphones
AT4049B
AT4051B
AT4053B
omnidirectional
cardioid
hypercardioid
Modular microphones
AT4049B
£439.00
Omnidirectional condenser microphone
• Recommended for professional recording and
critical applications in broadcast.
• Omnidirectional polar pattern provides maximum
ambient pickup.
AT4051B
£439.00
Cardioid condenser microphone
• Ideal for professional recording and critical applications
in broadcast.
• High front-to-back rejection ratio. Cardioid polar pattern
improves isolation of desired sound source.
AT4053B
£439.00
Hypercardioid condenser microphone
• Hypercardioid polar pattern reduces pickup of sounds from the
sides and rear, improving isolation of desired sound source.
Included accessories:
AT8405a stand clamp,
AT8159 windscreen, carrying case.
Specifications
AT4049b / AT4051b / AT4053b
Element
Externally polarized (DC bias) condenser
Frequency Response 20 -20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave
Open Circuit Sensitivity – 34 dB (19.9 mV) re 1V at 1 Pa*
Impedance 50 ohms
Max. Input Sound Level 145 dB SPL, 1 kHz at 1% T.H.D.;
(nominal)
155 dB SPL, with 10 dB pad (nominal)
Noise
Dynamic Range (typical) Signal-to-Noise Ratio
Switches (nominal)
16 dB SPL
129 dB, 1 kHz at Max SPL
78 dB, 1 kHz at 1 Pa*
Flat, roll-off; 10 dB pad (nominal)
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 27
20 series studio microphones
AT2050
cardioid
omnidirectional
figure-of-eight
he AT2050’s dual large-diaphragm design provides
T
consistent, superior performance in switchable cardioid,
omnidirectional and figure-of-eight polar pattern settings.
AT2050
£224.00
Multi-pattern condenser microphone
Included accessories:
AT8458 Shock mount for 5/8”-27 threaded stands; 5/8”-27 to 3/8”-16 threaded
adapter; soft protective pouch.
Specifications
AT2050
Element
Externally polarized (DC Bias) condenser
Frequency Response 20 -20,000 Hz
Low Frequency Roll-Off 80 Hz, 12 dB/octave
Open Circuit Sensitivity – 42 dB (10.0 mV) re 1V at 1 Pa*
Impedance 120 ohms
Max. Input Sound Level 149 dB SPL, 1 kHz at 1% T.H.D.; 159 dB SPL with 10 dB pad (nominal)
Noise
17 dB SPL
Dynamic Range (typical) 132 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
77 dB, 1 kHz at 1 Pa*
Switches Polar selection; Flat, roll-off; 10 dB pad (nominal)
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
28 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
20 series studio microphones
AT2035
cardioid
Designed for critical home/project/professional studio
applications and live performance, the AT2035 delivers
exceptional detail and low noise.
AT2035
£149.00
Cardioid condenser microphone
Included accessories:
AT8458 shock mount for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16
threaded adapter; soft protective pouch.
Specifications
AT2035
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response 20 -20,000 Hz
Low Frequency Roll Off 80 Hz, 12 dB/octave
Open Circuit Sensitivity – 33 dB (25.1 mV) re 1V at 1 Pa*
Impedance 120 ohms
Max. Input Sound Level 148 dB SPL, 1 kHz at 1% T.H.D.; 158 dB SPL, with 10 dB pad (nominal)
Noise
12 dB SPL
Dynamic Range (typical) 136 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
82 dB, 1 kHz at 1 Pa*
Switches Flat, roll-off; 10 dB pad (nominal)
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 29
20 series studio microphones
AT2020
cardioid
T he AT2020 sets a standard for price performance in a side-
address studio condenser way ahead of its time.
AT2020
£95.00
Cardioid condenser microphone
Included accessories:
AT8466 stand mount for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16
threaded adapter; soft protective pouch.
Specifications
AT2020
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response20 -20,000 Hz
Open Circuit Sensitivity
– 37 dB (14.1 mW), re 1V at 1 Pa*
Impedance100 ohms
Max. Input Sound Level
144 dB SPL, 1 kHz at 1% T.H.D.
Noise
20 dB SPL
Dynamic Range (typical)
124 dB, 1 kHz at max SPL
Signal-to-Noise Ratio 74 dB, 1 khz at 1 Pa*
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
30 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
20 series studio microphones
AT2031
cardioid
Included accessories:
AT8405a stand clamp;
windscreen;
soft protective pouch
The AT2031 is the ideal microphone for stringed instruments
in critical studio and live applications. Its permanently
polarized element offers extended frequency response with
a slight rise in the high frequency range for a more detailed
sound.
AT2031
£99.00
Cardioid condenser microphone
Specifications
AT2031
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response20 -20,000 Hz
Low Frequency Roll-Off
150 Hz, 6 dB/octave
Open Circuit Sensitivity
– 34 dB (19.9 mV) re 1V at 1 Pa*
Impedance85 ohms
Max. Input Sound Level
141 dB SPL, 1 kHz at 1% T.H.D.
Noise
17 dB SPL
Dynamic Range (typical)
124 dB, 1 kHz at max SPL
Signal-to-Noise Ratio 77 dB, 1 khz at 1 Pa*
Switches
Flat, roll-off
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 31
20 series studio microphones
AT2022
stereo
The AT2022 is a condenser microphone designed for stereo
recording. Two unidirectional condenser capsules in an X/Y
configuration pivot to allow for narrow (90°) or wide (120°)
stereo operation. The capsules also fold flat for storage and
transportation.
AT2022
£219.00
X/Y Stereo Microphone
Included accessories:
AT8405a stand clamp, AA battery, fuzzy
windscreen, 5 m cable that terminates in
a 3.5 mm stereo plug, pouch.
Specifications
AT2022
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response20 -20,000 Hz
Low Frequency Roll-off
150 Hz, 6 dB/octave
Open Circuit Sensitivity
– 41 dB (8.9mW), re 1V at 1 Pa*
Channel balance
< 2.5 dB
Impedance200 ohms
Max. Input Sound Level
122 dB SPL, 1kHz at 1% T.H.D.
Noise
19 dB SPL
Dynamic Range (typical)
103 dB, 1kHz at Max SPL
Signal-to-Noise Ratio 75 dB, 1kHz at 1 Pa*
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
32 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
20 series studio microphones
AT2010
cardioid
T he AT2010 is designed to bring the studio-quality articulation
and intelligibility of Audio-Technica’s renowned 20 Series to
the stage, for crystal-clear vocal performances.
AT2010
£95.00
Cardioid condenser handheld microphone
Included accessories:
AT8470 stand clamp,
threaded adapter, pouch.
Specifications
AT2010
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response40 -20,000 Hz
Open Circuit Sensitivity
– 48 dB (3.9mW), re 1V at 1 Pa*
Impedance100 ohms
Max. Input Sound Level
136 dB SPL, 1kHz at 1% T.H.D.
Noise
23 dB SPL
Dynamic Range (typical)
113 dB, 1kHz at Max SPL
Signal-to-Noise Ratio 71 dB, 1kHz at 1 Pa*
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 33
20 series studio microphones
AT2020USB+
cardioid
AT2020USB+
£139.00
USB cardioid condenser microphone
Equipped with a USB output, the AT2020USB+ is designed
for digitally capturing music or any acoustic audio source using
your favorite recording software. The microphone offers the
critically acclaimed, award-winning sound of the AT2020.
Included accessories:
Pivoting stand mount for 5/8”-27 threaded stands;
5/8”-27 to 3/8”-16 threaded adapter; soft protective
pouch; tripod desk stand; 3.1 m USB cable
Specifications
AT2020USB+
Element Fixed-charge back plate permanently polarized condenser
Frequency Response 20 -20,000 Hz
Power Requirements USB Power (5V DC)
Bit Depth 16 bit
Sample Rate 44.1/48 kHz
Volume Control
Mix control: headphone volume control
Headphone Output Power 130 mW (at 1 kHz, 10% T.H.D., 32 ohm load)
Output Connector USB
Headphone Jack 3.5 mm (1/8”) TRS (stereo)
34 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
20 series studio microphones
AT2020USBi
cardioid
AT2020USBi
£179.00
USB cardioid condenser microphone
The AT2020USBi works with both USB and Lightning cables
(included), so users can employ it straight from the box to
digitally capture audio on the device of their choice: PC, Mac
or iOS. The integrated gain control adds to the convenience,
allowing users to adjust the input level directly on the
microphone.
Included accessories:
Pivoting stand mount for 5/8”-27 threaded stands; 5/8”27 to 3/8”-16 threaded adapter; soft protective pouch;
tripod desk stand; 1.5 m USB cable; 1.5 m Lightning cable
Specifications
AT2020USBi
Element Fixed-charge back plate permanently polarized condenser
Frequency Response 20 -20,000 Hz
Power Requirements USB (5V DC); Lightning (3.3V DC)
Bit Depth 24 bit
Sample Rate up to 96 kHz
Volume Control
Mic gain control
Output Connector Micro-HDMI
System requirements: Macintosh: MAC OS 10.6 and above Windows: Windows 7 and
above iOS: iOS 7.02 and above (requires Lightning connection)
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 35
artist elite® live sound microphones
AE5400
AE3300
cardioid
cardioid
• Superior anti-shock engineering ensures low handling
noise and quiet performance.
• Robust design for enduring dependability on the road.
AE5400
£345.00
Cardioid condenser microphone
• P ristine sound quality demanded by the most
discriminating microphone user.
• L arge-diaphragm element and true condenser design.
AE3300
£290.00
Cardioid condenser microphone
• Exacting detail, brilliant clarity and uncoloured realism.
• Well-tempered polar pattern with outstanding rejection
qualities.
Specifications
AE5400AE3300
Element
Externally polarized condenser
Electret condenser
Frequency Response20 -20,000 Hz
30 -18,000 Hz
Open Circuit Sensitivity
– 42 dB (7.9 mV), re 1V at 1 Pa*
– 40 dB (10.0 mV), re 1V at 1 Pa*
Impedance150 ohms150 ohms
Max. Input Sound Level
147 dB SPL, 1 kHz at 1% T.H.D.
157 dB SPL, with 10 dB pad
147 dB SPL, 1 kHz at 1% T.H.D.
157 dB SPL, with 10 dB pad
Signal-to-Noise Ratio
80 dB, 1 kHz at 1 Pa*
75 dB, 1 kHz at 1 Pa*
Dynamic Range
133 dB, 1 kHz at Max SPL
128 dB, 1 kHz at Max SPL
Noise
14 dB SPL
19 dB SPL
Low Frequency Roll-Off
80 Hz, 12 dB/octave
80 Hz, 12 dB/octave
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
36 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist elite® live sound microphones
AE6100
AE4100
hypercardioid
cardioid
• Superior anti-shock engineering for low handling noise.
• Tough, durable, resilient – built for the road.
AE6100
£170.00
Hypercardioid dynamic microphone
• Great presence with excellent monitor cut.
• Maximum feedback rejection.
AE4100
£170.00
Cardioid dynamic microphone
• Aggressive sound that stays up-front in the mix.
• Optimized for the stage with excellent isolation properties.
AE5400 :
The same largediaphragm element
used in the AT4050.
AE3300 :
The same element
used in the
legendary AT4033.
Included accessories:
AT8470 Quiet-Flex™ stand clamp;
5/8”-27to 3/8”-16 threaded adapter;
soft protective pouch.
SpecificationsAE6100
AE4100
ElementDynamic Dynamic
Frequency Response60 -15,000 Hz
90 -18,000 Hz
Open Circuit Sensitivity
– 55 dB (1.7 mV), re 1V at 1 Pa*
– 55 dB (1.7 mV), re 1V at 1 Pa*
Impedance250 ohms250 ohms
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 37
artist elite® live sound microphones
dynamic
AE2500
condenser
cardioid
AE2500 accessories: protective pouch;
AT8471 Isolation clamp; cable 5 m dual shielded,
8-conductor cable, 5-pin XLRF-type connector
at microphone, two 3-pin XLRM-type output
connectors 5/8”-27 to 3/8”-16 threaded.
AE2500
£540.00
Dual-element cardioid microphone
• Revolutionary, first-of-its-kind dual-element design
represents a ground-breaking transducer achievement.
Specifications
AE2500
Element Condenser, dynamic
Frequency Response
Dynamic : 30 -10,000 Hz
Condenser : 20 -17,000 Hz
Open Circuit Sensitivity
Dynamic : – 54 dB (1.9 mV)
Condenser : – 51 dB (2.8 mV), re 1V at 1 Pa*
Impedance
Dynamic : 600 ohms
Condenser : 100 ohms
Max. Input Sound Level
Condenser : 148 dB SPL, 1 kHz at 1% T.H.D.
158 dB SPL, with 10 dB pad
Signal-to-Noise Ratio Condenser : 70 dB, re 1V at 1 Pa*
Dynamic Range
Condenser : 124 dB, 1 kHz at Max SPL
Low Frequency Roll-Off 80 Hz, 12 dB/octave
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
38 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist elite® live sound microphones
AE3000
cardioid
Included accessories:
AT8471 isolation clamp,
threaded adapter, pouch.
AE3000
£240.00
C ardioid condenser microphone
• L arge-diaphragm capsule combines with the open
architecture of the headcase to provide an extremely
accurate and open sound.
SpecificationsAE3000
Element
Electret condenser
Frequency Response20 -20,000 Hz
Open Circuit Sensitivity
– 43 dB (7 mV), re 1V at 1 Pa*
Impedance100 ohms
Max. Input Sound Level
148 dB SPL, 1 kHz at 1% T.H.D. - 158 dB SPL, with 10 dB pad
Signal-to-Noise Ratio 83 dB, re 1V at 1 Pa*
Dynamic Range
137 dB, 1 kHz at Max SPL
Low Frequency Roll-Off
80 Hz, 12 dB/octave
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 39
artist elite® live sound microphones
AE5100
cardioid
Included accessories:
AT8471 isolation clamp, threaded
adapter, AT8136 windscreen, pouch.
AE5100
£255.00
Cardioid condenser microphone
• L arge-diaphragm capsule delivers accurate, uncoloured and
extremely natural response.
SpecificationsAE5100
Element
Electret condenser
Frequency Response20 -20,000Hz
Open Circuit Sensitivity
– 36dB (15.8mV), re 1V at 1 Pa*
Impedance150 ohms
Max. Input Sound Level
148dB SPL, 1kHz at 1% T.H.D. - 158dB SPL, with 10dB pad
Signal-to-Noise Ratio 83dB, re 1V at 1 Pa*
Dynamic Range
137dB, 1kHz at Max SPL
Low Frequency Roll-Off
80Hz, 12dB/octave
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
40 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist elite® live sound microphones
AE2300
cardioid
Included accessories:
AT8471 isolation clamp,
threaded adapter, pouch.
AE2300
£219.00
Dynamic cardioid instrument microphone
The Artist Elite® AE2300 cardioid instrument microphone
features Audio-Technica’s proprietary double-dome diaphragm
construction, giving it high-frequency and transient response
that far exceeds typical dynamic microphones.
Equipped with a switchable low-pass filter that cuts out harsh,
high-frequency noise without negatively affecting the overall
tone of an instrument.
• Brass metal construction and low-profile design.
• The ability to handle high SPLs
•V
ersatile performer, able to capture sound from guitar amps,
brass and woodwind, drums and percussion instruments
with clarity and precision.
AE2300
Specifications
ElementDynamic
Frequency Response: 60 – 20 000Hz
High Frequency Roll-Off:
6,000Hz, 6dB/Octave with activated filter
Open Circuit Sensitivity: –57dB (1.4 mV) re 1V at 1 Pa*
Impedance: 250 ohms
Output Connector: Integral 3-pin XLRM-type
Accessories Included: AT8471 isolation clamp for 5/8”-27 threaded stands,
5/8”-27 to 3/8”-16 threaded adaptor, soft protective pouch
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 41
artist series live sound microphones
ATM710
cardioid
The studio quality performance of the ATM710 is brought
to the stage with an extremely tight cardioid pattern making
feedback and stage sound easier to manage.
ATM710
£149.00
High-fidelity handheld condenser
• Superior anti-shock engineering for low handling noise.
• Condenser design for studio-quality performance.
Included accessories:
AT8470 Quiet-Flex™ stand clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16 threaded
adapter; soft protective pouch.
Specifications
ATM710
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response40 -20,000 Hz
Low Frequency Roll-Off
80 Hz, 12 dB/octave
Open Circuit Sensitivity
– 40 dB (10.0 mV) re 1V at 1 Pa*
Impedance 200 ohms
Max. Input Sound Level
148 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (typical)
127 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio 73 dB, 1 kHz at 1 Pa*
Switches
Flat, roll-off; 10 dB pad
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
42 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist series live sound microphones
ATM610a
ATM510
hypercardioid
cardioid
ATM610a
£109.00
Hypercardioid dynamic vocal microphone
• Hypercardioid polar pattern reduces pickup of sounds from
the sides and rear, improving isolation of desired sound
source.
• Durable performance for professional applications.
ATM510
£89.00
Cardioid dynamic vocal microphone
• Tailored for smooth, natural vocal reproduction.
• Excellent off-axis rejection for minimum feedback.
Included accessories:
AT8470 Quiet-Flex™ stand clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16 threaded
adapter; soft protective pouch.
Specifications
ATM610aATM510
ElementDynamic Dynamic
Frequency Response40 -16,000 Hz
90 -16,000 Hz
Open Circuit Sensitivity
– 55 dB (1.7 mV) re 1V at 1 Pa*
– 55 dB (1.7 mV) re 1V at 1 Pa*
Impedance 300 ohms
300 ohms
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 43
artist series live sound microphones
ATM250DE
cardioid
hypercardioid
Included accessories:
AT8471 isolation clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16
adapter; soft protective pouch.
Cable: 5.0 m (16.5’) dual shielded,
8-conductor connector at microphone,
two 3-pin XLRM-type output connectors
cable, 5-pin XLRF-type.
ATM250DE
£309.00
Dual-element instrument microphone
• Audio-Technica’s proven dual-element design features two
elements (condenser and dynamic) enclosed in a single
housing.
Specifications
Element
Frequency Response
Low Frequency Roll-Off
Open Circuit Sensitivity
Impedance
Max. Input Sound Level
Dynamic Range (typical)
Signal-to-Noise Ratio ATM250DE
Condenser, dynamic
40-20,000 Hz (condenser) - 40-15,000 Hz (dynamic)
80 Hz, 12 dB/octave (condenser)
– 49 dB (3.5 mV), re 1V at 1 Pa* (condenser)
– 53 dB (2.2 mV), re 1V at 1 Pa* (dynamic)
50 ohms (condenser) - 600 ohms (dynamic)
148 dB SPL, 1 kHz at 1% T.H.D. (condenser)
122 dB, 1 kHz at Max SPL (condenser)
68 dB, 1 kHz at 1 Pa* (condenser)
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
44 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist series live sound microphones
ATM250
hypercardioid
Included accessories:
AT8471 isolation clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16
adapter; soft protective pouch
ATM250
£199.00
H ypercardioid dynamic instrument microphone
• Frequency response tailored for kick drum, percussion,
brass, and other highly dynamic instruments.
Specifications
ATM250
ElementDynamic
Frequency Response
40-15,000 Hz
Open Circuit Sensitivity
– 54 dB (1.9 mV), re 1V at 1 Pa*
Impedance
600 ohms
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 45
artist series live sound microphones
ATM650
ATM450
hypercardioid
cardioid
ATM650
£99.00
Hypercardioid dynamic instrument microphone
• Tailored response for musical instrument pickup–guitar
cabinets, snare and other percussion.
Included accessories:
AT8470 isolation clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16
adapter; soft protective pouch.
ATM450
£199.00
Cardioid condenser instrument microphone
•U
nique side-address stick design maximizes placement
options with minimal obstructions.
Included accessories:
AT8471 isolation clamp for 5/8”-27
threaded stands; 5/8”-27 to 3/8”-16
adapter; soft protective pouch.
Specifications
Element
ATM650ATM450
Dynamic
Fixed-charge back plate
permanently polarized condenser
Frequency Response
80-17,000 Hz
Low Frequency Roll-Off
Open Circuit Sensitivity
– 56 dB (1.5 mV), re 1V at 1 Pa*
Impedance
300 ohms
Max. Input Sound Level
Dynamic Range (typical)
Signal-to-Noise Ratio
40-20,000 Hz
80 Hz, 12 dB/octave
– 41 dB (8.9 mV), re 1V at 1 Pa*
200 ohms
152 dB SPL, 1 kHz at 1% T.H.D.
127 dB, 1 kHz at Max SPL
69 dB, 1 kHz at 1 Pa*
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
46 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist series live sound microphones
ATM230
hypercardioid
Included accessories:
AT8665 drum mount;
soft protective pouch
ATM230
£110.00
Hypercardioid dynamic instrument microphone
The ATM230 brings a model that’s ideal for capturing drums
and percussion to Audio-Technica’s popular Artist Series line.
• Hypercardioid polar pattern reduces pickup of sounds from
the sides and rear, improving isolation of desired sound
source.
ATM230PK
£299.00
Three hypercardioid dynamic microphones drum pack
The ATM230PK Drum Microphone 3-Pack gives you a set of
three compact microphones specifically engineered to mic rack
and floor toms, snare drums and other percussion instruments.
• Each ATM230 mic in this pack comes with an AT8665 drum
mount and a protective pouch.
Specifications
ATM230
Element:Dynamic
Frequency Response: 30 – 12 000Hz
Open circuit sensitivity:
– 54 dBV (1.9mV) re 1V at 1 Pa*
Impedance:
600 ohms
Output connector:
Integral 3-pin XLRM-type
Accessories Included: AT8665 drum mount; soft protective pouch
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 47
artist series live sound microphones
ATM350
cardioid
ATM350
£255.00
Cardioid condenser clip-on microphone
• Low-profile design for minimum visibility
• Attaches to brass, reeds, piano, double bass, snare, toms,
and violin.
ATM350 interchangeable elements
UE-H
£84.00
Hypercardioid interchangeable element
UE-O
£84.00
Omnidirectional interchangeable element
Included accessories:
AT8542 power module,
®
AT8418 UniMount ,
AT8468 violin mount, pouch.
Specifications
Element
Frequency Response
Low Frequency Roll-Off
Open Circuit Sensitivity
Impedance Max. Input Sound Level
Dynamic Range (typical)
Signal-to-Noise Ratio
Switches
ATM350
Fixed-charge back plate permanently polarized condenser
40-20,000 Hz
80 Hz, 12 dB/octave
– 49 dB (3.5 mV) re 1V at 1 Pa*
50 ohms
149 dB SPL, 1 kHz at 1% T.H.D.
122 dB, 1 kHz at Max SPL
67 dB, 1 kHz at 1 Pa*
Flat, roll-off
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
48 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist series live sound microphones
ATM73a
ATM75a
cardioid
cardioid
ATM73a
£199.00
Cardioid condenser headworn microphone
• Ideal for drummers, keyboard players or anyone requiring
hands-free operation.
ATM73ac
£109.00
Same as ATM73a but unterminated for wireless and
special applications
Includes AT8125 and AT8128 windscreens; no power module.
Included accessories:
AT8531 power module,
AT8125/AT8128 windscreens, battery.
ATM75
£169.00
Cardioid condenser headworn microphone
• Professional-quality vocal pickup with hands-free operation.
ATM75c
£75.00
Same as ATM75 but unterminated for wireless and
special applications
Includes AT8139L large windscreen and AT8439 cable clothing
clip; no power module.
Included accessories:
AT8531 power module, AT8439 cable clip,
AT8139L/AT8139S windscreens, battery
ATM73aATM75
Specifications
Element
Fixed-charge back plate
Fixed-charge back plate
permanently polarized condenser permanently polarized condenser
Frequency Response
Low Frequency Roll-Off
Open Circuit Sensitivity
40-15,000 Hz
100-13,000 Hz
80 Hz, 18 dB/octave
80 Hz, 18 dB/octave
Ph: –55 dB (1.7 mV) re 1V at 1 Pa* –51 dB (2.8 mV) re 1V at 1 Pa*
B: –56 dB (1.5 mV) re 1V at 1 Pa* –53 dB (2.2 mV) re 1V at 1 Pa*
Impedance Phantom: 200 ohms
Battery: 270 ohms
Max. Input Sound Level
Ph: 146 dB SPL, 1 kHz at 1% T.H.D. 132 dB SPL, 1 kHz at 1% T.H.D.
B: 132 dB SPL, 1 kHz at 1% T.H.D. 121 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (typical)
Ph: 111 dB, 1 kHz at Max SPL
B: 97 dB, 1 kHz at Max SPL
96 dB, 1 kHz at Max SPL
85 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio1
59 dB, 1 kHz at 1 Pa*
58 dB, 1 kHz at 1 Pa*
200 ohms
270 ohms
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 49
pro series multipurpose microphones
PRO31
PRO41
PRO61
cardioid
cardioid
hypercardioid
Dynamic handheld microphones
The Pro Series handheld dynamic microphones feature a
Hi-ENERGY® neodymium magnet for improved output and
transient response.
PRO31
£59.00
Cardioid dynamic microphone
• Designed for close-up vocal use.
• Silent on-off operation switch.
PRO31QTR
£49.00
Cardioid dynamic microphone
• PRO31 including an XLRF to 6,3 m jack cable.
PRO41
£59.00
C ardioid dynamic microphone
• Provides natural, full-range vocal reproduction.
• Silent on-off operation switch.
PRO61
£79.00
Hypercardioid dynamic microphone
• Premier Pro Series vocal microphone delivers excellent gain
before feedback and outstanding stage presence.
Included accessories:
AT8470 stand clamp, threaded
adapter, 15’ XLRF- to XLRM-type
cable, pouch
Specifications
PRO31 / QTRPRO41
PRO61
Elements Dynamic DynamicDynamic
Frequency Response
60-13,000 Hz
90-16,000 Hz
70-16,000 Hz
Open Circuit Sensitivity – 55 dB (1.7 mV)
–55 dB (1.7 mV)
–55 dB (1.7 mV)
(re 1 V at 1 Pa*)
Impedance600 ohms300 ohms300 ohms
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
50 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
pro series multipurpose microphones
PRO8HEx
PRO25ax
hypercardioid
hypercardioid
Dynamic instrument microphone
PRO25ax
£149.00
igh-SPL hypercardioid dynamic instrument microphone
H
• Ideal for kick drum, percussion, brass, and other highly
dynamic instruments.
Included accessories:
AT8471 isolation clamp, threaded
adapter, pouch.
Headworn microphone
PRO8HEx
£79.00
H ypercardioid Hi-ENERGY® dynamic headworn
microphone
• Low-visibility, lightweight headband and cushioned support
pads provide stable, comfortable fit.
Included accessories:
AT8139L large windscreen, AT8139S
small windscreen, AT8439 cable clip
Specifications
PRO25axPRO8HEx
ElementsDynamic
Dynamic
Frequency Response
30-12,000 Hz
200-18,000 Hz
Open Circuit Sensitivity –54 dB (1.9 mV), re 1 V at 1 Pa*
–55 dB (1.7 mV), 1 V at 1 Pa*
Impedance600 ohms600 ohms
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 51
pro series multipurpose microphones
PRO70
PRO35
PRO37
cardioid
cardioid
cardioid
Condenser instrument microphones
PRO70
£129.00
PRO35
£199.00
Cardioid condenser lavalier / instrument microphone
• Provides articulate, full-sounding voice and instrument
pickup
• E xcels in pickup of acoustic guitar with included AT8444
guitar mount.
Cardioid condenser clip-on instrument microphone
• Ideal for sax, toms, brass and percussion.
• Excels in high-SPL applications.
PRO37
£179.00
Small-diaphragm cardioid condenser microphone
• Ideal for acoustic guitar, overheads, piano and group vocals.
PRO70 accessories:
power module (attached),
AT8411 clothing clip,
AT8444 instrument adapter,
windscreen, battery, pouch.
Specifications
Elements
Frequency Response
Low Frequency Roll-Off
Open Circuit Sensitivity
re 1V at 1 Pa*
Impedance
Max. Input Sound Level
1 kHz at 1% T.H.D.
PRO35 accessories:
AT8538 power module,
AT8418 UniMount®, pouch.
PRO37 accessories:
AT8405a stand clamp,
threaded adapter,
AT8159 windscreen, pouch.
PRO70PRO35PRO37
Fixed charge back plate permanently polarized condenser
100-14,000 Hz
50-15,000 Hz
80 Hz, 12 dB / octave
80 Hz, 18 dB / octave
Ph: – 45 dB (5.6 mV)
B: – 45 dB (5.6 mV)
– 45 dB (5.6 mV)
30-15,000 Hz
– 42 dB (7.9 mV)
Ph: 200 ohm-B: 200 ohm 250 ohm200 ohm
123 dB SPL
145 dB SPL
141 dB SPL
Dynamic Range (typical) 96 dB, 1kHz at max. SPL 115 dB, 1kHz at max. SPL 112 dB, 1kHz at max. SPL
Signal-to-Noise Ratio 67 dB, 1 kHz at 1 Pa*
64 dB, 1 kHz at 1 Pa*
65 dB, 1 kHz at 1 Pa*
Switch
Off, on-flat, on-roll-off Flat, roll-off
*1 Pascal= 10 dynes/cm2 = 10 microbars = 94 dB SPL
52 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
pro series multipurpose microphones
PRO24
PRO24-CMF
stereo
Stereo condenser microphones
PRO24
£99.00
Stereo condenser microphone
• Designed for a wide range of stereo applications.
• Battery-free operation when used with recording devices
that provide ”plug-in power” at the mic input.
Included accessories:
AT8405a stand clamp & threaded
adapter, battery, windscreen, soft
protective pouch.
PRO24-CMF
£113.00
Stereo condenser microphone
• Includes: windscreen, battery, video camera shoe mount, soft
protective pouch, fur socks AT8123.
Included accessories:
AT8472 video-camera shoe mount, LR44
battery, windscreen, AT8123 fur socks,
soft protective pouch.
Specifications
PRO24 / PRO24CMF
Elements
Fixed charge back plate permanently polarized condenser
Frequency Response
100-17,000 Hz
Open Circuit Sensitivity
– 50 dB (3.1 mV), re 1V at 1 Pa*
Impedance600 ohm
Max. Input Sound Level
119 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (typical)
82 dB, 1kHz at max. SPL
Signal-to-Noise Ratio 57 dB, 1 kHz at 1 Pa*
*1 Pascal= 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 53
midnight blues® multipurpose microphones
MB 1k
MB 2k
MB 3k
MB 4k
cardioid
hypercardioid
hypercardioid
cardioid
The all-metal construction and velvety finish gives a secure,
comfortable grip.
Dynamic microphones
MB 1k
£39.00
D ynamic vocal microphone with high-output
MB 2k
£44.00
D ynamic instrument microphone
• For amplified and acoustic instruments at an attractive price.
MB 3k
£49.00
Dynamic vocal microphone with extended response
• E xtended frequency response for optimal vocal reproduction.
Cardioid condenser microphone
MB 4k
£99.00
C ardioid condenser microphone
• A quality studio microphone at a quality price.
Specifications
MB 1k
MB 2k/MB 3k MB 4k
Elements
Neodymium Neodymium
Dynamic
Dynamic
Fixed-charge back
plate permanently
polarized condenser
Frequency Response
80-20,000 Hz
80-12,000 Hz
60-14,000 Hz
Open Circuit Sensitivity – 53 dB (2.2 mV)
– 54 dB (1.9 mV)
re 1V at 1 Pa*
Ph: – 46 dB (5.0 mV)
B: – 48 dB (3.9 mV)
Impedance600 ohms600 ohms
Ph: 200 ohms - B: 250 ohms
Switch
MagnaLock™ ON/OFF MagnaLock™ ON/OFF ON/OFF
Max. Input Sound Level –
–
1 kHz at 1% T.H.D.
Phantom: 137dB SPL
Battery: 125dB SPL,
Signal-to-Noise-Ratio 70 dB, 1 kHz at 1 Pa*
Dynamic Range (typical) – Ph: 113 dB - B:101 dB**
–
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
54 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
midnight blues® multipurpose microphones
MB/Dk5
£199.00
Midnight Blues 5 microphone drum pack
The MB/Dk5 Drum Pack includes a core selection of five
microphones specifically engineered for drum applications.
The four included MB5k snare/tom microphones and one
MB6k kick microphone feature a low-profile design for
minimum visibility and versatile placement options around
the drum kit. Also included in the package are four AT8665
drum-rim microphone mounts and a durable carrying case.
MB/Dk7
£349.00
Midnight Blues 7 microphone drum pack
Studio-quality performance.
The comprehensive MB/Dk7 Drum Pack expands on the
MB/Dk5 Drum Pack with the addition of two MB4k cardioid
condenser microphones ideal for drum overhead miking.
MB 5k
MB 6k
cardioid
cardioid
Specifications
MB 5k
MB 6k
ElementsDynamic
Dynamic
Frequency Response
100-12,000 Hz
60-12,000 Hz
Open Circuit Sensitivity – 58 dB (1.2 mV), re 1V at 1 Pa* – 59 dB (1.1 mV), re 1V at 1 Pa*
Impedance500 ohms500 ohms
*1 Pascal= 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 55
atr series multipurpose microphones
ATR6250
stereo dual
cardioid
ATR6250
£45.00
Stereo condenser video/recording microphone
Capture the realism of live sound with two mics in one. The
ATR6250 provides extremely affordable, high-quality stereo
pickup in a single microphone.
ATR6550
cardioid
supercardioid
ATR6550
£75.00
Condenser shotgun microphone
Crisp & intelligible pickup—far away or up close.
• Two range settings: “Normal” for close & medium-distance;
“Tele” for long-distance.
Specifications
ATR6250ATR6550
Elements Stereo condenser
Condenser
Frequency Response
70-18,000 Hz
70-18,000 Hz
Open Circuit Sensitivity – 50 dB
Normal: – 56 dB
Tele: – 45 dB
Impedance 600 ohms
Normal: 1,000 ohms
Tele: 2,200 ohms
Cables Camera Cable: 0.2 m long, 3.5 mm (1/8”)
1 m long, permanently attached
stereo to 3.5 mm (1/8”) stereo
cable with 3.5 mm (1/8”)
Recording Cable: 3 m long, 3.5 mm (1/8”) stereo to
two 3.5 mm (1/8”) mono plugs
Accessories Furnished Professional camera mount; Camera mount; microphone stand
interchangeable mic-stand base; clamp; foam windscreen; AA battery
foam windscreen; two 3.5 mm
(1/8”) to 6.3 mm (1/4”) mono
adapters; AA battery
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
56 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
atr series multipurpose microphones
ATR3350
omnidirectional
ATR3350
£28.00
Omnidirectional condenser lavalier microphone
Audio-Technica’s newscaster-style omnidirectional
ATR3350 lavalier is engineered for intelligible, accurate voice
reproduction.
ATR3350iS
omnidirectional
ATR3350iS
£33.00
Omnidirectional condenser lavalier microphone
Included smartphone adapter provides instant compatibility
with newer smartphones (Android, iPhone, more).
ATR4697
omnidirectional
ATR4697
£25.00
Omnidirectional condenser boundary microphone
Ideal for meetings & teleconferencing, the ATR4697 is a
condenser boundary microphone with an omnidirectional polar
pattern.
Specifications
ATR3350 / ATR3350iS ATR4697
ElementsCondenser
Condenser
Frequency Response 50-18,000 Hz
50-15,000 Hz
Open Circuit Sensitivity – 54 dB
– 46 dB
Impedance 1,000 ohms1,000 ohms
Cable 6 m terminated 1.5 m terminated
with 3.5 mm (1/8”)mini-plug
Accessories Furnished Tie clip; battery; foam windscreen
Smartphone adapter (ATR3350iS only)
with 3.5 mm (1/8”) mini-plug
6.3 mm (1/4”) adapter plug
*1 Pascal = 10 dynes/cm = 10 microbars = 94 dB SPL
2
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 57
broadcast & production microphones
BP4071L - BP4071 - BP4073
line + gradient
Line + gradient condenser microphones
Based on extensive in-the-field research and user input,
Audio-Technica’s BP4071L, BP4071 and BP4073 microphones
are ideal for creating high-quality audio for documentaries
and feature films, wildlife recording and theatre sound
reinforcement. The highly directional mics offer low self-noise
and extremely focused pickup.
BP4071L
£990.00
Line + gradient condenser microphone, 539 mm long
BP4071
£890.00
• O verall length of 539 mm with an extremely narrow, highly
directional pickup pattern.
Line + gradient condenser microphone, 395 mm long
BP4073
£780.00
Line + gradient condenser microphone, 233 mm long
Specifications
Element
Polar Pattern
Frequency Response
Low Frequency Roll-Off
Open Circuit Sensitivity
Impedance
Max. Input Sound Level
Noise (A-weighted)
Dynamic Range (typical)
Signal-to-Noise Ratio
Switches
Accessories Furnished
BP4071L / BP4071 / BP4073
Externally polarized (DC bias) condenser
Line + gradient
20-18,000 Hz / 20-20000 Hz / 20-20000 Hz
80 Hz, 18 dB/octave
– 29 dB (35.5 mV), re 1V at 1 Pa*
50 ohms
141 dB SPL, 1 kHz at 1% T.H.D.
151 dB SPL, with 10 dB pad (nominal)
13 dB SPL
128 dB, 1 kHz at Max. SPL
81 dB, 1 kHz at 1 Pa
Flat, roll-off; 10 dB pad (nominal)
AT8405a stand clamp for 5/8”-27 threaded stands;
5/8”-27 to 3/8”-16 threaded adapter; AT8145 windscreen; AT8147 windscreen (L) ; protective carrying case; two O-Rings
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
58 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
Windscreen
information
( see p76 to p79)
BP4027 - BP4029
figure-of-eight
line + gradient
stereo
Stereo shotgun microphones
Based on models originally developed for the Sydney Olympics
in 2000, the BP4027 and BP4029 Stereo Shotgun models are
engineered for high-end broadcast and production use. Both
microphones feature independent line-cardioid and figure-ofeight elements configured in an MS (Mid-Side) arrangement
with switch-selectable internal matrixing.
BP4027
£930.00
380 mm phantom only stereo shotgun microphone
BP4029
£810.00
236 mm phantom only stereo shotgun microphone
Specifications
Elements
Frequency Response
Low frequency roll-off
Open circuit sensitivity (re 1V at 1 Pa*)
Impedance
Max. Input Sound Level BP4027 / BP4029
Mid
Side
LR stereo
Fixed-charge back plate permanently polarized condenser
30-20,000 Hz / 40-20,000 Hz
80 Hz, 12 dB/octave
– 30 dB (31,6mV)
– 34 dB (19,9 mV) – 36 dB (15,8 mV)
200 ohms
123 dB SPL
127 dB SPL
126 dB SPL
Signal-to-Noise Ratio (1 kHz at 1 Pa*)
Dynamic Range
72 dB SPL
68 dB SPL
70 dB SPL
101 dB
101 dB
102 dB
Switches
Cable
Mid Side, LR-Wide, LR-Narrow; flat, roll-off
Accessories Furnished
AT8405a stand clamp for 5/8”-27 threaded stands;
AT8135 foam windscreen, 5/8”-27 to 3/8”-16
threaded adapter; protective carrying case; two O-Rings
(1 kHz at 1% T.H.D.)
(typical, 1 kHz at 1% T.H.D.)
Dual 0.61m shielded two-conductor,
terminated in two XLR3M-type connectors
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 59
broadcast & production microphones
AT8015
AT8035
line + gradient
Line + gradient condenser microphone
Designed for video production and broadcast (ENG/EFP) audio
acquisition, the AT8015 and AT8035 provide the narrow
acceptance angle desirable for long-distance sound pickup.
They offer excellent sound rejection from the sides and rear,
switchable low-frequency roll-off, and the convenience of
battery or phantom power operation.
AT8015 £315.00
4 60 mm line + gradient condenser microphone
AT8035 £290.00
3 69 mm line + gradient condenser microphone
Specifications
Element
Polar Pattern
Frequency Response
Low Frequency Roll-Off Open Circuit Sensitivity Impedance Max. Input Sound Level Dynamic Range (typical) Signal-to-Noise Ratio
Switch Accessories Furnished AT8015 / AT8035
Fixed-charge back plate permanently polarized condenser
Line + gradient
40-20,000 hz
80 hz, 18 dB/octave
Phantom: -38 dB (12.5 mv) - Battery: -39 dB (11.2 mv), re 1V at 1 Pa*
Phantom: 250 ohms / Battery: 300 ohms
Phantom: 132 dB SPL/ Battery: 120 dB SPL, 1 kHz at 1% T.H.D.
Phantom: 110 dB / Battery: 98 db, 1 kHz at Max SPL
72 dB, 1 kHz at 1 Pa*
Flat, roll-off
AT8405a stand clamp for 5/8”- 27 threaded stands;
5/8”- 27 to 3/8”-16 threaded adapter; AT8135 windscreen;
battery; protective carrying case; two O-Rings
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
60 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
Windscreen
information
( see p76 to p79)
AT897
AT875R
line + gradient
Short shotgun sized to stay out of the frame
AT897
£199.00
279 mm line + gradient condenser microphone
Audio-Technica’s AT897 is designed for field audio acquisition
in film/TV/video production, professional recording, and
broadcast applications.
• Two versatile powering options: phantom
and internal AA battery.
Line + gradient condenser short microphone
A small, discrete phantom powered shotgun, for use in field
production where a compact, lighter camera mounted line
microphone is required. The AT875R is ideal for corporate,
event and wild life videographers or field sound engineers.
AT875R £140.00
175 mm line + gradient condenser microphone
Specifications
Element
Polar Pattern
Frequency Response
Low Frequency Roll-Off Open Circuit Sensitivity (re 1V at 1 Pa*)
AT897AT875R
Fixed-charge back plate permanently polarized condenser
Line + gradient
Line + gradient
20-20,000 hz
90Hz-20,000Hz
80 hz, 12 dB/octave
Phantom: – 40 dB (10.0 mV)
Battery: – 41 dB (8.9 mV)
– 30 dB (31.6 mV)
Impedance Phantom: 200 ohms - Battery: 300 ohms100 ohms
Max. Input Sound Level Phantom: 129 dB SPL
127 dB SPL
(1 kHz at 1% T.H.D.)
Battery: 115 dB SPL
Dynamic Range (typical) Phantom: 112 dB, 1 kHz at Max SPL
Battery: 98 dB, 1 kHz at Max SPL
107 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
77 dB, 1 kHz at 1 Pa*
74 dB, 1 kHz at 1 Pa*
Switch Flat, roll-off (recessed)
Accessories Furnished AT8405a stand clamp for 5/8”- 27 threaded stands;
AT8134 windscreen; battery; 5/8”- 27 to 3/8”-16 threaded adapter;
protective carrying case; two O-Rings
*1 Pascal = 10 dynes/cm = 10 microbars = 94 dB SPL
2
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 61
broadcast & production microphones
AT8024
mono
Included accessories:
AT8124 foam windscreen;
AT8124F fuzzy windscreen (fur
cover for AT8124); AA battery.
stereo
Selectable line-cardioid, mono, and internally matrixed
mid-side stereo modes provide the flexibility to focus the
recording on a single sound source or to widen the field for
outstanding sonic realism. In either mode, the AT8024 delivers
audio that is dramatically better than that supplied by the
camera’s internal microphone.
AT8024
£179.00
Stereo/mono camera-mount microphone
Specifications
AT8024
Element : Fixed-charge back plate, permanently polarized condenser
Frequency Response 40-15,000 Hz
Low Frequency Roll-Off 80 Hz, 12 dB/octave
Open Circuit Sensitivity –37 dB (14.1 mV) re 1V at 1 Pa* (Mono & LR Stereo)
Impedance 50 ohms
Maximum Input Sound Level 128 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (typical) Mono: 106 dB, 1 kHz at Max SPL; Stereo: 104 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio Mono: 72 dB, 1 kHz at 1 Pa*; Stereo: 70 dB, 1 kHz at 1 Pa*
Switch Mono, M-S Stereo; Three-position: attenuator; flat, roll-off
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
62 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
BP40
hypercardioid
AT8484
Shock Mount
(optional accessory)
Large-diaphragm dynamic broadcast
microphone
A dynamic vocal microphone with rich, natural condenser-like
sound for a variety of applications – including radio, overdubs,
post-production and more – the BP40’s hypercardioid polar
pattern provides isolation of the desired sound source and
maximum off-axis rejection when working in close production
environments. Its optimised capsule placement helps maintain
a commanding vocal presence even at a distance, while the
multistage windscreen provides superior internal pop filtering.
It also includes a switchable 100 Hz high-pass filter to provide
even more pop protection.
BP40 £290.00
L arge-diaphragm dynamic microphone
AT8484 £87.99
Microphone shock-mount
Specifications
BP40
ElementDynamic
Frequency Response:
50-16,000 Hz
Open Circuit Sensitivity:
– 48 dB (3.9 mV) re 1V at 1 Pa*
Impedance:
450 ohms
Switches:
Flat, roll-off
Accessories Furnished:
AT8483 mounting clamp for 5/8”-27 threaded stands;
5/8”-27 to 3/8”-16 threaded adapter; soft protective pouch
Optional Accessory: AT8484 shock mount for 5/8”-27 threaded stands
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 63
broadcast & production microphones
AT899
AT898
cardioid
omnidirectional
Subminiature condenser microphones
AT898 and AT899 Systems. With Audio-Technica’s legendary
innovations in electro-acoustic design, Audio-Technica’s
Broadcast & Production Subminiature Lavalier Microphones
are ideal for applications where quality sound and unobtrusive
design are imperative.
AT898
£279.00
Subminiature cardioid condenser microphone
AT898c
£149.00
Unterminated version of AT898
AT899
£279.00
Subminiature omnidirectional condenser microphone
AT899c
£139.00
Unterminated version of AT899, 1.40 m cable
AT899c-TH
£139.00
Unterminated version of AT899 in beige
AT899AK
£54.00
Accessories pack for AT899 and AT898
AT899AK-TH
£54.00
Accessories pack in beige for AT899c-TH
Specifications
AT898AT899
Element
Fixed-charge back plate permanently polarized condenser
Frequency Response 200-15,000 Hz
20-20,000 Hz
Low Frequency Roll-Off 80 hz, 12 dB/octave
Open Circuit Sensitivity Phantom: – 43 dB (7.0 mV), re 1V at 1 Pa* Battery: – 46 dB (5.0 mV), re 1V at 1 Pa*
Impedance Max. Input Sound Level Phantom: 200 ohms - Battery: 250 ohms
Phantom: 131 dB SPL
Battery : 115 dB SPL
138 dB SPL
116 dB SPL
Dynamic Range (typical) Phantom: 100 dB
Battery: 84 dB 108 dB
86 dB
(1 kHz at 1% T.H.D.)
(1 kHz at max SPL)
Signal-to-Noise Ratio 63 dB, 1 kHz at 1 Pa* 64 dB, 1 kHz at 1 Pa*
Switch flat, roll-off (recessed)
Cable 3.0 m long (permanently attached to microphone),
2.0 mm diameter, 2-conductor, shielded cable
with TA3F output connector that mates with TB3M
jack on power module
Accessories Furnished AT8537 power module; AT8439 cable clip;
clothing clip base; viper clip base; magnet clip
base and plate with lanyard; three single mic
holders; two double mic holders; two windscreens;
battery; protective carrying case
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
64 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
Windscreen
information
( see p76 to p79)
BP896
omnidirectional
With a capsule diameter not much bigger than the head of
a pin, Audio-Technica’s smallest-ever lavalier microphone
virtually disappears in props or clothing to create highestquality audio for broadcast and theatre sound reinforcement.
Offered in wired & wireless models, the BP896 comes
generously equipped with an extensive accessory kit: holders,
windscreens, element covers & more.
Subminiature wireless headworn microphones
for use with Audio-Technica UniPak® wireless systems
BP896cW
£219.00
Less power module; 1.4 m cable terminated with locking 4-pin
connector for audio-technica UniPak® wireless systems
BP896cW-TH
£219.00
Same as BP896cW, but in “theatre” colour (beige)
Subminiature headworn ­microphones for wired applications
BP896
£329.00
Subminiature omnidirectional condenser lavalier
microphone, includes AT8539 power module
BP896-TH
£329.00
Same as BP896, but in “theatre” colour (beige)
For use with other manufacturer’s wireless
transmitters please see complete description at:
eu.audio-technica.com
Specifications
BP896
Element Fixed-charge back plate, permanently polarized condenser
Frequency Response 20-20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave (wired only)
Open Circuit Sensitivity – 49 dB (3.5 mV) re 1V at 1 Pa*
Impedance 250 ohms (wired only)
Max. Input Sound Level
135 dB SPL, 1 kHz at 3% T.H.D.
Dynamic Range (typical) 104 dB, 1 kHz at Max SPL (wired only)
Signal-to-Noise Ratio 63 dB, 1 kHz at 1 Pa*
Switch Flat, roll-off (wired only)
Cable 1.4 m long (permanently attached to microphone),
1.6 mm Ø, 2-conductor shielded cable with locking 4-pin
connector (wired only)
Accessories Furnished BP896: AT8539 power module (wired only); two AT8157 windscreens;
six element covers (2 white, 2 beige, 2 black); viper clip base;
clothing clip base; 3 black single mic holders; 2 black double mic
holders; belt clip (wired only); carrying case
BP896-TH: AT8539 power module (wired only); two AT8157-TH
windscreens; six element covers (2 white, 2 beige, 2 black);
viper clip base; clothing clip base; 3 beige single mic holders;
2 beige double mic holders; belt clip (wired only); carrying case
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 65
broadcast & production microphones
BP892
BP892
MicroSet®
Windscreen
information
omnidirectional
AT8464
( see p76 to p79)
Omnidirectional condenser headworn microphone
Audio-Technica’s high-SPL BP892 MicroSet ® offers the
ultimate in low-profile, high-performance audio. Delivering
clear and accurate sound in a tiny package, the ultra-lightweight
BP892 hooks securely behind either ear and can be worn for
hours without fatigue.
Subminiature wireless headworn microphones for
use with Audio-Technica UniPak® wireless systems
BP892cW Less power module; 1.4 m cable terminated with locking
£269.00
4-pin connector for Audio-Technica UniPak® wireless systems
BP892cW-TH
£269.00
Same as BP892cW, but in “theatre” colour (beige)
Subminiature headworn ­microphones for wired applications
BP892
£359.00
Includes AT8539 (see description power moduler module).
BP892-TH
£359.00
Same as BP892, but in “theatre” colour (beige).
Audio-Technica’s dual-ear microphone mount
AT8464 Convert your single ear-worn BP892 or AT892 MicroSet®
£37.00
to a dual-ear-worn unit for maximum stability and comfort.
AT8464-TH
£37.00
Same as AT8464, but in “theatre” colour (beige).
For use with other manufacturer’s wireless transmitters please
see complete description at: eu.audio-technica.com
Specifications
BP892
Element Fixed-charge back plate, permanently polarized condenser
Frequency Response 20-20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave (wired only)
Open Circuit Sensitivity – 49 dB (3.5 mV) re 1V at 1 Pa*
Impedance 250 ohms (wired only)
Maximum Input Sound Level 135 dB SPL, 1 kHz at 3% T.H.D.
Dynamic Range (typical) 104 dB, 1 kHz at Max SPL (wired only)
Signal-to-Noise Ratio 63 dB, 1 kHz at 1 Pa*
Switch Flat, roll-off (wired only)
Accessories Furnished BP892: AT8539 power module (wired only); AT8440 cable clip; two AT8157
windscreens; two AT8156 element covers; moisture guard; belt clip
(wired only); carrying case; AT8464 dual-ear microphone mount
BP892-TH: AT8539 power module (wired only); AT8440 cable clip; two AT8157-TH
windscreens; two AT8156-TH element covers; moisture guard; belt clip
(wired only); carrying case; AT8464-TH dual-ear microphone mount
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
66 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
BP893
MicroEarset®
BP893
omnidirectional
Omnidirectional condenser headworn microphone
ith its ergonomically molded earpiece and unobtrusive
W
one-inch boom, Audio-Technica’s BP893 MicroEarset ®
offers inconspicuous placement along with clear, natural
vocal pickup. Its lightweight low-profile design makes the
microphone ideal for use in theatrical performances, houses of
worship and broadcast studios.
Subminiature wireless headworn microphones for
use with Audio-Technica UniPak ® wireless systems
BP893cW
£215.00
Less power module; 1.4 m cable terminated with locking
4-pin connector for audio-technica UniPak ® wireless systems.
BP893cW-TH
£215.00
Same as BP893cW, but in “theatre” colour (beige).
Subminiature wireless headworn microphones
for wired applications
BP893
£309.00
Includes AT8539 (see description power moduler module).
BP893-TH
£309.00
Same as BP893, but in “theatre” colour (beige).
For use with other manufacturer’s wireless
transmitters please see complete description at:
eu.audio-technica.com
Specifications
BP893
Element Fixed-charge back plate, permanently polarized condenser
Frequency Response 20-20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave (wired only)
Open Circuit Sensitivity – 34 dB (19.9 mV) re 1V at 1 Pa*
Impedance 245 ohms (wired only)
Maximum Input Sound Level 114 dB SPL, 1 kHz at 3% T.H.D.
Dynamic Range (typical) 88 dB, 1 kHz at Max SPL (wired only)
Signal-to-Noise Ratio 68 dB, 1 kHz at 1 Pa*
Switch Flat, roll-off (wired only)
Accessories Furnished BP893: AT8539 power module (wired only); AT8440 cable clip;
two AT8157 windscreens; two AT8156 element covers;
moisture guard; belt clip (wired only); carrying case
BP893-TH: AT8539 power module (wired only); AT8440 cable clip;
two AT8157-TH windscreens; two AT8156-TH element covers; moisture
guard; belt clip (wired only); carrying case
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 67
broadcast & production microphones
BP894
cardioid
BP894
MicroSet®
Subminiature cardioid condenser headworn microphone
The BP894 features a rotating capsule housing with
talk-side indicator for use on either ear and perfect polar
pattern placement. The MicroSet BP894 takes headworn
microphones to the next level, by allowing the cardioid capsule
to be aimed directly at the sound source.
AT8464
dual-ear microphone mount
68 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
BP894 Subminiature cardioid condenser headworn
£399.00
microphone, includes AT8539 power module.
BP894-TH
£399.00
Same as BP894, but in “theater” colour (beige).
BP894cW Less power module; 1.4 m cable terminated with
£299.00
locking 4-pin connector for A-T UniPak ® wireless systems.
BP894cW-TH
£299.00
Same as BP894cW, but in “theater” colour (beige).
For use with other manufacturer’s wireless
transmitters please see complete description at:
eu.audio-technica.com
included accessories:
Every BP894 comes with key accessories including a hard-style
carry case, two windscreens, moisture guard and a cable clip.
The wired model also includes a belt clip to attach the power
module to the wearer’s belt or pocket.
Specifications
BP894
Element : Fixed-charge back plate, permanently polarized condenser
Frequency Response 20-20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave (wired only)
Open Circuit Sensitivity –49 dB (3.5 mV) re 1V at 1 Pa*
Impedance 250 ohms (wired only)
Maximum Input Sound Level 135 dB SPL, 1 kHz at 3% T.H.D.
Dynamic Range (typical) 104 dB, 1 kHz at Max SPL (wired only)
Signal-to-Noise Ratio 63 dB, 1 kHz at 1 Pa*
Switch Flat, roll-off (wired only)
Accessories Furnished
BP894: AT8539 power module (wired only); AT8464 dual-ear microphone
mount; AT8440 cable clip; two AT8163 windscreens; moisture guard;
belt clip (wired only); carrying case
BP894-TH: AT8539 power module (wired only); AT8464-TH dual-ear microphone
mount; AT8440 cable clip; two AT8163-TH windscreens; moisture
guard; belt clip (wired only); carrying case
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 69
broadcast & production microphones
AT831R
AT831b
AT831R accessories:
AT8538 remote power module;
AT8444 guitar adapter; AT8419 clothing clip;
AT8116 windscreen; protective carrying case.
cardioid
Microphones with power modules
AT831R
£199.00
Miniature cardioid condenser microphone (phantom only)
For musical instruments and lavalier use where feedback or
room noise is a problem.
AT831b
£165.00
Miniature cardioid condenser microphone (both battery
and phantom)
Same as AT831R but both battery and phantom power.
AT831c
£75.00
Unterminated version of AT831
Less power module.
AT831b accessories:
AT8531 power module; AT8444 guitar adapter;
AT8417 clothing clip; AT8116 windscreen;
battery; protective carrying case.
Specifications
AT831RAT831b
Element
CondenserCondenser
Frequency Response40 -16,000 Hz
40 -18,000 Hz
Open Circuit Sensitivity
– 42 dB (7.9 mV) Phantom: – 44 dB (6.3 mV)
(re 1V at 1 Pa*) Battery: – 46 dB (5.0 mV)
Impedance
250 ohms Phantom: 200 ohms
Battery: 270 ohms
Max. Input Sound Level 141 dB SPL
(1 kHz at 1% T.H.D.)
Phantom: 135 dB SPL
Battery: 121 dB SPL
Signal-to-Noise Ratio
Low Frequency Roll-Off
65 dB, 1 kHz at 1 Pa*
65 dB, 1 kHz at 1 Pa*
80 Hz, 18 dB/octave
80 Hz, 18 dB/octave
Phantom Power Requirements
11-52V DC, phantom only 11-52V DC or 1.5V AA/UM3
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
70 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
AT803
AT803 accessories:
AT8531 power module; AT8419 clothing clip;
AT8116 windscreen; battery;
protective carrying case.
omnidirectional
Omnidirectional clip-on microphones
F or lavalier and musical instrument use.
Battery or phantom powered.
AT803
£159.00
Miniature omnidirectional condenser microphone
AT803c
£62.00
Unterminated version of AT803.
Less power module.
MT830R
MT830R accessories:
AT8538 power module;
clothing clip; windscreens.
omnidirectional
MT830R
£200.00
Miniature omnidirectional condenser microphone
For use as lavalier, or may be worn in clothing or hair.
Phantom power only.
MT830c
£70.00
Unterminated version of MT830R.
Less power module.
Specifications
AT803MT830R
Element CondenserCondenser
Frequency Response30 -20,000 Hz
30 -20,000 Hz
Open Circuit Sensitivity
Phantom: – 44 dB (6.3 mV)
– 34 dB (19.9 mV)
(re 1V at 1 Pa*)
Battery: – 46 dB (5.0 mV)
Impedance
Phantom: 200 ohms
Battery: 270 ohms
200 ohms Max. Input Sound Level Phantom: 135 dB SPL
Battery: 121 dB SPL
131 dB SPL
(1 kHz at 1% T.H.D.)
Signal-to-Noise Ratio
Low Frequency Roll-Off
Power Requirement
66 dB, 1 kHz at 1 Pa*
70 dB, 1 kHz at 1 Pa*
80 Hz, 18 dB/octave
80 Hz, 18 dB/octave
11-52V DC or 1.5V AA/UM3 11-52V DC, phantom only
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 71
broadcast & production microphones
AT8022
BP4025
stereo
stereo
AT8022
£379.00
X /Y stereo microphone
This stereo microphone uses a unique coincident capsule
configuration to produce an accurate stereo image in a very
small housing. With optional balanced or unbalanced output
the AT8022 is extremely versatile for all stereo microphone
applications including field recording, ambient pickup and
interviews. Studio / broadcast stereo microphone
BP4025 £475.00
Large diaphragm X/Y microphone
A unique large diaphragm coincident capsule configuration
offers a pristine stereo image with an exceptional low noise
floor. A standard for top quality broadcast ambient recordings,
this microphone is as happy in the studio as it is in the high sound
pressure volumes of motoring events offering an astounding
155dB SPL, 80Hz roll off and 10dB pad.
AT8022 accessories:
AT8405a stand clamp for 5/8”-27 threaded stands;
windscreen; battery; soft protective pouch.
Specifications
Element
Channel Balance Frequency Response Low Frequency Roll-Off Open Circuit Sensitivity BP4025 accessories:
AT8405a stand clamp for 5/8”-27 threaded
stands; windscreen; soft protective pouch.
AT8022BP4025
Fixed-charge back plate permanently polarized condenser
< 2.5 dB
< 2.5 dB
20-15,000 Hz
20-17,000 Hz
80 Hz, 18 dB/octave
80 Hz, 12 dB/octave
Phantom: – 38 dB (12.5 mV) Battery: –38 dB (12.5 mV)
– 32 dB (25.1 mV)
Impedance
Max. Input Sound Level Ph: 250 ohms - B: 300 ohms
170 ohms
Phantom: 128 dB SPL
Battery: 120 dB SPL
145 dB SPL
155 dB SPL, with 10 dB pad
Dynamic Range (typical) Phantom: 109 dB
Battery: 101 dB
131 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio Switches 75 dB, 1 kHz at 1 Pa*
(re 1V at 1 Pa*)
(1 kHz at 1% T.H.D.)
(1 kHz at Max SPL)
Battery On/Off; Flat, roll-off
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
80 dB, 1 kHz at 1 Pa*
10 dB pad (nominal); Flat, roll-off
72 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
BP4001
BP4002
cardioid
omnidirectional
Windscreen
information
( see p76 to p79)
Handheld dynamic microphones
BP4001 and BP4002 dynamic microphone are tailored for
extremely clear and articulate reproduction of spoken words.
Designed to provide exceptional isolation from handling noise,
the microphone is ruggedly built to withstand the abrasion and
jostling expected with life in the field.
BP4001 £169.00
Cardioid dynamic microphone
Cardioid polar pattern reduces pickup of sounds from the sides
and rear, improving isolation of desired sound source.
BP4002
£169.00
Omnidirectional dynamic microphone
Omnidirectional polar pattern provides a natural reproduction of
surrounding ambience.
Included accessories:
AT8470 Quiet-Flex™ stand clamp for 5/8”-27 threaded
stands; 5/8”-27 to 3/8”-16 threaded adapter; foam
windscreen; carrying case; soft protective pouch
Specifications
BP4001 BP4002
ElementDynamic Dynamic
Frequency Response 80-18,000 Hz
Open Circuit Sensitivity –54 dB (1.9 mV) re 1V at 1 Pa* –56 dB (1.5 mV) re 1V at 1 Pa*
Impedance 300 ohms
80-20,000 Hz
300 ohms
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 73
broadcast & production microphones
AT8031
AT8033
AT808G
cardioid
cardioid
subcardioid
Handheld and general purpose microphones
AT8031
£175.00
C ardioid condenser handheld microphone
T he AT8031 is ideal for close-up interviews,
vocals, overheads, piano, and strings.
AT8033
£159.00
C ardioid condenser microphone
I deal for general audio acquisition such as
interviews, acoustic guitar, percussion,
overheads, vocals and more, the AT8033
features high-SPL capability and wide
frequency response.
Gooseneck microphone
AT808G
£125.00
Subcardioid moving coil dynamic console
microphone 412.7 mm long.
XLRM-type output plugs directly into
XLRF-type panel mount or console connector.
AT8031 accessories:
AT8405a stand clamp, threaded adapter,
AT8114 windscreen, battery, pouch
Specifications
Element
AT8033 accessories:
AT8405a stand clamp, threaded adapter,
AT8136 windscreen, battery, pouch
AT8031 / AT8033
AT808G
Fixed-charge back plate, permanently polarized condenser
Dynamic
Frequency Response
30-20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave
Open Circuit Sensitivity Phantom: – 44 dB (6.3 mV), re at 1Pa*
Impedance
Max. Input Sound Level
Signal-to-Noise Ratio Dynamic Range Battery: – 45 dB (5.6 mV), re at 1Pa*
200 - 5,000 Hz
–
– 60 dB (1.0 mV), re at 1Pa*
– 45 dB (5.6 mV), re at 1Pa*
Phantom: 250 ohms - Battery: 300 ohms 800 ohms
Phantom: 137 dB SPL, 1 kHz at 1% T.H.D.
Battery: 123 dB SPL, 1 kHz at 1% T.H.D.
70 dB, 1 kHz at 1 Pa*
Phantom: 113 dB, 1 kHz at Max SPL
Battery: 99 dB, 1 kHz at Max SPL
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
74 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production microphones
AT8004L
omnidirectional
AT8010
AT8004
omnidirectional
omnidirectional
Omnidirectional microphones
AT8010
£160.00
Omnidirectional condenser microphone
The AT8010 is ideal for interviews, sportscasting and for use as
the ”mono” mic in conjunction with a stereo microphone.
AT8004
£110.00
Omnidirectional dynamic microphone
he AT8004 is ideal for interviews, sportscasting and for use as
T
the ”mono” mic in conjunction with a stereo microphone.
AT8004L
£120.00
Omnidirectional dynamic microphone with extended handle
he AT8004L has been optimised for broadcasted interviews;
T
The length of 239,5mm allows the use of ”customized mic flags”
with Broacaster’s logos proudly displayed.
AT8010 accessories:
AT8405a stand clamp, threaded adapter,
AT8114 windscreen, battery, pouch
Specifications
Element
AT8004L-AT8004 accessories:
AT8405a stand clamp, threaded adapter
AT8010
AT8004 / L
Fixed-charge back plate, permanently polarized condenser
Dynamic
Frequency Response
20-20,000 Hz
Low Frequency Roll-Off 80 Hz, 18 dB/octave
Open Circuit Sensitivity Phantom:– 44 dB (6.3 mV), re 1V at 1Pa*
80-16,000 Hz
Impedance
Phantom: 250 ohms - Battery: 300 ohms
Max. Input Sound Level Phantom: 137 dB SPL, 1 kHz at 1% T.H.D.
300 ohms
Battery: – 45 dB (5.6 mV), re 1V at 1Pa*
Battery: 123 dB SPL, 1 kHz at 1% T.H.D.
Signal-to-Noise Ratio
Dynamic Range
70 dB, 1 kHz at 1 Pa*
–
– 51 dB (2.8 mV), re 1V at 1Pa*
Phantom: 113 dB, 1 kHz at Max SPL
Battery: 99 dB, 1 kHz at Max SPL
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 75
broadcast & production windshield guide
SOFT ZEP
WINDSHIELD
Windsock closed
with“velcro”
Microphone
FUR SOCKS
Foam windscreen
SOFT-ZEP SERIES
Soft-Zep for ultimate windnoise protection.
• Comfortable hand grip
• Extremely light weight
• 3/8 inch boom-pole mount
WINDSHIELD SERIES
Complete encapsulated Windshield system, for quick and
easy application in the field and superior windnoise reduction.
FUR SOCKS SERIES
stro
ng
extr
eme
l
l
l
l
–
l(*)
l
l
WINDSHIELD SERIES
l
l
l
–
l
l
l
l
FUR SOCKS SERIES l
l
–
l
l
l
l
SOFT-ZEP SERIES
ligh
t
WIN
D
norm
al
MO
UN
T
han
d
inte held
grat
ed
han
d
exte held w
rnal ith
grip
cam
era
mou
nt
stan
dm
oun
t
boo
mp
ole
Pull-on Fur Socks fit over an existing foam windshield for
enhanced windnoise protection.
(*) NEEDS ADDITIONAL E X TERNAL MOUNTING HARDWARE
76 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
broadcast & production windshield guide
BPZ-M
BPZ-L
BPZ-XL
Soft-Zep Series
The Soft-Zep is lightweight, robust and simple to use and has
a permanently mounted high quality fur windcover around an
open cell foam core and a very comfortable hand grip made
from Kraton rubber with soft gel inserts.
BPZ-M
£188.00
oft-Zep Series system with permanently mounted
S
fur windcover and pistol grip
Length 310 mm - weight 360g
BPZ-L
£188.00
oft-Zep Series system with permanently mounted
S
fur windcover and pistol grip
Length 360 mm - weight 400g
BPZ-XL
£188.00
oft-Zep system with permanently mounted
S
fur windcover and pistol grip
BPZ-M
l
l
l
l
BPZ-L
l
l
BPZ-XLl
9
7
4 02
4 02
BP
BP
4 07
1L
3
4 07
7
4 07
1
BP
BP
35
5R
AT
89
AT
87
BP
SOFT-ZEP SERIES
AT
80
gun
s
AT
801
5
Length 490 mm - weight 450g
sho
t
l
l
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 77
broadcast & production windshield guide
Windshield series
Complete encapsulated windshield systems
The Windshield is perfect for camera, boom or handheld
microphones where speed of mounting and outstanding
performance is required.
BPW-120
£74.00
Complete Windshield system - Length 120 mm
BPW-180
£74.00
Complete Windshield system - Length 180 mm
BPW-250
£74.00
Complete Windshield system - Length 250 mm
BPW-330
£74.00
Complete Windshield system - Length 330 mm
BPW-365
£74.00
Complete Windshield system - Length 365 mm
BPW-470
£74.00
Complete Windshield system - Length 470 mm
AT
800
4L
w
rvie
029
027
mik
AT
es
800
4
Inte
BP4
071
L
BP4
071
BP4
BP4
BP4
073
R
AT
897
5
875
803
AT
AT
tgu
ns
AT
sho
801
5
BPW-1
£74.00
Windscreen for reporter microphones - Length 95 mm
WINDSHIELD SERIES
BPW-120l
BPW-180
l
l
l
l
BPW-250
l
BPW-330
l
BPW-365
l
BPW-470
l
BPW-1l
78 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
l
broadcast & production windshield guide
BPF-XLAV
BPF-LAV
Fur Socks series
Windscreens for broadcast and production microphones
Fur Socks are easily pulled over the existing foam.
BPF-120
£36.00
Fur Socks for shotgun microphones - Length 120 mm
BPF-175
£36.00
Fur Socks for shotgun microphones - Length 175 mm
BPF-250
£36.00
Fur Socks for shotgun microphones - Length 250 mm
BPF-340
£38.00
Fur Socks for shotgun microphones - Length 340 mm
BPF-470
£38.00
Fur Socks for shotgun microphones - Length 470 mm
BPF-2
£36.00
Fur Socks for field microphones - Length 125 mm
for AT8022, BP4025, BP4001 and BP4002
BPF-LAV
£12.00
Fur Socks for lavalier microphones
for AT898, AT899 and BP896
BPF-XLAV
£14.40
Fur Socks for lavalier microphones for AT803, AT831,
sho
tgu
ns
AT
801
5
AT
803
5
AT
875
R
AT
897
BP4
073
BP4
071
BP4
071
L
BP4
027
BP4
029
field
mic
s
AT
802
2
BP4
025
BP4
0
BP401
002
lava
lier
s
AT
803
AT
831
MT
350
MT
830
MT
838
AT
898
AT
899
BP8
96
MT350, MT830, MT838, PRO35, PRO70, ATM350.
FUR-SOCKS SERIES
BPF-120
l
BPF-175
l l
l
BPF-250
l
BPF-340
l
l
BPF-470 l
l
BPF-2
l l l
BPF-LAV
BPF-XLAV
l
l l l l
l
l l
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 79
unipoint® installed sound microphones
UE-C
UE-H
UE-O
UE-UL
cardioid
hypercardioid
omnidirectional
UniLine ®
unipoint® interchangeables elements
Interchangeable elements are also compatible
with first-generation UniPoint ® microphones.
UE-C
£84.00
Cardioid element only.
120° pickup pattern.
UE-H
£84.00
Hypercardioid element only.
100° pickup pattern.
UE-O
£84.00
Omnidirectional element only.
360° pickup pattern.
UE-UL
£118.00
UniLine® UniPoint® element only.
90° pickup pattern.
UniPoint ® UniLine® element are only compatible
with U853 and U857 models.
80 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
unipoint® installed sound microphones
Modular gooseneck microphones
Quick-mount design plugs into any standard XLRF-type
surface or cable connector. Adapter-mount
design mounts to any 5/8”-27 stand
Interchangeables elements:
Cardioid - UniLine®
Standard length è
Long version è
A
d
( B ap t
at
t e er m
ry
an o u
d P nt
ha n t Ba
om t
p o t er
w y
er
)
A
d
( P ap t
ha e
nt r m
om
o
p o un
w
er t
on
ly )
Q
u
( P ick
ha - m
nt
o m ou
po n t
w (X
er
L
on R )
ly )
ç Quick-mount (XLR)
or
Adapter mount è
Standard length
U857Q
36,5 cm
£210.00
–
–
U857QU
48,7 cm
£250.00
–
–
Cardioid
UniLine™
Standard length
U857QLU857RLU857AL
48,1 cm
42,0 cm
42,0 cm
£220.00
£240.00
£295.00
Cardioid
Long version
U857QLUU857RLU
60,3 cm
54,3cm £260.00
£280.00
UniLine®
Long version
–
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 81
unipoint® installed sound microphones
U859QL
U855QL
cardioid
cardioid
U859QL
£156.00
Cardioid condenser quick-mount gooseneck microphone
Overall length of 48.0 cm.
Overall length of 44.8 cm.
U855QL
£80.00
Cardioid dynamic gooseneck microphone
U859QLU855QL
Specifications
Element
Polarized condenser
Frequency Response
100-16,000 Hz
150-16,000 Hz
Open Circuit Sensitivity
– 43 dB (7.0 mV) , re 1V at 1 Pa*
– 53 dB (2.2 mV) , re 1V at 1 Pa*
600 ohms
Impedance
250 ohms Max. Input Sound Level
140 dB SPL , 1 kHz at 1% T.H.D.
Dynamic Range (typical)
111 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
65 dB, 1 kHz at 1 Pa*
Low Frequency Roll-Off
80 Hz, 18 dB/octave
Dynamic
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
U873R
279,00 e
Handheld hypercardioid condenser microphone
The U873R UniPoint ® hypercardioid condenser microphone
is equipped with Audio-Technica’s UniGuard™ technology for
unsurpassed immunity from radio frequency interference.
U873R
hypercardioid
Specifications
U873R
Element
Polarized condenser
Frequency Response
70-20,000 Hz
Open Circuit Sensitivity – 41 dB (8.9 mV), re 1V at 1 Pa*
Impedance200 ohms
Max. Input Sound Level
155 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (typical)
131 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
70 dB, 1 kHz at 1 Pa*
Low Frequency Roll-Off
80 Hz, 18 dB/octave
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
82 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
unipoint® installed sound microphones
U853A
U853R
U853AW
U853RW
U853AU
U853RU
cardioid
cardioid
UniLine ®
Battery or phantom powered microphones
U853A
£260.00
Cardioid condenser hanging microphone
Low-reflectance black finish.
U853AW
£265.00
Cardioid condenser hanging microphone
White version of U853A.
U853AU
£295.00
UniLine™ condenser hanging microphone
Narrow 90º acceptance angle; low-reflectance black finish.
Phantom powered only microphones
U853R
£230.00
Cardioid condenser hanging microphone
Low-reflectance black finish.
U853RW
£230.00
Cardioid condenser hanging microphone
White version of U853R.
U853RU
£260.00
UniLine™ condenser hanging microphone
Narrow 90º acceptance angle; low-reflectance black finish.
Specifications
U853A / AW / AU
U853R / RW / RU
Element Permanently polarized condenser
Frequency Response 30-20,000 Hz
30-20,000 Hz
Open Circuit Sensitivity
(re 1 V at 1 Pa*)
Phantom: – 42 dB (7.9 mV), Battery: – 43 dB (7.0 mV)
– 39 dB (11.2 mV)
Impedance
Phantom: 200 ohms - Battery: 270 ohms250 ohms
Max. Input Sound Level
(1 kHz at 1% T.H.D.)
Phantom: 133 dB SPL Battery: 123 dB SPL
139 dB SPL
Dynamic Range (Typical)
(1 kHz at Max SPL)
Phantom: 109 dB
Battery: 99dB
115 dB
Signal-to-Noise Ratio (1 kHz at 1 Pa*)
70 dB
70 dB
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 83
unipoint® installed sound microphones
U841A
U851A
omnidirectional
cardioid
U851RW
cardioid
PivotPoint™
Engineered for maximum flexibility, the UniPoint®
boundary mic housing incorporates PivotPoint™ (On
all UniPoint® boundary microphone models except
the U841A), a unique rotating output connector that
allows the cable to exit from either the back or the
bottom of the microphone.
U841A
£229.00
Omnidirectional condenser boundary microphone
Operates on battery or phantom power; low-reflectance black
finish.
U851A
£260.00
Cardioid condenser boundary microphone
Operates on battery or phantom power; low-reflectance black
finish.
U851R
£240.00
Cardioid condenser boundary microphone
Operates on phantom power only; low-reflectance black finish.
U851RW
£240.00
Cardioid condenser boundary microphone
White version of U851R.
Specifications
U841A
U851A
U851R / RW
Element
Fixed-charge back plate, permanently polarized condenser
Frequency Response 30-20,000 Hz
30-20,000 Hz
30-20,000 Hz
Open Circuit Sensitivity Phantom: – 39 dB (11.2 mV)
– 40 dB (10.0 mV) – 34 dB (19.9 mV)
(re 1V at 1 Pa*)
Battery: – 40 dB (10.0 mV)
– 41 dB (8.9 mV)
Impedance
Phantom: 200 ohms200 ohms200 ohms
Battery: 270 ohms
270 ohms
Max. Input Sound Level
Phantom: 132 dB
Battery: 122 dB
133 dB
123 dB
134 dB
Dynamic Range (typical)
Phantom: 111 dB
Battery: 101 dB
111 dB
101 dB
108 dB
72 dB
68 dB
(1 kHz at 1% T.H.D.)
(1 kHz at Max SPL)
Signal-to-Noise Ratio 73 dB
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
84 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
unipoint® installed sound microphones
U891Rx
U891RCx
U891RWx
cardioid
cardioid
U843R
cardioid
U891Rx
£265.00
Cardioid condenser boundary microphone with switch
Operates on phantom power only; red LED status indicator;
low-reflectance black finish.
U891RWx
£265.00
Cardioid condenser boundary microphone with switch
White version of U891Rx.
U891RCx
£290.00
Cardioid condenser boundary microphone with switch
Operates on phantom power only; low reflectance.
U843R
£370.00
Three channel boundary cardioid condenser microphone
Three cardioid condenser elements are mounted in the U843R’s
housing, by default set with an angle of 120 degrees between
them to give complete 360 degree coverage.
Specifications
Element
Frequency Response
Open Circuit Sensitivity
U891Rx / RWx
Impedance
Max. Input Sound Level
200 ohms200 ohms200 ohms
(re 1V at 1 Pa*)
U891RCx
U843R
Fixed-charge back plate, permanently polarized condenser
30-20,000 Hz
30-20,000 Hz
70-16,000 Hz
– 34 dB (19.9 mV)
– 34 dB (19.9 mV)
– 37 dB (14.1 mV)
130 dB
130 dB
134 dB
104 dB
104 dB
105 dB
68 dB
68 dB
65 dB
(1 kHz at 1% T.H.D.)
Dynamic Range (typical)
(1 kHz at Max SPL)
Signal-to-Noise Ratio
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 85
propoint® installed sound microphones
PRO42
PRO44
cardioid
cardioid
PRO45
Included accessories:
AT8146/AT8146(WH) windscreen,
AT8451/AT8451(WH) steel hanger
PRO42
£89.00
PRO44
£109.00
PRO45
£99.00
cardioid
Boundary microphones
Miniature unidirectional condenser boundary microphone
Unidirectional condenser boundary microphone
Hanging microphones
Cardioid condenser hanging microphone
PRO45W
£129.00
White version of PRO45
Specifications
Element
Frequency Response
Open Circuit Sensitivity
PRO42
Impedance
Max. Input Sound Level
100 ohms100 ohms100 ohms
(re 1V at 1 Pa*)
PRO44
PRO45 / W
Fixed-charge back plate, permanently polarized condenser
70-14,000 Hz
70-16,000 Hz
70-16,000 Hz
–38 dB (12.5 mV)
–25 dB (56.2 mV)
–37 dB (14.1 mV)
134 dB
114 dB
134 dB
105 dB
86 dB
106 dB
65 dB
66 dB
66 dB
(1 kHz at 1% T.H.D.)
Dynamic Range (typical)
(1 kHz at Max SPL)
Signal-to-Noise Ratio
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
86 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
propoint® installed sound microphones
PRO47T
PRO47TL
PRO49Q
PRO49QL
cardioid
cardioid
included accessories:
AT8146 windscreen,
AT8425 5/8”-27 threaded
mounting stud
included accessory:
AT8146 windscreen
Gooseneck microphones
PRO47T
£129.00
ardioid condenser thread-mount gooseneck
C
microphone attaches to 5/8”-27 thread
• Overall length of 31.5 cm
PRO47TL
£135.00
C ardioid condenser thread-mount gooseneck
microphone attaches to 5/8”-27 thread
• Overall length of 40.1 cm
PRO49Q
£109.00
Cardioid condenser quick-mount gooseneck microphone
• Overall length of 33.2 cm
PRO49QL
£113.00
Cardioid condenser quick-mount gooseneck microphone
• Overall length of 41.8 cm
Specifications
PRO47T / TL - PRO49Q / QL
ElementCondenser
Frequency Response
70-16,000 Hz
Open Circuit Sensitivity
–37 dB (14.1 mV), re 1V at 1 Pa*
Impedance100 ohms
Maximum Input Sound 134 dB, 1 kHz at 1% T.H.D.
Signal-to-Noise Ratio
66 dB 1 kHz at 1 Pa*
Dynamic Range
106 dB, 1 kHz at Max. SPL
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 87
engineered sound® installed sound microphones
ESE-C
ESE-H
ESE-O
ESE-ML
cardioid
hypercardioid
omnidirectional
MicroLine™
engineered sound®
interchangeables elements
For microphones ES915, ES933, ES935.
ESE-C
£66.00
Cardioid element only; standard
on all ES915, ES933 and ES935 models.
120° pickup pattern.
ESE-H
£66.00
Hypercardioid element only;
standard on all ES915, ES933 and ES935 models.
100° pickup pattern.
ESE-O
£66.00
Omnidirectional element only.
360° pickup pattern.
ESE-ML
£89.00
MicroLine® element only;
standard on all ES915, ES933 and ES935 “ML” models.
90° pickup pattern.
88 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
engineered sound® installed sound microphones
Modular gooseneck microphones
Interchangeables elements:
Cardioid - Hypercardioid - MicroLine™
Length: 6”
Length: 12”
Length: 18”
ES935
Single gooseneck
Length: 21”
ES915
Double gooseneck
k
(2
Do
u
1” ble
lo
n g go o
)
s
en
ec
k
ec
en
D
o
(18 ub
” l le g
on
g ) oo
s
se
D
o
(12 ub
” l le g
on
g ) oo
(6
on
g)
Si
ng
” l le g
oo
se
ne
ne
ck
ck
ES935S - ES915S models with mute switch and LED.
Cardioid
ES935C6
ES915C12 ES915C18 ES915C21
197,3 mm 304,8 mm 457,2 mm
533,4 mm
£249,00£266,00£286,00£306,00
Hypercardioid ES935H6 ES915H12ES915H18ES915H21
197,3 mm 304,8 mm 457,2 mm
533,4 mm
£249,00£266,00£286,00£306,00
MicroLine™ ES935ML6 ES915ML12ES915ML18ES915ML21
316,3 mm
423,8 mm 576,2 mm
652,4 mm
£272,00£289,00£309,00£329,00
Cardioid with mute switch
and LED ES935SC6 ES915SC12ES915SC18ES915SC21
197,3 mm
304,8 mm 457,2 mm
533,4 mm
£279,00£290,00£310,00£330,00
Hypercardioid ES935SH6 ES915SH12ES915SH18ES915SH21
with mute switch 197,3 mm 304,8 mm
457,2 mm 533,4 mm
and LED£279,00£000,00£000,00£000,00
MicroLine™ with mute switch and LED
ES935SML6 ES915SML12ES915SML18ES915SML21
316,3 mm
423,8 mm
576,2 mm
652,4 mm
£302,00£323,00£333,00£000,00
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 89
engineered sound® installed sound microphones
ES933
cardioid
hypercardioid
MicroLine™
Hanging microphones
ES933C
£274.00
C ardioid condenser hanging microphone
ES933WC
£284.00
W hite version of ES933C (cardioid)
ES933H
£274.00
H ypercardioid condenser hanging microphone
ES933WH
£284.00
W hite version of ES933H (hypercardioid)
ES933ML
£297.00
M
icroLine® condenser hanging microphone
ES933WML
£307.00
W hite version of ES933ML (MicroLine®)
AT8452
hanger
Specifications
Element
Frequency Response
Open Circuit Sensitivity
(re 1V at 1 Pa*)
Impedance
AT8138
ML windscreen
AT8109
windscreen
AT8538 standard
power module
ES933C / WC ES933H / WH ES933ML / WML
Fixed-charge back plate, permanently polarized condenser
30-20,000 Hz
80-20,000 Hz
30-20,000 Hz
– 40 dB (10.0 mV)
– 40 dB (10.0 mV)
– 35 dB (17.7 mV)
250 ohms250 ohms250 ohms
1000 ohms without power module
Max. Input Sound Level 138 dB
138 dB
133 dB
65 dB
68 dB
(1 kHz at 1% T.H.D.)
Signal-to-Noise Ratio
65 dB
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
90 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
engineered sound® installed sound microphones
ES945
omnidirectional
ES947
cardioid
ES945
£159.00
Boundary microphones
Omnidirectional fixed charge condenser boundary
microphone. For table or ceiling mounting (maximum 45 mm
pannel thickness), in 24 mm diameter hole.
ES945W
£169.00
W hite version of ES945
ES947
£189.00
Cardioid wide range fixed charge condenser boundary
microphone. For table or ceiling mounting in 15/16” (24 mm)
diameter hole.
ES947W
£199.00
W hite version of ES947
Specifications
ES945 / W
ES947 / W
Element
Fixed-charge back plate, permanently polarized condenser
Frequency Response
40-18,000 Hz
40-12,000 Hz
Open Circuit Sensitivity – 42 dB (7.9 mV) re 1 V at 1 Pa*­­– 42 dB (7.9 mV) re 1 V at 1 Pa*
Impedance200 ohms200 ohms
Maximum Input Sound 142 dB SPL, 1 kHz at 1% T.H.D.
142 dB SPL, 1 kHz at 1% T.H.D.
Signal-to-Noise Ratio
64 dB, 1 kHz at 1 Pa*
65 dB, 1 kHz at 1 Pa*
Dynamic Range
112 dB, 1 kHz at Max SPL
113 dB, 1 kHz at Max SPL
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 91
engineered sound® installed sound microphones
ES945/LED
ES947W/LED
omnidirectional
half-cardioid
ES947SV/LED
half-cardioid
ES945/LED
£219.00
T he ES945/LED features a touch-sensitive capacitive
switch and LED status ring.
The ES945/LED is available in black only.
ES947/LED
£239.00
T he ES947/LED features a touch-sensitive capacitive
switch and LED status ring.
The ES947/LED is available in black, white and silver.
ES947W/LED
£249.00
W
hite version of ES947/LED.
ES947SV/LED
£239.00
Silver version of ES947/LED.
Specifications
Element
ES945/LEDES947/LED (W/SV)
Fixed-charge back plate, permanently polarized condenser
Frequency Response
40-19,000 Hz
40-13,000 Hz
Open Circuit Sensitivity
– 40 dB (10 mV) re 1V at 1 Pa*
– 40 dB (10 mV) re 1V at 1 Pa*
Impedance
200 ohms
200 ohms
Maximum Input Sound Level
142 dB SPL, 1 kHz at 1% T.H.D.
142 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range (typical)
113 dB, 1 kHz at Max SPL
114 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio
65 dB, 1 kHz at 1 Pa*
66 dB, 1 kHz at 1 Pa*
Switch
Touch-sensitive control: On/Mute
Output Connector
Accessory Furnished
Integral 3-pin XLRM-type
One pair isolators
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
92 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
engineered sound® installed sound microphones
Flush-mount
microphone socket
with logic I/O
AT8657/LED
£141.00
Flush-mount microphone adapter with LED ring and
touch switch for EXTERNAL control adds functionality to
quick-mount gooseneck models from the Audio-Technica’s
Engineered Sound, Unipoint and ProPoint installation mic
ranges and ES945 and ES947 boundary microphone models.
AT8656/LED
£184.00
F lush-mount microphone adapter
with LED ring and touch switch for LOCAL control
The AT8656/LED features a red / green LED to indicate
whether the microphone is on or off, and a touch button
(switch) to manually mute and unmute the microphone during
meetings and conferences.
AT8657/LEDAT8656/LED
Specifications
Output Impedance: Switch Logic:
360 ohms
High (+5V DC) when pressed;
Low (0V DC) when not pressed
Red when high (+5V DC), Green when low (0V DC), TTL compatible
LED Input:
Green when mic on;
Red when mic off
Maximum Input Voltage:
Switch:
– 0.5V to 5.5V
Touch-sensitive control: momentaryTouch-sensitive control:
toggle (talk / mute)
Input Connector :
3-pin XLRF-type
Output Connector:
5-pin XLRM-type
Accessories furnished:One pair surface isolators; gooseneck retaining ring & isolator; mounting nut; screws (3)
3-pin XLRF-type
3-pin XLRM-type
One pair isolators;
one set metal retainer ring
mounting nut
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 93
Dante® installed sound microphones
ATND971
cardioid
Audio-Technica’s ATND971 Cardioid Condenser Boundary
Network Microphone bridges the gap between audio and IT as
the first wired microphone that transmits audio and control data
together over Audinate’s Dante™ network protocol.
ATND971
£510.00
C
ardioid condenser boundary network microphone
Specifications
ATND971
Element: Fixed-charge back plate, permanently polarized condenser
Frequency response: 30-20,000 Hz
Low frequency roll-off: 80 Hz, 18 dB/octave
Maximum input levels:
117 dB SPL, 1 kHz at 1% T.H.D.
Signal-to-noise ratio:
68 dB, 1 kHz at 1 Pa*
Switches:Local Mode: Touch-sensitive capacitive type user switch function: toggle (mute on
power up), toggle (talk on power up), momentary on, momentary off;
Low-cut filter: flat, roll-off; Gain: +30 dB, +40 dB, +50 dB and OFF;
Remote Mode: Low-cut and Gain via third-party software
*1 Pascal = 10 dynes/cm2 = 10 microbars = 94 dB SPL
94 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
Dante® installed sound microphones
The ATND8677 is a Dante-enabled microphone desk stand
for use with any gooseneck microphone with a three-pin
XLRM-type output connector. The desk stand is designed
for surface-mount applications such as high-quality sound
reinforcement, conferencing, distance learning and other
demanding sound pickup applications.
ATND8677
£440.00
Microphone desk stand with Dante™ network output
The desk stand provides 12V DC phantom power by default,
which can be switched off and on.
Specifications
ATND8677
Frequency response: 20-20,000 Hz
Low frequency roll-off: 80 Hz, 18 dB/octave
Input impedance: 1.4 kW
Maximum input levels: –10 dBu @ +30 dB gain
–20 dBu @ +40 dB gain
–30 dBu @ +50 dB gain
Signal-to-noise ratio: 68 dB, 1 kHz at 1 Pa*
Switches:Local Mode: Touch-sensitive capacitive type user switch function: toggle (mute on
power up), toggle (talk on power up), momentary on, momentary off;
Low-cut filter: flat, roll-off; Gain: +30 dB, +40 dB, +50 dB and OFF;
Phantom power: 12V DC
Remote Mode: Low-cut and Gain via third-party software
*1 Pascal = 10 dynes/cm 2 = 10 microbars = 94 dB SPL
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 95
smart mixer ® installed sound microphones
AT-MX341b
£625.00
Automatic SmartMixer ® featuring four switchable
microphone or line channels
• Four Mic/Line inputs with individual priority pre-select
switch for each channel
• Switchable manual mode overrides automatic functions
• T TL logic output signals available to control speaker or
camera switching, tally lights, etc.
Rack mount accessories
AT8628B
£30.00
Joining plate for mounting two AT-MX341a mixers in a
single rack space
Accessories
AT8325/1.0
£30.00
Link cable (included with SmartMixer ®)
Specifications
AT-MX341b
Input Impedance
Mic: 4,000 ohms
Output Impedance
Line: 30,000 ohms
Mic: 200 ohms
Line: 320 ohms
Maximum Input Level
Mic: –20 dBV
Line: +30 dBV
Maximum Output Level
Line: +14 dBm (600 ohms)
Mic: –40 dBm (600 ohms
Nominal Output Level (0VU)
Line: +4 dBm (600 ohms), +4.4 dBV (open circuit)
Mic: –46 dBm (600 ohms), -44 dBV (open circuit)
Maximum Gain > =70 dB
96 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
smart mixer ® installed sound microphones
AT-MX351a
£779.00
SmartMixer ® Five-channel Automatic Mixer
• Four automatic Mic/Line inputs, plus Aux in
• Switchable manual mode overrides automatic functions
• Sub-D connector for TTL output, plus closure-control input for
external control of each channel
Specifications
AT-MX351a
Input Impedance
Mic:8,000 ohms
Line: 50,000 ohms
Aux: 50,000 ohms
Link In: 20,000 ohms
Output Impedance Balanced Unalanced Maximum Input Level
Mic:200 ohms
Line: 300 ohms
Mic: 400 ohms
Link out: 100 ohms
Preamp Out: 750 ohms
Mic: –24 dBV
Line: +27 dBV
Aux: +17 dBV
Maximum Output Level +22 dBm
Master Level control at maximum
(fully clockwise)
Nominal Output Level (0 VU)
Balanced Line: +4 dBm (600 ohms), +4.4 dBV (open circuit)
Mic: –46 dBm (600 ohms), –44 dBV (open circuit)
Unbalanced: –10 dBV (open circuit)
Preamp Out: –10 dBV (open circuit)
Master Level control at maximum (fully clockwise)
Maximum Monitor Output 700 mW, 20 ohm load
Maximum Gain 73 dB
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 97
atuc-50 conference system
ATUC-50CU
ATUC-50DU
ATUC-50CU
P.O.A.
Control Unit
• Powers up to 50 Discussion Units
• Cascade capability to handle up to 150 Discussion Units
ATUC-50DU
P.O.A.
Discussion unit with high-quality audio
• Individually programmable multi-profile versatile unit:
Delegate or Chairman
• 2 x RJ45 Port for connecting to the Control Unit and other
Discussion Units and 1x expansion terminal for future options
• 1x Headphone output.
Specifications
ATUC-50CU
Frequency response:
+ 1.0, – 2.0dB, 20Hz~20kHZ, refer to +4dBu output @ 1kHz
Dynamic range:
110dB A-weighted
Signal to noise:
90dB A-weighted
Phantom power:
DC +48V
D imensions (1 RU):
482.6mm x 324.3mm x 44mm (W x D x H)
Included accessories:
AC power cord, Quick Setup Guide x 2,
Euroblock connectors x 9, Warranty Sheet
Specifications
ATUC-50DU
Frequency response:
+ 1.0, – 2.0dB, 20Hz~20kHz, refer to +4dBu output @ 1kHz
Dynamic range:
107dB A-weighted
Signal to noise:
87dB A-weighted
Equivalent input noise:
Less than –121dBu, Rs=150 ohm
Total harmonic distortion:
Less than 0.03% @1kHz unity
Phantom power:
DC +24V
Dimensions (W x D x H):
135mm x 148.3mm x 83.7mm
Included accessories:
Quick Setup Guide, Warranty Sheet
98 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
atuc-50 conference system
ATUC-M43H
ATUC-M58H
hypercardioid
ATUC-M43H
P.O.A.
Microphone with LED Ring
• Overall length 43 cm
ATUC-M58H
P.O.A.
Microphone with LED Ring
• Overall length 58 cm
Web Remote Control
Easy control and management through web-based remote access
• Accessible from any web browser
(Mac, PC, iOS & Android Tablet)
• No need to install any additional software
• User access control with Operator and Administrator
privilege
• Setup and configuration: Network Setting,
Audio Setting, Mic Setting, Conference Setup, Individual
Discussion Unit Setting, etc.
• Conference management: Delegate list, Mic activation,
Recording activation, etc.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 99
infrared conference system
ATCS-C60
P.O.A.
Master control unit
• Full automatic mode or manual push-to-talk mode.
ATCS-M60
P.O.A.
Delegate unit
ATCS-60MIC
P.O.A.
Dedicated microphone
• Overall length 43 cm
ATCS-L60MIC
P.O.A.
Dedicated
long microphone
• Overall length 58 cm
ATCS-60MIC
ATCS- L60MIC
hypercardioid
ATCS-M60
ATCS-C60
100 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
infrared conference system
ATIR-T88
ATIR-T85
unidirectional
ATCS-V60
ATIR-T88
P.O.A.
Handheld microphone
ATIR-T85
P.O.A.
Lavalier microphone
ATCS-V60
P.O.A.
Voting unit for ATCS-60 IR conference system
The ATCS-V60 is connected to the ATCS-M60 delegate unit
by the permanently attached cable.
ATCS-A60MX
P.O.A.
IR transmitter/receiver mixer
ATCS-A60RX
P.O.A.
IR Receiver antenna (red indicator)
ATCS-A60TX
P.O.A.
IR Transmitter antenna (green indicator)
ATCS-A60
P.O.A.
IR transmitter/receiver unit
ATCS-D60
P.O.A.
Distributor
ATCS-B60
P.O.A.
Battery Charger
LI-240
P.O.A.
Lithium-ion battery
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 101
m3 in-ear monitor wireless system
M3R receiver
EP3 earphones
M3T transmitter
M3 £690.00
M3R
£440.00
Audio-Technica’s advanced M3 IEM system offers a full
range of professional in-ear monitoring features. While up
to 16 complete M3 systems may be used simultaneously, any
number of M3R stereo receivers can operate on the same
frequency with a single M3T stereo transmitter. The M3T
also offers a headphone output that allows you to monitor
transmitter input signals directly.
M3 Wireless in-ear monitor system
onitor system including 1 stereo transmitter, 1 stereo receiver
M
and EP3 headphones
Stereo receiver for M3 in-ear monitor system
Personal mix control in a lightweight body-pack with backlit
LCD display
M3T
£390.00
Stereo transmitter for M3 in-ear monitor system
ireless UHF transmitter (frequency-agile) offers LCD display
W
and up to 1321 user-selectable frequencies
EP3
£56.00
In-ear dynamic headphones offer high-fidelity sound
and excellent isolation.
Add the suffix L or M, to the end of the part number to
denote required frequency band (see table on page 103).
In-ear monitor
ATH-E70
£279.00
T hree balanced armature drivers
ATH-E50
£140.00
Powerful single balanced armature drivers
ATH-E40
£69.00
Proprietary dual phase push-pull drivers
(See complete in-ear monitor description on page 11.)
102 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
m3 in-ear monitor wireless system
AM3
AT8623
omnidirectional
MCB4
Accessories
AT8623
£29.00
oining plate mounts two M3 transmitters in a single 19”
J
rack space
AM3
£64.00
Omnidirectional Condenser Lavalier Microphone
MCB4
£515.00
Audio-Technica MCB4 Antenna Combiner
(see the complete description page 125).
M3 specifications
Minimum Frequency Step 25 kHz
Number of Frequencies 1321
Modulation Mode FM stereo
Dynamic Range 90 dB (typical), A-weighted
Operating Range 100 m, typical. Open range environment with no interfering signals.
Frequency Response 60 Hz to 13 kHz (±3 dB)
M3 FEATURES
• Up to 16 simultaneous systems per frequency band
• Personal Mix Control allows you to adjust your own mix on stage
• S electable auxiliary input offers connection point for ambient
microphone, click track, or other mic- or line-level input
Wireless frequency range (UHF)
Band Frequency Range
M3
5000 / 4000
3000b 2000a AT-One
••
D Band 655.500 - 680.375 MHz
• ••
824.831 - 863.865 MHz
F Band
840.125 - 865.000 MHz
•
606.000 - 614.000 MHz
U Band
••
614.000 - 631.000 MHz
I Band 487.125 - 506.500 MHz •
L Band 575.500 - 608.000 MHz
•
M Band 614.000 - 647.000 MHz •
C Band 541.500 - 566.375 MHz
•
(Plan A)
(Plan B)
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 103
artist elite® wireless system
AEW-T5400a
AEW-T3300a
AEW-T6100a
AEW-T4100a
cardioid
cardioid
hypercardioid
cardioid
• All transmitters offer rugged, ergonomic metal bodies,
programmable features, soft touch controls,
and 10 mW/35 mW switchable RF power
• Backlit LCD displays on transmitters
• All components store up to five preset configurations, with
customized “names” if desired
UHF Series artist elite® wireless transmitters
AEW-T5400a
£820.00
C ardioid large diaphragm condenser UHF transmitter
The same element as AE5400 (using the large-diaphragm
element as in the AT4050)
AEW-T3300a
£680.00
C ardioid condenser UHF transmitter
The same element as AE3300 (used in the legendary AT4033)
AEW-T4100a
£580.00
UHF Cardioid dynamic transmitter
The same element used in the AE4100
AEW-T6100a
£580.00
UHF Hypercardioid dynamic transmitter
The same element used in the AE6100.
Add the suffix C or D, to the end of the part number to
denote required frequency band (see table on page 103).
104 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist elite® wireless system
AEW-T1000a on the referee for boxing during the summer games 2008.
AEW-T1000a
4000/5000 UniPak™ transmitter
AEW-T1000a
£420.00
UHF UniPak™ transmitter
Compatible with the Wireless Essentials® range.
Rugged, ergonomic metal housing.
Includes field-replaceable helical and flexible-whip antennas.
Three-position sliding cover limits access to controls as
desired: full access, Power/Mute button only, or no access.
Two position mounting clip.
• Locking battery door on UniPak body-pack transmitter.
For use with AEW-T1000 and all Audio-Technica UniPak™
Wireless Transmitters, see Wireless Essentials® page 120
to 123.
Specifications
AEW-T1000a UniPak™ Handheld Transmitters
RF Power Output
High: 35 mW; Low: 10 mW, nominal High: 35 mW; Low: 10 mW, nominal
Dynamic RangeMicrophone: ≥ 110 dB, A-weighted ≥ 110 dB, A-weighted
Instrument : ≥ 100 dB, A-weighted
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 105
artist elite® wireless system
5000 Series receiver frequency-agile
true diversity UHF wireless systems
with computer interface
Designed for use on professional tours, in stadiums, concert
halls, houses of worship and other demanding audio
environments, Audio-Technica’s dual-receiver Artist Elite®
5000 Series provides incredible audio quality and proven,
critically acclaimed performance for artists, broadcasters and
presenters worldwide.
• IntelliScan™ feature automatically finds and sets best
available frequencies on all linked receivers.
• Dual Compander circuitry processes high and low
frequencies separately for unmatched audio quality.
AEW-R5200
£2,600.00 Frequency-agile true diversity UHF dual receiver with
ethernet connection
See page 124 and 125, Wireless Accessories.
On-board Ethernet interface and included software on CD permit monitoring and
controlling system parameters and operation from an associated computer.
Receiver Specifications AEW-R5200
Image Rejection 60 dB typical
Signal-to-noise Ratio
115 dB at 40 kHz deviation (IEC-weighted), 75 kHz
maximum modulation
Audio Output
Output Connectors
Headphone Output
Microphone:25 mV (at 1 kHz, ±5 kHz deviation, 10k ohm load),
transformer isolated and balanced (ATTN switch at “0”)
Instrument:50 mV (at 1 kHz, ±5 kHz deviation, 10k ohm load),
transformer isolated and balanced (ATTN switch at “0”)
Microphone: XLRM-type, balanced
Instrument: 1/4” (6.3 mm) TRS balanced phone jack
Connector: 1/4” (6.3 mm) TRS (“stereo”) phone jack.
Power Output: 10 mW + 10 mW into 32 ohms (at 1 kHz, ±5 kHz
deviation); maximum output: 220 mW + 220 mW into
32 ohms. Headphones switchable between Channel 1
and Channel 2.
106 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
artist elite® wireless system
4000 Series receiver frequency-agile
true diversity UHF wireless systems
• IntelliScan™ feature automatically finds and sets best
available frequencies on all linked receivers
• Dual Compander circuitry processes high and low
frequencies separately for unmatched audio quality
AEW-R4100
£980.00
Frequency-agile true diversity UHF receiver
Add the suffix C or D, to the end of the part number to
denote required frequency band (see table on page 103).
Accessories
AT8628B
£30.00
Joining plate kit allow mounting two AEW-R4100
receivers in a single 19” rack space
See page 124 and 125, Wireless Accessories.
Overall 4000 and 5000 Series systems specifications
Operating Frequencies
UHF Band C: Frequency Range 541.500 to 566.375 MHz
UHF Band D: Frequency Range 655.500 to 680.375 MHz
Number of Frequencies 996
Normal Deviation ±5 kHz
Operating Range
100 m typical
Receiver Specifications
Image Rejection
60 dB typical
AEW-R4100
Signal-to-Noise Ratio115 dB at 40 kHz deviation
(IEC-weighted, 75 kHz maximum modulation)
Audio Output
Microphone: (ATTN switch at “0”) 25 mV
(at 1 kHz, ±5 kHz deviation, 10k ohm load)
Instrument: (ATTN switch at “0”) 50 mV
(at 1 kHz, ±5 kHz deviation, 10k ohm load)
Output Connectors
Headphone Output
Microphone: XLRM-type (balanced)
Instrument: 1/4” (6.3 mm) TS unbalanced phone jack
Connector: 1/4” (6.3 mm) TRS (“stereo”) phone jack
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 107
3000b series wireless system
ATW-T310b
ATW-R3100b
AEW-T341b
AEW-T371b
cardioid
Audio-Technica’s third-generation 3000b Series wireless
systems offer up to 1001 selectable UHF frequencies and
features for clear sound & intuitive operation.
Add the suffix C, D or U, to the end of the part number to
denote required frequency band (see table on page 103).
ATW-R3100b
£249.00
UHF diversity receiver with up to 1001 frequencies, with
frequency scan function enabling automatic channel assignment.
ATW-T310b
£260.00
3000b Series UniPak™ transmitter with a locking battery
compartment providing a more secure latch and more robust
design. For use with ATW-T310b and all Audio-Technica
UniPak™ Wireless Transmitters, see Wireless Essentials®
page 120 to 123.
ATW-T341b
£295.00
3000b Series handheld microphone/ transmitter with
cardioid dynamic element.
ATW-T371b
£370.00
3000b Series handheld microphone/ transmitter with
cardioid condenser element.
ATW-R3100b Receiver Specifications
Image Rejection
Dynamic Range
Audio Output
Specifications
RF Power Output
Dynamic Range
Specifications
RF Power Output
Dynamic Range
Microphone Element
60 dB nominal, 55 dB minimum
>110 dB (A-weighted), typical
Unbalanced : +7 dBV, 1/4” phone jack - Balanced :+9 dBV, XLRM-type
ATW-T310b UniPak™ Transmitter
High: 30 mW, Low: 10 mW
≥110 dB, A-weighted
ATW-T341b and ATW-T371b Handheld Transmitters
High: 30 mW, Low: 10 mW
≥110 dB, A-weighted
ATW-T341b Dynamic cardioid - ATW-T371b Condenser cardioid
108 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
3000b series wireless system
ATW-3141b
£475.00
Handheld transmitter system
• ATW-R3100b receiver
• ATW-T341b handheld cardioid dynamic microphone/
transmitter
ATW-3171b
£549.00
Handheld transmitter system
• ATW-R3100b receiver
• ATW-T371b handheld cardioid condenser microphone/
transmitter
ATW-3110b
£440.00
3 000b Series UniPak™ system
• ATW-R3100b receiver
• ATW-T310b UniPak ® transmitter.
Select a Wireless Essentials ® microphone or cable to complete
the system.
ATW-3110b/G
£465.00
•
ATW-R3100b receiver
• ATW-T310b UniPak ® transmitter
• AT-GcW instrument cable
ATW-3110b/P
£495.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• AT829cW cardioid condenser lavalier microphone
ATW-3110b/P1
£595.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• AT899cW subminiature cardioid condenser lavalier
microphone
ATW-3110b/P2
£569.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• AT831cW miniature cardioid condenser lavalier microphone
ATW-3110b/P3
£539.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• M T838cW omnidirectional cardioid condenser lavalier
microphone
ATW-3110b/H
£519.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• P RO 8HEcW hypercardioid dynamic headworn microphone
ATW-3110b/HC1
£529.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• ATM75cW cardioid condenser headworn microphone
ATW-3110b/HC2
£595.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• ATM73cW cardioid condenser professional headworn
microphone
ATW-3110b/HC3
£709.00
ATW-R3100b receiver
•
• ATW-T310b UniPak ® transmitter
• B P892cW-TH subminiature omnidirectional condenser
headworn microphone
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 109
2000a series wireless system
ATW-R2100a
ATW-T210a
AEW-T220a
cardioid
Audio-Technica’s second generation of the well known
2000 Series now offers increased RF power on both the
handheld and beltpack transmitters for increased link stability.
Charging contacts on the transmitters allow easy operation
with rechargeable batteries.
Add the suffix I, D, U or F, to the end of the part number to
denote required frequency band (see table on page 103).
ATW-R2100a
£160.00
Receiver for 2000a Series
ATW-T210a
£145.00
2000a Series UniPak transmitter
ATW-T220a
£175.00
2000a Series handheld microphone/
transmitter with unidirectional
dynamic element
2000a CHARGER
ATW-CHG2
£152.00
Plug-in charging unit
for two 2000a Series radio transmitters
Specifications
RF Power Output
Specifications
RF Power Output
Microphone Element
ATW-T210a UniPak™ Transmitter
10mW / 30mW
ATW-T220a Handheld Transmitter
10mW / 30mW
Dynamic, unidirectional
ATW-R2100a Receiver Specifications
Image Rejection
55 dB nominal, 50 dB minimum
Signal-to-Noise Ratio
>100 dB at 40 kHz deviation (A-weighted),
maximum modulation 40 kHz
Audio Output
Unbalanced : 25 mV (100k ohms load), 1/4” phone jack
Balanced : 50mV (Attenuator; 0dB)
12.5mV (Attenuator; -12dB) at 1kHz, +/- 5kHz
deviation, 100k ohm load., XLRM-type
110 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
2000a series wireless system
Accessories
AT8630
£29.00
Joining plate kit for mounting two ATW-R2100
or ATW-R3100b receivers in a single 19” rack space.
ATW-RM1
£59.00
Rack-mount hardware kit for Audio-Technica 2000a
and 3000b Series wireless systems and for ATW-DA49.
System configurations
ATW-2120a
£329.00
Handheld transmitter system
• ATW-T220a handheld microphone/transmitter.
• ATW-R2100a receiver.
ATW-2110a
£299.00
2000a Series UniPak™ system
• ATW-T210a UniPak™ transmitter.
• ATW-R2100a receiver.
ATW-2110a/G
£324.00
2000a Series UniPak™ guitar system
• With AT-GcW instrument cable.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/P
£354.00
UniPak™ system with AT829cW
• AT829cW miniature cardioid condenser microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/P1
£454.00
UniPak™ system with AT899cW
• AT899cW subminiature omnidirectional condenser
microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/P2
£428.00
UniPak™ system with AT831cW
• AT831cW miniature cardioid condenser microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/P3
£398.00
UniPak™ system with MT838cW
• M T838cW omnidirectional condenser lavalier microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/H
£378.00
UniPak™ system with PRO8HEcW
• PRO8HEcW headworn hypercardioid dynamic microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/HC1
£388.00
UniPak™ system with ATM75cW
• ATM75cW headworn cardioid condenser microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/HC2
£454.00
UniPak™ system with ATM73cW
• ATM73cW professional headworn cardioid condenser
microphone.
• ATW-2110a UniPak™ transmitter system.
ATW-2110a/HC3
£568.00
UniPak™ system with BP892cW-TH
• B P892cW-TH subminiature omnidirectional condenser
headworn microphone.
• ATW-2110a UniPak™ transmitter system.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 111
AT-One wireless system
ATW-R1F
ATW-T1F
ATW-T3F
cardioid
With a 2 x 4 channel frequency plan for enhanced flexibility,
sturdy but stylish build quality and a simple user interface,
AT-One is ready to become your perfect wireless companion.
AT-One is designed with simplicity and ease-of-use in mind.
Equipped with a practical carrying case, rack-mount kit and
detachable antennae, AT-One is the perfect balance of price
and performance, ideal for those looking for accurate, reliable
performance at an entry level price.
The AT-One’s frequency plan is divided into two groups with
4 available channels in each group, giving users unparalleled
flexibility in its price range.
The ATW-13F’s condenser handheld microphone prevents
the possibility of feedback when used in venues with induction
loops installed.
ATW-T1F
£69.00Beltpack Transmitter
The ATW-T1F Beltpack transmitter is designed to be used
exclusively with the AT-One UHF wireless system.
ATW-T3F
£85.00Handheld Transmitter
The ATW-T3F Handheld Transmitter is a cardioid condenser
microphone designed to be used exclusively with the AT-One
UHF wireless system.
Add the suffix F to the end of the part number to denote
required frequency band (see table on page 103).
112 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
AT-One wireless system
System configurations
ATW-11F
£169.00Body-pack transmitter system
• ATW-R1F Receiver,
• ATW-T1F Beltpack Transmitter
ATW-11/PF
£203.50Body-pack transmitter system
with lavalier microphone
• ATW-R1F Receiver,
• ATW-T1F Beltpack Transmitter,
• ATR35cW Miniature
omnidirectional condenser
microphone
ATW-13F
£185.00Handheld transmitter system
• ATW-R1F Receiver,
• ATW-T3F Handheld Transmitter
Accessories
AT8677
£14.00Dual rackmount kit (optional)
Include 2 rack ears + 2 joint brackets
Overall System
Frequency Range: F-band: 824-831 MHz, 863-865 MHz
Modulation Mode: FM
Number of Frequencies: 2x 4-frequencies
Frequency Response: 60 Hz - 16 kHz
Specifications
ATW-T1F Transmitter
RF Power Output10mW
Specifications
ATW-T3F Handheld Transmitter
RF Power Output10mW
Microphone Element: Condenser Cardioid
Specifications Image Rejection
Dynamic Range: Antenna Input: Audio Output: Output Connectors: Accessories Included: ATW-R1F Receiver
55 dB minimum
HH: 108 dB, BP 103 dB (@ max deviation)
BNC type, 50 ohms - BIAS voltage 12V DC 100mA each
Unbalanced – 2dBV, Balanced +4 dBV
Unbalanced: 6.3 mm mono jack, Balanced: XLRM-type
AC Adapter, Antennas, Rack mount adapter
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 113
system 10 wireless system
System 10
ATW-T1002
cardioid
Audio-Technica’s System 10 is a digital high-fidelity wireless
system, designed to provide performing musicians and
presenters with advanced 24-bit operation, easy setup and
clear, natural sound quality. Operating in the 2.4 GHz range, far
from TV and DTV interference, System 10 offers extremely
easy operation and instantaneous channel selection.
ATW-1101
£239.00
Complete system including a 2.4 GHz diversity receiver
and a body-pack transmitter UniPak™.
The system is compatible with the Wireless Essentials®
range (see page 120 to 123).
ATW-1102
£255.00
Complete system including a 2.4 GHz diversity receiver and
handheld dynamic unidirectional microphone/transmitter.
Accessories
AT8674
£45.00
19’’rack mount tray for 4 receivers. Height : 2U – Colour black
AT8675
£12.00
Blanking plate can be used with AT8674 to block out half of
the rack tray front (9.5”) in case only 2 ATW-R1100 receivers
are mounted.
AT8674
AT8675
Overall System
Operating Frequencies: Dynamic Range: Operating Range: Frequency Response: 2.4 GHz ISM band
>109 dB (A-weighted), typical
30 m typical Open range environment with no interfering signals
20 Hz to 20 kHz Depending on microphone type
114 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
system 10 stompbox
AT-GcW
ATW-T1001
ATW-R1500
Stompbox design with multiple output modes.
Receiver may be paired with multiple transmitters
to make switching instruments easy.
Audio-Technica’s System 10 Stompbox digital high-fidelity
guitar wireless system combines the advanced 24-bit
operation, easy setup and clear, natural sound quality of
other System 10 configurations with unique functionality for
guitarists, bassists and other instrumentalists.
ATW-1501
£299.00
System 10 Digital 2.4 GHz Stompbox wireless system
• E ach Stompbox system includes an ATW-R1500 stompbox
receiver, an ATW-T1001 UniPak body-pack transmitter
with an AT-GcW guitar cable, and Velcro ® strips for adding
receiver to an effects pedal board
Overall System
Operating Frequencies: Dynamic Range: Frequency Response: 2.4 GHz ISM band
>109 dB (A-weighted), typical
20 Hz to 20 kHz Depending on microphone type
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 115
system 10 camera mount
ATW-R1700
ATW-T1001
ATW-T1002
cardioid
The lightweight ‘hot or cold-shoe’ mountable ATW-R1700
receiver is compact and features an independent headphone
monitor output and selectable balanced or unbalanced
audio output on 3.5mm mini-jack connectors. Powered by an
internal rechargeable Li-Ion battery, the System 10 cameramount unit has both receiver and transmitter battery life
indicators and can be used with Audio-Technica’s System 10
beltpack or dynamic handheld digital wireless microphone
transmitters.
Operating in the 2.4 GHz range, immune to TV and DTV
interference, System 10 makes frequency hunting a thing of
the past and offers amazingly accurate sound and extremely
easy operation with instantaneous channel selection, sync
and set-up.
ATW-T1001
£119.00System 10 / System 10 Pro beltpack transmitter
ATW-T1002
£135.00System 10 / System 10 Pro handheld transmitter
with unidirectional dynamic element
Overall System
Operating Frequencies: Dynamic Range: Frequency Response: 2.4 GHz ISM band
>109 dB (A-weighted), typical
20 Hz to 20 kHz Depending on microphone type
116 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
system 10 camera mount
ATW-1701
£289.00
Body-Pack transmitter system
ATW-R1700 receiver and ATW-T1001 UniPak ® transmitter.
The system is compatible with the Wireless Essentials®
range (see page 120 to 123).
ATW-1702
£305.00
Handheld Transmitter system
TW-R1700 receiver and ATW-T1002 handheld dynamic
A
unidirectional microphone/transmitter.
Includes AT8456a Quiet-Flex™ stand clamp.
ATW-1701/P
£323.50
Handheld Transmitter system
TW-R1700 receiver and ATW-T1001 UniPak ® transmitter
A
with ATR35cW omnidirectional lavalier microphone.
ATW-1701X3M
£306.00
System 10 portable camera mount belt pack
with 3.5mm/XLR cable
• Digital Receiver ATW-R1700
• System 10 Portable Camera Mount Belt Pack ATW-T1001
• Mini-jack 3.5mm / XLR cable for balanced operation
ATW-1702X3M
£322.00
System 10 portable camera mount handheld microphone
with 3.5mm/XLR cable
• Digital Receiver ATW-R1700
• System 10 Portable Camera Handheld Pack ATW-T1002
• Mini-jack 3.5mm / XLR cable for balanced operation
Accessories
AT8691
£44.00
Camera Shoe Dual Receiver Mount
AT8691 allows to mount two ATW-R1700 camera receivers
on a camera. Includes AT8351 Y-stereo cable.
AT8349
£11.00
Mini Jack 3.5 mm / mini Jack 3.5 mm mono cable
AT8350
£17.00
Mini Jack 3.5 mm / XLR balanced cable
AT8351
£17.00
Mini Jack 3.5mm / 2 x mini Jack 3.5 mm Y stereo cable
AT8691
AT8349
AT8350
AT8351
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 117
system 10 pro installation
System 10 Pro
Featuring
Remote-Mountable
Receiver Units
ystem 10 PRO delivers interference-free operation in the
S
2.4 GHz range (i.e., outside TV bands) with many innovative
features for ultimate versatility. The durable half-rack chassis
houses two receiver units that can be operated locally or
released from the chassis and mounted remotely (up to 100 m
away) via Ethernet cable.
Up to five chassis (10 receiver units) can be linked using the
RJ12 cable included with each system, creating a stable,
multichannel system with the simultaneous use of up to
10 channels.
ATW-RU13
£185.00System 10 Pro receiver unit
ATW-RC13
£200.00
System 10 Pro rack-mount receiver chassis
Overall System
Operating Frequencies: Dynamic Range: Frequency Response: 2.4 GHz ISM band
>109 dB (A-weighted), typical
20 Hz to 20 kHz Depending on microphone type
118 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
system 10 pro installation
ATW-1301
£399.00Body-pack system
ATW-RC13 Rack-mount receiver chassis, ATW-RU13 receiver
unit and ATW-T1001 UniPak ® transmitter.
ATW-1302
£415.00Handheld system
TW-RC13 Rack-mount receiver chassis,
A
ATW-RU13 receiver unit and ATW-T1002 handheld dynamic
unidirectional microphone/transmitter.
ATW-1311
£664.00Dual body-pack system
ATW-RC13 Rack-mount receiver chassis,
ATW-RU13 x 2 receiver unit
and ATW-T1001 UniPak ® transmitter x 2.
ATW-1312
£680.00Body-pack / handheld system
ATW-RC13 Rack-mount receiver chassis,
ATW-RU13 x 2 receiver unit, ATW-T1002 handheld
dynamic unidirectional microphone/transmitter
and ATW-T1001 UniPak ® transmitter.
ATW-1322
£696.00
Dual handheld system
ATW-RC13 Rack-mount receiver chassis,
ATW-RU13x2 receiver unit and ATW-T1002 x 2 handheld
dynamic unidirectional microphone/transmitter.
ATW-T1006
cardioid
ATW-T1007
ATW-T1006
£335.00Boundary microphone transmitter for System 10 Pro
ATW-T1007
£299.00
Microphone desk stand transmitter for System 10 Pro
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 119
wireless essentials®
All microphones page 120 to 123 are fitted with a 4-pin
HRS connector, for use with Audio-Technica UniPak™
transmitters.
BP892cW
omnidirectional
MicroSet ® wireless headworn microphones
BP892cW
£269.00
MicroSet ® headworn omnidirectional condenser
microphone Includes two element covers, two windscreens
and cable clip.
BP892cW-TH
£269.00
MicroSet ® headworn microphone beige colour
BP892cW with beige colour finish microphone and cable.
BP894cW
cardioid
Subminiature wireless cardioid condenser headworn
microphone
BP894cW
£299.00
MicroSet ® subminiature cardioid condenser headworn
microphone Includes two element covers, two windscreens
and cable clip.
BP894cW-TH
£299.00
MicroSet ® subminiature microphone beige colour
BP894cW with beige colour finish microphone and cable.
BP893cW
omnidirectional
Subminiature wireless headworn microphones for use
with Audio-Technica UniPak™ wireless systems
BP893cW
£215.00
Less power module; 1.4 m cable terminated with locking
4-pin connector for audio-technica UniPak ® wireless systems.
BP893cW-TH
£215.00
Same as BP893cW, but in “theatre” colour (beige).
120 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
wireless essentials®
PRO92cW
Omnidirectional condenser
headworn microphone
omnidirectional
PRO92cW
£99.00
Omnidirectional condenser headworn microphone
Includes AT8442 clothing clip, storage pouch and AT8158
windscreen.
PRO92cW-TH
£99.00
Omnidirectional condenser headworn microphone beige
colour. PRO92cW with beige colour finish microphone and
cable.
Headworn microphones for A-T UniPak™
AT889cW
£235.00
N
oise cancelling headworn
condenser microphone
Humidity and perspiration resistant.
PRO8HEcW
£79.00
Headworn hypercardioid
dynamic ­microphone
hypercardioid
ATM75cW
£89.00
Headworn cardioid condenser
microphone.
cardioid
ATM73cW
£155.00
Headworn cardioid condenser
microphone
cardioid
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 121
wireless essentials®
Tie clip and lavalier microphones ATR35cW
£34.50 Miniature omnidirectional condenser
microphone.
AT829cW
£55.00 Miniature cardioid condenser microphone
supplied with AT8434 clip.
AT831cW
£129.00 Miniature cardioid condenser microphone
AT803cW
£119.00 Omnidirectional tie clip microphone
for broadcast applications.
Subminiature microphones for A-T UniPak™ AT898cW
£155.00 Subminiature cardioid condenser microphone
AT899cW
£155.00 Subminiature omnidirectional condenser
microphone
AT899cW-TH
£155.00 Beige version of AT899cW
BP896cW
£219.00 Less power module; 1.4 m cable terminated
with locking 4-pin connector for A-T UniPak ®
wireless systems.
BP896cW-TH
£219.00 Same as BP896cW, but in “theater” colour (beige).
MT830cW
£79.00 Miniature omnidirectional condenser
­microphone
MT838cW
£99.00 Omnidirectional microphone with clip and
windscreen.
Instrument microphones for A-T UniPak™
ATM350cW
£245.00 Cardioid condenser clip-on instrument
microphone
PRO35cW
£105.00 Cardioid condenser clip-on instrument
microphone
122 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
wireless essentials®
Conference microphones
for A-T UniPak™
U851cW
£209.00
Unidirectional condenser boundary
microphone
U841cW
£235.00
Omnidirectional condenser boundary
microphone
U857ALcW
£219.00
Cardioid condenser gooseneck
microphone 42 cm long
Connecting cables
for A-T UniPak™ transmitters
XLRW (same as AT8317)
£39.00
X LRF cable to HRS connector; 1.50 m
AT-GcW (same as AT8319)
£25.00
Guitar cable 6.35 mm jack to HRS
connector
AT-GcW-PRO
£39.00
Professional guitar input cable
for wireless
AT-GRcW-PRO
£39.00
Professional guitar input cable for
wireless with right-angle connector
Professional ¼” right-angle connector
to locking 4-pin connector for use between
instrument and Audio-Technica UniPak ®
body-pack wireless transmitter.
ATW-RCS1
£155.00
Remote momentary mute cough switch
Features a large momentory push button
switch.
ATW-RMS1
£216.00
R
emote mute switch
Features a toggle switch with positive
on-off function.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 123
wireless accessories
Active antenna splitter kit
ATW-49SP
£269.00
Active Antenna Splitter Kit
• Each kit includes:
2 x one-input, two-output Active Antenna Splitters;
4 x 45 cm BNC-to-BNC RG 58 coaxial antenna cables;
2 x BNC-to-BNC barrel adapters
Active antenna combiner kit
ATW-49CB
£269.00
Active Antenna Combiner Kit
• Each kit includes:
2 dual-input, one-output Active Antenna Combiners;
2 x 45 cm BNC-to-BNC RG 58 coaxial antenna cables
SpecificationsATW-49SP
Description 2-Way Active Antenna Splitter
Bandwidth 440 MHz to 900 MHz
ATW-49CB
2-Input Active Combiner
440 MHz to 900 MHz
Specifications are subject to change without notice.
ATW-B80x
£375.00 UHF in-line antenna boosters (pair)
Add the suffix C, D, I, U or F, to the end of the
part number to denote required frequency
band (see table on page 103).
Frequency Range: 25 MHz wide – see p.103 for details
Impedance:
50 ohms
Gain High: +10 dB / +3 dB switchable
Power Supply Voltage:
DC 12 V
Power Consumption:30mA
Connector :
BNC-J (In) – BNC-J (Out)
ATW-B80WB
£366.00 In-Line RF Booster 470 – 990 MHz
Frequency Range: 470 to 990MHz
Impedance:
50 ohms
Gain High: +12 dB Red, Low: +6 dB Green
Power Supply Voltage:
DC 12 V
Power Consumption:60mA
Connector :
BNC-J (IN), BNC-J (OUT)
124 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
wireless accessories
AC12
£19.00
AC25
£89.00
AC50
£169.00
AC100
P.O.A.
Antenna cables BNC - BNC 4 m link cable, type RG58
BNC - BNC 8 m link cable, type RG8
AC12
BNC - BNC 16 m link cable, type RG8
BNC - BNC 33 m link cable, type RG8
Transmitter accessories
AEW-TB44
£49.00
Transmitter bag for AEW Series
Holds 4 handheld
and 4 body pack transmitters
Antennas
ATW-A49
£299.00
Pair of wide band dipole antennas
for use with 440-990 MHz UHF systems
ATW-A49S
£175.00
Single wide band dipole antennas
for use with 440-990 MHz UHF systems
MCB4 £515.00
Antenna combiner
udio-Technica MCB4 Antenna Combiner allows the signals of up to
A
four M3 Wireless In-Ear Monitor stereo transmitters to be combined
into a single transmitting antenna, reducing rack clutter. It is also
suitable for many other in-ear wireless systems (with external BNC
antenna connections) operating within the 440 to 865 MHz range.
Diversity UHF antenna distribution systems
The UHF active unity-gain antenna distribution systems provides two
“1-in, 4-out” RF channels. Connects a pair of antennas to as many as
four diversity receivers.
AEW-DA660D
£619.00
Active unity-gain distribution amplifier
for UHF bands 655.500 MHz to 680.375MHz
AEW-DA550C
£619.00
Active unity-gain distribution amplifier
for UHF bands 541.500 MHz to 566.875 MHz
ATW-DA49 £399.00
UHF Antenna distribution system
The ATW-DA49 is a UHF (wide-band 440-900 MHz) active unity-gain
diversity antenna distribution system.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 125
professional turntables
AT-LP120-USBHC
£279.00
Direct-Drive Professional Turntable (USB & Analog)
T his professional stereo turntable features a high-torque
direct-drive motor for quick start-ups and a USB output that
connects directly to your computer. Other features include:
forward and reverse play capability, and 33/45/78 RPM
selectable speeds.
Included accessories:
Mac- and PC-compatible Audacity software,
USB cable, Two output adapter cables (dual
RCA female to mini-plug male & dual RCA
female to mini-plug female), Power cord.
Specifications
Type
Motor Drive Method
Speeds Pitch Variation Starting Torque Wow and Flutter Signal-to-Noise Ratio Output Level AT-LP120-USBHC
3-speed, fully manual operation
DC motor
Direct drive
33-1/3 RPM, 45 RPM, 78 RPM
+/-10% or +/-20%
>1.6 kgf-cm
<0.2% WRMS (33 RPM)
>50 dB
Pre-amp “PHONO”: 2.5 mV nominal at 1 kHz, 5 cm/sec
Pre-amp “LINE”: 150 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain 36 dB nominal, RIAA equalized
USB Function A/D, D/A - 16 bit 44.1 kHz or 48 kHz USB selectable; Computer
interface - USB 1.1 Compliant Windows XP, Vista or MAC OSX
Accessories Included AT-HS10 headshell; AT95E cartridge; AC line cord; dual RCA
(female) to 3.5 mm (1/8”) mini-plug (male) stereo adapter cable;
dual RCA (female) to 3.5 mm (1/8”) mini-plug (female) stereo
adapter cable; 45 RPM adapter; USB cable; recording software
126 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
professional turntables
AT-LP1240-USB
£439.00
Professional DJ direct-drive turntable (USB & Analog)
T his superbly made, professional quality DJ turntable is
designed primarily for DJ use in nightclubs, touring and mobile
applications. As an added benefit, the turntable offers a USB
output that allows direct connection to a computer for easy
LP-to-digital conversion.
Included accessories:
Mac- and PC-compatible Audacity software,
Dual RCA output cable with ground wire,
Two output adapter cables (dual RCA female to
mini-plug male & dual RCA female to mini-plug
female), USB cable, Power cord.
Specifications
Type
Motor Drive Method Speeds Starting Torque Wow and Flutter Signal-to-Noise Ratio Output Level AT-LP1240-USB
3-speed, fully manual operation
16-pole, 3-phase, brushless DC motor
Direct drive
33-1/3 RPM, 45 RPM, 78 RPM
>4.5 kgf.cm
< 0.1% WRMS (JIS WTD) with 33 RPM
> 55 dB (DIN-B)
Pre-amp “PHONO”: 2.5 mV nominal at 1 kHz, 5 cm/sec (HP-4005)
Pre-amp “LINE”: 150 mV nominal at 1 kHz, 5 cm/sec (HP-4005)
USB Function A/D, D/A - 16 bit 44.1 kHz or 48 kHz USB selectable;
Computer interface - USB 1.1 Compliant Windows XP or above or
MAC OSX or above
Accessories Included Slip mat; dust cover; platter; 45 RPM adapter; counterweight;
headshell; power cord; USB cable; dual RCA (female) to 1/8”
(3.5 mm) mini-plug (male) stereo adapter cable; dual RCA (female)
to 1/8” (3.5 mm) mini-plug (female) stereo adapter cable; dual
RCA (male) cable with integrated ground wire; stylus target light;
Audacity software (CD)
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 127
cartridges & styli
AT100E
£50.00
E
lliptical stylus VM cartridge
with para-toroidal coil
• VM type dual magnet system
• High-performance para-toroïdal generator coil
system
• Gold plated connectors
• PCOCC coil
• Molded integrated suspension wire
• Elliptical stylus
AT5V
£75.00
Moving Magnet Cartridges
• VM type dual magnet system
• High-performance para-toroïdal generator coil
system
• Gold plated connectors
• PCOCC coil
• Stainless steel suspension wire improving sound
quality and transient response
• Conical polished diamond stylus for less critical
tilt angle adjustment allowing more flexible use on
various tonearms
AT95E
£27.00
Moving Magnet Cartridges
• Outstanding overall performance for mid range
systems
• Elliptical diamond stylus and dual magnet setup
• Features the same dual magnet design as the
celebrated AT440MLa
• Popular amongst entry to mid level enthusiasts
• E xcellent value for money
AT91
£19.00
Moving Magnet Cartridges
• Features a conical stylus
• Robust housing for reliable, long lasting performance
• Recommended by industry professionals
• T he go-to cartridge for entry level systems and older
record players
128 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
cartridges & styli
ATN100E
£30.00
Replacement stylus for AT100E cartridge
• T he ATN100E stylus is also compatible
with AT100E/G cartridge
• Jointed Round Shank Contruction
ATN5V
£45.00
Replacement stylus for AT5V cartridge
• Conical Shape
• Jointed Round Shank Construction
ATN95E
£19.00
Replacement stylus for AT95E cartridge
ATN91
£14.00
• Compatible with AT93 and AT95 cartridges
Replacement stylus for AT91 cartridge
• Compatible stylus for CN5625AL
and AT90 discontinued cartridges.
• Upgrade replacement styli for AT3600L
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 129
accessories
Power supplies
AT8801
£93.00 Single channel 48V DC
phantom supply
(AC power adapter included).
Attenuators
AT8202
£63.00 Adjustable In-line Attenuator
Provides –10 dB, –20 dB or –30 dB
attenuation.
Unitools®
Phantom-powered in-line microphone accessories overcome
commonly-encountered sound installation challenges quickly,
easily and effectively.
AT8681
£74.00 UniMix® 2-to-1 mic combiner
with balance control. Combines
the output from two microphones
into one channel. Balance control
attenuates each microphone by 6 dB
(typical) at midpoint.
• Requires 24V-48V Phantom
power.
AT8684
£64.00 UniMute® mic attenuator with
user-definable switch function.
Remote switch control interface
ESRSC
£139.00 T he ESRSC is a control interface
that enables a contractor to add
external control, contact closure,
programmable mute functions and
status indication to any dynamic or
condenser microphone.
130 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
accessories
Condenser microphones remote power modules
AT8531
£85.00 Belt Pack type power module,
1.5V AA battery & phantom,
with low frequency roll-off, input on TA3M,
output on integral XLRM 3-pin.
AT8542
£73.00 Phantom power only in-line power module,
with low frequency roll-off, input on TA3M,
output on integral XLRM 3-pin.
AT8538
£73.00 Phantom power only in-line power module, with
bass roll-off, Input TA3M, output on 3-pin line XLRM.
AT8537
£149.00 In-Line 1.5V AA battery & phantom power
module, TA3M to XLRM line 3-pin.
Remote power module for all wireless essentials
AT8539
£103.00 Phantom power only in-line power module
Input on HRS connector for all wireless essentials.
The AT8539 allows you to convert your wireless
microphone into a wired model.
Comes equipped with a snap-on belt clip.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 131
accessories
Our genuine Audio-Technica microphone clamps have an
American standard 5/8” female thread, therefore because most
European microphone stands use 3/8” male thread, an adaptor
5/8 male to 3/8”female is needed (use AT8423 or AT8422).
Microphone clamps
AT8405
£11.00 Snap-in mic clamp, metal base,
for 21 mm body diameter mics.
AT8406
£10.00 Tapered slip-in mic clamp,
metal base for all tapered mics.
AT8407
£15.00 Universal mic clamp, spring loaded clip, metal base.
Fits most mics with diameter 15 to 25mm.
AT8470
£13.00 Quiet-Flex™ stand clamp for tapered Artist Elite®
microphones AT2010, ATM710, ATM610a, ATM510
and Midnight Blues.
AT8471
£25.00 Microphone isolation stand clamp
rovides effective reduction of stand-transmitted
P
noise dependably maintains positioning while securely
holding the microphone compatible with 5/8”-27
threaded stands.
AT8456a
£20.00 Clamp for wireless handheld microphones
in the AEW-, 3000b- 2000a-series, System10 Series.
Adapters and stand accessories
AT8422
£1.50 P
lastic threaded adapter, converts 3/8”stands
to 5/8”threaded mic clamp.
AT8433
£10.00 S
hoe clamp with two locking nuts and 5/8”
microphone adaptor. Fits to the accessory shoe
of a camcorder. Enables a microphone clamp to be
attached to the camera.
AT8423
£4.00 Brass threaded adapter, converts 3/8” stands
to 5/8”threaded mic clamp.
AT8459
£43.00 Swivel mount microphone clamp adapter.
Provides unlimited number of angles/ positions.
Compatable with 5/8”-27 threaded stands.
AT8665
£8.00 D
rum microphone clamp adapter ( 5/8” thread).
AT8472
£28.00 Slip-in mic clamp for PRO24 or any 21 mm body
diameter microphone with camera shoe mount.
132 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
accessories
Our genuine Audio-Technica microphone clamps have an
American standard 5/8” female thread, therefore because most
European microphone stands use 3/8” male thread, an adaptor
5/8 male to 3/8”female is needed (use AT8423 or AT8422).
Clamps, shock mounts for studio microphones
AT8430
£134.00 Stand clamp with 5/8” - 27 thread
for AT4033a / AT4040 / AT4050 / AT4047SV.
AT8447
£155.00 Shock mount for AT4060a.
AT8449
£73.00 Shock mount for AT4033a / AT4040 / AT4050 / AT2035
/ AT2050 / AT4050ST.
AT8449SV
£93.00 Shock mount for AT4047SV/ AT4047MP / AT4080.
AT8458
£72.00 Shock mount for AT3035 / AT3060 / AT2020 /
AT2035 / AT2050.
AT8466
£15.00 Stand mount for AT2020.
AT8482
£219.99 Shock mount for AT5045.
Shock mounts for Broadcast microphones
AT8410a
£55.00 Shock mount, spring loaded, fits most mics
with diameter 15 to 22 mm.
AT8415
£69.00 Low-profile shock mount with flexible bands.
Fits most mics.
AT8484
£87.99 Microphone shock mount designed
to be used with BP40.
Accessories for miniature microphones
AT8418
£38.00 UniMount® microphone instrument mount ATM350
/ AT803 / AT831/ AT829 / PRO35 / PRO70.
AT8444
£33.00 Instrument adapter ATM350 / AT803 / AT831 /
AT829 / PRO35 / PRO70 for acoustic guitar/violin.
AT8468
£10.00 Violin mount for ATM350
• Permits unobtrusive placement of microphone
between the instrument’s bridge and tailpiece.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 133
accessories
Clamps and accessories for tie clip microphones
AT8411
£10.00 Plastic clothing clip, fits AT803/AT829/ AT831
AT8412
£16.00 Plastic double clothing clip, fits AT803/ AT831/AT829
AT8414
£20.00 Metal tie tac, fits AT803/AT831/AT829
AT8417
£11.00 Wire clothing clip, fits AT803/AT831/AT829
AT8419
£11.00 Wire clothing clip which allows to position the
microphone in 45° steps, AT803
AT8420
£8.00 Metal clothing clip, for MT830
AT8434
£8.00 Plastic clothing clip, for AT829
AT8435
£8.00 Tie clip for MT350
MT838TC
£14.00 Tie clip for MT838
AT8442
£8.00 Clothing clip for PRO92cW
AT8460
£16.20 Clothing clip for ES943
134 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
accessories
AT899 miniature microphone accessories
AT8461
£16.00 Clothing clip base for AT899 and AT898 with single
and double microphone holders
AT8461-TH
£16.00 C
lothing clip base for AT899 and AT898 with single
and double microphone adapters in beige
AT899AK
£54.00
A
ccessory kit for AT899
and AT898 models in black
AT899AK-TH
£54.00
A
ccessory kit for AT899
and AT898, models in beige
Accessories for headworn and
miniature microphones
AT8439
£6.00 C
able clothing clip for headworn, tie clip, and
miniature microphone.
AT8440
£26.00 Cable clothing clip for BP892
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 135
accessories
Desk stands
AT8601
£21.00
Desk stand for all 5/8”-27 mic holders
AT8615
£79.00
Q M plug-in desk stand;
XLRF in, XLRM out for all QM mics.
AT8615RS
£83.00
Same as AT8615 with switch.
AT8666
£86.00
Low-profile microphone desk stand.
AT8666RSC
£164.00 Microphone desk stand
with switch and external contact closure.
AT8666RSP
£139.00 Microphone desk stand
with user programmable switch
136 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
accessories
Suspension accessories
for fixed installation microphones
AT8416
£59.00 Shockmount for all UniPoint AM and ES range.
AT8438
£17.00 C
ustom stand adapter
for U853 and U853W fits 5/8”-27 stands.
AT8451
£13.00 Wire hanger adapter for overhead
applications with U853 and PRO45.
AT8451WH
£13.00 W hite version of AT8451
AT8452
£13.00 Wire hanger adapter for overhead MicroLine®
ES933
AT8452WH
£13.00 W hite version of AT8452
AT8646AM
£37.00 Shockmount plate with 5/8”-27 threaded
adapter mount
AT8646QM
£52.00 Shockmount plate with XLRF connector
AT8647QM/S
£94.00 S
hockmount plate for quick mount
microphones with on/off switch for fixed
installation
AT8651
£8.00
T hread mount adapter for old ES range
AT8662
£30.00 Shockmount for gooseneck microphones
with Quick-mount (included with U857Q.)
AT8663
£11.00 L ow profile table or wall mount plate
AT8664
£11.00 A
-mount cable pass-through adapter for
Unipoint
AT8473
£25.00 Stand clamp permits attachment
AT8474
£35.00 Low-profile isolation mount (allows mounting
above or beneath mounting surface).
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 137
windscreens
Windscreens for 20 and 40 series microphones
AT8137
£42.00 Large studio foam windscreen for AT2020 /
AT4033a / AT4040 / AT4047SV / AT4047MP / AT4050
/ AT4050ST / AT4080
AT8106
£44.00 M
etal slip-on pop filter for AT4041 (for ultimate pop
and wind protection, use an AT8114 in addition)
AT8159
£8.00 S
mall egg-shaped foam windscreen for AT4041
/ PRO37 / AT4021 / AT4022 / AT4049b / AT4051b /
AT4053b
Windscreens for vocal and instrument microphones
AT8101
£9.00 L arge cylindrical foam windscreen
for AT8004 / AT8004L
AT8111
£11.00 Thin cylindrical foam windscreen for ATM650
AT8112
£9.00 L arge cylindrical foam windscreen
for ATM610 / AE4100 / AE6100
AT8114
£11.00 Ball-shaped foam windscreen
for ATM31a / ATM410 / ATM710 / AE3300 / AE5400
AT8115
£13.00 L arge-pore egg-shaped foam windscreen
for ATM650
AT8118
£5.00 Small foam windscreen for ATM350
AT8120
£16.00 Large foam windscreen
for AT8022 / PRO25ax / AT4025 / AE3000
AT8122
£9.00 Small foam windscreen for U873
AT8123
£9.00 Windshield for PRO24-CMF
AT8136
£10.00 S
mall egg-shaped foam windscreen
for ATM10a / ATM33a
Windscreens for shotgun microphones
AT8132
£20.00 Shotgun windscreen for AT8035
AT8133
£17.00 Shotgun windscreen for AT875R
AT8134
£19.00 S
hotgun windscreen for BP4073 / AT897 /
BP4029 / ATR55
AT8135
£21.00 Shotgun windscreen for AT8015 / BP4071 / BP4027
138 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
windscreens
Headworn microphone windscreens
AT8125
£8.00
Large foam golfball windscreen for ATM73.
AT8128
£9.00
S
mall foam torpedo
windscreen for ­headworn mic ATM73.
AT8139L
£8.00
L arge foam windscreen
for headworn mic ATM75 / PRO8HE.
AT8139S
£8.00
Small foam windscreen
for headworn mic ATM75 / PRO8HE.
AT8142A
£2.00
F oam temple pads (pair)
for headworn mic ATM75 / PRO8HE.
AT8142B
£3.00
Foam temple pads (pair)
for headworn mic ATM73.
AT8143
£25.00
Coloured windscreen pack suitable
for ATM75 / PRO8HE, set of 4 (pink, purple,
green and yellow) includes temple pads
AT8119
£3.00
Windscreen for ­headworn mic ATM73.
Tie clip microphone windscreens
AT8110
£15.00
Foam windscreen for ES943.
AT8116
£11.00
M
ini windscreen
for AT803 / AT829 / AT831 / PRO70.
AT8129
£3.00
Miniature foam windscreen for MT350.
AT8130
£7.00
S
ubminiature foam windscreens
(pack of 3) for MT830.
AT8131
£3.00
Miniature foam windscreen
for AT829 / AT803 / AT831 / PRO70.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 139
windscreens
Miniature AT899
and AT898 microphones accessories
AT8150
£15.00
Element covers (pack of 3).
AT8150-TH
£15.00
Beige element covers (pack of 3).
AT8151
£13.00
Windscreen (pack of 3).
AT8151-TH
£13.00
Beige windscreen (pack of 3).
Microset headworn
and lavalier microphones accessories
AT8156
£12.00
E
lement cover for BP892, BP893
and BP896 (pack of 3).
AT8156-TH
£12.00
Beige version of AT8156 (pack of 3).
AT8157
£11.00
BP893, BP893 and BP896 windscreen
(pack of 3).
AT8157-TH
£11.00
Beige version of AT8157 (pack of 3).
AT8163
£19.00
BP894 windscreen (pack of 3).
AT8163-TH
£19.00
BP894 windscreen beige (pack of 3).
AT8158
£13.00
PRO92 windscreen (pack of 3).
AT8158-TH
£13.00
Beige version of AT8158 (pack of 3).
140 l UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) .
windscreens
Unipoint®, Propoint®
and Engineered Sound® windscreens
AT8153
£11.00
Small 2-stage foam windscreen
for use with U853 / U859 / U857.
AT8153WH
£19.00
White version of AT8153.
AT8102
£10.00
Small 2-stage foam windscreen
for use with U853 / U859 / U857.
AT8102WH
£11.00
White version of AT8102.
AT8104a
£59.00
S
mall metal lockable windscreen
with ­additional outer foam windscreen provided
suitable for U853 / U857 / U859.
AT8109
£15.00
Snap-on foam windscreen
for ES Series gooseneck mics.
AT8117
£11.00
L arge high density foam windscreen
for U853 outdoor use.
AT8161
£64.00 Metal windshield with additional outer foam
for use with engineered sound gooseneck
microphones.
AT8154
£12.00
Small 2-stage foam windscreen
for use with U853 / U859 / U857
with UniLine™ elements.
AT8154WH
£22.00
White version of AT8154.
AT8138
£11.00
Windscreen for MicroLine®
All ML/suffix mics.
AT8138WH
£18.00
White version of AT8138.
AT8146
£10.00
Windscreen for PRO47 / PRO49.
AT8146WH
£10.00
White version of AT8146.
UK Retail Catalogue 2016-2017. Prices in GB Sterling including VAT (20%) (1) . l 141
notes
notes
notes
Terms, Sales Policies & Limited Warranty
Prices and Sales Policy in the UK
Prices featured in this catalogue include VAT and are
recommended retail prices only.
Please note that as our prices are recommended prices only,
product prices may vary between dealers.
(1)
Audio-Technica Product Availability
and Sales Policies in Europe
The Audio-Technica products featured in this catalogue are
available throughout Great Britain, Western and Eastern
Europe, Africa and the Middle East.
They are supplied through Audio-Technica Ltd, Leeds, UK.
Our products are available through a network of authorised
distributors, as well as from dealers. Audio-Technica Ltd
does not sell its professional products directly to end users.
Limited Warranty
All Audio-Technica products supplied by Audio-Technica Ltd are
guaranteed for TWO years from date of purchase to be free of
defects in materials and workmanship.
In the event of such defect, the product will be repaired or replaced
without charge.
Such products should be returned to the place of purchase, ie. the
dealer or distributor together with proof of purchase.
The dealer or distributor will return such products to AudioTechnica Ltd, ensuring that prior authority is sought from
Audio-Technica Ltd. Should it not be possible to return products to
the place of purchase, please contact
Audio-Technica Ltd directly with details of the defect. Returned
goods cannot be accepted without the appropriate returns
authorisation number.
The Audio-Technica warranty excludes defects due to normal
wear, abuse, shipping damage, or failure to use the product in
accordance with the instructions. This warranty is void in the event
of unauthorised repair or modification, or removal or defacing of the
product label and/or serial number.
Tel. : + 44 (0) 113 277 1441
Fax : + 44 (0) 113 270 4836
e-mail : [email protected]
www.audio-technica.com
©2016 Audio-Technica Ltd - Printed in U.K.
E&OE*: Published specifications may be subject to change without notice.
(*Errors and Omissions Excepted)
ATCAT16 UK £
Audio-Technica Europe
A Division of Audio-Technica Ltd
Technica House
Unit 5, Millennium Way
Leeds LS11 5AL England
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
