“We are integrators building
products for integrators.”
– Sean McDermott, CEO
Great design, integration, and excellence in manufacturing all play critical roles in creating Current Audio products.
Current Audio is backed by an award winning and inspiring team of seasoned designers, engineers, and installation experts,
holding title as CE Pro Top 100 Integrators with years of patented, custom audio product development, manufacturing and
experience.
You don’t have to go far to see how the electronics industry has changed over the last few
decades but what can we say about the actual speakers?
With decades of sales and installation know-how in the speaker business, as integrators we
understand the installers’ wants, needs, and struggles because we are installers ourselves.
Current Audio presents proven and innovative products that excel in quality and performance
which will save you time and money. We carefully listen to and respond to our customers’
suggestions and needs. The result of our listening has modeled a superior company and
product line.
Current Audio is holder of fifteen international pending patents. This is a true testament of our
determination to bring a fresh set of innovative ideas to what has become known as stagnant part of the industry.
Take part in this exciting, revolutionary time in the audio industry. Start impressing your clients with the crisp and clear sound
that is Current Audio. Call us today and Believe Your Ears™!
AMPLIFIER
Improve the quality of your whole house audio system with
powerful 2, 8 and 12 channel amplifiers that contain key
features like global and individual inputs that can be selected
per zone, Phoenix connectors which ensure reliable speaker
connection and independent gain control for each channel.
AMP1270
AMP870
AMP270
6 Zone,
12 Channel Amplifier
4 Zone,
8 Channel Amplifier
1 Zone,
2 Channel Amplifier
Continuous Power
Output BOTH channels
driven
70 Watts RMS at 4 ohms
50 Watts at 8 ohms
70 Watts RMS at 4 ohms
50 Watts at 8 ohms
70 Watts RMS at 4 ohms
50 Watts at 8 ohms
Bridged Power Output
BoTH channels driven
140 Watts per channel RMS at 8 ohms
140 Watts per channel RMS at 8 ohms
140 Watts per channel RMS at 8 ohms
Caution: Maintain an 8 ohm load in the
bridged mode
Caution: Maintain an 8 ohm load in the
bridged mode
Caution: Maintain an 8 ohm load in the
bridged mode
Input Sensitivity
500 millivolts
500 millivolts
500 millivolts
Input Impedance
20,000 ohms
20,000 ohms
20,000 ohms
Signal to Noise Ratio
95 dB
95 dB
95 dB
Frequency Response
20 Hz to 20 kHz
20 Hz to 20 kHz
20 Hz to 20 kHz
0.1% THD 20 Hz to 20 kHz
Total Harmonic
Distortion
(Unabridged or Bridged)
0.1% THD 20 Hz to 20 kHz
0.2% THD 20 Hz to 20 kHz
LENGTH x WIDTH x DEPTH
17” (431.8mm) x 4” (101.6mm) x 13”
(330.2mm)
17” (431.8mm) x 4” (101.6mm) x 13”
(330.2mm)
17” (431.8mm) x 4” (101.6mm) x 13”
(330.2mm)
Weight
32 lbs (14.6kgs)
25 lbs (11.4kgs)
18 lbs (8.2kgs)
FASTLOC
TM
Unique patent pending
mechanism allows for
quick installation
and removal
of the FastLocTM grille
Smallest exposed bezel
in the industry!
Disappears into the
mounting surface
FastLocTM grilles take only seconds to twist into place.
This allows for easy access to the installed speaker for
quick, custom positioning. Offering the smallest exposed
plastic bezel in the industry - virtually invisible!
STANDARD SPEAKER
FASTLOC SPEAKER
Available in:
FIT Series
CS Series
In-Wall Series
LCR Theater Series
SPA525
FIT SERIES
FIT Focused Image Technology™ Series
Patent-Pending Three-dimensional woofer positioning
Patent-Pending Diffractionless, pivoting tweeter
The only speaker with the Patent-Pending Positive Positioning Lock
Clear, undistorted sound where you want it, with deeper
room penetration
FIT804FL
FIT802FL
FIT801FL
FIT800FL
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
DRIVER
8” Woven Carbon Fiber Cone w/Butyl Rubber Surround
8” Aluminum Cone w/Butyl Rubber Surround
8” Injection Molded Carbon Fiber Cone w/Butyl Rubber Surround
8” MetaPlex™ Composite Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic
Coated Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
FREQ RESP
33Hz - 21kHz
35Hz - 20kHz
38Hz - 20kHz
40Hz - 20kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8 Ohms. Fixed Crossovers
POWER
5-150 Watts
5-150 Watts
5 - 150 Watts
5 - 125 Watts
SPL
91.5 db 1W/1m
91 db 1W/1m
90 db 1W/1m
89.5 db 1W/1m
DIAMETER x DEPTH
FIT series (Focused Image TechnologyTM) ceiling speakers incorporate a patent pending
design that allows for precise focusing of the acoustic image to the desired listening area.
No other manufacturer allows for the range of adjustability that this product offers. The
FIT series should be your first choice when purchasing home theater and distributed audio
speakers. The FIT speaker puts the sound where you want it, not where you place it.
FIT series speakers features include 3 position EQ switches, gold press terminals and
weatherized, perforated aluminum grilles. All Focused Image TechnologyTM speakers are
available in either FastLoc™ Grilles (Patent Pending) or standard press fit grilles.
Woofer. The Focused Image TechnologyTM series incorporates the patent-pending (positive positioning lock) or PPL. Once positioned, PPL allows for the
woofer to be securely locked into place. The patent pending locking feature consistently focuses all of the energy to your sweet spot. In addition, the
lock prevents the woofer assembly from moving and changing the sweet spot due to temperature and humidity variations. No other manufacturer in the
marketplace can offer this exclusive locking feature.
Tweeter. Not only is our patent-pending tweeter diffractionless, it’s also easily positioned to the sweet spot of the room allowing for a cleaner and
more natural sound.
FastLoc grille. The Focused Image TechnologyTM series are available with our patent-pending FastLocTM grilles. The look of these grilles have revolutionized the industry. They are extremely easy to install with consistent fit and finish. FastLocTM offers the industry’s smallest exposed bezel. The mechanism
that locks the grille in place is secure and vibration free.
FIT Series Speakers are available w/FastLoc™ or standard press fit grilles.
12 1/4” (311 mm) x 7 1/8” (182mm)
RETROFIT CUTOUT DIAMETER
10.437” (265mm)
FASTLOCTM GRILLE DIAMETER
13” (330mm)
BRACKET TYPE
NC8FITCB
FIT654/FIT654FL
FIT652/FIT652FL
FIT651/ FIT651FL
FIT650/FIT650FL
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
DRIVER
6.5” Woven Carbon Fiber Cone w/Butyl Rubber Surround
6.5” Aluminum Cone w/Butyl Rubber Surround
6.5” Injection Molded Carbon Fiber Cone w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm)
Ceramic Coated Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
FREQ RESP
35Hz - 21kHz
38Hz - 20kHz
40Hz - 20kHz
42Hz - 20kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8 Ohms. Fixed Crossovers
POWER
5 - 150 Watts
5 - 125 Watts
5 - 125 Watts
5 - 100 Watts
SPL
91.5 db 1W/1m
91 db 1W/1m
90 db 1W/1m
90 db 1W/1m
DIAMETER x DEPTH
Original Bezel - 9 7/8” (250mm) x 5 5/8”(144mm)
FastLocTM - 10 1/4” (260mm) x 5 5/8” (144mm)
RETROFIT CUTOUT DIAMETER
8 3/8” (213mm)
FASTLOCTM GRILLE DIAMETER
10 7/8 (276mm)
BRACKET TYPE
NC6CB
CS Series Ceiling Speakers
CS Series Speakers are available w/FastLoc™ or standard press fit grilles.
CS804/CS804FL
CS802/CS802FL
CS801/CS801FL
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
DRIVER
8” Woven Carbon Fiber Cone w/Butyl Rubber Surround
8” Aluminum Cone w/Butyl Rubber Surround
8” Injection Molded Carbon Fiber Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic Coated
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm)
Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum Ferrofluid Cooled
Dome
FREQ RESP
33Hz - 21kHz
35Hz - 20kHz
38Hz - 20kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
POWER
5 - 150 Watts
5 - 150 Watts
5 - 150 Watts
SPL
91.5 db 1W/1m
91 db 1W/1m
DIAMETER x DEPTH
90 db 1W/1m
Original Bezel - 11 3/64” (281mm) x 4 3/8” (111mm)
RETROFIT CUTOUT DIAMETER
9 5/8” (245mm)
FASTLOCTM GRILLE DIAMETER
13” (330mm)
BRACKET
The easy to install CS Series is a full range of in-ceiling loudspeakers that
incorporate high tech woofer materials with a butyl rubber surround and
state-of-the-art, 1” Patent-Pending diffractionless, pivoting, ferrofluid-cooled
dome tweeters. The CS Series is available with either the Patent-Pending
FastLoc™ or standard press fit grilles.
NC8CB
CS654/CS654FL
CS651/CS651FL
CS650/CS650FL
CS501
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
6.5” 2-way, in-ceiling,
coaxial, infinite baffle loudspeaker
5.25” 2-way, in-ceiling,
coaxial, infinite baffle loudspeaker
DRIVER
6.5” Woven Carbon Fiber Cone w/Butyl Rubber Surround
6.5” Injection Molded Carbon Fiber Cone w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
5.25” Injection Molded Graphite Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic
Coated Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum
Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk
Ferrofluid Cooled Dome
3/4” (19mm) Titanium Coated Polycarbonate Ferrofluid
Cooled Dome
FREQ RESP
35Hz - 21kHz
40Hz - 20kHz
42Hz - 20kHz
55Hz - 19kHz
IMPEDANCE
8, 6 or 4 Ohms dependant on driver EQ Setting
8, 6 or 4 Ohms dependant on driver EQ Setting
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
POWER
5 - 150 Watts
5 - 125 Watts
5 - 100 Watts
5 - 45 Watts
SPL
91.5 db 1W/1m
90 dB 1W/1m
90 db 1W/1m
89 db 1W/1m
DIAMETER x DEPTH
CS SERIES
FastLocTM - 12 1/4” (311mm) x 4 3/8” (111mm)
Original Bezel - 9 1/2” (241mm) x 3 7/8” (98mm)
FastLocTM - 10 1/4” (260mm) x 3 7/8” (98mm)
8” (203mm) x 3 1/4” (83mm)
RETROFIT CUTOUT DIAMETER
8 1/4” (210mm)
6 1/2” (165mm)
FASTLOCTM GRILLE DIAMETER
10 7/8 (276mm)
NA
NC6CB
NA
BRACKET
DIPOLE/BIPOLE SERIES
The Dipole/Bipole Series delivers a sound much like you’d
experience in a movie theater that has multiple surround
speakers. This dual-purpose speaker rolls both side
surround and surround back applications in one package,
with a switch on the tweeter bridge deciding functionality.
The dipole function sets tweeters out of phase to create a
null around the listening area that detunes the localization
for ambience, while the bipole functionality sets tweeters in
phase to enhance localization for Dolby Digital EX, DTS-ES,
THX-EX and Dolby True HD. Patent Pending FastLoc™ grilles
slip into place without magnets and offer the smallest exposed bezel on the market, seamlessly blending the speaker
into the ceiling.
CS Series Ceiling Speakers
CS654DBFL
CS650DBFL
6.5” 2-way, low profile
dipole/bipole, in-ceiling,
coaxial, infinite baffle
loudspeaker, w/fastloc™ grille
6.5” 2-way, low profile
dipole/bipole, in-ceiling,
coaxial, infinite baffle
loudspeaker, w/fastloc™ grille
DRIVER
6.5” Woven Carbon Fiber w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/Butyl Rubber Surround
TWEETER
Two 1” (25mm), Diffractionless Ceramic Coated Aluminum Ferrofluid
Cooled Dome
Two 1” (25mm), Diffractionless Dome Silk Ferrofluid Cooled Dome
FREQ RESP
35Hz - 21kHz
42Hz - 20kHz
IMPEDANCE
8 Ohms. Adjustable Tweeters, Selectable Dipole or Bipole
8 Ohms. Adjustable Tweeters, Selectable Dipole or Bipole
POWER
5 - 150 Watts
5 - 100 Watts
SPL
91.5 db 1W/1m
90dB 1W/1m
DIAMETER x DEPTH
10 1/4” (260mm) x 3 3/4” (95mm)
RETROFIT CUTOUT DIAMETER
8 3/8” (207mm)
FASTLOCTM GRILLE DIAMETER
10 7/8 (276mm)
BRACKET
CS654DBFL
CS Series Speakers are available w/FastLoc™
NC6CB
Dual Tweeter Series Ceiling Speakers
The easy to install Dual Tweeter Series is a full
range stereo ceiling loudspeaker in a single
speaker package, perfect for bathroom and
hallway applications where a pair of speakers
isn’t practical. The dual voice coil woofer offers
revolutionary natural sound for foreground and
background applications.
CS800DTFL
DUAL TWEETER SERIES
CS Series Speakers are available w/FastLoc™
CS800DTFL
CS650DTFL
8” 2-way low profile, in-ceiling,
coaxial, infinite baffle loudspeaker,
w/fastloc™ grille
6.5” 2-way, in-ceiling, coaxial, infinite baffle,
dual input stereo, single loudspeaker,
w/fastloc™ grille
DRIVER
8” Dual Voice Coil MetaPlex™ Composite w/Butyl Rubber Surround
6.5” Dual Voice Coil MetaPlex™ Composite Cone w/Butyl Rubber Surround
TWEETER
Dual 1” (25mm), Silk Ferrofluid Cooled Dome
Dual 1” (25mm) Silk Ferrofluid Cooled Dome
FREQ RESP
40Hz - 20kHz
42Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 Ohms. Fixed Crossovers
POWER
5 - 125 Watts
5 - 100 Watts
SPL
89.5 db 1W/1m
90 db 1W/1m
DIAMETER x DEPTH
12 1/4”(311mm) x 4 4/16”(112mm)
10 1/4” (259mm) X 3 3/4” (95mm)
RETROFIT CUTOUT DIAMETER
9 11/16” (246mm)
8 3/8” (213mm)
FASTLOCTM GRILLE DIAMETER
13” (330mm)
10 7/8 (276mm)
BRACKET
NC8CB
NC6CB
CECS65DT
CECS80DT
6.5” 2-way, in-ceiling, coaxial,
infinite baffle, dual input stereo,
single loudspeaker
8” 2-way, in-ceiling, coaxial,
infinite baffle, dual input stereo,
single loudspeaker
DRIVER
6.5” Dual Voice Coil, Talc Filled Polypropylene Cone w/Butyl Rubber Surround
8” Dual Voice Coil, Talc Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
Dual 3/4” (19mm) Silk Ferrofluid Cooled Dome
Dual 3/4” (19mm) Silk Ferrofluid Cooled Domes
FREQ RESP
55Hz - 19.5kHz
50Hz-19.5kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
8 ohms. Fixed Crossovers
POWER
5 - 55 Watts
5-60 Watts
SPL
88 db 1W/1m
88.5 db 1W/1m
DIAMETER x DEPTH
8 15/16” (227mm) x 2 7/8” (75mm)
10 11/16”(272mm) X 3 3/8”(85.7m)
RETROFIT CUTOUT DIAMETER
7 3/4” (197mm)
9 7/16” (240mm)
BRACKET
NC6CECB
NC8CB
WS Series Wall Speakers
The easy to install WS Series is a full range of in-wall loudspeakers that incorporate high tech woofer materials with a
butyl rubber surround and state-of-the-art, 1” Patent-Pending
diffractionless, pivoting, ferrofluid-cooled dome tweeters.
The WS Series is available with either FastLoc™ or standard
press fit grilles.
WS Series Speakers are available w/FastLoc™ or standard press fit grilles.
WS804/WS804FL
WS801/WS801FL
8” 2-way, in-wall,
full range loudspeaker
8” 2-way, in-wall,
full range loudspeaker
DRIVER
8” Woven Carbon Fiber Cone w/Butyl Rubber Surround
8” Injection Molded Carbon Fiber Cone w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic Coated Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum Ferrofluid Cooled Dome
FREQ RESP
33Hz - 21kHz
38Hz - 20kHz
8 or 6 Ohms dependant on driver EQ Setting
IMPEDANCE
POWER
SPL
5 - 150 Watts
91.5 db 1W/1m
LENGTH x WIDTH x DEPTH
90 db 1W/1m
Original Bezel - 14 13/16” (377mm) x 10” (254mm) x 3 3/4” (95mm)
13 9/16” (345mm) x 8 3/4” (233mm)
FASTLOCTM GRILLE LENGTH x WIDTH
16 5/16” (415mm) x 10 13/16” (274mm)
BRACKET
WS804
NC8WB
WS651/WS651FL
WS650/WS650FL
6.5” 2-way, in-wall,
full range loudspeaker
6.5” 2-way, in-wall,
full range loudspeaker
DRIVER
6.5” Injection Molded Carbon Fiber Cone w/Butyl Rubber Surround
6.5” MetaPlex™ Composite Cone w/ Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Aluminum Ferrofluid Cooled Dome
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk Ferrofluid Cooled Dome
FREQ RESP
40Hz - 20kHz
42Hz - 20kHz
IMPEDANCE
8 or 6 Ohms dependant on driver EQ Setting
8 Ohms. Fixed Crossover
POWER
5 - 125 Watts
SPL
IN-WALL SERIES
FastLocTM - 14 7/8” (378mm) x 10 1/8” (257mm) x 4 1/4” (107mm)
RETROFIT CUTOUT LENGTH x WIDTH
LENGTH x WIDTH x DEPTH
5 - 100 Watts
90 db 1W/1m
Original Bezel - 12 1/4” (310mm) x 8 5/32” (207mm) x 3 1/16” (78mm)
FastLocTM - 12 1/16” (310mm) x 8 3/16” (208mm) x 3 1/4” (83mm)
RETROFIT CUTOUT LENGTH x WIDTH
10 13/16” (270mm) x 6 3/4” (172mm)
FASTLOCTM GRILLE LENGTH x WIDTH
13 5/8” (346mm) x 8 7/8” (225mm)
BRACKET
NC6WB
WSLCRFL Series Wall Speakers
WSLCR654FL
WSLCR650FL
low profile, in-wall, coaxial,
infinite baffle loudspeaker,
w/fastloc™ grille
low profile, in-wall, coaxial,
infinite baffle loudspeaker,
w/fastloc™ grille
DRIVER
Two 6.5” Woven Carbon Fiber w/Butyl Rubber Surround
Two 6.5” MetaPlex™ Composite w/Butyl Rubber Surround
TWEETER
Patent Pending Pivoting, Diffractionless 1” (25mm) Ceramic
Coated Aluminum Ferrofluid Cooled
Patent Pending Pivoting, Diffractionless 1” (25mm) Silk Ferrofluid
Cooled Dome
FREQ RESP
35Hz - 21kHz
42Hz - 20kHz
IMPEDANCE
8 Ohms. Three Position Crossovers
8 Ohms. Fixed Crossover
POWER
5 - 150 Watts
5 - 100 Watts
SPL
91.5 dB 1W/1m
90 dB 1W/1m
WSLCR654FL
The easy to install LCR Theater Series are best in class in-wall
loudspeakers that incorporate high tech woofer materials
with a butyl rubber surround and state-of-the-art, 1” PatentPending diffractionless, pivoting, ferrofluid-cooled dome
tweeters, ensuring true left/center/right sound with flawless
imaging.
LCR THEATER
SERIES
WSLCR Series Speakers are available w/FastLoc™
LENGTH x WIDTH x
DEPTH
15 3/4” (401mm) x 8 15/16” (227mm) x 3 7/8” (98.6mm)
RETROFIT CUTOUT
LENGTH x WIDTH
14 1/5”(360.7mm) x 7 3/5”(193mm)
FASTLOCTM GRILLE
LENGTH x WIDTH
17” (432mm) x 9 5/8” (248mm)
BRACKET
NC6LCRWB
CECS SERIES
Built to install easily in both residential and commercial applications,
the CECS Series provides the best possible sound at a value price level.
Their talc filled polypropylene cone drivers, butyl rubber surrounds and
pivoting 5/8” polycarbonate, ferrofluid-cooled dome tweeters are sure
to outperform similar products at much higher price points.
CECS Series Ceiling Speakers
CECS80
CECS65
8” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
6.5” 2-way, in-ceiling, coaxial,
infinite baffle loudspeaker
DRIVER
8” Talc Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Talc Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
Pivoting 5/8” (16mm) Polycarbonate Ferrofluid Cooled Dome
5/8” (16mm) Polycarbonate Ferrofluid Cooled Dome
FREQ RESP
50Hz - 19.5kHz
55Hz-19.5kHz
IMPEDANCE
8 Ohms. Fixed Crossovers
POWER
5 - 60 Watts
5-55 Watts
SPL
88.5 db 1W/1m
88 db 1W/1m
DIAMETER x DEPTH
10 11/16” (272mm) x 3 3/8” (85.7mm)
8 15/16” (227mm) x 2 13/16” (72mm)
RETROFIT CUTOUT
DIAMETER
9 7/16” (240mm)
7 7/8” (200mm)
BRACKET
NC8CB
NC6CECB
PRO SERIES
SPA525FR
Whether you need speakers for a resort in Las Vegas, boardroom in New
York or a yoga studio in Northern California our Pro Series speaker line up
provides a best in class solution. These dynamic sounding speakers will
deliver improved low frequency response, higher highs and great mid range
in all applications. Our Pro Series speakers will enhance any project.
Pro Series
SPA525FR
CECS80-70V
5.25” low profile, UL listed,
in-ceiling, full range
loudspeaker, w/fastloc™ grille
8” 2-way, in-ceiling,
coaxial, infinite baffle loudspeaker
DRIVER
5.25” Paper Cone, Cloth Surround
8” Talc Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
NA
Pivoting 5/8” (16mm) Polycarbonate Ferrofluid Cooled Dome
FREQ RESP
75Hz-18kHz
50Hz-19.5kHz
IMPEDANCE
8 ohms
8 ohms. Fixed Crossovers
POWER
16 Watts Continuous & 32 Watts Program
5-85 Watts @ 8Ω
30-15-7.5 Watts @ 70Volts
SPL
83 dB 1W/1m
88.5 db 1W/1m
DIAMETER X DEPTH
9 3/4“ (248mm) x 4” (102mm)
10” (273mm) x 7 1/2” (190.5mm)
RETROFIT CUTOUT DIAMETER
8 15/16” (227mm)
9 7/16” (240mm)
BRACKET
NA
NC8CB
SUB801-70V
SUB801-70V
OC8B-70V
OC65B-70V
8” 8 ohm/70Volt, indoor/outdoor
in-ceiling subwoofer
8” 2-way indoor/outdoor,
full range loudspeaker
6.5” 2-way indoor/outdoor,
full range loudspeaker
DRIVER
8” Injection Molded Carbon Fiber w/Butyl Rubber Surround
8” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
NA
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
FREQ RESP
35Hz-300kHz
42Hz - 20kHz
47Hz - 20kHz
IMPEDANCE
8 ohms. Fixed Crossovers
8 ohms. Fixed Crossovers
8 ohms. Fixed Crossovers
POWER
5-150 Watts @ 8Ω
60-30-15 Watts @ 70Volts
5-150 Watts @ 8Ω
60-30-15 Watts @ 70Volts
5-125 Watts @ 8Ω
30-15 -7.5 Watts @ 70Volts
SPL
90db 1W/1m
90 db 1W/1m
90 db 1W/1m
DIAMETER X DEPTH
10” (273mm) x 7 1/2” (190.5mm)
16 1/2”(419mm) x 11”(279.4mm) x 10”(254mm)
12 1/8” (308mm) x 8 1/2” (216mm) x 8 1/8” (206mm)
RETROFIT CUTOUT DIAMETER
9 7/16” (240 mm)
NA
NA
SUBWOOFER
FL Series
FLSUB-10
10” floor subwoofer
The FL Series is a complete line of powered, front firing,
floor-standing subwoofers with both line level and speaker
level inputs. The slotted port helps the sub reproduce tight,
crisp bass, which is ideal for both movies and music.
*Pictured without grille. Includes cloth grille.
FLSUB-10
*Pictured without cloth grille.
AMPLIFIER
175 Watts, Line Level and Speaker Level Inputs, High Pass Filtered Line Level and Speaker Level
Outputs
DRIVER
10” Mica Treated Paper Pulp Cone w/Butyl Rubber Surround
CROSSOVER
25Hz - 250Hz - Variable
ADJUSTMENTS
Level, Crossover and Phase
OC65W
OR6G
Outdoor simulated rock speakers are ‘heard but not seen’ in outdoor
landscapes, resembling real rock right down to the grille. The single
stereo, standalone speaker is built with dual voice coils and tweeters to
deliver both left and right sound in one package — providing high fidelity sound required in outdoor environments. Encased in a totally weatherized material and offered in two colors, they can withstand sun, rain,
heat, cold, fog and coastal dew, even deterring theft via a threaded
insert for an eyebolt for added security.
OC Series Outdoor Speakers
OC8B
can be used as standalone subwoofer
OC65B/OC65W
OC525B/OC525W
8” 2-way indoor/outdoor,
full range loudspeaker
6.5” 2-way indoor/outdoor,
full range loudspeaker
5.25” 2-way indoor/outdoor,
full range loudspeaker
DRIVER
8” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
5.25” Mica Filled Polypropylene Cone w/Butyl Rubber Surround
TWEETER
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
1” (25mm) Titanium Ferrofluid Cooled Dome
FREQ RESP
42Hz - 20kHz
47Hz - 20kHz
52Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossovers
POWER
5 - 150 Watts
5 - 125 Watts
5 - 100 Watts
SPL
90 db 1W/1m
90 db 1W/1m
89 db 1W/1m
HEIGHT x WIDTH x DEPTH
16 1/2”(419mm) X 11”(279.4mm) X 10”(254mm)
12 1/8” (308mm) x 8 1/2” (216mm) x 8 1/8” (206mm)
9 7/8” (251mm) x 6 3/4” (171mm) x 6 1/4” (159mm)
OR Series Outdoor Rock Speakers
feature optional Granite or Sandstone colors
OR6S
OC8B
This dual-purpose loudspeaker series is the perfect choice for
main listening or sound reinforcement applications, with a
ported bass reflex that supplies serious sound. Graphite mica
filled polypropylene woofer cones and butyl rubber surround
are impervious to the weather and insects, and perforated
powder-coated aluminum alloy grilles are corrosion-resistant
and rustproof.
OUTDOOR
OR6G
OR6S
6.5” 2-way, outdoor rock speaker,
dual input stereo. Can be used as a single
stand alone or separates for true stereo
6.5” 2-way, outdoor rock speaker,
dual input stereo. Can be used as a single
stand alone or separates for true stereo
DRIVER
6.5” Mica Filled Polypropylene Cone w/Dual Voice Coil and Butyl
Rubber Surround
6.5” Mica Filled Polypropylene Cone w/Dual Voice Coil and Butyl
Rubber Surround
TWEETER
Dual 3/4” (19mm) Titanium Dome Tweeters
Dual 3/4” (19mm) Titanium Dome Tweeters
FREQ RESP
47Hz - 20kHz
47Hz - 20kHz
IMPEDANCE
8 Ohms. Fixed Crossover
8 Ohms. Fixed Crossover
POWER
5 - 125 Watts
5 - 125 Watts
SPL
88.5 db 1W/1m
88.5 db 1W/1m
HEIGHT x WIDTH x DEPTH
12” (304m) x 14” (356mm) x 11” (279mm)
12” (304m) x 14” (356mm) x 11” (279mm)
CS BACK CAN
LISTED
In-Line Surge Suppression
Why risk irreparable damage to your TV or other expensive equipment
when you can have the peace of mind that comes with installing the
ILS-120 in-line surge suppressor?
The ILS-120 a UL listed, first-in-class, in-line surge suppressor. It ensures
maximum protection against lightning, several types of power surges, and
fluctuations from in-home spikes. It absorbs harmful energy and safeguards your
investment. The ILS-120 has three auto reseting thermal fuses.
PROTECT
Easily replace any female IEC plug with an ILS-120 and your protection begins.
Give your customers a sense of security and add $100 profit to every install.
Power dissipation: 1575 joules.
SERVE
The Current Audio speaker Back Can is a housing system
designed as a multipurpose acoustic enclosure aid for the
installation of speakers.
ILS-120
It provides for sound attenuation migrating to adjacent
rooms. The housing focuses acoustic energy directly into the
room for maximum speaker performance. The enclosure has
a selectable slotted screw cover to chose between a sealed
or ported enclosure boost bass response.
LINE VOLTAGE
120 VAC,50/60Hz
MAX LOAD CAPACITY
10 amps
PROTECTION MODE
3-way line to ground, line to neutral, neutral to ground
POWER DISSAPTION
1575 joules
PEAK IMPULSE CURRENT
60,000 amps
UL RATING
UL 1449 Revision 3
TOTAL LENGTH
76.98” (6.5 feet)
A damping device reduces standing waves and mechanical
resonances plus enhances bass frequencies. It also serves to
prevent debris, rodent droppings and insects from entering
the speaker baffle that can alter the sound of the speaker.
The enclosure can also be used as a vapor barrier in some
instances, check your local building codes.
*Pictured with CS650DTFL
CS65BC
CS80BC
acoustical rear enclosure, ready to attach, comes complete with gold
constant tension binding posts, wiring and dacron damping material
acoustical rear enclosure, ready to attach, comes complete with gold constant
tension binding posts, wiring and dacron damping material
DIAMETER x DEPTH
8 1/10” (205mm) x 5 4/9” (138mm)
9 3/5” (244mm) x 7 1/10” (180mm)
SPEAKER CROSSREFERENCE
CS650, CS651, CS654, CS650FL, CS651FL, CS654FL, CS650DTFL,
CS650DBFL, CS654DBFL
CS804, CS802, CS801, CS804FL, CS802FL, CS801FL, CS800DTFL
*Fits speakers produced from November 2011 and later.
*Fits speakers produced from November 2011 and later.
ILS-PAC Power Adapter Cord
The Current Audio ILS-PAC is a special power adapter cord for
the ILS-120 Surge Protector. The purpose of the ILS-PAC is to
allow the ILS-120 Surge Protector to be used on slim line TVs
and other female 3-prong plugs that do not have a removable
power cord. You can also use it to take advantage of the unused
IEC outlets on the back of some PCs to power printers, monitors
and other 120VAC devices.
New Construction Brackets
NC6CB
NC8CB
NC8FITCB
NC6WB
NC8WB
NC6LCRWB
NC6CECB
TB6
TB8
Pre-wire prior to drywall,
new construction speaker
mounting brackets
SpeKap
Speaker Cap
SpeKap
- Breathable membrane insulation and debris speaker cap
The purpose of the patent-pending SpeKap is to solve the age
old problem of blown-in insulation and other debris from entering the backside of any speaker. Speaker operation can
be affected when insulation and items like rodent droppings
enter the baffle.
- Keeps insulation, debris, and rodent dropping out of the speaker.
SPEAKER CROSSREFERENCE
CS650, CS651, CS654,
CS654FL CS651FL, CS650FL,
CS654DBFL, CS650DBFL,
CS650DTFL, FIT654, FIT652,
FIT651, FIT650, FIT654FL,
FIT652FL, FIT651FL,
FIT650FL
CS804FL, CS802FL,
CS801FL, CS800DTFL,
CS804, CS802,
CS801, CECS80
FIT804FL, FIT802FL,
FIT801FL, FIT800FL
WS651FL,
WS650FL, WS651,
WS650
WS804FL, WS801FL,
WS804, WS801
WSLCR654FL,
WSLCR650FL
CECS65,
CS650DTFL,
CECS65DT
CS650, CS651, CS654,
CS650FL, CS651FL,
CS654FL, CECS65,
CECS65DT, CS650DTFL,
CS650DBFL, CS654DBFL,
FIT654, FIT652, FIT651,
FIT650,FIT654FL, FIT652FL,
FIT651FL, FIT650FL
CS804FL, CS802FL,
CS801FL, CS800DTFL,
CS804, CS802, CS801,
CECS80
- Fits most 5” to 8” in-ceiling and in-wall speakers
Droppings can make the speaker sound like a drum roll and
insulation can muffle and dampen the audio performance.
*IN-WALL SPEAKER
The SpeKap is a low-cost solution for this problem. It is easy to
install and does not affect speaker performance.
*IN-CEILING FIT SPEAKER
*CS SPEAKER
The Current Audio New Construction
Rough-in Bracket system is designed
as an aid for the installation of speakers
at a later date and as a place holder
for the installed speaker.
Wire Whisker Plate
WWP
The Current Audio WWP universal Wire Whisker Pass Through Plate allows
installers to offer a clean on wall wire management device. There is no need to
stock multiple plates and connectors for various wire feeds. The WWP does it all!
You have a choice of brush color - white or black. The WWP may be double or
triple ganged for larger wire feeds. Avalable in Black or White.
BRACKET
VOLUME CONTROL
ZLoc Volume Control
ZL45R
High quality stereo autoformer, multiple speaker
impedance matching, 12 step rotary knob, make before
break switching volume control
The Current Audio 4 position speaker selector allows you to connect and control up to 4 pairs of speakers. This unit can
be used in multi-room audio systems to control switching of the remote speakers. The unit has a 40W RMS power handling
capability per channel @ 8 ohms. The unit comes complete with an internal impedance protection circuit that is always
on to help prevent the amplifier from being overdriven. The convenient push to connect speaker terminals in the rear will
accept 14 AWG wire. The dimensions of the unit are 2” high x 8 5/8” wide x 4 2/5” deep.
TAPS
TRANSFORMER
R70VT
4PS
Multi-tap 70V to 8 ohm Transformer, 70 volt line common, mounts directly
onto CS650, CS651,CS652,CS654,CECS65 and CECS80 speakers
Four Pair Manual Stereo
Speaker Selector
70 Volt to 8 ohm, Color Coded Wattage Wire Taps
30 Watt, 16 Watt, 8 Watt, 4 Watt
PLATE STYLE
Decora
CONTROL SWITCH SILENT STEP
12-step rotary knob
FREQUENCY RESPONSE
20Hz-20kHz
POWER HANDLING
45 watt RMS
PAIRS OF SPEAKERS BY JUMPER POSITION
1-2-4-8
DEPTH BEHIND PLATE X HEIGHT
OF CIRCUIT BOARD
2.688” (6.8cm) X 2.87” (7.3cm)
POWER
40 Watts RMS @ 8 ohms
MAX WIRE GAUGE
10” Mica Treated Paper Pulp Cone w/Butyl Rubber Surround
Volume Control Faceplates
LENGTH x WIDTH x DEPTH (WEIGHT)
2“ (50mm) x 8 5/8“ (216mm) x 4 2/5“ (112mm) 1.8 lbs.
VCDII
VCDIA
VCDIB
Ivory
Almond
Black
SPEAKER SELECTOR
COLOR
Notes 1
1830 John Towers Avenue, El Cajon, CA 92020 • Sales 866-927-7181
©2012 Current Audio LLC, All product specifications are subject to change without notice.
www.currentaudio.com
Rev. PGv5_2012_0225
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
