KLC-106A
KLC-106A
GPS Vehicle Tracker
GPS Tracker,which set multiple functions of accurately positioning,security, monitoring
surveillance, emergency alarms and tracking in its entirety,special for vehicle. The product fully
supports the functions of SMS / GPRS / Internet data transmission,to make it more widely used in
large-scale monitoring, emergency scheduling, location-based services, traffic safety and many
other areas of management.It is based on GSM/GPRS(850/900/1800/1900MHZ)wireless
telecommunication internet and GPS satillite global position system,track by several ways.provide
monitor software and global map.real-time track through the monitor software in your pc;track
through your PDA cell phone and googleearth.
Features:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
GSM 850/900/1800/1900 MHZ
For vehicle (12V-24V), Location based service(LBS)
Support Camera& SD card,Support fuel sensor
Compatible with car original anti-theft alarm system
Real time tracking, voice listen in function
Remote shutdown vehicle engine and resume
Geo-fence, movement, overspeed, low batter alarm, link fuel and shock sensor, SOS alarm
SMS tracking on cellphone with google maps link
Aboslute address including street name by sms
Free PC based software for live tracking
Web based online tracking server
Multi area management
Automatic update positions of vehicle turns
Data logging
Forward third parties message to authorized phone number and charge inquiry
Configure parameters by USBLess GPRS traffic
ACC working alarm
GPS drift suppression
Movement alert
Door alarm
Support Fuel sensor(option)
Optional functions:
Quiver alarm
siren/horn
Fuel sensor alarm
Specifications:
Content
GSM Frequenccy
GPS Chips
GPRS GPS Sensitivity GPS Accuracy GSM Accuracy GPS center frequency Reacquisition
Cold Status
Warm Status Hot Status
Battery
Standby time
Dimensions
Weight
Storage Temperature
Working Temperature
Humidity
Voltage Current
Stuandy Average current
Specification
850/900/1800/1900MHz
SIRF Star III
Class 12, TCP/IP build in GSM Module
-159dBm
5m
50-200m
L1, 1575.42MHz
0.1s
<45s
<35s
<1s
Chargeable 3.7V 800mAh Li-ion battery
5 Hours
85(L)x71(W)x26(H)mm
170g
-40°C to +85° C
-20°C--+65°C
5%---95%RH
7--30v DC
60mA(12v DC) --35mA(24v DC)
<80MA
