GRAPH THEORY
Keijo Ruohonen
(Translation by Janne Tamminen, Kung-Chung Lee and Robert Piché)
2013
Contents
1
1
6
10
14
18
I DEFINITIONS AND FUNDAMENTAL CONCEPTS
1.1 Definitions
1.2 Walks, Trails, Paths, Circuits, Connectivity, Components
1.3 Graph Operations
1.4 Cuts
1.5 Labeled Graphs and Isomorphism
20 II TREES
20 2.1 Trees and Forests
23 2.2 (Fundamental) Circuits and (Fundamental) Cut Sets
27
27
29
32
III DIRECTED GRAPHS
34
34
36
40
43
48
IV MATRICES AND VECTOR SPACES OF GRAPHS
50
50
52
53
61
63
66
71
V GRAPH ALGORITHMS
3.1 Definition
3.2 Directed Trees
3.3 Acyclic Directed Graphs
4.1 Matrix Representation of Graphs
4.2 Cut Matrix
4.3 Circuit Matrix
4.4 An Application: Stationary Linear Networks
4.5 Matrices over GF(2) and Vector Spaces of Graphs
5.1 Computational Complexity of Algorithms
5.2 Reachability: Warshall’s Algorithm
5.3 Depth-First and Breadth-First Searches
5.4 The Lightest Path: Dijkstra’s Algorithm
5.5 The Lightest Path: Floyd’s Algorithm
5.6 The Lightest Spanning Tree: Kruskal’s and Prim’s Algorithms
5.7 The Lightest Hamiltonian Circuit (Travelling Salesman’s Problem): The Annealing
Algorithm and the Karp–Held Heuristics
76 5.8 Maximum Matching in Bipartite Graphs: The Hungarian Algorithm
80 5.9 Maximum Flow in a Transport Network: The Ford–Fulkerson Algorithm
i
ii
85
85
90
VI DRAWING GRAPHS
92
92
93
96
98
100
102
VII MATROIDS
6.1 Planarity and Planar Embedding
6.2 The Davidson–Harel Algorithm
7.1 Hereditary Systems
7.2 The Circuit Matroid of a Graph
7.3 Other Basic Matroids
7.4 Greedy Algorithm
7.5 The General Matroid
7.6 Operations on Matroids
106 References
108 Index
Foreword
These lecture notes were translated from the Finnish lecture notes for the TUT course on graph
theory. The laborious bulk translation was taken care of by the students Janne Tamminen (TUT)
and Kung-Chung Lee (visiting from the University of British Columbia). Most of the material
was then checked by professor Robert Piché. I want to thank the translation team for their effort.
The notes form the base text for the course ”MAT-62756 Graph Theory”. They contain
an introduction to basic concepts and results in graph theory, with a special emphasis put on
the network-theoretic circuit-cut dualism. In many ways a model was the elegant and careful
presentation of S WAMY & T HULASIRAMAN, especially the older (and better) edition. There are
of course many modern text-books with similar contents, e.g. the popular G ROSS & Y ELLEN .
One of the usages of graph theory is to give a unified formalism for many very differentlooking problems. It then suffices to present algorithms in this common formalism. This has
lead to the birth of a special class of algorithms, the so-called graph algorithms. Half of the
text of these notes deals with graph algorithms, again putting emphasis on network-theoretic
methods. Only basic algorithms, applicable to problems of moderate size, are treated here.
Special classes of algorithms, such as those dealing with sparse large graphs, ”small-world”
graphs, or parallel algorithms will not be treated. In these algorithms, data structure issues have
a large role, too (see e.g. S KIENA).
The basis of graph theory is in combinatorics, and the role of ”graphics” is only in visualizing things. Graph-theoretic applications and models usually involve connections to the ”real
world” on the one hand—often expressed in vivid graphical terms—and the definitional and
computational methods given by the mathematical combinatoric and linear-algebraic machinery on the other. For many, this interplay is what makes graph theory so interesting. There is
a part of graph theory which actually deals with graphical drawing and presentation of graphs,
briefly touched in Chapter 6, where also simple algorithms are given for planarity testing and
drawing. The presentation of the matter is quite superficial, a more profound treatment would
require some rather deep results in topology and curve theory. Chapter 7 contains a brief introduction to matroids, a nice generalization and substitute for graphs in many ways.
Proofs of graph-theoretic results and methods are usually not given in a completely rigorous
combinatoric form, but rather using the possibilities of visualization given by graphical presentations of graphs. This can lead to situations where the reader may not be completely convinced
of the validity of proofs and derivations. One of the goals of a course in graph theory must then
iii
be to provide the student with the correct ”touch” to such seemingly loose methods of proof.
This is indeed necessary, as a completely rigoristic mathematical presentation is often almost
unreadable, whereas an excessively slack and lacunar presentation is of course useless.
Keijo Ruohonen
Chapter 1
Definitions and Fundamental Concepts
1.1 Definitions
Conceptually, a graph is formed by vertices and edges connecting the vertices.
Example.
Formally, a graph is a pair of sets (V, E), where V is the set of vertices and E is the set of
edges, formed by pairs of vertices. E is a multiset, in other words, its elements can occur more
than once so that every element has a multiplicity. Often, we label the vertices with letters (for
example: a, b, c, . . . or v1 , v2 , . . . ) or numbers 1, 2, . . . Throughout this lecture material, we will
label the elements of V in this way.
Example. (Continuing from the previous example) We label the vertices as follows:
v1
v5
v2
v3
v4
We have V = {v1 , . . . , v5 } for the vertices and E = {(v1 , v2 ), (v2 , v5 ), (v5 , v5 ), (v5 , v4 ), (v5 , v4 )}
for the edges.
Similarly, we often label the edges with letters (for example: a, b, c, . . . or e1 , e2 , . . . ) or numbers 1, 2, . . . for simplicity.
1
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
2
Remark. The two edges (u, v) and (v, u) are the same. In other words, the pair is not ordered.
Example. (Continuing from the previous example) We label the edges as follows:
v1
e1
v5
e2
v2
e3
e4
v3
e5
v4
So E = {e1 , . . . , e5 }.
We have the following terminologies:
1. The two vertices u and v are end vertices of the edge (u, v).
2. Edges that have the same end vertices are parallel.
3. An edge of the form (v, v) is a loop.
4. A graph is simple if it has no parallel edges or loops.
5. A graph with no edges (i.e. E is empty) is empty.
6. A graph with no vertices (i.e. V and E are empty) is a null graph.
7. A graph with only one vertex is trivial.
8. Edges are adjacent if they share a common end vertex.
9. Two vertices u and v are adjacent if they are connected by an edge, in other words, (u, v)
is an edge.
10. The degree of the vertex v, written as d(v), is the number of edges with v as an end vertex.
By convention, we count a loop twice and parallel edges contribute separately.
11. A pendant vertex is a vertex whose degree is 1.
12. An edge that has a pendant vertex as an end vertex is a pendant edge.
13. An isolated vertex is a vertex whose degree is 0.
Example. (Continuing from the previous example)
• v4 and v5 are end vertices of e5 .
• e4 and e5 are parallel.
• e3 is a loop.
• The graph is not simple.
• e1 and e2 are adjacent.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
3
• v1 and v2 are adjacent.
• The degree of v1 is 1 so it is a pendant vertex.
• e1 is a pendant edge.
• The degree of v5 is 5.
• The degree of v4 is 2.
• The degree of v3 is 0 so it is an isolated vertex.
In the future, we will label graphs with letters, for example:
G = (V, E).
The minimum degree of the vertices in a graph G is denoted δ(G) (= 0 if there is an isolated
vertex in G). Similarly, we write ∆(G) as the maximum degree of vertices in G.
Example. (Continuing from the previous example) δ(G) = 0 and ∆(G) = 5.
Remark. In this course, we only consider finite graphs, i.e. V and E are finite sets.
Since every edge has two end vertices, we get
Theorem 1.1. The graph G = (V, E), where V = {v1 , . . . , vn } and E = {e1 , . . . , em }, satisfies
n
X
d(vi ) = 2m.
i=1
Corollary. Every graph has an even number of vertices of odd degree.
Proof. If the vertices v1 , . . . , vk have odd degrees and the vertices vk+1 , . . . , vn have even degrees, then (Theorem 1.1)
d(v1 ) + · · · + d(vk ) = 2m − d(vk+1) − · · · − d(vn )
is even. Therefore, k is even.
Example. (Continuing from the previous example) Now the sum of the degrees is 1 + 2 + 0 +
2 + 5 = 10 = 2 · 5. There are two vertices of odd degree, namely v1 and v5 .
A simple graph that contains every possible edge between all the vertices is called a complete
graph. A complete graph with n vertices is denoted as Kn . The first four complete graphs are
given as examples:
K1
K2
K3
K4
The graph G1 = (V1 , E1 ) is a subgraph of G2 = (V2 , E2 ) if
1. V1 ⊆ V2 and
2. Every edge of G1 is also an edge of G2 .
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
Example. We have the graph
v2
e1
v4
G2:
e4
e2
e3
v1
e5
v3
v5
e6
and some of its subgraphs are
v2
e1
G1:
v1
v2
e1
v4
G1:
e4
e2
v1
v3
e5
v5
e6
v2
G1:
v1
v3
e5
v5
e6
4
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
5
and
v5
G1:
e6
The subgraph of G = (V, E) induced by the edge set E1 ⊆ E is:
G1 = (V1 , E1 ) =def. hE1 i,
where V1 consists of every end vertex of the edges in E1 .
Example. (Continuing from above) From the original graph G, the edges e2 , e3 and e5 induce
the subgraph
v2
〈e2,e3,e5〉:
v1
e3
e2
v3
e5
v5
The subgraph of G = (V, E) induced by the vertex set V1 ⊆ V is:
G1 = (V1 , E1 ) =def. hV1 i,
where E1 consists of every edge between the vertices in V1 .
Example. (Continuing from the previous example) From the original graph G, the vertices v1 ,
v3 and v5 induce the subgraph
〈v1,v3,v5〉:
v1
e3
v3
e5
v5
e6
A complete subgraph of G is called a clique of G.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
6
1.2 Walks, Trails, Paths, Circuits, Connectivity, Components
Remark. There are many different variations of the following terminologies. We will adhere to
the definitions given here.
A walk in the graph G = (V, E) is a finite sequence of the form
vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik ,
which consists of alternating vertices and edges of G. The walk starts at a vertex. Vertices vit−1
and vit are end vertices of ejt (t = 1, . . . , k). vi0 is the initial vertex and vik is the terminal
vertex. k is the length of the walk. A zero length walk is just a single vertex vi0 . It is allowed to
visit a vertex or go through an edge more than once. A walk is open if vi0 6= vik . Otherwise it
is closed.
Example. In the graph
v2
e1
e2
v3
v1
G:
e8
e7
e10
e3
e5
e9
v5
e6
v4
v6
e4
the walk
v2 , e7 , v5 , e8 , v1 , e8 , v5 , e6 , v4 , e5 , v4 , e5 , v4
is open. On the other hand, the walk
v4 , e5 , v4 , e3 , v3 , e2 , v2 , e7 , v5 , e6 , v4
is closed.
A walk is a trail if any edge is traversed at most once. Then, the number of times that the
vertex pair u, v can appear as consecutive vertices in a trail is at most the number of parallel
edges connecting u and v.
Example. (Continuing from the previous example) The walk in the graph
v1 , e8 , v5 , e9 , v1 , e1 , v2 , e7 , v5 , e6 , v4 , e5 , v4 , e4 , v4
is a trail.
A trail is a path if any vertex is visited at most once except possibly the initial and terminal
vertices when they are the same. A closed path is a circuit. For simplicity, we will assume in
the future that a circuit is not empty, i.e. its length ≥ 1. We identify the paths and circuits with
the subgraphs induced by their edges.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
7
Example. (Continuing from the previous example) The walk
v2 , e7 , v5 , e6 , v4 , e3 , v3
is a path and the walk
v2 , e7 , v5 , e6 , v4 , e3 , v3 , e2 , v2
is a circuit.
The walk starting at u and ending at v is called an u–v walk. u and v are connected if there
is a u–v walk in the graph (then there is also a u–v path!). If u and v are connected and v and w
are connected, then u and w are also connected, i.e. if there is a u–v walk and a v–w walk, then
there is also a u–w walk. A graph is connected if all the vertices are connected to each other.
(A trivial graph is connected by convention.)
Example. The graph
is not connected.
The subgraph G1 (not a null graph) of the graph G is a component of G if
1. G1 is connected and
2. Either G1 is trivial (one single isolated vertex of G) or G1 is not trivial and G1 is the
subgraph induced by those edges of G that have one end vertex in G1 .
Different components of the same graph do not have any common vertices because of the following theorem.
Theorem 1.2. If the graph G has a vertex v that is connected to a vertex of the component G1
of G, then v is also a vertex of G1 .
Proof. If v is connected to vertex v ′ of G1 , then there is a walk in G
v = vi0 , ej1 , vi1 , . . . , vik−1 , ejk , vik = v ′ .
Since v ′ is a vertex of G1 , then (condition #2 above) ejk is an edge of G1 and vik−1 is a vertex
of G1 . We continue this process and see that v is a vertex of G1 .
Example.
e5
G:
v3
e1
e2
v1
v6
e3
v4
e4
v7
e6
v5
v2
G1
G2
The components of G are G1 , G2 , G3 and G4 .
G3
G4
e7
v8
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
8
Theorem 1.3. Every vertex of G belongs to exactly one component of G. Similarly, every edge
of G belongs to exactly one component of G.
Proof. We choose a vertex v in G. We do the following as many times as possible starting with
V1 = {v}:
(∗) If v ′ is a vertex of G such that v ′ ∈
/ V1 and v ′ is connected to some vertex of V1 , then
′
V1 ← V1 ∪ {v }.
Since there is a finite number of vertices in G, the process stops eventually. The last V1 induces a
subgraph G1 of G that is the component of G containing v. G1 is connected because its vertices
are connected to v so they are also connected to each other. Condition #2 holds because we can
not repeat (∗). By Theorem 1.2, v does not belong to any other component.
The edges of the graph are incident to the end vertices of the components.
Theorem 1.3 divides a graph into distinct components. The proof of the theorem gives an
algorithm to do that. We have to repeat what we did in the proof as long as we have free
vertices that do not belong to any component. Every isolated vertex forms its own component.
A connected graph has only one component, namely, itself.
A graph G with n vertices, m edges and k components has the rank
ρ(G) = n − k.
The nullity of the graph is
µ(G) = m − n + k.
We see that ρ(G) ≥ 0 and ρ(G) + µ(G) = m. In addition, µ(G) ≥ 0 because
Theorem 1.4. ρ(G) ≤ m
Proof. We will use the second principle of induction (strong induction) for m.
Induction Basis: m = 0. The components are trivial and n = k.
Induction Hypothesis: The theorem is true for m < p. (p ≥ 1)
Induction Statement: The theorem is true for m = p.
Induction Statement Proof: We choose a component G1 of G which has at least one edge.
We label that edge e and the end vertices u and v. We also label G2 as the subgraph of G and
G1 , obtained by removing the edge e from G1 (but not the vertices u and v). We label G′ as the
graph obtained by removing the edge e from G (but not the vertices u and v) and let k ′ be the
number of components of G′ . We have two cases:
1. G2 is connected. Then, k ′ = k. We use the Induction Hypothesis on G′ :
n − k = n − k ′ = ρ(G′ ) ≤ m − 1 < m.
2. G2 is not connected. Then there is only one path between u and v:
u, e, v
and no other path. Thus, there are two components in G2 and k ′ = k + 1. We use the
Induction Hypothesis on G′ :
ρ(G′ ) = n − k ′ = n − k − 1 ≤ m − 1.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
9
Hence n − k ≤ m.
These kind of combinatorial results have many consequences. For example:
Theorem 1.5. If G is a connected graph and k ≥ 2 is the maximum path length, then any two
paths in G with length k share at least one common vertex.
Proof. We only consider the case where the paths are not circuits (Other cases can be proven in
a similar way.). Consider two paths of G with length k:
vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik
(path p1 )
vi′0 , ej1′ , vi′1 , ej2′ , . . . , ejk′ , vi′k
(path p2 ).
and
Let us consider the counter hypothesis: The paths p1 and p2 do not share a common vertex.
Since G is connected, there exists an vi0 –vi′k path. We then find the last vertex on this path
which is also on p1 (at least vi0 is on p1 ) and we label that vertex vit . We find the first vertex of
the vit –vi′k path which is also on p2 (at least vi′k is on p2 ) and we label that vertex vi′s . So we get
a vit –vi′s path
vit , ej1′′ , . . . , ejℓ′′ , vi′s .
The situation is as follows:
vi0 , ej1 , vi1 , . . . ,vit , ejt+1 , . . . , ejk , vik
ej1′′
..
.
ejℓ′′
′
, . . . , ejk′ , vi′k
vi′0 , ej1′ , vi′1 , . . . ,vi′s , ejs+1
From here we get two paths: vi0 –vi′k path and vi′0 –vik path. The two cases are:
√1
• t ≥ s: Now the length of the vi0 –vi′k path is ≥ k + 1.
√
• t < s: Now the length of the vi′0 –vik path is ≥ k + 1.
A graph is circuitless if it does not have any circuit in it.
Theorem 1.6. A graph is circuitless exactly when there are no loops and there is at most one
path between any two given vertices.
Proof. First let us assume G is circuitless. Then, there are no loops in G. Let us assume the
counter hypothesis: There are two different paths between distinct vertices u and v in G:
u = vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik = v
(path p1 )
u = vi′0 , ej1′ , vi′1 , ej2′ , . . . , ejℓ′ , vi′ℓ = v
(path p2 )
and
(here we have i0 =
i′0
and ik =
i′ℓ ),
where k ≥ ℓ. We choose the smallest index t such that
vit 6= vi′t .
There is such a t because otherwise
1
√
From now on, the symbol means contradiction. If we get a contradiction by proceeding from the assumptions, the hypothesis must be wrong.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
10
√
1. k > ℓ and vik = v = vi′ℓ = viℓ ( ) or
2. k = ℓ and vi0 = vi′0 , . . . , viℓ = vi′ℓ . Then, there would be two parallel edges between two
consecutive vertices in the path. That would imply the existence of a circuit between two
√
vertices in G.
p1
v
u
vi
vi
s
t–1
p2
We choose the smallest index s such that s ≥ t and vis is in the path p2 (at least vik is in p2 ). We
choose an index r such that r ≥ t and vi′r = vis (it exists because p1 is a path). Then,
vit−1 , ejt , . . . , ejs , vis (= vi′r ), ejr′ , . . . , ejt′ , vi′t−1 (= vit−1 )
√
is a circuit.
(Verify the case t = s = r.)
Let us prove the reverse implication. If the graph does not have any loops and no two distinct
vertices have two different paths between them, then there is no circuit. For example, if
vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik = vi0
√
is a circuit, then either k = 1 and ej1 is a loop ( ), or k ≥ 2 and the two vertices vi0 and vi1
are connected by two distinct paths
√
vi0 , ej1 , vi1 and vi1 , ej2 , . . . , ejk , vik = vi0 ( ).
1.3 Graph Operations
The complement of the simple graph G = (V, E) is the simple graph G = (V, E), where the
edges in E are exactly the edges not in G.
Example.
v2
v3
G:
v5
v1
v4
v2
v3
_
G:
v5
v1
v4
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
11
Example. The complement of the complete graph Kn is the empty graph with n vertices.
Obviously, G = G. If the graphs G = (V, E) and G′ = (V ′ , E ′ ) are simple and V ′ ⊆ V , then
the difference graph is G − G′ = (V, E ′′ ), where E ′′ contains those edges from G that are not
in G′ (simple graph).
Example.
G:
G':
G – G':
Here are some binary operations between two simple graphs G1 = (V1 , E1 ) and G2 =
(V2 , E2 ):
• The union is G1 ∪ G2 = (V1 ∪ V2 , E1 ∪ E2 ) (simple graph).
• The intersection is G1 ∩ G2 = (V1 ∩ V2 , E1 ∩ E2 ) (simple graph).
• The ring sum G1 ⊕G2 is the subgraph of G1 ∪G2 induced by the edge set E1 ⊕E2 (simple
graph). Note! The set operation ⊕ is the symmetric difference, i.e.
E1 ⊕ E2 = (E1 − E2 ) ∪ (E2 − E1 ).
Since the ring sum is a subgraph induced by an edge set, there are no isolated vertices. All three
operations are commutative and associative.
Example. For the graphs
v1
e2
e1
G1:
v3
e4
v2
e3
e5
v4
v1
v5
G2:
e1
e6
v7
v3
e7
v6
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
12
we have
v1
G1 ∪ G2:
v2
e2
e1
v3
e3
e5
e6
v7
v4
e4
e7
v6
v1
G1 ∩ G2:
v1
e1
v5
v2
e2
e3
G1 ⊕ G2:
v3
e4 e6
v3
e7
e5
v4
v6
Remark. The operations ∪, ∩ and ⊕ can also be defined for more general graphs other than
simple graphs. Naturally, we have to ”keep track” of the multiplicity of the edges:
∪ : The multiplicity of an edge in G1 ∪ G2 is the larger of its multiplicities in G1 and G2 .
∩ : The multiplicity of an edge in G1 ∩ G2 is the smaller of its multiplicities in G1 and G2 .
⊕ : The multiplicity of an edge in G1 ⊕ G2 is |m1 − m2 |, where m1 is its multiplicity in G1
and m2 is its multiplicity in G2 .
(We assume zero multiplicity for the absence of an edge.) In addition, we can generalize the difference operation for all kinds of graphs if we take account of the multiplicity. The multiplicity
of the edge e in the difference G − G′ is
(
m1 − m2 , if m1 ≥ m2
m1 −̇ m2 =
(also known as the proper difference),
0, if m1 < m2
where m1 and m2 are the multiplicities of e in G1 and G2 , respectively.
If v is a vertex of the graph G = (V, E), then G − v is the subgraph of G induced by the
vertex set V − {v}. We call this operation the removal of a vertex.
Example. (Continuing from the previous example)
v2
v1
G1 – v4:
v3
e1
e3
v5
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
13
Similarly, if e is an edge of the graph G = (V, E), then G − e is graph (V, E ′ ), where E ′ is
obtained by removing e from E. This operation is known as removal of an edge. We remark
that we are not talking about removing an edge as in Set Theory, because the edge can have
nonunit multiplicity and we only remove the edge once.
Example. (Continuing from the previous example)
v1
G1 – e5:
v3
e2
e1
e4
v2
v5
e3
v4
If u and v are two distinct vertices of the graph G = (V, E), then we can short-circuit the
two vertices u and v and obtain the graph (V ′ , E ′ ), where
V ′ = (V − {u, v}) ∪ {w} (w ∈
/ V is the ”new” vertex)
and
E ′ = (E − {(v ′ , u), (v ′, v) | v ′ ∈ V }) ∪ {(v ′ , w) | (v ′ , u) ∈ E or (v ′ , v) ∈ E}
∪ {(w, w) | (u, u) ∈ E or (v, v) ∈ E}
(Recall that the pair of vertices corresponding to an edge is not ordered). Note! We have to
maintain the multiplicity of the edges. In particular, the edge (u, v) becomes a loop.
Example. (Continuing from the previous example) Short-circuit v3 and v4 in the graph G1 :
v2
v1
v5
w
In the graph G = (V, E), contracting the edge e = (u, v) (not a loop) means the operation in
which we first remove e and then short-circuit u and v. (Contracting a loop simply removes that
loop.)
Example. (Continuing from the previous example) We contract the edge e3 in G1 by first removing e3 and then short-circuiting v2 and v3 .
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
v1
v2
e2
e1
v3
14
v5
e5
e4
v4
v1
e2
w
v5
v4
Remark. If we restrict short-circuiting and contracting to simple graphs, then we remove loops
and all but one of the parallel edges between end vertices from the results.
1.4 Cuts
A vertex v of a graph G is a cut vertex or an articulation vertex of G if the graph G − v consists
of a greater number of components than G.
Example. v is a cut vertex of the graph below:
cut vertex
G:
v
G – v:
(Note! Generally, the only vertex of a trivial graph is not a cut vertex, neither is an isolated
vertex.)
A graph is separable if it is not connected or if there exists at least one cut vertex in the
graph. Otherwise, the graph is nonseparable.
Example. The graph G in the previous example is separable.
Example. The graph below is nonseparable.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
15
A block of the graph G is a subgraph G1 of G (not a null graph) such that
• G1 is nonseparable, and
• if G2 is any other subgraph of G, then G1 ∪ G2 = G1 or G1 ∪ G2 is separable (think about
that!).
Example. The graph below is separable:
cut vertex
Theorem 1.7. The vertex v is a cut vertex of the connected graph G if and only if there exist
two vertices u and w in the graph G such that
(i) v 6= u, v 6= w and u 6= w, but
(ii) v is on every u–w path.
Proof. First, let us consider the case that v is a cut-vertex of G. Then, G − v is not connected
and there are at least two components G1 = (V1 , E1 ) and G2 = (V2 , E2 ). We choose u ∈ V1
and w ∈ V2 . The u–w path is in G because it is connected. If v is not on this path, then the path
√
is also in G − v ( ). The same reasoning can be used for all the u–w paths in G.
If v is in every u–w path, then the vertices u and w are not connected in G − v.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
16
Theorem 1.8. A nontrivial simple graph has at least two vertices which are not cut vertices.
Proof. We will use induction for the graph G with n vertices.
Induction Basis: The case n = 2 is obviously true.
Induction Hypothesis: The theorem is true for n ≤ k. (k ≥ 2)
Induction Statement: The theorem is true for n = k + 1.
Induction Statement Proof: If there are no cut vertices in G, then it is obvious. Otherwise,
we consider a cut vertex v of G. Let G1 , . . . , Gm be the components of G − v (so m ≥ 2).
Every component Gi falls into one of the two cases:
1. Gi is trivial so the only vertex of Gi is a pendant vertex or an isolated vertex of G but it is
not a cut vertex of G.
2. Gi is not trivial. The Induction Hypothesis tells us that there exist two vertices u and w
in Gi which are not cut vertices of Gi . If v and u (respectively v and w) are not adjacent
in G, then u (respectively w) is not a cut vertex in G. If both v and u as well as u and w
are adjacent in G, then u and w can not be cut vertices of G.
A cut set of the connected graph G = (V, E) is an edge set F ⊆ E such that
1. G − F (remove the edges of F one by one) is not connected, and
2. G − H is connected whenever H ⊂ F .
Theorem 1.9. If F is a cut set of the connected graph G, then G − F has two components.
Proof. Let F = {e1 , . . . , ek }. The graph G − {e1 , . . . , ek−1 } is connected (and so is G if k = 1)
by condition #2. When we remove the edges from the connected graph, we get at most two
components.
Example. In the graph
e1
v1
v4
e2
v2
e5
e3
e4
v3
e8
v6
e7
v5
e6
{e1 , e4 }, {e6 , e7 }, {e1 , e2 , e3 }, {e8 }, {e3 , e4 , e5 , e6 }, {e2 , e5 , e7 }, {e2 , e5 , e6 } and {e2 , e3 , e4 } are
cut sets. Are there other cut sets?
In a graph G = (V, E), a pair of subsets V1 and V2 of V satisfying
V = V1 ∪ V2 ,
V1 ∩ V2 = ∅ ,
V1 6= ∅ ,
V2 6= ∅,
is called a cut (or a partition) of G, denoted hV1 , V2 i. Usually, the cuts hV1 , V2 i and hV2 , V1 i are
considered to be the same.
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
17
Example. (Continuing from the previous example) h{v1 , v2 , v3 }, {v4 , v5 , v6 }i is a cut.
We can also think of a cut as an edge set:
cut hV1 , V2 i = {those edges with one end vertex in V1 and the other end vertex in V2 }.
(Note! This edge set does not define V1 and V2 uniquely so we can not use this for the definition
of a cut.)
Using the previous definitions and concepts, we can easily prove the following:
1. The cut hV1 , V2 i of a connected graph G (considered as an edge set) is a cut set if and
only if the subgraphs induced by V1 and V2 are connected, i.e. G − hV1 , V2 i has two
components.
2. If F is a cut set of the connected graph G and V1 and V2 are the vertex sets of the two
components of G − F , then hV1 , V2 i is a cut and F = hV1 , V2 i.
3. If v is a vertex of a connected (nontrivial) graph G = (V, E), then h{v}, V − {v}i is a cut
of G. It follows that the cut is a cut set if the subgraph (i.e. G − v) induced by V − {v}
is connected, i.e. if v is not a cut vertex.
If there exists a cut hV1 , V2 i for the graph G = (V, E) so that E = hV1 , V2 i, i.e. the cut
(considered as an edge set) includes every edge, then the graph G is bipartite.
Example. The graph
v4
v1
v5
v2
v6
v3
v7
is bipartite. V1 = {v1 , v2 , v3 } and V2 = {v4 , v5 , v6 , v7 }.
A simple bipartite graph is called a complete bipartite graph if we can not possibly add any
more edges to the edge set hV1 , V2 i, i.e. the graph contains exactly all edges that have one end
vertex in V1 and the other end vertex in V2 . If there are n vertices in V1 and m vertices in V2 , we
denote it as Kn,m (cf. complete graph).
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
18
Example.
K1,1:
K2,1:
K1,2:
K2,3:
(Usually Kn,m and Km,n are considered to be the same.)
1.5 Labeled Graphs and Isomorphism
By a labeling of the vertices of the graph G = (V, E), we mean a mapping α : V → A, where
A is called the label set. Similarly, a labeling of the edges is a mapping β : E → B, where B is
the label set. Often, these labels are numbers. Then, we call them weights of vertices and edges.
In a weighted graph, the weight of a path is the sum of the weights of the edges traversed.
The labeling of the vertices (respectively edges) is injective if distinct vertices (respectively
edges) have distinct labels. An injective labeling is bijective if there are as many labels in A
(respectively in B) as the number of vertices (respectively edges).
Example. If A = {0, 1} and B = R, then in the graph,
1
0.1
0.2
0
1
0.4
0.7
0
1
0.6
0
the labeling of the edges (weights) is injective but not the labeling of the vertices.
The two graphs G1 = (V1 , E1 ) and G2 = (V2 , E2 ) are isomorphic if labeling the vertices of
G1 bijectively with the elements of V2 gives G2 . (Note! We have to maintain the multiplicity of
the edges.)
CHAPTER 1. DEFINITIONS AND FUNDAMENTAL CONCEPTS
19
Example. The graphs G1 and G2 are isomorphic and the vertex labeling vi 7→ vi′ and edge
labeling ej 7→ e′j define the isomorphism.
e2
v1
G1:
e1
e3
e7
e10
e8
e6
v3
v2
v6
v5
e5
v8
e9
v4
e4
v7
e'9
v'7
G2:
v'8
e'10
v'5
v'6
e'7
v'4
e'2
v'2
e'5
e'4
e'8
e'6
e'1
v'1
e'3
v'3
Determining whether or not two graphs are isomorphic is a well researched2 problem. It
differs significantly from other problems in graph theory and network analysis. In addition,
it has a lot to do with group theory in algebra. The problem is important in the theory of
Computational Complexity. For example, refer to KÖBLER , J. & S CHÖNING , U. & TORÁN ,
J.: The Graph Isomorphism Problem. Its Structural Complexity. Birkhäuser (1993).
2
Maybe too well, cf. R EAD , R.C. & C ORNEIL , D.G.: The Graph Isomorphism Disease. Journal of Graph
Theory 1 (1977), 339–363.
Chapter 2
Trees
2.1 Trees and Forests
A forest is a circuitless graph. A tree is a connected forest. A subforest is a subgraph of a forest.
A connected subgraph of a tree is a subtree. Generally speaking, a subforest (respectively
subtree) of a graph is its subgraph, which is also a forest (respectively tree).
Example. Four trees which together form a forest:
A spanning tree of a connected graph is a subtree that includes all the vertices of that graph. If
T is a spanning tree of the graph G, then
G − T =def. T ∗
is the cospanning tree.
Example.
G:
spanning tree:
20
CHAPTER 2. TREES
21
cospanning tree
The edges of a spanning tree are called branches and the edges of the corresponding cospanning
tree are called links or chords.
Theorem 2.1. If the graph G has n vertices and m edges, then the following statements are
equivalent:
(i) G is a tree.
(ii) There is exactly one path between any two vertices in G and G has no loops.
(iii) G is connected and m = n − 1.
(iv) G is circuitless and m = n − 1.
(v) G is circuitless and if we add any new edge to G, then we will get one and only one circuit.
Proof. (i)⇒(ii): If G is a tree, then it is connected and circuitless. Thus, there are no loops in
G. There exists a path between any two vertices of G. By Theorem 1.6, we know that there is
only one such path.
(ii)⇒(iii): G is connected. Let us use induction on m.
Induction Basis: m = 0, G is trivial and the statement is obvious.
Induction Hypothesis: m = n − 1 when m ≤ ℓ. (ℓ ≥ 0)
Induction Statement: m = n − 1 when m = ℓ + 1.
Induction Statement Proof: Let e be an edge in G. Then G − e has ℓ edges. If G − e is
connected, then there exist two different paths between the end vertices of e so (ii) is false.
Therefore, G − e has two components G1 and G2 . Let there be n1 vertices and m1 edges in G1 .
Similarly, let there be n2 vertices and m2 vertices in G2 . Then,
n = n1 + n2
and
m = m1 + m2 + 1.
The Induction Hypothesis states that
m1 = n1 − 1 and
m2 = n2 − 1,
so m = n1 + n2 − 1 = n − 1.
(iii)⇒(iv): Consider the counter hypothesis: There is a circuit in G. Let e be some edge in
√1
that circuit. Thus, there are n vertices and n − 2 edges in the connected graph G − e.
(iv)⇒(v): If G is circuitless, then there is at most one path between any two vertices (Theorem 1.6). If G has more than one component, then we will not get a circuit when we draw an
edge between two different components. By adding edges, we can connect components without
creating circuits:
1
In a connected graph with n vertices, there are at least n − 1 edges. (Theorem 1.4)
CHAPTER 2. TREES
22
1st component
2nd component
3rd
component
4th
component
If we add k(≥ 1) edges, then (because (i)⇒(iii))
m+k =n−1
√
( because m = n − 1).
So G is connected. When we add an edge between vertices that are not adjacent, we get only
one circuit. Otherwise, we can remove an edge from one circuit so that other circuits will not
be affected and the graph stays connected, in contradiction to (iii)⇒(iv). Similarly, if we add a
parallel edge or a loop, we get exactly one circuit.
(v)⇒(i): Consider the counter hypothesis: G is not a tree, i.e. it is not connected. When we
√
add edges as we did previously, we do not create any circuits (see figure).
Since spanning trees are trees, Theorem 2.1 is also true for spanning trees.
Theorem 2.2. A connected graph has at least one spanning tree.
Proof. Consider the connected graph G with n vertices and m edges. If m = n − 1, then G
is a tree. Since G is connected, m ≥ n − 1 (Theorem 1.4). We still have to consider the case
m ≥ n, where there is a circuit in G. We remove an edge e from that circuit. G − e is now
connected. We repeat until there are n − 1 edges. Then, we are left with a tree.
Remark. We can get a spanning tree of a connected graph by starting from an arbitrary subforest M (as we did previously). Since there is no circuit whose edges are all in M, we can
remove those edges from the circuit which are not in M.
By Theorem 2.1, the subgraph G1 of G with n vertices is a spanning tree of G (thus G is
connected) if any three of the following four conditions hold:
1. G1 has n vertices.
2. G1 is connected.
3. G1 has n − 1 edges.
4. G1 is circuitless.
Actually, conditions #3 and #4 are enough to guarantee that G1 is a spanning tree. If conditions
#3 and #4 hold but G1 is not connected, then the components of G1 are trees and the number of
edges in G1 would be
number of vertices − number of components < n − 1
√
( ).
CHAPTER 2. TREES
23
Theorem 2.3. If a tree is not trivial, then there are at least two pendant vertices.
Proof. If a tree has n(≥ 2) vertices, then the sum of the degrees is 2(n − 1). If every vertex
√
has a degree ≥ 2, then the sum will be ≥ 2n ( ). On the other hand, if all but one vertex have
√
degree ≥ 2, then the sum would be ≥ 1 + 2(n − 1) = 2n − 1 ( ). (This also follows from
Theorem 1.8 because a cut vertex of a tree is not a pendant vertex!)
A forest with k components is sometimes called a k-tree. (So a 1-tree is a tree.)
Example.
4-tree:
We use Theorem 2.1 to see that a graph with k components has a spanning k-tree, also known
as a spanning forest, which has k components.
2.2 (Fundamental) Circuits and (Fundamental) Cut Sets
If the branches of the spanning tree T of a connected graph G are b1 , . . . , bn−1 and the corresponding links of the cospanning tree T ∗ are c1 , . . . , cm−n+1 , then there exists one and only one
circuit Ci in T + ci (which is the subgraph of G induced by the branches of T and ci ) (Theorem 2.1). We call this circuit a fundamental circuit. Every spanning tree defines m − n + 1
fundamental circuits C1 , . . . , Cm−n+1 , which together form a fundamental set of circuits. Every
fundamental circuit has exactly one link which is not in any other fundamental circuit in the
fundamental set of circuits. Therefore, we can not write any fundamental circuit as a ring sum
of other fundamental circuits in the same set. In other words, the fundamental set of circuits is
linearly independent under the ring sum operation.
Example.
G:
T:
c1
c2
T*:
c3
CHAPTER 2. TREES
24
C1
C3
C2
The graph T − bi has two components T1 and T2 . The corresponding vertex sets are V1 and
V2 . Then, hV1 , V2 i is a cut of G. It is also a cut set of G if we treat it as an edge set because
G − hV1 , V2 i has two components (result #1 p. 17). Thus, every branch bi of T has a corresponding cut set Ii . The cut sets I1 , . . . , In−1 are also known as fundamental cut sets and they
form a fundamental set of cut sets. Every fundamental cut set includes exactly one branch of T
and every branch of T belongs to exactly one fundamental cut set. Therefore, every spanning
tree defines a unique fundamental set of cut sets for G.
Example. (Continuing from the previous example) The graph
e1
G:
e2
e4
e6
e5
e8
e7
e3
has the spanning tree
b1
b3
T:
b5
b4
b2
that defines these fundamental cut sets:
b1 : {e1 , e2 }
b2 : {e2 , e3 , e4 } b3 : {e2 , e4 , e5 , e6 }
b4 : {e2 , e4 , e5 , e7 } b5 : {e8 }
Next, we consider some properties of circuits and cut sets:
(a) Every cut set of a connected graph G includes at least one branch from every spanning
tree of G. (Counter hypothesis: Some cut set F of G does not include any branches of a
√
spanning tree T . Then, T is a subgraph of G − F and G − F is connected.
)
(b) Every circuit of a connected graph G includes at least one link from every cospanning tree
of G. (Counter hypothesis: Some circuit C of G does not include any link of a cospanning
√
tree T ∗ . Then, T = G − T ∗ has a circuit and T is not a tree.
)
CHAPTER 2. TREES
25
Theorem 2.4. The edge set F of the connected graph G is a cut set of G if and only if
(i) F includes at least one branch from every spanning tree of G, and
(ii) if H ⊂ F , then there is a spanning tree none of whose branches is in H.
Proof. Let us first consider the case where F is a cut set. Then, (i) is true (previous proposition
(a)). If H ⊂ F then G − H is connected and has a spanning tree T . This T is also a spanning
tree of G. Hence, (ii) is true.
Let us next consider the case where both (i) and (ii) are true. Then G − F is disconnected.
If H ⊂ F there is a spanning tree T none of whose branches is in H. Thus T is a subgraph of
G − H and G − H is connected. Hence, F is a cut set.
Similarly:
Theorem 2.5. The subgraph C of the connected graph G is a circuit if and only if
(i) C includes at least one link from every cospanning tree of G, and
(ii) if D is a subgraph of C and D 6= C, then there exists a cospanning tree none of whose
links is in D.
Proof. Let us first consider the case where C is a circuit. Then, C includes at least one link
from every cospanning tree (property (b) above) so (i) is true. If D is a proper subgraph of C,
it obviously does not contain circuits, i.e. it is a forest. We can then supplement D so that it is
a spanning tree of G (see remark on p. 22), i.e. some spanning tree T of G includes D and D
does not include any link of T ∗ . Thus, (ii) is true.
Now we consider the case where (i) and (ii) are both true. Then, there has to be at least one
circuit in C because C is otherwise a forest and we can supplement it so that it is a spanning
tree of G (see remark on p. 22). We take a circuit C ′ in C. Since (ii) is true, C ′ 6= C is not
true, because C ′ is a circuit and it includes a link from every cospanning tree (see property (b)
above). Therefore, C = C ′ is a circuit.
Theorem 2.6. A circuit and a cut set of a connected graph have an even number of common
edges.
Proof. We choose a circuit C and a cut set F of the connected graph G. G − F has two
components G1 = (V1 , E1 ) and G2 = (V2 , E2 ). If C is a subgraph of G1 or G2 , then the
theorem is obvious because they have no common edges. Let us assume that C and F have
common edges. We traverse around a circuit by starting at some vertex v of G1 . Since we come
back to v, there has to be an even number of edges of the cut hV1 , V2 i in C.
The reader is advised to read the following several times:
Theorem 2.7. A fundamental circuit corresponding to link c of the cospanning tree T ∗ of a
connected graph is formed exactly by those branches of T whose corresponding fundamental
cut set includes c.
Proof. There exists a fundamental circuit C that corresponds to link c of T ∗ . The other edges
b1 , . . . , bk of C are branches of T . We denote Ii as the fundamental cut set that corresponds to
branch bi . Then, bi is the only branch of T which is in both C and Ii . On the other hand, c is
the only link of T ∗ in C. By Theorem 2.6, we know that the common edges of C and Ii are bi
and c, in other words, c is an edge of Ii . Then, we show that there is no c in the fundamental cut
sets Ik+1, . . . , In−1 that correspond to the branches bk+1 , . . . , bn−1 of T . For instance, if c were
in Ik+1 , then the fundamental cut set Ik+1 and the circuit C would have exactly one common
√
edge. ( ). So c is only in the fundamental cut sets I1 , . . . , Ik .
CHAPTER 2. TREES
26
The following is the corresponding theorem for fundamental cut sets:
Theorem 2.8. The fundamental cut set corresponding to branch b of the spanning tree T of a
connected graph consists exactly of those links of T ∗ whose corresponding fundamental circuit
includes b.
Proof. Let I be a fundamental cut set that corresponds to the branch b of T . Other edges
c1 , . . . , ck of I are links of T ∗ . Let Ci denote the fundamental circuit that corresponds to ci .
Then, ci is the only link of T ∗ in both I and Ci . On the other hand, b is the only branch of T in
I. By Theorem 2.6, the common edges of I and Ci are b and ci , in other words, b is an edge of
Ci . Then, we show that the fundamental circuits Ck+1 , . . . , Cm−n+1 corresponding to the links
ck+1 , . . . , cm−n+1 do not include b. For example, if b were in Ck+1 , then the fundamental circuit
√
Ck+1 and the cut set I would have exactly one common edge ( ). Hence, the branch b is only
in fundamental circuits C1 , . . . , Ck .
From the results, we can see the duality between cut sets and circuits of a graph: The
theorems for cut sets can generally be converted to dual theorems for circuits and vice versa.
Usually, we just need to change some of the key terminologies to their duals in the theorems and
proofs. In particular, we take advantage of this dualism for dealing with matroids (see Chapter
7).
Chapter 3
Directed Graphs
3.1 Definition
Intuitively, a directed graph or digraph is formed by vertices connected by directed edges or
arcs.1
Example.
Formally, a digraph is a pair (V, E), where V is the vertex set and E is the set of vertex pairs as
in ”usual” graphs. The difference is that now the elements of E are ordered pairs: the arc from
vertex u to vertex v is written as (u, v) and the other pair (v, u) is the opposite direction arc. We
also have to keep track of the multiplicity of the arc (direction of a loop is irrelevant). We can
pretty much use the same notions and results for digraphs from Chapter 1. However:
1. Vertex u is the initial vertex and vertex v is the terminal vertex of the arc (u, v). We also
say that the arc is incident out of u and incident into v.
2. The out-degree of the vertex v is the number of arcs out of it (denoted d+ (v)) and the
in-degree of v is the number of arcs going into it (denoted d− (v)).
3. In the directed walk (trail, path or circuit),
vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik
viℓ is the initial vertex and viℓ−1 is the terminal vertex of the arc ejℓ . .
4. When we treat the graph (V, E) as a usual undirected graph, it is the underlying undirected
graph of the digraph G = (V, E), denoted Gu .
1
This not a standard terminology. We will however call directed edges arcs in the sequel.
27
CHAPTER 3. DIRECTED GRAPHS
28
5. Digraph G is connected if Gu is connected. The components of G are the directed subgraphs of G that correspond to the components of Gu . The vertices of G are connected if
they are connected in Gu . Other notions for undirected graphs can be used for digraphs
as well by dealing with the underlying undirected graph.
6. Vertices u and v are strongly connected if there is a directed u–v path and also a directed
v–u path in G.
7. Digraph G is strongly connected if every pair of vertices is strongly connected. By convention, the trivial graph is strongly connected.
8. A strongly connected component H of the digraph G is a directed subgraph of G (not a
null graph) such that H is strongly connected, but if we add any vertices or arcs to it, then
it is not strongly connected anymore.
Every vertex of the digraph G belongs to one strongly connected component of G (compare to
Theorem 1.3). However, an arc does not necessarily belong to any strongly connected component of G.
Example. For the digraph G
e9
v1
v5
e2
e6
e1
e8
v3
e3
v2
e4
e5
v4
e7
v6
the strongly connected components are ({v1 }, ∅), ({v2 , v3 , v4 }, {e3 , e4 , e5 }), ({v5 }, ∅) and ({v6 }, ∅).
The condensed graph Gc of the digraph G is obtained by contracting all the arcs in every
strongly connected component.
Example. (Continuing from the previous example) The condensed graph is
v1
e9
v5
e8
w
v6
CHAPTER 3. DIRECTED GRAPHS
29
3.2 Directed Trees
A directed graph is quasi-strongly connected if one of the following conditions holds for every
pair of vertices u and v:
(i) u = v or
(ii) there is a directed u–v path in the digraph or
(iii) there is a directed v–u path in the digraph or
(iv) there is a vertex w so that there is a directed w–u path and a directed w–v path.
Example. (Continuing from the previous example) The digraph G is quasi-strongly connected.
Quasi-strongly connected digraphs are connected but not necessarily strongly connected.
The vertex v of the digraph G is a root if there is a directed path from v to every other vertex
of G.
Example. (Continuing from the previous example) The digraph G only has one root, v1 .
Theorem 3.1. A digraph has at least one root if and only if it is quasi-strongly connected.
Proof. If there is a root in the digraph, it follows from the definition that the digraph is quasistrongly connected.
Let us consider a quasi-strongly connected digraph G and show that it must have at least
one root. If G is trivial, then it is obvious. Otherwise, consider the vertex set V = {v1 , . . . , vn }
of G where n ≥ 2. The following process shows that there must be a root:
1. Set P ← V .
2. If there is a directed u–v path between two distinct vertices u and v in P , then we remove
v from P . Equivalently, we set P ← P − {v}. We repeat this step as many times as
possible.
3. If there is only one vertex left in P , then it is the root. For other cases, there are at least
two distinct vertices u and v in P and there is no directed path between them in either
direction. Since G is quasi-strongly connected, from condition (iv) it follows that there
is a vertex w and a directed w–u path as well as a directed w–v path. Since u is in P , w
can not be in P . We remove u and v from P and add w, i.e. we set P ← P − {u, v} and
P ← P ∪ {w}. Go back to step #2.
4. Repeat as many times as possible.
Every time we do this, there are fewer and fewer vertices in P . Eventually, we will get a root
because there is a directed path from some vertex in P to every vertex we removed from P .
The digraph G is a tree if Gu is a tree. It is a directed tree if Gu is a tree and G is quasistrongly connected, i.e. it has a root. A leaf of a directed tree is a vertex whose out-degree is
zero.
CHAPTER 3. DIRECTED GRAPHS
30
Example.
6 leaves
root
Theorem 3.2. For the digraph G with n > 1 vertices, the following are equivalent:
(i) G is a directed tree.
(ii) G is a tree with a vertex from which there is exactly one directed path to every other vertex
of G.
(iii) G is quasi-strongly connected but G − e is not quasi-strongly connected for any arc e in
G.
(iv) G is quasi-strongly connected and every vertex of G has an in-degree of 1 except one
vertex whose in-degree is zero.
(v) There are no circuits in G (i.e. not in Gu ) and every vertex of G has an in-degree of 1
except one vertex whose in-degree is zero.
(vi) G is quasi-strongly connected and there are no circuits in G (i.e. not in Gu ).
Proof. (i)⇒(ii): If G is a directed tree, then there is a root. This implies that there is a directed
path from the root to every other vertex in G (but not more than one path since Gu is a tree).
(ii)⇒(iii): If (ii) is true, then G obviously is quasi-strongly connected. We will prove by
contradiction by considering the counter hypothesis: There is an arc e in G such that G − e is
quasi-strongly connected. The arc e is not a loop because G is a directed tree. Let u and v be
the two different end vertices of e. There does not exist a directed u–v path or a directed v–u
path in G − e (otherwise Gu would have a circuit). Therefore, there is a vertex w and a directed
w–u path as well as a directed w–v path. However, this leads to the existence of two directed
w–u paths or two directed w–v paths in G depending on the direction of the arc e. Then, there
√
is a circuit in the tree Gu . ( by Theorem 1.6).
(iii)⇒(iv): If G quasi-strongly connected, then it has a root r (Theorem 3.1) so that the indegrees of other vertices are ≥ 1. We start by considering the counter hypothesis: There exists
a vertex v 6= r and d− (v) > 1. Then, v is the terminal vertex of two distinct arcs (u, v) and
√
(w, v). If there were a loop e in G, then G − e would be quasi-strongly connected ( ). Thus,
u 6= v with w 6= v. Now, there are two distinct directed trails from r to v. The first one includes
(u, v) and the second one includes (w, v). We have two possible cases:
CHAPTER 3. DIRECTED GRAPHS
31
u
u
v
r
v
r
w
w
In the digraph on the left, the paths r–u and r–w do not include the arcs (u, v) and (w, v).
Both G − (u, v) and G − (w, v) are quasi-strongly connected. In the digraph on the right,
the r–u path includes the arc (w, v) or (as in the figure) the r–w path includes the arc (u, v).
In either case, only one of G − (u, v) and G − (w, v) is quasi-strongly connected because
√
the root is r (Theorem 3.1). ( ) We still have to show that d− (r) = 0. Let us consider the
counter hypothesis: d− (r) ≥ 1. Then, r is the terminal vertex of some arc e. However, the tree
√
G − e is then quasi-strongly connected since r is its root (Theorem 3.1). ( )
(iv)⇒(v): If (iv) is true, then it is enough to show that there are no circuits in Gu . The sum
of in-degrees of all the vertices in G is n − 1 and the sum of out-degrees of all the vertices in G
is also n − 1, i.e. there are n − 1 arcs in G. Since G is quasi-strongly connected, it is connected
and it is a tree (Theorem 2.1). Therefore, there are no circuits in Gu .
(v)⇒(vi): If we assume that (v) is true, then there are n − 1 arcs in G (compare to the
previous proof). By Theorem 2.1, G is a tree. We denote by r the vertex satisfying condition
(v). By Theorem 2.1, we see that there is exactly one path to any other vertex of G from r.
These paths are also directed. Otherwise, d− (r) ≥ 1 or the in-degree of some vertex on that
path is > 1 or the in-degree of some other vertex other than r on that path is zero. Hence, r is a
root and G is quasi-strongly connected (Theorem 3.1).
(vi)⇒(i): If G is quasi-strongly connected, then it has a root (Theorem 3.1). Since G is
connected and there are no circuits in G, it is a tree.
A directed subgraph T of the digraph G is a directed spanning tree if T is a directed tree
and T includes every vertex of G.
Example.
G:
T:
Theorem 3.3. A digraph has a directed spanning tree if and only if it is quasi-strongly connected.
Proof. If the digraph G has a directed spanning tree T , then the root of T is also a root for G
and it is quasi-strongly connected (Theorem 3.1).
We now assume that G is quasi-strongly connected and show that it has a directed spanning
tree. If G is a directed tree, then it is obvious. Otherwise, from Theorem 3.2, we know that there
CHAPTER 3. DIRECTED GRAPHS
32
is an arc e in G so that if we remove e, G remains quasi-strongly connected. We systematically
remove these kind of arcs until we get a directed tree. (Compare to the proof for Theorem
2.2)
3.3 Acyclic Directed Graphs
A directed graph with at least one directed circuit is said to be cyclic. A directed graph is acyclic
otherwise. Obviously, directed trees are acyclic but the reverse implication is not true.
Example. The digraph
is acyclic but it is not a directed tree.
Theorem 3.4. In an acyclic digraph, there exist at least one source (a vertex whose in-degree
is zero) and at least one sink (a vertex whose out-degree is zero).
Proof. Let G be an acyclic digraph. If G has no arcs, then it is obvious. Otherwise, let us
consider the directed path
vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik ,
which has the maximum path length k. Since G is acyclic, vi0 6= vik . If (v, vi0 ) is an arc, then
one of the following is true:
• v 6= vit for every value of t = 0, . . . , k. Then,
v, (v, vi0 ), vi0 , ej1 , vi1 , ej2 , . . . , ejk , vik
is a directed path with length k + 1.
√
• v = vit for some value of t. We choose the smallest such t. Then, t > 0 because there are
no loops in G and
vi0 , ej1 , vi1 , ej2 , . . . , ejt , vit , (v, vi0 ), vi0
√
is a directed circuit.
Hence, d− (vi0 ) = 0. Using a similar technique, we can show that d+ (vik ) = 0 as well.
If G = (V, E) is a digraph with n vertices, then a labeling of the vertices with an injective
function α : V → {1, . . . , n} which satisfies the condition α(u) < α(v) whenever (u, v) is an
arc in G is known as topological sorting.
CHAPTER 3. DIRECTED GRAPHS
33
Theorem 3.5. We can sort the vertices of a digraph topologically if and only if the graph is
acyclic.
Proof. If the digraph is cyclic, then obviously we can not sort the vertices topologically.
If the digraph G is acyclic, then we can sort the vertices in the following manner: 2
1. We choose a vertex v which is a sink. It exists by Theorem 3.4. We set α(v) ← n,
G ← G − v and n ← n − 1.
2. If there is just one vertex v in G, set α(v) ← 1. Otherwise, go back to step #1.
2
This is known as Marimont’s Algorithm. The algorithm itself contains other items, too. The original reference is M ARIMONT, R.B.: A New Method of Checking the Consistency of Precedence Matrices. Journal of the
Association for Computing Machinery 6 (1959), 164–171.
Chapter 4
Matrices and Vector Spaces of Graphs
4.1 Matrix Representation of Graphs
The adjacency matrix of the graph G = (V, E) is an n × n matrix D = (dij ), where n is the
number of vertices in G, V = {v1 , . . . , vn } and
dij = number of edges between vi and vj .
In particular, dij = 0 if (vi , vj ) is not an edge in G. The matrix D is symmetric, i.e. DT = D.
Example.

v2
v1


D=


v4
v3
0
2
1
0
0
2
1
0
1
0
1
0
3
0
0
0
1
0
0
0
0
0
0
0
0






v5
Obviously, an adjacency matrix defines a graph completely up to an isomorphism.
The adjacency matrix of a directed graph G is D = (dij ), where
dij = number of arcs that come out of vertex vi and go into vertex vj .
Example.

0
 1
D=
 0
2
v2
v1
v4
1
0
0
1
0
0
0
0

0
0 

0 
1
v3
The all-vertex incidence matrix of a non-empty and loopless graph G = (V, E) is an n × m
matrix A = (aij ), where n is the number of vertices in G, m is the number of edges in G and
(
1 if vi is an end vertex of ej
aij =
0 otherwise.
34
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
35
e1
Example.
v1
v2
e2
e3
e4
v5
v4
v3
 e1
1
 1

A=
 0
 0
0
e2
1
1
0
0
0
e3
1
0
1
0
0
e4
0
1
0
1
0

v1
 v2

 v3

 v4
v5
The all-vertex incidence matrix of a non-empty and loopless directed graph G is A = (aij ),
where


1 if vi is the initial vertex of ej
aij = −1 if vi is the terminal vertex of ej


0 otherwise.
Example.
e1
v2
v1
e2
e3
e4
v4
e5
 e1 e2 e3 e4 e5 
v1
1 −1 −1 −1
0

 −1
1
0
0 −1  v2
A=
 0
0
0
0
0  v3
v4
0
0
1
1
1
v3
Since every column of an all-vertex incidence matrix contains exactly two non-zero numbers, two ones, we can remove a row and still have enough information to define the graph. The
incidence matrix of a graph is obtained by removing a row from the all-vertex incidence matrix.
It is not unique because there are n possible rows to remove. The vertex corresponding to the
row removed is called the reference vertex.
Similarly, every column in the all-vertex incidence matrix of a digraph contains exactly two
non-zero numbers, +1 and −1. We can remove a row from the all-vertex incidence matrix and
obtain the incidence matrix. Notice that the rows of an all-vertex incidence matrix are linearly
dependent because the sum of rows is a zero vector.
Theorem 4.1. The determinant of an incidence matrix of a nontrivial tree is ±1, regardless of
whether the tree is a directed graph or not.
Proof. We use induction on n, the number of vertices in the tree.
Induction Basis: n = 2 and it is obvious.
Induction Hypothesis: The theorem is true for n ≤ k. (k ≥ 2)
Induction Statement: The theorem is true for n = k + 1.
Induction Statement Proof: Let T be a tree which has k + 1 vertices and let A be an (arbitrary) incidence matrix of T . T has at least two pendant vertices (Theorem 2.3). We choose a
pendant vertex vi which is not the reference vertex of A and the edge et which is incident on vi .
Then,
ait = (±)1 and aij = 0, when j 6= t.
We expand the determinant of |A| by the ith row:
|A| = (±)(−1)i+t |A′ |,
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
36
where A′ is the minor corresponding to ait . We write T ′ = T − vi which is also a tree (vi is a
pendant vertex). We use the induction hypothesis to get |A′| = ±1 because A′ is obviously an
incidence matrix of T ′ .
Corollary. If the digraph G has no loops, then the rank of its all-vertex incidence matrix is
ρ(G).
Proof. If we rearrange the rows or columns of the all-vertex incidence matrix, the rank of the
matrix will not change. Let us rearrange the vertices and arcs to group them by components.
Then, the all-vertex incidence matrix is a block diagonal matrix in which each block is an allvertex incidence matrix of a component.
 st

1 compo nent



nd


2
compo

O


nent




..


.
O


th

k compo- 
nent
We denote ni as the number of vertices in the ith component. Every component has a spanning
tree whose incidence matrix has a nonzero determinant by Theorem 4.1, i.e. the matrix is not
singular. The all-vertex incidence matrix of the ith component is obtained by adding columns
and one row to an incidence matrix of the corresponding spanning tree. The row added is
linearly dependent of other rows so that the rank of this matrix is the same as the rank of the
incidence matrix (= ni − 1). Notice that in the special case when a component is trivial, the
rank is zero = 1 − 1. Therefore,
rank of A = sum of the ranks of the components
= (n1 − 1) + · · · + (nk − 1)
= n1 + · · · + nk −k = ρ(G).
|
{z
}
=n
Remark. From this proof, we can also get a basis for the row space and the column space of
the all-vertex incidence matrix. The columns corresponding to the branches of the spanning
forest of G are a basis of the column space. We can get a basis of the row space by removing
one row out of each component block.
4.2 Cut Matrix
If all the cuts of a nontrivial and loopless graph G = (V, E) are I1 , . . . , It , then the cut matrix
of G is a t × m matrix Q = (qij ), where m is the number of edges in G and
(
1 if ej ∈ Ii (the cut is interpreted as an edge set)
qij =
0 otherwise.
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
37
Example. For the graph
e1
v1
e4
v2
e2
e3
v3
the cuts are I1 = {e1 , e4 }, I2 = {e2 , e3 , e4 } and I3 = {e1 , e2 , e3 }. The cut matrix is
 e1
1
Q= 0
1
e2
0
1
1
e3
0
1
1
e4 
1 I1
1 I2
0 I3
Remark. If the graph has n vertices, then it has 21 (2n − 2) = 2n−1 − 1 cuts. Usually, there are
not this many distinct edge sets. For the cut matrix, we only take one cut corresponding to an
edge set so that there would not be repeated rows. Even so, there are usually too many rows.
If G is a nontrivial and loopless digraph, then we assign an arbitrary direction to every cut
hV1 , V2 i: the orientation of hV1 , V2 i is from V1 to V2 . In other words, we consider oriented cuts
and we pick only one direction from the two possibilities. Then, the cut matrix Q = (qij ) is


1 if ej ∈ Ii and they are in the same direction
qij = −1 if ej ∈ Ii and they are in opposite directions


0 otherwise.
Example. For the digraph
e1
v2
v1
e2
e3
e4
v4
e5
v3
the different cuts (interpreted as edge sets) are I1 = {e1 , e2 , e3 , e4 } (in the direction of e1 ),
I2 = {e3 , e4 , e5 } (in the direction of e3 ), I3 = {e1 , e2 , e5 } (in the direction of e1 ) and I4 = ∅.
The cut matrix is
 e1 e2 e3 e4 e5 
1 −1 −1 −1 0 I1
 0
0
1
1 1 
I2
Q=
 1 −1
0
0 1 I3
0
0
0
0 0 I4
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
38
Since h{v}, V − {v}i is a cut for every vertex v, rows of the all-vertex incidence matrix are
rows of Q. If we are dealing with directed graphs, then these rows may have to be multiplied
by −1.
Theorem 4.2. Every row of the cut matrix of a digraph can be expressed in two different ways
as a linear combination of the rows of the all-vertex incidence matrix. The non-zero coefficients
are either all = +1 or all = −1.
Proof. Let Q be the cut matrix of a digraph G = (V, E) and let A be the all-vertex incidence
matrix. Let hV1 , V2 i (note that it is oriented) be the cut corresponding to the ith row of Q.
Reindexing if needed, we can assume that
V1 = {v1 , . . . , vr } and
V2 = {vr+1 , . . . , vn }.
We write
qi = ith row of Q
We show that
qi =
and at = tth row of A.
r
X
at = −
t=1
n
X
at ,
t=r+1
which proves the theorem. Let (vp , vq ) = ek be the k th arc of G. Then,
apk = k th element of the vector ap = 1,
aqk = k th element of the vector aq = −1
and
ajk = 0
if
j 6= p, q.
We get four cases:
• vp ∈ V1 and vq ∈ V2 : Now p ≤ r and q ≥ r + 1 so qik = 1 and
qik =
r
X
atk = −
t=1
n
X
atk .
t=r+1
• vp ∈ V2 and vq ∈ V1 : Now p ≥ r + 1 and q ≤ r so qik = −1 and
qik =
r
X
atk = −
t=1
n
X
atk .
t=r+1
• vp ∈ V1 and vq ∈ V1 : Now p ≤ r and q ≤ r so qik = 0 and
qik =
r
X
t=1
atk = − ar+1,k − · · · − ank .
|{z}
| {z }
=0
=0
• vp ∈ V2 and vq ∈ V2 : Now p ≥ r + 1 and q ≥ r + 1 so qik = 0 and
qik = a1k + · · · + ark = −
|{z}
|{z}
=0
=0
n
X
t=r+1
atk .
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
39
The statements above are valid for every k.
Example. (Continuing from the previous example) The corresponding row of I1 is
(1, −1, −1, −1, 0) = (1, −1, −1, −1, 0) = −(−1, 1, 0, 0, −1) − (0, 0, 0, 0, 0) − (0, 0, 1, 1, 1).
Corollary. The rank of the cut matrix of a digraph G is ρ(G).
Proof. The all-vertex incidence matrix A of G is also a submatrix of the cut matrix Q of G.
Then, (by Corollary of Theorem 4.1)
rank(Q) ≥ rank(A) = ρ(G).
On the other hand, by Theorem 4.2, every row of Q can be expressed as a linear combination
of the rows of A. Therefore,
rank(Q) = rank(A) = ρ(G).
Another consequence is that the cut matrix Q can be expressed as
Q = A1 A,
where the elements of A1 are 0 or ±1. In addition, the matrix A1 can be constructed from the
process in the proof of Theorem 4.2.
If the graph G is connected, then it has a spanning tree T and an associated fundamental cut
set. The fundamental cut sets are also cuts (when cuts are interpreted as edge sets). Therefore,
the cut matrix Q of G has a submatrix Qf that corresponds to these fundamental cut sets.
This matrix is called the fundamental cut set matrix. Similarly, the connected digraph G has
a fundamental cut set matrix: if we interpret a fundamental cut set as a set, then the direction
of the cut is chosen to be the same as the direction of the corresponding branch of T . If we
rearrange the edges of G so that we have the branches first and sort the fundamental cut sets in
the same order, then we get the fundamental cut set matrix in the form
Qf = In−1 Qfc ,
where In−1 is the identity matrix with n − 1 rows. The rank of Qf is thus n − 1 = ρ(G).
Example. (Continuing from the previous example) We left out vertex v3 so we get a connected
digraph. We choose the spanning tree
e1
v1
T:
v2
e3
v4
The fundamental cut sets are I2 = {e3 , e4 , e5 } (in the direction of e3 ) and I3 = {e1 , e2 , e5 } (in
the direction of e1 ). Then,
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
40
e1 e3 e2 e4 e5 1 0 −1 0 1 I3
Qf =
0 1
0 1 1 I2
and
 e1 e2 e3 e4 e5 
1 −1 −1 −1 0

0
0
1
1 1 ←
Q=
1 −1
0
0 1 ←
4.3 Circuit Matrix
We consider a loopless graph G = (V, E) which contains circuits. We enumerate the circuits of
G: C1 , . . . , Cℓ . The circuit matrix of G is an ℓ × m matrix B = (bij ) where
(
1 if the arc ej is in the circuit Ci
bij =
0 otherwise
(as usual, E = {e1 , . . . , em }).
The circuits in the digraph G are oriented, i.e. every circuit is given an arbitrary direction
for the sake of defining the circuit matrix. After choosing the orientations, the circuit matrix of
G is B = (bij ) where


1 if the arc ej is in the circuit Ci and they in the same direction
bij = −1 if the arc ej is in the circuit Ci and they are in the opposite direction


0 otherwise.
Example. For the directed graph
e1
v1
e4
v2
e2
e3
v3
the circuits are
v1
e1
v2
C1
e4
e3
v3
and the circuit matrix is
v1
e1
C2
e4
v2
v2
e2
v3
e2
e3
v3
C1
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
41
 e1 e2 e3 e4 
1
0 −1
1
C1
1
0 −1  C2
B =  −1
0 −1
1
0
C3
If the graph G is connected and contains at least one circuit, then it has a cospanning tree
T and the corresponding fundamental circuits. By choosing the corresponding rows of the
circuit matrix B, we get an (m − n + 1) × m matrix Bf , called the fundamental circuit matrix.
Similarly, a connected digraph G with at least one circuit has a fundamental circuit matrix: the
direction of a fundamental circuit is the same as the direction of the corresponding link in T ∗ .
When we rearrange the edges of G so that the links of T ∗ come last and sort the fundamental
circuits in the same order, the fundamental circuit matrix takes the form
Bf = Bft Im−n+1 ,
∗
where Im−n+1 is the identity matrix with m−n+1 rows. The rank of Bf is thus m−n+1 = µ(G)
and the rank of B is ≥ m − n + 1.
Example. (Continuing from the previous example) We left out vertex v3 so we get a connected
digraph (see p.34) and we chose the spanning tree
e1
v1
T:
v2
e3
v4
The fundamental circuits are
e1
v2
v1
C1
e2
v1
e1
v1
e3
e4 C2
v4
e3
v2
C3
e5
v4
and
 e1 e3 e2
1
0 1
Bf =  0 −1 0
−1 −1 0
e4
0
1
0
e5 
0 C1
0 C2
1 C3
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
42
Theorem 4.3. An oriented cut and an oriented circuit of a digraph have an even number of
common arcs. Half of these arcs have the same direction in the cut and in the circuit, and the
remaining arcs have opposite directions in the cut and in the circuit.
Proof. Compare to the proof of Theorem 2.6.
Theorem 4.4. For a digraph, BQT = O (zero matrix).
Proof. By the previous theorem, half of the nonzero numbers in the dot product corresponding
to each element of BQT are +1. The remaining nonzero numbers are −1. Therefore, the dot
product is = 0.
Theorem 4.5. If the digraph G contains at least one circuit, then the rank of its circuit matrix
B is µ(G). Furthermore, if G is connected, then the circuit matrix B can be expressed as
B = B2 Bf , where the matrix B2 consists of 0’s and ±1’s, and the cut matrix Q can be expressed
as Q = Q1 Qf , where the matrix Q1 consists of 0’s and ±1’s.
Proof. First we consider the case when G is connected. We choose a spanning tree T of G and
rearrange the m edges of G so that the branches of T come first and the links of T ∗ come last.
We sort the fundamental cut sets in the same order as the branches and links. Then,
Qf = In−1 Qfc
and Bf = Bft Im−n+1 .
The blocks of B can be constructed in a similar way:
B=
B1 B2
.
Since Qf is a submatrix of Q and Bf is a submatrix of B, it follows from Theorem 4.4 that
T
In−1
T
In−1 Qfc
= Bft Im−n+1
O = Bf Qf = Bft Im−n+1
QT
fc
T
= Bft In−1 + Im−n+1 QT
fc = Bft + Qfc .
Hence
Bft = −QT
fc .
Furthermore, since Qf is a submatrix of Q, we can use the same theorem to get
T
In−1
T
In−1 Qfc
O = BQf = B1 B2
= B1 B2
QT
fc
= B1 In−1 + B2 QT
fc = B1 − B2 Bft .
Hence
B=
B2 Bft B2
= B2
Bft Im−n+1
= B2 Bf ,
as claimed. In the same way, Q can be expressed as Q = Q1 Qf , as claimed, which is clear
anyway since the rank of Q is n − 1 and its elements are 0’s and ±1’s.
Every row of B is a linear combination of the rows corresponding to the fundamental circuits
and the rank of B is at most equal to the rank of Bf = m − n + 1. On the other hand, as we
pointed out earlier, the rank of B is ≥ m − n + 1. Thus, rank(B) = m − n + 1 (= µ(G)) for a
connected digraph.
In the case of a disconnected digraph G (which contains at least one circuit), it is divided into
components (k ≥ 2 components) and the circuit matrix B is divided into blocks corresponding
to the components (compare to the proof of the corollary of Theorem 4.1), in which case
rank(B) =
k
X
i=1
(mi − ni + 1) = m − n + k = µ(G).
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
43
Notice that the proof also gives the formula, Bft = −QT
fc , which connects the fundamental
cut matrix and the fundamental circuit matrix.
4.4 An Application: Stationary Linear Networks
A stationary linear network is a directed graph G that satisfies the following conditions:
1. G is connected.
2. Every arc of G belongs to some circuit and there are no loops in G.
3. Every arc ej in G is associated with a number ij called the through-quantity or flow. If
there are m arcs in G, then we write


i1


i =  ... 
im
(through-vector).
4. Every vertex vi in G is associated with a number pi called the potential. Furthermore, the
across-quantity or potential difference of the arc ej = (vi1 , vi2 ) is
u j = p i2 − p i1 .
If there are n vertices and m arcs in G, then we write



p1



p =  ...  and u = 
pn

u1
.. 
. 
um
(potential vector and across-vector). (Potentials are rarely needed.)
5. Every arc ej is one of the following:
(a) a component1 , for which there is an associated number rj . rj is constant (6= 0)
(stationarity) and the following equation links the quantities:
uj = ij rj
(linearity).
(b) a through-source, for which the through-quantity ij is fixed.
(c) an across-source, for which the across-quantity uj is fixed.
6. (Kirchhoff’s Through-Quantity Law) The sum of the through-quantities of an oriented cut
of G is zero when the cut is interpreted as an edge set and the sign of a through-quantity
is changed if the directions of a cut and an arc are different.
7. (Kirchhoff’s Across-Quantity Law) The sum of the across-quantities of an oriented circuit
of G is zero when the sign of an across-quantity is changed if the directions of a circuit
and an arc are different.
1
Not to be confused with a component of a graph!
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
44
Example. A typical stationary linear network is an electrical circuit with linear resistors, constant current sources and constant voltage sources. The components are resistors and rj are the
resistances. Equation 5.(a) is Ohm’s Law.
We take a spanning tree T of a stationary linear network G, its fundamental cut matrix Qf
and its fundamental circuit matrix Bf . Let us rearrange the arcs in these matrices and vectors i
and u like we did before. That is, the branches of T will come first followed by the links of T ∗ .
Kirchhoff’s Laws can then be written as
Qi = 0
and Bu = 0.
On the other hand, the rows of the fundamental cut matrix Qf span all the rows of Q, and
similarly rows of the fundamental circuit matrix Bf span the rows of B. Then, Kirchhoff’s
Laws can also be written as
Qf i = 0n−1
and
Bf u = 0m−n+1 .
Let us form the diagonal matrices K = ⌈k1 , . . . , km ⌋ and L = ⌈ℓ1 , . . . , ℓm ⌋, where




−rj if ej is a component
1 if ej is a component
kj = 1 if ej is a through-source
and ℓj = 0 if ej is a through-source




0 if ej is an across-source
1 if ej is an across-source,
and the m-vector s = (s1 , . . . , sm )T , where


0 if ej is a component
sj = ij if ej is a through-source


uj if ej is an across-source.
Then, all the information can be expressed as a system of linear equations




K
L
s
i

Qf
O(n−1)×m 
=  0n−1  ,
u
O(m−n+1)×m
Bf
0m−n+1
known as the fundamental equations. The through and across quantities can be solved (ideally)
if rj and the sources are given.
Remark. The same procedure can be applied to form state (differential) equations for dynamic
networks, which have nonstationary components.
The matrix of this system of linear equations does not have to be nonsingular and the system
does not even have to have a unique solution at all. For example, in the matrix above, we can
easily see that it is singular if some circuit only consists of across-sources or if some cut only
consists of through-sources. As a matter of fact, this is the only case when the through and
across quantities are not defined uniquely if the constants rj are real numbers with the same
sign (and often otherwise too).
We choose a specific spanning tree T to explore these concepts more carefully:
Lemma. If no cut of G consists of only through-sources and no circuit of G consists of only
across-sources, then G has a spanning tree T such that every across-source is a branch of T
and every through-source is a link of T ∗ .
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
45
Proof. If G satisfies the hypothesis, then we first choose a digraph M which has every vertex
and across-source (arc) of G. There are no circuits in this digraph. Then we add components to
M one by one and try to come up with a spanning tree. If this fails at some point, then G has a
cut with only through-sources, which is impossible.
Now let us assume that no cut of G consists of only through-sources and no circuit of G
consists of only across-sources. We use the spanning tree T mentioned in the lemma. We
rearrange the arcs of G so that (as before) the branches of T come first. Within these branches,
the across-sources come first followed by components. Similarly, the links are rearranged so
that the components come first and the through-sources come last.
The system of 2m equations can then be written as



O O
O
O
I
O O O
i1
 O −R1 O


O
O
I O O 

  i2 
 O O −R2 O


O
O I O 

  i3 
 O O


O
I
O
O O O 

  i4 
 I


O
Q11 Q12 O
O O O   u1 


 O
  u2 
I
Q
Q
O
O
O
O
21
22



 O O
O
O B11 B12 I O   u3 
O O
O
O B21 B22 O I
u4






= 





s1
0
0
s2
0
0
0
0

← across-sources (in branches)
 ← components (in branches)

 ← components (in links)

 ← through-sources (in links)

 ← fundamental cut sets (across-sources)

 ← fundamental cut sets (components)

 ← fundamental circuits (components)
← fundamental circuits (through-sources)
where the I’s are identity matrices of the right dimensions, the O’s are zero matrices of the right
dimensions and the 0’s are zero vectors of the right dimensions.
Remark. Here we assume that G has all these four types of arcs (across-source branch, component branch, through-source link and component link). In other cases (for example, when
there are no through-sources), we leave the corresponding rows, columns and elements out of
the system of equations. Other cases are treated in a similar way.
Solving the equations, we get
u1 = s1
,
u2 = R1 i2
,
u3 = R2 i3
which leaves this system of equations:


i1
I
O
Q11 O


 O
I
Q
O
21
  i2

 O B12 R1 R2 O   i3
u4
O B22 R1 O I
Thus,
i1 = −Q11 i3 − Q12 s2
,
,
i4 = s2

Q12 s2



 = −  Q22 s2  .

 B11 s1 
B21 s1

i2 = −Q21 i3 − Q22 s2

,
u4 = −B22 R1 i2 − B21 s1 .
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
46
From the results in the previous section, we get
Bft =
B11 B12
B21 B22
=
−QT
fc
=−
Q11 Q12
Q21 Q22
T
=
T
−QT
11 −Q21
T
−QT
12 −Q22
.
T
Therefore, B11 = −QT
11 and B12 = −Q21 . Finally, there is only one set of equations for i3 :
T
T
(QT
21 R1 Q21 + R2 )i3 = Q11 s1 − Q21 R1 Q22 s2 .
The matrix2 of this system of equations can written as
O
R
Q
1
21
T
Q21 R1 Q21 + R2 = QT
.
21 I
O R2
I
We can see that it is not singular if the diagonal elements of R1 and R2 are all positive or all
negative.
Therefore, we get
Theorem 4.6. If the constants rj are real numbers with the same sign, then the fundamental
equations of the stationary linear network have a unique solution exactly when no cut of the
network consists of only through-sources and no circuit of the network consists of only acrosssources.
From the theorem above, we notice that the number of equations we have to solve (numerically)
is considerably fewer than 2m.
Example. A mono-frequency AC circuit with passive elements (resistors, capacitors and inductors) can also be modelled as a stationary linear network (Theorem 4.6 does not apply). In the
circuit below, the component values are R = 10 Ω, C = 100 µF, L = 10 mH and the current
source is
I = 10 cos(1000t) A.
R
I
R
C
L
The complex current of the source is 10ej1000t , where j is the imaginary unit. The (angular)
frequency is ω = 1000 rad/s. There are no voltage sources. The corresponding digraph is
2
This matrix is called the impedance matrix. Similarly, the admittance matrix can be constructed from the
blocks of the fundamental circuit matrix
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
47
v2
e4
e5
e1
e3
v3
e2
v1
The voltages and currents written as complex exponentials are ik = Ik ej1000t and uk = Uk ej1000t .
In particular, the current source is i5 = s5 = 10ej1000t . We get rk from the familiar formulae
from electrical circuit analysis:
r1 = r4 = R = 10 ,
r3 =
1
= −10j
jωC
,
r2 = jωL = 10j.
We choose the arcs e1 and e2 as the branches of the spanning tree T . Because of the linearity
of the system of equations, the exponential factors ej1000t cancel out and we get
















−10
0
0
0 0 1 0 0
0 −10j 0
0 0 0 1 0
0
0
10j
0 0 0 0 1
0 −10 0 0 0 0
0
0
0
0
0
0 1 0 0 0
1
0
1
1 1 0 0 0
0
1
0
−1 0 0 0 0
0
0
0
0 0 −1 0 1
0
0
0
0 0 −1 1 0
0
0
0
0 0 −1 0 0
0
0
0
1
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
1
















I1
I2
I3
I4
I5
U1
U2
U3
U4
U5


 
 
 
 
 
 
 
=
 
 
 
 
 
 
 
0
0
0
0
10
0
0
0
0
0








.







Notice that we have left out the across-sources because there are none. This system is easily
solved using computer programs, e.g. MATLAB:
»H=[-10
0
0
0 0
0 -10*j
0
0 0
0
0 10*j
0 0
0
0
0 -10 0
0
0
0
0 1
1
0
1
1 1
0
1
0
-1 0
0
0
0
0 0
0
0
0
0 0
0
0
0
0 0
»s=[0 0 0 0 10 0 0 0 0 0]’;
»UV=inv(H)*s;
»[UV angle(UV) abs(UV)]
1
0
0
0
0
0
0
-1
-1
-1
0
1
0
0
0
0
0
0
1
0
0
0
1
0
0
0
0
1
0
0
0
0
0
1
0
0
0
0
1
0
0 ;
0 ;
0 ;
0 ;
0 ;
0 ;
0 ;
0 ;
0 ;
1];
ans =
-6.0000
-2.0000
-2.0000
-2.0000
10.0000
-60.0000
+
+
+
2.0000i
4.0000i
6.0000i
4.0000i
+20.0000i
2.8198
2.0344
-1.8925
2.0344
0
2.8198
6.3246
4.4721
6.3246
4.4721
10.0000
63.2456
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
-40.0000
-60.0000
-20.0000
-60.0000
-20.0000i
+20.0000i
+40.0000i
+20.0000i
-2.6779
2.8198
2.0344
2.8198
48
44.7214
63.2456
44.7214
63.2456
Thus, for example, the complex voltage across the current source is
u5 = U5 ej1000t = 63.25ej(1000t+2.82)
and the real voltage is 63.25 cos(1000t + 2.82) V.
Kirchhoff’s Through-Quantity Law can also be written in the form
Ai = 0n ,
where A is the all-vertex incidence matrix of G. Furthermore,
AT p = −u.
Hence
u • i = uT i = −pT Ai = 0.
This result only depends on the structure of the digraph G (through the all-vertex incidence
matrix). Now we get the famous theorem:
Theorem 4.7. (Tellegen) If two stationary linear networks have the same digraph with corresponding through-vectors i1 and i2 as well as corresponding across-vectors u1 and u2 , then
u1 • i2 = 0 and
u2 • i1 = 0.
If we apply this to the case when the two networks are exactly the same (= G), then we get
u • i = 0,
known as the Law of Conservation of Energy.
Remark. More details on this subject can be found e.g. in S WAMY & T HULASIRAMAN or
VÁGÓ , as well as D OLAN & A LDOUS .
4.5 Matrices over GF(2) and Vector Spaces of Graphs
The set {0, 1} is called a field (i.e. it follows the same arithmetic rules as real numbers) if
addition and multiplication are defined as follows:
+ 0 1
0 0 1
1 1 0
× 0 1
0 0 0
1 0 1
In this case −1 = 1 and 1−1 = 1. This is the field GF(2).
If we think of the elements 0 and 1 of the all-vertex incidence, cut, fundamental cut, circuit
and fundamental circuit matrices of a (”undirected”) graph as elements of the field GF(2), then
Theorems 4.1, 4.2, 4.4, 4.5 and their corollaries also apply to ”undirected graphs”. (Keep in
mind that −1 = 1 in the field GF(2).) The proofs are the same.
CHAPTER 4. MATRICES AND VECTOR SPACES OF GRAPHS
49
For ”undirected” graphs, the vector spaces are over the field GF(2). For directed graphs, the
vector spaces are real (i.e. over the field R). The row space of the cut matrix of a (di)graph is
the cut space. Similarly, the row space of the circuit matrix is the circuit space. The dimension
of the cut space is the rank of the (di)graph and the dimension of the circuit space is the nullity
of the (di)graph. Furthermore, the cut space and the circuit space are orthogonal complements.
(All of these statements follow directly from the results above.)
Often, we deal with the above mentioned spaces through subgraphs, i.e. we identify a vector
with the subgraph generated by the corresponding arcs. In the case of ”undirected” graphs, the
addition of GF(2) vectors corresponds to the ring sum operation.
Chapter 5
Graph Algorithms
5.1 Computational Complexity of Algorithms
The complexity of a problem is related to the resources required to compute a solution as a
function of the size of the problem. The size of a problem is measured by the size of the input N,
and the resources required are usually measured by time (number of steps) and space (maximum
amount of memory measured appropriately). Decision problems or yes-or-no questions are very
common. Read H OPCROFT & U LLMAN for classical complexity theory.
To make computational complexities comparable, we need to agree on some specific mathematical models for algorithms. For example, consider computing with Turing Machines and
refer to courses in Theoretical Computer Science and Mathematical Logic. We have deterministic and nondeterministic version of algorithm models. In the deterministic version, there are
no choices to be made. In the nondeterministic version, there is a choice to be made somewhere
on the way. For a nondeterministic algorithm, we have to make the following assumptions so
that we can actually solve problems:
1. The algorithm terminates at some point no matter how we choose the steps.
2. The algorithm can terminate without yielding a solution.
3. When the algorithm terminates and yields a solution, the solution is correct (it is possible
to have more than one solution).
4. For decision problems, if the algorithm fails to give a positive answer (yes), then the
answer is interpreted to be negative (no).
5. If the problem is to compute a value, then the nondeterministic algorithm has to give a
solution for every input (value of the function).
Nondeterministic algorithms are best treated as verification procedures for problems rather than
procedures for producing answers.
Computational complexity is considered asymptotically, that is for large problems, time
or space complexities that differ by constant coefficients are not distinguished because linear
acceleration and compression of space are easy to perform in any kind of algorithm model.
Although the choice of an algorithm model has a clear impact on the complexity, it is not an
essential characteristic, i.e. it does not change the complexity class. Often, we use the big-O
notation for complexities. O(f (N)) refers to the class of functions g(N) such that if N ≥ N0
holds, then |g(N)| ≤ Cf (N) holds, where C is a constant.
50
CHAPTER 5. GRAPH ALGORITHMS
51
Without exploring algorithm models any further, we define a couple of important complexity classes. The time complexity class P (deterministic polynomial time problems) consists of
problems of (input) size N where it takes at most p(N) steps to solve the problem using deterministic algorithms. p(N) is some problem dependent polynomial of N. The time complexity
class N P (nondeterministic polynomial time problems) consists of problems of size N where it
takes at most p(N) steps to solve the problem using nondeterministic algorithms. Once again,
p(N) is some problem dependent polynomial of N.
Time complexity class co−N P (complements of nondeterministic polynomial time problems) consists of decision problems whose complements are in N P. (The complement of a
problem is obtained by swapping the positive and the negative answer.)
Obviously, P ⊆ N P and (for decision problems) P ⊆ co−N P. Whether or not the inclusion is proper is an open problem, actually quite a famous problem. It is widely believed that
both of the inclusions are proper. It is not known if the following holds for decision problems:
N P = co−N P
or
P = N P ∩ co−N P
Most researchers believe that they do not hold.
The space complexity class PSPACE (deterministic polynomial space problems) consists
of problems of (input) size N where it takes at most p(N) memory units to solve the problem using deterministic algorithms. p(N) is some problem dependent polynomial of N. The
space complexity class N PSPACE (nondeterministic polynomial space problems) consists of
problems of size N where it takes at most p(N) memory units to solve the problem using nondeterministic algorithms. Once again, p(N) is some problem dependent polynomial of N. It is
known that
N P ⊆ PSPACE = N PSPACE,
but it is not known whether the inclusion is proper or not.
An algorithm may include some ideally generated random numbers. The algorithm is then
called probabilistic or stochastic. The corresponding polynomial time complexity class is BPP
(random polynomial time problems or bounded-error probabilistic polynomial time problems).
Some stochastic algorithms may fail occasionally, that is, they produce no results and terminate
prematurely. These algorithms are called Las Vegas algorithms. Some stochastic algorithms
may also produce wrong answers (ideally with a small probability). These kind of algorithms
are called Monte Carlo algorithms. Some stochastic algorithms seldom yield exact solutions.
Nevertheless, they give accurate approximate solutions with high probability. These kind of
algorithms are called approximation algorithms.
The task of an algorithm may be to convert a problem to another. This is known as reduction.
If problem A can be reduced to another problem B by using a (deterministic) polynomial time
algorithm, then we can get a polynomial time algorithm for problem A from a polynomial time
algorithm for B. A problem is N P-hard if every problem in N P can be reduced to it by a
polynomial time algorithm. N P-hard problems are N P-complete if they are actually in N P.
N P-complete problems are the ”worst kind”. If any problem in N P could be shown to be
deterministic polynomial time, then every problem in N P would be in P and P = N P. Over
one thousand N P-complete problems are known currently.
The old division of problems into tractable and intractable means that P problems are
tractable and others are not. Because we believe that P =
6 N P in general, N P-complete
problems are intractable. In the following, graph algorithms are either in P or they are approximations of some more demanding problems. The size of an input can be for example the
number of nonzero elements in an incidence matrix, the number of vertices n or the number of
edges m or some combination of n and m.
CHAPTER 5. GRAPH ALGORITHMS
52
5.2 Reachability: Warshall’s Algorithm
We only deal with directed graphs in this section. The results also hold for ”undirected” graphs
if we interpret an edge as a pair of arcs in opposite directions.
Problem. We are given an adjacency matrix of the digraph G = (V, E). We are to construct
the reachability matrix R = (rij ) of G, where
(
1 if G has a directed vi –vj path
rij =
0 otherwise.
(Note that V = {v1 , . . . , vn }.) In particular, we should note that if rii = 1, then vi is in a
directed circuit.
Warshall’s Algorithm constructs a series of n × n matrices E1 , . . . , En where
1. elements of Ei are either zero or one.
2. Ei ≤ Ei+1 (i = 0, . . . , n − 1) (comparison is done element by element).
3. E0 is obtained from the adjacency matrix D by replacing the positive elements with ones.
4. En = R.
The algorithm is presented as a pseudocode:
procedure Warshall
begin
E := E0
for i := 1 to n do
for j := 1 to n do
if (E)ji = 1 then for k := 1 to n do
(E)jk := max((E)jk , (E)ik )
fi
od
od
end
In this case, the maximizing operation is sometimes called the Boolean sum:
max 0 1
0 0 1
1 1 1
Let us show that Warshall’s Algorithm gives us the desired results. Let Ei denote the value
of E after i steps.
Statement. (i) If there is a directed path from vs to vt such that apart from vs and vt , the path
only includes vertices in the set {v1 , . . . , vi }, then (Ei )st = 1.
(ii) If vertex vs belongs to a directed circuit whose other vertices are in the set {v1 , . . . , vi },
then (Ei )ss = 1.
CHAPTER 5. GRAPH ALGORITHMS
53
Proof. We will use induction on i.
Induction Basis: i = 1. (E1 )st = 1 if (E0 )st = 1, or (E0 )s1 = 1 and (E0 )1t = 1. We have
one of the following cases:
vt
s
t: vs
vt
s = t: vs
vs
v1
v1
vs
Induction Hypothesis: The statement is true for i < ℓ. (ℓ ≥ 2)
Induction Statement: The statement is true for i = ℓ.
Induction Statement Proof: Let us handle both statements together. The proof for (ii) is
given in square brackets. We have two cases:
• vℓ belongs to the directed path [resp. directed circuit] but ℓ 6= s, t [resp. ℓ 6= s]. Then, we
use the Induction Hypothesis:
(Eℓ−1 )sℓ = 1
and (Eℓ−1 )ℓt = 1 [resp.
(Eℓ−1)sℓ = 1 and
(Eℓ−1 )ℓs = 1],
so (Eℓ )st = 1 [resp. (Eℓ )ss = 1].
• vℓ is either vs or vt [resp. vℓ is vs ] or it does not belong to the directed path [resp. directed
circuit] at all. Then, by the Induction Hypothesis
(Eℓ−1 )st = 1 [resp.
(Eℓ−1)ss = 1],
so (Eℓ )st = 1 [resp. (Eℓ )ss = 1].
In Warshall’s Algorithm, the maximizing operation is performed at most n3 times.
5.3 Depth-First and Breadth-First Searches
Problem. We have to traverse through a (di)graph to find some kind of vertices or edges.
We assume that the (di)graph is connected and loopless. For disconnected graphs, we have to
go through the components separately. We ignore loops if the (di)graph has any.
Depth-First Search, DFS, has many uses. The procedure is a bit different for undirected
graphs and directed graphs. Therefore they will be treated separately.
Undirected Graphs
We choose a starting vertex r (root) to start the search. Then, we traverse an edge e = (r, v)
to go to the vertex v. At the same time, we direct e from r to v. Now, we say that the edge e
is examined and we call it a tree edge. The vertex r is called the father of v and we denote it
r = FATHER(v).
We continue the search. At a vertex x, there are two cases:
CHAPTER 5. GRAPH ALGORITHMS
54
(1) If every edge incident to x has been examined, return to the father of x and continue the
process from FATHER(x). The vertex x is said to be completely scanned.
(2) If there exist some unexamined edges incident to x, then we choose one such edge e =
(x, y) and direct it from x to y. This edge is now said to be examined. We have two
subcases now:
(2.1) If y has not been visited before, then we traverse the edge (x, y), visit y and continue
the search from y. In this case, e is a tree edge and FATHER(y) = x.
(2.2) If y has been visited before, then we select some other unexamined edge incident to
x. In this case, the edge e is called a back edge.
Every time we come to a new vertex which has never been visited before, we give it a distinct
number. The number of the root is 1. We write
DFN(x) = running number of vertex x.
A complete DFS ends when we traverse back to the root and we have visited every vertex or
when we have found the desired edge/vertex.
DFS divides the edges of G into tree edges and back edges. Obviously, the tree edges form
a spanning tree of G, also known as a DFS tree. If we include the directions of the tree edges,
we get a directed DFS tree. DFS gives a direction to every edge in G. When we use these
directions, we get a digraph whose underlying subgraph is G. It has the DFS tree as a directed
spanning tree.
Example. For the graph
we start the DFS from a root in the upper left corner. The back edges are marked with two lines.
CHAPTER 5. GRAPH ALGORITHMS
55
11
1
=
2
9
=
=
=
3
=
5
=
10
8
=
7
4
6
The corresponding DFS tree is
11
1
2
9
10
3
5
8
7
4
6
In the following, we denote,
(
0 if vertex x has not been visited
K(x) =
1 if vertex x has been visited
and TREE and BACK are set variables containing the directed tree edges and back edges.
Depth-First Search for Graphs:
1. Set TREE ← ∅, BACK ← ∅ and i ← 1. For every vertex x of G, set FATHER(x) ← 0
and K(x) ← 0.
2. Choose a vertex r for which K(r) = 0 (this condition is needed only for disconnected
graphs, see step #6). Set DFN(r) ← i, K(r) ← 1 and u ← r.
3. If every edge incident to u has been examined, go to step #5. Otherwise, choose an edge
e = (u, v) that has not been examined.
CHAPTER 5. GRAPH ALGORITHMS
56
4. We direct edge e from u to v and label it examined.
4.1 If K(v) = 0, then set i ← i + 1, DFN(v) ← i, TREE ← TREE ∪ {e}, K(v) ← 1,
FATHER(v) ← u and u ← v. Go back to step #3.
4.2 If K(v) = 1, then set BACK ← BACK ∪ {e} and go back to step #3.
5. If FATHER(u) 6= 0, then set u ← FATHER(u) and go back to step #3.
6. (Only for disconnected graphs so that we can jump from one component to another.) If
there is a vertex r such that K(r) = 0, then set i ← i + 1 and go back to step #2.
7. Stop.
~ as the directed graph obtained from the algorithm. T
We denote T as the DFS tree and G
~
is a directed spanning tree of G. If there is a directed path from u to v in T , then we call u an
ancestor of v and v a descendent of u. Vertices u and v are related if one of them is an ancestor
of the other. In particular, if (u, v) is an edge of T , then u is the father of v and v is a son of u.
An edge (u, v) of G, where u and v are unrelated, is called a cross edge. However,
Statement. Cross edges do not exist.
Proof. Let u and v be two distinct vertices which are unrelated. Then, (by quasi-strong connectivity) there are two vertices u′ and v ′ such that
• FATHER(u′ ) = FATHER(v ′ ),
• u′ = u or u′ is an ancestor of u and
• v ′ = v or v ′ is an ancestor of v.
We examine the case where DFN(u′ ) < DFN(v ′ ) (the other case is obviously symmetrical).
We label T1 as the directed subtree of T whose root is u′ and T2 as the directed subtree of T
whose root is v ′ . Obviously, DFS goes through the vertices of T2 only after u′ is completely
scanned. Furthermore, u′ is completely scanned only after all the vertices of T1 are completely
scanned. Hence, it is impossible to have an edge (u, v).
Directed Graphs
Depth-first search in a (connected and loopless) digraph G is similar to the case for undirected graphs. The algorithm divides the arcs in G into four different classes. If the search
proceeds to an unexamined arc e = (x, y), then the four possible classes are:
(1) If y has not been visited, then e is a tree edge.
(2) If y has been visited, then there are three cases:
(2.1) y is a descendent of x in the subgraph induced by existing tree edges. Then, e is a
forward edge and DFN(y) > DFN(x).
(2.2) x is a descendent of y in the subgraph induced by the existing tree edges. Then, e is
a back edge and DFN(y) < DFN(x).
(2.3) x and y are not related by any of the existing tree edges. Then, e is a cross edge
and DFN(y) < DFN(x). (Note! It is impossible that DFN(y) > DFN(x). This is
proven in the same way as we did previously.)
CHAPTER 5. GRAPH ALGORITHMS
57
The directed subgraph of G induced by tree edges is called the DFS forest (directed forest).
If DFN(y) > DFN(x) holds for the arc (x, y), then (x, y) is a tree edge or a forward edge.
During the search, it is easy to distinguish the two because (x, y) is a tree edge if y has not been
visited and it is a forward edge otherwise. If DFN(y) < DFN(x), then (x, y) is a back edge or
a cross edge. During the search, it is easy to distinguish the two because (x, y) is a cross edge
if y is completely scanned and it is a back edge otherwise.
In the following, K, FATHER, TREE and BACK are defined as previously. We also have
two new variables FORWARD and CROSS (their meanings are obvious) and
(
1 if x is completely scanned
L(x) =
0 otherwise.
Depth-First Search for Digraphs:
1. Set TREE ← ∅, FORWARD ← ∅, BACK ← ∅, CROSS ← ∅ and i ← 1. For every
vertex x in G, set FATHER(x) ← 0, K(x) ← 0 and L(x) ← 0.
2. Choose a vertex r such that K(r) = 0 and set DFN(r) ← i, K(r) ← 1 and u ← r.
3. If every arc coming out of u has already been examined, then set L(u) ← 1 and go to
step #5. Otherwise, choose an unexamined arc e = (u, v).
4. Label the arc e examined.
4.1 If K(v) = 0, then set i ← i + 1, DFN(v) ← i, TREE ← TREE ∪ {e}, K(v) ← 1,
FATHER(v) ← u and u ← v. Go to step #3.
4.2 If K(v) = 1 and DFN(v) > DFN(u), then set FORWARD ← FORWARD ∪ {e}
and go to step #3.
4.3 If K(v) = 1 and DFN(v) < DFN(u) and L(v) = 0, then set BACK ← BACK ∪
{e} and go to step #3.
4.4 If K(v) = 1 and DFN(v) < DFN(u) and L(v) = 1, then set CROSS ← CROSS ∪
{e} and go to step #3.
5. If FATHER(u) 6= 0, then set u ← FATHER(u) and to go step #3.
6. If there is a vertex r such that K(r) = 0, then set i ← i + 1 and go to step #2.
7. Stop.
Example. DFS in the following digraph starts from a root in the upper left corner and proceeds
like this (back edges are marked with one line, cross edges are marked with two lines and
forward edges are marked with three lines):
CHAPTER 5. GRAPH ALGORITHMS
58
8
1
–––
––
–––
3
–
–
––
–
–
5
–––
4
9
7
11
13
–
2
10
–
12
6
The corresponding DFS forest is
8
1
2
4
9
7
13
3
5
11
6
10
12
CHAPTER 5. GRAPH ALGORITHMS
59
Theorem 5.1. If a depth-first search in a quasi-strongly connected digraph starts from one of its
roots, then the DFS forest is a directed tree. In particular, the DFS forest of a strongly connected
digraph is a directed tree no matter where the search starts from.
Proof. Let us prove by contradiction and consider the counter hypothesis: The DFS forest T
resulted from a DFS in a quasi-strongly connected digraph G that began from root r is not a
directed tree.
Since T is a directed forest, the component T1 of T which has the root r does not contain
some vertex v of G. On the other hand, there is a directed path from r to v. We choose the last
vertex u on this path which is in T1 and the arc e = (u, w). Since the vertex w is not in T1 ,
the edge e is not a tree edge, a back edge nor a forward edge. Then, it must be a cross edge.
√
Because the search began at r, the vertex w has to be in T1 ( ).
Strongly connected digraphs are also quasi-strongly connected and any vertex can be chosen
as a root.
Breadth-first search, BFS, is related to DFS. Let us consider a connected graph G.
Breadth-First Search for Graphs:
1. In the beginning, no vertex is labeled. Set i ← 0.
2. Choose a (unlabeled) starting vertex r (root) and label it with i.
3. Search the set J of vertices that are not labeled and are adjacent to some vertex labeled
with i.
4. If J 6= ∅, then set i ← i + 1. Label the vertices in J with i and go to step #3.
5. (Only for disconnected graphs so we can jump from one component to another.) If a
vertex is unlabeled, then set i ← 0 and go to step #2.
6. Stop.
BFS also produces a spanning tree, called the BFS tree, when we take the edges
(vertex labeled with i, unlabeled vertex)
while forming J. One such tree edge exists for each vertex in J. We obtain the directed BFS tree
by orienting the edges away from the labeled vertex to the unlabeled vertex. BFS as presented
above does not however orient every edge in the graph. Obviously, the label of a vertex is the
length of the shortest path from the root to it, in other words, the distance from the root.
Example. BFS in the graph we had in the previous example starts at a root in the upper left
corner and proceeds as follows. (Tree edges are marked with two cross lines.)
CHAPTER 5. GRAPH ALGORITHMS
60
=
=
=
=
=
=
=
=
=
=
The corresponding BFS tree is
We obtain the directed BFS tree by orienting the branches away from the root.
BFS in a digraph G is very similar to what we just did.
Breadth-First Search for Digraphs:
1. In the beginning, no vertex is labeled. Set i ← 0.
2. Choose an unlabeled starting vertex r (root) and label it with i.
3. Search the set J of terminal vertices of arcs whose initial vertices have been labeled with
i but whose terminal vertices have not been labeled.
4. If J 6= ∅, then set i ← i + 1. Label the vertices in J with i and go to step #3.
5. If not all vertices have been labeled, then set i ← 0 and go to step #2.
6. Stop.
CHAPTER 5. GRAPH ALGORITHMS
61
BFS in a digraph produces a BFS forest (directed forest) when we take the examined arcs
(vertices labeled withi, unlabeled vertices)
while forming J. One such tree edge exists for each vertex in J.
Remark. In addition, BFS can be modified to sort the arcs like DFS.
5.4 The Lightest Path: Dijkstra’s Algorithm
Problem. The edges of a (di)graph are given non-negative weights. The weight of a path is
the sum of the weights of the path traversed. We are to find the lightest (directed) path in the
(di)graph from vertex u to vertex v (6= u) if the path exists (sometimes also called the shortest
path). We should state if such path does not exist.
Obviously, we can assume that we do not have any loops or parallel edges. Otherwise, we
simply remove the loops and choose the edge with the lowest weight out of the parallel edges.
From now on, we only consider directed graphs. Undirected graphs can be treated in the same
way by replacing an edge with two arcs in opposite directions with the same weight.
We denote α(r, s) as the weight of the arc (r, s). Dijkstra’s Algorithm marks the vertices as
permanent or temporary vertices. The label of a vertex r is denoted β(r) and we define
(
1 if the label is permanent
γ(r) =
0 if the label is temporary.
A permanent label β(r) expresses the weight of the lightest directed u–r path. A temporary
label β(r) gives an upper limit to this weight (can be ∞). Furthermore, we denote:
(
the predecessor of vertex r on the lightest directed u–r path if such a path exists
π(r) =
0 otherwise,
so we can construct the directed path with the lowest weight.
Dijkstra’s Algorithm:
1. Set β(u) ← 0 and γ(u) ← 1. For all other vertices r, set β(r) ← ∞ and γ(r) ← 0. For
all vertices r, we set π(r) ← 0. Furthermore, set w ← u.
2. For every arc (w, r), where γ(r) = 0 and β(r) > β(w) + α(w, r), set
β(r) ← β(w) + α(w, r) and
π(r) ← w.
3. Find a vertex r ∗ for which γ(r ∗ ) = 0, β(r ∗) < ∞ and
β(r ∗ ) = min {β(r)}.
γ(r)=0
Set
γ(r ∗ ) ← 1 and
w ← r∗.
If there is no such vertex r ∗ , a directed u–v path does not exist and we stop.
CHAPTER 5. GRAPH ALGORITHMS
62
4. If w 6= v, then go to step #2.
5. Stop.
We see that the algorithm is correct as follows. We denote (for every step):
V1 = {permanently labeled vertices}
V2 = {temporarily labeled vertices}.
(hV1 , V2 i is a cut with the completely scanned vertices on one side and other vertices on the
other side.)
Statement. The label β(r) of the vertex r in V1 is the weight of the lightest directed u–r path
and π(r) is the predecessor of r on such a path.
Proof. After step #2, the temporary label of r is always the weight of a directed u–r path with
the lowest weight whose vertices are in V1 except for r (= ∞ if there is no such path), and π(r)
is a predecessor of r on this path (or = 0). This is because (two cases):
• Before step #2, β(r) = ∞. The only ”new” vertex in V1 is now w so every possible
directed u–r path has to visit w. If there is no such path, then the case is obvious (β(r)
stays at ∞ and π(r) stays at zero). Let us assume that we have the (lightest) directed
u–r path that contains only vertices of V1 and r as well. In particular, w is included. The
subpath from u to w has of course the lowest weight. We consider the vertex s (∈ V1 )
which is the predecessor of r on the directed u–r path. If s = w, then the case is clear. If
√
s 6= w, then s has been a w before, in which case β(r) can not be = ∞ (step #2) ( ).
• Before step #2, β(r) < ∞. Then, β(r) is the weight of the lightest directed u–r path
whose vertices are in V1 − {w} except for r. The only ”new” vertex in V1 is w so every
possible lighter directed u–r path has to visit w. If there is no such path, then the case
is obvious (β(r) and π(r) remain unchanged). Let us assume that we have a (lighter)
directed u–r path that contains only vertices of V1 and r as well. In particular, w is
included. The subpath from u to w has of course the lowest weight. We consider the
vertex s (∈ V1 ) which is the predecessor of r on the directed u–r path. If s = w, then
the case is clear. If s 6= w, then s is in V1 − {w}. Since s has been a w before, there is
a lightest directed u–s path that does not contain w (otherwise, we should have chosen
r ∗ in step #3 to be some predecessor of s on the directed u–w–s path). Then, we get a
√
directed u–r path with a lower weight that contains r and only vertices in V1 − {w} ( ).
The permanent label is the weight we seek because of the minimization in step #3 and π(r)
gives a predecessor of r as we claimed.
At the end of the algorithm, vertex v gets a permanent label or the process stops at step #3
(which means a directed u–v path does not exist). The directed path with the lowest weight can
be obtained by starting from the vertex v and finding the predecessors by using the label π.
If we replace step #4 by
4.’ Go to step #2.
and continue the process until it stops at step #3, we get


0 if w = u
β(w) = the weight of the lightest directed u–w path if there is one


∞ otherwise
CHAPTER 5. GRAPH ALGORITHMS
63
and
π(w) =
(
the predecessor of w on the lightest directed u–w path if there is one and w 6= u
0 otherwise.
Remark. Dijkstra’s algorithm may fail if there are negative weights. These cases are investigated in the next section.
5.5 The Lightest Path: Floyd’s Algorithm
Problem. We are to find the lighest path from vertex u to vertex v (6= u) in a digraph or to show
that there is no such path when the arcs of the digraph have been assigned arbitrary weights.
Note that the weight of a directed path is the sum of the weights of the arcs traversed.
Obviously, we can assume there are no loops or parallel arcs. Otherwise, we simply remove the
loops and choose the arc with the lowest weight out of the parallel arcs. Floyd’s Algorithm only
works for digraphs. We write the weight of (x, y) as α(x, y) and construct the weight matrix
W = (wij ) where
(
α(vi , vj ) if there is an arc (vi , vj )
wij =
∞ otherwise.
(Once again, V = {v1 , . . . , vn } is the vertex set of the digraph.) Floyd’s Algorithm is similar
to Warshall’s Algorithm. It only works if the digraph has no negative cycles, i.e. no directed
circuit in the digraph has a negative weight. In this case, the lightest directed path is the lightest
directed walk.
Floyd’s Algorithm constructs a sequence of matrices W0 , W1 , . . . , Wn where W0 = W
and
(Wk )ij = weight of the lightest directed vi –vj path,
where there are only vertices v1 , . . . , vk on the path besides vi and vj
( = ∞ if there is no such path).
Statement. When Wk is computed from Wk−1 by the formula
(Wk )st = min{(Wk−1)st , (Wk−1)sk + (Wk−1 )kt },
then we get the previously mentioned sequence of weight matrices. If the digraph has negative
cycles, then the sequence is correct up to the point when one of the diagonal elements turns
negative for the first time.
Proof. We use induction on k.
Induction Basis: k = 1. Since the digraph is loopless, the diagonal elements of W0 can only
be ∞ and the lightest directed path (if there is one) is one of the following, and the statement is
obvious:
vt
t: vs
vt
s = t: vs
v1
s
vs
v1
CHAPTER 5. GRAPH ALGORITHMS
64
Induction Hypothesis: The statement is true for k < ℓ. (ℓ ≥ 2)
Induction Statement: The statement is true for k = ℓ.
Induction Statement Proof: The diagonal elements of Wℓ−1 have to be nonnegative (∞ is
permitted) for us to get this k. Let us consider the case where s 6= t. (The case s = t is
analogous.) We have five cases:
• Vertex vℓ is on the lightest directed path but it is not vs or vt , i.e. ℓ 6= s, t. Let us
consider the directed subpath from vs to vℓ whose vertices other than vs and vℓ are in
{v1 , . . . , vℓ−1 }. Suppose the lightest directed vs –vℓ path of this kind has common vertices
with the directed subpath from vℓ to vt other than vℓ itself, e.g. vp . The directed vs –vp –
vℓ –vt walk we get would be lighter than the original directed vs –vt path. By removing
cycles, we would get a directed vs –vt path that would be lighter and would only contain
√
vs as well as vt and the vertices v1 , . . . , vℓ ( ). (We have to remember that weights of
cycles are not negative!) Therefore, the directed subpath from vs to vℓ is the lightest directed vs –vℓ path which contains the vertices v1 , . . . , vℓ−1 as well as vs and vℓ . Similarly,
the directed subpath from vℓ to vt is the lightest directed vℓ –vt path which contains the
vertices v1 , . . . , vℓ−1 as well as vt and vℓ . Now, we use the Induction Hypothesis:
(Wℓ )st < (Wℓ−1 )st
(check the special case (Wℓ−1 )st = ∞) and
(Wℓ )st = (Wℓ−1 )sℓ + (Wℓ−1 )ℓt .
• The directed vs –vt path with the lowest weight exists and vℓ = vs . By the Induction
Hypothesis, (Wℓ )st = (Wℓ−1 )st and
(Wℓ−1 )sℓ + (Wℓ−1 )ℓt = (Wℓ−1 )ℓℓ + (Wℓ−1 )ℓt ≥ (Wℓ−1 )ℓt = (Wℓ−1 )st ,
since (Wℓ−1)ℓℓ ≥ 0 (possibly = ∞).
• The directed vs –vt path exists and vℓ = vt . By the Induction Hypothesis, (Wℓ )st =
(Wℓ−1 )st and
(Wℓ−1 )sℓ + (Wℓ−1 )ℓt = (Wℓ−1 )sℓ + (Wℓ−1 )ℓℓ ≥ (Wℓ−1 )sℓ = (Wℓ−1 )st ,
since (Wℓ−1)ℓℓ ≥ 0 (possibly = ∞).
• The lightest directed vs –vt path exists but vℓ is not on the path. Now, we construct the
lightest directed vs –vℓ path and the lightest vℓ –vt path which, in addition to the end vertices, contain only vertices v1 , . . . , vℓ−1 , if it is possible. By combining these two paths,
we get a directed vs –vt walk. By removing possible cycles from this walk, we get an as
light or even lighter vs –vt path, which only contains vertices v1 , . . . , vℓ as well as vs and
vt . (We have to remember that weights of cycles are not negative!) Therefore, this is a
case where
(Wℓ−1 )sℓ + (Wℓ−1 )ℓt ≥ (Wℓ−1 )st
and the equation in the statement gives the right result. If there is no directed vs –vℓ path
or vℓ –vt path, then it is obvious.
• The lightest directed vs –vt path does not exist. Then, (Wℓ )st = ∞ and (Wℓ−1 )st = ∞.
On the other hand, at least one of the elements (Wℓ−1 )sℓ or (Wℓ−1)ℓt is = ∞ because
otherwise we would get a directed vs –vt path by combining the vs –vℓ path with the vℓ –vt
√
path as well as removing all possible cycles ( ).
CHAPTER 5. GRAPH ALGORITHMS
65
Floyd’s Algorithm also constructs another sequence of matrices Z0 , . . . , Zn in which we
store the lightest directed paths in the following form


ℓ where vℓ is the vertex following vi on the lightest directed

 v –v path containing only vertices v and v as well as v , . . . , v
i
j
i
j
1
k
(Zk )ij =
(if
such
a
path
exists)



0 otherwise.
Obviously,
(
j if (W)ij 6= ∞
(Z0 )ij =
0 otherwise.
The matrix Zk (k ≥ 1) of the sequence can be obtained from the matrix Zk−1 by
(
(Zk−1 )ik if (Wk−1 )ik + (Wk−1)kj < (Wk−1 )ij
(Zk )ij =
(Zk−1 )ij otherwise,
so the sequence can be constructed with the sequence W0 , W1 , . . . , Wn at the same time.
Finally, Floyd’s Algorithm is presented in the following pseudocode. We have added a part
to test if there are negative elements on the diagonal and the construction of the Z0 , . . . , Zn
sequence of matrices.
procedure Floyd
begin
W := W0
k := 0
for i := 1 to n do
for j := 1 to n do
if (W)ij = ∞ then
(Z)ij := 0
else
(Z)ij := j
fi
od
od
while k < n and Test(W) do
Iteration(W, Z, k)
od
end
subprocedure Test(W)
begin
for i := 1 to n do
if (W)ii < 0 then
return FALSE
fi
od
return TRUE
end
CHAPTER 5. GRAPH ALGORITHMS
66
subprocedure Iteration(W, Z, k)
begin
k := k + 1
for i := 1 to n do
for j := 1 to n do
if (W)ik + (W)kj < (W)ij then
(W)ij := (W)ik + (W)kj
(Z)ij := (Z)ik
fi
od
od
end
5.6 The Lightest Spanning Tree: Kruskal’s and Prim’s Algorithms
Problem. We have to find the spanning tree with the lowest weight of a connected graph if the
edges of the graph have been weighted arbitrarily and the weight of a tree is the sum of all the
weights of the branches.
Obviously, we can assume that the graph G = (V, E) is nontrivial and simple. Otherwise, we
simply remove the loops and choose the edge with the lowest weight out of the parallel edges.
We denote the weight of the edge e as α(e) and the weight of the spanning tree T as γ(T ).
As usual, we write the number of vertices as n, number of edges as m, V = {v1 , . . . , vn } and
E = {e1 , . . . , em }.
The distance between two spanning trees T1 and T2 of G is
n − 1 − #(T1 ∩ T2 ) =def. d(T1 , T2 ),
where #(T1 ∩T2 ) is the number of edges in the intersection of T1 and T2 . Obviously, d(T1 , T2 ) =
0 if and only if T1 = T2 . If d(T1 , T2 ) = 1, then T1 and T2 are neighboring trees.
The spanning tree T of G is cut minimal if the weights of the edges of the fundamental
cut set determined by the branch b are ≥ α(b) for every branch b. Similarly, the spanning tree
T is circuit minimal if the edges of the fundamental circuits are ≤ α(c) for every link c in
the cospanning tree T ∗ . The spanning tree T is locally minimal if γ(T ) ≤ γ(T ′ ) for every
neighboring tree T ′ of T .
Lemma. The following three conditions are equivalent for the spanning tree T :
(i) T is cut minimal.
(ii) T is circuit minimal.
(iii) T is locally minimal.
Proof. (i)⇒(ii): Let us assume T is cut minimal and let us consider a fundamental circuit C of
G corresponding to the link c of the cospanning tree T ∗ . Other than c, the branches in C are
branches of T . Every such branch b defines a fundamental cut set of T , which also contains c
(Theorem 2.7). Hence α(b) ≤ α(c).
(ii)⇒(iii): Let us assume that T is circuit minimal and let us consider a neighboring tree T ′
of T . T ′ has (exactly one) branch e′ which is not in T , i.e. e′ is a link of T ∗ . We examine the
CHAPTER 5. GRAPH ALGORITHMS
67
fundamental circuit C defined by e′ . Not all edges of C are in T ′ . We choose an edge e in C
that is not in T ′ . Then, e is a branch of T (actually the only branch of T that is not in T ′ ). Now,
we remove e out of T and add e′ to T . The result has to be T ′ . Because of circuit minimality,
α(e′ ) ≥ α(e), i.e. γ(T ′ ) ≥ γ(T ).
(iii)⇒(i): We consider the locally minimal spanning tree T . We take an arbitrary branch
b from T corresponding to a fundamental cut set I and an arbitrary link c 6= b in I. Then, b
belongs to the fundamental circuit of T defined by c (Theorem 2.8). By removing the branch
b from T and adding the edge c to T , we get the neighboring tree T ′ of T . Because of local
minimality, γ(T ) ≤ γ(T ′ ), i.e. α(c) ≥ α(b).
The spanning tree T is minimal if it has the lowest possible weight.
Theorem 5.2. The following three conditions are equivalent for the spanning tree T :
(i) T is cut minimal.
(ii) T is circuit minimal.
(iii) T is minimal.
Proof. By the lemma above, (i) and (ii) are equivalent. A minimal spanning tree is obviously
locally minimal. Thus, it suffices to prove that a cut minimal spanning tree is also minimal.
We will prove by contradiction and consider the counter hypothesis: There is a cut minimal
spanning tree T which is not minimal. Let us consider the minimal spanning tree T ′ and choose
T and T ′ so that the distance d(T, T ′ ) is as small as possible. By the lemma, d(T, T ′) > 1.
T has a branch e which is not in T ′ , i.e. it is a link of (T ′ )∗ . We label the fundamental
cut set of T defined by e as I and the fundamental circuit of T ′ defined by e as C. In the
intersection I ∩ C, there are also other edges besides e (Theorem 2.6). We choose such an edge
e′ . Then, e′ is a link of T ∗ and a branch of T ′ . Since T is cut minimal, α(e′ ) ≥ α(e). Since
T ′ is (circuit) minimal, α(e′ ) ≤ α(e). Therefore, α(e′ ) = α(e). By removing e′ from T ′ and
adding e to T ′ , we get a minimal spanning tree T ′′ which has the same weight as T ′ . However,
√
d(T, T ′′ ) < d(T, T ′ ).
In Kruskal’s Algorithm, the edges of the graph G (and their weights) are listed as e1 , . . . , em .
The algorithm constructs a circuit minimal spanning tree by going through the list to take some
edges to form the tree. This is especially effective if the edges are sorted in ascending order by
weight.
In the dual form of Kruskal’s Algorithm, we construct a cut minimal spanning tree by going
through the list of edges to take some edges to form the cospanning tree. Once again, this is
especially effective if the edges are sorted in descending order by weight.
In all, we get four different versions of Kruskal’s Algorithm. (We have to remember that the
subgraph induced by the edge set A is written as hAi.)
Kruskal’s Algorithm No. 1
Here we assume that the edges are given in ascending order by weight.
1. Set k ← 1 and A ← ∅.
2. If ek does not form a circuit with the edges in A, then set A ← A ∪ {ek } as well as
k ← k + 1 and go to step #4.
3. If ek forms a circuit with the edges in A, then set k ← k + 1 and go to step #4.
CHAPTER 5. GRAPH ALGORITHMS
68
4. If (V, A) is not a tree, then go to step #2. Otherwise stop and output the spanning tree
T = hAi.
Whenever we leave out an edge from A (step #3), its end vertices are already connected in A.
Thus, the vertices of G are connected in T as they are in G. Since T is obviously circuitless
(step #3), it is also a spanning tree of G. At each stage, the branches of the fundamental circuit
defined by the link belonging to T ∗ (step #3) are predecessors of that link in the list. Hence, T
is circuit minimal and thus minimal.
Remark. In every step, the branches and links are permanent. We do not have to know the
edges beforehand as long as we process them one by one in ascending order. The rank of the
graph (number of branches in a spanning tree) is then required beforehand so we know when to
stop.
Kruskal’s Algorithm No. 2
Here we assume the edges are given in an arbitrary order.
1. Set k ← 1 and A ← ∅.
2. If hA ∪ {ek }i contains no circuits, then set A ← A ∪ {ek } as well as k ← k + 1 and go
to step #4.
3. If hA ∪ {ek }i contains a circuit C, then choose the edge with the largest weight e in C (if
there are more than one, take any), set A ← (A ∪ {ek }) − {e} as well as k ← k + 1 and
go to step #4.
4. If k ≤ m, then go to step #2. Otherwise, stop and output the spanning tree T = hAi.
Whenever we leave out an edge from A (step #3), its end vertices are already connected in A.
Thus, the vertices of G are connected in T as they are in G. Since T is obviously circuitless
(step #3), it is a spanning tree of G.
We see that T is circuit minimal (and minimal) by the following logic. During the whole
process, hAi is a forest by step #4. In addition, if u and w are connected in hAi at some point,
then they are also connected afterwards. The u–w path in hAi is unique but it can change to
another path later in step #3. Nevertheless, whenever this change occurs, the maximum value
of the weights of the edges of the path can not increase anymore. Every link c of T ∗ has been
removed from A in step #3. Then, the weight of c is at least as large as the weights of the other
edges in C, After we have gone through step #3, the only connected end vertices of c in hAi
have to go through the remaining edges of C. The final connection between the end vertices of
c in T goes through the edges of the fundamental circuit defined by c. Therefore, the weights
of the edges of this fundamental circuit are ≤ α(c).
Remark. In each step, the links (e in step #3) are permanent and the branches are not. We do
not have to know the edges beforehand as long as we process them one by one. However, we
need to know the nullity of the graph (number of links in a cospanning tree) so that we know
when to stop. The algorithm can also be used to update a minimal spanning tree if we add edges
to the graph or decrease their weight.
CHAPTER 5. GRAPH ALGORITHMS
69
Kruskal’s Algorithm No. 3
Here we assume the edges are given in descending order by weight.
1. Set A ← E and k ← 1.
2. If (V, A − {ek }) is connected, then set A ← A − {ek } as well as k ← k + 1 and go to
step #4.
3. If (V, A − {ek }) is disconnected, then set k ← k + 1 and go to step #4.
4. If (V, A) is not a tree, then we go to step #2. Otherwise we stop and output the spanning
tree T = (V, A).
T is obviously connected because (V, A) is connected everytime we go to step #4. On the other
hand, T is circuitless because if the circuit C is in T and the edge c is in the circuit, then c is
√
removed from A in step #2 when ek = c ( ). Thus, T is a spanning tree of G. In each step, the
links of the fundamental cut set defined by the branch belonging to T (step #3) are predecessors
of that branch in the list. Hence, T is cut minimal and it is thus minimal.
Remark. In each step, the branches and links are permanent. We have to know the edges
beforehand. On the other hand, we do not have to know their weights as long as we get them
one by one in descending order.
Kruskal’s Algorithm No. 4
Here we assume the edges are given in an arbitrary order.
1. Set A ← E and k ← 1.
2. If (V, A − {ek }) is connected, then set A ← A − {ek } as well as k ← k + 1 and go to
step #4.
3. If (V, A − {ek }) is disconnected, then it has two components. The corresponding vertex
sets form a cut hV1 , V2 i. We interpret it as an edge set and choose the edge e with the
lowest weight in hV1 , V2 i (if there are more than one, take any). Set A ← (A−{ek })∪{e}
as well as k ← k + 1 and go to step #4.
4. If k ≤ m, then go to step #2. Otherwise stop and output the spanning tree T = (V, A).
T is obviously connected because (V, A) is connected everytime we go to step #4. (Take note
that the connectivity is preserved everytime we go through step #3.) On the other hand, T is
circuitless. If a circuit C of G ends up in T and c is the edge of C, which is first in the list,
then c must be removed from A in step #2 when ek = c. (Note that the edge removed from the
circuit first can not be removed in step #3.) If c comes back later (in step #3), then it forms a
cut set of (V, A) by itself in which case some other edge of C has been removed. By continuing
√
this process, we see that all the edges of C can not be in A in the end ( ). Therefore, T is a
spanning tree of G.
In addition, T is cut minimal and minimal because every branch b of T comes in in step
#3. The links of the fundamental cut set defined by b are either edges of the cut hV1 , V2 i which
is examined at that point or they are links of the cuts we examined later in step #3. Whenever
an edge of this kind gets removed later in step #3, it is always compensated by edges that are
heavier in weight than b. Those heavier edges are in the cut hV1 , V2 i which is examined at that
time. Therefore, the weights of the fundamental cut set defined by b are ≥ α(b).
CHAPTER 5. GRAPH ALGORITHMS
70
Remark. In each step, the branches (e in step #3) are permanent and the links are not. We
have to know the edges beforehand. We do not have to know the weights beforehand as long as
we process them one by one. This algorithm can also be used for updating a minimal spanning
tree if we remove edges from a graph or if we increase the weights of edges.
Prim’s Algorithm
In Prim’s Algorithm (also known as Jarnik’s Algorithm), we use the all-vertex incidence matrix of G. If we label the set of edges incident on vertex v as Ω(v), then we can get a list
Ω(v1 ), . . . , Ω(vn ), i.e. the cuts defined by the vertices (interpreted as edge sets). In addition, we
assign weights to the vertices.
The algorithm works in the same way as Dijkstra’s Algorithm by constructing the spanning
tree branch by branch. The variables are A (set of branches of the spanning tree we have at the
time), B (set of vertices of the spanning tree we have at the time) and I (the cut interpreted as
an edge set from which we choose the next branch).
Prim’s Algorithm (First Version):
1. Choose a starting vertex r and set A ← ∅, B ← {r} as well as I ← Ω(r).
2. Choose the lightest edge e from I (if there are more than one, choose any). Take the end
vertex v of e that is not in B. Set A ← A ∪ {e}, B ← B ∪ {v} as well as I ← I ⊕ Ω(v)
and go to step #3. (Remember that ⊕ denotes the symmetric difference operation between
two sets, see page 12.)
3. If B 6= V , then go to step #2. Otherwise, stop and output the spanning tree T = (B, A) =
hAi.
Since the edge e was chosen from a cut, T is circuitless. On the other hand, because there is
a path from r to every other vertex, T has every vertex of G and it is connected. T is thus a
spanning tree. It is also minimal because
Statement. During the whole process, (B, A) is a subtree of some minimal spanning tree of G.
Proof. We use induction on ℓ, the number of vertices in B.
Induction Basis: ℓ = 1. The case is obvious because (B, A) is trivial.
Induction Hypothesis: The statement is true for ℓ = k − 1. (k ≥ 2)
Induction Statement: The statement is true for ℓ = k.
Induction Statement Proof: In step #2, we can write A = A′ ∪ {e}, where e ∈ I ′ and
B = B ′ ∪ {v}. (B ′ , A′ ) is a subtree of some minimal spanning tree Tmin from the induction
hypothesis. If e belongs to Tmin , then the case is clear. Otherwise, there is a fundamental circuit
C in Tmin + e and there is another edge e′ of I ′ in C (Theorem 2.6). Then, α(e′ ) ≥ α(e) and
(Tmin + e) − e′ is also a minimal spanning tree and (B, A) is its subtree (because Tmin is circuit
minimal and α(e′ ) ≤ α(e)).
Often, we use one or two additional labels for the vertices to make Prim’s Algorithm easier.
In the next version of the algorithm, we will use two labels π(v) and β(v), which are used to
perform step #2 more effectively. The values of π are weights (up to ∞) and the values of β are
edges (or = 0). Otherwise, the algorithms works in the same way as before.
CHAPTER 5. GRAPH ALGORITHMS
71
Prim’s Algorithm (Second Version):
1. Choose a starting vertex r and set π(r) ← 0. For every other vertex v, set π(v) ← ∞.
For every vertex v, set β(v) ← 0 as well as A ← ∅ and B ← ∅.
2. Choose a vertex u ∈
/ B for which
π(u) = min{π(v)}.
v∈B
/
Set B ← B ∪ {u}. If β(u) 6= 0, then set A ← A ∪ {β(u)}.
3. Go through all the edges e = (u, v) where v ∈
/ B. If α(e) < π(v), then set π(v) ← α(e)
and β(v) ← e.
4. If B 6= V , then go to step #2. Otherwise, stop and output the spanning tree T = (B, A) =
hAi.
5.7 The Lightest Hamiltonian Circuit (Travelling Salesman’s
Problem): The Annealing Algorithm and the Karp–Held
Heuristics
Problem. If it is possible, we are to find the Hamiltonian circuit with the lowest weight. A
Hamiltonian circuit visits all the vertices of a graph. As usual, the weights of the edges have
been assigned and the weight of a (directed) circuit is the sum of the weights of the edges
traversed.
Obviously, we can assume that the graph is nontrivial, connected (otherwise it would not be
possible to get a Hamiltonian circuit) and simple. If not, then we simply remove all the loops
and choose the edge with the lowest weight out of the parallel edges. As usual, we denote n as
the number of vertices, m as the number of edges, V = {v1 , . . . , vn } and E = {e1 , . . . , em }.
We label the weight of an edge e = (vi , vj ) as α(e) = α(vi , vj ) and the weight of a Hamiltonian
circuit H as γ(H). We agree that the ”first” vertex of a Hamiltonian circuit is v1 .
The same problem exists for directed graphs in which case we are looking for the directed
Hamiltonian circuit with the lowest weight (known as the Unsymmetric Travelling Salesman’s
Problem).
The Travelling Salesman’s Problem (TSP)1 is an N P-complete problem, read e.g. M EHL HORN for more information. Actually, even deciding the existence of a Hamiltonian circuit is
an N P-complete problem. Solving a small TSP takes a lot of time and larger problems take so
much time that it is almost impossible to obtain accurate solutions. Therefore, many stochastic
and approximation methods are used in practice. Then, we have to accept the possibility of
inaccurate outcomes or even the lack of results.
1
The name ”Travelling Salesman’s Problem” comes from an interpretation where the vertices of a graph are
cities and the weights of the edges between the cities are travelling times. The salesman needs to visit every city
in the shortest amount of time.
CHAPTER 5. GRAPH ALGORITHMS
72
The Annealing Algorithm
The annealing algorithms or thermodynamic algorithms have the following common features:
(A) The system in question is always in some state s. The set of all states S is finite and
known. In the TSP, a state is a Hamiltonian circuit.
(B) Each state s has a response f (s), which can be calculated in a timely fashion from the
state. Our goal is to find a state whose response is near the minimum/maximum value.
The response of a state of a TSP is the weight of a Hamiltonian circuit.
(C) There is a procedure Ak which is used to move from state s to state Ak (s). k is a parameter
of the procedure which belongs to the set K. K can change during the procedure. The
purpose is to move to certain states ”near” the state s which are defined by the parameter
k. By repeating the procedure with proper values of k, we should be able to move from
any state to any other state. (In some cases, we can omit this last part.)
(D) Every time we move from one state to another, we should be able to choose the parameter k quickly and randomly from K. In particular, the set K itself should be easily
computable.
(E) We should be able to quickly perform the procedure Ak given a value of k.
(F) We should be able to find a starting state s0 . For the TSP, the starting state is a Hamiltonian
circuit.
The algorithm is as follows:
The Annealing Algorithm:
1. Choose the starting state s0 , the initial temperature T0 and set s ← s0 as well as T ← T0 .
2. When we are in the state s, we randomly choose a parameter k ∈ K and compute s′ =
Ak (s).
3. If f (s′ ) ≤ f (s), then set s ← s′ and go to step #5.
f (s)−f (s′ )
4. If f (s′ ) > f (s), then generate a random number r in the interval [0, 1). If′ r ≤ e T ,
f (s)−f (s )
then set s ← s′ . Thus, we accept a ”worse” state with probability e T . Note that the
greater the temperature T , the greater the probability that we go ”uphill”.
5. If we have gone through a maximum total number of iterations, then we stop and output
s. Otherwise, if we have gone through sufficiently many iterations of the procedure using
temperature T , then we lower T by some rule and go to step #2.
f (s)−f (s′ )
Remark. The distribution of the probability ps′ = e T
used in step #4 is (apart from
normalizing) a so-called maximum entropy distribution with the following condition on the
expected value:
X
ps′ f (s′ ) = µ
s′ =Ak (s)
k∈K
f (s′ )>f (s)
where µ depends on T and s. The distribution is also called a Boltzman distribution and it is
analogous to the distribution of the same name in Statistical Mechanics. Refer to courses in
Physics and Information Theory for more information.
CHAPTER 5. GRAPH ALGORITHMS
73
At first, we wait until the fluctuation in the states settles to a certain equilibrium (using the
response f (s)). After that, we lower the value of T a bit and wait again for the equilibrium.
Then, we lower T again and so on. We continue this until the change in values of f (s) is
sufficiently small or if we have ran out of time.
The operation Ak and the set K of the neighboring states depend on the problem. The state
structure and the response function also depend on the problem. For the TSP, we still need to
assign Ak and K for every situation. For this purpose, we take another parameter j and set
j ← 2. In step #2, we update j in the following way:
(
j + 1 if j < n
j←
2 otherwise.
(Another way of choosing j in step #2 would be to choose it randomly out of {2, . . . , n}.)
Furthermore, we choose
K = {2, . . . , n} − {j}.
Ak is defined by the following operation (known as the reversal):
• If k > j, then we reverse the order of the vertices vij , . . . , vik on the corresponding
subpath in the current Hamiltonian circuit
s : v1 , vi2 , . . . , vin , v1 .
• If k < j, then we reverse the order of the vertices vik , . . . , vij on the corresponding
subpath in the current Hamiltonian circuit
s : v1 , vi2 , . . . , vin , v1 .
We add the missing edges to the graph with very large weights so that we get a complete
graph and we will not have to worry about the existence of a Hamiltonian circuit in the first
place. If we still do not get a Hamiltonian circuit in the end without those added edges, then
there is not a Hamiltonian circuit.
The starting temperature T0 should be much larger than the values of |f (s′ ) − f (s)| which
guarantees that we can in principle move to any state (”annealing”) in the earlier stages of the
algorithm. After that, we lower the temperature applying some rule, for example a 10% change.
The annealing algorithm also works for the unsymmetric TSP with obvious changes.
Karp–Held Heuristics
In the Karp–Held Heuristics, we do not directly look for a Hamiltonian circuit but look for a
similar subgraph, known as a spanning 1-tree2 . The process does not work for the unsymmetric
TSP. The spanning 1-tree Sv corresponding to the vertex v (known as the reference vertex) is a
subgraph of G that satisfies the following conditions:
(a) Sv is connected and contains every vertex of G.
(b) Sv contains exactly one circuit C and the vertex v belongs to C.
(c) Sv has exactly two edges incident on v.
2
Not to be confused with the 1-tree on p. 23!
CHAPTER 5. GRAPH ALGORITHMS
74
Clearly, a Hamiltonian circuit is a spanning 1-tree corresponding to any of the vertices. The
weight of the spanning 1-tree Sv is the sum of of the weights of all its edges, denoted γ(Sv ). Sv
is minimal if it has the lowest possible weight.
Statement. Sv is minimal if and only if
(i) Sv − v is a minimal spanning tree of G − v, and
(ii) the two edges of Sv incident on v are the two lightest edges of G out of all the edges
incident on v.
Proof. Let Sv be a minimal spanning 1-tree. Let e and e′ be the two edges in Sv incident on
v. Then, Sv − v is a spanning tree of G − v because removing v destroys the circuit but the
connections remain unsevered. If Sv − v is not a minimal spanning tree of G − v then there is
a lighter spanning tree T of G − v. By adding the vertex v and the edges e and e′ to T , we get a
√
spanning 1-tree corresponding to vertex v which is lighter than Sv ( ). Therefore, (i) is true.
Obviously, (ii) is true (because otherwise we would get a lighter spanning 1-tree by replacing e
and e′ with the two lightest edges in G incident on v).
Let us assume that (i) and (ii) are true. If Sv is not minimal, then there is a lighter minimal
spanning 1-tree Sv′ corresponding to v. Because Sv′ also satisfies (ii), the two edges incident on
v are the same (or at least they have the same weight) in Sv and Sv′ . Thus, Sv′ − v is lighter than
√
Sv − v ( ).
It follows from the statement that any algorithm that finds the minimum spanning tree also
works for finding the minimum spanning 1-tree with minor modifications. Especially, Kruskal’s
and Prim’s Algorithms are applicable.
In the Karp–Held Heuristics, we also use weights of vertices, denoted β(v). With these, we
can define the virtual weight of an edge as
α′ (vi , vj ) = α(vi , vj ) + β(vi ) + β(vj ).
With the concept of virtual weights, we get the virtual weight of a spanning 1-tree Sv (we label
the edge set of Sv as A):
X
X
X
γ ′ (Sv ) =
α′ (vi , vj ) =
α(vi , vj ) +
(β(vi ) + β(vj ))
(vi ,vj )∈A
(vi ,vj )∈A
= γ(Sv ) +
X
(vi ,vj )∈A
(β(vi ) + β(vj )).
(vi ,vj )∈A
Now we denote the degree of the vertex u in Sv as dSv (u). Then,
X
(β(vi ) + β(vj )) =
γ ′ (Sv ) = γ(Sv ) +
β(vi )dSv (vi )
i=1
(vi ,vj )∈A
and
n
X
n
X
β(vi )dSv (vi ).
i=1
In particular, if we have a Hamiltonian circuit H (a special spanning 1-tree), then
dH (v1 ) = · · · = dH (vn ) = 2
CHAPTER 5. GRAPH ALGORITHMS
75
and
′
γ (H) = γ(H) + 2
n
X
β(vi ) .
i=1
|
{z
}
Does not depend on H!
Minimization of the Hamiltonian circuits using virtual weights yields the same minimal circuit
than obtained by using real weights. In general though, if we use virtual weights to search for
spanning 1-trees, then we get results different from the spanning 1-trees obtained by using real
weights.
From now on, we only consider the spanning 1-tree corresponding to vertex v1 and we leave
out the subscript. This is not a limitation of any kind on the Hamiltonian circuits although it
might be a good idea to change the reference vertex every now and then. We assume that Hmin
is a minimal Hamiltonian circuit and S ′ is the minimal spanning 1-tree obtained from using
virtual weights (which of course corresponds to v1 ). Then,
γ ′ (Hmin ) ≥ γ ′ (S ′ ).
In addition,
′
γ (Hmin ) = γ(Hmin ) + 2
n
X
β(vi )
i=1
and
′
′
′
γ (S ) = γ(S ) +
n
X
β(vi )dS ′ (vi ).
i=1
Thus,
γ(Hmin ) = γ ′ (Hmin ) − 2
n
X
β(vi ) ≥ γ ′ (S ′ ) − 2
i=1
= γ(S ′ ) +
n
X
n
X
β(vi )
i=1
β(vi )(dS ′ (vi ) − 2),
i=1
from which we get a lower limit on γ(Hmin).
The idea of the Karp–Held Heuristics is to guide the degrees of the vertices in S ′ to the value
2 by changing the weights of the vertices. If we succeed, then we get a minimal Hamiltonian
circuit. In all cases, we get a lower limit on the weights γ(H) of the (possible) Hamiltonian
circuits by using the calculation above. (Note that dS ′ (v1 ) is always = 2 if S ′ is the spanning
1-tree corresponding to v1 .)
The Karp–Held Heuristics:
1. Set β(v) ← 0 for every vertex v.
2. Set α′ (u, v) ← α(u, v) + β(u) + β(v) for each edge (u, v).
3. Find the minimal spanning 1-tree S ′ using virtual weights α′ (u, v). If we fail to find this
kind of spanning 1-tree, then there is no Hamiltonian circuit and we can stop.
4. If S ′ is a circuit, then output the minimal Hamiltonian circuit H = S ′ and stop.
5. If S ′ is not a circuit and the lower limit calculated from S ′ increased during the last K
iterations, then set β(v) ← β(v) + dS ′ (v) − 2 for every vertex v and go to step #2. (K is
a fixed upper bound on the number of iterations.)
CHAPTER 5. GRAPH ALGORITHMS
76
6. If the lower limit calculated from S ′ has not increased during the last K iterations, then
output that lower limit and stop.
This procedure does not always produce a minimal Hamiltonian circuit even if there exists
one. In practice, it often produces either a minimal Hamiltonian circuit or a good lower limit on
the weight of it. Getting a number for the lower limit does not, however, guarantee the existence
of a Hamiltonian circuit in the graph!
Karp–Held Heuristics has many steps where we have to choose between different options
(such as the reference vertex and the spanning 1-tree). We can not go through every possibility
so we must choose randomly. Then, we have a Las Vegas algorithm or stochastic algorithm.
5.8 Maximum Matching in Bipartite Graphs: The Hungarian Algorithm
A matching in the graph G = (V, E) is a set of edges S ⊆ E none of which are adjacent to each
other. A matching is a maximum matching if it has the greatest possible number of edges. The
end vertex of an edge in a matching is matched.
Problem. We want to find the maximum matching in a bipartite graph.
An alternating path of a matching S is a path that satisfies the following conditions:
(1) The first vertex on the path is not matched, and
(2) every second edge is in the matching and the remaining edges are not in the matching.
Note that the first edge in an alternating path is not in the matching. In addition, if the last vertex
of an alternating path is not matched, then this path is an augmenting path of S. A matching
without augmenting paths is called a maximal matching.
Example. For the bipartite graph
v1
v2
G:
v3
v4
v5
w1
w2
w3
w4
w5
v1
v2
v3
v4
S:
v5
w6
w1
w2
w3
w4
w5
w6
one augmenting path of the matching S = {(v1 , w3 ), (v3 , w2 ), (v4 , w6), (v5 , w5)} is the path
where the vertices are v2 , w2 , v3 , w6 , v4 , w1 .
v1
v2
v3
v4
v5
w1
w2
w3
w4
w5
w6
CHAPTER 5. GRAPH ALGORITHMS
77
We can augment a matching S using its augmenting path p as follows:
1. We remove the edges of S in p, and
2. We add the edges in p which are not in S.
The new edge set is obviously a matching. Note that the number of edges in S on an augmenting
path is one fewer than the number of the remaining edges. Therefore, the number of edges in
a matching increases by one after the augmenting operation. It is not possible to augment a
maximal matching.
Example. (Continuing from the previous example) By using the given augmenting path from
the matching S, we get a new maximal matching S1 = {(v1 , w3), (v2 , w2), (v3 , w6), (v4 , w1),
(v5 , w5)}.
w1
w2
v1
v2
w3
v3
v4
w4
w5
v5
w6
In the Hungarian Algorithm, we systematically search for augmenting paths until we get
a maximal matching. After that, it suffices to prove that a maximal matching is a maximum
matching. From now on, we only consider bipartite graphs because the algorithm is then much
simpler. We search for augmenting paths by constructing an alternating tree of a matching S
which is a subtree of G such that
(1) a vertex r (the root of the tree) is unmatched,
(2) every second edge on each path out from r is in S and the remaining edges are not in S,
and
(3) either there is an augmenting path out from r or we can not add any more edges to S.
An alternating tree is an augmenting tree if it has an augmenting path. Otherwise, it is a Hungarian tree. Every augmenting path is obviously an augmenting tree by itself. Note that the
only unmatched vertex of a Hungarian tree is the root.
Example. (Continuing from the previous example) Two alternating trees of the matching S are
(the root is circled):
v2
v3
v4
w1
w2
w4
w6
v2
v3
v4
w2
w4
w6
CHAPTER 5. GRAPH ALGORITHMS
78
Both of them are augmenting trees. An alternating tree of the matching S1 (the root is w4 ) is the
Hungarian tree
v1
w1
w3
v4
w4
Augmenting and Hungarian trees are not unique. We can have many different trees depending on the order we take the edges for constructing the trees even though the roots are the same.
On the other hand,
Statement. If a matching in a bipartite graph G has a Hungarian tree, then it does not have an
augmenting tree with the same root.
Proof. Let us prove by contradiction and consider the counter hypothesis: A matching S has a
Hungarian tree U and an augmenting tree T with the same root r. We get an augmenting path
in the augmenting tree
p : r = v0 , e1 , v1 , e2 , . . . , ek , vk .
We choose the last vertex vi which is in U from the path p (at least r = v0 is in U). Since
vk is not in U, i < k. Furthermore, the edge ei+1 is not in the matching nor in U (otherwise
vi+1 would also be in U). On the other hand, since ei+1 is not in U, vi+1 has to be an end
√
vertex of another edge in U ( ) because the only reason why the edge ei+1 is not put into U
while constructing U is that the other end vertex vi+1 of ei+1 is already in U. Note how the
bipartiteness of the G comes in: If the cut in G that results in the bipartition is hV1 , V2 i, then the
vertices of U and p alternate between V1 and V2 . Therefore, the length of the r–vi path is even
in p and U.
Constructing an alternating tree from a root always leads to a Hungarian tree or an augmenting
tree but not both. The order of the edges taken does not matter. (This is not the case for general
graphs.)
For the bipartite graph G = (V, E), the Hungarian Algorithm is as follows. The cut that
yields the bipartition is hV1 , V2 i.
The Hungarian Algorithm:
1. Set S ← ∅. (We can also use some other initial matching.)
2. If every vertex in V1 or in V2 is matched in S, then S is a maximum matching and we
stop.
3. If there are unmatched vertices in S of V1 , then go through them in some order constructing alternating trees (the method of construction is not important as we claimed). If there
is an augmenting tree, then augmenting the matching S by using the augmenting path we
have another matching S1 . Set S ← S1 and go to #2.
4. If all the alternating trees that have unmatched vertices in V1 as roots are Hungarian, S is
maximal and we stop.
CHAPTER 5. GRAPH ALGORITHMS
79
Theorem 5.3. A maximal matching in a bipartite graph is a maximum matching.
Proof. Let us prove by contradiction and consider the counter hypothesis: A maximal matching
S in the bipartite graph G = (V, E) is not a maximum matching. Then, there are more edges in
the maximum matching Smax than in S and in V1 there are more vertices matched in Smax than
in S. We choose an arbitrary vertex v ∈ V1 , which is matched in Smax but not in S. Then, we
have a path
p : v = v0 , e1 , v1 , e2 , . . . , ek , vk = w,
whose edges are alternating between Smax and S, i.e. e1 is in Smax and e2 is in S and so on.
We choose the longest such path p. Because p is obviously an alternating path of S, it has
even length, i.e. ek is an edge of S. (Otherwise, p would be an augmenting path of S which is
impossible because S is maximal.) Thus, w is matched in S but not matched in Smax (because
the path p can not be continued).
Hence, every vertex v ∈ V1 which is matched in Smax but not in S corresponds to a vertex
w ∈ V1 , which is matched in S but not in Smax . Now, every path that ends at w must start
from the vertex v if the starting vertex is matched in Smax but not in S. The last edge of such a
path has to be ek (the only edge in S incident on w) and the second to the last vertex has to be
vk−1 . Furthermore, the second to the last edge of this path has to be ek−1 (the only edge of Smax
incident on vk−1 ) and the third to the last vertex has to be vk−2 , and so on.
However, there are then in V1 at least as many vertices w that are matched in S but not in
√
Smax as there are vertices v that are matched in Smax but not in S ( ).
Corollary. The Hungarian algorithm produces a maximum matching in a bipartite graph.
A matching is perfect if it matches every vertex of a graph. Thus, a graph with an odd
number of vertices can not have a perfect matching. Let usSconsider the graph G = (V, E) and
denote ν(v) = {adjacent vertices of v} as well as ν(A) = v∈A ν(v) for the vertex set A ⊆ V .
Let us denote by #(X) the number of elements in the set X (the cardinality of the set). With
these notions, we can present the following famous characterization:
Theorem 5.4. (Hall’s Theorem or ”Marriage Theorem”) A bipartite graph G whose bipartition cut is hV1 , V2 i has a perfect matching if and only if every vertex set A ⊆ V1 and B ⊆ V2
satisfies the conditions #(A) ≤ #(ν(A)) and #(B) ≤ #(ν(B)).
Proof. If a perfect matching exists, then obviously #(A) ≤ #(ν(A)) and #(B) ≤ #(ν(B))
hold for all sets of vertices A ⊆ V1 and B ⊆ V2 . (Otherwise, we can not find a pair for every
vertex in A or B in the matching.)
Let us assume that for all sets of vertices A ⊆ V1 and B ⊆ V2 , #(A) ≤ #(ν(A)) and
#(B) ≤ #(ν(B)). Let S be a maximum matching in G. We will prove by contradiction
and consider the counter hypothesis: S is not perfect. We choose a vertex v which is not
matched in S. Let us examine the case where v ∈ V1 (the other case where v ∈ V2 is obviously
symmetrical). The contradiction is apparent if v is an isolated vertex so we can move to the case
where v is an end vertex of an edge. The alternating tree with the root v is then nontrivial and
since the matching is also maximal, this tree is Hungarian. We choose such a Hungarian tree U.
We label the set of vertices of V1 (resp. V2 ) in U by A (resp. by B). Because of the construction
of U, B = ν(A). On the other hand, the vertices of A and B in U are pairwise matched by the
√
edges of S, except for the root r. Hence, #(A) = #(B) + 1 > #(B) ( ).
CHAPTER 5. GRAPH ALGORITHMS
80
5.9 Maximum Flow in a Transport Network: The Ford–Fulkerson Algorithm
A transport network is a directed graph G = (V, E) with weighted arcs that satisfies the following:
(1) G is connected and loopless,
(2) G has only one source s,
(3) G has only one sink t, and
(4) the weight c(e) of the arc e is called the capacity and it is a nonnegative real number, i.e.
we have a mapping c : E → R0 .
(Compare to stationary linear networks in Section 4.4.) Actually, we could assume that G has
every possible arc except loops and it can even have multiple parallel arcs. If this is not the case,
then we simply add the missing arcs with capacity zero. Naturally, we can also assume that G
is nontrivial.
A flow f of a transport network is a weight mapping E → R0 , which satisfies:
(i) For each arc e, we have the capacity constraint f (e) ≤ c(e), and
(ii) each vertex v 6= s, t satisfies the conservation condition (also called Kirchhoff’s Flow
Law, compare to Section 4.4)
X
X
f (e).
f (e) =
initial vertex
of e is v
terminal vertex
of e is v
f (e) is called the flow of e. The flow of the arc (u, v) is also denoted as f (u, v). The value of
the flow f is
X
f (e).
|f | =
initial vertex
of e is s
A flow f ∗ is a maximum flow if its value is the largest possible, i.e. |f ∗| ≥ |f | for every other
flow f .
An s–t cut of a transport network S is a (directed) cut I = hV1 , V2 i such that s is in V1 and
t is in V2 . The capacity of such a cut is
X
c(u, v).
c(I) =
u∈V1
v∈V2
(Note that the arcs in the direction opposite to the cut do not affect the capacity.) The capacity of
the cut hV1 , V2 i is also denoted as c(V1 , V2 ). Furthermore, we define the flux of the cut I = hV1 ,
V2 i as
X
f (u, v)
f + (I) =
u∈V1
v∈V2
and the counter-flux as
f − (I) =
X
f (u, v).
u∈V2
v∈V1
The value of a flow can now be obtained from the fluxes of any s–t cut:
CHAPTER 5. GRAPH ALGORITHMS
81
Theorem 5.5. If f is a flow of a transport network and I is an s–t cut, then
|f | = f + (I) − f − (I).
Proof. Obviously,
X
f (e) −
initial vertex
of e is v
X
f (e) =
terminal vertex
of e is v
(
|f | if v = s
0 if v 6= s, t.
We denote I = hV1 , V2 i. By going through the vertices v in V1 and by adding up the equations
we get
X X
X
X
f (e) −
f (e) = |f |.
v∈V1 initial vertex
of e is v
v∈V1 terminal vertex
of e is v
For each arc e whose end vertices are both in V1 , f (e) and −f (e) are added exactly once and
thus they cancel out. Therefore,
X
X
f (u, v) = |f |.
f (u, v) −
u∈V1
v∈V2
u∈V2
v∈V1
Corollary. If f is a flow of a transport network and I is an s–t cut, then |f | ≤ c(I).
Proof. |f | = f + (I) − f − (I) ≤ f + (I) ≤ c(I).
An arc e of a transport network is saturated if f (e) = c(e). Otherwise, it is unsaturated.
Now, we point out that |f | = c(V1 , V2 ) if and only if
(i) the arc (u, v) is saturated whenever u ∈ V1 and v ∈ V2 , and
(ii) f (u, v) = 0 whenever u ∈ V2 and v ∈ V1 .
An s–t cut I ∗ of a transport network is called a minimum cut if c(I ∗ ) ≤ c(I) for every other
s–t cut I.
Corollary. If f is a flow of a transport network, I is an s–t cut and |f | = c(I), then f is a
maximum flow and I is a minimum cut.
Proof. If f ∗ is a maximum flow and I ∗ is a minimum cut, then |f ∗ | ≤ c(I ∗ ) by the corollary
above. Thus,
|f | ≤ |f ∗ | ≤ c(I ∗ ) ≤ c(I)
and f is indeed a maximum flow and I is indeed a minimum cut.
Actually, the value of the maximum flow is the capacity of the minimum cut. The show this, we
examine a path from vertex s to vertex v (not necessarily a directed path):
s = v0 , e1 , v1 , e2 , . . . , ek , vk = v
(path p).
If ei = (vi−1 , vi ), then the arc ei is a forward arc. If ei = (vi , vi−1 ), then the arc ei is a back arc.
The arc ei of p is now weighted by the following formula:
(
c(ei ) − f (ei ) if ei is a forward arc
ǫ(ei ) =
f (ei ) if ei is a back arc
CHAPTER 5. GRAPH ALGORITHMS
82
and the path p is weighted by the following formula:
k
ǫ(p) = min{ǫ(ei )}.
i=1
The path p is unsaturated if ǫ(p) > 0, i.e. all of the forward arcs of p are unsaturated and
f (ei ) > 0 for all the back arcs ei of p.
In particular, an s–t path can be unsaturated in which case it is called an augmenting path3 .
All of these definitions are of course attached to a certain flow f . By starting from an s–t path
p (and a flow f ), we can define a new flow:


f (e) + ǫ(p) if e is a forward arc of p
f = f (e) − ǫ(p) if e is a back arc of p


f (e) otherwise.
f is really a flow. Changes in f can only occur at the arcs and vertices of p. Every arc of
p satisfies the capacity constraint because of how ǫ(p) and f (e) are defined. A vertex vi of p
satisfies the conservation condition which we can verify. We have four cases:
ei
ei
vi
vi
ei
ei+1
ei
ei+1
vi
ei+1
vi
ei+1
Obviously (think about the source s)
|f | = |f | + ǫ(p),
so f is not a maximum flow if it has an augmenting path. Moreover, the converse is true as well.
Hence,
Theorem 5.6. A flow is a maximum flow if and only if it does not have any augmenting path.
Proof. As we claimed, a maximum flow can not have an augmenting path. Let us assume that
a flow f does not have an augmenting path. We denote the set of vertices which we can reach
from the source s along unsaturated paths by V1 . Then, trivially, s ∈ V1 and t ∈
/ V1 (because
there are no augmenting paths). Thus, the cut I = hV1 , V2 i is an s–t cut. We proceed to prove
that |f | = c(I). By the previous corollary, f is then a maximum flow.
Let us consider the arc (u, v), where u ∈ V1 and v ∈ V2 . Then, there exists an unsaturated
s–u path p. The edge (u, v) is saturated because there would be an unsaturated s–v path otherwise. Similarly, we conclude that f (u, v) = 0 for every arc (u, v), where u ∈ V2 and
v ∈ V1 . Therefore, the flux f + (I) is c(I) and the counter-flux f − (I) is zero. By Theorem
5.5, |f | = c(I).
3
Not to be confused with the augmenting path in the previous section!
CHAPTER 5. GRAPH ALGORITHMS
83
We have also proven the celebrated
Theorem 5.7. (Max-Flow Min-Cut Theorem) The value of a maximum flow in a transport
network is the same as the capacity of a minimum cut.
If the capacities of the arcs are rational numbers, then a maximum flow can be found by
using Theorem 5.6. The algorithm tries to find an augmenting path for f . If it can not be found,
then we have a maximum flow. If we find an augmenting path, then we use it to create a greater
flow f . In the algorithm, we use a label α for the vertices in the following way:
α(v) = (u, direction, ∆),
where u is a vertex in the transport network (or − if it is not defined), ”direction” is either
forward (→) or back (←) (or − if it is not defined) and ∆ is a nonnegative real number (or
∞). The point is, whenever a vertex v is labeled, there is an s–v path p which contains the
(”directed”) arc (u, v) and ∆ = ǫ(p). A direction is forward if an arc is in the direction of the
path and back otherwise. We can label a vertex v when the vertex u has been labeled and either
(u, v) or (v, u) is an arc. We have two cases:
(1) (Forward Label) If e = (u, v) is an arc and α(u) = (·, ·, ∆u ) as well as c(e) > f (e), then
we can write α(v) = (u, →, ∆v ), where
∆v = min{∆u , c(e) − f (e)}.
(2) (Back Label) If e = (v, u) is an arc and α(u) = (·, ·, ∆u ) as well as f (e) > 0, then we
can write α(v) = (u, ←, ∆v ), where
∆v = min{∆u , f (e)}.
There are two phases in the algorithm. In the first phase, we label the vertices as presented
above and each vertex is labeled at most once. The phase ends when the sink t gets labeled as
α(t) = (·, →, ∆t ), or when we can not label any more vertices. In the second case, there are no
augmenting paths and the flow we obtain is a maximum flow so we stop. In the first case, the
flow we obtain is not a maximum flow and we have an augmenting path p for which ǫ(p) = ∆t .
The algorithm moves on to the second phase. In the second phase, we construct a new greater
flow f by using the labels of the vertices of p obtained previously. After this, we go back to the
first phase with this greater new flow.
The Ford–Fulkerson Algorithm:
1. Choose an initial flow f0 . If we do not have a specific flow in mind, we may use f0 (e) = 0.
Label the source s by α(s) ← (−, −, ∞). Set f ← f0 .
2. If we have a unlabeled vertex v, which can be labeled either forward by (w, →, ∆v ) or
backward by (w, ←, ∆v ), then we choose one such vertex and label it. (There can be
many ways of doing this and all of them are permitted.) If such a vertex v does not exist,
output the maximum flow f and stop.
3. If t has not been labeled, go to step #2. Otherwise, set u ← t.
CHAPTER 5. GRAPH ALGORITHMS
84
4. If α(u) = (w, →, ∆u ), then set
f (w, u) ← f (w, u) + ∆t
and
u ← w.
If α(u) = (w, ←, ∆u ), then set
f (u, w) ← f (u, w) − ∆t
and u ← w.
5. If u = s, then remove all the labels α but not the label of the source and go to step #2. If
u 6= s, then go to step #4.
If f0 (e) and c(e) are rational numbers, then the algorithm stops and produces a maximum flow.4
In this case, we can assume that these weights and capacities are nonnegative integers. Thus,
the value of a flow increases by a positive integer every time we move from the second phase to
the first phase and the value reaches a maximum eventually. On the other hand, the number of
steps can be as large as the value of the maximum flow. The performance time of the algorithm
does not only depend on the number of vertices but also the capacities.
The algorithm can be modified5 so that it does not depend on the capacities. Thus, it will
work for irrational capacities. In this case, our purpose during the labeling phase is to find the
shortest augmenting path. We get this by always choosing the vertex v in step #2 in such a way
that in α(v) = (w, ·, ∆v ), w received its label as early as possible.
The Ford–Fulkerson Algorithm also works for finding a maximum matching in a bipartite
graph. Let us do an example:
Example. Using the bipartite graph G from an example in the previous section, we get a transport network G′ :
v1
v2
G:
v3
v4
v5
w1
w2
w3
w4
w5
w6
G′: s
t
Every edge of G′ is directed from left to right and given a capacity of 1. The initial flow is a
zero flow (or a greater flow we obtain from some other initial flow). During the whole process,
the flows of the edges are integers 0 or 1. We take into the matching those edges in G whose
corresponding edges e in G′ receive a flow f (e) = 1 and a maximum flow gives a maximum
matching. Note that an augmenting path can be of length larger than three in this case. (We
can also claim now that the augmenting paths here and the augmenting paths obtained from the
Hungarian Algorithm do have something in common after all!)
4
If there are irrational capacities or flows f0 (e), then the algorithm may not stop at all and it may not produce a
maximum flow even if the process repeats endlessly. Of course, we do not have to use irrational flows. In practice,
we will not use irrational capacities.
5
This is known as the Edmonds–Karp Modification (refer e.g. to S WAMY & T HULASIRAMAN).
Chapter 6
Drawing Graphs
6.1 Planarity and Planar Embedding
We have not treated graphs as geometric objects so far in the course. In practice, we draw
graphs, i.e. we treat vertices as geometric points and edges as continuous curves. If a graph
G can be drawn on a plane (or a sphere) so that the edges only intersect at vertices, then it is
planar. Such a drawing of a planar graph is a planar embedding of the graph.
A connected part of a plane which does not contain any vertices and is surrounded by edges
is called a region of a planar embedding. In addition, the part outside the embedding is considered as a region, known as the exterior region (when we draw a planar graph on a plane or on a
sphere, it is just like any other region). The vertices surrounding a region s are called boundary
vertices and the edges surrounding s are called boundary edges. Two regions are adjacent if
they share a boundary edge. Note that a region can be adjacent to itself.
Example. In the following planar embedding
v1
e1
s1
s2
v2
e6
e10
e2
e9
e8
v3
s5
s4 e3
v7
v5
e4 s3 e5
v6
e7
v4
v8
the regions are s1 , s2 , s3 , s4 and s5 (the exterior region) and their boundary vertices and edges
as well as their adjacent regions are given in the table below:
region boundary vertices
s1
v1 , v5 , v2
s2
v2 , v5 , v4 , v3 , v6 , v7
s3
v4 , v5
s4
v5
s5
v1 , v5 , v4 , v3 , v2 , v8
boundary edges
e1 , e10 , e2
e2 , e4 , e7 , e9 , e8 , e6
e4 , e5
e3
e10 , e3 , e5 , e7 , e6 , e1
85
adjacent regions
s2 , s5
s1 , s2 , s3 , s5
s2 , s5
s5
s1 , s2 , s3 , s4
CHAPTER 6. DRAWING GRAPHS
86
In the following, we investigate some fundamental properties of planar embeddings of
graphs.
Theorem 6.1. (Euler’s Polyhedron Formula1) If a planar embedding of a connected graph G
has n vertices, m edges and f regions, then
f + n = m + 2.
Proof. Let us use induction on m.
Induction Basis: m = 0. Planar embedding of G has only one vertex and one region (the
exterior region) so the claim is true.
Induction Hypothesis: The theorem is true for m ≤ ℓ. (ℓ ≥ 0)
Induction Statement: The theorem is true for m = ℓ + 1.
Induction Statement Proof: We choose an edge e of G and examine the graph G′ = G − e.
If e is in a circuit, then G′ is connected and by the Induction Hypothesis, we get
f ′ + n = (m − 1) + 2,
where f ′ is the number of regions in G′ . However, closing the circuit with e increases the
number of regions by one so f ′ = f − 1 and the theorem is true. If G − e is disconnected,
then it has two planar components, G1 and G2 whose number of vertices, edges and regions are
n1 , n2 , m1 , m2 , f1 and f2 , respectively. By the Induction Hypothesis,
f1 + n1 = m1 + 2 and
f2 + n2 = m2 + 2.
While adding e, the number of regions becomes f1 + f2 − 1 (G1 and G2 share the same exterior
region or one exterior region is drawn to be a region of the other component), the number of
vertices becomes n1 + n2 and the number of edges becomes m1 + m2 + 1. Hence, the claim is
true.
Example. (Continuing from the previous example) We remove the vertex v8 to get a connected
planar embedding. Now, we have 7 vertices, 10 edges, 5 regions and 5 + 7 = 10 + 2.
Theorem 6.2. (The Linear Bound) If a simple connected planar graph G has n ≥ 3 vertices
and m edges, then
m ≤ 3n − 6.
Proof. If the regions of a planar embedding of G are s1 , . . . , sf , then we denote the number of
boundary edges of si by ri (i = 1, . . . , f ). The case f = 1 is obvious because G is then a tree
and m = n − 1 ≤ 3n − 6. Thus, we assume that f ≥ 2. Since G is simple, every region has at
least 3 boundary edges and thus
f
X
ri ≥ 3f.
i=1
Every edge is a boundary edge of one or two regions in the planar embedding, so
f
X
ri ≤ 2m.
i=1
The result now follows directly from Euler’s Polyhedron Formula.
1
The name comes from a polyhedron with n vertices, m edges, f faces and no holes.
CHAPTER 6. DRAWING GRAPHS
87
Theorem 6.3. (The Minimum Degree Bound) For a simple planar graph G, δ(G) ≤ 5.
Proof. Let us prove by contradiction and consider the counter hypothesis: G is a simple planar
graph and δ(G) ≥ 6. Then, (by Theorem 1.1) m ≥ 3n, where n is the number of vertices and
√
m is the number of edges in G. ( Theorem 6.2)
A characterization of planar graphs is obtained by examining certain forbidden subgraphs.
Theorem 6.4. (Kuratowski’s Theorem) A graph is planar if and only if none of its subgraphs
can be transformed to K5 or K3,3 by contracting edges.
The proof is quite complicated (but elegant!), refer e.g. to S WAMY & T HULASIRAMAN for
more information. K5 and K3,3 are not planar, which can be verified easily.
There are many fast but complicated algorithms for testing planarity and drawing planar
embeddings. For example, the Hopcroft–Tarjan Algorithm2 is one. We present a slower classical polynomial time algorithm, the Demoucron–Malgrange–Pertuiset Algorithm3 (usually just
called Demoucron’s Algorithm). The idea of the algorithm is to try to draw a graph on a plane
piece by piece. If this fails, then the graph is not planar.
If G is a graph and R is a planar embedding of a planar subgraph S of G, then an R-piece
P of G is
• either an edge of G − S whose end vertices are in S, or
• a component of the subgraph induced by vertices not in S which contains the edges (if
any) that connect S to the component, known as pending edges, and their end vertices.
Those vertices of an R-piece of G that are end vertices of pending edges connecting them to
S are called contact vertices. We say that a planar embedding R of the planar subgraph S is
planar extendable to G if R can be extended to a planar embedding of the whole G by drawing
more vertices and/or edges. Such an extended embedding is called a planar extension of R to
G. We say further that an R-piece P of G is drawable in a region s of R if there is a planar
extension of R to G where P is inside s. Obviously all contact vertices of P must then be
boundary vertices of s, but this is of course not sufficient to guarantee planar extendability of R
to G. Therefore we say that a P is potentially drawable in s if its contact vertices are boundary
vertices of s. In particular, a piece with no contact vertices is potentially drawable in any region
of R.
Demoucron’s Algorithm:
1. We first check whether or not G is a forest. If it is a forest, then it clearly is planar and
can be planar embedded. (There are fast algorithms for this purpose.) We can then stop.
2. If G is not a forest then it must contain at least one circuit. We choose a circuit C, embed
it to get the planar embedding D, and set R ← D. (A circuit is obviously planar and is
easily planar embedded.)
3. If R is a planar embedding of G, then we output it and stop.
2
The original reference is H OPCROFT, J.E. & TARJAN , R.E.: Efficient Planarity Testing. Journal of the ACM
21 (1974), 549–568.
3
The original reference is D EMOUCRON , G. & M ALGRANGE , Y. & P ERTUISET, R.: Graphes planaires: reconnaissance et construction des représentations planaires topologiques. Revue Française Recherche Opérationnelle
8 (1964), 33–47.
CHAPTER 6. DRAWING GRAPHS
88
4. We construct the set P of all R-pieces of G. For each piece P ∈ P we denote by S(P )
the set of all those regions of R which P is potentially drawable in.
5. If, for an R-piece P ∈ P, the set S(P ) is empty then G is not planar. We can then output
this information and stop.
6. Choose an R-piece P , starting from those potentially drawable only in one region.
7. Depending on the number of contact vertices of P , we planar extend R:
7.1 If P has no contact vertices, we call Demoucron’s Algorithm recursively with input
P . If it turns out that P is not planar, then G is not planar, and we output this
information and stop. Otherwise we extend R to a planar embedding U by drawing
P in one of its regions, set R ← U, and return to step #3.
7.2 If P has exactly one contact vertex v, with the corresponding pendant edge e, we
call Demoucron’s Algorithm recursively with input P . If it turns out that P is not
planar, then G is not planar, and we output this information and stop. Otherwise we
extend R to a planar embedding U by drawing P in a region with boundary vertex v,
set R ← U, and return to step #3. (This region of R will then be an exterior region
of the planar embedding of P .)
7.3 If P has (at least) two contact vertices v1 and v2 , they are connected by a path p in
P . We then extend R to a planar embedding U by drawing p in a region of R with
boundary vertices v1 and v2 where P is potentially drawable, set R ← U, and return
to step #3.
Clearly, if G is not planar, Demoucron’s Algorithm will output this information. On the
other hand, the algorithm will not get stuck without drawing the planar embedding if the input
is planar, because
Statement. If G is planar, then at each step of the algorithm R is planar extendable to G.
Proof. We use induction on the number of times ℓ the algorithm visits step #7.
Induction Basis: ℓ = 0. Now either G is a forest (and R is not needed) or R is a circuit of
G. Obviously the planar embedding of this circuit can be planar extended to G.
Induction Hypothesis: The statement is true for ℓ ≤ r. (r ≥ 0)
Induction Statement: The statement is true for ℓ = r + 1.
Incuction Statement Proof: For step #7.1 the matter is clear. If, in step #7.2, P is potentially
drawable in the region s of R, it can always be drawn in this region without endangering subsequent steps. In other words, any possible region can be chosen. This is because the region can
be exchanged for another at all times by ”reflection” with respect to the vertex v (and possibly
rescaling):
s2
s3
v
e P
s1
s2
P
s3
v
e
s1
CHAPTER 6. DRAWING GRAPHS
89
Similarly, if in step #7.3, P is drawable in a region of R, then it can be drawn in this region
without endangering subsequent steps. If P is drawable in both region s1 and region s2 , its
contact vertices are boundary vertices of both s1 and s2 . At any time, a drawn P (or part of
it) can be moved from region s1 to s2 , or vice versa, simply by reflection with respect to the
common boundary (and possibly rescaling to fit into the region).
Remark. Nonplanar graphs may be embedded on closed continuous surfaces with holes. For
instance, a torus is closed surface with exactly one hole. On a torus we can embed the nonplanar graphs K5 , K6 and K7 , and also K3,3 . K8 is more complex and its embedding requires
a closed surface with two holes. The smallest number of holes in a closed surface required for
embedding the graph G on it is called the genus of G. On the other hand the smallest number of
crossings of edges in a drawing of G on plane is called the crossing number of G. Computation
of genus and crossing number are both N P-complete problems.
A coloring of a graph is a labeling of vertices where adjacent vertices never share a label.
The labels are then often called colors. We say that a graph is k-colorable if it can be colored
using (at most) k colors. If a graph is colorable then it obviously can not have loops. Equally
obviously, parallel edges can be reduced to one, so we may assume our graphs here to be simple.
The smallest number k for which the graph G is k-colorable, is called the chromatic number of
G, denoted by χ(G).
K4 is an example of a planar simple graph which is not 3-colorable. On the other hand there
is the celebrated
Theorem 6.5. (The Four-Color Theorem) Every simple planar graph is 4-colorable.
Proof. The only known proofs require extensive computer runs. The first such proof was obtained by Kenneth Appel ja Wolfgang Haken in 1976. It takes a whole book to present the
proof: A PPEL , K. & H AKEN , W.: Every Planar Map is Four Colorable. American Mathematical Society (1989).
If we require a bit less, i.e. 5-colorability, then there is much more easily provable result,
and an algorithm.
Theorem 6.6. (Heawood’s Theorem or The Five-Color Theorem) Every simple planar graph
is 5-colorable.
Proof. We may think of G as a planar embedding. We use induction on the number n of vertices
of G.
Induction Basis: n = 1. Our graph is now 1-colorable since there are no edges.
Induction Hypothesis: The theorem is true for n ≤ ℓ. (ℓ ≥ 1)
Induction Statement: The theorem is true for n = ℓ + 1.
Induction Statement Proof: According to the Minimum Degree Bound, there is a vertex v
in G of degree at most 5. On the other hand, according to the Induction Hypothesis the graph
G − v is 5-colorable. If, in this coloring, the vertices adjacent to v are colored using at most
four colors, then clearly we can 5-color G.
So we are left with the case where the vertices v1 , v2 , v3 , v4 , v5 adjacent to v are colored
using different colors. We may assume that the indexing of the vertices proceeds clockwise,
and we label the colors with the numbers 1, 2, 3, 4, 5 (in this order). We show that the coloring
of G − v can be changed so that (at most) four colors suffice for coloring v1 , v2 , v3 , v4 , v5 .
We denote by Hi,j the subgraph of G − v induced by the vertices colored with i and j. We
have two cases:
CHAPTER 6. DRAWING GRAPHS
90
• v1 and v3 are in different components H1 and H3 of H1,3 . We then interchange the colors 1
and 3 in the vertices of H3 leaving the other colors untouched. In the resulting 5-coloring
of G − v the vertices v1 and v3 both have the color 1. We can then give the color 3 to v.
• v1 and v3 are connected in H1,3 . Then there is a v1 –v3 path in H1,3 . Including the vertex
v we get from this path a circuit C. Now, since we indexed the vertices v1 , v2 , v3 , v4 , v5
clockwise, exactly one of the vertices v2 and v4 is inside C. We deduce that v2 and v4 are
in different components of H2,4 , and we have a case similar to the previous one.
The proof gives a simple (recursive) algorithm for 5-coloring a planar graph, the so-called
Heawood’s Algorithm.
6.2 The Davidson–Harel Algorithm
For the actual drawing of a graph we need to define the drawing area (the ”window”), i.e. a
rectangular area with sides parallel to the coordinate axes, the drawing curve of the edges (here
edges are drawn as line segments), and certain ”criteria of beauty”, so that the resulting drawing
is pleasant to the eye, balanced, and as clear as possible. Such ”beauty criteria” are of course
context-dependent and even matters of individual taste. In the sequel we restrict ourselves to
simple graphs, given by, say, an adjacency matrix or an all-vertex incidence matrix.
We will now present the so-called Davidson–Harel Algorithm4 which, applying an annealing algorithm, aims at better and better drawings of a graph using a certain ugliness function
(cf. Section 5.7). An ugliness function R computes a numerical ugliness value obtained from
a drawing P of a graph G. This value is a sum of various contributing factors. We denote, as
usual, the sets of vertices and edges of G by {v1 , . . . , vn } and {e1 , . . . , em }, respectively. We
also denote by vi the vector (or geometric point) corresponding to the vertex vi , and by ej the
line segment corresponding to the edge ej . Further, we denote
= kvi − vj k,
= distance of vi from the right border of the window,
= distance of vi from the left border of the window,
= distance of vi from the upper border of the window,
= distance of vi from the lower border of the window,
= length of the line segment ej ,
(
1, if the line segments ei and ej intersect without ei and ej being adjacent
fij =
0 otherwise,
(
distance of vi from the line segment ej if it exceeds γ and vi is not an end vertex of ej
gij =
γ otherwise.
dij
ri
li
ui
bi
cj
γ is a parameter of the algorithm telling how close to vertices edges can be. The ugliness
function is then given by
4
The original reference is DAVIDSON , R. & H AREL , D.: Drawing Graphs Nicely Using Simulated Annealing.
ACM Transactions on Graphics 15 (1996), 301–331.
CHAPTER 6. DRAWING GRAPHS
91
n−1 X
n
n m
X
X
X
1
1
1
1
1
R(P ) = λ1
+ λ2
+ 2 + 2 + 2 + λ3
c2j
2
2
d
r
l
u
b
i
i
i
i
i=1 j=i+1 ij
i=1
j=1
+ λ4
m−1
X
m
X
fij + λ5
i=1 j=i+1
n X
m
X
1
,
2
g
ij
i=1 j=1
where λ1 , . . . , λ5 are nonnegative-valued parameters weighting the contributions of the various
factors. (One could actually use negative values as well, whatever the interpretation then might
be.)
We can compute dij , . . . , gij quite easily using some basic formulae of vector geometry. We
must, however, think about the speed of the computation as well. One way to speed up the
computation is to use complex arithmetic. dij , . . . , gij are then equally easily computable.5 It
may also be of advantage to force the vertices into a lattice of geometric points. This can be
achieved for instance by rounding the coordinates (or complex numbers) to a fixed accuracy
and abandoning drawings where the ugliness function has the value ∞ (this happens e.g. when
vertices occupy the same point).
In the annealing process the state is P and the response is R(P ). An initial state can be
obtained by choosing the points v1 , . . . , vn in the window randomly, and then drawing the
edges accordingly. The state transition process P ← Aρ (P ) is the following:
• Choose a random vertex vi . (Alternatively the vertices may be circulated cyclically.)
• Draw a circle of radius ρ centered on vi . The radius ρ is a parameter, which is initially
large and gradually reduced later in some systematic fashion.
• Chose a random point u on this circle.
• If u is outside the drawing window, the state remains the same. Otherwise set vi ← u
and change the edges accordingly in the drawing.
The remaing parts of the algorithm are very similar to the annealing algorithm for the TSP in
Section 5.7.
Remark. This method has numerous variants. The window could be a circle and the edges
concentric arcs or radii. Or the window could be a sphere and edges drawn as arcs of great
circles. The window could also be unbounded, for instance, the whole of R2 . We could ”draw”
graphs three-dimensionally. Etc. We could also use a metric other than the Euclidean one when
computing distances, e.g. the Manhattan metric (”1-norm”) or the max-metric (”∞-norm”),
geodetic distances on a sphere, etc. Needless to say, the resulting drawings are rather different
using these variants of the algorithm.
It may be noted that using nearly any effective criteria, finding the optimally pleasing drawing of a simple graph is an N P-hard problem.
5
Note that if z1 = x1 + jy1 and z2 = x2 + jy2 , where j is the imaginary unit, then the
real part of z1 z2 equals
x1 x2 .
the dot product (x1 , y1 ) • (x2 , y2 ) and the imaginary part equals the determinant y1 y2 Chapter 7
MATROIDS
Many concepts in the preceding chapters do not so much deal with graphs themselves as their
structural properties. Examples are various dualities (cut set vs. circuit), principles behind certain algorithms (e.g. Kruskal’s Algorithms), and various extremality properties (many structures
are the ”smallest of their kind”, one cannot e.g. remove an edge of a cut set without it losing
this property).
Exactly corresponding structures were found in many other areas of mathematics, and they
were called matroids.1
7.1 Hereditary Systems
A hereditary family of sets is a family of sets such that whenever a set F is in the family then
so are all subsets of F (and in particular the empty set ∅). A hereditary system M of a set E
is a nonempty hereditary family IM of subsets of E. Included there are also the various ways
of specifying IM , called aspects. It will be assumed in what follows that E is a finite set. The
following nomenclature is traditional:
• Sets in the family IM are called independent sets of M.
• The family of subsets of E other than those in IM is denoted by DM and called the family
of dependent sets of M.
• An independent set is maximal if it is not a proper subset of another independent set. A
maximal independent set is called a basis. The family of all bases is denoted by BM . Note
that an independent set is always contained in a basis.
• A dependent set is minimal if no dependent set is its proper subset. A minimal dependent
set is called a circuit.2 (Recall that the empty set is always in IM .) The family of all
circuits is denoted by CM . Note that a dependent set always contains a circuit.
• A circuit consisting of only one element is a so-called loop. Elements of a circuit with
two elements are called parallel. A hereditary system is simple if it has no loops and no
parallel elements.
1
The remarkable thing is that many of these structures were found independently at the same time around the
year 1935: Hassler Whitney investigated planarity of graphs, Saunders MacLane geometric lattices of points, and
Bartel van der Waerden’s topic was independence in vector spaces.
2
This or any other ”familiar sounding” concept should not be confused with the corresponding concept for
graphs, even though there is a certain connection, as will be seen!
92
CHAPTER 7. MATROIDS
93
• The rank of a subset F of E is the largest size of an independent set contained in F .
(Recall that E is assumed to be finite.) Note that the empty set is always an independent
set contained in F . The rank of F is denoted by ρM (F ), and ρM is called the rank function
of M.
A notation similar to one used for graphs will be adopted in the sequel concerning adding
an element e to the set F (denoted by F + e) or removing it from F (denoted by F − e). Two
easy properties of the rank function are the following
Theorem 7.1. If M is a hereditary system of the set E then
(i) ρM (∅) = 0, and
(ii) for any subset F of E and any element e,
ρM (F ) ≤ ρM (F + e) ≤ ρM (F ) + 1.
Proof. Item (i) is clear, so let us move to item (ii).
Since F + e contains those independent sets that are contained in F , we have ρM (F + e) ≥
ρM (F ). On the other hand, possible independent subsets of F + e not contained in F may only
consist of an independent subset of F and e, so ρM (F + e) ≤ ρM (F ) + 1.
A hereditary system M may of course be specified by giving its independent sets, that is by
giving IM . It can be specified as well by giving its bases, i.e. BM , independent sets will then
be exactly all subsets of bases. On the other hand, M can be specified by giving its circuits,
i.e. CM , independent sets are then the sets not containg circuits. Finally, M can be defined by
giving the rank function ρM , since a set F is independent exactly when ρM (F ) = #(F ). (As
before, we denote cardinality of a set F by #(F ).) Thus an aspect may involve any of IM , BM ,
CM and ρM .
It might be mentioned that a hereditary system is a far too general concept to be of much
use. This means that well chosen aspects are needed to restrict the concept to a more useful one
(that is, a matroid). Let us have a look at certain proper aspects in connection with a matroid
well familiar from the preceding chapters.
7.2 The Circuit Matroid of a Graph
The circuit matroid M(G) of a graph G = (V, E) is a hereditary system of the edge set E
whose circuits are the circuits of G, considered as edge sets. (It is naturally assumed that G is
not empty.) The bases of M(G) are the maximal independent edge sets, i.e. spanning forests
of G, and the independent sets of M(G) are the subforests, both considered as edge sets. Let
us denote GF = (V, F ) for a subset F of E. The number of vertices of G is denoted by n, as
usual.
Remark. A hereditary system that is not directly a circuit matroid of any graph but has a
structure identical to one is called a graphic matroid.
Let us then take a look at different aspects of the circuit matroid.
CHAPTER 7. MATROIDS
94
Basis Exchange Property
Let us consider two bases (i.e. spanning forests) B1 and B2 . If e is an edge in B1 , its removal
divides some component G′ of the graph G into two disjoint subgraphs. Now certain edges of
B1 will be the branches of a spanning tree T1 of G′ , and similarly, certain edges in B2 will be
the branches of a spanning tree T2 of G′ . The removed edge e is either a branch of T2 or then a
link of T2∗ . In the latter case e will be in the fundamental cut set determined by a branch f of T2
(cf. Theorem 2.7). Then T1 − e + f is also a spanning tree of G′ and we can replace e by f and
get again a spanning forest of G, that is, a basis.
Hence we have
Basis Exchange Property: If B1 and B2 are different bases and e ∈ B1 − B2 then there is an
element f ∈ B2 − B1 such that B1 − e + f is a basis.
In general, a hereditary system with the basis exchange property will be a matroid. In other
words, the basis exchange property is a proper aspect. Using basis exchange one can move
from one basis to another. All bases are thus of the same size.
Uniformity. Absorptivity
For a subset F of E let us denote by nF the number of vertices in the subgraph hF i of G
induced by F , and by kF the number of its components. Then there are nF − kF edges in a
spanning forest of hF i. Let us denote further by KF the number of components of the subgraph
GF of G. Clearly then
ρM (G) (F ) = nF − kF = n − KF ,
and all such spanning forests are of the same size. Hence
Uniformity: For a subset F of E all maximal independent subsets of F are of the same size.
(Maximality of a set H means here that there are no independent sets J such that H ⊂ J ⊆ F .)
In general, a hereditary system with the uniformity property will be a matroid, and uniformity
is a proper aspect.
In the figure below continuous lines are the edges of F , with the thick ones being the
branches of a spanning forest. Dashed lines indicate the remaining edges in E.
f
e
If e is an edge of G and ρM (G) (F + e) = ρM (G) (F ) then e does not connect two components
of GF . Suppose f is another edge with the same property, that is, ρM (G) (F + f ) = ρM (G) (F ).
Clearly then
ρM (G) (F + e + f ) = ρM (G) (F ).
Thus we get
Weak Absorptivity: If e, f ∈ E and F ⊆ E and
ρM (F ) = ρM (F + e) = ρM (F + f )
CHAPTER 7. MATROIDS
95
then also
ρM (F + e + f ) = ρM (F ).
In general a weakly absorptive hereditary system is a matroid, and thus weak absorptivity is
another proper aspect.
By repeating the above argument sufficiently many times we see that if F and F ′ are sets of
edges of G, and for each edge e in F ′ we have ρM (G) (F + e) = ρM (G) (F ), then
ρM (G) (F ∪ F ′ ) = ρM (G) (F ).
Hence also
Strong Absorptivity: If F, F ′ ⊆ E and ρM (F + e) = ρM (F ) for each element e in F ′ then
ρM (F ∪ F ′ ) = ρM (F ).
We conclude that strong absorptivity is a proper aspect.
Augmentation
Suppose I1 and I2 are independent sets of the circuit matroid M(G) (edge sets of subforests
of G) and #(I1 ) < #(I2 ). The subgraph GI1 then has n − #(I1 ) components, and the subgraph
GI2 has n − #(I2 ) components, so strictly less than GI1 . Adding an edge does not reduce the
number of components exactly in the case where the edge is added in some component. Thus,
if adding any edge in I2 − I1 to GI1 preserves the number of components then it must be that
the edge is added in some component of GI1 , and GI2 cannot have fewer components than GI1 .
But as noted, this is not the case if #(I1 ) < #(I2 ), and so
Augmentation: If I1 and I2 are independent sets of the hereditary system M and #(I1 ) <
#(I2 ) then there exists an element e ∈ I2 − I1 such that I1 + e is in IM .
In general, a hereditary system with the augmentation property is a matroid. Thus augmentation
is a proper aspect, too.
Elimination
The circuits of the circuit matroid M(G) are the edge sets of the circuits of G. The degree
of a vertex in a circuit is two. If C1 and C2 are different circuits of M(G) then the degree of
a vertex of the ring sum hC1 i ⊕ hC2 i is also even, see Section 1.3. Hence hC1 i ⊕ hC2 i must
contain at least one circuit as a subgraph, since a ring sum does not have isolated vertices and
a nonempty forest has at least one pending vertex (Theorem 2.3). Recalling the definition of
ring sum in Section 1.3 it is noticed that such a circuit does not contain edges in the intersection
C1 ∩ C2 , at least not with as high multiplicity as in C1 ∪ C2 . Thus
Elimination Property: If C1 and C2 are different circuits of the hereditary system M and
e ∈ C1 ∩ C2 then there is a circuit C ∈ CM such that C ⊆ C1 ∪ C2 − e.
Again, elimination property is a proper aspect, and a hereditary system with the elimination
property is a matroid.
CHAPTER 7. MATROIDS
96
Induced Circuits
If I is an independent set of the circuit matroid M(G) (edge set of a subforest) then adding
one edge either closes exactly one circuit in a component of GI (Theorem 2.3), or then it connects two components of GI and does not create a circuit. We have then
Property of Induced Circuits: If I is an independent set of a hereditary system M and e ∈ E
then I + e contains at most one circuit.
The property of induced circuits is a proper aspect, and a hereditary system having this property
will be a matroid.
7.3 Other Basic Matroids
Vectorial Matroid
Let E be a finite set of vectors of a vector space (say Rn ) and the independent sets of a
hereditary system M of E be exactly all linearly independent subsets of E (including the empty
set). M is then a so-called vectorial matroid. Here E is usually allowed to be a multiset, i.e. its
elements have multiplicities—cf. parallel edges of graphs. It is then agreed, too, that a subset of
E is linearly dependent when one its elements has a multiplicity higher than one. A hereditary
system that is not directly vectorial but is structurally identical to a vectorial matroid M ′ is
called a linear matroid, and the matroid M ′ is called its representation.
A circuit of a vectorial matroid is a linearly dependent set C of vectors such that removing any of its elements leaves a linearly independent set—keeping in mind possible multiple elements. An aspect typical to vectorial matroids is the elimination property. If C1 =
{r, r1 , . . . , rk } and C2 = {r, r′1 , . . . , r′l } are different circuits sharing (at least) the vector r then
r can be represented as linear combinations of other vectors in both C1 and C2 , and in such a
way that all coefficients in the combinations are nonzero. We get thus an equality
k
X
i=1
ci r i −
l
X
c′j r′j = 0.
j=1
Combining (possible) repetitive vectors on the left hand side, and noticing that this does not
make it empty, we see that C1 ∪ C2 − r contains a circuit. (Note especially the case where either
C1 = {r, r} or C2 = {r, r}.)
In the special case where E consists of columns (or rows) of a matrix A, a vectorial matroid
of E is called a matrix matroid and denoted by M(A). For example, the circuit matroid M(G)
of a graph G is a linear matroid whose representation is obtained using the rows of the circuit
matrix of G in the binary field GF(2) (see Section 4.5).3 Of course, if desired, any vectorial
matroid of E may be considered as a matrix matroid simply by taking the vectors of E as
columns (or rows) of a matrix.4
3
Hereditary systems with a representation in the binary field GF(2) are called binary matroids. The circuit
matroid of a graph is thus always binary.
4
This actually is the origin of the name ”matroid”. A matroid is a generalization of a linear matroid and a linear
matroid may be thought of as a matrix. Indeed, not all matroids are linear. The name ”matroid” was strongly
opposed at one time. Even today there are people who prefer to use names like ”geometry” or ”combinatorial
geometry”.
CHAPTER 7. MATROIDS
97
Transversal Matroid
Let A = {A1 , . . . , Ak } be a family of nonempty finite sets. The transversal matroid M(A)
is a hereditary system of the set E = A1 ∪ · · · ∪ Ak whose independent sets are exactly all
subsets of E containing at most one element of each of the sets Ai (including the empty set).
Here it is customary to allow the family A to be a multiset, that is, a set Ai may appear several
times as its element, thus allowing more than one element of Ai in an independent set.
A natural aspect of transversal matroids is augmentation, and it is connected with augmentings of matchings of bipartite graphs! (See Section 5.8.) Let us define a bipartite graph
G = (V, E ′ ) as follows: The vertex set is V = E ∪ A, and the vertices e and Aj are connected
by an edge exactly when e ∈ Aj . (Note how the vertex set V is naturally divided into the two
parts of the cut, E and A.) An independent set of M(A) is then a set of matched vertices of G
in E, and vice versa.
Example. In the figure below is the bipartite graph corresponding to the transversal matroid
of the family {{1, 2}, {2, 3, 4}, {4, 5}}, and its independent set {1, 2, 4} (thick line).
1
2
3
4
{1,2}
{2,3,4}
{4,5}
5
Very much in the same way as in the proof of Theorem 5.3 one may show that if I1 and I2 are
independent sets (vertex sets of the matchings S1 and S2 ) and #(I1 ) < #(I2 ) then there is an
augmenting path of the matching S1 such that the new matched vertex is in I2 . Thus M(A)
indeed has the augmentation property.
Remark. For matchings of bipartite graphs the situation is completely general. That is, matchings of bipartite graphs can always be thought of as independent sets of transversal matroids.
In fact this remains true for matchings of general graphs, too, leading to the so-called matching
matroids, see e.g. S WAMY & T HULASIRAMAN .
If the sets of the family A are disjoint—i.e. they form a partition of E—then the transversal
matroid is also called partition matroid. For a partition matroid augmentation is obvious.
Uniform Matroid
For all finite sets E one can define the so-called uniform matroids. The uniform matroid of E
of rank k, denoted Uk (E), is a hereditary system whose independent sets are exactly all subsets
of E containing at most k elements. The bases of Uk (E) are those subsets containing exactly
k elements, and the circuits are the subsets containing exactly k + 1 elements. In particular, all
subsets of E form a uniform matroid of E of rank #(E), this is often called the free matroid of
E. Quite obviously Uk (E) has the basis exchange property and the augmentation property.
Uniform matroids are not very interesting as such. They can be used as ”building blocks”
of much more complicated matroids, however. It may also be noted that uniform matroids are
transversal matroids (can you see why?).
CHAPTER 7. MATROIDS
98
7.4 Greedy Algorithm
Many problems of combinatorial optimization5 may be thought of as finding a heaviest or a
lightest independent set of a hereditary system M of E, when each element of E is given a
weight. The weighting function is α : E → R and the weight of a set F ⊆ E is
X
α(e).
e∈F
The two optimization modes are interchanged when the signs of the weights are reversed.
One may also find the heaviest or the lightest bases. Again reversing the signs of the weights
interchanges maximization and minimization. If all bases are of the same size—as will be the
case for matroids—they can be restricted to the case where there weights are positive. Indeed,
if A is the smallest weight of an element of E then changing the weight function to
β : β(e) = 1 + α(e) − A
one gets an equivalent optimization problem with positive weights. On the other hand, maximization and minimization are interchanged when the weighting function is changed to
β : β(e) = 1 + B − α(e)
where B is the largest weight of an element of E.
Example. (A bit generalized) Kruskal’s Algorithm (see Section 5.6) finds a lightest spanning
forest of an edge-weighted graph G, i.e. a lightest basis of the circuit matroid of G. As was seen,
this can be done quite fast—and even faster if the edges are given in the order of increasing
weight when one can always consider the ”best” remaining edge to be included in the forest.
Kruskal’s Algorithm No. 1 is an example of a so-called greedy algorithm that always proceeds
in the ”best” available direction. Such a greedy algorithm is fast, indeed, it only needs to find
this ”best” element to be added in the set already constructed.
It might be mentioned that Kruskal’s Algorithm No. 3 is also a greedy algorithm, it finds a
heaviest cospanning forest in the dual matroid of the circuit matroid, the so-called bond matroid
of G (see Section 7.6).
Even though greedy algorithms produce the correct result for circuit matroids they do not
always do so.
Example. Finding a lightest Hamiltonian circuit of an edge-weighted graph G may also be
thought of as finding the lightest basis of a hereditary system—assuming of course that there
are Hamitonian circuits. The set E is again taken to be the edge set of G but now the bases
are the Hamiltonian circuits of G (considered as edge sets). A lightest basis is then a lightest Hamiltonian circuit. As was noticed in Section 5.7, finding a lightest Hamiltonian circuit
is a well-known N P-complete problem and no greedy algorithm can thus always produce a
(correct) result—at least if P =
6 N P. The hereditary system thus obtained is in general not a
matroid, however (e.g. it does not generally have the basis exchange property).
It would thus appear that—at least for matroids—greedy algorithms are favorable methods
for finding heaviest/lightest bases (or independent sets). Indeed, matroids are precisely those
hereditary systems for which this holds true. To be able to proceed further we define the greedy
algorithm formally. We consider first maximization of independent sets, minimization is given
in brackets. The input is a hereditary system M of the set E, and a weighting function α.
5
These problems are dealt with more extensively in the course Optimization Theory 2.
CHAPTER 7. MATROIDS
99
Greedy Algorithm for Independent Sets:
1. Sort the elements e1 , . . . , em of E according to decreasing [increasing] weight: e(1) , . . . ,
e(m) .
2. Set F ← ∅ and k ← 1.
3. If α(e(k) ) ≤ 0 [α(e(k) ) ≥ 0], return F and quit.
4. If α(e(k) ) > 0 [α(e(k) ) < 0] and F ∪ {e(k) } is independent, set F ← F ∪ {e(k) }.
5. If k = m, return F and quit. Else set k ← k + 1 and go to #3.
For bases the algorithm is even simpler:
Greedy Algorithm for Bases:
1. Sort the elements e1 , . . . , em of E according to decreasing [increasing] weight: e(1) , . . . ,
e(m) .
2. Set F ← ∅ and k ← 1.
3. If F ∪ {e(k) } is independent, set F ← F ∪ {e(k) }.
4. If k = m, return F and quit. Else set k ← k + 1 and go to #3.
The main result that links working of greedy algorithms and matroids is
Theorem 7.2. (Matroid Greediness Theorem) The greedy algorithm produces a correct heaviest independent set of a hereditary system for all weight functions if and only if the system is
a matroid. (This is the so-called greediness property.) The corresponding result holds true for
bases, and also for finding lightest independent sets and bases. Furthermore, in both cases it
suffices to consider positive weights.
Proof. The first sentence of the theorem is proved as part of the proof of Theorem 7.3 in the
next section.
As noted above, greediness is equivalent for maximization and minimization, for both independent sets and bases. It was also noted that finding a heaviest basis may be restricted to the
case of positive weights. Since for positive weights a heaviest independent set is automatically
a basis, greediness for bases follows from greediness for independent sets.
On the other hand, if greediness holds for bases, it holds for independent sets as well. Maximization of independent sets using the weight function α then corresponds to maximization of
bases for the positive weight function
β : β(e) = 1 + max(0, α(e)),
the greedy algorithms behave exactly similarly, item #3 is not activated for independent sets.
Elements of weight 1 should be removed from the output.
Remark. Greediness is thus also a proper aspect for matroids. For hereditary families of sets
it is equivalent to usefulness of the greedy algorithm. Certain other similar but more general
families of sets have their own ”greediness theorems”. Examples are the so-called greedoids
and matroid embeddings.
CHAPTER 7. MATROIDS
100
7.5 The General Matroid
Any one of the several aspects above makes a hereditary system a matroid. After proving that
they are all equivalent, we may define a matroid as a hereditary system that has (any) one of
these aspects.
Before that we add one aspect to the list, which is a bit more difficult to prove directly for
circuits matroids of graphs:
Submodularity: If M is a hereditary system of the set E and F, F ′ ⊆ E then
ρM (F ∩ F ′ ) + ρM (F ∪ F ′ ) ≤ ρM (F ) + ρM (F ′ ).
Let us then prove the equivalences, including submodularity.
Theorem 7.3. If a hereditary system has (any) one of the nine aspects below then it has them
all (and is a matroid).
(i)
(ii)
(iii)
(iv)
(v)
Uniformity
Basis exchange property
Augmentation property
Weak absorptivity
Strong absorptivity
(vi)
(vii)
(viii)
(ix)
Submodularity
Elimination property
Property of induced circuits
Greediness
Proof. The implications are proved following the strongly connected digraph below:
(i)
(ii)
(iii)
(viii)
(ix)
(iv)
(v)
(vi)
(vii)
All nine aspects are then connected by implication chains in both directions, and are thus logically equivalent. Let us consider a general hereditary system M of the set E.
(i)⇒(ii): As a consequence of uniformity, all bases of M are of the same size. If B1 , B2 ∈
BM and e ∈ B1 − B2 , we may apply uniformity to the set F = (B1 − e) ∪ B2 . All maximal
independent sets included in F are then of the same size as B2 (and B1 ). Now B1 − e is not
one of these maximal sets having too few elements. On the other hand, by adding one element
f to B1 − e we get such an independent set H. The element f must then be in the set difference
B2 − B1 , so H = B1 − e + f . Moreover, H has as many elements as B1 , and so it is a basis.
(ii)⇒(iii): If I1 , I2 ∈ IM and #(I1 ) < #(I2 ), we choose bases B1 and B2 such that I1 ⊆ B1
and I2 ⊆ B2 . Applying basis exchange (repeatedly) we replace those elements of B1 − I1 that
are not in B2 by elements of B2 . After this operation we may assume that B1 − I1 ⊆ B2 . As a
consequence of the basis exchange property all bases are of the same size. Thus
#(B1 − I1 ) = #(B1 ) − #(I1 ) > #(B2 ) − #(I2 ) = #(B2 − I2 ),
and B1 − I1 cannot be included in B2 − I2 . Therefore there is an element e of B1 − I1 in I2 and
I1 + e is an independent set.
CHAPTER 7. MATROIDS
101
(iii)⇒(iv): Let us consider a situation where
ρM (F ) = ρM (F + e) = ρM (F + f ).
If now ρM (F + e + f ) > ρM (F ), we take a maximal independent subset I1 of F and a maximal
inpendent subset I2 of F + e + f . Then #(I2 ) > #(I1 ) and by the augmentation property I1
can be augmented by an element of I2 . This element cannot be in F (why
√ not?), so it must be
either e or f . But then ρM (F ) < ρM (F + e) or ρM (F ) < ρM (F + f ) ( ).
(iv)⇒(v): Let us assume weak absorptivity and consider subsets F and F ′ of E such that
ρM (F + e) = ρM (F ) for each element e of F ′ . We use induction on k = #(F ′ − F ) and show
that ρM (F ) = ρM (F ∪ F ′ ) (strong absorptivity).
Induction Basis: Now k = 0 or k = 1 and the matter is clear.
Induction Hypothesis: The claimed result holds true when k ≤ ℓ. (ℓ ≥ 1)
Induction Statement: The claimed result holds true when k = ℓ + 1.
Induction Statement Proof: Choose distinct elements e, f ∈ F ′ − F and denote F ′′ = F ′ −
e − f . The Induction Hypothesis implies that
ρM (F ) = ρM (F ∪ F ′′ ) = ρM (F ∪ F ′′ + e) = ρM (F ∪ F ′′ + f ).
Applying weak absorptivity to this it is seen that
ρM (F ) = ρM (F ∪ F ′′ + e + f ) = ρM (F ∪ F ′ ).
(v)⇒(i): If I is a maximal independent subset of F then ρM (I+e) = ρM (I) for elements e in
the set difference F −I (if any). Strong absorptivity implies then that ρM (F ) = ρM (I) = #(I),
i.e. all these independent sets are of the same size and uniformity holds true.
(i)⇒(vi): Let us consider sets F, F ′ ⊆ E and denote by I1 a maximal independent subset of
the intersection F ∩ F ′ and by I2 a maximal inpendent subset of the union F ∪ F ′ . Uniformity
implies augmentation, so we may assume that I2 is obtained from I1 by adding elements, that
is I1 ⊆ I2 . Now I2 ∩ F is an independent subset of F and I2 ∩ F ′ is an independent subset of
F ′ , and both of them include I1 . So
ρM (F ∩ F ′ ) + ρM (F ∪ F ′ ) = #(I1 ) + #(I2 )
∗
= #(I2 ∩ F ) + #(I2 ∩ F ′ ) ≤ ρM (F ) + ρM (F ′ ).
The equality marked by an asterisk is a set-theoretical one, see the figure below.
F
I2
I1
I2
F
(vi)⇒(vii):Let us consider distinct circuits C1 , C2 ∈ CM and an element e ∈ C1 ∩ C2 . Then
ρM (C1 ) = #(C1 ) − 1 and ρM (C2 ) = #(C2 ) − 1, and ρM (C1 ∩ C2 ) = #(C1 ∩ C2 ). (Remember
that every proper subset of a circuit is independent.) If now C1 ∪C2 −e does not contain a circuit,
it is independent and ρM (C1 ∪C2 −e) = #(C1 ∪C2 )−1, whence ρM (C1 ∪C2 ) ≥ #(C1 ∪C2 )−1.
Submodularity however implies that
ρM (C1 ∩ C2 ) + ρM (C1 ∪ C2 ) ≤ ρM (C1 ) + ρM (C2 ),
CHAPTER 7. MATROIDS
102
and further that (check!)
#(C1 ∩ C2 ) + #(C1 ∪ C2 ) ≤ #(C1 ) + #(C2 ) − 1.
This is a set-theoretical impossibility, and thus C1 ∪ C2 − e does contain a circuit.
(vii)⇒(viii): If I is an independent set and I + e contains two distinct circuits C1 and C2
then obviously both C1 and C2 contain the element e. The elimination property implies that
C1 ∪ C2 − e contains a circuit. Since C1 ∪ C2 − e is however contained in I, it is independent
√
( ). So I + e contains at most one circuit.
(viii)⇒(ix): Let us denote by I the output of the greedy algorithm for the weighting function
α. (The problem is finding a heaviest independent set.) If I is a heaviest independent set, then
the matter is clear. Otherwise we take a heaviest independent set having the largest intersection
with I. Let us denote this heaviest independent set by I ′ . I cannot be a subset of I ′ , because the
greedy algorithm would then find an even heavier independent set. Let us further denote by e the
first element of the set difference I − I ′ that the greedy algorithm chooses. I ′ + e is a dependent
set and contains thus exactly one circuit C (remember the property of induced circuits). This
circuit of course is not included in I, so there is an element f ∈ C − I. Since I ′ + e contains
only one circuit, I ′ + e − f is an independent set. I ′ is maximal, so that α(f ) ≥ α(e). On the
other hand, f and those elements of I that the greedy algorithm chose before choosing e are all
in I ′ , whence adding f to the elements does not create a circuit. This means that f was available
for the greedy algorithm when it chose e, and so α(f ) ≤ α(e). We conclude that α(f ) = α(e)
and the sets I ′ + e − f and I ′ have equal weight. This however is contrary to the choice of I ′
because #((I ′ + e − f ) ∩ I) > #(I ′ ∩ I). (The reader may notice a similarity to the proof of
Theorem 5.2. Indeed, this gives another proof for Kruskal’s Algorithm No. 1.)
(ix)⇒(iii): Let us consider independent sets I1 and I2 such that #(I1 ) < #(I2 ). For brevity
we denote k = #(I1 ). Consider then the weighting function


k + 2, if e ∈ I1
α : α(e) = k + 1, if e ∈ I2 − I1


0 otherwise.
The weight of I2 is then
X
α(e) ≥ (k + 1)2 > k(k + 2) =
e∈I2
X
α(e).
e∈I1
It is thus larger than the weight of I1 , so I1 is not a heaviest independent set. On the other
hand, when finding a heaviest independent set the greedy algorithm will choose all elements of
I1 before it ever chooses an element of I2 − I1 . Since it is now assumed to produce a heaviest
independent set, it must choose at least one element e of I2 −I1 and I1 +e is thus an independent
set. This shows that the augmentation property holds true.
The most popular aspect defining a matroid is probably the augmentation property.
7.6 Operations on Matroids
In the preceding chapters, in connection with fundamental cut sets and fundamental circuits,
mutual duality was mentioned. Duality is a property that is very natural for hereditary systems
and matroids.
CHAPTER 7. MATROIDS
103
The dual (system) M ∗ of a hereditary system M of the set E is a hereditary system of E
whose bases are the complements of the bases of M (against E). Often the bases of M ∗ are
called cobases of M, circuits of M ∗ are called cocircuits of M, and so on. It is easily checked
that M ∗ really is a hereditary system of E: If B 1 and B 2 are distinct bases of M ∗ then B1 and
√
B2 are distinct bases of M. Thus, if B 1 ⊆ B 2 then B2 ⊆ B1 ( ). Note also that (M ∗ )∗ = M.
Theorem 7.4. (Whitney’s Theorem) The dual M ∗ of a matroid M is a matroid, the so-called
dual matroid, and
ρM ∗ (F ) = #(F ) − ρM (E) + ρM ( F ).
(Note that ρM (E) is the size of a basis of M.)
Proof. Let us show that M ∗ has the basis exchange property, which makes it a matroid according to Theorem 7.3. If B 1 and B 2 are distinct bases of M ∗ and e ∈ B 1 − B 2 then B1 and B2
are distinct bases of M and e ∈ B2 − B1 . Since B1 is a basis of M, B1 + e contains exactly
one circuit C of M (the property of induced circuits) and this circuit must have an element
f ∈ B2 − B1 . Then however B1 + e − f does not contain a circuit of M, i.e. it is an independent
set of M, and has the same size as B1 . All bases have the same size, so B1 + e − f is a basis of
M and its complement B 1 − e + f is a basis of M ∗ .
To compute the rank ρM ∗ (F ) we take a maximal independent set H of M ∗ included in F .
Then
ρM ∗ (F ) = ρM ∗ (H) = #(H).
Then H is a minimal set containing the set F and a basis of M. (This is simply the same
statement in other words. Note that H is included in some basis of M ∗ .) But such a set is
obtained starting from F , taking a maximal independent set of M contained in F —which has
ρM ( F ) elements—and extending it to a basis—which has ρM (E) elements. So
#( H ) − #( F ) = ρM (E) − ρM ( F ).
Set theory tells us that
#( H ) + #(H) = #(E) = #( F ) + #(F ).
Combining these we get the claimed formula for ρM ∗ (F ) (check!).
Dualism gives a connection between bases of a matroid M and circuits of its dual matroid
M ∗ (i.e. cocircuits of M):
Theorem 7.5. (i) Circuits of the dual matroid of a matroid M are the minimal sets that intersect
every basis of M.
(ii) Bases of a matroid M are the minimal sets that intersect every circuit of the dual matroid
M ∗.
Proof. (i) The circuits of M ∗ are the minimal sets that are not contained in any complement of
a basis of M. Thus they must intersect every basis of M.
(ii) Bases of M ∗ are the maximal sets that do not contain any circuit of M ∗ . The same in
other words: Bases of M are the minimal sets that intersect every circuit of M ∗ .
Example. Bases of the circuit matroid M(G) of a connected graph G are the spanning trees.
Bases of the dual matroid M ∗ (G) are the complements of these, i.e. the cospanning trees. By the
theorem, circuits of the dual matroid are the cut sets of G. (Cf. Theorems 2.4 and 2.5.) Because
according to Whitney’s Theorem M ∗ (G) is a matroid, it has the greediness property, that is, the
CHAPTER 7. MATROIDS
104
greedy algorithm finds a heaviest/lightest basis. Working of Kruskal’s Algorithm No. 3 is based
on this. The algorithm finds the heaviest cospanning tree.
Analogous concepts can naturally be defined for a general, possibly disconnected, graph G.
Bases of M ∗ (G) are then the cospanning forests of G. The dual matroid M ∗ (G) is called the
bond matroid or the cut matroid or the cocircuit matroid of G. So, when is the bond matroid
M ∗ (G) graphic, i.e. the circuit matroid of a graph? The so-called Whitney Planarity Theorem
tells us that this happens exactly when G is a planar graph! (See e.g. W EST.)
If Mi is a hereditary system of the set Ei for i = 1, . . . , k then the direct sum M = M1 ⊕
· · ·⊕Mk of the systems M1 , . . . , Mk is the hereditary system of the set E = E1 ∪· · ·∪Ek whose
independent sets are exactly all sets I1 ∪ · · · ∪ Ik where Ii ∈ IMi (i = 1, . . . , k). In particular,
if E1 = · · · = Ek = E then the direct sum M is called the union of the systems M1 , . . . , Mk ,
denoted by M = M1 ∪ · · · ∪ Mk . Note that each hereditary system Mi could also be thought of
as a hereditary system of the set E simply by adding elements of E − Ei as circuits (loops, that
is).
It is not exactly difficult to see that if M1 , . . . , Mk are matroids and the sets E1 , . . . , Ek are
pairwise disjoint then M = M1 ⊕· · ·⊕Mk is a matroid, say, by demonstrating the augmentation
property (try it!). But actually a more general result holds true:
Theorem 7.6. (Matroid Union Theorem6 ) If M1 . . . , Mk are matroids of the set E then the
union M = M1 ∪ · · · ∪ Mk is also a matroid of E and
k
X
′
′
#(F
−
F
)
+
ρ
(F
)
.
ρM : ρM (F ) = min
Mi
′
F ⊆F
i=1
Proof. The proof is rather long and difficult, and is not given here (see e.g. W EST or OXLEY.)
It might be mentioned, though, that the rank formula is not valid for hereditary systems in
general.
The theorem has many fundamental corollaries, e.g.
Corollary. (Matroid Covering Theorem7 ) If M is a loopless matroid of the set E then the
smallest number of independent sets whose union equals E is
#(F )
.
max
F ⊆E ρM (F )
Proof. Note first that since M is loopless, each element of E is in itself an independent set. The
set E thus can be covered as stated. Take now k copies of M as the matroids M1 , . . . , Mk in the
union theorem. Then E is a union of k independent sets of M exactly when it is an independent
set of the union matroid M ′ = M1 ∪ · · · ∪ Mk . The covering property we are interested in can
then be expressed in the form ρM ′ (E) = #(E) or, by the union theorem,
#(E) = min #(E − F ) +
F ⊆E
k
X
ρMi (F )
i=1
i.e.
min(kρM (F ) − #(F )) = 0.
F ⊆E
Since the difference to be minimized is = 0 when F is the empty set, k will be the smallest
number such that k ≥ #(F )/ρM (F ) for all nonempty subsets F ⊆ E.
6
7
Also known by the names Edmonds–Fulkerson Theorem and Matroid Sum Theorem.
Also known as Edmonds’ Covering Theorem.
CHAPTER 7. MATROIDS
105
Example. For the circuit matroid M(G) of a loopless graph G independent sets are the subforests of G, and we are interested in the minimum number of subforests needed to contain all
edges of G. Let us denote this number by A(G), it is called the arboricity of G.
To analyze the maximization in the covering theorem we divide the subgraph hF i induced
by the edges in F into its components. Numbers of vertices and edges of these components are
denoted by n1 , . . . , nkF and m1 , . . . , mkF , respectively. We use an indexing such that
mkF
mkF −1
m1
≥
≥ ··· ≥
.
nkF − 1
nkF −1 − 1
n1 − 1
Now, in general if
x2
x1
x2
x1 + x2
≥
then
≥
. Thus
y2
y1
y2
y1 + y2
m1 + m2
m2
≥
,
n2 − 1
n1 + n2 − 2
and continuing inductively, also
mi
m1 + · · · + mi
≥
ni − 1
n1 + · · · + ni − i
(i = 1, . . . , kF ).
In particular then
#(F )
m1 + · · · + mkF
mkF
=
≥
.
nkF − 1
n1 + · · · + nkF − kF
ρM (G) (F )
Maximization can thus be restricted to edge-sets F such that hF i is connected and ρM (G) (F ) =
nF − 1 where nF is the number of vertices of F . (It might be further restricted to edge-sets F
such that hF i also equals the subgraph induced by its vertices, since connecting two vertices by
an edge increases the numerator of the fraction to be maximized, the denominator remaining
the same.) Thus we get the celebrated Nash-Williams Formula for arboricity:
#(F )
.
A(G) = max
F ⊆E nF − 1
It might be noted that since for a simple planar graph #(F ) ≤ 3nF − 6 (Linear Bound
applied to hF i), A(G) is then at most 3.
The restriction of a hereditary system M of the set E into the set F ⊆ E is a hereditary
system M|F whose independent sets are exactly those subsets of F that are independent sets
of M. The contraction of M into the set F is the hereditary system (M ∗ |F )∗ , often denoted by
M.F . Clearly the augmentation property of M is directly transferred to M|F , so (cf. Whitney’s
Theorem)
Theorem 7.7. If M is a matroid of the set E and F ⊆ E then M|F and M.F are both matroids,
too.
The minors of a matroid M are all those matroids that can be obtained from M by consecutive
restrictions and contractions.
References
1. A NDRÁSFAI , B.: Introductory Graph Theory. The Institute of Physics (1978)
2. A NDRÁSFAI , B.: Graph Theory: Flows, Matrices. The Institute of Physics (1991)
3. BANG -J ENSEN , J. & G UTIN , G.: Digraphs: Theory, Algorithms and Applications. Springer–Verlag (2002)
4. B OLLOBÁS , B.: Modern Graph Theory. Springer–Verlag (2002)
5. C HRISTOFIDES , N.: Graph Theory. An Algorithmic Approach. Academic Press (1975)
6. D IESTEL , R.: Graph Theory. Springer–Verlag (2005)
7. D OLAN , A. & A LDOUS , J.: Networks and Algorithms. An Introductory Approach. Wiley
(1999)
8. G IBBONS , A.: Algorithmic Graph Theory. Cambridge University Press (1987)
9. G IBBONS , A. & RYTTER , W.: Efficient Parallel Algorithms. Cambridge University Press
(1990)
10. G ONDRAN , M. & M INOUX , M.: Graphs and Algorithms. Wiley (1986)
11. G RIMALDI , R.P.: Discrete and Combinatorial Mathematics. Addison–Wesley (2003)
12. G ROSS , J. & Y ELLEN , J.: Graph Theory and Its Applications. CRC Press (2006)
13. G ROSS , J. & Y ELLEN , J.: Handbook of Graph Theory. CRC Press (2003)
14. H OPCROFT, J.E. & U LLMAN , J.D.: Introduction to Automata Theory, Languages, and
Computation. Addison–Wesley (1979)
15. J UNGNICKEL , D.: Graphs, Networks and Algorithms. Springer–Verlag (2004)
16. M C E LIECE , R.J. & A SH , R.B. & A SH , C.: Introduction to Discrete Mathematics.
McGraw–Hill (1990)
17. M C H UGH , J.A.: Algorithmic Graph Theory. Prentice–Hall (1990)
18. M EHLHORN , K.: Graph Algorithms and NP-Completeness. Springer–Verlag (1984)
19. N OVAK , L. & G IBBONS , A.: Hybrid Graph Theory and Network Analysis. Cambridge
University Press (1999)
20. OXLEY, J.G.: Matroid Theory. Oxford University Press (2006)
106
107
21. R EAD , R.C. & W ILSON , R.J.: An Atlas of Graphs. Oxford University Press (2004)
22. S KIENA , S.S.: The Algorithm Design Manual. Springer–Verlag (1998)
23. S WAMY, M.N.S. & T HULASIRAMAN , K.: Graphs, Networks, and Algorithms. Wiley
(1981)
24. S WAMY, M.N.S. & T HULASIRAMAN , K.: Graphs: Theory and Algorithms. Wiley (1992)
25. VÁGÓ , I.: Graph Theory. Application to the Calculation of Electrical Networks. Elsevier
(1985)
26. WALTHER , H.: Ten Applications of Graph Theory. Kluwer (1985)
27. W EST, D.B.: Introduction to Graph Theory. Prentice–Hall (1996)
108
Index
across-quantity 43
across-source 43
across-vector 43
acyclic directed graph 32
adjacency matrix 34
adjacent edges 2
adjacent vertices 2
admittance matrix 46
all-vertec incidence matrix 34
alternating path 76
annealing algorithm 72,91
approximation algorithm 50
arboricity 105
arc 27
articulation vertex 14
aspect 92
augmentation 95,100
augmenting path 76,82
augmenting tree 77
back edge 54,56
basis 92
basis exchange property 94,100
BFS tree 59
big-O notation 50
binary matroid 96
bipartite graph 17,76,97
block 15
bond matroid 104
branch 21
Breadth-First Search 59
capacity 80
capacity constraint 80
chord 20
chromatic number 89
circuit 6,23,40,92
circuit matrix 40
circuit matroid 93,105
circuit space 49
clique 5
closed walk 6
cobasis 103
cocircuit 103
cocircuit matroid 104
coloring of a graph 89
complement of graph 10
complete bipartite graph 17
complete graph 3
component 7,28,43
computational complexity 50
condensed graph 28
connected digraph 28
connected graph 7
contracting of edge 13
contraction of matroid 105
cospanning tree 20
cross edge 56
cut 16
cut matrix 36
cut matroid 104
cut set 16,24,36
cut space 49
cut vertex 14
Davidson–Harel Algorithm 90
decision problem 50
degree of vertex 2
Demoucron’s Algorithm 87
Demoucron–Malgrange–Pertuiset Algorithm 87
dependent set 92
Depth-First Search 53
deterministic algorithm 50
DFS forest 57
DFS tree 54
difference of graphs 11
digraph 27
Dijkstra’s Algorithm 61
direct sum 104
directed edge 27
directed graph 27
directed spanning tree 31
directed tree 29
directed walk 27
dual hereditary system 103
dual matroid 102
edge 1
Edmonds Covering Theorem 104
Edmonds–Fulkerson Theorem 104
Edmonds–Karp Modification 84
elimination property 95,100
empty graph 2
end vertex 2
Euler’s Polyhedron Formula 86
Five-Color Theorem 89
flow 80
Floyd’s Algorithm 63
Ford–Fulkerson Algorithm 83
forest 20
forward edge 56
Four-Color Theorem 89
free matroid 97
fundamental circuit 23
109
fundamental circuit matrix 41
fundamental cut set 24
fundamental cut set matrix 39
fundamental equations 44
fundamental set of circuits 23
fundamental set of cut sets 24
graph 1
graphic matroid 93
greediness property 99,100
greedy algorithm 98
Hall’s Theorem 79
Hamiltonian circuit 61,98
Heawood’s Algorithm 90
Heawood’s Theorem 89
hereditary family 92
hereditary set 92
Hopcroft–Tarjan Algorithm 87
Hungarian Algorithm 77
Hungarian tree 77
impedance matrix 46
in-degree 27
incidence matrix 35
independent set 92
induced subgraph 5
intersection of graphs 11
intractable problem 51
isolated vertex 2
isomorphic graphs 18
Jarnik’s Algorithm 70
Karp–Held Heuristics 73
Kirchhoff’s Across-Quantity Law 43
Kirchhoff’s Flow Law 80
Kirchhoff’s Through-Quantity Law 43
Kruskal’s Algorithm 67,98,104
Kuratowski’s Theorem 87
labeled graph 18
labeling 18
Las Vegas algorithm 51
leaf 29
lightest Hamiltonian circuit 71
lightest path 61,63
lightest spanning tree 66
Linear Bound 86,105
linear matroid 96
link 21
loop 2,92
Marimont’s Algorithm 33
Marriage Theorem 79
matching 76,97
matrix matroid 96
matroid 100
Matroid Covering Theorem 104
Matroid Greediness Theorem 99
Matroid Sum Theorem 104
Matroid Union Theorem 104
Max-Flow Min-Cut Theorem 83
maximal matching 76
maximum degree 3
maximum matching 76,84
minimum degree 3
Minimum Degree Bound 87
minor 105
Monte Carlo algorithm 51
multiplicity 1,12
multiset 1
Nas–Williams Formula 105
N P 51
N P-complete 51,71
N P-hard 51,91
nondeterministic algorithm 50
null graph 2
nullity of graph 8
open walk 6 out-degree 27
P 51
parallel edges 2
parallel elements 92
partition matroid 97
path 6
pendant edge 2
pendant vertex 2
perfect matching 79
planae embedding 85
planar graph 85,104,105
polynmial time 51
polynomial space 51
potential vector 43
Prim’s Algorithm 70
probabilistic algorithm 51
proper difference 12
property of induced circuits 96,100
quasi-strongly connected digraph 29
rank function 93
rank of graph 8
rank of matroid 93
reachability matrix 52
reference vertex 35
region 85
removal of edge 13
removal of vertex 12
representation 96
restriction of matroid 105
ring sum of graphs 11,23
root 29
separable graph 14
110
short-circuiting of vertices 13
shortest path 61
simple graph 2
spanning tree 20
stationary linear network 43
stochastic algorithm 51
strong absorptivity 95,100
strongly connected 28
strongly connected component 28
subforest 20
subgraph 3
submodularity 100
subtree 20
symmetric difference 11
Tellegen’s Theorem 48
through-quantity 43
through-source 43
through-vector 43
topological sorting 32
tractable problem 51
trail 6
transport network 80
transversal matroid 97
Travelling Salesman’s Problem 71
tree 20,29
tree edge 54,56,59
trivial graph 2
underlying graph 27
uniform matroid 97
uniformity 94,100
union of graphs 11
union of matroids 104
vectorial matroid 96
vertex 1
walk 6
Warshall’s Algorithm 52
weak absorptivity 94,100
weights 18
Whitney’s Planarity Theorem 104
Whitney’s Theorem 103
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
